VRF Simple Wired Remote User Guide

VRF Simple Wired Remote User Guide
2
1
User Guide
Variable Refrigerant Flow (VRF) System
Simple Wired Remote Control
Model Number: TVCTRLTWR001T, TVCTRLTWR001A
Important: Environmental Concerns! Scientific research has shown
that certain man-made chemicals can affect the earth's naturally occurring
stratospheric ozone layer when released to the atmosphere. In particular,
several of the identified chemicals that may affect the ozone layer are
refrigerants that contain Chlorine, Fluorine and Carbon (CFCs) and those
containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all
refrigerants containing these compounds have the same potential impact
to the environment. Trane advocates the responsible handling of all
refrigerants-including industry replacements for CFCs such as HCFCs and
HFCs.
Important: Responsible Refrigerant Practices! Trane believes that
responsible refrigerant practices are important to the environment, our
customers, and the air conditioning industry. All technicians who handle
refrigerants must be certified. The Federal Clean Air Act (Section 608) sets
forth the requirements for handling, reclaiming, recovering and recycling of
certain refrigerants and the equipment that is used in these service
procedures. In addition, some states or municipalities may have additional
requirements that must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
Wired Remote Control Display
Only qualified personnel should install and service the equipment. The installation,
starting up, and servicing of heating, ventilating, and air-conditioning equipment can
be hazardous and requires specific knowledge and training. Improperly installed,
adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
Indicates a potentially hazardous situation which, if not avoided,
WARNING could result in death or serious injury.
Figure 1.
March 2015
VRF-SVU045B-EN
⑧
⑨
Explanation of display icons
Icon
Explanation
1
Unit operation
2
Quiet operation
3
Temperature setpoint
①
③
⑥
4
Fan speed
④
⑦
5
Air swing (up/down)
⑤
②
6
On/Off timer (scheduled time)
7
Filter cleaning
8
Locked functions/invalid operation
9
Centralized control
Installing/servicing this unit could result in exposure to electrical, mechanical and
chemical hazards. Before installing/servicing this unit, technicians MUST put on all
Personal Protective Equipment (PPE) recommended for the work being
undertaken. ALWAYS refer to appropriate MSDS sheets and OSHA guidelines for
proper PPE. When working with or around hazardous chemicals, ALWAYS refer to
the appropriate MSDS sheets and OSHA guidelines for information on allowable
personal exposure levels, proper respiratory protection and handling
recommendations. If there is a risk of arc or flash, technicians MUST put on all
necessary Personal Protective Equipment (PPE) in accordance with NFPA70E for
arc/flash protection PRIOR to servicing the unit. Failure to follow
recommendations could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
NOTICE:
Item
number
Display icons
⑩
Personal Protective Equipment Required!
CAUTIONs could result in minor or moderate injury. It could also be used to
alert against unsafe practices.
Indicates a situation that could result in equipment or propertydamage only accidents.
Table 1.
Use Figure 1 and Table 1 to identify the icons on the wired remote control
display.
WARNING
SAFETY WARNING
3
WARNING
Proper Field Wiring and Grounding Required!
10
All field wiring MUST be performed by qualified personnel. Improperly installed
and grounded field wiring poses FIRE and ELECTROCUTION hazards. To avoid
these hazards, you MUST follow requirements for field wiring installation and
grounding as described in NEC and your local/state electrical codes. Failure to
follow code could result in death or serious injury.
Purifier mode
© 2015 Trane All Rights Reserved
4
Buttons
Table 2.
Basic Operation
Buttons descriptions
Use Figure 2 and Table 2 to identify the buttons on the wired remote control.
Figure 2.
Buttons
7
6
5
Button
Description
Power button
Press to turn the indoor unit On or Off.
Mode button
Press to select an operating mode.
Up/down arrow buttons
Press to select an indoor temperature setpoint and to change the
time when setting the timer On/Off feature.
Turning On/Off the Indoor Unit
Table 3.
Mode
Description
Auto
In Auto mode, the indoor unit automatically sets the temperature and fan
speed to maintain the selected temperature. If the indoor temperature is
too high, a cooling breeze is generated until the room returns to a
comfortable level. As the room cools, the fan slows down and maintains
a gentle airflow.
Cool
In Cool mode, the temperature setpoint, fan speed, and air flow direction
on the indoor unit can be controlled.
Dry
In Dry mode, the unit dehumidifies the indoor air.
Fan
In Fan mode, the unit ventilates the area to maintain a comfortable indoor
environment.
Heat
In Heat mode, the temperature setpoint, fan speed, and air flow direction
on the indoor unit can be controlled.
Notes:
• There may be a delay before the fan begins running to avoid
generating a cold breeze.
• The defrost indicator (Defrost) appears when frost is being removed
from the outdoor unit. When the defrost function is completed, the
defrost indicator disappears.
• After heating operation is stopped, the fan continues running for a
period of time to cool the unit.
To turn On or Off the indoor unit, press the Power button.
Selecting the Operating Mode
To select an operating mode, press the Mode button until the desired
operating mode appears on the display. Each time the Mode button is
pressed, the screen displays a different mode, in the order shown in
Figure 3.
Figure 3.
Operating mode sequence
Fan Speed button
Press to select a fan speed: Auto, Low, Medium, High.
Air Swing/Quiet button
Press to select air flow direction or quiet operation.
Timer/Filter Reset button
Press and hold 3 seconds to turn the filter cleaning icon off.
Set/Cancel button
Saves/cancels (if held 3 seconds) an On/Off timer setting.
Table 3 describes each of the operating modes.
Operating mode descriptions
8
9
Selecting the Fan Speed
Selecting the Air Flow Direction
To select a fan speed, press the Fan Speed button repeatedly until the
desired fan speed appears on the display. Fan speed availability is
dependent on the current indoor unit operating mode, as shown in Table 4.
The air flow can be directed by tilting the blade upward or downward. To
select the air flow direction:
Table 4.
Fan speed availability according to operating mode
Operating
mode
Available fan speeds
Auto
(Auto)
Cool
(Auto)
Dry
(Auto)
(Med)
(Low)
(High)
(Low)
(Med)
(High)
Heat
(Auto)
(Low)
(Med)
(High)
Note: If you press and hold the Air Swing/Quiet button for 3 seconds on
an indoor unit that does not support the quiet feature or when the indoor
unit is operating in Fan mode, the lock icon (
) light will blink on the
display.
The Off Timer feature is used to set the indoor unit to turn off at a specific
time.
Resetting a Filter
1. Press the Timer/Filter Reset button one time. The time on the display will
blink.
2. Press the up/down arrow buttons until the display shows the time you
want to unit to turn Off. The time will change from 30 minutes to 3 hours
in 30 minute increments, and from 3 to 18 hours in 1 hour increments.
3. To save the selected time, press the Set button within 3 minutes or the
setting will be canceled.
Example of display with Off timer set to turn the unit off 2 hours later.
To set the desired temperature, press the up/down arrow buttons
repeatedly until the desired temperature appears on the display. See
Table 4.
1. Clean the filter.
2. Reset the filter use timer by pressing and holding the Timer/Filter Reset
button for 3 seconds.
Table 5.
Setting the On Timer
Temperature setting ranges and increments
Temperature range
Temperature setting
increments
Auto
65°F–86°F (18°C–30°C)
Fan
You can adjust the temperature
setting by increments of 1°F (1°C).
61°F–86°F (16°C–30°C)
12
User setting mode and main menu
Sub-menu
Main menu
Digit
1
2
Setting the Off Timer
Note: To set the Off timer, the indoor unit must be turned on.
Table 6.
Submenu
code
Option description
Digit
Option code
0
1
Reset to default values
1
0: Not used (default)
1: Reset
1
All features locked
1
2
Partial lock
2
On/Off operation locked
1
3
Operating mode selection
locked
1
4
Temperature setting
locked
1
5
Fan speed selection
locked
1
6
On/Off Timer setting
locked
1
1
Note: To set the On timer, the indoor unit must be turned Off.
1. Press the Timer/Filter Reset button one time. The time on the display will
blink.
2. Press the up/down arrow buttons until the display shows the time you
want to unit to turn On. The time will change from 30 minutes to 3 hours
in 30 minute increments, and from 3 to 18 hours in 1 hour increments.
Option codes/values
Main
menu
code
The On Timer feature is used to set the indoor unit to turn On at a specific
time.
13
Figure 4.
1. Refer to Table 6 to select the menu, sub-menu, digit, and option code for
the function you want to set. These settings become available when the
display is in the user setting mode (Figure 4).
Note: To cancel the On time, press and hold the Set button for 3 seconds.
Setting the Temperature
Heat
To set these additional user functions, follow this procedure:
Quiet operation reduces the noise of the indoor unit. To activate this feature,
press and hold the Air Swing/Quiet button for 3 seconds. To cancel quiet
operation, press the button again.
) appears on the
Additional Functions
Additional functions allow the user to:
• Reset values to factory default
• Lock functions
• Apply upper and lower temperature setting limits
1. Press the Air Swing/Quiet button to tilt the blade up or down.
2. Press and hold the Air Swing/Quiet button again until the desired tilt is
achieved. When the button is released, the blade will stop in place.
When it is time to clean the filter, the filter cleaning icon (
display. When this occurs, do the following:
Dry
Note: To cancel the Off time, press and hold the Set button for 3 seconds.
Selecting Quiet Operation
(Auto)
Cool
11
3. To save the selected time, press the Set button within 3 minutes or the
setting will be canceled.
Example of display with On Timer set to turn the unit on 2 hours later.
Note: If you press the Air Swing/Quiet button on a duct-type indoor unit,
the feature will not function and the lock icon (
) light will blink on the
display.
Fan
Operating
mode
10
1
2
Temperature
limit
0: Clear
1: Lock
0: Clear
1: Lock
0: Clear
1: Lock
0: Clear
1: Lock
0: Clear
1: Lock
0: Clear
1: Lock
Upper limit
1,2
16–30(a)
Lower limit
1,2
16–30
(a) Option code settings 16–30 refer to degrees in Celsius. Refer to Table 5 for
temperature ranges and their Fahrenheit equivalents according to operating mode.
14
5. Using the up/down arrow buttons, select the appropriate sub-menu
code from Table 6.
6. Press the Timer button to access digit 1. Digit 1 will flash as in the
following example.
7. Using the up/down arrow buttons, select the appropriate option code for
digit 1 from Table 6.
8. Press the Set button to save the setting and exit to the sub-menu screen.
2. Press and hold the Timer and Set buttons simultaneously for 3
seconds. The display will change to the user setting mode and the main
menu will flash, as in the following example.
Note: To exit to the sub-menu screen without saving the setting, press
the Air Swing button.
9. Press the Air Swing button to return to the regular display mode.
3. Using the up/down arrow buttons, select the appropriate main menu
code from Table 6.
E
4. Press the Timer button to access the sub-menu setting. The sub-menu
will flash as in the following example.
The manufacturer optimizes the performance of homes and buildings around the world. A
business of Ingersoll Rand, the leader in creating and sustaining safe, comfortable and
energy efficient environments, the manufacturer offers a broad portfolio of advanced
controls and HVAC systems, comprehensive building services, and parts. For more
information, visit www.IRCO.com.
The manufacturer has a policy of continuous product and product data improvement and reserves
the right to change design and specifications without notice.
© 2015 Trane All rights reserved
VRF-SVU045B-EN 01 Mar 2015
Supersedes VRF-SVU045A-EN 01 May
2014
We are committed to using
environmentally conscious
print practices that reduce
waste.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
