User manual | ActivPanel-Touch

Introducing the
CREATE A MORE COLLABORATIVE CLASSROOM
To enhance collaborative learning, digital interactive classrooms must integrate:
Multi-user classroom
displays and software
+
Interactive lessons designed to enable collaborative learning across
whole-class, individual, small-team and multi-team settings
THE ACTIVPANEL TOUCH IS OPTIMIZED FOR
COLLABORATIVE LEARNING
The new Promethean ActivPanel Touch transforms the
traditional “front-of-the-classroom” interactive display
into a collaborative learning center where a group of
students (up to 10 touches) can share ideas, practice
team-based problem solving, manipulate images and
edit digital content.
A WIDE RANGE OF
OPTIONS FOR
EVERY CLASSROOM
ActivGlide
Low-glare,
low-reflectivity
Full range of sizes
every seat in the house is a
frictionless surface technology
for smooth swiping and
comfortable extended use
great one with the wide viewing
available in 55”, 65”, 70” high-
angle of this LED display
definition and 84” ultra-highdefinition displays
Versatile mounting
allows educators to customize
lessons and content to meet the
options include a fixed wall
needs of their students
mount and mobile stand
Magnetic stylus or
touch interaction
Award-winning
interactive software
Flexible professional
development program
options available to help
Long-term,
worry-free use
educators unite their curriculum and
creates exceptionally smooth,
teaching styles with Promethean’s
50,000 hours of expected life
responsive and precise
ActivPanel Touch
ensures years of captivating
interactivity whether writing or
learning experiences
using multi-touch gestures
Powerful,
high-quality built-in
stereo speakers
Simple and intuitive
functionality similar to that of today’s
mobile devices with swipe, pinch,
and zoom interaction reduces the
ensure every student can focus
on the lesson being delivered
technology learning curve
Telephone and online
support available
ActivPanel Touch SPECIFICATIONS
65”
55”
SPECIFICATIONS BY MODEL
Resolution
70”
84”
ActivPanel Touch 55”
ActivPanel Touch 65”
ActivPanel Touch 70”
ActivPanel Touch 84”
Full-HD 1080p (1920 x 1080)
Full-HD 1080p (1920 x 1080)
Full-HD 1080p (1920 x 1080)
UHD 2160p (3840 x 2160)
Brightness (typical)
350 cd/ m2 (350 Nits)
360 cd/ m2 (360 Nits)
400 cd/m2 (400 Nits)
360 cd/ m2 (360 Nits)
Overall Dimensions
1290mm x 782mm x 75mm
(50.8in x 30.8in x 3.0in)
1536mm x 931mm x 85mm
(60.5in x 36.7in x 4in)
1637mm x 981mm x 96mm
(64.4in x 38.6in x 3.8in)
1954mm x 1156mm x 124mm
(76.9in x 45.5in x 4.9in)
HDMI
x4
x4
x4
x 4 (HD) x 1 (UHD)
VGA (D-Sub 15 RGB)
x1
x1
x1
x1
Component In (Video Y,Pb, Pr
& Stereo Audio)
x1
x1
x1
x1
AV-In (Composite Video
& Stereo Audio)
x1
x1
x1
x1
PC Audio (3.5mm)
x1
x1
x1
x1
USB 2.0
(for media playback)
x1
x1
x1
x1
USB 3.0
(for HD media playback)
x1
x1
x1
x1
HDMI Out
x1
x1
x1
x1
AV-Out (Composite
Video & Stereo Audio)
x1
x1
x1
x1
Optical Audio Out
x1
x1
x1
x1
Headphone Socket
x1
x1
x1
x1
Video & Audio Input
Video & Audio Output
GENERAL SPECIFICATIONS
Aspect Ratio
16:9
Surface
ActivGlideTM 4mm acid-etched tempered glass
Number of Touches
10
Response Time
8ms
Digitizing Technology
Infrared
Stereo Speakers
Integral, 2 x 10W
Presentation Functions
Blank Screen, Freeze Frame
Open Pluggable
Specification (OPS) Slot
1
Duty
18 hours per day
Interactive Software
ActivPanel Touch includes access to Promethean’s multi-user application, ActivInspire Professional Edition
software, version 1.7.62 or higher.
Packed Contents List
ActivPanel Touch, VESA mount bolts, power cable, 5m (16ft) USB cable, Infrared Remote Control, Installation
Guide, VGA cable, HDMI cable, 3.5mm audio cable, two pens, User Guide
To learn more, visit
www.PrometheanWorld.com/ActivPanel
or contact Wedgwood AV 01754 769967 www.wedgwood-group.com
