Mighty Mo Air Control Solutions

Mighty Mo Air Control Solutions

CONCENTRATED

cooling.

REDUCED

energy

consumption.

Mighty Mo

®

Air Control

Solutions

2

Legrand | Ortronics is the leader in passive airflow control,

with patented physical infrastructure solutions that properly manage heat and airflow. In addition to the traditional racks and cabinets that are the backbone of Ortronics

®

physical support solutions, Legrand | Ortronics now offers Mighty Mo

®

Air Control containment solutions. Together, Ortronics physical infrastructure and containment products provide complete thermal management solutions to direct heat and airflow in the data center, resulting in improved cooling that significantly increases energy savings.

Passive air control

provides the most energy efficient, cost-effective method of improving airflow and maintaining proper temperature in the data center.

3

Mighty Mo Air Control is part of Layer Zero

®

.

THE BENEFITS OF

AIRFLOW CONTROL &

COLD AISLE CONTAINMENT

Maintaining separation between the hot and cold aisles is a crucial aspect of best practice airflow design. The Mighty Mo

®

Air Control containment solution enhances the separation of the hot and cold aisles by containing and directing cold air where it is needed. This passive system improves airflow and optimizes thermal management without adding active cooling equipment, avoiding additional energy costs for cooling.

The Air Control system provides additional protection and performance benefits for your network. Containment extends the life of active equipment like switches and servers by reducing the heat load, boosting performance and preventing premature equipment burn-out. This separation of cold supply air and hot exhaust also increases the tonnage output and efficiency of

CRAC units.

Very simply, Mighty Mo Air

Control solutions provide more cooling with less energy by containing and directing the cold air to where it is needed.

4

Features and Benefits

n

Reduce costs by raising your data center set points n

Increase CRAC output and efficiency n

Harness thermal dynamics to increase the effectiveness of cold aisle isolation n

Multiple customizable configurations available to suit any data center - legacy or new builds n

Compatible with raised or non-raised floors n

Meet the physical, thermal, electrical and optical requirements of ASTM, UL and NFPA fire retardant requirements n

Designed to release in the event of a fire, allowing full operating range for fire sprinklers

5

MEASURED SUCCESS

CFD ANALYSIS

6

Flood Cooling is the most common approach today to data center cooling. This process fills the entire data center with air that meets the intake needs of all active equipment.

The problems associated with cooling the whole room to the same general temperature are that it creates: n

Lower than necessary set points n

Higher than necessary humidity set points n

Partial use of rack space, since the higher rack units are above recommended equipment temperatures n

Excessive fan use to create air movement throughout the room

These things all result in higher than necessary costs.

To demonstrate the benefits of concentrated cooling, Legrand |

Ortronics conducted a Computational

Fluid Dynamics (CFD) analysis on a typical data center to determine the energy savings impact of Mighty Mo

®

Air Control products, starting with the raised floor and ending with full containment.

BASELINE

DATA CENTER

The baseline data center is 9,000 square feet, with typical kW or heat load ranging from .5kW network racks to 6kW server racks. The baseline model features cabinets that are both parallel and perpendicular to the five operating CRAC units, with hot and cold aisles, as well as isolated equipment. There are some rows set up for cold aisle containment and some ancillary areas where flood cooling will be adequate.

Other common situations include an area without a raised floor, cabinets up against a wall or column and CRAC units that are not symmetrical.

The AC load was selected to represent what is typically found in legacy data centers. In this

image, the blue circles illustrate cold air flooding into the hot aisle, showing an oversupply of cold air.

However, the red circle points out where the cold aisle is receiving hot air, demonstrating that there is no clear separation between the hot and the cold.

Five of the cabinets are still showing intake temperatures in excess of 80 degrees; potentially damaging the equipment.

CONTAINED

DATA CENTER

Looking at the contained data center you can see that all of the supply air areas are well under 78 degrees and fall within the ASHRAE intake specifications. While the exhaust side still shows extreme temperatures, this is a desired result and will increase the CRAC units’ efficiency.

All active equipment has been entirely cold air contained, including isolated cabinets far from a CRAC unit. The Mighty Mo

®

Air Control cold aisle containment made it possible to shut off two CRAC units while still maintaining appropriate intake temperatures and increasing the efficiency and tonnage output of the remaining 3 CRAC units.

A combination of Mighty Mo aisle containment products was used:

n

Air Disrupters slowed the subfloor air to allow proper permeation through perforated tiles n

Air Plugs and Air Blanking Panels blocked holes between the hot and cold aisles, as well as between the subfloor and main room to prevent cold air leakage n

Air Curtains and Air Cap solidified the separation of the hot and cold aisle n

The Air Booth spot cooled isolated cabinets and racks

All active equipment intakes have been entirely cold air contained, making it possible to shut off two

CRAC units.

7

8

MIGHTY MO

®

AIR CONTROL

SOLUTIONS

To improve data center cooling efficiency it is crucial to separate and contain cold air and provide hot air back to the cooling units.

CRAC unit efficiency is achieved when hot air is returned to the unit. Mighty Mo Air Control products significantly reduce cooling requirements by creating a physical separation between the cold and hot air. They provide a contained supply of cold air to equipment, dramatically reducing active equipment energy consumption. Mighty Mo Air

Control products can be used to reduce the amount of cold air lost through unoccupied areas of equipment in hot and cold aisle environments, as well as balance the underfloor pressure and reduce air leakage.

9

10

MIGHTY MO

®

AIR PLUG & AIR DISRUPTER

Mighty Mo

®

Air Plug

Air Plugs are used to fill in cable openings in the raised floor or any gaps where airflow needs to be blocked. Air Plugs are soft, compressible and safe to use around all types of cable, including fiber optic cable.

They are made from Sandel ™ , a fireproof material. Sandel originates from sand, contains no asbestos and is non-combustible at any temperature. The Air Plugs are available in several sizes to cover most any opening and are easily installed by simply squeezing the plug and placing it in the opening to be filled. All plugs have a height of 5”.

PART NO.

OR-MMAPL0404

OR-MMAPL0606

OR-MMAPL0612

OR-MMAPL0618

OR-MMAPL0624

OR-MMAPL0909

OR-MMAPL0914

OR-MMAPL0918

OR-MMAPL0924

OR-MMAPL1212

OR-MMAPL1218

OR-MMAPL1224

OR-MMAPL1414

OR-MMAPL1616

OR-MMAPL1620

OR-MMAPL1624

OR-MMAPL1818

OR-MMAPL2024

OR-MMAPL2424

DESCRIPTION

Air Plug, 5” x 4” x 4”, black

Air Plug, 5” x 6” x 6”, black

Air Plug, 5” x 6” x 12”, black

Air Plug, 5” x 6” x 18”, black

Air Plug, 5” x 6” x 24”, black

Air Plug, 5” x 9” x 9”, black

Air Plug, 5” x 9” x 14”, black

Air Plug, 5” x 9” x 18”, black

Air Plug, 5” x 9” x 24”, black

Air Plug, 5” x 12” x 12”, black

Air Plug, 5” x 12” x 18”, black

Air Plug, 5” x 12” x 24”, black

Air Plug, 5” x 14” x 14”, black

Air Plug, 5” x 16” x 16”, black

Air Plug, 5” x 16” x 20”, black

Air Plug, 5” x 16” x 24”, black

Air Plug, 5” x 18” x 18”, black

Air Plug, 5” x 20” x 24”, black

Air Plug, 5” x 24” x 24”, black

Mighty Mo Air Disrupter

The Air Disrupter is a curtain designed to modify the air velocity under a raised floor. Low pressure areas above perforated tiles are often a result of air rushing past the tile opening at too great a speed.

By strategically placing the Mighty

Mo Air Disrupters under the raised floor, air velocity is greatly reduced and more air is allowed to permeate through the tiles, ensuring a consistent supply of cool air to each rack or cabinet.

The Mighty Mo Air Disrupters are made from the fireproof material Sandel.

PART NO.

OR-MMADIS0624

OR-MMADIS1224

OR-MMADIS1824

OR-MMADIS2424

DESCRIPTION

Air Disrupter,

6”H x 24”W, black

Air Disrupter,

12”H x 24”W, black

Air Disrupter,

18”H x 24”W, black

Air Disrupter,

24”H x 24”W, black

11

MIGHTY MO

®

AIR CURTAIN SYSTEM

12

The Air Curtain containment system includes hanging panels, sliding doors and swinging doors – all designed to eliminate the mixing of hot and cold airflow.

Hanging Vinyl Panels

Fire resistant vinyl panels hang from aluminum tracks mounted to the drop ceiling grid above the racks and cabinets. This curtain forms a barrier between the hot aisle and cold aisle. The aluminum tracks are connected to the ceiling grid by fusible links that release and drop to the floor when temperatures go above 135°F, ensuring that the fire sprinkler pattern is not interrupted. Normal fire suppression systems engage at 158°F.

The Hanging Vinyl Panel System is sold in kits that include all the necessary hangers, track and panels to cover your specific area.

The vinyl panels are the length of the aluminum track and overlap at the track seams. Each panel has two inches of additional width on each end to overlap and create one continuous partition.

The tracks are available in clear anodized aluminum.

To determine the size of the

Hanging Vinyl Panel System required you will need the following measurements: n

Linear feet – this is the length of aluminum track needed to create a rectangle around the aisle to be contained. Kits are available from 1’ to 6’ long and can be connected to one another for larger installations.

n

Drop down length (in inches) – this is the length of the vinyl panels from the aluminum track to the top of the racks and cabinets or floor. Available lengths are from 29” to 182” high.

Mighty Mo

®

Air Curtain,

Hanging Vinyl Strip Doors

PART NO.

DESCRIPTION

OR-MMACNS98X12 Vinyl Strip, 98”H x 12”L

OR-MMACNS98X24 Vinyl Strip, 98”H x 24”L

OR-MMACNS98X36 Vinyl Strip, 98”H x 36”L

OR-MMACNS98X48 Vinyl Strip, 98”H x 48”L

OR-MMACNS98X60 Vinyl Strip, 98”H x 60”L

OR-MMACNS98X72 Vinyl Strip, 98”H x 72”L

OR-MMACNS110X12 Vinyl Strip, 110”H x 12”L

OR-MMACNS110X24 Vinyl Strip, 110”H x 24”L

OR-MMACNS110X36 Vinyl Strip, 110”H x 36”L

OR-MMACNS110X48 Vinyl Strip, 110”H x 48”L

OR-MMACNS110X60 Vinyl Strip, 110”H x 60”L

OR-MMACNS110X72 Vinyl Strip, 110”H x 72”L

OR-MMACNS122X12 Vinyl Strip, 122”H x 12”L

OR-MMACNS122X24 Vinyl Strip, 122”H x 24”L

OR-MMACNS122X36 Vinyl Strip, 122”H x 36”L

OR-MMACNS122X48 Vinyl Strip, 122”H x 48”L

OR-MMACNS122X60 Vinyl Strip, 122”H x 60”L

OR-MMACNS122X72 Vinyl Strip, 122”H x 72”L

OR-MMACNS146X12 Vinyl Strip, 146”H x 12”L

OR-MMACNS146X24 Vinyl Strip, 146”H x 24”L

OR-MMACNS146X36 Vinyl Strip, 146”H x 36”L

OR-MMACNS146X48 Vinyl Strip, 146”H x 48”L

OR-MMACNS146X60 Vinyl Strip, 146”H x 60”L

OR-MMACNS146X72 Vinyl Strip, 146”H x 72”L

OR-MMACNS182X12 Vinyl Strip, 182”H x 12”L

OR-MMACNS182X24 Vinyl Strip, 182”H x 24”L

OR-MMACNS182X36 Vinyl Strip, 182”H x 36”L

OR-MMACNS182X48 Vinyl Strip, 182”H x 48”L

OR-MMACNS182X60 Vinyl Strip, 182”H x 60”L

OR-MMACNS182X72 Vinyl Strip, 182”H x 72”L

Mighty Mo Air Curtain,

Hanging Vinyl Panels

PART NO.

DESCRIPTION

OR-MMACNP29X12 Vinyl Panel, 29”H x 12”L

OR-MMACNP29X24 Vinyl Panel, 29”H x 24”L

OR-MMACNP29X36 Vinyl Panel, 29”H x 36”L

OR-MMACNP29X48 Vinyl Panel, 29”H x 48”L

OR-MMACNP29X60 Vinyl Panel, 29”H x 60”L

OR-MMACNP29X72 Vinyl Panel, 29”H x 72”L

OR-MMACNP56X12 Vinyl Panel, 56”H x 12”L

OR-MMACNP56X24 Vinyl Panel, 56”H x 24”L

OR-MMACNP56X36 Vinyl Panel, 56”H x 36”L

OR-MMACNP56X48 Vinyl Panel, 56”H x 48”L

OR-MMACNP56X60 Vinyl Panel, 56”H x 60”L

OR-MMACNP56X72 Vinyl Panel, 56”H x 72”L

OR-MMACNP98X12 Vinyl Panel, 98”H x 12”L

OR-MMACNP98X24 Vinyl Panel, 98”H x 24”L

OR-MMACNP98X48 Vinyl Panel, 98”H x 48”L

OR-MMACNP110X12 Vinyl Panel, 110”H x 12”L

OR-MMACNP110X24 Vinyl Panel, 110”H x 24”L

OR-MMACNP110X48 Vinyl Panel, 110”H x 48”L

OR-MMACNP122X12 Vinyl Panel, 122”H x 12”L

OR-MMACNP122X24 Vinyl Panel, 122”H x 24”L

OR-MMACNP122X48 Vinyl Panel, 122”H x 48”L

OR-MMACNP146X12 Vinyl Panel, 146”H x 12”L

OR-MMACNP146X24 Vinyl Panel, 146”H x 24”L

OR-MMACNP146X48 Vinyl Panel, 146”H x 48”L

OR-MMACNP182X12 Vinyl Panel, 182”H x 12”L

OR-MMACNP182X24 Vinyl Panel, 182”H x 24”L

OR-MMACNP182X48 Vinyl Panel, 182”H x 48”L

Mighty Mo Air Curtain,

Hanging Vinyl Corner Panels

PART NO.

OR-MMACNCP29X12

OR-MMACNCP56X12

OR-MMACNCP98X12

DESCRIPTION

Vinyl Corner Panel,

29”H x 12”L

Vinyl Corner Panel,

56”H x 12”L

Vinyl Corner Panel,

98”H x 12”L

13

14

MIGHTY MO

®

AIR DOORS

Mighty Mo

®

Sliding Aisle End Door

The Sliding Aisle End Door installs at the end of the row. The door frame is constructed of extruded aluminum and supports clear acrylic sliding doors, bridging an aisle up to 84” wide. The door is shipped fully assembled to make installation easier. Simply tilt the door into place, bolt it to the floor and attach the turnbuckles on the top of the door to the top of the end rack or cabinet.

The no-threshold design allows unfettered access to the contained aisle. The frames are available in clear or black anodized aluminum.

PART NO.

DESCRIPTION

OR-MMADRS80X89DL Air Door, Sliding, 80”H x 89”W, dual 24”W doors, clear

OR-MMADRS80X89DL-B Air Door, Sliding, 80”H x 89”W, dual 24”W doors, black

OR-MMADRS80X89LH Air Door, Sliding, 80”H x 89”W, single 36”W door, left, clear

OR-MMADRS80X89LH-B Air Door, Sliding, 80”H x 89”W, single 36”W door, left, black

OR-MMADRS80X89RH Air Door, Sliding, 80”H x 89”W, single 36”W door, right, clear

OR-MMADRS80X89RH-B Air Door, Sliding, 80”H x 89”W, single 36”W door, right, black

Mighty Mo Hinged Aisle End Door

The Hinged Aisle End Door is also constructed of extruded aluminum and clear acrylic and has the same ease of installation as our sliding door.

The door can be purchased with a left hand or right hand opening and has a swing radius of 3 feet. The frames are available in clear or black anodized aluminum.

PART NO.

OR-MMADRH80X56LH

DESCRIPTION

Air Door, Hinged, 80”H x 56”W, left hand open, clear

OR-MMADRH80X56LH-B Air Door, Hinged, 80”H x 56”W, left hand open, black

OR-MMADRH80X56RH Air Door, Hinged, 80”H x 56”W, right hand open, clear

OR-MMADRH80X56RH-B Air Door, Hinged, 80”H x 56”W, right hand open, black

Mighty Mo Frame Panel

The Frame Panel is used to create containment when one row of racks or cabinets is not the same length as another row. It creates a right angle from the aisle end door to the rack or cabinet of the shorter row, effectively closing the row and preventing the mixing of hot and cold air. Each frame support is two feet wide to match the size of the standard floor tiles. The frames are available in clear or black anodized aluminum.

PART NO.

OR-MMADRF80X24

OR-MMADRF80X24-B

DESCRIPTION

Air Door, Frame Support, 80”H x 24”W, clear

Air Door, Frame Support, 80”H x 24”W, black

15

MIGHTY MO

®

AIR PANEL ROOF

16

Mighty Mo Air Panel Roof

The Air Panel Roof is an aisle cover system that attaches to the top of the racks or cabinets to create a barrier that prevents hot air and cold air from mixing. The roof frame is constructed of heavy gauge aluminum that supports translucent drop away panels. These panels are molded of heat sensitive ceilume polyvinyl chloride plastic. The panels shrink when exposed to heat and drop out of the supporting frames, ensuring there is no interference with the operation of the overhead automatic sprinklers. The panels can also be removed for easy access when overhead maintenance is needed.

The frames are available in clear or black anodized aluminum.

PART NO.

OR-MMAPR56X80

DESCRIPTION

Air Panel Roof, 2”H x 55-1/2”W x 79-1/2”L, clear

OR-MMAPR56X80-B Air Panel Roof, 2”H x 55-1/2”W x 79-1/2”L, black

Contact customer service for additional sizes.

MIGHTY MO

®

AIR CAP

Mighty Mo Air Cap

Retractable Aisle Cover

The Air Cap is a flat, retractable roof system that attaches to the top of racks or cabinets. The Air Cap creates a barrier that prevents hot air and cold air from mixing. This retractable cover is held in place with thermal links that release the cover if temperatures go above 135°F. The fire resistant cover is spring loaded and retracts back into the metal cassette during a fire event. This ensures that the sprinkler pattern is not interrupted and prevents the cover from being exposed to the fire. Normal fire suppression systems engage at 158°F . The retractable feature also allows easy access when overhead maintenance is needed. The frames are available in black anodized aluminum.

PART NO.

OR-MMACAP60X30

DESCRIPTION

Air Cap, 60”W x 30’L, black

OR-MMACAP84X30 Air Cap, 84”W x 30’L, black

Contact customer service for lengths under 30 feet.

17

MIGHTY MO

®

AIR BOOTH

Mighty Mo Air Booth

The Air Booth is a three sided containment system that is placed directly over a perforated tile, in front of a rack or cabinet. This isolates the cold air provided from the perforated tile, creating a dedicated supply targeted specifically for the intake of active equipment within individual racks or cabinets. By providing exclusive access to cold air, the Air Booth spot cools high density and high powered equipment. The Air Booth is an effective containment system for isolated racks and cabinets.

The frames are available in clear or black anodized aluminum.

PART NO.

OR-MMABTH802424

18

OR-MMABTH802424-B

OR-MMABTH804824

OR-MMABTH804824-B

OR-MMABTH807224

OR-MMABTH807224-B

DESCRIPTION

Air Booth, 3 sided,

80”H x 24”W x 24”D, clear

Air Booth, 3 sided,

80”H x 24”W x 24”D, black

Air Booth, 3 sided,

80”H x 48”W x 24”D, clear

Air Booth, 3 sided,

80”H x 48”W x 24”D, black

Air Booth, 3 sided,

80”H x 72”W x 24”D, clear

Air Booth, 3 sided,

80”H x 72”W x 24”D, black

MIGHTY MO

®

AIR ACCESSORIES

Toolless Snap-in Filler Panels

Ortronics toolless snap-in filler panels are used to fill open rack units in racks and cabinets where separation of cold air and hot air is required.

They are designed to work with active equipment and Ortronics flat, angled or curved patch panels.

The toolless snap-in filler panels unique patent pending design allows them to snap into 19” EIA/ECA-310-E compliant tapped or square hole mounting rails. Because no field modification is required to fit a tapped hole, the panel can be remounted in a square hole in the future eliminating the need to stock two different types of panels.

PART NO.

OR-BFPT-1RU-10

DESCRIPTION

1.75”H x19”W, 1 rack unit, pack of 10, black

OR-BFPT-2RU-10 3.5”H x19”W, 2 rack units, pack of 10, black

Also available in white.

Mighty Mo Air Grille

The Air Grille is a ceiling vent that is installed above the hot aisle. This vent allows the hot exhaust air to pass into the plenum instead of recirculating throughout the equipment room.

PART NO.

DESCRIPTION

OR-MMAGCT2424 Ceiling vent, 24” x 24”, pk of 30, white

OR-MMAGCT2448 Ceiling vent, 24” x 48”, pk of 15, white

Mighty Mo CRAC Unit Air Extension

The CRAC Unit Air Extension mounts to the top of the CRAC unit and extends to the drop ceiling. The Air Extension then draws higher temperature return air from the ceiling, back to the CRAC unit, increasing cooling capacity and resulting in increased CRAC unit efficiency. The Air Extension can also be used in rooms without drop ceilings as well, acting as a snorkel to pull warmer air from above the CRAC unit to increase efficiency.

Mighty Mo Air Extensions are made of high grade aluminum and are manufactured to meet the individual requirements of your data center.

The prefix for the part number uses the following format:

OR-MMAE-

Part Number

Prefix

X X X

Height from top of

CRAC to drop ceiling

Width of

CRAC unit

X

Depth of

CRAC unit

-G

Color

G = Cool Grey

X X X X

Numerical

Suffix

The height, width and depth are rounded to the nearest foot. The maximum height for an air extension is 8 feet. The width and depth are based on the rough dimensions of the CRAC unit.

The 4 digit numerical suffix will be assigned after the quantity and location of access doors and exact dimensions for your unit are determined.

Please contact your Legrand | Ortronics Representative or Technical Support to help configure your

Mighty Mo Air Extension.

Ortronics

125 Eugene O’Neill Drive

New London, CT 06320

800.934.5432

Legrand, North America

60 Woodlawn Street

West Hartford, CT 06110

1.877.BY.LEGRAND (295.3472) www.legrand.us

570 Applewood Crescent

Vaughan, Ontario L4K 4B4

905.738.9195 www.legrand.ca

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
