Vandal WDR Rollerball
Cameras
EV-2726-N3GQ 3.6mm, 24 IR, Gray
EV-2726-N3WQ 3.6mm, 24 IR, White
EV-2726-NFGQ 2.8~12mm, 36 IR, Gray
EV-2726-NFWQ 2.8~12mm, 36 IR, White
EV-2706-N3GQ
EV-2706-N3WQ
EV-122C-DVB3Q
EV-122C-DVH3Q
1/3”
960H Resolution.
IP65
WDR (Wide Dynamic Range) for
o
clear images in strong backlight. 3DNR (3D Digital Noise Reduction) for
cleaner images in low light.
1/3” Sony EXview HAD II CCD.
700 TV Lines.
Sony Effio-P DSP.
IR LEDs for nighttime use.
OSD (On-Screen Display) for programming special
features.
360° Triple-axis rotation.
Heavy-duty, vandal-resistant design.
Cables concealed in bracket to prevent tampering.
Split-glass design to eliminate IR reflection.
Rugged, weatherproof (IP65) construction.
Ceiling, wall-mount, and conduit brackets
available.
EV-2726-NFGQ and EV-2726-NFWQ only:
Varifocal lens with adjustable zoom and focus.
3D-NR Off
3D-NR On
WDR Off
WDR On
(Simulated images)
Indoor IR Dome Cameras
2.8~12mm Vandal Rollerball
Cameras
3.6mm Vandal Rollerball
Cameras
EV-2706-NFGQ 2.8~12mm, 700TVL, Gray
EV-2706-NFWQ 2.8~12mm, 700TVL, White
EV-122C-DVAVQ 2.8~12mm, 480TVL, Gray
EV-122C-DVHVQ 2.8~12mm, 480TVL, White
3.6mm, 700TVL, Gray
3.6mm, 700TVL, White
3.6mm, 480TVL, Gray
3.6mm, 480TVL, White
Sony Super HAD II CCD.
IP65
24 IR LEDs for nighttime use.
o
360° Triple-axis rotation.
Heavy-duty, vandal-resistant design.
Cables concealed in bracket to prevent tampering.
Split-glass design to eliminate IR reflection.
Rugged, weatherproof (IP65) construction.
Ceiling, wall-mount, and conduit brackets available.
EV-2706-N3GQ and EV-2706-N3WQ only:
960H Resolution.
3X Vandal Dome Cameras
(600TVL)
Sony Super HAD II CCD.
18 IR LEDs, up to 50ft (15m) range.
Tamper-resistant design.
Cables concealed in bracket.
Day/Night operation.
o
EV-2866-NKGQ
2.8~12mm
33 IR LEDs.
3D-NR (3D Digital Noise Reduction).
600 TV Lines.
Elite
1/3” Sony Super HAD II CCD.
IR Cut filter.
OSD (On-Screen Display) with remote.
Service monitor port for
convenient installation.
Advanced 256x DSS
(Digital Slow Shutter).
360° Triple-axis rotation.
Dual voltage: 12VDC/24VAC.
2-in-1 Housing, flush or surface mount.
EV-2766-NVWQ 4~9mm, 21 IR, 700TVL
960H Resolution.
1/3” Sony Super HAD II CCD.
Low current draw:
[email protected]
IP65
Size: 41/ 4”x31/2”
o
(108x85 mm).
Wall-mount brackets available.
2
[email protected]
(700TVL)
EV-2636-NKGQ
3X
2.8~12mm
WDR (Wide Dynamic Range), and 1/3” Pixim
Seawolf sensor.
®
2.8~12mm
IP67
960H Resolution.
o
700 TV Lines.
3D-NR (3D Digital Noise
Reduction).
DWDR (Digital Wide
Dynamic Range).
28 IR LEDs for nighttime use.
IR Cut filter.
Elite 3X
OSD (On-Screen Display)
with built-in joystick.
Service monitor port for convenient
installation.
Advanced 256x DSS (Digital Slow Shutter).
360° Triple-axis rotation.
Rugged, weatherproof (IP67) construction.
Dual voltage: 12VDC/24VAC.
2-in-1 Housing, flush or surface mount.
Mounting Brackets
1/3”
Mid-Size Vandal IR Dome Camera
IP65
36 IR LEDs for nighttime use.
o
360° Triple-axis rotation.
Heavy-duty vandal-resistant design.
Cables concealed in bracket to prevent tampering.
Split-glass design to eliminate IR reflection.
Rugged, weatherproof (IP65) construction.
Adjustable zoom and focus.
Ceiling, wall-mount, and conduit brackets available.
EV-2706-NFGQ and EV-2706-NFWQ only:
960H resolution and OSD (On-Screen Display) for
programming special features.
IP68
Similar to EV-2866-NKGQ, but with 690 TV lines,
EV-2221-N3BQ 3.6mm, 470TVL
EV-2801-N3BQ 3.6mm, 540TVL
EV-2221-NKBQ 2.8~11mm, 470TVL
Sony Super HAD II CCD.
3X Vandal Dome Camera
Series
EV-2876-UKGQ
1/3”
Model
Wall
Ceiling
Conduit Box
Conduit Drop
EV-122C-DVB3Q
EV-2706-N3GQ
EV-2726-N3GQ
EV-DWSGQ
EV-DCSGQ
EV-DSSGQ
EV-DDSGQ
EV-122C-DVH3Q
EV-2706-N3WQ
EV-2726-N3WQ
EV-DWSWQ
EV-DCSWQ
EV-DSSWQ
EV-DDSWQ
EV-122C-DVAVQ
EV-2706-NFGQ
EV-2726-NFGQ
EV-DWLGQ
EV-DCLGQ
EV-DSLGQ
EV-DDLGQ
EV-122C-DVHVQ
EV-2706-NFWQ
EV-2726-NFWQ
EV-DWLWQ
EV-DCLWQ
EV-DSLWQ
EV-DDLWQ
Tel | 604.270.0135
Toll Free | 888.270.0135
www.associatedtelephone.com
3X Bullet Cameras
42-IR LED
12- and 24-IR LED Bullet Cameras
84-IR LED Bullet Camera
EV-1826-NKGQ 2.8~12mm, 700TVL
EV-1636-NKGQ 2.8~12mm, 700TVL
EV-1636-NWGQ 6~50mm, 700TVL
IP66
o
EV-1026-N2SQ 2.9mm, 480TVL, 12 IR
EV-1606-N2SQ 2.9mm, 700TVL, 12 IR
EV-1026-N3SQ 3.6mm, 480TVL, 24 IR
EV-1606-N3SQ 3.6mm, 700TVL, 24 IR
1/3”
IP67
o
Elite 3X
960H Resolution.
3D-NR (3D Digital Noise Reduction).
DWDR (Digital Wide Dynamic Range).
IR Cut filter.
OSD (On-Screen Display) with built-in joystick.
Service monitor port for convenient installation.
Programmable 8-zone privacy settings.
Advanced 256x DSS (Digital Slow Shutter).
Dual voltage: 12VDC/24VAC.
Cables concealed in bracket to prevent tampering.
960H Resolution.
1/3” Sony Super HAD II CCD.
12VDC Operation.
Cables concealed in bracket to prevent tampering.
OSD Functions programmable with controller
(EV-18C --- sold separately).
EV-11LR
Large Round Junction Box
o
EV-11LS
Single-Gang Mounting Plate
Wide-Angle Bullet Camera
EV-1665-N2BQ 2.2mm, 700TVL
42-IR LED Bullet Cameras
960H Resolution.
12VDC Operation.
1/3” Sony Super
HAD II CCD.
IP66
2.2mm Lens
o
(170° viewing angle).
DWDR (Digital Wide Dynamic Range).
3D-NR (3D Digital Noise Reduction).
Weatherproof (IP66).
EV-1196-N6GQ 6mm, 480TVL
EV-1816-N6GQ 6mm, 700TVL
EV-1196-NKGQ 2.8~12mm, 480TVL
EV-1816-NKGQ 2.8~12mm, 700TVL
EV-1726-NKGQ 2.8~12mm, 700TVL
IP66
EV-1606-N2SQ only:
Up to 40ft (12m) range.
EV-1026-N3SQ and EV-1606-N3SQ only:
Up to 50ft (15m) range.
Optional Mounting Brackets:
3X Bullet Camera
56-IR LED
Sony Super
HAD II CCD.
Split-glass
design eliminates
IR reflection.
Low current draw:
[email protected] with IRs on.
EV-1026-N2SQ and
W e at h er pr oof
for outdoor use
Elite 3X
Mini Bullet Camera
IP66
o
1/3”
960H Resolution.
1/3” Sony Super HAD II CCD.
Dual voltage: 12VDC/24VAC.
Advanced 256x DSS (Digital Slow Shutter). OSD
(On-Screen Display) for easy programming.
DWDR (Digital Wide Dynamic Range) for clear
images in strong backlight.
3D-NR (3D Digital Noise Reduction)
for clear images in low light.
Programmable 8-zone privacy settings.
Cables concealed in bracket to prevent tampering.
56 IR LEDs for clear images in total darkness.
o
[email protected]
1/3”
Sony
Super HAD II CCD.
Weatherproof (IP66).
12VDC Operation.
Low current draw: 150mA.
Low-profile design.
o
Z eta Series OSD Controller
3.6mm, 480TVL
3.6mm, 700TVL
o
2.8~12mm, 700TVL
Withstands temperatures of -40°~122° F (-40°~50° C).
960H Resolution.
1/3” Sony Super HAD II CCD.
12VDC Operation.
Weatherproof (IP66).
3.6mm, 480TVL
IP66
IP67
IP66
EV-1125-N3BQ
30-IR LED Bullet Cameras
EV-1186-N3GQ
EV-1806-N3GQ
Low-Temperature
42-IR LED Bullet Camera
EV-1826-NKGAQ
Sony Super HAD II CCD.
12VDC Operation.
Weatherproof (6mm: IP67, 2.8~12mm: IP66).
EV-1816-N6GQ and EV-1816-NKGQ only:
960H Resolution and OSD functions programmable
with controller (EV-18C -- sold separately).
Can mount to industry
standard lampholder
cover plate.
960H Resolution.
1/3” Sony Super HAD II CCD.
12VDC Operation.
Cables concealed in bracket to prevent tampering.
Can mount to industry standard lampholder
cover plate.
