Layer Zero Solutions Guide

Layer Zero Solutions Guide

Table of Contents

n

Layer Zero n

Mighty Mo Cabinets n

Mighty Mo Cabinet Accessories n

Mighty Mo GX Cabinets n

Mighty Mo GX Cabinet Accessories n

Mighty Mo Wall Mount Cabinets n

Mighty Mo General Cabinet Accessories n

Mighty Mo 10 Racks n

Mighty Mo 6 Racks n

Mighty Mo Rack Accessories n

Standard EIA Racks n

Standard EIA Rack Accessories n

Standard EIA Wall Mount Racks & Brackets n

Horizontal Cable Management, Shelves & Accessories n

General Rack & Cabinet Accessories n

Mighty Mo Air Control n

Tubular Runway & Accessories n

Bonding & Grounding n

Mighty Mo Fiber Raceway n

Cablofil

Solutions

n

Technical Information

180

192

204

210

150

158

161

170

120

126

132

140

48

110

114

116

2

12

42

232

250

Layer Zero

®

The Infrastructure Layer, Stabilizes the Network

“With the right planning, the defining elements of capacity, density, efficiency and scalability can be aligned through the infrastructure. One basic best practice:

adopt the rack as the basic building block for data center density.”

Energy Efficient

Data Center Solutions and

Best Practices, CISCO

Layer Zero – The Infrastructure Layer is the proposed foundation for the ISO/OSI model. Layer Zero addresses the critical role that the physical infrastructure plays in data storage and accessibility. Layer Zero solutions encompass the entire physical infrastructure that supports your network, including aisle containment, racks, cabinets, advanced cable management, pathway solutions, underfloor and overhead systems. By recognizing the importance of the underlying infrastructure layer and emphasizing best practices in pathway and physical support design, a new level of efficiency can be created for the network.

To meet today’s data usage, networks are being pushed to the limit by exponential growth of data storage and availability requirements. The result is a capacity and technology infrastructure that is overwhelmed by demands, with no end in sight: n ■

Lawrence Berkeley National Laboratory calculates that the

cloud consumes 1 to 2% of the world’s electricity

1 n ■

Gartner is predicting an 800% data growth over the next

5 years (2010 – 2015)

3 n ■

Data centers worldwide now consume more energy annually

than Sweden

1 n ■

Data center emissions are now approaching the same

quantities as countries such as Argentina or the

Netherlands.

2

Current projections show worldwide

carbon emissions from data centers will quadruple by 2020

2

.

1. Jonathan Koomey, a scientist at Lawrence Berkeley National Laboratory, as reported

by Tom Vanderbilt, NYTimes 06.08.2009.

2. 11.2008 McKinsey & Company.

3. Gartner, Infrastructure and Operations: Top 10 Trends to Watch, presented by

Ray Paquet 11.18.2010.

How does Layer Zero impact the network?

The innovative Layer Zero approach to physical infrastructure solutions can maximize network performance in a data center, commercial office, healthcare facility or educational institution. Layer

Zero solutions can have a dramatic effect on the system by lowering the overall temperature in the data center, reducing the risk of equipment failure and enhancing system performance, all while providing significant energy savings.

7 key elements to an effective network

Legrand | Ortronics has identified 7 key elements that shape the effectiveness of your network.

Managing these 7 elements will maximize your network’s potential and assure best practices.

n ■

Flexibility

n ■

Scalability

n ■

Density

n ■

Performance

n ■

Energy efficiency

n ■

Airflow

n ■

Protection l

Cabinet size appropriate for my switches?

t

Do I need aisle containment?

Proper cable management installed?

(bend limiting clips, cable management cages)

A scalable solution?

What’s my switch configuration?

3

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

www.kaishinlab.com

Layer Zero

®

The Infrastructure Layer, Stabilizes the Network

Effective space utilization requires an infrastructure that is agile and can adapt to changing environmental conditions. Ortronics solutions are fully modular and are configurable to suit the needs of your specific installation, be it a top of rack, middle of row or end of row.

Flexibility

A well thought out Layer Zero infrastructure assures a flexible physical design with solutions that effectively use network space, are fully modular and mitigate the impact of moves, adds and changes. Layer Zero solutions can be adjusted even after installation to adopt to your changing needs.

Scalability

Networks require infrastructure solutions that can be quickly and seamlessly reproduced, without disrupting the flow of business. The faster new equipment can be deployed and brought online, the greater the cost savings to the network manager. Layer Zero solutions are engineered to exceed today’s and tomorrow’s higher capacity environments and are able to facilitate growth in a timely and cost effective way.

Mighty Mo Cabinets

Mighty Mo GX Cabinets

Mighty Mo 6 Racks

Mighty Mo 10 Racks

5

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Layer Zero

®

The Infrastructure Layer, Stabilizes the Network

Layer Zero solutions help optimize network real estate by accommodating for higher density equipment. Mighty Mo cabinets and racks have ample space and static capacity for the latest switching equipment while implementing passive thermal management to balance the additional load.

Density

As chip power increases and density capacity rises, power requirements and heat output are concentrated to smaller areas. Layer Zero solutions help optimize space constrained network real estate by accommodating higher density equipment and connectivity solutions.

Performance

Layer Zero solutions help reduce capital and operational expenditures and maintain the integrity of active equipment by properly supporting the network physical infrastructure, connectivity and power distribution equipment.

Energy Efficiency

Passive cooling is the most energy efficient way to manage airflow and thermal loads of active equipment.

Legrand | Ortronics physical support systems use completely passive thermal management to increase airflow efficiency.

True passive cooling systems lower the ambient room temperature without introducing the additional power consumption of fans.

Mighty Mo cable management supports the density demands of virtualization, convergence and consolidation; with deeper cable channels to provide ample room even when a switch is loaded to capacity.

Excessive bending, kinking or allowing too much force to be exerted on the cables can negatively impact ethernet network performance.

7

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Layer Zero

®

The Infrastructure Layer, Stabilizes the Network

A crucial aspect of airflow design is to maintain the separation between the hot and cold aisles.

The Mighty Mo Air

Control containment solution contains and directs cold air where it is needed, enhancing the separation of the hot and cold aisles.

Airflow

Excessive heat is the primary enemy of most networking equipment. Layer Zero infrastructure solutions leverage the natural properties of hot and cold air to ensure proper airflow and dissipate the heat that can contribute to equipment failure.

Protection

Protecting the network means securing all elements, not just switches and servers. Layer Zero solutions offer a comprehensive way to protect your network equipment: n ■

Physical security, such as preventing unauthorized access

to servers n ■

Protecting network performance by safeguarding the integrity

of the cables n ■

Monitoring current for power surges and temperature for

hot spots

Establishing airflow best practices during the physical infrastructure design phase is critical in order to improve overall thermal management.

Each product integrates with each other, creating a unified system that provides complete protection from threats to your network.

9

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Reduce Energy Consumption with

Mighty Mo Airflow Baffle System

The heat generated from increased server densities and higher speed network equipment makes cooling a top concern for today’s

IT administrators and data center managers. With heat being the most common reason for equipment failures, proper cooling is essential to reliable operations. The preferred method of cooling in today’s data centers is the cold aisle/hot aisle approach.

The innovative Mighty Mo cabinet airflow baffle system is designed to redirect airflow from side venting equipment from the cold aisle to the hot aisle to maintain maximum cooling. The baffle is a full height barrier that allows only cold aisle air to the equipment and also provides a complete barrier to eliminate hot air recirculation. Blanking panels help to prevent the unintended flow of air through the rack.

The fluid dynamics analysis to the right illustrates the significant cooling effect of the airflow baffle system versus alternative methods. The models show the analysis of the thermal characteristics

of three network cabinets at the center of a row within the data center. Each cabinet is loaded with side to side venting switches and front vertical managers with a cable fill rate of 40%.

The first two examples show hot and cold air mixing at the intake with exhaust temperatures reaching the 105ºF mark.

The Mighty Mo cabinet airflow baffle solution reduces the exhaust temperature by 20°.

This reduction allows the data center temperature set point to be raised, creating significant

OPEX savings.

TEST.01

Typical Cabinet without

Dividers or Airflow Baffles

When side venting equipment is mounted in typical cabinets without side panels or dividers even maintaining the recommended distance between the equipment does not provide adequate cooling in a cold aisle/hot aisle environment. The problem with this approach is that it allows much of the exhaust of one switch to enter the intake of the next switch. Each switch down the row is receiving less cooling, even though the cold aisle air temperature is set at an appropriate 65ºF – 70ºF.

TEST.02

Typical Cabinet with Cabinet Dividers

Adding divider panels does little to improve the cooling in a cold aisle/hot aisle environment. This approach allows both the cold aisle and the hot aisle to provide air to the intake of the equipment. As the hot air is exhausted it recirculates back to the intake side of the equipment. Again each switch is receiving less cool air as you go down the row.

TEST.03

Mighty Mo Cabinet with Mighty Mo Airflow Baffles

When using the Mighty Mo cabinet airflow baffles the intake air is always supplied from the cold aisle and the exhaust is directed by the baffles to the hot aisle. The use of filler panels on the rear rails in addition to the full height airflow baffles eliminates the recirculation of hot air within the cabinets.

11

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo

®

Cabinets

n

Features

A solid foundation is critical for superior network performance in high density applications. A poorly designed physical support system can have a devastating effect on the performance of the network. Legrand | Ortronics has engineered the Mighty Mo cabinets from the ground up to protect network integrity by addressing best practices in cable management as well as passive thermal management.

The Mighty Mo cabinet is ideal for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. Mighty Mo cabinet airflow baffles provide separation of hot and cold aisles and redirect airflow from side vented equipment so it matches the front-to-back airflow of servers.

The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. In addition, the cabinets offer: n ■

Heavy duty construction: Heavy-duty 14 ga. construction offers improved durability over

conventional 16 ga. cabinets. Mighty Mo doors are especially designed to eliminate the

irritating flex found in less well built cabinets n ■

Cable management: Mighty Mo vertical and horizontal managers provide improved

management for both servers and high density switches. Available bend limiters provide

standards compliant protection for fiber and 10G copper patch cords n ■

Passive thermal management: Mighty Mo baffles redirect the airflow of side vented equipment

from front-to-back ensuring the proper flow of air from cold aisle to hot aisle n ■

Thermal protection: A wide selection of top panels, fans and doors are available to ensure

adequate ventilation is provided to keep equipment at the optimal operating conditions

Top Panels

Top panels are half-depth allowing for customization of the front and rear top of the cabinet. A combination of solid and cable entry versions are recommended for front-to-back airflow. Mesh is well suited for passive heat dissipation. Fan version is supplied with (2) 235 CFM 6” diameter fans and finger guards to create bottom-to-top airflow.

Side Panels

Side panels include latches and locks. Interbay dividers include mounting hardware.

Vertical Managers

Mighty Mo cabinet vertical managers protect patch cords, cable and equipment ports from damage by maintaining proper bend radius requirements, reducing tension on plugs and jacks and protecting network equipment ports.

Doors

The Mighty Mo doors are available in five full width and two split width offerings. The full width doors are available in full profile mesh,

Plexiglas ® , solid and full flat mesh or solid. The split door versions are available in flat mesh or solid.

All doors are manufactured from

18 ga. steel (0.048”) and have self-contained 180° hinges. The door handles offer two choices – a swing handle with keyed lock or swing handle with combination/key lock. All doors are keyed alike to match front, rear and side panel locks.

Mounting Rails

Mighty Mo cabinet mounting rails are available with either

.375”square holes or #12-24 tapped holes. The tapped holes allow fast installation of network equipment. Square holes are ideal for server environments and require cage nuts and screws (sold separately) for mounting equipment.

13

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo

®

Cabinets

– Pre-Configured

n

Pre-Configured Server Cabinets

All Pre-Configured Server Cabinet Versions Include:

n ■

Frame configured with cable opening

at bottom rear n ■

Frame levelers n ■

(2) pairs of RU labeled mounting rails with

3/8” square holes n ■

Full profile mesh front door n ■

Split flat mesh rear door n ■

(2) “L” shaped finger managers on

rear rails n ■

Vertical PDU mount and lacing bar n ■

Divider or side panels, depending

on selection n ■

Solid top panel in front n ■

Cable entry top panel in rear n ■

Rack unit cage nuts #12-24 thread

(package of 50) n ■

(2) packages of 50 panel mounting screws

#12-24 (total of 100) n ■

Additional adhesive rack unit labels

(mounted inside of rear set of rails) n ■

Black only n

Pre-Configured Network Cabinets

All Pre-Configured Network Cabinet Versions Include:

n ■

Frame configured with cable opening

at bottom front n ■

Frame levelers n ■

(2) pairs of RU labeled mounting rails with

#12-24 tapped holes n ■

Full profile Plexiglas

®

front door n ■

Full flat solid rear door n ■

(2) “L” shaped finger managers on

front rails n ■

Right and left locking side panels n ■

Fan top panel in front n ■

Cable entry top panel in rear n ■

Package of 50 panel mounting

screws #12-24 n ■

Black only

Mighty Mo Pre-Configured Cabinets

Part Number

Divider Version

MMC422440-00005

MMC422446-00002

MMC472440-00003

MMC472446-00001

Part Number

Side Panels Version

MMC422440-00006

MMC422446-00003

MMC472440-00004

MMC472446-00002

Description

Server Cabinet Sizes (Depth includes doors)

42 RU x 24”W x 42”D

42 RU x 24”W x 48”D

47 RU x 24”W x 42”D

47 RU x 24”W x 48”D

MMC423240-0000G

MMC423246-00007

MMC473240-00003

MMC423240-0000H

MMC423246-00008

MMC473240-00004

42 RU x 32”W x 42”D

42 RU x 32”W x 48”D

47 RU x 32”W x 42”D

MMC473246-00001 MMC473246-00002 47 RU x 32”W x 48”D

“Divider” versions have a right side divider panel and ganging hardware (for within row)

“Side Panels” versions have a set of end panels (for stand alone or to create ends of row)

Part Number

Network Cabinet

MMC422434-00004

MMC423234-0000A

Description

Network Cabinet Size

42 RU x 24”W x 36”D

42 RU x 32”W x 36”D

Server Frame Network Frame

15

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

24U x 24” W x 34”D Cabinets

n

OR-MMC242434-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

48.75”H x 24”W x 34”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC2424DFPM-B

OR-MMC2424DFPP-B

OR-MMC2424DFPS-B

OR-MMC2424DFFM-B

OR-MMC2424DFFS-B

Split Doors

OR-MMC2424DSFM-B

OR-MMC2424DSFS-B

EIA Mounting Rails

OR-MMC2424M38-B

OR-MMC2424M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

Side Panels

OR-MMC2434SPSL-B

Top Panels

OR-MMC2434TPHS-B

OR-MMC2434TPHM-B

OR-MMC2434TPHC-B

34” deep, solid, locking, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

OR-MMC2434TPH1-B

OR-MMC2434TPH2-B

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

Casters

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC24VPMLS

OR-MMC24VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

17

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 24”W X 34”D Cabinets

n

OR-MMC422434-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 24”W x 34”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4224DFPM-B

OR-MMC4224DFPP-B

OR-MMC4224DFPS-B

OR-MMC4224DFFM-B

OR-MMC4224DFFS-B

Split Doors

OR-MMC4224DSFM-B

OR-MMC4224DSFS-B

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

Side Panels

OR-MMC4234SPSL-B

OR-MMC4234SPSN-B

Top Panels

OR-MMC2434TPHS-B

OR-MMC2434TPHM-B

34” deep, solid, locking, black

Interbay divider panel, 34” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

OR-MMC2434TPHC-B

OR-MMC2434TPH1-B

OR-MMC2434TPH2-B

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

Casters

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, "L" shape, 1.5"W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

19

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 24”W X 40”D Cabinets

n

OR-MMC422440-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 24”W x 40”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4224DFPM-B

OR-MMC4224DFPP-B

OR-MMC4224DFPS-B

OR-MMC4224DFFM-B

OR-MMC4224DFFS-B

Split Doors

OR-MMC4224DSFM-B

OR-MMC4224DSFS-B

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

OR-MMC4240SPSL-B

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4240SPSN-B

Top Panels

OR-MMC2440TPHS-B

OR-MMC2440TPHM-B

OR-MMC2440TPHC-B

OR-MMC2440TPH1-B

OR-MMC2440TPH2-B

Casters

40” deep, solid, locking, black

Interbay divider panel, 40” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh , black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

21

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 24”W X 46”D Cabinets

n

OR-MMC422446-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 24”W x 46”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4224DFPM-B

OR-MMC4224DFPP-B

OR-MMC4224DFPS-B

OR-MMC4224DFFM-B

OR-MMC4224DFFS-B

Split Doors

OR-MMC4224DSFM-B

OR-MMC4224DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4246SPSL-B

OR-MMC4246SPSN-B

Top Panels

OR-MMC2446TPHS-B

OR-MMC2446TPHM-B

OR-MMC2446TPHC-B

OR-MMC2446TPH1-B

OR-MMC2446TPH2-B

Casters

46” deep, solid, locking, black

Interbay divider panel, 46” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

23

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 24”W X 34”D Cabinets

n

OR-MMC472434-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

89”H x 24”W x 34”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4724DFPM-B

OR-MMC4724DFPP-B

OR-MMC4724DFPS-B

OR-MMC4724DFFM-B

OR-MMC4724DFFS-B

Split Doors

OR-MMC4724DSFM-B

OR-MMC4724DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4734SPSL-B

OR-MMC4734SPSN-B

Top Panels

OR-MMC2434TPHS-B

OR-MMC2434TPHM-B

OR-MMC2434TPHC-B

OR-MMC2434TPH1-B

OR-MMC2434TPH2-B

Casters

34” deep, solid, locking, black

Interbay divider panel, 34” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

25

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 24”W X 40”D Cabinets

n

OR-MMC472440-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

89”H x 24”W x 40”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4724DFPM-B

OR-MMC4724DFPP-B

OR-MMC4724DFPS-B

OR-MMC4724DFFM-B

OR-MMC4724DFFS-B

Split Doors

OR-MMC4724DSFM-B

OR-MMC4724DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4740SPSL-B

OR-MMC4740SPSN-B

Top Panels

OR-MMC2440TPHS-B

OR-MMC2440TPHM-B

OR-MMC2440TPHC-B

OR-MMC2440TPH1-B

OR-MMC2440TPH2-B

Casters

40” deep, solid, locking, black

Interbay divider panel, 40” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

27

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 24”W X 46”D Cabinets

n

OR-MMC472446-B

The Mighty Mo cabinet is available 24”W for both servers and small network configurations.

Cable openings, rack mounting rails and optional vertical managers are properly positioned based on the server or network frame orientation. The Mighty Mo cabinets are fully welded and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs.

The Mighty Mo cabinet is designed to integrate with the Mighty Mo open rack systems, providing a comprehensive solution for even the demanding applications.

Configured-to-Order

Dimensions

89”H x 24”W x 46”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4724DFPM-B

OR-MMC4724DFPP-B

OR-MMC4724DFPS-B

OR-MMC4724DFFM-B

OR-MMC4724DFFS-B

Split Doors

OR-MMC4724DSFM-B

OR-MMC4724DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4746SPSL-B

OR-MMC4746SPSN-B

Top Panels

OR-MMC2446TPHS-B

OR-MMC2446TPHM-B

OR-MMC2446TPHC-B

OR-MMC2446TPH1-B

OR-MMC2446TPH2-B

Casters

46” deep, solid, locking, black

Interbay divider panel, 46” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC2406CTCE-B

OR-MMC2412CTCE-B

OR-MMC2418CTCE-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

29

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 32”W X 34”D Cabinets

n

OR-MMC423234-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 32”W x 34”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4232DFPM-B

OR-MMC4232DFPP-B

OR-MMC4232DFPS-B

OR-MMC4232DFFM-B

OR-MMC4232DFFS-B

Split Doors

OR-MMC4232DSFM-B

OR-MMC4232DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4234SPSL-B

OR-MMC4234SPSN-B

Top Panels

OR-MMC3234TPHS-B

OR-MMC3234TPHM-B

OR-MMC3234TPHC-B

OR-MMC3234TPH1-B

OR-MMC3234TPH2-B

Casters

34” deep, solid, locking, black

Interbay divider panel, 34” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB421612

OR-MMCAB423012

OR-MMCAB421632SA

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front-to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

31

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 32”W X 40”D Cabinets

n

OR-MMC423240-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 32”W x 40”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4232DFPM-B

OR-MMC4232DFPP-B

OR-MMC4232DFPS-B

OR-MMC4232DFFM-B

OR-MMC4232DFFS-B

Split Doors

OR-MMC4232DSFM-B

OR-MMC4232DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4240SPSL-B

OR-MMC4240SPSN-B

Top Panels

OR-MMC3240TPHS-B

OR-MMC3240TPHM-B

OR-MMC3240TPHC-B

OR-MMC3240TPH1-B

OR-MMC3240TPH2-B

Casters

40” deep, solid, locking, black

Interbay divider panel, 40” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB421612

OR-MMCAB423012

OR-MMCAB421632SA

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front- to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

33

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

42U X 32”W X 46”D Cabinets

n

OR-MMC423246-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

80.25”H x 32”W x 46”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4232DFPM-B

OR-MMC4232DFPP-B

OR-MMC4232DFPS-B

OR-MMC4232DFFM-B

OR-MMC4232DFFS-B

Split Doors

OR-MMC4232DSFM-B

OR-MMC4232DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4224M38-B

OR-MMC4224M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4246SPSL-B

OR-MMC4246SPSN-B

Top Panels

OR-MMC3246TPHS-B

OR-MMC3246TPHM-B

OR-MMC3246TPHC-B

OR-MMC3246TPH1-B

OR-MMC3246TPH2-B

Casters

46” deep, solid, locking, black

Interbay divider panel, 46” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC42VPMLS

OR-MMC42VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB421612

OR-MMCAB423012

OR-MMCAB421632SA

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front-to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 42 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

35

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 32”W X 34”D Cabinets

n

OR-MMC473234-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

89”H x 32”W x 34”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4732DFPM-B

OR-MMC4732DFPP-B

OR-MMC4732DFPS-B

OR-MMC4732DFFM-B

OR-MMC4732DFFS-B

Split Doors

OR-MMC4732DSFM-B

OR-MMC4732DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4734SPSL-B

OR-MMC4734SPSN-B

Top Panels

OR-MMC3234TPHS-B

OR-MMC3234TPHM-B

OR-MMC3234TPHC-B

OR-MMC3234TPH1-B

OR-MMC3234TPH2-B

Casters

34” deep, solid, locking, black

Interbay divider panel, 34” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB471612

OR-MMCAB473012

OR-MMCAB471632SA

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front-to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

37

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 32”W X 40”D Cabinets

n

OR-MMC473240-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

89”H x 32”W x 40”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4732DFPM-B

OR-MMC4732DFPP-B

OR-MMC4732DFPS-B

OR-MMC4732DFFM-B

OR-MMC4732DFFS-B

Split Doors

OR-MMC4732DSFM-B

OR-MMC4732DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4740SPSL-B

OR-MMC4740SPSN-B

Top Panels

OR-MMC3240TPHS-B

OR-MMC3240TPHM-B

OR-MMC3240TPHC-B

OR-MMC3240TPH1-B

OR-MMC3240TPH2-B

Casters

40” deep, solid, locking, black

Interbay divider panel, 40” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB471612

OR-MMCAB473012

OR-MMCAB471632SA

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front-to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

39

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

47U X 32”W X 46”D Cabinets

n

OR-MMC473246-B

The 32”W Mighty Mo cabinet is ideal for network configurations. Designed for high density applications, the cabinet offers many passive airflow and cable management options for maintaining cold aisle/hot aisle airflow, whether the network equipment is front-to-back, bottom or side venting. These options are fully configurable to allow the end user to choose the proper components for their specific application, without sacrificing performance or reliability.

The Mighty Mo cabinets are fully welded, with a static capacity weight of 3,000 lbs, and built to your configuration. They arrive fully assembled with all components installed and accessories included, reducing equipment deployment time and overall costs. The Mighty Mo cabinet is designed to integrate with Mighty Mo open rack systems, providing a comprehensive solution for even the most demanding applications.

Configured-to-Order

Dimensions

89”H x 32”W x 46”D

Weight Load Capacity

n ■

3,000 lbs

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or cool gray

Enclosure Options

Part Number

Full Width Doors

OR-MMC4732DFPM-B

OR-MMC4732DFPP-B

OR-MMC4732DFPS-B

OR-MMC4732DFFM-B

OR-MMC4732DFFS-B

Split Doors

OR-MMC4732DSFM-B

OR-MMC4732DSFS-B

Description

Full profile, mesh, black

Full profile, Plexiglas

®

, black

Full profile, solid, black

Full flat, mesh, black

Full flat, solid, black

Split flat, mesh, black

Split flat, solid, black

EIA Mounting Rails

OR-MMC4724M38-B

OR-MMC4724M12-B

Door Handles

OR-MMCDHSKL-0333

OR-MMCDHSCK-0333

Side Panels

0.375” square holes, black, includes 2 rails with RU labels

#12-24 tapped holes, black, includes 2 rails with RU labels

Swing, key lock, key# 0333

Swing, combination/key lock, key# 0333

OR-MMC4746SPSL-B

OR-MMC4746SPSN-B

Top Panels

OR-MMC3246TPHS-B

OR-MMC3246TPHM-B

OR-MMC3246TPHC-B

OR-MMC3246TPH1-B

OR-MMC3246TPH2-B

Casters

46” deep, solid, locking, black

Interbay divider panel, 46” deep, solid, bolt-on, black

Half-depth, solid, black

Half-depth, mesh, black

Half-depth, cabling H-panel, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 120V, black

Half-depth, includes (2) 6” fans, 235 CFM ea. 208V, black

OR-MMCCAS-SW-3 Swivel casters, 3” diameter, set of 4

Note: Replace “B” with “G” for cool gray.

Note: The height of the cabinet includes levelers. Casters add 1.25” to the height of the cabinet.

Cable Management

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC47VPMLS

OR-MMC47VPMLD

Airflow Management

Center exit cable trough, 6” wide, black

Center exit cable trough, 12” wide, black

Center exit cable trough, 18” wide, black

Vertical manager fingers, “L” shape, 1.5”W

Vertical manager fingers, “U” shape, 12”W

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-MMCAB471612

OR-MMCAB473012

OR-MMCAB471632SA

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 16-1/4” front-to-rear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, mounts between 2 cabinets with rails set at 30” front-torear and “U” shaped vertical installed, black

Airflow baffle for 32” W 47 RU frame, with rails set at 16-1/4” front-to-rear and side panels installed, black

41

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

Accessories

Hardware

n

OR-PS-M6X1-50 n■

OR-MMCMBK n

OR-MMCUN-1420-10 n■

OR-MMCRULBL-60-A n

OR-MMCLVL-IP n■

OR-MMCISOB-38 n

OR-MMCISOB-50 n■

OR-MMCISOB-38

Fans

n

OR-MMCFANP19-4-2 n■

OR-MMCFAN-6 n

OR-MMCFAN-6-2

Panel mounting screws, M6 x 1 x .625”, package of 50, clear

Multi-bay hardware kit, 1/4-20 bolts and nuts, set of 6

Unistrut hardware kit, 1/4-20 bolts and Unistrut nuts, set of 10

Adhesive rack unit label, 60 RU length

Levelers, 1/2-13 thread with isolation pads, set of 4

Isolation bushing for 3/8” hardware, set of 4

Isolation bushing for 1/2” hardware, set of 4

Isolation bushing for 3/8” hardware, set of 4

19” fan panel, includes (2) 4” fans, 110 CFM ea. 120 V, 24” cord, black

6” fan, 235 CFM, 120 V, 24” cord, black

6” fan, 235 CFM, 208 V, 24” cord, black

OR-MMCUN-1420-10

OR-MMCMBK

OR-MMCFANP19-4-2

The Ortronics line of cabinet hardware provides the products needed to complete your installation.

Rack Unit Cage Nuts enable easy and quick installation of three cage nuts simultaneously.

43

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Made in the USA!

Manufacturing in Anaheim, California, Fairfield, New Jersey and

Mascoutah, Illinois.

We pride ourselves on manufacturing our enclosure and wire mesh cable tray products in the U.S.A. By manufacturing in

America, we not only lessen our environmental impact, but we also provide American jobs. Our bi-coastal manufacturing facilities enable us to provide our customers with their products more quickly. This is a winning solution for our company, our customers and our community.

45

Mighty Mo

®

GX Cabinets

n

Features

The Mighty Mo GX Cabinet Series is made in the USA.

The Mighty Mo GX cabinet is fully modular and configurable to suit the needs of your specific installation. Each cabinet can be assembled with as few or as many accessories as needed to properly support your servers, switches and patch panels. The cabinets are designed to stand alone or easily gang together, as your network demands increase.

n ■

Select models available for next day shipment n ■

Custom configured to meet equipment and space storage requirements n ■

Select accessories can be pre-installed, reducing installation time and packaging waste n ■

Configurations utilize a single part number and price to simplify ordering n ■

Available in 24U, 42U, 45U and 48U heights n ■

Available in 24” (match 24”W floor tiles), 29.5” and 31.5” widths n ■

Available in 36”, 42” and 48” depths n ■

EIA mounting rails are available with 0.375” square hole or #12-24 tapped styles n ■

3,000 lbs static load capacity n ■

UL and cUL listed, UL 60950-1 2nd Edition, NWIN

Side Panels

2-piece side panels simplify handling and allow easy access for MAC work. Side panels individually lock for greater security. Flush panels maintain exact cabinet width. 24U cabinet has single piece side panel.

Mounting Rails

EIA mounting rails are available with 0.375” square holes or

#12-24 tapped holes. Rack units are marked on each rail from top to bottom. Rails positioned based on server (rail spacing at 30”) or network (rail spacing at 16.25”) cabinet design. Fully adjustable along each frame.

Full Width Doors

Doors have 180° swing.

Field reversible. Lockable swing door handle is included. Available in mesh, Plexiglas

®

and solid.

Mesh is 63% open area.

Top Panels

Top panels are single-piece construction and field reversible to provide cable access in the front or the rear. They are bolted to cabinet frame for added security and available in solid panels with (2) 4” cable gland grommets. They are also available vented, with (2) 4” cable gland grommets and optional fans. Another choice is the cabling panel with (2) rectangular openings that allow for removal after cables are installed. An optional top panel brush kit is available.

Split Doors

Doors have 180° swing.

Lockable swing door handle is included. Available in mesh and solid. Mesh is 63% open area.

Frames

The steel 4-post frame is welded and bolted. Equipment mounting rails are supported by (3) front-to-back

Unistrut frame members for added structural support.

The Unistrut design allows for infinite mounting rail and accessory adjustment. Vertical accessories can be installed at any location along the strut. It’s quick: two cabinets can be ganged together with eight bolts. Every cabinet includes adjustable, self leveling feet and ganging hardware.

Levelers & Casters

All cabinets come fully equipped with levelers; cabinets can also be configured with casters.

47

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo

®

GX Cabinets

– Pre-Configured

n

Pre-Configured Server Cabinets

All Pre-Configured Server Cabinet Versions Include:

n ■

42U frame with levelers and casters n ■

(2) pairs of RU labeled equipment

mounting rails with 0.375” square holes n ■

Mounting rail spacing at 30” n ■

Full width front mesh door n ■

Split mesh rear door n ■

Solid top panel with (2) 4” diameter

gland grommets n ■

Double-wide PDU-mount lacing bar n ■

Side panels, both sides n ■

Rack unit cage nuts, #12-24 thread

(package of 50) n ■

Panel screws, #12-24 (package of 50) n ■

Color is black n

Pre-Configured Network Cabinets

All Pre-Configured Network Cabinet Versions Include:

n ■

42U frame with levelers and casters n ■

(2) pairs of RU labeled equipment

mounting rails with #12-24 tapped holes n ■

Mounting rail spacing at 16.25” n ■

Full width front mesh door n ■

Split mesh rear door n ■

Solid top panel with (2) 4” diameter

gland grommets n ■

Double-wide PDU-mount lacing bar n ■

Side panels, both sides n ■

Panel screws, #12-24 (package of 50) n ■

Color is black

Mighty Mo GX Pre-Configured Cabinet

Part Number

OR-GXC422442-A1-B

OR-GXC422942-A1-B

Description

Server, cabinet assembly

42U (80.45”H), 24”W, 42”D, black

Network, cabinet assembly

42U (80.45”H), 29.5”W, 42”D, black

NEXT DAY SHIPMENT

The Mighty Mo GX offers two pre-configured cabinets, designed for servers or networking equipment. They are stocked and available in limited quantities for next day shipment.

49

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

24U X 24”W X 36”D Cabinets

n

OR-GXC242436-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

47.25”H x 24”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC2424DFM-B

OR-GXC2424DFP-B

OR-GXC2424DFS-B

Split Doors

OR-GXC2424DSM-B

OR-GXC2424DSS-B

EIA Mounting Rails

OR-GXC2424M12-B

OR-GXC2424M38-B

Side Panels

OR-GXC2436SPSL-B

Top Panels

OR-GXC2436TPC-B

OR-GXC2436TPS-B

OR-GXC2436TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

OR-GXC24VPMLS-B

OR-GXC24VPMLD-B

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

51

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

24U X 24”W X 42”D Cabinets

n

OR-GXC242442-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

47.25”H x 24”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC2424DFM-B

OR-GXC2424DFP-B

OR-GXC2424DFS-B

Split Doors

OR-GXC2424DSM-B

OR-GXC2424DSS-B

EIA Mounting Rails

OR-GXC2424M12-B

OR-GXC2424M38-B

Side Panels

OR-GXC2442SPSL-B

Top Panels

OR-GXC2442TPC-B

OR-GXC2442TPS-B

OR-GXC2442TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

OR-GXC24VPMLS-B

OR-GXC24VPMLD-B

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

53

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 24”W X 36”D Cabinets

n

OR-GXC422436-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

78.75”H x 24”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4224DFM-B

OR-GXC4224DFP-B

OR-GXC4224DFS-B

Split Doors

OR-GXC4224DSM-B

OR-GXC4224DSS-B

EIA Mounting Rails

OR-GXC4224M12-B

OR-GXC4224M38-B

Side Panels

OR-GXC4236SPSL-B

Top Panels

OR-GXC2436TPC-B

OR-GXC2436TPS-B

OR-GXC2436TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC42VFK-B

OR-GXC4206VWT

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

55

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 24”W X 42”D Cabinets

n

OR-GXC422442-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

78.75”H x 24”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4224DFM-B

OR-GXC4224DFP-B

OR-GXC4224DFS-B

Split Doors

OR-GXC4224DSM-B

OR-GXC4224DSS-B

EIA Mounting Rails

OR-GXC4224M12-B

OR-GXC4224M38-B

Side Panels

OR-GXC4242SPSL-B

Top Panels

OR-GXC2442TPC-B

OR-GXC2442TPS-B

OR-GXC2442TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

57

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 24”W X 48”D Cabinets

n

OR-GXC422448-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

78.75”H x 24”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4224DFM-B

OR-GXC4224DFP-B

OR-GXC4224DFS-B

Split Doors

OR-GXC4224DSM-B

OR-GXC4224DSS-B

EIA Mounting Rails

OR-GXC4224M12-B

OR-GXC4224M38-B

Side Panels

OR-GXC4248SPSL-B

Top Panels

OR-GXC2448TPC-B

OR-GXC2448TPS-B

OR-GXC2448TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

59

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 24”W X 36”D Cabinets

n

OR-GXC452436-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

84”H x 24”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4524DFM-B

OR-GXC4524DFP-B

OR-GXC4524DFS-B

Split Doors

OR-GXC4524DSM-B

OR-GXC4524DSS-B

EIA Mounting Rails

OR-GXC4524M12-B

OR-GXC4524M38-B

Side Panels

OR-GXC4536SPSL-B

Top Panels

OR-GXC2436TPC-B

OR-GXC2436TPS-B

OR-GXC2436TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

61

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 24”W X 42”D Cabinets

n

OR-GXC452442-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

84”H x 24”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4524DFM-B

OR-GXC4524DFP-B

OR-GXC4524DFS-B

Split Doors

OR-GXC4524DSM-B

OR-GXC4524DSS-B

EIA Mounting Rails

OR-GXC4524M12-B

OR-GXC4524M38-B

Side Panels

OR-GXC4542SPSL-B

Top Panels

OR-GXC2442TPC-B

OR-GXC2442TPS-B

OR-GXC2442TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

63

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 24”W X 48”D Cabinets

n

OR-GXC452448-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

84”H x 24”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4524DFM-B

OR-GXC4524DFP-B

OR-GXC4524DFS-B

Split Doors

OR-GXC4524DSM-B

OR-GXC4524DSS-B

EIA Mounting Rails

OR-GXC4524M12-B

OR-GXC4524M38-B

Side Panels

OR-GXC4548SPSL-B

Top Panels

OR-GXC2448TPC-B

OR-GXC2448TPS-B

OR-GXC2448TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

65

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 24”W X 36”D Cabinets

n

OR-GXC482436-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

89.25”H x 24”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4824DFM-B

OR-GXC4824DFP-B

OR-GXC4824DFS-B

Split Doors

OR-GXC4824DSM-B

OR-GXC4824DSS-B

EIA Mounting Rails

OR-GXC4824M12-B

OR-GXC4824M38-B

Side Panels

OR-GXC4836SPSL-B

Top Panels

OR-GXC2436TPC-B

OR-GXC2436TPS-B

OR-GXC2436TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

67

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 24”W X 42”D Cabinets

n

OR-GXC482442-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

89.25”H x 24”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4824DFM-B

OR-GXC4824DFP-B

OR-GXC4824DFS-B

Split Doors

OR-GXC4824DSM-B

OR-GXC4824DSS-B

EIA Mounting Rails

OR-GXC4824M12-B

OR-GXC4824M38-B

Side Panels

OR-GXC4842SPSL-B

Top Panels

OR-GXC2442TPC-B

OR-GXC2442TPS-B

OR-GXC2442TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

69

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 24”W X 48”D Cabinets

n

OR-GXC482448-B

Ideal for server applications, the 24”W Mighty Mo GX enclosure allows users to align with floor tiles, to stay “on grid” even when side panels are deployed. Speed of deployment was a primary consideration in design; the cabinets can be ganged by a single person without removing the doors. The cabinet provides maximum versatility with a static weight load capacity of 3,000 lbs, cable entry from the top or bottom and infinite rail adjustment. All cabinets are electrically bonded and UL and cUL listed, UL 60950-1 2nd Edition, NWIN.

These cabinets are configured-to-order, ensuring you get only what you need for your application.

The structural components of the cabinet are available in black or white, while the accessories are available in black.

Configured-to-Order

Dimensions

89.25”H x 24”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4824DFM-B

OR-GXC4824DFP-B

OR-GXC4824DFS-B

Split Doors

OR-GXC4824DSM-B

OR-GXC4824DSS-B

EIA Mounting Rails

OR-GXC4824M12-B

OR-GXC4824M38-B

Side Panels

OR-GXC4848SPSL-B

Top Panels

OR-GXC2448TPC-B

OR-GXC2448TPS-B

OR-GXC2448TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-MMC2406CTCE-B

OR-MMC2418CTCE-B

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Center exit cable trough, 6” wide

Center exit cable trough, 18” wide

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

71

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Acting Now

For Tomorrow

Energy Efficiency is now an essential part of every Legrand project.

It has even become a major factor for the success of projects.

As the global specialist in electrical and digital building infrastructures, Legrand is offering more solutions for improved control of electricity to reduce consumption and contribute towards supplying high quality energy.

Legrand is committed to building high quality products. We strive to be more considerate of our environmental impact and to help save energy. In the end, this is a greater cost savings for our customers.

Legrand is one of just nine U.S. industrial organizations that have joined the “Better Buildings, Better Plants” Presidential

Leadership initiative as a Challenge Partner, pledging to the most aggressive energy savings, management and reporting practices outlined in a U.S. Department of Energy agreement.

Legrand | Ortronics, together with the other Legrand companies is committed to integrating sustainability through our business operations and in the design and function of our products by organizing our environment goals around Operations, Products and Energy Efficiency in the marketplace.

Legrand | Ortronics commitments include:

n

ISO 14001 certified facilities since 2009

n

RoHS compliant products*. Legrand | Ortronics considers

RoHS guidelines in the design and material selection for

all new products

n

USGBC member since 2004

*Except legacy 110 blocks

73

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 29.5”W X 36”D Cabinets

n

OR-GXC422936-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

78.75”H x 29.5”W x 36”D”

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4229DFM-B

OR-GXC4229DFP-B

OR-GXC4229DFS-B

Split Doors

OR-GXC4229DSM-B

OR-GXC4229DSS-B

EIA Mounting Rails

OR-GXC4229M12-B

OR-GXC4229M38-B

Side Panels

OR-GXC4236SPSL-B

Top Panels

OR-GXC2936TPC-B

OR-GXC2936TPS-B

OR-GXC2936TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

#12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2)

29.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4229ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421629SA-B

OR-GXCAB423029SA-B

OR-GXCAB421629-B

OR-GXCAB423029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of

29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4229SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

75

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 29.5”W X 42”D Cabinets

n

OR-GXC422942-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

78.75”H x 29.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4229DFM-B

OR-GXC4229DFP-B

OR-GXC4229DFS-B

Split Doors

OR-GXC4229DSM-B

OR-GXC4229DSS-B

EIA Mounting Rails

OR-GXC4229M12-B

OR-GXC4229M38-B

Side Panels

OR-GXC4242SPSL-B

Top Panels

OR-GXC2942TPC-B

OR-GXC2942TPS-B

OR-GXC2942TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2)

29.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4229ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421629SA-B

OR-GXCAB423029SA-B

OR-GXCAB421629-B

OR-GXCAB423029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4229SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

77

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 29.5”W X 48”D Cabinets

n

OR-GXC422948-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

78.75”H x 29.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4229DFM-B

OR-GXC4229DFP-B

OR-GXC4229DFS-B

Split Doors

OR-GXC4229DSM-B

OR-GXC4229DSS-B

EIA Mounting Rails

OR-GXC4229M12-B

OR-GXC4229M38-B

Side Panels

OR-GXC4248SPSL-B

Top Panels

OR-GXC2948TPC-B

OR-GXC2948TPS-B

OR-GXC2948TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2)

29.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4229ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421629SA-B

OR-GXCAB423029SA-B

OR-GXCAB421629-B

OR-GXCAB423029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4229SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

79

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 29.5”W X 36”D Cabinets

n

OR-GXC452936-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

84”H x 29.5”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4529DFM-B

OR-GXC4529DFP-B

OR-GXC4529DFS-B

Split Doors

OR-GXC4529DSM-B

OR-GXC4529DSS-B

EIA Mounting Rails

OR-GXC4529M12-B

OR-GXC4529M38-B

Side Panels

OR-GXC4536SPSL-B

Top Panels

OR-GXC2936TPC-B

OR-GXC2936TPS-B

OR-GXC2936TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2)

29.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4529ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451629SA-B

OR-GXCAB453029SA-B

OR-GXCAB451629-B

OR-GXCAB453029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4529SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

81

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 29.5”W X 42”D Cabinets

n

OR-GXC452942-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

84”H x 29.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4529DFM-B

OR-GXC4529DFP-B

OR-GXC4529DFS-B

Split Doors

OR-GXC4529DSM-B

OR-GXC4529DSS-B

EIA Mounting Rails

OR-GXC4529M12-B

OR-GXC4529M38-B

Side Panels

OR-GXC4542SPSL-B

Top Panels

OR-GXC2942TPC-B

OR-GXC2942TPS-B

OR-GXC2942TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 29.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4529ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451629SA-B

OR-GXCAB453029SA-B

OR-GXCAB451629-B

OR-GXCAB453029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4529SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

83

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 29.5”W X 48”D Cabinets

n

OR-GXC452448-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

89.25”H x 29.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4529DFM-B

OR-GXC4529DFP-B

OR-GXC4529DFS-B

Split Doors

OR-GXC4529DSM-B

OR-GXC4529DSS-B

EIA Mounting Rails

OR-GXC4529M12-B

OR-GXC4529M38-B

Side Panels

OR-GXC4548SPSL-B

Top Panels

OR-GXC2948TPC-B

OR-GXC2948TPS-B

OR-GXC2948TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 29.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4529ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451629SA-B

OR-GXCAB453029SA-B

OR-GXCAB451629-B

OR-GXCAB453029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4529SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

85

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 29.5”W X 36”D Cabinets

n

OR-GXC482936-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

89.5”H x 29.5”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4829DFM-B

OR-GXC4829DFP-B

OR-GXC4829DFS-B

Split Doors

OR-GXC4829DSM-B

OR-GXC4829DSS-B

EIA Mounting Rails

OR-GXC4829M12-B

OR-GXC4829M38-B

Side Panels

OR-GXC4836SPSL-B

Top Panels

OR-GXC2936TPC-B

OR-GXC2936TPS-B

OR-GXC2936TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 29.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4829ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481629SA-B

OR-GXCAB483029SA-B

OR-GXCAB481629-B

OR-GXCAB483029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of

29.5”W frame

Angled airflow baffles, 16.25”D, mount between

(2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4829SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

87

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 29.5”W X 42”D Cabinets

n

OR-GXC482942-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

89.25”H x 29.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4829DFM-B

OR-GXC4829DFP-B

OR-GXC4829DFS-B

Split Doors

OR-GXC4829DSM-B

OR-GXC4829DSS-B

EIA Mounting Rails

OR-GXC4829M12-B

OR-GXC4829M38-B

Side Panels

OR-GXC4842SPSL-B

Top Panels

OR-GXC2942TPC-B

OR-GXC2942TPS-B

OR-GXC2942TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 29.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4829ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481629SA-B

OR-GXCAB483029SA-B

OR-GXCAB481629-B

OR-GXCAB483029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4829SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

89

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 29.5”W X 48”D Cabinets

n

OR-GXC482948-B

The Mighty Mo GX 29.5”W was developed to accommodate ever increasing cable densities while maintaining proper airflow patterns. Predictable air inlet temperature to side-breathing switches is ensured by installing an airflow baffle. Efficiency is gained by properly channeling the airflow to help solve the problem of over-temperature alarms. If the equipment has a front-to-rear airflow pattern, bypass airflow is eliminated by installing an air dam kit on the face of the cabinet. Side patching kits allow for mounting patch panels outside of the vertical rack unit space. Each kit contains (2) 1U 19” EIA mounting locations between the vertical mounting rail and the outside of the cabinet, allowing deployment of up to four additional patch panels per cabinet. A wide cable management offering facilitates proper routing of cabling to maintain the integrity of the network.

The Mighty Mo GX will meet your most demanding network applications and is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN.

Configured-to-Order

Dimensions

89.25”H x 29.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4829DFM-B

OR-GXC4829DFP-B

OR-GXC4829DFS-B

Split Doors

OR-GXC4829DSM-B

OR-GXC4829DSS-B

EIA Mounting Rails

OR-GXC4829M12-B

OR-GXC4829M38-B

Side Panels

OR-GXC4848SPSL-B

Top Panels

OR-GXC2948TPC-B

OR-GXC2948TPS-B

OR-GXC2948TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC2906CTCE-B

OR-GXC2912CTCE-B

OR-GXC2918CTCE-B

OR-GXC29WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 29.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4829ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481629SA-B

OR-GXCAB483029SA-B

OR-GXCAB481629-B

OR-GXCAB483029-B

Air dam kit, 29.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 29.5”W frame

Angled airflow baffles, 30”D, mount at end of 29.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 29.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 29.5”W frames

OR-GXC4829SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

91

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 31.5”W X 36”D Cabinets

n

OR-GXC423136-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

78.75”H x 31.5”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4231DFM-B

OR-GXC4231DFP-B

OR-GXC4231DFS-B

Split Doors

OR-GXC4231DSM-B

OR-GXC4231DSS-B

EIA Mounting Rails

OR-GXC4231M12-B

OR-GXC4231M38-B

Side Panels

OR-GXC4236SPSL-B

Top Panels

OR-GXC3136TPC-B

OR-GXC3136TPS-B

OR-GXC3136TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4231ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421631SA-B

OR-GXCAB423031SA-B

OR-GXCAB421631-B

OR-GXCAB423031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4231SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

93

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 31.5”W X 42”D Cabinets

n

OR-GXC423142-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

78.75”H x 31.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4231DFM-B

OR-GXC4231DFP-B

OR-GXC4231DFS-B

Split Doors

OR-GXC4231DSM-B

OR-GXC4231DSS-B

EIA Mounting Rails

OR-GXC4231M12-B

OR-GXC4231M38-B

Side Panels

OR-GXC4242SPSL-B

Top Panels

OR-GXC3142TPC-B

OR-GXC3142TPS-B

OR-GXC3142TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4231ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421631SA-B

OR-GXCAB423031SA-B

OR-GXCAB421631-B

OR-GXCAB423031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4231SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

95

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

42U X 31.5”W X 48”D Cabinets

n

OR-GXC423148-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

78.75”H x 31.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4231DFM-B

OR-GXC4231DFP-B

OR-GXC4231DFS-B

Split Doors

OR-GXC4231DSM-B

OR-GXC4231DSS-B

EIA Mounting Rails

OR-GXC4231M12-B

OR-GXC4231M38-B

Side Panels

OR-GXC4248SPSL-B

Top Panels

OR-GXC3148TPC-B

OR-GXC3148TPS-B

OR-GXC3148TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC42VFK-B

OR-GXC4206VWT-B

OR-GXC42VPMLS-B

OR-GXC42VPMLD-B

Airflow Management

OR-GXC4231ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB421631SA-B

OR-GXCAB423031SA-B

OR-GXCAB421631-B

OR-GXCAB423031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4231SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

97

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 31.5”W X 36”D Cabinets

n

OR-GXC453136-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

84”H x 31.5”W x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4531DFM-B

OR-GXC4531DFP-B

OR-GXC4531DFS-B

Split Doors

OR-GXC4531DSM-B

OR-GXC4531DSS-B

EIA Mounting Rails

OR-GXC4531M12-B

OR-GXC4531M38-B

Side Panels

OR-GXC4536SPSL-B

Top Panels

OR-GXC3136TPC-B

OR-GXC3136TPS-B

OR-GXC3136TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4531ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451631SA-B

OR-GXCAB453031SA-B

OR-GXCAB451631-B

OR-GXCAB453031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4531SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

99

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 31.5”W X 42”D Cabinets

n

OR-GXC453136-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

84”H x 31.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4531DFM-B

OR-GXC4531DFP-B

OR-GXC4531DFS-B

Split Doors

OR-GXC4531DSM-B

OR-GXC4531DSS-B

EIA Mounting Rails

OR-GXC4531M12-B

OR-GXC4531M38-B

Side Panels

OR-GXC4542SPSL-B

Top Panels

OR-GXC3142TPC-B

OR-GXC3142TPS-B

OR-GXC3142TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4531ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451631SA-B

OR-GXCAB453031SA-B

OR-GXCAB451631-B

OR-GXCAB453031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4531SPB-B Side patching baffle - covers 1 side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

101

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

45U X 31.5”W X 48”D Cabinets

n

OR-GXC453148-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

84”H x 31.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4531DFM-B

OR-GXC4531DFP-B

OR-GXC4531DFS-B

Split Doors

OR-GXC4531DSM-B

OR-GXC4531DSS-B

EIA Mounting Rails

OR-GXC4531M12-B

OR-GXC4531M38-B

Side Panels

OR-GXC4548SPSL-B

Top Panels

OR-GXC3148TPC-B

OR-GXC3148TPS-B

OR-GXC3148TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC45VFK-B

OR-GXC4506VWT-B

OR-GXC45VPMLS-B

OR-GXC45VPMLD-B

Airflow Management

OR-GXC4531ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB451631SA-B

OR-GXCAB453031SA-B

OR-GXCAB451631-B

OR-GXCAB453031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4531SPB-B Side patching baffle - covers one side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

103

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 31.5”W X 36”D Cabinets

n

OR-GXC483136-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

89.25”H x 31.5”H x 36”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4831DFM-B

OR-GXC4831DFP-B

OR-GXC4831DFS-B

Split Doors

OR-GXC4831DSM-B

OR-GXC4831DSS-B

EIA Mounting Rails

OR-GXC4831M12-B

OR-GXC4831M38-B

Side Panels

OR-GXC4836SPSL-B

Top Panels

OR-GXC3136TPC-B

OR-GXC3136TPS-B

OR-GXC3136TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

36” deep, solid, locking, covers 1 side of frame

36” deep, cabling H-panel

36” deep, solid, includes (2) 4” diameter grommets

36” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4831ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481631SA-B

OR-GXCAB483031SA-B

OR-GXCAB481631-B

OR-GXCAB483031-B

Air dam kit, 31.5”W cabinet

Angled air flow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4831SPB-B Side patching baffle - covers one side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

105

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 31.5”W X 42”D Cabinets

n

OR-GXC483142-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

89.25”H x 31.5”W x 42”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4831DFM-B

OR-GXC4831DFP-B

OR-GXC4831DFS-B

Split Doors

OR-GXC4831DSM-B

OR-GXC4831DSS-B

EIA Mounting Rails

OR-GXC4831M12-B

OR-GXC4831M38-B

Side Panels

OR-GXC4842SPSL-B

Top Panels

OR-GXC3142TPC-B

OR-GXC3142TPS-B

OR-GXC3142TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

42” deep, solid, locking, covers 1 side of frame

42” deep, cabling H-panel

42” deep, solid, includes (2) 4” diameter grommets

42” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4831ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481631SA-B

OR-GXCAB483031SA-B

OR-GXCAB481631-B

OR-GXCAB483031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled air flow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4831SPB-B Side patching baffle - covers one side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

107

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

48U X 31.5”W X 48”D Cabinets

n

OR-GXC483148-B

The 31.5”W Mighty Mo GX has all the features and benefits of the 29.5”W cabinet while providing more width for cable intensive applications. The extra width allows for larger cable bundles to be managed to the sides of the cabinet and not impede airflow. Multiple top panels are also available, providing flexibility for cable entry and egress. The Mighty Mo GX is UL and cUL listed,

UL 60950-1 2nd Edition, NWIN. These cabinets are configured-to-order, ensuring you get only what you need for your application.

Configured-to-Order

Dimensions

89.25”H x 31.5”W x 48”D

Weight Load Capacity

n ■

3,000 lbs static n ■

2,250 lbs on casters

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black or white

Note: For white cabinets, please contact your sales representative.

Enclosure Options

Description Part Number

Full Width Doors

OR-GXC4831DFM-B

OR-GXC4831DFP-B

OR-GXC4831DFS-B

Split Doors

OR-GXC4831DSM-B

OR-GXC4831DSS-B

EIA Mounting Rails

OR-GXC4831M12-B

OR-GXC4831M38-B

Side Panels

OR-GXC4848SPSL-B

Top Panels

OR-GXC3148TPC-B

OR-GXC3148TPS-B

OR-GXC3148TPV-B

Casters

OR-GXCCSTR-B

Full width, mesh, 180° swing

Full width, Plexiglas

®

, 180° swing

Full width, solid, 180° swing

Split, mesh, 180° swing

Split, solid, 180° swing

# 12-24 tapped, 12 ga., includes 2 rails

0.375” square hole, 14 ga., includes 2 rails

48” deep, solid, locking, covers 1 side of frame

48” deep, cabling H-panel

48” deep, solid, includes (2) 4” diameter grommets

48” deep, vented or fan, includes (2) 4” diameter grommets

Casters, set of 4

Cable Management

OR-GXC3106CTCE-B

OR-GXC3112CTCE-B

OR-GXC3118CTCE-B

OR-GXC31WMK-5-B

Center exit cable trough, 6” wide

Center exit cable trough, 12” wide

Center exit cable trough, 18” wide

Wire manager kit, mounts between (2) 31.5”W frames, kit of 5

OR-GXC48VFK-B

OR-GXC4806VWT-B

OR-GXC48VPMLS-B

OR-GXC48VPMLD-B

Airflow Management

OR-GXC4831ADK-B

Vertical finger kit, covers 1 rail

Vertical wire trellis, 6” wide

Cable lacing / PDU mount, single-wide

Cable lacing / PDU mount, double-wide

OR-GXCAB481631SA-B

OR-GXCAB483031SA-B

OR-GXCAB481631-B

OR-GXCAB483031-B

Air dam kit, 31.5”W cabinet

Angled airflow baffles, 16.25”D, mount at end of 31.5”W frame

Angled airflow baffles, 30”D, mount at end of 31.5”W frame

Angled airflow baffles, 16.25”D, mount between (2) 31.5”W frames

Angled airflow baffles, 30”D, mount between

(2) 31.5”W frames

OR-GXC4831SPB-B Side patching baffle - covers one side of cabinet

Note: Air dam kit and side patching baffle are available in white, all other accessories are black.

109

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

Accessories

Hardware

n

OR-MMCRULBL-60-A n■

OR-MMCUN-1420-10

Fans

n

OR-MMCFAN-6 n■

OR-MMCFAN-6-2 n

OR-MMCFANP19-4-2

Brush

n

OR-GXCTPBK

Shelves

n

OR-MMCSSVH-1930 n■

OR-MMCSSVL-1924 n

OR-MMCSSVM-1924 n■

OR-MMCCSS2-1915 n

OR-MMCCSS3-1915 n■

OR-MMCCSV1-1912 n

OR-MMCCSV2-1915 n■

OR-MMCCSV3-1915 n

OR-MMCFSV-1926

Adhesive rack unit label, 60 RU length

Unistrut hardware kit, 1/4-20 bolts and Unistrut nuts, set of 10

6” fan, 235 CFM, 120 V, 24” cord

6” fan, 235 CFM, 208 V, 24” cord

19” fan panel, includes (2) 4” fans, 110 CFM ea. 120 V, 24” cord

Top panel brush kit

Vented, sliding shelf, 300 lb capacity, 4 point, 19”H x 30”D

Vented, sliding shelf, 100 lb capacity, 4 point, 19”H x 24”D

Vented, sliding shelf, 150 lb capacity, 4 point, 19”H x 24”D

Solid, cantilevered shelf, 2 RU, 50 lb capacity, 19”H x 15”D

Solid, cantilevered shelf, 3 RU, 100 lb capacity, 19”H x 15”D

Vented, cantilevered shelf, 1 RU, 50 lb capacity, 19”H x 12”D

Vented, cantilevered shelf, 2 RU, 50 lb capacity, 19”H x 15”D

Vented, cantilevered shelf, 3 RU, 100 lb capacity, 19”H x 15”D

Vented, fixed shelf, 200 lb. capacity, 19”H x 26”D, 4 point

OR-MMCUN-1420-10

OR-MMCFAN-6

OR-MMCCSS1-1912

OR-MMCFSV-1926

OR-MMCDR2-1915

OR-MMCFPS-2-B

OR-BFPT-1RU-10

OR-BFPT-2RU-10

Drawers

n

OR-MMCDR2-1915 n

OR-MMCDR4-1915

Blanking Panels

n

OR-MMCFPS-1-B n

OR-MMCFPS-2-B n

OR-MMCFPS-3-B n

OR-MMCFPS-4-B n

OR-MMCFPS-5-B n

OR-MMCFPS-6-B n

OR-MMCFPT-1-B n

OR-MMCFPT-2-B n

OR-MMCFPT-3-B n

OR-MMCFPT-4-B n

OR-MMCFPT-8-B n

OR-BFPT-1RU-10 n

OR-BFPT-2RU-10

Note: All accessories are black unless otherwise noted.

2U drawer, 19”W x 15”D

4U drawer, 19”W x 15”D

1 RU filler panel, #12-24 mounting hardware

2 RU filler panel, #12-24 mounting hardware

3 RU filler panel, #12-24 mounting hardware

4 RU filler panel, #12-24 mounting hardware

5 RU filler panel, #12-24 mounting hardware

6 RU filler panel, #12-24 mounting hardware

Toolless filler panel, 1 RU

Toolless filler panel, 2 RU

Toolless filler panel, 3 RU

Toolless filler panel, 4 RU

Toolless filler panel, 8 RU

Snap in Toolless filler panel, 1 RU, 19”W x 1.75”H, pack of 10

Snap in Toolless filler panel, 2 RU, 19”W x 3.5”H, pack of 10

111

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo GX Cabinets

Accessories

Cable Tray Mounting Brackets

n

OR-MMCCTMB06-B

Cable tray mounting bracket with Cablofil FAS attachment for 6”W tray, black n■

OR-MMCCTMB12-B

Cable tray mounting bracket with Cablofil FAS attachment for 12”W tray, black n

OR-MMCCTMB18-B

Cable tray mounting bracket with Cablofil FAS attachment for 18”W tray, black

Cable Runway Mounting Brackets

n

OR-MMCCRMB06-B

Cable runway mounting bracket for 6”W runway, black n■

OR-MMCCRMB12-B n

OR-MMCCRMB18-B

Cable runway mounting bracket for 12”W runway, black

Cable runway mounting bracket for 18”W runway, black

OR-MMCCTMB12-B

OR-MMCCRMB12-B

The Ortronics line of cabinet hardware provides the products needed to complete your installation.

Rack unit cage nuts enable easy and quick installation of three cage nuts simultaneously.

113

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Wall Mount Cabinets

The Mighty Mo wall mount cabinets utilize advanced cable management to help secure, support and organize your network where floor space is limited.

Providing capacity for both active and passive equipment, the cabinets feature 1 rack unit finger style vertical managers to ensure proper cable management for maximum network performance.

An optional rear horizontal mount bracket kit is designed to provide 2 additional fixed rack units on the rear wall for mounting fiber, equipment or power distribution units. In addition, the cabinet center section swings out from the wall to provide easy access to the equipment.

The front lockable wing turn latch allows you to secure the front door without having to lock the cabinet. This feature allows for easy access into the front of the cabinet when you are in a secure environment.

The Mighty Mo wall mount cabinets are also an ideal choice for mounting in an open office environment. The cabinet’s heavy duty construction minimizes sagging under heavy loads and the optional 50cfm fan is 50% quieter than most other leading cabinets.

Dimensions

20” and 26” deep frames

Weight Load Capacity

n ■

150-300 lbs

Agency Approvals

n ■

UL60950-1

Compliant with

n ■

RoHS n ■

EIA

Colors

n ■

Black

Enclosure Options

Part Number Description Weight

Capacity

20”D wall mount cabinets

OR-MMW122420S-B

OR-MMW122420P-B

12U: 23.50”H x 24”W x 20”D, solid door, black 150 lbs

12U: 23.50”H x 24”W x 20”D, Plexiglas

®

door, black 150 lbs

OR-MMW192420S-B

OR-MMW192420P-B

19U: 35.75”H x 24”W x 20”D, solid door, black 200 lbs

19U: 35.75”H x 24”W x 20”D, Plexiglas

®

door, black 200 lbs

OR-MMW262420S-B

OR-MMW262420P-B

26”D wall mount cabinets

26U: 48.00”H x 24”W x 20”D, solid door, black 300 lbs

26U: 48.00”H x 24”W x 20”D, Plexiglas

®

door, black 300 lbs

OR-MMW122426S-B

OR-MMW122426P-B

12U: 23.50”H x 24”W x 26”D, solid door, black 150 lbs

12U: 23.50”H x 24”W x 26”D, Plexiglas

®

door, black 150 lbs

OR-MMW192426S-B

OR-MMW192426P-B

OR-MMW262426S-B

OR-MMW262426P-B

19U: 35.75”H x 24”W x 26”D, solid door, black 200 lbs

19U: 35.75”H x 24”W x 26”D, Plexiglas

®

door, black 200 lbs

26U: 48.00”H x 24”W x 26”D, solid door, black 300 lbs

26U: 48.00”H x 24”W x 26”D, Plexiglas

®

door, black 300 lbs

Wall mount accessories

OR-MMCFAN-4-50 Fan kit, 4”, 50cfm with finger guard, 2’ power cord

OR-MMWHMBM12-B Rear horizontal mount bracket kit

OR-MMWBPK Brush plate kit

Mounting rails

OR-MMW12M12-B

OR-MMW19M12-B

OR-MMW26M12-B

12U, #12-24 tapped holes, includes 2 rails

19U, #12-24 tapped holes, includes 2 rails

26U, #12-24 tapped holes, includes 2 rails

115

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cabinets

General Accessories

n

OR-PS-1224CN n■

OR-PS-M6X1-50 n

OR-PS- M6X1CN n■

OR-RU-1224CN n

OR-MM6BLC n

OR-MM6HMF1RU n■

OR-MM6HMF2RU n

OR-MMCCNTOOL

#12-24 cage nut kit, pack of 50, clear zinc

Panel mounting screws, M6 x 1 x 0.625”, pack of 50, clear

Cage nut kit, pack of 50, clear zinc

Cage nut assembly, 1 RU, #12-24 threads, pack of 50

Bend limiting clips, set of 12

MM6 horizontal cable management panel, 1 RU, black

MM6 horizontal cable management panel, 2 RU, black

Cage nut installation tool

OR-PS-1224CN

OR-RU-1224CN

OR-MM6HMF1RU

OR-MMCCNTOOL

The Ortronics line of cabinet hardware provides the products needed to complete your installation.

Rack unit cage nuts enable easy and quick installation of three cage nuts simultaneously.

117

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Looking for a Cisco Approved

Home for Your Nexus 7010 or 7018 Switch?

We have specifically designed Mighty Mo Cabinets and Mighty Mo

10 Four-Post Racks to accommodate the Cisco Nexus 7018 Data

Center Switch requirements.

This specific group of products expands upon the traditional airflow and cable management features of the Mighty Mo line to support the unique cooling and density needs of the Nexus 7018.

Visit www.legrand.us/ortronics/cabinets for more information.

Legrand | Ortronics is a Cisco Verified

Cabinet Vendor for the Nexus 7018

Data Center Switch

Ortronics Mighty Mo

Cabinets and

Mighty Mo 10 Four-Post

Racks boast industry leading airflow and cable management features that address the cooling and high density requirements in the data center and SAN environments of today and the future.

The Mighty Mo Cabinet for the Cisco Nexus 7018 (stand-alone version)

n

OR-MMC424846-00001

Mighty Mo cabinet, 42U X 48”W X 46”D for Cisco 7018 with dual side car kit, black n

0R-MMC474846-00001

Mighty Mo cabinet, 47U X 48”W X 46”D for Cisco 7018 with dual side car kit, black

Note: Includes the 32”W cabinet with mounting rails, front and rear doors, (2) side extensions, (2) side panels, (1) piece roof, (2) vertical “U” shaped cable managers, and all of the internal baffles.

For creating a stand-alone Nexus 7018 cabinet from an existing 32”W Mighty Mo Cabinet

n

OR-MMC421646-SC001

Mighty Mo dual side cart kit, 42U X 16”W X 46”D for Cisco 7018, black n

OR-MMC471646-SC001

Mighty Mo dual side cart kit, 47U X 16”W X 46”D for Cisco 7018, black

Note: Includes (2) side extensions, (2) vertical “U” shaped cable managers, all of the internal baffles and mounting hardware.

For creating a Nexus 7018 cabinet from two 32”W Mighty Mo Cabinets at the end of a row

n

OR-MMC420846-SC001

Mighty Mo single side car kit, 42U X 8”W X 46”D for Cisco 7018, black n

OR-MMC470846-SC001

Mighty Mo single side car kit, 47U X 8”W X 46”D for Cisco 7018, black

Note: Includes (1) side extension, (1) vertical “U” shaped cable manager and all of the internal baffles and mounting hardware.

For creating a Nexus 7018 cabinet in the center cabinet of three 32”W Mighty Mo Cabinets

n

OR-MMCAB427018

Mighty Mo in row baffle kit, 42U X 46”D for Cisco 7018, black n

OR-MMCAB477018

Mighty Mo in row baffle kit, 47U X 46”D for Cisco 7018, black

Note: Includes all of the internal baffles and mounting hardware.

Mighty Mo 10 Cable Management Racks

n

Cable Management Racks

The patented Mighty Mo advanced racking system is specifically designed for higher density cabling system applications such as data centers, SANs and main cross connect areas. It is easy to assemble and offers many configuration options, extra vertical cable capacity and other functional and aesthetic elements. The Mighty Mo system features an innovative vertical management “cage” with individual 1-rack unit fingers and a double-hinged door. Horizontal cable managers, available with covers, are designed to match the layout of Ortronics Clarity patch panels. Mighty Mo racks and accessories work together to mount, manage and organize virtually any structured cabling equipment and provide a unified, streamlined look.

Choose from the new Mighty Mo 10 rack, specifically designed to improve airflow in data centers, or the Mighty Mo 6 for standard LAN applications.

n ■

Patented channel construction has built-in strain relief, bend radius control and cable routing with floor and ceiling access to distribution cables n ■

Top trough with built-in waterfall provides bend radius control and efficient patch cable routing n ■

Vented double hinged front and rear doors are available for additional security on Mighty Mo 6 and Mighty Mo 10 racks n ■

Can be assembled as a 19” or 23” rack. No additional hardware required; no need for two

sizes of racks n ■

Unless otherwise noted, all Mighty Mo 6 and Mighty Mo 10 components are compatible with both racks

Mighty Mo Speednut

Faster Assembly!

Included with every Mighty Mo cable management rack. The Mighty

Mo Speednut increases the speed and ease of assembly while adding extra strength to your racks! Hold the Speednut behind the rack while hand tightening the bolts in front.

Speednut eliminates the need for a second wrench!

Mighty Mo 10

Rack

Mighty Mo 10

Vented Door

Assemblies

Door design allows mounting to the front or rear of any Mighty Mo 6 or

Mighty Mo 10 rack.

The double-hinged door pivots to the right or left and is easily removed.

Black.

Mighty Mo 10

Airflow Baffle

Mighty Mo 10 airflow baffles mount between racks and direct intake and exhaust air on side-flow network equipment from cold aisle to hot aisle. Black.

Mighty Mo 10

Cable Management

Cage with Door

Cage design promotes efficient routing of patch cords between racks. Hinged doors allow easy access during moves, adds and changes. 16” wide cage creates a 12.25” gap between racks.

12” wide cage creates a 8.25” gap between racks for front-to-back routing of equipment cables and patch cords. Both are supplied with

(4) spools and

(12) bend-limiting clips. Black.

121

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo 10 Racks

n

7’H Cable Management Racks and Equipment Racks

Cable Management Racks

Mighty Mo 10 racks are designed to maximize the airflow of network equipment. Honeycomb side rails and baffles combine to manage intake and exhaust air, creating cold aisle/hot aisle air distribution from side vented equipment. The bottom flange turns inward, allowing it to fit on a

2’ x 2’ floor tile.

Equipment Racks

The Mighty Mo 10 equipment rack works with all of the Mighty Mo 6 and 10 racks and cable management. The mounting rails adjust from 12.5” to 30”, independent of the structural members allowing the rails to be adjusted after the rack is installed. Mighty Mo vertical managers can be mounted front or rear.

Dimensions

7’H, 16.25” channel depth and 4-post adjustable to 30” depth

Weight Load Capacity

n ■

1,500 lbs (static)

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

OR-MM10716

OR-MM107SVR

Rack Options

Part Number Description

7’H cable management and equipment racks

OR-MM10716 16.25” channel depth, 45 rack units, 7’H

Note: Static capacity: 1,500 lbs Assembly required. Patent number 8,130,494.

OR-MM107SVR

4-post aluminum frame, supplied with 50 #12-24 cage nuts and screws, 45 rack units, 7’H

Note: Static capacity: 1,500 lbs (evenly distributed) Assembly required.

Cable management cage with door

OR-MM10VMD712

OR-MM10VMD716

With door, 7’H x 12.13”W x 13”D

With door, 7’H x 16.38”W x 13”D

Note: All cable managers include hardware necessary to mount the cage on the face of two Mighty Mo 6 or 10 racks. Patent Numbers 6,946,605, 6,968,647 and 7,026,553.

Airflow baffles

OR-MM10AB71612

OR-MM10AB71616

For use with 7’H x 16”D Mighty Mo 10 rack and 12”W

Mighty Mo 10 cage

For use with 7’H x 16”D Mighty Mo 10 rack and 16”W

Mighty Mo 10 cage

OR-MM10AB73012

OR-MM10AB73016

For use with 7’H Mighty Mo 10 equipment rack and 12”W

Mighty Mo 10 cage when rails are spaced at 30” apart

For use with 7’H Mighty Mo 10 equipment rack and 16”W

Mighty Mo 10 cage when rails are spaced at 30” apart

Note: Includes all hardware necessary to mount between two Mighty Mo 10 racks. Not intended for use with

Mighty Mo 6 racks. Patent number 8,130,494.

Vertical cable trays

OR-MM1070206VCT

Vertical cable tray 2”W x 6”D for the

Mighty Mo 10 7’H equipment rack

Note: Product dimensions are listed by width, height and depth unless specified otherwise.

End panels (narrow). For use with 10”, 12” and 16” vertical cable managers

OR-MM6EPN716 For 7’H rack with 16.25” channel

OR-MM10EPN730

For 7’H Mighty Mo 10 equipment rack rails set at 30’’

Note: Includes mounting hardware

OR-MM10EPS End panel support bracket kit

Note: To use the narrow end panels with 10” or 12” vertical managers, the OR-MM10EPS end support bracket kit must be installed.

123

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo 10 Cable Management Racks

n

8’H Cable Management and Equipment Racks

Cable Management Racks

Mighty Mo 10 racks are designed to maximize the airflow of network equipment. Honeycomb side rails and baffles combine to manage intake and exhaust air, creating cold aisle/hot aisle air distribution from side vented equipment. The bottom flange turns inward, allowing it to fit on a

2’ x 2’ floor tile.

Equipment Racks

The Mighty Mo 10 equipment rack works with all of the Mighty Mo 6 and 10 racks and cable management. The mounting rails adjust from 12.5” to 30”, independent of the structural members allowing the rails to be adjusted after the rack is installed. Mighty Mo vertical managers can be mounted front or rear.

Dimensions

8’H, 16.25” channel depth and 4-post adjustable to 30” depth

Weight Load Capacity

n ■

1,500 lbs (static)

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

OR-MM10816

OR-MM108SVR

Rack Options

Part Number Description

8’H cable management and equipment racks

OR-MM10816 16.25” channel depth, 51 rack units, 8’H

Note: Static capacity: 1,500 lbs Assembly required. Patent 8,130,494.

OR-MM108SVR

4-post aluminum frame, supplied with 50 #12-24 cage nuts and screws, 51 rack units, 8’H

Note: Static capacity: 1,500 lbs (evenly distributed) Assembly required.

Cable management cage with door

OR-MM10VMD812

OR-MM10VMD816

With door, 8’H x 12.13”W x 13”D

With door, 8’H x 16.36”W x 13”D

Note: All cable managers include hardware necessary to mount the cage on the face of two Mighty Mo 6 or 10 racks. Patent Numbers 6,946,605, 6,968,647 and 7,026,553.

Airflow baffles

OR-MM10AB81612

OR-MM10AB81616

For use with 8’H x 16”D Mighty Mo 10 equipment rack and 12”W

Mighty Mo 10 cage

For use with 8’H x 16”D Mighty Mo 10 rack and 16”W

Mighty Mo 10 cage

OR-MM10AB83012

OR-MM10AB83016

For use with 8’H Mighty Mo 10 equipment rack and 12”W

Mighty Mo 10 cage when rails are spaced at 30” apart

For use with 8’H Mighty Mo 10 equipment rack and 16”W

Mighty Mo 10 cage when rails are spaced at 30” apart

Note: Includes all hardware necessary to mount between two Mighty Mo 10 racks. Not intended for use with

Mighty Mo 6 racks. Patent 8,130,494.

Vertical cable trays

OR-MM1080206VCT

Vertical cable tray 2”W x 6”D for the

Mighty Mo 10 8’H equipment rack

Note: Product dimensions are listed by width, height and depth unless specified otherwise.

End panels (narrow). For use with 10”, 12” and 16” vertical cable managers

OR-MM6EPN816 For 8’H rack with 16.25” channel

Note: Includes mounting hardware

OR-MM10EPS End panel support bracket kit

Note: To use the narrow end panels with 10” or 12” vertical managers, the OR-MM10EPS end support bracket kit must be installed.

125

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo 6 Racks

n

Cable Management and Equipment Racks

The patented Mighty Mo advanced racking system is specifically designed for higher density cabling system applications such as data centers, SANs and main cross connect areas. It is easy to assemble and offers many configuration options, extra vertical cable capacity and other functional and aesthetic elements. The Mighty Mo system features an innovative vertical management “cage” with individual 1-rack unit fingers and a double-hinged door. Horizontal cable managers, available with covers, are designed to match the layout of Ortronics Clarity patch panels. Mighty Mo racks and accessories work together to mount, manage and organize virtually any structured cabling equipment and provide a unified, streamlined look.

Choose from the new Mighty Mo 10 rack, specifically designed to improve airflow in data centers, or the Mighty Mo 6 for standard LAN applications.

n ■

Patented channel construction has built-in strain relief, bend radius control and cable routing with floor and ceiling access to distribution cables n ■

Top trough with built-in waterfall provides bend radius control and efficient patch cable routing n ■

Vented double hinged front and rear doors are available for additional security on Mighty Mo 6 and Mighty Mo 10 racks n ■

Can be assembled as a 19” or 23” rack. No additional hardware required; no need for two

sizes of racks n ■

Unless otherwise noted, all Mighty Mo 6 and Mighty Mo 10 components are compatible with both racks

Mighty Mo Speednut

Faster Assembly!

Included with every Mighty Mo cable management rack. The Mighty

Mo Speednut increases the speed and ease of assembly while adding extra strength to your racks! Hold the Speednut behind the rack while hand tightening the bolts in front.

Speednut eliminates the need for a second wrench!

Mighty Mo 6

Rack

Mighty Mo 6

Cable Management

Cage with Door

Cage design promotes efficient routing of patch cords between racks. Hinged doors allow easy access during moves, adds and changes. 10” wide cage creates a 6.5” gap between racks. 6” wide cage creates a

2.5”gap between racks for front-to-back routing of equipment cables and patchcords.

Both are supplied with

(4) spools and (12) bend-limiting clips.

Black.

Mighty Mo 6

Vertical Cable

Management

Cage with Cover

Cage design promotes efficient routing of patch cords between racks. Dual snap on hinged covers allow easy access during moves, adds and changes. 6” wide cage creates a 2.5” gap between racks for front-to-back routing of equipment cables and patch cords. 6” wide cage is supplied with

(4) spools and (12) bend limiting clips. Black.

Mighty Mo 6

Vertical

Cable Management

Cage with Latches

Patented design promotes efficient routing of patch cords between racks.

Hinged latches allow easy access during moves, adds and changes.

6” wide cage creates a

2.5” gap between racks for front-to-back routing of equipment cables and patch cords. Black.

127

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo 6 Racks

n

7’H Cable Management Racks

Cable Management Racks

Mighty Mo 6 racks are available in 6.5”, 10.5” and 16.25” channel depths. The 16.25” size is designed specifically for large and heavy network equipment. The bottom flange on the 16.25” standard rack turns inward, allowing it to fit on a 2’ x 2’ floor tile.

Dimensions

7’H, 6.5”, 10.5” and 16.25” channel depths

Weight Load Capacity

n ■

1,500 lbs (static)

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

OR-MM6710

OR-MM6716

Rack Options

Part Number Description

7’H cable management racks

OR-MM6706

OR-MM6710

6.5” channel depth, 45 rack units, 7’H,

10.5” channel depth, high, 45 rack units, 7’H

OR-MM6716 16.25” channel depth, 45 rack units, 7’H

Note: Static capacity 1,500 lbs Assembly required. Patent No. D360,189.

Cable management cage with door

OR-MM6VMD706

OR-MM6VMD710

With door, 7’H x 6”W x 8”D

With door, 7’H x 10”W x 13”D

Note: All cable managers include hardware necessary to mount the cage on the face of two Mighty Mo 6 or 10 racks. Patent Numbers 6,946,605, 6,968,647 and 7,026,553.

Vertical cable management cage with cover

OR-MM6VMS704 With cover, 7’H x 4”W x 7”D

OR-MM6VMS706 With cover, 7’H x 6”W x 7”D

Note: Includes all hardware necessary to mount cage on face of two Mighty Mo 6 racks, single rack or end of row. Patent Numbers 6,946,605 and 7,026, 553.

Vertical cable management cage with latches

OR-MM6VML704

OR-MM6VML706

With latches, 7’H x 4”W x 6”D

With latches, 7’H x 6”W x 6”D

Note: Includes all hardware necessary to mount cage on face of two Mighty Mo 6 racks, single rack or end of row. Patent No. 6,365,834.

End panels (standard). For use with 6” vertical cable managers

OR-MM6EP706 For 7’H rack with 6.5” channel depth

OR-MM6EP710 For 7’H rack with 10.5” channel depth

OR-MM6EP716 For 7’H rack with 16.25” channel depth

End panels (narrow). For use with 4”, 10”, 12” and 16” vertical cable managers

OR-MM6EPN706 For 7’H rack with 6.5” channel

OR-MM6EPN710

OR-MM6EPN716

For 7’H rack with 10.5” channel

For 7’H rack with 16.25” channel

Note: Includes mounting hardware

OR-MM10EPS End panel support bracket kit

Note: To use the narrow end panels with 10” or 12” vertical managers, the OR-MM10EPS end support bracket kit must be installed.

129

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo 6 Racks

n

8’H Cable Management Racks

Cable Management Racks

Mighty Mo 6 racks are available in 10.5” and 16.25” channel depths. The 16.25” size is designed specifically for large and heavy network equipment. The bottom flange on the 16.25” standard rack turns inward, allowing it to fit on a 2’ x 2’ floor tile.

Dimensions

8’H, 10.5” and 16.25” channel depths

Weight Load Capacity

n ■

1,500 lbs (static)

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

OR-MM6810

OR-MM6816

Rack Options

Part Number Description

8’H cable management racks

OR-MM6810

OR-MM6816

10.5” channel depth, 8’H, 51 rack units

16.25” channel depth, 8’H, 51 rack units

Note: Static capacity 1,500 lbs Assembly required. Patent No. D360,189.

Cable management cage with door

OR-MM6VMD806

OR-MM6VMD810

With door, 8’H x 6”W x 8”D

With door, 8’H x 10”W x 13”D

Note: All cable managers include hardware necessary to mount the cage on the face of two Mighty Mo 6 or 10 racks. Patent Numbers 6,946,605, 6,968,647 and 7,026,553.

Vertical cable management cage with cover

OR-MM6VMS804 With cover, 8’H x 4”W x 7”D

OR-MM6VMS806 With cover, 8’H x 6”W x 7”D

Note: Includes all hardware necessary to mount cage on face of two Mighty Mo 6 racks, single rack or end of row. Patent Numbers 6,946,605 and 7,026, 553.

End panels (standard). For use with 6” vertical cable managers

OR-MM6EP810 For 8’H rack with 10.5” channel depth

OR-MM6EP816 For 8’H rack with 16.25” channel depth

End panels (narrow). For use with 10”, 12” and 16” vertical cable managers

OR-MM6EPN810 For 8’H rack with 10.5” channel

OR-MM6EPN816 For 8’H rack with 16.25” channel

Note: Includes mounting hardware

*To use the narrow end panels with 4”, 10” or 12” vertical managers, the

OR-MM10EPS end support bracket kit must be installed.

OR-MM10EPS End panel support bracket kit

131

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cable Management System

Mighty Mo Rack Accessories

Mighty Mo Waterfall Extension

Increases the height of the front flange of the Mighty Mo waterfall by 2.25” when additional cable capacity is required. Black.

n

OR-MM10WFE

Note: Fits all Mighty Mo 10 and 6 waterfalls.

Cable Management Rings

These plastic rings flex at the end for easy insertion or removal of cross connect cables.

They snap in place on the front and back of the Mighty Mo racks. Black.

n

OR-60400614 n

OR-60400542 n

OR-60400062

Note: Includes mounting hardware.

Snap-type, 1.75” X 6”, package of 14

Snap-type, 1.75” X 6”, package of 2 n

OR-60400314

Snap-type, 1.75” x 3”, package of 14 n

OR-60400302

Note : No hardware needed.

Snap-type, 1.75” x 3”, package of 2

Cable Management Rings

These rings allow efficient routing of patch or cross connect cables between distribution racks.

They can be mounted where needed on the front and back of the Mighty Mo racks. Black.

n

OR-60400017

2” x 6”, package of 14

2” x 6”, package of 2

OR-MM10WFE

OR-60400614

OR-60400017

OR-MM6CMS8

OR-MM6BLC

OR-MM6CBL10

OR-MMPDUMBT

Mighty Mo Cable Management Spools

Cable management spools effectively manage excess copper or fiber cable slack. They mount at rack unit intervals, providing flexibility and proper bend radius for cables on the front of the

6” wide cage with door or on the front and rear of the 10” wide cage with door. Set of four. Black.

n

OR-MM6CMS10

11” long for 10” vertical management cage with door n

OR-MM6CMS8 n

OR-MM6CMS6

8” long for 10” vertical management

6” long for 6” vertical management cage with door

Mighty Mo Bend Limiting Clip

Bend limiting clips snap on to any finger on the vertical management cage to provide bend limitation for fiber jumpers entering and exiting the cage. Set of 12. Black.

n

OR-MM6BLC

3.25” long for vertical management cages with door or cover

Mighty Mo Channel Bend Limiters

Mighty Mo channel bend limiters clip on to the top edge of Mighty Mo channels providing the proper bend radius for cables entering the channel. Set of 2. Black.

n

OR-MM6CBL06

For use with Mighty Mo racks with 6.5” channels n

OR-MM6CBL10 n

OR-MM6CBL16

For use with Mighty Mo racks with 10.5” channels

For use with Mighty Mo racks with 16.25” channels

Mighty Mo PDU Mounting Bracket Kit

Enables the mounting of toolless (button mount) PDUs to the side of a Mighty Mo rack.

n

OR-MMPDUMBT

Mighty Mo PDU Mounting Bracket Kit

133

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cable Management System

Mighty Mo Rack Accessories

Mighty Mo Vertical Management Bracket Kit

Vertical management bracket kit includes 4 brackets and all the hardware needed to mount

2 Mighty Mo 6 vertical managers to a standard EIA rack. Black.

n

OR-60400687

Kit consists of (4) brackets, (8) panel mounting screws and (4) cage mounting screws

Mighty Mo Cable Runway Mounting Brackets

Mounts to top of either the Mighty Mo 6 or Mighty Mo 10 racks. Provides a mounting location for 6”–18” ladder racking.

n

OR-MM6CRB06 n

OR-MM6CRB10 n

OR-MM6CRB16 n

OR-MM10CRBSVR n

OR-MM10CRBRSVR

For rack with 6.5” channel depth

For rack with 10.5” channel depth

For rack with 16.25” channel depth

For MM10 equipment rack

For rear of MM10 equipment rack

Mighty Mo Rack Base Dust Cover

Prevents dust and debris from accumulating in rack base. Scored for bending to clear cables from floor up to channel. Black.

n

OR-MM6BDC06

For 6.5” channel standard rack n

OR-MM6BDC10 n

OR-MM6BDC16

For 10.5” channel standard rack

For 16.25” channel standard rack

OR-60400687

OR-MM10CRBSVR

OR-MM6BDC16

OR-MM6CEK10

OR-MM6CT4RUK

Mighty Mo Runway Ceiling Extension Kit

Mounts on the top of Mighty Mo 6 racks. The kit extends one channel 24” and is supplied with a cover to hide the cables. Black. n

OR-MM6CEK06

For rack with 6.5” channel depth, (1) per kit with cover n

OR-MM6CEK10

For rack with 10.5” channel depth, (1) per kit with cover n

OR-MM6CEK16

Note: Extension uses rack hardware for mounting.

For rack with 16.25” channel depth, (1) per kit with cover

Mighty Mo Cable Trough

For supporting fiber cables at the bottom of Mighty Mo racks. The kit includes an extension that bridges the space between racks. Black. n

OR-MM6CT4RU

Cable trough, 4 rack units n

OR-MM6CT4RUK

Note: Extension uses rack hardware for mounting.

Cable trough kit, 4 rack units

Mighty Mo Isolation Pad Kit

Isolates Mighty Mo racks from concrete floors for effective bonding and grounding. n

OR-MMIPK

Isolation pad kit for Mighty Mo racks

OR-MMIPK

135

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cable Management System

Mighty Mo Horizontal Management

Mighty Mo Horizontal Management Panels

Ortronics Mighty Mo cable management panels are optimized to organize patch cords vertically and horizontally on Mighty Mo racks. They will also mount on any standard 19” rack. The finger design encourages defined and traceable routing of individual patch cords.

n

OR-MM6HMF1RU Multiple fingers, cover, (1) rack unit (1.75” x 19”) n

OR-MM6HMF2RU

Multiple fingers, cover, (2) rack units (3.5” x 19”) n

OR-MM6HMF4RU n

OR-MM6HM61RU n

OR-MM6HM62RU n

OR-MM6HM81RU n

OR-MM6HM82RU n

OR-MM6HM6D2RU

Multiple fingers, cover, (4) rack units (7.0” x 19”)

Six-port finger spacing, cover, (1) rack unit (1.75” x 19”)

For rack with 6.5” channel depth, (1) per kit with cover

For rack with 10.5” channel depth, (1) per kit with cover

For rack with 16.25” channel depth, (1) per kit with cover

For rack with 10.5” channel depth, (1) per kit with cover

OR-MM6HMF1RU

OR-MM6HMF4RU

OR-MM6HM62RU

OR-MM6HM6D2RU

OR-60400355

OR-604045681

OR-60400538

OR-70700126

Equipment Shelves for Mighty Mo Racks

Double Equipment Shelf for Mighty Mo Racks

Ortronics double equipment shelf supports miscellaneous equipment, test gear, etc.

The double shelf works with Mighty Mo racks with 6.5” deep channels. Black. n

OR-60400355

19” x 5.25” x 24”, 150 lbs capacity n

OR-60400517

23” x 5.25” x 24”, 150 lbs capacity n

OR-60400655

19” x 5.25” x 24”, 150 lbs capacity

Note: Shelf is slotted to accept the Ortronics monitor strap kit OR-70700126. Includes #12-24 mounting hardware.

Four Point Equipment Shelf for Mighty Mo Racks and Cabinets

Ortronics four point equipment shelf supports miscellaneous equipment or test gear. The one unit shelf works with Mighty Mo racks with all depth channels and Mighty Mo cabinets 24” and deeper. Shelf is 17.25” wide. Black. n

OR-604045681

19” x 1.72” x 20”, 100 lbs capacity

Note: Shelf is slotted to accept the Ortronics monitor strap kit OR-70700126. Includes #12-24 mounting hardware.

Mighty Mo Equipment Rack Shelf

The Mighty Mo equipment rack shelf has a fixed front flange with an infinitely adjustable rear flange that allows for secure four point mounting as deep as 30”. Shelf width is 17.25”. Black. n

OR-60400538

19” x 1.7” x 30”, 200 lbs capacity

Note: Shelf is slotted to accept the Ortronics monitor strap kit OR-70700126. Includes #12-24 mounting hardware.

Mighty Mo Monitor Strap Kit

The monitor strap kit consists of hook and loop straps which can secure a monitor with a base of any size or shape to all equipment shelves on this page. The monitor screen remains fully adjustable. Black.

n

OR-70700126

Hook and loop type strap kit

137

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Cable Management System

Mighty Mo Overhead Cable Pathway Rack

Mighty Mo Overhead Cable Pathway Rack

The Mighty Mo overhead cable pathway racks come with everything needed to mount the bracket to the side of Ortronics cable runway with 1-1/2” stringers or any Cablofil cable tray

2” or deeper. Black. n

OR-60401001 2 rack units, 7.4”H x 23.6”W x 9”D, 90 lbs capacity n

OR-60401015

5 rack units, 12.6”H x 23.6”W x 9”D, 90 lbs capacity n

OR-60401089

8 rack units, 23.6”W x 18.1”H x 9”D, 90 lbs capacity

OR-60401001

OR-BCGSM6X7

OR-BCGFM3X9

OR-BCGFMC3X9

OR-BCGFME5X7

Mighty Mo Accessories

Air Guard

®

Brush Cable Grommets

Features:

n ■

Provides an exceptional seal around cables for an effective and economical solution towards

eliminating bypass air through cable cutouts n ■

Provides an energy savings benefit by reducing cool air loss while improving the static

pressure to cool data center equipment n ■

Helps prevent network equipment from overheating n ■

Seals cable openings with an overlapping brush and/or EPDM gaskets to help prevent under

floor contamination n ■

Floor tiles can be removed without disconnecting equipment n ■

Flame retardant ABS polycarbonate material provides a finished look n

OR-BCGSM6X7* Surface mount two piece assembly designed to retrofit around existing cables without the need to disconnect cables. Covers any shape or size up to 10” x 10”.

n

OR-BCGFM3X9

Flush mount two piece assembly designed for new installations in data centers to maximize energy efficiency. Designed with a removable back brush that allows for great versatility when floor tiles need to be removed. n

OR-BCGFMC3X9

Cover fits over the flush mount brush cable grommet to provide a solid surface for increased durability and safety when cables are not going through the floor. n

OR-BCGFME5X7

Flush mount Extreme is a heavy duty unit with a two stage, integrated sealing system, EPDM gasket material (UL94 HF-1 rated) and standard Air Guard brush technology, to provide the most effective air seal.

A heavy duty, integrated safety cover comes as a standard component. OSHA jobsite statutes require open holes in floor panels to be covered. The cover may remain in place until cabling systems are installed and maybe saved for future use.

Note: *The OR-BCGSM6X7 can mount to any standard Mighty Mo Cabinet cable entry top panel to provide a layer of protection from dust and debris. One two piece grommet will cover both openings in a cable entry top panel.

139

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

n

4-Post Racks and Accessories

Adjustable Dual Equipment Racks

The patented, adjustable dual equipment rack provides an affordable, innovative solution for housing network equipment. Unlike cabinets, its open design allows for expansion, so it is ready to adapt to future needs. The design also expands installation opportunities by enabling crossconnects, facilitating cable management and eliminating heat build-up. Available with three adjustable depths, the rack provides a solid foundation for mounting hubs, routers and other heavy equipment.

Features: Self-supporting and self-squaring base; Assembles quickly and easily;

Top angles and patented reinforced base are standard; Depth adjusts in 1/2-inch increments;

Mounting holes are roll threaded for #12-24 hardware; Allows excellent cable management opportunities; Mounts 19” equipment and includes cross-recessed panel mounting screws;

5/8”, 5/8”, 1/2” universal mounting hole pattern; Equipped with standard 1/2” junctioning holes for securing multiple-rack lineups; Constructed of 6061-T6 structural grade aluminum.

Dimensions

84”H x 20.19”W x 15”–32”D

Weight Load Capacity

n ■

1,000 lbs

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

19-84-T4SDA2132

Part Number Description

Adjustable Dual Equipment Racks

OR-19-84-T4SDA1520

OR-19-84-T4SDA2132

OR-19-96-T4SDA2132

84”H x 20.19”W x 15-20”D, 45 rack units, load rating: 1,000 lbs

84”H x 20.19”W x 21-32”D, 45 rack units, load rating: 1,000 lbs

96”H x 20.19”W x 21-32”D, 51 rack units, load rating: 1,000 lbs

A

B

Equipment rack options self-support bases are 3-1/2” x 6” extruded aluminum angles mounted at the bottom of all standard adjustable equipment racks

C

1520 = 15.00–20.00”

2132 = 21.00–32.00”

1520 = 24.14–29.14”

2132 = 30.14–41.14”

1520 = 26.00–31.00”

2132 = 32.00–43.00”

141

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

n

OR-19-84-SSDA2132

M6 Adjustable Dual Equipment Rack

Features:

n ■

Self-squares to assemble quickly and easily n ■

Depth adjusts in 1/2” increments n ■

Open ventilation reduces the need for fans n ■

5/8”, 5/8”, 1/2” square hole mounting pattern n ■

Notched markers beside hole pattern facilitate counting of rack spaces n ■

Base mounts to rack with the angles facing inward or outward; mount inward to use

minimal floor space n ■

Universal L-shaped uprights allow for mounting of sliding server rails n ■

Steel construction allows 1000 lbs load rating n ■

Equipped with 1/2” junctioning holes for securing multiple-rack lineups n ■

Mounting hardware not included

Dimensions

84”H x 20.19”W x 21–32”D*

Weight Load Capacity

n ■

1,000 lbs

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Black

*Depth does not include top angle. For full depth, add 3”.

OR-19-84-SSDA2132

OR-ES-19-FDR2126

Accessories

Adjustable Equipment Shelves

Features: Mounts to all adjustable dual racks; #12-24 cage nuts and screws included; Adjust in the same 1/2” increments as the rack; Shelves do not include a front or back 90° bend; Easy to add and remove deep equipment; Mounted to all four uprights for maximum stability; Black.

Vented Equipment Shelf

n

OR-ESV-19-FDR1520

3.34”H x 17.50”W x 15–20”D, center load rating: 125 lbs, distributed load rating: 300 lbs n

OR-ESV-19-FDR2126 n

OR-ESV-19-FDR2732

Load rating determined at .25” deflection.

Equipment Shelf

3.34”H x 17.50”W x 21– 26”D, center load rating: 125 lbs, distributed load rating: 300 lbs

3.34”H x 17.50”W x 27– 32”D, center load rating: 125 lbs, distributed load rating: 300 lbs n

OR-ES-19-FDR1520 n

OR-ES-19-FDR2126 n

OR-ES-19-FDR2732

Load rating determined at .25” deflection.

3.34”H x 17.50”W x 15–20”D, center load rating: 125 lbs, distributed load rating: 300 lbs

3.34”H x 17.50”W x 21– 26”D, center load rating: 125 lbs, distributed load rating: 300 lbs

3.34”H x 17.50”W x 27– 32”D, center load rating: 125 lbs, distributed load rating: 300 lbs

143

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

4-Post Racks & Accessories

Fixed Dual Shelves

Features: Mounts to all adjustable dual racks; Heavy-duty for high-load bearing capacity;

Bottom brackets adjust to rack depth; Easy to add and remove deep equipment; Fully usable surface area to accommodate servers; Airflow slots ensure equipment is kept cool; #12-24 cage nuts and screws hardware included; Steel construction with black finish.

Fixed Dual Shelves

n

OR-ES-19-SDR1520F

1.94”H x 19”W x 20.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs n

OR-ES-19-SDR2126F n

OR-ES-19-SDR2732F

1.94”H x 19”W x 26.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs

1.94”H x 19”W x 32.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs

Vented Equipment Shelves

n

OR-ESV-19-SDR1520F n

OR-ESV-19-SDR2126F n

OR-ESV-19-SDR2732F

Load rating determined at .25” deflection.

1.94”H x 19”W x 20.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs

1.94”H x 19”W x 26.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs

1.94”H x 19”W x 32.50”D, center load rating: 125 lbs, distributed load rating: 300 lbs

OR-ESV-19-SDR2126F

OR-ESV-19-FST2126

OR-M6DRSAK

OR-DC1520-19

OR-RRJC-S

Adjustable Pull-Out Equipment Shelves

Features: Shelves glide forward and backward for equipment access; Auto-lock function responds when fully extended; Brackets secure the shelf to the rack when returned to its standard operating position; All shelves are vented; Adjust in 1/2” increments; M6DRSAK required when mounting on M6 rack; Black.

n

OR-ESV-19-FST1520

4.13”H x 17.50”W x 20.17”D, load rating extended: 275 lbs n

OR-ESV-19-FST2126

4.13”H x 17.50”W x 26.17”D, load rating extended: 275 lbs n

OR-ESV-19-FST2732

4.13”H x 17.50”W x 32.17”D, load rating extended: 275 lbs

Load rating determined by .50” deflection at end of extended shelf.

M6 Adapter Bracket

Features: Converts adjustable pull-out equipment shelf mounting on M6 adjustable dual racks;

Durable finish; (4) adapter brackets; Mounting hardware included; 12 ga. steel construction; Meets EIA-310 standards.

n

OR-M6DRSAK

3.50”H x 1” W x 3.19”D*

*Depth includes full depth (including bracket M6 latch hook).

Adjustable Dual Rack Dust Cover

Features: Fully shields the self-support base opening to keep dust from accumulating;

Mounts on all adjustable dual racks; Provides a clean installation; 3 piece cover easily assembles without the use of tools; Constructed of 16 ga. steel; Black.

n

OR-DC1520-19

19.38 ”W x 15–20”D n

OR-DC2126-19

19.38”W x 21–26”D n

OR-DC2732-19

19.38”W x 27–32”D

Adjustable Dual Rack Runway Kit

Features: Mounts runway to adjustable dual equipment rack; Brackets create a strong bond between the rack and the runway for solid overhead cable support; Includes (2) top angle brackets and (2) side brackets for parallel or perpendicular mounting.

n

OR-RRJC-S

Adjustable dual rack runway bracket kit

145

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Connect with us in the places you already are.

Be the first to know about our innovative product launches, join in on industry discussions and keep up to date with the latest how-to videos.

The easiest way to stay close to everything you care about.

n

Facebook

n■■

Twitter

n■■

LinkedIn

n■■

YouTube

n■■

Flickr

147

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

n

2-Post Racks & Accessories

Standard Equipment Racks

The computer-guided manufacturing process assures that each rack meets exact dimensions, guaranteeing a self-squaring assembly. Made of top quality 6061-T6 structural grade aluminum,

Ortronics equipment racks provide strength and stability for years. Racks ship unassembled for efficient delivery and storage.

Features:

n ■

Self-squaring and self-supporting n ■

Tapped uprights, no nuts are required for assembly n ■

Top angles, patented self-support base are standard n ■

Assembly hardware included n ■

Mounting holes are roll formed for work hardened thread system n ■

Includes #12-24 cross-recessed panel mounting screws n ■

Constructed of 6061-T6 structural-grade aluminum n ■

3” x 1 1/4” channel uprights

Specifications:

n ■

5/8”, 5/8”, 1/2” universal mounting hole pattern n ■

Equipped with 1/2” junctioning holes for securing multiple-rack lineups n ■

Meets EIA-310 standards

Compliant with

n ■

RoHS n ■

EIA/ECA-310E

Colors

n ■

Aluminum or black

OR-19-84-T2SD

Part Number

19” Rack – 3” Channel

Description

OR-19-72-T2SD

OR-19-84-T2SD

72”H x 20.19”W x 15”D, 38 rack units, channel width:

3”, load rating: 750 lbs

84”H x 20.19”W x 15”D, 45 rack units, channel width:

3”, load rating: 750 lbs

OR-19-96-T2SD

96”H x 20.19”W x 15”D, 51 rack units, channel width:

3”, load rating: 750 lbs

Aluminum finish. Add “B” to part number for black finish.

19” Rack – 6” Channel

OR-19-84-6T2SDB

84”H x 20.19”W x 18”D, 45 rack units, channel width:

6”, load rating: 750 lbs

23” Rack – 3” Channel

OR-23-72-T2SD

OR-23-84-T2SD

OR-23-96-T2SD

72”H x 24.19”W x 15”D, 38 rack units, channel width:

3”, load rating: 750 lbs

84”H x 24.19”W x 15”D, 45 rack units, channel width:

3”, load rating: 750 lbs

96”H x 24.19”W x 15”D, 51 rack units, channel width:

3”, load rating: 750 lbs

Aluminum finish. Add “B” to part number for black finish.

23” Rack – 6” Channel

OR-23-84-6T2SDB

84”H x 24.19”W x 18”D, 45 rack units, channel width:

6”, load rating: 750 lbs

149

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

Accessories

Equipment Rack Isolation Pad Kit

Isolates equipment racks from concrete floors for effective bonding and grounding.

n

OR-IPK

Isolation pad kit for standard equipment racks

Standard Vertical Cable Management Cage with Cover

Mounts to the side of a standard EIA rack. The fingers are spaced to line up with rack units, promoting efficient routing of patch cords to patch panels and equipment from the vertical manager. Dual snap on hinged covers allow easy access during moves, add and changes.

Available in single-sided and double-sided versions.

Single-sided

n

OR-SVMS704

7’H x 3.75”W x 6.58”D, single-sided n

OR-SVMS706 n

OR-SVMS804 n

OR-SVMS806

7’H x 6”W x 6.58”D , single-sided

8’H x 3.75”W x 6.58”D, single-sided

8’H x 6”W x 6.58”D, single-sided

Double-sided

n

OR-DVMS704 n

OR-DVMS706 n

OR-DVMS804 n

OR-DVMS806

Note: Includes all hardware necessary to mount to the side of a standard EIA rack.

7’H x 3.75”W x 13.17”D, double-sided

7’H x 6”W x 13.17”D, double-sided

8’H x 3.75”W x 13.17”D, double-sided

8’H x 6”W x 13.17”D, double-sided

OR-IPK

OR-SVMS706

OR-VO-84-T6FTE

Vertical Organizers

Patented vertical organizers save time and money during moves, adds and changes to patch panels. Rings in the front organize patch cords with ease. A rear, U-shaped channel is formed either between equipment racks or at the end of a lineup to provide a pathway for delivering horizontal cables to patch panels. The 6” width is used between fully loaded racks; the 3” width is used with a single rack, at the end of a lineup or between partially loaded racks. Black.

Features: Rings are spaced 9” apart, center ring is spaced 13” apart from others; Shipped in two sections for easy on-site assembly; Sturdy steel construction; Mounting hardware included: 6 of each: 3/8 hex nuts, 3/8 bolts, 3/8 lock washers, 3/8 flat washers; Fits all EIA-310 compliant equipment racks.

n

OR-VO-84-T3E n

OR-VO-84-T6E n

OR-VO-84-T3FTE n

OR-VO-84-T6FTE n

OR-VO-96-T3E n

OR-VO-96-T6E n

OR-VO-96-T3FTE n

OR-VO-96-T6FTE

Solid, channel width: 3”, 80”H x 3”W x 5.31”D

Solid, channel width: 6”, 80”H x 6”W x 5.31”D

Feed-through holes, channel width: 3”, 80”H x 3”W x 5.31”D

Feed-through holes, channel width: 6”, 80”H x 6”W x 5.31”D

Solid, channel width: 3”, 92”H x 3”W x 5.31”D

Solid, channel width: 6”, 92”H x 6”W x 5.31”D

Feed-through holes, channel width: 3”, 92”H x 3”W x 5.31”D

Feed-through holes, channel width: 6”, 92”H x 6 ”W x 5.31”D

151

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

Accessories

Vertical Control Brackets

Vertical control brackets attach to equipment racks to provide secure backside cable containment; Legrand | Ortronics recommends using (4) brackets on an 84” rack.

Features: Use with 6” vertical organizers for double-sided management; Sold individually

Includes #12-24 mounting hardware; Constructed of steel.

Use with 6” wide Vertical Organizers

n

OR-VCB-93-6L

Cable capacity: 216, 1”H x 8.56”W x 0.06”D n■

OR-VCB-93-6U n

OR-VCB-93-6H

Cable capacity: 216, 1”H x 7.28”W x 2.73”D

Cable capacity: 432, 1”H x 8.56”W x 6”D n

OR-VCB-93-6UH

Note: Black finish. Cable capacities are based on Cat5e cable and a 40% fill.

Cable capacity: 432, 1”H x 7.28”W x 3.69”D

Cable Brackets

Features: Attach to any equipment rack to secure cable; Used for routing vertically;

Includes #12-24 mounting hardware; Constructed of steel.

n

OR-CB-93-6

0.75”H x 0.71”W x 6”D n■

OR-CB-93-7 n

OR-CB-93-8

Note: Gray finish. Add “B” to part number for black finish.

0.75”H x 0.71”W x 7”D

0.75”H x 0.71”W x 8”D

OR-VCB-93-6L

OR-VCB-93-6H

OR-CB-93-6

OR-CR-93S-1B

OR-CR-93S-3B

OR-CR-93S-2B

OR-CR-93S-4B

Cable Rings

Features: Mount to any equipment rack, including Swing-EZs, for versatile vertical jumper management; Channel cables from the floor or ceiling to patch panels; CR-93S-1B and

CR-93S-3B rings fit within the width of a rack; they are designed for smaller, single-rack installations or where the width of the rack cannot be exceeded; Larger capacity CR-93S-2B and CR-93S-4B rings mount between adjacent racks and equal the combined width of the rack channels; they are designed for multiple rack installations; Slotted mounting holes for easy installation; able to mount beneath pre-installed equipment; Includes #12-24 mounting hardware; Constructed of 12 ga. steel; Sold individually.

n

OR-CR-93S-1B

Inside ring dimensions: 0.91”W x 2.50”D, 2 rack units, cable capacity: 27 n■

OR-CR-93S-2B

Inside ring dimensions: 2.19”W x 2.50”D, 2 rack units, cable capacity: 65 n

OR-CR-93S-3B

Inside ring dimensions: 0.91”W x 4.75”D, 2 rack units, cable capacity: 51 n

OR-CR-93S-4B

Inside ring dimensions: 2.19”W x 4.75”D, 2 rack units, cable capacity: 124

Note: Black finish. Cable capacities are based on Cat5e cable and a 40% fill.

Runway Bracket Kit

Mount runway to equipment racks using the runway bracket kit. J-Bolts secure the brackets to the top angles of racks and create a solid connection between the rack and runway. The kit is easy to install and includes all required hardware.

n

OR-RRJC-T

Note: Clear zinc plated.

Runway bracket kit

OR-RRJC-T

153

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

It’s finally here! Efficient product packaging for patch cords!

EZ Patch is not just another box. It’s a revolutionary, environmentally friendly way to dispense and manage patch cords for a quick and easy installation. Engineered to save time, expense and a whole lot of frustration, EZ Patch is unlike anything the industry has ever seen!

To learn more, visit www.legrand.us/ezpatch and contact your local distributor.

innovative clip

Clarity 6A, 6 or 5E patch cords

100% Recyclable

155

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

Accessories

Junction Plate

Used for junctioning cable runway and equipment racks. Runway can be junctioned parallel or perpendicular to rack. Hardware included.

For racks with 3” uprights

n

OR-JP0606B

7.50”L x 4”W x 0.25”D, for use with 6”W runway, black n■

OR-JP0612B

12.50”L x 4”W x 0.25”D, for use with runway from 6”W and 12”W, black n

OR-JP1218B n

OR-JP1824B

18.50”L x 4”W x 0.25”D, for use with runway from 12”W and 18”W, black

24.50”L x 4”W x 0.25”D, for use with runway from 18”W and 24”W, black

For racks with 6” uprights

n

OR-JP0606-6TB n■

OR-JP0612-6TB n

OR-JP1218-6TB n

OR-JP1824-6TB

7.50”L x 7”W x 0.25”D, for use with 6”W runway, black

12.50”L x 7”W x 0.25”D, for use with runway from 6”W and 12”W, black

18.50”L x 7”W x 0.25”D, for use with runway from 12”W and 18”W, black

24.50”L x 7”W x 0.25”D, for use with runway from 18”W and 24”W, black

Guard Rail

Features: Protects equipment from accidents; (1) guard rail per order; Sturdy steel construction; Mounting hardware included.

n

OR-GR-19

2.88”H x 19.81”W x 4.50”D n■

OR-GR-23

Note : Gray finish. Add “B” to part number for black finish.

2.88”H x 23.81”W x 4.50”D

OR-JP0612B

OR-GR-19

OR-DC-19B

Dust Cover

Features: Fully shields the self-support base opening to keep dust from accumulating;

Provides a clean installation; Cover easily assembles without the use of tools; Constructed of 16 ga. steel.

For racks with 3” uprights

n

OR-DC-19

0.75”H x 19.88”W x 5.30”D n■

OR-DC-23

Note: Gray finish. Add “B” to part number for black finish.

For racks with 6” uprights

n

OR-DC6-19B n■

OR-DC6-23B

Note: Black finish.

0.75”H x 23.88”W x 5.30”D

0.75”H x 19.88”W x 8.30”D

0.75”H x 23.88”W x 8.30”D

157

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

Wall Mount Racks & Brackets

Swing-EZ Wall Racks

The patented Swing-EZ wall rack arrives ready to square and keyhole mount in minutes.

Reinforcement plates stabilize the frame to allow maximum load bearing capacity. Hub and LAN applications are easily accommodated without door deflection. Latch pins or bolts secure the door to the frame and remove to swing open smoothly from the left or right.

Features: Opens to allow easy access without disturbing terminations; Both latch pins and bolts are included; Hook and loop straps feed into slots for backside cable management; Side panels fold flat for shipping, then unfold for easy on-site assembly; 5/8”, 5/8”, 1/2” universal mounting hole pattern; Mounting holes threaded for #12-24 hardware; Includes cross-recessed

#12-24 panel mounting screws; Made of steel; Meets EIA/ECA-310-E standards.

n

OR-19-21-T8D

21”H x 19.75”W x 8”D, 11 rack units, load rating: 75 lbs n■

OR-19-35-T8D n

OR-19-21-T12D n

OR-19-35-T12D

35”H x 19.75”W x 8”D, 19 rack units, load rating: 75 lbs

21”H x 19.75”W x 12”D, 11 rack units, load rating: 75 lbs

35”H x 19.75”W x 12”D, 19 rack units, load rating: 75 lbs n

OR-19-48-T12D n■

OR-19-21-T18D n

OR-19-35-T18D n

OR-19-48-T18D

48”H x 19.75”W x 12”D, 26 rack units, load rating: 75 lbs

21”H x 19.75”W x 18”D, 11 rack units, load rating: 75 lbs

35”H x 19.75”W x 18”D, 19 rack units, load rating: 75 lbs

48”H x 19.75”W x 18”D, 26 rack units, load rating: 75 lbs n

OR-19-21-T25D n■

OR-19-35-T25D

21”H x 19.75”W x 25”D, 11 rack units, load rating: 75 lbs

35”H x 19.75”W x 25”D, 19 rack units, load rating: 75 lbs n

OR-19-48-T25D

48”H x 19.75”W x 25”D, 26 rack units, load rating: 75 lbs

Note: Gray finish. Add “B” to part number for black finish. Load rating based on using swing feature. Load increases when fixed.

OR-JP0612B

OR-HFM-19-2

Cable Management Products for Swing-EZs

Ortronics cable management panels provide organized patch cables horizontally and vertically on Swing-EZ wall mount racks. Black.

For racks with 3” uprights

n

OR-HFM-19-2

Front rings: vertical 1.75”W x 3.75”D, front rings: horizontal 1.75”H x 1.75”D, back rings: horizontal 2.50”H x 1.62”D, 2 rack units

Heavy Duty Swing-EZ Wall Racks

Patented heavy duty Swing-EZ wall racks are designed to mount heavier networking equipment in tight closets. A 12 ga. steel reinforcement pan attached to the bottom of the rack provides added strength. The pan works in conjunction with the stabilization plates and the self-squaring feature, allowing sturdy, dependable 150 lbs equipment loads. The 25” depth allows plenty of room to open and close fully loaded with patch panels, hubs and routers.

Features: 150 lbs load rating accommodates hubs and routers; Swings open to the left or right for access to terminations; Hook and loop straps included for backside cable management;

Self-squaring assembly; Mounting holes threaded for #12-24 hardware; Includes cross-recessed panel mounting screws; 5/8”, 5/8”, 1/2” universal mounting hole pattern; Meets EIA/ECA-310-E standards; Made of steel; Both latch pins and bolts included for easy rear access.

n

OR-19-21-T25DHYDT

24.25”H x 19.75” W x 25”D, 11 rack units, load rating: 150 lbs n■

OR-19-35-T25DHYDT

Note: Gray finish. Add “B” to part number for black finish.

38.25”H x 19.75” W x 25”D, 19 rack units, load rating: 150 lbs

OR-19-35-T25DHYDT

159

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Standard EIA Racking Systems

Wall Mount Racks & Brackets

Wall Mount Racks

Ortronics wall mounted racks offer the flexibility of an 18” (457 mm) deep wall mounted unit for mounting telecommunications and data equipment. They are available in three heights, with front swing gates and 19” #12-24 threaded EIA pattern. Black.

n

OR-604045400

26”H x 20.25”W x 18”D, 12 rack units, load rating: 75 lbs n■

OR-604045450

38”H x 20.25”W x 18”D, 18 rack units, load rating: 100 lbs n

OR-604045451

50”H x 20.25”W x 18”D, 25 rack units, load rating: 125 lbs

Note: Fully assembled, supplied with 10 self-adhesive saddles and 12 – 6” hook and loop straps.

Hinged Wall Mount Brackets

Ortronics hinged wall mount brackets meet smaller system requirements and allow easy access to the rear of the panels. Holes in back allow for rear cable feed through. These brackets are available in four heights, with 19” #12-24 threaded EIA pattern. Fully assembled. Black.

n

OR-604004396 n■

OR-604004301 n

OR-604004068 n■

OR-604004645

3.5”H x 19”W x 6”D, 2 rack units

5.25”H x 19”W x 6”D, 3 rack units

7”H x 19”W x 6”D, 4 rack units

10.5”H x 19”W x 6”D, 6 rack units

OR-604045450

OR-604004396

OR-604004645

OR-60400131

OR-808045590

OR-808004867

OR-60400057

OR-808004759

OR-808004818

Horizontal Cable Management, Shelves

& Accessories

Cable Management Panels

Cable Management Panels

Ortronics cable management panels provide organized movement of patch cables horizontally and vertically on 19” EIA distribution racks. Black. n

OR-60400131 n

OR-60400057

(5) horizontal distribution rings, 1.7”H x 3.5”D, 1 rack unit

(5) horizontal distribution rings, 3”H x 4”D, 2 rack units n

OR-808045590 n

OR-808004759 n

OR-808004867 n

OR-808004818

(5) horizontal polycarbonate plastic distribution rings, 1.7”H x 6”D, 1 rack unit

(5) horizontal plastic distribution rings, 1.7”H x 2.70”D, 1 rack unit

(5) horizontal plastic distribution rings, 3.95”H x 2.4”D, 2 rack units

(5) horizontal plastic distribution rings, 3.95”H x 4.8”D, 2 rack units n

OR-808044855

(4) horizontal, (4) vertical distribution rings, 2”H x 4”D,

(24) routing clips, .10”W x 2.63”D, 2 rack units n

OR-808045768

(5) horizontal polycarbonate plastic distribution rings, 1.7”H x 3”D, 1 rack unit

Note: Includes #12-24 mounting hardware.

OR-808044855

OR-808045768

161

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Cable Management Panels

Feed-Through Cable Management Panels

Ortronics feed-through cable management panels provide organized management of patch cables horizontally, vertically and from front to back on 19” EIA distribution racks. Black.

n

OR-60400129 n■

OR-808044916 n

OR-60400426

(5) horizontal distribution rings, 1.7”H x 3.5”D, (4) 1” x 2” cutouts, 1 rack unit

(5) horizontal distribution rings, 3”H x 2”D, (4) 1.5” x 2” cutouts, 2 rack units

(5) horizontal distribution rings, 3”H x 4”D, (4) 2.75” x 2.75” cutouts, 2 rack units n■

OR-808044915

Note: Includes #12-24 mounting hardware.

(4) horizontal distribution rings, 2”H x 4”D, (24) routing clips,

.10”W x 2.63”D, (3) 1.5” x 2” cutouts, 2 rack units

Bend Limiting Cable Management Panels

Ortronics bend limiting cable management panels have curved falls that protect against cable crimping and also maintain proper bend radius. The panels are ideal at the top of standard

19” EIA racks. Black.

n

OR-60400189

1.7”H x 3.5”D rings with waterfall, 1 rack unit n■

OR-60400099 n

OR-60400114 n■

OR-60400098 n

OR-60400054

Note: Includes #12-24 mounting hardware.

3.5”H x 3.5”D rings with waterfall, 2 rack units

3.5”H x 6”D rings with waterfall, 2 rack units

7”H x 4.5”D rings with waterfall, 4 rack units

7”H x 7”D rings with waterfall, 4 rack units

OR-60400129

OR-808044915

OR-60400189

OR-60400098

OR-60400426

OR-60400114

OR-808044549

OR-FCM-19-2XL

OR-808000010

OR-808045030

OR-808044549

Finger Duct Cable Management Panels

Ortronics closed cover finger duct cable management panels provide organized movement for horizontal and vertical routing of patch cables on 19” EIA distribution racks. Black.

n

OR-808000010 n

OR-808044508

1.5”H x 1.5”D duct, 1 rack unit

3”H x 1.5”D duct, 2 rack units n

OR-808044549

3”H x 3”D duct, 2 rack units n■

OR-808045030

Front and rear ducts, 3”H x 3”D front duct, 2”H x 4”D rear duct, 2 rack units

Note: Includes #12-24 mounting hardware.

Interbay Organizers

Ideal for bulk routing patch cords between bays and within bays to eliminate congestion, interbay organizers are larger in capacity than patch cord organizers. Express routes make it easy to trace and maintain circuits.

Features: FCM-19-1XL, FCM-19-2XL and FCM-19-2XLH should be mounted at the top, center or bottom of equipment racks. FCM-19-2XLH features feed-through holes to accommodate front-to-back jumpering; The larger capacity FCM-19-4XL is mounted at the top or bottom of the rack. Rounded ring edges protect cables; Constructed of 16 ga. steel; Welded cable rings also constructed of steel for maximum support.

n

OR-FCM-19-1XL

Inside ring: 1.50”H x 3.50”D, 1.75”H x 20.19”W x 4.75”D, 1 rack unit n

OR-FCM-19-2XL

Inside ring: 3”H x 3.50”D, 3.50”H x 20.19”W x 4.94”D, 2 rack units n

OR-FCM-19-2XLH* n■

OR-FCM-19-4XL

Note: Black finish. *H = feed-through holes.

Inside ring: 3”H x 3.50”D, 3.50”H x 20.19”W x 4.94”D, 2 rack units

Inside ring: 6.50”H x 3.50”D, 7”H x 20.19”W x 4”D, 4 rack units

OR-FCM-19-2XLH*

163

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Cable Management Panels

Patch Cord Organizers

Patch cord organizers create horizontal and vertical pathways for frontside cable management.

Designed for use with patch panels, the organizers simplify the tracing, identifying and rerouting of patch cords.

Features: FCMs with side rings help manage wall rack installations; Use rack adapters when mounting organizers to 23” racks; Made of 16 ga. steel; 1SR and 1SRC made of

18 ga. steel.

n

OR-FCM-19-1

Inside ring: vertical 1.75”W x 3.75”D, 1 rack unit n■

OR-FCM-19-1SR n

OR-FCM-19-1SRC* n■

OR-FCM-19-2

Inside ring: vertical 1.75”W x 1.75”D, horizontal 1”H x 1.75”D, 1 rack unit

Inside ring: horizontal 1”H x 1.75”D, 1 rack unit

Inside ring: vertical 1.75”W x 3.75”D, horizontal 1.75”H x 1.75”D, 2 rack units n

OR-FCM-19-2SR n■

OR-FCM-19-2SRC*

Inside ring: vertical 1.75”W x 1.75”D, horizontal 1.75”H x 1.75”D, 2 rack units

Inside ring: horizontal 1.75”H x 1.75”D, 2 rack units n

OR-FCM-19-2L

Inside ring: vertical 1.75”W x 3.75”D, horizontal 1.75”H x 3.75”D, 2 rack units

Note: Black finish. * Recommended for use with vertical organizers.

Can also be used in cabinet installations.

OR-FCM-19-1

OR-FCM-19-1SR

OR-FCM-19-2SR

OR-FCM-19-2SRC*

OR-60400404

OR-60400006

OR-ESV-19-3B

OR-ESV-19-3B (upside-down)

Equipment Shelves

Equipment Shelves

Ortronics equipment shelf supports miscellaneous equipment or test gear. Can be mounted on standard 19” EIA racks. Inside shelf width is 17”. Black.

n

OR-60400404 n

OR-60400006

5. 25”H x 19”W x 10.13”D, 75 lbs capacity

5. 25”H x 19”W x 12.13”D, 75 lbs capacity n

OR-60400405 n

OR-ES-19-3B

5.25”H x 19”W x 15.13”D, 75 lbs capacity

Note: #12-24 mounting hardware included with all shelves.

Equipment Shelves

Features: Mounts to 19” or 23” equipment racks; Heavy-duty 16 ga. steel accommodates heavy equipment; Depth variety matches installation needs; Patented shelf can be mounted upside down; Vented to allow airflow beneath mounted equipment; Mounting hardware included; Black.

Solid Version

3.50”H x 17.38”W x 15.50”D, 2 rack units, load rating: 150 lbs n

OR-ES-19-4B n

OR-ES-23-3B

3.50”H x 17.38”W x 21.75”D, 2 rack units, load rating: 150 lbs

3.50”H x 21.38”W x 15.50”D, 2 rack units, load rating: 150 lbs n

OR-ES-23-4B

Vented Version

n

OR-ESV-19-3B n

OR-ESV-19-4B n

OR-ESV-23-3B n

OR-ESV-23-4B

3.50”H x 21.38”W x 21.75”D, 2 rack units, load rating: 150 lbs

3.50”H x 17.38”W x 15.50”D, 2 rack units, load rating: 150 lbs

3.50”H x 17.38”W x 21.75”D, 2 rack units, load rating: 150 lbs

3.50”H x 21.38”W x 15.50”D, 2 rack units, load rating: 150 lbs

3.50”H x 21.38”W x 21.75”D, 2 rack units, load rating: 150 lbs

165

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Equipment Shelves

4-Point Vented Equipment Shelf

This 4-point vented shelf can be used with the Mighty Mo racks in all three channel depths.

Shelf width is 17.5”. Black.

Vented Equipment Shelf for Mighty Mo Racks

n

OR-604045388

5.75”H x 19”W x 20”D, 150 lbs capacity

Vented Equipment Shelf

Ortronics vented equipment shelves keep active equipment cool. Can be mounted on standard

19” EIA racks. Shelf width is 17.5”. Black.

Cantilevered Vented Equipment Shelves

n

OR-604045075

5.75”H x 19”W x 20”D, 85 lbs capacity n■

OR-604045081

Standard Vented Equipment Shelf

n

OR-604045401

Vented Equipment Shelf, Fixed

n

OR-604044486

Vented Equipment Shelf, Slide-out

n

OR-604044938

5.75”H x 19”W x 24”D, 85 lbs capacity

4”H x 19”W x 16”D, 50 lbs capacity

4”H x 19”W x 18”D, 35 lbs capacity

4”H x 19”W x 18”D, 35 lbs capacity

OR-604045388

OR-604045401

OR-604044938

OR-ESV-19-FMB

Front-Mount Equipment Shelf

Features: Cantilever shelf mounts in several positions; 1/2”deep tray can be inverted to create a flat surface for deep equipment; Mounts to 3” or 6” channel; Choose between standard or vented version; Mounting hardware included; Made of 16 ga. steel.

Solid Version

n

OR-ES-19-FMB 5.25”H x 17.25”W x 14”D, 3 rack units, load rating: 50 lbs n

OR-ES-23-FMB

Vented Version

n

OR-ESV-19-FMB

5.25”H x 21.25”W x 14”D, 3 rack units, load rating: 50 lbs

5.25”H x 17.25”W x 14”D, 3 rack units, load rating: 50 lbs n

OR-ESV-23-FMB

5.25”H x 21.25”W x 14”D, 3 rack units, load rating: 50 lbs

Note: Black finish.

Multi-Configuration Equipment Shelf

Features: Mounts in at least 14 different ways; Mounts on 3” or 6” channel equipment racks;

Brackets invert to meet mounting space requirements; Shelf can be inverted to create a 3/4” deep tray; Mount two units back-to-back to form a double-sided shelf; Mounting hardware included; Made of 16 ga. steel.

n

OR-ES-19-MCSB

5.25”H x 17.50”W x 12”D, 3 rack units, load rating: 50 lbs

Multi-Configuration Equipment Shelf Mounting Options

OR-ES-19-MCSB

Shelf back to rack center

Shelf front flush to rack front

Shelf front 1-1/2” beyond rack front

Two units form a

24”double-sided shelf

Brackets can be inverted to meet mounting space requirements

Brackets can be inverted to meet mounting space requirements

Shelf can be inverted to make a 3/4”deep tray

167

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Equipment Shelves

Computer Tie Down Kit

Ortronics CPU tie down kit includes mounting plates with rubber bumpers which can be quickly attached to the EIA pattern on the front and rear of any rack with a rail depth from 3” to 6.5”.

The hook and loop strap with elastic center safely holds the CPU in place against the rubber bumpers. The CPU can be easily removed for service. Black.

n

OR-60400523

(1) hook and loop type strap, (2) brackets

Note: Includes #12-24 mounting hardware.

Patent No. 6,598,270.

Wall Mount Shelf

Ortronics wall mount shelf is designed for smaller systems applications or where space is limited and a free standing rack cannot be used. Black.

n

OR-604044927

4.875”H x 20”W x 18”D, 120 lbs capacity

Note: Shelf has six keyholes in the rear for mounting. Mounting hardware not included.

Folding Keyboard Shelf

This shelf has a keyboard tray which folds up and locks in place. The tray holds all full standard keyboards up to 19”W. Black.

n

OR-60400550

19” rack mount, 1 rack unit n■

OR-60400551

23” rack mount, 1 rack unit

Rear Support Brackets

Rear support brackets allow the folding keyboard shelf to support any standard computer monitor up to 35 lbs. The brackets adjust from 6.25” to 17”. Black.

n

OR-60400606

For folding keyboard shelf

OR-60400523

OR-604044927

OR-60400550

OR-604044938

OR-60400575

OR-KTR19-DR

Mouse Tray with Pad

The mouse tray slides underneath the keyboard tray when not in use. Black.

n

OR-60400575

Note: Mounting hardware included.

For folding keyboard shelf

Keyboard Tray

Features: Fits all standard keyboards and mounts to 19” equipment racks; Mouse pad tray slides beneath the keyboard tray when not in use; Mounting hardware is included; Mouse pad can be mounted on left or right side; Constructed of 16 ga. steel; Black.

n

OR-KTR19-DR

4.47”H x 20.38”W x 12”D, load rating: 25 lbs

Fold-Up Keyboard Tray

Features: Fits all standard keyboards and mounts to 19” equipment racks; Mouse pad tray slides beneath the keyboard tray when not in use; Keyboard tray folds upward against uprights when not in use; Mounting hardware is included; Mouse pad can be mounted on left or right side; Constructed of 16 ga. steel; Black.

n

OR-KTF-19-DR

Note: Mouse pad tray adds 7.28” to the direction extended.

3.50”H x 20.38”W x 7.13”D, load rating: 25 lbs

OR-KTF-19-DR

169

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Rack & Cabinet Accessories

Toolless Snap-in Filler Panels

Ortronics toolless snap-in filler panels are used to fill open rack units in racks and cabinets where separation of cold air and hot air is required. They are designed to work with active equipment and Ortronics flat, angled or curved patch panels.

The toolless snap-in filler panels unique patent pending design allows them to snap into 19”

EIA/ECA-310-E compliant tapped or square hole mounting rails. Because no field modification is required to fit a tapped hole, the panel can be remounted in a square hole in the future – eliminating the need to stock two different types of panels. Black.

n

OR-BFPT-1RU-10

19”W x 1.75”H, 1 rack unit, pack of 10 n■

OR-BFPT-2RU-10

19”W X 3.5”H, 2 rack units, pack of 10

Blank Filler Panels

Ortronics blank filler panels fill in open spaces on all standard 19” EIA racks and cabinets. They are composed of powder coated aluminum and have a blue silk screened logo. Includes #12-24 mounting hardware. Black.

Flat Blank Filler Panels

n

OR-401004788

19”W x 1.75”H, 1 rack unit n■

OR-401004789 n

OR-401004790 n■

OR-401004791 n

OR-401045773

19”W x 3.5”H, 2 rack units

19”W x 5.25”H, 3 rack units

19”W x 7”H, 4 rack units

19”W x 38.5”H, 22 rack units

OR-BFPT-1RU-10

OR-BFPT-2RU-10

OR-401004789

OR-401004790

OR-BFPA-2RU

OR-BFPC-1RU

OR-604045108

Blank Filler Panels

(cont)

Angled Blank Filler Panels

n

OR-BFPA-1RU n

OR-BFPA-2RU

Curved Blank Filler Panels

n

OR-BFPC-1RU

19”W x 1.75”H, 1 rack unit

19”W x 3.5”H, 2 rack units

19”W x 1.75”H, 1 rack unit

Rack Adapter Kit

Ortronics rack adapter kits allow 19” equipment to be used on 23” EIA racks. Includes #12-24 mounting hardware. Black.

n

OR-604045108

19” to 23”, 1.75”H, 1 rack unit n

OR-604045109

19” to 23”, 3.5”H, 2 rack units n

OR-604045110 n

OR-604045111 n

OR-604045112

19” to 23”, 5.25”H, 3 rack units

19” to 23”, 7”H, 4 rack units

19” to 23”, 8.75”H, 5 rack units

19” Equipment Support Bracket

Mounts on the rear of any 19” rack to support the weight of heavy equipment. The bracket is especially effective on the Mighty Mo racks where the channel depth is 6.5” or deeper. Includes

#12-24 mounting hardware. Black.

n

OR-60400383

19”W x 1.75”H x 1”D

OR-60400383

171

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Rack & Cabinet Accessories

19” Rack Mount Power Strips

The 8 outlet 20 AMP rack mount power strips are available with or without a switch, and with a standard 3 prong or twist-lock plug design. All four power strips come with 15’ of cord. Includes

#12-24 mounting hardware.

n

OR-50900051

19”W, 8 outlet, 20 AMP, circuit breaker, switch n■

OR-50900051-TL

19”W, 8 outlet, 20 AMP, circuit breaker, switch, twist-lock plug n

OR-50900052 n■

OR-50900052-TL

19”W, 8 outlet, 20 AMP, circuit breaker

19”W, 8 outlet, 20 AMP, circuit breaker, twist-lock plug

Power Strip for Mighty Mo Racks and Free Standing Cabinets

The 16-position power strip mounts vertically on the back of the Mighty Mo racks and on the inside frame of the Mighty Mo cabinets. Includes mounting hardware.

n

OR-60400381

Vertical, 49”, 16 outlet, 15 AMP, circuit breaker, switch, 15’ cord n■

OR-60400681

Vertical, 49”, 16 outlet, 20 AMP, circuit breaker, switch, 15’ cord

Wire Distribution Spool

This spool has a #12-24 stud molded in place and can be threaded into the EIA holes on any

Ortronics rack. Use it to mount cable management panels, patch panels or screw it in anywhere additional cable management is desired. Black.

n

OR-60400013

#12-24 stud

OR-50900051

OR-60400681

OR-60400013

OR-CMBFR0RU

OR-Z4-RR-WC

OR-60400005

OR-RU-1224CN

Cable Management Support Bar, Zero RU

Provides strain relief at the front or rear of a standard 19” patch panel that does not include rear management panels. The support bar is mounted with patch panel mounting screws to the front or with the supplied additional nuts to the rear. Black.

n

OR-CMBFR0RU

19.00”W x 4.00”D

Earthquake Bracing Kit

Earthquake bracing kits secure installations against excessive damage from earthquakes or simply add another measure of stability in areas not zoned. The kit is easy to install: Drill a 5/8” clearance hole in the top angle of your rack, attach brackets to both ends of a 5/8-11” threaded rod (ordered separately), then brace the assembly to a beam, column or load-bearing wall.

n

OR-Z4-RR-WC

Kit contains: 4 brackets - 5/8 hole, (2) 1/2-13 hex nuts,

(2) 1/2-13 x 1 bolt, (2) 1/2” split lock washer

Panel Mounting Screws

Ortronics mounting screws replace lost or damaged screws for patch panels and cable management panels. These combination head screws with #12-24 threads have a pilot point for easy starting. Black.

n

OR-60400005

#12-24 x .625”, package of 4 n

OR-60400533

#12-24 x .625”, package of 50

Rack Unit Cage Nuts

Ortronics rack unit cage nuts provide steel nuts in all 3 positions of a 1-3/4” rack unit with the installation of a single nut with multiple housings.

n

OR-RU-1224CN

Thread size: #12-24, package of 50 n■

OR-RU-M6X1CN

Thread size: M6 (metric), package of 50

173

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management, Shelves

& Accessories

Rack & Cabinet Accessories

Cage Nuts

Features: Adapts holes to meet specific server threads; Available in #10-32, #12-24 and M6 metric applications; Fits all EIA rack uprights with square holes; Heat treated with spring grip nut retainer for heavy-duty performance; Packaged in quantities of 50; Zinc plated;

Steel construction.

n

OR-PS-1032CN

0.50”H x 0.50”W x 0.38”D, thread size: #10-32 n■

OR-PS-1224CN

0.50”H x 0.50”W x 0.38”D, thread size: #12-24 n

OR-PS-M6X1CN

0.50”H x 0.50”W x 0.38”D, thread size: M6 (metric)

Hardware

Ortronics offers a selection of hardware to support the specific needs of each installation.

Order hardware with equipment racks and accessories to readily complete installations.

n

OR-JH-93

Junction hardware; (6) 3/8”x 3/4” bolts, with nuts and washers n■

OR-CA-93

Concrete floor anchors; set of (2) 3/8” x 3” bolts, with nuts and washers n

OR-WA-93

Wooden floor anchors; set of (2) 3/8” x 2” bolts, with washers

Saddles

Ortronics self-adhesive saddles will attach to any smooth dry surface and are designed to accept hook and loop straps. Sold in packages of 10. Black.

n

OR-70800205

Two-way, self-adhesive base for cable management straps up to

1.25” maximum width

OR-PS-1032CN

OR-WA-93

OR-70800205

OR-CA-93

OR-JH-93

OR-70700080

OR-70700143

OR-70700084-00

OR-60400199

Color-Coded Cable Management Straps

Ortronics color-coded cable management straps provide an organized solution for the management of patch and horizontal distribution cables. The 3/4” W straps have a hook and loop type closure to secure and administer cables without damaging the construction of the copper or fiber cable. Sold in packages of 10.

n

OR-70700080

6”L x 0.75”W, grip range: .625” to 1.625” diameter n

OR-70700079

12”L x 0.75”W, grip range: 1.25” to 3.25” diameter

Note: To order colored straps, specify color by putting color code at end of part number Color Code: -00=Black, -22=Red, -23=Orange,

-24=Yellow, -25=Green, -26=Blue (Example: To order a 6” red OR-70700080 strap: OR-70700080-22).

Color-Coded Cable Management Straps

Ortronics plenum cable management straps provide an organized solution for the management of cables in plenum rated air handling spaces. These 1/2” wide hook and loop type straps are reusable, easy to install and will not damage high performance cabling. Sold in 20 count rolls that are neat, convenient and quick to use. Cranberry.

n

OR-70700143

8”L x 0.5”W, grip range: .75”–1.75” diameter n

OR-70700144 n

OR-70700107-00

12”L x 0.5”W, grip range: .75”–3” diameter

D-Ring Cable Management Straps

Ortronics D-ring cable management straps provide an organized solution for the management of horizontal distribution cables. The 3/4” W straps have a hook and loop type closure to secure and administer cables without damaging the construction of the copper or fiber cable. Sold in packages of 10. Black.

12”L grip range: 1.5” to 2.5” diameter n

OR-70700084-00

18”L, grip range: 2” to 4” diameter

Bend Limiting Strain Relief Bar

Ortronics bend limiting strain relief bar has curved falls that maintain proper bend radius and prevent distribution cable from crimping. The panel mounts to the rear of standard 19” EIA racks. Route cable ties through the holes in the bar to hold cables in place.

n

OR-60400199

19” x 1” x 2.5”, fills 1 rack unit

175

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Horizontal Cable Management

Accessories

Power

Basic PDU

Increased processing speeds require additional power distributed to each cabinet. Managing the power while minimizing the interference with the rack equipment and airflow is critical.

The Ortronics range includes 120V and 208V basic power distribution in 15, 20 and 30 AMP sizes.

Horizontal

n

OR-MMCPB11510-01

17.5” PDU, 120V 15A, (10) NEMA 5-15 outlets, 5-15P input plug, 10’ cord n■

OR-MMCPB12010-01 n

OR-MMCPB22012-01

Vertical

n

OR-MMCPB11518-01 n■

OR-MMCPB11524-01 n

OR-MMCPB12018-01 n■

OR-MMCPB12024-01 n

OR-MMCPB13016-01 n■

OR-MMCPB13024-01 n

OR-MMCPB22018-01 n■

OR-MMCPB22024-01 n

OR-MMCPB23016-01 n■

OR-MMCPB23024-01

17.5” PDU, 120V 20A, (10) NEMA 5-20 outlets, L5-20P input plug, 10’ cord

17.5” PDU, 208V 20A, (12) IEC C13 outlets, L6-20P input plug, 10’ cord

29.5” PDU, 120V 15A, (18) NEMA 5-15 outlets, 5-15P input plug,10’ cord

66.5” PDU, 120V 15A, (24) NEMA 5-15 outlets, 5-15P input plug, 10’ cord

29.5” PDU, 120V 20A, (18) NEMA 5-20 outlets, L5-20P input plug, 10’ cord

66.5” PDU, 120V 20A, (24) NEMA 5-20 outlets, L5-20P input plug, 10’ cord

29.5” PDU, 120V 30A, (16) NEMA 5-20 outlets, L5-30P input plug,10’ cord

66.5” PDU, 120V 30A, (24) NEMA 5-20 outlets, L5-30P input plug, 10’ cord

29.5” PDU, 208V 20A, (18) IEC C13 outlets, L6-20P input plug, 10’ cord

66.5” PDU, 208V 20A, (24) IEC C13 outlets, L6-20P input plug, 10’ cord

29.5” PDU, 208V 30A, (16) IEC C13 outlets, L6-30P input plug, 10’ cord

66.5” PDU, 208V 30A, (24) IEC C13 outlets, L6-30P input plug, 10’ cord n

OR-MMCPB23024-02

66.5” PDU, 208V 30A, (20) IEC (4) IEC C19 outlets, L6-30P input plug, 10’ cord

OR-MMCPB11518-01 OR-MMCPM22018-01

Metered PDU

Increased processing speeds require additional power distributed to each cabinet. Monitoring and managing the power while minimizing the interference with the rack equipment and airflow is critical. Ortronics options include 120V and 208V metered power distribution in

20 and 30 AMP sizes.

Horizontal

n

OR-MMCPM12010-01

17.5” PDU, 120V 20A, (10) NEMA 5-20 outlets, L5-20P input plug, 10’ cord n

OR-MMCPM22012-01

Vertical

n

OR-MMCPM12010-01 n

OR-MMCPM12024-01

17.5” PDU, 208V 20A, (12) IEC C13 outlets, L6-20P input plug, 10’ cord

29.5” PDU, 120V 20A, (18) NEMA 5-20 outlets, L5-20P input plug, 10’ cord

66.5” PDU, 120V 20A, (24) NEMA 5-20 outlets, L5-20P input plug, 10’ cord n

OR-MMCPM13016-01 n

OR-MMCPM13024-01 n

OR-MMCPM22018-01 n

OR-MMCPM22024-01

29.5” PDU, 120V 30A, (16) NEMA 5-20 outlets, L5-30P input plug, 10’ cord

66.5” PDU, 120V 30A, (24) NEMA 5-20 outlets, L5-30P input plug, 10’ cord

29.5” PDU, 208V 20A, (18) IEC C13 outlets, L6-20P input plug, 10’ cord

66.5” PDU, 208V 20A, (24) IEC C13 outlets, L6-20P input plug, 10’ cord n

OR-MMCPM23016-01 n

OR-MMCPM23024-01

29.5” PDU, 208V 30A, (16) IEC C13 outlets, L6-30P input plug,10’ cord

66.5” PDU, 208V 30A, (24) IEC C13 outlets, L6-30P input plug, 10’ cord n

OR-MMCPM23024-02

66.5” PDU, 208V 30A, (20) IEC (4) IEC C19 outlets, L6-30P input plug, 10’ cord

177

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Layer Zero - The Infrastructure Layer

Revolutionize Your Network

From The Ground Up

For maximum network efficiency, start at the foundation.

Layer Zero provides a new foundation for the OSI model to address the critical role that infrastructure plays in network performance.

The right solutions at Layer Zero can reduce power consumption and cooling costs, reduce the risk of equipment failure, and improve overall system performance. Contact your Legrand representative to learn more about the impact of Layer Zero on your data center.

For more information on

Layer Zero Solutions, scan the QR code.

Mighty Mo Air Control

Aisle Containment Solutions

Mighty Mo Air Cap Retractable Aisle Cover

The air cap is a flat, retractable roof system that attaches to the top of the racks or cabinets.

The air cap creates a barrier that prevents hot air and cold air from mixing. This retractable cover is spring loaded and designed to retract into a metal case should a fire suppression event occur. Thermal links melt at 135ºF and release the cover into the housing should temperatures go beyond a certain level. This ensures that the sprinkler pattern is not interrupted and also prevents the fire resistant cover from being exposed to the fire. The retractable feature also allows easy access when overhead maintenance is needed.

n

OR-MMACAP60X30

Air cap, 60”W x 30’L, black n■

OR-MMACAP84X30

Note: Contact customer service for lengths under 30 feet.

Air cap, 84”W x 30’L, black

Mighty Mo Air Panel Roof

The air panel roof is an aisle cover system that attaches to the top of the racks or cabinets to create a barrier that prevents hot air and cold air from mixing. The roof frame is constructed of heavy gauge aluminum that supports translucent drop away panels. These panels are molded of heat sensitive ceilume polyvinyl chloride plastic. The panels shrink and drop out of the supporting frames when the temperature reaches 135ºF. This ensures there is no interference with the operation of the overhead automatic sprinklers. The panels can also be removed for easy access when overhead maintenance is needed. The frames are available in clear or black anodized aluminum.

n

OR-MMAPR56X80

Air panel roof, 2”H x 55-1/2”W x 79-1/2”L, clear n■

OR-MMAPR56X80-B

Note: Contact customer service for additional sizes.

Air panel roof, 2”H x 55-1/2”W x 79-1/2”L, black

Mighty Mo Air Cap

Mighty Mo Air Panel Roof

181

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Air Control

Aisle Containment Solutions

Hanging Vinyl Panels

Fire resistant vinyl panels hang from aluminum tracks mounted to the drop ceiling grid above the racks and cabinets. This curtain forms a barrier between the hot aisle and cold aisle.

The aluminum tracks are connected to the ceiling grid by fusible links that release and drop to the floor when temperatures go above 135°F, ensuring that the fire sprinkler pattern is not interrupted. Normal fire suppression systems engage at 158°F.

The hanging vinyl panel system is sold in kits that include all the necessary hangers, track and panels to cover your specific area. The vinyl panels are the length of the aluminum track and overlap at the track seams. Each panel has two inches of additional width on each end to overlap and create one continuous partition.

The tracks are available in clear anodized aluminum.

To determine the size of the Hanging Vinyl Panel System required you will need the

following measurements: n ■

Linear feet – this is the length of aluminum track needed to create a rectangle around the

aisle to be contained. Kits are available from 1’ to 6’ long and can be connected to one

another for larger installations.

n ■

Drop down length (in inches) – this is the length of the vinyl panels from the aluminum

track to the top of the racks and cabinets or floor. Available lengths are from 29” to 182” high.

n

OR-MMACNP29X12

Vinyl panel, 29”H x 12”L n■

OR-MMACNP29x24

Vinyl panel, 29”H x 24”L n■

OR-MMACNP29x36 n■

OR-MMACNP29x48 n■

OR-MMACNP29x60 n■

OR-MMACNP29x72 n

OR-MMACNP56X12

Vinyl panel, 29”H x 36”L

VVinyl panel, 29”H x 48”L

Vinyl panel, 29”H x 60”L

Vinyl panel, 29”H x 72”L

Vinyl panel, 56”H x 12”L

Hanging Vinyl Panel

Hanging Vinyl Panels

(cont)

n

OR-MMACNP56X24 n

OR-MMACNP56X36 n

OR-MMACNP56X48 n

OR-MMACNP56X60 n

OR-MMACNP56X72 n

OR-MMACNP98X12 n

OR-MMACNP98X24 n

OR-MMACNP98X48 n

OR-MMACNP110X12 n

OR-MMACNP110X24 n

OR-MMACNP110X48 n

OR-MMACNP122X12 n

OR-MMACNP122X24 n

OR-MMACNP122X48 n

OR-MMACNP146X12 n

OR-MMACNP146X24 n

OR-MMACNP146X48 n

OR-MMACNP182X12 n

OR-MMACNP182X24 n

OR-MMACNP182X48

Vinyl panel, 56”H x 24”L

Vinyl panel, 56”H x 36”L

Vinyl panel, 56”H x 48”L

Vinyl panel, 56”H x 60”L

Vinyl panel, 56”H x 72”L

Vinyl panel, 98”H x 12”L

Vinyl panel, 98”H x 24”L

Vinyl panel, 98”H x 48”L

Vinyl panel, 110”H x 12”L

Vinyl panel, 110”H x 24”L

Vinyl panel, 110”H x 48”L

Vinyl panel, 122”H x 12”L

Vinyl panel, 122”H x 24”L

Vinyl panel, 122”H x 48”L

Vinyl panel, 146”H x 12”L

Vinyl panel, 146”H x 24”L

Vinyl panel, 146”H x 48”L

Vinyl panel, 182”H x 12”L

Vinyl panel, 182”H x 24”L

Vinyl panel, 182”H x 48”L

183

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Air Control

Aisle Containment Solutions

Hanging Vinyl Strip Doors

The hanging vinyl strip doors are designed as an economical solution for closing the end of an aisle. The track sections are available in 1’ increments up to 6’. The 1’ wide vinyl strips have a 2” overlap on each side for a total width of 16”.

The hanging vinyl strip doors are sold in a variety of sizes to fit virtually every application.

n

OR-MMACNS98X12 n

OR-MMACNS98X24 n

OR-MMACNS98X36 n

OR-MMACNS98X48 n

OR-MMACNS98X60 n

OR-MMACNS98X72 n

OR-MMACNS110X12 n

OR-MMACNS110X24 n

OR-MMACNS110X36 n

OR-MMACNS110X48 n

OR-MMACNS110X60 n

OR-MMACNS110X72

Vinyl strip, 98”H x 12”L

Vinyl strip, 98”H x 24”L

Vinyl strip, 98”H x 36”L

Vinyl strip, 98”H x 48”L

Vinyl strip, 98”H x 60”L

Vinyl strip, 98”H x 72”L

Vinyl strip, 110”H x 12”L

Vinyl strip, 110”H x 24”L

Vinyl strip, 110”H x 36”L

Vinyl strip, 110”H x 48”L

Vinyl strip, 110”H x 60”L

Vinyl strip, 110”H x 72”L

Hanging Vinyl Strip Doors

Hanging Vinyl Strip Doors

(cont)

n

OR-MMACNS122X12 n

OR-MMACNS122X24 n

OR-MMACNS122X36 n

OR-MMACNS122X48 n

OR-MMACNS122X60 n

OR-MMACNS122X72 n

OR-MMACNS146X12 n

OR-MMACNS146X24 n

OR-MMACNS146X36 n

OR-MMACNS146X48 n

OR-MMACNS146X60 n

OR-MMACNS146X72 n

OR-MMACNS182X12 n

OR-MMACNS182X24 n

OR-MMACNS182X36 n

OR-MMACNS182X48 n

OR-MMACNS182X60 n

OR-MMACNS182X72

Vinyl strip, 122”H x 12”L

Vinyl strip, 122”H x 24”L

Vinyl strip, 122”H x 36”L

Vinyl strip, 122”H x 48”L

Vinyl strip, 122”H x 60”L

Vinyl strip, 122”H x 72”L

Vinyl strip, 146”H x 12”L

Vinyl strip, 146”H x 24”L

Vinyl strip, 146”H x 36”L

Vinyl strip, 146”H x 48”L

Vinyl strip, 146”H x 60”L

Vinyl strip, 146”H x 72”L

Vinyl strip, 182”H x 12”L

Vinyl strip, 182”H x 24”L

Vinyl strip, 182”H x 36”L

Vinyl strip, 182”H x 48”L

Vinyl strip, 182”H x 60”L

Vinyl strip, 182”H x 72”L

185

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Air Control

Aisle Containment Solutions

Hanging Vinyl Corner Panels

The hanging vinyl corner panels include a curved track, panels and all the necessary hangers to make a 90° radius corner. The corner is 12” long in each direction.

n

OR-MMACNCP29X12

Vinyl corner panel, 29”H x 12”L n

OR-MMACNCP56X12

Vinyl corner panel, 56”H x 12”L n

OR-MMACNCP98X12 n

OR-MMACNCP110X12

Vinyl corner panel, 98”H x 12”L

Vinyl corner panel, 110”H x 12”L n

OR-MMACNCP122X12 n

OR-MMACNCP146X12

Vinyl corner panel, 122”H x 12”L

Vinyl corner panel, 146”H x 12”L n

OR-MMACNCP182X12

Vinyl corner panel, 182”H x 12”L

Mighty Mo Frame Panel

The frame panel is used to create containment when one row of racks or cabinets is not the same length as another row. It creates a right angle from the aisle end door to the rack or cabinet of the shorter row, effectively closing the row and preventing the mixing of hot and cold air. Each frame support is two feet wide to match the size of the standard floor tiles. The frames are available in clear or black anodized aluminum.

n

OR-MMADRF80X24

Air door, frame panel, 80”H x 24”W, clear n

OR-MMADRF80X24-B

Air door, frame panel, 80”H x 24”W, black

Hanging Vinyl Corner Panels

OR-MMADRS80X89DL

Mighty Mo Sliding Aisle End Door

The sliding aisle end door installs at the end of the row. The door frame is constructed of extruded aluminum and supports clear acrylic sliding doors, bridging an aisle up to 84” wide.

The door is shipped fully assembled to make installation easier. Simply tilt the door into place, bolt it to the floor and attach the turnbuckles on the top of the door to the top of the end rack or cabinet. The no-threshold design allows unfettered access to the contained aisle. The frames are available in clear or black anodized aluminum.

n

OR-MMADRS80X89DL

Air door, sliding, 80”H x 89”W, dual 24”W doors, clear n

OR-MMADRS80X89DL-B

Air door, sliding, 80”H x 89”W, dual 24”W doors, black n

OR-MMADRS80X89LH n

OR-MMADRS80X89LH-B n

OR-MMADRS80X89RH n

OR-MMADRS80X89RH-B

Air door, sliding, 80”H x 89”W, single 36”W door, left, clear

Air door, sliding, 80”H x 89”W, single 36”W door, left, black

Air door, sliding, 80”H x 89”W, single 36”W door, right, clear

Air door, sliding, 80”H x 89”W, single 36”W door, right, black

Mighty Mo Hinged Aisle End Door

The hinged aisle end door is also constructed of extruded aluminum and clear acrylic and has the same ease of installation as our sliding door.

The door can be purchased with a left hand or right hand opening and has a swing radius of 3’.

The frames are available in clear or black anodized aluminum.

n

OR-MMADRH80X56LH

Air door, hinged, 80”H x 56”W, left hand open, clear n

OR-MMADRH80X56LH-B n

OR-MMADRH80X56RH n

OR-MMADRH80X56RH-B

Air door, hinged, 80”H x 56”W, left hand open, black

Air door, hinged, 80”H x 56”W, right hand open, clear

Air door, hinged, 80”H x 56”W, right hand open, black

187

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Air Control

Aisle Containment Solutions

Mighty Mo Air Booth

The air booth is a three sided containment system that is placed directly over a perforated tile, in front of a rack or cabinet. This isolates the cold air provided from the perforated tile, creating a dedicated supply targeted specifically for the intake of active equipment within individual racks or cabinets. By providing exclusive access to cold air, the air booth spot cools high density and high powered equipment. The air booth is an effective containment system for isolated racks and cabinets.

The frames are available in clear or black anodized aluminum.

n

OR-MMABTH802424 n

OR-MMABTH802424-B

Air booth, 3 sided, 80”H x 24”W x 24”D, clear

Air booth, 3 sided, 80”H x 24”W x 24”D, black n

OR-MMABTH804824 n

OR-MMABTH804824-B

Air booth, 3 sided, 80”H x 48”W x 24”D, clear

Air booth, 3 sided, 80”H x 48”W x 24”D, black n

OR-MMABTH807224

Air booth, 3 sided, 80”H x 72”W x 24”D, clear n

OR-MMABTH807224-B

Air booth, 3 sided, 80”H x 72”W x 24”D, black

Mighty Mo Air Plug

Air plugs are used to fill in cable openings in the raised floor or any gaps where airflow needs to be blocked. Air plugs are soft, compressible and safe to use around all types of cable, including fiber optic cable.

They are made from Sandel™, a fireproof material. Sandel originates from sand, contains no asbestos and is non-combustible at any temperature. The air plugs are available in several sizes to cover most any opening and are easily installed by simply squeezing the plug and placing it in the opening to be filled. All plugs have a height of 5”.

n

OR-MMAPL0404 n

OR-MMAPL0606

Air plug, 5” x 4” x 4”, black

Air plug, 5” x 6” x 6”, black

Mighty Mo Air Plugs

Mighty Mo Air Plug

(cont)

n

OR-MMAPL0612 n

OR-MMAPL0618 n

OR-MMAPL0624 n

OR-MMAPL0909 n

OR-MMAPL0914 n

OR-MMAPL0918 n

OR-MMAPL0924 n

OR-MMAPL1212 n

OR-MMAPL1218 n

OR-MMAPL1224 n

OR-MMAPL1414 n■

OR-MMAPL1616 n

OR-MMAPL1620 n

OR-MMAPL1624 n

OR-MMAPL1818 n

OR-MMAPL2024 n

OR-MMAPL2424

Air plug, 5” x 6” x 12”, black

Air plug, 5” x 6” x 18”, black

Air plug, 5” x 6” x 24”, black

Air plug, 5” x 9” x 9”, black

Air plug, 5” x 9” x 14”, black

Air plug, 5” x 9” x 18”, black

Air plug, 5” x 9” x 24”, black

Air plug, 5” x 12” x 12”, black

Air plug, 5” x 12” x 18”, black

Air plug, 5” x 12” x 24”, black

Air plug, 5” x 14” x 14”, black

Air plug, 5” x 16” x 16”, black

Air plug, 5” x 16” x 20”, black

Air plug, 5” x 16” x 24”, black

Air plug, 5” x 18” x 18”, black

Air plug, 5” x 20” x 24”, black

Air plug, 5” x 24” x 24”, black

189

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Air Control

Aisle Containment Solutions

Mighty Mo Air Disrupter

The air disrupter is a curtain designed to modify the air velocity under a raised floor. Low pressure areas above perforated tiles are often a result of air rushing past the tile opening at too great a speed. By strategically placing the Mighty Mo air disrupters under the raised floor, air velocity is greatly reduced and more air is allowed to permeate through the tiles, ensuring a consistent supply of cold air to each rack or cabinet.

The Mighty Mo air disrupters are made from the fireproof material Sandel.

n

OR-MMADIS0624

Air disrupter, 6”H x 24”W n

OR-MMADIS1224

Air disrupter, 12”H x 24”W n

OR-MMADIS1824 n

OR-MMADIS2424

Air disrupter, 18”H x 24”W

Air disrupter, 24”H x 24”W

Toolless Snap-in Filler Panels

Ortronics toolless snap-in filler panels are used to fill open rack units in racks and cabinets where separation of cold air and hot air is required. They are designed to work with active equipment and Ortronics flat, angled or curved patch panels.

The toolless snap-in filler panels unique patent pending design allows them to snap into 19”

EIA/ECA-310-E compliant tapped or square hole mounting rails. Because no field modification is required to fit a tapped hole, the panel can be remounted in a square hole in the future eliminating the need to stock two different types of panels. Black.

n

OR-BFPT-1RU-10

1.75”H x19”W, 1 rack unit, pack of 10 n■

OR-BFPT-2RU-10

3.5”H x19”W, 2 rack units, pack of 10

OR-MMADIS0624

OR-BFPT-1RU-10

OR-BFPT-2RU-10

OR-MMAGCT2448

Mighty Mo CRAC Unit Air Extension

Mighty Mo Air Grille

The air grille is a ceiling vent that is installed above the hot aisle. This vent allows the hot exhaust air to pass into the plenum instead of recirculating throughout the equipment room.

n■

OR-MMAGCT2424

Ceiling vent, 24”L x 24”W, pk of 30, white n

OR-MMAGCT2448

Ceiling vent, 48”L x 24”W, pk of 15, white

Mighty Mo CRAC Unit Air Extension

The CRAC unit air extension mounts to the top of the CRAC unit and extends to the drop ceiling. The air extension then draws higher temperature return air from the ceiling, back to the CRAC unit, increasing cooling capacity and resulting in increased CRAC unit efficiency.

The air extension can also be used in rooms without drop ceilings as well, acting as a snorkel to pull warmer air from above the CRAC unit to increase efficiency.

Mighty Mo air extensions are made of high grade aluminum and are manufactured to meet the individual requirements of your data center.

To determine part number you will need the following measurements:

OR-MMAE-

Part Number

Prefix

X

Height from top of CRAC to drop ceiling

X X

Width of

CRAC unit

X

Depth of

CRAC unit

-G

Color

G = Cool

Gray

X X X X

Numerical

Suffix

The height, width and depth are rounded to the nearest foot. The maximum height for an air extension is 8’. The width and depth are based on the rough dimensions of the CRAC unit.

The 4 digit numerical suffix will be assigned after the quantity and location of access doors and exact dimensions for your unit are determined.

Please contact your Legrand | Ortronics Representative or Technical Support to help configure your Mighty Mo air extension.

Depth

Width

191

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

Tubular Runway

Flexibility is the key to cable management. Ortronics tubular cable runway is designed to adapt to each twist and turn cables must make. Made of lightweight rectangular steel tubing, the runway reduces floor loading and is easy to install and maintain. Steel meets stringent specifications for yield and tensile strength, assuring a strong, lightweight product that easily supports and delivers overhead cable.

Features: Tubular cross slats are welded to the top of stringers; Cross slats feature rounded edges for cable protection; Runway widths available from 6” to 24”; Two standard lengths: 5’11” or 9’ 11”.

Specifications: Stringers made of 3/8” x 1-1/2” high tensile tubular steel; Cross slats are 1” x 1/2” tubular steel; Available in rust-resistant, powder coated dove gray or black finish; UL listed.

n

OR-TR6-6B

Dimensions: 6”W x 5’ 11”L, black n■

OR-TR6-12B n

OR-TR6-18B n■

OR-TR6-24B n

OR-TR10-6B n■

OR-TR10-12B n

OR-TR10-18B n■

OR-TR10-24B

Note: Replace “B” black, with “D” for dove gray.

Dimensions: 12”W x 5’ 11”L, black

Dimensions: 18”W x 5’ 11”L, black

Dimensions: 24”W x 5’ 11”L, black

Dimensions: 6”W x 9’ 11”L, black

Dimensions: 12”W x 9’ 11”L, black

Dimensions: 18”W x 9’ 11”L, black

Dimensions: 24”W x 9’ 11” L, black

OR-TR10-12B

OR-URT10-12B

OR-TRT10-12B

Universal Style Tubular Runway

Features: Tubular cross slats are welded between stringers; Cross slats feature rounded edges for cable protection; Runway widths available from 6” to 24”; Standard length is 9’ 11”.

Specifications: Stringers made of 3/8” x 1-1⁄2” high tensile tubular steel; Cross slats are

1” x 1/2” tubular steel; Available in rust-resistant, powder coated black finish only; UL listed.

n

OR-URT10-6B

Dimensions: 6”W X 9’11”L, black n

OR-URT10-12B

Dimensions: 12”W X 9’11”L, black n

OR-URT10-18B n

OR-URT10-24B

Dimensions: 18”W X 9’11”L, black

Dimensions: 24”W X 9’11”L, black

Telco Style Tubular Runway

Features: Tubular cross slats are welded between stringers; Cross slats feature rounded edges for cable protection; Runway widths available from 6” to 24”; Standard length is 9’ 11”.

Specifications: Stringers made of 3/8” x 1-1⁄2” high tensile tubular steel; Cross slats are

1” x 1/2” tubular steel; Available in rust-resistant, powder coated dove gray or black finish;

UL listed.

n

OR-TRT10-6B

Dimensions: 6”W x 9’ 11”L, load rating: 115 lbs n

OR-TRT10-12B

Dimensions: 12”W x 9’ 11”L, load rating: 115 lbs n

OR-TRT10-18B n

OR-TRT10-24B

Note: Remove “B” to designate dove gray.

Dimensions: 18”W x 9’ 11”L, load rating: 115 lbs

Dimensions: 24”W x 9’ 11”L, load rating: 115 lbs

193

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

Curved Runway

Radius curved runway permits smooth vertical to horizontal transitions. Stringers are

1-1/2” x 3/8” steel tubes; Cross slats are 1” x 1/2” x 1/8” steel tubes; UL listed.

Outside Curved Runway

n

OR-TRTC-6B

11.50”H x 6”W x 11.50”D n

OR-TRTC-12B

11.50”H x 12”W x 11.50”D n

OR-TRTC-18B n

OR-TRTC-24B

Inside Curved Runway

n

OR-TRTCI-6B n

OR-TRTCI-12B n

OR-TRTCI-18B n

OR-TRTCI-24B

Note: Replace “B” black, with “D” for dove gray.

11.50”H x 18”W x 11.50”D

11.50”H x 24”W x 11.50”D

11.50”H x 6”W x 11.50”D

11.50”H x 12”W x 11.50”D

11.50”H x 18”W x 11.50”D

11.50”H x 24”W x 11.50”D

OR-TRTC-12D

OR-TRHR-12B

OR-TRTHR-12B

Horizontal Radius Runway

Horizontal radius runway allows cables to be routed around horizontal corners. The runway features stringers made of 1-1/2” x 3/8” steel tubes; Cross slats are 1” x 1/2” x 1/8” steel tubes;

UL listed.

TR Style

n

OR-TRHR-12B

12”W x 18.03”IR x 29.66”OR* n■

OR-TRHR-18B

TRT Style

n

OR-TRTHR-12B

18”W x 18.03”IR x 35.66”OR*

12”W x 18.03”IR x 29.66”OR* n■

OR-TRTHR-18B

18”W x 18.03”IR x 35.66”OR*

*IR = inside radius; OR = outside radius.

Note: Replace “B” black, with “D” for dove gray.

End Closing Tubes

End closing tubes are used when junctioning runway sections of different widths or closing the stringers of a single piece of runway. They are used together with corner, edge or straight clamps. Made of 3/8” x 1-1/2” tubular steel.

n

OR-P413511H-TB

1.50”H x 5.75”W x 0.38”D, use with 6” n■

OR-P413512H-TB n

OR-P413530H-TB

1.50”H x 11.75”W x 0.38”D, use with 12”

1.50”H x 17.75”W x 0.38”D, use with 18” n■

OR-P413531H-TB

Note: Replace “B” black, with “D” for dove gray.

1.50”H x 23.75”W x 0.38”D, use with 24”

OR-P413512H-TB

195

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

End Closing Kit

The end closing kit includes one end closing tube and two corner clamps for closing the stringers of a single piece of runway.

n

OR-RECBK-6B

For use with 6” runway n■

OR-RECBK-12B

For use with 12” runway n

OR-RECBK-18B

For use with 18” runway n■

OR-RECBK-24B

For use with 24” runway

Note: Remove “B” to designate dove gray.

Runway Wall To Rack Kit

The runway wall to rack kit provides support for cable between the rack and the wall.

Kit consists of: (1) 12” wide 4’ 5-1/2” long tubular runway, (1) 12” wide wall angle assembly,

(1) Runway bracket kit, (1) Set of end caps.

Features: Works with standard equipment racks of all channel depths, Mighty Mo 6 and

Mighty Mo 10 rack systems.

n

OR-WRTRT-12B

Kit of (1) 4’ 5-1/2” long runway, (1) wall angle assembly,

(1) runway bracket kit and (1) set of end caps

Note: Remove “B” to designate dove gray.

Ground Strap

Ground straps provide grounding between spliced runway. Simply pre-drill runway to accept the strap and connect to runway sections using compression lugs.

Consists of: All compression lugs and 1/4-20” hardware included: (1) 8” ground strap,

(2) compression lugs, (2) toothed lock washers, (2) hex nuts; Constructed of flexible tinned copper flat braid.

n

OR-GS-8

Dimensions* 8.75”L x 0.63”H

*Lug hole-to-lug hole length is 8.00”. Runway clearance hole for 1/4-20” is needed to mount ground strap.

OR-RECBK-12B

OR-WRTRT-12B

OR-GS-8

OR-P820127H

OR-P820147H

OR-P820127HA

OR-P820287H

Straight & Corner Clamp Assemblies

Clamps are used to junction runway sections together in a variety of configurations. Whether sections are extended in-line or junctioned perpendicularly or are transitioned from horizontal to vertical; clamps provide a solid connection. This assures the runway layout will provide the necessary support for your cabling.

Straight Clamp

n

OR-P820127H

Straight clamp kit - (2) straight clamps n

OR-P820367H

Corner Clamp

Straight clamp kit - For different stringer widths - (2) clamps with filler n

OR-P820147H

Corner clamp kit - (2) corner clamps

Clear zinc plated.

Adjustable Angle Splice Kit

Adjustable angle splices junction runway sections from separate horizontal planes for smooth vertical transitions.

n

OR-P820127HA

Clear zinc plated.

(2) adjustable angles

Edge Clamp Assemblies

Edge clamps junction runway of the same width where horizontal-to-vertical and horizontal-to-horizontal transitions are needed.

45° Edge Clamp

n

OR-P820287H

90° Edge Clamp

n

OR-P820327H

Clear zinc plated.

45° edge clamp kit - (2) edge clamps

90° edge clamp kit - (2) edge clamps

197

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

Cable Fence

Cable fence is available in 6” or 12” and provides added cable capacity for TR, URT or TRT runway.

One set includes 10 pieces that attach to runway as needed. Legrand | Ortronics recommends placing cable fence on every other cross-member to support large cable piles.

For Use with TR Runway

n

OR-CF-6B

6”H x 2.63”W x 0.19”D n

OR-CF-12B

Note: Replace “B” black, with “D” for dove gray.

For Use with Any 1-1/2” Runway

n

OR-CFTRC-6B

12”H x 2.63”W x 0.19”D

6”H x 0.75”W x 1.15”D n

OR-CFTRC-12B

Note: Remove “B” to designate dove gray.

12”H x 0.75”W x 1.15”D

Cable Runway Feet

Cable runway feet anchor runway to the wall or floor. Feet are attached to runway with clamps.

Made of 3/8” x 1-1/2” steel bar. One foot included.

n

OR-P401750H-1DB

Note: Replace “B” black, with “D” for dove gray.

n

OR-P820827HB

Note: Remove “B” to designate dove gray.

6”H x 2”W x 1.50”D

Kit of (2) 6”H cable runway feet and (2) straight clamps

OR-CF-6D

OR-CFTRC-6D

OR-P401750H-1D

OR-P139240HD

OR-P820527H

OR-TRP5-CM

Shelf Brackets

Shelf brackets attach to the wall and extend up to 24” for heavy duty runway support. Runway is secured to the bracket with J-bolts (included). Made of 3/16” x 1” steel bar. Hardware is zinc plated and dichromated.

n

OR-P139240HB

A 6.44”, B 6.44”, runway width: 6” n■

OR-P139340HB n

OR-P139540HB

A 12.44”, B 12.44”, runway width: 12”

A 18.44”, B 18.44”, runway width: 18” n■

OR-P139740HB

A 24.44”, B 24.44”, runway width: 24”

Note: Replace “B” black, with “D” for dove gray.

Cable Bracket

The Ortronics steel cable bracket offers a separate channel for power cables that must not contact primary cables. Mounting hardware included. Mounts on 1-1/2” and 2” stringers.

n

OR-P820527HB

4.50”H x 5”D

Note: Remove “B” to designate dove gray.

Transition Pans

Assure the proper bend radius for cables delivered from overhead runway to equipment racks with our transition pan. Each pan clamps to runway cross members or runway stringers (TRP8-S). Truss head screws with protective covers assure cables are not damaged.

Provides 1.25” radius.

n

OR-TRP5-CM

2”H x 5”W x 4.13”D n■

OR-TRP8-CM n

OR-TRP11-CM

2”H x 8”W x 4.13”D

2”H x 11”W x 4.13”D n■

OR-TRP17-CM

2”H x 17”W x 4.13”D n

OR-TRP8-S

2”H x 7.50”W x 4.63”D

Black finish. CM= pan mounts on runway cross member; S= pan mounts on runway stringer.

199

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

Wall Angle Assemblies

Wall angle assemblies attach to the wall and provide a shelf or edge on which runway can be anchored using J-bolts. Anchoring can be either parallel or perpendicular to the wall. Includes

2” x 2” x 1/4” steel angle, (2) J-bolts, (2) 1/4-20” hex nuts and (2) 1/4” lock washers. Hardware is zinc plated and dichromated.

n

OR-P128040HB

For runway width: 6” n■

OR-P128240HB n

OR-P128440HB

For runway width: 12”

For runway width: 18” n■

OR-P128640HB

Note: Replace “B” black, with “D” for dove gray.

Runway Ceiling Kit

The runway ceiling kit is used to suspend cable runway from the ceiling.

For runway width: 24” n

OR-RCBK-6

(1) ceiling hanger bracket, (1) closed clip, (1) 5/8-11” x 6’ threaded rod, (4) 5/8-11” hex nuts

Runway Elevation Kit

Used to provide additional space between the tops of racks or cabinets and the runway. Can be mounted to the runway junction plates, Mighty Mo runway support brackets or to the rear flange of a Mighty Mo rack. Can also be mounted to the Mighty Mo cabinets simply by drilling two holes into the cabinet’s removable top plates. Black finish.

n

OR-REK-2-3

2”, 2.5” or 3” n■

OR-REK-4-6

4”, 5” or 6”

OR-P128040HD

OR-RCBK-6

OR-REK-2-3

OR-P400298HD

OR-2-E1-25C-A

OR-RHB-12B

OR-P406395H

Ceiling Hanger Brackets

When ceiling support is required, ceiling hanger brackets are used with 5/8-11” threaded rods and open or closed clips to suspend runway overhead. n

OR-P400298HB

(1) bracket n■

OR-P820667HB

(1) bracket, (2) nuts n

OR-P820677HB

(1) bracket, (2) nuts, (1) plate*

*Plate color matches bracket.

Note: Replace “B” black, with “D” for dove gray.

Protective Rubber End Caps

Protective end caps conceal sharp runway edges that may harm the installation or injure those administering the installation. Sold in pairs.

n

OR-2-E1-25C-A

For 1-1/2” stringers

Black rubber.

Runway Hanger Brackets

Use runway hanger brackets to suspend runway using a 5/8-11” threaded rod. A 12” cable path forms above the runway. The brackets mount without the threaded rod interfering with the cable path. Mounting hardware included.

n

OR-RHB-06B

12”H x 6.38”W x 2”D, runway width: 6” n■

OR-RHB-12B

12”H x 12.38”W x 2”D, runway width: 12”

Note: Replace “B” black, with “D” for dove gray.

Open Clips

Use open clips with 1-1/2” stringers to secure runway to threaded rods when suspending runway from the ceiling or when stacking runway. Use with 5/8-11” threaded rod. Made of

3/16” x 1-1/2” steel bar. UL classified. n

OR-P406395H

(1) clip n■

OR-P820547H

Clear zinc plated.

Two sides - (2) clips, (4) nuts

201

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Tubular Runway & Accessories

Closed Clips

Use closed clips with 1-1/2” stringers to secure runway to threaded rods when suspending runway from the ceiling or when stacking runway. Use with 5/8-11” threaded rod.

Made of 1/4” x 1-1/4” steel bar. UL classified.

n

OR-P429503H

(1) clip n■

OR-P820477H

Two sides - (2) clips, (4) nuts

Clear zinc plated.

Vertical Wall Bracket

Made of 1/8” x 2” steel, vertical wall brackets fasten runway to the wall and provide a secure route for cables to channel vertically. Use 7/16” mounting hardware (not included).

One bracket included.

n

OR-P982078HB

1.50”H x 2”W x 2.53”D

Note: Replace “B” black, with “D” for dove gray.

Threaded Rods (5/8-11”)

Threaded rods are available in a variety of lengths to support runway sections suspended from the ceiling. Includes (2) 5/8-11” hex nuts and (2) 5/8” flat washers.

n

OR-P987650H

Length of rod 5’ n■

OR-P987649H

Length of rod 6’ n

OR-P987645H

Length of rod 10’

Zinc plated and dichromated.

Threaded Rod Coupler

Join (2) 5/8” threaded rods together with spliced coupling. Has yellow zinc dichromate finish;

Constructed of steel.

n

OR-2-E1-75

Kit contains: (1) 5/8” coupler, (2) 5/8” x 11” hex nuts

OR-P429503H

OR-P982078HD

OR-P987650H

OR-2-E1-75

OR-2-E2-TRPC

Protective Sleeve

Slitted protective sleeves cover threaded rods to protect cables from damage. Field cut to desired size.

n

OR-2-E2-TRPC

10’ PVC protective sleeve for 5/8-11” threaded rod

J-Bolt Assemblies

Each J-bolt assembly includes (1) 1/4-20” or 5/16-18” hex nut and (1) 1/4” or 5/16” lock washer.

UL classified.

n

OR-P987529H

A 1.75”, B 0.250”, C 0.50”, D 0.75”, thread size: 1/4-20” n■

OR-P987528H

A 3.25”, B 0.438”, C 0.75”, D 1.50”, thread size: 1/4-20” n

OR-P987527H n■

OR-P987526H n

OR-P987525H n■

OR-P987524H n

OR-P987523H

Clear zinc plated.

A 2.25”, B 0.438”, C 0.75”, D 1.00”, thread size: 1/4-20”

A 3.75”, B 0.313”, C 0.75”, D 1.25”, thread size: 5/16-18”

A 3.25”, B 0.313”, C 0.75”, D 0.75”, thread size: 5/16-18”

A 3.25”, B 0.438”, C 0.75”, D 1.50”, thread size: 5/16-18”

A 2.25”, B 0.438”, C 0.75”, D 1” thread size: 5/16-18”

OR-P987527H

D

A

C

B

203

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Bonding & Grounding

Ground Bars & Kits

Telecommunications Main Ground Bars and Kits

Manufactured of 1/4” thick, electrolytic tough pitch, 110 alloy copper bar. Includes 1-1/2” insulators and 1” offset stainless steel mounting brackets. Includes (1) 1/2 oz. tube of antioxidant joint compound. Meets BICSI and EIA/TIA 607 standards.

Kits include: (1) Copper ground bar with brackets and insulators, (6) #6 compression lugs,

(3) #2 compression lugs, (1) 2/0 compression lug, (1) 4/0 compression lug, (12) 1/4”-20 x 3/4”

SS hex head cap screws, (12) 1/4”-20 SS lock washers, (12) 1/4”-20 SS hex nuts, (6) 3/8”-16 x 1”

SS hex head cap screws, (6) 3/8”-16 SS lock washers, (6) 3/8”-16 SS hex nuts.

Telecommunications Main Ground Bars

n

OR-GB4X12TMGB

Bar size: 12”W x 4”H, 12 5/16” hole sets, 6 7/16” hole sets n■

OR-GB4X20TMGB

Bar size: 20”W x 4”H, 24 5/16” hole sets, 6 7/16” hole sets

Telecommunications Main Ground Bar Kits

n

OR-GB4X12TMGBKIT

Bar size: 12”W x 4”H, 12 5/16” hole sets, 6 7/16” hole sets n■

OR-GB4X20TMGBKIT

Bar size: 20”W x 4”H, 24 5/16” hole sets, 6 7/16” hole sets

OR-GB4X12TMGB

OR-GB4X20TMGB

OR-GB4X12TMGBKIT

OR-GB4X20TMGBKIT

OR-GB2X10TGB

OR-GB2X12TGB

OR-GB4X12J

Telecommunications Ground Bars and Kits

Manufactured of 1/4” thick, electrolytic tough pitch, 110 alloy copper bar. Includes 1-1/2” insulators and 1” offset stainless steel mounting brackets. Includes (1) 1/2 oz. tube of antioxidant joint compound. Meets BICSI and EIA/TIA 607 standards.

Kits include: (1) Copper ground bar with brackets and insulators, (6) #6 compression lugs;

(3) #2 compression lugs, (1) 2/0 compression lug, (1) 4/0 compression lug, (12) 1/4”-20 x 3/4” SS hex head cap screws, (12) 1/4”-20 SS lock washers, (12) 1/4”-20 SS hex nuts, (6) 3/8”-16 x 1” SS hex head cap screws, (6) 3/8”-16 SS lock washers, (6) 3/8”-16 SS hex nuts.

Telecommunications Ground Bars

n

OR-GB2X10TGB

Bar size: 10”W x 2”H, 4 5/16” hole sets, 3 7/16” hole sets n

OR-GB2X12TGB

Telecommunications Ground Bar Kits

n

OR-GB2X12TGBKIT

Bar size: 12”W x 2”H, 6 5/16” hole sets, 3 7/16” hole sets

Bar size: 12”W x 2”H, 6 5/16” hole sets, 3 7/16” hole sets

Standard Ground Bars

n

OR-GB4X12J n

OR-GB4X20J

Bar size: 12”W x 4”H, 27 holes

Bar size: 20”W x 4”H, 51 holes

Wall Mounting Bracket Kit

n

OR-GBWMBKIT

Set of (2) brackets with insulators and hardware to mount to a ground bar

OR-GBWMBKIT

205

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Bonding & Grounding

Ground Bars & Kits

Equipment Rack Ground Bars and Kits

Manufactured of 1/4” thick, electrolytic tough pitch, 110 copper alloy bar. Accommodates (1) hole lugs or (2) hole lugs (5/8” on center). 36” bar has (2) PEM studs at one end and the 72” bar has (2) PEM studs at both ends for ground conductor connection.

Kits include: (1) 1/4” thick, electrolytic tough pitch, 110 copper alloy bar, (8) 1/4” x 1/2” stainless steel hex head cap screws, (3) white delrin insulators; (4) 5/16” stainless steel lock washers,

(8) 1/4” stainless steel lock washers, (3) #12-24 x 5/8” hex washer head screws, (4) 5/16” stainless steel hex nuts, (1) two hole long barrel compression lug.

Vertical Ground Bars

n

OR-GBV36

5/8” x 36” vertical ground bar n■

OR-GBV72 n

OR-GBV36KIT n■

OR-GBV72KIT

5/8” x 72” vertical ground bar

5/8” x 36” vertical ground bar kit

5/8” x 72” vertical ground bar kit

Horizontal Ground Bar Kit

Kits include: (1) 1/4” thick, electrolytic tough pitch, 110 copper alloy bar, (1) 3” bar splice plate with 2 slotted holes, (2) white delrin insulators, (2) 12-24 x 5/8” hex washer head screws;

(2) #12-24 x 3/4” copper flashed brass screws, (2) #12 copper flat washers, (8) #6-32 x 1/4” copper flashed brass screws, (8) #6 ring terminals, (1) #6 long barrel compression lugs, 3/4” o.c. for 1/4” hardware, (2) 1/4”-20 x 3/4” stainless steel cap screws, (2) 1/4” stainless steel lock washers, (2) 1/4”-20 stainless steel nuts.

n

OR-GBH19KIT

1” X 19.25” horizontal ground bar kit

OR-GBV36

OR-GBV36KIT

OR-GBH19KIT

OR-GBV72

OR-GBV72KIT

OR-CL2LB6A

OR-CL2LB6C

OR-CL2LB2C

OR-CL2LB20C

OR-CL2LB6B

OR-CL2LB2A

OR-CL2LB10C

OR-CL2LB30C

OR-CL2LB40C

OR-CTHD4666 OR-CTHD4446 OR-CTHD2248

OR-CTHD2222 OR-CTHD220

Compression Lugs and Taps

Two Hole Long Barrel Compression Lugs

Manufactured from electroplated tinned copper. Long barrels maximize number of crimps and are color coded. Inspection port assures full conductor insertion. Sold in packages of 10.

Part Number

OR-CL2LB6A

OR-CL2LB6B

OR-CL2LB6C

OR-CL2LB2A

OR-CL2LB2C

OR-CL2LB10C

OR-CL2LB20C

OR-CL2LB30C

OR-CL2LB40C

2

1/0

2/0

3/0

4/0

6

6

2

Cable Size

6

1”

1”

1”

1”

1”

OC Dimension

Between Holes

.625”

.75”

1”

.625”

3/8”

3/8”

3/8”

3/8”

3/8”

Screw Size

1/4”

3/8”

3/8”

1/4”

Color Code

Blue

Blue

Blue

Brown

Brown

Pink

Black

Orange

Purple

C-Type Compression Taps

Connects two copper conductors together with a hydraulic crimp tool. Sold in packages of 10.

Part Number

OR-CTHD4666

OR-CTHD4446

OR-CTHD2248

OR-CTHD2222

OR-CTHD220

Conductor Run

#4 Stranded

#6 Solid

#4 Stranded

#6 Solid

#2 Stranded

#2 Solid

#2 Stranded

#2 Solid

2/0 Stranded

1/0 Solid

Conductor Tap

#6 Stranded

#6 Solid

#4 Stranded

#4 Solid

#4 Stranded

#8 Solid

#2 Stranded

#2 Solid

#2 Stranded

#8 Solid

207

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Bonding & Grounding

Ground Bars & Kits

Mechanical Compression Tools

n

OR-MCT840

Dieless adjustable compression tool with steel handle. Works with copper conductor sizes #8 through 250MCM and aluminum conductors

#8 through 4/0. For use with compression lugs and compression taps.

n■

OR-MCT810

Terminates copper compression connectors in wire sizes #8 through 1/0.

Dies included.

Insulated Ground Jumper Kit

n

OR-GJ8KIT

Copper Offset Terminal Lugs

n

OR-COTL1014 n■

OR-COTL614

Ground jumper assembly kit, 6-7G, 8” length

Wire range: max 10 str, min 14 str, bolt hole size: #8, ampere rating: 25

Wire range: max 6 str, min 14 str, bolt hole size: #8, ampere rating: 50 n

OR-COTL28

Wire range: max 2 str, min 8 str, bolt hole size: 1/4”, ampere rating: 70

Grounding Kit for Racks

This kit provides a reliable systems ground for the distribution rack. One grounding kit is recommended for each rack.

n

OR-60400010

Single conductor ground lug for 6 AWG to 14 AWG conductors

Two Hole Ground Lug

Allows grounding of racks and cabinets utilizing the standard EIA/TIA hole pattern.

Manufactured of electro-tin plated aluminum and allows attachment of copper or aluminum conductor sizes from 14AWG to 2/0. Meets BICSI and EIA/TIA 607 recommendations for 2 hole mounting. Includes (2) 3/8” x 1” hex socket head set screws.

n

OR-GL2014

Bolt hole size: 1/4” O.C. Spacing 5/8”

OR-MCT840

OR-MCT810

OR-GJ8KIT

OR-COTL1014 OR-COTL614 OR-COTL28

OR-60400010 OR-GL2014

OR-PCU575

OR-PCU152

OR-PCU354

OR-AJCA

OR-AJCC

OR-PCU1125

OR-PCU253

OR-PCU56

OR-AJCA8

OR-AJCC8

Pipe Clamps

Manufactured from electroplated tinned bronze. Conductor range: #6 through 250 MCM PEM stud ensures a flush mounting surface. Sold in packages of 5.

n

OR-PCU575

Nominal pipe size range: 0.5” - .75”, pipe outside diameter: 0.375” – 1” n

OR-PCU1125

Nominal pipe size range: 1” – 1.25”, pipe outside diameter: 0.75” – 1.7” n

OR-PCU152 n

OR-PCU253

Nominal pipe size range: 1.5” – 2”, pipe outside diameter: 1” – 2.4”

Nominal pipe size range: 2.5” – 3”, pipe outside diameter: 2.25” – 3.5” n

OR-PCU354

Nominal pipe size range: 3.5” – 4”, pipe outside diameter: 3.2” – 4.5” n

OR-PCU56

Nominal pipe size range: 5” – 6”, pipe outside diameter: 5.63” – 6.63”

Antioxidant Joint Compound

Oxide inhibiting joint compounds are used to improve electrical conductivity and enhance the integrity of the connection.

Aluminum Antioxidant

Synthetic base with suspended zinc particles. Material is gray in color. Recommended for aluminum to aluminum, aluminum to copper and aluminum conduit threads.

n

OR-AJCA

1/2 oz., package of 12 n

OR-AJCA8

8 oz.

Copper Antioxidant

Synthetic base compound with suspended copper particles. Material is copper in color.

Recommended for copper to copper connections, copper threads and all ground applications.

n

OR-AJCC

1/2 oz., package of 12 n

OR-AJCC8

8 oz.

209

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-934-5432

Mighty Mo Fiber Raceway

Optical Fiber Ducting Raceway

Mighty Mo fiber raceway is specifically designed for routing and protecting fiber optic cords between termination equipment, fiber patching or splicing enclosures, racks and cabinets in data centers, telecommunications rooms or anywhere fiber optic cabling is present.

Mighty Mo fiber raceway is available in 5 sizes with a complete selection of fittings and drop outs for every size. It is easily mounted above racks and cabinets or mounted to runway or

Cablofil tray.

Mighty Mo fiber raceway components simply snap together or can be joined with “slotless” joiners. Vertical drops can be positioned or added easily by adding a cutout in the horizontal raceway with a simple to operate hand tool. The unique design of the Mighty Mo system protects the fiber from damage and ensures that the bend radius of the cable is not compromised.

All components in the Mighty Mo fiber raceway system are manufactured from Noryl, a strong plastic, which is self extinguishing and halogen free. In the case of a fire, the gases emitted will not cause harm to personnel, buildings or transmission equipment, unlike some other brands of raceway.

Material

n ■

Noryl fire retardent plastic, halogen free, UL94-VO rated

Agency Approvals

n ■

SO 9001 certified quality management system by NCS International n ■

UL2024A standard

Compliant with

n ■

RoHS

Colors

n ■

Yellow, orange and black

Note: black and orange colors available by special order.

OR-MMFJ4X4-Y

OR-MMFSDC4X4-Y

OR-MMFSDHC4X4-Y

Mighty Mo Straight Duct

Solid Duct

Solid duct is available with and without covers in 5 sizes. The unique design of the hinged cover allows it to remain in an open position while fiber is installed in the raceway. All sizes are 6’ 3-3/8” long and are slotted at each end for snapping to each other or to fittings with a slotted joiner.

n

OR-MMFSD2X2-Y

2” x 2”, yellow n

OR-MMFSD4X2-Y

4” x 2”, yellow n■

OR-MMFSD4X4-Y n

OR-MMFSD8X4-Y n

OR-MMFSD12X4-Y n

OR-MMFSDC2X2-Y n

OR-MMFSDC4X2-Y n

OR-MMFSDC4X4-Y n

OR-MMFSDC8X4-Y n

OR-MMFSDC12X4-Y n

OR-MMFSDHC2X2-Y n■

OR-MMFSDHC4X2-Y n

OR-MMFSDHC4X4-Y n

OR-MMFSDHC8X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4”, yellow

8” x 4”, yellow

12” x 4”, yellow

2” x 2”, with cover, yellow

4” x 2”, with cover, yellow

4” x 4”, with cover, yellow

8” x 4”, with cover, yellow

12” x 4”, with cover, yellow

2” x 2”, with hinged cover, yellow

4” x 2”, with hinged cover, yellow

4” x 4”, with hinged cover, yellow

8” x 4”, with hinged cover, yellow

211

NEW

Mighty Mo Fiber Raceway

Straight Duct

Slotted Duct

Slotted duct (side exit) is available with and without covers in 3 sizes. The unique design of the hinged cover allows it to remain in an open position while fiber is installed in the duct. All sizes are 6’ 3-3/8” long and are slotted at each end for snapping together or to fittings with a slotted joiner. Side exit slots run down both sides and are spaced approximately every 6” apart. Radius guides can be snapped into the side exit slots to provide protection for fiber optic cables exiting the duct. n

OR-MMFSL2X2-Y

2” x 2”, yellow n■

OR-MMFSL4X2-Y

4” x 2”, yellow n

OR-MMFSL4X4-Y n■

OR-MMFSLC2X2-Y n

OR-MMFSLC4X2-Y n■

OR-MMFSLC4X4-Y n

OR-MMFSLHC2X2-Y n■

OR-MMFSLHC4X2-Y n

OR-MMFSLHC4X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4”, yellow

2” x 2”, with cover, yellow

4” x 2”, with cover, yellow

4” x 4”, with cover, yellow

2” x 2”, with hinged cover, yellow

4” x 2”, with hinged cover, yellow

4” x 4”, with hinged cover, yellow

OR-MMFSL4X4-Y

OR-MMFSLC4X4-Y

OR-MMFSLHC4X4-Y

OR-MMFJ4X4-Y

Fiber Raceway Fittings

Joiners

Joiners are used to connect the straight duct and components together. Simply snap the joiner into the slots at the end of each part to be joined. For straight duct that has been cut to length new slots will need to be made with the proper slotting tool. “Slotless” joiners are available in sizes from 4” x 4” upwards that will join the fittings to the duct with or without joining slots.

n

OR-MMFJ2X2-Y n

OR-MMFJ4X2-Y n

OR-MMFJ4X4-Y n

OR-MMFJ8X4-Y n

OR-MMFJ12X4-Y n

OR-MMFJSL4X4-Y n

OR-MMFJSL8X4-Y n

OR-MMFJSL12X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Required assembly slots for 2” x 2” duct, yellow

Required assembly slots for 4” x 2” duct, yellow

Required assembly slots for 4” x 4” duct, yellow

Required assembly slots for 8” x 4” duct, yellow

Required assembly slots for 12” x 4” duct, yellow

Slotless for 4” x 4” duct, yellow

Slotless for 8” x 4” duct, yellow

Slotless for 12” x 4” duct, yellow

OR-MMFJSL4X4-Y

213

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

Vertical Elbows

Vertical elbows are used to connect horizontal routes at different heights or to allow the fiber path to be raised or lowered to avoid obstacles. They are available with or without covers. The retrofit versions come with split covers that are used where there is existing fiber.

n

OR-MMFVE30D2X2-Y

30° down, 2” x 2”, yellow n■

OR-MMFVE30D4X4-Y n

OR-MMFVE30D8X4-Y n■

OR-MMFVEC30D2X2-Y n

OR-MMFVEC30D4X4-Y n■

OR-MMFVEC30D8X4-Y n

OR-MMFVER30D4X4-Y n■

OR-MMFVER30D8X4-Y n

OR-MMFVE30U4X4-Y n■

OR-MMFVE30U8X4-Y n

OR-MMFVEC30U4X4-Y n■

OR-MMFVEC30U8X4-Y n

OR-MMFVER30U4X4-Y n■

OR-MMFVER30U8X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange. Images are representative.

30° down, 4” x 4”, yellow

30° down, 8” x 4”, yellow

30° down, 2” x 2”, with cover, yellow

30° down, 4” x 4”, with cover, yellow

30° down, 8” x 4”, with cover, yellow

30° down, 4” x 4”, retrofit, yellow

30° down, 8” x 4”, retrofit, yellow

30° up, 4” x 4”, yellow

30° up, 8” x 4”, yellow

30° up, 4” x 4”, with cover, yellow

30° up, 8” x 4”, with cover, yellow

30° up, 4” x 4”, retrofit, yellow

30° up, 8” x 4”, retrofit, yellow

OR-MMFVE30D4X4-Y

OR-MMFVEC30U4X4-Y

OR-MMFVEC30D8X4-Y

OR-MMFVEC45D8X4-Y

Vertical Elbows

(cont)

n

OR-MMFVE45D2X2-Y n

OR-MMFVE45D4X4-Y n

OR-MMFVE45D8X4-Y

45° down, 2” x 2”, yellow

45° down, 4” x 4”, yellow

45° down, 8” x 4”, yellow n

OR-MMFVE45D12X4-Y n

OR-MMFVEC45D2X2-Y n

OR-MMFVEC45D4X4-Y n

OR-MMFVEC45D8X4-Y n

OR-MMFVEC45D12X4-Y n

OR-MMFVER45D4X4-Y n

OR-MMFVER45D8X4-Y n

OR-MMFVE45U2X2-Y n

OR-MMFVE45U4X4-Y n

OR-MMFVE45U8X4-Y

45° down, 12” x 4”, yellow

45° down, 2” x 2”, with cover, yellow

45° down, 4” x 4”, with cover, yellow

45° down, 8” x 4”, with cover, yellow

45° down, 12” x 4”, with cover, yellow

45° down, 4” x 4”, retrofit, yellow

45° down, 8” x 4”, retrofit, yellow

45° up, 2” x 2”, yellow

45° up, 4” x 4”, yellow

45° up, 8” x 4”, yellow n

OR-MMFVE45U12X4-Y n

OR-MMFVEC45U2X2-Y n

OR-MMFVEC45U4X4-Y n

OR-MMFVEC45U8X4-Y

45° up, 12” x 4”, yellow

45° up, 2” x 2”, with cover, yellow

45° up, 4” x 4”, with cover, yellow

45° up, 8” x 4”, with cover, yellow n

OR-MMFVEC45U12X4-Y

45° up, 12” x 4”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange. Images are representative.

215

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

Vertical Elbows

(cont)

n

OR-MMFVER45U2X2-Y n

OR-MMFVER45U4X4-Y n■

OR-MMFVER45U8X4-Y n

OR-MMFVE90D2X2-Y n■

OR-MMFVE90D4X2-Y n

OR-MMFVE90D4X4-Y n■

OR-MMFVE90D8X4-Y n

OR-MMFVE90D12X4-Y n■

OR-MMFVEC90D2X2-Y n

OR-MMFVEC90D4X2-Y n■

OR-MMFVEC90D4X4-Y n

OR-MMFVEC90D8X4-Y n■

OR-MMFVEC90D12X4-Y n

OR-MMFVER90D2X2-Y n■

OR-MMFVER90D4X2-Y n

OR-MMFVER90D4X4-Y n■

OR-MMFVER90D8X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

45° up, 2” x 2”, retrofit, yellow

45° up, 4” x 4”, retrofit, yellow

45° up, 8” x 4”, retrofit, yellow

90° down, 2” x 2”, yellow

90° down, 4” x 2”, yellow

90° down, 4” x 4”, yellow

90° down, 8” x 4”, yellow

90° down, 12” x 4”, yellow

90° down, 2” x 2”, with cover, yellow

90° down, 4” x 2”, with cover, yellow

90° down, 4” x 4”, with cover, yellow

90° down, 8” x 4”, with cover, yellow

90° down, 12” x 4”, with cover, yellow

90° down, 2” x 2”, retrofit, yellow

90° down, 4” x 2”, retrofit, yellow

90° down, 4” x 4”, retrofit, yellow

90° down, 8” x 4”, retrofit, yellow

OR-MMFVEC90D4X4-Y

OR-MMFVEC90U4X4-Y

OR-MMFVER90U4X4-Y

Vertical Elbows

(cont)

n

OR-MMFVE90U2X2-Y n

OR-MMFVE90U4X2-Y n

OR-MMFVE90U4X4-Y n

OR-MMFVE90U8X4-Y n

OR-MMFVE90U12X4-Y n

OR-MMFVEC90U2X2-Y n

OR-MMFVEC90U4X2-Y n

OR-MMFVEC90U4X4-Y n

OR-MMFVEC90U8X4-Y n

OR-MMFVEC90U12X4-Y n

OR-MMFVER90U2X2-Y n

OR-MMFVER90U4X2-Y n

OR-MMFVER90U4X4-Y n

OR-MMFVER90U8X4-Y n

OR-MMFVEE90UD4X4-Y n

OR-MMFVEE90UD8X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

90° up, 2” x 2”, yellow

90° up, 4” x 2”, yellow

90° up, 4” x 4”, yellow

90° up, 8” x 4”, yellow

90° up, 12” x 4”, yellow

90° up, 2” x 2”, with cover, yellow

90° up, 4” x 2”, with cover, yellow

90° up, 4” x 4”, with cover, yellow

90° up, 8” x 4”, with cover, yellow

90° up, 12” x 4”, with cover, yellow

90° up, 2” x 2”, retrofit, yellow

90° up, 4” x 2”, retrofit, yellow

90° up, 4” x 4”, retrofit, yellow

90° up, 8” x 4”, retrofit, yellow

90° up/down, 4” x 4”, enclosed, yellow

90° up/down, 8” x 4”, enclosed, yellow

217

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

Horizontal Elbows

Horizontal elbows are used to change the direction of horizontal routes. They are available with and without covers.

n

OR-MMFHE302X2-Y

30°, 2” x 2”, yellow n■

OR-MMFHE304X4-Y n

OR-MMFHE308X4-Y n■

OR-MMFHEC302X2-Y n

OR-MMFHEC304X4-Y n■

OR-MMFHEC308X4-Y n

OR-MMFHE452X2-Y n■

OR-MMFHE454X4-Y

30°, 4” x 4”, yellow

30°, 8” x 4”, yellow

30°, 2” x 2”, with cover, yellow

30°, 4” x 4”, with cover, yellow

30°, 8” x 4”, with cover, yellow

45°, 2” x 2”, yellow

45°, 4” x 4”, yellow n

OR-MMFHE458X4-Y n■

OR-MMFHE4512X4-Y n

OR-MMFHEC452X2-Y n■

OR-MMFHEC454X4-Y n

OR-MMFHEC458X4-Y n■

OR-MMFHEC4512X4-Y n

OR-MMFHE902X2-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

45°, 8” x 4”, yellow

45°, 12” x 4”, yellow

45°, 2” x 2”, with cover, yellow

45°, 4” x 4”, with cover, yellow

45°, 8” x 4”, with cover, yellow

45°, 12” x 4”, with cover, yellow

90°, 2”x 2”, yellow

OR-MMFHEC454X4-Y

OR-MMFHEC904X4-Y

OR-MMFHT4X4-Y

Horizontal Elbows

(cont)

n

OR-MMFHE904X2-Y n

OR-MMFHE904X4-Y n

OR-MMFHE908X4-Y

90°, 4” x 2”, yellow

90°, 4” x 4”, yellow

90°, 8” x 4”, yellow n

OR-MMFHE9012X4-Y n

OR-MMFHEC902X2-Y n

OR-MMFHEC904X2-Y n

OR-MMFHEC904X4-Y

90°, 12” x 4”, yellow

90°, 2” x 2”, with cover, yellow

90°, 4” x 2”, with cover, yellow

90°, 4” x 4”, with cover, yellow n

OR-MMFHEC908X4-Y

90°, 8” x 4”, with cover, yellow n

OR-MMFHEC9012X4-Y

90°, 12” x 4”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Horizontal Tees

Horizontal tees are used to branch off the main route or provide a method of breaking into horizontal duct. Standard tees branch off at the same size as the through duct. Transition tees branch off to a smaller duct. They are available with and without covers.

n

OR-MMFHT2X2-Y

2” x 2”, yellow n

OR-MMFHT4X2-Y

4” x 2”, yellow n

OR-MMFHT4X4-Y n

OR-MMFHT8X4-Y

4” x 4”, yellow

8” x 4”, yellow n

OR-MMFHT12X4-Y

12” x 4”, yellow n

OR-MMFHTC2X2-Y

2” x 2”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

219

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

Horizontal Tees

(cont)

n

OR-MMFHTC4X2-Y n■

OR-MMFHTC4X4-Y n

OR-MMFHTC8X4-Y n■

OR-MMFHTC12X4-Y n

OR-MMFHTC12T8-Y n■

OR-MMFHTC12T4-Y n

OR-MMFHTC8T4-Y

4” x 2”, with cover, yellow

4” x 4”, with cover, yellow

8” x 4”, with cover, yellow

12” x 4”, with cover, yellow

Transition, 12” to 8”, with cover, yellow

Transition, 12” to 4”, with cover, yellow

Transition, 8” to 4”, with cover, yellow n■

OR-MMFHTC4T8-Y

Transition, 4” to 8”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Vertical Tees

Vertical tees are used to drop cables vertically from horizontal routes into frames or cabinets.

They are available with and without covers. Vertical tees in 8” x 4” and 12” x 4” can be used to transition to smaller duct and retrofit tees can be installed where cables are already in place.

n

OR-MMFVT2X2T2-Y

2” x 2” to 2” x 2”, yellow n■

OR-MMFVT4X2T4-Y n

OR-MMFVT4X4T4-Y n■

OR-MMFVT8X4T4-Y n

OR-MMFVT12X4T8-Y n■

OR-MMFVTC2X2T2-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 2” to 4” x 2”, yellow

4” x 4” to 4” x 4”, yellow

8” x 4” to 4” x 4”, yellow

12” x 4” to 8” x 4”, yellow

2” x 2” to 2” x 2”, with cover, yellow

OR-MMFHTC8T4-Y

OR-MMFVT8X4T4-Y

OR-MMFVTR4X4T4-Y

OR-MMFHCC4X4-Y

Vertical Tees

(cont)

n

OR-MMFVTC4X2T4-Y n

OR-MMFVTC4X4T4-Y n

OR-MMFVTC8X4T4-Y

4” x 2” to 4” x 2”, with cover, yellow

4” x 4” to 4” x 4”, with cover, yellow

8” x 4” to 4” x 4”, with cover, yellow n

OR-MMFVTC8X4T8-Y n

OR-MMFVTC12X4T8-Y n

OR-MMFVTR2X2T2-Y n

OR-MMFVTR4X4T4-Y

8” x 4” to 8” x 4”, with cover, yellow

12” x 4” to 8” x 4”, with cover, yellow

2” x 2” to 2” x 2”, retrofit, yellow

4” x 4” to 4” x 4”, retrofit, yellow n

OR-MMFVTR8X4T4-Y

8” x 4” to 4” x 4”, retrofit, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Horizontal Cross

Horizontal crosses can be used to provide a cross intersection in straight duct. Transition crosses join duct of different sizes. They are available with and without covers. n

OR-MMFHC2X2-Y

2” x 2”, yellow n

OR-MMFHC4X2-Y

4” x 2”, yellow n

OR-MMFHC4X4-Y n

OR-MMFHC8X4-Y

4” x 4”, yellow

8” x 4”, yellow n

OR-MMFHC12X4-Y n

OR-MMFHCC2X2-Y

12” x 4”, yellow

2” x 2”, with cover, yellow n

OR-MMFHCC4X2-Y

4” x 2”, with cover, yellow n

OR-MMFHCC4X4-Y

4” x 4”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

221

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

Horizontal Cross

(cont)

n

OR-MMFHCC8X4-Y n■

OR-MMFHCC12X4-Y n

OR-MMFHC8X4T4-Y n■

OR-MMFHC8X4T12-Y n

OR-MMFHC12X4T4-Y n■

OR-MMFHCC8X4T4-Y n

OR-MMFHCC8X4T12-Y

8” x 4”, with cover, yellow

12” x 4”, with cover, yellow

Transition, 8” x 4” to 4” x 4”, yellow

Transition, 8” x 4” to 12” x 4”, yellow

Transition, 12” x 4” to 4” x 4”, yellow

Transition, 8” x 4” to 4” x 4”, with cover, yellow

Transition, 8” x 4” to 12” x 4”, with cover, yellow n■

OR-MMFHCC12X4T4-Y

Transition, 12” x 4” to 4” x 4”, with cover, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Fiber Storage Loops

Fiber storage loops are used to safely store excess fiber length and can be placed in any horizontal route. They are available in inline or offset versions.

n

OR-MMFFSLIN2X2-Y

2” x 2”, inline, yellow n■

OR-MMFFSLIN4X2-Y

4” x 2”, inline, yellow n

OR-MMFFSLIN4X4-Y n■

OR-MMFFSLIN8X4-Y n

OR-MMFFSLIN12X4-Y n■

OR-MMFFSLOF2X2-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4”, inline, yellow

8” x 4”, inline, yellow

12” x 4”, inline, yellow

2” x 2”, offset, yellow

OR-MMFFSLIN4X4-Y

OR-MMFFSLOF4X4-Y

OR-MMFECS4X4-Y

Fiber Storage Loops

(cont)

n

OR-MMFFSLOF4X2-Y n

OR-MMFFSLOF4X4-Y n

OR-MMFFSLOF8X4-Y

4” x 2”, offset, yellow

4” x 4”, offset, yellow

8” x 4”, offset, yellow n

OR-MMFFSLOF12X4-Y

12” x 4”, offset, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

End Caps

End caps are used to close off the end of a horizontal or vertical route of duct. Some are solid, others have knockouts, cutouts or outlets for attaching flexible tubing.

n

OR-MMFECS4X2-Y

4” x 2”, blank, yellow n

OR-MMFECS4X4-Y

4” x 4”, blank, yellow n

OR-MMFECS8X4-Y n

OR-MMFECSL4X4-Y n

OR-MMFECSL8X4-Y n

OR-MMFECSL12X4-Y n

OR-MMFEC2X220KO-Y n

OR-MMFEC2X238KO-Y

8” x 4”, blank, yellow

4” x 4”, blank, slotless duct, yellow

8” x 4”, blank, slotless duct, yellow

12” x 4”, blank, slotless duct, yellow

2” x 2”, (2) 20mm diameter knockouts, yellow

2”x 2”, 38mm diameter knockout, yellow n

OR-MMFEC2X238CO-Y n

OR-MMFEC2X244TO-Y

2” x 2”, 32mm diameter cutout, yellow

2” x 2”, 44mm tube outlet, yellow n

OR-MMFEC4X432KO-Y

4” x 4”, (2) 32mm diameter knockouts, yellow n

OR-MMFEC4X446KO-Y

4” x 4”, (2) 46mm diameter knockouts, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

223

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Mighty Mo Fiber Raceway Fittings

End Caps

(cont)

n

OR-MMFEC4X4ESB-Y n■

OR-MMFEC4X488TO-Y

4” x 4”, end support bracket, yellow

4” x 4”, 88mm tube outlet, yellow n

OR-MMFEC8X488TO-Y n

OR-MMF4X2R2X2-Y

4” x 4”, (2) 88mm tube outlets, yellow

Reducers

Reducers allow different size ducts to be joined together. They are available with or without covers.

4” x 2” to 2” x 2”, yellow n■

OR-MMF4X4R2X2-Y n

OR-MMFC4X2R2X2-Y n■

OR-MMFC4X4R2X2-Y n

OR-MMF4X4R4X2-Y n■

OR-MMF12X4R8X4-Y n

OR-MMFC4X4R4X2-Y n■

OR-MMFC12X4R8X4-Y n

OR-MMFR8X4R4X4-Y n■

OR-MMFRC8X4R4X4-Y n

OR-MMFL8X4R4X4-Y n■

OR-MMFLC8X4R4X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4” to 2” x 2”, yellow

4” x 2” to 2” x 2”, with cover, yellow

4” x 4” to 2” x 2”, with cover, yellow

4” x 4” to 4” x 2”, yellow

12” x 4” to 8” x 4”, yellow

4” x 4” to 4” x 2”, with cover, yellow

12” x 4” to 8” x 4”, with cover, yellow

8” x 4” to 4” x 4”, right hand, yellow

8” x 4” to 4” x 4”, with cover, right hand, yellow

8” x 4” to 4” x 4”, left hand, yellow

8” x 4” to 4” x 4”, with cover, left hand, yellow

OR-MMFEC4X4ESB-Y

OR-MMFC4X4R2X2-Y

OR-MMFLC8X4R4X4-Y

OR-MMFOT4-Y

OR-MMFSDK4X4-Y

Drop Components

Radius guides provide protection for fiber optic cables exiting slotted duct. Outlet trumpets provide bend limitation for fiber optic cables exiting the side or end of the duct.

n

OR-MMFRG10

Radius guide, package of 10, yellow n

OR-MMFOT2-Y n

OR-MMFOT4-Y n

OR-MMFOT8-Y

Outlet trumpet, 2”, yellow

Outlet trumpet, 4”, yellow

Outlet trumpet, 8”, yellow n

OR-MMFOT12-Y

Outlet trumpet, 12”, yellow

Note: Replace “Y” yellow, with “B” for black or “O” orange.

Side Drop-Off Kits

Side drop-off kits provide different methods of allowing fiber optic cables to enter or leave the duct. Both kits for the flexible tubing include a ramp up, drop-off and spreader.

The 2” x 2” kit includes a ramp up, outlet trumpet, joiner and down elbow. The 4” x 4” kit includes an outlet trumpet, joiner and down elbow. The 4” x 2” kit includes a ramp up, outlet trumpet and joiner. A down angle or 4” x 2” duct can be attached to the 4” x 2” kit to create a low profile cross ducting solution.

n

OR-MMFSDK50DCT-Y

50mm diameter flexible tube, yellow n

OR-MMFSDK50SCT-Y n

OR-MMFSDK2X2-Y

50mm square flexible tube, yellow

2” x 2” duct, yellow n

OR-MMFSDK4X4-Y n

OR-MMFSDK4X2-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4” duct, yellow

4” x 2” duct, yellow

225

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

High Capacity Side Drop-Offs & Kits

High Capacity Side Drop-Offs & Kits

High capacity side drop-offs and kits provide different methods of allowing fiber optic cables to enter or leave the duct. Individual drop offs include the combined outlet/90° elbow and cover.

In addition to the outlet the 4” x 4” kit also includes one single 88mm tube end cap and one

2m long flexible tube. The 8” x 4” kit includes the outlet, one dual 88mm tube outlet and two

2m long flexible tubes.

n

OR-MMFHCDO4X4-Y

90°, 4”x 4”, yellow n■

OR-MMFHCDOK4X4-Y

90°, 4”x 4”, kit, yellow n

OR-MMFHCDO8X4-Y

90°, 8”x 4”, yellow n■

OR-MMFHCDOK8X4-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

90°, 8”x 4”, kit, yellow

Flexible Tubing

Tubing is used for feeding entering or exiting fibers from the duct into equipment racks and cabinets. They are ribbed to allow flexibility if drops cannot be positioned exactly over or under equipment. Some are available with removable covers or split for ease of cable installation.

n

OR-MMFCT50D1M-Y

50mm diameter, 1 meter, yellow n■

OR-MMFCT50D1M-B n

OR-MMFCT50D2M-Y n■

OR-MMFCT50D2M-B n

OR-MMFCT50S350-Y n■

OR-MMFCT50S350-B

50mm diameter, 1 meter, black

50mm diameter, 2 meter, yellow

50mm diameter, 2 meter, black

50mm square, 350mm long, yellow

50mm square, 350mm long, black

OR-MMFHCBO8X4-Y

OR-MMFCT50D1M-Y

OR-MMFCT50S350-Y

OR-MMFAKL8X4ADC6-Y

Flexible Tubing

(cont)

n

OR-MMFCTOC50S350-Y n

OR-MMFCTF751M-Y

50mm square, 350mm long, open, with cover, yellow

75mm inside diameter, 88mm outside diameter, 1 meter, yellow n■

OR-MMFCTF752M-Y

75mm inside diameter, 88mm outside diameter, 2 meter, yellow

Adapter Kits

Adapter kits are used to connect parts from other brands to the Fiber Raceway duct.

n

OR-MMFAK4X4ADC4-Y n

OR-MMFAKL8X4ADC6-Y n

OR-MMFAKR8X4ADC6-Y n

OR-MMFAK12X4ADC6-Y

4” x 4” to ADC 4”, yellow

8” x 4” to ADC 6”, left hand, yellow

8” x 4” to ADC 6”, right hand, yellow

12” x 4” to ADC 12”, yellow n

OR-MMFAKR4X4ADC6-Y n

OR-MMFAKL4X4ADC6-Y n

OR-MMFAKR8X4PAN6-Y n

OR-MMFAKL8X4PAN6-Y

Note: Replace “Y” yellow, with “B” for black or “O” orange.

4” x 4” to ADC 6”, right hand, yellow

4” x 4” to ADC 6”, left hand, yellow

8” x 4” to Panduit 6”, right hand, yellow

8” x 4” to Panduit 6”, left hand, yellow

227

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Fiber Raceway Mounting Hardware

Wall Mounting Kits

Wall mounting and bracket extension kits are used to mount raceway to the side of existing metal work or walls.

n

OR-MMFMMK4

For 4” duct, right angle bracket, duct management bracket, base bracket and hardware n

OR-MMFMMK8

For 8” duct, right angle bracket, duct management bracket, base bracket and hardware n

OR-MMFMMKEX4

For 4” duct, right angle bracket, straight bracket and hardware* n

OR-MMFMMKEX8

For 8” duct, right angle bracket and hardware*

*Duct mounting brackets purchased separately

Suspension Kits

Suspension kits are used to suspend raceway from existing metal work.

n

OR-MMFSUSK1212 n

OR-MMFSUSK5812

12” duct mounting bracket, (2) straight brackets,

(2) 15” long 12mm threaded rods and hardware

12” duct mounting bracket, (2) straight brackets,

(2) 15” long 5/8” threaded rods and hardware n

OR-MMFSUSKNR12 n

OR-MMFSUSK128 n

OR-MMFSUSK168 n

OR-MMFSUSK124 n

OR-MMFSUSK164

12” duct mounting bracket, (2) straight brackets and hardware (no threaded rod)

8” duct mounting bracket, straight bracket,

(2) 15” long 12mm threaded rods and hardware

8” duct mounting bracket, straight bracket,

(2) 15” long 16mm threaded rods and hardware

4” duct mounting bracket, straight bracket,

(2) 15” long 12mm threaded rods and hardware

4” duct mounting bracket, straight bracket,

(2) 15” long 16mm threaded rods and hardware

OR-MMFMMK4

OR-MMFSUSK1212

OR-MMFRMK4

OR-MMFRFPMK

Raised Mounting Kits

Raised mounting kits are used for supporting the raceway above cabinets or metal work.

n

OR-MMFRMK2

For 2” duct, mounting plate, 15” long threaded rod and hardware n

OR-MMFRMK4 n

OR-MMFRMK8

For 4” duct, duct management bracket, 15” long threaded rod, protective sleeve and hardware

For 8” duct, duct management bracket, 15” long threaded rod, protective sleeve and hardware n

OR-MMFRMK12

For 12” duct, duct management bracket, 15” long threaded rod, protective sleeve and hardware

Underfloor Mounting Kits

Underfloor mounting kits are used to support the raceway from raised floor pedestals or from the concrete floor.

n

OR-MMFRFPMK

For raised floor pedestal, bracket, U-bolt and hardware* n

OR-MMFCFMBKT

*Duct mounting brackets purchased separately

For concrete floor, bracket only, requires raised mounting kit

Runway and Mounting Kits

Runway mounting kits are used to support the raceway from runway with 1-1/2” high side rails.

n

OR-MMFRUNBK4812

For 4”, 8” & 12” duct mounting brackets n

OR-MMFRUNBK2 n

OR-MMFU158MB4812

For 2” duct mounting brackets

For 4”, 8” & 12” raised mounting brackets

OR-MMFRUNBK4812

229

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

NEW

Mighty Mo Fiber Raceway

Fiber Raceway Mounting Hardware & Tooling

Duct Mounting Brackets

Duct mounting brackets are used with mounting angle brackets and other kits that can accept multiple sizes of duct. They contain one bracket and attaching hardware.

n

OR-MMFDMB2

For 2” duct n

OR-MMFDMB4 n

OR-MMFDMB8 n

OR-MMFDMB12

For 4” duct

For 8” duct

For 12” duct

Raceway Tooling

Tool kits and individual tools are available for cutting, slotting and providing cut-outs for drop components.

Slotting Tool – Foot Operated

The foot operated duct slotting tool allows installers to improve efficiency with it’s no fuss operation and ergonomic design. Take advantage of this new method to safely and easily slot ducting, which will improve the efficiency of your installations and save you and your customer time and money.

n ■

Ducting can be easily aligned and positioned on slotting jig n ■

Fast and easy to use slotting mechanism which slots in seconds n ■

Compact unit only weighs 18 lbs – easy to transport n ■

Steady and robust platform n ■

Ergonomically designed, no stress or heavy manual operation required n ■

Repeatedly produces accurate slots n

OR-MMFSTFO

Foot operated, 4” x 2” and larger duct

Various sizes shown

OR-MMFSTFO

OR-MMFST48

OR-MMFCOT6

Slotting Tools

Slotting tools are used to produce slots in the end of a cut length of duct required when using slotted joiners.

n

OR-MMFST2

For 2” duct n

OR-MMFST48 n

OR-MMFSTS4X2

For 4” & 8” duct

For 4” x 2” duct, side

Raceway Cut Out Tools

Cut out tools are used to cut notches in the side of the duct to accommodate drop-outs. They are supplied with a fiber spreader to protect previously installed fibers when using the tools.

n

OR-MMFCOT35

For 3.5” cutouts n

OR-MMFCOT6

For 6” cutouts

Mitre Box

The mitre box provides a means of producing an accurate and straight cut on ducting. This is essential for correct alignment of the slotting tools and joiners.

n

OR-MMFMBOX4812

For 4”, 8” & 12” duct

OR-MMFMBOX4812

231

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Cablofil

®

Solutions

The First Name in Wire Mesh Cable Tray

Cablofil wire mesh cable tray and accessories are available in a variety of finishes to meet any industry need from decorative to extreme environments.

Over 35 years ago, Cablofil invented the concept of wire mesh cable tray and introduced it to the European market.

The company’s continued success is the result of on-going innovation and the ability of wire cable tray to adapt to any application. Since then Legrand | Cablofil has become a leader in cable management around the world with more than

94,000 miles of tray installed globally. Today the company is continuing to develop new labor-saving products and installation techniques that are changing the way cables are supported in every aspect of the global electrical market.

UL Classified Painted Wire Cable Tray

Cablofil’s UL Classified painted wire tray meets NEC392 from the National Electric Code that states, “all cable tray systems must be properly BONDED, per 250.96”. It is also UL Classified as an EGC (Equipment Grounding Conductor). Installation is easy: remove the mask and splice tray sections together using the SWK splice. The bottom splice needs to be placed upon the folded copper strip of adjoining trays.

Legrand | Cablofil is the right choice for cable management in all types of construction. Look to the leader for specially engineered products that reduce installation time and create cost-effective installations. For specific installation ideas and downloadable drawings, go to our online Best Practices web site at: www.legrand.us/cablofil.

CF 30

Cable Tray

Cablofil Wire Mesh Cable Tray

Unique Safe-T-Edge design keeps cables and the installer safe from sharp edges.

All trays are available in 10’ lengths.

Cablofil Cable Tray

n

CF 30

1” deep, widths from 2” to 12” n

CF 54

2” deep, widths from 2” to 24” n

CF 105 n

CF 150

4” deep, widths from 4” to 24”

6” deep, widths from 6” to 24”

CF 54

CF 105

CF 150

Certifications

Cablofil products have been independently evaluated by UL, CSA, ABS, DNV, ETL and VDE to meet applicable standards and requirements. Our products hold UL Classification to NEC requirements, cCSAus certification to NEMA & CSA requirements, ABS Product Design

Assessment certification and E90 certification. Our products also meet the standards requirements of IEC, EIA-TIA and BICSI. For more information on Cablofil certifications, please visit www.legrand.us/cablofil.

Memberships:

NEMA, CTI, EIA-TIA, NFPA, IEC, BICSI

REGISTERED TO

ISO 9001:2000

®

RoHS

COMPLIANT

233

Cablofil Solutions

Underfloor Cable Management System (UFS)

Truly Designed for Raised Access Floors

The UFS system from Cablofil consists of uniquely designed supports and trays that snap together without the need for complex tools or fasteners. This reduces installation time and allows the system to be installed through the floor tile openings. UFS tray utilizes the same wire grid as our 10’ tray so that all Cablofil tray and accessories attach without adjustment.

UFS Wire Tray Sections

n ■

Tray sections are available in 2’ lengths; 2”, 4” and 6” depths; and 12”, 16” and 20” widths

UFS Support Kit

n ■

Support kits include one crossbar, two leg supports and two leg attachment clips. All crossbars

fit within standard floor leg positions and leg heights are available from 3.5” to 21.2” high.

* Note: Other sizes are available upon request

UFT 90 Kit

n ■

Flat tray and tray clips are used to construct corners, tees and junctions.

UFS Wire Tray Sections

UFCRSBAR

UFS Support Kit

UFCSTCLP

EDF

UFT 90 Kit

Supports and trays snap together without the need for complex tools or fasteners.

Tray sections are available in 2’ lengths;

2”, 4” and 6” depths; and 12”, 16” and

20” widths.

Heavy-duty crossbars are designed with built-in FAS style tabs to secure tray sections.

235

For additional product availability visit www.legrand.us/cablofil or contact sales at 800-658-4641

Cablofil Solutions

Splice & Connector Hardware

Legrand | Cablofil has a splice for every need. Our EDRN is the fastest splice we offer, saving up to half the installation time compared to bolted connections. Other splices are available that give your installation additional strength or have improved electrical continuity. The choice is yours.

EDRN –

Fast Splice

n ■

EDRN is our fastest splice – saves up to half the install time compared to using bolted connections n ■

Special assembly tool (EDRNTOOL) is included in every bag of 50 splices n ■

UL classified splice

RADT90KIT –

Radius Tee 90˚ Kit

n ■

RADT90KIT creates secure tray junctions n ■

Facilitates easy cable pulling into the cable pathway n ■

Available for 2”, 4” and 6” depth tray n ■

*RADT9012KIT now available with a wider radius that makes pulling large power cables into

Cablofil much easier

* Note: Denotes separate product offering with different part numbers for available sizes and finishes.

FASLOCK –

90º Splice

n ■

FASLOCK splice creates sweeps and bends without the need for bolted hardware n ■

Available in S and XL sizes n ■

Use FASLOCK S for CF54/100, 150, 200, CF 105/100, 150, 200, 300 n ■

Use FASLOCK XL for all other larger sizes

SWK –

Splice Washer Kit

n ■

SWK is designed with a 1/4” x 20” threaded bolt compatible with standard US tools n ■

Use SWK to splice any two sections of Cablofil tray n ■

Swaged nut allows clamp to be stationary while nut is tightened n ■

Also use for fabricating bends, turns and tees n ■

UL classified splice

EDRN – Fast Splice

RADT90KIT – Radius Tee 90˚ Kit

OR-COTL1014

OR-60400010

FASP – FAS Profile

FASPCH – FAS Center Hanger

FASl – FASL Bracket

FASC – FASC Bracket

Fast Assembly System (FAS)

The FAS system utilizes simple one-step locking tabs that require no additional hardware to secure tray runs to its supports, reducing installation time and saving money.

FASP –

FAS Profile

n ■

FASP supports Cablofil tray in trapeze hung and/or wall mounted applications n ■

Available in 6” through 120” lengths n ■

For trapeze hung installations, use a FAS Profile that is 4” longer than the tray width

FASPCH –

FAS Center Hanger

n ■

FASPCH supports Cablofil tray in center hung ceiling installations n ■

Supports tray widths from 8” to 24” n ■

Only one threaded rod is needed to suspend the tray

FASL –

FASL Bracket

n ■

FASL supports Cablofil tray in wall-mounted applications n ■

FASL supports Cablofil tray in under floor applications (in combination with UFC

clamp or EDF rail) n ■

Supports tray widths from 4” to 18” n ■

Patented FAS style attachment holds cable tray secure without nuts and bolts

FASC –

FASC Bracket

n ■

FASC supports Cablofil tray in wall-mounted or ceiling-mounted applications n ■

Use one or more FASC brackets to create multiple tray level installations n ■

Patented FAS style attachment holds cable tray secure without nuts and bolts n ■

Supports tray widths from 4” to 18”

237

For additional product availability visit www.legrand.us/cablofil or contact sales at 800-658-4641

Cablofil Solutions

Fast Assembly System (FAS)

FASU –

FAS Universal Bracket

n ■

FASU supports Cablofil tray in wall-mounted applications n ■

Supports tray widths from 4” to 24” n ■

Patented FAS style attachment holds cable tray secure without nuts and bolts

UFC550KIT –

Under Floor Support Kit

n ■

UFC550KIT supports Cablofil tray in raised floor applications n ■

The kit includes (2) UFC clamps, (1) FASP 550 and (2) EZBN1/4 bolt/nuts

FASROLLER –

FAS Roller

n ■

FASROLLER installs directly onto Cablofil tray, facilitating the pulling of cables around

bends, beams and under floor n ■

Unique, four roller design prevents cable snagging n ■

Easy open gate allows full access to FASROLLER n ■

Sold in sets of 6 – includes carrying case

Other Mountings

CABLEXIT

n ■

Protects cables when exiting and entering tray n ■

Snap in mounting tabs eliminate the need for attachment hardware and speeds install time

FASU – FAS Universal Bracket

UFC550KIT – Under Floor Support Kit

FASROLLER – FAS Roller

CABLEXIT

Cablofil wire cable tray and accessories are available in a variety of finishes to meet any industry need, from decorative to extreme environments. Use this chart to help you determine the best finish for your application and its availability.

ous

Finishes

SYMBOL MATERIAL FINISH & STANDARD

Int erior

Ins tallations

Ext erior

Ins tallations ol al Plants envir onments onments

Cl ean r ooms ogen onments

Hal envir

PG

EZ

GC

DC

304L

Carbon

Steel

ASTM A653

Carbon

Steel

ASTM A510

Grade 1008

Carbon

Steel

ASTM A510

Grade 1008

Carbon

Steel

ASTM A510

Grade 1008

Stainless

Steel

AISI Type

304L

Pre-Galvanized:

Continuous Galvanization

Before Fabrication

ASTM A 653

Electrozinc:

After Fabrication

ASTM A 123

Hot Dipped Galvanized:

After Fabrication

ASTM A 123

Geomet:

Zinc and Aluminum

Protection

Equivalent to Hot Dip

Galvanization

ASTM F 1136

Stainless Steel 304L:

Cleaned and Passivated

ASTM 380 n n n n n n n n n n n n n n n n

316L

Carbon

Steel

ASTM A510

Grade 1008

Stainless Steel 316L:

Cleaned and Passivated

ASTM A 380 n n n n n n

BL

Carbon

Steel

ASTM A510

Grade 1008

Black Painted:

Black Powder Coated

ASTM D 3451 n

PE

Carbon

Steel

ASTM A510

Grade 1008

Custom Painted:

Custom Color

Powder Coated

ASTM D 3451 n

For a more detailed explanation of finish standards and compatibility, visit www.legrand.us/cablofil. n

Recommended n

Possible

239

For additional product availability visit www.legrand.us/cablofil or contact sales at 800-658-4641

Cablofil Solutions

FAS Power

If you are constructing a hospital, condominium complex, office building or hotel and the wiring project is substantial or repetitive, look to FAS Power products from Cablofil. With FAS Power, much of the electrical assembly is completed in advance, dramatically cutting project completion times and saving a minimum of 50% in labor costs.

Installation is fast and easy. FAS Power floor brackets slide under the sill plate so no vertical measuring is necessary. Wall brackets that attach to the stud are also available. Everything is pre-wired for fast rough in – Pass & Seymour Plug Tail is connected to Southwire MCAP™ branch circuit wiring with push connector hardware. Devices can then be connected to a home run enclosure mounted to the underside of a Cablofil cable pathway.

All FAS Power products are pre-packaged and shipped to the requirements of the contractor for fast job starts.

Find out how FAS

Power can save you

50% on your next project. Visit www.faspower.com or contact sales at

800-658-4641.

Floor Bracket Wired Assembly

Floor Bracket Wired Assembly

Floor Bracket Wired Assembly

Each FAS Power assembly includes:

n ■

Floor or wall bracket with one to four gang openings n ■

Pre-installed boxes n ■

Pre-installed rings available in 1/2” to 2” raise or adjustable style n ■

Far side support arms n ■

Plug Tail devices pre-wired to MCAP™ cable

Floor Bracket Wired Assembly

Each FAS Power assembly includes:

n ■

FAS Power assemblies are packaged per contractor requirements n ■

Simple installation – no vertical measuring necessary for mounting boxes n ■

Pre-mounted and grounded boxes reduces installation time n ■

Pre-installed rings can be specified to fit any wall thickness n ■

FAS Power assemblies are pre-wired to pre-cut MCAP™ cable lengths n ■

Plug Tail allows you to make device choices at finish n ■

UL listed

Wall Bracket Wired Assembly

n ■

Available with one to four gang openings n ■

Pre-installed outlets, switches and PlugTail devices are shielded in plastic to protect

from tape and paint n ■

Boxes can be used for in-line or multi-wire branch circuits n ■

All brackets are also sold separately as components

Wall Bracket Wired Assembly

241

Cablofil Solutions

Two Rail Cable Tray Systems

Our ladder tray products are offered in a wide variety of sizes, designs and finishes to meet exacting seismic, industry and load standards. Choose from our extensive selection of rail, rung and bottom styles that are available in a variety of finishes. Our experienced representatives will work with you to ensure that your tray needs are fulfilled on time and to your exacting specifications. With manufacturing and distribution facilities strategically located in Atlanta and Los Angeles, we are ready to deliver the exact product you need, exactly when you need it.

Metallic Cable Tray Design Options – Vented

Metallic Cable Tray Design Options – Non-Vented

Metallic Cable Tray Design Options – Vented

Includes tray options that meet NEMA definition of vented tray – 75% or less of the cable bearing surface.

Ladder Standard Rung

n ■

Individual 1” rungs spaced on 6”, 9”, 12” or 18” centers, offering maximum ventilation n ■

Slotted rungs available

Venilated Trough – Corrugated

n ■

Corrugated construction with additional vents for increased airflow n ■

7/8” wide cable support ribs are 1/2” deep on 2” centers

Metallic Cable Tray Design Options – Non-Vented

Solid Bottom – Corrugated

n ■

Solid corrugated bottom provides added stiffness n ■

Tray bottoms are 1/2” deep with 7/8” wide support ribs on 2” centers

Solid Bottom – Flat Sheet

n ■

Solid flat bottom without ventilation openings n ■

Optional rungs can be included over the bottom to provide additional rigidity n ■

Contact Legrand | Cablofil for availability in light and medium-weight tray

Fiberglass Cable Tray Design Options

Ladder Standard Rung

n ■

Individual rungs spaced on 6”, 9” or 12” centers. Contact Legrand | Cablofil for availability

in light and medium-weight tray

Solid Bottom – Flat Sheet

n ■

Flat sheet bottom with individual rungs spaced on 6” or 12” centers

Fiberglass Cable Tray Design Options

243

NEW

Cablofil Solutions

Fiber Trough Tray & Fittings

Fiber Trough, from Legrand | Cablofil, is a cable management system designed to maximize network reliability and minimize lifecyle costs. Fiber Trough utilizes high strength steel components to provide strength and durability to manage fiber cabling in the most demanding data center environments. It provides protection and security for fiber optic and copper cabling, and is manufactured to exacting standards so that all components fit together perfectly and install with ease.

FT –

Straight Section Tray

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel n ■

For toolless, snap-on cover, ask for part number FTC

FTFB90 –

Horizontal 90° Elbow

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel n ■

For toolless, snap-on cover, ask for part number FTCFB90

FTFB45 –

Horizontal 45° Elbow Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

18 gauge steel n ■

For toolless, snap-on cover, ask for part number FTCFB45

FT – Straight Section Tray

FTFB90 – Horizontal 90° Elbow Base

FTFB45 – Horizontal 45° Elbow Base

FTVI90 – Vertical 90° Inside Elbow Base

FTV090 – Vertical 90° Outside Elbow Base

FTT – Horizontal Tee Base

FTB – Horizontal Branch Base

FTVI90 –

Vertical 90° Inside Elbow Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel n ■

For toolless, snap-on cover, ask for part number FTCV190

FTV090 –

Vertical 90° Outside Elbow Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel n ■

For toolless, snap-on cover, ask for part number FTCV090

FTT –

Horizontal Tee Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

18 gauge steel n ■

For toolless, snap-on cover, ask for part number FTTC

FTB –

Horizontal Branch Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

18 gauge steel n ■

For toolless, snap-on cover, ask for part number FTBC

245

For additional product availability visit www.legrand.us/cablofil or contact sales at 800-658-4641

NEW

Cablofil Solutions

Fiber Trough Tray & Fittings

FTX –

Horizontal Cross Base

n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel n ■

For toolless, snap-on cover, ask for part number FTXC

FTVT –

Upright Dropout Tee

(covers included) n ■

Strong, corrosion resistant steel construction n ■

Rolled edge for cable protection n ■

Unique design allows covers to snap on n ■

8 gauge steel

FTX – Horizontal Cross Base

FTVT – Upright Dropout Tee

Finishes

Fiber Trough is stocked in durable, pre-galvanized and textured, flat black powder coat finishes that resist corrosion over the lifetime of the installation. Optional finishes of orange or yellow powder coat, often specified for quick identification of multi-mode or single mode fiber cables, are available.

SYMBOL MATERIAL FINISH & STANDARD

PG

BL

YL

OR

EZ

340L

316L

Carbon

Steel

Carbon

Steel

ASTM A510

Grade 1008

Carbon

Steel

ASTM A510

Grade 1008

Carbon

Steel

ASTM A510

Grade 1008

Stainless

Steel

ASTM A510

Grade 1008

Stainless

Steel

AISI Type

304L

Stainless

Steel

AISI Type

316L

Pre-Galvanized:

Continuous galvanization before fabrication

ASTM A 653

Black Painted:

Black powder coated

ASTM D 3451

Yellow Painted:

Yellow powder coated

ASTM D 3451

Orange Painted:

Orange powder coated

ASTM D 3451

Electrozinc:

Electrozinc plating

ASTM B 633

Stainless Steel 304L:

Cleaned and passivated

ASTM A 380

Stainless Steel 316L:

Cleaned and passivated

ASTM A 380

247

For additional product availability visit www.legrand.us/cablofil or contact sales at 800-658-4641

Legrand Resource Center

www.legrand.us/resources-and-downloads

The Legrand resource center allows you to quickly and easily access online product design and selection tools, along with our whole video library – all in one place. Be sure to visit often, as new resources are added all of the time.

Resources available include:

n

Catalogs and brochures n

Design and selection tools n

Videos n

ETL certificates n

White papers n

DWGs

Our new resource guide App for the iPad and iPhone includes the 2011/2012

Legrand | Ortronics product catalog and other product information programmed in an easy to use touch screen format that gives you all the information you need in the office, for training or on the jobsite. Moving forward, more literature will be made available digitally through this app.

Download from the App

Store now!

249

Technical Information

Drawings, Measures & Reference

Mighty Mo Cabinet Series – Dimension Tables

Cabinet Heights

24U 42U

Overall cabinet height, levelers at minimum height

48.75” (1238) 80.25” (2038)

Overall cabinet height with casters included 50” (1270)

Vertical frame opening, front 42.13” (1070)

81.50” (2292)

73.63” (1870)

Cabinet Widths

Overall width

Frame opening, front

Panel width

24"

23.94” (608)

20” (508)

19" EIA

32"

31.94” (811)

28” (711)

19" EIA

47U

89” (2261)

90.25” (2292)

82.38” (2092)

Cabinet Depths

Overall depth

Overall depth, corner post to corner post

34"

36” (608)

34” (864)

40"

42” (1067)

40” (1016)

46"

48” (1219)

46” (1168)

Minimum/maximum rail depth 5” (127) / 31.50” (800) 5” (127) / 37.50” (953) 5” (127) / 43.50” (1105)

When adjusted to maximum depth on 24”W cabinets, mounting rails wrap around the frame corner posts.

( ) indicates mm.

NETWORK / SERVER

CONFIGURATION RAIL SPACING

SERVER

SETUP

NETWORK

SETUP

TOP VIEW FRONT VIEW SIDE VIEW

251

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Technical Information

Drawings, Measures & Reference

Mighty Mo GX Cabinet Series – Dimension Tables

Cabinet Heights

24U 42U

Overall cabinet height, levelers at minimum height

47.25” (1200) 78.75” (2000)

Overall cabinet height with casters included 48.95” (1243)

Vertical frame opening, front 42.13” (1070)

80.45” (2043)

73.63” (1870)

Cabinet Widths

Overall width

Frame opening, front

Panel width

24"

23.94" (608)

20.44" (519)

19" EIA

29.5"

29.44" (748)

25.94" (659)

19" EIA

45U

84.00” (2134)

85.70” (2177)

78.88” (2004)

31.5"

31.44" (799)

27.94" (710)

19" EIA

48U

89.25” (2267)

90.95” (2310)

84.13” (2137)

Cabinet Depths

Overall depth

Overall depth, corner post to corner post

36"

36” (914)

34” (864)

42"

42” (1067)

40” (1016)

48"

48” (1219)

46” (1168)

Minimum/maximum rail depth 7” (178) / 31.5” (800) 7” (178) / 37.5” (953) 7” (178) / 43.5” (1105)

When adjusted to maximum depth on 24”W cabinets, mounting rails wrap around the frame corner posts.

( ) indicates mm.

30"

3.5"

SERVER SETUP

NETWORK / SERVER

CONFIGURATION RAIL SPACING

30"

3.0 "

SERVER SETUP

SERVER

SETUP

16.25 "

9"

NETWORK SETUP

16.25"

9"

NETWORK SETUP

NETWORK

SETUP

TOP VIEW FRONT VIEW SIDE VIEW

253

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Technical Information

Drawings, Measures & Reference

Cable Fill Capacities for Ortronics Mighty Mo Cable Management Products

Part Number Description

Usable

Area

(sq. in.)

MM10VMD716

MM10VMD712

MM10VMD816

MM10VMD812

MM6VMD710

MM6VMD706

MM6VMD810

MM6VMD806

MM6VMS704

MM6VMS706

MM6VMS804

MM6VMS806

MM10 vertical cable management w/door, 16” X 13” X 7’

MM10 vertical cable management w/door, 12” X 13” X 7’

MM10 vertical cable management w/door, 16” X 13” X 8’

MM10 vertical cable management w/door, 12” X 13” X 8’

MM6 vertical cable management w/door, 10” X 13” X 7’

MM6 vertical cable management w/door, 6” X 8” X 7’

MM6 vertical cable management w/door, 10” X 13” X 8’

MM6 vertical cable management w/door, 6” X 8” X 8’

MM6 vertical cable management w/split covers, 4” X 7” X 7’

MM6 vertical cable management w/split covers, 6” X 7” X 7’

MM6 vertical cable management w/split covers, 4” X 7” X 8’

MM6 vertical cable management w/split covers, 6” X 7” X 8’

MM6VML704

MM6VML706

MM6VML804

MM6VML806

MM6HMF1RU

MM6HMF2RU

MM6HMF4RU

MM6HM61RU

MM6 vertical cable management cage with latches, 4” X 6” X 7’

MM6 vertical cable management cage with latches, 6” X 6” X 7’

MM6 vertical cable management cage with latches, 4” X 6” X 8’

MM6 vertical cable management cage with latches, 6” X 6” X 8’

MM6 horizontal cable management panel, multiple fingers, 1RU

MM6 horizontal cable management panel, multiple fingers, 2RU

MM6 horizontal cable management panel, multiple fingers, 4RU

MM6 horizontal cable management panel, six-port spacing, 1RU

MM6HM62RU

MM6HM81RU

MM6HM82RU

MM6 horizontal cable management panel, six-port spacing, 2RU

MM6 horizontal cable management panel, eight-port spacing, 1RU 5

MM6 horizontal cable management panel, eight-port spacing, 2RU

MM6HM6D2RU MM6 horizontal cable management panel, six-port, double-sided, 2RU

Front

Rear

13.5

13.5

12.5

5

16

26

16

26

5

13.5

32.5

5

25

15

25

73

25

15

90

73

25

134

90

134

Cable

Recommended Cable Fill (40%)

Cat 5e

O.D. (in.) 0.215

1608

1080

1608

1080

876

300

Cat 6

0.230

135

50

135

125

50

160

260

160

260

50

135

325

50

730

250

150

250

150

250

192

312

192

312

60

162

390

60

876

300

180

300

180

300

162

60

162

150

60

1340

900

1340

900

730

250

Cat 6a

182

35

95

228

35

175

105

175

112

182

112

95

35

95

88

35

630

511

175

511

175

105

0.290

938

630

938

Horizontal Cable Capacities for Ortronics Mighty Mo Racks

Part Number

MM10716

MM10816

MM6706

MM6710

MM6810

MM6716

MM6816

Description

MM10 cable management rack, 16.25” channel depth, 7’, black

MM10 cable management rack, 16.25” channel depth, 8’, black

MM6 cable management rack, 6.5” channel depth, 7’, black

MM6 cable management rack, 10.50” channel depth, 7’, black

MM6 cable management rack, 10.50” channel depth, 8’, black

MM6 cable management rack, 16.25” channel depth, 7’, black

MM6 cable management rack, 16.25” channel depth, 8’, black

34

56

56

Usable

Area

(sq. in.)

88

88

88

88

24 CNT

Bundle

Single Channel Capacity

Cat 5e

O.D. (In) 1.125”

Cat 6

1.25”

Cat 6a

1.625”

768

768

288

480

480

768

768

480

480

240

288

288

480

480

336

336

156

240

240

336

336

Total Rack Capacity

Cat 5e Cat 6

1.625” 1.25”

1536

1536

576

960

960

1536

1536

960

960

480

576

576

960

960

Cat 6a

1.625”

672

672

312

480

480

672

672

12.25” 8.25” 6.5” 2.5”

16”

36”

12”

32”

10”

30.25”

6”

26.25”

255

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Part Number Index

CABLEXIT

CF 30

CF 54

CF 105

CF 150

EDRN

FASC

FASL

FASLOCK

FASP

FASPCH

FASROLLER

FASU

Fiberglass Cable Tray Design Options

Floor Bracket Wired Assembly

FT

FTB

FTBC

FTC

FTCFB45

FTCFB90

FTCV090

FTCV190

FTFB45

FTFB90

FTT

FTTC

243

243

243

244

244

243

237

242

240

243

244

244

243

244

244

236

236

235

236

236

237

237

232

232

232

232

235

FTV090

FTVI90

FTVT

244

244

245

FTX

FTXC

245

245

Metallic Cable Tray Design Options – Non-Vented 242

Metallic Cable Tray Design Options – Vented

MMC422434-00004

MMC422440-00005

MMC422440-00006

MMC422446-00002

MMC422446-00003

14

14

14

242

14

14

MMC423234-0000A

MMC423240-0000G

MMC423240-0000H

MMC423246-00007

MMC423246-00008

MMC472440-00003

MMC472440-00004

MMC472446-00001

MMC472446-00002

MMC473240-00003

MMC473240-00004

MMC473246-00001

MMC473246-00002

OR-2-E1-25C-A

OR-2-E1-75

14

14

14

14

14

14

14

14

14

14

14

14

14

200

201

OR-2-E2-TRPC

OR-19-21-T8D

OR-19-21-T12D

OR-19-21-T18D

OR-19-21-T25D

OR-19-21-T25DHYDT

OR-19-35-T8D

OR-19-35-T12D

OR-19-35-T18D

OR-19-35-T25D

OR-19-35-T25DHYDT

OR-19-48-T12D

OR-19-48-T18D

OR-19-48-T25D

OR-19-72-T2SD

OR-19-84-6T2SDB

OR-19-84-SSDA2132

OR-19-84-T2SD

OR-19-84-T4SDA1520

OR-19-84-T4SDA2132

OR-19-96-T2SD

OR-19-96-T4SDA2132

OR-23-72-T2SD

OR-23-84-6T2SDB

OR-23-84-T2SD

OR-23-96-T2SD

OR-50900051

140

140

148

140

148

148

157

157

148

148

141, 147

147, 148

148

148

171

157

157

157

157

158

157

202

157

157

157

157

158

OR-60400099

OR-60400114

OR-60400129

OR-60400131

OR-60400189

OR-60400199

OR-60400302

OR-60400314

OR-60400355

OR-60400381

OR-60400383

OR-60400404

OR-60400405

OR-60400426

OR-60400517

OR-50900051-TL

OR-50900052

OR-50900052-TL

OR-60400005

OR-60400006

OR-60400010

OR-60400013

OR-60400017

OR-60400054

OR-60400057

OR-60400062

OR-60400098

OR-60400523

OR-60400533

OR-60400538

OR-60400542

OR-60400550

OR-60400551

OR-60400575

OR-60400606

OR-60400614

OR-60400655

OR-60400681

OR-60400687

OR-60401001

OR-60401015

OR-60401089

OR-70700079

OR-70700080

OR-70700084-00

OR-70700107-00

OR-70700126

OR-70700143

OR-70700144

OR-70800205

OR-401004788

OR-401004789

OR-401004790

OR-401004791

131

131

136

171

170

164

161

161

161

160

161

174

164

161

136

171

131

161

160

131

161

171

171

171

172

164

207

174

136

174

174

173

169

137

137

137

174

174

174

169

169

169

168

167

131

136

171

133

167

172

136

131

167

167

OR-401045773

OR-604004068

OR-604004301

OR-604004396

OR-604004645

OR-604044486

OR-604044927

OR-604044938

OR-604045075

OR-604045081

OR-604045108

OR-604045109

OR-604045110

OR-604045111

OR-604045112

OR-604045388

OR-604045400

OR-604045401

OR-604045450

OR-604045451

OR-604045681

OR-808000010

OR-808004759

OR-808004818

OR-808004867

OR-808044508

OR-808044549

257

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

159

159

136

162

160

160

170

170

170

165

159

165

160

162

162

167

165

165

165

170

170

169

159

159

159

159

165

Part Number Index

OR-808044855

OR-808044915

OR-808044916

OR-808045030

OR-808045590

OR-808045768

OR-AJCA

OR-AJCC

OR-AJCC8

OR-BCGFM3X9

OR-BCGFMC3X9

OR-BCGFME5X7

OR-BCGSM6X7

OR-BFPA-1RU

OR-BFPA-2RU

OR-BFPC-1RU

OR-BFPT-1RU-10

OR-BFPT-2RU-10

OR-CA-93

OR-CB-93-6

OR-CB-93-7

OR-CB-93-8

OR-CF-6B

OR-CF-6D

OR-CF-12B

OR-CFTRC-6B

OR-CFTRC-6D

173

151

151

151

197

197

138

170

170

170

110, 169, 189

110, 169, 189

197

197

197

208

208

208

138

138

138

160

161

161

162

160

160

OR-CFTRC-12B

OR-CL2LB2A

OR-CL2LB2C

OR-CL2LB6A

OR-CL2LB6B

OR-CL2LB6C

OR-CL2LB10C

OR-CL2LB20C

OR-CL2LB30C

OR-CL2LB40C

OR-CMBFR0RU

OR-COTL28

OR-COTL614

OR-COTL1014

OR-CR-93S-1B

OR-CR-93S-2B

OR-CR-93S-3B

OR-CR-93S-4B

OR-CTHD220

OR-CTHD2222

OR-CTHD2248

OR-CTHD4446

OR-CTHD4666

OR-DC6-19B

OR-DC6-23B

OR-DC-19

OR-DC-23

206

206

206

206

206

156

207

207

152

152

152

152

156

156

156

206

206

206

206

172

207

197

206

206

206

206

206

OR-DC1520-19

OR-DC2126-19

OR-DC2732-19

OR-DVMS704

OR-DVMS706

OR-DVMS804

OR-DVMS806

OR-ES-19-3B

OR-ES-19-4B

OR-ES-19-FDR1520

OR-ES-19-FDR2126

OR-ES-19-FDR2732

OR-ES-19-FMB

OR-ES-19-MCSB

OR-ES-19-SDR1520F

OR-ES-19-SDR2126F

OR-ES-19-SDR2732F

OR-ES-23-3B

OR-ES-23-4B

OR-ES-23-FMB

OR-ESV-19-3B

OR-ESV-19-4B

OR-ESV-19-FDR1520

OR-ESV-19-FDR2126

OR-ESV-19-FDR2732

OR-ESV-19-FMB

OR-ESV-19-FST1520

164

166

164

164

142

142

166

166

143

143

143

164

142

166

144

149

164

164

142

142

142

144

144

144

149

149

149

OR-ESV-19-FST2126

OR-ESV-19-FST2732

OR-ESV-19-SDR1520F

OR-ESV-19-SDR2126F

OR-ESV-19-SDR2732F

OR-ESV-23-3B

OR-ESV-23-4B

OR-ESV-23-FMB

OR-FCM-19-1

OR-FCM-19-1SR

OR-FCM-19-1SRC

OR-FCM-19-1XL

OR-FCM-19-2

OR-FCM-19-2L

OR-FCM-19-2SR

OR-FCM-19-2SRC

OR-FCM-19-2XL

OR-FCM-19-2XLH

OR-FCM-19-4XL

OR-GB2X10TGB

OR-GB2X12TGB

OR-GB2X12TGBKIT

OR-GB4X12J

OR-GB4X12TMGB

OR-GB4X12TMGBKIT

OR-GB4X20J

OR-GB4X20TMGB

162

204

204

204

204

203

163

163

163

163

162

162

203

204

203

164

166

163

163

163

162

144

144

143

143

143

164

OR-GB4X20TMGBKIT 203

OR-GBH19KIT 205

OR-GBV36 205

OR-GBV36KIT

OR-GBV72

OR-GBV72KIT

205

205

205

OR-GBWMBKIT

OR-GJ8KIT

OR-GL2014

OR-GR-19

OR-GR-23

OR-GS-8

204

207

207

155

155

195

OR-GXC24VPMLD-B 50, 52

OR-GXC24VPMLS-B 50, 52

OR-GXC29WMK-5-B 74, 76, 78, 80, 82, 84, 86, 88, 90

OR-GXC31WMK-5-B 92, 94, 96, 98, 100, 102, 104, 106, 108

OR-GXC42VFK-B 54, 56, 58, 74, 76, 78, 92, 94, 96

OR-GXC42VPMLD-B 54, 56, 58, 74, 76, 78, 92, 94, 96

OR-GXC42VPMLS-B 54, 56, 58, 74, 76, 78, 92, 94, 96

OR-GXC45VFK-B 60, 62, 64, 80, 82, 84, 98, 100, 102

OR-GXC45VPMLD-B 60, 62, 64, 80, 82, 84, 98, 100, 102

OR-GXC45VPMLS-B 60, 62, 64, 80, 82, 84, 98, 100, 102

OR-GXC48VFK-B 66, 68, 70, 86, 88, 90, 104, 106, 108

OR-GXC48VPMLD-B 66, 68, 70, 86, 88, 90, 104, 106, 108

OR-GXC48VPMLS-B 66, 68, 70, 86, 88, 90, 104, 106, 108

OR-GXC2424DFM-B 50, 52

OR-GXC2424DFP-B 50, 52

OR-GXC2424DFS-B 50, 52

OR-GXC2424DSM-B 50, 52

OR-GXC2424DSS-B

OR-GXC2436SPSL-B

OR-GXC2436TPS-B

OR-GXC2436TPV-B

OR-GXC2442TPS-B

OR-GXC2442TPV-B

OR-GXC2448TPS-B

OR-GXC2448TPV-B

OR-GXC2912CTCE-B

OR-GXC2936TPS-B

OR-GXC2936TPV-B

OR-GXC2942TPS-B

OR-GXC2942TPV-B

OR-GXC2948TPC-B

OR-GXC2948TPS-B

50, 52

OR-GXC2424M12-B 50, 52

OR-GXC2424M38-B 50, 52

50

OR-GXC2436TPC-B 50, 54, 60, 66

50, 54, 60, 66

50, 54, 60, 66

OR-GXC2442SPSL-B 52

OR-GXC2442TPC-B 52, 56, 62, 68

52, 56, 62, 68

52, 56, 62, 68

OR-GXC2448TPC-B 58, 64, 70

58, 64, 70

58, 64, 70

OR-GXC2906CTCE-B 74, 76, 78, 80, 82, 84, 86, 88, 90

74, 76, 78, 80, 82, 84, 86, 88, 90

OR-GXC2918CTCE-B 74, 76, 78, 80, 82, 84, 86, 88, 90

OR-GXC2936TPC-B 74, 80, 86

74, 80, 86

74, 80, 86

OR-GXC2942TPC-B 76, 82, 88

76, 82, 88

76, 82, 88

78, 84, 90

78, 84, 90

259

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Part Number Index

OR-GXC2948TPV-B 78, 84, 90

OR-GXC3106CTCE-B 92, 94, 96, 98, 100, 102, 104, 106, 108

OR-GXC3112CTCE-B 92, 94, 96, 98, 100, 102, 104, 106, 108

OR-GXC3118CTCE-B 92, 94, 96, 98, 100, 102, 104, 106, 108

OR-GXC3136TPC-B 92, 98, 104

OR-GXC3136TPS-B 92, 98, 104

OR-GXC3136TPV-B 92, 98, 104

OR-GXC3142TPC-B 94, 100, 106

OR-GXC3142TPS-B 94, 100, 106

OR-GXC3142TPV-B 94, 100, 106

OR-GXC3148TPC-B 96, 102, 108

OR-GXC3148TPS-B 96, 102, 108

OR-GXC3148TPV-B 96, 102, 108

OR-GXC4206VWT 54

OR-GXC4206VWT-B 56, 58, 74, 76, 78, 92, 94, 96

OR-GXC4224DFM-B 54, 56, 58

OR-GXC4224DFP-B 54, 56, 58

OR-GXC4224DFS-B 54, 56, 58

OR-GXC4224DSM-B 54, 56, 58

OR-GXC4224DSS-B 54, 56, 58

OR-GXC4224M12-B 54, 56, 58

OR-GXC4224M38-B 54, 56, 58

OR-GXC4229ADK-B 74, 76, 78

OR-GXC4229DFM-B 74, 76, 78

OR-GXC4229DFP-B 74, 76, 78

OR-GXC4229DFS-B 74, 76, 78

OR-GXC4229DSM-B 74, 76, 78

OR-GXC4229DSS-B

OR-GXC4229M12-B

OR-GXC4229M38-B

OR-GXC4229SPB-B

OR-GXC4231ADK-B

OR-GXC4231DFM-B

OR-GXC4231DFP-B

OR-GXC4231DFS-B

OR-GXC4231DSM-B

OR-GXC4231DSS-B

OR-GXC4231M12-B

OR-GXC4231M38-B

OR-GXC4231SPB-B

OR-GXC4236SPSL-B

OR-GXC4242SPSL-B

OR-GXC4248SPSL-B

OR-GXC4506VWT-B

OR-GXC4524DFM-B

OR-GXC4524DFP-

OR-GXC4524DFP-B

OR-GXC4524DFS-

OR-GXC4524DFS-B

OR-GXC4524DSM-B

OR-GXC4524DSS-B

OR-GXC4524M12-B

OR-GXC4524M38-B

OR-GXC4529ADK-B

74, 76, 78

74, 76, 78

74, 76, 78

74, 76, 78

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

92, 94, 96

54, 74, 92

56, 76, 94

58, 78, 96

60, 62, 64, 80, 82, 84, 98, 100, 102

60, 62, 64

62

60, 64

62

60, 64

60, 62, 64

60, 62, 64

60, 62, 64

60, 62, 64

80, 82, 84

OR-GXC4529DFM-B

OR-GXC4529DFP-B

OR-GXC4529DFS-B

OR-GXC4529DSM-B

OR-GXC4529DSS-B

OR-GXC4529M12-B

OR-GXC4529M38-B

OR-GXC4529SPB-B

OR-GXC4531ADK-B

OR-GXC4531DFM-B

OR-GXC4531DFP-B

OR-GXC4531DFS-B

80, 82, 84

80, 82, 84

80, 82, 84

80, 82, 84

80, 82, 84

80, 82, 84

80, 82, 84

80, 82, 84

98, 100, 102

98, 100, 102

98, 100, 102

98, 100, 102

OR-GXC4531DSM-B

OR-GXC4531DSS-B

OR-GXC4531M12-B

98, 100, 102

98, 100, 102

98, 100, 102

OR-GXC4531M38-B

OR-GXC4531SPB-B

98, 100, 102

98, 100, 102

OR-GXC4536SPSL-B 60, 80, 98

OR-GXC4542SPSL-B 62, 82, 100

OR-GXC4548SPSL-B 64, 84, 102

OR-GXC4806VWT-B 66, 68, 70, 86, 88, 90, 104, 106, 108

OR-GXC4824DFM-B

OR-GXC4824DFP-B

OR-GXC4824DFS-B

66, 68, 70

66, 68, 70

66, 68, 70

OR-GXC4824DSM-B

OR-GXC4824DSS-B

OR-GXC4824M12-B

66, 68, 70

66, 68, 70

66, 68, 70

OR-GXC4824M38-B

OR-GXC4829ADK-B

OR-GXC4829DFM-B

OR-GXC4829DFP-B

OR-GXC4829DFS-B

OR-GXC4829DSM-B

OR-GXC4829DSS-B

OR-GXC4829M12-B

OR-GXC4829M38-B

OR-GXC4829SPB-B

OR-GXC4831ADK-B

OR-GXC4831DFM-B

OR-GXC4831DFP-B

OR-GXC4831DFS-B

OR-GXC4831DSM-B

OR-GXC4831DSS-B

OR-GXC4831M12-B

OR-GXC4831M38-B

OR-GXC4831SPB-B

OR-GXC4836SPSL-B

OR-GXC4842SPSL-B

OR-GXC4848SPSL-B

OR-GXC242436-B

OR-GXC242442-B

OR-GXC422436-B

OR-GXC422442-A1-B

OR-GXC422448-B

53

48

57

104, 106, 108

104, 106, 108

104, 106, 108

104, 106, 108

104, 106, 108

104, 106, 108

104, 106, 108

66, 86, 104

68, 88, 106

70, 90, 108

49

51

66, 68, 70

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

86, 88, 90

104, 106, 108

104, 106, 108

OR-GXC422936-B

OR-GXC422942-A1-B

OR-GXC422942-B

OR-GXC422948-B

OR-GXC423136-B

OR-GXC423142-B

OR-GXC423148-B

OR-GXC452436-B

OR-GXC452442-B

OR-GXC452448-B

OR-GXC452936-B

OR-GXC452942-B

OR-GXC453136-B

OR-GXC453148-B

OR-GXC482436-B

OR-GXC482442-B

OR-GXC482448-B

OR-GXC482936-

OR-GXC482936-B

OR-GXC482942-B

OR-GXC482948-B

OR-GXC483136-B

OR-GXC483142-B

OR-GXC483148-B

OR-GXCAB421629-B

OR-GXCAB421629SA-B

OR-GXCAB421631-B

85

87

89

103

105

107

67

69

85

97, 99

101

65

74, 76, 78

74, 76, 78

92, 94, 96

95

59

61

63, 83

79

81

77

91

93

73

48

75

OR-GXCAB421631SA-B 92, 94, 96

OR-GXCAB423029-B 74, 76, 78

OR-GXCAB423029SA-B 74, 76, 78

OR-GXCAB423031-B

OR-GXCTPBK

OR-HFM-19-2

OR-IPK

92, 94, 96

OR-GXCAB423031SA-B 92, 94, 96

OR-GXCAB451629-B 80, 82, 84

OR-GXCAB451629SA-B 80, 82, 84

OR-GXCAB451631-B 98, 100, 102

OR-GXCAB451631SA-B 98, 100, 102

OR-GXCAB453029-B 80, 82, 84

OR-GXCAB453029SA-B 80, 82, 84

OR-GXCAB453031-B 98, 100, 102

OR-GXCAB453031SA-B 98, 100, 102

OR-GXCAB481629-B 86, 88, 90

OR-GXCAB481629SA-B 86, 88, 90

OR-GXCAB481631-B 104, 106, 108

OR-GXCAB481631SA-B 104, 106, 108

OR-GXCAB483029-B 86, 88, 90

OR-GXCAB483029SA-B 86, 88, 90

OR-GXCAB483031-B 104, 106, 108

OR-GXCAB483031SA-B 104, 106, 108

OR-GXCCSTR-B 50, 52, 54, 56, 58, 60, 62, 64, 66,

68, 70, 74, 76, 78, 80, 82, 84, 86,

88, 90, 92, 94, 96, 98, 100, 102,

104, 106, 108

109

158

149

261

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Part Number Index

OR-JH-93

OR-JP0606-6TB

OR-JP0606B

OR-JP0612-6TB

OR-JP0612B

OR-JP1218-6TB

OR-JP1218B

OR-JP1824-6TB

OR-JP1824B

OR-KTF-19-DR

OR-KTR19-DR

OR-M6DRSAK

OR-MC4702VMFL

OR-MCT810

OR-MCT840

OR-MM6BDC06

OR-MM6BDC10

OR-MM6BDC16

OR-MM6BLC

OR-MM6CBL06

OR-MM6CBL10

OR-MM6CBL16

OR-MM6CEK06

OR-MM6CEK10

OR-MM6CEK16

OR-MM6CMS6

OR-MM6CMS8

38

207

207

133

133

133

115, 132

132

132

132

134

134

134

132

132

155

155

155

168

168

144

173

155

155

155

155

155

OR-MM6CMS10

OR-MM6CRB06

OR-MM6CRB10

OR-MM6CRB16

OR-MM6CT4RU

OR-MM6EP706

OR-MM6EP710

OR-MM6EP716

OR-MM6EPN706

OR-MM6EPN710

OR-MM6EPN716

OR-MM6EPN816

OR-MM6HM6D2RU

OR-MM6HM61RU

OR-MM6HM62RU

OR-MM6HM81RU

OR-MM6HM82RU

OR-MM6HMF1RU

OR-MM6HMF2RU

OR-MM6HMF4RU

OR-MM6 T4RUK

OR-MM6VMD706

OR-MM6VMD710

OR-MM6VMD806

OR-MM6VMD810

OR-MM6VML704

OR-MM6VML706

135

135

135

135

135

115, 135

115, 135

135

134

128

128

130

130

128

128

132

133

133

133

134

128

128

128

128

128

122, 128

124

OR-MM6VMS704

OR-MM6VMS706

OR-MM6VMS804

OR-MM6VMS806

OR-MM10AB71612

OR-MM10AB71616

OR-MM10AB73012

OR-MM10AB73016

OR-MM10AB81612

OR-MM10AB81616

OR-MM10AB83012

OR-MM10AB83016

OR-MM10CRBRSVR

OR-MM10CRBSVR

OR-MM10EPN730

OR-MM10EPS

OR-MM10VMD712

OR-MM10VMD716

OR-MM10VMD812

OR-MM10VMD816

OR-MM10WFE

OR-MM107SVR

OR-MM108SVR

OR-MM6706

OR-MM6710

OR-MM6716

OR-MM6810

133

133

122

122, 124, 128

122

122

124

124

131

121, 122

123, 124

128

127, 128

127, 128

129, 130

122

122

124

124

124

124

128

128

130

130

122

122

OR-MM6816

OR-MM10716

OR-MM10816

OR-MM1070206VCT

OR-MM1080206VCT

OR-MMABTH802424

OR-MMABTH802424-B

OR-MMABTH804824

OR-MMABTH804824-B

OR-MMABTH807224

OR-MMABTH807224-B

OR-MMACAP60X30

OR-MMACAP84X30

OR-MMACNCP29X12

OR-MMACNCP56X12

OR-MMACNCP98X12

OR-MMACNCP110X12

OR-MMACNCP122X12

OR-MMACNCP146X12

OR-MMACNCP182X12

OR-MMACNP29X12

OR-MMACNP29x24

OR-MMACNP29x36

OR-MMACNP29x48

OR-MMACNP29x60

OR-MMACNP29x72

OR-MMACNP56X12

185

185

181

181

181

181

179

185

185

185

185

185

181

181

181

187

187

187

187

187

179

129, 130

121, 122

123, 124

122

124

187

OR-MMACNP56X24

OR-MMACNP56X36

OR-MMACNP56X48

OR-MMACNP56X60

OR-MMACNP56X72

OR-MMACNP98X12

OR-MMACNP98X24

OR-MMACNP98X48

OR-MMACNP110X12

OR-MMACNP110X24

OR-MMACNP110X48

OR-MMACNP122X12

OR-MMACNP122X24

OR-MMACNP122X48

OR-MMACNP146X12

OR-MMACNP146X24

OR-MMACNP146X48

OR-MMACNP182X12

OR-MMACNP182X24

OR-MMACNP182X48

OR-MMACNS98X12

OR-MMACNS98X24

OR-MMACNS98X36

OR-MMACNS98X48

OR-MMACNS98X60

OR-MMACNS98X72

OR-MMACNS110X12

182

182

183

183

183

183

182

182

182

182

182

182

183

183

183

182

182

182

182

182

182

182

182

182

182

182

182

OR-MMACNS110X24

OR-MMACNS110X36

OR-MMACNS110X48

OR-MMACNS110X60

OR-MMACNS110X72

OR-MMACNS122X12

OR-MMACNS122X24

OR-MMACNS122X36

OR-MMACNS122X48

OR-MMACNS122X60

OR-MMACNS122X72

OR-MMACNS146X12

OR-MMACNS146X24

OR-MMACNS146X36

OR-MMACNS146X48

OR-MMACNS146X60

OR-MMACNS146X72

OR-MMACNS182X12

OR-MMACNS182X24

OR-MMACNS182X36

OR-MMACNS182X48

OR-MMACNS182X60

OR-MMACNS182X72

OR-MMADIS0624

OR-MMADIS1224

OR-MMADIS1824

OR-MMADIS2424

263

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

184

184

184

184

184

189

184

184

184

184

184

184

189

189

189

184

184

184

184

184

184

183

183

183

183

183

184

Part Number Index

OR-MMADRF80X24

OR-MMADRF80X24-B

OR-MMADRH80X56LH

OR-MMADRH80X56LH-B

OR-MMADRH80X56RH

OR-MMADRH80X56RH-B

OR-MMADRS80X89DL

OR-MMADRS80X89DL-B

OR-MMADRS80X89LH

OR-MMADRS80X89LH-B

OR-MMADRS80X89RH

OR-MMADRS80X89RH-B

OR-MMAGCT2424

OR-MMAGCT2448

OR-MMAPL0404

OR-MMAPL0606

OR-MMAPL0612

OR-MMAPL0618

OR-MMAPL0624

OR-MMAPL0909

OR-MMAPL0914

OR-MMAPL0918

OR-MMAPL0924

OR-MMAPL1212

OR-MMAPL1218

OR-MMAPL1224

OR-MMAPL1414

188

188

188

188

188

188

190

190

187

187

188

188

188

188

188

185

185

186

186

186

186

185, 186

186

186

186

186

186

OR-MMAPL1616

OR-MMAPL1620

OR-MMAPL1624

OR-MMAPL1818

OR-MMAPL2024

OR-MMAPL2424

OR-MMAPR56X80

OR-MMAPR56X80-B

OR-MMC24VPMLD

OR-MMC24VPMLS

OR-MMC42VPMLD

OR-MMC42VPMLS

188

188

188

188

188

188

179

179

16

16

18, 20, 22, 30, 32, 34

18, 20, 22, 30, 32, 34

OR-MMC47VPMLD

OR-MMC47VPMLS

24, 26, 28, 36, 38, 40

24, 26, 28, 36, 38, 40

OR-MMC2406CTCE-B 16, 18, 20, 22, 24, 26, 28, 50, 52, 54,

56, 58, 60, 62, 64, 66, 68, 70

OR-MMC2412CTCE-B 16, 18, 20, 22, 24, 26, 28

OR-MMC2418CTCE-B 16, 18, 20, 22, 24, 26, 28, 50, 52, 54,

56, 58, 60, 62, 64, 66, 68, 70

OR-MMC2424DFFM-B 16

OR-MMC2424DFFS-B 16

OR-MMC2424DFPM-B 16

OR-MMC2424DFPP-B 16

OR-MMC2424DFPS-B 16

OR-MMC2424DSFM-B 16

OR-MMC2424DSFS-B 16

OR-MMC2424M12-B

OR-MMC2424M38-B

16

16

OR-MMC2434SPSL-B

OR-MMC2434TPH1-B

OR-MMC2434TPH2-B

OR-MMC2434TPHC-B

OR-MMC2434TPHM-B

OR-MMC2434TPHS-B

OR-MMC2440TPH1-B

OR-MMC2440TPH2-B

OR-MMC2440TPHC-B

OR-MMC2440TPHM-B

OR-MMC2440TPHS-B

OR-MMC2446TPH1-B

OR-MMC2446TPH2-B

OR-MMC2446TPHC-B

OR-MMC2446TPHM-B

OR-MMC2446TPHS-B

OR-MMC3206CTCE-B

OR-MMC3212CTCE-B

OR-MMC3218CTCE-B

OR-MMC3234TPH1-B

OR-MMC3234TPH2-B

OR-MMC3234TPHC-B

OR-MMC3234TPHM-B

OR-MMC3234TPHS-B

OR-MMC3240TPH1-B

OR-MMC3240TPH2-B

OR-MMC3240TPHC-B

20, 26

20, 26

20, 26

20, 26

20, 26

22, 28

16

16, 18, 24

16, 18, 24

16, 18, 24

16, 18, 24

16, 18, 24

22, 28

22, 28

22, 28

22, 28

30, 32, 34, 36, 38, 40

30, 32, 34, 36, 38, 40

30, 32, 34, 36, 38, 40

30, 36

30, 36

30, 36

30, 36

30, 36

32, 38

32, 38

32, 38

OR-MMC3240TPHM-B

OR-MMC3240TPHS-B

OR-MMC3246TPH1-B

OR-MMC3246TPH2-B

OR-MMC3246TPHC-B

OR-MMC3246TPHM-B

OR-MMC3246TPHS-B

OR-MMC4202VMFL

OR-MMC4212VMFU

OR-MMC4224DFFM-B

OR-MMC4224DFFS-B

OR-MMC4224DFPM-B

OR-MMC4224DFPP-B

OR-MMC4224DFPS-B

OR-MMC4224DSFM-B

OR-MMC4224DSFS-B

OR-MMC4224M12-

OR-MMC4224M12-B

OR-MMC4224M38-B

OR-MMC4232DFFM-B

OR-MMC4232DFFS-B

OR-MMC4232DFPM-B

OR-MMC4232DFPP-B

OR-MMC4232DFPS-B

OR-MMC4232DSFM-B

OR-MMC4232DSFS-B

OR-MMC4234SPSL-B

32, 38

32, 38

34, 40

34, 40

34, 40

34, 40

34, 40

18, 20, 22, 30, 32, 34

18, 20, 22, 30, 32, 34

18, 20, 22

18, 20, 22

18, 20, 22

18, 20, 22

18, 20, 22

18, 20, 22

18, 20, 22

22

18, 20, 30, 32, 34

18, 20, 22, 30, 32, 34

30, 32, 34

30, 32, 34

30, 32, 34

30, 32, 34

30, 32, 34

30, 32, 34

30, 32, 34

18, 30

OR-MMC4234SPSN-B

OR-MMC4240SPSL-B

OR-MMC4240SPSN-B

OR-MMC4246SPSL-B

OR-MMC4246SPSN-B

OR-MMC4702VMFL

OR-MMC4712VMFU

OR-MMC4724DFFM-B

OR-MMC4724DFFS-B

OR-MMC4724DFPM-B

OR-MMC4724DFPP-B

OR-MMC4724DFPS-B

OR-MMC4724DSFM-B

OR-MMC4724DSFS-B

OR-MMC4724M12-B

OR-MMC4724M38-B

OR-MMC4732DFFM-B

OR-MMC4732DFFS-B

OR-MMC4732DFPM-B

OR-MMC4732DFPP-B

OR-MMC4732DFPS-B

OR-MMC4732DSFM-B

OR-MMC4732DSFS-B

OR-MMC4734SPSL-B

OR-MMC4734SPSN-B

OR-MMC4740SPSL-B

OR-MMC4740SPSN-B

18, 30

20, 32

20, 32

22, 34

22, 34

24, 26, 28, 36, 40

24, 26, 28, 36, 38, 40

26, 28

26, 28

24, 26, 28

24, 26, 28

24, 26, 28

24, 26, 28

24, 26, 28

24, 26, 28, 36, 38, 40

24, 26, 28, 36, 38, 40

36, 38, 40

36, 38, 40

36, 38, 40

36, 38, 40

36, 38, 40

36, 38, 40

36, 38, 40

24, 36

24, 36

26, 38

26, 38

OR-MMC4746SPSL-B

OR-MMC4746SPSN-B

OR-MMC242434-B

OR-MMC422434-B

OR-MMC422440-B

OR-MMC422446-B

OR-MMC423234-B

OR-MMC423240-B

OR-MMC423246-B

OR-MMC472434-B

OR-MMC472440-B

OR-MMC472446-B

OR-MMC473234-B

OR-MMC473240-B

OR-MMC473246-B

OR-MMCAB421612

OR-MMCAB421632SA

OR-MMCAB423012

OR-MMCAB471612

OR-MMCAB471632SA

OR-MMCAB473012

OR-MMCCAS-SW-3

111

111

111

109

23

25

27

29

31

33

17

19

21

28, 40

28, 40

15

35

37

39

30, 32, 34

30, 32, 34

30, 32, 34

36, 38, 40

36, 38, 40

36, 38, 40

16, 18, 20, 22, 24, 26, 28, 30, 32,

34, 36, 38, 40

115 OR-MMCCNTOOL

OR-MMCCRMB06-B

OR-MMCCRMB12-B

OR-MMCCRMB18-B

OR-MMCCSS2-1915

265

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

Part Number Index

OR-MMCCSS3-1915

OR-MMCCSV1-1912

OR-MMCCSV2-1915

OR-MMCCSV3-1915

OR-MMCCTMB06-B

OR-MMCCTMB12-B

OR-MMCCTMB18-B

OR-MMCDHSCK-0333

OR-MMCDHSKL-0333

OR-MMCDR2-1915

OR-MMCDR4-1915

OR-MMCFAN-4-50

OR-MMCFAN-6

OR-MMCFAN-6-2

OR-MMCFANP19-4-2

OR-MMCFPS-1-B

OR-MMCFPS-2-B

OR-MMCFPS-3-B

OR-MMCFPS-4-B

OR-MMCFPS-5-B

OR-MMCFPS-6-B

OR-MMCFPT-1-B

OR-MMCFPT-2-B

OR-MMCFPT-3-B

OR-MMCFPT-4-B

OR-MMCFPT-8-B

110

110

110

110

110

110

110

110

110

110

110

109

109

109

109

111

111

111

16, 18, 20, 22, 24, 26, 28, 30,

32, 34, 36, 38, 40

16, 18, 20, 22, 24, 26, 28, 30,

32, 34, 36, 38, 40

110

110

114

41, 109

41, 109

41, 109

OR-MMCFSV-1926

OR-MMCISOB-38

OR-MMCISOB-50

OR-MMCLVL-IP

OR-MMCMBK

OR-MMCPB11510-01

OR-MMCPB11518-01

OR-MMCPB11524-01

OR-MMCPB12010-01

OR-MMCPB12018-01

OR-MMCPB12024-01

OR-MMCPB13016-01

OR-MMCPB13024-01

OR-MMCPB22012-01

OR-MMCPB22018-01

OR-MMCPB22024-01

OR-MMCPB23016-01

OR-MMCPB23024-01

OR-MMCPB23024-02

OR-MMCPM12010-01

OR-MMCPM12024-01

OR-MMCPM13016-01

OR-MMCPM13024-01

OR-MMCPM22012-01

OR-MMCPM22018-01

OR-MMCPM22024-01

OR-MMCPM23016-01

175

176

176

176

176

176

175

175

175

175

175

175

176

176

176

175

175

175

175

175

175

109

41

41

41

41

175

OR-MMCPM23024-01

OR-MMCPM23024-02

OR-MMCRULBL-60-A

OR-MMCSSVH-1930

OR-MMCSSVL-1924

OR-MMCSSVM-1924

OR-MMCUN-1420-10

OR-MMF4X2R2X2-Y

OR-MMF4X4R2X2-Y

OR-MMF4X4R4X2-Y

OR-MMF12X4R8X4-Y

OR-MMFAK4X4ADC4-Y

OR-MMFAK12X4ADC6-Y

OR-MMFAKL4X4ADC6-Y

OR-MMFAKL8X4ADC6-Y

OR-MMFAKL8X4PAN6-Y

OR-MMFAKR4X4ADC6-Y

OR-MMFAKR8X4ADC6-Y

OR-MMFAKR8X4PAN6-Y

OR-MMFC4X2R2X2-Y

OR-MMFC4X4R2X2-Y

OR-MMFC4X4R4X2-Y

OR-MMFC12X4R8X4-Y

OR-MMFCFMBKT

OR-MMFCOT6

OR-MMFCOT35

OR-MMFCT50D1M-B

226

223

223

223

223

228

226

226

226

226

226

226

230

230

225

176

176

41, 109

109

109

109

41, 109

223

223

223

223

226

OR-MMFCT50D1M-Y

OR-MMFCT50D2M-B

OR-MMFCT50D2M-Y

OR-MMFCT50S350-B

OR-MMFCT50S350-Y

OR-MMFCTF751M-Y

OR-MMFCTF752M-Y

OR-MMFCTOC50S350-Y

OR-MMFDMB2

OR-MMFDMB4

OR-MMFDMB8

OR-MMFDMB12

OR-MMFEC2X220KO-Y

OR-MMFEC2X238CO-Y

OR-MMFEC2X238KO-Y

OR-MMFEC2X244TO-Y

OR-MMFEC4X4ESB-Y

OR-MMFEC4X432KO-Y

OR-MMFEC4X446KO-Y

OR-MMFEC4X488TO-Y

OR-MMFEC8X488TO-Y

OR-MMFECS4X2-Y

OR-MMFECS4X4-Y

OR-MMFECS8X4-Y

OR-MMFECSL4X4-Y

OR-MMFECSL8X4-Y

OR-MMFECSL12X4-Y

222

223

223

222

222

222

222

222

222

222

223

222

222

222

222

226

226

229

229

229

229

225

225

225

225

225

226

OR-MMFFSLIN2X2-Y

OR-MMFFSLIN4X2-Y

OR-MMFFSLIN4X4-Y

OR-MMFFSLIN8X4-Y

OR-MMFFSLIN12X4-Y

OR-MMFFSLOF2X2-Y

OR-MMFFSLOF4X2-Y

OR-MMFFSLOF4X4-Y

OR-MMFFSLOF8X4-Y

OR-MMFFSLOF12X4-Y

OR-MMFHC2X2-Y

OR-MMFHC4X2-Y

OR-MMFHC4X4-Y

OR-MMFHC8X4T4-Y

OR-MMFHC8X4T12-Y

OR-MMFHC8X4-Y

OR-MMFHC12X4T4-Y

OR-MMFHC12X4-Y

OR-MMFHCC2X2-Y

OR-MMFHCC4X2-Y

OR-MMFHCC4X4-Y

OR-MMFHCC8X4T4-Y

OR-MMFHCC8X4T12-Y

OR-MMFHCC8X4-Y

OR-MMFHCC12X4T4-Y

OR-MMFHCC12X4-Y

OR-MMFHCDO4X4-Y

220

220

220

221

221

221

220

221

221

220

221

220

221

221

225

222

222

222

222

220

220

221

221

221

221

221

221

OR-MMFHCDO8X4-Y

OR-MMFHCDOK4X4-Y

OR-MMFHCDOK8X4-Y

OR-MMFHE302X2-Y

OR-MMFHE304X4-Y

OR-MMFHE308X4-Y

OR-MMFHE452X2-Y

OR-MMFHE454X4-Y

OR-MMFHE458X4-Y

OR-MMFHE902X2-Y

OR-MMFHE904X2-Y

OR-MMFHE904X4-Y

OR-MMFHE908X4-Y

OR-MMFHE4512X4-Y

OR-MMFHE9012X4-Y

OR-MMFHEC302X2-Y

OR-MMFHEC304X4-Y

OR-MMFHEC308X4-Y

OR-MMFHEC452X2-Y

OR-MMFHEC454X4-Y

OR-MMFHEC458X4-Y

OR-MMFHEC902X2-Y

OR-MMFHEC904X2-Y

OR-MMFHEC904X4-Y

OR-MMFHEC908X4-Y

OR-MMFHEC4512X4-Y

OR-MMFHEC9012X4-Y

267

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

217

217

217

218

218

218

218

217

218

217

217

217

218

217

218

217

217

217

217

218

218

225

225

225

217

217

217

Part Number Index

OR-MMFHT2X2-Y

OR-MMFHT4X2-Y

OR-MMFHT4X4-Y

OR-MMFHT8X4-Y

OR-MMFHT12X4-Y

OR-MMFHTC2X2-Y

OR-MMFHTC4T8-Y

OR-MMFHTC4X2-Y

OR-MMFHTC4X4-Y

OR-MMFHTC8T4-Y

OR-MMFHTC8X4-Y

OR-MMFHTC12T4-Y

OR-MMFHTC12T8-Y

OR-MMFHTC12X4-Y

OR-MMFJ2X2-Y

OR-MMFJ4X2-Y

OR-MMFJ4X4-Y

OR-MMFJ8X4-Y

OR-MMFJ12X4-Y

OR-MMFJSL4X4-Y

OR-MMFJSL8X4-Y

OR-MMFJSL12X4-Y

OR-MMFL8X4R4X4-Y

OR-MMFLC8X4R4X4-Y

OR-MMFMBOX4812

OR-MMFMMK4

OR-MMFMMK8

212

212

212

212

223

223

219

219

212

212

212

212

230

227

227

219

219

219

219

219

219

218

218

218

218

218

218

OR-MMFMMKEX4

OR-MMFMMKEX8

OR-MMFOT2-Y

OR-MMFOT4-Y

OR-MMFOT8-Y

OR-MMFOT12-Y

OR-MMFR8X4R4X4-Y

OR-MMFRC8X4R4X4-Y

OR-MMFRFPMK

OR-MMFRG10

OR-MMFRMK2

OR-MMFRMK4

OR-MMFRMK8

OR-MMFRMK12

OR-MMFRUNBK2

OR-MMFRUNBK4812

OR-MMFSD2X2-Y

OR-MMFSD4X2-Y

OR-MMFSD4X4-Y

OR-MMFSD8X4-Y

OR-MMFSD12X4-Y

OR-MMFSDC2X2-Y

OR-MMFSDC4X2-Y

OR-MMFSDC4X4-Y

OR-MMFSDC8X4-Y

OR-MMFSDC12X4-Y

OR-MMFSDHC2X2-Y

210

210

210

210

210

210

228

228

228

228

210

210

210

210

210

223

223

228

224

228

228

227

227

224

224

224

224

OR-MMFSDHC4X2-Y

OR-MMFSDHC4X4-Y

OR-MMFSDHC8X4-Y

OR-MMFSDK2X2-Y

OR-MMFSDK4X2-Y

OR-MMFSDK4X4-Y

OR-MMFSDK50DCT-Y

OR-MMFSDK50SCT-Y

OR-MMFSL2X2-Y

OR-MMFSL4X2-Y

OR-MMFSL4X4-Y

OR-MMFSLC2X2-Y

OR-MMFSLC4X2-Y

OR-MMFSLC4X4-Y

OR-MMFSLHC2X2-Y

OR-MMFSLHC4X2-Y

OR-MMFSLHC4X4-Y

OR-MMFST2

OR-MMFST48

OR-MMFSTFO

OR-MMFSTS4X2

OR-MMFSUSK124

OR-MMFSUSK128

OR-MMFSUSK164

OR-MMFSUSK168

OR-MMFSUSK1212

OR-MMFSUSK5812

230

229

230

227

227

227

211

211

211

211

211

230

227

227

227

224

224

211

211

211

211

210

210

210

224

224

224

OR-MMFSUSKNR12

OR-MMFU158MB4812

OR-MMFVE30D2X2-Y

OR-MMFVE30D4X4-Y

OR-MMFVE30D8X4-Y

OR-MMFVE30U4X4-Y

OR-MMFVE30U8X4-Y

OR-MMFVE45D2X2-Y

OR-MMFVE45D4X4-Y

OR-MMFVE45D8X4-Y

OR-MMFVE45D12X4-Y

OR-MMFVE45U2X2-Y

OR-MMFVE45U4X4-Y

OR-MMFVE45U8X4-Y

OR-MMFVE45U12X4-Y

OR-MMFVE90D2X2-Y

OR-MMFVE90D4X2-Y

OR-MMFVE90D4X4-Y

OR-MMFVE90D8X4-Y

OR-MMFVE90D12X4-Y

OR-MMFVE90U2X2-Y

OR-MMFVE90U4X2-Y

OR-MMFVE90U4X4-Y

OR-MMFVE90U8X4-Y

OR-MMFVE90U12X4-Y

OR-MMFVEC30D2X2-Y

OR-MMFVEC30D4X4-Y

215

215

216

216

216

216

214

214

214

215

215

215

216

213

213

213

214

214

214

214

214

227

228

213

213

213

213

OR-MMFVEC30D8X4-Y

OR-MMFVEC30U4X4-Y

OR-MMFVEC30U8X4-Y

OR-MMFVEC45D2X2-Y

OR-MMFVEC45D4X4-Y

OR-MMFVEC45D8X4-Y

OR-MMFVEC45D12X4-Y

OR-MMFVEC45U2X2-Y

OR-MMFVEC45U4X4-Y

OR-MMFVEC45U8X4-Y

OR-MMFVEC45U12X4-Y

OR-MMFVEC90D2X2-Y

OR-MMFVEC90D4X2-Y

OR-MMFVEC90D4X4-Y

OR-MMFVEC90D8X4-Y

OR-MMFVEC90D12X4-Y

OR-MMFVEC90U2X2-Y

OR-MMFVEC90U4X2-Y

OR-MMFVEC90U4X4-Y

OR-MMFVEC90U8X4-Y

OR-MMFVEC90U12X4-Y

OR-MMFVEE90UD4X4-Y

OR-MMFVEE90UD8X4-Y

OR-MMFVER30D4X4-Y

OR-MMFVER30D8X4-Y

OR-MMFVER30U4X4-Y

OR-MMFVER30U8X4-Y

216

216

216

216

216

213

215

215

215

215

216

216

213

213

213

214

214

214

214

214

215

213

213

213

214

214

214

OR-MMFVER45D4X4-Y

OR-MMFVER45D8X4-Y

OR-MMFVER45U2X2-Y

OR-MMFVER45U4X4-Y

OR-MMFVER45U8X4-Y

OR-MMFVER90D2X2-Y

OR-MMFVER90D4X2-Y

OR-MMFVER90D4X4-Y

OR-MMFVER90D8X4-Y

OR-MMFVER90U2X2-Y

OR-MMFVER90U4X2-Y

OR-MMFVER90U4X4-Y

OR-MMFVER90U8X4-Y

OR-MMFVT2X2T2-Y

OR-MMFVT4X2T4-Y

OR-MMFVT4X4T4-Y

OR-MMFVT8X4T4-Y

OR-MMFVT12X4T8-Y

OR-MMFVTC2X2T2-Y

OR-MMFVTC4X2T4-Y

OR-MMFVTC4X4T4-Y

OR-MMFVTC8X4T4-Y

OR-MMFVTC8X4T8-Y

OR-MMFVTC12X4T8-Y

OR-MMFVTR2X2T2-Y

OR-MMFVTR4X4T4-Y

OR-MMFVTR8X4T4-Y

269

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

219

220

220

220

220

220

216

219

219

219

219

219

220

220

220

215

215

215

216

216

216

214

214

215

215

215

215

Part Number Index

OR-MMIPK

OR-MMPDUMBT

OR-MMW12M12-B

OR-MMW19M12-B

OR-MMW26M12-B

OR-MMW122420P-B

OR-MMW122420S-B

OR-MMW122426P-B

OR-MMW122426S-B

OR-MMW192420P-B

OR-MMW192420S-B

OR-MMW192426P-B

OR-MMW192426S-B

OR-MMW262420P-B

OR-MMW262420S-B

OR-MMW262426P-B

OR-MMW262426S-B

OR-MMWBPK

OR-MMWHMBM12-B

OR-P128040HB

OR-P128040HD

OR-P128240HB

OR-P128440HB

OR-P128640HB

OR-P139240HB

OR-P139240HD

OR-P139340HB

114

199

199

199

199

199

114

114

114

114

114

114

198

198

198

114

114

114

114

114

114

134

132

114

114

114

114

OR-P139540HB

OR-P139740HB

OR-P400298HB

OR-P400298HD

OR-P401750H-1D

OR-P401750H-1DB

OR-P406395H

OR-P413511H-TB

OR-P413512H-TB

OR-P413530H-TB

OR-P413531H-TB

OR-P429503H

OR-P820127H

OR-P820127HA

OR-P820147H

OR-P820287H

OR-P820327H

OR-P820367H

OR-P820477H

OR-P820527H

OR-P820527HB

OR-P820547H

OR-P820667HB

OR-P820677HB

OR-P820827HB

OR-P982078HB

OR-P982078HD

OR-P987523H

OR-P987524H

OR-P987525H

OR-P987526H

OR-P987527H

OR-P987528H

OR-P987529H

OR-P987645H

OR-P987649H

OR-P987650H

OR-PCU35

OR-PCU56

OR-PCU152

OR-PCU253

OR-PCU575

OR-PCU1125

OR-PS-1032CN

OR-PS-1224CN

OR-PS-M6X1-50

OR-PS- M6X1CN

OR-PS-M6X1CN

OR-RCBK-6

OR-RECBK-6B

OR-RECBK-12B

OR-RECBK-18B

OR-RECBK-24B

OR-REK-2-3

201

198

198

200

200

200

196

196

196

196

196

196

197

201

201

200

194

194

194

194

201

198

198

200

200

197

197

208

208

208

208

173

115, 173

41, 115

115

173

199

195

195

195

195

199

202

201

201

201

208

208

202

202

202

202

202

202

OR-REK-4-6

OR-RHB-06B

OR-RHB-12B

OR-RRJC-S

OR-RRJC-T

OR-RU-1224CN

OR-RU-M6X1CN

OR-SVMS704

OR-SVMS706

OR-SVMS804

OR-SVMS806

OR-TR6-6B

OR-TR6-12B

OR-TR6-18B

OR-TR6-24B

OR-TR10-6B

OR-TR10-12B

OR-TR10-18B

OR-TR10-24B

OR-TRHR-12B

OR-TRHR-18B

OR-TRP5-CM

OR-TRP8-CM

OR-TRP8-S

OR-TRP11-CM

OR-TRP17-CM

OR-TRT10-6B

OR-TRT10-12B

OR-TRT10-18B

OR-TRT10-24B

OR-TRTC-6B

OR-TRTC-12B

OR-TRTC-12D

OR-TRTC-18B

OR-TRTC-24B

OR-TRTCI-6B

OR-TRTCI-12B

OR-TRTCI-18B

OR-TRTCI-24B

OR-TRTHR-12B

OR-TRTHR-18B

OR-URT10-6B

OR-URT10-12B

OR-URT10-18B

OR-URT10-24B

OR-VCB-93-6H

OR-VCB-93-6L

OR-VCB-93-6U

OR-VCB-93-6UH

OR-VO-84-T3E

OR-VO-84-T3FTE

OR-VO-84-T6E

OR-VO-84-T6FTE

OR-VO-96-T3E

191

194

194

198

198

198

191

191

191

191

191

191

198

198

192

172

149

149

149

149

191

199

200

200

144

152

115, 172

151

151

151

151

150

150

194

194

192

192

192

192

150

150

150

193

193

193

193

193

193

192

192

192

193

193

193

OR-VO-96-T3FTE

OR-VO-96-T6E

OR-VO-96-T6FTE

OR-WA-93

OR-WRTRT-12B

OR-Z4-RR-WC

RADT90KIT

SWK

UFC550KIT

UFS Support Kit

UFS Wire Tray Sections

UFT 90 Kit

Wall Bracket Wired Assembly

271

For additional product availability visit www.legrand.us/ortronics or contact sales at 800-658-4641

235

235

237

233

233

233

240

150

150

150

173

195

172

Cablofil is a registered trademark of Legrand | Cablofil.

Layer Zero, Mighty Mo and Ortronics are all registered trademarks of Legrand | Ortronics.

Legrand is a registered trademark of Legrand.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
