35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Qxx30xHx & Qxx35xx & Qxx35xHx Series
RoHS ®
Description
30 Amp / 35 Amp bi-directional solid state switch series is
designed for AC switching and phase control applications
such as motor speed and temperature modulation controls,
lighting controls, and static switching relays.
Standard type devices normally operate in Quadrants I & III
triggered from AC line.
Alternistor type devices only operate in quadrants I, II, & III
and are used in circuits requiring high dv/dt capability.
Features & Benefits
• RoHS Compliant
Agency Approval
Agency
• Glass – passivated
junctions
Agency File Number
FASTPAK & L Package: E71639
®
• Electrically isolated
package “FASTPAK” &
“L - Package” are UL
recognized for 2500Vrms
• Voltage capability up to
800V
• Surge capability up to 350A
Main Features
Applications
Symbol
Value
Unit
30 & 35
A
400 to 800
V
50
mA
IT(RMS)
VDRM /VRRM
IGT (Q1)
Excellent for AC switching and phase control applications
such as heating, lighting, and motor speed controls.
Typical applications are AC solid-state switches, industrial
power tools, exercise equipment, white goods and
commercial appliances.
Alternistor Triacs (no snubber required) are used in
applications with extremely inductive loads requiring
highest commutation performance.
Schematic Symbol
MT2
Internally constructed isolated packages are offered for
ease of heat sinking with highest isolation voltage.
G
MT1
Absolute Maximum Ratings —Standard Triac
Symbol
Value
Unit
RMS on-state current (full sine wave)
Qxx35P5
TC = 55°C
35
A
ITSM
Non repetitive surge peak on-state current
(full cycle, TJ initial = 25°C)
f = 50 Hz
t = 20 ms
300
f = 60 Hz
t = 16.7 ms
350
I2t
I2t Value for fusing
tp = 8.3 ms
508
A2s
100
A/μs
IT(RMS)
Parameter
A
Critical rate of rise of on-state current
(IG = 200mA with ≤ 0.1µs rise time)
f = 120 Hz
TJ = 125°C
IGTM
Peak gate trigger current
tp ≤ 10 μs IGT ≤ IGTM
TJ = 125°C
2
A
PG(AV)
Average gate power dissipation
TJ = 125°C
0.5
W
Storage temperature range
-40 to 125
°C
Operating junction temperature range
-25 to 125
°C
di/dt
Tstg
TJ
Note: xx = voltage
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Absolute Maximum Ratings — Alternistor Triac (3 Quadrants)
Symbol
IT(RMS)
Parameter
RMS on-state current (full sine wave)
ITSM
Non repetitive surge peak on-state current
(full cycle, TJ initial = 25°C)
I2t
I2t Value for fusing
Value
Unit
Qxx35RH5/Qxx35NH5
TC = 90°C
35
Qxx30LH5/Qxx30LH3
TC = 50°C
30
f = 50 Hz
t = 20 ms
290
f = 60 Hz
t = 16.7 ms
350
tp = 8.3 ms
508
A2s
A
A
di/dt
Critical rate of rise of on-state current
(IG = 200mA with ≤ 0.1µs rise time)
f = 120 Hz
TJ = 125°C
100
A/μs
IGTM
Peak gate trigger current
tp ≤ 10 μs IGT ≤ IGTM
TJ = 125°C
2
A
PG(AV)
Average gate power dissipation
TJ = 125°C
0.5
W
Storage temperature range
-40 to 150
°C
Operating junction temperature range
-25 to 125
°C
Tstg
TJ
Electrical Characteristics (TJ = 25°C, unless otherwise specified) —Standard Triac
Symbol
IGT
Test Conditions
Quadrant
VGD
VD = VDRM RL = 3.3 kΩ TJ = 110°C
IH
IT = 400mA
Unit
I – II – III
MAX.
50
IV
TYP.
120
I – II – III
MAX.
2.75
V
ALL
MIN.
0.2
V
50
mA
VD = 12V RL = 30 Ω
VGT
Qxx35P5
MAX.
600V
mA
475
dv/dt
VD = VDRM Gate Open TJ = 125°C
MIN.
(dv/dt)c
(di/dt)c = 18.9 A/ms TJ = 125°C
TYP.
5
V/µs
tgt
IG = 2 x IGT PW = 15µs IT = 49.5A(pk)
TYP.
3
µs
800V
V/μs
400
Electrical Characteristics (TJ = 25°C, unless otherwise specified) — Alternistor Triac (3 Quadrants)
Symbol
IGT
VGT
Test Conditions
VD = 12V RL = 30 Ω
VGD
VD = VDRM RL = 3.3 kΩ TJ = 125°C
IH
IT = 400mA
dv/dt
VD = VDRM Gate Open TJ = 125°C
(dv/dt)c
(di/dt)c = 18.9 A/ms TJ = 125°C
tgt
35A device
IG = 2 x IGT PW = 15µs IT = 49.5A(pk)
30A device
IG = 2 x IGT PW = 15µs IT = 42.4A(pk)
Note: xx = voltage
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Quadrant
Qxx35RH5
Qxx35NH5
Qxx30LH5
Qxx30LH3
Unit
I – II – III
MAX.
50
25
mA
I – II – III
MAX.
2
2
V
I – II – III
MIN.
0.2
0.2
V
MAX.
75
40
mA
475
350
400
250
MIN.
20
10
V/µs
TYP.
3
3
µs
400V
600V
MIN.
V/μs
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Static Characteristics
Symbol
Test Conditions
Value
35A device ITM = 49.5A tp = 380 µs
VTM
MAX.
30A device ITM = 42.4A tp = 380 µs
Qxx35P5
IDRM
IRRM
VD = VDRM / VRRM
Qxx35R/NH5
Qxx30LH5
Qxx30LH3
TJ = 25°C
600 - 800V
TJ = 125°C
600 - 800V
TJ = 25°C
400 - 600V
TJ = 125°C
400 - 600V
MAX.
MAX.
Unit
1.5
V
1.4
100
μA
5
mA
10
μA
2
mA
Thermal Resistances
Symbol
Parameter
Junction to case (AC)
Rθ(J-C)
Junction to ambient
Rθ(J-A)
Value
Qxx35P5
1.50
Qxx35RH5 / Qxx35NH5
0.85
Qxx30LH5 / Qxx30LH3
2.30
Qxx35RH5
45
Qxx30LH5 / Qxx30LH3
50
Unit
°C/W
°C/W
Note: xx = voltage
Figure 2: Normalized DC Gate Trigger Current for
All Quadrants vs. Junction Temperature
Figure 1: Definition of Quadrants
ALL POLARITIES ARE REFERENCED TO MT1
(-)
+
I GT
GATE
(+)
MT1
REF
I GT
GATE
(+)
MT1
REF
REF
QII QI
QIII QIV
MT2
(-)
MT2
I GT
GATE
MT1
I GT
4.0
-
+ IGT
MT2
Ratio of IGT/IGT (TJ = 25°C)
MT2
MT2 POSITIVE
(Positive Half Cycle)
3.0
2.0
1.0
I GT
GATE
MT2 NEGATIVE
(Negative Half Cycle)
MT1
REF
0.0
-40
-15
10
35
60
85
110
+125
Junction Temperature - °C
NOTE: Alternistors will not operate in QIV
Note: Alternistors will not operate in QIV
Additional Information
Datasheet
Resources
Samples
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Figure 3: Normalized DC Holding Current
vs. Junction Temperature
Figure 4: Normalized DC Gate Trigger Voltage for
All Quadrants vs. Junction Temperature
2.0
3.0
Ratio of VGT/VGT(Tj=25°C)
Ratio of IIH/IIH (Tj=25°C)
4.0
2.0
1.0
0.0
-40
-15
10
35
60
85
110
+ 125
1.5
1.0
0.5
0.0
-40
-15
10
Junction Temperature - °C
Figure 5: Power Dissipation (Typical)
vs. RMS On-State Current
85
110
+125
130
40
120
Max Allowable Case Temperature
(TC) - °C
Average On-State Power Dissipation
[PD (AV)] - Watts
60
Figure 6: M
aximum Allowable Case Temperature
vs. On-State Current
45
35
110
30
Qxx35RH5
Qxx35NH5
100
25
20
15
10
5
90
Qxx35P5
80
0
4
8
12
16
20
24
28
32
36
40
60
Note: xx = voltage
Figure 7: On-State Current vs. On-State Voltage
(Typical)
90
80
70
TC = 25°C
60
50
40
30
20
10
0
0.8
1.0
1.2
1.4
1.6
Positive or Negative Instantaneous On-State Voltage
(VT) - Volts
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
0
5
10
15
20
25
30
RMS On-State Current [IT(RMS)] - AMPS
RMS On-State Current [IT(RMS)] - AMPS
0.6
Qxx30LH5
Qxx30LH3
70
50
0
Positive or Negative Instantaneous
On-State Current (IT) - AMPS
35
Junction Temperature - °C
1.8
35
40
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Figure 8: Surge Peak On-State Current vs. Number of Cycles
Peak Surge (Non-repetitive) On-State Current
(ITSM) – Amps
1000
Supply Frequency: 60Hz Sinusoidal
Load: Resistive
RMS On-State [IT(RMS)]: Max Rated Value at
Specific Case Temperature
Qxx35RH5
Qxx35NH5
Qxx35P5
100
Notes:
1) G
ate control may be lost during and
immediately following surge current interval.
2) Overload may not be repeated until junction
temperature has returned to steady-state
rated value.
Qxx30LH5
Qxx30LH3
10
1
1
10
100
1000
Surge Current Duration – Full Cycles
Note: xx = voltage
Soldering Parameters
Pre Heat
Pb – Free assembly
- Temperature Min (Ts(min))
150°C
- Temperature Max (Ts(max))
200°C
- Time (min to max) (ts)
60 – 180 secs
Average ramp up rate (Liquidus Temp)
(TL) to peak
5°C/second max
TS(max) to TL - Ramp-up Rate
5°C/second max
Reflow
- Temperature (TL) (Liquidus)
217°C
- Time (min to max) (ts)
60 – 150 seconds
260
Time within 5°C of actual peak
Temperature (tp)
20 – 40 seconds
Ramp-up
TL
tL
TS(max)
Preheat
TS(min)
25
Peak Temperature (TP)
+0/-5
tP
TP
Temperature
Reflow Condition
Ramp-do
Ramp-down
tS
time to peak temperature
Time
°C
Ramp-down Rate
5°C/second max
Time 25°C to peak Temperature (TP)
8 minutes Max.
Do not exceed
280°C
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Physical Specifications
Environmental Specifications
Test
Terminal Finish
100% Matte Tin-plated.
Body Material
UL recognized epoxy meeting flammability
classification 94V-0.
Terminal Material
Copper Alloy
Specifications and Conditions
AC Blocking
Temperature Cycling
Temperature/
Humidity
Design Considerations
High Temp Storage
Careful selection of the correct device for the application’s
operating parameters and environment will go a long way
toward extending the operating life of the Thyristor. Good
design practice should limit the maximum continuous
current through the main terminals to 75% of the device
rating. Other ways to ensure long life for a power discrete
semiconductor are proper heat sinking and selection of
voltage ratings for worst case conditions. Overheating,
overvoltage (including dv/dt), and surge currents are
the main killers of semiconductors. Correct mounting,
soldering, and forming of the leads also help protect
against component damage.
Low-Temp Storage
MIL-STD-750, M-1040, Cond A Applied
Peak AC voltage @ 125°C for 1008 hours
MIL-STD-750, M-1051,
100 cycles; -40°C to +150°C; 15-min
dwell-time
EIA / JEDEC, JESD22-A101
1008 hours; 320V - DC: 85°C; 85%
rel humidity
MIL-STD-750, M-1031,
1008 hours; 150°C
1008 hours; -40°C
MIL-STD-750, M-1056
10 cycles; 0°C to 100°C; 5-min dwelltime at each temperature; 10 sec (max)
transfer time between temperature
EIA / JEDEC, JESD22-A102
168 hours (121°C at 2 ATMs) and
100% R/H
Thermal Shock
Autoclave
Resistance to
Solder Heat
MIL-STD-750 Method 2031
Solderability
ANSI/J-STD-002, category 3, Test A
Lead Bend
MIL-STD-750, M-2036 Cond E
Dimensions — TO-220AB (R-Package) — Non-Isolated Mounting Tab Common with Center Lead
AREA (REF.) 0.17 in2
TC MEASURING POINT
O
A
E
8.13
.320
P
MT2
A
B
C
13.36
.526
D
7.01
.276
NOTCH IN
GATE LEAD
TO ID.
NON-ISOLATED
TAB
F
R
G
L
H
K
N
J
Dimension
M
MT1 MT2 GATE
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Note: Maximum torque to
be applied to mounting tab
is 8 in-lbs. (0.904 Nm).
Inches
Millimeters
Min
Max
Min
Max
0.380
0.420
9.65
10.67
B
0.105
0.115
2.67
2.92
C
0.230
0.250
5.84
6.35
D
0.590
0.620
14.99
15.75
E
0.142
0.147
3.61
3.73
F
0.110
0.130
2.79
3.30
G
0.540
0.575
13.72
14.61
H
0.025
0.035
0.64
0.89
J
0.195
0.205
4.95
5.21
K
0.095
0.105
2.41
2.67
L
0.060
0.075
1.52
1.91
M
0.085
0.095
2.16
2.41
N
0.018
0.024
0.46
0.61
O
0.178
0.188
4.52
4.78
P
0.045
0.060
1.14
1.52
R
0.038
0.048
0.97
1.22
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Dimensions — TO-220AB (L-Package) — Isolated Mounting Tab
AREA (REF.) 0.17 in2
TC MEASURING POINT
O
A
E
Dimension
8.13
.320
P
B
C
13.36
.526
D
7.01
.276
F
R
G
L
H
K
Note: Maximum torque to
be applied to mounting tab
is 8 in-lbs. (0.904 Nm).
N
J
M
MT1 MT2 GATE
Inches
Millimeters
Min
Max
Min
Max
A
0.380
0.420
9.65
10.67
B
0.105
0.115
2.67
2.92
C
0.230
0.250
5.84
6.35
D
0.590
0.620
14.99
15.75
E
0.142
0.147
3.61
3.73
F
0.110
0.130
2.79
3.30
G
0.540
0.575
13.72
14.61
H
0.025
0.035
0.64
0.89
J
0.195
0.205
4.95
5.21
K
0.095
0.105
2.41
2.67
L
0.060
0.075
1.52
1.91
M
0.085
0.095
2.16
2.41
N
0.018
0.024
0.46
0.61
O
0.178
0.188
4.52
4.78
P
0.045
0.060
1.14
1.52
R
0.038
0.048
0.97
1.22
Dimensions — TO-263 (N-Package) — D2 Pak Surface Mount
TC MEASURING POINT
B
AREA: 0.11 IN2
C
V
7.01
.276
A
S
W
U
G
H
D
F
11.68
.460
2.16
.085
7.01
.276
7.01
.276
16.89
.665
8.89
.350
1.40
.055
3.81
.150
J
K
GATE
MT1
Dimension
E
MT2
8.13
.320
8.41
.331
Inches
Millimeters
Min
Max
Min
Max
A
0.360
0.370
9.14
9.40
B
0.380
0.420
9.65
10.67
C
0.178
0.188
4.52
4.78
D
0.025
0.035
0.64
0.89
E
0.045
0.060
1.14
1.52
F
0.060
0.075
1.52
1.91
G
0.095
0.105
2.41
2.67
H
0.092
0.102
2.34
2.59
J
0.018
0.024
0.46
0.61
K
0.090
0.110
2.29
2.79
S
0.590
0.625
14.99
15.88
V
0.035
0.045
0.89
1.14
U
0.002
0.010
0.05
0.25
W
0.040
0.070
1.016
1.78
2.03
.080
6.60
.260
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Dimensions — TO-3 Fastpak (P Package) — Isolated Mounting Tab
A
Dimension
B
D
MT2
H
F
MT1
Gate
ΦG
E
TC Measuring Point
C
Φ J (MT1, MT2)
M L
Millimeters
Max
Min
Max
A
1.531
1.543
38.90
39.20
B
1.177
1.185
29.90
30.10
C
0.843
0.850
21.40
21.60
D
0.780
0.795
19.80
20.20
E
0.783
0.791
19.90
20.10
F
0.874
0.906
22.20
23.00
G
0.161
0.169
4.10
4.30
H
0.386
0.465
9.80
11.80
I
0.508
0.587
12.90
14.90
I
J
0.079
0.087
2.00
2.20
T
K
0.047
0.055
1.20
1.40
U
L
0.307
0.319
7.80
8.10
10.05
V
W
5-ΦN
Inches
Min
M
0.372
0.396
9.45
R
N
0.043
0.059
1.10
1.50
Φ K (Gate)
O
0.315
0.331
8.00
8.40
P
0.098
0.106
2.50
2.70
Q
0.846
0.886
21.50
22.50
R
0.244
0.256
6.20
6.50
S
0.106
0.130
2.70
3.30
T(MT1)
0.321
0.329
8.15
8.35
S
Q
O
P
Thickness off all three copper-alloy terminals is .032" (0.81 mm).
T(MT2)
0.321
0.329
8.15
8.35
T(Gate)
0.220
0.228
5.60
5.80
U(MT1)
0.246
0.254
6.25
6.45
U(MT1)
0.246
0.254
6.25
6.45
U(Gate)
0.183
0.191
4.65
4.85
V
0.120
0.130
3.05
3.30
W
0.175
0.185
4.45
4.70
Maximum torque to be applied to mounting tab is 8 in-lbs
(0.904 Nm)
Product Selector
Part Number
Voltage
Gate Sensitivity Quadrants
Type
Package
35A
Standard Triac
FASTPACK
35A
Alternistor Triac
TO-220R
50 mA
35A
Alternistor Triac
TO-263 D2-PAK
X
50 mA
30A
Alternistor Triac
TO-220L
X
25 mA
30A
Alternistor Triac
TO-220L
400V
600V
800V
X
X
Qxx35RH5
X
X
50 mA
Qxx35NH5
X
X
Qxx30LH5
X
Qxx30LH3
X
Qxx35P5
Note: xx = Voltage
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
I – II – III
IV
50 mA
120 mA (TYP)
IT(RMS)
Teccor® brand Thyristors
35 Amp Standard & 30 / 35 Amp Alternistor (High Commutation) Triacs
Packing Options
Part Number
Marking
Qxx35P5
Weight
Packing Mode
Base Quantity
Qxx35P5
21.4 g
Bulk
160
Qxx35RH5
2.20 g
Bulk
500
Qxx35RH5TP
Qxx35RH5
2.20 g
Tube
500 (50 per tube)
Qxx35NH5TP
Qxx35NH5
1.60 g
Tube
500 (50 per tube)
Qxx35NH5RP
Qxx35NH5
1.60 g
Embossed Carrier
500
Qxx30LH5
Qxx30LH5
2.20 g
Bulk
500
Qxx30LH5TP
Qxx30LH5
2.20 g
Tube
500 (50 per tube)
Qxx30LH3
Qxx30LH3
2.20 g
Bulk
500
Qxx30LH3TP
Qxx30LH3
2.20 g
Tube
500 (50 per tube)
Qxx35RH5
Note: xx = Voltage
TO-263 Embossed Carrier Reel Pack (RP) Specifications
Meets all EIA-481-2 Standards
0.63
(16.0)
0.157
(4.0)
0.059
DIA
(1.5)
0.945
(24.0)
0.827
(21.0)
Gate
MT1
*
* Cover tape
MT2
0.512 (13.0) Arbor
Hole Dia.
12.99
(330.0)
Dimensions
are in inches
(and millimeters).
1.01
(25.7)
Direction of Feed
Part Numbering System
Part Marking System
Q 60 35 P 5
DEVICE TYPE
Q : Triac or Alternistor Triac
VOLTAGE
40 : 400V
60 : 600V
80 : 800V
CURRENT
30 : 30A
35 : 35A
TO-220 AB - (L and R Package)
TO-263 AB - (N Package)
SENSITIVITY & TYPE
Standard Triac
5 : 50mA (QI, II, III)
Alternistor Triac
H5 : 50mA (QI, II, III)
H3 : 25mA (QI, II, III)
FASTPAK - (P Package)
Q6035P5
Q6030RH5
YM
®
YMXXX
®
PACKAGE TYPE
L : TO-220 Isolated
R : TO-220 Non-Isolated
N : TO-263 (D2-PAK)
P : FASTPAK
Date Code Marking
Y:Year Code
M: Month Code
XXX: Lot Trace Code
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/14/14
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
