Internet Easy Connect Kit guide
Time Warner Cable Internet
Easy
Connect
Guide
for Modem Upgrades
Enjoy surfing at your own speed. Super fast.
Swap your modem for even faster access.
Experience smooth, fast Internet. Swapping your modem will bring you access to our best
Internet service yet, and this Easy Connect Guide will help you complete the transition. If
you have any questions during your connection process, visit us at twc.com/easyconnect for
more self-help information or call us at 1-877-309-5869. We will be happy to help and thank
you for choosing Time Warner Cable.
Included in your kit
G
EASY CONNECT
GUIDE
CABLE
MODEM
POWER
CORD
COAXIAL
CABLES (2)
ENHANCED ETHERNET
CABLE (CAT5E)
SPLITTER
RETURN
SHIPPING LABEL
Contents
Pages 2-3
Pages 4-5
Page 6-9
Page 10
Page 11
Home WiFi preparation
and setup
Connect modem
or wireless modem
Activate modem
for service
Modem indicator
guide
Troubleshooting
Home WiFi preparation
and setup
Step 1 Access your modem’s web interface
Type 192.168.0.1 into your browser window’s address bar.
You will be presented with a log in page.
Before connecting your modem, take a moment to
determine which pages of this instruction guide are
relevant to your needs. If you are not a TWC Home WiFi
subscriber, you will skip “Home WiFi setup” and begin on
page 4 at “Connect modem or wireless modem”. If you
are a TWC Home WiFi subscriber, you will need to begin
with the “Home WiFI preparation and setup” that follows.
Record your current Home WiFi Network Wireless Settings.
As a TWC Home WiFi subscriber, you may want to use the
same Network Name and Password settings for your new
modem. Although this process attempts to transfer your
existing settings automatically, please take a moment
to record them for your reference before beginning.
Refer to steps 1 through 3 to identify your existing
network name and password. After you have identified
your network name and password, please proceed to
page 4 to begin.
Step 2 Log in to the web interface
You will be prompted to enter a User Name and Password to
log in to the web interface.
Enter the User Name and Password you set up, or refer to
the chart that follows for your existing modem’s default User
Name and Password.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 2
Default User Names and Passwords for most modems.
Tip: You can find your modem model on the sticker located on
the back of your modem and at twc.com/wifisettings.
MODEM
DEFAULT
USER NAME
DEFAULT
PASSWORD
Arris 860A
Arris 862G
Arris DG1670/TG1672
Arris TG852
Arris TG862G
Motorola 6580
Technicolor TC8715/TC8717
Thomson DW875
Thomson DWG855
Thomson DWG875
Ubee DDW365
Ubee DDW3611
Ubee DVW3201B
Ubee U10C022
Ubee DDW36C/DDW32CB
admin
admin
admin
admin
admin
admin
admin
No user name required
No user name required
No user name required
user
user
user
user
admin
password
password
password
user
password
motorola
password
password
admin
password
user
user
user
user
Step 3 View existing settings for your modem
Once you have successfully logged into the web interface,
select the Wireless Tab to view your existing settings.
Your Network Name is located in the Network Name
(SSID) field.
Your Password is located in the WPA Pre-Shared Key field.
NETWORK NAME
*see bottom
of device
*A unique 12-digit password is located on the bottom of the device
PASSWORD
Note: The auto provisioning process attempts to transfer your existing wireless
settings automatically. In the event you are unable to access your wireless
settings following activation, attempt access using the default credentials in
the table above or reset the modem to its factory default settings.
To reset your modem to its factory default settings, locate the small pinhole
button on the back of the device. Using the end of a paper clip or something
similar in size and shape, press and hold for 10-15 seconds. Use the default user
name and password provided for your modem type in the list above to access
your computer’s wireless settings. All wireless devices will need to be updated
with any changes made to your network name or password in order to connect.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 3
Connect modem or
wireless modem ELECTRICAL OUTLET
Step 1 Disconnect existing modem
COMPUTER
From the back of your existing modem, disconnect the coaxial
cable and Ethernet cable (wireless modem users will not have
Ethernet cable connected). Unplug the modem from the
electrical outlet.
MODEM
ENHANCED
ETHERNET CABLE
(CAT5e)
Step 2 Connect your new modem
COMPUTER
MODEM
POWER CORD
IN
CABLE OUTLET
CABLE OUTLET
COAXIAL CABLE
ENHANCED
ETHERNET
CABLE (CAT5e)
IN
Before connecting your new modem to power, connect the
coaxial cable from the cable wall outlet to the IN port of your
new modem.
COAXIAL CABLE
Wired and wireless modems will follow the same steps
to complete the modem swap successfully. If you are
connecting a wireless modem, the Ethernet cable can
be disconnected once the activation step is complete.
Connect your computer to your new modem using the
Enhanced Ethernet cable (CAT5e) provided in your kit.
The Enhanced Ethernet cable (CAT5e) will ensure optimal
performance for 100Mbps or higher service tiers.
Please ensure both wired and wireless modems connect to
Ethernet to ensure a successful modem swap.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 4
Step 3 Connect modem to electrical outlet
Optional Connect modem to phone, if applicable
MODEM
TEL 1
MODEM
PHONE
ELECTRICAL OUTLET
POWER CORD
PHONE WIRE
NOTE: The power cord should not be plugged into an electrical outlet that can be
turned on/off with a light switch.
Plug one end of the power cord into the back of the modem
and the other end into an electrical outlet, or a surge
protector (not included).
PHONE
If everything is properly connected, the lights on the front
of the modem will flash while the connection is being
established.
TURN THE PAGE TO LEARN HOW TO ACTIVATE
YOUR MODEM.
If you are replacing a modem that will also provide your
TWC Home Phone service, please reconnect your TWC
Home Phone to your new modem now, as shown on the
right. If you are not a TWC Home Phone subscriber, you may
skip this step.
Ensure the “Tel1” light is on.
Remove the gray telephone wire from the back of the
existing modem and plug it into Line 1 (1/2) of your new
modem.
Pick up your home phone and listen for a dial tone.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 5
Activate modem for service
Step 2 Log in to continue
Now that you have successfully connected your new
modem, it will need to be activated to receive services.
Choose one of two convenient ways to activate your modem;
1. Activate your modem online by following the steps
detailed on pages 6 through 9 of this guide.
2. Activate your modem by phone at 1-877-309-5869 using
the 10 digit phone number on your account. Say “Activate”
when prompted by the automated phone system and it will
guide you through our simple activation process.
Step 1 Start the activation process
Please sign in with your TWC account information using one
of the two login options presented. Complete the required
fields and select ‘Continue’.
Step 3 Account authentication
Open a web browser on your computer. Type
activatemymodem.com into the address search bar
and click ‘Search’. The TWC Modem Activation Portal,
shown above, will appear.
For your protection, you will be asked to authenticate your
account access by completing one of the two screens
below. Your selection from step 2 will determine which of
the two screens appear. Complete the required fields then
select ‘Continue’. You may select ‘Cancel’ to return to the
previous screen.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 6
A Verify personal information
Step 4 Agree to terms of service
B Provide account information
Review and acknowledge the TWC terms of service. Select
‘Continue’ to proceed.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 7
Step 5 Review your information
Step 6 Return equipment acknowledgement
Review your modem’s information to ensure it is accurate.
You may want to record the information in case you need to
reference it later. Select ‘Continue’.
To return your modem:
1. Pack the equipment you are returning into the same box
that contained your new equipment.
2. Place the enclosed return shipping label over the original
shipping label.
3. Drop off the package at your nearest shipping location or
return the equipment to your local TWC Store.
Visit twc.com/stores to find a location near you.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 8
Step 7 Click close once activation is complete
B Your new modem and wireless settings
You’ve reached the final step in your activation process and
will see one of the two screens detailed below. Screen A will
be presented if you do not subscribe to TWC Home WiFi and
Screen B will be presented to those that are.
A Your new modem
Please review your modem details and wireless settings
information.
Take a moment to verify that your wireless devices (such
as tablets or smartphones) have wireless capability. Select
“Close” to close and exit the modem activation process. If
connectivity with all of your devices is unsuccessful, please
review the Home WiFi setup steps on pages 2 and 3.
Please review the information provided and select “Close”
to close and exit the modem activation process.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 9
Modem indicator guide
Light
What Does It Mean?
Power
Steady green – the modem is on.
Online, Cable, Sync or Bloc Sync
Steady green – the modem is connected to the network.
Flashing – this happens during initial synchronization.
No light – this means no cable connection.
(Call 1-877-309-5869 and say “Internet Technical Support”
to speak with a representative.)
Test or Error
Normally off.
Flashing – this happens during initial self-test or
software downloading.
Steady light – indicates modem or network failure.
Data or Activity
Some modems have a separate light (RD or
RX) that indicates when modem is receiving
data, as well as a light (TD, TX or SD) that
indicates when modem is transmitting data.
Steady green – the computer connection is working.
No light – the computer is turned off or not connected.
PC or Link
Some modems don’t have this light or
an equivalent.
Flashing or blinking – data is flowing through the modem.
Power
Online
Test
Data
Link
Phone 1
Phone 2
Battery
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 10
Troubleshooting
Your cable modem should operate continuously without
maintenance. You may leave the modem on even when
you turn off your computer.
Self-help tool
Confirm the cable signal is active
If you have cable TV service, confirm that you are
receiving a signal and that the channels are clear.
Power cycle your modem
The TWC Self-help tool provides easy access to how-to
videos and common troubleshooting steps online 24/7.
Access self-help resources through twc.com/account or
the MyTWC® mobile app for iOS and Android. Select the
“Register for a TWC ID” button that appears on the login
page to complete the one-time registration process. Once
you have successfully logged in:
•
Select the “My Account” tab.
Turn off your computer and unplug the power cord to your
modem and router (if applicable). Wait 45 seconds and plug
them back in. When the lights on your modem are solid,
restart your computer.
If the above steps do not resolve your issue, please call
1-877-309-5869 and say, “Internet Technical Support,” or
visit twc.com/easyconnect.
To verify your upload and download speeds, please visit
twc.com/speedtest and follow the instructions on the site.
•
Scroll to “Manage and Troubleshoot Services.”
•
Select the “Troubleshooting” tab.
Additional support
•
Select “Video, Internet or Phone” from the dropdown to display the equipment you would like to
troubleshoot.
•
Select the symptom you are experiencing.
Check coaxial cable and Ethernet connections
If the connection on any of your cables becomes loose,
you will not be able to send or receive data. Make sure all
connections are secure.
If you have any questions during the connection process,
visit us at twc.com/easyconnect for more self-help
information or call us at 1-877-309-5869.
If you need a professional service appointment, there
may be a nominal fee if the resolution is related to an
incomplete or incorrect Easy Connect connection.
FOR QUESTIONS AND ACTIVATION 1-877-309-5869 ^ twc.com/easyconnect | 11
Thank you for choosing Time Warner Cable.
For Activation or Customer Support: 1-877-309-5869 ^ twc.com/easyconnect
© 2015 Time Warner Cable Enterprises, LLC. All Rights Reserved.
Time Warner Cable and the eye/ear logo are trademarks of Time Warner Inc. Used under license.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
