Welcome to Bonaire.
As Australia’s leading heating and cooling brand, Bonaire has been providing homes with state of the art, efficient
heating and cooling systems for over 60 years. Using proven technology we create intelligent, user friendly systems
that maximise energy efficiency and reduce operating costs. We constantly strive to ensure that the Bonaire name
is synonymous with quality and innovation and this is what continues to drive the company today.
The Bonaire mission.
Our Mission is to deliver the most advanced range of whole of home heating and cooling solutions to fit
today’s modern lifestyles.
Bonaire quality.
At Bonaire we place enormous importance on continually improving design, engineering and manufacturing
processes and every one of our products is manufactured to the highest possible standards using premium
quality materials. All Bonaire units are quality tested before they leave our factory, and are supported by a
carefully selected dealer network that is committed to customer satisfaction.
Contents.
3
We are proud that Bonaire is Australian made and owned with world class manufacturing facilities in
Adelaide SA and Leeton NSW being the foundation of the business.
Welcome to Bonaire
4Choosing the right cooling system for your home
6
Bonaire Evaporative Air Conditioning
9
The Bonaire Evaporative Range
10 A choice of controllers
11 Bonaire Durango Evaporative Window Air Conditioner
12 Bonaire Reverse Cycle Air Conditioning
14 Bonaire Inverter High Wall Split System Air Conditioning
16 Bonaire Dual Cycle Refrigerated Air Conditioning / Gas Heating Systems
17 New Homes and Renovations with Bonaire
18 Specifications
Saves water.
Saves on running costs.
Saves the environment.
Cool your whole home.
3
Choosing the right cooling system
for your home.
There’s nothing quite like walking into the cool surrounds of your home and escaping the blistering summer
heat outside. When you consider that cooling accounts for a large proportion of household’s energy costs
over summer, it’s so important to select the right cooling methods for your home. The wrong choice can
prove both costly and uncomfortable.
Whole of home cooling vs room cooling.
The most important choice you have to make is whether
you need to cool separate rooms or your whole home.
Room cooling.
If you only need to cool individual rooms in your home,
then a Refrigerated High Wall Split System is the way to go.
Refrigerated High Wall Split Systems consist of a condensing unit
installed on the outside of your home, and a wall mounted unit
inside your home, which artificially cools the air through indoor
and outdoor coils connected by pipes carrying refrigerant gas.
Bonaire also offers a low cost and easy to install option a window mounted fresh air room evaporative cooler.
Some important questions
• In a long hot summer, will I be comfortable just cooling
one or two rooms?
• Do I want the comfort of having every room cooled?
• Should the purchase price be my biggest consideration?
• Do I need cooling all day or for short periods of time?
• Should I think about running costs?
• Will noise bother me or my neighbours?
• Does anyone in my house suffer from asthma or
hay fever?
Whole of home cooling
When it comes to cooling your whole home, you have the choice
of two main systems, ducted refrigerated systems and ducted
evaporative systems.
The ducted refrigerated systems work on the same principal
as the split room systems, with an indoor and outdoor coil.
Traditionally you’ll find these systems work on a day/night zone
system which lets you cool the living areas of your home during
the day and cool the sleeping areas at night.
Ducted evaporative coolers on the other hand, use fresh air
to cool all rooms of your home at the same time. Fresh air is
drawn from outside your home through the water moistened
filter which cools and cleans the air. The cool, fresh air is then
circulated through the ducts, forcing stale air out through
open windows and doors. This natural cooling process has low
installation and low running costs, low noise and low greenhouse
emissions, and is ideal for asthma and hay fever sufferers. All
rooms in your home are cooled at the same time.
4
5
Bonaire Evaporative Air Conditioning.
An evaporative cooling system is simply the most cost effective and quietest way to cool your home. For over 50
years Bonaire have been providing Australians with innovative, efficient evaporative cooling systems. Today we
continue to draw on the latest technology to create intelligent, environmentally friendly and user friendly cooling
systems that maximise energy efficiency and minimise expense to your pocket.
• 10 year structural warranty (parts only)
Bonaire is the environmentally friendly cooling option.
• 25 year corrosion warranty on the cabinet (parts only)
• Integra 3 year plus 2 year extended parts and labour
warranty standard*
• Australian made and owned
• Pioneers in evaporative cooling in Australia
• Injection moulded cabinets
The low profile Bonaire EAC
Evaporative Air Conditioning.
When it comes to the most efficient and economical way to
cool your whole home, you can’t go past evaporative cooling.
Economical to buy and to run, it is the most cost efficient and
quiet way to stay cool this summer.
Why choose Bonaire Evaporative Cooling.
• Models to suit any home size or budget
• Easy installation
• Low running costs
• Low energy consumption = reduced electricity bills
• Designed and built for Australia’s harsh environment
• All four CELdek® pads are equal in size for optimum cooling
To ensure that the correct unit is installed in your home, we
designed Bonaire’s unique Bonres® sizing system. The Bonres®
computerised unit selection system takes into account such
things as wall construction, insulation, glass area, room sizes,
house orientation eg North, South, East, West and the climatic
conditions of the area in which you live, to select and design the
right Bonaire system for you and your family.
Bonaire ducted evaporative cooling is cheaper to run.
Our ducted evaporative systems are an extremely efficient way
to cool your home as indicated by the table below. It shows just
how little power the Bonaire systems actually use.
Cooling system
• Quiet operation
• Large CELdek pads, unlike some competitor units for
maximum cooling efficiency
• Circulates only fresh, clean naturally cooled air throughout
your home – doors and windows are left open
• Filtered air is soft and gentle on noses, eyes, and skin. Ideal for
asthma and hayfever sufferers
• More cost effective to install and run than comparable ducted
refrigerated units
• Environmentally friendly, producing less than 15% of the
CO2 greenhouse gases produced by a standard ducted
reverse cycle system (Refer to graph page 7)
• Helps eliminate smoke and cooking odours
Hourly running cost (¢) **
0
20
40
60
80
Ducted refrigerated air conditioning
(average efficiency-150m2)
87
Split system air conditioner
(average efficiency-150m2)
27
12
Central evaporative cooling† (150m2)
Portable evaporative cooler
5
Portable fan
1
Ducting
• Indoor plants thrive on fresh air cooling
• Helps reduce the spread of infections
The Bonaire Water Conservation System*.
This clever and reliable device is designed to automatically
minimise the water usage of the evaporative air conditioner
while still ensuring that the system has the correct amount
of fresh water to guarantee efficient operation.
Helps save the environment.
If you’re concerned about the environment, you should
choose a Bonaire evaporative cooling system. Our evaporative
‘whole of home’ system produces less than 15% of the CO2
greenhouse gases produced by a comparable ducted reverse
cycle refrigerated system.
* Subject to a maintenance service call in the third year.
**SEAV, ‘Operating costs of electrical appliances’ Nov 2002.
Roof Unit
Bonaire conserves water and helps save the environment.
As water conservation becomes more and more a priority for
Australians, Bonaire have a number of water saving technologies
that will ensure water usage is kept as low as possible.
By using Bonaire evaporative air conditioning, you can reduce
your impact on climate change! Evaporative air conditioning
produces less black balloons of green house gas than ‘whole of
home’ refrigerated systems. Ref: saveenergy.vic.gov.au Feb 2009
Naturally cooled, evaporative air conditioners circulate fresh air throughout your entire home.
Hot, stale air is forced out.
Tonnes of CO2/Year **
0
0.5
1.0
1.5
Ducted refrigerated
air conditioning
(average efficiency – 150 m2)
2.5
3.0
2.85
Split system air conditioner
(average efficiency – 50 m2)
Bonaire evaporative
cooling (150 m2)
• Unique ‘Bonres’ unit selection system
2.0
0.86
0.37
• Adds value to your home
• 3 years parts and labour warranty standard
Ceiling Outlets
6
* Compared to a conventional ducted evaporative air-conditioning system with manual bleed. Actual water saving depends on geographical location and unit size.
**SEAV Victoria "Choosing a cooling system" Nov 2002.
7
Bonaire Evaporative Air Conditioning.
The Bonaire Evaporative Range.
Bonaire has been manufacturing evaporative coolers with state of the art components and technology for over
Bonaire have always been leaders in evaporative cooling technology and offer you the choice of two outstanding
50 years. To guarantee your total comfort, all units have been designed by our specialised R & D team to ensure
evaporative cooling systems. Whether it’s the economical Summer Breeze or the top of the range Integra, you
they suit Australian conditions.
know Bonaire will cool your home ultra efficiently and quietly this summer.
Setting a benchmark in quietness.
For the quietest way to stay cool this summer, you should choose
a Bonaire evaporative cooling system. That’s because Bonaire’s
direct drive cooling fan is low noise and it’s effective design
means it is extremely efficient.
Smart stylish design.
In comparison to other units, Bonaire’s sleek low profile design
sits snugly on your rooftop and comes in a range of stylish
colours. This clever design holds less water than conventional flat
based units.
The Bonaire Summer Breeze.
The Summer Breeze range gives you cool, fresh air to every room
with just the touch of a button. Carefully designed to maximise
energy use, the Summer Breeze will help you save on running
costs.
The Premium Bonaire Integra.
The Bonaire Integra comes standard with a 2 year extended
warranty,* an Enviroseal duct shutter and the ultimate wireless
remote control, all specially designed and optimised to maximise
the performance of your Bonaire Evaporative air conditioning.
Advanced engineering.
Advanced engineering design has seen the Bonaire evaporative
cooling systems at the leading edge of cooling efficiency. The
unique motor and fan construction, together draw air evenly
over the four CELdek® pads. This delivers enhanced efficiency,
low maintenance and measurable savings in running costs.
Bonaire coolstart*.
With Bonaire’s pre cool system, your home will be cool from the
start. You’ll only feel cool, fresh air when you turn on your air
conditioner as opposed to some competitors units that actually
blow hot air for up to 5 minutes.
Just look at the benefits it offers to outperform its competition.
• It is low maintenance with measurable savings in running costs
• It is low maintenance with measurable savings in running costs
• Strength to withstand the most extreme weather conditions
• Strength to withstand the most extreme weather conditions
• A high strength injection moulded polymer cabinet
• A high strength injection moulded polymer cabinet
• Stabilised polymers keep it looking new year after year
The in built water management system also ensures that a
minimum amount of water is used in providing optimal levels
of cooling performance.
Installed by specialists.
For added peace of mind, we recommend you choose one of our
authorised Bonaire specialists, who have been trained to ensure
your Bonaire cooler is installed to the highest standards.
• Stabilised polymers keep it looking new year after year
• Low noise and efficient direct drive cooling fan
• Low noise and efficient direct drive cooling fan
• Sleek, low profile design fits snugly on your roof
• Sleek, low profile design fits snugly on your roof
• Bonaire Water Conservation System standard
• Bonaire Water Conservation System standard
• A range of beautiful fashion colours that are aesthetically
pleasing
Low Noise Fan
The direct drive system of the low
noise fan has no belts or pulleys that
traditionally use more energy and
wear out. It employs the latest in
aerodynamic research technology
to ensure super quiet operation and
maximum air flow.
• A range of beautiful fashion colours that are aesthetically
pleasing
• Circulates only fresh, clean naturally cooled air throughout
your home
* Only available with RF and LV controllers.
• Soft and gentle on noses, eyes, and skin. Ideal for asthma and
hayfever sufferers
• More cost effective to install and run than comparable ducted
refrigerated units
Structural strength.
Bonaire units have a high strength, injection moulded polymer
cabinet. So unlike other competitors units that may sag or
warp, they are strong enough to withstand Australian weather
conditions and are UV stabilised to ensure sun protection year
after year.
• 3 year parts and labour warranty standard
• 3 size options; small, medium and large, to cool any sized
home.
High tech computerised control module
Self cleaning water distribution tray
More economical super sensor motor
and direct drive fan
Super Sensor V Motor
Strategically placed away from the unit’s
central air stream, your home is cooled
more efficiently. An over temperature
cut-out protects the motor from
over-heating.
Air is drawn evenly from all four louvre pads
Motor: Thermal Overload Protection
Self-cleaning EZI drain tank
High tech louvre construction
8
Reliable multi-flow pump
• Circulates only fresh, clean naturally cooled air throughout
your home
• Soft and gentle on noses, eyes, and skin. Ideal for asthma and
hayfever sufferers
• More cost effective to install and run than comparable ducted
refrigerated units
• Enviroseal duct shutter accessory
• 3 year plus 2 year extended parts and labour warranty
accessory*
• RF Remote control standard
• Choice of controllers**
The Enviroseal
Duct Shutter.
During winter when
the unit is not in use,
Bonaire’s Enviroseal
keeps warm air in
and drafts out. It’s
fully automatic and
fits into the duct of
your evaporative air
conditioning system.
The duct shutter
in the open position
The duct shutter in
the closed position
* Subject to a maintenance service call in the third year.
**Controller purchased separately.
9
A choice of controllers.
Bonaire Durango Evaporative
Window Air Conditioner.
Putting you in complete control at home, you can choose from an RF remote control or an electronically
The Bonaire Durango is designed to easily cool today’s open plan homes with areas up to 75 square metres.*
programmable controller, depending on your family needs and the type of home you have.
It’s quiet, environmentally friendly and best of all, very economical to run. It can be easily installed into most
windows and with its neutral colour, the Bonaire Durango blends in no matter what the environment.
RF Remote controller - Integra/Reverse cycle controller.
If you’re after the ultimate in controllers our radio frequency
remote control is for you. All you have to do is choose the setting
you want and it’s automatically monitored and maintained. All
without leaving the comfort of your armchair.
Ultimate wireless remote controller
• Wireless Radio Frequency remote
• Able to operate from room to room
• Temperature sensing in any room with an air outlet
OUTSIDE
INSIDE
• Easy to operate in either manual or auto modes
Pictures may not depict latest model
• 24 hour start/stop timer
• Built in zoning controls*
• Economy and boost functions
• Clear and easy to read LCD display
• Option to control multiple Bonaire appliances
• Self diagnostics
• Compatible with Bonaire’s ducted heating, evaporative air
conditioning and refrigerative cooling systems
IN
out
Premium programmable controller
Running costs
from as little
as 25 cen**ts
per day
Programmable premium controller Summer Breeze/Reverse cycle controller.
Wall controller with easy to use functions and LCD display.
• Easy to operate in either manual or auto modes
• 24 hour start/stop timer
• Economy and boost functions
• Clear and easy to read LCD display
• Option to control multiple Bonaire appliances
Features.
• Compatible with Bonaire’s ducted heating, Summer breeze
evaporative air conditioning models and Bonaire refrigerative
air conditioning systems
•Cools an area up to 75 square metres*
•Costs less than 25 cents per day to run**
•250mm deep low profile cabinet does not obstruct exterior area
•Powerful three speed fan motor
Digital Manual Controller - Summer Breeze controller.
Is compact and simple to operate.
• Simple 4 button operation
•Direct drive fan for higher efficiency
Manual digital thermostat
• Small and compact
• Option to control multiple Bonaire appliances
•Transition duct supports the unit without any need for
additional structural support
Air flow
4,500 m3/hr
Window section
H 550mm
W 550mm
D 260mm
•UV stabilised polymer cabinet will never rust
External cabinet
H 1170mm
W 850mm
D 250mm
External cabinet clearance (TOP)
100mm
Weight
40kg
Electrical
240 Volts
1 Phase
50 Hz
Fan speeds
3
•The cool and ventilation mode allows the choice of water
flow cooling or just fan operation
• Compatible with Bonaire’s Summer Breeze evaporative coolers
and ducted heating
10
Product Specification
•Uses standard electrical and plumbing connections
• Clear and easy to read LCD display
• Not available with ducted refrigerated models
•Easy to install into most windows
•Full two year parts and labour warranty
* Individual zone motors supplied by installer at additional cost. Zoning not used with Evaporative Air Conditioning.
* Depending on geographic location, unit position, room heat gain, and 2.4m ceiling
height @ 25 air changes per hour.
**Based on 8 hours of running @ 14 cents per kW/h.
11
Bonaire Reverse Cycle Air Conditioning.
The ultimate in climate control.
The Bonaire Ducted Reverse Cycle Air Conditioning System has been designed so that you
and your family can relax in complete comfort.
B009RS
B009HD
B012HD
B012RS
8.9kW SINGLE PHASE
12kW SINGLE PHASE
B015RS
B015HD
B019HD
B019RT
14.7kW SINGLE PHASE
18.7kW 3 PHASE
The ultimate in performance.
Built to Australian standards, Bonaire Ducted Reverse Cycle
Air Conditioners feature internal noise insulation for quiet
performance, state of the art compressors and electronically
controlled variable speed outdoor fans to ensure optimum
performance at maximum output. All single phase units feature
the latest soft starting technology.
To ensure long lasting reliability, even in Australia’s extreme
environment, all Bonaire outdoor units have a powdercoated
cabinet and refrigeration coils are manufactured with a
Hydrophilic Polymer Anti-corrosion Coating.
Bonaire refrigerated air conditioners use a light weight
Australian made indoor fan coil unit, especially designed for
Australian homes and conditions. These fan coil units include
safety trays and foil faced closed cell cabinet insulation.
To ensure that the correct unit is installed in your home,
we have developed Bonres®, Bonaire’s unique sizing system.
The Bonres® computerised unit selection system takes into
account such things as wall construction, insulation, glass area,
room sizes and the climatic conditions of the area in which you
live, to select and design the right Bonaire system for you and
your family.
Other clever design features include soft heat to prevent cold
drafts and auto restart (RF controller only) to
restart units in the event of a power failure.
Finally, Auto Changeover allows one
temperature to be set which runs the unit in
heating or cooling mode and maintains comfort
in all models of Bonaire high performance
Refrigerated Air Conditioning units.
They are available with a single phase
power supply up to 14.7kW, saving on
installation costs.
Fin material cross section view.
F I N M AT E R I A L C R O S S S E C T I O N V I E W
Water
Corrosion
Airflow
The ultimate peace of mind.
For added peace of mind, we recommend you choose one of our
authorised Bonaire specialists, who have been trained to ensure
your Bonaire Air Conditioner is installed to the highest standards.
You should talk to your dealer about matching your cooling
needs with Bonaire’s inbuilt zoning control system. This system
offers you the flexibility to control cooling in up to 4 living
zones so you can choose between cooling the kitchen, dining
and family rooms, bedrooms or the study to suit your lifestyle
requirements. Please see you Bonaire dealer to discuss your
lifestyle requirements.
12
Warranty.
Every Bonaire Ducted Reverse Cycle Air Conditioner is manufactured
to stringent quality standards and backed by a five year residential
and two year commercial, parts and labour warranty fully supported
by Bonaire’s National Service Division.
It’s real peace of mind as you and your family enjoy the ultimate
in home climate control.
Hydrophilic coating
Corrosion-resistant layer
Compressor starting current*.
Outdoor fan economy mode*.
127
100
COMPRESSOR STARTING CURRENT*
Without Bonaire
Soft Starter = 127 A
With Bonaire
Soft Starter = 36 A
36
18
Running Current
(approx) = 18 A
Hydrophilic coating
Start
All Bonaire outdoor units are manufactured with an
anti-corrosion material for long lasting reliability.
Conventional
Fixed Speed Fans
70
Alluminium metal sheet
Corrosion-resistant layer
O U T D O O R FA N E C O N O M Y M O D E *
TIME
SPEED (%)
The Bonaire Reverse Cycle Air Conditioning System consists of
an outdoor unit conveniently located outside your home and
an indoor unit concealed out of sight. They are connected to
an insulated duct system which distributes the conditioned air
through your home via small floor or ceiling ducts. So no matter
what your style of home, your Bonaire air conditioner will hardly
be seen or noticed.
CURRENT (A)
The ultimate in design.
One of the real advantages of refrigerated cooling systems
is the ability to cool selected zones in your home which means
you won’t waste energy cooling rooms that no one is using.
Economy Mode function
reduces the maximum
outdoor fan speed level
34
35
O U T D O O R T E M P. ( º C )
Bonaire Soft Starters reduce extreme starting loads and
annoying light flicker associated with system start-ups.
Ideal for night-time operation to reduce the
outdoor noise level.**
* Operation based on cooling mode. This chart refers to the
compressor starting current of the B015RS.
* Operation based on cooling mode.
**The outdoor noise level reduction may vary depending on unit location and environmental conditions.
13
Bonaire Inverter High Wall
Split System Air Conditioning.
Bonaire is proud to launch our new range of inverter high wall split systems. The Bonaire range of
inverter high wall split systems have clever features coupled with a stylish design to complement
today’s modern homes.
7.0kW Indoor Unit
Good looks.
At Bonaire we understand that the looks of the unit are
important and the Bonaire wall mounted unit will blend
unobtrusively into today’s homes. It also has functional appeal
as the panel can be simply wiped clean.
More economical.
Because an inverter will increase or decrease power to the
compressor and fans depending on the requirement, this
means they can operate more economically than traditional
fixed speed units.
Inverter technology.
Bonaire inverter technology accurately matches your cooling or
heating requirements to give you energy efficiency. Conventional
fixed speed units operate at 100% delivering a fixed volume
of heating or cooling. Effectively they operate on a stop start
system. Bonaire’s advanced inverter technology increases or
decreases the power depending on the conditions. Bonaire’s
compressors will vary their capacity to maintain a consistent
temperature.
Comfort levels.
When the Bonaire Inverter air conditioner is switched on in either
heating or cooling mode it will automatically operate at high
speed to ensure your selected temperature is achieved quickly.
It will then adjust the fan speed to maintain the desired room
temperature.
Temperature
Off
Inverter Model
On
Conventional Model
Time
High energy efficiency.
As a result, Inverter air conditioners are smoother in operation,
more economical, quieter and deliver higher efficiency compared
to conventional systems.
Low noise level.
The Bonaire Inverter operates so quietly you will hardly notice
it. It can also operate in low noise sleep function where the unit
will automatically adjust the temperature to make the room
more comfortable while you sleep.
The right advice.
If your unit is too small you can end up with reduced comfort
levels, if it’s too big you could have a large electricity bill. Bonaire
dealers are specialists in heating and cooling and will ensure the
unit is correctly sized for your requirements. Our dealers are also
installers and will give you a price covering all the installation
requirements.
Service support.
Bonaire Inverter air conditioners are fully backed up by Bonaire’s
integrated service department giving you total peace of mind.
Remote controls.
The remote control makes it easy to operate the system.
The LCD display on the remote and the LED display on
the unit allow you to view the current settings.
Simple programming.
Simple programming functions allow you to easily program
functions like time till on and time till off.
Air filters.
Easily removable and washable air filters enable you to wash out
dust and other air-borne particles.
Intelligent digital dehumidification.
Controls the comfort level of the humidity in the air for a more
comfortable room temperature.
Fan only mode.
This setting runs the fan only, which is ideal for Autumn and
Spring, providing air movement within the room.
I feel mode.
Allows you to preset an automatic temperature and fan speed
to optimise comfort based on outside
ambient temperatures.
Warranty.
The Bonaire Inverter High Wall Split
System is supported with a five year
domestic parts and labour warranty.
5.0kW Indoor Unit*
3.5kW Indoor Unit*
External condenser unit
Domestic Warranty Only
* Picture shown may vary slightly from actual model.
14
15
Bonaire Dual Cycle Refrigerated
Air Conditioning / Gas Heating Systems.
New Homes and Renovations with Bonaire.
The ultimate in home heating and cooling, all year round. When you couple a Bonaire ducted gas heating unit
Whether you’re building a new home or renovating, we recommend you consider the following
with a Bonaire ducted refrigerative unit, your complete Bonaire Dual Cycle system delivers warm and cool air
points to make sure you choose the right cooling system.
effortlessly through the same concealed duct system.
At Bonaire, we strongly recommend matching only Bonaire gas
central heating with Bonaire refrigerated air conditioning and a
duct system specifically designed for a dual cycle. The end result
is Australia’s ultimate dual cycle heating and air conditioning
system.
Ultimate features and benefits.
Bonaire Dual Cycle systems* have been designed to deliver
efficient and reliable performance all year round. Some of the
benefits of installing a Bonaire Dual Cycle system with a Bonaire
ducted gas heater are:
With thermostatic temperature control all year round, you’ll
enjoy the ultimate in climate control for your family even
during sustained periods of hot and humid weather or freezing
cold weather.
• The entire system’s operation, programming and zoning
selection can be controlled by one controller
• The ultimate in climate control for your family year round, even
during sustained periods of hot and humid weather
• Uncompromised constant heating performance regardless of
how cold it is outside
†
• Integrated zoning control on all 4 and 5 star ducted gas central
heating units
• State of the art soft starter controls fitted to all single phase
refrigerated outdoor units for optimum operation
• Fully combined heating and cooling comfort via a single ducting
system – specifically designed for a Bonaire dual cycle system
• Zone control standard†. Heat or cool only the rooms you want to
• Installed with Bonaire’s Bonres® computerised unit
selection system**
• Engineered for Australian conditions
Ultimate in peace of mind.
Every Bonaire Dual Cycle System is manufactured to stringent
quality standards backed by a five year residential and two year
commercial, parts and labour warranty*** and Bonaire’s fully
trained National Service Division.
It’s real peace of mind as you and your
family enjoy the Ultimate Heating and
Cooling Solution for your home.
Indoor Refrigerated Unit
Dual Cycle Unit
* Bonaire Dual Cycle systems are only recommended for sale and installation with matched Bonaire ducted gas heating units.
** Invalid if not sized strictly in accordance with Bonres® specifications. Installation and commissioning to Manufacturer’s and Industry Standards and State regulatory law is the responsibility of the installer.
***The Bonaire Dual Cycle warranty does not apply to the ducted gas heating unit. All Bonaire ducted gas heating units carry their own warranty program and conditions. Please refer to your dealer or product information for more details.
† Individual Zone motors supplied by installer at additional costs.
16
• Energy efficient homes should consider an evaporative
cooling option
• Ducted gas heating/dual cycle Bonaire systems gives you the
ultimate in heating and cooling.
Renovating your home.
Whether you already have an existing evaporative or refrigerated
air conditioning system, Bonaire has the range that’s ideal for
you. However, before you install a new system there are a few
points that you should consider.
Building a new home.
If you’re building a new home then it makes sense to ensure
you incorporate central heating and cooling planning from the
outset so that they are part of your earliest designs and not an
after thought. After all, this is your biggest investment and the
right ducted heating and cooling system will add value to your
investment. It can be easily integrated into the construction of
your home and make for simpler and more efficient installation
during construction. Here are some points to consider.
• Lifestyle choice of indoor, outdoor living with
evaporative cooling
• Environmental option of evaporative cooling
• Running costs are lower with evaporative cooling
• You should check if your existing duct work can handle your
future needs as it may need to be upgraded.
• Also, check if your current air conditioner is suitable for your
existing needs and will it meet your new requirements once the
renovation is complete.
• Another consideration is whether you need upgrading
from a room air conditioner to Bonaire’s whole of home
ducted cooling.
All of these can make your new Bonaire air conditioner even
more efficient.
Finally, you should consider a Bonaire gas heating option.
This means your one controller will cater for both your heating
and cooling needs all year round.
• Ultimate Bonaire zoned ducted refrigerated air conditioning
Heating
Outdoor Refrigerated Unit
Dual Cycle System
• Bonaire can provide your total heating and cooling solutions
from the design stage onwards
Cooling
Bonaire, the year round choice.
Bonaire lets you enjoy complete heating and cooling comfort all
year round at the touch of a button. Illustrating our commitment
to innovation, Bonaire ducted evaporative cooling can be
combined with Bonaire 3 star, 4 star or 5 star gas ducted central
heating using just one thermostat. You have
the choice of installing Bonaire heating at
the same time as your Bonaire cooling or
simply add it at a later date.
Bonaire is a Quality Endorsed Company and all products are
Australian owned. In addition, all products made and engineered
by Bonaire are backed by Climate Technologies National Service
Division, a wholly Australian owned company.
Please ask your
dealer for a Bonaire
Gas Heating Product
Brochure
Bonaire B4 20E 4 star external model.
17
Specifications.
Bonaire Inverter HIGH WALL SPLIT AIR CONDITIONING
Model Number
Model Indoor
Indoor Part Number
Model Outdoor
Outdoor Part Number
Type
Control type
Rated cooling capacity (range)
kW
Rated heating capacity (range)
kW
EER for cooling
Star rating cooling
COP for heating
Star rating for heating
Moisture removal
l/Hr
Indoor sound pressure level at 1 MTR (High Speed) dB(A)
Outdoor sound pressure level at 1 MTR
dB(A)
Electrical Data
Power supply
Rated Current (Amps)
Cooling
Heating
Rated input (watts)
Cooling
Heating
Refrigerant System
Refrigerant Type
Compressor Type
Evaporator coil
Condensor coil
Fan system
Indoor air circulation
l/s
Indoor fan motor output
Watts
Outdoor fan motor output
Watts
Connections
Connecting Pipe - Gas
Inches
Connecting Pipe max length
Metres
Connecting Pipe - Liquid
Inches
Other
Suitable area
M2
Indoor Dimensions (WxHxD)
mm
Outdoor dimensions (WxHxD)
mm
Packaging dimensions Indoor (WxHxD)
mm
Packaging dimensions Outdoor (WxHxD)
mm
Gross Weight Indoor
Kg
Gross weight Outdoor
Kg
Warranty - Domestic
Outdoor Operating Temperature Range*
Cooling
Heating
BONAIRE Reverse Cycle ducted refrigerative air conditioning
BH35
BHWSI35
6700031
BHWSO35
6700030
Inverter reverse cycle
Remote
1.2 - 3.7
1.3 - 4.5
3.06
4.5
3.22
4.0
1
38
67
BH52
BHWSI52
6700041
BHWSO52
6700040
Inverter reverse cycle
Remote
1.6 - 6.0
1.4 - 6.8
2.97
4.0
3.05
3.5
2
42
69
BH70
BHWSI70
6700051
BHWSO70
6700050
Inverter reverse cycle
Remote
1.98 - 7.50
2.1 - 8.5
2.84
3.5
3.02
3.0
2.5
57
72
220 ~ 240VAC /50/1P
4.7
5.0
1060
1140
220 ~ 240VAC /50/1P
8.2
8.7
1750
1880
220 ~ 240VAC /50/1P
10.0
10.2
2460
2460
R410A
Rotary
3 bend
Double arranged
R410A
Rotary
3 bend
Double arranged
R410A
Rotary
3 bend
Double arranged
142
12
31
236
23
68
306
55
95
1/2”
15
1/4”
1/2”
15
1/4”
5/8”
15
3/8”
15~23
770x240x180
760x552x256
863x325x256
863x598x376
10.5
37
5 year parts and labour
21°C ~ 43°C
-5°C ~ 24°C
25~40
898x280x202
820x605x300
955x365x298
955x650x438
14
46
5 year parts and labour
30~50
1240x325x250
902x650x307
1317x422x338
1027x705x433
25
64
5 year parts and labour
Capacity
Rated capacity
Power input
Features
RF Wireless Remote Controller
Soft Starter
Super Hydrophilic Anti Corrosion Fins­
LV Wall Mounted Controller
Reverse Cycle
7-Day Multi-schedule Programming
Soft Heat Mode
Multi-function Defrost Cycles
Auto-Changeover Function
Economy Mode
Zone Control
Auto Restart*
Performance
Rated Indoor Airflow
Rated Static Pressure
EER
COP
Electrical
Power Supply
Running Current
Compressor Type
Outdoor Sound Level @ 1m
Installation & Dimensions
Dimensions
Weight
*All units tested to T1 parameters
Indoor
Outdoor
B009HD
B009RS
B012HD
B012RS
B015HD
B015RS
B019HD
B019RT
kW
kW
kW
kW
8.9
9.3
3.1
3.1
12
12.2
4.4
4.3
14.7
15.3
5.3
5.3
18.7
19.3
6.7
6.1
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Cooling
Heating
L/S
Pa
W/W
W/W
540
140
2.87
3.00
750
140
2.73
2.84
850
140
2.77
2.89
1050
160
2.79
3.16
Cooling
Heating
Ø/V/Hz
A
A
Pressure
(dB(A)±2)
1/240/50
14.4
14.4
Scroll
56
1/240/50
20.4
19.9
Scroll
56
1/240/50
25.1
25.1
Scroll
58
3/415/50
12.8
12.1
Scroll
63
Indoor
Outdoor
Indoor
Outdoor
Supply
Return
HxWxD mm
HxWxD mm
Kg
Kg
WxH mm
WxH mm
401x1181x510
Liquid
Gas
mm
mm
381x946x510
960x970x365
39
92
246x251
716x292
R22
9.53
19.05
Flare
25
15
10
25
15°C ~ 46°C
(-5°C) ~ 24°C
Model
Duct Connection
Flanges
Refrigerant
Pipe Connection
Sizes**
Connection Type
Max. Pipe Length
Max. Height Difference
Precharged Length
Drain Connection Size
Outdoor Operating Range
Cooling
Heating
Cooling
Heating
M
M
M
OD Ø mm
Cooling
Heating
1260x970x365
46
103
46
97
721x281
951x342
R22
9.53
19.05
Flare
25
15
10
25
R22
9.53
19.05
Flare
25
15
10
25
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
401x1301x510
1465x970x365
53
131
721x295
1071x342
R22
9.53
19.05
Flare
25
15
10
25
*The ‘Auto Restart’ feature is only available with the ‘RF Remote Control’ system kit. **Depending on length they can change
BONAIRE Evaporative air conditioning
Model
Height (mm)
VSS50
VSS55
VSM60
VSM65
VSL70
VSL75
Front
683
683
790
790
1047
1047
Back
573
573
681
681
937
937
Notes:
1. Rated Cooling Capacities are based on an indoor temp 27°C DB / 19°C WB and an outdoor
temp 35°C DB and 24°C WB in accordance with AS/NZS3823.1.2, at the rated airflows
listed above.
2. Rated Heating Capacities are based on an indoor temp 21°C DB and an outdoor temp 7°C
DB/6°C WB in accordance with AS/NZS3823.1.2, at the rated airflows listed above.
3. All capacities are net and include 7.5m of interconnecting pipe, with zero level difference.
Width (mm)
1184
1184
1192
1192
1192
1192
Weight (kg)
61
61
65
65
80
80
Duct work (mm)
550 x 550
550 x 550
550 x 550
550 x 550
800 x 550
800 x 550
Bonaire Ducted Gas Heaters
Water Conservation System®
Standard
Standard
Standard
Standard
Standard
Standard
B5-35**
B5-30 Extra
B5-30
B5-21 Extra
B5-21
B4-30 Extra
B4-30
B4-20 Extra
B4-20
B3-30 Extra
B3-30
B3-20
Unit sizing.
All evaporative air conditioners vary in performance according
to the architectural features of a home and different climatic
conditions in Australia. Bonaire recommends using the Bonres®
Unit Selection Guide as the only reliable method of determining
the cooling capacity of a Bonaire unit in your home.
4. Outdoor sound pressure measurement is taken inside and anechoic chamber at a distance of 1M
directly in front. Sound levels may vary due to different installation locations and environments.
5.Running Current is at rated conditions in accordance with AS/NZS3823.1.2. This does not include
start-up or variations in power supply and load conditions.
BONAIRE DUAL CYCLE SYSTEM MATCHING CHART
B009RS/DC
B012RS/DC
Air**
B015RS/DC
B019RT/DC
✓
✓
✓
✓
✓
✓
✓
✓
✓
Air
✓
Air**
✓
✓
Air
✓
Air**
✓
✓
**Dual Heater Return Air duct connections are recommended when selecting a B019RT/DC systems.
18
19
Your nearest Bonaire stockist is:-
For further information please phone:
VIC/ACT/NSW/QLD (03) 8795 2424
WA (08) 9454 1010
SA (08) 8307 5300
www.bonaire.com.au
www.bonaire.com.au
A CLIMATE TECHNOLOGIES BRAND. ABN 13 001 418 042. 26 Nylex Avenue, Salisbury 5108.
In the interest of continued product improvement, Bonaire reserves the right to alter specifications without notice E & OE. Colours represented are as accurate as the printing process will allow.
For further information on warranty terms and conditions please refer to Bonaire’s warranty information booklet. Domestic warranty only. Unit warranty for commercial applications varies depending on model.
BON615 August 2009
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
