CTC Union FRM220A-GSW/SNMP Installation manual
FRM220
Hardware Installation
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center (Neihu Technology Park)
8F, No. 60 Zhouzi St.
Neihu District
Taipei 114
Taiwan
Tel:
+886-2-26591021
Fax:
+886-2-27991355
Email: info@ctcu.com
URL: http://www.ctcu.com
FRM220 Hardware Installation Manual
Fiber In-band Managed
Media Platform Rack, 20 Slot, 2U
Version 1.0 Dec. 2008 (Release)
Version 1.1 July 8, 2009 (Update, added card introductions)
Version 1.11 July 20, 2009 (Update, add management quick start)
Version 1.12 July 31, 2009 (Update, add 3R and 10G card introductions)
Version 1.13 March 4, 2010 (Update, power modules changed to 200 watt)
Version 1.14 March 22, 2010 (Update, 2.7G power consumption rating)
Version 1.15 January 6, 2011 (Update, add FiberChannel types to 10G, add NMC-R2, add, 10/100iS-2E, MD40/80,
iMUX5,8,16, Eoe1, E1/Data, Serial/FDC, TR-21, 1000TS and FTEC new cards)
Version 1.16 May 17, 2011 (Update power module specifications; change TR21 to 4G-2R)
Version 1.17 June 14, 2011 (Update, add power cord specification, add 10G series max 10 cards in CH20 warning)
Version 1.17a July 15, 2011 (Update, add protective earth wire specification, page 9)
Copyright © 2007~2011, CTC Union Technologies, Inc.
All rights reserved.
All specifications are subject to change without prior notice.
Legal
The information in this publication has been carefully checked and is believed to be entirely accurate at the time of publication.
CTC Union Technologies assumes no responsibility, however, for possible errors or omissions, or for any consequences
resulting from the use of the information contained herein. CTC Union Technologies reserves the right to make changes in its
products or product specifications with the intent to improve function or design at any time and without notice and is not
required to update this documentation to reflect such changes.
CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for any
particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product and
specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
CTC Union products are not designed, intended, or authorized for use in systems or applications intended to support or sustain
life, or for any other application in which the failure of the product could create a situation where personal injury or death may
occur. Should the Buyer purchase or use a CTC Union product for any such unintended or unauthorized application, the Buyer
shall indemnify and hold CTC Union Technologies and its officers, employees, subsidiaries, affiliates, and distributors
harmless against all claims, costs, damages, expenses, and reasonable attorney fees arising out of, either directly or indirectly,
any claim of personal injury or death that may be associated with such unintended or unauthorized use, even if such claim
alleges that CTC Union Technologies was negligent regarding the design or manufacture of said product.
TRADEMARKS
Microsoft is a registered trademark of Microsoft Corp.
HyperTerminal™ is a registered trademark of Hilgraeve Inc.
WARNING:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with the instruction manual may cause harmful interference in which case the user will be
required to correct the interference at his own expense. NOTICE: (1) The changes or modifications not expressively approved
by the party responsible for compliance could void the user's authority to operate the equipment. (2) Shielded interface cables
and AC power cord, if any, must be used in order to comply with the emission limits.
CISPR PUB.22 Class A COMPLIANCE:
This device complies with EMC directive of the European Community and meets or exceeds the following technical standard.
EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information Technology Equipment.
This device complies with CISPR Class A.
CE NOTICE
Marking by the symbol CE indicates compliance of this equipment to the EMC and LVD directives of the European
Community. Such marking is indicative that this equipment meets or exceeds the following technical standards: EN
55022:2006, Class A, EN55024:1998+A1:2001+A2:2003, and EN60950-1:2001
Table of Contents
Chapter 1 Introduction.................................................................................................................................................................. 7 1.0 Introduction.......................................................................................................................................................................... 7 1.1 Functional Description ......................................................................................................................................................... 7 1.2 Chassis Front Description .................................................................................................................................................... 7 1.3 Chassis Rear Description ..................................................................................................................................................... 8 1.4 Chassis Physical Dimensions ............................................................................................................................................... 8 1.5 Chassis Specifications.......................................................................................................................................................... 9 1.6 NMC (SNMP) ...................................................................................................................................................................... 9 1.7 Line card options................................................................................................................................................................ 10 1.7.1 FRM220-10/100i In-band managed 10/100 Fiber Media Converter ........................................................................... 10 1.7.2 FRM220-10/100iS-2 Dual Channel In-band managed 10/100 Fiber Media Converter............................................... 11 1.7.3 FRM220-10/100i-2E In-band managed 10/100 Fiber Media Converter ..................................................................... 12 1.7.4 FRM220-10/100A(S) 802.3ah In-band managed 10/100 Fiber Media Converter....................................................... 13 1.7.5 FRM220-1000EA(S) 802.3ah In-band managed Gigabit Fiber Media Converter....................................................... 14 1.7.6 FRM220-1000EDS Managed Gigabit Fiber Media Converter.................................................................................... 15 1.7.7 FRM220-E1/T1 In-band managed G.703 E1/T1(DS1) Fiber Modem......................................................................... 16 1.7.8 FRM220-Data In-band managed V.35, X.21, RS-530/449/232 Fiber Modem............................................................ 17 1.7.9 FRM220-Serial/485 In-band managed RS-485/422/232 Fiber Modem ...................................................................... 18 1.7.10 FRM220-FXO/FXS In-band managed POTS (Voice) over Fiber Modem................................................................ 19 1.7.11 FRM220-155MS SM/MM, MM/SM converter / repeater ......................................................................................... 20 1.7.12 FRM220-2.7G-2S, 2.7Gbps 3R Fiber Transponder................................................................................................... 21 1.7.13 FRM220-2.7G-3S 3R Transponder with Protection .................................................................................................. 22 1.7.14 FRM220-10G-xx 10Gbps 3R Fiber Transponder...................................................................................................... 23 1.7.15 FRM220-MD40/80 CWDM Mux/DeMux ................................................................................................................ 24 1.7.16 FRM220-iMUX Inverse Multiplexer Blades............................................................................................................. 25 1.7.17 FRM220-Eoe1 Ethernet over E1 Converter .............................................................................................................. 26 1.7.18 FRM220-E1/Data DSU/CSU Converter Card ........................................................................................................... 27 1.7.19 FRM220-FTEC E1/T1 Cross Rate Converter Card................................................................................................... 28 1.7.20 FRM220-1000TS GbE to Gigabit Fiber Converter Card........................................................................................... 29 1.7.21 FRM220-4G 2R 4.25G Transponder Card ................................................................................................................ 30 1.7.22 FRM220-Serial/FDC RS-485/RS-232 Fiber Ring Converter Card ........................................................................... 31 1.7.23 FRM220-FOM04 4xE1/T1 +100M Ethernet Fiber Optical Multiplexer Card .......................................................... 32 Chapter 2 Installation.................................................................................................................................................................. 33 2.1 Introduction....................................................................................................................................................................... 33 2.2 Site Preparation ................................................................................................................................................................. 33 2.3 Mechanical Assembly ....................................................................................................................................................... 33 2.3.1 Rack mounting............................................................................................................................................................. 33 2.3.2 Fan Units Removal/Replacement ................................................................................................................................ 34 2.3.3 Line Card Conversion, Stand-alone/Rack ................................................................................................................... 34 2.4 Electrical Installation ........................................................................................................................................................ 35 2.5 Alarm Installation.............................................................................................................................................................. 35 2.6 Chassis Cascade ................................................................................................................................................................ 36 2.7 Power Modules Removal/Replacement ............................................................................................................................ 37 2.8 Installation......................................................................................................................................................................... 38 2.6.1 Line Card Installation .................................................................................................................................................. 38 2.6.2 NMC Card Installation ................................................................................................................................................ 38 Chapter 3. Management Quick Start............................................................................................................................................ 39 3.1 Introduction........................................................................................................................................................................ 39 3.2 Management Methods........................................................................................................................................................ 39 3.3 Console Terminal ............................................................................................................................................................... 39 3.3.1 Terminal Connection & Settings ................................................................................................................................. 39 3.3.2 Terminal Login............................................................................................................................................................ 39 3.3.3 TCP/IP Setup ............................................................................................................................................................... 40 3.3.4 Test TCP/IP Connection.............................................................................................................................................. 40 3.4 Telnet Terminal.................................................................................................................................................................. 41 3.5 Web Based Manager .......................................................................................................................................................... 41 3.6 Element Management System (EMS) ................................................................................................................................ 42 i
Table of Contents
ii
Chapter 1 Introduction
Chapter 1 Introduction
1.0 Introduction
Thank you for choosing the FRM220 Platform Fiber Media Converter Rack. If you would like to skip right to the
installation of the Converter Chassis, proceed to Chapters 2.
This manual is used to explain the hardware installation procedures for the FRM220, and present its
capabilities and specifications. This manual is divided into 2 Sections, the Introduction and Installation, plus the
Appendix. The Appendix includes further information on options for placing the device in service.
Installers should carefully read the Chapter 2, Installation and the Cabling Specification Appendix. The
companion document, the FRM220 NMC Configuration Manual, is available in electronic format only. The
divisions in that manual are intended for use by personnel to answer questions in general areas. Planners and
potential purchasers may read the Introduction to determine the suitability of the product to its intended use;
Operating Personnel would use the Operations and Web Based Management Chapters and Appendices to
become familiar with the line cards and settings. Network Administrators should read the chapters on Operation,
Web Based Management and Trouble Shooting to become familiar with the diagnostic capabilities, network
settings and management strategies for the SNMP managed chassis.
1.1 Functional Description
The FRM220-CH20 is a 2U high 19" Rack, 20 slot modular media converter center. The FRM220 provides an
economic solution for high density Fiber Converter installations in enterprises or central offices. All critical
components, Power, fans, management module and interface cards are hot swappable allowing online field
replacement. An additional feature allows the FRM220 to detect the working or failing status either of power module
or any fan assembly in the unit and activate relays that can be used to control external alarm devices.
There are 19 slots available for installation of FRM220 Converter Cards in the FRM220 compact rack. An
SNMP Card is installed in the far left hand, or first slot, for local and remote management purposes. Each FRM
Card is an independent fiber to copper converter. When linked to a compatible FRM stand-alone or "I" series FMC
(Fiber Media Converter) stand-alone converter, complete in-band management is supported. All settings of the line
card and remote connected stand-alone device may be managed through any of the available management
interfaces. A variety of cards are or will be available that support multi-mode or single-mode fiber types and
connections to SC, ST, FC or even the latest bi-directional single fiber WDM (Wave Division Multiplexing) in ranges
from 2Km to 120Km. Converter cards will include Fast Ethernet, Gigabit Ethernet, Serial (RS-485, RS-232 and RS422), ITU-T G.703 E1 and T1, Synchronous and Asynchronous Datacom (V.35, RS-530, X.21, RS-449, and RS232), 155.52M STM-1 repeater, FXO/FXS over fiber and more as the product matures.
The FRM220 optionally incorporates redundant power modules. The supply, depending on the model, derives
its power from either an AC power source (100 ~ 240VAC) and/or DC power source (36-60VDC). When two
modules are installed, they provide for power redundancy and are hot swappable even during the FRM220 Line
Cards' transmissions. The FRM220 provides all copper interface connections on the face of each FRM220 Line
Card. The fiber interface connectors are also located on the individual FRM220 Line Card's face, along with status
indicator LEDs. The status LED indicators provide for quick indications of both copper and fiber link statuses and
fault detection.
1.2 Chassis Front Description
The front of the FRM220 contains the line card slots. They are numbered 1 through 20, from left to right as
viewed from the front. The typical configuration is with one NMC (Network Management Controller) card in slot
number 1 and in-band manageable line cards in any other slot numbered 2 through 20.
FRM220 Series In-Band Managed
Media Converter Cards
Console Port (DB9F RS-232 Async)
115,200, 8, N, 1-DCE
NMC
10/100Base-TX Ethernet
Figure 1-1 Chassis Front View
7
Chapter 1 Introduction
1.5 Chassis Specifications
Environment
Temperature
Humidity
-10 - 50°C Ambient (14-122°F)
5-95% non condensing
Alarm relay contact ratings
125VAC
110VDC
30VDC
1A
0.6A
4A
Power Module Specifications
AC Power Module
Input : Universal, 100 ~ 240 ±10% VAC; Frequency : 50/60 Hz
Output : DC 12V, 200W maximum rating
Connector : C14 (IEC 60320-1)
DC Power Module
Input : 36 ~ 60 VDC
Output : DC 12V, 200W maximum rating
Connector : 3 connector terminal block
AC Power Cord Specification (detachable cord, C13 connector, with national plug per national standards)
6A rated 18AWG (conductors with a minimum cross-section area of 0.75 mm2)
DC Power Cord Specification (wiring must comply with EN 60950-1:2006 standard)
Conductors with a minimum cross-section area of 1mm2 (16AWG)
Protective Earth (PE) Specification (wiring must comply with EN 60950-1:2006 standard)
Conductor with a minimum cross-section area of 0.75mm2 (18AWG), star washer and non-self-tapping M3.5 screw
Power Consumption
~60 watts (fully loaded chassis, with random mix of line card types)
Heat Generation
~210 BTU (fully loaded chassis, with random mix of line card types)
Compliance
European Union : EN55022:2006, Class A, EN55024:1998+A1:2001+A2:2003, and EN60950-1:2001
FCC : part 15, subpart B, class A
Reliability
MTTB : >65,000 hours (25°C)
Physical Specifications
Dimensions : 438mm (Width) x 302mm (Depth) x 88mm (Height)
(US: 17 1/4" wide x 11 7/8" deep x 3 1/2" high)
Weight : 4.5Kg (US: ~10 lbs)
AC module weight : 690g (US 1.5 lbs)
DC module weight : 505g (US 1.2 lbs)
Fan module weight : 200g (US 0.5 lbs)
NMC card weight : 120g (US 0.25 lbs)
Net Weight : 6.2kgs (US 13 lbs 11 oz)
(with 1 NMC, 2 fan modules, 1 AC +1 DC power module & two bracket panels for 19" rack-mounting)
Fully Populated Reference Net Weight: 8.4Kg (US 18.5 lbs.)
(fully loaded, two powers, NMC and 19 pcs 10/100i line cards)
1.6 NMC (SNMP)
The FRM220 must be ordered with an NMC Card. The card is placed in the far left, number one card slot.
Management is accomplished either via local control on the asynchronous RS-232 port with an ASCII terminal or
via Ethernet and any standard SNMP network management software that supports MIB-II. The WEB GUI based
interface provides an easy method for the user to operate and monitor the whole system. Almost all FRM line cards
support remote in-band configuration when paired with the same type FRM220 stand-alone in-band converter.
9
Chapter 1 Introduction
1.7 Line card options
The FRM220 is capable of supporting a variety of in-band managed or non-managed line card types which
may be mixed and matched in any slot of the rack. See below for a brief of the linecards at the time of this printing.
Please refer to the latest version of FRM220 NMC User Manual for details of all the line card options for the
FRM220.
1.7.1 FRM220-10/100i In-band managed 10/100 Fiber Media Converter
The FRM-10/100i (in-band converter) is an In-band Managed (OAM) Fiber Ethernet media converter (MC) that
supports 10Base-T or 100Base-TX and converts to 100Base-FX (fiber). The UTP side supports auto-negotiation or
forced settings for speed and duplex by setting as well as auto-MDIX. When the FRM-10/100i is placed in the
FRM220 with NMC, the settings are controlled by the chassis management system. The remote FRM-10/100i
stand-alone may also be configured from the FRM220 through the in-band management features (OAM). An
optional console manageable single slot chassis, the CH01M, is also available with DB9F connector for standalone serial console management.
Features
• Supports Loop Back Test
• Auto-Cross over for MDI/MDIX in TP port
• Supports far end fault (FEF) function via OAM
• Auto-Negotiation or Manual mode in TP port
• Supports link fault pass through (LFP) function
• Bandwidth control (32K or 512Kbps x N)
CPU
• Forward 2046 bytes (max.) packets in switch mode
Chip
• Forward 9K jumbo packets in converter mode
• Supports forwarding mode option
• Store and forward (switch) mode, Convert mode (small latency)
• Supports local or remote In-band management (Monitor and
Configure status) by the SNMP manager in FRM220
• Supports remote CPE power fail detection (Dying gasp)
• Provides Auto Laser Shutdown (ALS) function
• Supports Fiber Hardware Reset (FHR) function
• Provides fiber transceiver information for management
• Supports On-Line In-band F/W upgrade (local or remote) by the
• SNMP manager in FRM220
Fiber
(SC Type)
LED
Indicators
10/100
Ethernet
10/100i is a media converter that
must be placed in FRM220-CH20
for management.
It utilizes fixed transceiver for
100Base-FX fiber connection and
one 10/100 Ethernet electrical port.
Specifications
Complies with IEEE 802.3 and IEEE 802.3u
288kb packet buffer in switch mode
1K MAC address table in switch mode
Supports IEEE802.3x flow control in switch mode
OAM is based on TS-1000 protocol
10Base-T UTP Cable Requirement
Cable type: Category 3, 4 or 5. Maximum distance: 100 meters (328 feet)
100Base-TX UTP Cable Requirement
Cable type: Category 5, minimum. Maximum distance: 100 meters (328 feet)
Management
The 10/100i line card is managed by an on-card CPU when installed in the FRM220 CH20 chassis. There are
no DIP switches or manual settings. If the MC is placed stand-alone, without local or remote connection to FRM220
NMC management, the MC runs with default parameter. The default parameters are: switch mode, autonegotiation, LFP disabled, ALS (Auto Laser Shutdown) disabled, and no bandwidth limit. An optional console
manageable single slot chassis, the CH01M, is available with DB9F connector for stand-alone serial console
management.
This product includes the following models:
• FRM220-10/100i (1 electrical plus 1 Fixed transceiver media converter)
• FRM220-10/100iS (1 electrical plus 1 SFP media converter)
10
Chapter 1 Introduction
1.7.2 FRM220-10/100iS-2 Dual Channel In-band managed 10/100 Fiber Media Converter
The FRM-10/100iS-2 (in-band converter) is a Dual Channel (2 converters in 1 card) In-band Managed (OAM)
Fiber Ethernet media converter (MC) that supports 10Base-T or 100Base-TX and converts to 100Base-FX (fiber).
The UTP side supports auto-negotiation or forced settings for speed and duplex by setting as well as auto-MDIX.
When the FRM-10/100iS-2 is placed in the FRM220 with NMC, the settings are controlled by the chassis
management system. The remote FRM-10/100i stand-alone may also be configured from the FRM220 through the
in-band management features (OAM).
Features
• Dual Converter on a single card (2 independent channels)
• Supports Loop Back Test
Fiber SFP
• Auto-Cross over for MDI/MDIX in TP port
(LC Type)
• Supports far end fault (FEF) function via OAM
• Auto-Negotiation or Manual mode in TP port
• Supports link fault pass through (LFP) function
CPU
• Bandwidth control (32K or 512Kbps x N)
Chip
LED
• Forward 2046 bytes (max.) packets in switch mode
Indicators
• Forward 9K jumbo packets in converter mode
10/100
• Supports forwarding mode option
Ethernet
• Store and forward (switch) mode, Convert mode (small latency)
• Supports local or remote In-band management (Monitor and
Configure status) by the SNMP manager in FRM220
• Supports remote CPE power fail detection (Dying gasp)
Dual Channel (2-in-1)
• Provides Auto Laser Shutdown (ALS) function
Ethernet Converter
• Supports Fiber Hardware Reset (FHR) function
• Provides fiber transceiver information for management
• Supports On-Line In-band F/W upgrade (local or remote) by the
• SNMP manager in FRM220
10/100iS-2 is a dual channel media
Specifications
converter that must be placed in
Complies with IEEE 802.3 and IEEE 802.3u
FRM220-CH20 for management.
288kb packet buffer in switch mode
It utilizes SFP for fiber connection
1K MAC address table in switch mode
and two 10/100 Ethernet electrical
Supports IEEE802.3x flow control in switch mode
ports.
OAM is based on TS-1000 protocol
Compliance: FCC part 15, Subpart B, Class A,
ANSI C63.4:2003
CE EN55022:2006, Class A
EN55024:1998+A1:2001+A2:2003
LVD: EN60950-1:2001
MTBF: 65,000 h (25°C)
10Base-T UTP Cable Requirement
Cable type: Category 3, 4 or 5. Maximum distance: 100 meters (328 feet)
100Base-TX UTP Cable Requirement
Cable type: Category 5, minimum. Maximum distance: 100 meters (328 feet)
Management
The 10/100iS-2 card is managed by an on-card CPU when installed in the FRM220 CH20 chassis. There are
no DIP switches or manual settings. If the MC is placed stand-alone, without local or remote connection to FRM220
NMC management, the two separate MC run with default parameters. The default parameters are: switch mode,
auto-negotiation, LFP disabled, ALS (Auto Laser Shutdown) disabled, and no bandwidth limit. When a fully
populated CH20 (with 19 10/100iS-2) is deployed, a total of 38 loops are available from the 2U FRM220-CH20.
Due to dimension limitations, the 10/100iS-2 is only available for SFP based fiber optics.
This product includes the following models:
• FRM220-10/100iS-2 (2 electrical plus 2 SFP Dual media converter)
11
Chapter 1 Introduction
1.7.3 FRM220-10/100i-2E In-band managed 10/100 Fiber Media Converter
The FRM-10/100i-2E (in-band converter) is an In-band Managed (OAM) Fiber Ethernet media converter (MC)
that supports 2 Ethernet channels of 10Base-T or 100Base-TX and converts to 100Base-FX (fiber). The UTP ports
support auto-negotiation or forced settings for speed and duplex by setting as well as auto-MDIX. When the FRM10/100i-2E is placed in the FRM220 with NMC, the settings are controlled by the chassis management system. The
remote FRM-10/100i-2E stand-alone may also be configured from the FRM220 through the in-band management
features (OAM). An optional console manageable single slot chassis, the CH01M, is also available with DB9F
connector for stand-alone serial console management.
Features
• Supports Loop Back Test
• Auto-Cross over for MDI/MDIX in TP port
• Supports far end fault (FEF) function via OAM
• Auto-Negotiation or Manual mode in TP port
• Supports link fault pass through (LFP) function
• Bandwidth control (32K or 512Kbps x N)
CPU
• Forward 2046 bytes (max.) packets in switch mode
Chip
• Forward 9K jumbo packets in converter mode**
• Supports forwarding mode option
• Store and forward (switch) mode, Convert mode (small latency)
• Supports local or remote In-band management (Monitor and
Configure status) by the SNMP manager in FRM220
• Supports remote CPE power fail detection (Dying gasp)
• Provides Auto Laser Shutdown (ALS) function
• Supports Fiber Hardware Reset (FHR) function
• Provides fiber transceiver information for management
• Supports On-Line In-band F/W upgrade (local or remote) by the
• SNMP manager in FRM220
Fiber
(SC Type)
LED
Indicators
10/100
Ethernet
10/100
Ethernet
**When in converter mode, port 3 is disabled and only Fiber port 1 and
UTP port 2 are active.
10/100i-2E is a media converter that
must be placed in FRM220-CH20
for management.
It utilizes fixed transceiver for
100Base-FX fiber connection and
two 10/100 Ethernet electrical ports.
Specifications
Complies with IEEE 802.3 and IEEE 802.3u
288kb packet buffer in switch mode
1K MAC address table in switch mode
Supports IEEE802.3x flow control in switch mode
OAM is based on TS-1000 protocol
10Base-T UTP Cable Requirement
Cable type: Category 3, 4 or 5. Maximum distance: 100 meters (328 feet)
100Base-TX UTP Cable Requirement
Cable type: Category 5, minimum. Maximum distance: 100 meters (328 feet)
Management
The 10/100i-2E line card is managed by an on-card CPU when installed in the FRM220 CH20 chassis. There
are no DIP switches or manual settings. If the MC is placed stand-alone, without local or remote connection to
FRM220 NMC management, the MC runs with default parameter. The default parameters are: switch mode, autonegotiation, LFP disabled, ALS (Auto Laser Shutdown) disabled, and no bandwidth limit. An optional console
manageable single slot chassis, the CH01M, is available with DB9F connector for stand-alone serial console
management.
This product includes the following models:
• FRM220-10/100i-2E (2 electrical plus 1 Fixed transceiver media converter)
12
Chapter 1 Introduction
1.7.4 FRM220-10/100A(S) 802.3ah In-band managed 10/100 Fiber Media Converter
This IEEE802.3ah OAM compliant copper to fiber Fast Ethernet solution is designed to make conversion
between 10/100Base-TX and 100Base-FX with SC or ST connector. With SNMP agent and GUI Web-based
management in the FRM220, the Network administrator can monitor, configure and control the activity of each
802.3ah series line card. This 802.3ah OAM Compliant media converter, with its Q-in-Q and maximum
interoperability will enable carriers and service provides to have a clear vision of their network and conveniently
manage their demarcation point.
Features
• 10/100Mbps auto-negotiation or forced mode operation on the TP interface
• Fiber 100Mbps/Full
• Supports Flow control function
• Supports OAM remote loopback to assist in diagnosing network problems
• Supports bandwidth control
• Supports Dying Gasp Reporting for power outage
• Supports QoS Classification
• Supports local / remote monitor
• Supports local / remote Configuration
• Supports Q in Q double tagged frame transparent
• Supports remote firmware upgrade
• Supports IEEE 802.1q Tag VLAN pass thru
• Compatible with FRM220 Managed Chassis
LAN Interface Specification
One RJ-45 female connector for straight or cross-over connection.
Supports 10/100Base-TX, n-way (Auto-Negotiation).
Transmission Packet Rate for 10Base-T: 14880 per second
10/100AS-2 is a stand-alone
100Base-TX: 148800 per second
manageable 4 port Fast Ethernet
Copper TP cable 4 pair Cat. 3 4, 5e or 6 UTP
fiber switch, utilizing SFP for
Optical Interface Specification
100Base-FX fiber connection and
two 10/100 Ethernet electrical ports.
Transceiver Connector type:ST or SC, or LC with SFP
Supports Full 100Mbps speed
Supports auto-receive sensitivity function, no extra attenuators needed.
General Specification
IEEE 802.3ah In-band OAM management compliant
6 diagnostic LEDs : Power/FX-Link ,TX-Speed/TX-Duplex/TX-Link/Test (loopback)
Temperature: 0 - 50° C (Operating); 0 - 70° C (Storage).
Humidity: 20-80% non-condensing (Operating); 10-90% (Storage).
Power: DC Jack : Switching adaptor (12V, 400mA)
Consumption: < 4W
Dimensions: 155mm x 88mm x 23mm (LxWxH).
Weight: 120g.
Compliance: FCC part 15, Subpart B, Class A,
ANSI C63.4:2003
CE EN55022:2006, Class A
EN55024:1998+A1:2001+A2:2003
LVD: EN60950-1:2001
MTBF: 65,000 h (25°C)
This product includes the following models:
• FRM220-10/100AS-2 (2 electrical plus 2 SFP 4-port fiber switch)
• FRM220-10/100A (2 electrical plus 1 fixed transceiver 3 port fiber switch)
13
Chapter 1 Introduction
1.7.5 FRM220-1000EA(S) 802.3ah In-band managed Gigabit Fiber Media Converter
This IEEE802.3ah OAM compliant copper to fiber Gigabit Ethernet solution is designed to make conversion
between 10/100/1000Base-TX and 1000Base-SX/LX with SFP-LC connector. With SNMP agent and GUI Webbased management in the FRM220, the Network administrator can monitor, configure and control the activity of
each 802.3ah series line card. This 802.3ah OAM Compliant media converter, with its Q-in-Q and maximum
interoperability will enable carriers and service provider to have a clear vision of their network and conveniently
manage their demarcation point.
Features
• 802.3ah In-band OAM management compliant
• 2 ports 10/100/1000Base-T and 2 ports GbE fiber (SFP)
• Supports Flow control function
• Supports OAM remote loopback
• Supports spanning tree function
• Supports bandwidth control
• Supports Dying Gasp Reporting for power outage
• Supports local / remote monitor
• Supports local / remote Configuration
• Supports Q in Q double tagged frame transparent
• Supports remote F/W upgrade (In-band)
• Supports IEEE 802.1q Tag VLAN pass thru and port-base VLAN
• Provides fiber transceiver information for management
• Compatible with FRM220 Managed Chassis
Fiber SFP
(LC Type)
LED
Indicators
10/100/1000
Ethernet
LAN Interface Specification
Two RJ-45 female connectors for straight or cross-over connection.
Supports 2-port 10/100/1000Base, n-way (Auto-Negotiation).
1000EAS is a stand-alone
Supports Full, Half duplex, 10/100/1000 speed force mode selections.
manageable 4 port Gigabit Ethernet
Transmission Packet Rate for 10Base-T: 14880 per second
fiber switch, utilizing SFP for
100Base-TX: 148800 per second ; 1000Base-T: 1488000 per second
1000Base-SX/LX fiber connections
Copper TP cable 4 pair Cat. 5e or 6 UTP
and two 10/100/1000 Ethernet
Optical Interface Specification
electrical ports.
Transceiver Connector type:SFP-LC
Supports 2-port, 1000Mbps SFP slot
Supports auto-receive sensitivity function, no extra attenuators needed.
General Specification
Standards IEEE 802.3 10Base-T,
IEEE 802.3u 100Base-TX , 100Base-FX,
IEEE 802.3ab, 802.3z 1000Base-T, 1000Base-SX/LX
IEEE 802.3ah In-band OAM management compliant
6 diagnostic LEDs : Power / FX-Link ,TX-Speed / TX-Duplex/ TX-Link / Test (loopback)
Temperature: -10 - 60° C (Operating);-20 - 70° C (Storage).
Humidity: 0-95% non-condensing (Operating); 10-90% (Storage).
Power: DC Jack : Switching adaptor (12V, 1A)
Consumption: < 12W
Dimensions: 155mm x 88mm x 23mm (LxWxH).
Weight: 120g.
Compliance: FCC part 15, Subpart B, Class A,
ANSI C63.4:2003
CE EN55022:2006, Class A
EN55024:1998+A1:2001+A2:2003
LVD: EN60950-1:2001
MTBF: 65,000 h (25°C)
This product includes the following models:
• 1000EAS (2 electrical plus 2 SFP)
• 1000EAS-1 (1 electrical plus 1 SFP)
• 1000EA-1 (1 electrical plus 1 fixed fiber)
• 1000EAS-2F (2 SFP)
14
Chapter 1 Introduction
1.7.6 FRM220-1000EDS Managed Gigabit Fiber Media Converter
The FRM220-1000EDS is a 4-port switch or dual channel (two in one) copper to fiber Gigabit Ethernet solution
designed to make conversion between 10/100/1000Base-TX and 1000Base-SX/LX with SFP transceivers. With
SNMP and Web-based management in the FRM220, the Network administrator can monitor, configure and control
the activity of each card in the chassis. This converter also supports features such as ingress/egress bandwidth
control, auto or forced mode setting for copper Ethernet as well as auto laser shutdown. The FRM220-1000E(s)-1
is a single copper to single fiber Gigabit Ethernet solution designed to make conversion between
10/100/1000Base-TX and 1000Base-SX/LX with SC or SFP LC connector.
Features
• 2-port 10/100/1000Base-T to 2-port 1000Base-SX/LX (EDS)
• 1-port 10/100/1000Base-T to 1 port 1000Base-SX/LX (ES-1)
• Supports dual converter mode or switch mode
• Auto-negotiation or forced mode
• Auto MDI/MDIX
• Forward 2046 bytes (Max.) packets
• Support Bandwidth Control (70k ~ 250Mbps)
1000EDS is a manageable 4 port
• Supports Flow control (Pause)
Gigabit Ethernet fiber switch when
• Support Link fault pass through (LFP) function
placed in the FRM220-CH20 or by
• Supports remote CPE power fail detect (dying gasp) DIP switches if used stand-alone. It
• Auto Laser Shutdown (ALS)
utilizes SFP for 1000Base-SX/LX
• Online local f/w upgrade
fiber connection and two
10/100/1000 Ethernet electrical
ports.
Specifications
Ports
Standards
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : SFP LC
Data rate : 1000Mbps
Duplex mode : Full duplex
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Distance : MM 2km, SM 15/30/50/80/120km, WDM 20/40/60/80km
Wavelength: 1310nm, 1550nm,
Electrical Interface
Connector : RJ45
Data rate : 10Mbps, 100Mpbs, 1000Mbps
Duplex mode: Half / Full duplex
Cable type: 10Base-T Cat.3, 4, 5, UTP, 100Base-TX Cat.5, 5e,
1000Base-T Cat. 5e or higher
Distance: 100 meters
IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE802.3z
Power, FX-Link 1/2, 2Ch, TX-Link, TX-SPD
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
• 1000EDS (2 electrical plus 2 SFP)
• 1000ES (1 electrical plus 1 SFP)
• 1000E (1 electrical plus 1 fixed optical)
15
Chapter 1 Introduction
1.7.7 FRM220-E1/T1 In-band managed G.703 E1/T1(DS1) Fiber Modem
The FRM220-E1/T1 is a fiber modem transport for G.703 E1 or T1(DS1) transmission. The BNC model (E1
only) provides unbalanced 75 Ohm coaxial connections while the RJ-45 model provides balanced 100/120 Ohm
connections over twisted pair wiring. When the FRM220-E1/T1 card is placed in the FRM220 rack with in-band
management, the card status, type, version, fiber link status, E1 or T1 link status and alarms can all be displayed.
Configuration is also available to enable or disable the port, reset the port, do far end fault setting, and initiate local
or far end loop-back tests. When configured in G.703 E1 mode, this model also supports fractional E1 (G.704) as
well as remote connection to FRM220-Data (V.35, RS-530/449, X.21) fiber modem for either unframed (2048Kbps)
or fractional (nx64kbps where n=1 to 31) transmissions.
Features
• Network Management via Terminal or SNMP in FRM220 chassis
• T1/E1 RJ-45 (USOC RJ-48C) or Coax (BNC) Fiber Modem
• Supports AMI or B8ZS/HDB3 line codes
• Unframed (transparent clear channel) mode
• N x 64K (fractional E1) mode
• Supports point to point (CPE) solution with FRM220-DATA
• User selectable Loop back tests
E1/T1 is a stand-alone manageable
• Far End Fault (FEF) detection
G.703 E1/DS1(T1) Fiber Optical
Modem that can carry E1/T1 over
fiber transparently or with framing.
One model is designed with RJ-45,
while another model supports E1 via
coaxial BNC connections.
Specifications
Ports Connector
1x9 (SC, ST, FC) or SFP LC
Optical Interface
Cable type
MM 62.2/125µm, 50/125µm.
SM 9/125µm
Cable length
MM 2km, SM 15/30/50/80/120km,WDM 20/40/60/80km
Wavelength
MM 1310nm, SM 1310, 1550nm, WDM 1310Tx/1550Rx(type A),1550Tx/1310Rx(type B)
Data rate
36.864Mbps
Electrical Interface
Connector
RJ45 E1-120ohm, T1-100ohm, BNC E1-75ohm
Data rate
E1: 2.048Mpbs, T1:1.544Mbps
Line Code
E1 HDB3/AMI, T1 B8ZS/AMI
Cable type
Cat.3 or higher Twisted-Pair cable
Standards
E1 ITU-T G.703, G.704, G.706, G.732, G.823
T1 ITU-T G.703, G.704, AT&T, TR-62411, ANSI T1.403
LEDs
Power, FX-Link, E1/T1 SIG, Test, SYN, RD, TD, AIS
Power
DC In 12V
Consumption
< 5W
Dimensions
155 x 88 x 23mm (D x W x H)mm
Weight
120g
Temperature
-10~60°C (Operating) ,-20~70°C (Storage)
Humidity
10~95% non-condensing
Certification
CE, FCC, LVD, RoHS
MTBF
65,000 h (25°C)
This product includes the following models:
• E1/T1R (RJ-45 electrical plus fixed optical)
• E1T1RS (RJ-45 electrical plus SFP)
• E1B (Dual BNC plus fixed optical)
• E1BS (Dual BNC plus SFP)
16
Chapter 1 Introduction
1.7.8 FRM220-Data In-band managed V.35, X.21, RS-530/449/232 Fiber Modem
The FRM220-DATA is a fiber modem for high-speed (up to 8.192Mbps) synchronous or low speed
synchronous and asynchronous data transmissions (V.35, RS-232, RS-530, X.21 or RS-449) over fiber optical
media. When the FRM220-DATA card is placed in the FRM220 rack with SNMP management, in-band
management allows viewing the card and remote modem's status, type, version, fiber link status, data link status
and alarms. Both card and remote can be configured to enable or disable the port, reset the port, set the data rate,
modify the clock mode, and initiate local or far end loop back tests. The FRM220-Data Fiber Modem may also be
paired with the FRM220-E1/T1 for Nx64K transmissions.
Features
• Synchronous or Asynchronous data over fiber
• In-band network management
• Manage via terminal, web or SNMP in FRM220-CH20 chassis
• Software selectable interface, V.35, X.21, RS530, RS449, RS232
• Software selectable DCE or DTE mode
• User selectable data rate n x 64kbps, up to 9Mbps
• Independent clock mode setting
• TC RC clock (internal, external, or recovery)
• Electrical and optical loop back tests
• Compatible with FRM220-E1 on same fiber link for N x 64k
• Stand-Alone Console management with CH01M single slot chassis
Specifications
Ports
Standards
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : 1x9 (SC, ST, FC) or SFP LC
Data rate : 36.864Mbps
Line coding: Scrambled NRZ
Bit Error Rate: Less than 10-10
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Distance : MM 2km, SM 15/30/50/80/120km, WDM 20/40/60/80km
Wavelength: 1310nm, 1550nm,
Electrical Interface
Connector : HDB26F w/ adapter cable for V35, X21, RS530,
RS449,RS232
Line Code:
NRZ
Baud Rate: RS-232 up to 384K sync and async
V.35/RS-530 up to 9152k sync, async up to 2048k
N*64Kbps , where n=1 to 143 (64K ~ 9152KKbps)
Receive and Transmit Clock source :Internal, Recovery, External
ITU-T
Power, FX Link, RTS, Test , TD, RD, CTS, DCD
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
• FRM220-Data/XXX (Fiber Modem with fixed optical and adapter cable)
• FFRM220-DataS/XXX (Fiber Modem with SFP and adapter cable)
Where XXX equals:
232 for RS-232 cable (DB25F)
530 for RS-530 cable (DB25F)
V35 for V.35 cable (MB34F)
X21 for X.21 cable (DB15F)
449 for RS-449 cable (DB37F)
17
Chapter 1 Introduction
1.7.9 FRM220-Serial/485 In-band managed RS-485/422/232 Fiber Modem
The FRM220-Serial/485 provides an Asynchronous Fiber Modem solution to extend RS-485 or RS-232
transmission distance up to 2km over multimode fiber or up to 120km over single mode fiber. The modem is
equipped with multiple interface circuits for connection to RS-232 or RS-485/422 (2 or 4 wire, full or half duplex).
The FRM220-Serial/485 secures data transmission over EMI resistant fiber at speeds up to 460kbps for RS-232 or
up to 1024kbps for RS-485/422. When the FRM220-Serial/485 card modem is placed in the FRM220 rack with
SNMP management, in-band management allows viewing the card and remote modem's status, type, version, fiber
link status, data link status and alarms. Both card and remote can be configured to enable or disable the port, reset
the port and set the interface type.
Features
• Extend asynchronous serial transmission from 2km to 120km over fiber
• In-band network management
• Manage via terminal, web or SNMP in FRM220-CH20 chassis
• Software selectable data interface for RS232/ 422/ 485
• Software selectable two wires (half duplex) or four wires (full duplex) RS485
• Software selectable three or five wires RS232
• Speeds up to 460kbps for RS232 (Async. mode)
• Speeds up to 1Mbps for RS485/ 422 (Async)
Specifications
Ports
Standard
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : 1x9 (SC, ST, FC) or SFP LC
Data rate : 36.864Mbps
Line coding: Scrambled NRZ
Bit Error Rate: Less than 10-10
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Distance : MM 2km, SM 15/30/50/80/120km, WDM 20/40/60/80km
Wavelength: 1310nm, 1550nm,
Electrical Interface
Connector : 6 pins Terminal block
Data Signal Formats
RS485 2-wire
RS422 4-wire
RS232 RTS/CTS 5-wire
RS232 3-wire
Baud Rate:
RS422, RS485 up to 1024kbps
RS232 up to 256kbps
EIA/TIA RS485, RS422, RS232
Power, FX Link, DI, DO, Test
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
• FRM220-Serial/485 (6 pin terminal block and fixed fiber transceiver)
• FRM220-Serial/485S (6 pin terminal block with SFP)
18
Chapter 1 Introduction
1.7.10 FRM220-FXO/FXS In-band managed POTS (Voice) over Fiber Modem
FRM220-FXO/FXS POTS phone line converter extender is used to connect PSTN voice signals to distant Plain
Old Telephone (POTS) devices. FRM220-FXO/FXS provides a fiber media transport for POTS transmission and
features an RJ-11C for copper connection. A pair of FRM220-FXO/FXS is required to implement an end to end
system. FXO mode connects to a telephone line or PBX and has ability to detect ringing voltages and to act as a
telephone. FXS mode is the reciprocal unit and has ability to act as PSTN and connects to a telephone device.
When the FRM220-FXO/FXS card is placed in the FRM220 rack with SNMP management, in-band management
allows viewing the card and remote converter's status, type, version, fiber link status, on hook status and alarms.
Both card and remote can be configured to enable or disable the port, reset the port and set the FXO or FXS mode.
Features
• Extend telephone voice transmission from 2km to 120km over fiber
• Management via terminal, web or SNMP in FRM220-CH20 chassis
• Manage stand-alone via DIP Switch
• Supports telephone voice transmission
• Supports caller ID pass through
• Selectable FXO or FXS mode
• Supports FXS to FXS hot line
Specifications
Ports
Optical Interface
Connector : 1x9 (SC, ST, FC) or SFP LC
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Distance : MM 2km, SM 15/30/50/80/120km, WDM 20/40/60/80km
Wavelength: 1310nm, 1550nm,
Electrical Interface
Connector : RJ-11
FXO mode
Impedance : 600 ohms
Coding : 16 bits liner
Loop Current : 10~100mA
Ring Frequency : Acceptable 20 ~50Hz
Insertion Loss: 0.0 ± 1.0dB at 1000Hz
FXS mode
Impedance : 600 ohms
Coding : 16 bits liner
Dial:
DTMF and Dial Paul
Battery Source: 48VDC ± 4V
Ringing Waveform : Sine wave
Ringing Frequency : 20/25/30/50 Hz selectable
Ring Cadence: FXS to FXS : On / 1 sec, Off / 2 sec
FXO to FXS; Reproduces the cadence detected by FXO
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Insertion Loss
0.0 ± 1.0dB at 1000Hz
REN:
4.0B(Ring Equivalence Number)
Power, FX Link, Phone Act, Test
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
• FRM220-FXO/FXS (POTS over Fiber fixed transceiver)
• FRM220-FXO/FXS-S (POTS over Fiber SFP)
19
Chapter 1 Introduction
1.7.11 FRM220-155MS SM/MM, MM/SM converter / repeater
The FRM220-155MS is a fiber to fiber optical media converter and repeater that allows data rates up to
155Mbps. FRM220-155MS supports 2R regeneration, which consists of re-amplification and reshaping. This
converter is compatible with fiber interfaces such as 100Mbps Fast Ethernet, 155Mbps STM1 and OC3. The
FRM220-155MS works well with FRM220-CH20 chassis as slide-in card or with FRM220-CH01, one slot chassis
as a stand-alone fiber converter. When the FRM220-155MS card is placed in the FRM220 rack with SNMP
management, the management can view the converter card's status, type, version, fiber link status and alarms. The
card can be configured to enable or disable the port, reset the port or enable/disable Auto Laser Shutdown.
Features
• Transparent fiber media converter / repeater
• Speed up to 155Mbps ( Fast Ethernet, OC3, STM-1)
• Manage via terminal, web or SNMP in FRM220-CH20 chassis
• Extend transmission from 2km to 120km over fiber
• Perform optical repeater function (Re-amplification & Reshaping)
• Supports Client / Line loop back test
• Link Fault Pass through (LFP)
• Auto Laser Shutdown (ALS)
Specifications
Ports
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : 1x9 (SC, ST, FC) or SFP LC
Data rate: Up to 155Mbps ( Fast Ethernet, OC3, STM-1)
Regeneration type: 2R
Loop back: Line/Client
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Wavelength:1310nm, 1550nm,
Power, Line Link, Client Link, Test
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
• FRM220-155MS (STM-1 Fiber Repeater with fixed transceivers)
• FRM220-155MS-SFP (STM-1 Fiber Repeater with SFP)
20
Chapter 1 Introduction
1.7.12 FRM220-2.7G-2S, 2.7Gbps 3R Fiber Transponder
The FRM220-2.7G-2S is an optical 3R regeneration device, which provides re-amplification, reshaping and
retiming. The transponder card converts a data signal to the correct wavelength for transmission on a specific
channel by supporting SFP optics on both line side and client side interfaces. When the FRM220-2.7G-2S 3R card
is placed in the FRM220 rack with SNMP management, the management can view the converter card's status, type,
version, fiber link status and alarms. The card can be configured to enable or disable the port, reset the port and
set the desired data rate.
Features
• Protocol transparent fiber media converter / repeater
• Up to 2.7Gbps
• Clocking for Fast Ethernet, OC3, STM-1,STM-4, STM-16,FC-1, FC-2
• Network management via terminal, web or SNMP in FRM220-CH20 chassis
• Extend transmission from 2km to 120km over fiber
• Perform 3R optical repeater function (Re-amplification & Reshaping, Re-clocking)
• Supports Client / Line loop back test
• Link Fault Pass through (LFP)
• Auto Laser Shutdown (ALS)
• Serial console for stand-alone management
When used with CH02M two slot chassis
Specifications
Ports
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : LC (SFP)
Data rate: Up to 2.7Gbps
Fixed rates for:
E3 (34.368M)
DS3/T3 (44.736M)
OC1/STM-0 (51.84M)
Fast Ethernet (125M)
STM-1/OC3 (155.52M)
STM-4/OC12 (622.080M)
STM-16/OC48 (2,488.32M)
FC-1 (1.0625G)
FC-2 (2.125G)
Regeneration type: 3R
Loop back: Line/Client
Cable type : SM 9/125μm, MM 50/125μm, 62.2/125μm
Wavelength: 850, 1310,1550nm,
Power, Line Link, Client Link, Test, Alarm
DC In 12V
< 10W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE, FCC, LVD, RoHS
65,000 h (25° C)
21
Chapter 1 Introduction
1.7.13 FRM220-2.7G-3S 3R Transponder with Protection
The FRM220-2.7G-3S is an optical 3R regeneration device, which provides re-amplification, reshaping and
retiming and offers fiber protection. The transponder card converts a data signal to the correct wavelength for
transmission on a specific channel by supporting SFP optics on line side to Primary or Secondary interfaces. When
the FRM220-2.7G-3S 3R card is placed in the FRM220 rack with SNMP management, the management can view
the converter card's status, type, version, fiber link status and alarms. The card can be configured to enable or
disable the port, reset the port and set the desired data rate.
Features
• Protocol transparent fiber media converter / repeater
• Supports fiber redundancy by switching Primary to Secondary path
• Programmable receive optical threshold fiber protection
• Up to 2.7Gbps
• Clocking for Fast Ethernet, OC3, STM-1,STM-4, STM-16,FC-1, FC-2
• Network management via terminal, web or SNMP in FRM220-CH20 chassis
• Extend transmission from 2km to 120km over fiber
• Perform 3R optical repeater function (Re-amplification & Reshaping, Re-clocking)
• Supports Line / Primary / Secondary loop back test
• Link Fault Pass through (LFP)
• Auto Laser Shutdown (ALS)
• Serial console for stand-alone management
When used with CH02M two slot chassis
Specifications
Ports
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : LC, 1 Line SFP, 1 Primary SFP, 1 Secondary SFP
Data rate: Up to 2.7Gbps
Fixed rates for:
E3 (34.368M)
DS3/T3 (44.736M)
OC1/STM-0 (51.84M)
Fast Ethernet (125M)
STM-1/OC3 (155.52M)
STM-4/OC12 (622.080M)
STM-16/OC48 (2,488.32M)
FC-1 (1.0625G)
FC-2 (2.125G)
Regeneration type: 3R
Loop back: Line / Primary or Secondary
Cable type : SM 9/125μm, MM 50/125μm, 62.2/125μm
Wavelength: 850, 1310,1550nm,
Power, Line Link, Primary Link, Secondary Link, Test, Alarm
DC In 12V
< 10W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE, FCC, LVD, RoHS
65,000 h (25° C)
22
Chapter 1 Introduction
1.7.14 FRM220-10G-xx 10Gbps 3R Fiber Transponder
The FRM220-10G-xx is a series of managed 10G fiber to fiber 3R repeater/transponders. Based on a number
of 10 Gigabit Fiber standards, these transponders support XFP to XFP (XX), SFP+ to XFP (SX), or SFP+ to SFP+
(SS) fiber connections. The transponders are protocol transparent, providing 3R regeneration between these
different optical module types. One of the major applications for this converter is in connecting proprietary
transceiver equipment to CWDM or DWDM when these 'colored' optical modules are not available for the
proprietary equipment. With full duplex wire speed forwarding capability between the 2 fiber media, the FRM22010G-xx brings you the best and simplest solution for your 10G conversion between fiber and fiber.
Features
• Protocol transparent 3R fiber media transponder/repeater
• Supports IEEE802.3ae, 10G Fiber Ethernet
• Supports 10G Fiber Channel, STM-64
• Network management via terminal,
web or SNMP in FRM220-CH20 chassis
• Extend 10G Ethernet transmission over fiber
• Useful as a 'Transponder' in CWDM or DWDM systems
for 10G Ethernet/Fiber Channel/STM-64
• Supports Client / Line loop back tests
• Serial console for stand-alone management
when inserted in CH02M Two Slot Chassis
Specifications
Ports
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
FRM220-10G-SS
Connector : LC, 1 Line SFP+, 1 Client SFP+
FRM220-10G-XX
Connector : LC, 1 Line XFP, 1 Client XFP
FRM220-10G-SX
Connector : LC, 1 Line XFP, 1 Client SFP+
Data rates:
1G FC (1.0625G)
2G FC (2.125G)
4G FC (4.25G)
8G FC (8.5G)
10G FC (10.51875G)
10G Base Ethernet (10.3125G)
STM-64/OC192 (9.95328G)
OTN G.709 OTU2 (10.709225G)
Loop back: Line/Client
Cable type : SM 9/125μm, MM 50/125μm, 62.2/125μm
Wavelength: 850, 1310, 1550nm,
Power, Line Link, Client Link, Test
DC In 12V
< 8W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE, FCC, LVD, RoHS
65,000 h (25° C)
Warning: Due to high power requirements and heat dissipation of 10G Series cards, they are limited to placing a
maximum of 10 cards in CH20 chassis leaving an empty space between each card. 10G Series cards should not be placed in
CH01 single slot chassis for this same reason. Additionally, only one card should be placed in CH02 with an additional NMC
for management.
This product includes the following models:
• FRM220-10G-SS (10G fiber 3R transponder/repeater, SFP+ to SFP+)
• FRM220-10G-XX (10G fiber 3R transponder/repeater, XFP to XFP)
• FRM220-10G-SX (10G fiber 3R transponder/repeater, SFP+ to XFP)
23
Chapter 1 Introduction
1.7.15 FRM220-MD40/80 CWDM Mux/DeMux
The FRM220-MD40 is 4 channels MUX / DEMUX, modular design card for CWDM wavelengths including 1510nm,
1530nm, 1550nm, 1570nm. The FRM220-MD40-UP02 is 4 channels MUX / DEMUX, modular design card for
CWDM wavelengths including 1470nm, 1490nm, 1590nm, 1610nm and two upgrade ports for CWDM wavelength
ranges of 1503nm ~ 1577nm and 1260nm ~ 1457nm. The FRM220-MD80-UP01 is 8 channels MUX/DEMUX,
modular design card for CWDM wavelengths including 1470nm, 1490nm, 1510nm, 1530nm, 1550nm, 1570,
1590, 1610nm and one upgrade port for CWDM wavelength range of 1260nm ~ 1457nm. The MUX / DEMUX
cards provide the primary wave division and combination functions for CWDM. Line side wave lengths require
translation to client side equipment via a transponder card.
Features
• Full native mode performance
• Optical connectors : LC / UPC
• Passive model requires no power
• Protocol transparent, no limitation
• Utilizes industry standard ITU CWDM wavelength
• High isolation WDM
• Low insertion loss
• Wide Operation wavelength Range
• Environmentally Stable
Specifications
Connector : LC / UPC
Standard : ITU-T G.694.2 (CWDM grid)
FRM220-MD40 : 4 Wavelength CWDM Mux / DeMux Card
Wavelengths : 1510, 1530, 1550, 1570nm
Insertion Loss : <1.8dB (including connector loss)
Return Loss : >45dB
FRM220-MD40-2UP : 4 Wavelength CWDM Mux / DeMux Card + 2 upgrade ports
Wavelengths : 1470, 1490, 1590, 1610nm
Upgrade port 1 : 1503 ~ 1577nm
Upgrade port 2 : 1260 ~ 1457nm
Upgrade port isolation : >30dB
Insertion Loss : < 2.2dB (including connector loss)
Return Loss : > 45dB
FRM220-MD80 : 8 Wavelength CWDM Mux / DeMux Card
Wavelengths : 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm
Insertion Loss : < 2.8dB (including connector loss)
Return Loss : > 45dB
FRM220-MD80-1UP : 8 Wavelength CWDM Mux / DeMux Card + 1 upgrade port
Wavelengths : 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610nm
Upgrade port 1 : 1260 ~ 1457nm
Upgrade port isolation : > 30dB
Insertion Loss : < 2.8dB (including connector loss)
Return Loss : > 45dB
Environment :
Operating Temp.: 0°C – 50°C
Storage Temp. : -10°C – 70°C
Humidity : 5 – 90%(non-condensing)
Dimension : (D x W x H)
Single width blade : 155 x 88 x 23mm
Double width blade : 155 x 88 x 41mm
Certification : RoHS
MTBF >275,000 hours
24
Weight :
Single width blade card : 200g
Double width blade card : 300g
Chapter 1 Introduction
1.7.16 FRM220-iMUX Inverse Multiplexer Blades
The FRM220A-nE1/ET100 are 5, 8 or 16 E1 port inverse multiplexer cards with built-in Bridge for the
FRM220/220A Series Platform Media Converter Rack. The multiplexers support bundling Unframed E1s using
GFP-F (Generic Framing Procedure-Framed). The clock source may be selected internally or recovered from any
one of the received E1 signals. The Ethernet port utilizes a single RJ-45 connector or SFP for optical fiber,
depending on model. One single model supports either unbalanced 75 ohm or balanced 120 ohm (adapter cables
required). When the FRM220A-nE1/ET100 card is placed in the FRM220A rack with GSW/SNMP management, the
management can view the converter card's status, type, version, Ethernet link status and alarms. The card can be
configured to enable or disable the port, reset the card, set clocking, Ethernet mode and provide E1 analog
diagnostic loopbacks. A unique feature of the FRM220A-nE1/ET100 is the use of a common card design which
may either be inserted in an appropriate single or dual slot chassis as a stand-alone modem or as a card when
placed in the FRM220A-CH20 In-band managed rack.
Features
• Standalone type Ethernet to 5, 8, or 16 port E1 converter.
• Uplinks 100M Ethernet to aggregate trunk card of FRM220A
• Interface connectors, RJ-48C for 120Ω , BNCx2 for 75Ω per channel.
• E1s are bundled according to standard GFP-F
• LCAS (Link Capacity Adjustment Scheme) supports dynamic
bandwidth of virtual concatenated containers.
• E1 settings.
• E1 loopback (per channel)
• 75 or 120 ohm impedance
• Timing source setting (Any receive E1 recovery or internal oscillator).
• Embedded Operations Channel (EOC) for remote in-band management.
• Integrated BERT function
• RMON counter for LAN Tx/Rx byte count.
• VLAN tag support
• Bandwidth control (32K to 100M)
• LED indicators
Specifications
ƒ G.703 Interface
ƒ
Connector
ƒ
Data rate
ƒ
Impedance
ƒ
Framing
ƒ
RxSensitivity
ƒ
TxPulseAmp.
ƒ
Line code
ƒ Indications
ƒ Ethernet Port
HDB26 Female with adapters for 75 or 120 Ohm
2048kb/s
75 ohm for unbalanced, 120 ohm for balanced
Requires Unframed, transparent clear channel E1s
-43dB (extra Long Haul)
3.00V p-p (120 ohm); 2.73V p-p (75 ohm)
HDB3
LED (PWR, Alarm, Individual E1 status, Link, SD)
1 x RJ-45, Auto-Negotiation, Auto-MDIX (T-model)
1 x caged SFP (100Base-FX) (S-model)
ƒ VLAN
IEEE802.1Q tagged VLAN support
ƒ Maximum MTU 1916 bytes
ƒ Ingress/Egress Bandwidth control (32K to 100M, nx32K granularity)
ƒ GFP-F
ƒ LCAS
ƒ Power
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
per ITU-T G.7041
Enabled or disabled
(Card supports hot-swapping)
Input
Card : 12VDC, Standalone : AC, DC options
Consumption <6W
Dimensions
Weight
Temperature
Humidity
Certification
MTBF
Test Loops
ƒ
E1
ƒ BERT
155 x 88 x 23mm (D x W x H)
120g
0 ~ 50°C (Operating), -10 ~ 70°C (Storage)
10 ~ 90% non-condensing
CE, FCC, LVD, RoHS
65000 hrs (25°C)
(set from console)
Remote and Request Remote Loop back
Integral 511 pattern generator (set from console)
This product includes the following models:
FRM220A-5, 8, 16E1-ET100T (5E1, 8E1 or 16E1 with RJ-45 LAN)
FRM220A-5, 8, 16E1-ET100S (5E1, 8E1 or 16E1 with SFP LAN)
25
Chapter 1 Introduction
1.7.17 FRM220-Eoe1 Ethernet over E1 Converter
The FRM220A-Eoe1 is a single port G.703/704 Fractional E1 DSU/CSU card with built-in HDLC Bridge for the
FRM220/220A Series Platform Media Converter Rack. The converter supports Unframed, PCM31, and PCM30
framing modes. The clock source may be selected internally or recovered from received E1 signal. The Ethernet
port utilizes a single RJ-45 connector. One single model supports either unbalanced 75 ohm with two BNC
connectors or balanced 120 ohm with one RJ-45 connector. When the FRM220A-Eoe1 card is placed in the
FRM220 rack with SNMP management, the management can view the converter card's status, type, version,
Ethernet link status and alarms. The card can be configured to enable or disable the port, reset the card, set
clocking, frame mode and provide analog diagnostic loopbacks. A unique feature of the FRM220A-Eoe1 is the use
of a common card design which may either be inserted in the FRM220-CH01M single slot chassis as a stand-alone
modem or as a card when placed in the FRM220-CH20 In-band managed rack.
Features
• Standalone type, 1 port E1 to HDLC converter.
• Uplinks 100M Ethernet to Gigabit trunk card of FRM220A
• Interface connectors, RJ-48C for 120? , BNC*2 for 75?.
• E1 settings.
• Line Code HDB3 or AMI.
• Full or Fractional.
• Frame setting, E1(CCS/CAS).
• Idle code setting (0x7E or 0xFF).
• Auto generate (AIS) enable, disable setting.
• Timing source setting (Receive E1 recovery or internal oscillator).
• Active timeslot number setting (E1 CCS 1-31 or E1 CAS 1-30).
• Base timeslot setting (E1 CCS 1-31, E1 CAS 1-15 or 17-31.)
• Loop Back with integral BERT
• LED indicators
Specifications
• G.703 Interface
• Connector
1 x RJ-45 and 2 x BNC
• Data rate
2048kb/s
• Impedance
75 ohm for unbalanced, 120 ohm for balanced
• Framing
CCS, CAS, Unframed
• RxSensitivity
-43dB (extra Long Haul)
• TxPulseAmp.
3.00V p-p (120 ohm); 2.73V p-p (75 ohm)
• Line code
HDB3 or AMI selectable
• Indications
LED (PWR, TD/RD act., Test, Signal loss, Sync loss,
• Alarm, Error
• Ethernet Port
1 x RJ-45, Auto-Negotiation, Auto-MDIX
• Power
(Card supports hot-swapping)
• Input
Card : 12VDC, Standalone : AC, DC options
• Consumption
<6W
• Dimensions
155 x 88 x 23mm (D x W x H)
• Weight
120g
• Temperature
0 ~ 50°C (Operating), -10 ~ 70°C (Storage)
• Humidity
10 ~ 90% non-condensing
• Certification
CE (EMI/LVD), FCC, RoHS
• MTBF
75000 hrs (25°C)
• Tests
(set from console)
• E1 Loops
Remote and Request Remote Loop back
• BERT
Integral 511 pattern generator (set from console)
This product includes the following models:
FRM220A-Eoe1 (Ethernet over E1 converter card)
26
Chapter 1 Introduction
1.7.18 FRM220-E1/Data DSU/CSU Converter Card
The FRM220-E1/Data is a single port G.703/704 Fractional E1 DSU/CSU card for the FRM220/220A Series
Platform Media Converter Rack. The converter supports Unframed, PCM31, PCM31+CRC4, PCM30, and
PCM30+CRC4 framing modes. The clock source may be selected internally, recovered from received E1 signal,
externally from the Data port or transparent. The Data port interface utilizes a single Hi-Density 26pin connector.
Cable solutions are provided for RS-530/449, X.21, V.35 and RS-232. The unit can recognize the cable type
attached and automatically self-configure the interface circuits. Choosing from one of two model types, the E1
connection is either unbalanced 75 ohm with two BNC connectors or balanced 120 ohm with one RJ-45 connector.
When the FRM220-E1/Data card is placed in the FRM220 rack with SNMP management, the management can
view the converter card's status, type, version, E1 link status and alarms. The card can be configured to enable or
disable the card, reset the card, set clocking, frame mode, interface type and provide analog or digital diagnostic
loopbacks. A unique feature of the FRM220-E1/Data is the use of a common card design which may either be
inserted in the FRM220-CH01 single slot chassis as a stand-alone modem or as a card when placed in the
FRM220-CH20 In-band managed rack.
Features
• Standalone type, 1 port E1 to Synchronous Data converter.
• Interface connectors, RJ-48C for E1/Data-R, BNCx2 for E1/Data-B.
• E1 settings.
• Line Code HDB3 or AMI.
• Full or Fractional.
• Frame setting, E1(CCS/CAS).
• CRC enable/disable.
• Idle code setting (0x7E or 0xFF).
• Auto generate (AIS) enable, disable setting.
• Timing source setting (Receive E1 recovery, Internal oscillator,
External from Synchronous Data port or transparent).
• Active timeslot number setting (E1 CCS 1-31 or E1 CAS 1-30).
• Base timeslot setting (E1 CCS 1-31, E1 CAS 1-15 or 17-31.)
• Loop Back with integral BERT
• LED indicators
Specifications
G.703 Interface
Connector
Data rate
Impedance
Framing
RxSensitivity
TxPulseAmp.
Line code
Indications
1xRJ-45 or 2xBNC (depending on model)
2048kb/s
75 ohm for unbalanced, 120 ohm for balanced
CCS, CAS, w or w/o CRC4, Unframed
-43dB (extra Long Haul)
3.00V p-p (120 ohm); 2.73V p-p (75 ohm)
HDB3 or AMI selectable
LED (PWR, TD/RD act., Test, Signal loss,
Sync loss, Alarm, Error)
Data Port
HD26 w/cable for V.35, RS530, RS449, X.21
or RS232 (software selectable); DCE type
Power
(Card supports hot-swapping)
Input
Card : 12VDC, Standalone : AC, DC options
Consumption
<6W
Dimensions
155 x 88 x 23mm (D x W x H)
Weight
120g
Temperature
0 ~ 50°C (Operating), -10 ~ 70°C (Storage)
Humidity
10 ~ 90% non-condensing
Certification
CE, FCC, LVD, RoHS
MTBF
65000 hrs (25°C)
Test Loops
(set from console)
E1
Local, Remote and Request Remote Loop back
Data
Local, Remote and Request Remote Loop back
BERT
Integral 511 pattern generator (set from console)
This product includes the following models:
FRM220-E1/Data-R E1 DSU/CSU Converter Card with RJ-45
FRM220-E1/Data-B E1 DSU/CSU Converter Card with BNC
27
Chapter 1 Introduction
1.7.19 FRM220-FTEC E1/T1 Cross Rate Converter Card
The FRM220-FTEC is a T1 (US Standard) /E1 (European Standard) converter and timeslot cross connect which
enables conversion between one T1 signal and one E1 signal.
T1 and E1 signals with framing employ u-Law and A-Law compander encoding principles respectively and encode
those analog (voice) signals into 64kbits digital data.
The T1 interface supports D4(SF) or ESF frame formats with B8ZS or AMI line code. The E1 interface supports
CCS (PCM31) or CAS (PCM30) framing without CRC-4 and framing with CRC-4. The line coding is HDB3.
Tests and diagnostics can easily be performed from the local console interface or via Web based management of
the FRM220. Diagnostics include T1 local/remote and E1 local/remote loop back.
Features
• Converts between T1 and E1 data and signaling
• Enable equipment to operate at T1 and E1 rates
• Support G.802 Annex B (T1 over E1)
• Configures A-law/u-law and signaling conversion
• Transparent conversion at 64kbps timeslot level
• Controlled slip for buffer over or under flow
• 24 timeslots of T1 Nx64 can be inserted into E1 Nx64,
30/CAS or 31/CCS timeslots
Specifications
T1 Interface Specifications
• Complies with:
ITU-T G.703 Recommendation
• Bit rate:
1.544Mbps
• Frame format:
D4(SF) or ESF selectable
• Line code:
AMI or B8ZS selectable
• Equalization:
0-655 feet settable
• Voice channel sample rule: u-Law
• CRC check:
CRC-6 (when ESF)
• Impedance:
100 Ohm balanced
• Transmit pulse level: +/-3.0V (10%)
• Receive signal level: 0 to –36dB
• RJ-45 Connector
USOC RJ-48C
E1 Interface Specifications
• Complies with:
ITU-T G.703 Recommendation
• Bit rate:
2.048Mbps
• Frame format:
CAS (PCM30) or CCS (PCM31)
• Line code:
HDB3
• Voice channel sample rule: A-Law
• CRC check:
CRC-4 enable/disable
• Impedance:
75 Ohm or 120 Ohm selectable
• Transmit pulse level: 75 Ohm +/-2.37V (10%)
120 Ohm +/-3.0V (10%)
• Impedance:
• Receive signal level: 0 to –30dB
• RJ-45 Connector
USOC RJ-48C
• BNC
via RJ-45 to 2xBNC adapter cable
Timeslot mapping selectable
• E1 CAS mode:
TS1-TS15, TS17-TS31 any 24 timeslots
• E1 CCS mode:
TS1-TS31 any 24 timeslots
This product includes the following models:
FRM220-FTEC E1/T1 Cross Rate Converter Card
28
Chapter 1 Introduction
1.7.20 FRM220-1000TS GbE to Gigabit Fiber Converter Card
The FRM220-1000T(S) is a 1000Base copper to fiber converter which transparently supports any protocol or
packet size. This slide in fiber media converter is available in two different models that work stand-alone or as line
cards for placement in the FRM220 Platform Media Converter chassis. The FRM220-1000T uses a fixed optical
transceiver while the FRM220-1000TS features an standard SFP socket. The FRM220-CH01 is a stand-alone case
for FRM220 slide-in cards with built-in power supply features.
All media converters are available with either multi-mode or single-mode optical transceivers with SC connectors
for fixed transceivers or LC connectors for the SFP version. In single mode, WDM (Wave Division Multiplexing with
SC or LC ) or “Bidi” are also available in 20, 40, 60km reach, which provide the ability to transmit and receive data
using only a single optical fiber. When the FRM220-1000T(S) card is placed in the FRM220 rack with SNMP
management, the card status, type, fiber link status and UTP link status can all be displayed.
This converter is excellent when used in high speed gigabit networks that employ jumbo packets. The FRM2201000T(S) supports unlimited packet size and has extremely low latency.
Features
• 1000Base-T to 1000Base-SX/LX
• Network management via terminal, web or SNMP in FRM220 chassis
• Forced 1000Base/Full Ethernet
• Auto MDI/MDIX
• Pass > 9K bytes packets
• Supports Link Fault Pass Through (LFP) function
• Auto Laser Shutdown (ALS)
Specifications
Standards
• IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX, Gigabit Standards
1000Base-T RJ-45 Connectors
• 1000T(S) : One RJ45 connector is provided for UTP cable connection
All RJ45 ports utilizing auto MDI/MDIX, which allow all UTP connections for both
straight and crossover UTP cable.
1000Base-X Fiber Optic Connectors
• 1000TS : One SFP slot is provided for standard 1.25Gbps SFP module.
Environment
• Operating -10 to 60C
• Storage -20 to 70C
• Humidity -- 10 to 90%, (non-condensing)
Power
• Adapter: 12V DC 1A (CH01-DC12)
• Built-in AC Power 100~240 V (CH01-AC)
• Built-in DC Power 18~72VDC (CD01-DC)
Dimensions: (W x D x H) mm
• 1000TS-DC12 : 88 × 160 × 24
• 1000TS-DC48 : 135 × 201 × 35
1000T(S)-AC: 135 × 201 × 35
1000T(S)-AD/AA/DD: 135 × 201 × 35
This product includes the following models:
FRM220-1000TS GbE to Gigabit Fiber Converter Card
29
Chapter 1 Introduction
1.7.21 FRM220-4G 2R 4.25G Transponder Card
FRM220-4G-2S is a multi-rate, 28M to 4.25G 2R optical repeater device. The "2R" consists of Re-amplification
and Re-shaping. The transponder card converts a data signal to the correct wavelength for transmission on a
specific channel by supporting SFP optics on both line side and client side interfaces. When FRM220-4G-2S card
is placed in FRM220 rack with SNMP management, the management can view the converter card's status, type,
version, fiber link status and alarms. The card can be configured to enable or disable the port, reset the port,
provide client or line side diagnostic loop back, and set the desired data rate.
FRM220-4G-3S is in every way the same as the 2S model except an additional optical port is added to provide
1+1 optical protection. Automatic optical line Protection Switching is supported for the aggregate fiber port.
Features
• Supports multiple protocols and data rates from 28Mbps to 4.25Gbps.
• 2R Repeater functions for re-amplification and re-shaping.
• Low cost transponder application.
• Available with redundant fiber support (3S model).
• Supports rack management or stand-alone.
• Supports Auto-Laser Shutdown (ALS) and Link Fault Pass through (LFP).
• Supports both line side and client side optical loop backs.
• Digital Diagnostic Monitor of supported SFP modules.
• Optical Connector: SFP-LC ( On both Line & Client Side)
Specifications
Optical Interface :
Indications
Power Input
Power Consumption
Dimensions
Weight
Temperature
Humidity
Certification
MTBF
Connector :
Data rate :
Fiber :
SFP LC
28Mbps ~ 4.25Gbps
MM 62.2/125µm, 50/125µm.
SM 9/125µm
Distance :
2~120km
Wavelength :
850, 1311, 1471 ~ 1611nm
Power, Link(Line), Link(Client), TX/Act, Loopback
Card: 12 VDC
Stand-alone: AC, DC option
<5W
155 x 88 x 23mm(D x W x H)
120g
0~60°C (Operating), -10~70°C (Storage)
10~90% non-condensing
CE, FCC, RoHS
75,000 hours
This product includes the following models:
FRM220-4G-2S 2R 4.25G Transponder Card
FRM220-4G-3S 2R 4.25G Transponder Card w/1+1 fiber protection
30
Chapter 1 Introduction
1.7.22 FRM220-Serial/FDC RS-485/RS-232 Fiber Ring Converter Card
The FRM220-Serial/FDC provides a dual fiber connection converter solution to extend asynchronous RS-485 or
RS-232 transmission distance up to 2km over multimode fiber or up to 120km over single mode fiber. The dual fiber
inputs allow connecting multiple devices in a cascade or "daisy chain" fashion as well as creating ring architecture
for fiber redundancy. The converter is equipped with multiple interface circuits for connection to RS-232 or RS485/422 (2 or 4 wire, full or half duplex). The FRM220-Serial/FDC secures data transmission over EMI resistant
fiber at speeds up to 256kbps for RS-232 or up to 1024kbps for RS-485/422. When the FRM220-Serial/FDC card is
placed in the FRM220 rack with SNMP management, in-band management allows viewing the card and remote
converter's status, type, version, fiber link status, data link status and alarms. Both card and remote can be
configured to enable or disable the port and set the interface type.
Features
• Extend asynchronous serial transmission from 2km to 120km over fiber
• In-band management via terminal, GUI or SNMP in FRM220 chassis
• Two fiber ports support daisy chain and ring architecture
• Multi-drop operation over fiber ring
• Software selectable data interface for RS232/ 422/ 485
• Software selectable two wires (half duplex) or four wires (full duplex) RS485
• Software selectable three or five wires RS232
• Speeds up to 256kbps for RS232 (Async. mode)
• Speeds up to 1Mbps for RS485/422
Specifications
Ports
Standard
LEDs
Power
Power Consumption
Dimension (D x W x H) mm
Weight
Temperature
Humidity
Certification
MTBF
Optical Interface
Connector : 2x SFP LC
Data rate : 36.864Mbps
Line coding: Scrambled NRZ
Bit Error Rate: Less than 10-10
Cable type : MM 62.2/125μm, 50/125μm. SM 9/125μm
Distance : MM 2km, SM 15/30/50/80/120km, WDM 20/40/60/80km
Wavelength: 1310nm, 1550nm,
Electrical Interface
Connector : 6 pins Terminal block
Data Signal Formats
RS485 2-wire
RS422 4-wire
RS232 RTS/CTS 5-wire
RS232 3-wire
Baud Rate:
RS422, RS485 up to 1024kbps
RS232 up to 256kbps
EIA/TIA RS485, RS422, RS232
Power, FX Link, DI, DO, Test
DC In 12V
< 5W
155 x 88 x 23mm
120g
-10~60° C (Operating) ,-20~70° C (Storage)
10~95% non-condensing
CE LVD/EMI, FCC, RoHS
65,000 h (25° C)
This product includes the following models:
FRM220-Serial/FDC RS485/232 Fiber Ring Media Converter Card
31
Chapter 1 Introduction
1.7.23 FRM220-FOM04 4xE1/T1 +100M Ethernet Fiber Optical Multiplexer Card
FRM220-FOM04 is a modular design for 4xE1/T1 + Fast Ethernet multi-service to dual strand fiber PDH multiplexer.
FRM220-FOM04 provides E1/T1 transmission transparently and pure 100Mbps Fast Ethernet simultaneously. The
fiber optic line is based on the SFP technology that allows the flexible use of Multimode or Single mode lines and
enables the support of different wavelengths and distances. The use of bi-directional SFPs maximizes the
utilization of the fiber optic line and results in saving line costs. With SNMP and Web-based management in the
FRM220, the Network administrator can monitor, configure and control the activity of each card in the chassis.
Features
• 4 channels unframed E1/T1
• 10/100Base-TX Ethernet
• Auto MDI/MDIX
• Auto-Negotiation or Force mode
• Supports flow control
• Supports 9K jumbo packets
• Supports Link fault pass through (LFP)
• One clear channel RS232 up to 250Kbps(Async)
• 1+1 fiber protection, less than 50ms
• Supports Digital Diagnostics Monitoring Interface (DDMI)
• AIS on signal loss on E1/T1 and fiber port
• Loopback test on Optical, E1/T1, and RS232 ports
• Supports Dying Gasp
• Two row by twelve character LCD/Menu Keys for configuration
• Supports local or remote In-band management
• Monitor and Configuration status by console port and SNMP manager
• Supports Order wire Ear / Microphone port
• Supports On-Line F/W upgrade
Specifications
E1/T1 ports
Framing
Bit Rate
Line Code
Line Impedance
Unframed (transparent)
E1:2.048 Mb/s , T1: 1.544Mb/s
E1:AMI/HDB3, T1: AMI/B8ZS
E1: Unbalanced 75 ohms (BNC cable)
E1: Balanced 120 ohms (RJ-45)
T1: Balanced 100 ohms (RJ-45)
Receiver sensitivity
Short haul
“Pulse" Amplitude
Nominal 2.37V+/-10% for 75 ohms
Nominal 3.00V+/-10% for 120 ohms
“Zero" Amplitude
Nominal +/-0.3V
Transmit Frequency Tracking +/-30 ppm
Internal Timing
Crystal Oscillator
Jitter Performance
According to ITU-T G.823
Performance monitoring
According to ITU-T G.821
Standards
ITU-T G.703, G.704, G.706 and G.732
Interface Connectors
RJ-45, BNC
Test Loops
LLB (Local Loop Back)
RLB (Remote Loop Back)
Ethernet
Interface Type
Connector
Standards
Duplex modes
Indications
Power Input
Dimensions
Temperature
Humidity
Certifications
10/100Base-TX
RJ-45
IEEE 802.3, 802.3u
Full/Half
OP1 Link, OP2 link, E1/T1 Mode/Link/Loopback test, Order wire, LAN Link/Speed.
AC adapter, 12VDC (or with built-in power in CH20 or CH02M)
88 x 42 x 139mm(DxWxH)
0 ~ 60°C (Operating), -10 ~ 70°C (Storage)
10 ~ 90% RH (non-condensing)
CE, FCC, RoHS
This product includes the following models:
FRM220-FOM04 (Fiber Multiplexer Card)
FOM220-FOM04-CH02M (Stand-alone FOM in 2-slot chassis)
32
Chapter 2 Installation
Chapter 2 Installation
2.1 Introduction
The Installation chapter will cover the physical installation of the FRM220, Rack Mount In-Band Managed
Series Fiber Converter Platform Chassis, the electrical connections, interface connections and cabling
requirements. A brief overview of the functional components such as main unit and management options will also
be outlined in this chapter.
Required Tools
You will need these tools to install the FRM220:
Number 2 Phillips screwdriver for the 3mm and the 12-24 rack installation screws.
Wrist strap or other personal grounding device to prevent ESD occurrences.
Antistatic mat or antistatic foam to set the equipment on.
2.2 Site Preparation
Install the FRM220 within reach of an easily accessible grounded AC outlet or three wire (-48VDC, Power
return, Earth Ground) central office power. The AC outlet should be capable of furnishing 100 to 240 VAC. Refer to
2.4 Electrical Installation. Allow at least 10cm (4 inch) clearance at the front of the FRM220 for the Fiber and other
copper cables.
2.3 Mechanical Assembly
The FRM220 is designed for rack mount installation and will require 2U space in a standard EIA 19" or 23" rack.
The FRM220 has two removable fan units that install in the rear side of the chassis. Without fans, excessive
temperatures within the unit might cause it to electrically shutdown. The FRM220 chassis is delivered completely
assembled, however power modules and converter cards may or may not be installed in the chassis upon delivery.
The rack mount adapters may be placed along the front or centrally located on the chassis. The same brackets
also allow installation into a 23" rack and in this configuration, central mounting is recommended.
2.3.1 Rack mounting
Bracket may install for
19" or 23" mounting.
(factory installed)
Figure 2-1 Standard 19" Rack-Mount Installation of FRM220 Unit requires 2RU space
33
Chapter 2 Installation
2.3.2 Fan Units Removal/Replacement
Figure 2-2 Removal/Replacement of FRM220 Fan Units
2.3.3 Line Card Conversion, Stand-alone/Rack
The FRM220 Media Converter Line Card may be mounted in the FRM220-CH20 chassis or serve as a standalone unit. When installing in the FRM220-CH01 single slot chassis or FRM220-CH02 dual slot chassis, the outer
cover holds the line card. The unit then serves as a stand-alone media converter that can be linked to a line card in
the FRM220 chassis.
FRM220-CH01-AC(DC), single
slot chassis with built-in AC,
DC or 2AC, 2DC, AC+DC
power. (five models)
FRM220-CH01, single slot
chassis
Requires external AC to DC
12V switching adapter.
FRM220-CH02-AD, dual slot
chassis with built-in AC+DC
power. (2 models; one with
DB9 console, one for NMC)
Figure 2-3 Converting FRM220 line card for stand-alone use
34
Chapter 2 Installation
2.4 Electrical Installation
With an AC power module, AC power is supplied to the FRM220 through a standard IEC C14 3-prong
receptacle, located on the rear of the module. Any national power cord with IEC C13 line plug may be used to
connect AC power to the power module. With a DC module, DC -48V is connected to the terminal block located on
the rear of the module, observing the proper polarity. The FRM220 should always be grounded through the
protective earth lead of the power cable in AC installations, or via the frame ground connection for DC installations.
IEC C13 line plug
Left: Live line
Right: Neutral line
Middle: Ground
-V
DC IN
FG +V
Left: -V (-48V)
Right: +V (0V)
Middle: Frame Ground
36~60VDC
Figure 2-4 IEC (AC) & terminal block (DC) power connector pin assignment
2.5 Alarm Installation
The alarm relay provides one set of Power Failure contacts (normally open) and another set of FAN Failure
contacts (normally open) contacts for monitoring the power and fans condition of the FRM220. The alarm contacts
may also be programmed through the management interface to react to different fault conditions.
Cascade Ports
IN
Alarm Contacts
1 2
125VAC
110VDC
30VDC
1A
0.6A
4A
OUT
Chassis ID
Figure 2-5 Alarm Relay Contacts and Cascade Ports
Figure 2-6 Example of electrical circuit for visual and audible alarms
35
Chapter 2 Installation
2.6 Chassis Cascade
The FRM220 chassis may be cascaded in such a manner that only one single IP address is required to
manage up to 10 chassis in a single location. The connection diagram is shown below. Each chassis is assigned a
unique ID starting at zero for the master chassis and incrementing for each cascaded chassis, up to an ID of nine.
The "out" of the parent chassis connects to the "in" of the slave using any standard UTP cable with RJ-45
connectors.
Chassis ID = 0
(Master)
0
IN
OUT
Chassis ID = 1
(Slave)
1
IN
OUT
Chassis ID = 2
(Slave)
2
IN
OUT
Chassis ID = 9
(Slave)
9
IN
OUT
Figure 2-7 Cascade Ports Connections and ID assignment
Pin No.
Signal
1
2
3
4
5
6
7
8
Tx+
TxRx+
Chain+
NC
RxChainNC
Definition
Transmit positive signal
Transmit negative signal
Receive positive signal
Chain positive signal
No connection
Receive negative signal
Chain negative signal
No connection
Direction
(Master)
Out
Out
In
Out
Direction
(Slave)
In
In
Out
In
In
Out
Out
In
Figure 2-8 Cascade Ports Detailed Pin Assignment
36
Chapter 2 Installation
2.7 Power Modules Removal/Replacement
The Power Supply Modules in the FRM220 are available in two versions, one AC and one DC type. The
universal AC version supports input voltages of 100 to 240 (±10% @ ambient temperature) volts at frequencies of
47 to 63 Hertz. The DC version supports either a standard 36 to 60VDC input voltage. Only one power supply
module is required to power a completely full rack. When two Power Supply Modules are installed, the supplies are
hot swappable and redundant, meaning any one supply may be removed and replaced without impacting the
operation of the FRM220 Rack.
Hot Swap
Power
Modules
Figure 2-7 Power Modules for FRM220
37
Chapter 2 Installation
2.8 Installation
2.6.1 Line Card Installation
The Line Cards for the FRM220 are Fiber Media Converter Cards which slide into the FRM220 chassis, and
interface with the pack panel "main board". The back panel provides a connection to the converter cards for power
and serial control.
The media converter cards are designed to be "hot" swappable, meaning the FRM220 chassis need not be
powered off in order to remove or replace a card. Removal and installation of converter cards with the rack chassis
under power will not effect the operation of other converter cards.
Removal of a converter card is accomplished by loosening the one (1) captive screw (upper) and then pulling
the card straight out of the chassis with the same screw. Replace the card by reversing the procedure, align in the
slot groove and gently seat the card, retightening the captive screw.
Figure 2-7 Line card removal/replacement
2.6.2 NMC Card Installation
Slot number 1 of the chassis is reserved for the Network Management Controller (NMC). The NMC card
provides the full network management features. When the NMC is installed, the rack and all line cards become
manageable by industry standard SNMP protocol. (Please refer to Chapter 3 for more information on the operation
of the network management features). The remaining slots, numbered 2 through 20, may contain any other
FRM220 In-band Managed fiber media converter card.
Figure 2-8 NMC removal/replacement in slot number 1
IMPORTANT: In the FRM220 In-Band Managed Rack, slot number1 must contain an NMC card. In a chassis where nonmanaged line cards are employed (cards that use DIP switch settings), slot number 1 may then be used for a non-managed
media converter line card.
38
Chapter 3 Management Quick Start
3.3.3 TCP/IP Setup
From the main menu, use the 'L' key to enter the 'SNMP System Configuration Setup' menu. An example menu is
displayed below.
1
2
3
4
5
****************************************
*** CTC UNION TECHNOLOGIES CO., LTD. ***
*** FRM220 NMC
VER. 2.12 ***
****************************************
<< SNMP System Configuration Setup of Chassis 0 >>
Model = FRM220
S/N
= 000000
Target MAC Address
= 00:02:ab:06:20:20
<1>: Target IP
: 59.125.162.252
<2>: Target Netmask
: 255.255.255.240
<3>: Target Gateway
: 59.125.162.241
<4>: Target Name
: FRM220
<5>: TFTP Server IP
: 172.24.1.251
<6>: TFTP Download Kernel
: kernel14619.gz
<7>: TFTP Download File System : romfs212.gz
<8>: Load default settings and write to system.
<9>: Do TFTP and Flash Kernel function.
<A>: Do TFTP and Flash File System function.
<T>: Adjust Date and Time.
<U>: Upgrade Line Card Menu.
<ESC>: Write to system and go to previous menu.
Please select an item.
Items of interest:
1. This is the display header. The version shown reflects the currently installed 'romfs.gz' or file system version (2.12).
2. The model name and serial number are shown in this section.
3. The TCP/IP settings for IP, subnet mask, default gateway and hostname and set using keyin 1~4.
4. Items 5~A handle setting and upgrading via TFTP protocol. Set the TFTP server's IP and names of the kernel and filesystem
file names. Execute upgrade as directed in the upgrade procedure included with each update package.
5. Item 'T' is used to setup the SNTP time protocol so that this management can synchronize time with a time server. Item 'U'
enters the menu to upgrade line cards in the FRM220.
Setup the default gateway, subnet mask and IP address as instructed by your network administrator. After any
TCP/IP setting change, the NMC must be rebooted. So, ESC back to the main menu and key-in 'R' to reboot and
confirm with 'Y' (yes).
3.3.4 Test TCP/IP Connection
Open a command window and ping the FRM220. Make sure the network settings are correct.
40
Chapter 3 Management Quick Start
3.4 Telnet Terminal
Use either a Windows® command window or Telnet client application and connect to the FRM220 NMC using
the assigned management IP address. The following is an example of a Telnet screen. It is exactly the same as a
local serial console screen, only it can be accessed remotely.
3.5 Web Based Manager
The FRM220 NMC supports web based management. Use your favorite browser (Internet Explorer or Firefox)
and connect to the FRM220 NMC by using the NMC's IP address. Refer to the FRM220 NMC User Manual for
details.
41
Chapter 3 Management Quick Start
3.6 Element Management System (EMS)
The objective of an Element Management System is to provide four major functions for telecommunication operators:
- Fault Management (FM)
- Performance Management (PM)
- Configuration Management (CM)
- Security Management (SM)
CTC Union's EMS is a proprietary management system designed to provision, monitor and maintain multiple
equipments designed by CTC Union. It is a client/server architecture using a Windows® based server with
Microsoft MS-SQL Server for a database and Java based server and client. The client software can be run on the
server or remotely on another physical machine as long as there is an IP connection between the client and server.
Refer to the EMS User Manual for details.
INMS
LAN
or
WAN
Broker
DB
CORBA Server Server
Server
polling
for PM
Client
LAN
or
WAN
Client
notification
SNMP
polling
Agent
The EMS administrator creates users with different permissions and builds different management trees. Public
trees can be seen by all users while private trees can only be seen by their creator. Client interface provides
provisioning functions and the viewing and handling of Alarms, Traps and performance data.
42
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
