IMPORTANT NOTE
Getting Started
Warning
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The mains lead on this equipment is supplied with a
moulded plug incorporating a fuse. The value of the
fuse is indicated on the pin face of the plug. If it requires
replacing, a fuse approved to BS1362 of the same
rating must be used.
Never use the plug with the fuse cover omitted if the cover
is detachable. If a replacement fuse cover is
required, it must be of the same colour as the pin face of
the plug. Replacement covers are available from your
dealer.
If the fitted plug is not suitable for the power points in your
house or the cable is not long enough to reach a
power point, you should obtain a suitable safety approved
extension lead or consult your dealer for assistance.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
Do not install this equipment in a confined space such
as a bookcase or similar unit.
WARNING : To prevent damage which may result in fire
or electric shock hazard, do not expose this
appliance to rain or moisture.
CAUTION : HDD & DVD RECORDER USES AN INVISIBLE
LASER BEAM WHICH CAN CAUSE
HAZARDOUS RADIATION EXPOSURE IF
DIRECTED. BE SURE TO OPERATE HDD &
DVD RECORDER CORRECTLY AS
INSTRUCTED.
CAUTION
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
This product satisfies CE regulations when shielded cables
and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with
electric appliances, such as radios and televisions, use
shielded cables and connectors for connections.
Downloaded From2DvDPlayer-Manual.com
Samsung Manuals
- English
However, if there is no alternative to cutting off the plug,
remove the fuse and then safely dispose of the
plug. Do not connect the plug to a mains jack, as there is
a risk of shock hazard from the bared flexible cord.
The product unit accompanying this user manual is
licenced under certain intellectual property rights of certain
third parties. This licence is limited to private noncommercial use by end-user consumers for licenced
contents.
No rights are granted for commercial use.
The licence does not cover any product unit other than this
product unit and the licence does not extend to any
unlicenced product unit or process conforming to ISO/IEC
11172-3 or ISO/IEC 13818-3 used or sold in combination
with this product unit. The licence only covers the use of
this product unit to encode and/or decode audio files
conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3.
No rights are granted under this licence for product
features or functions that do not conform to the ISO/IEC
11172-3 or ISO/IEC 13818-3.
Precaution
Read these operating instructions carefully before using
the unit. Follow all the safety instructions listed below.
Keep these operating instructions handy for future
reference.
1)
2)
3)
4)
5)
6)
7)
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings, Install in
accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding- type plug. A polarized plug has two
blades with one wider than the other. A groundingtype plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. if the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
• Before connecting other components to this HDD &
DVD RECORDER, be sure to turn them all off.
• Do not move the HDD & DVD RECORDER while a
disc is being played, or the disc may be scratched
or broken, the HDD & DVD RECORDER internal
parts may be damaged.
• Do not put a flower vase filled with water or any
small metal objects on the HDD & DVD RECORDER.
• Be careful not to put your hand into the disc tray.
• Do not place anything other than the disc in the
disc tray.
• Exterior interference such as lightning and static
electricity can affect normal operation of this HDD
& DVD RECORDER. If this occurs, turn the HDD &
DVD RECORDER off and on again with the DVD
STANDBY/ON button, or disconnect and then
reconnect the AC power cord to the AC power
outlet. The HDD & DVD RECORDER will operate
normally.
• Be sure to remove the disc and turn off the HDD &
DVD RECORDER after use.
• Disconnect the AC power cord from the AC outlet
when you don’t intend to use the HDD & DVD
RECORDER for long periods of time.
• Clean the disc by wiping in a straight line from the
inside to the outside of the disc.
Maintenance of Cabinet
For safety reasons, be sure to disconnect the AC
power cord from the AC outlet.
• Do not use benzene, thinner, or other solvents
for cleaning.
• Wipe the cabinet with a soft cloth.
HDD (Hard Disk Drive)
The hard disk has a high storage density, which
enables long recording durations and quick
access to written data. However, it can easily be
damaged by shock, vibration or dust and should
be kept away from magnets. To avioid losing
important data, observe the following precautions.
• Do not use the HDD & DVD RECORDER in a
place subject to extreame changes in
temperature.
• Do not apply a strong shock to the HDD & DVD
RECORDER.
• Do not place the HDD & DVD RECORDER in a
location subject to mechanical vibrations or in an
unstable location.
English - 3
Getting Started
Important Safety Instructions
Handling Cautions
Getting Started
• Do not place the HDD & DVD RECORDER on
top of a heat source.
• Do not disconnect the AC power cord while the
power is on.
• Do not attempt to change the hard disk. This
may result in a malfunction.
use discs fixed with exposed tape adhesive or
leftover peeled-off stickers.)
• Do not use scratch-proof protectors or covers.
• Do not use discs printed with label printers
available on the market.
• Do not load warped or cracked discs.
Should the hard disk be damaged, you cannot
recover lost data. The hard disk is only a
temporary storage space.
Disc Storage
Disc Handling
• Use discs with regular
shapes. If an irregular disc
(a disc with a special shape)
is used, this HDD & DVD
RECORDER may be
damaged.
Holding discs
Be careful not to harm the disc because the data on
these discs is highly vulnerable to the environment.
• Do not keep under direct sunlight.
• Keep in a cool ventilated area.
• Store vertically.
• Keep in a clean protection jacket.
• If you move your HDD & DVD RECORDER suddenly
from a cold place to a warm place, condensation may
generate on the operating parts and lens and cause
abnormal disc playback. If this occurs, do not connect
the plug to the power outlet and wait for two hours.
Then insert the disc and try to play back again.
• Avoid touching the surface of a
disc where recording is
performed.
Disc Specifications
DVD-RAM, DVD-RW and DVD-R
• Clean with an optional DVD-RAM/PD
disc cleaner (LF-K200DCA1 where
available). Do not use cleaners or
cloths for CDs to clean DVD-RAM/
-RW/-R discs.
DVD-Video, Audio-CD
• Wipe off dirt or contamination on the disc with a
soft cloth.
Disc Type
DVD-Video
• A digital versatile disc (DVD) can contain up to 135minutes of images, 8 audio languages and 32 subtitle
languages. It is equipped with MPEG-2 picture
compression and Dolby digital surrounding, allowing
you to enjoy vivid and clear theatre quality images in
the comfort of your own home.
• When switching from the first layer to the second layer
of a dual-layered DVD Video disc, there may be
momentary distortion in the image and sound. This is
not a malfunction of the unit.
• Once a DVD-RW/-R recorded in Video Mode is
finalised, it becomes DVD-Video.
Cautions on handling discs
• Do not write on the printed side with a ball-point
pen or pencil.
• Do not use record cleaning sprays or antistatic.
Also, do not use volatile chemicals, such as
benzene or thinner.
• Do not apply labels or stickers to discs. (Do not
Downloaded From4DvDPlayer-Manual.com
Samsung Manuals
- English
Audio CD
• Recording and playback can be performed on DVDRW discs in both the Video and VR Modes.
• Once a DVD-RW recorded in both the Video and VR
Modes is finalised, you cannot perform addtional
recording.
• Once a DVD-RW recorded in Video Mode is finalised,
it becomes DVD-Video.
CD-RW/-R
• Use a 700MB(80 minutes) CD-R/RW disc. If possible,
do not use a 800MB(90 minutes) or above disc, as the
disc may not play back.
• If the CD-R/RW disc was not recorded as a closed
session, you may experience a delay in the early
playback time, all recorded files may not play.
• Some CD-R/RW discs may not be playable with this
unit, depending on the device which was used to burn
them. For contents recorded on CD-R/RW media from
CDs for your personal use, playability may vary
depending on contents and discs.
DVD-R Disc Playback and Recording
• Once a DVD-R recorded in Video Mode is finalised, it
becomes DVD-Video.
• You can record onto the available space on the disc
and perform editing functions such as giving titles to
discs and programmes and erasing programmes
before finalising.
• When programming is erased from a DVD-R, that
space does not become available. Once an area on a
DVD-R is recorded on, that area is no longer available
for recording, whether the recording is erased or not.
• It takes about 30 seconds for the unit to complete
recording management information after recording
finishes.
• This product optimizes the DVD-R for each recording.
Optimizing is carried out when you start recording
after inserting the disc or turning on the unit.
Recording onto the disc may become impossible if
optimizing is carried out too many times.
• Playback may be impossible in some cases due to the
condition of recording.
• This unit can play back DVD-R discs recorded and
finalised with a Samsung DVD video recorder. It may
not be able to play some DVD-R discs depending on
the disc and the condition of the recording.
• In both modes, playback can be performed before and
after finalisation, but additional recording, deleting and
editing can not be performed after finalisation.
• If you want to record the disc in VR Mode and then
record in V Mode, be sure to execute Format. Be
careful when executing Format because all the
recorded data may be lost.
• A DVD-RW blank disc is initialized to VR Mode when
first initialized.
DVD-RAM Disc Playback and Recording
• Ensure that the recording mode is set to VR mode.
Otherwise, this product will not be able to play the
recording.
• You cannot play a DVD-RAM in most DVD
components due to compatibility issues.
• Only DVD-RAM standard Version 2.0. discs can be
played in this unit.
• DVD-RAM recorded on this unit may not work with
other DVD components. To determine compatibility
with these DVD-RAM discs, refer to the user’s manual
for the player.
• For cartridge type DVD-RAM discs, remove the
cartridge and use the disc only.
Disc Copy
Contents Copy Specifications
Contents
Recorded Video Title
Copy Protected Title
Copy Once Title
MP3
JPEG(photo)
DivX
HDD ➞ DVD
Supported
Not supported
Move
(Deletes the Title in the
HDD after copying)
Not supported
Not supported
Not supported
DVD ➞ HDD
Supported
Not supported
Not supported
supported
supported
Not supported
Once "Copy Once programme" has been recorded on the
DVD disc, this title cannot be copied to HDD anymore.
But "Copy Once programme" has been recorded on the
HDD, this title can be copied to DVD-RW(VR mode) or
DVD-RAM.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 5
Getting Started
• An audio disc on which 44.1kHz PCM Audio is
recorded.
• Plays CD-DA format audio CD-R and CD-RW discs.
• The unit may not be able to play some CD-R or CDRW discs due to the condition of the recording.
DVD-RW Disc Playback and Recording
Getting Started
COPY PROTECTION
• Many DVD discs are encoded with copy
protection. Because of this, you should only
connect your HDD & DVD RECORDER directly to
your TV, not to a VCR. Connecting to a VCR
results in a distorted picture from copy-protected
DVD discs.
• This product incorporates copyright protection
technology that is protected by methods claims of
certain U.S. patents and other intellectual
property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright
protection technology must be authorised by
Macrovision Corporation, is intended for home
and other limited viewing uses only unless
otherwise authorised by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Protection
This HDD & DVD RECORDER can allow you to protect
the contents of your discs, as described below.
• Programme-protected: See page 95
“Locking(Protecting) a Title”
Using JPEG disc
• CD-R, DVD-R/RW/RAM, HDD with JPEG files
recorded with UDF, ISO9660 or JOLIET format can be
playbacked.
• Only JPEG files with the “.jpg” or “.JPG” extension
can be displayed.
• The unit can handle a maximum of 4,500 files and
1,000 sub folders under a folder.
• MOTION JPEG and progressive JPEG are not
supported.
Using MPEG4 disc
• Disc : CD-RW/-R, DVD-RAM/-RW/-R
• MPEG4 File with following extensions can be played. :
.avi, .divx, .AVI, .DIVX
• MPEG4 Codec format : DivX 3.11 DivX 4.x DivX 5.x
(without QPEL and GMC)
• Available Audio Format : “MP3”, “MPEG”, “WMA”,
“LPCM”, “AC3”
• Supported subtitle file formats: .smi, .srt, .sub, .psb,
.txt, .ass
• Disc-protected: See page 120 “Disc Protection”
❋ DVD-RAM/-RW/-R discs that are incompatible with
the DVD-VIDEO format cannot be played with this
product.
❋ For more information on DVD recording compatibility,
consult your DVD-RAM/-RW/-R manufacturer.
❋ Use of poor quality DVD-RAM/-RW/-R discs may
cause following unexpected problems including,
without limitation, recording failure, loss of recorded
or edited materials or damage to the HDD & DVD
RECORDER.
DVD-RAM/-RW (VR)
• This is a format that is used for recording data on a
DVD-RAM or DVD-RW disc. You can record multiple
titles, edit, delete, partial delete, create a playlist, etc.
• A disc that is recorded in this mode may not be
played by existing HDD & DVD RECORDER.
DVD-RW (V)/-R
Disc Format
Using MP3 disc
• CD-R, DVD-R/RW/RAM, HDD with MP3 files recorded
with UDF, ISO9660 or JOLIET format can be
playbacked.
• Only MP3 files with the “.mp3” or “.MP3” extension
can be played.
• For MP3 files recorded with a VBR(Variable Bit
Rates), from 32 Kbps to 320 Kbps, the sound may cut
in out.
• Playable bit-rate range is from 56 Kbps to 320 Kbps.
• The unit can handle a maximum of 1,500 files and
1,000 sub folders under a folder
Downloaded From6DvDPlayer-Manual.com
Samsung Manuals
- English
• This is a format that is used for recording data on a
DVD-RW or DVD-R disc. The disc can be played by
existing HDD & DVD RECORDER once it has been
finalised.
• If a disc that has been recorded in Video Mode by a
different maker’s recorder but has not been finalised,
it cannot be played or additionally be recorded by this
HDD & DVD RECORDER.
Do not use the following discs!
Getting Started
• LD, CD-G, CD-I, CD-ROM, DVD-ROM, DVD+R and
DVD+RW discs should not be used in this product.
[Note]
Disc types that can be played : CD/CD-R/-RW/
MP3/JPEG/DVD-Video/DVD-RAM/-RW/-R.
For a DVD-RW/-R disc, which has been recorded in
Video Mode on another component, it can play only
when finalised.
• Some commercial discs and DVD discs purchased
outside your region may not be playable with this
product. When these discs are played, either “No
disc.” or “Please check the regional code of the disc.”
will be displayed.
• If your DVD-RW disc is an illegal copy or is not in
DVD video format, it may also not be playable.
Disc compatibility
• High Speed Recording discs can be used in this unit.
• Not all brands of discs will be compatible with this
unit.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 7
Getting Started
Contents
Case 3: Connecting to an AV amplifier
with a digital output jack .................................................23
Connecting to AV 3 IN, DV input jack...................24
Case 1 : Connecting a VCR, Set-Top Box(STB),
DVD player or Camcorder to the AV3 IN jacks ........24
Case 2 : Connecting a Camcorder to the
DV IN jack ..............................................................24
Getting Started
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . .3
Handling Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Maintenance of Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . .3
HDD (Hard Disk Drive) . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Disc Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Disc Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Disc Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Disc Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
General Features . . . . . . . . . . . . . . . . . . . . . . . . . .10
Before Reading the User’s Manual . . . . . . . . . . .11
How to use the HDD & DVD RECORDER . . . . . .11
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Front Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Tour of the Remote Control . . . . . . . . . . . . . . . . . . . . . .17
Connecting & Setting Up
Quick Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Connecting the HDD & DVD RECORDER . . . . . .19
Additional connections . . . . . . . . . . . . . . . . . . . . .19
Antenna + HDD & DVD RECORDER + External
decoder box + TV . . . . . . . . . . . . . . . . . . . . . . . . . 20
Other type of connecting the Video output cable . .20
Case 1 : Connecting to a Video (Composite)
output jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Case 2 : Connecting to an S-Video output jack . . . . . .21
Case 3 : Component Video output jacks . . . . . . . . . . .22
Other type of connecting the Audio output cable . . . .22
Case 1 : Connecting to your TV . . . . . . . . . . . . . . . . . .22
Case 2 : Connecting to a stereo amplifier
with AV output jacks . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Downloaded From8DvDPlayer-Manual.com
Samsung Manuals
- English
System Setup
On-Screen Menu Navigation..................................25
Plug & Auto Setup ...................................................26
Setting the Clock......................................................27
Presetting Channels with the Auto Setup function .....28
Presetting Channels with the Manual Setup
function......................................................................30
Setting up the Language Options.........................31
Auto Power Off Setting...........................................32
CM Skip Time Setting..............................................33
EP Mode Time Setting.............................................34
Setting up the Front Display Options ..................35
Automatic Chapter Creator....................................36
Setting up NICAM Options.....................................37
DivX(R) Registration................................................38
Setting up the Audio Options................................38
Setting up the Video display Options ..................40
Setting up Video Output Options..........................41
Setting up the Progressive scan...........................42
Canceling the Progressive scan ...........................43
Setting up the Parental Control.............................44
If you forgot your password ............................................44
Setting the Rating Level..................................................45
Changing the Password .................................................45
Playback
Before Playing..........................................................46
Playing a Disc...........................................................47
Using the Disc Menu & Title Menu .......................48
Using the Search & Skip Functions .....................48
Slow Motion Play/Step Motion Play......................49
About ANYKEY.........................................................50
Playing the Title List................................................52
Copying from HDD to DVD..................................109
About the Copy Screen ................................................109
Changing the Record Mode .........................................112
Copying Multiple Titles at One Time..................112
Deleting an Undesired Title from the Copy List...........114
Previewing a Selected Title from the Copy List...........114
Selecting Record Mode of Each Title
from the Copy List. ........................................................115
Changing Record Mode of All Titles
from the Copy List .........................................................115
Copying from DVD to HDD ..................................116
Copying MP3 or JPEG Files
from a Disc to HDD ..............................................117
File Copy........................................................................117
Folder Copy ...................................................................118
Recording
Before Recording.....................................................77
Recording the current TV programme you are
watching ....................................................................79
Recording from external equipment
you are watching .....................................................81
Copying from a Camcorder ...................................82
Making a One Touch Recording (OTR)................83
Chasing Play.............................................................84
Simultaneous Recording and Playback ..............85
Making a Timer Recording ....................................86
Flexible Recording (for Timer recording only) ...88
Editing the Timer Record List................................88
Deleting a Timer Record List.................................89
Go To History List....................................................90
Disc Manager .........................................................119
Editing the Disc Name ..................................................119
Disc Protection ..............................................................120
Formatting a Disc ..........................................................121
Delete All Title Lists/Music Lists/Photo Lists................122
Delete All Title Lists ......................................................123
Finalising a Disc ...........................................................124
Unfinalising a Disc (V/VR mode) .................................125
Reference
Troubleshooting .....................................................126
Specifications ........................................................130
Editing
Basic Editing (Title List) .........................................94
Renaming(Labeling) a Title.............................................94
Locking (Protecting) a Title ............................................95
Deleting a Title.................................................................96
Splitting a Section of a Title (Split)..................................97
Deleting a Section of a Title (Partial Delete)..................99
Advanced Editing (Playlist) .................................101
Creating a Playlist .........................................................101
Playing Entries in the Playlist .......................................102
Renaming a Playlist Entry ............................................103
Editing a Scene for the Playlist.....................................104
Deleting a Playlist Entry from the Playlist ....................108
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 9
Getting Started
Navigation Menu ......................................................53
Using Markers ..........................................................56
Using the Bookmarks .............................................58
Selecting the Subtitle Language...........................60
Selecting the Soundtracks & Audio Channels...61
Changing the Camera Angle..................................62
Repeat Play...............................................................62
Zooming-In................................................................64
Select Media..............................................................65
Playing an Audio CD/MP3 ......................................65
Viewing a Picture .....................................................72
Playing an MPEG4...................................................75
Getting Started
General Features
recording time, LP & SP modes provide less recording
time with higher quality recording, XP mode gives you the
highest quality recording.
Automated Quality Adjustment for Timer
Recording
The HDD(Hard Disk Drive) & DVD RECORDER allows
you to record and play high quality digital video on DVDRAM/-RW/-R discs or on the HDD. You can also edit
digital images on DVD-RAM/-RW/-R discs or HDD.
HDD Recording
• DVD-HR710
You can record up to 127 hours of video (in EP mode) on
the internal 80GB (gigabyte) hard disk (HDD).
• DVD-HR721
You can record up to 272 hours of video (in EP mode) on
the internal 160GB (gigabyte) hard disk (HDD).
With both recordable DVD and a high-capacity HDD in the
same recorder, you have the flexibility to keep recordings
on the HDD for quick access anytime, or record to DVD
for archiving or playing on other DVD players.
If FR mode is selected, the video quality is adjusted
automatically so that all video for the scheduled time can
be recorded onto the free disc space.
(See page 88)
Creating a DVD video title using DVD-RW/-R
disc
With the HDD & DVD RECORDER, you can create your
own DVD Video titles on 4.7 GB DVD-RW/-R discs.
Copying data from a digital camcorder using
a DV input jack
Record DV Device video onto HDD and DVD-RAM/-RW/-R
discs using the DV input jack (IEEE 1394-4pin/4pin).
(See page 82)
High quality progressive scan
Copy between HDD and DVD
You can copy recordings from the HDD to recordable
DVD, or from DVD to the HDD. Usually you can use the
high speed copy feature.
You can also choose to copy material at a different
recording quality from the original. For example, you might
want to copy at XP mode (highest quality) recording on
the HDD to SP (standard play) quality on a DVD so that
you can fit other recordings on the same disc.
Simultaneous Recording and Playback
Playback and recording for both the DVD and the built-in
hard disk drive (HDD) are completely independent. For
example you can record a broadcast programme to either
a recordable DVD or the HDD, while watching another
recording you already made on the same DVD or on the
HDD.
High quality digital audio and video recording
and playback
Record up to 16-hours of video with a double sided 9.4
GB DVD-RAM disc, up to 8-hours of video with a 4.7 GB
DVD-RAM/-RW/-R disc, depending on the recording
mode.
Selectable Recording Mode
You can set your HDD & DVD RECORDER to one of four
different recording speeds, each varying in recording
quality and length. EP (6Hr or 8Hr) mode yields the most
Downloaded From10
DvDPlayer-Manual.com
Samsung Manuals
- English
Progressive scanning provides high resolution and flicker
free video. The 10-bit 54-MHz DAC and 2D Y/C
Separating Circuitry provides the highest image playback
and recording quality. (See pages 42~43)
A variety of functions with an easy-to-use
user interface
The integrated menu system allows you to perform
desired operations both easily and conveniently. With a
HDD, DVD-RAM or DVD-RW disc, you can edit recorded
video, create a playlist, edit video in a specific sequence
according to your requirements.
MPEG4 playback
This HDD & DVD RECORDER can play MPEG4 formats
within an avi file.
DivX Certification
DivX, DivX Certified, and associated
logos are trademarks of DivXNetworks,
Inc and are used under licence.
©2005 Samsung Electronics Co.
All rights reserved; No part or whole of this user’s
manual may be reproduced or copied without the prior
written permission of Samsung Electronics Co.
Make sure to check the following terms before reading
the user manual.
Icons that will be used in manual
Icon
How to use the
HDD & DVD RECORDER
Term
Definition
HDD
This involves a function available
on the HDD.
DVD
This involves a function available
on DVD or DVD-R/DVD-RW
discs that have been recorded
and finalised in Video Mode.
RAM
This involves a function available
on DVD-RAM.
RW
This involves a function available
on DVD-RW.
R
This involves a function available
on DVD-R.
CD
This involves a function available
on a data CD (CD-R or CD-RW).
JPEG
This involves a function available
on CD-R/-RW or DVD-R/-RW/
-RAM discs.
MP3
This involves a function available
on CD-R/-RW or DVD-R/-RW/
-RAM discs.
Step 2
MPEG4
This involves a function available
on CD-R/-RW or DVD-R/-RW/
-RAM discs.
Unlike a VCR, the HDD & DVD RECORDER automatically
starts formatting when an unused disc is inserted. This is
required for the preparation of recording on a disc.
Caution
This involves a case where a
function does not operate or
settings may be cancelled.
NOTE
This involves tips or instructions
on the page that help each
function operate.
One-Touch A function that can be operated
button
by using only one button.
ANYKEY A function that can be operated
button
by using ANYKEY button.
About the use of this user’s manual
1) Be sure to be familiar with Safety Instructions before
using this product. (See pages 2~7)
2) If a problem occurs, check the Troubleshooting.
(See pages 126~129)
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Step 1
Select the disc type or HDD
This unit can record on the following types of discs.
If you want to repeatedly record on the same disc or
you want to edit the disc after recording, select a
rewritable DVD-RW or DVD-RAM type disc. If you
want to save a recording without any changes,
choose a non-rewritable DVD-R. You can record files
directly to the built-in HDD or edit a recorded file.
Format the disc to start recording
Using the HDD
Formatting unneccessory.
Using a DVD-RAM
This type of disc can be formatted in DVD-Video
Recording format (VR mode). You can edit recorded
video and create a playlist and edit video in a specific
sequence according to your requirements.
Using a DVD-RW
This type of disc can be formatted in either DVD-Video
format (V mode) or DVD-Video Recording format (VR
mode). For an unused disc, a message that asks
whether to format in VR Mode or not is displayed. You
can play a Video mode disc on various DVD
components. A VR mode disc allows more varied editing.
Using a DVD-R
This type of disc can be formatted in DVD Video
format. After formatting is complete, you can record on
the disc. You can play these type of discs on various
DVD components only when they have been finalised.
English - 11
Getting Started
Before Reading the
User’s Manual
Copyright
■
NOTE
Getting Started
■
You can only use either the VR or Video
mode on a DVD-RW, but not both at the
same time.
You can change the DVD-RW to format
to another format by reinitializing. It
should be noted that the disc's data will
be lost when changing formats.
Step 5
Editing a recorded disc
Editing on discs is easier than conventional video
tapes. The HDD & DVD RECORDER supports many
different edit functions, possible only with DVDs and
HDD.
With a simple and easy edit menu, you can operate
various edit functions, such as delete, copy, rename,
lock, etc., on a recorded title.
Step 3
Recording
There are two different recording methods, Direct
Recording and Timer Recording. Timer recording is
classified as follows:
Recording mode : XP (high quality mode), SP
(standard quality mode), LP (long recording mode),
and EP (extended mode) according to the recording
mode. When recording is set in the FR mode, the best
quality picture is recorded with regards to the
remaining time on the disc.
Creating a playlist (DVD-RAM/-RW in VR mode,
HDD)
With this HDD & DVD RECORDER, you can create a
new playlist on a disc and edit it without the original,
pre-existing recording.
Step 6
Finalising & Playing on
other DVD components
To play your DVD on other DVD components,
finalising may be necessary. First, finish all editing and
recording operations, then finalise the disc.
When using a DVD-RW disc in VR Mode
Step 4
Playing
You can select the title you want to play in a
displayed menu and then immediately start
playback.
A DVD consists of sections, called titles, and subsections, called chapters.
During recording, a title is created between two
points where you start and stop recording.
Chapters will be created automatically when you
finalise recording on DVD-RW/-R discs in Video
mode.
The chapter’s length (interval between chapters)
varies according to the recording mode.
Downloaded From12
DvDPlayer-Manual.com
Samsung Manuals
- English
DVD discs recorded in VR mode can only be played
back in DVD recorders, not players.
When using a DVD-RW disc in Video Mode
The disc should be finalised first to enable playback
on anything other than this HDD & DVD RECORDER.
No more editing or recording can be made on the disc
once it has been finalised.
To enable recording on the disc again, the disc must
be unfinalised.
When using a DVD-R disc
You should finalise the disc to play it on a component
other than this HDD & DVD RECORDER. You cannot
edit or record on the disc once it has been finalised.
Unpacking
Setting the Remote Control
Check for the supplied accessories below.
You can control certain functions of another
manufacturer’s TV with this remote control.
Control function buttons involve: TV STANDBY/ON,
PROG
, TV VOL + -, Number buttons, TV MUTE,
INPUT button.
Video/Audio Cable
Remote Control
Instruction Manual
RF Cable for TV
Batteries for Remote
Control (AAA Size)
Quick Guide
Preparing the Remote Control
Install Batteries in the Remote Control
• Open the battery cover on the back of the remote control.
• Insert two AAA batteries. Make sure that the polarities
(+ and -) are aligned correctly.
• Replace the battery cover.
If the remote does not operate properly:
• Check the polarity + - of the batteries (Dry-Cell)
• Check if the batteries are drained.
• Check if remote sensor is blocked by obstacles.
• Check if there is any fluorescent lighting nearby.
Dispose of batteries according to local environmental
regulations. Do not put them in the household trash.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 13
Getting Started
Accessories
Getting Started
To determine whether your television is
compatible, follow the instructions below.
1. Switch your television on.
2. Point the remote control towards the television.
3. Press and hold the TV STANDBY/ON button and
enter the two-figure code corresponding to the
brand of your television, by pressing the
appropriate number buttons.
Controllable TV Codes
BRAND
SAMSUNG
AIWA
ANAM
BANG & OLUFSEN
BLAUPUNKT
BRANDT
BRIONVEGA
CGE
CONTINENTAL EDISON
DAEWOO
EMERSON
FERGUSON
FINLUX
FORMENTI
FUJITSU
GRADIENTE
GRUNDIG
HITACHI
IMPERIAL
JVC
LG
LOEWE
LOEWE OPTA
MAGNAVOX
METZ
MITSUBISHI
MIVAR
NEC
NEWSAN
NOBLEX
NOKIA
NORDMENDE
PANASONIC
PHILIPS
PHONOLA
PIONEER
RADIOLA
RADIOMARELLI
RCA
REX
SABA
SALORA
SANYO
SCHNEIDER
BUTTON
01, 02, 03, 04, 05, 06, 07, 08, 09
82
10, 11, 12, 13, 14, 15, 16, 17, 18
57
71
73
57
52
75
19, 20, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34
64
73
06, 49, 57
57
84
70
49, 52, 71
60, 72, 73, 75
52
61, 79
06, 19, 20, 21, 22, 78
06, 69
06, 57
40
57
06, 48, 62, 65
52, 77
83
68
66
74
72, 73, 75
53, 54, 74, 75
06, 55, 56, 57
06, 56, 57
58, 59, 73, 74
06, 56
57
45, 46
74
57, 72, 73, 74, 75
74
41, 42, 43, 44, 48
06
Downloaded From14
DvDPlayer-Manual.com
Samsung Manuals
- English
BRAND
SELECO
SHARP
SIEMENS
SINGER
SINUDYNE
SONY
TELEAVA
TELEFUNKEN
THOMSON
THOMSON ASIA
TOSHIBA
WEGA
YOKO
ZENITH
BUTTON
74
36, 37, 38, 39, 48
71
57
57
35, 48
73
67, 73, 75, 76
72, 73, 75
80, 81
47, 48, 49, 50, 51, 52
57
06
63
Result: If your television is compatible with the remote
control, it will switch off.
It is now programmed to operate with the remote
control.
■
If several codes are indicated for your
television brand, try each one in turn until
you find one that works.
■
If you replace the remote control's
batteries, you must set the brand code
again.
NOTE
Then you can control the television using the following
buttons after pressing the TV button.
Button
TV STANDBY/ON
INPUT
TV VOL (+ -)
PROG (
)
TV MUTE
Number
■
NOTE
Function
Used to switch the television on and off.
Used to select an external source.
Used to adjust the volume of the television.
Used to select the desired channel.
Used to toggle the sound on and off.
Used to input number directly.
The functions listed above will not necessarily
work on all televisions. If you encounter
problems, operate the television directly.
Description
Getting Started
Front Panel
1
2
9
3
10
1. STANDBY/ON BUTTON
Turns the HDD & DVD RECORDER on and off.
2. DVD BUTTON
Select DVD mode.
3. HDD BUTTON
Select HDD mode.
4. DISC TRAY
Opens to accept a disc.
5. DISPLAY
Displays the playing status, time, etc.
6. STOP BUTTON
Stops disc playback.
7. SEARCH/SKIP BUTTONS
Goes to the next title/chapter/track or goes
back to the previous title/chapter/track.
4
5
11
6
7
12
8
13
14
8. PROG
BUTTONS
Select TV preset Channels. Same as
PROG button on the remote control.
9. AV 3 INPUT
Connect external equipment.
10. DV-INPUT
Connect external digital equipment with a DV
jack. (such as a camcorder)
11. OPEN/CLOSE BUTTON
Opens and closes the disc tray.
12. PLAY/PAUSE BUTTON
Plays a disc or pauses playback or recording.
13. P.SCAN BUTTON
Selects the progressive scan mode.
14. REC BUTTON
Starts recording.
Front Panel Display
1. Lights when a disc is loaded.
2. Lights in the record mode.
3. Lights to indicate the timer record mode.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
4. Lights when a -R/RW/RAM disc is loaded.
5. Playing time/clock/current status indicator.
6. Lights in the progressive scan mode.
English - 15
Getting Started
Rear Panel
Fan
The fan always revolves when the power is on.
Ensure a minimum of 10cm clear space on all sides of
the fan when installing the product.
1. DIGITAL AUDIO OUT(OPTICAL)
5. S-VIDEO OUT
Connects to an amplifier having a digital optical
audio input jack.
2. DIGITAL AUDIO OUT(COAXIAL)
Connects to an amplifier having a digital coaxial
audio input jack.
3. AUDIO OUT
Connects to the audio input of external equipment
using audio cables.
4. VIDEO OUT
Connects the input of external equipment using a
Video cable.
Connects the input of external equipment using
an S-Video cable.
6. COMPONENT VIDEO OUT
Connects to equipment having Component video
input.
7. AV1(TV) OUTPUT SCART Connector
8. AV2(EXT) INPUT SCART Connector
9.
10.
In from aerial connector
Out to TV connector
■
NOTE
Downloaded From16
DvDPlayer-Manual.com
Samsung Manuals
- English
The Antenna connection does not pass the
output signal of the DVD. To watch
DVD/HDD playback your TV, you must
connect audio/video or Scart cables.
Tour of the Remote Control
13. OK/DIRECTION Buttons (…†œ √ Buttons)
14. RETURN Button
1
20
3
21
4
5
22
7
8
9
10
11
23
24
25
26
7
9
27
28
17. COPY Button
Press this when you copy DVD to HDD or HDD or viceversa.
To start copying, press the COPY button on the title list
screen or press the COPY button during the playback.
18. REPEAT Button
Allows you to repeat a title, chapter, track or disc.
19. REC PAUSE Button
Use this to pause during recording.
20. TV STANDBY/ON Button
29
21. AUDIO/TV MUTE Button
Use this to access various audio functions on a disc
(DVD mode).
In TV mode, this operates as sound mute.
14
30
15
31
22. INPUT Button
Select input signal in external input mode (PROG,
AV1,AV2, AV3 or DV input)
16
32
17
33
18
34
19
35
12
13
1. DVD STANDBY/ON Button
2. NUMBER Buttons
3. TV/DVD Button
4. DVD Button
Press this to operate DVD.
5. HDD Button
Press this to operate HDD.
6. TV VOL Button
TV volume adjustment
7. REVERSE/FORWARD SKIP Buttons
Press to skip backwards or forwards.
8. REVERSE/FORWARD STEP Buttons
Each press will play one-frame forward or reverse.
9. REVERSE/FORWARD SEARCH Buttons
Press to search a disc backwards or forwards.
10. STOP Button
Press to stop a disc.
11. TITLE LIST/DISC MENU Button
Use this to enter the View Recording list/disc menu.
12. MENU Button
Brings up the HDD & DVD RECORDER’s setup menu.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
23. TV Button
Press this to operate TV.
24. OPEN/CLOSE Button
To open and close the disc tray.
25. CM SKIP Button
When a programme recorded on DVD disc or HDD is
played, the unit can be set to automatically skip a portion
of the programme.
26. PROG Button
Use this to select a TV programme.
27. PLAY/PAUSE Button
Press to play/pause a disc.
28. PLAY LIST/TITLE MENU Button
Use this to return to the Title menu, or to view the
recorded files list.
29. ANYKEY Button
Allows access to common functions of the recorder.
30. CANCEL Button
31. SUBTITLE Button
Press this to switch the DVD’s subtitle language.
32. TIMER Button
Press to directly enter the Timer Recording Mode menu.
33. MARKER Button
Use this to bookmark a position while playing a disc.
34. REPEAT A-B Button
Allows you to repeat a title, chapter, track or disc.
35. REC MODE Button
Use this to set the desired Recording time and picture
quality. (XP/SP/LP/EP)
English - 17
Getting Started
16. REC Button
Use to make a recording on HDD/DVD-RAM/-RW/-R
discs.
2
6
15. INFO Button
This will display current setting or disc status.
Connecting & Setting Up
Connecting &
Setting Up
This section involves various methods of
connecting the HDD & DVD RECORDER to
other external components and required initial
setting modes.
Quick Overview
A Quick Overview presented in this guide will give you enough
information to start using the HDD & DVD RECORDER.
Connecting the HDD & DVD RECORDER
†
Additional connections
†
Antenna + HDD & DVD RECORDER +
External decoder box + TV
†
Other type of connecting the Video
output cable
†
Other type of connecting the Audio
output cable
†
Connecting to AV 3 IN, DV input jack
Quick Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Connecting the HDD & DVD RECORDER . . . . . .19
Additional connections . . . . . . . . . . . . . . . . . . . . . .19
Antenna + HDD & DVD RECORDER +
External decoder box + TV . . . . . . . . . . . . . . . . . .20
Other type of connecting the Video output cable . .20
Other type of connecting the Audio output cable . .22
Connecting to AV 3 IN, DV input jack . . . . . . . . . .24
- English
Downloaded From18
DvDPlayer-Manual.com
Samsung Manuals
Additional connections
You can connect your HDD & DVD RECORDER to the
television using the SCART cable if the appropriate
input is available on the television.
1. Connect the RF cable as shown.
2. Connect one end of the SCART cable to the AV1
socket on the rear of the HDD & DVD RECORDER.
3. Plug the other end into the appropriate connector on
the television.
4. Plug in the HDD & DVD RECORDER and TV
5. Turn on the HDD & DVD RECORDER and TV.
6. Press the INPUT button on your TV remote control
until the Video signal from the HDD & DVD
RECORDER appears on the TV screen.
You can connect your HDD & DVD RECORDER to a
satellite or digital tuner.
1
external device
(VCR/Satellite receiver)
2
To RF IN
2
1
To TV
3
RF Cable
To ANT INPUT
■
NOTE
■
The RF cable connection of this product
sends only signals of TV. You must connect
SCART cable or Audio/Video cables to watch
a DVD from your HDD & DVD RECORDER.
TV mode Press the TV/DVD button on remote
control, then “TV” appear on Front LED
display (or turn off HDD & DVD RECORDER).
Then you can watch programmes received
through RF cable.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
- DVD mode
1. Connect the AV2 connector of HDD & DVD
RECORDER and VCR/Satellite receiver or digital
tuner using a SCART cable.
2. Connect the AV1 connector to the SCART AV
connector on TV.
3. Turn on the HDD & DVD RECORDER,
VCR/Satellite receiver or digital tuner and TV.
4. Set Input mode on AV2.
- TV mode
1. Press the TV/DVD button on remote control,then
“TV” appear on Front LED display. (or turn off
HDD & DVD RECORDER.)
2. You can watch programmes from a satellite or
digital tuner connected to this HDD & DVD
RECORDER, even when the HDD & DVD
RECORDER is turned off.
English - 19
Connecting & Setting Up
Connecting the
HDD & DVD RECORDER
Connecting & Setting Up
Antenna + HDD & DVD
RECORDER + External
decoder box + TV
If you connect external decoder box to HDD & DVD
RECORDER, you can record scrambled channels
(CANAL+or Premiere broadcasts) received through
the built-in TV tuner in HDD & DVD RECORDER.
Other type of connecting
the Video output cable
There are several ways to output video signal not
using scart cables. Select one of the following video
connecting that best suits you below.
• Case 1 : Connecting to a Video (Composite) output
jack
• Case 2 : Connecting to an S-Video output jack
• Case 3 : Component Video output jacks
S-Video, Component video and Progressive
Output Modes
Wall
1
3
DECODER
4
2
1. Connect RF antenna cables as shown.
2. Connect the AV1 connector on this recorder to the
SCART AV connector on TV using a SCART
cable.
3. Connect the AV2 connector to a SCART AV
connector on decoder box.
4. To watch or record PAY-TV Canal Plus
programmes, set your HDD & DVD RECORDER
to receive the channels using the on-screen
display.(Refer to page 30)
- English
Downloaded From20
DvDPlayer-Manual.com
Samsung Manuals
• S-Video and Component video output are available
only if your TV supports S-Video input or
Component video input, respectively. If S-Video or
Component video output does not work, check the
TV connections and the TV input selection settings.
• Compared to standard interlaced video,
progressive scan doubles the amount of video lines
fed to your TV, resulting in a more stable, flickerfree, clear image than interlaced video.
This is only available with TVs that support
progressive scan.
• Progressive Scan Output (576p)
Consumers should note that not all high definition
television sets are fully compatible with this product
and may cause artifacts to be displayed in the
picture, in case of 576 progressive scan picture
problems, It is recommended that the user switch
the connection to the ‘standard definition’ output. If
there are questions regarding our TV set
compatibility with this model 576p HDD & DVD
RECORDER, please contact our customer service
centre.
Case 1 : Connecting to a Video
(Composite) output jack
Case 2 : Connecting to an S-Video
output jack
1. Connect an S-Video cable (not included) between
the S-VIDEO OUT jack on HDD & DVD
RECORDER and S-VIDEO INPUT jack on your TV
(or AV amplifier).
• You will enjoy high quality images.
2. Connect audio cables (white and red) between the
AUDIO OUT jacks on the HDD & DVD RECORDER
and AUDIO IN jacks on TV (or AV amplifier).
(See pages 22~23)
2. Connect audio cables (white and red) between the
AUDIO OUT jacks on HDD & DVD RECORDER
and AUDIO IN jacks on TV (or AV amplifier).
(See pages 22~23)
yellow
Video/Audio Cable
yellow
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 21
Connecting & Setting Up
1. Connect a video(yellow) cable between the
VIDEO (yellow) OUT jack on HDD & DVD
RECORDER and VIDEO (yellow) INPUT jack on
your TV (or AV amplifier).
• You will enjoy regular quality images.
Case 3 : Component Video output
jacks
1. Connect Component video cables(not supplied)
between the COMPONENT OUT(Y,PB,PR) jacks on
HDD & DVD RECORDER and COMPONENT
IN(Y,PB,PR) jacks on your TV.
Connecting & Setting Up
• You will enjoy high quality and accurate colour
reproduction images.
2. Connect audio cables (white and red) between the
AUDIO OUT jacks on the HDD & DVD
RECORDER and AUDIO IN jacks on TV (or AV
amplifier).
(See pages 22~23).
Other type of connecting
the Audio output cable
There are several ways to output audio signal not
using scart cables. Select the audio connection that
best suits you below.
• Case 1 : Connecting to your TV
• Case 2 : Connecting to a stereo amplifier with AV
output jacks
• Case 3 : Connecting to an AV amplifier with a
digital output jack
3. After connecting, refer to the pages 41~43.
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
“DTS” and “DTS Digital Out” are trademarks of
Digital Theater Systems, Inc.
green
blue
red
green
Case 1 : Connecting to your TV
If your TV has audio input jacks, use this connection.
blue
red
- English
Downloaded From22
DvDPlayer-Manual.com
Samsung Manuals
white
red
yellow
Progressive setting is only available when
the Video Out is set to Component. (See
pages 41~43)
yellow
white
■
Make sure that the colour coded
connections match. The Y, PB, PR
component output jacks of your HDD &
DVD RECORDER must be connected to
the exact corresponding component input
jacks on your TV.
red
■
NOTE
Case 2 : Connecting to a stereo
amplifier with AV output jacks
Case 3: Connecting to an AV
amplifier with a digital output jack
If your stereo amplifier only has AUDIO INPUT
jacks(L and R), use the AUDIO OUT jacks.
If your AV amplifier has a Dolby Digital, MPEG2 or
DTS decoder and a digital input jack, use this
connection. To enjoy Dolby Digital, MPEG2 or
DTS sound, you will need to set up the audio
settings.
(See page 39)
Connecting & Setting Up
red
white
or
red
white
Rear(L)
Front(L)
speaker
Rear(R)
Front(R)
speaker
Front(L)
Front(R)
Subwoofer
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Centre
English - 23
Connecting & Setting Up
Connecting to AV 3 IN,
DV input jack
Case 2 : Connecting a Camcorder to
the DV IN jack
If your digital camcorder has a DV output jack,
connect it to the DV input jack of your HDD & DVD
RECORDER.
This allows you to connect your HDD & DVD
RECORDER to other external devices and view or
record their outputs.
• Case 1 : Connecting a VCR, Set-Top Box(STB), DVD
player or Camcorder to the AV3 IN jacks
• Case2 : Connecting a DV Device to the DV IN jack
Camcorder
Case 1 : Connecting a VCR, Set-Top
Box(STB), DVD player or Camcorder
to the AV3 IN jacks
Connecting a VCR or external device to AV3 IN
jacks of the HDD & DVD RECORDER.
You can record from connected equipment (VCR,
STB, DVD player or Camcorder).
■
NOTE
Camcorder
VCR
red
white
yellow
STB
DVD
yellow
white
red
■
AV 3 in selection will be automatically
done. If the input is not selected
automatically, use INPUT button to select
proper input.
■
Copy protected content cannot be
recorded.
NOTE
- English
Downloaded From24
DvDPlayer-Manual.com
Samsung Manuals
If the input is not selected automatically,
use INPUT button to select proper input.
System Setup
On-Screen Menu
Navigation
The on-screen menus allow you to enable or disable
various functions on your HDD & DVD RECORDER.
Use the following buttons to open and navigate
through the on-screen menus.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
MOVE
On-Screen Menu Navigation . . . . . . . . . . . . . . . . .25
SELECT
1
MENU Button
2
…†, œ √ Buttons
3
OK Button
4
RETURN Button
Plug & Auto Setup . . . . . . . . . . . . . . . . . . . . . . . . .26
RETURN
EXIT
Press this button on the remote control to open
the on-screen menu.
Press again to exit the on-screen menu.
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . .27
Presetting Channels with the Auto Setup
function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Presetting Channels with the Manual Setup
function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Press these buttons on remote control to move
the selection bar …†, œ √ to cycle through the
menu options.
Setting up the Language Options . . . . . . . . . . . . .31
Auto Power Off Setting . . . . . . . . . . . . . . . . . . . . .32
CM Skip Time Setting . . . . . . . . . . . . . . . . . . . . . .33
Press this button on the remote control to confirm any
new settings.
EP Mode Time Setting . . . . . . . . . . . . . . . . . . . . .34
Setting up the Front Display Options . . . . . . . . . . .35
Automatic Chapter Creator . . . . . . . . . . . . . . . . . .36
Setting up NICAM Options . . . . . . . . . . . . . . . . . .37
Press this button on the remote control to return to
the Previous menu screen displayed or to exit the
on-screen menu.
DivX(R) Registration . . . . . . . . . . . . . . . . . . . . . . .38
Setting up the Audio Options . . . . . . . . . . . . . . . . .38
Setting up the Video display Options . . . . . . . . . . .40
Setting up Video Output Options . . . . . . . . . . . . . .41
Setting up the Progressive scan . . . . . . . . . . . . . .42
Canceling the Progressive scan . . . . . . . . . . . . . .43
Setting up the Parental Control . . . . . . . . . . . . . . .44
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 25
System Setup
Setup
Plug & Auto Setup
5
Select “Country” using the …† œ √ buttons to
select your country.
Country Selection
Your HDD & DVD RECORDER will automatically set itself up
when it is plugged in for the first time. TV stations and clock
will be stored in memory. The process takes a few
minutes. Your HDD & DVD RECORDER will then be ready for
use.
A
NL
S
PL
B
I
CH
CZ
Others
DK
N
TR
FIN
P
GR
D
E
HU
• Refer to following abbreviation table when selecting “Country”.
System Setup
1
2
Connect the RF cable as indicated on page 19.
(Connecting Your HDD & DVD RECORDER to the
TV Using the RF Cable and scart cable.)
Plug the HDD & DVD RECORDER into the mains.
“AUTO” in the front panel display flickers.
A(Austria)
NL(Netherlands) S(Sweden)
PL(Poland)
B(Belgium)
I(Italy)
CH(Swiss)
CZ (Czech)
DK(Denmark)
FIN(Finland)
N(Norway)
P(Portugal)
TR(Turkey) Others
GR(Greece)
D(Deutschland) E(Spain)
HU(Hungary)
• The HDD & DVD RECORDER searches for the stations according
to a preset preference list corresponding to the country that you
have selected.
3
Press a number button to select the language.
6
Auto channel scan will be started.
Channel Scan
Scanning...
Press
Touche
Drücken Sie
Pulse
Premere
Druk op
1
2
3
4
5
6
for English
pour Français
Für Deutsch
para Español
per Italiano
voor Nederlands
10%
• The number of stations automatically stored by the
4
Press the OK button to start the auto setup.
HDD & DVD RECORDER depends on the number of
stations that it has found.
7
Auto setup will be started.
Check antenna and TV cable connection.
Yes
After auto channel scan is completed, auto clock
setting will be started automatically in 10 seconds.
If you want to start auto clock setting immediately,
press OK button. If you do not want to do auto
clock setting, press CANCEL or MENU button.
No
Auto channel scan completed successfully.
Press the [OK] button to auto clock set.
Yes
- English
Downloaded From26
DvDPlayer-Manual.com
Samsung Manuals
No
8
Wait until current date and time are displayed
automatically. If you want to exit auto clock setting,
press MENU button.
Please wait. Now setting the clock.
Setting the Clock
This menu is used to set the current time.
You need to set the time to use timer recording.
If you want to exit clock setting,
press the [MENU] button.
1
9
With the unit in Stop mode, press the MENU
button.
Title
Check the date and time.
HDD
Title
√
Title List
Music
Time
12 : 00
Date
01 / JAN SAT
Setup
Auto clock
2005
MOVE
On
• if it is : Correct, press OK button then the date
and time will be saved. If you don't press the OK
button, the date and time will be saved
automatically after 5 seconds.
2
SELECT
RETURN
EXIT
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
HDD
Title
• if it is : Incorrect, input correct Time, Date, Year
using …†œ √ buttons or number buttons.
Press OK button then the date and time will be
saved. When you need to change clock setting,
you can set up it manually.
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
■
NOTE
■
Now, HDD & DVD RECORDER is ready
for use. Function for “Plug & Auto Setup”
is fixed already. So if you want to change
this fixed one, you can change it by
Presetting the Stations in OSD
“Presetting Channels with the Manual
setup function” menu. (See page 30)
Auto setup function can be performed by
pressing STOP ( ) on the unit
continuously for 5 seconds or more
during power off with no disc inserted.
3
SELECT
RETURN
EXIT
Press the …† buttons to select Clock Set, then
press the OK or √ button.
Press the …†œ √ buttons to input Time, Date or
Year. Press the number buttons to input clock
data directly.
The day of the week is displayed automatically.
Clock Set
HDD
Title
Music
Time
Date
12 : 00
Auto Clock
01 / JAN SAT 2005
On
Programme
Setup
0~9 NUMBER
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
English - 27
System Setup
Programme
4
Press the …† buttons to select On for the Auto
Clock.
Presetting Channels with
the Auto Setup function
Clock Set
HDD
Title
Music
Time
Date
12 : 00
Auto Clock
01 / JAN SAT 2005
On
Programme
This feature allows you to manually set the HDD & DVD
RECORDER tuner band to Antenna or Cable,
whichever you connected to the Antenna In jack during
initial setup.
Setup
0~9 NUMBER
System Setup
5
SELECT
RETURN
EXIT
Press the OK button, then the date and time will
be saved. If you don’t press the OK button, it will
not be saved.
1
2
With the unit in Stop mode, press the MENU
button.
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
HDD
■
NOTE
■
You must have the RF cable connected
to set the Auto Clock. (See page 19)
Title
Music
The HDD & DVD RECORDER
automatically sets the clock according to
the time signal broadcast between the
channels PR1 to PR5. If you do not need
the auto clock set function, select Off.
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
EXIT
Press the …† buttons to select Install, then press
the OK or √ button.
Install
HDD
Title
Auto Setup
√
Manual Setup
√
Music
Programme
Setup
MOVE
- English
Downloaded From28
DvDPlayer-Manual.com
Samsung Manuals
SELECT
RETURN
EXIT
4
• The first frequency band is scanned and the first
station found is displayed and stored. And the
HDD & DVD RECORDER searches for the
second station and so on.
• When the automatic scanning procedure has
finished, the HDD & DVD RECORDER switches
automatically to programme 1.
• The number of stations automatically stored by
the HDD & DVD RECORDER depends on the
number of stations that it has found.
Press the …† buttons to select Auto Setup, then
press the OK or √ button.
The message “Your data will be lost. Press [OK]
to continue, [Return] to exit.” is displayed.
Install
HDD
Title
Music
Your data will be lost.
PhotoPress [OK] to continue, [Return] to exit.
OK
Programme
Setup
SELECT
5
RETURN
7
EXIT
Channel scan will be started. Press the OK button
to stop the Auto Setup.
System Setup
Press the OK button, then press the …†œ √
buttons to select your Country.
• The HDD & DVD RECORDER searches for the
stations according to a preset preference list
corresponding to the country that you have
selected.
Install
HDD
Country Selection
Title
A
Music
B
NL
S
PL
I
CH
CZ
Others
DK
N
TR
FIN
P
GR
E
HU
Programme
D
Setup
MOVE
SELECT
RETURN
EXIT
Refer to following table when selecting your
country.
A(Austria)
B(Belgium)
DK(Denmark)
FIN(Finland)
NL(Netherlands)
I(Italy)
N(Norway)
P(Portugal)
S(Sweden)
CH(Swiss)
TR(Turkey)
GR(Greece)
D(Deutschland)
E(Spain)
HU(Hungary)
6
PL(Poland)
CZ (Czech)
Others
Press the OK button. If you want to exit, press the
MENU button.
Auto Setup
HDD
Title
Please wait.
Music
11%
Scanning...
Stop
Programme
Setup
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 29
Presetting Channels with
the Manual Setup function
You can add preset channel that Auto Channel Search
missed. And you can delete a channel you wish to
remove. You can programme the order of channels.
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
System Setup
1
Setup
5
Press the …† buttons to select a PR(programme)
you wish to edit, delete, or swap, then press the
ANYKEY button.
Select Edit, Delete or Swap.
Manual Setup
PR
01
02
03
04
Edit05
06
Delete
07
Swap
CH
---------------
MOVE
Name
----------------------
SELECT
Decoder
--------
RETURN
EXIT
• In case of Edit : You can add or edit
PR(programme) information. After change PR
informations(CH, Name, Decoder, MFT), select
Save, then press the OK button.
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
SELECT
RETURN
Manual Setup
PR
CH
Name
Decoder
MFT
EXIT
Save
MOVE
3
SELECT
Press the …† buttons to select Install, then
press the OK or √ button.
Install
HDD
Title
Auto Setup
√
Manual Setup
√
Music
Programme
Setup
MOVE
4
01
02
---Off
--- ---
SELECT
RETURN
EXIT
Press the …† buttons to select Manual Setup,
then press the OK or √ button.
CH
---------------
MOVE
Name
----------------------
SELECT
Decoder
--------
RETURN
• In case of Delete : the channel information of
selected PR(programme) will be removed.
• In case of Swap : You can swap the channel
information of two PR(programme). For example,
if you wish to swap PR2 and PR5, select swap at
PR2, then press the OK button at PR5.
Manual Setup
PR
01
02
03
04
05
06
07
- CH : Tune the channel using œ √ buttons.
- Name : Display station name automatically detected
in broadcasting signal. If not detected, you
can edit name by using …†œ √ buttons.
- Decoder : If you set on, you can record scrambled
channels using external decoder box.
Before setting on, refer to connecting
external decoder box in the page 20.
- MFT(Manual Frequency Tunning) : You can tune
up the channel frequency better using œ √ buttons.
EXIT
- English
Downloaded From30
DvDPlayer-Manual.com
Samsung Manuals
Setting up the Language
Options
4
Press the …† buttons to select the desired
language option, press the OK or √ button.
Language
HDD
Audio
Title
Subtitle
If you set the audio, subtitle, disc menu and on-screen
menu, in advance, they will come up automatically
every time you watch a movie.
If the selected language is not recorded on the disc, the
original pre-recorded language is selected.
Music
Français
Disc Menu
: English
On-Screen menu Deutsch
: English
Español
2
Press the …† buttons to select Setup,
then press the OK or √ button.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
SELECT
RETURN
5
Korean
SELECT
RETURN
EXIT
Press the …† buttons to select the desired
language, then press the OK or √ button.
■
Press the RETURN or œ button to return
to the previous menu. Press the MENU
button to exit the menu.
■
The selected language will only appear if
it is supported on the disc.
NOTE
3
√
• Audio : For the disc audio language.
• Subtitle : For the disc subtitles.
• Disc Menu: For the disc menu contained on the
disc
• On-Screen menu: For the on-screen menu of your
HDD & DVD RECORDER.
EXIT
Press the …† buttons to select Language,
then press the OK or √ button.
Language setup menu will be displayed.
√
Nederlands
Setup
Setup
MOVE
√
Language
HDD
Title
Music
Audio
: Original
√
Subtitle
: Automatic
√
Disc Menu
: English
√
On-Screen menu
: English
√
Programme
Setup
MOVE
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 31
System Setup
With the unit in Stop mode, press the MENU
button.
√
Italiano
Programme
MOVE
1
Original
: Original
English
: Automatic
Auto Power Off Setting
5
Press the …† buttons to select the desired item,
then press the OK or √ button.
• Off : Auto power off is disabled.
This feature automatically turns off your HDD & DVD
RECORDER, if you do not press any button for the
selected time.
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
System Setup
1
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
EXIT
Press the …† buttons to select System,
then press the OK or √ button.
System menu will be displayed.
System
HDD
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
√
DivX(R) Registration
Setup
MOVE
4
SELECT
RETURN
EXIT
Press the …† buttons to select Auto Power Off,
then press the OK or √ button.
System
HDD
Title
Music
Programme
Auto Power Off : Off
Off
CM Skip Time : 152 Sec
Hour
√
EP Mode Time
: 6 6Hour
Hour
√
Front Display
: Auto Dim
√
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
SELECT
RETURN
EXIT
- English
Downloaded From32
DvDPlayer-Manual.com
Samsung Manuals
• 2 Hour : DVD-HDD Receiver will automatically
turn off for 2 hours after the last button
is pressed.
• 6 Hour : DVD-HDD Receiver will automatically
turn off for 6 hours after the last button
is pressed.
• If the turn off time set with the Auto Power off
function is reached during playback or recording,
the device will operate until the playback or
recording is finished.
CM Skip Time Setting
4
Press the …† buttons to select CM Skip Time,
then press the OK or √ button.
System
HDD
Title
Music
When a programme recorded on a HDD, a DVD-RAM, a
DVD-RW, or a DVD-R is played, the unit can be set to
automatically skip a portion of the programme
corresponding to a CM(commercial) skip time set by the
user.
Auto Power Off : Off
√
CM Skip Time
: 1515Sec
Sec
√
EP Mode Time
: 6 30
Hour
Sec
√
: Auto
Dim
60 Sec
Chapter Creator : Off
√
NICAM
√
Front Display
Programme
: On
DivX(R) Registration
√
√
Setup
MOVE
SELECT
RETURN
EXIT
With the unit in Stop mode, press the MENU
button.
5
Press the …† buttons to select the desired time
interval, then press the OK or √ button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
6
If you press the CM SKIP button during playback,
the section corresponding to the set time is
skipped, and then the next section is played.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
■
CM Skip can be performed only during
normal playback.
■
When the time set is more than a
remaining time of a current title: The next
title is played from the beginning.
■
When the time set is more than a
remaining time of a play list, the next
scene is played.
■
CM Skip does not work in still picture
mode.
■
When a set time is greater than the
remaining time of a scene, last title, or
last track that is currently displayed, a
prohibition mark appears.
■
CM Skip releases Repeat (including
Repeat A-B, Chapter, and Title).
■
CM Skip may not operate with some
DVD-Video discs.
NOTE
EXIT
Press the …† buttons to select System, then
press the OK or √ button.
System menu will be displayed.
System
HDD
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 33
System Setup
1
EP Mode Time Setting
4
Press the …† buttons to select EP Mode Time,
then press the OK or √ button.
System
HDD
Title
You can select one of four recording modes by pressing
the REC MODE button repeatedly.
EP mode is one of four REC Mode (XP, SP, LP, EP).
In EP(Extended Play) mode, you can set recording time
to 6 or 8 hours with this setting.
Music
System Setup
1
2
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
EXIT
Press the …† buttons to select System, then
press the OK or √ button.
System menu will be displayed.
System
HDD
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
SELECT
RETURN
EXIT
- English
Downloaded From34
DvDPlayer-Manual.com
Samsung Manuals
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 6Hour
Hour
√
: Auto
Dim
8 Hour
Chapter Creator : Off
√
NICAM
√
Front Display
Programme
: On
DivX(R) Registration
√
√
Setup
MOVE
With the unit in Stop mode, press the MENU
button.
Auto Power Off : Off
5
SELECT
RETURN
EXIT
Press the …† buttons to select the desired Time,
then press the OK or √ button.
Setting up the Front
Display Options
4
Press the …† buttons to select Front Display,
then press the OK or √ button.
System
HDD
Title
Music
Adjust the brightness of the unit’s front panel display.
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto
Dim
Bright
√
Chapter Creator : Off
Dim
√
NICAM
√
: On
Auto Dim
DivX(R) Registration
√
Setup
MOVE
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
RETURN
EXIT
Press the …† buttons to select the desired item,
then press the OK or √ button.
• Bright : Makes the Front Panel Display bright.
• Dim : Makes the Front Panel Display dim.
• Auto Dim : Makes the Front Panel Display dim
automatically when the set is
powered off.
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
EXIT
Press the …† buttons to select System, then
press the OK or √ button.
System menu will be displayed.
System
HDD
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 35
System Setup
Setup
5
SELECT
Automatic Chapter
Creator
4
Press the …† buttons to select Chapter Creator,
then press the OK or √ button.
System
DVD-RW(V)
Title
A DVD-Video consists of ‘Titles’ and ‘Chapters’.
When you record one programme, it makes one Title.
If you use this function, the Title will be divided into
Chapters.
Music
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
Off
√
NICAM
√
: On
On
DivX(R) Registration
Programme
√
Setup
MOVE
SELECT
RETURN
EXIT
System Setup
(V mode)
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
5
• Off: Select if you do not want use Automatic
Chapter Creator.
• On: Select this option to use the Automatic
Chapter Creator feature.
Setup
Press the MENU button to exit the menu.
DVD-RW(V)
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
6
Setup
MOVE
3
SELECT
RETURN
Press the …† buttons to select On or Off, then
press the OK or √ button.
EXIT
Press the …† buttons to select System, then
press the OK or √ button.
System menu will be displayed.
Press the REC button to start recording. (See
page 81 about how to set recording speed) The
message “Do you want to create the chapter
menu after this recording?” is displayed.
Do you want to create the chapter menu
after this recording?
Yes
No
System
DVD-RW(V)
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
SELECT
RETURN
EXIT
- English
Downloaded From36
DvDPlayer-Manual.com
Samsung Manuals
7
Press the œ √ buttons to select Yes and press
the OK button.
• A new chapter is created according to the selected
recording mode. A chapter will be about 5 minutes
long in XP and SP, and about 15 minutes long in LP
and EP mode.
8
Press the STOP button to stop recording.
9
To display the created titles, finalise the disc
(See page 124) and then press the TITLE MENU
button. The title menu will be displayed.
Previous
NICAM programmes are divided into 3 types. NICAM
Stereo, NICAM Mono and Bilingual (transmission in
another language). NICAM programmes are always
accompanied by a standard mono sound broadcast and
you can select the desired sound by setting NICAM on
or off.
Next
To display the created chapters, select the
desired Title and then press the DISC MENU
button. The chapter menu for the selected Title
will be displayed.
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
CHAPTER
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
Previous
Top
The Automatic Chapter Creator function does
Caution
SELECT
RETURN
EXIT
Next
not work during Timer Recording or when you
turn the power off.
3
Press the …† buttons to select System,
then press the OK or √ button.
System menu will be displayed.
System
HDD
Title
Music
Programme
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
Front Display
: Auto Dim
√
Chapter Creator : Off
√
NICAM
√
: On
DivX(R) Registration
√
Setup
MOVE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
English - 37
System Setup
10
Top
Setting up NICAM
Options
4
Press the …† buttons to select NICAM, then
press the OK or √ button.
Setting up the Audio
Options
System
HDD
Title
Music
Auto Power Off : Off
√
CM Skip Time
: 15 Sec
√
EP Mode Time
: 6 Hour
√
: Auto Dim
√
Front Display
Chapter Creator : Off
Programme
√
Off
: On
√
DivX(R) RegistrationOn
√
NICAM
You can connect the HDD & DVD RECORDER to an
external amp or Home theatre.
Allows you to setup the Audio device and sound status
depending on the audio system in use.
Setup
MOVE
System Setup
5
SELECT
RETURN
EXIT
Press the …† buttons to select Off or On, then
press the OK or √ button.
• Off: Only set at this position to record the
standard mono sound during a NICAM
broadcast if the stereo sound is distorted
due to inferior reception conditions.
• On: NICAM mode
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
DivX(R) Registration
3
SELECT
RETURN
EXIT
Press the …† buttons to select Audio, then press
the OK or √ button.
Audio setup menu will be displayed.
Audio
HDD
Please use the Registration code to register this HDD &
DVD RECORDER with the DivX(R) Video On Demand
format. For more information, visit www.divx.com/vod
Title
Music
: PCM
√
: Off
√
Dynamic Compression : On
√
V-Mode Compatibility
√
Digital Output
DTS
: Off
Programme
Setup
MOVE
RETURN
EXIT
4
Press the …† buttons to select the desired audio
option, then press the OK or √ button.
5
Press the …† buttons to select the desired item,
then press the OK or √ button.
■
NOTE
- English
Downloaded From38
DvDPlayer-Manual.com
Samsung Manuals
SELECT
Press the RETURN or œ button to return
to the previous menu.
Press the MENU button to exit the menu.
Digital Output
V-Mode Compatibility
1. PCM : Select this when your equipment is not
decode Dolby Digital compatible.
This feature is about the setup for selecting
audios when recording the NICAM STEREO
(Multi-audio) broadcasting on HDD. It does not
affect to the direct DVD recording of a
programme.
2. Bitstream : Outputs Dolby Digital (or MPEG-2)
audio as bitstream. Select this
when your AV receiver or AV
amplifier has a Dolby Digital (or
MPEG-2) Decoder.
■
NOTE
■
Digital output setting is equally applied to
both Dolby Digital and MPEG-2 audio.
LPCM sound track is always outputted as
PCM. It has no relation with Digital
Output setting.
Be sure to select the correct Digital
Output or you will hear no sound or a
loud noise.
1. Off : Both “DUAL L” and “DUAL R” of the multiaudio broadcasting are recorded on
HDD.Titles recorded on HDD under such
setup status cannot be copied to V mode
(DVD-RW/-R).
2. On : Either “DUAL L” or “DUAL R” of the multiaudio broadcasting is recorded on
HDD.Titles recorded on HDD under such
setup status can be copied to DVD-R or
DVD-RW (V mode). “DUAL L” and “DUAL
R” options can be selected from “Audio
Selection.”
Title
DTS
Music
Digital Output
: PCM
√
DTS
: Off
√
Dynamic Compression : On
√
V-Mode CompatibilityOff : Off
√
On
1. Off : Doesn’t output DTS signal. Select this
when your AV receiver or AV amplifier
does not have DTS decoder.
2. On : Outputs DTS Bitstream via digital output
when you play DTS track. Select this only
when your AV receiver (or AV amplifier)
have DTS decoder.
Programme
Setup
MOVE
SELECT
RETURN
EXIT
Audio
HDD
Title
Music
Digital Output
: PCM
√
DTS
: Off
√
Dynamic Compression : On
√
V-Mode Compatibility
: On
√
Audio Selection
: DUAL L √
Programme
■
NOTE
When DTS soundtrack is played, sound
does not output from AV Audio Output.
Setup
MOVE
SELECT
RETURN
EXIT
Dynamic Compression
This is only active when a Dolby Digital signal is
detected.
1. On : When Movie soundtracks are played at
low volume or from smaller speakers, the
system can apply appropriate
compression to make low-level content
more intelligible and prevent dramatic
passages from getting too loud.
2. Off : You can enjoy the movie with the
standard Dynamic Range.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 39
System Setup
Audio
HDD
Setting up the Video
display Options
Press the …† buttons to select the desired video
option, then press the OK or √ button.
4
Video
HDD
This function allows you to setup the TV screen
settings. This function depends on disc type. It may
not work for some disc types.
√
: 16:9
Wide Box
4:3 Letter
3D Noise Reduction : Off
4:3 Pan/Scan√
Title
TV Aspect
Music
Video Output
: Component
16:9 Wide √
Programme
Setup
System Setup
MOVE
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
RETURN
EXIT
Press the …† buttons to select the desired item,
then press the OK or √ button.
5
■
NOTE
Setup
SELECT
Press the RETURN or œ button to return
to the previous menu.
Press the MENU button to exit the menu.
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
3
SELECT
RETURN
Video
HDD
TV Aspect
: 4:3 Letter Box √
3D Noise Reduction : Off
Music
Video Output
√
: Component √
Programme
Setup
MOVE
SELECT
RETURN
Depending on the type of television you have,
you may want to adjust the screen setting.
(aspect ratio)
EXIT
Press the …† buttons to select Video, then press
the OK or √ button.
Video setup menu will be displayed.
Title
TV Aspect
EXIT
- English
Downloaded From40
DvDPlayer-Manual.com
Samsung Manuals
1. 4:3 Letter Box : Select when you want to see
the total 16:9 ratio screen
DVD supplies, even though
you have a TV with a 4:3 ratio
screen. Black bars will appear
at the top and bottom of the
screen.
2. 4:3 Pan/Scan : Select this for conventional
size TV when you want to see
the central portion of the 16:9
screen. (Extreme left and right
side of movie picture will be cut
off.)
3. 16:9 Wide : You can view the full 16:9 picture
on your widescreen TV.
3D Noise Reduction (motion
adaptive noise reduction)
3
Press the …† buttons to select Video, then
press the OK or √ button.
Video setup menu will be displayed.
Video
HDD
TV Aspect
Title
: 4:3 Letter Box √
Video Output
Video
√
3D Noise Reduction :Off
Off
Music
HDD
:On
Component √
TV Aspect
Title
: 4:3 Letter Box √
√
3D Noise Reduction : Off
Music
Programme
Video Output
√
: Component√
Setup
MOVE
SELECT
RETURN
Programme
EXIT
Setup
MOVE
SELECT
RETURN
EXIT
1. Off : Normal
2. On : Provides a clear picture through noise
reduction (for recording).
4
Press the …† buttons to select Video Output,
then press the OK or √ button.
Setting up Video Output
Options
TV Aspect
Title
: 4:3 Letter Box √
3D Noise Reduction : Off
Music
Video Output
√
√
:Component
Component√
RGB
Programme
Setup
MOVE
You can enjoy high quality image through RGB or
Component video connections. RGB video output is
available connecting scart jack(AV1) and component
video output is available connecting component(Y,PB,PR)
jack. Only one of these signals can be selected at one
time.
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
Setup
HDD
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Setup
MOVE
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
5
SELECT
RETURN
EXIT
Press the …† buttons to select the desired
item, then press the OK or √ button.
In Component mode, you can set video output to
Progressive(P.SCAN) or Interlace, see pages 42 to 43.
Available video output jacks are as follow.
Available Video Output Jack
Component mode
Setting mode
RGB Mode
Output jack
P.SCAN off mode (Interlace mode) P.SCAN on mode
Component Output
O
X
O
(Y, PB, PR)
(TV in progressive mode)
R, G, B
X
O
X
AV1 Scart
Composite
X
O
X
AV2 Scart Composite
O
O
X
O
O
Composite Video out
X
S-Video out
O
O
X
English - 41
System Setup
Video
HDD
Setting up the
Progressive scan
3
The message “Video Output Mode Progressive
Scan” will appear.
The video will now be Progressive Scan.
If your TV supports Progressive Scan, press the
P.SCAN button on the front of the HDD & DVD
RECORDER.
To view ‘Progressive scan mode’, first connect the
component cable.(See page 22)
Video Output Mode
Progressive Scan
Be sure the Component cables are connected properly.
System Setup
1
With the unit in Stop mode, press the P.SCAN button
on the front of the HDD & DVD RECORDER.
The message “Press [Yes] to confirm Progressive
scan mode. Otherwise, press [No]” will appear.
Press the œ √ buttons to select Yes, and then
press the OK button.
Press [Yes] to confirm Progressive scan mode.
Otherwise, press [No]
Yes
2
No
The message “Please, set your TV to Progressive
input. To deactivate, press [STOP] key.” will
appear. Press the OK button.
Please, set your TV to Progressive input,
To deactivate, press [STOP] key.
OK
- English
Downloaded From42
DvDPlayer-Manual.com
Samsung Manuals
■
If the P.SCAN button on the HDD & DVD
RECORDER’s front panel is pressed
during playback, the message “This
function is possible only on stop mode”
appears on the screen.
■
Progressive setting is only available when
the HDD & DVD RECORDER is in stop
mode.
NOTE
Canceling the
Progressive scan
1
With the unit in Stop mode, press the P.SCAN button
on the front of the HDD & DVD RECORDER.
The message “Press [Yes] to confirm Interlace
scan mode. Otherwise, press [No]” will appear.
Press the œ √ buttons to select Yes, and then
press the OK button.
■
NOTE
■
Do not press the P.SCAN button if you are
using a TV that does not support
Progressive mode as nothing will be
displayed on the screen.
If you press the P.SCAN button by mistake
when your TV does not support Progressive
mode, the mode will then need to be
released. To release the Progressive mode,
press the P.SCAN button on the front panel
3 times. The screen will recover after the
PS indicator on the front panel display
turns off.
Press [Yes] to confirm Interlace scan mode.
System Setup
Otherwise, press [No]
Yes
2
No
The message “Please, set your TV to Interlace
input. To deactivate, press [STOP] key.” will
appear. Press the OK button.
Please, set your TV to Interlace input,
To deactivate, press [STOP] key.
OK
3
The message “Video Output Mode Interlace Scan”
will appear.
Video Output Mode
Interlace Scan
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 43
Setting up the Parental
Control
Enter the 4-digit password using the number
buttons on the remote control.
The “Confirm the password” message will be
displayed. Enter your password again.
4
Parental Control
The Parental Control function works in conjunction with
DVDs that have been assigned a rating which helps you
control the types of DVDs that your family watches.
There are up to 8 rating levels on a disc.
HDD
Title
Confirm the password.
Music
Programme
Setup
System Setup
0~9 NUMBER
1
With the unit in Stop mode, press the MENU
button.
2
Press the …† buttons to select Setup, then press
the OK or √ button.
SELECT
RETURN
EXIT
Press the OK or √ button to select Password.
5
Parental Control
HDD
Password
Title
Setup
HDD
: Off
Off
√
On
Music
Title
Music
Programme
System
√
Clock Set
√
Language
√
Audio
√
Video
√
Parental Control
√
Install
√
Programme
Setup
MOVE
SELECT
RETURN
EXIT
Setup
MOVE
SELECT
RETURN
EXIT
Press the …† buttons to select On or Off, then
press the OK or √ button.
6
3
Press the …† buttons to select Parental Control,
then press the OK or √ button.
■
Parental Control
NOTE
HDD
Title
Press the RETURN or œ button to return
to the previous menu.
Press the MENU button to exit the menu.
Create the password.
Music
Programme
If you forgot your password
Setup
0~9 NUMBER
SELECT
RETURN
EXIT
- English
Downloaded From44
DvDPlayer-Manual.com
Samsung Manuals
1
Remove the disc.
2
Press and hold the SEARCH/SKIP ( ) button on
the front panel for 5 seconds or more.
Setting the Rating Level
1
Changing the Password
Press the …† buttons to select Rating Level,
then press the OK or √ button.
1
Press the …† buttons to select Change Password,
then press the OK or √ button.
Parental Control
HDD
Parental Control
Title
Music
Password
: On
√
Rating Level
: Level1 - Kids
√
HDD
Title
√
Change Password
Music
Programme
Password
: On
√
Rating Level
: Level1 - Kids
√
√
Change Password
Programme
Setup
MOVE
SELECT
RETURN
Setup
EXIT
MOVE
SELECT
RETURN
EXIT
Parental Control
HDD
Change Password
Title
Level8 - Adults√
: On
Rating Level
Level7
√
: Level
8 (Adults)√
Change Password
Level6
HDD
Title
√
Level5
Level3
Programme
Enter the password.
Music
Level4
Level2
Setup
Programme
Level1 - Kids
MOVE
SELECT
RETURN
EXIT
Setup
0~9 NUMBER
2
Press the …† buttons to select the rating level
you want, then press the OK or √ button.
3
When you operate your HDD & DVD RECORDER
for the first time, the “Create the Password”
message will be displayed.
For example, if you select up to Level 6, discs that
contain Level 7, 8 will not play. A larger number
indicates that the programme is intended for adult
use only.
2
SELECT
RETURN
EXIT
Enter the 4-digit password using the number
buttons on the remote control.
The “Confirm the password” message will be displayed.
Change Password
HDD
Title
Confirm the password.
Music
Programme
Setup
0~9 NUMBER
3
SELECT
RETURN
EXIT
Enter your password again using the number
buttons on the remote control.
■
See page 44 if you forgot your password.
NOTE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 45
System Setup
Music
Password
Before Playing
Playback
Read the following information before playing a disc.
This section introduces basic functions of
playback and playback by disc type.
Dolby Digital
DTS
Region code (DVD-Video only)
Both the HDD & DVD RECORDER and the discs are coded
by region. These regional codes must match in order for the
disc to play. If the codes do not match, the disc will not play.
The Region Number for this HDD & DVD RECORDER is
described on the rear panel of the HDD & DVD RECORDER.
Digital Audio
Disc types that can be played
Stereo
PAL broadcast
system in U.K, France,
Germany, etc.
MP3
Playback
DivX
Disc Types
Disc Logo Recorded content
DVD-VIDEO
AUDIO + VIDEO
AUDIO-CD
AUDIO
DVD-RAM
AUDIO + VIDEO
DVD-RW
AUDIO + VIDEO
DVD-R
AUDIO + VIDEO
Before Playing.....................................................................46
Playing a Disc......................................................................47
Using the Disc Menu & Title Menu ....................................48
Using the Search & Skip Functions...................................48
Slow Motion Play/Step Motion Play...................................49
About ANYKEY ...................................................................50
Playing the Title List ............................................................52
Navigation menu .................................................................53
Using Markers .....................................................................56
CD-RW/-R
DVD-RAM/
-RW/-R
JPEG
MP3
MPEG4
DVDHR710
Selecting the Soundtracks & Audio channels ...................61
Changing the Camera Angle..............................................62
AUDIO + VIDEO
Approx. 38 (XP: Excellent Quality)
Approx. 72 (SP: Standard Quality)
Approx. 138 (LP: Long Playback)
Approx. 205 or Approx. 272
(EP:Extended)
HDD
Select Media........................................................................65
Playing an Audio CD/MP3..................................................65
Viewing a Picture ................................................................72
Playing an MPEG4 .............................................................75
Downloaded From46
DvDPlayer-Manual.com
Samsung Manuals
- English
DVDHR721
-
AUDIO + VIDEO
Repeat Play.........................................................................62
Zooming-In ..........................................................................64
-
Approx. 18 (XP: Excellent Quality)
Approx. 34 (SP: Standard Quality)
Approx. 65 (LP: Long Playback)
Approx. 96 or Approx. 127
(EP:Extended)
Using the Bookmarks .........................................................58
Selecting the Subtitle Language ........................................60
Disc Shape Max. Playing Time
Single sided(12cm)
240
Double sided(12cm)
480
Single sided(8cm)
80
Double sided(8cm)
160
Single sided(12cm)
74
Single sided(8cm)
20
1 (XP: Excellent Quality)
Single-sided 2 (SP: Standard Quality)
12cm (4.7GB) 4 (LP: Long Playback)
6 or 8 (EP:Extended)
2 (XP: Excellent Quality)
Double-sided 4 (SP: Standard Quality)
12cm (9.4GB) 8 (LP: Long Playback)
12 or 16 (EP:Extended)
1 (XP: Excellent Quality)
2 (SP: Standard Quality)
12cm (4.7GB)
4 (LP: Long Playback)
6 or 8 (EP:Extended)
1 (XP: Excellent Quality)
2 (SP: Standard Quality)
12cm (4.7GB)
4 (LP: Long Playback)
6 or 8 (EP:Extended)
Discs that cannot be played
•
•
•
•
DVD-Video with a region number other than “2” or “ALL”
12cm 2.6 GB and 5.2 GB DVD-RAM
3.9 GB DVD-R Disc for Authoring.
DVD-RAM/-RW(VR mode) not recorded following the Video
Recording Standard
• Unfinalised DVD-R,unfinalised DVD-RW(V mode) recorded on
other equipment.
• DVD-ROM/DVD+RW/PD/MV-Disc, etc
• CVD/CD-ROM/CDV/CD-G/CD-I
■
NOTE
■
■
■
■
1
Press the OPEN/CLOSE button.
2
Place a disc gently into the tray with the disc’s
label facing up.
3
Press the OPEN/CLOSE button to close the disc tray.
• Your HDD & DVD RECORDER closes the disc
This HDD & DVD RECORDER can only operate
with discs that are compatible with DVD-RAM
Standard Version 2.0.
Playback and/or recording may not work for
some types of discs, or when specific
operations, such as angle change and aspect
ratio adjustment, are being performed.
Information about the discs is written in detail
on the box. Please refer to this if necessary.
Do not allow the disc to become dirty or scratched,
finger prints, dirt, dust, scratches or deposits of
cigarette smoke on the recording surface may
make it impossible to use the disc for recording.
DVD-RAM/-RW/-R discs may not be able to
play on some DVD players, depending on the
player, disc and the condition of the recording.
Discs with NTSC programmes recorded on
them cannot be recorded using this product.
tray and plays the disc automatically.
• The HDD & DVD RECORDER does not play
•
•
•
•
•
Playing a Disc
Press the STOP(
■
When you stop playing back a disc, the HDD & DVD
RECORDER remembers where you stopped, so
when you press PLAY( ) button again, it will pick
up where you left off. (Unless the disc is removed or
the HDD & DVD RECORDER is unplugged, or if you
press the STOP( ) button twice.)
■
Do not move your HDD & DVD RECORDER
while playing, as this may cause damage to
the disc.
Make sure to press the OPEN/CLOSE
button to open or close the disc tray.
Do not push the disc tray while it is being
opened or closed, as this may cause a
product malfunction.
Do not place foreign materials on or in the
disc tray.
Some functions may perform differently or
be disabled depending on the disc type.
If this occurs, refer to the instructions
written on the disc case.
Be especially careful that children's fingers
are not caught between the disc tray and
the tray chassis when it closes.
You must only insert one DVD disc at a
time. Inserting two or more discs will not
allow playback and may cause damage to
the HDD & DVD RECORDER.
NOTE
Caution
■
■
■
■
■
■
Downloaded From DvDPlayer-Manual.com Samsung Manuals
) button to stop playback.
English - 47
Playback
4
discs automatically after the initial power on.
When the HDD & DVD RECORDER is powered
on and a disc is in the tray, the unit will be
activated and wait in stop status.
Press the PLAY( ) button to start playback.
If you insert an MP3 Disc, your HDD & DVD
RECORDER will display the file list on the
screen and start playing.
If you insert a JPEG Disc, folders and files is
displayed in the thumbnail picture.
If you want the unit to play automatically when it
is powered on with a disc in the unit, power on
with the PLAY( ) button.
Using the Disc Menu &
Title Menu
Using the Search & Skip
Functions
Searching through a Chapter or
Track
Some type of discs contain a dedicated menu system that
allows you to select special functions for title, chapter, audio
track, subtitle, film preview, information on characters, etc.
For DVD-VIDEO Disc
Press the DISC MENU button to enter the disc menu
of the disc.
1
• Move to the setup menu related to playback
operation.
• You can select audio language and subtitle etc.
provided by the disc.
Press the TITLE MENU button to move to the title
menu of the disc.
• Press this button if the disc contains more than one
title. Some discs may not support the title menu
functionality.
Playback
2
1
During play, press the SEARCH (
the remote control.
HDD/
DVD-VIDEO/
DVD-RAM/-RW/-R
Fast X 2 ➞
Fast X 8 ➞
Fast X 32 ➞
MPEG4
AUDIO CD
(CD-DA)
X2➞
) buttons on
Fast X 4 ➞
Fast X 16 ➞
Fast X 128
X4➞
X8
• You can scan the programme in reverse.
To return to normal speed playback, press the
PLAY ( ) button.
• When you press and hold the SEARCH (
)
buttons, playback is done at the default speed of X4.
If you release the SEARCH (
) buttons ,
playback is performed at a normal speed.
For HDD/DVD-RAM/-RW/-R Disc
• The speed marked in this function may be
different from the actual playback speed.
1
Press the TITLE LIST button to display title list.
■
NOTE
■
Title List : Title List is a list of previously
recorded programmes. If a title
is deleted, that title cannot be
played again.
Play List : This refers to a list of userselected titles. When one
playlist is played,only the scene
selected by the user will play
and then stop. Since only the
information necessary for
playing a desired scene is
included in a playlist, even if
that playlist is deleted, the
original recording will not be
deleted. (only VR mode)
Downloaded From48
DvDPlayer-Manual.com
Samsung Manuals
- English
■
NOTE
No sound is heard during Scan(Search)
mode, except with CDs (CD-DA).
Skipping Chapters, Tracks or
Markers
During play, you can search quickly through a chapter
or track.
Slow Motion Play/
Step Motion Play
Slow Motion Play
1
During play, press the SKIP (
remote control.
) buttons on the
• If you press the SKIP ( ) button,
it moves to the beginning of the chapter or track or
marker(HDD/DVD-RAM/-RW(VR mode)).
Pressing the button once again within 3 seconds
returns to the beginning of the previous chapter or
track or marker(HDD/DVD-RAM/-RW(VR mode)).
• If you press the SKIP (
) button,
it moves to the next chapter or track or marker
(HDD/DVD-RAM/-RW(VR mode)).
In pause or step mode, press the SEARCH (
the remote control.
• If you press the SEARCH (
Slow 1/8 ➞
)button,
Slow 1/4 ➞
• If you press the SEARCH (
) buttons on
Slow 1/2
) button,
Slow 1/8 ➞
Slow 1/4 ➞
Slow 1/2
• To return to normal speed playback, press the
PLAY (
) button.
Press and hold the SEARCH (
) buttons during
pause, the disc will play slowly at 1/4 speed. If the
button is released, the pause operation will resume.
NOTE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
■
The speed marked in this function may be
different from the actual playback speed.
Slow motion operates only in the forward
direction on MPEG4 discs.
English - 49
Playback
■
Step Motion Play
Press the STEP(
in the pause mode.
) buttons on the remote control
• Each time the button is pressed, a new frame will
appear.
When the STEP(
About ANYKEY
) button is pressed, the previous
The ANYKEY function allows you to easily search for
a desired scene by accessing title, chapter, time.
You can also change the subtitle and audio settings
and set some features including Marker, Angle,
Zoom, Repeat, Select Media, Disc Manager.
frame will be activated.
When the STEP(
) button is pressed, the next
Moving to a scene directly using the
ANYKEY
frame will be activated.
• To return to normal speed playback, press the PLAY
) button.
(
■
NOTE
• If you want to move to a title or a chapter to find
a desired scene.
Step motion operates only in the forward
direction on MPEG4 discs.
Playback
1
Press the ANYKEY button during playback.
Search
√
Navigation
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
√
Select Media
Disc Manager
2
Press the …† buttons to select Search, then
press the OK or √ button.
HDD
Title
1/10
Time
00:01:45
MOVE
CHANGE
DVD-Video
Title
1/10
Chapter
1/40
Time
MOVE
Downloaded From50
DvDPlayer-Manual.com
Samsung Manuals
- English
00:01:45
CHANGE
■
3
Press the …† buttons to select Title or
Chapter.
4
Press the œ √ buttons or number buttons to
select the desired scene, then press the OK
button.
NOTE
■
■
This may not work for some discs. When
an audio CD(CD-DA) or an MP3 disc is
inserted, depending on the disc type, the
information display may not appear.
The Time Search function does not
operate in some discs.
To make the screen disappear, press the
ANYKEY button again
• If you want to move to a desired time, the following
instructions will help you find a scene.
1
Press the ANYKEY button during playback.
Search
√
Navigation
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
√
Select Media
Disc Manager
Playback
2
Press the …† buttons to select Search, then
press the OK or √ button.
HDD
Title
1/10
Time
00:01:45
MOVE
CHANGE
DVD-Video
Title
1/10
Chapter
1/40
Time
MOVE
00:01:45
CHANGE
3
Press the …† buttons to select Time.
4
Enter the time in the sequence of hours, minutes,
and seconds using the number buttons, then
press the OK button.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 51
Playing the Title List
2
Press the …† buttons to select an entry you
want to play from Title List, then press the OK
or PLAY ( ) button.
The selected entry (title) will be played back.
- About INFO button If you press the INFO button once during a playback,
the system information screen appears.: Displays Active
Status, Background Status, and Main Screen
information.
Follow these instructions to play back a scene from the
Title List.
HDD
Active status
Background Status
Screen
01/JAN/2005 (SAT)
Using the TITLE LIST button
1
12:00
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
Pressing the INFO button twice, Disc information screen
appears.: Displays Total numbers of Titles and Playlists,
Recordable Time(Title), Available Space(Music/Photo).
Title List
HDD
No.
001
002
003
004
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
HDD
Total Title
Total Playlist
Recordable Time:Title
Available Space:Music/Photo
01/JAN/2005 (SAT)
18/JAN/2005 12:15 AV3
Playback
System Info
Play
––
Playback
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 page
SELECT
RETURN
EXIT
Disc Info
15
2
31:46 SP
10033 MB
12:00
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
Pressing the INFO button three times, Current playback
information screen appears.: Displays information of
Playback Name, Title, Created Time, Length, Playing
Time, Audio, and if the disc protection is activated.
Title
HDD
√
Title List
Title
Music
HDD
Name
Playing Info
01/JAN/2005 12:39 AV
3
Title
1/15
Created Time
01/JAN/2005 12:00
Length
00:01:43 SP
Playing Time
00:13:27
Audio
Dolby Digital 2/0 L+R
Title Protection
Not Protected
01/JAN/2005 (SAT)
12:00
Programme
Setup
MOVE
SELECT
RETURN
EXIT
• Press the …† buttons to select Title, then
press the OK or √ button twice.
3
Downloaded From52
DvDPlayer-Manual.com
Samsung Manuals
- English
To stop title play, press the STOP( ) button.
To return the title list screen, press the TITLE
LIST button.
Navigation Menu
2
Press the …† buttons to select an entry you
want to play from Title List, then press the
ANYKEY button.
Title List
Scene Navigation
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
If there is a title composed of markers (See page 56), you
can search the desired scene using the Scene Navigation.
Edit
√
Playlist
√
19/JAN/2005 12:15AV3
Title
√
Navigation
19/JAN/2005 12:15
√
Select Media
SP V-Mode Compatibility
Disc Manager
MOVE
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
1/1 page
SELECT
RETURN
EXIT
(VR mode)
Using the TITLE LIST button
3
Press the …† buttons to select Navigation,
then press the OK or √ button.
Title List
1
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
No.
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
Scene Navigation
SP
Length
MOVE
00:10:21
00:40:03
00:20:15
00:50:16
SELECT
RETURN
EXIT
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 page
SELECT
RETURN
EXIT
4
Press the …† buttons to select Scene
Navigation, then press the OK or √ button.
Using the MENU button.
Scene Navigation
HDD
• With the unit in Stop mode/Playback mode,
press the MENU button.
Title List No. 1
01 00:00:16 02 00:05:16
Title
1/1 Page
HDD
MOVE
√
Title List
Title
SELECT
RETURN
EXIT
Music
Programme
Setup
MOVE
SELECT
RETURN
EXIT
5
Press the …† œ √ buttons to select desired
scene, then press the OK or PLAY ( ) button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 53
Playback
001
002
003
004
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√ Time Navigation
Select Media
V-Mode Compatibility
1/1 page
Disc Manager
Title List
HDD
Title
Time Navigation
Using the ANYKEY button
(VR mode)
1
Press the ANYKEY button during playback.
Using this function, you can search scene minute-byminute from the recorded title list.
Search
Using the TITLE LIST button
√
Navigation
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
1
√
Disc Manager
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
Title List
2
Press the …† buttons to select Navigation,
then press the OK or √ button.
HDD
No.
001
002
003
004
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
Search
SP
√
Navigation
Playback
V-Mode Compatibility
MOVE
Time Navigation
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
1/1 page
Scene Navigation
Marker
SELECT
RETURN
EXIT
Using the MENU button.
√
Disc Manager
• With the unit in Stop mode/Playback mode,
press the MENU button.
3
Press the …† buttons to select Scene
Navigation, then press the OK or √ button.
Title
HDD
√
Title List
Title
Music
Scene Navigation
HDD
Title List No. 1
Programme
Setup
01 00:00:16 02 00:05:16
MOVE
1/1 Page
MOVE
4
RETURN
EXIT
Press the …† œ √ buttons to select desired
scene, then press the OK or PLAY ( ) button.
■
NOTE
SELECT
Scene Navigation will not operate if a
selected title does not have Markers.
Downloaded From54
DvDPlayer-Manual.com
Samsung Manuals
- English
SELECT
RETURN
EXIT
• Press the …† buttons to select Title,
then press the OK or √ button twice.
2
Press the …† buttons to select an entry you
want to play from Title List, then press the
ANYKEY button.
Title List
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
19/JAN/2005 12:15AV3
Title
MOVE
3
1
Press the ANYKEY button during playback.
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√
Navigation
19/JAN/2005 12:15
√
Select Media
SP V-Mode Compatibility
Disc Manager
Using the ANYKEY button
00:10:21
00:40:03
00:20:15
00:50:16
Search
Marker
EXIT
No.
Protection
001
002
003
004
Edit
√
Playlist
√
2
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√
Search
Length
Navigation
00:10:21
00:40:03
00:20:15
00:50:16
Marker
√
Scene Navigation
Time Navigation
Subtitle
√
Audio
√
Repeat
√
Zoom
SELECT
RETURN
Select Media
√
Disc Manager
EXIT
Press the …† buttons to select Time
Navigation, then press the OK or √ button.
3
Press the …† buttons to select Time
Navigation, then press the OK or √ button.
Time Navigation
HDD
Time Navigation
HDD
12:15
√
12:15
12:15
œ√
12:25
CHANGE
SELECT
RETURN
EXIT
√
12:15
œ√
12:25
CHANGE
SELECT
RETURN
EXIT
4
5
Press the œ √ buttons to skip one minute at a
time and search the desired scene, then press
the OK or PLAY ( ) button.
Press the œ √ buttons to skip one minute at a
time and search the desired scene, then press
the OK or PLAY ( ) button.
■
NOTE
■
■
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Cursor does not move if the selected
recorded title is shorter than 1 minute.
The Navigation function may not work on
a disc that has not been recorded by this
device.
An edited title may not display the exact
search time.
English - 55
Playback
4
√
Press the …† buttons to select Navigation,
then press the OK or √ button.
√ Scene Navigation
Navigation
19/JAN/2005 12:15
√ Time Navigation
Select Media
SP V-Mode Compatibility
1/1 page
Disc Manager
MOVE
√
Repeat
Disc Manager
Title List
HDD
Rename
19/JAN/2005 12:15AV3
√
Audio
Select Media
RETURN
Press the …† buttons to select Navigation,
then press the OK or √ button.
Delete
Subtitle
Zoom
1/1 page
SELECT
Copy
√
Navigation
Using Markers
2
Press the OK button when the desired scene appears.
• The number 01 is displayed and the scene is memorized.
Marker
01 -- -- -- -- -- -- -- -- --
N:1
(VR mode)
MOVE
√ PLAY
CANCEL
RETURN
Using the MARKER button
1
Press the MARKER button during playback.
Marker
-- -- -- -- -- -- -- -- -- --
SELECT
N:0
3
Press the œ √ buttons to move to the next position.
4
Press the OK button again when the desired scene
appears.
• The number 02 is displayed and the scene is
memorized.
RETURN
Playback
Marker
01 02 -- -- -- -- -- -- -- --
N:2
Using the ANYKEY button.
• Press the ANYKEY button during playback.
MOVE
√ PLAY
CANCEL
RETURN
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
√
Disc Manager
• Press the …† buttons to select Marker,
then press the OK or √ button.
Downloaded From56
DvDPlayer-Manual.com
Samsung Manuals
- English
• HDD, DVD-RAM or DVD-RW (VR Mode) discs have
the Marker function instead of the Bookmark function.
The Marker function allows you to mark up to 99
scenes. Since the scenes may be displayed as many
different pages, numbering is necessary. If a disc in
use is encoded with Disc Protection, Markers cannot
be set or deleted, only playback is available.
Playing back a marker
Clearing a marker
Using the MARKER button
1
Press the MARKER button during playback.
Marker
MOVE
01 02 -- -- -- -- -- -- -- --
√ PLAY
CANCEL
Using the MARKER button
1
N:2
Marker
RETURN
MOVE
√ PLAY
CANCEL
RETURN
Using the ANYKEY button.
• Press the ANYKEY button during playback.
• Press the ANYKEY button during playback.
Search
√
Navigation
√
Navigation
Marker
Marker
Subtitle
√
Subtitle
√
Audio
√
Audio
√
Repeat
√
Repeat
√
Zoom
Select Media
Select Media
√
Press the œ √ buttons to select a marked scene.
01 02 -- -- -- -- -- -- -- --
• Press the …† buttons to select Marker,
then press the OK or √ button.
2
Press the œ √ buttons to select a marked scene.
Press the CANCEL button to delete the selected
mark.
N:2
Marker
MOVE
√
Disc Manager
• Press the …† buttons to select Marker,
then press the OK or √ button.
Marker
Playback
Zoom
Disc Manager
√ PLAY
CANCEL
Press the OK or PLAY ( ) button to start
playing from the selected scene.
• If you press the SKIP ( ) button, it moves to
the beginning of the marker. Pressing the button
once again within 3 seconds returns to the
beginning of the previous marker.
• If you press the SKIP (
the next marker.
01 02 03 04 05 06 07 08 09 10 √ N:10
RETURN
MOVE
3
01 02 03 04 05 06 07 08 09 10 √ N:10
Using the ANYKEY button.
Search
2
Press the MARKER button during playback.
√ PLAY
Marker
MOVE
CANCEL
01 02 03 04 05 06 07 08 09 --
√ PLAY
CANCEL
RETURN
N:9
RETURN
) button, it moves to
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 57
■
When a marker is cleared while HDD/DVDRAM/-RW (VR mode) is playing, marker
numbers will change. For example, if the 7th
marker is cleared after ten markers are
registered, the marker numbers after the
eighth will automatically move ahead by one
and the 8th marker becomes the 7th.
2
Press the OK button when the desired scene
appears.
• The number 1 is displayed and the scene is
memorized.
Bookmark 1 - - - - - - - - --
Using the Bookmarks
MOVE
(V-mode)
Playback
CANCEL
RETURN
3
Press the œ √ buttons to move to the next
position.
4
Press the OK button again when the desired
scene appears.
The number 2 is displayed and the scene is
memorized.
Using the MARKER button
1
√ PLAY
Press the MARKER button during playback.
Bookmark 1 2 - - - - - - - -Bookmark - - - - - - - - - --
MOVE
MOVE
SELECT
√ PLAY
CANCEL
RETURN
RETURN
• Repeat above to bookmark other positions.
• You can bookmark up to 10 scenes.
Using the ANYKEY button.
• Press the ANYKEY button during playback.
■
Search
Bookmark
Audio
√
Subtitle
√
Angle
√
Repeat
√
Zoom
Select Media
√
• Press the …† buttons to select Bookmark, then
press the OK or √ button.
Downloaded From58
DvDPlayer-Manual.com
Samsung Manuals
- English
NOTE
When the disc tray is opened and then
closed, bookmarks will disappear.
Playing back a bookmark
Clearing a bookmark
Using the MARKER button
1
Press the MARKER button during playback.
Using the MARKER button
1
Bookmark 1 2 - - - - - - - --
MOVE
√ PLAY
CANCEL
Press the MARKER button during playback.
Bookmark 1 2 - - - - - - - --
RETURN
MOVE
√ PLAY
CANCEL
RETURN
Using the ANYKEY button.
Using the ANYKEY button.
• Press the ANYKEY button during playback.
• Press the ANYKEY button during playback.
Search
Search
Bookmark
Bookmark
√
Subtitle
√
Angle
√
Repeat
√
Zoom
Select Media
Audio
√
Subtitle
√
Angle
√
Repeat
√
Playback
Audio
Zoom
√
Select Media
• Press the …† buttons to select Bookmark, then
press the OK or √ button.
2
Press the œ √ buttons to select a bookmarked
scene.
3
Press the OK or PLAY(
from the selected scene.
• Press the …† buttons to select Bookmark, then
press the OK or √ button.
2
) button to start playing
Press the œ √ buttons to select a bookmarked
scene.
Bookmark 1 2 - - - - - - - --
MOVE
3
Downloaded From DvDPlayer-Manual.com Samsung Manuals
√
√ PLAY
CANCEL
RETURN
Press the CANCEL button to delete the selected
bookmark.
English - 59
Selecting the Subtitle
Language
Using the ANYKEY button
1
Press the ANYKEY button during playback.
Selects one of the subtitle language recorded on the
disc.
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
√
Disc Manager
(VR mode)
Using the SUBTITLE button
1
Press the SUBTITLE button during playback.
Subtitle
2
Press the …† buttons to select Subtitle, then
press the OK or √ button.
Search
Off
Navigation
√
Marker
Subtitle
√
Off
Audio
√
KOR
Repeat
√
CHI
ENG
Playback
Zoom
Select Media
√
Disc Manager
2
Press the …† buttons to select the desired
subtitle language. Also, press the SUBTITLE
button repeatedly to select the desired subtitle
language.
• To make the screen disappear, press the
CANCEL or RETURN button.
3
Press the …† buttons to select the desired subtitle
language, then press the OK or √ button.
■
NOTE
■
Downloaded From60
DvDPlayer-Manual.com
Samsung Manuals
- English
The subtitle display may be different
depending on the disc type.
Some discs allow you to select the
language for the disc menu only.
Selecting the Soundtracks
& Audio Channels
Using the ANYKEY button
1
Press the ANYKEY button during playback.
Selecting the Audio
Search
Navigation
Selects one of the soundtracks recorded on the disc.
Also selects the audio channels from recorded TV
programmes.
√
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
√
Disc Manager
(VR mode)
Using the AUDIO button
1
Press the AUDIO button during playback.
2
Press the …† buttons to select Audio, then
press the OK or √ button.
HDD/DVD-RAM/-RW
Search
Navigation
Audio
√
Marker
Dolby Digital 2/0 L + R
Subtitle
√
Audio
√
Dolby Digital 2/0 L + R
Repeat
√
Dolby Digital 2/0 L
Select Media
Playback
Dolby Digital 2/0 R
Zoom
√
Disc Manager
3
DVD-VIDEO
Audio
ENG Dolby Digital 5.1CH
Press the …† buttons to select the desired
soundtracks or audio channel, then press the
OK or √ button.
■
NOTE
■
2
Soundtracks or Audio channel may be
different because they are disc-specific.
Some discs allow you to select the audio
language for the disc menu only.
Press the …† buttons to select the desired
soundtracks or audio channel. Also, press the
AUDIO button repeatedly to select the desired
soundtracks or audio channel.
• To make the screen disappear, then press the
CANCEL or RETURN button.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 61
Changing the Camera
Angle
Repeat Play
When a DVD VIDEO contains multiple angles of a
particular scene, you can select the Angle function.
Playing Repeatedly(Repeat Playback)
Using the ANYKEY button
1
Press the ANYKEY button during playback.
Using the REPEAT button
1
Press the REPEAT button during playback.
Repeat
Search
Off
Bookmark
Audio
√
Subtitle
√
Angle
√
Repeat
√
Zoom
Playback
Select Media
2
√
Press the …† buttons to select Angle, then
press the OK or √ button.
2
Press the …† buttons to select the Off, Title or
Chapter you want to play repeatedly, then
press the OK button.
Search
Bookmark
Audio
√
Angle 1
Subtitle
√
Angle 2
Angle
√
Angle 3
Repeat
√
Angle 4
Angle 5
Zoom
Select Media
3
√
Angle 6
Press the …† buttons to select the desired angle,
then press the OK or √ button.
■
NOTE
■
This function is disc-dependent, and may
not work on all DVDs.
This function does not work when a DVD
has not been recorded with a multicamera angle system.
Downloaded From62
DvDPlayer-Manual.com
Samsung Manuals
- English
Repeat
Title
Repeat A-B
Using the ANYKEY button
1
Press the ANYKEY button during playback.
Using the REPEAT A-B button
Search
Navigation
√
1
Marker
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
Press the REPEAT A-B button during playback.
Repeat A-B
Off
√
Disc Manager
2
Press the …† buttons to select the Repeat,
then press the OK or √ button.
2
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
Repeat Off
√
Repeat Title
Disc Manager
3
A-B
Press the …† buttons to select Repeat Off,
Repeat A-B, Repeat Title, Repeat Track or
Repeat Chapter you want to play repeatedly, then
press the OK or √ button.
■
NOTE
Repeat A-B
Playback
Repeat A - B
Zoom
Select Media
Press the OK button at the point where you want the
repeat play to start (A) and press it again at the point
where you want the repeat play to stop (B). Repeat
playback of the A-B section starts.
HDD/DVD-RAM/-RW(VR mode),
unfinalised DVD-R and unfinalised DVDRW (V mode) discs will do not repeat a
chapter.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 63
Using the ANYKEY button
1
Zooming-In
Press the ANYKEY button during playback.
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
1
Zoom
Select Media
√
Press the ANYKEY button during playback.
Disc Manager
Search
Navigation
√
Marker
2
Press the …† buttons to select Repeat, then
press the OK or √ button.
Subtitle
√
Audio
√
Repeat
√
Zoom
Select Media
√
Disc Manager
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
Select Media
Repeat Off
Repeat A - B
Zoom
√
Repeat Title
2
Press the …† buttons to select Zoom, then press
the OK or √ button. ( ) will be displayed.
3
Press …† œ √ buttons to move to the area you
want to enlarge.
4
Press the OK button.
The screen will be enlarged to twice the normal
size. The screen size will be enlarged to four times
the normal size.
Playback
Disc Manager
3
Press the …† buttons to select Repeat A-B,
then press the OK or √ button.
4
Press the OK button at the point where you
want the repeat play to start (A) and press it
again at the point where you want the repeat
play to stop (B).Repeat playback of the A-B
section starts.
- To return to normal playback -
5
Press the CANCEL button to return to normal
playback.
■
NOTE
■
■
If you set point (B) before five seconds of
playback has lapsed, the prohibition mark
( ) will appear.
You can also activate Normal Playback by
pressing the CANCEL button.
Audio CDs(CD-DA), MP3 discs and
MPEG4 discs do not support the Repeat
A-B function.
Downloaded From64
DvDPlayer-Manual.com
Samsung Manuals
- English
HDD/DVD-VIDEO/
DVD-RAM/-RW/-R
■
NOTE
normal size ➞ X2 ➞ X4
➞ X2 ➞ normal size
When recording is done in the EP mode, the
Zoom function will not be supported except
when the recording has been done in V
mode.
Select Media
Playing an Audio
CD/MP3
Playing an Audio CD(CD-DA)
1
Press the ANYKEY button during playback.
1
Insert an audio CD (CD-DA) into the disc tray.
• The audio CD menu appears and the tracks
(songs) are played automatically.
Search
Navigation
√
Marker
Subtitle
√
Audio
√
Repeat
√
Music List
CD
TRACK 1
Zoom
Select Media
√ 02 : 10
TRACK 1
√
Disc Manager
CD-DA
01/15
04:57
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
1/3 Page
2
Press the …† buttons to select Select Media,
then press the OK or √ button.
Search
2
√
Marker
Subtitle
√
Audio
√
Repeat
√
SELECT
RETURN
EXIT
Press the …† buttons to select the track (song)
you want to hear, and then press the OK button.
Zoom
Select Media
Disc Manager
3
√
HDD
DVD
Audio CD(CD-DA) Screen Elements
!
Press the …† buttons to select HDD or DVD,
then press the OK or √ button.
Music List
CD
√ 02 : 10
TRACK 1
$
TRACK 1
@
CD-DA
01/15
04:57
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
%
1/3 Page
#
MOVE
SELECT
RETURN
EXIT
1. Current track (song): Displays the number of the
track currently being played.
2. Displays the current play index, total track number.
3. Display available buttons.
4. This shows the operating state of a disc and a
playback time corresponding to a portion that is
currently played.
5. Displays the track list (song list).
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 65
Playback
Navigation
MOVE
Buttons on the Remote Control
used for Audio CD(CD-DA) playback
DVD
TV
Playing an MP3 Disc
Insert an MP3 disc into the disc tray.
• The MP3 menu is displayed and the tracks
(songs) are played automatically.
1
Music List
CD
√ 02 : 10
Flower.mp3
..
Flower.mp3
MP3
01/15
4.0 MB
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
MP3
Heaven.mp3
MP3
This Love.mp3
1/3 Page
MOVE
SELECT
RETURN
EXIT
Press the …† buttons to select the track you want to
hear, and then press the OK button.
2
Playback
MP3 Screen Elements
!
Music List
CD
√ 02 : 10
Flower.mp3
$
..
Flower.mp3
MP3
01/15
4.0 MB
@
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
MP3
Heaven.mp3
MP3
This Love.mp3
%
1/3 Page
1. …†: Selects a track (song).
2. œ √ : Moves the page up/down.
3. OK button: Plays the selected track (song).
4. SKIP ( ) button: Plays the next track.
5. SKIP ( ) button: Returns to the beginning of the
current track when pressed during playback. If
pressed again, your HDD & DVD RECORDER
moves to and plays the previous track.
If you press the this button within three seconds after
playback starts, the previous track will be played.
If you press the this button after three seconds, the
current track will be replayed from the beginning.
6. Press the SEARCH (
) buttons:
Fast Play (X2, X4, X8)
7. STOP ( ) button: Stops a track(song).
8. PLAY ( ) button: Plays a track(song) or pauses
playback.
9. ANYKEY button: The ANYKEY menu is displayed.
(Play Mode, Go To Playlist or New Playlist).
Downloaded From66
DvDPlayer-Manual.com
Samsung Manuals
- English
#
MOVE
SELECT
RETURN
EXIT
1. Current track (song): Displays the name of the
track being played.
2. Displays the current folder, play index and current
track size.
3. Displays available buttons.
4. This shows the operating state of a disc and a
playback time corresponding to a portion that is
currently played.
5. Displays the information for the folder and its tracks.
■
NOTE
■
If a disc contains only MP3 files or only
JPEG files, the MP3 or JPEG screen
appears after the disc is loaded.
If a disc contains a mix of MP3 and JPEG
files, you need to select Music for MP3
files or Photo for JPEG files.
Buttons on the Remote Control
used for MP3 playback
DVD
Repeat CD (CD-DA) & MP3
Using the REPEAT button.
TV
1
Press the REPEAT button during playback.
Music List
CD
√ 02 : 10
TRACK 1
TRACK 1
CD-DA
01/15
04:57
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
1/3 Page
MOVE
2
SELECT
RETURN
EXIT
Press the REPEAT button repeatedly to select the repeat
mode you want.
Music List
CD
√ 02 : 10
TRACK 1
TRACK 1
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
1/3 Page
MOVE
1. …†: Selects a track (song).
2. œ √ : Moves the page up/down.
3. OK button: Plays the selected track (song).
4. SKIP ( ) button: Plays the next track.
5. SKIP ( ) button: Returns to the beginning of the
current track when pressed during playback. If
pressed again, your HDD & DVD RECORDER
moves to and plays the previous track.
If you press the this button within three seconds after
playback starts, the previous track will be played.
If you press the this button after three seconds, the
current track will be replayed from the beginning.
6. STOP ( ) button: Stops a track(song).
7. PLAY ( ) button: Plays a track(song) or pauses
playback.
8. ANYKEY button: The ANYKEY menu is displayed.
(Copy, Play Mode, Go To Playlist, New Playlist or
Select Media).
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
Repeat Track (CD (CD-DA)/MP3)
Repeat Folder (MP3)
Repeat All (CD (CD-DA)/MP3)
Random (CD (CD-DA)/MP3): The random option
plays a disc’s track in random order.
• Normal (CD (CD-DA)/MP3): Tracks on a disc are
played in the order in which they were recorded on the
disc.
•
•
•
•
- To return to normal playback -
3
Press the REPEAT or CANCEL button repeatedly
to return to normal playback.
English - 67
Playback
CD-DA
01/15
04:57
CDDA
New Playlist
Using the ANYKEY button
1
Press the ANYKEY button during the Music List
playback.
You can register a maximum 28 tracks in the playlist.
1
Press the ANYKEY button during the Music List
playback.
Music List
CD
» 02 : 10
TRACK 1
TRACK 1
CD-DA
01/15
Go To Playlist
04:57
Play Mode
√
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
New Playlist
Music List
CD
TRACK 1
CD-DA
01/15
Go To Playlist
04:57
1/3 Page
MOVE
SELECT
√
Play Mode
RETURN
EXIT
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
New Playlist
1/3 Page
MOVE
2
» 02 : 10
TRACK 1
SELECT
RETURN
EXIT
Press the …† buttons to select Play Mode,
then press the OK or √ button.
Music List
CD
2
Press the …† buttons to select New Playlist,
then press the OK or √ button.
» 02 : 10
TRACK 1
TRACK 1
CD-DA
Play Mode
01/15
Go To Playlist
04:57
Playback
New Playlist
MOVE
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
Make Playlist
CD
CDDA
TRACK 1
5
Repeat
Track6
CDDA
TRACK
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
Repeat
All
TRACK
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
Normal
CDDA
TRACK
√
7
Random 1/3 Page
SELECT
RETURN
EXIT
1/3 Page
MOVE
3
Press the …† buttons to select desired play mode,
then press the OK or √ button.
• Normal (CD (CD-DA)/MP3): Tracks on a disc are
played in the order in which they were recorded on the
disc.
•
Repeat Track (CD (CD-DA)/MP3)
•
Repeat Folder (MP3)
•
Repeat All (CD (CD-DA)/MP3)
•
Random (CD (CD-DA)/MP3): The random option
plays a disc’s tracks in random order.
3
Add
EXIT
Press the …† buttons to select tracks in the
order in which you want them to play, then
press the OK button.
Make Playlist
CD
CDDA
TRACK 1
01.
TRACK 1
CDDA
TRACK 2
02.
TRACK 3
CDDA
TRACK 3
03.
TRACK 7
CDDA
TRACK 4
04.
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
1/1 Page
1/3 Page
MOVE
Downloaded From68
DvDPlayer-Manual.com
Samsung Manuals
- English
RETURN
Add
RETURN
EXIT
Go To Playlist
4
If you playlisted a wrong track, press the √…†
buttons to select the wrong track, then press
the OK or CANCEL button. The wrong track will
be removed.
1
Press the ANYKEY button during the Music List
playback.
Make Playlist
CD
Music List
01.
TRACK 1
TRACK 2
02.
TRACK 3
CDDA
TRACK 3
03.
TRACK 7
CDDA
TRACK 4
CDDA
TRACK 2
CDDA
TRACK 5
CDDA
TRACK 3
CDDA
TRACK 6
CDDA
TRACK 4
CDDA
TRACK 7
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
CDDA
TRACK 1
CDDA
Delete
CD-DA
01/15
Go To Playlist
04:57
Play Mode
EXIT
√
New Playlist
MOVE
5
» 02 : 10
TRACK 1
TRACK 1
1/1 Page
1/3 Page
MOVE
CD
1/3 Page
SELECT
RETURN
EXIT
To store the Playlist, press the ANYKEY button.
Make Playlist
CD
CDDA
TRACK 1
01.
TRACK 1
CDDA
TRACK 2
02.
TRACK 3
CDDA
TRACK 3
03.
TRACK 7
CDDA
TRACK 4
CDDA
TRACK 5
2
Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
Playlist
CD
00 : 00
TRACK 6
Delete
CDDA
TRACK 7
CDDA
PLAYLIST
Go To Playlist1/3 Page
MOVE
Playlist 1
1/1 Page
Playlist 2
SELECT
RETURN
EXIT
1/1 Page
6
Press the …† buttons to select the Go To
Playlist, then press the OK button.
A new Playlist will be created.
MOVE
3
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
Press the …† buttons to select the desired
playlist folder, then press the OK button.
The selected tracks are played automatically.
English - 69
Playback
PLAYLIST
-00 : 00
Delete the Playlist
1
Go To Edit Playlist
Press the ANYKEY button during the Music List
playback.
1
Press the ANYKEY button during the Music List
playback.
Music List
CD
Music List
» 02 : 10
TRACK 1
CD
CD-DA
01/15
Go To Playlist
04:57
√
Play Mode
2
TRACK 1
CDDA
TRACK 2
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 6
CDDA
TRACK 7
CDDA
TRACK 7
New Playlist
CD-DA
01/15
Go To Playlist
04:57
Play Mode
1/3 Page
MOVE
» 02 : 10
TRACK 1
TRACK 1
SELECT
√
New Playlist
RETURN
EXIT
Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
Playlist
CD
MOVE
2
1/3 Page
SELECT
RETURN
EXIT
Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
00 : 00
PLAYLIST
Playlist 1
Playlist
Playlist 2
CD
00 : 00
PLAYLIST
PLAYLIST
-00 : 00
Playlist 1
Playlist 2
1/1 Page
MOVE
SELECT
RETURN
PLAYLIST
-00 : 00
EXIT
Playback
1/1 Page
3
Press the …† buttons to select the Playlist you
want to delete.
4
Press the ANYKEY button.
MOVE
SELECT
RETURN
EXIT
3
Press the …† buttons to select the Playlist you
want to edit.
4
Press the ANYKEY button in playlist mode.
Playlist
CD
00 : 00
PLAYLIST
Playlist 1
Playlist 2
Delete Playlist
PLAYLIST
01/02
00 : 00
Go To Edit Playlist
Playlist
Go To Music List
CD
New Playlist
00 : 00
1/1 Page
MOVE
SELECT
PLAYLIST
RETURN
EXIT
Playlist 1
Playlist 2
Delete Playlist
PLAYLIST
01/02
00 : 00
Go To Edit Playlist
5
Press the …† buttons to select the Delete
Playlist, then press the OK or √ button.
New Playlist
MOVE
Playlist
CD
00 : 00
PLAYLIST
Playlist 1
Playlist 1
Playlist 2
Do you want to delete?
No
Yes
1/1 Page
MOVE
6
Go To Music List
SELECT
RETURN
EXIT
Press the œ √ buttons to select Yes, then press
the OK button. The selected Playlist is deleted.
Downloaded From70
DvDPlayer-Manual.com
Samsung Manuals
- English
1/1 Page
SELECT
RETURN
EXIT
Go To Music List
5
Press the …† buttons to select the Go To Edit
Playlist, then press the OK or √ button.
1
Edit Playlist
Press the ANYKEY button during the Playlist
playback.
CD
CDDA
TRACK 1
01
TRACK 1
CDDA
TRACK 2
02
TRACK 3
CDDA
TRACK 3
03
TRACK 7
CDDA
TRACK 4
04
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
TRACK 1
1/1 Page
Add
RETURN
PLAYLIST
01/04
Go To Music List
04 : 30
EXIT
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
New Playlist
MOVE
6
7
Press the …† buttons to select tracks in the order
in which you want them to play, then press the OK
button.
If you playlisted a wrong track, press the √ …†
buttons to select the wrong track, then press the
OK or CANCEL button.
To store the Playlist, press the ANYKEY button.
2
1/1 Page
SELECT
RETURN
EXIT
Press the …† buttons to select Go To Music List,
then press the OK or √ button.
Music List
CD
√ 02 : 10
TRACK 1
TRACK 1
CD-DA
01/15
04:57
CDDA
TRACK 2
CDDA
TRACK 3
CDDA
TRACK 4
CDDA
TRACK 5
CDDA
TRACK 6
CDDA
TRACK 7
1/3 Page
MOVE
Edit Playlist
SELECT
RETURN
EXIT
CD
CDDA
TRACK 1
01
TRACK 1
CDDA
TRACK 2
02
TRACK 3
CDDA
TRACK 3
03
TRACK 7
CDDA
TRACK 4
04
TRACK 4
CDDA
TRACK 5
05
TRACK 6
CDDA
TRACK 6
AddTRACK
CDDA
7
Go To Playlist
1/3 Page
MOVE
9
1/1 Page
SELECT
RETURN
EXIT
Press the …† buttons to select the Go To
Playlist, then press the OK button.
Playlist will be edited.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 71
Playback
8
» 02 : 10
TRACK 1
Playlist 1
1/3 Page
MOVE
Playlist
CD
Select Media (MP3)
1
Viewing a Picture
Press the ANYKEY button.
Music List
CD
» 02 : 10
Flower.mp3
..
Flower.mp3
Copy
Play Mode
ROOT
Go 01/15
To Playlist
New
4.0Playlist
MB
Select Media
√
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
MP3
Heaven.mp3
MP3
This Love.mp3
√
MOVE
1
Insert a JPEG disc or Mixed disc (JPEG + MP3 + DivX)
into the disc tray.
Title
1/3 Page
SELECT
CD
RETURN
EXIT
Title
Title List
√
DivX List
√
Music
Programme
2
Music List
CD
» 02 : 10
Flower.mp3
..
Flower.mp3
Copy
Play Mode
ROOT
Go 01/15
To Playlist
New
4.0Playlist
MB
Playback
Setup
Press the …† buttons to select Select Media, then
press the OK or √ button.
Select Media
MOVE
√
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
MP3
Heaven.mp3
MOVE
2
DVD
SELECT
EXIT
Photo List
CD
Index: 6/10
1/3 Page
RETURN
EXIT
..
3
RETURN
Press the …† buttons to select Photo, then press the
OK or √ button.
MP3
HDD This Love.mp3
√
SELECT
Press the …† buttons to select HDD or DVD, then
press the OK or √ button.
If there are no mp3 files on the selected media, it
notifies you that there are no mp3 files and the
media will not be switched.
DSC01193.JPG DSC01194.JPG
1/2 Page
MOVE
3
SELECT
RETURN
EXIT
Press the …† œ √ buttons to select a picture.
• To see the next 8 pictures, press the SKIP (
button.
• To see the previous 8 pictures, press the
SKIP( ) button.
■
NOTE
■
Downloaded From72
DvDPlayer-Manual.com
Samsung Manuals
- English
)
If a disc contains only MP3 files or only
JPEG files, the MP3 or JPEG screen
appears after the disc is loaded.
If a disc contains a mix of MP3 and JPEG
files, you need to select Music for MP3
files or Photo for JPEG files.
Slide Show
- To stop the Slide Show -
4
1
Press the ANYKEY button.
Press the ANYKEY button.
Photo List
CD
..
Index: 1/10
Copy
Slideshow
√
Slide Show
DSC01192
Select Media
√
MOVE
5
1/2 Page
SELECT
√
Slideshow Off
Go To Photo List
RETURN
EXIT
Press the …† buttons to select Slide Show,
then press the OK or √ button.
2
Press the …† buttons to select Slideshow Off,
then press the OK or √ button.
Photo List
CD
..
Slide Show
Select Media
√
DSC01193
√
Normal
DSC01194
Fast
1/2 Page
SELECT
RETURN
Playback
MOVE
6
Slow
Copy
DSC01192
Index: 1/10
EXIT
Press the …† buttons to select the slide show
speed, then press the OK or √ button.
The slide show starts.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 73
Rotate
Zoom
To setup, follow steps 1 to 3 in page 72.
4
Playback
5
6
Press the OK button to select the picture you want
to see, then press the ANYKEY button.
To setup, follow steps 1 to 3 in page 72.
4
Press the OK button to select the picture you want
to see, then press the ANYKEY button.
Slideshow
√
Slideshow
√
Rotate
√
Rotate
√
Zoom
Zoom
Go To Photo List
Go To Photo List
Press the …† buttons to select Rotate, then
press the OK or √ button.
Slideshow
√
Rotate
√
5
Press the …† buttons to select Zoom, then
press the OK or √ button.
6
Each time the OK button is pressed, the picture
is enlarged up to 4x(four times the normal size).
Rotate 90
Zoom
Rotate 180
Go To Photo List
Rotate 270
Press the …† buttons to select the rotate angle,
then press the OK or √ button.
➞ X2 ➞ X4 ➞ X2 ➞ Normal
- To stop the Rotate -
1
Press the ANYKEY button.
- To stop the Zoom -
1
Rotate
Press the ANYKEY button.
√
Rotate Off
Go To Photo List
Zoom Off
Go To Photo List
2
Press the …† buttons to select Rotate Off, then
press the OK or √ button.
2
Downloaded From74
DvDPlayer-Manual.com
Samsung Manuals
- English
Press the …† buttons to select Zoom Off, then
press the OK or √ button.
Go To Photo List
Playing an MPEG4
To setup, follow steps 1 to 3 in page 72.
4
Press the OK button to select the picture you want
to see, then press the ANYKEY button.
Using the MENU button
Slideshow
√
Rotate
√
1
Insert a DivX disc or Mixed disc (JPEG + MP3 + DivX)
into the disc tray.
2
Press the …† buttons to select Title, then press
the OK or √ button.
(In case of playing a DivX Disc, see number 4 on
this page.)
Zoom
Go To Photolist
5
Press the …† buttons to select Go To Photo
List, then press the OK or √ button.
Title
CD
Photo List
CD
Title
Index: 1/10
Title List
√
DivX List
√
Music
Programme
Setup
MOVE
SELECT
RETURN
EXIT
1/2 Page
MOVE
SELECT
RETURN
EXIT
3
Press the …† buttons to select DivX List,
then press the OK or √ button.
The DivX List screen is displayed.
DivX List
CD
ABC.avi
..
DIVX
[DivX] ABC.avi
MPEG4
01/01
703.4MB
1/1 Page
MOVE
4
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
Press the …† buttons to select the avi file
(DivX), then press the OK or PLAY ( ) button.
English - 75
Playback
..
DivX Subtitle Encoding
5
When MPEG4 file is played, you can use
following functions. Pressing the STOP ( )
button once during playback will display the file
list, pressing the button again will exit the menu
screen.
1
Press the ANYKEY button during playback.
MPEG4 Function Description
Function
Search
Description
Audio
√
Subtitle
√
Repeat
√
Subtitle Encoding √
Skip
During play, press the SKIP (
) buttons, it
moves forward or backward 5 minutes.
Search
) buttons
During play, press the SEARCH (
and press again to search at a faster speed.
(X2, X4, X8)
Slow Motion In pause or step mode, press the SEARCH ( )
Play
button on the remote control. (X1/8, X1/4, X1/2)
2
Press the …† buttons to select Subtitle
Encoding, then press the OK or √ button.
Step Motion Press the STEP (
) button on the remote
Play
control in the still mode.
Search
Playback
■
NOTE
■
■
This unit can play the following video
compression formats,
- MPEG4 Codec format : DivX 3.11 DivX
4.x DivX 5.x (without QPEL and GMC)
- Audio format : .MP3, .MPEG, .WMA,
.LPCM, .AC3
Supported subtitle file formats: .smi, .srt,
.sub, .psb, .txt, .ass (The subtitle file
should have exactly the same name to
corresponding MPEG4 file name)
Some MPEG4 files created on a personal
computer may not be play back.
That is why Codec Type, Version and
Higher resolution over specification is not
supported.
√
Subtitle
√
Central(Windows)
Repeat
√
Western(Windows)
Subtitle Encoding √
3
NOTE
Greek(Windows)
Press the …† buttons to select a supported
DivX subtitle language by region, then press the
OK or √ button.
Western
English, Breton, Catalan, Danish, Dutch,
Faroese, Finnish, French, Gaelic, German,
Icelandic, Irish, Italian, Norwegian, Portuguese,
Spanish and Swedish
Central
English, Albanian, Croatian, Czech, Hungarian,
Polish, Romanian, Slovak, Slovene and
Serbian(Latin)
Greek
English and modern Greek
■
Downloaded From76
DvDPlayer-Manual.com
Samsung Manuals
- English
Audio
If the subtitle language is displayed in
broken fonts, change DivX Subtitle to the
appropriate region. If is still does not work,
the format is not supported.
Recording
Before Recording
This unit can record on various types of discs. Before
recording, read the following instructions and select the
disc type according to your preference.
Recordable Discs
This section shows various HDD & DVD
Recording methods.
This HDD & DVD RECORDER can record on the
following discs.
HDD
DVD-RAM
DVD-RW
DVD-R
•DVD-RWs and DVD-RAMs are rewritable.
•DVD-Rs are non-rewritable
Compatibility between Samsung and Other Company’s
Recorder
Disc Types
Recording
format
DVD-RAM
VR Mode
DVD-RW
Before Recording . . . . . . . . . . . . . . . . . . . . . . . . .77
V Mode
Recording the current TV
programme you are watching . . . . . . . . . . . . . . . .79
Recording from external equipment
you are watching . . . . . . . . . . . . . . . . . . . . . . . . . .81
V Mode
DVD-R
Copying from a Camcorder . . . . . . . . . . . . . . . . . .82
■
Making a One Touch Recording (OTR) . . . . . . . . .83
NOTE
Chasing Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Simultaneous Recording and Playback . . . . . . . . .85
Making a Timer Recording . . . . . . . . . . . . . . . . . .86
Flexible Recording (for Timer recording only) . . . .88
Editing the Timer Record List . . . . . . . . . . . . . . . .88
Deleting a Timer Record List . . . . . . . . . . . . . . . . .89
Go To History List . . . . . . . . . . . . . . . . . . . . . . . . .90
Downloaded From DvDPlayer-Manual.com Samsung Manuals
■
Finalise
- This closes the DVD-RW/-R so no
additional recording can be done.
Unfinalise
- This allows additional recording on a
DVD-RW disc originally recorded on the
HDD & DVD RECORDER.
- A DVD-RW disc that has been recorded
by DAO(Disc At Once) in a PC cannot be
unfinalised.
- A DVD-RW disc that has been recorded
in Video Mode of a different maker’s
recorder cannot be unfinalised.
- A DVD-R disc cannot be unfinalised.
English - 77
Recording
VR Mode
Recording Device Finalising Additional Recording
in Samsung Recorder
Samsung
X
Recordable
X
Recordable
Other Company
Not
recordable
finalised
Samsung
Recordable
not finalised
Not recordable
finalised
Other Company
Recordable
not finalised
Not recordable
finalised
Samsung
not finalised
Recordable
Not recordable
finalised
Other Company
not finalised Not recordable
finalised
Not recordable
Samsung
not finalised
Recordable
finalised
Not recordable
Other Company
not finalised Not recordable
Recording Formats
When you insert an unused disc, the following message
appears. Since available functions differ depending on
the disc type, select a disc that best fits your preferences.
DVD-RAM: Use after formatting the disc.
Recording Mode
Select one of four recording modes by pressing the
REC MODE button repeatedly while the unit is in Stop
mode for the desired recording time and picture quality.
In general, picture quality improves as the recording
time decreases. In FR mode, the most suitable record
mode is adjusted automatically, according to remaining
time on the disc and length of the timer recording. This
function is selected only one mode in XP, SP, LP and
EP modes and you can use this mode for timer
recording.
Unformatted Disc
Do you want to format this disc?
Yes
• DVD-HR710
No
Recording Mode
DVD-RW: When unused DVD-RW disc is first inserted,
the message “Uninitialized Disc Do you want
to initialize this disc?” will be displayed. If you
select Yes, the disc will be formatted in VR
mode.
If you want to change the mode, refer to
Formatting a Disc on page 121.
XP
(high quality mode)
SP
(standard quality mode)
Recording Times
HDD (80GB)
DVD-RAM/-RW/-R
Approx. 1 hour
Approx. 18 hours
about 8.5 Mbps
Approx. 2 hours
Approx. 34 hours
about 4.5 Mbps
LP
(long recording mode)
Approx. 65 hours
Approx. 96 hours
EP
(extended mode)
Approx. 127 hours
FR
(Flexible Recording)
Approx.18~96 hours
Approx. 4 hours
about 2 Mbps
Approx. 6 hours/
about 1.6 Mbps
Approx. 8 hours/
about 1.2 Mbps
Approx.1~6 hours
Uninitialized Disc
Do you want to initialize this disc?
Yes
• DVD-HR721
No
Recording
Recording Mode
DVD-R: Formatting DVD is unnecessary and only Video
Mode Recording is supported.
DVD-RW(V mode)/-R
• Chapters will be created automatically when you finalise
recording on DVD-RW/-R discs in Video mode.
The chapter’s length (interval between chapters) varies
according to the recording mode.
• Simple editing (erasing titles/changing title name)
XP
(high quality mode)
SP
(standard quality mode)
Recording Times
HDD (160GB)
DVD-RAM/-RW/-R
Approx. 1 hour
Approx. 38 hours
about 8.5 Mbps
Approx. 2 hours
Approx. 72 hours
about 4.5 Mbps
LP
(long recording mode)
Approx. 138 hours
EP
(extended mode)
FR
(Flexible Recording)
Approx. 205 hours
Approx. 272 hours
Approx.38~205 hours
Approx. 4 hours
about 2 Mbps
Approx. 6 hours/
about 1.6 Mbps
Approx. 8 hours/
about 1.2 Mbps
Approx.1~6 hours
DVD-RAM/-RW(VR mode)
• This mode allows multiple editing functions (such as
deletion of the whole title, partial deletion of a title, etc.)
• Various editing options using a created Playlist.
Downloaded From78
DvDPlayer-Manual.com
Samsung Manuals
- English
■
NOTE
Recording time may vary according to
specific conditions.
Unrecordable pictures
Video with copy protection cannot be recorded on this
HDD & DVD RECORDER.
When the HDD & DVD RECORDER receives a copyguard signal while recording, recording stops and the
following message appears on the screen.
Recording the current TV
programme you are watching
Check that the disc has enough available space for the
recording. Adjust the recording mode.
You cannot record copy protected movie.
1
Concerning Copy Control Signals
TV broadcasts that contain copy control signals may have
one of the following three signal types, Copy-Free, CopyOnce and Copy-Never. If you want to record a copy-once
type programme, use DVD-RW with CPRM in VR Mode and
DVD-RAM.
Signal type
Media
DVD-RW(Ver.1.1)
Copy-Free
Copy-Once
Copy-Never
O
-
-
Press the HDD or DVD button.
If you select DVD, Press the OPEN/CLOSE button and
place a recordable disc on the disc tray.
Press the OPEN/CLOSE button to close the disc tray.
Wait until LOAD disappears from the front panel display.
If an unused DVD-RAM disc is used, you will be
prompted to format first. Make your selection using the
œ √ buttons, then press OK button.(See page 78)
DVD-RW(Ver.1.1)
Unformatted Disc
with CPRM
Do you want to format this disc?
VR mode
O
O*
V mode
O
-
DVD-R
O
-
DVD-RAM(Ver.2.0)
O
O*
Yes
-
No
-
Once “Copy Once” has been recorded, recording
cannot be done anymore.
- Content Protection for Recordable Media (CPRM)
CPRM is a mechanism that ties a recording to the media on
which it is recorded. It is supported by some HDD & DVD
RECORDERs, but not by many DVD players. Each blank
recordable DVD has a unique 64-bit media ID etched in the
BCA. When protected content is recorded onto the disc, it can
be encrypted with a 56-bit C2 (Cryptomeria) cipher derived
from the media ID.
During playback, the ID is read from the BCA and used to
generate a key to decrypt the contents of the disc. If the
contents of the disc are copied to other media, the ID will be
absent or wrong and the data will not be decryptable.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Uninitialized Disc
Do you want to initialize this disc?
Yes
2
No
Press the PROG (
) or number buttons to select
the current programme you want to record.
English - 79
Recording
If an unused DVD-RW disc is used, whether to initialize
or not will be asked first. Make your selection, then press
the OK button.(See page 78)
3
Press the REC MODE button repeatedly, (or press the
REC MODE button and then press the …† buttons) to
select the recording speed(quality).
➞ SP ➞ LP ➞ EP ➞ XP
■
You can not change the recording mode
and the PROG while recording.
■
Recording will stop automatically if there is
no free space left for recording.
■
Up to 99 titles can be recorded onto a
disc.(DVD-RAM/-RW/-R)
■
Up to 999 titles can be registered on the
HDD.
■
HDD recording is available for up to 24
hours, and when recording for 24 hours, 4
titles will be recorded with each being 6
hours in length.
■
Recording will stop automatically if a copy
protected image is selected.
■
DVD-RAM/-RW discs must be formatted
before starting to record. Most new discs
are sold unformatted.
■
Do not use DVD-R authoring discs with
this unit.
NOTE
Record Mode SP 031:39
4
Press the REC button.
Information concerning the channel is displayed
on the screen, then recording begins.
Icon( ) is displayed on the front panel.
Recording
● Recording : PR 1 [SP]
- To pause recording • Press the REC PAUSE button to pause a recording
in progress.
• Press the REC PAUSE button again during pause to
resume recording.
• You can switch channels by pressing the
PROG (
) buttons while recording pauses.
- To stop recording Press the STOP ( ) button to stop or finish a
recording in progress.
• When using DVD-RAM/-RW/-R discs, the message
“Updating the information of disc. Please wait for a
moment” is displayed.
Downloaded From80
DvDPlayer-Manual.com
Samsung Manuals
- English
Recording from external
equipment you are watching
4
Press the REC button.
Information concerning the external input mode is
displayed on the screen, then recording begins.
Icon(
) is displayed on the front panel.
- To pause recording Before you start
Check that the disc has enough available space for the
recording. Adjust the recording mode.
• Press the REC PAUSE button to pause a recording
in progress.
• Press the REC PAUSE button again during pause to
resume recording.
• You can switch channels by pressing the
PROG (
) buttons while recording pauses.
1
2
Press the HDD or DVD button.
If you select DVD, press the OPEN/CLOSE button and
place a recordable disc on the disc tray. Press the
OPEN/CLOSE button to close the disc tray.
Wait until LOAD disappears from the front panel display.
If an unused DVD-RAM disc is used, whether to format
or not will be asked first. (See page 78)
If an unused DVD-RW disc is used, whether to initialize
or not will be asked first. (See page 78)
- To stop recording Press the STOP ( ) button to stop or finish a
recording in progress.
• When using DVD-RAM/-RW/-R discs, the
message “Updating the information of disc. Please
wait for a moment” is displayed.
Press the INPUT button to select the input source
according to the connection you made.
The front panel display changes in the following
sequence:
➞ PR Number ➞ AV1 ➞ AV2 ➞ AV3 ➞ DV
If you connect a digital camcorder, press the INPUT
button to select DV. (See page 82)
Recording
3
Press the REC MODE button repeatedly, (or press
the REC MODE button, then press the …† buttons)
to select the recording speed (quality).
➞ SP ➞ LP ➞ EP ➞ XP
Record Mode SP 031:39
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 81
Copying from a Camcorder
4
Press the INPUT button to select DV.
If the input is set to DV, a playback/record menu that
enables camcorder control appears on the top of the
screen.
DV
The DV device is connected.
You may control the Camcorder using the IEEE1394 (DV)
interface.
MOVE
RETURN
1
Connect the DV output jack of your camcorder to the
DV input jack on the front of your HDD & DVD
RECORDER using a DV cable.
5
Select the Play (√) icon on the upper part of the
screen to playback the camcorder and find the
starting position to copy.
You can press the PLAY ( ) button of the remote
control to play the camcorder.
2
Press the HDD or DVD button.
If you select DVD, press the OPEN/CLOSE button and
place a recordable disc on the disc tray. Press the
OPEN/CLOSE button to close the disc tray. Wait until
LOAD disappears from the front panel display.
6
3
Press the REC MODE button repeatedly to select
the recording speed(quality).
To start recording, use the œ √ buttons to select
Record ( ● ) icon in the top side of the screen, then
press the OK button.
You can press the REC button of the remote control
to start recording. To display playback related icons
on the screen, press any direction button on the
remote control.
➞ SP ➞ LP ➞ EP ➞ XP
Recording
SELECT
- To stop recording Press the STOP ( ) button to stop or finish a
recording in progress.
Record Mode SP 031:39
Downloaded From82
DvDPlayer-Manual.com
Samsung Manuals
- English
• When using DVD-RAM/-RW/-R discs, the
message “Updating the information of disc.
Please wait for a moment” is displayed.
Making a One Touch
Recording (OTR)
■
NOTE
The timer counter decreases by the
minute from 8:00 to 0:00, then the HDD &
DVD RECORDER stops recording.
- To stop recording You can set the HDD & DVD RECORDER to record in
30-minute increments up to 8 hours by pressing the REC
button.
Press the STOP ( ) button. The message “Do you
want to stop recording?” is displayed.
• Press the œ √ buttons to select Yes, then press the
OK button.
• Or press the STOP (
1
Press the HDD or DVD button.
If you select DVD, press the OPEN/CLOSE button and
place a recordable disc on the disc tray. Press the
OPEN/CLOSE button to close the disc tray. Wait until
LOAD disappears from the front panel display.
2
Press the PROG (
) or number buttons to select
the programme to record. If you want to record
through a connected external component, press the
INPUT button to select an appropriate external
input(AV1, AV2, AV3, DV or PR01).
3
Press the REC button to start recording.
OTR Mode
0:30
) button again.
About INFO button
During recording, press the INFO button once, the system
information screen appears.: Displays Active Status,
Background Status, and Main Screen information.
HDD
Active status
Background Status
Screen
01/JAN/2005 (SAT)
System Info
Record XP
––
Recording:PR3 [SP]
12:00
Pressing the INFO button twice, Disc information screen
appears.: Displays Total numbers of Titles and Playlists,
Recordable Time(Title), Available Space(Music/Photo).
4
Press the REC button repeatedly to adjust the
desired recording time.
➞ 0:30 ➞ 1:00 ➞ ... 8:00 ➞ Off
Disc Info
15
2
17:12 XP
10033 MB
12:00
Pressing the INFO button three times: Current recording
information screen appears.: Displays information of recording
Name, Title, Created Time and Recording Time.
HDD
Name
Recording Info
01/JAN/2005 12:00 PR
1
Recording Title
4
Created Time
01/JAN/2005 12:00
Recording Time
00:13:27
01/JAN/2005 (SAT)
12:00
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 83
Recording
HDD
Total Title
Total Playlist
Recordable Time : Title
Available Space:Music/Photo
01/JAN/2005 (SAT)
2
Chasing Play
Press the OK or PLAY ( ) button.
It plays back the title that you are currently
recording from the beginning.
√ Play
You can play back from the beginning of the programme
you are currently recording.
While Recording
1
Press the PLAY (
) button.
It plays back the title that you are currently
recording from the beginning.
Playback is not available for 10 seconds from the
start of recording.
You can use the SKIP (
) and other
playback-related buttons to view the previous
recorded list.
- Stopping Playback / Recording -
1
Press the STOP ( ) button. Playback screen
disappears and the recording in progress screen
appears.
2
Pressing the STOP (
stop the recording.
) button once more will
√ Play
■
NOTE
■
Recording
■
Using the TITLE LIST button
1
With the unit in recording mode, press the TITLE LIST
button.
The Title List screen is displayed.
Press the …†/SKIP (
) buttons to select the
recording title list.
Title List
HDD
No.
RECORDING...
008
009
010
011
012
Title
18/JAN/2005 02:15A
19/JAN/2005 14:15A
20/JAN/2005 16:05A
25/JAN/2005 17:00A
RECORDING...
Length
00:10:21
00:40:03
00:40:15
00:30:16
00:00:00
19/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
2/2Page
SELECT
RETURN
EXIT
Downloaded From84
DvDPlayer-Manual.com
Samsung Manuals
- English
No sound is heard during search mode.
DVD disc playback is available during HDD
recording. However, JPEG, MP3, and DivX
files in the disc cannot be played back.
HDD playback is available during DVD
recording. However, JPEG and MP3 files in
the HDD cannot be played back.
Simultaneous
Recording and Playback
1
Press the STOP ( ) button. Playback screen
disappears and the recording in progress screen
appears.
You can watching the previous title list while recording a
programme.
2
Pressing the STOP (
stop the recording.
- Stopping Playback / Recording -
■
) button once more will
No sound is heard during search mode.
NOTE
Using the TITLE LIST button
1
With the unit in recording mode, press the TITLE
LIST button.
The Title List screen is displayed.
Title List
HDD
No.
18/JAN/2005 12:15 AV3
008
009
010
011
012
Title
Length
18/JAN/2005 02:15A
19/JAN/2005 14:15A
20/JAN/2005 16:05A
25/JAN/2005 17:00A
RECORDING...
00:10:21
00:40:03
00:40:15
00:30:16
00:00:00
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
Press the …†/ SKIP (
RETURN
EXIT
) buttons to select the
Recording
2
2/2Page
SELECT
title you want to play OK or PLAY ( ) button.
Selected title list will be played back.
√ Play
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 85
Making a Timer
Recording
3
Press the OK button to select Add a list.
The Timer Record List screen is displayed.
Timer Record List
HDD
No.
To
Current Time 12:00
Source
Date
Start
End
Mode VPS/PDC
Add a list
Title No. 01
To
Source
Date
Start
End
HDD
PR 02
01 JAN
12 : 00
14 : 00
Mode VPS/PDC
SP
Title
1. Check the antenna cable is connected.
2. Check the remaining time of the disc.
3. Check the date and time are correct.
Make sure the Clock (Setup-Clock Set) must be set
before you proceed with a timer recording. (See page
27)
Available Time
Available Time
HDD
HDD
MOVE
Off
Save
29:10 SP
29:10 SP
SELECT
RETURN
EXIT
Using the ANYKEY button.
• Press the ANYKEY button.
• Press the …† buttons to select Add, then press
the OK or √ button.
Using the TIMER button
1
With the unit in Stop mode/Playback mode,
press the TIMER button.
The Programme screen is displayed.
4
Set timer recording option.
• Fill the input items using the …†œ √ buttons and
number buttons.
œ √ : Moves to the previous/next item.
…† 0~9 : Sets a value.
Programme
HDD
√
Timer Record
Title
Music
Programme
Setup
Recording
MOVE
SELECT
RETURN
EXIT
• To : Select the media to record HDD or DVD.
• Source : The video input source (AV1, AV2 or
AV3), or the broadcasting channel you want to
make a timer recording from.
• Date : Timer Recording allows setting the
recording time within one month period. Set the
recording day. (day/month)
Using the MENU button.
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Programme,
then press the OK or √ button.
01 JAN
02 JAN
03 JAN
30 JAN
31 JAN
2
Press the OK or √ button to select Timer Record.
Timer Record List
HDD
No.
To
Current Time 12:00
Source
Date
Start
End
Mode VPS/PDC
Add a list
Available Time
HDD
MOVE
29:10 SP
SELECT
RETURN
EXIT
Downloaded From86
DvDPlayer-Manual.com
Samsung Manuals
- English
Every Day
MON-SAT
MON-FRI
Every SAT
Every SUN
• Start/End Time : Start and end time of the timer
recording.
• Mode (Recording Mode) :
- FR (Flexible Recording) : Select when you want to
set video quality automatically. In FR mode, the
most suitable record mode is adjusted automatically,
according to remaining time on the disc and length
of the timer recording. This function is selected only
one mode in XP, SP, LP and EP modes.
5
After selecting the set up value for each mode, press the
OK button to select Save, and press the OK button
again.
•
will appear on the front panel. It means that a
timer recording is registered.
If the timer settings overlap;
The programmes are recorded in order of priority.
If timer recording is set for the first programme and
then again for the second programme and both
programmes overlap, the following message will
appear on the screen: “This setting is identical with
1.” The message shows that the first programme
has priority. After recording of the first programme is
complete, the second programme starts being
recorded.
- XP (high quality) : Select when video quality is
important.
- SP (standard quality) : Select to record in standard
quality.
- LP (low quality) : Select when a long recording time
is required.
- EP (extended) : Select when a longer recording time
is required.
To exit without saving the current setting
Press the MENU button.
■
NOTE
When you are recording at EP mode on a
DVD-RW(V mode)/-R disc, it may not
record the full 6 or 8 hours because the
unit uses the VBR(Variable Bit Rate)
ENCODING system. For example, if you
record a programme with a lot of action, it
uses a higher bit rate which in turn
consumes more disc memory.
• VPS/PDC : VPS(Video Programme System) or
PDC(Programme Delivery Control) function.
6
When you want to recording on DVD-RAM/-RW/-R,
you must insert the disc.
7
Turn the power off to finish the Timer Recording
setting.
Timer Recording will not work when the power is on.
■
The timer recording time may differ from the
set time depending on disc status and
overall timer recording status (for example,
recording times overlapping, or when the
previous recording ends within 2 minutes
before the start time of the next recording.)
■
You can make the Timer Recording up to 12
programmes.
■
If HDD disk has no available recording
space, blinks. It means that HDD disk has
no space to record.
NOTE
• TITLE : To label the title name, select the title and then press
the OK button. Title renaming screen appears.
See page 96 for the registration.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 87
Recording
- If you set this function on, you can control the starting
and ending time of recording by special signal included
in the broadcasting signal. If a TV programme is
shortened or starts earlier or later than scheduled, this
function synchronizes the starting and ending time of
recording with the actual broadcasting time
automatically.
- Set up the start-time EXACTLY according to the
published TV schedule. Otherwise the timer recording
will not operate.
- Do not select PDC or VPS unless you are sure the
programme you wish to record is broadcast with PDC
or VPS.
To return to the previous menu
Press the RETURN button if you don’t want to set a
timer recording.
Flexible Recording
(for Timer recording only)
Editing the Timer
Record List
Follow these directions to edit the timer record list.
In FR mode, the most suitable record mode is adjusted
automatically, according to remaining time on the disc
and length of the timer recording. This function is
selected only one mode in XP, SP, LP and EP modes
and you can use this mode for timer recording.
The FR mode recording setup is the same as Timer
Recording. When setting the mode in step 4, set the FR
mode.
Using the TIMER button
1
With the unit in Stop mode/Playback mode, press
the TIMER button. The Programme screen is
displayed.
Programme
HDD
√
Timer Record
Title
Music
Programme
Setup
MOVE
SELECT
RETURN
EXIT
Using the MENU button.
Recording
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Programme,
then press the OK or √ button.
2
Press the OK or √ button to select Timer Record.
Timer Record List
HDD
Current Time 12:00
No.
To
Source
01
02
03
HDD
HDD
HDD
PR 02
PR 07
AV2
Available Time
Date
HDD
MOVE
Downloaded From88
DvDPlayer-Manual.com
Samsung Manuals
- English
Start
01 JAN 12 : 00
15 JAN 14 : 10
01 JAN 15 : 10
Add a list
End
14 : 00
14 : 30
15 : 30
Mode VPS/PDC
SP
SP
SP
On
On
On
29:10 SP
SELECT
RETURN
EXIT
=
3
Press the …† buttons to select the number of the
Timer Record List you want to edit, then press the
ANYKEY button.
• The Add, Edit, Delete and Go To History List items
is displayed.
Timer Record List
HDD
No.
01
02
03
To
Current Time 12:00
Source
HDD
HDD
HDD
Add
Date
PR 02
PR 07
AV2
Start
End
01 JAN 12 : 00
15 JAN 14 : 10
01 JAN 15 : 10
Add a list
14 : 00
14 : 30
15 : 30
Deleting a Timer
Record List
Follow these directions to delete an entry from the timer
record list.
Mode VPS/PDC
SP
SP
SP
On
On
On
Edit
Delete
Go ToTime
History List
Available
HDD
29:10 SP
MOVE
SELECT
RETURN
EXIT
Using the TIMER button
4
Press the …† buttons to select Edit, then press the
OK or √ button.
• The Timer Record Input item is displayed.
Edit the items you want to modify. See the “Making a
Timer Recording” section for more information on
Timer Recording Input items.(See pages 86 to 87)
1
With the unit in Stop mode/Playback mode, press
the TIMER button. The Programme screen is
displayed.
Programme
HDD
√
Timer Record
Title
Timer Record List
HDD
No.
To
Music
Current Time 12:00
Source
Date
Start
End
Mode VPS/PDC
To
Source
Date
Start
End
HDD
PR 02
01 JAN
12 : 00
14 : 00
Available Time
HDD
HDD
MOVE
Programme
Mode VPS/PDC
SP
Title
Available Time
Add a list
Title No. 01
Setup
Off
Save
MOVE
SELECT
RETURN
EXIT
29:10 SP
29:10 SP
SELECT
RETURN
EXIT
Using the MENU button.
5
Press the OK button to select Save, then press the
OK button to confirm the edited setting.
6
Press the MENU button after finishing the operation.
The Timer Record List screen will disappear.
• Press the …† buttons to select Programme,
then press the OK or √ button.
2
Press the OK or √ button to select Timer Record.
Timer Record List
HDD
Current Time 12:00
No.
To
Source
01
02
03
HDD
HDD
HDD
PR 02
PR 07
AV2
Available Time
Date
HDD
MOVE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Start
01 JAN 12 : 00
15 JAN 14 : 10
01 JAN 15 : 10
Add a list
End
14 : 00
14 : 30
15 : 30
Mode VPS/PDC
SP
SP
SP
On
On
On
29:10 SP
SELECT
RETURN
EXIT
English - 89
Recording
• With the unit in Stop mode/Playback mode, press
the MENU button.
3
Press the …† buttons to select the number of the
Timer Record List you want to delete, and then
press the ANYKEY button.
• The Add, Edit, Delete and Go To History List
items are displayed.
Timer Record List
HDD
No.
01
02
03
To
Go To History List
You can confirm the performance results of title lists that have
passed the reserved recording time.
Current Time 12:00
Source
HDD
HDD
HDD
Add
Date
PR 02
PR 07
AV2
Start
01 JAN 12 : 00
15 JAN 14 : 10
01 JAN 15 : 10
Add a list
End
14 : 00
14 : 30
15 : 30
Mode VPS/PDC
SP
SP
SP
On
On
On
Edit
Delete
Go ToTime
History List
Available
HDD
MOVE
29:10 SP
SELECT
RETURN
EXIT
Using the TIMER button
4
Press the …† buttons to select Delete, then press
the OK or √ button.
• You will be prompted with the delete confirm
message such as “Do you want to delete No.01?”.
1
With the unit in Stop mode/Playback mode, press
the TIMER button. The Programme screen is
displayed.
Programme
Timer Record List
HDD
No.
To
01
02
03
HDD
HDD
HDD
HDD
Current Time 12:00
Source
Date
Start
End
PR 02 01 JAN 12 : 00 14 : 00
PR
JAN to 14
: 10 No.01?
14 : 30
Do07you15want
delete
AV2
01 JAN 15 : 10 15 : 30
Yes Add a list No
SP
SP
SP
√
Timer Record
Title
Mode VPS/PDC
Music
On
On
On
Programme
Setup
Available Time
HDD
MOVE
29:10 SP
SELECT
RETURN
MOVE
EXIT
SELECT
RETURN
EXIT
Recording
Using the MENU button.
5
Press the œ √ buttons to select Yes, then press the
OK button.
• The selected entry will be deleted from the list.
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Programme,
then press the OK or √ button.
Timer Record List
HDD
Current Time 12:00
No.
To
Source
01
02
HDD
HDD
PR 07
AV2
Date
Start
15 JAN 14 : 10
01 JAN 15 : 10
Add a list
End
14 : 30
15 : 30
Mode VPS/PDC
SP
SP
On
On
2
Press the OK or √ button to select Timer Record.
Timer Record List
HDD
Available Time
HDD
MOVE
6
No.
29:10 SP
SELECT
RETURN
To
Current Time 12:00
Source
Date
EXIT
Available Time
Press the MENU button after finishing the operation.
The Timer Record List screen will disappear.
Downloaded From90
DvDPlayer-Manual.com
Samsung Manuals
- English
Start
End
Mode VPS/PDC
Add a list
HDD
MOVE
29:10 SP
SELECT
RETURN
EXIT
3
Information about History List
Press the ANYKEY button.
• The Add and Go To History List items is
displayed.
Informs whether the selected History List performed a
Timer Recording successfully.
Timer Record List
HDD
Current Time 12:00
No.
To
Source
Date
Start
End
01
--
---
-- / --
--:--
--:--
Mode VPS/PDC
--
--
-1 Press the …† buttons to select the number of the
History List, then press the ANYKEY button.
5
History List
HDD
Add
Go ToTime
History List
Available
HDD
MOVE
29:10 SP
No. Source
SELECT
RETURN
EXIT
Date
01 PR 02 01 JAN
02 PR 07 15 JAN
03 AV2 01 JAN
Info
Start
End Mode VPS/PDC To
12 : 00 14 : 00
14 : 10 14 : 30
15 : 10 15 : 30
SP
SP
SP
On
On
On
HDD
HDD
HDD
Status
OK
OK
OK
Delete
List Clear
4
Press the …† buttons to select Go To History List,
then press the OK or √ button.
The History List screen is displayed.
History List
HDD
No. Source
01
02
03
Date
PR 02 01 JAN
PR 07 15 JAN
AV2 01 JAN
Start
End Mode VPS/PDC To
12 : 00 14 : 00
14 : 10 14 : 30
15 : 10 15 : 30
SP
SP
SP
On
On
On
HDD
HDD
HDD
Status
Go To Timer Rec List
MOVE
SELECT
RETURN
EXIT
Press the …† buttons to select Info, then press the
OK or √ button.
6
OK
OK
OK
History List
HDD
No. Source
MOVE
SELECT
RETURN
01
02
03
EXIT
Date
Start
End Mode VPS/PDC To
PR 02 01 JAN 12 : 00 14 : 00 SP
On
HDD
PR 07 Timer
15 JAN rec
14 was
: 10 finished
14 : 30 SPsuccessfully
On
HDD
AV2 01 JAN 15 : 10 15 : 30 SP
On
HDD
Status
OK
OK
OK
OK
MOVE
5
SELECT
RETURN
EXIT
Press the MENU button after finishing the operation.
The History List screen will disappear.
Recording
Delete History List
Deletes a History List individually.
-1 Press the …† buttons to select the number of
the history list you want to delete, and then press
the ANYKEY button.
5
History List
HDD
No. Source
Date
01 PR 02 01 JAN
02 PR 07 15 JAN
03 AV2 01 JAN
Info
Start
End Mode VPS/PDC To
12 : 00 14 : 00
14 : 10 14 : 30
15 : 10 15 : 30
SP
SP
SP
On
On
On
HDD
HDD
HDD
Status
OK
OK
OK
Delete
List Clear
Go To Timer Rec List
MOVE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
SELECT
RETURN
EXIT
English - 91
Go To Timer Rec List
Press the …† buttons to select Delete, then press
the OK or √ button.
6
History List
HDD
No. Source
01
02
03
Date
Start
End Mode VPS/PDC To
PR 02 01 JAN 12 : 00 14 : 00 SP
On
HDD
PR 07 15 JAN
14 : 10
14 to
: 30delete
SP No.01?
On
HDD
Do you
want
AV2 01 JAN 15 : 10 15 : 30 SP
On
HDD
Yes
Status
Switches directly from the History List to the Timer Rec List.
-1 Press the ANYKEY button.
5
OK
OK
OK
History List
HDD
No
No. Source
MOVE
SELECT
RETURN
Date
01 PR 02 01 JAN
02 PR 07 15 JAN
03 AV2 01 JAN
Info
EXIT
Start
End Mode VPS/PDC To
12 : 00 14 : 00
14 : 10 14 : 30
15 : 10 15 : 30
SP
SP
SP
On
On
On
HDD
HDD
HDD
Status
OK
OK
OK
Delete
List Clear
Go To Timer Rec List
MOVE
6
Clear History List
SELECT
RETURN
EXIT
Press the …† buttons to select Go To Timer Rec
List, then press the OK or √ button.
Clears all History Lists at once.
Timer Record List
HDD
No.
To
Current Time 12:00
Source
Date
-1 Press the ANYKEY button.
5
Start
End
Mode VPS/PDC
Add a list
History List
Available Time
HDD
No. Source
Date
01 PR 02 01 JAN
02 PR 07 15 JAN
03 AV2 01 JAN
Info
Start
End Mode VPS/PDC To
12 : 00 14 : 00
14 : 10 14 : 30
15 : 10 15 : 30
SP
SP
SP
On
On
On
HDD
HDD
HDD
Status
OK
OK
OK
Delete
Recording
List Clear
Go To Timer Rec List
MOVE
6
SELECT
RETURN
EXIT
Press the …† buttons to select List Clear, then
press the OK or √ button.
History List
HDD
No. Source
01
02
03
PR 02
PR 07
AV2
Date
Start
End Mode VPS/PDC To
01 JAN 12 : 00 14 : 00 SP
On
HDD
15 JAN
14 : 10 to14delete
: 30 SP
On list?
HDD
Do
you want
a history
01 JAN 15 : 10 15 : 30 SP
On
HDD
Yes
MOVE
Status
OK
OK
OK
No
SELECT
RETURN
EXIT
Downloaded From92
DvDPlayer-Manual.com
Samsung Manuals
- English
HDD
MOVE
29:10 SP
SELECT
RETURN
EXIT
Editing
This section introduces basic functions of
editing and explains both edit functions for the
recording on a disc and edit functions for the
entire disc.
• Title List
Title List is a list of previously recorded programmes. If
a title is deleted, that title cannot be played again.
Basic Editing (Title List) . . . . . . . . . . . . . . . . . . . . .94
Advanced Editing (Playlist) . . . . . . . . . . . . . . . . . .101
Copying from HDD to DVD . . . . . . . . . . . . . . . . . .109
Copying Multiple Titles at One Time . . . . . . . . . . .112
Copying from DVD to HDD . . . . . . . . . . . . . . . . . .116
This refers to a unit of playback, which is made by
selecting a desired scene in the entire Title List.
When one playlist is played, only the scene selected by
the user will play and then stop. Since only the
information necessary for playing a desired scene is
included in a playlist, even if that playlist is deleted, the
original stream will not be deleted.
Recording or editing might not be completed if an
error, such as a sudden power failure occurs.
Please be aware that a material that has been
damaged is unable to be retrieved to its
original content.
Copying MP3 or JPEG Files from a Disc to HDD . . .117
Disc Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 93
Editing
• Play List
Basic Editing (Title List)
3
Press the …† buttons to select Rename, then press
the OK or √ button.
The Rename screen is displayed.
Rename
HDD
Renaming(Labeling) a Title
1 8 / JAN / 2005 12:15 AV3
Follow these instructions to rename a title list entry,
i.e., to edit the title of a recorded programme.
Back Space
MOVE
Using the TITLE LIST button
1
4
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
Space Delete
SELECT
Clear
RETURN
Save
EXIT
Select the desired characters using the …† œ √
buttons, press the OK button.
Rename
HDD
Sports(A1)
Title List
HDD
No.
001
002
003
004
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
Back Space
MOVE
Space Delete
SELECT
Clear
RETURN
Save
EXIT
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
• Back Space: Deletes and moves the cursor
backwards by one position. (Equivalent to the
CANCEL button)
• Space: Enters a blank and moves the cursor one
forward (to the right).
• Delete: Deletes the character at the cursor position.
• Clear: Deletes all the character inputs.
• Save: Registers the character inputs.
1/1 Page
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Title,
Editing
then press the OK or √ button twice.
2
Press the …† buttons to select an entry you want to
rename from the Title List, then press the ANYKEY
button.
5
Press the …† œ √ buttons to select Save, and then
press the OK button.
The changed title name is displayed on the title item
of the selected entry.
Title List
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
HDD
No.
00:10:21
00:40:03
00:20:15
00:50:16
001
002
003
004
Title
Sports(A1)
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
Sports(A1)
18/JAN/2005 12:15
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
Title List
Length
SP
1/1 Page
SELECT
RETURN
EXIT
Downloaded From94
DvDPlayer-Manual.com
Samsung Manuals
- English
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Locking (Protecting) a Title
Follow these instructions to lock an entry to protect it
from accidental deletion.
3
Press the …† buttons to select Protection, then press
the OK or √ button.
Title List
HDD
Title Protection:
18/JAN/2005 12:15 AV3
Using the TITLE LIST button
V-Mode Compatibility
MOVE
With the unit in Stop mode/Playback mode, press the
TITLE LIST button .
The Title List screen is displayed.
Title List
HDD
No.
001
002
003
004
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
4
001
002
003
004
1/1 Page
SELECT
RETURN
EXIT
Title List
No.
18/JAN/2005 12:15
MOVE
RETURN
00:10:21
00:40:03
00:20:15
00:50:16
HDD
V-Mode Compatibility
SELECT
Press the œ √ buttons to select On, then press the
OK button. The key icon on the information window
for the selected entry changes to the locked status.
( ➝ )
18/JAN/2005 12:15 AV3
SP
Off
18/JAN/2005 12:15
SP
1
On
EXIT
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
Using the MENU button.
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
• With the unit in Stop mode/Playback mode,
press the MENU button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
2
Press the …† buttons to select an entry you want to
protect from the Title List, then press the ANYKEY
button.
Title List
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
Length
Editing
HDD
Rename
00:10:21
00:40:03
00:20:15
00:50:16
1/1 Page
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 95
3
Deleting a Title
Press the …† buttons to select Delete, then press the
OK or √ button.
Follow these instructions to delete an entry from the
Title List.
Title List
HDD
Do you want to delete?
(Related playlists
may be deleted.)
18/JAN/2005 12:15 AV3
Using the TITLE LIST button
SP
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
No.
001
002
003
004
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
SELECT
RETURN
EXIT
• The message may be different depending on the type of
disc. You will be prompted with the confirmation
message. HDD, DVD-RAM(VR mode), DVDRW(VR mode): If a Playlist is present, the
message “Do you want to delete? (Related
playlists may be deleted.)” is displayed.
DVD-RW(Video mode)/-R: If a Playlist is not
present, the message “Do you want to delete?” is
displayed.
Title List
HDD
No
V-Mode Compatibility
MOVE
1
Yes
18/JAN/2005 12:15
1/1 Page
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Title,
4
Press the œ √ buttons to select Yes, then press the OK
button.
Title List
HDD
then press the OK or √ button twice.
Deleting...
(Please wait.)
2
Press the …† buttons to select an entry you want to
delete in the Title List, then press the ANYKEY button.
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
Title List
HDD
Rename
No.
Protection
001
002
003
004
Copy
Editing
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
Title List
HDD
No.
Title
Length
001 19/JAN/2005 12:15A 00:40:03
002 20/JAN/2005 12:15A 00:20:15
003 25/JAN/2005 12:15A 00:50:16
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
Length
1/1 Page
SELECT
RETURN
19/JAN/2005 12:15 AV3
EXIT
19/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
Downloaded From96
DvDPlayer-Manual.com
Samsung Manuals
- English
1/1 Page
SELECT
RETURN
EXIT
■
NOTE
You cannot delete a protected entry. If you
want to delete a protected entry, select
“Off” in the Title Protection menu. (See
page 95)
■
When the Disc Protection has been set to
Protected, you cannot delete titles. (See
page 120)
■
Once an entry is deleted from the Title List
it cannot be recovered.
■
Once DVD-RW/-R is finalised, it cannot be
deleted.
Splitting a Section of a Title (Split)
Follow these instructions to split a section of a Title
List entry into two titles.
Using the TITLE LIST button
1
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
Title List
HDD
No.
001
002
003
004
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode, press
the MENU button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
2
Press the …† buttons to select an entry you want to
Split from the Title List, then press the ANYKEY button.
Title List
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
19/JAN/2005 12:15AV3
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√
Navigation
19/JAN/2005 12:15
√
Select Media
SP V-Mode Compatibility
Disc Manager
MOVE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Length
00:10:21
00:40:03
00:20:15
00:50:16
1/1 Page
SELECT
RETURN
EXIT
English - 97
Editing
HDD
Rename
3
Press the …† buttons to select Edit, then press the
OK or √ button.
The Edit menu is displayed.
Split
HDD
18/JAN/2005 12:15AV3
Title List No. 001
Split 1
Split 2
00:00:00
00:05:21
Title List
HDD
Rename
No.
Protection
001 18/JAN/2005 12:15A
002 19/JAN/2005 12:15A
003 20/JAN/2005 12:15A
004Split25/JAN/2005 12:15A
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
00:10:21
00:40:03
00:20:15
00:50:16
00:05:21
Select
√
Select Media
V-Mode Compatibility
Disc Manager
Return
MOVE
SELECT
RETURN
EXIT
1/1 Page
SELECT
RETURN
EXIT
6
4
Split
Partial Delete
SP
MOVE
Length
Press the …† buttons to select Split, then press the
OK or √ button.
Press the OK button to select Split.
The message “This title cannot be recovered after
splitting. Do you want to split?” is displayed.
Split
Split
HDD
HDD
18/JAN/2005 12:15AV3
18/JAN/2005 12:15AV3
Title List No. 05
Title List No. 001
Split 1
Split 1
Split 2
This title cannot be recovered after spliting.
Split 2
Do you want to split?
Yes
00:00:00
Split
MOVE
5
Split
Return
SELECT
RETURN
MOVE
7
18/JAN/2005 12:15 AV3
Title List No. 001
Editing
Split
MOVE
SP
00:05:21
Return
SELECT
RETURN
Title
Length
004 20/JAN/2005 12:15A 00:20:15
005 25/JAN/2005 12:15A 00:50:16
18/JAN/2005 12:15
Split 2
00:05:21
Select
EXIT
001 18/JAN/2005 12:15A 00:05:21
002 18/JAN/2005 12:15A 00:05:00
003 19/JAN/2005 12:15A 00:40:03
Split
①
RETURN
Title List
No.
18/JAN/2005 12:15AV3
00:00:00
SELECT
Press the œ √ buttons to select Yes, then press the
OK button.
The split title is divided into two, and the following titles
will be shifted down by one.
HDD
Split 1
Return
EXIT
Using the playback-related buttons (PLAY( ),
SEARCH (
)), move to a point for
splitting and press the OK button.
If it is not the point where you want to split, press the
RETURN button to cancel the selection. Using the
playback-related buttons, move to a point to split and
press the OK button.
HDD
00:05:21
No
00:05:21
Select
00:00:00
Select
00:00:00
00:00:00
EXIT
① First split interval
➁ Current playtime
➂ Start time of the second split and its screen
Downloaded From98
DvDPlayer-Manual.com
Samsung Manuals
- English
➂
➁
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Deleting a Section of a Title (Partial
Delete)
3
Follow these instructions to delete a section of a
Title List entry.
Press the …† buttons to select Edit, then press the
OK or √ button.
The Edit Title List screen is displayed.
Title List
HDD
Rename
No.
Protection
001 18/JAN/2005 12:15A
002 19/JAN/2005 12:15A
003 20/JAN/2005 12:15A
004Split25/JAN/2005 12:15A
Copy
(VR mode)
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
√
Select Media
V-Mode Compatibility
Disc Manager
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
MOVE
4
Length
00:10:21
00:40:03
00:20:15
00:50:16
Partial Delete
SP
Using the TITLE LIST button
1
Title
1/1 Page
SELECT
RETURN
EXIT
Press the …† buttons to select Partial Delete, then
press the OK or √ button.
Partial Delete
HDD
18/JAN/2005 12:15AV3
Title List No. 001
Title List
HDD
No.
001
002
003
004
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
Start
End
00:00:00
00:00:00
00:01:00
Start
18/JAN/2005 12:15 AV3
End
18/JAN/2005 12:15
SP
MOVE
V-Mode Compatibility
MOVE
Return
SELECT
RETURN
EXIT
1/1 Page
SELECT
RETURN
EXIT
5
Using the MENU button.
Press the OK button at the starting point.
The image and starting point time is displayed in the
section deletion starting point window.
• With the unit in Stop mode/Playback mode,
press the MENU button.
• Press the …† buttons to select Title,
Partial Delete
HDD
then press the OK or √ button twice.
2
Delete
Press the …† buttons to select an entry you want to
edit from the Title List, then press the ANYKEY button.
18/JAN/2005 12:15AV3
Title List No. 001
Start
End
00:01:00
00:00:00
00:01:00
Start
End
Delete
MOVE
Return
SELECT
RETURN
EXIT
Title List
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
Length
Editing
HDD
Rename
00:10:21
00:40:03
00:20:15
00:50:16
1/1 Page
SELECT
RETURN
EXIT
• When using a DVD-RAM/-RW(VR) disc, you can
select Partial Delete directly by pressing the
ANYKEY button.
(Then go to step 5)
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 99
Edit Title List Screen Elements
7
Press the œ √ buttons to select Delete, then press
the OK button.
Partial Delete
HDD
18/JAN/2005 12:15AV3
Partial Delete
Title List No. 001
Start
HDD
End
18/JAN/2005 12:15AV3
Title List No. 001
00:01:00
①
00:00:00
00:06:35
Start
End
Delete
MOVE
Return
SELECT
RETURN
➃
➁
End
00:01:00
00:06:35
00:06:35
EXIT
Start
End
➂
Delete
MOVE
① Playback bar
➁ Playtime
➂ Section deletion starting point window and time
➃ Section deletion end point window and time
• Select the start and end points of the section you
want to delete using the playback related buttons.
• Playback related buttons :
(PLAY( ), SEARCH (
))
6
Start
Press the OK button at the end point.
The image and end point time is displayed in the
Section deletion ending point window.
Return
SELECT
RETURN
EXIT
Partial Delete
HDD
18/JAN/2005 12:15AV3
Title List No. 001
Start
Do you want to delete?
End
(Deleted part will not be restored.)
00:01:00
Yes
Start
End
Delete
MOVE
00:02:00
No
00:06:35
Return
SELECT
RETURN
EXIT
8
Press the œ √ buttons to select Yes, then press the
OK button. The selected section has been deleted.
9
Press the œ √ buttons to select Return, then press
the OK button to finish the operation.
Title List
HDD
18/JAN/2005 12:15AV3
Title List No. 001
Start
End
00:01:00
00:06:35
00:06:35
Start
End
Delete
MOVE
Return
SELECT
RETURN
EXIT
■
The length of the section to be deleted
must be at least 5 seconds long.
■
If the length of the section to be deleted is
less than 5 seconds, you will be prompted
with the message “The range is too
short.”.
■
If the end time precedes the starting time,
you will be prompted with the message
“End point cannot be marked earlier than
start point”.
■
The section cannot be deleted when it
includes a still picture.
■
Press the MENU button after the operation has
finished.
The Title List screen will disappear.
Editing
NOTE
Downloaded From100
DvDPlayer-Manual.com
Samsung Manuals
- English
3
Advanced Editing
(Playlist)
Press the …† buttons to select New Playlist,
then press the OK or √ button.
The Make Playlist screen is displayed.
Make Playlist
HDD
New Playlist
Scene No. 001
Creating a Playlist
Follow these instructions to create a new playlist entry
from a recorded title.
Title List 1/4
Start
End
00:00:00
00:00:00
00:00:10
Start
End
Make
MOVE
Return
SELECT
RETURN
EXIT
(VR mode)
Using the TITLE LIST button
1
4
Press the OK button at the start point.
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
Make Playlist
HDD
New Playlist
Scene No. 001
Title List 1/4
Start
End
00:00:10
00:00:00
Title List
HDD
No.
001
002
003
004
Title
00:00:10
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Start
End
00:10:21
00:40:03
00:20:15
00:50:16
Make
MOVE
Return
SELECT
RETURN
EXIT
18/JAN/2005 12:15 AV3
• The image and time at the start point is displayed on
the Start window.
• The yellow-coloured selection bar moves to the End
item.
• Select the starting point of the section from which you
want to create a new scene using the playback
related buttons (PLAY( ), SEARCH (
)).
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
5
Press the OK button at the end point.
Make Playlist
HDD
New Playlist
Scene No. 001
Title List 1/4
Start
End
00:00:10
00:10:10
00:10:10
Title List
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Edit
√
Playlist
√
New Playlist
Navigation
√
Go To Playlist
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
√
Select Media
SP V-Mode Compatibility
Disc Manager
MOVE
Length
00:10:21
00:40:03
00:20:15
00:50:16
1/1 Page
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Editing
2
Press the ANYKEY button.
Press the …† buttons to select Playlist, then
press the OK or √ button.
Start
End
MOVE
Make
Return
SELECT
RETURN
EXIT
• The image and end point time is displayed in the
End window.
• The yellow-coloured selection bar moves to the
Make item.
English - 101
Playing Entries in the Playlist
6
Press the œ √ buttons to select Make,
then press the OK button.
• To make a scene for the playlist.
A new Make scene screen is displayed.
Repeat steps 4~6 to make a new scene for the
playlist.
A new scene will be added to the current playlist.
You can check and see all the scenes on the Edit
playlist screen. (See page 104)
• To make a new playlist.
Repeat steps 1~6 if you want to make a new playlist.
7
Follow these instructions to play the playlist entries.
(VR mode)
Using the PLAY LIST button
1
Press the œ √ button to select Return,
then press the OK button to finish the operation.
With the unit in Stop mode/Playback mode, press the
PLAY LIST button.
The Playlist screen is displayed.
Playlist
■
NOTE
■
You can create up to 99 playlist entries.
HDD
No.
001
002
003
004
Depending on the kind of disc, the
displayed screen may have a slight
difference.
Title
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
16/JAN/2005 12:15 AV3
16/JAN/2005 12:15
7 Scenes
1/1 Page
MOVE
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
The Title List screen is displayed.
• Press the ANYKEY button.
• Press the …† buttons to select Playlist, then press
the OK or √ button.
Editing
• Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
Downloaded From102
DvDPlayer-Manual.com
Samsung Manuals
- English
2
Press the …† buttons to select the playlist you
want to play, then press the OK or PLAY ( )
button.
3
Press the STOP ( ) button to stop playing.
The screen returns to the Playlist screen.
Renaming a Playlist Entry
Follow these instructions to rename a playlist entry, i.e.
to edit the title of a playlist entry.
3
(VR mode)
Press the …† buttons to select Rename, then press
the OK or √ button.
The Rename screen is displayed.
Rename
HDD
1 8 / JAN / 2005 12:15 AV3
Using the PLAY LIST button
Back Space
1
With the unit in Stop mode/Playback mode, press the
PLAY LIST button.
The Edit Playlist screen is displayed.
Playlist
HDD
No.
001
002
003
004
Title
Length
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
MOVE
4
Space Delete
SELECT
Clear
Save
RETURN
EXIT
Select the desired characters using the …† œ √
buttons, then press the OK button.
00:10:21
00:40:03
00:20:15
00:50:16
Rename
HDD
16/JAN/2005 12:15 AV3
Dolphin
16/JAN/2005 12:15
7 Scenes
1/1 Page
MOVE
SELECT
RETURN
EXIT
Back Space
Using the MENU button.
MOVE
• With the unit in Stop mode/Playback mode,
press the MENU button.
Space Delete
SELECT
Clear
Save
RETURN
EXIT
• This function is the same as the Rename function in
Renaming the Title. (See page 94)
• The maximum number of characters that can be
entered is 31. All 31 characters can be displayed
by pressing the INFO button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
The Title List screen is displayed.
• Press the ANYKEY button.
• Press the …† buttons to select Playlist, then press
the OK or √ button.
• Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
Press the …† buttons to select the title you want to
Rename from the Playlist, then press the ANYKEY
button.
ANYKEY menu is displayed : Rename, Copy, Delete,
Edit Playlist, Go To Titlelist, Disc Manager
Press the …† œ √ buttons to select Save, then press
the OK button.
The changed title is displayed in the title field of the
selected playlist entry.
Playlist
HDD
No.
001
002
003
004
Title
Length
00:10:21
19/JAN/2005 12:15A 00:40:03
22/JAN/2005 12:15A 00:20:15
25/JAN/2005 12:15A 00:50:16
Dolphin
Dolphin
16/JAN/2005 12:15
Playlist
HDD
No.
001
002
003
004
Rename
Copy
Title
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
7 Scenes
1/1 Page
Length
00:10:21
00:40:03
00:20:15
00:50:16
MOVE
SELECT
RETURN
EXIT
Delete
16/JAN/2005 12:15AV3
Edit Playlist
16/JAN/2005 12:15
Go To Titlelist
7 Scenes
1/1 Page
Disc Manager
MOVE
SELECT
RETURN
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 103
Editing
2
5
Editing a Scene for the Playlist
Follow these instructions to edit scenes for a playlist.
3
Press the …† buttons to select Edit Playlist,
then press the OK or √ button.
The Edit Scene screen is displayed.
(VR mode)
Edit Playlist
HDD
Playlist No. 1
Using the PLAY LIST button
1
01
00:00:26
02
0:00:07
03
00:06:04
05
0:00:26
06
00:01:07
07
00:00:00
With the unit in Stop mode/Playback mode, press the
PLAY LIST button.
The Edit Playlist screen is displayed.
04
0:00:03
1/1 Page
MOVE
Return
SELECT
RETURN
EXIT
Playlist
HDD
No.
001
002
003
004
Title
Length
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
16/JAN/2005 12:15 AV3
4
16/JAN/2005 12:15
7 Scenes
1/1 Page
MOVE
SELECT
Playing a Selected Scene
RETURN
EXIT
Press the …†œ √ buttons to select the scene you
want to play, then press the ANYKEY button.
The playlist entry to be played is selected.
Using the MENU button.
Edit Playlist
HDD
• With the unit in Stop mode/Playback mode,
press the MENU button.
01
• Press the …† buttons to select Title,
Editing
2
Press the …† buttons to select the title you want to
edit from the Playlist, then press the ANYKEY button.
The Edit Playlist menu is displayed: Rename, Copy,
Delete, Edit Playlist, Go To Titlelist, Disc Manager.
02
0:00:07
03
00:06:04
06
00:01:07
07
00:00:00
04
0:00:03
Modify
Move
then press the OK or √ button twice.
The Title List screen is displayed.
• Press the ANYKEY button.
• Press the …† buttons to select Playlist, then press
the OK or √ button.
• Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
0:00:26
Play
Playlist No. 1
05
Add0:00:26
Delete
1/1 Page
MOVE
5
SELECT
Return
RETURN
EXIT
Press the …† buttons to select Play, then press the
OK or √ button.
The selected scene is played.
√ Play
Playlist
HDD
No.
001
002
003
004
Rename
Copy
Title
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
Delete
16/JAN/2005 12:15AV3
• To stop scene play, press the STOP (
Edit Playlist
16/JAN/2005 12:15
Go To Titlelist
7 Scenes
1/1 Page
Disc Manager
MOVE
SELECT
RETURN
EXIT
Downloaded From104
DvDPlayer-Manual.com
Samsung Manuals
- English
) button.
Modifying a Scene (Replacing a Scene)
7
Press the OK button at the end point of the scene.
To setup, follow steps 1 to 3 in page 104.
Modify Scene
4
HDD
Press the …† œ √ buttons to select the scene you
want to modify, then press the ANYKEY button.
16/JAN/2005 12:15
Scene No. 001
Title List 1/9
Start
End
00:00:20
00:00:30
00:00:30
Edit Playlist
HDD
Start
End
Change
MOVE
01
Cancel
Playlist No. 1
0:00:26
Play
02
0:00:07
03
00:06:04
06
00:01:07
07
00:00:00
04
SELECT
RETURN
EXIT
0:00:03
Modify
Move
05
Add0:00:26
Delete
1/1 Page
MOVE
• The image and ending point time is displayed in the
End window.
Return
SELECT
RETURN
EXIT
8
5
Press the œ √ buttons to select Change, then press
the OK button.
Press the …† buttons to select Modify, then press the
OK or √ button.
The Modify Scene screen is displayed.
Edit Playlist
HDD
Playlist No. 1
01
0:00:26
02
0:00:07
03
00:00:04
05
0:00:26
06
00:01:07
07
00:00:00
04
0:00:03
Modify Scene
HDD
16/JAN/2005 12:15
1/1 Page
Scene No. 001
Title List 1/9
Start
End
00:00:00
00:00:00
MOVE
00:00:20
End
Start
Change
MOVE
6
Cancel
SELECT
RETURN
SELECT
Return
RETURN
EXIT
• The scene you want to modify is changed with the
selected section.
EXIT
Press the OK button at the start point of the scene.
Modify Scene
HDD
16/JAN/2005 12:15
Title List 1/9
End
00:00:20
00:00:00
Editing
Scene No. 001
Start
00:00:20
Start
End
Change
MOVE
Cancel
SELECT
RETURN
EXIT
• The image and starting point time is displayed
on the Start window.
• Select the starting or ending point of the
section you want to modify using the playback
related buttons (PLAY( ), SEARCH (
)).
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 105
Moving a Scene (Changing the Position of a Scene)
6
To setup, follow steps 1 to 3 in page 104.
4
Press the …† œ √ buttons to select the position
to which you want to move the selected scene,
then select the OK button.
Edit Playlist
Press the …† œ √ buttons to select the scene you
want to move (change the position), then press the
ANYKEY button.
HDD
Playlist No. 1
01
00:00:26
02
00:00:07
03
00:00:04
05
00:00:26
06
00:00:07
07
00:00:00
Edit Playlist
HDD
1/1 Page
0:00:26
Play
02
0:00:07
03
00:06:04
06
00:01:07
07
00:00:00
04
Cancel
Delete
1/1 Page
MOVE
SELECT
RETURN
EXIT
• The selected scene is moved to the selected
position.
Move
Add
0:00:26
SELECT
0:00:03
Modify
05
00:00:03
Playlist No. 1
MOVE
01
04
Return
RETURN
EXIT
Edit Playlist
HDD
5
Press the …† buttons to select Move, then press the
OK or √ button.
Playlist No. 1
01
00:00:07
02
00:00:04
03
00:00:03
05
00:00:26
06
00:00:07
07
00:00:00
04
1/1 Page
MOVE
Edit Playlist
HDD
01
05
00:00:26
00:00:26
SELECT
00:00:26
Return
RETURN
EXIT
Playlist No. 1
02
06
00:00:07
00:01:07
03
07
00:00:04
04
00:00:00
1/1 Page
MOVE
SELECT
00:00:03
■
You cannot move the selected scene to
the position of the next scene, because
the selected scene should be inserted
before that position, which requires no
action.
■
Depending on the kind of disc, the
displayed screen may have a slight
difference.
NOTE
Cancel
RETURN
EXIT
Editing
• A yellow selection window is displayed on the
scene to be moved.
Downloaded From106
DvDPlayer-Manual.com
Samsung Manuals
- English
7
Adding a Scene
Press the OK button at the end point of the scene.
Add Scene
HDD
To setup, follow steps 1 to 3 in page 104.
4
01/JAN/2005 12:15
Scene No. 001
Press the …† œ √ buttons to select the scene that
will have a new scene inserted before it, then press
the ANYKEY button.
Title List : 1/7
Start
End
00:00:15
00:00:35
00:00:35
Start
End
Add
Cancel
MOVE
SELECT
RETURN
EXIT
Edit Playlist
HDD
01
Playlist No. 1
0:00:26
Play
02
0:00:07
03
00:00:04
02
00:00:07
07
00:00:00
04
• The image and end point time are displayed in
the End window.
• To cancel, press the œ √ buttons to select Cancel,
then press the OK button.
0:00:03
Modify
Move
01
Add0:00:26
Delete
1/1 Page
MOVE
Return
SELECT
RETURN
EXIT
8
5
Press the œ √ buttons to select Add, then press the OK
button.
Press the …† buttons to select Add, then press the
OK or √ button.
The Add Scene screen is displayed.
Edit Playlist
HDD
Playlist No. 1
01
00:00:26
02
00:00:07
03
00:00:04
05
00:00:26
06
00:00:07
07
00:00:00
04
00:00:03
Add Scene
HDD
01/JAN/2005 12:15
Scene No. 001
Title List : 1/7
1/1 Page
Start
End
00:00:00
00:00:00
MOVE
SELECT
Cancel
RETURN
EXIT
00:00:00
End
Start
Add
MOVE
6
Cancel
SELECT
RETURN
EXIT
• The section you want to add is inserted prior to the
scene selected in step 4 of Adding a Scene on the
previous page.
Press the OK button at the starting point of the scene.
Add Scene
HDD
01/JAN/2005 12:15
Title List : 1/7
End
00:00:15
00:00:00
Editing
Scene No. 001
Start
00:00:15
Start
End
MOVE
Add
Cancel
SELECT
RETURN
EXIT
• The image and starting point time is displayed
on the Start window.
• Select the starting or ending point of the
section you want to modify using the playback
related buttons (PLAY( ), SKIP (
)).
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 107
Deleting a Scene
Deleting a Playlist Entry from the
Playlist
To setup, follow steps 1 to 3 in page 104.
4
Using the PLAY LIST button
Press the …† œ √ buttons to select the scene you
want to delete, then press the ANYKEY button.
Edit Playlist
HDD
01
0:00:26
Play
Playlist No. 1
02
0:00:07
03
00:06:04
04
1
With the unit in Stop mode/Playback mode, press the
PLAY LIST button.
The Edit Playlist screen is displayed.
0:00:03
Playlist
Modify
HDD
Move
05
Add0:00:26
06
00:01:07
Delete
07
001
002
003
004
00:00:00
1/1 Page
MOVE
No.
Return
SELECT
RETURN
EXIT
Title
Length
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
16/JAN/2005 12:15 AV3
16/JAN/2005 12:15
7 Scenes
5
1/1 Page
MOVE
Press the …† buttons to select Delete, then press
the OK or √ button.
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
Edit Playlist
HDD
01
Playlist No. 1
the scene
0:00:26 Do02you want
0:00:07 to delete
03
00:06:04
04
Yes
05
0:00:26
06
then press the OK or √ button twice.
The Title List screen is displayed.
No
00:01:07
1/1 Page
MOVE
• Press the …† buttons to select Title,
? 0:00:03
SELECT
• Press the ANYKEY button.
Return
RETURN
EXIT
• Press the …† buttons to select Playlist, then press
the OK or √ button.
• The message “Do you want to delete the scene ?” is
displayed.
Press the œ √ buttons to select Yes,
then press the OK to delete the selected scene.
Editing
6
• Press the …† buttons to select Go To Playlist,
then press the OK or √ button.
2
Press the …† buttons to select the title you want to
edit from the Playlist, then press the ANYKEY button.
The Edit Playlist menu is displayed:Rename, Copy,
Delete, Edit Playlist, Go To Titlelist, Disc Manager.
Playlist
HDD
No.
001
002
003
004
Rename
Copy
Title
16/JAN/2005 12:15A
19/JAN/2005 12:15A
22/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
Delete
16/JAN/2005 12:15AV3
Edit Playlist
16/JAN/2005 12:15
Go to Titlelist
7 Scenes
1/1 Page
Disc Manager
MOVE
Downloaded From108
DvDPlayer-Manual.com
Samsung Manuals
- English
SELECT
RETURN
EXIT
3
Press the …† buttons to select Delete, then press
the OK or √ button.
• You will be prompted with the delete confirmation
message “Do you want to delete?”.
Copying from HDD to
DVD
Playlist
HDD
About the Copy Screen
Do you want to delete?
16/JAN/2005 12:15 AV3
16/JAN/2005 12:15
Yes
Copy
No
MOVE
4
Copy To : HDD ➞ DVD
HDD
7 Scenes
SELECT
RETURN
!
@
EXIT
Press the œ √ buttons to select Yes, then press the
OK button.
You will be automatically returned to the Playlist screen
after the delete operation has finished.
No.
1
Title
Rec.Mode
01/JAN/2005 20:25A SP ➞ HS
Add a list
Length
00:01:40
Start
Rec. Mode
[DVD] Available
SP 02:00:32
#
$
4.48 GB
Total
00:01:40
0.05 GB
MOVE
SELECT
RETURN
%
^
&
*
EXIT
! Title to be copied
@ Add titles to be copied (up to 7 titles can be copied
at one time)
Playlist
# Recording mode for copying
HDD
Deleting...
(Please wait)
$
%
^
&
16/JAN/2005 12:15 AV3
16/JAN/2005 12:15
7 Scenes
*
Playlist
HDD
No.
Title
- HS(high speed): you can copy more quickly than
normal playback speed.
Copies in the same record mode as source title.
- XP/SP/LP/EP : you can not use high speed copy.
Record time of title to be copied
Copy start button
Record mode setup button
Remaining time and space on the current disc in
DVD Record mode
Total record time and space of selected titles for
copying
Length
001 19/JAN/2005 12:15A 00:40:03
002 22/JAN/2005 12:15A 00:20:15
003 25/JAN/2005 12:15A 00:50:16
Contents Copy Specifications
19/JAN/2005 12:15 AV3
19/JAN/2005 12:15
7 Scenes
1/1 Page
MOVE
SELECT
RETURN
EXIT
Contents
Recorded Video Title
Copy Protected Title
Once "Copy Once programme" has been recorded on the
DVD disc, this title cannot be copied to HDD anymore.
But "Copy Once programme" has been recorded on the
HDD, this title can be copied to DVD-RW(VR mode) or
DVD-RAM.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 109
Editing
Copy Once Title
HDD ➞ DVD
Supported
Not supported
Move
(Deletes the Title in the HDD after copying)
Using the TITLE LIST button
6
Press the ANYKEY button.
Title List
1
Press the OPEN/CLOSE button and place a
recordable disc on the disc tray.
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
2
Press the OPEN/CLOSE button to close the disc
tray. Wait until LOAD disappears from the front panel
display. Check that the disc has enough available
space for the recording.
3
Select the HDD by pressing the HDD button on the
front panel of the HDD & DVD RECORDER or on the
remote control.
4
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
19/JAN/2005 12:15
Title
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
7
1/1 Page
SELECT
RETURN
Copy
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
Length
00:10:21
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Start
Rec. Mode
Title List
No.
EXIT
Copy To : HDD ➞ DVD
HDD
1
001
002
003
004
00:10:21
00:40:03
00:20:15
00:50:16
Press the …† buttons to select Copy, then press the
OK or √ button.
Copy screen is displayed.
No.
HDD
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
[DVD] Available
LP 04:00:16
Length
4.48 GB
00:10:21
00:40:03
00:20:15
00:50:16
Total
00:10:21
0.25 GB
MOVE
SELECT
RETURN
EXIT
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
• If you want to change the record mode when copying,
see page 115.
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
8
Press the OK or √ button to select Start,
then press the OK button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
The Title List screen is displayed.
Copy
No.
1
Editing
5
Copy To : HDD ➞ DVD
HDD
Press the …† buttons to select the title you want to
copy.
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
Length
00:10:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
To move to other pages, press the SKIP(
buttons.
SKIP( ) : previous page of title list
SKIP( ) : next page of title list
Total
)
00:10:21
0.25 GB
MOVE
SELECT
RETURN
EXIT
- About Using COPY button Press the …† buttons to select title you want to
copy from the title list and then press the COPY
button on the remote control. You can go to copy
screen.
• During Playback, you can also copy the title by
pressing the COPY button.
Downloaded From110
DvDPlayer-Manual.com
Samsung Manuals
- English
- Copying a Title that has been edited
once before -
9
The “Do you want to view screen of copying title?”
message is displayed.
-1 To begin high speed copy, press the œ √ buttons to
select Yes, then press the OK button.
High speed copy begins. The title to be copied is not
played back, while the currently broadcasting
programme is displayed on the screen.
10
Copy
Copy To : HDD ➞ DVD
HDD
No.
1
Title
Rec.Mode
Length
18/JAN/2005 12:15A LP ➞ HS 00:10:21
Start
Do you want
view screen of copying title?
Add to
a list
Rec. Mode
Yes
No
[DVD] Available
LP
04: 08:47
Total
04: 08:47
MOVE
SELECT
RETURN
EXIT
HDD
1%
DVD
If you want to stop copy, press CANCEL key.
10
To copy a title while viewing the title on the copy
screen, press the œ √ buttons to select Yes, then
press the OK button.
• If No is selected, the title to be copied is displayed at
its playback speed while copying.
• To cancel the copying in progress, press the
CANCEL button.
-1 After a successful copy, “The title is successfully
copied” message is displayed.
11
HDD
1%
DVD
If you want to stop copy, press CANCEL key.
• If No is selected, the title to be copied is not displayed
on the screen, and copying begins while the currently
broadcasting programme is displayed on the screen.
• To cancel the copying in progress, press the
CANCEL button.
The title is successfully copied.
- Copying an Unedited title -1 The “Do you want to use high speed copy mode?”
message is displayed.
9
Editing
Copy
Copy To : HDD ➞ DVD
HDD
No.
1
Title
Rec.Mode
Length
18/JAN/2005 12:15A LP ➞ HS 00:10:21
Start
Do you want
use high speed copy mode?
Add to
a list
Rec. Mode
Yes
No
[DVD] Available
LP
04: 08:47
Total
04: 08:47
MOVE
■
NOTE
SELECT
RETURN
EXIT
High speed copy : This means that you
can transfer without having to worry about
the quality getting worse with each copy
‘generation’. It also means that copying
can be carried out at the maximum speed
possible.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 111
Changing the Record Mode
To setup, follow steps 1 to 7 in page 110.
8
Press the √ and † buttons to select Rec. Mode, then
press the OK button.
Copying Multiple Titles
at One Time
Using the TITLE LIST button
Copy
Copy To : HDD ➞ DVD
HDD
No.
1
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
Length
00:10:21
Start
Rec. Mode
XPAvailable
[DVD]
LPSP 04: 08:47
LP
EP Total
High 04:
Speed
08:47
MOVE
9
SELECT
RETURN
Press the OPEN/CLOSE button and place a
recordable disc on the disc tray.
2
Press the OPEN/CLOSE button to close the disc
tray. Wait until LOAD disappears from the front panel
display. Check that the disc has enough available
space for the recording.
3
Select the HDD by pressing the HDD button on the
front panel of the HDD & DVD RECORDER or on the
remote control.
4
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
EXIT
Press the …† buttons to select record mode you want
to record, then press the OK button.
• HS(High Speed) : Copies in the same record mode as
HDD.
• XP/SP/LP/EP : You cannot copy at a higher
quality mode than original. If the same record
mode is selected, the title is copied at high speed.
■
NOTE
■
■
■
■
Editing
1
Using the same method, you can copy a
Playlist.
High speed copying is not available for a title
list that has been partially deleted.
During copying, timer recording is not
available.
High speed copying is not available when:
- Copying a title that can only be copied once
- Copying a playlist
- Copying a partially-deleted title
Regarding title lists that can be copied only
once:
- Only available for DVD discs that support
CPRM
- If a playlist contains a scene that can only be
copied once, it cannot be copied.
Title List
HDD
001
002
003
004
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Using the MENU button.
• With the unit in Stop mode/Playback mode,
press the MENU button.
• Press the …† buttons to select Title,
then press the OK or √ button twice.
The Title List screen is displayed.
5
Downloaded From112
DvDPlayer-Manual.com
Samsung Manuals
- English
No.
Press the …† buttons to select the titles you want to
copy.
)
To move to other pages, press the SKIP (
buttons.
SKIP( ) : previous page of title list
SKIP( ) : next page of title list
6
9
Press the ANYKEY button.
Title List
HDD
Rename
No.
Protection
001
002
003
004
Copy
Delete
Edit
√
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
Title
√
Select Media
V-Mode Compatibility
Disc Manager
SP
MOVE
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
Press the …† buttons to select Add, then press the OK
button.
Add Copy List screen is displayed.
Press the …† buttons to select the title to copy, then
press the OK button.
Other method: Press the …† buttons to select Add a
list, then press the OK button.
Press the …† buttons to select a title you to copy, then
press the OK button.
1/1 Page
SELECT
RETURN
EXIT
Add Copy List
HDD
7
No.
001
002
003
004
Press the …† buttons to select Copy, then press the
OK or √ button.
Copy screen is displayed.
Title
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
00:10:21
00:40:03
00:20:15
00:50:16
18/JAN/2005 12:15 AV3
18/JAN/2005 12:15
SP
V-Mode Compatibility
MOVE
1/1 Page
SELECT
RETURN
EXIT
Copy
Copy To : HDD ➞ DVD
HDD
No.
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
1
Length
00:10:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
10
Press the …† buttons to select an additional title
you want to copy, then press the OK button.
Repeat steps 8~10 to select a title you want to copy.
4.48 GB
Total
00:10:21
0.25 GB
MOVE
SELECT
RETURN
Copy
EXIT
Copy To : HDD ➞ DVD
HDD
No.
8
1
2
3
Press the ANYKEY button.
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A LP ➞ HS
20/JAN/2005 15:15A LP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
Total
00:56:03
1.88 GB
MOVE
SELECT
RETURN
EXIT
Copy
Copy To : HDD ➞ DVD
HDD
No.
1
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
Length
00:10:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
Add
Delete
4.48 GB
Total
Preview
00:10:21
0.25 GB
√
Rec. Mode
MOVE
SELECT
RETURN
11
Press the OK or √ buttons to select Start,
then press the OK button.
EXIT
Copy
Copy To : HDD ➞ DVD
HDD
No.
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A LP ➞ HS
20/JAN/2005 15:15A LP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
Total
00:56:03
1.88 GB
MOVE
SELECT
RETURN
EXIT
The added title lists are copied into the copy list.
To cancel the copying in progress, press the CANCEL
button.
■
NOTE
Downloaded From DvDPlayer-Manual.com Samsung Manuals
If copy list contains at least one title that
cannot be copied at high speed, it performs
step 9 described on page 111. Otherwise, it
performs the step 9-1 described on page 111.
English - 113
Editing
1
2
3
Deleting an Undesired Title from the
Copy List
To setup, follow steps 1 to 7 in pages 112~113.
8
Press the …† buttons to select a title you want to
delete from the copy screen.
Previewing a Selected Title from the
Copy List
To setup, follow steps 1 to 7 in pages 112~113.
8
Press the …† buttons to select a title you want to
preview in the copy screen.
Copy
Copy
No.
1
2
3
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A LP ➞ HS
20/JAN/2005 15:15A LP ➞ HS
Add a list
No.
Length
00:10:21
00:15:21
00:30:21
Copy To : HDD ➞ DVD
HDD
Copy To : HDD ➞ DVD
HDD
1
2
3
Start
Rec. Mode
[DVD] Available
LP 04:00:16
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ LS
20/JAN/2005 15:15A SP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
4.48 GB
Total
Total
00:56:03
1.88 GB
00:56:03
1.88 GB
MOVE
9
SELECT
RETURN
MOVE
EXIT
Press the ANYKEY button. Press the …† buttons to
select Delete, then press the OK or √ button.
The message “Do you want to delete?” is displayed.
9
SELECT
RETURN
EXIT
Press the ANYKEY button. Press the …† buttons to
select Preview, then press the OK or √ button.
You can preview the selected title through the display
window located at the centre of the screen.
Copy
Copy To : HDD ➞ DVD
HDD
No.
1
2
3
Title
Rec.Mode
Copy
Length
18/JAN/2005 12:15A LP ➞ HS 00:10:21
Do youLPwant
19/JAN/2005 13:15A
➞ HS to delete?
00:15:21
20/JAN/2005 15:15A LP ➞ HS 00:30:21
Add a list
Yes
No
HDD
Copy To : HDD ➞ DVD
Start
No.
Rec. Mode
1
2
3
[DVD] Available
LP 04:00:16
4.48 GB
Total
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ LS
20/JAN/2005 15:15A SP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
01:06:03
1.88 GB
MOVE
SELECT
RETURN
Editing
Press the œ √ buttons to select Yes, then press the
OK button.
The selected title is deleted.
Copy
Copy To : HDD ➞ DVD
HDD
No.
Title
Rec.Mode
Length
1
3
19/JAN/2005 13:15A
20/JAN/2005 15:15A
LP ➞ HS
LP ➞ HS
00:15:21
00:30:21
Add a list
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
Total
00:45:42
1.30 GB
MOVE
SELECT
RETURN
[DVD] Available
LP 04:00:16
4.48 GB
Total
00:56:03
1.88 GB
EXIT
SELECT
10
Start
Rec. Mode
EXIT
Downloaded From114
DvDPlayer-Manual.com
Samsung Manuals
- English
10
RETURN
EXIT
Press the RETURN button to exit the Preview mode.
Selecting Record Mode of Each
Title from the Copy List
Changing Record Mode of All Titles
from the Copy List
You can copy multiple titles while setting different record
You can copy multiple titles while setting the same record
modes for each title.
mode for all titles.
To setup, follow steps 1 to 7 in pages 112~113.
To setup, follow steps 1 to 7 in pages 112~113.
8
Press the …† buttons to select a title to change its
record mode in the copy screen.
8
Select the Rec. Mode on the right-hand side on the
screen using the …†œ √ buttons, then press the
OK button.
Copy
No.
1
2
3
Copy
Copy To : HDD ➞ DVD
HDD
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ LS
20/JAN/2005 15:15A SP ➞ HS
Add a list
00:10:21
00:15:21
00:30:21
Copy To : HDD ➞ DVD
HDD
Length
Start
No.
Rec. Mode
1
2
3
[DVD] Available
LP 04:00:16
4.48 GB
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ LS
20/JAN/2005 15:15A SP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
Total
00:56:03
1.88 GB
MOVE
SELECT
RETURN
EXIT
MOVE
9
Press the ANYKEY button. Press the …† buttons to
select Rec. Mode, then press the OK or √ button.
Copy
1
2
3
[DVD]
XP Available
LP
SP 04:00:16
LP 4.48 GB
Total
EP 01:06:03
High Speed
1.88 GB
RETURN
EXIT
Press the …† buttons to select the record mode you
want, then press the OK button.
Rest of the copying process can be performed as
described in pages 110 to 111.
Copy To : HDD ➞ DVD
HDD
No.
9
SELECT
Start
Rec. Mode
Rec.Mode
Length
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ LS
20/JAN/2005 15:15A SP ➞ HS
Add
XP
Add a list
Delete
SP
Title
00:10:21
00:15:21
00:30:21
Preview
LP
√
Rec. Mode
MOVE
Start
4.48 GB
Total
00:56:03
1.88 GB
RETURN
Copy To : HDD ➞ DVD
HDD
[DVD] Available
LP 04:00:16
EP
SELECT
Copy
Rec. Mode
EXIT
No.
1
2
3
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
19/JAN/2005 13:15A SP ➞ HS
20/JAN/2005 15:15A SP ➞ HS
Add a list
Length
00:10:21
00:15:21
00:30:21
Start
Rec. Mode
[DVD] Available
LP 04:00:16
4.48 GB
Total
00:56:03
1.88 GB
MOVE
Press the …† buttons to select the record mode you
want, then press the OK or √ button.
11
Repeat steps 9~11 to select a title to change its record
mode.
Rest of the copying process can be performed as
described in pages 109 to 111.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
RETURN
EXIT
Editing
10
SELECT
English - 115
Copying from DVD to
HDD
4
Press the …† buttons to select the title you want to
copy.
)
To move to other pages, press the SKIP (
buttons.
SKIP( ) : previous page of title list
SKIP( ) : next page of title list
5
Press the ANYKEY button.
Using the TITLE LIST button
1
2
Press the OPEN/CLOSE button and place a
recorded disc on the disc tray.
Title List
DVD-RAM(VR)
Rename
No.
Protection
001
002
003
004
Copy
Press the OPEN/CLOSE button to close the disc tray.
Delete
Partial Delete
Playlist
√
Navigation
√
19/JAN/2005 12:15AV3
19/JAN/2005 12:15
3
√
Select Media
V-Mode Compatibility
Disc Manager
Title List
No.
001
002
003
004
Title
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
Length
00:10:21
00:40:03
00:20:15
00:50:16
MOVE
6
Length
18/JAN/2005 12:15A
19/JAN/2005 12:15A
20/JAN/2005 12:15A
25/JAN/2005 12:15A
SP
With the unit in Stop mode/Playback mode, press the
TITLE LIST button.
The Title List screen is displayed.
DVD-RAM(VR)
Title
1/1 Page
SELECT
RETURN
Copy
18/JAN/2005 12:15
DVD-RAM(VR)
V-Mode Compatibility
Copy To : DVD ➞ HDD
1/1 Page
No.
MOVE
EXIT
Press the …† buttons to select Copy, then press the
OK or √ button.
Copy screen is displayed.
18/JAN/2005 12:15 AV3
SP
00:10:21
00:40:03
00:20:15
00:50:16
SELECT
RETURN
EXIT
1
Title
Rec.Mode
18/JAN/2005 12:15A LP ➞ HS
Add a list
Length
00:10:21
Start
[HDD] Available
LP 40:16:56
52.99 GB
Using the MENU button.
Total
00:10:21
0.25 GB
• With the unit in Stop mode/Playback mode,
press the MENU button.
MOVE
• Press the …† buttons to select Title,
then press the OK or √ button.
SELECT
RETURN
- About Using COPY button Press the …† buttons to select the title you want
to copy from the title list and then press the COPY
button on the remote control. You can go to copy
screen.
• During Playback, you can also copy the title by
pressing the COPY button.
Editing
• Press the …† buttons to select Title List,
then press the OK or √ button.
The Title List screen is displayed.
7
Press the OK or √ buttons to select Start, then press
the OK button.
DVD
1%
If you want to stop copy, press CANCEL key.
Downloaded From116
DvDPlayer-Manual.com
Samsung Manuals
- English
EXIT
HDD
8
After a successful copy, “The title is successfully copied.”
message is displayed.
Copying MP3 or JPEG
Files from a Disc to HDD
File Copy
The title is successfully copied
• Copying Multiple Titles at One Time – Same as an
1
2
HDD operation(See page 112)
• Deleting an Undesired Title from the Copy List –
Insert a JPEG disc or MP3 disc into the disc tray.
Press the OPEN/CLOSE button to close the disc tray.
Wait until LOAD disappears from the front panel display.
Check that the disc has enough available space for the
recording.
Same as an HDD operation(See page 114)
• Previewing a Selected Title from the Copy List –
Same as an HDD operation(See page 114)
■
NOTE
■
■
■
■
■
You cannot copy anything else on finalised
DVD-R and DVD-RW(V mode) mode.
You cannot copy a DVD-VIDEO to HDD.
Only video will be copied from title lists or
playlist that contains still images.
High speed copying from a DVD-RAM or
DVD-RW (VR mode) is available.
When you copy from DVD-RW(V mode)/-R
disc to HDD, high speed copy is not
available.
Record mode cannot be changed when
you copy a title from DVD to HDD.
3
Press the …† buttons to select Music or Photo, then
press the OK or √ button.
MP3 or JPEG file list is displayed.
Music List
CD
√ 02 : 10
Flower.mp3
..
Flower.mp3
MP3
01/15
4.0 MB
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
MP3
Heaven.mp3
MP3
This Love.mp3
1/3 Page
MOVE
SELECT
RETURN
EXIT
Contents Copy Specifications
DVD ➞ HDD
Supported
Not supported
Not supported
Downloaded From DvDPlayer-Manual.com Samsung Manuals
Editing
Contents
Recorded Video Title
Copy Protected Title
Copy Once Title
English - 117
Folder Copy
4
Press the …† buttons to select the MP3 or JPEG files
you want to copy, then press the ANYKEY button.
1
Insert a Disc (JPEG or MP3) into the tray.
2
Press the …† buttons to select Music or Photo, then
press the OK or √ button.
MP3 or JPEG folder is displayed.
Music List
CD
» 02 : 10
Flower.mp3
..
Flower.mp3
Copy
Play Mode
√
MP3
Love.mp3
MP3
Straight from the heart.mp3
MP3
Run to you.mp3
Go01/15
To Playlist
MP3
Heaven.mp3
New
4.0Playlist
MB
MP3
This Love.mp3
MUSIC
Select Media
MOVE
√
1/3 Page
SELECT
RETURN
EXIT
Music List
CD
00 : 00
..
Song1
Song2
5
Song3
Press the …† buttons to select Copy, then press the
OK or √ button.
File copy begins.
The copying of only 1 file cannot be cancelled.
When copying only 1 file from a disc to HDD, it is
located under the HDD’s Music or Photo folder.
Music List
CD
Flower.mp3
» 02 : 10
Song4
ROOT
Song5
01/15
__
1/1 Page
MOVE
3
MUSIC
Bryan Adams.mp3
Copying...
HDD
MP3 Bryan Adams_2.mp3
Disc Type : HDD
MP3 Straight from the heart.mp3
Free space : 2939 MB
Total
file number : 1/1 MP3 Run to you.mp3
MUSIC
MP3 Heaven.mp3
Copying File Name : Flower.mp3
This
43Love.mp3
%
SELECT
RETURN
EXIT
Press the …† buttons to select the MP3 or JPEG
folder you want to copy, then press the ANYKEY
button.
Music List
CD
00 : 00
..
1/3 Page
Song1
CANCEL
Song2
Song3
Copy
ROOT
Go To Playlist
01/15
__
Song4
Song5
New Playlist
Select Media
Editing
MOVE
4
√
1/1 Page
SELECT
RETURN
EXIT
Press the …† buttons to select Copy, then press the
OK or √ button.
Folder copy begins.
Subfolders and files in the selected folder are copied.
Music List
CD
» 02 : 10
Flower.mp3
MUSIC
Bryan Adams.mp3
HDD
MP3 Bryan Adams_2.mp3
Disc Type : HDD
MP3 Straight from the heart.mp3
Free space : 2939 MB
Total
file number : 1/16 MP3 Run to you.mp3
MUSIC
MP3 Heaven.mp3
Copying File Name : Flower.mp3
Copying...
This
43Love.mp3
%
1/3 Page
CANCEL
Downloaded From118
DvDPlayer-Manual.com
Samsung Manuals
- English
■
Pressing the CANCEL button during folder
copying will cancel the folder copying after
the current file is copied.
■
Up to 1,500 files and 1,000 subfolders can
be copied into one folder for MP3 files.
■
Up to 4,500 files and 1,000 subfolders can
be copied into one folder for JPEG files.
■
Files having an existing name of
***.mp3/***.jpg, are automatically renamed
to ***01.mp3/***01.jpg and copied.
NOTE
■
It allows up to 999 copies to have the
same name.
■
You cannot copy an Audio CD.
■
MP3 or JPEG files can be copied only
from a disc to the HDD.
■
File size on a disc and the copied file in
the HDD may be slightly different due to
the file system.
Disc Manager
Editing the Disc Name
Follow these instructions to give a name to a disc.
1
With the unit in Stop mode, press the ANYKEY
button.
Search
Scene Navigation
Time Navigation
Contents Copy Specifications
Contents
MP3
JPEG(photo)
DivX
HDD ➞ DVD
Not supported
Not supported
Not supported
Marker
DVD ➞ HDD
Rec. Mode
√
Select Madia
√
Disc Manager
supported
supported
Not supported
2
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
Disc Manager
DVD-RAM(VR)
Disc Name
Used Space
00 : 01 : 43
Available Space
02 : 09 SP
Disc Protection Info
Not Protected
Rename
Protection
MOVE
Delete All
SELECT
Format
RETURN
EXIT
Editing
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 119
Disc Protection
3
Press the œ √ buttons to select Rename, then press
the OK button.
The Rename screen is displayed.
Disc Protection allows you to protect your discs from
being formatted or deleted due to unintended
operations.
Rename
DVD-RAM(VR)
Back Space
Space Delete
MOVE
SELECT
Clear
RETURN
Save
1
With the unit in Stop mode, press the ANYKEY
button.
EXIT
Search
Scene Navigation
4
Select the desired characters using the …† œ √
buttons, then press the OK button.
Time Navigation
Marker
Rec. Mode
√
Select Madia
√
Disc Manager
Rename
DVD-RAM(VR)
Disc
Back Space
Space Delete
MOVE
SELECT
Clear
RETURN
Save
2
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
EXIT
Disc Manager
DVD-RAM(VR)
Disc Name
5
Press the …† œ √ buttons to select Save,
then press the OK button.
A disc name is given to the disc.
Used Space
00 : 01 : 43
Available Space
02 : 09 SP
Disc Protection Info
Not Protected
Rename
Protection
MOVE
Delete All
SELECT
RETURN
Format
EXIT
Disc Manager
DVD-RAM(VR)
Disc Name
Disc
Used Space
00 : 01 : 43
Available Space
02 : 09 SP
Disc Protection Info
Not Protected
Rename
Protection
MOVE
3
Delete All
SELECT
RETURN
Press the œ √ buttons to select Protection, then press
the OK button.
Format
Disc Manager
EXIT
DVD-RAM(VR)
Editing
Disc Name
Used Space
Available Space
00 : 11 : 56
Disc Protection:
00 : 11 : 56 SP
On
Disc Protection Info
■
NOTE
■
You may need to clear disc protect before
beginning editing.
Rename
Off
Not Protected
Protection
MOVE
Delete All
SELECT
RETURN
Format
EXIT
Depending on the kind of disc, the
displayed screen may be different.
4
Downloaded From120
DvDPlayer-Manual.com
Samsung Manuals
- English
Press the œ √ buttons to select On, then press the OK
button.
Formatting a Disc
Use these instructions to format a disc.
The disc protect should also be cleared.
DVD-RW
• You will be prompted with the confirmation
message “Choose the recording format for
DVD- RW.”
Disc Manager
DVD-RW(VR)
Disc Name
1
With the unit in Stop mode, press the ANYKEY
button.
Used Space
00 : 10 : 32
Available Space
01 : 29 SP
Choose the recording format for DVD-RW.
Disc Protection Info Not Protected
Current Rec. ModeDVD-VR
VR-Mode
DVD-V
Rename
Protection
Delete All
MOVE
Search
Finalise
SELECT
Format
RETURN
EXIT
Scene Navigation
Time Navigation
Marker
Rec. Mode
√
Select Madia
√
Disc Manager
2
4
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
Press the œ √ buttons to select Yes, then press the OK
button. The disc is formatted.
DVD-VR and DVD-V are defined according to their
recording format.
Disc Manager
HDD
[Title Partition]
Used Space
002 : 22 : 08
Available Space
033 : 27 SP
DISC
DVD-VR
DVD-RAM
DVD-V
DVD-RW
DVD-RW
DVD-R
[Music/Photo Partition]
0145MB
Used Space
Available Space
4725MB
Delete All
MOVE
3
SELECT
RETURN
Format
EXIT
Press the œ √ buttons to select Format, then press the
OK button.
Disc Manager
HDD
[Title Partition]
Used Space
00 : 10 : 32
Available Space
35 : 47 : 10 SP
Do you want to format this disc?
[Music/Photo Partition]
Used Space
0006MB
Yes
Available Space
No
10034MB
SELECT
RETURN
Editing
Delete All
MOVE
Format
EXIT
HDD/DVD-RAM
• You will be prompted with the confirmation
message “Do you want to format this disc?”.
• If you select Yes, you will be prompted with the
confirmation message “All data will be deleted.
Do you want to continue?”.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 121
Delete All Title Lists/Music
Lists/Photo Lists
4
Press the œ √ buttons to select the Title, Music or
Photo, then press the OK button.
Title
Disc Manager
HDD
1
With the unit in Stop mode, press the ANYKEY
button.
[Title Partition]
Used Space
00 : 10 : 32
Available Space
35 : 47 : 10 SP
All title will be deleted.
[Music/Photo Partition]
Do you want to continue?
Used Space
0006MB
Available Space
Yes
No
10034MB
Delete All
Search
MOVE
Scene Navigation
SELECT
RETURN
Format
EXIT
Time Navigation
Marker
Rec. Mode
√
Select Madia
√
Music
Disc Manager
Disc Manager
HDD
2
[Title Partition]
Used Space
00 : 10 : 32
Available Space
35 : 47 : 10 SP
All music will be deleted.
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
[Music/Photo Partition]
Do you want to continue?
Used Space
0006MB
Available Space
Yes
No
10034MB
Delete All
MOVE
Disc Manager
SELECT
RETURN
Format
EXIT
HDD
[Title Partition]
Used Space
002 : 22 : 08
Available Space
033 : 27 SP
[Music/Photo Partition]
0145MB
Used Space
Available Space
4725MB
Delete All
MOVE
SELECT
Disc Manager
Format
RETURN
HDD
EXIT
[Title Partition]
Used Space
00 : 10 : 32
Available Space
35 : 47 : 10 SP
All photo will be deleted.
[Music/Photo Partition]
Do you want to continue?
Used Space
0006MB
3
Available Space
Press the œ √ buttons to select Delete All, then press
the OK button.
Yes
No
10034MB
Delete All
MOVE
SELECT
RETURN
Format
EXIT
Disc Manager
Editing
HDD
[Title Partition]
Used Space
00 : 10 : 32
Available Space
35 : 47 : 10 SP
5
Select contents to delete all
[Music/Photo Partition]
Used Space
0006MB
Title
Available Space
Music
10034MB
Delete All
MOVE
SELECT
RETURN
Format
EXIT
• When Protected Entry exists: The Delete All Title List
function will not operate. If there is a title containing a
still picture, however, that function will not operate. If
you want to delete a protected entry, disable Protect
for it on the Lock item.
Downloaded From122
DvDPlayer-Manual.com
Samsung Manuals
- English
Press the œ √ buttons to select Yes, then press the OK
button.
All title lists, music lists or photo lists are deleted.
• When Protected Entry exists: The Delete All Title List
function will not operate. If there is a title containing a
still picture, however, that function will not operate.
If you want to delete a protected entry, disable Protect
for it on the Lock item.
• When protected a DVD-RAM is used, data cannot be
deleted from a disc.
Delete All Title Lists
1
With the unit in Stop mode, press the ANYKEY
button.
4
Press the œ √ buttons to select Yes, then press the OK
button.
All title lists are deleted.
Search
Scene Navigation
Time Navigation
Marker
Rec. Mode
√
Select Madia
√
Disc Manager
2
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
Disc Manager
DVD-RAM(VR)
Disc Name
Used Space
00 : 01 : 43
Available Space
02 : 09 SP
Disc Protection Info
Not Protected
Rename
Protection
MOVE
3
Delete All
SELECT
RETURN
Format
EXIT
Press the œ √ buttons to select Delete All, then press
the OK button.
• You will be prompted with the confirmation message
“Do you want to delete all title lists?”.
Editing
Disc Manager
DVD-RAM(VR)
Disc Name
00 : 11 : 56
Used Space
Do you want to00delete
allSPtitle lists?
: 11 : 56
Available Space
Yes
Disc Protection Info
Rename
No
Not Protected
Protection
MOVE
Delete All
SELECT
RETURN
Format
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 123
If you select Yes, you will be prompted again with the
message “Disc will be finalised. Do you want to
continue?”.
Finalising a Disc
After you record titles onto a DVD-RW/DVD-R disc with
your HDD & DVD RECORDER, it needs to be finalised
before it can be played back on external devices.
Disc Manager
DVD-RW(VR)
Disc Name
00 : 10 : 32
Used Space
Available Space
01 : 29 SP
Disc will be finalised.
Do you want to continue?
Disc Protection Info Not Protected
Current Rec. Mode Yes
VR-Mode
1
With the unit in Stop mode, press the ANYKEY
button.
No
Rename
Protection
Delete All
MOVE
Finalise
SELECT
Format
RETURN
EXIT
Search
Scene Navigation
Time Navigation
4
Marker
Rec. Mode
√
Select Madia
√
Disc Manager
2
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
Press the œ √ buttons to select Yes, then press the
OK button.
The disc is finalised.
■
Once a disc is finalised, you cannot delete
entries from the record list.
■
After being finalised, the DVD-R/DVDRW(video mode) operates in the same
manner as a DVD-Video.
■
Depending on the disc type, the displayed
screen may be different.
■
Finalising time may be different depending
on the amount of data recorded on the
disc.
■
Data on the disc will be damaged if the
recorder is powered off during finalisation
process.
■
When the disc contains a music or JPEG
files, it cannot be finalised.
NOTE
Disc Manager
DVD-RW(VR)
Disc Name
Used Space
00 : 01 : 17
Available Space
01 : 40 SP
Disc Protection Info Not Protected
Current Rec. Mode VR-Mode
Rename
Protection
Delete All
MOVE
Editing
3
Finalise
SELECT
Format
RETURN
EXIT
Press the …† œ √ buttons to select Finalise, then
press the OK button.
You will be prompted with the message “Do you want to
finalise disc?”.
Disc Manager
DVD-RW(VR)
Disc Name
Used Space
00 : 10 : 32
Available Space
01 : 29 SP
Do you want to finalise disc?
Disc Protection Info Not Protected
Current Rec. Mode Yes
VR-Mode
No
Rename
Protection
Delete All
MOVE
Finalise
SELECT
Format
RETURN
EXIT
Downloaded From124
DvDPlayer-Manual.com
Samsung Manuals
- English
Unfinalising a Disc (V/VR mode)
4
Press the œ √ buttons to select Yes, then press the
OK button.
The disc is unfinalised.
■
1
With the unit in Stop mode, press the ANYKEY
button.
NOTE
A DVD-RW can be finalised or unfinalised
in Video mode.
Mark
Finalise
Unfinalise
DVD-Video(RW)
DVD-RW(V)
Additional recording, protection
Operation Same as DVD-Video
Search
Scene Navigation
and deletion are possible.
Time Navigation
Marker
√
Select Madia
■
Disc Manager
2
Press the …† buttons to select Disc Manager, then
press the OK or √ button.
Disc Manager
DVD-RW(VR:F)
Disc Name
Used Space
00 : 01 : 17
Available Space
01 : 40 SP
A DVD-RW can be finalised or unfinalised
in VR mode.
Finalise
Unfinalise
Mark
DVD-RW(VR:F)
DVD-RW(VR)
Operation
Additional recording,
deletion, editing, and
Additional recording,
deletion, editing, and
protection are impossible.
protection are possible.
Current Rec. Mode DVD-VR
unfinalise
MOVE
3
SELECT
RETURN
Format
EXIT
Press the œ √ buttons to select Unfinalise, then
press the OK button.
You will be prompted with the message “Do you want
to unfinalise disc?”.
Disc Manager
DVD-RW(VR:F)
Disc Name
Used Space
00 : 00 : 00
Available Space
00 : 00 SP
Do you want to unfinalise disc?
Current Rec. Mode DVD-V
No
unfinalise
MOVE
SELECT
RETURN
Editing
Yes
Format
EXIT
If you select Yes, you will be prompted again with the
message “Disc will be unfinalised. Do you want to
continue?”.
Disc Manager
DVD-RW(VR:F)
Disc Name
00 : 00 : 00
Used Space
Available Space
00 : 00 SP
Disc will be unfinalised.
Do you want to continue?
Current Rec. Mode DVD-V
Yes
No
unfinalise
MOVE
SELECT
RETURN
Format
EXIT
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 125
Reference
Troubleshooting
If your product malfunctions, go through the
checkpoints below before contacting a Samsung
authorised service centre.
Power
The input is displayed for a while when the
power is turned on.
Checkpoint 1
The HDD & DVD RECORDER
requires some time to initialize and the
input will be displayed for approx. 10
seconds after it is turned on.
Recording
Cannot record TV programmes.
Checkpoint 1
Check whether the power cord is
securely plugged into the power outlet.
Checkpoint 2
Did you set the HDD & DVD
RECORDER channel settings correctly?
Checkpoint 3
Check the free space on your
HDD/DVD-RAM/-RW/-R discs.
Reference
I pressed the REC button but there is no response.
Checkpoint 1
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .126
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
Downloaded From126
DvDPlayer-Manual.com
Samsung Manuals
- English
Recording is possible for HDD/DVDRAM/-RW/-R discs only.
If a programme is copy protected, it
cannot be recorded.
Playback
Cannot play the disc.
Checkpoint 1
Checkpoint 2
Checkpoint 3
Check whether the disc is inserted
correctly with the label facing up.
Checkpoint 1
Check the regional code of the DVD
disc.
The angle operation is available only
when the disc contains images
captured from different angles.
This HDD & DVD RECORDER cannot
play some types of discs.
(See pages 7, 47)
icon appears on the screen.
Checkpoint 1
The angle operation does not work while playing a
DVD disc.
You cannot use this operation or
function due to one of the following
reasons:
(1) Your DVD disc restricts it.
(2) Your DVD disc does not support
this feature (for example: angles)
(3) The feature is not available at the
moment.
(4) You've requested a title, chapter, or
scan time that is out of range.
The selected audio and/or subtitle language is not
played.
Checkpoint 1
Audio and subtitle languages are
disc-specific. Only the sound and
subtitle languages contained on the
DVD disc are available and displayed
in the disc menu.
Cannot copy title or file to the other mode.
Play mode settings are different from the settings
configured in the Settings menu.
Checkpoint 1
The disc does not support all selected
functions. In this case, some settings
configured in the settings menu may
not work properly.
Checkpoint 1
DVD discs encoded with copy
protection can not be copied to HDD.
Checkpoint 2
Refer to “Contents Copy Specifications”
on page 5 to check if copying is
supported.
Reference
Cannot change the aspect ratio.
Checkpoint 1
The aspect ratio is fixed for DVD
discs. (See pages 40~41)
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 127
Video
Timer Recording
The disc revolves, but no image or bad quality
images is displayed.
Checkpoint 1
Be sure that the Video Setting is
properly set. (See pages 40~41)
Checkpoint 2
Check whether there is damage to or
any foreign material on your disc.
Checkpoint 3
Checkpoint 4
If scenes change from dark to bright
suddenly, the screen may shake
vertically temporarily, but this is not a
fault.
No sound.
Checkpoint 1
Are you watching a programme in
slow or skip mode?
If you are playing a programme at a
speed other than normal speed,
sound will not be heard.
Checkpoint 2
Check the connections and settings.
(See pages 22~23, 38~39)
Checkpoint 3
Check whether the disc is damaged.
Clean the disc, if necessary.
Check whether the disc is inserted
correctly with the label facing up.
Reference
No audio output.
Checkpoint 1
Checkpoint 1
Check there is enough space in the
disc or HDD for recording.
Checkpoint 2
Check whether the current disc is
recordable or not.
Make sure to check before the start
time of recording.
Some low quality discs may not play
properly.
Sound
Checkpoint 4
Timer lamp flickers.
Check whether you have selected
the correct digital output options in
the Audio Output Options menu.
(See pages 38~39)
Downloaded From128
DvDPlayer-Manual.com
Samsung Manuals
- English
Timer recording does not work properly.
Checkpoint 1
Re-check the recording time and the
end time settings again.
Checkpoint 2
Recording will be cancelled if the
power is interrupted due to a power
failure or another similar reason
while recording.
Remote Control Unit
Other problems.
The remote control doesn't work.
Checkpoint 1
Checkpoint 2
Checkpoint 3
Checkpoint 4
Point the remote control at the remote
control sensor on your HDD & DVD
RECORDER. Allow for proper
distance. Remove obstacles between
your HDD & DVD RECORDER and
the remote control.
Checkpoint 1
Read the table of contents and then
find and read the section describing
your problem, follow the instructions
given.
Checkpoint 2
Plug your HDD &DVD RECORDER
off and on.
Checkpoint 3
If the problem still persists, contact a
nearby Samsung service centre.
Check whether the batteries are
drained.
Check the TV/DVD selection button
setting.
Check whether TV control button is
selected or not.
Other
I forgot my password for parental supervision.
Checkpoint 1
Press and hold the SEARCH/SKIP( )
button on the front panel of the
Recorder for more than 5 seconds
with no disc in the unit. All settings
including the password will revert to
the factory settings. Do not use this
unless absolutely necessary. (Note
that this function is possible only when
no disc is inserted.)
Checkpoint 1
Reference
Is it possible to change a subtitle and an audio
signal on a recorded disc?
A recorded disc is played with only
the subtitle and the audio signal
which were selected during recording.
Downloaded From DvDPlayer-Manual.com Samsung Manuals
English - 129
Specifications
Power requirements
AC 220-240V, 50Hz
Power consumption
45 Watts
Weight
General
Dimensions
4,2 Kg
430mm(W) x 255mm(D) x 79mm(H)
Operating temp.
+5°C to +35°C
Other conditions
Keep level when operating. Less than 75% operating humidity
Input
Video
Composite Video : 1,0 V p-p at 75Ω load, sync negative
Audio
Max.Audio Input Level : 2Vrms
DV Input
IEEE 1394(4p) compatible jack
Receivable Channels
PAL, SECAM-B/G, D/K, I
AV1 (Scart TV)
Video : Composite, Audio: analogue
AV2 (Scart Ext)
Video : Composite, RGB Audio: analogue
Scart Jack
Audio
Analogue output jacks x 2
Optical/Coaxial digital audio output
Composite Video : Video output jack x 1
Output
Video
S-Video output x 1 (Y:1,0Vp-p, C:0,286Vp-p at 75Ω load)
Component output x 1 (Y: 1,0Vp-p, Pb: 0,70Vp-p, Pr: 0,70Vp-p at 75Ω load)
Scart Jack
Recording
AV1 (Scart TV)
Video : Composite, RGB Audio: analogue
Picture Compression format
MPEG-II
Audio Compression format
Dolby Digital 2ch/256Kbps, MPEG-II
Recording Quality
XP (about 8,5 Mbps), SP (about 4,5 Mbps), LP (about 2,5 Mbps),
EP (about 1,6 Mbps or about 1,2 Mbps)
Audio Frequency Response
Reference
HDD
Capacity
20 Hz~20 kHz
DVD-HR710
80 GB
DVD-HR721
160 GB
Audio Output
For DVD discs, audio signals recorded at 96kHz sampling frequency are converted into and output at 48kHz.
Disc Type
DVD
AUDIO CD(CD-DA)
Analog Audio Output
48 / 96kHz
44,1kHz
Digital Audio Output
48kHz
44,1kHz
Downloaded From130
DvDPlayer-Manual.com
Samsung Manuals
- English
ELLAS (GREECE)
Agaphtev pelavth,
Saı eucaristouvme gia thn empistosuvnh pou deivxate
sthn SAMSUNG me thn agorav authvı thı suskeuhvı.
To proiovn autov thı SAMSUNG eivnai egguhmevno gia
perivodo dwvdeka (12) mhnwvn apov thn hmeromhniva agoravı tou gia antallaktikav kai ergatikav. Sthn
perivptwsh pou qa creiasteiv episkeuhv, to proiovn autov
thı SAMSUNG qa prevpei na staleiv hv na metaferqeiv
sto exousiodothmevno service, me evxoda tou agorasthv.
Exousiodothmevnoi antiprovswpoi kai exousiodothmevna
kevntra service se avlleı Eurwpaikevı cwvreı, qa
apodecqouvn touı ovrouı thı egguvhshı.
Plhroforiveı gia ta exousiodothmevna kevntra service
sthn Ellavda, mporeivte na pavrete apov thn
FOURLIS TRADE A.E.B.E.
L. Kruonerivou 112
145 68 Kruonevri, Apikhvı
Thl. 210.629.3100
■ Oroi thı egguvhshı
1. H egguvhsh iscuvei eavn kai movno eavn to proiovn
creiavzetai service kai h kavrta egguvhshı evcei
plhvrwı sumplhrwqeiv kai sfragisqeiv apov to
katavsthma agoravı. Epivshı prevpei na proskomisqeiv
kai to timolovgio hv h apovdeixh lianikhvı pwvlhshı,
pavnw sthn opoiva o seiriakovı ariqmovı tou proiovntoı prevpei na eivnai eukrinhvı.
2. H upocrevwsh thı SAMSUNG aforav movno thn
episkeuhv tou proiovntoı
3. H episkeuhv tou proiovntoı prevpei na anativqetai
movno se exousiodothmevna kevntra service hv
exousiodothmevnouı antiproswvpouı thı SAMSUNG. Kamiva apozhmivwsh den qa givnei apodekthv
gia episkeuhv pou evcei givnei apov mh exousiodothmevno apov thn SAMSUNG sunergeivo.
4. To proiovn autov den qa qewrhqeiv ellatwmatikov sta
ulikav hv sthn ergasiva episkeuhvı eavn qa prevpei na
prosarmosteiv, metatrapeiv hv ruqmisteiv wvste na
summorfwqeiv me tiı topikevı tecnikevı prodiagrafevı hv prodiagrafevı pou iscuvoun se cwvra avllh
apov authv gia thn opoiva proorizovtan hv
kataskeuavsthke.
H egguvhsh authv den kaluvptei apozhmiwvseiı giaÚ
* Kefalevı bivnteo kai kasetofwvnwn
* Kefalevı binteokavmeraı
* Gennhvtrieı aktinwvn Iaser sta CD, DVD
* Thleceiristhvria
* Lucniveı fouvrnwn mikrokumavtwn
Downloaded From DvDPlayer-Manual.com Samsung Manuals
* Prosarmogevı, metatropevı hv ruqmivseiı, anexavrthta an eivnai epituchvı hv anepituchvı, ouvte
opoiadhvpote zhmiva proevrcetai ex autouv...
5. H egguvhsh authv den kaluvptei kamiva apov tiı
parakavtw periptwvseiıÚ
* Periodikouvı elevgcouı, sunthvrhsh kai episkeuhv
hv antikatavstash merwvn pou ofeivlontai se
fusiologikhv fqorav
Ta
evxoda kai touı kinduvnouı metaforavı pou
*
scetivzontai me thn egguvhsh autouv tou proiovntoı
* Zhmiva se autov to proiovn pou proevrcetai apovÚ
A. Katavcrhsh hv kai kakhv crhvsh, sumperilambanomevnhı allav kai mh periorismevnhı seÚ
Mh crhvsh autouv tou proiovntoı gia touı
skopouvı pou fusiologikav proorivzetai hv suvmfwna me tiı odhgiveı crhvsewı gia thn swsthv
crhvsh kai sunthvrhsh autouv tou proiovntoı
Thn egkatavstash kai crhvsh tou proiovntoı
me trovpouı pou antivkeintai stiı tecnikevı
prodiagrafevı
asfaleivaı pou iscuvoun katav thn crhvsh tou
proiovntoı
B. Episkeuhv pou evgine apov mh exousiodothmevna
sunergeiva service
G. Atuchvmata, qeomhniveı hv opoiadhvpote aitiva
pevra tou elevgcou thı SAMSUNG, sumperilambanomevnwn allav mh periorismevnwn twn
keraunwvn, tou nerouv, thı fwtiavı, twn dhmosivwn anataracwvn, tou kakouv aerismouv klp.
D. H egguvhsh authv den ephreavzei ta dikaiwvmata tou katanalwthv pou
problevpontai apov thn efarmosteva eqnikhv
nomoqesiva pou iscuvei, ouvte ta dikaiwvmata
twn katanalwtwvnv enantivon twn lianopwlhtwvnv pou aporrevoun apov thn suvmbash
pwvlhshı.
E. Se perivptwsh pou den upavrcei eqnikhv nomoqesiva authv h egguvhsh qa eivnai h monadikhv
kai apokleistikhv kavluyh tou katanalwthv gia
kavqe zhmiav.
FOURLIS TRADE A.E.B.E.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care centre.
☎ 1-800-SAMSUNG (7267864) / www.samsung.com
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
English
Downloaded From DvDPlayer-Manual.com Samsung Manuals
AK68-00903E-01
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
