Linux-PowerPC QuickStart Instructions phyCORE

Linux-PowerPC  QuickStart Instructions phyCORE

QuickStart Instructions

Linux-PowerPC

phyCORE

®

-MPC5121e-tiny

Using Eclipse and the GNU Cross Development Toolchain

Note: The PHYTEC Linux-PowerPC-Disc includes the electronic version of the phyCORE-MPC5121e-tiny English Hardware Manual

Edition: December 2009

A product of a PHYTEC Technology Holding company

Instructions

_______________________________________________________________

In this manual copyrighted products are not explicitly indicated. The absence of the trademark (

™) and copyright (©) symbols does not imply that a product is not protected. Additionally, registered patents and trademarks are similarly not expressly indicated in this manual.

The information in this document has been carefully checked and is believed to be entirely reliable. However, PHYTEC Messtechnik GmbH assumes no responsibility for any inaccuracies. PHYTEC Messtechnik GmbH neither gives any guarantee nor accepts any liability whatsoever for consequential damages resulting from the use of this manual or its associated product. PHYTEC Messtechnik GmbH reserves the right to alter the information contained herein without prior notification and accepts no responsibility for any damages which might result.

Additionally, PHYTEC Messtechnik GmbH offers no guarantee nor accepts any liability for damages arising from the improper usage or improper installation of the hardware or software. PHYTEC Messtechnik GmbH further reserves the right to alter the layout and/or design of the hardware without prior notification and accepts no liability for doing so.

© Copyright 2009 PHYTEC Messtechnik GmbH, D-55129 Mainz.

Rights - including those of translation, reprint, broadcast, photomechanical or similar reproduction and storage or processing in computer systems, in whole or in part - are reserved. No reproduction may be made without the explicit written consent from

PHYTEC Messtechnik GmbH.

EUROPE

Address: PHYTEC Technologie Holding AG

Robert-Koch-Str. 39

55129 Mainz

GERMANY

Ordering

Information:

+49 (800) 0749832 [email protected]

PHYTEC America LLC

203 Parfitt Way SW, Suite G100

Bainbridge Island, WA 98110

USA

1 (800) 278-9913 [email protected]

Technical

Support:

+49 (6131) 9221-31 [email protected]

Fax: +49 (6131) 9221-33

Web Site: http://www.phytec.de

1 st

Edition: December 2009

1 (800) 278-9913 [email protected]

1 (206) 780-9135 http://www.phytec.com

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Contents

_______________________________________________________________

1 Introduction .........................................................................................1

1.1

Rapid Development Kit Documentation ......................................1

1.2

Professional Support Packages available .....................................2

1.3

Overview of this QuickStart Instruction.......................................2

1.4

Conventions used in this QuickStart ............................................3

1.5

System Requirements ...................................................................4

1.6

The PHYTEC phyCORE-MPC5121e-tiny ..................................5

1.7

Software Development Toolchains ..............................................8

1.7.1

Eclipse..............................................................................8

1.7.2

The Gnu Cross Development Toolchain .........................9

2 Getting Started...................................................................................10

2.1

Requirements of the Host Platform ............................................10

2.2

Configuring the Host Platform ...................................................11

2.2.1

Installing Software packages:........................................11

2.2.2

Set up Network Card Configuration..............................17

2.2.3

Disabling the Firewall ...................................................19

2.2.4

Set up TFTP-Server.......................................................20

2.3

Linux-PowerPC-Kit Setup..........................................................22

2.4

Advanced Configuration Information ........................................31

2.5

Connecting the host with the target ............................................33

2.6

Copying an Example to the Target .............................................38

2.6.1

Copying a Program to the Target ..................................38

2.6.2

Using Telnet to execute a Program on the Target .........41

2.6.3

Using SSH to execute a Program on the Target............42

2.7

Advanced Information ................................................................45

2.7.1

Copying a program to the Target with the Command

Line ................................................................................45

2.7.2

Executing a Program on the Target ...............................45

2.7.3

Executing a Program directly on the Target using SSH45

3 Getting More Involved ......................................................................46

3.1

Configuring and Compiling the Kernel......................................46

3.2

Writing the Kernel into the Target’s Flash.................................51

3.3

Opening an Existing Project .......................................................56

3.4

Creating a New Project...............................................................62

3.5

Changing the Demo Application ................................................73

3.6

Starting a Program out of Eclipse on the Target ........................76

3.7

Automatically starting the Program when booting the Target ...78

5 min

35 min

70 min

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

4 Debugging an Example Project .......................................................83

4.1

Starting the GDB Server on the target........................................83

4.2

Configuring and Starting the Debugger in Eclipse ....................85

4.3

Setting a Breakpoint ...................................................................90

4.4

Stepping and Watching Variables Contents...............................91

4.5

Changing Variables Values ........................................................93

4.6

Using the Memory Monitor........................................................95

5 Further Information .........................................................................98

6 Summary ............................................................................................99

20 min

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Introduction

_______________________________________________________________

1 Introduction

5 min

In this QuickStart you can find general information information on the

PHYTEC phyCORE

®

-MPC5121e-tiny and an overview of the Eclipse software development tool and GNU GCC C/C++ Cross-Development

Toolchain. You can also find instructions on how to run example programs on the phyCORE

®

-MPC5121e-tiny, mounted on the PHYTEC phyCORE

®

Development Board MPC5121e-tiny, in conjunction with the Eclipse development tool.

Please refer to the phyCORE-MPC5121e-tiny Hardware Manual for specific information on such board-level features as jumper configuration , memory mapping and pin layout .

1.1 Rapid Development Kit Documentation

This "Rapid Development Kit" includes the following electronic documentation on the enclosed "PHYTEC Linux-PowerPC-Disc":

• PHYTEC phyCORE-MPC5121e-tiny Hardware Manual and

Development Board Hardware Manual

• MPC5121e-tiny controller

User's Manuals and Data Sheets

• this QuickStart Instruction with general "Rapid Development Kit" description, software installation advice and an example program enabling quick out-of-the box start-up of the phyCORE

®

- MPC5121etiny in conjunction with the Eclipse / GNU GCC C/C++ software development toolchain

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 1

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

1.2 Professional Support Packages available

This Kit comes with free installation support. If you have any questions concerning installation and setup, you’re welcome to contact our support department.

For more in-depth questions, we offer a variety of custom tailored packages with different support options (e-mail, phone, direct contact to the developer) and different reaction times.

Please contact our sales team to discuss the appropriate support option if professional support beyond installation and setup is important for you.

1.3 Overview of this QuickStart Instruction

This QuickStart Instruction gives a general "Rapid Development Kit" description, as well as software installation advice and an example program enabling quick out-of-the-box start-up of the phyCORE

®

-MPC5121e-tiny in conjunction with the Eclipse IDE and GNU GCC/C++ software tools. It is structured as follows:

1) The “Getting Started” section describes the configuration of the host platform and the setup to install the tools used in this QuickStart.

2) The “Getting More Involved” section provides step-by-step instructions on how to configure and build a new kernel, modify the example, create and build new projects and copy output files to the phyCORE

®

-

MPC5121e-tiny using Eclipse.

3) The “Debugging” section provides information on how to debug an application with the Eclipse debugging interface.

In addition to the dedicated data for this Rapid Development Kit, the

PHYTEC Linux-PowerPC-Disc contains supplemental information on embedded microcontroller design and development.

2

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Introduction

_______________________________________________________________

1.4 Conventions used in this QuickStart

The following is a list of the typographical conventions used in this book:

Italic

Used for file and directory names, program and command names, command-line options, menu items, URLs, and other terms that corresponds the terms on your desktop.

Bold

Used in examples to show commands or other text that should be typed literally by the user.

Pay special attention to notes set apart from the text with the following icons:

At this part you might leave the path of this QuickStart.

This is a warning. It helps you to avoid annoying problems.

Provides useful supplementary information about the topic.

At the beginning of each chapter you can find information of the time to pass the following chapter.

You have successfully passed an important part of this

QuickStart.

Provides information to solve problems.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 3

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

1.5 System Requirements

Use of this "Rapid Development Kit" requires:

• the PHYTEC phyCORE-MPC5121e-tiny,

• the PHYTEC Development Board with the included DB-9 serial cable,

AC-to-DC adapter supplying 12 V DC/min. 2 A,

• PHYTEC Distribution based on OSELAS from Pengutronix

• an IBM-compatible host-PC (586 or higher)

• openSUSE Linux 11.0 OSS (x86) and KDE 3.5 desktop

• recommended free disk space: 2 GB

For more information and example updates, please refer to the following sources: http://www.phytec.de

[email protected]

http://www.freescale.com/

4

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Introduction

_______________________________________________________________

1.6 The PHYTEC phyCORE-MPC5121e-tiny

The phyCORE-MPC5121e-tiny represents an affordable yet highly functional Single Board Computer (SBC) solution in the size 60 x 76 mm

2 for the tiny-Board. The standard board is populated with a Freescale

PowerPC Microcontroller MPC5121e featuring a 32-bit processor architecture with Double precision FPU, 400 MHz processor speed,

Peripheral component interconnect (PCI) controller, ATA controller, Fast

Ethernet controller (FEC), DMA subsystem, 12 programmable serial controllers (PSC) configurable for the following functions:

UART , AC97 and Codec (Soft Modem, ESAI, SPI, I2S).

All applicable LocalPlus data/address lines and applicable signals extend to two high-density 160-pin Molex SMT pin header connectors (pin width is

0.635 mm./25mil) lining the circuit board edges. This enables the phyCORE-MPC5121e-tiny to be plugged like a “big chip” into target hardware.

The standard memory configurations of the phyCORE-MPC5121e-tiny features 128MByte DDR-SDRAM and 16MByte external Flash. The external Flash supports direct on-board programming without additional programming voltages.

phyCORE-MPC512e-tiny Technical Highlights

• phyCORE dimensions 60 x 76 mm with two high-density 160-pin

Molex SMT pin header connectors

• Processor: Freescale Embedded PowerPC MPC5121e, 400 MHz clock

Internal Features of the MPC5121e:

• e300 Power Architecture processor core

-

-

760 MIPS at 400 MHz (-40 to +85 °C)

32 k instruction cache, 32 k data cache

• Power modes include doze, nap, sleep, deep sleep, and hibernate

• AXE – Auxiliary Execution Engine

• MBX Lite – 2D/3D graphics engine (not available in MPC5123)

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 5

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• DIU – Display interface unit

• DDR1, DDR2, and LPDDR/mobile-DDR SDRAM memory controller

-

Multi port controller, listening on five incoming ports

• Flexible multi-function external bus interface

• MEM – 128 Kbyte on-chip SRAM

• USB 2.0 OTG controller with integrated physical layer (PHY)

• DMA subsystem

• EMB – Flexible multi-function external memory bus interface

• NFC – NAND flash controller

• LPC – LocalPlus interface

• FEC – Fast Ethernet controller

-

Supports 100Mbps IEEE 802.3 MII, 10 Mbps IEEE 802.3 MII

• PCI interface, version 2.3

• PATA – Parallel ATA integrated development environment (IDE) controller

• SATA – Serial ATA controller with integrated physical layer (PHY)

• SDHC – MMC/SD/SDIO card host controller

• PSC – 12 programmable serial controllers

- configurable for the following protocols: UART, Codec/PCM, serial audio data, I2S, multi-channel data, SPI, and AC97

• I2C – 3 inter-integrated circuit communication interfaces

• S/PDIF – Serial audio interface

• CAN – Controller area network

-

Implementation of CAN protocol, version 2.0 A/B

• BDLC – J1850 interface

• VIU – Video Input, ITU-656 complianft

• RTC – On-Chip real-time clock

• On-chip temperature sensor

• IIM – IC Identification module

• IEEE 1149.1 compliant JTAG boundary scan

6

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Introduction

_______________________________________________________________

The PHYTEC Development Board, in card dimensions (240 x 240 mm

2

/9.44 x 9.44 in

2

.), is fully equipped with all mechanical and electrical components necessary for the speedy and secure insertion of PHYTEC phyCORE-MPC5121e-tiny Single Board Computer.

Development Board Technical Highlights

• reset and power push button

• CPLD with power logic

• two software programmable LED for processor/peripheral

• LEDs for supply voltage monitoring

• power supply for regulated input voltage of +12V. It supplies regulated

+3.3 V for the phyCORE-MPC5121e-tiny and further supply voltages.

• two DB-9 sockets for the RS-232 interface

• two DB-9 plugs for two separate CAN interfaces

• Ethernet socket

• USB AB Interface for the phyCOREs Hig Speed OTG Interface

• Compact Flash Card Socket

• 2x PCI Socket

• ATA-Interface

• SATA Interface

• Graphic Interface (TTL/LVDS)

• Audio Interface with WM9712G

• ATX Power Supply sockets

• Expansion Connector

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 7

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

1.7 Software Development Toolchains

1.7.1 Eclipse

The Eclipse Platform provides support for C/C++ development. Because the Eclipse Platform is only a framework for developer tools, it doesn't support C/C++ directly; it uses external plug-ins for support. This

QuickStart shows you how to make use of the CDT -- a set of plug-ins for

C/C++ development in conjunction with the GNU GCC C/C++ Toolchain.

The CDT is an open source project (licensed under the Common Public

License) implemented purely in Java as a set of plug-ins for the Eclipse

SDK Platform. Theese plug-ins add a C/C++ Perspective to the Eclipse

Workbench that can now support C/C++ development with a number of views and wizards, along with advanced editing and debugging support.

Due to its complexity, the CDT is broken down into several components, which take the form of separate plug-ins. Each component operates as an autonomous project, with its own set of committers, bug categories, and mailing lists. However, all plug-ins are required for the CDT to work properly. Here is a list of the plug-ins/components:

Primary CDT plug-in is the "framework" CDT plug-in.

CDT Feature Eclipse is the CDT Feature Component.

CDT Core provides Core Model, CDOM, and Core Components.

CDT UI is the Core UI, views, editors, and wizards.

CDT Launch provides the launch mechanism for external tools such as the compiler and debugger.

CDT Debug Core provides debugging functions.

CDT Debug UI provides the user interface for the CDT debugging editors, views, and wizards.

CDT Debug MI is the application connector for MI-compatible debuggers.

8

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0

Introduction

_______________________________________________________________

1.7.2 The Gnu Cross Development Toolchain

Cross-development in general refers to the overall software development process that produces a single application or a complete system running on a platform that is different from the development platform. This is an important concept when the target system doesn't have a native set of compilation tools, or when the host system is faster and has greater resources.

The platform where the actual development takes place is called the host platform. The platform where the final application is tested and run is called target platform. In this QuickStart we are using a x86-architecture based Linux as host platform. As target platform we are using the power-pc architecture with a MPC5221e CPU.

Building a program for a CPU architecture different from the one used on the machine where the compilation is done, is accomplished using a crosscompiler toolchain and cross-compiled libraries. In this QuickStart we are using the GNU C/C++ Cross Development Toolchain.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 9

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

2 Getting Started

35 min

In this chapter you will establish the basis to pass the steps in this

QuickStart. First you will learn how to configure the host platform. You will install additional software packages and setup the network configuration for connecting your host to the target. After connecting the host to the target you will copy an application to the target. At the end of this chapter you will be able to start a first demo application on the target.

2.1 Requirements of the Host Platform

To pass the following steps in this Quickstart, you will need a host pc with an installation of openSUSE 11.0 OSS (x86) and KDE 3.5 desktop.

When you are installing openSUSE 11.0, you can select KDE 3.5 as

Desktop selection. The default packages to use openSUSE 11.0 with your host pc will be selected automatically. This default selection will suffice to pass the steps in this QuickStart Instruction. The installation of additional packages and configurations will be described on the following pages.

In the following configuration steps we assume, that the host pc is not connected to any other network. The target and host will be connected with a cross-over cable via a peer-to-peer connection. If your host is part of a company’s network, we recommend disconnecting your host from such a network.

In this QuickStart Instruction you will have to shutdown the firewall and configure the network card of your host pc. If your host pc is connected to another network, changing the ip address can cause conflicts with existing hosts.

_________________________________________________________________________________________

10 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.2 Configuring the Host Platform

In this passage you will learn how to configure the host platform. You will execute the following steps in this passage:

• Installing additional software packages. These packages are necessary to accomplish the steps in the QuickStart Instruction.

• Setup the network configuration to use the host pc with your target.

• Disabling the firewall. If the firewall is enabled, you will have problems with connections to the target.

• Setup a TFTP-Server. You can use a TFTP Server to download files

(e.g. a Kernel images or root file systems) into the RAM of the target from the bootloader.

2.2.1 Installing Software packages:

To accomplish the steps in the QuickStart Instruction you will have to install additional packages.

If you don’t install all of these packages, the setup may fail or some configuration steps won’t work correctly.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 11

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Open the K menu from the lower-left corner of the desktop and click on the tab Computer.

• Open the Administrator Settings / YaST.

• Enter your root password and click OK.

_________________________________________________________________________________________

12 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Open Software Management in Software.

• Select the filter Search.

• Type libxml2-devel and click Search button.

• Check libxml2-devel.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 13

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Type python-devel and click Search button.

• Check python-devel.

• Type tftp and click Search button.

• Check the packages tftp and yast2-tftp-server.

_________________________________________________________________________________________

14 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Type qt3-devel and click Search button.

• Check qt3-devel.

• Select the filter Patterns.

• Select Basis Development, C/C++ Development, and Tcl/Tk

Development.

• Click Accept.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 15

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Some additional packages will be selected automatically to resolve dependencies.

If problems occur while resolving dependencies, we recommend going back to a default configuration.

• Click on Continue to install the packages.

• Click Finish.

_________________________________________________________________________________________

16 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.2.2 Set up Network Card Configuration

In the following step you will have to configure the ip address of your host. We recommend disconnecting your host from any other network. If you change the host’s ip, chances are that problems may occur with other hosts in the network.

• Open the YasST Control Center if it is not already open.

• Choose Network Settings in Network Devices.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 17

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select the right network card, if more than one network card is installed on your host.

• Click Edit to enter the Network Card Setup.

• Choose Static address setup.

• Enter IP Address 192.168.3.10 and Subnet Mask 255.255.255.0

_________________________________________________________________________________________

18 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.2.3 Disabling the Firewall

To ensure that there are no problems with connections to the target, the host’s firewall should be disabled.

• Select the General tab in the upper-left corner.

• Use the drop-down box in the Firewall Zone settings to set the current interface to Internal Zone (Unprotected).

• Then press Next, and in the following window click Finish to complete the settings.

The firewall is now disabled for this network card.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 19

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

2.2.4 Set up TFTP-Server

Later in this QuickStart you will learn how to write a new kernel image into the flash memory of the target. To download the kernel image from the target you need to have a tftp server up and running. In this passage we show you how to configure a tftp server.

• Open the YasST Control Center if is not already open.

• Choose TFTP Server in Network Services.

If the TFTP Server icon does not exist, restart the YaST

Control Center.

_________________________________________________________________________________________

20 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Switch the selection to Enable.

• The path of the boot image directory should be /tftpboot. If there is a different path, change it to /tftpboot.

• Click Finish.

• Click Yes to create the /tftpboot directory.

• The TFTP Server will be started.

• Close the YaST Control Center.

You have successfully finished the configuration of the host platform.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 21

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

2.3 Linux-PowerPC-Kit Setup

In this section you will find a description of the Linux-PowerPC-Kit setup.

The whole setup will be done by a graphical interface. At the end of the setup, you will find all programs to develop applications for the target on your host PC.

The setup contains the following programs:

GNU C/C++ cross development tool chain – you can use this tool chain to develop programs for the target on your host PC.

• Eclipse SDK with CDT – the Eclipse SDK is a platform and application framework for building software which can use the GNU C/C++ cross development tool chain.

• Microcom – a program for serial communication with the target.

• Linux Kernel archive – this kernel archive contains the Linux kernel source code as well as all patches needed to compile the kernel for the phyCORE

®

MPC5121e-tiny.

• HelloWorld – this example program can be used to test how to download and execute a program on the target.

There will be some additional configuration on your host PC:

• The setup program will create desktop links to the installed programs.

• The setup will also create desktop links to access the target via FTP,

SSH, and Telnet.

• The path of the cross development tool chain will be added to the

$PATH environment variable.

• Read and write access to the serial interface will be added to your user account so you use the serial communication program Microcom.

• The setup will configure Microcom.

Starting the Setup:

• To start with the Linux-PowerPC-Kit Setup enter your PHYTEC

Linux-PowerPC-Disc into your CD-ROM drive.

_________________________________________________________________________________________

22 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

The following dialog probably appears:

• Click Cancel.

• From the K menu, select the Applications tab.

• Select System Terminal Terminal Program / Konsole.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 23

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

In the next step you will have to change to the directory accordant to your drive. If you use a dvd drive change to the directory /media/dvd. If you have installed a cdrom drive in your host, you will have to change to the directory /media/cdrom.

• Type

cd /media/cdrom

or

cd /media/dvd accordant to your drive.

The media may be mounted on a different mount point in the directory /media. The mount points can be shown with the command ls /media. Change to the accordant directory if no directory cdrom or dvd should exist.

• Enter ./install.sh to start the setup program.

_________________________________________________________________________________________

24 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Enter the root password.

• Click on Yes to proceed.

The welcome screen appears.

• Click on Next to continue.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 25

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Click on Next to continue.

The default destination location is

/usr/local/share/phyCORE-MPC5121e-Kit. All path and file statements within this QuickStart Instruction are based on the assumption that you accept the default install paths and drives.

If you decide to individually choose different paths you must consider this for all further file and path statements when working with this QuickStart.

We strongly recommend accepting the default destination location.

_________________________________________________________________________________________

26 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Click on Next to install the setup files to

/usr/local/share/phyCORE-MPC5121e-Kit

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 27

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

The GNU GCC C/C++ Toolchain will be installed to the standard default directory /opt/OSELAS.Toolchain-1.99.3/powerpc-603e-linux-gnu. The program mkimage will be installed in /usr/local/bin. All other programs and examples will be installed in the selected destination directory.

After the files are copied, a dialog box for the Eclipse installation will appear.

• Click on Yes to install Eclipse. If you want to skip the installation of

Eclipse choose No.

We recommend installing Eclipse even if you have already installed Eclipse on your system. This version of Eclipse includes additional plugins.

• Click Next.

_________________________________________________________________________________________

28 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Click Finish to exit the setup.

• Close the terminal window.

Now you will have to restart the KDE desktop.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 29

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Open the K Menu from the lower-left corner of the desktop.

• Select the Leave tab and choose Logout.

• When the display manager appears, enter your login name and password to restart the KDE desktop.

You have successfully installed the software for the Linux-

PowerPC-Kit. You can now use the programs you need to develop your own applications for the target on your host system. The setup program did all necessary configurations.

In the following passage you can find some advanced configuration information.

_________________________________________________________________________________________

30 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.4 Advanced Configuration Information

In this part you can find some information on how to change the configuration steps of the setup program by your own. The setup program performed all the following configuration steps.

The information in this part is for users who want to use the Linux-PowerPC-Kit on another Linux distribution than openSUSE. This is also interesting for users who want to see what configurations were done by the setup program.

During the setup program the GNU GCC C/C++ cross-compiler was installed in the directory /opt/OSELAS.Toolchain-1.99.3/powerpc-603e-

linux-gnu/gcc-4.3.2-glibc-2.8-binutils-2.18-kernel-2.6.27-sanitized/bin. To start the cross-compiler directly from every part of the system, the directory of the cross compiler was added to the $PATH environment variable.

You can manually add the directory of the cross compiler to the $PATH by adding the following line in the file /etc/profile:

export PATH=/opt/OSELAS.Toolchain-1.99.3/powerpc-603e-linuxgnu/gcc-4.3.2-glibc-2.8-binutils-2.18-kernel-2.6.27sanitized/bin:$PATH

You can open a terminal program and use the cross-compiler directly from the command line. For example you can compile a C program with the following command:

powerpc-603e-linux-gnu-gcc -o HelloWorld HelloWorld.c

In the standard configuration only the user root has write access to the serial interface. To use a serial communication tool like Microcom with normal user rights, you have to be a member of the group uucp.

A user can be added to this group with the following command:

groupmod -A <username> uucp

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 31

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

The serial communication program was configured during the setup with the following configuration:

115200 baud, 1 Start bit, 8 data bits, 1 stop bit, no parity, no flow control.

If you want to use another program than Microcom for serial communication, you will have to setup this program with these settings.

_________________________________________________________________________________________

32 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.5 Connecting the host with the target

In this section you will learn how to connect your host PC with the target.

The connection will be done using a cross-over Ethernet cable and a serial one-to-one cable. You will start Linux from flash on the target, and you will be able to login with the serial communication program Microcom as well as via a Telnet session using a peer-to-peer network connection.

• Connect the serial cable with the lower connector P2 on the target and the serial interface COM1 on your host.

Ensure to use the one-to-one serial cable included in this

Rapid Development Kit.

• Connect the cross-over Ethernet cable with the connector Ethernet on the target and the appropriate network card of your host.

• Click the Microcom icon on your desktop.

• Connect the AC adapter with the power supply connector X19 (12V) on your board.

The power connector should have 12 VDC inside and outside should be ground.

After connecting the board with the power supply the target starts booting.

When the target finished loading the file system you will see a screen similar to the following screenshot:

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 33

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Type root to login.

• After you have successfully logged in, you can close Microcom.

When the target is connected with the Power supply, first the bootloader U-Boot is loaded from the flash memory. Then the bootloader is uncompressing and booting the Linux kernel from the flash. The kernel will then mount the root file system, which is also located in the target’s flash. The root file system uses the

Journaling Flash File System, Version 2.

JFFS2 is the successor, and a complete rewrite, of the original

JFFS by Red Hat. As its name implies, the JFFS2 implements a journaling file system on the memory technology device

(MTD) it manages. JFFS2 does not attempt to provide a translation layer that enables the use of a traditional file system with the device. Instead, it implements a log-structured file system directly on the MTD. The file system structure itself is recreated in RAM at mount time by JFFS2 through a scan of the MTD's log content.

In addition to its log-structured file system, JFFS2 implements

_________________________________________________________________________________________

34 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________ wear leveling and data compression on the MTD it manages, while providing power-down reliability. JFFS2 can gracefully restart, and is capable of restoring a file system's content, without requiring outside intervention regardless of power failures.

Troubleshooting:

If you don’t see any output in the Microcom window, check the serial connection between the target and your host.

At the end of the setup, you had to restart the KDE desktop. If you haven’t done yet, restart the KDE desktop and try again.

It is also possible that your user account is missing read and write access to the serial interface:

Open the YaST Control Center.

Choose Security and Users.

Choose User Management

In the line of your user name should be the group uucp.

If the group is missing select your user name and click the

Edit button.

Select the tab Details.

Check in Groups the group uucp.

Click Accept.

Click Finish and close YaST.

• You need to log out and log in again for the new group membership to take effect.

Now you can test the network connection to the target.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 35

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Click on the Telnet for Target icon on your desktop.

A new window with a connection to the target opens.

If you see the user login in the opened window, the network configurations were configured correctly.

• Close the window.

_________________________________________________________________________________________

36 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

Troubleshooting:

If you don’t see the user login, check the connection between the target and the host. If you have installed more than one network card on your host, be sure to connect the cable with the network card you have configured with the IP address

192.168.3.10.

If you don’t see the login, you may not have set up the right IP address of your host. You can check the settings of your network card by opening YaST. In the YaSt Control Center you can select Network Settings in Network Devices. There should be the following configuration:

Information how to configure your network device can be found in the section Configuring the Host Plattform.

You have successfully setup all configurations to access your target from your host.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 37

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

2.6 Copying an Example to the Target

In this section you will learn how to copy an example program to the target using the FTP protocol with the Konqueror browser. After that you will execute the example on the target. At the end of this passage you can find some information how to copy and execute a file on the target using the command line.

2.6.1 Copying a Program to the Target

• First click on the icon phyCORE-MPC5121e-Kit on your KDE desktop.

A new window with the content of the installation directory opens.

• Enter the directory HelloWorld.

_________________________________________________________________________________________

38 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

• Click the FTP for Target icon on your desktop.

A window with an FTP session to the target opens. User is root and password is empty. Now you have two windows opened, one for the target and one for the host. You can use these two windows to copy files per

“drag and drop” from the host to the target (and vice versa).

• Select the window that lists HelloWorld program on your hard disk.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 39

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Click the HelloWorld program and hold the left mouse button pressed.

• Drag the program into the window with the FTP session to the target and release the mouse button.

• Choose Copy here in the appearing context menu.

• Close the two windows.

_________________________________________________________________________________________

40 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.6.2 Using Telnet to execute a Program on the Target

• Click the Telnet for Target icon on your KDE desktop.

• Enter root as login name and press Enter.

• Enter ./HelloWorld and press Enter.

The program starts and you see the following output:

Welcome to the World of the phyCORE-MPC5121e!

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 41

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

2.6.3 Using SSH to execute a Program on the Target

SSH can be used if you want to execute a program directly from the host on the target. Later, this will be used to execute programs out of Eclipse on the target. Before you can start programs out of Eclipse, you have to log into the target via SSH from the command line for one time. This is necessary to add the RSA public key of the target to the list of the known hosts.

There are several authentication methods when using

SSH. The method used on the phyCORE-MPC5121e-tiny is the hosts.equiv method combined with RSA-based host authentication.

If the machine the user logs in from is listed in

/etc/hosts.equiv on the remote machine, and the user name is the same on both sides, the user is allowed for log in.

On the target, the file /etc/hosts.equiv has the following entry:

# file: /etc/hosts.equiv

#

# Allow access from everywhere.

#

+ +

The “+ +” means that every user can login from every host.

When the host connects to the target, the file

~/.ssh/known_hosts (on the host) is consulted when using

hosts.equiv with RSA host authentication to check the public key of the target. The key must be listed in this file to be accepted. When the host connects to the target for the first time, you will be asked to store the target’s RSA public key to your ~/.ssh/known_hosts. If you agree to do this, then the host will be able to connect to the target without entering a password.

_________________________________________________________________________________________

42 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

This authentication method closes security holes due to IP spoofing, DNS spoofing and routing spoofing. But note that /etc/hosts.equiv is, in general, inherently insecure and should be disabled if security is a concern.

• Click the SSH for Target icon on the desktop.

A new window opens.

In this window you can see that the authenticity of the target can’t be established. This is normal if you want to create an SSH connection for the first time.

• Enter yes and press Enter to continue. The RSA public key of the target will be permanently added to the list of the known hosts.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 43

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Troubleshooting:

If an error occurs and you can’t see the

[email protected]:~> prompt, open a terminal window and enter the following command:

rm ~/.ssh/known_hosts

Try to log in again by entering:

ssh [email protected]

Enter yes to add the target to the list of known_hosts.

Now you should see the login prompt.

We expect that you haven’t changed the SSH configuration file on your host. If you change this file, the authentication may not work.

Now you are logged in, you can execute programs on the target.

• Type ./HelloWorld start the program you had copied to the phyCORE-

MPC5121e-tiny before.

The program starts and you should see the following output:

Welcome to the World of the phyCORE-MPC5121e!

• Close the SSH window.

If you click on the Icon SSH for Target again, the host will connect directly to the target.

• Close the window.

You have successfully copied and executed an example application on the target.

_________________________________________________________________________________________

44 © PHYTEC Messtechnik GmbH L-747e_0

Started

_______________________________________________________________

2.7 Advanced Information

2.7.1 Copying a program to the Target with the Command Line

Open a new terminal window.

• Change to /usr/local/share/phyCORE-MPC5121e-Kit/HelloWorld:

cd /usr/local/share/phyCORE-MPC5121e-Kit/HelloWorld

• Copy the application to the target by typing:

ftp -u ftp://root:[email protected]/ HelloWorld

Be sure to enter a slash followed by a space after the IP address.

2.7.2 Executing a Program on the Target

Open a Telnet session to the target:

telnet 192.168.3.11

• Type root and press Enter.

• Type ./HelloWorld to start the application.

• Type exit.

2.7.3 Executing a Program directly on the Target using SSH

To start the program, type:

ssh [email protected] ./HelloWorld

After the program has finished, SSH will logout automatically.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 45

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

3 Getting More Involved 70 min

In this chapter you will pass some continuative topics. First you will configure and compile your own kernel. With the kernel configuration tool you can add additional features or disable them if they are not needed.

After compiling the kernel, you will learn how to write the newly created kernel into target’s flash memory and how to start the new kernel.

Then you will start working with the Eclipse platform using the

C/C++ Development Tools (CDT) in conjunction with the GCC C/C++ tool chain. You will learn how to configure the Eclipse platform and how to open an existing project. After that you will create your first own project and modify the example’s source code.

At the end of this chapter you will execute the program as external application out of Eclipse. Additionally, you will add your application to the startup configuration of the target so it is automatically started when the phyCORE-MPC5121e-tiny boots.

3.1 Configuring and Compiling the Kernel

In this part you will learn how to configure and build a new Linux kernel and a root filesystem. First you will copy the kernel archive to your home directory and extract the kernel source. Then you will configure the kernel and the root filesystem with the help of PTXdist, a tool to build the Board

Support Package and to create your own image. After the configuration you will create your own image.

The kernel used by PHYTEC is based on a standard kernel available from

www.kernel.org. Additionally, the kernel archive in your setup installation directory already includes all necessary patches for the phyCORE-

MPC5121e-tiny.

_________________________________________________________________________________________

46 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

In the end, you need the following files:

• ptxdist-1.99.12.tgz (Tool from our partner Pengutronix, that configures and compiles BSPs)

• ptxdist-1.99.12-patches.tgz (Patches for the tool)

OSELAS.BSP-Phytec-phyCORE-MPC512x-tiny-PD09.1.0R1.tar.gz

(BSP for phyCORE-MPC5121e-tiny)

• powerpc-603e-linux-gnu.tar.bz2 (ready-to-use toolchain)

All files are downloadable from our ftp-server. Please create a temporary directory within your home directory, for example local/, and copy the files into it.

Now, open a new terminal if not already open and install PTXdist:

Click the terminal icon on your desktop.

Type the following commands to extract the PTXdist-archieves:

cd local tar zxvf ptxdist-1.99.12.tgz tar zxvf ptxdist-1.99.12-patches.tgz

Now you should check if all necessary tools are installed on your host.

Therefor call the configure script:

cd ptxdist-1.99.12

./configure

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 47

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

After a long list of checking …

it should return with: configure: creating ./config.status config.status: creating Makefile config.status: creating scripts/ptxdist_version.sh config.status: creating rules/ptxdist-version.in ptxdist version 1.99.12 configured.

Using '/usr/local' for installation prefix.

Report bugs to [email protected]

If any tool that is necessary for PTXdist is missing, script will abort with an error. In this case you need to install the missing tool from your linux distribution. After that, please restart the configure script.

In any case, tool quilt needs to be installed additionally, in order to avoid errors while compiling patches!

• After successful completion of configure script, please type:

make

• Now you can install PTXdist. Because target directory is /usr/local, this must be done as user root:

sudo make install

[enter root password]

[...]

• Finally you can delete the temporary directory:

cd rm -rf local

_________________________________________________________________________________________

48 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

When using PTXdist for the first time, setting some configurations is needed. The most important are:

Where to put the source packages to.

Proxy settings for accesses to the internet.

Please start PTXdist setup:

ptxdist setup

PTXdist will download all necessary sources from the internet. For every source package, that cannot be found on your host, PTXdist will do this by executing command wget. If a proxy server should be used for doing internet accesses, please select Proxies, then FTP Proxy and then enter address and port of the proxy in the following form:

<protocol>

://

<address>

:

<port>

PTXdist will store downloaded source packages locally. Thus, if you work with more than one project, every project would download its own sources, even if they are the same that have already been downloaded. In order to avoid this, we suggest to use one single directory for all source packages of all projects. Some source packages are already included within this BSP, so we suggest to use its src-directory as source directory for all projects.

Please select Source Directories and enter:

${PTXDIST_WORKSPACE}/src

In order to be able to build an BSP for the MPC5121e, you need a toolchain with a suitable crosscompiler for this processor. So please decompress the corresponding archive with root rights. It will be stored in directory /opt automatically.

tar xPvjf powerpc-603e-linux-gnu.tar.bz2

Now you’re ready to build the BSP. Please decompress archieve

OSELAS.BSP-Phytec-phyCARD-i.MX27-PD09.1.0R1.tar.gz into a directory and then move into it. Select the platform for which the BSP should be build:

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 49

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

ptxdist platform \

configs/phyCARD-i.MX27-1.99.12-trunk/platformconfig

You should get the messages:

'configs/phyCARD-i.MX27-1.99.12-trunk/platformconfig'

Furthermore PTXdist should have recognized the necessary toolchain and confirm this by giving you the messages: found and using toolchain:

'/opt/OSELAS.Toolchain-1.99.3/powerpc-603e-linux-gnu/gcc-4.3.2-glibc-2.8-binutils-

2.18-kernel-2.6.27-sanitized/bin'

Otherwise you need to choose the toolchain manually:

ptxdist toolchain /opt/OSELAS.Toolchain-1.99.3/powerpc-603e-linux-

gnu/gcc-4.3.2-glibc-2.8-binutils-2.18-kernel-2.6.27-sanitized/bin

For building the BSP you could call ptxdist go

now, but then you would get so much stuff for the root-filesystem of your target, that it won’t fit into the flash-memory any more. This rootfs could only be used when mounting it via NFS. Thus, PHYTEC provides the BSP together with a file called a

'collection', that excludes not necessary stuff for you. Please tell ptxdist to use this collection by calling

ptxdist collection configs/collectionconfig-kit

Now, for building the BSP call

ptxdist go

Now it will take some hours. Sometimes it can happen that an attempt to download a source package failes due to dead links. PHYTEC cannot guarantee the accessibility of all the webpages that are needed to build a

BSP. You can check our ftp-server via ftp://ftp.phytec.de/pub/BSP_PACKAGES/EXTERNALS

_________________________________________________________________________________________

50 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

If you find a missing source package there. Otherwise you need to search the web for missing packages. If you have found them, you need to download them into your src-directory manually. After that, please restart build process by calling ptxdist go again. If you cannot find a needed source package, please tell us via

[email protected]

.

Sometimes it even might happen, that ptxdist can download a file that is claimed to be an archive, but then cannot decompress it. Reason is, that the link didn’t deliver the requested archive, but an HTML containing a message like: “Error - This file has been moved to …”. Please treat this case in the same way as if nothing had been delivered by the link.

Finally you can create the rootfs by calling

ptxdist images

You will find the kernel-image linuximage

and the flashfilesystem-image root.jffs2

in directory platform-phyCORE-MPC5121e/images

. The NFSmountable rootfs will be located in platform-phyCORE-MPC5121e/root

.

Close the terminal window.

In this section you learned how to configure and compile a new kernel.

Now you can add new features to your kernel, or remove features you do not need.

3.2 Writing the Kernel into the Target’s Flash

In this passage you will find a description how to write the newly created images into the phyCORE’s flash memory. Before the images can be written into the flash, the target will have to download them from a tftp server. This will be done from the command line of the boot loader.

The images will be copied into target’s RAM. Then you will have to erase the part of the flash where you want to copy the images to.

Finally the images are written from the RAM to the flash.

In the default configuration you will find five partitions on the target. The first partition contains the boot loader, the second is used to store the boot

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 51

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

loader settings, the third partition stores the Linux kernel, the fourth containes the root file system, and the fivth containes the oftree.

The four partitions have the following address ranges:

0xfff00000 - 0xfff5ffff (U-Boot)

0xfff60000 - 0xfff9ffff (U-Boot Environment)

0xfe060000 - 0xfe23ffff (Linux Kernel)

0xfe240000 - 0xffefffff (Linux Root File System)

0xfffa0000 - 0xffffffff (Linux Oftree)

You should never erase the U-Boot partition. If this partition is erased, you won’t be able to start your target anymore. Refer to the chapter “Installing Linux on the

phyCORE-MPC5121e-tiny” for detailed information on how to restore your U-Boot partition in such a case.

• First open a new terminal window if it is not opened yet.

• Copy the new images to the /tftpboot directory and exit:

cd platform-MPC5121e/images cp linuximage /tftpboot cp root.jffs2 /tftpboot cp oftree /tftpboot exit

_________________________________________________________________________________________

52 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Open Microcom and press the RESET button on the target.

You will see the output “Hit any key to stop autoboot.”

• Press any key to stop autoboot.

You can download an image from the TFTP – server, erasing the required

Flash area and writing the image from the RAM into the Flash with one simple command.

• Before you can execute this command you have to set the names of your images to the corresponding environment variables:

set kernel linuximage set rootfs root.jffs2 set oftree oftree

• Make sure that you’ve got the correct IP-setting:

set serverip 192.168.3.10 set ipaddr 192.168.3.11 set netmask 255.255.255.0

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 53

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Now you can start downloading and writing the three images into the

Flash using the commands:

run update_kernel run update_rootfs run update_oftree

The copy processes can take some minute, depending on the speed of your system.

• Press the RESET button on the target to restart with the new images.

The target will restart booting with the newly created images.

• Close Microcom when the target successfully finished with booting the kernel and mounting the root filesystem.

_________________________________________________________________________________________

54 © PHYTEC Messtechnik GmbH L-747e_0

.

Getting More Involved

_______________________________________________________________

Troubleshooting:

If any problem occurs after writing the images into flash, you can restore the original images system from your setup CD-

ROM.

You will find the kernel and root file system in the directory

PHYTEC/PCM046 phyCORE-MPC5121e/Linux-Kit/BSP/

Images.

• Copy the files

uImage-pcm046, root-pcm046.jffs2 and oftree-pcm046 into the directory /tftpboot

• Type the following commands in the u-boot command line:

set kernel uImage-pcm046 set rootfs root-pcm046.jffs2 set oftree oftree-pcm046 run update_kernel run update_rootfs

run update_oftree

In this section you learned how to download images from a tftp server into the RAM memory of the target. The images have been written from RAM to flash, and finally the target was started with the new images.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 55

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Opening an Existing Project

In this section you will import an existing Eclipse project into your workspace. The imported example project will be compiled with the cross compiler. After compiling the project you will copy and execute the newly created program on the target.

Copying the HelloWorld project:

• Click on the phyCORE-MPC5121e-Kit directory icon.

• Right-click the HelloWorld directory and select Copy.

• Browse to your home directory.

• If the workspace directory doesn’t exist, create a directory workspace in your home directory.

• Enter the workspace directory.

• Right-click in the workspace directory and select Paste.

• Close the Konqueror file browser.

Starting Eclipse and importing the example project:

• Click on the Eclipse icon to start the application. You can find the icon on your desktop.

_________________________________________________________________________________________

56 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Confirm the workspace directory with OK.

The Welcome screen will appear.

• Select File -> Import in the menu bar.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 57

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select Existing Projects into Workspace.

• Click Next.

• Select Browse.

_________________________________________________________________________________________

58 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

Double-Click on the HelloWorld directory.

• Click OK.

• Select Finish to import the project.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 59

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Close the Welcome Screen.

The HelloWorld program will be compiled and the HelloWorld executable is built for the target. Then the HelloWorld file is copied to the target using the FTP. After the file has been copied to target, the program is executed on the target using SSH. You should now see the “Welcome to the World of

the phyCORE-MPC5121e! “ output in the console window.

• Select the Console tab.

You will see the following content in the console window:

_________________________________________________________________________________________

60 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

If the project is not built automatically, you will have to check

Project ► Build automatically from the menu bar.

You have successfully passed the first steps with the Eclipse

IDE. You are now able to import existing projects into the

Eclipse Workspace. You can compile an existing project and execute the program on the target.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 61

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

3.3 Creating a New Project

In this section you will learn how to create a new project with Eclipse and how to configure the project for use with the GNU C/C++ cross development toolchain.

• Open Eclipse if it isn´t already open.

• Select File ► New ► Project from the menu bar.

A new dialog opens.

• Select Managed Make C Project and click Next.

_________________________________________________________________________________________

62 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Enter the project name myHelloWorld and click Next.

• Click Next.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 63

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Click Finish.

• Select Yes to open the C/C++ perspective.

You will see the C / C++ IDE with the myHelloWorld project.

_________________________________________________________________________________________

64 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Right-click on HelloWorld.c in the HelloWorld project which we have worked with previously.

• Select Copy.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 65

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select the myHelloWorld project.

• Right-click and select Paste.

• Double-click on HelloWorld.c in the myHelloWorld project.

If Build Automatically from the Project menu is selected, the HelloWorld application will now be compiled and created with the standard GNU GCC

C/C++ compiler suitable for your host machine. You will find the executable file, which can only be run on your host system, in the

workspace/ myHelloWorld/Debug directory.

To compile your project for the phyCORE-MPC5121e-tiny instead, you will have to use the GNU C/C++ cross compiler.

• Right-click the myHelloWorld project and choose Properties.

The Properties dialog appears.

_________________________________________________________________________________________

66 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Select C/C++ Build.

• Enter powerpc-603e-linux-gnu-gcc into the Command input field.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 67

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select GCC C Linker.

• Enter powerpc-603e-linux-gnu-gcc into the Command input field.

_________________________________________________________________________________________

68 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Select GCC Assembler.

• In the Command input field, change the default as to powerpc-603e-

linux-gnu-as.

• Click Apply.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 69

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select the Build Steps tab:

• Enter following command in the Command input field:

ftp -u ftp://root:[email protected]/ ./myHelloWorld; ssh [email protected] ./myHelloWorld

Be sure to enter the semicolon between ./myHelloWorld and

ssh.

• Click Apply.

• Click OK.

_________________________________________________________________________________________

70 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Select Project ► Clean from the menu bar.

• Confirm with OK.

The project will be rebuilt.

• Select the Console tab.

If no errors occur while building, you will see the following output:

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 71

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

You have successfully created your first own project with the

Eclipse IDE. You have configured the project to create an application for your target platform.

_________________________________________________________________________________________

72 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

3.4 Changing the Demo Application

Now we will extend the myHelloWorld application. The extended

myHelloWorld application will write an output to the first serial interface as well as to the standard output.

Open Eclipse if it is not opened yet.

Double-click HelloWorld.c in the myHelloWorld project.

First include the following two additional header files:

#include <unistd.h

>

#include <fcntl.h>

Then add the function write_tty(), which writes n bytes to the first serial interface (which, on the phyCORE-MPC5121e-tiny, is connected to the system console /dev/console): void write_tty (char *buffer, int count) {

int out;

out = open ("/dev/console", O_RDWR);

write (out, buffer, count);

close (out);

}

Enter the following two lines in the main() function to declare the buffer und call the write_tty() function. char buf [] = {"Welcome to the World of the

phyCORE-MPC5121e! (serial)\n"}; write_tty (buf, sizeof (buf) - 1);

In the next screenshot you can see the complete program.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 73

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Save your program after changing the code.

The application will be compiled, built, copied to the target and executed.

Executing the program on the target using Microcom:

Click the Microcom icon on the desktop.

If you are not logged in, enter root and press Enter.

Type ./myHelloWorld to start the application.

You will see the following output:

Welcome to the World of the phyCORE-MPC5121e! (serial)

Welcome to the World of the phyCORE-MPC5121e!

Close Microcom.

When you start the application over an SSH session, you only see one output line. When you execute the program with Microcom, you see two output lines.

_________________________________________________________________________________________

74 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

The first line is a direct output on the serial interface. You can’t see this line in an SSH session, because you are connected over a TCP/IP connection to the target. With Microcom, however, you have direct access to serial interface, so you can also see the line that is written to the serial console.

In this passage you have changed an existing application. You also learned how to to access the serial interface. First you called the function open() on the device /dev/console. The return value of this function was a file descriptor. With the file descriptor you called the function write() to send n bytes to the device /dev/console. After that, the file descriptor was closed with the function close().

This procedure is in principle quite typical for Linux, because Linux treats everything like a file.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 75

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

3.5 Starting a Program out of Eclipse on the Target

After compiling a project in Eclipse, the program is copied to the target and directly executed. A program can also be executed on the target without compiling a project. In the following section you will learn how to start a program on the target as an external tool.

• Select Run External Tools External Tools from the menu bar.

Select Program.

• Select New.

_________________________________________________________________________________________

76 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

In the Name input field, enter: myHelloWorld Target

Enter /usr/bin/ssh in the Location input field.

• Enter [email protected] ./myHelloWorld into the Arguments field.

Select Apply.

• Select Run.

If you want to execute the program the next time, you can use the Run

External Programs button from the menu bar.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 77

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

3.6 Automatically starting the Program when booting the Target

In this passage you will integrate the myHelloWord program into the startup process of the target. When you have finished this part, the

myHelloWorld application will be started automatically each time you are starting the target.

The scripts for controlling the system will be found in /etc/init.d.

These are executed directly or indirectly by /sbin/init, the father of all processes. The configuration of the /sbin/init is placed in

/etc/inittab.

After system startup, /sbin/init will switch on the default run level, as configured in /etc/inittab. It calls the run level master script /etc/init.d/rcS to start or stop services provided by the other scripts in /etc/init.d/. This is done by the help of symbolic links in the directory /etc/rc.d/. These links point to the actual startup scripts in /etc/init.d.

First you will have to create a start script in /etc/init.d.

• Click the FTP for Target icon on your KDE desktop.

_________________________________________________________________________________________

78 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

• Browse to the target’s /etc/init.d. If an authorization dialog should appear, just click OK (no password is required).

In the directory /etc/init.d you can see existing scripts.

Right-click in the opened window and select Create New Text File.

Enter myHelloWorld.

Click OK.

Right-click on myHelloWorld and select Open with.

Enter kwrite and click OK.

The text editor KWrite starts with an empty document.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 79

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Enter the following two lines:

#!/bin/sh

/home/myHelloWorld

• Select FileSave.

• Close the KWrite window.

• Close the FTP window.

Click the Telnet for Target icon on your desktop.

_________________________________________________________________________________________

80 © PHYTEC Messtechnik GmbH L-747e_0

Getting More Involved

_______________________________________________________________

Enter root and press Enter to login.

• The startup script we have just created with KWrite must be made executable in order to run it later:

chmod a+x /etc/init.d/myHelloWorld

Change to the directory /etc/rc.d. Type the following command:

cd /etc/rc.d

• Enter ls -l to show the directory content.

You can see the different links to the scripts in the directory /etc/init.d. The scripts are started in alphabetic order: The script udev is the first script started, because the link starts with S00…, whereas

S99zzz_PHYTEC_BSP_version_startup_script will be started last. To start your myHelloWorld application automatically when the system boots, you have to create a new link to the start script /etc/init.d/myHelloWorld.

In /etc/rc.d, create a symbolic link which points to

/etc/init.d/myHelloWorld. Enter the following command:

ln -s ../init.d/myHelloWorld S99myHelloWorld

• Type ls -l again to check the newly created link.

Close the window.

• Open Microcom.

• Push the RESET button on the target to restart your system.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 81

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

The program myHelloWorld now starts automatically on startup. Because its link in /etc/rc.d starts with S99…, you should see myHelloWorld’s output near the output of the two other scripts that start with S99… (which print all sorts of version information).

Close Microcom.

Now you can add your own programs to the root file system and start these programs automatically when your phyCORE-MPC5121e-tiny boots.

You have successfully passed the “Getting More Involved” part of this QuickStart.

_________________________________________________________________________________________

82 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

4 Debugging an Example Project

20 min

In this chapter you will learn using the GNU Debugger GDB on the host for remote debugging in conjunction with the GDB server on the target.

GDB is the symbolic debugger of the GNU project and is arguably the most important debugging tool for any Linux system.

First you will start the GDB server on the target. Then you will configure the Eclipse platform and start the GNU debugger out of Eclipse using the

Debug view.

The CDT extends the standard Eclipse Debug View with functions for debugging C/C++ code. The Debug view allows you to manage the debugging or running of a program in the Workbench. Using the Debug view you will be able to set breakpoints/watchpoints in the code and trace variables and registers. The Debug view displays the stack frame for the threads of each target you are debugging. Each thread in your program appears as a node in the tree, and the Debug view displays the process for each target you are running.

The GDB client is running on the host and is used to control the GDB server on the target, which in turn controls the application running on the target. GDB client and GDB server can communicate over a TCP/IP network connection as well as via a serial interface. In this QuickStart we will only describe debugging via TCP/IP.

4.1 Starting the GDB Server on the target

In this passage you will learn how to start the GDB server on the target.

The GDB server will be used to start and control the myHelloWorld program.

To debug a program with GDB, the program needs extending debugging symbols. This has already been added while building the program.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 83

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Open Microcom

Type root and press Enter.

• Start the gdbserver:

gdbserver 192.168.3.10:10000 myHelloWorld

You have started the GDB server on the target. The GDB server is now waiting for connections on TCP port 10000.

_________________________________________________________________________________________

84 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

4.2

Configuring and Starting the Debugger in Eclipse

In this passage you will learn how to configure your project settings to use

Eclipse with the GNU debugger. After the configuration of your project settings, the GNU debugger will start and connect to the GDB server on the target.

• Start Eclipse if the application is not started yet.

• Select myHelloWorld in the Navigator window.

• Select Run ► Debug from the menu bar.

A dialog to create, manage and run applications will appear.

Select C/C++ Local Application.

• Click New.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 85

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Select the Search Project button.

• Click OK .

_________________________________________________________________________________________

86 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

• Select the Debugger tab.

• Select GDB Server from the Debugger drop-down box.

• Click the Browse button right beside the GDB debugger input field.

A new dialog opens to choose the GDB executable.

Click on File System.

• Navigate to the directory /opt/OSELAS.Toolchain-1.99.3/powerpc-603e-

linux-gnu/gcc-4.3.2-glibc-2.8-binutils-2.18-kernel-2.6.27-sanitized/bin.

• Select the file powerpc-603e-linux-gnu-gdb.

Click OK.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 87

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• From the Connection drop-down box, select TCP.

Enter 192.168.3.11 (the target’s IP address) in the Host name input field. The host’s GDB will connect to this IP address to communicate with the target’s GDB server.

Click Apply.

Click Debug.

A new dialog appears.

_________________________________________________________________________________________

88 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

Select Yes to switch to the Debug perspective.

The Debug perspective opens and the debugger stops at the first line automatically. The host’s GDB is now connected to the GDB server on the target.

You have configured your project for remote debugging. You have started the GNU debugger in Eclipse and connected the host’s GDB with the target’s GDB server. You can now start to debug the project.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 89

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

4.3 Setting a Breakpoint

Now you will set a breakpoint in your program. The breakpoint will be set on the last line of the function main(). If you resume the application, the debugger will stop on this line.

• Select the last line in main().

Right-click into the small grey border on the left-hand side and select

Toggle Breakpoint to set a new breakpoint.

_________________________________________________________________________________________

90 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

4.4 Stepping and Watching Variables Contents

In this part you will step through the example project with the debugger.

You will also learn how to watch the content of a variable.

• Expand buf in the Variables window

• Click the Step Over

button in the Debug Window to step to the next line.

You will see the content of the buf variable in the Variables window.

Click on the variable buf.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 91

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Then click the button Step into

The debugger stops in write_tty().

to enter the function write_tty().

You will see the following variable window:

• Click on the variable buffer.

You will probably see a different address at the buffer pointer. Remember what address is shown in your case; you will need this address later.

_________________________________________________________________________________________

92 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

4.5 Changing Variables Values

In this section you will change the value of a variable. At the end of this part you will see the effect of this change.

• Select the count variable in the Variables window.

• Right-click on count and select Change Value.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 93

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

• Change the value of count to 7 and select OK.

Open Microcom if the application is not already opened.

• Go back to Eclipse.

• Click the Step Over

button two times.

• Change to Microcom.

You will see the output Welcome in the Microcom window. This means that due to changing the counter variable’s value, instead of printing the full “Welcome to the World of the phyCORE-MPC5121e!” string, only the first seven characters of the buffer were written to the screen.

_________________________________________________________________________________________

94 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

4.6 Using the Memory Monitor

At the last part in this chapter you will use the memory monitor to watch the content at a memory address.

Select the Memory tab in the window below.

• Click Add Memory Monitor.

Enter the address of buffer and click OK. Remember that the variable’s address might differ on your system.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 95

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Change the window size.

Click Add Rendering.

Select ASCII and click OK.

_________________________________________________________________________________________

96 © PHYTEC Messtechnik GmbH L-747e_0

Debugging

_______________________________________________________________

You can see the content of the variable buf at the address 0xbfd62908 (or whatever address is used on your system).

Now click the Resume button from the menu bar.

The debugger stops at the breakpoint in the last line of main().

Click the Resume button to end the application.

You have successfully passed the debugging chapter. You are now able to configure and use Eclipse for remote debugging.

You can step through a project, watch and change the content of variables and you can use the memory monitor to view the content at a memory address.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 97

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

5 Further Information

In the PTXdist User Manual you can find further information. You will find the manual in the directory OSELAS.BSP-Phytec-phyCORE-

MPC512x-tiny-PD09.1.0/documentation of the archive OSELAS.BSP-

Phytec-phyCORE-MPC512x-tiny-PD09.1.0.tar.gz on your setup cdrom.

The PTXdist User Manual includes information about the following topics:

Installation and Configuration of PTXdist

Using and Building a Toolchain

Create and activate a project

Running phyCORE-MPC5121e-tiny from network only

Running phyCORE-MPC5121e-tiny stand alone

U-Boot and phyCORE-MPC5121e-tiny phyCORE-MPC5121e-tiny’s BSP

_________________________________________________________________________________________

98 © PHYTEC Messtechnik GmbH L-747e_0

Summary

_______________________________________________________________

6 Summary

This QuickStart manual provided a general "Rapid Development Kit" description, as well as software installation advice and an example program enabling quick out-of-the-box start-up of the phyCORE

®

-MPC5121e-tiny in conjunction with the Eclipse IDE and GNU

C/C++ software tools.

In the Getting started section you learned to configure your host to provide a basis for working with your target platform. You installed the Rapid

Development Kit software and you learned how to copy and run a program on the target.

In the Getting More Involved section you got a step-by-step instruction on how to configure and build a new kernel, modify the example application, create and build new projects and copy output files to the phyCORE –

MPC5121e-tiny using Eclipse.

The Debugging part of this QuickStart gave you information on setting up and using the GNU debugger with the Eclipse IDE. You learned how to set breakpoints, watching and changing variable contents and using the memory monitor.

_________________________________________________________________________________________

© PHYTEC Messtechnik GmbH L-747e_0 99

phyCORE-MPC5121e-tiny QuickStart Instructions

_______________________________________________________________

Document: phyCORE

®

-MPC5121e-tiny with Linux

QuickStart Instructions

Document number: L-747e_0, December 2009

How would you improve this manual?

Did you find any mistakes in this manual? page

Submitted by:

Customer number:

Name:

Company:

Address:

Return to:

PHYTEC Technologie Holding AG

39

Mainz
