AIPHONE (B.C. Technology) (2 Year Warranty)
Code
Trade
AUDIO DOOR ENTRY
DA Surface kits
913-0317
DA-1AS 1 way kit, inc 1 button surface panel, 1 x Audio Handset & PSU
913-0318
DA-2AS As above 2 way
913-0319
DA-3AS As above 3 way
The above kits are also available in Stainless Steel with the option of a keypad or proximity reader
Vandal Resistant VC Audio flush kits
(Larger kits are available, also with keypad and proximity reader options)
914-0117
VCAFS-1 V/R flush kit 1 way, inc Stainless Steel flush panel, phone, PSU & mortice/rim release
914-0553
VCAFS-2 As above 2 way
914-0554
VCAFS-3 As above 3 way
Vandal Resistant VC Audio surface kits
(Larger kits are available, also with keypad and proximity reader options)
913-0138
VCASS-1 V/R surface kit 1 way, inc Stainless Steel surface panel, phone, PSU & mortice/rim release
913-0139
VCASS-2 As above 2 way
913-0564
VCASS-3 As above 3 way
Accessories
915-0232
VC-K Apartment audio handset
922-0042
VC-AC/DC PSU, 12V dc 800mA & 12V AC 1.5 Amp (includes 40781)
Aiphone TWO-Wire BUS Apartment System.
The GF system features a simple 2-wire BUS connection to all room stations throughout the system, enabling simple and quick set-up.
The entrance panel is vandal resistant diecast zinc with call buttons. Fully modular design with speech module and call switch module
The GF audio system is the ideal communication solution for new and existing apartment applications.
GF Audio Flush kits
914-0203
GF-1A/F/KIT 1 way GF kit, inc 1 button panel, controller, PSU & handset
914-0204
GF-2A/F/KIT As Above 2 way
914-0205
GF-4A/F/KIT As Above 4 way
Kits are available from 1 way to 50 way
Video FLUSH 4 Wire BUS Analogue Entry kits (Monochrome)
917-0130
GF-5V/F/KIT 5 Way GF Video Kit, inc Flush Door Station, relevant number of monitor’s,
PSU’s, video & audio BUS controllers
917-0131
GF-6V/F/KIT As above 6 Way
917-0132
GF-7V/F/KIT As above 7 Way
The above kits are also available in Stainless Steel with Keypad or Proximity from 1 to 50 way
Video SURFACE 4 Wire BUS Analogue Entry kits (Monochrome)
GF SERIES
916-0158
GF-5V/SHB/KIT 5 Way GF Video Kit, inc Surface Door Station, relevant number of monitor’s, PSU’s, video & audio BUS controllers
916-0159
GF-6V/SHB/KIT As above 6 Way
916-0160
GF-7V/SHB/KIT As above 7 Way
The above kits are also available in Stainless Steel with Keypad or Proximity from 1 to 50 way
Audio & Video Door Entry Systems
2 Wire BUS Digital Audio Entry
914-0257
GF-ADGF/KIT 1 Way Digital Audio Kit, inc 1x FLUSH door station, 1 x audio handset, BUS controller & PSU’s
913-0321
GF-ADGS/KIT 1 Way Digital Audio Kit, inc 1x SURFACE door station, 1 x audio handset, BUS controller & PSU’s
915-0559
GF-ADGF Additional Digital Audio Door Station - FLUSH (24V dc PSU required)
915-0560
GF-ADGS Additional Digital Audio Door Station - SURFACE (24V dc PSU required)
915-0561
GF-1D Audio Handset
922-0047
PS-24N 24V dc Power Supply
For larger systems please add relevant number of room stations required & for additional doorstations add correct type required (max 5).
The above kits are also available in Stainless Steel with a Keypad or Proximity reader.
4 Wire BUS Digital Video Entry
917-0146
GF-DVF/KIT 1 Way Digital Video Kit, inc 1 x FLUSH Door Station, 1 x Video Handset, BUS Control & PSU’s
916-0174
GF-DVS/KIT 1 Way Digital Video Kit, inc 1 x SURFACE Door Station, 1 x Video Handset, BUS Control & PSU’s
918-0194
GF-VDGF Additional Digital Video Door Station - FLUSH (24V dc PSU required)
918-0195
GF-VDGS Additional Digital Video Door Station - SURFACE (24V dc PSU required)
915-0562
GF-1MD Additional Video Room station
915-0563
GF-4Z 4 Way Video Distribution Unit
922-0047
PS-24N 24V dc Power Supply
GF SERIES
For larger systems please add relevant number of room stations required (maximum of 250 on Video systems) & for additional
doorstations add correct type required (max 5). The above kits are also available in Stainless Steel with a Keypad or Proximity reader.
CABLE SPECIFICATION for GF 2 & 4 Wire BUS systems (See page 19 for Wiring Diagram)
Audio
Maximum distance between the BUS controller & the audio phone is 300m using C2-CABLE-PE cable (928-0568)
Maximum distance between the BUS controller & the audio door panel is 300m using C2-CABLE-PE cable (928-0568)
Video
Maximum distance between the BUS controller & the video monitor phone is 150m using C4-CABLE-PE cable (928-1058).
This can be extended by using another BUS controller.
Maximum distance between the BUS controller & the video door panel is 100m using C4-CABLE-PE cable (928-1058).
CAT5e cable can be used - contact Technical Sales Support for details
Failure to use the correct cable will result in poor picture quality, and will void any warranty applicable
All GF Video/Audio/Analogue & Digital systems are fully compatible with each other
AIPHONE (B.C. Technology) (2 Year Warranty)
17
Code
Trade
GH Series Digital Colour Video Entry
Aiphone GH 2-Wire (audio) and 4-Wire (video) BUS apartment system offers audio, monochrome and colour video and up to 16 entrances
with up to 500 apartment stations
The GH apartment system features a simple 2-wire or 4-wire BUS connection to all room stations throughout, enabling simple and quick set-up.
The entrance panel is vandal resistant diecast zinc with call buttons in a fully modular design with speech module and call switch module.
The GH audio system is the ideal communication solution for new and existing apartment applications.
All of the following kits are available in Stainless Steel with the option of a keypad or proximity reader. Other kit sizes are available.
GH Analogue Audio Flush kits
NEW
914-1095
GH-1A/F/KIT 1 way GH kit, including 1 button panel, controller, PSU and handsfree apartment station
NEW
914-1096
GH-2A/F/KIT As above - 2 way
NEW
914-1097
GH-4A/F/KIT As above - 4 way
GH Analogue Audio Surface kits
NEW
913-1075
GH-1A/S/KIT 1 way GH kit, including 1 button panel, controller, PSU and handsfree apartment station
NEW
913-1076
GH-2A/S/KIT As above - 2 way
NEW
913-1077
GH-4A/S/KIT As above - 4 way
GH-1AD
GH Analogue Video Flush kits (colour)
NEW
917-0778
GH-1V/F/KIT/COLOUR 1 way GH kit, including 1 button panel, controllers, PSU and handsfree apartment station
NEW
917-0779
GH-2V/F/KIT/COLOUR As above - 2 way
NEW
917-0780
GH-4V/F/KIT/COLOUR As above - 4 way
GH Analogue Video Surface kits (colour)
NEW
916-0648
GH-1V/S/KIT/COLOUR 1 way GH kit, including 1 button panel, controllers, PSU and handsfree apartment station
NEW
916-0649
GH-2V/S/KIT/COLOUR As above - 2 way
NEW
916-0650
GH-4V/S/KIT/COLOUR As above - 4 way
GH Digital Kits
NEW
914-1104
GH-ADGF/KIT 1 Way Digital Audio Kit, inc 1 x FLUSH Door Station, 1 x audio handsfree apartment station, BUS controller & PSU’s
NEW
913-1083
GH-ADGS/KIT 1 Way Digital Audio Kit, inc 1x SURFACE Door Station, 1 x audio handsfree apartment station, BUS controller & PSU’s
NEW
914-1105
GH-VDGF/KIT/COLOUR 1 Way Digital Video Kit, inc 1 x FLUSH Door Station, 1 x handsfree colour video apartment station, BUS controllers & PSU’s
NEW
913-1084
GH-VDGS/KIT/COLOUR 2 Way Digital Video Kit, inc 1 x SURFACE Door Station, 1 x handsfree colour video apartment station, BUS controllers & PSU’s
GH additional digital doorstations and component parts
NEW
915-1626
GH-ADGF Additional Digital Audio Door Station - FLUSH (24V dc PSU required)
NEW
915-1627
GH-ADGS Additional Digital Audio Door Station - SURFACE (24V dc PSU required)
NEW
915-1628
GH-VDGF Additional Digital Video Door Station - FLUSH (24V dc PSU required)
NEW
915-1629
GH-VDGS Additional Digital Video Door Station - SURFACE (24V dc PSU required)
NEW
915-1630
GH-1AD Audio handsfree apartment station
NEW
915-1631
GH-HS Optional handset for the GH-1KD colour video handsfree apartment station
NEW
915-1632
GH-1KD Colour video handsfree apartment station
NEW
915-1633
GH-4Z 4 way floor level distributor (eases wiring)
922-0047
PS-24N PSU 24V dc 1.8A
GH-1KD
CABLE SPECIFICATION for GF 2 & 4 Wire BUS systems
Audio
Maximum distance between the BUS controller and the furthest audio apartment station is 300m using C2-CABLE-PE cable (928-0568)
Maximum distance between the BUS controller and the furthest audio doorstation is 300m using C2-CABLE-PE cable (928-0568)
Video
Maximum distance between the BUS controller and the furthest video apartment station is 150m using C4-CABLE-PE cable (928-1058).
This can be extended by using another BUS controller.
Maximum distance between the BUS controller and the furthest video doorstation is 300m using C4-CABLE-PE cable (928-1058)
CAT5e cable can be used - contact Technical Sales Support for details
Failure to use the correct cable will result in poor picture quality, and will void any warranty applicable
AX SYSTEM
8 Master stations and a total of 120 doorstations using CAT5 cable. Audio or colour video communications. Can be integrated with CCTV
and access control systems.
NEW
915-1634
AX-DM Audio doorstation
NEW
918-0897
AX-DV Video doorstation - SURFACE mounted
NEW
918-0899
AX-DVF Video doorstation - FLUSH mounted
NEW
918-0900
AX-DV-P Video doorstation - SURFACE mounted with space for proximity reader (reader not included)
NEW
918-0901
AX-DVF-P Video doorstation - FLUSH mounted with space for proximity reader (reader not included)
NEW
918-0896
AX-8MV Colour video master monitor - 8 call
NEW
915-1624
AX-8M Audio master monitor - 8 call
NEW
915-1635
AX-16SW Add-on selector - 16 call
NEW
915-1623
AX-084C Central unit for 8 doors and 4 masters
NEW
915-1636
AX-248C Central unit for 24 doors and 8 masters
NEW
915-1637
AX-320C Add-on control unit for 32 doors
AX-DV
AX-8MV
Aiphone continued overleaf
For more information about our products, please call +353 (0) 1450 1366
Audio & Video Door Entry Systems
For larger systems please add relevant number of room stations required (max 500) and for additional doorstations add correct type
required (max 16).
Systems above 5 doorstations OR 48 apartment stations require additional parts. Contact Technical Sales Support for details.
The above kits are also available in Stainless Steel with keypad or proximity reader.
18
AIPHONE (B.C. Technology) (2 Year Warranty)
(continued)
Code
Trade
VIDEO DOOR ENTRY (MONOCHROME)
Pan and Tilt System (maximum 2 pan & tilt door stations & maximum of 3 monitors & handsets)
918-0110
MK-DAC Surface pan and tilt Infra-Red camera, pre set memory & lens
918-0002
MK-2MCD Master monitor & handset (MY-2CD)
918-0005
MK-2HCD Sub monitor & handset (MYH-2CD)
915-0035
MK-2SD Audio handset substation for MK-2MCD (MY-1HD)
922-0003
PS-18D Power supply 18V dc 1.8 Amp
915-0394
RY-3DL Door release switcher
913-0856
MK-D Surface mount, audio door station with brown plastic cover
922-0002
PS-12S PSU, 12V 1.5 Amp dc
Vandal Resistant Panels (including camera)
916-0004
CVFS-1 MK-DAC camera, V/R Stainless Steel FLUSH mount panel & button
918-0020
CVSS-1 MK-DAC camera, V/R Stainless Steel SURFACE mount panel & button
MK-DAC & VIDEO MONITOR
CABLE SPECIFICATION
Maximum distance between MK-DAC & MK-2MCD is 100m using C2-CABLE-PE
Maximum distance between MK-2MCD & furthest MK-2HCD is 75m using C6-CABLE-PE
VIDEO DOOR ENTRY (COLOUR)
KC Series Tilt camera system (maximum 1 camera to 3 monitors)
918-0089
KC-DAR Colour tilt camera door station, surface, for use with KC-1GRD only
918-0090
KC-1GRD Colour tilt master monitor/handset and all call facility
918-0091
KC-1HRD Colour tilt sub monitor/handset and all call facility
915-0263
KC-1SD Audio handset for use with KC-1GRD & KC-1HRD monitors
918-0092
KCFS-1 Flush 1 way V/R Stainless Steel panel, with colour tilt camera KC-DAR
918-0093
KCSS-1 Surface 1 way V/R Stainless Steel panel, with colour tilt camera KC-DAR
918-0094
KCFS-1+KPET Flush 1 way V/R Stainless Steel panel & keypad, with colour tilt camera KC-DAR
918-0095
KCSS-1+KPET Surface 1 way V/R Stainless Steel panel, with colour tilt camera KC-DAR
918-0116
KC-32EU Video memory unit
922-0047
PS-24N PSU 24V dc 1.8A
928-1058
C4-CABLE-PE-100 B. C. Tec 1mm diameter 4 core cable, 100m
bcR2 WIRING DIAGRAM
Failure to use PE suffixed cable will result in poor picture quality and void any warranty applicable
Audio & Video Door Entry Systems
JA series colour pan and tilt system (maximum 2 cameras to 3 monitors)
916-0557
JA-DAC Colour video doorstation with pan and tilt
916-0555
JA-2MCD Master colour monitor with pan and tilt
916-0554
JA-2HCD Sub colour monitor with pan and tilt
916-0556
JA-2MECD Master colour monitor with picture memory & pan and tilt
913-0957
JA-D Audio doorstation, plastic
917-0647
JAFS-1 1 way flush fitting Stainless Steel video panel including JA-DAC pan and tilt camera
913-0958
JASS-1 1 way surface fitting Stainless Steel video panel including JA-DAC pan and tilt camera
922-0047
PS-24N PSU 24V dc 1.8A
928-1058
C4-CABLE-PE-100 B. C. Tec 1mm C4 four core polyethylene cable, 100m
Failure to use the correct cable will result in poor picture quality and
void any warranty applicable
JA-2MCD
bcR2 Network interface for Aiphone KC & JA colour video doorstations. LAN remote operation
plus two CCTV inputs and four auxiliary outputs.
918-0719
bcR2 TCP/IP network interface for Aiphone colour video pan & tilt door entry system
JB series colour fixed system (maximum 2 cameras to 3 monitors)
918-0545
JB-DA Surface 1 way ABS plastic video door station for use with JB-2MD
916-0416
JB-DV Semi-vandal resistant surface-mounted door station for use with JB-2MD
917-0445
JB-DVF Semi-vandal resistant flush-mounted door station for use with JB-2MD
917-0473
JA-2SD Audio sub handset
917-0444
JB-2MD Master hands-free monitor
918-0518
JB-2HD Sub hands-free monitor
922-0003
PS-18D Power supply 18V dc 2 Amp
916-0469
JBS-2AD Boxed Set Including JB-DA, JB-2MD & Power supply
916-0459
JBS-2ADV Boxed Set Including JB-DV, JB-2MD & Power supply
917-0446
JBS-2ADVF Boxed set including JB-DVF, JB-2MD & Power supply
928-1058
C4-CABLE-PE-100 B. C. Tec 1mm C4 four core polyethylene cable, 100m
JB Series
Failure to use the correct cable will result in poor picture quality and void any warranty applicable
19
RNIB APPROVED DOOR ENTRY SYSTEMS
GF SERIES WIRING DIAGRAM
AIPHONE (B.C. Technology) (2 Year Warranty)
(continued)
Code
Trade
VIDEO DOOR ENTRY (COLOUR) (continued)
KB Series tilt camera system (maximum 3 cameras to 5 monitors)
918-0111
KB-DAR Colour tilt camera door station surface, for use with KB-3MRD only
918-0112
KB-3MRD Colour tilt master monitor/handset and all call facility
918-0113
KB-3HRD Colour tilt sub monitor/handset and all call facility
915-0289
KB-3SD Audio handset for use with KB-3MRD & KB-3HRD monitors
918-0114
KBFS-1 Flush 1 way V/R Stainless Steel panel, with colour tilt camera KB-DAR
918-0115
KBSS-1 Surface 1 way V/R Stainless Steel panel, with colour tilt camera KB-DAR
918-0116
KC-32EU Video memory unit
922-0047
PS-24N PSU 24V dc & 12V AC
928-1058
C4-CABLE-PE-100 B. C. Tec 1mm C4 four core polyethylene cable, 100m
Failure to use the correct cable will result in poor picture quality and void any warranty applicable
RNIB approved door entry systems designed to be in line with DDA requirements
Note: Complete 1 way kits include Stainless Steel door station, master monitor & PSU to RNIB standards
KCFS-1/RNIB/KIT 1 way kit including flush fitting Stainless Steel video panel with KC-DAR tilt camera
916-0558
KCSS-1/RNIB/KIT 1 way kit including surface fitting Stainless Steel video panel with KC-DAR tilt camera
917-0648
KBFS-1/RNIB 1 way flush fitting doorstation in Stainless Steel with KB-DAR tilt camera
916-0559
KBSS-1/RNIB 1 way surface fitting doorstation in Stainless Steel with KB-DAR tilt camera
CABLE SPECIFICATION
918-0721
KB-3MRD/RNIB KB series colour tilt master monitor, RNIB modified
918-0720
KB-3HRD/RNIB KB series colour tilt sub monitor, RNIB modified
915-1332
KB-3SD/RNIB KB series audio only sub monitor, RNIB modified
917-0646
CVFS-1/RNIB 1 way flush fitting doorstation in Stainless Steel with MK-DAC pan & tilt camera
916-0553
CVSS-1/RNIB 1 way surface fitting doorstation in Stainless Steel with MK-DAC pan & tilt camera
918-0723
MK-2MCD/RNIB MK series colour pan & tilt master monitor, RNIB modified
When ordering any KB,
KC or GF series
equipment you must
use C2-CABLE-PE
(928-0568) or
C4-CABLE-PE (928-1058).
If alternative cable is
used we cannot be
responsible should
any fault occur.
918-0722
MK-2HCD/RNIB MK series colour pan & tilt sub monitor, RNIB modified
915-1333
MK-2SD/RNIB MK series audio only sub handset, RNIB modified
Please note that variants of the above are available. Contact our Technical Sales Support Department for details
CABLE for Aiphone Video
928-1057
C2-CABLE-PE-100 B. C. Tec 1mm C2 polyethylene cable, 100m
928-0568
C2-CABLE-PE-200 B. C. Tec 1mm C2 polyethylene cable, 200m
928-1058
C4-CABLE-PE-100 B. C. Tec 1mm C4 polyethylene cable, 100m
928-1059
C4-CABLE-PE-200 B. C. Tec 1mm C4 polyethylene cable, 200m
927-1887
C6-CABLE-PE-100 B. C. Tec 1mm C6 polyethylene cable, 100m
All Aiphone equipment is available for various applications and larger systems are available.
Please contact our Technical Sales Support department for further information.
For more information about our products, please call +353 (0) 1450 1366
Audio & Video Door Entry Systems
917-0649
20
1
1
1
1
1
x
x
x
x
x
SPA1N
61
801
212
203
21
Door panel
Speech unit
Handset
PSU
Lock release
These kits come with an aluminium
surface panel, relevant number of
phones, power supply, rim release
& speech unit.
Surface panel up to 10 ways, flush
panels after 10 ways, but all panels
are available in flush.
Please contact technical sales
support for further information.
901N
901N WIRING DIAGRAM
901N KIT CONTENTS
901N 2 DOOR WIRING DIAGRAM
BELL SYSTEM (BSTL) (1 Year Warranty)
Code
Trade
Audio Door Entry
Surface 900 kits
913-0072
901N Audio door entry, 1 way surface system complete with rim release
913-0073
902N As above 2 way
913-0074
903N As above 3 way
913-0075
904N As above 4 way
913-0076
905N As above 5 way
913-0077
906N As above 6 way
913-0078
907N As above 7 way
913-0079
908N As above 8 way
913-0080
909N As above 9 way
913-0081
910N As above 10 way
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a 340C or PS4 PSU. Larger flush systems are available.
2 surface door panels to 1 phone system
913-0072
901N Audio door entry, 1 way surface system complete with rim release
915-0078
SPA1N Standard, 1 button surface aluminium panel
915-0076
61 Replacement speech/amplifier Unit
915-0059
719S Multi door switching Unit (one per every two door panels, requires model 225 PSU)
922-0006
225 Transformer 12V AC 2 Amp fused
921-0006
203 Rim release, 12V AC/dc, fail secure, 300kg holding force
2 surface door panels to 2 phones system
913-0073
902N Audio door entry, 2 way surface system complete with rim release
915-0077
SPA2N Standard, 2 button surface aluminium panel
915-0076
61 Replacement speech/amplifier Unit
915-0059
719S Multi door switching Unit (one per every two door panels, requires model 225 PSU)
922-0006
225 Transformer 12V AC 2 Amp fused
921-0006
203 Rim release, 12V AC/dc, fail secure, 300kg holding force
914-0059
901FN Audio door entry, 1 way flush system complete with rim release
914-0060
902FN As above 2 way
914-0061
903FN As above 3 way
914-0062
904FN As above 4 way
914-0063
905FN As above 5 way
914-0064
906FN As above 6 way
914-0065
907FN As above 7 way
914-0066
908FN As above 8 way
914-0067
909FN As above 9 way
914-0068
910FN As above 10 way
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a 340C
or PS4 PSU. Larger systems are available.
Surface 900 kits including trade facility
These system kits come with the relevant number of call buttons on the panel, telephones
and an extra button for trade, TS2000-BST 7 day quartz time clock, power supply, speech
unit & rim release.
913-0096
903TN Audio door entry, 3 way surface system including trade facility complete with rim release
913-0097
904TN As above 4 way
913-0098
905TN As above 5 way
913-0099
906TN As above 6 way
913-0100
907TN As above 7 way
913-0101
908TN As above 8 way
913-0102
909TN As above 9 way
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a 340C
or PS4 PSU. Flush boxes are available for the above kits, larger kits are available in FLUSH ONLY.
Bell System continued overleaf
For more information about our products, please call +353 (0) 1450 1366
Audio & Video Door Entry Systems
Flush 900 kits
22
AVAILABLE LOCK OUTPUTS
FOR KIT RANGES
VRP PANELS
LASER CUT PANEL
PRODUCT
12V AC
900 Series
•
VRK Series
•
12V dc
Fail Secure
Fail Safe
•
•
LCK Series
•
•
CK109
•
•
•
CK110
•
•
•
CS109 Series
•
•
•
CS106 Series
•
•
•
BellSwipe BS500
•
•
•
BELL SYSTEM (BSTL) (1 Year Warranty)
(continued)
Code
Trade
Belltone Interface door entry system
The Belltone interface allows for connection of a door entry panel to a standard household BT style telephone or to a PABX. A lock release can
be triggered from the BT style telephone.
Belltone Surface system
913-0304
BT901 Belltone entry system with telephone interface (BT1), 1 button surface panel (SPA1N), speech unit (61), power supply (340C)
and a lock release (203)
The above kit has a lock output @ 12V dc.
Belltone Interface
915-0545
BT1 Belltone dialling interface unit
Surface 900 BRASS kit
913-0107
901BN Audio door entry, 1 way surface system complete with rim release
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a
340C or PS4 PSU. Larger systems are available with or without trade facilities.
Vandal Resistant FLUSH kits
914-0027
VRK1 Audio door entry, 1 way vandal resistant system complete with rim release
914-0048
VRK2 As above 2 way
914-0049
VRK3 As above 3 way
914-0050
VRK4 As above 4 way
914-0051
VRK5 As above 5 way
914-0052
VRK6 As above 6 way
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a
340C or PS4 PSU. Larger systems are available with or without trade facilities.
VRK4
Surface Vandal Resistant boxes
S1 Surface box size 1, generally for panels up to 6 buttons (depending on engraving & button layout)
915-0579
S2 Surface box size 2, generally for panels with 7 - 12 buttons (depending on engraving & button layout)
915-0580
S3 Surface box size 3, generally for panels with 13 - 18 buttons (depending on engraving & button layout)
915-0581
S4 Surface box size 4, generally for panels with 19 - 36 buttons (depending on engraving & button layout)
Vandal Resistant SURFACE kits
Audio & Video Door Entry Systems
915-0578
913-0230
VRK1S Audio door entry, 1 way vandal resistant system complete with rim release
913-0231
VRK2S As above 2 way
913-0232
VRK3S As above 3 way
913-0233
VRK4S As above 4 way
913-0234
VRK5S As above 5 way
913-0235
VRK6S As above 6 way
VRK7S & TRADE FACILITY
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a 340C or PS4 PSU. Larger systems are available
with or without trade facilities.
Panel mount proximity readers can be integrated into Vandal Resistant panels (special order Only). However, systems requiring
the PAC 20049 panel mount reader may incur an additional charge. Please contact our Technical Sales Support Department
for further information.
2 door panels to 1 phone system (choose either flush or surface option)
914-0027
VRK1 Audio door entry, 1 way FLUSH vandal resistant system complete with rim release
915-0151
VRP1 Vandal Resistant FLUSH panel, 1 button
913-0230
VRK1S Audio door entry, 1 way SURFACE vandal resistant system complete with rim release
915-0489
VRP1S Vandal Resistant SURFACE panel, 1 button
915-0076
61 Replacement speech/amplifier Unit
915-0059
719S Multi door switching Unit (one per every two door panels, requires model 225 PSU)
922-0006
225 Transformer 12V AC 2 Amp fused
921-0006
203 Rim release, 12V AC/dc, fail secure, 300kg holding force
23
DDA-1
DDA-EXT-1
CK200
BELL SYSTEM (BSTL) (1 Year Warranty)
CK109
(continued)
Code
Trade
Vandal Resistant BRASS flush kits
914-0196
VRKB1 Audio door entry, 1 way vandal resistant Brass system complete with rim release
914-0197
VRKB2 As above 2 way
914-0198
VRKB3 As above 3 way
914-0199
VRKB4 As above 4 way
914-0200
VRKB5 As above 5 way
914-0201
VRKB6 As above 6 way
The above kits have a lock output @ 12V AC. They can be changed to 12V dc by adding a 340C or PS4 PSU. Larger systems are available with or without trade facility.
Laser cut flush panel ONLY (these panels require a model 61 speech/amplifier unit & system accessories)
915-0153
LCP1 Vandal Resistant panel 1 button, with laser cut bezel & back box (requires 61 amplifier)
915-0154
LCP2 As above 2 buttons
915-0491
LCP3 As above 3 buttons
915-0181
LCP4 As above 4 buttons
915-0182
LCP5 As above 5 buttons
915-0183
LCP6 As above 6 buttons
Larger panels are available. The panels can come with a keypad or panel mount reader cut out or trade facility
Panel mount proximity readers can be built into Bell System Vandal Resistant panels (special order Only).
DISABILITY DISCRIMINATION ACT (DDA) 1995 entry panels
The DDA kits come with either a 1 button FLUSH or SURFACE Stainless Steel DDA panel with illuminated call button in Braille and indicator lights, an integral speech unit,
a 12V dc power supply, a model 801 wall mount telephone and a fail-secure lock release.
914-0657
DDA-1 Audio door entry, 1 way FLUSH vandal resistant DDA system complete with rim release
913-0698
DDA-1S Audio door entry, 1 way SURFACE vandal resistant DDA system complete with rim release
DDA long panel with 2 call buttons
DDA-EXT-1 1 station FLUSH door entry system, including DDA long FLUSH panel with two buttons, 340C PSU, 1x 801 telephone, speech unit and
rim release
914-0740
DDA-EXT-1S 1 station SURFACE door entry system, including DDA long SURFACE panel with two buttons, 340C PSU, 1x 801 telephone, speech unit
and rim release
The above kits have a lock output @ 12V dc. DDA kits are available for multi station applications. Other options include systems combined with Paxton Compact proximity
readers or coded access keypads. Video systems are also available.
Bellcode Secure coded access control with a touch sensitive keypad
The Bellcode is a SECURE coded keypad system with an independent controller and a touch sensitive keypad
with no moving parts (Piezo technology), waterproof and rated to IP68. Ten user codes, hosts of programming
options - 12V dc, lock output @ 500mA.
Bellcode system
905-0035
CK200 Bellcode coded entry system with keypad (218),
controller (200), power supply (340C)
and a lock release (203)
Bellcode ancillaries
905-0036
218 Bellcode touch sensitive surface keypad
911-0202
200 Bellcode boxed controller
911-0203
201 Bellcode controller for second door (PCB only)
Secure coded access control
CK200 WIRING DIAGRAM
218
906-0001
CK109 Coded entry system with Stainless Steel vandal resistant surface keypad, power
supply, rim release and controller (200) for up to 2 keypads, 2 user codes 1-8 digits per door
906-0007
CK110 As above with slimline Stainless Steel keypad (model 217)
905-0003
216 Stainless Steel vandal resistant surface keypad for use with the above kits
905-0020
216F Stainless Steel vandal resistant flush keypad for use with the above kits
905-0022
217 Slimline Stainless Steel vandal resistant surface keypad for use with the above kits
CK109 WIRING DIAGRAM
Bell System continued overleaf
For more information about our products, please call +353 (0) 1450 1366
Audio & Video Door Entry Systems
914-0739
25
CSP-4
CSP-8/VR
BELL SYSTEM (BSTL) (1 Year Warranty)
TS2000-BST
(continued)
Code
Trade
Additional cards and keyfobs for CSP systems
926-0398
830-010G PROXIMITY 10 card pack Green
926-0386
820-010G PROXIMITY 10 keyfob pack Green
Larger card and keyfob packs can be purchased in quantities of 25’s, 50’s and 100’s. Please refer to the Paxton Standalone Proximity
sections on page 85 for more information.
Accessories
Audio handsets
915-0033
801 Standard wall mounted telephone for 900 & VRK systems
915-0057
801S Standard wall mounted telephone with call tone mute switch
915-0155
801P Standard wall mounted telephone with privacy of speech
915-0156
801PS Standard wall mounted telephone with privacy of speech & call tone mute switch
NEW
915-1658
801-DESK Standard desk mounting telephone
NEW
915-1659
BS-A Bellissimo audio telephone for extension to video systems and bellcall digital system
NEW
915-1660
BS-LX Bellissimo audio telephone with mute switch, LED indicator & Door Open indicator
915-0042
500A Wall mounted telephone 2 buttons, AC
915-0030
500D Wall mounted telephone 2 buttons, dc for combined and LCK systems
915-0043
500X As above, inc. buzzer mute push-button (privacy) & L.E.D. indicator
915-0161
500LX Wall mounted dc telephone with buzzer mute switch, LED indicator & Door Open indicator
915-0157
500A-Desk Desk mounted 500A telephone
915-0158
500D-Desk Desk mounted 500D telephone
Loud speaker apartment stations
915-0159
LS47 Loudspeaking apartment station (wall mounting - requires 12V dc)
915-0160
LSD47 Loudspeaking apartment station (desk mounting - requires 12V dc)
915-0034
212 Transformer 12V AC 1 Amp fused
922-0006
225 Transformer 12V AC 2 Amp fused
922-0186
340C PSU, 12V dc 1.5 Amp
922-0185
PS4 PSU, 12V dc 4 Amp
922-0032
640 PSU, 12V dc 1 Amp standby power supply complete with 2.1 A/H battery
Amplifiers
915-0032
51 Old style replacement speech/amplifier Unit
915-0076
61 Replacement speech/amplifier Unit
Relays & audio ancillaries
927-0044
88 12V AC, 1 pole change over relay, contact rating 10A @ 30V dc, boxed
927-0045
89 12V dc, 1 pole change over relay, contact rating 10A @ 30V dc, boxed
927-0186
LT88 Single shot timer, 4-40 seconds, 1 pole change over boxed relay
927-0196
HT88 Single shot timer, 1 sec up to 10 hours, 1 pole change over boxed relay
928-0253
RT27 Extension sounder for all telephones
915-0059
719S Multi door switching Unit (one per every two door panels, requires model 225 PSU or 440 PSU, depending on telephones used)
915-0083
SG1 Extension sound generator, timed and 8 options of tone 10-15V AC or 10-21V dc
927-0229
TS2000-BST 12V AC/dc, quartz crystal time clock with automatic European Time Settings, isolated contacts, 7 day programming
915-0082
62 Hex bit 1/4” for new style SPA surface panels
915-0281
62F Hex bit 1/4” for new style SPA flush panels
915-0081
63 V/R screw for new style SPA panels
915-0322
SPA-LAMP Lamp module for connection to the push button on standard panels, 1 module will back-light 1 pushbutton
Bell System continued overleaf
Audio & Video Door Entry Systems
Transformers & Power Supplies
26
BS1-C
BS-C MONITOR
BSP4VR-C PANEL
BS4-C
BELL SYSTEM (BSTL) (1 Year Warranty)
(continued)
Code
Trade
COLOUR VIDEO DOOR ENTRY “BELLISSIMO” (NON COAXIAL)
NEW
916-0660
BS1-C COLOUR Video door entry, 1 way surface system complete with rim release
NEW
916-0661
BS2-C As above 2 way
NEW
916-0662
BS3-C As above 3 way
NEW
916-0663
BS4-C As above 4 way
NEW
916-0664
BS5-C As above 5 way
NEW
916-0665
BS6-C As above 6 way
NEW
916-0666
BS7-C As above 7 way
NEW
916-0667
BS8-C As above 8 way
NEW
916-0668
BS9-C/VR V/R 9 way flush kit, inc Stainless Steel flush panel, monitor/phone, PSU & rim release
NEW
916-0669
BS10-C/VR As above 10 way flush
NEW
916-0670
BS11-C/VR As above 11 way flush
NEW
916-0671
BS12-C/VR As above 12 way flush
BS1-C WIRING DIAGRAM
The above kits include relevant number of video telephones (BS), BSP panel, speech unit, power supply, controllers and rim release.
All kits above 8 ways come standard with a Vandal Resistant Stainless Steel flush panel but can be made surface if required
Larger systems are available, with or without TRADE, also in Stainless Steel or Brass. Combined proximity or coded access options are available.
The above kits have a lock output @ 12V dc.
2 doors to 1 phone system
NEW
916-0660
BS1-C Video door entry, 1 way surface system complete with rim release
NEW
918-0912
BSP1-C Video panel 1 way, camera with LED lighting & speech unit
922-0191
BSD1 Video Panel Controller, 1 required for each panel, for 1 way systems ONLY
921-0006
203 Rim release, 12V AC/dc, fail secure, 300kg holding force
Audio & Video Door Entry Systems
Vandal Resistant COLOUR video kits
Flush
NEW
917-0812
BS1-C/VR V/R 1 way FLUSH kit, inc Stainless Steel flush panel, monitor/phone, PSU & rim release
NEW
917-0813
BS2-C/VR As above 2 way
Surface
NEW
916-0672
BS1-C/VR/S V/R 1 way SURFACE kit, inc Stainless Steel flush panel, monitor/phone, PSU & rim release
NEW
916-0673
BS2-C/VR/S As above 2 way
The above kits have a lock output @ 12V dc. Larger systems are available, also in brass. also combined with keypad.
COLOUR Video Digital Systems
NEW
918-0914
BSP-DIG-C/VR Vandal Resistant Digital video panel flush (requires BSD-DIG Controller)
NEW
918-0915
BSP-DIG-C/VRS Vandal Resistant Digital video panel surface (requires BSD-DIG Controller)
NEW
918-0916
BSP-DIG-C/LCP Vandal Resistant Digital LCP style video panel flush (requires BSD-DIG Controller)
NEW
918-0700
BSD-DIG Digital panel controller
NEW
918-0917
BS-C Bellissimo COLOUR video monitor handset (wall mounting)
918-0579
BSC4 Telephone controller for up to 4 x BS-C video telephones - not required on a single button system
922-0185
PS4 12V dc 4A PSU for Bellissimo systems
Accessories
NEW
918-0917
BS-C Bellissimo COLOUR video monitor handset (wall mounting)
NEW
918-0918
BS-DESK-C COLOUR Bellissimo desk mounting video telephone
NEW
915-0659
BS-A Bellissimo audio telephone for extensions
NEW
918-0919
BSP1VR-C V/R 1 way flush video Stainless Steel panel, inc camera
NEW
918-0920
CAMBS-C COLOUR Camera module for Bellissimo entry systems
922-0191
BSD1 Video Panel Controller, 1 required for each panel, for 1 way systems ONLY
918-0707
BSD8 Video Panel Controller, 1 required for each panel, for panels up to 8 buttons
918-0637
BSD72 Video Panel Controller, 1 required for each panel, for panels up to 72 buttons
918-0700
BSD-DIG Digital panel controller
918-0579
BSC4 Telephone controller for up to 4 x BS-C video telephones - not required on a single button system
922-0185
PS4 12V dc 4A PSU for Bellissimo systems
NEW
For more information about our products, please call +353 (0) 1450 1366
5
9.50
27
Bellcall BCP1
BS-C MONITOR
Bellcall BC801
BELL SYSTEM (BSTL) (1 Year Warranty)
(continued)
Code
Trade
Bellissimo systems requiring a separate/additional camera
The CCTV cameras below have all been tested and are recommended for use with Bellissimo video systems.
VANTAGE ‘G’ Series DSP 1/3” Colour camera (3 year warranty)
308-1030
VGC450D 520 Line, 0.5 Lux colour camera, DD, AMP, BLC (on/off), CS, DIP, 90-260V AC
Lens for above camera
310-0165
VD35803 3.5-8mm, f1.4, Varifocal lens, (Long Lead)
Impact Resistant Evolution Colour/mono dome
326-0907
VSCM520IR 1/3”, Spartan, high resolution colour/mono impact dome, moving IR cut filter, 3.6 - 9mm auto iris varifocal lens, built in IR LED
array. 0 Lux with LED’s ON, 12V dc power supply required.
CABLE SPECIFICATION
Cable specification is dependant on system layout and distances required. Please contact our Technical Sales Support department for further information.
Bellcall Digital Door Entry system
The Bellcall Digital door entry system allows for up to 128 telephones
to be connected to a digital entrance panel with 6 common wires.
The panel incorporates a large LED display. Additional panels can be
connected on the same 6 wires without the need for additional
equipment. The lock output for the Bellcall system is 12V dc. Bellcall
Video systems are now available with Bellissimo video telephones prices on application. (A complete audio system would comprise of
one BCP1 panel, the required number of BC801 telephones, power
supply and optional lock release).
Bellcall Stainless Steel Audio panels
BCP1 Bellcall SURFACE Stainless Steel Digital audio entry panel
915-0543
BCP1/F Bellcall FLUSH Stainless Steel Digital audio entry panel
915-1532
S-BCP Steel surface housing for above
915-0544
BC801 Bellcall wall mounting audio telephone
915-1659
BS-A Telephone with mute switch, LED and Door Open Indications (Door Open Indication on VR panels only)
NEW
Bellcall Stainless Steel Audio panels
NEW
915-1654
BCP1/VR Vandal Resistant panel flush (requires a BSD-DIG )
NEW
918-0921
BCP1/VRS Vandal Resistant panel surface (requires a BSD-DIG )
NEW
915-1661
BCP1/LCP Vandal Resistant LCP style panel flush (requires a BSD-DIG )
NEW
918-0700
BSD-DIG Digital panel controller
NEW
Bellcall Audio telephone
Bellcall WIRING DIAGRAM
Bellcall PSU’s
922-0185
PS4 12V dc 4A PSU for single entrance Bellcall systems with less than 60 telephones
922-0058
1385N 12V dc 5 Amp backup power supply for any single entrance Bellcall system
For multi-panel applications please contact our Technical Sales Support Team for a suitable PSU.
CABLE SPECIFICATION for Bellcall systems
Cable specifications depend on the number of telephones, distances and system layout. Please contact our Technical Sales Support department
for full specifications.
BSX and DAX Isolated Exchange Systems
The BSX & DAX Isolated exchange systems are highly specified door entry systems for use in Public Housing or any location prone to high
levels of vandalism. These systems operate on an exchange principle and any damage to a telephone or its cables will not effect the operation
of the rest of the system.
The DAX digital door entry telephone system is designed primarily for large blocks of flats where a conventional door entry panel may be
impractical due to its size. The DPX panel has a simple 16-button keypad for typing the flat numbers (including alpha characters A - Z) and a
clear, large character, liquid-crystal display (LCD) or Light Emitting Diode (LED) which provides user-friendly messages and instructions.
Please contact Technical Sales Support for further information.
Audio & Video Door Entry Systems
915-0542
28
For more information about our products, please call +353 (0) 1450 1366
B.P.T. (1 Year Warranty (2 Year Warranty on all the Lynea range of equipment))
Code
29
Trade
Audio Door Entry
Targha Surface audio entry panels with Lynea Handsets and PSUs
Prices include a Targha surface entry panel, the relevant number of YC/200UK
Lynea handsets & PSU. No release.
913-0640
VSET1N/HPYCUK Kit, surface Targha slim line aluminium entry panel 1 way,
1 x YC/200UK Lynea handset & PSU. No release
913-0641
VSET2N/HPYCUK As above 2 way
913-0642
VSET3N/HPYCUK As above 3 way
913-0643
AKIT/4TARYC Surface Targha slim line aluminium entry panel HSC/4ST,
4 x YC/200UK Lynea handsets & A/200N PSU. No release
Targha surface audio entry panel with integrated illuminated
access keypad, Lynea handset and PSU
AUDIO DOOR ENTRY PANELS
The price includes a Targha surface entry panel including illuminated keypad,
the stylish YC/200UK Lynea handset & PSU. No release.
913-0645
VSET1N/HNA Surface Targha, aluminium slim line entry panel including keypad,
1 x Lynea handset & PSU. No release
Note: Larger kits are available. Contact our Technical Sales Support
department for details.
Targha Surface audio entry panels with NOVA audio receivers and PSUs
Prices include a Targha surface entry panel, the award winning, flush, graphite
Nova apartment station & PSU. No release.
913-0646
AKIT/1TARNOV Surface Targha slim line aluminium entry panel HSC/1ST,
1 x Nova receiver & A/200N PSU. No release
913-0647
AKIT/2TARNOV As above 2 way, with HSC/2ST panel & 2 Nova receivers
913-0648
AKIT/3TARNOV As above 3 way, with HSC/3ST panel & 3 Nova receivers
AUDIO DOOR ENTRY HANDSETS
Note: the Nova receiver is made up of 1 x NSI/3M, NS/3V, NC/221PAGR & NPP/3VGR. Colour options are available.
Targha vandal resistant audio entry panel kits with Lynea handset and PSU
Prices include a Targha surface entry panel, the award winning, flush, graphite Nova apartment station & PSU. No release.
NEW
915-1365
AKIT/1TARVR Targha vandal resistant entry panel 1 way, 1 x YC/200UK Lynea handset & PSU. No release
NEW
914-1112
AKIT/2TARVR Targha vandal resistant entry panel 2 way, 2 x YC/200UK Lynea handset & PSU. No release
NEW
914-1109
AKIT/3TARVR Targha vandal resistant entry panel 3 way, 3 x YC/200UK Lynea handset & PSU. No release
Vandal resistant flush audio entry panels with Lynea handsets
Prices include a vandal resistant flush entry panel, the stylish YC/200UK Lynea handset & PSU. No release.
914-0623
AKIT/1VRYC Vandal resistant, flush audio entry panel VRA/1, 1 x YC/200UK Lynea handset & A/200N PSU. No release
914-0624
AKIT/2VRYC As above 2 way, with VRA/2 panel
914-0625
AKIT/3VRYC As above 3 way, with VRA/3 panel
918-0346
VRSH/1 Vandal resistant surface housing, add to the above kits to surface mount
Vandal resistant flush audio panels with integrated access keypad & Lynea Handsets
914-0626
AKIT/1VRACYC Vandal Resistant, flush audio entry panel with keypad VRAK/1, 1 x YC/200UK Lynea handset & A/200N PSU. No release
914-0627
AKIT/2VRACYC As above 2 way, with VRAK/2 panel/keypad
914-0628
AKIT/3VRACYC As above 3 way, with VRAK/3 panel/keypad
912-0131
VRSH/2 Vandal resistant surface housing, add to the above kits to surface mount
Vandal resistant flush mount audio entry panels with proximity reader cut out & Lynea handsets
Prices include a vandal resistant flush panel incorporating a proximity reader cut out, the stylish YC/200UK Lynea handset & PSU. No release.
914-0629
AKIT/1VRIMPYC Vandal Resistant, flush audio entry panel with proximity cut-out VRAP/1, 1 x YC/200UK Lynea handset & A/200N PSU. No release
914-0630
AKIT/2VRIMPYC As above 2 way, with VRAP/2 panel with proximity cut-out
914-0631
AKIT/3VRIMPYC As above 3 way, with VRAP/3 panel with proximity cut-out
918-0346
VRSH/1 Vandal resistant surface housing, add to the above 1 & 2 way kits to surface mount
912-0131
VRSH/2 Vandal resistant surface housing, add to the above 3 way kit to surface mount
Targha Digital entry panels
928-0261
HAC/200ST Targha digital panel, requires Targha audio entry panel and HTS recess backbox
913-0456
HSC/0ST Targha audio entry panel, aluminium, surface mount, 0 button
915-1329
HAC/200VR Targha vandal resistant digital panel, requires targha vandal resistant audio entry panel and HTS/VR recess backbox
915-1334
HPC/1VR Targha audio, vandal resistant, surface mount entry panel, 1 button
915-0305
HA/200 Audio Module
927-0980
HTS/GR Targha Panel Back box
915-0675
HTS/VR Vandal resistant Targha panel back box
Vandal Resistant Digital entry panels
914-0860
VRAD/200 Vandal Resistant audio digital entry panel, includes HAC/200 keypad and audio module
915-1330
VRAD/200IMP Vandal Resistant audio digital entry panel, includes HAC/200 keypad, prox cut out and audio module
B.P.T. continued overleaf
Audio & Video Door Entry Systems
Prices include a vandal resistant flush entry panel including keypad, the stylish YC/200UK Lynea handset & PSU. No release.
B.P.T. (1 Year Warranty (2 Year Warranty on all the Lynea range of equipment)) (continued)
30
Code
Trade
DISABILITY DISCRIMINATION ACT (DDA) 1995 entry panels with PSU and handsets
Panels include large, illuminated tactile/braille button, ‘speak now’ and ‘door open’ LEDs and audible indication of lock release.
914-0808
AKIT/1DDAYC V/R, DDA flush audio panel VRADDA/1, 1 x AZ98DDA audio group, 1 x YC/200UK Lynea handset & A/200N PSU. No release
914-0809
AKIT/1DDAPYC V/R, DDA flush audio panel c/w prox cut-out VRAPDDA/1, 1 x AZ98DDA audio group, 1 x YC/200UK handset & A/200N PSU. No release
914-0810
AKIT/1DDAKYC V/R, DDA flush audio panel c/w keypad VRAKDDA/1, 1 x AZ98DDA audio group, 1 x YC/200UK handset & A/200N PSU. No release
Disability Discrimintation Act (DDA) 1995 Digital and Dual Height Entry Panels
915-1325
VRAD/KEDDA Vandal Resistant audio digital entry panel, includes braille dewhurst keypad
915-1326
VRAD/KEDDADUAL Vandal Resistant audio digital entry panel, includes braille dewhurst keypad - Dual Height
915-1327
VRAD/KEPDDA Vandal Resistant audio digital entry panel, includes HAC/200 keypad and prox cut-out
915-1328
VRAD/KEPDDADUAL Vandal Resistant audio digital entry panel, includes HAC/200 keypad - Dual Height
915-1107
AZ/98DDA Audio Module for DDA Panels
Audio handsets & receivers
915-0963
YC/200UK Surface mounted Lynea audio handset includes large lock release button and auxillary button, white
915-0964
YC/200AUK Surface mounted Lynea audio handset includes large lock release button and space for aux/intercom, white
915-1016
NOVA3MGR Nova audio flush receiver with lock release button and auxillary button, grey with back box for brick
915-1017
NOVA3PLGR Nova audio flush receiver with lock release button and auxillary button, grey with back box for plaster board
915-1018
NOVA3MBB Nova audio flush receiver with lock release button and auxillary button, white with back box for brick
913-0463
NOVA3PLBI Nova audio flush receiver with lock release button and auxillary button, white with back box for plaster board
915-0284
XC/200 Surface mounted Exedra audio handset with lock release button and auxillary buttons
Note: the Nova receiver is made up of 1 x NSI/3M, NS/3V, NC/221PAGR & NPP/3VGR. Colour options are available.
Control equipment
922-0034
A/200N Main PSU/Control unit, powers a maximum of 3 handsets on the same call button
922-0046
AS/200 Additional PSU powers a maximum of 3 handsets on the same call button
915-0262
BC/200 Call booster for up to 7 handsets on the same call button (must be used with an AS/200)
915-0305
HA/200 Audio module to accompany Targha and Vandal Resistant audio entry panels
915-0286
IT/200 Telephone interface - allows the connection of an entry panel to a BT line
915-0260
SI/200 Entrance selector, 1 required per additonal entrance (requires AS/200)
927-0014
TT/2 Tradesman timer with LCD display, 7 day timer, 6 daily on/off times, many features
Video Door Entry
Targha surface video entry panels with YVF/200UK surface monitors
Prices include a Targha, surface, aluminium video entry panel, the stylish YVF/200UK surface Lynea monitor with 4.5” screen & PSU. No release.
916-0362
VSET/200YVF-1HSV Kit. Targha aluminium video entry panel HSV/1ST, HAV/200 camera,
YVF/200UK Lynea monitor & VA/200 PSU. No release
916-0363
VKIT/2TARYVF Targha video panel HSV/2ST, HAV/200 camera, 2 x YVF/200UK Lynea monitor,
1 x VAV/400 video distributor & VA/200 PSU. No release
916-0364
VKIT/3TARYVF As above 3 way, with HSV/4DST panel
Targha surface video entry panels with YVFC/200UK colour surface monitors
Audio & Video Door Entry Systems
Prices include a Targha, surface, aluminium video entry panel, the stylish YVFC/200UK
colour surface Lynea monitor with 4.5” screen & PSU. No release.
916-0493
VSET/200YVC-1HPV Kit. Targha aluminium video entry panel HSV/1ST, HAV/200 camera,
YVFC/200UK Lynea monitor & VA/200 PSU. No release
918-0709
VKIT/2TARYVFC Targha video panel HSV/2ST, HAV/200 camera, 2 x YVFC/200UK
Lynea monitor, 1 x VAV/400 video distributor & VA/200 PSU. No release
918-0710
VKIT/3TARYVFC As above 3 way, with HSV/4DST panel
VIDEO DOOR PANELS
Ophera X1 2 wire kit with the Ophera monitor with
tilting 3.5" swivel mount, full colour screen
917-0642
OPHERAKIT/01 Targha X1 recessed entry panel with colour camera, the Ophera semi-recessed,
colour monitor with a choice of three coloured front plates, embedding box and optional intercom
module plus VA/301 PSU
Targha surface video entry panels with the flush, award winning
Colour Nova wall monitors in graphite
Prices include a Targha surface, colour video entry panel, the flush colour Nova wall monitor
with 2” screen in graphite & PSU. No release.
916-0367
VKIT/1TARNOV Targha aluminium video entry panel HSV/1ST, HAVC/200 colour camera,
Nova monitor & VA/200 PSU. No release
916-0368
VKIT/2TARNOV As above 2 way, with HSV/2ST panel
916-0369
VKIT/3TARNOV As above 3 way, with HSV/4DST panel
OPHERA MONITORS
Note: the Nova monitors consist of the following; NSI/6M, NS/6, NC/221PAGR, NPP/6VGR & NVM/200. Colour options are available.
Targha vandal resistant video entry panels with YV & YKP/200 black and white monitors
Prices include a Targha, surface, aluminium video entry panel, the stylish YV & YKP/200 black & white surface Lynea monitor with 4.5” screen & PSU. No release.
NEW
917-0807
VKIT/1TARVRYVF Targha vandal resistant entry panel 1 way, 1 x YVF/200UK Lynea monitor & PSU. No release
NEW
917-0801
VKIT/2TARVRYVF Targha vandal resistant entry panel 2 way, 2 x YVF/200UK Lynea monitor & PSU. No release
NEW
917-0808
VKIT/3TARVRYVF Targha vandal resistant entry panel 3 way, 3 x YVF/200UK Lynea monitor & PSU. No release
For more information about our products, please call +353 (0) 1450 1366
B.P.T. (1 Year Warranty (2 Year Warranty on all the Lynea range of equipment)) (continued)
Code
31
Trade
Targha vandal resistant video entry panels with YVC & YKP/200 colour surface monitors
Prices include a Targha, vandal resistant video entry panel, the stylish YV & YKP/200 colour surface Lynea monitor with 4.5” screen & PSU. No release.
NEW
917-0802
VKIT/1TARVRYVFC Targha vandal resistant entry panel 1 way, 1 x YVFC/200UK Lynea colour monitor & PSU. No release
NEW
917-0803
VKIT/2TARVRYVFC Targha vandal resistant entry panel 2 way, 2 x YVFC/200UK Lynea colour monitor & PSU. No release
NEW
917-0804
VKIT/3TARVRYVFC Targha vandal resistant entry panel 3 way, 3 x YVFC/200UK Lynea colour monitor & PSU. No release
Vandal resistant flush video entry panels with YVF/200UK surface wall monitors
Prices include a Vandal Resistant flush video entry panel, the stylish YVF/200UK Lynea surface wall monitor with 4.5” screen & PSU. No release.
917-0381
917-0382
917-0383
918-0346
VKIT/1VRYVF V/R video panel VRV/1, HAV/200 camera, 1 x YVF/200UK Lynea monitor & VA/200 PSU. No release
VKIT/2VRYVF As above 2 way, with VRV/2 panel & 1 x VAV/400 video distributor
VKIT/3VRYVF As above 3 way, with VRV/3 panel & 1 x VAV/400 video distributor
VRSH/1 Vandal resistant surface housing, add to the above panels to surface mount
Vandal resistant flush video entry panels including keypad with YVF/200UK
surface wall monitors
Prices include a Vandal Resistant flush video panel incorporating keypad, the stylish YVF/200UK Lynea surface wall monitor with 4.5” screen & PSU. No release.
917-0384 VKIT/1VRACYVF V/R video panel VRVK/1, HAV/200 camera, 1 x YVF/200UK Lynea monitor & VA/200 PSU. No release
917-0385 VKIT/2VRACYVF As above 2 way, with VRVK/2 panel & 1 x VAV/400 video distributor
917-0386 VKIT/3VRACYVF As above 3 way, with VRVK/3 panel & 1 x VAV/400 video distributor
912-0131 VRSH/2 Vandal resistant surface housing, add to the above 1 & 2 way kits to surface mount
918-0316 VRSH/3 Vandal resistant surface housing, add to the above 3 way kit to surface mount
DISABILITY DISCRIMINATION ACT (DDA) 1995 entry panels with PSU and handsets
Panels include large, illuminated tactile/braille button, ‘speak now’ and ‘door open’ LEDs and audible indication of lock release. No release.
Surface housings available.
917-0508
917-0509
917-0510
VKIT/1DDAYVF V/R, DDA flush video panel VRVDDA/1, AZ98DDA audio group, MVT/100 camera, 1 x YVF/200UK Lynea monitor & VA/200 PSU.
VKIT/1DDAPYVF V/R, DDA flush panel with prox cut out VRVPDDA/1, AZ98DDA audio, MVT/100 camera, 1 x YVF/200UK Lynea monitor & VA/200 PSU.
VKIT/1DDAKYVF V/R, DDA flush panel with keypad VRVKDDA/1, AZ98DDA audio, MVT/100 camera, 1 x YVF/200UK Lynea monitor & VA/200 PSU.
Note: the YVF/200UK Monitor is made up of YKP/200UK back plate and YV/200 monitor
Targha Digital entry panels
NEW
928-0261
HAC/200ST Targha digital panel, requires Targha entry panel and HTS recess backbox
NEW
913-0388
HSV/0ST Targha video entry panel, aluminium, surface mount, No buttons
NEW
915-1329
HAC/200VR Targha vandal resistant digital panel, requires Targha VR entry panel and HTS recess backbox
NEW
918-0716
HPV/0VR Targha video entry panel, Vandal Resistant, recessed mount, No buttons
NEW
918-0147
HAV/200 Audio and Video module
NEW
918-0165
HAVC/200 Audio and video colour module
NEW
927-0980
HTS/GR Targha Panel Back box
NEW
915-0675
HTS/VR Vandal resistant Targha panel back box
YVC MONITOR
Vandal Resistant Digital entry panels
NEW
918-0616
VRVD/200 Vandal Resistant video digital entry panel, includes HAC/200 keypad and HAV/200 audio/video module
NEW
918-0717
VRVD/200IMP Vandal Resistant video digital entry panel, includes HAC/200 keypad, prox cut out and HAV/200 audio/video module
NEW
NEW
NEW
Video monitors
918-0181
918-0182
918-0183
918-0184
Note: the
YV Lynea Monitor 4.5” Monochrome Screen (requires YKP/200)
YVC Lynea Monitor 4.5’’ Colour Screen (requires YKP/200)
YKP/200 System 200 Lynea Monitor Back Plate And Handset
YKT/F Table Kit for Lynea monitors - RJ45 ended cable supplied
OPHERA/B Semi-recessed, colour monitor with 3.5” tilting display including choice of three coloured front plates. Complete with intercom module
and embedding box. For use with the X1 two wire system
NOVA6MGR Nova 2“ video monitor, flush with lock release button and auxillary button, grey with back box for brick
NOVA6PLGR Nova 2“ video monitor flush receiver with lock release button and auxillary button, grey with back box for plaster board
NOVA6MBB Nova 2“ video monitor flush receiver with lock release button and auxillary button, white with back box for brick
NOVA6PLBB Nova 2” video flush receiver with lock release button and auxillary button, white with back box for plaster board
Nova monitors consist of the following; NSI/6M, NS/6, NC/221PAGR, NPP/6VGR & NVM/200. Colour options are available.
Control equipment
922-0052
922-0051
918-0048
918-0046
918-0017
918-0250
918-0098
918-0147
918-0165
915-0286
VA/200 Main power supplier/control unit. Rated at 60VA output 17.5V dc 0.9A
VAS/100.20 DC power supplier rated at 60VA output 17.5V dc 1.7A
VAV/400P Amplified video distributor, 4 outputs - 1 advised for every 4 monitors
VAV/600 Amplified video distributor, 6 outputs - 1 advised for every 6 monitors
VDV/400 Video distributor, 4 outputs to split co-ax
VDX/400 Video distributor, 4 outputs to twisted pair
VSI/200 Entrance and block selector - 1 needed for each additional entrance
HAV/200 Monochrome video/audio module to fit Targha and Vandal Resistant entry panels
HAVC/200 Colour video/audio module to fit Targha and Vandal Resistant entry panels
IT/200 Telephone interface enables XT/200 telephone to connect to both entry panel and BT line
Cable for Video Systems
927-0156
927-0336
VCM/130 Composite cable 12 core inc. RG59 Coax, 150m (for panel to PSU)
VCM/130CUT As VCM/130, cut to order, 1m
NOVA VIDEO MONITORS
Note; You will also require an extra call wire per monitor, ie for a 5 way system you will require another 5 wires from the panel to PSU.
927-0157
927-0337
017-0020
017-0022
5
VCM/60 Composite cable 5 core inc. RG59 Coax, 100m (for PSU to monitors)
VCM/60CUT As VCM/60, cut to order, 1m
0170020 White, 4 core, 100m
0170022 White, 6 core, 100m
Audio & Video Door Entry Systems
918-0446
918-0447
918-0445
918-0448
918-0718
32
Wireless Audio Door Entry
The wireless audio door entry systems provide a solution where
traditional wiring is difficult or costly. Being completely self
contained by battery operation, the only wires necessary are
those between the door unit and controller, and the locking
device - mains versions are available on request.
The systems are available as single function and three function
depending upon the requirements. Additional handsets can be
ordered separately to operate from the common call button.
D5501GB
The minimum operating distance is 150m. As with all wireless
devices, environmental conditions can affect the performance of
the units - avoiding transmission through metal clad buildings etc
will help to achieve optimum performance.
DPV-2KH MONITOR
C.D.V. (UK) Ltd (1 Year Warranty)
Code
Trade
Wireless Audio Door Entry Kits
913-0543
913-0549
D5501GB 1 Function 1 way kit complete (beige) (D5521U)
comes complete with a PSU-H mains adapter for handset
D5601GB 3 Function 1 way kit complete (beige) (D5601U) comes
complete with a PSU-H mains adapter for handset, includes Stainless
Steel cover for door station, this cover does NOT cover the push
button, so therefore cannot be classed as Vandal Resistant
The kits include:- front surface panel, control & audio handset,
1 function = 1 audio handset & 1 relay output giving
12V dc @ 1.5A
3 function = 1 audio handset, 1 relay output giving
12V dc @ 1.5A , a normally open contact (max 48V dc 1 Amp) &
door status indicator
Handsets for Wireless Door Entry Kits
915-1108
915-0549
D5130GB 1 Function basic handset (beige) (D5120U) includes rechargeable handset function
D5131GB 3 Function basic handset (beige) (D5121U) includes rechargeable handset function
Accessories for Wireless Door Entry Kits
915-0999
D5802 2 way door station - requires handset and controller
915-1000
D5821 1 way door station c/w 2 user code keypad 4 or 6 digits
915-1001
D5822 2 way door station c/w 2 user code keypad 4 or 6 digits
915-1003
DB601 Vandal resistant cover for 1 button door station
915-1004
DB602 Vandal resistant cover for 2 button door station
915-1005
DB721 Vandal resistant cover for 1 button door station c/w 2 user code keypad
915-1006
DB722 Vandal resistant cover for 2 button door station c/w 2 user code keypad
915-0990
EXTPOWER Mains adapter for door station also includes CA1R P.S.U
915-0557
SHROUD Stainless Steel shroud for door stations
Note: EXTPOWER, PSU-H, and SHROUD apply to all ranges
Electronic Telephone directory system
Audio & Video Door Entry Systems
The PDN345/T is a fully featured audio entry system, allowing communication to 345 telephone numbers via an external telephone line.
With a 2-line back-lit LCD display to assist visitors, entry/programming keypad, integral proximity reader for 2,760 users and constructed in a
marine grade Stainless Steel panel the PDN345/T offers a very competitive solution for a wire-free system with minimal installation time.
The unit requires the CIP interface to connect to external land lines and PABX systems.
914-0566
913-0387
925-0253
912-0283
914-0569
913-0533
926-0142
926-0143
926-0144
915-1154
PDN345/T-F Audio entry system, 345 users, Stainless Steel, flush, no release, requires CIP interface
PDN345/T-S as above, surface
LOG-345T Software for PC programming
BMU RS232 interface for PC
PDN-345T-F-KIT PDN-345T-F, complete with CIP interface, LOG-345T software & BMU RS232 interface
PDN-345T-S-KIT PDN-345T-S, complete with CIP interface, LOG-345T software & BMU RS232 interface
CPE Standard Clamshell Proximity card (with slot) (read range of up to 20cm for cards at optimum performance)
CPC ISO standard printable proximity card (read range of up to 20cm for cards at optimum performance)
BP-PG Proximity grey key fob (read range of up to 15cm for fobs at optimum performance)
CIP CIP interface, telecom approved
CIP-12DR series Electronic Telephone directory system
PDN345/T
The CIP-12DR series provides simple and cost-effective audio entry over the public telephone network - to either land-lines or mobile phones.
Up to 12 contacts may be programmed into the unit, each contact having 2 telephone numbers allocated - one for day, one for night.
913-0411
CIP-12DR-1-F 1 Call button kit complete, flush
913-0783
CIP-12DR-1-S As above, surface
914-0970
CIP-12DR-2-F 2 Call button kit complete, flush
913-0918
CIP-12DR-2-S As above, surface
Note: Integral keypads and proximity readers can be added to the above kits at an additional charge.
Larger systems are available. Please contact Technical Sales Support for details.
GSM Modem for PDN345 systems
CIP-12DR-1
The GSM modem allows the PDN345 to be installed in locations where it is impractical to install a telephone landline. It requires a standard SIM
card as found in mobile phones that is connected to a mobile network with sufficient credit to be able to make calls (supplied by others). Subject
to mobile service providers area coverage.
915-1155
WF-GSM/MODEM GSM modem interface, requires mobile phone type SIM card connected to a GSM network
For more information about our products, please call +353 (0) 1450 1366
33
VRVE-S-4-ADS
MONO VIDEO DOOR ENTRY
COLOUR VIDEO DOOR ENTRY
C.D.V. (UK) Ltd (1 Year Warranty)
DIGITAG LR
(continued)
Code
Trade
2-WIRE 1 Way Hands-Free Monochrome Video Door Entry
A fully automatic video intercom system. When a call is made at the door the image appears immediately on the monitor, making it possible
to converse prior to releasing the door.
The monitor can also be operated by pushing the auto switch-on button. In both cases disconnection is automatic after approximately
60 seconds leaving the equipment in standby mode.
917-0117
SVE-F-2 1 way 2-wire FLUSH video entry kit, hands-free
916-0145
SVE-S-2 1 way 2-wire SURFACE video entry kit, hands-free
917-0118
VRVE-F-2 1 way 2-wire Vandal Resistant FLUSH video entry kit, hands-free
916-0146
VRVE-S-2 1 way 2-wire Vandal Resistant SURFACE video entry kit, hands-free
Note, The 2-wire video entry system has a maximum capacity of 1 x camera to 2 x monitors. Integral keypads and proximity readers
can be added to the above VRVE kits only at an additional charge. Please contact Technical Sales Support for details.
2-WIRE Hands-Free Video Accessory
918-0175
DPV-2KH Additional Hands-Free video monitor
4-WIRE 1 Way Monochrome Video Door Entry (Mix ‘n’ Match)
Door Stations
NEW
918-0908
DRC-40BP Narrow style camera unit, shallow profile, robust cast aluminium
NEW
918-0909
DRC-40BG Standard camera unit, shallow profile, robust cast aluminium
916-0308
VRVE-F-4-ADS Additional FLUSH vandal resistant door station
916-0215
VRVE-S-4-ADS Additional SURFACE vandal resistant door station
Monitors
NEW
918-0176
DPV-4PE2 Master monitor, accepts up to 2 door stations and connects to up to 3 slave monitors (DPV-4PB) and/or 1 x audio handset (DR-4RV)
NEW
916-0623
DPV-4PB Slave monitor - up to 3 can be connected to the master (DPV-4PE2)
NEW
915-1672
DR-4RV Audio handset - can take the place of 1 DPV-4PB monitor
NEW
918-0894
DPV-4RH Hands-free monitor **
Note: **The DPV-4RH Hands-free monitor can only be used as part of a 1 to 1 system and cannot be mixed with the other above monitors.
4-WIRE 1 Way COLOUR Video Door Entry (NOT Hands-Free)
916-0149
SVE-S-4-C 1 way 4-wire SURFACE/SEMI FLUSH video entry kit, colour
917-0122
VRVE-F-4-C 1 way 4-wire Vandal Resistant FLUSH video entry kit, colour
916-0150
VRVE-S-4-C 1 way 4-wire Vandal Resistant SURFACE video entry kit. colour
Note, The 4-wire video entry system has a maximum capacity of 1 x camera to 4 x monitors. The monitors are traditional, and not Hands-Free.
Particular attention must be paid to installing the correct cable size and distance, to achieve the optimum colour picture quality.
4-WIRE Video Accessory
918-0179
CDV-50 Additional colour video monitor
DIGITAG-LR Long Range Reader System
CABLE SPECIFICATION
2 & 4 wire video cable specs are common:
up to 50 metres, 22 AWG up to 100 metres, 0.75mm
DIGITAG-LR is a new, innovative long-range reader/tag system. With range adjustment from 1 – 15 metres**. DIGITAG-LR offers true hands-free
access control for personnel and vehicles alike. The reader has a selectable output for wiegand, clock & data and CDV format, making the
product suitable for connection to all standard access control systems. The problem of limited life in traditional active tags is removed, by the
ability to change the readily available battery within the tag – this means the tag has an infinite shelf-life, and will continue working for many
years (same as any passive tag). DIGITAG-LR has brought hands-free access control within the reach of most people’s budgets, where traditional
hands-free products have been uneconomical.
DIGITAG-LR has the ability to connect to most access control systems due to the inclusion of a selectable output.
** All RF devices can be affected by environmental conditions, therefore there may be some increase/decrease experienced in the range.
NEW
909-0510
DTLR1-R Long range receiver, in ABS housing with range adjustment. Requires 8-30V dc, current draw @ 40m/Amps. Selectable data output
(Wiegand, clock & data etc) IP55. 90 x 60 x 22mm
NEW
926-0808
DTLR1-T0 Long range tag transmitter, no buttons. Active tag with changeable battery for long life
NEW
926-0809
DTLR-T1 Long range tag transmitter,1 button for manual transmit. Active tag with changeable battery for long life
NEW
927-2612
300445 Varta 3V CR2032 Coin Cell Lithium replacement battery
Audio & Video Door Entry Systems
Note, The 4-wire video entry system has a maximum capacity of 2 x cameras to 4 x monitors. The monitors are traditional, and not Hands-Free.
It is possible to connect an audio handset to the system, it takes the place of 1 x monitor. Integral keypads (ADD-CB) and proximity readers
(ADD-PROX) can be added to the above VRVE door stations only at an additional charge. Please contact Technical Sales Support for details.
FERMAX (1 Year Warranty)
34
Code
Trade
Private - Proximity access control kits
914-0194
2284 Audio Private flush kit
913-0216
2285 Audio Private surface kit
917-0097
2286 Video Private flush kit
916-0100
2287 Video Private surface kit
926-0328
2363 Proximity card
926-0466
XK-2 Proximity tag
Note: The above kits include door panel, PSU, internal unit (where required), 6 x proximity cards (system capacity 400) & mortice release.
Stand alone keypads 100 codes
902-0117
3610 Memocity keypad, flush mount, 100 user codes, 4, 5 or 6 digit code, 2 outputs
902-0118
3600 Memocity 100 code keypad kit, inc flush keypad, PSU & release
915-0008
8951 Surface back box, to surface mount Memocity keypad
AUDIO DOOR ENTRY
Neox 2 wire Audio kit
913-0928
5370 Surface mount 1 way 2 wire kit
Neox 4+n Audio kits
916-0534
5350 Surface mount 1 way audio kit c/w Sailing audio handset
916-0535
5351 Surface mount 2 way audio kit c/w Sailing audio handset
CityMax flush audio kits (include 8044 CityMax telephone)
914-0609
6940 Flush mount 1 way kit, inc. panel, phone & PSU. No release
914-0610
6262 As above. 2 way
914-0611
6362 As above. 3 way
914-0612
63351 As above. 4 way
914-0613
63401 As above. 6 way
914-0614
63451 As above. 8 way
Larger kits/systems are available and can be surface mounted by the addition of the relevant series surface box.
CityMax surface audio kits (include 8044 CityMax telephone)
913-0628
68706 Surface mount 1 way kit, inc. panel, phone & PSU, No release
913-0629
63256 As above. 2 way
913-0630
63306 As above. 3 way
913-0631
63356 As above. 4 way
913-0632
63406 As above. 6 way
913-0633
63456 As above. 8 way
Larger kits/systems are available
Memophone flush kits (combined audio/100 code keypad)
914-0825
3602 Flush mount 1 way, audio/keypad kit, inc panel, keypad, phone, PSU & rim release
914-0826
3604 As above 2 way
Larger kits/systems are available
Audio & Video Door Entry Systems
Memophone surface kits (combined audio/100 code keypad)
913-0288
36035 Surface mount 1 way, audio/keypad kit, inc panel, keypad, phone, PSU & rim release
913-0289
36055 As above 2 way
Larger kits/systems are available
Vandal Resistant systems (Stainless Steel panel)
927-0098
VR1K V/R system 1 way, inc Stainless Steel panel with FLUSH back box, phone, & PSU
913-0113
VR1KS V/R system 1 way, inc Stainless Steel panel with SURFACE back box, phone, & PSU
NEW
913-0114
VR2KS As above, 2 way
NEW
913-0115
VR3KS As above, 3 way
NEW
913-0116
VR4KS As above, 4 way
NEW
913-1088
VR5KS As above, 5 way
NEW
913-0334
VR6KS As above, 6 way
NEW
913-1089
VR7KS As above, 7 way
NEW
913-1090
VR8KS As above, 8 way
DDA 1 WAY AUDIO
Larger systems are available
Vandal Resistant audio/keypad systems (Stainless Steel panel)
914-0106
VR1KNC V/R 1 way, audio/keypad kit, inc Stainless Steel panel with FLUSH back box,
keypad, phone & PSU
913-0129
VR1KNCS V/R 1 way, audio/keypad kit, inc Stainless Steel panel with SURFACE
back box, keypad, phone & PSU
Larger systems are available
DDA Vandal Resistant Audio Kits (Stainless Steel panels)
NEW
914-1106
VR1BRLFK 1 way DDA Stainless Steel kit - FLUSH
NEW
913-1085
VR1BRLSK 1 way DDA Stainless Steel kit - SURFACE
NEW
913-1086
VR1BRLNCSK DDA KIT 1 way audio SURFACE + keypad
NEW
913-1087
VR1BRLXSK DDA KIT 1 way audio SURFACE + prox reader
DDA BUTTON
For more information about our products, please call +353 (0) 1450 1366
35
DECT KIT
DECT PANEL
FERMAX (1 Year Warranty)
DECT TELEPHONE
MICROLINE VIDEO MONITOR
(continued)
Code
Trade
Handsets & Accessories
915-0215
8044 CityMax audio telephone
915-0413
8099 CityMax Basic table mount audio telephone
915-0231
2451 Basic ADS audio telephone
915-1164
5302 Sailing audio handset, metallic finish
915-1165
5310 Sailing ADS audio handset, metallic finish
927-0272
2040 Call extension sounder
922-0232
4800 PSU 12V AC
915-0054
8811 Automatic audio switcher, for 2 doors, one required for two entrances
922-0157
88231 12V dc PSU (inc 12V AC for audio), for use with 2 door switcher, to be used with 8811
915-0008
8951 Surface back box, to surface mount Memocity keypad
915-0009
8954 Surface box, series 4
915-0051
8955 Surface box, series 5
Wireless DECT Door Entry Kit
NEW
913-1023
1200 Flush 1 way DECT audio kit, inc. panel, cordless telephone with charging base, PSU and release. Requires 8951 backbox to surface mount
NEW
915-1460
1206 Additional DECT handset for above kit for inter-communication purposes only. This unit will not talk to the front panel
310.00
85.00
UNIVERSAL SYSTEMS
Fermax universal equipment has been developed with the installer in mind. They can replace most other makes of door entry equipment
(buzzer or electronic) by simply following the conversion chart supplied. Therefore the installer will no longer have to carry a multitude of
other types of door entry system components.
915-0216
8039 Universal CityMax telephone handset (in the style of a 8044 CityMax phone)
The above telephone is designed to replace most other makes of door entry telephones (5 wires required).
915-1166
8050 Universal Amplifier pack
Designed for replacement of amplifiers of other makes (4+N type installations or 5 wire systems).
Not suitable for telephones using electret microphones. Connects to existing speaker and microphone.
913-0329
9042 Intercom BUS kit 2 way, inc. 2 handsets & PSU
915-0565
8084 Palace intercom BUS telephone (max 12 extensions)
915-0566
9010 Palace intercom BUS desktop telephone (max 12 extensions)
915-0567
9020 1 way additional multiway panel
915-0568
8086 Palace extra BUS 3 telephone (max 12 extensions)
915-0569
88039 Intercom PSU BUS 3
915-0570
9017 Multiway switcher BUS 3
Multiway Intercom & Door Panel Kits (3 WIRE BUS)
913-0330
9022 Kit includes; 1 way entrance panel, 2 intercom phones, switcher & PSU
915-0565
8084 Palace intercom BUS telephone (max 12 extensions)
MICROLINE press to talk kits
A new line of 1 way audio and video door entry kits that include MICRO model telephone and monitors. MICRO terminals are comfortable and
easy to use intercom devices. “press-to-talk, let go to listen”. They are very slim surface-mounted devices. This equipment is recommended to be
installed in shops, businesses, receptions, pharmacies, petrol stations, homes etc.
NEW
914-0615
1151 1 way audio kit
917-0376
1153 1 way video kit (colour)
917-0377
1154 1 way video kit (mono)
915-1010
1152 Audio press to talk handset
918-0467
1155 Video press to talk monitor (mono)
915-1441
4812 Additional PSU for parallel monitors (3rd & 4th monitors)
Fermax continued overleaf
Audio & Video Door Entry Systems
Multiway Intercom Kits (3 WIRE BUS)
36
VR1KSV
HALO PANEL 1 WAY
FERMAX (1 Year Warranty)
SAILING MONITOR
(continued)
Code
Trade
VIDEO DOOR ENTRY (COAXIAL)
CityMax flush kits/systems
917-0007
917-0010
6002 CityMax 1 way flush mount kit, inc panel, monitor/phone, PSU & rim release. Series 4
6006 As above 2 way
Sailing video kits
917-0527
917-0528
5304 Sailing mono 1 way flush mount kit, inc panel, Sailing monitor, PSU, electric lock release and a free extra Sailing audio handset
5300 Sailing colour 1 way flush mount kit, inc panel, Sailing monitor, PSU, electric lock release and a free extra Sailing audio handset
Olympo Video Kit
917-0621
5410 Olympo colour 1 way flush mount kit, inc panel, Olympo monitor, PSU and electric lock release
CityMax Memovision flush kits (combined video/100 code keypad)
917-0115
917-0116
NEW
3606 CityMax 1 way flush mount, video/keypad kit, inc panel, keypad, phone, PSU & release. Series 6
3608 As above 2 way
HALO Video Kit
916-0655
5710 1 way Colour Halo video kit - Includes Halo panel and Loft Monitor
Vandal Resistant systems (Stainless Steel panel)
917-0529
916-0481
VR1KV V/R video kit 1 way, inc Stainless Steel panel with FLUSH back box, camera, monitor/phone & PSU
VR1KSV V/R video kit 1 way, inc Stainless Steel panel with SURFACE back box, camera, monitor/phone & PSU
Vandal Resistant video/keypad systems (Stainless Steel panel)
916-0030
916-0482
NEW
NEW
NEW
Audio & Video Door Entry Systems
NEW
OLYMPO MONITOR
VR1KNCV V/R video kit 1 way, inc Stainless Steel panel with FLUSH back box, keypad, camera, monitor/phone & PSU
VR1KNCSV V/R video kit 1 way, inc Stainless Steel panel with SURFACE back box, keypad, camera, monitor/phone & PSU
DDA Vandal Resistant Video Kits (Stainless Steel panels)
916-0656
916-0657
916-0658
916-0659
VRV1BRLSK DDA KIT 1 way video b/w Surface
VRV1BRLXSK DDA KIT 1 way video b/w Surface + prox reader
VR1VBRLSK DDA KIT 1 way video colour Surface
VR1VBRLXSK DDA KIT 1 way video colour Surface + prox reader
Accessories
918-0057
918-0140
918-0058
918-0141
918-0583
918-0584
918-0585
918-0586
918-0587
918-0668
918-0059
922-0041
918-0053
927-0060
918-0142
918-0143
927-0158
8022 CityMax Basic video monitor (requires connector plate Ref. 8032)
8032 CityMax Basic connector plate, for CityMax Basic video monitor
8023 CityMax Export video monitor manufactured to a new concept design. (requires connector plate Ref. 8033)
8033 CityMax Extended connector plate, for other video monitors (including CityMax export monitor)
5303 Sailing Mono Monitor, metallic finish (requires connector plate Ref. 8032)
5301 Sailing Colour Monitor, metallic finish (requires connector plate Ref. 8032)
3310 Loft Mono Monitor (requires connector plate Ref. 3315)
3312 Loft Colour Monitor (requires connector plate Ref. 3315)
3315 Loft Connector plate
5404 Olympo Colour Monitor (requires connector plate Ref.8032)
8232 CityMax monitor table mounting kit (for use with 8022 basic monitor) c/w back plate & junction box
6062 Additional PSU, required to run 2 monitors per call line
2470 TV Modulator, to connect monitor image to TV set
SK Security key
2448 2 - Line video distributor
2449 4 - Line video distributor
8023 MONITOR
5920 Composite cable per 50m - 11 core (8 x 0.5mm & 3 x 1mm stranded) + RG59 coax
ADS DIGITAL CityMax VIDEO KITS (Monochrome kits) (3 + coax = 40m)
The ADS video kits are complete systems which utilise an in-built microprocessor. This enables each terminal, monitor or telephone to be
initiated into the system by addressing the terminal via a call from the door panel whilst in programming mode. All this is achieved by the
use of 3 x 1mm and coax common to all terminals (max distance 100m). DC lock output. 2 monitors or 3 handsets can be installed per call line.
917-0011
917-0038
917-0039
NEW
6030 ADS flush mount kit 1 way, inc panel, monitor/phone, PSU & rim release. Series 4
6034 As above 2 way, Series 4
6038 As above 3 way Series 4
Loft ADS video kits
917-0654
917-0653
917-0652
3340 Loft mono 1 way ADS/V5 flush mount kit, inc panel, Loft monitor, PSU and lock release, Series 4
3332 As above, 2 way kit, Series 5
3324 As above, 3 way kit, Series 5
Note: The above kits can be installed using 3 wires + coax, or using 5 wires and no coax
ADS Digital Memory 128 kit
917-0092
6115 CityMax 1 way flush mount kit, inc panel, memory monitor/phone, PSU & rim release
Note: The monitor can store pictures of the last 128 calls with their corresponding date & time.
For more information about our products, please call +353 (0) 1450 1366
37
KIT DIRECT 199
BRUTO KITS
FERMAX (1 Year Warranty)
BRUTO KITS
(continued)
Code
Trade
ADS DIGITAL CityMax VIDEO KITS (Colour kits)
917-0012
6047 ADS flush mount kit 1 way, inc panel, monitor/phone, PSU & rim release. Series 4
917-0040
6071 As above 2 way, Series 4
917-0041
6073 As above 3 way, Series 4
Loft ADS Colour video kits
917-0651
3330 Loft colour 1 way ADS/V5 flush mount kit, inc panel, Loft monitor, PSU and lock release, Series 4
917-0650
3333 As above, 2 way kit, Series 5
917-0655
3335 As above, 3 way kit, Series 5
Note: The above kits can be installed using 3 wires + coax, or using 5 wires and no coax
199 KITS
Kit Vox 199 (Audio)
Audio door entry system kit for buildings up to 199 apartments, all references in one kit, TELEPHONES NOT INCLUDED.
913-0217
6151 Kit Bruto Vox 199, audio entry flush kit, no telephones
913-0218
6093 Kit Vox 199, audio entry flush kit, no telephones
915-0231
2451 ADS CityMax telephone
913-0392
2118 Surface box, to make the 6151 surface
915-0051
8955 Surface box, series 5 (two required to make the 6093 surface)
KIT DIRECT 199 (Monochrome Video)
Video door entry system kit for buildings up to 199 apartments, all references in one kit, MONITORS NOT INCLUDED.
916-0101
6132 Kit Bruto Direct 199, video entry flush kit, no monitors
917-0042
6092 Kit Direct 199, video door entry flush kit, no monitors
916-0102
6094 Kit Direct 199, video colour door entry flush kit, no monitors
Note: the mono kit requires the 2447 video monitor & the colour kit requires the 2446 colour video monitor, both monitors require the
2454 backplate.
2447 ADS monochrome video monitor (requires a back plate)
918-0470
2446 ADS colour video monitor (requires a back plate)
918-0588
5306 Sailing ADS monochrome video monitor (requires back plate 2454)
918-0589
5305 Sailing ADS colour video monitor (requires back plate 2454)
918-0164
2454 Back plate to use with 2447, 2446, 5306 & 5305 video monitors
918-0590
3311 Loft ADS monochrome video monitor (requires back plate 3314)
918-0591
3313 Loft ADS colour video monitor (requires back plate 3314)
918-0592
3314 Back plate to use with 3311 & 3313 monitors
928-0121
2119 Surface box, to make the 6132 surface
915-0051
8955 Surface box, series 5 (two required to make the 6092 surface)
CABLE (maximum distance between panel and phone is 100m using 3+COAX (5919) cable) for longer distances please contact the
Technical Sales Support department.
927-0282
5919 ADS specialised cable 3 x 1mm + 75 ohm coax per 100m
Bruto Vandal Resistant audio/video Kits
Audio
914-0189
2601 1 way Bruto Audio Kit (Amplifier includes a voice synthesiser)
915-0846
2115 Surface box for 2601
Audio Accessories
915-0215
8044 CityMax audio telephone (Up to 3 telephones without additional PSU)
915-0414
2246 Bruto audio kit panel (Flush box included)
915-0846
2115 Surface box for 2246
Video
916-0103
2239 1 way Bruto Video ADS Digital Kit (Amplifier includes a voice synthesiser)
928-0243
2116 Surface box for 2239
Video Accessories
918-0144
2248 Bruto video kit panel (Flush box included)
928-0243
2116 Surface box for 2248
Audio & Video Door Entry Systems
918-0163
38
For more information about our products, please call +353 (0) 1450 1366
39
ECONOMY AUDIO & VIDEO KITS
GENYA AUDIO KITS
SINTHESI 1145 RANGE
URMET (1 Year Warranty)
Code
Trade
Audio Door Entry
Economy Audio Kits
The audio door entry kits below include a surface/semi flush panel, the relevant number of handsets & transformer
907-0065
913-0968
913-0969
1129/501 Smyle Audio door entry 1 way surface Kit complete with rim/mortice release (1133/1 handset)
1129/502 As above 2 way (1129/502)
1129/10 Smyle 1 way 2 wire audio entry kit inc. surface panel, transformer & 1133 style handset. No release
Vandal Resistant mini kit
The VS-SA1M vandal resistant audio kit has one of the smallest surface mount Stainless Steel 1-way panels available measuring just 75mm x
147mm x 55mm (WxHxD) making it ideal for narrow mount and pedestal applications. 1133 Atlantico handset included. Use POST1-MVR
for post mount applications (915-0997). The lock output is 12V AC or a timed relay.
913-0172
VS-SA1M Mini V/R surface panel audio door entry kit, 1 way inc. transformer & phone. No release
Genya Audio Kits - Aluminium Panel
Genya Slim surface mount audio kits contain an ABS/anodised aluminium entry panel and 1133 Atlantico handsets.
913-0970
913-0971
913-0972
913-0973
913-0974
913-0987
913-0975
913-0976
1128-SA3 3 way Genya slim surface panel audio entry kit, inc transformer & 3 phones. No release
1128-SA4 As above 4 way
1128-SA5 As above 5 way
1128-SA6 As above 6 way
1128-SA7 As above 7 way
1128-SA8 As above 8 way
1128-SA9 As above 9 way
1128-SA10 As above 10 way
Larger Genya series audio kits and kits with trades facility are also available. Lock output is 12V AC or timed relay.
Sinthesi 1145 Surface Audio Kits
913-0305
913-0306
913-0307
913-0308
913-0309
913-0310
913-0607
913-0448
913-0608
913-0609
1145-SA1 1 way 1145 Surface mount panel audio entry kit, inc transformer & 1 phone. No release
1145-SA2 As above 2 way
1145-SA3 As above 3 way
1145-SA4 As above 4 way
1145-SA5 As above 5 way
1145-SA6 As above 6 way
1145-SA7 As above 7 way
1145-SA8 As above 8 way
1145-SA9 As above 9 way
1145-SA10 As above 10 way
Larger Sinthesi systems and systems with trades facility/proximity/keypad and video options are available. The lock release output is
12V AC @ 1A.
Sinthesi 1145 Flush Audio Kits - Horizontal and vertical mounting options
914-0251
914-0252
914-0253
914-0254
914-0255
914-0256
914-0584
914-0585
914-0586
914-0587
1145-FA1 1 way 1145 flush mount panel audio entry kit, inc transformer & 1 phone. No release
1145-FA2 As above 2 way
1145-FA3 As above 3 way
1145-FA4 As above 4 way
1145-FA5 As above 5 way
1145-FA6 As above 6 way
1145-FA7 As above 7 way
1145-FA8 As above 8 way
1145-FA9 As above 9 way
1145-FA10 As above 10 way
Larger Sinthesi systems and systems with trades facility/proximity/keypad and the video options are available. The lock release
output is 12V AC @ 1A
Urmet continued overleaf
Audio & Video Door Entry Systems
Sinthesi audio kits contain an anodised aluminium flush mount entry panel with backlit push buttons and nameplates. Flexible design also
allows flush Sinthesi panels to be installed horizontally as well as vertically. Sinthesi kits feature the Atlantico handset which redefines modern
contemporary design.
40
K-STEEL AUDIO KITS
URMET (1 Year Warranty)
K-STEEL AUDIO PANEL
(continued)
Code
Trade
K-Steel Surface Audio kits
K-Steel vandal resistant entry kits offer a modular Stainless Steel panel, which offers flexibility in panel design and greatly reduces delivery time.
The panels are rated to IP45. The IP45 rating is a 2 figure number that represents a testing procedure. In this case, 4 = protected against insertion
of solid objects over 1mm & 5 = protected against low pressure jets of water from all directions. The buttons and engravable nameplates are
LED back lit. Integrated coded access keypad and proximity modules are available. K-Steel kits feature the Atlantico handset which redefines
modern contemporary design.
913-0173
913-0174
913-0175
913-0176
913-0177
913-0178
913-0179
913-0180
913-0181
913-0182
KS-SA1 Stainless Steel surface mount 1 way audio entry kit inc. transformer & phone. No release
KS-SA2 As above 2 way
KS-SA3 As above 3 way
KS-SA4 As above 4 way
KS-SA5 As above 5 way
KS-SA6 As above 6 way
KS-SA7 As above 7 way
KS-SA8 As above 8 way
KS-SA9 As above 9 way
KS-SA10 As above 10 way
Larger K-Steel systems plus proximity/keypad and video options are available. The lock release output is 12V AC @ 1A or a timed relay.
K-Steel flush Audio kits
914-0213
914-0214
914-0215
914-0216
914-0217
914-0218
914-0588
914-0436
914-0524
914-0589
KS-FA1 Stainless Steel flush mount 1 way audio entry kit inc. transformer & phone. No release
KS-FA2 As above 2 way
KS-FA3 As above 3 way
KS-FA4 As above 4 way
KS-FA5 As above 5 way
KS-FA6 As above 6 way
KS-FA7 As above 7 way
KS-FA8 As above 8 way
KS-FA9 As above 9 way
KS-FA10 As above 10 way
Larger K-Steel systems plus proximity/keypad and video options are available. The lock release output is 12V AC @ 1A or a timed relay.
Audio & Video Door Entry Systems
K-Steel Surface Audio/Keypad kits
913-0183
913-0184
913-0185
913-0186
913-0187
913-0188
913-0610
913-0611
913-0612
913-0613
KS-SAK1 Stainless Steel surface mount 1 way audio/keypad entry kit inc. transformer & phone. No release
KS-SAK2 As above 2 way
KS-SAK3 As above 3 way
KS-SAK4 As above 4 way
KS-SAK5 As above 5 way
KS-SAK6 As above 6 way
KS-SAK7 As above 7 way
KS-SAK8 As above 8 way
KS-SAK9 As above 9 way
KS-SAK10 As above 10 way
Larger K-Steel systems plus proximity and video options are available. The lock release output is 12V AC @ 1A or a timed relay.
K-Steel flush Audio/Keypad kits
914-0177
914-0178
KS-FAK1 Stainless Steel flush mount 1 way audio/keypad entry kit inc. transformer & phone. No release
KS-FAK2 As above 2 way
Larger K-Steel systems plus proximity and video options are available. The lock release output is 12V AC @ 1A or a timed relay.
K-Steel DDA Audio kits
K-Steel vandal resistant entry kits offer a modular Stainless Steel panel, which offers flexibility in panel design and greatly reduces delivery time.
The panels are rated to IP45. The IP45 rating is a 2 figure number that represents a testing procedure. In this case, 4 = protected against insertion
of solid objects over 1mm & 5 = protected against low pressure jets of water from all directions. The buttons and engravable nameplates are LED
back lit. Integrated coded access keypad and proximity modules are available. K-Steel kits feature the Atlantico handset which redefines modern
contemporary design. The K-Steel DDA module is suitable for all K-Steel panel configurations including Digital Digivoice, and provides off the
shelf solutions for systems installed in Public Access buildings. The lock output is 12V AC or a timed relay.
914-0801
913-0846
914-0802
913-0847
914-0803
913-0848
KS-FA1DDA 1 way DDA K-Steel FLUSH mount panel audio entry kit, inc transformer & 1 phone. No release
KS-SA1DDA 1 way DDA K-Steel SURFACE mount panel audio entry kit, inc transformer & 1 phone. No release
KS-FAK1DDA 1 way DDA K-Steel FLUSH mount panel audio entry with keypad kit, inc transformer & 1 phone. No release
KS-SAK1DDA 1 way DDA K-Steel SURFACE mount panel audio entry with keypad kit, inc transformer & 1 phone. No release
KS-FAP1DDA 1 way DDA K-Steel FLUSH mount panel audio entry with proximity reader kit, inc transformer & 1 phone. No release
KS-SAP1DDA 1 way DDA K-Steel SURFACE mount panel audio entry with proximity reader kit, inc transformer & 1 phone. No release
For more information about our products, please call +353 (0) 1450 1366
41
ATLANTICO AUDIO HANDSETS
DOMUS AURA
URMET (1 Year Warranty)
TRANSIT
STAINLESS STEEL POSTS
(continued)
Code
Trade
Audio Accessories
915-1358
1130 12V AC buzzer type telephone with lock release key
915-0324
1132 Telephone audio handset with door release key
915-0497
1132/50 Desk mount kit to suit 1132 telephone
912-0215
1133 Atlantico audio handset with door release key & extra button
915-1152
1133/12 Atlantico 12 button audio handset
915-1153
1133/20 Atlantico audio handset with privacy button, door open indicator and door release key
915-0546
1133/50 Desk mount kit to suit Atlantico 1133 telephone
915-0499
9854/41 Extension sounder (for electronic call handsets)
922-0201
786/13 Audio PSU with high output PS, timed relay & 2 tone generator
915-0323
ENG2 Engraving per name plate for K-Steel panels (max 10 Char)
928-0245
ENG6 Engraving per name plate for Sinthesi panels (max 10 Char)
927-1277
ENG6/2 Engraving for double Sinthesi name plate (max 4 Char each)
Domus Aura - Audio
The Domus Aura range has been designed using high quality materials to achieve an attractive and robust panel with a super mirrored
Stainless Steel fascia providing protection with style. The frame is PVD treated brass, ensuring that the panel is kept untarnished, push
buttons and LED backlit nameplates are brass. Kits also contain amplifier, transformer/power supply and relevant number of 1133 Atlantico
handsets for audio or Artico video handsets for video kits.
914-0219
1110-FA1 Domus Aura flush mount audio kit 1-way
914-0220
1110-FA2 As above 2 way
The above Domus Aura panels are available up to 20 way. The lock release output is 12V AC @ 1A or a timed relay.
Domus Aura - Video (mono)
917-0112
1710-FV1 Domus Aura flush mount mono video kit 1-way
917-0113
1710-FV2 As above 2 way
The above Domus Aura panels are available up to 20 way. The lock release output is 12V AC @ 1A or volt free relay contacts.
915-0354
926/1 Intercom phone including integral keypad
922-0076
926/3 Power Supply 38VA, for maximum of 25 Intercom phones (4 required for 97 phones)
915-0355
926/4 Desk kit for intercom phone
Transit Dual Technology (RF and Proximity)
Transit is a 2 channel 500 user controller with built in display and programming reader. The radio range is 26m free field, or 46m free field
with antenna. Transit can be powered by 12V AC/dc and is wall or DIN rail mountable. The lock output is via a timed relay.
911-0204
1104/1 Transit dual technology 2 Channel 500 user controller
926-0411
1104/5 Dual technology RF/proximity key
926-0491
1125/50-1 Proximity key (price each)
926-0412
1125/50 Proximity key (Pack of 10)
909-0181
1104/12 Transit proximity reader for Kombi (can also be used with K-Steel using 1155/50/P)
915-0513
1155/50/P K-Steel proximity reader housing for Transit/panel mount reader
927-0727
1104/52 Antenna Kit for Transit (with 3m lead)
922-0075
9000/230 12V AC Transformer (18 VA)
Stainless Steel Posts
915-0996
POST1 Stainless Steel vehicle height post 80x80x1200mm
915-0772
POST1-KS1 Stainless Steel vehicle height post 80x80x1200mm to suit 1 module K-Steel surface kits
928-0060
POST1-KS2 Stainless Steel vehicle height post 80x80x1200mm to suit 2 module K-Steel surface kits
928-0086
POST1-KS3 Stainless Steel vehicle height post 80x80x1200mm to suit 3 module K-Steel surface kits
915-0997
POST1-MVR Stainless Steel vehicle height post 80x80x1200mm to suit mini V-Steel audio panel
915-0998
POST2 Stainless Steel dual height vehicle post 80x80x2000mm
927-1280
POST3 Stainless Steel pedestrian height post 80x80x1600mm
915-0773
POST-ROOT Root for POST1 and POST2
Urmet continued overleaf
Audio & Video Door Entry Systems
Easivoice Digital Intercom system up to 97 intercom phones (9 wire BUS)
42
GENYA VIDEO PANELS
SINTHESI VIDEO PANELS
URMET (1 Year Warranty)
K-STEEL DDA VIDEO PANEL
(continued)
Code
Trade
Video Door Entry
Economy 2 wire Video Kits
The 952/11 2 wire video kit with Smyle video panel. The kit can be expanded by one audio handset, sounder or one video monitor.
916-0566
952/11 2 wire SMYLE mono Atlantico video kit complete with PSU
918-0528
1702/1 Atlantico monitor for use as a second monitor on a 952/11 kit (also need 789/2 PSU and 1202/90 bracket)
918-0740
1202/90 Wall bracket for Atlantico video handset
916-0567
952/41 2 wire SMYLE colour Atlantico video kit
Genya Video Kits - Aluminium Panel
Genya Slim surface mount video kits contain an ABS/anodised aluminium entry panel and Artico video handsets.
916-0568
1128-SV3 3 way Genya slim surface panel video entry kit, inc transformer & 3 video handsets. No release
916-0569
1128-SV4 As above 4 way
916-0570
1128-SV5 As above 5 way
916-0571
1128-SV6 As above 6 way
916-0572
1128-SV7 As above 7 way
Larger Genya video kits and kits with trades
facility are also available. The lock release
output is 12V AC @ 1A or volt free relay
contacts.
Sinthesi 1145 Surface Video Kits (mono)
Audio & Video Door Entry Systems
1145 coax video kits contain the flexible SINTHESI design modular anodised aluminium panel, amplifier, power supply, relevant number of
Artico monitors and 4 way video distributors (above 1-way). Flush Sinthesi panels may be horizontally or vertically mounted.
916-0152
1145-SV1 1 way 1145 SINTHESI surface mount kit inc. surface panel (1 module), PSU & monitor/phone. No release
916-0153
1145-SV2 As above 2 way (1 module)
916-0154
1145-SV3 As above 3 way (2 modules)
916-0155
1145-SV4 As above 4 way (2 modules)
916-0156
1145-SV5 As above 5 way (2 modules)
916-0157
1145-SV6 As above 6 way (2 modules)
916-0324
1145-SV7 As above 7 way
These kits are also available in flush and
larger sizes with prox and keypad options
and can be expanded for multi entrance
applications. The lock release output is
12V AC @ 1A or volt free relay contacts.
Colour systems also available.
Sinthesi 1145 Flush Video Kits (mono) - Horizontal and vertical mounting options
917-0124
1145-FV1 1 way 1145 SINTHESI flush mount kit inc. flush panel (1 module), PSU & monitor/phone. No release
917-0125
1145-FV2 As above 2 way (1 module)
917-0126
1145-FV3 As above 3 way (2 modules)
917-0127
1145-FV4 As above 4 way (2 modules)
917-0128
1145-FV5 As above 5 way (2 modules)
917-0129
1145-FV6 As above 6 way (2 modules)
917-0340
1145-FV7 As above 7 way
917-0341
1145-FV8 As above 8 way
917-0342
1145-FV9 As above 9 way
917-0273
1145-FV10 As above 10 way
The above kits are also available in larger sizes with prox and keypad options and can be expanded for multi entrance applications.The lock
release output is 12V AC @ 1A or volt free relay contacts. Colour systems also available.
K-Steel surface Video Kits (mono)
916-0061
KS-SV1 1 way K-Steel SURFACE mount kit inc. surface panel (2 module), PSU & monitor/phone. No release
916-0062
KS-SV2 As above 2 way (2 module)
916-0063
KS-SV3 As above 3 way (2 module)
916-0064
KS-SV4 As above 4 way (2 module)
916-0065
KS-SV5 As above 5 way
916-0066
KS-SV6 As above 6 way
These kits are also available in flush and
larger sizes with prox and keypad options
and can be expanded for multi entrance
applications. The lock release output is
12V AC @ 1A or volt free relay contacts.
Colour systems also available.
For more information about our products, please call +353 (0) 1450 1366
43
K-STEEL VIDEO KITS
ATLANTICO VIDEO HANDSET
URMET (1 Year Warranty)
ARTICO VIDEO HANDSET
(continued)
Code
Trade
K-Steel flush Video Kits (mono)
K-Steel vandal resistant entry kits offer a modular Stainless Steel panel, which offers flexibility in panel design and greatly reduces delivery
time. The panels are rated to IP45 (see K-Steel audio section for IP explanation). The buttons and engravable nameplates are LED back lit.
Integrated coded access keypad and proximity modules are available. Kits also contain power supply, 4-way video distributor (above 1-way)
and relevant number of Artico monitors. When surface mounted, these housings are Stainless Steel.
917-0105
917-0106
917-0107
917-0108
917-0287
917-0261
917-0240
917-0313
917-0348
917-0288
KS-FV1 1 way K-Steel FLUSH mount kit inc. flush panel (2 module), PSU & monitor/phone. No release
KS-FV2 As above 2 way (2 module)
KS-FV3 As above 3 way (2 module)
KS-FV4 As above 4 way (2 module)
KS-FV5 As above 5 way
KS-FV6 As above 6 way
KS-FV7 As above 7 way
KS-FV8 As above 8 way
KS-FV9 As above 9 way
KS-FV10 As above 10 way
The above kits are also available in larger sizes with prox and keypad options and can be expanded for multi entrance applications. The lock
release output is 12V AC @ 1A or volt free relay contacts. Colour systems also available.
K-Steel surface Video keypad Kits (mono)
916-0067
916-0068
916-0299
916-0330
916-0331
916-0332
KS-SVK1
KS-SVK2
KS-SVK3
KS-SVK4
KS-SVK5
KS-SVK6
Modular S/S SURFACE video/keypad kit, 1 way inc. panel, keypad, PSU & monitor/phone. No release
As above 2 way
As above 3 way
As above 4 way
As above 5 way
As above 6 way
The above kits are also available in flush and larger sizes with prox and keypad options and can be expanded for multi entrance applications.
The lock release output is 12V AC @ 1A or volt free relay contacts. Colour systems also available.
K-Steel DDA Video Kits (mono)
917-0505
916-0465
917-0506
916-0466
917-0507
916-0467
KS-FV1DDA 1 way DDA K-Steel FLUSH mount panel video entry kit, inc transformer & 1 phone. No release
KS-SV1DDA 1 way DDA K-Steel SURFACE mount panel video entry kit, inc transformer & 1 phone. No release
KS-FVK1DDA 1 way DDA K-Steel FLUSH mount panel video entry with keypad kit, inc transformer & 1 phone. No release
KS-SVK1DDA 1 way DDA K-Steel SURFACE mount panel video entry with keypad kit, inc transformer & 1 phone. No release
KS-FVP1DDA 1 way DDA K-Steel FLUSH mount panel video entry with proximity reader kit, inc transformer & 1 phone. No release
KS-SVP1DDA 1 way DDA K-Steel SURFACE mount panel video entry with proximity reader kit, inc transformer & 1 phone. No release
Video System Accessories
918-0528
918-0554
915-1128
918-0571
918-0572
918-0741
918-0742
918-0747
918-0748
918-0749
918-0750
918-0751
918-0740
918-0363
922-0073
922-0074
918-0130
915-0291
915-0518
915-0760
915-0323
1702/1 Atlantico mono Video Handset
1702/86 Atlantico bracket with 5 buttons & privacy switch/LED
1702/92 Deskmount kit for 1702/1
1703/1 Utopia Designer Colour LCD video handset, c/w mute switch with LED, illuminated lock release button & door open LED
1703/90 Bracket for Utopia Colour LCD Video Handset - coax
1703/2 Utopia Colour LCD Handsfree flush/surface Video Handset
1703/91 Bracket for Handsfree Utopia handset - analogue
1703/92 Bracket for Utopia 1703/1 - Digivoice systems
1703/60 Embedding box for flush Utopia video handset
1705/1 Artico Video handset (mono)
1705/90 Artico wall mount video bracket for coax systems
1702/40 Atlantico Video Handset - Colour
1202/90 Wall bracket for Atlantico video handsets
789/5B Video PSU with call output for 4 monitors
789/2 Power supply for one additional monitor
789/3 Power supply for 2 additional SENTRY or 3 additional WINFLAT monitors
1794/4 Four way video distributor (coax) 1 per every 4 additional monitors
788/21 Call repeater relay - 1 per every 4 additional monitors over 2 monitors
9406 Timed lock release relay 12V AC/dc
TC3 Digital 7 day/24 hour time clock - VF contacts
ENG2 Engraving per name plate for K-Steel and Sinthesi panels (max 10 Characters)
Audio & Video Door Entry Systems
K-Steel vandal resistant entry kits offer a modular Stainless Steel panel, which offers flexibility in panel design and greatly reduces delivery
time. The panels are rated to IP45 (see K-Steel audio section for IP explanation). The buttons and engravable nameplates are LED back lit.
Integrated coded access keypad and proximity modules are available. Kits also contain power supply, 4-way video distributor (above 1-way)
and relevant number of Artico monitors. When surface mounted, these housings are Stainless Steel. For larger systems DIGITAL panels are also
available. Lock output is 12V AC @1A or volt free contact. The K-Steel DDA module is suitable for all K-Steel panel configurations including
Digital Digivoice, and provides off the shelf solutions for systems installed in Public Access buildings.
44
For more information about our products, please call +353 (0) 1450 1366
VIDEX (1 Year Warranty)
45
Code
Trade
Stand Alone Keypads
902-0046
902-0047
VX800NF (21PF) Flush mount, 14 gauge Stainless Steel keypad, 2 user codes 4 to 8 digits, 2 outputs, 12/24V AC/dc
VX800NS (21PS) As above, surface mounted, 12/24V AC/dc
XPR KEYPADS
The XPR range of keypads include code and dualtech in various finishes. This cost effective range feature 99 users with blue backlit buttons.
NEW
NEW
NEW
NEW
NEW
NEW
NEW
NEW
NEW
NEW
NEW
99 CODE KEYPADS
902-0188
902-0189
902-0191
902-0192
EX5-43B (EX5-43B) Backlit ABS keypad with plastic buttons. 99 users. Surface mounted
EX5-72C (EX5-72C) Backlit matt chrome keypad with plastic buttons. 99 users. Surface mounted
EX5M-43B (EX5-43B) Backlit ABS keypad with metal buttons. 99 users. Surface mounted
EX5M-72C (EX5-72C) Backlit chrome keypad with metal buttons. 99 users. Surface mounted
DUALTECH KEYPADS - CODE & PROXIMITY
Dualtech keypads can be configured as code only, prox only or code and prox.
908-0071
908-0073
908-0074
908-0076
909-0524
XPR RANGE
EX5P-43B (EX5P-43B) Backlit ABS dualtech keypad with plastic buttons. 99 users. Surface mounted
EX5P2-73C (EX5P273C) Backlit matt chrome dualtech keypad with plastic buttons. 99 users. Surface mounted
EX5PM-43B (EX5P-43B) Backlit ABS dualtech keypad with metal buttons. 99 users. Surface mounted
EX5PM2-73C (EX5P273C) Backlit matt chrome dualtech keypad with metal buttons. 99 users. Surface mounted
EXMINI/C (MINI-C) ABS prox reader. Can be used as slave reader for dualtech keypads
Other configurations and finishes are available. Please contact Technical Sales Support for details
Cards and Fobs
926-0818
926-0677
EXPBX-2C (PBX-2C) NISO proximity card 2mm thick (numbered)
EXPBX-1E (PBX-1E) Blue ABS key fob (numbered)
Videx now offer a comprehensive access control system within their product range. Contact Technical Sales Support for further information.
Audio Door Entry
Surface 2 wire kit
913-0805
ESK1S (ESK-1S) Surface kit 1 way, inc. aluminium door panel, phone (3151A) & AC PSU. No release
Surface Slimline 4 wire Kits (panel dimensions 150 x 52.4 x 25mm (H x W x D))
913-0556
913-0557
SLK (6H) 1 way slimline surface door entry kit, diecast alloy finish (grey) panel with electronic call tone
SLK-380 (6H/380) As above with SP380 telephone interface (SLK/T (6H/T))
3K Surface Kits (3011 Handsets using 3 + 1 wiring)
4 wires only required, 5 wires for 2 way. Call tone volume adjustable. Lock relay in the door panel.
913-0736
913-0737
913-0738
3K1S (3K1S) Surface kit 1 way, inc. light gauge hinged Stainless Steel panel, phone & PSU. No release
3K2S (3K2S) As above 2 Way
3K3S (3K3S) As above 3 Way
The 3000 series kits are available in Stainless Steel, bronze, brown and white finishes. Larger systems are
available. Please contact our Technical Sales Support department for details.
3K Flush Kits (3011 Handsets using 3 + 1 wiring)
914-0686
914-0687
914-0688
3K1 (3K1) Flush kit 1 way, inc. light gauge hinged Stainless Steel panel, phone & PSU. No release
3K2 (3K2) As above 2 Way
3K3 (3K3) As above 3 Way
Smart Kits (Flush)
Smart kits, 4 wires only required, 5 wires for 2 way. Call tone instead of buzzer.
Lock relay in the door panel.
914-0191
914-0192
SMART1 (10H/A) Smart kit 1 way, inc. aluminium flush panel & rain shield, phone & PSU. No release
SMART2 (12H/A) As above 2 Way
Smart Kits (Surface)
Smart kits, 4 wires only required, 5 wires for 2 way. Call tone instead of buzzer.
Lock relay in the door panel.
913-0213
913-0214
Smart Series Videokits
Slim Line Surface Mount Door Panel
Facility for 2nd Door Panel
Camera Picture Recall Facility
Electronic Call Tone
Adjustable 3 Level Call Tone
Volume, Plus Brightness and
Contrast Controls
6 Wires only, No Coax required
3000 Series Videophone with
5 Push Buttons
Vertical and Horizontal Camera
Picture Angle Adjustment
SMART1S (9H/A) Smart kit 1 way, inc. aluminium surface panel, phone & PSU. No release
SMART2S (11H/A) As above 2 Way
The Smart range is available with aluminium, white or gold finish door panels
Vandal Resistant flush kits
927-0107
914-0089
914-0090
VRDK1kit (25H) V/R flush kit 1 way, inc 12 gauge Stainless Steel flush panel, phone & PSU. No release
VRDK2kit (26H) As above 2 way
VRDK3kit (27H) As above 3 way
Larger kits are available
The prices quoted include standard engraving (I.e. 1-4), and layout of the buttons on the panels are standard configuration.
For different options of engraving and button layout please contact Technical Sales Support.
Vandal Resistant flush audio/keypad kits
NEW
VRDK1 KIT
914-0099
VRDK1/CL (25H/VCL) V/R flush mount 1 way, combined audio/keypad kit, inc. panel, phone & PSU. No release (DK918VR)
913-0421
VR/S2 (101E) V/R Stainless Steel surface box for above kit
The prices quoted above do not include engraving, and layout of the buttons on the panels are standard configuration. Larger systems are
available. For different options of engraving and button layout please contact Technical Sales Support.
Videx continued overleaf
Audio & Video Door Entry Systems
The 3000 series kits are available in Stainless Steel, bronze, brown and white finishes. Larger systems are
available. Please contact our Technical Sales Support department for details.
SLK
VIDEX (1 Year Warranty)
46
(continued)
Code
NEW
NEW
Trade
Disability Discrimination Act (DDA) audio systems
914-0988
SLK/DDA (SLK/DDA) 1 way surface mounted slimline audio kit with disabled logo engraved on
door panel. Complete with handset and PSU
914-0779
VRDK-DDA (25H/DDA) 1 way flush mounted Stainless Steel audio door entry system with tactile
rear illuminated braille button and LED indication for “Call”, “Speak” and “Door Open”. Complete with
handset and PSU
914-1123
VRDKSP-DDA (25H/SP/DDA) 1 way flush mounted Stainless Steel audio door entry system with
tactile rear illuminated braille button, LCD display and voice confirmation of “call” “speak and “door open”.
Complete with handset and PSU
Surface audio/keypad kits
913-0801
DK-1S (3K1S/CL) Surface 1 way combined audio/keypad, housed in a light gauge hinged Stainless
Steel panel, phone & PSU. No release
913-0802
DK-2S (3K2S/CL) As above, 2 way
913-0803
DK-3S (3K3S/CL) As above, 3 way
1 WAY AUDIO DDA
The DK series kits are available in Stainless Steel and bronze finishes only. Larger systems are available. Please contact
our Technical Sales Support departmant for details.
Accessories
915-1130
3021 (3021A) Replacement for SMART1 telephone - with A/C buzzer
928-0877
3011 (3011A) Audio telephone with call tone (for New 3k 4 wire kits)
928-0481
3121 (3121A) Audio telephone with privacy for Sentry systems - replaces 924S
915-0693
3111 (3111A) Audio telephone with electronic call tone for DC systems - replaces 924E
922-0059
322 (6M) Boxed Transformer 12V AC 18 VA
922-0163
520M (4C) 8V dc & 13.5V AC PSU
927-0726
701T (28G) 12V AC and dc GMT time clock with LCD display, 6 on/off periods. Fully programmable with manual override and trades button input
4000 Series Door Panels
The new 4000 series door panels feature cast aluminium alloy backboxes - available in gunmetal grey, gold chrome and silver chrome,
Modules are either mirror-finished Stainless Steel or anodised aluminium. The modules simply clip securely into back boxes and the fixings
are torx pin screws. Surface and flush versions are available. For details of the full range available please contact Technical Sales Support.
4000 Series Audio Flush Kits
4000 series door entry kits (3+1) with gunmetal grey housing with security screws and mirror
finish face plates. Handsets have adjustable electronic calltone and lock release button.
NEW
914-1124
4K1 1 Way flush door entry system with gunmetal grey housing and Stainless Steel face plate
complete with handset and PSU
NEW
914-1125
4K2 As above, 2 way
NEW
914-1126
4K3 As above, 3 way
4000 SERIES DOOR PANELS
Larger kits are available
Audio & Video Door Entry Systems
4000 Series Audio Surface Kits
4000 series door entry kits (3+1) with gunmetal grey housing with security screws and mirror
finish face plates. Handsets have adjustable electronic calltone and lock release button.
NEW
913-1100
4K1S 1 Way surface door entry system with gunmetal grey housing and Stainless Steel face plate
complete with handset and PSU
NEW
913-1101
4K2S As above, 2 way
NEW
913-1102
4K3S As above, 3 way
4K4S
Larger kits are available
4000 Series Audio/Keypad Kits
913-0962
DK4K/1S (DK4K/1S) 1 Way Digiphone surface audio kit with codelock. Gunmetal grey
housing with Stainless Steel modules
914-0965
DK4K/1 (DK4K/1) 1 Way Digiphone flush audio kit with codelock. Gunmetal grey
housing with Stainless Steel modules
4000 Series Vprox Modules
DK4K
Vprox stand alone readers do not require any external controllers and are programmed via buttons on the rear of the module. The 4850P
can be programmed with a PC with the addition of optional software. The readers have a relay output (c/o 24V AC/dc Max. 3A)
NEW
909-0525
4850 (4850) 100 user module with Stainless Steel faceplate
NEW
909-0526
4850P (4850P) 1000 user module with Stainless Steel faceplate RS-232 & RS-485 protocols
NEW
916-0587
4851 (4851) Flush backbox with gunmetal housing
NEW
915-1341
4881 (4881) Surface back box gunmetal grey
NEW
922-0142
521B (3C) 12V dc PSU 1A with back up battery input
Backboxes in other finishes are available. Contact Technical Sales Support for details.
Proximity devices
926-0359
955/C (2X) Additional proximity card to suit VPROX systems
926-0360
955/T (1X) Proximity tag to suit VPROX systems
4850 & 4881
For more information about our products, please call +353 (0) 1450 1366
VIDEX (1 Year Warranty)
47
(continued)
Code
Trade
Disability Discrimination Act (DDA) 2200 series 2 wire audio panel
The SP300-1M digital door panel features relief engraved buttons to RNIB standard and with
individual circles infilled yellow. Large LCD display and voice confirmation of call status.
256 individual access codes. Panel is available with or without proximity reader cut out.
NEW
914-1136
SP300-1M (SP300-1M) Fully featured V/R DDA digital door panel with High contrast Relief
Engraved buttons, Large backlit LCD display and audio confirmation of call progress
The above panel is fully compatible with the Videx 2200 digital system.
Please contact Technical Sales Support for further information.
Other DDA compliant systems are available to special order including analogue,
digital and dual height panels. Please contact Technical Sales Support for details.
SP300-1M
Video Door Entry (NON COAXIAL)
MONOCHROME (Flush)
917-0022
VK6 (3J) Flush kit 1 way, inc. CCD camera housed in light gauge Stainless Steel hinged panel,
3351 video monitor, 3980 mounting plate & PSU. No release
917-0094
VK6/2 (16J) As above 2 way
MONOCHROME (Surface)
916-0001
916-0098
VK6S (4J) Surface kit 1 way, inc. CCD camera housed in light gauge Stainless Steel hinged
panel, 3351 video monitor, 3980 mounting plate & PSU. No release
VK6S/2 (15J) As above 2 way
Video kits are also available with aluminium, white, brown and bronze finish door panels, with a
maximum of 2 extension monitors (3980 mounting plate and 850K PSU are required for each
extension monitor.)
VK6S WIRING DIAGRAM
Smart Video Kits (Monochrome)
916-0356
SMVK1/G (1J/G) Surface kit 1 way, inc. CCD camera housed in an aluminium facia panel
(grey) plastic dark grey back box, 3351 video monitor, 3980 mounting plate & PSU. No release
916-0357
SMVK2 (2J) As above 2 way
916-0396
SMVK1/W (1J/W) Surface kit 1 way, inc. CCD camera housed in an aluminium facia panel
(white) plastic dark grey back box, 3351 video monitor, 3980 mounting plate & PSU. No release
Smart Video Kits (Colour)
916-0359
CSMVK1 (1J/C) Surface Colour kit 1 way, inc. CCD camera housed in an aluminium facia panel
(grey), plastic dark grey back box 3451 video monitor, 3980 mounting plate & PSU. No release
916-0358
CSMVK2 (2J/C) As above 2 way
917-0024
VKC6 (7J) Flush kit 1 way, inc. CCD camera housed in light gauge Stainless Steel hinged panel,
keypad, 3351 video monitor, 3980 mounting plate & PSU. No release
913-0022
VKC6S (8J) As above, surface panel
Audio & Video Door Entry Systems
Combined Video/keypad kits
VK6N
Maximum of 2 extension monitors can be installed on video door entry (non coaxial) systems.
COLOUR video door entry
917-0025
CVK6 (9J) Flush kit 1 way, inc. Colour CCD camera housed in light gauge Stainless Steel
hinged panel, 3451 video monitor, 3980 mounting plate & PSU. No release
916-0024
CVK6S (10J) As above, surface panel
Vandal Resistant Monochrome Video Kit
917-0123
VRVID (11J) Flush kit, 1 way inc. Stainless Steel video panel with CCD camera, 3351 video
monitor, 3980 mounting plate and PSU. No release
Disability Discrimination Act (DDA) compliant video system
917-0658
VRDKVID-DDA (11J/DDA) Flush mounted Stainless Steel video door entry system with
tactile rear illuminated braille button and LED indication for “Call”, “Speak” and “Door Open”.
Complete with video handset and PSU
1 WAY VIDEO DDA
Videx continued overleaf
48
LOCK OUTPUTS OPTIONS FOR VIDEX
12V
AC
12V
dc
Fail
Open
Fail
Secure
Dry
Contacts
800 Series Codelocks
•
•
•
•
•
VPROX Series
•
•
•
•
•
SLK Series
•
3K Series
•
4K Series
•
PRODUCT
D.C. Kits
•
•
•
•
•
•
VK Video Series
•
•
SP 380
•
•
DK Series
•
VRDK Series
•
•
•
VIDEX (1 Year Warranty)
•
•
•
•
VK4K
(continued)
Code
Trade
Video Accessories
918-0256
3351 (3351J) Extension mono videophone for video kits - Requires 3980 Mounting plate & a 850K video PSU (913-0020) per monitor
918-0255
3980 (3980J) Mounting Plate c/w connection board
918-0323
3451 (3451J) Extension colour videophone for video kits - Requires 3980 Mounting plate & a 850K video PSU (913-0020) per monitor
918-0322
3931 (3931J) 3000 Series desk kit for videophone
915-0693
3111 (3111A) Extension telephone handset for video kit
915-0958
3038 (3038A) 3000 Series telephone desk kit
913-0020
850K (78J) PSU for Video monitor (1 PSU required for each extra monitor)
Monochrome VK4K DISABILITY FRIENDLY VIDEO KITS
NEW
917-0822
VK4K1 1 Way flush 4000 series mono video kit with gunmetal grey housing and Stainless Steel face plate with 3356 mono monitor,
3980 back plate and PSU. No lock release
NEW
916-0679
VK4K1S As above, surface
NEW
917-0823
VK4K2 2 Way flush 4000 series mono video kit with gunmetal grey housing and Stainless Steel face plate with 3356 mono monitors,
3980 back plates and PSU. No lock release
NEW
916-0680
VK4K2S As above, surface
Audio & Video Door Entry Systems
The VK4K kit is a disability friendly non coax door kit featuring call progress LEDS and is expandable up to four doors. Up to four
monitors per apartment with full intercommunication between monitors. Please contact Technical Sales Support for more information.
Colour VK4K DISABILITY FRIENDLY VIDEO KITS
NEW
917-0824
CVK4K1 1 Way flush 4000 series colour video kit with gunmetal grey housing and Stainless Steel face plate with 3456 mono monitor,
3980 back plate and PSU. No lock release
NEW
916-0681
CVK4K1S As above, surface
NEW
917-0825
CVK4K2 2 Way flush 4000 series colour video kit with gunmetal grey housing and Stainless Steel face plate with 3456 mono monitors,
3980 back
NEW
916-0682
CVK4K2S As above, surface
Accessories for above kits
NEW
918-0939
3356 (3356J) Mono video monitor for VK4K video kit (max 3 additional)
NEW
918-0940
3456 (3456J) Colour video monitor VK4K video kit (max 3 additional)
918-0255
3980 (3980J) Video monitor backplate (required for each 3356/3456 monitor)
915-0693
3111 (3111A) Audio handset (max 2 per video monitor)
913-0020
850K (78J) Power supply unit (1 required for each additional 3356/3456 monitor
915-0597
512A (22G) Extension sounder
NEW
CABLE SPECIFICATION VIDEO (NON COAXIAL)
Maximum distance from panel to video monitor is 100m using 020-0004 cable (Please contact Technical Sales Support for longer distances).
Video Door Entry ( MONOCHROME ) (COAXIAL)
Surface kits
916-0025
VID1S (98J) Surface kit 1 way, inc. CCD camera housed in light gauge Stainless Steel hinged panel, video monitor & PSU. No release
Larger kits up to 37 way are available in flush or surface format with S/S, aluminium, white, brown and bronze finish door panels.
For installations larger than 37 way please contact Technical Sales Support for information on Digital systems.
Disability Discrimination Act (DDA) video systems (Coaxial)
NEW
917-0826
VRVID-DDA (11J/DDA) 1 way flush mounted Stainless Steel Video door entry system with tactile rear illuminated braille button and
LED indication for “Call”, “Speak” and “Door Open”. Complete with handset and PSU
NEW
917-0827
VRVIDSP-DDA(11J/SP/DDA) 1 way flush mounted Stainless Steel Video door entry system with tactile rear illuminated braille button,
LCD display and voice confirmation of call” and “door open” Complete with handset and PSU
Extra coaxial video monitor
918-0254
3311 (3311J) Monochrome coaxial video monitor, requires 3980 mounting plate & a 850K video PSU (913-0020) per monitor
918-0255
3980 (3980J) Mounting Plate c/w connection board
913-0020
850K (78J) PSU for Video monitor (1 PSU required for each extra monitor)
For more information about our products, please call +353 (0) 1450 1366
VIDEX (1 Year Warranty)
49
(continued)
Code
Trade
BT Systems
The BT kits allow calls to be made from an external door station to a BT telephone, then a two way conversation can be held between the
door station and a BT telephone. The door release can then be triggered by the BT telephone. The BT kits come with either a flush or
surface 1 way light gauge hinged Stainless Steel panel, BT approved interface (SP380) & a PSU (520).
914-0101
EK380 (101H/380) FLUSH 1 way kit with BT approved interface unit to work with BT type cordless or standard telephone (EK280 (101H))
913-0124
EK380S (100H/380) As above, surface
915-0212
380 (SP380) BT approved telephone interface
2200 Series 2 wire audio system
This easy to install system works on a two wire BUS which can be star or parallel wired. Up to 180 users and 10 doors. Concierge facility
available. For a single door system, only three components are necessary - a) door panel, b) PSU, c) handsets.
NEW
NEW
914-0520
2202SA-1R (SP304-1R) Surface mount digital door panel with L.C.D alphanumeric display and name search facility
918-0941
4202/1/S/R (SP408-1R) 4000 series surface digital audio panel + speech board and name search faciity with gunmetal grey surround
915-0753
SP400 (SP400) Metal control box containing 1 Amp PSU & BST/GMT time clock
915-0879
3171 (3171A) 2 button audio handset
915-1007
3172 (3172A) 2 button audio handset with on/off switch
915-0770
3176 (3176A) 2 button audio handset with timed on/off switch and door open LED
For other system configurations please contact our Technical Sales Support department.
2200 Series non coaxial Flush video Kits
The 2200 non coaxial video system requires just 6 cores (BT cable CW1308) to each handset (subject to distances). Systems can be
configured from 1 to 10 doors and up to 180 users.
NEW
917-0828
VID3-NC (103JNC) 3 Way flush mounted video kit with Stainless Steel faceplate
NEW
917-0829
VID4-NC (105JNC) As above, 4 way
NEW
917-0830
VID5-NC (107JNC) As above, 5 way
Please consult with Technical Sales Support before running cabling.
2200 Series non coaxial Surface video Kits
The 2200 non coaxial video system requires just 6 cores (BT cable CW1308) to each handset
(subject to distances). Systems can be configured from 1 to 10 doors and up to 180 users.
NEW
916-0683
VID3S-NC (102JNC) 3 Way surface mounted video kit with Stainless Steel faceplate
NEW
916-0684
VID4S-NC (104JNC) As above, 4 way
NEW
916-0685
VID5S-NC (106JNC As above, 5 way
2200
Please consult with Technical Sales Support before running cabling.
Different finishes and larger systems (including digital) are available. Please contact Technical Sales Support for further information.
BioAccess Fingerprint Readers
NEW
909-0478
4821 (4821) 900 user module with Stainless Steel faceplate. Requires suitable backbox
NEW
909-0529
4823 (4823) 3000 user module with Stainless Steel faceplate. Requires suitable backbox
NEW
925-0364
4827 (4827) Software kit for above readers
NEW
916-0587
4851 (4851) Flush backbox with gunmetal grey housing
NEW
915-1341
4881 (4881) Surface back box gunmetal grey
Backboxes in other finishes are available. Contact Technical Sales Support for details.
BioAccess Fingerprint readers
BioAccess 4821
900 users with 3 templates per user
Stand alone - programmed via buttons on rear of module
Networked version available via optional PC software
BioAccess 4823
3000 users with 3 templates per user
Stand alone - programmed via buttons on rear of module
Networked version available via optional PC software
Database for last 12800 operations
Real Time Clock with battery back-up
Technical Specifications for both models
Working voltage 12V AC/dc
Sensor type Thermal Swipe
Sensor resolution 500 dpi
Recognition time <1 second
Working temperature -10°C +60°C
Inputs/Outputs 3 relays c/o type (24V AC/dc Max 3 amp)
3 inputs (active low) for direct relay operation
Interfaces RS-232, RS-485 & Wiegand 26 bit
4821 & 4881
Videx continued overleaf
Audio & Video Door Entry Systems
The BioAccess Thermal fingerprint reader is available in 2 versions - 900 or 3000 users with 3 fingerprint templates per user. These readers
are programmed either by a series of pushbuttons located on the rear of the module or, with the optional software via a PC. BioAccess
modules can be integrated into 4000 series audio and video systems.
50
The EntryCom door entry system comes configured to allow connectivity via either a PABX analogue extension port, telephone line, or
with the addition of a GSM EasyGate interface unit, which makes calls via the GSM network.
The base modules will only require a 12V AC/dc power supply if you require the panel to be backlit. Otherwise the panel can be powered
by the voltage coming down the respective phone line connections.
All the base modules come with a volt free contact, rated 50V @ 2Amps. There is an optional second auxiliary volt free contact available.
On the keypad version the keypad can be used as a short dial, of up to 50 numbers, or as an electronic code lock. If using separate push
keys the system can call up to 54 numbers.
With the GSM interface there is no limitation to distance, easy two wire connection. All the programming is carried out by dialling into
the system. It recognises busy lines or no answer and can if required hang up and call another number, land line or mobile (max 6
numbers).
The Camera is colour/mono switchable with infra red. The camera unit will require a regulated 12V dc, 2Amp PSU. Output of the camera
is colour composite PAL video signal. It will need to be wired in 75 ohm coax/twisted pair or UTP CAT5 or higher. Other connection
methods are using web browser over IP via a MPEG/LAN converter, or it can connect into an s-video connection.
All panels are available in Vandal resistant flush housings and in 12swg Stainless Steel with flush or Surface options.
EASYGATE
All units are IP55 rated, with voice guided programming.
The GSM EasyGate interface unit comes with a 2Amp plug top PSU, high gain aerial, CD, and RJ11 cable. PLEASE NOTE. No SIM card is supplied with
the unit. The GSM unit is SIM free, which enables the end user to select the service provider, depending on signal strength coverage.
9135130E BASE MODULE
SYSTEM DIAGRAM
How do you put a system together?
Base Modules
• Establish the number of telephone numbers you wish to call
• Choose whether you want individual push buttons per telephone number or do you wish to use the keypad as a short dial function. the maximum number of
push buttons is 54 and the maximum number of short dial options via the keypad is 50 numbers. The keypad can also be used as a code lock.
• Work out the base module you require i.e. number of buttons (3 button 9135130E (914-1137) or 6 button 9135160E (914-1139) and if a keypad is required
(913513OKE (914-1138) or 9135160KE (914-1140)), then add extension modules as required. (9135181E (914-1145) or 9135182E (914-1146)
How do you want to Communicate?
• BT or equivalent telephone line or via an analogue extension port on a PABX (No additional communication equipment required)
• GSM Interface (if using GSM then you will require a GSM interface unit (501303GB (915-1502))
Accessories
• Add a roof module (Rain cover) (optional i.e. 9135331E (915-1675))
• The Base Modules are surface mounted as standard. If you require the unit to be flush fitting add the relevant flush fixing kit.
• If you require an anti-vandal base module add the appropriate anti-vandal kit, note that the flush fitting kit comes with the anti-vandal unit.
Power Supply
• All the base modules requires a 12V dc PSU
Camera
Any base module can be fitted with a colour/mono switchable camera with infra-red. The camera will need to be cabled to either an LCD screen or by using an
MPEG/LAN converter to the Local Area Network (LAN). This will allows the camera to be given an IP address and all images can then be viewed by using an
authorised PC via a web browser.
System Build Examples
3 Way System to BT Line
14 Way System to BT line
1 x 935130E (914-1137)
1 x 12V dc PSU
1 x 9135160E (914-1139)
1 x 9135181E (914-1145)
1 x 12V dc PSU
To make the above system GSM capable add
1 x 501303GB (915-1502) and purchase a
suitable SIM card with sufficient credit to
make calls (available from others)
To make the above system GSM capable add
1 x 501303GB (915-1502) and purchase a
suitable SIM card with sufficient credit to
make calls (available from others)
Up to 50 Way System dialling via
numeric keypad to BT line
1 x 9135130KE (914-1138)
1 x 12v dc PSU
To make the above system GSM capable add
1 x 501303GB (915-1502) and purchase a
suitable SIM card with sufficient credit to
make calls (available from others)
9135130KE BASE MODULE
The GSM interface requires a standard SIM card as found in mobile phones that is connected to a mobile network with sufficient credit to be able
For more information about our products, please call +353 (0) 1450 1366
to make calls (supplied by others). Subject to mobile service providers area coverage.
Relink systems DO NOT work with SIM cards from the 3 network
WAVELINK COMMUNICATIONS (2 Year Warranty)
Code
51
Trade
Base Modules
Note: All Base modules require a 12V dc PSU
NEW
914-1137
9135130E 3 way Base module with 3 single buttons
NEW
914-1139
9135160E 6 way Base module with 3 double buttons
Base Modules with Keypad
NEW
914-1138
9135130KE 3 way Base module with 3 single buttons + Keypad
NEW
914-1140
9135160KE 6 way Base module with 3 double buttons + Keypad
NEW
Video module
927-2508
9135210E Video Camera kit. Will fit any base unit
Extension Modules
NEW
914-1145
9135181E 8 way expansion module with single buttons
NEW
914-1146
9135182E 16 way expansion module with double buttons
Module accessories (Optional)
NEW
915-1675
9135331E Roof for 1 module (Rain Cover)
NEW
915-1676
9135332E Roof for 2 modules (Rain Cover)
NEW
915-1677
9135351E Flush fixed box for 1 module
NEW
915-1678
9135352E Flush fixed box for 2 modules
NEW
915-1679
9135361E Roof and box for flush fitting 1 module
NEW
915-1680
9135362E Roof and box for flush fitting 2 modules
NEW
915-1681
9135511E Anti-Vandal cover + flush back box for 1 module
NEW
915-1683
9135521E Anti-Vandal cover + flush back box for 2 modules
NEW
915-1682
9135511KE Anti-Vandal cover with keypad + flush back box for 1 module
NEW
915-1684
9135521KE Anti-Vandal cover with keypad + flush back box for 2 modules
Note: All Base modules require a 12V dc PSU
NEW
914-1054
111SF 1 way Flush
NEW
915-1538
111SS 1 way Surface
NEW
914-1055
112SF 2 way Flush
NEW
913-1039
112SS 2 way Surface
NEW
914-1056
113SF 3 way Flush
NEW
913-1040
113SS 3 way Surface
NEW
914-1057
114SF 4 way Flush
NEW
913-1041
114SS 4 way Surface
NEW
914-1058
115SF 5 way Flush
NEW
913-1042
115SS 5 Way Surface
Stainless Steel Base modules with Panel Mount Reader Cut Out
NEW
914-1059
211PCSF 1 way Flush with PAC/Paxton cut out
NEW
913-1043
211PCSS 1 way Surface with PAC/Paxton cut out
Stainless Steel Base modules with numerical keypad
NEW
914-1060
311KSF 1 way Flush with Keypad
NEW
913-1044
311KSS 1 way Surface with Keypad
Stainless Steel Base modules with video camera
NEW
914-1061
411VSF 1 way Flush with Video Camera
NEW
913-1045
411VSS 1 way Surface with Video Camera
NEW
914-1062
412VSF 2 way Flush with Video Camera
NEW
913-1046
412VSS 2 way Surface with Video Camera
Stainless Steel Base modules with video camera and Panel Mount Reader cut out
NEW
914-1063
511VPSF 1 way Flush Video with PAC/Paxton cut out
NEW
914-1064
511VPSS 1 way Surface Video with PAC/Paxton cut out
NEW
Accessories
915-1502
501303GB EasyGate GSM Interface Unit - for use when GSM connection is required
The GSM interface requires a standard SIM card as found in mobile phones that is connected to a mobile network with sufficient credit
to be able to make calls (supplied by others). Subject to mobile service providers area coverage.
NEW
927-2509
9135250 Secondary auxiliary switch – Allows the control of a secondary device. Rated at 50V 2A
NEW
927-2510
9135301 Additional single button name badge – Replacement button for extension panels. Can also be used to configure button arrangement on extension panels
NEW
927-2511
9135302 Additional double button name badge – As above but with double button
NEW
927-2512
9135311 Info panel name badge - Replaces all buttons in 8 way expansion module. the purchase of an additional 8 button extension module is required
NEW
927-2506
9134145E Video Server MPEG4/LAN convertor
NEW
927-2514
W9134147E LCD display 7”
NEW
927-2507
91341481E 12V dc 2A power supply
NEW
927-2513
W9134171E VoIP adaptor
646.00
Audio & Video Door Entry Systems
Stainless Steel Base Modules with Single Buttons (Up to 54 way available)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
