SYSTEM FOR LAYING
FLOOR AND WALL COVERINGS
TECHNOLOGY FOR AESTHETICS
Catalogue 2015
2
10
36
46
68
INDEX
2
4
6
8
Adhesives, an essential part of our system
System for laying floor and wall coverings: certified quality
History speaks for us
Four fields of application, for a unique system
SUBSTRATE PREPARATION
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
ST 444
CALCESTRUZZO CELLULARE
SILENS STA 10
SILENS SLE 23
SA 500
E 439
SC 420 - SC 420 P
LEGEO MIX
FASSACEM
SV 472
SV 472 P
SR 450
SL 416
SM 485
PRIMER DG 74
PRIMERTEK 101
PRO-MST
REPAR MST SE 477
GAPER 3.30
LEVEL 30
FASSA REMOVE
FIBER MST 20
CR 90
WATERPROOFERS
38
39
40
41
42
43
44
45
AQUAZIP GE 97
AQUAZIP ADV
AQUAZIP ONE
AQUAZIP RDY
AQUAZIP HIBRIDO
FASSABLOCK
MO 660
ACCESSORIES FOR WATERPROOFERS
ADHESIVES
48
AD 8
49
ADYS
50
AP 71 FLEX
51
AZ 59 FLEX
52
AT 99 MAXYFLEX
53
AQ 60 STONE
54
FASSATECH 2
55
SPECIAL ONE
56CRISTAL-TECH
57
A 81
58
FASSAFIX 1000
59
FASSAFIX
60
AX 91
61
LATEX DE 80
62
ADYWOOD 2K
63
ADYWOOD MS
64
ADYTEX 2K
65
ADYTEX RS
66
PRIMER ADW - DILUENTE ADW
67
ACCESSORIES FOR ADHESIVES
GROUTING
70
FC 830 GF 0-4
72
FC 869 GM 2-10
74
FC 854 GG 4-15
76
FC 872 GM 2-20
78
LATEX DR 843
79
FASSA CLEAN D 91
80
BLUCOLORS
82
GLITTER LUXOR FOR BLUCOLORS
83
BLUCOLORS ZERO
84
FE 838
86DETERPOXY
88
FASSASIL NTR
89
SYLAN 290
90
ACCESSORIES FOR GROUTING
93
ALPHABETICAL INDEX
2
ADHESIVES,
AN ESSENTIAL
PART OF OUR
SYSTEM
2
3
Fassa Bortolo has always had a mission: create quality for the
construction industry. We do this by using the best materials,
developing innovative solutions through research, constantly expanding the range of our products. Always with particular attention to respect for the environment, for humankind and eco-sustainability. These aspects have always characterised the Fassa
Bortolo approach. In fact, the company is a partner of GBC Italia
(Green Building Council) and has established an important partnership with CasaClima.
Even the System for Laying Floor and Wall Coverings naturally
meets all these requirements, offering building professionals a
wide range of solutions for substrates, adhesives, waterproofing,
grouts. To always ensure the job is done with the best working
standards.
SYSTEM FOR LAYING
FLOOR AND WALL
COVERINGS:
CERTIFIED QUALITY
4
5
The products of this system conform to the stringent green housing certification criteria of the LEED® (Leadership in Energy and Environmental
Design) standard, which certifies environmentally sustainable buildings
both in terms of energy consumption and the use of environmental resources involved in the production process. The distinctive feature of this
standard is that it covers all aspects involving the design of buildings,
including the choice of the relevant site, building site management, responsible use of potable water, efficiency of the shell and facilities, the
use of renewable energy sources, the use of materials with recycled
components, and the quality and comfort of the indoor environment.
The adhesives of the laying system have obtained the prestigious GEV
EMICODE certification, a voluntary mark relative to emissions of volatile
and semi-volatile organic compounds (VOC and SVOC) issued by GEV
(Gemeinschaft Emissionskontrollierte Verlegewerkstoffe, Klebstoffe und
Bauprodukte). AD 8, A 81, ADYS, AP 71 FLEX, AZ 59 FLEX, AT 99
MAXYFLEX, AQ 60 STONE and SPECIAL ONE have obtained the GEV
EMICODE EC 1Plus classification, which certifies the ultra-low emissions
of volatile organic compounds (VOC).
Moreover, AT 99 MAXYFLEX and AD 8 are the first adhesives from our
System for Laying Floor and Wall Coverings to earn the prestigious certification “Certifié CSTB Certified”, a voluntary certification based
on the NF EN 12004 European standard, which certifies the Performance classification of tile adhesives and the fulfilment and application of a
production control system which allows to ensure the constant quality
of the products.
HISTORY
SPEAKS FOR US
6
12 production sites
3 sales office in Italy
1 production site in Portugal
3 sales office in Switzerland
1 sales office in France
1 sales office in Spain
1 sales office in
the United Kingdom
Production
facilities
Sales offices
7
The credibility of a company is built year after year, through the quality
of its work and enhancing the skills and passion of our employees. History speaks for us: for over 300 years Fassa Bortolo has been a well
known presence in the construction sector, with a leading role that we
have gained in the premixed plaster market in Italy.
And with a full range of solutions for the construction industry, 12 production facilities in Italy and 1 in Portugal, 3 sales offices in Italy, 3 in
Switzerland, 1 in France, 1 in Spain and 1 in the United Kingdom. Thanks
to the presence of production plants and sales branches located throughout the territory, in Italy it is possible to obtain locally manufactured
products, which helps to cut transport-related pollution by reducing the
amount of exhaust gases and tyre rubber in the environment.
To continue to offer the construction sector the superior quality that we
are known for, evolving products and services.
FOUR FIELDS
OF APPLICATION,
FOR A UNIQUE
SYSTEM
8
9
The System for Laying Floor and Wall Coverings addresses and
solves all the possible applications, with products of excellent
quality, selected and tested in the Fassa Bortolo Research Centre
to offer installers the best solution, from substrate preparation to
waterproofing, from adhesives to grouts.
10
SUBSTRATE PREPARATION
36
WATERPROOFERS
46
ADHESIVES
68
GROUTING
SUBSTRATE PREPARATION
10
A good preparation of the
substrate is essential to achieve
an excellent result when
installing the coverings, both
technically and aesthetically.
The substrate must have the
right mechanical strength and
must be made with antishrinkage
technology, to prevent
detachments, imperfections and
ensure durability over time.
11
Standard EN 13813
Defines the requirements for screed materials used in the construction
of indoor floors. It is a European standard, which classifies screeds in
relation to the binder used:
CT = cementitious screeds
C = compressive strength after 28 days
F = flexural strength after 28 days
page
Product Reference classes
12
ST 444
13
CALCESTRUZZO CELLULARE
14 SILENS STA 10
15 SILENS SLE 23
16SA 500CT-C20-F5
17E 439CA-C30-F7
18
SC 420 - SC 420 P
CT-C25-F5
19LEGEO MIXCT-C12-F3
20 FASSACEM
21 SV 472CT-C25-F6
22
SV 472 P
CT-C25-F6
23 SR 450CT-C25-F7
24 SL 416CT-C30-F7
25
SM 485CT-C25-F7
26 PRIMER DG 74
27 PRIMERTEK 101
28
PRO-MST
29 REPAR-MST SE 477
30 GAPER 3.30
31
LEVEL 30
32 FASSA-REMOVE
33 FIBER MST 20
34 CR 90
COLOUR
12
Lightweight filling underlay for
indoors based on selected
cement and polystyrene beads
measuring under 5 mm with
both thermal insulating and
noise reduction properties.
ST 444
FIELD OF APPLICATION:
Realisation of lightweight
filling underlays. Thanks to the
particular composition and
size of the polystyrene beads
it is ideal for the creation of
lightweight filling substrates
and helps to reduce noise
transmission.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: light grey and grainy
Storage: 12 months in a dry place
Consumption: 1 bag/m2 for 40 mm thickness
Thermal conductivity coeff. λ: 0.09 W/mK
TECHNICAL SPECIFICATIONS
Achievable thickness: 4-20 cm
Compressive strength after 28 days: ≥ 0.5 N/mm2
CODE
COLOUR
PACK
PACKS/PALLET
692
light grey
50 l
40
COLOUR
Cement-based lightweight
underlay made up of a special
cement binder (premixed
powder based on Portland
cement) supplied in silos, and
a liquid additive based on
natural surfactants. Its special
preparation technique ensures
production continuity, constant
dosage of components, speed
and high productivity.
CALCESTRUZZO CELLULARE
FIELD OF APPLICATION:
CALCESTRUZZO CELLULARE
(foamed concrete) is used as
an intermediate layer between
the floor and final screed to
create surfaces with low static
load and for enhancing the
thermal insulation properties.
The product is obtained by
mixing the 2 components with
the MC2 FASSA machine.
13
Dosage of CEMENTITIOUS BINDER: approx. 330 kg/m3 *
Dosage of ADDITIVE FOR FOAMED CONCRETE: approx. 2 l/m3
Storage: CEMENTITIOUS BINDER can be stored for at least 12 months;
ADDITIVE FOR FOAMED CONCRETE can be stored for at least 12 months
away from freezing
Thermal conductivity coefficient λ (EN 1745): 0.1 W/mK (tabulated value)
* Variations of up to 10% in the binder dosage do not determine changes in the technical specifications of the
hardened product.
TECHNICAL SPECIFICATIONS
Application thickness: 5-20 cm
Compressive strength after 28 days: approx. 1 N/mm2
CODE
PACK
693
25 kg
32 packs/pallet
Additive
694
940
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
1,000 kg tank
Cementitious binder
Loose
Acoustic insulation sheets
for impact noise. Chemically
cross linked polyethylene foam
with closed cells coupled with
polyester fibre non-woven fabric.
Impact noise reduction by 21 dB in compliance
with Standard EN-ISO 140-8:1999 and EN-ISO
717-2:2007 with 10.65 m2 normalised sample
14
SILENS STA 10
FIELD OF APPLICATION:
Impact sound insulation of
floors in compliance with the
provisions of Prime Ministerial
Decree 05.12.97, by creating
a floating screed for laying
coverings such as ceramics,
wood, stone, resilient and
textile material.
A floating screed, if made
properly, allows to isolate the
upper structure of the slab
(the one that suffers impact)
from the other structures of
the building, thus reducing the
transmission of vibrations to it.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Total nominal thickness: 10 mm
Noise reduction: 21dB (certified)
Thermal conductivity coeff. λ: 0.0367 W/mK
CODE
PACK
545410
25x1.5 m rolls
COMPLEMENTARY ACCESSORIES
CODE
SILENS
GP1
545430
PACK
“L” shaped
preformed
perimeter joint
CODE
SILENS
NA1
545420
50 m
rolls
PACK
acoustic
adhesive tape
50 m
rolls
Acoustic insulation sheets
for impact noise. Flame
retardant closed cell expanded
polystyrene (EPS) sheet, water
vapour sintered and elasticised
to comply with soundproofing
material requirements.
Impact noise reduction by 24 dB in compliance
with Standard EN-ISO 140-8:1999 and EN-ISO
717-2:2007 with 10.65 m2 normalised sample
SILENS SLE 23
FIELD OF APPLICATION:
Impact sound insulation of
floors in compliance with the
provisions of Prime Ministerial
Decree 05.12.97, by creating
a floating screed for laying
coverings such as ceramics,
wood, stone, resilient and
textile material.
A floating screed, if made
properly, allows to isolate the
upper structure of the slab
(the one that suffers impact)
from the other structures of
the building, thus reducing the
transmission of vibrations to
it. SILENS SLE 23 has been
designed to provide impact
noise reduction and thermal
insulation in a single step.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
15
Total nominal thickness: 23 mm
Fire resistance (EN 13501): class E
Noise reduction: 24 dB (certified)
Thermal conductivity coeff. λ: 0.040 W/mK
CODE
PACK
545440
sheets 100x50x23 mm
COMPLEMENTARY ACCESSORIES
CODE
SILENS
GP1
545430
PACK
“L” shaped
preformed
perimeter joint
CODE
SILENS
NA1
545420
50 m
rolls
PACK
acoustic
adhesive tape
50 m
rolls
COLOUR
16
The SA 500 liquid screed is a
dry premixed product made
up of specific cementitious
binders, graded sands and
special additives for improving
workability and optimising the
levelling characteristics.
Its formulation ensures quicker
drying times compared to
those obtained with traditional
cementitious screeds.
SA 500
FIELD OF APPLICATION:
SA 500 can be used for creating
unbonded or floating screeds to
be subsequently covered with
ceramic, stone, wooden or resilient
flooring suitable for indoor use in
residential applications and the
tertiary sector.
The product’s fluidity makes it
particularly suitable for creating
screeds on underfloor heating/
cooling systems and screeds to be
subsequently laid with coverings
requiring extremely levelled-out
surfaces (resilient flooring, laminate
flooring, thin porcelain gres,
pre-finished parquet flooring, etc.).
The maximum surface of around
40 m2 can be created without
divisions.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey powder
Storage: 6 months in a dry place
Consumption: approx. 18 kg/m2 for 10 mm thickness
TECHNICAL SPECIFICATIONS
Application thickness: 3-6 cm
Density: 2,100 kg/m3
Compressive strength: 20 N/mm2
Walkability: approx. 24 hours
CODE
PACK
690T
30 kg
48 packs/pallet
690
Loose
COLOUR
The E 439 liquid screed is a
dry premixed product made up
of anhydrite (CaSO4), graded
sands and special additives
for improving workability
and optimising the levelling
characteristics.
E 439
FIELD OF APPLICATION:
The product can be used for
creating unbonded or floating
screeds to be subsequently
covered with ceramic, stone
and wooden or resilient flooring
suitable for indoor use in
residential applications and the
tertiary sector.
Ideal for creating screeds
characterised by dimensional
stability, as the product does
not shrink during the curing
phase.
Particularly suitable for large
surfaces without divisions (up
to 900 m2) and for creating
screeds over large surfaces,
as fewer expansion joints are
required (up to 300 m2 on
underfloor heating).
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
17
Appearance: grey powder
Storage: 6 months in a dry place
Consumption: approx. 18 kg/m2 for 10 mm thickness
TECHNICAL SPECIFICATIONS
Application thickness: 3.5–7.5 cm
Density: 2,100 kg/m3
Thermal expansion: 0.01 mm/mK
Resistance to bending: 7 N/mm2
Compressive strength: 30 N/mm2
CODE
PACK
687T
30 kg
48 packs/pallet
687
Loose
COLOUR
Traditional ready-to-use and
normal-setting premixed
screeds for indoor and outdoor
applications. Suitable for laying
ceramic, wood and other types
of flooring. The products are
fluidified and are thus highly
workable while guaranteeing an
excellent finish.
The products conform to the
UNI EN 13813 CT-C25-F5 standard.
18
SC 420 - SC 420 P
FIELD OF APPLICATION:
Substrate screeds used as
underlays for wooden, vinyl,
linoleum, carpeted and ceramic
flooring.
Creation of 3.5 cm thick
floating screeds and 2 cm
thick bonded screeds; ideal for
patching and makeovers.
Available in the normal version
(SC 420) or pumpable version
(SC 420P).
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grainy and grey
Storage: 12 months in a dry place
Consumption: 19 kg/m2 per cm of thickness
Thermal conductivity coefficient λ: 1.31 W/mK - test report n° 182296
available; certificate kept at the Istituto Giordano
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days: approx. 25 N/mm2
Working time: approx. 60 min at +20°C
CODE
COLOUR
PACK
PACKS/PALLET
683
grey
30 kg
48
685
pumpable version
grey
30 kg
48
688
pumpable version
grey
Loose
COLOUR
Ready-to-use cementitious
screed, lightweight and
insulating, made of lightweight
expanded glass aggregates,
for laying of ceramic, stone
materials, various types of
mosaics and wooden, linoleum,
vinyl and carpeted floors.
For indoor and outdoor
applications.
LEGEO MIX
FIELD OF APPLICATION:
Realisation of 5 cm thick
floating screeds and 3.5 cm
thick bonded screeds; ideal
for screed patching and
makeovers whenever excessive
weight on the structure must
be avoided.
Allows for applying ceramic
tiles after roughly 10 days.
When applying LEGEO MIX
on soundproofing materials,
the screed thickness must
be sized according to the
compressibility and thickness
of the insulating material used,
starting from 6 cm.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
19
Appearance: grainy and grey
Storage: 12 months in a dry place
Consumption: 1 sack roughly every 2 m2 for each cm of thickness,
corresponding to roughly 12 kg/m2 for each cm of thickness
Thermal conductivity coefficient λ : 0.35 W/mK (tabulated value)
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days (EN 13318*): approx. 15 N/mm2
Working time: 60 min
CODE
COLOUR
PACK
PACKS/PALLET
674
grey
25 kg
50
* The mechanical strength values are obtained by mixing the material with the amount of water
needed to achieve a mix having a “moist soil” consistency, by using a hammer to mechanically
compact the various layers of material on 4x4x16 cm prisms. The mechanical strength values
obtained on-site largely depend on the material actual degree of compactness.
COLOUR
20
Special hydraulic binder for the
realisation of screeds, quick
drying and controlled shrinkage
for indoors and outdoors.
Suitable for laying ceramics,
wood, vinyl, carpets, linoleum.
The product mixed with sand
with grain size 0-8 mm, is very
workable and gives an excellent
finish.
FASSACEM
FIELD OF APPLICATION:
Realisation of 3.5 cm
floating screeds, 2
cm bonded screeds;
particularly suitable for
high traffic environments.
Indicated for heated
screeds thanks to
excellent thermal
conductivity, patching
and relaying of screeds.
Installation of ceramic
floors can take place after
48 hours, the installation
of wooden floors after 10
days, the installation of
natural stone after 4 days.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey powder
Storage: 12 months in a dry place
Consumption: 2-3 kg/m2 per cm of thickness
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days: approx. 35 MPa
Working time: 60 min
Walkability: after 12 hours
CODE
COLOUR
PACK
PACKS/PALLET
945
grey
25 kg
48
COLOUR
Mixed mortar made with
special binders, selected
sands and additives for the
construction of quick drying
shrinkage-controlled floor
screeds, both indoors and
outdoors. Suitable for the
installation of ceramics, wood,
vinyl, carpets, linoleum.
Mixed mortar, classified as CT-C25-F6
in compliance with standard EN 13813
SV 472
FIELD OF APPLICATION:
Realisation of 3.5 cm floating
screeds and 2 cm bonded
screeds, particularly suitable
for high traffic environments,
patching and relaying of
screeds. Particularly suitable
for heated screeds thanks to
excellent thermal conductivity
and as a support for the
AQUAZIP® System. Ceramic
floors can be installed after 48
hours, wooden floors can be
installed after 10 days, natural
stone can be installed after 6
days.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
21
Appearance: grey and grainy
Storage: 12 months
Consumption: 19 kg/m2 for 10 mm of thickness
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days: 30 N/mm2
Working time: 60 min
Walkability: after 12 hours
CODE
COLOUR
PACK
PACKS/PALLET
682T
grey
30 kg
48
COLOUR
Pumpable premixed mortar
made with special binders,
selected sands and additives
specific for the construction
of quick drying shrinkagecontrolled floor screeds, both
indoors and outdoors. Suitable
for the installation of ceramics,
wood, vinyl, carpets, linoleum.
Fluidified product offering
excellent workability and finish.
Mixed mortar, classified as CT-C25-F6
in compliance with standard EN 13813
22
SV 472 P
FIELD OF APPLICATION:
Realisation of 3.5 cm floating
screeds and 2 cm bonded
screeds, particularly suitable
for high traffic environments,
patching and relaying of
screeds. Particularly suitable
for heated screeds thanks to
excellent thermal conductivity
and as a support for the
AQUAZIP® System. Ceramic
floors can be installed after 48
hours, wooden floors can be
installed after 10 days, natural
stone can be installed after 6
days.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey and grainy
Storage: 12 months
Consumption: 19 kg/m2 per 10 mm of thickness
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days: 30 N/mm2
Working time: 60 min
Walkability: after 12 hours
CODE
COLOUR
PACK
PACKS/PALLET
679
grey
30 kg
48
678
grey
Loose
COLOUR
Mixed mortar made with selected
sands, special binders and specific
additives for the construction of
screeds, featuring quick drying and
controlled shrinkage, for indoors.
Suitable for the installation of
ceramics, wood, vinyl, carpets,
linoleum.
Mixed mortar, classified as CT-C25-F7
in compliance with standard EN 13813
SR 450
FIELD OF APPLICATION:
Realisation of 3.5 cm
minimum floating screeds
and 2 cm minimum bonded
screeds. Particularly suitable
for high traffic environments
and for heated screeds
thanks to excellent thermal
conductivity.
Suitable for patching
and relaying of screeds,
installation of ceramic floors
(after 4 hours), installation
of wooden floors, linoleum.
For natural and artificial
stone sensitive to moisture,
PVC, installation can take
place after 24 hours (residual
moisture less than 2%), for
natural stone after 4 days.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
23
Appearance: grey and grainy
Storage: 12 months in a dry place
Consumption: 19 kg/m2 per cm of thickness
TECHNICAL SPECIFICATIONS
Compressive strength after 28 days: 25 N/mm2
Working time: 30 min
Walkability: after 3-4 hours
CODE
COLOUR
PACK
PACKS/PALLET
688K
grey
30 kg
48
COLOUR
Fast-setting, high performance,
self-levelling underlayment
for rectifying floors indoors
between 1 and 10 mm.
The product has an excellent
adhesive ability and, once
hardened, has a very smooth
surface.
Classified as CT-C30-F7
in compliance with standard EN 13813
24
SL 416
FIELD OF APPLICATION:
Realisation of 1-10 mm
selflevelling underlayments
in indoor industrial or civilian
environments that will then
be covered with ceramics,
parquet, resilient materials or
industrial floor paints after 12
hours. Indicated for high traffic
environments and even on
heating screeds.
SUBSTRATES:
Cement screeds in general,
very absorbent cement screeds
or anhydrite screeds after
using PRIMER DG 74; concrete
floors if powertrowelled and on
existing floors after application
of PRIMERTEK 101.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: fine grey powder
Storage: 12 months in a dry place
Consumption: 1.6 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Working time: 30 min
Compressive strength after 24 hours: 12 N/mm2
Compressive strength after 28 days: 31 N/mm2
Walkability: after 3 hours
CODE
COLOUR
PACK
PACKS/PALLET
896K
grey
25 kg
48
COLOUR
Fast-setting, high-performance,
self-levelling underlayment for
rectifying floors indoors between
3 and 30 mm.
The product has an excellent
adhesive ability and, once
hardened, has a smooth
surface.
Classified as CT-C25-F7
in compliance with standard EN 13813
SM 485
FIELD OF APPLICATION:
Realisation of 3-30 mm
self-levelling underlayments
in indoor industrial or civilian
environments that will then
be covered with ceramics,
parquet, resilient materials or
industrial floor paints after 24
hours. Indicated for high traffic
environments and even on
heating screeds.
SUBSTRATES:
Cement screeds in general,
very absorbent cement screeds
or anhydrite screeds after
using PRIMER DG 74; concrete
floors if powertrowelled and on
existing floors after application
of PRIMERTEK 101.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
25
Appearance: fine grey powder
Storage: 12 months in a dry place
Consumption: 1.7 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Working time: 30 min
Compressive strength after 24 hours: 12 N/mm2
Compressive strength after 28 days: 28 N/mm2
Walkability: after 3 hours
CODE
COLOUR
PACK
PACKS/PALLET
897K
grey
25 kg
48
COLOUR
Water-based synthetic resin
primer that ensure good
penetration on absorbent
surfaces, specific for gypsum,
anhydrite, plasterboard. The
product has binding and
film forming properties that
determine a high consolidating
and waterproofing power of the
surface on which it is applied.
26
PRIMER DG 74
FIELD OF APPLICATION:
Treatment of gypsum-based
substrates or GYPSOTECH®
plasterboards before using
cementitious adhesives,
treatment of very absorbent
substrates before applying
adhesives, levelling mortars or
selflevelling cement screeds.
SUBSTRATES:
Gypsum-based substrates or
GYPSOTECH® plasterboards,
anhydrite screeds before laying
ceramic or stone, cementbased substrates, cement lime
based substrates.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: low viscosity white liquid
Storage: 12 months in a dry place
Consumption: approx. 100-200 g/m2
TECHNICAL SPECIFICATIONS
Drying time: 2 hours
CODE
COLOUR
PACK
PACKS/PALLET
765K
white
5 kg
40
764K
white
20 kg
33
COLOUR
One component multi-purpose
and acrylic resins bonding
promoting primer, with siliceous
aggregates for indoors and
outdoors. Excellent on any
surface to improve adhesion of
cement based products whether
they are adhesives, levelling
mortars or plasters.
PRIMERTEK 101
DOMAINE
FIELD
OF APPLICATION:
D'UTILISATION :
Treatment of absorbent or
non-absorbent substrates
before laying adhesives
or levelling mortars, on
walls or floors. Essential
before laying self-levelling
compounds on
non-absorbent substrates.
SUBSTRATES:
Absorbent cement, lime, or
gypsum substrates,
non-absorbent substrates
such as old ceramic, marble
conglomerates, natural stone,
Venetian floors; substrates such
as power-trowelled concrete,
bricks, vibration-compressed
concrete, lightweight blocks.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
27
Appearance: grey liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: approx. 200-300 g/m2
TECHNICAL SPECIFICATIONS
Waiting time before applying plaster or skim coat: 15-30 minutes depending on
environmental conditions
CODE
COLOUR
PACK
PACKS/PALLET
646
grey
10 kg
48
Consolidant for screeds and
cement based mortars in the
form of an aqueous dispersion,
with excellent penetration
power.
28
PRO-MST
FIELD OF APPLICATION:
Consolidating treatment
of substrates based on
cement or lime/cement,
especially recommended
for crumbling substrates
caused by too rapid drying
and consequent lack of
hydration of the cement.
Ideal against dusting for
cement surfaces.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: low viscosity transparent liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 400-1,000 g/m2 depending on the substrate absorption
TECHNICAL SPECIFICATIONS
Waiting time before recoatability: 24 hours after complete drying
pH: approx. 11-12
CODE
COLOUR
PACK
PACKS/PALLET
884K
transparent
25 Kg
20
COLOUR
Two-component epoxy
adhesive for monolithic
sealing of cracks or cold
joints in cement and
anhydrite screeds.
REPAR-MST SE 477
FIELD OF APPLICATION:
Repair of cracks formed
during the curing process
of traditional or concrete
subfloors, bonding layer on
smooth surfaces for levelling
mortars, bonding of “fresh”
concrete to “old” concrete.
Appearance: comp A: light grey; comp B: liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: for cold joints 0.5-1.8 kg/dm3; with brush 150-200 g/m2
TECHNICAL SPECIFICATIONS
Working time: 50-70 minutes depending on temperature
CODE
SUBSTRATES:
Concrete, anhydride screeds
cement screeds, gauged
mortars, wood, ceramic
floors.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
29
879K
COLOUR
PACK
grey
1.7 kg comp. A
0.3 kg comp. B
COLOUR
Thixotropic, fibre-reinforced,
anti-shrinkage, semi-fast
setting cementitious, technical
mortar for levelling substrates
indoor and outdoor on walls or
floors for thickness from 3 to
30 mm.
Mortar classified as R2-PCC
in compliance with standard EN 1504-3
and GP-CSIV-W1 in compliance with
standard EN 998-1
30
GAPER 3.30
FIELD OF APPLICATION:
Levelling mortar for civilian
or industrial environments
for thickness from 3 to 30
mm to be covered with
ceramic tiles or natural
stone after 12 to 24 hours
depending on temperature
and thickness. For levelling
or repairing concrete
surfaces also in pools
before laying ceramic
tiles. Reconstruction of
balcony fronts, eaves and/
or restoration of columns
or concrete steps with
thickness from 3 to 30 mm.
Resistant to weather, even
severe.
SUBSTRATES:
Concrete plasters, gauged
mortar, masonries made of
bricks or concrete.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey or white powder
Storage: 12 months in a dry place
Consumption: 1.3 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Setting time: approx. 5 hours
Compressive strength after 28 days: 17 N/mm2
CODE
COLOUR
PACK
PACKS/PALLET
570
grey
25 kg
48
571
white
25 kg
48
COLOUR
Cementitious, thixotropic,
normal-setting levelling
mortar for evening underlays
both indoors and outdoors,
on walls and floors. For
thicknesses ranging between
2 mm and 30 mm.
Conforms to the EN 998-1
GP-CSIV-W1 standard.
LEVEL 30
FIELD OF APPLICATION:
Evening of walls prior to laying
of ceramic tiles and evening of
concrete surfaces (including
pools) prior to the laying of
coverings or waterproofing or
paint treatments.
SUBSTRATES:
Cement-based plaster,
mixed mortar, brick masonry,
concrete, materials such as
Eraclit, gypsum-based plaster
prior the application of PRIMER
DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
31
Appearance: grey and white powder
Storage: 12 months in a dry place
Consumption: 1.3 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Setting time: approx. 6-10 hours
Compressive strength after 28 days: 17 N/mm2
CODE
COLOUR
PACK
PACKS/PALLET
572
grey
25 kg
48
577
white
25 kg
48
Alkaline-based cleaner,
essential before laying a
covering on an existing floor; it
permanently removes residues
of oils, greases and waxes.
32
FASSA-REMOVE
FIELD OF APPLICATION:
Removal of residues of oils,
greases and waxes on any
non-absorbent surface.
Ideal for washing old
flooring to be covered later.
Appearance: transparent liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 100-200 g/m2
TECHNICAL SPECIFICATIONS
pH: approx. 12
Action time: approx. 10-15 min
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
CODE
PACK
PACKS/PALLET
886K
5 kg
96
888K
10 kg
40
COLOUR
High tenacity, alkali-resistant
synthetic fibre for cement
screeds, to prevent shrinkage
cracking. It improves the surface
of the screed by making it
more resistant to abrasion and
impacts.
FIBER MST 20
FIELD OF APPLICATION:
For conventional or
quickdrying screeds in
order to avoid occurrence
of shrinkage cracks during
hardening. The product
gives the structure greater
flexibility. Ideal for screeds
made with FASSACEM
binder instead of metal
mesh. Ideal with SV 472,
SC 420 and SR 450 instead
of metal mesh.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
33
Appearance: grey fibres
Storage: 24 months in a dry place
Consumption: 1-3 kg/m3 of screed or 0.5% of the cement added
TECHNICAL SPECIFICATIONS
Length: 20 mm
Tensile strength: 600 MPa
CODE
PACK
PACKS/PALLET
813
1 kg bags in boxes
of 10 pcs
30
COLOUR
Ultra fast-setting, high
strength hydraulic binder.
Made of high-strength
cements, selected
aggregates and special
additives to improve
workability and achieve
fast-setting properties
34
CR 90
FIELD OF APPLICATION:
For sealing concrete pipes,
installing wood and metal
sub-frames, manhole
covers, seals of electrical
boxes, plumbing pipes,
bathroom fixtures, hinges,
masonry anchors, wood
dowels, and to block small
water leaks.
SUBSTRATES:
Plasters and concrete
screeds, masonry made of
bricks or concrete.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: fine grey powder
Storage: 12 months in a dry place
TECHNICAL SPECIFICATIONS
Working time: approx. 2-3 min at + 20°C
Compressive strength after 3 hours: 5 N/mm2
Compressive strength after 28 days: 40 N/mm2
CODE
COLOUR
PACK
PACKS/PALLET
729K
grey
5 kg x 5 pcs
24
730
grey
25 kg
48
WATERPROOFERS
36
After the substrate has been
prepared, it must be made
waterproof to prevent seepage,
causing water and chemical
agents to seep up and damage
the structure.
37
Standard EN 14891
Standard EN 14891 establishes the criteria and methods for classifying
liquid-applied water impermeable products for use beneath ceramic
tiling bonded with adhesives, for internal and external tile installations
on walls and floors. It divides the products into three categories:
CM = liquid-applied cementitious waterproofing product
DM = liquid-applied dispersion waterproofing product
RM = liquid-applied reaction resin waterproofing product
Each of these categories can have two optional classes
O = with crack bridging ability at low temperature
P = resistant to contact with chlorinated water
Standard EN 1504-2
This standard provides specifications for surface protection products and
systems for concrete and to make the relative structures longer lasting.
MC = moisture control
IR = increasing resistivity by limiting the moisture content
page
Product Reference classes
Standard
38
AQUAZIP GE 97
CM-O2
EN 14891
EN 1504-2
39 AQUAZIP ADV CM-OPEN 14891
40 AQUAZIP ONE
CM-OPEN 14891
41 AQUAZIP RDY
42
AQUAZIP HIBRIDO
CM and PI-MC-IR
EN 14891
EN 1504-2
43
FASSABLOCK
44 MO 660
MC-IREN 1504-2
45 ACCESSORIES FOR WATERPROOFERS
COLOUR
Two-component, highly flexible cementitious
membrane for waterproofing and
anticarbonation for concrete, plasters,
cement floor screeds, existing coatings.
Suitable for contact with drinking water
(according to Italian Law Decree No. 31 of
February 2, 2001, implementing EC Directive
98/83/EC).
Test report 201115994/1 impermeability to water
under pressure in compliance with standard EN
14891 - Modena centro prove; suitable for contact
with drinking water - Arpa Lombardia
38
AQUAZIP GE 97
FIELD OF APPLICATION:
Waterproofing of pools, tanks,
bathrooms, showers, areas
subject to high humidity.
Waterproofing of terraces,
balconies, prior to installing
ceramic tiling, waterproofing
of old terraces without
demolishing the existing floor,
smoothing of micro-cracked
plasters and concrete,
protection of concrete from
the effects of carbonation as
well as from salt or sulphur
attacks, waterproofing
of tanks or cisterns also
containing drinking water.
SUBSTRATES:
Cement based plaster,
gauged mortar, cement
floor screeds, concrete,
ceramic, plasterboard,
marine plywood.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey powder and white latex
Conservation: comp. A: 12 months in a dry place, comp. B: 12 months
in a dry place away from freezing and high temperatures
Consumption: 1.7 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
For laying the covering use only FASSA adhesives
Maximum thickness per coat: 2 mm
Waiting time for overcoating: approx. 5 hours
Delay for installing ceramic tiles: approx. 5 days
CODE
COLOUR
PACK
PACKS/PALLET
891K
Comp. A
grey
25 kg
48
892K
Comp. B
white
latex
8.3 kg
48
COLOUR
Two-component cementitious membrane,
with high elasticity, for waterproofing and
anti-carbonation for concrete, plasters,
cement floor screeds, existing coatings.
The product can be applied by brush,
roller, sprayer.
AQUAZIP ADV
FIELD OF APPLICATION:
Waterproofing of pools, tanks,
bathrooms, showers, areas
subject to high humidity.
Waterproofing of terraces,
balconies, prior to installing
ceramic tiling, waterproofing
of old terraces without
demolishing the existing floor,
smoothing of micro-cracked
plasters and concrete,
protection of concrete from
the effects of carbonation as
well as from salt or sulphur
attacks.
SUBSTRATES:
Cement based plaster,
gauged mortar, cement
screeds, concrete, ceramic,
plasterboard.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
39
Appearance: white powder and white latex
Storage: comp. A: 12 months in a dry place, comp. B: 12 months in a
dry place away from freezing and high temperatures
Consumption: 1.6-2 kg/m2 per mm of thickness depending on
application conditions (by hand or machine)
TECHNICAL SPECIFICATIONS
For laying the covering use only FASSA adhesives
Maximum thickness per coat: 1 mm
Waiting time for overcoating: approx. 5 hours
Delay for installing ceramic tiles: minimum 5 days at +20°C and 65% relative
humidity.
CODE
COLOUR
PACK
PACKS/PALLET
815 Comp A
white
20 kg
48
816 Comp B
white latex
10 kg
48
COLOUR
One-component cementitious
waterproofing membrane for concrete,
plasters, cement floor screeds,
existing coatings.
Easy and practical to use.
40
AQUAZIP ONE
FIELD OF APPLICATION:
Waterproofing of bathrooms,
showers, areas subject to
high humidity. Waterproofing
terraces, balconies prior to
laying ceramic, waterproofing
of old terraces without
demolishing the existing floor,
smoothing of micro-cracked
plasters and concrete.
SUBSTRATES:
Cement based plaster,
gauged mortar, cement
screeds, concrete, ceramic,
plasterboard.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: white powder
Storage: 12 months in a dry place
Consumption: 1.1 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Thickness: 1-4 mm
Waiting time for overcoating: approx. 2 hours
Delay for installing ceramic tiles: approx. 2 days
CODE
COLOUR
PACK
PACKS/PALLET
817
white
20 kg
48
COLOUR
Ready to use, quick drying
waterproofing membrane
in paste form in aqueous
dispersion.
For indoor and outdoor
use. Must not be used in
continuous immersion.
Easy and practical to use.
AQUAZIP RDY
FIELD OF APPLICATION:
Waterproofing of bathrooms,
showers, areas subject to
high humidity. Waterproofing
of terraces, balconies,
prior to installing ceramic
tiling, waterproofing of
old terraces without
demolishing the existing
floor, following application
of PRIMERTEK 101. Ideal
as gripping component on
residues of synthetic glues,
waterproofing of gutters,
eaves.
SUBSTRATES:
Cement based plaster,
gauged mortar, cement
screeds, concrete,
plasterboard, old coverings,
wood
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
41
Appearance: Light blue paste
Storage: 24 months away from freezing
Consumption: 1.3 kg/m2 per mm of thickness
TECHNICAL SPECIFICATIONS
Thickness per coat: 0.4-1 mm
Waiting time for overcoating: approx. 1 hour
Delay for installing ceramic tiles: approx. 3-4 hours
CODE
COLOUR
PACK
PACKS/PALLET
818
light blue
15 kg
33
820
light blue
5 kg
40
COLOUR
42
Highly flexible two-component
cement-based mortar with waterproof
and anti-carbonation properties, for
concrete and/or masonry subject
to positive or negative hydraulic
force. Aquazip Hibrido is capable
of withstanding soluble salts
present in seawater and soil, and
is characterised by a high elasticity.
Furthermore, the product can be
applied with a roller or sprayer.
AQUAZIP HIBRIDO
FIELD OF APPLICATION:
Waterproofing of pools, tanks,
channels, underground rooms,
underground parking lots,
basements, underground tanks,
lift compartments; particularly
suitable for environments
subject to high humidity even
under counter-pressure.
SUBSTRATES:
Concrete and masonry, and all
adequately prepared cementbased surfaces.
Do not apply the product on
surfaces saturated with water.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: grey powder and white latex
Storage: comp. A: 12 months in a dry place, comp. B: 12 months in a
dry place away from freezing and high temperatures
Consumption: 1.7 kg/m2 (by hand) per mm of thickness
TECHNICAL SPECIFICATIONS
Maximum thickness: 2 mm
Waiting time for overcoating: approx. 5-6 hours
CODE
COLOUR
PACK
PACKS/PALLET
573
Comp. A
grey
20 kg
48
575
Comp. B
white latex
9 kg
48
COLOUR
Ultra-fast-setting hydraulic
binder for blocking water
infiltrations. FASSABLOCK is
formulated with a hydraulic
mix comprising highly resistant
cements, graded siliceous
aggregates and specific
additives for conferring fast
setting and hydrophobic
properties. The product is free
from chlorides and ensures
quick and easy application,
while adhering perfectly to the
surface.
FASSABLOCK
FIELD OF APPLICATION:
FASSABLOCK is used for
blocking infiltrations of water
even under pressure that may
appear in concrete or masonry
surfaces, for sealing rigid joints
between floors and walls, for
sealing cracks and holes, and
for filling joints subject to stress
(mixed with AG 15 latex).
Suitable for ultra-fast filling
in the face of water under
pressure, instant filling of
localised infiltrations, sealing
of water leaks from cracks
or gravel nests, or prior to
waterproofing interventions.
SUBSTRATES:
Concrete.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
43
Appearance: grey powder
Storage: 12 months in a dry place
Yield: approx. 1.7 kg of powder for roughly 1 litre of wet mortar
TECHNICAL SPECIFICATIONS
Workability time: 1 min at +20°C
Setting time: 2-3 min at +20°C
Minimum waiting time for applying mortar for superficial waterproofing: at least 30 min
CODE
COLOUR
PACK
PACKS/PALLET
439
grey
5 kg sack in plastic
bucket
64
COLOUR
Osmotic cement based mortar,
white and grey for waterproofing
with negative force too, for masonry
and concrete structures. Suitable for
underground masonry and for contact
with drinking water.
Compliant with Italian Law Decree No. 31 of
February 2, 2001, implementing EC Directive
98/83/EC, suitable for contact with drinking water Arpa Lombardia
44
MO 660
FIELD OF APPLICATION:
Waterproofing of retaining walls,
internal and external walls of
basements, swimming pools,
tanks, cisterns, waterproofing
of lift structures, renovation
of underground masonry
with moisture infiltration or
counterpressure water.
SUBSTRATES:
Masonry or concrete
structures.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: white or grey powder
Storage: 12 months in a dry place
Consumption: 1.5 kg/m2 per mm of thickness
Waiting time for overcoating: 2 hours
CODE
COLOUR
PACK
PACKS/PALLET
455K
white
25 kg
48
454K
grey
25 kg
48
ACCESSORIES
SEALING STRIP FOR
AQUAZIP® SYSTEMS
ADHESIVE SEALING STRIP
FOR AQUAZIP® SYSTEMS
Self-adhesive elastic sealing tape
for perimeter and internal joints. The
product is specific and perfectly
compatible with AQUAZIP® Systems.
The whole surface of the strip is
waterproofing.
Item 240700 - 50 m roll
Item 240706 - 1 Roll height 10 cm, length 20 m
45
FASSATNT 80
Polypropylene macro-perforated
non-woven fabric for AQUAZIP® systems
Item 240730 - Roll 1x25 m
CORNER FOR AQUAZIP® SYSTEMS
Item 240710
EDGE FOR AQUAZIP® SYSTEMS
Item 240720
FASSANET 160
160 gr/m2 glass fibre reinforced,
resin-impregnated mesh specific for
reinforcement in AQUAZIP® Systems
thanks to its excellent resistance
to alkalis and to ageing even under
extreme conditions.
Item 700960 - 1x50 m roll, 160 g/m2
AMERICAN TROWEL
with long steel bracket for one hand.
Item 221110 - 280x120x0.5 cm
ADHESIVES
46
The choice of adhesive is
determined by the diverse
requirements of the substrate
and the material to lay, by the
thickness needed, the intended
use of the premises. All the
adhesives that are presented
satisfy the requirements
established by the strictest
international guidelines with
regard to quality and safety.
47
The EN 12004 and EN 12002 standards
The EN 12004 standard defines the criteria and procedures for the
classification of adhesives for ceramic floor and wall coverings and
similar materials.
C = cementitious adhesives
R = reaction resin adhesives
D = dispersion adhesives
It also defines additional features such as:
F = fast setting adhesives
T = adhesives with reduced slip
E = adhesives with extended open time
The EN 12002 standard defines the level of transverse deformation or
elasticity of cementitious adhesives and grouts and defines two classes
S1 = deformable
S2 = highly deformable
page
Product Reference classes
48
49 50 51 52 53 54 55 56
57 58 59 60 61 62 63 64 65 66 67 AD 8
C1
ADYS
C1TE
AP 71 FLEX
C2TE
AZ 59 FLEX
C2TE S1
AT 99 MAXYFLEX
C2TE S1
AQ 60 STONE
C2FT S1
FASSATECH 2
C2FTE S2
SPECIAL ONE
C2E S1
CRISTAL-TECH
M15 according to EN 998-2
A 81 GP-CSIV-WO according to EN 998-1
FASSAFIX 1000
D1TE
FASSAFIX
D2TE
AX 91
R2
LATEX DE 80
ADYWOOD 2K
ADYWOOD MS
ADYTEX 2K
ADYTEX RS
PRIMER ADW - DILUENTE ADW
ACCESSORIES FOR ADHESIVES
COLOUR
Professional white or grey
one-component adhesive
formulated with cement binders
and selected aggregates for
laying absorbent coverings on
absorbent substrates, both
vertically and horizontally,
indoors as well as outdoors.
Cementitious adhesive classified as C1
in compliance with standard EN 12004
Test reports - Sassuolo AECC
48
AD 8
FIELD OF APPLICATION:
For laying double-fired tiles,
single-fired tiles, terracotta
tiles, absorbent ceramic
mosaics, natural stones, if not
susceptible to staining and
moisture stable.
Open time: 25 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
Initial tensile adhesion
SUBSTRATES:
Aged cement substrates
without flexion, gauged
mortar, cement plaster, lime
and cement plaster; on
gypsum-based substrates
apply PRIMER DG 74.
NOTES:
Mixed with LATEX DE 80 it
becomes a C2 S2 classified
product. (See page 61)
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
WHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
0.9
1.3
≥0.5
Tensile adhesion after water immersion
0.7
0.5
≥0.5
Adhesion after heat ageing
0.6
0.8
≥0.5
Tensile adhesion after freeze-thaw cycles
1.0
1.1
≥0.5
CODE
COLOUR
PACK
PACKS/PALLET
720K
white
5 kg x 5 pcs
24
701
white
25 kg
48
700K
grey
25 kg
48
COLOUR
One-component adhesive extra-white
and grey, formulated with special
binders and aggregates, suitable
for installation of tiles on absorbent
substrates. Great workability and easy
application, zero vertical slippage.
Applicable up to 15 mm thick, both
vertically and horizontally, indoors as
well as outdoors.
Cementitious adhesive classified as
C1TE in compliance with EN 12004
ADYS
FIELD OF APPLICATION:
For laying double-fired
tiles, single-fired tiles,
terracotta tiles, absorbent
ceramic mosaics, natural
stones, if not susceptible
to staining and moisture
stable.
SUBSTRATES:
Aged cement substrates
without flexion, gauged
mortar, cement plaster, lime
and cement plaster; on
gypsum-based substrates
apply PRIMER DG 74.
NOTES:
Mixed with LATEX DE 80
it becomes a C2TE S2
classified product.
(See page 61)
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
49
Open time: 30 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
EXTRAWHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
Initial tensile adhesion
approx. 0.7 approx. 0.6
≥0.5
Tensile adhesion after water immersion
approx. 0.6 approx. 0.6
≥0.5
Adhesion after heat ageing
approx. 0.6 approx. 0.6
≥0.5
Tensile adhesion after freeze-thaw cycles
approx. 0.6 approx. 0.6
≥0.5
Vertical slippage
0.4 mm
0.3 mm
≤0.5 mm
CODE
COLOUR
PACK
PACKS/PALLET
811
extra-white
25 kg
48
810
grey
25 kg
48
COLOUR
Professional one-component
adhesive with mixed binder, white
and grey, formulated with special
binders and aggregates, suitable for
installing all types of ceramic tiles
and stone materials provided they
are stable to moisture and stains.
High workability and zero vertical
slippage, usable both vertically
and horizontally, indoors as well as
outdoors.
Cementitious adhesive classified as C2TE in
compliance with standard EN 12004 Test reports
- Sassuolo AECC and Modena Centro Prove
50
AP 71 FLEX
FIELD OF APPLICATION:
For laying double-fired
tiles, single-fired tiles,
porcelain gres, terracotta
tiles, absorbent ceramic
mosaics, natural stones, if not
susceptible to staining and
moisture stable, klinker.
SUBSTRATES:
Aged cement substrates
without flexion, gauged mortar,
cement plaster, lime and
cement plaster, ceramic floors,
heating or cooling screeds,
(in the latter two cases max
size 900 cm2); on gypsum and
anhydrite substrates apply
PRIMER DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Open time: 30 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
WHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
Initial tensile adhesion
2.1
1.9
≥1
Tensile adhesion after water immersion
1.2
1.6
≥1
Adhesion after heat ageing
2.0
1.7
≥1
Tensile adhesion after freeze-thaw cycles
1.7
1.8
≥1
0.01 mm
0.08 mm
≤0.5 mm
Vertical slippage
CODE
COLOUR
PACK
PACKS/PALLET
743K
white
25 kg
48
742K
grey
25 kg
48
COLOUR
Professional one-component
adhesive with mixed binder, high
polymer content, white and grey,
formulated with special binders and
aggregates. Suitable for installing
all types of ceramic tiles, stone and
mosaic materials provided they
are stable to moisture and stains.
High workability and no vertical
slippage, usable both vertically and
horizontally, indoors and outdoors.
Cementitious adhesive classified as C2TE S1
in compliance with standard EN 12004 and
EN 12002 Test reports - Sassuolo AECC and
Modena Centro Prove
AZ 59 FLEX
FIELD OF APPLICATION:
For laying double-fired tiles,
single-fired tiles, porcelain
gres, terracotta tiles, any kind
of absorbent ceramic and
vitreous mosaics, natural stones,
if not susceptible to staining
and moisture stable, klinker.
Installation in pools and on
plasterboard.
SUBSTRATES:
Aged cement substrates even if
with high traffic, gauged mortar,
cement plaster, lime and cement
plaster, ceramic floors, heating
or cooling screeds, cementitious
membranes. Given the perfect
compatibility of the materials,
it is highly recommended for
screed SA 500, the AQUAZIP®
line and GYPSOTECH®
plasterboards. On gypsumbased substrates apply PRIMER
DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
51
Open time: 30 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
Initial tensile adhesion
WHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
2.6
2.3
≥1
Tensile adhesion after water immersion
1.5
1.5
≥1
Adhesion after heat ageing
3.1
2.1
≥1
Tensile adhesion after freeze-thaw cycles
Vertical slippage
1.9
1.9
≥1
0.26 mm
0.05 mm
≤0.5 mm
CODE
COLOUR
PACK
PACKS/PALLET
747K
white
25 kg
48
746K
grey
25 kg
48
747E
white
5 kg x 5 pcs
30
COLOUR
Professional one-component adhesive
with mixed binder, high polymer
content, extra white and grey,
formulated with special binders and
aggregates, suitable for installing
all types of ceramic tiles and stone
materials provided they are stable
to moisture and stains; very high
workability, no vertical slipping, high
elasticity, installation with thickness
up to 15 mm, both vertically and
horizontally, indoors and outdoors.
Particularly suitable for the laying of
glass and ceramic mosaic on paper or
mesh.
Cementitious adhesive classified as C2TE S1
in compliance with standard EN 12004 and
EN 12002 Test reports - Sassuolo AECC and
Modena Centro Prove
52
AT 99 MAXYFLEX
FIELD OF APPLICATION:
Particularly suitable for big
size installations. For laying
double-fired tiles, single-fired
tiles, porcelain gres, terracotta
tiles, any kind of ceramic and
vitreous mosaics, natural
stones, if not susceptible to
staining and moisture stable,
klinker. Installation in pools, on
plasterboard, big size installations.
SUPPORTI:
Aged cement substrates even if
with high traffic, gauged mortar,
cement plaster, lime and cement
plaster, ceramic floors, heating
or cooling screeds, cementitious
membranes. Given the perfect
compatibility of the materials, it is
highly recommended for screed
SA 500, the AQUAZIP® line and
GYPSOTECH® plasterboards. On
gypsum-based substrates apply
PRIMER DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Open time: 30 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
EXTRA
WHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
Initial tensile adhesion
2.5
1.5
≥1
Tensile adhesion after water immersion
1.7
1.6
≥1
Adhesion after heat ageing
2.6
2.0
≥1
1.6
1.8
≥1
Transverse deformation
Tensile adhesion after freeze-thaw cycles
3.3 mm
2.8 mm
≥2.5 mm
Vertical slippage
0.49 mm
0.12 mm
≤0.5 mm
CODE
COLOUR
PACK
PACKS/PALLET
748
extra white
25 kg
48
749
grey
25 kg
48
COLOUR
Professional one-component,
quick hydration adhesive with
mixed binder and high polymer
content, extra white and grey,
formulated with special binders and
aggregates. Suitable for installation
of ceramic tiles of any type when
a rapid installation is required,
both vertically and horizontally,
indoors and outdoors. The extra
white version of AQ 60 STONE is
especially recommended for stone
material that is sensitive to stains
but stable to moisture.
Cementitious adhesive classified as C2FT S1
in compliance with standard EN 12004 and EN
12002 Test reports - Sassuolo AECC
AQ 60 STONE
FIELD OF APPLICATION:
For laying double-fired tiles,
single-fired tiles, porcelain
gres, klinker, terracotta tiles,
any kind of ceramic and
vitreous mosaics, natural
stones, susceptible to staining
but moisture stable. Suitable
for installation in pools.
Particularly suitable for laying
over existing floors, and for
low temperatures.
SUBSTRATES:
Aged cement substrates
even if with high traffic,
gauged mortar, cement
plaster, lime and cement
plaster, ceramic floors,
heating and cooling
screeds, cementitious
membranes. Given the
perfect compatibility of
the materials, it is highly
recommended for screed
SA 500, the AQUAZIP®
line and GYPSOTECH®
plasterboards. On gypsumbased substrates apply
PRIMER DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
53
Open time: 15 min
Grouting: 4-6 hours on floor, 2 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
EXTRA WHITE
N/mm2
GREY
N/mm2
Initial tensile adhesion
1.5
2.1
≥1
Early tensile adhesion strength (6 hours)
0.6
0.8
≥0.5
Tensile adhesion after water immersion
1.4
1.5
≥1
Adhesion after heat ageing
2.1
2.4
≥1
TECHNICAL CHARACTERISTICS
Tensile adhesion after freeze-thaw cycles
STANDARD
N/mm2
2.0
1.6
≥1
Transverse deformation
3.3 mm
3.4 mm
≥2.5
Vertical slippage
0.12 mm
0.09 mm
≤0.5 mm
CODE
COLOUR
PACK
PACKS/PALLET
745K
extra white
25 kg
48
744K
grey
25 kg
48
COLOUR
Professional two-component, quick
hydration cementitious adhesive,
highly deformable, with no vertical
slippage, extra white and grey,
formulated with special binders and
aggregates. Suitable for installation
of ceramic tiles, even large sizes, and
for mosaics of any type when a rapid
installation is required, both vertically
and horizontally, indoors as well as
outdoors. The extra white version is
especially recommended for stone
material that is sensitive to stains and
moderately stable to moisture.
Cementitious adhesive classified as C2FTE
and S2 in compliance with standard EN 12004
and EN 12002
54
FASSATECH 2
FIELD OF APPLICATION:
For rapid laying of double-fired
tiles, single-fired tiles, porcelain
gres even large sizes, klinker,
terracotta tiles, ceramic and vitreous
or stone mosaics, reconstituted
material only in interiors, natural
stones susceptible to staining
and moderately moisture stable.
Particularly suitable for laying
over existing floors, and for low
temperatures. Laying on deformable
substrates such as marine plywood,
old wood floors, precast concrete,
exterior façades. Suitable for
installation in pools. Installation in
environments subject to considerable
mechanical stress and vibration.
SUBSTRATES:
Aged cement substrates even if with
high traffic, gauged mortar, cement
plaster, lime and cement plaster,
ceramic floors, precast concrete,
heating and cooling screeds,
cementitious membranes. Given
the perfect compatibility of the
materials, it is highly recommended
for screed SA 500, the AQUAZIP®
line and GYPSOTECH®
plasterboards. On gypsum-based
substrates apply PRIMER DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Open time: 30 min
Grouting: 4-6 hours on floor, 2 hours on wall
Storage: 12 months in a dry place
Consumption: approx. 3-4 kg/m2
TECHNICAL CHARACTERISTICS
EXTRA WHITE
N/mm2
GREY STANDARD
N/mm2
N/mm2
Initial tensile adhesion
1.46
1.38
≥1
Early tensile adhesion strength (6 hours)
0.74
0.76
≥0.5
Tensile adhesion after water immersion
1.15
1.3
≥1
Adhesion after heat ageing
1.47
1.35
≥1
Tensile adhesion after freeze-thaw cycles
1.23
1.14
≥1
Transverse deformation
Vertical slippage
5 mm
5 mm
≥5 mm
0.1 mm
0.2 mm
≤0.5 mm
CODE
COLOUR
PACK
PACKS/PALLET
805 Comp A
grey
25 kg
48
807 Comp A
extra white
25 kg
48
6.25 kg
48
806 Comp B
COLOUR
Professional one-component, medium
rapidity, selfwetting adhesive with mixed
binder and high polymer content,
formulated with special binders and
aggregates. Suitable for installing
all types of ceramic tiles and stone
materials provided they are stable
to moisture and stains, even large
sizes and small thickness. Very high
workability, high elasticity, it avoids
double spreading. For horizontal
installation, indoors and outdoors.
Excellent as levelling coat up to 15 mm.
Cementitious adhesive classified as C2E S1
in compliance with standard EN 12004 and
EN 12002
SPECIAL ONE
FIELD OF APPLICATION:
For laying double-fired tiles,
single-fired tiles, porcelain
gres, terracotta tiles, any
kind of ceramic and vitreous
mosaics, natural stones, if
not susceptible to staining
and moisture stable, klinker.
Particularly suitable for
tiles of large sizes and
small thickness and for
cementitious membranes.
SUBSTRATES:
Aged cement substrates
even if with high traffic,
gauged mortar, ceramic
floors, heated or cooled
screeds. Given the perfect
compatibility of the
binders and resins, it is
highly recommended for
screed SA 500, and for the
AQUAZIP® line. On gypsum
and anhydrite substrates
apply PRIMER DG 74.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
55
Open time: 30 min
Grouting: 12-24 hours on floors
Storage: 12 months in a dry place
Consumption: approx. 4-5 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
GREY
N/mm2
STANDARD
N/mm2
Initial tensile adhesion
1.28
≥1
Tensile adhesion after water immersion
1.24
≥1
Adhesion after heat ageing
1.27
≥1
Tensile adhesion after freeze-thaw cycles
1.19
≥1
2.9 mm
≥2.5 mm
TECHNICAL CHARACTERISTICS
Transverse deformation according to EN 12002
CODE
COLOUR
PACK
PACKS/PALLET
812
grey
25 kg
48
COLOUR
Extra-white cementitious adhesive and
sealant for laying and sealing glass
block elements, both indoors and
outdoors. As a sealant it can be used
to create 2 mm to 25 mm thick joints.
Conforms to the EN 998-2 M15
standard.
56
CRISTAL-TECH
FIELD OF APPLICATION:
Embedding of glass blocks,
smoothing of foamed concrete
walls indoors and outdoors.
Appearance: extra-white powder
Storage: 12 months in a dry place
Consumption: 18-25 kg/m2 for bonding and sealing joints, depending
on the dimensions of the glass blocks and the thickness of the grouts
to be made.
TECHNICAL CHARACTERISTICS
SUBSTRATES:
Glass blocks.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Compressive strength after 28 days: 16 N/mm2 (M15: >15 N/mm2)
CODE
COLOUR
PACK
PACKS/PALLET
576
extra white
5 kg x 5 pcs
24
576K
extra white
25 kg
48
COLOUR
Adhesive and levelling
mortar specific for laying and
smoothing foamed concrete
blocks.
Classified as GP-CSIV-WO in
compliance with standard EN 998-1
A 81
FIELD OF APPLICATION:
Embedding of foamed concrete
blocks, smoothing of foamed
concrete walls indoors and
outdoors.
57
Pot-life: approx. 4 hours at +20°C
Storage: 12 months in a dry place
Consumption: for smoothing 1.4 kg/m2 per mm of thickness; for
bonding 5-7 kg/m2
GEV Classification: GEV EMICODE EC 1Plus - very low emission
TECHNICAL CHARACTERISTICS
SUBSTRATES:
Foamed concrete blocks.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Compressive strength after 28 days: 10 N/mm2
CODE
COLOUR
PACK
PACKS/PALLET
895K
white
25 kg
48
895
white
5 kg x 5 pcs
24
COLOUR
Ready-to-use paste
dispersion adhesive. No
vertical slippage. For
installation of any kind of
absorbent ceramic tiles on
interior walls.
Classified as D1TE
in compliance with standard EN 12004/1324
58
FASSAFIX 1000
FIELD OF APPLICATION:
Indoor laying of doublefired
tiles, single-fired tiles,
terracotta tiles on absorbent
substrates. Specific for laying
on plasterboard.
Open time: 30 min
Grouting: 24 hours
Storage: 12 months in a dry place away from freezing and high temperatures
Consumption: 2-4 kg/m2
TECHNICAL CHARACTERISTICS
N/mm2
STANDARD
N/mm2
SUBSTRATES:
Initial shear adhesion strength
3.3
≥1
Gauged mortar, gypsum
based plasters, cement
plasters, lime and cement
plaster, concrete, wood.
Particularly suitable for
laying on plasterboard.
Adhesion at elevated temperature
3.9
≥1
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
CODE
COLOUR
PACK
PACKS/PALLET
724K
white
10 kg
100
737K
white
25 kg
33
COLOUR
Ready-to-use paste
dispersion adhesive. No
vertical slippage. For
installation of ceramic tiles of
any kind on interior walls.
Classified as D2TE
in compliance with standard EN 12004/1324
Test reports - Sassuolo AECC
FASSAFIX
FIELD OF APPLICATION:
Laying of ceramic tiles
of any kind on absorbent
substrates in interiors. Indoor
laying of double fired tiles or
terracotta on non-absorbent
substrates. Suitable for laying
in humid environments such
as bathrooms, showers and
specific for plasterboard.
59
Open time: 30 min
Grouting: 24 hours
Storage: 12 months in a dry place away from freezing and high temperatures
Consumption: 2-4 kg/m2
N/mm2
STANDARD
N/mm2
Initial shear adhesion strength
3.4
≥1
Shear adhesion strength after water immersion
0.8
≥0.5
Shear adhesion at elevated temperature
3.9
≥1
Shear adhesion strength after heat ageing
4.1
≥1
TECHNICAL CHARACTERISTICS
SUBSTRATES:
Gauged mortar, gypsum
based plasters, cement
plasters, lime and cement
plaster, plasterboard,
concrete, wood surfaces
(provided they are water
stable), well stabilized marine
plywood. Particularly suitable
for laying on plasterboard.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
CODE
COLOUR
PACK
PACKS/PALLET
757K
white
10 kg
100
756K
white
25 kg
33
COLOURS
White and grey two
component polyurethane
adhesive with very high
flexibility for ceramic tiles
of any kind. Particularly
suitable for laying stone
materials sensitive to
moisture and stain and for
laying reconstituted natural
materials. For indoors and
outdoors.
Classified as R2 in compliance with
standard EN 12004.
Test reports - Sassuolo AECC
60
AX 91
FIELD OF APPLICATION:
Laying of ceramic tiles
of any type on difficult
substrates or subject to
strong deformation. Laying
of natural stones, sensitive
to moisture or tending to
staining. Particularly suitable
for laying reconstituted
marbles, ceramic tiles on
terraces, balconies, kitchen
worktops or wooden work
surfaces or iron substrates.
SUBSTRATES:
Aged cement substrates,
gauged mortar, gypsum
plaster, lime and cement
plaster, gypsum plasters,
heating and cooling
screeds, concrete, metal,
rubber, fiber cement,
old floors, wood, marine
plywood and plasterboard.
Suitable for substrates with
strong vibration or where
waterproofing of the surface is
desired.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Open time: 1 hour
Grouting: 12 hours
Storage: 12 months in a dry place away from freezing and low temperatures
Consumption: for bonding 1.5-2.5 kg/m2 ; for waterproofing 3-3.5 kg/m2
WHITE
N/mm2
GREY
N/mm2
STANDARD
N/mm2
Initial tensile adhesion
3.9
2.9
≥2
Tensile adhesion after water immersion
2.5
2.2
≥2
Adhesion after heat ageing
3.3
2.3
≥2
TECHNICAL CHARACTERISTICS
CODE
COLOUR
PACK
PACKS/PALLET
750K
white
10 kg
(Comp A 9.4 kg)
(Comp B 0.6 kg)
76
749K
grey
10 kg
(Comp A 9.4 kg)
(Comp B 0.6 kg)
76
COLOUR
Elasticising and adhesion
promoting latex with high binding
power for adhesives and cement
based mortars. To be used as
a substitute for water in the mix
in the ratio 1:1, according to the
elasticity required and the grip
improvement.
Test reports - ITC Milan
LATEX DE 80
FIELD OF APPLICATION:
Mixing LATEX DE 80 with AD 8,
an adhesive of category C2 S2 is
obtained, whereas LATEX DE 80
with ADYS form an adhesive of
category C2TE S2. The resulting
products are particularly suitable
for big size installations indoors
and outdoors as well as in
pools, on heating screeds and in
refrigeration cells.
SUBSTRATES:
Cement screeds, gauged
mortars, concrete, old ceramic
floors indoors and outdoors,
for floors and walls. Suitable for
laying on the membranes of the
AQUAZIP® line, GYPSOTECH®
plasterboard and SA 500
screed.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
61
Open time: 15 min
Grouting: 24-36 hours on floor, 4-6 hours on wall
Storage: 12 months in a dry place away from freezing and low
temperatures
LATEX DE 80
CONSUMPTION
ADHESIVE
7.5 l
1 bag AD 8
7.5 l
1 bag ADYS
CODE
COLOUR
PACK
PACKS/PALLET
761K
white
5 kg
40
760K
white
20 kg
33
Two-component
epoxypolyurethane adhesive
for laying wooden floors of any
size and kind.
62
ADYWOOD 2K
FIELD OF APPLICATION:
Laying wood of any kind
and type (laminated wood,
industrial wood, lamparquet,
pre-polished and pre-finished).
Open time: 60 min
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 1-1.4 kg/m2
TECHNICAL CHARACTERISTICS
SUBSTRATES:
Aged cement substrates,
cement plaster, lime and
cement plaster, screeds SV
472 and SA 500, screeds
made with FASSACEM
binder, heated or cooled
screeds, concrete, metal,
rubber, fibre cement, old
floors in ceramic or natural
stone, metal sheets,
anhydrite screeds such as
E 439, after using PRIMER
ADW, diluted 1:1 with
DILUENTE ADW.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Walkability: 1-2 days, depending on temperature and humidity conditions
Ready for use after: 3 days
CODE
580K
COLOUR
PACK
PACKS/PALLET
beige
10 kg (Comp. A 9.4
+ Comp. B 0.6 kg)
100
Ready to use one-component
adhesive with a high bonding
power for laying wooden floors
of any size and kind with no
indication of harmful risk.
ADYWOOD MS
FIELD OF APPLICATION:
Laying wood of any kind
and type (laminated wood,
industrial wood, lamparquet,
pre-polished and pre-finished).
63
Open time: 60 min
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 0.8-1.1 kg/m2
TECHNICAL CHARACTERISTICS
SUBSTRATES:
Aged cement substrates,
cement plaster, lime and
cement plaster, screeds SV
472 and SA 500, screeds
made with FASSACEM binder,
heated or cooled screeds,
concrete, metal, rubber, fiber
cement, old floors in ceramic
or natural stone, metal sheets,
anhydrite screeds, such as
E 439, after using PRIMER
ADW, diluted 1:1 with
DILUENTE ADW.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Walkability: 2-3 days, depending on temperature and humidity conditions
Can be polished after: 2 days
Ready for use after: 3 days
CODE
COLOUR
PACK
PACKS/PALLET
581K
beige
15 kg
60
Two-component epoxypolyurethane adhesive free
of water, for bonding resilient
flooring (rubber, rubber
agglomerates, PVC, linoleum,
textile) on absorbent and
non-absorbent underlays.
For indoor and outdoor
applications.
64
ADYTEX 2K
FIELD OF APPLICATION:
Laying of rubber and rubber
agglomerate flooring, also
for sports fields, and PVC,
linoleum, textile and fibrecement flooring.
Open time: approx. 90-120 minutes
Appearance: beige-coloured paste
Storage: 12 months in a dry place
TECHNICAL CHARACTERISTICS
Consumption: approx. 1-1.4 kg/m2
Lay at temperatures between +15°C and +25°C
SUBSTRATES:
Applicable on cementitious
screeds, concrete, gauged
mortar, cementitious plaster,
ceramic floors, anhydride
screeds, fibre-cement, metal,
PVC, rubber, wood.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Walkability: 4-5 days, depending on the environmental conditions
CODE
COLOUR
PACK
PACKS/PALLET
579K
beige
10 kg
76
Universal single-component
acrylic adhesive with fast initial
setting, in aqueous dispersion,
for resilient flooring on
absorbent and dry underlays in
indoor environments.
ADYTEX RS
FIELD OF APPLICATION:
Laying of homogeneous and
heterogeneous PVC, fitted
carpeting and tufted carpets,
coverings backed with latex
foam, jute and linoleum in
sections.
65
Open time: approx. 15-25 minutes
Appearance: beige-coloured paste
Storage: 12 months in a dry place
TECHNICAL CHARACTERISTICS
Consumption: 300-400 g/m2
Lay at temperatures between +15°C and +25°C
SUBSTRATES:
Applicable on all absorbent
underlays in interiors, such
as cementitious screeds,
cementitious plaster, wood,
concrete, anhydride screeds,
fibre-cement.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Walkability: 3-4 days, depending on the environmental conditions
CODE
COLOUR
PACK
PACKS/PALLET
578K
beige
10 kg
60
Consolidating primer for
screeds or cementitious
underlayments and for
anhydrite screeds. Particularly
suitable as damp-proof
membrane for cement
substrates with residual
humidity inferior or equal to
4%.
66
PRIMER ADW - DILUENTE ADW
FIELD OF APPLICATION:
Consolidant for crumbling
cement screeds. Particularly
suitable as damp-proof
membrane for cement screeds
before laying wood.
SUBSTRATES:
Cement screeds and
cementitious underlayments,
fiber-cement, anhydrite
screeds.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Primer ADW Appearance: amber liquid
Diluente ADW Appearance: transparent liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 200-300 g/m2
CODE
COLOUR
PACK
PACKS/PALLET
PRIMER ADW
582K
amber
10 kg
76
DILUENTE ADW
583K
transparent
10 kg
76
ACCESSORIES
MANUAL ELECTRIC MIXERS
Eibenstock 1000 W
Item 480500
Eibenstock 1100 W
Item 480550
EHR 1800 W
Item 480600
67
ADHESIVE MIXERS
Mixer
for electric drill
Item 480320
Mixer
for electric drill
Item 480330
Mixer
for electric drill
Item 480310
TROWELS
1 hand 280x130 mm American trowel
10x10 mm notch
Item 240510
280x120 mm trowel 10x10 mm notch
Item 240500
280x120 mm trowel 6x8 mm notch
Item 240520
280x120 mm trowel 3x3 mm notch,
for mosaics
Item 240540
280x120 mm trowel 20 mm U-notch
Item 240530
480x140 mm American trowel
10x10 mm notch
Item 240000
GROUTING
68
The joint between tiles has
two reasons: technical and
aesthetic. Technical, to
compensate for the effects of
the hydrothermal expansion
that can cause tension between
the covering and the substrate.
Aesthetic, to mitigate any
defects of calibration and
squareness of the covering and
enhance the entire surface.
69
Standard EN 13888
The EN 13888 standard sets, at the European level, the performance
characteristics of grouts for joints, dividing the products into two main
categories:
CG = cementitious grouts
RG = reaction resin grouts
Category CG has two sub-classes:
Class 1 = normal grout (meets the minimum requirements)
Class 2 = improved grout
W = reduced water absorption
AR = high abrasion resistance
page
Product Reference classes
70
72 74 76 78
79
80 82 83 84 86 88
89
90
FC 830 GF 0-4
CG2 WA
FC 869 GM 2-10 CG2 WA
FC 854 GG 4-15 CG2 WA
FC 872 GM 2-20CG2 WA
LATEX DR 843 FASSA-CLEAN D 91
BLUCOLORSRG
GLITTER LUXOR FOR BLUCOLORS
BLUCOLORS ZERO
RG
FE 838RG
DETERPOXY
FASSASIL NTR
SYLAN 290
ACCESSORIES FOR GROUTING
Fine-graded, highly workable
and high performance
cementitious grout,
containing special cements
and polymers, selected
sands, water repellent.
Suitable for sealing joint
widths from 0 to 4 mm
indoors and outdoors.
Classified as CG2 WA in compliance
with standard EN 13888
70
FC 830 GF 0-4
FIELD OF APPLICATION:
Grouting the joints of floor and
wall coverings of any type, i.e.
ceramic tiles, both single and
double fired, porcelain gres,
klinker, natural stone, marble,
granite, agglomerated stones,
vitreous, ceramic and marble
mosaics. For indoor and
outdoor grouting. For pools
add LATEX DR 843
CHARACTERISTICS:
- excellent moisture and
abrasion resistance
- does not crack
- easy to clean
- water repellent
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: coloured fine powder available in 8 colours
Storage: 20 kg sack 12 months in a dry place
5 kg sack 24 months in a dry place
Approximate estimated consumption of FC 830 kg/m² according to the
size of tiles
Tile size
A
20
50
100
150
200
300
300
500
600
B
20
50
100
150
200
300
300
500
600
D = joint width
C
4
4
6
6
8
8
20
12
12
1 mm
0.6
0.3
0.2
0.2
0.2
0.1
0.2
0.1
0.1
(A+B)
x C x D x 1.5 = kg/m2
(AxB)
2 mm
1.2
0.5
0.4
0.3
0.3
0.2
0.4
0.2
0.2
3 mm
1.8
0.8
0.6
0.4
0.4
0.3
0.6
0.3
0.2
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
4 mm
2.4
1
0.8
0.5
0.5
0.4
0.8
0.3
0.3
CODE
COLOUR
PACK
PACKS/PALLET
48
WHITE
20 kg sack
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
30
822K
842S
842E
913S
913E
847S
847E
841S
841E
843S
843E
844S
844E
911S
911E
912S
912E
MANHATTAN
LIGHT GREY
QUARTZ GREY
CHARCOAL
BLACK
JASMINE
BEIGE
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
30
30
30
30
30
30
30
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
71
Mid-graded, highly workable
and high performance
cementitious grout, containing
special cements and
polymers, selected sands,
water repellent. Suitable for
sealing joint widths from 2
to 10 mm. For indoor and
outdoor use with pastel
finishing.
Classified as CG2 WA in compliance
with the standard EN 13888
72
FC 869 GM 2-10
FIELD OF APPLICATION:
Grouting the joints of floor and
wall converings of any type, i.e.
ceramic tiles, both single and
double fired, porcelain gres,
klinker, natural stone, marble,
granite, agglomerated stones,
vitreous, ceramic and marble
mosaics. For indoor and
outdoor grouting.
For pools add LATEX DR 843.
CHARACTERISTICS
- excellent moisture and
abrasion resistance
- does not crack
- easy to clean
- water repellent
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: coloured mid-graded powder available in 25 colours
Storage: 20 kg sack 12 months in a dry place
5 kg sack 24 months in a dry place
Approximate estimated consumption of FC 869 kg/m² according to the
size of tiles
Tile size
A
20
50
100
200
300
300
400
500
600
B
20
50
100
200
300
300
400
500
600
D = joint width
C
4
4
6
8
8
10
10
12
12
3 mm
2
0.8
0.6
0.4
0.3
0.4
0.3
0.3
0.2
(A+B)
x C x D x 1.6 = kg/m2
(AxB)
5 mm
3.2
1.3
1
0.7
0.5
0.6
0.4
0.4
0.4
7 mm
4.5
1.8
1.4
0.9
0.6
0.8
0.6
0.6
0.5
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
10 mm
6.4
2.6
2
1.3
0.9
1.1
0.8
0.8
0.7
CODE
COLOUR
PACK
PACKS/PALLET
48
WHITE
20 kg sack
5 kg x 5 pcs
5 kg x 5 pcs /complete pallet
30
823K
824S
824E
831S
831E
922S
922E
921S
921E
818K
833S
833E
825S
825E
835S
835E
920S
920E
923S
923E
925S
925E
924S
924E
926S
926E
927S
927E
929S
929E
930S
930E
928S
928E
840S
840E
839S
839E
931S
931E
932S
932E
933S
933E
830S
830E
918S
918E
919S
919E
917S
917E
LIGHT GREY
ICE
MANHATTAN
QUARTZ GREY
CHARCOAL
BLACK
PERGAMON
JASMINE
BEIGE
ANEMONE
CARAMEL
BROWN
RUBY
AMARANTH
TERRACOTTA
DARK BROWN
SAND
MAGNOLIA
AQUA GREEN
GREEN
YELLOW
CROCUS
ANISE
ULTRAMARINE
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
20 kg sack
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pz
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
5 kg x 5 pcs
5 kg x 5 pcs / complete pallet
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
30
30
30
48
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
73
Coarse-graded, highly
workable and high
performance cementitious
grout, containing special
cements and polymers,
selected sands, water
repellent. Suitable for sealing
joint widths from 4 to 15 mm
indoors and outdoors.
Classified as CG2 WA in compliance
with standard EN 13888
74
FC 854 GG 4-15
FIELD OF APPLICATION:
Grouting the joints of floor and
wall converings of any type, i.e.
ceramic tiles, both single and
double fired, porcelain gres,
klinker, stone material, natural
stones, marbles, granite,
agglomerated stones.
For indoor and outdoor
grouting.
For pools add LATEX DR 843.
CHARACTERISTICS
- excellent moisture and
abrasion resistance
- does not crack
- easy to clean
- water repellent
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: coloured coarse-graded powder available in 6 colours
Storage: 12 months in a dry place
Approximate estimated consumption of FC 854 kg/m² according to the
size of tiles
Tile size
A
20
50
100
200
300
300
400
500
600
B
20
50
100
200
300
600
400
500
600
D = joint width
C
4
4
6
8
8
10
10
12
12
5 mm
3.2
1.3
1
0.7
0.5
0.4
0.4
0.4
0.4
(A+B)
x C x D x 1.6 = kg/m2
(AxB)
8 mm
5.2
2.1
1.6
1.1
0.7
0.7
0.7
0.7
0.6
10 mm
6.4
2.6
2
1.3
0.9
0.8
0.8
0.8
0.7
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
12 mm
7.7
3.1
2.4
1.6
1.1
1
1
1
0.8
15 mm
9.6
3.9
2.9
2
1.3
1.2
1.2
1.2
1
CODE
COLOUR
PACK
PACKS/PALLET
914K
MANHATTAN
25 kg sack
48
861K
quartz grey
25 kg sack
48
864K
CHARCOAL
25 kg sack
48
865K
BLACK
25 kg sack
48
915K
BEIGE
25 kg sack
48
916K
BROWN
25 kg sack
48
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
75
Water-repellent and high
performance cementitious
grout, with increased
resistance to mould and
algae, for joints from 2 to
20 mm. The product is
extremely workable and
contains special cement,
polymers, selected
aggregates and microfibres.
Particularly suitable for joints
subject to vibration or for
all cases where maximum
hygiene is required. Suitable
for outdoor applications.
Classified as CG2 WA in compliance
with standard EN 13888
76
FC 872 GM 2-20
FIELD OF APPLICATION:
Grouting the joints of floor and
wall coverings of any type, i.e.
ceramic tiles, both single and
double fired, porcelain gres,
klinker, stone material, natural
stones, marbles, granite,
agglomerated stones. Suitable
for grouting indoors and
outdoors, in pools and in damp
rooms.
CHARACTERISTICS
- excellent moisture and
abrasion resistance
- does not crack
- easy to clean
- water repellent
- increased resistance to
mould and algae
- fibre-reinforced
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: coloured mid-graded powder available in 8 colours
Storage: 12 months in a dry place
Approximate estimated consumption of FC 872 kg/m² according to the
size of tiles
Tile size
A
20
50
100
150
200
300
400
500
600
B
20
50
100
150
200
300
400
500
600
D = joint width
C
4
4
6
6
8
8
10
12
12
3 mm
1.8
0.8
0.6
0.4
0.4
0.3
0.3
0.3
0.2
(A+B)
x C x D x 1.5 = kg/m2
(AxB)
5 mm
3
1.2
0.9
0.6
0.6
0.4
0.4
0.4
0.3
8 mm
4.8
2
1.5
1
1
0.7
0.6
0.6
0.5
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
10 mm
6
2.4
1.8
1.2
1.2
0.8
0.8
0.8
0.6
20 mm
12
4.8
3.6
2.4
2.4
1.6
1.5
1.5
1.2
CODE
COLOUR
PACK
PACKS/PALLET
872K
WHITE
20 kg sack
48
938K
LIGHT GREY
20 kg sack
48
939K
MANHATTAN
20 kg sack
48
868K
QUARTZ GREY
20 kg sack
48
870K
CHARCOAL
20 kg sack
48
871K
BLACK
20 kg sack
48
949K
BEIGE
20 kg sack
48
869K
DARK BROWN
20 kg sack
48
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
77
COLOUR
78
Elasticising and adhesion
promoting latex for FC 830 GF
0-4, FC 854 GG 4-15 and FC869
GM 2-10. Used to replace water
to make the grout resistant to
saponification and weathering.
The product improves the
mechanical characteristics,
such as abrasion resistance and
impermeability.
LATEX DR 843
FIELD OF APPLICATION:
Grouting of floors subject to
heavy foot traffic and ceramic
floors laid on wood. Grouting of
coverings subject to frequent or
energetic washes such as toilets
and showers, gyms, sports
centres, commercial centres.
Grouting of outdoor coverings
or pools.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: white liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Grouting: 24-36 hours on floor, 4-6 hours on wall
LATEX DR 843
GROUT
1.3/1.8 kg
6/9 kg
5 kg FC 830 GF 0-4
25 kg FC 830 GF 0-4
6/9 kg
25 kg FC 854 GG 4-15
1.6 kg
6.4 kg
5 kg FC 869 GM 2-10
20 kg FC 869 GM 2-10
CONSUMPTION
CODE
COLOUR
PACK
PACKS/PALLET
763K
white
5 kg
40
762K
white
20 kg
33
Acid-based cleaner with
corrosion inhibitors to remove
cement residues from
ceramic tiles and from tools.
FASSA-CLEAN D 91
FIELD OF APPLICATION:
Removal of encrustations,
residues of cement,
lime, cement-based
adhesives and grouts,
salt efflorescence from
ceramic surfaces, removal
of encrustations on
construction materials
and equipment used on
building site.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
79
Appearance: transparent liquid
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 100-200 g/m2
TECHNICAL SPECIFICATIONS
pH: approx. 1.5-2.5
Action time: 10 min
CODE
PACK
PACKS/PALLET
889K
1 kg
24 pcs box
890K
5 kg
Two-component anti-acid
epoxy grout for 2-20 mm
joints for indoor and outdoor
use with high technical and
aesthetic performance,
excellent as an adhesive.
Ideal in cases in which a
high degree of hygiene
or mechanical strength
or resistance to chemical
aggression are required, with
a refined aesthetic finish.
Classified as R2 in compliance with
standard EN 12004 and as RG in
compliance with standard EN 13888
80
BLUCOLORS
FIELD OF APPLICATION:
Grouting the joints of floor
and wall coverings of any
type, i.e. ceramic tiles, both
single and double fired,
porcelain gres, klinker, nonporous natural stone, granite,
agglomerated marbles. Ideal
for glass, ceramic and marble
mosaics. Excellent for pools,
bathrooms, kitchen counters,
wellness centres, wine
cellars, dairies, aggressive
water tanks, food processing
plants, industrial kitchens,
fisheries, slaughterhouses and
butcheries.
CHARACTERISTICS
- pot-life: 45 min
- thermal resistance: -20/+140°C
- excellent resistance to acids
- excellent resistance to alkalis
- excellent resistance to oils
- adhesion after 28 days 3 N/mm2
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: Comp. A = dense paste - Comp. B = dense liquid;
available in 17 colours
Storage: 12 months in a dry place away from freezing and high
temperatures
Approximate estimated consumption of BLUCOLORS in kg/m²
Tile size
A
20
100
150
200
300
300
450
500
600
B
20
100
150
200
300
600
450
500
600
D = joint width
C
4
6
6
8
8
10
12
12
12
2 mm
1.2
0.4
0.3
0.3
0.2
0.2
0.2
0.2
0.2
(A+B)
x C x D x 1.5 = kg/m2
(AxB)
5 mm
3
0.9
0.6
0.6
0.4
0.4
0.4
0.4
0.3
8 mm
4.8
1.5
1
1
0.7
0.6
0.7
0.6
0.5
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
10 mm
6
1.8
1.2
1.2
0.8
0.8
0.8
0.8
0.6
20 mm
12
3.6
2.4
2.4
1.6
1.5
1.6
1.5
1.2
CODE
COLOUR
PACK
721
ULTRAWHITE
3 kg
728
LIGHT GREY
3 kg
733
ICE
3 kg
737
GREY
3 kg
724
BLACK
3 kg
722
NEUTRAL
3 kg
723
IVORY
3 kg
725
CYCLAMEN
3 kg
726
LILAC
3 kg
727
TRAVERTINE
3 kg
788
YELLOW
3 kg
735
GREEN
3 kg
736
LIGHT BLUE
3 kg
786
BLUE
3 kg
785
LIGHT SAND
3 kg
739
MOCHA
3 kg
787
RED
3 kg
81
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
Glitter for an excellent
aesthetic apperance,
specifically created to enrich
the BLUCOLORS Line, so
as to obtain very decorative
shining chromatic effects.
82
GLITTER LUXOR FOR BLUCOLORS
FIELD OF APPLICATION:
Perfect to give more light and
more charm to floors and walls,
in conjunction with the most
advanced BLUCOLORS fashion
colours. Using the three colours
of Glitter Luxor for Blucolors,
(gold, silver, pearlescent),
shining chromatic effects can
be obtained, with an excellent
aesthetic appearance to give
a dimension of contemporary
elegance to the premises.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: coloured glitter
Storage: 12 months in a dry place away from freezing and high
temperatures
Consumption: 1 pack for every 3 kg of BLUCOLORS
CODE
COLOUR
PACK
935
GOLD
90 g
936
SILVER
90 g
937
PEARLESCENT
90 g
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute
reference for matching.
Two-component anti-acid epoxy
sealant for 0-2 mm grouts, for
indoor and outdoor applications.
Product of a high technical and
aesthetic performance that can
be used as an adhesive. Ideal
whenever a high degree of
hygiene, mechanical resistance
or resistance to chemical
aggression are required, with
a refined aesthetic finish when
materials are butt-jointed.
Conforms to the EN 13888 standard,
Class RG as a sealant.
Conforms to the EN 12004 standard,
Class R2T as an adhesive.
BLUCOLORS ZERO
FIELD OF APPLICATION:
Grouting the joints of floor
and wall coverings of any
type, i.e. ceramic tiles, both
single and double fired,
porcelain gres, klinker, nonporous natural stone, granite,
agglomerated marbles. Ideal
for glass, ceramic and marble
mosaics. Excellent for pools,
bathrooms, kitchen counters,
wellness centres, wine
cellars, dairies, aggressive
water tanks, food processing
plants, industrial kitchens,
fisheries, slaughterhouses and
butcheries.
83
Appearance: Comp. A = dense paste - Comp. B = dense liquid;
available in 7 different colours
Storage: 12 months in a dry place away from freezing and high
temperatures
CODE
COLOUR
PACKS/PALLET
793
ULTRA WHITE
3 kg
797
LIGHT GREY
3 kg
846
ICE
3 kg
798
GREY
3 kg
799
BLACK
3 kg
794
LIGHT SAND
3 kg
795
IVORY
3 kg
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute
reference for matching.
Approximate estimated consumption of BLUCOLORS ZERO in kg/m²
Tile size
B
C
1 mm
20
20
4
0.6
1.2
50
50
4
0.24
0.48
50
50
8
0.48
0.96
75
150
6
0.18
0.36
100
100
6
0.18
0.36
100
100
10
0.3
0.6
100
100
8
0.24
0.48
100
200
6
0.14
0.24
100
200
10
0.23
0.46
150
150
6
0.12
0.24
200
200
8
0.12
0.24
150
150
10
0.2
0.4
120
240
12
0.23
0.46
250
250
12
0.15
0.30
(A+B)
x C x D x 1.5 = kg/m2
(AxB)
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
D = joint width
A
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
2 mm
Anti-acid two-component
epoxy grout for joints from
3 to 15 mm, for indoor
and outdoor use. Excellent
also as an adhesive.
Ideal in cases in which a
high degree of hygiene
or mechanical strength
or resistance to chemical
aggression are required.
Classified as R2T in compliance with
standard EN 12004 and as RG in
compliance with standard EN 13888
84
FE 838
FIELD OF APPLICATION:
Grouting the joints of floor and
wall coverings of any type,
i.e. ceramic tiles, both single
and double fired, porcelain
gres, klinker, natural stone,
marble, granite, agglomerated
stones, vitreous ceramic and
marble mosaics. Ideal for
pools, butcheries, wine cellars,
dairies, aggressive water
tanks, food processing plants,
industrial kitchens.
CHARACTERISTICS
- pot-life: 45 min
- thermal resistance: -20/+140°C
- excellent resistance to acids
- excellent resistance to alkalis
- excellent resistance to oils
- adhesion after 28 days 3 N/mm2
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: Comp. A = dense paste 9.4 Kg - Comp. B = dense liquid
6.5 Kg; available in 4 colours
Storage available in: 12 months in a dry place away from freezing and
high temperatures
Approximate estimated consumption of FE 838 kg/m²
Tile size
A
20
50
100
200
300
400
500
600
B
20
50
100
200
300
400
500
600
D = joint width
C
4
4
10
8
8
10
12
12
3 mm
2
0.8
1
0.4
0.3
0.3
0.3
0.2
(A+B)
x C x D x 1.6 = kg/m2
(AxB)
5 mm
3.2
1.3
1.6
0.7
0.5
0.4
0.4
0.4
8 mm
5.2
2.1
2.6
1.1
0.7
0.7
0.7
0.6
10 mm
6.4
2.6
3.2
1.3
0.9
0.8
0.8
0.7
A = tile length (mm)
B = tile width (mm)
C = tile thickness (mm)
D = joint width (mm)
12 mm
7.7
3.1
3.9
1.6
1.1
1
1
0.8
15 mm
9.6
3.9
4.8
2
1.3
1.2
1.2
1
CODE
COLOUR
PACK
PACKS/PALLET
875K
white
10 kg
48
877K
GREY
10 kg
48
878K
CHARCOAL
10 kg
48
887K
BEIGE
10 kg
48
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute reference for matching.
85
Water based cleaner for
removing epoxy grout
residues on non-absorbent
materials.
86
DETERPOXY
FIELD OF APPLICATION:
Removal of residues from
use of epoxy grouts of the
BLUCOLORS line and of FE
838; suitable for final cleaning.
Diluted 1:5 with water, it
enhances and gives more
gloss to the grouting with the
BLUCOLORS line. Diluted
it also degreases very dirty
ceramic floors. Perfect for the
removal of epoxy encrustations
on materials and tools used on
the building site.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Appearance: straw-colored liquid
Storage: 24 months in a dry place away from freezing and high
temperatures
Consumption: 150 g/m2 depending on the amount of residue to be removed
TECHNICAL SPECIFICATIONS
Pot-life: 15-20 minutes
CODE
COLOUR
PACK
809
straw-yellow
1 l tank
87
Neutral-reticulation, mould-resistant
silicone sealant with low modulus of
elasticity, for absorbent or
non-absorbent materials.
Its special formulation makes it ideal
for sealing expansion and perimeter
joints, with application on various types
of substrates, either porous or smooth,
such as ceramics, cement, metal,
glass and rigid plastics.
Particularly suitable for marble, granite
and natural stones. Suitable for interior
and exterior applications.
In compliance with standards: ISO 11600F25LM and G-25LM
88
FASSASIL NTR
FIELD OF APPLICATION:
Sealing all types of ceramic
floors and coverings: single
and double fired, porcelain
gres, klinker. Sealing floors
and coverings made from
stone materials, natural
stone, marble, granite and
agglomerates. Sealing glass,
ceramic or marble mosaic tiles.
Sealing interiors and exteriors.
CHARACTERISTICS
- excellent resistance to
sunlight, water and snow
- neutral and odourless
reaction
- increased resistance to mould
- application temperature: from
+5°C to +40°C
- working temperature from
-40°C to +150°C
Appearance: thixotropic paste available in 10 colours
Storage: 12 months in a dry place
Consumption
Size of joint
(mm)
Metres for single
cartridge (ml)
5x5
12
10x5
6
10x10
3
15x10
2
20x10
1.5
CODE
COLOUR
1010S
TRANSPARENT
1006S
WHITE
1003S
LIGHT GREY
1001S
QUARTZ GREY
1002S
MANHATTAN
1007S
CHARCOAL
1004S
JASMINE
1005S
BEIGE
1009S
BROWN
1008S
SAND
PACK
24x300 ml
cartridge
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute
reference for matching.
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
Silane-terminated mouldresistant polymer adhesivesealant with low modulus of
elasticity, moisture curing.
Ensures high performance
sealing and adhesion, giving
a permanently flexible-elastic
result in both interiors and
exteriors, on floors and
coverings.
Also adheres to wet
surfaces.
Can be painted over.
SYLAN 290
FIELD OF APPLICATION:
Sealing all types of ceramic
floors and coverings, ideal for
exterior façades, pools and
driveways.
Sealing floors and coverings
made from stone materials,
natural stone, marble, granite,
agglomerates and glass.
Attaching and sealing
insulating and soundproofing
panels, insulation materials,
polystyrene profiles and panels.
CHARACTERISTICS
- exceptional weather
resistance
- excellent adhesion on wet
surfaces
- application temperature from
-5°C to +40°C
- working temperature from
-40°C to +100°C with peaks
at 150°C
- can be driven over
- good sound and vibration
absorption properties
- suitable for use in
environments where foods
are processed
For a proper evaluation and use of the product read the data sheet on the www.fassabortolo.com website
89
Appearance: thixotropic paste available in 5 colours
Storage: 24 months in a dry place
Conumption
Size of joint
(mm)
Metres per single
cartridge (ml)
5x5
12
10x5
6
10x10
3
15x10
2
20x10
1.5
CODE
COLOUR
1012S
WHITE
1014S
LIGHT GREY
1011S
QUARTZ GREY
1015S
BLACK
1013S
BROWN
PACK
12x290 ml
cartridge
Please note that the colours shown are for illustrative purposes only and cannot be used as an absolute
reference for matching.
ACCESSORI
TILE CROSS
SPACERS
1 mm
Item 900026 - 500 pcs
2 mm
Item 900012 - 500 pcs
3 mm
Item 900000 - 500 pcs
4 mm
Item 900001 - 500 pcs
5 mm
Item 900002 - 500 pcs
7 mm
Item 900003 - 500 pcs
90
“T” SHAPED TILE
SPACERS
1 mm
Item 900021 - 500 pcs
2 mm
Item 900018 - 500 pcs
3 mm
Item 900016 - 500 pcs
4 mm
Item 900017 - 500 pcs
5 mm
Item 900019 - 500 pcs
LEVEL TILE BASE
Item 900013 - 250 pcs
LEVEL TILE RING
Item 900014 - 250 pcs
WEDGE
0 - 5 mm
Item 900004
JOINTS
PVC expansion joint 8x8
Item 900005
PVC expansion joint 8x10
Item 900006
PVC expansion joint 8x14
Item 900008
ACCESSORI
RUBBER
FLOATS
250x110 mm polyurethane float
Item 240600
250x110 mm polystyrene float
Item 240602
SPONGES
290x150x40 mm sponge float
Item 221570
Interchangeable sponge float
290x150x40 mm
Item 251580
Spare for float
with 290x150x40 mm sponge
Item 221590
FELT FLOAT
AND REPLACEMENT FELTS
Felt float for cleaning
250x110 mm
Item 240650 - 2 pcs
Coarse-grained felt K16/24
for roughing
Item 240655 - 6 pcs
Mid-grained felt K40/60
Item 240657 - 12 pcs
Fine-grained felt K320
Item 240662 - 12 pcs
Fine-grained felt K220 for polishing
Item 240660 - 12 pcs
RINSING BUCKET
FOR SPONGES
Rinsing bucket for cleaning sponges
Item 240400
91
ALPHABETICAL INDEX OF PRODUCTS
57
67
90
45
48
49
64
65
62
63
50
53
39
38
42
40
41
52
60
51
80
83
13
34
56
86
17
79
32
43
20
59
58
88
54
70
74
72
76
84
33
30
82
61
78
19
31
44
66
26
27
28
29
16
18
15
14
24
25
55
23
12
21
22
89
A 81
ACCESSORIES FOR ADHESIVES
ACCESSORIES FOR GROUTING
ACCESSORIES FOR WATERPROOFERS
AD 8
ADYS
ADYTEX 2K
ADYTEX RS
ADYWOOD 2K
ADYWOOD MS
AP 71 FLEX
AQ 60 STONE
AQUAZIP ADV
AQUAZIP GE 97
AQUAZIP HIBRIDO
AQUAZIP ONE
AQUAZIP RDY
AT 99 MAXYFLEX
AX 91
AZ 59 FLEX
BLUCOLORS
BLUCOLORS ZERO
CALCESTRUZZO CELLULARE
CR 90
CRISTAL-TECH
DETERPOXY
E 439
FASSA CLEAN D 91
FASSA REMOVE
FASSABLOCK
FASSACEM
FASSAFIX
FASSAFIX 1000
FASSASIL NTR
FASSATECH 2
FC 830 GF 0-4
FC 854 GG 4-15
FC 869 GM 2-10
FC 872 GM 2-20
FE 838
FIBER MST 20
GAPER 3.30
GLITTER LUXOR PER BLUCOLORS
LATEX DE 80
LATEX DR 843
LEGEO MIX
LEVEL 30
MO 660
PRIMER ADW - DILUENTE ADW
PRIMER DG 74
PRIMERTEK 101
PRO-MST
REPAR MST SE 477
SA 500
SC 420 - SC 420 P
SILENS SLE 23
SILENS STA 10
SL 416
SM 485
SPECIAL ONE
SR 450
ST 444
SV 472
SV 472 P
SYLAN 290
93
NOTES
NOTES
PRODUCTION FACILITIES - Italy
Spresiano (TV) - tel. +39 0422 521945 - fax +39 0422 725478
Artena (Roma) - tel. +39 06 951912145 - fax +39 06 9516627
Bagnasco (CN) - tel. +39 0174 716618 - fax +39 0422 723041
Bitonto (BA) - tel. +39 080 5853345 - fax +39 0422 723031
Calliano (AT) - tel. +39 0141 915145 - fax +39 0422 723055
Mazzano (BS) - tel. +39 030 2629361 - fax +39 0422 723065
Molazzana (LU) - tel. +39 0583 641687 - fax +39 0422 723045
Moncalvo (AT) - tel. +39 0141 911434 - fax +39 0422 723050
Montichiari (BS) - tel. +39 030 9961953 - fax +39 0422 723061
Popoli (PE) - tel. +39 085 9875027 - fax +39 0422 723014
Ravenna - tel. +39 0544 688445 - fax +39 0422 723020
Sala al Barro (LC) - tel. +39 0341 242245 - fax +39 0422 723070
FASSALUSA Lda - Portugal
São Mamede (Batalha) - tel. +351 244 709 200 - fax +351 244 704 020
SALES BRANCHES
Italy
Altopascio (LU) - tel. +39 0583 216669 - fax +39 0422 723048
Bolzano - tel. +39 0471 203360 - fax +39 0422 723008
Sassuolo (MO) - tel. +39 0536 810961 - fax +39 0422 723022
FASSA SA - Switzerland
Mezzovico (Lugano) - tel. +41 (0) 91 9359070 - fax +41 (0) 91 9359079
Aclens - tel. +41 (0) 21 6363670 - fax +41 (0) 21 6363672
Dietikon (Zurigo) - tel. +41(0) 43 3178588 - fax +41 (0) 43 3211712
FASSA FRANCE Sarl - France
Lyon - tel. 0800 300338 - fax 0800 300390
FASSA HISPANIA SL - Spain
Madrid - tel. +34 606 734 628
FASSA UK Ltd - United Kingdom
Slough - tel. +44 (0) 1753573078
DEP056IN - 07/15
FASSA S.r.l.
Via Lazzaris, 3 - 31027 Spresiano (TV)
tel. +39 0422 7222 - fax +39 0422 887509
www.fassabortolo.com - [email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
