DVD Micro Theatre
User manual
Manuel d'utilisation
Manual del usuario
Benutzerhandücher
Gebruikershandleidingen
Manuale per l'utente
Användarhandböckerna
Brugermanual
Downloaded From Disc-Player.com Philips Manuals
MCD515
Important notes for users in the
U.K.
Italia
DICHIARAZIONE DI CONFORMITA’
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
Si dichiara che l’apparecchio MCD515 Philips
risponde alle prescrizioni dell’art. 2 comma 1 del
D.M. 28 Agosto 1995 n. 548.
1
2
Remove fuse cover and fuse.
Fatto a Eindhoven
3
Refit the fuse cover.
Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
Norge
Typeskilt finnes på apparatens underside.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
¶ As these colours may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
Downloaded From Disc-Player.com Philips Manuals
2
CAUTION
Visible and invisible laser radiation. If
the cover is open, do not look at the
beam.
^
1
5
T H E AT H R E
#
$
4
%
2
7
6
PRESET
TUNING
(
3
5
0
!
@
*
9
&
8
Downloaded From Disc-Player.com Philips Manuals
3
1
4
2
6
#
5
8
7
9
7
8
0
0
@
!
ANGLE
A-B
$
∞
%
§
^
MODE
PROGRAM
ª
£
3
•
™
¡
IS
&
DSC
)
(
*
Downloaded From Disc-Player.com Philips Manuals
4
DK
SF
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen
muulla kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specificerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina
silloin, kun pistoke on pistorasiassa.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
Manufactured under license from Dolby
Laboratories.
"Dolby", "Pro Logic" and the double-D symbol
are trademarks of Dolby Laboratories.
.
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reserve engineering
or disassembly is
prohibited.
DivX, DivX Certified,
and associated logos
are trademarks of
DivXNetworks, Inc and
are used under license.
Windows Media is a trademark of
Microsoft Corporation.
Downloaded From Disc-Player.com Philips Manuals
5
Language Code
Abkhazian
6566
Afar
6565
Afrikaans
6570
Amharic
6577
Arabic
6582
Armenian
7289
Assamese
6583
Avestan
6569
Aymara
6589
Azerhaijani
6590
Bahasa Melayu
7783
Bashkir
6665
Belarusian
6669
Bengali
6678
Bihari
6672
Bislama
6673
Bokmål, Norwegian
7866
Bosanski
6683
Brezhoneg
6682
Bulgarian
6671
Burmese
7789
Castellano, Español
6983
Catalán
6765
Chamorro
6772
Chechen
6769
Chewa; Chichewa; Nyanja
7889
9072
Chuang; Zhuang
9065
Church Slavic; Slavonic 6785
Chuvash
6786
Corsican
6779
Česky
6783
Dansk
6865
Deutsch
6869
Dzongkha
6890
English
6978
Esperanto
6979
Estonian
6984
Euskara
6985
6976
Faroese
7079
Français
7082
Frysk
7089
Fijian
7074
Gaelic; Scottish Gaelic 7168
Gallegan
7176
Georgian
7565
Gikuyu; Kikuyu
7573
Guarani
7178
Gujarati
7185
Hausa
7265
Herero
7290
Hindi
7273
Hiri Motu
7279
Hrwatski
6779
Ido
7379
Interlingua (International)7365
Interlingue
7365
Inupiaq
Irish
Íslenska
Italiano
Ivrit
Japanese
Javanese
Kalaallisut
Kannada
Kashmiri
Kazakh
Kernewek
Khmer
Kinyarwanda
Kirghiz
Komi
Korean
Kuanyama; Kwanyama
Kurdish
Lao
Latina
Latvian
Letzeburgesch;
Limburgan; Limburger
Lingala
Lithuanian
Luxembourgish;
Macedonian
Malagasy
Magyar
Malayalam
Maltese
Manx
Maori
Marathi
Marshallese
Moldavian
Mongolian
Nauru
Navaho; Navajo
Ndebele, North
Ndebele, South
Ndonga
Nederlands
Nepali
Norsk
Northern Sami
North Ndebele
Norwegian Nynorsk;
Occitan; Provencal
Old Bulgarian; Old Slavonic
Oriya
Oromo
Ossetian; Ossetic
Pali
Panjabi
Persian
Polski
Português
Downloaded From Disc-Player.com Philips Manuals
6
7375
7165
7383
7384
7269
7465
7486
7576
7578
7583
7575
7587
7577
8287
7589
7586
7579
7574
7585
7679
7665
7686
7666
7673
7678
7684
7666
7775
7771
7285
7776
7784
7186
7773
7782
7772
7779
7778
7865
7886
7868
7882
7871
7876
7869
7879
8369
7868
7878
7967
6785
7982
7977
7983
8073
8065
7065
8076
8084
Pushto
Russian
Quechua
Raeto-Romance
Romanian
Rundi
Samoan
Sango
Sanskrit
Sardinian
Serbian
Shona
Shqip
Sindhi
Sinhalese
Slovensky
Slovenian
Somali
Sotho; Southern
South Ndebele
Sundanese
Suomi
Swahili
Swati
Svenska
Tagalog
Tahitian
Tajik
Tamil
Tatar
Telugu
Thai
Tibetan
Tigrinya
Tonga (Tonga Islands)
Tsonga
Tswana
Türkçe
Turkmen
Twi
Uighur
Ukrainian
Urdu
Uzbek
Vietnamese
Volapuk
Walloon
Welsh
Wolof
Xhosa
Yiddish
Yoruba
Zulu
8083
8285
8185
8277
8279
8278
8377
8371
8365
8367
8382
8378
8381
8368
8373
8373
8376
8379
8384
7882
8385
7073
8387
8383
8386
8476
8489
8471
8465
8484
8469
8472
6679
8473
8479
8483
8478
8482
8475
8487
8571
8575
8582
8590
8673
8679
8765
6789
8779
8872
8973
8979
9085
English
Index
Français
English ------------------------------------------------ 8
Español
Français -------------------------------------------- 41
Deutsch
Español --------------------------------------------- 73
Nederlands
Deutsch ------------------------------------------- 105
Italiano
Nederlands -------------------------------------- 138
Svenska
Italiano -------------------------------------------- 171
Dansk
Svenska ------------------------------------------- 204
Dansk --------------------------------------------- 237
Downloaded From Disc-Player.com Philips Manuals
7
Contents
English
General Information
Disc Operations
Features ................................................................ 10
Discs for playback .............................................. 10
Supplied accessories .......................................... 10
Environmental information .............................. 11
Care and safety information ...................... 11-12
Playing discs ......................................................... 24
Using the disc menu .......................................... 24
Basic playback controls ............................... 24-26
Pausing playback
Selecting a track/chapter/title
Resuming playback from the last stopped
point
Zoom
Repeat
Repeat A-B
Program
Forward/Reverse Searching
Time search & search by chapter/track
number
Information display during playback
Special disc features ........................................... 26
Playing a Title
Camera Angle
Changing the Audio Language
Changing the Audio Channel
Subtitles
Playing MP3/WMA disc ..................................... 27
General operation
Playback selection
Playing JPEG Picture CD ................................... 27
General operation
Playback selection
Special JPEG features ......................................... 28
Zoom picture
Slide show playback modes
Playback with multi-angles
Playing a DivX disc ............................................. 28
Connections
Step 1: Placing speakers .................................... 13
Step 2: Connecting speakers ............................ 14
Step 3: Antenna connection ............................. 14
Step 4: Connecting TV ................................. 14-16
Using SCART jack
Using Video In jack
Using S-Video In jack
Using an accessory RF modulator
Step 5: Connecting the power cord ............... 16
Optional: Connecting additional equipment 1617
Controls
Controls on the system .................................... 18
Controls on the remote control .............. 18-19
Preparations
Step 1: Inserting batteries into the remote
control .................................................................. 20
Using the remote control to operate the
system
Step 2: Setting the clock ................................... 20
Step 3: Setting video preference ............... 21-22
Step 4: Setting language preference ................ 22
Basic Functions
Switching the system on ................................... 23
Switching the system to Eco Power Standby
mode ..................................................................... 23
Power-saving automatic standby ..................... 23
Sound control ..................................................... 23
DBB
Volume control ................................................... 23
Downloaded From Disc-Player.com Philips Manuals
8
English
Contents
System Menu Options
Basic operations ................................................. 29
SYSTEM SETUP ............................................ 29-31
TV SYSTEM
SCREEN SAVER
TV TYPE
PASSWORD
RATING
DEFAULT
DIVX(R) VOD registration code
LANGUAGE SETUP .......................................... 31
VIDEO SETUP .................................................... 31
BRIGHTNESS
CONTRAST
HUE
SATURATION
AUDIO SETUP ............................................. 31-32
DIGITAL OUT
DOWNMIX
3D PROCESSING
LPCM
NIGHT MODE
Radio Reception
Tuning to radio stations .................................... 33
Programming radio stations ............................. 33
Automatic programming ............................... 33
Manual programming ...................................... 33
Tuning to preset radio stations ....................... 33
RDS ....................................................................... 34
Setting the RDS clock ....................................... 34
Tape Operation/Recording
Tape playback ...................................................... 35
General information on recording ................. 35
Preparation for recording ................................ 36
Synchro start CD recording ............................ 36
One touch recording ......................................... 36
Clock/Timer
Clock setting ....................................................... 37
Timer setting ....................................................... 37
Sleep timer setting ............................................. 37
Specifications ........................................... 38
Troubleshooting .............................. 39-40
Glossary ......................................................... 41
Downloaded From Disc-Player.com Philips Manuals
9
General Information
English
Features
Additional Component Connections
Lets you connect other audio and audio/visual
components to the system so you can use the
system’s surround sound speakers.
Parental control (rating level)
Lets you set a rating level so that your children
cannot watch a DVD that has a rating higher
than you set.
The following formats can’t be supported
• The files like *.VMA, *.AAC, *.DLF, *.M3U,
*.PLS, *.WAV,
• The discs recorded under Joliet format
Region Codes
DVDs must be labeled for ALL regions or Region
2 in order to play on this DVD system. You
cannot play discs that are labeled for other
regions.
Sleep timer
Enables the system to switch to standby mode
automatically at a preset time.
Night Mode
Lets you compress the dynamic range, reducing
the difference in loudness between different
sounds in Dolby Digital mode.
Discs for playback
Your DVD System will play:
– Digital Video Discs (DVDs)
– Video CDs (VCDs)
– Super Video CDs (SVCDs)
– Digital Video Discs + Rewritable (DVD+RW)
– Compact Discs (CDs)
– Picture (Kodak, JPEG) files on CDR(W)
– Windows Media Audio (WMA)
– DivX(R) disc on CD-R(W):
– DivX 3.11, 4.x and 5.x
– Supported MP3-CD format.
• ISO 9660 / UDF format
• Max. title/album name –10 characters
• Max. title number plus album is 255.
• Max. nested directory is 8 levels.
• The max. album number is 32.
• The max. MP3 track number is 999.
• Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
• Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
Downloaded From Disc-Player.com Philips Manuals
10
ALL
2
Notes:
– For mixed mode discs, only one mode will be
selected for playback according to the recording
format.
– If you are having trouble playing a certain disc,
remove the disc and try a different one. Improperly
formatted discs will not play on this system.
– DTS surround audio output is not available in
this DVD player.
Supplied accessories
–
–
–
–
Composite video cable (yellow)
MW loop antenna
FM wire antenna
Remote Control and two AA batteries
– This instruction booklet and a quick start guide
Environmental information
Any unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Do not block the vents
● Do not operate the system in an enclosed
cabinet and allow about 10 cm (4 inches) of free
space all around the player for adequate
ventilation.
10 cm
(4 inches)
10 cm
(4 inches)
DVD Micro Hi-Fi System
10 cm
(4 inches)
Care and safety information
Avoid high temperatures, moisture,
water and dust
● Do not expose the system, batteries or discs to
humidity, rain, sand or excessive heat (caused by
heating equipment or direct sunlight). Always
keep disc trays closed to avoid dust buildup on
the lens.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers table-cloths, curtains, etc.
Cleaning the cabinet
● Use soft cloth slightly moistened
with a mild detergent solution.
Do not use a solution containing
alcohol, spirits, ammonia or
abrasives.
Cleaning discs
● The apparatus shall not be exposed to dripping
or splashing.
● To clean a CD, wipe it in a straight line from the
center towards the edge using soft and lint-free
cloth. A cleaning agent may damage the disc.
Avoid condensation problem
● The lens may cloud over when the player is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the player in the warm environment until
the moisture evaporates.
● Write only on the printed side of a CDR(W)
and only with a soft felt-tipped pen.
● Handle the disc by its edge. Do not touch the
surface.
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
Downloaded From Disc-Player.com Philips Manuals
11
English
General Information/Maintenance
General Information/Maintenance
English
Finding a suitable location
● Place the player on a flat, hard, stable surface.
● Install this unit near the AC outlet and where the
AC power plug can be reached easily.
Cleaning the head and the tape paths
● To ensure good recording and playback quality,
clean the head A, the capstan(s) B, and
pressure roller(s) C after every 50 hours of
tape operation.
● Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
● You also can clean the head by playing a
cleaning tape once.
Disposal of your old product
Your product is designed and
manufactured with high quality
materials and components,
which can be recycled and
reused.
C
B A
B
C
Demagnetising the head
● Use a demagnetising tape available at your
dealer.
When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do
not dispose of your old products with your
normal household waste. The correct disposal of
your old product will help prevent potential
negative consequences for the environment and
human health.
Downloaded From Disc-Player.com Philips Manuals
12
English
Connections
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
AUDIO
IN
FM wire
antenna
MW loop
antenna
S-VIDEO
IN
TV IN
VIDEO IN
DIGITAL
OUT
speaker
(right)
R
LINE OUT
speaker
(left)
L
L
R
MW ANTENNA
FM ANTENNA
AUX/
CDR IN
SUB
WOOFER OUT
+
R
L
+
SPEAKERS 8Ω
5
AC power cord
IMPORTANT!
– The type plate is located at the rear of
the system.
– Before connecting the AC power cord
to the wall outlet, ensure that all other
connections have been made.
– Never make or change any
connections with the power switched on.
– High voltage! Do not open.You run the
risk of getting an electric shock.
– The machine does not contain any userserviceable parts.
– Modification of the product could result
in hazardous radiation of EMC or other
unsafe operation.
To avoid overheating of the system, a
safety circuit has been built in.Therefore,
your system may switch to Standby
mode automatically under extreme
conditions. If this happens, let the system
cool down before reusing it (not available
for all versions).
Downloaded From Disc-Player.com Philips Manuals
Step 1: Placing speakers
Front
speaker
( right )
Front
speaker
( left )
VIEWING AREA
Place the front left and right speakers at equal
distances from the TV set and at an angle of
approximately 45 degrees from the listening
position.
Notes:
– To avoid magnetic interference, do not position
the front speakers too close to your TV set.
– Allow adequate ventilation around the DVD
System.
13
Connections
English
Step 2: Connecting speakers
1
FM Antenna
2
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-". Fully inser t
the stripped portion of the speaker wire into the
terminal as shown.
● For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
Step 4: Connecting TV
Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
– For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Step 3: Antenna connection
IMPORTANT!
– You only need to make one video
connection from the following options,
depending on the capabilities of your TV
system.
– Connect the DVD system directly to
the TV.
– A SCART connection will let you use
features both Audio and Video on the
DVD Player.
Using SCART jack
Connect the supplied MW loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
MW Antenna
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
MW
DIGITAL
OUT
R
R
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
Downloaded From Disc-Player.com Philips Manuals
14
LINE OUT
L
L
MW ANTENNA
FM ANTENNA
● Use the SCART cable (black) to connect the
DVD Player’s SCART jack (SCART OUT) to
the corresponding Scart input jacks on the TV
(cable not supplied).
English
Connections
Using S-Video In jack
AUDIO
IN
Note:
– Ensure that the “TV” indication on SCART cable
is connected to the TV set and “DVD” indication on
SCART cable is connected to the DVD Player.
S-VIDEO
IN
TV IN
VIDEO IN
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
2
1
Using Video In jack (CVBS)
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
DIGITAL
OUT
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
R
1
LINE OUT
L
2
R
L
MW ANTENNA
FM ANTENNA
AUX/
1
2
DIGITAL
OUT
R
R
1
2
LINE OUT
L
L
MW ANTENNA
FM ANTENNA
Use the S-Video cable (not supplied) to connect
the system's S-VIDEO OUT jack to the SVideo input jack (or labelled as Y/C or S-VHS)
on the TV set.
To hear the sound of this DVD Player through
your TV, use the audio cables (white/red-not
supplied) to connect LINE OUT (L/R) jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Use the composite video cable (yellow) to
connect the system's VIDEO OUT jack to the
video input jack (or labelled as A/V In, Video In,
Composite or Baseband) on the TV set.
To hear the sound of this DVD Player through
your TV, use the audio cables (white/red-not
supplied) to connect LINE OUT (L/R) jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Downloaded From Disc-Player.com Philips Manuals
15
Connections
English
Using an accessory RF modulator
IMPORTANT!
– If your TV set only has a single
Antenna In jack (or labelled as 75 ohm or
RF In), you will need a RF modulator in
order to view the DVD playback via TV.
See your electronics retailer or contact
Philips for details on RF modulator
availability and operations.
Step 5: Connecting the power
cord
IMPORTANT!
– Never make or change any connection
with the power switched on.
After everything is connected properly, plug in
the AC power cord to the power outlet.
Optional: Connecting additional
equipment
RF coaxial cable to TV
2
Back of RF Modulator
(example only)
ANT IN
TO TV
VIDEO
IN
AUDIO IN
R
L
CH3 CH4
Antenna or
Cable TV signal
AUDIO
IN
S-VIDEO
IN
TV IN
VIDEO IN
1
IMPORTANT!
– Some discs are copy-protected.You
cannot record the disc through a VCR or
digital recording device.
– When making connections, make sure
the colour of cables matches the colour
of jacks.
– Always refer to the owner's manual of
the other equipment for complete
connection and usage details.
AUDIO OUT
L
DIGITAL
OUT
R
1
Use the composite cable (yellow) to connect the
system's VIDEO OUT jack to the video input
jack on the RF modulator.
R
LINE OUT
L
A
R
L
AUX/
CDR IN
2 Use an RF coaxial cable (not supplied) to
SUB
WOOFER OUT
connect the RF modulator to your TV's RF jack.
+
R
AUDIO
INPUT
L
+
B
Downloaded From Disc-Player.com Philips Manuals
16
SPEAKERS 8Ω
MW AN
English
Connections
Viewing and listening to the playback of
other equipment A
Connect the system's AUX (R/L) jacks to the
AUDIO OUT jacks on the other audio/visual
device (such as a TV, VCR, Laser Disc player or
cassette deck).
Before starting operation, press SOURCE on
the front panel to select AUX or press AUX on
the remote in order to activate the input source.
Connecting an active subwoofer B
Connect the DVD micro system's
SUBWOOFER OUT jack to the AUDIO
INPUT jack on an active subwoofer (not
supplied).
VIDEO IN
AUDIO IN
L
R
C
DIGITAL
OUT
D
R
LINE OUT
L
DIGITAL IN
L
R
MW ANTENNA
FM ANTENNA
AUX/
CDR IN
SUB
WOOFER OUT
Using the VCR for recording DVDs C
Connect one of the system's VIDEO OUT
jacks to the corresponding VIDEO IN jack and
LINE OUT (R/L) jacks to the AUDIO IN jacks
on the VCR. This will allow you to make analogue
stereo (two channel, right and left) recordings.
Recording (digital) D
Connect the system's DIGITAL OUT jack to
the DIGITAL IN jack on a digital recording
device (such as DTS-Digital Theatre compatible,
with Dolby Digital decoder).
Before star ting operation, set the DIGITAL OUT
according to the audio connection. (See “System
Menu Options-DIGITAL OUT”.)
Downloaded From Disc-Player.com Philips Manuals
17
Controls
English
Controls on the system
1 ECO POWER/STANDBY-ON y
# RECORD
–
$ CLOCK SET/RDS
to switch the system on or to Eco power/normal
standby mode.
–
*for Clock .......... (on the system only) to set the
clock function.
for tuner ............. displays RDS information.
2 Display screen
–
to view the current status of the system.
% iR sensor
3 SOURCE
–
to start recording.
to select the respective sound source : DVD
TAPE, AUX or TUNER.
4 BAND / DISPLAY
for Tuner ............. to select waveband : FM or MW.
for DVD/VCD/CD/MP3-CD displays disc
information on the TV screen
and system display panel during
playback.
5 PROGRAM
for VCD/CD/MP3-CD…to program disc tracks.
for Tuner ............. to program preset radio stations.
–
infrared sensor for remote control.
^ OPEN•CLOSE ç
–
to open or close the disc tray.
&
DSC
selects different types of preset sound equalizer
settings (FLAT, CLASSIC, JAZZ, POP or ROCK).
–
*
–
–
DBB/INCREDIBLE SURROUND
to create a super-enhanced stereo effect.
to enhance the bass.
(n
–
to connect headphones.
6 PRESET í/ë
7
for Tuner ............. to select a preset radio station.
for DVD/VCD/CD/MP3 CD… to select a
desired track.
TUNING 22/33
*for DVD/VCD/CD................... to fast reverse/
forward the disc. (It is impossible to fast reverse /
forward for MP3-CD)
for Tuner ............. to tune to a lower or higher
radio frequency.
for Tape ............... to rewind or fast forward.
Controls on the remote control
1y
–
2 Numeric Keypad (0-9)
–
–
–
–
–
0 ÉÅ
4
–
–
to start or interrupt playback.
!9
for DVD/VCD/CD/MP3-CD…to stop playback
or to clear a program.
for Tape ............... to stop playback or recording.
inputs a track/title/chapter number of the disc.
3 PROGRAM
8 Tape deck
9 OPEN/CLOSE ç
to open the tape compartment.
switches the system on/off.
5
–
DVD/VCD/CD/MP3-CD: enters the program
menu.
Picture CD: during playback, to select a slide
show mode.
Tuner: programs preset radio stations.
SOURCE
to select the respective sound source : DISC
TUNER, TAPE or AUX.
SYSTEM MENU (disc mode only)
to enter or exit the system menu bar.
@ VOLUME
–
–
to increase or decrease the volume.
to adjust the hours and minutes for the clock/
timer functions.
* = Press and hold the button for more than three seconds.
Downloaded From Disc-Player.com Philips Manuals
18
6 DISC MENU (disc mode only)
–
–
DVD/VCD: enters or exits the disc contents
menu.
VCD2.0: switches the playback control mode on
or off .
7 22/33
–
–
–
–
Tuner
press to tune to a lower/higher radio frequency
gradually.
press and hold, then release the key to start
automatic search for a radio frequency
downward/upward.
Disc
(not for MP3 CD) searches backward/forward in
a disc at different speeds.
In DISC mode, to select a movement direction in
the disc menu or system menu bar.
* DSC
–
( DBB
–
enables or disables bass enhancement.
)
MUTE
to interrupt or resume sound reproduction.
–
¡ DISPLAY (OSD)
–
In DISC mode, to select a movement direction in
the disc menu or system menu bar.
9 OK
–
to exit or confirm the selection.
–
–
Disc: skips to the previous/next chapter/title/
track.
Tuner: selects a preset radio station.
(unavailable for this version)
to select various repeat modes or the shuffle
play mode for a disc.
≤ A-B
–
–
for VCD/CD: to repeat a specific section within
the same track.
for DVD: to repeat a specific section in a disc.
∞ AUDIO
–
0 í/ë
–
displays information on TV screen during
playback.
™ ECHO
£ MODE
8 3/4
–
selects different types of preset sound equalizer
settings (FLAT, CLASSIC, JAZZ, POP or ROCK).
–
for VCD
sets Stereo, Mono-Left or Mono-Right sound
mode.
for DVD
selects an audio language.
§ TIMER
! STOP 9
*– to set the timer.
–
≥ ZOOM
In DISC mode, to stop playback or clear a
program.
@ PLAY/PAUSE 2;
–
In DISC mode, to start or interrupt playback.
# VOL +/–
–
–
adjusts the volume upward/downward.
adjusts the hours and minutes in clock/timer
setting mode.
switches the set timer ON or OFF.
$ ANGLE
–
selects a DVD camera angle.
% SUBTITLE
–
selects a subtitle language.
^
SLEEP
to set the sleep (auto-off) timer function.
–
&
–
–
DVD/VCD/Picture CD: enlarges or reduces a
picture or active image on the TV screen.
• KEY (unavailable for this version)
ª GOTO
–
In DISC mode, to fast search in a disc by
entering a time, title, chapter or track.
Notes for remote control:
– First, select the source you wish to
control by pressing one of the source select
keys on the remote control (DISC or
TUNER, for example).
– Then select the desired function ( 2;, í,
ë for example).
IS
to create a super-enhanced stereo effect.
* = Press and hold the button for more than three seconds.
Downloaded From Disc-Player.com Philips Manuals
19
English
Controls
Preparations
English
IMPORTANT!
– Make sure to complete the
preparation procedures before operating
the system.
Step 1: Inserting batteries into
the remote control
1
2
3
2
3
1
2
Place two batteries (Type R06 or AA) in the
compartment with the correct polarity as
indicated by “+” and “–” symbols.
Close the cover.
Point the remote control directly
at the remote sensor (iR) on the
front panel.
Select the source you wish to
control by pressing one of the
source select buttons on the
remote control (for example
DISC, TUNER).
PRESET
T
Then select the desired function
(for example 2;, í, ë).
CAUTION!
– Remove batteries if they are
exhausted or will not be used for a long
time.
– Do not use old and new or different
types of batteries in combination.
– Batteries contain chemical substances,
so they should be disposed of properly.
Downloaded From Disc-Player.com Philips Manuals
20
Go to Standby mode.
Press and hold CLOCK SET/RDS on the
front panel.
➜ “SET CLOCK” is displayed briefly. Then, the
hour digits flash on the display screen.
3
Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
hours.
4
Press CLOCK SET/RDS again.
➜ The minute digits flash on the display screen.
5
Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
minutes.
6
Press CLOCK SET/RDS to confirm the clock
setting.
Open the battery compartment.
Using the remote control to operate the
system
1
Step 2: Setting the clock
Notes:
– This system only supports 24-hour mode.
– The clock setting will be erased when the system
is disconnected from the power supply.
– The system will exit clock setting mode if no
button is pressed within 30 seconds.
Step 3: Setting video
preference
PAL
– If the connected TV is PAL system, select this
mode. It will change the video signal of a NTSC
disc and output in PAL format.
IMPORTANT!
– Make sure you have completed all the
necessary connections. (See
"Connections-Connecting TV".)
AUTO
– If the connected TV is multi system, select this
mode.The output format will be in accordance
with the video signal of the disc.
–
Setting TV TYPE
Select the aspect ratio of the TV to be
connected.
Turn on the TV set and set it to the correct
Video-In channel.
➜ You may go to channel 1 on your TV set, then
press the channel button repeatedly until you see
the Video In channel.
➜ Or, you can use the TV remote control to
select different video modes.
➜ Or, set TV to channel 3 or 4 if you are using
an RF modulator.
1
2
In stop mode or during playback, press
SYSTEM MENU.
Press 22/33/5/4 on the remote control to
toggle through the functions and select your
preferential option.
4:3 PS (Pan and Scan mode )
– If you have a conventional TV set and your
DVD is not formatted for widescreen viewing,
use this setting. A wide picture is displayed on
the whole TV screen with a por tion
automatically cut off.
4:3 LB (Letterbox mode )
– If you have a conventional TV set and your
DVD is formatted for widescreen viewing, use
this setting. A wide picture with bands displayed
on the upper and lower portions of the TV
screen.
➜ Move to SYSTEM SETUP and press 4.
➜ Move to one of the following and press 33.
–
Setting TV SYSTEM
Allows you to select the colour system matching
the connected TV set.
NTSC
– If the connected TV is NTSC system, select
this mode. It will change the video signal of a PAL
disc and output in NTSC format.
Downloaded From Disc-Player.com Philips Manuals
16:9 (Wide screen mode)
– If you have a widescreen TV set, use this
setting (you must also set your widescreen TV to
“full size”) available on a disc, then the disc’s own
preference will be used.
21
English
Preparations
Preparations
English
Note:
The format you select must be available on the
disc. If it is not, the setting for TV Type will not affect
the picture during playback.
OSD LANGUAGE (On-Screen Display)
Switches the display language on the TV screen.
Select the language from the displayed list.
AUDIO LANG (DVD only)
Switches the display language of the sound track.
Select the language from the displayed list.
To exit the menu
Press SYSTEM MENU again.
SUBTITLE LANG (DVD only)
Switches the display language of the subtitle.
Select the language from the displayed list.
Step 4: Setting language
preference
MENU LANG (DVD only)
Select the language for the DVD menu.
You can select your preferred language settings
so that this DVD Micro System will automatically
switch to the language for you whenever you
load a disc. If the language selected is not
available on the disc, the language set by default
will be used instead. But the menu language of
the DVD Micro System cannot be changed once
selected.
When the selected language is not recorded in
the DVD, one of the recorded languages will be
selected automatically (except for OSD).
You can reset all the DVD settings except for
Rating.
If the language selected is not available on the
disc, the original language designated by each
disc will be selected.
3
4
ITALIAN
Press 5/4 to select a language and press OK.
Repeat steps 2~3 for other settings.
To exit the menu
Press SYSTEM MENU again.
1
2
In stop mode or during playback, press
SYSTEM MENU.
Press 22/33/5/4 on the remote control to
select your preferred option.
➜ Move to LANGUAGE SETUP and press
4.
➜ Move to one of the following and press 33.
Downloaded From Disc-Player.com Philips Manuals
22
Switching the system on
● Press ECO POWER/STANDBY-ON B (B
on the remote).
➜ “HELLO” is displayed briefly. The system will
switch to the last selected source.
● Press SOURCE repeatedly (or DISC,
TUNER, TAPE or AUX on the remote).
➜ The system will switch to the selected source.
Switching the system to Eco
Power Standby mode
Volume control
Turn the VOLUME control on the front panel
clockwise or anticlockwise or press VOL +/- on
the remote to increase or decrease the volume
level.
➜ ”VOLUME XX” is displayed on the display
panel. “XX” denotes the volume level.
To listen through the headphone
● Connect the headphone plug to the n socket
on the top of the back side of the DVD player.
➜ The speakers will be muted.
● Press ECO POWER/STANDBY-ON B in
the active mode.
➜ The system enters Eco power standby (the
ECO POWER LED is on) or normal standby
with clock display.
To switch off the volume temporarily
● Press MUTE on the remote.
➜ Playback will continue without sound and
“MUTE” flashes.
● The volume level (up to a maximum volume
level of 12), interactive sound settings, last
selected mode, source and tuner presets will be
retained in the player's memory.
● To activate sound reproduction, you can:
– press MUTE again;
– adjust the volume controls;
– change source.
● If the system is normal standby with clock display,
press and hold ECO POWER/STANDBYON Bfor 3 seconds or more to switch to Eco
power standby or vice versa.
Power-saving automatic standby
As a power-saving feature, the system will
automatically switch to Standby mode if you do
not press any buttons within 15 minutes after a
disc has stopped playing.
Sound Control
● Press DSC repeatedly to select the desired
sound effect: FLAT, CLASSIC, JAZZ, POP or
ROCK.
● Press DBB/INCREDIBLE SURROUND on
the system to switch on or off the surround
sound effect or bass enhancement.
● You can also press DBB or IS on the remote to
turn on or off the DBB or IS function
respectively.
Note:
– The effect of INCREDIBLE SURROUND may
vary with different types of music.
Downloaded From Disc-Player.com Philips Manuals
23
English
Basic Functions
Disc Operations
English
IMPORTANT!
– This system is designed for regular
discs. Therefore, do not use any
accessories such as disc stabiliser rings or
disc treatment sheets, etc., as offered on
the market, because they may jam the
disc mechanism.
– Do not move the system during
playback. Doing so may damage the
system.
– DVD discs and players are designed
with regional restrictions. Before playing
a disc, make sure the disc matches the
regional code of your player.
– According to the format requirement
of DVD or VCD, some operations may be
different or restricted.
– Do not push on the disc tray or put
any objects other than disc on the disc
tray. Doing so may cause the disc player
malfunction.
– If appears on the TV screen when a
button is pressed, it means the function
is not available on the current disc at the
current time.
Using the disc menu
For disc with Table Of Contents, a menu may
appear on the TV screen once you load the disc.
To select a playback feature or item
● Use 22/33/5/4 and OK or Numeric
Keypad (0-9) on the remote.
➜ Playback will start automatically.
To access or exit the menu
●
For VCD with Playback Control (PBC)
feature (version 2.0 only)
PBC playback allows you to play Video CDs
interactively, following the menu on the display.
● During playback, press DISC MENU.
➜ If PBC was ON, it will switch to OFF and
continue playback.
➜ If PBC was OFF, it will switch to ON and
return to menu screen.
Basic playback controls
Pausing playback (DVD/VCD/CD/MP3
/WMA)
Playing discs
1
2
3
4
Connect the power cords of the system and TV
(or any optional stereo or AV receiver) to a
power outlet.
Turn on the TV power and set to the correct
Video In channel. (See "Setting up the TV".)
Press ECO POWER/STANDBY-ON 2 on
the DVD Player front panel or 2 on the
remote.
➜ You should see the blue Philips DVD
background screen on the TV.
1
During playback, press PLAY/PAUSE 2;.
➜ Playback will pause and sound will be muted.
2
Press PLAY/PAUSE 2; again to resume.
Selecting a track/chapter/title (DVD/
VCD/CD/MP3/WMA)
1
2
Press OPEN•CLOSE3 to open the disc door
and load in a disc, then press the same button
again to close the disc door.
➜ Make sure the label side is facing up.
Press PRESET í/ë during playback to go to
the previous or next chapter/title/track.
To go directly to any chapter/ title/track, enter
the chapter/ title/track number using the
Numeric Keypad (0-9).
Resuming playback from the last
stopped point (DVD/VCD/CD/MP3
/WMA)
5
Playback will start automatically (depending on
the disc type).
➜ If a disc menu appears on the TV, see "Using
the Disc Menu".
➜ If the disc is locked by parental control, you
must enter your four-digit password. (See
"SYSTEM SETUP-PASSWORD".)
6 At any time, simply press STOP 9 to stop
playback.
Downloaded From Disc-Player.com Philips Manuals
24
Press DISC MENU on the remote.
● In stop mode and when a disc has not been
removed, press PLAY/PAUSE 2;.
To cancel resume mode
●
In stop mode, press STOP 9 again.
Zoom (DVD/VCD/JPEG)
1
2
Program (not for Picture CD)
Zooming allows you to enlarge or reduce the
video image during playback.
Press ZOOM repeatedly to enlarge or reduce
the playback video image.
To select favourite tracks/chapters for playback in
preferred sequence.
Press 22/33/5/4 to pan across the TV
screen.
Repeat (DVD/VCD/CD/MP3/WMA)
● Press MODE repeatedly to choose a repeat
mode during playback.
For DVD
CHAPTER
– to repeat playback of the current chapter.
TITLE
– to repeat playback of the current title.
1
2
Press PROGRAM to enter the program mode.
3
Move the cursor by pressing 22/33/5/4 to
select PLAY.
4
Press OK to start playback.
Use the Numerical Keypad (0-9) to directly
input the tracks or chapters.
OFF
– switches off the repeat mode.
For VCD/MP3/CD
REP 1
– to repeat playback of the current track.
REP ALL
– to repeat playback of the whole disc.
REPEAT ALL SHUFFLE
– to repeat playback of the whole disc in
random order.
REPEAT ALL SHUFFLE OFF
– switches off the repeat mode.
Repeat A-B (DVD/VCD/CD/MP3/WMA)
1
2
Press A-B at your chosen starting point.
3
To exit the sequence, press A-B again.
➜ “A-B CANCEL” is displayed on the TV
screen.
Press A-B again at your chosen end point.
➜ The section A and B can be set only within
the same chapter/track.
➜ The section will now repeat continuously.
Downloaded From Disc-Player.com Philips Manuals
25
English
Disc Operations
Disc Operations
English
Special disc features
Forward/Reverse Searching (DVD/VCD/
CD/MP3/WMA)
1
2
Press TUNING 22/33 during playback to
select the required speed: 2X, 4X, 8X or 20X
(backward or forward).
➜ Sound will be muted.
To return to normal speed, press PLAY/
PAUSE 2;.
Playing a Title (DVD)
1
Press DISC MENU.
➜ The disc title menu appears on the TV screen.
2
3
Use 22/33/5/4 to select a play option.
Press OK to confirm.
Camera Angle (DVD)
Note:
The 22/33 buttons on the remote cannot be
used in forward/reverse searching for MP3/WMA
discs.
Time search & search by chapter/track
number (DVD/VCD/CD/MP3/WMA)
1
2
Press GOTO until the time or chapter/track
edit box appears.
Enter hours, minutes and seconds from left to
right in the time edit box using the Numeric
Keypad (0-9) on the remote.
OR
Enter your desired chapter/track number in the
chapter/track edit box using the Numeric
Keypad (0-9) on the remote.
Information display during playback
(DVD/VCD/CD/MP3/WMA)
● During playback, press DISPLAY to show disc
information on the TV screen.
For DVD/VCD/CD
➜ Elapsed playback time of the current track/
chapter.
➜ Remaining playback time of the current track/
title.
➜ Elapsed playback time of the whole disc.
➜ Remaining playback time of the whole disc.
➜ Display off.
For MP3 CD
➜ Elapsed playback time of the current track.
➜ Remaining playback time of the current track.
Downloaded From Disc-Player.com Philips Manuals
26
● Press ANGLE repeatedly to select different
desired angle.
Changing the Audio Language (for DVD
recorded with multiple languages)
● Press AUDIO repeatedly to select different
audio languages.
Changing the Audio Channel (for VCD
only)
● Press AUDIO to select the available audio
channels provided by the disc (Mono Left, Mono
Right or Stereo).
Subtitles (DVD)
● Press SUBTITLE repeatedly to select different
subtitle languages.
Playing MP3/WMA/JPEG Disc
Playing JPEG Picture CD
IMPORTANT!
– You have to turn on your TV and set to
the correct Video In channel. (See
"Setting up the TV".)
General operation
Playing MP3/WMA disc
General operation
1
2
Load an MP3/WMA disc.
➜ A data disc menu appears on the TV screen
and playback starts automatically from the first
track.
Press 22 to move to the album column on the
left of the TV screen, then use 5/4 to select an
album and press OK to open it.
1
English
Disc Operations
Load a JPEG Picture CD.
➜ A data disc menu appears on the TV screen
and playback starts automatically from the first
file.
2
Press 22 to move to the folder column on
the left of the TV screen, then use 5/4 to
select a folder and press OK to open it.
3
Press 33 to move to the file column on the
right of the TV screen and then use 5/4 to
highlight a file; or directly use the Numeric
Keypad (0-9) to input a file number.
4
Press OK to confirm.
Playback selection
During playback, you can:
● Press PRESET í/ë to select another file in
the current folder.
● Use 22/33/5/4 on the remote to rotate/
flip the picture files.
3
Press 33 to move to the track column on the
right of the TV screen and then use 5/4 to
highlight a track; or directly use the Numeric
Keypad (0-9) to input a track number.
4
Press OK to confirm.
➜ The playback will start from the selected
track to the end of the album.
● Press PLAY/PAUSE 2; repeatedly to pause/
resume playback.
● Press STOP 9 to stop playback and return to
the disc content menu.
Note:
The disc reading time may exceed 10 seconds due
to large number of songs compiled onto the disc.
Playback selection
During playback, you can:
● Press PRESET í/ë to select another track in
the current album.
● Press PLAY/PAUSE 2; repeatedly to pause/
resume playback.
Downloaded From Disc-Player.com Philips Manuals
27
Disc Operations
English
Special JPEG features
Playing a DivX disc
Zoom picture (JPEG)
This DVD player supports the DivX movie
playback that you download from your
computer onto a CD-R/RW (see “System Menu
Options-DIVX(R) VOD registration code” for
more information).
Load a DivX disc.
➜ Playback will start automatically. If not press
PLAY/PAUSEÉÅ.
● During playback, press ZOOM repeatedly to
display the picture with different scales (X2, X3,
X4, X1/2, X1/3 and X1/4).
● Use 22/33/5/4 to view the enlarged
picture.
Slide show playback modes (JPEG)
● During playback, press PROGRAM repeatedly
to select different slide-show playback modes:
Mode 0: NONE
Mode 1: WIPE TOP
Mode 2: WIPE BOTTOM
Mode 3: WIPE L
Mode 4: WIPE R
Mode 5: DIAGONAL L TOP
Mode 6: DIAGONAL R TOP
Mode 7: DIAGONAL L BOTTOM
Mode 8: DIAGONAL R BOTTOM
Mode 9: EXTEND CENTER H
Mode 10: EXTEND CENTER V
Mode 11: COMPRESS CENTER H
Mode 12: COMPRESS CENTER V
Mode 13: WINDOW H
Mode 14: WINDOW V
Mode 15: EDGE TO CENTER
Mode 16: RANDOM
Playback with multi-angles (JPEG)
● During playback, press 22/33/5/4 to rotate
the picture on the TV screen.
5: flip the picture vertically.
4: flip the picture horizontally.
22: rotate the picture anti-clockwise.
33: rotate the picture clockwise.
Downloaded From Disc-Player.com Philips Manuals
28
1
2
If the DivX movie contains external subtitles, the
subtitle menu will appear on the TV screen for
your selection.
● In this case, pressing SUBTITLE on the remote
control will turn on or off the subtitle.
● If multilingual subtitles are embedded on the
DivX disc, pressing SUBTITLE will change the
subtitle language during playback.
Note:
– Subtitle files with the following filename
extensions (.srt, .smi, .sub, .ssa, .ass) are supported
but do not appear on the file navigation menu.
– The subtitle filename have to be the same as
the filename of the movie.
English
System Menu Options
Basic operations
1
Press SYSTEM MENU to enter the Setup
Menu.
2
3
4
5
Press 22/33 to select a page to be set.
6
Press 5/4 to highlight an option.
Enter its submenu by pressing 33 or OK.
Move the cursor by pressing 5/4 to highlight
the selected item.
➜ In cases of value setting, press 5/4 to adjust
values.
Press OK to confirm.
➜ ON: In STOP, PAUSE or No DISC mode, if
no actions are performed about 5 minutes, the
screen saver will be activated.
➜ OFF: Screen saver is disabled.
To return to the upper-level menu
TV TYPE
See "Preparations-Step 3: Setting video
preference" for details.
● Press 22.
To exit from the menu
PASSWORD
● Press SYSTEM MENU again.
➜ The settings will be stored in the player’s
memory even if the player is switched off.
You can enter your four-digit password to
activate or deactivate rating control.
➜"
" is displayed if rating control is activated.
➜"
" is displayed if rating control is
deactivated.
Note:
– Some of the features in the System Menu
Options are described in “Preparations”.
SYSTEM SETUP
The options included in SYSTEM SETUP page
are: “TV SYSTEM”, “SCREEN SAVER”, “TV TYPE”,
“PASSWORD”, “RATING”, “DEFAULT”and
“DIVX(R) VOD”.
To change password
1
Move to "PASSWORD" and press 33 or OK
to enter its submenu.
2
DIVX(R) VOD
TV SYSTEM
See "Preparations-Step 3: Setting video
preference" for details.
SCREEN SAVER
This function is used to turn the screen saver on
or off.
Downloaded From Disc-Player.com Philips Manuals
If " " is displayed, enter the default password
(0000) and press OK to unlock.
● If " " is displayed, directly proceed with Step 3
and 4.
3 Enter your new four-digit password using
Numeric Keypad (0-9) on the remote.
4 Press OK to confirm and the new password
takes effect.
Note:
– The default password (0000) is always active
even if the password has been changed.
29
System Menu Options
English
4 PG 13
– Material is unsuitable for children under age
13. Parental Guidance suggested.
RATING
Some DVDs may have a parental level assigned
to the complete disc or to certain scenes on the
disc. This feature lets you set a playback limitation
level.
The rating levels are from 1 to 8 and are country
dependent. You can prohibit the playing of
certain discs that are not suitable for your
children or have certain discs played with
alternative scenes.
5-6 PG-R, R
– Parental Guidance – Restricted;
recommended that parents restrict children
under 17 from viewing or allow them to view
only when supervised by a parent or adult
guardian.
7 NC-17
– No children under age 17; not recommended
for children under age 17.
8 ADULT
– Material for adults only; viewed only by adults
due to graphic sexual scenes, violence, or
language.
DEFAULT
Setting the “Default” function will reset all
options and your personal settings to the factory
defaults and all your personal settings will be
erased.
● VCD, SVCD and CD have no level indication, so
parental control function has no effect on those
kinds of discs. This applies to most illegal DVD
discs.
1
2
3
Press 5/4 to highlight “RATING”.
Enter its submenu by pressing 33.
Use 5/4 to highlight a rating level for the disc
inserted.
➜ DVDs that are rated above the level you
selected will not play unless you enter your fourdigit password and choose a higher level rating.
Note:
– Some DVDs are not encoded with a rating
though the movie rating may be printed on the
Disc cover.The rating level feature does not work
for such Discs.
Rating explanations
1 KID SAFE
– Suitable for children.
2G
– General Audience; recommended as
acceptable for viewers of all ages.
3 PG
– Parental Guidance suggested.
Downloaded From Disc-Player.com Philips Manuals
30
1
2
3
Press 5/4 to highlight “DEFAULT”.
Highlight RESTORE by pressing 33.
Press OK to confirm selection.
Caution!
– When this function is activated, all
settings will be reset to factory defaults.
English
System Menu Options
DIVX(R) VOD registration code
1
Philips provides you the DivX® VOD (Video On
Demand) registration code that allows you to
rent and purchase videos using the DivX® VOD
service.
For more information, visit us at www.divx.com/
vod.
In SYSTEM SETUP page, press 3 4 to highlight
DIVX(R) VOD, then press 33 or OK to ener
its submenu and press OK again to confirm.
➜ The registration code will appear.
XR8954E9
DONE
2
3
Press OK to exit.
Use the registration code to purchase or rent
the videos from DivX® VOD service at
www.divx.com/vod. Follow the instructions and
download the video onto a CD-R for playback
on this DVD player.
Notes:
– All the downloaded videos from DivX® VOD can
only be played back on this DVD player.
– Time search feature is not available during DivX
movie playback.
LANGUAGE SETUP
The options included in LANGUAGE SETUP
page are: "OSD LANGUAGE", "AUDIO LANG",
"SUBTITLE LANG" and "MENU LANG".
See "Preparations-Step 4: Setting language
preference" for details.
COMPONENT
Sets the video output according to your video
connection. This setting is not required if you are
using the VIDEO OUT jack (yellow) to
connect the DVD micro system to your TV.
➜ SVIDEO: Select this if you have connected
the DVD micro system to your TV using S-Video
jack.
➜ TV-RGB: Select this if you have connected
the DVD micro system to your TV using SCART
jack.
BRIGHTNESS
Adjusts the brightness level. Range: 0-12.
CONTRAST
Adjusts the contrast level. Range: 0-12.
HUE
Adjusts the hue level. Range: -6-+6.
SATURATION
Adjusts the saturation level. Range: 0-12.
Note:
The default setting of “TV MODE” cannot be
changed (“INTERLACE” ).
AUDIO SETUP
The options included in AUDIO SETUP page
are: "DIGITAL OUT", "DOWNMIX", "3D
PROCESSING", "LPCM" and "NIGHT MODE".
VIDEO SETUP
The options included in VIDEO SETUP page are:
"COMPONENT", "TV MODE", "BRIGHTNESS",
"CONTRAST", "HUE" and "SATURATION".
Downloaded From Disc-Player.com Philips Manuals
31
System Menu Options
English
DIGITAL OUT
➜ DIGITAL/OFF: Turns off the digital output.
➜ DIGITAL/RAW: If you have connected
your DIGITAL OUT to a multi-channel decoder/
receiver.
➜ DIGITAL/PCM: Only if your receiver is not
capable of decoding multi-channel audio.
DOWNMIX
This options allows you to set the stereo
analogue output of your DVD Player.
➜ LT/RT: Select this option if your DVD Player
is connected to a Dolby Pro Logic decoder.
➜ STEREO: Select this option when output
delivers sound from only the two front speakers.
➜ VSS: Allows the DVD player to use virtual
surround sound effects.
3D PROCESSING
3D processing provides a virtual surround sound
experience using just two speakers.
➜ OFF, CONCERT, CHURCH, PASSIVE,
WIDE and LIVE
LPCM
If you connect the DVD Player to a PCM
compatible receiver via the coaxial terminal, you
may need to adjust 'LPCM'.
Discs are recorded at a certain sampling rate.
The higher the sampling rate, the better the
sound quality.
➜ 48kHz: Playback a disc recorded at the
sampling rate of 48kHz.
➜ 96kHz: Playback a disc recorded at the
sampling rate of 96kHz.
➜ 192kHz: Playback a disc recorded at the
sampling rate of 192kHz.
NIGHT MODE
➜ OFF: Select this when you want to enjoy the
surround sound with its full dynamic range.
➜ ON: Select this to level out the volume. High
volume outputs will be softened and low volume
outputs are brought upward to an audible level.
This feature is only available for movies with
Dolby Digital mode.
Downloaded From Disc-Player.com Philips Manuals
32
English
Radio Reception
ECO POWER
BAND
RECORD
STANDBY-ON
DISPLAY
M C D 5 1 5 DV D M I C RO T H E AT R E
iR
PRESET
SOURCE
TUNING
PROGRAM
VOLUME
DSC
DBB
INCREDIBLE
SURROUND
ANGLE
A-B
MODE
PROGRAM
OPEN/
Tuning to radio stations
1
Select TUNER source.
➜ “FM” or “MW” is displayed.
2
Press BAND/DISPLAY (TUNER on the
remote) to select the desired waveband : FM or
MW.
3
4
Manual programming
1
Tune to your desired station (refer to “Tuning to
radio stations”).
2
Press PROGRAM to activate programming.
➜ PROG flashes on the display, in which X stands
for the programme number.
Press and hold TUNING 22/33 and then
release it.
➜ The display will show "SEARCH" until a radio
station with sufficient signal strength is found.
3
Press PRESET í/ë to allocate a number
from 1 to 20 for this station.
4
Press PROGRAM again to confirm the setting.
➜ The frequency of the preset station is shown.
Repeat step 3 if necessary until you find the
desired station.
5
● To tune to a weak station, press TUNING
22/33 briefly and repeatedly until you have
found optimal reception.
Programming radio stations
You can store up to 40 radio stations in the
memory (20 for FM and 20 for MW).
Automatic programming
Press PROGRAM for more than three
seconds to activate programming.
➜ All available stations are programmed.
➜ AUTO is displayed and available stations are
programmed in order of waveband.
Downloaded From Disc-Player.com Philips Manuals
Repeat the above four steps to store other
stations.
● You can override a preset station by storing
another frequency in its place.
Note:
– During setting, if no button is pressed within 30
seconds, the system will exit manual programming
automatically.
Tuning to preset radio stations
● Press PRESET í/ë until the desired preset
station is displayed.
33
Radio Reception
English
RDS
Radio Data System is a service that allows
FM stations to show additional information. If
you are receiving a RDS station,
and the
station name are displayed.
When automatic programming is used, RDS
stations will be programmed first.
Scrolling through different RDS
information
● Press CLOCK SET/RDS briefly and
repeatedly to scroll through the following
information (if available):
– Station name
– Radio text messages
– Frequency
Setting the RDS clock
Some RDS radio station may be transmitting a
real clock time at an interval of every minute. It
is possible to set the clock by using a time signal
which is broadcast together with the RDS signal.
1
Tuned to an RDS station from FM band (refer to
“Tuning to radio stations”).
2
Press and hold CLOCK SET/RDS for more
than two seconds.
3
Press CLOCK SET/RDS again.
➜ "SEARCH TM" is displayed.
➜ When RDS time is read, “RDS” and RDS time
time value are displayed and the current time
will be stored.
Note:
– Some RDS radio station may be transmitting a
real time clock at a minute interval. The accuracy
of the transmitted time depends on the
transmitting RDS radio station.
Downloaded From Disc-Player.com Philips Manuals
34
English
Tape Operation/Recording
5
PRESET
T H E AT H R E
TUNING
ANGLE
IS
Tape playback
1
2
3
Select TAPE source.
Press OPEN/CLOSE ç to open the tape
door.
Insert a recorded tape and close the tape door.
A-B
MODE
PROGRAM
DSC
General information on
recording
● For recording, use only NORMAL (IEC type I)
tapes on which the tabs have not yet been
broken. This deck is not suitable for recording on
METAL (IEC IV) type tapes.
● Load the tape with the open side downward
and the full spool to the left.
4 Press ÉÅ on the system to start playback.
● The best recording level is set automatically.
Altering the VOLUME, INCREDIBLE
SURROUND or DBB will not affect the
recording in progress.
To stop playback
● Press STOP9.
● At the very beginning and end of the tape, no
recording will take place during the 7 seconds
when the leader tape passes the recorder heads.
Rewinding / Fast forwarding
1
Stop playback, press TUNING 22/33.
➜ The tape will stop automatically at the end of
rewinding or fast forwarding.
2
Press STOP9 to stop rewinding or fast
forwarding.
● To protect a tape from accidental erasure, have
the tape in front of you and break out the left
tab. Recording on this side is no longer possible.
If, however, you wish to record over this side
again, cover the tabs with a piece of adhesive
tape.
IMPORTANT!
Recording is permissible if copyright or
other rights of third parties are not
infringed upon.
Downloaded From Disc-Player.com Philips Manuals
35
Tape Operation/Recording
English
Preparation for recording
1
2
3
Select TAPE source.
Load a recordable tape into the tape deck with
the full spool to the left.
Prepare the source to be recorded.
DISC – load the disc.
TUNER – tune to the desired radio station.
AUX – connect external equipment.
When recording is in progress
● To stop recording, press STOP9.
● It is not possible to activate the timer function.
Synchro start CD recording (for
CD only)
1
Select DISC source.
● You can programme the tracks in the order you
want them to be recorded (refer to “Disc
Operations - Programming favorite tracks”).
2
Press RECORD to start recording.
➜ Playing of the disc programme starts
automatically. It is not necessary to start the
DVD player separately.
One touch recording
1
2
Select DISC, TUNER or AUX source.
3
Press RECORD to start recording.
If necessary, start playback of the selected
source.
The making of unauthorized copies of
copy-protected material, including
computer programmes, files, broadcasts
and sound recordings, may be an
infringement of copyrights and constitute
a criminal offence.This equipment should
not be used for such purposes.
Downloaded From Disc-Player.com Philips Manuals
36
English
Clock/Timer
5
PRESET
T H E AT H R E
TUNING
ANGLE
IS
Clock setting
4
See "Preparations-Step 2: Setting the clock".
Timer setting
● The system can be used as an alarm clock,
whereby the last selected source is switched on
at a set time (one time operation). The clock
time needs to be set first before the timer can
be used.
A-B
MODE
PROGRAM
DSC
Turn the VOLUME control on the front panel
or press VOL +/- on the remote to activate or
deactivate the timer and press TIMER on the
remote to complete the setting.
if activated, and disappears
➜ Display shows
if deactivated.
Sleep timer setting
The sleep timer enables the system to switch off
by itself after a set period of time.
1
In standby mode, press and hold TIMER on the
remote for more than three seconds.
➜ "SET TIMER" is displayed briefly. Then, the
hour digits flash on the display panel.
2
Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
hours and press TIMER on the remote to
confirm.
➜ The minute digits flash on the display panel.
2
Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
minutes and press TIMER on the remote to
confirm.
➜ "ON" or "OFF" flashes.
To deactivate the sleep timer
● Press SLEEP repeatedly until "0FF" is displayed,
or press ECO POWER/STANDBY ON y.
3
Downloaded From Disc-Player.com Philips Manuals
1
Press SLEEP on the remote control repeatedly
to select a preset time.
➜ The selections are as follows (time in
minutes):
0FF™010 ™ 020 ™ 030 ™ 040 ™ 050 ™
060 ™ 070 ™ 080 ™ 090™ 0FF
➜ "SLEEP XX" is displayed. "XX" is the time in
minutes.
When you reach the desired length of time, stop
pressing the SLEEP button.
37
Specifications
English
AMPLIFIER
Output power ....................................... 2 x 50 W RMS
......................................................................... 1000 W MPO
Signal-to-noise ratio ....................................... ≥ 60 dBA
Frequency response ......... 63 – 16000 Hz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeakers ......................................... 8 Ω
Impedance headphones .................... 32 Ω -1000 Ω
DVD PLAYER
Laser Type ................................................ Semiconductor
Disc Diameter .............................................. 12cm / 8cm
Video Decoding ........................... MPEG-2 / MPEG-1
Video DAC ................................................................ 10 Bits
Signal System ............................................... PAL / NTSC
Video Format ..................................................... 4:3 / 16:9
Video S/N ........................................... 56 dB (minimum)
Composite Video Output ................ 1.0 Vp-p, 75 Ω
S-Video Output ............................. Y - 1.0 Vp-p, 75 Ω
........................................................... C - 0.286 Vp-p, 75 Ω
Audio DAC .......................................... 24 Bits / 96 kHz
Frequency Response .... 4 Hz - 20 kHz (44.1kHz)
...................................................... 4 Hz - 22 kHz (48kHz)
...................................................... 4 Hz - 44 kHz (96kHz)
Digital Output .........................................................................
....... SPDIF (Sony Philips digital interface) Coaxial
Number of programmable tracks ......................... 16
Signal-to-noise ratio ....................................... ≥ 65 dBA
Channel separation .......................... ≥ 40 dB (1 kHz)
Total harmonic distortion ............... < 0.1% (1 kHz)
TUNER
FM wave range ................................... 87.5 – 108 MHz
MW wave range ................................ 531 – 1602 kHz
Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion ..................................... ≤ 5%
Frequency response ............ 63 – 5500 Hz (-6 dB)
Signal-to-noise-ratio ...................................... ≥ 50 dBA
TAPE DECK
Frequency response
Normal tape (type I) ...... 125 – 6300 Hz (8 dB)
Signal-to-noise ratio
Normal tape (type I) .................................... 40 dBA
Wow and flutter ......................................... ≤ 0.4% DIN
SPEAKERS
2-way bass reflex system
Dimensions (w x h x d) . 170 x 252 x 214 (mm)
GENERAL INFORMATION
AC Power ........................................ 220-240V / 50 Hz
Dimensions (w x h x d) .. 175 x 252 x 305 (mm)
Weight(with/without speakers) ............. 8.1 /4.0 kg
Standby power consumption ............................ ≤ 7W
Eco power Standby ................................................ < 1W
Specifications and external appearance are
subject to change without notice.
Downloaded From Disc-Player.com Philips Manuals
38
English
Troubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will
invalidate the warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If
you are unable to remedy a problem by following these hints, consult your dealer or
Philips for help.
Problem
No power.
Solution
✔ Check if the AC power cord is properly
connected.
“NO DISC” is displayed.
✔ Check if the disc is inserted upside down.
✔ Wait until the moisture condensed at the lens
has cleared.
✔ Replace or clean the disc, see “Maintenance”.
✔ Use a readable disc or correctly recorded format
MP3-CD.
No picture.
✔ Select the appropriate video input mode on the
TV set.
✔ Check if the TV set is switched on.
✔ Check the video connection.
✔ Check if the system is securely connected.
Distorted or poor picture.
✔ Sometimes a slight picture distor tion may appear.
This is not a malfunction.
✔ Clean the disc.
✔ Connect the system to the S-video input of your
TV set.
The aspect ratio of the screen cannot be
changed even though you have set the TV
shape.
✔ The aspect ratio is fixed on the DVD disc.
✔ The aspect ratio may not be changed for some
The DVD player does not start playback.
✔ Insert a readable disc.
✔ Check the disc type, color system and region
TV systems.
code.
✔ Clean the disc.
✔ Place the disc with the playback side down.
✔ Press SYSTEM MENU to turn off the setup
menu.
✔ Cancel the parental control rating function or
change the rating level.
✔ Moisture has condensed inside the system.
Remove the disc and leave the system turned on
for about an hour.
The DVD player does not respond when
buttons are pressed.
Downloaded From Disc-Player.com Philips Manuals
✔ Disconnect the power plug from the jack, and
insert again.
39
Troubleshooting
English
Problem
The language for the sound or subtitle
cannot be changed when playing a DVD.
Solution
✔ Multi-language sound or subtitle is not recorded
on the DVD.
✔ Changing the language for the sound or subtitle
is prohibited on the DVD.
No image is output when a function is
selected.
✔ Make sure the component is connected
correctly.
✔ Press the correct function button for the input
source.
Sound cannot be heard or is of poor
quality
✔
✔
✔
✔
✔
Poor radio reception.
✔ If the signal is too weak, adjust the antenna or
Adjust the volume.
Disconnect the headphones.
Check that the speakers are connected correctly.
Check if the stripped speaker wire is clamped.
If the system is in pause, slow motion or fast
forward/reverse mode, press PLAY/PAUSE 2;
to resume the normal play mode.
✔ Make sure the MP3-CD was recorded within 32256 kbps bit rate with sampling frequencies at
48 kHz, 44.1 kHz or 32 kHz.
✔ Ensure that the DTS disc also supports Dolby
Digital output.
connect an external antenna for better
reception.
✔ Increase the distance between the System and
your TV set or VCR.
Recording or playback cannot be made
✔ Clean deck parts, see “Maintenance”.
✔ Use only NORMAL tape.
✔ Apply a piece of adhesive tape over the missing
tab space.
Left and right sound outputs are
reversed.
✔ Check the speaker connections and location.
The remote control does not function.
✔ Point the remote control at the remote control
✔
✔
✔
✔
sensor of the unit.
Reduce the distance to the player.
Remove any possible obstacles.
Replace the batteries with new ones.
Check that the batteries are loaded correctly.
The timer is not working
✔ Set the clock correctly.
✔ If recording is in progress, stop it
The Clock/Timer setting is erased
✔ Power has been interrupted or the power cord
has been disconnected. Reset the clock/timer.
Downloaded From Disc-Player.com Philips Manuals
40
Analog: Sound that has not been turned into
numbers. Analog sound varies, while digital sound
has specific numerical values. These jacks send
audio through two channels, the left and right.
Aspect ratio: The ratio of vertical and
horizontal sizes of a displayed image. The
horizontal vs. vertical ratio of conventional TVs. is
4:3, and that of wide-screens is 16:9.
AUDIO OUT Jacks: Jacks on the back of the
DVD System that send audio to another system
(TV set, Stereo, etc.).
Bit Rate: The amount of data used to hold a
given length of music; measured in kilobits per
second, or kbps. Or, the speed at which you
record. Generally, the higher the bit rate better
the sound quality. However, higher bit rates use
more space on a Disc.
Chapter: Sections of a picture or a music
piece on a DVD that are smaller than titles. A
title is composed of several chapters. Each
chapter is assigned a chapter number enabling
you to locate the chapter you want.
Disc menu: A screen display prepared for the
selection of images, sound, subtitles, multi-angles,
etc recorded on a DVD.
Digital: Sound that has been converted into
numerical values. Digital sound is available when
you use the DIGITAL AUDIO OUT COAXIAL
or OPTICAL jacks. These jacks send audio
through multiple channels, instead of just two
channels as analog does.
Dolby Digital: A surround sound system
developed by Dolby Laboratories containing up
to six channels of digital audio (front left and
right, surround left and right and center).
JPEG: A still-picture data compression system
proposed by the Joint Photographic Expert
Group, which features small decrease in image
quality in spite of its high compression ratio.
MP3: A file format with a sound data
compression system, “MPE” is the abbreviation of
Motion Picture Experts Group 1 (or MPEG-1)
Audio Layer 3. Through the MP3 format, one
CD-R or CD-RW can contain about 10 times as
much data volume as a regular CD can.
Multichannel: DVD is specified to have all
sound tracks constitute one sound field.
Multichannel refers to a structure of sound
tracks having three or more channels.
Parental control: A function of the DVD to
limit playback of the disc by the age of the users
according to the limitation level in each country.
The limitation varies from disc to disc; when it is
Downloaded From Disc-Player.com Philips Manuals
activated, playback will be prohibited if the
software’s level is higher than the user-set level.
PCM (Pulse Code Modulation): A system
for converting analog sound signal to digital
signal for later processing without data
compression.
Playback control (PBC): Refers to the signal
recorded on video CDs or SVCDs for
reproduction control. By using screen menus
recorded on a Video CD or SVCD that supports
PBC, you can enjoy interactive-type software as
well as software having a search function.
Region code: A system allowing discs to be
played only in preset regions. This unit will only
play discs that have compatible region codes.You
can find the region code of your unit from the
product label. Some discs are compatible with
more than one region (or ALL regions).
S-Video: Produces a clear picture by sending
separate signals for luminance and the color. You
can use S-Video only if your TV set has S-Video
In jack.
Sampling Frequency: Frequency of data
sampling when analog data is converted to
digital data. Sampling frequency numerically
represents how many times the original analog
signal is sampled per second.
Surround: A system for users to create
realistic three-dimensional sound fields full of
realism by arranging multiple speakers around
the listener.
Title: The longest section of a picture or music
feature on DVD, music, etc., in video software, or
the entire album in audio software. Each title is
assigned a title number enabling you to locate
the title you want.
VIDEO OUT jack: Jack on the back of the
DVD System that sends video to TV.
41
English
Glossary
