32 Mbit (1M x 32-Bit), 16 Mbit (512K x 32-Bit),
2.5 V, Burst, Dual Boot Flash
This product family has been retired and is not recommended for designs. For new and current designs, the S29CD016J and
S29CD032J supercede S29CD016G and S29CD032G respectively. This is the factory-recommended migration path. Please refer
to the S29CD-J data sheet for specifications and ordering information. Availability of this document is retained for reference and
historical purposes only.
Distinctive Characteristics
Architecture Advantages
– Standby mode: CMOS: 60 µA max
 1 million write cycles per sector typical
 Simultaneous Read/Write Operations
– Read data from one bank while executing erase/program
functions in other bank
– Zero latency between read and write operations
– Two bank architecture: large bank/small bank 75% / 25%
 20 year data retention typical
 Dual Boot Block
– Top and bottom boot sectors in the same device
Software Features
es
ig
n
 User-Defined x32 Data Bus
 VersatileI/O™ Control
– Generates data output voltages and tolerates data input voltages
as determined by the voltage on the VIO pin
– 1.65 V to 3.60 V compatible I/O signals
 Persistent Sector Protection
– Locks combinations of individual sectors and sector groups to
prevent program or erase operations within that sector (requires
only VCC levels)
ew
rN
 Supports Common Flash Interface (CFI)
de
d
 Manufactured on 170 nm Process Technology
om
m
en
 Programmable Burst Interface
– Interfaces to any high performance processor
– Linear Burst Read Operation: 2, 4, and 8 double word linear burst
with or without wrap around
 Program Operation
– Performs synchronous and asynchronous write operations of
burst configuration register settings independently
R
ec
 Single Power Supply Operation
– Optimized for 2.5 to 2.75 volt read, erase, and program operations
N
ot
 Compatibility with JEDEC standards (JC42.4)
– Software compatible with single-power supply Flash
– Backward-compatible with AMD/Fujitsu Am29LV/MBM29LV and
Am29F/MBM29F flash memories
Performance Characteristics
 High Performance Read Access
– Initial/random access times of 48 ns (32 Mb) and 54 ns (16 Mb)
– Burst access times of 7.5 ns (32 Mb) or 9 ns (16Mb)
 Ultra Low Power Consumption
– Burst Mode Read: 90 mA @ 75 MHz max
– Program/Erase: 50 mA max
 Password Sector Protection
– Locks combinations of individual sectors and sector groups to
prevent program or erase operations within that sector using a
user-definable 64-bit password
fo
 Secured Silicon Sector (256 Bytes)
– Factory locked and identifiable: 16 bytes for secure, random
factory Electronic Serial Number; Also know as Electronic Marking
D
 Flexible Sector Architecture
– CD032G: Eight 2K Double Word, Sixty-two 16K Double Word, and
Eight 2K Double Word sectors
– CD016G: Eight 2K Double Word, Thirty-two 16K Double Word,
and Eight 2K Double Word sectors
 Unlock Bypass Program Command
– Reduces overall programming time when issuing multiple program
command sequences
 Data# Polling and Toggle Bits
– Provides a software method of detecting program or erase
operation completion
Hardware Features
 Program Suspend/Resume & Erase Suspend/Resume
– Suspends program or erase operations to allow reading,
programming, or erasing in same bank
 Hardware Reset (RESET#), Ready/Busy# (RY/BY#), and Write
Protect (WP#) Inputs
 ACC Input
– Accelerates programming time for higher throughput during
system production
 Package Options
– 80-pin PQFP
– 80-ball Fortified BGA
– Pb-free package option also available
– Known Good Die
General Description
The S29CD-G Flash Family is a burst mode, Dual Boot, Simultaneous Read/Write family of Flash Memory with VersatileI/O™
manufactured on 170 nm Process Technology.
The S29CD032G is a 32 Megabit, 2.6 Volt-only (2.50 V - 2.75 V) single power supply burst mode flash memory device that can be
configured for 1,048,576 double words.
Cypress Semiconductor Corporation
Document Number: 002-01299 Rev. *B
•
198 Champion Court
•
San Jose, CA 95134-1709
•
408-943-2600
S29CD032G
S29CD016G
The S29CD016G is a 16 Megabit, 2.6 Volt-only (2.50 V - 2.75 V) single power supply burst mode flash memory device that can be
configured for 524,288 double words.
To eliminate bus contention, each device has separate chip enable (CE#), write enable (WE#) and output enable (OE#) controls.
Additional control inputs are required for synchronous burst operations: Load Burst Address Valid (ADV#), and Clock (CLK).
Each device requires only a single 2.6 Volt-only (2.50 V – 2.75 V) for both read and write functions. A 12.0-volt VPP is not required
for program or erase operations, although an acceleration pin is available if faster programming performance is required.
The device is entirely command set compatible with the JEDEC single-power-supply Flash standard. The software command set is
compatible with the command sets of the 5 V Am29F or MBM29F and 3 V Am29LV or MBM29LV Flash families. Commands are
written to the command register using standard microprocessor write timing. Register contents serve as inputs to an internal statemachine that controls the erase and programming circuitry. Write cycles also internally latch addresses and data needed for the
programming and erase operations. Reading data out of the device is similar to reading from other Flash or EPROM devices.
The Unlock Bypass mode facilitates faster programming times by requiring only two write cycles to program data instead of four.
D
es
ig
n
The Simultaneous Read/Write architecture provides simultaneous operation by dividing the memory space into two banks. The
device can begin programming or erasing in one bank, and then simultaneously read from the other bank, with zero latency. This
releases the system from waiting for the completion of program or erase operations. See Simultaneous Read/Write Operations
Overview on page 20.
ew
The device provides a 256-byte Secured Silicon Sector that contains Electronic Marking Information for easy device traceability.
fo
rN
In addition, the device features several levels of sector protection, which can disable both the program and erase operations in
certain sectors or sector groups: Persistent Sector Protection is a command sector protection method that replaces the old 12 V
controlled protection method; Password Sector Protection is a highly sophisticated protection method that requires a password
before changes to certain sectors or sector groups are permitted; WP# Hardware Protection prevents program or erase in the two
outermost 8 Kbytes sectors of the larger bank.
om
m
en
de
d
The device defaults to the Persistent Sector Protection mode. The customer must then choose if the Standard or Password
Protection method is most desirable. The WP# Hardware Protection feature is always available, independent of the other protection
method chosen.
The VersatileI/O™ (VCCQ) feature allows the output voltage generated on the device to be determined based on the VIO level. This
feature allows this device to operate in the 1.8 V I/O environment, driving and receiving signals to and from other 1.8 V devices on
the same bus.
ec
The host system can detect whether a program or erase operation is complete by observing the RY/BY# pin, by reading the DQ7
(Data# Polling), or DQ6 (toggle) status bits. After a program or erase cycle is completed, the device is ready to read array data or
accept another command.
ot
R
The sector erase architecture allows memory sectors to be erased and reprogrammed without affecting the data contents of other
sectors. The device is fully erased when shipped from the factory.
N
Hardware data protection measures include a low VCC detector that automatically inhibits write operations during power
transitions. The password and software sector protection feature disables both program and erase operations in any combination
of sectors of memory. This can be achieved in-system at VCC level.
The Program/Erase Suspend/Erase Resume feature enables the user to put erase on hold for any period of time to read data
from, or program data to, any sector that is not selected for erasure. True background erase can thus be achieved.
The hardware RESET# pin terminates any operation in progress and resets the internal state machine to reading array data.
The device offers two power-saving features. When addresses are stable for a specified amount of time, the device enters the
automatic sleep mode. The system can also place the device into the standby mode. Power consumption is greatly reduced in
both these modes.
AMD’s Flash technology combines years of Flash memory manufacturing experience to produce the highest levels of quality,
reliability and cost effectiveness. The device electrically erases all bits within a sector simultaneously via Fowler-Nordheim
tunnelling. The data is programmed using hot electron injection.
Document Number: 002-01299 Rev. *B
Page 2 of 78
