INSTALLATION PRODUCTS
4
Installation Mixers/Preamplifiers
4
Audio Sound Sources
7
5x4 Analog Audio Matrix
8
8x8 Digital Audio Matrix
9
Self-powered Mixers
11
Compact Amplifiers
14
Amplifiers
15
Processors
25
In Ceiling / In Wall Speakers
28
Loudspeaker Cabinets
33
ACCESSORIES
61
Audio Accessories
61
Desktop Paging Stations
63
Video Accessories
64
Accessories Compatibility Chart
65
INSTALLATION REFERENCES
66
ADVERTISEMENTS
72
WORLDWIDE DISTRIBUTION
75
3
SERIE SAM
SAM312, SAM 412T, SAM512T,
SAM614T
SAM312, SAM 412T, SAM512T,
SAM614T
SAM312
••
••
••
••
••
••
••
••
••
••
••
••
••
••
4
Applications
Accessories
••
••
••
••
••
••
••
••
••
•• MPAGE1 , desktop paging station
(for more information visit the MPAGE series product page)
Gyms
Licensed venues
Restaurants
Leisure venues
Retail outlets
Boardrooms and
conference centres
Entertainment music playback
Education centres
A/V presentations
MPAGE1
Key features
3 input channels, 2 main outputs 19” installation mixer
3 MIC/stereo LINE input channel mixer
Input signal pushbutton selector (MIC/LINE) on back panel
Dedicated "Low Line" input with adapated sensibility for low level line signal sources, like mp3 players (iPod®, etc.) and laptop computers
Independent internal assignable phantom power for all MIC inputs
Direct MIX input allows straight forward connection of further mixers
Triple tone control (accessible only with screwdriver)
2 stereo outputs
3 led output level metre
2 additional stereo REC outputs (REC1, REC2)
Mono mode pushbutton
Headphones general MIX monitoring
Full remote MUTE control
Side rack mount ears with 2 possible positions, for front panel alignment with devices in the same rack
SAM412T
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
SAM512T
Key features
4 MICRO/LINE input channels with independent 3 band tone control 19” installation mixer
4 channels with 2 selectable inputs per channel (balanced micro, line)
Dedicated “Low Line” input with adapted sensibility for low level line signal sources, like mp3 players (iPod®, etc.) and laptop computers
Micro sensitivity level can be adjusted on the back panel
+18V Phantom Power available in all “MIC” inputs
Direct micro input on front panel, channel 1
Includes a talkover assigned to “INPUT 1” with internal release time adjustment
Three-band tone controls for each channel, accessible with a screwdriver
Vu-meter for the mix signal
Output level control
Two internally adjustable output levels
Recording output
Direct access to the mixing bus allowing you to connect another mixer and increase the number of inputs
Remote MUTE control affecting all inputs for connecting fire detection systems and/or other safety devices. Internally programmable “NO / NC” (normally open, normally closed)
Mono/stereo switch
Side rack mount ears with 2 possible positions, for front panel alignment with devices in the same rack
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
installation mixers / preamplifiers
5 input channels, 2 main outputs 19” installation mixer
5 MIC/stereo LINE input channel mixer
Input signal pushbutton selector (MIC/LINE) on back panel
Dedicated “Low Line” input with adapated sensibility for low level line signal sources,
like mp3 players (iPod®, etc.) and laptop computers
PFL on all inputs for headphone monitoring
Independent internal assignable phantom power for all MIC inputs
Channel 1 features integrated TALKOVER on MIC input. Additional front panel MIC connector
Direct MIX input allows straight forward connection of further mixers
Triple tone control (accessible only with screwdriver)
2 stereo outputs with independent volume control
3 LED output level metre
2 additional stereo REC outputs (REC1, REC2)
Mono mode pushbutton
Full remote MUTE control
Side rack mount ears with 2 possible positions, for front panel alignment with devices in the same rack
SAM614T
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Key features
Product
installation mixers / preamplifiers
SERIE SAM
Key features
6 input channels routable to 2 main outputs. 19” installation mixer
6 input channels
MIC inputs on channels 1 and 2
Dedicated “Low Line” input with adapted sensibility for low level line signal sources, like mp3 players (iPod®, etc.) and laptop computers
MIC/stereo LINE in channels 3 and 4. Input signal selector (MIC/LINE) on back panel
Stereo LINE on channels 5 and 6
Input signal gain level control (accessible only with a screwdriver)
Each channel features signal present (SP) and CLIP indicators
General phantom power switch located on back panel. Independent internal phantom power assignment to any MIC input
Triple tone control (accessible only with a screwdriver)
2 main stereo outputs with independent volume control
3 LED output level metre
Input channels can be routed to any main output (A,B) or both
2 additional stereo REC outputs (REC1, REC2)
Mono mode selector
Headphones monitoring of selected output (A or B)
Integrated, internally configurable TALKOVER. Affects OUT A and REC A
Built-in, internally programmable TALKOVER. Affects OUT A and REC A
Side rack mount ears with 2 possible positions, for front panel alignment with devices in the same rack
SAM312
Frequency
response
Signal/Noise ratio
LINE
MIC BAL
LINE
MIC BAL
BASS
Technical Characteristics
Inputs
Sensitivity nom(*)
Impedance
Input sensitivity
adjust
Outputs
SAM312
SAM412T
SAM512T
MIX
0dBV/50kΩ
-5dBV/50kΩ
-50(-30)dBV*/2.2kΩ
0(-10)dBV*/›20(›6)kΩ
0dBV/50kΩ
-5dBV/50kΩ
-50(-20)dBV/›1kΩ
0dBV›6kΩ
0dBV/50kΩ
-5dBV/50kΩ
-50(-30)dBV/2.2kΩ
0(-10)dBV*/›20(›6)kΩ
-5dBV/47kΩ
-5dBV/50kΩ
-45dBV*/›1kΩ
-
GAIN
-
-
-
±20dB
OUT BAL
0(+6)dBV*/600Ω1(2)V
0(+6)dBV*/2.2kΩ1(2)V
0dBV/10kΩ
200mW/200Ω
0(+6)dBV*/600Ω1(2)V
0(+6)dBV*/2.2kΩ1(2)V
0dBV/10kΩ
-
0(+6)dBV*/600Ω1(2)V
0(+6)dBV*/2.2kΩ1(2)V
0dBV/10kΩ
200mW/200Ω
0(+6)dBV*/600Ω1(2)V
0(+6)dBV*/600Ω1(2)V
0dBV/10kΩ
230mW/400Ω
LINE (1/2/3)
L LINE (4)
MIC BAL
OUT UNBAL
Level/Minimum load
REC
HEADPHONES
SAM614T
Tone control
MID
TREBLE
Talkover
Phantom Voltage
Mains
Power consumption
Dimensions
Weight
PANEL
DEPTH
10Hz-55kHz-1dB
10Hz-35kHz-1dB
›100dB
›85dB
100Hz±15dB
2kHz±15dB
10kHz±15dB
+18VDC
90-264VCA 47-63Hz
18VA
482.6x44mm
195mm
2.4kg
SAM412T
10Hz-50kHz-1dB
10Hz-30kHz-1dB
›100dB
›85dB
100Hz±15dB
2kHz±15dB
10kHz±15dB
TIME 1/2/3 seg*
-30dB
+18VDC
90-264VCA 47-63Hz
23VA
482.6x44mm
195mm
2.4kg
SAM512T
10Hz-55kHz-1dB
10Hz-35kHz-1dB
›100dB
›85dB
100Hz±15dB
2kHz±15dB
10kHz±15dB
TIME 1/2/3 seg*
EFFECT -30dB
+18VDC
90-264VCA 47-63Hz
20VA
482.6x44mm
195mm
2.4kg
SAM614T
10Hz-30kHz-1dB
10Hz-30kHz-1dB
›100dB
›80dB
100Hz±12dB
1.8kHz±15dB
10kHz±12dB
RECOVERY TIME
2 (1-3) seg*
+18VDC
90-264VCA
29VA
482.6x44mm
195mm
2.6kg
(*) Internally selectable
5
COMPACT series
COMPACT5, COMPACT8
audio sound sources
Versatile laptop and 19” installation mixers. Specially targeted to both non
technical and expert users.
COMPACT5 Key features
••
••
••
••
••
••
Universal 5 channel laptop and 19” installation rack mixer
8 LINE inputs, 3 MIC inputs, 2 PHONO inputs
2 independent MASTER (1x XLR / 1x RCA) and REC output
3 band equalizer per channel
PFL monitoring. Talkover. Phantom power
45mm ECLER faders per channel
COMPACT8
••
••
••
••
••
••
••
••
••
••
••
••
Key features
Universal 8 channel laptop and 19” installation rack mixer
3 Phono inputs
7 Stereo Line RCA inputs plus AUX (RCA) inputs in front panel
8 MIC (COMBO connector) inputs. Phantom power
2 independent outputs (XLR3 and RCA)
Additional REC output
3 band tone control featuring mids 300Hz-6,5kHz
semi-parametric equalisation
Headphones output for PFL and MIX monitoring
Extra bright 12 position VU-meter
Assignable talkover with EFFICIENCY and TIME adjustments
60 mm high quality ECLER faders
Specifically developed for applications requiring a large number of micro
phone inputs
Double sound source including one FM radio tuner and one multi-format audio player:
CD-drive, USB slot and SD card slot readers. The 2VSP includes 3 audio outputs: tuner
output, multi-format player output and a third one called PRIORITY, which delivers the
same audio as the CD / USB / SD player as long as it is playing, switching to the FM tuner
audio when the CD / USB / SD player stops. This way your installation can be always fed
with audio contents. Additionally, the Vari-Speed control lets the user change the audio
track’s tempo, a function especially interesting in fitness applications.
Product
installation mixers / preamplifiers
2VSP
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
Double-deck audio player
FM TUNER with 60 presets
CD / USB / SD card readers (PCM and mp3 formats supported)
Antishock system in CD reader
FM tuner RCA stereo output
CD / USB / SD card player RCA stereo output
PRIORITY RCA stereo output (deliver the same audio as the CD / USB / SD
player until it finishes, switching to the FM tuner audio)
Double front panel LCD display (player and tuner)
ID3 tags support
Folders reading support
IR remote control
Vari-Speed control for tracks’ tempo modification
REPEAT and PROGRAM functions
The 2VSP integrates a priority output to guarantee that the
installation’s audio contents or BGM is never stopped
COMPACT8 back panel
Technical Characteristics
COMPACT5
COMPACT8
MICRO ATT (BAL)
0dBV/50kΩ
-40dBV/50kΩ
-50dBV/›1kΩ
-
OUT 1 (BAL)
0dBV/600Ω 1V*
OUT 2
0dBV/2.2kΩ 1V*
REC
0dBV/10kΩ
230mW/400Ω
10Hz÷30kHz-1dB
10Hz÷25kHz-1dB
RIAA±0.5dB
›100dB
›85dB
›90dB
0dBV/50kΩ
-40dBV/50kΩ
-50dBV/›1kΩ
-30dBV/›1kΩ
0dBV/600Ω
1V*(+6dB 2V)
0dBV/2.2kΩ
1V*(+6dB 2V)
0dBV/10kΩ
200mW/200Ω
10Hz÷30kHz-1dB
10Hz÷30kHz-1dB
RIAA±0.5dB
›100dB
›85dB
›95dB
LINE (A-B-AUX)
Inputs
Sensitivity nom(*)Impedance
Outputs
Level/Minimum load
PHONO
MICRO (BAL)
HEADPHONES
LINE
Frequency response
MICRO BAL
PHONO
LINE
Signal/Noise ratio
MICRO
PHONO
6
Gain control all inputs
GAIN
BASS
Tone control
MID
TREBLE
Talkover
TIME
EFFECT
Phantom Voltage
Mains
Power consumption
Dimensions
Weight
PANEL
DEPTH
COMPACT5
COMPACT8
±20dB
100Hz±12dB
1.8kHz±15dB
10kHz±11dB
0,3/3 seg
0/-30dB
+18VDC/5mA max
90-264VAC 47-63Hz
28VA
482.6x132.5mm
200mm
3.7kg
±20dB
90Hz
300Hz÷6,5kHz±15dB
12kHz
0,3/3 seg
0/-30dB
+18VDC/5mA max
90-264VAC 47-63Hz
33VA
482.6x177mm
221,6mm
5.2kg
COMPACT5 Applications
••
••
••
••
Pubs
Night Clubs
Retail Shops
Fitness Centres
Technical Characteristics
Inputs
Outputs
Nominal output level
COMPACT8 Applications
Frequency response
••
••
••
••
••
Separation @ 1 KHz
THD @ 1 KHz
S/N ratio
Weight
Dimensions
A/V presentations
Entertainment music playback
Meeting and seminar rooms
Education Centres
Mobile outdoor applications
2VSP
FM 75 ohm unbalanced antenna terminals
USB & SD CARD slots (mp3 reader)
CD drive (PCM and mp3 reader)
3 x stereo RCA connectors: TUNER, CD and PRIORITY outputs
1.2V ±2dB
20 Hz ± 1 dB
100 Hz ± 1dB
10 KHz ± 2 dB
20 KHz ± 3 dB
›60dB
‹ 0.15%
› 80dB
4 Kg.
482 x 44 x 250 mm (1 RU)
Applications
•• BGM audio in single or multi-zone
applications
•• Fitness
•• Fixed sound source in clubs, pubs, etc.
Recommended preamplification
••
••
••
••
MIMO54 analogue matrix
MIMO88 digital matrix
SAM series mixers
COMPACT series mixers
Recommended amplification
••
••
••
••
MPA multichannel series
HZA multichannel 100V line series
NZA multichannel networkable series
AMPACK multichannel series
7
MIMO54
MIMO88
WPm SERIES
Accessories
••
••
••
Inputs
Sensitivity nom(*)Impedance
Outputs
Level/Minimum load
Remote
Frequency response
Harmonic distortion
CMRR
Signal/Noise ratio
Tone control
8
MIC BAL
LINE (1-2-5)
LINE (3-4)
OUTPUT BAL
HEADPHONES
LINE
MIC BAL
LINE
MIC BAL
MIC
LINE
MIC BAL
BASS
TREBLE
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
4 stereo program inputs (two allow MIC/LINE signals, the other two only LINE signals)
4 mono zone outputs with two-band tone controls for each output (accessible on the front panel using a screwdriver)
Selectable Phantom power for the MIC inputs
Fifth input signal (MIC/LINE) with priority (dual operating mode: PRIORITY/EVACUATION)
PAGER connector for the MPAGE4 desktop paging station
Source selection and independent output volume control (per zone)
Remote control panels connectivity for source selection and zone volume adjustments
Selection of local or remote zone control mode (from the front panel or from the remote control panels)
Headphone monitoring section
Euroblock connectors in inputs and outputs (input no. 1 also includes an XLR connector for the MIC/LINE L signal)
Front panel controls can be replaced with security caps (included) to prevent undesired manipulation
•• Multi-channel MPA series
•• Ampack series
•• HZA multichannel 100V line series
MPAGE4
MIMO54
MIMO54
-50(-20)dBV/›2kΩ
-10dBV/2kΩ
-10dBV/50kΩ
0(+6)dBV*/600Ω1(2)V
200mW/200Ω THD 1%
Analog control
5Hz-40kHz -3dB
5Hz-37kHz -3dB
‹0.08%
‹0.1%
›70dB@1kHz
›110dB
›100dB
100Hz±15dB
10Hz±15dB
Key features
Recommended amplification
MPAGE4 four-zone desktop paging station
MPAGE1 single-zone desktop paging station
WPmVOL, WPmVOL-SR and the rest of wall panel remote controls in the WPm series (visit the WPm product page for more information)
Technical Characteristics
MIMO54 is an audio matrix with 5 input sources and 4 zone outputs specially designed for
multi-zone sound applications involving source selection and independent volume adjustments. It also includes priority signal and message management for generic and/or
evacuation announcements.
Now, the recently upgraded MIMO54 also allows for real-time paging applications, in
combination with the optional MPAGE4 desktop paging station.
MIMO88 is an 8 in / 8 out digital audio matrix, fully programmable and linkable to a
second unit to become a 16x16 matrix, with real routing from any input to any output.
It can be configured and managed via Ethernet with the included EclerNet Manager
software, also offering many other external control options: networked webserverwebclients control system (a graphical, custom-made screen for each user, run from
computers, tablets, smartphones, etc.), TP-NET third-party control protocol for the
integration with external control hardware like Crestron®, AMX®, RTI®, etc., digital
WPTOUCH wall panels, digital MPAGE16 paging station, 8 GPIO ports, etc. using the
MIMO88 Ethernet or RS-232 ports.
Talkover
TIME
EFFECT
Phantom Voltage
Mains
Power consumption
Dimensions
Weight
(*) Internally selectable
PANEL
DEPTH
1 / 2 / 3 seg*
-20/-30/-80dB*
+18VDC
90-264VCA 47-63Hz
29VA
482.6x44mm
195mm
2.7kg
Applications
••
••
••
••
••
Multi-zone/multi-source management of public address systems with
announcements and/or evacuation notices
Sound in multi-use areas
Sound with choice of source and remote
and independent volume control (by zone)
Corporate facilities
Industrial facilities
8x8 digital audio matrix
Product
MIMO88, MPAGE16, WPTOUCH
5x4 analog audio matrix
8 MIC/LINE balanced inputs, with phantom power selection and mono or stereo
management
8 balanced outputs with mono or stereo management
2 additional monitoring outputs
Expandable to 16 inputs / 16 outputs to become a real 16 x 16 matrix (using the digital audio bus between MIMO88 units, a CAT5 connection which can handle 100 meter distances)
Ethernet and RS-232 comm ports
8 GPI ports (General Purpose Inputs): 0-10 VDC control inputs assignable to MIMO functions, like volume control, MUTE, preset recall, etc.
8GPO ports (General Purpose Outputs): relay contacts to remote control external devices, like motors, lights, etc.
Digital control bus for the WPTOUCH (digital touch-sensitive) wall panel and the MPAGE16 (digital & touch sensitive paging station)
Fully programmable and controllable via EclerNet software (with a straight PC-
MIMO88 cable connection or by means of an Ethernet network)
Ethernet remote control, based on webserver multiple clients: the EclerNet Manager projects can include several control panels, which have been customised for the needs of each user. The panels can be recalled and operated from client devices such as computers, tablets, smartphones, etc. (an Internet browser is used as the client app.)
•• A few processing bits: signal generator, delays, full parametric EQ filters at inputs and
outputs, inputs noise gate, level, mute, phase, vu-meters, outputs compressor / limi-
ter, ducking (priority & overriding), virtual and physical paging stations management, automatic mixer function, presets save & recovery, scheduled events triggering
Applications
••
••
••
••
••
••
••
Centralized, distributed or hybrid fixed installation
BGM & Paging solutions, with message priorities and source/volume independent selection
Integration in installation global control systems
Conferencing (automatic mixing)
P.A. management (multi-way speaker processing, delay adjustment, etc.)
Installations requiring remote supervision, diagnostic and adjustment via Internet
Live sound (WiFi management is possible from a PC, tablet, smartphone, etc.)
Accessories
••
••
••
••
WPTOUCH touch-sensitive digital wall panel control
MPAGE16 touch-sensitive digital paging station
WPm-series wall panel controls
Webserver client devices: computers, smartphones, tablets, etc. using their web browsers to recall customised UCP (User Control Panels)
contained in the EclerNet Manager project
Recommended amplification
••
••
••
••
MPA multichannel series
HZA multichannel 100V line series
NZA multichannel networkable series
NPA stereo networkable series
9
8x8 digital audio matrix
MIMO88
AMI series
MIMO88, MPAGE16, WPTOUCH
AMI2-70
AMI2-70TR
self-powered mixers
MPAGE16
Both models are equipped with integrated class D amplifiers that deliver an output of
70W RMS + 70W RMS.
Key features
••
••
••
••
••
Product
The self-powered mixer models AMI2-70 and AMI2-70TR (for 100/70V power lines)
offer a simple single-unit solution that solves professional installs targeted at end user
who are not necessarily audio experts.
MPAGE16 is a digital paging station for the MIMO88. It features 21 touch-sensitive keys that,
together with the MIMO88 hardware, allow for an easy, flexible and user-friendly configuration
of a paging system that can coexist with other MIMO88 functions and with other control hardware and/or software control systems.
(for more information visit the MPAGE series product page)
Key features
16 zone selection keys
SELECT ALL, CLEAR and PAGE keys
Two user-defined functions keys (for recalling presets, for example)
Gooseneck integrated microphone
Several MPAGE16 or software (virtual) paging stations can work simultaneously (priorities and zones availability is managed by the MIMO88 software setup)
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
WPTOUCH
WPTOUCH digital wall panel control for zone source selection, preset recall, volume and
MUTE control, etc. (see WPm series for more details about this and other available wall panel
accessories)
Mixers with 2 MIC/stereo LINE auto-amplified input channels
(MIC/LINE) input signal detector located in the back panel
Dedicated MIC input sensitivity adjustment
Dedicated, fully adjustable channel 1 with TALKOVER
Direct MIX input allowing connection of additional mixers
Channel 2 is equipped with a stereo minijack connector for direct connection to audio
sources such as the iPOD®
Triple tone control (only accessible with a screwdriver)
Amplified stereo output. Class D amplifier. 70W RMS + 70 W RMS at 4 ohms
Bridge operation
3-LED output level indication. CLIP indicator
1 additional REC stereo output
Mono selector
General pre-fader MIC monitor (headphones)
Remote volume control via VCA (EUROBLOCK)
Remote MUTE
MPAGE1
Technical Characteristics
DSP
Converters
Analog
DSP
Sampling rate
Latency IN to OUT
Resolution
Dynamic Range
8+8 Input/Output
2 monitor output
Headphones related
Analog input headroom
Max. output level
Input sensitivity @ 0dBV out
Input impedance
Phantom power
Headphones
Frequency response (-3dB)
MIMO88
2X 32/64 bit
48kHz
‹2.9ms (+1ms for 16 x 16)
24 bit AKM
AD:110dB, DA: 115dB
Terminal block (Symmetrical)
Terminal block (Symmetrical)
Jack ¼
+27dBV = +30dBu
+18dBV = +21dBu
From -50dBV to +10dBV in 0.5dB step
Balanced, ›4kΩ
+42VCD, 5mA max. software switched
›200mW/200Ω
5Hz to 24 kHz
Applications
MIMO88
Analog
Flatness
THD+Noise @ 1kHz, 0BV input (line)
THD+Noise @ 1kHz, -40dBV input (mic)
Output Noise floor FFT (20Hz - 20kHz)
Interchannel crosstalk (20Hz - 20kHz)
Channel leakage (20Hz - 20kHz)
CMRR 20Hz - 20kHz
Mechanical
Dimensions
Weight
Supply
Mains
Power consumption
Better than ±0.1dB
‹0.004%
‹0.008%
Better than 115dB
Better than 90dB (100dB typ.)
Better than 100dB (115dB typ.)
65dB typ.
482.6x44x266.5 mm
3.5 kg
90-264VCA 47-63Hz
75VA
Technical Characteristics
WPTOUCH
Inputs
Sensitivity nom(*)Impedance
MPAGE16
LINE
MIC (BAL)
MIX
Input sensitivity adjust
CMRR
MIC ADJ
Outputs
Level/Minimum load
REC
MICRO (BAL)
HEADPHONES
BASS
Tone control
MID
TREBLE
Signal/Noise ratio
Talkover
Phantom Voltage
LINE
MIC (BAL)
TIME
EFFECT
AMI2-70
AMI2-70TR
0dBV/47kΩ
-35dBV/›1kΩ
0dB/2kΩ
±15dB
›65dB@1kHz
0dBV/10kΩ 1V*
0dBV/2.2kΩ 1V*
10Hz÷30kHz-1dB
10Hz÷25kHz-1dB
RIAA±0.5dB
›100dB
›85dB
2 (1, 3) Seg*
-30 (-20, -70)dB
+15VDC/4mA max.
AMI2-70
1 Channel @ 4Ω
1 Channel @ 8Ω
All Channels @ 4Ω
Power 1kHz 1% THD
All Channels @ 8Ω
Bridget @ 8Ω
100V Line
70V Line
Frequency response
THD+Noise @ 1kHz Full Pwr.
S+N/N 20Hz -20kHz @ 1W/4Ω
Damping factor 1kHz @ 8Ω
Channel crosstalk @ 1kHz
Mains
Power consumption (max. Out)
Dimensions
Weight
AMI2-70TR
70W
38W
50W
38W
96W
›60W
›60W
15Hz-30kHz (-1dB)
45Hz-25kHz (-3dB)
‹0.07%
‹0.1%
›92dB
›92dB
›140
›50dB
›50dB
90-264 VAC 47-63Hz
230VA
482.6 x 266.5 x 44mm
3.5kg
6.5kg
Accessories
••
••
••
••
••
••
••
Gyms
Restaurants
Leisure centres
Shops
Meeting rooms
Educational centres
A/V presentations
•• MPAGE1, desktop paging station (for more information visit the MPAGE series product page)
•• WPm series wall panel controls
(*) Internally selectable
10
11
11
HMA180
PKUB
self-powered mixers
self-powered desktop mixer
HMA180 is a self-powered installation Public Address mixer. It features a total of 9 audio inputs and a high
/ low impedance amplified output, together with an extensive set of control connections and features to be
the perfect single-box solution in most projects involving background music, microphone signals, paging,
pre-recorded messages and evacuation alarms.
Key features (PRELIMINARY)
• 4 MIC balanced inputs, with bus phantom power (selectable)
• 4 LINE inputs
• Independent 3 band EQ for the MIC inputs mix bus
• Independent 3 band EQ for the LINE inputs bus
• Pager & chime function, MIC1 input (voice level or contact closure activation)
• Additional EMERGENCY MIC/LINE input with independent features:
- Selectable phantom power
- 3 band EQ
- Activation mode: VOICE / CONTACT
- Independent output volume level (ignores the MASTER volume adjusted for the rest of the audio signals mix, assuring a pre-defined level for the emergency messages all over the installation)
- Linkable to the included 24 VDC control output (to activate the priority relays in volume control wall panels)
• Remote Volume control port (0 – 10 VDC)
• Remote MUTE control port (to allow an external device MUTE the P.A. system completely)
• 24 VDC control output, linkable to the PAGER and/or EMERGENCY functions (to activate the priority relays
in remote volume controls)
• Subsonic filter (@ 70 Hz)
• Insertion point in TRS format
• 8Ω , 70 V, 100 V powered output
• LINE level AUX output (allows for an external amplifier connection, like the HSA300 or HZA-F amps, in case that higher power is required)
• Class D 180 W amplifier, convection cooled (100% silent)
• Internal & universal Power Supply
Accessories
Recommended loudspeaker selection
• WPm series wall panel controls
• WPTOUCH touch-sensitive digital wall panel control
• MPAGE1 desktop paging station
• IC in-ceiling series
• ICPLUS in-ceiling series
• ECL in-ceiling series
• AC acoustic column series
• AUDEO series
• AMBIT series
pKUB is a desktop professional two-channel amplified mixer. It includes a powerful class D stereo amplifier and a universal switching power supply.
pKUB is a compact professional solution for sound installations where the end users do not necessarily
have skills in the use of audio equipment. It is easy to start up and use, similar to home audio equipment.
When running, it is totally silent, and its special format and look make it perfect for visible locations where
classic professional equipment, designed for rack mount, would not be suitable.
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Two-channel mixer with two input channels, one MICRO/LINE and the other one just LINE
Built-in 2 x 50 WRMS at 4Ω class D stereo amplifier
Direct mini-jack line input on the front panel, AUX IN (channel 2), ideal for connecting an iPod®, MP3 player, multimedia player, etc. Channel 2 also has a duplicate stereo RCA connection on the back panel
A-type USB Power plug connector for charging the batteries of your iPod®, MP3 player, multimedia player, etc.
Includes a talkover assigned to input 1 with internal release and efficiency time switches
Microphone sensitivity level can be adjusted using a trimmer on the back panel
Phantom power (+18 V DC), internally switchable, for MIC input (channel 1)
Level control for each input channel
Independent three-band tone controls for each channel on the back panel, accessible with a screwdriver
Rotary output level control and push-for-MUTE function
Remote output volume and mute control with included infrared remote control
Auxiliary line output for subwoofer reinforcement system or other audio equipment send
MIX IN input, direct to the mixing bus to connect the unit with external equipment, such as another PKUB unit or a SAM mixer
General remote MUTE control by external contact closure, which is ideal for connecting fire detection systems and/or other safety devices. Internally programmable “NO / NC” (normally open, normally closed)
Output switch for MONO (SUB)/STEREO modes on the back panel
Technical Characteristics
LINE 1
Inputs
Sensitivity nom(*)Impedance
• BGM, Public Address & Paging solutions,
with up to 9 audio inputs, message priorities
and volume / EQ independent management
Input sensitivity adjust
CMRR
Outputs Level / Minimum load
LINE 2
IPod®
MIC ADJ
MICRO (BAL)
SUB AUX
BASS
Tone control
MID
TREBLE
Signal/Noise ratio
Talkover
Phantom Voltage
12
MIC (BAL)
MIX
Applications
Product
Y
R
A
N
I
M
I
L
PRE
LINE
MIC (BAL)
TIME
EFFECT
PKUB250
0dBV/47kΩ
-35dBV/600Ω
0dB/4.7kΩ
-10dBV/›300Ω
0dBV/2kΩ
±15dB
›65dB @ 1kHz
0dBV/10kΩ
100Hz±15dB
1.8kHz±15dB
10kHz±15dB
-80dB
-75dB
2 (1, 3) Seg*
-30dB
+15VDC/4mA max.
MPAGE1
PKUB250
1 Channel @ 4Ω
1 Channel @ 8Ω
Power 1kHz 1% THD
2 Channels @ 4Ω
2 Channels @ 8Ω
Bridget @ 8Ω
Frequency response
THD+Noise @ 1kHz Full Pwr.
S+N/N 20Hz -20kHz @ 1W/4Ω
Damping factor 1kHz @ 8Ω
Channel crosstalk @ 1kHz
Mains
Power consumption
(max. Out)
Dimensions WxDxH
Weight
(*) Internally selectable
(pink noise, 1/8 power @ 4Ω)
(pink noise, 1/3 power @ 4Ω)
52W
31W
33W
27W
68W
20Hz-25kHz (-1dB)
‹0.07%
›92dB
›140
›50dB
90-264 VAC 47-63Hz
52VA
81VA
132.5 x 155 x 142.5mm
1.5kg
Accessories
••
MPAGE1, desktop paging station (for more informa
tion visit the MPAGE series product page)
Applications
••
••
••
••
••
••
••
••
Shopping centres
Restaurants and bars
Health, beauty and leisure centres
Audiovisual presentations
Meeting rooms
Educational centers
Corporate facilities
Residential facilities
13
AMPACK series
HSA300
AMPACK2-70, AMPACK4-70,
DLAPACK
amplifiers
With the AMPACK2-70 / 4-70 line of compact amplifiers, installers can
enjoy the pro-audio market’s lightest, most robust and most reliable
amplification technology in a silent and compact format, ideal for use in
virtually every kind of application and environment. The delivered power
is 2 x 70 or 4 x 70 W RMS in low impedance (4Ω). For 100 V line applications, you will need the DLAPACK2-70 dual converter, which transforms
two 70 W channels at 4Ω into two 70 W channels at 100 V line level.
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Technical Characteristics
AMPACK2-70
AMPACK4-70
DLAPACK2-70
POWER 20-20kHz 1%THD
1 Channel @ 4Ω
1 Channel @ 8Ω
2-4 Channels @ 4Ω
2-4 Channels @ 8Ω
1-2 Bridged @ 8Ω
Power rating
Frequency response (-3dB)
High pass filter 3rd order Butterworth
THD+Noise @ 1kHz Full Pwr.
Intermodulation distortion 50Hz & 7kHz, 4:1
TIM 100
S+N/N 20Hz-20kHz @ 1W/4Ω
Damping factor 1kHz @ 8Ω
Channel crosstalk @ 1kHz
Input sensitivity /Impedance
14
68 WRMS
35 WRMS
64 WRMS
35 WRMS
135 WRMS
68 WRMS
35 WRMS
57 WRMS
34 WRMS
130 WRMS
10Hz - 40kHz
100Hz
‹0.08%
‹0.1%
‹0.06%
›80dB
›140
›50dB
0dBV/›20kΩ
10Hz - 40kHz
100Hz
‹0.1%
‹0.3%
‹0.15%
›80dB
›140
›50dB
0dBV/›20kΩ
80W RMS MAX
45Hz÷25kHz
Auto power threshold
Auto power time
Mains Voltage
Output voltages
Power consumption
(pink noise, 1/8 power @ 4Ω)
(pink noise, 1/3 power @ 4Ω)
Power dissipation (standby)
Dimensions
Weight
Class D amplifier with an output of 2 x 70 W RMS
(AMPACK2-70) or 4 x 70 W RMS (AMPACK4-70) at 4Ω
Ultra light format in the AMPACK2-70 (1.6 kg) and the AMPACK4-70 (1.75 kg)
Silent, high-efficiency amplifier (ventilation by convection, no fan)
Built-in power supply, switching type
AUTO STANDBY: when no signal is detected, it automatically goes into standby mode, saving energy
Can operate in stereo, parallel and bridge modes
Independent remote VCA volume control (for each input channel).
See WPm wall panel accessories: rotary wall controls and infrared remote control can be connected to the VCA port
EUROBLOCK input, output and VCA remote control connectors
Additional RCA stereo input connector (AMPACK2-70)
L+R mono switch (only in AMPACK2-70)
Independent gain adjustment for each input channel, protected against accidental manipulation
Built-in 100 Hz high-pass filter
Can be installed directly on a 35 mm DIN rail
AMPACK2-70
AMPACK4-70
›-35dB aprox.
2 min. aprox.
230V AC
›-35dB aprox.
2 min. aprox.
230V AC
DLAPACK2-70
•• WPm series wall panel controls
70/100V
96VA
170VA
‹9W
234x158.5x75mm
1.6kg
135VA
250VA
‹9W
234x158.5x75mm
1.75kg
Accessories
230x151.5x75mm
3.9kg
Applications
•• A/V corporate rooms
•• Retail shops
•• Residential applications
The HSA300 is a single channel amplifier with direct 100 V line (high impedance)
output. It’s equipped with Ecler’s proprietary SPM 100 Technology - Channel N,
which allows for 100 V speaker lines connection without using 100 V line transformers, as this kind of amplifiers usually do. This fact has many advantages,
being the main one the excellent audio quality, specially improved in the low-end
frequencies when compared to classical 100V line amplifiers.
Product
compact amplifiers
Key features
•• 1 mono balanced input
•• 1 x 260 W output (100V line level)
•• Euroblock connectors
•• SPM 100 amplification Technology - Channel N
(no 100 V output transformers used):
-Improved frequency response (specially at the low-end)
- Great efficiency
-Low weight
•• Butterworth, 3rd order high pass filter @ 70Hz
•• Thermal protection
•• Overload protection
•• Anti-clip system
Technical Characteristics
Power output @ 100VRMS
Full power
Frequency response (-3dB)
High pass filter 3rd order Butterworth
THD + Noise @ 1kHz Full power
Signal Noise Ratio @ 100V
Inputs:
Sensitivity nom/Impedance
Connector
Outputs:
Connector
Indicators:
Power
Signal present
Clip
Overload
Thermal
HSA 300
254 WRMS@32Ω@1% THD
302 WRMS@32Ω@10% THD
482VA
30Hz - 35kHz
70hz
‹0.07%
›85dB
0dBV/›20kΩ
Terminal block (symmetrical)
Applications
Suggested 100V line Speakers:
•• Single or multi-zone BGM and paging systems with 100V line speakers, combined with
the MIMO54 and MIMO88 matrixes and SAM
series preamplifiers
••
••
••
••
Mains voltage
Power consumption
pink noise, 1/8 power @ 32Ω
pink noise, 1/3 power @ 32Ω
Dimensions
Panel
Depth (handle excluded)
Weight
AUDEO series
IC / IW / ICPLUS series
AMBIT series
ECL106 series
HSA 300
Depending on your country. See characteristics in the
back of the unit
218VA
319VA
482.6x88mm
285mm
8.4kg
Terminal block
-35dB
15
MPA-R series
HZA4-70F,
HZA4-120F
MPA4-80R, MPA6-80R, MPA4-150R, MPA6-150R,
MPA4-400R
The HZA4-70F and HZA4-120F are four MERGING channel amplifiers with direct 100 V line (high
impedance) outputs. They integrate Ecler’s proprietary SPM 100 Technology - Channel N, which allows
for 100 V speaker lines connection without using 100 V line transformers at their amplified outputs, as
this kind of amplifiers usually do. This fact has many advantages, being the main ones the audio quality
improvement (specially in the low-end frequencies) and the convection cooling, 100% silent.
Key features
•• 4 mono balanced inputs
•• 4 x 70 W or 4 x 120 W amplified outputs (100V line level)
•• 4 volume remote control ports (0 - 10 VDC)
•• Euroblock connectors
•• SPM 100 amplification Technology - Channel N (no 100 V output transformers used):
- Improved frequency response (specially at the low-end)
- Convection cooling (100% silent and increased reliability)
- Great efficiency
- Low weight
•• Auto stand-by function after 2 minutes without audio input signals, with instantaneous auto-recovery
•• Thermal protection
•• Overload protection
•• Anti-clip system
•• Every 2 adjacent channels can be merged, getting one out of these possible configurations in the
case of the HZA4-70F:
−−4 x 70W @ 100 V line outputs
−−2 x 70W + 1 x 140 W @ 100 V line outputs
−−2 x 140W @ 100 V line outputs
−−1 x 70W + 1 x 210 W @ 100 V line outputs
−−1 x 280W @ 100 V line output
•• And these ones in the case of the HZA4-120F:
−−4 x 120W @ 100 V line outputs
−−2 x 120W + 1 x 240 W @ 100 V line outputs
−−2 x 240W @ 100 V line outputs
−−1 x 120W + 1 x 360 W @ 100 V line outputs
−−1 x 480W @ 100 V line output
Applications
•• Multi-zone BGM and paging systems with 100V line speakers, combined with the MIMO54 and MIMO88 matrixes and SAM series preamplifiers
Technical Characteristics
1 Channel
Output power:
2 Merged Channels
3 Merged Channels
4 Merged Channels
Frequency response (-3dB)
High Pass filter 3rd order Butterworth
THD + Noise @ 1 kHz Full power
Signal Noise Ratio @ 100V
Channel Crosstalk @ 1kHz/100V
Inputs:
Outputs:
Sensitivity nom/Impedance
Connectors
Connectors
Power
Signal present
Indicators:
HZA4-120F
1%THD
114WRMS@88Ω
195WRMS@50Ω
290WRMS@32Ω
356WRMS@26Ω
HZA4-70F
10% THD
145WRMS@88Ω
226WRMS@50Ω
348WRMS@32Ω
430WRMS@26Ω
30Hz - 55kHz
70Hz
‹0.03%typ. 0.2% max.
›90dB
›90dB
0dBV/›20kΩ
Terminal Block (Symmetrical)
Terminal Block
Green (ON), Red (Standby)
-35dB
HZA4-120F
DC
TBA
TBA
TBA
TBA
Remote control:
No attenuation
Full attenuation
Connectors
Auto Power:
Mains Voltage:
Threshold
Time
Depending on your country
See characteristics in the back of the unit
pink noise, 1/8 power @ 136©
Power consumption: pink noise 1/3 power @ 136©
Standby
Dimensions:
Weight:
Panel
Depth (Handle excluded)
HZA4-70F
0-10V/0.1A max
0V
+10V
Terminal block
›-30dB aprox
100 sec. aprox
Depending on your country. See
characteristics in the back of the unit
340VA
TBA
470VA
TBA
‹3W
TBA
482.6x88mm
392mm
13.60kg
TBA
amplifiers
Line of multi-zone power amplifiers for high end installations
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Product
FLEXI-POWER AMPLIFIER SERIES
HZA-F SERIES
2 RU high, 19” installation multi-channel amplifier series
Extended linear power supply
ECLER SPM patented technology (MPA4-150R, MPA6-150R, MPA4-400R)
Individual input sensitivity controls with sealing possibility to avoid unwanted manipulation
Signal presence (SP) and CLIP indicators for each channel
Balanced inputs (XLR) , EUROBLOCK output connectors
Stack outputs (JACK) on all models
Input channels link switch for superior versatility
Independent VCA (EUROBLOCK) volume remote control port for each input channel, ready for external 0-10 V signals, WPmVOL or WPmVOL-IR wall panel controls
Noiseless convection cooling (MPA4-80R and MPA6-80R)
Dual Slope Controlled Fan system (MPA4-150R, MPA6-150R and MPA4-400R)
Totally protected against shorting, DC at the outputs and overheating
Integrated internal 3rd order Butterworth HI-pass and LO-pass x-over (MPA4-150R, MPA6-150R, MPA4-400R) for bi-amped applications
2 RU high
Three year warranty
WPmVOL
Suggested 100V line speakers:
••
••
••
••
••
AUDEO series
IC / IW / ICPLUS series
AMBIT SERIES
ECL106 series
ICPLUS series (100V version)
Suggested remote control
accessories:
•• WPm series wall panels
Applications
Accessories
•• DLA600: dual channel 100V adaptor for MPA4-150R, MPA6-150R and MPA4-400R
•• DLA4-80, DLA6-80: 4/6 channel 100V adaptor for MPA4-80R and MPA6-80R
•• WPm series wall panel controls
The reliable multi-channel solution for all applications
requiring multi-zone audio distribution
•• Public Address
•• Theme parks
•• Clubs
•• Theme restaurants
•• Multi-purpose halls
•• Boardrooms and conference halls
•• Franchise retail shops
Clip
Overload
Thermal
Merge
16
17
amplifiers
MPA-R series
LPA SERIES
MPA4-80R, MPA6-80R,
MPA4-150R, MPA6-150R, MPA4-400R
LPA6000, LPA10000,
LPA16000
amPLIFIErs
The new LPA series brings all the classic, well-known reliability and amplification quality of Ecler
to a new light-weight format that is versatile and affordable.
Product
When activated, the built-in crossover allows you to send the low frequency band to channel 1 and
the high frequency band to channel 2 (cut-off point at 150 Hz) internally, making it simple and cost
effective to create two-channel configurations without any external processing.
Key features
••
••
••
••
••
••
••
••
••
••
MPA-R 6-80 conex
MPA-R power fast guide
1 channel @4Ω
POWER 20-20kHz 1% THD
Technical Characteristics
1 Channel @ 4Ω WRMS
POWER
20Hz-20kHz
1%THD
1 Channel @ 8Ω WRMS
All Channels @ 4Ω WRMS
All Channels @ 8Ω WRMS
1 Bridged Channel @ 8Ω
MPA4-80R MPA6-80R MPA4-150R MPA6-150R MPA4-400R
80 WRMS
50 WRMS
55 WRMS
40 WRMS
117 WRMS
All Bridged Channels @ 8Ω
Frequency response (-1dB)
Filter (Hi-lo) 3rd order Butterworth
-
THD+Noise*@1kHz Full Pwr.
Intermodulation distortion* 50Hz
& 7kHz, 4:1
TIM 100 *
S+N/N 20Hz-20kHz*@1W/4Ω
CMRR*
18
85 WRMS
52 WRMS
58 WRMS
48 WRMS
123 WRMS
20Hz - 30Hz
‹0.02%
160 WRMS
170 WRMS
100 WRMS
110 WRMS
120 WRMS
130 WRMS
83 WRMS
90 WMRS
300 WRMS
330 WMRS
250 WRMS
270 WRMS
7Hz - 30kHz
160Hz
‹0.05%
‹0.02%
‹0.06%
‹0.05%
‹0.04%
-
-
›55dB
7Hz - 50kHz
MPA4-150R MPA6-150R MPA4-400R
85WRMS
52WRMS
160WRMS
100WRMS
170WRMS
110 WRMS
410 WRMS
230 WRMS
117WRMS
123WRMS
300WRMS
330 WRMS
610 WRMS
›160
±10V/µs
›60dB
Channel crosstalk @ 1kHz*
Input Sensitivity / Impedance
-
Anticlip
Power consumption (max. Out)
524VA
Dimensions (mm)
* VCA OFF
‹0.03%
›85dB
-
MPA6-80R
MPA4-80R MPA6-80R MPA4-150R MPA6-150R MPA4-400R
Damping factor 1kHz @ 8Ω
Slew Rate
Weight
‹0.08%
‹0.06%
›90dB
410 WRMS
230 WRMS
305 WRMS
200 WRMS
610 WRMS
1 channel @8Ω
1 Bridged channel @8Ω
(all channels driven)
MPA4-80R
80WRMS
50WRMS
9,5kg.
800VA
482.6x88x391
11.2kg.
›300
±18V/µs
±50V/µs
›55dB
305 WRMS
0dBV/›20kΩ
2% THD
1 & 5% THD
1095VA
1590VA
2500VA
482.6x88x426
12.6kg.
15,25kg.
20.5kg.
Ultra light technology (5.6, 6.8 and 9.2 kg: LPA6000, 10000 and 16000)
Built-in crossover filter
Efficient progressive ventilation system with a flow that adapts to the internal temperature of the amplifier. The air comes in from the back and is pushed out to the front
Rotary input attenuation controls that are easily accessible on the front panel
LED indicators: power-on and standby (POWER ON, STD BY), signal presence (SIGNAL), clipping (CLIP), operating mode (STEREO, BRIDGE), crossover activated (XOVER) and protections activated (PROTECT)
Efficient short-circuit, overheat and DC signal protection system to prevent damage to the amplifier and/or the loudspeakers connected to it
Permanently activated built-in anti-clip circuit
Operating mode selector: STEREO, PARALLEL and BRIDGE
Balanced inputs via XLR3 connectors and 6.35 mm stereo jack. Unbalanced inputs via RCA connectors.
Amplified outputs with terminal-type connectors and Speakon® connectors
LPA power fast guide
POWER 20-20kHz 1% THD
(Both channels driven)
4Ω Stereo
8Ω Stereo
8Ω Bridged
Technical Characteristics
4Ω Stereo
POWER 20-20kHz 1% THD
8Ω Stereo
8Ω Bridged
Frequency response (-1dB/-3dB)
Crossover filter (-3dB) (CH1=LOW, CH2=HIGH)
THD+Noise @ 1kHz Full Pwr.
S+N/N 20Hz-20kHz @ 1W/4Ω
Damping Factor 1kHz @ 8©
Slew Rate
Input connectors
Input Sensitivity / Impedance
Signal present indicator
Output connectors
Mains
Power
(pink noise, 1/8 power @ 4ohm)
consumption (pink noise, 1/3 power @ 4ohm)
Dimensions (mm)
Weight
LPA6000
LPA10000
LPA16000
320WRMS
210WRMS
640WRMS
500WRMS
330 WRMS
1000 WRMS
760 WRMS
450 WRMS
1520 WRMS
LPA6000
LPA10000
LPA16000
320WRMS
210WRMS
640WRMS
10Hz/58kHz
500WRMS
330 WRMS
1000 WRMS
10Hz/58kHz
760 WRMS
450 WRMS
1520 WRMS
10Hz/52kHZ
150Hz/18dB oct.
‹0.1%
‹0.05%
‹0.1%
›85dB
›270
±37V/µs
±43V/µs
±30V/µs
XLR3 & 1/4” Jack balanced & RCA
26/32dB/20k© Bal. 10kΩ Unbal
-40dB
Speakon & Binding Posts
230V 50/60Hz
670VA
1040VA
600VA
1000VA
1580VA
1840VA
482.6x304x88
482.6x360x88
482.6x360x88
5.62kg
6.85kg
9.2kg
Applications
•• Touring (small live)
•• Mobile applications
•• Permanent installation
19
DPA series
XPA series
XPA3000, XPA5000,
XPA7000, XPA11000
amplifiers
Line of stereo power amplifiers including SPM proprietary technology and optional
in-bay AMIC DSP module, very suitable for the high end installation
DPA600, DPA1000,DPA1400,
DPA2000, DPA 4000T
amplifiers
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Key Features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Class G and H - 3 steps (XPA11000) amplifying technology
Extended power supply
Work modes: stereo (down to 2Ω loads) , parallel, bridged
Balanced inputs (XLR), balanced stack outputs (JACK)
Outputs on connection posts and Speakon® connectors
Intelligent ANTICLIP system: always on. Limits Harmonic Distortion by monitoring the transient behaviour of the input signal
SIGNAL PRESENT front panel indicator (-40dBV)
CLIP indicator
PROTECT indicator when DC, low freq signals, short circuit or overheating situations
On board 30Hz or off SUBSONIC filter
Input sensitivity selector (0.775V, 1V, 1.4V)
Smart back to front COOLING system
Tamper proof plastic caps
2 RU High
2 year warranty
XPA-power fast guide
POWER 20-20kHz 1% THD
(Both channels driven)
4Ω Stereo
8Ω Stereo
8Ω Bridget
XPA3000
XPA5000
XPA7000
XPA11000
295WRMS
198WRMS
590WRMS
498WRMS
314WRMS
996WRMS
718WRMS
450WRMS
1436WRMS
1180WRMS
745 WRMS
2360 WRMS
ECLER patented SPM amplifying technology
All the power all the time: permanent sound quality, no matter how long the unit is working (DPA4000T)
Drive down to 2Ω loads
A2SP Analog Autogain Signal Processor: input signal management in stress work conditions (DPA4000T)
Balanced inputs (XLR), balanced stack outputs (JACK , except the 4000T, XLR), Speakon® output connectors
Intelligent ANTICLIP system: always on. Limits Harmonic Distortion by monitoring the transient
behaviour of the input signal
Independent channel THERMAL protection with the front panel indicator
PROTECT indicator when DC, when detected DC / LF input signals, or short-circuit loads
SIGNAL PRESENT front panel indicator (-40dBV)
CLIP indicator active for output signals 1.5dB below real clipping
On-board 25 Hz switchable SUBSONIC filter
Crowbar (relay-free) DC protection circuit
Smart back-to-front cooling system
AMIC DSP card compatible
Tamper-proof front knobs plastic caps
2 RU high (3 RU for the DPA4000T)
Three year warranty
DPA and DPA-T Accessories
DPA and DPA-T SERIES Applications
•• AMIC DSP card for extensive and comprehensive signal processing. PC remote controlled by AMICLAB friendly setup software. Turns DPA and DPA-T amplifier into a complete audio solution
•• DLA600 dual 100V adaptor for DPA600
••
••
••
••
••
••
••
••
••
Applications
XPA3000 XPA5000 XPA7000 XPA11000
Technical Characteristics
POWER 20Hz-20kHz
1%THD
Both Channels driven
Peak power 2Ω
Frequency response (-1dB/-3dB)
High pass filter (-3dB)
THD+Noise @ 1kHz Full Pwr.
S+N/N 20Hz-20kHz @ 1W/4Ω
Damping factor 1kHz @ 8Ω
Slew Rate
Input connectors
Input Sensitivity / Impedance
20
4Ω Stereo
8Ω Stereo
8Ω Bridged
295 WRMS
198 WRMS
590 WRMS
600 WRMS
498 WRMS
718 WRMS
1180 WRMS
314 WRMS
450 WRMS
745 WRMS
996WRMS
1436 WRMS 2360 WRMS
1050 WRMS 1450 WRMS 2400 WRMS
10Hz/120kHz
10Hz/60kHz
30Hz/18dB oct.
‹0.05%
‹0.05%
‹0.1%
‹0.1%
›90dB
›300
±32V/µs
±40V/µs
±45V/µs
±30V/µs
XLR3 & 1/4” Jack balanced
0.775V. 1V. 1.4V/20KΩ Bal. 10KΩ Unbal.
XPA3000 XPA5000 XPA7000 XPA11000
Signal present indicator
Output connectors
Power consumption (EN 55103-1)
Pink noise, 1/8 power
Pink noise 1/3 power
Max. power (sinus)
Dimensions
Weight
575VA
15kg
-40dB
Speakon & Binding Posts
675VA
775VA
1230VA
482.6x88x452mm.
17kg
19.5kg
23.6kg
Accessories
•• DLA600 dual 100V adaptor for XPA3000
••
••
••
••
••
••
••
••
••
Clubs
Theme restaurants
Discos
Leisure centres
Cinemas and theatre
Educational centres
Boardrooms and conference halls
Sports Centres
Mobile outdoor applications
Product
A line of amplifiers with unbeatable sturdiness, ideal for fix installation and at an affordable price
Technical Characteristics
POWER
2Ω Stereo
20Hz-20kHz
4Ω Stereo
1% THD
8Ω Stereo
(Both channels driven) 8Ω Bridged
Peak Power 2Ω/1kHz
Frequency response (-1dB)
High pass filter (-3dB)
THD + Noise @ 1kHz Full Power
Imd. dist. 50Hz & 7kHz 4:1
TIM 100
S+N/N 20Hz-20kHz@ 1Ω/4Ω
Damping factor 1kHz@8Ω
Slew Rate
Channel Crosstalk @ 1kHz
DPA600
DPA1000
410 WRMS
275 WRMS
180 WRMS
550 WRMS
0.98Kw
7hz-50kHz
682 WRMS
440 WRMS
275 WRMS
882 WRMS
1.5Kw
7Hz-50kHz
‹0.03%
‹0.05%
‹0.01%
›85dB
›300
±60V/µs
›75dB
‹0.03%
‹0.08%
‹0.01%
›85dB
›300
±65V/µs
›75dB
Clubs
Theme restaurants
Discos
Leisure centres
Cinemas and theatre
Educational centres
Boardrooms and conference centres
Sports Centres
Mobile outdoor applications
DPA1400
DPA2000
990 WRMS
1420 WRMS
635 WRMS
940 WRMS
395 WRMS
550 WRMS
1270 WRMS
1880 WRMS
2Kw
2.95 Kw
7Hz-50kHz
6Hz-50kHz
25Hz/Butt/18dB/oct.
‹0.03%
‹0.07%
‹0.08%
‹0.08%
‹0.01%
‹0.01%
›85dB
›85dB
›300
›300
±75V/µs
±80V/µs
›75dB
›75dB
DPA4000T
2800 WRMS
1880 WRMS
1110 WRMS
3760 WRMS
6100 WRMS
6Hz-95kHz
‹0.07%
‹0.08%
‹0.04%
›84dB
›370
±135V/µs
›74dB
Input Connectors
Input CMRR/ref. Max. PWR
Input sensitivity/impedance
Signal present indicator
Output connectors
Clip indicators
Anticlip limiter
Mains
Power consumption (max. Out)
Dimensions
Panel
Depth
Weight
DPA600 DPA1000
830VA
12.7kg
DPA1400
DPA2000
XLR3 Balanced
›60dB@1kHz
0dBV / ›20kΩ
-40dB
Speakon®
-1.5dB real clip
Intelligent A2SP
Depending on your country
1250VA
1720VA
3115VA
482.6 x 88mm
482.6x88mm
420mm
470mm
16.6kg
19.3kg
22.7kg
DPA4000T
›70dB@1kHz
6760VA
482.6x132.5mm
532mm
34.1kg
21
NZA series
NPA4000T
NZA4-70, NZA4-180, NZA4-400,
NZA6-70, NZA6-180, NZA4-700
The EclerNet manager application is the control tool for this amplifier series. With this software application, users can configure each amplifier’s built-in DSP processor (gain, crossovers, parametric EQ with 10 filters, delay, compressor/limiter, etc.) as well as control and
supervise the status of individual amplifiers, amplifier groups, individual amplifier channels
and amplifier channel groups.
Key features
Technical Characteristics
NPA4000T
4Ω Stereo
POWER 20-20kHz 1% THD
8Ω Stereo
8Ω Stereo
8Ω Bridged
Peak Power 2Ω/1kHz
Overall Voltage Gain
Frequency response (-1dB/-3dB)
THD+Noise @ 1kHz Full Pwr.
S+N/N 20Hz-20kHz @ 1W/4Ω
Channel Crosstalk @ 1kHz
Slew Rate
Input connectors
Input CMRR/ref. Max. PWR
Signal present indicator
22
2840WRMS
1910 WRMS
1120 WRMS
3800WRMS
6200WRMS
26/32/38 dB
6Hz/37kHz
‹0.04%
›84dB
›350
›80dB
XLR3 balanced
›60dB@1kHz
-40dB
Output connectors
Anticlip limiter
Mains
Power consumption
(pink noise, 1/8 power @ 4ohm)
(pink noise, 1/3 power @ 4ohm)
Dimensions Panel
Depth
Weight
SPM TECHNOLOGY (Switching Power Mosfet)
Analogue and digital inputs (AES/EBU)
LCD screen and local controls on front panel
Built-in DSP module
Built-in EclerNet remote control module (including control over all DSP functions + super-
vision and control over alarms, protections, temperature, load impedance, output power, AC power supply, amplifier groups and/or channels, output power limiter, system log, etc.)
Cooled with variable-speed fan that adjusts to the internal temperature
Built-in anti-clip system
Soft start
Built-in RJ45 (Ethernet) remote control ports and TP-NET third-party protocol, ready for the integration with control systems like CRESTRON®, AMX®, RTI®, etc.
Speakon® outputs
Height: 3 rack units
NPA4000T
Speakon®
3 level DSP controlled
Depending on your country.
See charact. in the back of the unit
2500VA
3800VA
482.6x132.5mm
532mm
35.8kg
The NZA range includes 6 models, of 4 or 6 channels and different powers. All of them feature convection cooling (fan less), being absolutely silent and suitable for its installation in the most demanding
environments in terms of background noise.
As well as the NPA series, the NZA series can integrate in the increasing range of products compatible
with the EclerNet network, being the EclerNet Manager software application its programming and
remote control tool.
Additionally, the TP-NET third party communication protocol, which is integrated in the NPA, NZA and
MIMO88 devices, enables our NZA multichannel amplifiers to be remotely controlled via Ethernet by
third-party control systems (CRESTRON®, AMX®, RTI®, VITY®, MEDIALON®, etc.).
Applications
NZA series models
••
••
••
••
••
••
••
••
••
••
••
Live sound (WiFi management is possible from a PC)
Centralized, distributed or hybrid fixed installation
Integration in installation global control systems
Big zoned systems of Public Address
Installations requiring remote supervision, diagnostic
and adjustment via Internet
NZA4-70: 4 x 80 W RMS @ 4Ω
NZA4-180: 4 x 190 W RMS @ 4Ω
NZA4-400: 4 x 420 W RMS @ 4Ω
NZA4-700: 4 x 730 W RMS @ 4Ω (4 x 1200 W RMS @ 2Ω)
NZA6-70: 6 x 80 W RMS @ 4Ω
NZA6-180: 6 x 200 W RMS @ 4Ω
Applications
••
••
••
••
••
Live sound (possibility of in-place WiFi management from a laptop)
Fixed installation
Integration in global facility control systems
Large PA systems and zones with high number of speakers (high power direct over a 100 V line without additional transformers)
Facilities requiring supervision, diagnostics and ad-
justments from remote locations (via LAN or Internet)
Technical Characteristics
POWER 20Hz-20kHz 1%THD
1 Channel @ 2Ω
1 Channel @ 4Ω
1 Channel @ 8Ω
All Channels @ 4Ω
All Channels @ 8Ω
1 Bridge Channel @ 8Ω
1 Bridge Channel @ 4Ω
Overall Voltage Gain
Frequency response (-1dB/-3dB)
THD+Noise @ 1kHz Full Pwr.
Output connectors
Noise Floor (FFT) 20Hx - 20 kHz
Damping factor 1kHz @ 8Ω
Channel Crosstalk @ 1 kHz
Input connectors
NZA4-70 NZA6-70
NZA4-180 NZA6-180
NZA4-400
NZA4-700
81 WRMS
49 WRMS
63 WRMS
41 WRMS
152 WRMS
193 WRMS
115 WRMS
160 WRMS
102 WRMS
365 WRMS
426 WRMS
230 WRMS
330 WRMS
205 WRMS
760 WRMS
1220 WRMS
730 WRMS
406 WRMS
530 WRMS
327 WRMS
1180 WRMS
2070 WRMS
80 WRMS
47 WRMS
62 WRMS
40 WRMS
150 WRMS
208 WRMS
120 WRMS
155 WRMS
100 WRMS
380 WRMS
+26 / +32 dB
10Hz - 25kHz
‹0.05%
›150
›140
‹0.08%
Terminal block
›80dB (85dB typ.)
›400
›350
›600
›60dB
Terminal block (Symmetrical)
›200
NZA4-70 NZA6-70
POWER AUDIO
••
••
••
••
••
••
••
••
••
••
••
Product
Range of amplifiers with built-in DSP processing and remote Ethernet management.
A complete digital signal processing module and a remote Ethernet management module are
built into the NPA series amplifiers, allowing them to be controlled and supervised from any PC
on the network where they are installed, or even from a remote location via the Internet.
amplifiers
The new NZA multi-channel amplifier series responds to the present demands regarding remote
management and systems integration. Thanks to its DSP module and its integrated Ethernet interface,
these amplifiers turn into a powerful tool for signal processing, amplification and remote management, allowing the user to create centralized, distributed or hybrid systems, offering more flexible
sound system options to the installer or designer and reducing dramatically the cabling installation
costs.
POWER AUDIO
amplifiers
NPA series
Input CMRR/ref. Max. PWR.
Signal present indicator
Anticlip limiter
Volume remote control
Remote control connectors
Mains
Power consumption:
(pink noise, 1/8 power @ 4ohm)
(pink noise, 1/3 power @ 4ohm)
Stand-by mains consumption
Panel Dimensions
Depth (Handle excluded)
Weight
NZA4-180 NZA6-180
NZA4-400
NZA4-700
›55dB
Lit at -40dBV
Soft / Mid / Hard
(0-10VDC) (0.1A max.) 0V = no attenuation / +10V = full attenuation
Terminal block
Depending on your country. See characteristics in the back of the unit
102VA
198VA
137VA
277VA
8.6kg
9.65kg
214VA
466VA
297VA
652VA
‹3W
482.6x88mm
390mm
11.1kg
12.9kg
431VA
948VA
15kg
729VA
1610VA
440mm
19kg
23
NZA series
AMIC
NZA4-70, NZA4-180, NZA4-400,
NZA6-70, NZA6-180, NZA4-700
amplifiers
processors
NZA 6-180 conex
Product
2x4 internal DSP management card for DPA and DPA-T amplifier series. Fully configurable with AMICLAB PC control software.
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Key features
•• EclerNet software
••
••
••
••
••
••
••
••
••
••
••
••
4/6 analogue inputs routable to any output
4/6 volume remote control ports, each one assignable to one or various channels
Editable channels independently (SINGLE mode) or in pairs (BRIDGE and
PARALLEL modes)
Integrated DSP module
Integrated EclerNet remote control module (includes control of all DSP
functions and supervision and control of alarms, groups of
amplifiers and/or channels, output voltage limiter, system log file, etc.)
Silent cooling through convection, without fan
Integrated anti-clip system
Soft start in 180, 400 and 700 W models
RJ45 (Ethernet) remote control port
Auto-Stand By function
Euroblock type input, output and volume remote control connections
2 units rack height
Output peak voltage limiter:
High & Low pass Crossover filters
24
Threshold
Ratio
Attack time
Release time
Peak voltage
upon model (auto
settings)
24 bit, 48kHz, 105dB Cirrus Codec
32/64 bits
810˚s
+18 dBV = +21 dBu
Stepless from - to +0dB
Balanced, 22k©
1s (343.4m) for each channel
20.8µs (6mm)
from -36dBV to +18dBV
1:1 to :1 (limiter)
Auto or from 0.1ms to 500ms.
Auto or from 1ms to 5s.
Parametric Eq types:
(8 max. per output)
Built in signal generator
Signal Mute
Signal Polarity Invert
Connectivity:
- Bypass / On-Off all channels
- Param. Eq. 20Hz-20kHz; -60/+12dB; Q from -3 to 200
- Low & High Shelf 6/12 dB/oct
- Low & High Pass 6/12 dB/oct.
- All-Pass 1/2 order
- Sine (20Hz to 20 kHz)
- Polarity (10/20Hz to 10/20kHz)
- White
- Pink
- Yes
- Yes
-Ethernet base-Tx 10/100Mb, Auto X-Over, Cat5
SOFTWARE
Analog Input headroom:
Digital Input Attenuator:
Input Impedance
Maximum Delay:
Delay resolution:
Compressor / Limiter:
A/D & D/A
DSP
Latency
DIGITAL
DIGITAL
Technical Characteristics
Processing:
EclerNet Software
From 10Vpk to 70Vpk
Operating System:
Butterworth in 6/12/18/24/oct.
Bessel in 12/18/24dB/oct.
Linkwitz-Riley in 12/24dB/oct.
Minimum EclerNet
System Requirements
Realtime full GUI of all functions and controls thru
Ethernet with interactive graphical display
Grouping mode channels or devices
Automated report generation
Remote power on with programmable delay
Up to 256 devices on same net
Autodiscovery devices feature
Routing capability through NAT gateways
Real time metering at input/output (DSP)
Device “Finder” feature
Save & Recall setup and preset functions
Firmware update capability thru Ethernet
Password protection
Default Network configuration
IP: 192.168.0.100
Mask: 255.255.255.0
Gate: 192.168.0.1
UDP Port: 2210
Windows® W2000 Prof. (SP4); XP Prof. (SP3);Vista (SP1)
Windows 7
Pentium IV ® 1GHz
256MB RAM
40MB HDD free space
800x600 pixels & 16bits colour display
10/100 Ethernet Network Card
24bits / 48kHz sampling rate for superior audio quality
Powerful 48bits DSP architecture allows real time configurations
Four full independent channels management for extra versatility
Input selection and gain controls, MUTE and PHASE invert
Crossover section with 9 different high and low pass filter options. Up to 24dB/oct
Cross over edge link possibility
Equalisation section with 11 different filter types. Up to 10 equalisation points running per output channel
Limiter and compressor section with automatic mode possibility. Compression status indicator
Independent remote input VCA control
Independent delay per output adjustable to installers preferred units (m, cm, s, ms)
Built in signal generator allows white and pink noise, sine tone and polarity check as an extra versatility tool
USB controlled by AMICLAB included software
Graphic user interface (GUI) allows all parameters to be edited by a single drag and drop mouse operation
Password controlled for unwanted set up manipulation
Full VU-METER control at inputs and outputs
Grouping channels feature simplifies set up when stereo configurations are required
Upgradeable DSP firmware
Full file management
Can be easily installed in any DPA and DPA-T stereo power amplifier
Technical Characteristics
Processing
AMIC
A/D & D/A
DSP
Latency
Input / Output
Input Levels
Nominal
Maximum
Input Attenuator
Input Impedance balanced
Stack Output impedance
CMRR (20Hz - 20kHz)
Distortion @ odbV 20Hz-20kHz
Frequency Response (-0.3dB)
Noise from 20Hz to 20kHz
Crosstalk (20Hz-20kHz)
Maximum Delay
Delay resolution
Compressor / Limiter
Threshold
Ratio
Attack time
Release time
24 bit. 48kHz
48 bits
0.585ms
2 Inputs / 4 outputs (2 internal & 2 external)
0dBV
+12dBV
Stepless from -84dB to + 12dB
30KΩ
300Ω
›60dB
‹0.008%
10Hz - 20kHz
below -105dB
better than -60dB CH1 to CH2 & Stack 1 to Stack2
910ms (312.5m) global for all 4ch
20.83us (7mm)
from -48dBV to +12dBV
1:1 to inf:1 (limiter)
Auto or from 0.1ms to 150ms
Auto or from 1ms to 5s.
High & Low pass Crossover filters
Parametric Eq. types
(10 max. per output)
Built In signal generator
Signal Mute
Signal Polarity Invert
Analog Volume remote control
(0-10VDC)
Connectivity
AMIC
Butterworth in 6 / 12 / 18 / 24dB / oct
Bessel in 12 / 18 / 24dB / oct
Linkwitz-Riley in 12 / 24dB / oct
- Bypass
- Param. eq. 20Hz-20kHz; -60/+12dB; Q from=.3 to 200
- Low & High Shelf 6 / 12 dB / oct
- Low & High Pass 6 / 12 dB / oct
- All-Pass 1/2 order
- Sine (20Hz to 20kHz)
- Polarity (20Hz to 20KHz)
- Pink
- White
Yes
Yes
0V = no attenuation (0dB)
+10V = full attenuation (-inf.)
USB 1.1 (2.0 compatible)
Can provide supply to AMIC while programming
Applications
•• Permanent installation management system
•• Live sound. Monitor management
•• Stereo bi-amped general applications
Accessories
•• WPm series wall panel controls
*Measuring AMIC as an independent device
25
AMIC24
DP400
Technical Characteristics
Processing
AMIC24
A/D & D/A
DSP
Latency
Input / Output
Input Levels
Nominal
Maximum
Input Attenuator
Input Impedance balanced
Stack Output impedance
CMRR (20Hz - 20kHz)
Distortion @ odbV 20Hz-20kHz
Frequency Response (-0.3dB)
Noise from 20Hz to 20kHz
Crosstalk (20Hz-20kHz)
Maximum Delay
Delay resolution
Compressor / Limiter
Threshold
Ratio
Attack time
Release time
26
24 bit. 48kHz
48 bits
0.585ms
2 Inputs / 4 outputs
0dBV
+12dBV
Stepless from -84dB to + 12dB
30KΩ
300Ω
›60dB
‹0.008%
10Hz - 20kHz
below -105dB
›85dB
910ms (312.5m) global for all 4ch
20.83us (7mm)
from -48dBV to +12dBV
1:1 to inf:1 (limiter)
Auto or from 0.1ms to 150ms
Auto or from 1ms to 5s.
High & Low pass Crossover filters
Parametric Eq. types
(10 max. per output)
Built In signal generator
Signal Mute
Signal Polarity Invert
Analog Volume remote control
(0-10VDC)
Connectivity
Mains
Power consumption
Dimensions
Weight
processors
The 24bits-48kHz, 2x4 processor featuring a comprehensive and extensive DSP
management mainly targeted at permanent professional audio Installations.
Thanks to its external black box conception, AMIC24 offers added versatility and
security against unwanted manipulations.
AMIC24 comes with AMICLAB2 exclusive management software for PC: setting
up an Installation has never been so clear and easy.
Digital loudspeaker management unit. The ultimate solution for accurate control
and adjusting of professional sound systems.
Key Features
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
24bits / 48kHz sampling rate for superior audio quality
Powerful 48bits DSP architecture allows real time configurations
Four full independent channels management for an added versatility
Input selection and gain controls, MUTE and PHASE invert
Crossover section with 9 different high and low pass filter options. Up to 24dB/oct
Cross over edge link possibility
Equalisation section with 11 different filter types. Up to 10 equalisation points
running per output channel
Limiter and compressor section with automatic mode possibility.
Compression status indicator
Independent remote input VCA control
Independent delay per output adjustable to preferred units (m, cm, s, ms)
Built in signal generator allows white and pink noise, sine tone and polarity check
as an extra versatility tool
USB controlled by AMICLAB2 included software
Graphic user interface (GUI) allows all parameters to be edited by a single drag
and drop mouse operation
Password controlled for unwanted set up manipulation
Full VU-METER control at inputs and outputs
Grouping channels feature simplifies set up when stereo configurations are required
Upgradeable DSP firmware
Full file management
AMIC24
Butterworth in 6 / 12 / 18 / 24dB / oct
Bessel in 12 / 18 / 24dB / oct
Linkwitz-Riley in 12 / 24dB / oct
- Bypass
- Param. eq. 20Hz-20kHz; -60/+12dB; Q from=.3 to 200
- Low & High Shelf 6 / 12 dB / oct
- Low & High Pass 6 / 12 dB / oct
- All-Pass 1/2 order
- Sine (20Hz to 20kHz)
- Polarity (20Hz to 20KHz)
- Pink
- White
Yes
Yes
0V = no attenuation (0dB)
+10V = full attenuation (-inf.)
USB 1.1 (2.0 compatible)
90-246VAC 47-63Hz
25VA
482.6x44x198mm
2.25 kg.
Applications
•• Permanent installation management system
•• Live sound. Monitor management
•• Stereo bi-amped general applications
Accessories
•• WPm series wall panel controls
Product
processors
2 input / 6 output digital loudspeaker management processor
Dual 24 bits on board DSP
48 kHz sampling rate
Selectable crossover slopes of 12,18, 24 or 48dB per octave
Cross over filter types: Butterworth, Linkwitz-Riley or Bessel
Parametric or shelving equalisation for smooth system frequency response
in INPUTS and OUTPUTS
Available delays in INTPUTS and OUTPUTS
Limiter and compressor. Compressor output with adjustable threshold,
attack and release times
Phase invert switch per output
30 memory bank locations for user programs
Lock-function for protecting program settings
Electronically balanced inputs and outputs
USB control
2x20 character backlit LCD
Fully configurable from PC via DPLAB_2 control software
Applications
•• Stereo 3 way loudspeaker management
•• 2 way L, C, R configurations
•• 1 input / 6 output mono signal processor
Technical Characteristics
DP400
Input section
8k Ω electronically balanced
›55dB (30Hz ÷ 20kHz)
XLR3 female
150 Ω electronically balanced
XLR3 male
48kHz
‹10Hz-20kHz
›102dB
‹0.0028% (1kHz, 1Vms)
›95dB, 30Hz ÷ 20kHz
12, 18, 24 or 48dB/octave (Filter type dependant
Linkwitz-Riley, Butterworth or Bessel
682.52ms / 21 µs
21.31ms / 21 µs
Input impedance
CMRR
Input connector
Output section
Output impedance
Output connector
Sample rate
Frequency response
Dynamic range
THD
Crosstalk
Crossover
filters
Delays
Slopes
Type
Input delay / step
Output delay / step
EQ
Input EQ quantity
Output EQ quantity
EQ type
EQ gain
EQ bandwidth
EQ frequency
Compressor
Threshold
Attack time
Release time
Ratio
General
Mains
Power Consumption
Dimensions WxHxD
Weight
DP400
6 per channel
4 per channel
Parametric. L-Shelf 6dB, L-Shelf 12dB, HShelf 6dB, H-Shelf 12dB
-30dB - 15dB step 0.1 dB
0.016 to 4 octaves
19.7Hz ÷ 21.9 kHZ
-20 + 10 dBV
0.5 - 50ms
10 - 1000ms
1:1, 2 ro 1; ∞
90÷264VAC 50/60Hz
25VA
482.6x44x223mm
3kg
Accessories
••
DP400 is provided with DPLAB_2 control software for accurate remote unit set up in a simple and effective way.
27
IW series
IC5, IC6, IC8, ICSB10L
in-ceiling range
IW6PLUS
in-wall loudspeakers
••
••
••
••
••
••
••
••
ICSB10L
IC5
IC6
IC8
Key features of the
IC series
Two-way (except for the ICSB10) ABS speakers, infinite baffle configuration
Built-in audio transformer for 100 V use
Polypropylene woofer that resists heat and humidity
Front grille may be removed for painting
Clip-type input terminals
Cutting and painting templates included
Support system with 3 rotating tabs
ICSB10: Included metallic accessories to reinforce
installations in standard dropped ceilings
ICSB10L
The IC SB10L is the perfect partner for consistent “invisible”
bass amplification in installations involving ceiling speakers.
Powerful, discreet and easy to install with a simple rotating tab
system, this 10” sub-bass has a power of 100 W RMS and a very
high acoustic performance. The front grille and frame can be
painted to blend in better with the decoration environment. Each
IC SB10 unit comes with a set of accessories that make it easy to
install it in standard lowered ceiling grids, providing the installation all that much more solid and reliable.
Recommended amplification
IC and IW series are provided with cut-out and
painting template for easy installation
IC5
70 mm
••
••
••
••
••
••
••
AMPACK series
PKUB and AMI2-70 self-powered mixers
HMA180 self-powered mixer
MPA-R multi-channel amplifiers line (low impedance or high impedance with DLA adapters)
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management (low impedance)
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
IC6
73 mm
IC8
ICSB10L
91mm
IW6PLUS
The IW6PLUS contains a careful selection of components to produce a Hi-Fi-like
sound that is ideal for high-quality music and announcements in places requiring
in-wall or in-ceiling installation.
It has excellent performance in all frequencies thanks to its adjustable soft dome
tweeter and polypropylene woofer, both mounted for performance in accordance
with the infinite baffle philosophy.
It comes in pairs and is delivered in three parts (frame, speaker and grille) to cut
down the time and complexity ofpainting (if necessary) and installation.
Key features
••
••
••
••
••
••
••
Two-way ABS speaker
Infinite baffle configuration
Polypropylene woofer with high resistance to heat and humidity
Front grille may be removed for easy painting (removal hook included)
Cutting and painting templates included
Support system with 6 rotating lockscrews (do not detach when reaching the end)
Comes unassembled (3 parts) to reduce installation times
Recommended amplification
••
••
••
••
••
••
••
AMPACK series
PKUB and AMI2-70 self-powered mixers
HMA180 self-powered mixer
MPA-R multi-channel amplifiers line (low impedance or high
impedance with DLA adapters)
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management (low impedance)
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
Technical Characteristics
IC5
IC6
IC8
ICSB10L
IW6PLUS
Nominal low impedance
8Ω
8Ω
8Ω
8Ω
16Ω
100W
RMS power
25W
40W
60W
100V LINE
100V LINE
100V LINE
-
-
Power selector
1.5, 3, 6, 12W
2.5, 5, 7.5, 15W
5, 7.5, 15, 30W
-
-
80Hz - 20kHz
70Hz - 20kHz
55Hz - 20kHz
without
(-6dB)
-
-
-
-
75Hz - 750Hz
LP passive filter cut off frequency
-
-
-
150Hz
Sensitivity 1W/1m
(Filter off)
88dB
(Filter on, 80-200Hz)
External diameter
90dB
-
191mm
91dB
-
204mm
-
-
93dB
245mm
92Hz - 20kHz
90dB
91dB
-
335mm
-
Internal diameter
166mm
178mm
220mm
305mm
-
Recommended cut out diameter
168mm
180mm
222mm
307mm
-
Dimensions of hole for installation
28
40W
LP filter(-10dB)
-
-
-
IW6PLUS
80mm
Nominal high impedance
Frequency response
126 mm
Product
With their discreet design, this line of in-ceiling (IC) and in-wall
(IW) speakers is the perfect option for 100 V and low impedance
sound solutions. Both series provide excellent sound quality
thanks to their infinite baffle philosophy and a top-performance
high frequency transducer.
in-ceiling / in-wall speakers
IW6PLUS
in-ceiling / in-wall speakers
IC series
-
188x275mm
Required depth
70mm
73mm
91mm
126mm
80mm
Weight
1.2kg
1.52kg
2.3kg
3.4kg
1.85kg
29
ECL106i series
ICPLUS series
ECL106i, ECL106iFR
in-ceiling range
IC6+ IC8+
in-ceiling range
ECL106IFR
ECL106i Key features
30
Recommended amplification
Applications
••
••
••
••
••
••
••
••
••
••
••
••
••
HMA180 self-powered mixer
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
AMPACK series
AMI2-70TR self-powered mixer
MPA-R multi-channel amplifiers line
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management
Technical Characteristics
ECL106i
ECL106iFR
Nominal low impedance
RMS power
Power selector (100V line)
Frequency response (±3 dB)
Maximum SPL
Sensitivity 1W/1m
External ø
Recommended cut out ø
Required depth
Weight
8Ω
6W
0.75, 1.5, 3, 6W
100Hz - 18kHz
101dB
93dB
200mm
185mm
70mm
0.67 kg
8Ω
6W
0.75, 1.5, 3, 6W
100Hz - 18kHz
101dB
93dB
200mm
185mm
90mm
0.95 kg
Industrial facilities
Corporate, office and residential buildings
Supermarkets, shops, retail stores
Big public areas
Transport stations and related facilities
Health & sport centres
••
••
••
••
••
••
••
••
••
••
••
••
One way, 6” transducer
Nominal impedance: 8Ω
Power: 6 W RMS
Integrated 100 V line transformer
100 V line power taps: 0.75, 1.5, 3, 6 W
Frequency response (±3 dB): 100 Hz - 18 kHz
Max SPL: 101 dB
1 W / 1 m sensitivity: 93 dB
External diameter: 200 mm
Recommended cut out diameter: 185 mm
Required depth: 70 mm
Weight: 0.67 kg
ECL106iFR
••
••
••
••
••
••
••
••
••
••
••
••
••
Key features
Includes all the items required to comply with the BS 5839-8
to become a fire rated loudspeaker:
-Ceramic connector
-Thermal fuse
-Fire-proof back can
One way, 6” transducer
Nominal impedance: 8Ω
Power: 6 W RMS
Integrated 100 V line transformer
100 V line power taps: 0.75, 1.5, 3, 6 W
Frequency response (±3 dB): 100 Hz - 18 kHz
Max SPL: 101 dB
1 W/1 m sensitivity: 93 dB
External diameter: 200 mm
Recommended cut out diameter: 185 mm
Required depth: 90 mm
Weight: 0.95 kg
Product
Available in the standard (ECL106i) and fire rated (ECL106iFR)
versions, compliant with the BS-5839-8 regulation.
The ICPLUS series of in-ceiling speakers from
ECLER integrates a careful selection of components in a design that provides high quality sound
and fast installation, using a minimum of tools.
For maximum flexibility and adaptability to multiple installation profiles, the series has a metal
back can (included by default) and an optional
100V line transformer.
The ICPLUS series consists of 2 models:
IC6+ and IC8+.
Key features
••
••
••
••
••
••
••
••
••
High quality in-ceiling 2-way speaker
Kevlar ® woofer
Silk dome (ACCW) tweeter, ± 15º tiltable
NBR suspension and neodymium magnet
Light construction in 4 mechanical bodies
Fast installation system in 3 steps
(frame-speaker-grill) using a minimum of tools and integrating an automatic safety pin
Aluminium front grill
included metal back can
Optional 100 V line transformer (as a part of the IC PLF kits)
IC8+
In ceiling high-efficiency affordable loudspeakers. Suitable for
Public Address, BGM and other sound systems employing 100 V
lines, where high sound pressure with low amplifier’s power is a
requirement. They include aluminium front grill and fast mounting
system by means of their retractile clips.
in-ceiling / in-wall speakers
IC6+
in-ceiling / in-wall speakers
IC6PLUSBCAN and IC8PLUSBCAN back cans
Recommended amplification
••
••
••
••
••
••
••
••
DPA, XPA and LPA series
AMPACK series
PKUB and AMI2-70 self-powered mixers
HMA180 self-powered mixer
MPA-R multi-channel amplifiers line (low impedance or high impedance with DLA adapters)
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management (low impedance)
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
IC6PLUSTR and IC8PLUSTR 100V line transformers
Applications
High quality speech and music playback in:
•• Corporate and residential buildings
•• Commercial premises
•• Leisure centres
•• Sound reinforcement in clubs, bars, etc.
•• Health and sports centres
•• Meeting and conference rooms
•• 5.1 and 7.1 surround systems
•• Auditoriums, museums
31
ICPLUS series
IC6+ IC8+
in-ceiling range
AMBIT103, AMBIT106,
AMBITSB110
AMBIT range is more than just a line of acoustic cabinets for sound reinforcement. AMBIT is the outcome of a study on the present and immediate
future needs with respect to background and foreground pro audio
applications.
Available in 4 possible kits:
••
••
••
••
IC6PLC
IC6PLC: 6” woofer + 1” tweeter. 75 W RMS IC6PLUSCAN back can included
IC8PLC: 8” woofer + 1” tweeter. 100 W RMS IC8PLUSCAN back can included
AMBIT103
Ultra compact 2 way coaxial loudspeaker cabinet for non
obtrusive applications. Specially suitable for background
reinforcement in thematic restaurants, cafés, retail premises
and licensed venues.
Conceived to integrate into any décor and to provide superb
audio quality under a versatile basis.
IC6PLF: 6” woofer + 1” tweeter. 75 W RMS IC6PLUSBCAN back can
and IC6PLUSTR 100V line transformer included
Key features
IC8PLF: 8” woofer + 1” tweeter. 100 W RMS IC8PLUSBCAN back can
and IC8PLUSTR 100V line transformer included
••
••
••
••
••
••
••
••
IC8PLC
ABS architectural reinforced cabinets range
Built–in audio transformer for 100V applications
8 ohms /100V operation selector
All models include on-wall hardware, safety sling, screws and wrench for fast installation
Available in black and white colours to match any décor
Spring loaded input terminals
IP rated for weatherproof installations
Anti UV cabinet avoids colour degradation in case of direct sunlight exposition
AMBIT103
Best choice of amplifiers and processors
••
••
••
••
••
••
••
IC8PLF
IC6PLF
loudspeaker cabinets
Product
in-ceiling / in-wall speakers
AMBIT series
HMA180 self-powered mixer
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
AMPACK series
AMI2-70TR self-powered mixer
MPA-R multi-channel amplifiers line
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management
••
••
••
••
••
••
••
•• 2 way full range ultra compact loudspeaker cabinet
•• Built-in audio transformer for 100V applications
•• 25 W RMS/8 ohms
•• Power selector (100V): 15,7.5,5,2.5 W
•• 3.5” polypropylene woofer ensure stability against heat
and humidity
•• 13mm soft dome coaxial tweeter
13 mm soft dome coaxial tweeter
Included bracket for on-wall installation
IP54 rated
Efficiency 87 dB SPL 1W/1m
Freq response (-3dB) 150Hz – 20kHz
Dimensions (mm) 120x120x117
1.275 Kg
Accessories AMBIT103
•• MP103AMB2, MP103AMB4 for 2 or 4 units cluster configuration.
•• Available in black. See dedicated product pages for further information.
Applications
Technical Characteristics
IC6+
IC8+
Nominal impedance
RMS power
Frequency response (-6 dB)
Sensitivity 1W/1m
External diameter
Internal diameter
Recommended cut out diameter
Required depth
Weight
8Ω
75W
65Hz - 22kHz
86dB
270mm
224.5mm
227mm
105mm
1.5 kg
8Ω
100W
50Hz - 22kHz
90dB
310mm
264.5mm
267mm
120mm
2 kg
32
270mm
IC6+
105mm
310mm
••
••
••
••
••
IC8+
120mm
Shopping centres
Retail shops
PA distributed sound systems
Clubs, Cafes, Bars foreground/background reinforcement
Tourist temporary outdoor installations
Technical Characteristics
AMBIT103
AMBIT106
AMBITSB110
Ways
Nominal low impedance
Max RMS power
Program power
Nominal high impedance
Power selector
Efficiency SPL 1W 1m
Frequency response at -3dB @ 8Ω
Dimensions WxHxD (without accessories)
Weight
2
8Ω
25W
50W
100V LINE
2.5 / 5 / 7.5 / 15W
87 dB
150Hz ÷ 20kHz
120x120x117mm
1.275 kg
2
8Ω
50W
100W
100V LINE
5 / 7.5 / 15 / 30W
93 dB
110Hz ÷ 20kHz
210x210x160mm
2.75 kg
1
8Ω
200W
400W
92 dB
78Hz ÷ 320Hz
450x320x420mm
15.7 kg
33
AMBIT series
AMBIT103, AMBIT106,
AMBITSB110
AMBIT106
2 way full range compact loudspeaker cabinet
Built-in audio transformer for 100V applications
50 W RMS/8 ohms
Power selector (100V): 30,15,7.5,2.5 W
6.5” polypropylene woofer ensure stability against
heat and humidity
25 mm soft dome coaxial tweeter
Included U-bracket for on-wall installation
IP54 rated
Efficiency 93 dB SPL 1W/1m
Freq response (-3dB) 110Hz – 20kHz
Dimensions (mm) 210x210x160
2.75 Kg
loudspeaker cabinets
All measurements in mm.
MP106AMB3/WH
Hardware for 3/6 AMBIT106.
Available in black and white
MP103AMB2
Compact 2 way coaxial loudspeaker cabinet for non
obtrusive applications. Specially suitable for background
or foreground reinforcement in thematic restaurants,
cafés, retail premises and licensed venues.
••
••
••
••
••
••
••
••
••
••
••
••
MP103AMB2, MP103AMB4, MP106AMB2,
MP106AMB3, MP106AMB4
Product
AMBIT106
loudspeaker cabinets
AMBITSB110
loudspeaker cabinets
AMBIT accessories
Hardware for 2 AMBIT103.
Available in black
AMBITSB110
10” direct radiating bass reflex subwoofer.
Compact profile surface mounting cabinet.
••
••
••
••
••
••
••
••
MP106AMB4/WH
200W RMS/8ohms – 400 W program
Internal x-over 150Hz, 12 dB/oct
Efficiency dB SPL 1W/1m
Single 10” woofer
Efficiency 92 dB SPL 1W/1m
Freq response (-3dB) 78Hz – 200Hz
Dimensions (mm) 450x420x320
15.7 Kg
Hardware for 4 AMBIT106.
Available in black and white
MP106AMB2/WH
Hardware for 2 AMBIT106.
Available in black and white
SR6 ON WALL
Hardware for AMBIT108 and MP106AMB2.
Available in black and white
Accessories AMBIT106
••
••
34
MP106AMB2/WH, MP106AMB3/WH, MP106AMB4/WH: for 2,3 or 4 units cluster configuration. Available in black and white colours
SR6/WH: on wall bracket MP106AMB2 cluster. Available
in black and white colours. See dedicated product pages for further information.
Mechanical Characteristics SR6
MP103AMB4
Hardware for 4 AMBIT103.
Available in black
Length
Max. width
Max. height
Pan
Tilt
Wall hole diameter
Distance between holes
for speaker attachment
161mm
100mm
100mm
170°
180°
6mm
60 mm
35
AUDEO series
loudspeaker cabinets
This versatile series, which comes in three sizes (AUDEO 103, 106 and 108), and in
black or white, is completed by its wall/ceiling supports which allow the cabling to
be concealed and make it possible to install the speakers at low (8 ohms) or high
impedance operation (100 V line).
AUDEO103
AUDEO has a balanced, innovative design, resulting from the collaboration between Ecler and the prestigious group Giugiaro Design during the conceptual and
the external design phases of the speakers. This factor, together with its high quality sound reproduction, make this series the ideal solution for use in numerous
sound projects: corporate and residential buildings, commercial premises, leisure
centres, health centres, conference and meeting rooms, auditoriums, museums,
etc.
AUDEO103
••
••
••
••
••
••
••
••
25 W RMS - 8 ohms
Efficiency: 90 dB SPL 1 W / 1 m
8 ohm / 100 V (2.5, 5, 7.5 or 15 W) mode switch
3.5” woofer and 13 mm Tweeter
Frequency response (-10 dB):
110 Hz to 20 kHz
Dimensions: 132 x 134 x 110 mm
Weight: 1.45 kg
AUDEO103, AUDEO106, AUDEO108,
AUDEOSB110P, STANDAUDEO
loudspeaker cabinets
AUDEO106
••
••
••
••
••
••
••
50 W RMS - 8 ohms
Efficiency: 92,5 dB SPL 1 W / 1 m
8 ohm / 100 V (5, 7,5, 15 or 30 W) mode switch
6.5” woofer and 25 mm Tweeter
Frequency response (-10 dB): 90 Hz to 20 kHz
Dimensions: 242 x 242 x 163 mm
Weight: 2.3 kg
Product
The AUDEO loudspeaker series strikes the perfect balance between the intelligibility and sound reproduction quality requirements currently demanded in the
professional audio installation and ever increasing demands with respect to aesthetics, design and integration into all types of architectural environments.
loudspeaker cabinets
AUDEO106
AUDEO103, AUDEO106, AUDEO108,
AUDEOSB110P, STANDAUDEO
loudspeaker cabinets
AUDEO series
In addition to the included wall bracket, the 103 and 106 models can use the
DSTANDAUDEO desktop stand. If you need to mount the AUDEO speakers on a
microphone stand, then the MSTANDAUDEO is the right accessory to use.
For a subwoofer reinforcement of the AUDEO series speakers, try the AUDEO
SB110P self-powered subwoofer cabinet.
Key features
••
••
••
••
••
••
••
Full range, 2-way acoustic boxes.
Made of reinforced ABS
Available in black or white
8 ohms / 100 V line operating switch
Accessories for wall-mounting included
IP 54 class for installing outdoors
Protective grille at the front with anti-rust treatment
Recommended amplification:
••
••
••
••
••
••
••
••
36
HMA180 self-powered mixer
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
AMPACK series
AMI2-70TR self-powered mixer
MPA-R multi-channel amplifiers line
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management
DPA, XPA and LPA stereo amplifiers
Applications:
••
••
••
••
••
••
••
Corporate and residential buildings
Commercial premises
Leisure centres
Sound reinforcement in clubs, bars, etc.
Health and sports centres
Meeting and conference rooms
Auditoriums, museums
37
AUDEO108
AUDEOSB110P
••
••
••
••
••
••
••
••
The AUDEO SB110P is the self-powered subwoofer reinforcement unit
of the AUDEO series. With a discreet design that enables its use in any
environment, this 10”, 150 W RMS model, is the ideal partner for the
AUDEOs in those music applications where extended low-end response
is required.
100 W RMS - 8 ohms
Efficiency: 94,5 dB SPL 1 W / 1 m
8 ohm / 100 V (7,5, 15, 30 o 60 W) mode switch
8” Kevlar woofer and 1” ACCW silk dome tweeter
Frequency response (-10 dB): 65 Hz to 22 kHz
Aluminium made wall bracket
Dimensions: 300 x 310 x 225 mm
Weight:: 3.75 kg
AUDEO103, AUDEO106, AUDEO108,
AUDEOSB110P, STANDAUDEO
Key features
••
••
••
••
••
••
loudspeaker cabinets
10” driver
150 W RMS integrated amplifier
RCA inputs with mono conversion
RCA stack outputs (link to other SB110P units, AUDEO speakers, etc.)
PHASE and volume controls
Internal 150Hz/18dB oct. LPF
Product
loudspeaker cabinets
MSTANDAUDEO
loudspeaker cabinets
Product
AUDEO103, AUDEO106, AUDEO108,
AUDEOSB110P, STANDAUDEO
loudspeaker cabinets
AUDEO series
AUDEOSB110P
AUDEO series
AUDEO108
DSTANDAUDEO
Desktop stand for the AUDEO103 and AUDEO106 models
MSTANDAUDEO
Technical Characteristics
AUDEO103
AUDEO106
AUDEO108
Ways
Nominal low impedance
Max RMS power
Program power
Nominal high impedance
Power selector
Efficiency SPL 1W 1m
Frequency response at -3dB @ 8Ω
Dimensions WxHxD (without accessories)
Weight
2
8Ω
25W
50W
100V LINE
2.5 / 5 / 7.5 / 15W
90 dB
110Hz ÷ 20kHz
132x134x110mm
1.45 kg
2
8Ω
50W
100W
100V LINE
5 / 7.5 / 15 / 30W
92.5 dB
90Hz ÷ 20kHz
242x242x163mm
2.3 kg
2
8Ω
100W
200W
100V LINE
7.5 / 15 / 30 / 60W
94.5 dB
65Hz ÷ 22kHz
300x310x223mm
3.75 kg
Technical Characteristics
AUDEOSB110P
Driver
Power output (RMS)
Maximum SPL (dB@1m)
Inputs sensitivity nom/impedance
Connector type
Frequency response (-10dB)
Crossover filter (-3dB)
Mains
Power consumption
(pink noise, 1/8 power)
(pink noise, 1/3 power)
(max.power)
Dimension (WxDxH mm/Pcs.)
Weight
1x10* Bass
150W
112dB
0dBV 1V › 1kΩ
RCA
40Hz
150Hz/18dB oct.
AC 115V/230V 50-60Hz
107VA
152VA
237VA
310x505x420mm
16.75kg
MSTANDAUDEO
Microphone stand adapter for the AUDEO series speakers
DSTANDAUDEO
38
39
AUDEO106P
The AUDEO106P self-powered kit is the embodiment of the successful and highly reputed
AUDEO series in a user-friendly and cost-effective formula that can become the perfect
solution in a massive number of multimedia applications. A professional and compact
loudspeaker stereo kit with a fantastic performance and a unique design that will easily fit in
education classrooms, corporate meeting rooms, retail stores, etc.
Key features (PRELIMINARY)
• Self-powered + passive loudspeaker couple kit
• Full-range, 2 way (6” + 1”) loudspeakers
• Stereo balanced input with Euroblock connectors (MASTER unit)
• Stereo unbalanced input with RCA connectors (MASTER unit)
• Euroblock SLAVE unit connector
• Integrated 2 x 20 W RMS amplifier (MASTER unit)
• Integrated and universal power supply (MASTER unit)
• Auto stand-by function (saving energy is assured, no need for a daily ON / OFF switching)
• 2 band tone control & volume control knobs easily identified and gestured
• Anti-Clip integrated system
• ON / STD. BY, Signal Present and CLIP LED indicators
• Reinforced ABS construction
• Available in black or white
• Included wall bracket and security steel cable
• Compatible with the AUDEO series desktop and microphone stand mounting accessories
Accessories
• DSTANDAUDEO desktop stand
• MSTANDAUDEO standard microphone stand adapter
• AUDEOSB110P self-powered subwoofer reinforcement unit
Applications
• Education classrooms
• Multimedia, corporate and conference meeting rooms
• Retail stores
• Leisure centres
• Health and sport centres
• Museums
• Residential buildings
40
loudspeaker cabinets
The NEST106 installation speaker is the result of an in-depth analysis of current and future needs
for background music and voice systems. Retail stores, shopping malls, schools, conference rooms,
hotels, industrial facilities, offices, museums, meeting halls, hospitals, recreational areas, etc. are
just some of the more obvious and direct applications for the NEST106. However, being aware of the
considerable variety of locations and situations that can play host to a speaker, the design team at Ecler
wanted to take it a step further and has made the dreams of increasingly more demanding installers
and decorators come true:
Product
Y
R
A
N
I
M
I
L
PRE
SELF-POWERED AUDEO KIT
AUDEO106P kit
loudspeaker cabinets
NEST106
•• Integration. The special shape of the NEST106, with a front panel in the shape of a partial sphere
(1/8th of a sphere) and the back in the shape of a triangular pyramid, permits a wide variety of potential
installations, ranging from an individual loudspeaker cabinet, fitting perfectly in a corner, to several
units combined to make portions of a sphere or even a complete sphere.
•• Exclusivity. There is no other speaker like it. It is a unique Ecler design that is different, personal and
most importantly: can be adapted to a wide variety of situations. It consists of a two-way system with a
concentric tweeter on top of a woofer.
•• Flexibility. The NEST106 comes with a switch that lets you configure the speaker for its desired
function. All of the boxes can work in low or high impedance (100 V line), and in the latter case, at different levels of power. Simple, quick and versatile.
•• Reliability and quality. The NEST106 is, first and foremost, a speaker with a surprising sound quality,
particularly in view of its size. This is due in part to its particular shape, which produces an interior
volume that is much higher than the subjective, perceived volume. 60 W RMS of power with a performance of 93 dB SPL@1W/1m are hard to beat in speakers with these characteristics.
Key features
••
••
••
••
••
••
Full range, 2-way speaker.
Built-in 100 V line transformer
8 ohms / 100V (7, 10, 15 or 30 W) operating selector switch
Euroblock-type connector
Comes with accessories for wall-mounting, connectors,
screws and Allen key
IP54 class for installing outdoors
Technical Characteristics
NEST106
Ways
Nominal low impedance
Max RMS power
Program power
Nominal high impedance
Power selector
Efficiency SPL 1W 1m
Frequency response at –6dB @ 8Ω
Dimensions WxHxD (without accessories)
Weight
2
8Ω
60W
120W
100V LINE
5/7,5/15/30W
93dB
110Hz ÷ 20kHz
330x230x197mm
3.250kg
MP106NEST2
MP106NEST3
MP106NEST4
Applications
••
••
••
••
••
••
Messages and background music over 100 V or low impedance lines
Shopping and leisure centres
Corporate and residential buildings
Commercial premises, franchise stores
Museums, exhibition halls
Sound reinforcement in discos, bars and restaurants
Accessories
••
••
••
MP106NEST2: 2 NEST106 units wall mount bracket
MP106NEST3: 3 NEST106 units corner mount bracket
MP106NEST4: ceiling bracket for half sphere configurations (4 NEST106 units)
Recommended amplification
••
••
••
••
••
••
••
••
••
DPA, XPA and XLA series
AMPACK series
PKUB and AMI2-70 self-powered mixers
HMA180 self-powered mixer
MPA-R multi-channel amplifiers line (low impedance or high impedance with DLA adapters)
NZA multi-channel amplifiers with built-in DSP and remote
Ethernet management (low impedance)
HZA multi-channel 100 V line amplifiers
HSA single channel 100 V line amplifiers
41
loudspeaker cabinets
Public Address
Speakers
Public Address
Speakers
AC24, AC44, IG108
PHS20T, PRS10T, MSP50T
loudspeaker cabinets
The AC24 and AC44 Acoustic Columns have been specially designed
for Sound Reinforcement and Public Address applications where a
linear installation loudspeaker is required. They’re usually installed on columns or walls, delivering a good coverage and frequency
response for background music and speech uses.
PHS20T, MSP50T and PRS10T are
products carefully selected for the
most extended 100V/70V paging and
background music applications, offering durability and optimal speech and
music reproduction. All models are
manufactured in reinforced ABS and
are IP rated and therefore suitable for
outdoor superior performance.
Thanks to their IP44 rating, with a white aluminium cabinet and front
grill, they can even be used in some kinds of outdoor locations.
Key features
••
••
••
••
••
••
••
••
AC24
2 x 4” Full range loudspeaker
Max RMS Power: 20W
Frequency response: 100 – 18 kHz
Power Taps 100V (70V): 20W / 10W (10W / 5W)
Key features
AC44
4 x 4” Full range loudspeaker
Max RMS Power: 40W
Frequency response: 100 – 18 kHz
Power Taps 100V (70V): 40W / 20W (20W / 10W)
• Aluminium construction (cabinet and front grill), IP44
• White finish
• Included installation brackets with tilt adjustment
AC24
42
AC44
Technical Characteristics
AC24
Frequency response
Sensitivity
Max RMS Power
Power Taps 100V (70,7V)
Dimensions HxWxD mm
Weight
Cabinet Material
Grill Material
Colour
Component
100-18kHz
100-18kHz
91±3dB
93±3dB
20W
40W
20W/10W (10W/5W)
40W/20W (20W/10W)
373x152x100
613x152x100
2.54kg
3.92kg
Powder Coated Aluminium
Powder Coated Aluminium
White
2x4” Full range speaker 4x4” full range speaker
AC44
Product
AC24 / AC44
PHS20T
IG108
••
••
••
••
••
••
••
••
The IG108 is an in-ground weatherproof loudspeaker
(IP65) with an omni directional horizontal dispersion
pattern (360º). It is ideal for music and message
applications in outdoor areas where a reliable yet high
quality sound system is required.
Key features
••
••
••
••
••
••
••
••
••
••
••
IP65 outdoor rated loudspeaker
100 W RMS @ 8 ohms
Efficiency: 91 dB SPL 1 W / 1 m
8 ohm / 100 V (7,5, 15, 30 o 60 W) tap switch
8” Kevlar woofer and 1” ACCW silk dome tweeter
Frequency response (-6 dB): 65 Hz to 22 kHz
Omni directional horizontal coverage pattern (a cir
cular area with an average radius of 4 to 6 meters can be covered by one unit)
Security ground bracket included
Diameter: 366 mm
Height: 394 mm
Weight: 7.5 kg
Technical Characteristics
PRS10T
Nominal low impedance
RMS power
Nominal high impedance
10W
100V LINE 10, 5, 2.5W
Frequency response (-6dB)
Sensitivity 1W/1m
Dimensions (diameter x depth)
Weight
150Hz - 15kHz
91dB
136x220mm
1.6kg
Key features
ABS weatherproof horn loudspeaker
IP56
Power tappings (100V) : 15, 7.5, 3.75, 2 W
20 W RMS/8 ohms
Freq response (-3dB): 300Hz - 8kHz
Efficiency: 102 dB SPL 1W/1m
Dimensions (diameter x depth) : 200x233 mm
1.3 Kg
PHS20T
MSP50T
8W
20W
100V LINE 15W, 7.5W, 3.75W, 2W
70.7V LINE 15W, 7.5W, 3.75W, 2W, 1W
300Hz - 8kHz
102dB
200x233mm
1.35kg
8W
50W
100V LINE 50, 25, 12.5, 9, 4.5, 3.5W
70Hz - 20kHz
99dB
250x360x320mm
3.95kg
PRS10T Key features
MSP50T
••
••
••
••
••
••
••
••
••
••
••
••
••
••
ABS weatherproof sound projector
IP55
Power tappings (100V) : 10, 5, 2.5 W
Freq response (-3dB): 130Hz - 15kHz
Efficiency: 91 dB SPL 1W/1m
Dimensions (diameter x depth) :136x220 mm
1.6 Kg
Key features
ABS weatherproof two way musical horn
IP56
Power tappings (100V) : 50, 25, 12.5, 9, 4.5, 3.5W
Freq response (-3dB): 90Hz-20kHz
Efficiency: 99 dB SPL 1W/1m
Dimensions (mm): 250x360x320
3.9 Kg
Applications
•• General paging and background music reproduction in 100V/70V installations
43
VERSO series
VERSO8P, VERSO10P, VERSO12P
VERSO8, VERSO10, VERSO12
A full range, 2-way speakers line made of high-density plastic
material and with great resistance. Three models whose high
quality and versatility make them ideal for use in fixed and
mobile applications and also as stage monitors.
VERSO8P
A line of self-powered speakers made of high-density
plastic with great resistance. Separate amplifiers for
low and high frequencies. Integrated 2-channel mixer.
Three models whose high quality and versatility make
them ideal for use in fixed and mobile applications and
also as stage monitors.
••
••
••
••
••
••
••
The external design of the speakers, which is modern
and balanced, has been created in collaboration with
the reputed team Giugiaro Design.
••
••
••
••
••
••
••
Full range, 2-way, self-powered speakers
Active crosover with 24 dB/oct slope
Two MICRO/LINE XLR inputs with sensitivity switch
Two way mixer
3-band tone control at mixer output
Balanced “STACK OUT” output for connection to other units or amplifiers
Effective protection system to reduce signal clipping
Carry handles at the rear
6 flying points
Prepared for landscape installation on the ground, with no need for accessories
Protective grille at the front, acoustically transparent
35 mm stand at the base for pole mount
VERSO8P
System
Driver
Power output (RMS)
Maximum SPL (dB@1m)
Dispersion (HxV)
Inputs sensitivity nom/impedance Micro
(Balanced)
Line
Connector type
Frequency response (-10dB)
Tone control Crossover frequencies
Gain
Signal present indicator
Mains
Power consumption (pink noise 1/8 power)
Active Crossover two way full range active cabinet
1x8”(Bass) 1x34mm (Treble) 1x10”(Bass) 1x34mm (Treble) 1x12”(Bass) 1x44mm (Treble)
200W
300W
450W
118dB
120dB
123dB
80” x 60”
80” x 60”
80” x 60”
-40dBV 10mV 20kΩ
-40dBV 10mV 20kΩ
-40dBV 10mV 20kΩ
-20dBV 316mV 20kΩ
-10dBV 316mV 20kΩ
-10dBV 316mV 20kΩ
XLR3
XLR3
XLR3
80Hz~20kHz
65Hz~20kHz
50Hz~20kHz
250Hz-5.5kHz
250Hz-5.5kHz
250Hz-5.5kHz
-20dB + 10dB
-20dB + 10dB
-20dB + 10dB
-35dBV
-35dBV
-35dBV
AC 115V/230V 50-60Hz
AC 115V/230V 50-60Hz
AC 115V/230V 50-60Hz
41VA
95VA
134VA
45VA
112VA
168VA
350VA
680VA
770VA
291x241x398mm
350x290x475mm
447x368x607mm
340x300x480mm
410x355x555mm
520x440x700mm
9.9kg
16kg
24.05kg
11kg
17.6kg
26.7kg
(max. power)
Dimension (WxDxH mm/Pcs)
Packaging dimension (WxDxH mm/Pcs)
Net weight (kg/Pcs)
Gross weight
44
••
••
••
••
••
••
••
••
••
300 W RMS
maximum SPL: 120 dB
HxV dispersion: 80ºx 60º
10” woofer and 34 mm compression driver
Frequency response (-3dB): 65 Hz - 20 kHz
Dimensions: 350 x 290 x 475 mm
Weight: 16 kg
450 W RMS
maximum SPL: 123 dB
HxV dispersion: 80ºx 60º
12” woofer and 44 mm compression driver
Frequency response (-3dB): 50 Hz - 20 kHz
Dimensions: 447 x 368 x 607 mm
Weight: 24,05 kg
Full range, 2-way speakers
Carefully-studied selection of components
Efficient Larsen high-frequency protection system (feedback)
and signal clipping
Carry handle at the rear
6 flying points
Prepared for landscape installation on the ground, with no need for accessories
Protective grille at the front, acoustically transparent
35 mm stand at the base for pole mount
Speakon® connectors
VERSO12P
••
••
••
••
••
••
••
Applications
••
••
••
••
••
Sound for events and audiovisual presentations
Sound reinforcement
Stage monitors
Clubs, discos and leisure centres
Mobile discos
VERSO10
250 W RMS / 8 ohms (500 W programme)
Output: 96 dB SPL 1 W / 1 m
HxV dispersion: 80ºx60º
10” woofer and 34 mm compression driver
Frequency response (-3dB): 60 Hz - 18 kHz
Dimensions: 350 x 290 x 475 mm
Weight: 12.5 kg
VERSO12
••
••
••
••
••
••
••
150 W RMS / 8 ohms (300 W programme)
Output: 97 dB SPL 1 W / 1 m
HxV dispersion: 80ºx60º
8” polypropylene woofer and 25 mm compression driver
Frequency response (-3dB): 70 Hz - 18 kHz
Dimensions: 291 x 241 x 398 mm
Weight: 8 kg
VERSO10
Handle for ease
transportation
Technical Characteristics
(pink noise 1/3 power)
VERSO10P
••
••
••
••
••
••
••
Key features
VERSO12P
••
••
••
••
••
••
••
VERSO8
The external design of the speakers, which is modern and
balanced, has been created together with the reputed team
Giugiaro Design.
VERSO10P
Key features
••
••
••
••
••
••
••
••
••
••
••
••
200 W RMS
maximum SPL: 118 dB
HxV dispersion: 80ºx 60º
8” polypropylene woofer and 25 mm
compression driver
Frequency response (-3dB): 80 Hz - 20 kHz
Dimensions: 291 x 241 x 398 mm
Weight: 9.9 kg
loudspeaker cabinets
Product
loudspeaker cabinets
VERSO P series
Technical Characteristics
VERSO8
System
Driver
Frequency response (-10dB)
Sensitivity (dB@1m 1W)
Impedance
Power rating (RMS)
Maximum SPL (dB@1m)
Dispersion (HxV)
Connector type
Dimension(WxDxH mm/Pcs)
Packaging Dimension (WxDxH mm/Pcs)
Net weight (kg/Pcs)
Gross weight (kg/Pcs)
Built-in Crossover two way full range speaker
1x8”(Bass) 1x34mm(Treble) 1x10”(Bass) 1x34mm(Treble) 1x12”(Bass) 1x44mm(Treble)
80Hz-20kHz
60Hz-18kHz
50Hz-18kHz
97dB
96dB
98dB
8 ohms
8 ohms
8 ohms
150W
250W
350W
119dB
120dB
123dB
80”x60”
80”x60”
80”x60”
2xNL4
2xNL4
2xNL4
291x241x398mm
350x290x475mm
447x368x607mm
340x300x480mm
410x355x555mm
520x440x700mm
8kg
12.5kg
20..35kg
9kg
14kg
22.7kg
350 W RMS / 8 ohms (700 W programme)
Output: 98 dB SPL 1 W / 1 m
HxV dispersion: 80ºx60º
12” woofer and 44 mm compression driver
Frequency response (-3dB): 50 Hz - 18 kHz
Dimensions: 447 x 368 x 607 mm
Weight: 20.35 Kg
VERSO12
Applications
••
••
••
••
••
Sound for events and audiovisual presentations
Sound reinforcement
Stage monitors
Clubs, discos and leisure centres
Mobile discos
45
VERSOANDVERSOP
SERIES
VERSOSB115P
Accessories
VERSOSB115P
VERSO AND VERSOP
loudspeaker cabinets
SR8
Accessories
SR12
TRIPO 1
The VERSOSB115P is the self-powered subwoofer reinforcement unit of
the VERSO series. Its compact design is ideal for those musical mobile
applications where you need an extra punch at the low-end side of the
audible spectrum.
Key features
••
••
••
••
••
••
••
••
15” driver
500 W RMS integrated amplifier
XLR inputs with mono conversion
XLR stack outputs (link to other SB115P units, VERSO P speakers, etc.)
PHASE and volume controls
Internal 100 or 150 Hz LPF (selectable)
Top-hat 35 mm. standard pole mount socket
Optional wheel kit (QRA + WH200 KIT)
Product
loudspeaker cabinets
VERSO series
CNX2RCAXLR2
CNXRCAXLR2
CNXXLRXLRIM5/5/10/20
CNXMJXLR2
BAGVERSO8, BAGVERSO10, BAGVERSO12
46
46
Technical Characteristics
VERSOSB115P
System
Driver
Power output (RMS)
Maximum SPL (dB@1m)
Inputs sensitivity nom/impedance
Input connector type
Stack connector type
Frequency response (-3dB)
THD + Noise @ 1kHz Full power
Low pass filter 12dB/oct.
Indicators:
Signal present
Clip
Mains
Power consumption
(pink noise, 1/8 power)
(pink noise, 1/3 power)
Dimension (WxDxH) (without accessories)
Net weight
Bass active cabinet
15”x1
500W
125dB
0dBV 1V 20kΩ (Balanced)
XLR3 balanced
XLR3 balanced
35Hz~100Hz /35Hz~150Hz
‹1%
100Hz / 150Hz
-40dBV
AC 115V/230V* 50-60Hz
250VA
440VA
590x490x450mm
41.3kg
Audio signal connections
Wall brackets and tripod mounting
••
••
••
TRIP01: 35 mm adjustable tripod
SR8: wall support for VERSO8, VERSO8P,
VERSO10, VERSO10P
SR12: wall support for VERSO10, VERSO10P, VERSO12, VERSO12P
High quality pre made audio connections complete the Verso versatility:
•• CNX2RCAXLR2: 2 x RCA (stereo) - 1 x XLRM 2 m wire
•• CNXRCAXLR2: RCA - XLRM 2 m wire
•• CNXXLRXLR: 1M5 / 5 / 10 / 20: XLRM - XLRF 1.5, 5, 10, 20 m wire
•• CNXMJXLR2: jack 3.5 mm (stereo) - XLRM 2 m wire
XLR - XLR cables are available in four different wire lengths: 1.5, 5, 10 and 20 m.
All connections use OFC and PVC protective jacket. Stereo to mono connections
include internal resistors for load protection and proper audio signal addition.
Transportation bags
•• BAGVERSO8, BAGVERSO10,
BAGVERSO12: bag for easy
transportation and storage
47
DACORDi series
DACORDT108i
Loudspeaker cabinets in high-quality 15 mm plywood
Lyre bracket included for ceiling or wall mounting (except on DACORDT108i)
1.5 mm front grille with internal acoustically transparent screen
Built-in passive filter
HI/LO high frequency response switch
Speakon connectors (input and stack) built into carry handle
Available in black and white
For extra reinforcement of low tones, we recommend using DACORDSB208
or DACORDSB212.
TRIP01: 35mm adjustable tripod for DACORDT208i
SR12 wall anchor for DACORDT208i
SRDABK/WH accessory for anchoring in ceilings. Facilitates direction of the sound box.
Available in black and white.
••
••
••
••
••
••
••
••
••
Compact full-range two-way loudspeaker
150 W RMS/8 ohms – 300 W programme
Efficiency: 93 dB SPL 1 W/1 m
8” polypropylene woofer, 52 mm coil
1” tweeter
7.62 kg
Frequency response (-3 dB): 78 Hz – 22 kHz
Dimensions (mm): 276x360x280
6xM8 hanging points
Full-range two-way loudspeaker
300 W RMS/8 ohms – 600 W programme
Efficiency: 96 dB SPL 1 W/1 m
Double 8” polypropylene woofer, 52 mm coil
Double 1” tweeter
13.90 kg
Frequency response (-3 dB): 70 Hz – 18 kHz
Dimensions (mm): 478x360x332
6xM8 hanging points, 35 mm stand
SR12
SRDABK
DPA series + AMIC DSP integrated card
XPA and LPA series
MPA-R multi-channel amplifiers
NZA multi-channel amplifiers with built-in DSP and remote Ethernet management
Technical Characteristics
Ways
Nominal impedance
Max RMS power
Program power
Efficiency SPL 1W 1m
Max SPL 1m
Frequency response at –10dB
Filter cut-off frequency (slope –6 &-12 dB/oct)
Horizontal dispersion
Vertical dispersion
High frequency attenuation switch
Dimensions (without accessories) mm
Weight
48
••
••
••
••
••
••
••
••
••
SR100:
•• Meets Vesa 50/75/100 mm
•• Load capacity: 30 kgs
•• Tilt: -30 ~ 0 degree, Swivel: 180 degree
•• Material: Steel
•• Speaker to Wall : 105mm
•• Hardware included
•• Cafes
•• Restaurants
•• Theme parks
Recommended amplification and processing
••
••
••
••
Ultra compact, high-performance speaker for sound in audiovisual
rooms, theme restaurants, cafés, businesses and mobile applications.
SR100
•• Audiovisual presentations
•• Corporate halls
•• Perimeter support in clubs
Accessories
••
••
••
Ultra compact, high-performance speaker for sound in
dance clubs, theme restaurants, cafés, businesses, etc.
DACORDT108i Accessories
Applications
•• Shops and stores
•• Sports centres
•• Conference rooms
DACORDT208I
loudspeaker cabinets
Product
Key features
DACORDT108i
TRIPO 1
The new DACORDi series is an update to the successful DACORD series based
on requests by our clients and an added series of improvements:
•• The impedance has been changed from 4 to 8 ohms, which is very important in configurations with a large number of loudspeakers, since it facilitates the task of connecting them in parallel or in parallel-series combinations.
•• New look: new, remodelled front grille with interior sound screen and new logo
DACORDT108i, DACORDT208i, DACORDH206i,
DACORDH208i, SB208, SB212
DACORDT208i
DACORDT108i, DACORDT208i, DACORDH206i,
DACORDH208i, SB208, SB212
loudspeaker cabinets
••
••
••
••
••
••
••
••
DACORDI SERIES
DACORD T108i DACORD T208i DACORD H206i DACORD H208i DACORDSB208 DACORDSB212
2
8Ω
150W
300W
93dB
60Hz÷20kHz
4.5kHz
276x360x280
7.62kg
2
8Ω
300W
600W
91dB
55Hz÷20kHz
4.5kHz
478x360x332
13.90kg
2
8Ω
220W
440W
95dB
65Hz÷20kHz
3.5kHz
90º
60º
6dB
218x645x272
12.50kg
2
8Ω
300W
600W
93dB
55Hz÷20kHz
3.5kHz
90º
60º
4dB
282x670x310
14.45kg
1
4Ω
300W
600W
93.5 dB
122.5 dB
40Hz÷200Hz
548x467x355
21.85kg
1
4Ω
700W
1400W
98 dB
126 dB
40Hz÷300Hz
696x590x474
45.35kg
DACORDT208i Accessories
••
••
••
TRIP01: 35 mm adjustable tripod
SR12: 35 mm adjustable wall anchor (250x12 Omm).
250x140 mm wall plate, four 10 mm holes.
SRDABK/WH: accessory for simple ceiling installation.
Facilitates direction of the speaker
49
DACORDT108i, DACORDT208i, DACORDH206i,
DACORDH208i, SB208, SB212
DACORDH206i
DACORDH208i
Designed to provide high levels of sound pressure in a compact,
lightweight, easy-to-integrate design concept. Additional versatility:
its Presence switch allows for rapid adjustment of high frequencies for
optimum response for any situation or use.
Designed to provide high levels of sound pressure in a compact,
lightweight, non-obtrusive design concept. Additional versatility: its
Presence switch allows for rapid adjustment of high frequencies for
optimum response for any situation.
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
••
Compact full-range two-way loudspeaker
220 W RMS/8 ohms – 440 W programme
Efficiency: 95 dB SPL 1 W/1 m
Double 6.5” woofer, 49.5 mm coil
Exclusive 1” compression motor
90ºx60º adjustable horn
Presence switch for adjusting high frequencies
12.5 kg
Frequency response (-3 dB): 76 Hz – 19.5 kHz
Dimensions (mm): 218x645x272
6xM8 hanging points
Full-range two-way loudspeaker
300 W RMS/8 ohms – 600 W programme
Efficiency: 96 dB SPL 1 W/1 m
Double 8” polypropylene woofer, 52 mm coil
Exclusive 1” compression motor
90ºx60º adjustable horn
Presence switch for adjusting high frequencies
14.45 kg
Frequency response (-3 dB): 70 Hz– 19.5 kHz
Dimensions (mm): 282x670x310
6xM8 hanging points
loudspeaker cabinets
Product
DACORDT108i, DACORDT208i, DACORDH206i,
DACORDH208i, SB208, SB212
DACORDH206i
loudspeaker cabinets
DACORDI SERIES
DACORDH208i
DACORDi series
Especially intended for vocal reproduction. The DACORDSB208 increases its response in low frequencies and dual amplified applications.
SR100
Ideal for low-ceiling applications. The DACORDSB208
increases its response in low frequencies and dual
amplified applications.
SRDABK
SRDABK
DACORDH206i Accessories
•• SR10: adjustable wall anchor (225x150 mm). 85x150 mm wall plate, four 6 mm holes.
•• SRDABK/WH: accessory for simple ceiling installation. Facilitates direction of the speaker
50
DACORDH208i Accessories
•• SRDABK/WH: accessory for simple ceiling installation. Facilitates direction of the speaker
51
DACORDI SERIES
DACORDT108i, DACORDT208i, DACORDH206i,
DACORDH208i, SB208, SB212
Polar Plots
Frequency Response
DACORDSB208
With a focus based on permanent contact and followup with installers and interior design and system integration professionals, the DACORD line of speakers is
intended for fixed installation, especially in environments requiring a compact, high-performance, easyto-install loudspeaker with excellent sound quality.
This subwoofer was specially designed to complement the other speakers in the DACORD/DACORDi
and VERSO series.
It was manufactured using high-quality 18 mm
plywood.
It includes two 12” woofers with a ceramic magnet
and a 75 mm coil.
Key features
3 chamber dual 6th order bandpass cabinet
Ways: 1
Double 8” woofer
300 W RMS @ 4 ohms (600 W program)
Low pass filter tuned at 120 Hz, 12 dB / octave
Efficiency SPL 1 W / 1 m: 93.5 dB
Max SPL 1 m: 122.5 dB
Frequency response at -10 dB:
40Hz to 200Hz
Flying points available in top and
bottom faces (logo can rotate 180º)
Dimensions (without accessories):
548 x 467 x 355 mm
Weight: 21.85 kg
POLAR PLOTS
Key features
DACORDSB208
••
••
••
••
••
••
••
••
••
••
••
FREQUENCY RESPONSE
DACORDSB212
Following the steps of the new SB212, the SB208 is a very compact size and high
efficiency subwoofer, ideal for the reinforcement of the DACORD and AUDEO series.
loudspeaker cabinets
Product
loudspeaker cabinets
DACORDI SERIES
DACORDSB212
••
••
••
••
••
••
••
••
••
••
Three-chamber speaker box, 6th order bass filter
Ways: 1
Nominal impedance: 4Ω
RMS power: 700 W
Programme power: 1400 W
SPL performance 1 W / 1 m: 98 dB
SPL maximum 1 m: 126 dB
Frequency response at -10 dB: 40 Hz to 300 Hz
Dimensions (without accessories):
696 x 590 x 474 mm
Weight: 45.35 kg
Recommended amplification
•• XPA, NZA, DPA/DPA-T and NPA series
Applications
•• Reinforcing DACORDi and AUDEO series
52
53
UMA112i, UMA115i, UMASB118i
UMA112i, UMA115i, UMASB118i
Compact trapezoidal loudspeaker cabinet essentially
targeted for applications which call for compact size,
excellent output and ease of transportation.
Key features
••
••
••
••
••
••
••
••
••
••
••
••
••
15mm birch plywood full range 2 way loudspeaker cabinets
Accurate component selection
Fast set-up thanks to integrated lateral and extra back handles
Textured black paint finish
Protective front grid
M10 internally steel reinforced flying points
Speakon® connectors integrated in back handle
35 mm top-hat pole mount socket
Accessories UMA112i
Best choice of amplifiers and processors
••
••
••
SR12
•• DPA and DPA-T series and AMIC DSP for stereo sound reinforcement applications
•• NPA and NZA series with integrated DSP processing and Ethernet remote management
•• XPA series
350 W RMS / 8ohms
12” woofer. 77mm voice coil. Ceramic magnet
1” Mylar compression driver mounted in an axis
asymmetrical horn:
• 50º - 100º H dispersion
• 55º V dispersion
35mm top hat fitting
Stackable or pole mounting on UMA SB118i sub-bass
TRIP01: adjustable 35mm tripod
POLE01: adjustable 35 rod for UMA112 pole
mounting on UMASB118i
SR12: wall bracket
UMA115i
UMASB118i
Compact trapezoidal loudspeaker cabinet
essentially targeted for applications which
call for compact size, high power and ease of
transportation under a 15” approach.
Sub bass loudspeaker cabinet designed to complement UMAi series.
UMASB118i provides extended bass
response for applications like live club
performances and AV presentations.
••
••
••
••
••
••
••
••
450 W RMS / 8ohms
15” woofer. 100mm voice coil.
Ceramic magnet
1” Mylar compression driver mounted
in an axis asymmetrical horn
50º - 100º H dispersion
55º V dispersion
35mm top hat fitting
Stackable on UMASB118 sub-bass
UMASB118i
UMA112i
UMA115i
UMAi series is the optimal solution for a wide range of applications including portable and fixed
sound reinforcement, club applications, AV events and any installation requiring professional
sound quality and reliability.
Manufactured in 15mm birch plywood, the UMAi series is based in high performance, top quality
12”, 15” and 18” woofers and high end compression drivers to provide a clear natural sound for
both musical and speech programmes in a compact and light enclosure.
loudspeaker cabinets
••
••
••
••
••
Product
UMAi series
UMA112i
loudspeaker cabinets
UMAi series
Sub bass 500 W RMS / 8ohms direct radiating bass reflex enclosure
18” woofer. 100mm voice coil.
Ceramic magnet
Integrated lateral and extra back handles
35mm top hat fitting for UMA112i pole mounting
Accessories UMA115i
•• TRIP01: adjustable 35mm tripod
Applications
••
••
••
••
Live club performances
AV presentations and installations
Corporate productions
Clubs, Pubs and Bars Installs
Technical Characteristics
Ways
Nominal impedance
Max RMS power
Program power
Efficiency SPL 1W 1m
Frequency response at -3dB
Filter cut-off frequency
(slope -6& -12dB/oct)
Dispersion
Dimensions WxHxD (without feet)
Weight
54
••
••
••
••
Side fill monitoring
Church vocal and music playback
Sports events
Theme parks
UMA112i
UMA115i
2
8Ω
350W
700W
98dB
55Hz÷19.5kHz
3.5kHz
2
8Ω
450W
900W
100dB
47Hz÷19.5kHz
3.5kHz
1
8Ω
500W
1000W
102dB
45Hz÷15kHz
-
(50˚-100˚)x55˚
448x580x395mm
21.3kg
(50˚-100˚)x55˚
507x650x456mm
25.2kg
507x645x513mm
32.6kg
12x M10
flying points
UMASB118i
55
loudspeaker cabinets
CKL-T series
Polar Plots
Frequency Response
CKL110T
CKLSM115T
Long throw loudspeaker cabinets range. Manufactured in
18mm multi-layered Finnish birch plywood. Targeted to long
through vocal reproduction as well as music reinforcement
applications in adverse acoustic environments.
FREQUENCY RESPONSE
Key features
••
••
••
••
••
••
••
••
••
••
Long throw multi-layered Finnish 18mm birch plywood loudspeaker cabinets range
Internally reinforced. Trapezoidal shape
Careful component selection
Superior efficiency values: up to 112dB 1W/1m
Scratch and shock proof polyurethane paint finish
Side handles for easy set up
1.5mm protective front grid and acoustically transparent foam against dust and splashes
Six ISO 7166 air cargo tracks for precise rigging
Speakon connectors
EASE 4.1 Files available
loudspeaker cabinets
CKL110T
••
••
••
••
••
••
••
••
••
2 way, full range mid-high loudspeaker cabinet
350 W RMS/8 ohms – 700 W program
Efficiency: up to 112 dB SPL 1W/1m
10” enclosed speaker with neodymium motor and carbon fibre compound diaphragm attached to a Tractix horn with phase corrector
2“ compression driver with pure titanium diaphragm, neodymium motor
60ºx40º constant directivity diffuser
Freq response (-3dB): 170Hz – 19kHz
Dimensions (mm) : 550x550x650
47 Kg
Product
UMAi series
CKLSM115T
••
••
••
••
••
••
••
Mid-low frequencies loudspeaker cabinet
600 W RMS/ 8 ohms – 1200 W program
Efficiency: up to 105 dB SPL 1W/1m
High performance horn loaded 15” speaker
Freq response (-3dB): 70Hz – 280Hz
Dimensions (mm): 550x550x650
37,2 Kg
POLAR PLOTS
Six air cargo tracks for precise rigging
56
Technical Characteristics
CKL110T
Ways
Nominal impedance
Max RMS power
Program power
Efficiency SPL 1W 1m
Frequency response at -3dB
Horizontal dispersion
Vertical dispersion
Dimensions WxHxD (without feet)
Weight
2
8Ω
350W
700W
112dB
170Hz÷19kHz
80˚@250Hz / 60˚@4kHz
80˚@250Hz / 40˚@4kHz
550x550x650mm
47g
CKLSM115T
1
8Ω
600W
1200W
105dB
70Hz÷280Hz
550x550x650mm
37.2g
57
loudspeaker cabinets
CKL-T series
DLA series
CKL110T, CKLSM115T
DLA4-80, DLA6-80, DLA600
amplifier accessories
CKL110T
Multi-channel line adaptors permit the use of stereo and multi-channel low impedance
amplifiers in 100V/70V applications keeping the best sound quality and ensuring maximum power match and amplifiers’ load stability.
Key features
Applications
CKL 110T is ready to use with
EASE 4.1 prediction software
CKLSM115T
••
••
Speech reinforcement in permanent installa-
tion like stadiums, sport pavilions,
theatres, congress halls, houses of worship
CKL SM115T extends low frequency response for music playback in permanent applications and events
2, 4 and 6 channel 100V/70V line adaptors
Excellent frequency response for optimal audio performance even in the low
frequencies band
Nominal input power handling (DLA4-80 and DLA6-80) : 80 W RMS/4 ohms
Nominal input power handling (DLA600) : 80/150/300 W RMS/4 ohms
EUROBLOCK INPUT and OUTPUT connectors
1 RU
Accessories
••
••
••
••
••
••
DLA high quality approach
Accessories
DLA series uses the best audio autotransformers on the
professional audio market.
•• ADP: cargo restraint double stud and ring
•• BAGCKLT: CKL110T and CKL SM115 storage and transportation bag
The use of high quality units, allow amplifiers to drive 100V/70V
lines no matter what the frequency band of the input signal.
Hence, amplifiers’ possible output saturation is eliminated,
thus avoiding the use of internal o external high pass filters that
unnecessarily affect final sound quality.
Technical Characteristics
DLA600
DLA4-80
Input power (nominal)
input impedance at nominal power
Output voltages
Frequency response (-3dB)
Dimensions (mm)
Weight
80/150/300W
4Ω
70/100W
20Hz÷30kHz
482.6 x 266.5 x 44
12kg
80W
4Ω
70/100W
20Hz÷30kHz
482.6 x 266.5 x 44
8.42kg
DLA6-80
80W
4Ω
70/100W
20Hz÷30kHz
482.6 x 266.5 x 44
11.36kg
Applications
Best choice amplifiers
Every DLA model has been developed to match the following stereo and multi-channel
amplifiers:
•• DLA4-80: MPA4-80R, NZA4-70
•• DLA6-80: MPA6-80R, NZA6-70
•• DLA600: DPA600, XPA3000, MPA4-150R, MPA6-150R, MPA4-400R, NZA4-180, NZA6-180
•• Multi-zone and stereo long wire run background and foreground facilities (70/100V lines)
58
59
ATA & DAC series
wp
WPmVOL, WPmVOL-J, WPmVOL-SR, WPmVOL-SR-J,
WPmVOL-IR, WPmCNX-XLRM, WPmCNX-XLRF,
WPmCNX-JRCA, WPmH-AT3, WPmH-AT6, WPmH-SL4,
WPTOUCH, REVO-IR
Wall Panels series with magnetic front plate assembly
ATA1-1R
A single telephone adapter, perfect for medium sized radio stations or any facility
requiring impedance adaptation and galvanic insulation at the same time, to adapt
line level signals to telephonic lines.
Key features
1 RU 19” Single line telephone adapter
TEL SET , STBY and ON AIR switch: conversation can be held either by telephone
or by means of dedicated microphone connected to the mixer in use
Mixer signal level adjustment control
Telephone line impedance adjustment control
RJ11 SET and LINE telephone connectors
RCA connectors to and from mixer
DAC110E
Remote wall panel control for one output zone of a MIMO54 unit (zone volume). RJ45
standard connector. Compatible with all Ecler 0-10V DC REMOTE control ports (MPAR, AMIC, AMPACK, etc.) including the mimo88 GPI ports. Surface-mount installation
box included.
wp vol-J
Same features as WPm VOL + front panel stereo mini-jack connector.
wp vol-sr
Remote wall panel control for one output zone of a MIMO54 unit
(source selection and zone volume). RJ45 standard connector.
Volume control compatible with all Ecler0-10V DC REMOTE control
ports (MPA-R, AMIC, AMPACK, etc.) including the MIMO88 GPI ports.
Surface-mount installation box included.
wp VOL-SR-J
1 RU, 19” Distribution amplifier and splitter-mixer unit. Perfect choice in installations
where a single sound source must be broadcasted to different receivers adapting
impedance values and levels.
Key features
••
••
••
••
••
••
wp vol
1 RU 19” Line level distribution amplifier
Dual operation mode 1 mono input, 10 mono outputs or 1 stereo input, 5 stereo
outputs
12dB INPUT gain control
CLIP indicator in all INPUTS and OUTPUTS
XLR INPUT and OUTPUT connectors
CUT switch in all OUPUTS
Same features as WPmVOL-SR + front panel stereo mini-jack
connector.
wp VOL-IR
IR to 0-10 V DC interface + IR remote control set. Volume UP, DOWN & MUTE functions
converted from IR pulses to VCA voltages. Wall panel blind plate with IR receiver and
IR activity LED (green-orange-red). REVO-IR Remote control included. Compatible
with all Ecler 0-10V DC REMOTE control ports (MPA-R, AMIC, AMPACK, MIMO54, etc),
including the MIMO88 GPI ports. Surface-mount installation box included.
wp CNX-XLRM
Connection Wall Plate with Male 3 pin XLR connector. Screw-type connector at the
back (no solder needed). Surface-mount installation box included.
wp CNX-XLRF
WPTOUCH
••
••
••
••
••
••
Connection Wall Plate with Female 3 pin XLR connector. Screw-type connector at the
back (no solder needed). Surface-mount installation box included.
Technical Characteristics
ATAI-IR
Technical Characteristics
DAC110 E
Transmiter circuit
-10 dBV/15 kΩ
-10 dBV
-20 to 0 dBV
‹0.2%
280Hz - 3.2 kHz
+10dBV / 600Ω
-10dBV
-20 to 0 dBV
›300Ω
+19 dBV
-10dBV/2.2 kΩ
280 Hz - 3.3 kHz
›10dB auto adj.
90-264VCA 47-63Hz
14VA
(482.6 x 44) 195mm
2.2kg
Input level/impedance
Max. input level
Output level/minimum load
Output impedance
Max. output level (with min. load)
Frequency response (-1dB)
Harmonic distortion (1kHz)
TIM 100 (0 dBV)
Noise 20Hz - 20 kHz
CMRR @ 1 kHz
Gain margin
CLIP indicator
LEAKAGE (@ 1kHz)
Channel crosstalk @ 1kHz
Power consumption
Dimensions Panel (w x h) x d
Weight
0 dBV/47 kΩ
+20 dBV
0 dBV/600 Ω
75 Ω
20.2 dBV
2Hz - 95 kHz
‹ 0.005%
‹ 0.003%
‹-102 dB
› 60dB
± 12 dB
-3 dB real clip
‹-110 dB
‹-80dB
19.8 VA
482.6 x 44 x 182 mm
2.7 kg
Receiver circuit
Mains
Power consumption
Dimensions Panel
Weight
60
Input sensitivity/impedance
Nominal transmission level/600Ω
Adjustment margin
Transmission distortion
Frequency response (-3dB)
Max. output level 1% THD
Nominal input level
Adjustment margin
Telephone line input impedance
Max. input level
Output level/min. load
Frequency response (-3dB)
Hybrid return attenuation
(w x h) x depth
audio accessories
Accessories
ATA1-1R
DAC110E
audio accessories
SERIES
wp CNX-JRCA
Connection Wall Plate with 1 x stereo minijack and 2 x RCA connectors.
Surface-mount installation box included
wp H-AT3
Applications
100/70 V line attenuator with integrated 24 VCD priority relay. 3 W maximum output
power. Surface-mount installation box included.
•• Medium sized radio stations
•• General audio distribution/splitter applications in permanent installations
wp H-AT6
100/70 V line attenuator with integrated 24 VCD priority relay. 6 W maximum output
power. Surface-mount installation box included.
wp H-SL4
100/70 V line selector (one out of 4 music program lines). Surface-mount installation
box included.
REVO-IR
WPTOUCH
••
••
••
••
••
••
••
••
••
Digital remote control, compatible with the
MIMO88 digital matrix (CAN-BUS)
2 touch-sensitive keys
1 touch-sensitive jog wheel
1 IR receiver
2x16 char. LCD transflective display
Programmable under the MIMO88 control
(digital mode)
Compatible with the MIMO54 for both volume
control and source selection (analogue mode)
Compatible with other products with 0-10 VDC ports (MPA, AMIC, AMPACK, etc.) for volume
control (using an external power supply)
Recessed or top-wall mount with included accessory
61
wp
SERIES
MPAGE series
WPmVOL, WPmVOL-J, WPmVOL-SR, WPmVOL-SR-J,
WPmVOL-IR, WPmCNX-XLRM, WPmCNX-XLRF,
WPmCNX-JRCA, WPmH-AT3, WPmH-AT6, WPmH-SL4,
WPTOUCH, REVO-IR
audio accessories
MPAGE1, MPAGE4, MPAGE16
desktop paging stations
MPAGE16
MPAGE16 is a digital paging station for the MIMO88. It features 21
touch-sensitive keys that, together with the MIMO88 hardware, allow
for an easy, flexible and user-friendly configuration of a paging system
that can coexist with other MIMO88 functions and with other control
hardware and/or software control systems.
WPmVOL
WPmVOL-J
WPmVOL-SR
WPmVOL-SR-J
••
••
••
••
••
WPmVOL-IR
Accessories
Key features
16 zone selection keys
SELECT ALL, CLEAR and PAGE keys
Two user-defined functions keys (for recalling presets, activating GPOs, etc.)
Gooseneck integrated microphone
Several MPAGE16 or software (virtual) paging stations can work simultaneously (priorities and zones availability is managed by the MIMO88 software setup)
MPAGE4
MPAGE4 is the 4-zone desktop paging station for the MIMO54,
allowing for real-time paging in addition to all the MIMO54 features.
MPAGE1
WPmCNX-XLRM
WPmCNX-XLRF
WPmCNX-JRCA
WPmH-AT3-AT6
WPmH-SL4
MPAGE1 is a 1-zone desktop paging station, compatible with any device including a phantom-powered microphone input (pKUB, SAM series, COMPACT
series, AMI2-70, MIMO54, MIMO88, etc.).
Key features
••
••
••
••
••
••
••
••
4 zone selection keys
SELECT ALL, and PAGE keys
Selectable chime melody
Gooseneck microphone
1 zone paging station
PAGE key
“PAGE ACTIVE” trigger port (GPO), for its connection to external devices
Gooseneck microphone
86 mm
WPm SERIES
Key features
86 mm
62
36 mm
63
DVA-SVA series
64
DVA1-5c
Zin (not selected input)
(selected input)
600Ω approx.
Zout
±6dB adj.
Input level
+10dBV
Output level
0.05% Typ.
l-R Crosstalk
6Hz to 148kHz@-3dB
(@ 1kHz & 600W load)
‹-100dB Lin(10Hz-30kHz) (@ 1kHz & 10kW load)
‹-87dB Lin (10Hz-30kHz) Feedthrough (input to
›57 dB Lin (10Hz-30kHz) any unselected output)
Depending on country
4.5VA
241x44mm
Dimensions Panel
195mm
Depth
1.6kg
Weight
600Ω approx.
according to output
according to input
according to output
according to input
Zin
Zout
Vout
(1 Vpp Vin)
Chroma Gain (@ 4.43MHz)
Diff. Phase5 (10) outs loaded
Diff Gain
5(10) outs loaded
Bandwith (-3dB) approx
In/out
(phase @ 4.43 MHz)
Lum. Lin. Error
Vertical tilt (black pattern ref.)
Signal noise rat (100hz to 20MHz)
Vdc offset at any input
Chroma/Lum. Delay error
(@ 10T & 4.43MHz)
75Ω ± 5%
75Ω ± 4%
0.65Vpp to 1.4Vpp
-5% to + 35% approx
‹0.05 deg.
‹0.1%
28MHz Gaussian Roll-off
‹-18 deg.
‹1% approx.
‹1% approx.
›65dB
‹5mV DC
Zout
Gain
(@ 600Ω load)
Max. Out level (@ 600Ω load)
THD
Frequency response
Noise
(Without video)
Noise
(With video)
Crosstalk
Mains
Power consumption
Dimensions Panel
Depth
Weight
›85dB
›50dB
‹-110dB
241x44mm
195mm
1.15kg
18ns LAG approx.
SVA1-5c
Zin (not selected input)
(selected input)
Zout
Input level
Output level
Video to audio crosstalk
with Cross-hatch pattern
Feedthrough (input to
any unselected output)
75Ω
according to output
according to input
according to output
according to input
›80dB
Applications
‹-40dB @ 4.43MHz
•• General A/V source
distribution and selection
•
°
-
Full Compatible
Compatible with some models (check particular model)
Not compatible
(1)
(2)
(3)
(4)
•
•
−
−
•
•
•
•
−
−
−
•
(3)
(4)
(3)
−
−
−
−
−
−
−
−
−
−
−
−
−
•
•
−
−
•
•
•
•
(2)
(2)
(2)
•
(3)
(4)
(3)
−
−
−
°
−
−
−
−
−
−
−
−
−
•
•
−
−
•
•
•
•
−
−
−
•
(3)
(4)
(3)
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
°
°
−
−
°
°
−
°
°
−
−
−
−
−
−
−
°
°
°
−
−
−
°
°
−
−
−
−
−
−
−
°
−
−
−
−
−
°
°
−
−
−
−
−
−
−
−
−
−
−
−
°
−
−
−
−
−
−
−
−
−
−
−
−
°
°
−
−
−
Accessories
DPA
series
(1)
(1)
−
−
(1)
•
•
•
−
−
−
(1)
(3)
(4)
(3)
−
−
−
°
−
−
−
−
−
−
−
−
−
DPC
118
SVA1-5c
60kΩ approx.
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
•
•
−
−
•
•
•
•
(2)
(2)
(2)
•
(3)
(4)
(3)
−
−
−
°
−
−
−
−
−
−
−
−
−
CKL-T
series
DVA1-5c
•
•
−
−
•
•
•
•
•
•
•
•
(3)
(4)
(3)
−
−
−
−
−
−
−
−
−
−
−
−
−
UMAi
series
Tech. Characteristics
−
•
•
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
•
•
•
•
•
•
−
MPA
series
−
−
•
−
−
−
−
−
−
−
−
−
−
−
−
AMPACK
series
−
−
•
−
−
−
−
−
−
−
−
−
−
−
−
REVO-IR
MPAGE1
MPAGE4
MPAGE16
DLA series
SR8
SR12
SR100
SRDABK/WH
WH200
QRA
ADP
TRIP01
POLE01
pKUB
WP-PSU
•
•
−
−
•
•
•
•
−
−
−
•
(3)
(4)
(3)
−
−
−
−
−
−
−
−
−
−
−
−
−
DACORDi
series
1 RU minirack reversible A/V selector
Accept composite baseband video signal (PAL, SECAM, NTSC)
Dual operation mode: one INPUT/five OUTPUTS or five INPUTS/one OUTPUT
BNC video INPUT and OUTPUT connectors
RCA audio signal INPUT and OUTPUT connectors
Zin
VIDEO
AUDIO
••
••
••
••
••
−
−
−
−
−
•
•
•
−
−
−
−
VERSO
series
SVA1-5c Key features
•
•
−
−
•
•
•
•
−
−
−
•
(3)
(4)
(3)
•
−
−
−
−
−
−
−
−
−
−
−
−
AMIC
AMIC24
Minirack audio and video signal distributors
Accepts composite baseband video signal (PAL, SECAM, NTSC)
BNC video INPUT and OUTPUT connectors
RCA audio INPUT and OUTPUT connectors
Operation mode switch: 1 INPUT and 10 OUTPUTS
Video, chrominance and audio level adjustment
•
•
−
−
•
•
•
•
−
−
−
•
(3)
(4)
(3)
•
−
−
−
−
−
−
−
−
−
−
−
−
HZA
series
••
••
••
••
••
••
Key features
•
•
•
•
•
•
•
•
−
−
−
•
(3)
(4)
(3)
•
•
•
−
−
−
−
−
−
−
−
−
−
HSA
series
DVA1-5c
•
•
•
•
•
•
•
•
−
−
−
•
(3)
(4)
(3)
•
•
−
−
−
−
−
−
−
−
−
−
−
HMA
series
−
−
−
−
−
•
•
•
−
−
−
−
AMI
series
−
−
−
−
−
•
•
•
−
−
−
−
MIMO88
COMPACT
series
SVA1-5c reversible A/V selector features either one input and five outputs or five
inputs and one output signal selection.
MIMO54
SAM
series
WPmVOL
WPmVOL-J
WPmVOL-SR
WPmVOL-SR-J
WPmVOL-IR
WPmCNX-XLRM
WPmCNX-XLRF
WPmCNX-JRCA
WPmH-AT3
WPmH-AT6
WPmH-SL4
WPTOUCH
DVA1-5c distribution amplifiers are versatile accessories for video installations
requiring distribution of A/V signals to various monitors or video projectors, ensuring
minimal loss, maximal signal quality and a guaranteed reliability.
NZA
series
accessories compatibility chart
DVA1-5C, SVA1-5C
NPA
series
video accessories
When including AMIC module
When including DLA module
When including WPTOUCH
When including MPAGE16
65
Installation REFERENCES
EDUCATION
CORPORATE
Surrey University (UK)
Nokia Care (Singapore)
Haitong Group (China)
Telecom Malaysia
Electrolux (Hungary)
Bogdanka mines (Poland)
Bogdanka mines (Poland)
Installation REFERENCES
installation References
Haitong Group (China)
Nokia Care (Singapore)
Electrolux (Hungary)
66
Telecom Malaysia
67
HOSPITALITY
COMMERCIAL
Installation REFERENCES
Shoppes at Marina Bay Sands (Singapore)
Changi Village Hotel (Singapore)
Le Fouquet (Paris - France)
Fullerton Bay Hotel (Singapore)
Midpoint restaurants (Turkey)
Oasia Hotel (Singapore)
Changi Village Hotel (Singapore)
Installation REFERENCES
installation References
Le Fouquet (Paris - France)
Fullerton Bay Hotel (Singapore)
Oasia Hotel (Singapore)
Midpoint restaurants (Turkey)
68
69
LEISURE
Affinity Spa (India)
Palau de Gel FC Barcelona (Spain)
Oxygen Wellness (Hungary)
Maybach Museum (Germany)
Underdoggs Sports Bar (India)
Teatro Livorno (Italy)
Foire du Trône (Paris)
Oxygen Wellness (Hungary)
Installation REFERENCES
Teatro Livorno (Italy)
Affinity Spa (India)
installation References
Installation REFERENCES
SPORTS & WELLNESS
Maybach Museum (Germany)
Foire du Trône (Paris)
Palau de Gel FC Barcelona (Spain)
Underdoggs Sports Bar (India)
70
71
ADVERTISEMENTS
ADVERTISEMENTS
nza series
HZA-F series
AUDEO series
product advertisements
MIMO88
72
73
ADVERTISEMENTS
WORLDWIDE DISTRIBUTION
icplus series
GREEN FACTS
WWW.ECLER.ES/EN/INTERNATIONAL-DISTRIBUTORS.HTM/
74
75
2012
installer’s guide
All product characteristics are subject to variation due to production tolerances.
ECLER, S.A. reserves the right to make changes or improvements in the design
or manufacturing that may affect these product specifications.
Motors, 166-168 08038 Barcelona - Spain
Domestic sales / Ventas España (+34) 902221400 Export sales / Ventas Export (+34) 902331400
General calls (+34) 932238403 Fax (+34) 932238404
www.ecler.com
76
ENGLISH
Download PDF
