General Catalogue
2015/16
elegance, performance,
reliability, respect for the environment.
this is the mission of Foster
for you to Live the Quality.
We respect the ones around us. Foster has been the first
company to introduce burners with superior energy efficiency,
and 100% of the Foster appliances is in A-Class, because
we believe in respecting the environment and own future.
Dishwashers
The dynamics of a choice
02
127
Gas cooker hobs
The collections
130
08
Induction
& electric hobs
Sinks
38
Undermount sinks
162
Ovens - Microwave
Coffee Machine
88
Accessories & Complements
179
Hoods
109
Mixer taps
196
Refrigerators
114
223
1
The dynamics
of a choice
Founded in 1973, Foster is an Italian Company with
four manufacturing facilities wich operates in more
than 50 Countries worldwide. It is an integrated organization
with headquarters in the historical
“Terranova palace” in Brescello, a small village known
for the movies starring Don Camillo and Peppone and symbol of
the Northern Italy countryside.
We breath the love for beautiful things, the respect for nature
that surrounds us and the passion for quality, hence our
commitment to excellent service to meet the demands of a
market increasingly sensitive to technological development and
environmental protection.
2
3
The excellence in our DNA
Since the beginning we have created solutions for kitchen environments
according to our criteria: high performance with attention to energy efficiency,
ease of use enhanced by our design research and advanced technology as a
result of our long experience. This is the Foster philosophy which has inspired
each of our products, for the last 40 years. A value recognized today in every
product we manufacture.
4
Inspired
by Art and Culture
Terranova palace is not just a building, it is the
expression of Foster’s love for art. In 1988, after the
renovations of the former 17th century Franciscan
convent, Foster establishes its headquarters in Terranova
palace in Brescello. The restoration renovates the
splendor to the prestigious frescoes and unearths
ancient historical artifacts. The Terranova palace is
a cultural heritage that the company wants to give
back to the community in all its history, beauty and
magnificence. Foster was among the first Italian
companies to join projects for environmental
preservation and protection and the building is now
under the protection of the “Monuments and Fine Art
Office”.
5
Foster experience
6
Foster has always been involved in spreading the kitchen culture. The gestures of
skilled Chefs enhance the excellence of our appliances in Foster Experience events
and in prestigious Cooking Academy designed in partnership with the most
renowned Italian brand of kitchens.
Design, art and culinary culture are interwoven in the Open House, paths specially
designed by Foster for designers and decorators, and which become important
moments of study and sharing.
7
the Collections
GK
pag. 134
pag. 43
pag. 135
pag. 47
pag. 116
S4000 / S4001
pag. 166
Domino
pag. 139
pag. 54
pag. 120
pag. 171
FL
pag. 141
pag. 57
pag. 119
pag. 143
pag. 58
pag. 119
pag. 148
pag. 67
pag. 122
pag. 147
pag. 69
pag. 121
pag. 155
pag. 73
pag. 121
pag. 161
pag. 86
pag. 125
pag. 195
pag. 156
KE
KS
Marine
Elettra
S1000
Colours
8
pag. 157
pag. 206
pag. 184
pag. 172
pag. 185
pag. 172
pag. 186
pag. 172
pag. 188
pag. 189
pag. 191
pag. 191
pag. 211
pag. 207
pag. 169
pag. 194
pag. 170
pag. 194
pag. 157
pag. 157
pag. 128
pag. 206
pag. 188
pag. 192
pag. 207
pag. 190
pag. 210
pag. 128
pag. 129
pag. 194
pag. 157
9
GK Series
10
Essential and sophisticated, GK does not give in to compromises. The
functional principle inspiring it becomes the hallmark of a timeless
design. The asymmetrical form that characterizes the Series, is
highlighted by the soaring of the GK tap’s barrel, developed to perfectly
match in every detail the great harmony
of the GK design.
Professional at home
11
GK Series
The deep inclined containing area gives a touch of elegance to the GK hob and is at the
same time a very practical feature. The under-knob ring, functional for surface cleaning,
adorns the elegant polished knob. The GK burners are a flagship in terms of energy savings:
more than 25% more efficient than standard models and in full compliance with the strictest
norms, without any limitation of performance: the Dual burner delivers a power of 5000 W, a
feature adapted to professional cooker hobs.
Every detail is studied to enhance the elegance and functionality of the products of the GK
line: from the new, elegant automatic waste-fitting with rectangular remote command to
the exclusive GK tap that perfectly matches the sculpted shape of the sink, highlighting
its line. For all the GK sinks, a complete set of accessories that fit perfectly into the
bowl is available. Each one is studied to perform a specific task in the food preparation,
transforming the sink into a fully complete and functional unit.
12
13
The essence of functionality
14
4001 | 4000 Series
The 4000 Series embodies design devoted to functionality.
Tight and clean lines, innovative technology and attention to detail are the hallmarks
of a range of products to decorates in minimal style the kitchen environment.
15
The S4000 Series offers solutions adapted even to professional Chefs in terms of design and
performance. Ovens that permit a perfect control as well as the practicality of the large preset
recipes database; high efficiency induction and gas cooker hobs, and sinks which seem sculpted
in steel.
A complete range of products and a perfect harmony of design. Ovens, hoods, coffee machine:
a single, stylish aesthetic that blends the sheen of satin steel with elegant reflections of glass.
16
17
Tailor-made style
18
Domino Series
The Domino series of Foster is the perfect solution for the most demanding user,
who wants professional results coupled with an impeccable style.
Gas hobs, induction hobs, Wok and Teppanyaki with induction technology,
grill, downdraft hood, sinks with and without drainer: the Domino series always has
the right answer and stands for freedom of choice and flexibility.
19
20
FL Series
Perfect Home
Design, materials research
and technology. The new FL
collection explores new paths in
search of a perfect aesthetic and
functional fusion between the
kitchen and appliances.
21
FL Series
22
Perfect matching between the sink and hob, which have the same dimensions, shapes, edges, finishes
and above all the same functional concept: a large bowl and sliding accessories for washing; ultra-flat
grids, power and versatility of the Dual burner for cooking.
23
Elegance and practicality
24
KE Series
By choosing Foster you choose quality, design
and innovative technology. Values that leave
no room for compromise and now fully
reflected in the new KE series. The aim of all
the components, whether technological or
aesthetical, remains unaltered: to create an
elegant yet functional work environment.
25
26
KE Series
KE series is synonymous of a wide range of choice among many solutions:
a wide range of undermount bowls is a viable alternative to traditional
sinks with Q4 or flat edges; an extensive range of hobs allows you to
choose between in-line solutions, Domino, and the many versions of the
elegant 5 burners model; the original glass hoods alongside the more
traditional steel models with fireplace.
27
KS Series
Intuitive technology
Who says that technology must be
complicated? The KS range distils all the Foster
technology in simple and elegant forms that
aim first of all at practicality and easiness of use.
28
29
Intuitive technology
Ovens, cooker hoods, dishwashers: the KS range
offers a complete set of solutions exploring the same
concept: easiness of use and long-lasting value.
30
KS Series
31
32
ELETTRA Series
New, rational, sturdy
These are the adjectives that come to mind looking at the
products of the Elettra range. Their simple and linear shapes
promise an intuitive use and a great easiness of matching.
33
COLOURS Series
A collection of cooktops and ovens perfectly matched.
Modern lines that create a pleasant contrast to the range of
classic colors, and so easy to fit in different environments.
34
The classic... restyled
35
News
NEW
FL Series
A new complete system adds to the many collections of the Foster catalogue.
The FL series is distinguished by the harmony of its elements, the perfect harmony of design of hob and sink, and the consistency of materials
and geometries of the hood with the ovens system. The possible choice between white and black-mirror finishes makes it extremely easy and
pleasant pairing with all modern and trendy kitchens.
Sinks
67'
Gas cooker hobs
6)
)7
67'
6)
Hoods
)7
67'
67'
6)
)7
White
Ovens - Microwave & Coffee Machine
Black Mirror
36
Multifunctional 60x60
White
Multifunctional 90x48
White
Mircro combi 60x46
White
Steam oven 60x46
White
Coffee Machine 60x46
White
Plate-warmer module 60x14
White
Multifunctional 60x60
Black Mirror
Multifunctional 90x48
Black Mirror
Mircro combi 60x46
Black Mirror
Steam oven 60x46
Black Mirror
Coffee Machine 60x46
Black Mirror
Plate-warmer module 60x14
Black Mirror
News
NEW
New Wave Sinks
Moon Sinks
The wave is the exclusive mark of this new proposal. A sinuous element that
breaks the sternness of minimalism and makes it more flexible.
A new sleek design blends effortlessly into the reliability of a FOSTER classic.
Sinks without any welding, of great strength, with spacious bowls and a
practical drainer area.
Sink and Mixer restyling
Accessories
Great restyling work on sinks collections. Many of the series have been
renewed with the adoption of the perimeter overflow, which improves
aesthetics. The range of mixers is constantly updated, with the introduction
of 9 new models.
No longer just accessories for sinks, but additionally useful equipment and
complement for the kitchen, as the new systems for recycling and socketholder columns for worktops.
Hobs
Ovens and Coffee Machine
4000 Series is renewed with the new Line and Line XL models, with the
professional touch of cast-iron pot holders. Among the many induction
proposals, the new essential 1000 Series has the ability to limit the maximum
power.
The range of special solutions has been expanded with 4 different choices
between microwave and combi-micro ovens, 2 different steam ovens, 5
maxi-ovens 90 cm wide (48 or 60 cm high). Two coffee machines complete
the ovens modular systems of 4000 Series (automatic grinding of coffee
beans) and FL (Easy Serving Espresso pod system).
37
The Sinks
Foster takes great care to use materials able to provide the best performance. Our entire range is made with AISI 304 - 18/10 and AISI 316
austenitic steels. Thanks to the high percentages of chrome and nickel they contain, they give a particularly bright finish, and make the products
extremely sturdy and absolutely resistant to rust and corrosion. An incredible range at your disposal, counting as many as 26 sinks’ families.
38
GK p. 43
S3000 p. 62
Uragano p. 80
New Wave p. 45
Marine p. 65
Tornado p. 81
S4001 p. 47
KS p. 67
Angolare p. 83
S4000 p. 50
FM p. 69
Diamant p. 84
Quadra p. 52
F300 p. 71
Circolari p. 85
Master p. 56
Elettra p. 73
S1000 p. 86
FL p. 57
Big Bowl p. 75
Undermount sinks p. 88
KE p. 58
Big Bowl Soft p. 77
Triplo invaso p. 61
Moon p. 78
Designer finishes
The exclusive finishes on Foster steels are the result of painstaking research, the aim being to achieve the perfect combination between good
looks and functionality.
A distinctive feature, a true trademark that makes our products stand out for the ease with which they can be cleaned.
Microfoster
finish
Foster
finish
Design
finish
Foster brushed finish
Microfoster® finish
Design finish
The steel is treated with special vegetable fibres that
give it the characteristic extrafine satin finish that
is highly elegant and functional. This makes the
surfaces very smooth and easy to clean.
A scratchproof finish with an exclusive, extrafine and
almost imperceptible textured appearance that gives
the steel a special shine and sets off the style to its
best effect.
Scratchproof finish with an original and elegant texture
that protects the material from accidental scuffing and
from wear through use.
Gun Metal
finish
NEW
Gun Metal finish
A new look for the classic, exclusive AISI 304
steel, thanks to the innovative PVD physical
treatment (Physical Vapor Deposition). This
allows the deposition of precious metals on
steel surfaces, giving a unique look and greater
resistance to scratches and wear.
KE Gun Metal undermount bowls - page 101
N
GU TAL
ME
Vintage
finish
NEW
Vintage finish
An old-fashoined look, along with the
convenience of a steel surface that is not afraid
of scratches and nicks.
The asymmetric brushing obtained with
traditional methods simulates the signs of aging
and gives the steel a new and original appeal.
GK Vintage Sinks and cooker hobs - pages 43,
90, 134
GE
TA
VIN
39
Built-in and beyond
The methods with which worktops can be built-in have become increasingly more varied and customized. Foster was the first sink manufacturer
to have researched and used the new recessing methods and has thus acquired a great deal of experience. It now offers the most comprehensive
range available on the market, with flush-mount, flat-edge and undermount installation.
67'
4
Standard
Q4
Flat-edge
Traditional built-in with the vertical, 8-mm edge.
The casing has a square edge that stands on the work
surface by just 4 mm. Great solution to match the sink
with the ceramic glass hobs (Induction).
An original edge, with an inclined, 3 mm high profile,
matching an extreme elegance with the easiness of
installation.
)7
67
FTS
Flush-mount
Undermount
Built-in
The product is sunk in 1,5 mm deep recess thus beeing
perfectly flush with the worktop. As alternative, it can
be installed on the worktop as well.
A classy and contemporary idea, to be installed under
the worktop; available in various types of sinks, with
soft or square design.
Almost the whole range of Foster sinks can be
integrated into stainless steel worktops; it is the
most elegant and professional solution, that creates
a seamless work-surface.
Flush-mount & Flat-edge: a clarification to be done
Many manufacturers indicate as Flat-edge a Flush-mount edge mounted on the
worktop.
6)
For Foster Flat-edge means a real alternative built-in solution with an elegant 3 mm
sloping edge.
)7
FTS
In any case, Foster’s Flush-mount models can be mounted on the worktop (as in the
detail in the picture), thus offering a further built-in solution.
40
6)
Features
In designing a kitchen, it is essential to create a washing area tailored to one’s requirements.
As a matter of fact, statistics show that most of the time spent in the kitchen involves preparing and cleaning food or washing dishes, therefore,
using the sink.
Essential aspects to consider when choosing a sink include the quality of the steel, manufacturer’s warranty, shape and size of the bowls and
available accessories, be they standard or optional. Foster offers all of this in over 300 items, to enable everyone to choose his/her “OWN” sink.
Sturdy sinks
Spacious bowls
Bowls with tight radius
For every type of sink (welded or single-moulded) and
price bracket, Foster works with above-average steel
thickness when compared to other manufacturers. As
a result, also owing to our long experience, we are able
to construct “sturdy” sinks displaying a unique design.
Thanks to the pioneering manufacturing technology
used, all the bowls in Foster sinks provide a generous
depth (even the single-moulded versions, i.e. formed
from a single sheet of steel). The bowls in many of the
versions are more than 20 cm deep, thus sizeable and
practical for all washing operations.
Bowls with squared-out shapes, a modern design
and more capacity. Foster proposes a wide range of
choices with different manufacturing technologies
and corners with different radiuses.
Mixer tap holes
Diamond-shaped bottom
Waste fittings
On many Foster sinks the ample tap area is already
provided with two tap holes. Many sinks can be
customized with on-demand additional holes, to be
requested on the order. These can be used for taps
requiring two holes, for automatic waste fittings or
for soap dispensers. This features is marked on the
drawings by means of a dotted outline.
The water drainage on the bowl’s bottom is an
important feature, always well cared for on Foster
sinks. In the squared-out, flat-bottomed sinks, the
draining is ensured by the elegant diamond-shaped
creases that make the water flow easier.
Foster sinks are equipped with a generously sized 3.5”
waste fitting and practical strainer plug that prevents
solids from flowing away with the waste water. The
3.5” drain allows the Foster waste-disposer, which is
compatible with all models, to be used. (Compatibility
with the waste-disposer of other manufacturers is not
guaranteed).
Waste fitting with remote control
Perimetric overflow
Space-saver
The waste fitting with remote control is part of the
standard equipment supplied with some of the
models. A very convenient accessory that saves
you from wetting your hands when the bowl needs
emptying (see page 109).
The overflow safety, present on all Foster sinks, avoids
any spillage of water in case the tap is inadvertently
left open. The new perimetric solution available
on some models improves the look thanks to its
squared-out and essential shape.
A feature that optimizes the use of the under-sink
space, which is more and more important due to
recycling practices. This feature is standard on some
models but always possible also on any other model
by ordering specific waste fittings and siphons as
accessories (see page 109).
41
How to read the catalogue (sinks chapter)
Features
Cabinet 90
AISI 304 brushed
dimensions: 1160x500
2b: 400x400+340x400
cut-out: 1140x480
drain: 3½”
2
AISI 304 brushed
dimensions: 1173x513
2b: 400x400+340x400
cut-out: 1140x480
drain: 3½”
Accessories:
Version
Ref.
Technical Drawing
External dimensions refer to
standard version
3
67'
1312 061 rh
1312 062 lh
1
6)
5
1318 061 rh
1318 062 lh
4
A G L4 L5 M N2 N3 O2 P2 R S T2 T4
1
3
Types of installation
Right-hand, left-hand and reversible sinks
Many Foster sinks are available in a variety o versions (Standard, Flushmount, Flat-edge and Undermount) that can have slightly different
dimensions. Therefore we reccomend to check the specifications besides
every version. The built-in type to which figures are referred is always
specified under the drawing.
The double code for a single model indicates that both right-hand and
left-hand versions are available. The right-hand version (rh) refers to a sink
with the bowl (or bigger bowl on models without drainer) on the right.
Left-hand versions are identified by the code “lh”. The single code indicates
that the sink is reversible, or that only the version shown in the picture or
drawing is available.
4
Accessories
Accessories
A
G
L4
Chopping board
34x40
8647 000
Chopping board
40x40
8646 000
Glass chopping board
23x41 cm
8631 300
Always striving to blend aesthetics and functionality, Foster devotes
special attention to its products’ Accessories. This catalogue places special
emphasis on the optional features indicated below each model, to facilitate
identification of the proper combinations.
2
Cabinet
“Cabinet” refers to the smallest standard element of a modular kitchen in
which a sink can be fitted in.
In some cases you may find a double standard:
(ß) for fitting in top at least 40 mm thick, consider the smaller measure, as
indicated in parentheses (e.g. page 52);
726
(T) for fitting in the beginning/end of composition, consider the bigger
measure, as indicated in parentheses.
For special fittings that require extra adaptations to the furniture, please
refer to the kitchen manufacturer.
764
Please note: the listed cabinet sizes refer to the bowls’ encumbrance
and do to consider the fixing brackets, which can change in any given
installation. Please also refer to the kitchen manufacturer’s know-how
for specific installations which may require some customization on the
cabinets.
Cabinet 80 cm
5
Mixer tap holes
In the drawings standard tap holes are shown with continuous line.
Further possible holes on request, in order to install the automatic waste
fitting and the dispenser, are shown with a dashed line. For some models,
customization with additional holes can be done with some extra costs.
42
GK
Essential and sophisticated, GK is a unique sink with refined finishing touches. Every detail is cared for, from the new waste fitting with stainless steel cover to the exclusive matching tap.
SPACE drain
Perimetric overflow
Space saver drain
GE
TA
N
VI
GK
(8488 000 - pag. 116)
NEW
Vintage Finish
suggested mixer taps
Features
AISI 304 brushed
bowl depth: 195 mm
dimensions: 860x480
cut-out: 847x467
drain: autom. SPACE 3½”
Cabinet 90
AISI 304 brushed
bowl depth: 195 mm
dimensions: 860x480
cut-out:
flush-mount (FT): web site
up-mount (FTS): 847x467
drain: autom. SPACE 3½”
Version
Ref.
Technical Drawing
External dimensions refer to
Flat-edge version
6)
1401 100
)7
1401 000
FTS
Included: PA
Optional accessories: M4 N4 T2 P2 Z2
AISI 304 brushed
bowl depth: 235 mm
dimensions: 860x480
cut-out: 847x467
drain: autom. SPACE 3½”
235
Cabinet 90
AISI 304 brushed
bowl depth: 235 mm
dimensions: 860x480
cut-out:
flush-mount (FT): web site
up-mount (FTS): 847x467
drain: autom. SPACE 3½”
GE
TA
vintage VIN
Included: PA
Optional accessories: M4 N4 T2 P2 Z2
Cabinet 60
version
AISI 304 brushed
bowl depth: 195 mm
dimensions: 580x480
cut-out: 567x467
drain: autom. SPACE 3½”
AISI 304 brushed
bowl depth: 195 mm
dimensions: 580x480
cut-out:
flush-mount (FT): web site
up-mount (FTS): 567x467
drain: autom. SPACE 3½”
External dimensions refer to
Flat-edge version
6)
1402 100
)7
1402 000
FTS
)7
1402 080
FTS
External dimensions refer to
Flat-edge version
6)
1403 100
)7
FTS
1403 000
Included: PA
Optional accessories: M4 N4 T2 P2 Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
43
GK
R9
In the flush-mount and flat-edge models, a
remote control to open the drain without dipping
hands into the bowl is also included.
The elegant SPACE steel cap, included in all
models, closes the drain and leaves no visible
residues collected in the basket below.
The attention to detail and the minimalist design
can also be found in the original perimetric
overflow that enhances the bowl.
The inclined containing area is the jointing
element between sink and hob, creating a classy
combination, functional in use and in surfaces
cleaning.
90 mm
The squared vertical edges match to the soft
bottom practical and hygienic ones.
The diamond design on the bottom is a touch of
refinement ensuring the optimal water flow.
The GK sinks are equipped with space-saving
drain and siphon allowing the optimal use of the
under-sink space.
For all the GK models a complete set of optional
accessories is available. These fit perfectly in the
spacious bowl and transform the sink in a complete and functional working area for the preparation
and washing of food.
accessories
44
M4
N4
T2
Iroko chopping board
8656 001
HDPE Twin chopping board
8644 100
St. steel dishes holder
25x42,5 cm
8100 303
P2
Grating kit complete with ring
support and food collection bowl
8159 101
Z2
St. steel perforated pan
8151 000
New Wave
The wave is the exclusive mark of this new proposal. A sinuous element that breaks the sternness of minimalism and makes it more flexible.
R.0
R9
SPACE drain
Radiused bottom R9
Perimetric overflow
Space saver drain
Play
(8487 000 - pag. 117)
Q Circle
(8469 000 - pag. 116)
suggested mixer taps
Features
Cabinet 80
NEW
AISI 304 brushed
dimensions: 1160x520
1 bowl: 710x400
cut-out:
flush-mount (FT): see pack
up-mount (FTS): 1148x508
drain: automatic
SPACE 3½” PA
Perimetric overflow
Space inspectable siphon
Version
Ref.
Technical Drawing
)7
1416 001 rh
FTS
1416 002 lh
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet 60
NEW
AISI 304 brushed
dimensions: 860x520
1 bowl: 450x400
cut-out:
flush-mount (FT): see pack
up-mount (FTS): 848x508
drain: automatic
SPACE 3½” PA
Perimetric overflow
Space inspectable siphon
)7
1414 001 rh
FTS
1414 002 lh
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet 80
NEW
AISI 304 brushed
dimensions: 810x520
1 bowl: 710x400
cut-out:
flush-mount (FT): see pack
up-mount (FTS): 798x508
drain: automatic
SPACE 3½” PA
Perimetric overflow
Space inspectable siphon
)7
FTS
1412 000
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
45
New Wave
Features
Cabinet 60
NEW
Version
AISI 304 brushed
dimensions: 600x520
1 bowl: 500x400
cut-out:
flush-mount (FT): see pack
up-mount (FTS): 588x508
drain: automatic
SPACE 3½” PA
Perimetric overflow
Space inspectable siphon
Ref.
Technical Drawing
)7
FTS
1410 000
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
The distinctive design of the New Wave drainer, with its
refined and ample bend that facilitates the flow of water
into the bowl.
The “Space” waste-fitting with steel cap gives elegance to
the bowl and hides any residue collected in the underlying
basket.
The Space siphon supplied with the sink can be opened
for inspection and leaves all the necessary space to install
waste-sorting systems.
accessories
46
L1
L3
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
L4
N2
N3
O2
Glass chopping board
23x41 cm
8631 300
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
P1
P2
Chopping board
with stainless steel
colander kit
8644 042
Grating kit complete
with ring support and
food collection tray
8159 101
**
T1
T2
St. steel dishes holder
25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
S
T
St. steel basket 40x40
8612 000
*
St. steel dishes holder
25x35 cm
8100 154
White basket 40x40
8612 100
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
S4001
The evolution of S4000 sinks with new bowls with an even tighter radius, enriched by new drain with stainless steel plug and the exclusive perimetric overflow.
SPACE drain
Perimetric overflow
Space saver drain
Q Circle Colour
(8469 040 - p. 116)
Camillo
(8467 000 - pag. 118)
suggested mixer taps
Features
Cabinet 90
Picture shows lh version
AISI 304 brushed
dimensions: 1160x500
1 bowl: 710x400
cut-out: 1140x480
drain: SPACE 3½”
AISI 304 brushed
dimensions: 1173x513
1 bowl: 710x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 1160x500
drain: SPACE 3½”
Version
4
Ref.
4416 061 rh
Technical Drawing
External dimensions refer to
Flush-mount version
4416 062 lh
)7
4417 061 rh
FTS
4417 062 lh
4
4483 061 rh
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T1 T2 Z Z2
For Q4 version only: L5 M (page 49)
Cabinet 60
Picture shows lh version
AISI 304 brushed
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: SPACE 3½”
AISI 304 brushed
dimensions: 873x513
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500
drain: SPACE 3½”
External dimensions refer to
Flush-mount version
4483 062 lh
)7
4486 061 rh
FTS
4486 062 lh
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T1 T2 Z Z2
For Q4 version only: L5 M (page 49)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
47
S4001
R12 sinks range is the new series of flush-mount bowls featuring a particularly tight radius and and valuable fittings such as the stainless steel space-saving drain and the elegant
perimetric overflow.
SPACE drain
Perimetric overflow
Space saver drain
Tre Alto
(8468 000 - pag. 119)
1/2 Circle
(8480 000 - pag. 118)
suggested mixer taps
Features
Cabinet 80
AISI 304 brushed
dimensions: 760x450
1 bowl: 710x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 751x441
drain: SPACE 3½”
Version
Ref.
)7
3127 060
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
dimensions: 550x450
1 bowl: 500x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 541x441
drain: SPACE 3½”
)7
3125 060
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
dimensions: 500x450
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 491x441
drain: SPACE 3½”
)7
3124 060
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
48
Technical Drawing
S4001
Features
Version
AISI 304 brushed
dimensions: 450x450
1 bowl: 400x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 441x441
drain: SPACE 3½”
Cabinet 45
Ref.
Technical Drawing
)7
3126 060
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
dimensions: 390x450
1 bowl: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 381x441
drain: SPACE 3½”
Cabinet 40
)7
3123 060
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
dimensions: 220x450
1 bowl: 170x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 211x441
drain: SPACE 3½”
Cabinet 30
)7
3121 060
FTS
modello integrabile nei top in acciaio inox
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1 L5 P1 R T2
L3
L4
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
M
** p. 55
N2
Sliding
chopping board 30x54
8643 000
N3
O2
P2
HDPE Twin chopping
board 31,7x42,5
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Grating kit complete
with ring support and
food collection tray
8159 101
**
HDPE chopping board
27,2x42,5 cm
8657 001
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
T
*
St. steel dishes
holder 25x35 cm
8100 154
T1
St. steel dishes
holder 25x42,5 cm
8100 201
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
49
S4000
One of he hallmark of the S4000 sink range is the built-in draining board, an indispensable addition for a functional and clean kitchen.
NEW
Perimetric overflow
Play
(8487 000 - pag. 117)
Camillo
(8467 000 - pag. 118)
suggested mixer taps
Features
Cabinet 80
Picture shows lh version
AISI 304 brushed
dimensions: 1160x500
2 bowls: 340x400
cut-out: 1140x480
drain: 3½”
AISI 304 brushed
dimensions: 1173x513
2 bowls: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 1160x500
drain: 3½”
Version
4
Ref.
4312 051 rh
Technical Drawing
External dimensions refer to
Flush-mount version
4312 052 lh
)7
4315 051 rh
FTS
4315 052 lh
4
4362 051 rh
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
For Q4 version only: L5 M
Cabinet 60/(80)T (ref. page 42)
Picture shows lh version
AISI 304 brushed
dimensions: 970x500
2b: 180x340+340x400
cut-out: 950x480
automatic drain 3½”
AISI 304 brushed
dimensions: 983x513
2b: 180x340+340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 970x500
automatic drain 3½” PM
External dimensions refer to
Flush-mount version
4362 052 lh
)7
4365 051 rh
FTS
4365 052 lh
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
For Q4 version only: L5 M
Cabinet 90
Third tap hole available
AISI 304 brushed
dimensions: 860x500
2b: 340x400+400x340
cut-out: 840x480
automatic drain 3½” PM
AISI 304 brushed
dimensions: 873x513
2b: 340x400+400x340
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500
automatic drain 3½” PM
Accessories:
External dimensions refer to
Flush-mount version
4
4382 050
)7
4385 050
FTS
modello integrabile nei top in acciaio inox
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
For Q4 version only: L5 M
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
50
Third tap hole available
S4000
Features
Version
AISI 304 brushed
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
Cabinet 60
AISI 304 brushed
dimensions: 873x513
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500
drain: 3½”
Picture shows lh version
4
Ref.
Technical Drawing
External dimensions refer to
Flush-mount version
4383 051 rh
4383 052 lh
)7
4386 051 rh
FTS
4386 052 lh
4
4381 051 rh
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
For Q4 version only: L5 M
AISI 304 brushed
dimensions: 860x500
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
Cabinet 45
AISI 304 brushed
dimensions: 873x513
1 bowl: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500
drain: 3½”
Picture shows lh version
External dimensions refer to
Flush-mount version
4381 052 lh
)7
4384 051 rh
FTS
4384 052 lh
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
For Q4 version only: L5 M
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Two sloped “grooves” are carved into the drainig
board. Minimalism and functionality.
accessories
L1 L5 P1 R T2
L3
L4
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
M
** p. 55
N2
Sliding
chopping board 30x54
8643 000
N3
O2
P2
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Grating kit complete
with ring support and
food collection tray
8159 101
**
HDPE chopping board
27,2x42,5 cm
8657 001
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
T
*
St. steel dishes
holder 25x35 cm
8100 154
T1
St. steel dishes holder
25x42,5 cm
8100 201
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board 51
Quadra
The Quadra washing solutions are perfectly in tune with the minimalist trends sweeping through the interior design world. Pure squared lines coupled with the sophisticated finishes
of the Foster steels are the ingredients of the wide range of sinks and bowls, which can be fitted overmount (flat-edge and Q4-edge), flush-mount and undermount.
NEW
Perimetric overflow
R.0
R9
Radiused bottom R9
Tre Alto
(8468 000 - pag. 119)
Q Circle
(8469 000 - pag. 116)
suggested mixer taps
Features
Cabinet (60)ß/120 (ref. page 42)
Accessories: (page 55)
AISI 304 brushed
dimensions: 1064x464
1 bowl: 470x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 1047x447
drain: 3½”
Version
Ref.
Technical Drawing
External dimensions refer to
Flat-edge version
)7
1210 050
FTS
modello integrabile nei top in acciaio inox
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
dimensions: 1000x510
1 bowl: 470x400
cut-out: 980x495
drain: automatic 3½” PM
AISI 304 brushed
dimensions: 985x503
1 bowl: 470x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 968x486
drain: automatic 3½” PM
Picture shows rh version
6)
1213 051 rh
1213 052 lh
)7
FTS
1223 051 rh
1223 052 lh
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet (80)ß/120 (ref. page 42)
AISI 304 brushed
dimensions: 1000x440
1 bowl: 675x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 987x427
drain: 3½”
)7
1220 050
FTS
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
52
External dimensions refer to
Flat-edge version
8
Cabinet (60)ß/90 (ref. page 42)
Quadra
Features
AISI 304 brushed
dimensions: 864x464
1 bowl: 800x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 847x447
drain: 3½”
Cabinet 90
Version
Ref.
Technical Drawing
)7
FTS
1218 050
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
dimensions: 840x510
1 bowl: 761x400
cut-out: 820x495
drain: automatic 3½” PM
Cabinet 90
AISI 304 brushed
dimensions: 825x503
1 bowl: 761x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 808x486
drain: automatic 3½” PM
External dimensions refer to
Flat-edge version
6)
1219 050
)7
FTS
1229 050
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
AISI 304 brushed
dimensions: 839x479
bowl: 710x400
cut-out: 819x459
drain: automatic 3½” PM
Cabinet 90
6)
1250 050
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet 80
AISI 304 brushed
dimensions: 804x510
2 bowls: 340x400
cut-out: 784x495
drain: 3½”
AISI 304 brushed
dimensions: 789x503
2 bowls: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 772x486
drain: 3½”
External dimensions refer to
Flat-edge version
6)
1209 050
)7
1208 050
FTS
modello integrabile nei top in acciaio inox
Accessories: (page 55)
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
Cabinet (40)ß/60 (ref. page 42)
AISI 304 brushed
dimensions: 600x520
1 bowl: 270x400
cut-out: 580x500
drain: automatic 3½” PR
standard overflow
4
1246 091 rh
1246 092 lh
modello integrabile nei top in acciaio inox
Picture shows lh version
Accessories: L4 N2 O2 T1 (page 55)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
53
Quadra
Features
Cabinet 60
AISI 304 brushed
dimensions: 560x520
1 bowl: 500x400
cut-out: 540x500
drain: automatic 3½” PM
AISI 304 brushed
dimensions: 579x510
1 bowl: 500x400
cut-out: 559x495
drain: automatic 3½” PM
Version
Ref.
External dimensions refer to
Q4 version
4
6)
1243 050
1216 050
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet 60
AISI 304 brushed
dimensions: 564x464
1 bowl: 500x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 547x447
drain: 3½”
)7
1215 050
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 45
AISI 304 brushed
dimensions: 479x510
1 bowl: 400x400
cut-out: 459x495
drain: automatic 3½” PM
6)
1205 050
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Cabinet 45
AISI 304 brushed
dimensions: 464x464
1 bowl: 400x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 447x447
drain: 3½”
)7
1214 050
FTS
modello integrabile nei top in acciaio inox
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 40
AISI 304 brushed
dimensions: 400x520
1 bowl: 340x400
cut-out: 380x500
drain: automatic 3½” PM
4
1241 050
Accessories:
L1 L4 N2 N3 O2 P1 P2 T1 T2 Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
54
Technical Drawing
Quadra 7"
Features
Version
AISI 304 brushed
dimensions: 864x464
1 bowl: 800x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 847x447
drain: 7”
Cabinet 90
Ref.
Technical Drawing
)7
1218 097
FTS
modello integrabile nei top in acciaio inox
Accessories: L3 L4 N2 O2 S
T T1 Z
Available also in undermount version, see page 92
The 7” waste fitting features a bigger dimension
than standard ones. The drain offers a large and
deep basket for food waste collection.
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), 7” waste fitting/siphon, overflow. Packing: single carton box.
accessories
L1
Twin chopping board
31,7x42,5 cm
8644 041
L3
L4
L5
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
Glass chopping board
29x54 cm
8633 300
M
Sliding
chopping board 30x54
8643 000
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
R
S
St. steel basket 34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes holder
25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes holder
25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
55
Master
A sink with a minimalistic style, with its sloped and perfectly squared drain-board, coupled with functional, easy-to-clean bowls, thanks to their small radius.
NEW
Perimetric overflow
Master
(8493 000 - pag. 119)
Q Circle Plus
(8469 020 - pag. 116)
suggested mixer taps
Features
Cabinet 80
NEW
AISI 304 brushed
dimensions: 1160x520
2 bowls: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 1147x507
drain: automatic 3½” PM
Version
Ref.
)7
1252 051 rh
FTS
1252 052 lh
Picture shows lh version
Accessories: (page 55)
L1 L4 L5 N2 N3 O2 P1 P2 R T1 T2 Z2
Cabinet 60
NEW
AISI 304 brushed
dimensions: 1000x520
2 b.: 340x400 + 180x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 987x507
drain: automatic 3½” PM
)7
1251 051 rh
FTS
1251 052 lh
Picture shows lh version
Accessories: (page 55)
L1 L3 L4 L5 N2 N3 O2 P1 P2 S T T1 T2
Z Z2
Cabinet 60
NEW
AISI 304 brushed
dimensions: 860x520
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 847x507
drain: automatic 3½” PM
)7
1250 051 rh
FTS
1250 052 lh
Picture shows lh version
Accessories: (page 55)
L1 L3 L4 L5 N2 N3 O2 P1 P2 S T T1 T2
Z Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
56
Technical Drawing
FL
The functionality is the hallmark of this original and innovative sink: one big bowl on which slide on independent tracks the practical set of accessories.
SPACE drain
Perimetric overflow
Space saver drain
Master
(8493 000 - pag. 119)
Q Circle
(8469 000 - pag. 116)
suggested mixer taps
Features
Base 80
NEW
Version
AISI 304 brushed
dimensions: 860x500
bowl: 720x320
cut-out: 840x480
drain: 3½”
AISI 304 brushed
dimensions: 873x513
bowl: 720x320
cut-out: 840x480
drain: 3½”
AISI 304 brushed
dimensions: 873x513
bowl: 720x320
flush-mount (FT): web site
up-mount (FTS): 860x500
drain: 3½”
Accessories: M5 T5
Ref.
Technical Drawing
External dimensions refer to
Flat-edge version
67'
6)
2975 060
2976 060
)7
2977 060
FTS
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
M5
Sliding iroko
chopping board
33,2x38,4 cm
8659 113
T5
St. steel dishes
holder
21,4x33,1 cm
8100 304
The characteristic shape of the bowl creates
two lanes on which slide independently the
cutting board and the drip grid. A flexible,
complete and compact working set.
57
KE
KE sinks feature clear-cut, distinctive designs: a handy raised-edge drainer and large, spacious bowls (200 mm) edged with an inclined drip-guard that prevents over-spill.
NEW
Perimetric overflow
KE
(8492 000 - pag. 120)
suggested mixer taps
Features
Cabinet 90
AISI 304 brushed
dimensions: 1173x513
1 bowl: 710x400
cut-out: 1140x480
drain: 3½”
STD
Version
SF
Ref.
Technical Drawing
2211 051 rh
2211 052 lh
FT
modello integrabile nei top in acciaio inox
ST
Picture shows lh version
Accessories: L1 L3 L4 L5 M N2 N3 O2 P1 P2
S T T1 T2 Z Z2 (page 60)
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
STD
AISI 304 brushed
dimensions: 983x513
1 bowl: 500x400
cut-out: 950x480
drain: 3½”
SF
Second tap hole available
2263 051 rh
2263 052 lh
FT
modello integrabile nei top in acciaio inox
ST
Picture shows lh version
983
Accessories: L1 L3 L4 L5 M N2 N3 O2 P1 P2
S T T1 T2 Z Z2 (page 60)
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60/(80)T (ref. page 42)
STD
AISI 304 brushed
dimensions: 983x513
2b: 180x340+340x400
cut-out: 950x480
drain: 3½”
SF
Second tap hole available
2297 051 rh
2297 052 lh
FT
modello integrabile nei top in acciaio inox
ST
Picture shows lh version
Accessories: (page 60)
L1 L4 L5 M N2 N3 O2 P1 P2 R T1 T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
58
Second tap hole available
KE
Features
AISI 304 brushed
dimensions: 873x513
1 bowl: 710x400
cut-out: 840x480
drain: 3½”
Cabinet 80
STD
Version
SF
Ref.
Technical Drawing
2287 050
FT
modello integrabile nei top in acciaio inox
ST
Accessories: (page 60)
STD
L1 L4 L5 M N2 N3 O2 P1 P2 S T1 T2 Z2
AISI 304 brushed
dimensions: 873x513
2b: 340x400
cut-out: 840x480
drain: 3½”
Cabinet 80/(90)T (ref. page 42)
SF
2283 050
FT
modello integrabile nei top in acciaio inox
ST
STD
Accessories: (page 60)
L1 L4 L5 M N2 N3 O2 P1 P2 R T1 T2 Z2
AISI 304 brushed
dimensions: 873x513
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
Cabinet 60
SF
2280 051 rh
2280 052 lh
FT
modello integrabile nei top in acciaio inox
ST
Picture shows lh version
Accessories: L1 L3 L4 L5 M N2 N3 O2 P1 P2
S T T1 T2 Z Z2 (page 60)
STD
AISI 304 brushed
dimensions: 873x513
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
Cabinet 45/(60)T (ref. page 42)
SF
2281 051 rh
2281 052 lh
FT
modello integrabile nei top in acciaio inox
ST
Picture shows lh version
Accessories: (page 60)
L1 L4 L5 M N2 N3 O2 P1 P2 R T1 T2 Z2
Second tap hole available
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
KE Series also includes elegant gas cooker hobs
and a new collection of multifunction and pyrolytic
ovens. In the picture: the matching with the original
version of the hob with white grids.
59
KE Q4
Features
AISI 304 brushed
dimensions: 770x520
1 bowl: 710x400
cut-out: 750x500
drain: automatic 3½” PM
Cabinet 80
Version
4
Ref.
Technical Drawing
2278 050
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
AISI 304 brushed
dimensions: 770x520
2 bowls: 340x400
cut-out: 750x500
drain: automatic 3½” PM
Cabinet 80
4
2279 050
Accessories:
L1 N2 N3 O2 P1 P2 S T1 T2 Z2
AISI 304 brushed
dimensions: 510x520
1 bowl: 450x400
cut-out: 490x500
drain: automatic 3½” PM
Cabinet 60
4
2274 050
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1 P1 R T
L3
L4
L5
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
Glass chopping board
29x54 cm
8633 300
* Z2 ** p. 55
M
Sliding chopping
board 30x54
8643 000
N2
N3
O2
P2
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Grating kit complete
with ring support and
food collection tray
8159 101
S
St. steel basket 40x40
8612 000
T1
T2
St. steel dishes holder
25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
**
*
St. steel colander
25x36 cm
8154 000
White basket 40x40
8612 100
60
*To use only with L3 chopping board **To use only with N3 chopping board
Triplo Invaso
Professional in every aspect: dimensions as well as practicality. An absolutely new product featuring the Q4 edge and reduced 52 cm depth, to be combined with the new cooker hobs.
Magnum
(8484 000 - pag. 117)
Arsenio
(8471 000 - pag. 120)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 860x520
1 bowl: 710x400
cut-out: 840x500
drain: automatic
SPACE 3½” PA
Cabinet 90
Version
4
Ref.
Technical Drawing
1490 060
modello integrabile nei top in acciaio inox
52
Accessories: L4 M2 M3 N2 O2 S U2 (page 63)
AISI 304 brushed
dimensions: 860x520
2b: 500x400+233x335
cut-out: 840x500
drain: automatic 3½” PR
Cabinet 90
4
1485 061 rh
1485 062 lh
modello integrabile nei top in acciaio inox
52
Picture shows lh version
Accessories:
L4 M2 M3 N2 O2 S U2 T4 Z (page 63)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
52
Triplo Invaso sink is 52 cm deep, for a perfect matching with all S4000 gas cooker hobs.
61
S3000
A successful collection thanks to its sober elegance. The wide range of available versions - that vary in terms of size and type of installation - makes the S3000 an evergreen series that
can be combined with all Foster cooker hobs.
Flexo
(8456 000 - pag. 119)
Michy
(8489 000 - pag. 124)
suggested mixer taps
Features
Cabinet 90
AISI 304 brushed
dimensions: 1160x500
2b: 400x400+340x400
cut-out: 1140x480
drain: 3½”
AISI 304 brushed
dimensions: 1173x513
2b: 400x400+340x400
cut-out: 1140x480
drain: 3½”
Picture shows rh version
modello integrabile nei top in acciaio inox
Accessories:
A G L1 L4 N2 N3 O2 P1 P2 R S T2 T4
For Standard and Flat-edge version only: L5 M
Cabinet 60/(80)T (ref. page 42)
Picture shows rh version
modello integrabile nei top in acciaio inox
Accessories:
A L1 L4 N2 N3 O2 P1 P2 Q R T2 T4
Standard and Flat-edge version only: L5 M
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 90
AISI 304 brushed
dimensions: 1173x513
2b: 400x400+340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 1160x500
drain: 3½”
AISI 304 brushed
dimensions: 970x500
2b: 340x400+150x300
cut-out: 950x480
drain: 3½”
AISI 304 brushed
dimensions: 983x513
2b: 340x400+150x300
cut-out: 950x480
drain: 3½”
AISI 304 brushed
dimensions: 983x513
2b: 340x400+150x300
cut-out:
flush-mount (FT): web site
up-mount (FTS): 970x500
drain: 3½”
AISI 304 brushed
dimensions: 860x500
2b: 400x400+340x400
cut-out: 840x480
drain: 3½”
AISI 304 brushed
dimensions: 873x513
2b: 400x400+340x400
cut-out: 840x480
drain: 3½”
Version
67'
Ref.
1312 061 rh
Technical Drawing
External dimensions refer to
standard version
1312 062 lh
6)
1318 061 rh
1318 062 lh
)7
1315 061 rh
FTS
67'
1315 062 lh
1363 061 rh
External dimensions refer to
standard version
1363 062 lh
6)
1369 061 rh
1369 062 lh
)7
1366 061 rh
FTS
1366 062 lh
Second and third tap hole available
External dimensions refer to
standard version
67'
1382 062 lh
6)
1388 062 lh
AISI 304 brushed
)7
dimensions: 873x513
2b: 400x400+340x400
cut-out:
1385 062 lh
A G L1 L4 N2 N3 O2 P1 P2 R S T2 T4
flush-mount (FT): web site
FTS
up-mount
(FTS):
860x500
L5
M
Standard and Flat-edge version only:
drain: 3½”
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
modello integrabile nei top in acciaio inox
Accessories:
62
S3000
Features
Cabinet 60
Version
AISI 304 brushed
dimensions: 860x500
1 bowl: 400x400
cut-out: 840x480
drain: 3½”
67'
AISI 304 brushed
dimensions: 873x513
1 bowl: 400x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500
drain: 3½”
G L1 L4 N2 N3 O2 P1 P2 S T2 T4
Standard and Flat-edge version only: L5 M
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 790x500
2 bowls: 340x400
cut-out: 770x480
drain: 3½”
Cabinet 80
Technical Drawing
External dimensions refer to
standard version
1381 061 rh
1381 062 lh
AISI 304 brushed
dimensions: 873x513
1 bowl: 400x400
cut-out: 840x480
drain: 3½”
Picture shows lh version
modello integrabile nei top in acciaio inox
Accessories:
Ref.
6)
1387 061 rh
1387 062 lh
)7
1384 061 rh
FTS
1384 062 lh
Second tap hole available
67'
1372 060
Accessories:
A L1 L4 L5 M N2 N3 O2 P1 P2 R T2 T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
A
G
Chopping board
34x40
8647 000
L5
Chopping board
40x40
8646 000
M
Glass chopping board
29x54 cm
8633 300
Sliding
chopping board 30x54
8643 000
L1
L4
Twin chopping board
31,7x42,5 cm
8644 041
Glass chopping board
23x41 cm
8631 300
M2
M3
Chopping board
28x48
8643 115
Sliding chopping
board 28x48
8643 116
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
T2
**
St. steel dishes
holder 21,4x37,9 cm
8100 303
Q
White colander
17x32 cm
8151 100
R
St. steel basket 34x40 cm
8611 000
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
T4
U2
St. steel dishes
holder 25x43 cm
8100 301
St. steel dishes
holder 23x47
8100 115
Z
*
St. steel colander
25x36 cm
8154 000
*To use only with L3 chopping board **To use only with N3 chopping board 63
S3000
Features
Cabinet 60
AISI 304 brushed
dimensions: 554x454
1 bowl: 503x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 541x441
drain: 3½”
Version
Ref.
Technical Drawing
)7
1116 061 rh
FTS
1116 062 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: (page 63)
L1 L4 N2 N3 O2 P1 P2 S T2
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 45
AISI 304 brushed
dimensions: 454x454
1 bowl: 400x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 441x441
drain: 3½”
)7
1114 061 rh
FTS
1114 062 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: (page 63)
L1 L4 N2 N3 O2 P1 P2 S T2
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 40
AISI 304 brushed
dimensions: 394x454
1 bowl: 340x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 381x441
drain: 3½”
)7
1117 061 rh
FTS
1117 062 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: (page 63)
L1 L4 N2 N3 O2 P1 P2 R T2
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
For rh/lh version on mean bowl with drain on righ/left side.
The artful combination of straight lines (draining
board) and curved lines (the wide-radius bowls)
creates an ideal match with either squared or
curved-rod mixer taps.
64
Marine
The elegant design of the FM series, revived with the new AISI 316 stainless steel, particularly resistant to salt and acid, and with the elegant Flat-edge.
AISI 316
Stainless Steel
Gamma 3 vie
(8496 100 - pag. 121)
Hook
(8479 100 - pag. 119)
suggested mixer taps
Features
Cabinet 80/(90)T (ref. page 42)
AISI 316 brushed
dimensions: 1173x513
2 bowls: 362,5x400
cut-out: 1140x480
drain: 3½”
pre-installed gasket
Version
6)
Ref.
Technical Drawing
1978 961 rh
1978 962 lh
Picture shows lh version
Accessories: L4 M N2 R T4 (page 66)
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60 (80)T (ref. page 42)
AISI 316 brushed
dimensions: 983x513
2 b.: 362,5x400 + 150x300
cut-out: 950x480
drain: 3½”
pre-installed gasket
6)
1977 961 rh
1977 962 lh
Picture shows lh version
Accessories: L4 M N2 Q R T4 (page 66)
Second and third tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 80/(90)T (ref. page 42)
AISI 316 brushed
dimensions: 873x513
2 bowls: 362,5x400
cut-out: 840x480
drain: 3½”
pre-installed gasket
6)
1976 960
Accessories: L4 M N2 R T4 (page 66)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
65
Marine
Features
Version
AISI 316 brushed
dimensions: 873x513
1 bowl: 362,5x400
cut-out: 840x480
drain: 3½”
pre-installed gasket
Cabinet 45
6)
Ref.
Technical Drawing
1975 961 rh
1975 962 lh
Picture shows lh version
Accessories: L4 M N2 R T4
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Foster Marine is the new range of sinks and cooker hobs specially designed
for marine environments. Marine is made of AISI316 stainless steel, an alloy
with high content of nickel and molibden ensuring outstanding stainless
properties. AISI316 stainless steel is a material of a higher class, that grants
three times as much resistance to the effects of salt-rich atmospheres as
the most commonly used AISI304. Marine cooker hob (see page 147).
Special features - Marine sinks are
equipped with pre-installed gasket
that allows a quick and convenient
installation.
accessories
L4
Glass chopping board
23x41 cm
8631 300
N2
HDPE chopping board
27,2x42,5 cm
8657 001
66
M
Sliding chopping
board 30x54
8643 000
Q
White colander
17x32 cm
8151 100
R
St. steel basket
34x40 cm
8611 000
T4
St. steel dishes
holder 25x43 cm
8100 301
KS
KS sinks feature clear-cut, distinctive designs: a handy raised-edge drainer and large, spacious basins edged with an inclined drip-guard that prevents over-spill.
Lorenzo
(8466 000 - pag. 122)
NYC
(8486 0000 - pag. 122)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 1160x500
2 bowls: 340x400
cut-out: 1140x480
drain: 3½”
Cabinet 80
AISI 304 microfoster
dimensions: 1160x500
2 bowls: 340x400
cut-out: 1140x480
drain: 3½”
Picture shows rh version
Version
67'
Ref.
Technical Drawing
2112 061 rh
2112 062 lh
67'
2112 461 rh
microfoster
2112 462 lh
modello integrabile nei top in acciaio inox
Accessories: (page 70)
A L1 L4 L5 M N2 N3 O2 P1 P2 R T2 T4
AISI 304 brushed
dimensions: 970x500
2 bowls: 340x400
1 bowl: 150x300
cut-out: 950x480
drain: 3½”
AISI 304 microfoster
dimensions: 970x500
2 bowls: 340x400
1 bowl: 150x300
cut-out: 950x480
drain: 3½”
Cabinet 100
67'
2173 060
67'
2173 460
microfoster
modello integrabile nei top in acciaio inox
Accessories: (page 70)
A L1 L4 L5 M N2 N3 O2 P1 P2 Q R T2 T4
AISI 304 brushed
dimensions: 970x500
2b: 340x400+150x300
cut-out: 950x480
drain: 3½”
Cabinet 60/(80)T (ref. page 42)
AISI 304 microfoster
dimensions: 970x500
2b: 340x400+150x300
cut-out: 950x480
drain: 3½”
Picture shows rh version
67'
2163 061 rh
2163 062 lh
67'
2163 461 rh
microfoster
2163 462 lh
modello integrabile nei top in acciaio inox
Accessories: (page 70)
A L1 L4 L5 M N2 N3 O2 P1 P2 Q R T2 T4
Second and third tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
67
KS
Features
AISI 304 brushed
dimensions: 860x500
2 bowls: 340x400
cut-out: 840x480
drain: 3½”
Cabinet 80/(90)T (ref. page 42)
AISI 304 microfoster
dimensions: 860x500
2 bowls: 340x400
cut-out: 840x480
drain: 3½”
Version
Ref.
Technical Drawing
67'
2182 060
67'
2182 460
microfoster
modello integrabile nei top in acciaio inox
Accessories: (page 70)
A L1 L4 L5 M N2 N3 O2 P1 P2 R T2 T4
AISI 304 brushed
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
Cabinet 60
AISI 304 microfoster
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
Picture shows rh version
67'
2180 061 rh
2180 062 lh
67'
2180 461 rh
microfoster
2180 462 lh
modello integrabile nei top in acciaio inox
Accessories: (page 70)
E L1 L4 L5 M N2 N3 O2 P1 P2 S T2 T4
AISI 304 brushed
dimensions: 860x500
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
Cabinet 45
AISI 304 microfoster
dimensions: 860x500
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
67'
2181 061 rh
2181 062 lh
67'
2181 461 rh
microfoster
2181 462 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: (page 70)
A L1 L4 L5 M N2 N3 O2 P1 P2 R T2 T4
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 30
AISI 304 brushed
dimensions: 290x500
1 bowl: 180x340
cut-out: 270x480
drain: 3½”
67'
2129 060
modello integrabile nei top in acciaio inox
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
SinK code 2129 060 completes KS Domino cooking
solutions (see page 150)
68
FM
A new range of sinks of pure and essential design. The great skill of Foster in stainless steel processing allows to combine both tight radius and deep bowls, typical of the best welded
sinks, and the sturdyness of the seamless solutions.
NYC
(8486 0000 - pag. 122)
Lorenzo
(8466 000 - pag. 122)
suggested mixer taps
Features
Cabinet 80/(90)T (ref. page 42)
AISI 304 brushed
dimensions: 1160x500
2 bowls: 362,5x400
cut-out: 1140x480
drain: 3½”
AISI 304 microfoster
dimensions: 1160x500
2 bowls: 362,5x400
cut-out: 1140x480
drain: 3½”
Picture shows lh version
Accessories: L4 M N2 R T4 (page 70)
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60/(80)T (ref. page 42)
AISI 304 design
dimensions: 1160x500
2 bowls: 362,5x400
cut-out: 1140x480
drain: 3½”
AISI 304 brushed
dimensions: 970x500
2b: 362,5x400+150x300
cut-out: 950x480
drain: 3½”
AISI 304 microfoster
dimensions: 970x500
2b: 362,5x400+150x300
cut-out: 950x480
drain: 3½”
Picture shows lh version
Accessories: M N2 Q R T4 (page 70)
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 80/(90)T (ref. page 42)
AISI 304 design
dimensions: 970x500
2b: 362,5x400+150x300
cut-out: 950x480
drain: 3½”
AISI 304 brushed
dimensions: 860x500
2 bowls: 362,5x400
cut-out: 840x480
drain: 3½”
AISI 304 microfoster
dimensions: 860x500
2 bowls: 362,5x400
cut-out: 840x480
drain: 3½”
Accessories: L4 M N2 R T4 (page 70)
AISI 304 design
dimensions: 860x500
2 bowls: 362,5x400
cut-out: 840x480
drain: 3½”
Version
67'
Ref.
Technical Drawing
1972 061 rh
1972 062 lh
67'
1972 461 rh
microfoster
1972 462 lh
67'
1972 761 rh
design
67'
1972 762 lh
Second tap hole available
1973 061 rh
1973 062 lh
67'
1973 461 rh
microfoster
1973 462 lh
67'
1973 761 rh
design
1973 762 lh
Second and third tap hole available
67'
1974 060
67'
1974 460
microfoster
67'
1974 760
design
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
69
FM
Features
Version
AISI 304 brushed
dimensions: 860x500
1 bowl: 362,5x400
cut-out: 840x480
drain: 3½”
Cabinet 45
AISI 304 microfoster
dimensions: 860x500
1 bowl: 362,5x400
cut-out: 840x480
drain: 3½”
Picture shows lh version
Accessories: L4 M N2 R T4
Automatic waste fitting: PR PQ PC (page 109)
67'
Ref.
Technical Drawing
1971 061 rh
1971 062 lh
67'
1971 461 rh
microfoster
AISI 304 design
dimensions: 860x500
1 bowl: 362,5x400
cut-out: 840x480
drain: 3½”
1971 462 lh
67'
1971 761 rh
design
1971 762 lh
Second tap hole available
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
19 cm deep and capacious bowls, inserted in a
generous safe-drop profile, for this sturdy and
practical sink.
accessories
A
Chopping board
34x40
8647 000
L5
Glass chopping board
29x54 cm
8633 300
E
Chopping board 45x40
8655 000
M
Sliding chopping
board 30x54
8643 000
L1
L4
Twin chopping board
31,7x42,5 cm
8644 041
Glass chopping board
23x41 cm
8631 300
N2
N3
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
O2
P1
P2
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
Grating kit complete
with ring support and
food collection tray
8159 101
R
St. steel basket
34x40 cm
8611 000
S
St. steel basket 40x40
8612 000
T2
**
**
St. steel dishes
holder 21,4x37,9 cm
8100 303
Q
White colander
17x32 cm
8151 100
T4
St. steel dishes
holder 25x43 cm
8100 301
White basket 40x40
8612 100
70
**To use only with N3 chopping board
F300
The classic design of the 3000 Series is proposed in a new version with slightly less deep bowls and larger radiuses. All the Foster elegance in a product with exceptional value for money.
Beta
(8490 000 - pag. 124)
Luisa
(8482 000 - pag. 122)
suggested mixer taps
Features
Cabinet 90
AISI 304 brushed
dimensions: 1160x500
2 bowls: 362,5x400
cut-out: 1140x480
drain: 3½”
Version
67'
Ref.
Technical Drawing
1354 061 rh
1354 062 lh
modello integrabile nei top in acciaio inox
Picture shows lh version
Accessories: L4 M N2 O2 R T4
Cabinet 60
AISI 304 brushed
dimensions: 970x500
2 b.: 340x400 + 150x300
cut-out: 950x480
drain: 3½”
67'
1353 061 rh
1353 062 lh
modello integrabile nei top in acciaio inox
Picture shows lh version
Accessories: A M N2 O2 Q R T4
Second and third tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 90
AISI 304 brushed
dimensions: 860x500
2 bowls: 362,5x400
cut-out: 840x480
drain: 3½”
67'
1352 060
modello integrabile nei top in acciaio inox
Accessories: L4 M N2 O2 R T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
71
F300
Features
AISI 304 brushed
dimensions: 860x500
1 bowl: 362,5x400
cut-out: 840x480
drain: 3½”
Cabinet 45
Version
67'
Ref.
Technical Drawing
1351 061 rh
1351 062 lh
modello integrabile nei top in acciaio inox
Picture shows lh version
Accessories: L4 M N2 O2 R T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Elegant and functional matching. F300 sink with
refined Elettra hob.
accessories
A
Chopping board
34x40
8647 000
O2
White plastic bowl
27,2x41,4 cm
8153 100
72
L4
Glass chopping board
23x41 cm
8631 300
Q
White colander
17x32 cm
8151 100
M
Sliding chopping
board 30x54
8643 000
R
St. steel basket
34x40 cm
8611 000
N2
HDPE chopping board
27,2x42,5 cm
8657 001
T4
St. steel dishes
holder 25x43 cm
8100 301
Elettra
Linear design and capacious tanks. The new series of sinks completes the Elettra collection in line with the concept of functionality and practicality.
Luisa
(8482 000 - pag. 122)
E
Elettra
(8
(8476 000 - pag. 124)
suggested mixer taps
Features
Cabinet 80/(90)T (ref. page 42)
AISI 304 brushed
dimensions: 1160x500
2 bowls: 341x401
cut-out: 1140x480
drain: 3½”
Version
67'
Ref.
Technical Drawing
5812 061 rh
5812 062 lh
Picture shows lh version
Accessories: A L4 M N2 O2 R T4
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60
AISI 304 brushed
dimensions: 970x500
2b: 341x400 + 150x300
cut-out: 950x480
drain: 3½”
67'
5197 061 rh
5197 062 lh
Picture shows lh version
Accessories: A L4 M N2 O2 Q R T4
Second and third tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 80/(90)T (ref. page 42)
AISI 304 brushed
dimensions: 860x500
2 bowls: 341x401
cut-out: 840x480
drain: 3½”
67'
5886 060
modello integrabile nei top in acciaio inox
Accessories: A L4 M N2 O2 R T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
73
Elettra
Features
AISI 304 brushed
dimensions: 860x500
1 bowl: 341x401
cut-out: 840x480
drain: 3½”
Cabinet 45
Version
67'
Ref.
Technical Drawing
5186 061 rh
5186 062 lh
Picture shows lh version
Only taps with max ø 45 mm
base footprint are installable
Second tap hole available
Accessories: A L4 M N2 O2 R T4
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Large and deep bowls in a really practical and
functional design.
accessories
A
Chopping board
34x40
8647 000
O2
White plastic bowl
27,2x41,4 cm
8153 100
74
L4
Glass chopping board
23x41 cm
8631 300
Q
White colander
17x32 cm
8151 100
M
Sliding chopping
board 30x54
8643 000
R
St. steel basket
34x40 cm
8611 000
N2
HDPE chopping board
27,2x42,5 cm
8657 001
T4
St. steel dishes
holder 25x43 cm
8100 301
Big Bowl
Foster’s strength: the construction of a “single moulded” sink that competes with the design, quality and sturdiness of welded products. The choice is up to you.
Spring
(8472 000 - pag. 118)
Luisa
(8482 000 - pag. 122)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 1160x500
2b: 450x400+275x400
cut-out: 1140x480
drain: 3½”
Cabinet 90
AISI 304 microfoster
dimensions: 1160x500
2b: 450x400+275x400
cut-out: 1140x480
drain: 3½”
Version
67'
Ref.
1512 201 rh
Technical Drawing
External dimensions refer to
standard version
1512 202 lh
67'
1512 401 rh
microfoster
1512 402 lh
Picture shows rh version
AISI 304 brushed
dimensions: 1173x513
2b: 450x400+275x400
Accessories: C E L4 M N2 S T3 T4 (page 77) cut-out: 1140x480
drain: 3½”
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 1160x500
Cabinet 60
1 bowl: 450x400
cut-out: 1140x480
drain: 3½”
the overflow is outside
the bowl
modello integrabile nei top in acciaio inox
6)
1076 061 rh
1076 062 lh
67'
Second and third tap hole available
1513 201 rh
1513 202 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: E L4 M N2 S T4 (page 77)
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 860x500
2b: 450x400+275x400
cut-out: 840x480
drain: 3½”
Cabinet 90
AISI 304 brushed
dimensions: 873x513
2b: 450x400+275x400
cut-out: 840x480
drain: 3½”
67'
1562 001 rh
External dimensions refer to
standard version
1562 002 lh
6)
1072 061 rh
1072 062 lh
Picture shows lh version
Accessories: C
E L4 M N2 S T3 T4 (page 77)
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
75
Big Bowl
Cabinet 60
Features
AISI 304 brushed
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
AISI 304 microfoster
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
Picture shows rh version
Accessories: E L4 M N2 S T4
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60
AISI 304 brushed
dimensions: 873x513
1 bowl: 450x400
cut-out: 840x480
drain: 3½”
AISI 304 brushed
dimensions: 860x500
2b: 275x400+150x300
cut-out: 840x480
drain: 3½”
Version
67'
Ref.
1561 201 rh
Technical Drawing
External dimensions refer to
standard version
1561 202 lh
67'
1561 401 rh
microfoster
6)
1561 402 lh
1071 061 rh
1071 062 lh
67'
Second tap hole available
1361 261 rh
1361 262 lh
modello integrabile nei top in acciaio inox
Picture shows rh version
Accessories: C Q T3 T4
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60
Second tap hole available
AISI 304 brushed
dimensions: 590x500
1 bowl: 450x400
cut-out: 570x480
drain: 3½”
67'
1511 001 rh
1511 002 lh
Picture shows lh version
Accessories: E L4 N2 S T4
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60
Second tap hole available
AISI 304 brushed
dimensions: 590x500
2b: 275x400+150x300
cut-out: 570x480
drain: 3½”
67'
1510 061 rh
1510 062 lh
modello integrabile nei top in acciaio inox
Picture shows lh version
Accessories: C Q T3 T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
The main feature of the Big Bowl sinks is the large
45x40 cm bowl. A practical and versatile solution.
76
Big Bowl Soft
Features
Version
AISI 304 brushed
dimensions: 860x500
2b: 450x400+275x400
cut-out: 840x480 R 135
drain: 3½”
Cabinet 90
AISI 304 brushed
dimensions: 873x513
2b: 450x400+275x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500 R 145
drain: 3½”
Picture shows rh version
Accessories: C E L4 N2 S T3 T4
Standard version only: M
67'
Ref.
Technical Drawing
External dimensions refer to
standard version
1662 001 rh
1662 002 lh
)7
1062 061 rh
FTS
1062 062 lh
modello integrabile nei top in acciaio inox
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 860x500
1 bowl: 450x400
cut-out: 840x480 R 135
drain: 3½”
Cabinet 60
AISI 304 brushed
dimensions: 873x513
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 860x500 R 145
drain: 3½”
Picture shows rh version
Accessories: E L4 N2 S T4
Standard version only: M
67'
External dimensions refer to
standard version
1661 201 rh
1661 202 lh
)7
1061 261 rh
FTS
1061 262 lh
modello integrabile nei top in acciaio inox
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 550x500
1 bowl: 450x400
cut-out: 530x480 R 135
drain: 3½”
Cabinet 60
AISI 304 brushed
dimensions: 563x513
1 bowl: 450x400
cut-out:
flush-mount (FT): web site
up-mount (FTS): 550x500 R 145
drain: 3½”
External dimensions refer to
standard version
67'
1611 060
)7
1115 060
FTS
modello integrabile nei top in acciaio inox
Accessories: E L4 N2 S T4
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
C
Chopping board 29x40
8653 000
E
Chopping board 45x40
8655 000
Q
White colander
17x32 cm
8151 100
L4
Glass chopping board
23x41 cm
8631 300
S
St. steel basket 40x40
8612 000
M
Sliding chopping
board 30x54
8643 000
N2
HDPE chopping board
27,2x42,5 cm
8657 001
T3
T4
St. steel dishes
holder 28x40 cm
8100 280
St. steel dishes
holder 25x43 cm
8100 301
White basket 40x40
8612 100
77
Moon
A new sleek design blends effortlessly into the reliability of a FOSTER classic. Sinks without any welding, of great strength, with spacious bowls and a practical drainer area.
Features
Cabinet 80/(90)T (ref. page 42)
NEW
AISI 304 brushed
dimensions: 1160x500
2 bowls: 360x400
cut-out: 1140x480
drain: 3½”
Version
67'
Ref.
Technical Drawing
1284 001 rh
1284 002 lh
model weldable into st. steel worktops
Picture shows lh version
Second tap hole available
Accessories: L4 M N2 R T4
Cabinet 60/(80)T (ref. page 42)
NEW
AISI 304 brushed
dimensions: 970x500
2 b: 360x400+150x300
cut-out: 950x480
drain: 3½”
67'
1283 001 rh
1283 002 lh
model weldable into st. steel worktops
Picture shows lh version
Second tap hole available
Accessories: M N2 Q R T4
Cabinet 80/(90)T (ref. page 42)
NEW
AISI 304 brushed
dimensions: 860x500
2 bowls: 360x400
cut-out: 840x480
drain: 3½”
67'
1962 060
model weldable into st. steel worktops
Accessories: L4 M N2 R T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
78
Moon
Features
Cabinet 45
NEW
Version
AISI 304 brushed
dimensions: 860x500
1 bowl: 360x400
cut-out: 840x480
drain: 3½”
67'
Ref.
Technical Drawing
1281 001 rh
1281 002 lh
model weldable into st. steel worktops
Picture shows lh version
Second tap hole available
Accessories: L4 M N2 R T4
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Moon is the last-born in the Foster one-piece sinks
ranges. It offers all the sturdiness typical of the sinks
without welding, an elegant design, the practicality
of deep and spacious bowls, all of which at an
exceptional pricequality ratio.
accessories
L4
Glass chopping board
23x41 cm
8631 300
N2
HDPE chopping board
27,2x42,5 cm
8657 001
M
Sliding chopping
board
30x54
8643 000
Q
White colander
17x32 cm
8151 100
R
St. steel basket
34x40 cm
8611 000
T4
St. steel dishes
holder 25x43 cm
8100 301
79
Uragano
A name that evokes the large amount of water that this product is capable of housing. The ideal choice for those who prefer freedom of movement.
Uragano is almost a metre large.
Magnum
(8484 000 - pag. 117)
Geo
(8454 000 - pag. 118)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 970x500
1 bowl: 910x440
cut-out: 950x480
drain: 3½”
Cabinet 100
AISI 304 brushed
dimensions: 983x513
1 bowl: 910x440
cut-out: 950x480
drain: 3½”
Version
67'
Ref.
1555 600
1555 609
accessory kit
included
6)
1054 600
1054 609
accessory kit
included
Accessories: I L2 O Q T U V Z (page 82)
AISI 304 brushed
dimensions: 983x513
1 bowl: 910x440
cut-out:
flush-mount (FT): web site
up-mount (FTS): 970x500 R 145
drain: 3½”
Cabinet 100
)7
FTS
1055 600
1055 609
accessory kit
included
modello integrabile nei top in acciaio inox
Accessories: I L2 O Q T U V Z (page 82)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Uragano accessory kit
I
Chopping board
37x46 cm
8659 112
O
White plastic bowl
36x30 cm
8152 100
80
V
St. steel bowl holder
37x45 cm
8100 112
Q
White colander
17x32 cm
8151 100
Discover the great functionality
of the big Uragano bowl.
Now available also in the
accessorized version, including
the practical kit described
aside.
The full range of matching
accessories is presented in
the following pages.
Technical Drawing
External dimensions refer to
standard version
Tornado
A greater feeling of space with 80 cm. This is the essential quality of a Tornado sink, thanks to the shape and capacity of its bowl.
Lorenzo
(8466 000 - pag. 122)
Gamma
(8483 001 - pag. 121)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 790x500
1 bowl: 730x440
cut-out: 770x480
drain: automatic 3½”
Cabinet 80
AISI 304 brushed
dimensions: 803x513
1 bowl: 730x440
cut-out: 770x480
drain: automatic 3½”
Accessories: H
Version
Ref.
External dimensions refer to
standard version
67'
1579 660
6)
1078 660
I L2 O Q T U Z (page 82)
Third tap hole available
AISI 304 brushed
dimensions: 790x500
1 bowl: 730x440
cut-out: 770x480 R 135
drain: automatic 3½”
Cabinet 80
Technical Drawing
AISI 304 brushed
dimensions: 803x513
1 bowl: 730x440
cut-out:
flush-mount (FT): web site
up-mount (FTS): 790x500 R 145
drain: automatic 3½”
External dimensions refer to
standard version
67'
1679 660
)7
1079 660
FTS
modello integrabile nei top in acciaio inox
Accessories: H
I L2 O Q T U Z (page 82)
Third tap hole available
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
81
7” Uragano and Tornado
Features
AISI 304 brushed
dimensions: 970x500
1 bowl: 910x440
cut-out: 950x480
drain: 7”
Cabinet 100
Version
Ref.
Technical Drawing
67'
1555 070
modello integrabile nei top in acciaio inox
Accessories: I L2 O Q T U V Z
AISI 304 brushed
dimensions: 790x500
1 bowl: 730x440
cut-out: 770x480
drain: 7”
Cabinet 80
67'
1579 670
modello integrabile nei top in acciaio inox
Accessories: H
I L2 O Q T U Z
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), 7” waste fitting/siphon, overflow. Packing: single carton box.
The large bowls of Uragano and Tornado are
particularly suited to the drain with 7" hole: an
original solution, very practical thanks to to the large
stainless steel collecting basket.
accessories
A
Chopping board
34x40 cm
8647 000
H
Chopping board
37x30
8659 111
I
Chopping board
37x46 cm
8659 112
L2
L4
N2
Twin chopping
board
37x46 cm
8644 003
Glass chopping
board
23x41 cm
8631 300
HDPE chopping
board
27,2x42,5 cm
8657 001
Q
White colander
17x32 cm
8151 100
R
St. steel basket
34x40 cm
8611 000
S
St. steel basket 40x40
8612 000
O
**
White plastic bowl
36x30 cm
8152 100
T
St. steel dishes
holder 25x35 cm
8100 154
O2
White plastic bowl
27,2x41,4 cm
8153 100
T1
St. steel dishes
holder 25x42,5 cm
8100 201
W. basket 40x40
8612 100
T4
St. steel dishes
holder 25x43 cm
8100 301
82
U
St. steel dishes
holder 25x45 cm
8100 111
V
St. steel bowl
holder
37x45 cm
8100 112
W
St. steel dishes
holder inox
8100 331
Z
*
St. steel colander
25x36 cm
8154 000
*to use only with L2 chopping board **to use only with V bowl holder
Angolare
New bowls with tight-radius curves, redesigned draining board, the possibility of having both sinks on one side or with the draining board in the middle.
The Foster offer for corner sinks has never been this wide.
S1
S1000
- Z66
(8448 500 - pag. 125)
(8
Camillo
(8467 000 - pag. 118)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 830x830
2 bowls: 340x400
cut-out: see web site
drain: 3½”
Cabinet 90x90
Version
Ref.
Technical Drawing
67'
3307 060
modello integrabile nei top in acciaio inox
Accessories: A N2 O2 R T4 W (page 82)
AISI 304 brushed
dimensions: 830x830
2b: 400x400+180x340
cut-out: see web site
drain:
3½” + 1¼” on drainer
Cabinet 90 (linear)
67'
3306 060
modello integrabile nei top in acciaio inox
Accessories: L4 N2 O2 S T1 (page 82)
Second tap hole available
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
dimensions: 830x830
2b: 340x400+233x335
cut-out: see web site
drain:
3½” + 1¼” on drainer
Cabinet 90 (linear)
67'
3308 060
modello integrabile nei top in acciaio inox
Accessories: A N2 O2 R
T T4 Z (page 82)
Automatic waste fitting: PR PQ PC (page 109)
Second tap hole available
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
83
Diamant
A new proposal with an original design which can be fitted to angle, half angle or linear solutions. Available in two versions: with large+small bowl, or with a large 50 cm single bowl.
F20 - Basso
F2000
(8459 000 - pag. 124)
(84
Play
P
(8487
(
000 - pag. 117)
suggested mixer taps
Features
AISI 304 brushed
dimensions: 988x508
2b: 340x400+150x300
cut-out: see web site
drain: automatic 3½”
Cabinet 60
Version
Ref.
Technical Drawing
7mm
3312 062
Accessories: A L4 N2 O2 Q R T4
AISI 304 brushed
dimensions: 988x508
1 bowl: 504x400
cut-out: see web site
drain: 3½”
Cabinet 80
7mm
3321 060
Accessories: G L4 N2 O2 S
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
R p. 85
A
Chopping board
34x40 cm
8647 000
O2
White plastic bowl
41,4x27,2 cm
8153 100
G
Chopping board
40x40 cm
8646 000
Q
White colander
17x32 cm
8151 100
L4
N2
Glass chopping board
23x41 cm
8631 300
Chopping board HDPE
27,2x42,5 cm
8657 001
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
84
T4
St. steel dishes holder
25x43 cm
8100 301
Circolari
The round solutions offer 5 models that differ for the size of the waste – either 3.5” or 2” – and for the installation system: standard-edge, flush-mount or undermount.
S1000 - Z65
(8449 500 - pag. 125)
25)
F2000 alto
(8558 000 - pag. 123)
suggested mixer taps
Features
AISI 304 brushed
dimensions: Ø 440
1 bowl: Ø 380
cut-out: Ø 420
drain: 2”
Cabinet 45
Version
Ref.
Technical Drawing
67'
1010 000
modello integrabile nei top in acciaio inox
Accessories: J
AISI 304 brushed
dimensions: Ø 440
1 bowl: Ø 380
cut-out: Ø 420
drain: 3½”
Cabinet 45
AISI 304 brushed
dimensions: Ø 420
1 bowl: Ø 380
cut-out:
flush-mount (FT): web site
up-mount (FTS): Ø 407
drain: 3½”
67'
1010 060
)7
1110 060
FTS
modello integrabile nei top in acciaio inox
Standard
Flush-mount
Accessories: J
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
J
Chopping board
Ø40 cm
8651 000
M
Sliding chopping
board 30x54
8643 000
N2
HDPE chopping board
27,2x42,5 cm
8657 001
R
St. steel basket
34x40 cm
8611 000
T4
St. steel dishes
holder 25x43 cm
8100 301
85
S1000
AISI 304 (18/10) stainless steel as for all the other sinks, the availability of different finishes, functional accessories in addition to the Foster guarantee.
Lorenzo
(8466 000 - pag. 122)
S1000 - RO
(8443 002 - pag. 126)
suggested mixer taps
Features
Cabinet 80/(90)T (ref. page 42)
AISI 304 brushed
dimensions: 1160x500
2 bowls: 360x400
cut-out: 1140x480
drain: 3½”
AISI 304 microfoster
dimensions: 1160x500
2 bowls: 360x400
cut-out: 1140x480
drain: 3½”
Version
67'
Ref.
Technical Drawing
1812 161 rh
1812 162 lh
67'
1812 461 rh
microfoster
1812 462 lh
Picture shows lh version
Second tap hole available
Accessories: M N2 R T4 (page 85)
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60/(80)T (ref. page 42)
AISI 304 brushed
dimensions: 970x500
2b: 340x400+170x300
cut-out: 950x480
drain: 3½”
AISI 304 microfoster
dimensions: 970x500
2b: 340x400+170x300
cut-out: 950x480
drain: 3½”
67'
1197 161 rh
1197 162 lh
67'
1197 461 rh
microfoster
1197 462 lh
Picture shows lh version
Second tap hole available
Accessories: M N2 R T4 (page 85)
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 45
AISI 304 brushed
dimensions: 860x500
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
AISI 304 microfoster
dimensions: 860x500
1 bowl: 340x400
cut-out: 840x480
drain: 3½”
67'
1186 161 rh
1186 162 lh
67'
1186 461 rh
microfoster
1186 462 lh
Picture shows lh version
Accessories: M N2 R T4 (page 85)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
86
S1000
Cabinet 80/(90)T (ref. page 42)
Features
AISI 304 brushed
dimensions: 860x500
2 bowls: 360x400
cut-out: 840x480
drain: 3½”
AISI 304 brushed
dimensions: 860x500
2 bowls: 360x400
cut-out: 840x480
drain: 3½”
Version
Ref.
Technical Drawing
67'
1886 160
67'
1886 460
microfoster
Accessories: M N2 R T4 (page 85)
Cabinet 80
AISI 304 brushed
dimensions: 790x500
2 bowls: 360x400
cut-out: 770x480
drain: 3½”
67'
1279 060
Accessories: M N2 R T4 (page 85)
Cabinet 45
AISI 304 brushed
dimensions: 790x500
1 bowl: 340x400
cut-out: 770x480
drain: 3½”
67'
1179 061 rh
1179 062 lh
Picture shows lh version
Accessories: M N2 R T4 (page 85)
Cabinet 45
AISI 304 brushed
dimensions: 440x500
1 bowl: 360x360
cut-out: 420x480
drain: 2”
AISI 304 brushed
dimensions: 440x500
1 bowl: 360x360
cut-out: 420x480
drain: 3½”
67'
1144 001 rh
1144 002 lh
67'
1144 061 rh
1144 062 lh
Picture shows lh version
Version DX means right faucet hole, SX left faucet hole
Cabinet 30
AISI 304 brushed
dimensions: 290x500
1 bowl: 240x340
cut-out: 270x480
drain: 2”
67'
1129 000
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
87
Undermount sinks
Stainless steel is always fashionable, and it blends perfectly in any worktop, be it granite, quartz or solid-surface. The large range of Foster
undermount sinks, from those with “classical” design and wide radius to the minimalist ones with squared corners, makes it possible to choose
according to everyone’s specific needs.
88
GK p. 90
Triplo invaso p. 103
Quadra p. 91
S3000 p. 104
Quadra R10 p. 93
Big Bowl p. 106
S4000 p. 95
Tornado p. 107
KE p. 97
Elettra p. 108
KE Gun Metal p. 101
Circolari p. 108
Notice for installation
bowl with folded edge
Installation procedure with nut, bolt and
bracket for bowls with folded edge.
bowl with flat edge
Installation procedure with nut, bolt and
bracket for bowls with flat edge.
Installation procedure with nut and bolt for
bowls with edge provided with fixing holes
(Quadra series).
All models are supplied with installation kit (nut, bolt and bracket). The alternative use of different screws or bolts is left to the discretion of the installer.
Worktop drilling
The drawing with instruction to drill the worktop properly is included in the packing.
The holes’ dimension is to be considered merely as the manufacturer’s suggestion. Small adjustments can
be adopted on the basis of need or preference of the user, as per the attached schemes.
Compatibility of accessories
Negative drilling
(invisible edge)
NOTICE: the compatibility of the accessories is assured only if the manufacturer’s drilling instructions are
respected (drilling at bowl’s edge).
Drilling at bowl’s edge
Foster offers its assistance for drilling the worktop properly with dwg drawings, now available
for downloading on our website www.fosterspa.com on the product specifications page.
Positive drilling
(visible steel edge)
Standard fitting
Installation with
recess on the basin
Cabinets
The cabinets’ specifications shown for each model are referred only to the bowls’ overall dimensions,
and do not take into account the fixing systems. Different overall dimensions correspond to different
installation methods. Moreover, these are negligible if kept within the thickness of the worktop, by
creating a proper nook.
It is therefore recommended to check beforehand for possible interferences.
Installation with
recess on the worktop
89
GK
Features
Version
AISI 304 brushed
bowl: 73x40 cm
dimensions: 860x470
cut-out: see web site
drain: SPACE 3½”
Cabinet 90
Ref.
Technical Drawing
67
1401 800
Accessories: M4 N4 T2 P2 Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 45x40 cm
dimensions: 580x470
cut-out: see web site
drain: SPACE 3½”
Cabinet 60
67
1403 800
Accessories: M4 N4 T2 P2 Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 63x40 cm
dimensions: 740x450
cut-out: see web site
drain: SPACE 3½”
Cabinet 80
AISI 304 vintage
bowl: 63x40 cm
dimensions: 740x450
cut-out: see web site
drain: SPACE 3½”
67
1404 800
67
GE
TA
VIN
1404 880
Accessories: M4 N4
T2 P2 Z2 to be used only with chopping board N4
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 37x40 cm
dimensions: 480x450
cut-out: see web site
drain: SPACE 3½”
Cabinet 60
67
1405 800
Accessories: M4 N4
T2 P2 Z2 to be used only with chopping board N4
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
90
M4
N4
T2
P2
Z2
PA
Iroko chopping board
8656 001
HDPE Twin chopping board
8644 100
St. steel dishes holder
25x42,5 cm
8100 303
Grating kit complete with ring
support and food collection bowl
8159 101
St. steel perforated pan
8151 000
Automatic waste fitting
8407 108
Quadra
Cabinet 120
Features
AISI 304 brushed
bowl: 47x40 cm
dimensioni:1050x450
cut-out: see web site
drain: 3½”
Version
Ref.
Technical Drawing
67
1210 850
Accessories: (page 92)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 90
AISI 304 brushed
bowl: 80x40 cm
dimensions: 850x505
cut-out: see web site
drain: 3½”
67
1218 850
Accessories: (page 92)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: (2x) 34x40 cm
dimensions: 785x460
cut-out: see web site
drain: 3½”
67
1208 850
Accessories: (page 92)
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: 71x40 cm
dimensions: 760x500
cut-out: see web site
drain: 3½”
67
1217 850
Accessories: (page 92)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 50x40 cm
dimensions: 550x505
cut-out: see web site
drain: 3½”
67
1215 850
Accessories: (page 92)
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
91
Quadra
Features
Version
AISI 304 brushed
bowl: 40x40 cm
dimensions: 450x505
cut-out: see web site
drain: 3½”
Cabinet 45
Ref.
Technical Drawing
67
1214 850
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 27x40 cm
dimensions: 320x505
cut-out: see web site
drain: 3½”
Cabinet 40
67
1202 850
Accessories: L4 N2 O2 T1
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 80x40 cm
dimensions: 850x505
cut-out: see web site
drain: 7”
Quadra 7"
Cabinet 90
Accessories: L3 L4 N2 O2 S
67
1218 897
T T1 Z
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1
L3
L4
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
92
R
S
St. steel basket
34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes
holder 25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes
holder 25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
Quadra R10
The functionality of a 10 mm radius on all the edges matches the essential design of Quadra sinks, made even more exclusive by the new rectangular overflow.
Tre Alto
(8468 000 - pag. 119)
Geo
(8454 000 - pag. 118)
suggested mixer taps
Features
Cabinet 80
AISI 304 brushed
bowl: 71x40 cm
dimensions: 736x426
cut-out: see web site
drain: 3½”
Version
Ref.
Technical Drawing
67
2307 890
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 50x40 cm
dimensions: 526x426
cut-out: see web site
drain: 3½”
67
2305 890
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 45x40 cm
dimensions: 476x426
cut-out: see web site
drain: 3½”
67
2304 890
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T1 T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
93
Quadra R10
Features
Version
AISI 304 brushed
bowl: 38x40 cm
dimensions: 406x426
cut-out: see web site
drain: 3½”
Cabinet 45
Ref.
Technical Drawing
67
2303 890
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T1 T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Detail of the elegant perimetric overflow that
enhance the design of the sink.
accessories
L1
L3
L4
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
94
R
S
St. steel basket
34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes
holder 25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes
holder 25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
S4000 - R25
Whatever your type of worktop, a stainless steel flush-mount Foster sink will always guarantee hygiene, quality and durability over time.
NEW
Perimetric overflow
Fly
(8494 000 - p. 121)
Spring
(8472 000 - pag. 118)
suggested mixer taps
Features
Cabinet 80
AISI 304 brushed
bowl: 71x40 cm
dimensions: 750x440
cut-out: see web site
drain: 3½”
Version
Ref.
67
1266 850
Technical Drawing
R2.5
R25
710
750
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 53x40 cm
dimensions: 580x450
cut-out: see web site
drain: 3½”
67
1265 850
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 45x40 cm
dimensions: 490x440
cut-out: see web site
drain: 3½”
67
1263 850
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
95
S4000 - R25
Features
Version
AISI 304 brushed
bowl: 34x40 cm
dimensions: 380x440
cut-out: see web site
drain: 3½”
Cabinet 40
Ref.
Technical Drawing
67
1262 850
Accessories: L4 N2 O2 R
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 18x34 cm
dimensions: 220x380
cut-out: see web site
drain: 3½”
Cabinet 30
67
1260 850
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1
L3
L4
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
96
R
S
St. steel basket
34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes
holder 25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes
holder 25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
KE - R15
A comprehensive collection of one-bowl and two-bowl solutions where you will surely find the perfect sink for your needs.
NEW
Perimetric overflow
Camillo
(8467 000 - pag. 118)
Lorenzo
(8466 000 - pag. 122)
suggested mixer taps
Features
Cabinet 100
AISI 304 brushed
bowl: 45x40/40x40 cm
dimensions: 930x450
cut-out: see web site
drain: 3½
Version
Ref.
Technical Drawing
67
2207 850
Accessories:
L1 L3 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 90
AISI 304 brushed
bowl: 40x40/34x40 cm
dimensions: 820x450
cut-out: see web site
drain: 3½
67
2206 850
Accessories:
L1 L3 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: 45x40/27x40 cm
dimensions: 800x450
cut-out: see web site
drain: 3½
67
2205 850
Accessories:
L1 L3 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
97
KE - R15
Cabinet 80
Features
AISI 304 brushed
bowl: 50x40/18x40 cm
dimensions: 760x450
cut-out: see web site
drain: 3½
Version
Ref.
67
2204 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: (2x) 34x40 cm
dimensions: 760x450
cut-out: see web site
drain: 3½
67
2203 850
Accessories: (page 98)
L1 L4 N2 N3 O2 P1 P2 R T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: 40x40/18x40 cm
dimensions: 660x450
cut-out: see web site
drain: 3½
67
2202 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 34x40/18x40 cm
dimensions: 585x440
cut-out: see web site
drain: 3½
67
2201 851 rh
2201 852 lh
Picture shows rh version
Accessories: (page 98)
L1 L4 N2 N3 O2 P1 P2 R T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 80
AISI 304 brushed
bowl: 71x40 cm
dimensions: 750x440
cut-out: see web site
drain: 3½
67
2157 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
98
Technical Drawing
KE - R15
Features
Cabinet 60
AISI 304 brushed
bowl: 50x40 cm
dimensions: 544x444
cut-out: see web site
drain: 3½
Version
Ref.
Technical Drawing
67
2155 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
AISI 304 brushed
bowl: 45x40 cm
dimensions: 494x444
cut-out: see web site
drain: 3½
67
2154 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 45
AISI 304 brushed
bowl: 40x40 cm
dimensions: 440x440
cut-out: see web site
drain: 3½
67
2156 850
Accessories: (page 98)
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 40
AISI 304 brushed
bowl: 34x40 cm
dimensions: 380x440
cut-out: see web site
drain: 3½
67
2153 850
Accessories: (page 98)
L1 L4 N2 N3 O2 P1 P2 R T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 40
AISI 304 brushed
bowl: 27x40 cm
dimensions: 310x440
cut-out: see web site
drain: 3½
67
2152 850
Accessories: L4 N2 (page 98)
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
99
KE - R15
Features
Version
AISI 304 brushed
bowl: 18x40 cm
dimensions: 222x442
cut-out: see web site
drain: 3½
Cabinet 30
Ref.
Technical Drawing
67
2151 850
Automatic waste fitting: PA PE PM (page 109)
AISI 304 brushed
bowl: 18x34 cm
dimensions: 220x380
cut-out: see web site
drain: 3½
Cabinet 30
67
2150 850
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1
L3
L4
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
100
R
S
St. steel basket
34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes
holder 25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes
holder 25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
KE Gun Metal
NEW
Perimetric overflow
Gun Metal is a new finish, obtained thanks to a special surface treatment (Phisical Vapor Deposition) that gives to AISI 304 stainless steel the fine
dark color and a subtle sheen in addition to very high physical and mechanical characteristics.
In particular, the treatment gives the steel a higher resistance to corrosion; the increase of surface hardness, and therefore a greater resistance to
scratches; the reduction of surface friction and an improved water flow; a higher temperature resistance.
Features
Cabinet 80
NEW
AISI 304 Gun Metal
bowl: 71x40 cm
dimensions: 750x440
cut-out: see web site
drain: 3½
Version
Ref.
Technical Drawing
67
2157 856
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 60
NEW
AISI 304 Gun Metal
bowl: 50x40 cm
dimensions: 544x444
cut-out: see web site
drain: 3½
67
2155 856
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
101
KE Gun Metal
Features
Cabinet 45
Version
AISI 304 Gun Metal
bowl: 40x40 cm
dimensions: 440x440
cut-out: see web site
drain: 3½
NEW
Ref.
Technical Drawing
67
2156 856
Accessories:
L1 L3 L4 N2 N3 O2 P1 P2 S T T2 Z Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 40
NEW
AISI 304 Gun Metal
bowl: 34x40 cm
dimensions: 380x440
cut-out: see web site
drain: 3½
67
2153 856
Accessories:
L1 L4 N2 N3 O2 P1 P2 R T2 Z2
Automatic waste fitting: PA PE PM (page 109)
Cabinet 30
AISI 304 Gun Metal
bowl: 18x40 cm
dimensions: 222x442
cut-out: see web site
drain: 3½
NEW
67
2151 856
Automatic waste fitting: PA PE PM (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
L1
L3
L4
Twin chopping board
31,7x42,5 cm
8644 041
Twin chopping board
41x41 cm
8644 004
Glass chopping board
23x41 cm
8631 300
N2
N3
O2
P1
HDPE chopping board
27,2x42,5 cm
8657 001
HDPE Twin chopping
board
31,7x42,5 cm
8644 101
White plastic bowl
27,2x41,4 cm
8153 100
Chopping board
with stainless steel
colander kit
8644 042
P2
**
Grating kit complete
with ring support and
food collection tray
8159 101
102
R
S
St. steel basket
34x40 cm
8611 000
T
St. steel basket 40x40
8612 000
*
St. steel dishes
holder 25x35 cm
8100 154
White basket 40x40
8612 100
T1
T2
St. steel dishes
holder 25x42,5 cm
8100 201
St. steel dishes
holder 21,4x37,9 cm
8100 303
**
Z
*
St. steel colander
25x36 cm
8154 000
Z2
**
St. steel perforated pan
21,5x38 cm
8151 000
*To use only with L3 chopping board **To use only with N3 chopping board
Triplo Invaso
Features
Version
AISI 304 brushed
bowl: 71x40 cm
dimensions: 860x540
cut-out: see web site
drain:
automatic SPACE 3½”
Cabinet 90
Ref.
Technical Drawing
67
1490 860
Accessories: L4 M2 M3 O2 S U2
AISI 304 brushed
bowls: 50x40/23x34 cm
dimensions: 860x540
cut-out: see web site
drain: automatic 3½”
Cabinet 90
67
1488 861 rh
1488 862 lh
Picture shows lh version
Accessories: M2 M3 N2 O2 S U2 T4 Z
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
The undermount solution exalts the particular
feature of Triplo Invaso sink which is able to contain
different sliding accessories.
accessories
M2
M3
N2
O2
Chopping board 28x48
8643 115
Sliding chopping
board 28x48
8643 116
HDPE chopping board
27,2x42,5 cm
8657 001
White plastic bowl
27,2x41,4 cm
8153 100
S
St. steel basket 40x40
8612 000
U2
St. steel dishes
holder 23x47
8100 115
Z
St. steel colander
25x36 cm
8154 000
T4
St. steel dishes
holder 25x43 cm
8100 301
White basket 40x40
8612 100
103
S3000
Features
Cabinet 60
AISI 304 brushed
bowl: 50x40 cm
dimensions: 539x436
cut-out: see web site
drain: 3½”
Version
67
Ref.
1116 861 rh
1116 862 lh
Picture shows rh version
Accessories: L4 N2 O2 S
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 45
AISI 304 brushed
bowl: 40x40 cm
dimensions: 441x441
cut-out: see web site
drain: 3½”
67
1114 861 rh
1114 862 lh
Picture shows rh version
Accessories: L4 N2 O2 S
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 40
AISI 304 brushed
bowl: 34x40 cm
dimensions: 381x441
cut-out: see web site
drain: 3½”
67
1117 861 rh
1117 862 lh
Picture shows rh version
Accessories: A L4 N2 O2 R
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 80
AISI 304 brushed
bowl: (2x) 34x40 cm
dimensions: 761x446
cut-out: see web site
drain: 3½”
67
1302 860
Accessories: A L4 N2 O2 R
Automatic waste fitting: PR PQ PC (page 109)
Cabinet 60
AISI 304 brushed
bowl: 34x40/15x30 cm
dimensions: 580x460
cut-out: see web site
drain: 3½”
67
1309 861 rh
1309 862 lh
Picture shows rh version
Accessories: A N2 O2 Q R
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
104 For rh/lh version on mean bowl with drain on righ/left side.
Technical Drawing
S3000
Features
Version
AISI 304 brushed
bowl: 34x40/15x30 cm
dimensions: 580x460
cut-out: see web site
drain: 3½”
Cabinet 60
67
Ref.
Technical Drawing
1308 861 rh
1308 862 lh
Picture shows rh version
Accessories: A N2 O2 Q R
Automatic waste fitting: PR PQ PC (page 109)
67
1307 860
180
AISI 304 brushed
bowl: 34x40 cm
dimensions: 377x437
cut-out: see web site
drain: 3½”
Cabinet 40
Accessories: A N2 O2 R
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
A
Chopping board
34x40
8647 000
O2
White plastic bowl
27,2x41,4 cm
8153 100
L4
N2
Glass chopping board
23x41 cm
8631 300
HDPE chopping board
27,2x42,5 cm
8657 001
Q
White colander
17x32 cm
8151 100
R
St. steel basket
34x40 cm
8611 000
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
105
Big Bowl
Features
AISI 304 brushed
bowl: 45x40 cm
dimensions: 475x425
cut-out: see web site
drain: 3½”
Cabinet 60
Version
Ref.
Technical Drawing
67
1811 050
Accessories: S
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
bowl: 15x30 cm
dimensions: 170x320
cut-out: see web site
drain: 3½”
Cabinet 30
67
1300 068
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Big Bowl Soft
Features
AISI 304 brushed
bowl: 45x40 cm
dimensions: 550x500
cut-out: see web site
drain: 3½”
Cabinet 60
Version
Ref.
Technical Drawing
67
1611 068
Accessories: E L4 N2 S
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
E
Chopping board 45x40
8655 000
L4
N2
Glass chopping board
23x41 cm
8631 300
HDPE chopping board
27,2x42,5 cm
8657 001
S
St. steel basket 40x40
8612 000
White basket 40x40
8612 100
106
Tornado
Features
AISI 304 brushed
bowl: 73x44 cm
dimensions: 816x524
cut-out: see web site
drain: automatic 3½”
Cabinet 80
Accessories: H
Version
Ref.
Technical Drawing
67
1679 860
Third tap hole available
I L2 O Q T U Z
The wide radius of the corners in undermount
Tornado sink gives great elegance, which fits both
to classic and to modern kitchens.
accessories
H
Chopping board
37x30
8659 111
Q
White colander
17x32 cm
8151 100
I
L2
Chopping board
37x46 cm
8659 112
T
*
St. steel dishes holder
25x35 cm
8100 154
Twin chopping board
37x46 cm
8644 003
U
St. steel dishes
holder 25x45 cm
8100 111
O
White plastic bowl
36x30 cm
8152 100
Z
St. steel colander
25x36 cm
8154 000
*to use only with L2 chopping board
107
Elettra
Features
AISI 304 brushed
bowls: (2x) 36,25x40 cm
dimensions: 790x430
cut-out: see web site
drain: 3½”
Cabinet 80
Version
Ref.
Technical Drawing
67
1974 860
Accessories: L4 N2 R T4
Automatic waste fitting: PR PQ PC (page 109)
AISI 304 brushed
bowl: 36,25x40 cm
dimensions: 386,5x424
cut-out: see web site
drain: 3½”
Cabinet 45
67
1970 860
Accessories: L4 N2 R T4
Automatic waste fitting: PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
Circolari
Features
AISI 304 brushed
bowl: Ø 38 cm
dimensions: Ø 440
cut-out: see web site
drain: 3½”
Cabinet 45
AISI 304 brushed
bowl: Ø 38 cm
dimensions: Ø 440
cut-out: see web site
drain: 2”
Version
Ref.
Technical Drawing
67
1010 068
67
1010 008
Available for 3½” version only:
PR PQ PC (page 109)
Standard fittings: fixing brackets, gasket (not available for under-mount sinks), waste fitting, overflow and siphon. Packing: single carton box.
accessories
108
L4
N2
Glass chopping board
23x41 cm
8631 300
HDPE chopping board
27,2x42,5 cm
8657 001
R
St. steel basket
34x40 cm
8611 000
T4
St. steel dishes
holder 25x43 cm
8100 301
Complements
Automatic waste fitting
PA
SPACE automatic
waste fittings
"Space" automatic waste fitting with
squared rotating remote control and
with perimeter overflow
Ref.
8407 108
PE
"Space" automatic waste fitting with
round rotating remote control and with
perimeter overflow
Ref.
8407 109
PM
Automatic waste fitting
with squared rotating remote control
and with perimeter overflow
Ref.
PR
90 mm
8407 113
Automatic waste fitting with round
remote control and with overflow
Ref.
8407 100
Automatic waste fitting with round
remote control and without overflow
Ref.
8407 000
PQ
Premium automatic waste waste fitting with
squared remote control and with overflow
Ref.
8407 102
PC
Premium automatic waste fitting
with cubic remote control (push-pull)
and with overflow
Ref.
8407 103
Designed for deep bowls, Space has a very
small encumbrance. In the drawing the side
view of the Space is shown. The height of
the compact drain and the conformation of
the siphon optimize the area under the sink
leaving the necessary space for the needs of
separate waste collecting.
For installation on the worktop all the automatic waste fittings require hole Ø 35 mm.
Notes on compatibility of automatic drains
Automatic drains are compatible with sinks that are supplied
with at least one second hole (in addition to the tap hole).
For many sinks this is not a standard feature but it can be
requested when ordering it. In the sinks drawings standard
holes are shown with a continuous line, while positions
for any holes on request are shown with a dashed line (see
example aside).
For undermount sinks the possibility of insertion of the
automatic drain is always shown because the hole can be
positioned on the worktop. It is also recommended to check
the type of the overflow of the sink in order to choose a
compatible automatic drain.
The drains PA, PE, PM with perimeter overflow are
interchangeable.
The drains PR, PQ, PC with standard overflow are
interchangeable.
Second and third tap hole available
109
Complements
3”½ SPACE Waste fittings
Ref.
8403 008
8403 308
Siphon
Ref.
Description
"Space" waste fitting
without overflow
8410 000
One way siphon
with dishwasher
socket
8415 000
Two ways siphon
with dishwasher
socket
8435 000
Two way “Spazio”
siphon
with dishwasher
socket
8433 000
Three way “Spazio”
siphon
with dishwasher
socket
"Space" waste fitting
with perimetric overflow
3”½ Waste fittings
Ref.
Description
Description
8403 000
Basket waste fitting
without overflow
8403 003
Satin basket waste fitting
without overflow
8403 303
Basket waste fitting
with perimetric overflow
8403 300
Basket waste fitting
with overflow
Premium space-saver siphons
Ref.
8407 200
Ref.
Description
8403 001
LIRA Basket waste fitting
without overflow
LIRA Basket waste fitting
with overflow
2” Waste fittings
8401 000
8411 000
Description
2” waste fitting with
overflow and rubber
plug
2” waste fitting without
overflow and rubber
plug
8402 000
One 2” waste fitting
with overflow and one
2” waste fitting without
overflow
1”¼ Waste fitting
8404 000
8403 309
Two way floor type siphon
with dishwasher socket
Ref.
Overflow fitting 1”¼
for drainer
Description
8669 000
2” rubber plug
8669 001
Strainer plug for 3”½ waste fitting
8669 002
Strainer plug for 3”½ automatic
waste fitting
8669 003
Strainer plug for Premium 3”½ waste fitting
8669 004
Strainer plug for Premium 3”½ automatic
waste fitting
8155 000
Steel-clad plug 18/10 for waste bins
Ref. 8113-8123
8118 006
Connecting pipe - (black)
for waste disposal unit Ref. 8113-8123
8700 007
Silicone gasket for inset sinks
(4 and 8 mm)
8700 062
Silicone gasket for flat-edge
and flush-mount inset sinks
8700 080
Fixing brackets adapter kit (18)
to be used for worktops 20 mm *
Description
7” Waste fitting
Ref.
Description
One way floor type siphon
with dishwasher socket
Various
8405 300
Ref.
8435 002
Premium* two way
"Spazio" siphon
with dishwasher
socket
Floor type siphons
8416 000
Ref.
Premium* one way
"Spazio" siphon
with dishwasher
socket
* we recommend combining Premium siphons and waste fittings
Ref.
8403 301
8435 001
Waste fitting for
Uragano sink
(overflow with flexible
pipe)
3”½ LIRA waste fittings
Description
Description
7” waste fitting with
overflow and st. steel
basket
*Fixing bracket adapter
for worktops 20mm thick.
110
Complements
Waste-disposer unit
Power
Ref.
380 W
8439 112
Foster waste disposers can be installed in all our sinks with 3.5” waste fitting.
Remember to check the dimensions of the sink-waste shredder assembly. Waste
disposers’ compatibility with sinks of other manufacturers is not guaranteed.
327
176
127
18
The waste disposer unit includes a
practical pneumatic control. It can
be installed on the worktop or on
the sink.
182
Radio control for food waste disposers
Ref.
8439 901
The remote control allows easy activation
of the food waste disposer even when a
switch-controlled outlet is not available.
Waste bins
Ref.
TOP CUT-OUT Ø146
OUTER RING Ø160
8113 800
Patty one-way
One-way waste-basket with access from
the worktop (content 20 litres). Lid and paneling in stainless-steel.
20
tot. 20 lt
min 30 cm
Ref.
FLUSH-MOUNT
CUT-OUT
8119 000
Patty top
Waste-basket with access from the
worktop; top-end extractable bag with
stainless-steel cover (content 13 litres)
13
tot. 13 lt
min 30 cm
BUILT-IN CUT-OUT
FLUSH-MOUNT CUT-OUT
111
Complements
Waste bins
NEW
Ref.
8141 000
Smart
Extractable waste bin 16 litres
Minimum cabinet: 30 cm
Outer casing in stainless steel
Automatic lifting of the lid
16
tot. 16 lt
NEW
min 30 cm
Ref.
8142 000
Smart 2
Waste bins System for waste separation
two extractable compartments 16 + 16 litres
Minimum cabinet: 40 cm
(45 cm for automatic opening)
Outer casing in stainless steel
Stainless steel cover usable
as support for accessories
16
16
tot. 32 lt
NEW
min 40 cm
Ref.
8143 000
Split 2
Waste bins System for waste separation
two extractable compartments 12 + 12 litres
Minimum cabinet: 30 cm
Colored lids for easy
compartments recognition
12
12
tot. 24 lt
NEW
min 30 cm
Ref.
8144 000
Split 4
Waste bins System for waste separation
with four bins 15 + 15 + 6 + 6 litres
For coffered cabinets 60 and 90 cm
Modular compartments, colored lids
for easy compartments recognition
15 15
6 6
tot. 42 lt
NEW
min 60 cm
Ref.
8145 000
Split 4 XL
Waste bins System for waste separation
with four bin 35 + 35 + 7,5 + 7,5 litres
For cabinets 60 cm
Full extension slides with soft closing
Fixed metal cover, that become
a practical shelf
35 35
7,5 7,5
tot. 85 lt
112
min 60 cm
Complements
NEW
Ref.
8000 011
Totem4 inox
Extractable socket-holder tower
- 2 Shuko sockets
- 1 ITA 3 poles 10A-16A socket
- 1 USB port for charging
Power cable supplied
With brushed stainless steel cap
Cutout: ø102 mm
Top thickness: max 50 mm
NEW
Ref.
8000 012
Totem3
Extractable socket-holder tower
- 2 Shuko sockets
- 1 ITA 3 poles 10A-16A socket
Power cable supplied
With gray varnished cap
Cutout: ø102 mm
Top thickness: max 50 mm
NEW
Ref.
8000 013
Filo3
Built-in socket-holder slot
- 2 Shuko sockets
- 1 ITA 3 poles 10A-16A socket
Power cable supplied
Cutout: 165x157 mm
113
Mixer Taps
The wide range of Foster mixer taps completes the washing
area according to the sinks stainless steel finish and style.
KS p. 123
Flat p. 120
F2000 alto p. 123
Arsenio p. 120
F2000 basso p. 124
KE p. 120
Beta p. 124
Fly p. 121
Michy p. 124
Gamma p. 121
Elettra p. 124
Camillo p. 118
Gamma 3 vie p. 121
S1000 - Z66 p. 125
Geo p. 118
NYC p. 122
S1000 - Z65 p. 125
1/2 Circle p. 118
Lorenzo p. 122
S1000 - Z85 p. 125
GK p. 116
Spring p. 118
Luisa p. 122
Bite p. 125
Tube p. 117
Flexo p. 119
GF p. 122
Easy p. 126
Play p. 117
Hook p. 119
Omega p. 123
S1000 - RO p. 126
Magnum p. 117
Tre alto p. 119
Omega Plus p. 123
Dispenser p. 126
Q Circle Color p. 1166
Q Circle Plus p. 116
Q Circle p. 116
114
Master p. 119
Features
Foster offers a complete and varied collection of mixer taps both for their aesthetics and functional characteristics, and able to give added
value to the wide range of sinks. The essential and modern design of squared proposals are are laternative to more traditional models with
soft and sinuous aesthetic. The remote controls and dispensers (see Sink Accessories section), reproduce perfectly the design of mixer taps,
creating sets of high aesthetic value.
Quality materials
Foster mixer taps meet the strictest regulations. Certified materials with very low lead content and flexible ceramic cartridges tested at very high pressures provide high
sturdyness, an always smooth and precise working and, most of all, full safety.
Inox AISI 316
Double water flow
Made in AISI 316 stainless steel, which guarantee a
perfect resistance to corrosion and maximum hygiene
and safety, even for food use water.
Several models are equipped with a switch to easily change
the flow from continuous to shower.
Extractable shower head
Tap rotation
The head of the tap is extractable, in order to easily reach
any area of the sink.
All the taps have a wide angle of rotation. Some models even
permit a full 360° rotation.
170°
Strenghtening plate
Foster’s mixer taps are equipped with the strenghtening
plate that offers perfect stability on any sink.
115
Mixer Taps
90°
90°
NEW
NEW
Q Circle Colour
Q Circle Plus
Single-lever mixer tap with rotating barrel and temperature-controlled LED
illuminated water-flow.
Single lever mixer tap with rotating barrel and extractable barrel.
Ref.
Ref.
8469 040
8469 020
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: 55x46 mm
rotating angle: 90°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 50 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: 55x46 mm
rotating angle: 90°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 50 mm
90°
NEW
Q Circle
GK
Single lever mixer tap with rotating barrel.
Single lever faucet with rotating barrel and flexible head.
8469 000
8488 000
chromed
chromed
267
WARNING:
The Cabinet of the GK tap has an irregular form.
Please check the footprint
116
230
79
408
Ø 27
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: 62x46 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
167
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: 55x46 mm
rotating angle: 90°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 50 mm
39
103
Ø8
97
35
48
83 35
198
Ref.
62
46
Ref.
Mixer Taps
NEW
Tube
Single lever mixer tap with rotating barrel and flexible shower. AISI 316 stainless steel.
Ref.
8477 100
satin finish/
black
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 55 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 25 mm
Magnum
Single lever mixer tap with rotating barrel and movable shower.
Ref.
8484 000
Play
Single lever mixer tap with rotating and flexible barrel.
245
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 50 mm
rear encumbrance of
control leverage: 50 mm
190
580
chromed
Ref.
8487 000
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 40 mm
117
Mixer Taps
170°
Camillo
Single lever mixer tap with rotating barrel and extractable shower head.
Geo
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8467 000
8454 000
chromed
chromed
8467 100
satin finish
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 48 mm
rotating angle: 170°
ceramic disc cartridge
max worktop thickness: 40 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 55 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
140°
1/2 Circle
Spring
Single lever mixer tap with rotating barrel. New version with aerator.
Single lever mixer tap with rotating barrel and extractable shower head.
Ref.
Ref.
8480 000
8472 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 40 mm
118
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 45 mm
rotating angle: 140°
ceramic disc cartridge
max worktop thickness: 55 mm
rear encumbrance of control leverage: 80 mm
Mixer Taps
NEW
Flexo
Hook
Single lever mixer tap with rotating barrel and flexible head.
Single lever mixer tap with rotating barrel. AISI 316 stainless steel.
Ref.
Ref.
8456 000
8479 100
chromed
satin finish
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 45 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 15 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 51 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
120°
Tre alto
Master
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8468 000
8493 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 52 mm
rotating angle: 120°
ceramic disc cartridge
max worktop thickness: 40 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: 48x48 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
119
Mixer Taps
Flat
Arsenio
Single-lever mixer tap with rotating, collapsible barrel (Up&Down), with remote control
(double hole needed, maximum distance between the holes 500 mm).
Single-lever mixer tap with rotating, collapsible barrel (Up&Down), with extractable head
and remote control (double hole needed, maximum distance between the holes 500 mm).
Ref.
Ref.
8478 000
8471 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
double hole needed, distance between the holes:
max 500 mm - min. 85 mm
built-in base: ø 52 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
double hole needed, distance between the holes:
max 500 mm - min. 85 mm
built-in base: ø 52 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
KE White
KE
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel and extractable shower head.
Ref.
Ref.
8491 010
8492 000
white /
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
120
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
Mixer Taps
120°
120°
Fly
Fly White
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8494 000
8494 010
chromed
255
240
7°
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 120°
ceramic disc cartridge
max worktop thickness: 40 mm
cold/hot
water
white /
chromed
270
143
220
7°
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 120°
ceramic disc cartridge
max worktop thickness: 40 mm
255
240
270
143
220
filtered
water
180°
Gamma 3 vie
Gamma
Three-way mixer tap with dual control and rotating barrel. The three-way system
allows supply of hot/cold water and filtered water for alimentary use.
Single lever mixer tap with rotating barrel and extractable shower head.
Ref.
Ref.
8496 100
8483 001
satin finish
chromed
Mixer tap in AISI316 stainless steel, satin finish
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 50 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 180°
ceramic disc cartridge
max worktop thickness: 30 mm
121
Mixer Taps
120°
NYC
Lorenzo
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel and extractable shower head.
Ref.
Ref.
8486 000
8466 000
chromed
chromed
8466 100
satin finish
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 40 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 48 mm
rotating angle: 120°
ceramic disc cartridge
max worktop thickness: 40 mm
Luisa
GF
Single lever mixer tap with rotating barrel and extractable shower head.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8482 000
8452 000
chromed
chromed
122
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 53 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 30 mm
207
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance of control leverage: 50 mm
304
236
Ø53
Mixer Taps
NEW
Omega
Single lever mixer tap with rotating barrel.
NEW
Omega plus
us
Single lever mixer tap with rotating barrel and extractable shower head.
Ref.
Ref.
8497 000
8497 020
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 35 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 35 mm
KS
F2000 - Alto
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8485 000
8458 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 50 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 55 mm
rear encumbrance of control leverage: 40 mm
123
Mixer Taps
180°
F2000 - Basso
Beta
Single lever mixer tap with rotating barrel and extractable shower.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8459 000
8490 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 60 mm
rotating angle: 180°
ceramic disc cartridge
max worktop thickness: 50 mm
90°
Michy
Elettra
Single lever mixer tap with rotating barrel and extractable shower.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8489 000
8476 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 90°
ceramic disc cartridge
max worktop thickness: 40 mm
124
113°
202
137
199
249
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 58 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 55 mm
112°
182
212
221
Mixer Taps
180°
S1000 - Z66
S1000 - Z65
Single lever mixer tap with rotating barrel and extractable shower.
Single lever mixer tap with rotating barrel and extractable shower.
Ref.
Ref.
8448 500
8449 500
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 55 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 55 mm
rear encumbrance of control leverage: 60 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 55 mm
rotating angle: 180°
ceramic disc cartridge
max worktop thickness: 45 mm
NEW
S1000 - Z85
Bite
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8442 500
8481 000
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 48 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 55 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 54 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 15 mm
125
Mixer Taps
NEW
Easy
S1000 - RO
Single lever mixer tap with rotating barrel.
Single lever mixer tap with rotating barrel.
Ref.
Ref.
8498 000
8443 002
chromed
chromed
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 40 mm
rear encumbrance
of control leverage: 10 mm
strenghtening plate is included
hole for tap’s building-in: ø 35 mm
built-in base: ø 50 mm
rotating angle: 360°
ceramic disc cartridge
max worktop thickness: 55 mm
Complements
Dispenser
Quadra Dispenser
Round Dispenser
Chromed metal built-in liquid
soap/detergent dispenser
Chromed steel built-in liquid
soap/detergent dispenser
Ref.
Ref.
8520 000
8530 000
The detail shows the perfect combination between the Tre
Alto mixer and the Quadra Dispenser.
126
Dishwashers
High performance with
respect for the environment
Low consumption of energy and water, respect for the quality of home life and
high performance. These are the values of the new Foster dishwashers. An easy
but complete of solutions for every space and washing need, that reach the A+++
class, conforming to new european regulation.
Features
Programs: in the Foster range you can choose freely
between sets of practical and essential programs or
a complete sophisticated programming suit for every
individual need.
XXL plates: the large capacity of the lower rack is
capable of plates up to 33 cm diameter, also suitable for
serving dishes and special pizza-dishes.
Half Load: saving time and energy with the half-load setting.
Water saving: Foster dishwashers are particularly
attentive to the consumption of such a valuable resource.
Less than 8 liters of water are needed for a full wash
cycle,on model S4001. The icon accompanies the models
with a consumption of less than 10 liters.
Available on all programs.
Third level: S4001 dishwasher has a third level
specifically for cutlery and knives, composed of two
independent baskets that can be removed to make room
for goblets or bulky dishes.
Acquastop: stops the water supply and prevents leaks
and overflows at source. It is a standard equipment on
all models.
Delayed programming: it is possible to program
the operation of the dishwasher deferred in time, and to
optimize the energy consumption during the day.
Active Drying System: this exclusive active
convection system guarantees dry and shiny dishes with
a minimum energy consumption.
Number of place-settings: thanks to a carefully
engineered inside, the S4001 dishwasher reaches the
capacity of 14 place-settings.
Tabs “All in 1”: this option guarantees perfect results
with all kinds of detergent. Once it is activated, the
washing cycle is adapted to the practical “all in 1” Tabs
instead of the regular detergent.
Adjustable basket: the upper basket is simple to
Interior light: the washing chamber is equipped with
adjust in height, even when fully loaded. This allows
better space management according to washing needs.
halogen light, which is activated automatically when the
door opens, improving the visibility of the content.
127
Dishwashers
S4001
Ref.
fully built-in dishwasher
2911 000
NEW
Energy class A+++
Washing efficiency: A
Drying efficiency: A
Place-setting capacity 14
44 dB(A) sound power
as per EN 704-3
Electronic programming
Touch-control digital panel
6 washing programs: DCS+ (advanced
automatic program), intensive,
delicate, eco, quick, soaking
Active Drying System (ADS)
Third level for washing cutlery
with 2 independent baskets
Internal lighting
Acquastop safety system
1-12 hour delayed programming
Remaining wash time indication
Setting for all-purpose detergents
Low salt-rinsing agent indicators
Upper basket adjustable in height at
full load, also for 33 cm pizza dishes
Goblet support
Frontal adjustment of rear feet
Feet adjustement 0-70 mm
available from March 2015
Accessories:
A Stainless steel door panel
B Hinges kit S4000 - Slide Door
Technical data
voltage rating: 230 V - 50 Hz
total power: 2.000 W
heating power: 1.900 W
water consumption per cycle: 8 litres
6
KS 60
Door panel dimension limits:
thickness 16-24 mm
height 642-730 mm
max height with Slide Door kit 780 mm
Ref.
fully built-in dishwasher
2940 001
Energy class A+
Washing efficiency: A
Drying efficiency: A
Place-setting capacity 12
48 dB (A) sound power as per EN 704-3
Electronic programming
Digital panel
8 washing programs: intensive,
daily clean, delicate, auto, bio, quick,
soaking, baby care
Half-load function for all programs
Active Drying System (ADS)
Accessories (page 129):
A Stainless steel door panel
8
128
Technical data
voltage rating:
220-240 V - 50Hz
total power: 2.200 W
heating power: 2.000 W
water consumption per cycle:13 litres
Door panel dimension limits:
thickness 16-24 mm
height 630-715 mm
Acquastop safety system
1-9 hour delayed programming
Remaining wash time indication
Setting for all-purpose detergents
Low salt-rinsing agent indicators
Upper basket adjustable in height
at full load
Adjustable cutlery basket
Goblet support
Frontal adjustment of rear feet
Feet adjustement 0-50 mm
Dishwashers
Elettra
Ref.
fully built-in dishwasher
3-6-9 hour delayed programming
Remaining wash time indication
Setting for all-purpose detergents
Low salt-rinsing agent indicators
Upper basket adjustable in height
at full load
Adjustable cutlery basket
Goblet support
Frontal adjustment of rear feet
Feet adjustement 0-50 mm
Energy class A+
Washing efficiency: A
Drying efficiency: A
Place-setting capacity 12
49 dB (A) sound power as per EN 704-3
Electronic programming
Digital panel
5 washing programs: intensive,
eco, daily clean, quick, soaking
Half-load function for all programs
Acquastop safety system
2950 000
Accessories:
A Stainless steel door panel
Technical data
voltage rating:
220-240 V - 50Hz
total power: 2.000 W
heating power: 1.800 W
water consumption per cycle: 14 litres
Door panel dimension limits:
thickness 16-24 mm
height 630-715 mm
5
accessories
B
Stainless steel door panel
Hinges kit S4000 - Slide Door
Ref.
Ref.
2910 003
8929 100
max
138
A
finish: AISI 304 satin-finish
size:: 595x716x20 mm
The integrated handle is easy to couple with
any kitchen door.
Compatible with all the 60 cm dishwasher
models.
Makes it possible to correctly install the
dishwasher also in kitchens with lower
cabinet base.
The slide door system makes the door panel
tilt outwards while opening, and allows to
install panels up to 780 mm high.
129
Gas cooker hobs
Design, technology and high-grade materials are the ingredients of a cooking range characterised by high functionality, professional
performance and energy saving. Foster cooker hobs are offered in a wide range of built-in versions; moreover, the cooker hob can be
incorporated into the custom-sized stainless steel worktop. Foster cooker hobs are made of AISI 304 stainless steel and come in a variety
of finishes.
KE White p. 144
S4000 p. 135
KE Line p. 145
Veronika FT p. 153
S4000 Line XL p. 137
KE Domino p. 146
Veronika p. 154
S4000 Line p. 138
Marine p. 147
Elettra p. 155
S4000 Domino p. 139
KS p. 148
Elettra colour p. 156
p. 140
KS colour p. 149
Angolare p. 158
FL p. 141
KS Domino p. 150
Kristal p. 159
KE p. 143
Professionale p. 151
Rondò p. 160
Quadra
Angolare
130
Professionale
Domino
GK p. 134
p. 152
High efficiency coupled
with environmental awareness
III Serie (66%)
II Serie (55%)
Calore generato
Generated
heat
High efficiency coupled with environmental awareness. Foster
offers a broad and modern selection of cooker hobs that are
tailored to various space-related needs and implement special
technological features for guaranteed energy saving. The new
cooker hobs feature high-efficiency burners that allow a gas
saving from 20% to 25% when compared to traditional hobs.
- Generated heat
AE (69%)
Gas
consumption
Consumo
di gas - Gas consumption
Burners
High Efficiency burners (AE):
5kW and 25% gas saving
Energy efficiency is a plus offered by the research of Foster. All the new products
are studied to reduce gas consumption and respect the environment. Thanks to
the new AE burners (which stands for “Alta Efficienza”, i.e. high efficiency) cooker
hobs have a maximum efficiency rate of 69% and the DUAL AE burner reaches a
maximum power of 5 kW. The brass burner ring gives a professional look.
III^ serie burners: 20% gas saving
Ultra-new burners. A concentration of design, technology and performance.
Their efficiency is vastly superior to the dictates of the European standards, with
an even more extensive min/max power ratio for the utmost flexibility of use.
The system that locks the cover and burner cap achieves perfect positioning and
makes cleaning extremely practical.
Dual burners: from 300 to 4.500 W
Innovative and versatile burner, with triple crown ignited independently by a
single knob. Power delivery from 300 to 4500 W.
131
Features
Safety in the kitchen
The ultra-rapid latest generation thermocouples make the burners even safer while the ignition time is reduced to the minimum.
Safe cooking
Under-knob ignition
Ultra-flat
All Foster cooker hobs are equipped with safety valves.
They shut off the gas supply very quickly if the flame
accidentally goes out.
The utmost freedom of movement with electronic
under-knob ignition, a common feature of all models
that allows a one-hand ignition of the burner.
Power supply: 220-230 V 50-60 Hz.
Design meets functionality in the the ultra-flat
models. Elegant grids that form a generously sized
overall surface.
Grids
Almost all Foster hobs are equipped with cast-iron grids, an ideal material due to the manifold properties characterising it: high heat capacity
that improves cooking performance; high weight and stability that improve safety; sturdiness that preserves the hob’s original aspect over
time; easy cleaning.
132
Pure elegance
Cast-iron grids
Practicality
The cone-shaped hobs raise up from the surface,
evoking the power of fire. The grids surmount the
burners, leaving the hobs surface “free”.
Almost all the Foster cooker hobs are equipped with
cast-iron grids, a perfect material due to its many
properties: high thermal capacity that improves the
cooking efficiency; weight and stability that improve
safety; sturdiness which keeps their look unaltered
over time; easiness to clean.
A deep and inclined containing area cradles the
burners and cast-iron grids, which form a continuous
workable surface. The inclination of the containing
area’s edge, makes it very easy to clean, also in corners.
Features
Built-in and beyond
The methods with which worktops can be built-in have become increasingly more varied and customized.
Foster was the first sink manufacturer to have researched and used the new recessing methods and has thus acquired a great deal of
experience. It now offers the most comprehensive range available on the market, with flush-mount and flat-edge installation.
67'
6)
4
Standard
Q4
Flat-edge
Traditional built-in with the vertical, 8-mm edge.
The casing has a square edge that stands outside the
work surface by just 4 mm.
An original edge, with an inclined, 3-mm high profile,
matching an extreme elegance with the easiness of
installation.
)7
FTS
Flush-mount
Built-in
The flush-mount cooker hobs have no vertical edge,
and must be sunk into a 1,5 mm deep recess in the
worktop’s surface.
Almost the whole range of Foster cooker hobs can
be integrated into stainless steel worktops; it is the
most elegant and professional solution, that creates
a seamless work-surface. The products that can be
welded are listed hereafter.
accessories
1
Wok support
9601 668
4
Wok support
9601 727
2
St. steel Wok Ø 36 cm
8173 000
5
Pan support grid
8152 000
3
Cast-iron grill 44x22 cm
8172 000
6
Cast-iron support 11x23 cm
9601 742
7
Cast-iron support
9601 741
133
GK
Foster stylistic features and functional principles melt perfectly in this hob. The concept of in-line cooking evolves to create new spaces, flat grids and maximum practicality match in
the elegant inclined containing area, the innovative AE (high efficiency) burners guarantee unequalled performance and efficiency.
GE
TA
VIN
NEW
High-Efficiency burners.
Up to 25% energy saving
Features
Version
6)
Ref.
7628 032
Technical Drawing
Flat-edge: 1294x470 - cut-out: 1274x450
Flush-mount: 1294x470 - cut-out (FT): see web site
up-mount cut-out (FTS): 1274x450
)7
7627 032
FTS
AISI 304 brushed
cast iron grids and
enamelled burner covers
Tot. power: 11.750 W
auxiliary: 2x1.000 W
semi-rapid: 1.750 W
rapid: 3.000 W
dual AE: 5.000 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
Supplied with: 4 (see page 133)
6)
7626 032
External dimensions refer to
Flush-mount version
Flat-edge: 1050x470 - cut-out: 1030x450
Flush-mount: 1050x470 - cut-out (FT): see web site
up-mount cut-out (FTS): 1030x450
)7
7625 032
model weldable into st. steel worktops
AISI 304 brushed
cast iron grids and
enamelled burner covers
Tot. power: 9.500 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
vintage
dual AE: 5.000 W
versions
Electric ignition
Safety valves
GE
TA
with ultra-rapid
VIN
thermocouples
Supplied with: 4 (see p. 133)
GK combines generous dimensions with the ease of
insertion into standard cabinets. With 4 cm worktop
thickness, the special shape of the box allows the
fitting in 90 cm large cabinet.
134
FTS
)7
7625 082
FTS
External dimensions refer to
Flush-mount version
S4000
Cooker hobs of the 4000 series all mount the newly-introduced third generation burners characterised by their elegant conical shape. They offer increased maximum power while their
energy efficiency levels exceed those of European standards. The triple-crown burner reaches 3.8 kW and reduces gas consumption by up to 20%.
Cast-iron support included
New generation hobs.
Up to 20% energy saving
Features
Version
Ref.
4
7272 032
Technical Drawing
Q4: 1220x520 - cut-out: 1160x480
Flush-mount: 1220x520 - cut-out (FT): see web site
up-mount cut-out (FTS): 1200x500
)7
7273 032
FTS
model weldable into st. steel worktops
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power: 15.200 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
triple crown: 2x3.800 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Supplied with: 1
Accessories Q4: 2
Accessories Flush-mount: 2 6 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 11.400 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
triple crown: 3.800 W
4
7252 032
External dimensions refer to
Flush-mount version
Q4: 920x520 - cut-out: 860x480
Flush-mount: 920x520 - cut-out (FT): see web site
up-mount cut-out (FTS): 900x500
)7
7257 032
FTS
Electric ignition
model weldable into st. steel worktops
Supplied with: 1
Accessories Q4: 2
Accessories Flush-mount: 2 6 (see page 133)
Safety valves
with ultra-rapid
thermocouples
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 11.400 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
triple crown: 3.800 W
External dimensions refer to
Flush-mount version
4
7270 032
Q4: 920x520 - cut-out: 860x480
Flush-mount: 920x520 - cut-out (FT): see web site
up-mount cut-out (FTS): 900x500
)7
7271 032
FTS
Electric ignition
model weldable into st. steel worktops
Supplied with: 1
Accessories Q4: 2
Accessories Flush-mount: 2 6 (see page 133)
Safety valves
with ultra-rapid
thermocouples
External dimensions refer to
Flush-mount version
135
S4000
Features
Version
Ref.
Technical Drawing
Q4: 890x520 - cut-out: 870x500
4
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 11.750 W
semi-rapid: 1.750 W
dual AE: 2x5.000 W
7280 032
model weldable into st. steel worktops
Electric ignition
High-Efficiency burners.
Up to 25% energy saving
Supplied with: 2x 1 , 6
Accessories: 2 (see page 133)
Safety valves
with ultra-rapid
thermocouples
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 7.600 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
Preparing for the Far East markets
available on request.
4
7251 032
Q4: 620x520 - cut-out: 560x480
Flush-mount: 620x520 - cut-out (FT): see web site
up-mount cut-out (FTS): 600x500
)7
7256 032
FTS
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories Flush-mount: 6 (see page 133)
The flush-mount versions are supplied with the pot support accessory (Ref.
9601 742) that increases the work surface and safeguards the worktop against
accidental contact with hot pots. It is a standard feature available on all S4000
Domino hobs.
136
External dimensions refer to
Flush-mount version
S4000 Line XL
S4000 line hobs are now also in XL version, with the refined and practical cast iron pot supports.
New generation hobs.
Up to 20% energy saving
Ref.
Technical Drawing
Flush-mount: 1179x465 - cut-out (FT): see web site
up-mount cut-out (FTS): 1162x448
)7
7284 032
70
Version
1
Features
FTS
model weldable into st. steel worktops
31
1114
R10
1179
34
45
465
254
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power 9.650 W
auxiliary: 1.100 W
semi-rapid: 1.750 W
rapid: 3.000 W
triple crown: 3.800 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
R
SR
A
TC
254
Supplied with: 4x 7 , 1
Accessories: 2 6 (see page 133)
Flush-mount: 925x465 - cut-out (FT): see web site
up-mount cut-out (FTS): 908x448
70
1
)7
7285 032
FTS
33
858
R10
925
34
45
465
model weldable into st. steel worktops
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power 6.650 W
auxiliary: 1.100 W
semi-rapid: 1.750 W
triple crown: 3.800 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
SR
TC
A
Supplied with: 3x 7 , 1
Accessories: 2 6 (see page 133)
XL versions are characterized by the greater depth of the
floor of steel, on which are positioned elegant cast iron
elements. These are removable and also may be placed
in the front of the hob, or used as a support for the pots
in the table.
137
S4000 Line
All the elegance and performance of the 4000 Series, and the high functionality of the burners-in-line concept.
New generation hobs.
Up to 20% energy saving
Features
Version
Ref.
Technical Drawing
7254 032
Q4: 1179x368 - cut-out: 1159x348
Flat-edge: 1179x368 - cut-out: 1162x351
Flush-mount: 1179x368 - cut-out (FT): see web site
up-mount cut-out (FTS): 1162x351
4
6)
rapid: 3.000 W
triple crown: 3.800 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
7250 032
)7
Supplied with: 1
Accessories Q4 and Flat-edge: 2
Accessories Flush-mount: 2 6 (see page 133)
7259 032
External dimensions refer to
Flush-mount version
FTS
Flush-mount: 925x368 - cut-out (FT): see web site
up-mount cut-out (FTS): 908x351
)7
7286 032
FTS
70
NEW
1
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power: 9.650 W
auxiliary: 1.100 W
semi-rapid: 1.750 W
33
semi-rapid: 1.750 W
triple crown: 3.800 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Supplied with: 1
Accessori Q4 e semifilo: 2
Accessori Filotop: 2 6
The entire 4000 Series is equipped with the new elegant
and sober knob. As on all Foster cooker hobs, the appliances
have under-knob ignition. Moreover, ignition is now even
quicker thanks to the new burners.
138
925
R10
368
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power 6.650 W
auxiliary: 1.100 W
34
858
model weldable into st. steel worktops
45
SR
TC
A
S4000 Domino
Thanks to the new AE (high efficiency) burners, S4000 Domino series grants highest performances (up to 5 kW) and 69% energetic efficiency.
High-Efficiency burners.
Up to 25% energy saving
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 5.000 W
dual AE: 5.000 W
Version
Ref.
Technical Drawing
Q4: 450x520 - cut-out: 430x480
4
7278 032
Electric ignition
Preparing for the Far East markets
available on request.
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
Supplied with: 1 , 6
Accessories: 2 (see page 133)
Notes for fixing on the worktop: see page 173
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 4.500 W
dual: 4.500 W
Q4: 450x520 - cut-out: 430x480
4
7277 032
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
Supplied with: 1 , 6
Accessories: 2 (see page 133)
Notes for fixing on the worktop: see page 173
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 2.750 W
auxiliary AE: 1.000 W
semi-rapid AE: 1.750 W
Q4: 380x520 - cut-out: 360x480
4
7276 032
Electric ignition
model weldable into st. steel worktops
Supplied with: 6 (see page 133)
Safety valves
with ultra-rapid
thermocouples
Notes for fixing on the worktop: see page 173
139
Quadra Angolare
The power of five burners, all easily accessible. A design solution that elevates the cooking corner.
Features
Version
Ref.
Technical Drawing
Flat-edge: 972x972 - cut-out: see web site
Flush-mount: 972x972 - cut-out (FT): see web site
up-mount cut-out (FTS): see web site
6)
7235 042
)7
7238 042
FTS
model weldable into st. steel worktops
AISI 304 brushed
Cast iron grids and
enamelled burner covers
Tot. power: 9.950 W
auxiliary: 2x1.000 W
semi-rapid: 1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 1 (see page 133)
Thanks to its broad front work surface, the Quadra Corner
cooker hob allows for optimally exploiting corner spaces.
140
Connection to he gas supply network must be carried out through
both inlets (A and B)
FL
FL hobs feature the powerful and efficient AE burners and the practicality of the large planar cast iron surface on which you’ll be able to cook in perfect freedom and safety.
High-Efficiency burners
Up to 25% energy saving
Features
NEW
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power 10.500 W
auxiliary: 2x1.000 W
dual AE: 5.000 W
semi-rapid: 2x1.750 W
Version
67'
6)
Ref.
Technical Drawing
7201 032
Standard: 860x500 - cut-out: 840x480
Flat-edge: 873x513 - cut-out: 840x480
Flush-mount: 873x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 860x500
7205 032
Electric ignition
Safety valves with
ultra-rapid thermocouples
)7
7206 032
FTS
Supplied with: 4 (see page 133)
NEW
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power 11.750 W
semi-rapid: 1.750 W
dual AE: 2x5.000 W
External dimensions refer to
Flush-mount version
Standard: 860x500 - cut-out: 840x480
67'
7202 032
Electric ignition
Safety valves with
ultra-rapid thermocouples
Supplied with: 2x 4 (see page 133)
4
Wok support
9601 727
Ultra-flat grids
The sturdy cast iron grids form a single surface on which you can
move pans easily and in complete safety.
5 kW burner
FL cooker hob feature a powerful 5kw burner with two totally
indimendent crown of flames, controlled by two different knobs.
141
FL
Features
NEW
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power 10.000 W
dual AE: 2x5.000 W
Version
Ref.
Technical Drawing
Standard: 760x500 - cut-out: 740x480
67'
7203 032
Electric ignition
Safety valves with
ultra-rapid thermocouples
Supplied with: 2x 4 (see page 133)
NEW
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power 5.000 W
dual AE: 5.000 W
6)
7204 032
)7
Electric ignition
Safety valves with
ultra-rapid thermocouples
Standard: 353x513 - cut-out: 320x480
Flush-mount: 353x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 340x500
7207 032
FTS
Supplied with: 4 (see page 133)
Thanks to the powerfull and versatile AE Dual burner, FL domino is a complete hob even with its single burner. It is possible supplying little powers for a
single-cup moka, up to 5000 W for water boiling or wok cookings.
On five-burners and three-burners models, AE dual is even more flexible thanks to a twin-knobs system that allows to have the two completely indipendent
crowns of flames.
142
KE
By choosing Foster you choose quality, design and innovative technology. Values that leave no room for compromise and are now fully reflected in the new KE series. The aim of all the
components, whether technological or aesthetical, remains unaltered: to create an elegant yet functional work environment. Available in seven different versions, including the 86 cm
“wide” and white solutions.
New generation hobs.
Up to 20% energy saving
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.500 W
auxiliary: 2x1.100 W
semi-rapid: 2x1.750 W
triple crown: 3.800 W
Version
Ref.
Technical Drawing
Standard: 860x500 - cut-out: 840x480
67'
7603 032
67'
Microfoster
7603 432
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.500 W
auxiliary: 2x1.100 W
semi-rapid: 2x1.750 W
triple crown: 3.800 W
Standard: 790x500 - cut-out: 770x480
67'
7602 032
67'
Microfoster
7602 432
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.500 W
auxiliary: 2x1.100 W
semi-rapid: 2x1.750 W
triple crown: 3.800 W
4
7605 032
Q4: 810x520 - cut-out: 770x480
Flat-edge: 803x513 - cut-out: 770x480
Flush-mount: 803x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 790x500
NEW
6)
7600 032
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
)7
7601 032
FTS
External dimensions refer to
Flush-mount version
Accessories: 4 (see page 133)
143
KE white
The elegance and functionality of the KE hob is now available in the original version with white grids and burners with stainless steel finish that allows perfect matching in modern
“total white” kitchens.
New generation hob.
Up to 20% energy saving
Features
AISI 304 brushed
White enamelled grids
and steel burner covers
Tot. power: 9.500 W
auxiliary: 2x1.100 W
semi-rapid: 2x1.750 W
triple crown: 3.800 W
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
features
Elegance to put on display and
praticallity in cooking.
KE white comes with refined steel
burner covers.
The enamelled burner covers kit,
more practical for daily use, is also
available on request.
code 9601 480
KE White, a new elegance: the special high-resistance white
enamelled cast iron grids and burners steel details are an
expression of uniqueness and refinement.
144
Version
Ref.
Technical Drawing
Flat-edge: 803x513 - cut-out: 770x480
6)
7600 132
KE Line
The evolution of the in-line cooker hob. The new model KE Line inherits the functional arrangement of burners in a line, proposing it with an elegant version with frontal knobs.
New generation hob.
Up to 20% energy saving
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.650 W
auxiliary: 1.100 W
semi-rapid: 1.750 W
rapid: 3.000 W
triple crown: 3.800 W
model weldable into st. steel worktops
Ref.
6)
7606 032
Technical Drawing
Flat-edge: 1050x440 - cut-out: 1030x420
Flush-mount: 1050x440 - cut-out (FT): see web site
up-mount cut-out (FTS): 1037x427
)7
7607 032
FTS
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
Version
External dimensions refer to
Flat-edge version
A detail of the precious knob and of the highly
performing burners of KE hobs.
145
KE Domino
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
triple crown: 3.800 W
Version
Ref.
Technical Drawing
Flush-mount: 321x466 - cut-out (FT): see web site
up-mount cut-out (FTS): 309x454
)7
7624 032
FTS
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
Accessories: 4 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
rapid: 3.000 W
Flush-mount: 321x466 - cut-out (FT): see web site
up-mount cut-out (FTS): 309x454
)7
7623 032
FTS
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
semi-rapid: 1.750 W
Flush-mount: 321x466 - cut-out (FT): see web site
up-mount cut-out (FTS): 309x454
)7
7622 032
FTS
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
auxiliary: 1.100 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
model weldable into st. steel worktops
New generation hobs.
Up to 20% energy saving
146
Flush-mount: 321x466 - cut-out (FT): see web site
up-mount cut-out (FTS): 309x454
)7
7621 032
FTS
Marine
The new Marine hob falls into the category “ultra-flat”, with grills that protrude only a few millimeters from the worktop and create a wide and stable work surface.
The AISI 316 stainless steel, resistant to all types of corrosion, making it perfect for installation in marine environments.
Features
AISI 316 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.750 W
auxiliary: 1.000 W
semi-rapid: 3x1.750 W
triple crown: 3.500 W
Version
Ref.
Technical Drawing
Flat-edge: 803x513 - cut-out: 770x480
6)
7058 072
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
Marine sinks see page 65
Detail of the precious knob of the Marine cooker hob,
with its elegant satin-finish that matches the hob’s
surface finish.
The Marine sinks and hobs feature the elegant halfflush inclined edge, which protrudes only 3 mm from
the worktop.
147
KS
Innovative and essential, easy to clean thanks to some distinctive details: burners distance allow practical use, single grids keep the bottom free and corners cleaning is assured by the
inclined profile shapes.
New generation hobs.
Up to 20% energy saving
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 10.150 W
auxiliary: 1.100 W
semi-rapid: 3x1.750 W
triple crown: 3.800 W
Version
Ref.
Technical Drawing
Standard: 790x500 - cut-out: 770x480
67'
7610 032
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 7.600 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
Electric ignition
model weldable into st. steel worktops
The sloped recess conveys a modern, elegant touch
besides facilitating cleaning of the corners. A piece of
highly refined workmanship to be found on both the KE
and KS ranges.
148
Safety valves
with ultra-rapid
thermocouples
Standard: 590x500 - cut-out: 560x480
67'
7615 032
KS colour
Features
Enamelled steel
anthracite
Cast iron grids and
enamelled burner
covers
Tot. power: 10.150 W
auxiliary: 1.100 W
semi-rapid: 3x1.750 W
triple crown: 3.800 W
Version
Ref.
Technical Drawing
Standard: 790x500 - cut-out: 770x480
67'
7610 632
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
Enamelled steel
copper
Cast iron grids and
enamelled burner
covers
Tot. power: 10.150 W
auxiliary: 1.100 W
semi-rapid: 3x1.750 W
triple crown: 3.800 W
Standard: 790x500 - cut-out: 770x480
67'
7610 332
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
Enamelled steel
oats
Cast iron grids and
enamelled burner
covers
Tot. power: 10.150 W
auxiliary: 1.100 W
semi-rapid: 3x1.750 W
triple crown: 3.800 W
Standard: 790x500 - cut-out: 770x480
67'
7610 232
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
Enamelled steel
white
Cast iron grids and
enamelled burner
covers
Tot. power: 10.150 W
auxiliary: 1.100 W
semi-rapid: 3x1.750 W
triple crown: 3.800 W
Standard: 790x500 - cut-out: 770x480
67'
7610 132
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
New generation hobs.
Up to 20% energy saving
The enameled KS hobs match the classic style of coloured
appliances to a modern and linear design, with a original
and surprising effect.
149
KS Domino
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
triple crown: 3.800 W
Version
Ref.
Technical Drawing
Standard: 290x500 - cut-out: 270x480
67'
7634 032
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Accessories: 4 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
rapid: 3.000 W
Standard: 290x500 - cut-out: 270x480
67'
7633 032
Electric ignition
Safety valves
with ultra-rapid
thermocouples
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
semi-rapid: 1.750 W
Standard: 290x500 - cut-out: 270x480
67'
7632 032
Electric ignition
Safety valves
with ultra-rapid
thermocouples
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
auxiliary: 1.100 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
New generation hobs.
Up to 20% energy saving
150
Standard: 290x500 - cut-out: 270x480
67'
7631 032
Professionale
The Professional series cooker hob, with its sturdy cast-iron grids and a wide distance among burners, guarantees functionality and performances. Its elegant and linear design is a
classic evergreen. Available in different built-in solutions and steel finishes, it will satisfy any need.
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Version
Ref.
Technical Drawing
7055 062
Standard: 860x500 - cut-out: 840x480
Flat-edge: 873x513 - cut-out: 840x480
Flush-mount: 873x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 860x500
67'
67'
Microfoster
7055 462
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
6)
7246 062
)7
FTS
7245 062
External dimensions refer to
Flush-mount version
Accessories: 1 2 3 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 8.000 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
triple crown: 3.500 W
67'
7053 062
6)
7244 062
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
Standard: 590x500 - cut-out: 560x480
Flat-edge: 603x513 - cut-out: 560x480
Flush-mount: 603x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 590x500
)7
7243 062
FTS
Accessories: 1 2 (see page 133)
External dimensions refer to
Flush-mount version
151
Professionale Domino
A professional kitchen on measure.
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 2.750 W
auxiliary: 1.000 W
semi-rapid: 1.750 W
Electric ignition
model weldable into st. steel worktops
152
Safety valves
with ultra-rapid
thermocouples
Version
Ref.
Technical Drawing
Standard: 290x500 - cut-out: 270x480
67'
7062 042
Veronika Flush-mount
The clean design of the flush edge matches the soft and sinuous profile, perfectly matched with different washing solutions.
New generation hob.
Up to 20% energy saving
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 10.600 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 2x3.000 W
Version
Ref.
Technical Drawing
Flush-mount: 773x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 760x500 R 145
)7
7367 032
FTS
Electric ignition
model weldable into st. steel worktops
Safety valves
with ultra-rapid
thermocouples
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 7.600 W
auxiliary: 1.100 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
Flush-mount: 613x513 - cut-out (FT): see web site
up-mount cut-out (FTS): 600x500 R 145
)7
7266 032
FTS
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Veronika flush-mount versions feature large radiused
shapes that perfectly match Big Bowl and Tornado flushmount sinks.
153
Veronika
Cooker hobs with a clean and simple design, and the choice between versions in three, four or five fires.
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Version
Ref.
Technical Drawing
Standard: 760x500 - cut-out: 560x480
67'
7067 062
Electric ignition
Safety valves
with ultra-rapid
thermocouples
56x48
Accessories: 4 (see page 133)
Strait cut-out
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
Model which cannot be welded into
stainless steel worktops
Standard: 590x500 - cut-out: 560x480
67'
7066 052
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Model which cannot be welded into
stainless steel worktops
Standard: 440x500 - cut-out: 420x480
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 5.850 W
auxiliary: 1.100 W
semi-rapid: 1.750 W
rapid: 3.000 W
Electric ignition
model weldable into st. steel worktops
New generation hob.
Up to 20% energy saving
154
Safety valves
with ultra-rapid
thermocouples
67'
7063 042
Elettra
Elettra cooker hob: new, rational, sturdy.
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Version
Ref.
Technical Drawing
Standard: 760x500 - cut-out: 560x480
67'
7064 062
Electric ignition
Safety valves
with ultra-rapid
thermocouples
56x48
Strait cut-out
Accessories: 1 2 (see page 133)
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
Model which cannot be welded into
stainless steel worktops
Standard: 590x500 - cut-out: 560x480
67'
7068 042
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Model which cannot be welded into
stainless steel worktops
Detail of the sturdy and squared grids of Elettra hob, here
matched with Alien2 sink.
155
Elettra 5F colour
Features
Enamelled steel
anthracite
Cast iron grids and
enamelled burner
covers
Knobs colour: satin steel
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Accessories: 1 2 (see page 133)
Accessories: 1 2 (see page 133)
Elettra collection now is enriched by 4 new colors in
addition to the classic stainless steel models. The same
colors are offered on the new range of ovens Country,
to give life to perfect matches.
156
Standard: 760x500 - cut-out: 560x480
7064 662
56x48
Strait cut-out
Standard: 760x500 - cut-out: 560x480
67'
7064 362
knobs kit steel coloured
cod. 8209 001
56x48
Strait cut-out
Standard: 760x500 - cut-out: 560x480
67'
7064 262
knobs kit steel coloured
cod. 8209 001
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
ivory
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued brass
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Technical Drawing
67'
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
oats
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued brass
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Accessories: 1 2 (see page 133)
Ref.
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
copper
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued copper
Tot. power: 10.700 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
triple crown: 3.500 W
Accessories: 1 2 (see page 133)
Version
56x48
Strait cut-out
Standard: 760x500 - cut-out: 560x480
67'
7064 562
knobs kit steel coloured
cod. 8209 001
56x48
Strait cut-out
Elettra 4F colour
Features
Enamelled steel
anthracite
Cast iron grids and
enamelled burner
covers
Knobs colour: satin steel
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
Version
Ref.
Technical Drawing
Standard: 590x500 - cut-out: 560x480
67'
7068 642
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
copper
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued copper
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
Standard: 590x500 - cut-out: 560x480
67'
7068 342
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
oats
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued brass
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
knobs kit steel coloured
cod. 8209 001
Standard: 590x500 - cut-out: 560x480
67'
7068 242
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Enamelled steel
ivory
Cast iron grids and
enamelled burner
covers
Knobs colour:
antiqued brass
Tot. power: 7.200 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 2.700 W
Electric ignition
Safety valves
with ultra-rapid
thermocouples
knobs kit steel coloured
cod. 8209 001
Standard: 590x500 - cut-out: 560x480
67'
7068 542
knobs kit steel coloured
cod. 8209 001
Electra colours hobs feature coordinated knobs:
Antique brass for oats and ivory colours, antique
copper to copper. The steel coloured konb, standard
on anthracite model, is also available as an accessory kit.
157
Angolare
The optimal use of the corner in the kitchen: 5 burners in a space-saving dimension.
Features
Version
Ref.
Technical Drawing
Standard: 830x830 - cut-out: see web site
67'
7038 052
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 9.750 W
auxiliary: 1.000 W
semi-rapid: 3x1.750 W
triple crown: 3.500 W
Electric ignition
model weldable into st. steel worktops
Accessories: 1 2 (see page 133)
Foster's Angolare hob maximizes space thanks to the
cast iron "pan-support" zones that create a continuous
surface with the grids on cooking zones.
158
Safety valves
with ultra-rapid
thermocouples
Kristal
A compact and functional three-burners cooker hob, here shown in a fashionable version with black or white glass.
Features
Cast iron grids and
enamelled burner
covers
Tot. power: 5.650 W
auxiliary: 1.000 W
semi-rapid: 1.650 W
rapid: 3.000 W
Version
Ref.
Technical Drawing
Dimension: 450x510 - cut-out: 430x480
7030 142
white glass
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Cast iron grids and
enamelled burner
covers
Tot. power: 5.650 W
auxiliary: 1.000 W
semi-rapid: 1.650 W
rapid: 3.000 W
Dimension: 450x510 - cut-out: 430x480
7030 642
black glass
Electric ignition
Safety valves
with ultra-rapid
thermocouples
Kristal cooker hobs and S45 ovens are available in the same
colors and sizes. A perfect match for small spaces.
159
Rondò
Geometrically perfect design. A suitable solution for “space-saving” requirements or in combination with kitchens featuring curved lines. The Rondò model comes with three burners.
Now Rondò is also available in two new versions – Kristal White and Kristal Black – featuring gas burners on glass-ceramic.
Features
AISI 304 brushed
Cast iron grids and
enamelled burner
covers
Tot. power: 5.450 W
auxiliary: 1.000 W
semi-rapid: 1.750 W
rapid: 2.700 W
Electric ignition
model weldable into st. steel worktops
Accessories: 5 (see page 133)
The Rondò series received a special mention of merit at
the prestigious ADI “Golden Compass” international design
competition.
160
Safety valves
with ultra-rapid
thermocouples
Version
Ref.
Technical Drawing
Standard: Ø 520 - cut-out: Ø 500
67'
7052 022
Spazzolato
67'
7052 442
Microfoster
S1000
The sturdiness of the cast iron grids and Foster stainless steel with an incredible value for money.
Ref.
Technical Drawing
Standard: 890x510 - cut-out: 820x480
67'
7006 072
8
55
AISI 304
Cast iron grids and
enamelled burner covers
Tot. power: 11.300 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
triple crown: 3.800 W
Version
510
Features
Electric ignition
Standard: 750x510 - cut-out: 560x480
67'
7005 072
8
55
AISI 304
Cast iron grids and
enamelled burner covers
Tot. power: 11.300 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
triple crown: 3.800 W
890
510
MOQ requested
Safety valves
with ultra-rapid
thermocouples
Electric ignition
MOQ requested
Safety valves
with ultra-rapid
thermocouples
750
56x48
Strait cut-out
Standard: 590x510 - cut-out: 560x480
67'
7004 072
8
55
AISI 304
Cast iron grids and
enamelled burner covers
Tot. power: 7.500 W
auxiliary: 1.000 W
semi-rapid: 2x1.750 W
rapid: 3.000 W
Safety valves
with ultra-rapid
thermocouples
MOQ requested
510
Electric ignition
590
161
Induction and Electric Hobs
Excellent performance and cutting-edge technology characterise Foster electric cooker hobs. A completely redesigned range that strikes
the perfect blend of efficiency and design with the induction hobs.
S4000 Induction p. 166
Elettra Induction p. 169
S1000 Induction p. 170
S4000 Domino p. 171
Modular Induction p. 174
Vitroline Hi-light p. 177
Induction PRO Pots collection
162
p. 178
The advantages of the induction technology
Control
Security
Cleaning
Great versatility and accurate control are peculiar
features of induction cooking.
The nine possible power settings (with additional
Powerboost options) offer a wide spectrum
of possibilities, ranging from simple food heat
maintenance to an incredible net available power
compared to other cooking systems.
The principle of induction cooking is absolutely
safe. The surface of the hob is heated only by pot
contact and reaches no searing temperatures.
Moreover, the simple act of removing the pot
automatically shuts off the hob. The sophisticated
electronic of Foster hobs completes their
equipment in terms of security systems thanks
to Pot Detector, Overflow Detector, Automatic
Power-Off and Safety Lock.
The cooking area is activated only on the surface
directly in contact with the saucepan; the rest of
the cooking area remains cool, which means that
over-spilled food will not burn and will not produce
unpleasant deposits that are difficult to remove.
Cleaning is so simple and fast and hygiene is perfect.
High speed
Great efficiency
power
absorption
net
power
yield
electric hob
2.000 W
1.000 W
50%
gas hob
1.820 W
1.000 W
55%
induction hob
1.100 W
1.000 W
90%
Boiling time for 2 litres of water
electric hob
gas hob
induction hob
minutes
1
2
3
4
5
6
7
8
9
10
Energy saving
Thanks to its great speed in bringing the liquid to boil and its efficiency highly
above all other cooking systems, induction involves a significant energy saving
and represent the most economical choice.
Absorption examples for different types of cooking
cooking
levels
power
kind of
cooking
examples
1-2
50-130 W
very light
melt, bain-marie
3-4
150-300 W
light
warm, simmer
5-7
350-750 W
medium
sauces, rice
7-9
1.000-2.300 W
intense
roast meat, fry
Powerboost
1.400-3.000 W
time
reduction
liquids boiling
The induction high power level leads us to believe in a great commitment
of energy. By contrast, as can be seen in the table, most types of cooking
require low power.
163
New Bridge technology
Extended cooking area
Bridge
The new hobs with Bridge function allow to associate two zones forming
a single extended cooking zone for pots of large size, or for more than one
cooking simultaneously, with maximum flexibility in pot positioning. With
the additional Double Booster feature provided by all Bridge hobs, the
exceptional 3700 W power can be concentrated on a single plate or made
available uniformly over the enlarged area.
Features of Foster Bridge technology
The innovative rectangular shape of Bridge induction plates provides maximum efficiency over the entire cooking area. The possibility of dosing the entire
power on individual plates or on the whole surface, allows the best performances both with pots of large and small size. Activation of the Bridge function is
intuitive and straightforward: the entire area is then managed with a single Slider command.
PowerControl
PowerControl function allows the use of induction technology also in case of
standard 3 kW domestic use. The maximum power can indeed be self-limited
to the desired level to a minimum of 2.8 kW. Once the maximum power is
set, we can forget about the absorbed energy because Foster induction hob
will give us a warning about possible limitations, allowing to choose how to
allocate the available energy.
The hob can be easily reprogrammed at any time to modify or remove the
power limit.
Built-in solutions
Induction and electric hobs can be installed either on the top or with the flush-mount method, by creating a recess in the worktop the
same depth as the thickness of the glass.
6)
)7
inset options for models with bevelled edges
4
)7
inset options for models with vertical edges
164
Bevelled edge
Special slanting edge (bevelled) that gives a clean and elegant finish with both
the installation methods (flush-mount and top-mount) and perfectly matches
the flat-edge sinks.
Vertical edge
The casing has a square edge that stands over the work surface by just 4 mm.
The vertical ceramic-glass profile allows both top-mount and flush-mount
installation.
Powerboost
Foster induction hobs are equipped wih Booster function [P], which
provides increased power to the selected plate. In particular, when the
Booster is activated, the plate works for ten minutes at a very high
power that allows to heat quickly large quantities of water.
Quantity
Without Powerboost
With Powerboost
3 litres
3,5 min.
1,8 min.
Double Powerboost
5 litres
4,5 min.
2,7 min.
On the new models with Bridge technology the Double Booster
function is available: two further levels of power up to 3700 W, to be
used on a single zone or distributed over the entire Bridge-extended
area (where available).
Boiling timing with or without Powerboost
Slider control operation
End-of-cooking programming
The Slider control allows for extremely quick temperature setting: with
a light touch of the finger you may select the desired power level on
the TOUCH display.
All operations are programmed by means of the touch-control
on the glass itself. Each cooking plate is capable of independent
programming, and thus the possibility to set different cooking times.
Timer
On several models a further timer, indipendent from the end-ofcooking function, is available
Pot detector
All induction cooker hobs detect the pot resting on them, but they
also calculate the area they cover. This system allows the energy to be
used even more efficiently.
Moreover, the plates switch off automatically when the pot is removed.
T-chef
It is the new function that allows to set particular temperatures (42
°C, 70 °C, 84 °C) and keep them constant during cooking. Elaborate
preparations can be easily obtained, with chef-like results. Cooking
in a bain-marie, without the aid of a double container for the water,
custard or cream sauce will thus always be perfect. By setting the
temperature close to boiling, liquids will immediately reach the
requested temperature, increasing speed and performance.
Smart Fan System
Correct ventilation is essential for the induction hob to function in
the best possible way. The Foster system automatically regulates the
amount of ventilation to suit the temperatures reached.
Go&Stop device
Heat maintenance
Function that allows the food to be kept warm gently (70° C), without
reaching boiling temperatures or risking to burn the sauce.
This device initially turns on the plates at maximum power until the
selected temperature has been reached.
Full Safety System
Recall
This feature allows you to call back the last settings selected in the
previous cooking.
All electric cooker hobs feature the most modern and sophisticated
safety protections: Centralised power-off function; Child-proof
safety lock; Residual heat warning lights. Induction models feature
the following functions: Safety System that turn off the hob in the
absence of the pot; Overflow detector that automatically turns off the
plate in case of liquid overflow; Automatic deactivation to prevent
To ensure optimal functioning, induction hobs require
adequate aeration. We suggest leaving a space of at
least 50 mm between cooker hob and the back or side
walls.
In order to prevent any leakages into the appliance’s
cut-out, Foster recommends applying a coat of paint or
a sealant between the cooker hob and worktop.
Do not install the hob above an oven that is not
adequately ventilated, or above a dishwasher.
Ensure that there is a gap of at least 20 mm below the
appliance’s box so as to allow for sufficient aeration of
the hob.
Useful function that allows you to distract your attention from cooking,
interrupting and restoring the settings immediately.
min 50 mm
min 20 mm
Installation in the cabinet
Pause
Electrical connection
Many models can be connected with a single and
two-phase power. The icons beside show the different
possible connections.
165
S4000 Induction Bridge
Bridge models represent the ultimate step of S4000 technology. A new generation of inductors providing even more power and the possibility of connecting two zones together forming
a single extended cooking area.
Features
Version
Ref.
Technical Drawing
Flat-edge: 840x350 - cut-out: 810x332
Flush-mount: 840x350 - cut-out: see web site
6)
)7
Induction cooker hob
7330 245
Finish:
Black glass ceramic
Bridge
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
electronic
programming;
Bridge function;
9 power setting
per zone plus double
Powerboost function;
touch controls;
3 slider commands for
every zone;
T-Chef function;
go&stop device;
pause; recall;
indipendent timer;
security lock
Max power
7.400 W
left
Ø 260 mm-2.600 (3.600)* (3.700)** W
center
180x220 mm-2.100 (2.600)* (3.700)** W
right
180x220 mm-2.100 (2.600)* (3.700)** W
* Powerboost - **Double Powerboost
Flat-edge: 590x520 - cut-out: 560x490
Flush-mount: 590x520 - cut-out: see web site
6)
Induction cooker hob
)7
7370 245
Finish:
Black glass ceramic
Bridge
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
166
electronic
programming;
double Bridge function;
9 power setting
per zone plus double
Powerboost function;
touch controls;
4 slider commands for
every zone;
T-Chef function;
go&stop device;
pause; recall;
indipendent timer;
security lock
Max power
7.400 W
left: 2 zones with Bridge function
180x220 mm-2.100 (2.600)* (3.700)** W
right: 2 zones with Bridge function
180x220 mm-2.100 (2.600)* (3.700)** W
* Powerboost - **Double Powerboost
S4000 Induction con Power Control
The elegance and performance of S4000 induction hobs for standard 3 kW home power supply.
PowerControl allows you to limit the absorption of your induction hob, and re-set it at any time.
Features
Version
)7
Finish:
Black glass ceramic
Max power
Technical Drawing
Flat-edge: 590x520 - cut-out: 560x490
Flush-mount: 590x520 - cut-out: see web site
6)
Induction cooker hob
PowerControl function
electronic
programming;
9 power setting
per zone plus
Powerboost function;
touch controls;
pause;
security lock
Ref.
7372 241
2.800, 3.500, 6.000, 7.200** W
left
Ø 210 mm-1.500 (2.000)* W
left sup.
Ø 145 mm-1.200 (1.600)* W
right
Ø 145 mm-1.200 (1.600)* W
right sup.
Ø 210 mm-1.500 (2.000)* W
* Powerboost
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
**thanks to PowerControl function, the max power can be selected among the following values: 2.800 W, 3.500 W, 6.000 W, 7.200 W
)7
Finish:
White glass ceramic
PowerControl function
electronic
programming;
9 power setting
per zone plus
Powerboost function;
touch controls;
pause;
security lock
Flat-edge: 590x520 - cut-out: 560x490
Flush-mount: 590x520 - cut-out: see web site
6)
Induction cooker hob
Max power
7372 141
2.800, 3.500, 6.000, 7.200** W
left
Ø 210 mm-1.500 (2.000)* W
left sup.
Ø 145 mm-1.200 (1.600)* W
right
Ø 145 mm-1.200 (1.600)* W
right sup.
Ø 210 mm-1.500 (2.000)* W
* Powerboost
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
**thanks to PowerControl function, the max power can be selected among the following values: 2.800 W, 3.500 W, 6.000 W, 7.200 W
167
S4000 Induction
Features
Version
)7
Finish:
Black glass ceramic
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
Technical Drawing
Flat-edge: 1100x350 - cut-out: 1065x325
Flush-mount: 1100x350 - cut-out: see web site
6)
Induction cooker hob
electronic
programming;
9 power setting per
zone plus
double Powerboost;
touch controls;
indipendent timer;
security lock
Ref.
7334 240
Max power
7.400 W
left
Ø 210 mm-2.050 (2.500)* (3.700)** W
center left
Ø 210 mm-2.050 (2.500)* (3.700)** W
center right
Ø 180 mm-1.850 (2.300)* (3.000)** W
right
Ø 180 mm-1.850 (2.300)* (3.000)** W
* Powerboost - **Double Powerboost
Q4: 900x450 - cut-out: see web site
Flush-mount: 900x450 - cut-out: see web site
4
Induction cooker hob
)7
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
Finish:
Black glass ceramic
electronic
programming;
9 power setting per
zone plus
Powerboost function;
touch controls;
Slider command;
pause; recall;
temperature
maintenance;
indipendent timer;
security lock
7311 240
Max power
7.400 W
left
Ø 200 mm-2.300 (3.000)* W
center
Ø 160 mm-1.100 (1.400)* W
right
Ø 200 mm-2.300 (3.000)* W
*Powerboost
Flat-edge: 800x520 - cut-out: 650x490
Flush-mount: 800x520 - cut-out: see web site
6)
Induction cooker hob
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
168
Finish:
Black glass ceramic
electronic
programming;
9 power setting per
zone plus
Powerboost function;
touch controls;
Slider command;
go&stop device;
pause; recall;
temperature
maintenance;
indipendent timer;
security lock
)7
Max power
7332 240
7.400 W
left
Ø 250 mm-2.300 (3.000)* W
center
Ø 180 mm-1.200 (1.400)* W
right
Ø 220 mm-2.300 (3.000)* W
right sup.
Ø 160 mm-1.200 (1.400)* W
* Powerboost
Elettra Induction
The new Elettra induction hobs feature a quirky and innovative design. An element of originality to customize your kitchen with elegance.
Features
Version
)7
Finish:
Black glass ceramic
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
Technical Drawing
Flat-edge: 590x520 - cut-out: 560x490
Flush-mount: 590x520 - cut-out: see web site
6)
Induction cooker hob
electronic
programming;
9 power setting per
zone plus
Powerboost function;
touch controls;
indipendent timer;
security lock
Ref.
7370 231
Max power
7.100 W
left
Ø 160 mm - 1.400 (2.000)* W
left sup.
Ø 160 mm - 1.400 W
right
Ø 200 mm - 2.300 (3.000)* W
right sup.
Ø 160 mm - 1.400 W
* Powerboost
Flat-edge: 590x520 - cut-out: 560x490
Flush-mount: 590x520 - cut-out: see web site
6)
Induction cooker hob
)7
7331 231
Finish:
Black glass ceramic
Max power
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
electronic
programming;
9 power setting per
zone plus
Powerboost function;
touch controls;
indipendent timer;
security lock
Ø 160 mm - 1.400 (2.000)* W
left sup.
Ø 160 mm - 1.400 W
right
Ø 200 mm - 2.300 (3.000)* W
* Powerboost
)7
Finish:
Black glass ceramic
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
Flat-edge: 290x520 - cut-out: 270x500
Flush-mount: 290x520 - cut-out: see web site
6)
Induction cooker hob
electronic
programming;
9 power setting per
zone plus
Powerboost function;
touch controls;
indipendent timer;
security lock
6.400 W
left
Max power
7322 231
3.400 W
superior
Ø 160 mm - 1.400 W
bottom
Ø 200 mm - 1.400 (2.000)* W
* Powerboost
169
S1000 Induction
A classic-line hobs, with the elegant Q4 profile for standard built-in or flush-mount installation. The 60 cm model can be limited up to 3kW of power.
Features
Version
4
Black glass
PowerControl function
electronic programming;
9 power setting per
zone plus Powerboost Max power
function;
left
touch controls; pause; left sup.
full safety system
right
right sup.
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
Technical Drawing
)7
Induction cooker hob
NEW
Ref.
Q4: 580x510 - cut-out: 560x490
Flush-mount: 580x510 - cut-out: see web site
7370 300
2.800, 3.500, 6.000, 7.200** W
Ø 210 mm-1.500 (2.000)* W
Ø 145 mm-1.200 (1.600)* W
Ø 145 mm-1.200 (1.600)* W
Ø 210 mm-1.500 (2.000)* W
* Powerboost
)7
Q4: 290x510 - cut-out: 270x490
Flush-mount: 290x510 - cut-out: see web site
Induction cooker hob
NEW
4
Black glass
electronic programming;
9 power setting per
zone plus Powerboost
function;
Max power
touch controls;
superior
full safety system
bottom
7322 300
3.700 W
Ø 200 mm-2.300 (3.000)* W
Ø 160 mm-1.400 W
* Powerboost
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
**with the PowerControl function, the maximum power can be set at any time among the following values
170
S4000 Domino
With the Domino series by Foster you can fully equip an entire kitchen according to your own taste. All the appliances and sinks are perfectly coordinated in terms of design, materials
and shape to offer a uniform display on the worktop.
Features
Induction cooker hob
4
Finish:
Black glass ceramic
)7
electronic
programming;
9 power setting
per zone plus
Powerboost function;
touch controls;
indipendent timer;
security lock
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
Version
cooking zone
3.000 W
Ø 250 mm-2.300 (3.000)* W
Accessories: spacer
(see page 173)
electronic
programming;
9 power setting
per zone plus
Powerboost function;
touch controls;
indipendent timer;
security lock
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
7321 240
* Powerboost
Q4: 380x520 - cut-out: 350x490
Flush-mount: 380x520 - cut-out: see web site
4
Finish:
Black glass ceramic
Bridge
Technical Drawing
Q4: 380x520 - cut-out: 350x490
Flush-mount: 380x520 - cut-out: see web site
Max power
Induction cooker hob
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
Ref.
)7
Max power
7322 240
3.700 W
superior
Ø 200 mm-2.300 (3.000)* W
bottom
Ø 160 mm-1.200 (1.400)* W
* Powerboost
Accessories: spacer
(see page 173)
Induction cooker hob
4
Finish:
White glass ceramic
7341 245
)7
electronic
programming;
Bridge function;
9 power setting
Max power
3.700 W
per zone plus double
2
zones
with
Bridge
function
Powerboost function;
touch controls;
180x220 mm-2.100 (2.600)* (3.700)** W
2 slider commands for
* Powerboost - **Double Powerboost
every zone;
T-Chef function;
pause; recall;
indipendent timer;
security lock
Accessories: spacer
(see page 173)
Flat-edge: 380x520 - cut-out: 350x490
Flush-mount: 380x520 - cut-out: see web site
171
S4000 Domino
Features
Domino Wok
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
S4000.Domino.Teppan.IS.2
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
Induction cooker hob
Finish:
Black glass ceramic
electronic
programming;
9 power setting plus
double Powerboost;
Slider command
touch control;
T-Chef function;
pause;
go&stop device;
indipendent timer;
security lock
Version
Ref.
Technical Drawing
5 mm edge: 400x520 - cut-out: 370x490
Flush-mount: 400x520 - cut-out: see web site
)7
7320 240
Max power
center
3.200 W
2.300 (2.600)* (3.200)** W
* Powerboost - **Double Powerboost
Accessories:
2 (page 133)
spacer (see page 173)
Induction cooker hob
steel surface;
7325 445
2 independent cooking
areas A and B;
9 power setting
per zone;
electronic
programming;
touch-control;
Max power
2 slider commands;
2 indipendent timers;
2 cooking zones
pause;
security lock;
electronic temperature
control from
120° to 220°C
Accessories: spacer
(see page 173)
Domino Grill
Dimension: 380x520 - cut-out: 360x490
2.800 W
2x1.400 W
Q4: 380x520 - cut-out: 360x500
Flush-mount: 380x520 - cut-out: see web site
4
Stainless steel AISI 304
brushed base;
cast iron grid;
)7
7326 000
7 power settings;
supplied with 1,6 Kg
of volcanic stone
power supply:
single-phase 230V~1P+N
frequency
50÷60 Hz
172
Accessories: spacer
(see page 173)
Max power
A
2.500 W
S4000 Domino
Finish
Ref.
Stainless
steel
8320 000
Spacer for Domino elements
The stainless steel jointing profile, allows
the various Domino elements (vertical edge)
to be coupled together with wide distance.
Dimensions:
30x520 mm
Also available in "taylor-made" version
(on request), the spacer allows to increase
the space between Domino elements, thus
creating a practical working surface.
Notice on installation in modular continuous solution
Installation with separate cut-outs
For proper continuous installation a distance of 20 mm among the products
cutouts should be maintained (with the exception of a 18 mm distance
between the hood and another product). To ensure the vertical alignment of
the products we recommend a unique cut-out depth of 500 mm, regardless
what is mentioned in the user’s manuals (480, 490, 500 mm, depending
on model).
Installation with single cut-out using spacer
By using spacers you can install products in a single cut-out of 500 mm in
depth and in length equal to the sum of dimensions of products and spacers,
decreased of 20 mm. In the following example, from links: (380 +30 +30 +380
+120 +450 +30 +30 +400) mm-20 mm = 1830 mm
spacer
S4000 Domino is configured as a Q4 built-in. However, due to design constraints, some products have a slightly greater thickness. This produces a small step between the products when installed
in continuous: Teppan, Wok and hood. For proper evaluation refer to each model drawings which give the exact thickness.
173
Modular Induction Series
Maximum freedom
Modular Induction is a new Foster proposal that offers full freedom to compose your
induction hob according to the available space and your specific needs.
Countless possibilities
The three models of hobs, different for diameter and power, can be positioned with
great flexibility in combinations of two, three or four zones controlled by their own
touch controls.
Intuitive installation
The installation is quick and easy thanks to the connection box, easy to fit under the
worktop, which connects the plates to the touch controls.
Matching to your style
Modular Induction is available in black or white version, for a perfect harmony with
your worktop and your kitchen.
1774
174
Modular Induction Series - touch control module
connection box
Touch controls module
Slider function;
electronic indipendent
programming of cooking zones;
to be ordered with matching connection box
Connection cable lenght: 80 cm
Note: the touch control module requires a simple
configuration, depending on the combination of plates
associated, as indicated in the installation manual.
power supply:
single-phase 230V~1P+N
two-phase 400V~2P+N
frequency
50÷60 Hz
4 zones touch control
Dimensions: 275x150 mm R75
Flush-mount cut-out: see web site
)7
Version
Ref.
black
+
7368 040
+
7369 040
connection
box
)7
white
+
connection
box
3 zones touch control
)7
black
+
connection
box
)7
white
+
connection
box
2 zones touch control
)7
black
+
connection
box
)7
white
+
connection
box
Possible zones combinations:
- 2 zones 7361 27*
- 2 free zones (any model)
7368 045
+
7369 040
7368 030
+
7369 030
Possible zones combinations:
- 1 zone 7361 27*
- 2 free zones (any model)
7368 035
+
7369 030
7368 020
+
7369 020
Possible zones combinations:
- 2 free zones (any model)
7368 025
+
7369 020
Modular Induction connections
27 cm
30 cm
Arrangement of items
The Modular system allows the
free postioning of its elements.
The only limit is the length of the
cables connecting the elements to
the connection box: 80 cm for the
touch module and 100 cm for the
cooking zones.
Connection box
The installation is easy and intuitive.
The box can be placed wall mounted
behind the cabinet or inside it, below
the cooker hob.
Cooking areas combination
The hob can be created freely;
some combinations among not
compatible plates are reported in the
notes of the Touch Control Modules.
35 cm
175
Modular Induction Series - cooking zones
Features
Ø 350 induction zones
Version
flush-mount cut-out: see web site
black
7363 350
white
7363 355
Max power
2.300 (3.000)* W
* Powerboost
flush-mount cut-out: see web site
)7
Electronic
programming;
9 power setting per
zone plus
Powerboost function;
Slider control;
touch control;
go&stop device;
safety lock
Connection cable
lenght: 100 cm
Ø 270 induction zones
Technical Drawing
)7
Electronic
programming;
9 power setting per
zone plus
Powerboost function;
Slider control;
touch control;
go&stop device;
safety lock
Connection cable
lenght: 100 cm
Ø 300 induction zones
Ref.
black
7362 300
white
7362 305
Max power
2.300 (3.000)* W
* Powerboost
flush-mount cut-out: see web site
)7
Electronic
programming;
9 power setting per
zone plus
Powerboost function;
Slider control;
touch control;
go&stop device;
safety lock
Connection cable
lenght: 100 cm
black
7361 270
white
7361 275
Max power
1.100 (1.400)* W
* Powerboost
Example of composition and how to order it
The component elements of a Modular Induction system must be ordered
individually. This allows maximum flexibility in the design phase.
Before you order, we recommend to check the following:
- identify the installation area for the connection box and check that the
distances between it and the elements (touch controls and cooking zones)
are smaller than the lengths of the connecting cables included;
- verify that the combination of the selected cooking plates is a possible.
As example, we list below the items to be ordered for the composition of the
picture on the left:
N. 1-7368 030 - black glass 3-zones touch controls
N. 1-7369 030 - 3-zones connection box
N. 1-7363 350 - Black glass cooking zone Ø 350 mm
N. 1-7362 300 - Black glass cooking zone Ø 300
N. 1-7361 270 - Black glass cooking zone Ø 270 mm
176
Vitroline Hi-light
Features
Version
)7
left
7316 000
4.100 W
Ø 140 mm-1.200 W
center
Ø 180 mm-700/1.700 W
right
Ø 140 mm-1.200 W
Q4: Ø 520 - cut-out: Ø 500
Flush-mount: Ø 520 - cut-out: see web site
4
)7
7316 100
Max power
left
4.100 W
Ø 140 mm-1.200 W
center
Ø 180 mm-700/1.700 W
right
Ø 140 mm-1.200 W
Dimension: Ø 520 - cut-out: Ø 500
Finish:
black / st. steel
glass ceramic
stainless steel frame;
halogen plates
high-light;
residual heat warning
lights;
8 power setting per
zone;
power supply:
220-230 V 50-60 Hz
Q4: Ø 520 - cut-out: Ø 500
Flush-mount: Ø 520 - cut-out: see web site
Max power
Finish:
White glass ceramic
multiple zones;
security lock;
halogen plates
high-light;
residual heat warning
lights;
touch controls;
9 power setting per
zone;
power supply:
220-230 V 50-60 Hz
Technical Drawing
4
Finish:
Black glass ceramic
multiple zones;
security lock;
halogen plates
high-light;
residual heat warning
lights;
touch controls;
9 power setting per
zone;
power supply:
220-230 V 50-60 Hz
Ref.
STD
Max power
left
7352 010
4.000 W
Ø 140 mm-1.200 W
center
Ø 180 mm-1.800 W
right
Ø 140 mm-1.200 W
177
Induction PRO Pots collection
Often the performance of induction hobs is impaired by the kind of pots being used.
Induction PRO is a range of pots with professional features, directly tested by us to ensure the best result with every kind of cooking: induction, hi-light, gas.
Ref.
Ref.
Ref.
8210 008
8211 000
8212 000
Set of Induction PRO pots, 8 pcs.
In 18/10 stainless steel
Triple bottom steel/aluminium /steel,
thermo-welding with Impact Bonding technology.
Professional handles with 6 welding spots
Washable in dishwasher
Induction PRO Wok pan with flat bottom
In 18/10 stainless steel - Ø 30 cm
Triple bottom steel/aluminium /steel,
thermo-welding with Impact Bonding technology.
Washable in dishwasher
Induction PRO steak-pan
in aluminium, Teflon coated DuPont Platinum plus
Aluminium-steel thermo-fused bottom - 30x30 cm
Bakelite handle
Washable in dishwasher
• 1 Pot Ø cm 24
• 1 Deep casserole Ø cm 20
• 1 Deep casserole Ø cm 24
• 1 Saucepan Ø cm 16
• 1 Pan Ø cm 24
• 1 Milkpot Ø cm 12
• 1 Glass lid Ø cm 20
• 1 Glass lid Ø cm 24
Ref.
Ref.
8213 000
8173 000
Induction PRO Moka coffee-maker
In 18/10 stainless steel
Adapter for 2-4 cups
178
S4000 Domino wok pan
In 18/10 stainless steel - Ø 36 cm
Engineered for the S4000 domino Wok induction hob
Washable in dishwasher
Ovens, Microwave and Coffee Machine
A complete range of modern, efficient household appliances: from FL, KS, KE and Milano maxi ovens with their 90 cm width to the practical
dimensions of the Elettra Compact oven - barely 36 cm high - the ideal solution for any space-related need is always on hand. Foster offers
modular products that allow for creating coordinated design solutions by combining multifunctional ovens with microwave+grill ovens, with
multifunctional ovens including the steam cooking system, or even with multifunctional ovens with pyrolysis self-cleaning (models with 46
cm and 60 cm height and maximum capacity of up to 72 litres).
S4000 p. 184
ovens
FL p. 189
Micro Combi
KS p. 192
ovens
S4000 p. 185
Micro-Grill
FL p. 189
Combi Steam
Milano p. 193
oven
S4000 p. 185
Combi Steam
FL p. 190
Coffee Machine
Elettra p. 194
Compact
S4000
Plate-warmer module p. 185
FL
Plate-warmer module p. 190
1000 p. 194
Series
S4000 p. 186
Coffee Machine
KE p. 191
ovens
Country p. 195
ovens
FL p. 188
ovens
KE p. 191
Micro-Combi
179
Features
Easy-Clean enamelling
180° reversible opening
The Easy-Clean enamelling makes the internal
oven surfaces and accessories non-adhesive,
while the limited porosity ensures durability and
easy cleaning.
In the models with this feature, the door opens
fully through 180°.
The version supplied by Foster opens on the
left but the customer can easily mount the door
opening on the right.
Totally or partially extractable
telescopic guides
Most of Foster ovens feature telescopic guides
on three levels which improve space distribution
and ensure easy and safe extraction of grids and
pans.
36
46
60
180
45 60 90
Stop Sol glass
Cooking chamber capacity
Modularity
The special screening and mirroring treatment
of external glass gives the oven an elegant and
modern aesthetic. The oven remains dark when
not in use, once the illumination is switched on,
the inside is perfectly visible.
With a cooking chamber capacity of 72 litres and
6 different cooking levels, Foster ovens top their
category for guaranteed capacity featured on a
60x60 cm built-in oven.
XL means that those models feature a capacity
exceeding 60 litres.
The range of ovens with 46 cm height adds to the
traditional 60 cm size with the dual purpose of
solving space-related problems and configuring
various combinations. The Elettra Compact
solution is ideal for installation in small spaces,
while the 90 cm-wide Milano, FL, KE and KS ovens
are the perfect solution for kitchens without any
space constraints.
Heat probe
Self-Cooking
Removable glasses
Records the temperature at the core of the
product at all times. Once the cooking temperature has been set, the oven signals when the
foodstuffs are ready and deactivates the heating
elements.
Thanks to the extensive recipe menu made
available by Self-Cooking technology and the
food temperature control by Heat probe (where
available), you can turn into a good cook in short
time. Those who are already expert cooks can create
their personal cook book by memorizing the recipes
in the oven.
The glass of the door of the oven can be
removed for complete cleaning. In the picture
the system of KE oven: the glass can be removed
with a simple “click”.
Features
Self-cleaning pyrolysis
S4000 model 7139 043 comes with the Pyrolysis feature., an efficient, automatic cleaning system that guarantees oven cleanliness and saves our time.
Periodically the Pyrolysis self-cleaning can be
activated with 3 possible programs, according
to the oven degree of dirt.
As soon as you press the Pyrolysis button, the
oven door locks and the cooking chamber
heats to almost 500°C reducing any cooking
residue to fine ash.
Once the self-cleaning cycle has finished, all
you have to do is use a damp cloth or sponge
to remove the layer of fine ash; no detergent
required.
Foster offers an oven range entirely in A Class. An important
result which proves the high quality, targeted to optimize
performance and savings.
Anti-touch finish
Triple glass door
Full-Glass door
All Foster ovens are equipped with a multiple glass door (up to
3 glasses, 4 for the pyrolytic models). This device ensures low
temperatures of external surfaces and lower heat loss.
In many models the inside of the oven door constitutes a single
smooth glass surface making it practical for cleaning purposes.
Fast preheating
Thermal insulation and tangential fan
This function turns on the heating elements and a flow of hot air
raises the temperature to 200°C within a very short time.
The muffle is carefully designed to provide the appliance’s
supporting structure with a high degree of insulation. The
tangential ventilation, featured in all models, creates a flow of
air between the muffle and framework, thereby reducing the
temperature of the external surfaces. As consequence, the oven
does not expose furniture to temperature schock.
The new ovens are offered with the innovative anti-touch finish
which, thanks to its special protection, safeguards the steel
surfaces from the annoying fingerprints.
Ovens accessories
Pyrex tray
Refractory plate
The purity and elegance of Pyrex glass
for perfect cooking,
from oven straight to
table.
Dimensions:
42 x 31 x 2 cm
Plate in refractory
material with high
heat capacity giving
a natural cooking
process.
Pizzas and focacce
cook just like in a
wooden oven.
Ref.
Ref.
1 8802 000
35x35x2 cm
2b 9401 506
57x35,5x1,5 cm
single level
telescopic
guides kit
Self-cleaning
catalytic panels
Thanks to their special
enamel-finish surfaces,
these panels facilitate the
spontaneous elimination
of any residue spattered
during usual cooking at
around 200°C (392° F).
Ref.
Description
4a 8800 016
3 Kit panels
63 lt ovens
4b 8800 017
3 Kit panels
72 lt ovens
Dimensions
2a 8801 000
Ref.
5 8807 108
181
Multifunctional ovens cooking functions
The wide range of available programs allows Foster ovens to be performing in any situation: from delicate pastry cooking to the meat
or pizza intensive ones.
Lower-level cooking
Suitable for heating foodstuffs.
Central grill
Ideal for toasting or cooking small portions au gratin.
Upper-level cooking
Suitable for cooking particularly delicate foodstuffs and for keeping
them warm after cooking
Double grill
Heat is generated by the upper grill only: ideal for toasting, cooking
au gratin and browning foodstuffs and also suitable for meat, fish
and pasta.
Traditional cooking
The ideal function for all traditional recipes, including bread, cakes
and roasts.
Lower-level cooking + grill
To complete static cooking and to cook au gratin simultaneously.
Ventilated cooking
The combination of ventilation and circular heating elements
allows for cooking different types of foodstuffs together, without
mixing aromas and flavours.
Lower-level cooking + double grill
To complete the static cooking giving the right crispiness to
preparations.
Intensive cooking
The upper and lower heating elements and the fan ensure rapid,
uniform cooking. Ideal for cooking pizzas, roasts, lasagne and
savoury pies.
Energy saving
Programme that ensures limited energy consumption, ideal for
heating foodstuffs or for foodstuffs that require delicate, gradual
cooking.
Fast preheating
This function turns on the heating elements and a flow of hot air
raises the temperature to 200°C within a very short time.
Fan + grill
The combined action of the fan and grill produces rapid and
thorough cooking of thick foodstuffs.
Fan + double grill
For the final stages of cooking of foods such as roasts and poultry, to
give the surfaces the right browning.
Thawing
Allows for thawing foodstuffs in one-third of the normal time
through uniform distribution of the air at ambient temperature.
Keep warm
Ideal to keep at the right temperature before serving.
Pizza function
The combination of lower-level, ventilated and grill cooking allows
for obtaining a crisp, optimally done pizza.
Low temperatures
Program for a slow and gentle cooking at contained temperatures.
Grill+Spit
The grill and spit combination produces perfect browning of
foodstuffs.
Gas ovens cooking functions
Gas ventilated cooking
The combination of ventilation and heat from the bottom burner
allows good performances and uniform cooking.
182
Gas grill
Heat is generated by a second gas burner on the upper level,
functioning without ventilation: ideal for toasting, cooking au gratin
and browning foodstuffs and also suitable for meat, fish and pasta.
Steam ovens cooking functions
The Foster range features two different steam ovens with different characteristics, to meet different
needs.
S4000 combi steam oven is a top-class product of excellent performances and great flexibility.
It can be considered as a gastronomic oven thanks to a sophisticated technology deriving from
professional solutions. Steam cooking is combined with convection and creates a complete set of
programs ensuring excellent results for all dishes
The new FL solution is a classic steam oven, it features a controlled generation of steam in external
boiler, to guarantee perfect results, short heating times and large autonomy of water.
Steam cooking
Particularly recommended for cooking vegetables. Preserves all the
foodstuffs’ nutritional properties.
Convection + steam
Mixed system that combines the flow of warm air with vapour for
obtaining tasty dishes.
Convection cooking
A cooking system that implements hot air.
Professional cooking
Ideal for all foodstuffs subject to leavening, thanks to the two
cooking phases.
Food warmer
Suitable for simultaneously warming up multiple foodstuffs in a
practical, rapid and cost-efficient way.
Delicate cooking
Ideal for slow cooking of meat, thanks to the temperature controlled
by a heat probe.
Microwave oven cooking functions
Four different microwave solutions. The exclusive S4000 is characterized by many
programming options and a clean appearance, perfectly matched to the multifunction and
steam ovens of the Series. The new FL and KE are complete ovens, which add to microwaves
and grill also convection cooking, making it possible an incredible set of cooking programs. So
much convenience for S1000 micro+grill, perfectly matched to the many steel ovens.
Microwave oven cooking
Ideal for cooking or rapidly heating vegetables, rice, fish, meat and
liquids. Different power levels are available.
Convection cooking
The combination of ventilation and circular heating element
generates a uniform heat for a effective and homogeneous cooking.
Grill
For rapidly crusting the surface of foodstuffs. Moreover, the Crunch
plate provided creates a crusty layer even on the underside of
foodstuffs.
Convection microwave
The movement of air generated by the fan ensures better
homogeneity of micro cooking.
Fan plus grill
The combined action of the fan and grill allows a fast and deep
cooking, effective for foods of large volume.
Automatic thawing
Allows for thawing foodstuffs by setting the latter’s weight and type.
Micro+grill cooking
A combined cooking method that is ideal for lasagne, potatoes,
roasts and pies.
Pre-set programmes
A series of programmes can be selected for heating, cooking,
thawing or cooking several types of foodstuffs.
183
S4000
Finish
4000 Series
brushed
anti-touch
Technical Drawing
7134 043
586
multifunctional PL 60x60 - 72 litres
Ref.
7
Model
>=
56
0
40
5
590
-50
564
598
75
586
564
55
598
5
BOTTOM
COOKING
TRADIT.
COOKING
FANNED
COOKING
FANNED +
GRILL
ENERGY
SAVING
INTENSIVE
COOKING
DOUBLE
GRILL
25
560
>
40 =560
-50
590
• Multifunctional oven 60x60 cm, 72 litres capacity • 10 cooking functions • 6 cooking
levels • Reversible side-opening door (PL) • Touch Control opening • Touch controls •
Display with intuitive electronic programming • Automatic cooking with programmed
recipes • Heat probe for temperature control • 10 customizable recipes • Fast-preheating
function • Cooling system with tangential ventilation • 3 fully extractable telescopic
guides • Door: 3-glazed • StopSol glass • Full-Glass door • Removable door glasses • EasyClean enamelling • Protection for grill heating element • Safety shut-off • Anti-touch
finish • Indipendent inside light • Energy class: A • Power supply: 220-240 V 50-60 Hz
Standard accessories: 2 EasyClean enamelled trays - 1 stainless steel grid
Accessories: 1-2a-4b (see page 181)
CENTRAL
GRILL
DEFROSTING
PIZZA
FUNCTION
4000 Series
multifunctional pyrolytic 60x60 - 63 litres
brushed
anti-touch
15
Reversible door opening with
touch-control display
(no handle)
7139 043
580
50
>=
56
40
0
5
583
-50
560
5
184
TRADIT.
COOKING
FANNED
COOKING
FANNED +
GRILL
ENERGY
SAVING
INTENSIVE
COOKING
DOUBLE
GRILL
CENTRAL
GRILL
600
118
580
560
54
BOTTOM
COOKING
22
550
>
40 =560
-50
583
• Pyrolytic oven 60x60 cm, 63 litres capacity • 10 cooking functions • Pyrolysis selfcleaning • Touch controls • Display with intuitive electronic programming • Automatic
cooking with programmed recipes • 10 customizable recipes • Fast-preheating function
• Cooling system with tangential ventilation • Door: 4-glazed • StopSol glass • FullGlass door • Removable door glasses • Pyrolytic enamelling • Protection for grill heating
element • Safety shut-off • Door lock during pyrolysis • Indipendent inside light • Antitouch finish • Energy class: A • Power supply: 220-240 V, 50-60 Hz
Standard accessories: 2 EasyClean enamelled trays - 1 stainless steel grid
Accessories: 1-2a (see page 181)
DEFROSTING
PIZZA
FUNCTION
598
S4000
4000 Series
multifunctional 60x60 - 63 litres
Finish
Ref.
brushed
anti-touch
Technical Drawing
15
Model
7131 053
580
50
>=
combined steam 60x46 - 26 litres
brushed
anti-touch
FANNED
COOKING
FANNED +
GRILL
ENERGY
SAVING
INTENSIVE
COOKING
DOUBLE
GRILL
5
583
560
22
600
580
118
550
>
40 =560
-50
560
54
598
5
CENTRAL
GRILL
DEFROSTING
PIZZA
FUNCTION
7135 080
100
4000 Series
TRADIT.
COOKING
0
-50
20
BOTTOM
COOKING
56
40
583
• Multifunctional oven 60x60 cm, 63 litres capacity • 10 cooking functions • Touch
controls • Display with intuitive electronic programming • Automatic cooking
with programmed recipes • Heat probe for temperature control • 10 customizable
recipes • Fast-preheating function • Cooling system with tangential ventilation • 3
fully extractable telescopic guides • Door: 3-glazed • StopSol glass • Full-Glass door •
Removable door glasses • Easy-Clean enamelling • Protection for grill heating element
• Safety shut-off • Anti-touch finish • Indipendent inside light • Energy class: A
• Power supply: 220-240 V 50-60 Hz
Standard accessories: 2 EasyClean enamelled trays - 1 stainless steel grid
Accessories: 1-2a-4a (see page 181)
50
450
5
>
85 =56
-90 0
560
24
558
460
100
435
• Combined steam oven 60x46 cm, 26 litres capacity • 6 cooking functions • Touch
controls • Display with intuitive electronic programming • Automatic cooking with
programmed recipes • Heat probe for temperature control • 10 customizable recipes
• Cooling system with tangential ventilation • Door: 3-glazed • StopSol glass • FullGlass door • Stainless steel cooking chamber • Safety shut-off • Anti-touch finish •
Indipendent inside light • Energy class: A • Power supply: 220-240 V 50-60 Hz
Standard accessories: 1 tray - 1 perforated tray - 1 stainless steel grid
54
597
4
4000 Series
micro+grill 60x46 - 32 litres
FOOD
WARMER
brushed
anti-touch
PROFESSIONAL
COOKING
CONVECTION
COOKING
CONVECTION
+ STEAM
DELICATE
COOKING
7136 020
8
STEAM
COOKING
453
50
AUTOMATIC
THAWING
455
100
597
8
PRE-SET
PROGRAMMES
Cut-out: 560x(135 mm + H oven cut-out)
10
85
50
56
-90
0
121
>=
4
22
560
22
545
52
5
595
121
• Module 60x14 cm • Slide-out drawer • Stainless steel chamber • Max temperature:
85°C • Suitable to warm and maintain the temperature of food • Maximun load 25 kg
• Power supply: 220-240 V 50-60 Hz
10
7138 000
135+H*
plate-warmer module - 60x14
brushed
anti-touch
MICROWAVE
+ GRILL
54
135
4000 Series
GRILL
22
558
Standard accessories:
1 Integrated rotating plate Ø 32 cm - 1 Crunch plate - 2 grids at different heights
MICROWAVE
COOKING
2
450
>
85 =55
-90 0
560
447
• Micro+grill 60x46, 32 litres capacity • 5 cooking functions • 6 power settings:
200-400-600-800-1000 W (1500 W Grill) • Touch controls • Display with intuitive
electronic programming • Automatic defrosting by time and weight • 3 customizable
cooking fuctions • Cooling system with tangential ventilation • StopSol glass • FullGlass door • Stainless steel cooking chamber • Anti-touch finish •
Power supply: 220-240 V 50 Hz
185
S4000 Coffee Machine
Model
Serie 4000
coffee machine
Finish
brushed
anti-touch
Ref.
Technical Drawing
2999 000
60
0
0
60
450
• AISI 304 Anti-touch finish • Automatic functioning • Coffee supply in beans •
Adjustable grinding (10 levels) • Warm water and steam supply • Adjustable strength
and size of coffee • 2,5 liter water tank with descaling filter • LED lighting • Low water
level indicator • Cleaning funds warning light
0-
8
56
454
56
49
2
Detail of the fine LED lighting of the S4000 Coffee
machine.
S4000 Coffee machine has a simple and effective
drawer opening, which makes it easy to load the
coffee beans and water, and to clean out the coffee
grounds.
The perfect matching between S4000 ovens and coffee machine, further
enriched by the addition of plate-warmer units, which are particularly
useful both for food preparations and in the rite of preparing a highquality coffee.
186
597
The telescopic system of the dispenser allows the
use of different coffee cups and glasses.
FL
NEW
Heat probe
Records the temperature at the core of
the product at all times. Once the cooking
temperature has been set, the oven
signals when the foodstuff s are ready and
deactivates the heating elements.
Telescopic guides
FL multifunction ovens, in both 60 and
90 cm versions, are equipped with twolevels telescopic guides that favor a better
distribution of the spaces and make easier
the extraction of the trays.
Self Cooking
All the convenience of an advanced
programming, controlled by a simple
touch. A truly complete set of 14 different
cooking functions is accompanied by 17
preset cooking programs for a simple and
immediate use.
Equipments
Great attention to detail even for the
accessories. Two XXL trays of different
heights, the stainless steel grid and a
practical accessory for the extraction of
the trays are the standard equipment of
the oven.
Combi-Micro
Thanks to the three different principles of cooking FL
combi-micro is a really complete oven: microwave,
convection and grill are combined into an amazing
set of programs.
Steam oven
For a healthy and tasty cooking that does not alter
the structure of foods and enhances colors, flavors
and fragrance. The steam is generated in an external
boiler allowing great rapidity and great autonomy
for long cooking at low temperature.
187
FL
FL White series
NEW
Ref.
WHITE
7105 142
Technical Drawing
140
85
multifunctional 60x60 - 65 litres
Finish
30
Model
413,5
42
>=
55
0
85
TRADIT.
COOKING
FL Black Mirror series
multifunctional 60x60 - 65 litres
INTENSIVE
COOKING
NEW
FANNED
COOKING
PIZZA
FUNCTION
CENTRAL
GRILL
DOUBLE
GRILL
BOTTOM COOK. BOTTOM COOK.
+ GRILL
+ DOUBLE GRILL
FANNED +
MAXI GRILL
8
590
595
120
480
560
53
8
FANNED +
GRILL
595
LOW
HEAT
TEMPERATURE MAINTENANCE
140
30
BOTTOM
COOKING
22
7105 642
BLACK MIRROR
85
UPPER
COOKING
560
558
>=
85 550
-90
590
• Multifunctional oven60x60 cm, 65 litres capacity • 14 cooking functions • 17 automatic
cooking programs • touch control display • intuitive electronic programming • Heat
probe for temperature control • Fast pre-heating function • Collapsible double grill •
2 fully extractable telescopic guides • Door: 3-glazed • Full-Glass door • Removable
door glasses • Chromed handle • Easy-Clean enamelling • Protection for grill heating
element • Cooling system with tangential ventilation • Asimmetric double halogen
light, light-on at door opening • Door contact switch • Safety shut-off • Energy class:
A • Power supply: 220-240V 50-60Hz
Standard accessories: 1 tray (code 9401 539) and 1 drip tray XXL (code 9401 538),
stainless steel grid and trays handle
Accessories: 1-2a (see page 181)
-90
413,5
42
>=
55
85
TRADIT.
COOKING
INTENSIVE
COOKING
FL White - 90
FANNED
COOKING
NEW
multifunctional 90x48 - 91 litres
PIZZA
FUNCTION
CENTRAL
GRILL
WHITE
DOUBLE
GRILL
BOTTOM COOK. BOTTOM COOK.
+ GRILL
+ DOUBLE GRILL
FANNED +
MAXI GRILL
FANNED +
GRILL
FANNED
COOKING
CENTRAL
GRILL
DOUBLE
GRILL
BOTTOM COOK.
+ GRILL
FANNED +
MAXI GRILL
595
595
LOW
HEAT
TEMPERATURE MAINTENANCE
Standard accessories:
deep tray
stainless steel grid
Accessories: 2b (see page 181)
7107 142
FANNED +
BOTTOM COOK.
10
396
42
475
>
85 =55
-90 0
860
860
53
890
8
NEW
multifunctional 90x48 - 91 litres
Standard accessories:
deep tray
stainless steel grid
Accessories: 2b (see page 181)
BLACK MIRROR 7107 642
10
• Multifunctional oven90x48 cm, 91 litres capacity • 9 cooking
functions • Display con programmazione elettronica di iniziofine cottura e Retractable selection knobs • Collapsible double
grill• 2 telescopic guides • Door: 3-glazed • Chromed handle •
Full-Glass door • StopSol glass • Removable door glasses • EasyClean enamelling • Protection for grill heating element • Cooling
system with tangential ventilation • Asimmetric double halogen
light, light-on at door opening • Door contact switch • Energy
class: A • Power supply: 220-240V 50-60Hz
396
42
475
>
85 =55
-90 0
6
FL Black Mirror - 90
22
845
470
475
INTENSIVE
COOKING
120
8
85 >=55
-90 0
TRADIT.
COOKING
8
590
53
• Multifunctional oven90x48 cm, 91 litres capacity • 9 cooking
functions • Electronic programming of start-end of cooking
• Retractable selection knobs • Collapsible double grill • 2
telescopic guides • Door: 3-glazed • Chromed handle • FullGlass door • Removable door glasses • Easy-Clean enamelling •
Protection for grill heating element • Cooling system with
tangential ventilation • Asimmetric double halogen light, lighton at door opening • Door contact switch • Energy class: A •
Power supply: 220-240V 50-60Hz
BOTTOM
COOKING
480
560
480
BOTTOM
COOKING
>=
85 550
-90
6
UPPER
COOKING
860
22
FANNED
COOKING
CENTRAL
GRILL
DOUBLE
GRILL
BOTTOM COOK.
+ GRILL
FANNED +
MAXI GRILL
FANNED +
BOTTOM COOK.
470
INTENSIVE
COOKING
475
TRADIT.
COOKING
480
845
85 >=55
-90 0
BOTTOM
COOKING
860
53
8
188
22
558
590
• Multifunctional oven60x60 cm, 65 litres capacity • 14 cooking functions • 17 automatic
cooking programs • Touch control display • intuitive electronic programming • Heat
probe for temperature control • Fast pre-heating function • Collapsible double grill •
2 fully extractable telescopic guides • Door: 3-glazed • Full-Glass door • Removable
door glasses • Chromed handle • StopSol glass • Easy-Clean enamelling • Protection for
grill heating element • Cooling system with tangential ventilation • Asimmetric double
halogen light, light-on at door opening • Door contact switch • Safety shut-off • Energy
class: A • Power supply: 220-240V 50-60Hz
Standard accessories: 1 tray (code 9401 539) and 1 drip tray XXL (code 9401 538),
stainless steel grid and trays handle
Accessories: 1-2a (see page 181)
0
-90
560
890
FL
FL White series
mircro combi 60x46 - 32 litres
NEW
Finish
Ref.
Technical Drawing
WHITE
7104 120
10
Model
302
42
mircro combi 60x46 - 32 litres
NEW
BLACK MIRROR
FANNED +
GRILL
MICROWAVE
COOKING
MICROWAVE
+ GRILL
455
100
52
0
595
MICROWAVE
+ FANNED
7104 620
10
FL Black Mirror series
GRILL
3
450
445
560
Standard accessories: 1 Integrated rotating plate Ø 32 cm - 1 stainless steel grid
glass tray
CONVECTION
COOKING
22
558
85 >=55
-90 0
460
• Combi microwave + grill + convection oven 60x46 cm - 32 litres • 1000 W microwave
with 5 power settings • Selectable Grill 1500W • Max temperature 220°C • 6 cooking
functions • 12 automatic cooking programs + 3 customizable cooking fuctions • Touch
control display • Intuitive electronic programming • Stainless steel cooking chamber •
Cooling system with tangential ventilation • 0-90 minutes timer • Automatic defrosting
by time and weight • Disconnectable rotating plate • Full-Glass door • Chromed handle •
Safety shut-off • Power supply: 220-240V 50Hz
>
85 =55
-90 0
560
302
42
52
steam oven 60x46 - 35 litres
NEW
WHITE
FANNED +
GRILL
MICROWAVE
COOKING
MICROWAVE
+ GRILL
0
595
MICROWAVE
+ FANNED
7103 180
10
FL White series
GRILL
455
100
445
560
Standard accessories: 1 Integrated rotating plate Ø 32 cm - 1 stainless steel grid
glass tray
CONVECTION
COOKING
22
558
85 >=55
-90 0
460
• Combi microwave + grill + convection oven 60x46 cm - 32 litres • 1000 W microwave
with 5 power settings • Selectable Grill 1500W • Max temperature 220°C • 6 cooking
functions • 12 automatic cooking programs + 3 customizable cooking fuctions • Touch
control display • Intuitive electronic programming • Stainless steel cooking chamber •
Cooling system with tangential ventilation • 0-90 minutes timer • Automatic defrosting
by time and weight • Disconnectable rotating plate • Full-Glass door • StopSol glass •
Chromed handle • Safety shut-off • Power supply: 220-240V 50Hz
3
450
>
85 =55
-90 0
560
595
DEFROST
7103 680
10
BLACK MIRROR
302
42
Standard accessories: 1 stainless steel deep tray - 1 flat perfored stainless steel tray
1 stainless steel grid
STEAM
COOKING
52
0
3
455
560
22
558
85 >=55
-90 0
100
• Steam oven 60x46 - 35 litres • Wide cooking chamber - tray dimension 40x36 cm
• Stainless steel cooking chamber • Steam cooking: 40°C - 100°C • External boiler for
fast steam generation • Touch control display • intuitive electronic programming •
Programmi specifici per pesce, carne, verdure e scongelati • Drawer-opening water
conteiner of 1,2 litres - no water connection needed • Alert light
for absence of water and descaling cycle need • Chromed handle • Door: 2 -glazed •
Full-Glass door • StopSol glass • Power supply: 220-240V 50Hz
>
85 =55
-90 0
0
56
445
NEW
0
450
steam oven 60x46 - 35 litres
52
460
FL Black Mirror series
455
100
445
560
Standard accessories: 1 stainless steel deep tray - 1 flat perfored stainless steel tray
1 stainless steel grid
STEAM
COOKING
22
558
85 >=55
-90 0
460
• Steam oven 60x46 - 35 litres • Wide cooking chamber - tray dimension 40x36 cm
• Stainless steel cooking chamber • Steam cooking: 40°C - 100°C • External boiler for
fast steam generation • Touch control display • intuitive electronic programming •
specific cooking programs for fish, meat, vegetables and forzen • Drawer-opening
water conteiner of 1,2 litres - no water connection needed • Alert light for absence of
water and descaling cycle need • Chromed handle • Door: 2 -glazed • Full-Glass door •
Power supply: 220-240V 50Hz
3
450
302
42
>
85 =55
-90 0
0
56
595
DEFROST
189
FL - coffee machine
NEW
WHITE
2998 100
• E.S.E.coffee pod system (Easy Serving Expresso: coffee, barley, tea, ginseng)
• Dispenser for steam for cappuccino) and boiling water (infusions)
• touch control display and intuitive electronic programming
• Automatic opening and closing of the pod-drawer and Safety shut-off
• Removable water tank 2.5 liters
• Sensor light for lack of water
• Side compartment (for stock pods, sugar, cups, ...)
• Removable drip tray
• LED Lighting: 3 light points
• Working pressure: 20 bar
• Power supply: 220-240 V 50Hz
Technical Drawing
45 600
mi
n
560
23,6
554
455
Coffee Machine 60x46
Ref.
440
FL White series
Finish
450
Model
28
595
8
BLACK MIRROR
2998 600
• E.S.E.coffee pod system (Easy Serving Expresso: coffee, barley, tea, ginseng)
• Dispenser for steam for cappuccino) and boiling water (infusions)
• touch control display and intuitive electronic programming
• Automatic opening and closing of the pod-drawer and Safety shut-off
• Removable water tank 2.5 liters
• Sensor light for lack of water
• Side compartment (for stock pods, sugar, cups, ...)
• Removable drip tray
• LED Lighting: 3 light points
• Working pressure: 20 bar
• Power supply: 220-240 V 50Hz
45 600
mi
n
560
23,6
554
455
NEW
440
Coffee Machine 60x46
450
FL Black Mirror series
28
595
8
FL - plate-warmer module
7104 100
BLACK MIRROR
7104 600
• Push-pull opening with telescopic guides
• Stainless steel inner with non-slip coating
• Heating resistors with level control
• Max temperature: 85°C
• Maximun load: 15 kg
• Power supply: 220-240V 50-60Hz
5
WHITE
>=
55
0
85
-90
135
140
NEW
Technical Drawing
22
8
560-56
22
540
53
5
595
135
Plate-warmer 60x14 - 24 litres
Ref.
140
FL
Finish
140+H*
Model
*Cut-ou: 560x(140 mm + H oven cut-out)
Coffee Pod System
Fl uses the E.S.E. system, with standard pods easy-tofind, not only for each brand of coffee, but also for
ginseng, barley, tea and various infusions...
190
A genuine Bar
FL also dispenses boiling water and steam for the
traditional preparation of tea and herbal teas, and
to produce a dense foam a for perfect cappuccino!
Simple maintenance
The coffee machine does not require connection
to the water supply. Tthe large water tank is easy to
access, an indicator alerts the need for filling.
KE
Finish
KE series
Ref.
brushed
anti-touch
multifunctional 60x60 - 63 litres
Technical Drawing
7142 043
9
Model
578
45
>=
55
60
560
brushed
anti-touch
multifunctional 60x60 - 63 litres
FANNED
COOKING
FANNED +
GRILL
INTENSIVE
COOKING
ENERGY
SAVING
120
578
595
600
560
54
596
0
DOUBLE
GRILL
22
555
>
60 =580
-10
0
CENTRAL
GRILL
BOTTOM COOK.
+ GRILL
7141 042
9
KE series
TRADIT.
COOKING
8
0
Standard accessories: 1 tray e 1 drip tray with EasyClean enamelling XXL
1 stainless steel grid
Accessories: 1-2a (see page 181)
BOTTOM
COOKING
0
-10
590
• Multifunctional oven 60x60 cm, 63 litres capacity • 9 cooking functions • Electronic
programming of start and end of cooking • Heat probe for temperature control •
Cooling system with tangential ventilation • 2 telescopic guides • Door: 3-glazed •
Full-Glass door • Removable door glasses • Easy-Clean enamelling • Protection for
grill heating element • Anti-touch finish • Energy class: A
• Power supply: 220-240 V 50-60 Hz
578
45
micro combi 60x46 - 44 litres
brushed
anti-touch
NEW
BOTTOM COOK.
+ GRILL
FANNED +
GRILL
8
590
120
578
595
600
560
54
596
0
DEFROSTING
6
KE series
DOUBLE
GRILL
22
555
>=
60 580
-10
0
Standard accessories: 1 tray e 1 drip tray with EasyClean enamelling XXL
1 stainless steel grid
Accessories: 1-2a (see page 181)
BOTTOM
COOKING
>=
55
0
-10
0
560
60
• Multifunctional oven 60x60 cm, 63 litres capacity • 5 cooking functions • Electronic
programming of start and end of cooking • Cooling system with tangential ventilation
• 1 telescopic guide • Door: 2-glazed • Full-Glass door • Removable door glasses • EasyClean enamelling • Protection for grill heating element • Anti-touch finish • Energy
class: A • Power supply: 220-240 V 50-60 Hz
7146 020
305
42
• Combi oven convection+grill+microwave 60x46 cm - 44 litres • Microwave 900 W •
Convection and grill 1750W • Max temperature 230°C • 10 cooking functions • LED display
with touch-control and konbs • 15 automatic programs • Finger-proof finish • Stainless
steel cooking chamber • Door: 3-glazed • Tangential ventilation • 0-90 minutes timer •
Automatic defrosting by time and weight • Rotating plate ø 36 cm • Full-Glass door •
Power supply: 230 V 50 Hz
95
445
Standard accessories:
2 stainless steel grids (grill grids with different hight)
1 round enamelled baking pan
MICROWAVE
COOKING
KE series
FANNED
COOKING
NEW
GRILL
FANNED BOTTOM
COOKING
55
0
MICROWAVE
+ FANNED
MICROWAVE
+ VENT. GRILL
MICROWAVE
+ GRILL
FANNED BOTTOM
+ MICROWAVE
AUTOMATIC
THAWING
brushed
anti-touch 7126 047
8
multifunctional 90x60 - 103 litres
FANNED +
GRILL
22
558
• Multifunctional oven 90x60 cm, 103 litres gross volume • 8
cooking functions • Electronic programming of start and end
of cooking • Digital display • Cooling system with tangential
ventilation • Door: 2-glazed • StopSol glass • Full-Glass door •
Easy-Clean enamelling • Protection for grill heating element
• Indipendent inside light • Anti-touch finish • Power supply:
220-240 V 50-60 Hz
43
>=
586
90
56
0
860
21
TRADIT.
COOKING
INTENSIVE
COOKING
FANNED
COOKING
CENTRAL
GRILL
DOUBLE
GRILL
FANNED +
GRILL
FANNED +BOTTOM
COOKING
586
BOTTOM
COOKING
590
113
>=
5
90 60
582
826
Standard accessories: 2 grids
1 enamelling drip tray
Accessories: 2b (see page 181)
860
54
5
895
191
KS
brushed
anti-touch
Technical Drawing
7120 043
355
multifunctional PL 60x60 - 63 litres
Ref.
175
KS series
Finish
15
Model
583
>=
55
0
85
-90
multifunctional PP 60x60 - 63 litres
brushed
anti-touch
FANNED +
GRILL
INTENSIVE
COOKING
ENERGY
SAVING
DOUBLE
GRILL
591
564
52
598
5
CENTRAL
GRILL
DEFROSTING
15
KS series
FANNED
COOKING
25
117
575
>=
85 550
-90
Standard accessories: 2 EasyClean enamelled trays - 1 stainless steel grid
Accessories: 1-2a (see page 181)
TRADIT.
COOKING
40
564
525
583
• Multifunctional oven 60x60 cm, 63 litres capacity • 8 cooking functions • Reversible
side-opening door (PL) • Electronic programming of start and end of cooking •
Retractable selection knobs • Cooling system with tangential ventilation • 3 fully
extractable telescopic guides • Door: 3-glazed • StopSol glass • Full-Glass door •
Removable door glasses • Easy-Clean enamelling • Protection for grill heating element
• Anti-touch finish • Energy class: A • Power supply: 220-240 V 50-60 Hz
7120 053
580
41
>=
56
40
multifunctional PP 60x60 - 63 litres
brushed
anti-touch
FANNED +
GRILL
INTENSIVE
COOKING
ENERGY
SAVING
DOUBLE
GRILL
600
118
580
>
40 =560
-50
560
54
598
5
CENTRAL
GRILL
22
DEFROSTING
30
KS series
FANNED
COOKING
5
583
560
Standard accessories: 1 tray with EasyClean enamelling - 1 drip tray
2 stainless steel grids
Accessories: 1-2a-4a (see page 181)
TRADIT.
COOKING
0
-50
550
583
• Multifunctional oven 60x60 cm, 63 litres capacity • 8 cooking functions • Electronic
programming of start and end of cooking • Retractable selection knobs (PP) • Cooling
system with tangential ventilation • 2 telescopic guides • Door: 3-glazed • StopSol
glass • Full-Glass door • Removable door glasses • Easy-Clean enamelling • Protection
for grill heating element • Anti-touch finish • Energy class: A • Power supply: 220-240
V 50-60 Hz
7122 051
415
45
590
595
120
490
560
54
595
5
KS series
multifunctional PP 60x46 - 42 litres
DOUBLE
GRILL
brushed
anti-touch
BOTTOM COOK.
+ GRILL
FANNED +
GRILL
DEFROSTING
7123 040
15
BOTTOM
COOKING
23
555
>=
60 580
-10
0
600
Standard accessories: 1 XXL tray e 1 drip tray with EasyClean enamelling XXL
1 stainless steel grid
Accessories: 1-2a (see page 181)
>=
55
0
-10
0
560
60
• Multifunctional oven 60x60 cm, 63 litres capacity • 5 cooking functions • End of
cooking time • Cooling system with tangential ventilation • 1 telescopic guide •
Door: 2-glazed • Full-Glass door • Removable door glasses • Easy-Clean enamelling
• Protection for grill heating element • Anti-touch finish • Energy class: A • Power
supply: 220-240 V 50-60 Hz
455
43
54
5
TRADIT.
COOKING
192
FANNED
COOKING
FANNED +
GRILL
INTENSIVE
COOKING
ENERGY
SAVING
DOUBLE
GRILL
CENTRAL
GRILL
DEFROSTING
22
558
455
100
560
560
435
85 >=56
-90 0
460
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
Accessories: 1-2a (see page 181)
>
85 =56
-90 0
450
• Multifunctional oven 60x46 cm, 42 litres capacity • 8 cooking functions • End of
cooking time • Retractable selection knobs (PP) • Cooling system with tangential
ventilation • Door: 3-glazed • StopSol glass • Full-Glass door • Removable door glasses
• Easy-Clean enamelling • Protection for grill heating element • Anti-touch finish •
Indipendent inside light • Energy class: A • Power supply: 220-240 V 50-60 Hz
597
KS
KS 60 gas
Ventilated gas 60x60 - 63 litres
Finish
Ref.
brushed
anti-touch
Technical Drawing
17
Model
7191 061
574
41
>=
0
-90
600
• Ventilated gas oven 60x60 cm, 63 litres capacity • 2 cooking functions • Gas grill •
Under-knob ignition •Safety valves • End of cooking time • Cooling system with
tangential ventilation • Door: 2-glazed • StopSol glass • Easy-Clean enamelling • Antitouch finish • Power supply: 220-240 V 50-60 Hz
560
24
591
465
560
117
556
>=
85 550
-90
600
Standard accessories: 1 grid - 2 enamelled drip trays
55
85
Accessories: 1-2a (see page 181)
53
598
0
GAS
VENTILATED
KS 90
GRILL GAS
Foster
brushed
7126 046
15
multifunctional PP 90x60 - 105 litres
577
41
>=
585
90
56
0
3
865
24
113
577
>=
5
90 60
595
855
585
• Multifunctional oven 90x60 cm, 105 litres gross volume
• 8 cooking functions
• Electronic programming of start and end of cooking
• Retractable selection knobs (PP)
• Cooling system with tangential ventilation
• Door: 3-glazed
• StopSol glass
• Full-Glass door
• Easy-Clean enamelling
• Anti-touch finish
• Power supply: 220-240 V 50-60 Hz
865
53
896
0
Standard accessories: 2 grids - 1 enamelling drip tray
Accessories: 2b (see page 181)
TRADIT.
COOKING
FANNED
COOKING
FANNED +
GRILL
INTENSIVE
COOKING
GRILL
CENTRAL
GRILL
ENERGY
SAVING
DEFROSTING
Milano
16
>=
90 560
SUPERIOR
COOKING
TRADIT.
COOKING
865
865
470
54
5
FANNED
COOKING
FANNED +
GRILL
22
860
>
90 =560
Standard accessories:
1 grid
1 tray with EasyClean enamelling
1 spit - self-cleaning catalytic panels
Accessories: 2b (see page 181)
BOTTOM
COOKING
54
457
• Multifunctional oven 90x47 cm, 73 litres capacity
• 9 cooking functions
• Electronic programming of start and end of cooking
• Cooling system with tangential ventilation
• Telescopic guides
• Door: 3-glazed
• StopSol glass
• Easy-Clean enamelling
• Indipendent inside light
• Energy class: A
• Power supply: 220-240 V 50 Hz
13
7167 052
5
Foster
brushed
8
NEW
Technical Drawing
457
multifunctional 90x47 - 73 litres
Ref.
467
Milano 90
Finish
467
Model
INTENSIVE
COOKING
GRILL
DEFROSTING
895
GRILL +
SPIT
193
Elettra
Model
Elettra Compact
Ref.
Technical Drawing
dark glass
7170 052
6
ventilated 60x36 - 35 litres
Finish
349
42
85
5
85
-90
24
360
555
98
55
0
560
349
>=
353
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
-90
>=
55
0
560
353
• Ventilated oven 60x36 cm, volume 35 litres • 3 cooking functions • Electronic
programming of start and end of cooking • Cooling system with tangential ventilation
• Door: 3-glazed • StopSol glass • Easy-Clean enamelling • Full-Glass door • Anti-touch
finish • Energy class: A • Power supply: 220-240 V 50 Hz
Accessories: 1-2a (see page 181)
54
0
CENTRAL
GRILL
FANNED
COOKING
595
FANNED +
GRILL
1000 Series
Model
Technical Drawing
7102 042
24
9
150
brushed
anti-touch
142
multifunctional 60x60 - 60 litres
Ref.
62
S1000 Series
Finish
582
44
>=
50
50
585
0
560
5
• Multifunctional oven 60x60 cm, 60 litres capacity • 5 cooking functions • Indipendent
inside light • Timer 0-60 min • Cooling system with tangential ventilation • Easy-Clean
enamelling • Energy class: A • Power supply: 220-240 V 50-60 Hz
582
596
585
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
115
24
>=
50 500
560
54
594
5
TRADIT.
COOKING
Micro+Grill S1000
brushed
anti-touch
INTENSIVE
COOKING
DOUBLE
GRILL
LIGHT
7151 000
13
micro+grill 60x38 - 25 litres
FANNED +
GRILL
370
• Micro+grill 60x38 cm, 25 litres capacity • 5 cooking functions • 6 power settings up
to 900 W (1000 W Grill) • Electronic programming • Automatic defrosting by time and
weight • Stainless steel cooking chamber • Power supply: 220-240 V 50 Hz
380
-90
Standard accessories: 1 grid - 1 rotating plate
37
0
MICROWAVE
COOKING
194
GRILL
MICROWAVE
+ GRILL
AUTOMATIC
THAWING
PRE-SET
PROGRAMMES
20
388
370
550
5
20
85
>=
55
0
560
595
Country series
Model
Country series
multifunctional 60x60 - 60 litres
Color
Ref.
Technical Drawing
anthracite
7101 642
>=
595
• Multifunctional oven 60x60 cm, 60 litres capacity • 5 cooking functions • Indipendent
inside light • Analogue clock • Programmable start-end of cooking • Cooling system
with tangential ventilation • Easy-Clean enamelling • Energy class: A
• Power supply: 220-240 V 50-60 Hz
0
560
21
596
588
>=
50 500
115
543
595
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
50
50
560
Accessories: 5 (see page 181)
53
594
5
TRADIT.
COOKING
Country series
FANNED +
GRILL
copper
multifunctional 60x60 - 60 litres
INTENSIVE
COOKING
DOUBLE
GRILL
LIGHT
7101 342
>=
595
• Multifunctional oven 60x60 cm, 60 litres capacity • 5 cooking functions • Indipendent
inside light • Analogue clock • Programmable start-end of cooking • Cooling system
with tangential ventilation • Easy-Clean enamelling • Energy class: A
• Power supply: 220-240 V 50-60 Hz
0
560
21
596
588
>=
50 500
115
543
595
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
50
50
560
Accessories: 5 (see page 181)
53
594
5
TRADIT.
COOKING
Country series
FANNED +
GRILL
DOUBLE
GRILL
LIGHT
7101 242
oats
multifunctional 60x60 - 60 litres
INTENSIVE
COOKING
>=
595
• Multifunctional oven 60x60 cm, 60 litres capacity • 5 cooking functions • Indipendent
inside light • Analogue clock • Programmable start-end of cooking • Cooling system
with tangential ventilation • Easy-Clean enamelling • Energy class: A
• Power supply: 220-240 V 50-60 Hz
0
560
21
596
588
115
543
>=
50 500
595
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
50
50
560
Accessories: 5 (see page 181)
53
594
5
Country series
FANNED +
GRILL
ivory
multifunctional 60x60 - 60 litres
INTENSIVE
COOKING
DOUBLE
GRILL
LIGHT
7101 542
>=
595
• Multifunctional oven 60x60 cm, 60 litres capacity • 5 cooking functions • Indipendent
inside light • Analogue clock • Programmable start-end of cooking • Cooling system
with tangential ventilation • Easy-Clean enamelling • Energy class: A
• Power supply: 220-240 V 50-60 Hz
0
560
21
115
588
543
>=
50 500
595
Standard accessories: 1 tray with EasyClean enamelling - 1 stainless steel grid
50
50
596
TRADIT.
COOKING
560
Accessories: 5 (see page 181)
53
5
TRADIT.
COOKING
FANNED +
GRILL
INTENSIVE
COOKING
DOUBLE
GRILL
594
LIGHT
195
Hoods
In the modern kitchen the cooker hood has an increasingly important role, both as an interior design object and as a tool to improve the
pleasure of using and living the kitchen.
Fulfilling the dual principle of aesthetics and functionality, the Foster hoods perfectly follow the modern design guidelines, offering at the
same time efficient performances and high manufacturing standards.
196
Modular p. 202
FL p. 210
KS 90 p. 217
Cloud p. 203
KE Mirror p. 211
Pitagora p. 218
Sky p. 204
Master p. 212
Garage p. 219
Ghost p. 205
Q p. 213
Wing p. 220
S4000 p. 207
Q inox p. 214
Flat p. 221
S4000 Mirror p. 208
Cilindro p. 215
Flat inox p. 222
Maya p. 209
KS Lux p. 216
Silent power
Power and quietness are the two principal features of a cooker hood, even though they are often in contrast with one-another. The continuous
strive for the best compromise is however nowadays able to achieve surprising results. All the Foster solutions have an outstanding suction
power which makes them efficient and well-performing in all conditions of use, both in extracting and filtering modes. All this is achieved
quietly, thanks to motors and aerodynamic solutions carefully studied to reduce the acoustic impact to a minimum.
High performance motors
Noise level (dB (A))
The motors of the S4000 hoods have a high suction
capacity, topping the 1000 m3/h. Their refined design
hides a powerful appliance with professional features.
105
(rock concert)
Standard Motor
65
(office)
50
(living room)
40
(library)
49
43
34
Silent System motors
35
53
44
41
1a speed
2a speed
3a speed
4a speed
24
The new Silent System motors sport a very high
efficiency leading to top suction-power coupled with
reduced consumption and a noise-level 10 times lower
compared to standard solutions.
0
Silent System motor
100 200 300 400 500 600 700 800
Aspiration (m3/h)
A hood for every kitchen
A really complete range, with every kind of hood. Non only different looks, but also different functioning principles, in order to be able to
choose the hood which fits each one’s needs.
Wall-mount hoods
Island hoods
Ceiling-mount suction systems
A large range of choices in size, shape,
materials and functionality.
For many models an island version is also
available. These hoods are easy to install
thanks to the telescopic chimneys.
These are not mere hoods for aspiring
cooking fumes, but complete ventilation
systems, engineered to improve the quality
of the air and the comfort of your living space.
Table hoods
Built-in hoods
Custom-made hoods
Elegant and minimalistic solutions which
perfectly match the Domino and In-line
cooker hobs, both gas and induction.
These special solutions are craftily studied
to disappear within the kitchen cabinets,
nevertheless maintaining their own
personality and great functionality.
Foster specialises in tailor-made solutions.
As for the worktops, also for the hoods
Foster is able to manufacture custommade products according to the
customer’s drawing, always guaranteeing
the best match between worktop and
cooker hood, in terms both of design and
kind and finish of steel.
197
Filters
All the Foster hoods are, in their original configuration, suction hoods, and are equipped with greese, beehive, multilayer, anodized aluminium
filters. Wherever it is not possible to install a suction hood, the addition of active carbon filters (available as accessory) can transform the hood
in “filtering” hood.
Stainless steel filters
In many models, especially the ones where the filter is in plain sight,
the aluminium filtering element is covered in stainless steel. This
solution improves the look and increases the durability of the product.
Remark: the greese filters can periodically be washed in the dishwasher
in order to bring them back to their original filtering efficiency. It is however
recommended to use a low-temperature programme (max. 40° C) to avoid any
deformation and colour-change of the aluminium surfaces.
Standard stainless steel filter
Hi-class stainless steel filter
It guarantees an excellent filtering
function, thanks to the double
stainless steel filtering layer, and as
many as five layers of aluminium
beehive structure.
It features a peculiar and elegant
look, as well as an heightened
filtering power due to the sevenlayer structure.
Perimeter suction
The perimeter suction is a feature common to many Foster hoods. The
filters are hidden by steel- or crystal plates and the suction occurs along
their perimeter. This has aesthetic advantages but also functional ones:
the cleaning is easier, the suction power and noise-level are improved.
The depression which occurs in the perimeter area facilitates in fact
the suction of the particles composing the fumes.
Balanced suction system
This feature, exclusively available on Foster hoods, improves the
suction uniformity on the whole surface, thanks to a specific, irregular
perforation pattern that compensates the loss of suction power in the
terminal tracts. it is particularly efficient in the island hoods and in the
wall hoods of large size (120 cm).
120 cm
3%
13%21%
26%
120 cm
21% 13% 3%
Optimal suction
zone
198
10% 12%
18%
20%
18%
Optimal suction zone
90 cm
90 cm.
cm
standard hood
with balanced suction
12% 10%
Lighting
The Foster hoods have different lighting systems, all intended to create a comfortable and safe illumination of the cooking space, with a keen
eye on energy saving.
LED lighting
Neon lighting
Many Foster hoods feature a LED lighting system, with 10 times less power
consumption and 10 times more durability. The LED lighting furthermore makes
a very comfortable and efficient light.
The Ghost table hood is equipped with a neon lighting system that ensures an
homogeneous and extended illuminated area even though the light source is
close to the cooker hob.
Halogen lighting
Low-consumption lighting
For a more powerful lighting of the cooking area. The halogen spotlights are
equipped with a push-pull opening mechanism that makes it possible to replace
the lamp in a quick and easy way.
The ceiling suction systems are intended to be the main lighting source of the
kitchen. The Modular system therefore features low-consumption lamps, which
guarantee a long life and a considerable energy saving.
Digital control
Almost all Foster hoods are equipped with advanced electronic
controls that allow a perfect control and improve the efficiency of
the engines. The different solutions favor the aesthetic or functional
aspect with additional functions such as digital thermometer and
the timer, always useful for keep control of your preparations.
Easy
Advance
Minimal
Remote control
The ceiling suction systems and the Maya hoods are equipped with a remote
control to easily activate all their functions from any position.
Touch
199
Special functions
Auto Mode function
Filter-cleaning alarm
With the Auto function the hood has temperature sensors and it can
automatically set the suction power according to the heat developed
by the cooker hob underneath.
This function keeps track of the hours of use of the hood and signals
the need to wash the filters in order to maintain the perfect efficiency
of the hood.
Off-Timer
Safe&Clean system
All the models with electronic interface can be programmed to turn
off the suction at a postponed moment, so as to prolong the aeration
of the room even after the cooking has been completed.
The Safe&Clean system features a stainless steel panel installed
between the hood’s filters and motor. The panel constitutes a flat and
easy-to-clean surface, it improves the suction homogeneity on the
whole surface and is also an efficient safety system because it prevents
the fan and electronic parts from being easily accessible.
Rear exit mode
The motor can be rotated by 90°. In consequence the air outlet can be
directed towards the back, the classical solution, but also toward the
wall, with direct exit towards a specifically foreseen duct. With this kind
of installation the chimney is therefore no longer necessary and is, in
consequence, supplied as an option.
Accessories
Silencing kit
It consists of a sound-absorbing, highly flexible and extendable tube, which can
reduce the noise-level of the hood by as much as 7 dB(A). It also functions as
thermal insulation. It is available as accessory for all the hoods in suction mode,
with 120 and 150 mm diameter.
cod. 9700 602
silencing kit 10 mt ø 120 mm
cod. 9700 603
silencing kit 10 mt ø 150 mm
Intake manifolds for ceiling systems
These make it possible to channel the various possible configurations of the ceiling suction systems into a single pipe.
code 2525 000
code 2523 000
intake manifold for 4 pipes ø 120 mm
intake manifold for 2 pipes ø 120 mm
code 2524 000
code 2526 000
intake manifold for 3 pipes ø 120 mm
intake manifold for 2 pipes ø 150 mm
Example of installation of a Modular system with four
suction units (1 control module + 3 slave modules). The
use of sound-absorbing pipes (silencing kit) between the
hoods and the intake manifold reduces the noise-level of
the system by as much as 7 dB(a).
200
Choice suggestions
The correct choice of power and kind of installation are important in order to achieve good performances, efficiency, noise-level and consumption. In order to avoid
possible mistakes when buying, we list hereafter some suggestions to make the choice easier.
Choice of the flow capacity
The suction power of the hood must be correctly dimensioned compared to
the volume of the room in which it is installed, in order to ensure a correct
air circulation. The optimal air flow can be calculated by multiplying the
volume of the room by 12 (number of complete air volume replacements in
one hour). For ceiling suction systems it I recommended to calculate an air
replacement of 15 cycles/hour.
h
m2
Kitchen area
x
h
Kitchen height
x
12
Number of complete air replacements
per hour
=
m2
m3/h
Air flow (necessary suction power)
Positioning on the cooker hob
The optimal height above the cooker hob is 65 cm and anyway
comprised between 60 and 70 cm. For wall hoods with inclined
suction surface, this height is determined starting from the
median point of the filtering area.
Min 60 cm
Max 70 cm
Min 60 cm
Max 70 cm
Min
Max*
Max 70 cm
Min 60 cm
Max 70 cm
150 cm
For the ceiling systems a ceiling-panelling height of maximum 150 cm from the
cooker hob is recommended. The fixing systems of the hood makes it possible
to regulate the distance between ceiling and panelling, based on specific needs.
*See min. and max. dimensions for each specific model.
Width of hood
The dimension of the hood must be adapted to the size of the cooker
hob underneath. A slightly larger hood compared to the hob will
ensure an optimized suction.
Placement of pipelines
It is advisable to foresee exiting air ducts as straight as possible,
without bends or corners. A tortuous exit-duct will determine a loss
of suction power and therefore a less-than-optimal performance.
Moreover, it is important not to connect the air exit-duct with
chimneys of other appliances or heating boilers.
90 cm
60 cm
60 cm
Air currents
In order for the hood to perform efficiently it is important to position
it in a place not subject to air streams.
60 cm
60 cm
Hood bigger than the
cooking area: OPTIMAL
Hood equal to the
cooking area: ADEQUATE
90 cm
Hood smaller than the
cooking zone: INADEQUATE
201
Modular
Modular Control & Subordinate
Ref.
modular
control
2518 001
modular
subordinate
2519 001
Technical Drawing
Modular Control & Subordinate
ceiling modular suction system
Finish:
satin stainless steel - white glass
1 grease filter
4 speeds
LED Low consumption lighting
Perimetric aspiration
Automatic delayed shutdown
130
26
5
220
310
The Control module (which is necessary) can control up
to three Subordinate modules (for a total of maximum
4 suction units). The Light modules can be added to the
system without limitation of number.
Model
Ø120
Remote control included in Modular Control model only
Air flow rate: 600 m3/h
Air exhaust hole: Ø 120 mm
Motor power: 140 W
36
0
36
0
Suspended ceiling height:
min 220 mm / max 310 mm
Note: the height of the hood and the cooking surface suggests the
use of at least two modules for an adequate suction.
“Filtering mode” option not available for this model
accessories:
Modular Light
silencing kit Ø 120 mm
Ref.
9700 602
intake manifold for 2 pipes - in Ø120 / out Ø150 mm
2523 000
intake manifold for 3 pipes - in Ø120 / out Ø200 mm
2524 000
intake manifold for 4 pipes - in Ø120 / out Ø200 mm
2525 000
modular light
2520 001
130
Suspended ceiling height:
min 220 mm / max 310 mm
Note: the electrical system of the Modular Light module is independent
from that of the hood modules. Soon will be available a connection kit
for the simultaneous lighting of the lights.
202
26
5
220
310
Modular light
Finish:
satin stainless steel - white glass
LED Low consumption lighting
36
0
0
36
Cloud
Ref.
Cloud 90
Technical Drawing
2521 090
90 cm
Ceiling suction hood
Finish:
satin stainless steel - white glass
Remote control included
2 grease filters
4 speeds
Halogen illumination 4x20 W
Perimetric aspiration
Automatic delayed shutdown
42
700
min 200
max 300
0
12,
Air flow rate: 1200 m3/h
Air exhaust hole: Ø 120 mm (x2)
Motor power: 280 W
8
900
80
0
Suspended ceiling height: min 200 mm / max 300 mm
“Filtering mode” option not available
for this model
accessories:
Ref.
9700 602
intake manifold for 2 pipes - in Ø120 / out Ø150 mm
2523 000
2521 130
130 cm
Cappa aspirante a soffitto
Finish:
satin stainless steel - white glass
Remote control included
2 grease filters
4 speeds
Halogen illumination 6x20 W
Perimetric aspiration
Automatic delayed shutdown
Air flow rate: 1720 m3/h
Air exhaust hole: Ø 150 mm (x2)
Motor power: 320 W
900
42
0
min 270
max 420
Cloud 130
silencing kit Ø 120 mm
12,
8
80
0
0
130
Suspended ceiling height: min 270 mm / max 420 mm
“Filtering mode” option not available
for this model
accessories:
silencing kit Ø 150
Ref.
9700 603
intake manifold for 2 pipes - in Ø150 / out Ø200 mm
2526 000
203
Sky
Ref.
Sky 90
Technical Drawing
2522 090
90 cm
Ceiling suction hood
Finish:
satin stainless steel
Remote control included
2 grease filters
4 speeds
LED illumination
Perimetric aspiration
Automatic delayed shutdown
42
700
min 200
max 300
0
12,
8
900
80
0
Air flow rate: 1200 m3/h
Air exhaust hole: Ø 120 mm (x2)
Motor power: 280 W
Suspended ceiling height: min 200 mm / max 300 mm
“Filtering mode” option not available
for this model
accessories:
Sky 130
silencing kit Ø 120 mm
Ref.
9700 602
intake manifold for 2 pipes - in Ø120 / out Ø150 mm
2523 000
2522 130
130 cm
Ceiling suction hood
Finish:
satin stainless steel
Remote control included
2 grease filters
4 speeds
LED illumination
Perimetric aspiration
Automatic delayed shutdown
Air flow rate: 1720 m3/h
Air exhaust hole: Ø 150 mm (x2)
Motor power: 320 W
0
12,
8
80
0
Suspended ceiling height:
min 270 mm / max 420 mm
“Filtering mode” option not available
for this model
accessories:
204
42
min 270
max 420
900
silencing kit Ø 150
Ref.
9700 603
intake manifold for 2 pipes - in Ø150 / out Ø200 mm
2526 000
0
130
Ghost
Receding completely into the worktop, the Ghost hoods combine functionality and performance with an essential and classy
design. The 120 version has been engineered for a perfect matching with the many in-line solutions of Foster, both gas and induction.
The Domino version perfectly completes the S4000 Domino cooking range.
205
Ghost
Ref.
FTS
2451 120
9
300
0
377
1175
230
34
0
Air flow rate: 800 m3/h
Height from floor: 300 mm
Dimensions on the worktop: 1175x120 mm
Cut-out:
- on-top built-in: 1142x100 mm
- flush-mount built-in: see drawing beside
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
12
2
Flush-mount table hood
Finish:
satin stainless steel - black glass
Touch control
2 grease filters
4 speeds
LED illumination
Automatic delayed shutdown
Optional filtering operation mode
79
1133
290
75
)7
740
Ghost 120 Flush-mount
Technical Drawing
1090
96
20
The Ghost hoods offer a great easiness of installation: the
motor can be positioned frontally, on the back of the
hood or detached, by means of the specific optional kit
(see drawing here next)
0
440
Cut-out for flush mount installation
Remote motor installation schemes
121 +10
100
2
1176 +10
1142
The kit is available on request for the installation of the engine remotely,
up to a distance of 5 meters.
R 3.5
accessories:
Ref.
9700 460
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
remote motor installation kit
9700 459
4
75
2451 000
500
12
S4000 Domino Ghost
2 carbon filters kit
120
340
250
720
Ø150
30
0
48
44
0
The Ghost hoods offer a great easiness of installation: the
motor can be positioned frontally, on the back of the
hood or detached, by means of the specific optional kit
(see drawing here next)
Remote motor installation schemes
The kit is available on request for the installation of the engine remotely,
up to a distance of 5 meters.
accessories:
206
8
520
75
Air flow rate: 800 m3/h
Adjustable height from table 180-300 mm
Dimensions on the worktop: 520x120 mm
Cut-out: 490x104 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
300
Table-top hood
Finish:
satin stainless steel - black glass
Touch control
1 grease filter
4 speeds
Automatic delayed shutdown
Optional filtering operation mode
2 carbon filters kit
Ref.
9700 450
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
remote motor installation kit
9700 459
200
0
91
S4000
Ref.
S4000 Wall-mounted
Technical Drawing
2440 090
90 cm
2440 120
120 cm
Wall-mounted linear suction hood
with telescopic chimney
Finish: satin stainless steel
High performance Motor
Minimal electronic control
1 grease filter
4 speeds
LED illumination
hood 90 cm: 6 LED
hood 120 cm: 9 LED
Perimetric aspiration
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 1000 m3/h
Chimney height: 590 – 970 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 320 W
accessories:
S4000 Island
carbon filter
Ref.
9700 400
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
2442 090
90 cm
2442 120
120 cm
Island suction hood with telescopic chimney
Finish: satin stainless steel
High performance Motor
Minimal electronic control
1 grease filter
4 speeds
LED illumination
hood 90 cm: 12 LED
hood 120 cm: 18 LED
Perimetric aspiration
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 1000 m3/h
Chimney height: 810 – 1220 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 320 W
accessories:
carbon filter
Ref.
9700 400
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
207
S4000 Mirror
Ref.
S4000 Mirror
Technical Drawing
2444 090
90 cm
2444 120
120 cm
Wall-mounted linear suction hood
with telescopic chimney
Finish: satin stainless steel - black tempered glass
Touch control
Stainless steel grease filters
hood 90 cm: 3 filters
hood 120 cm: 4 filters
4 speeds
LED illumination
Automode function
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 700 m3/h
Chimney height:
for suction mode 580 – 1010 mm
for filtering mode 650 – 1080 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 205 W
accessories:
S4000 Mirror Wing
*chimney height in filtering mode is:
min 650 - max 1080
carbon filter
Ref.
9700 517
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
2445 090
Wall-mounted linear suction hood
with telescopic chimney
Finish:
satin stainless steel - black tempered glass
Touch control
2 grease filters
4 speeds
LED illumination
Automode function
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 700 m3/h
Chimney height:
for suction mode 575 – 995 mm
for filtering mode 645 – 1065 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 205 W
accessories:
208
*chimney height in filtering mode is:
min 645 - max 1065
carbon filter
Ref.
9700 516
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
Maya
Ref.
hood body
2500 100
telescopic
chimney kit
2500 101
Technical Drawing
Wall-mounted linear suction hood with telescopic chimney
Finish:
satin stainless steel - white glass
Remote control included
2 stainless steel grease filter
4 speeds
LED illumination (3 LED x 4,8 W)
Automatic delayed shutdown
3
Air flow rate: 850 m /h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
200
min 670 - max 950
360 300
Maya 80 wall
Model
235
690
432
524
805
“Filtering mode” option not available
for this model
accessories:
Ref.
9700 602
silencing kit Ø 150 mm
9700 603
hood body
2501 100
chimney
h 480 mm
2501 101
chimney
h 610 mm
2501 102
chimney
h 740 mm
2501 103
chimney
h 990 mm
2501 104
Ø 240
840 / 970 / 1100 / 1350
360
Maya 64 island
silencing kit Ø 120 mm
Island suction hood
Finish: satin stainless steel - white glass
Remote control included
1 stainless steel grease filter
4 speeds
LED illumination (3 LED x 4,8 W)
Automatic delayed shutdown
490
642
Air flow rate: 850 m3/h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
“Filtering mode” option not available for this model
accessories:
silencing kit Ø 120 mm
Ref.
9700 602
silencing kit Ø 150 mm
9700 603
209
NEW
FL white
Model
Ref.
90 cm
2527 190
telescopic
chimney kit*
2527 000
Technical Drawing
300
Air flow rate: 850 m3/h
Chimney height: 310 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
FL black mirror
1140 - 1570
600
9700 602
silencing kit Ø 150
9700 603
2527 000
900
*optional in filtering mode and in aspirating
mode with retro-mode exit
silencing kit Ø 120
2527 690
0
0
Ref.
9700 601
90 cm
300
accessories:
210
1140 - 1570
600
Wall-mounted linear suction hood with telescopic chimney
Finish:
satin stainless steel - black mirror glass
Touch control
2 grease filters
4 speeds
LED illumination
Belanced Aspiration System (BAS)
Rear exit mode function
Filter-cleaning alarm
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 850 m3/h
Chimney height: 310 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
0
50
17
carbon filters kit
telescopic
chimney kit*
30
687
Wall-mounted linear suction hood with telescopic chimney
Finish:
satin stainless steel - white glass
Touch control
2 grease filters
4 speeds
LED illumination
Belanced Aspiration System (BAS)
Rear exit mode function
Filter-cleaning alarm
Automatic delayed shutdown
Optional filtering operation mode
30
0
50
17
0
0
687
FL
900
*optional in filtering mode and in aspirating
mode with retro-mode exit
carbon filters kit
Ref.
9700 601
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
KE mirror
Ref.
KE mirror white
Technical Drawing
2503 170
70 cm
2503 190
90 cm
2503 000
300
Air flow rate: 850 m3/h
Chimney height: 310 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
46
0
600
800 - 1090
0
700 /
150
900
*optional in filtering mode and in aspirating
mode with retro-mode exit
carbon filters kit
Ref.
9700 601
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
2503 670
70 cm
2503 690
90 cm
2503 000
300
Air flow rate: 850 m3/h
Chimney height: 310 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
22
0
46
0
600
800 - 1090
Wall-mounted linear suction hood
with telescopic chimney
Finish: satin stainless steel - black tempered glass
Touch control
1 grease filter
4 speeds
LED illumination
Filter saturation warning light
Automatic delayed shutdown
Rear exit mode function
Optional filtering operation mode
300
telescopic chimney*
490
KE mirror black
22
490
Wall-mounted linear suction hood
with telescopic chimney
Finish: satin stainless steel - white tempered glass
Touch control
1 grease filter
4 speeds
LED illumination
Filter saturation warning light
Automatic delayed shutdown
Rear exit mode function
Optional filtering operation mode
300
telescopic chimney*
150
700 /
900
*optional in filtering mode and in aspirating
mode with retro-mode exit
carbon filters kit
Ref.
9700 601
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
211
Master
Ref.
Master wall
Technical Drawing
2505 090
90 cm
2505 120
120 cm
accessories:
45
440
52
0
900 /
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
1200
2506 120
Island suction hood with telescopic chimney
Finish:
satin stainless steel
Advance Electronic control
4 Stainless steel grease filters
4 speeds
Illumination: 4 LED
Air flow rate: 850 m3/h
Chimney height: 540 – 1140 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
380
312
450
585 - 1185
Belanced Aspiration System (BAS)
Filter saturation warning light
Automatic delayed shutdown
Timer and Thermometer display
Optional filtering operation mode
212
300
45
Master island
300
585 - 1015
Wall-mounted linear suction hood
with telescopic chimney
Finish: satin stainless steel
Advance Electronic control
Stainless steel grease filters
hood 90 cm: 3 filters
hood 120 cm: 4 filters
4 speeds
LED illumination
hood 90 cm: 2 LED - hood 120 cm: 3 LED
Belanced Aspiration System (BAS)
Filter saturation warning light
Automatic delayed shutdown
Timer and Thermometer display
Optional filtering operation mode
Air flow rate: 850 m3/h
Chimney height: 540 – 970 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
66
0
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
1200
Q
Q 90 wall
Model
Ref.
90 cm wall
mounted
white glass
hood body
Technical Drawing
2508 190
2508 191
white glass
0
30
2508 690
30
0
hood body
2508 691
300
90 cm wall
mounted
black glass
Wall-mounted linear suction hood with telescopic chimney
Finish:
tempered glass - satin stainless steel
Touch electronic control
3 Stainless steel grease filters
4 speeds
LED illumination
Automatic delayed shutdown
min 1210 - max 1500
900
black glass
Air flow rate: 850 m3/h
Chimney height: 300 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
0
45
0
90
“Filtering mode” option not available
for this model
accessories:
Ref.
9700 602
silencing kit Ø 120
silencing kit Ø 150
90 cm island
white glass
hood body
2509 191
white glass
2509 690
90 cm island
black glass
hood body
2509 691
black glass
Island suction hood with telescopic chimney
Finish:
tempered glass - satin stainless steel
Touch electronic control
3 Stainless steel grease filters
4 speeds
LED illumination
Automatic delayed shutdown
1350 max
900 min
Q 90 island
9700 603
2509 190
51
0
Air flow rate: 850 m3/h
Chimney height: 300 – 650 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
0
90
“Filtering mode” option not available
for this model
accessories:
silencing kit Ø 120
Ref.
9700 602
silencing kit Ø 150
9700 603
213
Q inox
Ref.
Q inox wall
Technical Drawing
2510 060
60 cm
2510 090
300
90 cm
min 1210 - max 1500
900
Air flow rate: 850 m3/h
Chimney height: 310 – 600 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
Q inox island
300
300
Wall-mounted linear suction hood
with telescopic chimney
Finish:
satin stainless steel
Easy electronic control
Stainless steel grease filters
hood 60 cm: 1 filter
hood 90 cm: 2 filters
4 speeds
LED illumination
Automatic delayed shutdown
Optional filtering operation mode
420
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
0/
60
0
90
2511 060
60 cm
2511 090
90 cm
Island suction hood with telescopic chimney
Finish:
satin stainless steel
Easy electronic control
Stainless steel grease filters
hood 60 cm: 1 filter
hood 90 cm: 2 filters
4 speeds
LED illumination
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 850 m3/h
Chimney height: 200-700 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
214
70
/8
450
650
min 850 - max 1350
570
480
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
0/
60
0
90
Cilindro
Ref.
2531 000
Wall-mounted linear suction hood
Finish:
satin stainless steel
Minimal electronic control
1 stainless steel grease filter
4 speeds
Illumination: 4 LED
Automatic delayed shutdown
Optional filtering operation mode
590
210
Air flow rate: 930 m3/h
Height: 920 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 320 W
accessories:
carbon filter
Ref.
9700 380
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
2530 000
Ø380
Telescopic island suction hood
Finish:
satin stainless steel
Minimal electronic control
1 stainless steel grease filter
4 speeds
Illumination: 4 LED
Automatic delayed shutdown
Optional filtering operation mode
920 - 1330
Cilindro island
Ø380
430
920
Cilindro wall
Technical Drawing
Air flow rate: 930 m3/h
Height: 920 – 1330 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 320 W
accessories:
carbon filter
Ref.
9700 380
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
215
KS Lux
Ref.
KS Lux
Technical Drawing
2504 081
80 cm
2504 091
90 cm
2504 121
120 cm
440
52
0
80
0
Air flow rate: 850 m3/h
Chimney height: 540 – 970 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
45
30
585 - 1015
4 speeds
LED illumination
Belanced Aspiration System (BAS)
Automatic delayed shutdown
Optional filtering operation mode
300
0
Wall-mounted linear suction hood with telescopic chimney
Finish: satin stainless steel
Easy electronic control
Stainless steel grease filters
hood 80 cm: 2 filters
hood 90 cm: 3 filters
hood 120 cm: 4 filters
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
0/
0
/9
00
12
Belanced Aspirating System (BAS)
120 cm
3%
It is a unique Foster system that improves the uniformity of
suction on the entire surface of the hood. It consists of a special irregular perforation which compensates for the loss of
suction power in end sections and is particularly effective for
stand-alone or wall-mounted hoods of considerable size (120
cm).
13%21%
26%
Optimal
intake zone
90 cm
120 cm
21% 13% 3%
10% 12%
18%
20%
Optimal
intake zone
90 cm.
cm
BAS System
216
18%
12% 10%
KS 90
Ref.
2409 001
Wall-mounted linear suction hood
with telescopic chimney
Finish:
satin stainless steel
Mechanical push-button control
3 grease filters
3 speeds
LED illumination
Optional filtering operation mode
27
8
40
Air flow rate: 600 m3/h
Chimney height: 490 – 840 mm
Air exhaust hole: Ø 120/150 mm
Motor power: 230 W
7
25
490 - 840
KS 90
Technical Drawing
0
90
47
0
accessories:
carbon filter
Ref.
9700 402
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
217
Pitagora
Ref.
Pitagora 90x90
Technical Drawing
2439 001
450 - 850
Corner suction hood with telescopic chimney section
Finish:
satin stainless steel
Minimal electronic control
2 grease filters
4 speeds
LED illumination
Automatic delayed shutdown
Optional filtering operation mode
Air flow rate: 850 m3/h
Chimney height: 450 – 850 mm
Air exhaust hole: Ø 150 mm
Motor power: 250 W
898
accessories:
218
carbon filter
Ref.
9700 409
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
90
0
22
0
42
0
40
8
89
Garage
Ref.
Garage
36
cm
60 cm
2515 060
90 cm
2515 090
120 cm
2515 120
90 cm
2516 090
120 cm
2516 120
90 cm
2517 090
120 cm
2517 120
48
cm
60
cm
Automatic delayed shutdown
Blum hinge with soft-closing mechanism
Rear exit mode function
Optional filtering operation mode
0
33
360 / 480 / 600
Fully-hidden wall suction hood
Finish: satin stainless steel
Easy electronic control
Stainless steel grease filters
hood 60 cm: 1 filter
hood 90 cm: 3 filters
hood 120 cm: 4 filters
4 speeds
LED illumination
600 / 9
00 / 12
00
3
Air flow rate: 850 m /h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
The hood is to be fixed to the wall.
It is installed in place of the suspended cabinet.
accessories:
carbon filters kit
Ref.
9700 601
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
lenght
60 cm
90 cm
120 cm
Garage hoods feature renowned
amortized Blum hinges.
36 cm
4,2 ÷ 13,6 Kg
4,2 ÷ 13,6 Kg
8,9 ÷ 18,0 Kg
The chart aside shows min and max
weights of the wing recommended for a
proper functioning of the mechanism.
48 cm
-
3,2 ÷ 10,2 Kg
6,7 ÷ 18,0 Kg
60 cm
-
5,4 ÷ 15,0 Kg
5,4 ÷ 15,0 Kg
height
219
Wing
Ref.
Wing
Technical Drawing
2512 060
60 cm
2512 090
90 cm
2512 120
120 cm
493
10
32
5
3
43 18
4
8…
Automatic delayed shutdown
Perimetric aspiration
Stainless steel protection profiles
for the hanging cabinets
Optional filtering operation mode
Air flow rate: 850 m3/h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
14
80
9
375
256
Under-cabinet built-in suction hood
Finish: satin stainless steel / glass
Easy electronic control
Aluminium greese filters
hood 60 cm: 1 filter
hood 90 cm: 1 filter
hood 120 cm: 4 filters
4 speeds
LED illumination
1160 62
860 /
1
560 / 2 / 862 / 1 1240
56 / 940 /
640
The hood is to be installed between the
shoulders of the hanging cabinet, and fixed
to the wall.
1
40
Stainless steel protection profiles for the
hanging cabinets included.
accessories:
220
carbon filters kit
Ref.
9700 601
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
Flat
Ref.
Flat white
Technical Drawing
2513 160
60 cm
2513 190
340
29
327
595 / 895 / 1195
595 / 895 / 1195
327
18
The hood is to be fixed to the shoulders
of the hanging cabinet.
Air flow rate: 850 m3/h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
2513 690
90 cm
2513 620
Air flow rate: 850 m3/h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
accessories:
279
110
29
340
348
837 / 1137
262
327
895 / 1195
84
120 cm
Under-cabinet built-in suction hood
Finish: black glass
Touch control
Grease filter
90 cm hoods: 2 filters
120 cm hood: 4 filters
4 speeds
LED stripe illumination
Automatic delayed shutdown
Perimetric aspiration
Optional filtering operation mode
895 / 1195
18
327
Flat black
348
120 cm
Under-cabinet built-in suction hood
Finish: white glass
Touch control
Grease filter
60 cm hoods: 1 filter
90 cm hoods: 2 filters
120 cm hood: 4 filters
4 speeds
LED stripe illumination
Automatic delayed shutdown
Perimetric aspiration
Optional filtering operation mode
279
110
537 / 837 / 1137
262
84
90 cm
2513 120
The hood is to be fixed to the shoulders
of the hanging cabinet.
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
221
Flat inox
Ref.
2513 090
90 cm
279
110
29
336
344
837 / 1137
262
120 cm
Under-cabinet built-in suction hood
Finish: satin stainless steel
Easy electronic control
Grease filter
90 cm hoods: 2 filters
120 cm hood: 4 filters
4 speeds
LED stripe illumination
Automatic delayed shutdown
Perimetric aspiration
Optional filtering operation mode
327
895 / 1195
80
2513 020
895 / 1195
18
327
Flat inox
Technical Drawing
Air flow rate: 850 m3/h
Air exhaust hole: Ø 120/150 mm
Motor power: 275 W
The hood is to be fixed to the shoulders
of the hanging cabinet.
accessories:
222
carbon filter
Ref.
9700 600
silencing kit Ø 120
9700 602
silencing kit Ø 150
9700 603
Refrigerators
The new built-in range brings the Foster philosophy into refrigerating products: excellence in performance accompanied by great functionality
and meticulous attention to the smallest detail.
High efficiency
Foster refrigerators ensure high performance and great power efficiency.
The entire range complies to A++ and A+ energy saving requirements, with
consumptions reduced by 40% and 25% compared to the standard A Class.
An important contribution to savings in full compliance with environmental
protection.
No frost
The No-Frost technology removes moisture from the freezer with a forced
ventilation system in controlled temperature and humidity conditions. No
more ice that reduces the usable volume, glues packings one to the other and
compromises performance. The system is full automatic and doesn’t require
unpractical manual defrosting operations.
Ventilated cooling system
The ventilation of the refrigerator area allows a perfect homogeneity of cooling
and improves the preservation of food, ensuring that it remains longer fresh.
The system also avoids the formation of odours and condensation on the walls,
without changing the internal humidity which prevents the food, especially the
fresh ones, from drying in a short time.
Climate classes
“Tropical” models offer the most extensive adaptability to climatic conditions and
temperatures, while maintaining a high efficiency and optimal consumption.
They are in fact approved for all climate classes SN, N, ST, T, with a range of
suitable temperatures from 10° C to 43° C.
223
Features
LED digital display
LED lighting
The electronic control of the functions allows for accurate programming of the
desired temperatures, both in the freezer and refrigerator compartments.
The No-frost model features an internal LED lighting system, with a greatly
improved brightness and a consumption 4 times lower than the one of
traditional lighting.
Holiday function
Fast freeze & Super cool
This function turns off only the refrigerator compartment. It is thus possible
to leave for the holidays without fears: the system will avoid all unnecessary
consumption of energy without having to empty the freezer.
These functions are available on models with digital programing; they
respectively allow the freezing and quick cooling of large quantities of food.
Door and temperature alarm
It prevents unnecessary consumption of food and energy in case of oversights
or malfunction of the machine. An acoustic alarm and a warning light on the
display indicate either the non-latching of the door, or an abnormal increase in
the internal temperature.
Fresh zone
The special Fresh Zone drawer is an ideal storage area for fresh food, be it meat
or fruit and vegetables, significantly increasing their period of preservation.
The ventilation of the refrigerator compartment is channelled directly into the
drawer, thus maintaining a constant temperature between 0° and 5° C.
Classy details
The outfit of all Foster refrigerators is finished with the utmost care and endowed with classy details and many solutions to optimize the use
of space.
224
Wine rack
Half shelves
Stainless steel details
The stylish stainless steel bottle holder makes it easier
to chill the drinks with a minimal use of space. The
slightly tilted shape can easily accommodate also
previously opened bottles.
The upper level is outfitted with two distinct shelves
which can be positioned in different ways according
to need. The space is thus optimized without losing
the possibility to store large containers.
The No-Frost model has been the object of a particular
care for every small detail in looks and finish. The
shelves and bottle holder sport a premium stainlesssteel finish.
Refrigerators
Model
Ref.
Technical Drawing
Built-in integrated refrigerator
2034 000
Energy class: A++
No-Frost Freezer
Ventilated refrigerator
Total gross capacity: 279 lt
Electronic control with LED display
Double alarm: open door / temperature
Reversible door - standard hinges on the right
size: 540x1770 mm
Climate class: SN/T (tropical +10°C / +43°C)
Annual energy consumption: 230 kWh
Freezing capacity: 7.5 kg / 24h
Power supply: 220-230V - 50Hz
Refrigerator
Fridge net capacity: 200 lt
Automatic defrost
Super-Cool quick cooling function
LED Lighting
Fresh-Zone drawer
Stainless steel wine rack
4 glass shelves
1 sectioned shelf
2 fruit & vegetable drawers
4 door shelves
1 egg holder (x12)
Freezer
Freezer net capacity: 62 lt
Automatic defrost
Fast-Freeze function
1 drawer for fast freezing
2 drawer for foods storage
1 ice cube container
min 200 cm2
min 200 cm2
Built-in integrated refrigerator
2033 000
Energy class: A+
Ventilated refrigerator
Total gross capacity: 285 lt
Reversible door - standard hinges on the right
size: 540x1770 mm
Climate class: SN/T (tropical +10°C / +43°C)
Annual energy consumption: 306 kWh
Freezing capacity: 5.0 kg / 24h
Power supply: 220-230V - 50Hz
min 200 cm2
Refrigerator
Fridge net capacity: 203 lt
Automatic defrost
Super-Cool quick cooling function
LED Lighting
Stainless steel wine rack
5 glass shelves
1 sectioned shelf
2 fruit & vegetable drawers
4 door shelves
1 egg holder (x12)
Freezer
Freezer net capacity: 70 lt
1 drawer for fast freezing
2 drawer for foods storage
1 ice cube container
min 200 cm2
225
Refrigerators
Model
Ref.
Technical Drawing
Refrigerator with freezing compartment
2031 000
Energy class: A+
Total gross capacity: 232 lt
Reversible door - standard hinges on the right
size: 540x1445 mm
Climate class: N/ST (subtropical + 16°C/+38°C)
Annual energy consumption: 263 kWh
Freezing capacity: 2.5 kg / 24h
Power supply: 220-230V - 50Hz
min 200 cm2
Refrigerator
Fridge net capacity: 183 lt
Automatic defrost
3 glass shelves
2 fruit & vegetable drawers
3 door shelves
1 egg holder (x6)
Freezer
Freezer net capacity: 49 lt
Fast freezing function
1 wire shelf
1 ice cube container
min 200 cm2
Built-in undercounter refrigerator
2030 000
Freezer
Freezer net capacity: 21 lt
1 ice cube container
mi
n5
50
600
818-898
Refrigerator
Fridge net capacity: 105 lt
Automatic defrost
2 glass shelves
1 sectioned shelf
1 fruit & vegetable drawer
1 sliding tray above vegetable drawer
3 door shelves
1 egg holder (x6)
820-900
Energy class: A+
Total gross capacity: 130 lt
Reversible door - standard hinges on the right
dimensions: 596x820 mm
Climate class: N/ST (subtropical +16°C/+38°C)
Annual energy consumption: 189 kWh
Freezing capacity: 2.0 kg / 24h
Power supply: 220-230V - 50Hz
54
5
H=820
H=900
226
100-170
180-250
How to clean steel
Stainless steel products do not need any particular servicing. However, they do require a certain care and use of adequate detergents for daily
cleaning. By and large, all that’s needed is to wash with hot water and soap or hot water and vinegar, and thoroughly rinse and dry
with a cloth. Do not use: hydrochloric acid, abrasive powders, steel wool, brushes and products for cleaning silver.
When it comes to detergents for cleaning steel, Foster recommends the products in the “Steel Clean” line:
-
all-purpose aerosol for daily cleaning use
-
microfiber cloth to wipe off traces of grease and powder.
-
professional cream to restore the original splendour of the steel, remove scaling, stubborn dirt and rust marks caused
by contact with ferrous materials.
Steel Clean - cream
Detergent cream for stainless steel
Steel Clean - microfiber
Microfiber cloths for cleaning stainless steel
250 ml bottle
pack of 3 pcs.
Ref.
Ref.
8331 000
8333 000
pack of 12 pcs.
12 pack of 3 pcs.
Ref.
Ref.
8331 012
8333 012
Steel Clean - all-purpose
All-purpose detergent with vaporizer
500 ml bottle
Steel Clean - kit
Steel cleaning kit containing:
- 1 bottle containing 250 ml of cream
- 1 bottle containing 500 ml of
all-purpose fluid
- 1 pack of 3 microfiber cloths
Ref.
8332 000
pack of 12 pcs.
cleaning kit
Ref.
Ref.
8332 012
8339 000
227
228
Foster management system is ISO 9001:2008 certified
Registration number CH-36474
Warranties
Dealers
Assistance
All Foster products conform to the EEC directive and are covered by the Foster 24-month warranty.
Our dealers are highly selected and are able to provide a professional service for our production range. For
information please consult our web site www.fosterspa.com or contact us: [email protected]
We wish to provide you with products and service that meet
your expectations. This is why Foster has a widespread network
of Technical Assistance centres in Italy and abroad.
Worldwide After-Sales Service
For an up to date list of Foster’s technical assistance centres,
consult our web site www.fosterspa.com
Each single item manufactured by Foster is branded CE, and is therefore made in compliance with the general regulations of the Europeran Union.
This publication is for international use. The featues are purely guideline. We reserve the right to modify them at any moment without notice.
The Foster organisation will be pleased to provide further details and updates about the products and services.
© Foster spa. Not to be reproduced wholly or in part without written permission of Foster spa.
Realized in collaboration with Maxistudio.
Download
Download
Foster spa - Via M. S. Ottone, 18/20 - 42041 Brescello (Re) Italy
Tel. +39 0522 687425 - Fax +39 0522 684518 - Fax export +39 0522 687639 - E-mail: [email protected]
www.fosterspa.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
