English
CONTROLS
TOP AND FRONT PANELS
BACK PANEL
(See 1)
1SOURCE – selects CD/ TUNER function
2STANDBY y – power on/ standby switch
(If the set is battery powered, this functions as
power on/ off)
3BASS, MID, HIGH – EQ keys to adjust the bass,
mid & treble frequencies
4PROG
CD:
programmes tracks and reviews the
programme;
Tuner: programmes preset radio stations
5Navigation controls
∞, §
MP3-CD: – searches back and forward within a
track;
– skips to the beginning of a current
track/ previous/ later track
Tuner: – tunes to radio stations (down, up).
2; – starts or pauses CD playback
9 – stops CD playback;
– erases a CD programme
6Door
7REMOTE SENSOR – infrared sensor for remote
control
8VOLUME – to adjust volume level
9MODE – selects different play modes:
e.g. REPEAT or SHUFFLE (random) order
0PRESET/ ALBUM (–, +) –
MP3-CD (only): – selects previous/ next album
Tuner: – selects the previous/ next preset
station
!BAND/ DISPLAY –
MP3-CD: – shows various text and time
information during playback
Tuner: – selects waveband
@DBB – (Dynamic Bass Boost) activates a more
vivid bass response
#Display – shows the status of the set
$Telescopic aerial – improves FM reception
%Battery compartment – for 6 batteries,
type R-20, UM1 or D-cells
^Voltage selector (inside battery compartment,
some versions only) – adjust to match the local
voltage 110/220V before plugging in the set
&p – 3.5 mm stereo headphone socket
Note: The speakers will be muted when
headphones are connected to the set.
*AC MAINS – inlet for mains lead
Downloaded From Disc-Player.com Philips Manuals
REMOTE CONTROL
(See 2)
1CD – selects CD sound source
2y – switches the set to standby/ on if set
operating on AC power. (Switches set off only if
battery powered)
3VOLUME 3,4 – adjusts volume level (up, down)
4SHUFFLE – plays MP3-CD/ CD tracks in random
order
5BASS – selects DBB on/off
62; – starts/ pauses MP3-CD/ CD playback
7SEARCH 5, 6 – searches backwards/ forwards
within a MP3-CD/ CD track
8BAND – selects FM/ MW (LW) waveband
9PRESET +, – (up, down) –
MP3-CD (only): – selects previous/ next album
Tuner: – selects the previous/ next preset
station
0TUNING ∞, § – tunes to tuner stations
(down, up)
!TUNER – selects tuner sound source
@9 – stops MP3-CD/ CD playback;
– erases a MP3-CD/ CD programme
#¡, ™ – skips to the beginning of a current track
previous/ subsequent track
$MUTE – interrupts/ resumes sound
%REPEAT – repeats a track /programme/ entire
MP3-CD/ CD
P
CA
Us
pr
ra
IM
Fo
th
M
W
co
po
ins
Ba
•
Re
•
Inc
lea
th
•
•
•
Us
1
2
S
s
POWER SUPPLY
CAUTION
Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
BASIC FUNCTIONS
Auto-Standby mode
When the MP3-CD/CD player has reached the end of
playback and remains in the stop position for more
than 15 minutes, the set will switch off automatically
to save energy.
IMPORTANT!
For users in the U.K.: please follow the instructions on The type plate is located on the bottom of the
set.
the upper righthand-side.
MAINS SUPPLY
BASIC FUNCTIONS
Whenever convenient, use the mains supply to
conserve battery life. Make sure you remove the
power plug from the set and wall socket before
inserting batteries.
Switching on and off and selecting function
1 Press STANDBY y on the set to switch on.
2 Press SOURCE once or more to select: CD or TUNER
function.
3 Press STANDBY y to switch off the set.
Batteries (not included)
• Insert 6 batteries, type R-20, UM-1 or D-cells,
(preferably alkaline) with the correct polarity.
Note: The tone, sound settings, tuner presets and the
volume level (up to a maximum volume level of
20) will be retained in the set’s memory.
Remote control (see A)
• Insert 2 batteries, type AAA, R03 or UM4
(preferably alkaline).
Adjusting volume and sound
1 Adjust the volume with the VOLUME control.
™ Display shows the volume level and a number
Incorrect use of batteries can cause electrolyte
from 0-32.
leakage and will corrode the compartment or cause
2 Press DBB once or more to select dynamic bass
the batteries to burst.
boost on or off.
• Do not mix battery types: e.g. alkaline with carbon
™ Display: shows DBB ON or DBB OFF when
zinc. Only use batteries of the same type for the
activated/deactivated.
set.
3 To adjust the bass, mid and treble tones, press and
• When inserting new batteries, do not try to mix old
hold + or – on the BASS, MID, HIGH keys until
batteries with the new ones.
you reach the desired level.
• Batteries contain chemical substances, so
™ Display briefly shows BASS, MID, or HIGH and the
they should be disposed of properly.
level.
Using AC Mains
1 Check if the mains supply, as shown on the type
plate located on the bottom of the set,
corresponds to your local mains supply. If it does
not, consult your dealer or service centre.
2 If your set is equipped with a voltage selector,
adjust the selector so that it matches with the
local mains.
Downloaded From Disc-Player.com Philips Manuals
3 Connect the mains lead to the wall socket.
4 To disconnect the mains supply, unplug the set
Note: To prevent sound interference the bass control
options operate exclusively. You cannot
combine the bass from BASS with DBB.
BAS
Mute
1 Press
soun
™ Pla
dis
2 To re
– pre
– adj
– cha
DIGITA
Tuning
1 Press
selec
–
sta
ap
2 Press
your
3 Press
displ
™ Th
su
du
™ If
sh
4 Repe
desir
• To tu
and r
recep
To impr
• For F
aeria
• For M
this a
NS
d of
e
ally
e
BASIC FUNCTIONS
Mute
1 Press MUTE on the remote control to interrupt
sound reproduction instantly.
™ Playback continues without sound and the
display flashes
.
2 To reactivate sound reproduction you can:
– press MUTE again;
– adjust the volume controls;
– change source.
DIGITAL TUNER
UNER
the
l of
er
s
and
il
Tuning to radio stations
1 Press STANDBY y to on, then press SOURCE to
select TUNER.
–
is displayed briefly and then the radio
station frequency, waveband and, if programmed,
a preset number are shown.
2 Press BAND/ DISPLAY once or more to select
your waveband.
3 Press and hold ∞ or § until the frequency in the
display starts running.
™ The radio automatically tunes to a station of
sufficient reception. Display shows
during automatic tuning.
™ If a FM station is received in stereo,
is
shown.
4 Repeat steps 2-3 if necessary until you find the
desired station.
• To tune to a weak station, press ∞ or § briefly
and repeatedly until you have found optimal
reception.
the
rol
To improve radio reception:
• For FM, extend, incline and turn the telescopic
aerial. Reduce its length if the signal is too strong.
• For MW (LW), the set uses a built-in aerial. Direct
this aerial by turning the whole set.
DIGITAL TUNER
Programming radio stations
You can store up to a total of 30 radio stations in the
memory, manually or automatically (Autostore).
Manual programming
1 Tune to your desired station (see Tuning to radio
stations).
2 Press PROG to activate programming.
3 Press PRESET DOWN/ UP once or more to select
a preset number.
4 Press PROG to confirm.
5 Repeat steps 1-4 to store other stations.
Note: You can erase a preset station by storing
another frequency in its place.
Autostore
Autostore automatically starts programming radio
stations from preset 1. Available stations are
programmed in order of waveband reception strength:
FM, followed by MW (LW). Any previous presets e.g.
manually programmed will be erased.
• Press PROG for 4 seconds or more to activate
autostore programming.
™ The display shows
.
After all stations are stored, the first autostore preset
station will then automatically play.
To listen to a preset or autostore station
Press the PRESET (up or down) buttons once or more
until the desired preset station is displayed.
Fr
PAN
(Voi
1S
T
2S
(S
à
3B
p
f
4P
C
T
5C
∞
M
T
2
le
9
6T
7R
à
8V
9M
le
0P
M
T
!B
M
Downloaded From Disc-Player.com Philips Manuals
