SolarRiver Series Inverter Installation
&DC/AC Terminal Disconnection Guide
Wall bracket
Use the wall bracket as a drilling template and mark the positions of the drill holes
Wall bracket
Use at least five holes
Hang the Solar River
The Solar River tilted slightly upward;
Attach the Solar River to the wall bracket slightly to the top of its final position
Hang the Solar River
Top side
Bottom side
Check the hanging
After hanging the Solar River, check both left and right sides to ensure that
it is correctly in place
Screw
Screw the bottom side
DC cable wiring
Step 1 Put the threaded sleeve and pressure screw
through the DC wire(refer to figure 1 to figure 5)
Step 1 Put the threaded sleeve and pressure screw through the DC wire
Bare wire
length about
7mm
1
3
2
4
5
DC cable wiring
Step 2 Crimping the terminal
DC cable wiring
Step 3 insert into plastic terminal
Positive Terminal
Negative Terminal
DC cable wiring
Step 4 Screw down the threaded sleeve and the pressure screw
Positive Terminal
Negative Terminal
AC cable wiring
Step 1 Put the threaded sleeve and pressure screw through the AC wire
Bare wire length about
7mm
AC cable wiring
Step 2 Wire the AC wire refer to below instructions.
·Screw the green-yellow wire to the ground terminator in the AC Connector
·Screw the blue wire to the N(Neutral) terminator in the AC Connector.
·Screw the brown wire to the L(Line) terminator in the AC Connector.
AC cable wiring
Step 3 Confirm all the wires should be screwed down
AC cable wiring
Step 4 Screw down the threaded sleeve and the pressure screw
SolarRiver DC/AC Terminal Disconnection Guide
Figure
Description
Tools
Disconnect the positive DC terminal
1.Use the Wrench Tool, insert it
on the back of the positive DC
terminal adaptor.(Figure 1),the
obvious position as Figure 2.
Figure 1
Universal unlocking tool
Manufacture: AMPHENOL
Note: For SolarRiver
1100TL,1600TL,1700TL,2300TL,3000TL,
both Wrench Tool and Universal
Unlocking Tool are suitable for this step.
For SolarRiver
3300TL,3680TL,4400TL,5200Tl,only Wrench
Tool is suitable for this step.
Figure 2
Wrench Tool
Manufacture: AMPHENOL
2.When you hear a “click “,it
means the Wrench Tool is fully
inserted (Figure3),then you can
pull out the positive DC terminal
adaptor as Figure 4.
Figure 3
Figure 4
SolarRiver DC/AC Terminal Disconnection Guide
Description
Figure
Disconnect the Negative DC terminal
1.Use the Wrench Tool, insert it
on the back of the Negative DC
terminal adaptor.(Figure 5),the
obvious position as Figure 6.
Note: For SolarRiver
1100TL,1600TL,1700TL,2300TL,3000TL,
both Wrench Tool and Universal
Unlocking Tool are suitable for this step.
For SolarRiver
3300TL,3680TL,4400TL,5200Tl,only Wrench
Tool is suitable for this step.
Figure 5
Figure 6
2.When you hear a “click” it
means the Universe Unlocking
Tool is fully inserted (Figure7),
then you can pull out the
negative DC terminal adaptor
as figure 8.
Figure 7
Figure 8
SolarRiver DC/AC Terminal Disconnection Guide
Description
Figure
Disconnect the AC terminal
1.Use the screw driver to press
the click on the AC terminal
adaptor(Figure 9),the obvious
position as Figure 10.
Figure 9
2.Pull out the AC terminal adaptor
as Figure 11.
Figure 11
Figure 10
•
•
•
•
•
•
•
•
•
•
•
