Instrukcja_Samsung_SPC

Contents

Table of Contents

…………………………………………………………… 2

Safety caution

………………………………………………………………… 3

Main Features and Characteristics

…………………………………… 5

1. Introduction

… ……………………………………………………………………………… …5…

2. Characteristics

……………………………………………………………………………… …5

Controller Button Layout

Package Contents

System Diagram

………………………………………………… 6

…………………………………………………………… 6

……………………………………………………………… 6

1. Wiring Diagram

… ………………………………………………………………………………7…

2. Connecting RS-485/422 Signal Wires

………………………………………………………7

Names and Functions

……………………………………………………… 8

Controlling PTZ Camera

…………………………………………………… 9

1. Power

………………………………………………………………………………………… …9…

2. Initial Screen Display

……………………………………………………………………… …9…

3. Camera ID Setup

…………………………………………………………………………… …9…

4. Pan / Tilt / Zoom Using Joystick

………………………………………………………… …10…

5. Iris / Focus / Zoom Buttons

……………………………………………………………… …11…

6. Preset

………………………………………………………………………………………… …11…

7. Swing

………………………………………………………………………………………… …12…

8. Group

… ……………………………………………………………………………………… …12…

9. A/F

……………………………………………………………………………………………… …12…

10. OSD

… ……………………………………………………………………………………… …13…

11. Lock

………………………………………………………………………………………… …13…

12. AUX

…………………………………………………………………………………………… …13

Setting Up Controller Environment

…………………………………… 14

1. PTZ Setup

…………………………………………………………………………………… …14…

2. Controller Main Setup

… ………………………………………………………………… …15…

3. Joystick Calibration

… …………………………………………………………………… …18

Troubleshooting

……………………………………………………………… 19

Design

…………………………………………………………………………… 19

Product Specifications

…………………………………………………… 20

PTZ CONTROLLER

2

User Guide

Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents

Samsung Techwin ’s will to create environment-friendly products, and indicates that the product satisfies the EU RoHS Directive.

Safety caution

Warning

• All work related to the installation of this appliance must be performed by qualified service personnel or system installers.

- If the product is connected or installed improperly, electric shock, fire, severe injury, and/or damage can result.

• Please install the product on a completely flat floor.

- Always check the strength and stability of the installation location.

- Do not drop the appliance on the floor. This may result in damage or injury.

Do not attempt to disassemble the appliance. To prevent electric shock, do not remove screws or covers.

- There are no user-serviceable parts inside. Contact qualified service personnel for maintenance.

• Never use the appliance in places where there are flammable materials.

- Never use the appliance in places where flammable materials such as gas are used.

• This may result in fire, explosion, and other serious accidents.

• Never touch un-insulated parts with wet hands.

- Touching un-insulated parts with wet hands may result in serious electric shock.

• Never expose the appliance to water or moisture.

- If the appliance gets wet, immediately turn the power off.

- Stop using the appliance if it gets wet. Contact the manufacturer immediately.

• Stop using the appliance if there appears to be any operational problem.

- Immediately turn the power off to the appliance if there is any abnormal condition such as smoke or unusual smells.

- Continuing to use the appliance under abnormal conditions may result in serious damage.

• Always use the recommended power.

- Using incorrect power source ratings may result in fire, electric shock, or damage.

• Always handle the connection cable with care.

- Never damage or modify the connection cable.

- Do not pull, expose to heat, or place heavy objects on the connection cable.

- Non-observance of these warnings may result in fire, electric shock or damage.

PTZ CONTROLLER

3

User Guide

Safety caution

Caution

• Use the appliance indoors only.

- Do not place the appliance outdoors or expose it to rain or moisture.

- If dropped in water, the appliance may be corroded and damaged.

• Do not use the appliance where there is excessive dust, smoke, or moisture.

- Using the appliance under such conditions may result in fire, electric shock or serious damage.

• Do not operate the appliance in temperatures beyond those specified.

- Excessive heat or cold may damage the appliance.

- Always operate the appliance within the recommended temperature range of 0

ºC

~ 40

ºC

.

• Do not place the appliance in direct sunlight.

- This may discolor the appliance.

• Do not apply excessive shock to the appliance.

- Excessive shock may damage the appliance.

Maintenance and Repair

If the controller body gets dirty, turn the power off and wipe the surface with a soft cloth.

- Do not use chemical agents such as alcohol or benzene. For detailed information on upgrading the firmware, please direct your inquiries to the installation vendor.

Refer all work related to the installation of this appliance to qualified service personnel or system installers.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercialenvironment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

PTZ CONTROLLER

4

User Guide

Main Features and Characteristics

1. Introduction

The SPC-1010 PTZ Controller controls the operation of the PTZ Dome and Zoom Camera series and the SRX-100B Receiver.

• Supported Protocols: SAMSUNG-T, SAMSUNG-E, PELCO-D, PELCO-P, Panasonic, Vicon, AD, and

Honeywell.

2. Characteristics

- Controls up to 255 cameras.

- Supports different protocols per channel.

- Supports serial communications for RS-485/422.

- Supports Pan / Tilt / Zoom operations using a 3-axis joystick.

- Supports Zoom / Focus / Iris operations using the controller buttons.

- Supports various camera options: Preset, Swing, Group, etc.

- Supports 9V Battery.

PTZ CONTROLLER

5

User Guide

Controller Button Layout

1. Wiring Diagram

System Diagram

Tx1+ Tx1Tx2+ Tx2Tx3+ Tx3TRx+ TRx-

RS-485/422 Signal Wire

Package Contents

Power Adapter (DC 12V) Terminal Block

SPC-1010

User’s Manual

PTZ CONTROLLER

6

User Guide

2. Connecting RS-485/422 Signal Wires

· RS485 Communications

Camera

RXD+

RXD-

· RS485 Communications

Camera

RXD+

RXD-

TXD+

TXD-

Controller

Tx1+

Tx1-

Controller

Tx1+

Tx1-

TRx+

TRx-

• You may use the Tx2 or Tx3 terminal instead of Tx1.

PTZ CONTROLLER

7

User Guide

Names and Functions

① ② ⑤

Controlling PTZ Camera

1. Power

To turn on the power, press the PWR button.

To turn off the power, hold down the PWR button.

2. Initial Screen Display

ID : Indicates the current channel number.

SAMSUNG-T : Indicates the current channel camera protocol.

9.6k : Indicates the current channel camera baud-rate.

SAMSUNG-T

③ ④ ⑥

① ESC / POWER Cancels a command or turns power on/off.

LCD DISPLAY 16 X 2 LCD

③ Number Pad Enables changing channels or opening and closing the camera OSD.

1. LOCK

2. FN

3. AUX

4. SET

5. OPEN

6. CLOSE

1. P-SET

2. SWING

3. GROUP

4. A/F

5. OSD

1. FOCUS -/+

2. ZOOM W/T

Locks out the system.

Function keys: Perform special functions in combination with other buttons.

Controls the camera’s AUX output.

Enters the controller settings menu.

IRIS OPEN

IRIS CLOSE

Sets up and moves to preset locations.

Commands the camera to move between 2 selected locations while panning or tilting.

Commands the camera to monitor preset locations at a selected speed and standby time in an orderly manner.

Performs the One-Shot AF function.

Indicates the camera’s OSD menu.

Manually focuses the camera.

Zooms the camera in or out.

PTZ CONTROLLER

8

User Guide

3. Camera ID Setup

Using the number pad, enter a number.

Press the ENT button to confirm the Camera ID.

• Camera IDs are between 1 to 255.

PTZ CONTROLLER

9

User Guide

Controlling PTZ Camera

4. Pan / Tilt / Zoom Using Joystick

■ You can use the joystick to control the camera's Pan and Tilt operations.

■ The farther you move the joystick from the center, the faster the camera moves.

■ You can also use the joystick to control the camera’s Zoom operation.

[ Zoom Wide Action ]

PTZ CONTROLLER

10

User Guide

[ Zoom Tele Action ]

Controlling PTZ Camera

5. Iris / Focus / Zoom Buttons

Screen Brightness

■ To adjust the camera's screen brightness, use the OPEN and CLOSE buttons.

- OPEN : Brighter (Iris Open)

- CLOSE : Darker (Iris Close)

Camera Focus

■ To adjust the focus of the camera, use the FOCUS - / + button.

- FOCUS - : Closer

- FOCUS + : Farther

Camera Zoom

■ To control the camera’s Zoom operation, use the ZOOM W / T button.

- ZOOM W : Zoom Wide

- ZOOM T : Zoom Tele

6. Preset

6-1. Setting Up Preset Location

Using the joystick and controller buttons, move the camera to a desired location.

Enter a preset number.

Hold down the P-SET button for 2 seconds to save the preset location.

6-2. Moving to Preset Location

Enter the number of a preset location.

Press the P-SET button to move the camera to the preset location.

Notes

• You can select preset numbers from 1 to 255 using the controller. The maximum preset location number varies depending on the camera model. (For more information, please refer to your camera’s user manual.)

• You can set up preset locations in the OSD menu of the camera.

PTZ CONTROLLER

11

User Guide

Controlling PTZ Camera

7. SWING

■ The Swing function commands the camera to move between 2 selected locations, monitoring the route.

Press the SWING button.

Press Number 1 or 2 to activate the Swing mode.

- Number 1 : Commands the camera to pan while moving between 2 locations.

- Number 2 : Commands the camera to tilt while moving between 2 locations.

• To pause Swing, move the joystick.

8. Group

■ The Group command recalls a ground of multiple preset locations in sequence.

Enter the group number.

Press the GROUP button to activate the Group mode.

• To pause the Group mode, move the joystick.

Notes

• In order to use Swing and Group modes, you must set up the modes in the camera’s OSD menu prior to actual operation.

• The Swing and Group modes only support the Samsung Techwin SAMSUNG-T protocol.

9. A/F

■ Pressing the A/F button uses One-Shot AF.

PTZ CONTROLLER

12

User Guide

Controlling PTZ Camera

10. OSD

■ Shows the camera’s OSD menu on the monitor screen.

To enter the OSD menu, press the OSD button. To exit the menu, hold down the OSD button. (SAMSUNG-T Protocol)

ENT Button : Performs the Enter function in the OSD menu.

CLR Button : Performs the Esc function in the OSD menu.

To move the menu cursor upward, downward, leftward, or rightward, use the joystick. Certain protocols (SAMSUNG-E,

Panasonic, etc.) do not support using the joystick to move the menu cursor. Instead, they require pressing a number button while holding down the FN button. (Number 2, 4, 6, 8

Buttons)

11. Lock

■ Locks out the controller.

To lock out, hold down the LOCK button.

To unlock, enter the 4-digit password. (Default Password: 0000)

12. AUX

■ Controls the camera’s Aux output operation.

AUX ON : Press the AUX button to turn AUX on.

AUX OFF : Hold down the AUX button for 2 seconds to turn AUX off.

PTZ CONTROLLER

13

User Guide

Setting Up Controller Environment

1. PTZ Setup

Press 1 on the number pad.

Hold down the SET button to enter the PTZ SETUP mode.

Enter the 4-digit password. (Default Password: 0000)

To change a channel address, select a channel by moving the joystick to the right or left. Or you can enter the channel number and then press the ENT button.

Change the Protocol, Baud Rate, and Parity Bit settings of the select channel.

Select the SAVE menu to save the changes. You can continue changing the settings by selecting different channels. To exit to the initial screen, select the EXIT menu or press the ESC button.

• To move between the options, move the joystick up or down.

• To change the value of the settings, move the joystick to the right or left.

• For the default settings values, please refer to the picture on the right.

Protocol : Samsung Techwin SAMSUNG-T

Baud Rate : 9.6Kbps, Parity Bit : None

SAMSUNG-T

Notes

• After changing the settings of a channel, you must select the Save menu. If you move to a different channel without using the SAVE menu, the changes will not be saved.

• Under Controller Serial Setup, Data Bit is fixed to 8 and Stop Bit to 1. Serial values of the controller and camera must match each other.

PTZ CONTROLLER

14

User Guide

Setting Up Controller Environment

2. Controller Main Setup

Press 2 on the number pad.

Hold down the SET button to enter the controller’s

MAIN SETUP mode.

Enter the 4-digit password. (Default Password: 0000)

After changing the settings, select <YES> in the

SAVE/EXIT menu to save the changes and move back to the initial screen. To cancel changes and move back to the initial screen, select <NO> in the Save menu or press the ESC button.

• To move between the options, move the joystick up or down.

• To change the value of the settings, move the joystick to the right or left.

• For the default settings values, please refer to the picture on the right.

2-1. Firmware Version

■ Displays the current version of the controller firmware.

2-2. Serial Data Transfer Standard

■ Select RS-485 or RS-422.

2-3. LCD Backlight

■ AUTO : Turns the backlight off automatically if no command has been entered in the last 30 seconds.

■ ON : Keeps the backlight on at all times.

■ OFF : Keeps the backlight off at all times.

PTZ CONTROLLER

15

User Guide

Setting Up Controller Environment

2-4. Sleep

■ If no joystick or button input is detected for a set duration, the LCD screen turns itself off and enters

Sleep mode.

2-5. Buzzer

■ Turns the sound of controller buttons on or off.

2-6. Terminate

■ To prevent the attenuation of communication signals between the camera and controller, the controller’s termination option must be ON if it is located farthest from the camera and controller communication loop. If the controller is in the middle of the camera and controller communication loop, turn the termination option off.

2-7. Joystick’s Serial Command Transfer Cycle

■ Select a PTZ serial command transfer cycle for using the joystick. Shortening the transfer cycle increases the response speed of the camera.

Notes

• Shortening the joystick's serial command transfer cycle may cause certain camera models to not process commands properly. To prevent and resolve such malfunctions, extend the transfer cycle.

PTZ CONTROLLER

16

User Guide

Setting Up Controller Environment

2-8. Password

■ Enables changing the controller password.

2-9. Factory Set

■ Resets the controller’s current settings to the factory release default values and optimizes the joystick calibration.

PTZ CONTROLLER

17

User Guide

Setting Up Controller Environment

3. Joystick Calibration

Press 3 on the number pad.

Hold down the SET button to enter the Joystick Calibration mode.

At each option, move the joystick as far as you can, and then press the ENT button to calibrate.

Joystick in the Center

Move to the far left side

Move to the far right side

Move to the far upper side

Move to the far lower side

Rotate to the Wide direction as far as possible

Rotate to the Tele direction as far as possible

Select <YES> to save the changes and move back to the initial screen. Select <NO> or press the ESC button to cancel changes and move back to the initial screen.

PTZ CONTROLLER

18

User Guide

Troubleshooting

If the power is not turned on

▶ Please check if the controller is connected to the power adapter.

If the joystick does not move, or the controller buttons are not pressed

There may be a problem with the controller board. Please contact your nearest dealer for further assistance.

If the controller cannot control the camera

Please check the network cable between the controller and camera.

Please check if you have selected the correct ID for the camera on the controller.

Please check the protocol and serial settings of the controller and camera.

Design

280

PTZ CONTROLLER

19

User Guide

180

Product Specifications

LCD Display

Product

Speed Control

PTZ Dome

Compatible

Hardware

Zoom

Camera

Receiver

Control Capacity

Standards

Communications

Transfer

Speed

Voltage

Operating Temperature

Operating Humidity

Dimensions

Weight

SPC-1010

16 x 2 Character LCD

Joystick (3-axis Twist Zoom)

Samsung Techwin PTZ Dome

SAMSUNG-T, SAMSUNG-E, PELCO-D/P, Panasonic, Vicon, AD,

Honeywell

SCZ-3430/2430/3370/2370/3250

SDZ-375/370

SRX-100B

Up to 255 Cameras (Suitable for Mid-, Large-size System)

RS-485 / RS-422 (Remote Control: 1km Distance)

2,400 ~ 57,600bps

12V DC, 140mA

0℃~ 45℃

10 ~ 70%

280(W) x 180(H) x 100(D)mm

Approx. 0.7Kg (Without Adapter)

PTZ CONTROLLER

20

User Guide

MEMO

PTZ CONTROLLER

21

User Guide

MEMO MEMO

PTZ CONTROLLER

22

User Guide PTZ CONTROLLER

23

User Guide

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
