Rosco Catalog #49

Rosco Catalog #49
This PDF contains interactive links. Click on product information to link
to the detailed information on the Rosco web page and click on the
Index and Table of Contents to go right to the product catalog page.
Table of Contents
Lighting and Projection Equipment
Filmmaking Tools
Belt Drive FX Rotators . . . . . . . . . . .3
Gear Drive Rotators . . . . . . . . . . . .4
Infinity . . . . . . . . . . . . . . . . . . . . .4
Bounce and Reflection . . . . . . . . .16
Light Control Filters . . . . . . . . . . .16
Keying Materials . . . . . . . . . . . . .17
DMX Iris . . . . . . . . . . . . . . . . . . .4
X24 X-Effects Projector . . . . . . . . .5
I-Cue Intelligent Mirror . . . . . . . . . .5
LitePad™ . . . . . . . . . . . . . . . . . . .6
Custom LitePad™ . . . . . . . . . . . . .6
LitePad™ Accessories . . . . . . . . .7–8
iPro™ Image Projector . . . . . . . . . .9
iPro™ Accessories . . . . . . . . . . . . .9
Scenic Paint and Coatings
Scenic Paints . . . . . . . . . . . . .18–19
Fluorescent Paints . . . . . . . . . . . .20
Brushes . . . . . . . . . . . . . . . . . . . .20
Coatings . . . . . . . . . . . . . . . . . . .21
Flame Retardants . . . . . . . . . . . . .21
Fog Products
Color and Correction Filters
Roscolux . . . . . . . . . . . . . . . . . . .10
E-Colour . . . . . . . . . . . . . . . . . . .10
Cinegel . . . . . . . . . . . . . . . . . . . .10
Specialized Filters . . . . . . . . . .10–11
RoscoShades . . . . . . . . . . . . . . . .17
RoscoView . . . . . . . . . . . . . . . . .17
Fog Machines . . . . . . . . . . . .22–23
Fog Fluids . . . . . . . . . . . . . . . . . .23
Dance and Performance Floors
Floors . . . . . . . . . . . . . . . . . .24–25
Floor Accessories . . . . . . . . . . . .26
Stage Hardware . . . . . . . . . . . . . .27–28
Color Filtration Products . . . . . . . . . .12
Gobos
Steel and Glass . . . . . . . . . . . . . .13
Holders . . . . . . . . . . . . . . . . . . . .14
Tapes . . . . . . . . . . . . . . . . . . . . . . . . .14
Candles . . . . . . . . . . . . . . . . . . . . . . .28
Connectors . . . . . . . . . . . . . . . . . . . .29
Scenic Materials . . . . . . . . . . . . .30–31
Index . . . . . . . . . . . . . . . . . . . . . .32–33
Projection Screens . . . . . . . . . . . . . .15
Please note: all prices are U.S. list prices.
Rosco is not responsible for errors or omissions.
Prices subject to change without notice.
Catalog 49 version 2
www.rosco.com
2
Lighting and Projection Equipment
RevoPRO™ Gobo Rotator
A dual programmable rotator which
includes complete DMX controlled
indexing features plus a stand-alone
programmable mode that requires no
DMX. Internal 100-240v mains power,
so no PSU is required. Like all Rosco Revo
rotators, it is built with a high temperature
silicon belt drive, stepper motors, a unique
threaded collar for easy installation of glass
or steel gobos, friction lock for secure
placement and dimmer control
capability.
RevoPRO™ Gobo Rotator $595.00
No. 205 64250 0000
SimpleSpin™ Dual Gobo Rotator
One stepper motor, two gobos, Rosco’s
SimpleSpin rotator is a variable speed
device capable of rotating two gobos in
opposing direction. A “set and forget”
on-board speed control and direction
switch is included, as is an internal
universal power supply at 100-240v,
50/60hz. The device can also be
controlled by connecting it to a dimmer. Like all Rosco Revo rotators, it is
built with a high temperature silicon
belt drive, a unique threaded collar for
easy installation of glass or steel gobos
and a friction lock for secure
placement.
SimpleSpin™ Dual Gobo Rotator $395.00
No. 205 63100 0000
REVO™ Dual Indexing Rotator
Two independent variable speed stepper
motors with 8 or 16-bit indexing on both
wheels provide maximum design flexibility.
Like all Rosco Revo rotators, it is built with
a high temperature silicon belt drive,
stepper motors, a unique threaded collar
for easy installation of glass or steel gobos,
friction lock for secure placement and
dimmer control capability.
REVO™ Dual Indexing Rotator $495.00
No. 205 64200 0000
Revo Rotator Accessories
PSU-50 $145.00
24v x 50 watt power supply
No. 205 71402 0050
PSU-200 $799.00
24v x 200 watt power supply
No. 205 71402 0200
4 Pin Extension Cable - 25' $57.00
No. 205 70002 0025
4 Pin Extension Cable - 50' $65.00
No. 205 70002 0050
www.rosco.com
3
Lighting and Projection Equipment
Vortex Gobo Rotator
The sleek unit houses two carefully
crafted drives. A single silent motor
drives both assemblies. Even at full
speed, the Vortex 360 Dual Rotator
is so quiet it can be used anywhere in a theatre or venue. The
Vortex 360 does not require any additional power supply. The
transformer/plug that comes with it can be plugged directly into
a wall outlet.
Vortex 360 Dual Rotator $435.00
No. 205 83000 0000
Double Gobo Rotator
Rosco’s Double Gobo Rotator allows
you to achieve kinetic and often spectacular lighting effects by rotating two
gobos in the same or opposite directions, at the same or varying speeds.
This unit requires a controller or MFX
Control Adaptor.
Double Gobo Rotator
DC Vari-Speed, 0-9 RPM $670.00
No. 205 21000 0120
Double Gobo Rotator Accessories
DMX/DC Controller
The Rosco DMX/DC Controller provides power and speed
control for the Double Gobo Rotator or other variable speed
effects. It is intended for remote control via a DMX512 signal.
The output circuitry of Rosco’s DMX/DC Controller is identical
to that of its four channel Variable Speed Controller. Speed,
range,bi-directional drive, load compensation and output
protection are all maintained.
DMX/DC Controller $655.00
No. 205 45000 0120
Variable Speed Controller
This four channel Variable Speed Controller is designed to
provide power, direction and speed control for variable speed
rotator units on four independent channels. Output connections
are made via four conductor cables terminating in two 4-pin
XLR connectors.
Four Channel Controller $600.00
No. 205 46000 0120
Single MFX Control Adaptor
(forward control only) $64.00
No. 205 47000 0120
Double MFX Control Adaptor
(offers control in opposing direction only) $72.00
No. 205 48000 0120
DMX Iris
Having complete control over the
beam spread of your leko just got
easier. The new Rosco DMX Iris is
quiet, dependable, affordable, and
a perfect complement to the I-Cue
Moving Mirror. This 24 leaf motorized iris unit can be used with your
ETC Source Four, Selecon Pacific or
most other modern lekos. Unlike
other iris units that have only 18 or
fewer leaves in the aperture, the
Rosco DMX Iris creates an even
edged, perfectly round aperture all the way down to its smallest
diameter. Using 1 channel of DMX512, the DMX Iris’s movement is smooth even along very slow cross fades. A microprocessor controlled stepper motor connects to the mechanical
arm of the iris unit, replacing the unreliable noisy chain drive
system found in other products. A manual knob lets you use the
DMX Iris without DMX control just by dialing in the aperture
size you want, just as you would a conventional iris unit. The
Rosco DMX Iris requires a non-dim circuit and is auto-sensing
from 100-240 volts for use anywhere in the world. No costly
external PSU is needed.
DMX Iris $495.00
No. 205 74500 0000
Infinity Gobo Animation Unit
The Infinity Gobo Animation Unit, which
can be attached to virtually any spotlight,
will accept an Infinity Disk. It is usually
used with a steel or glass gobo in the gate
to provide unusual kinetic effects. The
Infinity is equipped with onboard control
of the Infinity Disk speed and direction,
as well as an on/off switch. Supplied with
an adaptor plate and one Infinity Disk of
your choice.
Infinity $499.00
No. 205 82500 0000
Infinity Disks
Infinity disks are etched stainless steel disks powder coated to
prevent reflection. Eleven designs are available. The disks are
16.5"(42cm) in diameter.
Infinity Disks $99.00 each
30011 Tangential Breakup
30012 Radial Breakup
30013 Spiral Breakup
30014 Linear Breakup
30015 Triangle Breakup
30016 Cloud Breakup
30017 Elliptical Breakup
30018 Dot Breakup
30019 Flicker Breakup
30020 Coarse Radial Breakup
30021 Coarse Tangential
Breakup
DC Splitter Cable $48.00
No. 205 70001 0000
Mounting Kit for DC/DMX Controller and
a Variable Speed Controller $53.00
No. 205 70003 0KIT
www.rosco.com
4
Lighting and Projection Equipment
LitePad Axiom
X24 X-Effects Projector
This has become the projector of choice
for shows or installations requiring a fire
or water effect. It provides stunning rippling light effects previously unavailable
to designers. The projector is available
with on-board DMX for theatrical applications and in an analog
version for retail, museum or architectural applications.
X24 DMX X-Effects - Black (lens sold separately) $3,245.00
No. 205 37015 0120
X24 Analog X-Effects - Black (lens sold separately) $2,849.00
No. 205 37020 0120
X24 DMX X-Effects - White (lens sold separately) $3,245.00
No. 205 37025 0120
X24 Analog X-Effects - White (lens sold separately $2,849.00
No. 205 37030 0120
19 Degree Lens for X-Effects $150.00
No. 205 37119 0000
30 Degree Lens for X-Effects $150.00
No. 205 37130 0000
50 Degree Lens for X-Effects $150.00
No. 205 37150 0000
70 Degree Lens for X-Effects $150.00
No. 205 37170 0000
X24 Lamp – emARC SMR202/D1 $355.00
No. 205 36101 0000
X24 DMX Complete $3,395.00
X24 Analog Complete $2,999.00
I-Cue Intelligent Mirror
A spotlight attachment to re-position a
beam of light. This allows a single spotlight in a fixed position to be used for
multiple specials in dozens of locations.
Onboard DMX is included. A Power Supply Unit is necessary to get
24v DC to the I-Cue.
The LitePad Axiom range is a series of LED light sources
designed specifically for filmmakers, videographers and
photographers. The housing not only protects the light source, it
also provides a universal mounting system. This allows the
LitePad Axiom units to be affixed with brackets for C-Stands or
mounted with Velcro or other conventional methods. Each
product is available with either tungsten-level or daylight-level
output and with or without a transformer.
LitePad Axiom Daylight
LitePad Axiom 3" x 6" Daylight $195.00
No. 290 70306 0120
LitePad Axiom 3" x 12" Daylight $269.00
No. 290 70312 0120
LitePad Axiom 6" x 6" Daylight $269.00
No. 290 70606 0120
LitePad Axiom 6" x 12" Daylight $469.00
No. 290 70612 0120
LitePad Axiom 12" x 12" Daylight $599.00
No. 290 71212 0120
LitePad Axiom 24" x 24" Daylight $899.00
No. 290 72424 0120
LitePad Axiom Tungsten
LitePad Axiom 3" x 6" Tungsten $195.00
No. 290 80306 0120
LitePad Axiom 3" x 12" Tungsten $269.00
No. 290 80312 0120
LitePad Axiom 6" x 6" Tungsten $269.00
No. 290 80606 0120
LitePad Axiom 6" x 12" Tungsten $469.00
No. 290 80612 0120
LitePad Axiom 12" x 12" Tungsten $599.00
No. 290 81212 0120
LitePad Axiom 24" x 24" Tungsten $899.00
No. 290 82424 0120
I-Cue $695.00
No. 205 81000 0120
Power Supply Units
Rosco’s power supplies are compatible with
nearly all color scrollers, gobo rotators and other
accessory devices in common use. The PSU-200
has four outputs and four returns. It can be pipe
mounted with a C-Clamp or other hanging
device. PSU-51 has a DMX passthrough.
PSU-200 $799.00
No. 205 71402 0200
PSU-50 $145.00
No. 205 71402 005
PSU-51 $175.00
No. 205 71402 0051
PSU-200
www.rosco.com
5
Lighting and Projection Equipment
LitePad™ HO+
LitePad HO+ is a slim profile, edge-lit LED light source. At
only 1⁄3" thick, LitePad HO+ produces a soft quality of light that
is easy on the eyes and runs at cool temperatures. Available in
eight standard sizes, in either tungsten-level or daylight-level
outputs and with or without transformers.
LitePad HO+ Daylight
LitePad 3" x 6" HO+ Daylight $145.00
No. 290 40306 0120
LitePad 3" x 12" HO+ Daylight $219.00
No. 290 40312 0120
LitePad 6" x 6" HO+ Daylight $219.00
No. 290 40606 0120
LitePad 6" x 12" HO+ Daylight $419.00
No. 290 40612 0120
LitePad 12" x 12" HO+ Daylight $549.00
No. 290 41212 0120
LitePad 24" x 24" HO+ Daylight $825.00
No. 290 42424 0120
LitePad 3" Circle HO+ Daylight $89.00
No. 290 40003 0120
LitePad 12" Circle HO+ Daylight $525.00
No. 290 40012 0120
LitePad HO+ Tungsten
LitePad 3" x 6" HO+ Tungsten $145.00
No. 290 50306 0120
LitePad 3" x 12" HO+ Tungsten $219.00
No. 290 50312 0120
LitePad 6" x 6" HO+Tungsten $219.00
No. 290 50606 0120
LitePad 6" x 12" HO+ Tungsten $419.00
No. 290 50612 0120
LitePad 12" x 12" HO+ Tungsten $549.00
No. 290 51212 0120
LitePad 24" x 24" HO+ Tungsten $825.00
No. 290 52424 0120
LitePad 3" Circle HO+ Tungsten $89.00
No. 290 50003 0120
LitePad 12" Circle HO+ Tungsten $525.00
No. 290 50012 0120
LitePad™ DL
LitePad DL is a slim profile (1⁄3") light source that delivers soft,
even illumination in a sustainable, energy-efficient LED package, consuming about 40% less energy than LitePad HO+.
LitePad DL was designed with event planners, theatrical lighting
and architectural designers in mind, offering a more economical
lighting solution for these professionals. Available in six standard
sizes in daylight-level outputs and with or without transformers.
LitePad DL Daylight
LitePad 3" x 3" DL $49.00
No. 290 10303 0120
LitePad 3" x 6" DL $99.00
No. 290 10306 0120
LitePad 3" x 12" DL $150.00
No. 290 10312 0120
LitePad 6" x 6" DL $140.00
No. 290 10606 0120
LitePad 6" x 12" DL $325.00
No. 290 10612 0120
LitePad 12" x 12" DL $500.00
No. 290 11212 0120
Custom LitePad™
LitePad can be fashioned into virtually any two-dimensional
shape or size; up to 48" x 96" in a single piece or tiled together
for larger applications. Coupled with solution-based dimming
and power distribution, LitePad provides a complete lighting
solution for architectural, signage or decorative lighting projects.
LitePad HO+ is available in Tungsten and Daylight.
Rosco LitePads, plus decorative metal sheets and fabric cannage patterns,
brought Dior an amazing building awning and façade.
www.rosco.com
6
Lighting and Projection Equipment
LitePad™ Kits
Rosco offers four different kits for filmmakers, digital shooters
and still photographers. Each of the four is available with a full
complement of Axiom LitePads and the required accessories for
focusing, mounting, and coloring. Kits can be specified with
either daylight-level output LitePads or tungsten-level output.
A fifth kit, the HO+ Everywhere Kit, is equipped with both
tungsten and daylight level HO+ LitePads.
See the Rosco web site for details on what is in each kit.
LitePad Pro Gaffer’s Kit AX: Daylight $3,899.00
No. 290 240AXGKIT
LitePad Digital Shooters Kit AX: Daylight $2,999.00
No. 290 2400DSKIT
LitePad Quick Kit AX: Daylight $2,299.00
No. 290 240AXBKIT
LitePad Still Photo Kit AX: Daylight $899.00
No. 290 2400SPKIT
LitePad Pro Gaffer’s Kit AX: Tungsten $3,899.00
No. 290 241AXGKIT
LitePad Digital Shooters Kit AX: Tungsten $2,999.00
No. 290 2410DSKIT
LitePad Quick Kit AX: Tungsten $2,299.00
290 241AXBKIT
LitePad Still Photo Kit AX: Tungsten $899.00
290 2410SPKIT
LitePad HO+ Everywhere Lighting Kit $3,599.00
No. 290 2400ELKIT
LitePad™ Accessories
Accessories are generally included in the various LitePad kits,
but they are also available individually.
LitePad 1 amp Transformer - US style $15.00
No. 290 63501 0120
LitePad 3 amp Transformer $20.00
No. 290 63503 0120
LitePad 5 amp Transformer $30.00
No. 290 63505 0120
Car Adapter $25.00
No. 290 63600 0000
Y Splitter $20.00
No. 290 63700 0000
10 ft. Extension Cable $15.00
No. 290 63750 0000
4-Way Sputter $24.00
No. 290 63730 0000
AA Battery Holder $20.00
No. 290 63651 0812
4-Pin Adapter Cable $24.99
No. 290 63770 0012
Anton/Bauer Adapter $44.99
No. 290 63790 0012
Right Angle 10' Extension Cable $15.00
No. 290 63751 0000
LitePad 3" Mounting Bracket $24.99
No. 290 63900 0003
LitePad 6" Mounting Bracket $34.99
No. 290 63900 0006
LitePad 12" Mounting Bracket $44.99
No. 290 63900 0012
LitePad 24" Mounting Bracket $79.00
No. 290 63900 0024
1/4 – 20 Baby (5/8) Pin $6.00
No. 290 63910 1420
LitePad Axiom 1/4 – 20 Bracket $14.99
No. 290 63901 1420
LitePad Axiom Baby Pin Bracket $19.95
No. 290 63901 0058
LitePad Axiom 5/8 Receiver Bracket $44.99
No. 290 63901 0158
LitePad Axiom Wall Plate Bracket $39.99
No. 290 63901 0304
LitePad Axiom Battery Holder (for AA Battery) $14.99
No. 290 63901 8080
Digital Shooter LitePad Kit
3" x 6" Eggcrate $14.99
No. 290 65000 0306
3" x 12" Eggcrate $16.99
No. 290 65000 0312
6" x 6" Eggcrate $16.99
No. 290 65000 0606
6" x 12" Eggcrate $19.99
No. 290 65000 0612
12" x 12" Eggcrate $39.99
No. 290 65000 1212
24" x 24" Eggcrate $49.99
No. 290 65000 2424
www.rosco.com
7
Lighting and Projection Equipment
LitePad™ Accessories – continued
Single Fader Dimmer $125.00
No. 290 64000 0012
2CH/DMX Dimmer $299.00
No. 290 64100 0012
LitePad Light Stand $75.00
No. 290 66104 9089
LitePad Snake Arm $30.00
No. 290 66114 2002
LitePad Swivel Arm $35.00
No. 290 66158 1420
LightPad Cold Shoe Attachment $12.00
No. 290 66100 1420
3" Circle Medium Spot Lens $12.00
No. 290 67001 0003
3" x 6" Medium Spot Lens $12.00
No. 290 67001 0306
3" x 12" Medium Spot Lens $15.00
No. 290 67001 0312
6" x 6" Medium Spot Lens $15.00
No. 290 67001 0606
6" x 12" Medium Spot Lens $25.00
No. 290 67001 0612
12" x 12" Medium Spot Lens $45.00
No. 290 67001 1212
24" x 24" Medium Spot Lens $125.00
No. 290 67001 2424
12" Circle Medium Spot Lens $50.00
No. 290 67001 0012
3" Circle Full Spot Lens $22.00
No. 290 67002 0003
3" x 6" Full Spot Lens $22.00
No. 290 67002 0306
3" x 12" Full Spot Lens $29.00
No. 290 67002 0312
6" x 6" Full Spot Lens $29.00
No. 290 67002 0606
6" x 12" Full Spot Lens $49.00
No. 290 67002 0612
12" x 12" Full Spot Lens $89.00
No. 290 67002 1212
24" x 24" Full Spot Lens $249.00
No. 290 67002 2424
12" Circle Full Spot Lens $99.00
No. 290 67002 0012
LitePad™ Accessories – continued
Digital Shooter LitePad Case $625.00
No. 290 63860 0000
Still Photo LitePad Case $250.00
No. 290 63870 0000
Gaffer’s AX LitePad Case $625.00
No. 290 63851 0000
Quick AX LitePad Case $550.00
No. 290 63855 0000
24" x 24" LitePad Case $249.00
No. 290 63880 0000
3" x 6" Axiom Housing $50.00
No. 290 69999 0306
3" x 12" Axiom Housing $50.00
No. 290 69999 0312
6" x 6" Axiom Housing $50.00
No. 290 69999 0606
6" x 12" Axiom Housing $50.00
No. 290 69999 0612
12" x 12" Axiom Housing $50.00
No. 290 69999 1212
24" x 24" Axiom Housing $74.00
No. 290 69999 2424
LitePad accessory: Full Spot Lens
LitePad accessory: Swivel Arm
www.rosco.com
8
Projection Equipment
iPro™ Image Projector
The iPro fits as an accessory into the
iris slot of a typical ETC Source Four,
Altman Shakespeare, Strand SL or
Selecon Pacific light fixture. Fitted with
an iPro Slide, the iPro™ delivers
bright, visible full-color images that
will last between 15 and 50 hours.
iPro™ Slide Library
Designed specifically for the iPro, Rosco offers images in a wide
range of categories that are certain to suit your needs for most
theatrical productions and live entertainment events.
iPro Slide-Library Image $39.00
iPro Image Projector $295.00
No. 265 25100 0120
iPro™ Slide Film
For use with the Rosco iPro, iPro Slide
Film has been formulated from the
ground up to produce the highest
quality iPro Slide possible.
iPro Slide Film—10 sheet pack (LTR Size) $33.00
No. 265 27995 0010
iPro Slide Film—25 sheet pack (LTR Size) $67.50
No. 265 27995 0025
iPro Printing Pack
Contains 10 sheets of iPro Slide Film and
10 One-Time iPro Slide Mount $225.00
No. 265 27985 0010
Custom iPro™ Slide
iPro™ One-Time Slide Mount
Contains the slide mount and protective film necessary to make
an effective iPro Slide. Using your own transparency film and
your own printer to create the image, you can then
assemble a finished iPro Slide. Transparency film not included.
Virtually any design you can create on your computer can be
made into a Custom iPro Slide in just one day. Using Adobe
Photoshop or similar software, prepare your design and send it
to Rosco at [email protected] Within 24 hours, your
finished assembled iPro slide will be on its way back to you.
Custom iPro Slide $39.00
No. 265 27000 0860
iPro Slide Mount $29.00
No. 265 27999 0860
Hybrid Two-Fer
This accessory allows you to
connect the iPro and your light
fixture into the same dimmer. The
two-fer is configured with a male
stage-pin connector for the dimmer
and both a female stage pin connector for the light and a female
parallel blade connector for the iPro.
Hybrid Two-Fer $54.95
No. 265 25500 0000
www.rosco.com
9
Color and Correction Filters
PROTECTIVE FILTERS
Roscolux
Thermashield
Roscolux is the most widely used
color filter range for theatre, film,
television, live entertainment and
architectural applications. For a
detailed list of the colors and
diffusers of the range consult the
Roscolux swatchbook or Rosco
web site.
When used in conjunction with Roscolux or Cinegel color
filters, Thermashield prevents the color filters from absorbing IR
energy as heat, thus allowing the filters to last much longer.
Thermashield 12" x 12" $29.00
No. 101 01995 1212
Thermashield 20" x 24" $59.00
No. 101 01995 2024
Thermashield 48" x 48" $239.00
No. 101 01995 4804
Roscolux Sheets 20" x 24" $8.25
Rolls 24" x 25' $117.00
E-Colour
Super Heat Shield™
A comprehensive range of
European color and correction
filters based on the Cinemoid™
system. For a detailed list of
colors, diffusers and reflection
materials consult the E-Colour
swatch book or the Rosco web site.
Super Heat Shield is a heat resistant plastic that acts as a barrier,
blocking the heat of a fixture. For maximum efficiency, a
minimum 1" air space must be maintained between Super
Heat Shield and the color filter.
Super Heat Shield 20" x 24" sheet $13.75
No. 101 01991 2024
Super Heat Shield 24" x 25' roll $169.95
No. 101 01991 2425
Super Heat Shield 24" x 50' roll $329.50
No. 101 01991 2450
Super Heat Shield 48" x 25' roll $329.50
No. 101 01991 4825
E-Colour Sheets 21" x 24" $7.60
E-Colour Rolls 48" x 25' $165.00
Cinegel
The Academy Award winning
range of color and correction filters, Cinegel includes diffusers,
reflectors and the Storaro Selection and CalColor filters. For a
detailed list of products, consult
the Cinegel swatch book or the
Rosco web site.
®
Cinegel Sheets 20" x 24"
Cinegel Rolls $175.00
(Most rolls are 48" x 25'. )
UV Filter™
Rosco UV Filter effectively extends the life of your color filter by
absorbing the damaging ultraviolet energy that can prematurely
fade dyes.
$8.25
UV Filter 20" x 24" sheet $8.25
No. 101 03114 2024
UV Filter 24" x 50' roll $175.00
No. 101 03114 2450
UV Filter 48" x 25' roll $175.00
No. 101 03114 4825
DichroFilm™
DichroFilm combines the flexibility, light weight and safe characteristics of a plastic gel with the longevity and heat resistance
of a dichroic filter. Manufactured on 5-mil thick hi-temp plastic,
DichroFilm will outlast any ordinary plastic filter. It is ideal for
permanent installations where a flexible filter is required or
where installing glass could pose a safety hazard.
Standard Colors
Primary Blue
CTB Daylight
CTO Tungsten
Indigo
Magenta
Primary Green
Yellow
Cyan
Orange
Red
Sizes
No. 106 09108
No. 106 09320
No. 106 09340
No. 106 09460
No. 106 09476
No. 106 09520
No. 106 09550
No. 106 09559
No. 106 09590
No. 106 09650
25" x 25"
10" x 10"
7.5" x 7.5"
6" x 6"
$475.00
135.00
60.00
35.00
Safety Frames™
For use with Roscolux, Cinegel or E-Colour gel filters. Made
from FRP, an Underwriter’s Laboratories approved flame retardant fiberboard. The material remains cool for safe handling
and has a UL94 Flammability Classification of 94V-0.
No. 110 08600
Add to
Product No.
0750
0975
0625
Frame
Size
71⁄2"
93⁄4"
61⁄4"
Lens
Size
57⁄8"
73⁄4"
5"
www.rosco.com
3.85
5.50
3.50
10
Color and Correction Filters
Color Effects Kit
Permacolor Dichroic Glass Filters
The fifteen color effects filters in this kit are the most popular
selections from the 300-plus colors that Rosco produces for
theatre, film and television. Available either 10" x 12" in a
durable plastic pouch, or 20" x 24" in a convenient tube.
Color Effects Kit 10" x 12"
No. 110 09040 SKIT
Color Effects Kit 20" x 24"
No. 110 09040 LKIT
$38.30
$98.50
Color Correction Kit
This kit permits the color correction of virtually all mixed-light
sources found on location. There are sixteen materials, including a range of blue and amber color correction filters, along with
a selection of green and magenta color compensating filters.
Available either 10" x 12" in a durable plastic pouch,
or 20" x 24" in a convenient tube.
Color Correction Kit 10" x 12"
No. 110 09030 SKIT
Color Correction Kit 20" x 24"
No. 110 09030 LKIT
$38.30
$98.50
Cinegel Sampler Kit
This is an all-purpose selection of the most popular Cinegel
products. There are fifteen light control materials, including diffusion, reflection, color effects filters and color correction filters.
Available either 10" x 12" in a durable plastic pouch,
or 20" x 24" in a convenient tube.
Cinegel Sampler Kit 10" x 12"
No. 110 09010 SKIT
Cinegel Sampler Kit 20" x 24"
No. 110 09010 LKIT
$38.30
$98.50
CalColor Kit
The CalColor Kit consists of 10" x 12" sheets of the 32 colors in
the CalColor range.
CalColor Kit 10" x 12"
No. 110 04000 0KIT
$54.70
Diffusion Kit
Diffusion materials help modify the harsh character of a light
source by softening the beam and the resulting shadows. The
fifteen materials included in this kit offer a range of diffusion effects, from slight to dense, for dealing with a variety of light
sources and situations. Available either 10" x 12" in a durable
plastic pouch, or 20" x 24" in a convenient tube.
Diffusion Kit 10" x 12"
No. 110 09020 SKIT
Diffusion Kit 20" x 24"
No. 110 09020 LKIT
$38.30
$98.50
Rosco Permacolor dichroic glass filters are the perfect choice for
designers requiring long-lasting, high-quality filters. Permacolor
withstands the heat of high temperature lighting fixtures like
MR16, metal halide discharge, and high wattage tungsten lamps
and are ideal for use in permanent installations.
Rosco’s range of standard colors includes the bright saturated
colors prone to premature fading in gel as well as a selection of
pale tints and accent colors selected by leading architectural
designers around the world.
Color
Primary Red
Primary Blue
Flame Red
Bastard Amber
Amber Blush
Bright Straw
Goldenrod
Yellow
Amber
Medium Orange
Orange
Light Pink
Pale Pink
Medium Pink
Hot Pink
Deep Magenta
Vivid Magenta
Lavendar
Purple Fusion
Lavender Accent
Lilac
No.
36500
31080
36100
31002
31018
31012
31013
35200
35401
35600
35900
31033
31337
34758
34630
34763
34640
34965
31048
31054
31055
Color
Booster Blue
Mediterranean Blue
Sea Blue
Cyan
Sky Blue
Light Blue Green
Medium Red Blue
Deep Purple
Peacock Blue
Turquoise
Industrial Green
Light Yellow Green
Fern Green
Primary Green
Mauve
Indigo
Gaslight Green
Lavender 57
Light Green Blue
Victorian Gold
No.
31062
31065
35700
35590
35400
35100
34600
34200
31073
34853
31086
34959
35156
35055
31050
31059
33388
31057
31076
33114
Color
CTO
1
⁄2 CTO
3
⁄4 CTO
1
⁄4 CTO
1
⁄8 CTO
ND .3
ND .15
ND .6
1
⁄2 Minus Green
1
⁄4 Minus Green
No.
43407
43408
43411
43409
43410
43402
43415
43403
43313
43314
Color
1
⁄8 Minus Green
3
⁄4 CTB
1
⁄4 CTB
1
⁄2 CTB
CTB
Double Coated
UV Pass
IR/UV Block
White Diffusion
No.
43318
43203
43208
43204
43202
Size
Suffix
2" x 2" (51 mm x 51 mm)
7508
1.95" round (49.5 mm)
7495
5.25" (133 mm) round
7133
6.3" (160 mm) round
7160
8.25" (209 mm) round
7209
13.5" (343 mm) round
7343
Custom sizes available, call for pricing.
33660
38000
43026
Price
$ 8.95
8.95
57.75
69.75
142.50
235.00
Permacolor Technical Coatings
IR/UV Filter (Hot Mirror)
POA
No. 120 38000
A clear glass filter, IR/UV is designed to pass visible light while
reflecting both infrared (700nm – 1200nm) and near UV energy
(325nm – 400nm).
UV Blocking Filter
POA
No. 120 34000
Rosco’s UV Blocking Filter offers more complete filtration of
ultraviolet energy, blocking wavelengths from 250nm to 400nm.
www.rosco.com
11
Color and Correction Filters
Permacolor Frames
(Safety Grid Included)
Permacolor Frame 6.25" $17.00
No. 97625
Permacolor Frame 7.5" x 7.5" $18.25
No. 97750
Permacolor Frame 10" x 10" $23.00
No. 97100
MR-16 Filter Holder
A simple solution for adding color filters or patterned glass to
your MR-16 lamps.
MR-16 Filter Holder $4.00
No. 120 97195 0000
LED Channel Mount
Rosco’s LED Channel
Mount Kit allows designers
to add Rosco color and
diffusion filters to LED tape
or ribbon, and package it in
an elegant and practical
housing. The Kit consists of
a 72” long extruded
aluminum heat-sink, a clear
plastic cover, three mounting clips and end caps. Four Rosco
color filters are available, cut-to-size, for individual sale. All
other Rosco color filters are available, cut-to-size, in lots of 20.
LED Channel Mount - 6ft (1.8m) Kit Complete
$96.95
No. 295610000072
LED Channel Mount - Adjustable Bracket Complete
$35.00
No. 295611010003
LED CM Diffusion - Tough Rolux - 17⁄16in (3.6cm) x 6ft (1.8m) $4.00
No. 295701110072
LED CM Filter - CTO - 17⁄16in (3.6cm) x 6ft (1.8m)
$4.00
No. 295734070072
LED CM Filter - 1/2 CTO - 17⁄16in (3.6cm) x 6ft (1.8m)
$4.00
No. 295734080072
LED CM Filter - 1/4 CTO - 17⁄16in (3.6cm) x 6ft (1.8m)
$4.00
No. 295734090072
LED CM Filter - OTHER COLOR - 17⁄16in (3.6cm) x 6ft (1.8m) - QTY 20 $80.00
No. 295799992072
Roscosleeves™
For simple and economical control of
fluorescent lighting,
Roscosleeves can be supplied in any Rosco filter
color—(or combination of
colors) Roscolux, Cinegel or
E-Colour. Not recommended
for use with High Output or
Very High Output lamps. T5 and
T8 Sleeves come standard with UV
filter in addition to the color selected.
T5 x 24"
T8 x 24"
T12 x 24"
T5 x 36"
T8 x 36"
T12 x 36"
T5 x 48"
T8 x 48"
T12 x 48"
T5 x 60"
T8 x 60"
T8 x 96"
T12 x 96"
$8.95
8.95
7.95
16.95
16.95
14.95
16.95
16.95
14.95
21.25
21.25
29.00
22.50
No. 110 08401 2405
No. 110 08401 2408
No. 110 08401 2412
No. 110 08401 3605
No. 110 08401 3608
No. 110 08401 3612
No. 110 08401 4805
No. 110 08401 4808
No. 110 08401 4812
No. 110 08401 6005
No. 110 08401 6008
No. 110 08401 9608
No. 110 08401 9612
ChromaSleeves
ChromaSleeves are body-colored, extruded polycarbonate
sleeves with an added UV absorber to prevent premature color
fading. Available in nine standard stocked colors or custom colors matched to any Rosco filter. Not recommended for use with
High Output or Very High Output lamps
Royal Blue
Green
Ruby Red
Purple
No. 110 08410
No. 110 08411
No. 110 08412
No. 110 08413
Pink
Yellow
Amber
No. 110 08414
No. 110 08415
No. 110 08417
Add suffix to product code for each size
T5 x 48" $13.25
4805
T8 x 48" 13.25
4808
Lens/Reflector Cleaner
The professional’s choice for over 50 years. Specially designed
for cleaning lenses, mirrors, reflectors, glass and dichroic filters,
and other fine quality optics.
Lens Cleaner 2 ounce drip bottle $ 3.95
No. 855 07202 0002
Lens Cleaner 8 ounce spray bottle $10.95
No. 855 07202 0008
Lens Cleaner 16 ounce bulk bottle $17.95
No. 855 07202 0016
Lens Tissue
Premium, lightweight, disposable, micro-fiber tissue for cleaning
lenses, filters and optics.
Lens Tissue 4" x 6" booklet $3.95
No. 855 07204 0406
Storage Drawers
Heavy gauge two-inch deep corrugated drawer and sleeve that
accepts 20" x 24" sheets of Rosco color filters.
Shipped completely assembled. Packed six to a case.
Storage Drawers (set of 6) $59.00
No. 110 08610 0000
Quick Color Sleeves
This gel-only product is a flat welded
tube of Rosco color filter, made in any
color from any line of Rosco gel. T5 and
T8 sleeves come standard with UV filter. Folded flat for easy
shipping and storage, the sleeve puffs open like an envelope to
slide over any size or shape of fluorescent tube. Not recommended for use with High Output or Very High Output lamps
T5 x 24"
$11.95 No. 110 08430 2405
T8 x 24"
11.95
No. 110 08430 2408
T12 x 24" 11.95
No. 110 08430 2412
T5 x 36"
12.95
No. 110 08430 3605
T8 x 36"
12.95
No. 110 08430 3608
T12 x 36" 12.95
No. 110 08430 3612
T5 x 48"
13.95
No. 110 08430 4805
T8 x 48"
13.95
No. 110 08430 4808
T12 x 48" 13.95
No. 110 08430 4812
T5 x 60"
17.95
No. 110 08430 6005
T8 x 60"
17.95
No. 110 08430 6008
T12 x 60" 17.95
No. 110 08430 6012
Please specify Rosco gel color when ordering.
www.rosco.com
12
Gobos
Gobo Catalog
Image Glass™
Deeply textured glass gobos that bend or refract light. Recommended for use in moving
lights with lamps up to 1200 watts and in ellipsoidal fixtures up to 600 watts. Requires the use
of the Universal Iris Slot Holder.
Rosco’s Gobo Catalog lists the entire
range of standard gobos available, as
well as several pages of useful technical
information. It is available from any
Rosco office or reseller or may be
downloaded from the Rosco website.
You can also choose gobos from the
Rosco web site (www.rosco.com) or
from the free MyGobo app for
iPhones, iPads, and iPod Touch.
Image Glass B size and sized for moving lights $37.50
Image Glass X size (for use in Rosco’s X24) $52.50
Designs marked with an asterisk (*) are available in X size
Standard Designs
Rosco offers approximately 2,000 standard
designs in its gobo collection. Each design
is available for virtually any known
fixture used in theatrical or display
lighting. Rosco re-sellers can usually
deliver standard gobos either off the
shelf or within a day or two.
Standard metal gobos $13.50
Standard mesh designs $19.75
No. 33621
No. 77730
Standard B&W glass gobos A, B or M size $85.00
Moving light sizes $59.50
Standard 2-color gobos $150.00
Standard multi-color gobos $350.00
* No. 33600
* No. 33601
No. 33602
No. 33603
No. 33604
* No. 33605
* No. 33606
* No. 33607
* No. 33608
* No. 33609
* No. 33610
No. 33611
No. 33613
Random Blisters
Coalescing
Bubbles
Raised Mosaic
Hammered
Wood Grain
Ripples
Ice
Dune
Sparkelite
Reflections
Rain Glass
Foam Bubbles
No. 33614
* No. 33615
No. 33616
* No. 33617
* No. 33618
* No. 33619
* No. 33620
* No. 33621
* No. 33622
No. 33623
No. 33624
No. 33625
ColorWaves™
Each ColorWave glass gobo is coated in one of
five dichroic colors. There are four different
styles—Waves, Ripple, Strands, Mosaic—and
thus 20 different choices in the range. Recommended for use in moving lights with lamps
up to 1200 watts and in ellipsoidal fixtures up
to 600watts. Requires the use of the Universal Iris
Slot Holder.
Colorizers™
Multi-colored glass gobos that can be used
alone or in combination with a steel gobo.
Recommended for fixtures up to 1,000 watts.
Requires the use of either a Glass Gobo Holder or
the Universal Iris Slot Holder.
Flower
Lined
Plume
Lt. Plume
Pebble
Honeycomb
Waves
Irregular
Strands
Banded Lines
Lazy Swirls
Basket Weave
Pin Feathers
Winter Frost
*No. 55004
Colorizer B size and Moving Light size $65.00
Colorizer X size (for use in Rosco’s X24) $79.00
*No. 43104
ColorWave B size $79.50
ColorWave Moving Light size $57.25
Colorwave X-size (for use in Rosco’s X24) $99.95
Designs marked with an asterisk (*) are available in X size
Designs marked with an asterisk (*) are available in X size
Stippled Series
Blue and Lavender
Amber and Red
Red, Blue and Lavender
Green, Blue and Lavender
Green and Yellow
*No. 55004
*No. 55005
*No. 55006
*No. 55007
*No. 55008
Featherlight Series
Blue, Lavender and Yellow
Blue and Green
Red, Lavender and Yellow
Blue and Lavender
Green and Yellow
No. 56201
No. 56202
No. 56203
No. 56204
No. 56205
Free Flow Series
Cool: Blues, Reds and Lavenders
Warm: Red, Ambers, Blue and Lavenders
Midnight: Blues, Lavenders and Greens
*No. 56101
*No. 56102
*No. 56103
Waves - Red
Waves - Amber
Waves - Magenta
Waves - Cyan
Waves - Indigo
No. 33001
*No. 33002
*No. 33003
*No. 33004
*No. 33005
Mosaic - Red
Mosaic - Amber
Mosaic - Magenta
Mosaic - Cyan
Mosaic - Indigo
No. 33301
No. 33302
No. 33303
No. 33304
No. 33305
Ripple - Red
Ripple - Amber
Ripple - Magenta
Ripple - Cyan
Ripple - Indigo
*No. 33101
*No. 33102
*No. 33103
*No. 33104
*No. 33105
Sparkelite – Red
Sparkelite – Amber
Sparkelite – Magenta
Sparkelite – Cyan
Sparkelite – Indigo
No. 33401
No. 33402
No. 33403
No. 33404
No. 33405
Strands - Red
Strands - Amber
Strands - Magenta
Strands - Cyan
Strands - Indigo
*No. 33201
*No. 33202
*No. 33203
*No. 33204
*No. 33205
www.rosco.com
13
Gobos / Tapes
Prismatics™
Gaffers Tape
Recommended for use in moving lights with lamps
up to 1200 watts and in ellipsoidal fixtures, lamps
up to 600watts. Requires the use of the Universal
Iris Slot Holder.
Prismatic B size and moving light size $65.00
No. 43801
A premium quality cotton substrate,
coated with heavy-duty vinyl.
Rubber based adhesive has high
tack with excellent adhesion but
will not leave a sticky residue.
Rolls measure 48mm x 50m (1.9" x 54.6 yds.)
Prismatics are not available for use in Rosco’s X24.
Kaleidoscope
Cool Lavender
Spring Greens
Sunset
Blue Water
No. 43801
No. 43802
No. 43803
No. 43804
No. 43805
Fiery Sun
Warm Contrast
Patriotic
Crystalline
No. 43806
No. 43807
No. 43808
No. 43809
Universal Iris Slot Holder
Allows a glass gobo to be placed in the
iris slot of fixture in front of the gate.
Double sided to allow the use of two
gobos, glass and/or steel, in the iris slot at
the same time. Fits the ETC Source Four,
Altman Shakespeare and other modern
spotlights. For use with 86 mm standard
“B” size glass gobos only.
Universal Iris Slot Holder $15.95
No. 250 15786 0000
Glass Gobo Holders
Glass Channel Holder
BG Size Glass Gobo Holder (79 mm) — Altman fixtures $11.95
No. 250 14579 0000
Standard “B” Size Glass Gobo Holder (86 mm) — ETC S4 $11.95
No. 250 14686 0000
“M” Size Glass Gobo Slot Holder — ETC Source 4 Jr. $11.95
No. 250 14666 0000
“M” Size Glass Gobo Iris Slot Holder — ETC Source 4 Jr. $21.95
No. 250 15666 0000
“A” Size Glass Gobo Iris Slot Holder — ETC Source 4 $24.95
No. 250 15610 0000
Steel Gobo Holders
Tab Holder
“B” Size Tab Holder — Altman fixtures $8.95
No. 250 12586 0000
Sandwich Holder
“B” Size Sandwich Holder —Altman fixtures $9.95
No. 250 13586 0000
“B” Size Sandwich Holder — ETC S4 $9.95
No. 250 13686 0000
“A” Size Sandwich Holder — ETC S4 $9.95
No. 250 13610 0000
“M” Size Steel Gobo Slot Holder — ETC Source 4 Jr. $9.95
No. 250 13666 0000
Rosco Donuts
Reduce or eliminate the halation around projected gobos and
thus sharpen the image.
6.25" fits Source 4/Altman Shakespeare $5.65
No. 250 16625 0000
7.5" Donut fits most 6" ellipsoidal reflector spotlights $ 5.65
No. 250 16750 0000
Black
Grey
Red
Yellow
Blue
Electric Blue
Fluorescent Green
White
$19.00
19.00
19.00
19.00
19.00
20.10
20.10
19.00
No. 851 42221 4850
No. 851 42223 4850
No. 851 42339 4850
No. 851 42342 4850
No. 851 42340 4850
No. 851 42338 4850
No. 851 42346 4850
No. 851 42222 4850
Spike Tape
12mm cloth tape for marking location of actors and scenery on
stage floors. 25m roll.
Red
$4.40
No. 851 05210 1225
Yellow
4.40
No. 851 05220 1225
Blue
4.40
No. 851 05230 1225
Green
4.40
No. 851 05240 1225
White
4.40
No. 851 05250 1225
Caution Tape
48mm vinyl tape has alternating bands of bright yellow and
black. It is perfect for marking backstage areas that are off-limits
or dangerous. 16.5m roll.
Black/Yellow
$7.50
No. 851 02288 4816
Glow Tape
Glow-in-the-dark tape ideal for marking low light areas. It glows
to a yellow-green color that can remain illuminated for hours.
24mm wide.
5m roll (16.35 ft.)
$12.10
No. 851 05000 2405
10m roll (32.7 ft.)
$23.10
No. 851 05000 2410
30m roll
$69.30
No. 851 05000 2430
TecStretch™ Film
TecStretch is an excellent solution to secure cable, rope or extension cords safely and without leaving a sticky residue. Like
Shrinkwrap™ in tape form, this 80 gauge film secures a wide variety of materials. It has a 1:3 stretch ratio and will yield up to
600' of usable material. Roll size: 1” wide x 250’ (76.2 m). Sold
in sleeves of six rolls or cases of 72 rolls.
TecStretch 6-Roll Sleeves
Assorted No. 851 06901 6250
White
No. 851 06903 6250
Red
No. 851 06905 6250
Yellow
No. 851 06907 6250
each sleeve $20.00
Black No. 851 06902 6250
Blue No. 851 06904 6250
Green No. 851 06906 6250
TecStretch 72-Roll Cases
Assorted No. 851 06901 0BOX
White
No. 851 06903 0BOX
Red
No. 851 06905 0BOX
Yellow
No. 851 06907 0BOX
each case $234.00
Black No. 851 06902 0BOX
Blue No. 851 06904 0BOX
Green No. 851 06906 0BOX
www.rosco.com
14
Projection Screens and Accessories
Custom Screen
Rosco will fabricate a custom screen to your precise specifications for size, shape, and finishing details. Standard pricing
includes grommets on 12" centers, vertical seams, finished edges
and a pipe pocket and skirt. Irregular shapes can be made but
may require additional set-up charges. Delivery in as little as
two weeks. All Rosco screens are flame-retardant and washable.
Dimensions to outside edge of screen, rounded up to the foot.
Minimum order: 100 square feet.
Finished Screen
55" panels
86" panels
$4.95/sq. ft.
5.40/sq. ft.
Unfinished Screen (raw edges)
55" panels
86" panels
4.50/sq. ft.
4.95/sq. ft.
Chautauqua Theatre Company (July 2007), "The Just" by Albert Camus
Directed by Ethan McSweeny, Lighting Design by Scott Zielinski
Rosco’s projection screens can be used for front or rear
projection, digital or analog imaging, close up or long throw
installations. Available in 55" or 86" wide rolls or in custom
finished sizes.
Colors and recommended uses:
Front White: Bright white surface for front projection use.
Twin White: Suitable for front or rear projection, or as a
cyclorama.
Grey: Recommended for rear projection.
Black: Recommended for rear projection and high ambient light
situations.
Light Translucent: Virtually clear, suitable for daytime, exterior
rear projections or in exceptionally bright ambient light
conditions.
55" Seamless Screen
55" (139.7 cm) wide. Minimum order is one linear yard.
Price/Yard
Grey
$18.30
No. 500 52105 55
Twin White
18.30
No. 500 52106 55
Black
18.30
No. 500 52107 55
Light Translucent
18.30
No. 500 52108 55
Front White
18.30
No. 500 52109 55
110" Screen
Double width continuous rolls of two 55" sections welded
together. Minimum order is two linear yards.
Price/Yard
Grey
$102.75
No. 500 52105 10
Twin White
102.75
No. 500 52106 10
Black
102.75
No. 500 52107 10
Light Translucent
102.75
No. 500 52108 10
Front White
102.75
No. 500 52109 10
Clear Vinyl
14 mil thick, 72" wide.
Price/Yard
Crystal Clear
$32.10
No. 500 02110 7201
Also available in orange, yellow, green and grey.
Stretch-N-Hook™
This versatile fastener is constructed of 5⁄32” (4mm) elastic cord
with a sturdy molded hook . Overall length is 12”. Minimum
order: 12 units.
Stretch-N-Hook $3.50/each
No. 500 05100 0010
86" Seamless Screen
Minimum order is one linear yard.
Price/Yard
Grey
$85.00
No. 500 52105 86
Twin White
85.00
No. 500 52106 86
Front White
85.00
No. 500 52109 86
Transparent Screen Tape
For temporarily seaming screen yardage together for a production, or for temporary repairs of screen material. Taped seams
may spread within two months. 48 mm x 50 m.
Transparent Screen Tape
No. 851 05100 4850
$6.40
www.rosco.com
15
Filmmaking Tools
Cinefoil
Roscopak™
Cinefoil is a matte black aluminum
material used for masking light leaks
and/or eliminating unwanted
reflections. It can be quickly molded
to form barndoors, flags and other
configurations.
Roscopak S/G (silver/gold) $27.40
No. 08509 4854
Cinefoil 24" x 25' $33.95
No. 101 01001 2425
Cinefoil 12" x 50' $33.95
No. 101 01001 1250
Cinefoil 48" x 25' $80.00
No. 101 01001 4825
Reflection Media
Used for surfacing reflector boards or wherever reflected light is
required. The product designation generally indicates the
quality of the reflection. Rolls are 48" x 25' (122 cm x 7.6 m).
Cinefoil is also available in shorter lengths for still photographers, videographers and students. Called Photofoil it offers the
same light control properties at an economical price.
Matte Black Photofoil, 12" x 10' $9.95
No. 101 01001 1210
Matte Black Photofoil, 24" x 10' $17.95
No. 101 01001 2410
Butterflies and Overheads
A number of Cinegel materials are available to fit the standard
butterfly and overhead frames used in motion picture and television production. All materials are supplied edge-finished with
binding and grommets on 24" centers and sewn hems, except
for No. 3014 Hilite and No. 3029 Silent Frost. The latter two
have an ultrasonic welded seam every 48".
Silent Frost
Grid Cloth
Light Grid Cloth
1
⁄4 Grid Cloth
Silent Grid Cloth™
Silent Light Grid Cloth™
Silent 1⁄4 Light Grid Cloth™
Hilite
Full Blue Grid Cloth
1
⁄2 Blue Grid Cloth
Blue Grid Cloth
Full Straw Grid Cloth
1
⁄2 Straw Grid Cloth
Straw Grid Cloth
Moonlight Grid Cloth
No. 3029
No. 3030
No. 3032
No. 3034
No. 3060
No. 3062
No. 3064
No. 3014
No. 3071
No. 3072
No. 3073
No. 3081
No. 3082
No. 3083
No. 3090
Prices for Butterfly and Overhead materials
(except for No. 3014 Hilite)
6' x 6'
$150.00
8' x 8'
$250.00
12' x 12' $400.00
20' x 20' $850.00
Hilite:
No. 3014
6' x 6'
$200.00
12' x 12' $475.00
8' x 8'
20' x 20'
Roscopak material is light in weight, yet strong and durable. The
material can be taped or tacked to virtually any wall, ceiling or
panel to turn that area into an efficient reflector. Roscopak
measures 4' x 41⁄2' (1.2 x 1.4 m), and is packaged in a handy
pocket size pouch.
$325.00
$950.00
Acrylic Panels
Acrylic sheets for daylight correction or light intensity reduction.
Minimum quantity of 5.
4'x8'
5'x8'
Roscolex 85
$225.00
$325.00
No. 3761
Roscolex 1⁄2 CTO
225.00
325.00
No. 3751
Roscolex N.3
225.00
325.00
No. 3762
Roscolex N.6
225.00
325.00
No. 3763
Roscolex N.9
225.00
325.00
No. 3764
Roscoflex M (mirror) $169.75
No. 3801
Roscoflex H (hard) $169.75
No. 3802
Roscoflex S (soft) $169.75
No. 3803
Roscoflex SS (supersoft) $169.75
No. 3804
Roscoflex G (gold tinted) $169.75
No. 3805
Spun Silver $169.75
No. 3830
RoscoScrim
(perforated silver/black) $175.00
No. 3809
Featherflex S/G
(silver/gold) $169.75
No. 3812
Thin Mirror - S (60" x 20') $54.75
No. 3813
Thin Mirror - G (60" x 20') $54.75
No. 3814
Cinebounce – White/Black $169.75
No. 3840
Polarizing Filters
A neutral grey linear polarizing film used in front of lights to reduce the glare caused by smooth surfaces such as glass, water,
paper and certain metallic objects. Should be placed at a slight
distance from hot lights.
Sheet: 17" x 20" $ 54.00
No. 07300 1720
Roll: 17" x 10'
$289.00
No. 07300 1710
RoscoVIEW™
RoscoView is a unique two-part window control system for film
and television professionals. It consists of wide width polarizing
filter installed on windows and a matching camera polarizing filter. Rotating the camera filter results in 100% control of exterior
brightness as seen through the window.
P.O.A. See the demo video at
http://www.rosco.com/us/video/roscoview.cfm
TruColor IR™
In some digital video cameras the use of ND filters can excessively desaturate the color balance of the shot. Rosco’s TruColor
IR camera filter restores the proper color saturation by balancing
the visible and infrared light, allowing the camera sensors to
properly render color in the finished composition.
TruColor IR Filter - 4" x 4" $199.00
No. 120 48010 0404
TruColor IR Filter - 4" x 5.65" $225.00
No. 120 48010 4565
TruColor IR Filter - 5.65" x 5.65" $275.00
No. 120 48010 5656
TruColor IR Filter - 6.6" x 6.6" $325.00
No. 120 48010 6666
www.rosco.com
16
Filmmaking Tools
RoscoShades
DigiComp™ Materials
The RoscoShades system allows lighting professionals to balance
the brightness and color temperatures of the outdoor light seen
through a window in a TV broadcasting facility or film set.
RoscoView
DigiComp is Rosco’s trade name for paint and cable precisely
crafted to allow seamless compositing for film, video and digital
use. In the modern compositing or matting process
DigiComp Paint
®
RoscoView is a unique two-part window control system for film
and television professionals. It consists of a wide width polarizing
filter installed on windows and a matching camera polarizing
filter. This results in 100% control of exterior brightness as seen
through the window.
DigiComp Blue
One Gallon $94.05
No. 150 05705 0128
Five Gallon $423.30
No. 150 05705 0640
DigiComp Green
One Gallon $123.75
No. 150 05707 0128
Five Gallon $557.40
No. 150 05707 0640
TV Paint™
Specifically formulated for the sensitive contrast requirements of
standard television systems, this versatile acrylic paint can be
applied to nearly any surface and comes ready to use right
out of the bucket.
TV White – A neutral grey that meets the specifications for 60%
reflectance (maximum brightness intended fortransmission).
Gallon
$47.25
No. 150 05735 0128
TV Black – A rich, matte black that meets the specifications for
3% reflectance (minimum brightness intended for transmission).
Gallon
$47.25
No. 150 05740 0128
Keying Paints
Video Paint Ultimatte™
Designed with the Ultimatte® technical staff to meet the
requirements of their keying effects systems.
Gal
$78.90
Ultimatte® Blue
No. 150 05720
Ultimatte® Green
118.35
No. 150 05721
Ultimatte® Super Blue
86.25
No. 150 05722
For One Gallon add 0128 to product number.
For Five Gallon, add 0640 to product number.
5 Gal
$362.25
532.05
378.90
DigiComp Cable
3⁄32" (2.4 mm) DigiComp cable
1⁄16" (1.6 mm) 7x7, coated diameter 3⁄32" (2.4 mm)
480 lb. (217 kg) rating, 500' (152 m) spool
DigiComp Green Cable $235.00
No. 850 57075 0938
DigiComp Blue Cable $235.00
No. 850 57055 0938
3⁄16" (4.8 mm) DigiComp cable
1⁄8" (3.2 mm) 7x19, coated diameter 3⁄16" (4.8 mm)
2000 lb. (917 kg) rating, 500' (152 m) spool
DigiComp Green Cable $400.00
No. 850 57075 1875
DigiComp Blue Cable $400.00
No. 850 57055 1875
1⁄4" (6.4 mm) DigiComp cable
3⁄16" (4.8 mm) 7x19, coated diameter 1⁄4" (6.4 mm)
4200 lb. (1905 kg) rating, 500' (152 m) spool
DigiComp Green Cable $450.00
No. 850 57075 2500
DigiComp Blue Cable $450.00
No. 850 57055 2500
Chroma Key™
Specifically formulated to provide high luminance values and
color saturation for keying effects. The acrylic colors provide
high build, one-coat coverage for use on nearly any surface.
Gal.
Chroma Key Blue
$78.90
No. 150 05710
Chroma Key Green
78.90
No. 150 05711
For One Gallon add 0128 to product number.
For Five Gallon add 0640 to product number.
5 Gal.
$362.25
362.25
Chroma Floor
Chroma Floor is a lightweight reversible vinyl floor, Chroma Key
Green on one side and Chroma Key Blue on the other.
Width: 63" x 131.3' (1.6 m x 40 m)
Thickness: 0.05" (1.3 mm)
Weight: 250 lbs. per roll
Blue/Green Chroma Floor
No. 300 58726 6300
$1495.00
www.rosco.com
17
Scenic Paint and Coatings
Iddings Deep Colors™
Off Broadway™
Flexible casein binder with substantial
quantities of ground pigment for rich,
ultra-matte colors with excellent
adhesion to absorbent materials.
A vinyl acrylic paint which may be used on
a wide variety of scenic materials
including hard scenery, foam scenery,
drops and ground cloths.
5 Gallon
White
$154.65
White White
181.50
Black
168.00
Yellow Ochre
Burnt Umber
Raw Sienna
Burnt Sienna
Raw Umber
Earth Umber
Ultramarine Blue
Fire Red
Deep Red
Orange
Emerald Green
Chrome Oxide Green
Lemon Yellow
Golden Yellow
Purple
Magenta
Pthalo Green
Sky Blue
Pthalo Blue
Imperial Green
*Navy
Brilliant Red
*Van Dyke Brown
Paynes Grey
Gallon
$33.60
40.35
37.65
37.65
37.65
37.65
37.65
37.65
37.65
53.70
61.05
60.60
47.25
47.25
47.25
47.25
47.25
60.60
60.60
47.25
47.25
47.25
64.05
60.60
64.05
47.25
64.05
No. 150 05350
No. 150 05351
No. 150 05352
No. 150 05353
No. 150 05354
No. 150 05355
No. 150 05356
No. 150 05357
No. 150 05358
No. 150 05359
No. 150 05360
No. 150 05361
No. 150 05363
No. 150 05364
No. 150 05365
No. 150 05366
No. 150 05367
No. 150 05368
No. 150 05369
No. 150 05371
No. 150 05372
No. 150 05373
No. 150 05374
No. 150 05375
No. 150 05376
No. 150 05380
No. 150 05382
* New
Product numbers refer to color only.
Add 0640 to the product number for Five Gallons, 0128 for
One Gallon, 0032 for One Quart and 0016 for One Pint.
Metallic Colors
Gallon
Bright Gold
$96.75
Gold
96.75
Silver
96.75
Copper
96.75
Antique Gold 96.75
Quart
$33.60
33.60
33.60
33.60
33.60
Approximate Paint Weights:
Pint = 1.5 lbs./1 kilogram
Quart = 2.75 lbs./1.5 kilograms
Gallon = 11 lbs./5 kilograms
5 Gallon = 60 lbs./27 kilograms
Pint
$21.60
21.60
21.60
21.60
21.60
No. 150 05383
No. 150 05384
No. 150 05385
No. 150 05386
No. 150 05387
5 Gallon
Gallon
White
$212.40 $47.25
Black
241.80
53.70
Yellow Ochre
53.70
Burnt Umber
53.70
Raw Sienna
53.70
Burnt Sienna
53.70
Raw Umber
53.70
Van Dyke Brown
53.70
Ultramarine Blue
67.35
Red
67.35
Dark Red
87.60
Bright Red
87.60
Orange
87.60
Emerald Green
67.35
Chrome Oxide Green
67.35
Lemon Yellow
87.60
Golden Yellow
87.60
Purple
87.60
Magenta
87.60
Turquoise Blue
67.35
Dark Green
67.35
Cerulean Blue
67.35
Navy Blue
67.35
Quart
$16.20
18.90
18.90
18.90
18.90
18.90
18.90
18.90
24.30
24.30
27.00
27.00
27.00
24.30
24.30
27.00
27.00
27.00
27.00
24.30
24.30
24.30
24.30
No. 150 05551
No. 150 05552
No. 150 05553
No. 150 05554
No. 150 05555
No. 150 05556
No. 150 05557
No. 150 05558
No. 150 05559
No. 150 05560
No. 150 05561
No. 150 05562
No. 150 05563
No. 150 05564
No. 150 05565
No. 150 05566
No. 150 05567
No. 150 05568
No. 150 05569
No. 150 05570
No. 150 05571
No. 150 05572
No. 150 05573
Product numbers refer to color only. Add 0640 to the product
number for Five Gallons, 0128 for One Gallon and 0032 for
One Quart.
Paint Sample Kits
Off Broadway Paint Kit $71.70
No. 150 05300 0KIT
29-piece kit contains one ounce samples of each Off Broadway
color plus Clear Flat and Clear Gloss.
Deep Colors Paint Kit $73.35
No. 150 05500 0KIT
23-piece kit contains one ounce samples.
Supersaturated Paint Kit $71.70
No. 150 05900 0KIT
31-piece kit contains one ounce samples (neutral base not
included).
Fluorescent Paint Kit $49.05
No. 150 05700 0KIT
9-piece kit contains one ounce samples.
VividFX Sample Kit $60.90
No. 150 06200 0KIT
13-piece kit contains one ounce samples.
ClearColour Test Kit $47.70
No. 150 06600 0KIT
5-piece kit contains one ounce samples.
www.rosco.com
18
Scenic Paint and Coatings
Acrylic Glazes
Supersaturated Roscopaint™
Designed to be diluted with water and applied as an overcoat to
a painted surface. They can also be mixed with the paints for
additional binder strength.
Brilliant dye-like colors formulated to be
diluted with substantial quantities of water
while retaining binder strength. Flexible vinyl
acrylic binder. Adheres to most scenic
surfaces, including muslin, plastics
and metal.
Red
Green Shade Blue
Ultramarine Blue
Chrome Green
Emerald Green
Pthalo Green
Imperial Green
Magenta
Brilliant Red
Spectrum Red
Purple
Iron Red
Chrome Yellow
Yellow Ochre
Raw Sienna
Moly Orange
Burnt Umber
Raw Umber
Burnt Sienna
Lemon Yellow
Turquoise Blue
Prussian Blue
Navy Blue
Paynes Grey
Leather Lake
Grass Green
Cerulean Blue
Hunter Green
Van Dyke Brown
Quart
$36.30
36.30
36.30
36.30
36.30
36.30
36.30
36.30
39.90
36.30
36.30
24.30
36.30
24.30
24.30
36.30
24.30
24.30
24.30
36.30
36.30
33.60
33.60
36.30
24.30
33.60
33.60
33.60
24.30
Clear Gloss
Clear Flat
No. 150 05965
No. 150 05968
No. 150 05969
No. 150 05971
No. 150 05972
No. 150 05973
No. 150 05974
No. 150 05975
No. 150 05976
No. 150 05977
No. 150 05979
No. 150 05980
No. 150 05981
No. 150 05982
No. 150 05983
No. 150 05984
No. 150 05985
No. 150 05986
No. 150 05987
No. 150 05988
No. 150 05989
No. 150 05990
No. 150 05991
No. 150 05992
No. 150 05993
No. 150 05994
No. 150 05996
No. 150 05997
No. 150 05998
Product numbers refer to color only.
Add 0032 to product number for One Quart.
Supersaturated Concentrated Bases™
5 Gal.
Neutral Base
White
$212.55
Velour Black 254.10
Gal.
$40.35
45.90
57.90
Qt.
N/A
No. 150 06001
N/A
No. 150 06002
$20.25 No. 150 06003
Product numbers refer to color only.
Add 0640 to the product number for Five Gallons,
0128 for One Gallon, and 0032 for One Quart.
5 Gallon
$194.85
194.85
Gallon
$43.20
43.20
No. 150 05580
No. 150 05581
Add 0640 to the product number for Five Gallons,
0128 for One Gallon.
ColorCoat™
Fast drying water borne acrylic enamel. Good choice for decks
and floors due to its high abrasion resistance.
Clear
Clear Satin
Black
Flat Black
Aluminum
Gallon
$51.30
51.30
56.55
56.55
83.40
Quart
$16.20
16.20
16.20
16.20
27.00
No. 150 05620
No. 150 05621
No. 150 05634
No. 150 05635
No. 150 05636
Tough Prime™
Rosco offers a unique waterbased primer with adhesion
properties that allow it to
bond to the hard-to-prime
scenic materials found in
every scene shop. Tough
Prime covers just about any surface, including PVC pipe,
aluminum, foams and concrete floors, as well as wood and
foam core.
Tough Prime White
Tough Prime Black
5 Gallons
$231.90
231.90
Gallon
$51.30
51.30
No. 150 06050
No. 150 06055
Add 0032 to the product number for Quarts,
0128 for One Gallon and 0640 for Five Gallons.
www.rosco.com
19
Scenic Paint and Coatings
Fluorescent Paint
Colorine™
Vivid vinyl acrylic colors are brilliant in normal light and glow
brightly when bathed in ultraviolet light. White fluoresces a light
blue under black light. Invisible blue appears milky white under
normal light but glows blue in ultraviolet.
Gallon
White
$110.10
Red
110.10
Orange
110.10
Yellow
110.10
Green
110.10
Blue
110.10
Invisible Blue 135.30
Pink
110.10
Gold
115.65
Quart
$36.30
36.30
36.30
36.30
36.30
36.30
38.55
36.30
39.00
Pint
$24.30
24.30
24.30
24.30
24.30
24.30
25.65
24.30
25.65
No. 150 05779
No. 150 05780
No. 150 05781
No. 150 05782
No. 150 05783
No. 150 05784
No. 150 05785
No. 150 05786
No. 150 05787
Designed for coloring a wide range of low wattage bulbs used in
stagecraft and live entertainment. $28.20/pint
Cardinal Red (26)
Ruby Red (27)
Magenta (49)
Moonlight Blue (80)
Urban Blue (82)
Emerald Green (90)
Golden Amber (41)
Canary Yellow (15)
Clear
Thinner Pint $22.80
No. 150 07601
No. 150 07602
No. 150 07603
No. 150 07604
No. 150 07605
No. 150 07607
No. 150 07610
No. 150 07615
No. 150 07617
No. 150 07680
Colorine requires special packaging to meet DOT regulations.
This product can only be shipped via UPS, with additional fees.
ClearColour
Rosco Lay-In Brushes
Water-based product is absolutely invisible under normal light,
yet glows brightly under ultraviolet light.
Yellow
Green
Red
Blue
Black
Quart
$147.75
197.40
210.45
145.05
129.00
Pint
$103.65
100.35
107.70
76.95
70.05
Ounce
$8.50
8.50
8.50
6.50
5.50
No. 150 6610
No. 150 6620
No. 150 6630
No. 150 6650
No. 150 6660
Product numbers refer to color only. Add 0032 for One Quart
and 0016 for One Pint.
Rosco Lay-In brushes are available in ferrule widths of 4", 5", 6" and 7". Hog hair
bristles are 31⁄2” long, longer than most
commercial brushes. Handles are 51⁄2”
high quality hardwood.
4" Lay-In Brush
5" Lay-In Brush
6" Lay In Brush
7" Lay-In Brush
$45.24
49.60
56.14
63.77
No. 155 05630 0400
No. 155 05630 0500
No. 155 05630 0600
No. 155 05630 0700
Vivid FX™
The exceptional pigments in Vivid FX glow most brilliantly
between 365-380 nanometers. This creates stunning black light
effects and intermix cleanly to provide a wide array of
intermediate fluorescent hues.
Gallon
Bright White $178.80
Lemon Yellow 192.15
Orange Sunset 178.80
Orange
178.80
Scarlet Red
178.80
Hot Pink
178.80
Magenta
178.80
Violet
178.80
Deep Blue
178.80
Brilliant Blue
178.80
Aquamarine
178.80
Electric Green 178.80
Deep Green
178.80
Quart
$60.60
67.35
60.60
60.60
60.60
60.60
60.60
60.60
60.60
60.60
60.60
60.60
60.60
Pint
$33.60
37.65
33.60
33.60
33.60
33.60
33.60
33.60
33.60
33.60
33.60
33.60
33.60
No. 150 06250
No. 150 06251
No. 150 06252
No. 150 06253
No. 150 06254
No. 150 06255
No. 150 06256
No. 150 06257
No. 150 06258
No. 150 06259
No. 150 06260
No. 150 06261
No. 150 06262
Roscoglo™
A phosphorescent water-based paint designed for use in total
darkness for stage direction and visual orientation.
Ounce
Pint
$ 7.20
80.70
No. 150 05666 0001
No. 150 05666 0016
Rosco Fitch Brushes
Rosco’s professional quality scenic
fitches, often called lining brushes,
are available individually and in two
handy kits. All brushes feature seamless ferrules and natural bristles.
Brush No. 155 05610 (add number
in parentheses for each size)
⁄4" Fitch
⁄2" Fitch
3
⁄4" Fitch
1" Fitch
11⁄4" Fitch
11⁄2" Fitch
2" Fitch
3" Fitch
1
1
(0025)
(0050)
(0075)
(0100)
(0125)
(0150)
(0200)
(0300)
$ 6.06
7.58
11.84
16.30
21.28
25.87
32.05
50.84
7 Brush Set
$101.92
Includes fitches whose ferrule widths are:
1
⁄4", 1⁄2", 3⁄4", 1", 11⁄4", 11⁄2 and 2"
No. 155 056107KIT
8 Brush Set
$138.23
No. 155 056108KIT
Includes all the brushes in the 7 Brush Kit plus a 3" Fitch Foliage
www.rosco.com
20
Scenic Paint and Coatings
Rosco Flamex NF/Natural Fiber
Flame Retardant
Premiere Clear
Water-borne urethane coating
suitable for sealing and protecting
painted finishes, floors, and
high-traffic surfaces.
Premiere Clear Flat
Premiere Clear Satin
Premiere Clear Gloss
Gallon
$59.70
59.70
59.70
Should be used on fabrics like cotton, linen, wool, burlap and
most other materials made of natural fibers. Premixed for use
straight out of the bottle, NF is perfect for treating backdrops,
velours, muslin cycloramas and decorative fabric panels.
Quart
$19.65
19.65
19.65
CrystalGel™
Rosco CrystalGel is a non-toxic, waterbased material which provides a clear,
plastic-like coating on virtually any
surface used in modern stagecraft.
CrystalGel Gallon $58.65
No. 150 07400 0128
CrystalGel 5 Gallon $263.55
No. 150 07400 0640
Foamcoat™
Water-based, flame retardant,
protective coating for all rigid foams.
Foamcoat dries to a super hard durable
coating that resists chipping
and cracking.
Foamcoat Gallon $58.65
No. 150 07100 0128
Foamcoat 31⁄2 Gallons $195.75
No. 150 07100 0448
Flexcoat™
Flexible, non-toxic, water-based coating
for polyurethane and polystyrene foam.
It contains no plasticizers, so it will not
become brittle with age or
exterior exposure.
Flexcoat Gallon $58.65
No. 150 07120 0128
Flexcoat 5 Gallon $263.55
No. 150 07120 0640
FlexBond™
Clear, flexible scenic glue which bonds
many porous and non-porous scenic
materials. Rosco FlexBond dries to a
clear, hard, yet pliable coating that does
not suffer from the “tackiness” common
in many other flexible glues.
FlexBond Gallon Jug $40.20
No. 150 07500 0128
FlexBond 5 Gallon Pail $180.15
No. 150 07500 0640
No. 150 06830
No. 150 06820
No. 150 06810
Flamex NF Gallon $38.25
No. 150 079NF 0128
Rosco Flamex SF/Synthetic Fiber
Flame Retardant
Effectively treats many synthetic fibers, such as polyesters,
nylons, acrylics and rayons, as well as most cotton/synthetic
blends. Premixed for use straight out of the bottle.
Flamex SF Gallon $60.00
No. 150 079SF 0128
Rosco Flamex DF/Delicate Fabrics
Flame Retardant
Use for synthetic weaves, rayon or silk. Premixed for use straight
out of the bottle, DF maintains the gentleness and soft hand of
fragile fabrics and draperies.
Flamex DF Gallon $60.00
No.150 079DF 0128
Rosco Flamex PC/Paper and
Cardboard Flame Retardant
Effectively treats papers and un-waxed cardboard materials.
Premixed for use straight out of the bottle, PC is perfect for
props and set pieces made from flammable paper products.
Flamex PC Gallon $60.00
No. 150 079PC 0128
Rosco Flamex WD/Raw Wood
Penetrating Flame Retardant
WD is intended for untreated wood, plywood, cellulose board,
acoustical board and corrugated paper.
Flamex WD Gallon $60.00
No. 150 079WD 0128
Rosco Flamex PA/Latex Paint
Additive Flame Retardant
PA can be added to most latex or water based paints in order to
create a flame retardant paint film. PA is useful for treating scenic materials that cannot easily be treated by other methods and
for supplying the additional protection of a fire
retardant paint coating.
Flamex PA 8-oz jar $14.25
No. 150 079PA 0008
Flamex PA Case of 12 jars $157.05
No. 150 079PA 1208
www.rosco.com
21
Fog and Haze Products
Delta 3000™
Produces greater fog output than
any machine in its price class. DMX
is standard equipment and is available with a choice of two remote
control devices.
Delta 3000 Base Unit 120v $895.00
No. 200 13000 0120
Delta 3000 Base Unit CE 240v $995.00
No. 200 13000 0240
Delta Digital/DMX Remote Control Device $530.00
No. 200 13000 DDMX
Delta Analog/DMX Remote Control Device $330.00
No. 200 13000 ADMX
Delta 3000 Carrying Case $400.00
No. 200 43000 0000
4 inch Hose Adapter $41.50
No. 200 61690 0004
Ducting Hose 4 inch x 10 feet $49.95
No. 200 61695 0010
Model 1700™
The Rosco Model 1700 fog
machine is a high quality machine–
durable, dependable, and with a
lower cost. The machine delivers
fog output more than previous fog
machines, but draws less power—
1190W.
Model 1700 120v with remote $825.00
No. 200 21700 0120
Model 1700 240v with remote $860.00
No. 200 21700 0240
1700/1900 DMX Remote $235.00
No. 200 51700 RDMX
50' remote extension–1700/1900 $67.50
No. 200 51587 0050
100' remote extension–1700/1900 $89.90
No. 200 51588 0100
Model 1700 Carrying Case $450.00
No. 200 41700 0000
Delta 6000™
Rosco’s most powerful fog
machine, consuming more than
nine liters of fog fluid per hour.
Uses the same basic electronics
as the Delta 3000, including
DMX as standard equipment.
Delta 6000 120v Base Unit (requires remote control) $1,975.00
No. 200 16000 0120
Delta 6000 240v Base Unit (requires remote control) $2075.00
No. 200 16000 0240
Delta Digital/DMX Remote Control $530.00
No. 200 13000 DDMX
Delta Analog/DMX Remote Control $330.00
No. 200 13000 ADMX
Delta 6000 Carrying Case $595.00
No. 200 46000 0000
Model 1900™
Rosco’s Model 1900 fog machine is
a very high output professional fog
machine, designed primarily for
industrial applications. Its most
unique feature is the extremely high output, almost twice as
much as the Model 1700.
Model 1900 120v with remote $950.00
No. 200 21900 0120
Model 1900 240v with remote $995.00
No. 200 21900 0240
RDMX 1700/1900 DMX Remote $235.00
No. 200 51700 RDMX
50' remote extension–1700/1900 $67.50
No. 200 51587 0050
100' remote extension–1700/1900 $89.90
No. 200 51588 0100
Model 1900 Carrying Case $475.00
No. 200 41900 0000
www.rosco.com
22
Fog and Haze Products
Alpha 900™
Rosco Fog Fluid
Rosco’s most economical fog machine is an
excellent choice for applications where the
effect does not need volume control. A simple on-off switch, in the remote control only,
initiates a remarkably powerful stream of fog.
Alpha 900 – 120v $495.00
No. 200 20900 0120
Alpha 900 – 240v $505.00
No. 200 20900 0240
Alpha 900 Carrying Case $395.00
No. 200 40900 0000
Alpha 900 30' Remote Extension Cable
No. 200 50978 0030
4" Hose Adapter $41.50
No. 200 61690 0004
Ducting Hose 4 inch x 10 feet $49.95
No. 200 61695 0010
Fog Fluid Liter $16.95
No. 200 08200 0034
Fog Fluid 4 Liter Bottle $59.95
No. 200 08200 0135
Stage and Studio Fog Fluid
$32.00
Coldflow™
Converts liquid carbon dioxide to dry ice
to chill an aluminum chamber. The output of a fog machine passes through the
aluminum chamber and is chilled so that
it lays close to the ground. For best effect
use Rosco Stage & Studio Fluid.
Coldflow – 120v $1,695.00
No. 200 61700 0120
Coldflow – 240v $1,745.00
No. 200 61700 0240
Rosco Bubble Fluid
Building on Rosco’s 30+ years of success manufacturing the world’s
highest quality fog fluids, Rosco has developed a new formulation of
bubble fluid. Engineered as a universal fluid to work in any bubble
machine, Rosco’s water-based Bubble Fluid creates higher volumes
of extra colorful bubbles that fly higher and farther than existing
fluids currently available—with next to no residue left behind,
which makes it safer to use on performance and dance spaces or in
areas with expensive technology.
Bubble Fluid – Gallon
20009500012
Rosco Fog Fluid, for over 30 years is the most widely used fog
fluid in theatre, live entertainment and theme parks. When
vaporized, this water-based formulation produces a dense,
realistic fog with a long hang time.
$31.50
A water-based fluid which creates dense fog that will dissipate
more quickly than standard fluid. Also recommended for use
with the Rosco Coldflow to produce low-lying fog.
Stage and Studio Fog Fluid Liter $16.95
No. 200 09000 0034
Stage and Studio Fog Fluid 4 Liter Bottle $59.95
No. 200 09000 0135
Rosco Clear Fog Fluid
Produces dense fog with a long hang time without the
traditional Rosco scent.
Clear Fog Fluid Liter $16.95
No. 200 08600 0034
Clear Fog Fluid 4 Liter Bottle $59.95
No. 200 08600 0135
Rosco Light Fog Fluid
A lighter, less dense fog.
Light Fog Fluid Liter $13.95
No. 200 08500 0034
Light Fog Fluid 4 Liter Bottle $48.50
No. 200 08500 0135
Delta Haze Fluid
Rosco’s Delta Haze Fluid is specially formulated to work with
the Delta Hazer. Because it is water based, it leaves no oily
residue.
Delta Haze Fluid 4-Liter Bottle $59.95
No. 200 08425 0135
F-1 Fog Fluid
Rosco’s F-1 Fog Fluid is designed to be compatible with the
popular High End F-100™ Fog Generator. Available in a 2.5
gallon bottle, this formulation is composed of the highest grade
components available.
F-1 Fog Fluid 2.5 Gallon Bottle $95.00
No. 200 08700 0320
Rosco has been honored by the Academy of Motion Picture Arts and
Sciences four times. One of the Oscars (in this case a
Scientific and Technical Award) was for “the development
of a safe, non-toxic fluid for use in motion pictures.”
®
www.rosco.com
23
Dance and Performance Floors
Floor Catalog
Rosco’s floor products are
organized in a multi-page
catalog. Available as a printed
document or as a download at
www.rosco.com
Dance Floor
Rosco Dance Floor is lightweight (1.9 pounds per linear foot)
and is reversible with black on one side and your choice of
white or grey on the other. Floor thickness is .05" (1.3 mm),
width is 63" and it is sold by the linear foot or full rolls 131.25
feet long.
Black/Grey 63" x linear foot $12.75
No. 300 58720 63XX
Black/Grey 63" x 131.25 feet $1,528.00/roll
No. 300 58720 6300
Black/White 63" x linear foot $12.75
No. 300 58723 63XX
Black/White 63" x 131.25 feet $1,528.00/roll
No. 300 58723 6300
Blue/Green Chroma Floor 63" x 131.25 feet $1,495.00/roll
No. 300 58726 6300
Adagio™
Adagio’s durable surface can handle tap and other hard shoe
dance styles, yet it is supple enough for ballet and modern
dance styles. Since Adagio is dimensionally stable, it is suitable
for permanent or semi-permanent installation. 2.5 lbs.per
linear foot/250 lbs. per roll. Floor thickness is .06",
width is 63", and it is sold by the linear foot or full rolls
101.7 feet long.
Black 63" x linear foot $17.25
No. 300 58922 63XX
Black 63" x 101.7 feet $1,595.00/roll
No. 300 58922 6300
Grey 63" x linear foot $17.25
No. 300 58935 63XX
Grey 63" x 101.7 feet $1,595.00/roll
No. 300 58935 6300
Adagio™ Tour
Adagio Tour lays flat quickly and provides the same versatile surface as Adagio. Adagio Tour weighs only 1.6 lbs. per linear foot
so, as its name implies, it is excellent for touring dance companies. Floor thickness is .04", width is 63" and is sold by the
linear foot or full rolls 101.71 feet long.
Black 63" x linear foot $13.00
No. 300 58622 63XX
Black 63" x 101.71 feet $1,206.00/roll
No. 300 58622 6300
Grey 63" x linear foot $13.00
No. 300 58635 63XX
Grey 63" x 101.71 feet $1,206.00/roll
No. 300 58635 6300
Arabesque™
Arabesque is, on a cost-per-square-foot basis, Rosco’s most
affordable multi-purpose floor. Arabesque is available with a
marbled finish, adding both a note of elegance and the practical
advantage of helping to hide scuff marks. Floor thickness is .78"
(2 mm), width is 79". It can be specified by the linear foot or full
rolls 65.6 feet.
Marble Black 79" x linear foot $18.50
No. 300 58222 79XX
Marble Black 79" x 65.6 feet $1,095.00/roll
No. 300 58222 7900
Marble Grey 79” x linear foot $18.50
No. 300 58235 79XX
Marble Grey 79" x 65.6 feet $1,095.00/roll
No. 300 58235 7900
Marble Tan 79" x linear foot $18.50
No. 300 58218 79XX
Marble Tan 79" x 65.6 feet $1,095.00/roll
No. 300 8218 7900
www.rosco.com
24
Dance and Performance Floors
Studio Floor
Roscotiles
An ultra matte, black vinyl floor for ballet, theatre, or any
application where a light-absorbing surface is needed. Studio
Floor is not appropriate for heavy traffic or other types of dance.
Studio Floor is .08" thick and rolls measure 6 feet wide by 60
feet long, weighing 250 pounds.
Sold by full roll only..
Studio Floor Black Matte 6’ x 60’
No. 300 78035 7200
$1,525.00 per roll
This rugged floor product is 3 foot by 3 foot squares, making it
easy to pick up and put down. Designed for video production
facilities, each 1⁄8" thick, 12 pound tile is designed to lie flat for
temporary, as well as permanent installations. Available in
White, Black and TV Grey.
White $44.50/tile
No. 300 08415 3636
Black $44.50/tile
No. 300 08422 3636
TV Grey $44.50/tile
No. 300 08435 3636
Performance Floor
A durable, all-purpose floor, best for permanent or
semi-permanent installations in studios, multi-purpose rooms,
stages and showrooms—anywhere traffic is heaviest. Available in
black, white, light and dark grey. Performance Floor is .1"
thick and rolls measure 6 feet wide by 60 feet long, and weigh
280 pounds.
Sold by full roll only.
Black 6’ x 60’ $1,695.00
No. 300 73035 7200
White 6’ x 60’ $1,695.00
No. 300 73030 7200
Light Grey 6’ x 60’ $1,695.00
No. 300 73031 7200
Dark Grey 6’ x 60’ $1,695.00
No. 300 73025 7200
Roscoleum Floor
A hardwearing floor that provides an ideal surface for the
heaviest traffic areas. It stands up to tap, Flamenco and Irish
dance but will easily accommodate soft shoe styles as well. .1"
thick, 78.7" wide and approximately 104.92 feet long. Weight is
4 lbs. per linear foot, 425 lbs. per roll.
Sold by full roll only.
Rosco SubFloor
Rosco SubFloor can be bolted to concrete or wood floors and
can also be removed and re-used. The system consists of 42" x
42" panels which lock into each other with the unique WaveLock™ design. Perimeter pieces, 43⁄8" wide, lock the entire floor
together.
Semi-Permanent Studio System Components
42" x 42" x 2" Panel $149.00
No. 300 08000 4242
43⁄8" x 3'6" x 2" Perimeter $110.00
No. 300 08010 0042
43⁄8" x 7' x 2" Perimeter $139.00
No. 300 08010 0084
Outside Corner $149.00
No. 300 08015 0000
Customizing Panels $72.00
No. 300 08040 4242
Inside Corner $149.00
No. 300 08016 0000
21" x 3'6" x 2" Ramp $199.00
No. 300 08020 0000
21" Corner Transition Ramp $575.00
No. 300 08021 0000
Black 78.7" x 104.92' $2,360.00/roll
No. 300 58122 7900
Grey 78.7" x 104.92' $2,360.00/roll
No. 300 58135 7900
Show Floor
Super glossy floor for special events, commercials and fashion
promotions. It is not recommended for heavy traffic or for permanent installation. Available in high gloss black, white and red.
Show Floor is .08" thick, and each roll measures 6 feet wide by
60 feet long, weighing 275 pounds.
Sold by full roll only.
Black $1,450.00/roll
No. 300 74035 7200
White $1,450.00/roll
No. 300 74030 7200
Red $1,450.00/roll
No. 300 74036 7200
Unique WaveLock™ design assures easy installation and
safe, secure flooring.
www.rosco.com
25
Dance and Performance Floors
Floor Cleaners
Floor Adhesives
Rosco offers different floor cleaning
products, designed to meet every
need. Cleaners available in liters,
gallons or cases of liters or gallons.
For permanent installations. Consult a professional flooring contractor before installation.
Rosco All Purpose Floor Cleaner
Designed for the routine, regular cleaning of all Rosco vinyl
floors.
Premium Adhesive No. 755
For most porous surfaces, including concrete which is above grade.
1 Gallon Pail (weighs 12 lbs.) $64.00
No. 300 08755 0128
3 Gallon Pail (weighs 31 lbs.) $190.00
No. 300 08755 0448
Coverage is approximately 200 sq. ft. per gallon.
Epoxy Adhesive No. 300
For non-porous surfaces and concrete below grade.
1 Gallon Kit (weighs 15 lbs.) $79.00
No. 300 08300 0128
Coverage is approximately 110 sq. ft. per gallon.
1 liter $12.00
No. 300 09116 0034
1 gallon $30.00
No. 300 09116 0128
Roscoleum Adhesive
For use with Roscoleum floor only.
4 Gallons (weighs 55 lbs.) $160.00
No. 300 08100 0512
Rosco Heavy Duty Floor Cleaner
For stripping and deep cleaning of Rosco floors.
1 liter $12.00
No. 300 09112 0034
1 gallon $30.00
No. 300 09112 0128
Floor Welding Threads
Granulated Floor Cleanser
Granulated, dissolvable chemical for cleaning all Rosco flooring
surfaces.
2 lb. tub $11.95
No. 300 08710 0002
Welding threads are available to aid in permanent seam sealing
by professional contractors. Rosco has welding threads available
for Adagio, Roscoleum, Arabesque, Performance Floor, and
Studio Floor.
Floor Type
Adagio
Roscoleum
Performance Floor
Arabesque
Studio Floor
Roll Length
164 feet
165 feet
500 feet
410 feet
500 feet
Price
$ 48.00
130.00
102.50
92.00
122.00
PortaBarre™
A truly portable ballet dance barre, Rosco’s aluminum
PortaBarre uses an internal double button interlocking system,
making assembly and disassembly a matter of a few minutes,
without requiring tools or locking keys. Sold complete with a
custom designed carrying case.
Floortapes
For installing floors in temporary and semi-permanent situations.
Black Vinyl tape 48 mm x 33 m $13.00
No. 851 05014 4833
White Vinyl tape 48 mm x 33 m $13.00
No. 851 05015 4833
Grey Vinyl tape 48 mm x 33 m $13.00
No. 851 05016 4833
Clear Vinyl tape 48 mm x 33 m $13.00
No. 851 05013 4833
Roscofloor Double Stick tape 48 mm x 25 m
No. 851 08740 4825
9' barre with carrying case $465.00
No. 300 09095 0108
4'6" barre with carrying case $289.95
No. 300 09095 0054
Rosco Floor Bag
$16.30
Designed specifically for dancers and dance companies who
tour, the Rosco Floor Bag is made of durable water-resistant
PVC fabric. A hook and loop fastener along the entire length of
the bag keeps it securely shut while in transit, and also allows it
to open flat for loading and unloading.
Rosco Floor Bag $150.00
No. 300 59000 6300
www.rosco.com
26
Stage Hardware
Hinges and Pin Wire
Sandbags
Hinges are generally used as an aid in
attaching scenery flats. Three types are
Loose Pin Hinge
available. Loose Pin Hinges with removable pins; Tight Pin Hinges with permanent pins. And the Sure Hinge. The Sure
Hinge is a special type of loose pin
hinge with interchangeable halves. It is
scored so you can bend it around nomi- Tight Pin Hinge
nal 1" lumber.
Sure Hinge
1.5" Loose Pin Hinge – Box of 12 hinges $21.95
No. 850 73100 0001
1.5" Tight Pin Hinges – Box of 12 hinges $21.95
No. 850 73150 0001
2" Loose Pin Hinge – Box of 12 hinges $33.95
No. 850 73200 0002
2" Tight Pin Hinge – Box of 12 hinges $33.95
No. 850 73250 0002
Sure Hinge – Box of 12 hinges $29.95
No. 850 73300 0000
Pin Wire – One-pound bundle. $4.35
No. 850 73500 0000
Often used as an alternate pin in
hinges and for other stage purposes.
Sure Clamp™
The Sure Clamp has a grip range of 11⁄4"
to 2" and is used to hang lighting fixtures
or scenery directly to pipes. An extra-secure substitute for the standard CClamp, it closes automatically when
weight is hung on it and is further secured by a hand knob which requires no
tools for adjustment.
These sandbags, made in the U.S.A., are
carefully rated for the weight of sand they
will hold. They are made from strong canvas,
reinforced with a sling, and equipped with a
heavy metal hook and safety
catch. Sand is not included.
No. 850 72610 Sandbag (add 4 digits
for size)
10 pound sandbag
25 pound sandbag
50 pound sandbag
75 pound sandbag
100 pound sandbag
150 pound sandbag
200 pound sandbag
Mounted to the side of a platform or
scenery, this brake actually lifts the
scenery off its casters, preventing the
wagon from shifting under active actor
movements. A unique lever action
pushes down a plunger, lifting even very heavy pieces with only
minimal force required from a stagehand. A minimum of two
brakes per unit are recommended.
Wagon Brake w/Extension Spindle (5⁄16" x 21⁄2")
(300 lb. max.) $19.95
No. 850 74510 0000
Heavy Duty Wagon Brake (800 lb. max.) $34.95
No. 850 74550 0000
Heavy Duty Extension Spindle (optional) $3.75
No. 850 74555 0000
$30.25
33.25
43.75
57.75
62.75
65.50
77.95
Belay Pins
17" Wood Belay Pin $12.00
No. 850 71700 0017
Solid hickory wood, with an easy grip handle. 13⁄32" diameter
21" Wood Belay Pin $13.50
No. 850 71700 0021
Same as above but with4" longer shaft and 15⁄32" diameter
Lashing and Bracing Hardware
72901
Brace Hook
78200
Rocker Heel
72902
Brace Clamp Set
78231
Non-Skid Eye
Sure Clamp $48.95
No. 850 78020 0000
Wagon Brakes
(0010)
(0025)
(0050)
(0075)
(0100)
(0150)
(0200)
75420
Scheel Brace Cleat
Brace Hook $26.25
No. 850 72901 0000
This metal part is hooked onto the scenery flat
through a Scheel Brace Cleat.
Brace Clamp Set $15.00
No. 850 72902 0000
Used to adjust and secure the height of Stage Braces.
Rocker Heel $9.45
No. 850 78200 0000
Non-Skid Eye $6.30
No. 850 78231 0000
Scheel Brace Cleat $3.50
No. 850 75420 0000
Used to fasten stage braces to scenery, but grooved
to allow the stage brace hook to rest flat against the scenery.
www.rosco.com
27
Stage Hardware / Candles
Flicker Candles™
76310
Top Hanger Iron
76410
D-Ring Plate with Ring
76220
Ceiling Plate with Ring
76320
Bottom Hanger Iron
Hanging and Attaching Hardware
Ceiling Plate With Ring $17.85
No. 850 76220 0000
Lines or cable are more easily attached with this device affixed
to the ceiling of a box set. May also be used to hang relatively
lightweight scenery.
Top Hanger Iron $6.95
No. 850 76310 0000
Affixed to the top of a scenery flat for hanging.
A theatrical alternative to flame candles,
these units look and act just like the real
thing . . . right down to the dripped wax.
Most importantly, they are powered electrically, so they don’t present potential
hazards of using live flames. A simple
9-volt AC Adaptor allows you to raise or
lower the dimming level on the Flicker
Candles.
Professional Flicker Candle $72.00
No. 854 09001 0017
171⁄2" long by 11⁄2" in diameter. Comes with 4 foot leads for remote installation to a power source.
Self-Contained $44.50
No. 854 08903 0009
Complete with a candle tip, a realistic stem with a dripping wax
look, an on-off switch, and connection for a 9 volt battery, this
93⁄4" unit is for productions where the performers need to carry a
candle from place to place or where the candle needs to be
turned “on” or “off” during the show.
Bottom Hanger Iron $8.25
No. 850 76320 0000
Fits under the bottom member of a scenery flat.
Usually secured parallel to the Top Hanging Iron.
Wired Stem $35.75
No. 854 08902 0009
The Wired Stem Model is 93⁄4" and consists of the candle tip,
candle stem and 4 foot leads for remote installation to a power
source.
D-Ring Plate with Ring $3.75
No. 850 76410 0000
The floor plate bolts to the stage floor and lines may be tied off
through the D-ring.
Basic Module $29.75
No. 854 08901 0004
The Basic Module is a 4" long unit with short pins for wiring to a
power source and is ideal for building custom units.
Double Scaffold Clamp
Rosco’s Double Scaffold Clamp is manufactured using high tensile
strength aluminum extrusion. All bolts and wing nuts are zinc plated.
The Double Scaffold Clamp has a safe working load of 750Kg.
Double Scaffold Clamp
No. 850 81002 0000
$42.50
Custom Candle Range
Rosco Flicker Candles
can be custom built
into many popular
settings. Here are
some examples of the
bases and specialty
settings available.
A
B
D
C
E
Stage Screws
Stage screws are used to
Stage Plug
fasten flats or scenery
Steel Stage Screw
pieces to the stage floor.
They go directly into the wood stage floor. The Steel Stage
Screw should be used when the screw must be used in the
same place several times, or where exceptional holding power is
needed. To use the Steel Stage Screw, drill a 9⁄16" hole, screw the
Stage Plug into the floor with a wide straight blade screwdriver,
then fit the screw into the plug.
Stage Screw $6.95
No. 850 74200 0000
Steel Stage Screw $6.95
No. 850 74100 0000
3
⁄8" diameter.Heavy steel w/ zinc plating.
Stage Plug $6.95
No. 850 74150 0000
Used with Steel Stage Screw, but sold separately. For 9⁄16" hole.
F
A Three Arm Candelabra $399.00
No. 854 09002 0000
B Single Candlestick $136.00
No. 854 09004 0000
C Professional Flicker Candle $72.00
No. 854 09001 0017
D Classic Hurricane Lantern $138.00
No. 854 09003 0000
E Classic bottle with realistic dripping wax
No. 854 09006 0000
F Classic saucer holder $92.00
No. 854 09005 0000
$89.00
www.rosco.com
28
Connectors
20-Amp Dual Termination Connectors
60A Connectors
Rosco’s 60 amp connectors are available in both panel mount
and cable end configurations. UL-listed.
60A Male Plug $35.75
No. 203 10126 6001
60A Female Receptacle $40.00
No. 203 20126 6001
Direct wire or lugged connections. All the necessary hardware
for either style is included with each connector. Included strain
relief inserts allow the connector to grip standard industry cables
ranging from 12/3 stage cable to sleeved fixture leads.
20 amp male DTConnectors $6.75
No. 12120
20 amp female DTConnectors $6.75
No. 22120
Connector hardware is available in bulk packs for large shops or
installation projects. The bulk pack contains hardware sufficient for 100
connectors packed by like type for binning on the assembly bench. Also
available are 20-count packages of connectors. These are supplied with a
set of hardware conveniently packed with each connector.
To order 20-count packages of male connectors, use Product
Code 203 12120 2020;for 20-count packages of female connectors
use Product Code 203 22120 2020.
Adapters
Rosco Adapters are designed to quickly adapt Rosco 20A Connectors to the most common connections found: Twistlock and
U-ground. Unibody construction and internally wired at the
factory.
20A M Pin to 15A F U-ground $42.00
No. 203 70005 2001
20A M Pin to 20A F Twistlock $40.50
No. 203 70003 2001
20A F Pin to 15A M U-ground $27.75
No. 203 70007 2001
20A F Pin to20A M Twistlock $31.75
No. 203 70004 2001
Panel Mount Connectors
Color Covers
Connectors can be equipped with your choice of colored covers. Product numbers shown here are for 100 count boxes of
covers.
Made of high heat resistant material, the Rosco Panel Mount
Connector conforms to industry standards for compatibility and
installation. UL-listed.
20A Male Panel Mount $9.25
No. 203 50002 2001
60A Female Panel Mount $27.25
No. 203 60006 6001
20A Female Panel Mount $7.50
No. 203 60002 2001
60A Male Panel Mount $25.75
No. 203 50006 6001
Black
No. 203 00232 0100
Red
No.203 00332 0100
Green
No. 203 00432 0100
Blue
No. 203 00532 0100
Yellow
No. 203 00632 0100
Clear
No. 203 00732 0100
Wallhugger™
20-amp DTConnectors can be personalized with a company or
organization name or logo on the cover. Personalized covers can
be supplied with new connector orders or as replacement
covers for existing Rosco connectors.
Rosco’s Wallhugger is for situations where
lighting fixtures equipped with 2 P&G
connectors need to be powered from 15-amp
wall receptacles. Includes an indicator lamp
which illuminates when power is available to
the device.
Connector engraving charge
No. 22000
Wallhugger
$29.50
No. 203 70008 2001
Personalized Connectors
$ .20/cover
Auxiliary Strain Relief
A supplemental Strain Relief is available for the DT Connector
when used with undersized cable. It will accept
up to 16/3 Type S cable.
Auxiliary Strain Relief
No. 203 80002 2001
$1.00
www.rosco.com
29
Scenic Materials
Slit Drape
Glamé™
This Rosco version of slash
curtain consists of overlapping 1⁄8" strips of durable,
flame retardant vinyl, 36"
wide (91.44 cm). Add 4-digit
number in parentheses to
product number to indicate
length desired.
Solid Black
8'
16'
24'
Solid Silver
8'
16'
24'
Solid Gold
8'
16'
24'
Black/Silver
8'
16'
24'
Black/Gold
8'
16'
24'
Black/Diffraction
8'
16'
24'
White/Diffraction
8'
16'
24'
Silver/Diffraction
8'
16'
24'
Iridescent
8'
16'
24'
Silver/Iridescent/Gold 8'
16'
24'
Silver/Gold/Diffraction 8'
16'
24'
Glamé is woven from a
durable, lightweight, selfextinguishing plastic film
48" x 30 ft. roll. 330 ft. bolts
also available.
(0008) $12.50
(0016) 26.50
(0024) 53.00
(0008) 12.50
(0016) 26.50
(0024) 53.00
(0008) 12.50
(0016) 26.50
(0024) 53.00
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
(0008) 14.95
(0016) 32.50
(0024) 68.75
No. 350 02608
Silver
Gold
Silver/Black
Gold/Black
Gold/Silver
Silver/Diffraction
Gold/Diffraction
Clear/Diffraction
Iridescent/Diffraction
Razzle Dazzle
Black
Black/Iridescent
Silver/Iridescent
Gold/Iridescent
No. 350 02602
Add 4830 to product number for 30 ft. roll.
Add 4801 to product number for 330 ft. bolt.
No. 350 02610
No. 350 02609
No. 350 02625
No. 350 02600
No. 350 02606
No. 350 02601
No. 350 02630
No. 350 02634
No. 350 02636
Showcloth™
A weave of thread and self extinguishing plastic strips produces
an elegant, shimmering fabric with a soft hand and beautiful
drape. Showcloth has a selvedge edge for easy sewing.
Roll 47" x 30 ft.
Bolt 47" x 330 ft.
$ 150.00
$1,650.00
White/Gold
Black/Gold
White/Silver
White/Iridescent
Black/Silver
Black/Black
Black/Iridescent
No. 352 62101
No. 352 62102
No. 352 62103
No. 352 62104
No. 352 62105
No. 352 62106
No. 352 62107
Add 4730 to product number for 30 ft.roll.
Add 4701 to product number for 330 ft. bolt.
$ 89.25
89.25
89.25
89.25
89.25
99.00
99.00
99.00
99.00
118.00
89.25
99.00
119.00
119.00
No. 353 52006
No. 353 52009
No. 353 52012
No. 353 52013
No. 353 52014
No. 353 52032
No. 353 52033
No. 353 52034
No. 353 52035
No. 353 52041
No. 353 52045
No. 353 52052
No. 353 52053
No. 353 52054
Shimmer Scrim™
Shimmer Scrim is a combination of thread and plastic film
woven into a theatrical fabric. This self-extinguishing fabric may
be used for traditional scrim effects or as a shimmering, airy
drape. It has a selvedge edge for easy sewing.
Roll (47" x 30 ft.) $ 150.00
Bolt (47" x 330 ft.) 1,430.00
White/Iridescent/Gold
White/Clear/Iridescent
White/Iridescent/White
Black/Clear/Silver
Black/Clear/Iridescent
Black/Clear/Black
Black/Gold/Clear
No. 351 41001
No. 351 41005
No. 351 41011
No. 351 42001
No. 351 42005
No. 351 42011
No. 351 42021
Add 4730 to product number for 30 ft. roll.
Add 4701 to product number for 330 ft. bolt.
Glitter
RoscoGlitter, in 1⁄64" hexagonal chips, is uniquely suited for production applications. The chips are brilliant under stage lights
and can be sprinkled on or mixed directly into Clear Gloss or
Flat Acrylic for easy application. Small is 4 oz., large is 16 oz. except where noted.
Small / Large
Silver
$8.00 / 25.00
No. 360 02890
Gold
10.10 / 34.00
No. 360 02891
Red
10.10 / 34.00
No. 360 02893
Sky Blue
10.10 / 34.00
No. 360 02894
Royal Blue
10.10 / 34.00
No. 360 02895
Green
10.10 / 34.00
No. 360 02897
Fuchsia
10.10 / 34.00
No. 360 02898
Pink Fizz
10.10 / 34.00
No. 360 02902
Blue/Green Iridescent
10.10 / 34.00
No. 360 02904*
*Note: small is 3 oz. and large is 12 oz.
Add 0004 to number for small; add 0016 for large.
www.rosco.com
30
Scenic Materials and Products
Breakaways
Plastic breakaways shatter
realistically and are specially
packaged to assure that they are delivered intact. Bottles are shipped
with labels unattached for easy customization. Minimum order: 6 breakaways. (Bottles must be the same
color.)
1⁄2 dozen
Beer Bottle - Amber
$117.00
Beer Bottle – Green
117.00
Whiskey Bottle – Amber 130.00
Whiskey Bottle - Green 130.00
Wine Bottle – Amber
130.00
Wine Bottle – Green
130.00
Metalix™
No. 852 80011 0000
No. 852 80012 0000
No. 852 80031 0000
No. 852 80032 0000
No. 852 80051 0000
No. 852 80052 0000
This durable metalized plastic material is available in a variety of
colors and surfaces.
Metalix 48" x 30' roll
Silver Pebble
Soft Silver
Gold Pebble
Mirrors
No. 356 03902 4830
No. 356 03971 4830
No. 356 03972 4830
Multi-Lens™
A variety of reflective surfaces in a metalized plastic format.
Flexible Silver (48" x 30')
Thin Silver (60" x 30')
Thin Gold (60" x 30')
Rigid Gold (51" x 30')
Rigid Silver (51" x 30')
$89.60
$69.50
40.75
40.75
93.25
93.25
No. 359 03906 4830
No. 359 03925 6030
No. 359 03927 6030
No. 359 03930 5130
No. 359 03931 5130
A laser etched plastic film with the 3-D look of glass lenses.
Pressure sensitive for easy mounting.
Multi-Lens 24" x 15' rolls
⁄2" Silver
⁄2" Gold
2" Silver
2" Gold
1
1
$49.50
No. 357 04910 2415
No. 357 04915 2415
No. 357 04920 2415
No. 357 04925 2415
Diffractions™
Five laser etched plastic films for prismatic effects. All the
diffractions are adhesive backed.
Shrink Mirror™
Rosco’s Silver Shrink Mirror is a
lightweight substitute for heavy glass
mirror. This metalized plastic laminate is
designed to be mounted to a frame and
heat shrunk for superior
reflectance. 54" x 30'
Silver Shrink Mirror
$136.75
Diffractions 24" x 15' rolls
Exotic Circles
Exotic Hex
1
⁄4" Mosaic
Horizontal Stripes
No. 359 03909 5430
No. 358 02956 2415
No. 358 02957 2415
No. 358 02960 2415
No. 358 02962 2415
Sparklene™
Eleven glitter laminate plastic film colors.. Sparklene is pressure
sensitive for easy mounting.
Smooths™
The smooth colors are pressure-sensitive for easy mounting.
24" x 30' rolls (61 cm x 9.2 m).
Bright Orange
Gun Metal Grey
Cherry Red
Royal Blue
Silver
Pink Fizz
Light Gold
Smooth Iridescent
$46.50
$32.50
32.50
32.50
32.50
32.50
32.50
32.50
86.40
No. 355 03974 2430
No. 355 03975 2430
No. 355 03976 2430
No. 355 03980 2430
No. 355 03981 2430
No. 355 03983 2430
No. 355 03985 2430
No. 355 03986 2430
Sparklene 24" x 15' rolls (61 cm x 4.6 m).
Silver
Blue
Red
Green
Fuchsia
Gold
Fluorescent Pink
Blue/Green Iridescent
$49.50
No. 354 03990 2415
No. 354 03991 2415
No. 354 03992 2415
No. 354 03993 2415
No. 354 03994 2415
No. 354 03995 2415
No. 354 03961 2415
No. 354 03964 2415
www.rosco.com
31
Index
A
Acrylic Panels . . . . . . . . . . . . . . . .16
Acrylic Glazes . . . . . . . . . . . . . . . .19
Adagio™ Floor . . . . . . . . . . . . . . .24
Adagio™ Tour . . . . . . . . . . . . . . . .24
Adapters . . . . . . . . . . . . . . . . . . . .29
All Purpose Floor Cleaner . . . . . . .26
D
Arabesque . . . . . . . . . . . . . . . . . .24
Auxiliary Strain Relief . . . . . . . . . .29
Belay Pins . . . . . . . . . . . . . . . . . . .27
Belt Drive Rotators . . . . . . . . . . . . .3
Black (light wrapping)
Foil . . . . . . . . . . . . . . . . . . . . .16
C
Fluorescent Paint Kit . . . . . . . . . . .18
CrystalGel . . . . . . . . . . . . . . . . . . .21
Fluorescent Paints . . . . . . . . . . . . .20
Custom Candle Range . . . . . . . . .28
Foamcoat . . . . . . . . . . . . . . . . . . .21
Custom iPro Slides . . . . . . . . . . . . .9
Fog Machines . . . . . . . . . . . . .22-23
Custom Screens . . . . . . . . . . . . . .15
Fog Fluid . . . . . . . . . . . . . . . . . . .23
D-Ring Plate . . . . . . . . . . . . . . . . .28
Front Projection Screens . . . . . . . .15
Dance Floor . . . . . . . . . . . . . . . . .24
Alpha 900 Fog Machine . . . . . . . .23
B
Connectors . . . . . . . . . . . . . . . . . .29
G
Gaffers Tape . . . . . . . . . . . . . . . . .14
Deep Colors . . . . . . . . . . . . . . . . .18
Glamé . . . . . . . . . . . . . . . . . . . . .30
Deep Colors Paint Kit . . . . . . . . . .18
Glass Gobos . . . . . . . . . . . . . .13-14
Delta 3000
Fog Machine . . . . . . . . . . . . . .22
Glazes . . . . . . . . . . . . . . . . . . . . .19
Delta 6000
Fog Machine . . . . . . . . . . . . . .22
Glitter . . . . . . . . . . . . . . . . . . . . . .30
Gear Drive Rotators . . . . . . . . . . . .4
Glow Tape . . . . . . . . . . . . . . . . . .14
Delta Haze Fluid . . . . . . . . . . . . . .23
Gobo Catalog . . . . . . . . . . . . . . . .13
Black Light Paints . . . . . . . . . . . . .20
DichroFilm . . . . . . . . . . . . . . . . . .10
Bottom Hanger Iron . . . . . . . . . . .28
Diffractions . . . . . . . . . . . . . . . . . .31
Brace Clamp Set . . . . . . . . . . . . . .27
Diffusion Kit . . . . . . . . . . . . . . . . .11
Brace Hook . . . . . . . . . . . . . . . . .27
DigiComp™ . . . . . . . . . . . . . . . . .17
Breakaways . . . . . . . . . . . . . . . . .31
DigiComp™ Cable . . . . . . . . . . . .17
Brushes . . . . . . . . . . . . . . . . . . . . .20
DMC/DC Controller . . . . . . . . . . . .4
Bubble Fluid . . . . . . . . . . . . . . . . .23
DMX Iris . . . . . . . . . . . . . . . . . . . . .4
Butterflies . . . . . . . . . . . . . . . . . . .16
Donuts . . . . . . . . . . . . . . . . . . . . .14
Heavy Duty Floor Cleanser . . . . . .26
Cable End Connectors . . . . . . . . .29
Double Gobo Rotator . . . . . . . . . . .4
Hinges . . . . . . . . . . . . . . . . . . . . .27
CalColor Kit . . . . . . . . . . . . . . . . .11
Dual Termination
Connectors . . . . . . . . . . . . . . .29
Holders, Gobo . . . . . . . . . . . . . . .14
Candles . . . . . . . . . . . . . . . . . . . .28
Caution Tape . . . . . . . . . . . . . . . .14
E
E-Colour . . . . . . . . . . . . . . . . . . . .10
Gobo Holders . . . . . . . . . . . . . . . .14
Gobo Rotators . . . . . . . . . . . . . . .3-4
Gobo Stainless Steel . . . . . . . . . . .13
H
I
Granulated Floor
Cleanser . . . . . . . . . . . . . . . . .26
Hanging and Attaching
Hardware . . . . . . . . . . . . . . . .28
Hybrid Two-Fer . . . . . . . . . . . . . . . .9
I-Cue Intelligent Mirror . . . . . . . . . .5
Ceiling Plate With Ring . . . . . . . . .28
Epoxy Adhesive No. 300 . . . . . . . .26
Chroma Floor . . . . . . . . . . . . . . . .17
Extension Spindle . . . . . . . . . . . . .27
Iddings Deep Colors Paint Kit . . . .18
Fabric, Digital
Compositing . . . . . . . . . . . . . .17
Image Glass . . . . . . . . . . . . . . . . .13
ChromaSleeves . . . . . . . . . . . . . . .12
Cinefoil . . . . . . . . . . . . . . . . . . . . .16
Filmmaking Tools . . . . . . . . . . .16-17
Cinegel . . . . . . . . . . . . . . . . . . . . .10
Finished Screens . . . . . . . . . . . . . .15
Cinegel Sampler Kit . . . . . . . . . . .11
Fire Retardants . . . . . . . . . . . . . . .21
ClearColour . . . . . . . . . . . . . . . . .20
Fitch Brushes . . . . . . . . . . . . . . . .20
ClearColour Test Kit . . . . . . . . . . .18
Flamex . . . . . . . . . . . . . . . . . . . . .21
Clear Flat Acrylic . . . . . . . . . . . . . .19
FlexBond . . . . . . . . . . . . . . . . . . .21
Clear Gloss Acrylic . . . . . . . . . . . .19
Flexcoat . . . . . . . . . . . . . . . . . . . .21
Coatings . . . . . . . . . . . . . . . . . . . .21
Flicker Candles . . . . . . . . . . . . . . .28
Coldflow . . . . . . . . . . . . . . . . . . .23
Floor Adhesive . . . . . . . . . . . . . . .26
ColorCoat . . . . . . . . . . . . . . . . . . .19
Floor Bag . . . . . . . . . . . . . . . . . . .26
Color Correction Kit . . . . . . . . . . .11
Floor Care . . . . . . . . . . . . . . . . . .26
Color Effects Kit . . . . . . . . . . . . . .11
Floor Catalog . . . . . . . . . . . . . . . .24
Colorine . . . . . . . . . . . . . . . . . . . .20
Floors . . . . . . . . . . . . . . . . . . .24-25
Colorizer Gobos . . . . . . . . . . . . . .13
Floor Tapes . . . . . . . . . . . . . . . . . .26
ColorWaves . . . . . . . . . . . . . . . . .13
Floor Welding Threads . . . . . . . . .26
Chroma Key Paints . . . . . . . . . . . .17
F
Iddings Deep Colors . . . . . . . . . . .18
Infinity . . . . . . . . . . . . . . . . . . . . . .4
iPro™ . . . . . . . . . . . . . . . . . . . . . . .9
iPro Slides . . . . . . . . . . . . . . . . . . . .9
K
L
iPro Slide Film . . . . . . . . . . . . . . . .9
Keying Paints . . . . . . . . . . . . . . . .17
Lashing and Bracing Hardware . . .27
Lay-In Brushes . . . . . . . . . . . . . . .20
LED Channel Mount . . . . . . . . . . .12
Lens Cleaner . . . . . . . . . . . . . . . . .12
Lens Tissue . . . . . . . . . . . . . . . . . .12
Light Fog Fluid . . . . . . . . . . . . . . .23
LitePad Axiom . . . . . . . . . . . . . . . .5
LitePad Custom . . . . . . . . . . . . . . .6
LitePad DL . . . . . . . . . . . . . . . . . . .6
LitePad HO+ . . . . . . . . . . . . . . . . .6
LitePadKits . . . . . . . . . . . . . . . . . . .7
www.rosco.com
32
Index
Litepad Accessories . . . . . . . . . . .7–8
Roscoflamex SF . . . . . . . . . . . . . .21
Supersaturated Roscopaint . . . . . .19
Loose Pin Hinge . . . . . . . . . . . . . .27
Roscoflamex WD . . . . . . . . . . . . .21
Supersaturated Paint Kit . . . . . . . .18
Roscoglo Paint . . . . . . . . . . . . . . .20
Sure Clamp . . . . . . . . . . . . . . . . . .27
Mirrors . . . . . . . . . . . . . . . . . . . . .31
Roscoleum Floor . . . . . . . . . . . . . .25
Sure Hinge . . . . . . . . . . . . . . . . . .27
Model 1700 . . . . . . . . . . . . . . . . .22
Roscoleum Adhesive . . . . . . . . . . .26
Model 1900 . . . . . . . . . . . . . . . . .22
Roscolux . . . . . . . . . . . . . . . . . . . .10
Test Kits, Paint . . . . . . . . . . . . . . . .18
MR-16 Filter Holder . . . . . . . . . . .12
Roscopak . . . . . . . . . . . . . . . . . . .16
ThermaShield . . . . . . . . . . . . . . . .10
Multi-Lens . . . . . . . . . . . . . . . . . .31
Roscoscreen . . . . . . . . . . . . . . . . .15
Tight Pin Hinge . . . . . . . . . . . . . . .27
RoscoShades . . . . . . . . . . . . . . . . .17
Tiles . . . . . . . . . . . . . . . . . . . . . . .25
Roscosleeves . . . . . . . . . . . . . . . . .12
Top Hanger Iron . . . . . . . . . . . . . .28
Off Broadway Paint Kit . . . . . . . . .18
Roscotiles . . . . . . . . . . . . . . . . . . .25
Tough Prime . . . . . . . . . . . . . . . . .19
Overheads . . . . . . . . . . . . . . . . . .16
RoscoView . . . . . . . . . . . . . . . . . .17
Transparent Screen Tape . . . . . . . .15
Paint, Digital Compositing . . . . . . .17
Rotator Accessories . . . . . . . . . . . . .4
TruColor IR . . . . . . . . . . . . . . . . . .16
Safety Frames . . . . . . . . . . . . . . . .10
TV Paints . . . . . . . . . . . . . . . . . . .17
M Metalix . . . . . . . . . . . . . . . . . . . . .31
N Non-Skid Eye . . . . . . . . . . . . . . . .27
O Off Broadway Paint . . . . . . . . . . . .18
P
Paint, Video . . . . . . . . . . . . . . . . .17
Paint Sampler Kits . . . . . . . . . . . . .18
S
Sampler Kits, Paint . . . . . . . . . . . .18
T
U
Tec Stretch Film . . . . . . . . . . . . . .14
Ultimatte Paints . . . . . . . . . . . . . .17
Panel Mount Connectors . . . . . . .29
Sandbags . . . . . . . . . . . . . . . . . . .27
Universal Iris Slot Holder . . . . . . .14
Pattern Holders . . . . . . . . . . . . . . .14
Scaffold Clamps . . . . . . . . . . . . . .28
UV Filter . . . . . . . . . . . . . . . . . . . .10
Performance Floor . . . . . . . . . . . .25
Scheel Brace Cleat . . . . . . . . . . . .27
Permacolor Dichroic
Filters . . . . . . . . . . . . . . . . . . . .11
Screens . . . . . . . . . . . . . . . . . . . . .15
Video Paints . . . . . . . . . . . . . . . . .17
Screen Tape . . . . . . . . . . . . . . . . .15
Vivid FX Sample Kit . . . . . . . . . . .18
Permacolor Frames . . . . . . . . . . . .12
Shimmer Scrim . . . . . . . . . . . . . . .30
VividFX Ultraviolet Paint . . . . . . . .20
Permacolor Technical
Coatings . . . . . . . . . . . . . . . . .11
Show Floor . . . . . . . . . . . . . . . . . .25
Vortex 360 Dual Rotator . . . . . . . . .4
Personalized Connectors . . . . . . . .29
Pin Wire . . . . . . . . . . . . . . . . . . . .27
Polarizing Filters . . . . . . . . . . . . . .16
PortaBarre . . . . . . . . . . . . . . . . . .26
Power Supply Units . . . . . . . . . . . .5
Premiere Clear . . . . . . . . . . . . . . .21
Premium Adhesive No. 755 . . . . .26
Prismatics . . . . . . . . . . . . . . . . . . .14
Projection Screen . . . . . . . . . . . . .15
Q Quick Color Sleeves . . . . . . . . . . .12
R Rear Projection Screens . . . . . . . .15
Reflection Media . . . . . . . . . . . . .16
Reflector Cleaner . . . . . . . . . . . . .12
REVO™ Dual Indexing Rotator . . . .3
RevoPRO™ Gobo Rotator . . . . . . . .3
Revo Rotator Accessories . . . . . . . .3
Rocker Heel . . . . . . . . . . . . . . . . .27
Rosco Paint Sampler . . . . . . . . . . .18
Roscoflamex DF . . . . . . . . . . . . . .21
Roscoflamex NF . . . . . . . . . . . . . .21
Roscoflamex PA . . . . . . . . . . . . . .21
Roscoflamex PC . . . . . . . . . . . . . .21
V
Variable Speed Controller . . . . . . . .4
Showcloth . . . . . . . . . . . . . . . . . .30
W Wagon Brakes . . . . . . . . . . . . . . . .27
Shrink Mirror . . . . . . . . . . . . . . . .31
Wallhugger . . . . . . . . . . . . . . . . . .29
SimpleSpin™ Dual Gobo Rotator . .3
Welding Threads . . . . . . . . . . . . . .26
Slash Curtains . . . . . . . . . . . . . . . .30
X
X-Effects Projector . . . . . . . . . . . . . .5
Slit Drape . . . . . . . . . . . . . . . . . . .30
Smoke Machines . . . . . . . . . . .22-23
Smooths . . . . . . . . . . . . . . . . . . . .31
Sparklene . . . . . . . . . . . . . . . . . . .31
Spike Tape . . . . . . . . . . . . . . . . . .14
Stage & Studio Fluid . . . . . . . . . . .23
Stage Plug . . . . . . . . . . . . . . . . . . .28
Stage Screws . . . . . . . . . . . . . . . . .28
Stainless Steel Gobos . . . . . . . . . .13
Steel Stage Screw . . . . . . . . . . . . .28
Stippled Colorizers . . . . . . . . . . . .13
Storage Drawers . . . . . . . . . . . . . .12
Strain Relief . . . . . . . . . . . . . . . . .29
Stretch-N-Hook . . . . . . . . . . . . . .15
Studio Floor . . . . . . . . . . . . . . . . .25
SubFloor . . . . . . . . . . . . . . . . . . . .25
Super Heat Shield . . . . . . . . . . . . .10
Supersaturated Paint
Concentrated Bases . . . . . . . . .19
www.rosco.com
33
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
