Delivering Wireless Excellence
Wireless Product Line Up
MUSIC
AND
WORDS
For over a quarter of a century TOA
has been committed to developing
vocal and speech radio products to
the highest specification at the
cutting edge of technology.
We are proud to have become
synonymous with high quality and
reliability.
The introduction of Trantec S5/S4
wireless microphones has completed
the TOA line up that allows integration
into a wide and varied market sector
that makes challenging demands
within professional audio, broadcast,
film, music and theatre.
Additionally, TOA 5000 series has
also been the first choice by many
for the perfect match when it comes
to performance, reliability and build
quality to face the daily requirements
that sports, conferencing, education
and houses of worship have come
to expect.
TOA, sound without compromise…
TRANTEC Wireless Microphone
Systems S5 and S4 Series
TOA Wireless Microphone
Systems 5000 Series
The Trantec S5 and S4 Series is synonymous
with quality among vocalists, musicians and
theatrical performers. Additionally, presenters
and the like also enjoy the wide variety of
accessories that Trantec
has to offer, allowing
them to meet their
professional
needs.
TOA 5000 Series is the ultimate choice for the presenter,
offering incredible intelligibility so your audience won’t miss
a single word.
You can be assured that with TOA's continuous
commitment to research and development,
we will always provide wireless
solutions that allow your
voice to be heard
clearly by all.
01
S5
5000
SYSTEM SELECTION
S4
Trantec S5.5
TOA 5000
Trantec S5.3
Trantec S4.16
Trantec S4.4
Up to 24 Channels Up to 16 Channels Up to 12 Channels Up to 12 Channels Up to 4 Channels
02
S5.5 SERIES
24 Channel Wireless Solution
S5.5 Receiver
25 years after pioneering the first readily available radio
mics, Trantec’s foresight and imagination has again
taken wireless to a whole new level with their groundbreaking S5 Series. Based upon the award winning
S6000, widely used in theatre and broadcast, the S5
Series promises a powerful set of features combined with
an exceptional performance/cost ratio.
Features:
For venues of any size, we suggest you check out the
specifications of this remarkable system.
P
True diversity operation
P
Up to 1400 selectable frequencies
The S5.5, one of our latest multi-channel UHF products,
is the big brother of the successful S5.3 system; it has up
to 35MHz of bandwidth that will enable you to run up to
24 channels simultaneously at a price you will find hard to
match.
P
Interactive USB based computer control and
monitoring for all aspects of performance
P
Frequency scan function
P
Integral triple tone grip/noise and signal strength
mute circuit for protection against external interference
Fully synthesised UHF dual conversion receiver with
features including graphic LCD, display jog wheel,
IR data link, and headphone monitor.
P
Simple programming of transmitter with built-in
Infra-red data link
P
Clear and intuitive LCD display
P
EQ and phase reversal
P
Professional metal enclosure
For accessories see pages 22-25
0dB=1V
*
Power Consumption
300 mA (13 V DC)
S/N Ratio
Diversity System
Space diversity (true diversity)
Harmonic Distortion
1% or less (typical)
Audio Output
Line: -22 dB*/ Mic: -62 dB*
Line/Mic selectable, 600 Ω, balanced, XLR-3-32 type
connector. Headphone: max. 100 mW 16 Ω, unbalanced, phone jack -28 dB*, 600 Ω, unbalanced, phone
jack
Frequency Response
50 Hz - 20 kHz, ±3 dB
Function
Audio Low-cut, High-boost and phase reverse, Battery
indicator (7 steps), Headphone output, Infra-Red link
port, Channel scan, Monitoring software with
USB connectivity
9 V DC, 30 mA (max) (Available to turn off phantom
Dimensions
210 (W) x 46 (H) x 210 (D) mm (8.27" x 1.81" x 8.27")
(excluding antenna)
Receiving Sensitivity
0 dB μV or less (12 dB SINAD)
Weight
1.3kg (2.87lb)
Squelch Sensitivity
6 - 36 dB μV variable
Frequency Bands
606-638, 636-666, 668-698, 692-722, 722-752, 740-752, 794-830,
Antenna Phantom Power
power)
Squelch System
Using together of noise SQ, carrier SQ and tone SQ
Indicator
LCD, Power lamp, Mute lamp, ANT A/B lamp
110 dB or more (A-weight)
830-865 MHz
1400 channel capability (24 Simultaneous channels)
S5.5 RX Receiver
24 Channel Wireless Solution
S5.5 B Aerobic System
Supplied with X66
S5.5 B Theatre System
Supplied with X22-P-R
S5.5 B Earworn System
Supplied with EM77-P
03
S5.5 Handheld
Fully synthesised UHF handheld transmitter with features
including: integral LCD, IR data link, battery status
indicator, digital gain control, microphone mute switch.
Features:
S5.5 Beltpack
P
Simple programming of transmitter with
built-in Infra-red data link
Fully synthesised UHF beltpack transmitter with
P
Frequency & Power lock facility
features including: integral LCD, IR data link, battery
P
Single AA operation of transmitters with battery life
of over 10 hours
status indicator, digital gain control.
P
Integral antenna
P
Clear and intuitive LCD display
P
Colour coded ID band
P
P
P
Features:
P
Credit card size beltpack
Professional metal enclosure
P
Simple programming of transmitter with built-in
Infra-red data link
Options:
P
Frequency & Power lock facility
P
Clear and intuitive LCD display
P
Single AA operation of transmitters with battery life
of over 10 hours
P
Detachable antenna
P
Professional metal enclosure
S5.5 HDX Dynamic Capsule
S5.5 HCX Condenser Capsule.
RF Carrier Power
Less than 50mW (Factory preset 10mW ERP)
Maximum Input Level S5.5 HDX
Maximum Input Level S5.5 HCX
146 dB SPL (microphone sensitivity: Gain "0")
142 dB SPL (microphone sensitivity: Gain “0”)
Audio Frequency Response S5.5 HDX 60 Hz - 20 kHz
Audio Frequency Response S5.5 HCX 90 Hz - 20 kHz
RF Carrier Power
Less than 50mW (Factory preset 10mW ERP)
Modulation System
PLL synthesizer
Dynamic Range
110 dB or more (with S5.5-RX)
Maximum Input Level
120 dB SPL (microphone sensitivity: Gain "0")
Battery
LR6 (AA)
Audio Input Connector
TA-4 (Mini-XLR 4 pins)
Battery Life
10 hours (Alkaline)
Battery
LR6 (AA)
Indicator
LCD display, Power lamp
Battery Life
10 hours (Alkaline)
Function
Mute switch, Infra-Red link port, Battery life
indicator (4 steps), Microphone sensitivity
adjustment (Gain 0-2; 12dB)
Indicator
LCD display, Power lamp
Function
Infra-red Link Port, Battery life indicator (4 steps),
Microphone sensitivity adjustment (Gain 0-9; 20dB)
Dimensions
55 (W) x 80 (H) x 22 (D) mm (2.17" x 3.15" x 0.87")
Weight
140g (0.31lb) (with battery)
Dimensions S5.5 HDX
Dimensions S5.5 HCX
Weight S5.5 HDX
Weight S5.5 HCX
ø50 x 247.9 mm (ø1.97” x 9.76”)
ø50 x 232.9 mm (ø1.97" x 9.17")
380g (0.84lb) (with battery)
300g (0.66lb) (with battery)
S5.5 BTX Beltpack
24 Channel Wireless Solution
S5.5 HDX/HCX Handheld
24 Channel Wireless Solution
S5.5 Handheld System
Supplied with HDX / HCX
S5.5 L Lavalier System
Supplied with X2
S5.5 B Active System
Supplied with X33
04
S5.3 SERIES
12 Channel Wireless Solution
S5.3 Receiver
25 years after pioneering the first readily available radio
mics, Trantec’s foresight and imagination has again
taken wireless to a whole new level with their groundbreaking S5 Series. Based upon the award winning
S6000, widely used in theatre and broadcast, the
S5 Series promises a powerful set of features combined
with an exceptional performance/cost ratio. For venues
of any size, we suggest you check out the specifications
of this remarkable system.
The S5.3, one of our latest multi-channel UHF products,
is the little brother of the successful S5.5 system. It will
enable you to run up to 12 channels simultaneously at a
price you will find hard to match.
Fully synthesised UHF dual conversion receiver with
features including graphic LCD, display jog wheel, IR
data link, and headphone monitor.
Features:
P
True diversity operation
P
Up to 640 selectable frequencies
P
USB based computer monitoring
P
Frequency scan function
P
Integral triple tone grip/noise and signal strength mute
circuit for protection against external interference
P
Simple programming of transmitter with built-in
Infra-red data link
P
Clear and intuitive LCD displays
P
Professional metal enclosure.
For accessories see pages 22-25
0dB=1V
*
Power Consumption
300 mA (13 V DC)
Indicator
LCD, Power lamp, Mute lamp, ANT A/B lamp
Diversity System
Space diversity (true diversity)
S/N Ratio
110 dB or more (A-weight)
Audio Output
Line: -22 dB*/ Mic: -62 dB*
Line/Mic selectable, 600 Ω, balanced, XLR-3-32 type
connector
Headphone: max. 100 mW 16 Ω, unbalanced, phone
jack
-28 dB*, 600 Ω, unbalanced, phone jack
Harmonic Distortion
1% or less (typical)
Frequency Response
50 Hz - 20 kHz, ±3 dB
Function
Battery indicator (7 steps), Headphone output, Infra-Red
link port, Channel scan, Monitoring software with USB
connectivity
Antenna Phantom Power
9 V DC, 30 mA (max) (Available to turn off phantom
power)
Dimensions
210 (W) x 46 (H) x 210 (D) mm (8.27" x 1.81" x 8.27")
(excluding antenna)
Receiving Sensitivity
0 dB μV or less (12 dB SINAD)
Weight
1.3kg (2.87lb)
Frequency Bands
606-622, 830-866, 854-865 MHz
Squelch Sensitivity
Squelch System
6 - 36 dB μV variable
Using together of noise SQ, carrier SQ and tone SQ
640 channel capability (12 Channels simultaneously)
S5.3 RX Receiver
12 Channel Wireless Solution
S5.3 B Aerobic System
Supplied with X66
S5.3 B Theatre System
Supplied with X22-P-R
S5.3 B Earworn System
Supplied with EM77-P
05
S5.3 Handheld
Fully synthesised UHF handheld transmitter with features
including: integral LCD, IR data link, battery status
indicator, digital gain control, microphone mute switch.
S5.3 Beltpack
Features:
P
Simple programming of transmitter with
built-in Infra-red data link
P
Frequency & Power lock facility
P
Single AA operation of transmitters with battery life
of over 10 hours
P
Integral antenna
P
Clear and intuitive LCD display
P
Colour coded ID band
P
Professional metal enclosure.
Fully synthesised UHF beltpack with features including:
integral LCD, IR data link, battery status indicator,
digital gain control.
Features:
Options:
P
S5.3 HDX Dynamic Capsule
P
S5.3 HCX Condenser Capsule.
RF Carrier Power
Less than 50mW (Factory preset 10mW ERP)
Maximum Input Level S5.3 HDX
Maximum Input Level S5.3 HCX
146 dB SPL (microphone sensitivity: Gain "0")
142 dB SPL (microphone sensitivity: Gain “0”)
P
Credit card size beltpack
P
Simple programming of transmitter with built-in
Infra-red data link
P
Frequency & Power lock facility
P
Single AA operation of transmitters with battery
life of over 10 hours
P
Detachable antenna
P
Clear and intuitive LCD display
P
Professional metal enclosure.
Audio Frequency Response S5.3 HDX 60 Hz - 20 kHz
Audio Frequency Response S5.3 HCX 90 Hz - 20 kHz
RF Carrier Power
Less than 50mW (Factory preset 10mW ERP)
Modulation System
PLL synthesizer
Dynamic Range
110 dB or more (with S5.3-RX)
Maximum Input Level
120 dB SPL (microphone sensitivity: Gain "0")
Battery
LR6 (Single AA)
Audio Input Connector
TA-4 (Mini-XLR 4 pins)
Battery Life
10 hours (Alkaline)
Battery
LR6 (Single AA)
Indicator
LCD display, Power lamp
Battery Life
10 hours (Alkaline)
Function
Mute switch, Infra-Red link port, Battery life indicator (4 steps), Microphone sensitivity adjustment (Gain 0-2; 12dB)
Indicator
LCD display, Power lamp
Function
Infra-red Link Port, Battery life indicator (4 steps),
Microphone sensitivity adjustment (Gain 0-9; 20dB)
Dimensions
55 (W) x 80 (H) x 22 (D) mm (2.17" x 3.15" x 0.87")
Weight
140g (0.31lb) (with battery)
Dimensions S5.3 HDX
Dimensions S5.3 HCX
Weight S5.3 HDX
Weight S5.3 HCX
ø50 x 247.9 mm (ø1.97" x 9.76")
ø50 x 232.9 mm (ø1.97” x 9.17”)
380g (0.84lb) (with battery)
300g (0.66lb) (with battery)
S5.3 BTX Beltpack
12 Channel Wireless Solution
S5.3 HDX/HCX Handheld
12 Channel Wireless Solution
S5.3 Handheld System
Supplied with HDX / HCX
S5.3 L Lavalier System
Supplied with X2
S5.3 B Active System
Supplied with X33
06
5000 SERIES
Wireless Tuner
WT-5810 Space
Diversity Tuner
WT-4820 Tuner
The WT-5810 Wireless Tuner is designed for use on the
UHF band, and suitable for vocal or speech
reinforcement applications.
It features a compounder circuit that minimizes the
influence of ambient noise. 16 different operating
frequencies ranging from 576 to 865 MHz. Optimized
PLL-synthesizer minimizes the oscillation frequency drift
resulting from the ambient temperature change.
Compact size and high reliability.
MODULAR DUAL CHANNEL WIRELESS RECEIVER
combines cutting-edge wireless technology with user
benefits such as fast setup, simple operation and
reliable performance.
The WT-4820 accepts up to two WTU-4800 Diversity
Tuner Modules available in 3 different frequency bands
with sixteen user-selectable channels in the UHF band
with simultaneous operation of up to sixteen channels.
Features:
P
16 selectable channel frequencies
P
Antenna cascade output function (parallel
connection possible for linking two WT-4820 units)
P
TOA space diversity technology
P
Auto mixing input function
P
Tuner unit connections accessible from the
front (even if rack mountet the front panel opens
easily).
P
Mix output/tuner 1 output (selectable);
tuner 2 has 2 outputs.
P
Whip antenna x 2
P
Compact half-rack size body
P
External antenna input
Features:
P
Phase Locked Loop (PLL) synthesis operation
P
16 selectable channel frequencies
P
TOA space diversity technology
P
Double super-heterodyne receiving system
P
Auto mixing input function
P
Squelch function (carrier, noise, tone)
P
Usable frequencies scanning and vacant channel
search function
P
Compact portable design
P
Compander circuitry for minimizing ambient noise
P
Rod antenna x 2
P
Balanced output (XLR connector) and phone
jack output
P
Low-battery indicator (Wireless microphone's
battery voltage becomes low)
For accessories see pages 22-25
07
5000 SERIES
Wireless Tuner
WT-5805 Space
Diversity Tuner
WT-5800 True
Diversity Tuner
Space diversity reduces a fading effect of a received
signal and generates a constant output regardless of a
variation of a signal-to-noise ratio of the received signal.
The 5000 series tuners are designed to deliver outstanding
performance , stability and reliability. A wide choice of
channels can be obtained by the using PLL-synthesized
oscillators enabling the selection of channels freely
without interference.
The space diversity receiver compares a signal-to-noise
ratio of a signal received from a first antenna and a
signal-to-noise ratio of a signal received from a second
antenna, so as to amplify the received signal having a
higher signal-to-noise ratio and attenuate the received
signal having a lower signal-to-noise ratio.
The amplified signal is combined with the attenuated
signal.
Features:
P
Phase Locked Loop (PLL) synthesis operation
P
64 selectable channels
P
TOA space diversity technology
P
Double super-heterodyne receiving system
P
Two-line LCD display
P
Auto mixing input function
P
Squelch function (carrier, noise, tone)
P
Usable frequencies scanning and vacant channel
search function
Compact half-rack size body
P
Additionally, the 5000 series provide significantly less
potential for noise caused by antenna changeover , by
employing true diversity and space diversity methods.
Two-line LCD display enables faster meter reading.
Remaining battery power indication. PLL synthesis is
incorporated to generate highly accurate frequency
output signals that help achieve better overall system
performance. For further performance enhancement, a
TOA diversity system eliminates dead spots and
provides more stable signal reception. Noise reduction is
improved with a squelch function (carrier, noise, tone),
and a compounder function minimising ambient noise.
For easier operation, a Channel Check function simplifies
channel setting operations on microphones using
multiple channels simultaneously.
Features:
P
Phase Locked Loop (PLL) synthesis operation
P 64 selectable channels
P True diversity technology
P
Double super-heterodyne receiving system
P
6 points audio level meter for microphone
sensitivity adjustment
P
Compander circuitry for minimizing ambient noise
P Two-line LCD display
P Auto mixing input function
P
Whip antenna x 2
P
Squelch function (carrier, noise, tone)
P
Low-battery indicator (Wireless microphone's
battery voltage becomes low).
P
Usable frequencies scanning and vacant channel
search function
P
Compact half-rack size body
P
6 points audio level meter for microphone sensitivity
adjustment
P
Compander circuitry for minimizing ambient noise
P
Antenna distribution output
P
Whip antenna x 2
P
Low-battery indicator (wireless microphone's battery
voltage becomes low)
08
5000 SERIES
Wireless Microphones
Handhelds
Two handheld microphones powered by rechargeable batteries.
Supported by the WM-5325 wireless transmitter, which also operates on rechargeable batteries,
the new WM-5265 vocal microphone and WM-5225 speech microphone maintain the Series’ high performance
standards while lowering operating costs.
The ability to use rechargeable batteries, which permit up to 13 hours continuous use before recharging, offers the
additional advantage of enhancing equipment reliability by assuring that every activity begins with the batteries fully
charged.
A selection of three new high-efficiency battery chargers for 2, 6 or 12 batteries and a single-battery microphone add
further flexibility to the product line-up.
Features:
WM-5270
WM-5265
WM-5225
P
P
P
P
P
P
P
P
Dynamic microphone unit:
Unidirectional
64 selectable channels
Maximum input level:
142 dB SPL
Rolling stopper prevents
the microphone from rolling.
Single AA battery operation
for more compact and light
weight body
Built-in antenna
WM-5270
P
P
P
P
P
Dynamic microphone unit:
Unidirectional
64 selectable channels
Maximum input level:
132 dB SPL
ON/OFF switch prevents the
microphone from rolling
WB-2000 rechargeable
battery or single AA battery
operation for compact and
lightweight body
Built-in antenna
WM-5265
P
P
P
P
P
Electret condenser
microphone unit: Unidirectional
64 selectable channels
Maximum input level:
126 dB SPL
ON/OFF switch prevents the
microphone from rolling.
WB-2000 rechargeable
battery or single AA battery
operation for compact and
lightweight body
Built-in antenna
WM-5225
09
UHF WIRELESS
Microphone Sets
WS-5225
WS-5265
WM-5225 + WT-5810
WM-5265 + WT-5810
WS-5325U
WS-5325M
WM-5325 + YP-M5300 + WT-5810
WM-5325 + YP-M5310 + WT-5810
WS-5325H
WM-5325 + WH-4000H + WT-5810
10
5000 SERIES
Beltpack Receiver/Transmitter
WM-5325
WM-4300
WT-5100
Wireless Transmitter
Wireless Transmitter
Wireless Receiver
The WM-5325 wireless transmitter has
been manufactured for use with a
UHF system. It is for use in speech
reinforcement applications. Thanks to
the PLL-synthesizer system, 64
different operating frequencies are
made available.
The WM-4300 lavalier wireless
microphone has been manufactured
for use with a UHF system. It
incorporates a cardioid pick-up
pattern and has been designed for
use in vocal and speech reinforcement
applications.
The WT-5100 is a Portable Receiver
designed to receive UHF band radio
signals. An optional earphone is
required.
A high output power ensures stable
radio signal transmission.
The built-in compressor-expander
circuit minimizes the influence from
ambient noise.
YP-E401
YP-E5000
Features:
WM-5325
WM-4300
WT-5100
P
64 selectable channels
P
P
P
Maximum input level: 14 dB to -29 dB
Unidirectional electret
condenser microphone
element
Commercial earphones can
also be used (ø3.5 mm,
impedance: over 16Ω)
P
Built-in circuitry minimizes
ambient noise effects
P
64 selectable channels
P
P
Input sensitivity control included
WB-2000 rechargeable
battery or single AA battery
operation for compact and
lightweight body
P
Maximum input level:
120 dB SPL
Allows up to 16 different
frequencies to be received
by selection
P
P
Built-in circuitry minimizes
ambient noise effects.
P
Connector for
3.5 mini-plugs
P
Highly reliable TA-4 (XLR-type)
mini-cannon microphone plug
An optimized PLL-synthesizer
minimizes the oscillation
frequency drift resulting from the
ambient temperature or voltage
fluctuation.
P
Built-in antenna
P
Belt clip rotatable 360 degrees
P
WB-2000 rechargeable battery
or single AA battery operation for
compact and lightweight body
P
Built-in antenna
P
11
WM-5265
WM-5270
WM-5225
Microphone Element
Dynamic microphone: Unidirectional
Dynamic microphone: Cardioid
Electret condenser microphone: Unidirectional
Frequency Range
576 – 932 MHz*1, UHF
576 – 865 MHz*1, UHF
576 – 932 MHz*1, UHF
Channel Selectable
64 channels*1
64 channels*1
64 channels*1
Maximum Input Level
132 dB SPL
142 dB SPL
126 dB SPL
Battery
LR6 (AA) or WB-2000 (Ni-MH battery)
LR6 (AA)
LR6 (AA) or WB-2000 (Ni-MH battery)
Finish
Resin coating
Metal, dark gray
Resin, rubber coating
Dimensions
ø50 x 229 mm (ø1.97″ x 9.02″)
ø48 x 244 mm (ø1.89″ x 9.61″)
ø43 x 231.5 mm (ø1.72″ x 9.11″)
Weight
205 g (0.45lb) (with battery)
340 g (0.75lb) (with battery)
180 g (0.4lb) (with battery)
Accessories
Microphone holder
Microphone holder
Microphone holder
(with stand adapter), Screw driver,
(with standadapter), Screw driver,
(with stand adapter),
Storage case
Storage case, Rolling Stopper
Storage case
WM-5265, WM-5270, WM-5225
Wireless Handheld Microphones
WM-4300
Microphone Element
WM-5325
Electret condenser
microphone: Cardioid
WT-5100
—
Frequency Range
690 –865 MHz*1, UHF
576 – 932 MHz*1, UHF
Channel Selectable
64 channels*1
64 channels*1
Maximum Input Level
120 dB SPL
-14 dB to -29 dB*
Battery
6LR61 (9Vx1)
LR6 (AA) or WB-2000 (Ni-MH battery)
Finish
Resin, coating
Resin, coating (change other's)
Dimensions
62 (W) x 142 (H) x 32 (D) mm
(2.44″ x 5.59″ x 1.26″)
62 (W) x 102.5 (H) x 23 (D) mm
(2.44″ x 4.04″ x 0.91″)
Weight
135 g (0.30lb) (with battery)
90 g (0.2lb) (with battery)
Accessories
Storage case
Screw driver, Storage case, Neckstrap
Option
—
Ni-MH battery: WB-2000
Receiving Frequencies
UHF band (16 ch)
Receiving System
Double super-heterodyne
Receiving Sensitivity
Better than 60 dB Signal to Noise
ratio (20 dB μV input, ±40 kHz deviation)
Frequency Response
200 Hz – 5 kHz
(Portable transmitter to Portable receiver)
(Audio level control: Min. to Max.)
Battery
LR6 (AA) or WB-2000 (Ni-MH battery)
Finish
Resin, dark silver
Dimensions
62 (W) x 163.6 (H) x 32.5 (D) mm
(2.44″ x 6.44″ x 1.28″)
Weight
125 g (0.28lb) (with battery)
Accessory
Neck strap x 1
Options
Ni-MH battery: WB-2000,
Assist Earphone: YP-E5000
Ear-suspension Earphone: YP-E401
WM-4300, WM-5325
Wireless Beltpack Transmitters
WT-5800
WT-5805
576 – 865 MHz*1, UHF
576 – 865 MHz*1, UHF
Power Requirement
Frequency Range
WT-5810
WT-4820
AC mains (AC adapter must be used)
Channel Selectable
576 – 932 MHz
64 Selectable frequencies
Receiving System
Diversity System
WT-5100
Wireless Receiver
576 – 865 MHz*1, UHF (WTU-4800)
16 channels
Double Super-heterodyne
True diversity
Space diversity
Mixing Output
Double Super-heterodyne (WTU-4800)
Space diversity
MIC: -60 dB*2, 600Ω, balanced, XLR-3-31 type connector
Space diversity (WTU-4800)
—
LINE: -20 dB*2, 600Ω, unbalanced, phone jack"
Mixing Input
-20 dB*2, 10 kΩ, unbalanced, phone jack
Antenna
Whip antenna Rod antenna
Whip antenna
Antenna Input
75 Ω, BNC,
9 V DC 75 Ω, BNC, 9 V DC
—
75 Ω, BNC, 9 V DC
Antenna Output
75Ω, BNC (Gain 0dB)
—
—
75Ω, BNC (Gain 0dB)
Receiving Sensitivity
90 dB or more
Squelch Sensitivity
Tone Frequency
S/N Ratio
80 dB or more (WTU-4800)
18 – 40 dB μV variable
18 dB μV (WTU-4800)
32.768 kHz
—
110dB or more (A-weight, unbalanced output)
Harmonic Distortion
104dB or more
102dB or more
(A-weight, balanced output)
(A-weight, balanced output)
1% or less (typical)
Frequency Response
100 – 15,000 Hz, ±3 dB
Finish
50 – 18,000 Hz, ±3 dB
Resin, black
Dimensions
210(W) x 44(H) x 205.1(D) mm
(8.27″ x 1.73″ x 8.07″)
210(W) x 44(H) x 205.1(D) mm
(8.27″ x 1.73″ x 8.07″)
206(W) x 40.6(H) x 152.7(D) mm
(8.11″ x 1.60″ x 6.01″)
210(W) x 44.2(H) x 181(D) mm
(8.27″ x 1.73″ x 7.13″)
Weight
700 g (1.54lb)
700 g (1.54lb)
590 g (1.30lb)
770 g (1.70lb) (without tuner module)
WT-5800 WT-5805 WT-5810 WT-4820
Wireless Tuners
number of channels may differ from country to country
* 1.2. The
* 0dB = 1V
12
S4.16 SERIES
12 Channel Wireless Solution
S4.16 Receiver
Multichannel wireless simply does not get any easier. Based on Trantec’s award winning S4000 Series, the S4.16 is 16
channels of tough, reliable quality that is priced to suit the tightest of budgets.
This multifunction system is optimised for use with handheld, lapel mic and a range of headsets – or switch to use with a
musical instrument. A single 9V battery gives approximately 10 hours of quality performance with a range of up to 100 metres.
Features:
P
P
P
16 selectable frequencies
P
Up to 8 simultaneous channels
P
Fully synthesised PLL quartz tuning technology
P
Receiver LED’s show AF Peak level, RF Level, and
Diversity Channel A or B
P
Diversity operation with detachable antennae
Professional metal enclosure
19” rack mount option for one or two receivers.
*0dB=0.775V
Power Consumption
100 mA (12 V DC)
Frequency Response
Audio Output
Balanced output: +16 dB*(max), 600 Ω, balanced,
XLR-3-31 type connector
Unbalanced output: +10 dB*(max), 600 Ω,
unbalanced, phone jack
Operation Temperature
-10°C to +45°C
Dimensions
214 (W) x 35 (H) x 100.5 (D) mm (8.4″ x 1.39″ x 6.06″)
(excluding antenna)
Weight
580g (1.28lb)
Frequency Bands
606-614, 719-744, 854-865 MHz
Receiving Sensitivity
Over 90 dB, S/N ratio (20 dB μV input, 40 kHz deviation)
Squelch Sensitivity
18 - 40 dB μV variable
Indicator
ANT A/B, Audio (peak), RF level, Power
S/N Ratio
Over 95 dB (A-weight, unbalanced output)
Harmonic Distortion
Under 1% (typical)
100 - 15,000 Hz, ±3 dB
16 Channel Capability (12 Simultaneous Channels)
S4.16 RX Receiver
12 Channel Wireless System
S4.16B Aerobic System
Supplied with SJ66 & AB1000
S4.16 B Theatre System
Supplied with SJ22-P-R
S4.16 B Earworn System
Supplied with SJEM77-P
13
S4.16 Handheld
S4.16 Beltpack
For powerful vocal performance or general speech
applications, the S4.16 HDX is an ergonomically
designed mic featuring a high quality Trantec cardioid
dynamic capsule suitable for the most demanding of
vocal applications.
The beltpack is equally at home in applications as
diverse as a quiet church through to a grinding step
class or a stadium rock’n’roll gig thanks to its range of
matching microphone and cable options.
Features:
Features:
P
16 selectable frequencies
P
16 selectable frequencies
P
Fully synthesised PLL quartz tuning technology
P
Fully synthesised PLL quartz tuning technology
P
Detachable antenna
P
Detachable antenna
P
Single 9V transmitter battery life of approx. 10 hours.
P
Locking 3.5mm jack
P
Integral switch for selection between
instrument and microphone
P
Single 9V transmitter battery life of approx. 10 hours.
For accessories see pages 22-25
RF Carrier Power
Max. 10 mW
RF Carrier Power
Modulation System
PLL Synthesizer
Modulation System
PLL synthesizer
Battery
6LR61 (PP3 9V)
Mic Input Connector
ø3.5 mini jack
Battery Life
Approx. 10 hours
Battery
6LR61 (PP3 9V)
Indicator
Battery Status LED
Battery Life
Approx. 10 hours
Dimensions
ø50 x 270 mm (ø1.97″ x 10.63″)
Indicator
Battery status LED
Weight
220g (0.49lb)
Dimensions
62 (W) x 102 (H) x 31.5 (D) mm (2.48″ x 4.02″ x 1.27″)
(excluding antenna)
Weight
90g (0.2lb)
S4.16 BTX Beltpack
12 Channel Wireless System
S4.16 HDX Handheld
12 Channel Wireless System
S4.16 Handheld System
Supplied with S4.16 HDX
Max. 10 mW
S4.16 L Presenter System
Supplied with LP2 & Instrument Cable
S4.16 B Active System
Supplied with SJ33
14
S4.16 SERIES
8 Channel Wireless Solution
S4.16 Receiver
The S4.16 Dual Channel Wireless Receiver is a multifunctional system available in 16 selectable frequencies which can
run up to 8 simultaneous channels.
The S4.16 couples efficiency and simplicity to ensure consistent performance each and every time.
The S4.16 Dual Channel permits multiple receivers to conjoin, perfect for schools, churches and audio visual applications.
Features:
P 16 selectable frequencies
P Up to 8 simultaneous channels
P Fully synthesised PLL quartz tuning technology
P 19” rack mount option for one or two receivers.
P Receiver LED’s show AF Peak level, RF Level, and
Diversity Channel A or B
P Diversity operation with detachable antennae
Power Consumption
First If Frequency
Second If Frequency
Audio Output
Antenna Input
250 mA (13.8 V DC)
55.875 MHz
10.700 MHz
AF Output 1:
+10dBu unbalanced via 1/4 inch mono jacksocket
+16dBu balanced via XLR 3F connector Pin 2+
AF Output 2 BAL
+10dBu unbalanced via 1/4 inch mono jacksocket.
+16dBu balanced via XLR 3F connector Pin 2+
75Ω, BNC (phantom powering for antenna), 9 V DC,
30mA (max)
Antenna Output
Indicator
S/N Ratio
Harmonic Distortion
Frequency Response
Finish
Dimensions
Weight
Receiving Frequency
75Ω, BNC (Gain 0 dB)
ANT A/B, Audio (peak), Power
Over100dB(A-weignt)
Under 1%
Handheld 80 Hz -16 kHz +/-3dB.
Beltpack 60 Hz -16 kHz +/-3dB.
Resin, black
210 (W) x 44 (H) x 181 (D) mm (8.27″ x 1.73″ x 7.13″)
720g (1.59lb)
606-614 MHz.UHF
S4.16 RX2
8 Channel Wireless Solution
S4.16 RX2 Aerobic System
Supplied with SJ66 & AB1000
S4.16 RX2-T Theatre System
Supplied with SJ22-P-R
S4.16 RX2-E Earworn System
Supplied with SJEM77-P
15
S4.16 Handheld
S4.16 Beltpack
For powerful vocal performance or general speech
applications, the S4.16 HDX is an ergonomically
designed mic featuring a high quality Trantec cardioid
dynamic capsule suitable for the most demanding of
vocal applications.
The beltpack is equally at home in applications as
diverse as a quiet church through to a grinding step
class or a stadium rock’n’roll gig thanks to its range of
matching microphone and cable options.
Features:
P
P
P
P
Features:
16 selectable frequencies
Fully synthesised PLL quartz tuning technology
Detachable antenna
Single 9V transmitter battery life of approx. 10 hours.
P
P
P
P
P
16 selectable frequencies
Fully synthesised PLL quartz tuning technology
Detachable antenna
Locking 3.5mm jack
Integral switch for selection between
instrument and microphone
P Single 9V transmitter battery life of
approx. 10 hours.
For accessories see pages 22-25
RF Carrier Power
Max. 10 mW
RF Carrier Power
Modulation System
PLL Synthesizer
Modulation System
PLL synthesizer
Battery
6LR61 (PP3 9V)
Mic Input Connector
ø3.5 mini jack
Battery Life
Approx. 10 hours
Battery
6LR61 (PP3 9V)
Indicator
Battery Status LED
Battery Life
Approx. 10 hours
Dimensions
ø50 x 270 mm (ø1.97″ x 10.63″)
Indicator
Battery status LED
Weight
220g (0.49lb)
Dimensions
62 (W) x 102 (H) x 31.5 (D) mm (2.48″ x 4.02″ x1.27″)
(excluding antenna)
Weight
90g (0.2lb)
S4.16 Beltpack
S4.16 Handheld
S4.16 RX2 Handheld System
Supplied with S4.16 HDX
Max. 10 mW
S4.16 RX2-L Presenter System
Supplied with LP2 & Instrument Cable
S4.16 RX2-A Active System
Supplied with SJ33
16
S4.4 SERIES
Wireless Starter Pack
S4.4 Receiver
Trantec’s S4.4 is a function-packed system designed to launch you into the world of wireless. Tough, reliable and
compact, this multi-function system is optimised for use with handheld, lapel mic and a range of headsets – or switch to
use with a musical instrument.
Not only does the S4.4 come with a bargain basement price tag, it is also extremely economical to run. Its four channels
can be used licence free in the UK, and a single 9V battery will give you approximately 10 hours of quality performance
with a range of up to 100 metres.
Features:
P Four switchable frequencies
P Fully synthesised PLL quartz tuning technology
P Receiver LED’s show AF Peak level, RF Level, and
Diversity Channel A or B
P Professional metal enclosure
P 19” rack mount option for one or two receivers
*0dB=0.775V
Power Consumption
100 mA (12 V DC)
Frequency Response
Audio Output
Balanced output: +16 dB*(max), 600 Ω, balanced,
XLR-3-31 type connector
Unbalanced output: +10 dB*(max), 600 Ω, unbalanced,
phone jack
Operation Temperature
-10°C to +45°C
Dimensions
214 (W) x 35 (H) x 100.5 (D) mm (8.43″ x 1.38″ x 3.96″)
(excluding antenna)
Weight
580g (1.28lb)
Frequency Bands
691-693, 719-721, 742-744, 863-865 MHz
Receiving Sensitivity
Over 90 dB, S/N ratio (20 dB μV input, 40 kHz deviation)
Squelch Sensitivity
18 - 40 dB μV variable
Indicator
ANT A/B, Audio (peak), RF level, Power
S/N Ratio
Over 95 dB (A-weight, unbalanced output)
Harmonic Distortion
Under 1% (typical)
100 - 15,000 Hz, ±3 dB
4 Channel Capability
S4.4 RX Receiver
Wireless Starter Pack
S4.4 B Aerobic System
Supplied with SJ66 & AB1000
S4.4 B Theatre System
Supplied with SJ22-P-R
S4.4 B Earworn System
Supplied with SJEM77-P
17
S4.4 Handheld
S4.4 Beltpack
For powerful vocal performance or general speech
applications, the S4.4 HDX is an ergonomically designed
mic featuring a high quality Trantec cardioid dynamic
capsule suitable for the most demanding of vocal
applications.
The beltpack is equally at home in applications as
diverse as a quiet church through to a grinding step
class or a stadium rock’n’roll gig thanks to its range of
matching microphone and cable options.
Features:
P
P
P
P
Features:
Four switchable licence-free frequencies
Fully synthesised PLL quartz tuning technology
Detachable antenna
Single 9V transmitter battery life of approx. 10 hours.
P
P
P
P
P
Four switchable free frequencies
Fully synthesised PLL quartz tuning technology
Detachable antenna
Locking 3.5mm jack
Integral switch for selection between instrument and
microphone
P Single 9V transmitter battery life of approx. 10 hours.
For accessories see pages 22-25
RF Carrier Power
Max. 10 mW
RF Carrier Power
Modulation System
PLL Synthesizer
Modulation System
PLL synthesizer
Battery
6LR61 (PP3 9V)
Mic Input Connector
ø3.5 mini jack
Battery Life
Approx. 10 hours
Battery
6LR61 (PP3 9V)
Indicator
Battery Status LED
Battery Life
Approx. 10 hours
Dimensions
ø50 x 270 mm (ø1.97″ x 10.63″)
Indicator
Battery status LED
Weight
220g (0.49lb)
Dimensions
62 (W) x 102 (H) x 31.5 (D) mm (2.48″ x 4.02″ x 1.27″)
(excluding antenna)
Weight
90g (0.2lb)
S4.4 BTX Beltpack
Wireless Starter Pack
S4.4 HDX Handheld
Wireless Starter Pack
S4.4 Handheld System
Supplied with HDX
Max. 10 mW
S4.4 L Presenter System
Supplied with LP2 & Instrument Cable
S4.4 B Active System
Supplied with SJ33
18
S5
LAVALIER MICS
5000
S4
LP-2
PRODUCT CODE:
MIC-X2 (FOR S.5.5, BLACK),
MIC-X2 (FOR S.5.3, BLACK),
MIC-LP2 (FOR S.4.16, BLACK),
MIC-LP2 (FOR S.4.4, BLACK)
The LP-2 miniature lavalier
microphone offers superb audio
quality combined with stylish looks at
an affordable price.
Type:
Omni-directional electret condenser
Nominal Impedance:
3000 ohms
Max SPL:
>120dB
Operating Voltage:
2-10 volts min/max
Current Consumption:
50uA
Frequency response:
60Hz-16kHz ±3dB
Cable Length:
1500mm
Colours Available:
Black
LP-2 Lavalier Mic
The robustly designed LP-2 is a high quality microphone consistingof an electret transducer capsule exhibitingan
omni-directional characteristic. It has been specifically designed to suit the requirements of everyday applications and is
particularly suitable for voice applications, where highly intelligible speech is required. The LP-2 is available in black,
and has a permanently attached cable.
LM-55
PRODUCT CODE:
MIC-X55 (FOR S.5.5, BLACK),
MIC-X55 (FOR S.5.3, BLACK),
MIC-SJ55 (FOR S.4.16, BLACK),
MIC-SJ55 (FOR S.4.4, BLACK)
The LM-55 electret sub-miniature
microphone capsule has been
provided with a moulded plastic
housing and cable for convenient on
lapel or tie for communications,
public address, music recording and other applications.
Type:
Omni-directional electret condenser
Nominal Impedance:
4700 ohms
Max SPL:
>120dB
Operating Voltage:
2-20 volts min/max
Current Consumption:
50uA
Frequency response:
30Hz -16 kHz, ±3dB
Cable Length:
1500mm
Colours Available:
Black
LM-55 Lavalier Mic
This microphone features a flat, extended frequency response suitable for reproduction of voice or musical instruments.
A 1.5 metre long black shielded cable of 2.5mm diameter is provided in the basic configuration. This cable includes two
wires plus a spiral wound shield, which are soldered to the microphone capsule. A composite steel retainer plus
moulded elastic strain relief provide a very rugged miniature package. Noise transmission from handling and clothing
movement is very low. The LM-55 has a wide band omni-directional polar pattern. Internal RFI suppression is included.
YP-M5300
UNIDIRECTIONAL LAVALIER MICROPHONE
PRODUCT CODE: YP-M5300
P
P
Unidirectional electret
condenser microphone element
P
P
Connector for 3.5 mini-plug
Weight: 20 g
Maximum input level: 120 dB SP
LAVALIER CONNECTOR VARIATIONS
Model Number
LP-2
LM-55
SJ-690H
LM-212
S5.5
MIC-X2
MIC-X55
MIC-X690H
MIC-X212
S5.3
MIC-X2
MIC-X55
MIC-X690H
MIC-X212
S4.16
MIC-LP2
MIC-SJ55
MIC-SJ690H
MIC-SJ212
S4.4
MIC-LP2
MIC-SJ55
MIC-SJ690H
MIC-SJ212
19
LAVALIER MICS
SJ-690H
PRODUCT CODE:
MIC-X690H (FOR S5.5, BEIGE),
MIC-X690H (FOR S5.3, BEIGE),
MIC-SJ690H (FOR S4.16, BEIGE),
MIC-SJ690H (FOR S4.4, BEIGE)
Type:
Omni-directional electret condenser
Nominal Impedance:
1000 ohms
Max SPL:
>58dB (high SPL version available)
Operating Voltage:
1-10 volts min/max
Frequency response:
20Hz -20 kHz, ±3dB
The SJ-690H high quality glasses
Cable Length:
frame microphone has been
Colours Available:
designed to offer the finest
microphone alternative for users with
glasses. Designed with a view to
flexibility, the single sided microphonefits tightly onto several frame sizes.
1300mm
Beige
SJ-690H Lavalier Mic
The SJ-690H is lightweight and does not limit the movement of the user, the microphone is mounted onto a boom
enabling adjustments to the microphone to allow for optimum sound quality.
LM-212
PRODUCT CODE:
MIC-X212-BK (FOR S5.5, BLACK),
MIC-X212-BE (FOR S5.5, BEIGE),
MIC-X212-BK (FOR S5.3, BLACK),
MIC-X212-BE (FOR S5.3, BEIGE),
MIC-SJ212-BK (FOR S4.16, BLACK),
MIC-SJ212-BE (FOR S4.16, BEIGE),
MIC-SJ212-BK (FOR S4.4, BLACK),
MIC-SJ212-BE (FOR S4.4, BEIGE)
Type:
Omni-directional electret condenser
Nominal Impedance:
4400 ohms
Max SPL:
>120dB (high SPL version available)
Operating Voltage:
2-10 volts min/max
Current Consumption:
12-25uA min/max
Frequency response:
40Hz -18 kHz, ±3dB
Cable Length:
1200mm
Colours Available:
Black & Beige
The LM-212 high quality lavalier
LM-212 Lavalier Mic
microphone has been designed with
the professional in mind. Its subminiature construction, together with its durable microphone clip makes it an ideal
partner for all area of live work.
It can be used either as a microphone for instrument pick-up or for delivering highly intelligible speech or vocals.
The extremely low profile of the LM-212 enables this microphone to be used in places where others have failed due to
their more obtrusive size. With an exceptionally low physical profile, it can withstand the penetration of moisture and
make-up, and has the same membrane construction as its sister product the HM-22. Whether used in the hair, on the
face or as a body-worn lavalier, this microphone will withstand the everyday rigours of production.
YP-M5310
OMNIDIRECTIONAL LAVALIER MICROPHONE
PRODUCT CODE: YP-M5310
P
LP/SJ = 3.5mm Screw Jack
Omnidirectional electret
condenser microphone
element
P
P
P
Maximum input level:
110 dB SPL
Connector for 3.5 mini-plug
Weight: 20 g
X = 4 Pin Mini XLR
20
S5
HEADWORN MICS
5000
S4
HM-33
PRODUCT CODE:
MIC-X33 (FOR S5.5, BLACK),
MIC-33 (FOR S5.3, BLACK),
SJ-33 (FOR S4.16, BLACK),
SJ-33 (FOR S4.4, BLACK)
The HM-33 has been designed
primarily for the active professional
who needs hands-free operation.
Type:
Electret condenser
Nominal Impedance:
3300 ohms
Max SPL:
>120dB
Frequency response:
20Hz -16kHz
Cable Length:
1500mm
Colours Available:
Black
Suitable for people in the sports,
journalism, event organizers and
restaurant applications.
HM-33 Headworn Mic
The headband is perfect for those applications which require a high performance cost-effective solution.
Supplied with foam windshield.
HM-66
PRODUCT CODE:
MIC-X66-BK (FOR S5, BLACK),
MIC-X66-BL (FOR S5, BLUE),
MIC-X66-YE (FOR S5, YELLOW),
MIC-SJ66-BK (FOR S4, BLACK),
MIC-SJ66-BL (FOR S4, BLUE),
MIC-SJ66-YE (FOR S4, YELLOW)
The HM-66 has been designed
primarily with the sports and
aerobics industry in mind and is
therefore built to withstand the everyday rigours of an active lifestyle.
Type:
Super cardioid electret condenser
Nominal Impedance:
3000 ohms
Max SPL:
125dB
Operating Voltage:
2-10 volts min/max
Current Consumption:
50uA
Frequency response:
60Hz-16kHz ±3dB
Cable Length:
1500mm
Colours Available:
Black, Blue & Yellow
HM-66 Headworn Mic
The construction of this headband microphone offers a high degree of protection against the ingress of sweat. Precise
placement is obtained with the 4mm diameter flexible gooseneck, and the condenser capsule is highly efficient at noise
cancellation – helping prevent feedback or interference from crowd noise etc.
This slim-line Aerobic Headset is available in a choice of the following colours: Black, Blue & Yellow.
WH-4000H
HEADSET MICROPHONE
PRODUCT CODE: WH-4000H
P
Unidirectional electret
condenser microphone
element
P
Maximum input level:
120 dB SPL
P
Connector for 3.5 mini-plug
P
Secure and comfortably
fitting headset
P
Weight: 50 g
HEADWORN/EARWORN MIC CONNECTOR VARIATIONS
Model Number
HM-33
HM-66
HM-22
EM-77
S5.5
MIC-X33
MIC-X66
MIC-X22
MIC-XEM77
S5.3
MIC-X33
MIC-X66
MIC-X22
MIC-XEM77
S4.16
SJ-33
MIC-SJ66
MIC-SJ22
MIC-SJEM77
S4.4
SJ-33
MIC-SJ66
MIC-SJ22
MIC-SJEM77
21
HEADWORN MICS
HM-22
PRODUCT CODE:
MIC-X22-BK (FOR S5.5, BLACK),
MIC-X22-BE (FOR S5.5, BEIGE),
MIC-X22-BK (FOR S5.3, BLACK),
MIC-X22-BE (FOR S5.3, BEIGE),
MIC-SJ22-BK (FOR S4.16, BLACK),
MIC-SJ22-BE (FOR S4.16, BEIGE),
MIC-SJ22-BK (FOR S4.4, BLACK),
MIC-SJ22-BE (FOR S4.4, BEIGE)
Type:
Omni-directional electret condenser
Nominal Impedance:
4400 ohms
Max SPL:
>120dB (high SPL version available)
Operating Voltage:
2-10 volts min/max
Current Consumption:
12-25uA min/max
Frequency response:
40Hz-18 kHz, ±3dB
Cable Length:
1200mm
Colours Available:
Black & Beige
The HM-22 is a high quality
HM-22 Headworn Mic
headband microphone,
which not only claims to be
one of the smallest but also one of the lightest headband microphones on the planet.
It has been designed to be worn around the head and to be hidden discreetly under the hair.
The headband is engineered from a hard wearing nylon composite, which has been specially selected to withstand
robust use and yet can be adjusted to fit any user’s head and ear shape. The high quality microphone, optimized for
speech and vocals, is mounted on a boom that can be bent into shape to allow for optimum sound quality. A small
membrane is inserted into the capsule housing which protects the capsule from moisture, make-up and any other dirt
and can be replaced cheaply and effectively to allow the microphone to perform consistently at its best.
EM-77
EARWORN MIC
PRODUCT CODE:
MIC-XEM77 (FOR S5.5, BEIGE),
MIC-XEM77 (FOR S5.3, BEIGE),
MIC-SJEM77 (FOR S4.16, BEIGE),
MIC-SJEM77 (FOR S4.4, BEIGE)
The EM-77 is a high quality single
ear microphone. Its lightweight
construction allows the user
complete freedom of movement
making it ideal for theatre,
conference and educational use.
Element:
Back electret condenser
Polar Pattern:
Omni-directional
Frequency Response:
20Hz ~ 20kHz
Sensitivity:
5mV/Pa +/- 3dB
Operating Voltage:
1.5V ~ 10V D.C.
Cable Length:
1200mm
Colours Available:
Beige
EM-77 Earworn Mic
This single ear microphone features a highly configurable and discreet capsule, making it ideal for countless applications.
WH-4000A
HEADSET (AEROBIC) MICROPHONE
P
P
SJ = 3.5mm Screw Jack
PRODUCT CODE: WH-4000A
Unidirectional electret
condenser microphone
element
P
Connector for 3.5 mini-plug
P
Extra-secure and
comfortably-fitting head set
Maximum input level:
120 dB SPL
P
Weight: 50 g
X = 4 Pin Mini XLR
22
S5
ACCESSORIES
5000
S4
Antenna Distribution
S5 ADU A N T E N N A
DISTRIBUTOR
PRODUCT CODE: S5-ADU
The S5-ADU allows a single pair of antenna to feed up to four tuners.
The largest systems (up to 12 channels), additional ADUs can be cascaded.
WD-4800 A N T E N N A
DISTRIBUTOR
PRODUCT CODE: WD-4800
Is designed to be used in conjunction with VHF/UHF band systems. It
comes with 2 channels, in which 2 input signals are mixed and distributed
to 4 outputs. The WD-4800 also has 4 DCpower distribution outputs.
YW-7000
SPLITTER
RF AMPLIFIER
PASSIVE ANTENNA SPLITTER
PRODUCT CODE: YW-7000
PRODUCT CODE: ACC-SPLIT-2W
An RF amplifier specifically
designed to be used with 10-12
metre length cable runs of
RG58/URM43 connecting to
remote antennae.
Allows 1 x RF feed to be split in
order to feed 2 outputs.
Connector: TNC-type. Isolation:
25dB Insertion Loss: 5dB.
Frequency Range:500MHz-1GHz
Remote Antenna
YW-7570 REMOTE
ANTENNA
PRODUCT CODE: YW-7570
The YW-7520 and YW-7570 are antennas for the UHF band wireless system and are designed to
be mounted on an optional microphone stand.
Features:
P An omnidirectional antenna YW-7520 designed for receiving radio signal from all 360° directions.
P A directional antenna YW-7570 designed for having higher receiving sensitivity in the
directional angle compared with an omnidirectional antenna.
YW-7520
UHF
OMNIDIRECTIONAL
ANTENNA
WALL MOUNT ANTENNA
PRODUCT CODE: YW-7520
Cable loss can be compensated for
by a built-in RF signal booster.
The YW-4500 is a dipole antenna
designed to be installed indoors.
PRODUCT CODE: YW-4500
23
ACCESSORIES
Receiver Antenna
Receiver Antenna
Receiver Antenna
PRODUCT CODE:
PRODUCT CODE:
ANT-S4.16 RX-D (830-865 MHz)
ANT-S5 RX-D (830-865 MHz)
ANT-S4.16 RX-G (606-638 MHz)
ANT-S5 RX-G (606-638 MHz)
For S4.16 receiver
For S5.3 and S5.5 series.
Transmitter Antenna
Whip Antenna
Helical Antenna
PRODUCT CODE:
PRODUCT CODE:
ANT-54 BTX-D(830-865 MHz)
ANT-54 HDX-D(830-865 MHz)
ANT-54 BTX-G(606-638 MHz)
ANT-54 HDX-G(606-638 MHz)
For S4 & S5 Series
UHF belt-pack transmitters.
For S4.4 & S4.16
UHF hand-held transmitters.
Battery Chargers & Power Supplies
PRODUCT CODE: BC-5000-12
PRODUCT CODE: BC-5000-2
BC-5000-12
BC-5000-6
BATTERY CHARGER
BATTERY CHARGER
P Number of wireless
P Number of wireless
P
microphone to be charged
simultaneously: 12
Fully charged within 3 hours
PRODUCT CODE: BC-5000-6
P
microphone to be charged
simultaneously: 6
Fully charged within 3 hours
BC-5000-2
WB-2000-2
BATTERY CHARGER
RECHARGEABLE BATTERY
P Number of wireless
P AA nickel-metal hydride (Ni-MH)
P
microphone to be charged
simultaneously: 2
Fully charged within 3 hours
rechargeable battery
PRODUCT CODE: WB-2000-2
P For Wireless Microphones, Wireless
Transmitter, and Portable Receiver
AD-5000-6
AD-5000-2
AC ADAPTER
AC ADAPTER
PRODUCT CODE: AD-5000-6
PRODUCT CODE: AD-5000-6
P For BC-5000-12 and
BC-5000-6 Battery Chargers
P For BC-5000-2
Battery Charger
UK
Europe
PRODUCT CODE: PS-S115-UK
European Power supply for S4/S5 Series
Receiver. Output 13V DC 300mA.
UK Power supply for
S4/S5 Series Receiver
Output 13V DC 300mA.
USA
PRODUCT CODE: PS-S115-EU
PRODUCT CODE: PS-S115-USA
USA Power supply for S4/S5 Series
Receiver. Output 13V DC 300mA.
24
S5
ACCESSORIES
5000
S4
Antenna Cable
Link Cable ANTENNA
S4 Series ANTENNA
EXTENSION CABLE
EXTENSION CABLE
PRODUCT CODE: LD-BNC-TNC
PRODUCT CODE: LD-TNC ADU
Using RG58 50ohm coaxial
cable. Available in 60cms
lengths S4/S5 Series
TNC panel mount socket - BNC
plug using 35cms RG58 50ohm
coaxial cable.
Instrument Cable
Guitar Cable
Guitar Cable
S 4.4 AND S 4.16 SERIES
S 5.3 AND S 5.5 SERIES
PRODUCT CODE: LD-SJ-JAC
PRODUCT CODE: LD-X-JAC
Instrument cable terminated with
3.5mm Screw Jack – 6.3mm
Mono Jack Plug, 1.3m length.
Instrument cable terminated with
4 pin mini XLR (TA-4) – 6.3mm
Mono Jack Plug, 1.3m length.
Rackmount Kits
ACC-S5RX-MBI
ACC-S5RX-MB3
RACK MOUNT KIT FOR
S 5 RECEIVER
RACK MOUNT KIT FOR
S5 RECEIVER
This kit will enable you to mount 1
x S5 receiver in a 1U, 19” rack
space.
Mount 1 x S5 receiver in a 1U, 19”
rack space, kit included 2 x Panel
mount TNC extension cables.
MB-15B
MB-WT3
RACK MOUNT BRACKET
RACK MOUNT BRACKET KIT
For Rack Mounting 1 WD-4800 unit
For Rack Mounting 1 WT-5800,
WT580 and/or WT-4820 unit
MB-WT4
ACC-S5RX-MB2
RACK MOUNT BRACKET KIT
For Rack Mounting 2 WT-5800,
WT5805 and/or WT-4820 units
RACK MOUNT KIT FOR S 5
RECEIVER
PAN-1U19-TNC
MW-1U-BLANK
TNC RACK MOUNT PANEL
BLANK PANEL
For mounting 2 x TNC panel mount
sockets.
This kit will enable you to mount 2
x S5 receivers side by side.
25
ACCESSORIES
Microphone Windshields
YP-E401PAD01
PRODUCT CODE: YP-E401PAD01
Earphone Pads
Contains 100 Pieces
HM-22B
PRODUCT CODE: ACC-WS-BLK
LM-212B
PRODUCT CODE: ACC-WS-BLK
Foam windshield for HM-22B and
LM-212B
WH-4000S
PRODUCT CODE: WH-4000S
Windscreens
Contains 10 Pieces
Tie Clips
LM-55
LP-2
PRODUCT CODE: ACC-5200WS
PRODUCT CODE: ACC-LP2-TC
Foam windshield for LM-55
Spare Tie Clip for LP-2
HM-33
LM-55
PRODUCT CODE: ACC-33WS
PRODUCT CODE: ACC-5200-TC
Foam windshield for HM-33
Spare Tie Clip for LM-55
HM-66
HM-22P
PRODUCT CODE: ACC-66WS
PRODUCT CODE: ACC-TC-BGE
Foam windshield for HM-66
LM-212
PRODUCT CODE: ACC-TC-BGE
Spare Tie Clip for HM-22P
and LM-212
HM-22P
PRODUCT CODE: ACC-WS-BGE
HM-22B
PRODUCT CODE: ACC-TC-BLK
LM-212P
LM-212
PRODUCT CODE: ACC-WS-BGE
PRODUCT CODE: ACC-TC-BLK
Foam windshield for HM-22P
Spare Tie Clip for HM22B
and LM-212
and LM-212P
TOA Corporation
Human Society with
Sound & Communication
www.toa.jp
Specifications are subject to change without notice.
833-61-790-30
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
