ER N G
DESIGNER SERIES
OWNER’S MANUAL AND USER GUIDE
TABLE OF CONTENTS
SECTION 1 - IMPORTANT SAFEGUARDS�����������������������������������������������������������1
SECTION 2 - UNPACKING������������������������������������������������������������������������������������������������3
SECTION 3 - GETTING TO KNOW YOUR BLENDER��������������������������������4
SECTION 4 - INSTALLATION�������������������������������������������������������������������������������������������4
SECTION 5 - OPERATIONAL OVERVIEW������������������������������������������������������������6
SECTION 6 - CARE AND CLEANING�������������������������������������������������������������������15
SECTION 7 - TROUBLESHOOTING�����������������������������������������������������������������������16
SECTION 8 - WARRANTY�����������������������������������������������������������������������������������������������18
SECTION 1: IMPORTANT SAFEGUARDS
IMPORTANT INFORMATION
Read all instructions carefully before using your Designer series blender.
This important information has been provided as required by the North American
standards indicated below. Following these instructions will help prevent injuries and
damage to the machine and will ensure that you have the best possible experience
with your Designer series blender.
1.1 SAFETY CERTIFICATION
Designer series blenders are certified by ETL under Blendtec® in
the ETL Official Listing. Conforms to ANSI/UL Std. 982 and Cert. to
CAN/CSA Std. C22.2#195.
This certification ensures that your Designer series blender has
been tested for electrical and mechanical safety. The standards indicated have
been developed over many years to prevent injury, fire, and damage. Part of the
process includes quarterly audits to ensure that Blendtec is producing equipment
to these stringent criteria.
1.2 NSF CERTIFICATION
Items included in the box which bear the NSF® mark are certified by
NSF International (NSF) under Blendtec in the NSF Official Listing.
This certification ensures that your Designer series blender has been
tested for food (sanitation) safety. The standards utilized have been
developed over many years to prevent contamination from toxic substances and
to ensure ease of cleaning. Part of the certification process includes an annual
audit to ensure that Blendtec is producing equipment to these stringent criteria.
1.3 AVOID CONTACT WITH MOVING PARTS
•ALWAYS keep fingers, hands, hair and clothing away from all moving parts.
•ALWAYS keep all utensils away from the drive socket and blender jar blades during operation as utensils may damage blades or the blender jar.
•NEVER put hands into the blender jar or add substances by hand when the
blender jar is on the motor base.
•NEVER touch the blade with your fingers whether it is on or off the motor base.
•NEVER place jar into drive socket if blender motor is operating.
•DO NOT rock or remove the blender jar during operation.
These precautions will prevent personal injury and/or damage to the blender.
1.4 NEVER OPERATE THE BLENDER IF IT APPEARS DAMAGED
If the blender malfunctions, call your service agent first. If it is dropped or damaged in any way, return the blender to a Blendtec service agent immediately for
examination, repair, electrical or mechanical adjustment, or possible replacement.
1
1.5 NEVER OPERATE BLENDER IN LIQUID
To protect against the risk of electrical shock do not put the motor base in water or
other liquid. Do not use the blender outdoors where it is subject to precipitation.
1.6 NEVER PUT NON-FOOD ITEMS INTO JAR
Utensils, rocks, and glass are dangerous if placed in jar. Damage caused by such
foreign objects will void the warranty. Keep hands and utensils out of jar while
blending to reduce the risk of severe injury to persons or damage to the blender.
Utensils may only be used when the blender is not running.
1.7 NEVER OPERATE THE BLENDER WITHOUT THE LID IN PLACE
1.8 NEVER OPERATE THE BLENDER USING ATTACHMENTS NOT
SOLD BY BLENDTEC
The use of any unauthorized attachments may cause fire, electric shock, and/or
injury and will void the warranty.
1.9 BLENDER JAR MUST BE PROPERLY IN PLACE WHILE
APPLIANCE IS OPERATING
1.10 BLADES ARE SHARP! HANDLE CAREFULLY!
1.11 WARNING, DO NOT BLEND HOT LIQUIDS OR OTHER
HOT INGREDIENTS
1.12 USE CAUTION WHEN BLENDING ON THE SOUP CYCLE
When blending on the Hot Soup cycle, friction of the blade will heat the contents.
The vented lid will allow pressure relief. Be careful not to come in contact with any
steam coming from the clear center lid.
1.13 POWER CORD PRECAUTIONS
•
NEVER operate with a damaged cord or plug. If the supply cord is damaged
it must be replaced by the manufacturer or authorized service agent to avoid
a hazard.
•
DO NOT permit the cord to hang over the edge of the work surface.
•
NEVER use an extension cord with the unit.
•
Unplug the blender motor when not in use, before changing blender
locations, or cleaning.
1.14 NEVER ATTEMPT TO REPAIR THE POWER UNIT
Never remove the blender motor cover. The blender motor does not contain selfadjustable or serviceable parts. A qualified service agent must make all service
adjustments. Removing the cover or attempting to service the blender will void
the warranty.
2
1.15 TURN THE BLENDER OFF WHEN NOT IN USE
1.16 AVOID TOUCHING THE BLENDER DRIVE SOCKET AFTER
EXTENSIVE USE
The blender drive socket may become hot after numerous cycles.
1.17 SAFETY
This appliance is not intended for use by persons (including children with
lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they do not play with the
appliance.
1.18 DESIGNER SERIES BLENDERS ARE INTENDED FOR HOME
USE ONLY! ANY USE OF THE DESIGNER SERIES BLENDER
FOR COMMERCIAL PURPOSES VOIDS ALL WARRANTIES
1.19 NEVER OPERATE THE BLENDER WITH MORE THAN THE
MARKED CAPACITY OF THE JAR
SECTION 2: UNPACKING
SAVE ALL PACKAGING MATERIALS AND INSTRUCTIONS FOR FUTURE USE
2.1 UNPACKING YOUR BLENDER
You should have received the following items:
•
Designer series blender motor base
•
Blender jar with lid
•
Blendtec 101 booklet
•
Customer Service and Warranty Registration Card
Additional literature may be included depending on package configuration
1. Remove blender motor base, blender jar, and lid from packaging.
2. Unwind the power cord.
3. Check for any packing material that may have blocked ventilation holes on the
underside of the blender motor base.
4. Inspect all items to ensure no damage occurred during shipment.
5. If any damage has occurred, contact your Blendtec service agent immediately.
2.2 RECORDING YOUR SERIAL NUMBER AND DATE OF PURCHASE
Record your blender motor serial number and date of purchase in the space below. You will need these when contacting Blendtec for service or questions.
Motor Serial #(Found on bottom of motor base):________________________
Date of Purchase: ______________________________________________
Purchased From: ______________________________________________
3
2.3 REGISTRATION OF YOUR BLENDER
Register online at www.blendtec.com/registration
SECTION 3: GETTING TO KNOW YOUR BLENDER
(Refer to Figures 1 and 2)
3.1 BLENDER MOTOR BASE
•Smart Touch Interface: Consists of preprogrammed cycles, capacitive touch slider,
and various one-touch settings, depending on model.
•Hardened Metal Drive Socket: Where the jar couples with the motor to turn the
blade assembly; made of hardened metal.
•LED Information Center: Displays the number of times a blend cycle button has
been pressed, the time left to blend, and error messages.
•Power Unit: This unit is located within the blender motor base and contains the
computerized electronics that run the blender.
•Motor Base Cover: Houses the power unit in a durable, plastic material.
•Power Cord: Located at the back of the motor base cover.
3.2 BLENDER JAR ASSEMBLY
The blender jar assembly consists of the blender jar, blade assembly, and lid.
•Jar: Durable, BPA-free jar; easy to clean
•Blade Assembly: Uniquely designed stainless steel blade provides fast,
consistent blending
•Lid: Vented gripper lid seals liquids within the jar during blending
NOTE: Filling the blender jar beyond the marked capacity is not recommended.
SECTION 4: INSTALLATION
1. Place the blender on a flat, clean, and dry surface. Blender vents should be
unobstructed to allow proper cooling during use.
2. Make sure an outlet is available within two feet (61cm) of the blender motor.
3. Place appropriately filled blender jar, with lid in place, onto blender base.
4. We recommend that surge protection be placed between the receptacle and
the blender motor.
4
FIGURE 1: BLENDER JAR ASSEMBLY
Lid
Clear Vented
Cap Insert
Jar
Blade Assembly
The jar shown above is the Wildside+™ Jar
FIGURE 2: MOTOR BASE
Blender Drive Socket
LED Information Center
Smart Touch
Interface
Motor Base Cover
Power Cord
located in back
Motor Base Cover
Power Unit
5
SECTION 5: OPERATIONAL OVERVIEW
5.1 QUICK RECIPE INSTRUCTIONS –
Use these steps to get started right away.
1. Choose a recipe from the included Blendtec 101 booklet.
2. Gather all of the ingredients.
3. Load the blender jar as indicated in the recipe.
4. Plug in the blender.
5. Press the power button located on the upper right hand side of the smart touch
interface.
6. A cycle count (indicating the number of cycles the blender has run) will display
on the LED Information Center for three seconds following power on.
7. Attach the blender lid to the jar; ensure that it sits on the jar completely.
8. Place the blender jar onto the base, making sure the jar is secure and fully
seated on the motor base.
9. Press the indicated icon from the recipe once (or as indicated in the recipe)
or use the slider for manual control.
10. When cycle is complete, remove the blender jar from the motor base.
11. Remove the jar lid and serve as indicated in the recipe .
12. For best cleaning results, run the Clean cycle immediately after blending.
(See CARE AND CLEANING; 6.1)
5.2 ALL ABOUT BLEND CYCLES
Blend cycles are timed cycles designed for specific types of blends. These
one-touch cycles speed up, slow down, and shut off automatically, so results are
perfect every time.
Each blender in the Designer series features a number of preprogrammed cycles
and settings that provide a wide range of recipes and functions*:
Smoothie — Fruit smoothies, green smoothies, milkshakes
Timed Cycles — hot soup, bread dough
Dips — dressings, dips, sauces, batters
Ice Cream — ice cream, frozen yogurt, sorbets
Hot Soup — soups, hot chocolate, syrups, fondues
Whole Juice — juices, green drinks
Clean — automatic cleaning cycle
Batters — sauces, dips, dressings, batters
Mixed Drinks — mixed drinks, milkshakes, crush ice
+10 — adds 10 seconds to your preprogrammed cycles
Pulse — used to quickly stir, chop, or mince at a high speed
Blend Rewards — the Designer 725 displays a code when blending
milestones are reached that can be redeemed online for prizes.
*Interfaces and cycles will vary depending on model number
6
5.3 DESIGNER 600
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies and
thick drinks that frequently use dense or frozen ingredients. It slows down and
speeds up automatically during the course of the cycle. This allows the blender to
draw the ingredients into the blending vortex, creating the desired texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
ONE-TOUCH TIMED CYCLES
The Designer 600 comes equipped with three one-touch timed cycles: one
60-second, one 90-second, and one 180-second. These cycles free your hands
for other kitchen tasks and are ideal for recipes that require longer blending times,
such as hot soup or bread dough.
PULSE
The Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
7
5.4 DESIGNER 625
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies and
thick drinks that frequently use dense or frozen ingredients. It slows down and
speeds up automatically during the course of the cycle. This allows the blender to
draw the ingredients into the blending vortex, creating the desired texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
ICE CREAM
This 45-second cycle is designed specifically for frozen treats, including ice
cream, sorbets, and frozen yogurt. The cycle speeds up and slows down at the
appropriate moments to ensure your blends stay frozen.
To use the Ice Cream cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Ice Cream icon. The blender will run the cycle and
automatically shut off. After creating your frozen dessert, serve immediately and
store leftovers in the freezer.
WHOLE JUICE
This 50-second cycle is designed to completely blend tough and dense
ingredients, including carrots, celery, and seeds. Use the Whole Juice cycle if you
are using any fruits and/or vegetables with stems, seeds, or skins.
When blending carrot juice or other dense juices, you may need to repeat this
cycle once or twice until the desired texture and consistency are achieved.
HOT SOUP
This 90-second cycle is designed for hot recipes. The cycle’s length of time,
combined with the speed of the motor, heats the ingredients to a hot temperature.
This cycle can also be used for hot chocolate, syrups, and fondue.
When using fresh ingredients, remember that the speed of the blade generates
enough heat to warm the ingredients Do not add any liquids or ingredients over
115° F to the jar when preparing soups or hot items.
PULSE
The Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
8
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
5.5 DESIGNER 675
+10
This +10 icon allows users to add 10-second intervals to their blend cycles. It also
acts as a stand-alone, 10-second cycle. To use this feature, simply touch it once at
any point during the cycle.
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies and
thick drinks that frequently use dense or frozen ingredients. It slows down and
speeds up automatically during the course of the cycle. This allows the blender to
draw the ingredients into the blending vortex, creating the desired texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
ICE CREAM
This 45-second cycle is designed specifically for frozen treats, including ice
cream, sorbets, and frozen yogurt. The cycle speeds up and slows down at the
appropriate moments to ensure your blends stay frozen.
To use the Ice Cream cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Ice Cream icon. The blender will run the cycle and
automatically shut off. After creating your frozen dessert, serve immediately and
store leftovers in the freezer.
WHOLE JUICE
This 50-second cycle is designed to completely blend tough and dense ingredients, including carrots, celery, and seeds. Use the Whole Juice cycle if you are
using any fruits and/or vegetables with stems, seeds, or skins.
When blending carrot juice or other dense juices, you may need to repeat this
cycle once or twice until the desired texture and consistency are achieved.
9
HOT SOUP
This 90-second cycle is designed for hot recipes. The cycle’s length of time,
combined with the speed of the motor, heats the ingredients to a hot temperature.
This cycle can also be used for hot chocolate, syrups, and fondue.
When using fresh ingredients, remember that the speed of the blade generates
enough heat to warm the ingredients Do not add any liquids or ingredients over
115° F to the jar when preparing soups or hot items.
CLEAN
The Clean cycle is a 23-second cycle that automatically cleans the inside of your
blender jar. To use the Clean cycle:
1. Add 1 cup of water and a drop of dish soap to the blender jar
2. Secure the lid and place the jar on the blender base
3. Press the Clean button
4. Once the cycle is complete, remove the jar and rinse
For best results, use the Clean cycle immediately after blending.
PULSE
The Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
5.6 DESIGNER 700
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies and
thick drinks that frequently use dense or frozen ingredients. It slows down and
speeds up automatically during the course of the cycle. This allows the blender to
draw the ingredients into the blending vortex, creating the desired texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
10
DIPS
This 23-second cycle stays at relatively low speeds for shorter periods of time.
This combines your dips, allowing the flavors to blend together properly, without
over-mixing.
To use the Dips cycle, load your jar as indicated in the recipe you are using, secure the lid, and press the Dips icon. The blender will run the cycle and automatically shut off.
ICE CREAM
This 45-second cycle is designed specifically for frozen treats, including ice
cream, sorbets, and frozen yogurt. The cycle speeds up and slows down at the
appropriate moments to ensure your blends stay frozen.
To use the Ice Cream cycle, load your jar as indicated in the recipe you are using, secure the lid, and press the Ice Cream icon. The blender will run the cycle
and automatically shut off. After creating your frozen dessert, serve immediately
and store leftovers in the freezer.
WHOLE JUICE
This 50-second cycle is designed to completely blend tough and dense ingredients, including carrots, celery, and seeds. Use the Whole Juice cycle if you are
using any fruits and/or vegetables with stems, seeds, or skins.
When blending carrot juice or other dense juices, you may need to repeat this
cycle once or twice until the desired texture and consistency are achieved.
HOT SOUP
This 90-second cycle is designed for hot recipes. The cycle’s length of time,
combined with the speed of the motor, heats the ingredients to a hot temperature.
This cycle can also be used for hot chocolate, syrups, and fondue.
When using fresh ingredients, remember that the speed of the blade generates
enough heat to warm the ingredients Do not add any liquids or ingredients over
115° F to the jar when preparing soups or hot items.
CLEAN
The Clean cycle is a 23-second cycle that automatically cleans the inside of your
blender jar. To use the Clean cycle:
1. Add 1 cup of water and a drop of dish soap to the blender jar
2. Secure the lid and place the jar on the blender base
3. Press the Clean button
4. Once the cycle is complete, remove the jar and rinse
For best results, use the Clean cycle immediately after blending.
PULSE
The Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
11
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
5.7 DESIGNER 725
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies
and thick drinks that frequently use dense or frozen ingredients. It slows down
and speeds up automatically during the course of the cycle. This allows the
blender to draw the ingredients into the blending vortex, creating the desired
texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
DIPS
This 23-second cycle stays at relatively low speeds for shorter periods of time.
This combines your dips, allowing the flavors to blend together properly, without
over-mixing.
To use the Dips cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Dips icon. The blender will run the cycle and
automatically shut off.
ICE CREAM
This 45-second cycle is designed specifically for frozen treats, including ice
cream, sorbets, and frozen yogurt. The cycle speeds up and slows down at the
appropriate moments to ensure your blends stay frozen.
To use the Ice Cream cycle, load your jar as indicated in the recipe you are using, secure the lid, and press the Ice Cream icon. The blender will run the cycle
and automatically shut off. After creating your frozen dessert, serve immediately
and store leftovers in the freezer.
WHOLE JUICE
This 50-second cycle is designed to completely blend tough and dense
ingredients, including carrots, celery, and seeds. Use the Whole Juice cycle if
you are using any fruits and/or vegetables with stems, seeds, or skins.
When blending carrot juice or other dense juices, you may need to repeat this
cycle once or twice until the desired texture and consistency are achieved.
12
HOT SOUP
This 90-second cycle is designed for hot recipes. The cycle’s length of time,
combined with the speed of the motor, heats the ingredients to a hot temperature.
This cycle can also be used for hot chocolate, syrups, and fondue.
When using fresh ingredients, remember that the speed of the blade generates
enough heat to warm the ingredients Do not add any liquids or ingredients over
115° F to the jar when preparing soups or hot items.
CLEAN
The Clean cycle is a 23-second cycle that automatically cleans the inside of your
blender jar. To use the Clean cycle:
1. Add 1 cup of water and a drop of dish soap to the blender jar
2. Secure the lid and place the jar on the blender base
3. Press the Clean button
4. Once the cycle is complete, remove the jar and rinse
For best results, use the Clean cycle immediately after blending.
PULSE
TThe Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
BLEND REWARDS™
The Designer 725 rewards users for continuous use through our exclusive Blend
Rewards program. The 725 tracks each number of completed blends, then
displays a code once certain blending milestones are reached. The code can be
redeemed online for recipe books, gift cards, kitchen utensils, jar discounts, and
more.
13
5.8 EXPRESS
BATTERS
This 23-second cycle stays at relatively low speeds for shorter periods of time.
This combines your dips, allowing the flavors to blend together properly, without
over-mixing.
To use the Dips cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Dips button The blender will run the cycle and automatically shut off.
MIXED DRINKS
This 35-second cycle is used for mixed drinks, milkshakes, iced coffees, and
milkshakes. This length of time creates a consistency that is ideal for these types
of recipes. To use the Mixed Drinks cycle, load your jar as indicated in the recipe you are using, secure the lid, and press the Mixed Drinks icon.
SMOOTHIE
This 40-second cycle is designed specifically for various types of smoothies and
thick drinks that frequently use dense or frozen ingredients. It slows down and
speeds up automatically during the course of the cycle. This allows the blender to
draw the ingredients into the blending vortex, creating the desired texture
To use the Smoothie cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Smoothie icon. The blender will run the cycle and
automatically shut off.
ICE CREAM
This 45-second cycle is designed specifically for frozen treats, including ice
cream, sorbets, and frozen yogurt. The cycle speeds up and slows down at the
appropriate moments to ensure your blends stay frozen.
To use the Ice Cream cycle, load your jar as indicated in the recipe you are using,
secure the lid, and press the Ice Cream icon. The blender will run the cycle and
automatically shut off. After creating your frozen dessert, serve immediately and
store leftovers in the freezer.
WHOLE JUICE
This 50-second cycle is designed to completely blend tough and dense
ingredients, including carrots, celery, and seeds. Use the Whole Juice cycle if you
are using any fruits and/or vegetables with stems, seeds, or skins.
14
When blending carrot juice or other dense juices, you may need to repeat this
cycle once or twice until the desired texture and consistency are achieved.
HOT SOUP
This 90-second cycle is designed for hot recipes. The cycle’s length of time, combined with the speed of the motor, heats the ingredients to a hot temperature. This
cycle can also be used for hot chocolate, syrups, and fondue.
When using fresh ingredients, remember that the speed of the blade generates
enough heat to warm the ingredients Do not add any liquids or ingredients over
115° F to the jar when preparing soups or hot items.
PULSE
The Pulse function is used for chopping, mincing, whipping, or other momentary
tasks that do not require a long blend cycle. You can also Pulse to quickly stir a
blend before serving.
The Pulse setting runs at speed 7 and will only run while the Pulse icon remains
pressed. When the icon is released, the motor shuts off.
CAPACITIVE TOUCH SLIDER
The capacitive touch slider allows you to fine-tune the speed of your blender.
Simply slide your finger to the right to increase the blender’s speed or the left to
decrease speed.
SECTION 6: CARE AND CLEANING
6.1 CLEANING
1.Add 1 cup (240ml) of hot water and a drop of liquid dishwashing soap to the
blender jar.
2. Place the lid tightly onto the jar.
3. Place the blender jar on the blender base and, with your hand placed on top of the
lid, press the CLEAN cycle button.
6.2 LONG-TERM SANITATION
1. For long-term sanitation, fill the blender jar with hot water.
2. Add one to two teaspoons (5-10ml) of liquid chlorine bleach to the jar.
3. Stir for 10 seconds to mix water and bleach. Let mixture stand in blender jar
for five minutes.
4. Empty water/bleach mixture. Turn jar upside down on dish rack until dry.
6.3 CLEANING TIPS AND CAUTIONS
•Do not use stiff bristled brushes or abrasive cloths/pads to clean the blender base
or jar as this will dull or scratch the surface.
•NEVER submerge the blender motor in water. Avoid submerging blender jars for
more than 5 minutes. Water penetration through the lower jar seals will reduce the
life of the jar. After cleaning, we recommend the blender jar be stored upright.
15
•BLENDER JAR IS DISHWASHER SAFE—TOP RACK ONLY!
•Extreme temperatures damage the lower seal of the jar. We recommend hand
washing to prolong the life of the blender jar. We do not recommend the jar be
used for temperatures abo boiling (212°F, 100°C).
SECTION 7: TROUBLESHOOTING
While we don’t expect you to have any problems with your blender, sometimes
failures do occur. Use the following guidelines to see if the problem is easily fixed
or requires service.
7.1 BLENDER MOTOR WILL NOT TURN ON (NO POWER)
If the blender motor will not turn on, try the following:
•Determine if the Power Button is lit. Absence of a lit Power Button indicates a lack of
power to the unit.
•Make sure the blender is plugged in.
•Check your house circuit breaker switch or fuse to make sure it is set to the
ON position.
•Press the Power Button located on the upper right hand side of the touch area.
•Unplug the power cord from the wall receptacle, wait 5 seconds, then plug power
cord back in.
7.2 ERROR MESSAGES ON DISPLAY
If this icon appears on your blender, it indicates that the motor is overheating. The
blender has been disabled until the unit cools to operating temperatures. Turn off
and unplug the unit. Allow it to cool for at least 20 minutes, then plug it back into
check if the icon is still visible. If the icon does not disappear after 20 minutes or
more of cooling time, please call your Blendtec Service Agent.
If this icon appears on your blender, please turn off and unplug the unit. Check the
blender jar for blockage and clear if necessary. Plug in the unit and turn the blender
on again. If the icon is still visible on your blender, contact your Blendtec Service
Agent.
If this icon appears on your blender it indicates that more than one touch sensor
on the blender has been touched. This icon should only appear as long as the
multiple sensor areas are being touched. If this icon remains on when no one is
touching the touch area unplug and re-plug in the blender. If the problem persists
please contact your Blendtec Service Agent.
If this message appears on the LED information center it indicates there has been
an error. There are error messages from E-01 through E-06. If any of these errors
appear, press the stop button to clear the message. If the error message reappears
please contact your Blendtec Service Agent.
16
7.3 NOISE LEVEL CHANGES
If the blender noise level has increased from original levels, determine whether the
sound is coming from the blender motor or jar.
•Blender Motor: Remove the pitcher and run blender at highest speed.
•Listen to how the motor sounds. If it is excessively noisy, contact your
Blendtec service center for evaluation.
•Jar: After checking the motor, place the jar back on the motor. Run the motor
for a few seconds using the Pulse button. (If you have more than one jar, test
a different jar to determine whether the sound is different.) If a jar is exces­
sively noisy, or if the blade assembly seems loose or sounds “gravelly” when
turned by hand, contact your Blendtec service center.
7.4 BLENDED TEXTURE UNSATISFACTORY
If the blended texture of product is lumpy or uneven, do the following:
•Ensure the mixture is not cavitating during the cycle. Cavitation is a condition
in which an air pocket forms within the drink mix because the mix is too cold
or too solid. The blender blade then spins freely in this cavity. This problem
can be corrected by increasing the mix temperature by either reducing
ice, increasing liquid and/or ensuring that the frozen ingredients used in the
recipe are never colder than 10 degrees Fahrenheit (-12 degrees Celsius).
•If the drink is mixing well but has not had enough time for complete blending, increase cycle time. Try a longer cycle or touch and hold the “Pulse”
button for the required extra blending time.
•TRIED EVERYTHING? If none of the preceding suggestions work, contact
your Blendtec service agent for further assistance.
INSTRUCTIONS THAT APPEAR IN THIS USER GUIDE ARE NOT MEANT TO
COVER EVERY POSSIBLE CONDITION OR SITUATION THAT MAY OCCUR.
GOOD JUDGMENT MUST BE USED WHEN OPERATING THIS OR ANY
OTHER MACHINERY.
17
SECTION 8: WARRANTY US AND CANADA
WARRANTY DESCRIPTION (US Domestic and Canada)
The motor base and jar assembly, including all moving jar parts, are covered
against leaking or breakage for the warranty period. Warranties begin from
date of purchase.
Cosmetic damage, product abuse, unreasonable use, damage resulting
from an accident (including fire, flood, earthquake or other natural disasters),
product tampering, use of accessories not endorsed by Blendtec, service
performed or attempted by unauthorized service agencies, units that have
modifications, or have been or used for commercial purposes are not
included under this warranty.
•The quality of Blendtec blenders is unsurpassed. You will enjoy years of
wonderful and reliable service from your Blendtec Designer series Blender.
THIS WARRANTY APPLIES ONLY TO PRODUCTS SOLD BY BLENDTEC OR
ITS AUTHORIZED DEALERS
Limited Warranty
Blendtec warrants the blender motor to be free of defect in material and
workmanship for the warranty period. During this period, such defects will be
repaired or the product replaced at Blendtec’s discretion without charge. This
warranty does not cover damage caused by misuse, accident, or negligence.
All implied warranties, including but not limited to implied warranties of fitness
and merchantability, are limited in duration to the warranty period on motor
and jar. Any unit submitted for repair must be accompanied by proof of original
purchase and should be shipped prepaid to:
1206 South 1680 West
Orem, UT 84058
1-800-BLENDTEC
(801) 222-0888
18
UNDER WARRANTY
1. Contact Blendtec immediately to diagnose the difficulty. Please have the
blender serial number ready as well as a description of the problem. Do not
attempt to do your own repairs. Repairs made by persons other than Blendtec
authorized service representatives will void the warranty. Many issues can be
resolved simply and quickly over the phone.
2. If the difficulty cannot be resolved over the phone, your unit may require
replacement. If blender is under warranty, Blendtec will repair or replace the unit
at no cost. Cosmetic damage and abuse are not included.
3. Upon receiving instructions from Blendtec, box up your existing unit and
enclose the following:
Your Name: ���������������������������������������������������������������
Address: ������������������������������������������������������������������
Phone Number: ������������������������������������������������������������
Motor Serial #(Found on bottom of motor base): ��������������������������������
Cycle Count (From the LED Information Center): ���������������������������������
Your Purchase Date: ��������������������������������������������������������
Place of Purchase: ���������������������������������������������������������
An explanation of the problem: ����������������������������������������������3
OUT OF WARRANTY
1. Contact Blendtec to diagnose the difficulty. Please have the blender serial
number ready along with a description of the problem. Do not attempt to
do your own repairs. Many issues can be resolved simply and quickly over
the phone.
2. If the blender is not under warranty and you wish to have it repaired, please
call customer service with your serial number, place of purchase and date of
purchase so we may give you further instructions on how to send your machine
in for an out of warranty repair.
3. When you ship your unit please enclose the following:
Your Name: ���������������������������������������������������������������
Address: ������������������������������������������������������������������
Phone Number: ������������������������������������������������������������
Motor Serial #(Found on bottom of motor base): ��������������������������������
Cycle Count (From the LED Information Center): ���������������������������������
19
Your Purchase Date: ��������������������������������������������������������
Place of Purchase: ���������������������������������������������������������
An explanation of the problem: �����������������������������������������������
Products intended for sale in the United States and Canada are only covered
by U.S. and Canadian warranty, repair policies, and procedures. Products
used or sold outside the United States and Canada are subject to the
applicable international warranty and service procedures.
Using a machine outside the country it was designed for will void the warranty.
20
1206 SOUTH 1680 WEST
OREM, UTAH 84058 U.S.A.
1-800-BLENDTEC
BLENDTEC.COM
©2014 K-TEC, INC., ALL RIGHTS RESERVED
BLENDTEC IS A REGISTERED TRADEMARK
ed.
OWN-RD-210 MANUAL, DESIGNER SERIES,
ofJUNE
K-TEC,
Inc.
ALL MODELS, ENG, REV B,
2014
1
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
