HIGH ISOLATION VOLTAGE SSOP PHOTOCOUPLER
DESCRIPTION
The PS2801-1 and PS2801-4 are optically coupled isolators containing a GaAs light emitting diode and an NPN silicon
phototransistor in a plastic SSOP for high density applications.
This package has shield effect to cut off ambient light.
FEATURES
•
•
•
•
<R> •
•
<R> •
High isolation voltage (BV = 2 500 Vr.m.s.)
Small and thin package (4,16-pin SSOP, Pin pitch 1.27 mm)
High collector to emitter voltage (VCEO = 80 V)
High-speed switching (tr = 3 μs TYP., tf = 5 μs TYP.)
Ordering number of tape product: PS2801-1-F3, PS2801-4-F3
Pb-Free product
Safety standards
• UL approved: No. E72422
• BSI approved (BS EN 60065, BS EN 60950)
• CSA approved: No. CA 101391(CA5A, CAN/CSA-C22.2 60065, 60950)
• DIN EN 60747-5-5 (VDE 0884-5) approved (Option)
PIN CONNECTION
(Top View)
PS2801-1
4 3
1. Anode
2. Cathode
3. Emitter
4. Collector
1 2
PS2801-4
16 15 14 13 12 11 10 9
1 2 3 4 5 6 7 8
1. 3. 5. 7.
2. 4. 6. 8.
9. 11. 13. 15.
10. 12. 14. 16.
APPLICATIONS
•
•
•
•
Programmable logic controllers
Measuring instruments
Power supply
Hybrid IC
Anode
Cathode
Emitter
Collector
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 1 of 14
PS2801-1, PS2801-4
PACKAGE DIMENSIONS (UNIT: mm)
PS2801-1
PS2801-4
2.7±0.3
7.0±0.3
4.4
4.4
0.1±0.1
0.5±0.3
1.27
0.4±0.1
0.12 M
<R>
0.15+0.10
–0.05
7.0±0.3
2.0+0.3
–0.2
0.15+0.10
–0.05
2.0±0.1
0.1±0.1
10.3±0.3
0.40+0.10
–0.05
0.12 M
1.27
0.5±0.3
PHOTOCOUPLER CONSTRUCTION
Parameter
Unit (MIN.)
Air Distance
4.5 mm
Outer Creepage Distance
Inner Creepage Distance
Isolation Thickness
4.5 mm
2.5 mm
0.1 mm
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 2 of 14
PS2801-1, PS2801-4
<R>
MARKING EXAMPLE
PS2801-1
Company initial
Made in Taiwan
Last 1 numbers of type
No. : 1
Assembly Lot
301
Week Assembled
Year Assembled (Last 1 digit)
Made in Taiwan
Halogen free
"
" (Vertical bar)
:Made in Taiwan & Halogen free
"
" (Square)
:Made in Japan
"
" (Horizontal bar)
:Made in Japan & Halogen free
Made in Japan
Made in Japan
Halogen free
PS2801-4
R
Country Assembled
PS2801-4
NL301
Assembly Lot
No. 1 pin
Mark
N L 3 01
Week Assembled
Year Assembled
(Last 1 Digit)
In-house Code
(L: Pb-Free)
Rank Code
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 3 of 14
PS2801-1, PS2801-4
<R>
ORDERING INFORMATION
Part Number
Order Number
PS2801-1-F3
PS2801-1-F3-A
PS2801-1-V-F3
Solder Plating
Specification
Pb-Free
PS2801-1-V-F3-A
Safety Standard
Approval
Packing Style
Embossed Tape 3 500
Standard products
pcs/reel
(UL, BSI, CSA
approved)
Embossed Tape 3 500
DIN EN 60747-5-5
pcs/reel
Application
*1
Part Number
PS2801-1
(VDE 0884-5)
Approved (Option)
PS2801-4-F3
PS2801-4-F3-A
PS2801-4-V-F3
PS2801-4-V-F3-A
Embossed Tape 2 500
Standard products
pcs/reel
(UL, BSI, CSA
approved)
Embossed Tape 2 500
DIN EN 60747-5-5
pcs/reel
PS2801-4
(VDE 0884-5)
Approved (Option)
PS2801-1-F3
PS2801-1Y-F3-A
Special version
(Pb-Free and
Halogen Free)
PS2801-1-V-F3
PS2801-1Y-V-F3-A
Embossed Tape 3 500
pcs/reel
Standard products
Embossed Tape 3 500
DIN EN 60747-5-5
pcs/reel
(VDE 0884-5)
PS2801-1
(UL, BSI, CSA
approved)
Approved (Option)
Note:
*
1. For the application of the Safety Standard, following part number should be used.
ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified)
Diode
Parameter
Symbol
Ratings
PS2801-1
PS2801-4
Unit
Forward Current (DC)
IF
50
mA/ch
Reverse Voltage
VR
6
V
Power Dissipation Derating
Power Dissipation
*1
ΔPD/°C
0.6
0.8
mW/°C
PD
60
80
mW/ch
IFP
1
A/ch
Collector to Emitter Voltage
VCEO
80
V
Emitter to Collector Voltage
VECO
6
V
IC
50
mA/ch
ΔPC/°C
1.2
mW/°C
PC
120
mW/ch
BV
2 500
Vr.m.s.
Operating Ambient Temperature
TA
−55 to +100
°C
Storage Temperature
Tstg
−55 to +150
°C
Peak Forward Current
Transistor
Collector Current
Power Dissipation Derating
Power Dissipation
Isolation Voltage
Notes:
*
*2
1. PW = 100 μs, Duty Cycle = 1%
2. AC voltage for 1 minute at TA = 25°C, RH = 60% between input and output.
Pins 1-2 shorted together, 3-4 shorted together (PS2801-1).
Pins 1-8 shorted together, 9-16 shorted together (PS2801-4).
*
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 4 of 14
PS2801-1, PS2801-4
ELECTRICAL CHARACTERISTICS (TA = 25°C)
Parameter
Diode
Symbol
Conditions
Forward Voltage
VF
IF = 5 mA
Reverse Current
IR
VR = 5 V
Terminal Capacitance
Ct
V = 0 V, f = 1.0 MHz
Transistor
Collector to Emitter
Dark Current
ICEO
VCE = 80 V, IF = 0 mA
Coupled
Current Transfer Ratio
*1
(IC/IF)
CTR
IF = 5 mA, VCE = 5 V
Collector Saturation
Voltage
VCE (sat)
IF = 10 mA, IC = 2 mA
Isolation Resistance
RI-O
VI-O = 1.0 kVDC
Isolation Capacitance
CI-O
V = 0 V, f = 1.0 MHz
Rise Time
Fall Time
*2
tr
*2
<R>
Turn-on Time
*2
<R>
Turn-off Time
*2
Notes:
MIN.
TYP.
MAX.
Unit
1.1
1.4
V
5
μA
15
pF
80
10
VCC = 5 V, IC = 2 mA, RL = 100 Ω
100
nA
600
%
0.3
V
11
Ω
0.4
pF
3
μs
tf
5
ton
6
toff
5
*
1. CTR rank (PS2801-1 only)
K : 300 to 600 (%)
P : 150 to 300 (%)
L : 100 to 300 (%)
N : 80 to 600 (%)
*
2. Test circuit for switching time
VCC
Pulse Input
PW = 100 μ s
Duty Cycle = 1/10
Input
ton
IF
td
toff
ts
VOUT
50 Ω
RL = 100 Ω
90%
Output
10%
tr
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
tf
Page 5 of 14
PS2801-1, PS2801-4
TYPICAL CHARACTERISTICS (TA = 25°C, unless otherwise specified)
DIODE POWER DISSIPATION vs.
AMBIENT TEMPERATURE
TRANSISTOR POWER DISSIPATION
vs. AMBIENT TEMPERATURE
PS2801-4
75
50
Transistor Power Dissipation PC (mW)
Diode Power Dissipation PD (mW)
100
0.8 mW/°C
PS2801-1
0.6 mW/°C
25
0
25
50
75
100
100
PS2801-1
PS2801-4
1.2 mW/°C
50
25
75
50
100
Ambient Temperature TA (°C)
FORWARD CURRENT vs.
FORWARD VOLTAGE
COLLECTOR CURRENT vs.
COLLECTOR TO EMITTER VOLTAGE
70
TA = +100°C
+60°C
+25°C
60
10
5
0°C
–25°C
–55°C
1
0.5
50
40
50
30
20
mA
mA
20 mA
10
IF = 5 mA
10
0.1
0.7
150
Ambient Temperature TA (°C)
Collector Current IC (mA)
Forward Current IF (mA)
50
200
0
100
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
0
2
4
6
8
10
Forward Voltage VF (V)
Collector to Emitter Voltage VCE (V)
COLLECTOR TO EMITTER DARK
CURRENT vs. AMBIENT TEMPERATURE
COLLECTOR CURRENT vs.
COLLECTOR SATURATION VOLTAGE
40
10 000
VCE = 80 V
40 V
24 V
10 V
5V
1 000
Collector Current IC (mA)
Collector to Emitter Dark Current ICEO (nA)
<R>
100
10
50 mA
20 mA
10
10 mA
5 mA
5
2 mA
IF = 1 mA
1
0.5
1
0.1
–50
–25
0
25
50
75
100
Ambient Temperature TA (°C)
0
0.2
0.4
0.6
0.8
1.0
Collector Saturation Voltage VCE (sat) (V)
Remark The graphs indicate nominal characteristics.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 6 of 14
PS2801-1, PS2801-4
CURRENT TRANSFER RATIO vs.
FORWARD CURRENT
1.2
Current Transfer Ratio CTR (%)
Normalized Current Transfer Ratio CTR
NORMALIZED CURRENT TRANSFER
RATIO vs. AMBIENT TEMPERATURE
1.0
0.8
0.6
0.4
Normalized to 1.0
at TA = 25°C,
IF = 5 mA, VCE = 5 V
0.2
200
150
100
50
0.0
–50
0
–25
25
50
100
75
0.1
1.0
10
100
Forward Current IF (mA)
SWITCHING TIME vs.
LOAD RESISTANCE
SWITCHING TIME vs.
LOAD RESISTANCE
1 000
VCC = 5 V,
50 IC = 2 mA,
CTR = 236%
VCC = 5 V,
IF = 5 mA,
CTR = 236%
Switching Time t (μs)
tf
tr
10
5
td
ts
1
0.5
0.1
0.01
0.02
Ambient Temperature TA (°C)
100
Switching Time t (μs)
300 VCE = 5 V,
n=3
250
0.05 0.1
0.5
1
5
10
tf
100
ts
10
tr
td
1
0.1
0.1
1
10
100
Load Resistance RL (kΩ)
Load Resistance RL (kΩ)
FREQUENCY RESPONSE
IF = 5 mA,
VCE = 5 V
Normalized Gain Gv
0
–5
–10
RL = 1 kΩ
–15
100 Ω
–20
0.5
1
2
5
10 20
300 Ω
50 100 200 500
Frequency f (kHz)
Remark The graphs indicate nominal characteristics.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 7 of 14
PS2801-1, PS2801-4
TAPING SPECIFICATIONS (UNIT: mm)
2.0±0.1
4.0±0.1
φ 1.5+0.1
–0
16.0±0.3
7.55±0.1
1.75±0.1
Outline and Dimensions (Tape)
7.5±0.1
2.8 MAX.
0.3
1.55±0.1
2.3±0.1
2.85±0.1
4.0±0.1
Tape Direction
PS2801-1-F3
R1
301
R1
301
R1
301
R1
301
R1
301
Outline and Dimensions (Reel)
2.0±0.5
φ13.0±0.2
R 1.0
φ 21.0±0.8
φ 100±1.0
2.0±0.5
φ 330±2.0
<R>
17.5±1.0
21.5±1.0
Packing: 3 500 pcs/reel
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
15.9 to 19.4
Outer edge of
flange
Page 8 of 14
PS2801-1, PS2801-4
10.7±0.1
2.8 MAX.
16.0±0.3
φ 1.5+0.1
–0
7.5±0.1
2.0±0.1
4.0±0.1
1.75±0.1
Outline and Dimensions (Tape)
0.3
2.3±0.1
8.3±0.1
1.55±0.1
12.0±0.1
Tape Direction
PS2801-4-F3
Outline and Dimensions (Reel)
R 1.0
φ 21.0±0.8
φ 100±1.0
2.0±0.5
φ13.0±0.2
φ 330±2.0
2.0±0.5
17.5±1.0
21.5±1.0
Packing: 2 500 pcs/reel
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
15.9 to 19.4
Outer edge of
flange
Page 9 of 14
PS2801-1, PS2801-4
RECOMMENDED MOUNT PAD DIMENSIONS (UNIT: mm)
0.8
1.45
1.27
<R>
6.25
Remark All dimensions in this figure must be evaluated before use.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 10 of 14
PS2801-1, PS2801-4
NOTES ON HANDLING
1. Recommended soldering conditions
(1) Infrared reflow soldering
• Peak reflow temperature
• Time of peak reflow temperature
• Time of temperature higher than 220°C
• Time to preheat temperature from 120 to 180°C
• Number of reflows
• Flux
260°C or below (package surface temperature)
10 seconds or less
60 seconds or less
120±30 s
Three
Rosin flux containing small amount of chlorine (The
flux with a maximum chlorine content of 0.2 Wt% is
recommended.)
Package Surface Temperature T (°C)
Recommended Temperature Profile of Infrared Reflow
(heating)
to 10 s
260°C MAX.
220°C
to 60 s
180°C
120°C
120±30 s
(preheating)
Time (s)
(2) Wave soldering
• Temperature
• Time
• Preheating conditions
• Number of times
•
Flux
(3) Soldering by Soldering Iron
• Peak Temperature (lead part temperature)
• Time (each pins)
• Flux
<R>
260°C or below (molten solder temperature)
10 seconds or less
120°C or below (package surface temperature)
One (Allowed to be dipped in solder including plastic
mold portion.)
Rosin flux containing small amount of chlorine (The flux
with a maximum chlorine content of 0.2 Wt% is
recommended.)
350°C or below
3 seconds or less
Rosin flux containing small amount of chlorine (The flux
with a maximum chlorine content of 0.2 Wt% is
recommended.)
(a) Soldering of leads should be made at the point 1.5 to 2.0 mm from the root of the lead
(4) Cautions
• Fluxes
Avoid removing the residual flux with freon-based and chlorine-based cleaning solvent.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 11 of 14
PS2801-1, PS2801-4
2. Cautions regarding noise
Be aware that when voltage is applied suddenly between the photocoupler’s input and output or between collectoremitters at startup, the output transistor may enter the on state, even if the voltage is within the absolute maximum
ratings.
3. Measurement conditions of current transfer ratios (CTR), which differ according to photocoupler
Check the setting values before use, since the forward current conditions at CTR measurement differ according to
product.
When using products other than at the specified forward current, the characteristics curves may differ from the
standard curves due to CTR value variations or the like. This tendency may sometimes be obvious, especially below
IF = 1 mA.
Therefore, check the characteristics under the actual operating conditions and thoroughly take variations or the like
into consideration before use.
USAGE CAUTIONS
1. Protect against static electricity when handling.
2. Avoid storage at a high temperature and high humidity.
<R>
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 12 of 14
PS2801-1, PS2801-4
<R>
SPECIFICATION OF VDE MARKS LICENSE DOCUMENT
Parameter
Symbol
Climatic test class (IEC 60068-1/DIN EN 60068-1)
Dielectric strength
maximum operating isolation voltage
Test voltage (partial discharge test, procedure a for type test and
random test)
Upr = 1.6 × UIORM, Pd < 5 pC
Spec.
Unit
55/100/21
UIORM
Upr
705
1 128
Vpeak
Vpeak
Test voltage (partial discharge test, procedure b for all devices)
Upr = 1.875 × UIORM, Pd < 5 pC
Upr
1 322
Vpeak
Highest permissible overvoltage
UTR
6 000
Vpeak
CTI
175
Degree of pollution (DIN EN 60664-1 VDE 0110 Part 1)
Comparative tracking index (IEC 60112/DIN EN 60112 (VDE 0303
Part 11))
2
Material group (DIN EN 60664-1 VDE 0110 Part 1)
III a
Storage temperature range
Tstg
−55 to +150
°C
Operating temperature range
TA
−55 to +100
°C
Ris MIN.
Ris MIN.
1012
11
10
Ω
Ω
Tsi
Isi
Psi
150
300
500
°C
mA
mW
Ris MIN.
109
Ω
Isolation resistance, minimum value
VIO = 500 V dc at TA = 25°C
VIO = 500 V dc at TA MAX. at least 100°C
Safety maximum ratings (maximum permissible in case of fault, see
thermal derating curve)
Package temperature
Current (input current IF, Psi = 0)
Power (output or total power dissipation)
Isolation resistance
VIO = 500 V dc at TA = Tsi
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 13 of 14
PS2801-1, PS2801-4
Caution
GaAs Products
This product uses gallium arsenide (GaAs).
GaAs vapor and powder are hazardous to human health if inhaled or ingested, so please observe
the following points.
• Follow related laws and ordinances when disposing of the product. If there are no applicable laws
and/or ordinances, dispose of the product as recommended below.
1. Commission a disposal company able to (with a license to) collect, transport and dispose of
materials that contain arsenic and other such industrial waste materials.
2. Exclude the product from general industrial waste and household garbage, and ensure that the
product is controlled (as industrial waste subject to special control) up until final disposal.
• Do not burn, destroy, cut, crush, or chemically dissolve the product.
• Do not lick the product or in any way allow it to enter the mouth.
R08DS0096EJ0500 Rev.5.00
Jan 23, 2013
Page 14 of 14
Revision History
PS2801-1, PS2801-4 Data Sheet
Rev.
Date
Page
1.00
5.00
Mar 31, 2003
Jan 17, 2013
−
Throughout
p.1
p.2
p.3
p.4
p.5
p.6
p.7
p.8
p.10
p.11
p.12
p.13
Description
Summary
This data sheet was released as PN10251EJ01V0DS
Renesas format is applied to this data sheet.
The ordering number and safety standards are revised.
PHOTOCOUPLER CONSTRUCTION is added.
The explanation in MARKING EXAMPLE is revised.
ORDERING INFORMATION is modified with the revision of the safety
standards.
Turn-on Time (ton) and Turn-off Time (toff) are added to the table in
ELECTRICAL CHARACTERISTICS.
The graph of LONG TERM CTR DEGRADATION is deleted from those in
TYPICAL CHARACTERISTICS.
PS2801-1-F4 is deleted from Tape Direction image in TAPING
SPECIFICATIONS.
PS2801-4-F4 is deleted from Tape Direction image in TAPING
SPECIFICATIONS.
RECOMMENDED MOUNT PAD DIMENSIONS is added.
The note about temperature condition of the recommended soldering
conditions is deleted.
PROGRAMMABLE LOGIC CONTROLLERS EXMAPLE is deleted.
SPECIFICATION OF VDE MARKS LICENSE DOCUMENT is changed to the
same as PS2801C.
All trademarks and registered trademarks are the property of their respective owners.
C-1
Notice
1.
Descriptions of circuits, software and other related information in this document are provided only to illustrate the operation of semiconductor products and application examples. You are fully responsible for
the incorporation of these circuits, software, and information in the design of your equipment. Renesas Electronics assumes no responsibility for any losses incurred by you or third parties arising from the
use of these circuits, software, or information.
2.
Renesas Electronics has used reasonable care in preparing the information included in this document, but Renesas Electronics does not warrant that such information is error free. Renesas Electronics
3.
Renesas Electronics does not assume any liability for infringement of patents, copyrights, or other intellectual property rights of third parties by or arising from the use of Renesas Electronics products or
assumes no liability whatsoever for any damages incurred by you resulting from errors in or omissions from the information included herein.
technical information described in this document. No license, express, implied or otherwise, is granted hereby under any patents, copyrights or other intellectual property rights of Renesas Electronics or
others.
4.
You should not alter, modify, copy, or otherwise misappropriate any Renesas Electronics product, whether in whole or in part. Renesas Electronics assumes no responsibility for any losses incurred by you or
5.
Renesas Electronics products are classified according to the following two quality grades: "Standard" and "High Quality". The recommended applications for each Renesas Electronics product depends on
third parties arising from such alteration, modification, copy or otherwise misappropriation of Renesas Electronics product.
the product's quality grade, as indicated below.
"Standard": Computers; office equipment; communications equipment; test and measurement equipment; audio and visual equipment; home electronic appliances; machine tools; personal electronic
equipment; and industrial robots etc.
"High Quality": Transportation equipment (automobiles, trains, ships, etc.); traffic control systems; anti-disaster systems; anti-crime systems; and safety equipment etc.
Renesas Electronics products are neither intended nor authorized for use in products or systems that may pose a direct threat to human life or bodily injury (artificial life support devices or systems, surgical
implantations etc.), or may cause serious property damages (nuclear reactor control systems, military equipment etc.). You must check the quality grade of each Renesas Electronics product before using it
in a particular application. You may not use any Renesas Electronics product for any application for which it is not intended. Renesas Electronics shall not be in any way liable for any damages or losses
incurred by you or third parties arising from the use of any Renesas Electronics product for which the product is not intended by Renesas Electronics.
6.
You should use the Renesas Electronics products described in this document within the range specified by Renesas Electronics, especially with respect to the maximum rating, operating supply voltage
range, movement power voltage range, heat radiation characteristics, installation and other product characteristics. Renesas Electronics shall have no liability for malfunctions or damages arising out of the
use of Renesas Electronics products beyond such specified ranges.
7.
Although Renesas Electronics endeavors to improve the quality and reliability of its products, semiconductor products have specific characteristics such as the occurrence of failure at a certain rate and
malfunctions under certain use conditions. Further, Renesas Electronics products are not subject to radiation resistance design. Please be sure to implement safety measures to guard them against the
possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas Electronics product, such as safety design for hardware and software including but not limited to
redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other appropriate measures. Because the evaluation of microcomputer software alone is very difficult,
please evaluate the safety of the final products or systems manufactured by you.
8.
Please contact a Renesas Electronics sales office for details as to environmental matters such as the environmental compatibility of each Renesas Electronics product. Please use Renesas Electronics
products in compliance with all applicable laws and regulations that regulate the inclusion or use of controlled substances, including without limitation, the EU RoHS Directive. Renesas Electronics assumes
no liability for damages or losses occurring as a result of your noncompliance with applicable laws and regulations.
9.
Renesas Electronics products and technology may not be used for or incorporated into any products or systems whose manufacture, use, or sale is prohibited under any applicable domestic or foreign laws or
regulations. You should not use Renesas Electronics products or technology described in this document for any purpose relating to military applications or use by the military, including but not limited to the
development of weapons of mass destruction. When exporting the Renesas Electronics products or technology described in this document, you should comply with the applicable export control laws and
regulations and follow the procedures required by such laws and regulations.
10. It is the responsibility of the buyer or distributor of Renesas Electronics products, who distributes, disposes of, or otherwise places the product with a third party, to notify such third party in advance of the
contents and conditions set forth in this document, Renesas Electronics assumes no responsibility for any losses incurred by you or third parties as a result of unauthorized use of Renesas Electronics
products.
11. This document may not be reproduced or duplicated in any form, in whole or in part, without prior written consent of Renesas Electronics.
12. Please contact a Renesas Electronics sales office if you have any questions regarding the information contained in this document or Renesas Electronics products, or if you have any other inquiries.
(Note 1)
"Renesas Electronics" as used in this document means Renesas Electronics Corporation and also includes its majority-owned subsidiaries.
(Note 2)
"Renesas Electronics product(s)" means any product developed or manufactured by or for Renesas Electronics.
http://www.renesas.com
SALES OFFICES
Refer to "http://www.renesas.com/" for the latest and detailed information.
California Eastern Laboratories, Inc.
4590 Patrick Henry Drive, Santa Clara, California 95054, U.S.A.
Tel: +1-408-919-2500, Fax: +1-408-988-0279
Renesas Electronics Europe Limited
Dukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K
Tel: +44-1628-651-700, Fax: +44-1628-651-804
Renesas Electronics Europe GmbH
Arcadiastrasse 10, 40472 Düsseldorf, Germany
Tel: +49-211-65030, Fax: +49-211-6503-1327
Renesas Electronics (China) Co., Ltd.
7th Floor, Quantum Plaza, No.27 ZhiChunLu Haidian District, Beijing 100083, P.R.China
Tel: +86-10-8235-1155, Fax: +86-10-8235-7679
Renesas Electronics (Shanghai) Co., Ltd.
Unit 204, 205, AZIA Center, No.1233 Lujiazui Ring Rd., Pudong District, Shanghai 200120, China
Tel: +86-21-5877-1818, Fax: +86-21-6887-7858 / -7898
Renesas Electronics Hong Kong Limited
Unit 1601-1613, 16/F., Tower 2, Grand Century Place, 193 Prince Edward Road West, Mongkok, Kowloon, Hong Kong
Tel: +852-2886-9318, Fax: +852 2886-9022/9044
Renesas Electronics Taiwan Co., Ltd.
13F, No. 363, Fu Shing North Road, Taipei, Taiwan
Tel: +886-2-8175-9600, Fax: +886 2-8175-9670
Renesas Electronics Singapore Pte. Ltd.
80 Bendemeer Road, Unit #06-02 Hyflux Innovation Centre Singapore 339949
Tel: +65-6213-0200, Fax: +65-6213-0300
Renesas Electronics Malaysia Sdn.Bhd.
Unit 906, Block B, Menara Amcorp, Amcorp Trade Centre, No. 18, Jln Persiaran Barat, 46050 Petaling Jaya, Selangor Darul Ehsan, Malaysia
Tel: +60-3-7955-9390, Fax: +60-3-7955-9510
Renesas Electronics Korea Co., Ltd.
11F., Samik Lavied' or Bldg., 720-2 Yeoksam-Dong, Kangnam-Ku, Seoul 135-080, Korea
Tel: +82-2-558-3737, Fax: +82-2-558-5141
© 2012 Renesas Electronics Corporation. All rights reserved.
[Colophon 2.2]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
