Red Hat Enterprise Linux 7
Windows Integration Guide
Integrating Linux Systems with Active Directory Environments
Ella Deon Ballard
Red Hat Enterprise Linux 7 Windows Integration Guide
Integrating Linux Systems with Active Directory Environments
Ella Deo n Ballard
[email protected] m
Legal Notice
Copyright © 2014 Red Hat.
T his document is licensed by Red Hat under the Creative Commons Attribution-ShareAlike 3.0 Unported
License. If you distribute this document, or a modified version of it, you must provide attribution to Red
Hat, Inc. and provide a link to the original. If the document is modified, all Red Hat trademarks must be
removed.
Red Hat, as the licensor of this document, waives the right to enforce, and agrees not to assert, Section
4d of CC-BY-SA to the fullest extent permitted by applicable law.
Red Hat, Red Hat Enterprise Linux, the Shadowman logo, JBoss, MetaMatrix, Fedora, the Infinity Logo,
and RHCE are trademarks of Red Hat, Inc., registered in the United States and other countries.
Linux ® is the registered trademark of Linus T orvalds in the United States and other countries.
Java ® is a registered trademark of Oracle and/or its affiliates.
XFS ® is a trademark of Silicon Graphics International Corp. or its subsidiaries in the United States
and/or other countries.
MySQL ® is a registered trademark of MySQL AB in the United States, the European Union and other
countries.
Node.js ® is an official trademark of Joyent. Red Hat Software Collections is not formally related to or
endorsed by the official Joyent Node.js open source or commercial project.
T he OpenStack ® Word Mark and OpenStack Logo are either registered trademarks/service marks or
trademarks/service marks of the OpenStack Foundation, in the United States and other countries and
are used with the OpenStack Foundation's permission. We are not affiliated with, endorsed or
sponsored by the OpenStack Foundation, or the OpenStack community.
All other trademarks are the property of their respective owners.
Abstract
Identity and policy management — for both users and machines — is a core function for almost any
enterprise environment. Identity Management provides a way to create an identity domain that allows
machines to enroll to a domain and immediately access identity information required for single sign-on
and authentication services, as well as policy settings that govern authorization and access. T his
manual covers all aspects of installing, configuring, and managing Identity Management domains,
including both servers and clients. T his guide is intended for IT and systems administrators.
T able of Contents
Table of Contents
.Preface
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3. . . . . . . . .
⁠1. Information for Managing Identity and Authentication Policies in Linux
3
⁠2. Audience and Purpose
3
⁠3. Giving Feedback
3
⁠4 . Document Change History
4
. .hapter
⁠C
. . . . . . 1.
. . Ways
. . . . . .to
. . Integrate
. . . . . . . . .Active
. . . . . . Directory
. . . . . . . . .and
. . . .Linux
. . . . . Environments
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5. . . . . . . . .
⁠1.1. Defining Windows Integration
5
⁠1.2. Small Environments: Using Windows as an Identity Source
6
⁠1.3. Small Environments: Enrolling Individual Clients
6
⁠1.4. Big Environments: Synchronizing Users
7
⁠1.5. Big Environments: T rusted Realms
7
. .art
⁠P
. . .I.. Adding
. . . . . . . a. .Single
. . . . . .Linux
. . . . . System
. . . . . . . to
. . .an
. . Active
. . . . . . .Directory
. . . . . . . . Domain
. . . . . . . . . . . . . . . . . . . . . . . . . . . 9. . . . . . . . .
. .hapter
⁠C
. . . . . . 2.
. . Using
. . . . . .Active
. . . . . . Directory
. . . . . . . . .as
. . .an
. . Identity
. . . . . . . .Provider
. . . . . . . .for
. . .SSSD
. . . . . . . . . . . . . . . . . . . . . . . . 10
..........
⁠2.1. About SSSD
10
⁠2.2. Environments for SSSD
12
⁠2.3. How SSSD Integrates with an Active Directory Environment
12
⁠2.4. Configuring an Active Directory Domain with ID Mapping
16
⁠2.5. Configuring an Active Directory Domain with POSIX Attributes
19
⁠2.6. Configuring Active Directory as an LDAP Domain
23
⁠2.7. Additional Configuration Examples
26
. .hapter
⁠C
. . . . . . 3.
. . Using
. . . . . .realmd
. . . . . . to
. . .Connect
. . . . . . . .to
. . an
. . . Active
. . . . . . Directory
. . . . . . . . . Domain
. . . . . . . . . . . . . . . . . . . . . . . . . . 31
..........
⁠3.1. About realmd
31
⁠3.2. realmd Commands
31
⁠3.3. Discovering and Joining Active Directory Domains
32
⁠3.4. Managing User Logins from Active Directory
34
⁠3.5. Adding Default User Configuration
34
⁠3.6. Additional Configuration for the Active Directory Domain Entry
35
. .hapter
⁠C
. . . . . . 4. . .Using
. . . . . Samba,
. . . . . . . Kerberos,
. . . . . . . . . and
. . . . Winbind
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
..........
⁠4 .1. About Samba and Active Directory Authentication
37
⁠4 .2. Summary of Configuration Files, Options, and Packages
40
⁠4 .3. Configuring a Domain Member Using authconfig
42
. .art
⁠P
. . .II.. .Integrating
. . . . . . . . . . a. .Linux
. . . . . Domain
. . . . . . . .with
. . . .an
. . .Active
. . . . . .Directory
. . . . . . . . .Domain
. . . . . . . . . . . . . . . . . . . . . . . . .4. 8. . . . . . . . .
. .hapter
⁠C
. . . . . . 5.
. . Creating
. . . . . . . . .Cross-Realm
. . . . . . . . . . . .T. rusts
. . . . . with
. . . . Active
. . . . . . .Directory
. . . . . . . . and
. . . . Identity
. . . . . . . .Management
.....................
⁠5.1. T he Meaning of "T rust"
49 4 9
⁠5.2. Environment and Machine Requirements to Set up T rusts
59
⁠5.3. Creating T rusts
62
⁠5.4. Creating IdM Groups for Active Directory Users
84
⁠5.5. Maintaining T rusts
86
⁠5.6. Verifying T hat IdM Machines Have Resolvable Names
90
⁠5.7. Setting PAC T ypes for Services
91
⁠5.8. Using SSH from Active Directory Machines for IdM Resources
94
⁠5.9. Using T rust with Kerberized Web Applications
95
. .hapter
⁠C
. . . . . . 6.
. . Setting
. . . . . . . .up
. . Kerberos
. . . . . . . . . Cross-Realm
. . . . . . . . . . . . Authentication
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
..........
⁠6.1. A T rust Relationship
97
⁠6.2. Setting up a Realm T rust
100
. .hapter
⁠C
. . . . . . 7.
. . Synchronizing
. . . . . . . . . . . . . .Active
. . . . . .Directory
. . . . . . . . .and
. . . .Identity
. . . . . . .Management
. . . . . . . . . . . . Users
. . . . . . . . . . . . . . . .101
...........
⁠7.1. Supported Windows Platforms
101
⁠7.2. About Active Directory and Identity Management
101
⁠7.3. About Synchronized Attributes
103
1
Red Hat Enterprise Linux 7 Windows Integration Guide
⁠7.3. About Synchronized Attributes
⁠7.4. Setting up Active Directory for Synchronization
⁠7.5. Managing Synchronization Agreements
⁠7.6. Managing Password Synchronization
103
107
107
115
⁠I.ndex
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
...........
2
Preface
Preface
Many IT environments are heterogeneous. In a mixed environment, there has to be some way to join
systems to the larger domain, either directly as clients or by creating transparency between two peers
domains.
T his is especially important in environments where one domain (usually Active Directory) maanges users,
while another domain (such as a Linux domain through Identity Management) manages backend systems
or a development or production environment.
T his guide covers different default applications within Red Hat Enterprise Linux which can help a Linux
system or an entire Linux domain integrate with an Active Directory environment.
1. Information for Managing Identity and Authentication Policies in
Linux
Managing user and system identities, authentication settings, and application policies is one of the central
responsibilities of system administration. Even if users are defined within an Active Directory environment,
it is still critical that those users have the appropriate access controls and policies in place as they access
Linux-based services and resources. T hose policies are defined within the Linux environment.
T here are two related guides for Red Hat Enterprise Linux 7 which deal with different scenarios related to
identity, authentication, and policy management:
For managing identity and authentication services at the system-level, see the System-Level
Authentication Guide.
For configuring and managing a Linux domain and centralizing system policies, which uses Red Hat
Enterprise Linux Identity Management, see the Linux Domain Administration Guide.
2. Audience and Purpose
T here are a number of different paths to integrate Linux systems within a Windows environment. With the
different security and identity applications available within Red Hat Enterprise Linux, outlined both in this
guide and in the System-Level Authentication Guide and the Linux Domain Administration Guide, the
configuration options are almost limitless and depend on the needs of an individual system or
environment.
T his guide covers major applications and major integration options, which will be useful in many different
environments. T his is not a definitive or comprehensive source, and the true integration solution may be a
more complex mix of different scenarios. Use the options here as guidelines to plan how to integrate your
different environments.
T his guide is written for systems administrators and IT staff with a working knowledge of Linux systems
and applications, but the core audience is for Windows administrators who are planning integration.
3. Giving Feedback
If there is any error in this book or there is any way to improve the documentation, please let us know.
Bugs can be filed against the documentation for IdM through Bugzilla, http://bugzilla.redhat.com/bugzilla.
Make the bug report as specific as possible, so we can be more effective in correcting any issues:
1. Select the Red Hat group and the Red Hat Enterprise Linux 7 product.
3
Red Hat Enterprise Linux 7 Windows Integration Guide
2. Set the component to doc-Enterprise_Identity_Managem ent_Guide.
3. For errors, give the page number (for the PDF) or URL (for the HT ML), and give a succinct
description of the problem, such as incorrect procedure or typo.
For enhancements, put in what information needs to be added and why.
4. Give a clear title for the bug. For example, "Incorrect com m and exam ple for setup
script options" is better than "Bad exam ple".
We appreciate receiving any feedback — requests for new sections, corrections, improvements,
enhancements, even new ways of delivering the documentation or new styles of docs. You are welcome to
contact Red Hat Content Services directly at [email protected]
1. Select the Community group and the freeIPA product.
2. Set the component to Documentation.
3. Set the version number to 3.2.
4. For errors, give the page number (for the PDF) or URL (for the HT ML), and give a succinct
description of the problem, such as incorrect procedure or typo.
For enhancements, put in what information needs to be added and why.
5. Give a clear title for the bug. For example, "Incorrect com m and exam ple for setup
script options" is better than "Bad exam ple".
We appreciate receiving any feedback — requests for new sections, corrections, improvements,
enhancements, even new ways of delivering the documentation or new styles of docs. You are welcome to
contact the Fedora docs team at [email protected]
4. Document Change History
Revision 7.0-5.4 05
T hu Jul 7 2014
Add html-single and epub formats
Rüdiger Landmann
Revision 7.0-5
June 27, 2014
Improving Samba+Kerberos+Winbind chapters.
Ella Deon Ballard
Revision 7.0-4
June 13, 2014
Adding Kerberos realm chapter.
Ella Deon Ballard
Revision 7.0-3
Initial release.
Ella Deon Ballard
4
June 11, 2014
⁠C hapter 1. Ways to Integrate Active Directory and Linux Environments
Chapter 1. Ways to Integrate Active Directory and Linux
Environments
IT environments have a structure. T he systems in them are arranged with a purpose. Integrating two
separate infrastructures requires an assessment of the purpose of each of those environments and an
understanding of how and where they interact.
1.1. Defining Windows Integration
Windows integration can mean very different things, depending on the ultimate w desired interaction
between the Linux environment and the Windows environment. It could mean that individual Linux systems
are enrolled into a Windows domain, or it could mean that a Linux domain is configured to be a peer of the
Windows domain, or it could simply mean that information is copied between environments.
T here are several major potential points of contact between a Windows domain and Linux systems, and
each of these points revolve around identifying different domain objects (users, groups, systems,
services) and the services which are used in that identification.
User Identities and Authentication
Where are user accounts located, Windows only or both Linux and Windows?
How are users authenticated on a Linux system — locally or through Windows?
How is group membership configured for groups? How is that group membership determined?
Will users authenticate using a simple username/password, Kerberos tickets, certificates, or a
combination of methods?
How are user attributes managed? Specifically, for Linux-required POSIX attributes, are those attributes
set in the Windows domain, configured locally on the Linux system, or (for UID/GID numbers and
Windows SIDs) dynamically mapped?
What users will be accessing what resources? Will Windows-defined users access Linux resources?
Will Linux-defined users
In most environments, the Active Directory domain is the central hub for user information, which means that
there needs to be some way for Linux systems to access that user information for authentication requests.
T he real question then, with user identities, is how to obtain that information and how much of that
information is available to external systems. T here also needs to be a balance between information
required for Linux systems (POSIX attributes) and Linux users (e.g., some application administrators) and
how that information is managed.
Host and Service Principals
What resources will be accessed?
What authentication protocols are required?
How will Kerberos tickets be obtained? How will SSL certificates be requested or verified?
Will users need access to a single domain or to both Linux and Windows domains?
DNS Domains, Queries, and Name Resolution
Is there a single DNS domain? Are there subdomains?
How will system hostnames be resolved?
5
Red Hat Enterprise Linux 7 Windows Integration Guide
How will service discovery be configured?
Security Policies
Where are access control instructions set?
What administrators are configured for each domain?
Change Management
How frequently are systems added to the domain?
If the underlying configuration for something related to Windows integration is changed (e.g., the DNS
service is changed), how are those changes propagated?
Is configuration maintained through domain-related tools or a provisioning system?
Does the integration path require additional applications or configuration on the Windows server?
As important as what elements in the domains are integrated, is how that integration is maintained. If a
particular means of integration is heavily manual, yet the environment has a large number of systems
which are frequently updated, then that one means may not work for that environment from a maintenance
standpoint.
1.2. Small Environments: Using Windows as an Identity Source
Probably the lightest touch for Windows integration is to have the Linux system use Windows as an
identity store, but to otherwise maintain all service, security, and other configuration within the local system.
T here are two services available to configure the local system:
System Security Services Daemon (SSSD), using Active Directory as an identity provider
realm d, to configure SSSD (or, more rarely Winbind) as Active Directory as an identity provider
Both SSSD and realmd use Windows for pass-through authentication. T he user identities reside in the
Windows side, and there can be some limited configuration for groups or authorization, but most
configuration — including security policies like SELinux — remain within the ownership of the local system.
T here is also a lot of latitude in how user attributes are defined and used. For example, user IDs can be
created locally on the Linux system, mapped to Windows SIDs, or taken directly from the Windows
configuration. T his is also true for login shells, group membership, home directories, and other user
settings.
Both SSSD and realmd are local services, with local configuration files. Provisioning systems (such as
Foreman or Puppet) can be used to maintain these files to try to lower the administrative overhead of
making changes. Ultimately, though, each system has to be updated individually to change or add
integration settings. T his means that using SSSD or realmd alone are best in IT environments with a small
number of Linux systems.
1.3. Small Environments: Enrolling Individual Clients
An alternative to using Active Directory as an external identity store is to simply enroll a system within a
Windows domain.
T here are several different paths to enroll a Linux system in a Windows domain:
Winbind and Samba, to enroll a system directly in a Windows domain
6
⁠C hapter 1. Ways to Integrate Active Directory and Linux Environments
Local PAM and Kerberos configuration, to enroll a system directly in a Windows domain
As with using SSSD and realmd, using either Winbind or PAM/Kerberos configuration requires local
changes to the system. T hese can be managed through a provisioning system, but there is no central
authority defining the configuration. Additionally, it requires external servers (either a Samba server or
Kerberos KDC) within the Linux environment to integrate with the Windows environment. T he Linux
environment is more constrained, as well, with less use for or flexibility in managing user attributes.
1.4. Big Environments: Synchronizing Users
Red Hat Enterprise Linux has a Linux domain tool included by default, Identity Management. T his creates a
Linux domain and centralizes the maintenance of Linux systems policies (SELinux, password policy, sudo,
automount, host-based access controls, and others). Identity Management also creates and maintains a
central identity store, which is used by all Linux clients enrolled in the domain.
If there are a large number of configured Linux users in Identity Management (meaning, Windows is not the
only user directory), then it is possible to simply copy users between Windows and Linux directories.
Synchronization has some benefits:
T he Linux-based users exist within the Windows domain and can be configured to access Windows
resources.
T he sync configuration is relatively simple.
Windows users can be Identity Management users and administrators.
However, it also has some limitations:
It requires an additional Password Sync service to be installed on a Windows domain controller.
T here is a limited set of user attributes available for synchronization.
Groups are not synchronized in Identity Management ⁠ [1] .
One of the directories must still be the master directory or there can be conflicts in adding and
removing users and in the attributes in entries.
T here can be an overall performance hit to the IdM domain or to the IdM server with synchronization.
Synchronization is limited to a single IdM server and a single Active Directory domain.
1.5. Big Environments: Trusted Realms
Kerberos has a concept called trust where specific agreements can be put in place so that the member of
one Kerberos realm are trusted as if they belong to another Kerberos realm, and this grants transparent
access to resources.
Identity Management in Red Hat Enterprise Linux expands on a basic Kerberos v5 trust to include a mutual
configuration with a DNS domain. T his is the closest configuration to a full domain-level integration with an
Active Directory environment.
Linux systems and identities retain all of the flexibility of configuration: maintenance for the Linux domain,
including security policies, remains within the Linux domain. It is not dictated by the Windows domain (as
with Winbind/Samba) or limited as with synchronization.
7
Red Hat Enterprise Linux 7 Windows Integration Guide
T he Identity Management domain can use Windows group assignments to create its own, local security
policies, which gives administrative control to both the Windows and the Linux environments for managing
users and authorization.
Additionally, Identity Management supports multiple domains, which can be useful if there are different
Windows environments, subdomains within the Active Directory forest, or transitive trusts with between
Windows domains.
T he main drawback to using trusts with Identity Management is the complexity of the DNS configuration.
Identity Management manages its own DNS domain, either as a separate domain or as a subdomain of the
Active Directory DNS domain. If DNS is not properly configured in both Identity Management and Active
Directory, there can be problems resolving hostnames, handling queries, and even with running some
services.
[1] Sync hro niz atio n is als o availab le in Red Hat Direc to ry Server, and g ro up s are s ync hro niz ed there.
8
⁠P art I. Adding a Single Linux System to an Active Directory Domain
⁠Part I. Adding a Single Linux System to an Active
Directory Domain
9
Red Hat Enterprise Linux 7 Windows Integration Guide
Chapter 2. Using Active Directory as an Identity Provider for
SSSD
T he System Security Services Daemon (SSSD) provides access to different identity and authentication
providers. T his service ties a local system to a larger backend system. T hat can be a simple LDAP
directory, domains for Active Directory or IdM in Red Hat Enterprise Linux, or Kerberos realms.
SSSD configures a way to connect to an identity store to retrieve authentication information and then uses
that to create a local cache of users and credentials. With some types of identity providers — including
Active Directory — SSSD also pulls in group and authorization information.
2.1. About SSSD
SSSD is an intermediary between local clients and any configured data store. T his relationship brings a
number of benefits for administrators:
Reducing the load on identification/authentication servers. Rather than having every client service
attempt to contact the identification server directly, all of the local clients can contact SSSD which can
connect to the identification server or check its cache.
Permitting offline authentication. SSSD can optionally keep a cache of user identities and credentials
that it retrieves from remote services. T his allows users to authenticate to resources successfully,
even if the remote identification server is offline or the local machine is offline.
Using a single user account. Remote users frequently have two (or even more) user accounts, such as
one for their local system and one for the organizational system. T his is necessary to connect to a
virtual private network (VPN). Because SSSD supports caching and offline authentication, remote users
can connect to network resources simply by authenticating to their local machine and then SSSD
maintains their network credentials.
SSSD caches those users and credentials, so if the local system or the identity provider go offline, the
user credentials are still available to services to verify.
2.1.1. SSSD Configuration
SSSD is a local service which connects a system to a larger, external identity service. T his is done by
configuring domains in the SSSD configuration file. Each domain represents a different, external data
source. Domains always represent an identity provider which supplies user information and, optionally,
define other providers for different kinds of operations, such as authentication or password changes. (T he
identity provider can also be used for all operations, if all operations are performed within a single domain
or server.)
NOTE
SSSD allows all user identities to be created and maintained in a separate, external identity source.
For Windows integration, then the Active Directory domain can be used to manage user accounts
(as it is with most environments). Local system users do not need to be created or synced with
user accounts in Active Directory — SSSD uses those Windows identities and lets those Windows
users access the local system and local services.
SSSD also defines which services on the system use SSSD for credentials caching and user accounts.
T hese relate to foundational security services such as the Name Switch Service (NSS) and pluggable
authentication modules (PAM), which are then used by higher-level applications.
10
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
Example 2.1. Simple sssd.conf File
[sssd]
domains = LOCAL
services = nss
config_file_version = 2
[nss]
filter_groups = root
filter_users = root
[domain/WINDOWS]
id_provider = ad
auth_provider = ad
access_provider = ad
2.1.2. Active Directory Domain Configuration
T he most basic type of domain is an LDAP domain. Any LDAPv3 directory server can be configured as an
LDAP identity provider for an SSSD domain. Some specialty LDAP services have additional, specific
configuration, which can either simplify service-specific configuration or supply service-specific
functionality. One of those identity provider types is for Active Directory.
As shown in Example 2.1, “Simple sssd.conf File”, the SSSD configuration file has three major sections: the
first configures the SSSD service ([sssd]), the second configures system services which will use SSSD
as an identity cache (such as [nss] and [pam ]), and the third section configures the identity domains
([dom ain/NAME]).
By default, only an identity provider really needs to be configured — the identity provider is used for the
authentication, access (authorization), and password providers if no other types or servers are identified.
Active Directory can be configured as any kind of provider using the ad option.
[domain/ADEXAMPLE]
id_provider = ad
auth_provider = ad
access_provider = ad
chpass_provider = ad
ad_server = dc1.example.com
ad_hostname = client.example.com
ad_domain = example.com
T he connection information is required to identify what Active Directory server to use.
Past that basic configuration, the Active Directory identity provider can be configured specifically for the
Active Directory environment and specific features, such as how to use POSIX attributes or mapping for
Windows SIDs on the local system, failover servers, and account information such as home directories.
All of the LDAP domain parameters are available to the Active Directory provider, as well as Active
Directory-specific configuration parameters. T he complete lists are available in the sssd-ldap and sssd-ad
man pages.
T here are a number of options in the generic LDAP provider configuration which can be used to configure
an Active Directory provider. Using the ad value is a short-cut which automatically pulls in the parameters
and values to configure a given provider for Active Directory.
For example, the shortcut for an access provider is:
11
Red Hat Enterprise Linux 7 Windows Integration Guide
access_provider = ad
Using generic LDAP parameters, that configuration expands to:
access_provider = ldap
ldap_access_order = expire
ldap_account_expire_policy = ad
T hose settings are all set implicitly by using the ad provider type.
2.2. Environments for SSSD
A number of Linux system services can leverage SSSD for caching user identities and configuring backend
identity stores. Additionally, applications can be written or configured to use SSSD or services (like NSS or
PAM) managed by SSSD for identities. T his means that SSSD is ideal for identity integration for
environments using NSS, PAM, automount, SSH, and sudo or for applications which require access to an
externally-managed identity store.
SSSD replaces older identity management services which were used for Windows integration, including
NIS and Winbind.
SSSD is a local system service, so configuring it manually is only feasible for environments with a small
number of systems.
T here are some tools which can do the initial configuration for the SSSD Active Directory domain. realm d
edits all of the underlying configuration files automatically, but this is still a system-level tool. It simplifies
editing the configuration, but must be run separately on each system. T he ipa-client-install tool
also configures SSSD appropriately and an IdM server can configure a client to work with an Active
Directory-IdM trust, but that requires a configured and functioning IdM Linux domain and an alreadyconfigured trust environment.
2.3. How SSSD Integrates with an Active Directory Environment
2.3.1. About Active Directory Identities on the Local System
Active Directory can replicate user entries and attributes from its local directory into a global catalog, which
makes the information available to other domains within the forest. SSSD checks this global catalog for
information about users and groups, so information is not limited to a single Active Directory domain or
subdomain — SSSD, too, has access to all user data for all domains within the topology.
SSSD, then, can be used by applications which need to query the Active Directory global catalog for user
or group information.
T here are inherent structural differences between how Windows and Linux handle system users and in
the user schemas used in Active Directory and standard LDAPv3 directory services. When using an Active
Directory identity provider with SSSD to manage system users, it is necessary to reconcile the Active
Directory-style user to the new SSSD user. T here are two ways to do this:
Using ID mapping on SSSD to create a map between Active Directory security IDs (SIDs) and the
generated UIDs on Linux.
ID mapping is the simplest option for most environments because it requires no additional packages or
configuration on Active Directory.
12
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
Using Services for Unix to insert POSIX attributes on Windows user and group entries, and then having
those attributes pulled into PAM/NSS.
T his requires more configuration and information within the Active Directory environment, but it gives
more administrative control over the specific UID/GID values (and other POSIX attributes).
2.3.1.1. About Security ID Mapping
2.3.1.1.1. T he Mechanism of ID Mapping
Linux/Unix systems use a local user ID number and group ID number to identify users on the system.
T hese UID:GID numbers are a simple integer, such as 501:501. T hese numbers are simple because they
are always created and administered locally, even for systems which are part of a larger Linux/Unix
domain.
Microsoft Windows and Active Directory use a different user ID structure to identify users, groups, and
machines. Each ID is constructed of different segments that identify the security version, the issuing
authority type, the machine, and the identity itself. For example:
S-1-5-21-3623811015-3361044348-30300820-1013
T he third through sixth blocks are the machine identifier:
S-1-5-21-3623811015-3361044348-30300820-1013
T he last block is the relative identifier (RID) which identifies the specific entity:
S-1-5-21-3623811015-3361044348-30300820-1013
A range of possible ID numbers are always assigned to SSSD. (T his is a local range, so it is the same for
every machine.)
|_____________________________|
|
|
minimum ID
max ID
T his range is divided into 10,000 sections (by default), with each section allocated 200,000 IDs.
| slice 1 | slice 2 |
...
|
|_________|_________|_________|
|
|
|
|
minimum ID
max ID
When a new Active Directory domain is detected, the SID is hashed. T hen, SSSD takes the modulus of the
hash and the number of available sections to determine which ID section to assign to the Active Directory
domain. T his is a reliably consistent means of assigning ID sections, so the same ID range is assigned to
the same Active Directory domain on most client machines.
| Active | Active |
|
|Directory|Directory|
|
|domain 1 |domain 2 |
...
|
|
|
|
|
| slice 1 | slice 2 |
...
|
|_________|_________|_________|
|
|
|
|
minimum ID
max ID
13
Red Hat Enterprise Linux 7 Windows Integration Guide
Note
While the method of assigning ID sections is consistent, ID mapping is based on the order that
an Active Directory domain is encountered on a client machine — so it may not result in
consistent ID range assignments on all Linux client machines. If consistency is required, then
consider disabling ID mapping and using explicit POSIX attributes.
2.3.1.1.2. ID Mapping Parameters
ID mapping is enabled in two parameters, one to enable the mapping and one to load the appropriate
Active Directory user schema:
ldap_id_mapping = True
ldap_schema = ad
Note
When ID mapping is enabled, the uidNumber and gidNumber attributes are ignored. T his prevents
any manually-assigned values. If any values must be manually assigned, then all values must be
manually assigned, and ID mapping should be disabled.
2.3.1.1.3. Mapping Users
When an Active Directory user attempts to log into a local system service for the first time, an entry for that
user is created in the SSSD cache. T he remote user is set up much like a system user:
A system UID is created for the user based on his SID and the ID range for that domain.
A GID is created for the user, which is identical to the UID.
A private group is created for the user.
A home directory is created, based on the home directory format in the sssd.conf file.
A shell is created, according to the system defaults or the setting in the sssd.conf file.
If the user belongs to any groups in the Active Directory domain, then, using the SID, SSSD adds the
user to those groups on the Linux system.
2.3.1.2. About SSSD and POSIX Attributes
Active Directory can be configured to create and store POSIX attributes such as uidNumber, gidNumber,
unixHomeDirectory, and loginShell. As with all user attributes, these are originally stored in the local
domain, but they can be replicated to the global catalog — and once they are in the global catalog, they are
available to SSSD and any application which uses SSSD for its identity information.
IMPORTANT
When SSSD uses the POSIX attributes directly, they must be published to the Active Directory
global catalog. SSSD queries the global catalog for user information.
When POSIX attributes are already defined in Active Directory, then it is not acceptable to use the SID/UID
14
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
mapping as described in Section 2.3.1.1, “About Security ID Mapping”. T he UID and GID numbers are
already defined, and mapping creates new, different numbers. T he best solution in that situation is to use
the UID and GID numbers as defined in Active Directory and then apply that to the local Linux accounts
managed by SSSD.
T o use existing POSIX attributes, two things must be configured:
T he POSIX attributes must be published to Active Directory's global catalog.
ID mapping (ldap_id_m apping in the Active Directory domain entry) must be disabled in SSSD.
ldap_id_mapping = False
2.3.1.3. Active Directory Users and Range Retrieval Searches
Microsoft Active Directory has an attribute, MaxValRange, which sets a limit on how many values for a
multi-valued attribute will be returned. T his is the range retrieval search extension. Essentially, this runs
multiple mini-searches, each returning a subset of the results within a given range, until all matches are
returned.
For example, when doing a search for the member attribute, each entry could have multiple values, and
there can be multiple entries with that attribute. If there are 2000 matching results (or more), then
MaxValRange limits how many are displayed at once; this is the value range. T he given attribute then has
an additional flag set, showing which range in the set the result is in:
attribute:range=low-high:value
For example, results 100 to 500 in a search:
member;range=99-499: cn=John Smith...
T his is described in the Microsoft documentation at http://msdn.microsoft.com/en-us/library/cc223242.aspx.
SSSD supports range retrievals with Active Directory providers as part of user and group management,
without any additional configuration.
However, some LDAP provider attributes which are available to configure searches — such as
ldap_user_search_base — are not performant with range retrievals. Be cautious when configuring
search bases in the Active Directory provider domain and consider what searches may trigger a range
retrieval.
2.3.2. Linux Clients and Active Directory DNS Sites
SSSD connects a local Linux system to a larger Active Directory environment. T his requires that SSSD
have an awareness of possible configurations within the Active Directory forest and work with them so that
the Linux client is cleanly integrated.
Active Directory forests can be very large, with numerous different domain controllers, domains and
subdomains, and physical sites. T o increase client performance, Active Directory uses a special kind of
DNS record to identify domain controllers within the same domain but at different physical locations. Clients
connect to the closest domain controller.
15
Red Hat Enterprise Linux 7 Windows Integration Guide
NOTE
Microsoft has a tech brief at http://technet.microsoft.com/eses/library/cc759550%28v=ws.10%29.aspx which describes how DNS and Active Directory work
together.
Active Directory extends normal DNS SRV records to identify a specific physical location or site for its
domain controllers. Clients (such as SSSD) can determine which domain controllers to use based on their
own site configuration.
SSSD can determine which domain controller to use by querying the Active Directory domain first for its
site configuration, and then for the domain controller DNS records.
1. SSSD attempts to connect to the Active Directory domain and looks up any available domain
controller through normal DNS discovery.
2. It retrieves a list of primary and fallback servers.
3. SSSD sends a special CLDAP ping to any domain controller. T he ping is really an LDAP search
which looks for the DNS domain, domain SID, and version:
(&(&(DnsDomain=ad.domain)(DomainSid=S-1-5-21-1111-2222-3333))
(NtVer=0x01000016))
T his is used to retrieve the information about the client's site (if one is configured).
4. If a site is configured for the client, then the reply contains extended DNS SRV records for the
primary server, containing the site name (site-name._sites.):
_service._protocol.site-name._sites.domain.name
T he backup server record is also sent, as a standard SRV record:
_service._protocol.domain.name
If no site is configured, then a standard SRV record is sent for all primary and backup servers.
2.4. Configuring an Active Directory Domain with ID Mapping
When configuring an Active Directory domain, the simplest configuration is to use the ad value for all
providers (identity, access, password). Also, load the native Active Directory schema for user and group
entries, rather than using the default RFC 2307.
Other configuration is available in the general LDAP provider configuration (sssd-ldap) and Active
Directory-specific configuration (sssd-ad). T his includes setting LDAP filters for a specific user or group
subtree, filters for authentication, and values for some account settings. Some additional configuration is
covered in Section 2.7, “Additional Configuration Examples”.
1. Make sure that both the Active Directory and Linux systems have a properly configured environment.
Name resolution must be properly configured, particularly if service discovery is used with SSSD.
T he clocks on both systems must be in sync for Kerberos to work properly.
16
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
2. Set up the Linux system as an Active Directory client and enroll it within the Active Directory domain.
T his is done by configuring the Kerberos and Samba services on the Linux system.
a. Set up Kerberos to use the Active Directory Kerberos realm.
a. Open the Kerberos client configuration file.
[[email protected] ~]# vim /etc/krb5.conf
b. Configure the [logging] and [libdefaults] sections so that they connect to the
Active Directory realm.
[logging]
default = FILE:/var/log/krb5libs.log
[libdefaults]
default_realm = EXAMPLE.COM
dns_lookup_realm = true
dns_lookup_kdc = true
ticket_lifetime = 24h
renew_lifetime = 7d
rdns = false
forwardable = yes
If autodiscovery is not used with SSSD, then also configure the [realm s] and
[dom ain_realm ] sections to explicitly define the Active Directory server.
b. Configure the Samba server to connect to the Active directory server.
a. Open the Samba configuration file.
[[email protected] ~]# vim /etc/samba/smb.conf
b. Set the Active Directory domain information in the [global] section.
[global]
workgroup = EXAMPLE
client signing = yes
client use spnego = yes
kerberos method = secrets and keytab
log file = /var/log/samba/%m.log
password server = AD.EXAMPLE.COM
realm = EXAMPLE.COM
security = ads
c. Add the Linux machine to the Active Directory domain.
a. Obtain Kerberos credentials for a Windows administrative user.
[[email protected] ~]# kinit Administrator
b. Add the machine to the domain using the net command.
[[email protected] ~]# net ads join -k
Joined 'server' to dns domain 'example.com'
T his creates a new keytab file, /etc/krb5.keytab.
17
Red Hat Enterprise Linux 7 Windows Integration Guide
List the keys for the system and check that the host principal is there.
[[email protected] ~]# klist -k
3. If necessary, install the oddjob-m khom edir package to allow SSSD to create home directories for
Active Directory users.
[[email protected] ~]# yum install oddjob-mkhomedir
4. Use authconfig to enable SSSD for system authentication. Use the --enablem khom edir to
enable SSSD to create home directories.
[[email protected] ~]# authconfig --update --enablesssd --enablesssdauth -enablemkhomedir
5. Open the SSSD configuration file.
[[email protected] ~]# vim /etc/sssd/sssd.conf
6. Configure the Active Directory domain.
a. In the [sssd] section, add the Active Directory domain to the list of active domains. T his is
the name of the domain entry that is set in [domain/NAME] in the SSSD configuration file.
Also, add pac to the list of services; this enables SSSD to set and use MS-PAC information
on tickets used to communicate with the Active Directory domain.
[sssd]
config_file_version = 2
domains = ad.example.com
services = nss, pam, pac
b. Create a new domain section at the bottom of the file for the Active Directory domain. T his
section has the format domain/NAME, such as dom ain/ad.exam ple.com . For each
provider, set the value to ad, and give the connection information for the specific Active
Directory instance to connect to.
[domain/ad.example.com]
id_provider = ad
ad_server = ipaserver.example.com
ad_hostname = ipa1.example.com
auth_provider = ad
chpass_provider = ad
access_provider = ad
c. Make sure that the Active Directory schema is enabled (this is recommended for all
deployments and required when using ID mapping), and enable ID mapping.
# defines user/group schema type
ldap_schema = ad
# enabling ID mapping
ldap_id_mapping = True
d. Enable credentials caching; this allows users to log into the local system using cached
information, even if the Active Directory domain is unavailable.
18
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
cache_credentials = true
e. Configure access controls.
ldap_access_order = expire
ldap_account_expire_policy = ad
ldap_force_upper_case_realm = true
7. Restart the SSH service to load the new PAM configuration.
[[email protected] ~]# systemctl restart sshd.service
8. Restart SSSD after changing the configuration file.
[[email protected] ~]# systemctl restart sssd.service
2.5. Configuring an Active Directory Domain with POSIX Attributes
T o use Active Directory-defined POSIX attributes in SSSD, those attributes must be replicated to the global
catalog. T hat requires additional configuration on the Active Directory domain. Additionally, ID mapping
must be disabled in SSSD, so the POSIX attributes are used from Active Directory rather than creating
new settings locally.
Other configuration is available in the general LDAP provider configuration (sssd-ldap) and Active
Directory-specific configuration (sssd-ad). T his includes setting LDAP filters for a specific user or group
subtree, filters for authentication, and values for some account settings. Some additional configuration is
covered in Section 2.7, “Additional Configuration Examples”.
1. Make sure that both the Active Directory and Linux systems have a properly configured environment.
Name resolution must be properly configured, particularly if service discovery is used with SSSD.
T he clocks on both systems must be in sync for Kerberos to work properly.
2. In the Active Directory domain, set the POSIX attributes to be replicated to the global catalog.
a. Install Identity Management for UNIX Components on all primary and child domain controllers.
Full details are available in the Microsoft documentation at http://technet.microsoft.com/enus/library/cc731178.aspx.
T his allows the POSIX attributes and related schema to be available to user accounts. T hese
attributes are available in the UNIX Attributes tab in the entry's Properties menu.
b. Install the Active Directory Schema Snap-in to add attributes to be replicated to the global
catalog. T his is described in the Microsoft documentation at http://technet.microsoft.com/enus/library/cc755885%28v=ws.10%29.aspx.
c. T he full details for replicating schema are in the Microsoft documentation at
http://support.microsoft.com/kb/248717.
For the relevant POSIX attributes (uidNumber, gidNumber, unixHomeDirectory, and
loginShell), open the Properties menu, select the Replicate this attribute to
the Global Catalog checkbox, and then click OK.
3. On the Linux client, add the Active Directory domain to the client's DNS configuration so that it can
resolve the domain's SRV records.
19
Red Hat Enterprise Linux 7 Windows Integration Guide
search ipaserver.example.com adserver.example.com
nameserver 198.68.72.1
4. Set up the Linux system as an Active Directory client and enroll it within the Active Directory domain.
T his is done by configuring the Kerberos and Samba services on the Linux system.
a. Set up Kerberos to use the Active Directory Kerberos realm.
a. Open the Kerberos client configuration file.
[[email protected] ~]# vim /etc/krb5.conf
b. Configure the [logging] and [libdefaults] sections so that they connect to the
Active Directory realm.
[logging]
default = FILE:/var/log/krb5libs.log
[libdefaults]
default_realm = EXAMPLE.COM
dns_lookup_realm = true
dns_lookup_kdc = true
ticket_lifetime = 24h
renew_lifetime = 7d
rdns = false
forwardable = yes
If autodiscovery is not used with SSSD, then also configure the [realm s] and
[dom ain_realm ] sections to explicitly define the Active Directory server.
b. Configure the Samba server to connect to the Active directory server.
a. Open the Samba configuration file.
[[email protected] ~]# vim /etc/samba/smb.conf
b. Set the Active Directory domain information in the [global] section.
[global]
workgroup = EXAMPLE
client signing = yes
client use spnego = yes
kerberos method = secrets and keytab
log file = /var/log/samba/%m.log
password server = AD.EXAMPLE.COM
realm = EXAMPLE.COM
security = ads
c. Add the Linux machine to the Active Directory domain.
a. Obtain Kerberos credentials for a Windows administrative user.
[[email protected] ~]# kinit Administrator
b. Add the machine to the domain using the net command.
20
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
[[email protected] ~]# net ads join -k
Joined 'server' to dns domain 'example.com'
T his creates a new keytab file, /etc/krb5.keytab.
c. List the keys for the system and check that the host principal is there.
[[email protected] ~]# klist -ke
d. T est that users can search the global catalog, using an ldapsearch.
[[email protected] ~]# ldapsearch -H ldap://server.ad.example.com:3268 -Y
GSSAPI -N -b "dc=ad,dc=example,dc=com" "(&(objectClass=user)
(sAMAccountName=aduser))"
5. Install the sssd-ad package.
[[email protected] ~]# yum install sssd-ad
6. Start the SSSD service.
[[email protected] ~]# systemctl start sssd.service
7. Open the SSSD configuration file.
[[email protected] ~]# vim /etc/sssd/sssd.conf
8. Configure the Active Directory domain.
a. In the [sssd] section, add the Active Directory domain to the list of active domains. T his is
the name of the domain entry that is set in [domain/NAME] in the SSSD configuration file.
Also, add pac to the list of services; this enables SSSD to set and use MS-PAC information
on tickets used to communicate with the Active Directory domain.
[sssd]
config_file_version = 2
domains = ad.example.com
services = nss, pam, pac
b. Create a new domain section at the bottom of the file for the Active Directory domain. T his
section has the format domain/NAME, such as dom ain/ad.exam ple.com . For each
provider, set the value to ad, and give the connection information for the specific Active
Directory instance to connect to.
[domain/ad.example.com]
id_provider = ad
ad_server = ipaserver.example.com
ad_hostname = ipa1.example.com
auth_provider = ad
chpass_provider = ad
access_provider = ad
c. Enable the Active Directory schema. T his is recommended for all deployments.
21
Red Hat Enterprise Linux 7 Windows Integration Guide
# defines user/group schema type
ldap_schema = ad
d. Disable ID mapping. T his tells SSSD to search the global catalog for POSIX attributes, rather
than creating UID:GID numbers based on the Windows SID.
# disabling ID mapping
ldap_id_mapping = False
e. If home directory and a login shell are set in the user accounts, then comment out these lines
to configure SSSD to use the POSIX attributes rather then creating the attributes based on
the template.
# Comment out if the users have the shell and home dir set on the AD side
#default_shell = /bin/bash
#fallback_homedir = /home/%d/%u
f. Microsoft Active Directory allows each account to have two Kerberos principals. If the host
principal for the domain (such as [email protected]) is not
available, then uncomment the ldap_sasl_authid line and set the host principal to use.
# Uncomment and adjust if the default principal [email protected] is not
available
# ldap_sasl_authid = host/[email protected]
g. Set whether to use short names or fully-qualified user names for Active Directory users. In
complex topologies, using fully-qualified names may be necessary for disambiguation.
# Comment out if you prefer to user shortnames.
use_fully_qualified_names = True
h. Enable credentials caching; this allows users to log into the local system using cached
information, even if the Active Directory domain is unavailable.
cache_credentials = true
i. Configure access controls.
ldap_access_order = expire
ldap_account_expire_policy = ad
ldap_force_upper_case_realm = true
9. Set the file permissions and owner for the SSSD configuration file.
[[email protected] ~]# chown root:root /etc/sssd/sssd.conf
[[email protected] ~]# chmod 0600 /etc/sssd/sssd.conf
[[email protected] ~]# restorecon /etc/sssd/sssd.conf
10. If necessary, install the oddjob-m khom edir package to allow SSSD to create home directories for
Active Directory users.
[[email protected] ~]# yum install oddjob-mkhomedir
11. Use authconfig to enable SSSD for system authentication. Use the --enablem khom edir to
enable SSSD to create home directories.
22
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
[[email protected] ~]# authconfig --update --enablesssd --enablesssdauth -enablemkhomedir
12. Restart the SSH service to load the new PAM configuration.
[[email protected] ~]# systemctl restart sshd.service
13. Restart SSSD after changing the configuration file.
[[email protected] ~]# systemctl restart sssd.service
Using authconfig automatically configured the NSS and PAM configuration files to use SSSD as their
identity source.
For example, the nsswitch.conf file has SSSD (sss) added as a source for user, group, and service
information.
passwd:
shadow:
group:
...
services:
...
netgroup:
files sss
files sss
files sss
files sss
files sss
T he different pam .d files add a line for the pam _sass.so module beneath every pam _unix.so line in
the /etc/pam .d/system -auth and /etc/pam .d/password-auth files.
auth
...
account
...
password
...
session
session
sufficient
pam_sss.so use_first_pass
[default=bad success=ok user_unknown=ignore] pam_sss.so
sufficient
pam_sss.so use_authtok
optional
optional
pam_mkhomedir.so
pam_sss.so
2.6. Configuring Active Directory as an LDAP Domain
While Active Directory can be configured as a type-specific identity provider, it can also be configured as a
pure LDAP identity provider with a Kerberos authentication provider.
1. It is recommended that SSSD connect to the Active Directory server using SASL, which means that
the local host must have a service keytab for the Windows domain on the Linux host.
T his keytab can be created using Samba.
a. Configure the /etc/krb5.conf file to use the Active Directory realm.
[logging]
default = FILE:/var/log/krb5libs.log
[libdefaults]
default_realm = AD.EXAMPLE.COM
dns_lookup_realm = true
dns_lookup_kdc = true
23
Red Hat Enterprise Linux 7 Windows Integration Guide
ticket_lifetime = 24h
renew_lifetime = 7d
rdns = false
forwardable = yes
[realms]
# Define only if DNS lookups are not working
# AD.EXAMPLE.COM = {
# kdc = server.ad.example.com
# admin_server = server.ad.example.com
# }
[domain_realm]
# Define only if DNS lookups are not working
# .ad.example.com = AD.EXAMPLE.COM
# ad.example.com = AD.EXAMPLE.COM
b. Set the Samba configuration file, /etc/sam ba/sm b.conf, to point to the Windows Kerberos
realm.
[global]
workgroup = EXAMPLE
client signing = yes
client use spnego = yes
kerberos method = secrets and keytab
log file = /var/log/samba/%m.log
password server = AD.EXAMPLE.COM
realm = EXAMPLE.COM
security = ads
c. T hen, run the net ads command to log in as an administrator principal. T his administrator
account must have sufficient rights to add a machine to the Windows domain, but it does not
require domain administrator privileges.
[[email protected] ~]# net ads join -U Administrator
d. Run net ads again to add the host machine to the domain. T his can be done with the host
principal (host/FQDN) or, optionally, with the NFS service (nfs/FQDN).
[[email protected] ~]# net ads join createupn="host/[email protected]" -U Administrator
2. Make sure that the Services for Unix package is installed on the Windows server.
3. Set up the Windows domain which will be used with SSSD.
a. On the Windows machine, open Server Manager.
b. Create the Active Directory Domain Services role.
c. Create a new domain, such as ad.exam ple.com .
d. Add the Identity Management for UNIX service to the Active Directory Domain Services role.
Use the Unix NIS domain as the domain name in the configuration.
4. On the Active Directory server, create a group for the Linux users.
a. Open Adm inistrative T ools and select Active Directory Users and
Com puters.
24
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
b. Select the Active Directory domain, ad.exam ple.com .
c. In the Users tab, right-click and select Create a New Group.
d. Name the new group unixusers, and save.
e. Double-click the unixusers group entry, and open the Users tab.
f. Open the Unix Attributes tab.
g. Set the NIS domain to the NIS domain that was configured for ad.exam ple.com and,
optionally, set a group ID (GID) number.
5. Configure a user to be part of the Unix group.
a. Open Adm inistrative T ools and select Active Directory Users and
Com puters.
b. Select the Active Directory domain, ad.exam ple.com .
c. In the Users tab, right-click and select Create a New User.
d. Name the new user aduser, and make sure that the User m ust change password at
next logon and Lock account checkboxes are not selected.
T hen save the user.
e. Double-click the aduser user entry, and open the Unix Attributes tab. Make sure that
the Unix configuration matches that of the Active Directory domain and the unixgroup group:
T he NIS domain, as created for the Active Directory domain
T he UID
T he login shell, to /bin/bash
T he home directory, to /hom e/aduser
T he primary group name, to unixusers
TIP
Password lookups on large directories can take several seconds per request. T he initial user
lookup is a call to the LDAP server. Unindexed searches are much more resource-intensive,
and therefore take longer, than indexed searches because the server checks every entry in
the directory for a match. T o speed up user lookups, index the attributes that are searched
for by SSSD:
uid
uidNumber
gidNumber
gecos
6. On the Linux system, configure the SSSD domain.
[[email protected] ~]# vim /etc/sssd/sssd.conf
25
Red Hat Enterprise Linux 7 Windows Integration Guide
For a complete list of LDAP provider parameters, see the sssd-ldap(5) man pages.
Example 2.2. An Active Directory 2008 R2 Domain with Services for Unix
[sssd]
config_file_version = 2
domains = ad.example.com
services = nss, pam
...
[domain/ad.example.com]
cache_credentials = true
# for performance
ldap_referrals = false
id_provider = ldap
auth_provider = krb5
chpass_provider = krb5
access_provider = ldap
ldap_schema = rfc2307bis
ldap_sasl_mech = GSSAPI
ldap_sasl_authid = host/[email protected]
#provide the schema for services for unix
ldap_schema = rfc2307bis
ldap_user_search_base = ou=user accounts,dc=ad,dc=example,dc=com
ldap_user_object_class = user
ldap_user_home_directory = unixHomeDirectory
ldap_user_principal = userPrincipalName
# optional - set schema mapping
# parameters are listed in sssd-ldap
ldap_user_object_class = user
ldap_user_name = sAMAccountName
ldap_group_search_base = ou=groups,dc=ad,dc=example,dc=com
ldap_group_object_class = group
ldap_access_order = expire
ldap_account_expire_policy = ad
ldap_force_upper_case_realm = true
ldap_disable_referrals = true
krb5_realm = AD-REALM.EXAMPLE.COM
# required
krb5_canonicalize = false
7. Restart SSSD.
[[email protected] ~]# systemctl restart sssd.service
2.7. Additional Configuration Examples
26
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
2.7.1. Account Settings
With Linux users, certain system preferences are set by default for new users. For example, the
pam _oddjob_m khom edir.so library automatically creates home directories in a defined location.
T hese system preferences either may not be set in the Windows user accounts or may be set to
something incompatible with a Linux system. T here are two such areas:
T he user home directory
A default user shell
2.7.1.1. Setting a User Home Directory
Red Hat Enterprise Linux has a PAM library (pam _oddjob_m khom edir.so) which automatically creates
user directories when a user first logs in. T his includes Active Directory users, when they first log into a
Linux system.
With SSSD, the format of the user directory is retrieved from the identity provider. If the identity provider
has a home directory format that is different than the format for the Linux system or if it does not supply a
value, then SSSD can be configured to create a home directory using a template specified in its
configuration. T he template can be set globally in the NSS service section or per domain.
T here are two possible parameters:
fallback_hom edir, which supplies a template if the identity provider does not supply one
override_hom edir, which sets a template to use regardless of what information is set in the
identity provider
Both can use variables within the template, such a %u for the login name and %d for the domain name.
[nss]
fallback_homedir = /home/%u
...
[domain/ADEXAMPLE]
id_provider = ad
ad_server = ipaserver.example.com
ad_hostname = ipa1.example.com
auth_provider = ad
...
override_homedir = /home/%d/%u
2.7.1.2. Setting a User Shell
By default, SSSD attempts to retrieve information about user shells from the identity provider. In both Active
Directory and LDAPv3 schema, this is defined in the loginShell attribute. However, this is an optional
attribute, so it may not be defined for every user. For Active Directory users, the defined login shell may not
be allowed on the Linux system.
T here are a number of ways to handle shells in the SSSD configuration:
Setting a fallback value if no shells are supplied (shell_fallback)
Setting lists of allowed or blacklisted shells (allowed_shells and vetoed_shells)
Setting a default value (default_shell)
27
Red Hat Enterprise Linux 7 Windows Integration Guide
Setting a value to use, even if another value is given in the identity provider (override_shell)
NOTE
allowed_shells, vetoed_shells, and shell_fallback can only be set as global settings,
not per domain. However, these parameters do not affect local system users, only external users
retrieved through SSSD identity providers. Using a general setting, such as /bin/rbash, is good
for most external users.
Default values can be set per domain, while some values (such as the white and blacklists for shells) must
be set globally, in the NSS service configuration. For example:
[nss]
shell_fallback = /bin/sh
allowed_shells = /bin/sh,/bin/rbash,/bin/bash
vetoed_shells = /bin/ksh
...
[domain/ADEXAMPLE]
id_provider = ad
ad_server = ipaserver.example.com
ad_hostname = ipa1.example.com
auth_provider = ad
...
default_shell = /bin/rbash
2.7.2. Enabling Dynamic DNS Updates (Active Directory Only)
Active Directory allows its clients to refresh their DNS records automatically. Active Directory also actively
maintains DNS records to make sure they are updated, including timing out (aging) and removing
(scavenging) inactive records.
SSSD allows the Linux system to imitate a Windows client by refreshing its DNS record, which also
prevents its record from being marked inactive and removed from the DNS record. When dynamic DNS
updates are enabled, then the client's DNS record is refreshed at several times:
When the identity provider comes online (always)
When the Linux system reboots (always)
At a specified interval (optional configuration)
TIP
T his can be set to the same interval as the DHCP lease, which means that the Linux client is
renewed after the lease is renewed.
DNS updates are sent to the Active Directory server using Kerberos/GSSAPI for DNS (GSS-T SIG); this
means that only secure connections need to be enabled.
T he dynamic DNS configuration is set for each domain. For example:
28
⁠C hapter 2. Using Active Directory as an Identity Provider for SSSD
[domain/ad.example.com]
id_provider = ad
ad_server = ipaserver.example.com
ad_hostname = ipa1.example.com
auth_provider = ad
chpass_provider = ad
access_provider = ad
ldap_schema = ad
dyndns_update = true
dyndns_refresh_interval = 43200
dyndns_update_ptr = true
dyndns_ttl = 3600
T able 2.1. Options for Dynamic DNS Updates
Option
Description
Format
dyndns_update
Sets whether to update the DNS
server dynamically with the client
IP address. T his requires secure
updates. T his must be set to
true for any other dynamic DNS
setting to be enabled. T he
default is true.
Boolean
dyndns_ttl
Sets a time-to-live for the client's
DNS record. T he default is 3600
seconds.
Integer
dyndns_refresh_interval
Sets a frequency to perform an
automatic DNS update, in
addition to the update when the
provider comes online. T he
default is 86400 seconds (24
hours).
Integer
dyndns_update_ptr
Sets whether to update the PT R
record when the client updates
its DNS records. T he default is
true.
Boolean
2.7.3. Using a Filter with Access Controls
T here is an Active Directory access provider, which means that Active Directory is used as the source for
authorization information. T his is actually a shortcut, that combines several generic LDAP parameters into
a single configuration parameter. Setting the Active Directory provider:
access_provider = ad
T his is the same as setting several different LDAP parameters, including setting the access order to check
for account expirations.
access_provider = ldap
ldap_access_order = expire
ldap_account_expire_policy = ad
29
Red Hat Enterprise Linux 7 Windows Integration Guide
T here is an additional option to identify which user accounts to grant access to based on an LDAP filter.
First, accounts must match the filter, and then they must pass the expiration check (implicit in the
access_provider = ad setting.
For example, this sets that only users which belong to the administrators group and have a
unixHomeDirectory attribute match the access control check:
access_provider = ad
ad_access_filter = (&(memberOf=cn=admins,ou=groups,dc=example,dc=com)
(unixHomeDirectory=*))
T he access control check requires a secure connection (SASL with a GSS-API mechanism). Configuring
the same functionality using the generic LDAP parameters requires defining that SASL/GSS-API
connection, the filter, and the expiration checks.
access_provider = ldap
ldap_access_order = filter, expire
ldap_account_expire_policy = ad
ldap_access_filter = (&(memberOf=cn=admins,ou=groups,dc=example,dc=com)
(unixHomeDirectory=*))
ldap_sasl_mech = GSSAPI
ldap_sasl_authid = [email protected]
ldap_schema = ad
30
⁠C hapter 3. Using realmd to Connect to an Active Directory Domain
Chapter 3. Using realmd to Connect to an Active Directory
Domain
realm d provides a clear and simple way to discover and join identity domains. It does not connect to the
domain itself; rather, it configures underlying Linux system services (SSSD or Winbind) to connect to the
domain.
3.1. About realmd
Chapter 2, Using Active Directory as an Identity Provider for SSSD describes using the System Security
Daemon on a local system and Active Directory as a backend identity provider. T here are a number of
different configuration parameters, some required and some optional, for each possible identity provider
and for SSSD itself.
All of the domain information must be available in advance and then properly formatted in the SSSD
configuration for SSSD to integrate the local system with Active Directory. T hat can be complex.
realm d simplifies that configuration. realm d can run a service discovery to identify different, available
domains (both Active Directory and Red Hat Enterprise Linux Identity Management), and then join the
domain and manage user access.
realm d can discover and support multiple domains because the underlying service (SSSD) supports
multiple domains.
3.2. realmd Commands
T he realm d command has two major task areas: managing the system's enrollment in a domain and
setting which domain users are allowed to access the local system resources.
T he realm d command mostly specifies an action and the realm for which to perform that action.
realm command realmName
For example:
realm join ad.example.com
T able 3.1. realmd Commands
Command
Description
Realm Commands
discover
Run a discovery scan for domains on the network.
join
Add the system to the specified domain.
leave
Removes the system from the given domain.
list
Lists all configured realms for the system or
(optionally) all configured and discovered realms.
Login Commands
permit
Permits access for specified users or for all users
within a configured realm to access the local
system.
31
Red Hat Enterprise Linux 7 Windows Integration Guide
Command
Description
deny
Restricts access for specified users or for all
users within a configured realm to access the local
system.
3.3. Discovering and Joining Active Directory Domains
3.3.1. Discovering Domains
All that the discovery process requires is the discover command. T his returns all of the realm
configuration and a list of packages that must be installed for the system to be enrolled in the realm.
[[email protected] ~]# realm discover
ad.example.com
type: active-directory
realm-name: AD.EXAMPLE.COM
domain-name: ad.example.com
configured: kerberos-member
server-software: active-directory
client-software: sssd
required-package: oddjob
required-package: oddjob-mkhomedir
required-package: sssd
login-formats: %D\%U
login-policy: allow-realm-logins
realm d checks for the DNS SRV record:
_ldap._tcp.dc._msdcs.domain.example.com.
T hat is created by default when Active Directory is configured, which enables it to be found by the service
discovery. realm d uses the domain assigned through DHCP to discover any LDAP servers on the
network.
realm d can discover both Active Directory and Identity Management domains. If both are in the
environment, then it is possible to limit the discovery results to a specific type of server:
[[email protected] ~]# realm discover --server-software=active-directory
It is also possible to run a discovery for a specific domain, using the domain controller's hostname or IP
address. For example:
[[email protected] ~]# realm discover ad.example.com
3.3.2. Joining an Active Directory Domain
T he join command only requires the realm name:
[[email protected] ~]# realm join ad.example.com
See: journalctl REALMD_OPERATION=r1088239.6316
realm: Joined ad.example.com domain
T his performs the join as the default Windows administrator and, in most environments, will prompt for the
password. T he command can connect to the Active Directory environment as a different user, by using the
32
⁠C hapter 3. Using realmd to Connect to an Active Directory Domain
-U option:
[[email protected] ~]# realm join ad.example.com -U AD.EXAMPLE.COM\jsmith
If Kerberos is properly configured on the Linux system, then it can also be performed using a Kerberos
ticket to authenticate. T he realm d command can use the -U option then to select which principal to use
or can use the default credential cache or KRB5_CCACHE variable.
[[email protected] ~]# kinit jsmith
[[email protected] ~]# realm join ad.example.com -U jsmith
T he actual join process configures both the local system services and the entries in the Active Directory
domain.
1. Runs a discovery scan for the specified realm.
2. Installs any required packages to join the system to the domain. T his includes SSSD and the PAM
home directory job packages.
3. Attempts to join the Active Directory domain as Administrator (unless a different user is specified
with the -U option). T he command first attempt to connect without credentials, but it prompts for a
password if required.
4. Once it connects to the domain, it creates an account entry for the system in the directory.
5. It creates a host keytab (/etc/krb5.keytab.
6. It configures the domain in SSSD and restarts the service.
7. Enables domain users for the system services (/etc/nsswitch.conf).
One of the attributes returned in the discovery search is login-policy, which shows if domain users
are allowed to log in as soon as the join is complete. If logins are not allowed by default, then they can be
manually allowed using the perm it command. T his is covered in Section 3.4, “Managing User Logins from
Active Directory”.
3.3.3. Removing a System from the Active Directory Domain
If a system should ever be removed from an Active Directory domain, this is done with the leave
command. T his removes the domain configuration from SSSD and NSS on the local system.
[[email protected] ~]# realm leave ad.example.com
T his attempts to perform the removal as the default Administrator in Active Directory. T he script may
prompt for a password or, depending on how the system was joined to the domain, it may require
performing the operation as a different user. T his can be specified with the -U option.
[[email protected] ~]# realm leave ad.example.com -U AD.EXAMPLE.COM\jsmith
3.3.4. Listing Domains
T he list command lists every configured domain for the system, and the full details and default
configuration for that domain. T his is the same information as is returned for the realm discovery, only for a
domain that is already in the system configuration.
33
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# realm list
linux.example.com
type: kerberos
realm-name: LINUX.EXAMPLE.COM
domain-name: linux.example.com
configured: kerberos-member
server-software: ipa
client-software: sssd
required-package: ipa-client
required-package: oddjob
required-package: oddjob-mkhomedir
required-package: sssd
login-formats: %U
login-policy: allow-realm-logins
T he --all option includes discovered domains (Active Directory, Identity Management, and Kerberos) as
well as configured domains. T he --nam e-only limits the results to the domain name, without the
configuration details.
[[email protected] ~]# realm list --all
linux.example.com
example.com
ad.example.com
3.4. Managing User Logins from Active Directory
By default, login policies for domain users are defined in the domain itself. (T his can be overridden in the
realm configuration so that the local policies only define who is allowed to login.) In addition to those
domain policies, realm d can configure basic allow/deny access rules for users from a specific domain.
NOTE
T hese access rules either allow all access to the system or no access. Finer-grained access rules
must be set on a specific system resource or in the domain.
T here are two commands that set access rules: perm it and deny. Permit is the more flexible of the two
commands. T he deny command is a blanket command that prohibits access from any user within the
realm. T he perm it command, on the other hand, can grant access to all users (--all) or to only
specified users, and it can also withdraw permission from specified users (-x).
For example, this adds an allow rule for every user within the ad.exam ple.com domain, and then
withdraws login permission from the jsm ith user.
[[email protected] ~]# realm permit ad.example.com --all
[[email protected] ~]# realm permit ad.example.com --x AD.EXAMPLE.COM\jsmith
3.5. Adding Default User Configuration
T he /etc/realm d.conf configuration file can add custom configuration for global logged-in user
settings. Some POSIX attributes not be set in the Windows user accounts or may be set to something
different than other users on the local system. T here are two such areas:
34
⁠C hapter 3. Using realmd to Connect to an Active Directory Domain
T he user home directory
A default user shell
User settings are defined in the [users] section in the /etc/realm d.conf file.
T he default-shell parameter can be any supported system shell.
T he default-home parameter sets a template to use to create a home directory if none is defined in
the realm. A common format is /hom e/%d/%u, where %d is the domain name and %u is the user name.
For example:
[users]
default-home = /home/%U
default-shell = /bin/bash
3.6. Additional Configuration for the Active Directory Domain Entry
Each individual domain can have custom settings in the realm entry in the /etc/realm d.conf
configuration file. Each realm can have a configuration section:
[realm.name]
attribute = value
attribute = value
Each attribute can be set by manually adding them to the configuration file or by passing them as
arguments when the system is joined to the realm.
T able 3.2. Realm Configuration Options
Parameter
Description
computer-ou
Sets the directory location to use to add computer
accounts to the domain. T his can be the full DN or
an RDN, relative to the root entry. T he subtree
must already exist.
user-principal
Sets whether to create a host principal for the
system.
automatic-id-mapping
Sets whether to enable dynamic ID mapping or
whether to disable mapping and use POSIX
attributes configured in Active Directory.
manage-system
Sets whether certain login policies are set in the
local system or by Active Directory.
For example, this disables ID mapping, enables the host principal, and adds the system to the specified
subtree.
[domain.example.com]
computer-ou = OU=Linux Computers,DC=domain,DC=example,DC=com
user-principal = yes
automatic-id-mapping = no
manage-system = no
T hese same parameters can be passed when the system is joined to the domain:
35
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# realm join --computer-ou="ou=Linux Computers," --automatic-idmapping=no --user-principal=yes
36
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
Chapter 4. Using Samba, Kerberos, and Winbind
Samba allows Linux systems to join an Active Directory environment by making them appear to be
Windows clients. Samba is an intermediary. As a means of systems integration, this allows a Linux client to
join an Active Directory Kerberos realm and to use Active Directory as its identity store.
Once a central Samba server is configured, then clients can be configured to connect to that Samba
server, and from there to Active Directory. T his is done using the local Winbind client. Winbind itself is a
local authentication tool, but within a larger Samba domain, it helps maintain and resolve user identities to
help maintain file ownership and access.
4.1. About Samba and Active Directory Authentication
Samba was one of the first points for Windows integration, starting with a way to share files and data
between Linux and Windows environments. T he Samba group has an excellent reference for
understanding and configuring Samba.
Samba has the slogan Opening Windows to a wider world, and it has a very broad range of features and
deployment options. Its core functionality is filesharing and printing between Windows and Linux
environments — and that is outside the scope of this guide.
T his chapter looks at one aspect of using Samba to open up Windows: allowing Linux clients to
authenticate using Active Directory. T his means adding Samba as a domain memeber of the Windows
domain.
4.1.1. About Samba, Kerberos, and Active Directory Domains
Active Directory is the domain controller for a number of services for the Windows environment, including
Kerberos realms and DNS domains. Samba has several different means of integrating with a Windows
domain, both NT LM and Active Directory. T he different options track with differences inherent in the
Windows servers themselves. For Active Directory integration (which is the scope of this document),
integrating with Active Directory means configuring a security environment that uses Kerberos the native
security context in Active Directory.
Several different system services should be configured on the Linux client to use Active Directory as a
domain controller:
Samba (for users and authentication)
DNS (to set the Active Directory server as the nameserver)
Kerberos (to use the Active Directory KDC)
PAM (to use Winbind)
NSS (to use Winbind and Kerberos)
4 .1.1.1. Samba
T here are several different ways that a Samba server can join an Active Directory domain. T he central
decision is how the users can be associated with the domain. In Samba, the user/domain structure is
called a security mode. T here are four user security modes:
user, the Samba default setting, requires simple usernames and plaintext passwords. T he username
format must be domain\user, such as EXAMPLE\jsm ith. ⁠ [2]
T his is a local-level security mode, and is not used for Active Directory integration.
37
Red Hat Enterprise Linux 7 Windows Integration Guide
server configures pass-through authentication to another Samba server.
domain configures the local Samba server as a domain member within a Windows NT 4 domain.
ads configures the local Samba server as a domain member within an Active Directory domain.
Of those security modes, only dom ain or ads are used for Windows integration, and ads allows
Kerberos security, which is native to Active Directory.
T he critical settings are the security type (security); the name of the Active Directory Kerberos realm
(realm), which is resolved by DNS discovery; the Samba workgroup (workgroup); and enabling encrypted
passwords. T here are other settings for Winbind, such as ID ranges for mapping UID and GID numbers to
users and templates for group membership and home directories; these can either be set or left to default
values.
T his is all configured in the [global] section of /etc/sam ba/sm b.conf.
#======================= Global Settings =====================================
[global]
workgroup = ADEXAMPLE
security = ads
realm = ADEXAMPLE.COM
encrypt passwords = yes
... 8< ...
4 .1.1.2. Kerberos
Kerberos must be configured to use the Active Directory server as its KDC. T his allows users to use
Kerberos tickets for authentication. Additionally, Samba must be configured to use the Active Directory
Kerberos realm; this allows Winbind to manage the Kerberos principals.
T he Active Directory realm should be set as the default domain in the [libdefaults] section of the
/etc/krb5.conf file, and then as a KDC in the [realm s] section. T he [dom ain_realm ] section
should define the Active Directory domain.
[libdefaults]
... 8< ...
default_realm = ADEXAMPLE.COM
[realms]
ADEXAMPLE.COM = {
kdc = kdc.adexample.com
}
[domain_realm]
adexample.com = ADEXAMPLE.COM
.adexample.com = ADEXAMPLE.COM
4 .1.1.3. DNS
T he local DNS service must be configured to use Active Directory as its domain controller. DNS is critical
for proper resolution of hostnames and domains for Kerberos. While many systems have proper DNS
settings, so that Samba-Active Directory integration could work well without configuring Active Directory as
a nameserver, using Active Directory as a nameserver avoids any potential resolution problems. T he
domain should also be added as a search directive, so that the Active Directory domain is used for
searches and discovery.
38
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
T his is configured in the /etc/resolv.conf file.
nameserver 1.2.3.4
search adexample.com
4 .1.1.4 . PAM and NSS
PAM (and NSS) allow local applications to use the Kerberos credentials provided by Active Directory, which
enables single sign-on for system applications and domain users. It is possible to use Kerberos directly or
to use Winbind, but for ease of use, offline caching of credentials, and other features, it is recommended
that you use Winbind.
For PAM, the Winbind libraries are set for authentication, account, password, and (optionally) session
management. T his is configured in the /etc/pam .d/system -auth file.
auth
required
pam_env.so
auth
sufficient
pam_unix.so nullok try_first_pass
auth
requisite
pam_succeed_if.so uid >= 500 quiet
auth sufficient pam_winbind.so use_first_pass
auth
required
pam_deny.so
account
required
pam_unix.so broken_shadow
account
sufficient
pam_localuser.so
account
sufficient
pam_succeed_if.so uid < 500 quiet
account [default=bad success=ok user_unknown=ignore] pam_winbind.so
account
required
pam_permit.so
password
requisite
pam_cracklib.so try_first_pass retry=3 type=
password
sufficient
pam_unix.so sha512 shadow nullok try_first_pass use_authtok
password sufficient pam_winbind.so use_authtok
password
required
pam_deny.so
session
optional
pam_keyinit.so revoke
session
required
pam_limits.so
session
[success=1 default=ignore] pam_succeed_if.so service in crond quiet
use_uid
session
required
pam_unix.so
session
optional
pam_krb5.so
session optional pam_winbind.so use_first_pass
For NSS, Active Directory can be used for passwords, shadow (users), and groups by setting Winbind as
an option. Additionally, this can be used for hosts by setting the WINS service option. Always leave files
as the first location to check for accounts; this allows local system users and services to be able to log in
and access resources.
T his is configured in the /etc/nsswitch.conf file.
passwd:
shadow:
group:
files winbind
files winbind
files winbind
hosts:
files dns wins
4.1.2. About Winbind v3 and Samba v3, and Authentication
T here are two important tasks when dealing with files: establishing the proper ownership and controlling
access to appropriate parties. Both of these ultimately relate to an effective way to identify and
authenticate users, and that was supplied by Winbind.
39
Red Hat Enterprise Linux 7 Windows Integration Guide
Winbind does three related but separate things:
Authenticate users (using local PAM configuration)
Resolve IDs, usernames, and groups (using NSS lookups)
Create a database of mapped Active Directory SIDs and local UID/GID numbers
Winbind as a client interacts with Samba, and then Samba actually connects to the Active Directory
domain. T he local system is not enrolled in the Windows domain in any meaningful way; it simply uses the
Active Directory environment (through Samba) as an identity store. PAM and NSS are configured to use
Winbind for user identities on the local system.
Winbind is a part of Samba, and that structure has some inherent limits for more general Windows
integration:
Samba is configured only for filesharing, so the core design for authentication and identity management
is designed to manage file ownership and authenticate users. Users in Active Directory (and even
applications on the Linux resources) are limited to certain PAM modules and NSS configuration for
trying to leverage authentication or implement other security policies.
Winbind is only used for authentication, so only the username and password attributes in the Active
Directory entry are ever used or available for the Windows user.
SIDs are mapped to a locally-chosen UID/GID pair. T his ignores any POSIX settings within the Active
Directory entry.
Winbind's behavior is bound to the Windows domain. T hings like Kerberos ticket management, and
even joining the domain, are performed through Windows tools like net join ads.
ID ranges, ID mapping, and group management are all configured manually and in different
configuration files for Samba and PAM.
4.2. Summary of Configuration Files, Options, and Packages
T able 4 .1. System Configuration Files, Required Options, and Required Packages
Service
Configuration File
Samba
/etc/samba/smb.conf
Required Parameters
Required Packages
samba
[global]
workgroup =
ADEXAMPLE
security =
ads
realm =
ADEXAMPLE.COM
encrypt
passwords = yes
... 8< ...
Winbind
40
samba-winbind
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
Service
Configuration File
Kerberos
/etc/krb5.conf
Required Parameters
Required Packages
krb5-workstation
[libdefaults]
... 8< ...
default_realm
= ADEXAMPLE.COM
[realms]
ADEXAMPLE.COM
= {
kdc =
kdc.adexample.co
m
}
[domain_realm]
adexample.com =
ADEXAMPLE.COM
.adexample.com
= ADEXAMPLE.COM
PAM
NSS
/etc/pam.d/system-auth
or /etc/pam.d/systemauth-ac (with
authconfig)
auth
sufficient
pam_winbind.so
use_first_pass
account
[default=bad
success=ok
user_unknown=igno
re]
pam_winbind.so
password
sufficient
pam_winbind.so
use_authtok
session
optional
pam_winbind.so
use_first_pass
/etc/nsswitch.conf
#required
passwd:
files winbind
shadow:
files winbind
group:
files winbind
#optional
hosts:
files dns wins
41
Red Hat Enterprise Linux 7 Windows Integration Guide
Service
Configuration File
DNS
/etc/resolv.conf
Required Parameters
Required Packages
nameserver
IPaddress
search
domainName
4.3. Configuring a Domain Member Using authconfig
All of the configuration outlined in Section 4.2, “Summary of Configuration Files, Options, and Packages”
can be done automatically using the authconfig tool, with the exception of the DNS configuration. T his
also provides the ability to back up the configuration files, which allows any changes to be reverted later
(which can be especially convenient if there is a mistake or a change to the configuration).
4.3.1. authconfig Arguments and Configuration File Parameters
T he Authentication Configuration tool automatically updates the required configuration files for Samba,
Kerberos, and Active Directory integration when it is used to configure Winbind as the authentication store
for the local system. T he relationships between the authconfig options and the required configuration
changes are not always obvious. T able 4.2, “authconfig Arguments and Configuration File Parameters”
shows what parameters are set with each command option; this can help ensure that the correct values
are used and that optional settings are refined.
T able 4 .2. authconfig Arguments and Configuration File Parameters
Service
CLI Option
GUI Field
Configuration
File
Configuration
Parameter
Samba
--smbsecurity
Security Model
/etc/samba/smb.co
nf
security
Samba
--smbworkgroup
Winbind Domain
/etc/samba/smb.co
nf
workgroup
--smbrealm
Winbind ADS
Realm
--smbservers
Winbind Domain
Controllers
Samba
Kerberos
Kerberos
42
Samba
/etc/samba/
smb.conf
Kerberos
/etc/krb5.co
nf
/etc/krb5.conf
Samba
realm in
[global]
Kerberos
default_real
m in
[libdefaults]
realm entry
(REALMNA
ME = {...})
in [realms]
T he KDC in the
realm entry (e.g.,
REALMNAME {...})
in [realms]
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
Service
CLI Option
Kerberos
--krb5realm
GUI Field
Configuration
File
Configuration
Parameter
/etc/krb5.conf
T he domain entry
in [domain_realm]
IMPOR
TANT
T his value
must be
identical to
the value
given in -sm brealm
for the
domain to
be
configured
properly.
PAM
-enablewinbindauth
/etc/pam.d/systemauth
auth, account,
password,
sessions
NSS
--enablewinbind
/etc/nsswitch.conf
passwd, shadow,
group
NSS
--enablewins
/etc/nsswitch.conf
hosts
Winbind
--enablecache
Winbind
-enablewinbindkrb5
Winbind
-enablewinbindofflin
e
4.3.2. Configuring Active Directory Authentication with authconfig in the Command
Line
1. Install the sam ba-winbind package. T his is required for Windows integration features in Samba
services, but is not installed by default.
[[email protected] ~]# yum install samba-winbind
2. Install the krb5-workstation package. T his is required to connect to a Kerberos realm and
manage principals and tickets.
[[email protected] ~]# yum install krb5-workstation
3. Edit the DNS configuration to use the Active Directory domain as a nameserver and for search.
[[email protected] ~]3 vim /etc/resolv.conf
nameserver 1.2.3.4
search adexample.com
43
Red Hat Enterprise Linux 7 Windows Integration Guide
4. T he authconfig command does not set any requirements for what options must be invoked at a
given time, since it can be used to modify configuration as well as to define new configuration.
T his example provides all of the required Samba, Kerberos, PAM, and NSS parameters, as well as
options for Winbind which allow offline access and for the local system which allow system accounts
to continue to work. T his command should be all on one line; it has been broken into multiple lines
and annotated to show what options are being used.
[[email protected] ~]# authconfig
// NSS
--enablewinbind
--enablewins
// PAM
--enablewinbindauth
// Samba
--smbsecurity ads
--smbworkgroup=ADEXAMPLE
--smbrealm ADEXAMPLE.COM
// Kerberos
--smbservers=ad.example.com
--krb5realm=ADEXAMPLE.COM
// winbind
--enablewinbindoffline
--enablewinbindkrb5
--winbindtemplateshell=/bin/sh
// general
--winbindjoin=admin
--update
--enablelocauthorize
--savebackup=/backups
[/usr/bin/net join -w ADEXAMPLE -S ad.example.com -U admin]
T he --winbindjoin parameter automatically runs the net join command to add the system to
the Active Directory domain.
T he --enablelocalauthorize sets local authorization operations to check the /etc/passwd
file. T his allows local accounts to be used to authenticate users as well as the Active Directory
domain.
TIP
T he --savebackup option is not required, but it is recommended. T his backs up the
configuration files to the given directory before making the changes. If there is a configuration
error or of the configuration later is changed, authconfig can use the backups to revert the
changes.
4.3.3. Configuring Active Directory Authentication in the authconfig GUI
T here are fewer configuration options in the authconfig UI than are in the CLI. For example, it is
possible to configure Samba, NSS, and Winbind and to join the domain, but it does not configure Kerberos
or PAM. T hose must be configured manually if using the UI.
44
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
NOTE
T he authconfig command-line tools are installed by default, but the GUI requires the
authconfig-gtk package, which is not available by default.
1. Install the sam ba-winbind package. T his is required for Windows integration features in Samba
services, but is not installed by default.
[[email protected] ~]# yum install samba-winbind
2. Install the krb5-workstation package. T his is required to connect to a Kerberos realm and
manage principals and tickets.
[[email protected] ~]# yum install krb5-workstation
3. Configure the Active Directory Kerberos realm as the default realm and KDC for the local system.
[[email protected] ~]# vim /etc/krb5.conf
[libdefaults]
... 8< ...
default_realm = ADEXAMPLE.COM
[realms]
ADEXAMPLE.COM = {
kdc = kdc.adexample.com
}
[domain_realm]
adexample.com = ADEXAMPLE.COM
.adexample.com = ADEXAMPLE.COM
4. Edit the DNS configuration to use the Active Directory domain as a nameserver and for search.
[[email protected] ~]3 vim /etc/resolv.conf
nameserver 1.2.3.4
search adexample.com
5. Open the Authentication Configuration T ool.
[root2server ~]# authconfig-gtk
6. In the Identity & Authentication tab, select Winbind in the User Account Database
drop-down menu.
45
Red Hat Enterprise Linux 7 Windows Integration Guide
7. Set the information that is required to connect to the Microsoft Active Directory domain controller.
Winbind Dom ain gives the Windows work group.
T his should be in the Windows 2000 format, such as DOMAIN.
Security Model sets the security model to use for Samba clients. T his is ads, to configure
Samba to act as a domain member in an Active Directory Server realm.
Winbind ADS Realm gives the Active Directory realm that the Samba server will join.
Winbind Dom ain Controllers gives the hostname or IP address of the domain controller
to use.
T em plate Shell sets which login shell to use for Windows user account settings. T his is
optional.
Allow offline login allows authentication information to be stored in a local cache. T he
cache is referenced when a user attempts to authenticate to system resources while the system
46
⁠C hapter 4 . Using Samba, Kerberos, and Winbind
is offline.
8. Click the Join Dom ain to run the net ads join command to join the Active Directory domain.
T his is only to join the domain immediately; the configuration can be saved and then the net ads
join command can be run manually later.
9. Click the Apply button to save the configuration.
[2] When verifying that a g iven us er exis ts in the Wind o ws d o main, always us e Wind o ws 20 0 0 -s tyle fo rmats and es c ap e the b ac ks las h
(\) c harac ter. Fo r examp le:
[ro o [email protected] server ~ ]# g eten t p asswd d o m ai n \\user D O M AIN \user:* :1 6 7 7 7 2 1 6 :1 6 7 7 7 2 1 6 :N am e
S urn am e:/h o m e/D O M AIN /user:/b i n /b ash
This c an als o b e s p ec ified in the authc o nfig c o mmand -line to o l with the - - wi n b i n d sep arato r= o p tio n.
47
Red Hat Enterprise Linux 7 Windows Integration Guide
⁠Part II. Integrating a Linux Domain with an Active
Directory Domain
48
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Chapter 5. Creating Cross-Realm Trusts with Active Directory
and Identity Management
Kerberos allows the configuration of trusted realms. Each realm has its own resources and users, yet the
trust relationship allows users of any trusted realm to obtain tickets and connect to machines or services
in a peer realm as if they were members of that peer realm.
Because of differences in the way that Windows and Linux domains implement LDAP services, DNS
management, and even Kerberos realms, it is difficult to establish a direct trust between Active Directory
and Linux domains manually. A trust relationship using IdM centrally defines and establishes the Kerberos
trust and DNS mappings so that Active Directory users can access Linux hosts and services completely
transparently, using one set of credentials.
5.1. The Meaning of "Trust"
Kerberos has the ability to create a relationship between two otherwise separate realms. T his is called a
cross-realm trust. T hese realms create a shared ticket and key so a member of one realm is perceived as
a member of both realms. One realm trusts another.
A cross-realm Kerberos trust is limited to Kerberos realms. However, identity management environments
such as Active Directory and IdM in Red Hat Enterprise Linux include services other than Kerberos (most
notably DNS) within their domain definitions. It is possible to established a trusted relationship across the
full domain, not just the Kerberos realm, through IdM trusts.
5.1.1. The Architecture of a Trust Relationship
Both Active Directory and Identity Management manage a variety of core services: Kerberos, LDAP, DNS,
certificate services. For these two disparate domains to be integrated transparently, all of these core
services need to be able to interact cleanly with one another.
T hose services can be broken into two major points of interaction: a Kerberos realm and a DNS domain.
Certificate services, LDAP entries, and other services can be managed independently for Active Directory
and IdM. T he place where they intersect is where identities need to be authenticated (Kerberos) and a
mechanism to route queries between domains (DNS).
A trust establishes an identity/access relationship between one domain and another domain. Active
Directory environments can be complex, so there are different possible types and arrangements for Active
Directory trusts, between subdomains, root domains, forests, and external domains. Microsoft T echNet
provides an excellent primer, How Domain and Forest T rusts Work, on the internal components used to
create trust relationships and different types of trusts.
A trust is a path from one domain or realm to another. T he way that identities and information moved
between the domains is the trust flow.
At its most basic, a trust flows one direction. One domain contains users (the trusted domain), and one
domain contains resources (the trusting domain). T he domain with resources trusts the domain with the
users. T his means that the users can access the trusting domain resources — but it does not work the
other way. T he users in the trusting domain cannot access resources in the trusted domain.
T his is illustrated in Figure 5.1, “Basic Unidirectional T rusts”. Realm A is trusted by Realm B, but Realm B
is not trusted by Realm A. T he trust is unidirectional.
49
Red Hat Enterprise Linux 7 Windows Integration Guide
Figure 5.1. Basic Unidirectional T rusts
In many environments, there may be multiple domains which have trust agreements that are only explicit
between one or two domains. T here are two ways that trust can be handled: trusts can be followed
recursively so that a domain trusts another domain and any other domain trusted by that second domain
(transitive trusts), or a trust can be limited only to the explicitly included domains (non-transitive trusts).
Figure 5.2. T ransitive T rusts
Within a homogeneous Active Directory environment most (but not all) trusts are bidirectional and
transitive by default. However, in a heterogeneous environment, Active Directory can establish a trust with
a non-Active Directory domain, such as Identity Management in Red Hat Enterprise Linux. T his is a realm
trust, and, as Active Directory defines it, it has a slightly different default configuration than an Active
Directory domain trust:
It is unidirectional by default. (Even for bidirectional realm trusts, the actual configuration is set up so
that there are two unidirectional trusts, pointing different ways.)
It uses Kerberos authentication rather than Microsoft's native NT LM authentication.
It is non-transitive by default, but some additional configuration can help support transitive trusts.
T he default direction is for the external (IdM) domain to trust the Active Directory domain. T hat means
that the external domain trusts all security principles within the Active Directory domain.
50
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Figure 5.3. T rust Direction
5.1.2. Active Directory Principles, Security Objects, and Trust
T he key to a trust is evaluating principles within the Active Directory domain as those users attempt to
access resources in the external domain. T he protocols that are used to evaluate those identities is the
trust path. Active Directory trusts use NT LM to evaluate identities. Realm trusts — including the Identity
Management trust — use Kerberos to create send and verify privileged access certificates and create
Kerberos tickets for the external applications.
Figure 5.4 . Authentication Path for Windows T rusts
T he protocol which an application uses to process authentication requests is different at the front, either
NT LM or Kerberos. Both of those authentication protocols interact with the Net Logon layer in Active
Directory, and, from there, the process for accessing domain objects is the same. Each Active Directory
server maintains a local security authority (LSA), which maintains all of the locally-defined security policies
and provides a way to identify local users and identifiers, tickets and PACs, and other security data.
NOTE
All Kerberos communication for both Active Directory and IdM for trusts uses GSS-API.
51
Red Hat Enterprise Linux 7 Windows Integration Guide
Past the local security authority, there is the larger Active Directory configuration. T he domain System
container has all of the security information, including principles, user, and group information, for all of the
objects in the domain. At the root of the domain is a global catalog of all users, groups, and objects within
the entire forest. With a trust, information about Windows users can be retrieved from the System
container or from the global catalog.
5.1.3. Trust Architecture in IdM
On the Identity Management side, the IdM server has to be able to recognize Active Directory identities and
appropriately process their group membership for access controls. T he Microsoft PAC contains the
required information about the user — their security ID, domain username, and group memberships.
Identity Management has three components to analyze that data in the PAC on the Kerberos ticket:
Samba, to perform identity lookups on Active Directory and retrieve user and group security identifiers
(SIDs) for authorization information
SSSD, to cache user, group, and ticket information for users and to map Kerberos and DNS domains
Identity Management (Linux domain management), to associate the Active Directory user with an IdM
group for IdM policies and access
NOTE
Access control rules and policies for Linux domain administration (such as SELinux, sudo, and
host-based access controls) are defined and applied through Identity Management. Any access
control rules set on the Active Directory side are not evaluated or used by IdM; the only Active
Directory configuration which is relevant is group membership.
Figure 5.5. Applications and Services for T rust
5.1.3.1. Active Directory PACs and IdM T ickets
Group information in Active Directory is stored in a list of identifiers in each Kerberos ticket for Active
Directory users in a special data set called privileged access certificates or MS-PAC. T he group
information in the PAC has to be mapped to the Active Directory groups and then to the corresponding IdM
groups to help determine access. A PAC is essentially an account usability extension.
52
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Understanding the group mapping for trusts can help clarify how groups should be structured in trust
environments.
Microsoft uses a special authorization structure called privileged access certificates or MS-PAC. A PAC is
embedded in a Kerberos ticket as a way of identifying the entity to other Windows clients and servers in
the Windows domain.
On IdM resources, if an Active Directory user requests a ticket for a service, then IdM forwards the request
to Active Directory to retrieve the user information. T he PAC information sent back by Active Directory is
embedded in the Kerberos ticket.
IdM (through SSSD, as an IdM client), extracts the Active Directory group security identifiers (SIDs) from the
PAC. IdM then compares the Active Directory SIDs in the PAC to the group SIDs configured as members in
IdM groups. If the Active Directory group is a member of an IdM group, then the IdM group SID is added to
the PAC, and the Kerberos ticket is updated with the new PAC.
Figure 5.6. IdM, SSSD, and Active Directory
T hat new ticket is then used to generate a service ticket for the user, and the user is granted access to
the IdM-hosted services. according to their access rules. Additionally, the IdM group information in the
SSSD user cache is updated to include the mapped IdM groups for the Active Directory user.
SSSD stores multiple T GT s and tickets for each user, as new services are accessed.
A simpler way of saying this is that Active Directory supplies a list of groups for each user, based on an
identifier for the group. IdM compares that list of Active Directory groups to memberships in IdM groups
(where each group member is identified by that SID, rather than by a name or DN). If the Active Directory
groups to which the user belongs are known to the IdM domain, then the user is recognized by the IdM
domain.
5.1.3.2. Active Directory Users and IdM Groups
T he crucial factor is that Active Directory users are recognized to the IdM domain not by their
Active Directory user entry, but by their Active Directory group memberships. In a sense, Active
Directory users are not trusted by the IdM domain — Active Directory groups are.
53
Red Hat Enterprise Linux 7 Windows Integration Guide
But this method of mapping Active Directory group SIDs to IdM group members means that group structure
in IdM is important. Active Directory groups have different attributes than Linux groups and, therefore,
different attributes than IdM groups. Most critically, Active Directory groups are not POSIX groups, while
IdM groups are.
IdM uses an intermediary, non-POSIX group type, external groups, which allow entities outside IdM or a
Linux system to be added as member. T hat external group can then be added to a standard IdM (POSIX)
group as a member.
When Active Directory groups are added to an IdM group, they can be identified by their SID or by name, in
the formats DOMAIN\group_name or [email protected] IdM then resolves the group name to the SID
and stores the SID as the group member entry, to be compared to any offered user PAC.
Actually configuring groups for Active Directory users is described in Section 5.4, “Creating IdM Groups for
Active Directory Users”.
5.1.3.3. Mapping User IDs and Using POSIX Attributes
Active Directory user entries do not exist in the IdM server; they are not synchronized or copied over. Any
information required by IdM resources is pulled in from Active Directory and cached. T he unique identifiers
on the Active Directory side (the security ID, a combination of the security domain identifier and the user
identifier) are associated with usernames. When the username is used to access IdM resources, IdM
(through Samba) for resolves that username to its SID, and then looks up the information for that SID
within the Active Directory domain.
Linux systems require that every user has a local UID number and group ID number. When users are
created in IdM, the users are assigned UID/GID numbers by default. Even trusted users require a UI/GID
number on a Linux system. T hat UID/GID number can be generated by IdM, but if the Active Directory entry
already has UID/GID numbers assigned, then assigning different numbers creates a conflict. It is possible
to use the Active Directory-defined POSIX attributes (including the UID/GID number, preferred login shell,
and home directory location).
Active Directory stores a subset of information for all objects within the forest in a global catalog. T his
global catalog includes every entry for every domain in the forest. T he global catalog can be queried to
NOTE
T o use Active Directory-defined POSIX attributes, those attributes must be published to the global
catalog. Otherwise, IdM generates user IDs based on the SID and the IdM ID range.
IdM auto-detects what kind of ID range to use when the trust is configured, but the range type can be
manually set with the ipa trust-add command.
ipa trust-add
–range-type=ipa-ad-trust-posix
T able 5.1. T ypes of Ranges
Range Option
Description
ipa-local
For IDs defined locally.
ipa-ad-winsync
For ID numbers assigned through the
synchronization process.
ipa-ad-trust
For IDs set with SID - username mapping.
ipa-trust-posix
For IDs defined in POSIX attributes in the Active
Directory entry.
54
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Range Option
Description
ipa-ipa-trust
For IDs generated through trust configuration in
the IdM server.
5.1.3.4 . Active Directory Users and IdM Policies and Configuration
Several IdM policy definitions — SELinux, host-based access control, sudo, and netgroups — rely on user
groups to identify how the policies are applied.
Figure 5.7. Active Directory Users and IdM Groups and Policies
Active Directory users are external to the IdM domain, but they can still be added as group members to IdM
groups, as long as those groups are configured as external groups. External groups in IdM are non-POSIX
groups. T he external group is then added as a member of an IdM group (a POSIX group).
T he sudo, host-based access controls, and other policies are applied to that POSIX group and, ultimately,
to the Active Directory user when accessing IdM domain resources.
T he user SID in the PAC in the ticket is resolved to the Active Directory identity. T his means that Active
Directory users can be added as group members using their fully-qualified username or their SID.
NOTE
T esting tools such as hbactest will not work with trusted users because the trusted user group
associations are resolved dynamically, not stored in the IdM directory.
5.1.4. Different DNS-Trust Environments
Both Active Directory and Identity Management can define DNS services, and those DNS domains must
interact cleanly with each other. T here are two potential DNS configurations:
T he DNS domains can be independent.
Identity Management can be configured as a subdomain of Active Directory.
In all cases, the different domains forward requests to each other as necessary and maintain different
DNS namespaces. It is just a matter of defining how they recognize each other for forwarding queries.
55
Red Hat Enterprise Linux 7 Windows Integration Guide
IMPORTANT
DNS caches all data, at all levels of the DNS domain. T he time to propagate any changes to the
DNS records depends on the cumulative time for all of the configured time to live parameters.
Required: Identical Records in Superior and Subdomains
Within the Identity Management environment, every machine name must be fully resolvable. When using
trusts, this includes machines within the trusted Active Directory domain. Depending on the configuration of
the DNS environment, there can be a couple of different ways that the DNS services must be configured.
If IdM and Active Directory are subdomains within a larger, shared namespace or if IdM is a subdomain of
the Active Directory DNS namespace, then the best configuration is to use delegation to create
relationships between DNS domains. Delegation (NS) and glue (A or AAAA) records must be identical in
every superior zone (such as exam ple.com ) and inferior zone (such as ipa.exam ple.com ). T his
means that the superior and subdomains must contain the exact same NS, A, and AAAA records.
If the Active Directory and IdM DNS domains are in entirely different namespaces, then use conditional
forwarders. In that case, forwarding rules must be in place in both environments to allow all machines to be
resolved.
Configuration Option 1: Separate DNS Domains
In this case, there are two entirely different namespaces, such as ipaexam ple.com and
adexam ple.com . For these domains to communicate, they must be configured as conditional forwarders
of each other's domain.
Figure 5.8. T rust with Separate DNS Domains
Configuration Option 2: Separate DNS Subdomains
A similar scenario is where both the Active Directory domain and the IdM domain are subdomains of a
larger, central domain. For example, the Active Directory domain is ad.exam ple.com , the Identity
Management domain is ipa.exam ple.com , and the superior domain for both is exam ple.com . When
using equivalent subdomains, do not use forwarders — use DNS delegation instead. Forwarders set in
global configuration override any delegation rules, even if the local server is configured as authoritative.
Instead, identical delegation rules should be set in the superior domain and the subdomains.
Configuration Option 3: Identity Management as a Subdomain of Active Directory
In this case, Identity Management is a namespace within the larger Active Directory space, such as
linux.exam ple.com and exam ple.com . IdM can be configured to send all requests to the Active
Directory domain (a forward-only policy) or it can send queries first to Active Directory and then attempt to
resolve them itself (a forward-first policy).
56
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Figure 5.9. T rust with IdM as a DNS Subdomain of Active Directory
5.1.5. Identity Management Interactions with Multiple Domains
Whenever the IdM server connects to its peer server in trust, the information about the Active Directory
DNS domains are fetched from the domain controller and stored in the cn=Realm
Dom ains,cn=ipa,cn=etc,suffix subtree.
If there are multiple DNS domains defined within the Active Directory domain, then those DNS domains are
added individually to the configuration subtree, and those are used to route queries to the appropriate
domain.
5.1.6. Potential Behavior Issues with Active Directory Trust
5.1.6.1. Active Directory Users and IdM Administration
T rust relationships are unidirectional. Active Directory users exist only within the Active Directory domain
and are limited to what resources within the IdM domain they can access. Active Directory users can
not be administrators for IdM because they do not exist within IdM.
Active Directory users, then, cannot use any IdM administrative tools, including the web UI and commandline tools.
5.1.6.2. Authenticating Deleted Active Directory Users
By default, every IdM client uses the System Security Services Daemon to cache user identities and
credentials. T his allows the local system to reference identities for users who have already logged in
successfully once, even if one of the backend providers (IdM or Active Directory) is temporarily unavailable.
Because SSSD maintains a list of users locally, it is possible that changes that are made on the backend
are not immediately visible to clients.
If an Active Directory user has successfully logged into an IdM client resource, that user identity is cached
in SSSD on both the local client and on the IdM server. If that Active Directory user is then deleted in Active
Directory, that identity is still cached in IdM, which means that the user could successfully log into IdM
resources.
T he deleted Active Directory user will be able to log into IdM resources until the SSSD cache on any local
client and on the IdM server expire. T hen, when the IdM server attempts to retrieve the identity from Active
Directory, it will receive notification that the user does not exist, and the login attempt fails.
57
Red Hat Enterprise Linux 7 Windows Integration Guide
5.1.6.3. Credential Cache and Selecting Active Directory Principals
T he Kerberos credentials cache attempts to match a client principal to a server principal based on the
service name, then the hostname, then (possibly) the realm name. Because the client/server mapping is
done using the hostname and the realm name, this can create seemingly unexpected behavior in binding
as an Active Directory user because the realm name of the Active Directory user is different than the realm
name of the IdM system.
What this means in practice is that if an Active Directory user kinits and then uses SSH to connect to an
IdM resource, that principal is not selected for the resource ticket; an IdM principal is used because the IdM
principal matches the resource's realm name.
For example, if the Active Directory user is Adm inistrator and the domain is ADEXAMPLE.ADREALM,
the principal is Adm [email protected] ADEXAMPLE.ADREALM.
[[email protected] ~]# kinit [email protected]
Password for [email protected]:
[[email protected] ~]# klist
Ticket cache: KEYRING:persistent:0:0
Default principal: [email protected]
Valid starting
Expires
27.11.2013 11:25:23 27.11.2013 21:25:23
renew until 28.11.2013 11:25:16
Service principal
krbtgt/[email protected]
T his is set as the default principal in the Active Directory ticket cache. However, if any IdM user also has a
Kerberos ticket (such as adm in), then there is a separate IdM credentials cache, with an IdM default
principal. T hat IdM default principal is selected for a host ticket if the Active Directory user uses SSH to
connect to a resource.
[[email protected] ~]# ssh -l [email protected] ipaclient.example.com
[email protected]@ipaclient.example.com's password:
[[email protected] ~]# klist -A
Ticket cache: KEYRING:persistent:0:0
Default principal: [email protected]
Valid starting
Expires
27.11.2013 11:25:23 27.11.2013 21:25:23
renew until 28.11.2013 11:25:16
Service principal
krbtgt/[email protected]
Ticket cache: KEYRING:persistent:0:0
Default principal: [email protected] >>>>> IdM user
Valid starting
Expires
Service principal
27.11.2013 11:25:18 28.11.2013 11:25:16 krbtgt/[email protected]
27.11.2013 11:25:48 28.11.2013 11:25:16 host/[email protected]
>>>>> host principal
T his is because the realm name of the IdM principal matches the realm of the IdM resource.
5.1.6.4 . Resolving Group SIDs
Losing Kerberos T ickets
Running any command to obtain a SID from the Samba service — such as net getlocalsid or net
getdom ainsid — kills any existing admin ticket in the Kerberos cache.
Cannot Verify Group Membership for Users
58
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
T here is no way to verify that a specific trusted user is associated with a specific IdM group, external or
POSIX.
Cannot Display (Remote) Active Directory Group Memberships for an Active Directory User
For Linux system users, local group associations can be shown for a user using the id command.
However, Active Directory group memberships are not displayed with id for Active Directory users, even
though they are with Samba tools.
T he wbinfo command can be used to obtain a SID for an Active Directory user and then to display
groups associated with that SID.
[[email protected] ~]# wbinfo -n ADDOMAIN\\jsmith
S-1-5-21-1689615952-3716327440-3249090444-1104 SID_USER (1)
[[email protected] ~]# wbinfo --user-domgroups=S-1-5-21-1689615952-37163274403249090444-1104
S-1-5-21-1689615952-3716327440-3249090444-513
S-1-5-21-1689615952-3716327440-3249090444-1106
T he same query using id shows only the user information, not the Active Directory group membership
information.
[[email protected] ~]# id ADDOMAIN\\jsmith
uid=1921801104([email protected]) gid=1921801104([email protected])
groups=1921801104([email protected])
TIP
T o work around this, ssh into an IdM client machine as the given Active Directory user. After the first
successful login, the Active Directory group memberships are detected and returned in the id
search.
[[email protected] ~]# id ADDOMAIN\jsmith
uid=1921801107([email protected]) gid=1921801107([email protected])
groups=1921801107([email protected]),129600004(ad_users),1921800513(domain
[email protected])
5.2. Environment and Machine Requirements to Set up Trusts
Make sure that both the Active Directory and IdM servers, machines, and environments meet the
requirements and settings in this section before configuring a trust agreement.
5.2.1. Supported Windows Platforms
T rust relationships can be configured with these Windows server versions:
Windows Server 2008 R2 (32-bit)
Windows Server 2008 R2 (64-bit)
5.2.2. Domain and Realm Names
59
Red Hat Enterprise Linux 7 Windows Integration Guide
T he IdM DNS domain name and Kerberos realm name must be different than the Active Directory DNS
domain name and Kerberos realm name.
5.2.3. NetBIOS Names
T he NetBIOS name is the far-left component of the domain name. For example, if the domain is
linux.example.com, the NetBIOS name is linux, while if the domain name is simply example.com, it is
example. T he NetBIOS name is critical for identifying the Active Directory domain and, if the IdM domain is
within a subdomain of Active Directory DNS, for identifying the IdM domain and services.
T he IdM domain and Active Directory domain must have different NetBIOS names.
5.2.4. Integrated DNS
Both the Active Directory server and the IdM server must be configured to run their own respective DNS
services.
5.2.5. Integrated Certificate Authorities
Both Active Directory and Identity Management must be configured with integrated certificate services.
5.2.6. Firewalls and Ports
Required Ports
For a trust relationship, the Active Directory server and IdM server must have almost all of the required
system ports open that are required for an IdM server installation, with the exception of the LDAP
ports.
T able 5.2. IdM Ports
Service
HT T P/HT T PS
Ports
80
T ype
T CP
443
Kerberos
88
T CP and UDP
464
DNS
53
T CP and UDP
NT P
123
UDP
IMPORTANT
T he IdM backend LDAP server must not be reachable by the Active Directory domain controller. T he
associated ports — 389 and 636 — on the IdM server host must be shut down for the Active
Directory domain controller.
Starting firewalld at Boot T ime
Configure the firewalld service to start when the system boots:
[[email protected] ]# chkconfig firewalld on
60
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Setting firewalld Configuration
T he firewalld configuration needs to allow access to the required IdM ports and reject access to the
IdM LDAP ports. T he order of the rules is important. Active Directory-based requests to LDAP ports must
be blocked first (based on the Active Directory server IP address), then there must be connections allowed
to all IdM T CP and UDP ports.
1. Open the firewalld configuration file.
[[email protected] ~]# vim /etc/firewalld
2. Add the rule to restrict access to LDAP ports for the Active Directory host.
-A INPUT -s ad_ip_address -p tcp -m multiport --dports 389,636 -m state -state NEW,ESTABLISHED -j REJECT
3. Make sure that there lines to allow access to the T CP and UDP ports required by IdM.
-A INPUT -p tcp -m multiport --dports 80,443,389,636,88,464,53,138,139,445 -m
state --state NEW,ESTABLISHED -j ACCEPT
-A INPUT -p udp -m multiport --dports 88,464,53,123,138,139,389,445 -m state
--state NEW,ESTABLISHED -j ACCEPT
4. Save the file.
5. Restart the firewalld service:
[[email protected] ]# systemctl restart firewalld.service
Example 5.1. Example firewalld Configuration File
*filter
:INPUT ACCEPT [0:0]
:FORWARD ACCEPT [0:0]
:OUTPUT ACCEPT [0:0]
-A INPUT -m state --state ESTABLISHED,RELATED -j ACCEPT
-A INPUT -p icmp -j ACCEPT
-A INPUT -i lo -j ACCEPT
-A INPUT -m state --state NEW -m tcp -p tcp --dport 22 -j ACCEPT
-A INPUT -s ad_ip_address -p tcp -m multiport --dports 389,636 -m state --state
NEW,ESTABLISHED -j REJECT
-A INPUT -p tcp -m multiport --dports 80,443,389,636,88,464,53,138,139,445 -m
state --state NEW,ESTABLISHED -j ACCEPT
-A INPUT -p udp -m multiport --dports 88,464,53,123,138,139,389,445 -m state -state NEW,ESTABLISHED -j ACCEPT
-A INPUT -p udp -j REJECT
-A INPUT -p tcp -j REJECT
-A FORWARD -j REJECT --reject-with icmp-host-prohibited
COMMIT
5.2.7. IPv6 Settings
T he IdM system must have IPv6 enabled in the kernel. If IPv6 is disabled, then the CLDAP plug-in used by
the IdM services fails to initialize.
61
Red Hat Enterprise Linux 7 Windows Integration Guide
5.2.8. Clock Settings
Both the Active Directory server and the IdM server must have their clocks in sync.
5.2.9. Supported Username Formats
Username mapping is performed in the local SSSD client. A Python regular expression is used by SSSD to
identify the username and the domain to which it belongs.
By default in SSSD, the username format is defined in the form [email protected] T his uses the regular
expression:
re_expression = (?P<name>[^@]+)@?(?P<domain>[^@]*$)
Active Directory can support several different kinds of name formats, however, so the re_expression
parameter in the SSSD configuration file for IdM backends or Active Directory backends uses a more
complex expression:
re_expression = (((?P<domain>[^\\]+)\\(?P<name>.+$))|((?P<name>[^@]+)@(?
P<domain>.+$))|(^(?P<name>[^@\\]+)$))
T his supports usernames in multiple formats:
username
[email protected]
DOMAIN\username
TIP
An additional SSSD parameter, default_domain_suffix, can be used to supply a default domain
value for usernames. For example, if all users are in a trusted Active Directory domain of
adexam ple.com and the identity backend is the IdM domain of ipa.exam ple.com , the
default_domain_suffix parameter can be set with the value adexam ple.com . All users are
automatically assumed to belong to that user domain unless the domain value is explicitly given with
the username.
5.3. Creating Trusts
5.3.1. Setting up Trust with IdM as a DNS Subdomain of Active Directory
T he central purpose of a trust is to create a relationship between Kerberos realms and DNS domains. T he
Kerberos configuration is fairly consistent, but there can be very different DNS configurations for the IdM
and Active Directory domains. Configuration Option 3: Identity Management as a Subdomain of Active
Directory describes the configuration if IdM is a subdomain within a larger Active Directory-managed DNS
domain.
1. Stop the Windows firewall service.
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
62
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
3. Install the required trust packages, updated Samba4 packages, and LDAP-DNS packages for IdM
DNS management.
[[email protected] ]# yum install ipa-server "*ipa-server-trust-ad" sambawinbind-clients bind-dyndb-ldap samba-client
4. Set up the IdM server to use its own, integrated DNS services (--setup-dns), its own DNS domain
(-n), and the Active Directory DNS server as a forwarder (--forwarder). For example:
[[email protected] ]# ipa-server-install --setup-dns --forwarder=255.255.255.255 p secret -a secret -r IPAEXAMPLE -n linux.adexample.com --hostname
ipaserver.linux.adexample.com -U
5. ⁠ Add the IdM domain as a subdomain entry in the Active Directory configuration and add an NS
record for the IdM DNS. For this example, the IdM configuration has a NetBIOS name of linux (the
subdomain) and the domain name is adexam ple.com .
a. Open the command prompt, using Run as Administrator.
b. Use the dnscm d command to add the A record for the IdM server, using the IdM hostname,
NetBIOS name, and IP address.
/RecordAdd ad_domain ipa_hostname.ipa_netbios A ipa_ip_address
For example:
C:\> dnscmd 127.0.0.1 /RecordAdd adexample.com ipaserver.linux A
255.255.255.0
c. T hen add the NS record for the IdM server. T his has the format:
/RecordAdd ad_domain ipa_netbios NS ipa_hostname.ipa_subdomain
For example:
C:\> dnscmd 127.0.0.1 /RecordAdd adexample.com linux NS
ipaserver.linux.adexample.com
6. Check the SRV records for both domains from both servers.
On the IdM server, use the dig SRV command to list the records for the Active Directory domain
and the IdM domain.
[[email protected] ~]# dig SRV _ldap._tcp.adexample.com
;; ANSWER SECTION:
_ldap._tcp.adexample.com. 600
IN
SRV
0 100 389
adserver.adexample.com.
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
[[email protected] ~]# dig SRV _ldap._tcp.linux.adexample.com
;; ANSWER SECTION:
_ldap._tcp.linux.adexample.com. 86400
IN
SRV
0 100 389
ipaserver.linux.adexample.com.
63
Red Hat Enterprise Linux 7 Windows Integration Guide
;; AUTHORITY SECTION:
linux.adexample.com.
86400
IN
ipaserver.linux.adexample.com.
;; ADDITIONAL SECTION:
ipaserver.linux.adexample.com.
1200
NS
IN
A
192.168.2.158
On the Active Directory server, open the nslookup tool and check the corresponding SRV records.
>
>
>
>
>
nslookup
set type=srv
_ldap._tcp.adexample.com
_ldap._tcp.linux.adexample.com
quit
7. Enable DNS lookups in the Kerberos realm for the Kerberos client.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, add or set the dns_lookup_kdc value to true.
[libdefaults]
....
dns_lookup_kdc = true
8. Configure the IdM server to enable trust services.
a. Run the ipa-adtrust-install command.
T his requires the NetBIOS name of the IdM server and the password of the IdM
administrator. T hese can be passed with the script; otherwise, it prompts for them.
[[email protected] ]# ipa-adtrust-install --netbios-name=IPAEXAMPLE -a secret
Optionally, use the -U argument to run the script non-interactively.
b. T he script prompts to configure the slapi-nis plug-in. T his is a compatibility plug-in that allows
older Linux clients to work with trusted users.
Do you want to enable support for trusted domains in Schema Compatibility
plugin?
This will allow clients older than SSSD 1.9 and non-Linux clients to work
with trusted users.
Enable trusted domains support in slapi-nis? [no]: y
c. At least one user (the IdM administrator) exists when the directory is first installed. T he SID
generation task can create a SID for any existing users, to support the trust environment. T his
is a resource-intensive task; for a high-number of users, this can be run separately.
Do you want to run the ipa-sidgen task? [no]: yes
9. T o verify the IdM configuration at this point, use the Samba tools to check that the Windows-related
services are running and accessible. T he sm bclient command shows whether the domain is in
the Samba registry.
64
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
[[email protected] ~]# smbclient -L ipaserver.ipaexample.com -k
lp_load_ex: changing to config backend registry
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Sharename
Type
Comment
-----------------IPC$
IPC
IPC Service (Samba 4.0.0rc4)
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Server
Comment
--------------Workgroup
Master
---------------
T he wbinfo command shows whether the IdM domain is online.
[[email protected] ~]# wbinfo --online-status
BUILTIN : online
IPAEXAMPLE : online
10. If there are existing IdM users and groups. For existing IdM users, it is required that all users and
groups have an Active Directory-style security identifier (SID). A new ipaNTSecurityIdentifier
containing a SID can be created automatically for each entry by running a special ipa-sidgentask operation on the backend LDAP directory.
If there are no existing IdM users or groups, then this step can be skipped.
[[email protected] ]# ldapmodify -x -H ldap://ipaserver.ipaexample.com:389 -D
"cn=directory manager" -w Passwd -f
dn: cn=sidgen,cn=ipa-sidgen-task,cn=tasks,cn=config
changetype: add
objectClass: top
objectClass: extensibleObject
cn: sidgen
nsslapd-basedn: dc=ipadomain,dc=com
delay: 0
adding new entry "cn=sidgen,cn=ipa-sidgen-task,cn=tasks,cn=config"
When the task completes successfully, there will be a message in the error logs that the SID
generation task (Sidgen task) finished with a status of zero (0).
[[email protected] ]# grep "sidgen_task_thread" /var/log/dirsrv/slapd-IPALABQE/errors
[20/Jul/2012:18:17:16 +051800] sidgen_task_thread - [file ipa_sidgen_task.c,
line 191]: Sidgen task starts ...
[20/Jul/2012:18:17:16 +051800] sidgen_task_thread - [file ipa_sidgen_task.c,
line 196]: Sidgen task finished [0].
11. Create a trust agreement for the Active Directory domain and the IdM domain. T his command
requires the Active Directory domain and the credentials of an administrative user to use to connect
to the domain.
ipa trust-add --type=type ad_domain_name --admin ad_admin_username --password
For example:
65
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# ipa trust-add --type=ad adexample.com --admin
Administrator --password
Active directory domain administrator's password:
-----------------------------------------------------Added Active Directory trust for realm "adexample.com"
-----------------------------------------------------Realm name: adexample.com
Domain NetBIOS name: ADEXAMPLE
Domain Security Identifier: S-1-5-21-1689615952-3716327440-3249090444
Trust direction: Two-way trust
Trust type: Active Directory domain
Trust status: Established and verified
12. Request a ticket for an IdM user to check the Kerberos configuration, and then check that that user
can request service tickets.
[[email protected] ~]# kinit jsmith
First, request service tickets for services within the IdM domain.
[[email protected] ]# kvno host/[email protected]
T hen, request service tickets for services within the Active Directory domain.
[[email protected] ]# kvno cifs/[email protected]
If the Active Directory service ticket is successfully granted, then there will be a cross-realm T GT
listed with all of the other requested tickets. T his will have the name
krbtgt/[email protected]
[[email protected] ]# klist
Ticket cache: FILE:/tmp/krb5cc_0
Default principal: [email protected]
Valid starting
06/15/12 12:13:04
06/15/12 12:13:13
06/15/12 12:13:23
06/15/12 12:14:58
Expires
06/16/12
06/16/12
06/16/12
06/15/12
Service principal
12:12:55 krbtgt/[email protected]
12:12:55 host/[email protected]
12:12:55 krbtgt/[email protected]
22:14:58 cifs/[email protected]
NOTE
T his ticket is requested as an IdM user because Kerberos realm mappings are not yet
configured to allow Active Directory users to use Kerberos authentication to the realm.
13. Configure realm mapping in the Kerberos configuration. T his allows Kerberos authentication for
Active Directory users.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, enable DNS lookups in the Kerberos realm.
[libdefaults]
66
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
....
dns_lookup_kdc = true
c. In the [realm s] section, identify the IdM realm by name, and then add two auth_to_local
lines to define the Kerberos principal name mapping. One rule should have a value of
DEFAULT , for standard Unix usernames, and the other should include a rule which maps
different Active Directory username formats and the specific Active Directory domain. For
example, this rule allows usernames in the format [email protected],
[email protected][.something], or [email protected][.something]; the last two
expressions allow upper-case or lower-case domain names, since Kerberos is casesensitive.
[realms]
IDM = {
....
auth_to_local = RULE:[1:[email protected]$0](^.*@ADDOMAIN$)s/@ADDOMAIN/@addomain/
auth_to_local = DEFAULT
}
Alternatively, the username mapping can be used by creating .k5login files for each user.
T his is covered in Section 5.8.2, “Using SSH Without Passwords”.
d. Restart the KDC service.
[[email protected] ~]# service krb5kdc restart
14. Configure domain mapping in SSSD.
a. Open the /etc/sssd/sssd.conf.
[[email protected] ]# vim /etc/sssd/sssd.conf
b. In the [sssd] section, add pac to the services list to enable the SSSD service to request
and use Kerberos tickets with PAC data.
[sssd]
services = nss, pam, ssh, pac
....
c. In the IdM domain section, add the subdomains_provider parameter to explicitly enable
SSSD to refer from the configured IdM domain to any domains trusted by that domain.
[domain/ipa.lan]
cache_credentials = True
krb5_store_password_if_offline = True
ipa_domain = example2b.com
id_provider = ipa
auth_provider = ipa
access_provider = ipa
ipa_hostname = ipa2.example.com
chpass_provider = ipa
ipa_server = ipa2.example.com
ldap_tls_cacert = /etc/ipa/ca.crt
subdomains_provider = ipa
T he trusted Active Directory domain is not explicitly defined in the SSSD configuration. T he
IdM domain is automatically created in the SSSD configuration when the client is installed;
67
Red Hat Enterprise Linux 7 Windows Integration Guide
adding this line makes it possible to use the existing configuration.
d. Save the changes to the sssd.conf file.
e. Restart SSSD.
[[email protected] ]# systemctl restart sssd.service
15. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
16. Restart the Windows firewall.
5.3.2. Setting up Trust with IdM and Active Directory in Different DNS Domains
T he central purpose of a trust is to create a relationship between Kerberos realms and DNS domains. T he
Kerberos configuration is fairly consistent, but there can be very different DNS configurations for the IdM
and Active Directory domains. Configuration Option 1: Separate DNS Domains describes the configuration
if IdM and Active Directory are in separate DNS domains.
1. Stop the Windows firewall service.
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
3. Install the required trust packages, updated Samba4 packages, and LDAP-DNS packages for IdM
DNS management.
[[email protected] ]# yum install ipa-server "*ipa-server-trust-ad" sambawinbind-clients bind-dyndb-ldap samba-client
4. Set up the IdM server to use its own, integrated DNS services (--setup-dns), its own DNS domain
(-n), and the Active Directory DNS server as a forwarder (--forwarder). For example:
[[email protected] ]# ipa-server-install --setup-dns --forwarder=addns.adserver.example.com -p secret -a secret -r IPAEXAMPLE -n ipaexample.com -hostname ipaserver.ipaexample.com -U
5. ⁠ Add the IdM server as a conditional forwarder in the Active Directory DNS configuration.
a. Open the Adm inistrative T ools menu, and select the DNS item.
b. Right-click the Conditional Forwarders item in the left column of the window.
c. Select the New Conditional Forwarder... button.
d. Enter the DNS domain name of the IdM domain and the IP address of the IdM DNS server.
e. Save the new forwarder.
Alternatively, use the dnscm d command-line utility to add the forwarder entry:
> dnscmd 127.0.0.1 /ZoneAdd IPAEXAMPLE.COM /Forwarder 255.255.255.0
68
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
6. Check the SRV records for both domains from both servers.
On the IdM server, use the dig SRV command to list the records for the Active Directory domain
and the IdM domain.
[[email protected] ~]# dig SRV _ldap._tcp.adexample.com
;; ANSWER SECTION:
_ldap._tcp.adexample.com. 600
IN
SRV
0 100 389
adserver.adexample.com.
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
[[email protected] ~]# dig SRV _ldap._tcp.ipaexample.com
;; ANSWER SECTION:
_ldap._tcp.ipaexample.com. 86400
IN
SRV
0 100 389
ipaserver.ipaexample.com.
;; AUTHORITY SECTION:
ipaexample.com.
86400
IN
NS
ipaserver.ipaexample.com.
;; ADDITIONAL SECTION:
ipaserver.ipaexample.com.
1200
IN
A
192.168.2.158
On the Active Directory server, open the nslookup tool and check the corresponding SRV records.
>
>
>
>
>
nslookup
set type=srv
_ldap._tcp.adexample.com
_ldap._tcp.ipaexample.com
quit
7. Enable DNS lookups in the Kerberos realm for the Kerberos client.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, add or set the dns_lookup_kdc value to true.
[libdefaults]
....
dns_lookup_kdc = true
8. Configure the IdM server to enable trust services.
a. Run the ipa-adtrust-install command.
T his requires the NetBIOS name of the IdM server and the password of the IdM
administrator. T hese can be passed with the script; otherwise, it prompts for them.
[[email protected] ]# ipa-adtrust-install --netbios-name=IPAEXAMPLE -a secret
Optionally, use the -U argument to run the script non-interactively.
b. T he script prompts to configure the slapi-nis plug-in. T his is a compatibility plug-in that allows
older Linux clients to work with trusted users.
Do you want to enable support for trusted domains in Schema Compatibility
69
Red Hat Enterprise Linux 7 Windows Integration Guide
plugin?
This will allow clients older than SSSD 1.9 and non-Linux clients to work
with trusted users.
Enable trusted domains support in slapi-nis? [no]: y
c. At least one user (the IdM administrator) exists when the directory is first installed. T he SID
generation task can create a SID for any existing users, to support the trust environment. T his
is a resource-intensive task; for a high-number of users, this can be run separately.
Do you want to run the ipa-sidgen task? [no]: yes
9. T o verify the IdM configuration at this point, use the Samba tools to check that the Windows-related
services are running and accessible. T he sm bclient command shows whether the domain is in
the Samba registry.
[[email protected] ~]# smbclient -L ipaserver.ipaexample.com -k
lp_load_ex: changing to config backend registry
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Sharename
Type
Comment
-----------------IPC$
IPC
IPC Service (Samba 4.0.0rc4)
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Server
Comment
--------------Workgroup
Master
---------------
T he wbinfo command shows whether the IdM domain is online.
[[email protected] ~]# wbinfo --online-status
BUILTIN : online
IPAEXAMPLE : online
10. Create a trust agreement for the Active Directory domain and the IdM domain. T his command
requires the Active Directory domain and the credentials of an administrative user to use to connect
to the domain.
ipa trust-add --type=type ad_domain_name --admin ad_admin_username --password
For example:
[[email protected] ~]# ipa trust-add --type=ad adexample.com --admin
Administrator --password
Active directory domain administrator's password:
-----------------------------------------------------Added Active Directory trust for realm "adexample.com"
-----------------------------------------------------Realm name: adexample.com
Domain NetBIOS name: ADEXAMPLE
Domain Security Identifier: S-1-5-21-1689615952-3716327440-3249090444
Trust direction: Two-way trust
Trust type: Active Directory domain
Trust status: Established and verified
11. Request a ticket for an IdM user to check the Kerberos configuration, and then check that that user
can request service tickets.
70
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
[[email protected] ~]# kinit jsmith
First, request service tickets for services within the IdM domain.
[[email protected] ]# kvno host/[email protected]
T hen, request service tickets for services within the Active Directory domain.
[[email protected] ]# kvno cifs/[email protected]
If the Active Directory service ticket is successfully granted, then there will be a cross-realm T GT
listed with all of the other requested tickets. T his will have the name
krbtgt/[email protected]
[[email protected] ]# klist
Ticket cache: FILE:/tmp/krb5cc_0
Default principal: [email protected]
Valid starting
06/15/12 12:13:04
06/15/12 12:13:13
06/15/12 12:13:23
06/15/12 12:14:58
Expires
06/16/12
06/16/12
06/16/12
06/15/12
Service principal
12:12:55 krbtgt/[email protected]
12:12:55 host/[email protected]
12:12:55 krbtgt/[email protected]
22:14:58 cifs/[email protected]
NOTE
T his ticket is requested as an IdM user because Kerberos realm mappings are not yet
configured to allow Active Directory users to use Kerberos authentication to the realm.
12. Configure realm mapping in the Kerberos configuration. T his allows Kerberos authentication for
Active Directory users.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, enable DNS lookups in the Kerberos realm.
[libdefaults]
....
dns_lookup_kdc = true
c. In the [realm s] section, identify the IdM realm by name, and then add two auth_to_local
lines to define the Kerberos principal name mapping. One rule should have a value of
DEFAULT , for standard Unix usernames, and the other should include a rule which maps
different Active Directory username formats and the specific Active Directory domain. For
example, this rule allows usernames in the format [email protected],
[email protected][.something], or [email protected][.something]; the last two
expressions allow upper-case or lower-case domain names, since Kerberos is casesensitive.
71
Red Hat Enterprise Linux 7 Windows Integration Guide
[realms]
IDM = {
....
auth_to_local = RULE:[1:[email protected]$0](^.*@ADDOMAIN$)s/@ADDOMAIN/@addomain/
auth_to_local = DEFAULT
}
d. Restart the KDC service.
[[email protected] ~]# systemctl restart krb5kdc.service
13. Configure domain mapping in SSSD.
a. Open the /etc/sssd/sssd.conf.
[[email protected] ]# vim /etc/sssd/sssd.conf
b. In the [sssd] section, add pac to the services list to enable the SSSD service to request
and use Kerberos tickets with PAC data.
[sssd]
services = nss, pam, ssh, pac
....
c. In the IdM domain section, add the subdomains_provider parameter to explicitly enable
SSSD to refer from the configured IdM domain to any domains trusted by that domain.
[domain/ipa.lan]
cache_credentials = True
krb5_store_password_if_offline = True
ipa_domain = example2b.com
id_provider = ipa
auth_provider = ipa
access_provider = ipa
ipa_hostname = ipa2.example.com
chpass_provider = ipa
ipa_server = ipa2.example.com
ldap_tls_cacert = /etc/ipa/ca.crt
subdomains_provider = ipa
T he trusted Active Directory domain is not explicitly defined in the SSSD configuration. T he
IdM domain is automatically created in the SSSD configuration when the client is installed;
adding this line makes it possible to use the existing configuration.
d. Save the changes to the sssd.conf file.
e. Restart SSSD.
[[email protected] ]# systemctl restart sssd.service
14. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
15. Restart the Windows firewall.
72
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
5.3.3. Setting up Trust with a Shared Secret
T rusts within Active Directory can be configured with a shared secret, a password that is known to trusted
peers and can be used by other domains to join the trust. In Active Directory, this is stored as a trusted
domain object within the trust configuration. T he secret is updated periodically.
A trust can be created in IdM using a shared secret rather than the Active Directory administrator
credentials, but this requires additional configuration in Active Directory to create the shared secret.
Additionally, the trust must be validated manually on the Active Directory side and then the Active Directory
topology must be manually loaded on the IdM side to complete the configuration.
1. Stop the Windows firewall service.
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
3. Install the required trust packages, updated Samba4 packages, and LDAP-DNS packages for IdM
DNS management.
[[email protected] ]# yum install ipa-server "*ipa-server-trust-ad" sambawinbind-clients bind-dyndb-ldap samba-client
4. Set up the IdM server. T his example configures its integrated DNS services (--setup-dns), its own
DNS domain (-n), and the Active Directory DNS server as a forwarder (--forwarder). T he value
of the -n and --hostnam e arguments is slightly different, depending on the planned DNS
configuration. -n gives the name of the IdM domain, and --hostnam e gives the machine name.
T his example shows the IdM domain as a subdomain of the Active Directory domain.
[[email protected] ]# ipa-server-install --setup-dns --forwarder=2555.255.255.255
-p secret -a secret -r IPAEXAMPLE -n linux.adexample.com --hostname
ipaserver.linux.adexample.com -U
5. Set up the DNS realms. If IdM will be a subdomain of Active Directory, then follow step 5 in
Section 5.3.1, “Setting up T rust with IdM as a DNS Subdomain of Active Directory”. If IdM will host its
own domain, then follow step 5 in Section 5.3.2, “Setting up T rust with IdM and Active Directory in
Different DNS Domains”.
6. Enable DNS lookups in the Kerberos realm for the Kerberos client.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, add or set the dns_lookup_kdc value to true.
[libdefaults]
....
dns_lookup_kdc = true
7. Set up the external trust on Active Directory. T his sets the trust password, which is the shared
secret used in configuring the trust on IdM.
An external trust is configured in the Active Directory Dom ains and T rusts console. Select
the appropriate domain, and create a new trust. T hese are the settings to use:
73
Red Hat Enterprise Linux 7 Windows Integration Guide
T he T rust T ype is Realm .
T he T ransitivity of T rust can be either transitive or non-transitive.
T he Direction of T rust is One-way: incom ing.
T he Sides of T rust is T his dom ain only.
T he T rust Password can be anything. T his must be used when configuring the trust in IdM.
T he full instructions are in the Microsoft T echNet documentation.
8. Configure the IdM server to enable trust services.
a. Run the ipa-adtrust-install command.
T his requires the NetBIOS name of the IdM server and the password of the IdM
administrator. T hese can be passed with the script; otherwise, it prompts for them.
[[email protected] ]# ipa-adtrust-install --netbios-name=IPAEXAMPLE -a secret
Optionally, use the -U argument to run the script non-interactively.
b. T he script prompts to configure the slapi-nis plug-in. T his is a compatibility plug-in that allows
older Linux clients to work with trusted users.
Do you want to enable support for trusted domains in Schema Compatibility
plugin?
This will allow clients older than SSSD 1.9 and non-Linux clients to work
with trusted users.
Enable trusted domains support in slapi-nis? [no]: y
c. At least one user (the IdM administrator) exists when the directory is first installed. T he SID
generation task can create a SID for any existing users, to support the trust environment. T his
is a resource-intensive task; for a high-number of users, this can be run separately.
Do you want to run the ipa-sidgen task? [no]: yes
9. T o verify the IdM configuration at this point, use the Samba tools to check that the Windows-related
services are running and accessible. T he sm bclient command shows whether the domain is in
the Samba registry.
[[email protected] ~]# smbclient -L ipaserver.ipaexample.com -k
lp_load_ex: changing to config backend registry
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Sharename
Type
Comment
-----------------IPC$
IPC
IPC Service (Samba 4.0.0rc4)
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Server
Comment
--------------Workgroup
Master
---------------
T he wbinfo command shows whether the IdM domain is online.
[[email protected] ~]# wbinfo --online-status
74
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
BUILTIN : online
IPAEXAMPLE : online
10. Create a trust agreement for the Active Directory domain and the IdM domain, specifying the quires
the Active Directory domain and the credentials of an administrative user to use to connect to the
domain.
ipa trust-add --type=ad ad_domain_name --trust-secret
For example:
[[email protected] ~]# ipa trust-add --type=ad adexample.com --trust-secret
Shared secret for the trust:
-------------------------------------------------Added Active Directory trust for realm "adexample.com"
-------------------------------------------------Realm name: adexample.com
Domain NetBIOS name: ADEXAMPLE
Domain Security Identifier: S-1-5-21-1910160501-511572375-3625658879
SID blacklist incoming: S-1-0, S-1-1, S-1-2, S-1-3, S-1-5-1, S-1-5-2, S-15-3, S-1-5-4, S-1-5-5, S-1-5-6, S-1-5-7, S-1-5-8, S-1-5-9, S-1-5-10, S-1-511, S-1-5-12, S-1-5-13, S-1-5-14, S-1-5-15, S-1-5-16,
S-1-5-17, S-1-5-18, S-1-5-19, S-1-5-20
SID blacklist outgoing: S-1-0, S-1-1, S-1-2, S-1-3, S-1-5-1, S-1-5-2, S-15-3, S-1-5-4, S-1-5-5, S-1-5-6, S-1-5-7, S-1-5-8, S-1-5-9, S-1-5-10, S-1-511, S-1-5-12, S-1-5-13, S-1-5-14, S-1-5-15, S-1-5-16,
S-1-5-17, S-1-5-18, S-1-5-19, S-1-5-20
Trust direction: Two-way trust
Trust type: Active Directory domain
Trust status: Waiting for confirmation by remote side
11. On the Active Directory server, validate the new trust. T his is done in the Dom ains and T rusts
console.
12. On the IdM server, fetch the Active Directory domain topology.
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa trust-fetch-domains adexample.com
-------------------------------------------List of trust domains successfully refreshed
-------------------------------------------Realm name: test.adexample.com
Domain NetBIOS name: TEST
Domain Security Identifier: S-1-5-21-91314187-2404433721-1858927112
---------------------------Number of entries returned 1
----------------------------
13. Request a ticket for an IdM user to check the Kerberos configuration, and then check that that user
can request service tickets.
[[email protected] ~]# kinit jsmith
First, request service tickets for services within the IdM domain.
[[email protected] ]# kvno host/[email protected]
T hen, request service tickets for services within the Active Directory domain.
75
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ]# kvno cifs/[email protected]
If the Active Directory service ticket is successfully granted, then there will be a cross-realm T GT
listed with all of the other requested tickets. T his will have the name
krbtgt/[email protected]
[[email protected] ]# klist
Ticket cache: FILE:/tmp/krb5cc_0
Default principal: [email protected]
Valid starting
06/15/12 12:13:04
06/15/12 12:13:13
06/15/12 12:13:23
06/15/12 12:14:58
Expires
06/16/12
06/16/12
06/16/12
06/15/12
Service principal
12:12:55 krbtgt/[email protected]
12:12:55 host/[email protected]
12:12:55 krbtgt/[email protected]
22:14:58 cifs/[email protected]
NOTE
T his ticket is requested as an IdM user because Kerberos realm mappings are not yet
configured to allow Active Directory users to use Kerberos authentication to the realm.
14. Configure realm mapping in the Kerberos configuration. T his allows Kerberos authentication for
Active Directory users.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, enable DNS lookups in the Kerberos realm.
[libdefaults]
....
dns_lookup_kdc = true
c. In the [realm s] section, identify the IdM realm by name, and then add two auth_to_local
lines to define the Kerberos principal name mapping. One rule should have a value of
DEFAULT , for standard Unix usernames, and the other should include a rule which maps
different Active Directory username formats and the specific Active Directory domain. For
example, this rule allows usernames in the format [email protected],
[email protected][.something], or [email protected][.something]; the last two
expressions allow upper-case or lower-case domain names, since Kerberos is casesensitive.
[realms]
IDM = {
....
auth_to_local = RULE:[1:[email protected]$0](^.*@ADDOMAIN$)s/@ADDOMAIN/@addomain/
auth_to_local = DEFAULT
}
Alternatively, the username mapping can be used by creating .k5login files for each user.
T his is covered in Section 5.8.2, “Using SSH Without Passwords”.
d. Restart the KDC service.
76
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
[[email protected] ~]# systemctl restart krb5kdc.service
15. Configure domain mapping in SSSD.
a. Open the /etc/sssd/sssd.conf.
[[email protected] ]# vim /etc/sssd/sssd.conf
b. In the [sssd] section, add pac to the services list to enable the SSSD service to request
and use Kerberos tickets with PAC data.
[sssd]
services = nss, pam, ssh, pac
....
c. In the IdM domain section, add the subdomains_provider parameter to explicitly enable
SSSD to refer from the configured IdM domain to any domains trusted by that domain.
[domain/ipa.lan]
cache_credentials = True
krb5_store_password_if_offline = True
ipa_domain = example2b.com
id_provider = ipa
auth_provider = ipa
access_provider = ipa
ipa_hostname = ipa2.example.com
chpass_provider = ipa
ipa_server = ipa2.example.com
ldap_tls_cacert = /etc/ipa/ca.crt
subdomains_provider = ipa
T he trusted Active Directory domain is not explicitly defined in the SSSD configuration. T he
IdM domain is automatically created in the SSSD configuration when the client is installed;
adding this line makes it possible to use the existing configuration.
d. Save the changes to the sssd.conf file.
e. Restart SSSD.
[[email protected] ]# systemctl restart sssd.service
16. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
17. Restart the Windows firewall.
5.3.4. Creating Trusts on an Existing IdM Instance
When establishing a trust on a new IdM instance, certain configurations for both the IdM server and entries
within its domain are set from the beginning. However, when a trust is configured for an existing IdM
instance, at least two things need to be done: the DNS configuration needs to be set for the Active
Directory domain and all existing IdM users and groups need to be assigned Active Directory-style SIDs.
1. Stop the Windows firewall service.
77
Red Hat Enterprise Linux 7 Windows Integration Guide
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
3. Install the required trust packages.
[[email protected] ]# yum install "*ipa-server-trust-ad" samba-winbind-clients
samba-client
4. Add the Active Directory DNS domain as a forwarder for the IdM server.
[[email protected] ]# ipa dnsconfig-mod --forwarder=255.255.255.255 --forwardpolicy=first
Using a first policy means that queries are sent to the forwarder first and then to the local nam ed
process. Alternatively, this can be set to only, so that only the DNS forwarder is queried, never
nam ed.
5. Set up the DNS realms. If IdM will be a subdomain of Active Directory, then follow step 5 in
Section 5.3.1, “Setting up T rust with IdM as a DNS Subdomain of Active Directory”. If IdM will host its
own domain, then follow step 5 in Section 5.3.2, “Setting up T rust with IdM and Active Directory in
Different DNS Domains”.
6. Check the SRV records for both domains from both servers.
On the IdM server, use the dig SRV command to list the records for the Active Directory domain
and the IdM domain.
[[email protected] ~]# dig SRV _ldap._tcp.adexample.com
;; ANSWER SECTION:
_ldap._tcp.adexample.com. 600
IN
SRV
0 100 389
adserver.adexample.com.
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
;; ADDITIONAL SECTION:
adserver.adexample.com.
3600
IN
A
192.168.2.161
[[email protected] ~]# dig SRV _ldap._tcp.linux.adexample.com
;; ANSWER SECTION:
_ldap._tcp.linux.adexample.com. 86400
IN
SRV
0 100 389
ipaserver.linux.adexample.com.
;; AUTHORITY SECTION:
linux.adexample.com.
86400
IN
NS
ipaserver.linux.adexample.com.
;; ADDITIONAL SECTION:
ipaserver.linux.adexample.com.
1200
IN
A
192.168.2.158
On the Active Directory server, open the nslookup tool and check the corresponding SRV records.
>
>
>
>
>
nslookup
set type=srv
_ldap._tcp.adexample.com
_ldap._tcp.linux.adexample.com
quit
7. Enable DNS lookups in the Kerberos realm for the Kerberos client.
78
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, add or set the dns_lookup_kdc value to true.
[libdefaults]
....
dns_lookup_kdc = true
8. Configure the IdM server to enable trust services.
a. Run the ipa-adtrust-install command.
T his requires the NetBIOS name of the IdM server and the password of the IdM
administrator. T hese can be passed with the script; otherwise, it prompts for them.
[[email protected] ]# ipa-adtrust-install --netbios-name=IPAEXAMPLE -a secret
Optionally, use the -U argument to run the script non-interactively.
b. T he script prompts to configure the slapi-nis plug-in. T his is a compatibility plug-in that allows
older Linux clients to work with trusted users.
Do you want to enable support for trusted domains in Schema Compatibility
plugin?
This will allow clients older than SSSD 1.9 and non-Linux clients to work
with trusted users.
Enable trusted domains support in slapi-nis? [no]: y
c. At least one user (the IdM administrator) exists when the directory is first installed. T he SID
generation task can create a SID for any existing users, to support the trust environment. T his
is a resource-intensive task; for a high-number of users, this can be run separately.
Select no (the default).
Do you want to run the ipa-sidgen task? [no]:
9. T o verify the IdM configuration at this point, use the Samba tools to check that the Windows-related
services are running and accessible. T he sm bclient command shows whether the domain is in
the Samba registry.
[[email protected] ~]# smbclient -L ipaserver.ipaexample.com -k
lp_load_ex: changing to config backend registry
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Sharename
Type
Comment
-----------------IPC$
IPC
IPC Service (Samba 4.0.0rc4)
Domain=[IPAEXAMPLE] OS=[Unix] Server=[Samba 4.0.0rc4]
Server
Comment
--------------Workgroup
Master
---------------
T he wbinfo command shows whether the IdM domain is online.
79
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# wbinfo --online-status
BUILTIN : online
IPAEXAMPLE : online
10. Add a new ipaNTSecurityIdentifier attribute, containing a SID, automatically for each entry by
running a special ipa-sidgen-task operation on the backend LDAP directory.
[[email protected] ]# ldapmodify -x -H ldap://ipaserver.ipaexample.com:389 -D
"cn=directory manager" -w Passwd -f
dn: cn=sidgen,cn=ipa-sidgen-task,cn=tasks,cn=config
changetype: add
objectClass: top
objectClass: extensibleObject
cn: sidgen
nsslapd-basedn: dc=ipadomain,dc=com
delay: 0
adding new entry "cn=sidgen,cn=ipa-sidgen-task,cn=tasks,cn=config"
When the task completes successfully, there will be a message in the error logs that the SID
generation task (Sidgen task) finished with a status of zero (0).
[[email protected] ]# grep "sidgen_task_thread" /var/log/dirsrv/slapd-IPALABQE/errors
[20/Jul/2012:18:17:16 +051800] sidgen_task_thread - [file ipa_sidgen_task.c,
line 191]: Sidgen task starts ...
[20/Jul/2012:18:17:16 +051800] sidgen_task_thread - [file ipa_sidgen_task.c,
line 196]: Sidgen task finished [0].
11. Create a trust agreement for the Active Directory domain and the IdM domain. T his command
requires the Active Directory domain and the credentials of an administrative user to use to connect
to the domain.
ipa trust-add --type=type ad_domain_name --admin ad_admin_username --password
For example:
[[email protected] ~]# ipa trust-add --type=ad adexample.com --admin
Administrator --password
Active directory domain administrator's password:
-----------------------------------------------------Added Active Directory trust for realm "adexample.com"
-----------------------------------------------------Realm name: adexample.com
Domain NetBIOS name: ADEXAMPLE
Domain Security Identifier: S-1-5-21-1689615952-3716327440-3249090444
Trust direction: Two-way trust
Trust type: Active Directory domain
Trust status: Established and verified
12. Request a ticket for an IdM user to check the Kerberos configuration, and then check that that user
can request service tickets.
[[email protected] ~]# kinit jsmith
First, request service tickets for services within the IdM domain.
80
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
[[email protected] ]# kvno host/[email protected]
T hen, request service tickets for services within the Active Directory domain.
[[email protected] ]# kvno cifs/[email protected]
If the Active Directory service ticket is successfully granted, then there will be a cross-realm T GT
listed with all of the other requested tickets. T his will have the name
krbtgt/[email protected]
[[email protected] ]# klist
Ticket cache: FILE:/tmp/krb5cc_0
Default principal: [email protected]
Valid starting
06/15/12 12:13:04
06/15/12 12:13:13
06/15/12 12:13:23
06/15/12 12:14:58
Expires
06/16/12
06/16/12
06/16/12
06/15/12
Service principal
12:12:55 krbtgt/[email protected]
12:12:55 host/[email protected]
12:12:55 krbtgt/[email protected]
22:14:58 cifs/[email protected]
NOTE
T his ticket is requested as an IdM user because Kerberos realm mappings are not yet
configured to allow Active Directory users to use Kerberos authentication to the realm.
13. Configure realm mapping in the Kerberos configuration. T his allows Kerberos authentication for
Active Directory users.
a. Open the /etc/krb5.conf configuration file.
[[email protected] ]# vim /etc/krb5.conf
b. In the [libdefaults] section, enable DNS lookups in the Kerberos realm.
[libdefaults]
....
dns_lookup_kdc = true
c. In the [realm s] section, identify the IdM realm by name, and then add two auth_to_local
lines to define the Kerberos principal name mapping. One rule should have a value of
DEFAULT , for standard Unix usernames, and the other should include a rule which maps
different Active Directory username formats and the specific Active Directory domain. For
example, this rule allows usernames in the format [email protected],
[email protected][.something], or [email protected][.something]; the last two
expressions allow upper-case or lower-case domain names, since Kerberos is casesensitive.
[realms]
IDM = {
....
auth_to_local = RULE:[1:[email protected]$0](^.*@ADDOMAIN$)s/@ADDOMAIN/@addomain/
auth_to_local = DEFAULT
}
81
Red Hat Enterprise Linux 7 Windows Integration Guide
Alternatively, the username mapping can be used by creating .k5login files for each user.
T his is covered in Section 5.8.2, “Using SSH Without Passwords”.
d. Restart the KDC service.
[[email protected] ~]# service krb5kdc restart
14. Configure domain mapping in SSSD.
a. Open the /etc/sssd/sssd.conf.
[[email protected] ]# vim /etc/sssd/sssd.conf
b. In the [sssd] section, add pac to the services list to enable the SSSD service to request
and use Kerberos tickets with PAC data.
[sssd]
services = nss, pam, ssh, pac
....
c. In the IdM domain section, add the subdomains_provider parameter to explicitly enable
SSSD to refer from the configured IdM domain to any domains trusted by that domain.
[domain/ipa.lan]
cache_credentials = True
krb5_store_password_if_offline = True
ipa_domain = example2b.com
id_provider = ipa
auth_provider = ipa
access_provider = ipa
ipa_hostname = ipa2.example.com
chpass_provider = ipa
ipa_server = ipa2.example.com
ldap_tls_cacert = /etc/ipa/ca.crt
subdomains_provider = ipa
T he trusted Active Directory domain is not explicitly defined in the SSSD configuration. T he
IdM domain is automatically created in the SSSD configuration when the client is installed;
adding this line makes it possible to use the existing configuration.
d. Save the changes to the sssd.conf file.
e. Restart SSSD.
[[email protected] ]# systemctl restart sssd.service
15. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
16. Restart the Windows firewall.
5.3.5. Adding a Second Trust
82
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
Much of the configuration for the first trust relates to general configuration for IdM to support trusts:
installing packages, configuring SIDs for users, and enabling domain support in SSSD and Kerberos. After
that, the process is much simpler, adding a trust requires updating the domain configuration for the new
DNS domain and adding another trust agreement.
1. Stop the Windows firewall service.
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
3. Add the Active Directory server as a forwarder for IdM.
[[email protected] ]# ipa dnsconfig-mod --forwarder=255.255.255.255 --forwardpolicy=first
Using a first policy means that queries are sent to the forwarder first and then to the local nam ed
process. Alternatively, this can be set to only, so that only the DNS forwarder is queried, never
nam ed.
4. Set up the DNS realms. If IdM will be a subdomain of Active Directory, then follow step 5 in
Section 5.3.1, “Setting up T rust with IdM as a DNS Subdomain of Active Directory”. If IdM will host its
own domain, then follow step 5 in Section 5.3.2, “Setting up T rust with IdM and Active Directory in
Different DNS Domains”.
5. Create a trust agreement for the Active Directory domain and the IdM domain.
[[email protected] ~]# ipa trust-add --type=ad adexample.com --admin
Administrator --password
Active directory domain administrator's password:
-----------------------------------------------------Added Active Directory trust for realm "adexample.com"
-----------------------------------------------------...
6. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
7. Restart the Windows firewall.
5.3.6. Adding a Trust in the Web UI
Much of the initial trust configuration is easiest to perform in the command-line, since it involved editing
configuration files and installing packages. However, the actual operation to add the trust agreement can
be done in the IdM UI; once much of the initial configuration is set, this can be an easy way to add
additional trusts.
NOTE
T his procedure shows how to add an additional trust. It is also possible to create an initial trust in
the web UI, but those other steps have been excluded to focus on using the UI to add the trust
configuration.
1. Stop the Windows firewall service.
83
Red Hat Enterprise Linux 7 Windows Integration Guide
2. Stop firewalld on the IdM server.
[[email protected] ]# systemctl stop firewalld.service
3. Set up the DNS realms. If IdM will be a subdomain of Active Directory, then follow step 5 in
Section 5.3.1, “Setting up T rust with IdM as a DNS Subdomain of Active Directory”. If IdM will host its
own domain, then follow step 5 in Section 5.3.2, “Setting up T rust with IdM and Active Directory in
Different DNS Domains”.
4. Create a trust agreement for the Active Directory domain and the IdM domain.
a. Open the IdM web UI.
https://ipaserver.example.com
b. Open the IPA Server main tab, and then select the T rusts subtab.
c. In the T rusts subtab, click the Add link to open the new trust wizard.
d. Fill in the required information about the trust. T his includes the Active Directory domain name
and the credentials (either the Active Directory administrator's username and password or a
trusted password).
T he base ID (the POSIX ID starting ID) and range are IdM-specific configuration. If these are
not set manually, then they are autocalculated.
e. Click the Add button to save the new trust.
5. Restart the firewalld services on the IdM server.
[[email protected] ]# systemctl start firewalld.service
6. Restart the Windows firewall.
5.4. Creating IdM Groups for Active Directory Users
User groups are required to set access permissions, host-based access control, sudo rules, and other
controls on IdM users. T hese groups are what grant access to IdM domain resources, as well as
restricting access.
84
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
As described in Section 5.1.2, “Active Directory Principles, Security Objects, and T rust”, Active Directory
users are added to the IdM domain in a kind of daisy chain. T hey are to an IdM external group (meaning, a
non-POSIX group), and then that external group is added to a local POSIX group as a member. T he IdM
POSIX group can then be used for user/role management of Active Directory users.
TIP
It is also possible to add Active Directory user groups as members to IdM external groups. T his
may make it easier to define policies for Windows users, by keeping the user and group
management within a single realm (Active Directory).
1. Optional. Create or select the group in the Active Directory domain to use to manage Active
Directory users in the IdM realm. (Multiple groups can be used and added to different groups on the
IdM side.)
2. Create an external group in the IdM domain for the Active Directory users. Using the --external
argument indicates that this group will contain members from outside the IdM domain. For example:
[[email protected] ~]# ipa group-add --desc='AD users external map'
ad_users_external --external
------------------------------Added group "ad_users_external"
------------------------------Group name: ad_users_external
Description: AD users external map
3. Create the POSIX group for actually administering the IdM policies.
[[email protected] ~]# ipa group-add --desc='AD users' ad_users
---------------------Added group "ad_users"
---------------------Group name: ad_users
Description: AD users
GID: 129600004
4. Add the Active Directory users or groups to the IdM external group as an external member. T he
Active Directory member is identified by its fully-qualified name, such as DOMAIN\group_name or
DOMAIN\username. T he Active Directory identity is then mapped to the Active Directory SID for the
user or group.
For example, for an Active Directory group:
[[email protected] ~]# ipa group-add-member ad_users_external --external
"AD\Domain Users"
[member user]:
[member group]:
Group name: ad_users_external
Description: AD users external map
External member: S-1-5-21-3655990580-1375374850-1633065477-513
SID_DOM_GROUP (2)
------------------------Number of members added 1
-------------------------
5. Add the external IdM group to the POSIX IdM group as a member. For example:
85
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# ipa group-add-member ad_users --groups ad_users_external
Group name: ad_users
Description: AD users
GID: 129600004
Member groups: ad_users_external
------------------------Number of members added 1
-------------------------
5.5. Maintaining Trusts
T here are several layers to the trust configuration. T here is the immediate trust agreement with IdM and its
peer Active Directory. T here is also a substantial backend configuration in IdM. When IdM is configured to
support trusts, it creates a number of different kinds of configuration areas:
Global trust configuration that is used to identify IdM within Windows domains (such as a SID)
Identified DNS domains in Active Directory, which are pulled into the IdM DNS zone configuration (realm
domains)
T he Kerberos trust configuration (the individual trust agreements, in trust domains)
Assigned available ID ranges, per IdM server, to use to assign UID and GID numbers to Windows
users as they enter the IdM domain
5.5.1. Editing the Global Trust Configuration
When the ipa-adtrust-install is run, it automatically configures background information for the IdM
domain which is required to create a trust with the Active Directory domain. Even for external trusts, the
Active Directory domain assumes that its trusted peer has certain configuration attributes, such as a
security ID and domain ID. T he attributes are created for the IdM server, so that it is Active Directorycompliant.
T he global trust configuration contains five attributes:
A Windows-style security ID
A domain GUID
A Kerberos domain name
T he default group to which to add Windows users
Only some of those attributes (the NetBIOS name and default group) can be edited. T he GUID and SID are
autogenerated, and the Kerberos realm name is from the IdM configuration.
T he trust configuration is stored in the cn=domain,cn=ad,cn=etc,dc=exam ple,dc=com subtree.
5.5.1.1. Changing the NetBIOS Name
T he NetBIOS name is the far-left component of the domain name; this is a key identifier for the host
system of a domain controller. When IdM is enabled for trust, a NetBIOS name is set for the IdM server so
that it is compatible within an Active Directory topology. T his is configured in the ipa-adtrust-install
command. T o change it, rerun the ipa-adtrust-install command.
[[email protected] ]# ipa-adtrust-install --netbios-name=NEWBIOSNAME -a secret
86
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
T he -a option gives the IdM administrator password.
5.5.1.2. Changing the Default Group for Windows Users
IdM has a feature, automembership, which adds new users to specific groups automatically. T here is a
default automembership rule to add Windows users automatically to the Default SMB Group (a group
created as part of the IdM trust configuration). T his is a fallback group used if no other automembership
rules apply to the Windows users.
T he default group can be changed, which can be particularly useful if there are different external groups
added for Windows users (Section 5.4, “Creating IdM Groups for Active Directory Users”). T his group is
a fallback or default group which is used globally for all Windows users; other rules can be set
to apply specific groups to different Windows users, rather than using the default.
T he default group can be set using the trustconfig-m od command:
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa trustconfig-mod --fallback-primary-group="Example Windows
Group"
T his can also be modified through the IdM web UI.
1. Open the IdM web UI.
https://ipaserver.example.com
2. Open the IPA Server main tab, and then select the T rusts subtab.
3. In the Global Configuration subtab, select a new group from all of the IdM groups listed in the
Fallback primary group.
4. Click the Update link to save the new configuration.
87
Red Hat Enterprise Linux 7 Windows Integration Guide
5.5.2. Discovering, Enabling, and Disabling Trust Domains
A transitive trust means that the trust path can follow a chain of domains. If Domain A trusts Domain B, and
Domain B trusts Domain C, then Domain A implicitly trusts Domain C. T he trust it has with Domain B is
transitive — it follows the trust path to Domain C.
IdM has a trust with the root domain in a forest, and all of its subdomains and trusted domains are implicitly
included in that trust. IdM follows that topology as Windows users from anywhere in the forest attempt to
access IdM resources. Each domain and subdomain is a trust domain in the IdM trust configuration. Each
domain is stored in it own entry,
cn=subdomain,cn=trust_name,cn=ad,cn=trusts,dc=exam ple,dc=com in the trusts subtree.
IdM attempts to discover and map the full Active Directory topology when the trust is first configured,
although in some cases it is required (Section 5.3.3, “Setting up T rust with a Shared Secret”) or beneficial
to retrieve that topology manually. T hat is done with the trust-fetch-dom ains command:
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa trust-fetch-domains adexample.com
-------------------------------------------List of trust domains successfully refreshed
-------------------------------------------Realm name: test.adexample.com
Domain NetBIOS name: TEST
Domain Security Identifier: S-1-5-21-87535643-5658642561-5780864324
Realm name: users.adexample.com
Domain NetBIOS name: USERS
Domain Security Identifier: S-1-5-21-91314187-2404433721-1858927112
Realm name: prod.adexample.com
Domain NetBIOS name: PROD
Domain Security Identifier: S-1-5-21-46580863-3346886432-4578854233
---------------------------Number of entries returned 3
----------------------------
Once that topology is retrieved (thought automatic or manual discovery), individual domains and
subdomains in that topology can be enabled, disabled, or removed entirely within the IdM trust
configuration.
For example, to disallow users from a specific subdomain from using IdM resources, disable that trust
domain:
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa trustdomain-disable test.adexample.com
-----------------------------------------Disabled trust domain "test.adexample.com"
------------------------------------------
T hat trust domain can be re-enabled using the trustdom ain-enable command.
If a domain should be permanently removed from the topology, than it can be deleted from the IdM trust
configuration.
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa trustdomain-del prod.adexample.com
------------------------------------------------------------------Removed information about the trusted domain " "prod.adexample.com"
-------------------------------------------------------------------
88
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
5.5.3. Viewing and Managing DNS Realms
When a trust is created, the Active Directory DNS configuration is added to the IdM DNS configuration, with
each realm being added as a special realm domain. Each domain is stored in the cn=Realm
Dom ains,cn=ipa,cn=etc,dc=exam ple,dc=com subtree in the IdM directory.
Since these realm domains are added automatically, the DNS zones do not generally need to be added or
modified. T he list of configured realm domains can be displayed (instead of listing all DNS zones
configured in IdM) using the realm dom ains-show command.
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa realmdomains-show
Domain: ipa.example.org, ipa.example.com, example.com
If a single realm domain should be added to the configuration, this can be done with the --add-dom ain
option.
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa realmdomains-mod --add-domain=adexample.com
Domain: ipa.example.org, ipa.example.com, example.com, adexample.com
A single domain can be removed using the --del-dom ain option.
If there are multiple changes to be made to the list of domains, the list itself can be modified and replaced
using the --dom ain option.
[[email protected] ~]# ipa realmdomains-mod --domain={ipa.example.org,adexample.com}
5.5.4. Adding Ranges for UID/GID Numbers in a Transitive Trust
Windows systems treat ID numbers differently than Linux systems. When a user is created in Linux, it is
assigned a user ID number, and a private group is created for that user. T he private group UI number is
the same as the user ID number. In Linux, there is no conflict in that. On Windows, however, the security ID
is unique for every object in the domain, so there is a conflict if a user and a group have the same ID.
If the POSIX attributes (including uidNumber and gidNumber) are pulled from the global catalog in Active
Directory, then the ID numbers are unique, because they are unique within the Active Directory
environment. T his is an ipa-ad-trust-posix range type, which is set in the trust-add command when the
trust is created. Essentially, no ID validation or range is required.
However, if instead the SIDs will be generated in IdM, using SID/username mapping, then the ID ranges for
both the Windows identities and the IdM users and groups need to have unique, non-overlapping ranges
available. T his is ipa-ad-trust range type.
A unique ID range is created for each Active Directory domain automatically when it is added in a trust to
IdM. However, Active Directory and IdM can work in a transitive trust. A transitive trust is a daisy change,
where if Realm A trusts Realm B, and Realm B trusts Realms C, then Realm A also trusts Realm C. When
the trust is configured, a range is only added for the domain specified in the trust agreement. Ranges for
the transitively-trusted domains need to be added manually.
T o add an ID range, set the base ID for the POSIX range (the starting number), the starting number of the
RID (the far-right number in the SID), the size of the range, and the domain SID (since there can be multiple
domains configured for trusts).
89
Red Hat Enterprise Linux 7 Windows Integration Guide
[[email protected] ~]# kinit admin
[[email protected] ~]# ipa idrange-add --base-id=1200000 --range-size=200000 --rid-base=0
--dom-sid=S-1-5-21-123-456-789 trusted_dom_range
T he base ID is the starting POSIX ID number. T he RID is a range to add to the base ID to prevent conflicts.
If the base ID is 1200000 and the RID is 1000, then the resulting ID number is 1201000.
5.6. Verifying That IdM Machines Have Resolvable Names
As Section 5.1.4, “Different DNS-T rust Environments” explains, regardless of the DNS configuration, all
hostnames within both the Identity Management and Active Directory DNS domains must be fullyresolvable for trusted services to function reliably.
After configuring trust, verify that the Identity Management servers are resolvable in both the IdM and
Active Directory realms.
First, verify that the IdM-hosted services are resolvable from the IdM domain.
1. Run a DNS query for the Kerberos record over UDP.
[[email protected] ~]# dig +short -t SRV @10.1.1.1
_kerberos._udp.ipa.example.com.
0 100 88 ipamaster1.ipa.example.com.
2. Run a DNS query for the LDAP record over T CP.
[[email protected] ~]# dig +short -t SRV @10.1.1.1 _ldap._tcp.ipa.example.com.
0 100 389 ipamaster1.ipa.example.com.
3. Run a DNS query for the T XT record with the Kerberos realm name. T his must match the Kerberos
realm for the Identity Management servers.
[[email protected] ~]# dig +short -t TXT @10.1.1.1 _kerberos.ipa.example.com.
On the Active Directory server, verify that all of the IdM-hosted servers and services are
resolvable.
Active Directory has a utility called nslookup.exe which can query the DNS configuration.
1. Set the nslookup.exe utility to look up service records.
C:\>nslookup.exe
> set type=SRV
2. Enter the name of the service and (optionally) the IP address of the IdM name server.
> _ldap._tcp.ipa.example.com 10.1.1.1
Server:
[10.1.1.1]
Address:
10.1.1.1
_ldap._tcp.ipa.example.com
SRV service location:
priority
= 0
weight
= 100
port
= 389
svr hostname
= ipaserver.ipa.example.com
ipaserver.ipa.example.com
internet address = 10.1.1.1
90
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
3. Change the service type to T XT to check the IdM Kerberos realm configuration ⁠ [3]
> set type=TXT
4. Query the Kerberos records.
> _kerberos.ipa.example.com. 10.1.1.1
Active Directory caches the results of DNS lookups. T he current cache can be viewed by running
ipconfig /displaydns, and the cache can be deleted by running ipconfig /flushdns.
5.7. Setting PAC Types for Services
On IdM resources, if an Active Directory user requests a ticket for a service, then IdM forwards the request
to Active Directory to retrieve the user information. Access data, associated with the Active Directory group
assignments for the user, is sent back by Active Directory and embedded in the Kerberos ticket.
Group information in Active Directory is stored in a list of identifiers in each Kerberos ticket for Active
Directory users in a special data set called privileged access certificates or MS-PAC. T he group
information in the PAC has to be mapped to the Active Directory groups and then to the corresponding IdM
groups to help determine access.
POSIX systems have a similar data set called a POSIX authorization data element. PADs, like PACs,
contain group-based authorization data for a user. T he access data is returned in response to the initial
authentication request, so there is no additional cross-realm communication to retrieve group data.
IdM services can be configured to generate PACs, PADs, or both for each authentication request when a
user first attempts to authenticate to a domain service.
5.7.1. Setting Default PAC Types
T he IdM server configuration defines which PAC types are generated by default for a service. T he global
settings can be overridden by changing the local settings on a specific service.
1. Open the IPA Server tab.
2. Select the Configuration subtab.
3. Scroll to the Service Options area.
91
Red Hat Enterprise Linux 7 Windows Integration Guide
4. Select the check boxes by the PAC types to use. If both PAC types are selected, then both are
added to the Kerberos ticket.
MS-PAC adds a certificate that can be used by Active Directory services.
PAD adds a certificate that can be used by POSIX (non-Windows) systems.
If no checkbox is selected, then no PACs are added to Kerberos tickets.
5. Click the Update link at the top of the page to save the changes.
5.7.2. Setting PAC Types for a Service
T he global policy sets what PAC types to use for a service if nothing is set explicitly for that service.
However, the global settings can be overridden on the local service configuration.
1. Open the Identity tab, and select the Services subtab.
2. Click the name of the service to edit.
92
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
3. In the Service Settings area, select the check boxes by the PAC types to use. If both PAC
types are selected, then both are added to the Kerberos ticket.
MS-PAC adds a certificate that can be used by Active Directory services.
PAD adds a certificate that can be used by POSIX (non-Windows) systems.
If no checkbox is selected, then no PACs are added to Kerberos tickets.
4. Click the Update link at the top of the page to save the changes.
93
Red Hat Enterprise Linux 7 Windows Integration Guide
5.8. Using SSH from Active Directory Machines for IdM Resources
When a trust is configured, Active Directory users can access machines, services, and files on IdM hosts
using SSH and their Active Directory credentials.
NOTE
When using PuT T Y on the Windows machine, make sure that GSS-API credential delegation is
enabled.
5.8.1. Username Requirements for SSH
One critical factor when using SSH is the username. T he username must meet several criteria:
T he username must have the format [email protected]_domain.
T he domain name itself must be lower-case. T his is required for Kerberos principal mapping.
T he case of the username must match, exactly, the case of the username in Active Directory. jsmith
and JSmith are considered different users because of the different cases.
5.8.2. Using SSH Without Passwords
Even if a proper Kerberos ticket is obtained, using SSH still prompts for a user password for Active
Directory domain users. SSH specifies the username with the -l, but the Kerberos ticket contains the
Kerberos principal, not the username. T he system requires a way to compare the offered, local username
to a principal name to see if the user has a ticket. T he .k5login file offers a simple way to map a local
user to a Kerberos principal. T he file is in a local user's home directory (and the user is identified by the l option with SSH), and it lists Kerberos principals for that user. If the authenticating user matches the
principal in an existing Kerberos ticket, then the user is allowed to log in using the ticket for authentication,
rather than requiring a password.
T o change to Kerberos authentication (meaning, to use passwordless SSH authentication), each Active
Directory user should have a .k5login file in their Linux home directory. T he only contents in the file are
a list of Kerberos principals used by the user. T he principals can be any of the formats in Section 5.2.9,
“Supported Username Formats”, such as [email protected], AD.domain\user, or AD\user.
For example, for the user jsmith in an Active Directory realm named ENGINEERING.ADREALM.COM, the
.k5login is put in the home directory:
/home/engineering.adrealm/jsmith/.k5login
T he contents of the file contain two different principal names:
[email protected]
ENGINEERING.ADREALM.COM\jsmith
T he .k5login file is case-sensitive, so listing multiple principals in different formats and different cases
can be useful.
Because there are two different principals, either string can be used with kinit to obtain a ticket.
T he .k5login manpage has more details.
94
⁠C hapter 5. Creating Cross-Realm T rusts with Active Directory and Identity Management
5.9. Using Trust with Kerberized Web Applications
Any existing web application can be configured to use Kerberos authentication, which references the
trusted Active Directory and IdM Kerberos realms. T he full Kerberos configuration directives are covered in
the mod_auth_kerb module man pages.
For example, for an Apache server, there are several parameters that define how the Apache server
connects to the IdM Kerberos realm:
T he KrbAuthRealms directive gives the application location to the name of the IdM domain. T his is
required.
T he Krb5Keytab gives the location for the IdM server keytab. T his is required.
T he KrbServiceName sets the Kerberos service name used for the keytab (HT T P). T his is
recommended.
T he Kerberos methods directives (KrbMethodNegotiate and KrbMethodK5Passwd) enables
password-based authentication for valid users. T his is recommended for ease of use for many users.
T he KrbLocalUserMapping directive enables normal web logins (which are usually the UID or
common name of the account) to be mapped to the fully-qualified username (which has a format of
[email protected]).
T his parameter is strongly recommended. Without the domain name/login name mapping, the web login
appears to be a different user account than the domain user. T his means that users cannot see their
expected data.
Section 5.2.9, “Supported Username Formats” discusses different supported username formats.
Example 5.2. Kerberos Configuration in an Apache Web Application
<Location "/mywebapp">
AuthType Kerberos
AuthName "IPA Kerberos authentication"
KrbMethodNegotiate on
KrbMethodK5Passwd on
KrbServiceName HTTP
KrbAuthRealms IDM_DOMAIN
Krb5Keytab /etc/httpd/conf/ipa.keytab
KrbLocalUserMapping on
KrbSaveCredentials off
Require valid-user
</Location>
NOTE
After changing the Apache application configuration, restart the Apache service:
[[email protected] ~]# systemctl restart httpd.service
95
Red Hat Enterprise Linux 7 Windows Integration Guide
[3] There are us ually no TXT rec o rd s fo r Ac tive Direc to ry d o mains .
96
⁠C hapter 6. Setting up Kerberos Cross-Realm Authentication
Chapter 6. Setting up Kerberos Cross-Realm Authentication
Kerberos v5 creates a realm of clients. T hat realm can be trust and integrate with an Active Directory
domain, as well as other Kerberos domains. Kerberos itself is system-agnostic, so it can work in a number
of different environments, systems, and applications.
A lot of Linux environments (and mixed environments) will already have a Kerberos realm deployed for
single sign-on, application authentication, and user management. T hat makes Kerberos a potentially
common integration path for mixed Windows-Linux environments, particularly if the Linux environment is not
using a more structured domain configuration like Identity Management.
6.1. A Trust Relationship
A trust means that the users within one realm are trusted to access the resources in another domain as if
they belonged to that realm. T his is done by creating a shared key for a single principal that is held in
common by both domains.
Figure 6.1. Basic T rust
In Figure 6.1, “Basic T rust”, the shared principal would belong to Domain B
(krbtgt/[email protected] A.EXAMPLE.COM). When that principal is also added to Domain A, then the
clients in Domain A can access the resources in Domain B. T he configured principal exists in both realms.
T hat shared principal has three characteristics:
It exists in both realms.
When a key is created, the same password is used in both realms.
T he key has the same key version number (kvno).
A cross-realm trust is unidirectional by default. T his trust is not automatically reciprocated so that the
B.EXAMPLE.COM realm are trusted to authenticate to services in the A.EXAMPLE.COM realm. T o establish
trust in the other direction, both realms would need to share keys for the
krbtgt/[email protected] B.EXAMPLE.COM service — an entry with a reverse mapping from the
previous example.
A realm can have multiple trusts, both realms that it trusts and realms it is trusted by. With Kerberos trusts,
the trust can flow in a chain. If Realm A trusts Realm B and Realm B trusts Realm C, Realm A implicity
trusts Realm C, as well. T he trust flows along realms; this is a transitive trust.
97
Red Hat Enterprise Linux 7 Windows Integration Guide
Figure 6.2. T ransitive T rust
NOTE
While a Kerberos trust is transitive by default, that is not necessarily true for a Kerberos trust with a
Windows domain. In Windows, trusts with other Windows domains is transitive, but trusts with
external (meaning, non-Windows) realms are non-transitive by default. T hey can be configured to
be transitive.
T he direction of a transitive trust is the trust flow. T he trust flow has to be defined, first by recognizing to
what realm a service belongs and then by identifying what realms a client must contact to access that
service.
A Kerberos principal name is structured in the format service/[email protected] T he service is generally
a protocol, such as LDAP, IMAP, HT T P, or host. T he hostname is the fully-qualified domain name of the
host system, and the REALM is the Kerberos realm to which it belongs. Clients usually map the hostname
or DNS domain name to the realm. T he realm, then, somewhat related to the DNS domain name (uncless a
realm is explicitly defined in the dom ain_realm section of /etc/krb5.conf).
When traversing a trust, Kerberos assumes that each realm is structured like a hierarchical DNS domain,
with a root domain and subdomains. T his means that the trust flows up to a shared root. Each step, or
hop, has a shared key. In Figure 6.3, “T rusts in the Same Domain”, A shares a key with EXAMPLE.COM,
and EXAMPLE.COM shares a key with B.
Figure 6.3. T rusts in the Same Domain
T he client treats the relam name as a DNS name, and it determines its trust path by stripping off elements
of its own realm name until it reaches the root name. It then begins prepending names until it reaches the
service's realm.
98
⁠C hapter 6. Setting up Kerberos Cross-Realm Authentication
Figure 6.4 . Child/Parent T rusts in the Same Domain
T his is a nature of trusts being transitive. SIT E.SALES.EXAMPLE.COM only has a single shared key, with
SALES.EXAMPLE.COM. But because of a series of small trusts, there is a large trust flow that allows trust
to go from SIT E.SALES.EXAMPLE.COM to EVERYWHERE.EXAMPLE.COM.
T hat trust flow can even go between completely different domains by creating a shared key at the domain
level, where the sites share no common suffix.
Figure 6.5. T rusts in Different Domains
It is also possible to reduce the number of hops and represent very complex trust flows by explicitly
defining the flow. T he capaths section of the /etc/krb5.conf file defines the trust flow between
different realms.
T he format of the capaths section is relatively straightforward: there is a main entry for each realm where
a client has a principal, and then inside each realm section is a list of intermediate realms from which the
client must obtain credentials.
For example, this has the realm of A.EXAMPLE.COM, and a set of hops from A to D. A client in Realm A
must obtain credentials first from Realm B (the . means that it can obtain credentials directly, without any
intermmediate hops; otherwise, it would attempt to gain credentials by going through a hierarchy). It must
then use the B credentials to obtain credentials from C, and then use the C credentials to obtain
credentials for D.
99
Red Hat Enterprise Linux 7 Windows Integration Guide
[capaths]
A.EXAMPLE.COM
B.EXAMPLE.COM
C.EXAMPLE.COM
D.EXAMPLE.COM
}
=
=
=
=
{
.
B.EXAMPLE.COM
C.EXAMPLE.COM
6.2. Setting up a Realm Trust
In this example, the Kerberos realm is KRB.EXAMPLE.COM, and the Active Directory realm is
AD.EXAMPLE.COM.
1. Create the entry for the shared principal in Kerberos, using kadm in.
[[email protected] ~]# kadmin -r KRB.EXAMPLE.COM
kadmin: add_principal krbtgt/[email protected]
Enter password for principal "krbtgt/[email protected]":
Re-enter password for principal "krbtgt/[email protected]":
Principal "krbtgt/[email protected]" created.
quit
2. A realm trust is configured in the Active Directory Dom ains and T rusts console. Select the
appropriate domain, and create a new trust. T hese are the settings to use:
T he T rust T ype is Realm .
T he T ransitivity of T rust can be either transitive or non-transitive.
T he Direction of T rust is One-way: incom ing. T his trusts Active Directory users in the
Kerberos realm.
T his creates a unidirectional trust, where Active Directory users are trusted in the Kerberos
realm. T o create a two-way trust, set the direction of trust to two-way. T his is described in the
Microsoft T echNet documentation.
T he Sides of T rust is T his dom ain only.
T he T rust Password can be anything. T his must be used when configuring the trust in
Kerberos.
100
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
Chapter 7. Synchronizing Active Directory and Identity
Management Users
Red Hat Enterprise Linux Identity Management uses active synchronization to combine the user data
stored in an Active Directory domain and the user data stored in the IdM domain. Critical user attributes,
including passwords, are copied and synchronized between the services.
Entry synchronization is performed through a process similar to replication, which uses hooks to connect
to and retrieve directory data from the Windows server. T his is functionality is available immediately in
Identity Management, with no additional configuration in the Active Directory domain.
Password synchronization is performed through a Windows service which is installed on the Windows
server and then communicates to the Identity Management server.
7.1. Supported Windows Platforms
Synchronization are supported with these Windows servers:
Windows Server 2008 R2 (32-bit)
Windows Server 2008 R2 (64-bit)
T he version of the password sync service which works with Windows is 1.1.5. T his is available in the Red
Hat Directory Server downloads part of Red Hat Network.
7.2. About Active Directory and Identity Management
Within the IdM domain, information is shared among servers and replicas by copying that information,
reliably and predictably, between data masters (servers and replicas). T his process is replication.
A similar process can be used to share data between the IdM domain and a Microsoft Active Directory
domain. T his is synchronization.
Synchronization is the process of copying user data back and forth between Active Directory and Identity
Management.
Figure 7.1. Active Directory and IdM Synchronization
101
Red Hat Enterprise Linux 7 Windows Integration Guide
Synchronization is defined in an agreement between an IdM server and an Active Directory domain
controller. T he sync agreement defines all of the information required to identify sync-able user entries
(like the subtree to synchronize and requisite object classes in the user entries) as well as defining how
account attributes are handled. T he sync agreements are created with default values which can be
tweaked to meet the needs of a specific domain. When two servers are involved in synchronization, they
are called peers.
T able 7.1. Information in a Sync Agreement
Windows Information
User subtree (cn=Users,$SUFFIX)
Connection information
Active Directory administrator username
and password
Password Sync Service password
CA certificate
IdM Information
User subtree (ou=People,$SUFFIX)
Synchronization is most commonly bi-directional. Information is sent back and forth between the IdM
domain and the Windows domain in a process that is very similar to how IdM servers and replicas share
information among themselves. It is possible to configure synchronization to only sync one way. T hat is
uni-directional synchronization.
T o prevent the risk of data conflicts, only one directory should originate or remove user entries. T his is
typically the Windows directory, which is the primary identity store in the IT environment, and then new
accounts or account deletions are synced to the Identity Management peer. Either directory can modify
entries.
Synchronization, then, is configured between one Identity Management server and one Active Directory
domain controller. T he Identity Management server propagates throughout to the IdM domain, while the
domain controller propagates changes throughout the Windows domain.
Figure 7.2. Synchronization T opology
102
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
T here are some key features to IdM synchronization:
A synchronization operation runs every five minutes.
Synchronization can only be configured with one Active Directory domain.
Synchronization can only be configured with one Active Directory domain controller.
Only user information is synchronized.
Both user attributes and passwords can be synchronized.
While modifications are bi-directional (going both from Active Directory to IdM and from IdM to Active
Directory), creating accounts is only uni-directional, from Active Directory to Identity Management. New
accounts created in Active Directory are synchronized over to IdM automatically. However, user
accounts created in IdM must also be created in Active Directory before they will be synchronized.
Account lock information is synchronized by default, so a user account which is disabled in one domain
is disabled in the other.
Password synchronization changes take effect immediately. If a user password is added or changed
on one peer, that change is immediately propagated to the other peer server.
T he Password Sync client synchronizes new passwords or password updates.
Existing passwords, which are stored in a hashed form in both IdM and Active Directory, cannot be
decrypted or synchronized when the Password Sync client is installed, so existing passwords are not
synchronized. User passwords must be changed to initiate synchronization between the peer servers.
When Active Directory users are synchronized over to IdM, certain attributes (including Kerberos and
POSIX attributes) will have IPA attributes are automatically added to the user entries. T hese attributes are
used by IdM within its domain. T hey are not synchronized back over the corresponding Active Directory
user entry.
Some of the data in synchronization can be modified as part of the synchronization process. For
examples, certain attributes can be automatically added to Active Directory user accounts when they are
synced over to the IdM domain. T hese attribute changes are defined as part of the synchronization
agreement and are described in Section 7.5.3, “Changing the Behavior for Syncing User Account
Attributes”.
7.3. About Synchronized Attributes
Identity Management synchronizes a subset of user attributes between IdM and Active Directory user
entries. Any other attributes present in the entry, either in Identity Management or in Active Directory, are
ignored by synchronization.
NOTE
Most POSIX attributes are not synchronized.
Although there are significant schema differences between the Active Directory LDAP schema and the 389
Directory Server LDAP schema used by Identity Management, there are many attributes that are the same.
T hese attributes are simply synchronized between the Active Directory and IdM user entries, with no
changes to the attribute name or value format.
103
Red Hat Enterprise Linux 7 Windows Integration Guide
User Schema T hat Are the Same in Identity Management and Windows Servers
cn ⁠ [4]
physicalDeliveryOfficeName
description
postOfficeBox
destinationIndicator
postalAddress
facsimileT elephoneNumber
postalCode
givenname
registeredAddress
homePhone
sn
homePostalAddress
st
initials
street
l
telephoneNumber
mail
teletexT erminalIdentifier
mobile
telexNumber
o
title
ou
userCertificate
pager
x121Address
Some attributes have different names but still have direct parity between IdM (which uses 389 Directory
Server) and Active Directory. T hese attributes are mapped by the synchronization process.
T able 7.2. User Schema Mapped between Identity Management and Active Directory
104
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
Identity Management
Active Directory
cn ⁠ [a]
name
nsAccountLock
userAccountControl
ntUserDomainId
sAMAccountName
ntUserHomeDir
homeDirectory
ntUserScriptPath
scriptPath
ntUserLastLogon
lastLogon
ntUserLastLogoff
lastLogoff
ntUserAcctExpires
accountExpires
ntUserCodePage
codePage
ntUserLogonHours
logonHours
ntUserMaxStorage
maxStorage
ntUserProfile
profilePath
ntUserParms
userParameters
ntUserWorkstations
userWorkstations
[a] The cn is map p ed d irec tly (cn to cn) when s ync ing fro m Id entity Manag ement to Ac tive Direc to ry. When s ync ing fro m Ac tive
Direc to ry cn is map p ed fro m the name attrib ute in Ac tive Direc to ry to the cn attrib ute in Id entity Manag ement.
7.3.1. User Schema Differences between Identity Management and Active Directory
Even though attributes may be successfully synced between Active Directory and IdM, there may still be
differences in how Active Directory and Identity Management define the underlying X.500 object classes.
T his could lead to differences in how the data are handled in the different LDAP services.
T his section describes the differences in how Active Directory and Identity Management handle some of
the attributes which can be synchronized between the two domains.
7.3.1.1. Values for cn Attributes
In 389 Directory Server, the cn attribute can be multi-valued, while in Active Directory this attribute must
have only a single value. When the Identity Management cn attribute is synchronized, then, only one value
is sent to the Active Directory peer.
What this means for synchronization is that,potentially, if a cn value is added to an Active Directory entry
and that value is not one of the values for cn in Identity Management, then all of the Identity Management
cn values are overwritten with the single Active Directory value.
One other important difference is that Active Directory uses the cn attribute as its naming attribute, where
Identity Management uses uid. T his means that there is the potential to rename the entry entirely (and
accidentally) if the cn attribute is edited in the Identity Management. If that cn change is written over to the
Active Directory entry, then the entry is renamed, and the new named entry is written back over to Identity
Management.
7.3.1.2. Values for street and streetAddress
Active Directory uses the attribute streetAddress for a user's postal address; this is the way that 389
Directory Server uses the street attribute. T here are two important differences in the way that Active
Directory and Identity Management use the streetAddress and street attributes, respectively:
In 389 Directory Server, streetAddress is an alias for street. Active Directory also has the street
attribute, but it is a separate attribute that can hold an independent value, not an alias for
streetAddress.
105
Red Hat Enterprise Linux 7 Windows Integration Guide
Active Directory defines both streetAddress and street as single-valued attributes, while 389
Directory Server defines street as a multi-valued attribute, as specified in RFC 4519.
Because of the different ways that 389 Directory Server and Active Directory handle streetAddress and
street attributes, there are two rules to follow when setting address attributes in Active Directory and
Identity Management:
T he synchronization process maps streetAddress in the Active Directory entry to street in Identity
Management. T o avoid conflicts, the street attribute should not be used in Active Directory.
Only one Identity Management street attribute value is synced to Active Directory. If the
streetAddress attribute is changed in Active Directory and the new value does not already exist in
Identity Management, then all street attribute values in Identity Management are replaced with the
new, single Active Directory value.
7.3.1.3. Constraints on the initials Attribute
For the initials attribute, Active Directory imposes a maximum length constraint of six characters, but
389 Directory Server does not have a length limit. If an initials attribute longer than six characters is
added to Identity Management, the value is trimmed when it is synchronized with the Active Directory entry.
7.3.1.4 . Requiring the surname (sn) Attribute
Active Directory allows person entries to be created without a surname attribute. However, RFC 4519
defines the person object class as requiring a surname attribute, and this is the definition used in
Directory Server.
If an Active Directory person entry is created without a surname attribute, that entry will not be synced
over to IdM since it fails with an object class violation.
7.3.2. Active Directory Entries and POSIX Attributes
Windows uses unique, random security IDs (SIDs) to identify users. T hese SIDs are assigned in blocks or
ranges, identifying different system user types within the Windows domain. When users are synchronized
between Identity Management and Active Directory, Windows SIDs for users are mapped to the Unix UIDs
used by the Identity Management entry. Another way of saying this is that the Windows SID is the only ID
within the Windows entry which is used as an identifier in the corresponding Unix entry, and then it is used
in a mapping.
When Active Directory domains interact with Unix-style applications or domains, then the Active Directory
domain may use Services for Unix or IdM for Unix to enable Unix-style uidNumber and gidNumber
attributes. T his allows Windows user entries to follow the specifications for those attributes in RFC 2307.
However, the uidNumber and gidNumber attributes are not actually used as the uidNumber and
gidNumber attributes for the Identity Management entry. T he Identity Management uidNumber and
gidNumber attributes are generated when the Windows user is synced over.
NOTE
T he uidNumber and gidNumber attributes defined and used in Identity Management are not the
same uidNumber and gidNumber attributes defined and used in the Active Directory entry, and the
numbers are not related.
106
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
7.4. Setting up Active Directory for Synchronization
Synchronizing user accounts alone is enabled within IdM, so all that is necessary is to set up a sync
agreement (Section 7.5.2, “Creating Synchronization Agreements”). However, the Active Directory does
need to be configured in a way that allows the Identity Management server to connect to it.
7.4.1. Creating an Active Directory User for Sync
On the Windows server, it is necessary to create the user that the IdM server will use to connect to the
Active Directory domain.
T he process for creating a user in Active Directory is covered in the Windows server documentation at
http://technet.microsoft.com/en-us/library/cc732336.aspx. T he new user account must have the proper
permissions:
Grant the sync user account Replicating directory changes rights to the synchronized Active
Directory subtree. Replicator rights are required for the sync user to perform synchronization
operations.
Replicator rights are described in http://support.microsoft.com/kb/303972.
Add the sync user as a member of the Account Operator and Enterprise Read-Only Domain
controller groups. It is not necessary for the user to belong to the full Domain Admin group.
7.4.2. Setting up an Active Directory Certificate Authority
T he Identity Management server connects to the Active Directory server using a secure connection. T his
requires that the Active Directory server have an available CA certificate or CA certificate chain available,
which can be imported into the Identity Management security databases, so that the Windows server is a
trusted peer.
While this could technically be done with an external (to Active Directory) CA, most deployments should
use the Certificate Services available with Active Directory.
T he procedure for setting up and configuring certificate services on Active Directory is covered in the
Microsoft documentation at http://technet.microsoft.com/en-us/library/cc772393(v=WS.10).aspx.
7.5. Managing Synchronization Agreements
7.5.1. Trusting the Active Directory and IdM CA Certificates
Both Active Directory and Identity Management use certificates for server authentication. For the Active
Directory and IdM SSL server certificates to be trusted by each other, both servers need to trust the CA
certificate for the CA which issued those certificates. T his means that the Active Directory CA certificate
needs to be imported into the IdM database, and the IdM CA certificate needs to be imported into the Active
Directory database.
1. On the Active Directory server, download the IdM server's CA certificate from
http://ipa.exam ple.com /ipa/config/ca.crt.
2. Install the IdM CA certificate in the Active Directory certificate database. T his can be done using the
Microsoft Management Console or the certutil utility.
Right-click on the executable, and select Run as adm inistrator, then run certutil with the installcert option. For example:
107
Red Hat Enterprise Linux 7 Windows Integration Guide
C:\Windows\system32\certutil -installcert -v -config
"ipaserver.example.com\Example Domain CA" c:\path\to\ca.crt
T his command must be run as an administrative account, or it will fail because it cannot access the
certificate database.
For more details on installing certificates, see the Active Directory documentation.
3. Export the Active Directory CA certificate.
a. In My Network Places, open the CA distribution point.
b. Double-click the security certificate file (.crt file) to display the Certificate dialog box.
c. On the Details tab, click Copy to File to start the Certificate Export Wizard.
d. Click Next, and then select Base-64 encoded X.509 (.CER).
e. Specify a suitable directory and file name for the exported file. Click Next to export the
certificate, and then click Finish.
4. Copy the Active Directory certificate over to the IdM server machine.
5. Download the IdM server's CA certificate from
http://ipa.exam ple.com /ipa/config/ca.crt.
6. Copy both the Active Directory CA certificate and the IdM CA certificate into the
/etc/openldap/cacerts/ directory.
7. Update the hash symlinks for the certificates.
cacertdir_rehash /etc/openldap/cacerts/
108
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
8. Edit the /etc/openldap/ldap.conf file, and add the information to point to and use the
certificates in the /etc/openldap/cacerts/ directory.
TLS_CACERTDIR /etc/openldap/cacerts/
TLS_REQCERT allow
7.5.2. Creating Synchronization Agreements
Synchronization agreements are created on the IdM server using the ipa-replica-m anage connect
command because it creates a connection to the Active Directory domain. T he options to create the
synchronization agreement are listed in T able 7.3, “Synchronization Agreement Options”.
1. Make sure that the Active Directory and IdM servers trust each other's CA certificates, as in
Section 7.5.1, “T rusting the Active Directory and IdM CA Certificates”.
2. Remove any existing Kerberos credentials on the IdM server.
$ kdestroy
3. Use the ipa-replica-m anage command to create a Windows synchronization agreement. T his
requires the --winsync option. If passwords will be synchronized as well as user accounts, then
also use the --passsync option and set a password to use for Password Sync.
T he --binddn and--bindpwd options give the username and password of the system account
on the Active Directory server that IdM will use to connect to the Active Directory server.
$ ipa-replica-manage connect --winsync
--binddn cn=administrator,cn=users,dc=example,dc=com
--bindpw Windows-secret
--passsync secretpwd
--cacert /etc/openldap/cacerts/windows.cer
adserver.example.com -v
4. When prompted, enter the Directory Manager password.
5. Optional. Configure Password Synchronization, as in Section 7.6.2, “Setting up Password
Synchronization”. Without the Password Sync client, user attributes are synchronized between the
peer servers, but passwords are not.
NOTE
T he Password Sync client captures password changes and then synchronizes them
between Active Directory and IdM. T his means that it synchronizes new passwords or
password updates.
Existing passwords, which are stored in a hashed form in both IdM and Active Directory,
cannot be decrypted or synchronized when the Password Sync client is installed, so existing
passwords are not synchronized. User passwords must be changed to initiate
synchronization between the peer servers.
T able 7.3. Synchronization Agreement Options
109
Red Hat Enterprise Linux 7 Windows Integration Guide
Option
Description
--winsync
Identifies this as a synchronization agreement.
--binddn
Gives the full user DN of the synchronization
identity. T his is the user DN that the IdM LDAP
server uses to bind to Active Directory. T his user
must exist in the Active Directory domain and must
have replicator, read, search, and write
permissions on the Active Directory subtree.
--bindpw
Gives the password for the sync user.
--passsync
Gives the password for the Windows user account
which is involved in synchronization.
--cacert
Gives the full path and file name of the Active
Directory CA certificate. T his certificate is exported
in Section 7.5.1, “T rusting the Active Directory and
IdM CA Certificates”.
--win-subtree
Gives the DN of the Windows subtree containing
the users to synchronize. T he default value is
cn=Users,$SUFFIX.
AD_server_name
Gives the hostname of the Active Directory domain
controller.
7.5.3. Changing the Behavior for Syncing User Account Attributes
When the sync agreement is created, it has certain default behaviors defined for how the synchronization
process handles the user account attributes during synchronization. T he types of behaviors are things
like how to handle lockout attributes or how to handle different DN formats. T his behavior can be changed
by editing the synchronization agreement. T he list of attribute-related parameters are in T able 7.4,
“Synced Attribute Settings”.
T he sync agreement exists as a special plug-in entry in the LDAP server and each attribute behavior is
set through an LDAP attribute. T o change the sync behavior, use the ldapm odify command to modify
the LDAP server entry directly.
For example, account lockout attributes are synchronized between IdM and Active Directory by default, but
this can be disabled by editing the ipaWinSyncAcctDisable attribute. (Changing this means that if an
account is disabled in Active Directory, it is still active in IdM and vice versa.)
[[email protected] ~]$ ldapmodify -x -D "cn=directory manager" -w password
dn: cn=ipa-winsync,cn=plugins,cn=config
changetype: modify
replace: ipaWinSyncAcctDisable
ipaWinSyncAcctDisable: none
modifying entry "cn=ipa-winsync,cn=plugins,cn=config"
T able 7.4 . Synced Attribute Settings
Parameter
Description
Possible Values
General User Account Parameters
ipaWinSyncNewEntryFilter
110
Sets the search filter to use to
find the entry which contains the
list of object classes to add to
new user entries.
T he default is
(cn=ipaConfig).
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
Parameter
Description
Possible Values
ipaWinSyncNewUserOCAttr
Sets the attribute in the
configuration entry which actually
contains the list of object
classes to add to new user
entries.
T he default is
ipauserobjectclasses.
ipaWinSyncHomeDirAttr
Identifies which attribute in the
entry contains the default
location of the POSIX home
directory.
T he default is
ipaHom esRootDir.
ipaWinSyncUserAttr
Sets an additional attribute with a
specific value to add to Active
Directory users when they are
synced over from the Active
Directory domain. If the attribute
is multi-valued, then it can be set
multiple times, and the sync
process adds all of the values to
the entry.
ipaWinSyncUserAttr:
attributeName attributeValue
NOTE
T his only sets the
attribute value if the entry
does not already have
that attribute present. If
the attribute is present,
then the entry's value is
used when the Active
Directory entry is synced
over.
ipaWinSyncForceSync
Sets whether to check existing
IdM users which match an
existing Active Directory user
should be automatically edited
so they can be synchronized. If
an IdM user account has a uid
parameter which is identical to
the sAMAccountName in an
existing Active Directory user,
then that account is not synced
by default. T his attribute tells the
sync service to add the ntUser
and ntUserDomainId to the IdM
user entries automatically, which
allows them to be synchronized.
true | false
User Account Lock Parameters
111
Red Hat Enterprise Linux 7 Windows Integration Guide
Parameter
Description
Possible Values
ipaWinSyncAcctDisable
Sets which way to synchronize
account lockout attributes. It is
possible to control which account
lockout settings are in effect. For
example, to_ad means that
when account lockout attribute is
set in IdM, its value is synced
over to Active Directory and
overrides the local Active
Directory value. By default,
account lockout attributes are
synced from both domains.
ipaWinSyncInactivatedFilter
Sets the search filter to use to
find the DN of the group used to
hold inactivated (disabled) users.
T his does not need to be
changed in most deployments.
T he default is (&
(cn=inactivated)
(objectclass=groupOfNam
es)).
ipaWinSyncActivatedFilter
Sets the search filter to use to
find the DN of the group used to
hold active users. T his does not
need to be changed in most
deployments.
T he default is (&
(cn=activated)
(objectclass=groupOfNam
es)).
ipaWinSyncDefaultGroupAttr
Sets the attribute in the new user
account to reference to see what
the default group for the user is.
T he group name in the entry is
then used to find the gidNumber
for the user account.
T he default is
ipaDefaultPrim aryGroup.
ipaWinSyncDefaultGroupFilter
Sets the search filter to map the
group name to the POSIX
gidNumber.
T he default is (&
(gidNum ber=* )
(objectclass=posixGroup)
(cn=groupAttr_value)).
ipaWinSyncRealmAttr
Sets the attribute which contains
the realm name in the realm
entry.
T he default is cn.
ipaWinSyncRealmFilter
Sets the search filter to use to
find the entry which contains the
IdM realm name.
T he default is
(objectclass=krbRealm Co
ntainer).
both (default)
to_ad
to_ds
none
Group Parameters
Realm Parameters
7.5.4. Changing the Synchronized Windows Subtree
Creating a synchronization agreement automatically sets the two subtrees to use as the synchronized
user database. In IdM, the default is cn=users,cn=accounts,$SUFFIX, and for Active Directory, the
default is CN=Users,$SUFFIX.
T he value for the Active Directory subtree can be set to a non-default value when the sync agreement is
created by using the --win-subtree option. After the agreement is created, the Active Directory subtree
can be changed by using the ldapm odify command to edit the nsds7WindowsReplicaSubtree value in
the sync agreement entry.
112
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
1. Get the name of the sync agreement, using ldapsearch. T his search returns only the values for
the dn and nsds7WindowsReplicaSubtree attributes instead of the entire entry.
[[email protected] ~]$ ldapsearch -xLLL -D "cn=directory manager" -w password p 389 -h ipaserver.example.com -b cn=config
objectclass=nsdswindowsreplicationagreement dn nsds7WindowsReplicaSubtree
dn:
cn=meToWindowsBox.example.com,cn=replica,cn=dc\3Dexample\2Cdc\3Dcom,cn=mappin
g tree,cn=config
nsds7WindowsReplicaSubtree: cn=users,dc=example,dc=com
... 8< ...
2. Modify the sync agreement
[[email protected] ~]$ ldapmodify -x -D "cn=directory manager" -W -p 389 -h
ipaserver.example.com <<EOF
dn:
cn=meToWindowsBox.example.com,cn=replica,cn=dc\3Dexample\2Cdc\3Dcom,cn=mappin
g tree,cn=config
changetype: modify
replace: nsds7WindowsReplicaSubtree
nsds7WindowsReplicaSubtree: cn=alternateusers,dc=example,dc=com
EOF
modifying entry
"cn=meToWindowsBox.example.com,cn=replica,cn=dc\3Dexample\2Cdc\3Dcom,cn=mappi
ng tree,cn=config"
T he new subtree setting takes effect immediately. If a sync operation is currently running, then it takes
effect as soon as the current operation completes.
7.5.5. Configuring Uni-Directional Sync
By default, all modifications and deletions are bi-directional. A change in Active Directory is synced over to
Identity Management, and a change to an entry in Identity Management is synced over to Active Directory.
T his is essentially an equitable, multi-master relationship, where both Active Directory and Identity
Management are equal peers in synchronization and are both data masters.
However, there can be some data structure or IT designs where only one domain should be a data master
and the other domain should accept updates. T his changes the sync relationship from a multi-master
relationship (where the peer servers are equal) to a master-consumer relationship.
T his is done by setting the oneWaySync parameter on the sync agreement. T he possible values are
fromWindows (for Active Directory to Identity Management sync) and toWindows (for Identity Management
to Active Directory sync).
For example, to sync changes from Active Directory to Identity Management:
[[email protected] ~]$ ldapmodify -x -D "cn=directory manager" -w password -p 389 h ipaserver.example.com
dn: cn=windows.example.com,cn=replica,cn=dc\3Dexample\2Cdc\3Dcom,cn=mapping
113
Red Hat Enterprise Linux 7 Windows Integration Guide
tree,cn=config
changetype: modify
add: oneWaySync
oneWaySync: fromWindows
IMPORTANT
Enabling uni-directional sync does not automatically prevent changes on the un-synchronized
server, and this can lead to inconsistencies between the sync peers between sync updates. For
example, uni-directional sync is configured to go from Active Directory to Identity Management, so
Active Directory is (in essence) the data master. If an entry is modified or even deleted on the
Identity Management, then the Identity Management information is different then the information and
those changes are never carried over to Active Directory. During the next sync update, the edits are
overwritten on the Directory Server and the deleted entry is re-added.
7.5.6. Deleting Synchronization Agreements
Synchronization can be stopped by deleting the sync agreement which disconnects the IdM and Active
Directory servers. In the inverse of creating a sync agreement, deleting a sync agreement uses the ipareplica-m anage disconnect command and then the hostname of the Active Directory server.
1. Delete the sync agreement.
# ipa-replica-manage disconnect adserver.example.com
2. Remove the Active Directory CA certificate from the IdM server database:
# certutil -D -d /etc/dirsrv/slapd-EXAMPLE.COM/ -n "Imported CA"
7.5.7. Winsync Agreement Failures
Creating the sync agreement fails because it cannot connect to the Active Directory server.
One of the most common sync agreement failures is that the IdM server cannot connect to the Active
Directory server:
"Update failed! Status: [81
- LDAP error: Can't contact LDAP server]
T his can occur if the wrong Active Directory CA certificate was specified when the agreement was created.
T his creates duplicate certificates in the IdM LDAP database (in the /etc/dirsrv/slapd-DOMAIN/
directory) with the name Imported CA. T his can be checked using certutil:
$ certutil -L -d /etc/dirsrv/slapd-DOMAIN/
Certificate Nickname
SSL,S/MIME,JAR/XPI
Trust Attributes
CA certificate
Imported CA
Server-Cert
Imported CA
CTu,u,Cu
CT,,C
u,u,u
CT,,C
T o resolve this issue, clear the certificate database:
114
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
# certutil -d /etc/dirsrv/slapd-DOMAIN-NAME -D -n "Imported CA"
T his deletes the CA certificate from the LDAP database.
T here are errors saying passwords are not being synced because it says the entry exists
For some entries in the user database, there may be an informational error message that the password is
not being reset because the entry already exists:
"Windows PassSync entry exists, not resetting password"
T his is not an error. T his message occurs when an exempt user, the Password Sync user, is not being
changed. T he Password Sync user is the operational user which is used by the service to change the
passwords in IdM.
7.6. Managing Password Synchronization
Synchronizing user entries is configured with the sync agreement. However, passwords in both Active
Directory and Identity Management are not part of the normal user synchronization process. A separate
client must be installed on the Active Directory servers to capture passwords as user accounts are
created or passwords are changed, and then to forward that password information with the sync updates.
NOTE
T he Password Sync client captures password changes and then synchronizes them between
Active Directory and IdM. T his means that it synchronizes new passwords or password updates.
Existing passwords, which are stored in a hashed form in both IdM and Active Directory, cannot be
decrypted or synchronized when the Password Sync client is installed, so existing passwords are
not synchronized. User passwords must be changed to initiate synchronization between the peer
servers.
7.6.1. Setting up the Windows Server for Password Synchronization
Synchronizing passwords requires two things:
Active Directory must be running in SSL.
T he Password Sync Service must be installed on each Active Directory domain controller.
T he Password Sync Service records password changes and synchronizes them, over a secure
connection, to the IdM entry.
TIP
Install the Microsoft Certificate System in Enterprise Root Mode. Active Directory will then
automatically enroll to retrieve its SSL server certificate.
1. Make sure that the Active Directory password complexity policies are enabled so that the Password
Sync service will run.
a. Run secpol.m sc from the command line.
115
Red Hat Enterprise Linux 7 Windows Integration Guide
b. Select Security Settings.
c. Open Account Policies, and then open Password Policy.
d. Enable the Password m ust m eet com plexity requirem ents option and save.
2. If SSL is not already enabled, set up SSL on the Active Directory server. Setting up LDAPS is
explained in more detail in the Microsoft knowledgebase at http://support.microsoft.com/kb/321051.
a. Install a certificate authority in the Windows Com ponents section in Add/Rem ove
Program s.
b. Select the Enterprise Root CA option.
c. Reboot the Active Directory server. If IIS web services are running, the CA certificate can be
accessed by opening http://servername/certsrv.
d. Set up the Active Directory server to use the SSL server certificate.
a. Create a certificate request .inf, using the fully-qualified domain name of the Active
Directory as the certificate subject. For example:
;----------------- request.inf ----------------[Version]
Signature="$Windows NT$
[NewRequest]
Subject = "CN=ad.server.example.com, O=Engineering, L=Raleigh,
S=North Carolina, C=US"
KeySpec = 1
KeyLength = 2048
Exportable = TRUE
MachineKeySet = TRUE
SMIME = False
PrivateKeyArchive = FALSE
UserProtected = FALSE
UseExistingKeySet = FALSE
ProviderName = "Microsoft RSA SChannel Cryptographic Provider"
ProviderType = 12
RequestType = PKCS10
KeyUsage = 0xa0
[EnhancedKeyUsageExtension]
116
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
OID=1.3.6.1.5.5.7.3.1
;-----------------------------------------------
For more information on the .inf request file, see the Microsoft documentation, such
as http://technet.microsoft.com/en-us/library/cc783835.aspx.
b. Generate the certificate request.
certreq -new request.inf request.req
c. Submit the request to the Active Directory CA. For example:
certreq -submit request.req certnew.cer
NOTE
If the command-line tool returns an error message, then use the Web browser to
access the CA and submit the certificate request. If IIS is running, then the CA
URL is http://servername/certsrv.
d. Accept the certificate request. For example:
certreq -accept certnew.cer
e. Make sure that the server certificate is present on the Active Directory server.
In the File menu, click Add/Remove, then click Certificates and
Personal>Certificates.
f. Import the CA certificate from Directory Server into Active Directory. Click T rusted
Root CA, then Im port, and browse for the Directory Server CA certificate.
e. Reboot the domain controller.
7.6.2. Setting up Password Synchronization
Install the Password Sync Service on every domain controller in the Active Directory domain in order to
synchronize Windows passwords.
1. Download the PassSync.m si file to the Active Directory machine.
a. Log into the Customer Portal.
b. Click the Downloads tab.
c. Click the Red Hat Enterprise Linux downloads button in the middle of the page.
d. Filter the downloads by using a search term such as Directory Server, and then expand one
of the Red Hat Enterprise Linux versions.
e. Click the Directory Server link.
117
Red Hat Enterprise Linux 7 Windows Integration Guide
f. On the Directory Server page, download the appropriate version of the WinSync Installer. T his
is the Password Sync MSI file (RedHat-PassSync-1.1.5-arch.m si).
NOTE
Regardless of the Red Hat Enterprise Linux architecture, there are two PassSync packages
available, one for 32-bit Windows servers and one for 64-bit. Make sure to select the
appropriate packages for your Windows platform.
2. Double-click the Password Sync MSI file to install it.
3. T he Password Sync Setup window appears. Hit Next to begin installing.
4. Fill in the information to establish the connection to the IdM server.
T he IdM server connection information, including the hostname and secure port number.
T he username of the system user which Active Directory uses to connect to the IdM machine.
T his account is configured automatically when sync is configured on the IdM server. T he default
account is uid=passsync,cn=sysaccounts,cn=etc,dc=exam ple,dc=com .
T he password set in the --passsync option when the sync agreement was created.
T he search base for the people subtree on the IdM server. T he Active Directory server connects
to the IdM server similar to an ldapsearch or replication operation, so it has to know where in
the IdM subtree to look for user accounts. T he user subtree is
cn=users,cn=accounts,dc=exam ple,dc=com .
T he certificate token is not used at this time, so that field should be left blank.
Hit Next, then Finish to install Password Sync.
118
⁠C hapter 7. Synchronizing Active Directory and Identity Management Users
5. Import the IdM server's CA certificate into the Active Directory certificate store.
a. Download the IdM server's CA certificate from
http://ipa.exam ple.com /ipa/config/ca.crt.
b. Copy the IdM CA certificate to the Active Directory server.
c. Install the IdM CA certificate in the Password Sync database. For example:
cd "C:\Program Files\Red Hat Directory Password Synchronization"
certutil.exe -d . -A -n "IPASERVER.EXAMPLE.COM IPA CA" -t CT,, -a -i
ipaca.crt
cd "C:\Program Files\389 Directory Password Synchronization"
certutil.exe -d . -A -n "IPASERVER.EXAMPLE.COM IPA CA" -t CT,, -a -i
ipaca.crt
6. Reboot the Windows machine to start Password Sync.
NOTE
T he Windows machine must be rebooted. Without the rebooting, PasswordHook.dll is not
enabled, and password synchronization will not function.
7. If passwords for existing accounts should be synchronized, reset the user passwords.
NOTE
T he Password Sync client captures password changes and then synchronizes them
between Active Directory and IdM. T his means that it synchronizes new passwords or
password updates.
Existing passwords, which are stored in a hashed form in both IdM and Active Directory,
cannot be decrypted or synchronized when the Password Sync client is installed, so existing
passwords are not synchronized. User passwords must be changed to initiate
synchronization between the peer servers.
T he first attempt to synchronize passwords, which happened when the Password Sync application is
installed, will always fail because of the SSL connection between the Directory Server and Active Directory
sync peers. T he tools to create the certificate and key databases is installed with the .m si.
7.6.3. Allowing Users to Change Other Users' Passwords Cleanly
By default, every time an administrator changes a user password, that user is required to reset the
password at the next login. However, this behavior can be changed to allow administrators to reset a
password without requiring an immediate password reset.
T he passSyncManagersDNs attribute lists administrator accounts which are allowed to perform password
change operations and which will not then require a password reset.
119
Red Hat Enterprise Linux 7 Windows Integration Guide
IMPORTANT
T his is required for password synchronization because, otherwise, whenever a password is
synchronized, the IdM server would interpret that as a password change operation and then require
a password change at the next login.
Edit the password synchronization entry, cn=ipa_pwd_extop,cn=plugins,cn=config, and add the
passSyncManagersDNs attribute with the name of the user. T his attribute is multi-valued. For example:
$ ldapmodify -x -D "cn=Directory Manager" -w secret -h ldap.example.com -p 389
dn: cn=ipa_pwd_extop,cn=plugins,cn=config
changetype: modify
add: passSyncManagersDNs
passSyncManagersDNs: uid=admin,cn=users,cn=accounts,dc=example,dc=com
WARNING
Be careful to limit the listed DNs only to administrator accounts which require the ability to set user
passwords. Any user listed here is given access to all user passwords, which is extremely
powerful.
[4] The cn is treated d ifferently than o ther s ync ed attrib utes . It is map p ed d irec tly (cn to cn) when s ync ing fro m Id entity Manag ement
to Ac tive Direc to ry. When s ync ing fro m Ac tive Direc to ry to Id entity Manag ement, ho wever, cn is map p ed fro m the name attrib ute o n
Wind o ws to the cn attrib ute in Id entity Manag ement.
Index
A
Active Directory
- global catalog, About Active Directory Identities on the Local System
- schema differences between Identity Management, User Schema Differences between
Identity Management and Active Directory
S
schema
- differences between Identity Management and Active Directory, User Schema Differences
between Identity Management and Active Directory
- cn, Values for cn Attributes
- initials, Constraints on the initials Attribute
- sn, Requiring the surname (sn) Attribute
- street and streetAddress, Values for street and streetAddress
SSSD
- Active Directory
- global catalog, About Active Directory Identities on the Local System
120
⁠Index
- Microsoft Active Directory domain, Configuring an Active Directory Domain with ID Mapping,
Configuring Active Directory as an LDAP Domain
121
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
