1 Introduction & General Requirements

1.1 Installation Requirements

Thank you for purchasing a Grant unvented hot water storage cylinder from our Wave range. This installation manual must be read carefully before you begin installing the cylinder.

This cylinder must be installed by a competent person in compliance with all current legislation, codes of practice and local by-laws covering the installation of an unvented hot water cylinder. Please also make sure that any installation complies with the instructions contained in this installation instruction manual.

1.2 Water Supply Requirements

We recommend that your Grant

Unvented cylinder is installed with an uninterrupted water supply.

Where possible the unit should be fed via a Ø22mm supply pipe. It requires a supply pressure of 1.5bar with a flow rate of at least 20 litres per minute as a minimum for it to function. Even with these rates, flow from the outlets will be disappointing if several outlets are used simultaneously. Generally speaking, the higher the supply pressure, the better the incoming system will function. The cylinder control equipment is factory set to limit the incoming system operating pressure to 3bar. The maximum supply pressure into the pressure- reducing valve (PRV) is 12bar.

1.3 Location

The unit is designed to be floor standing, vertically mounted, indoors, in a frost-free environment. When choosing a suitable location for the cylinder, consideration should be given to the routing of the discharge pipe to a convenient point and also the availability of an adequate power supply for connecting the immersion heater(s).

The cylinder may stand on any flat and level surface without any special foundation preparations, provided that it is sufficiently robust to support the full weight of the cylinder. (Refer to

Technical specifications for weights).

The position of the cylinder should be such that easy access is provided for servicing the controls and replacing the immersion heater should the need arise.

Generally, pipe runs should be made as short as possible and lagged to prevent heat loss.

1.4 Storage and Handling

If the cylinder is not being installed immediately, it should remain in its carton to prevent damage. We recommend that the cylinder be transported to its installation position on a sack truck or similar whilst still within the carton.

1.5 About Your New Cylinder

DuoWave Solar and DuoWave HP indirect cylinders have two coils for connection to Primary heat sources.

For Solar Thermal to be connected, the bottom coil must be used. Please refer to the manufacturers installation instructions for more information.

The central heating or heat pump (HP version) connections should be made to the top coil.

DuoWave Solar and DuoWave HP indirect cylinders are also supplied fitted with a single 3kW electric immersion heater.

DuoWave Solar direct cylinders have a single coil only for connection of solar thermal, but are also supplied fitted with two 3kW electric immersion heaters.

Refer to page 15 for further details on immersion heaters.

In all cases, each coil must be connected using a 2-port motorised valve to shut off the flow from the primary source and electrically interlocked with the heat source via the cylinder control and limit thermostat (for solar installations a high temperature

2-port or solenoid valve must be used).

Contact Grant UK for details.

Failure to do so will invalidate all warranties and will be in breach of

The Building Regulations Approved

Document G3 (2010).

More information on electrical wiring is given on pages 15-20.

1.6 Open Vented Hot Water

Systems

If required, your Grant DuoWave

Cylinder can be used as part of an

Open Vented hot water system, i.e. fed from a cold water storage cistern and fitted with an Open Vent pipe, provided the maximum head does not exceed

30m.

When used in this way, it will not be necessary to install the expansion vessel and cold inlet manifold supplied with the cylinder.

Note:

The Temperature and Pressure relief

(T&P) valve should be left connected to the cylinder (as supplied). As it may still operate due to temperature it should be connected in the correct manner – refer to guidance given in Section 4 of these

Instructions.

1.7 Taps and Fittings

All taps and fittings incorporated in the unvented system should have a rated operating pressure of 7 bar or above.

1.8 Pipework Connections

All Pipework connections to the cylinder

must be made in accordance with

Figures 2-4 to 2-6 as appropriate.

1.9 Scaling

In hard water areas scaling will form inside the cylinder and this will reduce both the performance and working life of the cylinder. Where the total hardness exceeds 125ppm a high capacity water softener, or suitable water conditioner, should be installed in the incoming cold water supply to the cylinder.

It is recommended that the water temperature control thermostats (on the immersion heaters and dual thermostats) fitted to the cylinder be set no higher than 60°C to minimise scale build up.

1.10 Insulation

All Grant Cylinders are insulated with

40mm thick CFC/HFC free, fire retardant, polyurethane foam injected between the stainless steel cylinder and the outer casing. This polyurethane foam has a Global Warming Potential

(GWP) of less than 3 and an Ozone

Depletion Potential (ODP) of 0.

1.11 Health and Safety

The information supplied in the table in

Section 2 Technical Specification will help you assess the safest way to manoeuvre your cylinder into position.

Please use the table to find the empty weight of your cylinder and then consider how you can safely move it into its final position.

Please leave this manual with the householder after installation.

3

2 Technical Specifications

4

2.1 Technical Data - DuoWave Direct & Indirect Solar Cylinders

Cylinder model

Weight empty (kg) - direct models

Weight full (kg) - direct models

Weight empty (kg) - indirect models

Weight full (kg) - indirect models

Secondary return connection (mm)

Cold feed/hot draw-off connections (mm)

DuoWave Direct & Indirect Cylinders

170 200 250 300 400 500*

170 200 250 300 400 500

580 580 580 580 580 660

1075 1230 1480 1745 2110 1835

37

207

41

241

47

297

53

353

65

465

N/A

N/A

49

219

22

22

53

253

22

22

63

313

22

22

72

372

22

22

92

492

22

22

22 22 22 22 22

5.70

5.70

5.70

5.70

6.81

0.52

5.70

0.52

6.81

0.52

8.01 / 6.95*

0.52

8.01

0.73

11.68

108

608

22

22

22

8.01

1.14

13.90

Top coil length (m) - indirect models only

Top coil surface area (m 2 ) - indirect models only

Bottom (solar) coil length (m)

Bottom (solar) coil surface area (m 2 )

Top/bottom coil pipe diameter (mm)

Dedicated solar volume Vs (litres) - direct models

Dedicated solar volume Vs (litres) - indirect models

Maximum water supply pressure (bar)

System operating pressure - pre-set (bar)

Expansion vessel charge pressure (bar)

Expansion relief valve pressure (bar)

Temp & pressure relief valve lift pressure (bar)

Temp & pressure relief valve lift temperature (°C)

Maximum primary circuit working pressure (bar)

Performance:

Top coil rating (kW)

Top coil recovery rate (mins)**

Bottom (solar) coil rating (kW)

24hr standing loss (kW) - direct and indirect models***

Check list:

22

85

85

12

3

3

6

7

90

3

8.50

18

8.5

2.04

22

100

100

12

3

3

6

7

90

3

8.50

20

10.0

2.45

22

125

125

12

3

3

6

7

90

3

8.50

25

16.0 / 13.9*

2.69

22

150

150

12

3

3

6

7

90

3

8.50

26

16.0

2.71

22

200

200

12

3

3

6

7

90

3

10.00

25

24.0

2.94

16.00

27

27.0

3.15

Cylinder assembly 170 litre

Cylinder assembly 200 litre

Cylinder assembly 250 litre

Cylinder assembly 300 litre

Cylinder assembly 400 litre

Cylinder assembly 500 litre

Expansion vessel 19 litre

Expansion vessel 24 lite

Expansion vessel 35 Litre

Expansion vessel 50 Litre

Expansion vessel hose (

3

/

4

" BSPF x

3

/

4

" BSPM) c/w washer

Expansion vessel wall bracket and band

1

-

-

-

-

-

1

-

-

-

1

1

-

1

-

-

-

-

1

-

-

-

1

1

-

-

1

-

-

-

-

1

-

-

1

1

-

-

-

1

-

-

-

1

-

-

1

1

-

-

-

-

1

-

-

-

1

-

1

1

Adaptor (1" BSPF x

3

/

4

" BSPM)

Temp & pressure relief valve (7 bar 90ºC) factory-fitted

-

1

-

1

-

1

-

1

1

1

Drain cock ( 1 /

2 feed)

Dual thermostat (Control 25-65ºC High limit 90ºC) - direct

1 1 1 1

1 1 1 1 1

Inlet manifold (3 bar pressure reducing valve & 6 bar exp. relief valve) 1 1 1 1 1 1

1 1 1 1 1 1

1

2

1 1

-

Dual thermostat (Control 25-65ºC High limit 90ºC) - indirect

Immersion heater 3 kW (1

3

/

4

"

Immersion heater 3 kW (1 3 /

4

"

1

2

1

2

1

2

1

2

1

2

* DuoWave Indirect only. ** Recovery rate is based on 82˚C flow @ 0.2l/s over a 50˚C temp rise for 75% of contents.

***

Test carried out at 60˚C.

-

1

-

1

-

-

-

-

-

-

-

1

-

-

3

3

6

7

22

250

250

12

90

3

2.2 Technical Data - DuoWave HP Indirect Cylinders

Cylinder model

Weight empty (kg)

Weight full (kg)

Cold feed/hot draw-off connections (mm)

Top coil length (m)

Top coil surface area (m 2 )

Bottom (solar) coil length (m)

Bottom (solar) coil surface area (m 2 )

Top/bottom coil pipe diameter (mm)

Dedicated solar volume Vs (litres)

Maximum water supply pressure (bar)

System operating pressure - pre-set (bar)

Expansion vessel charge pressure (bar)

Expansion relief valve pressure (bar)

Temp & pressure relief valve lift pressure (bar)

Temp & pressure relief valve lift temperature (°C)

Maximum primary circuit working pressure (bar)

Performance:

Top coil rating (kW)

Bottom (solar) coil rating (kW)

Check list:

Cylinder assembly 170 litre

Cylinder assembly 200 litre

Cylinder assembly 250 litre

Cylinder assembly 300 litre

Cylinder assembly 400 litre

Expansion vessel 19 litre

Expansion vessel 24 lite

Expansion vessel 35 Litre

Expansion vessel hose ( 3 /

4

" BSPF x 3 /

4

" BSPM) c/w washer

Expansion vessel bracket and band

Adaptor (1" BSPF x 3 /

4

" BSPM)

Temp & pressure relief valve (7 bar 90ºC) factory-fitted

Drain cock ( 1 /

2 feed)

Inlet manifold (3 bar pressure reducing valve & 6 bar exp. relief valve

Dual thermostat (Control 25-65ºC High limit 90ºC)

Immersion heater 3 kW (1 3 /

4 factory-fitted

* Test carried out at 60˚C.

12

3

3

6

7

90

3

170

DuoWave HP Cylinders

200 250 300

170 200 250 300

400

400

580 580 580 580 580

1075 1230 1480 1745 2110

57

227

61

261

71

321

80

380

100

500

22 22 22 22 22

22 22 22 22 22

22 22 22 22 22

16.02

23.36

23.36

27.80

27.80

2.5 3.5 3.5 4.0 4.0

5.70

6.81

8.01

8.01

11.68

0.52 0.73 1.14 1.14 1.56

22

85

22

100

22

125

22

150

22

200

12

3

3

6

7

90

3

12

3

3

6

7

90

3

12

3

3

6

7

90

3

7

90

3

12

3

3

6

32.0

8.5

47.0

10.0

47.0

16.0

55.6

16.0

55.6

23.0

2.04 2.45 2.69 2.71 2.94

-

1

-

-

1

-

-

-

1

1

-

1

-

-

-

1

-

-

1

1

-

-

1

-

-

-

1

-

1

1

-

-

-

1

-

-

1

-

1

1

-

1

-

1

-

1

-

1

1 1 1 1 1

1 1 1 1 1

1

1

1

-

-

1

1

1

-

-

-

-

1 1 1 1 1

1 1 1 1 1

2 2 2 2 2

1 1 1 1 1

5

2 Technical Specifications

2.3 Dimensions - DuoWave Direct & Indirect Solar Cylinders

40˚ 30˚ 0˚ 30˚

22mm Hot water draw off

1

/

2

" T & P Relief valve (factory fitted)

22mm Boiler flow

22mm Secondary return

Boiler stat pocket

22mm Boiler return

22mm Solar flow

(500 model only)

Immersion heater

(factory fitted)

22mm Solar return

Solar stat pocket

22mm Solar flow

(not on 500 model)

22mm Cold water inlet

L K J I H G F E D C B A

6

Figure 2-1: DuoWave indirect solar cylinder dimensions

DuoWave Indirect Solar Cylinder Dimensions

Dims

(mm)

J

K

I

H

L

Dia

E

F

G

A

B

C

D

170

735

795

800

1025

1075

580

200

275

330

380

460

540

655

200

870

940

955

1170

1230

580

200

275

330

380

460

660

790

250

Model

300

1020

1085

1210

1430

1480

580

200

275

330

380

460

795

935

200

320

375

420

510

860

1005

1095

1155

1460

1695

1745

580

400

200

320

400

420

510

1100

1240

1340

1500

1970

2050

2110

580

500

235

N/A

600

620

715

820

1120

1260

1390

1590

1640

1835

660

Dia

40˚ 30˚ 0˚ 30˚

22mm Hot water draw off

1 /

2

" T & P Relief valve (factory fitted)

22mm Secondary return

Immersion heater

(factory fitted)

22mm Solar return

Solar stat pocket

22mm Solar flow

Immersion heater

(factory fitted)

22mm Cold water inlet

J I H G F E D C B A

Figure 2-2: DuoWave direct solar cylinder dimensions

DuoWave Direct Solar Cylinder Dimensions

Dims

(mm)

D

E

F

G

H

A

B

C

I

J

Dia

170

210

210

230

340

475

510

735

795

1025

1075

580

200

210

210

230

415

605

635

880

955

1170

1230

580

Model

250

210

210

230

460

720

745

1025

1210

1430

1480

580

300

210

210

230

505

840

860

1250

1475

1695

1745

580

400

210

210

240

610

1005

1040

1430

1980

2050

2110

580

Dia

7

2 Technical Specifications

2.4 Dimensions - DuoWave HP Indirect Cylinders

40˚ 30˚ 0˚ 30˚

22mm Hot water draw off

1 /

2

" T & P Relief valve (factory fitted)

22mm Heat pump flow

22mm Heat pump return

22mm

Secondary return

Heat pump stat pocket

Immersion heater

(factory fitted)

22mm Solar return

Solar stat pocket

22mm Solar flow

22mm Cold water inlet

J I H G F E D C B A

8

Figure 2-3: DuoWave HP indirect cylinder dimensions

DuoWave HP Indirect Cylinder Dimensions

Dims

(mm)

D

E

F

G

H

A

B

C

I

J

Dia

170

210

275

310

360

460

690

721

735

1025

1075

580

200

210

275

315

375

460

565

765

945

1170

1230

580

Model

250

210

275

375

460

700

705

1020

1145

1430

1480

580

300

210

280

380

460

855

1005

1290

1435

1695

1745

580

400

210

280

380

500

1100

1250

1550

1850

2045

2110

580

Dia

2.5 Connections and Controls

13

14

15

1

16

2

4

17

19 18

7

12

13

15

14

1

16

17

19 18

2

4

3

6

5

11

8

7

8

9

10

11

20

Figure 2-4: DuoWave direct solar cylinders

6

7

4

5

2

3

Item Description

1 DHW Out

T & P valve connection

Boiler return tapping

Secondary return tapping

Boiler dual thermostat pocket

Boiler flow tapping

Auxiliary (Solar) heat source return tapping

8 Auxiliary (Solar) heat source dual stat pocket (for dual stat only)

Cold water inlet 9

10 Auxiliary (Solar) heat source flow tapping

11 Immersion heater c/w control

& limit thermostat (factory fitted)

Connection Size

22mm compression

1 /

2

" BSPF

22mm compression

22mm compression

-

22mm compression

22mm compression

-

22mm compression

22mm compression

1

3

/

4

" BSPF

20

9

10

Figure 2-5: DuoWave indirect solar cylinders

Item Description

12 Immersion heater c/w control & limit thermostat (factory fitted)

Connection Size

1

3

/

4

" BSPF

13 Pressure reducing valve - 3 bar -

14 Balanced cold supply connection 22mm compression

15mm compression 15 Expansion relief valve - 6 bar

16 Temperature & Pressure relief valve - 90°C/7 bar

17 Tundish

15mm compression

15/22mm compression

18 Discharge pipe

(not supplied with cylinder)

19 Mains water supply pipe

(not supplied with cylinder)

20 Drain cock

(supplied with cylinder)

-

-

-

Note:

Pipework between items 15 and 16 not supplied with cylinder.

9

2 Technical Specifications

13

15

14

1

16

17

2

4

3 6

5

19

18

11

10

7

8

10

20

9

Figure 2-6: DuoWave HP indirect cylinders

6

7

4

5

2

3

Item Description

1 DHW Out

T & P valve connection

Heat pump return tapping

Secondary return tapping

Dual thermostat pocket

Heat pump flow tapping

Auxiliary (Solar) heat source return tapping

8 Auxiliary (Solar) heat source dual stat pocket (for dual stat only)

Cold water inlet 9

10 Auxiliary (Solar) heat source flow tapping

11 Immersion heater c/w control

& limit thermostat (factory fitted)

Connection Size

22mm compression

1 /

2

" BSPF

22mm compression

22mm compression

-

22mm compression

22mm compression

-

22mm compression

22mm compression

1

3

/

4

" BSPF

Item Description Connection Size

13 Pressure reducing valve - 3 bar -

14 Balanced cold supply connection 22mm compression

15 Expansion relief valve - 6 bar 15mm compression

16 Temperature & Pressure relief valve - 90°C/7 bar

17 Tundish

18 Discharge pipe

(not supplied with cylinder)

19 Mains water supply pipe

(not supplied with cylinder)

20 Drain cock

(supplied with cylinder)

15mm compression

15/22mm compression

-

-

-

Note:

Pipework between items 15 and 16 not supplied with cylinder.

3 Primary Circuit Installation

3.1 Grant DuoWave Solar

Cylinders

Grant DuoWave indirect solar cylinders are suitable for connection to most fully pumped domestic gas or oil fired central heating boilers working on an open vented or sealed system having a maximum working pressure of 3 bar and a maximum working temperature of

90ºC. If you are in any doubt over the

Suitability of a boiler for use with the cylinder, consult the boiler manufacturer.

3.2 Grant DuoWave HP

Cylinders

Grant DuoWave HP indirect cylinders are specifically designed for connection to most fully pumped Air Source Heat

Pump systems (such as the Grant

Aerona Heat Pump range)- either open vented or sealed systems having a maximum working pressure of 3 bar and a maximum working temperature of

90ºC. If you are in any doubt over the

suitability of an Air Source Heat

Pump (other than a Grant Aerona heat pump) for use with the cylinder, consult the heat pump manufacturer.

IMPORTANT

Solid fuel or wood burning boilers and gravity circulation systems must not be used on the primary circuit of an unvented hot water system.

3.3 Systems (DuoWave

Indirect solar cylinders only)

If an existing system is a “flow share” arrangement such as an “S” or “Y” plan type system, (see Figures 5-4, 5-5 and

5-6) they will provide satisfactory results, but during central heating demands, hot water production will not be as responsive. If this is important, consider the use of a “W” plan type system. (See Figures 5-2 and 5-3).

3.4 Primary Connections

(DuoWave Indirect solar and

Duowave HP cylinders only)

1. The primary flow and return connections from the boiler or heat pump (for HP cylinders) should be made to the upper coil connections of the cylinder.

The motorised valve (supplied) must be fitted into the primary flow. The primary flow and return fittings are

22mm compression. The valve has

22mm compression connections.

2. Locate the dual thermostat in the stainless steel pocket (refer to either

Figure 2-1 or 2-3, as appropriate, for location) and secure using the retaining screws on the thermostat housing.

3. Any automatic or manual air vent fitted to vent air from the upper coil should be installed on the primary flow pipe to the coil.

3.5 The 2-Port Valve

(DuoWave Indirect solar and

Duowave HP cylinders only)

To prevent gravity circulation when the boiler or heat pump switches off, the

2-port motorised valve supplied with the unvented hot water kit, must be fitted in the primary flow pipe to the cylinder and wired in accordance with

Figures 5-3, 5-5 or 5-7 for boilers

(depending on system design) and

Figure 5-9 for a Grant Aerona heat pump to comply with current legislation.

For other makes of heat pump please check with the heat pump manufacturer for connection details.

3.6 Auxiliary Primary

Connections

Solar Heating

1. The Solar flow and return connections should be made to the lower coil connections. If the lower coil is not thermostatically controlled a 2-port or solenoid valve (high temperature rated - not supplied) must be fitted in the flow and be controlled from the dual thermostat mounted at low level on the cylinder, via the thermostat pocket (8).

Contact Grant UK for details.

2. If you are connecting another primary heat source please refer to the installation manual of that appliance. Do not connect an uncontrollable appliance to this cylinder (e.g wood burning stove, multi fuel stove, etc.).

3.7 Hard Water Areas

If the cylinder is to be used in a hard water area, we recommend that the primary flow temperature be limited to

75˚C. This will help reduce the migration of suspended solids in the water and help prevent the build up of lime scale.

11

12

4 Secondary Circuit Installation

4.1 Cold Water Inlet Manifold

This manifold contains a pressure reducing valve (with integral strainer), double check valve, expansion valve with a stainless steel seat. The pressure reducing valve is factory set. The set pressure is shown on top of the valve.

Maximum inlet pressure to valve is 12 bar.

4.2 Installation

1. Cold water supply to be 22mm nominal size.

2. Flush supply pipework before

connection to remove all flux and debris prior to fitting the inlet controls. Failure to do this may result in irreparable damage to the controls and will invalidate the warranty. Once the pipework is flushed connect the cold supply to the Inlet manifold.

3. The manifold can be installed in any position as long as it is installed in the correct flow direction. Refer to the arrows on the side of the body.

Make sure that the head of the expansion relief valve is offset from the cylinder for ease of access.

4. The expansion relief valve should be either horizontal or upright - if fitted inverted, debris may be deposited on the seat and cause fouling of the seat when the valve operates.

Check direction of flow arrows.

5. The black plastic plug in the body is a pressure gauge connection to enable pressure monitoring to be carried out, should the system develop a fault. It is recommended that this be accessible.

6. Expansion relief drain pipework must be connected to a safe visible discharge point via a tundish and the pipework must have a continuous fall. Connect the

Expansion Relief valve outlet into the discharge pipe from the

Temperature and Pressure Relief valve using a 15mm copper pipe and tee piece (not supplied). Fit the

Tundish below this tee piece using a short length of copper pipe. Refer to Sections 4.7, 4.8 and 4.9 for further information on Tundish and

Discharge pipe.

7. The pressure reducing valve has two outlets, the second one is for a balanced cold water supply, to a shower or a bidet (over rim type

only, ascending spray type requires type AA, AB or AD air gap). Major shower manufacturers advise fitting a mini expansion vessel in the balanced cold supply to accommodate thermal expansion and prevent tightening of shower controls. If the dwelling has a shower mixing valve (manual or thermostatic) or a Bidet (over rim type) use the cold water supply from the

Balanced Cold water connection on the Inlet Manifold for these outlets. Do not use the balanced cold connection to supply bath taps as this can reduce the flow of water available to the cylinder.

If the balanced cold water outlet is not required, blank off the port.

The Benchmark book enclosed with the cylinder should be completed after commissioning of the system.

The cylinder must be registered with Grant UK within 30 days of installation. Refer to Section 11 for further details on the Cylinder

Warranty.

4.3 Expansion Vessel

A suitable expansion vessel with a precharge pressure of 3bar is supplied for fitting to all cylinders.

The supplied expansion vessel must be connected into the cold water supply between the expansion relief valve (in the inlet manifold) and the cylinder using the flexible hose provided.

Flexible hose not supplied with 50 litre expansion vessel. This vessel to be connected using rigid pipe. The expansion vessel must be positioned with the entry point at the bottom. No valve should be fitted between the expansion vessel and cylinder.

The air charge pressure in the expansion vessel must be regularly checked (e.g. at every service) and topped up as necessary. The correct air charge pressure is 3.0bar.

Refer to Sections 7.1 and 7.5 for further details.

4.4 Temperature and Pressure

Relief Valve

The temperature and pressure relief valve (T&P Valve) is supplied factory fitted to the cylinder. The T&P valve must not be removed from the cylinder or tampered with in any way. The valve is pre-set to lift at 7bar or 90°C and any attempt to adjust it will invalidate the warranty.

4.5 Hot Water Supply

1. Connect the hot water supply pipe to the top outlet (1) of the cylinder.

4.6 Prevention of Scalding

Building Regulations Approved

Document G (Part G3) requires that the hot water temperature supplied to a bath should be limited to a maximum of

48°C by using an in-line blending valve

(not supplied with the cylinder) with a maximum temperature stop. The length of the supply pipe between the blending valve and the bath hot water outlet should be kept to a minimum to prevent the colonisation of waterborne pathogens (e.g. legionella). Refer to

Approved Document G for further details.

4.7 Secondary Return

All DuoWave solar and HP cylinders are fitted with a secondary return connection. If a secondary return circuit is required it should be connected to the DuoWave solar or HP cylinder as shown below:

Cold inlet

Secondary return line

Balanced cold supply for showers or bidet only (see Section 4.2)

Circulation pump

Non return valve

Balanced cold supply outlet

Figure 4-1: Secondary Return Circuit

Note:

If a secondary circulation circuit is installed then a larger expansion vessel may be required to handle the increase in volume

.

4.8 Tundish

The tundish must not be positioned above or in close proximity of any electrical current carrying devices or wiring.

4.9 Discharge Pipe

1. The discharge pipe from the

Tundish should terminate in a safe place where there is no risk to persons in the vicinity of the discharge, be of metal and: a) Be at least one pipe size larger than the normal outlet size of the safety device unless its total equipment hydraulic resistance exceeds that of a straight pipe 9m long, i.e.

discharge pipes between 9m and

18m equivalent resistance length should be at least larger than the normal outlet size of the safety device, between 18m and 27m at least three sizes larger and so on.

Bends must be taken in to account in calculating the flow resistance.

See Sections 4.10, 4.11 and 4.12.

b) Have a vertical section of pipe at least 300 mm long, below the tundish before any elbows or bends in the pipe work.

c) Be installed with a continuous fall of

1:40 (2.5°).

d) Have discharges visible at both the tundish and the final point of discharge but where this is not possible or practically difficult there should be clear visibility at one or other of these locations.

2. Examples of acceptance discharge arrangements are: a. ideally below a fixed grating and above the water seal in a trapped gully.

b. downward discharges at a low level; i.e. up to 100mm above external surfaces such as car parks, hard standings, grassed areas etc.

are acceptable providing that where children may play or otherwise come in to contact with discharges, a wire cage or similar guard is positioned to prevent contact, whilst maintaining visibility.

c. discharges at high level; e.g. in to metal hopper and metal down pipe with the end of the discharge pipe clearly visible (tundish visible or not) or onto a roof capable of withstanding high temperature discharges of water and 3m from any plastics guttering systems that would collect such discharges

(tundish visible).

3. Where a single pipe serves a number of discharges, such as in blocks of flats, the number served should be limited to not more than

6 systems so that any installation can be traced reasonably easily.

The single common discharge pipe should be at least one pipe size larger than the largest individual discharge pipe to be connected.

If unvented hot water storage systems are installed where discharges from safety devices may not be apparent i.e. in dwellings occupied by blind, infirm or disabled people, consideration should be given to the installation of an electronically operated device to warm when discharge takes place.

Note:

The discharge will consist of scalding water and steam. Asphalt, roofing felt and non-metallic rainwater goods may be damaged by such discharges.

13

14

4 Secondary Circuit Installation

4.10 Discharge Pipe Arrangement

Safety device ( e.g.

temperature relief valve)

Metal discharge pipe from temperature

600mm max

Tundish

Metal discharge pipe from tundish with continuous fall. See table and worked example on next page

Trapped gully

Figure 4-2: Typical discharge pipe arrangement discharged below fixed grating

Fixed grating

4.12 Worked Example

The example below is for a 1 /

2

”diameter temperature relief valve with a discharge pipe (D2) having 4 elbows and a length of 7 m from the tundish to the point of discharge.

From

Maximum resistance allowed for a straight length of Ø22mm copper discharge pipe (D2) from a 1 /

2

” diameter temperature relief valve is - 9.0m.

Subtract the resistance for quantity of 4

Ø22mm elbows at 0.8m each = 3.2m.

Therefore, the maximum permitted length equates to 5.8m.

5.8m is less than the actual length of

7m; therefore calculate the next largest size.

Maximum resistance allowed for a straight length of Ø28mm-pipe (D2) from a 1 /

2

” diameter temperature relief valve equates to - 18m.

Subtract the resistance for a quantity of

4 Ø28mm elbows at 1.0 each = 4m.

Therefore the maximum permitted length equates to 14m.

As the actual length is 7m, a Ø28mm diameter copper pipe will be satisfactory.

4.11 Discharge Pipe Sizing

Valve outlet size, diameter (inches)

1

/

2

3 /

4

1

Minimum size of

Max resistance allowed, expressed as a length Resistance created

Minimum size of discharge pipe D2 from of straight pipe, i.e. no by each elbow or discharge pipe D1 (mm) tundish in (mm) elbows or bends bend in (m)

15

22

28

35

Up to 9

Up to 18

Up to 27

0.8

1.0

1.4

22

28

28

35

42

35

42

54

Up to 9

Up to 18

Up to 27

Up to 9

Up to 18

Up to 27

1.0

1.4

1.7

1.4

1.7

2.3

5 Electrical Installation

!

WARNING

This appliance must be earthed.

All electrical wiring must be carried out by a competent person and in accordance with the current I.E.E.

Wiring Regulations.

The control equipment supplied will ensure that the cylinder functions safely.

From an economic and convenience point of view, it is intended that these controls operate in conjunction with other control packages for example “S”,

“W” or “Y” plan type systems, which incorporate a programmable time clock, etc.

5.1 Immersion Heater

All cylinders are supplied fitted with either one or two immersion heaters, dependent on the model and capacity.

Each 3kW 230V 50Hz-immersion heater should be wired in accordance with the instructions given in Figure 5-1.

The cable must be routed through the strain relief bush. The control thermostat is pre-set at approximately

60°C. The immersion heater conforms to EEC Directive 76/889 for radio interference and complies with EN

60335-2-73.

Installation and wiring instructions for the immersion heater are supplied with each unit. Follow the wiring instructions connecting the live, neutral and earth as indicated.

Temperature control dial

= Earth (Green/Yellow)

= Live (Brown)

= Neutral (Blue)

Figure 5-1: Immersion heater wiring connections

Reset

The unit must be permanently connected to the electrical supply through a double-pole isolator. A safety cut-out is also incorporated within the thermostat and is factory set to operate at 80°C ± 5°C.

IMPORTANT

Before resetting the safety cut-out or altering the thermostat setting, isolate electrical supply to the unit prior to removal of the cover. Investigate and identify the cause of the cut-out operation and rectify the fault before manually resetting the cut-out by pressing in the reset button. Ensure the cover to the immersion element is replaced correctly and the retaining nut is fitted. Finally switch the mains electricity supply back on.

!

WARNING

The manual re-set high limit thermostat must not under any circumstances be bypassed. This is pre-set to 80°C and to prevent nuisance tripping the control thermostat should always be left in position 4.

5.2 Immersion Heater Wiring

Instructions

a) Ensure the main’s voltage corresponds to the voltage rating of the immersion heater as shown on the rating label on the terminal cover.

b) The immersion heater is factory fitted to the cyinder. If the immersion heater needs to be replaced it must be fitted to the cylinder using the gasket provided on the unit. Use a shaped spanner,

Stillsons or pipe grips should not be used. The use of sealing compound is not recommended.

c) Wire the immersion heater in accordance with the wiring diagram

(Figure 5-1). It should be wired through a double pole isolator switch or controller, with a minimum break capacity of 13 amp having contact separation of at least 3 mm, using 1.5mm sq. flexible cable,

85°C rubber insulated HOFR sheathed, to comply with BS 6141 table 8 and must be fully earthed.

d) The BEAB approval certification on this immersion heater only applies if a Cotherm TSE rod type thermostats is used. The temperature setting of the control thermostat should always be left in position 4.

5.3 Dual Thermostat (Indirect

Temperature Control)

For the Indirect models two Dual

Thermostats (each a combined control and high limit thermostat) are supplied separately with the unvented hot water safety kit. One is fitted into the upper sensor pocket in the cylinder (see

Figures 2-4 to 2-6 for position) to control the operation of the boiler or heat pump primary coil. The second is fitted in the lower sensor pocket to control the operation of the Solar coil.

For Direct models only one Dual

Thermostat is supplied to be fitted in the lower sensor pocket.

The control thermostat has an adjustment range between 25°C and

65°C, however it is recommended that it is set to 60°C. The overheat thermostat incorporated within the dual thermostat will operate at 90°C.

5.4 2-Port Valve (Indirect only)

To comply with regulations governing the installation of indirect unvented cylinders, a 2-port motorised valve must be fitted in the primary flow to prevent gravity circulation when the boiler switches off. Your Grant

DuoWave unit has been supplied with a

2-port motorised valve, which will act as a positive energy cut-out should the safety cutout operate. Should this happen the motorised valve will operate and close down the primary flow to the cylinder. The valve should be wired in accordance with Figures 5-3, 5-5,

5-7, 5-9 or 5-11 depending on system design, to comply with current legislation.

For an air source heat pump (other than a Grant Aerona heat pump) consult the heat pump manufacturer for connection details.

This motorised valve will also control the temperature of the domestic stored water via the cylinder thermostat, which is located in the upper dual thermostat.

The unit should be installed on a “W”,

“S” or “Y” plan system as shown in

Figures 5-2, 5-4 and 5-6.

15

5 Electrical Installation

5.5 ‘W’ Plan System Schematic and Wiring Diagram - DuoWave Indirect Solar Cylinder and Boiler

Grant DuoWave Indirect water cylinder

Radiator

3 port diverter valve

(not supplied)

2 port zone valve

(supplied)

Pump

Boiler

Figure 5-2: ‘W’ Plan system schematic

16

230V

50Hz

L N E

Blue

Green/Yellow

Brown

3 port divert valve (not supplied)

Room

Thermostat

2 1 3

Junction box

1 2 3 4 5 6

1

High limit

C

2 1 2

Contr ol

C

Cylinder Dual

Thermostat

(Top Coil)

7 8 9 10

Blue

Brown

2 port zone valve

(supplied)

Note:

Orange and grey wires not required electrically isolate

Time controller

Figure 5-3: ‘W’ Plan wiring diagram

N E

Boiler

L

N E L

Pump

5.6 ‘Y’ Plan System Schematic and Wiring Diagram - DuoWave Indirect Solar Cylinder and Boiler

Grant DuoWave Indirect water cylinder

Radiator

3 port mid-position valve (not supplied)

2 port zone valve

(supplied)

Pump

Boiler

Figure 5-4: ‘Y’ Plan system schematic

230V

50Hz

L N E

Blue

Green/Yellow

White

Grey

Orange

Mid position zone valve

Room

Thermostat

2 1 3

Junction box

1 2 3 4 5 6 7 8 9 10

1

High limit

C

2 1 2

Con trol

C

Cylinder Dual

Thermostat (Top Coil)

Blue

Brown

Green/Yellow

2 port zone valve

(supplied)

Note:

Orange and grey wires not required electrically isolate

Time controller

Figure 5-5: ‘Y’ Plan wiring layout

N E

Boiler

L

N E L

Pump

17

5 Electrical Installation

5.7 ‘S’ Plan System Schematic and Wiring Diagram - DuoWave Indirect Solar Cylinder and Boiler

Grant DuoWave Indirect water cylinder

Radiator

2 port zone valve

(supplied)

2 port diverter valve

(not supplied)

Pump

Boiler

Figure 5-6: ‘S’ Plan system schematic

230V

50Hz

L N E

Blue

Brown

Grey

Green/Yellow

Orange

Zone valve

HTG

Room

Thermostat

2 1 3

Blue

Brown

Green/Yellow

Grey

Orange

Zone valve

DHW

Junction box

1 2 3 4 5 6 7 8 9 10

N E L

Pump

Time controller

1

High limit

C

2 1 2

Con trol

C

Cylinder Dual

Thermostat (Top Coil)

18

Figure 5-7: ‘S’ Plan wiring layout

5.8 ‘S’ Plan System Schematic and Wiring Diagram - DuoWave HP Cylinder and Heat Pump

Grant DuoWave HP water cylinder

Radiator

2 port zone valve

(supplied)

2 port diverter valve

(not supplied)

Grant Aerona

Heat pump

(with integral circulating pump)

Figure 5-8: ‘S’ Plan system schematic - for Grant Aerona heat pump

230V

50Hz

L N E

Blue

Brown

Grey

Green/Yellow

Orange

Zone valve

HTG

Room

Thermostat

2 1 3

Blue

Brown

Grey

Green/Yellow

Orange

Zone valve

DHW

Junction box

1 2 3 4 5 6 7 8 9 10

1

High limit

C

2 1 2

Con trol

C

Cylinder Dual

Thermostat (Top Coil)

3

2

1

HW

CH

Grant Aerona Heat

Pump Controls

Connection

C

Time controller

Figure 5-9: ‘S’ Plan wiring layout 0 for Grant Aerona heat pump

19

5 Electrical Installation

5.9 Solar Thermal Schematic and Wiring Diagram

Solar

Collector

Grant GSD1

Controller

Electrical

Junction Box

Cylinder

Temperature

Sensor

Dual Thermostat

Figure 5-10: Solar thermal schematic

Grant GSD1 Mk2 Controller

2 port or solenoid valve (Not supplied)

7

8

5

6

3

4

1

2

9

10

N

230V

GND

Sensor

15

16

17

18

11

12

13

14

19

20

21

22

Collector sensor

Cylinder bottom sensor

L

N

E

230V 3A fused supply

20

Figure 5-11: Solar thermal system typical wiring layout

Solar Circulating

Pump

Solar Pump

Station

N E L

Solar pump

N E L

Solenoid valve

1

High Limit

C

2 1 2

C

C ontrol

Dual thermostat

(Solar coil)

6 Commissioning, Draining Down & Safety

6.1 Filling the Cylinder

IMPORTANT

Before filling the cylinder check that the immersion heater has not loosened in transit. Tighten as necessary using a shaped spanner. Stillsons or pipe grips should not be used.

1. Open all hot water taps.

2. Turn on the stop cock.

3. When water flows from all taps close the taps.

4. Allow system to stabilise for five minutes.

5. Open each hot water tap in turn to expel air from the system pipe work.

6. Check for leaks.

7. Manually operate Temperature and

Pressure Relief Valve (16) - Figures

2-4 to 2-6, to ensure free water flow through discharge pipe. (Turn knob to left).

6.2 Draining Down

Switch the electrical power off

(important to avoid damage to element).

Isolate boiler from DuoWave unit.

Turn off the cold water supply valve

(stop cock). Open hot water taps. Open drain (20) - Figures 2-4 to 2-6. The unit will drain.

6.3 Safety Cut-Out

1. The safety cut-out operates if: a. Wiring is incorrect.

b. The immersion heater thermostat or cylinder thermostat fails.

c. Thermostat is set too high.

2. Remember before resetting the safety cut-out or altering the thermostat setting, isolate electrical supply to the unit prior to removal of the electrical box lid.

3. Reduce thermostat setting and press the reset button. After adjustments are completed, ensure the lid to the electrical box is replaced correctly and the retaining screw is fitted.

4. If the problem persists, please contact your installer in the first instance.

6.4 Cold Water Discharge from

Tundish

There are two reasons why cold water will discharge from the tundish:

1. The pressure reducing valve has malfunctioned (This will cause a large volume of water to flow through the tundish).

2. The Expansion relief valve is letting by (This will cause a very low volume of water to flow through the tundish).

In both cases, identify the defective component and replace. All repairs must be carried out by a competent person.

6.5 Hot Water Discharge from

Tundish

There are four reasons why hot water will discharge from the tundish:

1. Thermal cut-out has malfunctioned.

2. The control thermostat has malfunctioned.

3. The T & P valve is letting by.

4. The expansion vessel has failed or lost its charge.

In all cases, should a repair be necessary, the work must be carried out by a competent person.

Isolate the cylinder from all electrical supplies before commencing maintenance work.

6.6 Expansion Vessel

1. The expansion vessel is connected into the cold water supply to the cylinder using the flexible hose.

Flexible hose not supplied with 50 litre vessel. This vessel is connected using rigid pipe. Refer to Section

4.3.

Note:

No valve should be fitted between the expansion vessel and the supply pipe.

2. Ensure that the air charge in the vessel matches the pressure setting shown on the pressure reducing valve.

3. The expansion vessel must be installed even if an accumulator is fitted.

4. The charge of the vessel must be checked at every annual service.

6.7 Customer Handover

1. Complete the Benchmark book supplied with the Cylinder and leave it with the User.

2. Explain the operation of the system to the User, referring to Section 10 of these instructions.

3. In particular, make the User aware of what to do if water is seen to flow from either the T&P Valve or

Expansion relief Valve. Refer User to the Information given in Section 10.

21

22

7 Maintenance

7.1 Servicing and Maintenance

1. Servicing and maintenance must only be carried out by a competent unvented hot water installer, or by

Grant Engineering (UK) Limited authorised personnel.

2. Before any work whatsoever is carried out on the installation, it

MUST first be isolated from the main’s electricity supply.

!

WARNING

Both the primary and secondary systems will contain very hot water that will scald; therefore care should be taken when opening any joints, seals or valves.

3. Only use spare parts authorised by

Grant Engineering (UK) Limited. The use of unauthorised spare parts will invalidate the warranty.

4. Drain the cylinder – When draining the cylinder, always switch off the boiler and the immersion heater first. Turn off the water supply at the mains stopcock.

Connect a hose pipe to the drain cock (see Figures 2-4 to 2-6) and route it to a convenient gully. Open the drain cock and all hot taps that are served by the cylinder. The cylinder may take several minutes to empty completely.

5. In hard water areas it may be necessary from time to time to remove and de-scale the immersion heater element. Replace the gasket each time it is removed.

6. Remove the cartridge from the pressure-reducing valve (PRV).

Check the strainer and if necessary remove any debris from in front of it. Replace the cartridge. Refer to section 7.3 on the right.

7. Check the charge pressure in the expansion vessel and top up as necessary. The charge pressure should be 3.0bar. Refer to section

7.5 on the right.

8. Whilst the hose pipe is connected, the drain cock open and with the immersion heater removed, the cylinder may be flushed out to remove any debris, sand or lime scale particles that may have collected in the bottom by using a further hose pipe connected to the cold water main.

9. Close the drain cock, disconnect the hose, refit the immersion heater and close all hot water taps before reopening the stopcock. Allow the cylinder time to fill whilst checking for any leaks. Release any air from the system by opening each hot water tap individually, starting with the one furthest from the cylinder.

10. Manually lift the expansion relief and temperature and pressure relief valve one at a time, every 12 months (more frequently in hard water areas) to prevent debris from building up behind the valve seat.

Whilst carrying out this operation, check that the discharge to waste is unobstructed. Check that each valve seals correctly when released.

As the valves are pre-calibrated, they require no further maintenance.

11. Finally switch on the mains electricity supply to the immersion heater and the boiler. As the system heats up, check again for any leaks and rectify as necessary.

7.2 Manifold Assembly

The manifold assembly should not, under normal circumstance, require any maintenance. During annual servicing it may be necessary to inspect and/or clean the line strainer, the pressure reducing valve cartridge, expansion relief valve cartridge. The frequency of cleaning will depend on the local water conditions.

7.3 Pressure Reducing Valve

1. Isolate the cold water supply.

2. Unscrew the retaining nut of the valve. The complete operating mechanism, including the strainer can be removed.

3. Clean the filter mesh and the cartridge under running water.

4. Replace cartridge ensuring that strainer is correctly located and reassemble the unit. Pressure

Reducing Valve cartridge and strainer Part No. GCS07C - 3.0 bar.

7.4 Expansion Relief Valve

Cartridge

1. Isolate the cold water supply.

2. Remove grub screw (Allen Key type) from body of valve and withdraw valve ensuring not to damage O-ring.

3. Clean valve seat face and seating do not scratch or damage either seat face or seating.

4. Refit in reverse order. Do not overtighten. Expansion valve cartridge Part No. GCS08.

7.5 Expansion Vessel

1. Isolate the cold water supply.

2. Open hot water taps.

3. Drain cylinder to below tee piece take off for expansion vessel flexible hose.

4. Replace expansion vessel after first checking the air charge (and hose if required).

5. Close drain off cock and turn on cold water supply.

6. When water is flowing freely from taps close taps.

8 Fault Finding Guide

8.1 Intermittent Water Discharge

Intermittent Water Discharge from T & P Valve

Expansion Vessel

Charge Reduced

No

Thermostat Failure

Yes

Test Vessel and

Recharge or Replace

Immersion Thermostat

Failure

No

Yes

Primary Cylinder

Thermostat

Yes

No

Repair or Replace

Immersion Thermostat

Repair or Replace

Thermostat

Faulty T & P

Valve

Yes

Replace T & P

Valve

Test for correct operation. If water is still discharging, contact a competent Engineer

23

8 Fault Finding Guide

8.2 Constant Water Discharge

Constant Water Discharge from T & P Valve

Expansion Vessel

Charge Reduced

No

Yes

Test Vessel and

Recharge or Replace

Faulty T & P

Valve

Yes

No

Faulty Pressure

Reducing Valve

Yes

No

Replace T & P

Valve

Yes

Replace Pressure

Reducing Valve

Test for correct operation. If water is still discharging, contact a competent Engineer

Yes

8.3 No Flow from Hot Water Taps

No Flow from Hot Water Taps

24

Mains Supply

Disconnected?

No

Mains Supply

Disconnected?

Yes

No

Mains Supply

Disconnected?

Yes

No

Yes

Open supply valve or wait for supply to be reconnected

Clean Line Strainer

Yes

Repair or Replace

Thermostat

Yes

Test for correct operation. If water is still not flowing, contact a competent Engineer

8.4 Cold Water Flow from Hot Water Taps

Cold Water from Hot Water Taps

Is Programmer calling for Hot Water?

Yes

Is Motorised Valve working?

Yes

Is Boiler working?

Yes

No No No

Check and Set Hot

Water setting

Is Cylinder Stat

Calling for Heat?

No

Yes

Check Motorised Valve motor and Micro-switch

Yes

Has Thermal Cut-Out

Operated?

Yes

Check and Reset

Button

No

Check and Replace

Cylinder Thermostat

Test for correct operation. If water is still cold, contact a competent Engineer

25

26

8 Fault Finding Guide

8.5 Excessive Hot Water from Taps

Excessive Hot Water from Taps

Is Cylinder Thermostat set too high?

No

Yes

Is System Wiring correct?

Yes

No

Correct Wiring as per instructions

Reduce Thermostat

Setting

Is Cylinder Thermostat

Operating?

No

Yes

Replace Cylinder

Thermostat

Does Motorised Valve close when Thermostat is satisfied?

No

Repair or Replace

Motorised Valve Motor

Repair or Replace

Motorised Valve

Yes

Fault. Contact

Engineer

Test for correct operation. If water is still cold, contact a competent Engineer

9 Spare Parts

9.1 Spare Parts

Figure 9-1: Pressure Reducing Valve

(Cartridge and Strainer) - 3 bar

Figure 9-3: Inlet Manifold including pressure reducing valve, expansion relief valve

Figure 9-5: Flexible Hose

Figure 9-2: Tundish Figure 9-4: Expansion Relief Valve

(Complete) - 6 bar

Figure 9-6: Expansion Vessel

DuoWave Indirect Cylinder Spare Parts

Part Name

Pressure Reducing Valve - 3 bar

Expansion Relief Valve - 6 bar

Flexible Hose -

3

/

4

" BSPF x

3

/

4

" BSPM

1 /

2

" Temperature & Pressure Relief Valve 90˚C/7 bar

Tundish - 15mm/22mm Compression

Coil Control/Limit Thermostat

Immersion Heater Element - Cotherm type ELE14-IN-800-UNV

Drain Cock

Immersion Heater Thermostat - Cotherm type TSE

Motorised Valve

Expansion Vessel 19 litre nominal (170, 200 & 250 models)* (18 litre actual vol) -

3

/

4

" BSPM connection

Expansion Vessel 24 litre nominal (300 model)* (22 litre actual vol) - 3 /

4

" BSPM connection

Expansion Vessel 35 litre nominal (400 model)* (35 litre actual vol) - 3 /

4

" BSPM connection

Expansion Vessel 50 litre nominal (500 model)* (50 litre actual vol) - 1" BSPM connection

1" BSPF x

3

/

4

" BSPM Adaptor - for 35 litre Expansion Vessel

Inlet Manifold c/w 3 bar Pressure Reducing Valve and 6 bar Expansion Relief Valve

*All pre-charged to 3 bar

Part No.

GCS32

GCS08

GCS02

GCS09

GCS10

GCS11

GCS30

GCS14

GCS31

GCS16

GCS24

GCS25

GCS28

GCS27

GCS33

GCS07

27

28

10 User Instructions

10.1 User Instructions

1. Your Grant DuoWave Solar or

DuoWave HP unvented hot water cylinder has been designed to give many years of trouble-free service and is made from hygienic high grade stainless steel. The Indirect models include two 3 kW electric immersion heaters for times when your central heating or heat pump is switched off, during the summer for instance.

2. The flow temperature of the hot water can be set to your requirements on the immersion heater up to 60°C and the indirect system dual thermostat up to 65°C.

These temperatures should not be set any higher otherwise nuisance tripping of the high limit thermostat will occur. If you are in any doubt, these adjustments should be best left to a qualified electrician.

3. When a hot tap is turned on there may be a short surge of water, this is quite normal with unvented systems and does not mean there is a fault.

4. When you first fill a basin the water may sometimes appear milky. This is due to very tiny air bubbles in the water, which will clear very quickly.

!

WARNING

If water is seen to flow from either the

Temperature & Pressure Relief (T&P

Valve) valve or the Expansion Relief

Valve (EV) on the cylinder seek expert advice immediately.

If the water is flowing from the T&P

Valve, immediately:

Shut off the electrical supply to the immersion heater(s)

Shut down the boiler

Switch off ALL other heat sources to the cylinder e.g. solar, heat pump, etc.

DO NOT SHUT OFF THE WATER

SUPPLY TO THE CYLINDER.

Contact your installer to check the system.

IMPORTANT

Do NOT tamper with any of the Safety controls fitted to the cylinder. If you suspect a fault always contact a

COMPETENT installer who is

QUALIFIED to work on unvented water cylinders.

11 Warranty

11.1 The Grant Cylinder

Warranty

Dear Customer

You are now the proud owner of a

Grant Cylinder from Grant Engineering

(UK) Limited, which has been designed to give you years of reliable, trouble free operation.

Grant Engineering (UK) Ltd. guarantees all electrical and mechanical components supplied with the cylinder for a period of two years from the date of purchase. In addition, the stainless steel used in the manufacture of the cylinder is guaranteed for a period of twenty five years with the manufacturing process of the cylinder guaranteed for two years from the date of purchase, provided that the cylinder is installed in full accordance with the installation instructions provided and the system is serviced after twelve months operation.

(see Terms and Conditions).

Important

Please register your Grant cylinder with

Grant UK within thirty days of the installation as follows.

Visit www.grantuk.com and follow the links to the 'Householder zone' where you can register your cylinder for a further one year warranty (giving two years from the date of purchase). This does not affect your statutory rights.

Breakdown during the

Manufacturer’s Warranty

If your Grant Cylinder should fail during the first two years, you must contact

Grant Engineering (UK) Limited, who will arrange for the repair under the terms of their Warranty, providing that the system has been correctly installed and commissioned, serviced (if older than twelve months) and the fault is not due to misuse, or the failure of any external components not supplied by Grant UK

(e.g. pipework, etc.). This extended two year warranty only applies if the cylinder is registered with Grant UK within thirty days of installation.

In the first Instance:

Contact your installer or commissioning engineer to ensure that the fault does not lie with the system or any other components, or any incorrect setting of the system controls.

If a Fault is Found:

Ask your installer to contact Grant

Engineering (UK) Limited, Service

Department on 01380 736920 who will arrange for a qualified service engineer to attend to the fault.

Free of Charge Repairs:

During the first two years no charge for parts or labour will be made providing that the Cylinder has been installed and commissioned correctly in accordance with the manufacturer’s instructions, servised at twelve month intervals and the cylinder was registered with Grant

UK within thirty days of installation.

Proof of ‘purchase’ date must be provided upon request.

Chargeable Repairs:

A charge will be made if the cause of the breakdown is due to any of the following:

• Faults caused by the plumbing or heating system, external electrics and external components.

• The Grant Cylinder has not been commissioned, or serviced in accordance with the installation and servicing manual.

• The system has been installed for over two years.

Remember before you contact

Grant:

Please register your Grant cylinder within thirty days of the installation.

Terms of Manufacturer’s Guarantee

1. The Grant Cylinder guarantee starts from the date of purchase.

2. All electrical and mechanical components supplied with the

Grant Cylinder are guaranteed for a period of two years. The stainless steel used in the manufacture of the cylinder is guaranteed for a period of twenty five years with the manufacturing process of the cylinder guaranteed for two years.

3. The cylinder is registered within 30 days of installation. Failure to do so does not affect your statutory rights.

4. The Grant Cylinder must be installed by a competent/licensed installer and in accordance with the Codes of

Practice and Regulations in force at the time of the installation.

5. The Grant Cylinder and its components must not have been modified or tampered with.

6. The installation must be serviced every twelve months as per the installation instructions. (Receipts should be kept as proof).

7. The Grant Cylinder must be connected to a mains water supply

(installations utilising a private water supply are not covered by this guarantee).

8. Breakdown/failure due to lime-scale will not be covered by this guarantee.

9. The Grant Cylinder must not be sited in a location where it may be subjected to frost.

10. All claims under this guarantee must be made to Grant Engineering

(UK) Ltd prior to any work being undertaken. Proof of purchase and date of installation must be provided on request. Invoices for call out/repair work by any third party will not be accepted unless previously authorised by Grant

Engineering (UK) Ltd.

11. This guarantee is transferable providing the installation is serviced prior to the dwelling’s new owners taking up residence. Grant

Engineering (UK) Ltd must be informed of the new owner’s details.

12. Grant Engineering (UK) Ltd will endeavour to provide prompt service in the unlikely event of a problem occurring, but cannot be held responsible for any consequence of delay however caused.

13. This guarantee applies to Grant

Cylinders installed on the UK mainland, Isle of Man and Channel

Islands only. Provision of in-warranty cover elsewhere in the UK is subject to agreement with Grant

Engineering (UK) Ltd.

29

30

11 Warranty

11.2 Extended Warranty

For further peace of mind Grant

Engineering (UK) Ltd offer the option to insure all the components of your Grant

Cylinder for a further three years, following on from the two year product warranty period. For a single premium payment (inclusive of Insurance

Premium tax) you get five years of protection against breakdown costs. At the end of this period you will have the opportunity to continue this cover on an annual basis.

To access full details and an application form for this extended cover, first visit www.grantuk.com.

Follow the links to the ‘Householder

Zone’, register your Cylinder for a further one year product warranty

(giving two years from the date of purchase), and then download the extended warranty details and application form.

Please note that this special offer is only available if the application form is submitted to Bluefin Insurance Services

Ltd. within three month of the installation date.

Notes

31

GRANT ENGINEERING (UK) LTD

Hopton House, Hopton Industrial Estate, Devizes, Wiltshire. SN10 2EU

Telephone: 01380 736920 Fax: 01380 736991

Email: [email protected] Website: www.grantuk.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
