ENVCWI-PTG1
Wireless Network (IP) Camera with
PAN & TILT
Advanced Installation Guide
Version 1.1
Regulatory notes and statements
Wireless LAN, Health and Authorization for use
Radio frequency electromagnetic energy is emitted from Wireless LAN
devices. The energy levels of these emissions however are far much less
than the electromagnetic energy emissions from wireless devices like for
example mobile phones. Wireless LAN devices are safe for use frequency
safety standards and recommendations. The use of Wireless LAN devices
may be restricted in some situations or environments for example:
•On board of airplanes, or
•In an explosive environment, or
•In case the interference risk to other devices or services is perceived or
identified as harmful
In case the policy regarding the use of Wireless LAN devices in specific
organizations or environments (e.g. airports, hospitals, chemical/oil/gas
industrial plants, private buildings etc.) is not clear, please ask for
authorization to use these devices prior to operating the equipment.
Regulatory Information/disclaimers
Installation and use of this Wireless LAN device must be in strict accordance
with the instructions included in the user documentation provided with the
product. Any changes or modifications made to this device that are not
expressly approved by the manufacturer may void the user’s authority to
operate the equipment. The Manufacturer is not responsible for any radio or
television interference caused by unauthorized modification of this device, of
the substitution or attachment. Manufacturer and its authorized resellers or
distributors will assume no liability for any damage or violation of
government regulations arising from failing to comply with these guidelines.
USA-FCC (Federal Communications Commission) statement
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may
cause undesired operation of this device.
-1-
FCC Radio Frequency Exposure statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET
65 and found compliant to the requirements as set forth in CFR 47 Sections
2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio
frequency devices. The radiated output power of this Wireless LAN device is
far below the FCC radio frequency exposure limits. Nevertheless, this device
shall be used in such a manner that the potential for human contact during
normal operation is minimized.
When nearby persons has to be kept to ensure RF exposure compliance, in
order to comply with RF exposure limits established in the ANSI C95.1
standards, the distance between the antennas and the user should not be
less than 20 cm.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy. If
not installed and used in accordance with the instructions, it may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try and correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the distance between the equipment and the receiver.
3. Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Export restrictions
This product or software contains encryption code that may not be exported
or transferred from the US of Canada without an approved US Department
of Commerce export license.
-2-
Safety Information
Your device contains a low power transmitter. When device is transmitted it
sends out radio frequency (RF) signal.
CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this
equipment should be installed and operated with minimum distance 20cm
between the radiator and your body. Use on the supplied antenna.
Unauthorized antenna, modification, or attachments could damage the
transmitter and may violate FCC regulations.
The antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be colocated or operating in conjunction with any other antenna or transmitter.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.
Protection requirements for health and safety – Article 3.1a
Testing for electric safety according to EN 60950 has been conducted.
These are considered relevant and sufficient.
Protection requirements for electromagnetic compatibility (EMC) – Article
3.1b
Testing for electromagnetic compatibility according to EN 301 489-1, EN 301
489-17 and EN 55024 has been conducted. These are considered relevant
and sufficient.
Effective use of the radio spectrum – Article 3.2
Testing for radio test suites according to EN 300 328 has been conducted.
These are considered relevant and sufficient.
CE in which Countries where the product may be used freely:
Germany, UK, Italy, Spain, Belgium, Netherlands, Portugal, Greece, Ireland,
Denmark, Luxembourg, Austria, Finland, Sweden, Norway and Iceland.
France: except the channel 10 through 13, law prohibits the use of other
channels.
Caution
The Federal Communication Commission warns the user that changes or
modifications to the device not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
-3-
Copyright
The company has an on-going policy of upgrading its products and it may be
possible that information in this document is not up-to-date. Please check
with your local distributors for the latest information.
The contents of this publication may not be reproduced in any part or as a
whole, stored, transcribed in an information retrieval system, translated into
any language, or transmitted in any form or by any means, mechanical,
magnetic, electronic, optical, photocopying, manual, or otherwise, without
the prior written permission or consent from the company.
Trademarks
All products, companies and brand names are trademarks or registered
trademarks of their respective companies. They are used for identification
purpose only.
Specifications are subject to be changed without prior notice.
-4-
P REFACE
Thank you for purchasing the Wireless Network (IP) Camera with
PAN & TILT, a powerful wireless network camera with the 2-way
audio function which provides the high-quality image and on-the-spot
audio via the Internet connection. The camera’s pan/tilt functions
allow you to control the camera to monitor everywhere remotely.
Through the GPIO connectors, the camera can attach a variety of
external devices for your specific purposes. The camera can be
installed as a standalone system within your application environment
easily and quickly, and supports remote management function so
that you can access and control it using a Web browser on your PC.
This Advanced Installation Guide provides you with the instructions
and illustrations on how to use your camera, which includes:
Chapter 1 Introduction to Your Camera describes the features of
the camera. You will also know the components and
functions of the camera.
Chapter 2 Hardware Installation helps you install the camera
according to your application environment. You can use
this camera at home, at work, at any where you want.
Chapter 3 Accessing the Camera lets you start using your camera
without problem. The camera can be set up easily and
work within your network environment instantly.
Chapter 4 Configuring the Camera guides you through the
configuration of the camera using the Web browser on
your PC.
Chapter 5 Appendix provides the specification of the camera and
some useful information for using your camera.
NOTE The illustrations and configuration values in this guide are for
reference only. The actual settings depend on your practical
application of the camera.
-5-
Contents
Preface................................................................................................5
Chapter 1 Introduction To Your Camera.............................................7
1.1 Checking the Package Contents...........................................7
1.2 Getting to Know Your Camera ..............................................8
1.3 Features and Benefits .........................................................10
1.4 System Requirement...........................................................12
Chapter 2 Hardware Installation .......................................................13
2.1 Installing the Wall Mount Kit................................................13
2.2 Connecting the Camera to LAN/WLAN...............................14
2.3 Applications of the Camera .................................................15
Chapter 3 Accessing The Camera....................................................16
3.1 Using IPFinder ....................................................................16
3.2 Accessing to the Camera ....................................................17
3.3 Configuring the IP Address of the PC .................................21
Chapter 4 Configuring The Camera..................................................22
4.1 Using the Web Configuration ..............................................22
4.2 Using Smart Wizard ............................................................23
4.3 Basic Setup .........................................................................26
4.4 Network Settings .................................................................30
4.5 Pan/Tilt Settings ..................................................................37
4.6 Setting up Video & Audio ....................................................38
4.7 Event Server Configuration .................................................42
4.8 Motion Detect ......................................................................45
4.9 Event Config........................................................................46
4.10 Tools ...................................................................................51
4.11 Information ..........................................................................53
Appendix...........................................................................................54
A.1 Specification........................................................................54
A.2 GPIO Terminal Application..................................................56
A.3 Glossary of Terms...............................................................57
-6-
C HAPTER 1
I NTRODUCTION T O Y OUR
C AMERA
1.1 Checking the Package Contents
Check the items contained in the package carefully. You should have
the following:
One Wireless Network (IP) Camera with PAN & TILT.
One AC Power Adapter.
One External Detachable Antenna
One Wall Mount Kit.
One GPIO Connector
One Ethernet Cable (RJ-45 type).
One Installation CD-ROM.
One Quick Installation Guide.
NOTE Once any item contained is damaged or missing, contact the
authorized dealer of your locale.
If you have any problem on the product(s), please contact your
local authorized dealer or check our web site
http://www.encore-usa.com for support.
-7-
1.2 Getting to Know Your Camera
Antenna
Lens Assembly
Power LED
indicates the
camera is powered
on with the steady
amber light.
Link LED
indicates the
camera’s network
connectivity with the
flashing green light.
Internal Microphone
allows the camera to
receive sound and voice.
Front View
-8-
Ethernet Cable Connector
connects the network
cable, which supports the
NWay protocol so that the
camera can detect the
network speed
automatically.
External Antenna
Connector connects
the external antenna.
DC Power Connector
connects the AC
power adapter, in
order to supply power
to the camera.
Audio-out Connector
connects an external
active speaker.
GPIO Connectors
is used to connect the
external devices.
Reset Button
will restart the camera when it
is pressed quickly; when it is
pressed and held for five
seconds, the camera will
resume the factory default
settings.
Rear View
-9-
1.3 Features and Benefits
MJPEG codec Supported
The camera provides you with excellent images by the MJPEG
codec technology, allowing you to adjust image size and quality,
and bit rate according to the networking environment.
2-way Audio Capability
The built-in microphone of the camera provides on-the-spot
audio via the Internet, allowing you to monitor the on-site voice.
In addition, you can connect an external speaker to the camera
to speak through the camera.
Optimal Viewing
With the pan/tile functions, you can easily monitor everywhere
via the camera by moving the camera lens to the left/right
(165/165 degrees) or up/down (90/15 degrees). In addition, you
can assign up to eight positions for the camera, enabling you to
move the camera lens to the desired position quickly.
I/O Connectors Provided
The camera provides the I/O connectors on the rear panel
(IN/OUT), which provide the physical interface to send and
receive digital signals to a variety of external alarm devices. You
can connect a special featured device, and then configure the
settings and control the device from the GPIO Trigger window of
Web Configuration.
Remote Control Supported
By using a standard Web browser or the bundled UltraView
software application, the administrator can easily change the
configuration of the camera via Intranet or Internet. In addition,
the camera can be upgraded remotely when a new firmware is
available. The users are also allowed to monitor the image and
take snapshots via the network.
- 10 -
Multiple Platforms Supported
The camera supports multiple network protocols, including
TCP/IP, SMTP e-mail, HTTP, and other Internet related
protocols. Therefore, you can use the camera in a mixed
operating system environment, such as Windows 2000 and
Windows XP.
Multiple Applications Supported
Through the remote access technology, you can use the
cameras to monitor various objects and places for your own
purposes.
For example, babies at home, patients in the hospital, offices
and banks, and more. The camera can capture both still images
and video clips, so that you can keep the archives and restore
them at any time.
- 11 -
1.4 System Requirement
Networking
LAN:
10Base-T Ethernet or 100Base-TX Fast Ethernet.
WLAN: IEEE 802.11g/b compliant wireless interface.
Accessing the Camera using Web Browser
Platform:
Microsoft® Windows® 2000/XP/Vista
CPU:
Intel Pentium III 350MHz or above
RAM:
128MB
Resolution:
800x600 or above
User Interface: Microsoft® Internet Explorer 6.0 or above
Apple Safari 2 or above
Mozilla Firefox 2.00 or above
Accessing the Camera using UltraView
Platform:
Microsoft® Windows® 2000/XP/Vista
Hardware Requirement:
1 camera connected: Intel Pentium III 800MHz; 512MB RAM
2 ~ 4 cameras connected: Intel Pentium 4 1.3GHz; 512MB RAM
5 ~ 8 cameras connected: Intel Pentium 4 2.4GHz; 1GB RAM
9 ~ 16 cameras connected: Intel Pentium 4 3.4GHz; 2GB RAM
Resolution:
1024x768 or above
NOTE If you connect multiple cameras to monitor various places
simultaneously, you are recommended to use a computer with
higher performance.
- 12 -
C HAPTER 2
H ARDWARE I NSTALLATION
2.1 Installing the Wall Mount Kit
The camera comes with a Wall Mount Kit, which allows you to place
your camera anywhere by mounting the camera through the three
screw holes located in the base of the Wall Mount Kit.
Screw
Wall Mount Kit
Screw
Screw
- 13 -
2.2 Connecting the Camera to LAN/WLAN
Use the provided Ethernet cable to
connect the camera to your local
area network (LAN).
When you connect the AC power
adapter, the camera is powered on
automatically. You can verify the
power status from the Power LED
on the front panel of the camera.
Once connected, the Link LED
starts flashing green light and the
camera is on standby and ready
for use now.
Connecting the Ethernet Cable
If you use a wireless network in
your application environment, you
need to attach the included
external antenna to the camera.
When the camera is powered on,
the camera will automatically
search any access point with
“default” SSID.
Connecting the External Antenna
NOTE If the camera cannot connect to your wireless network, you
need to install the camera in LAN and proceed with WLAN
settings.
- 14 -
2.3 Applications of the Camera
The camera can be applied in multiple applications, including:
Monitor local and remote places and objects via Internet or
Intranet.
Capture still images and video clips remotely.
Upload images or send email messages with the still images
attached.
The following diagram explains one of the typical applications for
your camera and provides a basic example for installing the camera.
*
*
* Please enclose by
waterproof housing
when using in outdoor
Home Applications
- 15 -
C HAPTER 3
A CCESSING T HE C AMERA
3.1 Using IPFinder
The camera comes with a convenient utility, IPFinder, which is
included in the Installation CD-ROM, allowing you to search the
camera on your network easily.
1. Insert the Installation CD-ROM into your computer’s CD-ROM
drive to initiate the Auto-Run program.
2. Click the IPFinder item to launch the utility. The control panel will
appear as below.
Display the connected
camera(s).
Double click to link the
Camera.
Click About to get the Version information of IPFinder.
Click Link to connect the selected camera.
Click Change IP to modify the IP address of the selected camera.
Click Search to find the IP address of the connected camera(s).
Click Exit to close the utility.
3. Once you get the IP address of the camera, launch the Web
browser through the Link button or use UltraView software to
access your camera.
- 16 -
3.2 Accessing to the Camera
Whenever you want to access the camera:
1. Connect your camera to the network (or the PC directly).
2. Since the default configuration of the camera is DHCP mode
enabled, you are recommended to launch IPFinder to search the
IP address that is assigned to the camera by the DHCP server,
and then click Link to access the camera via the Web browser.
3. When the login window appears, enter the default User name
(admin) and password (admin) and press OK to access to the
main screen of the camera’s Web Configuration.
Enter the User name
and Password.
NOTE If you are initially access to the camera, you will be ask to
install a new plug-in for the camera. Permission request
depends on the Internet security settings of your computer.
Click Yes to proceed.
- 17 -
After you login into the Web Configuration of the camera, the main
page will appear as below:
Zoom In
Buttons
Live View/Setup
Switch
Nightmode Button
Camera Information
Pan/Tilt Buttons
Live View
Function Buttons
The main page of the Web Configuration provides you with many
useful information and functions, including:
Camera Information – Displays the camera’s location and the
current date & time. The information can be modified in the Web
Configuration.
Live View Image – Displays the real-time image of the
connected camera.
Move your mouse to the Live View area and click on
anywhere, the camera lens will then move to the position
where you clicked to display it in the central part of Live View
area.
When you enlarge the Live View by clicking the Zoom In
buttons (2x or 3x), you can move the displayed image by
right-clicking your mouse on the Live View area. The position
- 18 -
where you right-clicked will be displayed in the central part of
Live View area.
Zoom In Buttons – Click the buttons to zoom in the live view
image by 1x, 2x, and 3x.
Nightmode Button – Click the button to enable the “nightshot
mode” to deliver clearer images in the dark environment.
However, this will reduce the frame rate of video setting.
Live View/Setup Switch – Click Setup to configure the camera.
For details, see Chapter 4.
Pan/Tilt Buttons – Provides the buttons to control the camera
lens:
Left/Right/Up/Down/Home buttons allow you to move the
camera lens position. Clicking the Home button will move
the camera lens to the assigned home position.
Up
Home
Left
Right
Down
Auto Patrol button controls the camera to automatically
scan the preset positions once. Click Stop to stop patrolling.
Click the Number button (1~8) to move the camera lens to
the preset position immediately.
To set up the preset positions, move the camera lens by
clicking the Left/Right/Up/Down buttons to the desired
position first, then select the number (1~8) from the pulldown list and click the Apply button. You can enter a
descriptive name for the assigned position in the text box to
identify it easily.
- 19 -
Function Buttons – Use these buttons to control the audio,
video, and trigger functions.
Manual Record allows you to record and save a video clip.
Snapshot allows you to capture and save a still image.
Browse allows you to assign the destination folder to store
the video clips and still images.
Talk allows you to speak out through the camera. Please
note only one user is allowed to use this function at a time.
Listen allows you to receive the on-site sound and voice
from the camera.
Trigger Out allows you to trigger on/off the GPIO output
manually.
NOTE If your PC use Microsoft Vista platform, maybe you can’t find
these recorded files what stored by Snapshot or Manual
Record. You need to disable the protected mode of Security
in the IE Browser. Please follow as below Steps:
1. Open IE Browser
2. Select Tools Internet Options
3. Select Security
4. Disable the “Enable Protected Mode” then press OK
- 20 -
3.3 Configuring the IP Address of the PC
If you are failed to access to the camera, please check the IP
address of your computer. When you connect the camera to your
computer directly to proceed with configuration of the camera, you
need to set up the IP addresses to be in the same segment for the
two devices to communicate.
1. On your computer, click Start > Control Panel to open the
Control Panel window.
2. Double-click Network Connection to open the Network
Connection window.
3. Right-click Local Area Connection and then click Properties
from the shortcut menu.
4. When the Local Area Connection Properties window appears,
select the General tab.
5. Select Internet Protocol [TCP/IP] and then click Properties to
bring up the Internet Protocol [TCP/IP] Properties window.
6. To configure a fixed IP address that is within the segment of the
camera, select the Use the following IP address option. Then,
enter an IP address into the empty field. The suggested IP
address is 192.168.0.x (x is 1~254 except 30), and the
suggested Subnet mask is 255.255.255.0.
7. When you finished the setting, click OK.
- 21 -
C HAPTER 4
C ONFIGURING T HE C AMERA
4.1 Using the Web Configuration
You can access and manage the camera through the Web browser
and the provided software application UltraView. This chapter
describes the Web Configuration, and guides you through the
configuration of the camera by using the Web browser.
To configure the camera, click Setup on the main page of Web
Configuration. The Web Configuration will start from the Basic page.
The Web Configuration contains the
settings that are required for the
camera in the left menu bar,
including Smart Wizard, Basic,
Network, Pan/Tilt, Video/Audio,
Event Server, Motion detect, Event
Config, Tools, and Information.
- 22 -
4.2 Using Smart Wizard
The camera’s Smart Wizard lets you configure your camera easily
and quickly. The wizard will guide you through the necessary
settings with detailed instructions on each step.
To start the wizard, click Smart Wizard in the left menu bar.
Step 1. Camera Settings
Enter the name for
the camera and
place.
Enter the
administrator
password set.
Step 2. IP Settings
Select the IP
setting according
to your network:
DHCP, Static IP,
or PPPoE.
- 23 -
Step 3. Email Settings
Enter the required
information to be
able to send email
with image.
Step 4. Wireless Networking
Complete the
required settings
for wireless
networking.
- 24 -
Step 5. Confirm Settings
This step shows the configuration of your camera. When you confirm
the settings, click Apply to finish the wizard and reboot the camera.
Otherwise, click Prev to go back to the previous step(s) and change
the settings. Or, click Cancel to end the wizard and discard the
changes.
- 25 -
4.3 Basic Setup
The Basic menu contains three sub-menus that provide the system
settings for the camera, such as the Camera Name, Location, Date &
Time, and User management.
Basic >> System
Basic
- Camera Name: Enter a descriptive name for the camera.
- Location: Enter a descriptive name for the location used by
the camera.
Indication LED
This item allows you to set the LED illumination as desired.
There are two options: Normal and OFF.
- 26 -
Basic >> Date & Time
- TimeZone: Select the proper time zone for the region from the
pull-down menu.
- Synchronize with PC: Select this option and the date & time
settings of the camera will be synchronized with the connected
computer.
- Synchronize with NTP Server: Select this option and the
time will be synchronized with the NTP Server. You need to
enter the IP address of the server and select the update
interval in the following two boxes.
- Manual: Select this option to set the date and time manually.
- 27 -
Basic >> User
Administrator
To prevent unauthorized access to the camera’s Web
Configuration, you are strongly recommended to change the
default administrator password. Type the administrator password
twice to confirm and set the password.
General User
- User Name: Enter the user’s name you want to add to use the
camera.
- Password: Enter the password for the new user.
When you are finished, click Add/Modify to add the new user
to the camera. To modify the user’s information, select the one
you want to modify from UserList and click Add/Modify.
- 28 -
- UserList: Display the existing users of the camera. To delete
a user, select the one you want to delete and click Delete.
Guest
- User Name: Enter the guest’s name you want to add to use
the camera.
- Password: Enter the password for the new guest.
- UserList: Display the existing guests of the camera. To delete
a user, select the one you want to delete and click Delete.
NOTE The “General User” can access the camera and control the
Function buttons of the camera’s Web Configuration. The
“Guest” can only view the live view image from the main page
of the Web Configuration while accessing the camera. Only
the “Administrator” is allowed to configure the camera through
the Web Configuration.
- 29 -
4.4 Network Settings
The Network menu contains three sub-menus that provide the
network settings for the camera, such as the IP Setting, DDNS
Setting, IP Filter, and Wireless network.
Network >> Network
IP Setting
- 30 -
This item allows you to select the IP address mode and set up
the related configuration. The default setting is DHCP mode
enabled.
- DHCP: Select this option when your network uses the DHCP
server. When the camera starts up, it will be assigned an IP
address from the DHCP server automatically.
- Static IP: Select this option to assign the IP address for the
camera directly. You can use IPFinder to obtain the related
setting values.
IP
Enter the IP address of the camera. The
default setting is 192.168.0.30.
Subnet Mask
Enter the Subnet Mask of the camera. The
default setting is 255.255.255.0.
Default Gateway
Enter the Default Gateway of the camera.
The default setting is 192.168.0.1.
Primary/
Secondary DNS
The DNS (Domain Name System) translates
domain names into IP addresses. Enter the
Primary DNS and Secondary DNS that are
provided by your ISP.
- PPPoE: Select this option when you use a direct connection
via the ADSL modem. You should have a PPPoE account from
your Internet service provider. Enter the User Name and
Password. The camera will get an IP address from the ISP as
starting up.
NOTE Once the camera get an IP address from the ISP as starting
up, it automatically sends a notification email to you.
Therefore, when you select PPPoE as your connecting type,
you have to set up the email or DDNS configuration in
advance.
DDNS Setting
- 31 -
With the Dynamic DNS feature, you can assign a fixed host and
domain name to a dynamic Internet IP address. Select the
Enable option to enable this feature. Then, select the DDNS
Provider from the pull-down list and enter the required
information in the Host Name, User Name, and Password
boxes. Please note that you have to sign up for DDNS service
with the service provider first.
UPnP
The camera supports UPnP (Universal Plug and Play), which is
a set of computer network protocols that enable the device-todevice interoperability. In addition, it supports port auto mapping
function so that you can access the camera if it is behind an NAT
router or firewall. Select the Enable option to enable this feature.
Ports Number
- HTTP Port: The default HTTP port is 80.
- 32 -
Network >> IP Filter
The IP Filter setting allows the administrator of the camera to limit
the users within a certain range of IP addresses to access the
camera.
Start/End IP Address
Assign a range of IP addresses that are not allowed to access
the camera by entering the Start IP address and End IP address.
When you finish the setting, click Add to save the range setting.
You can repeat the action to assign multiple ranges for the
camera.
For example, when you enter 192.168.0.50 in Start IP Address
and 192.168.0.80 in End IP Address, the user whose IP address
located within 192.168.0.50 ~ 192.168.0.80 will not be allowed to
access the camera.
- 33 -
Deny IP List
The list displays the range setting(s) of IP addresses that are not
allowed to access the camera. To clear the setting, select a
range of IP addresses from the list and click Delete.
Network >> Wireless Setting
The camera supports WLAN while you use the wireless network.
Select the Enable option to enable this feature.
- Network ID (SSID): Keep the default setting of this option to
connect the camera to any access point under the
infrastructure network mode. To connect the camera to a
- 34 -
specified access point, set a SSID for the camera to
correspond with the access point’s ESS-ID. To connect the
camera to an Ad-Hoc wireless workgroup, set the same
wireless channel and SSID to match with the computer’s
configuration.
Click Site Survey to display the available wireless networks,
so that you can easily connect to one of the listed wireless
networks.
List of searching results
- Wireless Mode: Select the type of wireless communication for
the camera: Infrastructure or Ad-Hoc.
- Channel: Select the appropriate channel from the list.
- Authentication: Select the authentication method to secure
the camera from being used by unauthorized user: Open,
Shared-key, WPA-PSK, and WPA2-PSK. The following table
explains the four options:
Open
The default setting of Authentication mode,
which communicates the key across the network.
Shared-key
Allow communication only with other devices
with identical WEP settings.
WPA-PSK/
WPA2-PSK
WPA-PSK/WPA2-PSK is specially designed for
the users who do not have access to network
- 35 -
authentication servers. The user has to manually
enter the starting password in their access point
or gateway, as well as in each PC on the
wireless network.
If you select Open or Shared-key as the Authentication mode,
you need to complete the following settings:
Encryption: Select the WEP option to enable the data
encryption feature to secure the camera within the wireless
network.
Format: Once you enable the Encryption feature, you need
to determine the encryption format by selecting ASCII or
HEX. ASCII format causes each character you type to be
interpreted as an eight-bit value. Hex format causes each
pair of characters you type to be interpreted as an eight-bit
value in hexadecimal (base 16) notation.
Key Length: Select the WEP key length you want to use: 64
bits or 128 bits.
WEP Key 1/2/3/4: Enter the WEP key(s) in the following
boxes.
If you select WPA-PSK or WPA2-PSK as the Authentication
mode, you need to complete the following settings:
Encryption: Select TKIP or AES. TKIP (Temporal Key
Integrity Protocol) changes the temporal key every 10,000
packets to insure much greater security than the standard
WEP security. AES (Advanced Encryption Standard) is used
to ensure the highest degree of security and authenticity for
digital information.
Pre-Shared Key: This is used to identify each other in the
network. Enter the name in the box, and this name must
match the Pre-shared key value in the remote device.
- 36 -
4.5 Pan/Tilt Settings
The Pan/Tilt menu allows you to configure the pan/tilt functions of the
camera.
Pan/Tilt >> Pan & Tilt Settings
- Pan/Tilt Calibration: Click Calibration to calibrate the
position of the camera lens.
- Pan Steps: Set the changing range (1~20 degrees) when you
click the Left/Right button.
- Tilt Steps: Set the changing range (1~20 degrees) when you
click the Up/Down button.
- Auto Patrol Stay Time: Set the stay time (1~999 seconds) of
each preset positions when the camera is patrolling.
- 37 -
4.6 Setting up Video & Audio
The Video & Audio menu contains three sub-menus that provide the
video and audio settings for the camera.
Video & Audio >> Camera
Image Setting
- Brightness: Adjust the brightness level from 0 ~ 100.
- Contrast: Adjust the contrast level from 0 ~ 100.
- Saturation: Adjust the colors level from 0 ~ 100.
- 38 -
Click Default to restore the default settings of the three options
above.
- Mirror: Select the Horizontal option to mirror the image
horizontally. Select the Vertical option to mirror the image
vertically.
- Light Frequency: Select the proper power frequency
according to the camera’s location: 50Hz, 60Hz, or Outdoor.
Overlay Setting
- Includes Date & Time: Select this option to display the date &
time stamp on the live view image.
- Enable Opaque: Select this option to set a black background
to the displayed date & time stamp.
- 39 -
Video & Audio >> Video
MJPEG
- Video Resolution: Select the desired video resolution from
the three formats: VGA, QVGA and QQVGA. The higher
setting (VGA) obtains better video quality while it uses more
resource within your network.
- Video Quality: Select the desired image quality from five
levels: Lowest, Low, Medium, High, and Highest.
- Frame Rate: Select Auto or a proper setting depending on
your network status.
- 40 -
Video & Audio >> Audio
Camera Microphone In
Select the Enable option to enable the camera’s audio function,
so that you can receive the on-site sound and voice from the
camera.
Camera Speaker Out
Select the Enable option to enable the camera’s external
speaker function, so that the connected speaker can play the
sound and voice through the camera.
- Volume: Set the speaker’s volume.
- 41 -
4.7 Event Server Configuration
The Event Server menu contains two sub-menus that allow you to
upload images to FTP, send emails that include still images, and
store the images to a NAS system.
When you complete the required settings for FTP or Email, click Test
to test the related configuration is correct or not. Once the camera
connects to the server successfully, click Apply.
Event Server Setting>> FTP
- Host Address: Enter the IP address of the target FTP server.
- Port Number: Enter the port number used for the FTP server.
- User Name: Enter the user name to login into the FTP server.
- Password: Enter the password to login into the FTP server.
- 42 -
- Directory Path: Enter the destination folder for uploading the
images. For example, /Test/.
- Passive Mode: Select the Enable option to enable passive
mode.
Event Server Setting >> Email
- SMTP Server Address: Enter the mail server address. For
example, mymail.com.
- Sender Email Address: Enter the email address of the user
who will send the email. For example, [email protected]
- Sender User Name: Enter the user name to login the mail
server.
- 43 -
- Sender Password: Enter the password to login the mail
server.
- Receiver #1 Email Address: Enter the first email address of
the user who will receive the email.
- Receiver #2 Email Address: Enter the second email address
of the user who will receive the email.
- 44 -
4.8 Motion Detect
The Motion Detect menu contains the command and option that
allow you to enable and set up the motion detection feature of the
camera. The camera provides two detecting areas.
To enable the detecting area, select Window 1 or 2 from the pulldown list, and then select Enable. When the detecting area is
enabled, you can use the mouse to move the detecting area and
change the area coverage.
- Name: Assign a name to the detecting area.
- Threshold: Move the slide bar to adjust the level for detecting
motion to record video.
NOTE Sliding the Threshold bar to the right will decrease the
sensitivity of motion detection; sliding the Threshold bar to the
left will increase the sensitivity of motion detection
- 45 -
4.9 Event Config
The Event Config menu contains five sub-menus that provide the
commands to configure event profiles.
Event Configuration >> General Setting
- Snapshot/Recording Subfolder: You can assign a
descriptive name for the subfolder to save the captured
image/video files. Otherwise, leave this option blank to use the
default setting.
- GPIO Trigger Out Retention Time Per Event: Limit the
retention time of the GPIO Trigger Out function.
- 46 -
Event Configuration >> Arrange Schedule Profile
This sub-menu displays the scheduled profile(s). To customize the
profile, click Add and then enter a descriptive name for the profile in
the prompt dialog window. After entering the profile name, click OK
and the profile is added to the Schedule Profiles list. To delete the
profile, select the profile in the list and click Delete.
- Profile Name: Display the profile name that you select in the
Schedule Profiles list.
- Weekdays: Select the weekday(s) that you want to separately
assign in the schedule profile. The weekday that has been
assigned will be displayed with green color.
- Time List: Display the time period that you have assigned
within the selected weekday. To assign the same time period
to every weekday, click Add this to all weekdays; click
Delete this from all weekdays to remove the selected time
period from every weekday. Click Delete to remove the
selected time period.
- Start/End Time: Enter the start and end time and then click
Add to assign a time period within in the selected weekday.
- 47 -
Event Configuration >> Motion Detect Trigger
Select the Enable option to enable the motion detect trigger function
of the camera, so that you can set Trigger Out function or send
captured images within the detecting area to the FTP server or email
receiver. You have to configure corresponding settings, such as FTP
server and email server, to enable this feature.
- Schedule Profile: Select a schedule profile from the pull-down
list.
- Action: Set the Trigger Out function or select the destination
of the captured images: Send Email or FTP Upload.
- 48 -
Event Configuration >> Schedule Trigger
You can separately configure the schedule for trigger function of the
camera by Email or FTP. Select the Enable option on each item,
and then select a Schedule Profile from the pull-down list and set
the Interval time.
Email/FTP Schedule
- Schedule Profile: Select a schedule profile from the pull-down
list.
- Interval: Enter a number in this box to setup the time (in
second) to send Email or upload to FTP regularly.
- 49 -
Event Configuration >> GPIO Trigger
Select the Enable option to enable the GPIO trigger function of the
camera, so that you can set Trigger Out function or send captured
images within the detecting area to the FTP server or email receiver.
You have to configure corresponding settings, such as FTP server
and email server, to enable this feature.
- Schedule Profile: Select a schedule profile from the pull-down
list.
- Action: Set the Trigger Out function or select the destination
of the captured images: Send Email or FTP Upload.
- 50 -
4.10 Tools
The Tools menu provides the commands that allow you to restart or
reset the camera. You can also backup and restore your
configuration, and upgrade the firmware for the camera.
Factory Reset
Click Reset to restore all factory default settings for the camera.
System Reboot
Click Reboot to restart the camera just like turning the device off
and on. The camera configuration will be retained after rebooting.
Configuration
You can save your camera configuration as a backup file on your
computer. Whenever you want to resume the original settings,
you can restore them by retrieving the backup file.
- 51 -
- Backup: Click Get the backup file to save the current
configuration of the camera.
- Restore: Click Browse to locate the backup file and then click
Restore.
Update Firmware
This item displays the current firmware version. You can upgrade
the firmware for your camera once you obtained a latest version
of firmware.
- Select the firmware: Click Browse to locate the backup file
and then click Update.
NOTE Make sure to keep the camera connected to the power source
during the process of upgrading firmware. Otherwise, the
camera might be damaged because of failure of upgrading
firmware.
- 52 -
4.11 Information
The Information menu displays the current configuration and events
log of the camera.
Device Info
Display the Basic, Video & Audio, Network, and Wireless
settings of the camera.
System Log
The Logs table displays the events log recorded by the system.
- 53 -
A PPENDIX
A.1 Specification
Image Sensor
Sensor
Resolution
1/4” color CMOS
640x480
Video
Compression
Video resolution
M-JPEG
VGA/QVGA/QQVGA; 30fps max.
Audio
Input
Output
Codec
Built-in MIC
Headphone output jack (Mono)
PCM
User Interface
LAN
Antenna
Reset
GPIO
LEDs
One RJ-45 port
One external antenna
One Reset button
1 in/1 out connectors
Input: active high: 9~40V DC; dropout: 0V
DC
Output: close circuit current 70mA AC or
100mA DC maximum, 30 Ohm; open circuit
voltage 240V AC or 350V DC maximum
Power LED (amber); Link LED (green)
System Hardware
Processor
ARM9 base
RAM
32MB SDRAM
- 54 -
ROM
Power
Communication
LAN
WLAN
4MB NOR Flash
DC 12V
10/100Mbps Fast Ethernet, auto-sensed,
Auto-MDIX
IEEE 802.11b/g
Protocol support TCP/IP, UDP, ICMP, DHCP, NTP, DNS,
DDNS, SMTP, FTP, PPPoE, UPnP
Pan/Tilt
Pan
Tilt
Software
OS Support
Browser
Software
Windows 2000/XP/Vista
Internet Explorer 6.0 or above
Apple Safari 2 or above
Mozilla Firefox 2.00 or above
UltraView for playback/recording/
configuration features
Operating Environment
Temperature
- Operation: 0°C ~ 45°C
- Storage: -15°C ~ 60°C
Humidity
165 degree (left) to 165 degree (right)
90 degree (up) to 15 degree (down)
- Operation: 20% ~ 85% non-condensing
- Storage: 0% ~ 90% non-condensing
EMI
FCC Class B, CE Class B
- 55 -
A.2 GPIO Terminal Application
This is typically used in association with programming scripts for
developing applications for motion detection, event triggering, alarm
notification via e-mail, and a variety of external control functions. The
GPIO connectors are located on the rear panel of the camera, which
provide the interface of connecting the sensor device (IN) and
controlled device (OUT).
Connector Pin Assignment
PIN
SPECIFICATION
IN
Active High voltage 9~40V DC;
Dropout-out voltage 0V DC
OUT
Close circuit current 70mA AC or 100mA DC maximum,
Output resistance 30 Ohm;
Open circuit voltage 240V AC or 350V DC maximum
Interface Schematic
- 56 -
A.3 Glossary of Terms
NUMBERS
10BASE-T
100BASE-TX
10BASE-T is Ethernet over UTP Category III, IV, or V
unshielded twisted-pair media.
The two-pair twisted-media implementation of 100BASET is called 100BASE-TX.
A
ADPCM
Adaptive Differential Pulse Code Modulation, a new
technology improved from PCM, which encodes analog
sounds to digital form.
Applet
Applets are small Java programs that can be embedded
in an HTML page. The rule at the moment is that an
applet can only make an Internet connection to the
computer form that the applet was sent.
American Standard Code For Information Interchange, it
is the standard method for encoding characters as 8-bit
sequences of binary numbers, allowing a maximum of
256 characters.
ASCII
ARP
Address Resolution Protocol. ARP is a protocol that
resides at the TCP/IP Internet layer that delivers data on
the same network by translating an IP address to a
physical address.
AVI
Audio Video Interleave, it is a Windows platform audio
and video file type, a common format for small movies
and videos.
B
BOOTP
Bootstrap Protocol is an Internet protocol that can
automatically configure a network device in a diskless
workstation to give its own IP address.
C
Communication
Communication has four components: sender, receiver,
- 57 -
message, and medium. In networks, devices and
application tasks and processes communicate messages
to each other over media. They represent the sender and
receivers. The data they send is the message. The
cabling or transmission method they use is the medium.
Connection
In networking, two devices establish a connection to
communicate with each other.
D
DHCP
Developed by Microsoft, DHCP (Dynamic Host
Configuration Protocol) is a protocol for assigning
dynamic IP addresses to devices on a network. With
dynamic addressing, a device can have a different IP
address every time it connects to the network. In some
systems, the device's IP address can even change while
it is still connected. It also supports a mix of static and
dynamic IP addresses. This simplifies the task for
network administrators because the software keeps track
of IP addresses rather than requiring an administrator to
manage the task. A new computer can be added to a
network without the hassle of manually assigning it a
unique IP address. DHCP allows the specification for the
service provided by a router, gateway, or other network
device that automatically assigns an IP address to any
device that requests one.
DNS
Domain Name System is an Internet service that
translates domain names into IP addresses. Since
domain names are alphabetic, they're easier to
remember. The Internet however, is really based on IP
addresses every time you use a domain name the DNS
will translate the name into the corresponding IP
address. For example, the domain name
www.network_camera.com might translate to
192.167.222.8.
E
Enterprise
An enterprise network consists of collections of networks
connected to each other over a geographically dispersed
- 58 -
network
Ethernet
area. The enterprise network serves the needs of a
widely distributed company and operates the company’s
mission-critical applications.
The most popular LAN communication technology. There
are a variety of types of Ethernet, including 10Mbps
(traditional Ethernet), 100Mbps (Fast Ethernet), and
1,000Mbps (Gigabit Ethernet). Most Ethernet networks
use Category 5 cabling to carry information, in the form
of electrical signals, between devices. Ethernet is an
implementation of CSMA/CD that operates in a bus or
star topology.
F
Fast Ethernet
Fast Ethernet, also called 100BASE-T, operates at 10 or
100Mbps per second over UTP, STP, or fiber-optic
media.
Firewall
Firewall is considered the first line of defense in
protecting private information. For better security, data
can be encrypted. A system designed to prevent
unauthorized access to or from a private network.
Firewalls are frequently used to prevent unauthorized
Internet users from accessing private networks
connected to the Internet, especially Intranets all
messages entering or leaving the intranet pass through
the firewall, which examines each message and blocks
those that do not meet the specified security criteria.
G
Gateway
Group
A gateway links computers that use different data
formats together.
Groups consist of several user machines that have
similar characteristics such as being in the same
department.
H
HEX
Short for hexadecimal refers to the base-16 number system,
- 59 -
which consists of 16 unique symbols: the numbers 0 to 9
and the letters A to F. For example, the decimal number 15
is represented as F in the hexadecimal numbering system.
The hexadecimal system is useful because it can represent
every byte (8 bits) as two consecutive hexadecimal digits. It
is easier for humans to read hexadecimal numbers than
binary numbers.
I
Intranet
This is a private network, inside an organization or
company that uses the same software you will find on the
public Internet. The only difference is that an Intranet is
used for internal usage only.
Internet
The Internet is a globally linked system of computers that
are logically connected based on the Internet Protocol
(IP). The Internet provides different ways to access
private and public information worldwide.
Internet address To participate in Internet communications and on Internet
Protocol-based networks, a node must have an Internet
address that identifies it to the other nodes. All Internet
addresses are IP addresses.
IP
Internet Protocol is the standard that describes the layout
of the basic unit of information on the Internet (the
packet) and also details the numerical addressing format
used to route the information. Your Internet service
provider controls the IP address of any device it connects
to the Internet. The IP addresses in your network must
conform to IP addressing rules. In smaller LANs, most
people will allow the DHCP function of a router or
gateway to assign the IP addresses on internal networks.
IP address
IP address is a 32-binary digit number that identifies
each sender or receiver of information that is sent in
packets across the Internet. For example, 80.80.80.69 is
an IP address. When you “call” that number, using any
connection methods, you get connected to the computer
that “owns” that IP address.
ISP
ISP (Internet Service Provider) is a company that
maintains a network that is linked to the Internet by way
of a dedicated communication line. An ISP offers the use
- 60 -
of its dedicated communication lines to companies or
individuals who can’t afford the high monthly cost for a
direct connection.
J
JAVA
Java is a programming language that is specially
designed for writing programs that can be safely
downloaded to your computer through the Internet
without the fear of viruses. It is an object-oriented multithread programming best for creating applets and
applications for the Internet, Intranet and other complex,
distributed network.
L
LAN
Local Area Network. It is a computer network that spans
a relatively small area sharing common resources. Most
LANs are confined to a single building or group of
buildings.
M
M-JPEG
M-JPEG (Motion JPEG) composes a moving image by
storing each frame of a moving picture sequence in
JPEG compression, and then decompressing and
displaying each frame at rapid speed to show the moving
picture.
N
NAT
Network Address Translator is generally applied by a
router that makes many different IP addresses on an
internal network appear to the Internet as a single
address. For routing messages properly within your
network, each device requires a unique IP address. But
the addresses may not be valid outside your network.
NAT solves the problem. When devices within your
network request information from the Internet, the
requests are forwarded to the Internet under the router's
- 61 -
Network
NWay Protocol
IP address. NAT distributes the responses to the proper
IP addresses within your network.
A network consists of a collection of two or more devices,
people, or components that communicate with each
other over physical or virtual media. The most common
types of network are:
LAN – (local area network): Computers are in close
distance to one another. They are usually in the same
office space, room, or building.
WAN – (wide area network): The computers are in
different geographic locations and are connected by
telephone lines or radio waves.
A network protocol that can automatically negotiate the
highest possible transmission speed between two
devices.
P
PCM
PING
PPPoE
Protocol
PCM (Pulse Code Modulation) is a technique for
converting analog audio signals into digital form for
transmission.
Packet Internet Groper, a utility used to determine
whether a specific IP address is accessible. It functions
by sending a packet to the specified address and waits
for a reply. It is primarily used to troubleshoot Internet
connections.
Point-to-Point Protocol over Ethernet. PPPoE is a
specification for connecting the users on an Ethernet to
the Internet through a common broadband medium, such
as DSL or cable modem. All the users over the Ethernet
share a common connection.
Communication on the network is governed by sets of
rules called protocols. Protocols provide the guidelines
devices use to communicate with each other, and thus
they have different functions. Some protocols are
responsible for formatting and presenting data that will
be transferred from file server memory to the file server’s
network adapter. Others are responsible for filtering
- 62 -
information between networks and forwarding data to its
destination. Still other protocols dictate how data is
transferred across the medium, and how servers respond
to workstation requests and vice versa. Common
network protocols responsible for the presentation and
formatting of data for a network operating system are the
Internetwork Packet Exchange (IPX) protocol or the
Internet Protocol (IP). Protocols that dictate the format of
data for transferors the medium include token-passing
and Carrier Sense Multiple Access with Collision
Detection (CSMA/CD), implemented as token-ring,
ARCNET, FDDI, or Ethernet. The Router Information
Protocol (RIP), a part of the Transmission Control
Protocol/Internet Protocol (TCP/IP) suite, forwards
packets from one network to another using the same
network protocol.
R
RJ-45
Router
RJ-45 connector is used for Ethernet cable connections.
RTP
RTP (Real-time Transport Protocol) is a data transfer
protocol defined to deliver live media to the clients at the
same time, which defines the transmission of video and
audio files in real time for Internet applications.
RTSP (Real-time Streaming Protocol) is the standard
used to transmit stored media to the client(s) at the
same time, which provides client controls for random
access to the content stream.
RTSP
A router is the network software or hardware entity in
charge of routing packets between networks.
S
Server
SIP
It is a simple computer that provides resources, such as
files or other information.
SIP (Session Initiated Protocol) is a standard protocol
that delivers the real-time communication for Voice over
IP (VoIP), which establishes sessions for features such
as audio and video conferencing.
- 63 -
SMTP
SNMP
Station
Subnet mask
The Simple Mail Transfer Protocol is used for Internet
mail.
Simple Network Management Protocol. SNMP was
designed to provide a common foundation for managing
network devices.
In LANs, a station consists of a device that can
communicate data on the network. In FDDI, a station
includes both physical nodes and addressable logical
devices. Workstations, single-attach stations, dual-attach
stations, and concentrators are FDDI stations.
In TCP/IP, the bits used to create the subnet are called
the subnet mask.
T
(TCP/IP)
Transceiver
Transmission Control Protocol/Internet Protocol is a
widely used transport protocol that connects diverse
computers of various transmission methods. It was
developed y the Department of Defense to connect
different computer types and led to the development of
the Internet.
A transceiver joins two network segments together.
Transceivers can also be used to join a segment that
uses one medium to a segment that uses a different
medium. On a 10BASE-5 network, the transceiver
connects the network adapter or other network device to
the medium. Transceivers also can be used on 10BASE2 or 10BASE-T networks to attach devices with AUI
ports.
U
UDP
The User Datagram Protocol is a connectionless protocol
that resides above IP in the TCP/IP suite
User Name
The USERNAME is the unique name assigned to each
person who has access to the LAN.
It is a program that performs a specific task.
Utility
UTP
Unshielded twisted-pair. UTP is a form of cable used by
- 64 -
all access methods. It consists of several pairs of wires
enclosed in an unshielded sheath.
W
WAN
WEP
Windows
WPA
WPA2
Wide-Area Network. A wide-area network consists of
groups of interconnected computers that are separated
by a wide distance and communicate with each other via
common carrier telecommunication techniques.
WEP is widely used as the basic security protocol in WiFi networks, which secures data transmissions using 64bit or 128-bit encryption.
Windows is a graphical user interface for workstations
that use DOS.
WPA (Wi-Fi Protected Access) is used to improve the
security of Wi-Fi networks, replacing the current WEP
standard. It uses its own encryption, Temporal Key
Integrity Protocol (TKIP), to secure data during
transmission.
Wi-Fi Protected Access 2. The latest security
specification that provides greater data protection and
network access control for Wi-Fi networks. WPA2 uses
the government-grade AES encryption algorithm and
IEEE 802.1X-based authentication, which are required to
secure large corporate networks.
- 65 -
