DU 1000
2621 Ridgepoint Drive, Suite 235 Austin, TX 78754
800.866.6506
www.ikey.com
DU-1000
Keyboard with Polycarbonate Case
The DU-1000 features the convenience of a full numeric keypad and a lightweight
polycarbonate case. Suitable for 19-inch rack applications, the DU-1000 offers
104-key functionality and USB compatibility. It has 12 function keys as well as
mounting holes in case.
Technical Specifications
Certifications
NEMA 4X UL60950, FCC Part 15 Class B
Shock
3x11 ms pulses of 50g on each of 3 axes
Cable
LENGTH: 10 feet (3 meters) DESIGN: PS/2 or Single-Cable USB
Key Switch
MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 6.35
oz. +/- 1.06 oz. (180g +/- 30g) FEEDBACK: Tactile with mechanical snap
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3
hours
Power
PS/2 or AT/Serial: [email protected] (from Keyboard port) USB: [email protected] (from CPU port)
Flammability
PRINTED CIRCUIT BOARD: 94 VO SILICONE OVERLAY: 94 HB INTERFACE CABLE: 94 VO
Compatability
PS/2: All Windows Operating Systems USB: All Windows and Macintosh OS
Temperature Range
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Weight
2.25 lbs +/- 0.10 lbs (1.02 kg +/- 0.05 kg)
Warranty
1 year limited warranty
Humidity
100%
Dimensions
14.94" x 6.63" x 1.81" (w-h-d) 379.5mm x 168.4mm x 45.9mm
Model Numbers
Features and Benefits
10-Key Numeric Pad
104-Key Functionality
Polycarbonate Case with Mounting Holes
PS/2 or USB configurations available
©2011 iKey, Ltd. All rights reserved. 2621 Ridgepoint Drive Suite 235 Austin, TX 78754 1-800- 866-6506
