Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Domestic Applications to BS1361 & BS1312

Consumer Unit Fuse Link

240V / 5 - 45 A

Specifications

Description:

Cylindrical Fuse Links for domestic application according to

BS1361

Ratings:

Volts: - 240V

Amps: - 5 - 45A

IR - 16.5kA

Applications:

Protection of domestic distribution systems.

Agency Information:

Approved to BS1361

Catalogue Numbers

Rating

(A)

5

15

20

30

45

Catalogue

Number

C55

C1515

C1520

C3030

C4545

Colour Code

White

Blue

Yellow

Red

Green

BK (Part Number), Unit packing = 100

Unit

Packing

10

Dimensions

Plug Top Fuse Links

240V / 1 - 13A

Specifications

Description:

Cylindrical Fuse links for domestic applications according to BS1362, to be fitted into domestic BS1363 plug top to conform with the requirements of the Plug and Socket Safety Regulations

1995

Ratings:

Volts: - 240V

Amps: - 1 - 13A

IR - 6kA

Applications:

protection of the cables connected to domestic equipment against overloads or small overcurrents.

Agency Information:

BSI Kite Mark, ASTA accreditation (except 1A Fuse), BS1362

RoHS Compliant

Catalogue Numbers

Rating

(A)

1

2

3

5

7

10

13

Catalogue

Number

C180-1A

C180-2A

C180-3A

C180-5A

C180-7A

C180-10A

C180-13A

Colour Code

Black

Black

Red

Black

Black

Black

Black

BK-(Part Number), Unit packing= 100

Unit

Packing

10

Dimensions

Catalogue

Number

C55

C1515

C1520

C3030

C4545

A

5.35

10.2

10.32

12.7

16.67

B

23

26

26

29

35

Catalogue

Number

C180-RatingA

A

6.45

B

25.4

4 For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Offset Bolted Tags

240 - 550V ac / 2 - 32A

Specifications

Description: Fuse Links for general industrial applications with Q1 fusing factor - general purpose (gG) and motor protection (gM) characteristics

Applications:

General Industrial & Motors applications

Ratings:

Volts: - 415 - 550V ac

Amps: - 2 - 32A

IR - 80kA @ 415/550V ac

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986)

RoHS Compliant

NITD

550V ac (gG) / 2 - 32A

415V ac (gM)

AAO

550V ac / 2 - 32A

Catalogue Numbers

Rating (A)

20

25

32

20M25

20M32

32M40

32M50

32M63

2

4

6

10

16

Catalogue

Number

NITD2

NITD4

NITD6

NITD10

NITD16

NITD20

NITD25

NITD32

NITD20M25

NITD20M32

NITD32M40

NITD32M50

NITD32M63

Class BS Ref

Fixing

Centres mm

gG gM

A1 44

Unit

Packing

20

Fuseholders: CAMASTER CM32FC, see page 20

Dimensions

Catalogue Numbers

Rating

(A)

2

4

6

10

16

20

25

32

32M40

32M50

32M63

Catalogue

Number

AAO2

AAO4

AAO6

AAO10

AAO16

AAO20

AAO25

AAO32

AAO32M40

AAO32M50

AAO32M63

Class BS Ref

Fixing

Centres mm

gG gM

A2 73

Unit

Packing

20

Fuseholders: CAMASTER CM32F, see page 20

Dimensions

Part

No

NITD

NITD32M

A

55.0

B

44

Dimensions (mm)

C

34.6

35.6

D

11.2

E

13.8

17.5

F

0.8

1.2

G

14.0

18.5

Part

No

A

AAO

AAO32M

85

Dimensions (mm)

B

73

C D E F

35.5

13.7

54.5

21

14

22.3

1.2

G H J

8.7

8.0

5.5

Data Sheet: 4106

Data Sheet: 4109

For Product Data Sheets, visit www.cooperbussmann.com

5

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Offset Bolted Tags (Cont.../...)

240-550V / 32 - 100A

Specifications

Description:

Fuse Links for general industrial applications with Q1 fusing factor - general purpose (gG) and motor protection (gM) characteristics

Applications:

General Industrial & Motors applications

Ratings:

Volts: - 415 - 550V ac

Amps: - 32 - 100A

IR - 80kA @ 415 / 550V ac

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986) and CSA C22.2 No 106-M 1985

RoHS Compliant

BAO

550V ac / 35-63A

CEO

550V ac / 32-100A

415V ac (gM)

Catalogue Numbers

Rating (A)

35

40

50

63

63M80

63M100

Catalogue

Number

BAO35

BAO40

BAO50

BAO63

BAO63M80

BAO63M100

Class BS Ref

Fixing

Centres mm

gG gM

A3 73

Unit

Packing

20

Fuseholder: CAMASTER CM63F, see page 20

Dimensions

Catalogue Numbers

Rating

(A)

32

40

50

63

Catalogue

Number

CEO32

CEO40

CEO50

CEO63

80

100

CEO80

CEO100

100M125 CEO100M125

100M160 CEO100M160

100M200 CEO100M200

Class BS Ref

gG gM

A4

Fixing

Centres mm

Unit

Packing

94 10

Dimensions

Part

No

BAO

BAO63M

A

87

B C

73 54.5

Dimensions (mm)

D E F

21 22.5

1.2

G

12.7

H

8.0

J

5.5

Part

No

CEO

CEO100M125 &

160

CEO100M200

A B

110 94

Dimensions (mm)

C D E F G H J

21.0 24.5

58.5

25.8 26.8

3.2

14.3 11.0 8.7

47.0 31 29.5

19.0 10.0 9.0

6

Data Sheet: 4112 Data Sheet: 4115

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Offset Bolted Tags (Cont.../...)

240 - 550V ac / 80 - 200A

Specifications

Description:

Fuse Links for general industrial applications with Q1 fusing factor - general purpose (gG) and motor protection (gM) characteristics

Applications:

General Industrial & Motors applications

Ratings:

Volts: - 415 - 550V ac

Amps: - 80 - 200A

IR - 80kA @ 415 / 550V ac

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986)

RoHS Compliant

DEO

415V ac / 125 - 200A (gG) (gM)

OSD

550V ac (gG) / 80 - 100A

415V ac (gM)

Catalogue Numbers

Rating (A)

80

100

100M125

100M160

Catalogue

Number

OSD80

OSD100

OSD100M125

OSD100M160

Class BS Ref

gG gM

N/A

Fixing

Centres mm

73

Fuseholders: CAMASTER CM100F, see page 20

Unit

Packing

20

Dimensions

Catalogue Numbers

Rating (A)

Catalogue

Number

125

160

DEO125

DEO160

200 DEO200

200M250 DEO200M250

200M315 DEO200M315

Class BS Ref

gG gM

N/A

Fixing

Centres mm

Unit

Packing

94 5

Dimensions

Part

No

A

OSD

OSD100M

95.0

B

73

C

54.5

Dimensions (mm)

D E F

21.0

22.5

26.0

25.7

1.2

G

12.7

H

8.0

J

5.5

Part

No

A

DEO

DEO200M

110

B C

Dimensions (mm)

D E F G H J

94 47.0

31.0

29.5

3.2

19.0

10.0

9.0

Data Sheet: 4107 Data Sheet: 4117

For Product Data Sheets, visit www.cooperbussmann.com

7

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Centre Bolted Tags

415 - 550V ac / 2 - 1250A

250V dc

Specifications

Description:

Fuse Links for general industrial applications with Q1 fusing factor - general purpose (gG) and motor protection (gM) characteristics

Applications:

General Industrial & Motors applications

Ratings:

Volts: - 415 - 550V ac / 250V dc

Amps: - 2 - 1250A

IR - 40kA @ 250V dc

- 80kA @ 415 / 550V ac

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986)

RoHS Compliant

AC / BC

550V ac / 2 - 63A

250 V dc (except gM)

Catalogue Numbers

AD / BD / CD / DD / ED

550V ac / 2 - 400A

415V ac (Types gM, DD, ED)

250 V dc (Types AD, BD)

Type

AC

BC

Rating

(A)

2

4

6

10

16

20

25

32

40

50

63

63M80

63M100

Catalogue

Number

AC2

AC4

AC6

AC10

AC16

AC20

AC25

AC32

BC40

BC50

BC63

BC63M80

BC63M100

Class

Fixing Centres mm

Unit

Packing

gG gG gM

97.5

97.5

20

20

Dimensions

Catalogue Numbers

Type

AD

BD

CD

DD

ED

Rating

(A)

63

80

100

100M125

100M160

100M200

125

160

200

200M250

200M315

250

32

40

50

16

20

25

2

4

6

10

315

355

400

315M400

400M500

Catalogue

Number

AD2

AD4

AD6

AD10

AD16

AD20

AD25

AD32

BD40

BD50

BD63

CD80

CD100

CD100M125

CD100M160

CD100M200

DD125

DD160

DD200

DD200M250

DD200M315

ED250

ED315

ED355

ED400

ED315M400

ED400M500*

Class Ref BS

Fixing Centres mm

Unit

Packing

gG gG gG gM gG gM gG gM

N/A

N/A

B1

B2

B3/B4

111

111

111

111

111

20

20

10

5

1

*-550V ac

8

Part

No

AC

AD

BC

BC63M

BD

CD

CD100M125 & CD100M160

CD100M200

DD

DD200M

ED250

ED315

ED315M4009.0

ED400M500

A

113.5

128.5

113.5

128.5

126

136

136

136

B

97.5

111

97.5

111

111

111

111

C

55.5

55.0

55.0

55.0

58.5

47.0

47.0

47.0

50.0

75.0

D

21.0

21.0

21.0

21.0

21.0

26.0

31.0

31.0

31.0

38.0

59.0

Dimensions

E

1.6

1.4

1.6

1.4

3.2

3.2

4.7

Data Sheets: AC: 4110 / BC: 4113 / AD: 4111 / BD: 4114 / CD: 4116 / DD: 4118 / ED: 4119

For Product Data Sheets, visit www.cooperbussmann.com

F

12.7

14.2

7.0

14.2

14.3

19.0

19.0

19.0

25.4

G

13.5

11.8

13.5

11.8

11.1

12.5

12.5

12.5

H

7.0

8.7

12.7

8.7

8.7

9.0

9.0

K

11.2

11.2

11.2

11.2

19.5

22.0

2.5

22.5

22.5

31.0

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Centre Bolted Tags (Cont.../...)

415 - 550Vac / 125 - 1250A

250 - 400Vdc

Specifications

Description:

Fuse Links for general industrial applications with Q1 fusing factor - general purpose (gG) and motor protection (gM) characteristics

Applications:

General Industrial & Motors applications

Ratings:

Volts: 415 - 550V ac / 250V dc

Amps: 2 - 1250A

IR 40kA @ 250V dc GF, GG except 1000 & 1250A

40kA @ 400V dc FG, FF

80kA @ 415/550V ac

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986)

RoHS Compliant

EFS / EF / FF / GF

415V ac / 125 - 800A

550V ac

(Types EF - gM, FF, FG, GF)

250V dc

(Type GF)

Catalogue Numbers

Type

EFS

EF

FF

GF

Rating

(A)

Catalogue

Number

Class

125

160

200

250

315

EFS125

EFS160

EFS200

EFS250

EFS315 gG

355

400

EF355

EF400 gG

400M500 EF400M500 gM

450

500

560

FF400

FF500

FF560 gG

630

710

800

1000

1250

FF630

GF710

GF800

GF1000

GF1250 gG

Ref

BS

N/A

C1

C2

C3

Fixing

Centres mm

Unit

Packing

Interrupting

Rating

133

133/184

133/184

133/184

133/184

1

1

1

1

80kA @

415 Vac

80kA @

415 Vac

80kA @

415 Vac

40kA @

400Vdc

80kA @

550Vac

40kA @

250Vdc

Dimensions

FG / GG / GH

550V ac / 450 - 1250A

250V dc

400V dc

(Type GG 710-800A only)

(Type FG)

Catalogue Numbers

Type

FG

GG

GH

Rating

(A)

450

500

560

630

710

800

1000

1250

710

800

1000

1250

Catalogue

Number

FG450

FG500

FG560

FG630

GG710

GG800

GG1000

GG1250

GH710

GH800

GH1000

GH1250

Class

Fixing

Centres mm

Unit

Packing

gG gG gG

167/231

165/231

165/228.5

149

1

1

1

Interrupting

Rating

80kA @ 550Vac

40ka @ 400vdc

80kA @ 550Vdc

40kA @ 250Vdc

80kA @ 550Vdc

No DC Rating

80kA @ 550Vac

Dimensions

Part No

FG

GF

GG710 & 800

GG1000 & 1250

Dimensions (mm)

A B C D E F G H J

262 231 77.5 10.5 15.5 38.0 167 74 6.4

210 184 80.5 10.5 15.5 25.4 133 83.0

9.5

262

231 77.5

228.5 84.0

10.5 15.5 38.0 165

83.0

6.4

100 12.7

Part No

A B C

EFS315

EF355 & 400

209 184 50.0

Dimensions (mm)

D E F

10.5

12.5

G

25.4 133

H

38.0

J

4.7

EF400M500 210 184 75.0

FF

210

15.5

59.0

184 77.5 10.5 15.5 25.4 133 74.0

6.4

FG

GF

262 231 77.5 10.5 15.5 38.0 167 74 6.4

210 184 80.5 10.5 15.5 25.4 133 83.0

9.5

Part No

A B C

Dimensions (mm)

D E F G H

GH710 & 800

GH1000 & 1250

198 149 81.0 32.0 63.5 19.0 14.0 9.5

J

83.0

100

Data Sheets: FG: 4122 / GG: 4104 / GH: 4108 Data Sheets: EFS: 4121 / EF: 4120 / FF: 4102 / GF: 4103

For Product Data Sheets, visit www.cooperbussmann.com

9

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial & Motor Applications to BS88

Offset Blade Tags

240 - 550V / 2 - 63A

Specifications

Description:

Fuse Links for general industrial applications with Q1 fusing factor general purpose (gG) and motor protection (gM) characteristics.

Ratings:

Volts: - 240V ac (SSD)

- 415V ac (NSD gM) / ESD gG (40 - 63A)

- 550V ac (NSD gG) / ESD gG (2 - 32A)

Amps: - 2 - 63A

IR - 33kA @ 240V ac

- 80kA @ 500V ac

Applications:

General Industrial and Motors applications

Agency Information:

Meets BS88: Part 6, 1988 and

IEC 269: Parts 1, 1986

RoHS Compliant

Dimensions

Part No

SSD

NSD &

NSD20M

NSD20M36 &

NSD32M

ESD - 32A

ESD40 - 63A

ESD63M

A

23.0

34.5

35.5

B

12.0

13.8

Dimensions (mm)

D

47.0

E

13.0

58.5

12.7

17.5

13.8

17.5

21.0

68.0

15.0

F

0.8

0.8

1.2

3.5

N

3.2

3.5

Catalogue Numbers

Rating (A)

16

20

32

2

4

6

10

Catalogue

Number

SSD2

SSD4

SSD6

SSD10

SSD16

SSD20

SSD32

Class

BS

Reference

Fuseholder

Unit

Packing

gG E1 N/A 20

Rating (A)

20

32

20M25

20M32

20M36

32M36

32M40

32M50

32M63

2

4

6

10

16

Catalogue

Number

NSD2

NSD4

NSD6

NSD10

NSD16

NSD20

NSD32

NSD20M25

NSD20M32

NSD20M36

NSD32M36

NSD32M40

NSD32M50

NSD32M63

Class

BS

Reference

Fuseholder

gR gM

F1

SAFELOC

32NNSF

Unit

Packing

20

Rating (A)

10

16

20

2

4

6

32

40

50

63

63M80

63M100

Catalogue

Number

ESD2

ESD4

ESD6

ESD10

ESD16

ESD20

ESD32

ESD40

ESD50

ESD63

ESD63M80

ESD63M100

Class

BS

Reference

Fuse Holder

gG gM

F2

SAFELOC

63ENSF

Unit

Packing

20

10

Data Sheet SSD: 4105

Data Sheet NSD: 4100

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Point of Sale Stand

Merchandising Stand

Specifications

Description:

Merchandising stand with

BS88 fuses packed in packs of 3’s or 10’s

Stand dimensions:

1.88 Metre tall x

0.91 Metre wide x 0.51 Metre deep*

(including hooks)

Please note this stand is for the UK market only

Catalogue Numbers

Part

Number

Part Description

M-AAO10

M-AAO16

M-AAO20

M-AAO25

M-AAO32

M-BAO40

M-BAO50

M-BAO63

M-CD100

M-CEO80

M-CEO100

M-NITD2

M-NITD10

M-NITD16

M-NITD20

M-NITD32

M-C180-3A

M-C180-5A

M-C180-13A

M-NSD4

M-NSD6

M-NSD10

M-NSD16

M-NSD20

10A 550V BS88 Fuse

16A 550V BS88 Fuse

20A 550V BS88 Fuse

25A 550V BS88 Fuse

32A 550V BS88 Fuse

40A 550V BS88 Fuse

50A 550V BS88 Fuse

63A 550V BS88 Fuse

100A 550V BS88 Fuse

80A 550V BS88 Fuse

100A 550V BS88 Fuse

2A 550V BS88 Fuse

10A 550V BS88 Fuse

16A 550V BS88 Fuse

20A 550V BS88 Fuse

32A 550V BS88 Fuse

3A BS1362 Fuse

5A BS1362 Fuse

13A BS1362 Fuse

4A 550V BS88 Fuse

6A 550V BS88 Fuse

10A 550V BS88 Fuse

16A 550V BS88 Fuse

20A 550V BS88 Fuse

M-NSD32

M-NITD6

M-STD6

M-STD10

32A 550V BS88 Fuse

6A 550V BS88 Fuse

6A 240V BS88 Fuse

10A 240V BS88 Fuse

M-32NNSF

M-63ENSF

32A Safeloc Fuseholder

63A Safeloc Fuseholder

M-CM20F 20A Camaster Fuseholder

M-CM32FC

32A Camaster Fuseholder

Compact

M-CM32F 32A Camaster Fuseholder

M-CM63F 63A Camaster Fuseholder

M-CM100F 100A Camaster Fuseholder

3

3

3

3

10

10

3

3

3

10

3

3

3

3

1

1

1

3

3

3

3

Pack Qty

(Nb of fuses per pack)

3

3

3

3

3

3

3

3

3

3

1

1

1

1

30

30

30

30

100

100

30

30

30

30

30

30

30

100

5

5

5

30

30

30

30

Outer box

Qty

(MOQ)

30

30

30

30

30

30

30

30

30

30

5

5

5

5

For Product Data Sheets, visit www.cooperbussmann.com

11

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial Applications to BS88 - 500Vdc

Special DC Range

Offset/Centre Bolted Tag

500Vdc / 10 - 63A

Specifications

Description:

Fuse links for industrial DC applications available in offset and centre bolted tags

Ratings:

Volts: - 500V dc

Amps: - 10 - 63A

IR - 40kA @ 500V dc

Applications:

Protection of DC electrical circuits

Agency information:

ASTA approved to BS88 part 2

RoHS Compliant

Dimensions

Catalogue Numbers

Offset

Bolted

Rating

(A)

73mm

10

16

20

25

32

40

50

63

10HS07

16HS07

20HS07

25HS07

32HS07

40KS07

50KS07

63KS07

Center fixings

Centre Bolted

98mm 111mm

-

-

-

-

-

40KS08

50KS08

63KS08

10KS09

16KS09

20KS09

25KS09

32KS09

40KS09

50KS09

63KS09

Unit

Packing

20

Part No

HS07

KS07

A

86.0

91.0

B

73

C

54.0

Dimensions (mm)

D F

22.0

27.0

0.8

1.2

G

9.2

13.0

H

8.0

10.5

J

5.0

Part No

A

KS08

113.0

KS09

138.0

B

98

111

C

56.0

Dimensions (mm)

D E

27.0

2.5

F

13.0

14.5

G

13.0

15.0

H

5.0

8.0

12

Data Sheet: E5785017

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial Applications to BS88 - 660/690V

Offset Bolted Tags

660-690V / 2 - 200A

Specifications

Description:

Fuse links for industrial applications at 660/690V that meets dimensional and performance requirements of BS88 and IEC 269-1-2 standards

Ratings:

Volts: - 660 / 690V ac

- 250V dc (2 - 63A)

- 400V dc (80 - 200A)

Amps: - 2 - 200A

IR - 80kA @ 660V ac

- 40kA @ 400V dc

Applications:

Protection of large industrial installations at 600/690Vac

Agency information:

Meets BS88: Part 1 & 2 and IEC

269: Parts 1 & 2

RoHS Compliant

Catalogue Numbers

Rating

(A)

32

40

50

63

16

20

25

2

4

6

10

80

100

125

160

200

Catalogue

Number

2H07-660

4H07-660

6H07-660

10H07-660

16H07-660

20H07-660

25H07-660

32H07-660

40K07-660

50K07-660

63K07-660

80L14-660

100L14-660

125M14-660

160M14-660

200M14-660

BS

Reference

Unit

Packing

CAMaster fuseholder

A2

A3

A4

N/A

20

20

10

5

CM32F

CM63F

CM100F

N/A

N/A

Part No

A

H07-660

82.3

B

73

K07-660

86.0

73

L14-660

111.0

94

M14-660

112.0

94

C

52.0

54.2

67.0

66.0

D

22.0

Dimensions (mm)

E

22.4

F

11.5

25.8

35.5

38.0

26.9

37.0

38.0

14.0

19.2

19.0

G

8.7

12.7

19.0

19.0

H

7.7

10.5

10.3

10.0

J

5.4

5.5

8.7

8.5

Data Sheet H07: 4150

Data Sheet K07: 4151

Data Sheet L14: 4152

Data Sheet M14: 4153

For Product Data Sheets, visit www.cooperbussmann.com

13

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial Applications to BS88 - 660/690V

Centre Bolted Tags

660 - 690V ac / 2 - 630A

250 - 400V dc

Specifications

Description:

Fuse Links for industrial applications at 660/690V that meets dimensional and performance requirements of BS88 and IEC 269-1-2 standards.

Ratings:

Volts: - 660 / 690V ac

-

- 250V dc (2 - 63A) (K08, K09)

400V dc (80 - 630A) (L09, M09, N09,

P09, N11, P11, P12, R11, R12)

Amps: - 2 - 630A

IR - 80kA @ 660V ac

- 40kA @ 250V dc/400V dc

Applications:

Protection of large industrial installations at 660/690Vac

Agency Information:

Meets BS88: Part 1 & 2 and IEC

269: Parts 1 & 2

RoHS Compliant

Dimensions

Part

No

A B C

Dimensions (mm)

D E F

K08-660 2-32A

111.0 92.5

53.7

22.0

K08-660

40-63A

111.5 93.0

54.2

25.0

K09-660 2-32A

127.0 111 53.7

22.0

K09-660

40-63A

128.0 111 54.2

25.0

2.4

2.4

12.7

14.0

G

13.0

15.2

H

7.5

8.7

40

50

63

80

100

125

160

200

250

315

355

400

16

20

32

2

4

6

10

125

160

200

250

315

355

400

450

500

560

630

355

400

450

500

560

630

Catalogue Numbers

Rating

(A)

40

50

63

16

20

32

2

4

6

10

Catalogue

Number

2K08-660

4K08-660

6K08-660

10K08-660

16K08-660

20K08-660

32K08-660

40K08-660

50K08-660

63K08-660

BS

Reference

N/A

Fixing

Centres

(mm)

93

2K09-660

4K09-660

6K09-660

10K09-660

16K09-660

20K09-660

32K09-660

40K09-660

50K09-660

63K09-660

80L09-660

100L09-660

125M09-660

160M09-660

200M09-660

250N09-600

315N09-660

355P09-660

400P09-660

125N11-660

160N11-660

200N11-660

250N11-660

315N11-660

355P11-660

400P11-660

450R11-660

500R11-660

560R11-660

630R11-660

355P12-660

400P12-660

450R12-660

500R12-660

560R12-660

630R12-660

N/A

B1

B2

B3

B4

N/A

C1

C2

N/A

111

133

133/184

133/184

167/231

Unit

Packing

20

20

1

1

1

1

Part

No

L09-660

M09-660

A B C

Dimensions (mm)

D E F G H

136.0 111 65.5

35.5

3.2

19.0

15.1

8.7

135.0 111 65.0

37.0

3.2

19.0

15.0

8.7

N09-660

135.0 111 73.0

49.0

3.2

25.4

12.7

9.5

P09-660

135.5 111 75.0

58.5

4.7

25.4

12.7

9.5

N11-660

162.0 133 73.0

49.0

3.2

25.4

15.8

10.5

Dimensions (mm)

Part No

A B C

P11-660

P12-660

R11-660

R12-660

212.0 184 133

262.0 231 167

210.0 184 133

262.0 231 167

D E F G H J

75.0 25.4 16.0 10.0 59.0

5.0

76.0 26.0 16.0 10.0 74.0

6.5

14

Data Sheets: K08: 415 / L09: 4156 / M09: 4157 / N09: 4158 / P09: 4159 / N11: 4160 / P11: 4161 / R11: 4162 / R12: 4162

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Industrial Applications to BS88 - 660/690V

Special Tag Arrangements

660 - 690V / 125 - 800A

Specifications

Description:

Fuse Links for industrial applications at 660/690V that meets dimensional and performance requirements of BS88 and IEC 269-1-2 standards.

Ratings:

Volts: - 660 / 690V ac

(except S20 type - 550V ac)

- 400V dc

(except S20 type)

Amps: - 125 - 800A

IR - 80kA @ 660V ac

- 40kA @ 400V

(except S20 type)

Applications:

Protection of large industrial installations at 600 / 690Vac

Agency Information:

BS88 part 1 section 2-1 & 2-2

RoHS Compliant

Dimensions

Offset Bolted Tag

Catalogue Numbers

Tag Types

Offset Bolted

Tag

Centre Bolted

Tag

Special Offset

Tag

Rating (A)

450

500

125

160

200

250

250

315

250

315

355

400

315

125

160

200

125

160

200

250

315

355

400

450

500

560

630

710

800

250N15

315N15

250N34

315N34

355P35

400P35

450R40

500R40

125N20

160N20

200N20

250N20

Catalogue

Number

125M13

160M13

200M13

250M13

315M13

125M23

160M23

200M23

315N20

355P20

400P20

450R20

500R20

560R20

630R20

710S20

800S20

Fixing Centres

(mm)

Unit Packing

99

231

100

113

133/184

133/184

92.5

92.5

94

94

5

1

1

1

1

1

1

1

1

1

Centre Bolted Tag

Part

No

A B C

M13 120.0 99.0

70.0

Dimensions (mm)

D E F

M23 262.0 231.0 167.0

38.0

27.0

38.5

8.0

19.0

N15 120.0 100.0 79.0

49.0

41.0

16.5

Special Tag Arrangement

G

26.0

H

12.0

14.0

15.0

J

8.7

9.8

Part

No

A B C

Dimensions (mm)

D

N34 135.0

111 74.5

66.5

E

5.0

F

25.4

G

12.5

H

9.5

Dimensions (mm)

Part

No

A

N20 110.0

P20 111.0

R20 112.0

S20 112.0

B

92.0

94.0

C

75.0

76.0

77.0

77.0

D

22.0

E

44.5

F

8.8

G

49.0

H

49.0

47.0

59.0

62.0

74.0

66.0

83.0

J

6.4

Part

No

P35

R40

A

210.0

B

184

C

133

Dimensions (mm)

D

75.0

81.0

E

19.0

F

16.0

G

10.0

H

59.0

74.0

Data Sheets: M13 & M23: 4153 / N15: 4164 / N34: 4165 / P35: 4161 / R40: 4162 / N20: 4166 / P20: 4167 / R20: 4168 / S20: E5785045

J

5.0

9.5

For Product Data Sheets, visit www.cooperbussmann.com

15

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Street Lighting Applications to BS88

Offset Bolted Tags

240 - 550V / 2 - 32A

Specifications

Description:

Fuse Links for general street lighting applications with Q1 fusing factor - general purpose (gG)

Applications:

Street lighting applications

SMD

415V ac (gG) / 2 - 32A

Ratings:

Volts: - 240 - 415V ac

Amps: - 2 - 32A

IR - 33kA @ 240V ac (STD)

- 80kA @ 415 / 550V ac (SMD)

Agency information:

Meets BS88: Part 1 & 2 (1988),

IEC 269: Parts 1 (1986)

RoHS Compliant

STD

240V ac /2 - 32A

Catalogue Numbers

Rating (A)

10

16

20

25

32

2

4

6

Part

Reference

SMD2

SMD4

SMD6

SMD10

SMD16

SMD20

SMD25

SMD32

Unit

Packing

20

Catalogue Numbers

Rating

(A)

2

4

6

10

16

20

25

32

Part

Reference

STD2

STD4

STD6

STD10

STD16

STD20

STD25

STD32

Unit

Packing

20

Dimensions Dimensions

Part

No

SMD

A

29.0

Dimensions (mm)

B

-

C

-

D

12.7

Also available as Offset Bladed Tags “SSD”, see page 10

Part

No

STD

Dimensions (mm)

A B C D E F G H

47.0 35 24.0 11.0 4.7 12.0 0.8 13.0

16

Data Sheet: 4123

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Utility Applications to BS88

House Service Cut-Out Fuse Links

415V / 5 - 100A

Specifications

Description:

Cylindrical Fuse Links for electrical utilities to BS Standard

Ratings:

Volts: - 415V

Amps: - 5 - 100A

IR - 33kA @ 415V

Applications:

Fuses to use in connection with House

Service cut-outs.

Agency Information:

ASTA certified and tested in accordance to BS 1361

RoHS Compliant

20

25

30

40

5

10

15

45

50

60

70

80

90

100

Catalogue Numbers

Catalogue Number

Rating

(A)

22mm

5KR85

10KR85

15KR85

20KR85

25KR85

30KR85

40KR85

45KR85

50KR85

60KR85

70KR85

80KR85

90KR85

100KR85

Diameter

30mm

-

-

-

-

-

30LR85

40LR85

-

50LR85

60LR85

-

80LR85

-

100LR85

Unit Packing

20

Dimensions

KR85 Type

J Type Fuse Links to BS88: Part 5

Cylindrical Type

415V / 20 - 250A

Specifications

Description:

Cylindrical type fuses designed for use with wedge type fuse carriers on

BS applications

Ratings:

Volts: - 415V

Amps: - 20 - 250A

IR - 80kA @ 415V

Applications:

For use by Electrical Authorities in distribution pillars, open type substation boards, heavy duty cut-outs, and underground connection boxes. Cylindrical type to be used in pole or wall mounted outdoor service fuse units.

Agency information:

ASTA certifed and tested to

BS88: Part 5

RoHS Compliant

Catalogue Numbers:

Rating

(A)

80

100

125

160

200

250

20

32

40

63

Catalogue Number

20MJ25-6

32MJ25-6

40MJ25-6

63MJ25-6

80MJ25-6

100MJ25-6

125MJ25-6

160MJ25-6

200MJ25-6

250MJ25-6

Unit

Packing

20

Dimensions

LR85 Type

Data Sheet KR85: 4185

Data Sheet LR85: 4186

Data Sheet: 4177

For Product Data Sheets, visit www.cooperbussmann.com

17

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Utility Applications to BS88

J Type Fuse Links to BS88: Part 5

Slotted/Non Slotted Types

415V / 20 - 800A

Specifications

Description:

Slotted type fuses designed for use with wedge type fuse carriers on BS applications

Ratings:

Volts: - 415V

Amps: - 20 - 630A (Slotted Type)

800A (Non Slotted Type)

IR - 80kA @ 415V

Applications:

For use by Electrical Authorities in distribution pillars, open type substation boards, heavy duty cut-outs, and underground connection boxes.

Agency information:

ASTA certified and tested BS88:

Part 5

RoHS Compliant

Catalogue Numbers

Rating

(A)

76mm

-

-

-

-

-

63MJ29-6

80MJ29-6

100MJ29-6

-

160MJ29-6

200MJ29-6

250MJ29-6

-

-

-

-

-

-

-

-

100

125

160

200

250

315

20

25

32

40

50

63

80

355

400

450

500

560

630

800

Slotted

Fixing Center

82mm

-

-

32MJ30-8

40MJ30-8

50MJ30-8

63MJ30-8

80MJ30-7

100MJ30-7

125MJ30-7

160MJ30-7

200MJ30-7

250MJ30-7

315MJ30-7

355PJ30-7

400PJ30-7

-

-

-

-

-

92mm

20MJ31-8

25MJ31-8

32MJ31-8

40MJ31-8

50MJ31-8

63MJ31-8

80MJ31-7

100MJ31-7

125MJ31-7

160MJ31-7

200MJ31-7

250MJ31-7

315MJ31-7

355PJ31-7

400PJ31-7

450RJ31-7

500RJ31-7

560SJ31-6

630SJ31-6

Non

Slotted

Unit

Packing

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

-

800SJ28

10

Dimensions

Type

MJ30-8

MJ30-7 (Up to 200A)

MJ30-7 (315-400A)

MJ31-7 (Up to 200A)

MJ31-7 (315-400A)

PJ30-7

PJ31-7

RJ31-7

SJ31-6

SJ28

A

110

110

110

131

131

110

131

131

128.5

128.5

B

82

82

82

92

92

82

92

92

92

92

C

45.2

45.2

44.8

46.8

46.4

44.8

46.4

D

40.5

40.5

40

40.5

40

40

40

45

44.5

44.5

E

30

30

30

41

41

30

41

38

38.1

38.1

F

14.8

14.8

14.4

17.4

17.4

14.4

17.4

16.5

16.5

16.5

G

17.5

17.5

17.5

20.7

20.7

17.5

20.7

15.5

20.6

20.5

H

9.8

9.8

9.8

10.9

10.2

9.8

10.2

10.9

11

I

30.9

30.9

38

30.8

38.1

38

38.1

49.1

73.3

73.3

J

2.4

2.4

2.4

3.2

3.2

2.4

3.2

3.2

3.2

3.2

K

6.45/6.53

6.45/6.53

6.45/6.53

8.05/8.73

8.05/8.73

6.45/6.53

8.05/8.73

8.05/8.73

8.05/8.73

8.05/8.73

Slotted Type (MJ31-7 up to 200A)

18

Data Sheets: MJ30-8: 4178A / MJ30-7: 4178B / MJ31-7 or 8: 4180 / PJ31: 4181 / RJ: 4182 / SJ: 4183

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Joint NATO Reference System

Cylindrical/Offset Bolted Tag

440V / 0.25 - 150A

Specifications

Description:

Cylindrical Fuse links originally developped for the Admiralty but are now used in a wide variety of applications

Ratings:

Volts: - 440V

Amps: - 0.25 - 100A (Cylindrical)

- 0.5 - 150A (Offset Bolted Tag)

IR - 33kA @ 440Vac

Applications:

defence, aeronautical, allied industries, electronics

Agency information:

Defence standard 59-96

(superceding DEF 63). Tested to BS88 at 440V/33kA

RoHS Compliant

Dimensions

Cylindrical

Catalogue Numbers

Size

0

1

2

3

Rating

(A)

40

50

60

10

15

20

30

7

10

15

20

30

40

50

80

100

125

160

0.5

1

2

3

5

3

5

7

10

15

0.25

0.5

1

2

Cylindrical

059-0107

059-0108

059-0109

059-0110

059-0111

059-0112

059-0113

059-9925

059-9926

059-0140

059-0141

059-0142

059-0143

059-0144

059-0145

059-0146

059-0147

011-9483

059-0148

059-0149

059-0150

059-0151

059-0152

059-0153

059-0154

059-0155

Offset Bolted

Unit

Packing

N/A

059-0114

059-0115

059-0116

059-0117

059-0118

059-0119

059-0120

059-0121

011-9679

012-0140

059-0122

059-0123

059-0124

059-0125

059-0067

011-9127

012-0141

059-0126

059-0127

059-0128

059-0129

011-9128

011-9129

100

25

25

25

Size

0

1

2

3

Offset Bolted Tag

A

32.05

33.6

37.6

47.9

D

6.37

11.86

16.7

33.3

B

5.55

7.14

8.71

11.9

Size

1

2

3

A

56.03

70.7

88.6

B

44.65

55.84

69.77

C

33.9

37.4

47.4

D

11.96

16.7

33.3

Data Sheets: size 0: 4188/ size 1: 4189 / size 2: 4190 / size 3: 4191

For Product Data Sheets, visit www.cooperbussmann.com

19

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

20

Low Voltage Fuse Links Catalogue

BS88 Fuseholders

CM

CAM

ASTER

HRC Fuseholder

690V ac / 20 - 400A

Specifications

Description:

Fully shrouded fuse bases with unique cam action system for BS88

Fuse link applications.

Ratings:

Volts: - 660V ac

Amps: - 20, 32 (Compact) 32, 63 and 100A

Applications:

Lighting and heating equipment, circuit protection, Motor protection, Control equipment circuit protection

Agency Information:

CE Compliance to BS88, EN

IEC 60269. For UL and CSA approved versions also available,consult Cooper Bussmann

®

RoHS Compliant

Dimensions

Cat. No

Max cable mm

2

A

Dimensions (mm)

B C D E F G H J K

CM20F 16 25.4 93.7

60 3.2 17.5 66.0 58.0 28.6 11.9 M6

CM32FC 16 25.4 93.7

60 3.2 17.5 66.0 58.0 28.6 11.9 M6

CM32F 16 31.8 117.5 60 3.2 17.5 66.0 74.0 28.6 11.9 M6

CM63F 70 35.6 125 60 4.75 16.4 86.5 81.0 28.6 11.9 M8

CM100F 70 35.6 125 60 4.75 16.4 86.5 81.0 28.6 11.9 M8

200DF 95 70 193 149 17.5 35.6

8 138 30 24 M12

400EF 240 98.4 254 192.1 31.8 36.5

-

Catalogue Numbers

Rating

(A)

20

32

32

63

100

200*

400*

Catalogue

Number

CM20F

CM32FC

CM32F

CM63F

CM100F

200DF

200DFBS

Front/Back

200DBS

Back/Back

400EF

Recommended

Fuse Link

NITD

NITD

AAO

BAO

OSD

DD

ED

* 200A & 400A do not have the CAM action

Accesories Numbers

Accessory

Back Stud

Rating (A)

32

32

63/100

Ganging Links

Neon Indicator

Lockable Safety

Carriers

90-415V ac

Neutral Links

32

32

63/100

Security Clip

Unit

Packing

10

10

10

10

5

Catalogue No

32BSC

32BS

63/100BS

GLP

NI

32LSCC

32LSC

63/100LSC

32CMLC

32CML

63/100CML

CMSC

Unit

Packing

10

10

5

1 set

3

3

3

3

1

20

Notes:

1 - Type CM32FC is also available rated at 20A, catalogue number CM20F

2 - For colours other than Black (standard) add the appropriate letter code: W = White; G = Green,

GY = Grey

3 - Care must be taken when fitting solid single or stranded cables of small cross-sectional area to ensure correct clamping. Small Multi-stranded cables must be terminated with bootlace ferrules to ensure correct clamping. Bootlace ferrules should not be used on standard power cables or high current applications. If in doubt please consult Cooper

Bussmann

®

4 - A +5% tolerance should be allowed on dimensions when cutting metal work to fit CAMaster fuse holders

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

BS88 Fuseholders

NNS, ENS

Safeloc Fuseholder

660V ac / 32 - 63A

Specifications

Description:

Fuseholder to be used with

BS88 Fuse links for bolted panel mounting or DIN rail.

Ratings:

Volts: - 550V ac, 415V ac (63A)

Amps: - 32, 63A

Applications:

Lighting and heating equipment, circuit protection, Motor protection, Control equipment circuit protection

Agency Information:

CE Compliance to BS88, EN

IEC 60269

RoHS Compliant

Dimensions

Catalogue Numbers

Rating

(A)

32

63

Catalogue

Number

Available Variants

32NNSF

32NNSBS

32NNSFBS

32NNL

63ENSF

63ENSBS

63ENSFBS

Front connected/

Front connected

Back stud/

Back stud

Front connected/

Back stud

Neutral links

Front connected/

Front connected

Back stud/

Back stud

Front connected/

Back stud

63ENL Neutral links

Required

Fuse Link

NSD

ESD

Unit

Packing

10

10

10

10

5

5

5

1

Notes:

1 - For colours other than Black (standard), add the appropriate letter code: W = White, G = Green, GY = Grey, at the end of the catalogue reference.

2 - Security seal (ref. 32551) available for 32A Safeloc

3 - Care must be taken when fitting solid single or stranded cables of small cross-sectional area to ensure correct clamping. Small Multi-stranded cables must be terminated with bootlace ferrules to ensure correct clamping. Bootlace ferrules should not be used on standard power cables or high current applications. If in doubt please consult Cooper

Bussmann

®

4 - A +5% tolerance should be allowed on dimensions when cutting metal work to fit Safeloc fuse holders

Rating

(A)

Part

No

Max

Cable mm

2

A B C D

Dimensions (mm)

E F G H J K

32 NNS 16 25.4 80.3 48.5

2.3

16.0 39.2 57.7 17.0

9.7

M6

63 ENS 35 29.1 90.0 55.0

3.3

17.7 75.0 67.9 39.2 11.0

M8

For Product Data Sheets, visit www.cooperbussmann.com

21

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Cylindrical Domestic Fuses

Class gG (gF)

250 - 400V / 0.5 - 32A

Sizes: 6x23, 8x23, 10x25

8x31, 10x31, 8x36

10x38

Specifications

Description:

Cylindrical fuses for domestic protection.

Available in types with and without striker indicator.

Ratings:

Volts: - 250V ac (6x23, 8x23, 10x25)

400V ac (8x31, 10x31, 8x36, 10x38)

Amps: - 0.5 - 32A

IR - 6kA (6x23, 8x23, 10x25)

- 20kA (8x31, 10x31, 8x36, 10x36)

Applications:

Protection of power lines, heating circuits, lighting circuits. electrical domestic appliances and domestic electricity meters

Agency Information:

NF C 62203, EN IEC 60269-3,

NF marking (see references in bold in catalogue numbers chart)

RoHS Compliant

Dimensions

Size

6 x 23

8 x 23

8 x 31

8 x 36

10 x 25

10 x 31

10 x 38

A

6.3

8.5

8.5

8.5

10.3

10.3

10.3

B

23

23

31.5

36

25.8

31.5

38

C

5

5

6.3

6.3

6.3

6.3

10

Catalogue Numbers

Size

6x23

8x23

10x25

8x31

Currrent

(A)

6

10

16

6

8

10

12

0.5

1

2

4

16

20

2

4

6

10

16

2

4

6

10

References without

Indicator

CD0623G2

CD0623G4

CD0623G6

CD0623G10

CD0823G2

CD0823G4

CD0823G6

CD0823G10

CD0823G16

CD1025G6

CD1025G10

CD1025G16

CD0831G0.5

CD0831G1

CD0831G2

CD0831G4

CD0831G6

CD0831G8

CD0831G10

CD0831G12

CD0831G16

CD0831G20

References with

Indicator

Voltage

(V)

250V

CD0823G2I

CD0823G4I

CD0823G6I

CD0823G10I

CD0823G16I

CD1025G6I

CD1025G10I

CD1025G16I

-

-

CD0831G2I

CD0831G4I

CD0831G6I

CD0831G8I

CD0831G10I

CD0831G12I

CD0831G16I

CD0831G20I

250V

250V

400V

Interrupting

Rating

(kA)

6kA

6kA

6kA

20kA

UP*

10

10

10

10

10x31

8x36

10x38

16

20

25

2

4

6

10

16

20

25

32

25

32

CD1031G16

CD1031G20

CD1031G25

CD0836G2

CD0836G4

CD0836G6

CD0836G10

CD0836G16

CD0836G20

CD0836G25

CD0836G32

CD1038G25

CD1038G32

CD1031G16I

CD1031G20I

CD1031G25I

CD0836G2I

CD0836G4I

CD0836G6I

CD0836G10I

CD0836G16I

CD0836G20I

CD0836G25I

CD0836G32I

CD1038G25I

CD1038G32I

400V

400V

400V

20kA

20kA

20kA

10

12

10

*UP = Unit Packing

NFC 60203

22

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Domestic Fuses

AD

440V ac / 15 - 90A

Sizes: 10x38, 14x51,

22x58 (cylindrical fuses)

00 (Knife fuses)

Catalogue Numbers

Size

Current

(A)

Catalogue

Number

Voltage

(V)

Unit

Packing

10x38

14x51

22x58

0

15

30

30

45

60

90

15

30

45

60

CA10D15

CA14D30

CA22D15

CA22D30

CA22D45

CA22D60

30NH00AD

45NH00AD

60NH00AD

90NH00AD

440V

440V

10

3

Specifications

Description:

fuse cartridge type AD for fitting to circuit breakers on low-voltage branch circuits.

Ratings:

Volts: - 440V ac

Amps: - 15 - 60A (Cylindrical fuses)

- 30 - 90A (Fuse size 00)

IR - 20kA (size 10x38)

- 32kA (size 14x51, 22x58, 00)

Applications:

Fitting for circuit breakers in public branch panels

Agency Information:

Conform to standards NF C 62-

921, EN IEC 60269

RoHS Compliant

Dimensions

Sizes

10x38

14x51

22x58

A

10.3

14.3

22.2

B

38

51

58

C

10

13

16

For Product Data Sheets, visit www.cooperbussmann.com

23

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Cylindrical Industrial Fuses

Class gG

400 - 690V / 0.5 - 125A

Sizes: 8x31, 10x38,

14x51, 22x58

Specifications

Description:

Cylindrical fuses for gG Industrial protection (general applications). Available with or without indicators and visual fuse activation indicator. Striker fitted to activate an auxiliary contact.

Ratings:

Volts: - 400, 500, 690V ac

Amps: - 0.25 - 125A

IR - 20kA - 400V ac (size 8 x 31)

- 120kA - 400 and 500V ac

- 80 kA - 690V ac

Applications:

Protection of electrical distribution circuits and electrical appliances (with the exception of electrical motors)

Agency Information:

EN IEC 60269

RoHS Compliant

Dimensions

D E Size

8 x 31

10 x 38

14 x 51

22 x 58

A

8.5

10.3

14.3

22.2

B

31.5

38

51

58

C

6.3

10

13

16

8

8

4

4

Catalogue Numbers

Size

8 x 31

10 x 38

14 x 51

22 x 58

Current

(A)

References without

Indicator

References with Indicator

References with

Striker

8

10

12

2

4

6

12

16

20

25

32

32

40

50

2

16

20

25

16

20

0.5

8

10

12

4

6

1

2

8

10

0.5

1

2

4

6

40

50

63

20

25

32

10

12

16

4

6

8

80

100

125

Voltage

(V)

C10G12

C10G16

C10G20

C10G25

C10G32

C14G2

C14G4

C14G6

C14G8

C14G10

C14G12

C08G0.5

C08G1

C08G2

C08G4

C08G4

C08G8

C08G10

C08G12

C08G16

C08G20

C10G0.5

C10G1

C10G2

C10G4

C10G6

C10G8

C10G10

C14G16

C14G20

C14G25

C14G32

C14G40

C14G50

C22G2

C22G4

C22G6

C22G8

C22G10

C22G12

C22G16

C22G20

C22G25

C22G32

C22G40

C22G50

C22G63

C22G4I

C22G6I

C22G8I

C22G10I C22G10S

C22G12I C22G12S

C22G16I

C22G20I

C22G25I

C22G32I

C22G4S

C22G6S

C22G8S

C22G16S

C22G20S

C22G25S

C22G32S

C22G40I C22G40S

C22G50I C22G50S

C22G63I C22G63S

690V

C22G80 C22G80I C22G80S

C22G100 C22G100I C22G100S

500V

C22G125 C22G125I C22G125S 400V

-

-

C08G2I

C08G4I

C08G4I

C08G8I

C08G10I

C08G12I

C08G16I

C08G20I

-

-

C10G2I

C10G4I

C10G6I

C10G8I

C10G10I

C10G12I

C10G16I

C10G20I

C10G25I

C10G32I

C14G2I

C14G4I

C14G6I

C14G2S

C14G4S

C14G6S

C14G8I C14G8S

C14G10I C14G10S

C14G12I C14G12S

400V

500V

400V

690V

C14G16I C14G16S

C14G20I C14G20S

C14G25I C14G25S

C14G32I C14G32S

C14G40I C14G40S

500V

C14G50I C14G50S 400V

C22G2I

Disconnection power (kA)

UP*

20kA

120kA

80kA

120kA

80kA

120kA

10

10

10

10

*UP: Unit Packing

24

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Cylindrical Industrial Fuses

Class aM

400 - 690V / 0.16 - 125A

Sizes: 8 x 31, 10 x 38,

14 x 51, 22 x 58

Specifications

Description:

Cylindrical fuses for aM industrial protection range (protection of motors).

Available in types without indicators, with visual fuse activation indicator and plunger for activation of an auxiliary contact.

Ratings:

Volts: - 440, 500, 690V ac

Amps: - 0.16 - 125A

IR - 20kA - 400V ac (size 8 x 31)

120kA - 400 and 500V ac

80kA - 690Vac

Applications:

Direct protection of motors

Agency information:

Conform to standard EN IEC

60269

RoHS Compliant

Dimensions

Size

8 x 31

10 x 38

14 x 51

22 x 58

A

8.5

10.3

14.3

22.2

B

31.5

38

51

58

C

6.3

10

13

16

D

8

8

E

4

4

Catalogue Numbers

Size

8 x 31

10 x 38

14 x 51

22 x 58

Current

(A)

References without

Indicator

References with Indicator

References with striker

Voltage

(V)

Disconnection power (kA)

10

32

40

50

63

12

16

20

25

80

100

125

4

6

8

1

2

C8M1

C8M2

C8M4

C8M6

C8M8

10 C8M10

0.16

C10M0.16

0.25

C10M0.25

0.5

1

2

4

6

8

10

C10M0.5

C10M1

C10M2

C10M4

C10M6

C10M8

C10M10

8

10

12

16

20

25

32

40

4

6

8

50

2

12

16

20

2

4

6

C10M12

C10M16

C10M20

25

32

C10M25

C10M32

0.25

C14M0.25

0.5

C14M0.50

1 C14M1

C14M2

C14M4

C14M6

C14M8

C14M10

C14M12

C14M16

C14M20

C14M25

C14M32

C14M40

C14M50

C22M2

C22M4

C22M6

C22M8

C8M1I

C8M2I

C8M4I

C8M6I

C10M16I

C10M20I

C10M25I

-

-

C8M10I

-

-

-

C10M1I

C10M2I

C10M4I

C10M6I

C10M8I

C10M10I

C10M12I

N/A

N/A

C14M1I

C14M2I

C14M4I

C14M6I

C14M2S

C14M4S

C14M6S

C14M8I C14M8S

C14M10I C14M10S

C14M12I C14M12S

C14M16I C14M16S

C14M20I C14M20S

400V

500V

400V

500V

C14M25I C14M25S

C14M32I C14M32S

C14M40I C14M40S

C14M50I C14M50S 400V

C22M2I

C22M4I

C22M6I

C22M8I

C22M10 C22M10I

C22M12

C22M16

C22M20

C22M25

C22M32

C22M40

C22M50

C22M63

C22M12I

C22M16I

C22M20I

C22M25I

C22M32I

C22M40I

C22M50I

C22M63I

C22M16S

C22M20S

C22M25S

C22M32S

C22M40S

C22M50S

C22M63S

690V

C22M80 C22M80I C22M80S

C22M100 C22M100I C22M100S

500V

C22M125 C22M125I C22M125S 400V

20kA

120kA

120kA

80kA

120kA

UP*

10

10

10

10

*UP: Unit Packing

Neutral Cartridges

8 x 31

10 x 38

14 x 51

22 x 58

Neutral

C8NL

C10NL

C14NL

C22NL

For Product Data Sheets, visit www.cooperbussmann.com

25

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Modular Domestic Fuse Holders

CHD

250 - 400V / 10 - 32A

Sizes: 8x23, 10x25, 8x31

10x31, 10x38

Specifications

Description:

Fuse Holder for domestic cylindrical fuses. Secured to DIN rail and available with light indicator for active fuse function. Range as single-pole and single-pole plus neutral in one module.

Ratings:

Volts: - 250V ac (8x31, 10x25)

- 400V ac (8x31, 10x31, 10x38)

Amps: - 10 - 32A

IR - 6kA (6x23, 8x23, 10x25)

- 20kA (8x31, 10x31, 8x36, 10x38)

Applications:

Protection for power lines, heating circuits, lighting circuits. electrical domestic appliances and domestic electricity meters

Agency Information:

NF C 62203, EN IEC 60269-3,

NF marking on all models

Catalogue Numbers

Size

Rating

(A)

Voltage

(V)

8x23 10 250

Single Pole Single Pole + Neutral with

Indicator without

Indicator with

Indicator

UP without

Indicator

CHD8231D CHD8231DI CHD8231DN CHD8231DNI 12

10x25 16 250 CHD10251D CHD10251DI CHD10251DN CHD10251DNI 12

8x31 20

10x31 25

10x38 32

Neutral 32

400

400

CHD8311D CHD8311DI CHD8311DN CHD8311DNI 12

400 CHD10311D CHD10311DI CHD10311DN CHD10311DNI 12

400 CHD1038D CHD1038DI CHD1038DN CHD1038DNI 12

CHDND 12

UP: Unit Packing

26

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Cylindrical Industrial Fuses

CHM

690V / 25 - 32A

Sizes: 8x31, 10x38

Specifications

Description:

Fuse Holder for cylindrical industrial fuses. Secured to

DIN rail and available with and without light indicator for active fuse function. Range as multi-pole and single-pole plus neutral fuse holders in one module. Accessories for the assembly of modules.

Ratings:

Volts: - 690V ac

Amps: - 25 - 32A

Applications:

Protection of industrial electrical distribution circuits and electrical appliances

Agency Information:

EN IEC 60269-3, EN IEC 60947

Dimensions

Catalogue Numbers

Size Poles

8 x 31

Neutral

1P

1P + N

1P + N

2P

3P

3P + N

3P + N

4P

Neutral

1P

1P + N

10 x 38

1P + N

2P

3P

3P + N

3P + N

4P

No of

Modules

1

1

4

1

3

3

4

2

2

3

3

4

4

1

1

1

2

2

References without

Indicator

CHMDNX

CH081D

References with

Indicator

-

CH081DI

CH081DNS CH081DNSI

CH081DN CH081DNI

CH082D CH082DI

Current

(A)

Voltage

(V)

Unit

Packing

25A 690V

12

12

12

6

6

CH083D CH083DI

CH083DNS CH083DNSI

CH083DN CH083DNI

CH084D

CHMDNX

CH084DI

-

CHM1D CHM1DI

CHM1DNS CHM1DNSI

CHM1DN

CHM2D

CHM3D

CHM1DNI

CHM2DI

CHM3DI

CHM3DNS CHM3DNSI

CHM3DN CHM3DNI

CHM4D CHM4DI

32A 690V

4

3

3

3

12

12

12

4

4

3

6

6

4

Catalogue Number

Description

Clips for assembly of multi-pole fuse holders

Multi phase handle pin connector

Size

8 x 31 - 10 x 38 -

14 x 51 - 22 x 58

References

AL-D

8 x 31 - 10 x 38 CH810-HP

Unit

Packing

12

12

For Product Data Sheets, visit www.cooperbussmann.com

27

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Cylindrical Industrial Fuses

CH

690V / 50 - 125A

Sizes: 14 x 51, 22 x 38

Specifications

Catalogue Numbers

Size Poles

References with auxiliary contact

Nb of

Modules

References without

Indicator

References with

Indicator Fuse response/ presence and pre-disconnect

Fuse response

Current

(A)

Voltage

(V)

UP*

Description:

Fuse Holders for cylindrical industrial fuses. Secured to DIN rail and screwed. Available with and without light indicator for active fuse function and with auxiliary contact for use with plunger fuses.

The auxiliary contact is available in two versions: one for the detection of fuse actuation and pre-disconnected, and the other fuse actuation only.

14 x 51

Neutral

1P

1P + N

2P

3P

1.5

1.5

3

3

4.5

CH141DNX

CH141D

CH141DN CH141DNI

CH142D

CH143D

CH142DI

-

CH141DI CH141DMS-F

-

-

CH143DI CH143DMS-F

-

CH141DMS

-

-

CH143DMS

50A 690V

6

6

3

3

2

3P + N 6 CH143DN CH143DNI CH143DNMS-F CH143DNMS 1

Ratings:

Volts: - 690V ac

Amps: - 25 - 32A

4P

Neutral

6

2

CH144D

CH221DNX

CH144DI -

-

1

6

1P 2 CH221D CH221DMS 6

Applications:

Protection of industrial circuits and electrical appliances.

22 x 58

1P + N

2P

4

4

CH221DN

CH222D

-

125A 690V

3

3

Agency Information:

EN IEC 60269-3, EN IEC 60947

3P 6 CH223D CH223DMS 2

3P + N 8 CH223DN CH22MDNMS 1

Dimensions

4P

*UP: Unit Packing

8 CH224D 1

14 x 51

Catalogue Numbers

Description

Clips for assembly of multi-pole fuse holder

Multi phase handle Pin connector

Auxiliary contact for fuse response - 1 pole

Auxiliary contact for fuse response - 3 pole

*UP: Unit Packing

Size

8x31, 10x38, 14x51,

14x51

14x51

14x51

Ref UP*

AL-D

CH14-P

CH14MS-1D

CH14MS-3D

12

12

5

2

22 x 58

28 For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses - Dual Indicator

Class gG - Low Power Loss

400V / 2 - 630A

Sizes 000, 00, 01, 1, 02, 2,

03, 3

Specifications

Description:

Low Power Loss NH Fuses for industrial protection, gG range (general protection). Dual Indicator system for fuse operation function

(in the body and in the side plate). Version with voltage free metal gripping lugs for insulated fuses. The components used are lead and cadmium free. Fuses subject to HRC recycling commitment.

Ratings:

Volts: - 400V ac

Amps: - 2 - 630A

IR - 120kA - 400V ac

Applications:

Protection of large electric distribution networks, cables and distribution boards where the minimization of power losses is a requirement. Electrical utilities and electrical distribution networks

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620, VDE approval.

Dimensions:

see page 35

Catalogue Numbers

Size

000

0

01

1

02

2

03

3

250

35

40

50

63

80

125

160

200

224

160

35

40

50

63

80

100

35

40

50

63

20

25

32

80

100

125

2

4

6

10

16

315

355

400

250

315

355

400

500

630

100

125

160

200

224

250

Rated

Current

(A) gG-gL

Dual Indicator voltage conducting gripping lugs voltage free metal gripping lugs

2NHG000B-400

4NHG000B-400

2NHG000BI-400

4NHG000BI-400

6NHG000B-400 6NHG000BI-400

10NHG000B-400 10NHG000BI-400

16NHG000B-400 16NHG000BI-400

20NHG000B-400 20NHG000BI-400

25NHG000B-400 25NHG000BI-400

32NHG000B-400 32NHG000BI-400

35NHG000B-400 35NHG000BI-400

40NHG000B-400 40NHG000BI-400

50NHG000B-400 50NHG000BI-400

63NHG000B-400 63NHG000BI-400

80NHG000B-400 80NHG000BI-400

100NHG000B-400 100NHG000BI-400

125NHG00B-400 125NHG00BI-400

160NHG00B-400 160NHG00BI-400

35NHG01B-400 35NHG01BI-400

40NHG01B-400

50NHG01B-400

40NHG01BI-400

50NHG01BI-400

63NHG01B-400

80NHG01B-40

63NHG01BI-400

80NHG01BI-400

100NHG01B-400 100NHG01BI-400

125NHG01B-400 125NHG01BI-400

160NHG01B-400 160NHG01BI-400

200NHG1B-400

224NHG1B-400

200NHG1BI-400

224NHG1BI-400

250NHG1B-400

35NHG02B-400

40NHG02B-400

50NHG02B-400

63NHG02B-400

80NHG02B-400

250NHG1BI-400

35NHG02BI-400

40NHG02BI-400

50NHG02BI-400

63NHG02BI-400

80NHG02BI-400

100NHG02B-400 100NHG02BI-400

125NHG02B-400 125NHG02BI-400

160NHG02B-400 160NHG02BI-400

200NHG02B-400 200NHG02BI-400

224NHG02B-400 224NHG02BI-400

250NHG02B-400 250NHG02BI-400

315NHG2B-400

355NHG2B-400

400NHG2B-400

315NHG2BI-400

355NHG2BI-400

400NHG2BI-400

250NHG03B-400 250NHG03BI-400

315NHG03B-400 315NHG03BI-400

355NHG03B-400 355NHG03BI-400

400NHG03B-400 400NHG03BI-400

500NHG3B-400

630NHG3B-400

500NHG3BI-400

630NHG3BI-400

Unit

Packing

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Data Sheets: 720097 / 720099

For Product Data Sheets, visit www.cooperbussmann.com

29

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses - Dual Indicator

30

Class gG - Low Power Loss

500V / 2 - 1600A

Sizes C00, 0, 1, 2, 3, 4, 4A

Specifications

Description:

Low Power Loss NH Fuses for industrial protection, gG range (general protection). Dual Indicator system for fuse operation function (in the body and in the side plate) except for the sizes 4 & 4A. Version with voltage free metal gripping lugs for insulated fuses. The components used in manufacture are lead and cadmium free. Fuses subject to HRC recycling commitment.

Ratings:

Volts: - 500V ac

Amps: - 2 - 1600A

IR - 120kA - 500V ac

- 50kA - 250V dc

Applications:

Protection of large electric distribution networks, cables and distribution boards (except motors) where the minimize of power losses is a requirement.

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620, VDE approval.

Dimensions:

see page 35

Data Sheets: 2142

Catalogue Numbers

Size

000

00

0

01

1

02

2

03

3

4

Slotted

End Tags

4A

None

Slotted

End Tags

Rated

Current

(A) gG-gL

Dual Indicator voltage conducting gripping lugs

2NHG000B

100NHG01B

125NHG01B

160NHG01B

200NHG1B

224NHG1B

250NHG1B

35NHG02B

40NHG02B

50NHG02B

63NHG02B

80NHG02B

100NHG02B

125NHG02B

160NHG02B

200NHG02B

224NHG02B

250NHG02B

315NHG2B

355NHG2B

400NHG2B

32NHG0B

35NHG0B

40NHG0B

50NHG0B

63NHG0B

80NHG0B

100NHG0B

125NHG0B

160NHG0B

10NHG01B

16NHG01B

20NHG01B

25NHG01B

32NHG01B

35NHG01B

40NHG01B

50NHG01B

63NHG01B

80NHG01B

250NHG03B

315NHG03B

355NHG03B

400NHG03B

500NHG3B

630NHG3B

500NHG4G

630NHG4G

800NHG4G

1000NHG4G

1250NHG4G

630NH4AG

800NH4AG

900NH4AG

1000NH4AG

1250NH4AG

1600NH4AG

4NHG000B

6NHG000B

10NHG000B

16NHG000B

20NHG000B

25NHG000B

32NHG000B

35NHG000B

40NHG000B

50NHG000B

63NHG000B

80NHG000B

100NHG000B

125NHG00B

160NHG00B

10NHG0B

16NHG0B

20NHG0B

25NHG0B

voltage free metal gripping lugs

2NHG000BI

100NHG01BI

125NHG01BI

160NHG01BI

200NHG1BI

224NHG1BI

250NHG1BI

35NHG02BI

40NHG02BI

50NHG02BI

63NHG02BI

80NHG02BI

100NHG02BI

125NHG02BI

160NHG02BI

200NHG02BI

224NHG02BI

250NHG02BI

315NHG2BI

355NHG2BI

400NHG2BI

-

-

-

-

-

-

-

-

-

10NHG01BI

16NHG01BI

20NHG01BI

25NHG01BI

32NHG01BI

35NHG01BI

40NHG01BI

50NHG01BI

63NHG01BI

80NHG01BI

250NHG03BI

315NHG03BI

355NHG03BI

400NHG03BI

500NHG3BI

630NHG3BI

-

-

-

-

-

-

-

-

-

-

-

4NHG000BI

6NHG000BI

10NHG000BI

16NHG000BI

20NHG000BI

25NHG000BI

32NHG000BI

35NHG000BI

40NHG000BI

50NHG000BI

63NHG000BI

80NHG000BI

100NHG000BI

125NHG00BI

160NHG00BI

-

-

-

-

100

125

160

200

224

250

315

355

400

100

125

160

200

224

250

35

40

50

63

80

40

50

63

80

20

25

32

35

63

80

100

125

32

35

40

50

160

10

16

1250

630

800

900

1000

1250

1600

250

315

355

400

500

630

500

630

800

1000

2

63

80

100

125

160

10

16

20

25

20

25

32

35

40

50

4

6

10

16

Unit

Packing

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses - Dual Indicator

Class gG

690V / 2 - 630A

Sizes 000, 00, 0, 1, 2, 3

Specifications

Description:

NH Fuses for gG range industrial protection (general protection). Double indicator system for fuse operation (in the body and in the side plate). Version with voltage free metal gripping lugs for insulated fuses. The components used in manufacture are lead and cadmium free. Fuses subject to HRC recycling commitment.

Ratings:

Volts: - 690V ac

Amps: - 2 - 630A

IR - 120kA - 690V ac

Applications:

Protection of electrical distribution circuits, cables and electrical appliances (with the exception of motors).

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620.

Dimensions:

see page 35

Catalogue Numbers

Size

000

00

0

1

2

3

200

63

80

100

125

160

50

63

80

100

125

160

200

224

250

315

250

315

355

400

500

630

32

35

40

16

20

25

80

100

6

10

50

63

80

100

20

25

32

35**

2

4

6

10

16

40

50

63

Rated

Current

(A) gG - gL

Dual Indicator voltage conducting gripping lugs

50NHG1B-690

63NHG1B-690

80NHG1B-690

100NHG1B-690

125NHG1B-690

160NHG1B-690

200NHG1B-690

63NHG2B-690

80NHG2B-690

100NHG2B-690

125NHG2B-690

160NHG2B-690

200NHG2B-690

224NHG2B-690

250NHG2B-690

315NHG2B-690

250NHG3B-690

315NHG3B-690

355NHG3B-690

400NHG3B-690

500NHG3B-690

-

2NHG000B-690

4NHG000B-690

6NHG000B-690

10NHG000B-690

16NHG000B-690

20NHG000B-690

25NHG000B-690

32NHG000B-690

35NHG000B-690

40NHG000B-690

50NHG00B-690

63NHG00B-690

80NHG00B-690

100NHG00B-690

6NHG0B-690

10NHG0B-690

16NHG0B-690

20NHG0B-690

25NHG0B-690

32NHG0B-690

35NHG0B-690

40NHG0B-690

50NHG0B-690

63NHG0B-690

80NHG0B-690

100NHG0B-690

voltage free metal gripping lugs

50NHG1BI-690

63NHG1BI-690

80NHG1BI-690

100NHG1BI-690

125NHG1BI-690

160NHG1BI-690

200NHG1BI-690

63NHG2BI-690

80NHG2BI-690

100NHG2BI-690

125NHG2BI-690

160NHG2BI-690

200NHG2BI-690

224NHG2BI-690

250NHG2BI-690

315NHG2BI-690

250NHG3BI-690*

315NHG3BI-690*

355NHG3BI-690*

400NHG3BI-690*

500NHG3BI-690*

-

2NHG000BI-690

4NHG000BI-690

6NHG000BI-690

10NHG000BI-690

16NHG000BI-690

20NHG000BI-690

25NHG000BI-690

32NHG000BI-690

35NHG000BI-690

40NHG000BI-690

50NHG00BI-690

63NHG00BI-690

80NHG00BI-690

100NHG00BI-690

-

-

-

-

-

-

-

-

-

-

-

-

Unit

Packing

3

3

3

3

3

3

* Contact Cooper Bussmann for availibility

** Interrupting Rating for the 35 A size 000 is 80kA

For Product Data Sheets, visit www.cooperbussmann.com

31

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses - Dual Indicator

Class aM

500 - 690V / 2 - 630A

Sizes 000, 00, 0, 1, 2, 3A

Specifications

Description:

NH Fuses for aM range industrial protection (general protection). Double indicator system for fuse operation (in the body and in the side plate). Version with voltage free metal gripping lugs for insulated fuses.

The components used in manufacture are lead and cadmium free. Fuses subject to HRC recycling commitment.

Ratings:

Volts: - 690V ac

Amps: - 25 - 32A

IR - 80 kA - 500Vac (sizes 000,00 - up to 100A)

- 120kA - 500Vac/690Vac

Applications:

Protection of electrical motors.

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620.

Dimensions:

see page 35

Catalogue Numbers

Size

000

00

0

1

2

3

35

40

50

63

80

100

50

63

80

100

160

6

10

16

20

25

32

16

20

25

32

35

40

50

2

4

6

10

160

200

224

250

63

80

63

80

100

125

315

355

400

250

315

355

400

500

630

100

125

160

200

224

250

Rated

Current

(A) aM

Dual Indicator voltage conducting gripping lugs

-

-

6NHM000B-690

10NHM000B-690

16NHM000B-690

20NHM000B-690

25NHM000B-690

32NHM000B-690

35NHM000B-690

40NHM000B-690

50NHM00B

63NHM00B

80NHM00B

100NHM00B

160NHM00B

6NHM0B

10NHM0B

16NHM0B

20NHM0B

25NHM0B

32NHM0B

35NHM0B

40NHM0B

50NHM0B

63NHM0B

80NHM0B

100NHM0B

-

63NHM1B-690

80NHM1B

100NHM1B

125NHM1B

160NHM1B

200NHM1B

224NHM1B

250NHM1B

-

-

-

125NHM2B-690

160NHM2B-690

200NHM2B-690

224NHM2B-690

250NHM2B-690

315NHM2B-690

355NHM2B-690

400NHM2B

-

315NHM3B-690

355NHM3B-690

400NHM3B-690

500NHM3B-690

630NHM3B

voltage free metal gripping lugs

-

-

6NHM000BI-690

10NHM000BI-690

16NHM000BI-690

20NHM000BI-690

25NHM000BI-690

32NHM000BI-690

35NHM000BI-690

40NHM000BI-690

50NHM00BI

63NHM00BI

80NHM00BI

100NHM00BI

160NHM00BI

-

-

-

-

-

-

-

-

-

-

-

-

-

63NHM1BI-690

80NHM1BI

100NHM1BI

125NHM1BI

160NHM1BI

200NHM1BI

224NHM1BI

250NHM1BI

-

-

-

125NHM2BI-690

160NHM2BI-690

200NHM2BI-690

224NHM2BI-690

250NHM2BI-690

315NHM2BI-690

355NHM2BI-690

400NHM2BI

-

315NHM3BI-690

355NHM3BI-690

400NHM3BI-690

500NHM3BI-690

630NHM3BI

Unit

Packing

3

3

3

3

3

3

32 For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses

Class aM

500V / 2 - 630A

Sizes C00, 0, 1, 2, 3

Specifications

Description:

NH Fuses for aM range industrial protection (general protection). Indicator for fuse activation in the side panel.

The components used in manufacture are lead and cadmium free. Fuses subject to HRC recycling commitment.

Ratings:

Volts: - 500V ac

Amps: - 2 - 630A

IR - 120kA - 500Vac

- 50kA - 250V dc

Applications:

Protection of direct starter motors

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620.

Dimensions:

see page 35

Catalogue Numbers

Size

C00

00

0

1

2

3

Voltage conducting gripping lugs

2NHC00M

4NHC00M

6NHC00M

10NHC00M

16NHC00M

20NHC00M

25NHC00M

32NHC00M

40NHC00M

50NHC00M

63NH00M

80NH00M

100NH00M

125NH00M

160NH00M

32NH0M

50NH0M

63NH0M

80NH0M

100NH0M

125NH0M

160NH0M

40NH1M

50NH1M

63NH1M

80NH1M

100NH1M

125NH1M

160NH1M

200NH1M

250NH1M

100NH2M

125NH2M

160NH2M

200NH2M

250NH2M

315NH2M

355NH2M

400NH2M

315NH3M

400NH3M

500NH3M

630NH3M

Disconnect

Power

(kA)

120kA

120kA

120kA

120kA

120kA

120kA

Rated current

(A)

50

63

80

100

125

160

40

63

80

100

125

160

32

32

40

50

16

20

25

2

4

6

10

160

200

250

315

355

400

315

400

500

630

50

63

80

100

125

160

200

250

100

125

Unit

Packing

3

3

3

3

3

3

For Product Data Sheets, visit www.cooperbussmann.com

33

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses with Striker

Class gG - aM

500 - 690V / 63 -1250A

Sizes 1, 2, 3, 4

Specifications

Description:

NH Fuses for industrial applications class gG and aM with integrated side striker for visual or remote indication of the fuse status. To be used with NH fuse holders fitted with micro-switch.

Ratings:

Volts: - 500V ac Size 4

- 690V ac Size 1,2,3

Current - 63A - 1250A

IR - 120kA - 500V ac

- 80kA - 690V ac

Applications:

Protection of electrical distribution circuits (Class gG) and motor protection (Class aM)

Standards and Approvals:

Conform to standards EN IEC

60269, VDE 0636, DIN 43620.

Catalogue Numbers

Size

1

2

3

4

400

315

355

400

500

630

500

630

800

1000

1250

200

224

250

125

160

200

224

250

315

355

63

80

100

125

160

Rated

Current

(A) gG aM

Voltage conducting metal gripping lugs

Voltage conducting metal gripping lugs

63NHG1BS-690*

80NHG1BS-690*

63NHM1BS-690*

80NHM1BS-690*

100NHG1BS-690* 100NHM1BS-690*

125NHG1BS-690* 125NHM1BS-690*

160NHG1BS-690* 160NHM1BS-690*

200NHG1BS-690* 200NHM1BS-690*

224NHM1BS-690*

250NHM1BS-690*

125NHG2BS-690* 125NHM2BS-690*

160NHG2BS-690* 160NHM2BS-690*

200NHG2BS-690* 200NHM2BS-690*

224NHG2BS-690* 224NHM2BS-690*

250NHG2BS-690* 250NHM2BS-690*

315NHG2BS-690* 315NHM2BS-690*

355NHM2BS-690*

-

315NHG3BS-690*

400NHM2BS-690*

-

355NHG3BS-690* -

400NHG3BS-690* 400NHM3BS-690*

500NHG3BS-690* 500NHM3BS-690*

630NHG3BS-690* 630NHM3BS-690*

500NH4G-S -

630NH4G-S

800NH4G-S

1000NH4G-S

1250NH4G-S -

-

-

-

Pack

Qty

3

3

3

3

* Contact Cooper Bussmann for availibility

34

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuses - Dimensions

Knife Fuses (NH)

Size a a1

1

02

2

000

00

0

01

03

3

4a

4a -1600A

150±2.5

150±2.5

200

200

78.5±1.5

78.5±1.5

125±2.5

135±2.5

135±2.5

150±2.5

150±2.5

75

75

75

75

a2

(max)

54

54

68

75

75

84

84

a3 a4

45±1.5

45±1.5

62±

+3/

-1.5

62±2.5

49±1.5

49±1.5

68±

+1.5/

-3

68±2.5

62±2.5

62±2.5

62±2.5

68±2.5

68±2.5

68±2.5

62±2.5

62±2.5

80

80

68±2.5

68±2.5

90

90

15

20

20

25

b

(rated)

15

15

15

25

32

50

50

c1(±8)

40

48

48

35

35

35

40

60

60

85

85

11

11

11

11

c2

(rated)

10

11

11

11

11

D

(rated)

2±0.5

2±0.5

2.5±0.5

2.5±0.5

2.5±0.5

2.5±0.5

2.5±0.5

2.5±0.5

3±0.5

3

3

48

53

53

61

e1

(max)

48

48

48

61

76

102

102

30

52

52

60

e2

(max)

30

30

30

60

60

87

87

25

25

25

25

e3

(max)

25

25

25

25

25

6

6

6

6

e4

(rated)

6

6

6

6

6

f (max)

15

15

15

15

15

15

15

15

18

30

30

For Product Data Sheets, visit www.cooperbussmann.com

35

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuse Holders for Knife Fuses

SB-D, SB-S, SB-DMS

690V / 160 - 1600A

Sizes 00, 0, 1, 2, 3, 4

Specifications

Description:

Knife fuses, NH, thermoplastic bodies for knife fuses. Securing to DIN rail and by screws (size 4 screw fixation only). Range of protection accesories for live parts in order to obtain IP20 protection standard. Available with micro- switch contact for use with fuses with striker (see page 30).

Ratings:

Volts: - up to 690V ac

Amps: - 2 - 1600A

Applications:

Protection of industrial circuits and electrical apparatus

Standards and Approvals:

IEC 60269, VDE 0636, DIN

43620

Dimensions

Size

NH00

NH0

NH1

NH2

NH3

NH4

Catalogue Numbers

Size

00

0

1

2

3

4

Poles

1

3

1

3

1

3

1

3

1

3

1

160A

160A

Part References

Current

(A)

Screw connection

DIN Rail connection

SB00-S

TB00-S

SB00-D

TB00-D

TB00-D-IP20

SB0-S

TB0-S

SB0-D

TB0-D

With microswitch contact

SB0-DMS

UP*

3

1

1

3

1

250A

400A

630A

SB1-S

TB1-S

SB2-S

TB2-S

SB3-S

TB3-S

SB1-D

TB1-D

SB2-D

TB2-D

SB3-D

TB3-D

SB1-DMS

SB2-DMS

SB3-DMS

3

1

3

1

3

1

1600A SB4-S SB4-DMS 3

Neutral

Size

NH00

NH0

NH1

NH2

NH3

NH4

Current

(A)

Part Ref

Unit

Packing

160

160

250

400

630

1000

SL00

SL0

SL1

SL2

SL3

SL4

3

Fuse extraction handle

Size

C00-3

Part Ref

Unit

Packing

FEH 1

Protection accessories

Current

(A)

Separation Partition

4

Part

Ref

Unit

Packing

Fuse Cover

5

Part

Ref

Unit

Packing

Terminal Cover

1

Part

Ref

Unit

Packing

160A

160A

250A

400A

630A

1250A

SP00

SP0

SP1-2

SP1-2

SP3

SP4

2

2

2

2

2

2

FC00

FC0

FC1

FC2

FC3

3

3

3

3

3

CS00

CS0

CS1

CS2

CS3

6

6

6

6

6

Separator

3

Part

Ref

Unit

Packing

BC00

BC0

BC1-2

BC1-2

BC3

2

2

2

2

2

IP Protection Kits

TB00-D-IP20

FPK0-3P

FPK1-3P

FPK2-3P

FP3K-3P

Complete triple pole fuse base IP20 rated

IP20 kit for TB0-D fuse base

IP20 kit for TB1-D fuse base

IP20 kit for TB2-D fuse base

IP20 kit for TB3-D fuse base

36

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Dimensions for Knife Fuse and Fuseholders (NH)

Knife Fuseholders (NH)

Bases for fuseholders size 00

Bases for fuseholders size 0, 1, 2, 3, 4

Size

NH0

NH1

NH2

NH3

A

170

200

225

240

B

150

175

200

210

C

47

60

60

60

D

24

28

32

38

E

122

148

148

148

F

63

77.5

88

97

G

63

35

35

35

H

29

80

80

80

I

74

192

192

224

J

48.5

66

66

82

K

91.5

123

123

143

L

185

250

250

270

M

MB

M10

M12

M12

N

25

25

25

25

O

-

30

30

30

P

7.5

10.5

10.5

10.5

Q

15

20.5

20.5

20.5

Bases for fuse holders size 4

For Product Data Sheets, visit www.cooperbussmann.com

37

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Dimensions for Knife Fuses and Fuseholders NH

Knife Fuseholders (NH)

Bases for fuseholders with micro circuit-breaker

Size

NH0

NH1

NH2

NH3

NH4

A

90

98

102

102

140

B

193

215

227

235

284

C

65.5

76

76

76

113

38 For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuse Rail

Vertical Style

BFRD

690V / 250-630A

Sizes 1, 2, 3

Specifications

Description:

Vertical Fuse Rails are designed to be used with NH Fuses. Fully protected against accidental contacts.

Main features are:

- Contact covers

- Inter polar barriers

- Label for protected circuit identification

- Busbar mounting with screws

Ratings:

Volts: - 690V ac

Amps: - 250 - 630A

Applications:

Disconnecting cabinets and low voltage distribution switchboards with busbar spacing of 185mm

Standards and Approvals:

CE, IEC EN 60269-1, IEC EN

60269-3-1

Dimensions:

Catalogue Numbers

Size

1

2

3

Rating

(A)

250

400

630

Part Reference

BFR1-3K/LM/C (*)

BFR1-3K/LW

BFR1-3K/LL

BFR2-3K/LM/C (*)

BFR2-3K/LW

BFR2/3K/LL

BFR3-3K/LM/C (*)

BFR3-3K/LW

BFR3-3K/LL

Leading out Terminals

Pressed-in Nuts with M10 Screw

V-Shaped Clamps

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with M12 bolts

Pressed-in Nuts with M10 Screw

V-Shaped Clamps

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with M12 bolts

Pressed-in Nuts with M10 Screw

V-Shaped Clamps

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with M12 bolts

(*) with Leading-out Terminal cover

For Product Data Sheets, visit www.cooperbussmann.com

39

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuse Switch Disconnectors

Vertical Style

BFD

690V / 250 - 630A

Sizes 1, 2, 3A

Specifications

Description:

Vertical Fuse Switch disconnectors are designed to be used with NH Fuses.

Enabling safe connection and disconnection operations.

Main features are:

- Measuring holes in the fuse cover

- Possibility to lock the fuse cover

- Label for protected circuit identification

- Busbar mounting with screws.

Ratings:

Volts: - 690V ac

Amps: - 250 - 630A

Utilization

- 400V ac - AC23B category

- 690V ac - AC22B

Applications:

Distribution and Industrial switchboards with busbar spacing of 185mm

Approvals:

CE, IEC EN 60947-1, IEC EN 60947-3

Dimensions:

Catalogue Numbers

Size

Rating

(A)

Part Reference

1 Pole

Switching

3 Poles

Switching

1 250 BFD1-31/LM BFD1-33/LM

BFD1-31/LW BFD1-33/LW

Terminals

Pressed-in Nuts with M10

Screw

V-shaped Clamps

2

BFD1-31/LL BFD1-33/LL

400 BFD2-31/LM BFD2-33/LW

BFD2-31/LW BFD2-33/LW

Switch Disconnector for

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with

M12 bolts

Pressed-in Nuts with M10

Screw

V-Shaped Clamps

3

BFD2-31/LL BFD2-33/LL

630 BFD3-31/LM BFD3-33/LM

Switch Disconnector for

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with

M12 bolts

Pressed-in Nuts with M12

Screw

BFD3-31/LW BFD3-33/LW

BFD3-31/LL BFD3-33/LL

V-Shaped Clamps

Switch Disconnector for

Busbar Systems

185mm Busbar Spacing

Connects to Busbar with

M12 bolts

* UP = Unit Packing

UP*

1

1

1

1

1

1

1

1

1

40

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

NH Fuse Switch Disconnectors

Horizontal Style

BFH

690V / 160 - 1600A

Sizes 000, 00, 1, 2, 3, 4A

Specifications

Description:

Horizontal Switch disconnectors are designed to be used with NH Fuses.

Enabling safe connection and disconnection operations.

Main features are:

- Measuring holes in the fuse cover

- Possibility to lock the fuse cover

- Label for protected circuit identification

- Panel mounting with screws. On 35mm DIN Rail (only size

000)

Ratings:

Volts: -

690V ac / 250V dc (sizes 1,2,3) /

400V dc (size 000)

Amps: - 160 - 1600A

Utilization

- 400V ac - AC23B category

- 500V ac - AC22B

- 690V ac - AC21B

- 250V dc - DC21B (sizes 1,2,3)

- 250V dc - DC22B (sizes 000, 00)

- 440V dc - DC20B

Applications:

Industrial control panels, motor control panels

Approvals:

CE, IEC EN 60947-1, IEC EN 60947-3

Dimensions:

Catalogue Numbers

2

3

Size

Rating

(A)

Catalogue Number

Terminals

1 Pole 3 Poles

000 160 BFH000-1A/T BFH000-3A/T

Terminal Clips for 1.5- to

50mm 2 cable

UP*

1

00 160 BFH00-1A/F BFH00-3A/F Terminal Screw M8 1

1 250 BFH1-1A/F BFH1-3A/F Terminal Screws M10 1

400

630

4A 1600

BFH2-1A/F

BFH3-1AF

LBS4/1

BFH2-3A/F

BFH3-3A/F

LBS4/3

Terminal Screws M10

Terminal Screws M12

1

1

Terminal Screws 2xM12 1

* UP = Unit Packing

For Product Data Sheets, visit www.cooperbussmann.com

41

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

DO Fuses

Class gG

400V / 2 - 100A

Sizes D01, D02, D03

Specifications

Description:

DO fuses, gG range, for industrial and domestic protection. All the fuses incorporate a visual display of fuse actuation. Additional range of fuse holders and accesories.

Ratings:

Volts: - 690V ac

Amps: - 160 - 1600A

IR - 50kA - 400V ac

Applications:

Protection of electrical distribution circuits, cables and electrical apparatus (with the exception of motors).

Standards and Approvals:

IEC 60269, VDE 0636,

Dimensions

D01

D02

In(A)

2

4

6

10

16

A

7.3

7.3

7.3

8.5

9.7

Catalogue Numbers

Size

Current

(A)

Colour

Code

Part Ref

Voltage

(V)

Disconnection

Power

(kA)

Unit

Packing

DO1

DO2

2

4

6

10

16

20

25

35

50

63

DO3

80

100

Pink

Brown

Green

Red

Grey

Blue

Yellow

White

Black

Copper

2NZ01

4NZ01

6NZ01

10NZ01

16NZ01

20NZ02

25NZ02

35NZ02

50NZ02

63NZ02

400V

400V

Silver

Red

80NZ03

100NZ03

400V

100kA

100kA

100kA

10

10

10

In(A)

20

25

35

50

63

A

10.9

12.1

13.3

14.5

15.9

D03

In(A)

80

100

A

21.4

21.4

42 For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

DO Fuseholders

FN C , TFN C, FRN C, TFRN C

400V / 16 - 100A

Sizes D01, D02, D03

Specifications

Description:

DO fuse carriers in ceramic bodies with versions for securing to DIN rail or screw connection.

Complete range of accessories.

Ratings:

Volts: - 400V ac

Amps: - 16 - 100A

Applications:

Protection of industrial circuits and electrical apparatus.

Standards and Approvals:

IEC 60269, VDE 0636,

Dimensions

Catalogue Numbers

Size

Current

(A)

Part Ref

Screw Connection

Single

Pole

Three

Pole

Part Ref

DIN Rail

Connection

Single

Pole

Three

Pole

Unit

Packing

DO1

DO2

16A

63A

FN01C

FN02C

TFN01C

TFN02C

FRN01C

FRNC02C

TFRN1C

TFRN2C

15/5

(Three

Pole)

15/5

(Three

Pole)

Size

DO1

DO2

A

53

57

Accessories

Accessories

Fuse

Carrier

Gauge/

Calibration ring

Size

DO1

DO2

DO1

DO2

Covers

DO1 1 pole

DO2 1 pole

DO1 3 pole

DO2 3 pole

Current

(A)

Fuse Base

Type

References

Unit

Packing

16

63

16

20

25

35

50

16

63

16

63

2

4

6

10

E14

E18

E14

E18

E14

E18

E14

E18

CN01

CN02

2GN01

4GN01

6GN01

10GN01

16GN02

20GN02

25GN02

35GN02

50GN02

SFPCDO1

SFPCDO2

TFPCDO1

TFPCDO2

20

50

50

30

For Product Data Sheets, visit www.cooperbussmann.com

43

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

D Fuses

Class gG

500V / 2 - 200A

Sizes: DI, DII, DIII, DIV, DV

Catalogue Numbers

Specifications

Description:

D fuses, gG range, for industrial and domestic protection. All the fuses incorporate a visual display of fuse actuation. Additional range of fuse holders and accesories.

Ratings:

Volts: - 690V ac

Amps: - 2 - 200A

IR - 50kA - 500V ac

Applications:

Protection of electrical distribution circuits, cables and electrical apparatus (with the exception of motors).

Standards and Approvals:

IEC 60269, VDE 0636,

Dimensions

Size

Current

(A)

Colour

Code

References

Voltage

(V)

Disconnection

Power

(kA)

Unit

Packing

DI

DII

DIII

2

4

6

10

16

20

25

2

4

6

10

16

20

25

35

50

63

Pink

Brown

Green

Red

Grey

Blue

Yellow

Pink

Brown

Green

Red

Grey

Blue

Yellow

Black

White

Copper

2D16

4D16

6D16

10D16

16D16

20D16

25D16

2D27

4D27

6D27

10D27

16D27

20D27

25D27

500V

500V

35D33

50D33

63D33

500V

100kA

100kA

100kA

10

10

10

DIV

80

100

Silver

Red

80D125

100D125

500V 100kA 10

Int

(A)

10

16

20

25

2

4

6

A

13.2

B

8

10

12

14

6

6

6

Int

(A)

35

50

A

27

27

B

16

16

Int

(A)

10

16

20

25

2

4

6

A

21.5

B

8

10

12

14

6

6

6

Int

(A)

35

50

63

A

27

27

27

B

16

16

18

44

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

D Fuseholders

SFD, TFD, SFRD C , TFR

500V / 25 - 63A

Sizes: DII, DIII

Catalogue Numbers

Size

Current

(A)

DI

DIII

25A

63A

Part Ref

Screw Connection

Single

Pole

Part Ref

DIN Rail Connection

Three Pole Single Pole Three Pole

SFD27

SFD33

TFD27

TFD33

SFRD27

SFRD33

Unit Packing

TFRD27

TFRD33

15/4

(Three Terminal)

15/6

(Three Terminal)

Specifications

Description:

D fuse carriers in ceramic bodies with versions for securing to DIN rail or screw connection.

Complete range of accessories.

Ratings:

Volts: - 500V ac

Amps: - 25 - 63A

Applications:

Protection of industrial circuits and electrical apparaturs.

Standards and Approvals:

IEC 60269, VDE 0636,

Dimensions

Accessories

Accessories Size

Fuse Carrier

Gauge/

Calibration

Ring

Covers

DII

DIII

DII

DIII

DII 1 pole

DIII 1 pole

DII 3 pole

DIII 3 pole

25A

63A

2

4

6

10

16

20

25

35

50

63

25

63

25

63

Current

(A)

Fuse Base

Type

References

Unit

Packing

E27

E33

E27

E33

E27

E33

E27

E33

CD27

CD33

2GD27

4GD27

6GD27

10GD27

16GD27

20GD27

25GD27

35GD33

50GD33

63GD33

SFPRD27

SFPRD27

TFPCD27

TFPCD33

50

30

50

50

30

Size A B C D E F

DII 41 39 44 47 60 62

DIII 43 47 44 47 56 79

Size

DII

DIII

A B C

41 121 44

43 148 44

D

47

47

E

60

56

F

30

32

G

4.3

4.3

H

50

62

Size

DII

DIII

A

E

E

B

44

44

C

12

12

D

34

43

1 Pole A

DII

DIII

40

49

B C D

24 10.8

80

21 9 80

3 Pole A

DII

DIII

121

148

B C D

24 10.8

80

21 9 80

For Product Data Sheets, visit www.cooperbussmann.com

45

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Other Low Voltage Fuse Ranges

North American Standard Fuses and

Holders

Specifications

Description:

Round fuses and holders in accordance with

North American standards. Some ranges available with fuse actuation display.

Makes: CUBEFuse TM low-peak, Fusetron, Limitron, CC-

Tron, Dura-LagTM, T-Tron, Optima.

Modular fuse holders (class CC, Midget and class J), fuse holders and isolator circuit-breakers.

Ratings:

Volts: - 125 to 600V ac

Amps: - 100mA to 6000A

IR - 300kA

Applications:

General use for all types of protection and also motor protection.

Standards and Approvals:

Classes UL and CSA certified

(consult us for types)

Dimensions:

Miniature, class CC, class RK5, class RK1, class J, class G, Midget, class L.

46

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Medium Voltage Fuses and Isolators

Fuses for Voltage and Transformer

Auxiliary Fuses

Other MV Fuses

DIN Fuses

Specifications

Description:

Medium Voltage fuses with low current values, which allow for the associated system to be isolated in the event of a fault in the transformer circuit.

Ratings:

Volts: - 1 to 36kV ac

Amps: - 2 - 10A

IR - 25 - 50kA

Applications:

For use in the voltage transformer primary circuit and in transformer auxiliary elements, etc.

Standards and Approvals:

BS2692-1, IEC 60282-1

Dimensions:

Cylindrical body fuses with various length and diameter dimensions

Specifications

Description:

Complete range of fuses (back-up, full range), and also motor protection.

Ratings:

Volts: - 12 to 36kV ac

Amps: - 6.3 to 160A

Dimensions:

Oil Fuses

DIN 43625, EN IEC 60782-1, VDE 0670-4

Specifications

Description:

Fuses for use in oil-insulated isolators and circuit breakers. Fuses fitted with a pyrotechnic plunger.

Ratings:

Volts: - 3.6 to 24kV ac

Amps: - 6.3 to 250A

Dimensions:

BS 2692-1, ESI 12-8, EN IEC 60292-1

Starter Motor Fuses

Specifications

Description:

Fuses to provide protection against shortcircuit in motor and engine circuits.

Ratings:

Volts: - 3.6 to 7.2kV ac

Amps: - 5 to 400A

Dimensions:

Conform to British Standards, Standards UL and IEC DIN 43625

For Product Data Sheets, visit www.cooperbussmann.com

47

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Ultra Fast Fuses and Holders

British Standard Fuses and Holders

North American Standard Fuses and

Holders

Specifications

Description:

Standard British ultra-fast fuses. Possibility of adapting side indicators and auxiliary micro-switch as accessories.

Ratings:

Volts: - 240 - 690V ac / 150 to 500V dc

Amps: - 6 - 900A

IR - 200ka RMS Sym

Applications:

Protection of semiconductors, UPS (ASI), rectifiers, static relays, converters etc

Standards and Approvals:

Conform to standards BS88-

4, EN IEC 60269-5, UL recognized

Dimensions:

Various fuses sizes in single or double cylindrical body

Specifications

Description:

Standard North American ultra-fast fuses.

Fuse actuation display available on external and internal versions.

Limited range of fuse bases

Ratings:

Volts: - 130 to 1000V ac / 130 to 800V dc

Amps: - 1 to 4000A

IR - 200kA RMS Sym

Applications:

Protection of semiconductors, UPS (ASI), rectifiers, static relays, converters, etc.

Standards and Approvals:

UL Recognised, CSA,

Component Acceptance

Dimensions:

There are no standard dimensions with these types of fuses.

48

For Product Data Sheets, visit www.cooperbussmann.com

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Ultra Fast Fuses and Holders

Cylindrical Fuses and Holders

Square Body Fuses and Holders

Specifications

Description:

Ultra Fast cylindrical fuses. Standard ranges without fuses actuation indicator and ranges with fuse blown indicator. Modular fuse holders (type CH) for sizes 10x38,

14x51 and 22x58, with light display and ancillary elements.

Fuse holders for size 22x58.

Ratings:

Volts: - 150 - 2000V ac / 150 to 1000V dc

Amps: - 1 - 100A

IR - 25 to 200kA RMS Sym

Applications:

Protection of semi-conductors, UPS (ASI), rectifiers, static relays, converters.

Standards and Approvals:

Conform to standards IEC

60269, UL Recognition, CSA Component Acceptance

(consult us).

Dimensions:

Variety of fuse sizes: from 6x32, 25x146

Specifications

Description:

Ultra Fast square-body fuses, in versions with visual indicator and striker for use with auxiliary microswitch. Fuses in formats DIN 43620, DIN 43653 (DIN 110 and DIN 80), French standard, North American standard.

Fuse bases to DIN 43620 and 43653.

Ratings:

Volts: - 690 to 3000V ac

Amps: - 10 to 700A

IR - 300kA RMS Sym

Applications:

Protection of semidconductors, UPS (ASI), rectifiers, static relays, converters.

Standards and Approvals:

Conform to standards IEC

60269-4, UL Recognition, CSA Component Acceptance

(consult us).

Dimensions:

Sizes 000, 00, 0, 1*, 1, 2, 3, 4, 5

For Product Data Sheets, visit www.cooperbussmann.com

49

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

50

Low Voltage Fuse Links Catalogue

Index

Page

26

37

16

13

12

18

18

26

30

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

25

26

25

27

27

26

17

29

29

29

16

16

17

17

29

26

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

18

Catalogue Number

059-0119

059-0120

059-0121

059-0122

059-0123

059-0124

059-0125

059-0126

059-0127

059-0128

059-0129

059-0140

059-0141

059-0142

059-0143

059-0144

059-0145

059-0146

059-0147

059-0148

059-0149

059-0150

059-0151

059-0152

059-0153

059-0154

059-0155

059-9925

059-9926

1000NH4AG

1000NH4G-S

1000NHG4G

100D125

100KR85

100L09-660

100L14-660

011-9127

011-9128

011-9129

011-9483

011-9679

012-0140

012-0141

059-0067

059-0107

059-0108

059-0109

059-0110

059-0111

059-0112

059-0113

059-0114

059-0115

059-0116

059-0117

059-0118

100LR85

100MJ25-6

100MJ29-6

100MJ30-7

100MJ31-7

100NH00M

100NH0M

100NH1M

100NH2M

100NHG000B

100NHG000B-400

100NHG000BI

100NHG000BI-400

100NHG00B-690

100NHG00BI-690

100NHG01B

Page

12

14

16

17

17

30

26

13

14

28

28

35

26

26

26

27

28

26

25

27

26

25

13

16

11

29

36

12

11

13

35

37

37

38

27

26

26

25

26

25

26

25

29

29

26

25

13

14

29

29

26

25

28

28

28

28

27

30

27

27

28

30

25

26

25

26

27

27

26

25

26

25

Catalogue Number

100NHG01B-400

100NHG01BI

100NHG01BI-400

100NHG02B

100NHG02B-400

100NHG02BI

100NHG02BI-400

100NHG0B

100NHG0B-690

100NHG1B-690

100NHG1BI-690

100NHG1BS-690

100NHG2B-690

100NHG2BI-690

100NHM00B

100NHM00BI

100NHM0B

100NHM1B

100NHM1BI

100NHM1BS-690

100NZ03

10D16

10D27

10GD27

10GN01

10H07-660

10HS07

10K08-660

10K09-660

10KR85

10KS09

10NHC00M

10NHG000B

10NHG000B-400

10NHG000B-690

10NHG000BI

10NHG000BI-400

10NHG000BI-690

10NHG01B

10NHG01BI

10NHG0B

10NHG0B-690

10NHM000B-690

10NHM000BI-690

10NHM0B

10NZ01

1250NH4AG

1250NH4G-S

1250NHG4G

125M09-660

125M13

125M14-660

125M23

125MJ25-6

125MJ30-7

125MJ31-7

125N11-660

125N20

125NH00M

125NH0M

125NH1M

125NH2M

125NHG00B

125NHG00B-400

125NHG00BI

125NHG00BI-400

125NHG01B

125NHG01B-400

125NHG01BI

125NHG01BI-400

125NHG02B

125NHG02B-400

Page

30

28

28

28

28

27

30

27

27

26

25

26

27

26

25

26

25

29

26

25

26

25

14

29

29

29

17

17

17

13

14

12

14

16

26

25

13

13

11

29

26

25

37

37

38

36

30

28

28

30

12

11

28

28

30

16

28

28

28

30

26

13

26

30

27

27

30

28

25

26

27

27

Catalogue Number

125NHG02BI

125NHG02BI-400

125NHG0B

125NHG1B-690

125NHG1BI-690

125NHG1BS-690

125NHG2B-690

125NHG2BI-690

125NHG2BS-690

125NHM00B

125NHM00BI

125NHM1B

125NHM1BI

125NHM1BS-690

125NHM2B-690

125NHM2BI-690

125NHM2BS-690

15KR85

1600NH4AG

160M09-660

160M13

160M14-660

160M23

160MJ25-6

160MJ29-6

160MJ30-7

160MJ31-7

160N11-660

160N20

160NH00M

160NH0M

160NH1M

160NH2M

160NHG00B

160NHG00B-400

160NHG00BI

160NHG00BI-400

160NHG01B

160NHG01B-400

160NHG01BI

160NHG01BI-400

160NHG02B

160NHG02B-400

160NHG02BI

160NHG02BI-400

160NHG0B

160NHG1B-690

160NHG1BI-690

160NHG1BS-690

160NHG2B-690

160NHG2BI-690

160NHG2BS-690

160NHM00B

160NHM00BI

160NHM1B

160NHM1BI

160NHM1BS-690

160NHM2B-690

160NHM2BI-690

160NHM2BS-690

16D16

16D27

16GD27

16GN02

16H07-660

16HS07

16K08-660

16K09-660

16KS09

16NHC00M

16NHG000B

16NHG000B-400

For Product Data Sheets, visit www.cooperbussmann.com

Page

13

13

16

11

16

38

36

12

11

28

30

37

37

28

28

30

28

26

25

27

30

27

25

26

25

27

29

26

25

26

17

13

14

29

27

30

26

27

28

28

28

35

27

26

25

27

17

29

26

25

26

26

14

12

14

16

28

35

19

13

17

17

27

26

26

27

28

28

26

25

27

26

Catalogue Number

16NHG000B-690

16NHG000BI

16NHG000BI-400

16NHG000BI-690

16NHG01B

16NHG01BI

16NHG0B

16NHG0B-690

16NHM000B-690

16NHM000BI-690

16NHM0B

16NZ01

200DF

200M09-660

200M13

200M14-660

200M23

200MJ25-6

200MJ29-6

200MJ30-7

200MJ31-7

200N11-660

200N20

200NH1M

200NH2M

200NHG02B

200NHG02B-400

200NHG02BI

200NHG02BI-400

200NHG1B

200NHG1B-400

200NHG1B-690

200NHG1BI

200NHG1BI-400

200NHG1BI-690

200NHG1BS-690

200NHG2B-690

200NHG2BI-690

200NHG2BS-690

200NHM1B

200NHM1BI

200NHM1BS-690

200NHM2B-690

200NHM2BI-690

200NHM2BS-690

20D16

20D27

20GD27

20GN02

20H07-660

20HS07

20K08-660

20K09-660

20KR85

20KS09

20MJ25-6

20MJ31-8

20NHC00M

20NHG000B

20NHG000B-400

20NHG000B-690

20NHG000BI

20NHG000BI-400

20NHG000BI-690

20NHG01B

20NHG01BI

20NHG0B

20NHG0B-690

20NHM000B-690

20NHM000BI-690

20NHM0B

20NZ02

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Page

12

11

16

11

17

37

37

38

36

30

28

28

30

27

27

28

28

29

26

25

27

26

25

27

25

27

27

27

30

26

25

27

26

26

25

26

25

26

25

26

25

14

14

14

29

29

17

17

13

13

30

14

16

17

28

30

28

28

25

27

26

25

27

27

27

26

25

26

25

26

30

28

Catalogue Number

250NHG02B

250NHG02B-400

250NHG02BI

250NHG02BI-400

250NHG03B

250NHG03B-400

250NHG03BI

250NHG03BI-400

250NHG1B

250NHG1B-400

250NHG1B-690

250NHG1BI

250NHG1BI-400

250NHG1BI-690

250NHG2B-690

250NHG2BI-690

250NHG2BS-690

250NHG3B-690

250NHG3BI-690

250NHM1B

250NHM1BI

250NHM1BS-690

250NHM2B-690

250NHM2BI-690

250NHM2BS-690

25D16

25D27

25GD27

25GN02

25H07-660

25HS07

25KR85

25KS09

25MJ31-8

25NHC00M

25NHG000B

25NHG000B-400

25NHG000B-690

25NHG000BI

25NHG000BI-400

25NHG000BI-690

224NHG02B

224NHG02B-400

224NHG02BI

224NHG02BI-400

224NHG1B

224NHG1B-400

224NHG1B-690

224NHG1BI

224NHG1BI-400

224NHG1BI-690

224NHG2B-690

224NHG2BI-690

224NHG2BS-690

224NHM1B

224NHM1BI

224NHM1BS-690

224NHM2B-690

224NHM2BI-690

224NHM2BS-690

250M13

250MJ25-6

250MJ29-6

250MJ30-7

250MJ31-7

250N09-600

250N11-660

250N15

250N20

250N34

250NH1M

250NH2M

Low Voltage Fuse Links Catalogue

Index

Page

28

19

19

19

28

28

30

28

26

25

27

30

27

27

30

19

12

25

26

25

26

14

29

29

26

14

17

17

13

13

14

14

25

27

11

13

13

11

19

19

16

17

17

29

29

26

25

27

35

16

26

25

27

26

37

38

36

12

13

13

29

16

23

26

26

26

27

28

28

28

35

37

Catalogue Number

315M13

315MJ30-7

315MJ31-7

315N09-660

315N11-660

315N15

315N20

315N34

315NH2M

315NH3M

315NHG03B

315NHG03B-400

315NHG03BI

315NHG03BI-400

315NHG2B

315NHG2B-400

315NHG2B-690

315NHG2BI

315NHG2BI-400

315NHG2BI-690

315NHG2BS-690

315NHG3B-690

315NHG3BI-690

315NHG3BS-690

315NHM2B-690

315NHM2BI-690

315NHM2BS-690

315NHM3B-690

315NHM3BI-690

32BS

32BSC

32CML

32CMLC

32H07-660

25NHG01B

25NHG01BI

25NHG0B

25NHG0B-690

25NHM000B-690

25NHM000BI-690

25NHM0B

25NZ02

2D16

2D27

2GD27

2GN01

2H07-660

2K08-660

2K09-660

2NHC00M

2NHG000B

2NHG000B-400

2NHG000B-690

2NHG000BI

2NHG000BI-400

2NHG000BI-690

2NZ01

30KR85

30LR85

30NH00AD

32HS07

32K08-660

32K09-660

32KS09

32LSC

32LSCC

32MJ25-6

32MJ30-8

32MJ31-8

32NH0M

32NHC00M

32NHG000B

Page

26

27

28

28

28

26

25

26

25

26

25

26

25

27

26

25

27

37

38

36

26

25

14

14

17

17

28

13

13

13

28

28

30

28

26

25

26

25

35

19

29

29

26

25

26

25

27

27

30

26

25

26

25

20

29

26

25

28

20

20

20

25

27

26

26

27

28

28

26

25

27

26

Catalogue Number

355NHM2B-690

355NHM2BI-690

355NHM2BS-690

355NHM3B-690

355NHM3BI-690

355P09-660

355P11-660

355P12-660

355P20

355P35

355PJ30-7

355PJ31-7

35D33

35GD33

35GN02

35NHG000B

35NHG000B-400

35NHG000B-690

35NHG000BI

35NHG000BI-400

35NHG000BI-690

35NHG01B

35NHG01B-400

35NHG01BI

35NHG01BI-400

35NHG02B

35NHG02B-400

35NHG02BI

35NHG02BI-400

35NHG0B

35NHG0B-690

35NHM000B-690

35NHM000BI-690

35NHM0B

32NHG000B-400

32NHG000B-690

32NHG000BI

32NHG000BI-400

32NHG000BI-690

32NHG01B

32NHG01BI

32NHG0B

32NHG0B-690

32NHM000B-690

32NHM000BI-690

32NHM0B

32NNL

32NNSBS

32NNSF

32NNSFBS

355NH2M

355NHG03B

355NHG03B-400

355NHG03BI

355NHG03BI-400

355NHG2B

355NHG2B-400

355NHG2BI

355NHG2BI-400

355NHG3B-690

355NHG3BI-690

355NHG3BS-690

35NZ02

400EF

400NH2M

400NH3M

400NHG03B

400NHG03B-400

400NHG03BI

400NHG03BI-400

400NHG2B

400NHG2B-400

For Product Data Sheets, visit www.cooperbussmann.com

Page

36

12

13

13

29

23

37

37

38

14

14

17

16

28

28

13

13

26

25

27

26

25

27

35

26

25

26

27

28

26

25

26

25

25

27

26

25

26

25

27

26

16

17

17

29

29

11

11

11

16

12

13

13

16

14

14

17

17

28

28

30

28

28

30

13

26

25

27

27

30

13

13

Catalogue Number

40NHG000B

40NHG000B-400

40NHG000B-690

40NHG000BI

40NHG000BI-400

40NHG000BI-690

40NHG01B

40NHG01B-400

40NHG01BI

40NHG01BI-400

40NHG02B

40NHG02B-400

40NHG02BI

40NHG02BI-400

40NHG0B

40NHG0B-690

40NHM000B-690

40NHM000BI-690

40NHM0B

450R11-660

450R12-660

450R20

450R40

450RJ31-7

45KR85

45NH00AD

4D16

4D27

4GD27

4GN01

4H07-660

4K08-660

4K09-660

4NHC00M

4NHG000B

4NHG000B-400

4NHG000B-690

4NHG000BI

4NHG000BI-400

4NHG000BI-690

4NZ01

400NHG2BI

400NHG2BI-400

400NHG3B-690

400NHG3BI-690

400NHG3BS-690

400NHM2B

400NHM2BI

400NHM2BS-690

400NHM3B-690

400NHM3BI-690

400NHM3BS-690

400P09-660

400P11-660

400P12-660

400P20

400P35

400PJ30-7

400PJ31-7

40K07-660

40K08-660

40K09-660

40KR85

40KS07

40KS08

40KS09

40LR85

40MJ25-6

40MJ30-8

40MJ31-8

40NH1M

40NHC00M

51

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

52

Page

13

14

17

16

16

28

28

35

13

27

27

27

28

25

26

25

26

26

25

26

25

26

26

25

27

27

29

29

26

25

16

17

17

29

19

29

26

30

16

23

19

19

26

25

13

16

11

11

11

38

36

12

13

14

14

17

37

28

30

13

13

29

30

25

27

30

26

28

26

25

27

26

Catalogue Number

50LR85

50MJ30-8

50MJ31-8

50NH0M

50NH1M

50NHC00M

50NHG000B

50NHG000B-400

50NHG000BI

50NHG000BI-400

50NHG00B-690

50NHG00BI-690

50NHG01B

50NHG01B-400

50NHG01BI

50NHG01BI-400

50NHG02B

50NHG02B-400

50NHG02BI

50NHG02BI-400

50NHG0B

50NHG0B-690

50NHG1B-690

50NHG1BI-690

50NHM00B

50NHM00BI

50NHM0B

50NZ02

560R11-660

560R12-660

560R20

560SJ31-6

5KR85

60KR85

500NH3M

500NH4G-S

500NHG3B

500NHG3B-400

500NHG3B-690

500NHG3BI

500NHG3BI-400

500NHG3BI-690

500NHG3BS-690

500NHG4G

500NHM3B-690

500NHM3BI-690

500NHM3BS-690

500R11-660

500R12-660

500R20

500R40

500RJ31-7

50D33

50GD33

50GN02

50K07-660

50K08-660

50K09-660

50KR85

50KS07

50KS08

50KS09

60LR85

60NH00AD

63/100BS

63/100CML

63/100LSC

630NH3M

630NH4AG

630NH4G-S

630NHG3B

630NHG3B-400

Low Voltage Fuse Links Catalogue

Index

Page

36

12

13

13

35

37

37

38

28

28

28

28

30

30

27

27

28

29

26

25

27

26

25

27

26

27

27

27

26

25

26

25

27

26

25

26

25

25

26

25

27

29

29

29

26

16

17

17

17

13

13

11

11

11

20

20

38

12

30

13

13

14

17

37

26

25

30

26

28

28

20

20

Catalogue Number

63NHG000B-400

63NHG000BI

63NHG000BI-400

63NHG00B-690

63NHG00BI-690

63NHG01B

63NHG01B-400

63NHG01BI

63NHG01BI-400

63NHG02B

63NHG02B-400

63NHG02BI

63NHG02BI-400

63NHG0B

63NHG0B-690

63NHG1B-690

63NHG1BI-690

63NHG1BS-690

63NHG2B-690

63NHG2BI-690

63NHM00B

63NHM00BI

63NHM0B

63NHM1B-690

63NHM1BI-690

63NHM1BS-690

63NZ02

6D16

6D27

6GD27

6GN01

6H07-660

6K08-660

6K09-660

6NHC00M

6NHG000B

6NHG000B-400

6NHG000B-690

6NHG000BI

6NHG000BI-400

6NHG000BI-690

630NHG3BI

630NHG3BI-400

630NHG3BS-690

630NHG4G

630NHM3B

630NHM3BI

630NHM3BS-690

630R11-660

630R12-660

630R20

630SJ31-6

63D33

63ENL

63ENSBS

63ENSF

63ENSFBS

63GD33

63K07-660

63K08-660

63K09-660

63KS07

63KS08

63KS09

63MJ25-6

63MJ29-6

63MJ30-8

63MJ31-8

63NH00M

63NH0M

63NH1M

63NHG000B

Page

5

5

5

5

5

5

5

5

26

16

23

5

5

28

28

30

35

8

8

8

8

8

5

8

27

28

28

28

27

27

30

27

25

26

25

26

27

25

26

25

26

25

27

27

26

29

26

25

26

17

17

17

29

29

13

12

16

16

14

26

30

26

14

17

27

28

28

28

35

16

37

16

Catalogue Number

80NHG01B-40

80NHG01BI

80NHG01BI-400

80NHG02B

80NHG02B-400

80NHG02BI

80NHG02BI-400

80NHG0B

80NHG0B-690

80NHG1B-690

80NHG1BI-690

80NHG1BS-690

80NHG2B-690

80NHG2BI-690

80NHM00B

80NHM00BI

80NHM0B

80NHM1B

80NHM1BI

80NHM1BS-690

80NZ03

900NH4AG

90KR85

90NH00AD

AAO10

AAO16

AAO2

AAO20

AAO25

AAO32

AAO32M40

AAO32M50

AAO32M63

AAO4

AAO6

AC10

AC16

AC2

AC20

AC25

AC32

6NHG0B-690

6NHM000B-690

6NHM000BI-690

6NHM0B

6NZ01

70KR85

710S20

800NH4AG

800NH4G-S

800NHG4G

800S20

800SJ28

80D125

80KR85

80L09-660

80L14-660

80LR85

80MJ25-6

80MJ29-6

80MJ30-7

80MJ31-7

80NH00M

80NH0M

80NH1M

80NHG000B

80NHG000B-400

80NHG000BI

80NHG000BI-400

80NHG00B-690

80NHG00BI-690

80NHG01B

For Product Data Sheets, visit www.cooperbussmann.com

Page

39

39

39

39

39

39

39

39

41

41

41

41

39

41

41

41

41

21

21

21

21

21

21

21

40

40

41

41

40

40

40

40

40

40

40

40

40

40

40

40

40

8

40

40

40

8

8

8

8

32

32

8

8

8

6

6

32

32

8

8

8

8

6

6

6

6

8

8

8

8

8

8

Catalogue Number

BFD1-33/LL

BFD1-33/LM

BFD1-33/LW

BFD2-31/LL

BFD2-31/LM

BFD2-31/LW

BFD2-33/LL

BFD2-33/LM

BFD2-33/LW

BFD3-31/LL

BFD3-31/LM

BFD3-31/LW

BFD3-33/LL

BFD3-33/LM

BFD3-33/LW

BFH000-1A/T

BFH000-3A/T

BFH00-1A/F

BFH00-3A/F

BFH1-1A/F

BFH1-3A/F

BFH2-1A/F

BFH2-3A/F

BFH3-1A/F

BFH3-3A/F

BFR1-3K/LL

BFR1-3K/LM/C

BFR1-3K/LW

BFR2-3K/LL

BFR2-3K/LM/C

BFR2-3K/LW

BFR3-3K/LL

BFR3-3K/LM/C

BFR3-3K/LW

C08G0.5

C08G1

C08G10

C08G10I

C08G12

C08G12I

C08G16

AC4

AC6

AD10

AD16

AD2

AD20

AD25

AD32

AD4

AD6

BAO35

BAO40

BAO50

BAO63

BAO63M100

BAO63M80

BC0

BC00

BC1-2

BC3

BC40

BC50

BC63

BC63M100

BC63M80

BD40

BD50

BD63

BFD1-31/LL

BFD1-31/LM

BFD1-31/LW

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Low Voltage Fuse Links Catalogue

Index

Catalogue Number

C10M20I

C10M25

C10M25I

C10M2I

C10M32

C10M32I

C10M4

C10M4I

C10M6

C10M6I

C10M8

C10M8I

C10NL

C14G10

C14G10I

C14G10S

C14G12

C10G6

C10G6I

C10G8

C10G8I

C10M0.16

C10M0.25

C10M0.5

C10M1

C10M10

C10M10I

C10M12

C10M12I

C10M16

C10M16I

C10M1I

C10M2

C10M20

C14G12I

C14G12S

C14G16

C14G16I

c14G16S

C14G2

C14G20

C10G1

C10G10

C10G10I

C10G12

C10G12I

C10G16

C10G16I

C10G2

C10G20

C10G20I

C10G25

C10G25I

C10G2I

C10G32

C10G32I

C10G4

C10G4I

C08G16I

C08G2

C08G20

C08G20I

C08G25

C08G25I

C08G2I

C08G4

C08G4I

C08G6

C08G6I

C08G8

C08G8I

C10G0.5

Page

22

21

21

21

21

22

22

22

22

22

22

22

22

22

22

22

22

21

21

21

21

21

21

21

22

22

22

22

22

22

22

22

22

22

22

22

22

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

Catalogue Number

C14M25

C14M25I

C14M25S

C14M2I

C14M2S

C14M32

C14M32I

C14M32S

C14M4

C14M40

C14M40I

C14M40S

C14M4I

C14M4S

C14M50

C14M50I

C14M50S

C14M0.25

C14M0.50

C14M1

C14M10

C14M10I

C14M10S

C14M12

C14M12I

C14M12S

C14M16

C14M16I

C14M16S

C14M1I

C14M2

C14M20

C14M20I

C14M20S

C14G20I

C14G20S

C14G25

C14G25I

C14G25S

C14G2I

C14G2S

C14G32

C14G32I

C14G32S

C14G4

C14G40

C14G40I

C14G40S

C14G45S

C14G4I

C14G4S

C14G50

C14G50I

C14G50S

C14G6

C14G6I

C14G6S

C14G8

C14G8I

C14G8S

C14M6

C14M6I

C14M6S

C14M8

C14M8I

C14M8S

C14NL

C1515

C1520

C180-10A

C180-13A

C180-1A

Page

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

4

4

4

4

4

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

For Product Data Sheets, visit www.cooperbussmann.com

Page

22

22

22

22

22

22

22

22

22

21

21

22

22

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

22

22

22

22

22

22

22

22

22

22

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

21

4

4

21

21

21

21

21

4

4

21

21

Catalogue Number

C22G8

C22G80

C22G80I

C22G80S

C22G8I

C22G8S

C22M10

C22M100

C22M100I

C22M100S

C22M10I

C22M12

C22M125

C22M125I

C22M125S

C22M12I

C22M16

C22G32I

C22G32S

C22G4

C22G40

C22G40I

C22G40S

C22G4I

C22G4S

C22G50

C22G50I

C22G50S

C22G6

C22G63

C22G63I

C22G63S

C22G6I

C22G6S

C180-2A

C180-3A

C180-5A

C180-7A

C22G10

C22G100

C22G100I

C22G100S

C22G10I

C22G10S

C22G12

C22G125

C22G125I

C22G125S

C22G12I

C22G12S

C22G16

C22G16I

C22G16S

C22G2

C22G20

C22G20I

C22G20S

C22G25

C22G25I

C22G25S

C22G2I

C22G32

C22M16I

C22M16S

C22M2

C22M20

C22M20I

C22M20S

C22M25

C22M25I

C22M25S

C22M2I

Page

22

22

22

22

22

22

22

22

22

22

22

22

22

23

23

23

22

22

22

23

23

23

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

4

4

22

22

22

22

22

22

4

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

Catalogue Number

C8M12I

C8M16

C8M16I

C8M2

C8M20

C8M20I

C8M25

C8M2I

C8M4

C8M4I

C8M6

C8M6I

C8M8

C8NL

CA10D15

CA14D30

CA22D15

CA22D30

CA22D45

CA22D60

CD0623G2

CD0623G4

CD0623G6

CD0823G10

CD0823G10I

CD0823G16

CD0823G16I

CD0823G2

CD0823G2I

CD0823G4

CD0823G4I

CD0823G6

CD0823G6I

CD0831G0.5

C22M32

C22M32I

C22M32S

C22M4

C22M40

C22M40I

C22M40S

C22M4I

C22M50

C22M50I

C22M50S

C22M6

C22M63

C22M63I

C22M63S

C22M6I

C22M8

C22M80

C22M80I

C22M80S

C22M8I

C22NL

C3030

C4545

C55

C8M10

C8M10I

C8M12

CD0831G1

CD0831G10

CD0831G10I

CD0831G12

CD0831G12I

CD0831G16

CD0831G2

CD0831G20

CD0831G20I

CD0831G25

53

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

54

Low Voltage Fuse Links Catalogue

Index

Catalogue Number

CD1025G16I

CD1025G6

CD1025G6I

CD1031G16

CD1031G16I

CD1031G20

CD1031G20I

CD1031G25

CD1031G25I

CD1038G25

CD1038G25I

CD1038G32

CD1038G32I

CD27

CD33

CD80

CEO100

CEO100M125

CEO100M160

CEO100M200

CEO32

CEO40

CEO50

CEO63

CEO80

CH081D

CH081DI

CH081DN

CH081DNI

CH081DNS

CH081DNSI

CH082D

CH082DI

CH083D

CD0831G25I

CD0831G2I

CD0831G4

CD0831G4I

CD0831G6

CD0831G6I

CD0831G8

CD0836G10

CD0836G10I

CD0836G16

CD0836G16I

CD0836G2

CD0836G20

CD0836G20I

CD0836G25

CD0836G25I

CD0836G2I

CD0836G32

CD0836G32I

CD0836G4

CD0836G4I

CD0836G6

CD0836G6I

CD100

CD100M125

CD100M160

CD100M200

CD1025G10

CD1025G10I

CD1025G16

CH083DI

CH083DN

CH083DNI

CH083DNS

CH083DNSI

CH084D

CH084DI

CH141D

Page

23

23

23

23

23

6

6

23

23

6

6

6

6

6

6

23

23

22

22

22

38

38

22

22

22

22

22

22

22

22

22

22

8

6

23

23

23

23

23

23

23

24

8

8

8

8

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

22

Catalogue Number

CHMDNX

CM100F

CM20F

CM32F

CM32FC

CM63F

CMSC

CN01

CN02

CS0

CS00

CS1

CS2

CS3

DD125

DD160

DD200

CH810-HP

CHM1D

CHM1DI

CHM1DN

CHM1DNI

CHM1DNS

CHM1DNSI

CHM2D

CHM2DI

CHM3D

CHM3DI

CHM3DN

CHM3DNI

CHM3DNS

CHM3DNSI

CHM4D

CHM4DI

DD200M250

DD200M315

DEO125

DEO160

DEO200

DEO200M250

DEO200M315

CH141DI

CH141DMS

CH141DMS-F

CH141DN

CH141DNI

CH141DNX

CH142D

CH142DI

CH143D

CH143DI

CH143DMS

CH143DMS-F

CH143DN

CH143DNI

CH143DNMS

CH143DNMS-F

CH144D

CH144DI

CH14-HP

CH14MS-1D

CH14MS-3D

CH221D

CH221DMS

CH221DN

CH221DNX

CH222D

CH223D

CH223DMS

CH223DN

CH224D

CH22MDNMS

Page

32

8

8

8

32

32

32

32

19

19

19

36

36

23

19

19

19

7

7

7

7

7

8

8

23

23

23

23

23

23

23

23

23

23

23

23

23

23

23

23

23

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

24

Catalogue Number

GF800

GG1000

GG1250

GG710

GG800

GH1000

GH1250

GH710

GH800

GLP

LBS4/1

LBS4/3

M-32NNSF

M-63ENSF

M-AAO10

M-AAO16

M-AAO20

FC3

FEH

FF400

FF500

FF560

FF630

FG450

FG500

FG560

FG630

FN01C

FN02C

FRN01C

FRN02C

GF1000

GF1250

GF710

ED250

ED315

ED315M400

ED355

ED400

ED400M500

EF355

EF400

EF400M500

EFS125

EFS160

EFS200

EFS250

EFS315

ESD10

ESD16

ESD2

ESD20

ESD32

ESD4

ESD40

ESD50

ESD6

ESD63

ESD63M100

ESD63M80

FC0

FC00

FC1

FC2

M-AAO25

M-BAO40

M-BAO50

M-BAO63

M-C180-13A

M-C180-3A

M-C180-5A

M-CD100

Page

41

41

11

11

11

9

9

9

19

9

9

9

9

9

9

11

11

36

36

36

36

9

9

9

9

9

32

32

9

9

9

9

9

9

11

11

11

11

11

11

11

11

10

10

10

32

32

10

10

10

10

10

10

10

10

9

9

9

10

32

32

9

9

9

9

9

8

8

8

8

8

8

For Product Data Sheets, visit www.cooperbussmann.com

Page

36

38

38

38

38

32

32

32

32

38

38

36

7

32

32

32

32

32

32

32

10

10

10

10

10

10

7

7

7

10

10

10

10

10

10

10

10

5

5

5

5

5

5

5

5

5

11

11

11

19

5

5

5

5

11

11

11

11

11

11

11

11

11

11

11

11

11

11

11

11

11

11

Catalogue Number

OSD80

SB00-D

SB0-D

SB0-DMS

SB1-D

SB1-DMS

SB2-D

SB2-DMS

SB3-D

SB3-DMS

SB4-DMS

SB4-S

SFD27

SFD33

SFPCDO1

SFPCDO2

SFPRD27

SFPRD33

SFRD27

SFRD33

NSD10

NSD16

NSD2

NSD20

NSD20M25

NSD20M32

NSD20M36

NSD32

NSD32M36

NSD32M40

NSD32M50

NSD32M63

NSD4

NSD6

OSD100

OSD100M125

OSD100M160

M-CEO100

M-CEO80

M-CM100F

M-CM20F

M-CM32F

M-CM32FC

M-CM63F

M-NITD10

M-NITD16

M-NITD2

M-NITD20

M-NITD32

M-NITD6

M-NSD10

M-NSD16

M-NSD20

M-NSD32

M-NSD4

M-NSD6

M-STD10

M-STD6

NI

NITD10

NITD16

NITD2

NITD20

NITD20M25

NITD20M32

NITD25

NITD32

NITD32M40

NITD32M50

NITD32M63

NITD4

NITD6

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Page

38

36

36

38

38

32

32

32

38

15

15

15

15

32

32

36

36

38

38

36

36

10

10

10

15

15

10

10

10

10

32

32

32

32

15

15

15

32

15

15

32

32

15

15

15

15

15

32

32

32

32

Low Voltage Fuse Links Catalogue

Index

Catalogue Number

STD25

STD32

STD4

STD6

TB00-D

TB0-D

TB1-D

TB2-D

TB3-D

TFD27

TFD33

TFN01C

TFN02C

TFPCD27

TFPCD33

TFPCDO1

TFPCDO2

TFRD27

TFRD33

TFRN1C

TFRN2C

SL0

SL00

SL1

SL2

SL3

SL4

SMD10

SMD16

SMD2

SMD20

SMD25

SMD32

SMD4

SMD6

SP0

SP00

SP1-2

SP3

SP4

SSD10

SSD16

SSD2

SSD20

SSD32

SSD4

SSD6

STD10

STD16

STD2

STD20

For Product Data Sheets, visit www.cooperbussmann.com

55

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Cooper Bussmann

®

Products and

Technical Support Delivered Worldwide

Customer Assistance

Customer Satisfaction Team

The Cooper Bussmann

®

Customer Satisfaction Team is available to answer questions regarding Cooper Bussmann ® products and services.

Contact should be made between:

Monday to Friday: 7:30am to 5:30pm GMT

The Customer Sastisfaction Team can be reached via:

 Phone: 00 44 (0) 1509 882 600

 Fax: 00 44 (0) 1509 882 786

 Email: [email protected]

Application Engineering

Application Engineering assistance is available to all customers. The Application Engineering team is staffed by degreed electrical engineers and available by phone with technical and application support Monday to Friday: 7:30am to

5:30pm GMT.

Application Engineering can be reached via:

 Phone: 00 44 (0) 1509 882 699

 Fax: 00 44 (0) 1509 882 794

 Email: [email protected]

Web Services

www.cooperbussmann.com

The Cooper Bussmann

® website makes available free information and other resources that include:

 Product Data Sheets for complete technical information on

Cooper Bussmann

® products

 Online catalogue for the latest United States and European catalogues

 Safety BASCIS

TM for the essentials of electrical safety

 Training modules for increasing skill levels of customers and end users

 Fuse Cross-reference to find the correct Cooper

Bussmann

® replacement for a competitive fuse

 Arc-Flash calculator to determine the incident energy level and flash protection boundry along with the recommendations the level of Personal Protective

Equipment (PPE)

Your authorised Cooper Bussmann

®

Distributor is:

Cooper Bussmann (UK) Ltd

Burton-on-the-Wolds, Loughborough

Leicestershire LE12 5TH, UK

Tel: 00 44 (0) 1509 882 600

Fax: 00 44 (0) 1509 882 786

Email: [email protected]

Website: www.cooperbussmann.com

Reorder: LV-2007

Courtesy of Steven Engineering, Inc. ● 230 Ryan Way, South San Francisco, CA 94080-6370 ● General Inquiries: (800) 670-4183 ● www.stevenengineering.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
