INTRODUCTION

DEC Digital Modules are a coordinated set of digital circuits used for building and testing computer systems.

For use as laboratory equipment, they are packaged for convenient patch cord interconnections. For use in systems, they are packaged in a unique plug-in unit construction.

They are available in three compatible speed ranges with maximum frequencies of 500 kilocycles,S megacycles, and

10 megacycles.

DEC Modules are designed to be easy to understand and easy to use. People with no knowledge of Boolean algebra can perform logical design with DEC Modules, and those who like to use Boolean mathematics can very quickly and easily implement their equations. Straightforward static logic is employed, and only a small number of Modules is needed for most systems because of the high driving capability of each unit.

The general logical principles utilized are the same for all Modules. The purpose of this booklet is to acquaint the reader with these principles.

The logic used with DEC Modules is "static."

"ONES"

and

"ZEROS"

in this system are represented by two different DC voltage levels. The use of such a static system makes it possible to change the state of a system at any time. Logic is performed by the coincidence of levels which are sampled by pulses. Unlike "dynamic" logic, where

ONES

and

ZEROS

are represented by the presence or absence of a train of pulses, static logic is not tied to a fixed clock frequency and usually avoids precise timing problems.

The rules governing loading will depend on the speed range of the equipment used. The rules and illustrations in this book are applicable principally to 500 kilocycle and

5 megacycle Modules.

3

DEC LABORATORY MODULES (TOP) AND DEC SYSTEM MODULES

ARE AVAILABLE IN THREE COMPATIBLE FREQUENCY RANGES

4

CONTENTS

INTRODUCTION. .

DEC SYMBOLOGY

BASIC DIGITAL MODULES

The Transistor Inverter .

Diode Logic.

Flip-Flops.

Delays . .

Pulse Amplifiers

Clocks . . . .

Pulse Generators .

TYPICAL APPLICATIONS

Counters . . .

Parallel Adders

Comparators

Synchronizers

Subtracters .

Gray-to-Binary Code Converter

RULES AND DEFINITIONS

Inverter Usage

Loading Definitions

Marginal Checking .

Indica tors . . . .

BOOLEAN ALGEBRA .

DEC TECHNICAL BULLETINS

. .

. .

.

.

3

6

7

12

17

7

9

18

19

19

21

21

27

31

41

44

47

47

36

39

39

41

49

56

5

DEC SYMBOLOGY

A small rectangle with an enclosed solid triangle is an inverter.

Input

Base

1

Emitter

INVERTER

°tlector

A resistor with a large solid dot is a standard

DEC clamped load resistor.

CLAMPED LOAD

The solid diamond is a logic level for which the assertion level is -3 volts.

LEVEL-NEGATIVE

The open diamond is a logic level for which the assertion level is ground.

LEVEL-GROUND

The solid arrowhead is a negative pulse (from ground).

PULSE-NEGATIVE

The open arrowhead is a positive pulse (from ground).

r

PULSE - POSITIVE

Arrowheads (or diamonds) are used at all branch points to indicate signal flow.

6

BASIC DIGITAL MODULES

THE TRANSISTOR INVERTER

Most logical operations with DEC Modules are performed with saturating PNP transistor inverters. When a junction transistor is turned completely on or "saturated," the collector is practically a short circuit to the emitter of the transistor. If the emitter is at ground in this condition, the output from the collector will also be at ground voltage.

When a junction transistor is turned completely off or

~~opened," the collector-to-emitter path is practically an open circuit. If the collector is connected to a clamped load resistor, the collector will be at

-3 volts.

- 3v -15v

W

I

I

I

Output

~ C'~::..d

Input

O-~/V'\-+-+-f

+

10v

I

.

1

FIGURE

1

I

I

- i

T'M""",

I

I

I

1

FIGURE

2

Figure 1 is a schematic drawing of a DEC inverter and clamped load resistor. The capacitor shunting the input resistor is used to provide overdriving current to the transistor during input level changes, thus switching the transistor much more rapidly. The resistor to +10 volts biases off the transistor to protect against noise voltage. The load resistor is clamped to

-3 volts with a diode so that, when the transistor is off, the output signal is always at -3 volts regardless of the loading on the inverter output.

7

To simplify logic drawings, the symbology of Figure 2 is used.

When the input is negative, the output is ttshorted" to ground.

When the input is positive or at ground level, the transistor is open circuit~d and the output, if connected to a clamped load resistor, is at -3 volts.

1----<>

Output

Input

FIGURE

3

The inverter switch is analogous to the mechanical switch, as shown in Figure 3. The logical designer can often build networks of inverters in the same manner as he would if he were using mechanical relays or simple switches.

A

B c

FIGURE

4

FIGURE

5

Figure 4 shows three mechanical switches connected in a series to form an

"AND" circuit. All switches A and Band C must be closed in order to ground the output. Similarly, in the series inverter network of Figure 5, all transistor inputs A and Band C must be negative in order to short the output to ground. If any input in

Figure 5 is ground, that transistor will be an open circuit, and the output will be -3 volts. Therefore, the network also acts as an

"OR" circuit for ground levels.

8

If

any of the switches of Figure 6 close, the output will be shorted to ground.

If

A or B or C in Figure 7 is negative, the output will be shorted to ground. Only if all inputs are at ground will the network output be negative. The parallel arrangement in Figure 7 is an

OR gate for negative levels and an

AND gate for ground levels .

r

1

FIGURE

6

r

c

FIGURE

7

Inverters can be stacked in complicated series-parallel combinations, like that of Figure 8, to perform sophisticated logical operations. There are some rules, however, since the inverters are not quite ideal switches. These rules are discussed in the sections beginning on Page 41.

C

B

A

.-----·~-G

G

H=C+(B+A·D)·(E+F)-G

H=C' [B'(A+D)+E'F+ G]

FIGURE

8

DIODE LOGIC

All logical systems could be constructed using only parallel and series combinations of transistors in inverter networks. However, as the number of inputs to a particular gate increases, it becomes more economical to perform the gating action with diode gates. The

9

INTERIOR VIEW OF

5

MEGACYCLE LABORATORY MODULE

LABORATORY MODULE MOUNTING PANEL SHOWING POWER

CONNECTIONS AT THE BACK

10

outputs of diode gates are permanently connected to a transistor inverter which re-establishes the reference level after every gate.

Thus, DEC diode gates may be connected in tandem indefinitely.

A o - - i < l - - - - r - - I

Bo--KJ--~ c o---Ki--~

D o - - - K i - - - t

E o - - i < l - - - t

F o---t< ... ....

FIGURE

9

DEC negative diode units are six-input diodes tied to an inverter, as in Figure 9, so that anyone of the input terminals can turn on the inverter. This makes a six-input

OR circuit for negative levels or pulses because A, B, C, D, E, or F can turn on the inverter and "short circuit" its output. This, of course, also acts as an

AND circuit for ground levels.

Bo---Dl---t c o---I>I---t

Do---I>I----t

E o---Dl---t

Fo--OI-~

FIGURE

10

The positive-type diode circuit, Figure 10, provides an

AND circuit for negative levels and an

OR circuit for ground levels. This unit is available only in DEC System Modules because DEC

Laboratory Modules are usually employed in small systems and the economy resulting from the use of this type of unit is small.

11

FLIP-FLOPS

If two grounded inverters are interconnected, as in Figure 11, a bi-stable ((flip-flop" is obtained. When one side is cut off, its output is negative. This holds the other side on, which, in turn, holds the first side off.

FIGURE

11

If a grounded inverter A is connected to the off side B of the flipflop in Figure 12, the state of the flip-flop can be changed by pulsing the base of transistor A with a negative signal. This extra transistor will short the collector of transistor B to ground and will cutoff transistor C, which will turn on transistor B. The flip-flop will then stay in that state even after the signal is removed from A. input

FIGURE

12

Simple flip-flops, such as in Figure 12, can be used wherever the load on the output is light and economy is important. DEC System

Modules Types 1213 and 4213 contain circuits similar to this one.

For general applications, it is desirable to have flip-flops with very low output impedance so that they can drive many other circuits. For this reason, most DEC flip-flops have buffer amplifiers on each side of the flip-flop.

12

FIGURE

13

A simple network is placed between the flip-flop in Figure 13 and the output amplifiers, which delays the change in the output. When the flip-flop is changed with a standard pulse, this delay is long enough so that the output does not change until after the pulse is over. This allows flip-flops to be sensed while they are being pulsed, which makes shift registers, counters and adders relatively simple.

FIGURE

14

The symbol for a flip-flop is shown in Figure 14. In order to set the flip-flop to the desired state, the inputs at the bottom are

((shorted" through inverters to ground. When the input on the

ZERO side has been shorted to ground, the

ZERO output is set to the - 3 volt level and the

ONE output is at ground. This is defined as the

ZERO state. Similarly, when the flip-flop is in the

ONE state, the

ONE output is at - 3 volts and the

ZERO output is at ground .

Input

FIGURE

15

13

FIGURE

16

Level

Flip-flops are always changed by momentarily shorting an input to ground, as shown in Figure 15. The input to the inverter is a

DEC Standard Negative Pulse of 2.5 volts amplitude relative to ground.

To gate information into a flip-flop, two inverters can be connected in series, as in Figure 16. If the level input is at ground when the upper inverter is pulsed, the flip-flop terminal will not be shorted to ground; but if the level input is at -3 when the negative pulse arrives, the input is shorted and the flip-flop is cleared.

Since most DEC flip-flops have buffer amplifiers, it is permissible to use the buffer as the level gate. This added flexibility is useful since it allows reading into a flip-flop with only one inverter gate.

I4--Pulse

FIGURE

17

Figure 17 is a ~~jam transfer" gate employing DEC buffered flipflops. The contents of flip-flop A can be ~~jammed" into flip-flop B with a single pulse independent of the previous state of flip-flop B.

The outputs of A are connected directly to the emitters of the pulse gates feeding the inputs of B. Both inverter pulse gates are pulsed simultaneously, but only the gate which has ground on its emitter will pass the pulse to set the flip-flop. For example, if flip-flop A holds a

ONE, its

ZERO output terminal will be at ground, allowing the right-hand gate to pass the pulse and set flip-flop B.

FIGURE

18

The shift register of Figure 18 is another use of the jam transfer gate of Figure 17. Since the outputs of the flip-flops do not change until the shift pulse has passed, no logical delays are needed between flip-flops.

14

10

MEGACYCLE SYSTEM MODULE FLIP-FLOP

SYSTEM MODULE MOUNTING PANEL WITH UNIT EXTENDER

15

When the inverters of Figure 19 are pulsed, the state of the flipflop will be changed or ~~complemented." On some of the DEC flip-flops this gating is done internally, and a complement terminal is brought out, as in Figure 20.

L..&J~-Poise

Complement

Input

FIGURE

20

FIGURE

19

There is also a complement output terminal P which will deliver a DEC Standard Negative Pulse every time the flip-flop complement input is pulsed. This P pulse output is useful in counters and adders.

Input

Pulse

FIGURE

21

A typical counter arrangement using DEC complementing flipflops is shown in Figure 21. The pulses being counted enter on the right. They always complement flip-flop C and generate a standard pulse at P. This P pulse complements flip-flop B when flip-flop C

16

holds a

ONE.

When this P pulse gets through the gate and actually complements B, it will generate a P pulse out of B. The process is continued down the length of the counter. Only one inverter and one flip-flop are needed for each bit in the counter.

Pulse

FIGURE

22

System Module flip-flops also have direct clear and set terminals which allow flip-flop registers to be set or cleared without the use of pulse gates on each flip-flop. The input to these terminals is a

DEC Standard Positive Pulse of 2.5 volts amplitude relative to ground. These pulses can be produced by DEC delays, pulse amplifiers, clocks, and pulse generators. Figure 22 shows a register being set to 00100 using the direct inputs.

DELAYS

DEC Delay units are flip-flops which have only one stable state.

When the input terminal is

~~shorted" to ground by a Standard

Pulse, the level output terminal will switch from its normal ground level to the -3 volt level for a fixed period of time, which is adjustable. A standard pulse will be produced at the pulse output when the level output returns to its normal a volt condition. The pulse output comes from a pulse transformer which has both terminals available. To obtain a negative pulse, ground the output from the positive terminal. To obtain a positive pulse, ground the output from the negative terminal.

Level Output

Pulse

Input

Pulse Output

L-_~~+

Pulse Output

-

Input

Level Output

-

-t+t+

I'*t-

~

J

c

I

--

,U

('--I-

FIGURE

23

Typical waveforms for a delay unit are shown in Figure 23.

17

FIGURE

24

Delay units are particularly useful in generating delayed standard pulses or signals of arbitrary width. The network of delays in

Figure 24 will produce the waveform in Figure 25.

FIGURE

25

PULSE AMPLIFIERS

DEC pulse amplifiers are a powerful logical element because they not only amplify and standardize the shape of pulses but also gate pulses. When the same logical gating is to be done on a whole register of flip-flops, it often can be done once before the pulse amplifier drives the register. o"i

Pulse

0

..... A;,.;,;,m_p.....--O

+

FIGURE

26

The outputs of the pulse amplifiers come from pulse transformers, which have both terminals available so that either positive or negative pulses may be obtained, depending on which terminal is grounded. Positive pulses are used to direct set and clear flip-flops without inverters. Negative pulses are used for setting, clearing and complementing with inverters.

18

CLOCKS

DEC clocks produce standard pulses from stable, variable frequency, RC-coupled oscillators which have a wide range of frequencies available. These clocks are often used as a primary source of timing for large systems. Where very precise timing is needed, crystal clocks which contain a single-frequency crystal oscillator are available.

I

Clock

I ~

+

FIGURE

27

PULSE GENERATORS

DEC pulse generators are used to initiate action as a result of outside activity. Every time the input of these pulse generators goes more negative than -272 volts after having been more positive than -1 volt, a standard pulse is generated. Most outside actions can be converted into voltage levels that will fill this criterion.

I

H

I

:~~~e i

-~

+

~1

External

'='

SWitch

~.J

-15

FIGURE

28

It is difficult to generate a single pulse from a switch or relay closure because contacts bounce many times before they finally make a solid contact. If these are connected directly to a pulse generator, they will produce a pulse for each contact bounce. An integrating circuit is included which can be connected between the pulse generator and the contact. This circuit converts the many fast voltage changes into a single slow change, which generates a single pulse.

19

FRONT VIEW OF DEC SYSTEM MODULE MOUNTING PANEL

SHOWING STANDARD PIN CONNECTIONS

FRONT VIEW OF NEW TAPER-PIN MOUNTING PANEL WHICH PERMITS

PATCHCORDING OF SYSTEM MODULES

20

TYPICAL APPLICATIONS

COUNTERS

Building a counter with DEC flip-flops is straightforward due to the built-in delay and the availability of the P pulse terminal. A carry pulse is created when the P pulse is fed to the base of a gate which is conditioned by the
