Residential Speakers
125 Watt 10" Front Firing
Powered Subwoofer
200 Watt 12" Front Firing
Powered Subwoofer
UI-PSW110
• BlackVinylWrapwithremovablefrontgrill
• Levelandvariable(18dB)CrossoverControlsfrontpanel
mounted
• SignalSensingAuto-OnOptionandPhaseSwitch
(rearpanel)
• DualFrontPorts
• Idealformountingincustomcabinet
• RCA(lowlevel)orspeaker(highlevel)Inputs
• Multivoltageswitchable120/230VAC
UI-PSW112
• BlackVinylWrapwithremovablefrontgrill
• Levelandvariable(18dB)CrossoverControlsfrontpanel
mounted
• SignalSensingAuto-OnOptionandPhaseSwitch
(rearpanel)
• Dualfrontports
• Idealformountingincustomcabinet
• RCA(lowlevel)orSpeaker(highlevel)Inputs
• Multivoltageswitchable120/230VAC
Classic Series Home Speakers
SoundWare In/Outdoor Speakers
7B-CS23(X)
• 2-Way3-1/2”Bookshelf
7B-CS26(X)
• 2-Way6-1/2”Bookshelf
7B-CS225(X)
• Dual5-1/4”2-WayCenterChannel
7B-SUB10(X)
• 100Watt10”Down-firingDCDSubwoofer
7B-CS26(X)
• Dual6-1/2”2-WayFloorstanding
• (X)=BlackWalnut(B),Cherry(C)
TVee Model Two
Voyager Rock Speakers
7B-TVEEM2MDT
• Midnight
7B-TVEEM2MST
• Mist
7B-VOYARK5(X)
7B-VOYARK6T(X)
7B-VOYARK8T(X)
• OutdoorRockSpeaker
• Weatherproof
• Optional70/100Volttransformerforuseincommercial
applications
• Soldasindividuals
• X=NewEnglandGranite(G),RiverRock(R),
andSandstone(S)
Audio/Video
• Clutter-freesetup
• Amplified2-channelspeakersystemwithpowered
wirelesswoofer
• Workswithyourremote-Cable,TV,DVDorUniversal
• Wirelessbassspeaker
• RoHS complaint
Voyager Outdoor Speaker
SoundWare XL
7B-VOYAGER4(X)
7B-VOYAGER5(X)
7B-VOYAGERM(X)
• Indoor/outdoorspeaker
• Easytomount
• Protectedbypowdercoatedaluminumgrille
• UVresistantpolypropylenecabinet
• HeavydutyaluminumC-bracketsincluded
• Soldinpairs
• X=Black(B)orWhite(W)
7B-SNDWAREXL
• Black
7B-SNDWAREXW
• White
Subwoofers
In-Ceiling Speakers
7B-SNDWRESUB
7B-SNDWRESUW
7B-HSI250
• 2-way,5-1/4”woofer
7B-HSI270
• 2-way,6-1/2”woofer
7B-HSI460
• 2-way,6”wooferwith3/4”pivotingKortectweeter
7B-HSI470
• 2-way,6-1/2”wooferwith1”pivotingKortectweeter
7B-HSI460T2
• 6”wooferwithdual3/4”tweeter
• HighPerformancePoweredSubwooferForgreatbass
upanddown
• FlexibleDesign.Uniquecabinetletsyoufacethewoofer
tofiredownatthefloororouttoyourlisteningarea.
Also,youcanpositionthecabinettightinacornerorflat
againstawall.
• 100-wattSubwooferAmplifierwithBassTrac®Circuitry
Fordeep,powerfulbasswithoutdistortion
• Blend-inorstandout.Paint-readysurfaceletsyou
customizeyourSoundWareSubtomatchyourdecor
256
7B-SOUNDWARE
• Bamboo
7B-SOUNDWRE(X)
• Versatiledesignfitsonwalls,shelves,floors,&corners
(mountingbracketsincluded)
• RoHSCompliant
• X=Black(B),White(W),Silver(S),Natural(N),
Red(R),Espresso(E)
• 70/100voltinternaltransformer
• Indoor/Outdoorspeaker
• Sitsofmountatanyangle
• 6-1/2”driver
In-Wall Speakers
Surround Loudspeakers
7B-HSI255
• 2-way5-1/4”LCRwith3/4”tweeter
7B-HSI275
• 2-way6-1/2”LCRwith3/4”tweeter
7B-HSI455
• 2-way5-1/4”LCRwith1”Kortectweeter
7B-HSI475
• 2-way6-1/2”LCRwith1”Kortectweeter
7B-HSI475T2
• 2-way6-1/2”SingleStereowithdual1”Kortectweeter
7B-HSI455W2
• 2-waydual5-1/4”LCRwith1”Kortectweeter
JB-HKS6
• 2-waysatellitespeakers
• 3"midrange
• 1/2"high-frequencydriver
• Upgradeto7.1speakersystem
• Includeswallmountbrackets,upgradedshelfstands
&cables
• UsewithoptionalJB-HTFS2floorstands
• Black-lacquerfinish
• Soldinpairs
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Speakers
Surround Loudspeakers
6-Pc. Home Theater Speaker System
JB-HKS9
• 2-waysatellitespeakers
• Dual3"midrange
• 3/4"high-frequencydriver
• Upgradeto7.1speakersystem
• Includeswallmountbrackets,upgradedshelfstands
&cables
• UsewithoptionalJB-HTFS2floorstands
• Black-lacquerfinish
• Soldinpairs
JB-HKTS15
• 100-wattbass-reflexpoweredsubwooferwith10"driver
• 4satellitespeakerswith3"midrangeand
1/2"high-frequencydriver
• Voicematcheddual-midrangecenterchannelspeaker
with3/4"dometweeter
• Triggerinputforautoturn-on
• Videoshielded(exceptsubwoofer)
• Black-lacquerfinish
6-Pc. Home Theater Speaker System
Floor Stands
JB-HKTS18
• 200-wattbass-reflexpoweredsubwooferwith10"driver
• 4satellitespeakerswith3"dualmidrangesand
3/4"high-frequencydriver
• Voicematcheddual-midrangecenterchannelspeaker
with3/4"dometweeter
• Triggerinputforautoturn-on
• Videoshielded(exceptsubwoofer)
• Black-lacquerfinish
JB-HTFS2B
• Slimprofile,aluminumextrusioncolumns
• Wiremanagementsystem
• CompatiblewithJB-HKS6,JB-HKS9,JB-HKTS15
andJB-HKTS18satellitespeakers
• Availableinblack-lacquerfinish
Contol 2.4g Wireless Speaker Kit
JBL Control Now
Wall Mount/Corner Mount Speaker
JB-CONTRO24G
• 2.4GHzwirelesstransmitter
• 2-Way,4”(100mm)activespeakerwith15-watt-
per-channelamplifier
• 2-Way,4”(100mm)passivespeaker
• Connectionandwall-mountaccessories
• Remotecontrol
• 50Hz-20kHz
Cinema SoundTM
2-Way Center Channel Speaker
Cinema SoundTM 2-Way Floorstanding
Speaker
Cinema SoundTM 10" Powered Subwoofer
JB-CSS10
• 10",150wattpoweredsubwooferwith300wattpeak
dynamicpower
• PolyPlas™driverdeliverscleaner,morerealisticlow
frequencies
• LFE/Lineinputsformaximumconnectionflexibility
• Adjustablecrossover&phaseswitch
• Soldindividually
Audio/Video
JB-CSC55
• 5"PolyPlas™wooferand3/4"Titanium-laminatetweeter
• MagneticallyshieldedPolyPlas™wooferwith
HeatScape™technology
• ProprietaryEOS™waveguide
• Soldindividually
JB-CNTRLNOW
• Mountsonstands,incorners,andonwallswithsupplied
mountinghardware
• Canbemountedinpairs,inthree,orfourspeakerarrays
• Perfectsolutionforhometheaterasmaincenter,and
surroundchannels
• Dimensions5”x14-5/16”x9-7/8”
• 8ohms
• Sensitivity(2.83V/1M)90db
• Powerhandling150RMSPeakPowerhandling300watts
JBL Cinema Sound 5.1 Speaker Package
JB-CST55
• Dual5"PolyPlas™woofers&3/4"Titanium-laminate
tweeter
• Magneticallyshielded
• PolyPlas™wooferwithHeatScape™technology
• ProprietaryEOS™waveguide
• Soldindividually
JB-CS6100
• Thesystemfeaturesfouridenticalsatellites,amatching
horizontalcenterspeakerandapowerful300-watt
(peak)subwoofer
• Theattractivecontemporarydesignofthesystemand
itsblackhigh-glossfinishwillcomplementanyflatpaneltelevisionanddecorofanyroom.Wallbrackets
areincludedforthesatellitesandcenterchannel.
• Subwoofer18-1/2”x12-3/4”x15”
• Satsandcenterchannel11-3/8”x5-1/8”x3-3/8”
ESTM Series On-Wall/Bookshelf Speaker
ESTM Series Bookshelf Speaker
JB-ES10
• 3-way4"On-Wall/BookshelfSpeaker
• 4"PolyPlas™wooferand3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlas™wooferwithHeatScapetechnology
• ProprietaryEOSwaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldinpairs
JB-ES20
• 3-way5-1/4"BookshelfSpeaker
• 5-1/4"PolyPlas™woofer
• 3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlas™wooferwithHeatscapetechnology
• ProprietaryEOSWaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldinpairs
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
257
Audio/Video
Residential Speakers
ESTM Series Center Channel Speaker
ESTM Series Bookshelf Speaker
JB-ES25C
• 3-waydual5-1/4"CenterChannelSpeaker
• 5-1/4"PolyPlas™woofer
• 3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlas™wooferwithHeatscapetechnology
• ProprietaryEOSWaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldindividually
JB-ES30
• 3-way6-1/2"BookshelfSpeaker
• 6-1/2"PolyPlasTMwoofer
• 3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlas™wooferwithHeatscapetechnology
• ProprietaryEOSWaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldinpairs
ESTM Series Floorstanding Speaker
ESTM Series Floorstanding Speaker
JB-ES80
• 3-waydual6-1/2"FloorstandingSpeaker
• Dual6-1/2"PolyPlas™woofers
• 3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlasTMwooferswithHeatscapetechnology
• ProprietaryEOSWaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldindividually
JB-ES90
• 3-waydual8"FloorstandingSpeaker
• Dual8"PolyPlasTMwoofers
• 3/4"Titanium-laminatetweeter
• 3/4"UHFDriver
• Magneticallyshielded
• PolyPlasTMwooferswithHeatscapetechnology
• ProprietaryEOSWaveguide
• Availableinblackpicaorcherrywoodgrainfinish
• Soldindividually
ESTM Series 10" Powered Subwoofer
ESTM Series 12" Powered Subwoofer
JB-ES150P
• 10",500/300-WattPoweredSub(Peak/RMS)
• PolyPlasTMdriverdeliverscleaner,morerealisticlow
frequencies
• LFE/Lineinputsformaximumconnectionflexibility
• Adjustablecrossover&phaseswitch
• Availableinblackpicaorcherrywoodgrainfinish
• Soldindividually
JB-ES250P
• 12",500/250-WattPoweredSub(Peak/RMS)
• PolyPlasTMdriverdeliverscleaner,morerealisticlow
frequencies
• LFE/Lineinputsformaximumconnectionflexibility
• Adjustablecrossover&phaseswitch
• Availableinblackpicaorcherrywoodgrainfinish
• Soldindividually
3-Way Center Channel Speaker
4-Way Wall-Mountable Center Channel
JB-LC1H
• Dual5-1/4"PolyPlasTMwoofers
• 1"titaniumtweeterand3/4"ultrahigh-frequency
• Extendedhighfrequenciesto40kHz;perfectfornatural
musicandfilmsoundreproduction
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• Availableinblack,beechorcherrywood-grainfinish
withblackgrilles
JB-LC2
• Dual6"PolyPlasTMwoofers,
• 1"titaniumtweeterand3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectfornaturalmusicandfilmsoundreproduction
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• Availableinblack,beechorcherrywood-grainfinish
withblackgrilles
2-Way 6-1/2" In-Ceiling Loudspeaker
2-Way 6-1/2" In-Wall Loudspeaker
JB-L226C
• Low-frequencydriver6-1/2"(165mm)aluminumcone
• High-frequencydriver1"(25mm)Titanium-laminate
• FrequencyResponse30Hz-20kHz(±6dB)
• Recommendedamplifierpowerrange10-125watts
• Sensitivity(2.83V@1m)89dB•Nom.Impedance8ohms
• Crossoverfrequency2,500Hz;24dB/octave
• Dimensions(HxWxD)Diameter:9-3/16"(233mm)
• Mountingdepth4-1/8"(104mm)
• Cut-outdiameter7-7/8"(200mm)
• Weight3.5lb(1.6kg)•Opt.rough-inframe(JB-RIF6CS)
258
JB-L226W
• Low-frequencytransducer6-1/2"(165mm)aluminum
cone
• High-frequencytransducer1"(25mm)Titaium-laminate
• Frequencyresponse30Hz-20kHz(+-6dB)
• Recommendedamplifierpowerrange:10-125watts
• Sensitivity(2.83V@1m):89dB•Nom.impedance:8ohms
• High-frequencylevelcontrol
• Dimensions(HxWxD)8-1/2"x11"(216mmx279mm)
• Mountingdepth3-9/16"(90mm)
• Cutoutdimensions(HxW)7"x9-1/2"(178mmx241mm)
2-Way 8" In-Ceiling Loudspeaker
3-Way 5-1/4" Bookshelf Loudspeaker
JB-L228C
• Low-frequencydriver8"(200mm)aluminumcone
• High-frequencydriver1"(25mm)Titanium-laminate
• Crossoverfrequency2,500Hz;18dB/octave
• Frequencyresponse28Hz-20kHz(±6dB)
• Recommendedamplifierpowerrange10-135watts
• Sensitivity(2.83V@1m)90dB•Nom.Impedance8ohms
• Dimensions:(HxWxD)Diameter:10-7/8"(276mm)
• MountingDepth4-5/8"(104mm)
• Cut-OutDiameter9-1/2"(241mm)
• Weight5.8lb(2.6kg)•Opt.rough-inframe(JB-RIF8C)
JB-L810
• 5-1/4"PolyPlasTMwoofer,1"Pure-Titaniumtweeter
• 3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectforhigh-definitionsources
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• ProprietaryEOSTMwaveguideensuressuperior
highfrequenciesthroughoutthelisteningroom
• Beautifullyfinishedinblack,beechorcherrywood-grain
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Speakers
4-Way Bookshelf Wall-Mount Speaker
3-Way Bookshelf Loudspeaker
JB-L820H
• 6"PolyPlasTMwoofer,4"PolyPlasTMmidrange
• 1"Pure-Titaniumtweeter
• 3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectforhigh-definitionsources
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• Availableinblack,beechorcherrywood-grain
• Soldinpairs
JB-L830(X)
• 6"PolyPlasTMwoofer,1"Pure-Titaniumtweeter
• 3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectforhigh-definitionsources
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• X=Black(B),Beech(BE)orcherry(CH)wood-grain
• Soldinpairs
4-Way Floorstanding Speaker
4-Way Floorstanding Speaker
JB-L880
• Dual6"PolyPlasTMwoofers,1"Pure-Titaniumtweeter
• 4"PolyPlasTMmidrange
• 3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectforhigh-definitionsources
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• Availableinblack,beechorcherrywood-grain
• Soldindividually
JB-L890H
• Dual8"PolyPlasTMwoofer,1"Pure-Titaniumtweeter
• 4"PolyPlasTMmidrange
• 3/4"ultrahigh-frequencydriver
• Extendedhighfrequenciesto40kHz;
perfectforhigh-definitionsources
• Cast-aluminumwooferwithHeatScapeTMtechnology
deliverstight,deepbassandhighpowerhandling
• ProprietaryEOSTMwaveguideensuressuperiorhigh
frequenciesthroughoutthelisteningroom
• Availableinblack,beechorcherrywood-grain
• Soldindividually
12" High-Performance Powered Subwoofer
2-Way 6-1/2" In-Ceiling Loudspeaker
JB-L8400P
• 12",600-WattPoweredSubwooferwith1,200-Watt
peakdynamicpower
• Addbassimpactandexcitementtoallyourfavorite
musicandmoviesoundtracks
• PolyPlasTMdriverdeliverscleaner,morerealisticlow
frequencies
• LFE/Lineandspeakerlevelinputsformaximum
connectionflexibility
• Adjustablecrossoverandphaseswitch
• Soldindividually
JB-LS326C
• Low-frequencydriver6-1/2"(165mm)aluminumcone
• High-frequencydriver1"(25mm)Pure-Titanium
• Frequencyresponse30Hz-30kHz(±6dB)
• Recommendedamplifierpowerrange10-135watts
• Sensitivity(2.83V@1m)89dB•Nom.Impedance8ohms
• CrossoverFrequency2,500Hz;18dB/octave
• Dimensions(HxWxD)Diameter:9-3/16"(233mm)
• Mountingdepth4-1/8"(104mm)
• Cut-outdiameter7-7/8"(200mm)
• Weight3.5lb(1.6kg)•Opt.rough-inframe(JB-RIF6CS)
2-Way 6-1/2" In-Wall Loudspeaker
2-Way 8" In-Ceiling Loudspeaker
JB-LS328C
• Low-frequencydriver8"(200mm)aluminumcone
• High-frequencydriver1"(25mm)Pure-Titanium
• Frequencyresponse28Hz-30kHz(±6dB)
• Recommendedamplifierpowerrange10-150watts
• Sensitivity(2.83V@1m)90dB•Nom.Impedance8ohms
• Crossoverfrequency2,500Hz;18dB/octave
• Dimensions(HxWxD)Diameter:10-7/8"(276mm)
• Mountingdepth4-5/8"(117mm)
• Cut-outdiameter9-1/2"(241mm)
• Weight5.8lb(2.6kg)•Opt.rough-inframe(JB-RIF8C)
3-Way In-Ceiling Home Theater Speaker
6" Weather-Resistant Bookshelf Speaker
JB-LS360C
• Low-FrequencyDriver7-3/4"x3-3/8"
(197mmx85mm)RadiatorPlus™
• MidrangeDriverDual3"(75mm)
• High-FrequencyDriver1"(25mm)Pure-Titanium
• RecommendedAmplifierPowerRange10-200watts
• Sensitivity(2.83V@1m)85dB
• CrossoverFrequency700Hz;2,000Hz;24dB/octave
• Dim:(HxWxD)ExternalDiameter:12-3/4"(323mm)
• MountingDepth:5-5/8"(142mm)
• Cut-OutDiameter:11-3/8"(289mm)
JB-N26AWII
• 2-wayspeaker
• Weather-resistant
• Off-whitefinish
• Soldinpairs
6-Piece Home Cinema System
8-Piece Home Cinema System
JB-SCS1455
• Complete6-piecehomecinemasystem:
*(5)satellites:100watts
*(1)Subwoofer:100wattsRMS
*(1)centerchannel:2-waywithdualwoofers
JB-SCS5005BK
• Complete5.1channelmusic&hometheater
loudspeakersystem:
*(5)satellites:100watts
*(1)subwoofer:150wattsRMS
*(1)centerchannel:2-waywithdualwoofers
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
JB-LS326W
• Low-frequencydriver6-1/2"(165mm)aluminumcone
• High-frequencydriver1"(25mm)Pure-Titanium
• Frequencyresponse30Hz-30kHz(±6dB)
• Recommendedamplifierpowerrange10-135watts
• Sensitivity(2.83V@1m)89dB•Nom.Impedance8ohms
• Crossoverfrequency3,000Hz;24dB/octave
• Dimensions(HxWxD)8-1/2"x11"(216mmx241mm)
MountingDepth3-9/16"(90mm)
CutoutDimensions(HxW)7"x9-1/2"(178mmx241mm)
• Weight•Optionalrough-inframe(JB-RIF6)
259
Residential Speakers
6.5" 2-Way Ceiling Speaker
Audio/Video
JB-SP6CII
• 6.5"wooferdeliversdeep,tightbass
• 80Wpowerhandling,8ohms
• 1"Titanium-laminatetweeterreproduceshigh
frequencieswithextremeclarity
• 8ohm
• Optionalrough-inframeavailable(JB-RIF6CS)
• Soldinpairs
6.5" 2-Channel Dual Tweeter
JB-SP6CSII
• 6.5"Titanium-laminatepolypropylenewoofer
• Dual.75"Titanium-laminateddome,
swivelmountedtweeters
• Longexcursion,lowfrequencydriverdesign
• Rearmountedwoofer
• 100Wpowerhandling(50WPC)
• 8ohmsimpedance
• Optionalrough-inframeavailable(JB-RIF6CS)
• Soldindividually
8" 2-Way Round Ceiling Speaker
5.25" 2-Way In-Wall Speaker
JB-SP8CII
• 8"woofer
• 1"Titanium-laminatetweeter
• Low-diffraction,swiveltweetermountingsystem
• 100Wpowerhandling,8ohmsflushmounted
• Integrateddog-earbracketsforretrofitapplications
• Optionalrough-inframeavailable(JB-RIF8C)
• Soldinpairs
JB-SP5II
• 5.25"woofer,1"tweeter,60W
• 88dBsensitivity,flushmount
• Optionalrough-inframeavailable(JB-RIF5)
• Soldinpairs
6.5" 2-Way In-Wall Speaker
8" 2-Way In-Wall Speaker
JB-SP6II
• 6.5"woofer
• 1"tweeter
• Flushmounted
• 88dBsensitivity
• Optionalrough-inframeavailable(JB-RIF6)
• Soldinpairs
JB-SP8II
• 8"woofer,1"tweeter
• 8ohm,100Wpowerhandling
• Low-diffraction,swiveltweetermountingsystem
• 8ohmsimpedance
• Flushmounted
• Integrateddog-earbracketsforretrofitapplications
• Optionalrough-inframeavailable(JB-RIF8)
• Soldinpairs
Weather-Resistant Bookshelf Speakers
Leviton/Spec-Grade SoundTM
In-Ceiling Speaker
JB-S36AWII
• 3-way6"horizontal/vertical
• Wall-mountable,weather-resistant
• 1"Pure-titaniumdomewithrubbersurround,
shielded;ellipticaloblatespheroidal(EOS™)waveguide
• 150W,8ohms,90dB,60Hz-20Hz
• Soldinpairs
LV-SGC6500W
• Designersoundwithoutthepricetag
• CompositeKevlar®conelow-frequencytransducer
• 0.5"Aero-nylondomehigh-frequencytransducer
• 2-waybalancedprecisioncrossovernetworkwith
AutoSurgecircuitprotection
Leviton/Spec-Grade SoundTM
In-Wall Loudspeakers
Leviton/Spec-Grade SoundTM
Outdoor Loudspeakers
LV-SGI6500W
LV-SGI8000W
• 6.5"and8"models
• Designersoundwithoutthepricetag
• CompositeKevlar®cone,low-frequencytransducer
• Aero-nylondomehi-frequencytransducerwith
phase/timealignmentguide
• 2-waybalancedprecisioncrossovernetworkwith
AutoSurgecircuitprotection
LV-SGO9900W
• Outdoor/Utility2-wayloudspeakers
• Designersoundwithoutthepricetag
• 5.25"Silicate-fibercone,low-frequencytransducer
• 0.5"Polydomehi-frequencytransducer
• AutoSurgecircuitprotection
Outdoor Rock Speakers
WG Series Ceiling Speakers
MU-ROCK8G
• Granitefinish
MU-ROCK8R
• RustFinish
MU-WG100C
• 8-ohm,100W
• 6.5"Kevlarwooferwith1"aluminumdomeswivel
tweeter
• 50Hzto20kHz(+/-3dB)
MU-WG150W
• 8-ohm,150W
• 8"Kevlarwooferwith1"aluminumdomeswivel
tweeter
• 35Hzto20kHz(+/-3dB)
• 8"wooferwith2.5"tweeter
• 100Wmax.power,8ohmimpedance
• 100Hzto20kHzfrequencyresponse
• Soldindividually
• Soldinpairs
260
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Speakers
WG Series In-Wall Speakers
Outdoor Speakers
MU-WG100W
• 8ohm,100W
• 6.5"Kelvarwooferwith1"aluminumdomeswivel
tweeter
• 50Hzto20kHz(+/-3dB)
MU-WG150W
• 8ohm,150W
• 8"Kelvarwooferwith1"aluminumdomeswiveltweeter
• 35Hzto20kHz(+/-3dB)
MU-WS5
• White3ohmoutdoorspeaker
• 5-1/4"wooferwith1"titaniumdometweeter
• 65Hz-20Hzfrequencyresponse
• 70Wmaximumpower
• Aluminumgrill
• Aluminumhangerbracketswithhardware
• Soldinpairs
evoQTM Angled In-ceiling Speakers
evoQTM 3000 Series Speakers
H4-HT5655
• evoQTM5000seriesAngledIn-CeilingSpeaker
• Optimizedforhometheateruse,designedforroomsof
unusualsizeorshape
H4-HT7655
• evoQTM7000seriesAngledIn-CeilingSpeaker
• Designedforsuperiorperformanceinhometheater
applications
H4-MS3650
• evoQTM3000seriesIn-CeilingSpeakers
• 6.5”speakerssoldinpairsanddesignedformulti-room
audioinstallations
• Highefficiencyspeakerprovidescrispclearsoundand
smoothfrequencyresponse
H4-HT5650
• evoQTM5000seriesIn-CeilingSpeaker
• 6.5”speakeroptimizedforhometheaterinstallations
• Featurespolywoofersforhighpowerhandlingand
premiumsoundquality
• TheAngledIn-CeilingSpeakerseriesfeaturesangled
driversandpivotingtweetersforoptimumpositioning.
Requires8”installationbracket(H4-36467302)
PS10 Floor-Standing Subwoofer
C1-PS8
• 8"longexcursiontreatedpaperconewoofer
• Power:80WattsRMS
• FrequencyResponse:45Hz-200Hz
• LFE(LowFrequencyEffects)Input
• OverloadProtectionCircuit
• AutoPowerviaSignalSensing
• Slottedrear-firingporteliminatesventnoiseand
distortion
• Blackwoodgrainfinish&chromefeet
• Dimensions(HxWxD):12-1/4"x9-7/8"x15-1/4"
C1-PS10
• 10"longexcursiontreatedpaperconewoofer
• Power:120WattsRMS
• FrequencyResponse:32Hz-200Hz
• LFE(LowFrequencyEffects)Input
• OverloadProtectionCircuit
• AutoPowerviaSignalSensing
• Slottedrear-firingporteliminatesventnoiseand
distortion
• Blackwoodgrainfinish&chromefeet
• Dimensions(HxWxD):15-1/4"x11-1/2"x17-9/16"
PS12 Floor-Standing Subwoofer
IW625 Inwall LCR Speaker
C1-PS12
• 12"longexcursiontreatedpaperconewoofer
• Power:250WattsRMS
• FrequencyResponse:28Hz-200Hz
• LFE(LowFrequencyEffects)Input
• OverloadProtectionCircuit
• AutoPowerviaSignalSensing
• Slottedrear-firingporteliminatesventnoiseand
distortion
• Blackwoodgrainfinish&chromefeet
• Dimensions(HxWxD):17"x14"x17-13/16"
C1-IW625
• Two6-1/2"graphitewoofers
• 1"pivotingsoftdometweeter
• ±3dBbass&treblecontourswitches
• PowerHandling:125watts
• FrequencyResponse:55Hz-20kHz
• Impedance:8Ω
• Sensitivity:90dB1W/1m
• Dimensions(HxWxD):9"x16-1/8"x3"
• WallCutOut(HxW):7-1/2"x14-1/2"
• Fitshorizontallybetween16"on-centerwallstuds
IW650 Inwall LCR Speaker
70V Dist Indoor/Outdoor Speaker
C1-IW650
• Two6-1/2"Kevlar®woofers
• 1"pivotingaluminumdometweeter
• ±3dBbass&treblecontourswitches
• PowerHandling:150watts
• FrequencyResponse:50Hz-20kHz
• Impedance:8Ω
• Sensitivity:90dB1W/1m
• Dimensions(HxWxD):9"x16-1/8"x3"
• WallCutOut(HxW):7-1/2"x14-1/2"
• Fitshorizontallybetween16"on-centerwallstuds
C1-AW8070VBL
• 8"polypropylenewoofer
• Two1-1/4"pivotingaluminumdometweeters
• 70Vtapswitchselectableat8,16,32&64watts,with
4Ωtransformerbypass
• PowerHandling:90watts
• FrequencyResponse:70Hz-20kHz
• Impedance:4Ω(intransformerbypass)
• Sensitivity:89dB1W/1m
• Dimensions(HxWxD):9"x16"x9"
• Includesswivelmountingbracketwiththeftdeterrent
securitybolts
Surface Mount Speakers
Onwall LCR Speaker
C1-MDSWHT
• 3"injection-moldedgraphitewoofers
• 1"softdometweeters
• Integratedbracketsconcealwiring&connections
• DesignedtomounttoaceilingorwallinMultiple
DwellingUnitssuchaslofts,townhouses,condosetc
• PowerHandling:50watts
• FrequencyResponse:85Hz-18kHz
• Impedance:4Ω
• Sensitivity:85dB1W/1m
• Dimensions(HxWxD):4-1/2"x6-1/4"x5-1/2"
• Compact,SurfaceMountDesign•White
C1-F400GB
• Dual4"injectionmoldedpolypropylenewoofers
• 1"pivotingaluminumdometweeter
• ±3dBbass&treblecontourswitches
• PowerHandling:100watts
• FrequencyResponse:62Hz-20kHz
• Impedance:4Ω
• Sensitivity:86dB1W/1m
• SurfaceMountBracketIncluded
• Dimensions(HxWxD):24"x7-1/2"x4"
• GlossBlack
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
PS8 Floor-Standing Subwoofer
261
Residential Speakers
NEW! Acclaim 5 Series
5.25” OutBack Speakers
RD-5B55
NewAcclaimBackyardSpeakers
• Lifetimewarranty!
• 10-150watts,8ohm
• 5.25”longthrowwoofer,1”Teterondometweeter
• 2.83V/1msensitivity:90dB
• Availableinblackorwhite
• Mountingbrackets&bookshelffootincluded
• Polemountable&cornermounting
• Soldaspair
NEW! Acclaim 5 Series 6.5” Single-Point
RD-5B65S
NewAcclaimBackyardSingle-PointSpeaker
• Lifetimewarranty!
• 10-150watts,8ohm
• 6.5”longthrowwoofer,dual1”Teterondometweeters
• 2.83V/1msensitivity:91dB
• Availableinblackorwhite
• Mountingbrackets&bookshelffootincluded
• Polemountable&cornermounting
• Soldindividually
NEW! Acclaim 5 Series
4” OutBack Speakers
NEW! Acclaim 5 Series
6.5” OutBack Speakers
RD-5B45
NewAcclaimBackyardSpeakers
• Lifetimewarranty!
• 10-100watts,8ohm
• 4”longthrowwoofer,1”Teterondometweeter
• 2.83V/1msensitivity:88dB
• Availableinblackorwhite
• Mountingbrackets&bookshelffootincluded
• Polemountable&cornermounting
• Soldaspair
RD-5B65
NewAcclaimBackyardSpeakers
• Lifetimewarranty!
• 10-150watts,8ohm
• 6.5”longthrowwoofer,1”Teterondometweeter
• 2.83V/1msensitivity:91dB
• Availableinblackorwhite
• Mountingbrackets&bookshelffootincluded
• Polemountable&cornermounting
• Soldaspair
NEW! Russound Flexbox Speaker
Back Boxes
Ratio High-Efficiency Outdoor Speakers
RD-FBC1FR
Flexboxspeakerbackboxesreducebackgroundnoise,
provideamoisturebarrier,diffusedistortion,andimprove
soundquality.Flexibleconstructionallowsforeasy
installationinretrofitornewconstructionsettings.
RD-RM691
• 6"x9"(pair)on-walldesignavailableinwhiteorblack
• Playslouderwithlesspower!
• Doublewarrantyprogram-Doublesoriginalwarrantyof
RussoundRatioSpeakers&Russoundmulti-roomaudio
electronicswheninstalledtogetheronthesameinvoice
Availableintwomodels:
• RD-FBC1FR:FireRatedIn-ceilingBackBox
• RD-FBW1FR:FireRatedIn-wallBackBox
Audio/Video
BothmodelsareflameretardantandmeetASTME119
andUL263/NFPA251(1-hour)andASTME84/NFPA70
standards.
262
Acclaim 5 Series 6.5" In-Ceiling Speaker
Acclaim 5 6.5" Single Point Speaker
RD-5C61
• Newlowerprice!
• RussoundControllerwarrantydoublesfrom2to4years
wheninstalledwithAcclaimspeakers!
• Limitedlifetimewarranty
• 2-wayin-ceilingspeakerpair
• 6.5”vacuumformedpolypropylenewooferwitha0.5”
pivotingPEItweeter
• Powerhandlingfrom10–75wattsat8ohms
• Sensitivity:87dB(2.83V@1m)
RD-5C61S
• Newlowerprice!
• RussoundControllerwarrantydoublesfrom2to4years
wheninstalledwithAcclaimspeakers!
• Limitedlifetimewarranty
• In-ceilingSinglePointStereospeaker
• 6.5"vacuumformedpolypropylenewooferwithtwo
0.5"pivotingPEItweeters
• Powerhandling10–75wattstotalat6ohmsper
channel
• Sensitivity:87dB(2.83V@1m)
• Soldindividually
Acclaim 5 6.5" In-Ceiling Speaker, 85W
Acclaim 5 8" In-Ceiling Speaker, 125W
RD-5C62
• Newlowerprice!
• RussoundControllerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• Limitedlifetimewarranty
• 2-wayin-ceilingspeakerpair
• 6.5"vacuumformedpolypropylenewooferwitha1.0"
pivotingsilktweeter
• Powerhandlingfrom10–85wattsat8ohms
• Sensitivity:87dB(2.83V@1m)
RD-5C82
• RussoundControllerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• Limitedlifetimewarranty
• 2-wayin-ceilingspeakerpair
• 8.0"polypropylenewooferwitha1.0"pivotingsilk
tweeter
• Powerhandlingfrom10–125wattsat8ohms
• Sensitivity:88dB(2.83V@1m)
Acclaim 5 6.5" In-wall Speaker, 100W
Acclaim 7 5.25" In-Ceiling Speaker, 75W
RD-5W64
• RussoundControllerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• Limitedlifetimewarranty
• 2-wayin-wallspeakerpair
• 6.5"polypropyleneandKevlarwooferwitha1.0"
pivotingsilktweeter
• Powerhandlingfrom10–100wattsat8ohms
• Sensitivity:87dB(2.83V@1m)
RD-7C51
• RussoundControllerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• NEW2-wayin-ceilingspeakerpair
• TwistandTilttechnologyallowsdriverandbaskettobe
directedtothesweetspot
• Limitedlifetimewarranty
• 5.25"polypropylenewooferwitha0.5"pivoting
polyamidetweeter
• Powerhandlingfrom10–75wattsat6ohms
• Sensitivity:87.5dB(2.83V@1m)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Speakers - Electronics
Ratio High-Efficiency Loudspeakers
NEW! Double Warranty Program
DoublestheoriginalwarrantyofRussoundRatio
Speakers&Russoundmulti-roomaudioelectronics
wheninstalledtogetheronthesameinvoice.
*systemcomponentswillbedoubledfrom
2yearsto4years
*Controller/Amplifierproducts
RD-CA4,RD-CAS44,RD-CAA66,RD-CAM66,
RD-CAV66)willbedoubledfrom2yearsto4years
*AllRatiospeakerswillbedoubledfrom5years
to10years
RD-RC61S
• 6.5"in-ceilingsingle-pointstereo(soldindividually)
RD-RC61
• 6.5"in-ceiling(pair)
RD-RC81
• 8"in-ceiling(pair)
RD-RW691
• 6"x9"in-wall(pair)
• AllRatiospeakersplaylouderwithlesspower!
• Newspringclipmountingsystem-
Justattachspeakerwireandpressintotheceiling!
Acclaim 7 7" In-ceiling Speaker, 100W
RD-7C72
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• NEW2-wayin-ceilingspeakerpair
• TwistandTilttechnologyallowsdriverandbaskettobe
directedtothesweetspot
• Limitedlifetimewarranty
• 7.0"polypropylenewooferwitha1.0"pivotingsilk
tweeter
• Powerhandlingfrom10–85watts
• Sensitivity:91dB(2.83V@1m)
RD-7C74
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• NEW2-wayin-ceilingspeakerpair
• TwistandTilttechnologyallowsdriverandbaskettobe
directedtothesweetspot
• Limitedlifetimewarranty
• 7.0"polypropyleneandKevlarwooferwitha1.0"
pivotingsilktweeter
• Powerhandlingfrom10–100wattsat6ohms
• Sensitivity:90dB(2.83V@1m)
Acclaim 7 7" In-ceiling Speaker, 125W
Acclaim 7 8" In-ceiling Speaker, 125W
RD-7C75
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalledwithacclaimspeakers
• NEW2-wayin-ceilingspeakerpair
• TwistandTilttechnologyallowsdriverandbaskettobe
directedtothesweetspot
• Limitedlifetimewarranty
• 7.0"aluminumwooferwitha1.0"pivotingTeteron
tweeter
• Powerhandlingfrom10–125wattsat6ohms
• Sensitivity:90dB(2.83V@1m)
RD-7C85
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• NEW2-wayin-ceilingspeakerpair
• TwistandTilttechnologyallowsdriverandbaskettobe
directedtothesweetspot
• Limitedlifetimewarranty
• 8.0"aluminumwooferwitha1.0"pivotingTeteron
tweeter
• Powerhandlingfrom10–125wattsat6ohms
• Sensitivity:91dB(2.83V@1m)
Acclaim 7 5.25" In-wall LCR Speaker, 100W
Acclaim 7 7" In-wall Speaker, 125W
RD-7W55LCR
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalled
• NEWPassive2-wayLCRspeaker
• PatentedIso-Mountchassisreduceswallvibrationsfor
bettersound
• Limitedlifetimewarranty
• 5.25"aluminumwooferwitha1.0"pivotingTeteron
tweeter
• Powerhandlingfrom10–100wattsat4/5/6ohms
• Soldindividually
RD-7W75
• Russoundcontrollerwarrantydoublesfrom2yearsto4
yearswheninstalledwithAcclaimspeakers
• NEW2-wayin-wallIso-Mountspeakerpair
• PatentedIso-Mountchassisreduceswallvibrationsfor
bettersound
• Limitedlifetimewarranty
• 7.0"aluminumwooferwitha1.0"pivotingTeteron
tweeter
• Powerhandlingfrom10–125wattsat6ohms
Custom Builder 6.5" In-Ceiling Speaker
HDMI Distribution Amplifiers
SO-SPCBC6
• 60WattMaximumPowerHandling
• 6"Compressionmolded
• Frequencyresponse:63Hz-21Khz•Impedance:8ohms
• 9"diameter•Soldinpairs
Alsoavailable:
SO-SPCBC5 5"model
SO-SPCBC8 8"model
SO-SPCBDVC5 5"dual-voicecoilmodel
SO-SPCBW6 6"in-wallmodel
7C-HA8
7C-HA43
• 1in4outor1in8outHDMIamplifiersdistributeone
highdefinitionsourcetomultipledisplays.
• Enhancedamplifiedsignalsforlongercableruns
• CompliantwithHDMI/HDCPrequirements
• Supportshigh-resolutiondisplaysofUXGA,480i,480p,
720p,1080iand1080p
• CascademultipleamplifiersforlargeTVdisplays
• SecureHDMIconnectionwithintegratedcableretention
bracket
7.1 Channel Home Theater
7.1 CH A/V Home Theater Multi-Source
DO-AVR990
• 120wattsperchannelx7channels
• DolbyTrueHD,DolbyDigitalPlus,DolbyDigitalSurround
EX,DolbyProLogicIIzdecoding
• DTS-HDMasterAudio,DTS-HDHighResolution,DTSES
6.1Discrete,DTSES6.1Matrix,DTSNeo:6decoding
• AudysseyMultEQ,DynamicVolume,DynamicEQ
• NetworkaudioandphotostreamingfromyourPC;
accessinternetradiostations;accessRhapsodyand
Napstermusicservices(subscriptionrequired)
• HDRadioAM/FMtunerbuilt-in;Siriussatelliteready
DO-AVR890
• 105wattsperchannelx7channels
• DolbyTrueHD,DolbyDigitalPlus,DolbyDigitalSurround
EX,DolbyProLogicIIzdecoding
• DTS-HDMasterAudio,DTS-HDHighResolution,DTSES
6.1Discrete,DTSES6.1Matrix,DTSNeo:6decoding
• AudysseyMultEQautomaticroomacousticmeasuring
andcorrectionsystem
• AudysseyDynamicVolume,AudysseyDynamicEQ
• Siriussatelliteready
• AnchorBayABT-2010advancedanaloganddigitalvideo
1080p/24fps/60f
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Acclaim 7 7" In-ceiling Speakers, 85W
263
Electronics
7.1 CH A/V Home Theater
5.1 Channel Home Theater Receiver
DO-AVR790
• 90wattsperchannelx7channels
• DolbyTrueHD,DolbyDigitalPlus,DolbyDigitalSurround
EX,DolbyProLogicIIzdecoding
• DTS-HDMasterAudio,DTS-HDHighResolution,DTSES
6.1Discrete,DTSES6.1Matrix,DTSNeo:6decoding
• AudysseyMultEQautomaticroomacousticmeasuring
andcorrectionsystem
• AudysseyDynamicVolume,AudysseyDynamicEQ
• AnchorBayVRSadvancedanaloganddigitalvideo
upconversionanddeinterlacingwith1080p24Hz
DO-AVR590
• 75wattsperchannelx5channels
• DolbyTrueHD,DolbyDigitalPlus,DolbyDigitalSurround
EX,DolbyProLogicIIzdecoding
• DTS-HDMasterAudio,DTS-HDHighResolution,DTSES
6.1Discrete,DTSES6.1Matrix,DTSNeo:6decoding
• AnalogvideotoHDMIconversion,with1080p
24Hz/60HzHDMIpass-through
• AudysseyMultEQautomaticroomacousticmeasuring
andcorrectionsystem
• AudysseyDynamicVolume,AudysseyDynamicEQ
• iPod/iPhonecompatible
Blu-ray Disc DVD/CD Digital Player
Wired and Wireless iPod Dock
DO-DBP1610
• BDProfile2.0,BD-LiveenabledviaEthernet
• HDMI,componentandcompositevideooutputs
• StandarddefinitionDVDvideoprocessingandscaling
upto1080p
• BitstreambypasstoHDMIfordirectDolbyTrueHDand
DTS-HDhighresolutionmulti-channeldigitalaudio
output
• 12bitvideoprocessingwithSDdigitalvideonoise
reduction
• Multiplepictureadjustments,includinggamma
correction
DO-ASD11RK
• ConnectandplayyouriPhone,iPodClassic,Touch,new
Nano(audio&video)
• Stereoaudiooutputs;S-videooutputtodisplayiPod
picturesandvideosonyourTV
• ConnectstoDockControlport(providedonmanyDenon
models)
• ChoosetracksandfavoritesusingyourDenon
component’sremotecontrol
• Provideschargingfunction
• ElegantstylingtomatchyouriPod
• CablesandadaptersforvariousiPodmodels
included
Single Channel Active Balun
7.1 Channel Home Theater Receiver
GE-BLNAT
• ActiveTransmitter
GE-BLNAR
• ActiveReceiver
JB-AVR1600
• 50wattsx7channels
• HDMIRepeaterprocessesbothaudioandvideo
• EzSet/EQ-automaticroomacousticcorrectionsystem
• Logic7,DTSHDMasterAudio,andDolbyTrueHD5.1&
7.1decoding
• SoftwareupdatesdeliveredviaUSB
• HarmanKardonVirtualSpeakersimulatedsurroundfor
2.1systems
Audio/Video
• Extendvideoto8,200feet
• Lowcost
• Superiorpicture
7.1 Channel iPHONE Compatible Home
Theater Receiver
7.2 Channel Home Theater Receiver with
Internet Radio and ABUS
JB-AVR2600
• 65wattsx7channels
• 1080pHighdefinitionon-screengraphicaluserinterface
• DolbyVolume-automaticvolumecorrectiontechnology
• FaroudjaTorino1080pDCDIvideoprocessing
• CompatiblewithTheBridgeIIIiPod/iPHONEdocking
station
• EzSet/EQ-automaticroomacousticcorrectionsystem
• Logic7,DTSHDMasterAudio,andDolbyTrueHD5.1
and7.1decoding
JB-AVR7550HD
• 110wattsx7channels
• 1080pHighdefinitionon-screengraphicaluserinterface
• DolbyVolume-automaticvolumecorrectiontechnology
• FaroudjaTorino1080pDCDIvideoprocessing
• TheBridgeIIiPoddockingstationincluded
• EzSet/EQII-automaticroomacousticcorrectionsystem
• Logic7,DTSHDMasterAudio,andDolbyTrueHD5.1&
7.1decoding
• Zone2optionsincludeABUS,Poweredoutputs,and
Pre-ampoutputs
7.1 Channel iPHONE Ready Home Theater
Receiver with ABUS
High Definition Blu-Ray DVD/CD player
JB-AVR3600
• 80wattsx7channels
• 1080pHighdefinitionon-screengraphicaluserinterface
• DolbyVolume-automaticvolumecorrectiontechnology
• FaroudjaTorino1080pDCDIvideoprocessing
• TheBridgeIIIiPod/iPHONEdockingstationincluded
• EzSet/EQ-automaticroomacousticcorrectionsystem
• Logic7,DTSHDMasterAudio,andDolbyTrueHD5.1&
7.1decoding
• Zone2optionsincludeABUS,Poweredoutputs,and
Pre-ampoutputs
264
JB-BDP1
• Profile2.0withsupportforBDLivecontent
• DVDscaledto1080p
• FrontpanelUSBjack
• PlaysMP3,WMA,andJPEGfilesfromdiscorUSBdrive
• DesignmatchesJB-HKAVR7550HD,JB-AVR3600,
JB-AVR2600,andJB-AVR1600
DVD-Audio/Video and SACDTM Player
Stereo Receiver
JB-DVD48BK
• PlaysDVD-Audio,SACDTM,DVD,DVD-R/RW,DVD+R/RW,
VCD,CD,CD-R/RW,MP3,WindowsMedia®WMA,JPEG
• Videoupscalingto720p,1080ior1080p
• Built-inDolby®Digital/MLPDecoderwith
BassManagement
• Component,S-andCompositevideooutputs
• HDMITMoutput
JB-HK3390
• 2x80W@8ohms
• Highcurrent,ultrawidebandwidth
• Features4videoinputswithRecordoutput,Phonoinput,
dualsubwooferoutputs,dimmablefluorescentdisplay,
pre-out/main-injacks&sleeptimer
• Multi-componentsystemremotecontrolincluded
• A/VcableincludedtoconnectiPod®orotherportable
players
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Electronics - Home Theater
Stereo Receiver
JB-HK3490
• 2x120W@8ohms
• Highcurrent,ultrawidebandwidth
• Features4videoinputswithRecordoutput,Phonoinput,
dualsubwooferoutputs,dimmablefluorescentdisplay,
pre-out/main-injacks&sleeptimer
• Optical&CoaxialDigitalAudioinputs
• DolbyVirtualSpeaker&DolbyHeadphone
• TheBridgeII-readyforiPod®connectivity
• XM-Ready®
• Multi-componentsystemremotecontrolincluded
Docking Station for iPod®
JB-THEBRIDGEII
• Audio/VideoPlayback&navigationcontrolofiPod®
(notincluded;videocapabilitydependsoniPodandAVR
models)
• Single-cableconnectiontoTheBridge-ready
HarmanKardonproducts
• DisplaysiPod®navigationonscreen
• ChargesiPod®whiledocked
• CompatiblewithiPod®modelsequippedwith
dockingconnector
M4 Multiroom Controller
JB-WEM1
• Makeanyspeakerwireless
• Usetoquicklyinstallsoundinhardtoreachlocations
• UseinbedroomsystemstodeliverlocalsoundfromTV
• Thekitcontainsa50wattx2amplifier,wirelesstransmitter,IRremotecontrol,andmountinghardware
• Eachtransmitterwillsupporttworeceivingamplifiers
• CustomEQsettingsforJBLspeakers
C1-M4
• Premiumcastaluminumfaceplate
• Fourzoneaudiocontroller
• Sixsourceinputs
• Power:30Wattsx8channels
• Telephonepaginganddoorbellmute
• Alldigitalamplification
• IncludesfourPMKIRmasterkeypadswithIR
• IncludessixIRsingleflashers
• ProgrammableviaProficientEditorsoftware
• Includesbolt-onrackears
125W x 2 Channel Power Amp
M6 Multiroom Receiver
C1-M2
• Premiumcastaluminumfaceplate
• High-currentdiscreteamplifierdesign
• Autosensingpoweron/off
• Stereolinelevelinput
• Individualinputleveladjustments
• Passthroughlineleveloutputs
• 5-waybindingposts
• Includesbolt-onrackears
C1-M6
• Premiumcastaluminumfaceplate
• Sixzoneaudioreceiver
• Sixsourceinputs+2AM/FMTuners
• Power:30wattsx12channels
• Telephonepaging&doorbellmute
• Alldigitalamplification
• IncludessixPMKIRmasterkeypadsw/IR
• IncludessixIRsingleflashers
• ProgrammableviaProficientEditorsoftware
• Dimensions(HxWxD):5-13/16"x17-1/8"x15-1/2"
35W x 8 Channel Power Amp
M40 High-Current 80 Watt Stereo Receiver
C1-M8
• Premiumcastaluminumfaceplate
• Independentlevelcontrolsoneachchannel
• 4positionsourceselectionswitchoneachchannel
• Odd-evenpairsarebridgeableforhigherpower
• Remotepower-onviasignalswitchingor3-30Vtrigger
• Separateprotectioncircuitryforeachchannelpair
• 12Vtriggeroutput
• Busloopoutputfordaisychainingadditionalamplifiers
• 5-waybindingposts
• Includesbolt-onrackears
C1-M40
• Premiumcastaluminumfaceplate
• High-currentamplifierdesign
• 80wattsperchannelinto8Ω
• AM/FMtunerwith30stationpresets
• Preampout/powerAmpinput
• Twofull-rangesuboutputs
• Compositevideoswitching
• Front-panelA/VInput
• Phonoinput
• Fullfunctionremote
130 Watt x 7 Cinema Receiver
The Source Dock/Dock Adapter
C1-M80
• Premiumcastaluminumfaceplate
• Videoinputs–(4)HDMI,(3)component,(5)s-video,
(5)composite
• Videoup-conversionto1080HDMI
• OptionaliPod®dockwith9linemetadataonscreen
display
• SmartEQTM–autoroomsetupwithmic
• Zone2(SurroundBackL/R)lineandspeakeroutputs
• DolbyTrueHDMasterAudio,DTS-ES6.1Discrete,
DTS-ES6.1Matrix
• Digitalaudioinputs–(4)Optical,(2)Coaxial
C1-SOURCEDKW
C1-SOURCEDKB
• ConvertsiPodaudiointoabalancedaudiosignal
• ConvertsiPodserialdatatoRS485data
• RJ45jackforCAT5connectiontodockadapter
• USBportforsyncingiPodtocomputer
• Auxiliaryaudioinput
• DesignedspecificallyforProficientC1-M4&C1-M6
• Includes(1)iPod-CompatibleSourceDock
• Includes(1)SourceDockAdapter
• Includes(1)StereoMinitoRCAAudioCable
• RequiresTheSourceDockPowerSupply
The Source Keypad
Aria Wireless Transmitter and Receiver
C1-SOURCEKPW
C1-SOURCEKPB
• High-res,64Kcolor(16Bit)LCDdisplay
• Menu,sourcecomponentandmetadatadisplay
• FullyretrofitcompatiblewithPMKIRinstallations
• Easynavigationscrollwheel
• Volumecontrolknobw/back-litlevelindicator
• 7back-lit,configurable‘HardKeys’
• Built-InIRreceiverfitsmostdualgangelectricalboxes
• Whiteversionincludeswhitebezel
• BlackVersionIncludesblack,bone&almondbezels
O3-WA320/321
O3-WA360/361
• Sendmulti-roomaudioaroundthehomeorcreatea
“wireless”5.1hometheater
• Transmitstereoaudio,AM/FM,XM,PCi-tunes®,i-Pod®
orMP3music,orgamingconsolesandTV’s
• 300ftdigitalmusicwithclearsignalfrequencyhopping
technology
• Effortlessinstallationofrearspeakersinsurroundsound
system
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Wireless Amplifier Expansion Module
265
Home Theater
2G-J10BLK
2G-H15BLK
J Type Power Conditioners with Battery
Backup
Audio/Video
2G-J10
2G-J10BLK
2G-J15
2G-J15BLK
• All-in-onepremiumpowerprotectionsolutionforaudio/
videosystems
• Batterybackup-Hot-swappable,userreplaceable
batterypreventsinterruptions,protectsbulbs,&savesDVR
recordingsduringoutages
• Automaticvoltageregulation-Reduceswearandtearon
components
• EMI/RFIfiltrationandsurgeprotectionwith
<40Vlet-throughvoltagerating
• 12surgeprotectedoutletsandCOAX,Ethernet/DSL,and
phoneprotectionjacks
• 1000VA(2G-J10)or1440VA(2G-J15)powercapacity
• LCDdisplay
• Lifetimeproductwarrantyand$750,000equipment
protectionpolicy
• Availableinblack(J10BLK,2G-J15BLK)orsilverfinish
(2G-J10,2G-J15)
H Type Power Conditioners
2G-H10
2G-H10BLK
2G-H15
2G-H15BLK
• Completepowerconditioningforaudio/videosystems
• Automaticvoltageregulation-Reduceswearandtearon
components
• EMI/RFIfiltrationandsurgeprotectionwith
<40Vlet-throughvoltagerating
• 12surgeprotectedoutletsandCOAX,Ethernet/DSL,and
phoneprotectionjacks
• 1000VA(2G-H10)or1440VA(2G-H15)powercapacity
• LCDdisplay(2G-H15)
• Lifetimeproductwarrantyand$500,000equipment
protectionpolicy
• Availableinblack(2G-H10BLK,2G-H15BLK)orsilverfinish
(2G-H10,2G-H15)
• ULlisted
266
2G-C2
2G-G5BLK
C Type Power Filters
2G-C2
2G-C5
2G-C5BLK
2G-C10
2G-C10BLK
• Guaranteedprotectionagainstsurges,spikes,andlightning
• Lowprofile,wall-mountablemodelavailable-perfectfor
LCDandplasmadisplays(2G-C2)
• EMI/RFIfiltrationandSurgeProtectionwith<40V
let-throughvoltagerating
• IsolatedNoiseFiltering
• COAX,Ethernet/DSL,andphoneprotectionjacks(2G-C5
and2G-C10)
• LEDstatusindicatorsavailablewith2outlets(2G-C2),10
outlets(2G-C5),
or12outlets(2G-C10)
• Lifetimeproductwarrantyand$350,000equipment
protectionpolicy
• Availableinblack(2G-C2,2G-C5BLK,2G-C10BLK)orsilver
finish(2G-C5,2G-C10)
• ULlisted
G Type Power Filters
2G-G5BLK
• Premiumsurgeprotectionandnoisefilteringforhigh
performanceAVequipment,inarack-mountable,1Uform
factor
• EMI/RFIfiltrationandsurgeprotectionwith
<40Vlet-throughvoltagerating
• 9surgeprotectedoutlets
• SequencedON/OFFsettingsvia4outletbanks
• LEDstatusindicatorsandanLCDdisplayformonitoring
andmanagement
• Lifetimeproductwarrantyand$450,000equipment
protectionpolicy
• ULlisted
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Home Theater - Distributed Audio
Home Theater Power Conditioner
Accurate Handheld Sound Level Meter
DK-HT1000
• 12outletsin6isolatedbanks,withprogrammabledelay
capability
• EMI/RFInoisefilteringprovidesbetterpictureandsound
quality
• IncludesACPowerandnetworksurgeprotection,four
protectedcoaxfeedsandphonelineprotection
• Separateampliferbankwithdelayedon/offfunction
eliminatesspeaker“thump”
• Threeyearlimitedwarrantywithconnectedequipmnet
protectionpolicy
GO-SPL120
• MeasuressoundlevelsinFlat,“A”or“C”weighting
• MeasuresFire,BurglaryorAutoAlarms
• MeasuresHomeTheaterSoundLevels
• ComplieswithOSHAandCityNoiseStatutes
Home Theater Extender
Universal Remote Control
2H-86A001
• AddsIRcapabilitytoHAIísOmniTouchPortableand5.7e
Touchscreenswithover300,000built-inIRcodesanda
built-inIRreceivertolearnadditionalIRcodes.
• Allowshomeownerstopressonebuttontoturnonthe
A/Vcomponents,playaDVD,closewindowcoverings,
andsettheentirehousetodesiredtemperatureand
lightinglevelsforanenjoyableentertainment
experience.
UT-KP900
• Wirelesskeypadremotecontrol
• No-holesmounting;Canbemountedonanysurface
• Perfectforretrofit(nowiringrequired)
• BacklitbuttonsandbrightLCD
• Canbeusedashandheldremotecontrol
• AvailableinWhite,BlackandLightAlmond
Universal Remote Control
UT-MX900
• PCProgrammableIR/RFRemotewithAddressableRF
• Compactwandstyleone-handremote
• Unique7characterLCDbuttonlabeldesign
• EasytounderstandWATCHandLISTENcommands
• Flexiblememoryarchitecture
• Macrosupto255stepsplusnesting
UT-MX3000
• Tablet-stylePCprogrammabletouchscreencolorLCD
IR/RFremotecontrol
• AddressableRF
• Colorgraphictouchscreenandhardbuttoninterface
withoptionalaudiofeedback
• Supportsupto255devices,andsupportsupto255
pagesperdevice
• Stylishdesignwithrichblackfinish
• IncludesrechargeableLi-Ionbatteryandchargerbase
System Controller
3.9" SmartPad LCDTM Graphic Touchpanel
VO-ISM4
• Constantstatuscontrolfor4components
• Autocorrectwhensystemmacrogetsoutofsync
• IRprogrammingNOPCRequired
• 4IRports
• Bi-directionalRS232portforstatus
• Cloningfeatureallowscopyingprogrammingfrom1
unittoanother
VO-SPLCD39G
• TheVO-SPLCD39Gbringstheconvenience,elegance,
andsimplicityofaLCDtouchscreencontrollertoa
smallersized,self-containedunitthatfitsinjustabout
anywhere
• Its320x240resolutionwith256colorsprovides
remarkablegraphicsandclarity
• Stand-alonedevicetooutputIRand/orRS232commands
• Fullycustomizabledisplaygraphics
• XDTStationfeedback,andXMUSICsongtitlenavigation
• Internalpre-programmedIRcodelibrary
6.4" SmartPad LCDTM Video Touchpanel
Power Amplifier
VO-SPLCD64V
• TheVO-SPLCD64Vcombinesvideodisplaywiththe
convenienceandsimpleoperationofaself-contained
touchpanelcontroller
• Its640x480resolution,with64Kcolor,provides
outstandinggraphicsandaremarkablevideoimage,
whichmaybedisplayedfullscreen,oras
picture-in-picture
• Touchpanelcontrollerwithvideodisplay
• Fullycustomizabledisplaygraphics
• Stand-alonedevicetooutputIRand/orRS-232
commands
UI-AMP100
• Automaticsourceswitcher(lolevelonly)
• 100wattpoweramplifiermaxpower
• 50wattsperchannel(8ohmstereo)
• 100wattbridgedmono(8ohm)
• 2pairofstereolowlevelinputswith
Automatic-PrioritySwitching
• SwitchableAuto-OnSensing
• A&BSpeakerSwitching
AMP102 (2) Channel Power Amplifier
AMP110 (2) Channel Power Amplifier
UI-AMP102
• NewAMP102(50Wx2/8Ω)
• Line1/Line2priorityinputswitchingwithLine2
auxiliaryoutput
• FrontpaneldiagnosticLED’s
• Frontpanelbalance,volumetrimandSpeakerA/B
switchingcontrols
• Signalsensing“PowerOn”12VDC“TriggerOn”
• Stereo/Bridge(Mono)Switch
• Optionalrackmountkitavailable
• 120/230VACmultivoltage
UI-AMP110
• NewAMP110(75Wx2/8Ω)
• NewTriple-DarlingtonPowerAmplifierStages
• Newdual-differentialinputforimprovednoisereduction
• Increasedbandwidthfrom20-20kto10-35K
• Line1/Line2priorityinputswitchingwith
Line2auxiliaryoutput
• FrontpaneldiagnosticLED’s
• Frontpanelbalance,volumetrimandspeakerA/B
switchingcontrols
• Signalsensing“PowerOn”12VDC“TriggerOn”
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Universal Remote Control
267
Audio/Video
Distributed Audio
AMP210/310 (2) Channel Power Amplifier
In-Wall Amplified
UI-AMP210
• 80Wx2/8Ω
UI-AMP310
• 150Wx2/8Ω
• NewTriple-DarlingtonPowerAmplifierStages
• Newdual-differentialinputforimprovednoisereduction
• Increasedbandwidthfrom20-20kto10-35K
• Line1/Line2priorityinputswitchingwith
Line2auxiliaryoutput
• Switchablehighlevelinputwithadjustabledelay
betweenLine1&Line2
JB-AB1
• CompatiblewithanyHarmanKardon®READY®
receiveroranyreceiverorsourceproductconnectedto
aJB-ABH4orJB-ABH4000
• ConnectedviaCat5/5ecable
• Powers6-or8-ohmspeakerswithsensitivity>88dB
• IRsensorforpass-throughofremotecommands
In-Wall Amplified
4-Room
Module
Expansion Hub
JB-AB2
• 4direct-accesssourcebuttonswhenusedwith
HarmanKardon®READY®receiveror
JB-ABH4000
• Transport&tunercontrols
• Powers6-or8-ohmspeakers
• IRsensorforpass-throughofremotecommands
• Customizablekeycaps
JB-ABH4
• CompatiblewithJB-AB1,JB-AB2orother
modules
• RequiresHarmanKardon®READY®receiver
oranysourcedevicewithstandardanalogoutputs
4-Zone/8-Room
Digital Media Server
Expansion Hub
JB-ABH4000
• Distributesupto4sourcestoseparatezones
• Upto2roomsperzone,expandablewhenusedwith
JB-ABH4
• RequiresHarmanKardon®READY®receiveror
anysourcedevicewithstandardanalogoutputs
• CompatiblewithJB-AB1,JB-AB2orother
modules
JB-DMC1000
• 250GBhard-discdrive
• Playsaudio/stillimagecontentfromSD,MMC,
MemoryStickorCFcardsandUSBPortforflashdrives
• CopiesaudiofromCDsorline-levelinputsandconverts
toMP3forstorageonhard-discdrive,cardsorUSB
• Gracenote®MusicRecognitionServiceincludingcover
artdisplay
• PlaysDVD,DVD-R/RW,DVD+R/RW,VCD,CD,CD-R/RW,
MP3,JPEG
• Videoprocessingwithupscalingto1080pviaHDMI™
Output
Hi-Fi Expansion Kit (to 8 Zone 6 Source)
Hi-Fi 4 Zone 4 Source Kit
in Vented Enclosure
2H-62A121
• 4-zoneamplifiercards
• 4volumesourcecontrols
• 2remoteinputmodules
• Powersupply,manuals
• Mustbeusedwith2H-62A001or2H-62A002
Decora® StraussTM
Transformer-Free Volume Controls
LV-SGVST00W
• Transformer-Free™VolumeControl
LV-SGVSM00W
• Transformer-Free™ImpedanceMatchingVolumeControl
• Decora®slidecontrolwithprecision12-positionswitch
• Frequencyresponse:20Hz-20kHz+/-1dB
• Powerhandling:200Wpeak/100WRMS
268
Module
• Mainassemblywith:
*4installedZoneAmplifierCardsinventedenclosure
*4RemoteInputModules
*4VolumeSourceControls
*PowerSupply,RemoteControl
*CableforHAIcontrollers,manuals
• Expandableto8Zone,6Source
• AlsoavailableforStructuredWiringEnclosures
(2H-62A001)
Encore Keypad
CS-ENCDRS
• Provideslocalcontrolofallsystemfunctions:Source
Selection&VolumeLevel,ToneControl(bass/treble
adjustment),BalanceLoudness&DynamicCompression,
Mute,Do-Not-Disturb&WholeHouseMusicMode
• IntegratedClassDdigitalamplifierprovidesupto80watts
totaloutput
• Backlitbuttonswithauto-fade
• Cat-5wiringconnectionstotheaudiodistributionhuband
alocalinputwallplate
• Mountsinasingle-gangJ-box
Encore Audio Distribution System Hub
Encore Advanced Learning Remote
CS-ENCHUB
• ConnectswithuptofourSourceInputWallPlatesand
fourEncorekeypadsfora4-source,4-zoneDigitalAudio
DistributionSystem
• Canalsobeusedasa4-zoneExpansionHubforan
existingEncoresystem,providingconnectionsforupto
fouradditionalkeypads
• Separatepowerboostoutputterminalsformaximum
performanceoverlongCat-5keypadrundistances
• Robust,highqualitypunchdownconnectors
• Zonepairingswitchesforsynchronizingmultiplekeypads
inlargerorconnectedrooms
CS-ENCLRM
• Hand-heldlearningremotecontrol
• Programmable4-sourcecapable
• Pre-programmedwithEncorecontrols
• Compatiblewithmajorsourcecomponents
• DedicatedEncorevolume,source,bass,treble,and
balancecontrols
• ThreeIRmacrofunctionbuttons
• Built-inIRcodelibrary
• IncludestwoAAbatteries
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Hear. There. Everywhere.
Encore by Linear…Pure Digital Sound Made Affordable.
Bring your home audio customers a sound value with
the new Encore Digital Audio Distribution System from
Linear. As an upgrade or new installation, the Encore
system’s award-winning DIGI-5 technology
delivers unbeatable sound quality, higher
power output, flexibility and ease of use – all
at a price that will have your customers
saying “Encore!”
• Base system provides distribution of 4 audio sources
to 4 zones, expandable to 32 zones
Simple, user-friendly keypads
and clean, modern design fits
any décor.
• Each keypad features an integrated 60-watt digital
amplifier for clear, powerful sound
• Easy-to-install new or as a retrofit upgrade for older
analog systems, requiring one CAT-5 run per keypad
• End-to-end 24-bit digital format prevents content
loss and distortion from source to keypad
All these brands are now under one name.
See how the Encore
Distributed Audio System
can enhance your
business.
For information visit
linearcorp.com/encore
for more details.
Distributed Audio
Encore Digital Audio Distribution System
CS-ENCKITM
• Standard4audiosource,4zonesystem,expandableto
32zones
• Integratedhighefficiency,40wattsperchannelinto
6-ohmspeakers/30wattsperchannelinto8-ohmspeakersatlessthan1%THD
• Easytoinstallneworasaretrofit,requiringonlyoneCat-5
runperkeypad
• Nocontentlossordistortionwithaward-winningDIGI-5
soundtechnology,fromsourcetokeypad
• 2yearlimitedwarranty
• Kitcomponentsinclude:(1)AudioDistributionHub&Power
Supply,(4)SourceInputWallPlates,(1)UniversalMounting
bracket,(4)AmplifiedKeypads,(1)StandardRemote,(4)
IREmitters
Encore Power Supply
Audio/Video
Encore Local Input Wall Plate
270
CS-ENCLIWP
• Providesconnectivitytoanamplifiedkeypadforanaudio
inputthatcanbeusedasafifthsourcewithinadiscreet
zoneofanEncoremulti-roomaudiosystem
• AnalogsourcematerialconnectedthroughRCAjacksis
convertedto24bit/48kHzdigitalformat
• Opticalandcoaxialdigitalconnectionsfordirectdigital
input
• IRemitteroutputjackforcontrollingsourcecomponents
remotely
• Inputgainadjustmentandclippingindicator
CS-ENCPS
• PowersupplyforEncoreAudioDistributionSystemHub
• 120VACinput,26VDC@1.2Ampoutput
• Outputcablehasconnectorforhub
• Greenpowerindicator
• MountsinstructuredwiringenclosureoronH275
UniversalMountingBracket
Encore Source Input Wall Plate
Music Distribution System
CS-ENCSIWP
• ProvidesconnectivitytotheDistributionHubforasource
thatcanbesharedinmultiplezonesofanEncoreaudio
distributionsystem
• AnalogsourcematerialconnectedthroughRCAjacksis
convertedto24bit/48kHzSPDIFdigitalformat
• Opticalandcoaxialdigitalconnectionsfordirectdigital
input
• IRemitteroutputjackforcontrollingsourcecomponents
remotely
• Inputgainadjustmentandclippingindicator
CS-MDS6AKIT1
• Kitincludes:
(1)CS-MDS6Amusicdistributionsystem,(4)CS-MCS1A
keypads,(2)CS-MCS2Akeypads,(6)CS-2171IRemitters
CS-MDS6AKIT2
• Kitincludes:
(1)CS-MDS-6Amusicdistributionsystem,
(6)CS-MCS-1Akeypads(6)CS-2171IRemitters
Impedance Matching Volume Control
Xtreme Digital Music System
MU-IM1
• Whitestandard
MU-IM1D
• WhiteDecora
MU-IM1DA
• AlmondDecora
MU-XDM4600KT
• Expandable4zone/6sourcedistributedaudiosystem
thatoffersintercomcapabilitythroughoutthehome
• EachzonecontainsaClassDamplifierdelivering
incrediblelisteningpowerat30wattsachannel
• Kitcontains:
*(4)MU-XDM46KKeypads
*(1)MU-XDM46CCCentralController
*(6)MU-XDMIREIREmitters
*(1)MU-DS3B2DoorStation
• Musicdistributionsystemthatselectivelyswitchessixaudio
sourcestosixspeakerzones,40wattsperchannel
• TheCS-MCS1A&CS-MCS2Akeypadsprovideflexible
controlovertheCS-MDS6Aandconnectedmusicsources
• 75Wmaxpower
• Constant8-ohmloadregardlessofthevolumesetting
• MountsinsinglegangJ-box
ShownwithMU-WG100Cceilingspeakers
Class-D Stereo Digital 40W Audio Amplifier
DSSM Speaker Selector
NF-KICKAMP40
• WorkswithiPOD®’s,laptops,MP3/CD/DVDplayers
• WorkswithAudioOutputofFlatPanelTV’s
• Drivesfloor,bookshelf,ceiling,andwallspeakers
• Runscoolandgreenat92%efficiency
• Ruggedaluminumcase
• 2.7”longx2.2”widex1.0”high
• Includes24VDC2AmpPowerSupply
• Speakers&inputdevicenotincluded
• 1yearlimitedwarranty
PH-IHDSSM6
• Dualsourceresistorbasedspeakerselector
• IndividualA/Bsourceswitchperzone
• Sixzone
• Manualprotectionswitchstrategicallylocatedonbackpanel
• 70Ww/protectionenabled,140wattsw/protectiondisabled
• Featuresremovableinput/outputconnectors
• Customtooledblackbrushedaluminumfaceplate
• Labelkitincludedforslottedon/offbuttons
VSS Speaker Selectors
Speaker Selector
PH-IHVSS2
PH-IHVSS4
• Dualsourcespeakerselectorswithvolumecontrols
• IndividualA/Bsourceswitchesperzone
• Internal100wattimpedancematchingvolumecontrol
perzone
• Availableintwoandfourzoneboxes
• Removableinput/outputconnectors
• Customtooledblackbrushedaluminumfaceplates
PH-ISM6
• Singlesourceresistorbasedspeakerselector
• Sixzone
• Manualprotectionswitchonbackpanel
• 70Ww/protectionenabled,140wattsw/protectiondisabled
• Featuresthruoutputsfordaisychaincapability
• Blackpowdercoatedfinish
• Labelkitincludedforslottedon/offbuttons
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Distributed Audio
Slider Type Volume Controls
PH-VMT100W
• 100wattwith12positions,39dBofattenuation
• Selectableimpedancematching:
1x,2x,4xand8xsettings
• Removableinput/outputsolderlessspeakerterminalsfor
easytermination
• Includescolorcodedknob,Decorametal/plasticinsert
andscrews
PH-VSL125
• “SliderStyle”Decorainsertvolumecontrol
• 125wattimpedancematchingvolumecontrolwith
39dBofAttenuation
• SelectableImpedancematching:
1x,2x,4xand8xsettings
• Removablerightanglesolderlessspeakerterminals
witheasytoptermination
• Includes3colorwallplatesandmatchingsliders:
white,almondandboneinasingledisplaypackage
AcousticDesign ADS32T
NEW! Russound Collage Dock for iPod
QB-ADS32T
• 3”polypropyleneconewoofer
• 0.75”titaniumdometweeter
• 30Wattscontinuouspowerhandling,120wattspeak
• 70/100voltmulti-taptransformerwith8ohmbypass
• FrequencyResponse(-6dB):73Hz-20kHz
• MaximumOutput:105dBSPL
• Includesballmountassemblyandyokemount
• Availableinblackorwhite
RD-CPD1
• EngineeredusingGridcastTMtechnology,theCollage
Dockcanbelocatedanywhereinahomewherethere’s
anACoutlet!
• CollageDockallowstheintegrationofaniPodasan
audiosourceinaCollagePowerlineMediaandIntercom
system
• Docksuppliesinformationaboutthesong,artist,album,
genreandplaylisttotheCollageAmplifiedKeypad
screenwhilekeepingtheiPodchargedandreadytogo
NEW! Russound Collage Source Bridge
NEW! Single-Point Speaker for Collage
RD-CSB1
TheCollageSourceandCCTVBridgeallowsyouto
connectlegacyaudioaswellasvideosourcestoaCollage
PowerlineMediaandIntercomsystem.StereoRCAand
S/PDIFdigitalaudioinputs,acompositevideoinput,andan
IRemitterport,theSourceBridgeallowsforconnectionand
controlofCDchangersorCCTVvideocameras.Using
GridcastTMtechnology,theSourceBridgeanditssource
equipmentcanbelocatedanywherenearanACoutlet.
RD-7W51SFT
• Acclaim75.25”SquareSinglepointstereoin-wall/
in-ceilingspeaker,75W
• Magneticgrilleforeasyinstallation!
• 10-75wattsofpowerat6ohms
• 88db2.83V@1msensitivity
• 5.25”polypropyleneDVCwoofer,dual.5”Polyimide
tweeter
• Iso-mountchassisreduceswallvibrationsforbetter
sound
• Angledbaffledirectssoundtowardsthelistener
• Soldindividually
NEW! Russound Stereo Speaker for Collage
Complete 4-Room System Single Source Kit
RD-7W52FT
• Acclaim75.25”squarestereoin-wall/in-ceiling
speaker,75W
• Magneticgrillesforeasyinstallation!
• 10-85wattsofpowerat6ohms
• 88db2.83V@1msensitivity
• 5.25”polypropylenewoofer,1”pivotingsilktweeter
• PatentedIso-mountchassisreduceswallvibrationsfor
bettersound
• Angledbaffledirectssoundtowardsthelistener
• Soldinpairs
RD-AD340
• Kitincludes:
*(1)RD-AH4D4-zonesinglesourcehub
*(4)RD-AK3amplifiedkeypads(nowallplates)
*(1)RD-ALRC2remotecontrol
*(1)RD-15841IRemitters
*(1)RD-APSpowersupply
• In-wallmount
• Whiteandalmondinthebox
Audio/Video
IM Volume Controls
NEW! Russound Collage System
Powerlinemusic,mediaandintercomsystem
Awholenewwaytothinkaboutmultiroomentertainment-thenewCollagesystem
distributesmusicandcontrolthroughoutthehomeusingHomePlugtechnologyover
existingACelectricalwiring.Everyhomeispre-wired!
Collage Amplified Keypad
RD-CAK1
• Listento8millionsongsthruRhapsody(free6-month
subscriptionincluded)plus25,000internetradiostations
forfree
• Featuresahigh-resolutionVGAdisplayforviewing
system,sourceinformation,andCCTVcameras
• Capacitivetouchbuttonsandscrollwheel
• Built-inamplifier,16Watts/channel@8ohms-4ohm
stableso2pairsof8ohmspeakerscanbeused
• InternalFMtuner,alarmclock,sleeptimer,andintercom
withroom-to-roomand“allpage”
• Built-inmicallowsforintercomcommunicationand
roommonitoring
• Modularandscalable;requiresnocentralcontroller
• Availableinwhite,black,andalmond
Collage Media Manager
RD-CMM1
• Bridgespowerlinecarrier(PLC)toLAN
• Broadcasts3independentstreamsofdigitalmusicfrom
alocalareanetworkortheinternettoupto10Collage
AmplifiedKeypads
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
271
#1 Brand in Multiroom Audio*
Innovative. Intuitive. Affordable.
Retrofit is now Retroquick
Experience.
Build on it.
www.russound.com
The Russound Collage power line media and intercom system
uses existing electrical wiring to stream music throughout a home.
Zones can be installed anywhere electrical fixtures are located,
making retrofit installations a breeze and unobtrusive.
More Choices. No Limits.
Anywhere you want.
The heart of the system is the Collage Media Manager.
No bigger than a router, it simply plugs into a standard
electrical outlet. The Media Manager acts as a bridge
between the Collage keypads, home LAN and the internet.
Access network attached music, online music services, and
communicate between keypads. In addition to a built-in FM
tuner, a free 6 month subscription to Rhapsody™ online music
service gives you 4 million songs and three independent streams
of music. For more information visit: www.russound.com
©2008 Russound. *2005, 2006 and 2007 studies by EH Research. All trademarks are the property of their respective owners. Specifications subject to change without notice.
Distributed Audio
Structured Wiring Panel Mount Kit
Russound Advanced
RD-AR340
• Kitincludes:
*(1)RD-AH11inputaudiointerfacehub
*(4)RD-AK3amplifiedkeypads(nowallplates)
*(1)RD-ALRC2learning/pre-programmedremote
*(1)RD-AHP44-zonehubpanel
*(1)RD-15841IRemitters
*(1)RD-APSpowersupply
• Whiteandalmondinthebox
RD-AC560
• Keypad:LCDscreen,2xtheoutput,andbass,treble,and
loudnesscontrol
• 1Uhub:6source/8-zone, IRlibraryforsourcecontrol
usingoptionalRD-AKSCkeypad,paging
support,andalsosupportssystemcommands-
“AllOff”forexample
• Kitincludes:
*(1)RD-AC68controller
*(6)RD-AK5Lkeypad
*(6)RD-8541IRemitters
*(1)RD-ASRC1
Russound Sphere ACA-E5
Russound Sphere Radio Frequency Remote
RD-ACAE5
• Flagshipcontroller/amplifier
• 12sources,8zoneswithvideoswitching,internal
tuner,modulartunerslot,pagingandmutingcapability,
doorbellinterfacewithstrikereleasecapability
• 40Wperchanneloutputinto6zones;zones7&8have
selectablepre-ampoutputs
• NEW!RD-KLKE6Click-wheelkeypadwithcolorscreen
• AvailabletoSphereCertifiedDealersonlysee
www.russoundsphere.comformoredetails
Nowshipping!Advancedsystemremotethatcombinesthe
latestintechnologyandfunctionality.
RD-RFRE5
• Featuresahigh-resolution,grayscalescreenthat
displayssourceinformationandfeedbackfroman
RD-ACAE5MultizoneControllerAmplifier
• Intuitiveclickwheelinterfacetoeasilyscrollthrough
playlists,stations,albumlibraries,andmediacollections
*AvailabletoSpherecertifieddealersonly.
Seewww.russoundsphere.comformoredetails.
Russound Sphere TSV-E5 Touch Screen
Russound Sphere ZXP-E5 Zone Expander
TouchscreeninterfacefortheSphereRD-ACAE5
MultizoneControllerAmplifier.Availableaswallmountor
desktop.
RD-TSVE5
• SingleCAT-5econnection
• FullSMS3control,includingalbum,coverart,theme
anddataediting
• IPCCTVcamerasupport
• Alarmwithsleeptimerandwaketomusic
• Webwidgets(weather,sports,news)
• IRreceiverwithoptionalplasmaresistantIRfilter
*AvailabletoSpherecertifieddealersonly.
Seewww.russoundsphere.comformoredetails.
RD-ZXPE5
TheRD-ZXPE5providessixadditionalaudiozonestoan
RD-ACAE5MultizoneController.Allowsforsystem
expansionwithouttheneedofaddingduplicatecontrollers.
• 6zoneaudiooutputs
• Paginginputandoutput
• RS-232serialport
• 2Uchassis
*AvailabletoSpherecertifieddealersonly
Seewww.russoundsphere.comformoredetails.
ALTX Impedance Matching
Volume Controls
iBridge Dock Kit
Russound iBridge Bay Kit
RD-BGK1
• Canbeinstalledaspartofanyaudiosystem-allowsfor
IRorRNETcontrol
• WithRNETsystems(suchasCAV/CAM6.6),keypads
displaysonginformation,andwiththeRD-UNOS2you
canselectyourmusicasiftheiPodwasinyourhands!
• Dockcanbelocatedanywhereinthehomewitheasy
CAT5connection
RD-BGK2
StreamiTunesfromyourMactoanyRussoundRNET
system!
• CompletesolutionforintegratingiTunesmediafroman
IntelCoreDuoMacdesktoporMacBookwithanRNET
multiroomsystem
• IncludesiBridgeBay,RAVD1RNETA/VDecoder,power
supplyandcables
iBridge Power Dock Kit
CAA66 Controller/Amplifier Kits
UseaniPodasaremotesourceforaRussoundRNET
multiroomaudio-videosystemwithoutnewlongwiring
runs.UsingRNETPowerLineCarrier(PLC)technology,
thePowerDockkittransmitsaudio,control,andmetadata
signalsoverresidential110Vpowerlines.Greatforretrofit!
RD-BGK3
• Kitincludes:RD-BGD2iBridgePowerDock,RD-BGDA
DockAdapterRD-BGCADockControllerAdapter,power
cord,5iPodwelladapters,RJ-45patchcableand
manual
RD-CAA66LAW
• Includes6RD-KPLLCDkeypads
RD-CAA66KAW
• Includes6RD-KP6keypads
Audio/Video
RD-ALTX2 Series
• Freereplacementsondefectiveunitsforlife!
• LegendaryperformancebackedbyRussound’sGold
Guarantee
• Autoformerbasedimpedancematching
(2/4/8Xconfigurations)
• Peakpowerhandlingof126W
• AvailableinbothDecora&standardwallplatesin
5colors
• New!Nowincludes:white,almondandboneinone
package
4-Room Multisource Kit
RD-AM341
• Kitincludes:
*(1)RD-AH4844-source/4-zonehubmount
*(4)RD-AK3amplifiedkeypads(nowallplates)
*(1)RD-ALRC2learning/pre-programmedremote
*(1)RD-ALC3localsourceinput
*(4)RD-845.1singlemicroIRemitters
*(1)RD-APSpowersupply
• Surfacemount
• Availableinalmondorwhite
• 6-zone,6-sourceaudiocontroller
• Built-inIRlibrarywithlearning
• ControllableviaRS-232
• Linkportforconnectiontoadditionalcontrollersand
Russoundsources
• Includesbothwhiteandalmondkeypadfaceplates
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
273
Distributed Audio
CAM6.6 Controller/Amplifier Kit
CAS44 Controller/Amplifier Kits
RD-CAM66S1AW
• (1)6-source,6-zonecontroller,(6)RD-UNOS1keypads
RD-CAM66S2AW
• (1)6-source,6-zonecontroller,(6)RD-UNOS2keypads
RD-CAS44LAW
• Includes4RD-KPLLCDkeypads
RD-CAS44KAW
• Includes4RD-KP4keypads
Audio/Video
• KitsIncludebothwhiteandalmondkeypadfaceplates
• Morekitsavailableinotherconfigurations
• 4-zone,4-sourceaudiocontroller
• ControllableviaRS-232
• Canlinkupto2controllersforan8-zone,
4-sourcesystem
• Kitsincludesbothwhiteandalmondkeypadfaceplates
CAV6.6 Controller/Amplifier Kit
CA4 Multiroom Audio Kit
RD-CAV66S2AW
• Kitincludes:
* (1)6-source,6-zonecontrollerw/audio/video
switching
* (6)RD-UNOS2keypads
* (1)SRC2Remote
* (6)845.1IRemitters
• RussoundRNETsourcesdeliversongtitles,artist,and
othermetadatatokeypads
• Easyexpansionviaandbufferedloopoutputs
• Almondandwhitekeypadplates
CA4MultizoneControllerKitisafour-zone,four-source
multiroomaudiosystematanentry-levelprice.
RD-CA4KT1
• Kitincludes:
*(1)CA4controller
*(4)CA4-KPsystemkeypads
*(4)845.1singleemitters
*(1)CA4-RCSystemremotecontrol
*(1)CA4wallport
*(1)Pairrackears
2-Channel Local Source Switching Amp
2-Channel/Dual Source Amplifier
RD-R235LS
• 35Wx2@8ohms,
50Wx2@4ohms,
100Wx1@8ohmsbridged
• Automaticlocalsourceswitchingwithadjustabledelay
• Built-inprotectionagainstdamagecausedbyshortsand
otherfaults
• Ultra-compactchassisforeasyplacement
RD-R290DS
• 90Wperchannelat8ohms,110Wperchannelat
4ohms,220Wat8ohms,2channelbridged
• Linelevelandspeakerlevel
• Lessthan0.05%THD+Nfrom20Hzto20kHz
• Frequencyresponse20Hzto20kHz±0.3dB
• Weightis17.2lbs.(7.8kg)
Multi-Channel Power Amplifiers
SMS3 Smart Media Server
RD-R850MC
• 4-zone,8-channel
RD-R1250MC
• 6-zone,12-channel
RD-SMS3320
• Newlowerprice!
• 3independentmusicstreams
• PersonalMediaAssistantorganizesyourmedia
automatically
• UserinterfacesincludeTV,webbrowser,andUNO
keypadsviaRNET
• Canalsobeusedwithanyothermulti-room
audiosystem
• NewversionRD-SMS3320features320GBharddrive
andupdatedRAM
• 50Wx2@8ohms,80Wx2@4ohms,
140Wx1@8ohmsbridged(perzone)
• Built-inprotectionagainstdamagecausedbyshortsand
otherfaults
• Autosensinglinelevelinput
• Rackearsincluded(3U)
Family of RNET Dual Tuners
NEW! RNET Touchpoint
RD-ST2
• DualAM/FMtuners
RD-ST2XM
• AM/FMandXMtuner
RD-ST2XM2
• DualXMtuners
RD-ST2S
• AM/FMandSiriustuner
RD-TCH1
TheRussoundRNETTouchpointallowsiPhoneoriTouch
tocontrolRussoundRNETmultizonecontrolleramplifiers.
WorkswiththeRussoundRD-CAV66,RD-CAM66,RDMCAC5,andRD-ACAE5
controlleramplifiers.
Alocalareanetworkandweb-enablediPhone®oriPod
Toucharerequiredforwirelesscontrol.
• AlltunersfeatureRNETwhichdeliversfeedbackincludingstationinfoandmetadatatoUNOkeypads
• ControlledviaRNET,RS-232orIR
274
LPTx Impedance Matching Volume Controls
UNO Smart Color Touch Screens
RD-LPTX
• Newlowerprice!
• Economicalwall-mounted75-wattvolumecontrol
• AvailablewithstandardorDecora®-stylewallplate
• Autoformerbasedimpedancematching
• Peakpowerhandlingof75watts
• Availableinwhite,almondorbone
RD-UNOTS2D
• DesktopModel
RD-UNOTS2W
• WallmountModel
• IntegrateswithanyRNET®controller/amplifier
• 3.75"LCDdisplaysmetadatafromRNETsourceslike
theRD-SMS3,RD-iBridge,andRD-ST2Seriestuners
• Minimalprogrammingrequired
• Availableasadesktopmountor2-gangin-wall
• Desktopavailableinwhiteorblack
• In-wallmodelavailableinwhite,almond,bone,black
orbrown
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Distributed Audio
NEW! Russound C-Series Multizone Kit
RD-KT1C5
Russound’sC-SeriesMultizonekitprovideseightzonesof
distributedstereoaudiofromanyofeightsources.Custom
audiosettings,PartyMode,DoNotDisturb,sourceandzone
linking,andAllOn/Offparticipationarestandardfeatures.
TheRD-MCAC5controllerincludesaninternalAM/FMtuner
withRDS,systemclockwithanalarmandsleeptimers,
HomeTheatertrigger,routedandcommonIRoutputs,
andeight12VDCtriggeroutputs.TheRD-MDKC5Keypads
featuregray-scaleLCDscreensthatdisplayreal-time
informationincludingplaylist,channel,artist,songtitle,
genreandmore.
• Eightinputsourcesdistributedtoeightzones,expandableto48zoneswithadditional
controllers
• 40wattsofdigitalamplificationperchannelonzonesonethroughsix
• Includesprogrammingsoftware
• KeypaddisplaysRDSinformationfromtuner,RNETfeedbackandmetadatafromthe
controlleramplifierin“real-time”
TheRD-KT1C5kitincludes:
• RD-MCAC5MultizoneControllerAmplifier
• SixRD-MDKC5MultilineDisplayKeypads
• RD-SRCC5SystemRemoteControl
VM1 Video Matrix Family
RD-DTS1
• AllowsfordesktopuseoftheC-SeriesMDK-C5Multiline
DisplayKeypad
• AlsofitsSphereKLK-E5&KLK-E6keypads
• Availableinblackorwhite
RD-VM14
• HDcomponentvideoswitchallowsseamlessintegration
withRussoundCAM,CAV,andC-Seriessystems.Can
alsobecontrolledviaRS-232forstand-alone
applications
• Newsoftwareallowsyoutoreconfigureinputsformore
flexibility
• Newfirmwareallowsstackingoftwocontrollers
• VideoiscarriedoverCAT-5ecableupto300’.SinglegangDecorareceivingunitsincluded
• 5modelstochoosefrom,includingmodelswithformat
conversion
WALTx Outdoor Volume Control
D5KPZK DDS Single Zone Amplifier Kit
RD-WALTX2
• Outdoorweatherproofvolumecontrolinself-sealing
grayboxwithconnectionfor3/4"PVCconduit
• Autoformerbasedimpedancematching
(2/4/8xconfigurations)
• UsessameVCcoreasthelegendaryRussound
ALTXSeriesvolumecontrols
• Limitedlifetimewarranty
VO-D5KPZK
• Addbuilt-indigitalmusictoanyroom
• 30WattClass-Ddigitalamplifierbuiltintokeypad
• IncludesD5IPinputplateforlocalaudiosourceand
powersupply
• All-digitalsignalpathfromsourcetoamplifier
• AdjustableEQ(bass&treble),dynamicrangeandloudnesscompensation
• VolumeLevelControl
• OLEDDisplay
• DecoraStylewithgasketforflushfit
D5IP DDS Local Source Input Wall Plate
D5KP DDS Single Source Digital Keypad
VO-D5IP
• Digitalcoaxaudioinputs
• AnalogLeft&Rightaudioinputs
• Audioinputlevelcontrol
• IREmitteroutput
• Decorastyle,fitsintosinglegangbox
• 110punchdownoutput
VO-D5KP
• BuiltInDigitalAmplifier
• SourceSelectionControl
• VolumeLevelControl
• Bass,Treble,balancecontrol
• OLEDDisplay
• BacklitButtonswithtimeoutcontrol
• 30WattDigitalAmp
• DecoraStylewithdecoragasketforaflushfit
D5LR DDS Advance Learning Remote
4 Source 4 Zone Equipment Rack Kit
VO-D5LR
• Programable4Sourcedevice
• Compatiblewithallmajorcomponents
• Pre-programmedwithDDScontrols
• 3IRmacrofunctionbuttons
• Built-inIRcodelibrary
• BatteriesInluded
VO-D5RHK
• DigitalDeliveryAudioSystemUsingDIGI-5Technology
• CompleteMulti-roomAudioPackage
• Controlsupto4Sources
• DistributesAudioto4Zones
• SingleRackSpaceHeight
• SuperBrightOLEDDisplay
Wall Mount Single Source 4 Zone Kit
6 Zone Equipment Rack Expansion Hub
VO-D5SHK4
• DigitalDeliveryAudioSystem
• CompleteSingleSourceMulti-roomAudiopackage
IncludesAllComponentsneeded
• HasWallMountHub
• SuperBrightOLEDDisplay
VO-D5XH
• DigitalDeliveryAudioSystem
• AudioLoop-throughconnectionfrommasterhub
• AudioInputLevelControl
• RS232ControlPort
• Zonepairingforcombiningkeypadsinazone
• Zonepoweroutputforlongdistanceinstallations
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Desktop Stand for Russound MDK Keypad
275
Distributed Audio - Residential Video
D5RHK DDS Audio Distribution System Kit
VO-D5RHK
• Completemulti-roomaudiopackage
• Controlsuptofoursources
• Distributesaudiouptofourzones
• 30WattDigitalAmp
• SuperBrightOLEDDisplay
• StudioSlimDesign-FitsinDecoraPlate
• Contains(1)4x4EquipmentRackHub
• (4)DIGI-5KeypadsPlus(4)MiniRemotes
• (1)110PunchDownTool
D5XH DDS 6 Zone Expansion Rack Hub
VO-D5XH
• AudioLoop-Thruconnectionfrommasterhub
• Audioinputlevelcontrol
• SerialRS232controlport
• IRemitteroutputs
• Zonepairingforcombiningkeypadsinazone
• ZonePoweroutputforlongerdistances
• OptionalRM1UKITrackearsavailable
Audio/Video
8 Source/Zone AV Controller Amp With
Metada
VO-MRC88M
• 8Source8ZoneVideo/AudioDistributionAmp
• Expandableto16zones
• 16routableIRports
• 7linesofmetadata
• Bi-directionalroutableRS232control
• Autotouch-padconfiguration
12-Channel Power Amplifier
with IR Control
VO-PA1235
• 35watts/channel
• Selectablechannelmodes
• IRcontrolledlevel,balance,mute
• LocalorCommonbuss(inputswitching)
• IR&DCvoltagecontrolled
• Lowimpedancecapability
• Autoprotection
• Rackmountable
276
8 Zone/Source Audio Distribution System
VO-MRAUDIO8X8M
• 6-zone70WPC4ohm
• Full8x8matrixswitching
• Expandableto16zonesystem
• 7linesmetadata
• Bi-directionalRS232control
• Autotouchredconfiguration
Six Channel Power Amplifier with IR
VO-PA635
• 35Wattsperchannel(Bridgeable)
• SelectableChannelModes•Adjustableinputsensitivity
• DCVoltagecontrolled(mainpower)
• Lowimpedancecapability
• Rackmountable•AutoProtection
• IRcontrolledlevel,balanceandmute
• LocalorCommonBussInputSwitching
• IRandDCvoltagecontrolled
• RequiresVO-RC68XProgrammerforIRcontrol
• Alsoavailablein230VAC/50Hz
100 Watt Rotary Volume Control
VO-XVCD100
• Powerhandling:100W/channelRMS
• Adjustableimpedancematchingforupto8speaker
pairs(1,2,4,8pairs)
• RoHScompliant
• Almond,black,ivory&whiteDecorainserts&knobs
includedinbox
DVDO EDGE
1080P Home Theater Front Projector
6X-EDGE101
• AwardwinningVRSvideoprocessingtechnologyby
AnchorBayupconvertsallinputsignalstoany
resolutionupto1080p
• 10Videoinputs:6HDMI1.3,2component,1S-video,
1composite
• 5Audioinputs:3optical,1coaxial,1analog
• 2HDMI1.3outputs:1outputforaudio&video,1output
foraudioonly
• SetupwizardsandincludedUniversalRemoteControl
• Eliminates“blackbars”withintuitivezoomcontrols
• Lowlatencyprocessingforgamers
2Q-W6000
• 50,000:1ContrastRatio
• 2500Ansilumensultrahighbrightness
• Nativefull1080presolution
• BrilliantColorTM,DynamicBlackTM
• DualHDMI(1.3)inputs,ISFCCC;HQVTM
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Video
Component HD Audio Video Distribution Amplifiers
7C-AV400COMP
• 1x4HighDefinitionComponentAmp
7C-AV901COMP
• 1x9HighDefinitionComponentAmp
7C-AV901HD
• 1x9HighDefinitionComponentAmp
withdigitalaudioandcompositevideo
7C-AV501HDX
• 1x5HighDefinitionComponentAmp
withdigitalaudioandcompositevideo
7C-AV501HDXi
• Sameas7C-AV501HDXwithisolatedground
CAT5 HD Distribution Products
7C-CAT5TX
• Requires2CAT5cablestodistributeHDuptodistances
of600'.3IRemitterports.(Requires7C-CAT5RX)
7C-CAT5RX
• Requires2CAT5cablestodistributeHDuptodistances
of600'.Builtincableequalization,IRfeedthroughwith
continuityandpolarizationchecking.
(Requires7C-CAT5TX)
7C-C5HDP
• PassiveCAT5Balunfor“onetoone”HDcomponent
distributionwithS/PDIFAudio(Operationrequiresa
balunateachend)
7C-C5T6
• HighDefinitionAudioVideo1x6DistributionHub,rack
mountable,6dualCAT5outputsforextendeddistances.
Componentloopthrough.DiscretepassiveIRremote
feed.(Requiresuseof7C-CAT5RXatotherend)
HDMI Distribution Amplifiers and Extender Kit
7C-HM41SR
• 4x1HDMISelectorSwitch,HDCPcompliant,
automaticsourcedetection,remotecontrol,RS-232
7C-HM6EK3
• 1.3HDMIcompliant
• HDTVresolution
• EaseofinstallationwithCAT5/CAT6
• Savestimeandexpense
HDMI Distribution Amplifiers and Extender Kit
7C-HA43
• 1in4outHDMI1.3distributionamplifier
• EnhancedAmplifiedsignalsforlongercableruns
• Compliantwithv1.3bHDMI/HDCPrequirements
• Supportshigh-resolutiondisplaysofUXGA,480i,480p,
720p,1080i,1080p
• SecureHDMI1.3connectionwithintegratedcable
retentionbracket
• CascadabletomultipleamplifiersforlargeTVdisplays
Audio/Video
7C-HA8
• 1in8outHDMIA/VDistributionAmplifier
• EnhancedAmplifiedsignalsforlongercableruns
• CompliantwithHDMI/HDCPrequirements
• SupportsHDMIconnectionwithintegratedcableretention
bracket
• SecureHDMIconnectionwithintegratedcableretention
bracket
• CascademultipleamplifiersforlargeTVdisplays
VGA Extender Kit
7C-VG5EK
• Adjustableequalizationlength
• AdjustableVGAsignalgain
• Ruggedmetalchassis
• VGAloopoutforlocalmonitoringon7C-VG5ETL
7C-VG5EKL
• ExtendsVGAsignalsmorethan575feet
• EasyinstallationwithCAT5/CAT6
• Savestimeandexpense
Matrix Component High Definition Switching
7C-SW204HD
• ComponentHDAudioVideoMatrixSwitchwith
IRremotecontrol.4inputsto2outputs,discretecodes,
RS-232andUSBcontrol.Rackmountable.
7C-SW404HD
• ComponentHDAudioVideoMatrixSwitch.
4inputsto4outputs,discretecodes,RS-232and
485control.Rackmountable.
7C-SW808HD
• ComponentHDAudioVideoMatrixSwitch.
8inputsto8outputs,discretecodes,RS-232and485
control.Rackmountable.
7C-HS103
• Small1inputx3outputHDMIAutoSwitch.Switches
toactivesourcewithmanualoverrideifneeded.HDCP
compliant.WorkswithXBOX360,PS3,BluRayplayer
andAppleTV.
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
277
Residential Video
HDMI CAT5 Matrix Switch
7C-HSW44C
• HDCPCompliant.Anysourcecanbeshownonany
displayatthesametime.Supports7.1channeldigital
audio.SupportsdefaultHDMIEDIDandlearnstheEDID
ifthedisplays.Switchsourcefromanyremotereceiver
bypushbutton,IR,orRS232.Extendsvideosignalupto
165feetoverCAT5eat1080p.
Audio/Video
Composite Audio Video Distribution
Amplifiers
HDMITM to Cat5 Converter
7C-AV400SV
• 1x4CompositeAudioVideoor“S”videoI/O
7C-AV400
• 1x4CompositeAudioVideoI/O
7C-AV700
• 1x7CompositeAudioVideoI/O
7I-7954NS01
• Designedforeasyset-upandoperation
• AutomaticallycorrectsHDCPandEDIDdataintegrity
• DVICompatible
• AccommodatesHDMI,HDTV480P,720P,1080i,
and1080P
• Compatiblewithcomputerresolutions
VGA,SVGA,XGA,SXGAandUXGA
HDMITM Restorer
HDMITM Tester
7I-7952NS08
• Designedforeasyset-upandoperation;
wallortablemount
• Directcoupledfrominputtooutputofferingmaximum
videobandwidth
• Selfdiagnosesandmonitoringindicators
• DesignedforHDTV480p,720p,1080i,and1080p
7I-7953NS08
• MeasureseachsubcircuitwithintheHDMITM
interfaceanddisplaysapassorfailfunction
• InstallHDMITMandDVIcableswithconfidence
• 9LEDsIlluminatetestingofallninefunctionsofthe
19conductorsoftheHDMITMcable
• Easytouse,justconnecteachsideofthecable
• MaybeusedforDVIcableassemblies,CECLEDwill
remainunlit
HDMITM Line Driver & Diagnostic Unit
Audio/Video Modulators
7I-7956NS08
• Directcoupledfrominputtooutputofferingmaximum
videobandwidth
• Fullbalancedlinetransition-minimizeddifferential
signaling(TMDS)
• Selfdiagnosesandmonitoringindicators
• DesignedforHDTV480i,480p,720p,1080iand1080p
• FourLED-HDMIstatusindicators:
verifiesHotPlug,+5Volts,HDCPandEDID
• AutomaticallycorrectsHDCPandEDIDdataintegrity
CS-3015
• Modulateasingleaudio/videosourcetoacustom
TVchannel
• Distributeantenna/CATVto4locations
• 40MHz-1000MHzforwardonly
• DTVcompatible
CS-3025
• Modulate2audio/videosourcesto2customTVchannels
• Distributeantenna/CATVtofivelocationswith5VIRcontrol
• 40MHz-1000MHzforwardonly
• DTVcompatible
Video Modulators
Video Modulators with Integrated IR
CS-5415
• 1-Channel
CS-5425
• 2-Channel
CS-5435
• 3-Channel
CS-5445
• 4-Channel
CS-5515
• 1-Channel
CS-5525
• 2-Channel
CS-5545
• 4-Channel
• 25dBmVmaximumoutput
• UHF:14-64CATV:65-125(excluding95-99)
278
7C-HSW88C
• HDMI1.2a/1.3ccompliant
• HDCPcompliant
• Allowsanysourcetobedisplayedonmultipledisplays
simultaneously
• Supports7.1channelaudio
• Matrixmastercanswitcheveryoutputchannel
• HDMIinputsbypushbutton,IRremotecontrol,or
7C-RS232
• Extendsvideosignalupto35m(115feet)overCat5e
at1080p
• UHF14-64,CATV65-125(excluding95-99)
• Compatiblewith12Vor5VIRsystems
• RemotelypowerCS-DA550orCS-DA-8200Series
distributionamplifiers,upto75'away
• Localloopoutput•IntegratedIR
Audio/Video Modulator Kits
RF Distribution Kit
CS-5555BID
• Bi-directionalRFdistributionkitwith12VIRsystem
• Contains(1)CS-DA550BIDamplifier,(1)CS-5545modulator,
(3)CS-2100Ainterfaces,(2)CS-2172dual-headIRemitters,
(5)CS-2501DCblockingcapacitors
• DTVcompatible
CS-5555HHR
• High-headroomRFdistributionkitwith12VIRsystem
• Contains(1)CS-DA550HHRamplifier,(1)CS-5545modulator,
(3)CS-2100Ainterfaces,(2)CS-2172dual-headIRemitters,
(5)CS-2501DCblockingcapacitors
• DTVcompatible
CS-5557HHR
• High-headroomkitforantennaapplications
CS-5557BID
• Bi-directionalkitforcablemodemand
pay-per-viewapplications
• RFdistributionkitwith5VIRsystem
• Kitcontains:
(1)CS-DA8200amplifier,(1)CS-5525modulator,
(2)CS-2133IRtargets,(1)CS-2172dual-headIRemitter
• DTVcompatible
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Video
RF Distribution Kit
Component with Audio Distribution Amplifier
CS-5558HHR
• High-headroomkitforantennaapplications
CS-5558BID
• Bi-directionalkitforcablemodemand
pay-per-viewapplications
CS-COMPDA1X3
CS-COMPDA1X8
• Sendonesourceofhighdefinitioncomponentvideo
andanalogordigitalaudiotomultipledisplaysatthe
sametime
• SupportsComponentequipment,suchasDVDplayers,
satellitesettopboxes,andallComponentdisplays
• SupportsHDTV(Component,YPbPr,RGsB)andSD
(Composite,YCbCr)inputsignals
• SupportsHDTVresolutionsupto1080p
• Bothanaloganddigitalaudiooutputsareactive
• RFdistributionkitwith5VIRsystem
• Contains(1)CS-DA8200amplifier,(1)CS-5545modulator,
(3)CS-2133IRtargets,(2)CS-2172dual-headIRemitters
• DTVcompatible
Component with Audio to HDMI Adapter
Component with Audio Extender
CS-COMP2HDMIAD
• Adapterconnectscomponentvideohometheater
devicestoHDMIcompliantdigitalmonitors
• AdapteralsotakesanalogL+Raudioandencodesit
ontotheHDMIsignalforthefullHDMIvideoandaudio
effect
• SupportsHDTVresolutionupto1080p
• HDMIcompliant
• Includes:5VDCPowerSupply(RegulatoryApprovals
IncludeULandCE),one6'RCAL+Raudiocable,and
one6'Componentcable
CS-COMPCAT5EXT
• ExtendsComponentvideoandaudioupto1000'
(300meters)overasingleCat-5,Cat-5e,orCat-6cable
• SupportsHDTVresolutionsupto1080p
• SupportsanalogL+Raudioandmultichanneldigital
audio(SPDIForOptical)
• Bothanaloganddigitalaudiooutputsareactiveonthe
receiverside
• Includes:Two5VDCPowerSupplies(Regulatory
ApprovalsIncludeULandCE),one6'Componentcable,
andone2RCAL+Raudiocable
RF Amplifier
RF Distribution Amplifiers
CS-DA500A
• 50MHzto1GHzbandwidth
• 18dBfixedgain
• Includesgridmountingearsfor2619rackmountgrid
• Idealforresidentialcablesystemsorasantenna
preamplifiers
• DTVcompatible
CS-DA550HHR
• High-headroomamplifierforantennaapplications
CS-DA550BID
• Forcablemodemandpay-per-viewapplications
• Bi-directionalamplifier
RF Distribution Amplifiers
Extreme CAT-5 Extender for HDMI
CS-DA8200HHR
• High-headroomamplifierforantennaapplications
CS-DA8200BID
• Forcablemodemandpay-per-viewapplications
• Bi-directionalamplifier
CS-HDMICAT5EXT
• ExtendsyourHDTVdisplayupto200'awayfromyour
HDTVsourceusingtwoCat-5,Cat-5e,orCat-6cables
(notincluded)
• Upto200'(60meters)fromthesourceat1080i
• Upto150'(45meters)fromthesourceat1080p
• HDMI/HDCPcompliant
• Includes:5VDCPowerSupply(regulatoryapprovals
includeULandCE)andone6'Mono-LokHDMIcable
Distribution Amplifier for HDMI
4X4 Matrix for HDMI
CS-HDMIDA1X8
CS-HDMIDA2X8
• Sendoneortwosourcesofdigitalhighdefinitionvideo
tomultipledisplaysatthesametime
• SupportsHDMIcompatibleequipmentsuchas
HDcableandHDsatellitesettopboxes,HDDVRs,
HD-DVDplayers,Blu-rayDiscplayers,andothersources
withanHDMIoutput
• OutputismirroredtoeightHDMIdisplays
simultaneouslywhenusedwithHDMItoDVIadapter
• Supportsresolutionsupto1080p,2K,and1920x1200
• HDMI/HDCPcompliant
CS-HDMIMX4X4
• Routesdigitalaudioandhighdefinitiondigitalvideoin
resolutionsupto1080pfromanyoffourHDMIsources
toanycombinationoffourdisplaysthroughthematrix
• Eachsourceisaccessibleforviewingonany
combinationofdisplaysbyselectingitwiththesupplied
IRremote
• Supportsresolutionsupto1080p,2Kand1920x1200
• HDMI/HDCPcompliant
• Includes:24VDCPowerSupply(regulatoryapprovals
includeULandCE),CS-RMT16IRremote
High Definition A/V Scaler for HDMI
S-Video Distribution System
CS-SCALER21080P
• Allowsyoutoupscaleandswitchyourstandard
definitionorhighdefinitionComponentandHDMI
sourcestoresolutionsupto1080p
• SupportsoneComponentsourcewithanalogaudio,
oneCompositeorS-Videosourcewithanalogaudio,
andtwoHDMIsourceswithdigitalaudio
• Easytouseon-screenmenusareaccessiblethrough
theIRremotecontrol
• DVI/HDCP/HDMIcompliantinput:
Operatesupto165MHz(UptoUXGA@60Hz)
• SupportsdigitalHDoutput
CS-SVC10
• Upto1,000CAT5betweentransmitterandreceiver
• S&Compositevideoinputs
• Digital,opticaldigital5.1&analogstereoinputs
• Autoterminationloop-through
• Autoopticaltocoaxdigitalaudioconversion
• IRemitter&RJ-45outputs
• Adjustablepicturecompensationforlengthofwirerun
• 19"rackmountable(1space)
• IncludesCS-SVC10Rreceiver
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
• 2inputsformodulatedsignals
• Outputsforupto8TVs
• 54MHzto1GHzforward
• 5MHzto42MHzreverse(BIDonly)
• Built-inIRengine-5voltIR
• DTVcompatible
• 54MHzto1GHzforward
• 5MHzto42MHz(BIDonly)
• 2inputsformodulatedsignals
• Outputsforupto8TVs
• Built-inIRengine-12voltIR
279
Residential Video
Switchers for HDMI
CS-HDMISW2X2
• SwitchbetweenanytwoHDMIsourcesandoutputto
twodisplays
• OutputsaremirroredtotwoHDMIdisplayssimultaneously
CS-HDMISW2X4
• SwitchbetweenanytwoHDMIsourcesandoutputto
fourdisplays
• OutputsaremirroredtofourHDMIdisplayssimultaneously
CS-HDMISW3X1
• ConnectthreeHDMI1.3Compliantdevicestoonedisplay
• Discretepushbuttonforlocalswitching
CS-HDMISW4X1
• RoutefourHDMI1.3sourcestoonedisplay
CS-HDMISW4X2
• Accessuptofoursourcesfromoneortwodisplays
• OutputsaremirroredtotwoHDMIDisplayssimultaneously
• Allmodels:
*Supportresolutionsupto1080p,2Kand1920x1200
*SupportHDMIcompatibleequipmentsuchasHDcable
andHDsatellitesettopboxes,HDDVRs,HD-DVDplayers,
Blu-rayDiscplayers,andothersourceswithanHDMIoutput
S-Video Stereo Modulators
Remote-Free 4-Port HDMI Switch
CS-SVM22
• 2-Channel
CS-SVM24
• 4-Channel
NF-IHDMICE
• HDMIversion1.3a,4-input,1-outputswitch
• Auto-sensesandconnectswhensourceturnson
• 480i,480p,720p,1080i,1080p,&DeepColor
• DVI/HDMIcomputerresolutionupto1920x1200
• Cascadetomake7x1,10x1,16x1,etc.
• IncludesPowerSupply
NF-IHDMI4X1
• Serialportforcomputerandautomatedcontrol
• Adjustabletermination,equalization,pre-emphasis
• TransmitsS-videoorcompositevideo
• MaintainsfullMTSstereosound-integratedIRcontrol
• Compatiblewith12Vor5VIRsystems
• 19"rackmountable(1space)
DirecTV Distribution Equipment - High Definition
UA-WBS41602N
UA-WBS4122F
UA-WBA425F
Audio/Video
MultiswitchesUA-WBS41222FandUA-WBS41602NFprovideuptosixteenreceiveroutletsfor
theDirecTVhighdefinitionsystems
• Compatiblewiththe5LNBKa/KuBandSystems
• Idealforresidentialandcommercialsystems
• Amplifiedforcompensationupto100ftofadditionalcable
Amplifier,UA-WBA125Fcompensatesforupto325ftofcableforthenewDirecTVor
DishNetworksystems
• 4input/4outputmodel(shown)provides25dBofgain
• Availableinsingleinput/singleoutput
280
WideBand Ka/Ku Multiswitches
Dish Network® Distribution Equipment
UA-WBS41602N
• NEWmultiswitchforthe5LNBsystemofferedby
DirecTV
• ThisiscompatiblewithKa/KuBandsatellite
Distributionsystemforsixtoover200satellitereceivers
UA-DMK55124F
• Outletsuptotwelvereceivers
• Optionalterrestrialinput
• Cascadedesignidealforcommercialinstallations
• Mustbeusedwithsystemlaunchamplifier
UA-SLA5530NF
UA-SLA5530NF
• Provides30dBofamplificationandremotepowerto
theLNBs
• ForusewithUA-DMK55124F
Satellite Signal Meter
HDMI over Cat5e/6
UA-SSM2500F
• SatelliteSignalMeterforusewithallorbitalslots
• Upgradesavailableassatelliteschangeorareadded
(freeofcharge)
• Providesidentificationofselectedsatellites
• DisplaysdBlevels,signalquality,C/N,andBER
• Usedforinstallationofsystem,dishalignmentand
troubleshooting
• CompatiblewithDIRECTVandDISHNETWORKsystems
SL-MVEAH010Q
• UsesinexpensiveCat5e/6cabletotransmitvideo&
audioinHDMIformataslargeas1080pupto
196’(60m)
• Transmitsovertwo(2)Cat5e/6cables
• Digitalaudio&videosignalsareamplifiedforsuperior
picture&sound
• Built-inequalizationcircuitryeliminatesfeedback&
interference
• ConformstoHDMI1.3&HDCP1.1standards.
• 5VDCpowersupplyincluded
1x4 HDMITM Splitter: 1 Source to 4 Display
3x1 HDMITM Switcher: 3 Sources to 1 Display
VO-HDMI1X4
• ConnectonevideosourcetouptofourHDMIdisplays
• Allowssimultaneousdisplay
• HDresolutionsupto1080p
• HDMITM1.3compatible
• HDCPcompliant
VO-HDMI3X1
• SwitchbetweenanythreeHDMI™sources
• IncreasedHDMIrange
• HDresolutionsupto1080p
• DiscreteIRcodesforallfunctions
• HDMI™1.3compatible
• HDCPcompliant
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Video - Residential Accessories
4x4 HDMITM Switcher: 4 Source to 4 Display
Point-to-Point HDMITM & IR/CAT5 Extender
VO-HDMI4X4
• SwitcheasilybetweenanyfourHDMI™sources
• Distributesanyofthefourinputstoanycombinationof
thefourHDMI™outputs
• HDMI™1.3compatible
• HDresolutionsupto1080p
• IRRemoteandrackearsincluded
• SerialRS-232controllable
• HDCPcompliant
VO-HDMIC5IR
• TheXantechPoint-to-PointHDMICAT-5Extender
increasesthedistanceofyourHDTVdisplayupto120'
awayfromyourHDTVsourceusingtwoCAT-5cables
• Automaticcompensationcorrectsskewanddelay,
aplug-and-useinstallation
• IRreceiverandemittercompatible;
ControlHDcomponentsfromaremotelocation
• Supports1080p,1080i,and720presolutions
Point-to-Point HDMITM/CAT5 Extender
HD Video and Digital Audio Extenders
VO-HDMIEXTEN
• ExtendsHDMIsignalsupto200'fromthesourceat
1080i(150'for1080p)overCAT5cable
• Eliminatesequipmentnoiseintheviewingenvironment
• Supportsresolutionsupto1080p
• Audioandvideoaretransmitteddigitallyoverthe
CAT5cableforzerosignalloss
• HDMI™1.3compatible
• HDCPcompliant
• Alsoavailableinin-wallDecoraStyle
VO-HDTXSG01
• SendsHDvideoanddigitalaudioupto1000'overCAT5
wiretoaVO-HDRXSG01
• Noadjustmentrequiredwhenusedwiththe
VO-HDRXSG01receiver
VO-HDRXSG01
• Receiverautomaticallycompensatesforwirerunlength
aswellascablequalityforsimple,fool-proofinstallation
• ReceiverforusewithVO-HD44CC5orVO-HDTXSG01
transmitter
4-Zone/Source HD Video Distribution CAT5
HD88CC5 8X8 HD Switcher with CAT5
VO-HD44CC5
• TheVO-HD44CC5HighDefinitionComponentVideo
MatrixSwitcher,allowshighdefinition1080ivideoand
digitalaudiotobesentupto1000'overCAT5cablewith
virtuallynolossinsignalquality
• Four-Source,Four-ZoneHighDefinitionmatrixvideo
switcher
• ComponentvideoinputsandS/PDIFdigitalaudioinputs
foreachsourcecomponent
• FourRJ-45outputsforHDvideoanddigitalaudio
distributionupto1000'overCAT5wire
VO-HD88CC5
• 8Source8ZoneHighDefMatrixVideoSwitcherwithSD
VideoCapability
• BufferedComponentVideoloop-thruandserialport
expansioncapablity
• ComponentVideoandS/DIFDigitalAudioInputsforeach
sourcecomponent
• 8RJ45outputsforHDVideoandDigitalAudio
Distributionupto1000’overCAT5
• 8CoaxComponentVideo+8S/DIFDigitalAudio
Outputsfordistributionuptp250’
• ControllablethroughIRandRS232commands
Integrated Doc for iPod
HDMI Digital A/V Assemblies
VO-XIS100
• HiResolutionVideo
• RS232andIRControllable
• ComponentVideoOutput
• OnScreenMenuDisplay
5B-HD2001
• 1meter,goldconnector,1080P/1080Iverified
5B-HD2002
• 2meter,goldconnector,1080P/1080Iverified
5B-HD2003
• 3meter,goldconnector,1080P/1080Iverified
5B-HD2004
• 4meter,goldconnector,1080P/1080Iverified
5B-HD2007
• 7meter,goldconnector,1080Iverified
• Bothtransmitterandreceiverseasilymountinasingle
gangJ-box
Component Video Baluns
Multi-Channel Active Receivers
GE-TRBRGBPT
• Componentvideobalunwithpigtailsforeaseof
connection
GE-TRBRGBPTDA
• Componentvideobalunwithdigitalaudiocapability
GE-AH16PRJ45BNC
• 16channelactivereceiverhub
GE-AH8PSTTBNC
• 8channelactivereceiverhub
• 1CATversus3coax
• Goodto500feet
• EliminatecostlyandconfusingRGBcoaxcabled
connectorsandterminationtools
External Infrared Remote Sensor
JB-HE1000A
• Idealforusewithremote-controlledproductshidden
insidecabinets
• CompatiblewithHarmanKardon®orotherproductswith
“IRRemoteIn”jack
• Includespowersupply,connectingblock&connecting
cable
Audio/Video
• Verified1080p,category2,ver1.3b
• Goodto8,500feet
• Built-intransientprotection
• Verylowcost
TOSLink Cable
7I-7801NS01
• 1meter
7I-7802NS01
• 2meter
7I-7804NS01
• 4meter
7I-7806NS01
• 6meter
• PlasticFiberOpticCable
• GoldPlattedTOSLinkConnector
• PEInsulation•Abrasionresistantjacket
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
281
Residential Accessories
HDMITM - Digital A/V Cable with
7I-7G00NS08
• MaletoMale.5meter
7I-7G003P08
• MaletoMale.5meter3pack
7I-7G01NS08
• MaletoMale1meter
7I-7G0I3P08
• MaletoMale1meter3pack
Technology
7I-7G02NS08
• MaletoMale2meter
7I-7G023P08
• MaletoMale2meter3pack
7I-7G03NS08
• MaletoMale3meter
7I-7G05NS08
• MaletoMale5meter
7I-7G07NS08
• MaletoMale7meter
7I-7G10NS08
• MaletoMale10meter
7I-7G12NS08
• MaletoMale12meter
7I-7G15NS08
• MaletoMale15meter
HDMITM - Digital A/V Assemblies Male to Male
7I-7000NS08
• .5meter
7I-70003P08
• .5meter3pack
7I-7001NS08
• 1meter
7I-70013P08
• 1meter3pack
7I-7002NS08
• 2meter
7I-70023P08
• 2meter3pack
7I-7003NS08
• 3meter
7I-7005NS08
• 5meter
7I-7007NS08
• 7meter
7I-7010NS08
• 10meter
DVI-Digital Video Assemblies
7I-7101NS01
• DVIMaletoMaleCable1meter
7I-7102NS01
• DVIMaletoMaleCable2meter
7I-7103NS01
• DVIMaletoMaleCable3meter
7I-7201NS01
• DVIMaletoHDMITMMaleCable1meter
7I-7202NS01
• DVIMaletoHDMITMMaleCable2meter
7I-7203NS01
• DVIMaletoHDMITMMaleCable3meter
7I-7901NS01
• PonyTailAdapterDVIMaletoHDMITMFemale
7I-79013P01
• PonyTailAdapterDVIMaletoHDMITMFemale3pack
7I-7902NS01
• PonyTailAdapterDVIFemaletoHDMITMMale
7I-79023P01
• PonyTailAdapterDVIFemaletoHDMITMMale3pack
Crystal Series Assemblies
Audio/Video
Analog Assemblies
7I-7301NS01
• MaletoMaleRCADigitalCoaxCable1meter
7I-7302NS01
• MaletoMaleRCADigitalCoaxCable2meter
7I-7303NS01
• MaletoMaleRCADigitalCoaxCable3meter
7I-7405NS01
• MaletoMaleRCASubwooferCable5meter
7I-7410NS01
• MaletoMaleRCASubwooferCable10meter
7I-7501NS01
• MaletoMaleRCAAudioCable1.5meter
7I-7503NS01
• MaletoMaleRCAAudioCable3meter
Analog Assemblies
7I-7601NS01
• MaletoMaleRCAComponentVideoCable1meter
7I-76013P01
• MaletoMaleRCAComponentVideoCable3Pack1meter
7I-7602NS01
• MaletoMaleRCAComponentVideoCable2meter
7I-76023P01
• MaletoMaleRCAComponentVideoCable3Pack2meter
7I-7603NS01
• MaletoMaleRCAComponentVideoCable3meter
Home Theater and Audio Wallplate
LV-AEHTK000
LV-AEMRK000
• Convenienceofready-madeplatewithpre-configured
wiringterminations
• High-Quality“audiophile-grade”connectors
• TwoQuickPortopeningsforaddingotherconnectors
• Designedforeasyinstallationofcables
• AEHTKaccommodatesfrom5.1to7.1channel
surround-sound
282
7I-76033P01
• MaletoMaleRCAComponentVideoCable3Pack3meter
7I-7703NS01
• MaletoMaleBNCRGBHVVideoCable3meter
7I-7705NS01
• MaletoMaleBNCRGBHVVideoCable5meter
7I-7710NS01
• MaletoMaleBNCRGBHVVideoCable10meter
7I-7715NS01
• MaletoMaleBNCRGBHVVideoCable15meter
Leviton/Spec-Grade SoundTM
Pre-Construction BracketsTM
LV-PCC55KIT
• ForLV-SGC65in-ceilingspeaker
LV-PCI65KIT
• ForLV-SGI65in-wallspeaker
LV-PCI80KIT
• ForLV-SGI80in-wallspeaker
• Pre-constructionbrackets
• Designedtosavetimeduringtherough-inand
trim-outphases
• Built-inwiremanagementloops
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
weʼve got the cure
Honeywell’s Self-Diagnostic Cable.
Your Prescription for Success.
Relief is on the way with the industry’s only patented self-healing HDMI
cable with CURE Light Technology. Thanks to a unique, embedded
line driver designed to detect and “cure” problematic loading and
communication issues, you can count on our cables to monitor and
provide instant feedback on Hot Plug Detect, 5 Volt Line, EDID and
HDCP status.
The prognosis? You’ll reduce installation costs while delivering the
superior format and brilliant, crystal-clear resolution your customers
deserve. It’s your prescription for success!
For more information, please visit www.honeywellcable.com
© 2009 Honeywell International Inc. All rights reserved.
Residential Accessories
Component Video/Analog Audio Balun
Active VGA Balun II Kit
5M-500052
• HDcomponentvideoandcombinedleft/rightaudioover
oneCat5e/6cable
• Supports480i/p,720p,1080i/presolutions
• Supports480i/pupto1,000ft(305m)viaCat5e/6
• Supports720p/1080i/pupto500ft(152m)viaCat5e/6
• Mouldedcolour-codedRCAcableleads
• Supportsanalogaudioonfourthtwistedpair
• ModularshieldedRJ45connector
• Manufacturer’slifetimewarranty
5M-500140
• VGAoverCat5E/6
• Upto600ftviaCat5e/6@1920x1440/1080p
• Remotepowerpass-thruupto150ft(46m)
• DDC1/DDC2(Plug-and-Play)Compliant
• Manualgaincompensationandlocalmonitorout
• IncludesTx,Rxandtwo(2)12VDCPSU
• SupportsVGAorRGB/YPbPr
• Idealforplug&plugimagingsystemssuchasdigital
signage,medical,videowalls,DVRextension
Stereo PC-Audio Balun
HDMI Econo Extender Kit
5M-500030
• ConvertslinelevelanalogaudiotoCat5E/6
• ConnectstoPC/serversoundcardsvia3.5mmplug
• Eliminatesadditonaladapters
• Workswith5M-500027andotherMuxLabaudiobaluns
• Upto5,000ftviaCat5E/6
5M-500400
• Extendone(1)HDMIconnectionviaCat5E/6
• Upto100ft(30m)@1080pviaCat6*
• Upto200ft(60m)@1080iviaCat5e
• Connectviatwo(2)Cat5ecables
• Compactdesign
• SupportsDeepColorupto1080i
• IncludesTx,Rxandone(1)12VDCPSU
Small Flat Panel Cantilever Mount
Medium Flat Panel Cantilever Mount
3O-17ARMB
• Black
3O-17ARMS
• Silver
3O-37ARMB
• Black
3O-37ARMS
• Silver
• Optimumviewing:swivel,pan,tiltandarticulation
• 30lbs.(13.6kg)maximumweightcapacity
• Lowprofiledesignfoldsflatagainstwall
• IncludescompleteGrade5hardwarekitand
• VESAcompliant:75/100
Audio/Video
Medium Flat Panel Fixed Mount
3O-37FBFB
• Black
3O-37FBFS
• Silver
• Liftn’LockTMforeasyinstallation
• 80lbs.(36.3kg)maximumweightcapacity
• Slidinglateralon-walladjustment
• Openarchitecturefortrimout
• UniversalandVESAcompliant:75/100/200
• IncludescompleteGrade5hardwarekit&security
hardware
Medium Flat Panel Cantilever Mount
3O-37HDARMB
• Black
3O-37HDARMS
• Silver
• Liftn’LockTMforeasyinstallation
• 80lbs.(36.3kg)maximumweightcapacity
• Portraitorlandscapeviewing
• Integratedcablemanagement
• Optimumviewing:swivel,pan,tiltandarticulation
• VESAcompliant:100/200
• Incl.completeGrade5hardwarekit&installtemplate
48 Articulated Retractable Mount
54 Fastback Tilt Mount
3O-48ARMUAB
• Black
3O-48ARMUAS
• Silver
3O-54FBTB
• Black
3O-54FBTS
• Silver
• Liftn’LockTMforeasyinstallation
• 125lbs.(56.7kg)maximumweightcapacity
• Lowprofiledesignfoldsflatagainstwall
• Lateralarmadjustment•Built-inscreenleveling
• Incl.18"&25"universalmountingrailstofitthewidest
varietyofflatpanelsizes•UniversalandVESAcompliant
• Double-studmounting•Incl.completeGrade5hardware
284
• Optimumviewingswivel,pan,tiltandarticulation
• 80lbs.(36.3kg)maximumweightcapacity
• Lowprofiledesignfoldsflatagainstwall
• Built-inscreenleveling
• VESAcompliant:75/100/200
• IncludescompleteGrade5hardwarekit
• Liftn’LockTMforeasyinstallation
• 175lbs.(79.4kg)maximumweightcapacity
• Fitsmost37"-60"flatpanels
• Tiltsupto+15°•Slidinglateralon-walladjustment
• Double-studmounting•Openarchitecturefortrimout
• UniversalandVESAcompliant:75/100/200/400
• IncludescompleteGrade5hardwarekit
Heavy Duty Floor Rack System
63 Fastback HD Tilt Mount
3O-RSF
• Productshipscompletelyassembled,arrivesasshown
• StandardEIA19”rackenclosureworkswithallstandard
19”rackaccessories
• Includes:(1)30spacerack,(4)2Uspaceshelves,(1)5U
spaceshelf,(5)2Uspaceventedblanksand(5)cable
lacingbars
• Supportsupto1,000lbs(453.6kg)
• Casterbaseprovideseasyplacementinsideclosetsor
againstwalls
• Integratedcablemanagementchannelsforroutingup
to3”bundles
3O-63FBHDTB
• Black
3O-63FBHDTS
• Silver
• Liftn’Lock™foreasyinstallation
• 200lbs.(90.7kg)maximumweightcapacity
• Tilts-5°to+15°•Slidinglateralon-walladjustment
• Double-studmounting•Lockingsystemforaddedsafety
• Incl.completeGrade5hardwarekit&installtemplate
• UniversalandVESAcompliant:400x600
• Includesextensionrodsandrailsforlargepanels
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Accessories
Tilt Low Profile Flat Panel Wall Mount
63 HD Articulated Retractable Mount
3O-LPHDXT
• Atop-of-the-linetiltmountthatbringsyourx-large
flatpanelevenclosertothewall:
• Ultralowprofiledesign•Liftn’Lock™foreasyinstall
• Built-inkickstandallowsforeasywiringaccess
• IncludescompleteGrade5hardwarekit
• Includesinstallationtemplate&securityhardware
• Slidinglateralon-walladjustment
• Openarchitecturefortrimout
• Lockingsystemforaddedsafetyandsecurity
• Coversconcealmountinghardwareforlagscrews
3O-63HDARMUAB
• Black
3O-63HDARMUAS
• Silver
Universal Projector Ceiling Mount
Pronto Network Extender
3O-PROPJTB
• Legsadjustableto19"diagonallyforsmalltolarge
projectors
• Built-inpitch/tiltadjustmentcontrols
• Universaladjustablemountingpattern
• Tamper-proofhardware
• 40lbs.(18.1kg)maximumweightcapacity
• Easytoinstall
• Availableinblackorsilver
PB-PCX9200
• ExtenderforthePB-TSU9200thatallowsforfull
2-wayPCaudiocontrolforMCE,WindowsMediaPlayer,
iTunes,andVista
• USBInterface(Dongle)
• WillallowusertoBrowsescreenswithintegrated
searchusingmulti-tap
• Willdisplay“NowPlaying”screenincludingcoverart
Pronto Network Extender
Pronto Network Extender
PB-RFX9200
• AllowsforfullIRandnonlineofsightcontrolusingthe
PB-TSU9200
• Wallmountablewithhiddenconnections
• FouraddressableIRports
• DigitalRF,2.4GHzbased
• AddressablefrontIRblaster
PB-RFX9400
• Thiswirelessextenderisacompactunitwith
4addressableIRoutputswithupto16onanetwork
• UniqueProntoprotocolguaranteesbestinclasscontrol
• Willworkwiredorwireless&emitsIRcodesupto1MHz
• Outoftheboxstandalonemodeenablesinstantuse
andincludessmartfeedbackindicatorsforeasy
troubleshooting
Pronto Network Extender
Pronto Home Theatre Control Panel
PB-RFX9600
• DesignedbyInstallers,madebyPhilips
• AdvancedSerialExtendercomesina19"rack
mountableenclosurewithtruemulti-roomcontrol
andreliableoperation
• Offers4addressableIRPorts,4RS-232Ports,
4RelayOutputsand4PowerSensingInputs
• UniqueProntoprotocolguaranteesbestinclasscontrol
• DHCP&fixedIPsupportedforflexiblenetwork
configuration
PB-TSU9200
• ColorScreenRemoteControlwithDockingStation
• ThePB-TSU9200willallowfull2-wayPCaudiocontrol
forMCE,WindowsMediaPlayer,iTunesandVistawith
PB-PCX9200Extender
• Remotewilldisplay“NowPlaying”screenandcoverart
• ProgramsinminuteswithWizardbasedprogramming
usingMyDatabase
• FullIRControlandnon-lineofsightusingPB-RFX9200
Extender
• FullChannelIconLibrary
Philips Pronto Home Theater Control Panel
Pronto Home Theatre Control Panel
PB-TSU9300
Ultra-thinwitha2.8QVGAcolortouchscreenthePronto
TSU9300isahybridoffullfunctionality.Itcanblendinto
practicallyanymoderninteriorwithitsdesignerlooksand
geometricaluminumandblackglossfinishing.
• Highresolution2.8”colortouchscreenwithsuperb
contrast
• Ergonomicdesignforsinglehandedoperation
• Pre-configuredLightingControl
• MusicServercontrolwithintuitiverotarycursor
PB-TSU9400
• Theultra-thinProntoPB-TSU9400featuresastunning
colorscreenidealforpersonalbackgrounds&graphics
• Withbold,aluminum-blackdesignerlooksandwhite
backlitbuttons,it’sultra-cool
• Completelycustomizablewithmulti-roomoperation,
itwillallowfullcontrolofyourA/VEquipment,
A/VServers,Lighting,Heating,Ventilation,
AirConditioningandMusicFilesstoredonyourPC
• Idealforcustomdesignedmulti-roominstallationsoras
partofatotalhomecontrolsolution
Pronto Home Control Panel
Pronto Home Control Panel
PB-TSU9600
• Anintegratedcontrolsolutionforconventionalhome
theater,on-linemultimediacontentandlighting
• The3.7"touch-screendisplayhasanamazing
640x480pixelVGAdisplay,givingitahigherpixel
densitythananycurrenttouch-screenhomecontrolunit
• EasiertoProgram-Theeditorcomeswithbuilt-inwizards
forguidedbasicprogrammingandmacrocreation
• Prontoisproudtointroducefull2-waycommunication,
knownasProntoScript,thisadvancededitingcapability
providesyoulivestatusfeedbackfromtheentiresystem
• ThePB-TSU9600isdesignedtoputyouincontrolof
practicallyeverythinginyourhome
PB-TSU9800
ThesensationallookingPhilipsProntogivesyoucomplete
controlofyourAVentertainment,lightingandmusic
throughoutyourentirehome.
• Cutting-edgedesignwithflush-mounteddisplay
• Ergonomicdesignforbothone-andtwo-handedcontrol
• 6.4"VGAscreenwithsuperbcontrastandvividcolors
• Userinterfacematchingyourpersonaltasteand
preferences
• Controlmultipledeviceswithasingletouch
• Controlhiddenequipmentanddevicesinotherrooms
• Systemfeedbackviadynamic2-wayuserinterface
• Musicservercontrolwithintuitiverotarycursor
• AccessdigitalfilesfromanyWindowsMCEPC
• Liftn’Lock™foreasyinstallation
• 200lbs(90.7kg)maximumweightcapacity
• Dualarmdesign•Double-studmounting
• Dualj-boxopeningsforAVandelectricalconnections
• Integratedcablemanagement•Incl.universaladapter
• IncludescompleteGrade5hardwarekit
• UniversalandVESAcompliant
Audio/Video
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
285
Residential Accessories
SaphIR Kit
7.1 Home Theater Plate
RD-IRJ2
• AllRussoundIRreceiversareCFLfriendly
• Kitincludes:
*(1)RD-862EYEflush-mountIRreceiver
*(1)RD-857IRConnectingblock
*(1)RD-846Cpowersupply
*(4)845.1IRemitters
• AlsoavailableinaPlasmaFriendlyversion:RD-IRJ2P
RD-HTP2
• Heavyduty,ruggedABSplate
• Gold-plated,5-waybindingpostsacceptspins,
spadelugsandsingleordoublebananaplugs
• Fitsstandarddoublegangbox
Addressable RF Base Station
Addressable, Modular RF Base Station
UT-MRF260
• FromUniversalRemoteControl,Inc.
• AdvancednarrowbandRFcircuitryprovideslonger
rangeandimprovedresistancetoRFinterference
• TwofixedlineoutputsforIRemittersandtwoadjustable
(variable)lineoutputs
• Integratedantenna
UT-MRF350
• FromUniversalRemoteControl,Inc.
• AdvancednarrowbandRFcircuitryprovideslonger
rangeandimprovedresistancetoRFinterference
• IncludesdetachedRFReceiver(UT-RFX250)which
enablesflexibilityinplacementforoptimumreception
• AdjustableandbufferedIRoutputsforupto6
componentsenablesquickandtrouble-freeinstallation
forcomponentswithorwithoutrear-panelIRimports
IR/RF Remote Control with LCD
IR/RF Color LCD Remote Control
UT-MX350
• FromUniversalRemoteControl,Inc.
• Agreatcontrolforsimplehometheatresorsimple
whole-housesystems
• Controlsupto10componentslocatedanywhereinthe
homewithoptionalRFbasestation
• Upto5characterlabelingenablesintuitivebuttonnaming
• Crisp,back-litLCDdisplaydeliversoptimumreadability
eveninlowlight
• On-boardprogrammingprovidesprogrammingeasefor
simplesystems
UT-MX450
• FromUniversalRemoteControl,Inc.
• WandstyleIR/RFstand-alone(nonPC-programmable)
• Bright2”colorLCDwithcolorgraphics
• On-screenmacroediting
• NoPCorInternetconnectionrequired
• DatabasecanbeupdatedviaUSBport
IR/RF PC Programmable Remote Control
With Color LCD
IR/RF PC Programmable Remote Control
UT-MX850
• FromUniversalRemoteControl,Inc.
• Customizedcontrolforhometheatersandsystems
withupto20components
• High-capacitymemoryallowsoptimumcustomization
andautomationofhometheatersystemsandsimple
whole-housesystems
• Controlsupto20componentslocatedanywhereinthe
homewithoptionalRFbasestation
• Upto5characterlabelingenablesintuitivebuttonnaming
• Crisp,back-litLCDdisplay
IR/RF PC Programmable Table Top Remote
In-wall Box Adapter
UT-TX1000
• FromUniversalRemoteControl,Inc.
• PCprogrammable,tablet-style,tabletopIR/RFremote
controlwithaddressableRF
• Extralarge,easy-to-readmonochromeLCDdisplay
• Touchscreenandhardbuttoninterface
• Flexiblememoryarchitecture
• From CRAVE and HES dealers only
V8-IWB1
• Holdsmost15”–37”monitors
• UsedinconjunctionwiththeLCD-1ortheLCD-2537
• Fitsinbetweentwo16”centeredwoodenstuds
• Includespaintabledecorativeplasticcover
• Includescableandelectricalknockouts
• Collapsesflushwithfrontface
• Loadcapacity–75lbs
• IncludessilveradaptorsfortheLCDmounts(V8-IWB1B
includesblackadaptors)
Low Profile Projector Mount
19" Equipment Rack - 71" Height
V8-PMLP
V8-PMLPB
• Black
V8-ER1
• Steelconstruction/71"height
• EIAcompliant/mountsupto40devices
• Standard10-32threading/comeswith32rackscrews
• Blackpowdercoatfinish
V8-ER148
• Sameexcept48"heightand27devices
V8-ER184
• Sameexcept84"heightand45devices
• Low2.625”mountingprofile(measurementincludesthe
mountingfeet)
• AdjustableTilt-±20°
• AdjustablePitch-±15°
• AdjustableYaw(Rotation)-360°
• FitsMostProjectorswithmountingholesinside14.5”
diameter
• MastTelescopes23”–35”fromceiling
• FlushMountPlateincluded
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
UT-MX810
• Bright2"colorLCDwithcolorgraphics
• Wizard-styleprogramming,noPCorInternetconnection
required
• Controlsupto24components
• Built-in,updatablepre-programmeddatabaseplus
standalonelearning
287
Residential Accessories
Universal 2 Space Rack Shelf
Mid-Size Flat Panel Flush With Tilt Mount
V8-ERS2U
• Fitscomponentsupto17.375"wide
• Traydepth14.75"
• Includesboth10-32and12-24rackscrews
• Loadcapacity50lbs
• Blackstaticresistantpowdercoatfinish
V8-LCDMIDFT
• Silverpowdercoatfinish
V8-ERS2UV
• Sameasaboveexceptvented
V8-LCDMIDFTB
• Blackfinish
• Holdsmost27"to42"FlatPanels
• MountingrailsadjusttoaccommodateTVswithupto
VESA400x200mountingholes
• Adjustable-5to+15tilt
• Loadcapacity100lbs
• DistancefromwalltobackofTVis2.4"
• Accommodatesdoublegangbox
Wall Mount Electronic Component Holder
IR Ready Kit (for 10 sources)
V8-VH003
• Canbeusedforholdingasinglecomponentor
“stacked”formultiplecomponents
• AccommodatesDVRs,Cable&Satelliteboxes,HD
receivers,andDVDplayers
• Mountingring“tray”extends12”fromthewall
• CanbeusedwithALLTVwallmounts
• Loadcapacity25lbs.
• Blackpowdercoatfinish
VO-IRDY1OKIT
• Everysystemrequiresthesebasiccomponents
• Includes:
*(10)VO-283Demitters
*(1)VO-781ERGPSpowersupply
*(1)VO-79144connectingblock
• IRreceiversoldseparately!
V8-VH003S
• SameexceptSilverpowdercoatfinish
IR Ready Kit (for 4 sources)
VO-IRDY4KTRP
• Everysystemrequiresthesebasiccomponents
• Includes:
*(4)VO-283Demitters
*(1)VO-781ERGPSpowersupply
*(1)VO-78944connectingblock
• IRreceiversoldseparately
Audio/Video
RF to IR Converter for XTR39 Remote
VO-RF2IR
• Completepackageincludes:
*(4)emitters
*(1)powersupply
*(1)RS-232cable
• No morepointingtheremote
• Plasmaproof,LCDproof,WORRYproof
• 100footrange
• 4IRports-1RS-232port
SmartPad3TM Dual Gang Learning Module Kit
VO-PM110RP
• Completein-wallkeypadkitincludes:
*(1)VO-PM110DualGangSmartPad3KeyModule
*(1)VO-MMD6Keypadwithfoursourceselectionkeys,
sixfunctionkeysandonerockervolumecontrolkey
*(1)VO-MMDBlack,AlmondandIvoryBezel
*(1)VO-CMD1Keypadmodulewithsixfunctioncontrol
keys,fourcursornavigationkeys&oneselectionkey
*(1)VO-CMDBlack,AlmondandIvoryBezel
LCD Touchscreen Remote Control
VO-XTR39
• 3.9"LCDtouchscreenremote
• RFtoIRcapable(requiresRF2IR)
• Completelycustomizable
• Cancontrolanyhomesystem
• Outstandingvalue
IR Over Coax Video Cable Kit
Emitter Multi-Packs
VO-17294RP
• EnablesIRcontroloverexistingcoaxcable
• Easilyretrofitsinexistinghomes
• Easytoconnectusingexistingcoax
• Everythingneededinoneconvenientpackage
• XantechXtra-Linkkit
VO-282D10P
• IRDesignerEmitter
VO-283D10P
• Blink-IRTDesignerEmitter
VO-284D10P
• DualIRDesignerEmitter
VO-286D10P
• DualBlink-IRDesignerEmitter
• Saveupto10%on5&10packsofIR&BlinkIR,
Dual&DualBlinkIRMouseemitters
New Designer Series IR Emitters
LCD/CFL Proof Shelf-Top IR Receiver Kit
VO-282TPD
• Twinplugmouseemitterallowscontrolofsinglesource
by(2)IRsystems
• Greatforintegratinghometheaterinmulti-zonesystem
VO-283TPD
• TwinplugBlink-IRmouseemitter
VO-282X
• Noshellemitter
VO-29185DBKIT (Black)
• Completesysteminonepackage
• Includes:
*(1)LCD/CFLProofShelf-TopIRReceiver
*(1)ConnectingBlock
*(1)PowerSupply
*(4)Emitters
• ProprietaryXantechLCD/CFLnoisefiltereliminates
interference
• ExclusiveadjustableIRcarrierfrequency
VO-29195DSKIT (White)
VO-29185DSKIT (Silver)
• Hideemitterinsideequipmentforcleanestappearance
288
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Accessories - Residential Intercom Systems
Shelf-Top Style IR Receivers
Plasma Proof Shelf-Top IR Receiver Kit
VO-29195D
• DesktopstylePlasmaProofstyle
VO-29185D
• DesktopstyleLCDproof
VO-29110D
• DesktopstyleIRreceiver
VO-29195DBKIT - black
• Completesysteminonepackage
• Includes:
*(1)ShelftopPlasmaProofIRreceiver
*(4)Emitters
*(1)Powersupply
*(1)Connectingblock
• ProprietaryXantechPlasmanoisefiltereliminates
interference
VO-29195DSKIT - Silver
VO-29195DWKIT - White
• Choosetherightreceiverforthejob
• UsewithVO-IRDY4KITforacompleteIRsystem
Standard Shelf-Top IR Receiver Kit
LCD/CFL Proof Dinky Link IR Receiver Kit
VO-29110DBKIT
• ThePricePerformanceLeader
• FromtheinventorsofIR
• PerfectforinstallationswithlowlevelIRinterference
• Includesbroadbandshelf-topstyleIRreceiver
• Everythingneededinoneconvenientpackage:
*(1)StandardShelf-TopIRReceiver
*(4)emitters
*(1)powersupply
*(1)connectingblock
• Easytoconnect&install•Black
VO-48085DBKIT
• Black
VO-48085DSKIT
• Silver
Plasma Proof Dinky Link IR Receiver Kit
Peephole Style IR Receivers
VO-48095DBKIT
• Black
VO-48095DSKIT
• Silver
VO-49095D
• PlasmaProofPeepholeIRReceiver
• Includes(3)bezels(brass,black&white)
VO-49085D
• LCD/CFLProofPeepholeIRReceiver
• Includes(3)bezels(brass,black&white)
VO-49010D
• StandardWhitePeepholeIRReceiver
• (3)Bezels(brass,black,whiteincluded)
• LCD/CFLProofDinkyLinkstyleIRreceiverkit
• Completesysteminonepackage
• Includes(1)LCD/CFLDinkyLinkIRreceiver,(4)emitters,
(1)powersupply,(1)connectingblock
• ProprietaryXantechLCD/CFLnoisefiltereliminates
interference
• ExclusiveadjustableIRcarrierfrequency
• PlasmaProofDinkyLinkstyleIRreceiverkit
• Completesysteminonepackage
• Includes(1)PlasmaDinkyLinkIRreceiver,
(4)emitters,(1)powersupply,(1)connectingblock
• ProprietaryXantechPlasmanoisefiltereliminates
interference
• Choosetherightreceiverforthejob!
• UsewithVO-IRDY4KITforacompleteIRsystem
Plasma Proof Peep-Hole IR Receiver Kit
VO-49085DKIT
• Completesysteminonepackage
• Includes
*(1)LCD/CFLProofPeepholeIRReceiver
*(1)ConnectingBlock
*(1)PowerSupply
*(4)Emitters
*(3)Bezels(brass,black&white)
• ProprietaryXantechLCD/CFLnoisefiltereliminates
interference
• ExclusiveadjustableIRcarrierfrequency
VO-49095DKIT
• PlasmaProofpeepholestyleIRreceiver
• Completesysteminonepackage
• Includes:
*(4)Emitters
*(1)Powersupply
*(1)Connectingblock
*(3)Bezels(brass,black&white)
• ProprietaryXantechPlasmanoisefiltereliminates
interference
J-Box Style IR Receivers
DB Series Hands-Free Entry Security
Audio/Video
LCD/CFL Proof Peephole IR Receiver Kit
AJ-DA2DS
• Doublebuttondoorstation
AJ-DA4DS
• 4-buttondoorstation
AJ-DB1MD
• Hands-freemasterstation
AJ-DB1SD
• Hands-freesubmasterstation
AJ-DBS1A
• BoxedsetincludesDA-1DS,DB-1MD,p/s
AJ-PT1211
• PowerSupply
VO-78095
• PlasmaproofstyleJ-boxIRreceiver
VO-78080
• LCDproofJ-boxIRreceiver
VO-78010RP
• StandardJ-boxIRreceiver
• Choosetherightreceiverforthejob
• UsewithVO-IRDY4KITforacompleteIRsystem
Wireless Intercom Systems
O2-OPI
• PortableIntercom
O2-RIFM1LM
• FlushMountIntercom
O2-OTI
• WeatherizedOutdoorIntercom
• CompletelyWireless
• DigitalClarity
• ExceptionalRange
• IntegratedDoor/GateRelease
• AllintercomsactasMasters
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
289
Residential Intercom Systems
Intercom System
MU-DMC10H
• Intercomsystemhub
MU-DMC10RS
• Intercomroomstation
MU-DMC10PS
• Intercompatiostation
MU-DMC10DS
• Intercomdoorstation
MU-DMC10KIT
• IntercomKit,contains:
(1)IntercomHub,(4)RoomStations,&(1)DoorStation
Music/Communication System
Music/Communication System
MU-DMC1
• Masterstation-white
MU-DMC1RS
• Remotescanroomstation
MU-DMC1CD
• Multi-discCDplayer
MU-DMC34
• Retrofitmaster
MU-DMC3RS
• 3-wireroomstation
MU-DMC4RS
• 4-wireroomstation
MU-DMCFM
• Finishoutframemasteronly
MU-DMCFR
• Finishoutframeroomstation
Audio/Video
• CAT5wiring
• Upgradabletostereo
• Privacyfeature
• 30%smallerdesign
Intercom System Package
Expansion Module
NT-NM200K
• Full-functionintercomandmusicdistributionpackage
fornewCAT-5installations
• Includes:
* (1)NT-NM200WH–IntercomMasterStation
* (4)NT-NRS200WH–IndoorRemoteStations
* (1)NT-NPS200WH–OutdoorRemoteStation
* (1)NT-NDB300WH–DoorSpeaker
* (1)NT-NA3003C–ChimeModule
NT-IAA440
• NT-IMA4406SystemComponent
• Providescapabilitytoadduptosixadditionalstationsto
anexistingNT-IMA4406IntercomSystem
Intercom Master Station
IMA-3303WHK Package
NT-IMA3303
• Includesbuilt-inAM/FMRadiowith12memorychannels
• AllCall,DoorTalk,RoomMonitorandVolumecontrol
features
• Dimensions:15-7/16"Wx8-3/16"Hx3-3/8"D
• Useupto13remotestationsand3doorspeakers
• Comesinbrightwhiteandbiscuitfinishes
NT-IMA3303WHK
• Includes:
*(1)NT-IMA3303WH-IntercomMasterStation
*(3)NT-ISA335WH-IndoorRemoteStations
*(1)NT-IS67WH-DoorSpeaker
*(1)NT-IA28-ChimeModule
• Supports3doorpushbuttonlocationsandfeatures
adjustablechimevolumecontrol
Indoor Remote Station
Outdoor Remote Station
NT-ISA335
• NT-IMA3303SystemComponent
• AllCall,DoorTalk,andVolumecontrolfeatures
• Dimensions:6-5/16"Wx8-1/4"Hx1-7/16"D
• ForusewithNT-IR50Rough-Inforrecessmounting
• ForusewithNT-IA60Frameforsurfacemounting
• Comesinblack,sablebrown,biscuitandbrightwhite
finishes
NT-ISA339WH
• NT-IMA3303SystemComponent
• 5"speaker
• AllCall,DoorTalk,andVolumecontrolfeatures
• Dimensions:6-11/16"Wx8-5/8"H
• Includessurfacemountingframe
• Brightwhitefinish
Intercom CD Changer
Intercom Master Station
NT-NC300WH
• White
NT-NC300AL
• Almond
NT-NM100WH
• Full-functionintercomandmusicdistributionsystemfor
3-wireand4-wireretrofitapplications
• Supportsupto13remotestationsin3-wiresystem;15
remotestationsin4-wiresystem
• Includesbuilt-inAM/FMradiotunerwith16memory
channels
• Backlitliquidcrystaldisplayshowsoperationmode,
audiosource,radiofrequency,volumesettingandtime
• Dimensions:161/8”Wx117/8”Hx31/4”D
• White
• Multi-disccompactdiscplayerconnectstoNT-NM200
orNT-NM100‘Master’Station
• Changermountsbelowthe‘Master’andcontainsa6
discslidemagazine
• Playingmodesinclude:Normal,RepeatSong,Repeat
Disc,RandomRepeat,andRandomAll
• NextDisc,PreviousTrack,Play/PauseandNextTrack
pushbuttonscontrolthechangerwhileinplay
290
• Type110punch-downforallroomstationsandhub
• Fitsstandard2-gangbox
• Easy-To-Usefunctions
• ContemporarydesignstationswithblueLEDbacklighting
• Handsfreecommunicationsfromallstations
• Supportsanymixofupto8room,patio,ordoorstations
(Upto16withadditionalhubconnection)
• Roomstationfaceplatesareavailablein4packstomatchanydecor
(white,almondandblack)
• Door&patiostationfaceplatesareavailablein4packs
(white,brightbrass,satin,nickel,andantiquebrass)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Residential Intercom Systems - Commercial Intercom Systems
Premium Video Doorphone Camera
Intercom Master Station
PA-VLGC001AN
• Gold
PA-VLGC001AS
• Silver
NT-NM200WH
• White
NT-NM200AL
• Almond
• Full-functionintercomandmusicdistributionfornew
CAT-5installationor6-wireretofitapplication
• Supportsupto15remotestationsandupto3door
speakers
• Includesbuilt-inAM/FMradiotunerwith16memory
channels
• Backlitliquidcrystaldisplayshowsoperationmode,
audiosource,radiofrequency,volumesettingandtime
• Adjustablepinholecameras
• Illuminatedbutton
• CompatiblewithPA-VLGM301AorPA-VLGM201A
ComPoint Door Station with Camera
Video Door Intercom Monitor
RD-ISK4
• DesignedtoelegantlyaddvideototheComPoint
intercomsystem
• Includesalow-lightmonochromevideocamerawith
awiderangeofadjustments
• Fitsinfulldepthdouble-gangworkbox@48"
recommendedheight
• AvailableinBrushedChromeorAntiquedBrass
PA-VLGM201A
• 2.5"ColorLCDdisplay
• 5stepbrightnesscontrol
• ShownwithoptionaldeskmountPA-VLGT001A
ComPoint Intercom System
Basic Systems:
RD-ISB4
• 4roomsystemwith1doorstation
RD-ISB6
• 6roomsystemwith1doorstation
Advanced Systems:
RD-ISA6
• 6roomsystemwith1doorstation
RD-ISA62
• 6roomsystemwith2doorstations
• Point-to-pointorwholehousepaging
• UsewithanymultiroomaudiosystemorwiththeRD-ISSPin-wallspeaker
• SystemoffersHands-Freereply,DoNotDisturb,ListenMode
• 2keypads:
*Basic(RD-ISK1)upto6zones
*AdvancedLCDkeypad(RD-ISK2)forupto36zones
• Upto2doorstations(RD-ISK3)withoptionalDoorStrikeRelease(RD-ISDR1)
• DoorstationavailableinBrushedChromeorAntiqueBrassfinish
• Severalotherkitsavailable-allitemsalsoavailableindividually
LEF Series Selective Call System - Master Stations
AJ-LEF5
AJ-LEF3
• 3CallMasterStation,surfacemount
AJ-LEF3C
• 3CallMasterStation,semi-flushmount
AJ-LEF3L
• 3CallMasterStationwithselectivedoorrelease,
surfacemount
AJ-LEF5
• 5CallMasterStation,surfacemount
AJ-LEF5C
• 5CallMasterStation,semi-flushmount
AJ-LEF10
• 10CallMasterStation,surfacemount
AJ-LEF10S
• 10CallMasterStationwithAllCall,surfacemount
Audio/Video
• Intermixmasterstations,subsanddoorstations
uptomaximumcapacityof11stations
• Selectivecallingfromamasterstationwith
hands-freereply
• Call-infromsubsanddoorsactivatetoneandLED
atmaster(s)
• SelectivedoorreleasefromAJ-LEF5,10,10S
• Privacyfeaturespreventseavesdropping
(“N”modelsubstationsandallmasterstations,
excludingAJ-LEF3L)
• Varietyofsubstationsmodelsavailable
• Communicationandcalltonevolumecontrols
AJ-LEF10S
LEF Series Door & Sub Stations
• Varietytochoosefrom
AJ-LESS
• Stainlesssteel,flushmount
AJ-LESS1G
• Stainlesssteel,flushmount,1-gang
AJ-LESSR
• Stainlesssteelw/redmushroomcallbutton,flushmount
AJ-LESSGP
• Goldplated,flushmount
AJ-LSNVPC
• Powdercoatedsteel,flushmount
Weather Resistant Door Stations
AJ-LEDA
• Stainlesssteelfaceplate,flushmount
AJ-LED
• Plasticcover,surfacemount
Inside Sub Stations
AJ-LEA
• Substation,surfacemount
AJ-LEB
• Substation,semi-flushmount
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
291
Commercial Intercom Systems
JF Series Color Video - Enhanced
• Quick&Easytoinstall-only2wires!
• Boxedsetscontaindoorstation,masterstationand
powersupplyforsimpleinstall!
• Keeplockeddoorslocked-identifyvisitorswithout
havingtoopendoor
• No handsettopick-up
• Doorrelease•Compact,attractivedesign
• Extendwarrantybyanadditional1yearwhen
Aiphonewireinstalled
• HID®cardreaderdoorstationavailable(AJ-JFDVFHID)
JF Series Enhanced Boxed Sets
• Boxedsetsfeaturesinclude:
*Picturememorytorecordvisitorsatentrance
*Voicememoallowsuserstorecordavoicememoatmasterstation
*Entrancemessagingtopre-recordmessagesforplaybackondoorstation
®
*Audio/videodoorstationwithHID
embeddedcardreadersavail.(AJ-JFDVFHID)
AJ-JFS2AED
• Includes:Masterstation,AJ-JFDAplasticsurfacemountdoorstationandp/s
AJ-JFS2AEDV
• Includes:Masterstation,AJ-JFDVzincdiecastsurfacemountdoorstationandp/s
AJ-JFS2AEDF
• Includes:Masterstation,AJ-JFDVFstainlesssteelflushmountdoorstationandp/s
GH Series Multi-Tenant Color Video Entry
• TheGHSeriesofferssimple,hands-freetenantstations,
providesunparalledreliability&isbackedbythebest
supportintheindustry
• Upto16entrancepanels,500tenantstationsand
4securitystations
• Modularentrancepanelcomponentsforadded
customability
• Quick&Easyset-up-1pairofwireforaudio,
1pairforvideo
• Easyprogramming
• Alpha-numericdigitaldisplays
• Entrancestationcallscanbeforwardedtoconcierge
stationforscreening
• Hardwiredsystem-NOmonthlyphonebillexpenses!
Audio/Video GH Series Components
AJ-GHVDESA
• Audio/VideoEntrancePanelkitwithDigitalDisplay
AJ-GH1KD
• OpenVoice,colorvideomasterstation
Audio Only GH Series Components
AJ-GHADES
• AudioonlyEntrancePanelKitwithDigitalDisplay
AJ-GH1AD
• Audioonlymasterstation
Additional Components
AJ-GHMK
• SecurityGuardStation
AJ-GFHID
• EmbeddedcardreaderEntrancePanelModule
(ProxPoint®PlusembeddedHID®CardReader)
AJ-GFHIDI
• EmbeddedcardreaderEntrancePanelModule
(iClass®embeddedHID®CardReader)
AJ-GFOP2
• PostalLockEntrancePanelModule
Audio/Video
AX Series Integratable Audio/Video Security
• Addcommunicationtoyoursecuritysystem!
• AXSeriesintegrateswithCCTVsystems,COLinesandAccessControldevices
• Cat-5ewired!
• Upto8masterstations&120remotestations
• PCProgrammableforsystemcustomization
AJ-AX8MV
• Masterstationwithcolormonitor(black)
AJ-AX8MVW
• MasterStationwithcolormonitor
(white-8masters/8doors)
AJ-AX8M
• Masterstation-audioonly(black)
AJ-AX16SW
• 16-callAddonselector(black)
AJ-AXDV
• Doorstation,aluminumdiecast,surfacemount
AJ-AXDM
• Mullionmount,audioonlydoorstation
AX Series All-in-One Door stations
KB Series Color Video System - 3 x 5
ColorVideoDoorStationswithHID®proximitycardreaders
AJ-AXDVP
• Surfacemount,aluminumdiecast
AJ-AXDVFP
• Flushmount,stainlesssteel
Upto3doorstationsand5colorvideoinsidestations
AJ-KB3MRD
• Masterstationwithcolorvideomonitor
AJ-KBDAR
• Videodoorstation,plasticsurfacemount
AJ-KB3HRD
• Substationwithcolorvideomonitor
AJ-KB3SD
• Audioonlysubstation
AJ-PS2420UL
• Powersupply
ColorVideoDoorStationswithStand-Aloneproximitycard
readers(NOAccessControlPanelneeded!!)
AJ-AXDVXP
• Surfacemount,aluminumdiecast
AJ-AXDVFXP
• Flushmount,stainlesssteel
292
AJ-AXDVF
• Doorstation,stainlesssteelflushmount
AJ-AXWAVT
• TransmissioninterfaceunittoconnectanyAXSeries
doorstationtovideoserver
AJ-AXWAVR
• ReceptioninterfaceunittoconnecttoanAXcell
AJ-AX084C
• CentralExchangeUnit(CEU)for8doors,4masters
AJ-AX248C
• CEUfor24doorsand8masters
AJ-AX320C
• Add-onexchangeunitfor32doors
AJ-PS2420UL
• Powersupply
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Commercial Intercom Systems - Central Vacuum
NEW! JK Series Video with PanTilt Zoom
• WidestCameraview!!170°ofviewingarea!!
• Zoominforgreaterdetail
• Doorrelease
• Upto1doorand2insidestations
• Quick&easytoinstall–only2wires!
• PictureMemory
• Nohandsettopick-up
• ColorVideo
AJ-JKS1AED
• Boxedsetincludes(1)AJ-JK1MED,colorvideomaster
stationwithpicturememory,(1)AJ-JKDA,plastic,
surfacemountdoorstation,p/s
AJ-JKS1AEDV
• Boxedsetincludes(1)AJ-JK1MED,colorvideomaster
stationwithpicturememory,(1)AJ-JKDV,zincdiecast,
surfacemountdoorstation,p/s
AJ-JKS1AEDF
• Boxedsetincludes(1)AJ-JK1MED,colorvideomaster
stationwithpicturememory,(1)AJ-JKDVF,stainless
steel,flushmountdoorstation,p/s
AJ-JK1HD
• ColorVideoMonitorSubMasterStation
AJ-JK1SD
• AudioOnlySubMaster
LED Visual (Non-Voice) Nurse Call System
AlphaStatusTM Room Status System
AY-NC110A
• Audible/VisualUL1069listedNurseCallsystem
• Idealforuseinhospital,assistedliving,Doctor’soffices,
andhospicecarefacilities
• MultipleMastercapable,50call-placedL.E.D.’s,Tone
Signal,andToneSilencebutton.
• Twoprioritylevels,expandabletothree.
• Simple,straightforwardwiringandoperation.Small
desktopfootprint.
• Caninterfacetopocketpagers.Workswithalarge
varietyofstaff/patientdevices
AY-ALPHASTATUS
• Simpleyetversatilelowvoltagelightsystemfor
Doctor’soffices,lawoffices,banks,clinics,andmore
• Positivevisualindication/notificationenablingefficient
operationofabusyoffice
• Wallordeskmountedmasterstationsavailablein
white,titanium,orbrown
• Canbeusedtoindicateroomstatus,emergencycall,
orpatient/stafflocation
• Eachsystemrequiresvariouscomponentsdepending
onapplication.Pleasecallforconfigurationassistance.
AlphaEntryTM 3.0 Building Entry System
QwikBusTM 2-Wire LOOP Multi-Unit
Color Video or Intercom System
AY-SWALENTRY3
• Visitorlobbypaneland/orconciergesystem
• Multipleentrance,multiplebuildingcapableandInternet
Programmable
• Feature-rich,multilanguage,touchscreenoperation
withvoiceprompts
• Veryversatile,canbeconfiguredforStandardDialer
TelephoneEntry,NoPhoneBill,mostexistingintercom
systems,orallthree!
• CanbeusedwithQuickBussystemtogiveadditional
buildingcommunicationsandemergencycallfeatures
• Additionalhardwarerequired-Patentpending
AY-VFS1000 Series
• 4"(diagonal)crystalclearColorLCDvideoscreen
• Fullfeaturedsystemforresidentialorcommercial
• Availablewithinternalcommunicationsupto5video
unitsperapartment
• Multipleentrancecapable,canbemixedwith
AY-FS1000audiointercomunits
• Open-voice,hands-freeoperationinSurfaceorFlushmount
• Availableinachoiceofsix(6)decoratorinspired
finishesfromwhiteto24Kgoldplated
Nurse Call Systems
Audio/Video Entry System
Video Door Phone
NL-NL3000
• Blackandwhite
NL-NL3000COL
• Color
SL-DP121Q
• Simple4-wireinstallation•CCDB/Wcamera
• Camerahas6LEDsfornighttimeoperation
• Remotelyunlockgates,doorsfrommonitor
• Camera&monitorturnon&offwithpushofabutton
• Adjustablecontrast,brightness&ringervolume
• Connectuptooneadditionalmonitorand/orcamera
SL-DP121SQ
• Additionalmonitor
SL-DP121CQ
• Additionalcamera
• Upto1000’range,2wiresystem
• Upto6monitorsandupto4doorcamerastationsand/or
indoorceilingcamerasobservationcameraswithaudio
• Dooropeningfunction:selectable12VDC300mAor
non-energizedN/Ooutputs
• 32picturesmemorywithdate/hourstamp
• A/VoutputwithautomatictriggerforA/Vrecordingof
events
Audio/Video
EN-900500
• ToneVisualAnnunciatorsandAVMasters
• VisualandAVRoomPatientStations
• PullCordandPushButtonEmergencyStations
• DomeLights
• CallCords
• DutyandStaffStations
VacuSweep®
HC-1410SS
• StainlessSteel
HC-141001
• White
HC-141010
• Black
HC-1410AL
• Almond
HC-1410IV
• Ivory
• TheVacuSweep®sweepinletvalvemakesiteasyfor
debrisanddirttobequicklysweptandremovedfrom
non-carpetedsurfaces
• Attractivedesignleavesnounsightlygapswhennotinuse
• Rearentrydesignandsculpturedcornersallowsforease
ofinstallationwhendoorisinanopenposition
• Largeopeningfacilitatesacceptanceofmaterialbeing
sweptintovalve
• Fitseasilyinthekickspaceofacabinet,orwithina
2"x4"studwall
• Springloadedwireconnectionsreducetimeofinstallation
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
293
Central Vacuum
Hayden SuperVac
Hayden SuperVac Premier
HC-SV90
• VacTrackelectronicmodule•Forhomesupto12000sq.ft.andover
• 3stage,7.2"motor#117500-12,12amps
• 147"waterlift,103CFM,550airwatts•Washablecartridgefilter
Hayden SuperVac 6000
HC-SV6000
• VacTrackelectroniccontrol•Forhomesofupto7500sq.ft.andover
• 3stage,5.7"motor#116765-00,13amps
• 137"waterlift,100CFM,485airwatts•Re-useablecartridgefilter
Hayden SuperVac 3600
HC-SV3600
• VacTrackelectroniccontrol•Forhomesofupto5000sq.ft.andover
• 2stage,7.2"motor#115334-00,12amps
• 110"waterlift,104CFM,384airwatts•Re-useablecartridgefilter
Hayden SuperVac
HC-SV2400BU
• Forhomesofupto3000sq.ft.andover
• 2stage,5.7"motor#116472-00,10amps
• 106"waterlift,112CFM,404airwatts•Re-useablecartridgefilter
ElectraValve® & ElectraValve® Accessories
HC-1760 Series
• ElectraValve®inletvalve-white,black,almond,ivory
Accessory Kit Selection
HC-317800C
• 12GaugeWire-6'Length
HC-317800D
• 12GaugeWire-14'Length
HC-317800A
• 14GaugeWire-6'Length
HC-317800B
• 14GaugeWire-14'Length
• TheElectraValve®isadirect-connectcentralvacuum
valve,eliminatingtheneedforextraplugsandextension
cordstodriveapowerbeaterbrush
• TheElectraValve®AccessoryKitcontainsanelectrical
cordandplug,mountingplate,plasterguard,and
instructionmanual
• Themouldedwireandplugeliminatestheneedto
connectthevalvetoahighvoltagepigtail
Audio/Video
Hayden Deluxe SuperPack
294
HC-4461GR/IV Series
• 30'CrushproofSuperhose-Gray/Ivory
HC-4491GR/IV Series
• 35'CrushproofSuperhose-Gray/Ivory
HC-4451GR/IV Series
• 30'WireReinforcedSuperhose-Gray/Ivory
HC-4436GR/IV Series
• 35'WireReinforcedSuperhose-Gray/Ivory
• Includes:
*Deluxe14"PowerNozzle
*MetalWandswithSuperLatch
*DeluxeFloorTool,DeluxeUpholsteryTool,
DeluxeDustingBrush,ToolCaddy,HoseHanger
*Superhose™andtheHaydenpowernozzlewiththe
quickreleaseconvenienceofSuperLatch™
• VactrackinHoseHandleVariation=Addsuffix(LD)attheendofItemNo.
• ReversedCuffVariation=Addsuffix(RV)atendofItemNo.
Quiet Clean Cleaning Set
Quiet Clean Power Unit
4E-CS3000
• Ultraquiet
• 3-positionheightadjustment
• LEDheadlight
• 30'TotalControlhosewithconvertiblecuff
• Quiltedhosesock
• Onboardtools
4E-PU3900B
• SmartMonitor-LCDpanel-intuitiveMaintenanceDisplay
• 640AirWatts
• Homesupto12,000sq.ft.
• Self-CleaningTriumphHEPAFiltration
• 10yearlimitedwarranty
Quiet Clean Power Unit
Starter Cleaning Set
4E-PU3650
• SmartMonitor-LCDpanel-intuitiveMaintenanceDisplay
• 600AirWatts
• Homesupto8,000sq.ft.
• Self-CleaningTriumphHEPAFiltration
• 10yearlimitedwarranty
4B-H100
• Electricpowerbrushadjustsautomaticallytoanycarpet
height
• 30'x1-1/4"crushproof,switchcontrolledelectrichose
• Ergonomicfixedhandlewithcordmanagement
• Attachmentsetincludes*Setofplasticwands*Wall&barefloorbrush
*Rounddustingbrush*Upholsterynozzle
*Crevicetool*Slip-onbrush
*3-toolcaddy*Hoserack
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Central Vacuum
Power Units
Model
Max.HomeSize
AirWatts
WaterLift(inches)
AirLift(CFM)
Max.Amps
Voltage
Capacity(ingallons)
MotorStages
Warranty
4B-H403
Upto3500sq.ft.
500
100"
92
13.7
120
4
1
5Year
4B-H503
Upto4000sq.ft.
540
135"
122
14.3
120
4
2
5Year
4B-H603
Upto8000sq.ft.
540
138"
124
19.5
120
6
2
5Year
4B-H703
4B-H803
4B-H902
Upto8000sq.ft. Upto12,000sq.ft. Upto15,000sq.ft.
590
630
10000
138"
135"
124"
124
125
211
14.5
15.0
13.5
120
120
240
4
7
7
2
2
2
5Year
5Year
5Year
• AllHoneywellPowerUnitscarrya5-yearwarranty!
Select Electric Cleaning Set
Elite Electric Cleaning Set
4B-H200
• 30'x1-3/8"electrichosewithreversiblecuff
4B-H250
• 35'x1-3/8"electrichosewithreversiblecuff
4B-H300
• Electricpowerbrushadjustsautomaticallytoanycarpet
height
• No-slipcoggeddrivebelt•Grayquiltedhosesock
• Easychangereleasedisconnectsthewandfromthe
powerhead
• 30'x1-3/8"crushproof,total-controlelectrichosewith
reversiblecuff•LEDheadlight
• Ergonomicfull-swivelhandlewithintegratedcord
• Premiumattachmentsetincludes*Barefloorbrush*Dustingbrush*Upholsterybrush
*Crevicetool*FineChinabrush*Toolcaddy
• Electricpowerbrushadjuststoanycarpetheight
• Crushproof,total-controlelectrichosewithreversiblecuff
• LEDheadlight
• Ergonomicfull-swivelhandlewithintegratedcord
• Attachmentsetincludes:
*Barefloorbrush*Dustingbrush
*Upholsterynozzle*Crevicetool
Red & Platinum Series
Power Unit Dimensions
• 40"Highx14"Diameter
• Allunitscanbeexhaustedtotheoutdoors
• AllunitsareULandUL-CanadaListed
• ShippingcontainersexceedallISTApackagingstandards
• CFMismeasuredat2"openorifice,
waterliftisatsealedcondition
Standard Electric Accessory Package
MU-VM1200S
• Low-voltagecrush-proofswivelhosewithon/offswitch
(MU-V400S)
• Air-driven12"turbocarpetbrush(MU-VM179B)
• Deluxehorsehairtools
• Telescopicwand
• Hoserack&clothcaddybagfortools
MU-VM2200DS
• Crushproof,direct-connectswivelhosewithon/offswitch
(MU-V510PS)
• Deluxe14"self-adjustingelectriccarpetbrushwith
headlight(MU-VM458)
• Deluxehorsehairtools
• MU-VMTC-thetelescopicwandwithcordmanagement
adjusttofityou
• Hoserack&clothcaddybagfortools
Deluxe SuperSystem Accessory Package
Platinum Series (Disposable Bag)
MU-VM4200DS
• Deluxedirect-connectcrush-proofhi/lowvoltage
swivelhosewith3-positionswitch(MU-V610PS)
• Deluxe14"self-adjustingelectriccarpetbrush
withheadlight(MU-VM458)
• MU-VMTC-thetelescopicwandwithcordmanagement
adjusttofityou
• Hoserack&clothcaddybagfortools
• Deluxehorsehairtools
MU-AVP3000
MU-AVP12000
MU-AVP7500
MU-AVP24000
• Unitfeatures:
*Highefficiency,2-stagefiltration
*Highairwattratingwhilemaintaininglowoperatingnoise
*Powerunitexhaustsoutsidelivingareasodirtdoesnot
recirculate
*Hosecanplugdirectlyintovacuumatportforlocalcleaning
• 4-colorsegmenteddisplayshowsbagdebrislevel
• 2-colorstatusindicatorshowspower&motorlife
• Slide-gatecollarbag•10yearwarranty
Red Series (Bagless)
Central Vacuum Retractable Hose
MU-AVR3000
MU-AVR12000
MU-AVR7500
MU-AVR24000
• Powerindicator
• Baglessdesignwithdebrisbucket,nobagtoreplace
• Unitfeatures:
*Highefficiency,2-stagefiltration
*Highairwattratingwhilemaintaininglowoperatingnoise
*Powerunitexhaustsoutsidethelivingareasodirt
doesnotrecirculate
*Hosecanplugdirectlyintovacuumatportforlocalcleaning
• 5yearwarranty
NT-VXCHV2
• 11’hoseextendstoprovide30’ofcleaningreach
• On/offpowerunitswitchonthehandle
• Hosequicklyretractswithapushofthebutton
• Reducesthespaceneededforstorageby60%over
traditionalhoses
• *ForusewithNuTone®VXSeriesPowerUnitsonly
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Air-Driven Turbo System Package
295
evolutionary design
Now available with an exciting new look and the latest features!
The new H750 and H850 central vacuum units...complimented
with the new H400 cleaning kit.
Now you can offer customers the sleek new design of this power unit with
the deluxe H400 cleaning kit. These units come with the latest features in
vacuuming: an Interactive LCD panel, the Quick Lock Bucket System, and
the internal Triumph HEPA filter. The H400 cleaning kit features a new
premium power brush with 5-level height adjustment, a long-life cogged
belt, an LED headlight and quick release wand.
This new system provides your customers one of the leading central
vacuum systems in indoor air quality!
To learn more about adding profits with Honeywell Central Vacuum Systems,
contact your ADI distributor at 1-800-223-6261 or visit cvac.honeywell.com
© 2009 Electrolux Home Care Products, Inc. All rights reserved. The Honeywell Trademark is used under license from Honeywell International Inc.
Central Vacuum
Six Gallon Bag
NT-CHV1
• 11’hoseextendstoprovide30’ofcleaningreach
• Hosequicklyretractswithapushofthebutton
• Reducesthespaceneededforstorageby60%over
traditionalhoses
• IncludesuniversalconnectorcollarthatfitsNuTone®
inletsandotherstandardwallinlets
NT-391
• Two-plyelectrostaticallychargedfiltermedia
• Capturesparticlesdownto0.10micronat85%
efficiency
• Setofthreebags
• Suggestedreplacementabouttwiceayear
• ForusewithNuToneNT-CV350,NT-CV352,NT-CV353,
NT-CV450,NT-CV653andNT-CV750PowerUnits
• Setofthreebags
Deluxe Electric Power Brush
Eight Gallon Bag
NT-CT600
• With“Easy-Release”wands
• Featuresagitatorwithtworowsoftuftednylonbrushes
andareplaceablebeaterbar
• Dualbrushededge-cleaningwithprotectivebumper
• Overloadresetbutton
• Greenlabelapproved
NT-VX3918
• TeflonlinedHEPAfiltermediaofferstheultimatein
filtrationefficiencyandsuperiorairflowwithminimum
clogging
• FeaturesMicroban®antimicrobialprotectionbag
technology
• Suggestedreplacementabouttwiceayear
• ForusewithNT-VX550andNT-VX1000PowerUnits
Standard Eight Gallon Bag
VXTM Series Power Units
NT-VX3918STD
• Two-plyelectrostaticallychargedmedia
• Capturesparticlesdownto0.10micronat85%
efficiency
• Suggestedreplacementabouttwiceayear
• ForusewithNT-VX550andNT-VX1000PowerUnits
NT-VX475
NT-VX475C
• 475AirWatts,90"WaterLift,114CFM,
forhomesupto4,000sq.feet
NT-VX550
NT-VX550C
• 550AirWatts,130"WaterLift,135CFM,
forhomesupto8,000sq.feet
NT-VX1000
NT-VX1000C
• 1040AirWatts,130"WaterLift,230CFM,
forhomesupto12,000sq.feet
VXCH515* or CH515 Crushproof Hose
VXCH615* or CH615 Crushproof Hose
NT-VXCH515
NT-CH515
• LightweightCurrent-carryingcordedhoseswith
3-positionon/offswitchand6'linecord
• VX™hoseincludesstatusindicatorlight
• WithpatentpendingUniversalhoseendwhichfitsall
NuToneandmostotherstandardinlets
• UsewithNuToneNT-CT600orNT-CT650Powerbrushes
NT-VXCH615
NT-CH615
• Lightweightcurrent-carryingDirect-Connecthoseswith
3-positionon/offswitch
• VX™hoseincludesstatusindicatorlight
• RecommendedforusewithNuToneNT-CI358,NT-CI390
andNT-CI395serieselectrifiedoutlets
• UsewithNuToneNT-CT600orNT-CT650Powerbrushes
*NT-VXCH515forusewithNT-VX550or
NT-VX1000SeriesPowerUnitsonly
*NT-VXCH615forusewithNT-VX550or
NT-VX1000SeriesPowerUnitsonly
VXCK150* or CK150 Air Turbine Kits
VXCK250* or CK250 Air Turbine Kits
NT-VXCK150
NT-CK150
• Includes:
*NT-CK120StandardToolSet
*Crushproofhose:NT-VXCH235*orNT-CH235
*NT-CA130Hosesock
• ForusewithNT-VX550orNT-VX1000Series
PowerUnitsonly
NT-VXCK250
NT-CK250
• Includes:
*NT-CK120StandardToolSet
*Crushproofhose:NT-VXCH235*orNT-CH235
*NT-CT350BTurbinebrush
*NT-CA130Hosesock
VXCK350* or CK350 Deluxe Electric Kits
VXCK355* or CK355 Deluxe Electric Kits
NT-VXCK350
NT-CK350
• Includes:
*NT-CK230DeluxeToolSet
*ElectrifiedCrushproofhose:NT-VXCH515*orNT-CH515
*NT-CT600Powernozzle
*NT-CA130Hosesock
*NT-CT120Cordmanagementwand
NT-VXCK355
NT-CK355
• Includes:
*NT-CK230DeluxeToolSet
*ElectrifiedDirectConnectCrushproofhose:
NT-VXCH615*orNT-CH615
*NT-CT600Powernozzle
*NT-CA130Hosesock
*NT-CT120Cordmanagementwand
*NT-VXCK350forusewithNT-VX550or
NT-VX1000SeriesPowerUnitsonly
Audio/Video
Central Vacuum Retractable Hose
*NT-VXCK250forusewithNT-VX550or
NT-VX1000SeriesPowerUnitsonly
*NT-VXCK355forusewithNT-VX550or
NT-VX1000SeriesPowerUnitsonly
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
297
Commercial Sound
Commercial XM Satellite Audio Receiver
CP400 and CP700 Power Amplifiers
5A-XM100
• Designedespeciallyforretail,restaurant&commercial
environments
• Upto99userprogrammableforcedtuneevents
(dayparting)perday
• Adjustablelineleveloutputforcomponentmatching
• FrontPanelLockout&channelblockingtopreventtampering
• BacklitLCDdisplayssong,title,andartistinformation
• StereoandmonoRCAoutputs
• Availablerack-mountingpanel(2RU)
• Bi-directionalRS-232serialdataport
AT-CP400
• CommercialDuty200W/ch(@70.7V)StereoPowerAmp
AT-CP700
• CommercialDuty350W/ch(@70.7V)StereoPowerAmp
AA120 & AA240 Mixer Amplifiers
100 Series Fixed Rail Cabinets
AT-AA120
• 120Watt,6-channelmixerampwithMOH&VCA
AT-AA240
• 240Watt,6-channelmixerampwithMOH&VCA
AT-14418
AT-14018
AT-13518
AT-12418
AT-12118
• Weldedsidepanelsandfixedrackrails
• Availablein21RUto44RUheights
• 18-1/2"deepand22-5/16"wide
• Shipswithsolidreardoorstandard
• Constructedwith16ga.CRS
• Includesbase,toppanel,sidepanels,mountingrails
Audio/Video
• These6inputunitsfeatureextensivemutingandoutput
optionsalongwithaveryuniquebridgein/outfeatureto
allowcombiningofmultipleamplifiersinballroom
applicationswithouttheneedforexternalrelays
• VCAcontrolisincludedwhichmaybeassigned
totheBGMinputorgloballyfortheentireamplifier
• 2highqualityinternaltoroidaltransformersprovide
isolationin25V,70.7V,100Vstereoor140V/200Vbridge
modeoperation
• 30-positionrearpanelsteppedinputgaincontrols
• TerminalblockandXLRinputs
• Perfectforhighpower/lowcostamplificationneeds
200 Series Adjustable Rail Cabinets
Gangable 500 Series Adjustable Cabinets
AT-24418
AT-24018
AT-23518
AT-22418
AT-22118
• Available21RUto44RUheights
• Adjustablerackrails•Topandbottomaccessareas
• Shipswithsolidreardoor•Constructedwith16ga.CRS
• Includesbase,toppanel,sidepanels,mountingrails,
removablereardoor,flushdoorpullhandle
AT-54425
AT-54025
AT-53525
AT-54430
• Available35RUto44RUheights
• Availablewith25-1/2"depth
(44RUheightalsoavailablein30"depth)
• Perfectforanymulti-rackinstallation
• Innovative&easysidepanelattachment
• Shippedwithflushmounting,removablereardoorwith
lockandadjustablemountingrails
PA601 Power Amplifier
PA702 Pole Mounted Amp
AT-PA601
• 60WattSingleInputPowerAmp
• 1BalancedorUnbalancedInput
• 1UnbalancedLineOutput
• Perfectfordistributedbackgroundmusicsystems
whensimpleamplificationisrequiredwithoutMOHor
advancedmixfunctionality
• LoudnessContourSwitch(+44Bu@100Hzand10kHz)
provideslowfrequencyenhancementforlowlevel
listeningenvironments
• Compactpackagewithsimple,rearmountedRCAI/O
AT-PA702
• 70Wattsperchannel@8ohms
• Provideslocalamplificationtoaprojectorsystem
• PatentPending“throughchassis”polemountingsystem
makesinstallationabreezeandkeepstheampsecure
• Includesinnovativepoleclampsystem
• IncludesaccessoryoutletwithACcurrentsenseto
respondinstantlyfromstand-bymodewhenthe
projectorispoweredonremotely
• Alsoavailableinwhite
• Alsoavailable70V,100Wversion(AT-PA1001G)
AA120M Mixer Amplifier
AT-AA120M
• 120Watt,6-channelmixerampwithmoduleinput,
MOH&VCA
• AtlasSound’sAT-AA120Mispossiblythemostversatile
mixer/amplifieronthemarkettoday
• True3-zonematrixing(main120Woutput,1Woutput
andlineleveloutput),24VDCoutputwithrelaysyncto
themutebus,bridgein/outwithbuiltinrelaycontrol,
(1)industrystandardmoduleinputwithdirecttomix
busordirecttoampassignment,globalorBGMinput
VCAcontrolandmultiplemutebusconfigurationoptions
roundouttheunit’sextensivefeatureset
• TheAT-AA120Misidealforapplicationssuchassound
masking,industrialpaging,retailandBGM,commercial
PA,priorityvolumecontrolapplicationsandhotel
ballrooms/meetingroomsjusttonameafew
AA35 and AA60 Mixer Amplifiers
AT-AA35
• 35Watt,3channelmixerampwithMOH
AT-AA60
• 60Watt,3channellmixerampwithMOH
• TheAA35&AA60,a3inputchannelmixeramplifier
designedfordistributedbusinesspagingand
backgroundmusic(BGM)systems,smalltomedium
speechprivacysystemsandinapplicationswhere
musiconhold(MOH)pluspagingisrequired.
298
• With1microphoneinputand(2)stereolineinputsthe
AA35andAA60willaccommodateavarietyofinput
sourcesincludingpagingmicrophones,CDplayersand
digitalmusicreceivers.
• Adipswitchselectablematrixallowsthecreationofa
zone2mixfromanyoralloftheinputsourcesformusic
ormessagingonholdapplications.25V,70.7Vand8
Ohmoutputsareprovided
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Commercial Sound
Strategy Series In-Ceiling Loudspeaker System
AT-FAP40T
• 4"Ultracompactfullrangesystem,70.7V(1Wto16Wtaps)plus8ohm
(AT-FAP42TBBlackbezel)
AT-FAP42TPR
• 4"Coaxialfullrangesystem,70.7V(1Wto16Wtaps)plus8ohm
AT-FAP42TCPR
• 4"LowprofileenclosureversionofFAP42T(4.25"overalldepth)
AT-FAP62TPR
• 6"Coaxialfullrangesystem,70.7V(2Wto32Wtaps)plus8ohm
AT-FAP82TPR
• 8"Coaxialfullrangesystem,70.7V(2Wto60Wtaps)plus8ohm
AT-FAPSUBPR
• 8"Ceilingsubsystemwithpassivecrossover,70.7V(7.5Wto60Wtapsplus8ohm)
AT-FAP8CXTPR
• IncludesAT-8CXT60driverforhighceilingapplications
• TheStrategySeriesPremium70.7/100V/8Ohmtuned&portedcoaxialceilingspeaker
packageswillsatisfytheneedsofowners,architects,contractors,andconsultantsby
deliveringtrue,highfidelitysoundreproductioninanattractiveandeasy-to-installsystem.
Thesehighperformancesystemsareperfectlysuitedformanybusinessmusicandpublic
addressapplications.Compactprofileenclosuresandawidevarietyofdispersionpatterns
maketheStrategySeriesaperfectchoiceformostanyceilingheight.
Modelsrangefrom4"fullrangeto8"coaxialmodelsplusaveryefficientceiling
subwoofersystem.Allunitsincludemountingaccessoriesforacousticceilingtile.
Optionalnewconstructionringsalsoavailable.Whitebezel&grilles.
Economy Series Ceiling Speaker Package
AT-SD72
• 8",10oz.dualcone,70.7V/25Vtransformer(.25to5Wtaps)
AT-SD72W
• 8",10oz.dualcone,70.7V/25Vtransformer(.25to5Wtaps)
12.75"whitesteelgrille
AT-SD72WV
• 8",10oz.dualcone,70.7V/25Vtransformer(.25to5Wtaps),
12.75"whitesteelgrille,centermounted5Kohmvolumecontrol
AT-GD87
• 8",10oz.coaxialspeaker,70.7Vtransformer(1Wto8Wtaps)
AT-GD87W
• 8",10oz.coaxialspeaker,70.7Vtransformer(1Wto8Wtaps),
12.75"whitesteelgrille
AT-958
• EnclosuresystemforSeries-usewithAT-818RorAT-768E2
Audio/Video
• AtlasSD/GDspeakerpackagesarethenextgenerationof
AtlasSoundhighperformanceconeloudspeakerswithidentical
specificationstotheprecedingCSeriesspeakers.
Thesimilarityinthesonicqualitiesensuresthatcontractors
anddesignerswhohaveworkedwiththeCSeries(AT-C10A,AT-C803A)
inthepastwillknowexactlywhattoexpectwhentheypurchasea
AT-SDorAT-GDpackage.Choosespeaker/transformerassemblyonly
orcompletesystemwithwhitesteelgrilles.AT-SDSeriesalsoincludes
amodelwithgrilleandcentermountedvolumecontrol(AT-SD72WV).
Strategy Series Surface Mount Loudspeaker Series
AT-SM42TPR
• 4"2-waySMsystem,70.7V(2Wto16Wtaps)plus8ohm
AT-SM52TPR
• 5.25"2-waySMsystem,70.7V(1Wto30Wtaps),plus8ohm
AT-SM82TPR
• 8"2-waySMsystem,70.7V(2Wto60Wtaps),plus8ohm
*BforBlack,WforWhite
• Usesurface-mountAtlasSoundSeriesloudspeakersystemsforcommercial,professional
andresidentialapplicationsorwhereversatilityandhigh-fidelitysoundisdesired.These
systemsareidealforindoorandoutdoorinstallation,inmonauralandstereoforegroundor
backgroundmusicsystems,videosystemsinconferencerooms&classrooms,
boutiques/shops,restaurants/cafes,leisure,recreation/sportscenters,andhousesof
worship.Allmodelsareconstructedofweatherresistantmaterials:UV-resistant,talc
impregnated,polypropyleneinjectionmoldedcabinets;polypropyleneortreatedwoofer
cones;powdercoatedaluminumgrillesandallbrasshardware.Amulti-position,C-shaped
mountingbracketisincludedwitheachmodelatnoadditionalcost.Optionalballmount
modelSMballmount-b/wavailableforapplicationswhereconcealedmountinghardware
isrequired.
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
299
Commercial Sound
AP Series High Efficiency Paging Horns
Audio/Video
AT-AP15
• 15Watt,8-ohmpaginghorn
AT-AP15T
• 15Watt,70.7V(1Wto15Wtaps)
AT-AP30
• 30Watt,8-ohmpaginghorn
AT-AP30T
• 30Watt,70.7V(2Wto30Wtaps)
• AtlasSoundAPSeriesdoublere-entrantloudspeakersare
availablein15and30Wattversionsformediumand
high-poweredsounddistribution.25/70.7/100Volt
transformermodelsincludescrewdriver-adjustpowertap
selectionforavarietyofsoundandsignalingapplications.
AllincludetheOmni-Purpose®bracketforvertical/horizontal
positioningandhaveprovisionsforsurface/strapmounting
topillarsandI-beams.Greybakedepoxyfinish.
SR-X Commercial Sirius Radio Tuner
NEAR A-Series Outdoor Speakers
U1-SRX
• SiriusSatelliteTunerwithDayParting
• Day-PartingFeature-Userprogrammabletuning,power
andvolumecontrolevents
• ChannelBlock-Userprogrammablechannellockout
• FrontPanelLockOut-MaintainsRS-232remotecontrol
• TimeZone&DaylightSavingsSetupforAutomatic
TimeShift
• SetupPCSoftware&NetworkControl-Requires
Mini-232E
• AdjustableLine-LevelOutputpermitsconnectiondirectly
toamplifiers
BO-A2T Series
BO-A6T Series
BO-A8T Series
• 8-ohmversions@100,150&175Wmaximum
• 70V(T)versions@16,32,&64Wmaximum
• Coaxialand2-waycapability
• High-precision,high-performancesound
• Long-termpowerhandlingforconstantuse
• Completelyweatherproof,fully-sealedcabinet
• Availableinblack,green,orwhite
Gold Seal Series Amplifiers
M-Class Dual-Channel Power Amplifiers
BO-GS35
BO-GS60
BO-GS100
BO-GS150
BO-GS250
• 7inputs(4MIC,1AUX,1MIC/TEL,1MIC/AUX)
• 4-ohm,8-ohm,25V,25VCT,&70Voutputs
• Dual-function,10-bandgraphicequalizer
• Automaticlevelcontrol
• Thermalandoverloadprotection
BO-M300
BO-M450
BO-M600
• 3modesofoperation
(4-ohmstereo,4-ohmdualmono,or70Vmono)
• 3monopowerlevels(600,900,or1200watts)
• 3stereopowerlevels(300,450,600watts)
• Accepts2inputmodules
• 2:1mixerfunctioninmonomodes
• Back-slopeACvoltagestabilization
• Powersavingsleepmodeforintermittentuse
Cone Speakers
Premier Loudspeakers
BO-MB8TSL
BO-CSD1X2CA
BO-CSD2X2CA
BO-S86T725PG8W
BO-SM1EZ
• Slantedmetalboxspeakerforwallmounting
(BO-MB8TSL)
• BO-CSDspeakersdropintosuspendedceilinggrids
• BO-S86traditionalceilinggrille;greatsound
• EasyInstallBO-SM1EZpiercesceilingtileswithout
cutting
BO-OCS1
• NEARCeilingSpeakerwithhigh-efficiency,fullbass;
off-white
BO-OPS1B
• NEARPendantSpeakerforopenspaceareas;darkgray
BO-HFCS1
• High-FidelityCeilingSpeaker;extendedbassresponse;
off-white
BO-HFCS1LP
• High-FidelityCeilingSpeaker;low-profile;off-white
Telephone Paging Amplifiers
Power Vector Amplifiers
BO-TPU35B
BO-TPU60B
BO-TPU100B
BO-TAMB
• 3inputsonTPUamps(1TEL,1MIC,1AUX)
• 600-ohmbalancedTELinputforpageports&adapters
• Separatevolumecontrolsforeachinput
• Built-innightringer
• 25V,70Voutputs
• BO-TAMBinterfacesphonesystemwithpagingsystem
BO-V35
BO-V60
BO-V100
BO-V150
BO-V250
• 70V,25V,8-ohm,4-ohmspeakerloads
• Accepts8inputmodules
• 4levelsofprioritybetweenmodules
• 11-segmentLEDoutputlevelmeter
• Motorizedmastervolumecontrol
• For16-ohm,70V&100Vsystems
Microphones - Regular & Wireless
BO-HDU250
• ProfessionalHandheldStageMicrophone
BO-HDU150
• HandheldStageMicrophone
BO-HD0100
• HandheldPublicAddressMicrophone
BO-GCU250
• CondensorGooseneckMicrophone
BO-GDU150
• DynamicGooseneckMicrophone
300
BO-WCU250
• ProfessionalOverheadHangingMicrophone
BO-SCU250
• ProfessionalBoundaryMicrophone
BO-UDMS16HH
• WirelessMicrophonesystem
withhandheldmicrophone&UHFreceiver
BO-UDMS16BP
• WirelessMicrophonesystem
withlavalieremic&UHFreceiver
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Commercial Sound
Pro Installation Contractor Speakers - UL Certified
High Quality Low Cost Mixer/Amplifiers
7B-PRI685
• 8"2-wayceilingcanspeaker
7B-PRI685CV
• 8"2-way70V/100Vceilingcanspeaker
7B-PRI665
• 6"2-wayceilingcanspeaker
7B-PRI665CV
• 6"2-way70V/100Vceilingcanspeaker
7B-PRI85SUB
• 8"ceilingcansubwoofer
5C-135MA
• 35Wattswith3Inputs
5C-160MA
• 60Wattswith4Inputs
Commercial Audio Amplifiers
Commercial Audio Mixer/Amplifiers
5C-180A
• 80wattoutputchannel
5C-280A
• (2)80wattoutputchannels
5C-1160A
• 160wattoutputchannel
5C-180MA
• 4inputwith(1)80wattoutputchannel
5C-280MA
• 8inputwith(2)80wattoutputchannels
• 4ohm/25V/70Voutputs
• Remotevolumecontrolcapable
• 3yearnofaultwarranty
• CommonFeatures:
*UniversalWorldwidePowerSupply
*4/8Ohmand70Voltoutputs
*MusiconHoldoutputs
*VoiceActivatedPaging(VOX)
*PreAmpoutput
*3yeartransferablewarranty
• RCAandPhoenixconnectorsoneveryinput
• Bass&trebletonecontrolsoneveryinput
• Micorlineselectable
• Auto-duckingforpaging
• Lineout/amp
• 3yearnofaultwarranty
Crown/JBL 180 MaxPack
5C-180MAX
• 80wattamplifierwithintegrated
• XMRadioreceiver
• XMantennaandremotecontrolincluded
• Tel/Micinputforvoiceactivatedpaging
• Musiconholdoutput
• 4ohm/25V/70Voutputs
• 2additionalaudiosourceinputs
5C-180MAXPAK
• Completebusinessmusicsystem
*80wattamplifierwithintegratedXMRadioreceiver
*(4)JBLProControl1STloudspeakers
• XMantennaandremotecontrolincluded
• Tel/Micinputforvoiceactivatedpaging
• Musiconholdoutput
Commercial Audio Mixers
Six Channel Commercial Audio Amplifier
5C-14M
• 4input/1outputchannel
5C-28M
• 8input/2outputchannel
5C-660A
• Sixinputs,six60Wamplifieroutputchannels
• 2ch-4ohm,4ch-70volt
• VCAremotevolumecontrolcapablewithoptionalVCap
accessories
• Bassandtreblecontrolsoneachinput
• 3yearnofaultwarranty
• Mic/Lineswitchableinputs
• Bass&Trebletonecontrolsoneveryinput
• Autoduckingforpaging
• 3yearnofaultwarranty
DBX ZonePro 640
DBX ZonePro 1260
9D-JBDBX640
• Signalprocessing&sourceroutingforbackground
musicapplications
• 6input/4output
• OnboardDSPprocessing
• GUIandconfigurationwizardforeasysetup
• Input/OutputprocessingincludesEQ,Advanced
FeedbackSuppression,AutoGainControl,compressor/
limiter&delay
• RS-232andEthernetcontrol
• Available(ZC)wallpanelcontrols.
9D-JBDBX1260
• Signalprocessing&sourceroutingforbackground
musicapplications
• 12input/6output
• OnboardDSPprocessing
• GUIandconfigurationwizardforeasysetup
• Input/OutputprocessingincludesEQ,Advanced
FeedbackSuppression,AutoGainControl,compressor/
limiter&delay
• RS-232andEthernetcontrolwithaddressableIP
function
Impedance Meter/Calculated Watts
In-Ceiling Loudspeakers
GO-ZM1
• Measuresimpedancefordistributedsoundor8ohm
systems
• Impedancemeasuredat100,330,1Kand10KHz
• Extremelyaccuratedigitalreadout
GO-ZM1P
• Withoverloadprotectiontopreventdamagefrom
amplifieroutput
JF-24C
• Coaxial4”&¾”tweeter,80W,16ohms
JF-24CT
• 30Wmulti-tap@70V
JF-26C
• Coaxial6.5”&¾”tweeter,150W,16ohms
JF-26CT
• 60Wmulti-tap@70V
Audio/Video
XM Radio Mixer/Amplifier
• Backgroundorforeground
• Wide,smoothcoverage
• Completewithbackcanandtilerail
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
301
Commercial Sound
Subwoofer/Satellite System
JF-50 Series
• Elegantdesignfitsawidevarietyofdecors
• 30Hz-20kHzwide-bandwidthsoundquality
• Monosystemforbackground/foregroundmusic
JF-52
• Ultra-compactsatellitespeakers(forusewith
subwoofer)
JF-50S/T
• 100Wsubwooferwith8”driver&built-incrossover
• Selectable8ohmsor80W@70V
JF-50PACK
• Setcontaining1subwooferand4satellites
In-Ceiling Loudspeakers
JF-24CMICRO
• 8ohms
JF-24CTMICRO
• 8Wmulti-tap@70V
• Backgroundmusic,4.5"wooferand1/2"tweeter,30W
• Shallow4"depth,widecoverage
• Wide,smoothcoverage
• Completewithbackcanandtilerail
Surface Mount Loudspeakers
JF-23
JF-23T
• Mostcompact,3.5"woofer,1/2"tweeter,
50W,8ohm(JF-23)or5W@70V(JF-23T)
JF-25
JF-25T
• Compact,5.25"woofer,3/4"tweeter,
150W,8ohm(JF-25)or30W@70V(JF-25T)
JF-28
JF-C28T60WH
• Highoutput,8”woofer,1"tweeter,
175W,8ohm(JF-28)or60W@70V(JF-28T60)
Premium Surface Mount Loudspeakers
JF-25AV
• Bestfidelity,shielded,5"woofer&3/4"tweeter,
200W,8ohmand70Vselectable
JF-29AV1
• Veryhighoutput,8"woofer&compressiondriver,
300W,8ohmand110W@70Vselectable
JF-30
• Verysmooth3-way,10"woofer,
500W,4ohmand150W@70Vselectable
• SonicGuard®overloadprotection
Theft-resistantInvisiBallmountingincluded
• OutdoorIP-55rated;Allavailableblackorwhite(add-WH)
Subwoofers
JF-19CS
• 8"In-ceilingsubwoofer,8ohm
JF-19CST
• 8"In-ceilingsubwoofer,70V
JF-CNTRLSB2
• Stereo,satelliteoutputs,10"driver,indoor/blackonly
JF-SB210
• Powerhousestereo/monosubwoofer,2x10",800W
Audio/Video
• Availableblackorwhite(add-WH)
• AskaboutJF-MTC210SATcrossoverand
JF-MTC210T70VinputmodulesforJF-SB210
302
Anytime of the day or night
you can place your order,
just log on to …
www.adilink.com
Utility Microphones
VHF and UHF Professional Wireless System
ND-1022071
• ProfessionalBoundaryMicrophone
ND-4000016
• ProfessionalOverheadHangingMicrophone
• AvailableinBlackorWhite(ND-4000016black;
ND-601132white)
ND-1052000
• WPM-1VVHFwirelesspodiummicrophone
• WorkswithEncoreIIreceiver
ND-1042411
• WPM-2UUHFwirelesspodiummicrophone
• WorkswithUHF-3receiver
ND-300080
ND-1042300
• Single-channelEncoreIIVHFandUHF-3systems
• Half-rackreceiverw/dualfoldingfrontpanelantennas
• OperatesineitherVHForUHFbanddependingonmodel
• DigiTruDiversityTMformaxrangeanddrop-outprotection
ND-401XQUAD
• Multi-channel401XQuadRackmountWirelessSystem
• 4VHFWirelesssystemsinoneallmetalchassis
• FrontAntennajacksforeitheron-boardorremoteantennas
• BalancedXLRoutputsoneachchannel
SLX Wireless Microphone
Desktop Gooseneck Microphone
SB-SLX1485
• Automaticfrequencyselectiontolocateaclearchannel
• AutotransmittersetupviaIRlink
• Useupto20compatiblesystems
• SuperiorsoundqualitywithAudioReference
Companding
• Detachableantennas,includedrackhardware
SB-MX418DC
• 18in.shaftlengthforcloseproximitytouser
• Cardiodpickuppatternforgoodsensitivityandfeedback
rejection
• Widedynamicrangeandfrequencyresponse
foraccuratesoundreproduction
• Balanced,outputforincreasedimmunitytonoiseover
longcableruns
• Snap-fitfoamwindscreen
• Attacheddesktopbase
USM Microphone Adaptor
PGX Wireless Microphone
SB-SMX2U
• ConnectsanyXLRmicrophonetoanyUSBcomputer
• PlugandPlayUSBConnectivity
• Useformulti-trackrecordingorPodcasting
• Integratedpre-ampwithMicrophoneGainControl
• Volumecontrolwith1/8”headphonejackforsignal
monitoring
• IncludeszipperpouchandUSBcable
SB-PGX24SM58
• Automaticchannelselection
• Infraredautosetupoftransmitterfrequency
• Simultaneousoperationofupto12units
• LowinterferenceUHFtransmission
• Functionalrangeupto300'
• SuperiorsoundqualitywithAudioReference
Companding
• Durablecarryingcaseincluded
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Commercial Sound
8-Channel Auto Microphone Mixer
Stereo Microphone Mixer
SB-SCM810
• Noise-freemicrophoneselectionthatautomatically
adjuststochangesinbackgroundroomnoise
• Automaticgainadjustmentasadditionalmicrophones
areactivated
• LastMicLock-Oncircuitthatmaintainsambientsound
• Onebalancedmasterlineleveloutput(Phoenixblock
connector)
• PeakoutputlimiterwithselectablethresholdsandLED
indicator
• 8Activebalancedmic-lineinputs(Phoenixblockconnectors)
• Full19”rackwidth
SB-SCM262
• DesignedforRestaurants,Aerobics/HealthClubs,
CorporateTraining,&Classrooms
• Defeatable“ducking”toreducemusicwhena
microphoneisinuse
• TwoXLRmicinputs
• Threestereoinputchannels
• Oneunbalancedstereooutputandonebalancedstereo
mic/lineoutput
• 12Vphantompowerforcondensermicrophones
• Allinahalf-rackchassis
Handheld Vocal Microphone
8" Speaker Combination
with 70/25V Transformer
SB-SM58S
• Frequencyresponsetailoredforvocals
• Uniformcardioidpickuppatternminimizesbackground
noise
• Pneumaticshock-mountsystemcutsdownhandlingnoise
• Effective,built-insphericalwindandpopfilter
• Suppliedwithbreak-resistantstandadapter
whichrotates180°
• Handheldmicrophonewithon/offswitch
• LowimpedanceXLRconnectorforlownoise
• LegendaryShurequality,ruggedness,andreliability
SO-G86TG
• 8"dualconespeaker
• Frequencyresponse:50-15,000Hz
• Grillediameter:12"
• Impedance:8Ohm
• Magnet:6oz.
• MaxPower:10Watts
• Versionofthisspeakerwithavolumecontroland
grillecombinationcanbefoundundermodelnumber
SO-G86TCG
Handheld Dynamic Microphone
SO-MCDT300
• Backelectretcondenser
• Widefrequency(50Hz-16kHz)
• XLR3-pinmaleconnector
• On/offswitchislocatedonthebase
• BlueLEDlight-upringindicatespower
• WindscreenspongeovertheMIC
• 20'XLRMiccableand2“AA”batteriesareincluded
• Uni-directional
• Impedance:500ohm
• Sensitivity:-37dB+-3dB
SO-MCHH100
• Lowsensitivitytobreath/popnoise,widefrequency
response,3-pinXLRmaleconnector
• On/offswitch
• Includes20'XLRcableandcarryingcase
• Dynamic
• Uni-directional
• Frequency:50Hz-16kHz
• Impedance:700ohms
• Sensitivity:-54dB+-3dB
Professional Hanging Microphone
a-liveTM Multi-Room 70/25V Audio System
SO-MCHM300
• Backelectretcondenser,springneck
• XLR3-pinmaleconnector
• 9V-52VDCphantompowerisrequired
• Uni-directional
• Frequency:50Hz-16kHz
• Impedance:250ohm
• Sensitivity:-37dB+-3dB
SO-A6X670A
• LivenetworkedaudiostreamingfromyourlaptoporPC
• a-liveTMMulti-Room70/25VAudioSystem
• Allowforcontrolofupto6zonesperunitthrough
PC/LaptopinterfaceorinteractiveLCDKeypads
• Poweroutput:20wattsper70/25Vzone
• Frequencyresponse20Hzto20kHz+0/–2.5dB
• SourceinputconnectorsRCAjacks(leftandright)
• SO-AKPAinteractivekeypad,alsoavailablein8ohm,
SO-A6x6A8
Multi-source/Multi-zone Matrix
Distribution P.A. Amplifier
70/25V/8 Ohm Hanging Pendant Speaker
SO-PL200M
• Featuresmatrixtechnology,allowingyoutorouteupto
5separateinputsto4distinctzones
• Simultaneousplaybackofupto5sourcesinto4zones
• Telephonepagingfunctionandmonitoroutputfor
music-on-holdfeature
• Microphone1prioritywithVOXmutefunction
• Intelligentcoolingfan
• RoHScompliant
• Separatecontrols(gain,bass,treble,volume)andLED
indicatorforeachzone
30 Watt PA Amplifier
with FM/AM Tuner with CD Plyer
SO-P30FACD
• FM/AMTunerwith8FunctionCDPlayer
• 30WattRMS/45WattMax
• AC115V/230V50/60Hz
• 60-15kHz;4MICinputs(1mV;250ohm)
• 1AUXinput(200mV47K);1Telephone(.1-1V600ohm)
• 4/8/16ohms&25/75Vlineoutputs
• MusiconHoldfeature
• Availablein60WversionS0-P60FACD
• ULListed
Audio/Video
Professional Table Conference Microphone
SO-SP30PT
• Theperfectspeakerforsituationswherebackgroundmusic
orpagingisneededbutceilingmountingisprohibitive
• Woofer:5”polypropylenewithrubbersurround
• Tweeter:1/2”Mylar
• Wattage:30Watts/RMS60wattsmax.
• Dimensions:8.25”wx5.5”h
• Weight:5lbs.
• Includeshangingapparatus(maydifferfromoneshown)
• Alsoavailableinblack(SO-SP30PTB)
240 Watt Power Booster Amplifier
SO-P240A
• Automaticoverloadprotection
• LEDdisplay
• DualVoltage:117/220VACat50/60Hz.
• 240WattRMSfor4ohm,8ohmand25/70V
• FrequencyResponse:30to20,000Hz.
• RCAaninputandscrewterminalspeakeroutputs
• Arackmountingkitisincluded
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
303
• Five 70V output zones
• Six XLR microphone inputs
• FM tuner with MP3 ready CD-player
• One AUX input
• AC 120V/50/60Hz
• One Telephone input (0.1-1V 600 Ohms)
• Up to 240 watts RMS
• 8 Ohm and 70V outputs
• 60Hz-15kHz
• Music-on-hold feature AND MORE
simply unique.
Commercial Sound
20 Watt Mobile Amplifier
with Two-Way Communication
High Powered, Portable Amplifier
with VHF Mic System & CD Player
SO-PAT20TB
• Completewithaplug-incigarettelighteradapter,
two-waycommunicationviaTalk-BackControlbutton
• Plug-incigarettelighteradapterforinstantDCpower
supply
• IndividualControlsforAuxiliary,MasterVolume&Tone
• AuxiliarySoundInputJackonRearPanel
• UnderlyingSuctionCupsforSecurePlacement
• CompletewithMountingBrackets
• Alsoavailableinwhite
SO-PAW80
• 80WattsRMS
• ChoiceofHandheldorLapelmicrophone(bothincluded)
• VHFSingleChannelSystem(170~245MHz)FCC
compliant
• Six-functionCDPlayer
• Internal,rechargeable12VDCbatteryforMobileApplications
• Two1/4"microphoneinputconnections
• 1/4"Auxiliaryinputandoutputconnections
• PriorityPagingswitch
15W Contractor Series PA Amplifier
60W Contractor Series PA Amplifier
SO-PBM15
• 15WattRMS
• AutoMutefunction
• MusiconHoldoutputwithseparatelevelcontrol
(600ohmlineandonewatt8ohm),
600ohmTelephoneLineinputwithlevelcontrol
• Bass/TrebleTonecontrols•Frontpanellevelcontrols
• Manualmutingcontacts
• Acceptsinputsfromtwosoundsources•RCAinput
• Outputsincludeachoiceof4,8,and16ohmaswellas
70and25voltlineoutputs
• Alsoavailablein30WversionS0-PBM30
SO-PBM60
• 60wattRMS
• AutoMutefunction
• MusiconHoldoutputwithseparatelevelcontrol
(600ohmlineandonewatt8ohm),
600ohmtelephonelineinputwithlevelcontrol
• Bass/TrebleTonecontrols
• Frontpanellevelcontrols
• Manualmutingcontacts
• Alsoavailablein120Wattversion:SO-PBM120
Seven Zone 260 Watt Commercial Amplifier
60 Watt 70V 3 Source/2 Zone Matrix Amplifier
SO-PL260A
• 260WattsRMS
• Seven70or25Voltzoneoutputswith70/25switch
selector
• 24Voltinputforemergencybackuppower!
• 5XLRMICconnectorinputsw/individualPhantom
Powerswitches
• 3Auxiliaryinputs•Additionalauxiliaryoutput
• Pre-ampinput/boosteroutput
• 4/8/16ohmoutputzone•MusiconHoldfeature
• 1Telephonepaginginput(0.1-1V600ohm)
SO-PL60SA
• 60WattsRMS
• XLRMicconnectorwithpagingpriority
• MusiconHold
• RCAinputterminals
• 600-ohmtelephonepaginginput
• RCAandMusic-on-Holdoutputs
• 24VDCinputforaback-uppowersupply
• Alsoavailablein120WattsversionSO-PL120SA
• 5-yearlimitedwarranty
Wall Baffle
With 70V Transformer & Volume Control
5.25" 70/25V Commercial ABS Plastic Back
5” AWX Series All-Weather Extreme
Indoor/Outdoor Speakers
SO-SP5MAT
• All-in-oneunit,pre-assembledwithabackcanand
mountedtransformer,quickflip70or25Voltselector
switch
• Easyselecttransformerwattagedialfeaturingthe
choiceof8or9individual“wattagetapsettings
• Flame-retardant,ABSunitalsocomeswithinsulated
wires
• Attachedmetalsafetyloopandeasymounttabsfor
securingtheunit
• Dimensions9.5"Dia.x6"Depth
• Alsoavailablein6.5"versionSO-SP6MAT
Audio/Video
SO-WB86D
• Woofer:8"DualCone
• FrequencyResponse:85-15,000Hz
• HeightandWidth:10”(H)x10”(W)
• Depth:5"Top,3"Bottom•Housing:Walnut
• Impedance:8ohm•RMSPower:10Watts
• Magnet:6oz.•Transformer:70Volt,10Watt
• TransformerTaps:10,5,2.5,1.25,.625Watt
• TypeDualCone
• Alsoavailablefor25Vline:SO-WB86D25
6.5" In-Ceiling Speaker System
SO-SP5AWX
• Woofer5.25”PolypropylenewithRubberSurround
• Tweeter.75”SilkDomeTweeter
• Frequency75Hz-20kHz
• Wattage40WattsRMS/80WattsMax
• Impedance8Ohm
• Alsoavailableinwhite,SO-SP5AWXWand
in5”withatransformerSO-SP5AWXT(black)
andSO-SP5AWXTW(white)andavailablein6”
SO-SP6AWX(black)andwithatransformer
SO-SP6AWXT
SO-SP6CLC
• Pivotingsilkdometweetersthatfocusthehigh
frequenciestoyourcustomizedlisteningarea
• Theinjection-designedwooferwithrubbersurround
deliverpowerful,richlowfrequencyresponsewith
minimaldistortion
• Alsoavailable:
SO-SP6CLW-6.5"In-WallSpeakerSystems
SO-SP8CLC-8"In-CeilingSpeakerSystem
SO-SP8CLW-8"In-WallSpeakerSystems
SO-SP8CLSW-8"In-WallSubwoofer
SO-SP5CLCC-CenterChannelSpeaker
6.5" In-Ceiling Enclosed Speaker
NEXUSTM UL® Contractor Series 6.5” 70V
SO-SP6ECS
• Woofer61/2"Polypropylene
• Tweeter:1/2"MylarDome
• FrequencyResponse:65-20,000Hz.
• Impedance:8Ohm
• MaxPower:100Watts•RMSPower:35Watts
• MountingDepth:51/2"•HoleSizeRequired:8-1/16"
• Soldinpairs
• Sensitivity:(1W/1M)90dB
• SpeakerDimensions:9-1/2"Diameter
• Alsoavailablein8"version:SO-SP8ECS
SO-SP6NXCTUL
• MeetorexceededthestrictUL1480requirementsfor
firesafety
• Removable“Quick-Snap”connectionterminalsprovide
easyaccessandoptimalanglesforconnectingspeaker
wire.Awattageselectordialsimplifiestransformer
settings
• Mountedsecurityloopsallowforasupportcablerun
andceilingsupportbracketsareincluded
• Fireretardantmetalbackcan
• 70Vtransformerdial
• Metalsafetyloopforsecuring
• Portedbass
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
305
Commercial Sound
6" Weatherproof PA Speaker, 8 Ohm
11" x 8" Weatherproof PA Speaker
SO-SPC10
• FrequencyResponse:250-15,000Hz
• Impedance:8Ohm
• Material:Aluminum
• MaxPower:15Watts
• Mountingbracketincluded
• Dimensions:6"(Dia)x6"(L)
• RMSPower10Watts
• Sensitivity:(1W/1M)105dB
SO-SPC30RT
• FrequencyResponse:250-16,000Hz.
• Impedance:8Ohm
• Material:Aluminum
• MaxPower:30Watts
• Dimensions11"(W)x8"(H)x101/4"
• Mountingbracketincluded
• Sensitivity:(4V/1M)120dB•Transformer:70/25V
• TransformerTaps:
25V30,15,10,3.7,1.9,1.3,0.6,0.4,0.1Watt
• TransformerTaps,70V30,15,10,5,3,1Watt
6 1/2" x 11"
32W Weatherproof PA Speaker
8" 70/25V Ceiling Tile Speaker
SO-SPC40RT
• FrequencyResponse:250-15,000Hz
• Impedance:8Ohm
• MaxPower:32Watts•RMSPower:15Watts
• Dimensions:6-1/2"(Dia)x11"(L)
• Housing:WhiteABSPlastic
• Mountingbracketsincluded•Packagedindividually
• Sensitivity:@4V/1M120dB
• Transformer:70/25V
• TransformerTaps32,16,8,4,2Watts
SO-SPCT8T
• Woofer:8"Polypropylenewithrubbersurround
• Tweeter:3/4"Mylardometweeter
• FrequencyResponse:50Hz-20kHz
• MaxPower:30WattsRMS/60WattsRMS
• Sensitivity:90+/-3dB•Impedance:8ohms
• SelectorSwitch:70/25
• TransformerSettings:20,10,5,2.5,1.25,and8ohms
• Dimensions23"Wx23"Hx6"D
• Weight7.1lbs.
• Accessories:2'Drop-ceilingcrossbarrailincluded
Audio/Video
SO RELIABLE, IT JUST
MIGHT OUTLAST YOUR
CLIENT’S BUSINESS.
INTRODUCING THE 135MA AND 160MA COMMERCIAL AMPLIFIER. Not even the
best business plan can outlast the rock-solid reliability of our most compact
commercial amplifier ever. Featuring the legendary Crown sound at a price tag no
business owner can resist, this amplifier features music-on-hold, voice activated
paging and pre-amp outputs, making it the best solution for nearly any installation.
Throw in our three-year, no-fault warranty, and it’s easy to understand why Crown
makes good business sense.
306
www.crownaudio. com
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Commercial Sound
1S-PGD3750W
1S-PGD4010X
1S-PGF255W
1S-PGF312X
1S-PGF325W
1S-PGF212XL
1S-PGF317X
1S-PGF267X
1S-PGF262X
Professional Display Products
SharpConference/Classroomprojectorsareknownfortheirexceptionalbrightness,imagequalityandversatilityatveryaffordable
prices.BrilliantColorTMDLP®technologywithfilter-freedesignand3-year24-hourturnaroundExpressRepairwarranty*helps
ensuresuperiorreliabilityandlowercostofownership.Withbrightnessupto4200ANSILumens,inHDcompatibleWide-XGAand
XGAresolutions,instandardandnew“short-throw”designs,thereisaSharpConference/ClassroomProjectortomeetalmostevery
application.
1S-PGD4010X
• 4200ANSILumensBrightness
• XGA(1024x768)NativeResolution
• HighOutput10WAudioSystem(5W/ChannelStereo)
• WideComputerandVideoCompatibility
• OptionalCeilingMountBracket(1S-ANXGCM55)
• SpareLamp:1S-AND400LP
1S-PGF255W
• 2500ANSILumensBrightness
• WXGA(1280x800)NativeResolution
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
1S-PGF325W
• 3000ANSILumensBrightness
• WXGA(1280x800)NativeResolution
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
1S-PGF312X
• 3000ANSILumensBrightness
• XGA(1024x768)NativeResolution
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
1S-PGF317X
• SimilartoPG-F312XwithadditionofRJ-45LAN
• 3000ANSILumensBrightness,XGA
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
1S-PGF212XL
• 2400ANSILumensBrightness
• XGA(1024x768)NativeResolution
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
1S-PGF262X
• 2600ANSILumensBrightness
• XGA(1024x768)NativeResolution
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
Audio/Video
1S-PGD3750W
• 3700ANSILumensBrightness
• WXGA(1280x800)NativeResolution
• HighOutput10WAudioSystem(5W/ChannelStereo)
• WideComputerandVideoCompatibility
• OptionalCeilingMountBracket(1S-ANXGCM55)
• SpareLamp:1S-AND400LP
1S-PGF267X
• UniqueShortThrowDesignprojectslargeimagesfrom
shortthrowdistance
• 2500ANSILumensBrightness,XGA
• WideComputerandVideoCompatibility
• On-ScreenSetupGuideandHelpFunction
• OptionalCeilingMountBracket(1S-ANXRCM30)
• SpareLamp:1S-ANF212LP
*Sharp’s3-year,24-hourturnaroundlimitedwarrantycoverspartsandlaborexcludingprojectorlamp.
90daywarrantyontheuserreplaceableprojectorlamp.
SharpisaregisteredtrademarkofSharpCorporation.
DLPandBrilliantColoraretrademarksorregisteredtrademarksofTexasInstruments.
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
307
Telephony
Visit
ADI at
THE
THE
ELECTRONIC
ELECTRONIC
HOUSE
HOUSE EXPO
EXPO
Orange County Convention Center
Orlando, FL
March 24-27
25-27
Booth #704
Stand-Alone Emergency Call Kits
“Area of Refuge” System
AY-EK117
• Lightkitonly
AY-EK117B
• Lightkit&buzzer
AY-NC150R
• Emergencyassistancesystem-ADAmandatedin
multi-levelbuildings(i.e.commercialbuildings,schools)
• Audible&visualannunciation–Voicecommunication
andmonitoringcapable
• RemotestationsavailableinAluminumorStainless
Steel
• MeetsADArequirements*
Audio/Video
• Perfectforpublicorprivatebathroomemergency
call,homeinvalidmedicalemergency&manyother
applications
• Lowcostsolution•Safe-Lowvoltagewiring
• Kitincludes:(Partsalsosoldseparately)
*AY-SS106-powertransformer
*AY-SF1172A-pullswitch
*AY-LI381orAY-LI123Bdomelightassembly
*NOTE:MayrequirespecialBrailleorotherlocation
indicationsignage.Checkyourlocalcodesforfull
complianceinformation
Emergency Pull Cord/Push Station
Micro Processor Nurse Call System
AY-SF155B
• CanbeusedwithavarietyofEmergencyand
Nursecallsystems
• Built-inLEDCall-placedindicator-
resetsonlyatpointoforigination
• Singlegangmount–whiteplastichousing
• Activateswithpushorpull–comeswithadjustable
6'longpullcord
• Waterresistantmodelalsoavailable(AY-SF337C)
AY-NC300II
• FullfeatureddigitaladdressableUL1069listedNurse
Callsystem
• Idealforuseinhospital,assistedliving,andhospice
carefacilities
• 256or512pointcapacityandupto8masterstations
perCPE
• Callsdisplayedbyprioritylevel
• Multiplexedloopwiremethod
• Caninterfacetoprinterorpocketpagers
5.8 GHz Site Survey Spectrum Analyzer
900 MHz Site Survey Spectrum Analyzer
8A-AW5800SPEC
AvaLAN5.8GHzradioreceiverandspectrumanalysis
functionalityprovidesasensitivesitesurveytoolina
rugged,weatherproofenclosure.
• IPAddressableforeasyconnectiontotcp/ipnetworks
• Built-inbrowserinterfaceforeasyconfigurationand
performancemonitoring
• Tunesfrom5.724GHzto5.853GHzin1MHzsteps
• -93dBmsensitivity(0.5nanoWatts)
• Canaverageupto256samplesperpoint
• Logarithmicgraphicdisplay
8A-AW900SPEC
AvaLAN900MHzradioreceiverandspectrumanalysis
functionalityprovidesasensitivesitesurveytoolina
rugged,weatherproofenclosure.
• IPAddressableforeasyconnectiontotcp/ipnetworks
• Built-inbrowserinterface
• Tunesfrom879to945MHzin500KHzsteps
• -97dBmsensitivity(0.2nanoWatts)
• Canaverageupto256samplesperpoint
• Logarithmicgraphofpeakandaveragepowervs.
frequency
• SuitableforMountingoutdoors
DSX Support Website
DSX-40 System Kits
QY-1091015
• 4x8x2Kitw/(3)22-ButtonTelephones(Black)
QY-1091026
• 4x8x2Kitw/(3)34-ButtonBacklitDisplayTelephones
and(1)2Port/8HourIntraMail(Black)
QY-1091027
• 4x8x2Kitw/(3)34-ButtonBacklitDisplayTelephones
and(1)2Port/8HourIntraMail(White)
• DSXSupportWebsitewww.necdsx.com
• FreeOn-demandWeb-basedTechnicalTraining
• FreeSoftwareUpdates
• FreePCProgrammingSoftware
• DownloadBrochures,UserGuides,Manuals
• DownloadSystemConfigurator/QuoteSpreadsheet
• ResellerTechnicalForum
QY-1091015 Kit shown
DSX IntraMail Voice Mail/Auto Attendant
Cordless DECT Telephone
QY-1091060
• 2Port8Hour
QY-1091011
• 4Port8Hour
QY-1091013
• 8Port16Hour
QY-730095
• DECT6.0
• 2Line,24DigitDisplay
• 5Channels
• 8ProgrammableFeatureKeys
• Consistsof:
BaseUnitHandset,ChargingCradle,(2)ACAdapters,
BeltClip,Ni-MhBattery,BaseStandandWall-Mounting
Hardware
• 128SubscriberMailboxes
• FlexibleAnswerSchedules
• MultipleLineGreetings
*HouseLine,OfficeLine,Kid’sLine
*CompanyA,CompanyB
308
• ResidentialorCommercialApplications
• Expandableto8COx26STA
• Built-inCallWaitingCallerID
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Telephony
Cordless DECT Repeater
DSX Digital Telephones
QY-730639
• UptoSixRepeatersPerBaseStation
• UptoThreeRepeatersinaSequentialorDaisy-Chain
Layout
• RepeaterConnectionVerificationTone
• LowPowerConsumption
QY-1090020
QY-1090025
• 22-ButtonDisplay(White/Black)
QY-1090021
QY-1090026
• 34-ButtonBacklitDisplay(White/Black)
QY-1090023
QY-1090028
• 34-ButtonSuperBacklitDisplay(White/Black)
Cordless DECT Repeater Programming Kit
QY-730640
• ProgrammingCable,Software,SetupGuide
• 1KitSuggestedPerReseller
• InteractiveDisplayonallphones
Advanced Hybrid Telephone Systems
PA-KXTA824
• 3COand8Extensionsystem,expandableto8x24
PA-KXTA824PK
• IncludesKSUand3piecesofPA-KXT7731Btelephones
PA-KXTAW848
• 4COand4extensionsystems,expandableto8x48
• PA-KXTAW848wirelesshandsetsarePA-KXTD7684/7690/7694/7685/7695/7696
• PA-KXTD7684/7690/7694requirethePA-KXT0151cellstation
• PA-KXTD7685/7695/7695requirethePA-KXTD155DECTcellstation
KX-T7700 Series Telephones
PA-KXT7737B
• TalkingCID,3-linebacklitdisplay,speakerphone
PA-KXT7736B
• 3-linebacklitdisplay,speakerphone
PA-KXT7731B
• 1-linebacklitdisplay,speakerphone
Digital Phone
PA-KXTVA50
• 2ports,4-hourexpandablesystem
• 64Mailboxes
• Windowsbasedprogramming
• USBport
PA-KXDT321
• 1lineLCDdisplay
• 16characters
• LCDbacklit
• Digitalduplexspeakerphone
• MessagewaitingLED
• Headsetjack
Digital Phone
Digital Phone
PA-KXDT333
• 3lineLCDdisplay
• 24characters
• Digitalduplexspeakerphone
• MessagewaitingLED
• Headsetjack
PA-KXDT343
• 3lineLCDdisplay
• 24characters
• LCDbacklit
• Digitalduplexspeakerphone
• MessagewaitingLED
• Headsetjack
Digital Phone
Network Communications Platform
PA-KXDT346
• 6lineLCDdisplay
• 24characters
• LCDbacklit
• Digitalduplexspeakerphone
• MessagewaitingLED
• Headsetjack
PA-KXNCP500
• BuiltinvoicemessagingandAutomatedAttendant
functionality
• AdvancedvoicemailusingoptionalTVAandTVA200
voiceprocessingsystems
• Mobilityapplicationsthatsupportmobilephonesas
officeextensions
• Supportforremoteworkersandremoteoffices
• Remotemanagement,upgradesandmonitoringforyour
phonesystem
• CommunicationAssistantcallmanagementsoftware
• Maximumcapacities:64extensions/60COLines
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Audio/Video
Voice Processing System
309
Audio/Video
Telephony
310
Network Communications Platform
SIP Telephone
PA-KXNCP1000
• BuiltinvoicemessagingandAutomatedAttendant
functionality
• AdvancedvoicemailusingoptionalTVAandTVA200
voiceprocessingsystems
• Mobilityapplicationsthatsupportmobilephonesas
officeextensions
• Supportforremoteworkersandremoteoffices
• Remotemanagement,upgradesandmonitoringforyour
phonesystem
• CommunicationAssistantcallmanagementsoftware
• Maximumcapacities:108extensions/84COLines
PA-KXHGT100
• SIPprotocol
• 2-lineLCDdisplay
• CallerID
• Calllog
• Speakerphone
• PoE
• 2-Ethernetports
• Webprogrammingforinstaller
IP Telephone
IP Telephone
PA-KXNT321
• 8programmablekeys
• 1-lineLCDdisplay
• PoE
• 2Ethernetports
• Speakerphone
• Message/ringerlamp
• Headsetjack
• Whiteandblackcolorsareavailable
PA-KXNT343
• 24programmablekeys
• 3-lineBacklitLCDdisplay
• PoE
• 2Ethernetports
• Speakerphone
• Message/ringerlamp
• Headsetjack
• Whiteandblackcolorsareavailable
IP Telephone
IP Telephone
PA-KXNT346
• 24programmablekeys
• 6-lineBacklitLCDdisplay
• PoE
• 2Ethernetports
• Speakerphone
• Message/ringerlamp
• Headsetjack
• Whiteandblackcolorsareavailable
PA-KXNT366
• 4x12programmablekeys
• 6-lineBacklitLCDdisplay
• PoE
• 2Ethernetports
• Speakerphone
• Message/ringerlamp
• Headsetjack
• Whiteandblackcolorsareavailable
IP Conference Speakerphone
Advanced Hybrid PBX System
PA-KXNT700
• Highdefinitionvoicequality
• Real-timeslowtalk
• SDcardrecording
• Noisereduction
• IP,SIP,Single-LineTelephoneandWebConferencing
Systemscapability
• PoE
PA-KXTA824PK
• PCprogrammable(onsiteandremote)
• Built-inremotemodemcard
• 3voicemailoptions
• Messagewaitinglampcontrol
• CallerIDwithcallwaiting
• CallerIDlogging(systemandstation)
• Roommonitor
• Callforwarding
• DirectInwardSystemAccess
• BuiltinUSBandRS232Cports
DECT Wireless Handset
DECT Wireless Handset
PA-KXTD7685
• Bluebacklitdisplay
• Illuminatedkeypad
• Easymenunavigationjoystickandlargeicons
• Programmablekeys
• Personaltelephonedirectorywithupto100entries
• Built-inspeakerphone
• Standardmodel
PA-KXTD7695
• Bluebacklitdisplay
• Illuminatedkeypad
• Easymenunavigationjoystickandlargeicons
• Programmablekeys
• Personaltelephonedirectorywithupto100entries
• Built-inspeakerphone
• Compactmodel
DECT Wireless Rugged Handset
Hybrid IP-PBX System
PA-KXTD7696
• Bluebacklitdisplay
• Illuminatedkeypad
• Easymenunavigationjoystickandlargeicons
• Programmablekeys
• Personaltelephonedirectorywithupto100entries
• Built-inspeakerphone
• Ruggedmodel
PA-KXTDA50G
• SIPtrunkingcapability
• Multi-CellWireless
• PC-BasedProgramming
• AutomaticRouteSelection(ARS)
• TollRestriction
• CallerID
• VoIP
• DigitalVoiceMailIntegration
• DirectInwardSystemAccess(DISA)
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Telephony
Converged IP-PBX System
Converged IP-PBX System
PA-KXTDE100
• Contains1cabinetwith6freeslots,1mainprocessor
unit,1SDcard,4virtualextensionslots,4virtualCO
slots,2chsimplifiedvoicemail
• Multi-cellwireless
• VoIPGatewaywithQSIG
• CallerID(NameandNumber)
• ISDNPrimaryRateInterface(PRI)withQSOG&T1
• NetworkingwithCentralizedVoiceMail
• VoiceMailIntegration
• UniformCallDistribution(UCD)
• Max.capacities:128extensions/128COLines
PA-KXTDE200
• Contains1cabinetwith11freeslots,1mainprocessor
cabinet,1SDcard,4virtualextensionslots,4virtualCO
slots,2chsimplifiedvoicemail
• Multi-cellwireless
• VoIPGatewaywithQSIG
• ISDNPrimaryRateInterface(PRI)withQSIGandT1
• Networkingwithcentralizedvoicemail
• Voicemailintegration
• Uniformcalldistribution(UCD)
• Max.capacitiy:256extensions/128COLines
Converged IP-PBX
Voice Mail Cabinet
PA-KXTDE600
• Contains1shelfwith10freeslots,1mainprocessor
unit,1SDcard,4virtualextensionslots,4virtualCO
slots
• SIPtrunkingcapability
• Multi-cellwireless
• VoIPGatewaywithQSIG
• VoIPextensions
• PC-basedprogramming
• DXDP
• AutomaticRouteSelection
• ISDNPrimaryRateInterface(PRI)withQSIGandT1
PA-TVA50
• Configuredwith:2portsexpandableto6portsusing
eitherthePA-KXTVA502orthePA-KXTVA503cards,4
hoursofstorageexpandableto8hours,64mailboxes,
1USBport
• AutomatedAttendant
• Emailintegration
• Windows-basedPCprogrammable(on-siteandremote)
• Optionalremotemodemcard
• ProprietaryTelephonevoicemailmenu
• Livecallscreening
• Intercompaging
Voice Mail Cabinet
Area of Rescue Command Unit
TF-CU8R
• Accommodatesupto8emergencyphones
• Strobe/sounderindicatesanincomingcall
• Identifiesacallingstationandenables2-way
communication
• For16stationcapacityorderTF-CU16
• RecessmountsforsurfaceorderTF-CU8
Consolidator
Area of Rescue/Elevator Emergency Phone
TF-EC8
• Allowsupto8emergencyphoneson1phoneline
• Minimizescablerequirements
• Built-inlineseizuremodel
• Alsouseforinternalcommunicationwithemergency
phones
TF-ETP100EB
• Flushmountedmodel
• Auto-dialercalls2numbers
• PoweredbyphonelinesorPBX
• ADAcompliant
ADA
Area of Rescue/Elevator Emergency Phone
TF-ETP100MB
• Fitsexistingelevatorphoneboxes
• Phonelinepowered
• Auto-dialercalls2numbers
• Vandalresistant
Audio/Video
PA-TVA200
• Configuredwith:4portsexpandableto24portsusing
eitherthePA-KXTVA504card,1000hoursofstorage,
1024mailboxes,USBandRS232ports
• AutomatedAttendant
• Emailintegration
• Windows-basedPCprogrammable(on-siteandremote)
• Optionalremotemodemcard
• ProprietaryTelephonevoicemailmenu
• Livecallscreening
• Intercompaging
• Interviewservice
Emergency Phone in Lighted
Surface Mount
TF-ETP400
TF-ETPSML
• Translucent“Emergency”signremainslitatalltimes
• Idealforparkingfacilities,collegecampuses,medical
centers
• Standardinbrushed-finishstainlesssteel
• Signalsoavailableas“HELP”,“ASSISTANCE”
orcustomwording
• ADACompliant
ADA
ADA
Outdoor Emergency Phone
TF-ETP400
• Indoor/outdooruse
• Flushorsurfacemount
• Perfectforparkingfacilities,campuses&ADAareas
ofrescue
• ADACompliant
ADA
Emergency Phone in Hooded
Surface Mount
TF-ETP400D
TF-ETPSMH
• 2buttoncallingcapabilitiesforemergency&info
• Idealforparkingfacilities,collegecampuses,medical
centers
• ADACompliant
ADA
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
311
Telephony
Keypad Emergency Phone
Emergency Phone
TF-ETP400K
TF-ETPSM
• Adds12keyphonepadtoemergencyphone
• CanmakeauthorizedcallsonPBXline
• Idealformedicalcenters,ATMs,accesscontrolbuildings
• Indoor/outdooruse
• ADACompliant
TF-ETP401COP3
• Indoor/outdooruse
• Surfacemountversion
• Integrateswithlight/strobe/CCTV
• Designedforaccesscontrolapplications
• TF-ETPSMEforconduitentryfrombottom
• Built-incamera
• OrderTF-ETP401Cforunitwithoutconcealedcamera
• ADAcompliant
ADA
ADA
Emergency Phone
Blue Light & Strobe
TF-ETP402
• 2-buttoncallingcapabilitiesforemergencyandinfo
• Surfacemountunit
• Indoor/outdooruse
• TF-ETPSMEforconduitentryfrombottom
• ADACompliant
TF-ETPEL
• Workswithall100&400seriesphones
• Indoor&outdooruse
• Strobeactivatedwhenbuttonispushedonan
emergencyphoneandceaseswhencallends
• For12//24VDCoperationorderTF-ETPEL12/24
ADA
ADA
Emergency Phone Tower
Emergency Phone Pedestal Mount
TF-ETPMTR
• IncludesTF-ETPELbluelight/strobe
• 9'tall,.25"steelconstruction
• Perfectforcampuses,parkinglots&hospitals
• Radiustoweroffersfixedorspeeddomecameraoptions
TF-ETPPM
• AllowsADAcompliantemergencyphonestobemounted
inafreestandingunit
• Vandalresistant
• Perfectforaccesscontrol,transitauthorities,andgate
entrances
• ShownwithTF-ETP400C
• Alsoavailableinstainlesssteel,TF-ETPPMSS
ADA
Area of Rescue Assistance Signs
Emergency Phone Economy
Pedestal Mount
Audio/Video
ADA
TF-ETPPME
• AllowsADAcompliantemergencyphonestobemounted
inafreestandingunit
• Gooseneckmountisidealfordrive-uporwalk-up
applicationsincludingaccesscontrolandentry
• ShownwithTF-ETP400C
• Vandalresistant
TF-ETPSIGN
• Self-adhesive,polycarbonatesignwithraisedletter
braille
TF-ETPSIGNL
• Steel,back-litsign
TF-ETPSIGNLD
• Lightedsignwithbatteryback-up
ADA
Talk-A-Lert Computer Package
Stainless Steel Wall Mount Enclosure
TF-ETPTAL
• Hardware/softwarepackagethatoperateswithany
Talk-A-Phoneemergencyphone
• Checktheintegrityofemergencyphones&phonelines
uptoonceaminute
• Keepsarecordofallincomingcalls
• Identifiestheexactlocationofincomingemergency
phonecalls
TF-ETPWM
• IncludesTF-ETPELbluelight/strobe
• Polycarbonatewindowprotectsstrobe
• UsewithTF-ETP400orTF-ETP400Kemergencyphone
models
• 11-gaugestainlesssteelconstruction
• ShownwithTF-ETP400Demergencyphone
ADA
Native IP Emergency Phone
Mass Notification Emergency Phone Tower
TF-VOIP400
• Unitcanbepagedremotelybysecurityaspartof
Talk-A-Phone’sWide-AreaEmergencyBroadcastSystem
(WEBS®)
• EthernetconnectivityandfullIPcompatibilitywith
existingroutersandLANinfrastructure
• SupportsstandardVoIPprotocolsH.323andSIP
• Keypad(TF-VOIP400K),dual-button(TF-VOIP400D),and
“ToCall”lettering(TF-VOIP400C)modelsavailable
TF-WEBSMTR
• IncludesTF-ETPELstrobelight
• Enablesmassbroadcastpagingtoindividualunits,
user-definedgroupingofunits,ortoallunits
• AvailableinAnalogandNativeIPformats
• Radiustoweroffersfixedorspeeddomecameraoptions
• 10'tall,.25"steelconstruction
ADA
312
ADA
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
Telephony
Mass Notification Outdoor Paging Unit
Mass Notification Paging Unit
TF-WEBSPA1
• Enablesmassbroadcastpagingtoindividualunits,
user-definedgroupingofunits,ortoallunits
• IP-formatthatiscompatiblewithH.323andSIP
protocols
• Constructedof16-gaugestainlesssteel
• Configurationandmanagementarecontrolledthrough
astandardWebbrowser
TF-WEBSPA2A
TF-WEBSPA2IP
• NativeIPandAnalogformatavailable
• Forindoorandoutdooruse
• Enablesmassbroadcastpagingtoindividualunits,
user-definedgroupingofunits,orallunits
• Constructedfrom16-gaugestainlesssteel
Mass Notification Wall Mount
ADA Compliant Emergency Tower Phone
TF-WEBSWM
• IncludesTF-ETPELbluelight/strobe
• Allowsformassbroadcastpagingtoindividualunits,
user-definedgroupingofunits,ortoallunits
• 12gaugestainlesssteelconstruction
• NativeIPandAnalogformatsavailable
VK-E1600ABLTEWP
• MeetsADArequirementsforemergencyphones
• Phonelinepoweredandnobatteriesrequired
• Handsfreeoperation
• Built-indigitalvoiceannouncer
• Dialsupto5emergencynumbers
• 1millioncandlepowerbluestrobelight
• Twobuttonversionhas“Info”and“Help”buttons
• EnhancedWeatherProtectionincluded(EWP)
ADA
ADA Compliant Emergency Phone
VK-DNA510
• Provides10differentdigitalalerttonesand5
emergencymessages
• Upto2minutesoftotalrecordtime
• Securelyactivateorpagefromaremotephone
• Tonesandmessagesrepeatupto99times
• Automaticallyinterruptscurrentpageorbackground
music
• ProvideEmergencyMassNotificationfor:schools,
colleges,theaters,officebuildings,etc.
VK-E1600A
• MeetsADArequirementsforemergencyphones
• Phonelinepoweredandnobatteriesrequired
• Handsfreeoperation
• Built-indigitalvoiceannouncer
• Dialsupto5emergencynumbers
• CentralStationMonitoringcompatible
• Availableindifferentcolorsandchassistosuit
numerousemergencyphoneapplications
• OptionalEnhancedWeatherProtection(EWP)
zBoost CI YX710
zBoost zP Cell Phone Signal Booster
W2-YX710
• Supportsboth800MHz(cellular)and1900MHz(PCS)
bands
• Increasesyourindoorcellsignalcoverage-upto
10,000sqfeet
• Extendsphonebatterylife(Useslesspowerwhensignal
isstronger)
• WorkswithallphonesandU.S.carriers(exceptNextel/
iDEN)
• Packageincludestheamplifierbaseunit,powersupply,
highgainsignalandbaseunitantennas,signal
combinerandmountinghardware
W2-YX300
• zBoostzPersonal:wirelessversion
• Decreasesdroppedormissedcalls
• Extendssignalindoorsforasingleuserattheir
workspace,hotel,homeoroffice
• CompatiblewithallU.S.phonesandaircards,except
Nextel(uses800or1900MHzbands)
• Extendsphonebatterylife(useslesspowerwhensignal
isstronger)
• Patent-pendingtechnologyprotectsthecarriernetwork
zBoost Cell Phone Signal Booster
for the Home or Office
zBoost Cell Phone Signal Booster for the Car
W2-YX510PCSC
• DualBand–boostsboth800&1900MHz(exceptNextel)
W2-YX500CEL
• Boosts800MHz(exceptNextel)
W2-YX500PCS
• Boosts1900MHz
• Eliminatesmostdroppedormissedcallsusingpatient
pendingtechnologythatprotectsthecarriernetwork
• Boostssignalupto2500squarefeetformultipleusers
• Includeseverythingneededtoboostindoorsignal
zBoost Cell Phone Signal Booster
for Professional Installation
W2-YX610PCSC
• zBoostDualBandProPackextendscellphonesignal
indoorsupto10,000sq.ft.
• Supportsmultipleuserssimultaneously
• CompatiblewithallU.S.phonesandwirelessdata
cards,exceptNextel(uses800and1900MHzbands)
• Patent-pendingtechnologyprotectsthecarriernetwork
• Extendsphonebatterylife
(useslesspowerwhensignalisstronger)
• Packageincludeshigh-gaindirectionalantennas,
baseunit/amplifierhardware&powersupply
Audio/Video
Digital Mass Notification Announcer
W2-YX230
• Reducesdroppedcallsanddeadzones
• Extendscellphonerange–upto10timesthesignal
strength
• CompatiblewithallU.S.phones&wirelessdatacards,
exceptNextel(Usesboth800and1900MHzbands)
• Improvesvoiceanddatatransmission
• Extendscellphonebatterylife(useslesspowerwhen
signalisstronger)
• Phonestayswireless–nodirectwiretophone
• Patent-pendingtechnologyprotectsthecarriernetwork
zBoost Cell Phone Signal Strength Meter
W2-YX699
• ThezBoostRFSignalMeterreadscellphonesignallevel
• DesignedforInstallers
• Identifiestheoptimallocationforanantenna
• Attachtodirectionalantennatoreadsignalstrengthfor
peakalignment
• Detectsthesignalstrengthandvariationinsidea
buildingtoaidintheplacementofinternalantennas
• Dual-band:workswithmostcarriersatbothCellular
(800MHz)and/orPCS(1900MHz)frequencies
(excludingNexteloriDEN)
• Packageincludessignalmeter,antennaandcable
For Orders, Call: 1-800-233-6261 | For Systems Sales And Support, Call 1-800-234-7971 | www.adiglobal.com/us
313
Next Stop, opportuNity.
ADI has been introducing new business opportunities to dealers for more than 25 years.
Choose ADI and experience the best brands, service and training in the industry.
Call 1.800.233.6261 for your nearest location  Visit us on the web at www.adiglobal.com/us
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
