Yamaha CC-75 Owner's manual
CC-75
Natural Sound Mini Component System
Chaîne Mini de la série “Natural Sound”
Natural Sound Mini Komponenten-System
Natural Sound Mini Komponent System
Sistema di Componenti Mini a Suono Naturale
Sistema de Componentes con Sonido Natural
Natural Sound Mini Component Systeem
CC-75: RX-S75 + CDC-S75 + KXW-S75 + NX-S75
Active Servo
Technology
OWNER‘S MANUAL
MODE D‘EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
SUPPLIED ACCESSORIES
ACCESSOIRES FOURNIS
MITGELIEFERTES ZUBEHÖR
MEDFÖLJANDE TILLBEHÖR
ACCESSORI IN DOTAZIONE
ACCESORIOS INCLUIDOS
BIJGELEVERDE ACCESSOIRES
●
●
●
●
●
●
●
●
●
●
●
●
●
●
After unpacking, check that the following parts are contained.
Après le déballage, vérifier que les pièces suivantes sont incluses.
Nach dem Auspacken überprüfen, ob die folgenden Teile vorhanden sind.
Kontrollera efter det apparaten packats upp att följande delar finns med.
Verificare che tutte le parti seguenti siano contenute nell’imballaggio dell’apparecchio.
Desembale el aparato y verificar que los siguientes accesorios están en la caja.
Controleer na het uitpakken of de volgende onderdelen voorhanden zijn.
Remote control transmitter
Télécommande
Fernbedienung
Fjärrkontroll
Telecomando
Controlador remoto
Afstandbediening
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
<Except U.K. and Europe
Models>
<Excepté le modèles pour
le Royaume-Uni et
l’Europe>
<Außer Großbritannien- und
Europa-Modelle>
<Undantaget modell för
Storbritannien och Europa>
<Eccetto modelli per Gran
Bretagna e l’Europa>
<Excepto modelos para
Reino Unido y Europa>
<Behalve de modellen voor
Groot-Brittannië en Europa>
<U.K. and Europe models>
<Modèles pour le RoyaumeUni et l’Europe>
<Großbritannien- und
Europa-Modelle>
<Modell för Storbritannien
och Europa>
<Modelli per Gran Bretagna
e l’Europa>
<Modelos para Reino Unido
y Europa>
<Modellen voor GrootBrittannië en Europa>
●
●
●
●
●
●
●
●
Batteries (size AA, UM/SUM-3, R6, HP-7)
Piles (format AA, UM/SUM-3, R6, HP-7)
Batterien (Größe AA, UM/SUM-3, R6, HP-7)
Batterier (Storl. AA, UM/SUM-3, R6, HP-7)
Batterie (dimensioni AA, o UM/SUM-3, o R6, o HP-7)
Pilas (tamaño AA, tipo UM/SUM-3, R6, HP-7)
Batterijen (maat AA, UM/SUM-3, R6, HP-7)
AM (MW/LW) loop antenna
Cadre-antenne AM (PO/GO)
MW/LW-Rahmenantenne
MV/LV ramantenn
Antenna ad anello per AM
(MW e LW)
Antena de cuadro AM (OM/OL)
AM (MW/LW) lusantenne
Indoor FM antenna
Antenne intérieure FM
UKW-Innenantenne
FM inomhusantenn
Antenna FM per interni
Antena interior de FM
FM binnenantenne
Speaker cords (for NX-S75)
Câbles d’enceintes (pour les enceintes NX-S75)
Lautsprecheranschlußkabel (für NX-S75)
Högtalarledningar (för NX-S75)
Cavi per gli altoparlanti (per l’NX-S75)
Cables de los altavoces (para el NX-S75)
Luidsprekerdraden (voor NX-S75)
This product complies with the radio frequency interference requirements of the Council Directive 82/499/EEC and/or
87/308/EEC.
Cet appareil est conforme aux prescriptions de la directive communautaire 87/308/CEE.
Diese Geräte entsprechen der EG-Richtlinie 82/499/EWG und/oder 87/308/EWG.
Dette apparat overholder det gaeldende EF-direktiv vedrørende radiostøj.
Questo apparecchio è conforme al D.M.13 aprile 1989 (Direttiva CEE/87/308) sulla soppressione dei radiodisturbi.
Este producto está de acuerdo con los requisitos sobre interferencias de radio frequencia fijados por el Consejo Directivo
87/308 CEE.
Dit product voldoet aan de EEG normen betreffende radio-frekwentie storingen 82/499/EEG en/of 87/308/EEG.
1
CDC-S75
1
2
3
4
TOTAL
REMAIN
S F REPEAT
5
A
0
A
PROGRAM RANDOM
1 2
3
4
5
EDIT
B 11 12 13 14 15
67
6
7
8
9
10
16 17 18 19 20 OVER
8
9
1
2
PLAY
CD CHANGER
CDC–S75
3
SINGLE
TIME
1
TIME
2
EDIT
3
REPEAT
RANDOM
SINGLE REMAIN
TOTAL
TOTAL REMAIN
SKIP
SEARCH
4 5 6 7
3
8
CHANGE OPEN/CLOSE
9
0
A
2
RX-S75
<Except U.K. and Europe Models>
<Excepté le modèles pour le Royaume-Uni et l’Europe>
<Außer Großbritannien- und Europa-Modelle>
<Undantaget modell för Storbritannien och Europa>
<Eccetto modelli per Gran Bretagna e l’Europa>
<Excepto modelos para Reino Unido y Europa>
<Behalve de modellen voor Groot-Brittannië en Europa>
B
C
D
E FG
INPUT SELECTOR
CD/TAPE/TUNER/AUX 1/AUX 2
H
VOLUME
DSS
POWER
ON/OFF
MODE
SP/PHONES
0
Active Servo
STEREO RECEIVER
RX–S75
Technology
TUNER PRESET
PHONES
DISPLAY
I J
DOWN
I0
UP
TUNING
MEMORY
DOWN
UP
AUTO/MAN'L
TIMER
TIME ADJ
HOUR
MINUTE
SEC
BAND
C
TREBLE
BALANCE
AUTO MEMO
TIMER REC
L M N O P Q R
K
B
BASS
A/B/C/D/E
–
+
S
–
+
T
L
R
U
D
MHz
E
MEMORY
AUTO TUNING STEREO TUNED
SLEEP TIMER
M
DSS
RO C K
JAZ Z
C L AS S I C
RE L AX E D
F
G
H I
4
J K
L
K
<U.K. and Europe models>
<Modèles pour le Royaume-Uni et l’Europe>
<Großbritannien- und Europa-Modelle>
<Modell för Storbritannien och Europa>
<Modelli per Gran Bretagna e l’Europa>
<Modelos para Reino Unido y Europa>
<Modellen voor Groot-Brittannië en Europa>
V
C
D
WX Y H
VOLUME
INPUT SELECTOR
CD/TAPE/TUNER/AUX/PHONO
RDS MODE
FREQ/PS/PTY/RT/CT
POWER
PTY SEEK
MODE
0
START
I0
PTY SELECTOR
Active Servo
STEREO RECEIVER
RX–S75
Technology
TUNER PRESET
PHONES
DISPLAY
I J
DOWN
UP
K
B
TUNING
BASS
A/B/C/D/E
MEMORY
DOWN
UP
AUTO/MAN'L
TIMER
TIME ADJ
HOUR
MINUTE
SEC
BAND
TIMER REC
L M N O P Q R
C
TREBLE
–
+
S
–
+
T
D
MHz
E
MEMORY PTY H
F
N
AUTO TUNING STEREO TUNED
SLEEP TIMER
HI J
G
5
BALANCE
AUTO MEMO
L
R
U
3
KXW-S75
Z
[
\
DECK A
`
a
]
DECK B
PLAYBACK
RECORD/PLAYBACK
l
a
PLAY
DIRECTION
CASSETTE DECK
KXW–S75
EJECT
MODE
DUBBING
NORM
b
4
cd e
REC/PAUSE
HIGH
f
NX-S75
NR
OFF
g
B
EJECT
C
h ij
m
n
6
k
5
1
CD
CD
2
3
1
2
3
4
5
1
2
3
4
5
9
0
6
7
8
6
7
8
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
PLAY/PAUSE OPEN/CLOSE
DISC SKIP
PLAY
TUNER
STOP
0
1
2
3
4
5
D
1
2
3
4
5
6
7
8
6
7
8
9
0
E
F
G
A
B
C
D
E
EDIT
+10
PLAY
4
5
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
PROG
TAPE
RANDOM
STOP
MODE
DISC SKIP
PLAY/PAUSE OPEN/CLOSE
P
TUNER
HIJ K L
TAPE
DECK
A/B
TIME
REPEAT
M
N
O
A
B
VOLUME
-
+
C
6
QR S
T
PLAY
STOP
PLAY
TAPE
U
7
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
VOLUME
-
V
DSS
+
W
89
6
7
1
3
0.2 m – 6 m
(8” – 20’)
30°
2
7
30°
8
A
To AC outlet
Vers la prise c.a.
Zur Netzsteckdose
Till nätuttag
Alla presa AC
Al tomacorriente
Naar wisselstroom-stopcontact
9
PHONES
B
0
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
VOLUME
-
8
DSS
+
ENGLISH
English
INTRODUCTION
Thank you for purchasing this YAMAHA product. We hope it will give you many years of trouble-free enjoyment. For the best
performance, read this manual carefully. It will guide you in operating your YAMAHA product.
FEATURES
•
•
•
•
•
75W + 75W (6Ω) Output Power, 10% THD, 1 kHz
•
Automatic CD Editing Function for Recording to
Tape
•
Double Cassette Tape Deck with Automatic
Reversing Function
•
•
2-Way Speed Dubbing
Random Access Programmable CD Playback
Single Track/Entire Disc/All Disc Repeat Play
Random-sequence Play
Automatic Synchronized Recording with CD
Playback
•
•
•
40 Station Automatic Preset Tuning
•
Remote Control Capability
Multi-Use Timer/Sleep Timer
Active Servo Processing Speaker System
(NX-S75)
<Except U.K. and Europe models >
• 4-Mode Digital Super Surround (DSS) Processor
• Digital Super Surround Effective Even by
Listening with Headphones
<U.K. and Europe models >
• Multi-Functions for RDS Broadcast Reception
Dolby B/C Noise Reduction System
CONTENTS
Page
Page
PRECAUTIONS ..................................................................2-3
COMPACT DISC PLAYER OPERATION.......................11-18
SETTING UP THE SYSTEM .................................................3
TUNING OPERATION ....................................................19-21
NAMES OF CONTROLS AND INDICATORS ....................4-5
REMOTE CONTROL TRANSMITTER................................5-6
RECEIVING RDS STATIONS
<U.K. and Europe models only> ...............................22-25
REMOVING THE FRONT GRILLE ........................................6
TAPE DECK OPERATION ............................................26-29
LISTENING WITH HEADPHONES ........................................6
RECORDING COMPACT DISCS ...................................30-35
OPEN/CLOSE THE CONTROL DOOR .................................6
OTHER RECORDINGS...................................................36-37
CONNECTIONS ..................................................................7-8
HOW TO USE THE BUILT-IN TIMER.............................38-41
TURNING THE POWER ON/OFF TO THIS SYSTEM ...........8
USING EXTERNAL UNITS ..................................................42
SETTING THE CLOCK ..........................................................9
MAINTENANCE ...................................................................43
SOUND CONTROL ..............................................................10
TROUBLESHOOTING .........................................................44
DIGITAL SUPER SURROUND (DSS) PROCESSOR
CONTROL <Except U.K. and Europe models> .........10-11
SPECIFICATIONS................................................................45
For basic source play, the following illustrations on top of
pages will help you to look for the section you need.
......CD playback
......Tape playback/recording
E-1
......Tuning
PRECAUTIONS: READ THIS BEFORE OPERATING YOUR UNIT
■ To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
•
■ This system is equipped with the newly developed Active Servo
Processing Speaker System. It is not designed for use with
conventional speakers. Therefore, do not attempt to connect
other speakers than the provided speaker system.
•
■ Choose the installation location of this unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Also avoid
locations subject to vibration and excessive dust, heat, cold or
moisture. Keep it away from sources of hum such as
transformers and electric motors.
•
CD pickup
Leave the power on with no disc in the unit until normal
playback is possible (about 1 hour).
Tape head
Leave the power on with no cassette in the unit until normal
playback is possible (about 1 hour).
Note
If condensation forms on the tape head, foreign matter may
accumulate during use.
Remote control
Wipe off condensation on the transmitter window with a soft
cloth before operating the unit.
■ Do not operate this unit upside-down. It may overheat, possibly
causing damage.
■ Never open the cabinet. If something drops into the set, contact
your dealer.
IMPORTANT
Please record the serial number of this unit in the space below.
■ The openings on the cabinet assure proper ventilation of the unit.
If these openings are obstructed, the temperature inside the
cabinet will rise rapidly and eventually damage the circuits.
Therefore, avoid placing objects against these openings and do
not install the unit where the flow of air through the ventilation
openings could be impeded.
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future reference.
■ Always set the VOLUME control to minimum before starting the
audio source: increase the volume gradually to an appropriate
level after play has started.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
■ When not planning to use this unit for long periods of time (ie.,
vacation, etc.), disconnect the AC power plug from the wall outlet.
CAUTION (FOR CANADA MODEL)
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT AND FULLY INSERT.
■ Grounding or polarization – Precautions should be taken so that
the grounding or polarization of an appliance is not defeated.
FOR CANADIAN CUSTOMER
THIS CLASS B DIGITAL APPARATUS MEETS ALL
REQUIREMENTS OF THE CANADIAN INTERFERENCECAUSING EQUIPMENT REGULATIONS.
■ Do not use force on switches, controls or connection wires. When
moving the unit, first disconnect the power plug and the wires
connected to other equipment. Never pull the wire itself.
■ Do not attempt to clean the unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
■ Be sure to read the “TROUBLESHOOTING” section regarding
common operating errors before concluding that the unit is faulty.
NOTE
Please check the copyright laws in your country to record from
records, compact discs, radio, etc. Recording of copyright material
may infringe copyright laws.
■ To prevent lightning damage, disconnect the AC power plug and
the antenna cable when there is an electrical storm.
■ Do not plug the AC power plug to the wall socket before you
finish all connections.
For U.K. customers
■ Never allow metallic items (e.g. screwdrivers, tools, etc.) to come
near the cassette deck’s record/playback head assembly in this
unit. Doing so may not only scratch or damage the head’s mirrorsmooth finish, it may change the magnetic characteristics of the
heads, causing a deterioration in reproduction performance
quality.
If the socket outlets in the home are not suitable for the plug
supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the
instructions described below.
Note: The plug severed from the mains lead must be
destroyed, as a plug with bared flexible cord is hazardous if
engaged in a live socket outlet.
■ Although the cassette deck’s record/playback heads used in this
unit are high quality heads with outstanding reproduction
characteristics, they can become dirty through the use of old
tapes or from dust accumulation over time. This can have a
serious effect on reproduction quality. Clean the heads regularly
with one of the commonly available head cleaners or with
cleaning solutions.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT:
The wire in the mains lead are coloured in accordance
with the following code:
■ The voltage to be used must be the same as that specified on
this unit. Using this product with a higher voltage than that which
is specified is dangerous and may result in a fire or other type of
accident causing damage. YAMAHA will not be held responsible
for any damage resulting from use of this unit with a voltage other
than that which is specified.
Blue: NEUTRAL
Brown: LIVE
The colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug. Proceed
as follows: the wire which is coloured BLUE must be
connected to the terminal which is marked with the letter
N or coloured BLACK. The wire which is coloured
BROWN must be connected to the terminal which is
marked with the letter L or coloured RED. Making sure
that neither core is connected to the earth terminal of the
three pin plug.
■ The sound level at a given volume setting depends on speaker
location and other factors. Care should be taken to avoid
exposure to sudden high levels of sound, which may occur when
turning on the unit with the volume control setting at high, and to
continuous high levels of sound.
■ Sudden temperature changes and storage or operation in an
extremely humid environment may cause condensation inside the
cabinet.
Condensation can cause the unit to malfunction.
To eliminate condensation:
E-2
WARNING
CAUTION FOR CARRYING THIS UNIT
Be sure not to carry or tip this unit with discs remaining in it.
To reduce the risk of fire or electric shock, do not expose this unit to
rain or moisture.
CAUTION FOR MOVING THIS UNIT
Before moving this unit, first remove all discs from the disc table
and close the table by pressing the OPEN/CLOSE button, and
then switch off the power by pressing the POWER switch, and
last, after you confirm that “no disc” is illuminated on the display,
disconnect the power plug from the AC outlet.
To avoid electrical shock, do not open the cabinet. Refer
servicing to qualified personnel only.
CAUTION 1
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
The apparatus is not disconnected from the AC power
source as long as it is connected to the wall outlet, even if
the apparatus itself is turned off.
CAUTION 2
As the laser beam used in this unit is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified
personnel only.
VOLTAGE SELECTOR (General model only)
The voltage selector on the rear panel of this unit must
be set for your local main voltage BEFORE plugging
into the AC main supply.
Voltages are 110/120/220/240V AC, 50/60 Hz.
This unit is classified as a CLASS
1 LASER product.
The CLASS 1 LASER PRODUCT
label is located on the rear exterior.
(Europe and U.K. model only)
Laser component in this product is capable of emitting radiation
exceeding the limit for Class 1.
Laser Diode Properties
Material: GaAlAs
Wavelength: 780nm
Emission Duration: continuous
Laser Output: max. 44.6µW*
* This output is the value measured at a distance of about 200mm
from the objective lens surface on the Optical Pick-up Block.
•
•
•
•
SETTING UP THE SYSTEM
Place this system as illustrated on the left and allow spaces
more than indicated around the system and more than 10 cm
(3-15/16”) behind the system to assure good ventilation. Be
sure not to place another unit or any object on top of the
receiver (RX-S75) to prevent the ventilation holes on the top
panel of the receiver from being obstructed. Otherwise, it
may cause fire or damage to the receiver.
Setup examples
KXW-S75
RX-S75
CDC-S75
10 cm
10 cm
1 cm
1 cm
Notes
• When placing the speakers apart from the main units,
allow a space of at least 10 cm (3-15/16”) from above,
behind and on the both sides of the main units.
• If the system is put in a rack, the front of it must be fully
opened.
• Disconnect the AC supply lead from the AC outlet before
connecting or disconnecting any component.
10 cm
10 cm
RX-S75
CDC-S75
KXW-S75
10 cm
10 cm
E-3
English
PRECAUTIONS: READ THIS BEFORE OPERATING YOUR UNIT
NAMES OF CONTROLS AND INDICATORS
(See figure 1 and 2 on page 3 – 5 at the beginning part of this manual.)
CD player (CDC-S75)
Display
1
2
3
4
5
6
7
8
Disc Table
For CD player
Stop Button:
1
2
3
4
5
6
7
8
9
0
A
9
0
A
Disc Selector Buttons
TIME Button
EDIT Button
REPEAT Button
RANDOM Button
SKIP Buttons:
/
(SEARCH Buttons:
Play/Pause Button:
/
)
/
OPEN/CLOSE Button:
PLAYXCHANGE Button
Receiver (RX-S75)
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Track Number Indicator
(S, F) REPEAT Indicator
Time Display
Play Indicator:
Disc Indicator
EDIT Indicator
Tape Side Indicator
Music Calendar Indicator
Music Calendar OVER Indicator
RANDOM Play Indicator
PROGRAM Indicator
For receiver
B
C
D
E
F
G
H
I
J
K
L
M
N
INPUT SELECTOR Control
POWER Switch
Remote Control Sensor
SP/PHONES Mode Selector Button
DSS ON/OFF Selector Button
DSS MODE Selector Button
VOLUME Control
PHONES Jack
DISPLAY Button
TUNER PRESET DOWN/UP Buttons
A/B/C/D/E (TIMER) Button
MEMORY (TIME ADJUST) Button
TUNING DOWN (HOUR) Button
TUNING UP (MINUTE) Button
AUTO/MAN’L (SEC) Button
BAND Selector Button
AUTO MEMORY (TIMER REC) Button
BASS Tone Control
TREBLE Tone Control
BALANCE Control
INPUT SELECTOR (PTY SELECTOR) Control
PTY SEEK MODE Button
RDS MODE Selector Button
PTY SEEK START Button
E-4
Preset Number Indicator
Band Indicator
Station Frequency Display
TUNED Indicator
MEMORY Indicator
AUTO TUNING Indicator
STEREO Indicator
SLEEP Indicator
TIMER Set Indicator
Effect Level Indicator
DSS Mode Indicators
Phones Mode Indicator
PTY H Indicator
English
NAMES OF CONTROLS AND INDICATORS
(See figure 3 and 4 on page 6 at the beginning part of this manual.)
Tape deck (KXW-S75)
Z
[
\
]
`
a
b
c
d
e
f
g
h
i
j
k
l
DECK A Cassette Compartment
DECK A Selector Button and Indicator
DECK B Selector Button and Indicator
DECK B Cassette Compartment
REC/PAUSE Button and Indicator
DOLBY NR Switch
Play Button:
Fast Wind Button:
DECK B EJECT Button
PLAY Indicator
Stop Button:
Play Direction Indicators
DECK A EJECT Button
Speakers (NX-S75)
Fast Wind Button:
Play Button:
Reverse MODE Switch
m
n
YST Port
F
G
H
I
J
K
REPEAT Button
Speaker Terminals
DUBBING (NORMAL/HIGH) Buttons and
Indicators
REMOTE CONTROL TRANSMITTER
Names of control buttons
(See figure 5 on page 7 at the beginning part of this
manual.)
■ Receiver control buttons
1
2
3
4
5
6
7
8
9
0
A
B
C
Remote Control Transmitter Window
■
CD player control buttons
D
E
Preset Station Number Buttons
L
M
N
O
P
A, B, C, D, E Selector Buttons
EFFECT LEVEL – (Down)/+ (Up) Buttons
POWER Switch
SLEEP Button
RANDOM Button
Disc Play MODE Selector Button
DISC SKIP Button
STOP Button:
Skip Buttons:
/
(Search Buttons:
/
PLAY/PAUSE Button:
PROGRAM Button
TAPE Button
EDIT Button
OPEN/CLOSE Button:
SP/PHONES Mode Selector Button
■ Tape deck control buttons
DISPLAY Button
VOLUME – (Down)/+ (Up) Buttons
Q
R
S
T
U
V
W
TUNER Input Selector Button
INPUT Selector Button
DSS On/Off Button
DSS MODE Selector Button
Play Button:
Stop Button:
Play Button:
Fast Wind Button:
DECK A/B Button
Fast Wind Button:
REC/PAUSE Button:
Track Number Input Buttons
TIME Button
* Parts in shaded areas on the figure 5 are not equipped on U.K. and Europe models.
This manual mainly uses illustrations for U.K. and Europe models.
E-5
)
REMOTE CONTROL TRANSMITTER
Loading the batteries for the
remote control transmitter
Proper use of the remote control
transmitter
(See figure 6 on page 7.)
(See figure 7 on page 7.)
1
Remove the battery compartment cover.
(Press the left edge of the cover to right with a finger, and
then pull it upward.)
Aim (within the range of 60° with no obstacles) the remote
control transmitter at the remote control sensor and operate
as shown.
2
Insert 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or
equivalent) into the battery compartment.
* Installing the batteries improperly may cause failure.
3
Replace the battery compartment cover.
Notes concerning use
• Replace the batteries if control distance decreases or
operation becomes unstable.
• Periodically clean the transmitter window on the remote
control transmitter and the sensor on the main unit with a
soft cloth.
• Exposing the sensor on the main unit to strong light
(especially an inverter type of fluorescent lamp etc.) may
interfere with operation. In this case, reposition the main
unit to avoid direct lighting.
• Keep the remote control transmitter away from moisture,
excessive heat, shock and vibrations.
• The remote control transmitter’s usable range is within
0.2m (8”) and 6m (20’) away from the sensor.
Precautions for battery use
Insert the batteries according to the direction indicated in
the battery compartment.
Replace all batteries with new ones at the same time.
Remove the batteries if they are weak or if the unit is not
in use for long periods.
Don’t mix normal batteries with rechargeable batteries.
•
•
•
•
REMOVING THE FRONT GRILLE
(See figure 8 on page 8.)
The front grille is fastened to the enclosure at four points, and
can be removed if desired. To remove the grille, hold on to
both sides and slowly pull straight away from the speaker. To
reattach, line up the four pegs on the speaker with the four
corresponding holes on the inside surface of the grille and
push gently.
Note
When the grille is removed, take care not to touch the
speaker units with your hands or to exert excessive force with
tools.
LISTENING WITH HEADPHONES
(See figure 9 on page 8.)
•
•
Be sure that your headphones have a 3.5 mm (1/8”)
diameter plug and are between 16 ohms and 50 ohms
impedance. Recommended impedance is 32 ohms.
When headphones are connected, the speakers are
defeated automatically. Adjust the VOLUME control for
desired volume.
OPEN/CLOSE THE CONTROL DOOR
When it is not necessary to operate controls inside the
control door, close the door.
To open or close the door, press the right edge until it clicks.
E-6
Never plug the AC supply lead of this system into the AC outlet until all connections are
completed.
Antenna connection
(1)
(1) Supplied FM antenna
Connect the FM antenna wire to the corresponding terminal
and direct the FM antenna wire to the direction where the
strongest signal can be received.
AM
ANT
GND
(2)
75Ω
UNBAL.
(2) Supplied AM (MW/LW) loop antenna
FM
ANT
Connect the AM (MW/LW) loop antenna wires to the
corresponding terminals. Position the AM (MW/LW) loop
antenna for optimum reception. Place the AM (MW/LW) loop
antenna on a shelf etc., or install it on the rack or wall with
screws (not supplied).
15 m (49 feet)
Notes
• When static is still heard even after adjusting the position
of the AM (MW/LW) loop antenna, try reversing the wire
connections (top to bottom).
• Do not place the AM (MW/LW) loop antenna on the unit. It
will result in noise generation, since the unit is equipped
with digital electronics. Place the AM (MW/LW) loop
antenna away from the unit.
(4)
(3)
7.5 m (25 feet)
(3) External FM antenna
Use an external FM antenna instead of an indoor FM
antenna if you need better reception. Consult your dealer.
Earth rod
AM
ANT
(4) External AM (MW/LW) antenna
GND
75Ω
UNBAL.
Use an external AM (MW/LW) antenna if you need better
reception. Consult your dealer.
FM
ANT
Note
When using an external AM (MW/LW) antenna, be sure to
keep the wire of the AM (MW/LW) loop antenna connected.
or
* For U.K. and Europe models, “AM” is replaced by
“MW LW”.
FREQUENCY STEP switch (General model only)
Because the interstation frequency spacing differs in
different areas, set the FREQUENCY STEP switch
(located at the rear) according to the frequency spacing in
your area. Before setting this switch, disconnect the AC
supply lead of this unit from the AC outlet.
100 kHz FM
10 kHz AM
50 kHz
9 kHz
FREQUENCY STEP
E-7
English
CONNECTIONS
CONNECTIONS
Speaker connection
Right
Left
Connect each speaker wire to the SPEAKERS terminals.
R
Cautions
• Do not let the bare speaker wires touch each other as this
could damage the receiver and/or speakers.
• When connecting the speakers to the unit, be sure to
connect the speaker wires properly. Do not make a
mistake from the right channel to the left channel and from
the plus (+) terminal to the minus (–) terminal.
• Do not connect these SPEAKERS terminals to speakers
other than the provided speaker system NX-S75.
L
System connection
(See figure 0 on page 8.)
•
•
(Black wire with white line → plus (+) terminal,
black wire → minus (–) terminal)
Connect the red connector on the rear of CDC-S75 to the
red socket on the rear of RX-S75.
Connect the black connector on the rear of KXW-S75 to
the black socket.
How to disconnect the system connector
Grasp both sides of the connector to disconnect the
connector.
Connecting the AC supply lead
(See figure A on page 8.)
•
•
After connecting the speakers and system connectors,
plug the AC supply lead into a convenient AC outlet.
Unplug the AC supply lead from the AC outlet if the unit is
not to be used for a long period of time.
TURNING THE POWER ON/OFF TO THIS SYSTEM
Automatic power-on function
(See figure B on page 8.)
Even when the power is off, pressing the following buttons
will turn the system on, and then perform their own functions.
If the AC supply lead is connected to the AC outlet, this
system can be turned ON and OFF (STANDBY mode) by
pressing the POWER switch on the front panel of RX-S75 or
the POWER switch on the remote control transmitter.
For Tuner operation
• TUNER on the remote control transmitter
For CD player operation
/ , disc selector buttons, OPEN/CLOSE on the front
panel of CDC-S75
/ , OPEN/CLOSE on the remote control transmitter
•
•
STANDBY mode
While the power is on, pressing the POWER switch (or the
POWER switch on the remote control transmitter) switches
the system to the STANDBY mode. (In this mode, the
display shows only the time.) In this mode, main voltage is
still present inside the system. If you want to switch off the
system completely, disconnect the AC power plug from the
AC outlet.
For tape deck operation
• , , DECK A, DECK B on the front panel of KXW-S75
• , , DECK A/B on the remote control transmitter
Automatic power-off function
When the CD or TAPE input source is selected, if there is no
operation and in the stop mode for about 30 minutes, the
system will be turned off automatically.
E-8
1
2
While the power is on, press the DISPLAY button to
display the time. If the power is off, you can proceed to the
next step.
2
While pressing the TIME ADJ button, press the HOUR
button and set the hour.
* Press the HOUR button once to advance the time by 1
hour. Press and hold to advance continuously.
3
While pressing the TIME ADJ button, press the MINUTE
button and set the minute.
* Press the MINUTE button once to advance the time by
1 minute. Press and hold to advance continuously.
* The hour setting will not advance even if minute is
advanced from “59” to “00”.
TUNING
MEMORY
DOWN
UP
TIME ADJ
HOUR
MINUTE
Changes.
3
1
DISPLAY
TUNING
MEMORY
DOWN
UP
TIME ADJ
HOUR
MINUTE
Changes.
To display the time by “second”
While pressing the SEC button, the current time is displayed
by minute and second.
To reset the second to “00”
While pressing the SEC button, press the TIME ADJ button.
* If the current second is lower than 30, it is reset to 00.
* If the current second is higher than 30, the minute is
advanced by 1 minute and the second is reset to 00.
(If the current minute is “59”, in this case, the hour is also
advanced by 1 hour.)
AUTO/MAN'L
SEC
Minute Second
In the event of a power failure or when the AC supply
lead is disconnected.
The time display will go out, however, the clock will function
for about 5 minutes without power supply. So you do not
have to reset the time if the AC power supply is resumed
within about 5 minutes.
When the AC power supply is resumed after more than 5
minutes pass without power supply, the time display will flash
on and off to indicate that the time must be reset.
Note
If this system is left for several minutes without setting the
time after the AC power lead of this system is connected to
the AC outlet, there may be a case that the display is turned
into a demonstration mode. (This mode is virtually
unnecessary for using this system.)
In this case, first turn the power on by pressing the POWER
switch to cancel the mode, and then set the time.
E-9
English
SETTING THE CLOCK
SOUND CONTROL
Volume
Front panel operation
Rotate the VOLUME control towards 10 to increase the
volume, and towards 0 to decrease the volume.
VOLUME
Remote control operation
Press the VOLUME + button to increase the volume and the
VOLUME – button to decrease the volume.
VOLUME
-
0
+
I0
Balance
Adjust the balance of the output volume to the left and right
speakers to compensate for sound imbalance caused from
the speaker settings or the listening room condition.
Turn this clockwise to emphasize the right and
counterclockwise for the left.
BALANCE
L
R
Tone
BASS
BASS
TREBLE
TREBLE
–
+
–
: Turn this clockwise to increase (or counterclockwise to decrease) the low frequency
response.
: Turn this clockwise to increase (or counterclockwise to decrease) the high frequency
response.
+
DIGITAL SUPER SURROUND (DSS) PROCESSOR CONTROL <Except U.K. and Europe models>
The Digital Super Surround (DSS) Processor built into this
unit presents you with sound effect which simulates acoustic
environments suitable for some genres of music.
This unit provides the following 4 DSS modes.
ROCK
JAZZ
Mode
Feature
ROCK
Low frequency and high frequency of the
source sound are somewhat emphasized.
It is suitable for listening to rock or pop music.
JAZZ
This mode creates a sound field with much
presence adding spatial effect as if music
instruments are coming in front.
MODE
CLASSIC
RELAXED
E-10
CLASSIC
The sound stage is expanded.
It is suitable for listening to classic music, etc.
RELAXED
This mode is suitable for easy-listening
music. The sound is reproduced with a soft,
comfortable atmosphere.
Listening to the music with the
DSS
Phones mode indicator
DSS
1
Press the DSS ON/OFF selector button so that the effect
level indicator lights up on the display.
2
Select a desired DSS mode by pressing the DSS MODE
selector button once or more until the name of the desired
mode appears on the display.
3
Playback a source. (For source playback, refer to other
sections described later.)
4
Adjust the level of effects by pressing the EFFECT LEVEL
down (–) or up (+) button.
* Effect level can be checked with the effect level indicator
on the display.
* Each of the DSS modes can be set with a different effect
level.
ROCK
Effect level indicator
1
2
If you will not use the DSS
Press the DSS ON/OFF selector button so that the effect
level indicator on the display goes off.
SP/PHONES
When listening with headphones
Press the SP/PHONES mode selector button so that the
phones mode indicator lights up on the display.
You can obtain a DSS effect suitable for the headphone
listening.
If not using headphones, the SP/PHONES mode selector
button should be pressed so that the phones mode indicator
on the display goes off.
CD
1
1
2
2
3
4
5
3
4
5
9
0
6
7
8
6
7
8
B
C
TIME
PROG
TAPE
REPEAT
A
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
4
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
VOLUME
-
+
1
Note
2
DSS effect is also recorded along with a source. If you wish
to record a source without DSS effect, turn the DSS off when
recording.
SP/PHONES
COMPACT DISC PLAYER OPERATION
Care of compact discs
Compact discs are fairly resistant to damage, however
mistracking can occur due to an accumulation of dirt on the
disc surface.
Follow the guidelines below for maximum enjoyment from
your CD collection and player.
• Do not write on either side of the disc, particularly the nonlabel side. Signals are read from the non-label side. Do
not mark this surface.
• Keep your discs away from direct sunlight, heat and
excessive moisture.
• Always hold the CDs by the edges. Fingerprints, dirt or
water on the CDs can cause noise or mistracking. If a CD
is dirty or does not play properly, clean it with a soft, dry
cloth, wiping straight out from the center, along the radius.
E-11
English
DIGITAL SUPER SURROUND (DSS) PROCESSOR CONTROL <Except U.K. and Europe models>
COMPACT DISC PLAYER OPERATION
CD playback
POWER
Receiver
1
1
Select the CD position with the INPUT SELECTOR
control, watching the display.
2
3
Press the OPEN/CLOSE button to open the disc table.
4
Press the OPEN/CLOSE button to close the disc table.
* The total number of tracks and the total playing time of
the disc being selected will be displayed for several
seconds.
* The music calendar will be displayed only for the
number of tracks on the disc being selected.
* If the compact disc contains more than 20 tracks, the
“OVER” indicator will light up on the music calendar.
Disc selector buttons
2, 4
CD Player
Place discs on the trays, label side up.
* Up to three discs can be loaded on the trays.
* 8 cm (3”) discs may be played without an adaptor.
The disc on the tray located on top of this
indicator is now being selected.
Total number of tracks
7, 1, 2
TOTAL
1
3
2
3
4
5
6
7
8
9
10
11 12
Music calendar
5
Total playing time
If necessary, change the disc play mode by pressing the
disc play MODE selector button on the remote control
transmitter while watching the display.
Single disc play mode: Only a designated disc is played
back.
All disc play mode: All discs on the disc table are played
back sequentially.
Lights up only when the all
disc play mode is selected.
CD
6
5
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
EDIT
+10
TIME
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
REC/PAUSE
EFFECT LEVEL
POWER
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
7, 1, 2
1
VOLUME
-
If necessary, select another disc by pressing the DISC
SKIP button on the remote control transmitter once or
more (so that the corresponding disc tray number is
located on top of the disc indicator).
7
Press the play/pause / button to start playback from
track 1.
* The “ ” indicator will appear and playback will begin.
As the playback of each track on the music calendar is
finished, that track number will go out.
2, 4
TAPE
DECK
A/B
6
+
For easier operation
Pressing the disc selector button (1, 2 or 3) will select the
disc directly, and playback will begin from track 1
automatically.
E-12
Direct operation
To interrupt playback
1
Press the play/pause / button.
* The “ ” indicator will flash.
2
Press the play/pause
from the same point.
/
Even when an input source other than CD player is selected,
pressing the play/pause / button, a disc selector button
or the RANDOM play button, or pressing the front edge of the
disc table gently will start playback directly. In this case, if
the tape deck is playing back a tape, it will be stopped
automatically.
* These ways of playback can also be used to close the disc
table. If the table is closed in these ways, playback will
begin automatically, however, the display will not show the
total number of tracks and the total playing time of the disc
to be played.
button to resume playback
To stop playback
Press the stop
button.
To switch the unit off after use
Turn the unit off by pressing the POWER switch. (The
indicators will go off except for the current time display.)
PLAYXCHANGE
During playback, you can open the disc table by pressing the
PLAYXCHANGE button without interrupting disc playback.
However, in this case, pressing the DISC SKIP button or a
disc selector button has no effect.
Precautions
• If TV or radio interference occurs during CD player
operation, move the unit away from the TV or radio.
• Subjecting the unit to shock or vibration can cause
mistracking.
• Playing some compact discs at high volume can cause
mistracking. In this case, listen at lower volume.
• Do not pull open the disc table forcibly with your hands.
• Do not push the disc table while it is moving.
• If the power fails while the table is open, wait until the
power supply returns or gently push the table manually to
close it.
• The temperature range for playing compact discs is
recommended to be 5°C (41°F) – 35°C (95°F).
Direct-selection play
By using the track number input buttons on the remote
control transmitter, any track you wish to listen to can be
played directly.
CD
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
B
C
TIME
PROG
TAPE
REPEAT
A
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
PLAY/PAUSE OPEN/CLOSE
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
Use the track number input buttons to select the desired
track number. Play will begin automatically.
E
A. For example, to choose selection 5
Press the “5” button.
+10
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
B. For example, to choose selection 12
(1) Press the “+10” button.
(2) Within 3 seconds, press “2” button.
INPUT
DSS
VOLUME
-
+
C. For example, to choose selection 20
(1) Press the “+10” button.
(2) Within 3 seconds, press the “+10” button again.
(3) Within 3 seconds, press the “0” button.
Note
If you select a track number higher than the number of tracks
on the disc, play will begin from the last track on the disc .
E-13
English
COMPACT DISC PLAYER OPERATION
COMPACT DISC PLAYER OPERATION
“Skip search” and “Manual search” are performed using the
same buttons.
Skip search
1
The beginning of any track can be found automatically.
CD player
1
2
2
Select a disc and begin playback.
Press the
button to advance or
button to
reverse through the disc.
Press once for each track to be advanced or reversed.
once to advance to the track following the
• Press
one now playing back.
once to return to the start of the track now
• Press
playing back.
twice to return to the track before the track
• Press
now playing back.
Notes
• This function can also be performed while the unit is
stopped. Press the play/pause / button when your
desired track number appears in the track number display.
Playback will begin from the beginning of the track.
• This function will be performed forward or backward from
any point on the disc. However, it will not move forward
during playback of the final track.
Manual search
CD
1
1
2
3
4
5
3
4
5
9
0
6
7
8
6
7
8
A
2
2
B
C
TIME
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
1
2
1
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
Press and hold the
button to advance play rapidly,
and the
button to reverse play rapidly.
* The sound can be heard (although slightly garbled)
during manual search in either direction. This is
convenient for reviewing the contents quickly.
Note
Manual search can also be performed while playback is
paused, though no sound will be heard.
VOLUME
-
Begin playback.
+
E-14
English
COMPACT DISC PLAYER OPERATION
Program play
6
CD player
1
You can program up to 20 tracks in any desired order.
TIME
1
2
Load discs and close the disc table.
3
If necessary, select a desired disc by pressing the DISC
SKIP button.
4
Use the track number input buttons to select the desired
track number.
* The selected track number and the total play time of
the programmed tracks will light up on the display, and
soon it is replaced by the display of the next playback
order. Programmed track numbers on the selected disc
will stop flashing and light up on the music calendar.
* Pressing the TIME button displays the total play time of
the programmed tracks for about 1 second, and then it
is replaced by the display of the next playback order.
CD
TIME
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
2
B
C
TIME
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
4
1
6
* For example, to choose selection 12
(1) Press the “+10” button.
(2) Press the “2” button.
TAPE
3
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
INPUT
DSS
VOLUME
5
Repeat steps 3 and 4 for any other track. Up to 20 tracks
can be programmed.
6
Press the play/pause
programmed tracks.
+
-
Display information during programming
Playback order
PROGRAM
2
3
4
5
6
7
8
9
10
11 12
Selected disc
Selected track number
Total playing time
TOTAL
PROGRAM
1
2
3
4
5
6
7
8
9
/
button to start playback of
Notes
It is also possible to program a sequence of tracks while
looking at the list of tracks on the surface of the disc
before closing the disc table.
• During playback or pause, programming is not possible.
• If the total time of the programmed tracks reaches 100
minutes or more, only the last two-digits will be displayed
for the three-digit number.
• The total time of the programmed tracks will not be
displayed, if a track number higher than 19 is
programmed.
• Skip search can be performed during playing back, but
only within the range of the programmed tracks.
• Manual search can be performed during playing back to
search through all tracks, including unprogrammed tracks.
• If programs are made selecting tracks from more than one
disc, pressing the PLAYXCHANGE button is useless
during program play.
•
1
When in the stop mode, press the PROG button to
prepare for programming.
* “PROGRAM” and “P-01” will light up on the display,
and all track numbers on the selected disc begin
flashing.
10
11 12
Music calendar
E-15
COMPACT DISC PLAYER OPERATION
To stop program play
•
•
/
CD player
Press the stop
button. The first programmed track
number will be displayed.
To resume playback, press the play/pause
/ button.
Playback will begin from the beginning of the program.
To cancel a programmed sequence
There are several methods as described below.
• Press the stop button while the unit is stopped.
• Open the disc table.
• Switch off the power.
To check program data
PROG
1. If during playing back, press the stop
button.
2. Press the PROG button.
3. Each time the SKIP
button is pressed, the track
numbers and sequential order of the programmed tracks
can be checked one after another. The display of the
track number can be returned (sequentially in reverse
order) by pressing the SKIP
button.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
To correct program data
PLAY/PAUSE OPEN/CLOSE
1. Follow the procedure described in “To check program
data”.
2. Display the track number to be corrected by pressing the
SKIP button.
3. Press a track number input button to select a track to
replace the one displayed. The previously programmed
track will be cleared from the memory and the new one
will be programmed.
4. After the correction has been completed, press the
PROG button or play/pause
/ button once again.
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
VOLUME
-
+
E-16
English
COMPACT DISC PLAYER OPERATION
Repeat play
2
All discs, an entire disc, a single track or a programmed
sequence can be continuously repeated.
CD player
1
While watching the display, press the REPEAT button
once or more to select a desired repeat play mode (S
REPEAT or F REPEAT).
2
Press the play/pause
/
button.
Repeat play modes
1
SINGLE REPEAT (S REPEAT)
A single track is played back repeatedly.
* This is also available in the program play mode and the
random play mode. (If the repeat play mode is switched off,
the program play mode or the random play mode will be
resumed.)
FULL REPEAT (F REPEAT)
When the unit is in the single disc play mode:
A designated disc is played back repeatedly.
* In the random play mode, the selected disc is repeatedly
played back, but the order of tracks is different every time.
CD
1
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
B
C
D
E
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
2
0
A
TIME
When the unit is in the all disc play mode:
All discs on the disc table are played back repeatedly.
* In the random play mode, the random play is performed
among all discs and repeated with a different order of
tracks every time.
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
Note
In the program play mode, a sequence of programmed tracks
is played back repeatedly.
VOLUME
-
+
To cancel the repeat play
Press the REPEAT button once or more so that the (S, F)
REPEAT indicator goes out.
OFF
S
REPEAT
F
REPEAT
E-17
COMPACT DISC PLAYER OPERATION
Random play
CD player
Tracks on a selected disc or all discs on the disc table can be
played back in a random order.
3
1
2
Load discs and close the disc table.
3
Press the RANDOM button to begin random play.
* The “RANDOM” indicator will light up.
1
If necessary, switch the disc play mode by pressing the
disc play MODE selector button.
* If the single disc play mode is selected, select a desired
disc by pressing the DISC SKIP button.
To cancel the random play
Press the stop
button, or press the RANDOM button
again. The “RANDOM” indicator will go out.
CD
3
1
2
1
2
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
2
3
4
3
4
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
5
EDIT
+10
1
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
Note
This feature will not function during programming, or during
program play.
5
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
INPUT
DISPLAY
DSS
VOLUME
+
-
Switching the time display
Each time the TIME button is pressed, the display will
change as described below.
➀
TIME
1
2
3
4
5
6
7
8
9
[Example]
When the second track is being played back (Refer to the
illustration on the left.)
10
11 12
➁
➀ The elapsed play time for the track now playing back will
CD
1
2
3
4
5
1
2
3
4
5
6
6
7
REMAIN
8
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY/PAUSE OPEN/CLOSE
1
PLAY
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
INPUT
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
3
4
5
6
7
8
9
10
3
4
5
6
7
8
9
10
➁
➂
DSS
TOTAL
VOLUME
-
2
11 12
+
➂
1
2
11 12
➃
➃
TOTAL
REMAIN
1
2
3
4
5
6
7
8
9
10
be displayed.
* 8 seconds have passed since the beginning of the
second track.
The remaining play time for the current track will be
displayed.
* 2 minutes and 58 seconds remain till the end of the
second track.
The total play time of the disc will be displayed.
(If the unit is in the program play mode, the total play time
of the programmed tracks will be displayed.)
The total remaining play time from the point being played
at that time will be displayed.
* 41 minutes remain till the end of the disc.
Notes
During random play, the total remaining play time on the
disc will not be displayed.
The remaining play time will not be displayed for track
number 20 or higher.
If track number 20 or higher is programmed, during the
program play, the total play time and the total remaining
play time will not be displayed.
11 12
•
•
•
CD Player
TIME
E-18
Normally, if station signals are strong and there is no
interference, quick automatic-search tuning (Automatic
tuning) is possible. However, if signals of the station you
want to select are weak, you must tune to it manually
(Manual tuning).
1
3, 2
Automatic tuning
Receiver
4, 3
1
Select the TUNER position with the INPUT SELECTOR
control, watching the display.
2
Select the reception band [FM or AM (MW or LW)] by
pressing the BAND button while watching the display.
3
Press the AUTO/MAN’L button so that “AUTO TUNING”
appears on the display.
(In this mode, stations are received in stereo or monaural
automatically.)
4
Press the TUNING UP button to tune to a higher
frequency, or press the TUNING DOWN button to tune to
a lower frequency.
(When tuned to a station, “TUNED” will light up on the
display.)
5
If the station where tuning search stopped is not the
desired one, follow step 4 again.
*
If the tuning search does not stop at the desired station,
change to the Manual tuning method as described below.
STEREO indicator will light up when an FM stereo
broadcast with sufficient signal strength is received.
2
*
Manual tuning
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
1
1
2
Follow steps 1 and 2 of the Automatic tuning method.
3
Press and hold the TUNING UP button to tune to a higher
frequency, or press and hold the TUNING DOWN button
to tune to a lower frequency.
Release it just before reaching the desired frequency,
and then press it repeatedly until the desired frequency
appears.
(When tuned to a station, “TUNED” will light up on the
display.)
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
Press the AUTO/MAN’L button so that “AUTO TUNING”
disappears from the display.
(In this mode, stations are received in monaural.)
DSS
VOLUME
-
+
Note
If you tune to an FM station manually, it is received in
monaural automatically to increase the signal quality.
“AM” is for U.S.A., Canada, Australia, Singapore and
General models.
“MW/LW” is for U.K. and Europe models.
E-19
English
TUNING OPERATION
TUNING OPERATION
Preset tuning
This unit can store station frequencies selected by tuning
operation. With this function, you can select any desired
station by only calling the corresponding preset station
number. Up to 40 stations (8 stations x 5 areas) can be
stored.
3, 1
To store stations
Receiver
(Example: To store a station to A1)
4, 2
2, 5
1
Tune to a desired station.
(Refer to the previous page for tuning procedure.)
2
Press the MEMORY button.
* “MEMORY” and “P” will flash on the display for about 5
seconds.
3
Select a desired area (A – E) by pressing the A/B/C/D/E
button while watching the display, before the MEMORY
indicator goes out.
(In this case, select area A)
4
Select a preset station number by pressing the TUNER
PRESET DOWN or UP button repeatedly before the
MEMORY indicator goes out.
(In this case, select “1”.)
5
Within about 5 seconds, press the MEMORY button
again.
MHz
AUTO TUNING STEREO TUNED
CD
3, 1
1
2
1
2
3
4
5
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
4, 2
Shows the displayed station
has been programmed to A1.
PLAY/PAUSE OPEN/CLOSE
* In the same way, program other stations to A2, A3 ... A8.
* You can program more stations to the preset station
numbers on other areas in the same way by selecting other
areas in step 3.
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
VOLUME
-
+
To recall a preset station
1
Select the area of preset station numbers by pressing the
A/B/C/D/E button.
2
Select the desired preset station number by pressing the
TUNER PRESET DOWN or UP button repeatedly.
Notes
• A new setting can be programmed in place of the former
one.
• For presets the setting of the AUTO/MAN’L button is
stored along with the station frequency.
For easier operation
By using the preset station number buttons and the
A,B,C,D,E selector buttons on the remote control transmitter,
a preset station number and an area can be selected directly.
E-20
Automatic preset tuning
1
You can also make use of an automatic preset tuning
function. By this function, this unit performs automatic tuning
and stores stations with strong signals sequentially. Up to 40
stations are stored automatically in the same way as in the
manual preset tuning method on the previous page.
Receiver
2
1
Select the TUNER position with the INPUT SELECTOR
control, watching the display.
2
Press and hold the AUTO MEMO button for about 2
seconds.
* The MEMORY and AUTO TUNING indicators will flash.
This unit performs automatic tuning and received stations are
programmed to A1, A2 ... A8 sequentially.
When the automatic preset tuning is completed
The display shows the frequencies of the first preset station
(stored to A1).
Check the contents and the number of preset stations by
following the procedure of the section “To recall a preset
station” on the previous page.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
B
C
D
E
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
Simply follow the procedure of the section “To recall a preset
station” on the previous page.
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
To recall a preset station
0
A
TIME
PLAY
1
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
Notes
• The automatic preset tuning search will be performed
through all frequencies until 40 stations are stored. If the
number of received stations is less than 40, the search will
stop after searching all frequencies.
• <U.K. and Europe models only>
The unit is originally set so that only RDS stations are
programmed onto the area for FM stations by this
operation.
However, you can change the setting so that the unit can
program not noly RDS stations but also other FM stations.
(Refer to page 25 for details.)
• With this function, only stations with sufficient signal
strength are stored automatically. If the station you want
to program is weak in signal strength, tune to it in
monaural manually and program it by following the
procedure of the section “To store stations” on the
previous page.
• You can replace a preset station by another FM or AM
(MW or LW) station manually by simply following the
procedure of the section “To store stations” on the
previous page.
INPUT
DSS
VOLUME
-
+
Fundamental rules of internal automatic preset tuning
operation
Basically, FM stations are programmed onto area A, B and
C, and AM stations are programmed onto area D and E (MW
stations are onto D and LW stations are onto E) in that order
automatically.
* If, for example, the number of received FM stations is not
enough to fill up three areas (A, B and C), AM (MW or LW)
stations are programmed closely from the preceeding
empty areas. In such a case, AM (MW) stations are
programmed from area B or C (and LW stations are from
area C or D.)
* Moreover, one area is programmed with stations of the
same band only. If, for example, the last FM station is
programmed to B4, B5–B8 will be programmed with no
station, and AM (MW) stations are programmed from area
C.
Memory back-up
The memory back-up circuit prevents the programmed
data from being lost even if the AC supply lead is
disconnected from the AC outlet or the power is cut due to
temporary power failure. If, however, the power is cut for
more than one week, the memory may be erased. If so, it
can be re-programmed by simply following the Preset
tuning steps.
E-21
English
TUNING OPERATION
RECEIVING RDS STATIONS
<U.K. and Europe models only>
RDS (Radio Data System) is a data transmission system
gradually being introduced by FM stations in many countries.
Stations using this system transmit an inaudible stream of
data in addition to the normal radio signal.
RDS data contains various information, such as AF
(Alternative Frequencies for the same program station),
PI (Program Identification), PS (Program Service name), PTY
(Program Type), RT (Radio Text), CT (Clock Time), etc.
RDS function is carried out among the network stations.
* This unit utilizes PS, PTY, RT and CT to receive RDS
broadcast stations.
Displaying RDS data
This unit can be turned into the following four modes to
display RDS data.
PS (Program Service name) mode:
Displays the name of the RDS station
now being received instead of the
frequency.
BBC R3
PTY (Program Type) mode:
RT (Radio Text) mode:
Displays information about the program (such as title of the
song, name of the singer, etc.) on the RDS station now being
received.
CT (Clock Time) mode:
Displays current time. This signal comes from the RDS station
now being received. Time of the built-in clock can be
automatically corrected on the basis of this signal.
Displays the type of the program on the RDS station now
being received. There are 15 program types to classify RDS
stations as follows.
NEWS
News:
Short accounts of facts, events and publicly
expressed views, reportage and actuality.
AFFAIRS
Current affairs:
Topical program expanding or enlarging
upon the news, generally in different
presentation style or concept, including
documentary debate, or analysis
INFO
Information:
Program whose purpose is to impart advice
in the widest sense, including
meteorological reports and forecasts,
consumer affairs, medical help, etc.
VARIED
Varied:
Used for mainly speech-based programs
usually of light-entertainment nature, not
covered by above categories. Examples
are: quizzes, panel games, personality
interviews, comedy and satire.
POP M
Pop:
Commercial music, which would generally
be considered to be of current popular
appeal, often featuring in current or recent
record sales charts.
ROCK M
Rock:
Contemporary modern music, usually
written and performed by young musicians.
M.O.R. M
M.O.R.:
(Middle of the Road Music). Common term
to describe music considered to be “easylistening”, as opposed to Pop, Rock or
Classical. Music in this category is often but
not always, vocal, and usually of short
duration (<5 min.)
SPORT
Sport:
Program concerned with any aspect of
sport.
EDUCATE
Education:
Program intended primarily to educate, of
which the formal element is fundamental.
DRAMA
Drama:
All radio plays and serials.
LIGHT M
CULTURE
Culture:
Programs concerned with any aspect of
national or regional culture, including
religious affairs, philosophy, social science,
language, theatre, etc.
Light classics:
Classical Musical for general, rather than
specialist appreciation. Examples of music
in this category are instrumental music, and
vocal or choral works.
CLASSICS
Serious classics:
Performances of major orchestral works,
symphonies, chamber music etc., and
including Grand Opera.
OTHER M
Other music:
Musical styles not fitting into any of the
above categories. Particularly used for
specialist music, of which Jazz, Rhythm &
Blues, Folk, Country, and Reggae are
examples.
SCIENCE
Science:
Programs about the natural sciences and
technology.
E-22
<U.K. and Europe models only>
To turn the unit into the RDS
mode
➀
Press the RDS MODE selector button. If the station now
being received is an RDS station, whenever pressed, the
mode changes into the PS mode, PTY mode, RT mode, CT
mode and returns to usual mode in turn.
* If the station is not an RDS station, pressing the RDS
MODE selector button displays “NO RDS” on the display,
and then it returns to the frequency display mode.
* When an RDS station is received, the display is
automatically turned into the PS mode. Do not press the
RDS MODE selector button until the display is turned into
the PS mode. If the button is pressed before the display
mode is changed, it may occur that “NO PS” appears on
the display. This is because the unit has not received all of
the RDS data on the station yet.
➁
➂
RDS MODE
➃
Receiver
1 FREQ mode
➄
FREQ (usual) mode
The frequency of the station being received is
displayed.
PS (Program Service name) mode
The name of the station being received is displayed.
“PS WAIT” may flash while the unit is receiving the
data.
If the station does not employ the PS data service,
“NO PS” lights up on the display for about 2 seconds
and then returns to usual mode.
PTY (Program Type) mode
The type of the program on the station being received
is displayed. If the RDS station does not employ the
PTY data service, “NO PTY” lights up on the display
for about 2 seconds and then returns to usual mode.
If the station has PS data, after that, it turns into the
PS mode.
In this mode, you can make this unit search for a
station which is broadcasting a program of your
desired program type. For details, refer to the next
page.
RT (Radio Text) mode
Information about the program on the station being
received is displayed. Information is displayed by a
maximum of 64 Roman Alphabets including umlaut
sign. If other characters are used on the RT data, they
are displayed with blank spaces.
“RT WAIT” may flash while the unit is receiving the
data.
If the RDS station does not employ the RT data
service, “NO RT” lights up on the display for about 2
seconds and then returns to usual mode.
If the station has PS data, after that, it turns into the
PS mode.
CT (Clock Time) mode
Current time is displayed in the following form. The
CT data from the station being received changes
every minute.
2 PS mode
RDS MODE
FREQ/PS/PTY/RT/CT
Hour
3 PTY mode
Minute
This unit corrects time of the built-in clock by
synchronizing it with the CT data. (This function can
also be canceled, if so desired. Refer to page 25 for
details.)
“CT WAIT” may flash while the unit is receiving the
data. If the data is accidentally cut off, “CT WAIT” may
flash and then turn into “NO CT”.
If the RDS station does not employ the CT data
service, “NO CT” lights up on the display for about 2
seconds and then returns to usual mode.
If the station has PS data, after that, it turns into the
PS mode.
4 RT mode
5 CT mode
Note
RDS data service cannot be utilized by this unit if the
received signal is not strong enough. Especially, the RT
(Radio Text mode) needs much data to be received, so it
may occur that RT mode cannot be displayed even if other
RDS modes (PS, PTY, etc.) are displayed.
E-23
English
RECEIVING RDS STATIONS
RECEIVING RDS STATIONS
<U.K. and Europe models only>
• If the signal strength gets weakened by external
interference during receiving an RDS station, the RDS data
service may be cut off suddenly and turn into the frequency
display mode.
Notes
• There may be a case that RDS data reception is not
possible due to poor reception conditions. If so, press the
AUTO/MAN’L button so that “AUTO TUNING” goes off from
the display. Though the reception mode is changed to
monaural by this operation, when you change the display to
an RDS mode, RDS data may be displayed.
Calling a preset RDS station by
the program type (PTY SEEK)
2
1
By designating a program type, the unit automatically
searches all preset FM stations for an RDS station which
broadcasts a program of that program type.
* There are 15 program types to classify RDS stations. For
details, refer to page 22.
3
1
Turn the unit into the PTY SEEK mode by pressing the
PTY SEEK MODE button.
* The name of the program type of the station now being
received or “NEWS” flashes on the display.
2
Select the desired program type with the PTY
SELECTOR.
* If there is no operation for about 20 seconds, this mode
is canceled and turns into the frequency display. If the
station has PS data, after that, it turns into the PS
mode.
3
Press the PTY SEEK START button.
The unit begins searching all preset FM stations.
* “PTY H” (abbrev. of PTY HOLD) lights up on the
display.
* The preset number indicator, the name of the program
type and “AUTO TUNING” flash. The preset number
changes rapidly in sequence.
Receiver
• If a station which broadcasts a program of the program
type is found, the unit stops at the station and turns into the
frequency display. If the station has PS data, after that, it
turns into the PS mode.
• If the called station is not the desired one, press the PTY
SEEK START button once more before “PTY H” goes out
from the display.
The unit begins searching for another station which
broadcasts a program of the same program type.
• If no station is found, “NO PTY” appears and then returns
to frequency display. If the station has PS data, after that,
it turns into the PS mode.
* If the PTY SEEK START button is pressed once more
during searching, this mode is canceled and turns into
the frequency display. If the station has PS data, after
that, it turns into the PS mode.
To cancel this function
If the PTY SEEK MODE button is pressed once more, the
PTY SEEK mode is canceled and turns into the frequency
display. If the station has PS data, after that, it turns into the
PS mode.
E-24
<U.K. and Europe models only>
Other functions which make use
of RDS data service
Receiver
2
3, 6
1
4
This unit has the following functions which make use of RDS
data service. These are originally in operation [ON].
However, you can cancel these functions [OFF], if so
desired.
➀
ON (OFF) CT > CLOCK
This unit corrects the time of the built-in clock
automatically by synchronizing it with the CT data on the
RDS station being received.
* If you receive an RDS station of some other country,
the built-in clock is synchronized with the time setting
of the country.
* If the built-in clock is not yet set for current time or
reset due to a power failure etc., it will be set for the
time of the CT data automatically, whether this setting
is ON or OFF.
➁
ON (OFF) LOCAL > CT
If the RDS station being received employs the local time
(summer time etc.) data service, its time is displayed in
the CT mode.
* If the setting of function ➀ is “ON”, the built-in clock is
synchronized with the local time data.
➂
ON (OFF) A. M. > RDS
Only RDS stations are programmed onto the area for FM
stations by the automatic preset tuning operation when
the setting is ON.
(See page 21 for the operating procedure.)
If you switch this function OFF, not only RDS stations but
also other FM stations are programmed along with MW
and LW stations by the automatic preset tuning
operation.
5
1
2
PTY SEEK
MODE
3
To switch these functions on and off
1
Select the FM band by pressing the BAND button,
watching the display.
2
3
Press the DISPLAY button to display the current time.
4
Select the title of function whose setting you want to
switch by pressing the PTY SEEK MODE button once or
more.
5
Switch the function ON or OFF by pressing the PTY SEEK
START button, watching the display.
6
Press the RDS MODE selector button again to restore the
frequency display mode.
* If the station has PS data, after that, it turns into the PS
mode.
Press the RDS MODE selector button.
The title of function ➀ “ON CT > CLOCK ” is displayed.
Notes
• Once the setting is changed, it will be stored until it is
changed again by the above operation.
• During the operation, if there is no operation for about 20
seconds, this mode is canceled and turns into the
frequency display.
If the station has PS data, after that, it turns into the PS
mode.
E-25
English
RECEIVING RDS STATIONS
TAPE DECK OPERATION
General information
•
•
•
•
•
•
•
•
Detection hole
Tab
E-26
Do not use C-120 tapes or poor-quality tapes, since they
can cause malfunctions.
Before loading a tape into the cassette compartment,
tighten the tape slack with a pen or pencil.
Tapes have removable tabs which prevent accidental
recording or erasing from taking place. Removing the tab
on the top left protects the side facing you from erasure.
Cover the tab holes with adhesive tape to erase or record
again.
This deck is a Double Cassette Deck with Automatic
Reverse Function.
DECK A: Playback only.
DECK B: Playback or recording.
This deck features an auto tape selector. Just load the
tape, and the tape formula being used will be sensed
automatically.
This unit can play back metal tapes as well as normal or
chrome tapes, and recording can also be done on metal
tapes.
When covering erasure prevention tab holes, do not cover
the chrome and metal detection holes. Otherwise, the
deck will treat tape as normal tape.
Do not press the EJECT button during playback or
recording.
Tape A or tape B playback
Receiver
1
Select the TAPE position with the INPUT SELECTOR
control, watching the display.
2
Open the DECK A or DECK B cassette compartment by
pressing the EJECT button.
3
Load the tape into the DECK A or DECK B cassette
compartment, and close the lid panel completely by
pressing the upper part of the center of the panel as
figured left.
* If you have loaded two tapes into both the DECK A and
B cassette compartments, select the DECK A or B in
which the tape you want to play back is loaded by
pressing the DECK A or B selector button.
4
Set the Dolby NR switch to B or C if the tape is recorded
with Dolby noise reduction, and to OFF if Dolby NR is not
used.
* For selection of the Dolby B or C position, refer to the
“Dolby B and C Type Noise Reduction” on page 29.
5
Set the reverse MODE switch as desired.
1
DECK A selector button
DECK B selector button
Tape Deck
The reverse MODE switch can be operated before or during
playback, and changes tape playback as follows:
2
56
64
2
Side A only
3
Side A → Side
B
Side A → Side B
(Repeats 8 times)
Starts from side A.
Side A → Side B
Side B only
6
Side B only
(Repeats 8 times)
Starts from side B.
(Side A is not played
at the first time.)
Press the play
button to listen to side A, or the
play
button for side B.
To stop playback
Press the stop
button.
Note
When removing the tape, press the stop
then open the cassette compartment.
CD
6
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
EDIT
+10
TIME
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
Even if an input source other than tape deck is selected,
pressing the play button (or the fast wind button) will start
playback (or fast winding) directly.
PLAY/PAUSE OPEN/CLOSE
TAPE
DECK A/B
button
Direct operation
TUNER
STOP
DISPLAY
INPUT
DSS
VOLUME
-
button, and
6
1
+
E-27
English
TAPE DECK OPERATION
TAPE DECK OPERATION
Winding the tape
Tape Deck
1
2
If during playback, first press the stop
3
Press the stop
Next press the fast wind
wind the tape.
or fast wind
button.
button to
button to stop.
* While winding the tape, the corresponding play direction
indicator flashes rapidly.
Note
When the tape is wound to the end, this unit will then function
as described below, according to the setting of the reverse
MODE switch.
: The tape stops at the end.
: If the winding direction is
, when the tape reaches
the end, playback automatically starts from the reverse
side.
If the winding direction is
, the tape stops at the
end.
: When the tape reaches the end, playback
automatically starts from the reverse side.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
Searching for the beginning of a
desired selection
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
Carry out the following operation during playback to find the
beginning of a desired selection on the tape.
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
To listen to the same selection
Press the
button if the direction of the current playback
is
.
Press the
button if the direction of the current playback
is
.
VOLUME
-
+
To listen to the next selection
Press the
button if the direction of the current playback
is
.
Press the
button if the direction of the current playback
is
.
* While searching, the corresponding play direction indicator
flashes slowly.
Notes
• This function may not work for tapes with
* Material with long pauses or quiet passages.
* Low recording levels or excessive noise.
* Pauses of less than 4 seconds between selections.
• If searching is carried out at the first or the last part of a
selection, the desired selection may not be found.
E-28
Continuous playback
3
Tape Deck
English
TAPE DECK OPERATION
1
Load the tapes into the DECK A and DECK B cassette
compartments.
2
Set the reverse MODE switch to
.
The reverse MODE switch can be operated before or during
playback, and changes tape playback as follows:
1
24
4
1
<Tape A>
Tape A Side A → B → Tape B Side A → B
(Repeats 8 times)
Starts from Tape A Side A.
<Tape A>
(Repeats 8 times)
Starts from Tape A Side B. (Tape A Side A
is not played at the first time.)
CD
4
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY/PAUSE OPEN/CLOSE
4
TUNER
STOP
PLAY
TAPE
3
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
Tape A Side A → B → Tape B Side A → B
3
Press the DECK A or B selector button to select the tape
to be played back first.
4
Press the play
button to listen to side A, or the
play
button for side B.
INPUT
DSS
VOLUME
-
+
Dolby B and C Type Noise Reduction
Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation.
“DOLBY” and the double-D symbol
are trademarks of
Dolby Laboratories Licensing Corporation.
With cassette tapes, the most noticeable form of noise is high
frequency hiss. To reduce this hiss noise, this unit has been
equipped with a newly developed Dolby C noise reduction
system in addition to its conventional Dolby B NR. Either type
of noise reduction may be selected with the switch provided.
Dolby B NR has a noise reduction effect of about 10 dB in
the high frequency range. The corresponding figure with
Dolby C NR is about 20 dB, but this is over the entire range
where the human ear is most sensitive to noise (2 kHz to 8
kHz). Also, Dolby C NR has the same noise reduction effect
at both high and low signal levels. In addition, Dolby C NR
improves the tape’s MOL (Maximum Output Level).
Dolby noise reduction is a 2 part process that acts both on
recording and playback; be sure that the noise reduction
button is set to the same position on record and play.
* Noise in the source material cannot be reduced with the
Dolby NR system.
E-29
RECORDING COMPACT DISCS
•
Receiver
•
•
1
•
6
6
When recording important selections, be sure to make a
preliminary test to ensure that the desired source material
is being properly recorded with good sound quality.
The automatic recording level control circuit automatically
controls the level of the input signal used for recording.
Adjusting the VOLUME, BALANCE, TREBLE and BASS
controls have no effect on the recorded sound.
<Except U.K. and Europe models>
If, however, the DSS is on, DSS effect is recorded along
with the source.
* Music with DSS effect is suitable for listening to inside a
car etc.
The deck which can be used for recording is the DECK B
only. When recording, be sure to load a tape into the
DECK B cassette compartment.
CD Player
CD synchronized recording
1
Select the CD position with the INPUT SELECTOR
control, watching the display, and load the disc to be
recorded.
2
Load a tape into the DECK B cassette compartment.
* Wind past the beginning part of the tape on which
recording cannot be performed.
3
When recording with the Dolby NR system, set the Dolby
NR switch to B or C; if not, set it to OFF.
* For selection of the Dolby B or C position, refer to the
“Dolby B and C Type Noise Reduction” on page 29.
4
Set the reverse MODE switch as desired.
Tape Deck
2
4
5 3
When the tape is set so that side A faces you, recording will
be done as follows automatically according to the selected
reverse mode.
2
Side A only
Side A → Side Side A → Side
B
B
Side B only
Side B only
CD
5
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
6
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
Side B only
DISPLAY
INPUT
DSS
1
5
Press the REC/PAUSE button.
* The corresponding indicator lights up and the play
direction indicators flash.
6
Start CD playback by pressing the corresponding disc
selector button, or by pressing the play/pause /
button if the disc is already selected.
* Before CD playback begins, recording automatically
begins on the side of the tape now selected.
VOLUME
-
+
E-30
To stop recording temporarily
1
2
/
CD Player
Press the stop
button of the CD player.
Choose the selection to be recorded next by using the
SKIP
or
button, and then press the play/pause
/ button of the CD player to resume recording (or
simply press the track number input button on the remote
control transmitter).
To stop recording
Press the stop
button of the tape deck.
(At this time, CD playback will not stop.)
Recording programmed tracks
Tape Deck
Programmed tracks from one or more discs can also be
recorded in the same way.
1
Program desired tracks from one or more discs. (Refer to
page 15. for the programming procedure.)
2
3
Follow steps 2–5 on the previous page.
Press the play/pause
/
button of the CD player.
Notes
• During CD Synchronized Recording, when more than 4
seconds elapse between tracks, the tape will stop
automatically and resume recording when the beginning
of the next track is found.
• The CD Synchronized Recording will function even when
the CD player is turned into random play mode.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
EDIT
+10
TIME
PROG
TAPE
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
/
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
VOLUME
-
+
E-31
English
RECORDING COMPACT DISCS
RECORDING COMPACT DISCS
Recording CD(s) on both sides of
a tape automatically
Receiver
1
1
Select the CD position with the INPUT SELECTOR
control, watching the display, and load the disc to be
recorded.
2
3
4
Select the disc by pressing the DISC SKIP button.
5
6
Set the reverse MODE switch to
CD Player
6
4
3
4
5
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
EDIT
+10
PROG
TAPE
RANDOM
STOP
MODE
DISC SKIP
PLAY
3
Notes
• When this CD player is in the all disc play mode, if the
tape’s total possible recording time is longer than the total
playing time of the selected disc, tracks on another disc
are recorded continuously.
In this case, as many as three discs can be recorded
automatically.
• During recording, the PLAYXCHANGE button on the CD
player is disabled.
• The CD player’s repeat play mode will be canceled during
this recording mode.
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
6
Programmed tracks from one or more discs can also be
recorded in the same way.
1
1
Program desired tracks from one or more discs. (Refer to
page 15 for the programming procedure.)
1
2
Follow steps 3–6 described above.
PLAY
TAPE
2
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
.
Recording programmed tracks
2
1
TIME
or
1
CD
1
REPEAT
When recording with the Dolby NR system, set the Dolby
NR switch to B or C; if not, set it to OFF.
* For selection of the Dolby B or C position, refer to the
“Dolby B and C Type Noise Reduction” on page 29.
Press the EDIT button. (“EDIT” appears on the display.)
CD playback and recording starts. Recording is carried
out on side A and B of the tape continuously.
* If the tape has not rewound to the end, it is rewound to
the end rapidly before recording starts.
Recording starts from the first part of the tape on which
recording can be done.
* “A
” (or “
B”) on the display shows the side of
the tape on which recording is being carried out.
* When the recording on side A finishes while a track is
being played back, the sound is automatically faded
out, and then the recording stops.
The recording on side B starts from the beginning of
the same track.
Tape Deck
5
Load a tape into the DECK B cassette compartment.
DSS
VOLUME
-
+
To stop recording
Press the stop
E-32
button of the tape deck or the CD player.
English
RECORDING COMPACT DISCS
Automatic tape-editing
Receiver
This convenient feature can be used to program tracks on a
disc (or discs) for recording to tape. By only memorizing the
tape’s total possible recording time, the unit will automatically
program tracks or help you to program tracks so they will fit
onto the tape with the least amount of unrecorded space
remaining at each end of the tape.
To record a disc with the order of tracks
unchanged
1
1
Select the CD position with the INPUT SELECTOR
control, watching the display, and load the disc to be
recorded.
2
3
4
Select the disc by pressing the DISC SKIP button.
5
6
Set the reverse MODE switch to
CD Player
7
1
Tape Deck
Load a tape into the DECK B cassette compartment.
When recording with the Dolby NR system, set the Dolby
NR switch to B or C; if not, set it to OFF.
* For selection of the Dolby B or C position, refer to the
“Dolby B and C Type Noise Reduction” on page 29.
→
4
6
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
7
2
9
0
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
7
6
1
TAPE
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
INPUT
DSS
1
VOLUME
-
C-60
→ C-90
Press the EDIT button. (“EDIT” appears on the display.)
The following internal operations are carried out before
recording is automatically started.
* If the tape has not rewound to the end, it is rewound to
the end rapidly before recording starts.
1)Tracks on the disc are automatically divided between
side A and side B. You can check the process by
watching the display.
2)The end part of the tape on which recording cannot be
done is wound.
3)CD playback and recording starts. Recording is carried
out on both side A and B of the tape.
PLAY
DECK
A/B
→ C-46 → C-54 →
When using tapes other than C-46, C-54, C-60 or C-90
When C-46, C-54, C-60 or C-90 is appearing on the
display, input the tape length by using the track number
input buttons on the remote control transmitter.
(Examples)
C-62: Press “6” and then “2”.
C-30: Press “3” and then “0”, or press “+10” three times
and then “0”.
3
CD
1
.
Press the TAPE button on the remote control transmitter
to select the length of the tape to be used. Whenever
pressed, C-46, C-54, C-60 and C-90 appear on the
display in turn, and next it returns to the normal display
mode.
off
5
or
+
E-33
RECORDING COMPACT DISCS
Notes
• When this CD player is in the all disc play mode, if the
tape’s total possible recording time is longer than the total
playing time of the selected disc, tracks on another disc
are recorded continuously.
In this case, as many as three discs can be recorded
automatically.
• The CD player’s repeat play mode will be canceled during
this recording mode.
CD player
To cancel tape-editing function
Before recording, press the stop
4
button of the CD player.
To stop recording
Press the stop
Tape Deck
button of the tape deck or the CD player.
To make this unit program tracks on a disc
automatically so that the least amount of
unrecorded space remains on the tape
1
2
3
Follow steps 1–6 on the previous page.
Press the PROG button.
Press the TAPE button.
“AP A> ” will light up during programming for side A,
and “AP B> ” will light up during programming for side
B.
* After “AP B> ” goes out from the display, you can
check the programmed contents for side A and B
respectively.
To check, cancel or correct program data, refer to page
16.
4
2
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
B
C
TIME
PROG
TAPE
REPEAT
A
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
3
4
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
INPUT
DSS
VOLUME
-
+
E-34
Press the EDIT button. (“EDIT” appears on the display.)
The recording automatically starts.
To record programmed tracks from one or
more discs
Receiver
1
Select the CD position with the INPUT SELECTOR
control, watching the display, and load a disc (or discs) on
the disc table.
2
3
Follow steps 3–6 on page 33.
4
If necessary, select a desired disc by pressing the DISC
SKIP button.
5
Select the desired track number by pressing the track
number input buttons.
6
Repeat steps 4 and 5 to program more selections for the
side A of the tape. You can select the same track again.
* Pressing the TIME button displays the total remaining
time on the side of the tape for about 1 second, and
then it is replaced by the display of the next playback
order.
* If “ERR” appears on the display, the track number just
selected cannot be programmed because there is not
enough time remaining on the side A of the tape.
However, at this time, if any other track number is
flashing continuously on the display, you can program
it instead of the unprogrammable one.
7
After you finish the programming for the side A, press the
TAPE button.
* “Pu” appears on the display, then you can begin
programming for side B.
8
Repeat steps 4 and 5 to program selections for the side B
of the tape. You can select the same track again.
* If “ERR” appears on the display, the track number just
selected cannot be programmed because there is not
enough time remaining on the side B of the tape.
However, at this time, if any other track number is
flashing continuously on the display, you can program
it instead of the unprogrammable one.
9
Press the EDIT button. (“EDIT” appears on the display.)
The recording automatically starts.
1
CD Player
TIME
9
1
CD
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
TIME
3
7
4
1
PLAY
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
5
1
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
INPUT
DSS
9
1
Display information during programming
Selected
disc
Press the PROG button.
* “PROGRAM” and “P-01” light up on the display, and all
track numbers on the selected disc begin flashing.
Side of
the tape
Next playback order
Notes on tape-editing
If programs are made selecting tracks from more than one
disc, during recording, the PLAYXCHANGE button on the
CD player is disabled.
• To check, cancel or correct program data, refer to page
16.
• The maximum number of tracks that can be programmed
is 20.
• This function can be used to program up to track number
20. If the disc has more than 20 tracks, track number 20
and thereafter will not be programmed.
•
PROGRAM
1
A
2
3
4
5
6
7
8
9
10
11 12
Total remaining time on
the side of the tape
Selected track
number
REMAIN
PROGRAM
1
A
2
3
4
5
6
7
8
9
10
11 12
Programmed track numbers light up
and unprogrammed ones flash.
E-35
English
RECORDING COMPACT DISCS
OTHER RECORDINGS
•
Receiver
•
•
•
1
Recording from the built-in tuner
Tape Deck
3
7, 2
5
4
6, 1
3
7, 2
1
Select the TUNER position with the INPUT SELECTOR
control, watching the display.
2
Tune to the desired station. (Refer to the “TUNING
OPERATION” on pages 19 and 20.)
3
4
Load a tape into the DECK B cassette compartment.
5
Set the reverse MODE switch to
one side, or to
(or
) for
continuous recording on both sides.
6
Press the REC/PAUSE button.
* The corresponding indicator lights up and the play
direction indicators flash.
7
Press the play
button to record on side A, or the play
button to record on side B.
* For continuous recording on both sides, begin on side
A. Recording stops automatically at the end of side B.
CD
7, 2
When recording important selections, be sure to make a
preliminary test to ensure that the desired source material
is being properly recorded with good sound quality.
The automatic recording level control circuit automatically
controls the level of the input signal used for recording.
Adjusting the VOLUME, BALANCE, TREBLE and BASS
controls have no effect on the recorded sound.
<Except U.K. and Europe models>
If, however, the DSS is on, DSS effect is recorded along
with the source.
* Music with DSS effect is suitable for listening to inside a
car etc.
The deck which can be used for recording is the DECK B
only. When recording, be sure to load a tape into the
DECK B cassette compartment.
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
B
C
D
E
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
1
2
1
7, 2
Press the REC/PAUSE button.
To resume recording, press the play button whose
indicator is flashing.
DSS
To stop recording
VOLUME
-
to record on only
To stop recording temporarily
0
A
TIME
When recording with the Dolby NR system, set the Dolby
NR switch to B or C; if not, set it to OFF.
* For selection of the Dolby B or C position, refer to the
“Dolby B and C Type Noise Reduction” on page 29.
+
Press the stop
6, 1
E-36
button.
English
OTHER RECORDINGS
Dubbing
Receiver
•
•
1, 2
1
Select the TAPE position with the INPUT SELECTOR
control, watching the display.
2
Load a prerecorded tape into the DECK A cassette
compartment. Insert a blank tape into the DECK B
cassette compartment.
3
Set the reverse MODE switch to
to record on only
one side, or to
(or
)
for continuous recording on both sides.
4
Press the DUBBING button.
* Press “NORMAL” to dub at normal speed, and “HIGH”
to dub at about twice the normal speed.
* Dubbing will begin from side A regardless of the side
now selected.
Tape Deck
2
4
4
2, 1
3, 3
4
4
During dubbing, adjusting the VOLUME, BALANCE,
TREBLE and BASS controls have no effect on the
recorded sound.
<Except U.K. and Europe models>
If, however, the DSS is on, DSS effect is recorded along
with the source.
* Music with DSS effect is suitable for listening to inside a
car etc.
Try to use the same tape formula and length for the
recording tape as for the master tape.
To stop dubbing
Press the stop
button.
* Tape A and tape B will stop at the same time.
Note
Only tapes originally encoded with Dolby B or C NR will be
dubbed onto tapes with Dolby B or C NR encoding.
The setting of Dolby NR will have no effect on the recording
of tape B during dubbing.
However, the playback tonal quality of tape A will change
according to the Dolby NR switch position.
CD
4
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
PLAY/PAUSE OPEN/CLOSE
4
TUNER
STOP
Erasing recorded tapes
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
1, 2
1
Load the tape to be erased into the DECK B cassette
compartment.
2
Select the TAPE position with the INPUT SELECTOR
control, watching the display.
3
Set the reverse MODE switch to
side and to
(or
) to
erase both sides.
4
Press the REC/PAUSE button, then press the play
button to erase side A of the tape, or the play
button to
erase side B.
VOLUME
-
+
4
E-37
to erase only one
HOW TO USE THE BUILT-IN TIMER
Timer play
2
By using the built-in timer, you can set the time when the unit
turns on and a source begins playing automatically, and the
time when the unit turns off automatically.
Receiver
1
Prepare the source to be played.
For tuner:
Tune in to the station you will listen to.
2
For tape deck:
Load a tape into the cassette compartment.
(If tapes are loaded in both the compartments, tape A
takes priority of tape B, and is played back by the timer
play.)
1
For CD player:
Load a disc on the disc table. If more than one disc are
loaded on the disc table, select the disc by using the disc
selector buttons or the DISC SKIP button.
2
Press the DISPLAY button.
Whenever the DISPLAY button is pressed, the display
mode changes as follows.
At each mode, make a setting for the timer play, referring
to the setting procedure described below.
1
2
2
3
4
5
3
4
5
9
0
6
7
8
6
7
8
B
C
TIME
PROG
TAPE
REPEAT
A
RANDOM
STOP
MODE
DISC SKIP
PLAY
D
E
EDIT
+10
➁
Source selecting mode (TAPE, TUNER, CD)
➂
ON TIME/Time setting mode
➃
OFF TIME/Time setting mode
➄
Normal display mode
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
INPUT
DSS
2
* The display mode will be changed to the next mode
after about 8 seconds elapse automatically. If the mode
is changed before the setting is completed, call the
mode again by pressing the DISPLAY button once or
more.
VOLUME
-
Current time (TIMER on/off mode)
→ → → →
→ ➀
CD
1
+
Setting procedure:
2
E-38
➀
At the display of current time
Check to be sure that the current time is correct, and
press the TIMER button so that “TIMER” lights up on
the display.
➁
At source selecting mode
Select the source (TAPE, TUNER or CD) to be played
with the INPUT SELECTOR control.
* If “TUNER” is selected, soon it is changed to the
frequency display mode. In this mode, you can
select the station to listen to with the timer play by
using the BAND button, A/B/C/D/E button and
TUNER PRESET DOWN/UP buttons.
POWER
TIME ADJ
➂
At ON TIME/time setting mode
[“ON TIME” appears on the display, and soon it is
changed to a time setting mode.]
Set to the time when you want to begin the timer play
by using the HOUR button and the MINUTE button.
➃
At OFF TIME/time setting mode
[“OFF TIME” appears on the display, and soon it is
changed to a time setting mode.]
If necessary, set to the time when you want to finish
the timer play (to turn this unit off) by using the HOUR
button and the MINUTE button. Even if you do not set
the time, it has already been set so that the timer play
finishes after 1 hour.
*
The TIMER button functions also in the time (ON
TIME or OFF TIME) setting mode. (However, it also
turns off the power.)
Receiver
TIMER HOUR
MINUTE
3
DISPLAY
If you will not use this unit until the timer play begins, turn
the power off by pressing the POWER switch or the
TIMER button.
Note
If a timer play setting is made and the power is not turned off,
the source set for the timer play will begin playing when the
time comes in place of the source played at that time.
To cancel the timer play setting
After the timer play is finished, press the DISPLAY button to
call the current time. While the current time is displayed,
press the TIMER button so that “TIMER” goes out from the
display.
If it is not canceled, the system will be turned on at the same
time every day, so it can be used as an alarm. However, if
you are planning to go out at that time, cancel the timer play
setting.
* Unless the AC supply lead is unplugged or there is a
power failure for more than 5 minutes, the time set on the
timer will be retained until it is reset.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
9
0
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
PLAY
TAPE
DECK
A/B
REC/PAUSE
EFFECT LEVEL
POWER
-
+
POWER
SLEEP
INPUT
SP/PHONES MODE
DISPLAY
DSS
VOLUME
-
+
How to make time setting in the ON TIME or OFF
TIME mode
For the hour:
Press the HOUR button to change the hour to a higher value.
Press and hold to change continuously.
To change the hour to a lower value, while pressing the TIME
ADJ button, press the HOUR button.
DISPLAY
For the minute:
Use the MINUTE button and operate it in the same way as
you did to change the hour.
E-39
English
HOW TO USE THE BUILT-IN TIMER
HOW TO USE THE BUILT-IN TIMER
Timer recording
(To record a tuner program)
INPUT SELECTOR
POWER
Receiver
DISPLAY
TIMER
1
Load a blank tape into the DECK B cassette
compartment.
2
If desired, change the setting of the reverse mode and
the Dolby NR position.
3
4
Tune to the station of which program you want to record.
TIMER REC
* In step ➁, select the TUNER position with the INPUT
SELECTOR control, and then press the TIMER REC
button. (“REC” will flash on the display.)
* In step ➂, set the time when you want to begin the
timer recording.
* In step ➃, set the time when you want to finish the
timer recording.
Tape Deck
5
2
Follow step 2 of the “Timer play” on page 38 and 39.
1
Press the TIMER button.
(The power will be turned off automatically.)
* If a normal display mode (the state which had been
selected before you began setting the timer recording)
is restored before you press the TIMER button, select
and follow either of the two methods below.
• Press the DISPLAY button, and then press the
TIMER button. (The power is still on.)
• Press the POWER switch to turn the power off, and
then press the TIMER button. (The power is turned
off.)
To confirm the timer time setting
Press the DISPLAY button.
To cancel the setting of timer recording
Press the DISPLAY button once or more so that “REC”
flashes on the display. While “REC” is flashing, press the
TIMER REC button.
* Unless the AC supply lead is unplugged or there is a
power failure for more than 5 minutes, the time set on the
timer will be retained until it is reset.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
TUNER
STOP
PLAY
TAPE
POWER
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
Note
When the timer recording is finished, the timer setting is
automatically canceled to avoid repeating timer recording of
the same setting.
PLAY/PAUSE OPEN/CLOSE
INPUT
DSS
VOLUME
-
TUNER
input
selector
button
+
DISPLAY
E-40
English
HOW TO USE THE BUILT-IN TIMER
Sleep timer operation
This unit can be turned off automatically.
POWER
Receiver
Play the desired sound source.
3
Press the SLEEP button repeatedly until the desired sleep
time appears on the display. The display will change as
described below. [Time is displayed by the hour (h) and
the minute (m).]
Press the SLEEP button. “SLEEP” appears on the display,
and soon it is replaced by “2h00m”.
1h00m
↑
AUTO MEMO
1h30m
↑
2h00m
↑
↑
DISPLAY
1
2
0h30m
↑
OFF SLEEP
(Sleep timer is off.)
* The original display mode will resume about 4 seconds
after the selection is made.
* The SLEEP indicator will light up to indicate that the
sleep timer is on.
4
The unit will turn off automatically when the selected sleep
time passes.
CD
1
2
3
4
5
1
2
3
4
5
6
7
8
6
7
8
9
0
A
B
C
D
E
TIME
PROG
TAPE
EDIT
+10
REPEAT
RANDOM
STOP
MODE
DISC SKIP
PLAY
To confirm the sleep time setting
Press the SLEEP button once. “SLEEP” appears on the
display, and soon it is replaced by the remaining time of the
selected sleep time.
PLAY/PAUSE OPEN/CLOSE
TUNER
STOP
To change the sleep time
PLAY
TAPE
POWER
DECK
A/B
REC/PAUSE
EFFECT LEVEL
SP/PHONES MODE
-
+
POWER
SLEEP
DISPLAY
While the SLEEP indicator is being illuminated, press the
SLEEP button repeatedly until the desired time appears.
INPUT
DSS
VOLUME
-
+
To stop the sleep timer operation
Press the POWER switch, or press the SLEEP button
repeatedly until “OFF SLEEP” appears on the display.
(The SLEEP indicator will go out.)
SLEEP
To set the sleep time using front panel buttons
First press the DISPLAY button to display the current time.
Within 7 seconds, press the AUTO MEMO button. Whenever
the AUTO MEMO button is pressed, the sleep time changes.
DISPLAY
Using the timer and the sleep
timer at the same time
1
Prepare timer play. (See page 38 and 39.)
* Do not turn the power of this unit off after the timer
setting is finished.
2
Press the SLEEP button and set the sleep time.
When the sleep timer operation finishes, the timer will
function to turn the source on at the preset time.
Note
Do not make the timer time setting so that the timer will start
during sleep timer operation. (Since sleep timer operation
has priority, the timer will not operate.)
E-41
USING EXTERNAL UNITS
<U.S.A., Canada, Australia,
Singapore and General models>
Other audio units (AUX1 and AUX2)
LD player etc.
Video cassette
player etc.
To connect
Connect the output terminals of a video cassette player, LD
player, etc. to the AUX1 terminals of this system.
(red → right channel, white → left channel)
INPUT
R
L
AUX 2
To listen to
1 Select the AUX1 position with the INPUT SELECTOR
control, watching the display.
AUX 1
2
Operate the unit connected to the AUX1 terminals.
* Its audio source can be recorded by this system’s tape
deck.
In the same way, connect another unit to the AUX2 terminals.
<U.K. and Europe models>
Another audio unit (AUX)
Video cassette player etc.
To connect
Connect the output terminals of a video cassette player, LD
player, etc. to the AUX terminals of this system.
(red → right channel, white → left channel)
INPUT
R
L
To listen to
1 Select the AUX position with the INPUT SELECTOR
control, watching the display.
PHONO
AUX
GND
2
Operate the unit connected to the AUX terminals.
* Its audio source can be recorded by this system’s tape
deck.
Turntable
Turntable (PHONO)
To connect
1
Connect the output terminals of the turntable to the
PHONO terminals of this system.
(red → right channel, white → left channel)
2
Connect the GND lead of the turntable to the GND
terminal of this system.
To listen to
1
Select the PHONO position with the INPUT SELECTOR
control, watching the display.
2
Operate the turntable.
* Its audio source can be recorded by this system’s tape
deck.
E-42
Internal care
DECK A
•
•
DECK B
Dirty heads, capstans and pinch rollers can cause poor
sound and tape jams.
Clean these parts with a cotton swab moistened with
commercially available head/pinch roller cleaner or
isopropyl alcohol, or with a commercially available
cleaning tape.
After long use, the deck’s heads and capstans may
become magnetized, causing poor sound. Demagnetize
these parts once every 30 hours of playing/recording time
by using a commercially available tape head
demagnetizer. Read the demagnetizer’s instructions
carefully before use.
External care
•
•
E-43
Periodically clean the surfaces of this system, especially
the top panel of the receiver to prevent the ventilation
holes from being blocked with dust etc.
Do not use chemically treated cleaning cloths or other
chemicals. (See “Precautions”.)
English
MAINTENANCE
TROUBLESHOOTING
If your unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple
measures suggested. If it cannot, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your
authorized YAMAHA dealer or service center for help.
Should be service required, the servicer will need all three pieces [RX-S75, CDC-S75, KXW-S75].
CAUSE
SYMPTOM
AC supply lead is not plugged in.
Plug in the AC supply lead.
No sound from one speaker
Loose speaker connections.
Connect properly.
No sound from speakers.
Internal protection circuit is functioning.
Unplug the AC supply lead from the wall AC outlet, and then
plug in again.
Excessive static in FM broadcasts.
Interference from starting motor of nearby car.
Position the FM antenna as high and as far away from
nearby roads as possible. Connect using a coaxial cable.
Interference from thermostat of nearby electrical
appliance.
RECEIVER
REMEDY
No power even if the POWER switch is
pressed.
Noise increases during stereo broadcasts.
Antenna input is too weak due to obstructions or
excessive distance from broadcasting station.
Check antenna connections.
Stereo broadcasts are noisy and STEREO
indicator blinks on and off.
Insufficient antenna input.
Install an antenna appropriate for the electric field strength of
your area.
Cannot select preset stations.
Preset memory has been erased.
Reprogram memory presets.
Buzzing or static during AM (LW or MW)
broadcasts.
Interference from source such as lightning,
flourescent lights, electric motors or thermostat
of nearby electrical appliance.
Problem is difficult to eliminate but can be lessened by
grounding MW/LW (AM) loop antenna.
TV or microprocessor is being used nearby.
Move away from TV or microprocessor.
Radio signal is weak or antenna is not properly
connected.
Properly connect MW/LW (AM) loop antenna.
AM (LW or MW) broadcast sensitivity is poor.
Install a multi-element type FM antenna if possible.
Change orientation of MW/LW (AM) loop antenna.
CD PLAYER
Install an external MW/LW (AM) antenna.
Can’t set timer.
Current time is not set.
Set current time.
This unit will not operate properly.
The internal microcomputer has been frozen by
an external electric shock (lightning, excessive
static electricity, etc.) or power supply with low
voltage.
Unplug the AC supply lead from the wall AC outlet, and then
plug in again after about one minute.
Play will not begin even if disc is loaded.
Disc is upside down.
Load disc label side up.
Disc is dirty.
Clean disc.
No sound.
Input selector setting is incorrect.
Select the CD input position.
Sound stops suddenly (always at same spot).
Disc is dirty.
Clean disc.
Volume is set too high.
Lower volume.
Tape won’t move during playback or
recording.
Slack tape wrapped around pinch roller.
Take up slack with a pencil before using.
Can’t record.
Erasure prevention tab is broken off.
Replace tape or cover erasure prevention hole with
cellophane tape.
Head is dirty.
Clean heads.
Head is dirty.
Clean heads.
Head has become magnetized.
Demagnetize heads with head eraser.
Tape is worn.
Replace tape.
Poor sound quality.
Dolby NR switch is set to wrong position.
Set to positions matching those used when tape was
recorded.
Stereo balance is poor.
Head is dirty.
Clean heads.
Excessive noise.
Head is dirty.
Clean heads.
Head has become magnetized.
Demagnetize heads with head eraser.
Tape is worn.
Replace tape.
Slack tape coming out of cassette shell.
Take up slack by turning reels with a pencil.
Tape is creased or torn.
Replace with new tape.
Endless tape is being used.
Don’t use endless tapes.
Silent gaps between selections are too short.
The function for searching for the beginning of desired
selections won’t operate unless the silent gaps between
selections are at least four seconds long.
TAPE DECK
Sound is distorted or fades out.
Tape travel stops in middle of playback or
recording.
Can’t find the beginning of desired selections
on tape.
Excessively soft passages in middle of
selections.
REMOTE CONTROL
Conversation etc. is recorded.
Remote control doesn’t work.
TV functions strangely when the remote
control is used.
Batteries are dead.
Replace batteries.
Remote control is too far away or is being used
at incorrect angle.
Use within 6 m and 60° radius.
Direct sunlight or lighting (of an inverter type of
flourescent lamp etc.) is striking the remote
control sensor of the main unit.
Change position of the main unit.
Remote control is being used near TV set with a
remote control sensor.
Move TV farther away or cover its remote control sensor.
E-44
As a part of policy of continuous improvement, YAMAHA reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units.
■ Receiver (RX-S75)
■ CD player (CDC-S75)
Minimum RMS Output Power per Channel
6 ohms, 1 kHz, 0.08% THD ........................................... 55W+55W
6 ohms, 1 kHz, 10% THD
[U.S.A., Canada, Singapore and General models only]
...................................................................................... 75W+75W
DIN Standard Output Power per Channel [Europe model only]
6 ohms, 1 kHz, 1% THD .......................................................... 60W
IEC Power [Europe model only]
6 ohms, 1 kHz, 0.1% THD ....................................................... 55W
Input Sensitivity/Impedance
PHONO MM [U.K. and Europe models only]
............................................................................ 2.5 mV/47 k-ohms
AUX ................................................................... 390 mV/20 k-ohms
Headphone Output Impedance.......................................... 68 ohms
Total Harmonic Distortion (1 kHz)
AUX to SP OUT (27.5W/6 ohms) ......................................... 0.08%
Signal to Noise Ratio (IHF-A Network)
AUX .........................................................................................90 dB
Tone Control Characteristics
BASS: Boost/cut ................................................... ±10 dB (50 Hz)
TREBLE: Boost/cut ............................................. ±10 dB (20 kHz)
Tuning Range
FM
[U.S.A. and Canada models]...................... 87.5 to 107.9 MHz
[Australia, U.K., Europe, Singapore and General models]
...................................................................... 87.5 to 108.0 MHz
AM (MW)
[U.S.A., Canada and General models] ...... 530 to 1,710 kHz
[Australia, U.K., Europe and Singapore models]
...................................................................... 531 to 1,611 kHz
LW
[U.K. and Europe models only] .................... 153 to 288 kHz
Usable Sensitivity
FM (75 ohms)
(30 dB S/N Quieting, 1 kHz, 100% mod.)
[U.S.A., Canada, Singapore and General models]
.......................................................................1.2 µV (12.8 dBf)
(DIN, Mono, S/N 26 dB)
[U.K., Europe and Australia models] ..........................1.5 µV
AM (MW)........................................................................ 280 µV/m
LW ................................................................................. 560 µV/m
Power Supply
[U.S.A. and Canada models] ............................ AC 120V, 60 Hz
[Australia model] .............................................. AC 240V, 50 Hz
[U.K., Europe and Singapore models] ............ AC 230V, 50 Hz
[General model] ...................... AC 110/120/220/240V, 60/50 Hz
Power consumption
[U.S.A. and Canada models] ............................................ 155W
[Australia, U.K., Europe and General models] ............... 150W
Dimensions (W x H x D)................................ 280 x 107.5 x 345 mm
(11” x 4-1/4” x 13-9/16”)
Weight .............................................................. 6.0 kg (13 lbs. 3 oz.)
Power Source ................................... AC supplies from receiver unit
Type ................................................. 3 DISC Carousel Auto-changer
Signal Readout
........................... Non-contact, 3-beam semi-conductor laser pick-up
D/A Converter ................................................................... 1-bit DAC
Filter ......................................8-time oversampling 18-bit digital filter
Wow and Flutter .........................................Below measurable limits
Dimensions (W x H x D)................................ 280 x 107.5 x 323 mm
(11” x 4-1/4” x 12-11/16”)
Weight ................................................................ 3.8 kg (8 lbs. 6 oz.)
■ Tape Deck (KXW-S75)
Power Source ................................... AC supplies from receiver unit
Type ............... Auto Reverse 4-Track 2-Channel playback/recording
and playback stereo double Cassette Deck
Heads ................................................ PB, REC/PB : Hard Permalloy
Erase : Double Gap Ferrite
Motors ................................................................ DC servo motor x 2
Wow and Flutter ................................................. 50.19%, W.PEAK
0.09%, W.RMS
Fast Winding Time (C-60 Tape) ........................ About 120 seconds
Frequency Response (–20 dB)
........................................................ 30 – 15,000 Hz 53 dB (Normal)
30 – 16,000 Hz 53 dB (CrO2)
30 – 18,000 Hz 53 dB (Metal)
Signal-to-Noise Ratio .................................. 58 dB (Dolby NR OFF)
66 dB (Dolby B NR ON)
74 dB (Dolby C NR ON)
Harmonic Distortion .......................................... No more than 1.2%
Channel Separation (Input Shorted 1 kHz)
................................................................................. More than 40 dB
Crosstalk (Input Shorted 125 Hz).......................... More than 55 dB
Dimensions (W x H x D)................................ 280 x 117.5 x 326 mm
(11” x 4-5/8” x 12-13/16”)
Weight ................................................................ 4.2 kg (9 lbs. 4 oz.)
■ Speaker (NX-S75)
Type .................................................... Active Servo Processing type
Speakers ........................................................ 14 cm (5-1/2”) woofer
5 cm (2”) tweeter
1.1 cm super tweeter
Frequency Range .................................................... 40 – 20,000 Hz
Sound Pressure Level............................................................. 89 dB
Maximum Power Handling Capacity........................................ 75W
Impedance ............................................................................ 6 ohms
Dimensions (W x H x D)................................... 200 x 330 x 239 mm
(7-7/8” x 13 x 9-7/16”)
Weight ........................................................ 4.5 kg (9 lbs. 14 oz.) x 2
E-45
English
SPECIFICATIONS
YAMAHA
YAMAHA
YAMAHA
YAMAHA
YAMAHA
YAMAHA
YAMAHA
ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.
CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA
ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, F.R. OF GERMANY
ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE
ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND
SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN
MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA
VT 51330
Printed in Malaysia
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
