User manual | WIRELESS GUIDE SYSTEM Be Heard, Be Clear

WIRELESS GUIDE SYSTEM
Be Heard, Be Clear
Features
Guided Tour Applications
16 different frequencies can be used simultaneously.
C ompact, light, and easy to operate —
even for the very first time.
B oth the wireless transmitter and receiver use the TOA
WB-2000-2 rechargeable battery, with the WT-5100
wireless receiver providing up to 16 hours
of continuous operation.
Transmit ter
for tour guide
F requency range of 576 to 865 MHz. Note: varies by country.
Receiver
for tourist s
O ne wireless transmitter can be assigned an unlimited
Conference Applications
number of wireless portable receivers.
C lear coverage up to 30 meters
indoors and up to 60 meters
outdoors.
Eng
lish
CH1: English
Note: varies according to the
surrounding environment.
Inside
30m
CH2
Ou
ts
CH2: Japanese
ide
60m
CH2
Receiver
for Japanese
listeners
CH1
Used for
listening
assistance
Lineup
Optional Earphones
WT-5100
Wireless Portable Receiver
・Tunable to any of 16 different
frequencies
・Runs for 16 hours on a fully charged
WB-2000-2 rechargeable battery
・Battery status indicator
・Compact and lightweight body
YP-E5000
connection
YP-E401
・φ3.5 mm
mini plug (2 pole)
YP-E401
connection
YP-E5000
・φ3.5 mm
mini plug (3 pole)
・Assist earphone
The YP-E5000 Assist Earphone boosts high
frequencies in voice output, making it
ideal for assistive listening applications.
Optional Microphones
WM-5325
Wireless Portable Transmitter
・Microphone sensitivity adjustment
(-14 dB to -20 dB)
・13 hours of quality performance
from a fully charged WB-2000-2
rechargeable battery
・Battery status indicator
・Compact and lightweight body
BC-5000-2
Battery Charger
BC-5000-6
Battery Charger
Human Society with
Sound & Communication
YP-M5300
・Unidirectional
lavalier microphone
YP-M5310
・Omnidirectional
lavalier microphone
WH-4000H
・Unidirectional
headset microphone
BC-5000-12
Battery Charger
AD-5000-2
AC Adapter
WM-5225
Wireless Handheld Microphone
・Condenser cardioid microphone
capsule
・Ideal for speech-related applications
・Turns on/off with one hand
・13 hours of quality performance
from a fully charged WB-2000-2
rechargeable battery
・Battery status indicator
AD-5000-6
AC Adapter
WB-2000-2
Ni-MH Battery
Pack
www.toa.jp
Specifications are subject to change without notice
(1310)833-61-793-20 o
