Industrial Components & Devices
Line Card Catalog
Many products sold by Fortune 500
companies use Panasonic technology,
and we are proud to provide
manufacturers with the performance,
quality, and reliability that are
synonymous with the Panasonic brand.
Our broad product
portfolio draws on a level of
proprietary technology rarely
found anywhere else in the world, giving
Panasonic added value that competitors
find difficult to achieve.
Panasonic brings strategic innovations
to our customers’ product development
process. We provide the technology
and engineering resources to enable
manufacturers to plan and build
world-class solutions to meet their
customer needs.
Our technology is deeply embedded within
our customers’ products, and our measure
of success is the confidence and trust
shown in our technology when it becomes
the core of our customers’ products.
At Panasonic, we’re driven to make what
matters most, better. Just another way
we’re engineering a better world for you.
Engineering and manufacturing form the
core of our company’s strength, infusing
our entire product line, from the smallest
component to the most
complex devices.
Design and specifications are subject to change without notice.
Please review technical specifications before purchase.
For any questions regarding these products, please visit na.industrial.panasonic.com.
3
RELAYS
Power 7-9
PhotoMOS®10-11
Solid State 12
Automotive13-14
Microwave Devices
14
Signal15
CAPACITORS
OS-CON™: Polymer Aluminum 17
17
SP-Cap™: Polzymer Aluminum
™
18
POSCAP : Polymer Aluminum
Gold Cap: Electric Double Layer Radial Lead
18
Leaded Aluminum Electrolytic
19
Surface Mount Aluminum Electrolytic
20
Ceramic21
Film, Leaded
22
Film, Surface Mount Chip
23
RESISTORS
Surface Mount Resistors
Power Resistors & Thermistors
Fuse Resistors
Axial Leaded Resistors
ESD Suppressors
Resistor Arrays & Networks
25-27
28
28
28
29
29
CONNECTORS
Narrow Pitch Board to FPC
Narrow Pitch Board to Board
FPC Connectors
Micro Coaxial
Active Optical
Stacking for High Current
31
31-32
32
33
33
33
INDUCTORS
Power Choke Coils Chip Inductors
EMI Filters
Chip Choke Coils 35-36
37
37
37
4
SENSORS
Passive Infrared
Infrared Array: Grid-EYE
Passive Light: NaPiCa
Air Pressure
Acceleration Active Light 39
39
40
40
40
41
ELECTROMECHANICAL
SENSORS
Light Touch Switches
43-44
Detector Switches
45
Snap Action Switches
46-47
Interlock Switches
48
Operation Switches
48
Encoders49
Potentiometers49
ELECTROMECHANICAL
CIRCUIT PROTECTION
Thermistors51
ZNR Surge Absorbers
51
Varistors51-53
Varistor Arrays
53
Pyrolytic Graphite Sheet (PGS)
53-54
EMI Filters
55
WIRELESS CONNECTIVITY
Bluetooth RF Modules
802.15.4 (Mesh) RF Modules ISM (Industrial, Scientific, Medical) RF Modules
WiFi, WiFi + BT RF Modules
57
57
57
58
®
SEMICONDUCTORS
Diodes61
Transistors 61
MOSFETs62
ASSP63-64
5
RELAYS
na.industrial.panasonic.com/products/relays-connectors
Power
PhotoMOS®
Solid State
Automotive
Microwave Devices
Signal
RELAYS
POWER
Series
Contact
Arrangement
Nominal Switching
Capacity (A)
Max. Switching
Voltage (V)
Latching:
Single Side
Stable (S)
Nominal Operating Power
(mW)
250VAC, 30VDC
S
0.53W, 0.9VA
10A 30VDC/250VAC (1c)
AHN
1a, 1c, 2c
5A 30VDC/250VAC (2c)
General Purpose Power Relays
16A 30VDC/250VAC (1a)
AC (50Hz): 1.3VA, AC
(60Hz): 1.2VA
10A 250VAC (1c)
HC
1c, 2c, 3c, 4c, 4c twin
7A 250VAC (2c, 3c)
250VAC
S
5A 250VAC (4c)
DC: 0.9 to 1.1W
3A 250VAC (4c twin)
7A 250VAC (2c)
HJ
2c, 4c
HK
1c, 2c
5A 250VAC (4c)
15A 125VAC (1c)
250VAC, 125VDC
S
250VAC, 125VDC
S
10A 125VAC (2c)
Safety Power Relays
AC: (50Hz) 1.3VA, (60Hz) 1.2VA
DC: 0.9 to 1W
10A 125/250VAC (1c, 2c)
NON-Polarized Power Relays
0.9W, 1.2VA
AC: (50Hz) 1.3VA, (60Hz) 1.2VA
HL
1c, 2c
250VAC
SFS
2a2b, 3a1b, 4a2b,
5a1b, 3a3b
6A 250VAC/125VDC
SFY
2A2B, 3A1B, 4A2B,
5A1B
6A 250VAC, 6A 30VDC
250VAC, 30VDC
S
670
ALA
2a
3A 125VAC, 5A 277VAC
125VAC, 277VAC
S
530
ALDP
1a
5A 277vac
277VAC
S
200mW
ALE
1a
16A 277VAC
277VAC
S
200 (std),
400 (high sensitivity)
ALF
1a
20A 250VAC
250VAC
S
900
250VAC
S
1400mW
440VAC
S
400
30VDC, 277VAC
S
1.7 to 2.7VA
(AC coil)
250VAC
S
1920
250VAC
S
900
15A 125VAC (1c)
250VAC, 125VDC
S
S
DC: 0.9 to 1W
360
(2a2b, 3a1b)
500
(4a2b, 5a1b, 3a3b)
22A 250VAC (Standard)
ALFG
1a
31A 250VAC (1.5mm contact gap
High capacity type)
33A 250VAC (1.8mm contact gap
High capacity type)
ALZ
1a, 1c
HE
1a, 2a
HE-PV
1a, 1a (high capacity)
JM
1a
16A 250VAC
30A 277VAC (1a)
1.92W (DC coil),
25A 277VAC (2a)
35A 250VAC (1a)
48A 250VAC (1a high capacity)
20A 250VAC
7
POWER
RELAYS
Series
Contact
Arrangement
Nominal Switching Capacity (A)
Max. Switching
Voltage (V)
Latching:
Single Side
Stable (S)
Nominal
Operating Power
(mW)
200
(1a, 1a high capacity)
1a standard: 2A 250VAC, 5A 30VDC/125VAC
1c standard NO: 2A 250VAC, 3A 30VAC,
5A 125VAC
JQ
1a, 1a (high capacity), 1c,
1c (high capacity)
1c standard NC: 1A 30VDC, 1A 250VAC,
2A 125VAC
250VAC, 110VDC (0.3A)
S
1a high capacity: 5A 30VDC/250VAC,
10A 125VAC
400
(1c, 1c high capacity)
1c high capacity NO: 5A 30VAC/250VAC,
10A 125VAC
1c high capacity NC: 1A 30VDC, 2A 250VAC,
3A 125VAC
JS
1a, 1c, 1a (long life)
1a, 1c: 5A 30VDC, 6A 277VAC,
10A 125VAC, 10A 250VAC (NO)
250VAC, 100VDC (0.5A)
S
360
277VAC
S
800
277VAC
S
1000
30VDC, 277VAC
S
1a (long life): 10A 250/277VAC, 5A 30VDC
20A 277VAC (1a, 1c NO)
JTN
1a, 1c
10A 277VAC (1c NC)
20A 277VAC (1a, 1c NO)
NON-Polarized Power Relays
JTV
1a, 1c
10A 277VAC (1c NC)
10A 30VDC, 125/277VAC
JVN
200 (4.5 to 48VDC)
1a
16A 125VAC
600 (100VDC)
5A 30VDC/250VAC (1a, 1c, 2a, 2c)
JW
1a, 1c, 2a, 2c
250VAC, 30VDC
S
530
10A 250VAC/30VDC (1a, 1c)
LFG
1a
31A 250VAC
250 VAC
S
1400
LKP
1a
10A 277VAC, 5A 30VDC
30VDC, 277VAC
S
530
1a: 5A 250VAC, 5A 30VDC
LQ
1a, 1c
1c: 5A 250VAC (NO),
5A 30VDC (NO), 2A 250VAC (NC),
1A 30VDC (NC)
200mW (1a)
250 VAC
S
400mW (1c)
2c DC: 360mW
(740mw: 100 VDC)
NC
2c, 4c
5A 250VAC
250VAC
S
2c AC:
0.5 to 1.05 VA
4c DC: 720mW
(740mW:100 VDC)
4c AC:
1.08 to 1.3VA
PA
1a
5A 250VAC/30VDC
110VDC, 250VAC
S
120 mW
(5 to 18 VDC)
170 mW
(5-24 VDC)
PF
1a, 1c
6A 250VAC
250VAC
S
217 mW (48 V DC)
175 mW (60 V DC)
PQ
1a
5A 250VAC/30VDC
110VDC (0.3A), 250VAC
8
S
200
RELAYS
POWER
Series
Contact
Arrangement
Max. Switching
Voltage (V)
Latching:
Single Side Stable (S),
1 coil latching (L1),
2 coil latching (L2)
250 VAC
S, L1, L2
150 (L1),
250 (S, L2)
250 VAC
L1, L2
500 (L1),
1000(L2)
380 VAC,
125 VDC
S, L2
200
250 VAC,
30 VDC
S, L2
200
8A 250VAC/30VDC (1a1b, 2a)
250 VAC,
125 VDC
S, L2
200
60A 250VAC
250 VAC
L1, L2
500 (L1),
1000 (L2)
5A 250VAC/30VDC (1a, 1a1b, 2a)
380 VAC,
125 VDC
S, L2
300
Nominal Switching
Capacity (A)
Nominal
Operating
Power (mW)
16A 250VAC (1a, 1b, 1c)
ADJ
1a, 1b, 1c, 1a1b, 2a,
2b, 2c
10A 250VAC (1a1b, 2a, 2b 2c)
ADQ
1a
30A 250VAC
10A 250VAC/30VDC (1a)
ADY
1a, 1a1b
DE
1a, 1a1b, 2a
DK
1a, 1a1b, 2a
DQM
1a
DSP
1a, 1a1b, 2a
DW
1a
8A 250VAC(standard type)
16A 277VAC( Inrush type)
8A 250VAC(standard type)
16A 277VAC(Inrush type)
L1, L2
200 (L1)
400 (L2)
S
2a2b, 3a1b, 4a
4A 250VAC, 3A 30VDC
250 VAC, 48 VDC
(30~48 VDC at less than
0.5 A)
S, L2
200
SP
2c, 4c
250 VAC, 30 VDC
(48V DC: Max. 2A)
S, L2
300
8A 250VAC/30VDC (1a1b)
10A 250VAC/30VDC (1a)
8A 250VAC/30VDC (1a1b, 2a)
Polarized Power Relays
10A 250VAC/30VDC (1a)
8A 250VAC (1a)
15A 250VAC (2c)
High Capacity DC Power Relays
10A 250VAC (4c)
ST
1a1b, 2a
8A 250 VAC
380 VAC,
250 VDC
S, L2
240
AEJ
1a
100A 100VDC
100 A, 100 VDC
S
5W
ADZ
1a
120A 250 VAC
276 VAC
L1, L2
1400mw (L1)
2800mw (L2)
10A 400VDC
(Molybdenum)
10 A, 400 VDC
S
Max 1.4W
80A 400VDC
(Tungsten, Copper alloy)
8 A, 400 VDC
S
Max 4.5W
200A 400VDC
(Lead Wire type)
200A 400VDC
S
Max 4 to 6W
300A 400VDC
(Copper alloy)
300 A, 400 VDC
S
Max 4 to 40W
20A 800VDC
(400VDC at each 1 form A contact)
1000 VDC
S
1920
AEP
HEV
1a
(Molybdenum), 1a
(tungsten,
copper alloy),
1a (copper alloy)
2a
9
PHOTOMOS
RELAYS
Load Voltage
Load Output
0.11 - 0.2 A
1a
PKG
20V
25V/30V
40V
80V
100V
200V
250V
350V
SOP4
1a
DIP4
1a
SOP6
400V
1a
DIP6
SOP8
1a1b
DIP8
1b
1b
1b
SOP4
SOP6
DIP6
2a
SOP8
AQW227NS
AQW210S
2a
DIP8
AQW227N
AQW210HL
2b
SOP8
AQW414S
2b
DIP8
AQW414EH
AQW414
4a
SOP16
1a
VSSOP
1a
VSSOP
1a
SSOP
1a
VSSOP
AQY221N5T
SSOP
AQY221N5V
AQV221
AQV225
AQV227N
AQV216S
AQV216
AQW610S
AQW614EH
AQW614
AQY414S
AQV414S
AQV414
AQW214S
AQW224N
AQW214EH
AQW214
AQS221FN2S
AQS225R2S
AQS221N2S
AQY221N3T
AQY221N2T
AQY225R3V
1a
SON
AQY221N3M
AQY221N2M
1a
SSOP
AQY221N3V
AQY221FN2V
AQY225R2V
AQY221N2V
1a
SOP4
1a
DIP4
1a
SOP6
AQY221N2S
AQY225R2S
AQV217S
AQV217
AQY210KS
AQY210LS
AQY210S
AQY230S
AQY210EH
AQY214EH
AQV210S
AQV253
AQV253H
AQV203
AQV210E
AQV210EH
AQV210
AQV214E
AQV214EH
AQV214
AQV214H
AQV254
AQV254H
AQV104
AQV204
AQV234
AQW610EH
AQW654
1a
DIP6
1a1b
DIP8
1b
SOP4
AQY410S
1b
DIP4
AQY410EH
AQY414EH
1b
DIP6
AQV453
AQV410EH
AQV414E
AQV414EH
AQV454
AQV454H
2a
SOP8
AQW223R2S
2a
DIP8
AQW210EH
AQW210
AQW254
2b
DIP8
SOP16
1000V 1500V
AQY216EH
AQV214S
AQV224NS
AQV224N
AQV227NS
1a1b
4a
600V
AQY214S
AQY234S
AQW217
AQW454
AQS221FR2S
AQS221R2S
10
AQW216EH
AQW216
AQV259
AQV258
RELAYS
PHOTOMOS
Load Voltage
4.1-10A
2.1-4A
1.1-2A
0.51-1A
0.21-0.5A
Load
Output
Packaging
25V/30V
40V
50V
60V
80V
100V
1a
VSSOP
1a
VSSOP
1a
VSSOP
1a
SON
AQY221R2M
1a
SSOP
AQY221FR2V
AQY221R2V
AQY221R4V
1a
SOP4
AQY221R2S
AQY212S AQY232S
AQY222R1S
1a
SOP6
AQV212S
AQV215S
AQV251
AQV201
AQV112KL AQV252
AQV202
AQV215
AQV255
200V
250V
AQV257
AQV103
400V
AQY221R2T
AQY222R2T
AQY221R2T
AQY225R1S
1a
DIP6
1a
Power-DIP4
AQY274
1a
SIL4
AQZ204
AQZ204D
1b
SOP4
AQY412S
1b
SIL4
1a1b
SOP8
AQW612S
AQZ404
1a1b
DIP8
AQW612EH
2a
SOP8
AQW212S
2a
DIP8
AQW212EH
AQW212
1a
VSSOP
AQY221R6T
1a
SSOP
AQY221R6V
1a
SOP4
AQY212GS
1a
DIP4
1a
Power-DIP4
1a
DIP6
1a
SIL4
1b
DIP4
1b
DIP6
1a
SOP
1a
SOP4
AQY212G2S
1a
DIP4
AQY212GH
1a
SOP6
1a
Power-DIP4
1a
SIL4
1a
SOP
1a
DIP6
1a
SIL4
1a
SIL4
1a
SIL4
AQW215
AQY211EH
AQY212EH
AQY277
AQV101
AQV212 AQV102
AQZ207
AQZ207D
AQY412EH
AQV412EH
AQY211G2S
AQV255GS
AQY272
AQY275
AQZ205
AQZ205D
AQZ107
AQZ107D
AQV252G2S
AQV251G
AQV252G
AQZ102 (DC)
AQZ102D (DC)
AQZ202 AQZ202D
AQZ105
AQZ105D
AQZ197
AQZ192 (DC)
AQZ262
11
AQZ104
AQZ104D
AQZ264
SOLID STATE Series
AQAD
AQ-C
AQ-F
Through-hole & SMD
AQ-G
AQ-H
RELAYS
Installation
Method & Shape
Screw mounting,
hockey puck type
PC board terminal, DIL
Load Current
Load Voltage
Non-repetitive
surge current
30A
100VDC
90A
10A
600VDC
20A
1A
3 to 60VDC
1.5A
1A
75 to 125/250VAC
20A
25mA
4 to 32VDC
-
2A & 3A
75 to 250 VAC
80A
2000VAC
2A & 3A
3 to 60 VDC
5A & 6A
2500VAC
1A
75 to 264VAC
8A
2A
75 to 264VAC
30A
Breakdown Voltage
4,000 Vrms between input and output
2500 Vrms between input and output case
2500VAC
Plug in terminal
PC board terminal, SIL
3000VAC
0.3A
3A
0.6A
6A
0.9A
9A
1.2A
12A
PC board terminal, DIP8
5000VAC
1A
10 to 200VDC
5A (1sec.)
2A
3 to 60VDC
5A (1sec.)
3A
75 to 250VAC
80A
10A
(Heat sink)
75 to 250VAC
100A
2A
75 to 125/250VAC
30A
3A
75 to 125/250VAC
80A
3000VAC
AQ1
Phototriac
Coupler
AQ8
PC board terminal, SIL
AQ-J
AQ-J
PC board terminal,
SOP & DIP
Screw mounting,
hockey puck type
DIN rail mounting,
hockey puck type
Screw mounting, hockey puck
type (tab terminal)
4000VAC
(between input & output)
2500VAC
(between input, output & case)
3000VAC
0.05A
APT
AQ-A
High Capacity
PC board terminal, SIL
0.1A
-
0.6A
3750VAC
1.2A
5000VAC
30A
4 to 32 VDC
90A
15A
75 to 250 VAC
150A
25A
75 to 250 VAC
250A
40A
75 to 250 VAC
400A
10A
75 to 264VAC
100A
20A
75 to 264VAC
250A
15A
75 to 264VAC
100A
10A
75 to 264VAC
100A
15A
75 to 264VAC
150A
25A
75 to 264VAC
250A
12
4000VAC (between input & output)
2500VAC (between input, output & case)
3000 Vrms
(between input & output)
2500 Vrms
(between input, output & case)
3000 Vrms
(between input & output)
2500 Vrms
(between input, output & case)
RELAYS
AUTOMOTIVE
Series
Contact
Arrangement
Nominal Switching Capacity (A)
(Resistive Loads)
Max. Switching Voltage
(V)
Nominal Operating Power (mW)
1a
20/30A 12VDC
15VDC, 16VDC, 30VDC
1.4W, 1.8W
CA
1b
20A 12VDC
1c
20A 12VDC
1a (high capacity)
70A 14VDC
16VDC (12V TYPE)
1.4W, 1.8W
1a
40A 14VDC
32VDC (24V TYPE)
1c N.O.
40A 14VDC
1c N.C.
30A 14VDC
1c
20A 14VDC (N.O.)
1cx2
10A 14VDC (N.C.)
1a
35A 14VDC (N.O.)
1c
20A 14VDC (N.C.)
1a
CB
CJ
14VDC
640/800mW
16VDC
1.5/1.8W
30A 14VDC
16VDC
450/640mW
1a
30A 14VDC (N.O.)
16VDC
640mW
1c
15A 14VDC (N.C.)
1a
20A 14VDC (N.O.)
-
640mW
1c
10A 14VDC (N.C.)
1a
20A 14VDC
-
450/640mW
-
640mW
-
800mW
-
1000mW
14VDC
800mW
120A (5sec @20C)
100VDC
1.4W
70A (1min @85C)
16VDC
CM
CN-H
CN-M
CP
Automotive
CP-Power
CQ
CT
CT-Power
CV
CW
1c
1c
10A 14VDC
20A 14VDC (N.O.)
10A 14VDC (N.C.)
1c
20A 14VDC (N.O.)
1cx2
10A 14VDC (N.C.)
1c
30A 14VDC(N.O.)
1cx2
10A 14VDC (N.C.)
1a
20A 14VDC (N.O.)
1c
2a
10A 14VDC (N.C.)
45A (continued @85C)
JJ-M
AJJM
JS-M
AEB
AEV
AEV
(Quiet)
1a
20A 14VDC (N.O.)
1c
10A 14VDC (N.C.)
Double make contact
1a
12A 14VDC
14VDC
640mW
-
1000mW
16VDC
640mW
6A 1contact
10A 16VDC
1c
15A 16VDC
1a
100A 42VDC
42VDC
5W
10A 400VDC
400VDC
1.4W
1a
1a
20A 400VDC
3.9W
80A 400VDC
4.5W
120A 400VDC
4.2W
300A 400VDC
37.9W (0.1sec inrush)
3.6W stable / 44.4(0.1sec inrush) 3.8W stable
60A 12VDC
4.5W
13
Automotive
AUTOMOTIVE, MICROWAVE DEVICES
RELAYS
Series
Contact
Arrangement
Nominal Switching Capacity (A)
(Resistive Loads)
Max. Switching Voltage
(V)
TA
1c
N.O.: 20A
N.C.: 10A
12 VDC
640mW
900mW
TB
1a
1c
1c x 2
N.O.: 20A
N.C.: 10A
12 VDC
640mW
900mW
1,440mW
TC
1a
1c
Double make contact 2a
N.O.: 30A
N.C.: 15A
12 VDC
640mW
900mW
1,309mW
TE
1c
1c x 2
(10 pin)
N.O.: 20A
N.C.: 10A
12 VDC
640mW
900mW
1,309mW
TG
1a
1c
N.O.: 30A
N.C.: 15A
12 VDC
450mW
640mW
TH
1c
1c x 2
(10 pin)
N.O.: 20A
N.C.: 10A
12 VDC
655mW
900mW
TJ
1c
N.O.: 30A
N.C.: 15A
12 VDC
450mW
Series
Contact
Arrangement
Maximum
Switching
Voltage
Frequency
Range
Contact Input
Power
Nominal Operating Power (mW)
Latching:
Single Side Stable (S),
1 Coil Latching (L1),
2 Coil Latching (L2)
Nominal Operating
Power (mW)
S: 140mW (1.5 to 12V),
200mW (24V)
300mW (48V)
High Frequency Relays
2c
30VDC
1GHz
3W @ 1GHz
S, L1, L2
L1: 70mW (1.5 to 12V),
100mW (24V)
L2: 140mW (1.5 to 12V),
200mW (24V)
ARE
1c
30VDC
2.6GHz
10W @ 2.6GHz
S
200
ARJ
2c
30VDC
8GHz
1W @ 5GHz
S, L2
200mW (S), 150mW (L2)
ARN
SPDT
1 GHz to 6 GHz
80W at 2GHz
S, L2
320mW (S), 400mW (L2)
ARS
1c
3GHz
10W @ 3GHz
S, L1, L2
200mW (S, L1),
400mW (L2)
30VDC
840mW (SPDT/SP6T, Fail-safe,
with indicator)
Coaxial Switches
Microwave Devices
ARA
ARD
ARV
SPDT, Transfer, SP6T
SPDT
30VDC 100mA
(indicator)
6 to 26.5GHz
4 to 18GHz
(PIN)
8 to 26.5GHZ
(SMA)
120W @ 3GHz
S
Max 50W @3GHz
S
14
1540mW
(Transfer, Fail-safe
with indicator)
700mW
RELAYS
SIGNAL
Series
AGN
Contact
Arrangement
Nominal Switching
Capacity (A)
Max.
Switching
Voltage (V)
2c
1A 30 VDC,
0.3 A 125 VAC
110 VDC,
125 VAC
Latching:
Single Side Stable (S),
1 coil latching (L1),
2 coil latching (L2)
S, L1,
S (high sensitivity)
Nominal Operating Power
L1 and S (high sensitivity type):
100mW (1.5 to 12VDC), 120mW (24VDC)
S: 140mW (1.5 to 12VDC), 230mW (24VDC)
L1 and S (high sensitivity type):
100mW (1.5 to 12VDC), 120mW (24VDC)
AGQ
2c
1 A 30 VDC,
0.3 A 125 VAC
110 VDC,
125 VAC
S, L1,
S (high sensitivity)
S: 140mW (1.5 to 12VDC), 230mW (24VDC)
S: 200mW (standard), 400mW (high sensitivity)
DS
1c, 2c
2 A 30 VDC
220 VDC,
250 VAC
S, L2
L2: 180mW (standard), 360mW (high sensitivity)
S 2c: 140mW (3 to 12VDC), 200mW (24VDC), 300mW
(48VDC)
S 2d M.B.B.: 200mW
S 4c: 280mW (3 to 24VDC), 400mW (48VDC)
TQ
2c,
2d (M.B.B.),
4c
1 A 30 VDC,
0.5A 125 VAC
110 VDC,
125 VAC
S, L1, L2
L1 (2c, 2d M.B.B.): 100mW (3 to 12VDC), 150mW (24VDC)
L1 4c: 200mW
L2 (2c, 2d M.B.B): 200mW (3 to 12VDC),
300mW (24VDC)
L2 4c: 400mW
Signal
S: 140, 200, 300mW
TQ-SMD
2c
2A 30 VDC,
0.5A 125 VAC
L1: 70, 100mW
220 VDC,
125 VAC
S, L1, L2
L2: 140, 200mW
S: 140 mW (1.5 to 24 V DC), 270 mW (48 V DC)
TX
2c
2A 30 VDC, 1A 30 VDC
220 VDC
S, L1, L2
L1: 100 mW (1.5 to 24 V DC)
L2: 200 mW (1.5 to 24 V DC)
2A 30 VDC (2c)
220 VDC (2c)
2c S: 200mW (1.5 to 12VDC), 230mW (24VDC)
2c L1: 150mW (1.5 to 12VDC), 170mW (24VDC)
TX-D
2c, 2d (M.B.B.)
1A 30 VDC (2d M.B.B.)
110 VDC
(2d M.B.B.)
S, L1
1A 30 VDC
110 VDC
S, L1, L2
2d M.B.B. S: 250mW (1.5 to 12VDC), 270mW (24VDC)
S: 50 mW (1.5 to 12 V DC), 70 mW (24 V DC)
TX-S
2c
L1: 35 mW (1.5 to 12 V DC), 50 mW (24 V DC)
L2: 70 mW (1.5 to 12 V DC),150 mW (24 V DC)
S: 140 mW (1.5 to 24 V DC), 270 mW (48 V DC)
TX
(TH type)
2c
2A 30 VDC,
0.5A 125 VAC
220 VDC,
250 VAC
S, L1, L2
L1: 100 mW (1.5 to 24 V DC)
L2: 140 mW (1.5 to 24 V DC)
DS2Y
2c
2A 30 VDC
220VDC
250 VAC
S
15
S: 200 mW (1.5 to 24 VDC),
300 mW (48 VDC)
CAPACITORS
na.industrial.panasonic.com/products/capacitors
OS-CON™: Polymer Aluminum
SP-Cap™: Polymer Aluminum
POSCAP™: Polymer Tantalum
Gold Cap: Electric Double Layer Radial Lead
Leaded Aluminum Electrolytic
Surface Mount Aluminum Electrolytic
Ceramic
Film, Leaded
Film, Surface Mount Chip
CAPACITORS
POLYMER ALUMINUM
Voltage
Capacitance
ESR
SVP
2.5-25 VDC
3.3-1500 μF
12-260 mΩ
SVPC
2.5-16 VDC
39-2700 μF
9-35 mΩ
SVPF
16-50 VDC
10-1000 μF
12-40 mΩ
SVPE
2-16 VDC
150-1200 μF
8-20 mΩ
SVPA
4-20 VDC
47-680 μF
19-28 mΩ
SVPD
25-30VDC
10-82 μF
28-65 mΩ
SVPG
16VDC
47μF
8 mΩ
SVPS
6.3-25VDC
10-330 μF
20-60 mΩ
SVQP
6.3-10 VDC
56-220 μF
10-45 mΩ
SEP
2.5-25 VDC
6.8-1500 μF
12-80 mΩ
SEPC
2.5-16 VDC
100-2700 μF
5-24 mΩ
SEPF
16-35 VDC
22-1000 μF
12-35 mΩ
SEQP
6.3 – 32 VDC
15-330 μF
20-80 mΩ
OS-CON: Radial Lead
OS-CON: Polymer Aluminum - Surface Mount
Series
General Purpose
Low ESR
260°C Reflow Capable
SP-CAP: Polymer Aluminum - Surface Mount
Series
Operating
Temperature
(Working Voltage)
Capacitance
Features
EEF-CD
(2 ~ 16VDC)
2.2 ~ 220 μF
•Low ESR, high ripple current
•1.8 mm height, ESR 18 mΩ maximum
EEF-CS
(4 ~35VDC)
68 ~ 120 μF
•1.2mm height
•Low ESR 15mΩ
EEF-CT
(4 ~ 35VDC)
100 ~ 180 μF
•1.5mm height
•Low ESR 15mΩ
EEF-CX
(2 ~ 35VDC)
100 ~ 560 μF
•Low ESR, high ripple current
•1.9 mm height, ESR 15 mΩ maximum
EEF-SR
(2 ~ 6.3)
68 ~ 220 μF
•1 mm max height; Low ESR
EEF-LR
(2 ~ 6.3)
68 ~ 220 μF
•1mm max height; Low ESR, 3 terminals
(2 ~ 8 VDC)
68 ~ 470 μF
•Low ESR, high ripple current
•2.8 mm height, ESR 15 mΩ maximum
EEF-UE
(2 ~ 8 VDC)
100 ~ 560 μF
•Low ESR, high ripple current
•4.2 mm height, ESR 12 mΩ maximum
EEF-GX
(2 VDC)
330 ~ 470 μF
•Super low ESR 3mΩ
EEF-LS, -LT
(2 ~ 2.5 VDC)
180 ~ 330 μF
•Low ESL by structure of SP-Cap
•50% ESL of current products
EEF-LX
(2 ~ 2.5 VDC)
330 ~ 560 μF
•Low ESL by structure of SP-Cap
•50% ESL of current products
EEF-SS, -ST
(2 ~ 2.5 VDC)
180 ~ 330 μF
•1.2mm (SS), 1.5mm (ST) height
•Low ESR 6mΩ
EEF-SL, -SX
(2 ~ 6.3 VDC)
56 ~ 560 μF
•Excellent noise absorbent characteristics
•Super low ESR (4.5mΩ - 9mΩ)
EEF-UD
-40 ~ +105ºC
17
POSCAP: Polymer Aluminum - Surface Mount
POLYMER ALUMINUM, ELECTRIC DOUBLE LAYER
Series
Voltage
Capacitance
ESR
TPE
2-10 VDC
47-1500 μF
7-35 mΩ
TQC
16-35 VDC
3.9-150 μF
40-400 mΩ
TPF
2-10 VDC
150-1000 μF
5-15 mΩ
TPSF
2 VDC
270 μF
6-9 mΩ
TPB
4-10 VDC
33-470 μF
35-70 mΩ
TPC
6.3-12.5 VDC
10-330 μF
40-80 mΩ
TPG
2.5-12.5 VDC
33-220 μF
30-70 mΩ
TPU
2.5-10 VDC
4.7-150 μF
100-300 mΩ
TA
2.5-6.3 VDC
47-220 μF
9-70 mΩ
TH
6.3 – 10 VDC
220-470 μF
35-40 mΩ
TPH
6.3 VDC
47 μF
150 mΩ
Operating
Temperature
(Working Voltage)
Capacitance
EEC-S0HD
EEC-S5R5
-25 ~ +70ºC
(5.5 VDC) 0.022 ~ 0.33 F
(5.5 VDC) 0.47 ~ 1.5 F
EEC-SE0H
-25 ~ +70ºC
(5.5 VDC)
0.022 ~ 0.22 F
EEC-F5R5U
EEC-F5R5H
-25 ~ +70C
-40 ~ +70C
-25 ~ +85C
-40 ~ +85C
(5.5 VDC) 0.22 to 1.5F
(5.5 VDC) 0.033 ~ 1.0 F
•General purpose, 1000 hours at 70c.
•General purpose, 1000 hours at 85c.
EEC-RG
EEC-RF
-25 ~ +85ºC
(3.6 VDC) 022-1.0 F
(5.5 VDC) 0.10 to 1.0 F
•2,000 hours at 85ºC, general purpose
•High Reliability
•Backup for mA-A range
EEC-HW0D
-25 ~ +70ºC
-25 ~ +60ºC
(2.3 VDC) 22 ~ 50 F
(2.1 VDC) 70 F
•Large capacitance
•Backup for mA - A range
EEC-HZ0D
-25 ~ +60ºC
(2.5 VDC) 3.3~10 F
•Large Capacitance
•Lower ESR than HW
Series
Gold Cap: Electric Double Layer Radial Lead
CAPACITORS
18
Features
•General purpose, 1,000 hours at 70ºC
•µA range IC memory back-up
•1,000 hours at 70ºC
•Lead taping for auto insertion
CAPACITORS
LEADED ALUMINUM ELECTROLYTIC
Operating
Temperature
(Working Voltage)
Capacitance
ECA-__M
-40 ~ +85ºC
(-25ºC: 160~450VDC)
(6.3 ~ 450 VDC)
0.1 ~ 22,000 μF
•General purpose, 2000 hours at 85ºC
•Compact size
ECA-__HG
-55 ~ +105ºC
(-25ºC: 160~450VDC)
(6.3 ~ 450 VDC)
0.1 ~ 22,000 μF
•Long life: 1,000~2,000 hours at 105ºC
•Compact size
EEA-GA
-55 ~ +105ºC
(10 ~ 50 VDC)
0.1 ~ 220μF
•Long life: 1000 hours at 105°C
•7mm height
EEU-HD
-55 ~ +105ºC
(10 ~ 50 VDC)
0.1 ~ 22000μF
•Long life: 1000~2000 hours at 105° C
•Case Size : 5mm x 11mm to 18mm x 35.5mm
ECE-A__KA
-40 ~ +85ºC
(4 ~ 50 VDC)
0.1 ~ 470 μF
•General purpose, 1,000 hours at 85ºC
•7 mm height
ECE-A__KK/KS
-40 ~ +85ºC
(4 ~ 50 VDC)
0.1 ~ 330 μF
•General purpose, 1000 hours at 85ºC
•5 mm height
ECE-A__N___U/X
-40 ~ +85ºC
(6.3 ~ 50 VDC)
0.47 ~ 6,800 μF
•2,000 hours at 85ºC
•Bi-Polar general purpose
EEU-EB
-40 ~ +105ºC
(-25ºC: 160~450VDC)
(10 ~ 450 VDC)
0.47 ~ 3,300 μF
•5,000~10,000 hours at 105ºC
•Very long life
EEU-ED
-25 ~ +105ºC
(160 ~ 450 VDC)
10 ~ 330 μF
•Very long life 8,000~10,000 hours at 105ºC
•High Ripple Current
EEU-EE
-25 ~ +105ºC
(160 ~ 450 VDC)
10 ~ 330 μF
•Very long life 8,000~10,000 hours at 105ºC
•High Ripple Current at high frequency
EEA/U-FC
-55 ~ +105ºC
(6.3 ~ 100 VDC)
1.0 ~ 15,000 μF
•1,000~5,000 hours at 105ºC
•Low impedance, miniature
EEU-FM
-40 ~ +105ºC
(6.3 ~ 50 VDC)
22 ~ 6,800 μF
•Long life, 2,000~7,000 hours at 105ºC
•Low ESR, approximately half of FC
EEU-FR
-40 ~ +105ºC
(6.3 ~ 63 VDC)
18 ~ 8,200 μF
•Ultra Low ESR: 12mΩ (20˚C/100kHz)
•5000 hours (case sizes 5 and 6mm Ø) ~10,000 hours at 105°C
EEU-TA
-40 ~ +125ºC
(10 ~ 63 VDC)
1 ~ 4,700 μF
•2,000 hours at 125ºC
•Automotive applications
EEU-TP
-40 ~ +135ºC
(25 ~ 35 VDC)
100 ~ 5,100 μF
•Low ESR: 16mΩ (20°C/100kHz)
•Long Life: 125°C 2000 to 5000 hours
(135° 1000 hours to 2000 hours)
105°C
Low Impedance
125ºC - 135ºC
Long Life
High Voltage
Bi-Polar
Leaded Aluminum Electrolytic
Miniature
General Purpose
85°C
Series
19
Features
Low ESR, Long Life
Bi-Polar
Hybrid
Surface Mount Aluminum Electrolytic
Long Life
General
Purpose
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
Series
Operating
Temperature
(Working Voltage)
Capacitance
EEE-_A/S
-40 ~ +85ºC
(4 ~ 100 VDC)
0.1 ~ 1,500 μF
•General purpose, 2,000 hours at 85ºC
•Very compact size
•High Temperature Reflow (260ºC)
EEE-HA
-40 ~ +105ºC
(6.3 ~ 100 VDC)
0.1 ~ 1,500 μF
•Long life, 1000~2,000 hours at 105ºC
•Very compact size
EEE-HB
-40 ~ +105ºC
(4 ~ 50 VDC)
0.1 ~ 470 μF
•Long life, 2,000 hours at 105ºC
•5.8 mm height (< Ø 6)
EEE-HC
-40 ~ +105ºC
(6.3 ~ 50 VDC)
33 ~ 1,000 μF
•Long life, 3,000~5,000 hours at 105ºC
•5.8 mm height (< Ø 6)
-40 ~ +105ºC
(6.3 ~ 50 VDC)
0.1 ~ 1000 μF
•Very long life, 5,000 hours at 105ºC
•Industrial grade
EEV-EB
-25 ~ +105ºC
(160 ~ 450 VDC)
2.2 ~ 100 μF
•Large can size
EEE-TG
EEV-TG
-40 ~ +125ºC
(10 ~ 100 VDC)
10 ~ 4,700 μF
•High temperature, 2,000 hours at 125ºC
•Low ESR at low temperature
EEE-TK
-40 ~ +125ºC
(10 ~ 35 VDC)
47 ~ 4700 μF
•High temperature, 3,000 hours at 125ºC
•Low ESR at low temperature
EEE-TP
-40 ~ +125ºC
(10 ~ 35 VDC)
47 ~ 470 μF
•Low ESR at Low Temperatures
•2,000~3,000 hours at 125ºC
EEE-FT
-55 ~ +105ºC
(6.3 ~ 50 VDC)
10 ~ 2,200 μF
•2000 hours at 105ºC
•Low ESR in smaller package
•High Temperature Reflow (260ºC)
EEE-FP
-55 ~ +105ºC
(6.3 ~ 35 VDC)
100 ~ 1,800 μF
•Very Low ESR, tantalum replacement
•High Temperature Reflow (260ºC)
EEE-FK
EEV-FK
-55 ~ +105ºC
(6.3 ~ 100 VDC)
3.3 ~ 6,800 μF
•Long life, 2,000~5,000 hours at 105ºC
•Low ESR, Tantalum replacement
•Compact, wide size range: 4~18 mm (Ø)
EEE-FC
-40 ~ +105ºC
(6.3 ~ 50 VDC)
1 ~ 1,500 μF
•1,000 hours at 105ºC
•Low impedance
EEE-___A___N
-40 ~ +85ºC
(6.3 ~ 50 VDC)
0.22 ~ 47 μF
•General Purpose
•5.4 mm height (< Ø 6)
EEE-HP
-40 ~ +105ºC
(6.3 ~ 50 VDC)
0.22 ~ 47 μF
•Industrial Grade
•5.8 mm height
EEH-ZA
-55 ~ +105ºC
(25 ~ 63 VDC)
10 ~ 330 μF
•Up to 5,000 Hours at 105°C
•Open Circuit Failure Mode
•Low ESR, High Ripple Current
EEH-ZC
-55 ~ +125ºC
(25 ~ 63 VDC)
10 ~ 330 μF
•Up to 4,000 Hours at 125°C
•Open Circuit Failure Mode
EEE-HD
NOTE:
Surface Mount Type RoHS Compliant Part Number Prefix:
•EEE (Diameter: 3~10mm)
•EEV (Diameter: 12.5~18mm)
For higher temperature reflow, use EEE (A_) suffix:
•260ºC Max. Reflow: AP & AR (4~10mm Ø)
•245ºC Max. Reflow: AQ & AM (12.5~18mm Ø)
20
Features
Ceramic
CAPACITORS
CERAMIC
Series
Operating
Voltage
Temperature
Characteristics
Capacitance Range
ECC-T3
1kVDC - 5kVDC
SL/GP
10 pF to 68 pF
ECK-T3
1kVDC - 5kVDC
Y5P
100 pF to 470 pF
ECC-TBC
250VAC
SL/GP
10 pF to 68 pF
•UL(CSA)/SEMCO Y2 approval,
1500 VAC for 1 minute
•SMD (7.1 x 6.3 x 2.5 mm)
ECK-TBC
250VAC
Y5P, Y5U, Y5V
100 pF to 4,700 pF
•UL(CSA)/SEMCO Y2 approval,
1500 VAC for 1 minute
•SMD (7.1 x 6.3 x 2.5 mm)
ECK-THC
250VAC
Y1
100 to 470 pF
•Safety Requirement Recognition:
UL, SEMKO, NEMKO, FIMKO, DEMKO
ECC-TFC
250VAC
SL/GP
5 pF to 330 pF
•UL(CSA)/SEMCO Y2 approval,
1500 VAC for 1 minute
•SMD, small size (5.7 x 4.5 x 2.3 mm)
ECK-TFC
250VAC
Y5P, Y5U, Y5V
470 pF to 4,700 pF
•UL(CSA)/SEMCO Y2 approval,
1500 VAC for 1 minute
•SMD, small size (5.7 x 4.5 x 2.3 mm)
21
Features
•Molded SMD case for reflow soldering
•Molded SMD case for reflow soldering
Metallized Polyester
Metallized
Polypropylene
Film, Leaded Interference Suppressors
Polypropylene
Metallized Film, Leaded
Polyester
Plastic
FILM, LEADED
CAPACITORS
Series
Operating
Temp.
ECWF-E
-40 ~ +105ºC
1.0 ~ 2.2 µF
450 VDC
•Boxed construction
•Active Filter Circuits
•High Frequency
•High Current circuits
ECQ-E(H)
-40 ~ +105ºC
0.1 ~ 2.2 µF
450 VDC
•Smaller Size
•Active filtering circuit
ECQ-E(F)
-40 ~ +85ºC
0.001 ~ 10 µF
100 ~ 1250 VDC
•Wide capacitance range
•Compact size
•General purpose applications
ECQ-E(B)
-40 ~ +85ºC
0.01 ~ 4.7 µF
250 VDC
•Wide capacitance range
•Miniaturized
•General purpose applications
ECW-F(L)
-40 ~ +105ºC
0.022 ~ 2.4 µF, 400 VDC
0.01 ~ 1.3 µF, 630 VDC
•Low Dissipation Factor
•High Voltage
•High Frequency
•High Current Circuits
ECW-F(B)
-40 ~ +105ºC
0.022 ~ 0.47 µF
400 VDC
•Low Dissipation Factor
•High Frequency
•High Current Circuits
ECW-H(V)
-40 ~ +105ºC
0.001 ~ 0.1 µF
800 ~ 2000 VDC
•Low Dissipation Factor
•High pulse circuits
(TV, display, electronic ballast)
ECW-F(A)
-40 ~ +105ºC
0.1 ~ 6.8 µF
250/450/630 VDC
•Miniaturized Size
•High Reliability Design
•Active Filter in PFC Circuits
ECW-F(D)
-40 ~ +105ºC
0.47 ~ 2.2 µF
450 VDC
•Miniaturized Size
•Flame Retardant Case
•Low Hum Noise
•High Frequency
•High Current Circuits
ECW-H(A)
-40 ~ +105ºC
0.001 ~ 0.047 µF
800/1600 VDC
•Miniaturized Size
•High Product Safety
•Low Hum Noise
•Resonance circuits found in AC
to DC Power Supplies
•Active Filter in PFC Circuit
ECW-H(C)
-40 ~ +85ºC
0.18 ~ 0.33 µF
630 VDC
•Miniaturized Size
•High Product Safety
•Low Hum Noise
•Resonance-Microwave &
Infrared Heat Cooker
EZP-E
-40 ~ +70ºC
10 µF ~ 60 µF
800/1100 VDC
•Rectangle type
•High safety
•Low hum noise
•DC Linkage
ECQ-U(G)
-40 ~ +100ºC
0.01 ~ 1.0 µF
300 VAC
(IEC384-14)
•Flame retardant case
•Equipped with safety mechanism
•UL, CSA, SEMKO, DEMKO, NEMKO, FIMKO,
VDE, SEV approved (Class X1)
•Noise suppressor for AC line
ECQ-U(L)
-40 ~ +100ºC
0.001 ~ 2.2 µF
250 VAC (ΜL, CSA)
275 VAC
(IEC384-14)
•Smaller size than ECQ-U(V) or ECQ-U(G)
•UL, CSA, VDE approved (Class X2)
•Equipped with safety mechanism
•High performance, fuse function in AC line
ECQ-U(A)
-40 ~ +100ºC
•Smaller size than ECQ-U(V) or ECQ-U(G)
•UL, CSA, VDE approved (Class X2)
•Equipped with safety mechanism
•High performance, fuse function in AC line
Ratings
0.1 ~ 2.2 µF
275 VAC
Features
22
Applications
Stacked Metallized
Film, Surface Mount Chip
CAPACITORS
FILM, SURFACE MOUNT
Series
Operating
Temp.
ECH-U(X)
-55 ~ +105ºC
0.0001~0.22 µF
16/50 VDC
ECH-U(C)
-55 ~ +105ºC
0.01~0.22 µF
100 VDC
ECW-U(C)
-55 ~ +105ºC
-55 ~ +125ºC
0.001 ~ 1.0 µF
100, 250, 630 VDC
ECW-U(V16)
-55 ~ +85ºC
ECW-U(X)
ECP-U(A)
Ratings
Features
Applications
•Non-inductive, stacked
•Miniature
•Reflow soldering
•High density mounting SMD
(industrial grade)
•Non-inductive, stacked
•Miniature
•Reflow and flow solderability
•High density mounting SMD
•Industrial Use
•Filters; oscillators
•Non-inductive, stacked
•Miniature
•Reflow Soldering
•High density mounting SMD
(commercial grade)
0.001~0.12 µF
250 VDC
•Non-inductive, stacked
•Miniature
•Similar to polyester film cap
•High density mounting SMD
(commercial grade)
-55 ~ +105ºC
0.001 ~ 0.01 µF
100 VDC
•Non-inductive, stacked
•Reflow soldering
•Electronic exchange
•Ringer circuit telephone & PBX
-40 ~ +85ºC
0.1 ~ 1.0 µF
16 VDC
•Non-inductive, stacked
•Reflow soldering
•Coupling, filtering & PLL
23
RESISTORS
na.industrial.panasonic.com/products/resistors-inductors /resistors
Surface Mount Resistors
Power Resistors & Thermistors
Fuse Resistors
Axial Leaded Resistors
ESD Suppressors
Resistor Arrays & Networks
Low Ohmic Thick Film Chip
Surface Mount Resistors
Thick Film Chip
RESISTORS
SURFACE MOUNT
Series
Case
Size
Power
Rating
(W)
Resistance
Range (Ω)
Resistance
Tolerance
(%)
T.C.R.
(ppm/dC)
ERJ-XGNJ
01005
1/32 W
10 ~ 1 M
±5
± 200
ERJ-XGNF
01005
1/32 W
10 ~ 1 M
±1
± 200
LxWxT
Dimensions
(mm)
0.40 x 0.20 x 0.13
Qty.
7” Reel
(pcs.)
20,000
ERJ-1GNJ
0201
1/20 W
1.0 ~ 1 M
±5
± 200
ERJ-1GNF
0201
1/20 W
10 ~ 1 M
±1
± 200
ERJ-1RHD
0201
1/20 W
1 K to 1 M
± 0.5
± 50
15000
10,000
ERJ-2GEJ
0402
1/16 W
1.0 ~ 2.2 M
±5
± 200
ERJ-2RKF
0402
1/16 W
10 ~ 1 M
±1
± 100
ERJ-2RHD
0402
1/16 W
100 to 100 K
± 0.5
± 50
ERJ-2RKD
0402
1/16 W
10 to 97.6 & 102 K to 1M
± 0.5
± 50
15,000
0.60 x 0.3 x 0.23
1.0 x 0.5 x 0.35
15,000
10,000
10000
10000
ERJ-3GEYJ
0603
1/10 W
1.0 ~ 10 M
±5
± 200
5,000
ERJ-3EKF
0603
1/10 W
10 ~ 1 M
±1
± 100
5,000
ERJ-3RBD
0603
1/8 W
100 to 100 K
± 0.5
± 50
ERJ-3RED
0603
1/8 W
10 to 97.6 & 102 K to 1M
± 0.5
± 100
ERJ-6GEYJ
zz0805
1/8 W
1.0 ~ 10 M
±5
± 200
5,000
ERJ-6ENF
0805
1/8 W
10 ~ 2.2 M
±1
± 100
5,000
ERJ-6RBD
0805
1/8 W
100 to 100 K
± 0.5
± 50
ERJ-6RED
0805
1/8 W
10 to 97.6 and 102 K to 1M
± 0.5
± 100
ERJ-8GEYJ
1206
1/4 W
1.0 ~ 10 M
±5
± 200
ERJ-8ENF
1206
1/4 W
10 ~ 2.2 M
±1
± 100
ERJ-14YJ
1210
1/4 W
1.0 ~ 10 M
±5
± 200
ERJ-14NF
1210
1/4 W
10 ~ 1 M
±1
± 100
ERJ-12YJ
1812
1/2 W
1.0 ~ 10 M
±5
± 200
ERJ-12NF
1812
1/2 W
10 ~ 1 M
±1
± 100
ERJ-12ZYJ
2010
1/2 W
1.0 ~ 10 M
±5
± 200
ERJ-12SF
2010
1/2 W
10 ~ 1 M
±1
± 100
1.6 x 0.8 x 0.45
5000
5000
2.0 x 1.25 x 0.6
5,000
3.2 x 1.6 x 0.6
3.2 x 2.5 x 0.6
4.5 x 3.2 x 0.6
5.0 x 2.5 x 0.6
5,000
5,000
5,000
5,000
5,000
1.0 ~ 1 M
±5
± 200
10 ~ 1 M
±1
± 100
ERJ-2BS
0402
1/8 W
0.1 ~ 0.2
± 1, ± 5
± 300
ERJ-2BQ
0402
1/8 W
0.22 ~ 1.0
± 1, ± 5
±250
ERJ-3RS
0603
1/10 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±250
5,000
ERJ-3RQ
0603
1/10 W
0.22 ~ 9.1
± 1, ± 2, ± 5
±200, ±250
5,000
ERJ-3BS
0603
1/4 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±300
ERJ-3BQ
0603
1/4 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±200, ±300
5,000
ERJ-6RS
0805
1/8 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±250
5,000
ERJ-6RQ
0805
1/8 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±200, ±250
6.4 x 3.2 x 0.6
1.0 x 0.5 x 0.35
1.6 x 0.8 x 0.45
2.0 x 1.25 x 0.6
4,000
5,000
5,000
0805
1/3 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±250
1/3 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±200, ±250
5,000
ERJ-8RS
1206
1/4 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±250
5,000
ERJ-8RQ
1206
1/4 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±200, ±250
± 1, ± 2, ± 5
±200
± 1, ± 2, ± 5
±100, ±200
ERJ-14RS
1210
1/4 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±200
ERJ-14RQ
1210
1/4 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±100, ±200
ERJ-14BS
1210
1/2 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±200
ERJ-14BQ
1210
1/2 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±100, ±200
25
5,000
5,000
3.2 x 2.5 x 0.6
-100~+600
* 200
-400~+150
•Small size and lightweight
•High reliability using metal glaze
thick film resistive elements and
three layers of electrodes
•Compatible with automatic
placement of bulk taping and
bulk case packaging
•Reflow and flow solderability
•Meets ISO-9001 &
QS-9000 standards
5,000
5,000
3.2 x 2.5 x 0.6
<10
10 - 1 M
>1M
10,000
0805
0.1 ~ 0.2
T.C.R.
(ppm/dC)
4,000
ERJ-6BS
0.22 ~ 0.91
Res. Range
(o)
10,000
ERJ-6BQ
3.2 x 1.6 x 0.6
•Low ohmic tolerance: ERJ-3E; 6E;
8E; 14, 12 series: ±1%
•NOTE:
Chip resistor 5% tolerance
1W
1/2 W
•Meets ISO-9001 &
QS-9000 standards
5,000
1W
1/2 W
•Reflow and flow solderability
•Halogen Free
2512
1206
•Compatible with automatic
placement of bulk taping
and bulk case packaging
5,000
2512
1206
•High reliability using metal
glaze thick film resistive
element and three layers
of electrodes
5,000
ERJ-1TYJ
ERJ-8BS
•Small size and lightweight
5,000
ERJ-1TNF
ERJ-8BQ
Features
20,000
•Low resistance tolerance:
ERJ-2R; 3R; 6R Series; ± 1%, ± 5%
5,000
5,000
5,000
5,000
•Halogen Free
Ultra Low Ohmic Thick Film Resistors
Thin Film Chip
Surface Mount Resistors
Surface Mount Resistors
Low OhmLow Ohmic
Thick Film Chip
SURFACE MOUNT
RESISTORS
Series
Case
Size
Power
Rating
(W)
Resistance
Range (Ω)
Resistance
Tolerance
(%)
T.C.R.
(ppm/dC)
ERJ-12RS
1812
1/2 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±200
ERJ-12RQ
1812
1/2 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±100, ±200
ERJ-12ZS
2010
1/2 W
0.1 ~ 0.2
± 1, ± 2, ± 5
±200
ERJ-12ZQ
2010
1/2 W
0.22 ~ 0.91
± 1, ± 2, ± 5
±100, ±200
ERJ-1TRS
2512
1W
0.1 ~ 0.2
± 1, ± 2, ± 5
±200
ERJ-1TRQ
2512
1W
0.22 ~ 0.91
± 1, ± 2, ± 5
±100, ±200
LxWxT
Dimensions
(mm)
4.5 x 3.2 x 0.6
Qty.
7” Reel
(pcs.)
Features
5,000
5,000
5.0 x 2.5 x 0.6
6.4 x 3.2 x 0.6
5,000
•See previous page
5,000
4,000
Series
Case
Size
Power
Rating
(W)
Resistance
Range
Resistance
Tolerance (%)
T.C.R.
(ppm/dC)
LxWxT
Dimensions
(mm)
Qty.
7” Reel
ERJ-2LW
0402
1/5 W
10 m
± 1, +-2, +-5
0 to 500
1.0 x 0.5 x0.4
10000
ERJ-2BW
0402
1/4 W
0.047 ~ 0.2
± 2, ± 5
±300
1.0 x 0.5 x 0.35
10,000
1.6 x 0.8 x0.55
5000
Features
ERJ-3LW
‘0402
1/4 W
5 m ~10 m
± 1, ± 2, ± 5
5 m: 0 to 700
10 m: 0 to 300
ERJ-3BW
0603
1/4 W
20 m ~ 100 m
± 1, ± 2, ± 5
±300
1.6 x 0.8 x 0.55
5,000
ERJ-6BW
0805
1/3 W
10 m ~ 50 m
± 1, ± 2, ± 5
±200, ±300
2.0 x 1.25 x 0.65
5,000
ERJ-8BW
1206
1W
0.01 ~ 0.1
± 1, ± 2, ± 5
±100, ±150, ±200
32 x 1.6 x 0.6
5,000
ERJ-8CW
1206
1W
10 m ~ 50 m
± 1, ± 2, ± 5
+-50
3.2 x 1.6 x 0.65
5000
ERJ-L03
0603
1/5 W
47 ~ 100 milli.
± 1, ± 5
± 200
1.6 x 0.8 x 0.45
5,000
ERJ-L06
0805
1/4 W
47 ~ 100 milli.
± 1, ± 5
± 100
2.0 x 1.25 x 0.6
5,000
ERJ-L08
1206
1/3 W
47 ~ 100 milli.
± 1, ± 5
± 100
3.2 x 1.6 x 0.6
5,000
ERJ-L14
1210
1/3 W
20 ~ 100 milli.
± 1, ± 5
3.2 x 2.5 x 0.6
5,000
ERJ-L12
1812
1/2 W
20 ~ 100 milli.
± 1, ± 5
4.5 x 3.2 x 0.6
5,000
ERJ-L1D
2010
1/2 W
40 ~ 100 milli.
± 1, ± 5
5.0 x 2.5 x 0.6
5,000
ERJ-L1W
2512
1W
40 ~ 100 milli.
±5
6.4 x 3.2 x 1.1
3,000
ERJ-M1WT
2512
1W
3, 4 m
± 1, ± 5
± 350
6.4 x 3.2 x 0.8
3,000
•Metal plate is used as
resistance element
ERJ-M1WT
2512
1W
5, 6, 10, 15, 20 m
± 1, ± 5
± 100
6.4 x 3.2 x 0.8
3,000
•Reflow and flow solderability
ERJ-M1WS
2512
1W
1, 1.5 m
± 1, ± 5
350 ± 100
6.4 x 3.2 x 0.8
3,000
ERJ-M1WS
2512
1W
2, 3, 4 m
± 1, ± 5
100 ± 50
6.4 x 3.2 x 0.8
3,000
ERJ-MS4S
2512
3W
1, 2, 3, 4 m
±1
± 75
6.4 x 3.2 x 1.2
2000
ERJ-MS4H
2512
3W
5, 6 m
±1
± 75
6.4 x 3.2 x 1.2
2000
ERJ-MS4H
2512
2W
7, 8, 9, 10 m
±1
± 75
6.4 x 3.2 x 1.2
2000
ERJ-MS6S
2526
5W
0.5, 1, 2 m
±1
± 75
6.4 x 6.8 x 1.2
1000
ERA-1A
0201
1⁄20 W
100 to 10 K
±01, ±0.25
± 25
0.6 x 0.3 x 0.23
15000z
ERA-2A
0402
1/16 W
10 - 100K
±0.1, ±0.25, ±0.5
± 10, ± 15
± 25, ± 100
1.0 x 0.5 x 0.35
10,000
•Low T.C.R. & current noise
ERA-3A
0603
1/10 W
10 ~ 330 K
± 0.05, ± 0.1, ± 0.5
± 10, ± 15,
± 25, ± 50
1.6 x .80 x 0.45
5,000
•High operating temperature
capability: -55 to +155ºC
ERA-6A
0805
1/8 W
10 ~ 1 M
± 0.05, ± 0.1, ± 0.5
± 10, ± 15,
± 25, ± 50
2.0 x 1.25 x 0.5
5,000
ERA-8A
1206
1/4 W
10 ~ 1 M
± 0.1, ± 0.5
± 10, ± 15,
± 25, ± 50
3.2 x 1.6 x 0.6
5,000
R < 47 milli: ± 300
R≥ 47 milli: ± 100
26
•Small size and lightweight
•High reliability using
metal glaze thick film resistive
elements and three layers of
electrodes
•Compatible with automatic
placement of bulk taping and
bulk case packaging
•Reflow and flow solderability
•Meets ISO-9001 & QS-9000
standards
•Low ohmic values for ERJ-L14;
L12; L1W series:
47 mΩ~100 mΩ
•Halogen Free
•ERJ-M1WT: For heat dissipation
•±1% tolerance for 1~2 mΩ
available upon request
•Halogen Free
•Small size and lightweight
•High reliability
•Excellent non-linearity
•Halgoen Free
•Reflow & flow solderability
•Meets ISO-9001 standards
RESISTORS
SURFACE MOUNT
Anti-Surge Thick Film Chip
ERJ-P03
0603
1/5 W
ERJ-PA3
0603
1/4 W
ERJ-P06
Anti-Pulse Thick
Film Chip
Surface Mount Resistors
Series
Anti-Sulfurated Thick Film Chip
0805
Resistance
Value
Resistance
Tolerance
(%)
T.C.R (ppm/C)
10 to 1M
±0.5, ±1
±150, ±200
1 to 1M
+5
R>10 Ω: ±200
R<10Ω: -150 to 400
10 to 1M
±0.5, ±1
±100
1 to 1.5 M
+5
±200
1 to 1M
±0.5, ±1
R≥30 Ω: ±100
R<30Ω: ±300
1 to 3.3M
+5
R≥30 Ω: ±200
R<30Ω: ±300
10 to 1M
±0.5, ±1
±100
1 to 10 M
+5
R≥10 Ω: ±200
R<10Ω: -100 to +600
10 to 1M
±0.5, ±1
±100
1 to 1M
+5
R≥10 Ω: ±200
R<10Ω: -100 to +600
10 to 1M
±1
±200
1 to 1M
+5
R < 10 : -100 to +600
10 < R : +-200
1/2 W
LxWxT
Dimensions
(mm)
2.0 x 1.25 x 0.60
ERJ-P14
1210
1/2 W
ERJ-P6W
0805
1/2 W
ERJ-T06
0805
1/4 W
1 to 1M
+5
R≥33 Ω: ±200
R<30Ω: ±300
R<10Ω: -100 to +600
2.0 x 1.25 x 0.60
ERJ-T08
1206
1/3 W
1 to 1M
+5
R≥10 Ω: ±200
R<10Ω: -100 to +600
3.2 x 1.6 x 0.60
ERJ-T14
1210
1/2 W
1 to 1M
+5
R≥10 Ω: ±200
R<10Ω: -100 to +600
3.2 x 2.5 x 0.60
ERJ-U01
0201
1/20 W
ERJ-S02
ERJ-U02
0402
0.1 W
ERJ-S03
ERJ-U03
0603
0.1 W
ERJ-S06
ERJ-U06
0805
0.125 W
ERJ-S08
ERJ-U08
1206
0.25 W
ERJ-S14
ERJ-U14
ERJ-S12
ERJ-U12
1210
1812
0.5 W
0.75 W
ERJ-S1D
ERJ-U1D
2010
0.75 W
ERJ-S1T
ERJ-U1T
2512
1W
Resistance
Value
Resistance
Tolerance
(%)
10 to 1M
±1
1 to 1M
±5
10 to 1M
±1
1 to 3.3M
±5
3.2 x 2.5 x 0.60
2.0 x 1.25 x 0.65
Qty.
7” Reel
±200
0.6 x 0.3 x 0.23
15,000
±200
1.0 x 0.50 x 0.35
10,000
1.60 x 0.8 x 0.45
5,000
2.0 x 1.25 x 0.60
5,000
3.20 x 1.60 x 0.60
5,000
3.20 x 2.50 x 0.60
5,000
4.50 x 3.20 x 0.60
5,000
5.0 x 2.50 x 0.60
5,000
6.40 x 3.20 x 0.60
40,000
±1
±100
±5
±200
10 to 1M
±1
±100
1 to 10M
±5
±200
10 to 1M
±1
±100
1 to 10M
±5
±200
10 to 1M
±1
±100
1 to 10M
±5
±200
10 to 1M
±1
±100
1 to 10M
±5
±200
10 to 1M
±1
±100
1 to 10zM
±5
±200
10 to 1M
±1
±100
1 to 1M
±5
±200
ERJ-U6S
0805
0.25
0.1 to 0.2
±1, ±2, ±5
±150
2.0 x 1.25 x 0.55
5000
ERJ-U6Q
0805
0.25
0.22 to 1
±1, ±2, ±5
±150
2.0 x 1.25 x 0.55
5000
EXB-U24
0402
1/16 W
10 to 1M
±5
±200
1.0 x 1.0 x 0.35
10,000
Refer to Spec
2.5 x 5.0 x 0.55
5000
ERJ-C1
1020
2W
10 m to 1
±1
±5
5000
•Pulse Tolerant
5,000
•High Reliability
•High Power
T.C.R (ppm/C)
10 to 1M
•High reliability
•Suitable for both
flow and re-flow
soldering
3.2 x 1.6 x 0.60
LxWxT
Dimensions
(mm)
1 to 10M
5,000
•High Power
2/3 W
Power
Rating
(W)
Features
•Anti-Surge
characteristics
superior to
standard metal
film resistors
1.6 x 0.8 x 0.45
1206
Case
Size
Qty
7” Reel
1.60 x 0.8 x 0.45
ERJ-P08
Series
Surface Mount Resistors
Power
Rating
(W)
Case
Size
Features
•Sulfur resistance
•High reliability
•Suitable for flow and
re-flow soldering
•ERJ-S: Au-based inner
electrode
•ERJ-U: Ag-Pd-based inner
electrode
•Array solution for high
placement efficiency
•Ag-Pb-based inner electrode
EXB-U28
0402
1/16 W
10 to 1M
±5
±200
27
2.0 x 1.0 x 0.35
10,000
•U24: 4 terminals, 2 resistors
•U28: 8 terminals, 4 resistors
Power Resistors & Thermistors
Chip
High Power Wide Terminal
Attenuator
POWER RESISTORS & THERMISTORS, FUSE RESISTORS, AXIAL LEADED RESISTORS
Series
Case
Size
Power
Rating (W)
Resistance
Range
Ω
Resistance
Tolerance
(%)
ERJ-A1
2512
1.33 W
10 m ~ 10 k
± 1, ± 2, ± 5
ERJ-B1
2010
1 W,
( 2 W R < 10 Ω)
10 m ~ 10 k
± 1, ± 2, ± 5
ERJ-B2
1206
0.75 W,
( 1 W R < 10 Ω)
5m~1M
± 1, ± 2, ± 5
ERJ-B3
0805
0.33 W,
( 0.5 W R < 1 Ω)
20 m ~ 10 M
EXB-24AT
0404
1 / 25 W
Package
Attenuation
Range
1 ~ 5 dB
6 ~ 10 dB
RESISTORS
LxWxT
Dimensions
(mm)
Quantity
7” Reel
6.4 x 3.2 x .55
4,000
5.0 x 2.5 x .55
5,000
Refer to Spec
3.2 x 1.6 x 0.65
5,000
±1, ±2, ±5
Refer to Spec
2.0 x 1.25 x 0.5
5,000
Attenuation
Tolerance
± 0.3 dB
± 0.5 dB
Characteristic
Impedance
50 Ω
1.0 x 1.0 x 0.35
10,000
T.C.R.
(ppm/dC)
Features
Refer to Spec
•High solder joint reliability
•Excellent heat dissipation
•Halogen Free
•Space saving design using
unbalanced pie-type
attenuator
Thermal
Cutoff
High Power
Metal (Oxide) Film Resistors
Leaded
SMD
Micro
Chip
Low Ohmic
Axial Leaded Resistors
Fuse Resistors
EIA Standard Resistance ValuesE-96 Tolerance *1% | E-24 Tolerance *5%, 0.5%, 0.1%
Rated
Voaltage
Interrupting
Rating at
Rated
Voltage
Rated
Current
37m ~ 820 mΩ
32VDC
35A
0.25A ~ 3A
-40ºC to +125ºC
19m ~ 330 mΩ
32VDC
50A
0.5A ~ 5A
1206
-40ºC to +125ºC
35m ~ 560 mΩ
32VDC, 63VDC
50A
0.5A ~ 4A
Thin,
Axial Lead,
Radial Lead
92ºC, 98ºC, 102ºC,
115ºC, 134ºC,
139ºC, 145ºC
250VAC, 50VDC,
32VDC
0.5A,
1.5A, 2A,
3A, 3.5A, 4A
55C ~ 125C (Vary
by part number)
135C, 200C
Series Case Size
Rated
Functioning
Temperature
Internal
R at 25C
(Max)
ERB-RD
0402
-40ºC to +125ºC
ERB-RE
0603
ERB-RG
EYP
Series
Power Rating
(W)
ERG(X)12S
0.5
ERG(X)1S
ERG(X)1F
1
ERG(X)2S
ERG(X)2F
2
ERG(X)3S
ERG(X)3F
3
ERG(X)5S
ERG(X)5F
5
ERG-12D
Resistance
Range
Resistance
Tolerance
1 to 22 K
±2
0.2 to 47 K
±5
1 to 68 K
±2
0.2 to 100 K
±5
Features
•Fast acting
•Small size
•High Reliability
•Various Package Styles: Radial,
Axial Lead, zand Thin
Dielectric
Withstanding
Voltage (VAC)
T.C.R.
(ppm/dC)
LxD
350
± 350
6.35 x 2.3
350
± 350
9.0 x 2.8
600
± 350
12.0 x 4.0
1000
± 300
15.0 x 5.5
1000
± 200
24.0 x 8.0
1 to 100 K
±2
0.22 to 100 K
±5
1 to 100 K
±2
0.22 to 100 K
±5
1 to 100 K
±2
0.33 to 100 K
±5
0.5
51 K to 240 K
± 2, ± 5
500
± 200
6.35 x 2.3
ERG-1D
1
110 K to 330 K
± 2, ± 5
500
± 200
9.0 x 2.8
ERG-2D
2
110 K to 510 K
± 2, ± 5
700
± 200
12.0 x 4.0
ERG-3D
3
110 K to 750 K
± 2, ± 5
700
± 200
15.0 x 5.5
ERX-12L
0.5
22 to 82 m
± 2, ± 5
350
ERX-1L
1
22 to 82 m
± 2, ± 5
350
ERX-2L
2
22 to 82 m
± 2, ± 5
600
28
6.35 x 2.3
22 to 39 m: +-1000
47 to 82 m: +-500
9.0 x 2.8
12.0 x 4.0
ESD Suppressors
RESISTORS
ESD SUPPRESSORS, RESISTOR ARRAYS & NETWORKS
Series
Case Size
Capacitance
LxWxT (mm)
Dimensions
Qty.
7” Reel
EZA-EG1A
0201
C = 0.04 pF
0.6 x 0.3 x 0.23
15,000
EZA-EG2A
0402
C = 0.10 pF
1.0 x 0.5 x 0.38
10,000
EZA-EG3A
0603
C = 0.05 pF
1.6 x .80 x 0.5
5,000
EZA-EGCA
0805
C = 0.25 pF (4 Per Pkg.)
2.6 x 1.85 x 0.5
5,000
Chip Resistor Array
Chip Resistor Network
Resistor Arrays & Networks
Series
Case
Size
Power
Rating (W)
Resistance
Range
Resistance
Tolerance
(%)
0.5
Features
•Good ESD Suppression
•Good ESD Withstanding
•Low Capacitance
T.C.R.
(ppm/°C)
LxWxT
Dimensions
(mm)
Qty.
7” Reel
± 25
3.2 x 1.6 x 0.5
5,000
± 200 x
0.8 x 0.6 x 0.35
ERA-38V
0603 x 4
Convex Term
1/16 W
Element
100K~220 K
1K~100 K
0.1, 0.25
EXB-14V
0201 x 2
Convex Term
1/32 W
10 ~ 1 M
±5
EXB-18V
0201 x 4
Flat Term
1/32 W
10 ~ 1 M
±5
EXB-N8V
0402 x 4
Concave Term
1/32 W
1~1M
EXB-24V
0402 x 2
Convex Term
1/16 W
1~1M
EXB-28V
0402 x 4
Convex Term
1/32 W
1~1M
2.0 x 1.0 x 0.35
EXB-2HV
0402 x 8
Convex Term
1/16 W
Element
1~1M
3.8 x 1.6 x 0.45
EXB-34V
0603 x 2
Convex Term
1/16 W
1~1M
EXB-38V
0603 x 4
Convex Term
1/16 W
1~1M
EXB-V4V
0603 x 2
Concave Term
1/16 W
1~1M
1.6 x 1.6 x 0.60
EXB-V8V
0603 x 4
Concave Term
1/16 W
1~1M
3.2 x 1.6 x 0.60
EXB-S8V
0805 x 4
Concave Term
1/10 W
Element
10 ~ 1 M
5.08 x 2.2 x 0.7
2,500
EXB-D10C
1206
Concave Term
1/20 W
Element
47 ~ 1 M
3.2 x 1.6 x 0.55
5,000
EXB-Q16
1506
Concave Term
1/40 W
100 ~ 470 K
3.8 x 1.6 x 0.45
EXB-E10C
1608
Concave Term
EXB-A10P
2512
Concave Term
Features
10-6/dC
±5
1.4 x 0.6 x 0.35
1 - 10o:
± 600/100x10-6/dC
2.0 x 1.0 x 0.45
1.0 x 1.0 x 0.35
±5
±1
upon request
±5
10 - 1 M :
± 200
10 > :
-100 - + 600
3.2 x 1.6 x 0.50
•Improved placement
efficiency (2 to
4 times greater)
compared to flat
chip type resistors
5,000
± 200
47 ~ 1 M
6.4 x 3.1 x 0.55
29
•High density of
resistors in single
array chip
1.6 x 1.6 x 0.50
4.0 x 2.1 x 0.55
1/16 W
Element
10,000
4,000
•High density
placement for digital
signal applications:
8 bussed resistors
for pull up/down
circuits
•Superior
mountability due
to unique concave
terminal
CONNECTORS
na.industrial.panasonic.com/products/relays-connectors/connectors
Narrow Pitch Board to FPC
Narrow Pitch Board to Board
FPC Connectors
Micro Coaxial
Active Optical Connectors
Stacking Connectors for High Current
CONNECTORS
NARROW PITCH
Board to FPC
Series
Part Number (Socket)
Part Number (Header)
Mated Height (mm)
Socket (W) (mm)
Header (W) (mm)
Terminal Pitch (mm)
S35
A35US
A4F
A4US
A4S
F4S
AXG1*
AXG7**
AXE3**
AXE1**
AXE5**
AXT5**
AXG8**
AXE4**
AXE2**
0.6
0.6
0.8
1.7
2.2
3.0
2
2.5
1.5
1.8
2.4
1.8
2.0
2.6
0.35
0.35
0.4
0.4
0.4
0.4
AXG2*
0.6
0.8
AXE6**
0.8
AXT6**
1.0
1.0
3.6
Number of Contacts
0-9
10 - 19
10, 16
12
10
12, 16
10, 12, 14, 16
10, 14, 18
10, 12, 14,
16, 18
10, 12, 14
10, 12,
14, 16, 18
20 - 29
20, 24
24
20, 24
20, 22,
24, 26, 28
20, 24
20, 22, 24,
26, 28
20, 24, 26
20, 22,
24, 26, 28
30 - 39
30, 34
34
30, 34
40 - 49
50 - 59
40, 44
50, 54
44
40
50
30, 32,
34, 36, 38
40, 42, 44
50, 54
60
60, 64
100, 120
70
80
0.25A
0.3A
60 - 69
70 - 79
80 +
Rated Current (contact)
Rated Voltage (AC/DC)
Insertion/Removal Life*
0.3A
30, 32, 34,
36, 38
40, 44
50, 54, 56
30, 34, 36
40
50
60
70
80
40, 44
50, 54
30, 32,
34, 36, 38
40, 42, 44, 46, 48
50, 54
60, 64
60
60, 64
70
80
70
80
70
80
0.3A
30, 32
0.3A
0.3A
60V
30 X
Board to FPC & Board to Board
Series
Part Number (Socket)
Part Number (Header)
Mated Height (mm)
Socket (W) (mm)
Header (W) (mm)
Terminal Pitch (mm)
P35S
P4S
P4
P4 w/ Soldering Terminal
P5KF
AXT1**
AXT3**
AXK7**
AXK7**
AX5F**
AXT2**
1.5
Number of Contacts
2.5
AXK8**
3.0
1.5
2.0
2.5
3.0
AXK8**
3.5
4.0
1.5
2.0
2.5
3.0
AXK6F**
3.5
4.0
1.5
2.0
2.5
3.60
5.10
5.10
5.8
2.35
2.35
3.96
3.96
3.3
0.4
0.4
0.4
0.4
20 - 29
20, 22,
24, 26,
28
30 - 39
30, 32,
34, 36,
38
40 - 49
40
50 - 59
50, 52
60 - 69
60
70 - 79
70
Rated Current (contact)
Max Current
Rated Voltage (AC/DC)
Insertion/Removal Life*
2.0
3.6
10 - 19
80 +
AXT4**
1.5
80, 90,
100
0.25A
10,
16
14,
16
14
14
20,
22,
24,
26,
28
30,
32,
34,
36,
38
40,
44,
46
50,
54,
56
60,
64
70
80,
90,
100
20,
24,
26
20,
24
20,
24
20
40
10,
12
20
20
20,
22,
24,
26,
28
30
30
30,
34,
36
30,
34,
38
30,
34
30
40
43
40,
42,
44
40
40,
44
40
56
50,
54
50,
54
50
50
20,
22,
24,
26
20, 22,
24, 26
20, 22, 24
20
20
30
30,
34,
36
30,
34
32,
36
36
30
34
30,
32,
34
30, 34
30, 34, 36
40
40,
44,
46
40
40
40
40
42
40
40
40, 44
50
50
50
50
50
50
50
50
50
60
60
60
60
60
60
60
60
70
70
70
70
70
80,
90
80
80
80, 100
80
80,
90,
100
80
80,
90
0.3A
5A
60V
31
10, 12, 14, 16
20,
28
0.3A
*Inspection Connectors Available @ 3000X :: Ambient Operating Temperature: -55 ~ +85°C
10, 12,
14, 16,
18
20,
24
60
0.3A
12
20,
22,
24,
28
24
60,
60 60 60
64
70 70 70
80, 80,
80,
90, 80,
80,
80,
100, 90,
90,
100 100
100
100
120 100
100
60
0.5
10,
12,
14,
16,
18
80,
90
0.5A
NARROW PITCH, FPC
CONNECTORS
Board to Board
Number of Contacts
Series
Part Number (Socket)
Part Number (Header)
Mated Height (mm)
Socket (W) (mm)
Header (W) (mm)
Terminal Pitch (mm)
P5K
P5KS
AXK5**
AXK5S**
AXk6**
AXk6S**
3.0
3.5
4.0
4.5
5.0
5.5
6.0
5.8
5.4
4.6
5.0
0.5
6.5
7.0
8.0
9.0
0.5
20 - 29
20, 22
20, 22
20, 24
20, 24
20, 24
20, 24
20
20
20
20
20
30 - 39
30
30, 34
30, 34
30, 34, 36
30, 34
30, 34
30
30
30
30
30
40 - 49
40
40
40
40
40
40
40
40
40
40
40
50 - 59
50
50
50
50
50
50
50
50
50
50
50
60 - 69
60
60
60
60
60
60
60
60
60
60
60
70 - 79
70
70
70
70
70
70
70
70
70
70
70
80 +
80, 100,
120
80, 100,
120
80, 100,
120, 160
80, 100,
120, 160
80, 100
80, 100
80, 100
80, 100,
130
80, 100
80, 100
80, 100
Rated Current (contact)
Max Current
Rated Voltage (AC/DC)
Insertion & Removal Life*
0.5A
16A
60V
*Inspection Connectors Available @ 3000X :: Ambient Operating Temperature: -55 ~ +85°C
FPC Connectors
Series
Part Number
Y3B
Y3BW
Y3BL
Y2B
Y5B
Y5BW
Y4BH
AYF33**35
AYF33**65
AYF35**25
AYF21**25
AYF53**35
AYF53**65T
AYF42**35
Back
Back
Back
Back
Back
Back
Mounting Height (mm)
0.9
0.6
0.9
1
1
1
Contact Pitch (mm)
0.3
0.3
0.2
0.5
0.5
0.4
Terminal Pitch (mm)
0.6
0.6
0.5
0.5
0.4
Dimension (W) (mm)
3.15
3.15
3.7
3.7
3.7
7
4, 5, 6, 8,
2, 3, 4, 6, 8
10, 12, 14, 16
10, 12, 14
Number of Contacts
Lock Structure
3.15
1 - 10
7, 8, 9
10 - 19
11, 13, 15, 17
11
15
20 - 29
21, 23, 25, 27
25
23
23
24, 28
22, 26, 28
30 - 39
31, 33, 35, 37, 39
31, 39
31
30, 32, 34
30, 32, 38
40 - 49
41, 45
41
40, 42
40, 48
40, 50
50 - 59
51
51
50
60+
60, 71
51
51
61
Compatibility w/
FPC/FFC
FPC
FPC
FPC
FPC/FFC
FPC
FPC
Contact Structure
Top & Bottom
Top & Bottom
Top & Bottom
Top & Bottom
Top & Bottom
Top & Bottom
0.2A
0.2A
0.2A
0.2A
0.5A
0.3A
Rated Current (Contact)
Rated Voltage (AC/DC)
50V
Insertion & Removal Life
30 X
32
CONNECTORS
MICRO COAXIAL, ACTIVE OPTICAL CONNECTORS, STACKING CONNECTORS
Micro Coaxial
Series
CS
CF
Part Number
Receptacle: AXC51Sxxxx
Plug: AXC61Sxxxx
Cover Shell: AXC81Sxxxx
Receptacle: AXC51Fxxxx
Plug: AXC61Fxxxx
Cover Shell: AXC81Fxxxx
Mated Height
1.27mm
0.8mm
Terminal Pitch
0.5mm
0.4mm
Dimensions
(Short width including terminals)
2.81mm
3.8mm
0.25A
0.30A
Rated Current (contact)
Max Current
4A
Rated Voltage (AC/DC)
50V
Insertion & Removal Life
30 times
Ambient Temperature
-55 - 85°C
Active Optical Connectors
V
Series
Part Number
AYG4V1**
Part Number
AXK6S20447M*
(Integrated Cable and Plug)
(Receptacle)
20Mbps to 6Gbps
Transmission Rate
Transmission Specification
Bi-directional, 1channel
Electrical Static Discharge
2kV
50mm, 300mm,1m
Cable Length
Stacking Connectors for High Current
Series
B01
Part Number (Socket)
AXF361500
AXF461500
Part Number (Header)
AXF363500
AXF463500
Stacking Height in mm
0.6
0.8
No of Contacts
6
6
Width (Socket) in mm
1.6
1.6
Width (Header) in mm
1.6
1.6
Total Rated Current Power Terminal
6A
6A
Insertion/Removal Life
30x
30x
33
INDUCTORS
na.industrial.panasonic.com/products/resistors-inductors/inductors-coils
Power Choke Coils
Chip Inductors
EMI Filters
Chip Choke Coils
INDUCTORS
Series
PCC-M1050ML
PCC-M1060ML
Parts No
ETQ-P5MR68YLC
ETQ-P5M1R0YLC
ETQ-P6M2R5YLC
ETQ-P6M3R3YLC
Size (mm)
10.9x10x5
10.9x10x6
Inductance
Rated
current
DCR
1uH ±20%
27.5A
2.3mOhm+/-10%
0.68uH ±20%
31.5A
1.75mOhm+/-10%
2.5uH ±20%
19.6A
4.5mOhm+/-10%
3.3uH ±20%
17.0A
6.0mOhm+/-10%
Features
•High power, Low loss
•High power, Low loss
PCC-M0850M
ETQ-P5M101YGK
8.5x8x5.4
100uH ±20%
2.1A
302mOhm+/-10%
•High power, Low loss
PCC-M0730L
ETQ-P3LR24CFM
8.7x7x3
0.24uH ±20%
22A
1.12mOhm+/-7%
•High power, Low loss
2.2uH ±20%
5.8A
22.6mOhm+/-10%
3.3uH ±20%
5.0A
31.3mOhm+/-10%
6.8uH ±20%
5.2A
39.3mOhm+/-10%
47uH ±20%
2.2A
210mOhm+/-10%
4.7uH ±20%
4.8A
36.0mOhm+/-10%
22uH ±20%
2.3A
163mOhm+/-10%
ETQ-P5M100YFM
10uH ±20%
5.7A
37.6mOhm+/-10%
ETQP5M4R7YFM
4.7µH ±20%
8A
20.4mΩ ±10%
ETQP5M4R7YFM
48µH ±20%
1.6A
156mΩ ±10%
22µH ±20%
3.7A
92mΩ ±10%
PCC-M0530M
PCC-M0645M
PCC-M0540M
PCC-M0754M
PCC-M0854M
Power Choke Coils
POWER CHOKE COILS
PCC-M1054M
ETQ-P3M2R2YFP
ETQ-P3M3R3YFP
ETQ-P4M6R8YFN
ETQ-P4M470YFN
ETQ-P4M4R7YFP
ETQ-P4M220YFP
ETQP5M220YFM
5.5x5x3
6.5x6x4.5
5.5x5x4
7.5 x 7.0 x 5.4
ETQP5M330YFM
34µH ±20%
3.3A
120mΩ ±10%
ETQP5M470YFM
48µH ±20%
2.9A
156mΩ ±10%
ETQP5M2R5YFK
2.45µH ±20%
14.0A
7.6mΩ ±10%
22µH ±20%
4.8A
63mΩ ±10%
ETQP5M220YFK
8.5 x 8.0 x 5.4
ETQP5M470YFK
48µH ±20%
3.4A
125mΩ ±10%
ETQ-P5M1R5YFC
1.5uH ±20%
21.4A
3.8mOhm+/-10%
ETQP5M2R5YFC
2.5µH ±20%
18.1A
5.3mΩ ±10%
ETQP5M3R3YFC
3.3µH ±20%
15.7A
7.1mΩ ±10%
ETQP5M4R7YFC
10.7 x 10.0 x 5.4
ETQP5M100YFC
ETQP5M220YFC
PCC-M105YGC
PCC-M0630L
PCC-M0630M
PCC-M074L
ETQP5M101YGC
10.7 x 10.0 x 5.0
ETQP3LR33XFN
7.5 x 6.5 x 3.0
13.1A
10.2mΩ ±10%
8.5A
23.8mΩ ±10%
21.5µH ±20%
6.2A
45.0mΩ ±10%
97µH ±20%
1.6A
208mΩ ±10%
0.33µH ±20%
17A
2.0mΩ ±10%
ETQP3MR68YFN
0.68µH ±20%
7.4A
6.3mΩ ±10%
ETQP3M1R0YFN
1.0µH ±20%
6.6A
7.9mΩ ±10%
ETQP3M1R5YFN
1.5µH ±20%
5.6A
11mΩ ±10%
ETQP3W1R0WFN
1.0µH ±20%
8.1A
9.32mΩ ±10%
1.5µH ±20%
6.6A
7.02mΩ ±10%
ETQP3W2R2WFN
2.2µH ±20%
5.8A
6.67mΩ ±10%
ETQP3W3R3WFN
3.3µH ±20%
4.8A
5.52mΩ ±10%
ETQP3W4R7WFN
4.7µH ±20%
2.8A
3.22mΩ ±10%
ETQP4LR24AFM
0.24µH ±20%
24A
1.0mΩ ±7%
0.36µH ±20%
20A
1.35mΩ ±7%
0.42µH ±20%
17A
1.5mΩ ±7%
0.36H ±20%
30A
0.76mΩ ±5%
0.68µH ±20%
21A
1.58mΩ ±5%
ETQP4LR19WFC
0.19µH ±20%
28A
0.70mΩ ±10%
ETQP4LR36WFC
0.36µH ±20%
24A
1.10mΩ ±5%
0.45µH +20%/-25%
25A
1.10mΩ ±5%
0.56µH ±20%
21A
1.56mΩ ±5%
ETQP3W1R5WFN
ETQP4LR36AFM
6.5 x 6.0 x 3.0
8.7 x 7.0 x 4.0
ETQP4LR42AFM
ETQP4LR36AFC
11.7 x 10.0 x 4.0
ETQP4LR68XFC
PCC-M104L
4.7µH ±20%
10.0µH ±20%
ETQP4LR45XFC
ETQ4LR56WFC
11.5 x 10.0 x 4.0
35
•High power, Low loss
•High power, Low loss
•High power, Low loss
•High Heat Resistance
•High Reliability
•High Bias Current
•Temperature Stability
•Low Audible Noise
•Highly Efficient
•Low profile for smaller circuits
•Excellent DC bias performance
•High reliability in humid conditions
•High frequency range for excellent performance
•Low audible noise
•High Power
•Small type
•Low loss (RDC 1.0 to 1.5mΩ)
•Tighter DCR tol (±&%)
•Suited for high frequency circuits (to 1 MHz)
•Low audible noise (no discrete air gap)
•Small size, Space saving, High power
(21A to 30A)
•Low loss (RDC: 0.76 to 1.58mΩ)
•Tighter DCR tolerance (±5%)
•Suitable for highh frequency circuits
(up to 1MHz)
•Low audible noise
POWER CHOKE COILS
Series
INDUCTORS
Inductance
Rated
Current
DCR
0.50µH ±20%
30A
0.80mΩ ±7%
ETQP5LR60XFA
0.60µH ±20%
27A
1.10mΩ ±5%
ETQP3H0R4BFA
0.36µH ±20%
23A
1.04mΩ max
0.80µH ±20%
16A
2.33mΩ max
ETQP3H1R4BFA
1.43µH ±20%
12A
4.52mΩ max
ETQP2H0R3BFA
0.29µH ±20%
36A
0.54mΩ max
ETQP2H0R7BFA
0.69µH ±20%
21A
1.30mΩ max
1.22µH ±20%
16A
2.27mΩ max
ETQP2H1R8BFA
1.83µH ±20%
14A
3.48mΩ max
ETQP2H2R6BFA
2.61µH ±20%
12A
4.98mΩ max
0.60µH ±25%
26A
0.90mΩ max
ETQP1H1R0BFA
1.00µH ±20%
19A
1.56mΩ max
ETQP6F0R6BFA
0.58µH ±20%
19A
1.44mΩ max
ETQP6F1R1BFA
1.06µH ±20%
16A
2.24mΩ max
1.71µH ±20%
14A
3.30mΩ max
ETQP6F2R5BFA
2.45µH ±20%
12A
4.92mΩ max
ETQP6F3R4BFA
3.32µH ±20%
10A
6.48mΩ max
ETQP6F0R8LFA
0.8µH ±30%
14.2A
2.24mΩ max
ETQP6F102HFA
10.2µH ±25%
6.5A
13.30mΩ max
ETQP6F1R0SFA
1.0µH ±30%
14.2A
2.24mΩ max
ETQP6F1R2HFA
1.2µH ±30%
14.2A
2.24mΩ max
ETQP6F1R3LFA
1.3µH ±30%
12.5A
3.30mΩ max
ETQP6F1R6SFA
1.6µH ±30%
12.5A
3.30mΩ max
ETQP6F2R0HFA
2.0µH ±30%
12.5A
3.30mΩ max
2.0µH ±30%
10.8A
4.92mΩ max
2.5µH ±30%
10.8A
4.92mΩ max
ETQP6F2R9LFA
2.9µH ±30%
9.3A
6.48mΩ max
ETQP6F3R2HFA
3.2µH ±25%
10.8A
4.92mΩ max
ETQP6F3R5SFA
3.5µH ±30%
9.3A
6.48mΩ max
ETQP6F4R1LFA
4.1µH ±20%
7.9A
8.64mΩ max
ETQP6F4R6HFA
4.6µH ±25%
9.3A
6.48mΩ max
ETQP6F6R4HFA
6.4µH ±25%
7.9A
8.64mΩ max
ETQP6F8R2HFA
8.2µH ±25%
7.2A
10.90mΩ max
Part
Number
Size (mm)
ETQP5LR50XFA
14.5 x 12.5 x 5.0
PCC-M125L
PCC-D124H
PCC-D125H
Power Choke Coils (cont.)
PCC-D126H
PCC-D126F
ETQP3H0R8BFA
ETQP2H1R2BFA
ETQP1H0R6BFA
ETQP6F1R8BFA
13.0 x 12.9 x 3.9
13.0 x 12.9 x 4.9
13.0 x 12.9 x 6.0
12.5 x 12.5 x 6.0
ETQP6F2R0LFA
PCC-F126F
ETQP6F2R5SFA
12.5 x 12.5 x 5.7
36
Features
•High Power (25A to 30A)
•Low loss (RDC:0.8 to 1.1 mohm)
•Tighter DCR tolerance (±5% ~ ±7%)
•Low profile
•High frequency (up to 1 MHz)
•Low Audible Noise
•High Power, High Inductance
(MnFe Core)
•Low Loss from Low RDC
•Low Audible Noise
•Surface Mount, Low profile
•High Power, High Inductance
(MnFe Core)
•Low Loss from Low RDC
•Low Audible Noise
•Surface Mount, Low profile
•High Power (Isat 20A/100)
•Thin Profile (5.7mm height)/SMD
•Low Leakage Flux (EI type/Center gap core)
CHIP INDUCTORS, EMI FILTERS, CHIP CHOKE COILS
Series
EIA
Case
Size
Inductance
@ 100 MHz
Nominal
Q* Min
@ 100 MHz
Q Typical
@ 800 MHz
ELJ-RF
0402
1.0 to 100 nH
8
21 to 14
400 to 90
0.05 to 5.5
6000 to 1200
•Non-polar
•Precision inductance
•High self-resonant frequency
ELJ-RE
0603
1.0 to 220 nH
4 to 12
47 to 20
500 to 70
0.05 to 7.5
6000 to 900
•Non-polar
•Precision inductance
•High self-resonant frequency
Rated DC
DC
Current Resistance
SRF
Max. (mA)
(Ω)
Min. (MHz)
Features**
Coil
Laser Cut
Surface Mount
Filters
High Frequency Inductors
Chip Choke Coils
EMI Filters
Chip Inductors
INDUCTORS
Series
Case
Size
ELK-E
1207
Impendance
(Ω)
Tolerance
Cap.
(pF)
Rated DC
Current
10 ~ 33K
Inductance Range
Saturation
Rated Current
DC
Resistance
Max (Ω)
Features
• For Filtering Digital Noise
•Stable Attenuation
Characteristics
Over Current Changes
Series
Size (mm)
ELL-VEG
ELL-VFG
ELL-VGG
3.0 x 3.0 x 1.0
3.0 x 3.0 x 1.2
3.0 x 3.0 x 1.5
0.68 ~ 100 µH
180 ~ 2200 mA
•Magnetic Shielding
•Low DC Resistance and large current capability
•Vibration Resistant
ELL-4GG
ELL-4LG
3.8 x 3.8 x 1.4
3.8 x 3.8 x 1.8
1.0 ~ 150.0 µH
220 ~ 2400 mA
•Magnetic Shielding
•Low DC Resistance and large current capability
•Vibration resistant
ELL-6RH
ELL-6SH
ELL-6UH
6.0 x 6.0 x 2.8
6.0 x 6.0 x 3.3
6.0 x 6.0 x 5.0
1.0 ~ 1000.0 µH
180 ~ 3400 mA
•Thin
•High Mounting Reliability
•Large Current Capability
ELL-6GG
6.0 x 6.0 x 1.6
0.8 ~ 100.0 µH
380 ~ 2500 mA
•Magnetic Shielding
•Low DC Resistance and large current capability
ELL-ATV
10.0 x 10.0 x 4.5
1.5 ~ 1000.0 µH
320 ~ 6700 mA
ELL-CTV
12.0 x 12.0 x 4.5
1.2 ~ 1000.0 µH
410 ~ 6500 mA
37
Features
•Magnetic Shielding
•Low DC Resistance and large current capability
•Available on Tape and Reel for automatic insertion
SENSORS
na.industrial.panasonic.com/products/sensors
Passive Infrared
Infrared Array: Grid-EYE
Passive Light: NaPiCa
Air Pressure
Acceleration
Active Light
SENSORS
PASSIVE INFRARED, INFRARED ARRAY
Series
Operating
Voltage
(VDC)
Current
Usage
Circuit
Stability
Time
Lens
Color
Range
Output
1µA/2µA - 25s
(typ.)
EKMB
1µA, 2µA,
6µA
2.3-4.0
PaPIRs
Passive Infrared
170µA
AMN2
3.0-6.0
170µA
AMN3
4.5-5.5
170µA
AMN4
30s (max.)
46µA
2m, 5m,
10m
45s (max.)
3.0-6.0
Black, White
2m, 5m,
10m
30s (max.)
2.2-3.0
White, Black,
Pearl White
5m, 12m
30s (max.)
Digital,
Analog
Analog
Black, White
2m, 5m,
10m
Profile (mm)*
Lens
Diameter
(mm)
5m:
94° (H), 82° (V)
5m:
14.4
5m:
9.5
12m:
102° (H), 92° (V)
12m:
20.2
12m:20.7
5m:
94° (H), 82° (V)
5m:
14.4
5m:
9.5
12m:
102° (H), 92° (V)
12m:
20.2
12m:
20.7
Slight motion:
91° (H), 91° (V)
Slight motion:
15.2
Slight motion:
12.7
5m:
100° (H), 82° (V)
5m:
14.5
5m:
9.5
Spot detection:
38° (H), 22° (V)
Spot detection:
15.1
Spot detection:
8.9
10m:
110° (H), 93° (V)
10m:
18.52
10m:
17.4
Slight motion:
91° (H), 91° (V)
Slight motion:
15.2
Slight motion:
12.7
5m:
100° (H), 82° (V)
5m:
14.5
5m:
9.5
Spot detection:
38° (H), 22° (V)
Spot detection:
15.1
Spot detection:
8.9
10m:
110° (H), 93° (V)
10m:
18.52
10m:
17.4
Slight motion:
91° (H), 91° (V)
Slight motion:
15.2
Slight motion:
12.7
5m:
100° (H), 82° (V)
5m:
14.5
5m:
9.5
Spot detection:
38° (H), 22° (V)
Spot detection:
15.1
Spot detection:
8.9
10m:
110° (H), 93° (V)
10m:
18.52
10m:
17.4
Digital,
Analog
6µA - 30s
(max.)
EKMC
NaPiOn
White, Black,
Pearl White
5m, 12m
Detection
Angle
Black, White
Digital
Digital
*Profile measured from top of sensor to base (does not include pin length)
Pixel
Array
Op.
Voltage
Amplification
Factor
Viewing
Angle
Frame
Rate
Accuracy
(typical)
Output
Resolution
Temp.
Range
(Measured
Object)
AMG8831
64
(8x8)
3.3VDC
High Gain
60°
10/1 fps
±2.5° C
0.25°C
0 ~ +80°C
0 ~ +80°C
11.6 (L)
8.0 (W)
4.3 (H)
AMG8832
64
(8x8)
3.3VDC
Low Gain
60°
10/1 fps
±3.0° C
0.25°C
-20 ~ +100°C
-20 ~ +80°C
11.6 (L)
8.0 (W)
4.3 (H)
AMG8851
64
(8x8)
5VDC
High Gain
60°
10/1 fps
±2.5° C
0.25°C
0 ~ +80°C
0 ~ +80°C
11.6 (L)
8.0 (W)
4.3 (H)
AMG8852
64
(8x8)
5VDC
Low Gain
60°
10/1 fps
±3.0° C
0.25°C
-20 ~ +100°C
-20 ~ +80°C
11.6 (L)
8.0 (W)
4.3 (H)
Infrared Array: Grid-EYE
P/N
39
Op.
Temp.
Range
Size
(mm)
Passive Light:
NaPiCa
PASSIVE LIGHT, AIR PRESSURE, ACCELERATION
SENSORS
Category
P/N
Photocurrent*
Max. Power
Dissipation
Reverse Voltage
(recommended)
Peak Sensitivity
Wavelength
Switching
Time
Dimensions
(mm)
Through-hole
AMS302
260µA*
40mW
1.5 to 6V
580nm
8.5ms (rise),
8.5ms (fall)
5.3 (H),
5.8 (Ø)
* Ev = 100lx (Ev Brightness, Fluorescent lamp is used as light source)
Series
Pressure
Range
Precision
ADP51*0
PS-A Series
Air Pressure
(Built-in amp &
compensating
circuit)
ADP51*1
ADP51A11
6kPA to
1000kPA,
ADP51B61
(±100kPA)
ADP51B62
ADP42
ADP11
Current
Consumption
Standard:
5±0.25V DC
Standard:
10mA max.
Economy:
3±0.15V DC
Economy:
3mA max.
Standard:
5±0.25V DC
Low Pressure:
10mA max.
Dimensions
(mm)*
7.2(L)x7.0(W)x8.5(H)
Opposite to pins
10.4(L)x10.4(W)x10.7(H)
10.4(L)x10.4(W)x19.3(H)
Low Pressure:
±2.5% FS
4.9kPA to
980.7kPA
1 - 1.5mA
Pressure Inlet
Hole Direction
7.2(L)x7.0(W)x6.5(H)
Economy:
±4% FS
ADP41
PF/PS Series
Standard:
±1.25% FS
Drive Voltage /
Current
Voltage input
dependent
ADP12
7.2(L)x7.0(W)x8.5(H)
Opposite to pins
7.2(L)x7.0(W)x8.5(H)
Same as pins
8.6(L)x10.0(W)x9.3(H)
Opposite to pins
8.6(L)x10.0(W)x9.3(H)
Same as pins
*Profile measured from top of sensor to base (does not include pin length)
Series
Acceleration
1-Axis
GF1
2-Axis
GS1
GS2
P/N
Operation
Voltage
Detection
Range
Detection
Sensitivity
Current
Consumption
Output
Dimensions
(mm)
Mounting
AGF10711
5V DC
±30°
3.0 V/g
10mA
Analog
58(L) x 36.5(W) x 33(H)
Direct mount
AGF11311
5V DC
±90°
1.333 V/g
10mA
Analog
85(L) x 40(W) x 37(H)
Metal bracket
AGF10712
12V DC
±30°
3.0 V/g
15mA
Analog
58(L) x 36.5(W) x 33(H)
Direct mount
AGF11312
12V DC
±90°
1.333 V/g
15mA
Analog
85(L) x 40(W) x 37(H)
Metal bracket
AGF10713
24V DC
±30°
3.0 V/g
15mA
Analog
58(L) x 36.5(W) x 33(H)
Direct mount
AGF11313
24V DC
±90°
1.333 V/g
15mA
Analog
85(L) x 40(W) x 37(H)
Metal bracket
AGS11151
5V DC
±2g
1 V/g
5mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
AGS11351
5V DC
±1.5g
1.333 V/g
5mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
AGS21631
3V DC
±2g
0.6 V/g
1.8mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
AGS21831
3V DC
±1.5g
0.8 V/g
1.8mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
AGS21151
5V DC
±2g
1 V/g
2mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
AGS21351
5V DC
±1.5g
1.333 V/g
2mA
Analog
8.5(L) x 6.2(W) x 1.6)
PCB
40
SENSORS
ACTIVE LIGHT
Series
Trigger
Function
AMA14
Built-in oscillation circuit
Thin, short,
Vertical mounting
Short,Horizontal
mounting
AMA11
External
AMBA14
Built-in oscillation circuit
Active Light
AMBA11
Middle,
Horizontal mounting
AMBA24
AMBA21
Long,
Horizontal mounting
External
Operating
Voltage
(VDC)
Detection
Range (cm)
Dimensions
(mm)
Ambient
Brightness Rating
4.5 to 5.5
5-15
20(L) x 10(W) x 12.7(H)
30,000 lux
5-10
20(L) x 10(W) x 19.5(H)
30,000 lux
20 - 80
31.2(L) x 14(W) x 23.1(H)
30,000 lux
30 - 200
46(L) x 20(W) x29.7(H)
30,000 lux
30 - 200
46(L) x 20(W) x 29.7(H)
30,000 lux
4.5 to 5.5
5.5 to 27
4.5 to 5.5
5.5 to 27
Built-in oscillation circuit
4.5 to 5.5
External
4.5 to 5.5
5.5 to 27
5.5 to 27
AMBA34
Buiilt-in oscillation circuit
AMBA31
External
AMBA34
Built-in oscillation circuit
4.5 to 6.5
6.5 to 27
4.5 to 6.5
6.5 to 27
4.5 to 6.5
Long,
Vertical mounting
AMBA31
External
6.5 to 27
4.5 to 6.5
6.5 to 27
41
ELECTROMECHANICAL
na.industrial.panasonic.com/products/electromechanical
Light Touch Switches
Detector Swtiches
Snap Action Switches
Interlock Switches
Operation Switches
Encoders
Potentiometers
Top Push
Light Touch Switches
ELECTROMECHANICAL
LIGHT TOUCH SWITCHES
Series
LxWxH
(mm)
Operating
Force
EVP-AY
3.4x2.9x1.7
1.6 N (160 gf)
2.4 N (240 gf)
•Built in Actuator
•IP67 Rated
EVP-BB
2.6x1.6x0.53
1.6 N (160 gf)
•Smallest switch in lineup
•Laser Welded Design
•Built in Actuator
•IP67 Rated
EVP-AF
3.0 x 2.6 x 0.65
3.0 x 2.6 x 0.70
1.6 N (160 gf)
2.4 N (240 gf)
3.4 N (340 gf)
•Built-in actuator for consistent tactile performance
EVP-AA
3.5 x 2.9 x 1.7
1.0 N (100 gf)
1.6 N (160 gf)
2.4 N (240 gf)
3.5 N (350 gf)
5.0 N (500 gf)
•Super small-sized, thin profile
•J-bent terminal
•Wide range of operating force
•Long operating life
EVQ-P6
4.1 x 4.1 x 0.35
4.1 x 4.1 x 0.43
4.1 x 4.1 x 0.58
1.0 N (100 gf)
1.6 N (160 gf)
2.4 N (240 gf)
•Compact/Thin Profile
•Long-life: up to 1,000,000 cycles min.
•Optional push-plate for improved actuation
•Optional ground terminal for ESD protection
EVQ-PQ
4.5 x 4.5 x 0.55
1.6 N (160 gf)
2.4 N (240 gf)
•Thin Profile
•Sealing film for dust resistance
EVQ-P2
EVQ-3P2
EVQ-P9
4.7 x 3.5 x 2.5
4.7 x 3.5 x 2.1
1.0 N (100 gf)
1.6 N (160 gf)
2.4 N (240 gf)
2.5 N (250 gf)
3.5 N (350 gf)
5.0 N (500 gf)
•J-bent terminals
•Ground terminal optional
•Middle Push: 0.7 mm
•Short Push: 0.25 mm
EVQ-PL
4.9 x 4.9 x 0.8
4.9 x 4.9 x 1.5
1.0 N (100 gf)
1.6 N (160 gf)
2.6 N (260 gf)
•Optional push-plate for improved actuation
•GND terminal included
EVQ-P0
EVQ-Q2
6.5 x 6.0 x 2.0
6.5 x 6.0 x 2.5
6.5 x 6.0 x 3.1
0.5 N (50 gf)
1.3 N (130 gf)
1.6 N (160 gf)
2.6 N (260 gf)
3.5 N (350 gf)
5.0 N (500 gf)
•Low cost
•Wide selection of height and force
•Wide push plate for reliable actuation
•Over-stroke & GND type available
•Long operating life
EVQ-PA
EVQ-PB
6.0 x 6.0 x 4.3
6.0 x 6.0 x 5.0
6.0 x 6.0 x 7.0
6.0 x 6.0 x 9.5
1.0 N (100 gf)
1.3 N (130 gf)
1.6 N (160 gf)
2.6 N (260 gf)
•Without ground terminal (EVQ-PA)
•With ground terminal (EVQ-PB)
EVQ-2
6.0 x 6.0 x 4.3
6.0 x 6.0 x 5.0
6.0 x 6.0 x 7.0
6.0 x 6.0 x 9.5
1.0 N (100 gf)
1.3 N (130 gf)
1.6 N (160 gf)
2.6 N (260 gf)
•With or without ground terminal
•Wide selection of height and force
EVQ-PE/PN/5P
6.0 x 3.5 x 4.3
6.0 x 3.5 x 5.0
1.0 N (100 gf)
1.6 N (160 gf)
2.4 N (240 gf)
•Narrow width for space saving
•SMT, bulk, radial-tape terminal types available
EVQ-11
6.0 mm dia. x 4.3
6.0 mm dia. x 5.0
6.0 mm dia. x 7.0
6.0 mm dia. x 9.5
1.0 N (100 gf)
1.3 N (130 gf)
1.6 N (160 gf)
2.6 N (260 gf)
•Radial Taping
•Forged terminals to improve mounting efficiency
•Round shape for improved packaging density
EVQ-P0
6.2 x 6.2 x 7.45
0.74 N (74 gf)
1.3 N (130 gf)
•Knob shape: De-centering, centering
•Ideal for frequent usage such as mouse button
6.1 x 6.0 x 5.0
1.6 N (160 gf)
2.0 N (200 gf)
2.2 N (220 gf)
2.5 N (250 gf)
3.5 N (350 gf)
•Push travel: 1.0 mm, 1.3 mm
•Forged terminals
•Large push plate for superior actuation
EVQ-PV
43
Features
LIGHT TOUCH SWITCHES
ELECTROMECHANICAL
Series
LxWxH
(mm)
Operating Force
EVQ-3P
EVQ-PR
6.0 x 6.0 x 0.9
6.0 x 6.0 x 0.95
1st 0.7 N,2nd 2.6 N
1st 1.0 N, 2nd 2.6 N
EVP-AK
3.8x1.9x1.6
1.6 N (160 gf)
•Edge Mount Design
•Laser Welded Design
• IP67 Rated
EVQ-P7
EVQ-P3
EVQ-9P7
3.5 x 2.9 x 1.35
1.6 N (160 gf)
2.2 N (220 gf)
•High impact resistance
•Boss and L-terminal available
Side Operated,
Half Drive
EVP-AN
3.5 x 2.9 x 1.2
1.6 N (160 gf)
2.2 N (220 gf)
•High mounting strength
•Allows for slim profile
Side
Operated,
Edge Mount
EVP-AE
4.5 x 2.25 x 2.9
1.6 N (160 gf)
•Improved soldering strength in the operating direction
•Long operational life
Double Action,
Side Operated
EVP-AJ
4.7 x 3.5 x 1.2
1.6 N (160 gf)
2.6 N (260 gf)
•With ground terminal
EVQ-PU
4.7 x 3.5 x 1.65
1.6 N (160 gf)
2.2 N (220 gf)
•High impact resistance
•Straight or J-bent terminals
EVQ-P4
6.2 x 2.55 x 3.5
1.0 N (100 gf)
1.6 N (160 gf)
2.4 N (240 gf)
2.5 N (250 gf)
3.5 N (350 gf)
5.0 N (500 gf)
•Optional edge mount for ultra high impact resistance
•0.25 mm, 0.70 mm travel
•Life: 200 K to 1 Million cycles
EVQ-PS
6.1 x 4.0 x 1.8
1.6 N (160 gf)
2.2 N (220 gf)
•Straight or J-bent terminals
•With or without positioning boss
EVQ-P1
EVQ-9P
6.1 x 6.0 x 5.0
1.6 N (160 gf)
2.0 N (200 gf)
2.2 N (220 gf)
2.5 N (250 gf)
3.0 N (300 gf)
3.5 N (350 gf)
•Push travel: 1.0 mm, 1.3 mm
•Popular for automotive applications
•J-bent terminal
•Large push plate for superior actuation
EVQ-Q1
8.5 x 8.5 x 6.5
4.0 N (400 gf)
5.0 N (500 gf)
•Ultra high force
•Popular for automotive applications
•Large push plate for superior actuation
•J-Bent Terminal
Center Space,
Long Travel
EVP-AD
9.8 x 9.8 x 4.7
4.0 N (400 gf)
•World’s first open Center Space for LED
•Long travel of 1.0mm
•100K life
Side
Operated
EVQ-PC
EVQ-PF
PC: 7.5 x 7.1 x 9.25
PF: 7.5 x 7.1 x 7.15
PF: 7.5 x 7.1 x 7.85
PF: 7.5 x 7.1 x 9.85
PF: 7.5 x 7.1 x 12.35
1.0 N (100 gf)
1.3 N (130 gf)
1.6 N (160 gf)
2.6 N (260 gf)
•Without ground terminal
•Bulk (EVQ-PF) or radial taping (EVQ-PC)
•Wide selection of height and force
Double Action
Light Touch Switches
Side
Operated
Side
Operated
Long Travel
44
Features
•Double action for camera shutter function
•Push plate, Boss & Ground as options
ELECTROMECHANICAL
DETECTOR SWITCHES
Series
Detector Switches
Horizontal
Detector
ESE-58
1HW
Detector
ESE-23
2W
Detector
ESE-24
Vertical
Detector
ESE-16
Dimensions
(mm)
Operating Force
3.5 x 3.0 x 0.9
300 mN max
(30 gf)
Mounting height:
1.4 mm
Features
•Industry’s smallest form factor and thinnest profile
•Normal close or normal open style
•Positioning boss optional
•Multiple actuation methods for design flexibility
300 mN (30 gf)
•Small/thin profile
•Long over-travel
•Usable as an operation switch (an input device)
7.5 mm x 5.6 mm x 3.0 mm
7.5 mm x 5.6 mm x 4.65 mm
350 mN (35 gf)
•Compact/thin profile
•Long over-travel
•Usable as an operation switch (an input device)
3.35 x 2.2 x 1.5
250 mN max (25 gf)
Outer dimensions:
5.0 mm x 4.15 mm
•Industry’s smallest projected size
Vertical mounting height:
4.1 mm
2 mm Size
Type 2N
ESE-22
Horizontal mounting height:
2.1 mm
300 mN (30 gf)
•Wiping contact construction
•Operable in two directions: X-X or Y-Y
•Extremely thin profile, SMD
300 mN (30gf)
•For horizontal and vertical mounting (ESE-13)
•For left and right side operation (ESE-18)
390 mN max.
•Increased the contact reliability and lifespan.
•Lifespan: 100,000 operations or more
Horizontal with frame height:
2.85 mm
Super Thin
Horizontal Thin
ESE-13
ESE-18
ESE-31
Mounting height:
1.2 mm
Mounting strength:
80 N
Switch body height:
1.7 mm
45
SNAP ACTION SWITCHES
Series
Op. Force
(gF max.)
ELECTROMECHANICAL
Max. Contact
Rating
Low
Resistive
Load Ratings
Expected
Electrical
Life
Contact
Material
Ratings
Features
—
IP40
•Handles low level load 100 μA at
3 VDC to 100 mA 30 VDC
2 × 10
3V DC 0.1mA
5
AEQ
AH1
1.2N (Pin plunger)
1.7N (Leaf lever)
1.5N
(Simulated leaf lever)
0.74N
1.47N
100 μA at 3 VDC to 100
mA 30 VDC
[Min. switching capacity
10 μA at 1 VDC]
1.47N
3 A 125 V AC
2 A 30 V DC
0.74N
1 A 125 V AC
1 A 30 V DC
10 μA at
1 VDC
105
30V DC 100mA
Standard: Ag
alloy
Au-clad contact
5 mA 6 VDC
2 mA 12 VDC
1 mA 24 VDC
3 × 10
4
Low-level:
Au-clad
Ag alloy
10 A 125, 250 VAC or 1 A
480 VAC
AM1
Non-Sealed (micro)
Snap Action Switches
AV3
AV4
AV6
0.69N to 5.30N
1/8HP 125 VAC
1/4HP 250 VAC
1/2A 125 VDC
1/4A 250 VDC
—
5 × 105
Ag alloy
1.47N
3 A 30 VAC
—
104
Ag alloy
2 × 104
Standard: Ag
alloy
UL/CSA
IP40
UL/C-UL
IP40
0.98N
0.50N
1.50N
Standard:
0.25N
AVT3
AVL3
AVM3
IP40
Ag contact:
0.5 A 30 VDC
Au contact:
0.1 A 30 VDC
0.1 A 30 VDC
Standard:
3 A 250 VAC
3 A 30 VDC
0.4 A 125 VDC
Gold-clad:
0.49N
0.98N
Long life version:
5 A 250 VAC
5 A 30 VDC
0.4 A 125 VDC
Long life version:
1.47N
Au clad contact:
0.1 A 250 VAC
—
(Au type:
2 × 105)
—
2 × 105
Double layer:
1 to 100 mA,
5 to 30 VDC
Low-level:
Au plating
Au-clad
Ag alloy
Standard: Ag
alloy
5 × 104
Triple layer:
1 to 100 mA,
5 to 250 VAC
Triple layer:
0.1 A 30 VDC
46
Low-level:
Au-clad
triple layer,
double layer
UL/C-UL,
ENEC/VDE
IP40
IP40
UL/C-UL, TÜV
•Ultra-miniature size
(12.8 × 6 × 6.5 mm 12.7
× 6 × 6 mm)
•Flux-resistant construction
•Flat terminal
•Versatile range for
all applications
•Contact gap of greater
than 1mm
•Door inter-lock switch for OA
equipment
•Super miniature size
(7.5 × 2.5 × 5 mm)
•Solder terminal type with
mounting holes available
•Mechanical life 3 × 105
•Using a connector for
connections significantly
improves operation
effectiveness
•Contact reliability by using a
simple dust prevention guard
and gold-clad double layer
contacts
IP40
•Consistent quality and high
precision through sophisticated
automatic fabrication system
UL/C-UL,
ENEC/VDE
•Low-level circuit types available
•Long life version available
ELECTROMECHANICAL
Series
SNAP ACTION SWITCHES
Op. Force
(gF max.)
Max. Contact
Rating
Low
Resistive
Load
Ratings
Expected
Electrical
Life
Contact
Material
Ratings
Features
Au-clad
IP67
•Compact size and ultra-long stroke
•IP67
•Silent operation
1P67
•Miniaturization
•Contact pressure does not depend on
the operation stroke
•Hgh contact relibility
•High effective sealing for resistance
against adverse environments
2 × 105
(Nominal)
ASQ
1.5N (Pin plunger)
1.7N (Leaf lever)
1.5N (Simulated leaf lever)
100 mA
30 V DC
1 mA 5 VDC
2 × 105
(Low-level)
1.5X10^5
(nominal)
ASQM
1.2N (Pin Plunger)
1.5N(Simulated Roller)
50mA 16VDC
1mA 5VDC
Au-Clad
3x10^5
(low level)
Ag Alloy Contact:
1.23N
1 A 125 VAC
1 A 30 VDC
Sealed (turquoise)
Snap Action Switches
1.23N
ABJ
1.96N
2.45N
(Long stroke)
1.96N
2 A 125 VAC
2 A 30 VDC
2.45N (Long stroke)
1 A 125 VAC
1 A 30 VDC
3 × 104
(Ag alloy
contact)
5 mA 6 VDC
2 mA 12 VDC
1 mA 24 VDC
105
(Au-clad
contact)
Au Clad Contact:
0.1 A 125 VAC
0.1 A 30 VDC
Ag Alloy Contact:
2 A 125 VAC
2 A 250 VAC
2 A 30 VDC
0.4 A 125 VDC
ABS
0.98N
1.47N
Au Clad Contact:
(triple, double layer)
0.1 A 125 VAC
0.1 A 250 VAC
0.1 A 30 VDC
Ag Alloy Contact:
5 A 250 VAC
(O.F. min. 1.96N)
3 A 250 VAC
(O.F. 0.98N)
ABV1
0.98N
1.96N
Au Clad Contact:
3 A 250 VAC
(O.F. min. 1.96N)
1 A 250 VAC
(O.F. 0.98N)
Standard:
Ag alloy
5 × 104
(Ag alloy
contact)
5 mA 6 VDC
2 mA 12 VDC
1 mA 24 VDC
2 × 105
(Au-clad
contact)
Low-level:
Au-clad
•Ultra-miniature size
(12.8 × 6 × 6.5 mm)
IP67
UL/CSA
•High environmental resistance (IP67)
Standard:
Ag alloy
Low-level:
Au-clad
•Sub-miniature size
(19.8 × 6.4 × 11.1 mm)
IP67
UL/C-UL,
ENEC/VDE
47
•Miniature size (33 × 10.3 × 15.9 mm)
Standard:
Ag alloy
106
(Low-level)
•Adoption of Elastomer double
molding technology and Ultrasonic
swaging technology to uniform
sealing in high production quantities
•High environmental resistance (IP67)
105
(Nominal)
5 mA 6 VDC
2 mA 12 VDC
1 mA 24 VDC
•Adoption of elastomer double
molding technology and Ultrasonic
swaging technology to uniform
sealing in high production quantities
Low-level:
Au-clad
IP67
UL/C-UL,
ENEC/VDE
•Adoption of Ultrasonic swaging
technology and epoxy sealing to
uniform sealing in high production
quantitiest
•High environmental resistance (IP67)
INTERLOCK SWITCHES, OPERATION SWITCHES
Op. Force
(gF max.)
Interlock Switches
Series
<Standard>
1 Form A: 3.92N
2 Form A: 3.92N
3 Form A: 5.88N
AGX
High capacity:
1 Form A: 4.90N
2 Form A and
3 Form A: 5.88N
1 Form A: 4.90N
1 Form B: 2.94N
1 Form A 1 Form B: 5.88N
2 Form A: 7.85N
3 Form A: 9.81N
AV1
Series
Contact
Arrangement
ELECTROMECHANICAL
Expected
Electrical
Life
Contact
Material
Standard:
10.1 A 250 V AC
1 × 105
Ag alloy
10.1 A 250 V AC
5 × 104
Ag alloy
Max. Contact
Rating
IP40
Power Rocker Switches
1a, 2a
Contact Rating
Op. Force
Load
TV Rating
5/78A 120VAC
10A (Resistive)
4A (Motor load)
100A (Capacitor)
250VAC
2.2N - 4N
10A 250V AC
6A 250V AC
16A (Resistive)
4A (Motor load)
250VAC
1a, 2a
Operation Switches
AJ8
AJ8
(Trip Function
Upgrade)
AJ8S
TV Rating
8/117A 120VAC
16A (Resistive)
4A (Motor load)
160A (Capacitor)
250VAC
16A (Resistive)
125 VAC
1a, 1c, 2a
3a
UL/C-UL, ENEC/
VDE
IP40
10A (Resistive)
4A (Motor load)
250VAC
AJ7
Ratings
10A (Resistive)
4A (Motor load)
250 VAC
16A (Resistive)
4A (Motor load)
250 VAC
10mA
5 VDC
2.45N - 4.5N
16A 250V AC
4.9N
(or less)
16A 125V AC
10A 250V AC
6.86N
(After reset)
4.9N
(or less)
UL/C-UL, ENEC/
VDE
Features
• Snap-in mounting
• 14 mm depth
• Contact gap of greater
than 4 mm
• Dual restoration spring mechanism
• Insulation distance 8 mm (snap-in mounting 2 form A
and 3 form A)
Mounting Method
Snap-in, Square hole
12.9 x 19.4 mm
(Panel thickness
1.25 to 2.0 mm)
Snap-in, Square hole
12.9 x 19.4 mm
(Panel thickness
1.25 to 2.0 mm)
Snap-in, Square hole
22 x 31.1 mm
(Panel thickness
1.8 to 2.3 mm)
Power section:
16A 250V AC
Snap-in, Square hole
22 x 31.1 mm
Signal section:
10mA 5V DC
(Panel thickness
1.8 to 2.3 mm)
48
Features
• 0.187 quick-connect
•Soldering
• PC board
• Right and left angle terminals
•0.250 quick-connect
•Soldering
•PC board
•Right and left angle terminals
• Electromagnetic reset function
• Comfortable operation
• CT terminals adopted for coil terminals
• Long life
• Ability to withstand inrush current
•Incorporates a contact for low level circuit
protection
• High inrush current resistance
• Light touch Operation
• Cadmium-free contact compatibility
ELECTROMECHANICAL
ENCODERS & POTENTIOMETERS
Life (cycles)
Rotation Torque
18mm Square
Waterproof
EVQ-V9
30,000
50 mN·m
11 mm Square
GS Encoders
EVE-V
EVE-Y
30,000
3 to 20 mN-m
•Low Profile
•Reflow Type 3.5mm Body Height
•Through-Hole Type 4mm Body Height
•Integrated Push Switch 0.4mm or 1.5mm Travel
•Minimum-Wobble Type Available
16 mm Square
High Grade
EVE-P
1,000,000
3 to 25 mN-m
•Smooth operating feel with minimal wobble
•Integrated Switch
•Long Life: 1,000,000 cycles minimum
Center Space
20/12mm, 27/18mm,
60/40mm
EVQ-V/W
30,000
3 to 20 mN-m
35 mN-m
•Open center space for LED and switch
•Allows for large knob design
•Allows for transparent shaft for superior lighting effect
Potentiometers
Encoders
Series
Features
•Water resistant
•Highly responsive click sound and feel
•High precision and reliability
Series
Life (cycles)
Rotation Torque
9mm
Rotary
EVU-E/F
10,000
1 to 20 mN-m
•Multiple Bushing & Height Configurations
•Midpoint detent optional
12mm
Dual Rotary
EVJ-C/Y
15,000
2 to 20 mN-m
•Dual output with accurate tracking
10mm Sensor
EVW-AE
1,000,000
3 mN-m max.
•Low profile, small size, long life
•<3% linearity
Center Space
39/20mm
EWV-YE/YG/YJ/YK
30,000
20 mN-m
49
Features
•Large center space for switch and LED
•Low wobble of 0.25mm max
•Multiple detent options (5, 8, 29)
•Automotive grade
•With built-in LED option
CIRCUIT PROTECTION
na.industrial.panasonic.com/products/circuit-thermal-protection/circuit-protection
Thermistors
ZNR Surge Absorbers
Varistors
Varistor Arrays
Pyrolytic Graphite Sheet (PGS)
EMI Filters
CIRCUIT PROTECTION
Case Size (EIA)
LxWxH (mm)
Electrical
Characteristics
Operating
Temperature
ERT-JZ
0201
(0.6 x 0.3 x 0.3)
Nominal Resistance @
2K ~ 100 K
-40 ~ +125°C
ERT-J0
0402
(1.0 x 0.5 x 0.5)
Nominal Resistance @
22 ~ 470 K
Power Dissipation
33 mW ~ 100mW
ERT-J1
0603
(1.6 x 0.8 x 0.8)
Nominal Resistance @
22 ~ 150 K
Dissipation Factor
1 mW/°C ~ 3m W/°C
Thermistors
Series
Leaded
ZNR Surge Absorbers
THERMISTORS, ZNR SURGE ABSORBERS, VARISTORS
Features
•Surface Mount 0201, 0402, 0603
•Highly Reliable
•Multi-layer & Monolithic available
•Lead Free (RoHS)
Series
Case Size (EIA)
LxWxH (mm)
ERZExxA
5 to 14 mm f Disc
Varistor voltages 200 to 1800 VDC
Max Peak Currents 1200 to 10000A
•Safety Agency recognized
•Replace next larger V Series devices
ERZ-VxxD
5 to 20 mm
Ø Disc
Varistor Voltages: 18 to 1,800 VDC
Max. Peak Currents: 125 to 6,500 A
•Large energy handling capabilities
•UL / VDE / CSA Safety Certifications
•QS9000
ERZVS34Cxx
36 x 47 mm
Varistor Voltages: 170-765 VDC
Electrical Characteristics
Operating
Temperature
Features
•Very large surge withstand capability
•Fast response to steep impulse voltage
•Low clamping voltage for better surge protection
•UL and CSA recognized
Zinc-oxide
ERZ-CxxCk
•High energy handling capability
(210 to 750 joules)
VAC 130 to 575 vms
•Common terminals for mounting and
electrical connections
Surface Mount
Strontium Titanate
Varistors
36.44 mm Ø
ERZ-VF
Molded Case
(6.0 x 8.0 x 3.2)
Varistor Voltages: 22 ~ 470 VDC
Max. Peak Currents: 125 to 300 A
EZJ-Z0
0402
(1.0 x 0.5 x 0.5)
Varistor Voltages: 12 ~ 170 VDC
Capacitance: 1 ~220 pF Max.
8 kV Max. ESD Capability
EZJ-Z1
0603
(1.6 x 0.8 x 0.8)
Varistor Voltages: 12 ~ 170 VDC
Capacitance: 1 ~ 330 pF Max.
8 kV Max. ESD Capability
•Flow (wave) / Reflow soldering
•UL (Pending)
-40 ~ +85°C
•Small case sizes
•Low capacitance loading
•Ideal for high speed signal lines
EZJ-ZS
0504
(1.37 x 1.0 x 0.6)
Varistor Voltages: 12 ~ 170 VDC
Capacitance: 3 ~ 220 pF Max.
8 kV Max. ESD Capability
•2 Varistors per array
•Part count reduction
•Board space savings
EZJ-P0
0402
(1.0 x 0.5 x 0.5)
Varistor Voltages: 8 VDC
Capacitance: 27 ~ 680 pF Max.
8 kV Max. ESD Capability
•4 Varistors per array
•Part count reduction
•Board space savings
•Excellent ESD Suppression
EZJ-S1
0603
(1.37 x 1.0 x 0.6)
Varistor Voltages: 12 ~ 50 VDC
Capacitance: 1,800 ~ 8,200 pF Max.
30 kV Max. ESD Capability
•High ESD capabilities
EZJ-S2
0805
(2.0 x 1.25 x .85)
Varistor Voltages: 12 ~ 50 VDC
Capacitance: 4,700 ~ 22,000 pF Typical
30 kV Max. ESD Capability
•High ESD capabilities
51
VARISTORS
Standard
Varistors
Low Capacitance
Type
CIRCUIT PROTECTION
Case Size
Varistor
Voltage
Max. Allowable
Voltage (DC)
Capacitance
EZJ-Z0V80010
0402
80 V
10 V
1 pF max
EZJ-Z0V80015D
0402
80 V
5V
1.5 ± 0.5
EZJ-Z0V500AA
0402
50 V
5V
3 pF max
EZJ-Z0V800AA
0402
80 V
18 V
3 pF max
EZJ-Z0V171AA
0402
170 V
18 V
3 pF max
EZJ-Z1V80010
0603
80 V
10 V
1 pF max
EZJ-Z1V500AA
0603
50 V
5V
3 pF max
EZJ-Z1V800AA
0603
80 V
18 V
3 pF max
EZJ-Z1V171AA
0603
170 V
18 V
3 pF max
EZJ-Z1V330GA
0603
33 V
26 V
100 pF max
EZJ-PZV6R8JA
0201
6.8 V
3.7 V
220 pF max
EZJ-PZV6R8GA
0201
6.8 V
3.7 V
100 pF max
EZJ-PZV080GA
0201
8V
5.6 V
100 pF max
EZJ-PZV120GA
0201
12 V
7.5 V
100 pF max
EZJ-PZV120DA
0201
12 V
7.5 V
27 pF max
EZJ-PZV120RA
0201
12 V
7.5 V
20 pF max
EZJ-PZV150RA
0201
15 V
9V
20 pF max
EZJ-PZV270RA
0201
27 V
16 V
20 pF max
EZJ-PZV270BA
0201
27 V
16 V
10 pF max
EZJ-P0V6R8MA
0402
6.8 V
3.7 V
680 pF max
EZJ-P0V6R8GA
0402
6.8 V
3.7 V
100 pF max
EZJ-P0V080MA
0402
8V
5.6 V
680 pF max
EZJ-P0V080KA
0402
8V
5.6 V
330 pF max
EZJ-P0V080GA
0402
8V
5.6 V
100 pF max
EZJ-P0V080DA
0402
8V
5.6 V
27 pF max
EZJ-Z0V120JA
0402
12 V
6.7 V
220 pF max
EZJ-Z0V180HA
0402
18 V
11 V
150 pF max
EZJ-Z0V220HA
0402
22 V
13 V
150 pF max
EZJ-P0V270EA
0402
27 V
16 V
47 pF max
Part Number
EZJ-P0V270RA
0402
27 V
16 V
20 pF max
EZJ-Z0V420WA
0402
42 V
30 V
56 pF max
EZJ-Z0V650DA
0402
65 V
40 V
27 pF max
ERJ-Z1V120KA
0603
12 V
6.7 V
330 pF max
ERJ-Z1V180JA
0603
18 V
11 V
220 pF max
ERJ-Z1V220JA
0603
22 V
13 V
220 pF max
ERJ-Z1V270GA
0603
27 V
16 V
100 pF max
ERJ-Z1V270EA
0603
27 V
16 V
47 pF max
ERJ-Z1V270RA
0603
27 V
16 V
20 pF max
52
Maximum ESD
[IE061000-4-2]
Contact Discharge
Voltage: 8 kV
CIRCUIT PROTECTION
Standard
2 Array
2 Varistors
2 Capacitors
Per Array
High
Capacitance
Varistors
Varistor Arrays
Varistors
Type
VARISTOR ARRAYS, PYROLYTIC GRAPHITE SHEET (PGS)
Part Number
Case Size
Varistor
Voltage
Max. Allowable
Voltage (DC)
Capacitance
ERJ-Z1V330GA
0603
33 V
26 V
100 pF max
ERJ-Z1V420FA
0603
42 V
30 V
68 pF max
ERJ-Z1V650DA
0603
65 V
40 V
27 pF max
EZJ-ZSV120JA
0504
12 V
6.7 V
220 pF max
EZJ-ZSV270RA
0504
27 V
16 V
20 pF max
EZJ-ZSV270EA
0504
27 V
16 V
47 pF max
EZJ-ZSV800AA
0504
80 V
18 V
3 pF max
EZJ-ZSV171AA
0504
170 V
18 V
3 pF max
EZJ-ZSV270TA
0504
27 V
16 V
43 pF
EZJ-ZSV270EA
0504
27 V
27 V
47 pF
EZJ-S1VB822
0603
12 V
6V
8200 pF
EZJ-S1VC392
0603
30 V
18 V
3900 pF
EZJ-S1VD182
0603
50 V
30 V
1800 pF
EZJ-S2VB223
0805
12 V
6V
22000 pF
EZJ-S2YC822
0805
30 V
18 V
8200 pF
EZJ-S2YD472
0805
50 V
30 V
4700 pF
Maximum ESD
[IE061000-4-2]
Contact Discharge
Voltage: 8 kV
Contact Discharge
Voltage: 30kV
Type,
A-RV
A-KV
Pyrolytic Graphite Sheet (PGS)
A-V
Heat Resistance:
400°C, Bending
(Angle 180, R5):
1000 cycles
Graphite
Sheet
With High
Heat
Resistant
Acrylic
Adhesive
Graphite
Sheet
With High
Heat
Resistant
Acrylic
Adhesive
Peek Tape
Graphite
Sheet With
High Heat
Resistant
Acrylic
Adhesive and
Polymide
Tape
Thickness
70 µm
0.07 ± 0.015 mm
25 µm
0.025 ± 0.010
17 µm
0.017 ± 0.005
70 µm
0.07 ± 0.015 mm
25 µm
0.025 ± 0.010
17 µm
0.017 ± 0.005 mm
70 µm
0.07 ± 0.015 mm
25 µm
0.025 ± 0.010
17 µm
0.017 ± 0.005
Thermal
Conductivity Electrical Extensional
Part Number Sheet Size Density (a-b plane) Conductivity Strength
EYG-A091207V
90 x 115
EYG-A121807V
115 x 180
EYG-A091203V
90 x 115
EYG-A121803V
115 x 180
EYG-A091202V
90 x 115
EYG-A121802V
115 x 180
EYG-A091207RV
90 x 115
EYG-A121807RV
115 x 180
EYG-A091203RV
90 x 115
EYG-A121803RV
115 x 180
EYG-A091202RV
90 x 115
EYG-A121802RV
115 x 180
EYG-A091207KV
90 x 115
EYG-A121807KV
115 x 180
EYG-A091203KV
90 x 115
EYG-A121803KV
115 x 180
EYG-A091202KV
90 x 115
EYG-A121802KV
115 x 180
Expansion
Coefficient
(a-b plane)
Expansion
Coefficient
(c axis)
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
53
PYROLYTIC GRAPHITE SHEET (PGS)
CIRCUIT PROTECTION
Type,
Graphite Sheet
Only
Graphite Sheet
With Acrylic
Adhesive
A-A
A-M
Graphite Sheet
With Thin Acrylic
Adhesive
Graphite Sheet
With Acrylic
Adhesive and
Polyester Tape
Thickness
EYG-S091210*
90 x 115
EYG-S121810*
115 x 180
EYG-S182310*
180 x 230
EYG-S091207*
90 x 115
70 µm
0.07 ± 0.015 mm
EYG-S121807 *
115 x 180
EYG-S182307*
180 x 230
25 µm
0.025 ± 0.010mm
EYG-S091203*
90 x 115
EYG-S121803*
115 x 180
70 µm
0.07 ± 0.015 mm
EYG-A091207A
90 x 115
EYG-A121807A
115 x 180
25 µm
0.025 ± 0.010
EYG-A091203A
90 x 115
EYG-A121803A
115 x 180
17 µm
0.017 ± 0.005 mm
EYG-A091202A
90 x 115
EYG-A121802A
115 x 180
70 µm
0.07 ± 0.015 mm
EYG-A091207M
90 x 115
EYG-A121807M
115 x 180
25 µm
0.025 ± 0.010
EYG-A091203M
90 x 115
EYG-A121803M
115 x 180
17 µm
0.017 ± 0.005
EYG-A091202M
90 x 115
EYG-A121802M
115 x 180
70 µm
0.07 ± 0.015 mm
EYG-A091207PA
90 x 115
EYG-A121807PA
115 x 180
25 µm
0.025 ± 0.010
EYG-A091203PA
90 x 115
EYG-A121803PA
115 x 180
17 µm
0.017 ± 0.005 mm
EYG-A091202PA
90 x 115
EYG-A121802PA
115 x 180
70 µm
0.07 ± 0.015 mm
EYG-A091207PM
90 x 115
EYG-A121807PM
115 x 180
25 µm
0.025 ± 0.010
EYG-A091203PM
90 x 115
EYG-A121803PM
115 x 180
17 µm
0.017 ± 0.005
EYG-A091202PM
90 x 115
EYG-A121802PM
115 x 180
A-DM
25 µm
0.025 ± 0.010
17 µm
0.017 ± 0.005 mm
NOTE:
Thermal
Conductivity Electrical Extensional
Part Number Sheet Size Density (a-b plane) Conductivity Strength
100 µm
0.10 ± 0.03 mm
70 µm
0.07 ± 0.015 mm
Graphite Sheet
With Thin Acrylic
Adhesive and
Thin Polyester Tape
Pyrolytic Graphite Sheet (PGS)
A-PA
A-PM
Graphite Sheet
With Thin Acrylic
Adhesive and
Polyester Tape
S
Heat Resistance:
400°C, Bending
(Angle 180, R5):
1000 cycles
EYG-A091207DM
90 x 115
EYG-A121807DM
115 x 180
EYG-A020207DM
20 x 20
EYG-A030307DM
30 x 30
EYG-A060907DM
60 x 90
EYG-A091203DM
90 x 115
EYG-A121803DM
115 x 180
EYG-A020203DM
20 x 20
EYG-A030303DM
30 x 30
EYG-A060903DM
60 x 90
EYG-A091202DM
90 x 115
EYG-A121802DM
115 x 180
EYG-A020202DM
20 x 20
EYG-A030302DM
30 x 30
EYG-A060902DM
60 x 90
Expansion
Coefficient
(a-b plane)
Expansion
Coefficient
(c axis)
0.85 g/cm3
700 W/(m·K)
10000 S/cm
19.6 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.21 g/cm3
1000 W/(m·K)
10000 S/cm
22.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
1.90 g/cm3
1600 W/(m·K)
20000 S/cm
30.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
2.10 g/cm3
1750 W/(m·K)
20000 S/cm
40.0 MPa
9.3 x 10-7 1/K
3.2 x 10-5 1/K
* “DP” suffix individually packed in paper separator folders
54
EMI Filters
Surface Mount Filters
Common Mode
Noise Filter
CIRCUIT PROTECTION
EMI FILTERS
Rated DC
Current
DC
Resistance
Max (Ω)
±20%
130 mA
2.5
Common mode
Z:24, 90
±20%
160mA,
100mA
1.5, 3.0
•Meet The Mask-Test For HDMI
•High Reliability
0504
Common mode Z:36
~ 200
±25%
130mA ~
200 mA
1.0 ~ 2.70
•High-Q Impedance Available
•Magnetic Shield
0804
Common mode Z:90
~ 200
±25%
130mA ~
160 mA
1.5 ~ 2.50
Series
Case
Size
Impendance
(Ω)
EXC-14CE
0302
Common mode
Z: 65, 90
EXC-24CG
0504
EXC-24CE EXC24CF
EXC-28CE
Tolerance
Cap.
(pF)
Features
•Low DC Resistance and Insertion Loss
•Low Profile
•2 Common Mode Noise Filters
Per Package
•Magnetic Shield
•Small Size
0504
Common mode Z:120
~ 1000
2 Mode Noise
Filter
Common mode Z:90
EXC-24CB/CP
EXC-24CN
Chip Bead
Cores
0804
EXC-CL
EXC-ML
EXC-3B
0603 ~
4532
Coil
EXC-28CG
ELK-E
1207
±25%
130 mA
±25%
50mA ~ 500
mA
3.0
•Burst/Radiation Noise Reduction
For Audio Circuits
0.3 ~ 1.5
•Filtering Common & Normal Mode Noises
•Magnetic Shielding
Z: 25 ~ 115
Z: 27 ~ 68
Z: 60 ~ 1000
50mA ~ 2000
mA
±25%
0.1 ~ 1.0
•Effective Noise Suppression For Power
Lines And High Speed Signal Lines
• For Filtering Digital Noise
10 ~ 33K
55
•Stable Attenuation Characteristics Over
Current Changes
WIRELESS
CONNECTIVITY
na.industrial.panasonic.com/products/wireless-connectivity
®
Bluetooth RF Modules
802.15.4 (Mesh) RF Modules
ISM (Industrial, Scientific, Medical) RF Modules
WiFi, WiFi + BT RF Modules
WIRELESS CONNECTIVITY
BLUETOOTH, MESH NETWORKING (802.15.4), ISM
I/Os
Interfaces
Max. Data
Rate
Dev Kit
Dev
Module
9.0x6.5x1.8
9.0x9.5.1.8
-93 dBm
+10.5 dBm
1.8 - 4.8V
2.4 GHz
N/A
PCM, UART, I2S
3M bits/sec
Yes
Yes
PAN1315A/
PAN1325A
**
9.0x6.5x1.8
9.0x9.5.1.8
-93 dBm
+10.5 dBm
1.8 - 4.8 V
2.4 GHz
2
PCM, UART, I2S
3MBits/s
Yes
Yes
PAN1322
15.6x8.7x1.8
-86 dBm
+4 dBm
2.9 - 4.1 V
2.4 GHz
>15
GPIO, UART,
JTAG
720K bits/s
Yes
Yes
PAN1311/
PAN1321
*
11.6x8.7x1.8
15.6x8.7x1.8
-86 dBm
+4 dBm
2.7 - 3.6 V
2.4 GHz
>15
GPIO, UART,
JTAG
720K bits/s
No
No
PAN1321i
*
15.6x8.7x 1.8
-86 dBm
+4 dBm
2.7 - 3.6 V
2.4 GHz
>15
GPIO, UART,
JTAG
720K bits/s
No
No
PAN1455/
PAN1555
*
13.5 x 18.75 x
2.85 mm
18.8x13.5x 2.5
-86 dBm
+4 dBm
2.7 - 3.6 V
2.4 GHz
18
3x UART, I2C,
SPI, ADC
3M bits/sec
Yes
No
PAN1026
15.6x8.7x1.8
-88 dBm
+4 dBm
1.8 - 3.3V
2.4GHz
N/A
GPIO, UART
720K bits/s
Yes
Yes
PAN1316B/
PAN1326B
9.0x6.5x1.8
9.0x9.5.1.8
-93 dBm
+10.5 dBm
1.8 - 4.8V
2.4 GHz
N/A
PCM, UART, I2S
3MBits/sec
Yes
Yes
PAN1316A/
PAN1326A
**
9.0x6.5x1.8
9.5x9.0x1.8
-93 dBm
+10.5 dBm
1.8 - 4.8 V
2.4 GHz
2
PCM, UART, I2S
3MBits/s
Yes
Yes
PAN1317/
PAN1327
**
6.5x9.0x1.8
9.5x9.0x1.8
-93 dBm
+10.5 dBm
1.8 - 4.8 V
2.4 GHz
2
PCM, UART, I2S
3MBits/s
Yes
Yes
PAN1740
9.0x9.5x1.8
-93 dBm
0 dBm
2.35 - 3.3
2.4 GHZ
2
GPIO, UART,
SPI, PC, 3-axis
QD, ADC
< 10K bit/sec
Yes
Yes
PAN1760
15.6x8.7x1.8
-88 dBm
+4 dBm
1.8 - 3.3V
2.4 GHZ
10
GPIO, UART
< 10K bit/sec
Yes
Yes
PAN1720/
PAN1720BR
*
15.6x8.7x1.8
-94 dBm
+3 dBm
2.0 - 3.6 V
2.4 GHz
19
GPIO, UART
(USB)
< 10K bit/sec
Yes
No
PAN1711/
PAN1711BR/
PAN1721/
PAN1721BR
*
11.6x8.7x1.8
15.6x8.2x3
-94 dBm
0 dBm
2.0 - 3.6 V
2.4 GHz
19
I2C, GPIO, UART
< 10K bit/sec
Yes
No
PAN1323
**
9.0x9.5.1.8
-93 dBm
+10 dBm
1.7 - 4.8 V
2.4 GHz
2
PCM, UART, I2S
3MBits/s
Yes
Yes
PAN4561/
PAN4561L
*
35.0x15.0x3.8
-98 dBM @ 250
kbps
+18.5 dBm/
0 dBm
2.7 - 3.4 V
2.4 GHz
39
GPIO, UART, A/D
250Kbs
Yes
Yes
PAN4580
29.8x19.0x2.6
-100dBm @ 250
kbps
+3.5 dBm
1.9 - 3.6 V
2.4 GHz
38
GPIO, 2 x UART,
SPI, ADC
2 M bits/sec
No
No
PAN235x
*
8.0x8.2x1.9
-104 dBm
@2.4kBits/s
+10 dBm
1.8 - 3.6 V
303MHz 2.4GHz
2
Output
GPO, SPI
500K bits/sec
No
No
Triple
Mode
Bluetooth Smart (Low Energy)
Bluetooth
Classic
PAN1315B/
PAN1325B
Bluetooth Smart Ready
(Multi-Mode)
Freq.
Range
Size (mm)
Dual Mode +
ANT™
Power
Supply
Series
Mesh Networking
(802.15.4)
Max.
Output
Power
ISM
Receiver
Sensitivity
* = Operating Temp: -40 to +85º C
** = Operating Temp: -20 to +70º C (-40 to +85º C Optional)
57
WIFI, WIFI + BT WIRELESS CONNECTIVITY
GPIO
Interfaces
Max. Data
Rate
Dev Kit
Dev
Module
WiFi (b/g/n)
(Non Embedded)
Freq.
Range
Size (mm)
PAN9010/
PAN 9020
22.75 x 13.5 x 2.42
-98 dBm
+18 dBm
3.0 - 3.6 V
2.4 GHz
N/A
USB 2.0 or SDIO
150Mbs
Yes
Yes
WiFi (b/g/n)
(Embedded)
Power
Supply
Series
PAN9320
*
29.0 x 13.5 x 2.66
-98 dBm
+18 dBm
3.0 - 3.6 V
2.4 GHz
8
2 UARTs, QSPI
300Mbs
Yes
Yes
WiFi (b/g/n) + BT
+ BLE (Non Embedded)
Max.
Output
Power
Receiver
Sensitivity
PAN9045/
PAN9055
26.0 x 13.5 x 2.40
-98 dBm
+18 dBm
3.0 - 3.6 V
2.4 GHz
N/A
USB 2.0, SDIO
3.0, HS UART
300Mbs
Yes
Yes
* = Operating Temp: -30 to +70º C
58
Over 65,000 Part Numbers
Are Just a Click Away
Visit the NEW Panasonic Website Today at:
na.industrial.panasonic.com
Quickly and Easily Search Product Details
Discover The Latest Panasonic Products
Easily Find Inventory By Part Number
Locate Distributors & Get Support
[email protected]
1-800-344-2112
SEMICONDUCTORS
na.industrial.panasonic.com/products/semiconductors
Diodes
Transistors
MOSFETs
ASSP
SEMICONDUCTORS
Type
Diodes
Switching Diode
DIODES, TRANSISTORS
Package
Surface Mount
Surface Mount
DB
Type
Package
Series
Zener Diode
Surface Mount
DA**F
Surface Mount
Type
Small Signal Transistor
(Low-frequency
Amplifiers)
Package
Surface Mount
VR
(V)
IF(AV)
(mA)
IR max.
(uA)
trr max.
(ns)
VF max.
(ns)
IF (mA)
40 - 300
100 - 200
0.1 - 1.0
3.0 - 60
--
--
VR
(V)
IF(AV)
(mA)
IR max.
(uA)
trr max.
(ns)
VF max.
(ns)
IF (mA)
20 - 60
30 - 5000
0.3 - 3150
--
0.37 - 1.0
30 - 5000
VF max.
(V)
IF (A)
trr max.
(ns)
200 - 800
0.98 - 4.0
0.2 - 1.0
25 - 400 (typ.)
VZ (V)
nom.
VZ (V)
min. to max.
2.7 - 82
2.28 - 87
DZ
0.3 - 1
DS
Polarity
DS
PNP-/NPN
Type
Package
Series
Polarity
Transistor with Built-in
Resistors
(Ic = 80mA Series)
Transistor with Built-in
Resistors
(Ic = 100mA Series)
Transistor with Built-in
Resistors
(Ic = 200mA Series)
Junction FET
(Low Frequency Amplifier)
Surface Mount
Surface Mount
Surface Mount
Surface Mount
DM
DR
DR
DR
DSK
--
PNP/NPN
Electrical
Characteristics
Absolute Maximum Rating
PNP/NPN
Surface Mount
Surface Mount
1 - 20
--
Series
Electrical
Characteristics
Absolute Maximum Rating
VRRM
IF(AV)
IFSM max.
(V)
(A)
(A)
Small Signal Transistor
(High-frequency
Amplifiers)
Composite Transistor
Electrical
Characteristics
Absolute Maximum Rating
DA/BA
Schottky
Barrier Diode
Fast Recovery
Diode
Transistors
Series
VCEO
(V)
IC
(mA)
VCE (sat)
max. (V)
IC
(mA)
hFE
IC (mA)
10 - 100
20 - 5000
0.15 - 2.5
10 - 3000
90 - 40000
1 - 2000
VCEO
(V)
IC
(mA)
fT typ.
(Hz)
IC
(mA)
hFE
IC (mA)
10 - 20
15 - 50
300M - 1.6G
(max.)
1 - 15
25 - 260
1-5
Electrical
Characteristics
Absolute Maximum Rating
VCEO
(V)
IC
(mA)
-50 - 100
-500 - 500
PNP/NPN
PNP/NPN
PNP/NPN
Nch
61
hFE
65 - 1200
Resistor Value (kΩ)
VCEO
(V)
IC
(mA)
50
80
VCEO
(V)
IC
(mA)
50
100
VCEO
(V)
IC
(mA)
30
200
VGDS
(V)
ID
(mA)
IDSS max.
(mA)
55
30
6.5
hFE
R1
R2
0.51 - 100
2.2 - 100
6 - 460
Resistor Value (kΩ)
hFE
R1
R2
0.51 - 100
2.2 - 100
6 - 460
Resistor Value (kΩ)
hFE
R1
R2
1 - 4.7
4.7 - 47
115 - 140
MOSFETS
SEMICONDUCTORS
Type
Package
Series
MOSFETs
VDSS
(V)
MOS FETs
Surface Mount
FK3
Composite MOS FETs
(Small Signal)
Surface Mount
F**
Type
Package
Series
RDS (on) max. (Ω)
ID
(A)
VGS =
2.5V
tON typ.
(ns)
VGS =
4.0V
tOFF typ.
(ns)
Pch
30
0.1
17
7
300
400
Nch
30 - 60
0.1
6 -15
3 -12
100
100
Nch x 2
30 - 60
0.1
6 - 15
3 -12
100
100
Pch + Nch
-30/30
-0.1/0.1
17/6
7/3
100/100
100/100
Electrical
Characteristics
Polarity Absolute Maximum Rating
VDSS
(V)
ID
(A)
RDS (on) max. (Ω)
VGS =
1.8V
VGS =
2.5V
VGS = 4.0V
Ciss typ. (pF)
tON typ.
(ns)
tOFF typ.
(ns)
MOSFETs
(Power Management)
Surface Mount
MTM/FJ
Pch
12
4.0
54 - 75
41 - 55
40 - 42
1200
30 - 50
300
MOSFETs
(Power Management)
Surface Mount
MTM/FJ
Pch
20
1.0 - 3.0
230/-
70 - 560
55 - 420
80 - 3000
14 - 50
27 - 250
MOSFETs
(Power Management)
Surface Mount
MTM/FK
Nch
20
2.0 - 4.5
300/-
28 - 150
28 - 110
280 - 1730
12 - 49
50 - 225
VDSS
(V)
ID
(A)
Ciss typ. (pF)
tON typ.
(ns)
tOFF typ.
(ns)
Pch
40
Nch
Nch x 2
MOSFETs
(Power Management)
Surface Mount
MOSFETs
(Power Management)
Surface Mount MTM / FK
Composite MOSFETs
(Power Management)
Surface Mount
MTM
FC
RDS (on) max. (Ω)
VGS =
4.5V
VGS =
5.0V
VGS = 10V
7.0
45
-
25
2700
33
300
33 - 40
6.5 - 14
13 - 35
-
4.6 - 25
360 - 1750
11 -19
33 - 350
33
5.0 - 6.5
35 - 68
-
20 - 40
210 - 360
10 - 11
24 -33
VDSS
(V)
ID
(A)
Ciss typ. (pF)
tON typ.
(ns)
tOFF typ.
(ns)
Pch x 2
-20 - -12
RDS (on) max. (Ω)
VGS =
1.8V
VGS =
2.5V
VGS = 4.0V
-4.8 - -12
60 - 280
40 - 200
42 - 130
440 - 1400
20 - 243
96 - 430
Composite MOSFETs
(Power Management)
Surface Mount
Composite MOSFETs
(Power Management)
Surface Mount MTM / FC
Nch x 2
20 - 24
2.0 - 8.0
300/-
15 - 150
25 - 105
280 - 1450
13 - 1030
38 -6000
Composite MOSFETs
(Power Management)
Surface Mount MTM / FG
Pch + Nch
-20/20
-1.2/1.9
-
200/150
130/105
440/280
35/12
100/50
Composite MOSFETs (Power
Surface Mount MTM / FG
Management)
Pch + Nch
-20/30
-2.0/0.1
245/-
185/6000 135/3000
300/12
14/100
112/100
Type
MTM
Package Series Polarity
Absolute Maximum
Rating
MOS FET
VDSS
(V)
MOSFETs
Electrical
Characteristics
Polarity Absolute Maximum Rating
MOSFET + SBD
(Power Management)
Surface Mount
FL
Pch
-20
MOSFET + SBD
(Power Management)
Surface Mount
FM
Nch
20
ID
(A)
Electrical
Characteristics
SBD
VR
(V)
MOS FET
IF
(A)
RDS (on) max. (Ω)
VGS = VGS = VGS =
1.8V 2.5V 4.0V
-1.0 0.5 15 - 20
230/2.1
0.8
2.0 - 2.2
20
62
0.8 1.0
-
SBD
Ciss typ. tON typ. tOFF typ. VF max. IF IR max.
(pF)
(ns)
(ns)
(V)
(mA) (uA)
170 560
120 0.47 80 - 400 6 - 35 17 - 112
420
0.55
150
105
280
13
38
0.47 0.52
500 10 - 200
800
800 1000
80
Hall
Sensor ICs
DCDC Converters
SEMICONDUCTORS
ASSP
Type
Package
Series
Operating
Voltage
(V)
High-Reliability DCDC with
Integrated FET
SSOP024-P-0300F
HQFP048-P-0707B
AN33xxx
5.0 - 39.0
Multi-Ch DCDC with
Integrated FET&LDO
UBGA009-W-1515AEA
HQFN024-P-0404
Others
Output
Voltage
(V)
1.2 - 9.0
Functions
•Settable Oscillation Frequency Range:
200 kHz - 2.0 MHz
•Various Built-in Protection Functions
(UVLO, OVP, SOP, TSD)
•High-speed Response Due to Hysteretic Control
AN301xxx
2.5 - 5.5
0.8 - 3.3
•Abundant Protection Functions
(Protection Against Over-current, Short-circuit,
UVLO, Overheating)
•On/Off Control Possible Using External Enable Pin
DCDC with FETs in a Package
HQFN024-A3-0404A
HQFN040-A3-0606
Others
NN30xxx
4.5 - 30.0
0.6 - 5.5
Position Sensor ICs
SMINI-5DE
AN488xx
-
-
Stepping Motor Drivers
SSOP032-P-0300B
HSOP042-P-0400D
Others
AN44xxx
10 - 34 (VM)
Peak Current
•High-speed Response Due to Hysteretic Control
•Various Built-in Protection Functions
(OVP, OCP, SCP, TSD)
•Low-power Consumption,
•High Sensitivity
•CMOS Hall IC COMOS Inverter
•Bult-in Thermal Protection Circuit
•Built in PWM Oscillator (Not in AN44071A)
Motor Drivers
LED Driver
RF Amplifiers
Logic LSI
ASSP
0.8A - 2.5A
Motor Drivers Special
Functions
AN41908
2.7 - 3.6 (Vcc)
3.0 - 5.5 (VM)
-
•4-channel H Bride Driver (256 Micro Step)
•Three-line Bi-directional Serial Data Communication
•Built-in PWM Drive Iris Control
AN41919
3.1, 4.8
-
•DC Iris Control IC
QFN044-P-0606D
3-Phase Brushless
DC Motor Driver IC
HQFN024-A-0404
AN441xxA
12v/24v system
-
•Provide sine-wave PWM drive with one Hall sensor to
reduce the component count, size,
•and noise of a motor module
Brushed DC Motor Driver IC
WLCSP
HSOP034-P-0300A
AN44xxxA/
AN41xxxA
5v/24v system
-
•Panasonic brushed DC motor series consists of the
single motor driver ICs and the dual motor driver ICs.
Matrix LED Drivers
XBGA012-W-1316AEL
UBGA035-W-3333AEA
Others
AN3xxxx
3.1 - 6.0
-
•LED Matrix Driver
General Purpose LED Drivers
SSOP016-P-0225E
QFN016-P-0304B
AN30888A/B
3.0 - 20.0
-
•High-brightness LED-drive Driver IC
•Reference Voltage (VREF) 30mV/200mV
•For Backlights, Camera Flashes, General Illumination
Low Noise Amplifiers
SSMINI-5DC
ALGA005-W-0609ANA
AN260xxx
1.65 - 3.6
-
•LNA for GPS (AN26014, AN26016)
•5 GHz-band LNA for WLAN (AN26025)
•Others
Power Amplifiers
ALGA011-W-0912ANB
AN26102
2.95 - 4.2
-
•2.4 GHz-band PA for WLAN
NFC Tag
SSOP 16pins 5.0 x 6.4mm
QFN 16pins 3.2 x 4.2mm
MN63Y12xx
1.7 - 3.6
-
•RF interface compliant to ISO/IEC14443 TypeB,
JISX6319-4
•NFC forum specification Type3 tag, Type4 tag
•Built in non volatile memory: 4k bit FeRAM
63
ASSP
SEMICONDUCTORS
Package
Touch key control MCU
SSOP 32pins 11.0 x 8.1mm
LQFP 64pins 16.0 x 16.0mm
Series
MN101EFA5-7
-
-
Functions
•Panasonic original AM1 (MN101) 8-bit Single-chip
Microcontroller
•Built-in capacitive touch key detection circuit
selection of products with built in ROM/RAM from
32k/1k to 128k/6k
MCU
Type
Operating Output
Voltage Voltage
(V)
(V)
•8-bit low-power consumption microcomputer
ReRAM MCU
TQFP064-P-1010D 80pins 14.0
x 14.0mm
TQFP080-P-1212F 80pins 14.0
x 14.0mm
MN101LR04/05
-
-
•Delivers both smaller area and small ROM code size as
8-bit microcomputer and high performance as 16-bit
microcomputer based on 16-bit microcomputer core
with alterable (3 or 4) stage pipeline.
Wireless Charging System ICs
ASSP
•It also delivers lower power consumption of the
system by intermittent operation.
Receiver
XBGA048-W-3232AML
AN32258A
4.4 - 19
5
•Panasonic’s wireless power solution uses a
transmitter control IC (NN32251A) for power
transmitter (battery charger) and a receiver control IC
(AN32258A) for power receiver (equipment), controlling
power transmission.
•The combination of NN32251A and AN32258A allows
the extension of high-power transmission of up to
10 W from the WPC 1.1 (Qi standard)-compliant 5 W
output.
Transmitter
HQFP64 Type
NN32251A
64
4.6 - 19.5
-
NOTES
65
NOTES
66
Panasonic Industrial Devices Sales Company of America
Two Riverfront Plaza, 7th Floor, Newark, NJ 07102
800-344-2112 | na.industrial.panasonic.com | [email protected]
Copyright © 2015 Panasonic Corporation of North America. | All Rights Reserved. Specifications are subject to change without notice. | Line Card Catalog Rev 1, FY14-103-10000
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
