Flow Sensors

Book 2 (14.3)

eFL-1

w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Book 2 (14.3)

eFL-2

Flow Sensors

Prices as of April 15, 2015. Check Web site for most current prices.

Flow Switches, Transmitters and

Meters

High Performance Magmeter at a

Great Price

$

Starting at

460.

00

ProSense FMM Series Magmeters are designed to reliably detect the flow rate of conductive media up to 160 gallons per minute. The stainless steel, mechanically-robust design mounts directly in-line providing a compact, low-profile installation for process control.

A 4-digit numeric display with pushbutton setup simultaneously indicates flow rate, fluid temperature and total volume.

Simple to setup and easy to install, the ProSense FMM is a reliable alternative to traditional flow meters and mechanical flow switches.

These flow meters are the new benchmark for price and performance for your flow sensing applications.

Key features

• For water and water-based media

• Flow rates up to 160 gpm

• Pipe sizes up to 2”

• DC switching, pulse, frequency and analog outputs

• Monitor flow rate, total volume and temperature in one sensor

$

Starting at

125.

00

FSD and FSA Series Flow Switches and Transmitters

The FSA Series flow transmitters monitor liquid media and provide an analog output proportional to flow rate for various flow applications. The FSA series flow transmitter sensing principle is based on differential pressure which ensures extremely fast response time and allows for a precise flow measurement.

The ProSense FSD Series flow switch sensor utilizes a springsupported piston that is lifted by the flowing medium. The piston position is detected via an inductive sensor and is output as a digital signal. The spring resets the piston to its initial position with decreasing flow.

Key features

• Ideal for applications such as machine tool coolant flow,

HVAC water flow, and injection molding cooling water flow

• Immune to rapid temperature changes of media

• Fast response time

• Flow rates up to 27 gpm

• Pipe sizes up to 1”

• Integrated check valve design allows the sensor to be

mounted horizontally or vertically

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series Magnetic-Inductive

Flow Meters

Company

Information

Drives

Soft Starters

Motors

Magnetic-Inductive Flow Meter Application

Magnetic-inductive flow meters meter not functioning at all. Additionally,

(Magmeters) are one of the most widely used technologies for liquid flow monitoring in industrial process markets such as wastewater, mining and minerals, utilities, food and beverage, the presences of air bubbles should be avoided as they will affect the accuracy of the meter’s measurements.

Installation location in the piping is important because disturbances in the and pharmaceuticals. To ensure reliable and accurate operation, some important application requirements should be considered. Meeting the minimum conductivity of the liquid and properly installing with a full pipe are required in order to avoid significant error or the flow caused by bends in the pipe, valves, reductions, etc. can cause inaccuracies.

Refer to the magmeter’s specifications and operating instruction documents for specific information regarding application and installation requirements.

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Magnetic-Inductive Flow Meter Measuring Principle

Magmeters operate by using the magnetic-inductive measuring principle in which a magnetic field is generated in the specified measuring pipe by current-carrying coils.

When the media flows through the pipe, the ions of the conductive media are diverted perpendicularly to the magnetic field with the positive and negative charge carriers flowing in opposite directions. The two electrodes that are in contact with the medium then measure the voltage that is induced. The measured signal voltage is proportional to the average flow velocity. By knowing the inside pipe diameter of the unit, the volumetric flow rate is determined. Magmeters are suitable for use with a variety of conductive liquids in industrial process applications such as those in the following graph:

Sensors:

Pressure

Sensors:

Temperature

Model

FMM50-1001

FMM50-1002

FMM75-1002

Price

$460.00

FMM75-1001

$499.00

FMM100-1001

$550.00

ProSense FMM Series Magnetic Flow Meter Selection Guide

Process

Connection

Flow Range

Temperature

Range

Display

Units

Output 1

1/2” FNPT 0 to 6.6 GPM

3/4” FNPT 0 to 13.2 GPM

Switch or pulse

(flow)

1” FNPT 0 to 26.4 GPM

GPM, GPH,

GAL, or °F

FMM150-1001

$825.00

1-1/2” FNPT

FMM200-1001

$890.00

$460.00

$499.00

2” FNPT

1/2” FNPT

3/4” FNPT

0 to 80 GPM

0 to 160 GPM

0 to 6.6 GPM

0 to 13.2 GPM

-4 to 176°F

[-20 to 80°C]

Switch, pulse or frequency

(flow)

FMM100-1002

$550.00

1” FNPT

FMM150-1002

$825.00

1-1/2” FNPT

0 to 26.4 GPM

0 to 79.3 GPM

GPM, GPH,

LPM, m³/h,

°F, °C

4-20 mA

(temperature)

FMM200-1002

$890.00

2” FNPT 0 to 158.5 GPM

Output 2

reset input (flow or temperature)

4-20 mA

(flow)

Empty Pipe

Detection

No

Yes

No

Yes w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-3

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

Part No.FMM75-1001

Part No. FMM200-1001

Overview

AutomationDirect’s ProSense FMM Series (-1001) Magmeter is designed to reliably detect the flow rate of conductive media up to 160 gallons per minute. The stainless steel, mechanically-robust design mounts directly in-line providing a compact, low-profile installation for process control. A 4-digit numeric display with pushbutton setup indicates flow rate, fluid temperature and total flow volume with selectable engineering units. Two outputs are available to remotely monitor the binary or analog status of flow rate/volume and temperature parameters. Simple to setup, easy to install and with no moving parts, the FMM is a reliable alternative to traditional flow meters and mechanical flow switches.

Features

• 1/2 to 2” NPT female process connections

• Measure up to 160 GPM

• Measure fluid temperature in addition to flow and volume

• 4-digit numeric display with pushbutton setup

• Selectable engineering units: GPM, GPH, GAL, °F, °C

• Two outputs selectable for switch, pulse, frequency or analog signals

• 4-pin M12 quick disconnect

• 5-year warranty

#E320431

Output Function Selections

Output 1:

Flow rate switch

Volumetric flow totalizer pulse

Volumetric flow totalizer preset switch

Flow rate frequency (1-1/2 and 2 inch models only)

Empty pipe detection switch (1-1/2 and 2 inch models only)

Output 2:

Flow rate switch

Temperature switch

Analog flow rate

Analog temperature

Volumetric flow totalizer reset input

Empty pipe detection switch (1-1/2 and 2 inch models only)

ProSense FMM Series (-1001) Magnetic Flow Meters

FMM50-1001 FMM75-1001 FMM100-1001 FMM150-1001

$460.00

$499.00

$550.00

$825.00

FMM200-1001

$890.00

Model

Price

Weight

Range

Process Connection

Application

Pressure Rating

Medium Temperature

Operating Voltage

Current Consumption

Insulation Resistance

Protection Class

Reverse Polarity

Protection

Output Type / Function

1.09 lb

0 to 6.6 GPM

1/2” FNPT

1.18 lb

0 to 13.2 GPM

3/4” FNPT

Conductive liquids: ≥ 20 µS/cm (micro Siemens per centimeter) liquids / viscosity: < 70cSt (centiStoke) at 104°F

19 to 30VDC

< 120mA

1.30 lb

0 to 26.4 GPM

1” FNPT

232PSIG [16bar]

14 to 158°F [-10 to 70°C]

> 100MΩ (500VDC)

III

YES

6.74 lb

0 to 80.0 GPM

1-1/2” FNPT

18 to 32VDC

< 150mA

6.75 lb

0 to 160.0 GPM

2” FNPT

Output Functions

OUT1: switch (N.O. or N.C. / PNP or NPN) / flow rate, volumetric flow totalizer preset, empty pipe detection (1-1/2 and 2”) or pulse / volumetric flow totalizer or frequency / flow rate (1-1/2 and 2”)

Switch/Pulse/

Frequency Outputs

Analog Output

Book 2 (14.3)

eFL-4

Flow Sensors

PNP / NPN Selectable

N.O. / N.C. Selectable

Current Rating: 2 x 200mA

Voltage Drop: < 2V

Short-circuit protection: Yes (non-latching)

Overload protection: Yes

Switch hysteresis or window function

4-20 mA max 22mA or 0-10 VDC selectable

Max. load: 500Ω (4-20 mA)

Min. load: 2000Ω (0-10 VDC)

PNP / NPN Selectable

N.O. / N.C. Selectable

Current Rating: 2 x 250mA

Voltage Drop: < 2V

Short-circuit protection: Yes (non-latching)

Overload protection: Yes

Switch hysteresis or window function

0.1 to 10000 Hz frequency

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Model

Measuring Range

Display Range

Resolution

Set Point, SP

Reset Point, rP

Analog Start Point,

ASP

Analog End Point,

AEP

In Steps Of

Pulse Value

Pulse Length

Measuring Range

Resolution

Set Point, SP

Reset Point, rP

Analog Start Point,

ASP

Analog End Point,

AEP

In Steps Of

Flow Monitoring

Accuracy*

Repeatability*

Temperature Monitoring

Accuracy

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

FMM50-1001

ProSense FMM Series (-1001) Magnetic Flow Meters

FMM75-1001 FMM100-1001

Flow Rate Monitoring

FMM150-1001

0.030 to 6.604 GPM 0.060 to 13.200 GPM 0.100 to 26.400 GPM 1.300 to 80.000 GPM

-7.925 to 7.925 GPM

0.010 GPM

0.060 to 6.600 GPM

0.300 to 6.570 GPM

-15.840 to 15.840 GPM

0.020 GPM

0.120 to 13.200 GPM

0.060 to 13.140 GPM

-31.700 to 31.700 GPM

0.050 GPM

0.250 to 26.400 GPM

0.100 to 26.250 GPM

-96.000 to 96.000 GPM

0.100 GPM

1.700 to 80.000 GPM

1.300 to 79.600 GPM

0.000 to 5.300 GPM 0.000 to 10.600 GPM 0.000 to 21.200 GPM 0.000 to 64.000 GPM

FMM200-1001

1.300 to 160.000 GPM

-190.000 to 190.000 GPM

0.100 GPM

2.100 to 160.000 GPM

1.300 to 159.200 GPM

0.000 to 128.000 GPM

Company

Information

Drives

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

1.300 to 6.600 GPM

0.010 GPM

0.010 to 30,300,000 GAL

0.010 to 2s

0.1°F

2.600 to 13.200 GPM 5.200 to 26.400 GPM 16.000 to 80.000 GPM 32.000 to 160.000 GPM

0.020 GPM 0.050 GPM

Volumetric Flow Totalizer

0.010 to 99,990,000 GAL 0.010 to 100,000,000 GAL

0.005 to 2s 0.0025 to 2s

Temperature Monitoring

-4 to 176°F [-20 to 80°C]**

0.5°F

0.100 GPM

0.020 to 80,000,000 GAL

0.016 to 2s

0.020 to 160,000,000 GAL

0.008 to 2s

-2.5 to 176°F

-3.5 to 175.0°F

-4.0 to 140.5°F

-2.0 to 176°F

-3.0 to 175°F

-4.0 to 140°F

31.5 to 176.0°F

32.0 to 176°F

0.5°F

Accuracy / Deviations

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

± (2% MW + 0.5% VMR)

± 0.2% VMR

± 4.5°K (Q > 0.26 GPM)

Reaction Times

± (0.8% MW + 0.5% VMR)

± 1°K (Q > 4.0 GPM)

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Power-On Delay

Time

Flow Monitoring

Start-Up Delay

Response Time

Display Damping, dAP

Temperature Monitoring

Response Time

N/A

< 0.150s (dAP = 0)

5s

0.0 to 5.0s

0 to 50s

< 0.350s (dAP = 0)

Pneumatics:

Directional Control

Valves

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

T09 = 3s (Q > 4.0 GPM)

Environment

14 to 140°F [-10 to 60°C]

Appendix

Book 2

Ambient

Temperature

Storage

Temperature

Protection

* MW = Measured value

VMR = Final value of the measuring range

** Displays °F only

IP 67

-13 to 176°F [-25 to 80°C]

IP 65, IP 67

Terms and

Conditions w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-5

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

Model

Process Connection

Materials

(wetted parts)

Housing Materials

FMM50-1001

ProSense FMM Series (-1001) Magnetic Flow Meters

FMM75-1001 FMM100-1001

Mechanical Data

FMM150-1001

1/2” NPT female 3/4” NPT female 1” NPT female

Stainless steel 316L / 1.4404; PEEK (polyether ether ketone); FKM

FMM200-1001

1-1/2” NPT female 2” NPT female

Stainless steel 316L / 1.4404; stainless steel 316Ti / 1.4571; PEEK (polyether ether ketone); Hastelloy C-4 (2.4610); Cetellen: FKM

Stainless steel 316L / 1.4404; PBT-GF 20; PC; EPDM/X

Displays / Operating Elements

Stainless steel 316L / 1.4404; stainless steel 316Ti / 1.4571; PEI; FKM;

PBT-GF 20; elastolan

Display

Display unit: 6 x LED green (GPM, GPH, GAL, °F, 10³, 10

6

)

Switching Status: 2 x LED yellow

Measured values: 4-digit alphanumeric display (7.5 mm)

Programming: 4-digit alphanumeric display (7.5 mm)

Display unit: 6 x LED green (GPM, GPH, GAL, °F, 10³, 10

6

)

Switching Status: 2 x LED yellow

Measured values: 4-digit alphanumeric display (7.5 mm)

Programming: 4-digit alphanumeric display (7.5 mm)

Electrical Connection

Connection

M12 connector; gold-plated contacts

EMC

Tests / Approvals

EN 61000-4-2: 4kV CD / 8kV AD

EN 61000-4-3 HF radiated: 10 V/m

EN 61000-4-4 Burst: 2kV

EN 61000-4-5 Surge: 0.5 kV

EN61000-4-6 HF conducted: 10V

DIN IEC 68-2-27: 20g (11ms)

Shock Resistance

Vibration Resistance

DIN IEC 68-2-6: 5g (10 to 2,000Hz)

Approvals*

UL (E320431), CE, RoHS

* To obtain the most current agency approval information, see the Agency Approval Checklist section on the specific part number’s web page at www.automationdirect.com

N ote

: C heCk the ChemiCal Compatibility of the seNsor

’ s wetted parts with the medium to be measured

.

Wiring Diagram

Cable Assembly Wiring Colors:

Pin 1 - Brown

Pin 2 - White

Pin 3 - Blue

Pin 4 - Black

Colors to DIN EN 60947-5-2

For additional wiring details see individual product manuals.

Use FMM-GND1 if meter is installed in ungrounded pipe system.

Note: Wiring colors are based on

AutomationDirect CD12L and CD12M

4-pole cable assemblies.

Book 2 (14.3)

eFL-6

Flow Sensors

Output Function Selections

Models:

FMM50-1001, FMM75-1001, FMM100-1001

Models:

FMM150-1001, FMM200-1001

Output 1:

Flow rate switch

Volumetric flow totalizer pulse

Volumetric flow totalizer preset switch

Output 2:

Flow rate switch

Temperature switch

Analog flow rate

Analog temperature

Volumetric flow totalizer reset input

Output 1:

Flow rate switch

Volumetric flow totalizer pulse

Volumetric flow totalizer preset switch

Flow rate frequency

Empty pipe detection switch

Output 2:

Flow rate switch

Temperature switch

Analog flow rate

Analog temperature

Volumetric flow totalizer reset input

Empty pipe detection switch

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

Pressure Loss/Flow Rate*

Company

Information

Drives

Soft Starters

Motors

Power

Transmission

* when used with water @ 68˚F [20˚C]

Dimensions

mm [inches]

Part No. FMM50-1001

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

See our website www.AutomationDirect.com for complete Engineering drawings.

Flow Sensors

Book 2 (14.3)

eFL-7

Dimensions

mm [inches]

Part No. FMM75-1001

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

Part No. FMM100-1001

Part No. FMM150-1001

Book 2 (14.3)

eFL-8

Flow Sensors

See our website www.AutomationDirect.com for complete Engineering drawings.

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Dimensions

mm [inches]

Part No. FMM200-1001

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1001) Magnetic-

Inductive Flow Meters

Company

Information

Drives

Soft Starters

See our website www.AutomationDirect.com for complete Engineering drawings.

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-9

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1002) Magnetic-

Inductive Flow Meters

Part No.FMM75-1002

Part No. FMM200-1002

Overview

AutomationDirect’s ProSense FMM Series (-1002) Magmeters are designed to reliably detect the flow rate of conductive media up to 158.5 gallons per minute. The stainless steel, mechanically-robust design mounts directly in-line providing a compact, low-profile installation for process control. A 4-digit numeric display with pushbutton setup indicates flow rate and fluid temperature with selectable engineering units. Two outputs are available to remotely monitor the analog status of flow rate and temperature parameters. Simple to set up, easy to install and with no moving parts, the FMM series is a reliable alternative to traditional flow meters and mechanical flow switches.

Features

• 1/2 to 2” NPT female process connections

• Measure up to 158.5 GPM

• Measure fluid temperature in addition to flow

#E320431

• 4-digit numeric display with pushbutton setup

• Selectable engineering units: GPM, GPH, LPM, m³/h, °F, °C

• Two analog output signals

• 4-pin M12 quick disconnect

• 5-year warranty

Output Function Selections

Output 1:

Analog temperature

Output 2:

Analog flow rate

Model

Price

Weight

Range

Process Connection

Application

Pressure Rating

Medium

Temperature

Operating Voltage

Current Consumption

Insulation

Resistance

Protection Class

Reverse Polarity

Protection

Output Type /

Function

Analog Output

Measuring Range

Display Range

Resolution

Analog Start Point,

ASP

Analog End Point,

AEP

In Steps Of

Book 2 (14.3)

eFL-10

Flow Sensors

FMM50-1002

$460.00

ProSense FMM Series (-1002) Magnetic Flow Meters

FMM75-1002

$499.00

FMM100-1002

$550.00

FMM150-1002

$825.00

FMM200-1002

$890.00

1.14 lb

0 to 6.6 GPM

1/2” FNPT

1.23 lb

0 to 13.2 GPM

3/4” FNPT

1.36 lb

0 to 26.4 GPM

1” FNPT

6.76 lb

0 to 79.3 GPM

1-1/2” FNPT

Conductive liquids: ≥ 20 µS/cm (micro Siemens per centimeter) liquids / viscosity: < 70cSt (centiStoke) at 104°F

232PSIG [16bar]

6.76 lb

0 to 158.5 GPM

2” FNPT

0.030 to 6.600 GPM

-7.920 to 7.920 GPM

0.010 GPM

0.000 to 5.280 GPM

14 to 158°F [-10 to 70°C]

20 to 30VDC

120mA

> 100MΩ (500VDC)

III

YES

Output Functions

OUT1: analog signal / temperature

OUT2: analog signal / flow

4-20 mA max 22mA

Max. load: 500Ω (4-20 mA)

Overload protection: Yes

Flow Rate Monitoring

0.020 to 13.200 GPM 0.100 to 26.400 GPM

-15.860 to 15.860 GPM

0.020 GPM

0.000 to 10.580 GPM

-31.700 to 31.700 GPM

0.050 GPM

0.000 to 21.100 GPM

18 to 32VDC

< 150mA

1.300 to 79.300 GPM 1.300 to 158.500 GPM

-95.100 to 95.100 GPM -190.200 to 190.200 GPM

0.100 GPM

0.000 to 63.400 GPM

0.100 GPM

0.000 to 126.800 GPM

2.640 to 13.220 GPM 5.300 to 26.400 GPM 15.900 to 79.300 GPM 31.700 to 158.500 GPM

1.320 to 6.600 GPM

0.010 GPM 0.020 GPM 0.050 GPM 0.100 GPM 0.100 GPM

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Model

Measuring Range

Resolution

Analog Start Point, ASP

Analog End Point, AEP

In Steps Of

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1002) Magnetic-

Inductive Flow Meters

ProSense FMM Series (-1002) Magnetic Flow Meters

FMM50-1002 FMM75-1002 FMM100-1002 FMM150-1002 FMM200-1002

Temperature Monitoring

-4 to 176°F [-20 to 80°C]

0.5°F [0.2°C]

-4.0 to 140°F [-20 to 60°C]

32 to 176.0°F [0.0 to 80°C]

0.5°F [0.28°C]

Accuracy / Deviations

Flow Monitoring

Accuracy¹

Repeatability¹

Temperature Monitoring

Accuracy

± (2% MW + 0.5% VMR)

± 0.2% VMR

± (0.8% MW + 0.5% VMR)

± 2.5°K (Q > 0.26 GPM)

Reaction Times

± 1°K (Q > 4.00 GPM)

Power-On Delay Time

Flow Monitoring

Response Time

Display Damping, dAP

Temperature Monitoring

Response Time

< 0.150s (dAP = 0)

0.0 to 3.0s

5s

< 0.350s (dAP = 0)

0.0 to 5.0s

Ambient Temperature

Storage Temperature

Protection

Process Connection

Materials (wetted parts)

1/2” NPT female

T09 = 3s (Q > 4.00 GPM)

Environment

14 to 140°F [-10 to 60°C]

-13 to 176°F [-25 to 80°F]

IP 67

Mechanical Data

3/4” NPT female 1” NPT female

Stainless steel 316L / 1.4404; PEEK (polyether ether ketone); FKM

1-1/2” NPT female

IP 65, IP 67

2” NPT female

Stainless steel 316L / 1.4404; stainless steel 316Ti / 1.4571; PEEK (polyether ether ketone); Hastelloy C-4 (2.4610); Cetellen: FKM

Company

Information

Drives

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Housing Materials

Display

Stainless steel 316L / 1.4404; PBT-GF 20; PC; EPDM/X

Displays / Operating Elements

Display unit: 6 x LED green (l/min, m³/h, GPM, GPH, °C, °F)

Measured values: 4-digit alphanumeric display (7.5 mm)

Programming: 4-digit alphanumeric display (7.5 mm)

Display unit: 6 x LED green (l/min, m³/h, GPM, GPH, °C, °F)

Function display: 1 x LED yellow (10³)

Measured values: 4-digit alphanumeric display (7.5 mm)

Programming: 4-digit alphanumeric display (7.5 mm

Electrical Connection

Connection

M12 connector; gold-plated contacts

EMC

Tests / Approvals

EN 61000-4-2: 4kV CD / 8kV AD

EN 61000-4-3 HF radiated: 10 V/m

EN 61000-4-4 Burst: 2kV

EN 61000-4-5 Surge: 0.5 kV

EN 61000-4-6 HF conducted: 10V

Shock Resistance

Vibration Resistance

DIN IEC 68-2-27: 20g (11ms)

DIN IEC 68-2-6: 5g (10 to 2,000Hz)

Approvals*

UL (E320431), CE, RoHS

* To obtain the most current agency approval information, see the Agency Approval Checklist section on the specific part number’s web page at www.automationdirect.com

¹ MW = Measured value; VMR = Final value of the measuring range

N ote

: C heCk the ChemiCal Compatibility of the seNsor

’ s wetted parts with the medium to be measured

.

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-11

Wiring Diagram

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1002) Magnetic-

Inductive Flow Meters

Output Function Selections

Models:

FMM50-1002, FMM75-1002, FMM100-1002,

FMM150-1002, FMM200-1002

Output 1:

Analog temperature

Output 2:

Analog flow rate

Cable Assembly Wiring Colors:

Pin 1 - Brown

Pin 2 - White

Pin 3 - Blue

Pin 4 - Black

Colors to DIN EN 60947-5-2

For additional wiring details see individual product manuals.

Use FMM-GND1 if meter is installed in ungrounded pipe system.

Pressure Loss/Flow Rate*

Note: Wiring colors are based on

AutomationDirect CD12L and CD12M

4-pole cable assemblies.

* when used with water @ 68˚F [20˚C]

Book 2 (14.3)

eFL-12

Flow Sensors

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Dimensions

mm [inches]

Part No. FMM50-1002

Part No. FMM75-1002

Part No. FMM100-1002

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1002) Magnetic-

Inductive Flow Meters

Company

Information

Drives

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

See our website www.AutomationDirect.com for complete Engineering drawings.

Flow Sensors

Book 2 (14.3)

eFL-13

Dimensions

mm [inches]

Part No. FMM150-1002

Prices as of April 15, 2015. Check Web site for most current prices.

FMM Series (-1002) Magnetic-

Inductive Flow Meters

Part No. FMM200-1002

Book 2 (14.3)

eFL-14

Flow Sensors

See our website www.AutomationDirect.com for complete Engineering drawings.

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Part No.

FMM-GND1

Dimensions

mm [inches]

Part No. FMM-GND1

Prices as of April 15, 2015. Check Web site for most current prices.

Magnetic-Inductive Flow Meter

Accessories

The FMM-GND1 Grounding Clamp is used when an FMM series Magnetic-Inductive Flow

Meter is installed in an ungrounded pipe system (e.g. PVC pipe).

Simply place the FMM-GND1 Grounding Clamp around the base of the M12 connector and attach a grounded wire to FMM-GND1 Grounding Clamp with the supplied machine screw and nut.

Note: Improper grounding may cause inaccurate readings

Company

Information

Drives

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

ProSense Magnetic Flow Meter Accessories

Description Price

ProSense 316 stainless steel grounding clamp for magnetic flow meters with an M12 connector.

$6.00

Weight

0.015 lb

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

See our website www.AutomationDirect.com for complete Engineering drawings.

Grounding Clamp Installation

The ProSense magnetic flow meter grounding clamp is installed as shown above.

Note: the ground wire shown above is not included.

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-15

Prices as of April 15, 2015. Check Web site for most current prices.

FSD Series Flow Switches

The ProSense FSD Series flow switches are ideal for applications with rapid temperature changes or where fast response time is required, such as:

• Machine tool coolant flow

• HVAC cooling water flow

• Injection molding cooling water flow

Part No. FSD75-AP-6H Part No. FSD1-AP-26H

Overview

The ProSense FSD Series flow switches monitor liquid media and provide reliable flow detection for various flow applications.

The ProSense FSD Series sensing principle ensures extremely fast response time and allows for a more precise setpoint setting. The setpoint can be easily set and locked with a setting screw.

Features

• Monitor 0.26 to 26.4 GPM (gallons per minute) in 2 models

• Immune to rapid temperature changes of media

• Fast response time of 10ms: great for cycling applications with a minimum of 10 million switching cycles

• Easy to set: turn dial to desired setpoint

• Able to be bench set outside the process

• 3/4” or 1” FNPT process connections

• Integrated check valve design allows the sensor to be mounted horizontally or vertically

• 4-pin M12 quick‐disconnect

• IP65 / IP67

• LED output status indication

• 2-year warranty

#E320431

Part No.

FSD75-AP-6H

FSD1-AP-26H

ProSense FSD Series Flow Switches

Description

24VDC, 0.26 to 6.6 GPM setpoint range, rotating dial adjustment with lock screw, 26.4 GPM max flow rate, nickel-plated brass housing with 3/4 in. FNPT process connections, N.O. DC PNP output. Cable sold separately.

24VDC, 1.32 to 26.4 GPM setpoint range, rotating dial adjustment with lock screw, 52.8 GPM max flow rate, nickel-plated brass housing with 1 in. FNPT process connections, N.O. DC PNP output. Cable sold separately.

Quantity Weight (lbs) Price

1 1.0

$125.00

1 1.6

$150.00

Model

Operating Voltage

Electrical Connection

Connection Pin Material

Output Function

Output Maximum Load Current

Current Consumption

Voltage Drop

Short-Circuit Protection

Reverse Polarity Protection

Overload Protection

Switching Cycles Minimum

Response Time

Accuracy*

Repeatability

Process Connection

Medium

Maximum Flow Rate

Setpoint Range

Hysteresis

Pressure Rating

* when used with water

ProSense FSD Series Flow Switches Technical Specifications

FSD75-AP-6H FSD1-AP-26H

20.4 to 26.4 VDC (must use a Class 2 power supply in order to comply with UL508 requirements)

0.06 GPM

3/4” FNPT

M12 (note: tightening torque < 0.6 Nm based on cable)

Gold-plated

Normally open (PNP)

100mA

< 15mA

< 2.5 VDC

YES

YES

YES

10 million

10ms

± 5% of full range

0.26 GPM

1” FNPT liquids (water, glycol solutions, oils)

< 26.4 GPM

0.26 – 6.6 GPM

0.13 – 0.53 GPM

< 52.8 GPM

1.32 – 26.4 GPM

0.8 – 1.58 GPM

362PSI

Book 2 (14.3)

eFL-16

Flow Sensors

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Prices as of April 15, 2015. Check Web site for most current prices.

FSD Series Flow Switches

Company

Information

Drives

Model

Housing Material

Materials (wetted parts)

ProSense FSD Series Flow Switches Environmental Specifications

FSD75-AP-6H FSD1-AP-26H

brass chemically nickel‐plated; aluminum anodized; POM

Operating Temperature

Medium Temperature

Storage Temperature

Protection

Protection Class

Agency Approvals

32 to 140°F (0 to 60°C)

32 to 185°F (0 to 85°C)

–40 to 212°F (–40 to 100°C)

IP65 / IP67

III cULus (#E320431), CE, RoHs

N ote

: C heCk the ChemiCal Compatibility of the seNsor

’ s wetted parts with the medium to be mesured

.

Wiring Diagrams

LED Functions

The FSD units monitor the flow of liquid media such as: water, glycol solutions, and oils. The LED functions are as follows:

• Output closed (LED = ON), if volumetric flow quantity

M setpoint.

• Output open (LED = OFF), if volumetric flow quantity l setpoint.

Installation*:

For proper flow switch operation, the sensor should be installed as indicated in the Illustrations below

(noting the flow direction arrow on the body of the sensor):

IN

1

4

3

L+

L

Cable Assembly Wiring Colors:

Pin 1 - Brown

Pin 2 - White

Pin 3 - Blue

Pin 4 - Black

Note: Wiring colors are based on

AutomationDirect CD12L and CD12M

4-pole cable assemblies.

OUT

Sensors:

Level

Sensors:

Flow

There are 4 LEDs (one on each side) on the top connector for easy visibility regardless of installation orientation.

Pushbuttons and Lights

Stacklights

Signal

Devices

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Horizontal Mounting

* Integral check valve design allows the sensor to be mounted in any position

(horizontally or vertically).

Vertical Mounting

w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-17

Prices as of April 15, 2015. Check Web site for most current prices.

FSD Series Flow Switches

Pressure Loss/Flow Rate*

FSD75-AP-6H FSD1-AP-26H

Pressure loss (dP) / flow rate (Q) psi

10.15

8.70

7.25

5.80

4.35

2.90

1.45

* when used with water

Dimensions

mm [inches]

Part No. FSD75-AP-6H

Book 2 (14.3)

eFL-18

Flow Sensors

Part No. FSD1-AP-26H

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Operation & Setting

Prices as of April 15, 2015. Check Web site for most current prices.

FSD Series Flow Switches

Company

Information

Drives

Soft Starters

Motors

The flow sensor utilizes a spring-supported piston that is lifted by the flowing medium. The piston position is detected via an inductive sensor and is output as a binary signal. The spring resets the piston to its initial position with decreasing flow. This allows the sensor to be mounted in any position (horizontally or vertically) and function as a check valve.

Power

Transmission

Motion: Servos and Steppers

Switch Setpoint

Hysteresis

Output Status

Note: Hysteresis varies based on switch setpoint.

Cutaway View

Setting FSD Series flow switches is quick and easy. There are two ways to set the flow switches - using a desired flow value and adjustment to existing flow.

Setting the ProSense FSD using a desired flow value

1. Loosen the locking screw.

2. Set the switching point by rotating the Setpoint dial until the desired flow value just becomes visible on the setting scale.

3. Tighten the locking screw.

Example in Figure 1: desired value = 2 GPM

0

GP

M

1

Setpoint dial

Locking screw

Setting scale

Adjustment to existing flow

1. Let the normal flow circulate in the installation.

2. Loosen the locking screw.

3. Set the switching point by rotating the Setpoint dial.

• If the LED lights before setting: turn the Setpoint dial in the direction [+] until the LED goes out. Then turn in the opposite direction [-] until the LED lights.

• If the LED does not light before setting: turn the Setpoint dial in the direction [-] until the LED lights.

4. Tighten the locking screw.

Correlation between the number of turns of the Setpoint dial and the switching point is that one complete turn of the Setpoint dial corresponds to an approximate gallons per minute rate. This is shown in the table below:

Part Number

FSD75-AP-6H

FSD1-AP-26H

Gallons/Minute

0.8 GPM

3.3 GPM

Max. Gallons/Minute*

6.6 GPM

26.4 GPM

* d o Not turN the settiNg sCrew beyoNd the maximum value of the settiNg raNge to avoid faulty switChiNg

.

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-19

Prices as of April 15, 2015. Check Web site for most current prices.

FSA Series Flow Transmitters

Part No. FSA75-42-6H

Part No. FSA1-42-27H

The ProSense FSA Series flow transmitters are ideal for applications with rapid temperature changes or where fast response time is required, such as:

• Machine tool coolant flow

• HVAC cooling water flow

• Injection molding cooling water flow

Overview

Part No. FSA75-42-10H

The ProSense FSA Series flow transmitters monitor liquid media and provide an analog output proportional to flow rate for various flow applications.

Features

• Measure up to 27GPM (gallons per minute) in 3 models

• Immune to rapid temperature changes of media

• Fast response time of <10ms

• 3/4” or 1” FNPT process connections

• Integrated check valve design allows the sensor to be mounted horizontally or vertically

• 4-pin M12 quick‐disconnect

• IP65 / IP67

• 2-year warranty

The ProSense FSA Series sensing principle is based on differential pressure which ensures extremely fast response time and allows for a precise flow measurement. The ProSense flow transmitters are available in three flow ranges up to

27GPM.

Part No.

FSA75-42-6H

FSA75-42-10H

FSA1-42-27H

ProSense FSA Series Flow Transmitters

Description

ProSense liquid flow transmitter, 0 to 6 GPM measuring range, 3/4 inch female NPT process connection,

4-20 mA analog output, 18 to 32 VDC operating voltage, 4-pin M12 quick-disconnect electrical connection.

Purchase cable separately.

ProSense liquid flow transmitter, 0 to 10 GPM measuring range, 3/4 inch female NPT process connection,

4-20 mA analog output, 18 to 32 VDC operating voltage, 4-pin M12 quick-disconnect electrical connection.

Purchase cable separately.

ProSense liquid flow transmitter, 0 to 27 GPM measuring range, 1 inch female NPT process connection,

4-20 mA analog output, 18 to 32 VDC operating voltage, 4-pin M12 quick-disconnect electrical connection.

Purchase cable separately.

Quantity Weight (lbs) Price

1

1

1

1.0

1.0

1.5

$140.00

$140.00

$165.00

Model

Operating Voltage

Electrical Connection

Connection Pin Material

Output Function

Analog Output

Maximum Load

Current Consumption

Short-Circuit Protection

Reverse Polarity Protection

Overload Protection

Cycles

Response Time

Accuracy*

Repeatability*

Process Connection

Medium

Maximum Flow Rate

Maximum Viscosity

Flow Measuring Range

Pressure Rating

* When used with water @ 20˚C [68˚F]

ProSense FSA Series Flow Transmitters Technical Specifications

FSA75-42-6H FSA75-42-10H

0 - 6 GPM

M12 (note: tightening torque <0.6 Nm based on cable)

3/4” FNPT

Liquids (water, glycol solutions, oils), use of 200 micron filter recommended

26.4 GPM

18 to 32 VDC (SELV/PELV)**

Gold-plated

Analog

4-20 mA (sourcing)

500Ω

<35mA

YES

YES

YES

10 million minimum

<10ms

± 5% of full range

± 1% of full range

<68 centistokes

0 - 10 GPM

362 psig max operating / 724 psig proof pressure

FSA1-42-27H

1” FNPT

52.8 GPM

0 - 27 GPM

** Voltage Supply According to EN50178 SELV (Safety Extra-Low Voltage) / PELV (Protected Extra-Low Voltage)

Book 2 (14.3)

eFL-20

Flow Sensors

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Model

Housing Material

Materials (wetted parts)

Operating Temperature

Medium Temperature

Storage Temperature

Protection

Protection Class

Agency Approvals

ProSense FSA Series Flow Transmitters Environmental Specifications

FSA75-42-6H FSA75-42-10H FSA1-42-27H

Brass chemically nickel‐plated; PP (Polypropylene); stainless steel (316L / 1.4404); aluminum anodized; PA (Polyamide)

Stainless steel (316 / 1.4401); brass chemically nickel‐plated; PP (Polypropylene); PPS (Polyphenylene sulfide);

O-ring:FKM (Viton)

32 to 140°F (0 to 60°C)

14 to 212°F (-10 to 100°C)

5 to 176°F (–15 to 80°C)

IP65 / IP67

III cULus (#E320431), CE, RoHs

N ote

: C heCk the ChemiCal Compatibility of the seNsor

’ s wetted parts with the medium to be measured

.

Wiring Diagrams

Installation*:

For proper operation, please observe the flow direction arrows on the body of the sensor. The mounting orientation does not effect the operation of the unit.

IN

Prices as of April 15, 2015. Check Web site for most current prices.

FSA Series Flow Transmitters

Company

Information

Drives

1

2

3

L+

L

Cable Assembly Wiring Colors:

Pin 1 - Brown

Pin 2 - White

Pin 3 - Blue

Pin 4 - Black

Note: Wiring colors are based on

AutomationDirect CD12L and CD12M

4-pole cable assemblies.

OUT

Horizontal Mounting

* Integral check valve design allows the sensor to be mounted in any position.

Vertical Mounting

1. Ferromagnetic materials in the surrounding environment should be at least 50mm from the housing of the unit.

2. Ferromagnetic piping may be used on the inlet and outlet connections.

3. Do not operate the unit in the vicinity of magnetic constant and alternating fields (e.g. welding systems).

4. If the sensors are installed side by side, observe a minimum distance of 50mm between the sensor axes.

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-21

Prices as of April 15, 2015. Check Web site for most current prices.

FSA Series Flow Transmitters

Pressure Loss/Flow Rate*

FSA75-42-6H

FSA75-42-10H

dP psig [bar]

4.4

3.6

2.9

2.2

1.5

0.7

0.0

0 1.3

2.6

3.9

5.3

* when used with water @ 20˚C [68˚F]

6.6

7.9

9.2

10.6 11.8 13.2 14.5

Q (GPM)

FSA1-42-27H

4.4

2.9

1.5

0.0

dP psig [bar]

7.3

5.8

0 5.3

10.6

15.8

21.1

26.4

Q (GPM)

Dimensions

mm [inches]

Part No. FSA75-42-6H

FSA75-42-10H

Book 2 (14.3)

eFL-22

Flow Sensors

Part No. FSA1-42-27H

1 - 8 0 0 - 6 3 3 - 0 4 0 5

Operation

The flow sensor utilizes a spring-supported piston that is lifted by the flowing medium. By monitoring the piston position the flow rate is determined on the principle of differential pressure and is converted into an analog output signal (4 to 20 mA). The spring resets the piston to its initial position with decreasing flow. This allows the sensor to be mounted in any position (horizontally or vertically) and function as a check valve.

Function

The analog signal for water (20ºC [68˚F]) is linear from 4.3 mA to

20mA (4mA = no flow). For an output signal >20mA the flow rate is above the final value of the measuring range.

Part Number

FSA75-42-6H

FSA75-42-10H

FSA1-42-27H

0.2

0

4

4.3

mA Output

Non Linear Output

Prices as of April 15, 2015. Check Web site for most current prices.

FSA Series Flow Transmitters

Company

Information

Drives

Flow Measuring Range

(Gallons/Minute)

0 to 6

0 to 10

0 to 27

Analog Output Charts

FSA75-42-6H GPM vs. Analog Output

6

20

10

FSA75-42-10H GPM vs. Analog Output

0.2

0

4

4.3

mA Output

Non Linear Output

20

Cutaway View

27

FSA1-42-27H GPM vs. Analog Output

0.5

0

4 4.3

mA Output

Non Linear Output

20

Soft Starters

Motors

Power

Transmission

Motion: Servos and Steppers

Motor Controls

Sensors:

Proximity

Sensors:

Photoelectric

Sensors:

Encoders

Sensors:

Limit Switches

Sensors:

Current

Sensors:

Pressure

Sensors:

Temperature

Pneumatics:

Cylinders

Pneumatics:

Tubing

Pneumatics:

Air Fittings

Appendix

Book 2

Terms and

Conditions

Sensors:

Level

Sensors:

Flow

Pushbuttons and Lights

Stacklights

Signal

Devices

Process

Relays and

Timers

Pneumatics:

Air Prep

Pneumatics:

Directional Control

Valves w w w . a u t o m a t i o n d i r e c t . c o m / f l o w - s e n s o r s

Flow Sensors

Book 2 (14.3)

eFL-23

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
