1. Avant de commencer
l'emballage
TEW-AI86D/TEW-AI86DB
Base de fixation de l'antenne
(TEW-AI86DB uniquement)
Guide de l'utilisateur
Kit d'installation (TEW-AI86DB uniquement)
Détails du produit
L'antenne intérieure directionnelle est équipée d'une prise SMA
femelle inversée qui peut être branchée soit à votre Point d'accès,
soit à votre adaptateur réseau sans fil.
AVERTISSEMENT: L'antenne peut basculer de 0° à 180° et
pivoter à 360°. Le câble interne de l'antenne étant fixé, veuillez ne
pas faire pivoter l'antenne au-delà de 360°.
Fixation murale ou sur cloison (la base de l'antenne est
équipée d'aimants)
Pour installer l'antenne, vous pouvez la fixer au mur à l'aide des
Fixations et des vis fournies ou simplement l'appliquer sur une
surface métallique.
1
Français
2. Installation du matériel
Dispositifs recommandés pour brancher cette
antenne
Stations de base sans fil avec antenne(s) amovible(s) :
Pour améliorer l'émission du signal afin d'obtenir une meilleure
couverture chez vous ou au bureau, l'antenne fournit un signal
directionnel de 80°.
Adaptateur PCI sans fil ou caméra IP avec antenne amovible
Recommandation: A cause de la nature bidirectionnelle des
terminaux WiFi (émission/réception), il est recommandé d'installer
des antennes externes sur la station de base PA ainsi que sur le
client.
2
Français
Positions d'installations recommandées
L'antenne TEW-AI86D a une couverture directionnelle de 80°.
C'est pourquoi la position idéale de l'antenne est le coin d'une
zone couverte.
Les antennes TEW-AI86D peuvent également être positionnées
sur le côté ou sur le bord de la zone couverte pour une
transmission longue portée dans un hall ou un couloir.
3
Français
Méthodes et configuration de fixation de la station
de base
VEUILLEZ LIRE ATTENTIVEMENT LES INSTRUCTIONS
D'INSTALLATION CI-DESSOUS AVANT DE FORER DES
TROUS DANS LE MUR.
Appuyez sur l'onglet
Soulevez le
couvercle
Enlevez le
contrepoids
Après avoir enlevé le couvercle de son logement, enlevez le
contrepoids métallique des clips de fixation, révélant ainsi les trous
des vis.
Afin de diminuer le poids et d'augmenter l'adhérence
magnétique, il est fortement recommandé d'enlever la plaque
métallique avant d'installer l'antenne au plafond, sur une
cloison ou sur toute surface métallique.
4
Français
Choisissez
l'endroit
Positionnez le
modèle de base
Indiquez la
position des vis
AVERTISSEMENT: Veuillez vous assurer que le dispositif de
PA / client peut atteindre la position que vous destinez à l'antenne
(le câble de l'antenne mesure 1 mètre)
Après avoir indiqué sur le mur les endroits à forer, remontez le
support de l'antenne sans le contrepoids métallique. Les clips ne
devraient pas dépasser.
A propos des vis
Après avoir foré les trous dans la cloison/ la plaque de plâtre,
enfoncer la cheville en plastique dans le trou (utiliser un foret de 3
mm). Laissez dépasser environ de 3 à 5 mm de la vis, comme
indiqué sur le schéma ci-dessous.
3mm
5
Français
Fixation au plafond à l'aide des clips de fixation ou
des aimants
Le système spécial de fixation au plafond est surtout recommandé
lorsque votre station de base sans fil est cachée dans le plafond
ou qu'un dispositif quelconque de protection anti-vol est installé.
Comment assembler le support de l'antenne au
plafond
Pressez l'onglet et
faites pivoter
Retournez le couvercle pour
exposer les clips de fixation
Fixez les clips
à la jointure
Camouflez le routeur / PA
Remarque: Si les jointures du plafond sont en métal,
retourner le couvercle de la base de l'antenne peut ne pas être
nécessaire, parce que la base est équipée d'aimants qui peuvent
être utilisés pour fixer l'antenne à la jointure du plafond.
6
Français
Troubleshooting
Q1. How come I cannot transmit or receive Wi-Fi signals with my TEWAI86D?
A1. The TEW-AI86D is a directional antenna and can only send and
receive signals from the front panel. Make sure to adjust the position
of the antenna by directing the front panel to laptops, PCs or other
wireless devices.
Q2. My access point indicates that it is receiving power, and my laptop
is within range of the TEW-AI86D. However, my laptop does not
receive any signals from my access point.
A2. Make sure that you properly connect the antenna to the Wi-Fi
Access Point. (See 2. Hardware Installation)
Q3. Why won’t the TEW-AI86D work with my IEEE 802.11a Wireless
Router or Access point?
A3. Yes. The TEW-AI86D is compatible with IEEE 802.11a/b/g
wireless devices.
Q4. Is it necessary to use the tapping screws or the wall anchors that
come with the TEW-AI86DB?
A4. It is only necessary if you decide to mount the TEW-AI86DB at a
permanent location. Use discretion when attaching mounting
brackets to the TEW-AI86DB.
If you have any questions regarding the TEW-AI86D/TEW-AI86DB, please
contact TRENDnet Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you
Local Authority or Retailer for recycling advice.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
