Software User's Manual M00068500 EN

Software User's Manual M00068500 EN
Software User's Manual
M00068500 EN
TM-T20II Software Installer
Software User's Manual
Cautions and Trademarks
Cautions and Trademarks
Cautions
❏ No part of this document may be reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of
Seiko Epson Corporation.
❏ The contents of this document are subject to change without notice. Please contact us for the latest information.
❏ While every precaution has taken in the preparation of this document, Seiko Epson Corporation assumes no
responsibility for errors or omissions.
❏ Neither is any liability assumed for damages resulting from the use of the information contained herein.
❏ Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of: accident, misuse, or
abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.)
failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
❏ Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any options
or any consumable products other than those designated as Original EPSON Products or EPSON Approved
Products by Seiko Epson Corporation.
Trademarks
®
®
MS-DOS , Microsoft , Win32 , Windows , Windows Vista , Visual Studio , Visual Basic , Visual C++ , and
®
®
®
®
®
®
®
®
Visual C# are either registered trademarks or trademarks of Microsoft Corporation in the United States and other
®
countries.
EPSON and ESC/POS are registered trademarks of Seiko Epson Corporation in the U.S. and other countries.
ESC/POS Command System
EPSON ESC/POS is a proprietary POS printer command system that includes patented or patent-pending
commands. ESC/POS is compatible with all types of EPSON POS printers and displays (excluding the TM-C100
printer). ESC/POS is designed to reduce the processing load on the host computer in POS environments. It comprises
a set of highly functional and efficient commands and also offers the flexibility to easily make future upgrades.
Copyright © 2013 Seiko Epson Corporation. All rights reserved.
2
TM-T20II Software Installer
Software User's Manual
Cautions and Trademarks
For Safety
Key to Symbols
The symbols in this manual are identified by their level of importance, as defined below. Read the following carefully
before handling the product.
!Caution:
Provides information that must be observed to avoid damage to your equipment or a malfunction.
Note:
Provides important information and useful tips.
Restriction of Use
When this product is used for applications requiring high reliability/safety such as transportation devices related to
aviation, rail, marine, automotive etc.; disaster prevention devices; various safety devices etc; or functional/precision
devices etc, you should use this product only after giving consideration to including fail-safes and redundancies into
your design to maintain safety and total system reliability. Because this product was not intended for use in
applications requiring extremely high reliability/safety such as aerospace equipment, main communication
equipment, nuclear power control equipment, or medical equipment related to direct medical care etc, please make
your own judgment on this product's suitability after a full evaluation.
Aim of the Manual
This manual provides information on how to use TM-T20II Software & Documents Disc for the product users or
development engineers who use the software.
3
TM-T20II Software Installer
Software User's Manual
Contents
Contents
Uninstalling the EpsonNet Simple Viewer. . . .
Uninstalling the OPOS ADK. . . . . . . . . . . . . .
Uninstalling the OPOS ADK for .NET. . . . . . .
Uninstalling the JavaPOS ADK. . . . . . . . . . . .
Cautions and Trademarks
Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESC/POS Command System. . . . . . . . . . . . . . . . .
For Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key to Symbols. . . . . . . . . . . . . . . . . . . . . . . . .
Restriction of Use. . . . . . . . . . . . . . . . . . . . . . . . .
Aim of the Manual. . . . . . . . . . . . . . . . . . . . . . . .
.2
.2
.2
.3
.3
.3
.3
Using the Printer Driver
Printer Driver Access Methods and the
Application Range. . . . . . . . . . . . . . . . . . . . . . . .
Accessing from the Printer Driver's Print
menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing from the Printer Driver's Properties
...................................
Accessing from the Application's Print Setting
Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Language for Displaying Properties. . . . . . . . . . .
How to Use the Basic Functions. . . . . . . . . . . . . .
Paper Feed and Cut Setting. . . . . . . . . . . . . . .
Peripheral Device's Action Settings. . . . . . . . .
Logo Printing. . . . . . . . . . . . . . . . . . . . . . . . .
Advanced Method. . . . . . . . . . . . . . . . . . . . . . . .
User Defined Paper Setting. . . . . . . . . . . . . . .
Barcode Printing. . . . . . . . . . . . . . . . . . . . . . .
2 dimensional symbol Printing. . . . . . . . . . . .
Coupon Printing. . . . . . . . . . . . . . . . . . . . . . .
Buzzer Settings. . . . . . . . . . . . . . . . . . . . . . . .
Other Convenient Functions. . . . . . . . . . . . . .
Overview
TM-T20II Software Installer. . . . . . . . . . . . . . . . . . 6
Drivers and Utilities to be Installed. . . . . . . . . . . 6
Support OS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Restrictions on Using Multiple Drivers on the
Same System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to Access the Manuals. . . . . . . . . . . . . . . . . . . 8
Differences Depending on the OS. . . . . . . . . . . . . . 9
Viewing the User's Manual. . . . . . . . . . . . . . . . . . 10
Getting the URL of Epson Support Website. . . . . . 11
Installation
Installation Types. . . . . . . . . . . . . . . . . . . . . . . .
Easy Install. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Address Setting for Ethernet Printer
...................................
Installing Advanced Printer Driver Ver5
Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuring IP Address of the Printer Driver
...................................
Custom Install. . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying the Select Software Screen. . . . . . . .
Installing the Printer Driver. . . . . . . . . . . . . . .
Installing the OPOS ADK. . . . . . . . . . . . . . . .
Installing the OPOS ADK for .NET. . . . . . . . .
Installing the JavaPOS ADK. . . . . . . . . . . . . .
Installing the Utility. . . . . . . . . . . . . . . . . . . .
Adding a printer to a Windows2000 PC. . . . . .
Update Mode. . . . . . . . . . . . . . . . . . . . . . . . . . .
Uninstallation. . . . . . . . . . . . . . . . . . . . . . . . . . .
Uninstalling the Windows Printer Driver. . . . .
Uninstalling the TM-T20II Utility. . . . . . . . . .
Uninstall the EpsonNet Config. . . . . . . . . . . .
Uninstalling the Epson TM Virtual Port
Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. 38
. 39
. 39
. 40
. 13
. 13
. 18
. 41
. 41
. 42
. 42
. 42
. 43
. 43
. 45
. 47
. 49
. 49
. 51
. 51
. 52
. 53
. 54
TM-T20II Utility
. 19
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting the TM-T20II Utility. . . . . . . . . . . . . . .
Starting the TM-T20II Utility. . . . . . . . . . . . .
Adding a Communication Port and Starting
the TM-T20II Utility. . . . . . . . . . . . . . . . . . . .
Current Settings. . . . . . . . . . . . . . . . . . . . . . . . .
Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation Check. . . . . . . . . . . . . . . . . . . . . . . . .
Storing Logos. . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding a Logo. . . . . . . . . . . . . . . . . . . . . . . .
Paper Reduction Settings. . . . . . . . . . . . . . . . . . .
Automatic Paper Cut Settings. . . . . . . . . . . . . . .
Printing Control Settings. . . . . . . . . . . . . . . . . . .
Font Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Buzzer Settings. . . . . . . . . . . . . . . . . . . . . . . . . .
Communication I/F Settings. . . . . . . . . . . . . . . .
Serial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. 20
. 22
. 22
. 23
. 27
. 28
. 29
. 31
. 33
. 34
. 36
. 36
. 37
. 38
. 38
4
. 55
. 55
. 55
. 57
. 61
. 61
. 63
. 64
. 67
. 70
. 71
. 73
. 75
. 76
. 77
. 78
TM-T20II Software Installer
Software User's Manual
Contents
USB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethernet. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Backup/Restore. . . . . . . . . . . . . . . . . . . .
Saving the Printer Settings to a File. . . . . . . . .
Restore the Settings to the Printer. . . . . . . . . .
Acknowledgements. . . . . . . . . . . . . . . . . . . . . . .
. 78
. 80
. 80
. 81
. 82
. 83
Application Development Information
How to Control the Printer. . . . . . . . . . . . . . . . .
Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESC/POS Commands. . . . . . . . . . . . . . . . . . .
Storing Logos. . . . . . . . . . . . . . . . . . . . . . . . . . .
Download. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. 85
. 85
. 86
. 86
. 87
5
TM-T20II Software Installer
Software User's Manual
Overview
Overview
This chapter describes the specifications of TM-T20II Software & Documents Disc.
TM-T20II Software Installer
TM-T20II Software Installer allows you to install various drivers and utilities for the TM-T20II printer.
Drivers and Utilities to be Installed
Drivers
❏ Advanced Printer Driver Ver5
Windows printer driver. The following versions are provided.
❏ Advanced Printer Driver Ver.5.xx
❏ UPOS
Stands for Unified Point of Service. This is the standard specification of POS market, which defines drivers for
controlling POS peripheral devices in various operation environments. The following drivers are provided.
❏ OPOS ADK
❏ OPOS ADK for .NET
❏ JavaPOS ADK for Windows
Utilities
❏ TM-T20II Utility
Allows you to check and configure the TM-T20II settings.
❏ EpsonNet Config
This utility is for configuring network settings, such as IP address, of the printer connected to an Ethernet.
❏ EpsonNet Simple Viewer
This allows you to monitor the status of the printer connected to a network printer or client computer (POS or
KIOSK terminal). Using this with TM-T20II Utility makes it possible to change the settings of TM-T20II
connected to a client computer.
❏ Epson TM Virtual Port Driver
This allows you to convert TM-T20II from serial to USB / Ethernet. When your POS application has a serial port of
TM-T20II, and you want to connect TM-T20II via USB / Ethernet, you can use the USB / Ethernet-connected
printer from the application as though the printer is serial printer. Because the tool performs the conversion
automatically, you do not need to change the application's ESC/POS commands that controls the printer
connected via serial port.
6
TM-T20II Software Installer
Software User's Manual
Overview
Support OS
The following lists the supported operating systems for running the TM-T20II drivers and utilities.
❏ Windows 8 (32 bit / 64 bit *1)
❏ Windows 7 SP1 (32 bit / 64 bit *1)
❏ Windows Vista SP2 (32 bit / 64 bit *1)
❏ Windows XP SP3 (32 bit)
❏ Windows 2000 SP4 *2
❏ Windows Server 2012 (64 bit *1)
❏ Windows Server 2008 R2 SP1 *1
❏ Windows Server 2008 SP2 (32 bit / 64 bit *1)
❏ Windows Embedded for Point of Service *3
❏ Windows Embedded POSReady 2009 *3
*1 The OPOS ADK can be used under 64-bit OS as long as the system meets the operating requirements. For more
details, see the release note before installing the OPOS ADK.
*2 The OPOS ADK for .NET, Advanced Printer Driver Ver.5 and the Epson TM Virtual Port Driver cannot be used
under Windows 2000.
*3 EpsonNet Simple Viewer is not supported.
Restrictions on Using Multiple Drivers on the Same
System
TM-T20II Software Installer may not install the driver, or if the driver can be installed, the combination of the existing
driver and the newly installed driver may not be supported. Refer to the following table.
Before TM-T20II driver is installed
TM-T20II Software Installer
A
B
C
D
Advanced Printer Driver Ver.3
-
-
-
-
Advanced Printer Driver Ver.4.00 to 4.08
-
-*
-*
-*
Advanced Printer Driver Ver4.09 or 4.17
-
-
-
-
Advanced Printer Driver Ver4.50 to 4.53
-
✓
✓
✓
Advanced Printer Driver Ver4.54 or later
✓
✓
✓
✓
OPOS ADK Ver.2.67 former
-
!
-
-
7
TM-T20II Software Installer
Software User's Manual
Overview
Before TM-T20II driver is installed
TM-T20II Software Installer
A
B
C
D
OPOS ADK Ver.2.68 or later
✓
!
✓
-
current OPOS ADK for .NET Ver.1.11.8 former
-
-
!
-
OPOS ADK for .NET Ver.1.11.20 or later
✓
✓
!
-
JavaPOS ADK Ver.1.11.18 former
-
-
-
!
JavaPOS ADK Ver.1.11.20 or later
✓
-
-
!
TM-S1000 Driver
✓
✓
✓
-
TM-S9000/2000 Driver
✓
✓
✓
-
TM-J9000 OPOS ADK
✓
✓
✓
-
TM-J9000 Advanced Printer Driver
✓
✓
✓
-
TM-J9000 Status API
✓
✓
✓
-
TMCOMUSB Ver.2
-
-
-
-
TMCOMUSB Ver.3 and Ver.4. or Epson TM Virtual Port Driver Ver.5 to
Ver.7.00
-
✓
✓
✓
Epson TM Virtual Port Driver Ver.7.10a or later
✓
✓
✓
✓
Epson InkJet Printer Driver
✓
✓
✓
✓
A : Advanced Printer Driver Ver.5
B : OPOS ADK Ver.2.7x (TM-T20II)
C : OPOS ADK for .NET Ver.1.12.x (TM-T20II)
D : JavaPOS ADK for Windows Ver.1.13.x (TM-T20II)
✓ : Supported
- : Not supported
* : Can not be installed.
! : TM-T20II Software Installer starts in update mode. The installer shows the version of driver already installed on the
computer and allows you to select whether to update the driver or not.
How to Access the Manuals
The manuals of the drivers and utilities are also installed.
To see the manuals, access the manual data as follows.
❏ Advanced Printer Driver Ver.5
Start - All Programs / All apps(Windows 8) - EPSON - EPSON Advanced Printer Driver 5 - EPSON APD5
TM-Txx Manual
The Easy Install does not install the manuals. Install the manuals separately after finishing the Easy Install.
U See “Installing Advanced Printer Driver Ver5 Manual” on page 19
❏ OPOS ADK
Start - All Programs / All apps(Windows 8) - OPOS - Manual
8
TM-T20II Software Installer
Software User's Manual
Overview
❏ OPOS ADK for .NET
Start - All Programs / All apps(Windows 8) - EPSON OPOS for .NET - Manual
❏ JavaPOS ADK for Windows
Start - All Programs / All apps(Windows 8) - Epson JavaPOS ADK - Documentation
❏ TM-T20II Utility
Except Windows 8:
Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility User's Manual
Windows 8:
Start - All apps - EPSON TM-T20II - EPSON TM-T20II Utility User's Manual
❏ EpsonNet Simple Viewer
Start - All Programs / All apps(Windows 8) - EpsonNet - EpsonNet Simple Viewer - User's Manual
Differences Depending on the OS
The content of the descriptions of some operations in this book may be different depending on the OS. See the
following.
Item
Description
Screens shown
Screens in Windows 7 are used for the descriptions in this manual.
Confirmation and setting of the printer
driver
Windows 8
Desktop - Sidebar Settings - Control Panel - Hardware and Sound Devices and Printers
Windows 7
Start - Control Panel - Hardware and Sound - Devices and Printers
Right click the printer driver, and select the Printer properties.
Windows Vista
Start - Control Panel - Hardware and Sound - Printers
Right click the printer driver, and select the Properties.
Windows XP
Start - Control Panel - Printers and Faxes Right click the printer driver, and
select the Properties.
Windows 2000
Start - Settings - Control Panel - Printers
Right click the printer driver, and select the Properties.
Starting the TM-T20II Utility
Windows 8
Start - All apps - EPSON TM-T20II - EPSON TM-T20II Utility
Windows 7
Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility
Windows Vista
Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility
Windows XP
Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility
9
TM-T20II Software Installer
Software User's Manual
Overview
Item
Description
Uninstall a program
Windows 8
Desktop - Sidebar Settings - Control Panel - Uninstall a program
Windows 7
Start - Control Panel - Uninstall a program
Windows Vista
Start - Control Panel - Uninstall a program
Windows XP
Start - Control Panel - Add or Remove Programs
Windows 2000
Start - Settings - Control Panel - Add/Remove Programs
Viewing the User's Manual
❏ Software User's Manual (this manual):
Explains about TM-T20II Software & Documents Disc, how to install the driver, how to use the utilities, and so
on.
❏ User's Manual:
Describes how to set up TM-T20II hardware, what are included in the box, how to handle the hardware, compliant
safety standards, safety precautions, and so on.
❏ Technical Reference Guide:
Provides all information necessary to develop, design, and/or install a system that uses TM-T20II, or to develop or
design a printer application for TM-T20II.
❏ ESC/POS Quick Reference:
Quick Reference is a guide to using ESC/POS command to control the printer.
The following is how to view the manuals.
A
Insert the TM-T20II Software & Documents Disc to the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Manuals button.
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the TM-T20II Software & Documents Disc.
10
TM-T20II Software Installer
Software User's Manual
Overview
B
The Manuals screen appears. Click the manual button you want to see.
Getting the URL of Epson Support Website
The website provides a variety of product information and the latest driver download service.
A
Insert the TM-T20II Software & Documents Disc to the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Support button.
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the TM-T20II Software & Documents Disc.
11
TM-T20II Software Installer
Software User's Manual
Overview
B
The Support Information screen appears. Click the button of your area. The URL of Epson support website is
displayed.
12
TM-T20II Software Installer
Software User's Manual
Installation
Installation
This chapter describes how to install the printer drivers and conduct a test print after the installation. The
uninstallation procedure is also provided.
U See “Uninstallation” on page 36
!Caution:
❏ Install with administrator privileges.
❏
Close all running applications before the installation.
❏
If your printer is a serial type, and your OS is Windows 2000, you can not install Advanced Printer Driver
using the installer. So, refer to , U “Adding a printer to a Windows2000 PC” on page 33 and install
Advanced Printer Driver.
Installation Types
You can select the installation type from the following.
❏ Easy Install: U See “Easy Install” on page 13
This is a standard installation, which installs the TM-T20II printer driver and TM-T20II Utility. If you are using
an Ethernet EpsonNet Config and EpsonNet Simple Viewer are also installed.
❏ Custom Install: U See “Custom Install” on page 22
You can select printer drivers and utilities you want to install. Select this installation type if you want to install the
OPOS driver, OPOS .NET driver, JavaPOS driver, the printer driver manual, and sample programs and tools for
developing programs.
❏ Update mode: U See “Update Mode” on page 34
If the printer driver and/or UPOS is already installed, the driver version is displayed and you can select whether to
update the driver or not.
Easy Install
!Caution:
❏ When installing, connect just one printer to the computer. Do not connect multiple printers.
❏
A
Turn off the printer and then start the installation.
Insert the TM-T20II Software & Documents Disc into the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Install Now
button.
Note:
The displayed language can be changed from Select language.
13
TM-T20II Software Installer
Software User's Manual
Installation
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the TM-T20II Software & Documents Disc.
B
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
C
The Select Installation Type screen appears. Click the Easy Install button.
D
The Communication Port Settings screen appears. The setting varies depending on the connection method.
Select the port to connect the printer.
Serial connection
Proceed to Step 5.
USB connection
Click the USB port button, and then click the Next button. Proceed to Step 8.
Ethernet connection
Proceed to Step 6.
14
TM-T20II Software Installer
Software User's Manual
Installation
E
Click the Serial port button. Configure the communication settings, then click the Next button. Proceed to
Step 8.
Select the COM port, Bits per second, Data bits, Parity and Stop bits.
Note:
The driver's serial communication setting should be the same as that of the printer.
F
Click the Ethernet button.
When printer is already networked
Proceed to Step 7.
When using Ethernet
Click the Run EpsonNet Config button and configure the
printer's network setting using the EpsonNet Config.
U See “Network Address Setting for Ethernet Printer” on
page 18
When configuring the network setting after
installing the driver.
Proceed to Step 7.
Note:
When the EpsonNet Config is not installed, the Cannot start EpsonNet Config. Do you want to install it now?
message appears. Click the Yes button to install it.
15
TM-T20II Software Installer
Software User's Manual
Installation
G
H
Configure the IP address of the printer on IP Address and then click the Next button. Proceed to Step 8.
When configuring the network setting after installing the driver, assign the printer driver port IP address you
configure here to the printer, or change the printer driver port IP address to the one that will be set to the
printer.
The Start Installation screen appears. The driver and utility to be installed are listed.
❏ Advanced Printer Driver Ver.5.xx
❏ TM-T20II Utility Ver. x.xx
❏ EpsonNet Config Ver. x.xx (Only for Ethernet connection)
❏ EpsonNet Simple Viewer (Only for Ethernet connection)
Click the Install button to start the installation.
16
TM-T20II Software Installer
Software User's Manual
Installation
I
The Connect Printer screen appears. Connect the computer to the printer, and turn the printer on.
When the USB connection between the computer and printer is established, a pop-up message; Installing
device driver software appears on the task tray, and the setup is automatically started. Proceed to Step 10 when
the setting is finished.
When you connect the printer using an interface other than USB, or when installing the driver without
connecting the printer, click the Next button.
J
When the installation is completed, the Installation Finished screen appears.
When conducting test print
Click the PrintingTest button. When the test print is finished, click
the Finish button to end the installation.
When exiting the installation
Uncheck the Run TM-T20II Utility. Then click the Finish button to
end the installation.
When setting the printer using TM-T20II Utility
continuously
Check the Run TM-T20II Utility checkbox (the box is checked by
default). Click the Finish button to end the installation. The
TM-T20II Utility starts to run.
U See “TM-T20II Utility” on page 55
17
TM-T20II Software Installer
Software User's Manual
Installation
This is the end of the printer driver installation. For information on how to print using the printer driver.
U See “Using the Printer Driver” on page 41
Network Address Setting for Ethernet Printer
If you are using an Ethernet connection, configure the IP address using the EpsonNet Config.
A
Start the EpsonNet Config.
When the EpsonNet Config is already installed, start it by clicking Start - All Programs - EpsonNet - EpsonNet
Config Vx - EpsonNet Config.
B
The EpsonNet Config screen appears.
C
Select the printer you want to configure, then click the Configuration button.
D
Check that the target printer is listed in the screen.
When the printer does not appear, click the Refresh button.
The Device Properties screen appears. Select the Network Interface - TCP/IP - Basic.
18
TM-T20II Software Installer
Software User's Manual
Installation
E
Configure the printer IP address. Then click the Transmit button.
F
The confirmation screen appears. Click the Yes button.
G
The configured settings are sent to the printer. After approx. 30 seconds, the completion screen appears.
Select the Manual and Set using PING. Then configure the IP Address, Subnet Mask and Default Gateway.
Click the OK button.
H
Confirm the settings on the EpsonNet Config screen.
I
Quit the EpsonNet Config.
Installing Advanced Printer Driver Ver5 Manual
The Easy Install does not install the Advanced Printer Driver manual. To see the manual, install it separately.
A
Insert the TM-T20II Software & Documents Disc into the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Install Now
button.
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the TM-T20II Software & Documents Disc.
B
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
19
TM-T20II Software Installer
Software User's Manual
Installation
C
The Update Software screen appears. Click the Next button.
D
The Select Software screen appears. Check the Sample and Manual checkbox and click the Next button.
E
The Start Installation screen appears. Click the Install button.
F
The EPSON APD5 Sample&Manual - InstallShield Wizard screen appears, click the Next button.
G
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
H
The Ready to Install the Program screen appears. Click the Install to install the sample programs and manual
of Advanced Printer Driver.
I
The InstallShield Wizard Complete screen appears. Click the Finish button.
J
The Installation Finished screen appears. Click the Finish button to finish the installation.
Clear the checkbox for the drivers or utilities that you do not install here.
This is the end of the installation of the Advanced Printer Driver manual.
Configuring IP Address of the Printer Driver
The following explains how to configure the printer's IP address for the installed printer driver. This will change the
Epson port setting.
A
Select from Start - Control Panel - Hardware and Sound and open Printers and then right click the target
printer driver and select Properties.
U See “Differences Depending on the OS” on page 9
20
TM-T20II Software Installer
Software User's Manual
Installation
B
The property screen of the printer appears. Select the Ports tab and then click the Configure Port... button.
C
The Configure Port screen appears. Set a configure port while referring to the screen and click the OK button.
D
The display returns to the Properties screen. When you click the OK button, the changes you made become
effective.
21
TM-T20II Software Installer
Software User's Manual
Installation
Custom Install
!Caution:
❏ When installing, connect just one printer. Do not connect multiple printers.
❏
When you are prompted whether to restart the computer during the installation, select No and continue the
installation. Restart the computer and the printer after all the installation is finished. If you select Yes and
restart the computer during the installation, the rest of the drivers will not be installed.
❏
If you select more than one drivers to install them under Windows 2000, you will be prompted that this may
cause the printer to malfunction. Under Windows 2000, you can install only one driver.
The following items can be installed with the Custom Install. The TM-T20II Software & Documents Disc is required
for Custom Install
❏ Advanced Printer Driver Ver.5
❏ Sample and Manual
❏ OPOS ADK
❏ OPOS ADK for .NET
❏ JavaPOS ADK
❏ TM-T20II Utility
❏ Coupon Generator
❏ EpsonNet Config
❏ EpsonNet Simple Viewer
❏ Epson TM Virtual Port Driver
Displaying the Select Software Screen
The TM-T20II Software & Documents Disc is required for Custom Install. You can select items you want to install in
Select Software screen. Follow the steps below to display the Select Software screen.
A
Insert the TM-T20II Software & Documents Disc into the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Install Now
button.
Note:
The displayed language can be changed from Select language.
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the printer driver CD.
B
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
22
TM-T20II Software Installer
Software User's Manual
Installation
C
The Select Installation Type screen appears. Click the Custom Install button.
D
The Select Software screen appears. Check the items you want to install from the list.
After this step, follow the installation procedure for each item.
Installing the Printer Driver
The printer driver can also be installed with Easy Install in the TM-T20II Software & Documents Disc. Easy Install
installs all items of the printer driver, and Custom Install allows you to select items you want to install from the
following.
❏ Advanced Printer Driver Ver.5
❏ Sample and Manual
Under Windows 2000, the Sample is not available. Only the Manual is available.
Follow the steps below to execute the printer driver installation.
A
Insert the TM-T20II Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 22
B
Select the Advanced Printer Driver Ver.5 .xx. Clear the check box for the items you do not want to install. Click
the Next button.
C
The Check Install screen appears. Check the Warning.
Check the computer environment and click Next to continue the installation.
Note:
In the Warning, the versions of Epson driver/tool that can coexist with the APD5 are listed.
23
TM-T20II Software Installer
Software User's Manual
Installation
D
The License Agreement screen is displayed. After checking the contents and selecting Agree, click Install.
Installation of Advanced Printer Driver Ver.5 begins.
E
The Printer Registration screen appears.
F
The Register, Change and Delete EPSON TM Printer screen is displayed.
G
Set the followings from 2. Printer.
Here, connect the printer to the computer and turn the printer's power on. Click Next.
From 1. Select Printer, select <New Printer>.
Item
Description
Name
Specify the printer driver name.
Do not use Unicode/2-byte characters for the name.
H
Select a port to use (Serial/USB/Ethernet) from Port Type under 3.Communication Settings. Necessary
settings are done according to the interface.
24
TM-T20II Software Installer
Software User's Manual
Installation
Port type
Item
COM
Description
Communicate with serial port. Set the following communication setting.
Port
Specify the number of serial port used for connecting the printer.
Baud Rate
Specify the baud rate.
Parity
Specify the parity.
Stop Bits
Specify the stop bits.
Flow Control
Specify the method of data flow between the computer and the printer.
Data Bits
Specify the data bits.
USB
Communicate with USB port. Set the following communication setting.
USB Port
Ethernet
Specify the USB port used for connecting the printer. Usually, no setting is
required.
Communicate with Ethernet port. Set the following communication setting.
Ethernet Port
Specify the Ethernet port used for connecting the printer. Usually, no setting is
required.
IP Address
Set the IP address of Ethernet port the TM printer is connected.
Set to Printer
Setup the IP address to the printer itself.
U See “Network Address Setting for Ethernet Printer” on page 18
Note:
When path through connection is used by the driver of APD4 customer display, adjust the TM printer's
communication settings with the communication settings of customer display driver set by APD4.
I
Set the followings from 4. Apply and click Save Setting.
Item
Description
Set as Default Printer
Check when configuring the printer as that normally used from
the Windows applications.
25
TM-T20II Software Installer
Software User's Manual
Installation
J
When the printer is registered, the screen comes up as shown below.
K
After confirming the test page printing of Windows, click Next under 5. Complete.
L
The Installation Complete screen appears.
M
When the installation is completed, the Installation Finished screen appears.
Click Yes. Test page printing of Windows is carried out.
Click Close to finish the installation.
When conducting test print:
Click the Printing Test button. When the test print is finished, click the Finish button to end the installation.
This is the end of the printer driver installation.
26
TM-T20II Software Installer
Software User's Manual
Installation
Installing the OPOS ADK
A
Insert the TM-T20II Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 22
B
Check the OPOS ADK Ver. x.xx. Clear the check box for the items you do not want to install. Click the Next
button.
C
The Start Installation screen appears. The driver and utility to be installed are listed. Click the Install button to
start the installation.
D
The Choose Setup Language appears. Select your language, and click the Next button.
E
The EPSON OPOS ADK for TM-T20II Version x.xx xxx appears. Click the Next button.
F
The Software License Agreement screen appears. Read the content and select the I accept the terms in the
license agreement. Then click the Next button.
G
The Select Registry File screen appears. Click the Next button.
H
The Setup Type screen appears. Select Developer and then click the Next button.
Click the Browse button to change the default installation location.
I
The Start Copying Files screen appears. Click the Next button.
J
The Port selection screen appears. Select the port. Click the Next button to start the installation.
K
The InstallShield Wizard Complete screen appears. Click the Finish button.
27
TM-T20II Software Installer
Software User's Manual
Installation
L
When the installation is completed, the Installation Finished screen appears. Then click the Finish button to
end the installation.
This is the end of the OPOS ADK installation.
Installing the OPOS ADK for .NET
Note:
To install the OPOS ADK for .NET, Microsoft .NET Framework and Microsoft POS for .NET are required.
Install Microsoft .NET Framework and Microsoft POS for .NET Ver.1.11 beforehand.
A
Insert the TM-T20II Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 22
B
Select the OPOS ADK for .NET Ver. x.xx.x. Clear the check box for the items you do not want to install. Click
the Next button.
C
The Start Installation screen appears. The driver and utility to be installed are listed. Click the Install button to
start the installation.
D
Install the EPSON OPOS ADK for .NET.
The EPSON OPOS ADK for .NET x.xx.x - InstallShield Wizard screen appears.
Select the language, and then click the Next button.
E
The Welcome to the InstallShield EPSON OPOS ADK for .NET screen appears. Click the Next button.
F
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Click the Next button.
G
The Setup Type screen appears. Select Developer and then click the Next button.
Click the Browse button to change the default installation location.
28
TM-T20II Software Installer
Software User's Manual
Installation
H
The Setup Type screen appears. Select the port and click the Next button.
I
The Start Copying Files screen appears. Click the Next button to start the installation.
J
The InstallShield Wizard Complete screen appears. Click the Finish button.
K
When the installation is completed, the Installation Finished screen appears. Then click the Finish button to
end the installation.
This is the end of the OPOS ADK for .NET installation.
Installing the JavaPOS ADK
Note:
To install the JavaPOS ADK, Java Runtime Environment and Java Advanced Imaging API are required.
Make sure to install the above software before installing JavaPOS ADK.
A
Insert the TM-T20II Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 22
B
Select the JavaPOS ADK Ver. x.xx.x. Clear the check box for the items you do not want to install. Click the Next
button.
C
The Start Installation screen appears. The driver and utility to be installed are listed. Click the Install button to
start the installation.
29
TM-T20II Software Installer
Software User's Manual
Installation
D
The EPSON JavaPOS ADK x.xx.x screen appears. Select the language and then click the OK button.
E
The Introduction screen appears. Click the Next button.
F
The License Agreement screen appears. Read the content and select the I accept the terms in the License
Agreement. Click the Next button.
G
The Choose JVM screen appears. Click the Next button.
H
The Choose Install Set screen appears. Select Developer and then click the Next button.
I
The Choose Folder Location screen appears. Click the Next button.
J
The Choose your communication screen appears. Select the port and click the Next button.
K
The Location for jpos.xml screen appears. Click the Next button.
L
The Pre-Installation Summary screen appears. Click the Install button to start the installation.
M
The Installation Complete screen appears. Click the Done button.
If a message to ask you to restart the computer appears, select No, I will restart my system myself.
30
TM-T20II Software Installer
Software User's Manual
Installation
N
When the installation is completed, the Installation Finished screen appears. Then click the Finish button to
end the installation.
This is the end of the JavaPOS ADK installation.
Installing the Utility
The utility can also be installed with Easy Install on the TM-T20II Software & Documents Disc.
Easy Install installs TM-T20II Utility for a serial or USB connection, and for an Ethernet it installs TM-T20II Utility,
EpsonNet Config and EpsonNet Simple Viewer.
Custom Install allows you to select utilities you want to install from the following.
❏ TM-T20II Utility Ver. x.xx
❏ Coupon Generator
❏ EpsonNet Config Ver. x.xx
❏ EpsonNet Simple Viewer Ver.x.xx
❏ Epson TM Virtual Port Driver Ver. x.xx
Follow the steps below to execute the utility installation.
A
Insert the TM-T20II Software & Documents Disc into the computer and follow the steps.
U See “Displaying the Select Software Screen” on page 22
B
Select the utilities you want to install from the list. Clear the check box for the items you do not want to install.
Click the Next button.
C
The Start Installation screen appears. The drivers and utilities to be installed are listed. Click the Install button
to start the installation.
31
TM-T20II Software Installer
Software User's Manual
Installation
D
TM-T20II Utility is installed.
Proceed to Step 12 if you do not install any other utility or driver.
The installation is started without displaying any other screens.
E
EpsonNet Config is installed.
F
EpsonNet Simple Viewer is installed.
The installation is started without displaying any other screens.
Proceed to Step 12 if you do not install any other utility or driver.
The installation is started without displaying any other screens.
G
Install the Epson TM Virtual Port Driver.
H
The Welcome to the EPSON TM Virtual Port Driver Ver. x.xx Setup Wizard screen appears. Click the Next
button.
I
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
J
The Ready to Install the Program screen appears. Then click the Install button.
K
When the following screen appears, click the Restart Later button.
The EPSON TM Virtual Port Driver Ver. x.xx - InstallShield Wizard screen appears. Select the language used
for installation and click the OK button.
Note:
If you restart your PC at this point, the installation process may not be completely performed. Be sure to select the
Restart Later button.
L
The InstallShield Wizard Complete screen appears. Click the Finish button.
If the restart of your PC is requested, select Yes, I want to restart my computer now. and click the Finish
button.
32
TM-T20II Software Installer
Software User's Manual
Installation
If you restarted the computer, there's no need to proceed to Step 12, but the installation is complete.
!Caution
If the restart of your PC is requested on the InstallShield Wizard Complete screen, be sure to select Yes, I want to
restart my computer now.
M
When the installation is completed, the Installation Finished screen appears.
When exiting the installation:
Uncheck the Run TM-T20II Utility (the box is unchecked by default). Then click the Finish button to end the
installation.
When setting the printer using TM-T20II Utility continuously:
Check the Run TM-T20II Utility checkbox. Click the Finish button to end the installation. The TM-T20II
Utility starts to run.
U See “TM-T20II Utility” on page 55
This is the end of the utility installation.
Adding a printer to a Windows2000 PC
If your printer is a serial type, and your OS is Windows 2000, install Advanced Printer Driver as follows.
33
TM-T20II Software Installer
Software User's Manual
Installation
A
In Windows2000's Printers, double click Add Printer. The Add Printer wizard starts up.
B
Follow the instructions shown on the screen. Select Local Printer, and turn off Automatically detect and
install my Plug and Play printer..
C
Select a COM port to connect the printer.
D
Select Have Disk then Browse, and then select the following INF files on the CD-ROM.
E
Select a driver to install, then install it.
F
In Windows2000's Printers, the printer's queue is created.
root/Windows/Advanced Printer Driver/V5_INF/Driver/EA5INSTMT20II.INF
Update Mode
!Caution:
❏ When installing, connect just one printer. Do not connect multiple printers.
❏
When you are prompted whether to restart the computer during the installation, select No and continue the
installation. Restart the computer and the printer after all the installation is finished. If you select Yes and
restart the computer during the installation, the rest of the drivers will not be installed.
The update mode allows you to update the printer driver already existing on the system, or check to see if the selected
newer version of printer driver can exist with the existing printer driver on the same system.
When the Advanced Printer Driver, OPOS ADK, OPOS ADK for .NET, JavaPOS ADK, and Epson TM Virtual Port
Driver are already installed, the driver installation is carried out in the update mode.
Under Windows 2000, you will be just notified that installing the new driver may cause the printer to malfunction due
to the incompatibility with the existing one.
A
Insert the TM-T20II Software & Documents Disc into the computer. The TM-T20II Software Installer is
automatically read and the EPSON TM-T20II Software Installer screen appears. Click the Install Now
button.
Note:
The displayed language can be changed from Select language.
When the TM-T20II Software Installer is not automatically read, double click the TMInstallNavi.exe icon in
the TM-T20II Software & Documents Disc.
B
The License Agreement screen appears. Read the content and select the I accept the terms in the license
agreement. Then click the Next button.
34
TM-T20II Software Installer
Software User's Manual
Installation
C
The Update Software screen appears. The system is checked and existing driver and its version are displayed.
Click the Next button.
D
The Select Printer Language (Resident Character) screen appears. Select the language of your printer and
click the Next button.
E
The Select Software screen appears. Check the checkbox for the drivers and utilities you want to install and
uncheck the checkbox for those you do not need.
Items that require updating are automatically selected.
F
The installer checks the validity of the update or the combination of the drivers. A warning message is displayed
if the combination can cause the printer to malfunction. Check the screen for the warning message, and click
the Next button.
When you click the Next button with the warning message displayed, a warning screen appears. Click the OK
button to proceed to Step 7.
35
TM-T20II Software Installer
Software User's Manual
Installation
Note:
If you select more than one drivers to install them under Windows 2000, you will be prompted that this may cause
the printer to malfunction. Under Windows 2000, you can install only one driver.
G
The Start Installation screen appears. Check that the listed items to be installed are correct, and click the Install
button.
H
When the installation is finished, the Installation Finished screen appears. Click the Finish button to end the
installation.
Uninstallation
❏ Uninstall the printer driver
❏ Uninstall the TM-T20II Utility
❏ Uninstall the EpsonNet Config
❏ Uninstall the Epson TM Virtual Port Driver
❏ Uninstall the EpsonNet Simple Viewer
❏ Uninstall the OPOS ADK
❏ Uninstall the OPOS ADK for .NET
❏ Uninstall the JavaPOS ADK
Uninstalling the Windows Printer Driver
!Caution:
Do not delete the printer driver in Start - Control Panel - Hardware and Sound - Printers.
U See “Differences Depending on the OS” on page 9
Even though the icon (the printer driver) disappears from the screen, the printer driver is not uninstalled.
A
Quit all applications running on the computer.
36
TM-T20II Software Installer
Software User's Manual
Installation
B
Select Start - Control Panel - Uninstall a program - EPSON Advanced Printer Driver for TM-T20II Ver.5
and click Uninstall.
C
The uninstallation confirmation screen appears. Click the Yes button.
D
The uninstallation confirmation screen for model specific utility is displayed. Click Yes when not using the
model specific utility with other drivers and applications. Click No when not uninstalling.
The Advanced Printer Driver Ver.5 is uninstalled.
The Advanced Printer Driver Ver.5 utility is uninstalled.
E
The Uninstallation Complete screen is displayed. Uninstallation is complete after clicking Finish.
Uninstalling the TM-T20II Utility
A
Quit all applications running on the computer.
B
Select Start - Control Panel - Uninstall a program - EPSON TM-T20II Utility. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
C
The TM-T20II Utility uninstallation confirmation screen appears. Click the Yes button.
D
The uninstallation of the TM-T20II Utility starts.
E
The Uninstall Complete screen appears. Click the Finish button to finish the uninstallation.
37
TM-T20II Software Installer
Software User's Manual
Installation
Uninstall the EpsonNet Config
A
Select Start - Control Panel - Uninstall a program - EpsonNet Config. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
B
The EpsonNet Config uninstallation confirmation screen appears. Click the Yes button.
C
The uninstallation of the EpsonNet Config starts.
D
The Uninstall Complete screen appears. Click the Finish button to finish the uninstallation.
Uninstalling the Epson TM Virtual Port Driver
A
Select Start - Control Panel - Uninstall a program - EPSON TM Virtual Port Driver. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
B
The Epson TM Virtual Port Driver uninstallation confirmation screen appears. Click the Yes button.
C
The uninstallation of the Epson TM Virtual Port Driver starts.
D
When uninstallation is complete, the window automatically closes.
Uninstalling the EpsonNet Simple Viewer
When uninstalling this tool, also uninstall EpsonNet SDK for Windows, unless you are using it with another
application. Follow the steps below to uninstall this tool.
A
Select Start - Control Panel - Uninstall a program - EpsonNet Simple Viewer. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
B
The Uninstall Confirmation window appears. Click on the Yes button. This tool will be uninstalled.
38
TM-T20II Software Installer
Software User's Manual
Installation
C
The Uninstall Complete window appears. click on the Finish button.
D
The Uninstall or change a program window appears. Double-click on EpsonNet SDK for Windows.
E
The Uninstall Confirmation window appears. click on the Yes button. The EpsonNet SDK for Windows will
be uninstalled.
F
The Uninstall Complete window appears. click on the Finish button.
If EpsonNet SDK for Windows is not been used with any another application, perform Step 4 through Step
6.
When Yes, I want to restart my computer now. is selected, the computer will restart.
Uninstalling the OPOS ADK
A
Quit all applications running on the computer.
B
Select Start - Control Panel - Uninstall a program - EPSON OPOS ADK Version x.xx. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
C
The EPSON OPOS ADK uninstallation confirmation screen appears. Click the Yes button.
D
The Information screen appears. Click the Yes button.
E
The ADK Selection screen appears. Click the Next button.
F
The Confirm Deletion screen appears. Click the Start button.
G
The uninstallation of the EPSON OPOS ADK starts.
H
The Uninstall Complete screen appears. Click the Finish button.
When Yes, I want to restart my computer now. is selected, the computer will restart.
Uninstalling the OPOS ADK for .NET
A
Quit all applications running on the computer.
39
TM-T20II Software Installer
Software User's Manual
Installation
B
Select Start - Control Panel - Uninstall a program - EPSON OPOS ADK for .NET x.x.x. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
C
The EPSON OPOS ADK for .NET uninstallation confirmation screen appears. Click the Yes button.
D
The uninstallation of the EPSON OPOS ADK for .NET starts.
E
The completion screen appears. Click the Finish button to complete the uninstallation.
Uninstalling the JavaPOS ADK
A
Quit all applications running on the computer.
B
Select Start - Control Panel - Uninstall a program - EPSON JavaPOS ADK. Click Uninstall.
For information of the differences in screen selections based on the OS versions.
U See “Differences Depending on the OS” on page 9
When the User Account Control screen appears, click the Continue button.
C
The Uninstall Epson JavaPOS ADK screen appears. Click the Uninstall button.
D
The uninstallation of the EPSON JavaPOS ADK starts.
E
The completion screen appears. Click the Done button to finish the uninstallation.
40
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Using the Printer Driver
This chapter explains how to use the major functions of the printer driver.
Printer Driver Access Methods and the Application
Range
Depending on how you access the printer driver, the application range of the settings you make on the printer driver
varies.
❏ Accessing the printer driver from the printer driver's Print menu
The print settings you made on the printer driver are applied to the print settings of the all users configured on the
computer. You must have administrative privileges to make the settings.
❏ Accessing the printer driver from the printer driver's Properties
The print settings you made on the printer driver are applied to your print settings only. They are not applied to
the settings of other users. This method is recommended.
❏ Accessing the printer driver from the application's print setting menu
The print settings you made on the application are applied to the application only. The settings are canceled when
you quit the application. When you start the application again, the print settings configured in the printer driver's
properties are applied.
Accessing from the Printer Driver's Print menu
41
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Accessing from the Printer Driver's Properties
Accessing from the Application's Print Setting Menu
Language for Displaying Properties
The language used in the Advanced Printer Driver screen and Help can be selected from 24 languages. Selecting the
language that is easiest for you to understand will help you correctly configure the settings in the Advanced Printer
Driver. The language that initially appears is set based on the language information in your operating system.
42
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
A
Select the Language tab from Printing Preferences.
B
Select the language that you wish to use in the screens and Help from the Select language pull-down list. When
finished, click the OK button.
The languages that can be selected are shown below.
Selectable languages
Chinese-Hongkon
Chinese-Simplified
Chinese-Traditional
Croatian
Czech
Danish
Dutch
English
Finnish
French
German
Hungarian
Italian
Japanese
Korean
Norwegian
Portuguese
Russian
Slovenian
Spanish
Swedish
Thai
Turkish
Vietnamese
How to Use the Basic Functions
U “Paper Feed and Cut Setting” on page 43
U “Peripheral Device's Action Settings” on page 45
U “Logo Printing” on page 47
Paper Feed and Cut Setting
It sets the timing of auto-cut and paper feed before and after the printing.
A
Select Feed and Cut tab from printing preferences.
43
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
B
Select a cut and paper feed method displayed in the Preset option list and click OK.
Select using the illustration of paper feed and cut displayed in Illustration for your reference.
Note:
❏ Feed: Paper is fed to the auto-cutter's cutting position after printing a document.
❏
No Feed: Paper is not fed after printing a document.
Customization of Paper Feed and Cut
Customization is possible, when no preset function is desired, such as specifying the amount of paper feed and
modifying the timing control.
Follow the steps below.
A
Select Custom from the list of Preset option.
B
Select the control timing from Detail option tab to setup the action.
Settings are described below.
44
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Item
Timing
Action
C
Description
Start of Document
At the beginning of document printing
Start of Page
At the beginning of each page in the document
End of Page
At the end of each page in the document
End of Document
At the end of document printing
Feed to cut position before
cutting
When checked, paper is fed to the cutting position of auto-cutter.
Cutting method
Auto-cutter will not act when No cut is selected.
Feeding amount
The amount of paper feed can be specified by inches.
Feed paper to the print
starting position
When checked, paper is fed to the head position.
Eject single-cut sheets
When checked, single cut sheets are printed.
Click OK.
Peripheral Device's Action Settings
It sets peripheral device's actions such as the cash drawer and buzzer.
!Caution
Option buzzer can be operated only with the APD5 utility.
U See “Buzzer” on page 46
How to Setup
Follow the steps below.
A
Select Peripherals tab from Printing Preferences.
45
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
B
From the Peripherals pull down list, select the combination of peripheral device to be connected to the printer.
C
Select the timing to set the peripheral device settings.
U See “Setting of Peripheral Device” on page 46
D
Confirm Current settings and click OK.
Setting of Peripheral Device
Settings may be different depending on peripheral devices.
Note:
Cash drawer and external buzzer cannot be used simultaneously.
Cash Drawer
Settings of cash drawer are shown below.
Peripherals
Setting Value
Description
Cash Drawer #1 (2 Pins)
Do not open
Drawer #1 (2 pins) does not open.
Open
Drawer #1 (2 pins) opens.
Do not open
Drawer #2 (5 pins) does not open.
Open
Drawer #2 (5 pins) opens.
Cash Drawer #2 (5 Pins)
Buzzer
Settings of buzzer are described below.
46
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Peripherals
Setting Value
Description
External Buzzer
Turn off
External buzzer does not sound.
Turn on
External buzzer sounds.
Pattern
Specify buzzer sound pattern.
Count
Specify buzzer sound frequency.
Logo Printing
Logo can be printed at the beginning and the end of printing.
There are 2 printing methods.
❏ Print by Registering Logo to Printer Driver
U See “Print by Registering Logo to Printer Driver” on page 47
❏ Print by Registering Logo to Printer
For detail, see Advanced Printer Driver Ver.5 Printer Manual.
Note:
❏ The file formats that can be registered are BMP, JPEG, GIF and PNG.
❏
The maximum file size that can be registered is 2047 x 831 dots (width x height). Number of dots is calculated as
follow. Calculation formula: Number of dots = length (cm) / 2.54 (1 inch) x resolution level of TM printer (DPI)
Print by Registering Logo to Printer Driver
Note:
When using a serial interface, it is recommended to register a logo to the printer. For detail, see Advanced Printer Driver
Ver.5 Printer Manual.
Follow the steps below to register a logo and print.
A
Launch the APD5 utility.
B
Select Logo.
47
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
C
Select the position where the logo is printed.
D
Click Select Image to specify the logo to print.
E
The Logo Edit screen is displayed. Refer to the preview at the upper part of the screen and edit the image data for
logo.When editing is done, click OK.
Select the printing position from Start of Document / End of Document / Start of Page / End of Page.
Settings are described below.
Item
Description
Resize
When checked, the image can be resized.
If the image size is bigger than the paper width and its size is not changed, any part that doesn't
fit the paper is cut off.
Image width
Setup the image size after resizing. (Unit : mm)
48
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Item
Description
Half toning
Setup the half-toning type.
Select from Dither / Error Diffusion / None.
Brightness
Setup the brightness. Select from 5 levels.
Density
Setup the printing density.
F
Click Set.
G
When printing, the logo is printed at the position set in the APD5 utility.
The logo is registered to the driver.
Epson [email protected]
Advanced Method
❏ U “User Defined Paper Setting” on page 49
❏ U “Barcode Printing” on page 51
❏ U “2 dimensional symbol Printing” on page 51
❏ U “Coupon Printing” on page 52
❏ U “Buzzer Settings” on page 53
❏ U “Other Convenient Functions” on page 54
User Defined Paper Setting
Regular paper size can be printed using the user defined paper setting. It cannot expand/reduce according to the
printer's paper width.
49
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
A
Select User Defined Paper of the APD5 utility to setup user defined paper.
Item
Description
Paper Name
Name of the user defined paper.
This name is displayed in Printing Preferences - Layout.
Unit
Specify the unit for the paper width setting.
Paper Size
Specify the user defined paper size (width, height).
Margin
Specify the user defined paper size space (top, bottom, left, right).
B
Reopen Printing Preferences and select the Layout tab. Click Advanced and detail document setting of the
printer appears.
C
From the paper size, select the user defined paper you defined. Click OK.
50
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Barcode Printing
Set a barcode font to the Advanced Printer Driver. Barcode can be printed without having barcode encoder in an
application or preparing graphic data of barcode. High precision reading of barcode can be printed comparing to
when the barcode data is set in an application.
A
Barcode font can be setup from Barcode of the APD5 utility.
B
Specify a barcode font to barcode data using the application.
C
Barcode is printed based on the settings of the APD5 utility.
For detail, see Advanced Printer Driver Ver.5 Printer Manual.
2 dimensional symbol Printing
It sets a 2 dimensional symbol font to APD5. The 2 dimensional symbol printing is possible for the customer without
implementing the 2 dimensional symbol encoder or preparing a 2 dimensional graphic data in an application.
51
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
A
2 dimensional font can be set from 2-dimensional symbol of the APD5 utility.
B
Specify a 2 dimensional font to 2 dimensional data using the application.
C
2 dimensional symbol is printed based on the settings of the APD5 utility.
For detail, see Advanced Printer Driver Ver.5 Printer Manual.
Coupon Printing
APD5 provides the coupon printing function.
Coupons can be printed with various settings without modifying the customer's POS application.
Application
ABCD
Printing data
Printer Driver
10%OFF
Coupon settings
Note:
For detail, see Advanced Printer Driver Ver.5 Printer Manual.
52
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
Buzzer Settings
Allows you to configure whether an external optional buzzer is used and the buzzer pattern settings. Configure as
follows.
A
Click the Optinal Buzzer menu.
B
Select whether or not the buzzer is used.
C
Disable Buzzer
Do not use the external buzzer. Go to step 4.
Enable Buzzer
Use the external buzzer. Go to step 3.
Specify when the optional buzzer sounds and the buzzer pattern.
Setting
Description
When an error occurs:
Configure the buzzer setting when an error occurs.
53
TM-T20II Software Installer
Software User's Manual
Using the Printer Driver
D
Setting
Description
When automatic paper cut activates:
Configure the buzzer setting when automatic paper cutting takes place.
When specified pulse 1 (2 pin) occurs:
Configure the buzzer setting when the specified pulse is generated.
When specified pulse 2 (5 pin) occurs:
Configure the buzzer setting when the specified pulse is generated.
Buzzer:
Test the buzzer. Select a sound pattern. To test the buzzer sound, click the
Test button.
Click the Set button. The settings are reflected in the printer.
Other Convenient Functions
Printer driver can be also used the ways shown below.
❏ Print by Registering Logo to Printer
❏ Sending Commands
❏ Print Device Font in .NET Environment
❏ Printing start position setting
❏ Print the 80mm width layout with 58mm width
❏ Alias name setting to font
❏ Creation of emulation font
❏ Replacing function of device font
❏ Printing Control Settings
Note:
For detail, see Advanced Printer Driver Ver.5 Printer Manual.
54
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
TM-T20II Utility
This chapter explains how to use the TM-T20II Utility that configures this printer.
Overview
!Caution:
While saving the settings, do not turn off the printer or terminate the connection with the printer.
TM-T20II Utility provides the following functions.
For general users
❏ Operation Check: U See “Operation Check” on page 63
❏ Electronic Journal *1
*2 *3
❏ Storing Logos: U See “Storing Logos” on page 64
❏ Coupon Settings *1
*2 *3
❏ Paper Reduction: U See “Paper Reduction Settings” on page 70
❏ Automatic Paper Cut: U See “Automatic Paper Cut Settings” on page 71
For printer administrators
❏ Printing Control: U See “Printing Control Settings” on page 73
❏ Font: U See “Font Settings” on page 75
❏ Buzzer Settings: U See “Buzzer Settings” on page 76
❏ Communication I/F: U See “Communication I/F Settings” on page 77
❏ Setting Backup/Restore: U See “Setting Backup/Restore” on page 80
*1 Cannot be used on Windows 2000.
*2 If the coupon driver or Epson TM Virtual Port DriverVer.8 is not installed, this is disabled.
*3 For details, refer to the TM-T20II Utility User's Manual.
Starting the TM-T20II Utility
Starting the TM-T20II Utility
Activate the TM-T20II Utility as follows.
55
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
If you have checked Run TM-T20II Utility at Step 10 of Easy Install procedure, start from Step 2.
A
Select Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility.
B
The following screen appears. Select the printer to use and click the OK button.
If you wish to change the language that appears in the TM-T20II Utility, click the Select Language button.
If the printer is not displayed, click the Add Port button. Then go to the following section; U See “Adding a
Communication Port and Starting the TM-T20II Utility” on page 57.
Note:
❏ Click the Add Port button when you want to newly configure a port of the printer.
U See “Adding a Communication Port and Starting the TM-T20II Utility” on page 57
❏
C
To delete a port, select the port and click the Delete Port button.
The TM-T20II Utility is started. When the communication with the printer is established, the printer settings
obtained from the printer are displayed in the Printer settings screen.
To recognize the connected printer when connected via USB, run the Test Printing after running TM-T20II
Utility, or check the serial number on one of the sides of the printer and the serial number of TM-T20II Utility.
When executing TM-T20II Utility for the first time, it does not boot if the communication with the printer
cannot be established. Once the communication is established, the utility can boot using the previous printer
setting information even if it is offline.
56
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Adding a Communication Port and Starting the TM-T20II Utility
Add a communication port as follows:
A
Select Start - All Programs - EPSON - TM-T20II Software - TM-T20II Utility.
B
The following screen appears. Click the Add Port button.
57
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
The Add Port screen appears. Configure the port to be added. Then, click the OK button.
Note:
❏ If the communication with the port failed, an error message appears. In such case, you cannot add the port.
Make sure the printer is connected properly and check your communication settings.
❏
Clicking the Communication test button displays the communication result on the screen. It does not
conduct a test print.
❏ Serial
Setting
Description
Port:
Selects the serial port of the computer you use.
Search:
Searches for available serial ports.
Communication speed:
Configures the communication speed.
Parity:
Configures the parity.
Data Bit:
Configures the bit length.
Stop Bit:
Configures the stop bit.
Virtual Port Settings
Starts the Virtual Port Settings tool. For details, see the manual for the
Virtual Port Settings tool.
Communication test
Runs a communication test.
❏ Parallel
58
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Setting
Description
Port:
Selects the parallel port of the computer you use.
Search:
Searches for available parallel ports.
Virtual Port Settings
Starts the Virtual Port Settings tool. For details, see the manual for the
Virtual Port Settings tool.
Communication test
Runs a communication test.
❏ USB
Setting
Description
Port:
Selects the USB port you use.
Search
Searches for the available USB port(s).
Communication test
Runs a communication test.
Note:
If connected via USB, printers cannot be added under the environment where both Printer Class printers and
Vendor Class printers exist. In such a case, first turn off the existing printers, and then start the utility.
❏ Ethernet
Setting
Description
IP Address:
Configures the IP address of the printer you use.
Search
Searches for the TM-T20II printers on the network and displays their IP
addresses.
Advanced settings (EpsonNet Config)
Activates the EpsonNet Config. Make the network settings of the printer
using the EpsonNet Config.
Communication test
Runs a communication test.
Note:
If no TM-T20II with its IP address configured is displayed even after clicking the Search button, enter the IP
address of TM-T20II directly to IP Address:.
59
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
D
The following screen appears again. Select the added port and click the OK button.
E
The TM-T20II Utility is started.
60
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Current Settings
Allows you to check the printer settings and the maintenance counter.
Setting
Description
Storing Logos:
Displays the number of stored logos and their sizes.
Coupon Settings: *1
Displays the coupon settings.
Paper Reduction Settings:
Displays the paper reduction Enable/Disable setting.
Automatic Paper Cut Settings:
Displays the settings of the automatic paper cut function.
Printing Control Settings:
Displays the paper width and the print density settings.
Font Settings:
Displays code page of the printer font, and international character set.
Optional Buzzer Settings:
Displays the buzzer settings.
Communication I/F:
Displays the communication setting of the port.
Details
Displays information of interface, and maintenance counters.
U See “Details” on page 61
*1 If the coupon driver or Epson TM Virtual Port Driver Ver. 8 is not installed, this won't be displayed.
Details
Interface Information
Note:
When a serial connection is used, interface information does not appear; only the maintenance counter appears.
61
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
❏ USB I/F
Setting
Description
USB Device:
Displays the product name.
USB Device Version:
Displays the product version.
USB ID:
Displays the serial number.
USB Information:
Displays the character string configured to the interface for identification
purpose.
❏ Ethernet I/F
Setting
Description
Ethernet I/F:
Displays the product name.
MAC address:
Displays the MAC address setting of the interface.
Hardware version:
Displays the hardware version of the interface.
Software version:
Displays the software version of the interface.
62
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Maintenance counter
Allows you to check the following counters and to reset some of them.
The cumulative counter cannot be reset.
❏ Length of paper feed [km]
❏ Number of autocutter operations Times
Operation Check
Allows you to check the printer operation and communication between the printer and the driver.
Configure as follows.
A
Click the Operation Check menu.
63
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
B
Click the button of the item you want to check.
You can check the followings.
❏ Unit Test
Setting
Description
Communication Test
Checks if the communication between the computer and the printer is
normal.
Test Printing
Makes a test print. To see if the printer prints correctly.
Print Logo
Prints the logo stored on the printer.
Print Font
Prints the fonts installed on the printer.
Open Drawer
Opens the drawer connected to the printer.
Test Buzzer
Sounds an external optional buzzer that is connected to the printer.
❏ Driver Test
Setting
Description
Select the driver to test
Selects the driver you want to check.
Test Printing
Makes a test print. To see if the printer prints correctly.
Note:
For Windows 2000, the Test Printing is not available.
❏ Electronic Journal
Setting
Description
Enable electronic journal
Sets electronic journal Enable/Disable. (This is activated when ticked)
Open
Displays the electronic journal screen.
Storing Logos
Allows you to configure the logos to be stored on the printer.
64
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
This section describes how to configure logos to be stored on the printer. The utility allows you to print your logo
already stored on the printer, but you cannot edit and restore it as a file. When using the OPOS to store your logo, U
see “Storing Logos” on page 86.
Storing Logos has the following functions.
Setting
Description
Key Code List
Displays the logos registered in the printer and the logos to be added in the
printer. The logos registered in the printer have
at the beginning of the
Key-code.
Add
Adds logo data on the list.
Edit
Edits the halftone and brightness settings of the selected logo data.
Delete
Deletes the selected logo data from the list or deletes logos stored on the printer.
Test print
Prints the selected logos.
Change Logo Mode
Displays Select Mode for Storing Logo screen.
Key-code Management
Displays Key-code Management screen.
Preview
Displays the logo image to be stored on the printer. Logo images stored on the
printer are not displayed.
Logo Indicator
Indicator: Registerable memory size in the printer for logos
Additional logo data: Size of logos displayed on the list
Used amount: Size of registered logos
Save to File
Saves the configured logo data as a file to store it to the printer. The data can also
be stored as a bmp file.
Store to Printer
Stores the configured logo data to the printer.
65
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Select Mode for Storing Logo has the following functions. The current setting is displayed below Storing Logos.
Setting
Description
First Key-code Selection Mode
Specifies the logo identifying code.
Automatically set the key-code for the logo to be stored.
If this is turned on, automatically sets Key-codes to the logos
to be registered. If turned off, sets Key-codes when adding or
editing logos.
Advanced Printer Driver Control Font Setting Mode
The Advanced Printer Driver allows you to assign a control
font (h to l) to your logo instead of using a key code.
Key-code Nonuse Mode (not recommended)
Not recommended.
Key-code Management has the following functions. You can check the Key-code of the logo stored in the printer, or
delete the logos.
Setting
Description
Get KeyCode
Obtains registered Key-code numbers.
66
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Adding a Logo
Add a logo as follows.
A
Click the Add button.
B
Specify the image data to be used as a logo.
A file size of 2047 (W) x 831 (H) pixels (dots) or less can be specified, and the format can be bmp, jpeg, gif, or png.
If the logo width is greater than the paper width, a warning message will appear. Click the OK button and reduce
the logo size in the Logo Edit screen of step 3.
67
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
The Logo Edit screen appears. Edit the logo image while checking the image previewed on the upper portion of
the screen. When finished, click the OK button.
You can edit the followings.
D
Setting
Description
Image width
Specifies the width to which the image is resized (in mm).
Resize
Specifies whether or not the image is resized. If the image width is greater
than the paper width and resizing is not specified, the part of the image
that exceeds the paper width will be cut off.
Half toning
Configures the halftone setting of the image.
Brightness
Configures the brightness of the image.
Density
Configures the printing concentration.
If the logo mode is First Key-code Selection Mode and Automatically set the keycode for the logo to be
stored. is not turned on, the Key-code Settings screen is displayed. Set a Key-code and click the OK button.
If the logo mode other than First Key-code Selection Mode is selected or Automatically set the keycode for
the logo to be stored. is turned on, the Key-code Settings screen is not displayed.
E
The logo data is added on the list. When storing multiple logo data, repeat Step 1 through 4.
68
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
F
After storing all the logo data to be added to the printer, check the indicator on the right side of the screen to see
if the data size is acceptable to be stored on the printer, and then click the Store to Printer button.
G
The logo data is stored to the printer. The logo data are also saved in the logo store file (TLG file). This file is used
when creating the printer setting file.
Logo Store File
Because the logo store file (TLG file) is automatically saved when adding logos to the printer, the logo store file only
contains the logo data last added to the printer. When saving multiple logo data in the printer setting file, add all the
logo data to the printer altogether at once. When saving the data already stored on the printer, follow the procedure
below.
A
Prepare all the logo data to add to the printer.
B
Delete all the logo already stored on the printer.
U See “Storing Logos” on page 64
69
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
Store all the logos and add them to the printer altogether at once. In this way, the logo store file (TLG file)
containing all the logo data is created.
U See “Adding a Logo” on page 67
Paper Reduction Settings
!Caution:
The paper reduction settings may not reduce paper usage as specified when you print images such as logos or
coupon tickets, or print in page mode. The followings are examples that the paper reduction settings are not
reflected.
❏
Windows printer driver:
Printing with the settings that enable Print all text as graphic images, such as rotation setting, watermark
setting, and barcode rotation setting.*
❏
Mac printer driver:
All printing using the Mac printer driver.*
❏
Linux printer driver:
All printing from the Linux printer driver.*
❏
UPOS:
Printing in page mode, printing with rotation setting, printing with bitmap Images/Barcode/Characters
horizontally aligned, and so on.
❏
ESC/POS command:
Printing images such as logos or coupon tickets, printing in page mode, printing with rotation setting, and so
on.
* The printer drivers have a function that allows you to reduce the top and bottom margins. Use the function if you
want to save paper. For more details, see the manual of the printer driver.
Allows you to configure the paper reduction settings. Configure as follows.
A
Click the Paper Reduction menu.
70
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
B
Configure the following items referring to the preview on the right portion of the screen.
Note:
Settings other than Extra Upper Space Reduction and Extra Lower Space Reduction are disabled due to the
Advanced Printer Driver being in graphics mode.
C
Setting
Description
Extra Upper Space Reduction
Selects whether to reduce the upper margin or not. Enable this to cut out the
extra upper margin that is created before the first print data is printed.
Extra Lower Space Reduction
Selects whether to reduce the lower margin or not. Enable this to cut out the
lower margin that is created from the time the last line is printed until the paper
is automatically cut.
Line Space Reduction Rate
Selects a reduction ratio of line spacing during printing. The minimum pitch is
two dots. If reduction results in a line spacing of less than 2 dots, the line
spacing will be reset to 2 dots.
Line Feed Reduction Rate
Selects a reduction ratio of line spacing of blank lines. This setting is ignored for
the portion set to be cut out by the Extra Upper Space Reduction setting. When
you advance the paper by inserting line feeds in order to cut the paper
manually, you may not be able to advance the paper until the last line reaches
the cut position because of this reduction setting.
Barcode Height Reduction Rate
Selects a reduction ratio of barcode height. The barcode height cannot be
reduced to less than 30-dots height. This setting can cause the barcode size to
fall outside the barcode standards.
Click the Set button. The settings are reflected to the printer.
Automatic Paper Cut Settings
Allows you to configure whether to cut paper and print a logo when the cover is closed.
71
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
!Caution:
❏ If you set a logo here, the logo will be printed when you print coupons too.
❏
If you don't want to print the logo on coupons, set the logo printing during auto cut in coupon printing. (For
details, refer to the TM-T20II Utility User's Manual.)
Configure as follows.
A
Click the Automatic Paper Cut menu.
B
Click the item you want to check.
Not use this function
Disables the automatic paper cut function. Go to Step 4.
Cut paper when the cover is closed.
Executes automatic paper cut when the cover is closed. Go to Step 4.
Print logo when paper is cut.
Prints the logo when executing the automatic paper cut. Go to Step 3.
72
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
Configure the Print logo when paper is cut.
Setting
Description
Top Logo
Sets the logo that is printed at the top of the paper.
Bottom Logo
Condition
Extra Upper Space Reduction:
❏
Key-code: Selects the Key-code of the logo to be printed.
❏
Alignment: Selects the logo print position.
Sets the logo that is printed at the bottom of the paper.
❏
Key-code: Selects the Key-code of the logo to be printed.
❏
Alignment: Selects the logo print position.
Sets the condition for top logo printing.
❏
When paper is cut by command: The checkmark cannot be removed
from this checkbox.
❏
When cover is closed: Sets whether the top logo is printed when the
cover is closed.
❏
When printer is powered on: When you select this, the printer is reset
every time the printer setting is changed, paper is automatically cut
and Top Logo is printed.
Selects whether to reduce the top margin when printing the logo
configured at Top Logo. You can select this function only when Top Logo
is selected.
Selecting this may cause a white line to appear on the logo (13 mm away
from the top of the logo). Make sure to conduct a test print to see if the
print result is acceptable for you.
D
Click the Set button. The settings are reflected to the printer.
Printing Control Settings
Allows you to configure the printing control settings of the printer. Configure as follows.
73
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
A
Click the Printing Control menu.
B
Configure the following printing control items.
Setting
Description
Paper width:
Selects the paper width.
Logo 180 dpi Emulation Mode:
Enables or disables Logo 180 dpi Emulation Mode.
Logo 180 dpi Emulation Mode allows you to print logos created for 180dpi
printers on the same position and in the size when using TM-T20. However,
Storing Logos (U See “Storing Logos” on page 64), allows you to freely
adjust the size of logos when adding/editing them. So it is recommended to
use Storing Logos when adjusting the size of logos.
Print density:
Selects the print density.
Print speed:
Selects the print speed.
Power Supply Unit Capacity:
Selects the capacity level of the power supply unit connected to the printer.
!Caution:
❏ When you change the paper width
When changing the paper width from 80 mm to 58 mm, attach the Roll Paper Guide to the printer.
Changing the paper width from 58 mm to 80 mm may produce unexpected printout results. Make sure you
test print after changing the width.
❏
If a power-related trouble occurs, such as a sudden power shutoff during printing, lower the Power Supply
Unit Capacity level. If the trouble still occurs, lower the Print speed.
74
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Note:
If you make any of the following settings different from that of the printer driver, the printer driver setting is used.
C
❏
Print density
❏
Print speed
❏
Paper width
Click the Set button. The settings are reflected to the printer.
Font Settings
Allows you to configure the printer font and international character set. Configure as follows.
Note:
❏ When using the Advanced Printer Driver Ver. 5.xx, Code-page: and International character set: settings become
disabled.
❏
When using the OPOS ADK, the code page configured in OPOS becomes enabled.
A
Click the Font menu.
B
Configure the following.
Setting
Description
Code-page:
Selects the Code Page of the printer font.
International character set:
Selects an international character set.
75
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
Click the Set button. The settings are reflected to the printer.
Click the Test print button to print the configured printer font pattern.
Buzzer Settings
Allows you to configure whether an external optional buzzer is used and the buzzer pattern settings. Configure as
follows.
A
Click the Optional Buzzer menu.
B
Select whether or not the buzzer is used.
Disable Buzzer
Do not use the external buzzer. Go to step 4.
Enable Buzzer
Use the external buzzer. Go to step 3.
76
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
D
Specify when the optional buzzer sounds and the buzzer pattern.
Setting
Description
When an error occurs:
Configure the buzzer setting when an error occurs.
When automatic paper cut activates:
Configure the buzzer setting when automatic paper cutting takes place.
When specified pulse 1 (2 pin) occurs:
Configure the buzzer setting when the specified pulse is generated.
When specified pulse 2 (5 pin) occurs:
Configure the buzzer setting when the specified pulse is generated.
Buzzer:
Test the buzzer. Select a sound pattern. To test the buzzer sound, click the
Test button.
Click the Set button. The settings are reflected in the printer.
Communication I/F Settings
This utility allows you to make printer communication settings. The port setting of the computer is not made, so
making the printer settings may cause a communication error with the printer. In such case, change the printer driver
settings or any other necessary settings on the computer so that they match with the settings made on the printer.
A
Click the Communication I/F menu. The type of port currently used for communicating with the printer is
automatically detected and displayed on the Communication I/F Settings screen.
B
Make the communication settings.
Serial
Configures the serial communication. U See “Serial” on page 78
USB
Configures the USB communication. U See “USB” on page 78
Ethernet
Configures the IP address. U See “Ethernet” on page 80
77
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
C
Click the Set button. The settings are reflected to the printer.
Serial
Configures the serial communication.
Setting
Description
Communication speed:
Selects the communication speed.
Parity:
Configures the parity.
Data Bit:
Configures the data bit.
Stop Bit:
Configures the stop bit.
Flow control:
Configures the flow control.
USB
Configures the USB class.
Note:
❏ When using the UPOS or Advanced Printer Driver Ver. 3.04, select Vender Class.
❏
When you do not need to use the Printer Class, using Vender Class is recommended.
78
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
❏ Printer Class: Configures the printer to the printer class.
❏ Vender Class: Configures the printer to the vender class.
If you change the USB class from Vender Class to Printer Class, the printer becomes a Printer Class device. The
computer detects the printer as a new Printer Class device and creates a new port.
Using the newly created port, you can print but cannot use the EPSON Status API. The existing port still allows you to
both print and use the EPSON Status API, so you can delete the newly created queue and use the existing queue
instead.
How to distinguish the EPSON Status API available port
Select Properties - Ports and check the Port and Description.
❏ Printer Class
Port: USBxxx
Description: Virtual printer port for USB
❏ Vender Class
Port: ESDPRTxxx
Description: USB TM-T20II
79
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Ethernet
Starts EpsonNet Config, and configures network addresses.
Setting
Description
Advanced settings
Starts EpsonNet Config when the Advanced settings button is clicked.
Setting Backup/Restore
Allows you to save the printer settings to a file and to restore the stored settings to the printer.
80
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
!Caution:
❏ On the environment with no Advanced Printer Driver, OPOS, OPOS for .NET, or JavaPOS installed,
Automatic Restore Settings is disabled.
❏
Automatic Restore Settings cannot be saved or restored. If you want to copy coupon settings on another
printer, refer to TM-T20II Utility User's Manual.
Saving the Printer Settings to a File
Save the settings as follows:
A
Click the Backup/Restore menu.
B
Select the setting items to be saved as a file from the Option.
❏ Stored logo data: Saves the logo data stored on the printer. In this step, data is not acquired from the printer,
but the data in the logo store file (TLG file) is saved. U See “Logo Store File” on page 69
❏ Printer settings: Saves all the set values of the printer.
Paper reduction settings
Font settings (font replacement, code page, and international character set settings)
Print control settings (paper width, print speed, density, etc.)
Automatic paper cut setting
Optional buzzer settings
C
Click the Backup button. A backup confirmation message will appear. Click the Yes button.
If Stored logo data was selected in step 2.
Go to step 4.
If Stored logo data was not selected in step 2.
Go to step 5.
81
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
D
E
The Select Logo File screen appears. The most recently saved logo filename will appear. Click the OK button.
If you wish to change the file to be saved, click the Browse button.
Specify the filename and backup location in the next screen and save the file.
Restore the Settings to the Printer
Restore the settings as follows:
A
Click the Backup/Restore.
B
Click the Browse button, and specify the printer setting file to be restored.
C
Click the Restore button. A restore confirmation message will appear. Click the Yes button.
D
If the restore is successful, a success message is displayed.
82
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
Automatic Restore Settings
Configures the automatic restore settings.
Setting
Description
Automatically restore the settings
when replaced with a new printer.
To have printer settings automatically restored using the previously created
backup file when the printer fails and is replaced with a new printer.
Display confirmation message befor
executing automatic restore
To display the confirmation message asking if you want to restore the settings
before execution of automatic restoration.
Display the restoration result.
To display the success/failure result on the screen when automatic restore is
executed.
Acknowledgements
TM-T20II Utility incorporate compression code from the Info-ZIP group.
------------------------------------------------------------------------------------------This is version 2009-Jan-02 of the Info-ZIP license. The definitive version of this document should be available at
ftp://ftp.info-zip.org/pub/infozip/license.html indefinitely and a copy at http://www.info-zip.org/pub/infozip/
license.html.
Copyright (c) 1990-2009 Info-ZIP. All rights reserved.
For the purposes of this copyright and license, "Info-ZIP" is defined as the following set of individuals:
Mark Adler, John Bush, Karl Davis, Harald Denker, Jean-Michel Dubois, Jean-loup Gailly, Hunter Goatley, Ed
Gordon, Ian Gorman, Chris Herborth, Dirk Haase, Greg Hartwig, Robert Heath, Jonathan Hudson, Paul Kienitz,
David Kirschbaum, Johnny Lee, Onno van der Linden, Igor Mandrichenko, Steve P. Miller, Sergio Monesi, Keith
Owens, George Petrov, Greg Roelofs, Kai Uwe Rommel, Steve Salisbury, Dave Smith, Steven M. Schweda, Christian
Spieler, Cosmin Truta, Antoine Verheijen, Paul von Behren, Rich Wales, Mike White.
83
TM-T20II Software Installer
Software User's Manual
TM-T20II Utility
This software is provided "as is," without warranty of any kind, express or implied. In no event shall Info-ZIP or its
contributors be held liable for any direct, indirect, incidental, special or consequential damages arising out of the use of
or inability to use this software.
Permission is granted to anyone to use this software for any purpose, including commercial applications, and to alter it
and redistribute it freely, subject to the above disclaimer and the following restrictions:
1.
Redistributions of source code (in whole or in part) must retain the above copyright notice, definition,
disclaimer, and this list of conditions.
2.
Redistributions in binary form (compiled executables and libraries) must reproduce the above copyright notice,
definition, disclaimer, and this list of conditions in documentation and/or other materials provided with the
distribution. Additional documentation is not needed for executables where a command line license option
provides these and a note regarding this option is in the executable's startup banner. The sole exception to this
condition is redistribution of a standard UnZipSFX binary (including SFXWiz) as part of a self-extracting
archive; that is permitted without inclusion of this license, as long as the normal SFX banner has not been
removed from the binary or disabled.
3.
Altered versions--including, but not limited to, ports to new operating systems, existing ports with new
graphical interfaces, versions with modified or added functionality, and dynamic, shared, or static library
versions not from Info-ZIP--must be plainly marked as such and must not be misrepresented as being the
original source or, if binaries, compiled from the original source. Such altered versions also must not be
misrepresented as being Info-ZIP releases--including, but not limited to, labeling of the altered versions with the
names "Info-ZIP" (or any variation thereof, including, but not limited to, different capitalizations), "Pocket
UnZip," "WiZ" or "MacZip" without the explicit permission of Info-ZIP. Such altered versions are further
prohibited from misrepresentative use of the Zip-Bugs or Info-ZIP e-mail addresses or the Info-ZIP URL(s),
such as to imply Info-ZIP will provide support for the altered versions.
4.
Info-ZIP retains the right to use the names "Info-ZIP," "Zip," "UnZip," "UnZipSFX," "WiZ," "Pocket
UnZip," "Pocket Zip," and "MacZip" for its own source and binary releases.
84
TM-T20II Software Installer
Software User's Manual
Application Development Information
Application Development Information
This chapter explains how to control this printer and gives information useful for printer application development.
How to Control the Printer
The printer is controlled by the drivers or ESC/POS commands.
Driver
Printer Driver
This is an Windows driver (APD = EPSON Advanced Printer Driver) which allows you to control POS operations,
such as printing logos and barcodes, controlling paper cutting function and cash drawer. See this manual for more
details about the printer driver. The driver includes Status API which allows you to monitor the printer status, and to
send the ESC/POS commands.
See the following manuals and sample programs provided with EPSON Advanced Printer Driver Ver.5 for further
details on using the driver and how to develop an application using the Status API functions.
❏ Install Manual
❏ Printer Manual
❏ Printer Specification for TM-T20II
❏ Status API Manual
UPOS
This stands for Unified Point of Service. It is the standard specification of POS market, which defines drivers for
controlling POS peripheral devices in various operation environments. Using the driver, you can develop POS system
efficiently because you do not need to newly create commands. The following TM-T20II drivers that conform to
UPOS are provided. Use one of them in accordance with your system environment.
❏ EPSON OPOS ADK
Suitable for an application that operates the printer under 32-bit version of Windows.
❏ EPSON OPOS ADK for .NET
Suitable for an application that operates the printer under Windows .NET environment.
❏ EPSON JavaPOS ADK for Windows
Suitable for an application that operates the printer under Windows Java environment.
See the following document for the information about how to create an environment and develop an application.
EPSON OPOS ADK
❏ OPOS Installation Manual
85
TM-T20II Software Installer
Software User's Manual
Application Development Information
❏ User's Manual
❏ Application Development Guide
❏ UnifiedPOS Retail Peripheral Architecture*
❏ Sample Program Guide
EPSON OPOS ADK for .NET
❏ OPOS ADK for .NET Installation Guide
❏ UnifiedPOS Retail Peripheral Architecture*
❏ User's Reference (SetupPOS)
❏ Application Development Guide (POSPrinter TM-T20II)
EPSON JavaPOS ADK for Windows
❏ JavaPOS ADK Installation Guide
* This guide describes general information on how to control printers using the OPOS ADK (in the chapter POS
Printer and Appendix-A). It does not describe Epson's specific functions.
ESC/POS Commands
The ESC/POS command is the printer command system developed by EPSON. This allows you to directly control the
all functions of the printer. Using the commands with the driver, you can use a function that is not provided by the
driver.
Compared to using the drivers, using the commands is difficult because you need to have knowledge about the detailed
printer specifications and how to combine the commands.
Refer to the ESC/POS Quick Reference for a simple explanation of the ESC/POS command. A detailed explanation of
the ESC/POS command is included in the ESC/POS Application Programming Guide. You can obtain this guide by
signing a non-disclosure agreement with Epson.
Storing Logos
!Caution:
❏ You cannot store UPOS SetBitmap logos and logos configured using TM-T20II Utility in the same printer.
❏
When a SetBitmap logo is stored, it overwrites and deletes an existing TM-T20II Utility logo.
The procedure to store logos differs by your system configuration as follows.
❏ When using the Advanced Printer Driver only
Use TM-T20II Utility to store logos.
❏ When using the OPOS and Advanced Printer Driver on the same system
86
TM-T20II Software Installer
Software User's Manual
Application Development Information
❏ OPOS setting
Using the OPOS SetupPOS, select Bitmap tab on the Device Specific Settings screen, and uncheck the
checkbox for NVRAM.
❏ Storing logos in the printer
Use TM-T20II Utility to store logos in the printer.
Download
Drivers, utilities, and manuals can be downloaded from one of the following URLs.
For customers in North America, go to the following web site:
http://www.epsonexpert.com/
For customers in other countries, go to the following web site:
https://download.epson-biz.com/?service=pos
Select the product name from the "Select any product" pulldown menu.
87
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
