EATON Bussmann MV fuse links
Contents
Introduction to medium voltage fuse link technology
6
How to order
8
DIN Fuse links
9
Motor fuse links
24
Auxiliary transformer fuse links
34
Oil fuse links
54
British standard air fuse links
62
US Style E-Rated fuse links
74
Fuse clips
92
Expulsion fuse links
93
ASL - Automatic Sectionalising Links
95
Boric acid fuse links
99
Cross references
106
DIN Fuse links
106
Motor fuse links
108
Voltage and auxiliary transformer fuse links 108
Oil fuse links
109
British standard air fuse links
110
US Style E-Rated fuse links
111
Boric acid fuse links
116
Time current curves and cut-off curves list
117
Index
119
EATON Bussmann MV fuse links
5
Introduction to medium voltage fuse link technology
Offering unparalleled short-circuit interruption capabilities, Medium Voltage (MV) current-limiting fuse links are
the principle protection device used by electrical utilities
and switchgear manufacturers throughout the world.
Safe, reliable, environmentally friendly and cost effective, MV Fuse
links are the protection device of choice for distribution circuits
due to their speed of operation and current limiting ability in the
event of a short-circuit fault.
The diagram below shows the operation of a fuse link interrupting a short-circuit fault, achieving a current zero well within the
first half-cycle of a fault. Energy let-through into the site of a fault
maybe typically only 1/500th of that of any other type of switching device.
The main standard covering Medium voltage (MV) fuse links is IEC
60282-1, 2009. IEC defines MV as from 1 kV to 72.5 kV.
Current-limiting MV Fuse links, split into three internationally recognised types: back-up (or sometimes called partial range), fuse
links, which will interrupt any current from their rated Breaking
capacity down to a Minimum breaking current, specified by the
manufacturer. General purpose MV Fuse links will interrupt all currents that will melt the elements within one hour. Full range MV
Fuse links can interrupt any current below the rated Breaking
capacity that melts the fuse elements satisfactorily.
The diagram below illustrates the three performance criteria in
terms of their Minimum breaking current I3.
Medium Voltage electrical fuse link performance to IEC 60282-1
RMS
amps
2
lt
Time in seconds
Back-Up
Fuse Link
Zone of uncertain protection
General Purpose
Fuse Link
Zone of uncertain
protection
Peak amps
Full Range
Fuse Link
2
l
Current (amps)
Minimum Breaking
Current (MBC) I3
Typically 1.1 x IN
Minimum fusing
current in free air
Typically 1.4 x IN
Minimum fusing
current under
DERATED conditions
Minimum Breaking
Current (MBC)
Typically 3 x IN
Minimum Breaking
Current (MBC)
Typically 1.8 x IN
Current-limiting MV Fuse links are similar in construction to Low
voltage (LV) cartridge types. Fuse elements do need to be much
longer however to safely interrupt a medium voltage short-circuit.
This is achieved by winding the elements round an internal core
or holder, often called a star-core or spider; using this technique
a one metre length element can be accommodated in a 250 mm
length body. The elements are surrounded by a pure, highly compacted granular quartz filler.
Like a LV fuse link, a MV Fuse link has a ceramic body. Most
current-limiting MV Fuse links are also fitted with a striker mechanism. This is used to operate the trip bar or mechanism in a
fuse-switch combination, fuse-switch or ring main unit (RMU) to
achieve low overload fault interruption and three-phase disconnection.
The speed of operation reduces the effect of short-circuit currents,
dramatically limiting the energy delivered to the faulted circuit, preventing the catastrophic results of high faults and disturbing voltage arcs. The fuse link operation significantly limits the arc-flash
hazard at the fault location. Improved power supply quality also
results from the use of fuse links. High fault currents are interrupted in a few milliseconds, minimising voltage dips in system
supply voltage.
6
EATON Bussmann MV fuse links
Typically striker mechanisms are driven by a spring mechanism,
triggered by a thin striker wire or striker coil running the length
of the fuse link, connected in parallel to the fuse link elements.
The striker coil is of much higher resistance than the fuse link elements, so a current only flows through the striker coil when the
fuse link elements melt. The current heats up the striker coil and
this in turn melts the wire retaining the spring, releasing it and
pushing out the striker.
Porcelain barrel
End cap
Striker coil
Striker
Porcelain
barrel
Granular
quartz
Striker
coil
Weather seal
Fuse elements
Star core
Granular quartz
Starcore
Elements
Non-current limiting
Essentially, non-current limiting fuse links have short elements
and incorporate some means of lengthening the arc after the
element melts, extinguishing the arc and preventing re-ignition.
These are known as expulsion fuse links.
Expulsion fuse links are an effective way of protecting overhead
distribution lines and transformers. They are designed for outdoor
use only and comprise a tin or copper fuse element in series with
a flexible braid in a tube. The tube forms one side of a triangle,
with a latched connection at the top and a hinge at the bottom.
The braid emerges from one end of the fuse link and is held in
tension by a spring downwards under gravity. Under fault conditions, the fuse link swings downwards, the arc is lengthened,
extinguished and prevented from restriking.
M-effect. This advantage is particularly useful when the MV
Fuse link is used in totally enclosed all insulated switchgear,
such as cast resin fuse-switches or compact SF6 insulated Ring
Main Units (RMUs), or GIS HV switchgear, since less derating is
required and hence a smaller rating of MV Fuse link will do the
same job as a higher rated MV Fuse link from another manufacturer.
In short M-effect fuse links are generally safer, give better protection and are longer lasting than alternative designs, which do not
employ these valuable features.t
GLOSSARY FOR MEDIUM VOLTAGE FUSE LINKS
Thermal effects of low overload faults
During overload faults lasting a long time, it is possible for medium voltage (MV) elements to get very hot prior to actually melting. Given that silver has a melting temperature of 960oC, for fuse
links with no temperature limitation, this can result in a fuse barrel temperature of over 400oC and 180oC at the insulating surface
surrounding the fuse. To prevent deterioration of the insulation
and to the fuse link itself, all MV Fuse links should incorporate
some form of technology to limit the thermal stress- heating, that
is possible under prolonged low overload faults, often referred to
as temperature limiting technology.
Since the launch of its first MV Fuse links almost half a century
ago, Bussmann has employed M-effect technology to achieve
temperature limitation throughout its MV Fuse link range. A small
mass of special low melting point alloy is added to each fuse element, this has the effect of drastically reducing the temperature
of the MV Fuse link during operation. The larger cross section
of the fuse link elements, made possible by use of this feature,
ensures cooler running and lower power dissipation under normal
service conditions than comparable temperature limitation technology.
Other manufacturers employ a temperature-limiting (or thermal)
striker to overcome their overheating problems. In general with
this approach the maximum temperatures reached by the fuse
link and its surrounding insulation are not as low as with the use
of M-effect. Such a solution is no more effective than use of
M-effect on the fuse link elements and moreover does not bring
the additional advantages of lower watts loss, cooler running and
greater withstand against transient surge currents.
When a Bussmann fuse link operates under low overload fault
conditions the maximum temperature rise of the fuse link is
such that the temperature of the surrounding synthetic insulation
remains below the temperature limits for all insulated fuse switchgear. The fuse barrel therefore remains intact and the fuse carrier
and its contacts remain unimpaired.
Typically a Bussmann MV Fuse link of a given rating may run
10-30oC cooler than comparable fuse links which do not employ
The following is a brief introduction to medium voltage
fuse link technology. Some of the terms are also used in
other areas of fuse technology.
Current rating/Current, In - The current of the fuse link,
given in amps.
•
Derating - A reference to the fact that all MV Fuse
links must be derated once they are placed in a confined space, for example when mounted in switchgear. The fuse link must be derated to take into
account the effect of heating on element resistance.
Typically a fuse link is derated by between 5-20%
depending on application.
•
Test Duty, TD - A term used to refer to a specific
type test within the IEC standard. Test Duty one
(TD1), short-circuit test, Test Duty two (TD2), maximum arc energy test and Test Duty three (TD3), low
overcurrent test.
•
Minimum Breaking capacity Current, MBC, I3 - The
minimum current the fuse link can interrupt safely,
without assistance from switchgear with instantaneous striker tripping.
•
Minimum Fusing Current (MFC) - The minimum current which will cause the fuse link elements to start
to melt.
•
I2T - The minimum value of pre-arcing and maximum
value of total clearing energy a fuse link will allow
to pass through it during short circuit operation,
expressed as an amount of current (I2), multiplied by
time in seconds.
•
Watts loss - The power dissipation of the fuse link at
a stated value of load current.
•
Breaking capacity, I1 - The maximum short circuit current the fuse link has been tested to in accordance
with test Duty one (TD1), expressed in kA.
•
Resistance - The resistance of the fuse link in free
air at (20oC), measured in mΩ.
EATON Bussmann MV fuse links
7
How to order
1 — Voltage
2 — Type designation letter
3 — Barrel diameter
4 — Barrel length
5 — Striker information *
6 — Tag information
* S = Spring striker 50N
* E = Spring striker 80N
* N = No striker fitted
* H or M = Pyrotechnic striker
Ordering key
Symbol
1
X
2
3
4
5
6
7
X
Meaning
Voltage of the fuse link in kV
The type of fuse link given by a single letter
Diameter of the fuse link barrel (in mm) denoted by a letter
X
X
Length of the fuse link barrel (in mm) denoted by a letter
X
Striker information: type of striker is denoted by a letter *
X
X
Tag information: type denoted by a letter
Current rating of the fuse link given in amperes
Example: 12TDLEJ50
Part numbers 12TDLEJ50 represents
an outdoor DIN Fuse rated at 12 kV
for use in Air (T) with a body diameter
of 50.8mm (D), a barrel length of
292mm (L), a striker to DIN 43625
80N (E), a tag arrangement to DIN
43625 (J) and an Amp rating of 50A.
Ordering code information
Voltage of the fuse link
Type of fuse link
Body diameter
Body length
Type of striker
Type of tag
Current rating
Complete part numbers
Type designation
12
T
D
L
E
J
12
T
D
L
E
J
50
50
Parts referencing system
2nd Letter
barrel
diameter
st
(mm)
kV 1 Letter general type
A, B, D, N = fuse links for use in air
M = 20.6
V, W = fuse links primarily for use in motor circuits B = 25.4
F = fuse links with Full range characteristics
D = 50.8
O = fuse links sealed for use in oil switches
E, H, L =
T = DIN Outdoor range
63.5
F, I, K = 76.2
X = 88
3rd Letter
barrel
length
(mm)
U = 86
W = 142
O = 192
C = 195
D = 203
F = 254
L = 292
G = 359
N = 403
M = 442
Q = 537
I = 565
K = 914
4th Letter striker (mm)
S = Striker to DIN 43625, form C 50N
E = Striker to DIN 43625, 80N
H,M = Striker to BS 2692-1
N = None fitted
5th/6th letter and or digit —
termination or fixing
A = No Tags. Ferrule diameter as the 2nd
letter
B = Offset tag, single bolt fixing
C, D = Tags to BS2692-1
F = Offset tag, double bolt fixing
J = Ferrule to DIN 43625
O = Tags to BS 2692-1
6 = Tags to BS 2692-1
22 = 5/16-BSW stud one end only
02, 03 = Double and triple barrel fuse link
F2, F3 = Double and triple barrel fuse link
Amps
A
Note: Most of these fuse types are suitable for outdoor use. A variety of alternative tag arrangements are also available, details on request from Bussmann application engineers
[email protected]
8
EATON Bussmann MV fuse links
DIN Medium voltage fuse links
Introduction to DIN Medium voltage fuse links
10
Features and benefits
11
General guide to the selection of DIN Fuse links
12
3.6 kV ‘A’ and ‘W’ Range current limiting back-up fuse links
14
7.2 kV ‘T’ Range current limiting back-up fuse links
15
12 kV ‘F’ Range current limiting full range fuse links
16
12 kV ‘A’ and ‘T’ Range current limiting back-up fuse links
17
17.5 kV ‘A’ and ‘T’ Range current limiting back-up fuse links
18
24 kV ‘F’ Range current limiting full range fuse links
20
24 kV ‘A’ and ‘T’ Range current limiting back-up fuse links
21
36 kV ‘T’ Range current limiting back-up fuse links
22
Striker force diagrams
23
EATON Bussmann MV fuse links
9
Introduction to DIN Medium voltage fuse links
•
Fuse links comply with DIN Dimensional standard DIN
43625.
•
‘F’ Range, high performance full range fuse links.
•
‘T’ Range, high performance back-up fuse links, with striker
tripping.
•
‘A’ Range, including high current rating back-up fuse link.
•
Comply with IEC 60282-1 and VDE 0670 part 4.
•
Wide variety of ratings, 3.6 kV to 36 kV.
•
‘T’ Range is suitable for outdoor use.
•
Motor circuit fuse link option, see motor fuse links section
page 24.
Bussmann ‘T’ Range
Bussmann ‘F’ Range
The Bussmann ‘T’ range medium voltage current-limiting fuse
links to dimensional standard DIN 43625, are one of the most
advanced design of medium voltage fuse links available anywhere
in the world today. Developed by Bussmann, they comply with
the very latest requirements of IEC 60282-1, are lead and cadmium free (meeting the RoHS and WEE directives) and have been
designed to meet current and future global electrical utility specifications.
The ‘F’ range fuse links have ‘full range’ clearing capability.
Bussmann ‘F’ fuse links types are designed to clear low overloads
right down to the fuse links’ Current in accordance with the latest IEC 60282-1 requirements. They are thus suitable for use as a
sole form of protection. ‘F’ range time-current characteristics are
especially advantageous for transformer protection applications.
The ‘T’ range offers time-current characteristics that are optimised
to improve discrimation with upstream devices, giving fast clearance of earth faults in secondary terminal zones. The fuse links
utilise Bussmann M-effect technology, ensuring low power consumption during operation, while at the same time providing temperature limitation in the event of an overload fault.
The fuse links are suitable for both indoor and outdoor applications and are fitted with a spring striker. This gives either an output force of 80N with a travel of 30 mm in the case of fuse links
with part numbers sequence ‘E’, or in the case of part numbers
referring to ‘S’, a spring striker with an output force of 50 N and a
maximum travel of 26 mm.
10
EATON Bussmann MV fuse links
Bussmann ‘A’ Range
This earlier, well proven, design has values of minimum breaking
current between the ‘T’ and ‘F’ range including higher current ratings.
Applications
MV DIN Fuse links are suitable for primary side transformer
protection, fuse switch combination unit, fuse bases and fuse
switches.
Features and benefits
Certification. Bussmann Medium Voltage (MV) DIN range of fuse
links has been fully tested and certified. Interrupting performance
has been certified at the world class independent test laboratories
of KEMA. All other performance requirements such as temperature-rise, time-current characteristics, weather sealing etc. have
been thoroughly tested to ASTA approval procedures.
All Bussmann medium voltage DIN Fuse links exhibit cool running and low power dissipation during normal operation in service. The use of M-effect, drastically reduces the temperature
of the fuse link during operation. The larger cross section of
the fuse link elements made possible by using M-effect ensures
cooler running and low power dissipation under normal service
conditions. This ensures maximum levels of network efficiency
by reducing unnecessary power loss and minimizing switchgear
wear and tear due to the fact the fuse link is running much cooler
during its service life.
Cool operation. When Bussmann MV Fuse links operate under
low fault conditions, the maximum temperature rise of the fuse
link is well within the temperature limits for all switchgear due to
the use of M-effect, ensuring fuse carrier contacts remain unimpaired, thereby increasing the life cycle of the substation and
so reducing capital and maintenance costs.
Silver elements. All Bussmann back-up MV Fuse links use 99.8%
pure silver in their elements, ensuring high conductivity and low
power (revenue) loss, maximising network efficiency.
Reduced nuisance operation due to surge currents. The use of
M-effect allows a larger element cross section for a given current
rating, improving withstand capability against transient overcurrents due to transformer magnetizing inrush current, reducing mal
operation. This improves system reliability reducing maintenance costs.
Low arc voltages during short-circuit operation. Bussmann
MV Fuse links are designed to produce low levels of arc voltage,
allowing fuse link to be used down to half their Voltage, so
during short-circuit operation, the switchgear and cables are not
unduly stressed by being exposed to high arc voltages, thereby
prolonging the life of the switchgear and improving asset
utilisation.
X-Ray. All Bussmann MV Fuse links are X-rayed during production. Element alignment, M-effect position, etc are all checked by
trained operators. This process ensures defects that would not
normally be detected by purely visual or electrical based quality
systems, to be captured during production.
Element design. Unlike many other medium voltage fuse link
manufacturers, Bussmann medium voltage fuse elements employ
a “neck” or ‘notch’ design principle as opposed to a perforated element design principle, see diagram below.
Bussmann - Neck or notch design
Other Medium voltage fuse links with perforated designs
This element design insures that even the smallest degree of
accidental element damage is easily detected during testing, as
part of the manufacturing process thus avoids the possibility of
such imperfect fuses being put into service. This is far more difficult to achieve with perforated element designs.
Lead and cadmium Free. All Bussmann ‘T’ Ranges fuse links are
lead and cadmium free and meet with the latest WEEE and RoHS
directives. RoHS is less than 1000 VAC.
Recycling scheme. Bussmann operates a recycling scheme for all
medium voltage fuse links, please contact
[email protected] for further information.
Additionally, stock holdings and part numbers can be reduced,
as a 24 kV Bussmann MV DIN fuse link can be used on a 12 kV
system. Utilities that run a mixed voltage network (say 24, 15.5,
13.8 12 and 10 kV) can standardise on one type of switchgear
with one type of fuse link, reducing costs and removing the
need for an additional fuse extension and inventory.
Construction. All electrical connections within the Bussmann MV
Fuse link are made by welded or brazed joints. This firstly ensures
a very mechanically robust fuse link and secondly, greatly reduces
the risk of poor intermittent internal contacts, improving substation
reliability.
EATON Bussmann MV fuse links
11
General guide to the selection of DIN Back-up fuse links
Back-up fuse links
Selection guide using low voltage fuse links operating class gG/gL on low voltage side for individual cable exit protection see figure 1.
Transformer primary voltage
Fuse links type
Back-up fuse links
10 kV
20 kV
30 kV
Transformer rating
Current of the
medium voltage fuse link
Current of the
medium voltage fuse link
Current of the
medium voltage fuse link
( kVA)
50
Min
6.3
Max
10
Min
6.3
Max
6.3
Min
3.15
Max
3.15
100
16
25
6.3
10
6.3
10
125
16
25
10
16
6.3
10
160
200
20
20
31.5
40
10
16
20
25
6.3
10
10
16
250
315
400
500
630
800
1000
1250
1600
2000
25
31.5
40
50
63
80
100
125
160
200
50
63
80
100
125
125
125
200
200
200
16
20z
20
25
31.5
40
50
63
71
100
25
31.5
40
50
63
63
80
80
125
160
10
16
16
16
20
25
31.5
40
50
63
16
16
25
31.5
40
40
50
50
63
63
Selection guide using low voltage fuse links operation class gG/gL on low voltage side for overload protection of the transformer, see figure 2.
Transformer primary voltage
Fuse links type
Back-up fuse links
10 kV
20 kV
30 kV
Transformer
rating
Current of the
medium voltage fuse link
Current of the
medium voltage fuse link
Current of the
medium voltage fuse link
Low voltage
NH Fuse size
gG/gL
( kVA)
50
100
125
160
200
250
315
400
500
630
800
1000
Min
10
16
20
25
31.5
40
50
63
80
100
125
200
Min
6.3
10
10
16
16
20
25
31.5
40
63
63
80
Min
3.15
6.3
6.3
10
16
16
16
20
25
31.5
40
50
(A)
63
125
160
200
250
315
400
500
630
800
1000
1250
Max
10
25
25
31.5
40
50
63
80
100
125
160
200
Max
6.3
10
16
20
25
25
31.5
40
50
63
63
80
Figure 2: Shows a fuse fitted
as secondary overload protection directly on the transformer
secondary output. The preferred method, the MV primary
fuse must coordinate with the
secondary overload LV fuse.
Figure 1: shows single exit
from transformer. The cable
exits the transformer and is
fed directly to the distribution
system. There is no secondary overload fuse protection.
So the MV primary fuse must
coordinate with the largest
fuse within the distribution
panel.
Figure 1 Individual cable exit
protection
12
EATON Bussmann MV fuse links
Max
3.15
10
10
10
16
16
20
25
31.5
40
40
50
Figure 2 Overload protection of
the transformer
General guide to the selection of DIN Full range fuse links
Full range fuse links
Transformer primary voltage
Selection guide using low voltage fuse links operating class
gG/gL on low voltage side for
individual cable exit protection,
see figure 1 opposite page.
Selection guide using low
voltage fuse links operating
class gG/gL on low voltage
side for overload protection
of the transformer, see figure 2 opposite page
Fuse links type
Full range fuse links
10 kV
20 kV
Transformer
rating
( kVA)
50
Current of the
medium voltage fuse link
Min
Max
6.3
10
Current of the
medium voltage fuse link
Min
Max
6.3
6.3
100
10
20
6.3
10
125
160
16
16
25
31.5
6.3
10
16
16
200
20
40
10
20
250
315
400
500
25
31.5
40
50
50
63
80
100
16
16
20
25
25
31.5
40
45
630
800
1000
63
80
100
100
100
100
31.5
40
45
45
45
45
Transformer primary voltage
Fuse links Type
Full range Fuse links
Transformer
Rating
( kVA)
50
100
125
160
200
250
315
400
500
630
800
10 kV
20 kV
Current of the
medium voltage fuse link
Min
Max
6.3
6.3
10
10
16
16
16
20
20
31.5
31.5
40
40
40
40
63
50
63
100
100
100
100
Current of the
medium voltage fuse link
Min
Max
6.3
6.3
10
10
10
10
16
16
16
16
16
20
20
20
25
31.5
31.5
40
40
45
-
Low voltage
NH Fuse size
gG/gL
(A)
80
125
160
200
250
315
400
500
630
800
1000
Selection of these MV Fuse links has been based on the followings:
1. The fuse link should withstand transformer magnetising inrush currents, taken as 12
times full load current for 0.1 seconds.
2. The primary MV Fuse link should discrimate with the secondary LV Fuse in all cases as
shown in figure 2.
Where individual cable exit is used and no secondary LV Fuse is fitted, the MV Fuse
should discriminate with the largest fuse fitted downstream to the secondary side of
the transformer at the distribution panel.
3. The fuse link should operate within two seconds for transformers complying with IEC
60076-5 in respect of impedance, voltage and short-circuit withstand current.
4. The fuse link should operate reasonably quickly in the event of a transformer internal
fault or an earth fault in the secondary terminal zone of the transformer.
5. In the case where there is no secondary fuse link for overload protection, the minimum
recommended MV Fuse link rating applies to the use of fuse links in encapsulated
enclosures where permissible continuous overload is generally limited to 120% of
transformer full load current. However, if greater overload currents are permissible, a
higher rating of fuse link may be required. Where the fuse link is used in open air or
conditions of unrestricted ventilation a higher permissible overload may be possible.
6. In most cases more than one rating of MV Fuse link is recommended for a particular
transformer size. Choice of fuse link will then depend on which fuse link offers the best
protection; e.g., having one fuse link for several transformer sizes.
Recommendations for other voltage are available on request, please email [email protected]
com.
EATON Bussmann MV fuse links
13
3.6 kV - ‘A & W’ Range current limiting back-up fuse links
Typical applications
Specifications
Description
A range of medium voltage DIN Fuse links, complete with striker,
suitable for transformer protection. The fuse links can be used
even when there is no secondary low voltage protection, provided
they are used with fuse switches fitted with instantaneous striker
tripping mechanism.
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Ratings
Voltage: 3.6 kV
Current: 6.3 - 200 A
Breaking capacity: 40 - 50 kA.
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670 part
4 and with IEC 60282-1 (2005).
Suitable for indoor use.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse reference
A
C
D
Weight (Kg)
ADLSJ
ADOSJ
WDOSJ
WFOSJ
292
192
192
192
54
54
54
76
51
51
51
76
1.63
1.1
1.1
2.1
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking
capacity I1 kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
3.6ADLSJ6.3
6.3
40
13
158
9
4.5 x 101
1.9 x 102
292
51
1.63
3.6ADLSJ10
10
40
13
95.6
13
1.3 x 10
5.4 x 102
292
51
1.63
3.6ADLSJ16
16
40
20
63.3
22
3 x 102
1.3 x 103
292
51
1.63
3.6ADLSJ20
20
40
31
45.9
25
6.3 x 102
2.7 x 103
292
51
1.63
3.6ADLSJ25
25
40
106
28.7
25
1.3 x 102
1.2 x 103
292
51
1.63
3.6ADLSJ31.5
31.5
40
106
19.1
26
2.9 x 102
2.7 x 103
292
51
1.63
3.6ADLSJ40
40
40
106
11.4
25
8 x 102
7.5 x 10
292
51
1.63
3.6ADOSJ6.3
6.3
40
13
158
9
4.5 x 101
1.9 x 102
192
51
1.1
3.6ADOSJ10
10
40
31
79.2
11
2.3 x 10
2
9.7 x 102
192
51
1.1
3.6ADOSJ16
16
40
49
50.8
18
5.5 x 102
2.4 x 103
192
51
1.1
3.6ADOSJ20
20
40
49
38.1
21
9.8 x 102
4.2 x 103
192
51
1.1
3.6ADOSJ25
25
40
106
28.9
25
1.3 x 102
1.2 x 103
192
51
1.1
3.6ADOSJ31.5
31.5
40
106
19.2
26
2.9 x 102
2.7 x 103
192
51
1.1
3.6ADOSJ40
40
40
106
11.6
26
8 x 102
7.5 x 103
192
51
1.1
3.6WDOSJ50
50
50
180
5.36
20
1.8 x 103
2.4 x 104
192
51
1.1
3.6WDOSJ63
63
50
225
3.68
21
3.8 x 103
4.5 x 104
192
51
1.1
3.6WDOSJ80
80
50
288
2.88
27
6.3 x 103
8 x 104
192
51
1.1
3.6WDOSJ100
100
50
360
2.16
31
9.8 x 103
1.1 x 105
192
51
1.1
3.6WDOSJ125
125
50
450
1.73
39
1.5 x 104
2.2 x 105
192
51
1.1
3.6WFOSJ160
160
50
600
1.28
47
3.1 x 104
6.2 x 105
192
76
2.1
3.6WFOSJ200
200
50
600
0.94
52
5.7 x 104
1.1 x 106
192
76
2.1
14
EATON Bussmann MV fuse links
2
7.2 kV - ‘T’ Range current limiting back-up fuse links
Specifications
Description
A range of medium voltage DIN Fuse links complete with striker,
suitable for transformer protection. The fuses can be used even
when there is no secondary low voltage protection, provided they
are used with fuse switches fitted with instantaneous striker tripping.
Ratings
Voltage: 3 - 7.2 kV
Current: 6.3 - 160 A
Breaking capacity: 40 kA
Dimensions - mm
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670 part
4 and with IEC 60282-1 (2005). Suitable for indoor and outdoor
use.
Fuse reference
TDLSJ
TFLSJ
A
292
292
C
54
80
D
51
76
Weight (Kg)
1.63
3.1
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity Minimum breaking
I1 ( kA)
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2TDLSJ6.3
7.2TDLSJ10
7.2TDLSJ16
6.3
10
16
40
40
40
20
31
49
205
99.7
65.1
11
19
23
4.8 x 101
2.5 x 102
5.5 x 102
6.5 x 103
2.7 x 103
292
292
51
51
1.63
1.63
8.2 x 103
292
51
1.63
7.2TDLSJ20
20
40
49
48.9
27
9.7 x 102
1.1 x 104
292
51
1.63
7.2TDLSJ25
25
40
80
32.6
28
5.7 x 102
8 x 103
292
51
1.63
7.2TDLSJ31.5
31.5
40
100
26
36
8.9 x 102
1 x 104
292
51
1.63
7.2TDLSJ40
40
40
114
16
36
2 x 103
2.2 x 104
292
51
1.63
7.2TDLSJ50
50
40
143
12.9
46
3.2 x 103
3.2 x 104
292
51
1.63
7.2TDLSJ63
63
40
180
8.14
45
8 x 103
7.5 x 104
292
51
1.63
7.2TFLSJ80
7.2TFLSJ100
7.2TFLSJ125
80
100
125
40
40
40
264
338
375
61
4.65
3.60
54
64
79
5 x 103
9.1 x 103
1.5 x 104
6.5 x 104
1.1 x 105
292
292
76
76
3.1
3.1
1.7 x 105
292
76
3.1
7.2TFLSJ160
160
40
525
2.73
97
3 x 10
3.1 x 105
292
76
3.1
4
EATON Bussmann MV fuse links
15
12 kV - ‘F’ Range current limiting full range fuse links
Typical applications
Specifications
Description
A range of medium voltage DIN Fuse links, complete with sealed
striker, suitable for transformer protection. Bussmann ‘F’ range
provide full range protection.
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases without instantaneous striker tripping.
•
Used in fuse switches.
Ratings
Voltage: 12 kV
Current: 6.3 - 100 A.
Breaking capacity: 50 kA.
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670 part
4, VDE 0670 part 402 and with IEC 60282-1 (2005). Suitable for
indoor use.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Our full range MV Fuse links can interrupt any current below
the rated breaking capacity.
Fuse reference
FDLSJ
FFLSJ
FXLSJ
A
292
292
292
C
54
80
92
D
51
76
88
Maximum
operating
Length
mm
Weight (Kg)
1.63
3.16
4
Part numbers and technical data
Part numbers
Current
In (A)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
Cold resistance & watts
loss in free air
Joule integral (I2t)
mΩ
Minimum
pre-arcing
W
Diameter
mm
Weight
kg
12FDLSJ6.3
12FDLSJ10
12FDLSJ16
12FDLSJ20
6.3
10
16
20
50
50
50
50
6.3
10
16
20
208
116
55.4
39.6
10
15
17
20
6.9 x 101
2.2 x 102
8.8 x 102
1.7 x 103
6.3 x 102
2.1 x 103
3.9 x 103
292
292
292
51
51
51
1.63
1.63
1.63
7.6 x 103
292
51
1.63
12FDLSJ25
12FDLSJ31.5
25
31.5
50
50
25
31.5
31.2
26.4
26
36
2.8 x 103
2.6 x 103
1.3 x 104
1.3 x 104
292
292
51
51
1.63
1.63
12FFLSJ40
12FFLSJ50
12FFLSJ63
40
50
63
50
50
50
40
50
63
19.7
14.8
12.4
42
51
72
3.8 x 103
6.8 x 103
5.1 x 103
3.8 x 104
5.6 x 104
5.4 x 104
292
292
292
76.2
76.2
76.2
3.16
3.16
3.16
12FXLSJ80
12FXLSJ100
80
100
50
50
80
100
7.94
5.64
72
82
2.2 x 104
4.2 x 104
1.1 x 105
2 x 105
292
292
88
88
4
4
16
EATON Bussmann MV fuse links
12 kV - ‘A’ and ‘T’ Range current limiting back-up range fuse links
Specifications
Description
A range of medium voltage DIN Fuse links, complete with sealed
striker, suitable for transformer protection. The fuse links can be
used even when there is no secondary low voltage protection,
provided they are used with fuse switches fitted with instantaneous striker tripping.
Ratings
Voltage: 6 - 12 kV
Current: 6.3 - 200 A
Breaking capacity: 50 - 63 kA
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670 part
4, VDE 0670 part 402 and with IEC 60282-1 (2005). Suitable for
indoor and outdoor use.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation, thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our high voltage fuse links are X-rayed ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection
•
Used in fuse switch combination unit
•
Used in fuse bases
•
Used in fuse switches.
Dimensions - mm
Fuse reference
AILSJ
TDLEJ
THLEJ
TKLEJ
TXLEJ
THMEJ
TFMSJ
A
292
292
292
292
292
442
442
C
79
54
67
80
88
67
80
D
76
51
64
76
88
64
76
Weight (Kg)
3.3
1.7
2.6
3.5
3.7
3.7
5.1
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity Minimum breaking
I1 ( kA)
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
12TDLEJ6.3
6.3
63
23
222
10
9.8 x 101
1 x 103
292
51
1.7
12TDLEJ10
12TDLEJ16
12TDLEJ20
10
16
20
63
63
63
35
53
73
131
54.6
39.1
16
16
18
2.8 x 10
2.6 x 102
5.2 x 102
2.3 x 103
3.9 x 103
292
292
51
51
1.7
1.7
5.4 x 103
292
51
1.7
12TDLEJ25
25
63
87
31.2
24
8.1 x 102
8.4 x 103
292
51
1.7
12TDLEJ31.5
31.5
63
111
23.4
28
1.4 x 103
1.5 x 104
292
51
1.7
12TDLEJ40
40
63
143
17.2
36
2.4 x 103
2.5 x 104
292
51
1.7
12TDLEJ50
50
63
168
13.5
47
2.8 x 103
3.1 x 104
292
51
1.7
12TDLEJ63
63
63
235
10.6
60
4.3 x 103
4.7 x 104
292
51
1.7
12THLEJ80
80
63
272
7.81
72
7.9 x 103
9.1 x 104
292
64
2.6
12THLEJ100
12AILSJ100*
12TKLEJ125
100
100
125
63
31.5
63
388
176
687
5.74
53
3.99
85
70
93
2 x 104
1.4 x 104
4 x 104
1.4 x 105
2 x 105
292
292
64
76
2.6
3.3
3.5 x 105
292
76
3.5
12TXLEJ160**
160
63
560
4.3
217
1.1 x 105
5 x 105
292
88
3.7
12TXLEJ200**
12THMEJ100
200
100
63
63
610
272
3.8
5.74
333
85
1.5 x 105
2 x 104
6.5 x 105
1.4 x 105
292
442
88
64
3.7
3.7
12TFMSJ160
160
50
485
3.65
139
5 x 104
3.5 x 105
442
76
5.1
2
* Not suitable for outdoor use / ** Not compliant with VDE 0670 part 402
EATON Bussmann MV fuse links
17
17.5 kV - ‘A’ and ‘T’ Range current limiting back-up range fuse links
Specifications
Description
A range of medium voltage DIN Fuse links, complete with sealed
striker, suitable for transformer protection. The fuse links can be
used even when there is no secondary low voltage protection,
provided they are used with fuse switches fitted with instantaneous striker tripping.
Ratings
EJ Fuses
Voltage: 10 - 17.5 kV
Current: 6.3 - 125 A
Breaking capacity: 20 - 50 kA
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670 part
4, VDE 0670 part 402 and with IEC 60282-1 (2005).
‘A’ range is suitable for indoor use.
SJ Fuses
‘T’ range is suitable for indoor and outdoor use .
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our high voltage fuse links are X-rayed ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection
•
Used in fuse switch combination unit
•
Used in fuse bases
•
Used in fuse switches.
18
EATON Bussmann MV fuse links
Dimensions - mm
Fuse reference
AILSJ
AIMSJ
TDLSJ
TFLSJ
TDMEJ
THMEJ
TKMEJ
A
442
442
292
292
442
442
442
C
79
79
54
80
54
67
80
D
76
76
51
76
51
64
76
Weight (Kg)
4.5
4.5
1.7
3.1
2.5
3.7
5.1
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
17.5AILSJ40*
17.5AILSJ50*
17.5AILSJ63*
100
50
63
25
20
20
176
137
125
7.33
29.5
23.6
102
102
130
1.4 x 104
1.8 x 103
3.2 x 103
2 x 105
2.9 x 104
4.5 x 104
442
442
442
76
76
76
4.5
4.5
4.5
17.5AIMSJ100*
71
20
176
15.1
106
6.3 x 103
8.5 x 104
442
76
4.5
17.5TDLSJ6.3*
17.5TDLSJ10*
6.3
10
35.5
35.5
23
19
313
185
15
23
4.8 x 101
2.8 x 102
6.1 x 102
4 x 103
292
292
51
51
1.7
1.7
17.5TDLSJ16*
16
35.5
59
104
34
2.9 x 102
2 x 103
292
51
1.7
17.5TDLSJ20*
20
35.5
80
69.2
38
2
5.7 x 10
4.4 x 103
292
51
1.7
17.5TDLSJ25*
25
35.5
100
55.4
48
8.9 x 102
6.6 x 103
292
51
1.7
17.5TDLSJ31.5* 31.5
17.5TDLSJ40*
40
35.5
35.5
118
148
41.4
31.1
58
76
5.1 x 102
8 x 102
1.1 x 104
1.8 x 104
292
292
51
51
1.7
1.7
17.5TFLSJ50*
50
35.5
225
17.3
62
8.1 x 103
6 x 104
292
76
3.1
17.5TDMEJ6.3
17.5TDMEJ10
17.5TDMEJ16
6.3
10
16
50
50
50
25
36
55
324
192
79.6
14
24
23
9.8 x 10
2.8 x 102
2.6 X 102
1 x 103
2.3 x 103
442
442
51
51
2.5
2.5
3.9 x 103
442
51
2.5
17.5TDMEJ20
20
50
69
57
27
5.2 x 102
5.4 x 103
442
51
2.5
17.5TDMEJ25
25
50
87
45.5
34
8.1 x 102
8.4 x 103
442
51
2.5
17.5TDMEJ31.5
31.5
50
87
34.1
41
1.4 x 103
1.5 x 104
442
51
2.5
17.5TDMEJ40
40
50
111
25
53
2.4 x 103
2.5 x 104
442
51
2.5
17.5TDMEJ50
17.5TDMEJ63
50
63
50
50
174
200
19.7
15.4
69
89
2.8 x 103
4.3 x 103
3.1 x 104
4.7 x 104
442
442
51
51
2.5
2.5
17.5THMEJ80
17.5THMEJ100
80
100
50
50
270
376
11.5
8.38
108
127
7.9 x 103
2 x 104
9.1 x 104
1.4 x 105
442
442
64
64
3.7
3.7
17.5TKMEJ125
125
50
467
5.95
146
3.4 x 104
3.5 x 105
442
76
5.1
1
* Not suitable for outdoor use
** Not compliant with VDE 0670 part 402
EATON Bussmann MV fuse links
19
24 kV - ‘F’ Range current limiting full range fuse links
Specifications
Description
A range of medium voltage DIN Fuse links, complete with
sealed striker, suitable for transformer protection. Bussmann
‘F’ range provide Full range protection.
Ratings
Voltage: 24 kV
Current: 6.3 - 45 A
Breaking capacity: 35.5 kA
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE
0670 part 4, VDE 0670 part 402 and with IEC 60282-1 (2005).
Suitable for indoor use.
Dimensions - mm
Time-current curves and cut-off curves
Fuse reference
A
C
D
Weight (Kg)
See list page 117 and data on USB at the back of the catalogue.
FDMSJ
FFMSJ
442
442
54
67
51
76
2.2
4.5
Features and benefits
•
Cool running, low watts loss and power dissipation thanks
to the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our high voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Our full range of MV Fuse links can interrupt any current
below the rated breaking capacity.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases without instantaneous striker tripping.
•
Used in fuse switches.
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
24FDMSJ6.3
24FDMSJ10
24FDMSJ16
24FDMSJ20
6.3
10
16
20
35.5
35.5
35.5
35.5
6.3
10
16
20
437
218
118
82.2
21
29
39
43
6.8 x 101
2.7 x 102
8.2 x 102
1.6 x 103
5.4 x 102
442
51
2.2
2.1 x 103
2.7 x 103
442
442
51
51
2.2
2.2
5.1 x 103
442
51
2.2
24FDMSJ25
25
35.5
25
54.7
48
3
3.4 x 10
1.2 x 104
442
51
2.2
24FDMSJ31.5
31.5
35.5
31.5
48.6
71
3.2 x 103
1.2 x 104
442
51
2.2
24FFMSJ25
25
35.5
25
58.6
47
3.4 x 103
1.1 x 104
442
76.2
4.5
24FFMSJ31.5
31.5
35.5
31.5
48.8
70
4.7 x 103
1.5 x 104
442
76.2
4.5
24FFMSJ40
40
35.5
40
38.4
85
7.6 x 103
2.5 x 104
442
76.2
4.5
24FFMSJ45
45
35.5
45
31.4
92
7.2 x 103
3 x 104
442
76.2
4.5
20
EATON Bussmann MV fuse links
24 kV - ‘A’ and ‘T’ Range current limiting back-up fuse links
Specifications
Description
A range of medium voltage DIN Fuse links, complete with sealed
striker, suitable for transformer protection. The fuse links can be
used even when there is no secondary low voltage protection,
provided they are used with fuse switches fitted with instantaneous striker tripping.
Ratings
Voltage: 12 - 24 kV
Current: 6.3 - 160 A
Breaking capacity: 20 - 63 kA
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE 0670
part 4, VDE 0670 part 402 and with IEC 60282-1 (2005).
‘A’ range is suitable for indoor use.
‘T’ range is suitable for indoor and outdoor use.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Fuse reference
AFMSJ
AIMSJ
TDMEJ
THMEJ
TFMEJ
TXMEJ
A
442
442
442
442
442
442
C
79
79
54
67
80
91
D
76
76
51
64
76
88
Weight (Kg)
4.5
4.5
2.5
3.7
5.1
5.9
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
Part numbers
Current
In (A)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
24AFMSJ50
50
20
137
29.5
102
1.8 x 103
2.9 x 104
442
76
4.5
24AFMSJ63
63
20
125
23.6
130
3.2 x 103
4.5 x 104
442
76
4.5
24AIMSJ71
71
20
176
15.1
106
6.3 x 103
8.5 x 104
442
76
4.5
24TDMEJ6.3
6.3
50
23
444
20
9.8 x 101
1 x 103
442
51
2.5
24TDMEJ10
10
50
34
262
32
2.8 x 102
2.3 x 103
442
51
2.5
24TDMEJ16
16
50
56
109
34
2.6 x 102
3.9 x 103
442
51
2.5
24TDMEJ20
20
50
73
78.2
38
5.2 x 102
5.4 x 103
442
51
2.5
24TDMEJ25
24TDMEJ31.5
24TDMEJ40
25
31.5
40
50
50
50
92
92
118
62.4
46.8
34.3
49
59
79
8.1 x 102
1.4 x 103
2.4 x 103
8.4 x 103
1.5 x 104
442
442
51
51
2.5
2.5
2.5 x 104
442
51
2.5
24TDMEJ50
50
50
185
27
98
2.8 x 103
3.1 x 104
442
51
2.5
24THMEJ63
63
50
217
21.1
127
4.3 x 103
4.7 x 104
442
64
3.7
24TFMEJ80
80
50
265
15.7
153
7.9 x 103
9.1 x 104
442
76
5.1
24TFMEJ100**
100
63
430
18
400
2.8 x 104
9.4 x 104
442
76
5.1
24TXMEJ125**
125
40
760
11
340
9.7 x 104
3.5 x 105
442
88
5.9
24TXMEJ160**
160
31.5
900
9.60
515
1.3 x 105
5 x 105
442
88
5.9
* Not suitable for outdoor use
** Not compliant with VDE 0670 part 402
EATON Bussmann MV fuse links
21
36 kV - ‘T’ Range current limiting back-up fuse links
Specifications
Description
A range of medium voltage DIN Fuse links, complete with
sealed striker, suitable for transformer protection. The fuse
links can be used even when there is no secondary low voltage protection, provided they are used with fuse switches
fitted with instantaneous striker tripping.
EJ Fuses
Ratings
Voltage: 18 - 36 kV
Current: 3.15 - 63 A
Breaking capacity: 20 - 35.5 kA
Agency information
Comply with DIN Dimensional standard DIN 43625, VDE
0670 part 4, VDE 0670 part 402 and with IEC 60282-1 (2005).
Suitable for indoor and outdoor use.
SJ Fuses
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks
to the M-effect ensuring high levels of substation utilisation.
Dimensions - mm
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse reference
TDQSJ
TFQSJ
TXQEJ
A
537
537
537
C
54
80
88
D
51
76
88
Weight (Kg)
2.9
6
6.5
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
36TDQSJ3.15
36TDQSJ6.3
36TDQSJ10
3.15
6.3
10
20
35.5
35.5
23
23
35
1455
684
402
18
34
44
2 x 101
1 x 102
3.1 x 102
2.4 x 102
1.2 x 103
537
537
51
51
2.9
2.9
3.6 x 103
537
51
2.9
36TDQSJ16
16
35.5
70
165
52
4.6 x 102
5.1 x 103
537
51
2.9
36TDQSJ20
20
35.5
98
117
62
8.9 x 102
8.2 x 104
537
51
2.9
36TDQSJ25
25
35.5
112
98
85
1.2 x 103
1.5 x 104
537
51
2.9
36TFQSJ31.5
31.5
35.5
116
73.4
96
2.1 x 103
2.3 x 104
537
51
6
36TFQSJ40
40
35.5
178
52.4
116
4.1 x 103
3.9 x 104
537
76
6
36TFQSJ50
50
35.5
255
36.8
133
8.3 x 103
8.1 x 104
537
76
6
36TXQEJ63*
63
20
360
35
271
1.1 x 104
6.2 x 104
537
88
6.5
** Not compliant with VDE 0670 part 402
22
EATON Bussmann MV fuse links
Striker force diagrams
E = Spring striker 80N to DIN IEC 60282-1 Designation ‘Medium’
Force x Travel diagram for 50N DIN striker
60
50
Force (N)
40
30
20
10
0
0
4
8
12
16
20
24
28
32
Travel (mm)
S = Spring striker 50N to DIN 43625 and IEC 60282-1 Designation ‘Medium’
Force x Travel diagram for 80N DIN striker
100
90
80
70
Force (N)
60
50
40
30
20
10
0
0
4
8
12
16
20
24
28
32
36
Travel (mm)
EATON Bussmann MV fuse links
23
Medium voltage motor fuse links
Introduction to motor fuse links
25
British standard
3.6 kV
26
7.2 kV
28
12 kV
29
3.6 kV
30
7.2 kV
31
2.75 kV
32
5.5 kV
33
DIN
USA
24
EATON Bussmann MV fuse links
Introduction to medium voltage motor fuse links
•
Motor fuse Links comply with IEC 60282-1, IEC 644 and
BS 5907.
•
Available in DIN 43625 and BS 2692 dimensions.
•
•
Sold in a wide range of ratings from:
∙
3.6 kV - 5 to 450 A
∙
7.2 kV - 5 to 355 A
North American dimensioned products also available, 2R to
24R ratings.
Bussmann motor fuse links
Bussmann range of motor fuse links are designed to meet the
specific requirements necessary for motor protection. During
the starting cycle of direct on-line motors, the fuse elements
will reach a considerably higher temperature than during normal
operation; this is due to the high amount of current the motor will
draw as it starts, typically, 6 times its normal load current value.
This results in expansion and contraction of the fuse elements
and could cause premature operation of the fuse link. Bussmann
motor fuse links encompass an advanced design to minimise this
effect. This therefore, negates the need to over specify the fuse
rating due to high values of motor starting current.
Bussmann fuse links operate extremely quickly under heavy fault
currents, resulting from the time-current characteristic. Low power
dissipation ensures low temperature rise, important in multi-tier
starters for example. Switching (Arc) voltages are lower than permitted values, therefore, 5.5 kV fuse links are also suitable for 4.8
kV and 2.4 kV circuits.
Application
Fuse links provide short-circuit protection in motor circuits to
both the motor starter and cables from the starter to the motor.
Overload protection is provided by the motor starter, generally by
an overload relay and contactor. Combination striker tripping may
also form part of the associated equipment which houses the fuse
links and motor starters.
Application procedure
For any motor the fuse current rating is determined by magnitude
and duration of starting current, except in a few situations where
the starting currents are very light.
Direct-on-line starting
In the absence of specific information, the starting current can
usually be taken to be six times the motor’s full load current.
The starting time will depend on the type of the drive but will be
approximately as follows:
•
Pump motors - 6 seconds
•
Mill motors - 10 to 15 seconds
•
Fan motors - 60 seconds
These are average values and the appropriate figures for starting
current and starting time for actual installation should be obtained
wherever possible.
Multiply the starting current by 1.7 and using this value of current
and the starting time, (it is recommended that a minimum time
of five seconds be adopted), plot this point on the time-current
characteristics of the fuse link. The correct current rating of the
fuse link is then chosen as being the one immediately to the right
of the point plotted. The chosen fuse link must also have a current
rating of at least 1.3 times the full load current of the associated
motor.
The rating chosen will be adequate for normal applications where
the associated motor is not started more than twice in a given
period of one hour.
For applications using more frequent starting duties, a greater
derating factor must be applied as shown below:
•
Maximum 2 starts per hour - Derating factor 1.7
•
Maximum 4 starts per hour - Derating factor 1.9
•
Maximum 8 starts per hour - Derating factor 2.1
•
Maximum 16 starts per hour - Derating factor 2.4
Assisted starting
A similar method of fuse selection may be used as for direct-online starting (see above), but it must be noted that the normal
running current of the motor is likely to be closer in value to the
nominal current rating of the fuse link than for direct-on-line applications.
The rating of fuse link chosen will need to be appreciably greater
than the motor running current to allow for restricted cooling
inside control gear cubicles, particularly where multi-tier starters are involved. For further guidance please contact Bussmann:
[email protected]
Notes
For applications involving more frequent starting duties than 16
times per hour or where unusual duty cycles are involved, consult
Bussmann application engineers for advice:
[email protected] or 00 44 (0) 1509 882 699.
EATON Bussmann MV fuse links
25
3.6 kV - Motor fuse links to British standard dimensions
Specifications
Description
Motor fuse links providing short circuit protection in motor circuits
to both the motor starter and cables from the starter to the motor.
Ratings
Features and benefits
Voltage: 3.6 kV
Current: 5 - 450 A
Breaking capacity: 50 kA
•
Cool running, low watts loss and power dissipation thanks
to the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained
•
Allows motor start current to pass on without degradation
of fuse link
Agency information
BS 2692-1
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Typical applications
•
Motor protection
Dimensions - mm
Tag type ‘6’ - BS 2692 Standard
Fuse link Type
+WJON6
WDO*H6
WFO*H6
A
257
261
261
Tag type ‘O’ - BS 2692 Standard
B
235
235
235
C
192
192
192
D
36
51
76
E
9.5
10.5
10.5
F
13
13
20
G
25
25
64
H
23
29
42
J
2.4
2.6
2.6
Fuse link Type
WDFHO
WFFHO
WKFHO
WFGHO
WKGHO
A
337
337
337
442
442
B
305
305
305
410
410
C
254
254
254
359
359
D
51
76
76
76
76
Tag type ‘0’
Tag type ‘6’
Triple barrel fuse link (3rd barrel shown dotted) with 03 tags.
Double barrel fuse link with 02 tags shown in full line.
26
EATON Bussmann MV fuse links
Part numbers and technical data
Part numbers
Current
In (A)
Cold resistance & watts
loss in free air
Joule integral (I2t)
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
Tag type ‘6’ - BS 2692 Standard
3.6WJON65
5
50
13
148
5
2 x 101
1.6 x 103
192
35
0.54
3.6WJON66.3
6.3
50
24
56.3
8
1.6 x 102
1.3 x 103
192
35
0.54
3.6WJON610
10
50
24
56.3
8
1.6 x 102
1.3 x 103
192
35
0.54
3.6WJON616
16
50
56
33.1
12
1.7 x 102
1.4 x 103
192
35
0.54
3.6WJON620
20
50
56
22.1
12
3.9 x 102
3.2 x 103
192
35
0.54
3.6WJON625
25
50
70
17.7
15
6.1 x 102
4.9 x 103
192
35
0.54
3.6WJON631.5
31.5
50
112
10.1
14
1.2 x 103
9.8 x 103
192
35
0.54
3.6WJON640
40
50
112
7.54
17
2.1 x 103
1.7 x 104
192
35
0.54
3.6WJON650
3.6WDOH650
3.6WDOH663
50
50
63
50
50
50
140
180
225
63
5.36
3.68
21
20
21
3.2 x 103
1.8 x 103
3.8 x 103
2.6 x 104
2.4 x 104
192
192
35
51
0.54
1.1
4.5 x 104
192
51
1.1
3.6WDOH680
80
50
288
2.88
27
6.3 x 10
8 x 104
192
51
1.1
3.6WDOH6100
100
50
360
2.16
31
9.8 x 103
1.1 x 105
192
51
1.1
3.6WDOH6125
125
50
450
1.73
39
1.5 x 104
2.2 x 105
192
51
1.1
3.6WFOH6160
160
50
600
1.28
47
3.1 x 104
6.2 x 105
192
76
2.1
3.6WFOH6200
200
50
600
0.94
52
5.7 x 104
1.1 x 106
192
76
2.1
3
Tag type ‘O’ - BS 2692 Standard
3.6WDFHO50
3.6WDFHO63
50
63
50
50
152
171
6.61
53
21
28
1.8 x 103
3.1 x 103
2.4 x 104
254
51
1.46
4.5 x 104
254
51
1.46
3.6WDFHO80
80
50
190
3.52
31
6.3 x 103
8 x 104
254
51
1.46
3.6WDFHO100
3.6WDFHO125
3.6WFFHO160
100
125
160
50
50
50
190
190
300
2.87
2.44
1.53
39
53
54
9.5 x 103
1.3 x 104
3.4 x 104
1.2 x 105
1.8 x 105
254
254
51
51
1.46
1.46
4.1 x 105
254
76
3.2
3.6WFFHO200
200
50
300
1.24
67
4
5.1 x 10
7.2 x 105
254
76
3.2
3.6WKFHO250
250
50
520
0.65
57
1.8 x 105
2.4 x 106
254
76
3.2
3.6WKFHO315
315
50
650
0.44
60
4.1 x 105
5 x 106
254
76
3.2
3.6WKFHO355
355
50
820
0.35
59
6.4 x 105
7 x 106
254
76
3.2
3.6WKFHO400
400
50
820
0.35
76
6.4 x 105
7 x 106
254
76
3.2
3.6WKFGHO31.5
3.6WFGHO40
3.6WFGHO50
31.5
40
50
50
50
50
151
151
151
18.4
13.9
9.24
25
31
32
4.5 x 102
8 x 102
1.8 x 103
6 x 103
1.2 x 104
359
359
76
76
4.1
4.1
2.2 x 104
359
76
4.1
3.6WFGHO63
63
50
151
6.93
38
3.2 x 103
4.5 x 104
359
76
4.1
3.6WFGHO80
80
50
170
5.47
48
5.1 x 103
7.5 x 104
359
76
4.1
3.6WFGHO100
100
50
212
4.40
62
7.9 x 103
1.2 x 105
359
76
4.1
3.6WFGHO125
125
50
212
3.60
79
1.2 x 104
1.7 x 105
359
76
4.1
3.6WFGHO160
160
50
300
2.16
75
3.4 x 104
4.2 x 105
359
76
4.1
3.6WFGHO200
3.6WFGHO250
3.6WKGHO315
200
250
315
50
50
50
300
500
852
1.77
1.13
0.65
95
96
89
5.1 x 104
1.3 x 105
4.5 x 105
7 x 105
1.9 x 106
359
359
76
76
4.1
4.1
6 x 106
359
76
3.9
3.6WKGHO355
355
50
852
0.51
90
5
6.4 x 10
8.5 x 106
359
76
3.9
3.6WKGHO400
400
50
960
0.45
100
8.2 x 105
1.1 x 107
359
76
3.9
3.6WKGHO450
450
50
1150
0.38
108
1.2 x 106
1.5 x 107
359
76
3.9
Higher ratings than those listed above can be obtained by using fuse links connected in parralel.
Special fixing arrangements for connecting up to three fuse links in parallel are available. Please
contact Bussmann application engineers [email protected] for more details. The code
designations for these arrangements are given in “How to order” page 8.
EATON Bussmann MV fuse links
27
7.2 kV - Motor fuse links to British standard dimensions
Specifications
Description
Motor fuse links providing short circuit protection in motor
circuits to both the motor starter and cables from the starter to
the motor.
Ratings
Voltage: 7.2 kV
Current: 25 - 315 A
Breaking capacity: 40 kA
Agency information
Comply with BS 2692-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Allows motor start current to pass on without degradation of
fuse link.
Typical applications
•
Motor protection.
Dimensions - mm
Fuse Link Type
WFNHO
WKNHO
A
486
486
B
454
454
C
403
403
Triple barrel fuse link (3rd barrel shown dotted) with 03 tags.
Double barrel fuse link with 02 tags shown in full line.
D
76
76
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
Part numbers
Current
In (A)
7.2WFNHO25
25
40
84
38.7
34
1.4 x 102
2.1 x 103
403
76
4.4
7.2WFNHO31.5
31.5
40
96
25.5
35
3.1 x 102
4.7 x 103
403
76
4.4
7.2WFNHO40
40
40
107
18.2
40
6.1 x 102
8 x 103
403
76
4.4
7.2WFNHO50
50
40
122
13.3
46
1.2 x 103
1.5 x 104
403
76
4.4
7.2WFNHO63
63
40
133
10.4
56
1.9 x 103
3 x 104
403
76
4.4
7.2WFNHO80
80
40
133
7.30
65
3.8 x 103
5.8 x 104
403
76
4.4
7.2WFNHO100
100
40
262
4.92
69
9.8 x 103
1.3 x 105
403
76
4.4
7.2WFNHO125
7.2WFNHO160
7.2WKNHO200
125
160
200
40
40
40
300
337
500
2.94
25
1.63
63
72
90
2.4 x 104
5 x 104
8.8 x 104
2.4 x 105
7 x 105
403
403
76
76
4.4
4.4
1.3 x 106
403
76
4.4
7.2WKNHO224
224
40
500
1.44
98
1.1 x 105
1.6 x 106
403
76
4.4
7.2WKNHO250
250
40
960
1.11
105
2.2 x 105
1.6 x 106
403
76
4.4
7.2WKNHO315
315
40
960
0.78
107
4.5 x 105
3.1 x 106
403
76
4.4
Breaking capacity Minimum breaking
I1 ( kA)
current I3 (A)
W
Higher ratings than those listed above can be obtained by using fuse links connected in parralel. Special fixing arrangements for connecting up
to three fuse links in parallel are available. Please contact Bussmann application engineers [email protected] for more details. The code
designations for these arrangements are given in “How to order” page 8.
28
EATON Bussmann MV fuse links
12 kV - Motor fuse links to British standard dimensions
Specifications
Description
Motor fuse links providing short circuit protection in motor
circuits to both the motor starter and cables from the starter to
the motor.
Ratings
Voltage: 12 kV
Current: 250 - 350 A
Breaking capacity: 56 kA
Agency information
Comply with BS 2692-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Allows motor start current to pass on without degradation of
fuse link.
Typical applications
•
Motor protection
Dimensions - mm
+2/(6
0$;
$
0$;
%
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current
In (A)
Breaking capacity Minimum breaking
I1 ( kA)
current I3 (A)
Minimum
pre-arcing 103
Maximum
operating 103
K81ERX250
K81ERX315
K81ERX350
250
315
350
56 kA
56 kA
56 kA
300
540
850
2000
3100
4500
1000
1000
1000
* Lower ratings available 32, 40, 50, 63, 75, 100, 125, 160 and 200 A. Please contact our technical department for further
information: [email protected] or 00 44 1509 882 699
EATON Bussmann MV fuse links
29
3.6 kV - Motor fuse links to DIN Standard dimensions
Specifications
Description
Motor fuse links providing short circuit protection in motor
circuits to both the motor starter and cables from the starter to
the motor.
Ratings
Voltage: 3.6 kV
Current: 50 - 400 A
Breaking capacity: 50 kA
Agency information
Comply with IEC 60282-1, VDE 0670 part 4 and DIN Dimensional
standard DIN 43625.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Allows motor start current to pass on without degradation of
fuse link.
Fuse link reference
WDOS
WFOS
WDLS
WFLS
WKLS
Length (A) mm
192
192
292
292
292
Diameter (D) mm
51
76
51
76
76
Weight Kg
1.1
2.1
1.63
3.16
3.16
Typical applications
•
Motor protection.
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
Part numbers
Current
In (A)
Breaking
capacity I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
3.6WDOSJ50
50
50
180
5.36
20
1.8 x 103
2.4 x 104
192
51
1.1
3.6WDOSJ63
63
50
225
3.68
21
3.8 x 103
4.5 x 104
192
51
1.1
3.6WDOSJ80
80
50
288
2.88
27
6.3 x 103
8 x 104
192
51
1.1
3.6WDOSJ100
100
50
360
2.16
31
9.8 x 103
1.1 x 105
192
51
1.1
3.6WDOSJ125
125
50
450
1.73
39
1.5 x 104
2.2 x 105
192
51
1.1
3.6WFOSJ160
160
50
600
1.28
47
3.1 x 104
6.2 x 105
192
76
2.1
3.6WFOSJ200
200
50
600
0.94
52
5.7 x 104
1.1 x 106
192
76
2.1
3.6WDLSJ50
3.6WDLSJ63
3.6WDLSJ80
50
63
80
50
50
50
152
171
190
7.73
5.9
4.12
27
32
37
1.8 x 103
3.1 x 103
6.3 x 103
2.4 x 104
4.5 x 104
292
292
51
51
1.63
1.63
8 x 104
292
51
1.63
3.6WDLSJ100
100
50
190
3.38
46
9.5 x 103
1.2 x 105
292
51
1.63
3.6WDLSJ125
125
50
190
2.85
61
1.3 x 104
1.8 x 105
292
51
1.63
3.6WFLSJ160
160
50
300
1.74
61
3.4 x 104
4.1 x 105
292
76
3.16
3.6WFLSJ200
200
50
300
1.42
80
5.1 x 104
7.2 x 105
292
76
3.16
3.6WKLSJ250
250
50
820
0.74
67
1.9 x 105
2.4 x 106
292
76
3.16
3.6WKLSJ315
315
50
820
0.51
69
4 x 105
5 x 106
292
76
3.16
3.6WKLSJ400
400
50
820
0.40
90
6.4 x 105
7 x 106
292
76
3.16
30
EATON Bussmann MV fuse links
7.2 kV - Motor fuse links to DIN Standard dimensions
Specifications
Description
Motor fuse links providing short circuit protection in motor
circuits to both the motor starter and cables from the starter to
the motor.
Ratings
Voltage: 7.2 kV
Current: 25 - 355A
Breaking capacity: 63 kA
Agency information
Comply with IEC 60282-1,VDE 0670 part 4 and DIN Dimensional
standard DIN 43625.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Allows motor start current to pass on without degradation of
fuse link.
Dimensions - mm
Fuse link reference
WFMS
WKMS
Length (A) mm
442
442
Diameter (D) mm
Weight Kg
76
76
5.2
5.2
Typical applications
•
Motor protection.
Part numbers technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
Part numbers
Current
In (A)
Breaking capacity Minimum breaking
I1 ( kA)
current I3 (A)
mΩ
W
Minimum
pre-arcing
7.2WFMSJ25
25
63
84
33.9
33
1.4 x 102
2.1 x 103
442
76
5.2
7.2WFMSJ31.5
31.5
63
96
25.4
40
3.1 x 102
4.7 x 103
442
76
5.2
7.2WFMSJ40
40
63
107
17.8
56
6.1 x 102
8 x 103
442
76
5.2
7.2WFMSJ50
50
63
122
14.8
53
1.2 x 103
1.5 x 104
442
76
5.2
7.2WFMSJ63
63
63
133
11.6
61
1.9 x 103
3 x 104
442
76
5.2
7.2WFMSJ80
80
63
133
8.12
72
3.8 x 103
5.8 x 104
442
76
5.2
7.2WFMSJ100
100
63
262
5.33
74
9.8 x 103
1.3 x 105
442
76
5.2
7.2WFMSJ125
7.2WFMSJ160
7.2WKMSJ200
125
160
200
63
63
63
300
337
500
3.19
2.23
1.79
70
79
99
2.4 x 104
5 x 104
8.8 x 104
2.4 x 105
7 x 105
442
442
76
76
5.2
5.2
1.3 x 106
442
76
5.2
7.2WKMSJ224
224
63
500
1.59
100
1.1 x 105
1.6 x 106
442
76
5.2
7.2WKMSJ250
250
63
960
1.23
107
2.2 x 105
1.6 x 106
442
76
5.2
7.2WKMSJ315
315
63
960
0.87
120
4.5 x 105
3.1 x 106
442
76
5.2
7.2WKMSJ355
355
63
1000
0.72
125
6.4 x 105
3.9 x 106
442
76
5.2
EATON Bussmann MV fuse links
31
2.75 kV - Motor fuse links to USA Dimensions
Specifications
Description
R-rated medium voltage current limiting fuse links for motor
protection.
Ratings
Voltage: 2.75 kV
Current: 2 - 24 R
Breaking capacity: 60 kA
Agency information
IEEE standards.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks
to the M-effect.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
•
Allows motor start current to pass on without degradation
of fuse link.
A Tags (ferrule)
Typical applications
•
Motor protection.
Dimensions
Fuse link reference
VFRHA
VKRHA
VKRHK
Length mm
276
276
276
Diameter mm
76
76
76
Weight Kg
2.5
2.5
5.2
K Tags (double barrel fuse links)
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
Pre-arcing
Maximum oper- Length
ating
mm
Diameter
mm
Weight
kg
2.75VFRHA2R
60
180
6.15
52
8.1 x 103
2.8 x 104
276
76
2.5
2.75VFRHA3R
60
229
44
57
4
1.9 x 10
7.5 x 104
276
76
2.5
2.75VFRHA4R
60
257
2.69
62
4.2 x 104
1.4 x 105
276
76
2.5
2.75VFRHA6R
60
525
1.62
65
3.9 x 104
3.4 x 105
276
76
2.5
2.75VKRHA9R
60
500
1.15
70
8.8 x 104
8.4 x 105
276
76
2.5
2.75VKRHA12R
60
500
13
80
1.1 x 105
1.2 x 106
276
76
2.5
2.75VKRHK18R
60
500
0.58
140
3.5 x 105
3.2 x 106
276
76
5.2
2.75VKRHK24R
60
500
0.51
156
4.5 x 105
5.5 x 106
276
76
5.2
32
EATON Bussmann MV fuse links
5.5 kV - Motor fuse links to USA Dimensions
Specifications
Description
R-rated medium voltage current limiting fuse links for motor
protection.
Ratings
Voltage: 5.5 kV
Current: 2 - 24 R
Breaking capacity: 60 kA
Agency information
IEEE standards.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A Tags (ferrule)
Typical applications
•
Motor protection.
Dimensions
Fuse link reference
VFNHA
VKNHA
VKNHK
Length mm
403
403
403
Diameter mm
76
76
76
Weight Kg
3.8
3.8
7.8
K Tags (double barrel fuse links)
Part numbers and technical data
Cold resistance & watts
loss in free air
Joule integral (I2t)
Part numbers
Breaking capacity
I1 ( kA)
Minimum breaking
current I3 (A)
mΩ
W
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
5.5VFNHA2R
60
180
8.35
70
8.1 x 103
2.8 x 104
403
76
3.8
5.5VFNHA3R
60
229
5.48
77
1.9 x 104
7.9 x 104
403
76
3.8
5.5VFNHA4R
60
257
3.65
85
4.2 x 104
1.6 x 105
403
76
3.8
5.5VFNHA6R
60
525
2.31
91
3.9 x 104
3.6 x 105
403
76
3.8
5.5VKNHA9R
60
500
1.63
99
8.8 x 104
8.8 x 105
403
76
3.8
5.5VKNHA12R
60
500
1.45
110
1.1 x 105
1.3 x 106
403
76
3.8
5.5VKNHK18R
5.5VKNHK24R
60
60
500
500
0.82
0.73
198
220
3.5 x 105
4.5 x 105
3.4 x 106
5.8 x 106
403
403
76
76
7.8
7.8
EATON Bussmann MV fuse links
33
Medium voltage and auxiliary transformer fuse links
Introduction to medium voltage and auxiliary transformer fuse links
35
Medium voltage and auxiliary transfomer
1.1 kV
36
3.6 kV
37
5.5 kV - Type E
38
7.2 kV
39
12 kV
40
15.5 kV
41
17.5 kV
42
24 kV
43
36 kV
44
3.6 kV
45
5.5 kV
46
7.2 kV
47
12 kV
48
15.5 kV
49
17.5 kV
50
24 kV
51
36 kV
52
38 kV
53
Type CAV
34
EATON Bussmann MV fuse links
Introduction to medium voltage and auxiliary transformer fuse links
∙
British standard voltage and auxiliary transformer (VT) fuse links.
∙
A range of voltage transformer primary fuse links to BS 2692-1
and IEC 60282-1.
∙
Wide range of ratings from 1 kV to 36 kV.
∙
3.15 Amp industry standard current ratings.
∙
CAV range with ratings from 3.6 kV to 38 kV.
Bussmann voltage and auxiliary transformer fuse links
Bussmann manufactures a wide range of voltage transformer
(VT) fuse links. In North America they are referred to as ‘potential
transformer fuse links’. These fuse links are designed for use in the
primary side of voltage transformers to provide system isolation in
the event of faults occuring in the transformer circuit.
Voltage transformer fuse links have a preferred current rating of
3.15A. Experience has shown that there is a risk of spurious operation by transient overcurrents where lower current ratings are
used. In addition, in order to minimise the risk of deterioration of
the fine fuse elements caused by corona, it is desirable to mount
the fuse links so that the earthed metal is not in the immediate
vicinity of the part of the barrel between the ferrules.
Higher current and ‘E’ ratings are available for special applications,
including auxiliary transformers.
A range of VT fuse links with a breaking capacity of 200 kA for
use at the output terminals of large turbo alternators can also be
ordered. For further information, please contact Bussmann application engineers: [email protected]
Types prefixed ‘A’ or ‘N’ are suitable for use indoors in air only.
Types prefixed ‘O’ may be used under oil.
Application
Small rated fuse links for protection of voltage and auxiliary transformers. Back-up protection up to 3.15 A and voltages from 1.1 kV
to 36 kV.
EATON Bussmann MV fuse links
35
1.1 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 1.1 kV
Current: 2 - 6.3 A
Breaking capacity: 50 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Fuse link reference
NBUN
Typical applications
•
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
A (mm)
86
B (mm)
17.5
D (mm)
25.4
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
1.1NBUN*2
2
50
0.15
6.3 x 100
1.8 x 101
86
25.4
0.12
1.1NBUN*3.15
3.15
50
0.11
1.2 x 101
3.4 x 101
86
25.4
0.12
1.1NBUN*6.3
6.3
50
0.07
3.2 x 101
9.2 x 101
86
25.4
0.12
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
36
EATON Bussmann MV fuse links
3.6 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 3.6 kV
Current: 3.15 - 10A
Breaking capacity: 50 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Ferrule fuse links tag type ‘A’ shown in full lines and
‘22’: tag shown in dotted lines
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
ABWN
ABCN
A (mm)
142
195
B (mm)
30
30
D (mm)
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
3.6ABWN*3.15
3.6ABWN*6.3
3.15
6.3
50
50
0.36
0.12
6.3 x 100
4.8 x 101
1.8 x 101
142
25.4
0.19
3.1 x 102
142
25.4
0.19
3.6ABCN*3.15
3.15
50
0.36
6.3 x 100
1.8 x 101
195
25.4
0.245
3.6ABCN*6.3
6.3
50
0.12
4.8 x 101
3.1 x 102
195
25.4
0.245
3.6ABCN*10
10
50
0.08
1.1 x 102
7 x 102
195
25.4
0.245
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
EATON Bussmann MV fuse links
37
5.5 kV - Type E Voltage transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 5.5 kV
Current: 0.5 - 5A
Breaking capacity: 50 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
ABWNA
AMWNA
A (mm)
142
142
B (mm)
30
16
D (mm)
25.4
20.6
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
5.5AMWNA0.5E
0.5
50
32.5
1.2 x 100
3.5 x 100
142
20.6
0.114
5.5AMWNA1E
1
50
16
5 x 100
1.4 x 101
142
20.6
0.114
5.5AMWNA2E
2
50
0.58
4 x 100
1.2 x 101
142
20.6
0.114
5.5AMWNA3E
3
50
0.32
1.8 x 101
1.1 x 102
142
20.6
0.114
5.5AMWNA4E
4
50
0.19
4.6 x 101
3 x 102
142
20.6
0.114
5.5AMWNA5E
5
50
0.15
7.9 x 101
5.1 x 102
142
20.6
0.114
5.5ABWNA0.5E
0.5
50
50.2
0.49 x 100
1.4 x 100
142
25.4
0.19
5.5ABWNA1E
1
50
25.1
2 x 100
5.7 x 100
142
25.4
0.19
5.5ABWNA2E
5.5ABWNA3E
5.5ABWNA5E
2
3
5
50
50
50
18
0.47
0.2
1.2 x 100
6.3 x 100
3.2 x 101
3.4 x 100
1.8 x 101
142
142
25.4
25.4
0.19
0.19
2 x 102
142
25.4
0.19
38
EATON Bussmann MV fuse links
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 7.2 kV
Current: 3.15 - 6.3A
Breaking capacity: 45 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Features and benefits
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
ABWN*
ABCN*
AMWN
OBCN*
OBWN*
A (mm)
142
195
142
195
142
B (mm)
30
30
16
30
30
D (mm)
25.4
25.4
20.6
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2ABWN*3.15
3.15
45
0.61
6.3 x 100
4 x 101
142
25.4
0.19
7.2ABWN*6.3
6.3
45
0.24
4.8 x 10
3.1 x 102
142
25.4
0.19
7.2ABCN*3.15
3.15
45
0.61
6.3 x 100
4 x 101
195
25.4
0.245
7.2ABCN*6.3
6.3
45
0.24
4.8 x 101
3.1 x 102
195
25.4
0.245
7.2AMWNA0.5E
0.5
50
47.5
0.2 x100
1 x 100
142
20.6
0.19
7.2AMWNA1E
7.2AMWNA2E
7.2AMWNA3E
1
2
3
50
50
50
23.3
1.37
0.77
1.2 x 100
1.7 x 100
4 x 100
4.8 x 100
8.8 x 100
142
142
20.6
20.6
0.19
0.19
2.7 x 101
142
20.6
0.19
7.2AMWNA4E
4
50
0.43
1.2 x 101
5.1 x 101
142
20.6
0.19
7.2AMWNA5E
5
50
0.27
2.8 x 101
1.4 x 102
142
20.6
0.19
7.2OBCN*3.15
3.15
45
0.61
6.3 x 100
4 x 101
195
25.4
0.245
7.2OBCN*6.3
6.3
45
0.24
4.8 x 101
3.1 x 102
195
25.4
0.245
7.2OBWN*3.15
3.15
45
0.61
6.3 x 100
4 x 101
142
25.4
0.19
7.2OBWN*6.3
6.3
45
0.24
4.8 x 101
3.1 x 102
142
25.4
0.19
1
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
EATON Bussmann MV fuse links
39
12 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 12 kV
Current: 3.15A
Breaking capacity: 45 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Features and benefits
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
Fuse link reference
ABCN*
OBCN*
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
195
195
B (mm)
30
30
D (mm)
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
12ABCN*3.15
3.15
45
1.21
6.3 x 100
1.8 x 101
195
25.4
0.245
12OBCN*3.15
3.15
45
1.21
6.3 x 100
1.8 x 101
195
25.4
0.245
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
40
EATON Bussmann MV fuse links
15.5 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 15.5 kV
Current: 3.15A
Breaking capacity: 32 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Features and benefits
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
Fuse link reference
ABFN*
OBFN*
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
254
254
B (mm)
30
30
D (mm)
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
15.5ABFN*3.15
15.5OBFN*3.15
3.15
3.15
32
32
1.24
1.24
6.3 x 100
6.3 x 100
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
4 x 101
254
25.4
0.31
4 x 101
254
25.4
0.31
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
EATON Bussmann MV fuse links
41
17.5 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 17.5 kV
Current: 3.15A
Breaking capacity: 35 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Fuse link reference
ABGN*
OBGN*
A (mm)
359
359
B (mm)
30
30
D (mm)
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
17.5ABGN*3.15
3.15
35
1.45
6.3 x 100
4 x 101
359
25.4
0.43
17.5OBGN*3.15
3.15
35
1.45
6.3 x 100
4 x 101
359
25.4
0.43
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
42
EATON Bussmann MV fuse links
24 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 24 kV
Current: 3.15A
Breaking capacity: 25 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Dimensions - mm
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
ABGN*
OBGN*
A (mm)
359
359
B (mm)
30
30
D (mm)
25.4
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
24ABGN*3.15
24OBGN*3.15
3.15
3.15
25
25
2
2
6.3 x 100
6.3 x 100
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
4 x 101
359
25.4
0.43
4 x 101
359
25.4
0.43
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
EATON Bussmann MV fuse links
43
36 kV - Voltage and auxiliary transformer fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 36 kV
Current: 3.15A
Breaking capacity: 31.5 kA
Agency information
Comply with BS 2692-1 and IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Ferrule fuse links tag type ‘A’ shown in full lines and ‘22’: tag shown in
dotted lines
Dimensions - mm
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
OBGN*
A (mm)
359
B (mm)
30
D (mm)
25.4
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
36OBGN*3.15
3.15
31.5
25
1.2 x 101
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.7 x 101
359
25.4
0.43
* The last letter of the ordering code on these items is normally either “A” or “22”, please refer to how to order page 8.
44
EATON Bussmann MV fuse links
3.6 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 3.6 kV
Current: 2A
Breaking capacity: 50 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
3.6CAV
A (mm)
220
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
3.6CAV2
2
50
0.49
6.2 x 100
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
1.8 x 101
220
41.3
0.7
EATON Bussmann MV fuse links
45
5.5 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 5.5 kV
Current: 0.5 - 15A
Breaking capacity: 50 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Shown with striker fitted.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Fuse link reference
CAV and CAVH
A (mm)
187
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
5.5CAVH0.5E
5.5CAVH1E
0.5
1
50
50
12.1
12.1
1.4 x 101
1.4 x 101
9 x 101
187
41.3
0.6
9 x 101
187
41.3
0.6
5.5CAVH2E
5.5CAV15E
2
15
50
50
0.39
0.49
1.8 x 101
5.5 x 102
1.1 x 102
3.5 x 103
187
187
41.3
41.3
0.6
0.6
CAV fuse links are suitable for indoor use in air only.
Type CAVH fuse links are fitted with striker pins which may be used for indication purposes.
46
EATON Bussmann MV fuse links
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 7.2 kV
Current: 2 - 10A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Fuse link reference
CAV
A (mm)
220
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2CAV2
2
40
0.89
6.2 x 100
1.8 x 101
220
41.3
0.7
7.2CAV4
4
40
0.50
2 x 101
5.7 x 101
220
41.3
0.7
7.2CAV6
6
40
0.32
4.8 x 101
1.4 x 102
220
41.3
0.7
7.2CAV10
10
40
0.22
1.1 x 102
3.2 x 102
220
41.3
0.7
EATON Bussmann MV fuse links
47
12 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 12 kV
Current: 2A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Fuse link reference
CAV
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
220
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
12CAV2
2
40
1.34
6.2 x 100
48
EATON Bussmann MV fuse links
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
1.8 x 101
220
41.3
0.7
15.5 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 15.5 kV
Current: 0.5 - 7 A
Breaking capacity: 80 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
Dimensions - mm
See list page 117 and data on USB at the back of the catalogue.
Fuse link reference
CAV and CAVH
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
327
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
15.5CAV0.5E
0.5
80
151
0.5 x 100
1.5 x 100
327
41.3
0.9
15.5CAV1E
1
80
75.4
2 x 10
5.8 x 100
327
41.3
0.9
15.5CAV2E
2
80
32.3
1.2 x 100
3.5 x 100
327
41.3
0.9
15.5CAV3E
3
80
16.2
4.8 x 100
1.4 x 101
327
41.3
0.9
15.5CAV5E
5
80
0.66
2 x 101
1.3 x 102
327
41.3
0.9
15.5CAV7E
15.5CAVH0.5E
15.5CAVH1E
7
0.5
1
80
80
80
0.38
30.1
30.1
7.1 x 101
1.4 x 101
1.4 x 101
4.5 x 102
9 x 101
327
327
41.3
41.3
0.9
0.9
9 x 101
327
41.3
0.9
15.5CAVH2E
2
80
0.95
1.8 x 101
1.1 x 102
327
41.3
0.9
0
CAV fuse links are suitable for indoor use in air only.
Type CAVH fuse links are fitted with striker pins which may be used for indication purposes.
EATON Bussmann MV fuse links
49
17.5 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 17.5 kV
Current: 2 - 10 A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Fuse link reference
CAV
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
220
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
17.5CAV2
2
40
1.69
6.3 x 100
1.8 x 101
220
41.3
0.7
17.5CAV4
4
40
0.61
4.8 x 101
1.4 x 102
220
41.3
0.7
17.5CAV6
6
40
0.36
1.4 x 102
4 x 102
220
41.3
0.7
17.5CAV10
10
40
0.24
3.2 x 102
9.2 x 102
220
41.3
0.7
50
EATON Bussmann MV fuse links
24 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
Voltage: 24 kV
Current: 2 - 4A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
CAV
A (mm)
340
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
24CAV2
2
40
2.54
6.2 x 100
1.8 x 101
340
41.3
1
24CAV3
3
40
1.43
2 x 101
5.7 x 101
340
41.3
1
24CAV4
4
40
0.92
4.8 x 101
1.4 x 102
340
41.3
1
EATON Bussmann MV fuse links
51
36 kV - Voltage transformer and auxiliary type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary transformers.
Ratings
Voltage: 36 kV
Current: 2 - 4 A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Dimensions - mm
Fuse link reference
CAV
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
A (mm)
440
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
36CAV2
36CAV4
2
4
40
40
3.12
1.12
6.2 x 100
4.8 x 101
52
EATON Bussmann MV fuse links
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
1.8 x 101
440
41.3
1.2
1.4 x 102
440
41.3
1.2
38 kV - Voltage and auxiliary transformer type CAV Fuse links
Specifications
Description
Voltage transfomer fuse links. suitable for the protection of auxiliary
transformers.
Ratings
ated Voltage: 38 kV
Current: 0.5 - 4 A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1.
Time-current curves and cut-off curves
See list page 117 and data on USB at the back of the catalogue.
Shown with striker fitted.
Dimensions - mm
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Fuse link reference
CAV and CAVH
A (mm)
440
Typical applications
•
Protection of auxiliary transformers.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
38CAV4E
38CAVH0.5E
4
0.5
40
40
2.42
66.6
1.2 x 101
1.4 x 101
3.4 x 101
440
41.3
1.2
9 x 101
440
41.3
1.2
38CAVH1E
1
40
66.6
1.4 x 101
9 x 101
440
41.3
1.2
38CAVH2E
2
40
2.2
1.8 x 101
1.1 x 102
440
41.3
1.2
CAV fuse links are suitable for indoor use in air only.
Type CAVH fuse links are fitted with striker pins which may be used for indication purposes.
EATON Bussmann MV fuse links
53
Medium voltage oil fuse links
Introduction to current limiting fuse links for use in oil switchgear
55
British standard
54
EATON Bussmann MV fuse links
3.6 kV
56
7.2 kV
57
12 kV
58
15.5 kV
59
17.5 kV
60
24 kV
61
Introduction to current limiting fuse links for use in oil switchgear
•
Fuse Links comply with IEC 60282-1, BS 2692-1 and ESI
standard 12-8.
•
7.2 and 12 kV Fuse links tested at highest system voltage and
approved by the UK Electricity Association approvals panel.
•
Voltage ranges from 3.6 to 24 kV.
•
Fitted with powerful pyrotechnic striker pin.
Bussmann under oil fuse links
Bussmann range of oil tight fuse links are designed for use in oil
filled switchgear. This type was pioneered in the UK. Bussmann
range has been in continuous manufacture for almost 40 years,
being by far the most widely used device of its kind in the world.
Over 1,000,000 Bussmann branded fuse links have been put into
service without a single reported case of oil ingress. A unique
triple seal system ensures against long term seal deterioration.
Low power dissipation ensures long running in oil filled switchgear.
Application
Oil medium voltage fuse links are suitable for primary side transformer protection and oil filled switch combination unit.
Selection of these fuse links has been based on a compromise between the following:
1 - Withstand against magnetising inrush current is taken as
12 times full-load current for 0.1 second.
2 - Withstand against 150% permissible overload current.
Recommendations marked with the following:
* Limited to permissible overload of 130%
The range is not suitable for use inside oil filled transformer
tanks where high oil temperatures may be expected.
** Permits use of a 12 kV OHFMA 80A fuse link with a 1000
kVA transformer where permissible overload does not exceed
130%.
Application procedure
3 - For 6.6 kV systems, 12 kV fuse links are recommended
where possible in the interests of standardisation.
For any transformer the fuse current rating is determined by magnitude and duration of inrush current.
4 - Wherever possible, 254mm long fuse links are offered
rather than equivalent 359mm types
General Guide to the Selection of Oil Tight Fuse Links for Use in
Primary Circuit of Three Phase Transformers.
5 - The above recommendations are not generally applicable
to transformers feeding motor circuits with starting currents
in excess of the transformer full load current. In this event
please consult Bussmann application engineers: [email protected]
General guide to the selection of oil tight fuse links for use in primary circuit of three phase transformers
Transformer priority voltage
3.3 kV
6.6 kV
11 kV
13.8 kV
Transformer
kVA
200
250
300/315
400
500
Product
code
OEFMA
OEFMA
OEFMA
OEFMA
OEFMA
Current
(A)
63
80
100
125
160
Voltage
kV
3.6
3.6
3.6
3.6
3.6
Product
code
OEFMA
OEFMA
OEFMA
OEFMA
OEFMA
Current
(A)
31.5
40
50
63
71
Voltage
kV
12
12
12
12
12
ESI 12-8
Ref
01
02
03
Product
code
OEFMA
OEFMA
OEFMA
OEFMA
OEFMA
Current
(A)
25
25
31.5
40
50
Voltage
kV
12
12
12
12
12
Product
code
OEFMA
OEFMA
OEFMA
OEFMA
OEFMA
Current
(A)
16
20
25
31.5
40
Voltage
kV
15.5
15.5
15.5
15.5
15.5
630
750/800
1000
1250
1600
OEFMA
OLGMA
OLGMA
-
200
250
250*
-
3.6
3.6
3.6
-
OEFMA
OHGMA
OHGMA
OHGMA
-
100
125
140
160*
-
7.2
7.2
7.2
7.2
-
04
05
-
OHFMA
OHFMA
OGFMA
OGFMA
OLGMA
63
80
90**
100
125*
12
12
12
12
12
OEFMA
OEFMA
OHGMA
OHGMA
OLGMA
50
63
71
90
100*
15.5
15.5
15.5
15.5
15.5
EATON Bussmann MV fuse links
55
3.6 kV - British standard oil tight fuse links
Typical applications
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Ratings
Voltage: 3.6 kV
Current: 6.3 - 250 A
Breaking capacity: 50 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Minimum
Cold resistance mΩ Pre-arcing
Maximum
operating
Dimensional
Reference BS 2692
Length
mm
Diameter
mm
Weight
kg
3.6OEFMA6.3
3.6OEFMA10
6.3
10
50
50
207
83.6
2 x 101
1.4 x 102
4.9 x 102
F01
254
63.5
1.9
1.4 x 103
F01
254
63.5
1.9
3.6OEFMA16
3.6OEFMA20
3.6OEFMA25
16
20
25
50
50
50
42.5
33.9
26.5
1.7 x 102
2.7 x 102
4.5 x 102
2.4 x 103
3.6 x 103
F01
F01
254
254
63.5
63.5
1.9
1.9
4.8 x 103
F01
254
63.5
1.9
3.6OEFMA31.5
31.5
50
17.6
1 x 10
8.8 x 103
F01
254
63.5
1.9
3.6OEFMA40
40
50
15.4
8.9 x 103
1 x 104
F01
254
63.5
1.9
3.6OEFMA50
50
50
11.5
1.6 x 103
1.4 x 104
F01
254
63.5
1.9
3.6OEFMA63
63
50
7.60
3.3 x 103
2.4 x 104
F01
254
63.5
1.9
3.6OEFMA80
80
50
63
5.2 x 103
3.4 x 104
F01
254
63.5
1.9
3.6OEFMA100
100
50
42
1.2 x 104
6.2 x 104
F01
254
63.5
1.9
3.6OEFMA125
3.6OEFMA160
3.6OEFMA200
125
160
200
50
50
50
32
2.21
1.74
2.1 x 104
1.5 x 104
2.4 x 104
9.6 x 104
1.6 x 105
F01
F01
254
254
63.5
63.5
1.9
1.9
2.3 x 105
F01
254
63.5
1.9
3.6OEGMA63
6.3
50
11
3.2 x 103
1.9 x 104
F02
254
63.5
2.6
3.6OEGMA80
80
50
8.70
5.2 x 103
2.7 x 104
F02
254
63.5
2.6
3.6OEGMA100
100
50
5.5
5 x 103
4.9 x 104
F02
254
63.5
2.6
3.6OEGMA125
125
50
4.59
7.2 x 103
6.4 x 104
F02
254
63.5
2.6
3.6OEGMA160
160
50
3.44
1.3 x 104
1 x 105
F02
254
63.5
2.6
3.6OEGMA200
200
50
2.29
2.9 x 104
1.8 x 105
F02
254
63.5
2.6
3.6OLGMA250
250
50
1.72
5.1 x 104
2.7 x 105
F02
254
63.5
2.6
56
EATON Bussmann MV fuse links
3
7.2 kV - British standard oil tight fuse links
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
Ratings
Voltage: 7.2 kV
Current: 80 - 160 A
Breaking capacity: 45 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
Minimum
I1 ( kA)
Cold resistance mΩ pre-arcing
Maximum
operating
Dimensional reference Length
BS 2692
mm
Diameter
mm
Weight
kg
7.2OEFMA80
7.2OEFMA100
7.2OEFMA112
7.2OHGMA100
80
100
112
100
45
45
45
45
8.36
5.59
4.57
69
3.2 x 103
6.3 x 103
9.1 x 103
5 x 103
5.8 x 104
F01
254
63.5
1.9
9 x 104
1.3 x 105
F01
F01
254
254
63.5
63.5
1.9
1.9
7.5 x 104
F02
359
63.5
2.6
7.2OHGMA125
125
45
58
7.2 x 102
9.6 x 104
F02
359
63.5
2.6
7.2OHGMA140
140
45
4.35
9.8 x 103
1.4 x 105
F02
359
63.5
2.6
7.2OHGMA160
160
45
3.81
1.3 x 104
1.8 x 105
F02
359
63.5
2.6
EATON Bussmann MV fuse links
57
12 kV - British standard oil tight fuse links
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
Ratings
Voltage: 12 kV
Current: 6.3 - 125 A
Breaking capacity: 40 - 45 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity Cold resistance
I1 ( kA)
mΩ
12OEFMA6.3
12OEFMA10
12OEFMA16
12OEFMA20
6.3
10
16
20
40
40
40
40
520
214
108
77
2 x 101
1.4 x 102
1.7 x 102
3.4 x 102
6.1 x 102
F01
254
63.5
1.9
1.8 x 103
3 x 103
F01
F01
254
254
63.5
63.5
1.9
1.9
5 x 103
F01
254
63.5
1.9
12OEFMA25
25
40
57.8
4 x 10
6.5 x 103
F01
254
63.5
1.9
12OEFMA31.5
31.5
40
38.5
8.9 x 102
1.2 x 104
F01
254
63.5
1.9
12OEFMA40
40
40
28.2
1.5 x 103
1.8 x 104
F01
254
63.5
1.9
12OEFMA50
50
40
20.1
2.9 x 103
2.8 x 104
F01
254
63.5
1.9
12OEFMA63
63
40
15.1
5.1 x 103
4.3 x 104
F01
254
63.5
1.9
12OHFMA71
71
45
12.3
3.2 x 103
5.4 x 104
F01
254
63.5
1.9
12OHFMA80
12OHGMA6.3
12OHGMA10
80
6.3
10
45
40
40
10.9
520
214
4.1 x 103
2 x 101
1.4 x 102
7 x 104
6.1 x 102
F01
F02
254
359
63.5
63.5
1.9
2.6
1.8 x 103
F02
359
63.5
2.6
12OHGMA16
16
40
108
1.7 x 102
3 x 103
F02
359
63.5
2.6
12OHGMA20
20
40
77
3.4 x 102
5 x 103
F02
359
63.5
2.6
12OHGMA25
25
40
57.8
4 x 102
6.5 x 105
F02
359
63.5
2.6
12OHGMA31.5
31.5
40
38.5
8.9 x 102
1.2 x 104
F02
359
63.5
2.6
12OHGMA40
40
40
28.2
1.5 x 103
1.8 x 104
F02
359
63.5
2.6
12OHGMA50
12OHGMA63
12OHGMA71
50
63
71
40
40
40
22.6
17
16.6
2.3 x 103
4.1 x 103
2 x 103
2.4 x 104
3.7 x 104
F02
F02
359
359
63.5
63.5
2.6
2.6
3.9 x 104
F02
359
63.5
2.6
12OHGMA80
80
40
13.4
3.2 x 10
3
5.5 x 104
F02
359
63.5
2.6
12OHGMA90
90
40
12.2
3.8 x 103
6.2 x 104
F02
359
63.5
2.6
12OHGMA100
100
40
8.75
6.3 x 103
8.9 x 104
F02
359
63.5
2.6
12OLGMA125
125
40
79
1 x 104
1.7 x 105
F02
359
63.5
2.6
58
EATON Bussmann MV fuse links
Minimum
pre-arcing
Maximum
operating
Dimensional reference
BS 2692
Length
mm
Diameter
mm
Weight
kg
2
15.5 kV - British standard oil tight fuse links
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
Ratings
Voltage: 15.5 kV
Current: 6.3 - 100 A
Breaking capacity: 40 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Dimensional reference
BS 2692
Length
mm
Diameter
mm
Weight
kg
15.5OEFMA6.3
6.3
40
392
4.8 x 101
1 x 103
F01
254
63.5
1.9
15.5OEFMA10
10
40
188
4 x 10
3.4 x 103
F01
254
63.5
1.9
15.5OEFMA16
16
40
101
2.7 x 101
3.4 x 103
F01
254
63.5
1.9
15.5OEFMA20
20
40
78.7
4.5 x 101
4.9 x 103
F01
254
63.5
1.9
15.5OEFMA25
25
40
55.3
5.2 x 101
1.1 x 104
F01
254
63.5
1.9
15.5OEFMA31.5
31.5
40
36.9
1.2 x 103
1.5 x 104
F01
254
63.5
1.9
15.5OEFMA40
40
40
29.5
1.8 x 103
1.5 x 104
F01
254
63.5
1.9
15.5OEFMA50
50
40
22.1
3.3 x 103
3 x 104
F01
254
63.5
1.9
15.5OEFMA63
15.5OHGMA71
15.5OHGMA80
63
71
80
40
40
40
17.8
17.7
15.5
2 x 103
2.5 x 103
3.2 x 103
3.9 x 104
4.4 x 104
F01
F02
254
359
63.5
63.5
1.9
2.6
5.4 x 104
F02
359
63.5
2.6
15.5OHGMA16
90
40
11.6
5 x 103
7.5 x 104
F02
359
63.5
2.6
15.5OLGMA100
100
40
10
7.2 x 103
9.6 x 104
F02
359
63.5
2.6
1
EATON Bussmann MV fuse links
59
17.5 kV - British standard oil tight fuse links
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
Ratings
Voltage: 17.5 kV
Current: 6.3 - 80 A
Breaking capacity: 35 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Cold resistance mΩ
Minimum
pre-arcing
Maximum
operating
Dimensional reference
BS 2692
Length
mm
Diameter
mm
Weight
kg
17.5OHGMA6.3
17.5OHGMA10
6.3
10
35
35
665
282
2 x 101
1.4 x 102
6.1 x 102
F02
359
63.5
2.6
1.8 x 103
F02
359
63.5
2.6
17.5OHGMA16
16
35
139
1.7 x 102
3 x 103
F02
359
63.5
2.6
17.5OHGMA20
17.5OHGMA25
17.5OHGMA31.5
20
25
31.5
35
35
35
100
74.7
49.8
3.4 x 102
4 x 102
9 x 102
5 x 103
6.5 x 103
F02
F02
359
359
63.5
63.5
2.6
2.6
1.2 x 104
F02
359
63.5
2.6
17.5OHGMA40
40
35
36.5
1.5 x 103
1.9 x 104
F02
359
63.5
2.6
17.5OHGMA50
50
35
26
2.9 x 103
2.9 x 104
F02
359
63.5
2.6
17.5OHGMA63
63
35
19.5
5.2 x 103
4.5 x 104
F02
359
63.5
2.6
17.5OHGMA80
80
35
15.5
3.8 x 103
5.7 x 104
F02
359
63.5
2.6
60
EATON Bussmann MV fuse links
24 kV - British standard oil tight fuse links
Specifications
Description
Oil tight fuse links suitable for the protection of primary side
transformer and oil filled fuse switch combination unit.
Ratings
Voltage: 24 kV
Current: 6.3 - 50 A
Breaking capacity: 25 kA
Agency information
Comply with IEC 60282-1, BS 2692-1 and ESI standard 12-8.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Oil filled fuse switch combination unit.
The range is not suitable for use inside oil filled transformer tanks
where high oil temperatures may be expected.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Cold resistance mΩ
Minimum
Pre-arcing
Maximum
operating
Dimensional
Reference BS 2692
Length
mm
Diameter
mm
Weight
kg
24OEGMA6.3
24OEGMA10
24OEGMA16
6.3
10
16
25
25
25
605
290
153
4.8 x 101
2.5 x 102
2.7 x 102
1 x 103
3.4 x 103
F02
F02
359
359
63.5
63.5
2.6
2.6
3.4 x 103
F02
359
63.5
2.6
24OEGMA20
20
25
119
2
4.4 x 10
4.9 x 103
F02
359
63.5
2.6
24OEGMA25
25
25
84.5
5.2 x 102
1.1 x 104
F02
359
63.5
2.6
24OEGMA31.5
31.5
25
55.9
1.2 x 103
1.5 x 104
F02
359
63.5
2.6
24OEGMA40
40
25
44.7
1.8 x 103
2 x 104
F02
359
63.5
2.6
24OEGMA50
50
25
34
1.2 x 103
2.4 x 104
F02
359
63.5
2.6
EATON Bussmann MV fuse links
61
Medium voltage British standard air fuse links
Introduction to current limiting fuse links for use in air
63
British standard
62
EATON Bussmann MV fuse links
3.6 kV
64
7.2 kV
66
12 kV
68
15.5 kV
70
24 kV
71
36 kV
72
72.5 kV
73
Introduction to current limiting fuse links for use in air
•
Medium voltage fuse links for use in air, comply with BS
2962-1 dimensions.
•
Available in voltage from 3.6 kV to 72.5 kV.
•
Full range performance option available at 12 kV and 24 kV.
•
Wide variety of fixing arrangements available.
•
Powerful pyrotechnic striker fitted.
•
E-rated North American dimension products also available.
•
Suitable for indoor and outdoor use.
Bussmann fuse links for use in Air
The Bussmann range of fuse links for use in air are available in
British Standard form, BS 2692, Part 1 1975. A number of options
are available, including Full range capability, and alternative fixing
arrangements such as different types of tags, studs and collars
etc. Details are available on application. Higher current ratings
can be obtained by using fuse links in parallel and special fixing
arrangements are available for this purpose.
Bussmann - USA Dimensions
Selection of fuse these links has been based on a compromise between the following:
1 - The fuse links should withstand transformer magnetising
inrush currents, taken as 12 times full load current for 0.1 seconds.
2 - The fuse links should discriminate with the highest rating of
secondary fuse links
3 - The fuse links should withstand periodic overcurrents of up
to 150% of transformer fuse load current
4 - The fuse links should operate reasonably quickly in the
event of a transformer inter-turn fault or a fault in the secondary terminal zone of the transformer
Notes
A comprehensive range of ‘E’ rated North American dimension
fuse links for industrial applications is also available. These are the
latest technology Full range fuse links in USA Industrial Standard 2
inch and 3 inch diameter ferrule style. Extended ratings in double
barrel assemblies; striker, indicator and tag versions are also available, see pages 74 to 88.
Application
Air fuse links are suitable for primary side transformer protection,
fuse switch combination unit, fuse bases and fuse switches.
a) The above recommendations are not generally applicable
to transformers feeding motor circuits with starting currents
in excess of the Current fuse. In this event, please consult
Bussmann application engineers.
b) For 6.6 kV transformers, 12 kV fuse links are recommended,
where the required current rating is available.
* Where the transformer is not subjected to periodic overcurrents, a lower fuse rating may be suitable, fuse ratings marked
with “*”, are only suitable for use with the transformer sizes
quoted, where significant over loading does not occur.
Fuse links for use in transformers with primary voltages of 3.3,
22 and 33 kV are available, please consult Bussmann application engineers for further details [email protected]
General guide to the selection of air fuse links for use in the primary circuit of three phase transformers
Transformer Priority Voltage
6.6 kV
11 kV
13.8 kV
Transformer
kVA
200
250
300/315
400
500
Product code
BDG
BDG
BDG
BFG
BFG
Current (A)
31.5
40
50
63
80
Voltage ( kV)
12
12
12
12
12
Product code
BDG
BDG
BDG
BDG
BDG
Current (A)
20
25
31.5
40
50
Voltage ( kV)
12
12
12
12
12
Product code
BDG
BDG
BDG
BDG
BFG
Current (A)
20
25
31.5
40
50
Voltage ( kV)
15.5
15.5
15.5
15.5
15.5
630
750/800
1000
1250
1500
BFG
BFG
BFG
BFG
BFG
90
125
140
160
160*
12
7.2
7.2
7.2
7.2
BFG
BFG
BFG
AKG
AKG
63
71
90
112
125*
12
12
12
12
12
BFG
BFG
BFG
BFG
-
63
63
85
85*
-
15.5
15.5
15.5
15.5
-
EATON Bussmann MV fuse links
63
3.6 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 3.6 kV
Current: 6.3 - 100 A
Breaking capacity: 25 - 40 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
A Tags
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Dimensions - mm
F Tags
Tags type
A
C&D
F
Code
ADGHA
ADFHC
ADGHC
ADFHF
ADGHF
A
359
356
461
356
461
B
N/A
314
419
314
419
C
N/A
254
359
254
359
Dø
51
51
51
51
51
C & D Tags
64
EATON Bussmann MV fuse links
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity Cold resistance
I1 ( kA)
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
3.6ADFH*6.3
6.3
40
208
4.8 x 101
7.2 x 102
254
50.8
1.5
3.6ADFH*10
10
40
91.8
2.3 x 10
2.3 x 103
254
50.8
1.5
3.6ADFH*16
16
40
31.1
7.2 x 101
1 x 103
254
50.8
1.5
3.6ADFH*20
20
40
24.9
1.1 x 102
1.5 x 103
254
50.8
1.5
3.6ADFH*25
25
40
18.6
2 x 102
2.1 x 103
254
50.8
1.5
3.6ADFH*31.5
31.5
40
14.9
3.1 x 102
2.8 x 103
254
50.8
1.5
3.6ADFH*40
3.6ADGH*6.3
3.6ADGH*10
40
6.3
10
40
25
25
10
185
77.1
7.1 x 102
4.8 x 101
3.1 x 102
7.7 x 103
7.2 x 102
254
359
50.8
50.8
1.5
2.1
4.7 x 103
359
50.8
2.1
3.6ADGH*16
16
25
58.6
5.5 x 102
8.3 x 103
359
50.8
2.1
3.6ADGH*20
20
25
44
9.8 x 102
1.5 x 104
359
50.8
2.1
3.6ADGH*25
25
25
36.9
1.3 x 102
1.5 x 103
359
50.8
2.1
3.6ADGH*31.5
31.5
25
24.6
2.9 x 102
3.5 x 103
359
50.8
2.1
3.6ADGH*40
40
25
13.9
8 x 102
9.6 x 103
359
50.8
2.1
3.6ADGH*50
50
25
9.91
1.6 x 103
1.9 x 104
359
50.8
2.1
3.6ADGH*63
3.6ADGH*80
3.6ADGH*100
63
80
100
25
25
25
75
4.94
3.96
3.1 x 103
6.3 x 103
9.8 x 103
3.7 x 104
7.6 x 104
359
359
50.8
50.8
2.1
2.1
1.2 x 105
359
50.8
2.1
2
* The fifth letter or number of the part reference denotes the end fixing arrangement.
There are a wide variety of end terminations available, the most popular types, some of which have
dimensional references to BS2692: Part 1, are:
∙
ADFHC and ADGHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS
Ref TA3
∙
ADFHF and ADGHF: F Offset tags two bolt fixing
∙
ADGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
See previous page for outline drawings and dimensions.
Other tag variants available please consult Bussmann application engineers [email protected]
EATON Bussmann MV fuse links
65
7.2 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 7.2 kV
Current: 6.3 - 160 A
Breaking capacity: 20 - 40 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
A Tags
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
Dimensions - mm
Tags type
A
C&D
F
Code
ADGHA
BFGHA
ADFHC
BDGHC
BFGHD
ADFHF
BDGHF
A
359
359
356
461
461
356
461
B
N/A
N/A
314
419
419
314
419
C
N/A
N/A
254
359
359
254
359
Dø
51
76
51
51
76
51
51
AFFHF
BFGHF
356
461
314
419
254
359
76
76
F Tags
C & D Tags
66
EATON Bussmann MV fuse links
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking
capacity I1 ( kA)
Cold resistance
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
7.2ADFH*6.3
6.3
20
206
4.8 x 101
5.6 x 102
254
50.8
1.5
7.2ADFH*10
10
20
83
7.2 x 101
9.4 x 102
254
50.8
1.5
7.2ADFH*16
16
20
52.3
7.2 x 101
8.6 x 102
254
50.8
1.5
7.2ADFH*20
20
20
41.8
1.1 x 102
1.5 x 103
254
50.8
1.5
7.2ADFH*25
25
20
31.5
2 x 102
2.6 x 103
254
50.8
1.5
7.2ADFH*31.5
7.2ADFH*40
7.2ADFH*50
31.5
40
50
20
20
20
22.8
15.6
11.8
3.8 x 102
8 x 102
1.3 x 103
4.8 x 103
1.1 x 104
254
254
50.8
50.8
1.5
1.5
1.4 x 104
254
50.8
1.5
7.2ADFH*63
63
20
8.41
3
2.5 x 10
2.9 x 104
254
50.8
1.5
7.2AFFH*80
80
20
5.83
6.3 x 103
6.9 x 104
254
50.8
1.5
7.2AFFH*100
100
20
4.38
9.8 x 103
1.4 x 105
254
50.8
1.5
7.2BDGH*6.3
6.3
40
206
5.1 x 101
6 x 102
359
50.8
2.1
7.2BDGH*10
10
40
83
1 x 102
1.3 x 103
359
50.8
2.1
7.2BDGH*16
16
40
52.3
8.4 x 101
1 x 103
359
50.8
2.1
7.2BDGH*20
7.2BDGH*25
7.2BDGH*31.5
20
25
31.5
40
40
40
41.8
31.4
22.8
1.1 x 102
2 x 102
4.6 x 102
1.5 x 103
2.6 x 103
359
359
50.8
50.8
2.1
2.1
5.8 x 103
359
50.8
2.1
7.2BDGH*40
40
40
15.7
8 x 102
1.1 x 104
359
50.8
2.1
7.2BDGH*50
50
40
11.8
1.6 x 103
1.8 x 104
359
50.8
2.1
7.2BDGH*63
63
40
7.48
3.6 x 103
4.3 x 104
359
50.8
2.1
7.2BDGH*80
80
40
5.82
6.4 x 103
7 x 104
359
50.8
2.1
7.2BFGH*90
90
40
4.72
1 x 104
1.4 x 105
359
76.2
4.2
7.2BFGH*100
7.2BFGH*125
7.2BFGH*140
100
125
140
40
40
40
45
3.15
2.57
1.3 x 104
1.6 x 104
2.4 x 104
1.9 x 105
1.9 x 105
359
359
76.2
76.2
4.2
4.2
3.3 x 105
359
76.2
4.2
7.2BFGH*160
160
40
2.35
2.9 x 10
4 x 105
359
76.2
4.2
4
* The fifth letter or number of the part reference denotes the end fixing arrangement.
There are a wide variety of end terminations available, the most popular types, some of which have
dimensional references to BS2692: Part 1, are:
•
ADFHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
ADFHF: F Offset tags two bolt fixing
•
AFFHD: D Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
AFFHF: F Offset tags two bolt fixing
•
BDGHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
BDGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHABDGHF
•
BFGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
BFGHF: F Offset tags two bolt fixing
See previous page for outline drawings and dimensions.
Other tag variants available please consult Bussmann application engineers:
[email protected]
EATON Bussmann MV fuse links
67
12 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 12 kV
Current: 6.3 - 125 A
Breaking capacity: 12 - 40 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
A Tags
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit.
•
Used in fuse bases.
•
Used in fuse switches.
F Tags
Dimensions - mm
Tags Type
A
C&D
F
Code
BDGHA
AKGHA
BFGHA
ADFHC
BDGHC
AFFHD
AKGHD
BFGHD
ADFHF
BDGHF
AFFHF
AKGHF
BFGHF
A
359
359
359
356
461
356
461
461
356
461
356
461
461
B
N/A
N/A
N/A
314
419
314
419
419
314
419
314
419
419
C
N/A
N/A
N/A
254
359
254
359
359
254
359
254
359
359
Dø
51
76
76
51
51
76
76
76
51
51
76
76
76
C & D Tags
30mm
ø14mm
30mm
ø14mm
45mm
45mm
50mm
Tag 49
68
EATON Bussmann MV fuse links
50mm
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking
capacity I1 ( kA)
Cold resistance
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
12ADFH*6.3
12ADFH*10
6.3
10
12
12
356
89.8
4.8 x 101
1.3 x 102
5 x 102
254
50.8
1.5
2 x 103
254
50.8
1.5
12ADFH*16
16
12
56.5
1.3 x 102
2 x 103
254
50.8
1.5
12ADFH*20
20
12
36.2
3.1 x 102
3.5 x 103
254
50.8
1.5
12ADFH*25
25
12
28.3
5.1 x 102
6.1 x 103
254
50.8
1.5
12ADFH*31*5
31.5
12
22.6
8 x 102
9 x 103
254
50.8
1.5
12AFFH*40
12AFFH*50
12AFFH*63
40
50
63
12
12
12
21.8
15.7
12.5
1.2 x 103
2 x 103
3.1 x 103
1.5 x 104
2.5 x 104
254
254
76.2
76.2
2.8
2.8
3.9 x 104
254
76.2
2.8
12BDGH*6.3
6.3
40
356
1
5.2 x 10
5 x 102
359
50.8
2.1
12BDGH*10
10
40
138
6.4 x 101
1 x 103
359
50.8
2.1
12BDGH*16
16
40
87
6.4 x 101
1 x 103
359
50.8
2.1
12BDGH*20
20
40
63.3
1.6 x 102
1.8 x 103
359
50.8
2.1
12BDGH*25
25
40
43.5
3.2 x 102
3.8 x 103
359
50.8
2.1
12BDGH*31.5
31.5
40
32.6
5.8 x 102
6.5 x 103
359
50.8
2.1
12BDGH*40
12BDGH*45
12BDGH*50
40
45
50
40
40
40
21.8
17.5
14.5
1.2 x 103
1.8 x 103
2.5 x 103
1.5 x 104
2.3 x 104
359
359
50.8
5t0.8
2.1
2.1
3.2 x 104
359
50.8
2.1
12BFGH*56
56
40
14.6
3
2.9 x 10
3.7 x 104
359
76.2
4.2
12BFGH*63
63
40
12.8
3.4 x 103
4.5 x 104
359
76.2
4.2
12BFGH*71
71
40
10.6
4.6 x 103
6.3 x 104
359
76.2
4.2
12BFGH*80
80
40
9.73
6.1 x 103
7.8 x 104
359
76.2
4.2
12BFGH*90
90
40
8.37
8.1 x 103
1 x 105
359
76.2
4.2
12BFGH*100
12AKGH*112
12AKGH*125
100
112
125
40
20
20
6.88
5.25
4.92
1.1 x 103
1.5 x 104
2.1 x 104
1.4 x 105
1.9 x 105
359
359
76.2
76.2
4.2
4.3
2.4 x 105
359
76.2
4.3
Full range
12FFGN4910
12FFGN4916
10
16
40
40
90.6
69.1
2.7 x 102
4.2 x 102
4.7 x 103
359
76.2
4.1
6.1 x 103
359
76.2
4.1
12FFGN4920
20
40
45.8
9.5 x 102
1.1 x 104
359
76.2
4.1
12FFGN4925
25
40
36.5
1.6 x 103
1.5 x 104
359
76.2
4.1
12FFGN4931.5
12FFGN4940
12FFGN4950
31.5
40
50
40
40
40
25.4
19.7
14.7
3.1 x 103
4.7 x 103
8.4 x 103
2.5 x 104
3.8 x 104
359
359
76.2
76.2
4.1
4.1
5.6 x 104
359
76.2
4.1
12FFGN4963
63
40
12.6
6.3 x 103
5.4 x 104
359
76.2
4.1
* The fifth letter or number of the part reference denotes the end fixing arrangement.
There are a wide variety of end terminations available, the most popular types, some of which have
dimensional references to BS2692: Part 1, are:
•
ADFHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
ADFHF: F Offset tags two bolt fixing
•
AFFHD: D Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
AFFHF: F Offset tags two bolt fixing
•
AKGHD: D Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
AKGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
AKGHF: F Offset tags two bolt fixing
•
BDGHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
BDGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
BDGHF: F Offset tags two bolt fixing
•
BFGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
BFGHF: F Offset tags two bolt fixing
•
FFGN49: 49 Centre tags, single bolt fixing for use in Fused End Boxes
See opposite page for outline drawings and dimensions.
Other tag variants available please consult Bussmann application engineers: [email protected]
EATON Bussmann MV fuse links
69
15.5 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 15.5 kV
Current: 6.3 - 85 A
Breaking capacity: 20 - 40 kA
A Tags
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
F Tags
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit, fuse bases and fuse
switches.
Dimensions - mm
Tags Type
A
C&D
F
Code
BDGHA
BFGHA
BDGHC
BFGHD
BDGHF
BFGHF
A
359
359
461
461
461
461
B
N/A
N/A
419
419
419
419
C
N/A
N/A
359
349
359
359
Dø
51
76
51
76
51
76
C & D Tags
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity Cold resistance
I1 ( kA)
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
15.5BDGH*6.3
6.3
20
485
4.8 x 101
8.5 x 102
359
50.8
2.1
15.5BDGH*10
10
20
158
1
7.2 x 10
1.2 x 103
359
50.8
2.1
15.5BDGH*16
16
20
99.1
7.2 x 101
1.2 x 103
359
50.8
2.1
15.5BDGH*20
20
20
74.6
1.3 x 102
2.8 x 103
359
50.8
2.1
15.5BDGH*25
25
20
54.2
2.4 x 102
4.3 x 103
359
50.8
2.1
15.5BDGH*31.5
31.5
20
38.2
4.9 x 102
7 x 103
359
50.8
2.1
15.5BDGH*40
15.5BFGH*50
15.5BFGH*63
40
50
63
20
20
20
27.2
22.2
15.5
9.6 x 102
1.6 x 103
3.2 x 103
1.2 x 104
3.2 x 104
359
359
50.8
76.2
2.1
4.2
4.6 x 104
359
76.2
4.2
15.5BFGH*80
80
20
9.73
7.2 x 103
1 x 105
359
76.2
4.2
15.5BFGH*85
85
20
9.45
7.2 x 103
1 x 105
359
76.2
4.2
* The fifth letter or number of the part reference denotes the end fixing arrangement.
There are a wide variety of end terminations available, the most popular types, some of which have dimensional references to BS2692: Part 1, are:
•
BDGHC: C Special offset tags, two hole fixings for Brush fuse switch equipment , BS Ref TA3
•
BDGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA / BDGHF: F Offset tags two bolt fixing
•
BFGHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA / BFGHF: F Offset tags two bolt fixing
70
EATON Bussmann MV fuse links
24 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 24 kV
Current: 6.3 - 90 A
Breaking capacity: 12 - 35.5 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
A Tags
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Tags Type
A
Code
ADIHA
FDIHA
AFIHA
A
565
565
565
Dø
51
51
76
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit, fuse bases and fuse
switches.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Cold resistance
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
24ADIHA6.3
6.3
12
520
7.9 x 101
8.5 x 102
565
50.8
3
24ADIHA10
10
12
173
7.2 x 10
1.1 x 102
565
50.8
3
24ADIHA16
16
12
129
1.3 x 102
1.7 x103
565
50.8
3
24ADIHA20
24ADIHA25
24ADIHA31.5
20
25
31.5
12
12
12
104
82.7
66.2
2 x 102
3.1 x 102
4.9 x 102
2.8 x 103
4.1 x 103
565
565
50.8
50.8
3
3
6.8 x 103
565
50.8
3
24AFIHA40
40
16
46.5
1.2 x 103
1.1 x 104
565
76.2
6.1
24AFIHA50
50
16
33.2
2.4 x 103
2.2 x 104
565
76.2
6.1
24AFIHA63
63
16
23.5
3.2 x 103
5.2 x 104
565
76.2
6.1
24AFIHA80
80
16
17.9
5.5 x 103
8.2 x 104
565
76.2
6.1
24AFIHA90
90
16
14.7
7.2 x 103
1 x 105
565
76.2
6.1
Full range
24FDIHA3.15
24FDIHA5
24FDIHA6.3
3.15
5
6.3
35.5
35.5
35.5
893
412
412
3.1 x 101
5.9 x 101
5.9 x 101
9.8 x 101
4.5 x 102
565
565
50.8
50.8
3
3
4.5 x 102
565
50.8
3
24FDIHA10
10
35.5
205
2.7 x 102
2.1 x 103
565
50.8
3
24FDIHA16
16
35.5
103
1.1 x 103
8.3 x 103
565
50.8
3
24FDIHA20
20
35.5
88.2
1.3 x 103
4.8 x 103
565
50.8
3
24FDIHA31.5
31.5
35.5
56
5.3 x 103
2 x 104
565
50.8
3
1
There are a wide variety of end terminations available, the most popular types, some of which have dimensional references to BS2692: Part 1, are:
•
ADIHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
AFIHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
FDIHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
Other tag variants available please consult Bussmann application engineers [email protected]
EATON Bussmann MV fuse links
71
36 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 36 kV
Current: 3.15 - 71 A
Breaking capacity: 12 - 35.5 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
A Tags
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Tags type
A
Code
ADIHA
AFIHA
AFKHA
A
565
565
914
Dø
51
76
76
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit, fuse bases and fuse
switches.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity
I1 ( kA)
Cold resistance
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
36ADIHA3.15
36ADIHA5
3.15
5
16
16
1460
973
2 x 101
4.4 x 101
2.5 x 102
565
50.8
3
5.5 x 102
565
50.8
3
36ADIHA6-3
6.3
16
781
7.1 x 101
8.9 x 102
565
50.8
3
36ADIHA10
10
16
378
7.2 x 101
1.1 x 103
565
50.8
3
36ADIHA16
36ADIHA20
36ADIHA25
16
20
25
16
16
16
190
142
115
1.1 x 102
2 x 102
3.1 x 102
1.7 x 103
2.8 x 103
565
565
50.8
50.8
3
3
4.5 x 103
565
50.8
3
36ADIHA31.5
31.5
16
81.5
6.1 x 102
8.1 x 103
565
50.8
3
36AFIHA40
40
25
61.5
1.2 x 103
1.9 x 104
565
76.2
6.1
36AFKHA50
50
25
54.5
1.9 x 103
2.8 x 104
914
76.2
9.7
36AFKHA63
63
25
40.6
3.5 x 103
5 x 104
914
76.2
9.7
36AFKHA71
71
25
32.5
5.5 x 103
8.2 x 104
914
76.2
9.7
There are a wide variety of end terminations available, the most popular types, some of which have
dimensional references to BS2692: Part 1, are:
•
ADIHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
AFIHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
•
AFKHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
See previous page for outline drawings and dimensions.
Other tag variants available please consult Bussmann application engineers.
72
EATON Bussmann MV fuse links
72.5 kV - British standard air fuse links
Specifications
Description
Air fuse links for the protection of primary side transformer. They
are also used in fuse switch combination unit, fuse bases and
fuse switches
Ratings
Voltage: 72.5 kV
Current: 3.15 - 40 A
Breaking capacity: 12 kA
Agency information
Comply with BS 2962-1 dimensions.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
A Tags
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
Silver elements ensuring high conductivity and low power
(revenue) loss.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions - mm
Tags type
A
Code
AFKHA
A
914
Dø
76
Typical applications
•
Primary side transformer protection.
•
Used in fuse switch combination unit, fuse bases and fuse
switches.
Part numbers and technical data
Joule integral (I2t)
Part numbers
Current In (A)
Breaking capacity I1 ( kA)
Cold resistance
mΩ
Minimum
pre-arcing
Maximum
operating
Length
mm
Diameter
mm
Weight
kg
72.5AFKHA3.15
3.15
12
4230
1.4 x 101
1.8 x 102
914
76.2
9.7
72.5AFKHA5
5
12
1600
1.1 x 102
1.4 x 103
914
76.2
9.7
72.5AFKHA6.3
6.3
12
1200
1.9 x 102
2.5 x 103
914
76.2
9.7
72.5AFKHA10
10
12
519
7.2 x 101
9.3 x 102
914
76.2
9.7
72.5AFKHA16
16
12
389
1.3 x 102
1.7 x 103
914
76.2
9.7
72.5AFKHA20
72.5AFKHA25
72.5AFKHA31.5
20
25
31.5
12
12
12
249
195
130
3.1 x 102
5.1 x 102
1 x 103
4 x 103
6.6 x 103
914
914
76.2
76.2
9.7
9.7
1.3 x 104
914
76.2
9.7
72.5AFKHA40
40
12
92.7
2 x 103
2.6 x 104
914
76.2
9.7
The fifth letter or number of the part reference denotes the end fixing arrangement.
There are a wide variety of end terminations available, the most popular types, some of which have
dimensional references to BS2692: Part 1, are:
•
AFKHA: A No tags - Ferrule - BS Ref. FA3 ADIHA / BS Ref FA4 AFIHA / BS Ref FA5 - AFKHA
Other tag variants available please consult Bussmann application engineers [email protected]
EATON Bussmann MV fuse links
73
US style E-Rated medium voltage fuse links
E-Rated DIN Fuse links
5.5 kV to 38 kV
75
E-Rated fuse links for transformers and feeder protection
5.5 kV
77
8.25 kV
79
15.5 kV
80
E-Rated fuse links for potential and small power transformers
JCX, JCY, JCU, JCZ and JDZ
82
JCD, JCW, JCE, JCQ, JCI and JCT
84
5 - 38 kV
85
CL-14 and bolt-in
5.5 kV
86
8.3 kV
87
15.5 kV
88
R-Rated fuse links for motor circuit protection
74
EATON Bussmann MV fuse links
89
5.5 kV to 38 kV E-Rated DIN Fuse links
Specifications
Description
DIN dimensional E-Rated power fuse links with striker fitted for
indoor use.
Agency
Meets E Requirements per ANSI C37.46, meets general purpose
and full range requirements per ANSI C37.40.
Ratings
Voltage: 5.5 - 38 kV
Current: 10 - 450 E
IR: 25 - 65 kA
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Medium voltage transformer primary protection.
•
Medium voltage feeder circuit protection.
Part numbers and technical data
Part numbers
5.5 kV General purpose
55GDMSJ10E
55GDMSJ15E
55GDMSJ20E
55GDMSJ25E
55GDMSJ30E
55GDMSJ40E
55GDMSJ50E
55GDMSJ65E
Current
Interrupting capacity
sym kA
Number of barrels
Length inches (mm)
Diameter inches (mm)
10E
15E
20E
25E
30E
40E
50E
65E
65
65
65
65
65
65
65
65
1
1
1
1
1
1
1
1
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
55GDMSJ80E
55GDMSJ100E
55GDMSJ125E
55GFMSJ150E
55GFMSJ175E
55GFMSJ200E
55GFMSJ250E
55GFMSJ300E
55GFMSJ350E
55GFMSJ400E
55GFMSJ450E
80E
100E
125E
150E
175E
200E
250E
300E
350E
400E
450E
65
65
65
65
65
65
65
65
65
65
65
1
1
1
1
1
1
1
1
1
1
1
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
17.40 (442)
2 (51)
2 (51)
2 (51)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
15.5 kV General purpose
155GXQSJ175E
155GXQSJ200E
175E
200E
65
65
1
1
21.14 (537)
21.14 (537)
3.5 (88)
3.5 (88)
EATON Bussmann MV fuse links
75
5.5 kV to 38 kV E-Rated DIN Fuse links
Part numbers and technical data
Part numbers
17.5 kV General purpose
175GDMSJ10E
Current
Interrupting capacity
sym kA
Number of barrels
Length inches (mm)
Diameter inches (mm)
10E
65
1
17.40 (442)
2 (51)
175GDMSJ15E
15E
65
1
17.40 (442)
2 (51)
175GDMSJ20E
20E
65
1
17.40 (442)
2 (51)
175GDMSJ25E
175GDMSJ30E
25E
30E
65
65
1
1
17.40 (442)
17.40 (442)
2 (51)
2 (51)
175GFMSJ40E
175GFMSJ50E
40E
50E
65
65
1
1
17.40 (442)
17.40 (442)
3 (76)
3 (76)
175GFMSJ65E
65E
65
1
17.40 (442)
3 (76)
175GXMSJ80E
80E
65
1
17.40 (442)
3.5 (88)
175GXMSJ100E
175GXQSJ125E
175GXQSJ150E
100E
125E
150E
65
65
65
1
1
1
17.40 (442)
21.14 (537)
21.14 (537)
3.5 (88)
3.5 (88)
3.5 (88)
25.8 kV Full range
258GDQSJ10E
258GDQSJ15E
258GDQSJ20E
258GDQSJ25E
258GDQSJ30E
258GXQSJ40E
258GXQSJ50E
258GXQSJ65E
258GXZSJ80E
258GXZSJ100E
10E
15E
20E
25E
30E
40E
50E
65E
80E
100E
25
25
25
25
25
25
25
25
25
25
1
1
1
1
1
1
1
1
1
1
21.14 (537)
21.14 (537)
21.14 (537)
21.14 (537)
21.14 (537)
21.14 (537)
21.14 (537)
21.14 (537)
283 (712)
283 (712)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
3.46 (88)
3.46 (88)
3.46 (88)
3.46 (88)
3.46 (88)
38 kV Full range
38GFZSJ10E
38GFZSJ15E
38GFZSJ20E
38GFZSJ25E
38GFZSJ30E
38GXZSJ40E
38GXZSJ50E
38GXZSJ65E
10E
15E
20E
25E
30E
40E
50E
65E
25
25
25
25
25
25
25
25
1
1
1
1
1
1
1
1
283 (712)
283 (712)
283 (712)
283 (712)
283 (712)
283 (712)
283 (712)
283 (712)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3.46 (88)
3.46 (88)
3.46 (88)
76
EATON Bussmann MV fuse links
5.5 kV E-Rated fuse links for transformers and feeder protection
Specifications
Description
E-Rated power fuse links having Full range clearing capability for
medium voltage transformer circuit protection.
Ratings
Voltage: 5.5 kV
Features and benefits
Current: 5 - 450E
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
IR: 50 kA
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Typical applications
Dimensions
See outline drawings below and part numbers details page 76
•
Medium voltage transformer primary protection.
•
Medium voltage feeder circuit protection.
MV055F1CAX
15.61"
14.77"
.21"
.63"
BUSSMANN
2.03"
Ø2.095"
INDICATOR
POSITION OF BLOWN
INDICATOR AFTER
OPERATING.
12.00"
CLIP CENTER
Double Barrel Dimensions
MV055F1DAX
15.61"
14.77"
2.40"
.21"
BUSSMANN
Ø2.96"
.63"
Ø1.30"
3.50"
INDICATOR
12.00"
CLIP CENTER
Ø3.38"
6.68"
POSITION OF BLOWN
INDICATOR AFTER
OPERATING.
Data Sheet 6700
EATON Bussmann MV fuse links
77
5.5 kV E-Rated fuse links for transformers and feeder protection
Part numbers and technical data
Part numbers
5.5FFNHA30E
Current
30E
Interrupting capacity
sym kA
50
Number of barrels
1
Length inches (mm)
15.87 (403)
Diameter inches (mm)
3 (76)
Clip center
inches (mm)
12 (304)
5.5FFNHA40E
5.5FFNHA50E
40E
50E
50
50
1
1
15.87 (403)
15.87 (403)
3 (76)
3 (76)
12 (304)
12 (304)
5.5FFNHA65E
60E
50
1
15.87 (403)
3 (76)
12 (304)
5.5FFNHA75E
75E
50
1
15.87 (403)
3 (76)
12 (304)
5.5FFNHK100E
100E
50
2
15.87 (403)
3 (76)
12 (304)
5.5FFNHK150E
5.5BFNHA80*
5.5BFNHA100*
5.5BFNHA150*
150E
80A
100A
150A
50
50
50
50
2
1
1
1
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
3 (76)
3 (76)
3 (76)
3 (76)
12 (304)
12 (304)
12 (304)
12 (304)
5.5BKNHA200*
5.5BFNHK250*
5.5BFNHK300*
5.5BFNHK400*
MV055F1CAX5E
MV055F1CAX7E
MV055F1CAX10E
MV055F1CAX15E
MV055F1CAX20E
MV055F1CAX25E
MV055F1CAX30E
MV055F1CAX40E
MV055F1CAX50E
MV055F1CAX65E
MV055F1DAX10E
MV055F1DAX15E
MV055F1DAX20E
MV055F1DAX25E
MV055F1DAX80E
MV055F1DAX125E
MV055F1DAX175E
MV055F1DAX200E
MV055F2DAX250E
MV055F2DAX300E
MV055F2DAX350E
MV055F2DAX400E
MV055F2DAX450E
200A
250A
300A
400A
5E
7E
10E
15E
20E
25E
30E
40E
50E
65E
10E
15E
20E
25E
80E
125E
175E
200E
250E
300E
350E
400E
450E
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
1
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
15.75 (400)
3 (76)
3 (76)
3 (76)
3 (76)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
* These ratings are classed as Back-up fuse links
Data Sheet 6700
78
EATON Bussmann MV fuse links
8.25 kV E-Rated fuse links for transformers and feeder protection
Specifications
Description
E-Rated power fuse links having full range clearing capability for
medium voltage transformer circuit protection.
Ratings
Voltage: 8.25 kV
Current: 80 - 200A, 20 - 150E
IR: 50 kA
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Features and benefits
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Typical applications
•
Medium voltage transformer primary protection.
•
Medium voltage feeder circuit protection.
Part numbers and technical data
Part numbers
8.25FFNHA20E
8.25FFNHA25E
8.25FFNHA30E
8.25FFNHA40E
8.25FFNHA50E
8.25FFNHA65E
8.25FFNHA75E
8.25FFNHK100E
8.25FFNHK150E
8.25BFNHA80*
8.25BFNHA100*
8.25BFNHA150*
8.25BFNHA200*
Current
20E
25E
30E
40E
50E
65E
75E
100E
150E
80A
100A
150A
200A
Interrupting capacity
sym kA
50
50
50
50
50
50
50
50
50
50
50
50
50
Number of barrels
1
1
1
1
1
1
1
2
2
1
1
2
2
Length inches (mm)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87(4t03)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
Diameter inches (mm)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
Clip center
inches (mm)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
12 (304)
* These ratings are classed as back-up fuse links
EATON Bussmann MV fuse links
79
15.5 kV E-Rated fuse links for transformers and feeder protection
Specifications
Description
E-Rated power fuse links having full range clearing capability for
medium voltage transformer circuit protection.
Ratings
Voltage: 15.5 kV
Features and benefits
Current: 5 - 200E
IR: 50 kA
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
•
Cool running, low watts loss and power dissipation thanks to
the M-effect ensuring high levels of substation utilisation.
•
100% X-ray, all our medium voltage fuse links are X-rayed
ensuring the highest possible standards are maintained.
Dimensions
Typical applications
See outline drawings below and part numbers table opposite
page.
•
Medium voltage transformer primary protection.
•
Medium voltage feeder circuit protection.
MV155F1CBX
18.61"
17.77"
2.03"
BUSSMANN
.21"
Ø2.095"
.63"
INDICATOR
POSITION OF BLOWN
INDICATOR AFTER
OPERATING.
15.00"
CLIP CENTER
MV155F1DBX
Double Barrel
Dimensions
18.61"
17.77"
.21"
2.40"
BUSSMANN
.63"
Ø2.96"
Ø1.30"
INDICATOR
Ø3.38"
15.00"
POSITION OF BLOWN
INDICATOR AFTER
OPERATING.
CLIP CENTER
3.50"
MV155F1DCX
21.61"
20.77"
Ø2.96"
BUSSMANN
.21"
2.40"
INDICATOR
Ø3.38"
18.00"
CLIP CENTER
Data Sheet 6701
80
EATON Bussmann MV fuse links
.63"
Ø1.30"
POSITION OF BLOWN
INDICATOR AFTER
OPERATING.
6.68"
Part numbers and technical data
Part numbers
15.5FFVHA15E
15.5FFVHA20E
15.5FFVHA25E
Current
15E
20E
25E
Interrupting capacity
sym kA
50
50
50
Number of barrels
1
1
1
Length inches (mm)
18.86 (479)
18.86 (479)
18.86 (479)
Diameter inches (mm)
3 (76)
3 (76)
3 (76)
Clip center
inches (mm)
15
15
15
15.5FFVHA30E
30E
50
1
18.86 (479)
3 (76)
15
15.5FFVHA40E
40E
50
1
18.86 (479)
3 (76)
15
15.5FFVHA50E
50E
50
1
18.86 (479)
3 (76)
15
15.5FFVHA65E
15.5FFVHA75E
65E
75E
50
50
1
1
18.86 (479)
18.86 (479)
3 (76)
3 (76)
15
15
15.5FFVHK100E
100E
50
2
18.86 (479)
3 (76)
15
15.5FFVHK150E
150E
50
2
18.86 (479)
3 (76)
15
MV155F1CBX5E
MV155F1CBX7E
MV155F1CBX10E
MV155F1CBX15E
MV155F1CBX20E
MV155F1CBX25E
MV155F1CBX30E
MV155F1DBX10E
MV155F1DBX80E
MV155F1DBX100E
MV155F2DBX125E
MV155F2DBX175E
MV155F2DBX200E
MV155F1DCX65E
MV155F1DCX80E
MV155F1DCX100E
MV155F2DCX125E
MV155F2DCX150E
MV155F2DCX175E
MV155F2DCX200E
5E
7E
10E
15E
20E
25E
30E
10E
80E
100E
125E
175E
200E
65E
80E
100E
125E
150E
175E
200E
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
2
2
2
2
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
18.75 (476)
21.75 (552)
21.75 (552)
21.75 (552)
21.75 (552)
21.75 (552)
21.75 (552)
21.75 (552)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
2 (50)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
15
15
15
15
15
15
15
15
15
15
15
15
15
18
18
18
18
18
18
18
Data Sheet 6701
EATON Bussmann MV fuse links
81
JCX, JCY, JCU, JCZ and JDZ E-Rated fuse links for potential and
small power transformers
Specifications
Description
Indoor/enclosure E-rated medium voltage, current-limiting fuse
links for potential & small power transformers with blown fuse
link indication.
Ratings
Voltage: 2.4 - 8.3 kV
Current: ½ - 750A
Breaking capacity: 40 - 63 kA Sym.
Features and benefits
•
Physically dimensioned for retrofitting in existing hardware.
•
Open fuse indicator for ease in troubleshooting.
•
Full range ANSI classification.
Typical applications
•
Medium voltage transformer primary protection.
•
Medium voltage feeder circuit protection.
•
Medium voltage switches.
•
Medium voltage metal-enclosed switchgear.
Part numbers and technical data
JCX-1⁄2E
Voltage
2.4 kV
Current
0.5E
Interrupting capacity
sym kA
40
Number of barrels
1
Length
inches (mm)
9.19 (233)
Diameter inches (mm)
2 (51)
JCX-1E
JCX-2E
JCX-3E
JCX-5E
JCX-7E
JCX-10E
JCX-15E
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
1E
2E
3E
5E
7E
10E
15E
40
40
40
40
40
40
50
1
1
1
1
1
1
1
9.19 (233)
9.19 (233)
9.19 (233)
9.19 (233)
9.19 (233)
9.19 (233)
9.50 (241)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
2 (51)
2.1 (53)
JCX-20E
2.4 kV
20E
50
1
9.50 (241)
2.1 (53)
JCX-25E
JCX-30E
JCX-40E
JCX-50E
JCX-65E
JCX-80E
JCX-100E
JCX-125E
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
2.4 kV
25E
30E
40E
50E
65E
80E
100E
125E
50
50
50
50
50
50
50
50
1
1
1
1
1
1
1
1
9.50 (241)
10.88 (276)
10.88 (276)
10.88 (276)
10.88 (276)
10.88 (276)
10.88 (276)
10.88 (276)
2.1 (53)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
JCX-150E
2.4 kV
150E
50
1
10.88 (276)
3 (76)
JCX-200E
JCX-225E
2.4 kV
2.4 kV
200E
225E
50
50
1
1
10.88 (276)
10.88 (276)
3 (76)
3 (76)
JCX-250E/280X
2.4 kV
250E
50
1
10.88 (276)
3 (76)
JCX-300E/325X
JCX-350E
2.4 kV
2.4 kV
300E
350E
50
50
1
1
10.88 (276)
10.88 (276)
3 (76)
3 (76)
JCX-400X
2.4 kV
400X
50
1
10.88 (276)
3 (76)
JCX-450X
2.4 kV
450X
50
1
10.88 (276)
3 (76)
Part numbers
82
EATON Bussmann MV fuse links
Part numbers and technical data
JCY-1⁄2E
Voltage
5.5 kV
Current
0.5E
Interrupting capacity
sym kA
40
Number of barrels
1
Length
inches (mm)
11.19 (284)
Diameter inches (mm)
2 (51)
JCY-1E
JCY-2E
5.5 kV
5.5 kV
1E
2E
40
40
1
1
11.19 (284)
11.19 (284)
2 (51)
2 (51)
JCY-3E
5.5 kV
3E
40
1
11.19 (284)
2 (51)
JCY-5E
5.5 kV
5E
40
1
11.19 (284)
2 (51)
JCY-7E
JCY-10E
5.5 kV
5.5 kV
7E
10E
40
40
1
1
11.19 (284)
11.19 (284)
2 (51)
2 (51)
JCY-15E
5.5 kV
15E
40
1
11.19 (284)
2 (51)
JCY-20E
5.5 kV
20E
40
1
11.19 (284)
2 (51)
JCY-25E
5.5 kV
25E
40
1
11.19 (284)
2 (51)
JCU-10E
JCU-15E
JCU-20E
JCU-25E
JCU-30E
JCU-40E
JCU-50E
JCU-65E
JCU-80E
JCU-100E
JCU-125E
JCU-150E
JCU-175E
JCU-200E
JCU-250E
JCU-300E
JCU-350E
JCU-400E
JCU-450E
JCU-600E
JCU-750E
JCZ-15E
JCZ-20E
JCZ-25E
JCZ-30E
JCZ-40E
JCZ-50E
JCZ-65E
JCZ-80E
JCZ-100E
JCZ-125E
JCZ-150E
JCZ-200E
JDZ-20E
JDZ-25E
JDZ-30E
JDZ-40E
JDZ-50E
JDZ-65E
JDZ-80E
JDZ-100E
JDZ-125E
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
8.3 kV
10E
15E
20E
25E
30E
40E
50E
65E
80E
100E
125E
150E
175E
200E
250E
300E
350E
400E
450E
600E
750E
15E
20E
25E
30E
40E
50E
65E
80E
100E
125E
150E
200E
20E
25E
30E
40E
50E
65E
80E
100E
125E
50
50
50
50
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
17.81 (452)
12.87 (326)
12.87 (326)
12.87 (326)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
28.81 (731)
28.81 (731)
15.51 (393)
15.51 (393)
15.51 (393)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
17.88 (454)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
15.87 (403)
3 (76)
2.1 (53)
2.1 (53)
2.1 (53)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
4 (101)
4 (101)
2.1 (53)
2.1 (53)
2.1 (53)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
Part numbers
EATON Bussmann MV fuse links
83
JCD, JCW, JCE, JCQ JCI, JCT E-Rated fuse links for potential and
small power transformers
Specifications
Description
Indicating and non-indicating E-Rated medium voltage, current
limiting fuse links for potential and small power transformers.
Ratings
Voltage: 2.4 - 15.5 kV
Current: ½ - 10A
Breaking capacity: 25 - 80 kA Sym.
Typical applications
•
Primary protection of medium voltage potential transformers.
Part numbers and technical data
Voltage
2.4 kV
Current
0.5E
Interrupting capacity
sym kA
63
Number of barrels
1
Length
inches (mm)
4.49 (114)
Diameter inches (mm)
0.8 (20)
JCW-1⁄2E
2.4 kV
2.4 kV
2.4 kV
2.4 kV/5.5 kV
1E
2E
5E
0.5E
40
40
25
40
1
1
1
1
4.49 (114)
4.49 (114)
4.49 (114)
7.31 (185)
0.8 (20)
0.8 (20)
0.8 (20)
1.56 (39)
JCW-1E
JCW-2E
JCW-3E
JCW-4E
JCW-5E
2.4 kV/5.5 kV
2.4 kV/5.5 kV
2.4 kV/5.5 kV
2.4 kV/5.5 kV
2.4 kV/5.5 kV
1E
2E
3E
4E
5E
40
40
40
40
40
1
1
1
1
1
7.31 (185)
7.31 (185)
7.31 (185)
7.31 (185)
7.31 (185)
1.56 (39)
1.56 (39)
1.56 (39)
1.56 (39)
1.56 (39)
Part numbers
JCD-1⁄2E
JCD-1E
JCD-2E
JCD-5E
JCE-1⁄2E
5.5 kV
0.5E
50
1
5.63 (143)
0.8 (20)
JCE-1E
JCE-2E
JCE-3E
JCE-4E
JCE-5E
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
1E
2E
3E
4E
5E
50
50
50
50
50
1
1
1
1
1
5.63 (143)
5.63 (143)
5.63 (143)
5.63 (143)
5.63 (143)
0.8 (20)
0.8 (20)
0.8 (20)
0.8 (20)
0.8 (20)
JCQ-1⁄2E
5.5 kV
0.5E
80
1
9.50 (241)
1.6 (40)
JCQ-1E
5.5 kV
1E
80
1
9.50 (241)
1.6 (40)
JCQ-1-1⁄2E
5.5 kV
1.5E
80
1
9.50 (241)
1.6 (40)
JCQ-3E
JCQ-5E
JCQ-10E
5.5 kV
5.5 kV
5.5 kV
3E
5E
10E
80
80
80
1
1
1
9.44 (239)
9.44 (239)
9.44 (239)
1.6 (40)
1.6 (40)
1.6 (40)
JCI-1⁄2E
8.3 kV
0.5E
80
1
9.50 (241)
1.6 (40)
JCI-3E
JCI-5E
JCI-10E
8.3 kV
8.3 kV
8.3 kV
3E
5E
10E
80
80
80
1
1
1
12.88 (327)
12.88 (327)
12.88 (327)
1.6 (40)
1.6 (40)
1.6 (40)
JCT-1⁄2E
15.5 kV
0.5E
80
1
12.93 (328)
1.6 (40)
JCT-1E
JCT-1-1⁄2E
15.5 kV
15.5 kV
1E
1.5E
80
80
1
1
12.93 (328)
12.93 (328)
1.6 (40)
1.6 (40)
JCT-3E
JCT-5E
JCT-10E
15.5 kV
15.5 kV
15.5 kV
3E
5E
10E
80
80
80
1
1
1
17.50 (444)
17.50 (444)
17.50 (444)
1.6 (40)
1.6 (40)
1.6 (40)
Data Sheet 6002
84
EATON Bussmann MV fuse links
E-Rated fuse links for potential and small power transformers
Specifications
Description
Indicating and non-indicating E-Rated medium voltage, currentlimiting fuses for potential and small power transformers.
Ratings
Voltage: 5 - 38 kV (See Part numbers table for details)
Current: 0.5 - 7E
Breaking capacity: 40 - 80 kA.
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Typical applications
•
Primary protection of medium voltage potential transformers.
Part numbers and technical data
Part numbers
5.5AMWNA0.5E
5.5AMWNA1E
5.5AMWNA2E
5.5AMWNA3E
5.5AMWNA4E
5.5AMWNA5E
5.5ABWNA0.5E
5.5ABWNA1E
5.5ABWNA2E
5.5ABWNA3E
5.5ABWNA5E
5.5CAV15E
5.5CAVH0.5E
5.5CAVH1E
5.5CAVH2E
7.2AMWNA0.5E
7.2AMWNA1E
7.2AMWNA2E
7.2AMWNA3E
7.2AMWNA4E
7.2AMWNA5E
15.5CAV0.5E
15.5CAV1E
15.5CAV2E
15.5CAV3E
15.5CAV5E
15.5CAV7E
Voltage
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
5.5 kV
7.2 kV
7.2 kV
7.2 kV
7.2 kV
7.2 kV
7.2 kV
15.5 kV
15.5 kV
15.5 kV
15.5 kV
15.5 kV
15.5 kV
Current
0.5E
1E
2E
3E
4E
5E
0.5E
1E
2E
3E
5E
15E
0.5E
1E
2E
0.5E
1E
2E
3E
4E
5E
0.5E
1E
2E
3E
5E
7E
Interrupting
capacity sym kA
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
80
80
80
80
80
80
Number of barrels
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Length
inches (mm)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
7.36 (186)
7.36 (186)
7.36 (186)
7.36 (186)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
5.59 (141)
12.87 (326)
12.87 (326)
12.87 (326)
12.87 (326)
12.87 (326)
12.87 (326)
Diameter inches
(mm)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
1 (25)
1 (25)
1 (25)
1 (25)
1 (25)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
0.81 (20)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
Clipping Centres
inches (mm)
6 (152)
6 (152)
6 (152)
6 (152)
11.5 (292)
11.5 (292)
11.5 (292)
11.5 (292)
11.5 (292)
11.5 (292)
15.5CAVH0.5E
15.5CAVH1E
15.5CAVH2E
38CAVH0.5E
38CAVH1E
15.5 kV
15.5 kV
15.5 kV
38 kV
38 kV
0.5E
1E
2E
0.5E
1E
80
80
80
40
40
1
1
1
1
1
12.87 (326)
12.87 (326)
12.87 (326)
17.32 (439)
17.32 (439)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
1.63 (41)
11.5 (292)
11.5 (292)
11.5 (292)
15 (381)
15 (381)
38CAVH2E
38CAV4E
38 kV
38 kV
2E
4E
40
40
1
1
17.32 (439)
17.32 (439)
1.63 (41)
1.63 (41)
15 (381)
15 (381)
EATON Bussmann MV fuse links
85
E-Rated fuse links: 5.5 kV CL-14 and bolt-in
ECL055 Specifications
Description
E-Rated medium voltage, current-limiting fuses for transformer
and feeder protection.
Ratings
Voltage: 5.5 kV E-Rated
Current: 10 - 900 A
Breaking capacity: 63 kA Sym. Max.
Agency information
Meets E requirements per ANSI C37.46, meets general purpose
requirements per ANSI C37.40.
Typical applications
•
5 kV Transformer primary protection.
•
5 kV Feeder circuit protection.
•
5 kV Voltage switches.
•
5 kV Metal-enclosed switchgear.
Part numbers and technical data
Part numbers
ECL055-10E
ECL055-15E
ECL055-20E
ECL055-25E
ECL055-30E
ECL055-40E
ECL055-50E
ECL055-65E
ECL055-80E
ECL055-100E
ECL055-125E
ECL055-150E
ECL055-200E
ECL055-250E
ECL055-300E
ECL055-400E
ECL055-450E
ECL055-500E
ECL055-600E
ECL055-750E
ECL055-900E
Voltage ( kV)
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
5.5
Current (E)
10
15
20
25
30
40
50
65
80
100
125
150
200
250
300
400
450
500
600
750
900
Part numbers Construction (example)
Part numbers
ECL
Voltage rating
055 (055 = 5.5 kV)
Ampere rating
300E
Data Sheet 9002
86
EATON Bussmann MV fuse links
Breaking capacity
(Sym) kA
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
63
Number of barrels
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
3
3
E-Rated fuse links: 8.3 kV CL-14
ECL083 Specifications
Description
E-Rated medium voltage, current-limiting fuses for transformer
and feeder protection.
Ratings
Voltage: 8.3 kV E-Rated
Current: 65 - 350 A
Breaking capacity: 50 kA
Agency information
Meets E requirements per ANSI C37.46, meets general purpose
requirements per ANSI C37.40.
Typical applications
•
8.3 kV Transformer primary protection.
•
8.3 kV Feeder circuit protection.
•
8.3 kV Voltage switches.
•
8.3 kV Metal-enclosed switchgear.
Part numbers and technical data
Part numbers
ECL083-65E
ECL083-80E
ECL083-100E
ECL083-125E
ECL083-150E
ECL083-175E
ECL083-200E
ECL083-250E
ECL083-300E
ECL083-350E
Voltage ( kV)
8.3
8.3
8.3
8.3
8.3
8.3
8.3
8.3
8.3
8.3
Current (E)
65
80
100
125
150
175
200
250
300
350
Breaking capacity
(Sym) kA
50
50
50
50
50
50
50
50
50
50
Number of barrels
1
1
1
1
1
1
2
2
2
2
Part numbers construction (example)
Part numbers
ECL
Voltage rating
083 (0.83 = 8.3 kV)
Ampere rating
300E
EATON Bussmann MV fuse links
87
E-Rated fuse links: 15.5 kV CL-14
ECL155 Specifications
Description
E-Rated medium voltage, current-limiting fuses for transformer
and feeder protection.
Ratings
Voltage: 15.5 kV E-Rated
Current: 10 - 300A
Breaking capacity: 63 kA Sym. (10-200 A)
50 kA Sym. (250-300 A)
Agency information
Meets E requirements per ANSI C37.46, meets general purpose
requirements per ANSI C37.40.
Typical applications
•
15 kV Transformer primary protection.
•
15 kV Feeder circuit protection.
•
15 kV Voltage switches.
•
15 kV Metal-enclosed switchgear.
Part numbers and technical data
Part numbers
ECL155-10E
ECL155-15E
ECL155-20E
ECL155-25E
ECL155-30E
ECL155-40E
ECL155-50E
ECL155-65E
ECL155-80E
ECL155-100E
ECL155-125E
ECL155-150E
ECL155-200E
ECL155-250E
ECL155-300E
Voltage ( kV)
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
15.5
Current (E)
10
15
20
25
30
40
50
65
80
100
125
150
200
250
300
Part numbers construction (example)
Part numbers
ECL
Voltage rating
Ampere rating
155 (155 = 15.5 kV) 300E
Data Sheet 9004
88
EATON Bussmann MV fuse links
Breaking capacity
(Sym) kA
63
63
63
63
63
63
63
63
63
63
63
63
63
50
50
Number of barrels
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
R-Rated fuse links for motor circuit protection
Specifications
Description
Indoor/enclosure R-Rated medium voltage, current-limiting fuse
links for motor circuit protection.
Ratings
Voltage: 2.4 - 7.2 kV
Current: 25 - 450A
Breaking capacity: 50 kA Sym
Agency information
UL recognized: 2540Vac — JCK, JCK-A, 5080Vac — JCL, JCL-A,
UL recognized (Guide #MSSS2, File #E96676).
Typical applications
•
Medium voltage motor controllers.
Figure 1
Figure 2
Figure 3
Data Sheet 6001
EATON Bussmann MV fuse links
89
R-Rated fuse links for motor circuit protection
Part numbers and technical data
Current
Part numbers
(A)
2400V (see figure 1 page 89)
JCK-2R
70A
Interrupting
capacity sym kA
Number of barrels
Length in (mm)
Diameter in
(mm)
50
1
11.24 (285)
3 (76)
JCK-3R
100A
50
1
11.24 (285)
3 (76)
JCK-4R
130A
50
1
11.24 (285)
3 (76)
JCK-5R
JCK-6R
150A
170A
50
50
1
1
11.24 (285)
11.24 (285)
3 (76)
3 (76)
JCK-9R
JCK-12R
200A
230A
50
50
1
1
11.24 (285)
11.24 (285)
3 (76)
3 (76)
JCK-18R
390A
50
2
11.24 (285)
3 (76)
JCK-24R
450A
50
2
11.24 (285)
3 (76)
2400V - With Westinghouse ampguard hookeye (see figure 1 page 89)
JCK-A-2R
70A
50
1
JCK-A-3R
100A
50
1
JCK-A-4R
130A
50
1
JCK-A-5R
150A
50
1
JCK-A-6R
170A
50
1
JCK-A-9R
200A
50
1
JCK-A-12R
230A
50
1
JCK-A-18R
390A
50
2
JCK-A-24R
450A
50
2
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
11.24 (285)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
2400V - Bolt-on (see figures 2 and 3 page 89)
JCK-B-30
25A
50
JCK-B-2R
70A
50
JCK-B-3R
100A
50
JCK-B-4R
130A
50
JCK-B-5R
150A
50
JCK-B-6R
170A
50
JCK-B-9R
200A
50
JCK-B-12R
230A
50
JCK-B-18R
390A
50
JCK-B-24R
450A
50
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
14.18 (360)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
2400V - Hermetically sealed, for use with ampguard motor starters (see figure 1 page 89)
JCH-30
25A
50
1
10.81 (275)
JCH-2R
70A
50
1
10.81 (275)
3 (76)
3 (76)
JCH-3R
JCH-4R
JCH-5R
JCH-6R
JCH-9R
JCH-12R
JCH-18R
JCH-24R
100A
130A
150A
170A
200A
230A
390A
450A
4800V (see figure 1 page 89)
JCL-2R
70
JCL-3R
100
JCL-4R
130
JCL-5R
150
JCL-6R
170
JCL-9R
200
JCL-12R
230
JCL-18R
390
JCL-24R
450
50
50
50
50
50
50
50
50
1
1
1
1
1
1
2
2
10.81 (275)
10.81 (275)
10.81 (275)
10.81 (275)
10.81 (275)
10.81 (275)
10.81 (275)
10.81 (275)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
50
50
50
50
50
50
50
50
50
1
1
1
1
1
1
1
2
2
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
15.76 (400)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
3 (76)
Data Sheet 6001
90
1
1
1
1
1
1
1
1
2
2
EATON Bussmann MV fuse links
R-Rated fuse links for motor circuit protection
Part numbers and technical data
Current
Interrupting
Part numbers
(A)
capacity sym kA
Number of barrels
4800V - With Westinghouse ampguard hookeye (see figure 1 page 89)
JCL-A-2R
70
50
1
15.76 (400.3)
3 (76.2)
JCL-A-3R
100
50
1
15.76 (400.3)
3 (76.2)
JCL-A-4R
130
50
1
15.76 (400.3)
3 (76.2)
JCL-A-5R
JCL-A-6R
150
170
50
50
1
1
15.76 (400.3)
15.76 (400.3)
3 (76.2)
3 (76.2)
JCL-A-9R
JCL-A-12R
200
230
50
50
1
1
15.76 (400.3)
15.76 (400.3)
3 (76.2)
3 (76.2)
JCL-A-18R
390
50
2
15.76 (400.3)
3 (76.2)
JCL-A-24R
450
50
2
15.76 (400.3)
3 (76.2)
4800V - Bolt-on (see figures 2 and 3 page 89)
JCL-B-30
30
50
JCL-B-2R
70
50
JCL-B-3R
100
50
JCL-B-4R
130
50
JCL-B-5R
150
50
JCL-B-6R
170
50
JCL-B-9R
200
50
JCL-B-12R
230
50
JCL-B-18R
390
50
JCL-B-24R
450
50
1
1
1
1
1
1
1
1
2
2
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
4800V - Hermetically sealed, for use with ampguard motor starters (see figure 1 page 89)
JCG-30
30
50
1
15.91 (404.1)
JCG-2R
70
50
1
15.91 (404.1)
JCG-3R
100
50
1
15.91 (404.1)
JCG-4R
130
50
1
15.91 (404.1)
JCG-5R
150
50
1
15.91 (404.1)
JCG-6R
170
50
1
15.91 (404.1)
JCG-9R
200
50
1
15.91 (404.1)
JCG-12R
230
50
1
15.91 (404.1)
JCG-A-18R
390
50
2
15.91 (404.1)
JCG-A-24R
450
50
2
15.91 (404.1)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
7200V - With ampguard hookeye (see figure 1 page 89)
JCR-A-2R
70
50
JCR-A-3R
100
50
JCR-A-4R
130
50
JCR-A-5R
150
50
JCR-A-6R
170
50
JCR-A-9R
200
50
1
1
1
1
1
1
15.85 (402.6)
15.85 (402.6)
15.85 (402.6)
15.85 (402.6)
15.85 (402.6)
15.85 (402.6)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
3 (76.2)
JCR-A-12R
JCR-A-18R
JCR-A-24R
50
50
50
1
2
2
15.85 (402.6)
15.85 (402.6)
15.85 (402.6)
3 (76.2)
3 (76.2)
3 (76.2)
7200V - Bolt-on (see figures 2 and 3 page 87)
JCR-B-2R
70
50
JCR-B-3R
100
50
JCR-B-4R
130
50
JCR-B-5R
150
50
JCR-B-6R
170
50
JCR-B-9R
200
50
JCR-B-12R
230
50
JCR-B-18R
390
50
JCR-B-24R
450
50
1
1
1
1
1
1
1
2
2
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
19.25 (488.9)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
3.31 (84.1)
230
390
450
Length in (mm)
Diameter in
(mm)
Data Sheet 6001
EATON Bussmann MV fuse links
91
Fuse clips
•
VT Fuse Clips for 25.4mm diameter.
•
DIN standard Clips for ‘F’ and ‘T’ range fuse links.
•
BS Mounting Clips suitable for 50.8mm and 76.2mm Oil, Air,
and Motor Fuse Links up to 200A.
Bussmann fuse clips
To complement the range of tag fixings offered by Bussmann, a
range of fuse clips are available. These are suitable for use with
British Standard, DIN Dimensioned and VT ferrule style fuse
links. The BS and DIN Clips are rated up to 200 Amps. They are
designed to be fitted onto insulated studs or directly onto a busbar.
Fuse clips
DIN fuse links to 43625
Voltage transformer and auxiliary type fuse links
British standard fuse links
Clip reference
270303 or A3354745
A3354705
50.8mm (2”) diameter
63.5mm (2”) diameter
76.2mm (2”) diameter
A3354710
A3354720
A3354730
Clips for 25.4mm VT Fuse links
Material
Nickel silver alloy.
Order as part number: A3354705#
Clips for DIN Fuse links
Material
Nickel-plated copper
Order as part number: 270303
Suitable for use with Bussmann DIN
fuse links. Also suitable for use with
other Bussmann fuse links having type
‘J’ end tags, to DIN 43625, with maximum current rating of 200 Amps
Clips for British standard and DIN Style fuse
links
Material
Nickel-plated copper
Order as part numbers:
A3354745 for 45mm diameter
A3354710 for 50.8mm diameter
A3354720 for 63.5mm diameter
A3354730 for 76.2mm diameter
92
EATON Bussmann MV fuse links
Expulsion fuse links for use in high voltage distribution cut-outs
•
Wide range of options available from 15 kV to 72 kV in ANSI T
& K characteristics.
•
Extra rapid option also available.
Bussmann expulsion fuse links
Bussmann expulsion fuse links have been widely used throughout
the world for over 40 years. They have in that time built up a formidable reputation and consistency of performance.
Bussmann expulsion fuse links are designed to be interchangeable
with other types of manufacturers cut-out units and are available
in several patterns.
Application
Expulsion fuse links current ratings should be selected on the
basis of maximum expected transient no damage currents rather
than on full load current. In addition, the selection of higher current ratings will reduce the possibility of supply interruption due
to transient surges such as those due to lightning strikes (for
information on our Surge Protection Device SPD, please contact
[email protected]
Links should be handled with a reasonable degree of care when
installing. Excessively rough handling may damage the element.
It is normal, under certain fault conditions, for arc extinguishing material and/or metal particles to be expelled from the fuse
assembly. It is therefore recommended that reasonable precautions be taken to prevent the installation being approached by
unauthorised persons.
How to order — Parts referencing system
Voltage ( kV)
15
25
46
72
1st Letter
Type of current characteristics
T = complies with ANSI C 37-42 requirements for slow acting T
characteristics.
K = complies with ANSI C 37-42 requirements for fast acting K
characteristics.
XA = this type of expulsion fuse link has an extra rapid characteristic. It is suitable for applications where a high degree of system
protection is required at the expense of discrimination.
S = Solid links rated at 100A only are also available in both button
head and universal versions for fitting into expulsion fuse carriers
where required. These can be ordered in a similar way using the
abbreviation S, e.g. 15SB100, etc.
2nd letter
Type of termination
B = a fixed NEMA button head link.
U = a universal link, with double tail and slip off NEMA button
head.
D = double tailed link without NEMA button head.
Current (A)
1 to 6, 7.5, 8,
10, 12, 15, 20,
25, 30, 40, 50,
60, 65, 75, 80,
100.
BR = as pattern B but the button head is attached via a 1/4 UNF
thread to allow use of an extension rod.
See outline drawings opposite page for reference.
Thus a typical ordering reference for a 15 kV NEMA type K, button
head 30A fuse link would be 15KB30 expulsion fuse link.
The fuse link assembly for a given range is standard to all
Voltages. The exception is that the tail length is varied to suit the
dimensions of expulsion carrier of different ratings.
EATON Bussmann MV fuse links
93
Expulsion fuse links
Specifications
Description
Expulsion fuse links available in a wide range of options from 15
kV to 72 kV in ANSI T&K characteristics.
Ratings
Voltage: 15 to 72 kV
Amps: 1 to 100 A
Breaking capacity: depends on voltage but is approximately 8 kA
Agency information
Type T: complies with ANSI C37-42
Type K: complies with ANSI C37-42
Time-current curves and cut-off curves
See list page 118 and data on USB at the back of the catalogue.
Packaging
Up to and including 50A: 25 in a carton.
From 60A to 100A: 10 in a carton.
To avoid incorrect replacement the fuse links have colour coded
labels:
Pink label: Type XA.
Yellow label: Type K.
Green label: Type T.
Typical applications
•
Primary side transformer protection.
•
Feeder protection.
•
Capacitor bank protection.
1-50A
Type kV
15 kV
25 kV
46 kV
72 kV
A
533 (21”)
660 (26”)
787 (31”)
1016 (40”)
Notes:
Type BR is similar to button head shown, except that the button
head is attached via a ¼ UNF thread.
Tails can be cut to any length.
60-100A
94
EATON Bussmann MV fuse links
ASL - Automatic Sectionalising Links
•
Low cost retrofit option for spur line isolation in place of existing expulsion fuse links.
•
Available for up to 33 kV lines.
•
Standard pick-up current ratings of 20, 25, 40, 50, 63, 100
Amps.
•
Other ratings up to 320 Amps available.
•
Available in single or 3-phase ganged arrangements.
•
Enhanced lightning immunity performance.
Bussmann Automatic Sectionalising Link ASL (smart links)
Bussmann low cost retrofit Automatic Sectionalising Link (ASL),
represents a significant breakthrough in the field of high voltage
overhead line distribution system protection. It is a completely
self-contained device designed for use with multi-shot circuit
breakers or auto-reclosers. The ASL was originally developed
by Bussmann from invention by the Electrical Council Research
Centre, now EA technology in the UK.
Bussmann ASL ensures effective overhead spur line isolation in
the event of a geniune local fault, while at the same time remaining unresponsive to transient (temporary) no-damage surge currents, caused by electrical storms etc, see figure 1.
How the sectionaliser works
The sectionaliser houses a logic circuit in its main conductive carrying tube. This ensures the electronic circuitry is free from electrical interference, as the tube acts as an effective Faraday cage and
is powered by a small current transformer mounted on the outside
of the carrier tube.
Statistics show that 90% of expulsion fuse operations on spur
lines are in response to transient no-damage faults and that the
cost for each expulsion fuse link replacement can be of the same
order as the capital cost of a complete fuse cut-out. The alternative approach favoured by some Utilities of replacing expulsion
fuse links by solid links has the major disavantage that any permanent fault on a spur line results in an outage of the whole system.
Bussmann ASL provides an economic solution to the problem, by
ensuring effective spur line isolation in the event of a geniune local
fault, while at the same time remaining unresponsive to transient
no-damage surge currents.
Operation is accomplished by discharging a capacitor into a small
chemical actuator (or ‘striker’) which unlatches the carrier tube and
causes it to swing down. The ASL is reset by fitting a replacement
actuator and re-inserting the carrier into its mount.
The logic circuit is designed to inhibit response to transformer
magnetising inrush current surges and induced current waves
resulting from electrical storms. Therefore, in practice any spur
line fault condition which persists for a time of several seconds
will operate the ASL, so isolating the spur as explained above. Any
transient or ‘no damage’ current will be ignored.
Operational sequence
The logic circuit on the printed circuit board within the ASL is
powered by a small current transformer mounted on the outside
of the conductive carrier tube. Under normal load conditions the
printed circuit board remains inert. However, should the line current increase above a certain pre-set value (the pick-up current)
the logic circuit activates. The upstream auto re-closer then opens,
temporarily removing the fault from the line. The logic circuit,
powered by an internal capacitor, stores the incident for around
25 seconds (the ‘reclaim’ time). When the upstream device recloses, some three to ten seconds later, if the fault current is no
longer in evidence, the ASL will ignore the incident and eventually
reverts to an inert state again. However if the fault current (i.e. a
current above the pick-up value) is still present, the logic circuit
will decide that this represents a permanent fault on the spur line
and will prepare to de-latch. The logic circuit is however, inhibited
from operating the latch mechanism until the upstream recloser
has tripped for the second time and the line current has fallen to
a value of less than 300mA (the ‘hold-off’ current) for a period of
at least 0.1 second. The ASL thus operates during the dead time
of the upstream protective device and does so quietly, without
sparks or ionised gas emission and without contact erosion.
EATON Bussmann MV fuse links
95
ASL - Automatic Sectionalising Links
Main Overhead Line
Auto re-closer
(Pole mounted auto re-closer or circuit
breaker fitted with auto-recloser relay
protection)
Spur LIne
Sectionaliser
TX
TX
Figure 1
FAULT CURRENT
LEVEL OF CURRENT
IN THE MAIN LINE
NOMINAL LOAD CURRENT
AUTO RE-CLOSER
CONTACTS
CLOSED
FIRST PULSE
NOTED AND
STORED IN
SECTIONALISER'S
MEMORY
Sectionaliser Isolating a Spur-Line Fault
Sectionaliser isolating a spur-line fault
96
EATON Bussmann MV fuse links
CLOSED
FAULT
ASL - Automatic Sectionalising Links
a
Mounting arrangements
The contact assemblies of the ASL are adjustable to allow for use with a variety of types of expulsion
fuse mount. Alternative upper contact assemblies are available. These can be either fitted to the ASL
during manufacture or may be provided loose as conversion kits. ASLs can also be provided complete with suitable ‘fuse mounts’ where required.
Applications
The ASL must be used in conjunction with either an upstream circuit breaker having multi-shot
reclose facility or an auto-recloser. In either case the dead time of the device must be appreciably
less than the 25 second ASL reclaim time.
The most useful pick-up current setting is likely to be 100A. This will allow protection of spur line
loads totalling up to 1000 kVA 3-phase (11 kV).
Where the total load is smaller and greater sensitivity to low level faults is required, one of the
alternative lower settings can be supplied. It should be noted that the recommended pick-up current
setting is approximately twice the value of the maximum load current of the connected downstream
transformers.
EATON Bussmann MV fuse links
97
ASL - Automatic Sectionalising Links
Additional information
•
Response time: At inception < 50 ms
•
Weight: 1.6 kg
•
Maximum recommended mounting height: 10 metres
•
Hold off current: > 300 mA
•
The three-phase version is available to suit Moris Line Equipment mounts only, ref. BR1T
Mounting references
Bussmann reference
BR1
Suitable for mount type
S & E Line Equipment, pre. 1967
Actuator part numbers
4772968BS
BR2
BR3
BR5
BR1M
BR1T
C
Brush Power (1967 - 1987)
Hawker Switchgear
J & P (GEC)
Morris Line Equipment
Morris Line Triple Pole Unit
Universal USA, NEMA
4772968BS
4772968BS
4772964BS
4772968BS
4772968BS
4772968BS
Replacement pack of 100 grease sachets
4772717BS
Ordering codes
Symbol
Rating voltage
15
Product type
Pick-up current in
amps
Mounting
arrangements
Number of shots
ASL
100
BR1
2
15
ASL
For example: 15ASL100BR1-2
98
100
EATON Bussmann MV fuse links
BR1
2
Meaning
Sectionaliser to be used in 15 kV cut-outs
Automatic Sectionalising Link (ASL)
The pick-up current wil be set at 100 Amps
Details the contact arrangement for a given fuse mount.
(See mounting references in the table above)
Details the number of current pulses, or shots, the unit will
accept before operating either 1, 2 or 3 multi.
Total Part numbers
Boric acid fuse links
•
Expulsion style fuse link complete with a single-pole porcelain fuse mount.
•
Available from 17 kV to 38 kV, 3 to 200A.
•
Can be used indoors and outdoors.
•
ANSI C.37 and Australian standard AS1033.
Introduction
Bussmann BBU medium voltage boric acid fuse link and complementary fuse
mount or cut-out package is an expulsion fuse link style fuse, complete with a
single-pole porcelain fuse mount offering medium voltage protection for indoor and
outdoor applications.
The fuse mount is available at either 17 or 27 kV and is designed to withstand the
most hazardous environmental conditions. The contact system is made from a copper alloy ensuring a long service life in the field.
The fuse mount already has the outdoor fittings, so simply adding a Bussmann BBU
fuse link will deliver a complete outdoor transformer protection solution.
Bussmann range of BBU fuse links can be used indoors as well as outdoors. A
muffler attachment can be ordered to limit noise and contamination to indoor equipment during operation.
BBU fuse links are designed to be interchangeable with other leading manufacturers and are available from 17 kV through to 38 kV, from 3 to 200 amps, with K, E
and SE time-current characteristics.
Boric acid fuse link employs calibrated silver elements combined with boric acid
crystals for its interruption media. The mechanical utilisation of the spring and rod
mechanism creates an interruption technique that offers mild exhaustion during fault
interruption.
Boric acid fuse links are ideally suited to provide distribution transformer protection
within electrical distribution networks.
Features of BBU Fuses
A complete distribution transformer package from a single source. Bussmann offers
a single source for all of your protection needs, both fuse links and fuse mount are
fully interchangeable with other manufacturers product lines.
Sealed fuse links - All BBU fuse links are sealed from moisture ingress, preventing
deterioration of performance in the fields and improving overall network reliability
while reducing costs.
Fully tested - Bussmann BBU fuse links are tested to both ANSI C.37 and Australian
standard AS1033.1, which due to Australia’s unique landscape and harsh climate, is
widely regarded as the most onerous type test of expulsion fuse link style protection in the world today.
Single piece end fittings - Bussmann fuse link package comes with single piece end
fittings, reducing set-up time in the field and lowering inventory, thereby improving
network productivity.
Single wrench installation - The fuse links are designed to be installed with a single
type of tool, again reducing maintenance, replacement and installation costs.
Other features to improve safety and overall reliability induce the use of a Nichrome
strain element, to reduce susceptibility to spurious operation in the field caused
by vibration and corona, a glass expoxy tube, preventing warping during long time
exposure and permanent date marking facilitating a more robust operation and
maintenance regime.
EATON Bussmann MV fuse links
99
Boric acid fuse links
BBU Fuse link mount construction
Bird proof design insulator provides insulation
characteristics higher than ANSI distribution cutout standards and equal in most cases to ANSI
switch and bus standards
Fuse unit upper end fitting (reusable)
Latch and upper contact assembly
Loadbuster attachment hooks also
provide self guiding action for fuse
unit during closing.
BBU fuse unit replaced after a
fault-clearing operation.
Fuse unit lower end fitting (reusable)
Hinge and lower contact assembly
BBU Fuse construction
Principle parts of the replaceable BBU fuse unit are shown in the cross section view. Main operating
parts are the silver element, arcing rod, boric acid cylinder and spring. A glass epoxy tube encloses
the assembly.
The use of a pure silver element and Nichrome wire stain element makes the BBU less susceptible
to outages caused by vibration, corona corrosion, and aging of the fuse elements. It is not damaged
by transient faults or overloads which approach the minimum melt point.
The components are housed in a fiberglass reinforced resin tube with plated copper contacts.
Positive connection is maintained between the arcing rod and contact with a sliding tulip contact.
BBU End fittings
Fuse unit lower end fitting.
Part number (including muffler):
BBU-EFID
100
Fuse unit upper end fitting.
Part number (including muffler):
BBU-EFID
EATON Bussmann MV fuse links
Muffler part number: BBU-MFLR
Boric acid fuse links
Operation
BBU expulsion fuse links utilise the proven performance of boric
acid to create the de-ionizing action needed to interrupt the current. Fault interruption is achieved by the action of an arcing rod
and a charged spring, elongating the arc through a boric acid
chamber upon release by the fuse element.
At high temperatures, boric acid decomposes, producing a blast
of water vapor and inert boric anhydride. Electrical interruption
is caused by the steam extinguishing the arc, as the arc is being
elongated through the cylinder.
Higher particle turbulence of the boric acid causes the rate of deionization in the cylinder to exceed the ionization of the electrical
arc. Both high and low current faults are interrupted in the same
manner with no foreign material other than the boric acid required.
This enables the fuse to interrupt short-circuit within one half cycle
and prevents the arc from restriking after a current zero.
After interruption, the gases are expelled from the bottom of the
fuse.
The arching rod is prevented from falling back into its original position by a friction stop at the top of the fuse unit.
When the fuse operates, the upward motion of the spring forces
the top of the arcing rod to penetrate the upperseal, striking the
latch mechanism.
Elements melts
Rod withdraws
elongating arc and
vaporizing boric acid
Vapor quenches arc
at first current zero
On indoor applications, this action caused the blown fuse indicator
to actuate.
When replacing the blown fuse link, the end fittings should be
removed from the operated fuse unit, and if undamaged, clamped
onto the new fuse unit.
Application
The BBU Boric acid fuse provides effective protection for circuits
and equipment which operate on voltage system up to 34.5 kV.
They can be used on industrial distribution systems and all fuses
are designed for use on the following:
•
Power transformers.
•
Feeder circuits.
•
Distribution transformers.
•
Metal-enclosed switchgear.
•
Pad mount switches.
BBU fuse units can be used in indoor applications, and can be
used to directly replace competitive equivalent units.
EATON Bussmann MV fuse links
101
Boric acid fuse links
Outdoor BBU Mount
BBU27-PDM
BBU17-PDM
Part numbers and technical data
Part numbers
BBU27-PDM
BBU17-PDM
1Min High voltage
withstand test kV
42
35
Total insulator length
inches (mm)
18.3 (465)
14.8 (375)
Outdoor BBU Fuse fitting
Outdoor end fittings are made of a cast-copper plated alloy.
A large hook eye on the upper fitting allows for easy installation into pole-top mountings with a hook stick. The pivotal
design of this hook eye provides for proper engagement of
the upper live part. The positive locking action of the latch
mechanism prevents detachment from the mounting due to
shock or vibration. In the event of a fault, the arcing rod will
penetrate through the upper end of the fuse unit, and cause
the latch to release. Once released, the fuse will rotate down
into the drop-out position to indicate a blow fuse condition.
The lower end fitting has two cylindrical posts that insert into
the lower live part of the mounting. These posts allow the
fuse to rotate into the proper engaged position, and suspend
the fuse during a blown, drop-out condition.
102
EATON Bussmann MV fuse links
A inches (mm)
20.4 (516.9)
16.8 (426.9)
B inches (mm)
21 (534)
17.5 (444)
Approximate weight (kg)
20
17.5
Boric acid fuse links
Testing
Bussmann BBU Power fuse links and fuse mounts were tested in
compliance to the standards listed below. This testing was carried
out in independent test laboratories in Canada and in Australia by
recognised independent power testings laboratories. Thermal and
interrupting testing was conducted at 17, 27 kV. The entire series
of tests was conducted in a specific sequence as stipulated by
governing standards without any maintenance being performed.
All tests results are verified by laboratory tabulations and oscillogram plots.
1.244
DIA.
Fuse dimensions
A
198 (484)
22.58 (573)
28.76 (730)
B
27.19 (690)
30.69 (779)
36.87 (936)
ANSI C37.40 - Service conditions and definitions.
•
ANSI C37.41 - Power fuse design and testing.
•
ANSI C37.42 - Distribution fuse ratings and specification.
•
ANSI C37.46 - Power fuse ratings and specifications.
•
ANSI C37.48 - Power fuse application, operation and maintenance.
•
AS1033.1 1990 - Australian standard high voltage fuses expulsion type.
Specifications
Fuse unit fitting inches (mm)
kV max
17
27
38
•
C
28.82 (732)
32.32 (821)
38.50 (978)
Description
Expulsion fuse link style fuse, complete with a single pole porcelain fuse mount offering medium voltage protection for indoor and
outdoor applications.
Ratings
Application notes
Low currents, usually referred to as overload currents, must be
considered as BBU fuses have a rather low thermal capacity. They
cannot carry overloads of the same magnitude/duration as motors
and transformers of equal continuous currents. For this reason,
the BBU fuse must be sized with the load current in mind so the
fuse does not open on otherwise acceptable overloads and inrush
conditions. Coordination should be considered to help determine
what type of fuse is applied. The BBU fuse interrupts at a natural
current zero in the current wave and allows minimum of a halfcycle of fault current to flow before the fault is cleared. The timecurrent characteristics associated with a BBU fuse has a rather
gradual slope making it easier to coordinate with downstream
equipment. In addition, the BBU is ideal for higher voltage (up to
38 kV) and high current applications (up to 200A). It is important
to examine the minimum melting and total clearing time-current
characteristics of this fuse.
Voltage: 17 - 38 kV (for the fuse link)
7 and 27 kV (for the fuse mount)
Amps:
3 - 200 A (for the fuse link)
IR:
10, 12 or 14 kA
Time-current curves
see curves on CD at the back of the catalogue.
Agency information
Refer to the ‘Standards’ paragraph.
Typical applications
•
Power transformers.
Standards
•
Feeder circuits.
Bussmann does not compromise when performance, quality and
safety are involved. Exacting standards have been established
relative to the design, testing and application of expulsion type
power fuses. Compliance with these standards ensures the best
selection and performance. The BBU Power fuses are designed
and tested for compliance to global standards such as ANSI and
Australian standard AS1033.1 1990.ANSI (American National
Standards Institute) is a non-profit privately funded membership
organization that coordinates the development of the US voluntary
national standards.
•
Distribution transformers.
•
Metal enclosed switchgear.
•
Pad mount switches.
EATON Bussmann MV fuse links
103
Boric acid fuse links
Part numbers and technical data
Part numbers
Current (A)
Voltage (kV)
Breaking
capacity kA
Fuse type
Part numbers
Current (A)
Voltage (kV)
Breaking
capacity kA
Fuse type
BBU17-3K
3
17
14
K
BBU27-3K
3
27
12.5
K
BBU17-6K
6
17
14
K
BBU27-6K
6
27
12.5
K
BBU17-8K
8
17
14
K
BBU27-8K
8
27
12.5
K
BBU17-10K
10
17
14
K
BBU27-10K
10
27
12.5
K
BBU17-12K
12
17
14
K
BBU27-12K
12
27
12.5
K
BBU17-15K
15
17
14
K
BBU27-15K
15
27
12.5
K
BBU17-20K
20
17
14
K
BBU27-20K
20
27
12.5
K
BBU17-25K
25
17
14
K
BBU27-25K
25
27
12.5
K
BBU17-30K
30
17
14
K
BBU27-30K
30
27
12.5
K
BBU17-40K
40
17
14
K
BBU27-40K
40
27
12.5
K
BBU17-50K
50
17
14
K
BBU27-50K
50
27
12.5
K
BBU17-65K
65
17
14
K
BBU27-65K
65
27
12.5
K
BBU17-80K
80
17
14
K
BBU27-80K
80
27
12.5
K
BBU17-100K
100
17
14
K
BBU27-100K
100
27
12.5
K
BBU17-140K
140
17
14
K
BBU27-140K
140
27
12.5
K
BBU17-200K
200
17
14
K
BBU27-200K
200
27
12.5
K
BBU17-5E
5
17
14
E
BBU27-5E
5
27
12.5
E
BBU17-7E
7
17
14
E
BBU27-7E
7
27
12.5
E
BBU17-10E
10
17
14
E
BBU27-10E
10
27
12.5
E
BBU17-13E
13
17
14
E
BBU27-13E
13
27
12.5
E
BBU17-15E
15
17
14
E
BBU27-15E
15
27
12.5
E
BBU17-20E
20
17
14
E
BBU27-20E
20
27
12.5
E
BBU17-25E
25
17
14
E
BBU27-25E
25
27
12.5
E
BBU17-30E
30
17
14
E
BBU27-30E
30
27
12.5
E
BBU17-40E
40
17
14
E
BBU27-40E
40
27
12.5
E
BBU17-50E
50
17
14
E
BBU27-50E
50
27
12.5
E
BBU17-65E
65
17
14
E
BBU27-65E
65
27
12.5
E
BBU17-80E
80
17
14
E
BBU27-80E
80
27
12.5
E
BBU17-100E
100
17
14
E
BBU27-100E
100
27
12.5
E
BBU17-125E
125
17
14
E
BBU27-125E
125
27
12.5
E
BBU17-150E
150
17
14
E
BBU27-150E
150
27
12.5
E
BBU17-175E
175
17
14
E
BBU27-175E
175
27
12.5
E
BBU17-200E
200
17
14
E
BBU27-200E
200
27
12.5
E
BBU17-15SE
15
17
14
SE
BBU27-15SE
15
27
12.5
SE
BBU17-20SE
20
17
14
SE
BBU27-20SE
20
27
12.5
SE
BBU17-25SE
25
17
14
SE
BBU27-25SE
25
27
12.5
SE
BBU17-30SE
30
17
14
SE
BBU27-30SE
30
27
12.5
SE
BBU17-40SE
40
17
14
SE
BBU27-40SE
40
27
12.5
SE
BBU17-50SE
50
17
14
SE
BBU27-50SE
50
27
12.5
SE
BBU17-65SE
65
17
14
SE
BBU27-65SE
65
27
12.5
SE
BBU17-80SE
80
17
14
SE
BBU27-80SE
80
27
12.5
SE
BBU17-100SE 100
17
14
SE
BBU27-100SE 100
27
12.5
SE
BBU17-125SE 125
17
14
SE
BBU27-125SE 125
27
12.5
SE
BBU17-150SE 150
17
14
SE
BBU27-150SE 150
27
12.5
SE
BBU17-175SE 175
17
14
SE
BBU27-175SE 175
27
12.5
SE
BBU17-200SE 200
17
14
SE
BBU27-200SE 200
27
12.5
SE
The BBU fuse is offered in three constructions to meet specific melt curves for an application. The construction is designated in the Part numbers suffix: E
(Standard), K (Fast) and SE (Slow). Contact Bussmann for application details: [email protected]
104
EATON Bussmann MV fuse links
Boric acid fuse links
Part numbers and technical data
Part numbers
Current (A)
Voltage (kV)
Breaking
capacity kA
Fuse type
BBU38-3K
3
38
10
K
BBU38-6K
6
38
10
K
BBU38-8K
8
38
10
K
BBU38-10K
10
38
10
K
BBU38-12K
12
38
10
K
BBU38-15K
15
38
10
K
BBU38-20K
20
38
10
K
BBU38-30K
30
38
10
K
BBU38-40K
40
38
10
K
BBU38-50K
50
38
10
K
BBU38-65K
65
38
10
K
BBU38-80K
80
38
10
K
BBU38-100K
100
38
10
K
BBU38-140K
140
38
10
K
BBU38-200K
200
38
10
K
BBU38-5E
5
38
10
E
BBU38-7E
7
38
10
E
BBU38-10E
10
38
10
E
BBU38-13E
13
38
10
E
BBU38-15E
15
38
10
E
BBU38-20E
20
38
10
E
BBU38-25E
25
38
10
E
BBU38-30E
30
38
10
E
BBU38-40E
40
38
10
E
BBU38-50E
50
38
10
E
BBU38-65E
65
38
10
E
BBU38-80E
80
38
10
E
BBU38-100E
100
38
10
E
BBU38-125E
125
38
10
E
BBU38-150E
150
38
10
E
BBU38-175E
175
38
10
E
BBU38-200E
200
38
10
E
BBU38-15SE
15
38
10
SE
BBU38-20SE
20
38
10
SE
BBU38-25SE
25
38
10
SE
BBU38-30SE
30
38
10
SE
BBU38-40SE
40
38
10
SE
BBU38-50SE
50
38
10
SE
BBU38-65SE
65
38
10
SE
BBU38-80SE
80
38
10
SE
BBU38-100SE 100
38
10
SE
BBU38-125SE 125
38
10
SE
BBU38-150SE 150
38
10
SE
BBU38-175SE 175
38
10
SE
BBU38-200SE 200
38
10
SE
EATON Bussmann MV fuse links
105
Cross reference
DIN Fuse links
ETI (80N
Striker)
ETI (50N
Striker)
Merlin Gerin
CF-7.2/6.3
4226005
4225005
51006 500 M0 N/A
3.6 IB-D2 6.3
1YMB531001M0001
CF-7.2/10
4226006
4225006
51007.501.M0 N/A
3.6 IB-D2 10
1YMB531001M0002
CF-7.2/16
4226007
4225007
51008 502.M0 N/A
3.6 IB-D2 16
1YMB531001M0003
CF-7.2/20
CF-7.2/25
4226008
4226009
4225008
4225009
51009 503 M0 N/A
51010 504 M0 N/A
3.6 IB-D2 20
3.6 IB-D2 25
N/A
1YMB531001M000
3000213
CF-7.2/31.5
4226010
4225010
51011 505 M0 N/A
3.6 IB-D2 31.5
N/A
3000213
3000213
CF-7.2/40
CF-7.2/50
4226011
4226012
4225011
4225012
51012 506 M0 N/A
51013 507 M0 N/A
3.6 IB-D2 40
3.6 IB-D2 50
1YMB53100M0005
1YMB531001M0006
67110630
3001013
CF-7.2/63
4226013
4225013
51014 508 M0 N/A
3.6 IB-D2 63
1YMB531001M0007
67110800
67110.1000
67110.1250
67110.1600
67210.2000
3001013
3001013
3001013
3001813
3001814
CF-7.2/80
CF-7.2/100
N/A
N/A
N/A
4226014
4226015
4226016
4226017
N/A
4225014
4225015
4225016
4225017
N/A
51015 509 M0
51016 510 M0
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
3.6 IB-D2 80
3.6 IB-D2 100
N/A
N/A
N/A
1YMB531001M0008
1YMB531001M0009
N/A
N/A
N/A
7.2 kV
7.2TDLSJ6.3
7.2TDLSJ10
7.2TDLSJ16
7.2TDLSJ20
7.2TDLSJ25
7.2TDLSJ31.5
7.2TDLSJ40
7.2TDLSJ50
7.2TDLSJ63
7.2TFLSJ80
7.2TFLSJ100
7.2TFLSJ125
7.2TFLSJ160
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
3009813
3009813
3009813
3009813
3009813
3009813
3009813
3009813
3009913
3009913
3009913
3009913
3010013
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
CF-7.2/125
CF-7.2/160
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
757352 BN
757352 BP
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1YMB531034M0001
1YMB531034M0002
1YMB531034M0003
N/A
1YMB531034M0004
N/A
1YMB531034M0005
1YMB531034M0006
1YMB531034M0007
1YMB531034M0008
1YMB531034M0009
1YMB531034M0010
1YMB531034M0011
12 kV
12TDLEJ6.3
12TDLEJ10
12TDLEJ16
12TDLEJ20
12TDLEJ25
67120060
67120100
67120160
67120200
67120250
3000413
3000413
3000413
3000413
3000413
CF-12/6.3
CF-12/10
CF-12/16
CF-12/20
CF-12/25
4236005
4236006
4236007
4236008
4236009
4235005
4235006
4235007
4235008
4235009
51006 511 M0
51006 512 M0
51006 513 M0
51006 514 M0
51006 515 M0
ES 6509 006
ES 6509 010
ES 6509 016
ES 6509 020
ES 6509 025
12 IB-D1 6.3
12 IB-D1 10
12 IB-D1 16
12 IB-D1 20
12 IB-D1/D2 25
1YMB531042M0001
1YMB531042M0002
1YMB531042M0003
1YMB531042M0004
1YMB531002M0004
12TDLEJ31.5
12TDLEJ40
12TDLEJ50
12TDLEJ63
12THLEJ80
12THLEJ100
12TKLEJ125
12TXLEJ160
12TXLEJ200
12THMEJ100
12TFMSJ160
67120320
67120400
67120500
67120630
67120800
67120.1000
67120.1250
67220.1600
67220.2000
67004-1000
67004-1600
3000413
3000413
3000413
3001213
3001213
3001213
3001213
3002013
3002014
3010213
3010313
CF-12/31.5
CF-12/40
CF-12/50
CF-12/63
CF-12/80
CF-12/100
N/A
N/A
N/A
CF-12/100
CF-12/160
4236010
4236011
4236012
4236013
4236014
4236015
4236016
4236017
N/A
4236515
4236517
4235010
4235011
4235012
4235013
4235014
4235015
4235016
4235017
N/A
4235515
4235517
51006 516 M0
51006 517 M0
51006 518 M0
51006 519 M0
51006 520 M0
51006 521 M0
N/A
N/A
N/A
757364CN
757354C
ES 6509 030
ES 6509 040
ES 6509 050
ES 6509 063
ES 6509 080
ES 6509 100
N/A
N/A
N/A
N/A
N/A
12 IB-D1/D2 31.5
12 IB-D1/D2 40
12 IB-D2 50
12 IB-D2 63
12 IB-D3 80
12 IB-D3 100
N/A
N/A
N/A
N/A
N/A
1YMB531002M0014
1YMB531002M0005
1YMB531002M0006
1YMB531002M0007
1YMB531002M0021
1YMB531002M0022
1YMB531043M0010
N/A
N/A
1YMB531035M0022
1YMB531035M0011
Bussmann
3.6 kV
3.6ADOSJ6.3
EFEN
SIBA
MESA
67110060
3000213
3.6ADOSJ10
67110100
3000213
3.6ADOSJ16
67110160
3000213
3.6ADOSJ20
3.6ADOSJ25
67110200
67110250
3000213
3000213
3.6ADOSJ31.5
67110320
3.6ADOSJ40
3.6WDOSJ50
67110400
67110500
3.6WDOSJ63
3.6WDOSJ80
3.6WDOSJ100
3.6WDOSJ125
3.6WFOSJ160
3.6WFOSJ200
106
EATON Bussmann MV fuse links
Elimsan
Inael
ABB
Cross reference
DIN Fuse links
ETI (80N
Striker)
Bussmann
17.5 kV
17.5TDLSJ6.3
EFEN
SIBA
MESA
N/A
3025513
N/A
N/A
17.5TDLSJ10
N/A
3025513
CFR-17.5/10
N/A
17.5TDLSJ16
N/A
3025513
CFR-17.5/16
N/A
17.5TDLSJ20
17.5TDLSJ25
N/A
N/A
3022113
3022113
N/A
CFR-17.5/25
17.5TDLSJ31.5
N/A
17.5TDLSJ40
17.5TFLSJ50
N/A
N/A
17.5TDMEJ6.3
17.5TDMEJ10
17.5TDMEJ16
17.5TDMEJ20
17.5TDMEJ25
17.5TDMEJ31.5
17.5TDMEJ40
17.5TDMEJ50
17.5TDMEJ63
17.5THMEJ80
17.5THMEJ100
17.5TKMEJ125
ETI (50N
Striker)
Merlin Gerin
Elimsan
Inael
ABB
N/A
N/A
N/A
17.5 IB-D1 6.3
1YMB531003M0001
N/A
51006 522 M0
N/A
17.5 IB-D1 10
1YMB531003M0002
N/A
51006 523 M0
N/A
17.5 IB-D1 16
1YMB531003M0003
N/A
N/A
N/A
N/A
N/A
51006 524 M0
N/A
N/A
17.5 IB-D1 20
17.5 IB-D1/D2 25
1YMB531003M0013
1YMB531003M0004
3022113
CFR-17.5/31.5 N/A
N/A
51006 525 M0
N/A
17.5 IB-D1/D2 31.5 1YMB531003M0014
3022113
3022113
CFR-17.5/40
N/A
N/A
N/A
N/A
N/A
51006 525 M0
N/A
N/A
N/A
17.5 IB-D1/D2 40
17.5 IB-D2 50
1YMB531003M0021
1YMB531003M0022
N/A
3023113
N/A
N/A
N/A
N/A
N/A
17.5 IB-D1 6.3
1YMB531037M0001
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
3023113
3023113
3023113
3023113
3023113
3023113
3023213
3023213
3023213
3023313
3023414
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
17.5 IB-D1 10
17.5 IB-D1 16
17.5 IB-D1 20
17.5 IB-D1 25
17.5 IB-D1 31.5
17.5 IB-D1 40
N/A
17.5 IB-D2 63
N/A
17.5 IB-D2 100
N/A
1YMB531037M0002
1YMB531037M0003
1YMB531037M0013
1YMB531037M0004
1YMB531037M0014
1YMB531037M0021
1YMB531037M0006
1YMB531037M0007
1YMB531037M0008
1YMB531003M0009
1YMB531003M0010
24 kV
24TDMEJ6.3
24TDMEJ10
24TDMEJ16
24TDMEJ20
24TDMEJ25
24TDMEJ31.5
24TDMEJ40
24TDMEJ50
24THMEJ63
24TFMEJ80
24TFMEJ100
24TXMEJ125
24TXMEJ160
67140060
67140100
67140160
67140200
67140250
67140320
67140400
67140500
67140630
67140800
67240.1000
67240.1250
67240.1600
3000613
3000613
3000613
3000613
3000613
3000613
3000613
3001413
3001413
3001413
3002213
3002213
N/A
CF-24/6.3
CF-24/10
CF-24/16
CF-24/20
CF-24/25
CF-24/31.5
CF-24/40
CF-24/50
CF-24/63
CF-24/80
CF-24/100
N/A
N/A
4256005
4256006
4256007
4256008
4256009
4256010
4256011
4253012
4253013
4253014
4253015
4253016
N/A
4255005
4255006
4255007
4255008
4255009
4255010
4255011
4255012
4255013
4255014
4255015
4255016
N/A
51006 538 M0
51006 539 M0
51006 540 M0
51006 541 M0
51006 542 M0
51006 543 M0
51006 544 M0
51006 545 M0
51006 546 M0
51006 547 M0
51006 548 M0
N/A
N/A
ES 6513-006
ES 6513-010
ES 6513-016
ES 6513-020
ES 6513-025
ES 6513-030
ES 6513-040
ES 6513-050
ES 6513-063
ES 6513-080
ES 6513-100
N/A
N/A
24 IB-D1 6.3
24 IB-D1 10
24 IB-D1 16
24 IB-D1 20
24 IB D1/D2 25
24 IB D1/D2 31.5
24 IB D1/D2 40
24 IB-D2 50
24 IB-D2 63
24 IB-D3 80
24 IB-D3 100
N/A
N/A
1YMB531044M0001
1YMB531044M0002
1YMB531044M0003
1YMB531044M0004
1YMB531004M0004
1YMB531004M0012
1YMB531004M0005
1YMB531004M0021
1YMB531004M0022
1YMB531022M0001
1YMB531022M0002
1YMB531022M0003
N/A
36 kV
36TDQSJ3.15
36TDQSJ6.3
N/A
67150060
N/A
3000813
N/A
CF-36/6.3
N/A
4266005
N/A
4265005
N/A
51006 549 M0
N/A
ES 6515-006
N/A
24 IB-D1 6.3
N/A
1YMB531006M0001
36TDQSJ10
36TDQSJ16
36TDQSJ20
36TDQSJ25
36TFQSJ31.5
67150100
67150160
67150200
67150250
67150320
3000813
3000813
3000813
3000813
3000813
CF-36/10
CF-36/16
CF-36/20
CF-36/25
CF-36/31.5
4266006
4266007
4266008
4266009
4266010
4265006
4265007
4265008
42650009
4265010
51006 550 M0
51006 551 M0
51006 552 M0
51006 553 M0
51006 554 M0
ES 6515-010
ES 6515-016
ES 6515-020
ES 6515-025
ES 6515-030
24 IB-D1 10
24 IB-D1 16
24 IB-D1 20
24 IB-D1 25
24 IB-D1 31.5
1YMB531006M0002
1YMB531006M0003
N/A
1YMB531006M0004
N/A
36TFQSJ40
36TFQSJ50
36TXQEJ63
67150400
67150500
67150630
3000813
3000813
3000813
CF-36/10
CF-36/50
CF-36/63
4266011
4266012
4266013
4265011
4265012
4265013
51006 555 M0
51006 556 M0
51006 557 M0
ES 6515-040
ES 6515-050
ES 6515-063
24 IB-D1 40
24 IB-D1 50
24 IB-D1 63
1YMB531006M0005
N/A
N/A
EATON Bussmann MV fuse links
107
Cross reference
Voltage and auxiliary fuse links
Motor fuse links
Bussmann
3.6 kV
3.6WDFHO50
3.6WDFHO63
SIBA
GE
3026956-50
3026956-63
3.6WDFHO80
3026956-80
3.6WDFHO100
3.6WDFHO125
3026956-100
3026956-125
K81PEX100
K81PEX125
3.6WFFHO160
3026956-160
K81PEX160
3.6WFFHO200
3026956-200
K81PEX200
3.6WFFHO250
3026956-250
K81PEX250
3.6WKFHO315
3.6WKFHO355
3.6WKFHO400
3.6WFGHO100
3.6WFGHO150
3.6WFGHO200
3.6WFGHO250
3.6WKGHO315
3.6WDLSJ50
3.6WDLSJ63
3.6WDLSJ80
3.6WDLSJ100
3.6WDLSJ125
3.6WFLSJ160
3.6WFLSJ200
3.6WKLSJ250
3.6WKLSJ315
3026956-315
K81PEX315
K81PEX350 (1)
K81PEX450 (2)
3025513-100
1YMB531031M0001
1YMB531031M0002
1YMB531031M0003
1YMB531031M0004
1YMB531031M0005
3020153-50
3020153-63
3020153-80
3020153-100
3020253-125
3020253-160
3020253-200
3020054-250
3020054-315
7.2 kV
7.2WFNHO50
7.2WFNHO63
7.2WFNHO80
7.2WFNHO100
7.2WFNHO125
7.2WFNHO160
7.2WFNHO200
7.2WKNHO224
7.2WKNHO250
7.2WKNHO315
7.2WFMSJ50
7.2WFMSJ63
7.2WFMSJ80
7.2WFMSJ100
7.2WFMSJ125
7.2WFMSJ160
7.2WKMSJ200
3027156-50
3027156-63
3027156-80
3027156-100
3027156-125
3027156-160
3027156-200
3027156-224
3027156-250
3027156-315
3010853-50
3010853-63
3010853-80
3010853-100
3010953-125
3010953-160
3011054-200
7.2WKMSJ224
7.2WKMSJ250
7.2WKMSJ315
3011054-224
3011054-250
3011054-315
ABB
SIBA
GE
AIR3.3/3
7.2 kV
7.2ABWNA3.15
7.2ABCNA3.15
7.2OBCNA3.15
3038311-3
3037711-3
12 kV
12ABCNA3.15
12ABCN223.15
3037811-3
VTF6.6/3
VTF6.6/3
VTF11/3
5XVTF11/3
12OBCNA3.15
VTF11/3
12OBCN223.15
5XVTF11/3
15.5 kV
15.5ABFNA3.15
15.5OBFNA3.15
15.5ABFNA223.15
15.5OBFN223.15
VTF15/3
VTF15/3
6XVTF15/3
6XVTF15/3
17.5 kV
17.5ABGNA3.15
3037911-3
24 kV
24ABGNA3.15
3038011-3
1YMB531028M0001
1YMB531028M0002
1YMB531028M0003
1YMB531028M0004
1YMB531028M0005
K81SDX50
K81SDX63
K81SDX80
K81SDX100
K81SDX125
K81SDX160
K81SDX200
K81SDX225
K81SDX250
K81SDX315
1YMB531032M0001
1YMB531032M0002
1YMB531032M0003
1YMB531032M0004
1YMB531032M0005
1YMB531032M0006
1YMB531029M0001
1YMB531029M0002
1YMB531029M0003
1YMB531029M0004
1YMB531029M0005
1YMB531029M0006
(1) GE’s fuse link is rated 355A, Bussmann’s 350A
(2) GE’s fuse link is rated at 450A, Bussmann’s at 400A
108
Bussmann
3.6 kV
3.6ABWNA3.15
EATON Bussmann MV fuse links
Please note the Bussmann fuse links above are rated at 3.15A. GE and
Siba’s are rated at 3A.
Cross reference
Oil fuse links
Bussmann
3.6 kV
3.6OEFMA6.3
Siba
GE
Notes
3013236-6.3*
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA10
3013236-10*
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA16
3013236-16*
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA20
3.6OEFMA25
3013236-20*
3013236-25*
Bussmann fuse link can only be used at a maximum of 3.6 kV
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA31.5
3013236-31.5*
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA40
3013236-40*
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA50
3.6OEFMA63
3013236-50*
3013236-63*
Bussmann fuse link can only be used at a maximum of 3.6 kV
Bussmann fuse link can only be used at a maximum of 3.6 kV
3.6OEFMA80
3.6OEFMA100
3013236-80*
3013236-100*
7-2 kV
7.2OEFMA80
7.2OEFMA100
7.2OEFMA112
7.2OHGMA100
7.2OHGMA125
7.2OHGMA140
7.2OHGMA160
12 kV
12OEFMA6.3
12OEFMA10
12OEFMA16
12OEMFA20
12OEFMA25
12OEFMA31.5
12OEFMA40
12OEFMA50
12OEFMA63
12OHFMA80
KSBXO100
3013236-80
3013236-100
3013236-112
KSBXO100
3023436-125
KSMXO100
KSMXO120
KSMXO140
GE fuse link is rated at 120A, Bussmann at 125A
3023436-160
3014436-6.3
3014436-10
3014436-16
3014436-20
3014436-25
3014436-31.5
3014436-40
3014436-50
3014436-63
3014436-80
KEBXO5
KEBXO10
KEBXO16
KEBXO20
KEBXO25
KEBXO36
KEBXO40
KEBXO50
KEBXO63
KEBXO80
15.5 kV
15.5OEFMA25
15.5OEFMA31.5
15.5OEFMA40
15.5OEFMA50
15.5OEFMA63
15.5OHGMA80
KFBXO25
KFBXO36
KFBXO40
KFBXO50
KFBXO63
KFMXO85
15.5OLGMA100
KFMXO100
17.5 kV
17.5OHGMA20
17.5OHGMA25
17.5OHGMA31.5
KFMXO20
KFMXO25
KFMXO32
17.5OHGMA40
17.5OHGMA50
17.5OHGMA63
17.5OHGMA80
KFMXO40
KFMXO50
KFMXO63
KFMXO80
24 kV
24OEGMA6.3
24OEGMA10
24OEGMA16
24OEGMA20
24OEGMA25
24OEGMA31.5
24OEGMA40
24OEGMA50
Bussmann fuse link can only be used at a maximum of 3.6 kV
Bussmann fuse link can only be used at a maximum of 3.6 kV
3023736-6.3**
3023736-10**
3023736-16**
3023736-20**
3023736-25**
3023736-31.5**
3023736-40**
3023736-50**
GE fuse link is rated at 5A, Bussmann at 6.3A
GE fuse link is rated at 36A, Bussmann at 31.5A
GE fuse link is rated at 36A, Bussmann at 31.5A
GE fuse link is rated at 85A, Bussmann at 80A
KTMXO10***
Bussmann fuse link can only be used at a maximum 24 kV
KTMXO20***
KTMXO25***
KTMXO32***
KTMXO40***
KTMXO50***
Bussmann fuse link can only be used at a maximum 24 kV
Bussmann fuse link can only be used at a maximum 24 kV
Bussmann fuse link can only be used at a maximum 24 kV
Bussmann fuse link can only be used at a maximum 24 kV
* SIBA fuse links are rated at 7.2 kV.
** SIBA fuse links are rated at 12 kV
*** GE fuse links are rated at 25.8 kV
EATON Bussmann MV fuse links
109
Cross reference
British standard air fuse links
Bussmann
3.6 kV
3.6ADFHA6.3*
3.6ADFHA10*
3.6ADFHA16*
3.6ADFHA20*
3.6ADFHA25*
SIBA
SIBA
3024136-6.3
Bussmann
12 kV
12ADFHA6.3
3024136-10
3024136-16
3024136-20
3024136-25
12ADFHA10
12ADFHA16
12ADFHA20
12ADFHA25
3.6ADFHA31.5*
3024136-31.5
3.6ADFHA40*
3024136-40
7.2 kV
7.2ADFHA6.3
3024136-6.3
7.2ADFHA10
7.2ADFHA16
7.2ADFHA20
7.2ADFHA25
7.2ADFHA31.5
7.2ADFHA40
7.2ADFHA50
7.2ADFHA63
7.2AFFHA80
7.2AFFHA100
7.2BDGHA6.3
7.2BDGHA10
7.2BDGHA16
7.2BDGHA20
7.2BDGHA25
7.2BDGHA31.5
7.2BDGHA40
7.2BDGHA50
7.2BDGHA63
7.2BDGHA80
7.2BFGHA100
7.2BFGHA125
7.2BFGHA140
7.2BFHA160
7.2BDGHC6.3
7.2BDGHC10
7.2BDGHC16
7.2BDGHC20
7.2BDGHC25
3024136-10
3024136-16
3024136-20
3024136-25
3024136-31.5
3024136-40
3024136-50
3024136-63
3013536-80
3013536-100
3024236-6.3
3024236-10
3024236-16
3024236-20
3024236-25
3024236-31.5
3024236-40
3024236-50
3024236-63
3024236-80
3013736-100
3013736-125
3013736-140
3013736-16
3024636-6.3
3024636-10
3024636-16
3024636-20
3024636-25
7.2BDGHC31.5
7.2BDGHC40
7.2BDGHC50
7.2BDGHC63
7.2BDGHC80
7.2BFGHC90
7.2BFGHC100
7.2BFGHC125
7.2BFGHC140
7.2BFGHC160
3024636-31.5
3024636-40
3024636-50
3024636-63
3024636-80
3024936-90
3024936-100
3024936-125
3024936-140
3024936-160
Bussmann
24 kV
24ADIHA6.3
SIBA
3014136-10
3014136-16
3014136-20
3014136-25
24ADIHA10
3024436-10
24ADIHA16
3024436-16
24ADIHA20
24ADIHA25
3024436-20
3024436-25
12ADFHA31.5
3014136-31.5
12AFFHA40
3013536-40
24ADIHA31.5
24FIHA40
3024436-31.5
3016136-40
12AFFHA50
30133536-50
24AFIHA50
3016136-40
12AFFHA63
12ADFN6B31.5
30133536-63
24AFIHA63
3016136-63
24AFIHA80
3016136-80
3014136-6.3
K6EB32
12AFFN6B40
12AFFN6B50
12AFFN6B63
12BDGHA6.3
12BDGHA10
12BDGHA16
12BDGHA20
12BDGHA25
12BDGHA31.5
12BDGHA40
12BDGHA50
12BFGHA50
12BFGHA63
12BFGHA80
12BFGHA100
12AKGHA125
12BDGHC6.3
12BDGHC10
12BDGHC16
12BDGHC20
12BDGHC25
12BDGHC31.5
12BDGHC40
12BDGHC50
12BFGHC63
12BFGHC80
12BFGHC90
12BFGHC100
12AKGHC125
K6EB40
K6EB50
K6EB63
3024336-6.3
3024336-10
3024336-16
3024336-20
3024336-25
3024336-31.5
3024336-40
3024336-50
3014736-50
3014736-63
3014736-80
3014736-100
3014736-125
3024736-6.3
3024736-10
3024736-16
3024736-20
3024736-25
3024736-31.5
3024736-40
3024736-50
3025036-63
3025036-80
3025036-90
3025036-100
3025036-125
15.5 kV
15.5BDGHC6.3
15.5BDGHC10
15.5BDGHC16
15.5BDGHC20
15.5BDGHC25
15.5BDGHC31.5
15.5BDGHC40
15.5BFGHC50
15.5BFGHC63
15.5BFGHC80
3025836-6.3
3024836-10
3024836-16
3024836-20
3024836-25
3024836-31.5
3024836-40
3024836-50
3024836-63
3024836-80
* These specific Bussmann fuse links can only be used at a maximum of 3.6 kV
110
EATON Bussmann MV fuse links
GE
3024436-6.3
US Style E-Rated fuse links
Bussmann
Mersen (Ferraz Shawmut)
5.5 kV E-Rated fuse links for transformers and feeder protection
MV055F1DAX10E
A055F1D0R0-10E
5HLE-10E
10E-1C-5.5
MV055F1DAX15E
A055F1D0R0-15E
5HLE-15E
15E-1C-5.5
MV055F1DAX20E
A055F1D0R0-20E
5HLE-20E
20E-1C-5.5
MV055F1DAX25E
MV055F1DAX80E
A055F1D0R0-25E
A055F1D0R0-80E
5HLE-25E
5HLE-80E
9F62DCB080
25E-1C-5.5
80E-1C-5.5
MV055F1DAX125E
MV055F1DAX175E
A055F1D0R0-125E
A055F1D0R0-175E
5HLE-125E
5HLE-175E
9F62DCB125
9F62DCB175
125E-1C-5.5
175E-1C-5.5
MV055F1DAX200E
A055F1D0R0-200E
5HLE-200E
9F62DCB200
200E-1C-5.5
MV055F2DAX300E
A055F2D0R0-300E
5HLE-300E
9F62FCB300
300E-1C-5.5
MV055F2DAX350E
MV055F2DAX400E
A055F2D0R0-350E
A055F2D0R0-400E
5HLE-350E
5HLE-400E
9F62FCB350
9F62FCB400
350E-2C-5.5
400E-2C-5.5
MV055F2DAX450E
A055F2D0R0-450E
5HLE-450E
9F62FCB450
450E-2C-5.5
5.5FFNHA30E
5.5FFNHA40E
A055F1D0R0-30E
A055F1D0R0-40E
5HLE-30E
5HLE-40E
9F60FJD030
9F60FJD040
30E-1C-5.5
40E-1C-5.5
5.5FFNHA50E
5.5FFNHA65E
A055F1D0R0-50E
A055F1D0R0-65E
5HLE-50E
5HLE-65E
9F60FJD050
9F60FJD065
50E-1C-5.5
65E-1C-5.5
8.3 kV E-Rated fuse links for transformers and feeder protection
8.25FFNHA20E
A825X20E-1
8.25FFNHA25E
A825X25E-1
8.25FFNHA30E
A825X30E-1
8.25FFNHA40E
A825X40E-1
8.25FFNHA50E
A825X50E-1
8.25FFNHA65E
A825X65E-1
8HLE-20E
8HLE-25E
8HLE-30E
8HLE-40E
8HLE-50E
8HLE-65E
9F60FJE020
9F60FJE025
9F60FJE030
9F60FJE040
9F60FJE050
9F60FJE065
20E-1C-8.25
25E-1C-8.25
30E-1C-8.25
40E-1C-8.25
50E-1C-8.25
65E-1C-8.25
15.5 kV E-Rated fuse links for transformers and feeder protection
MV155F1DBX10E
A155F1D0R0-10E
MV155F1DBX80E
A155F2D0R0-80E
MV155F1DBX100E
A155F2D0R0-100E
MV155F2DBX175E
A155F2D0R0-175E
MV155F2DBX200E
A155F2D0R0-200E
15.5FFVHA15E
A155F1D0R0-15E
15.5FFVHA20E
A155F1D0R0-20E
15.5FFVHA25E
A155F1D0R0-25E
15.5FFVHA30E
A155F1D0R0-30E
15.5FFVHA40E
A155F1D0R0-40E
15.5FFVHA50E
A155F1D0R0-50E
15.5FFVHA65E
A155F2D0R0-65E
15.5FFVHK150E
A155F2D0R0-150E
15HLE-10E
15HLE-80E
15HLE-100E
15HLE-175E
15HLE-200E
15HLE-15E
15HLE-20E
15HLE-25E
15HLE-30E
15HLE-40E
15HLE-50E
15HLE-65E
15HLE-150E
E-Rated fuse links: CL-14 and bolt-in 5.5 kV
ECL055-10E
A055C1D0R0-10E
ECL055-15E
A055C1D0R0-15E
ECL055-20E
A055C1D0R0-20E
ECL055-25E
A055C1D0R0-25E
5HCL-10E
5HCL-15E
5HCL-20E
5HCL-25E
10E-1CL-5.5
15E-1CL-5.5
20E-1CL-5.5
25E-1CL-5.5
ECL055-30E
ECL055-40E
ECL055-50E
ECL055-65E
ECL055-80E
ECL055-100E
ECL055-125E
ECL055-150E
ECL055-200E
ECL055-250E
ECL055-300E
ECL055-400E
ECL055-450E
ECL055-500E
ECL055-600E
EBI055-750E
EB1055-900E
5HCL-30E
5HCL-40E
5HCL-50E
5HCL-65E
5HCL-80E
5HCL-100E
5HCL-125E
5HCL-150E
5HCL-200E
5HCL-250E
5HCL-300E
5HCL-400E
5HCL-450E
5HCL-500E
5HCL-600E
5HCL-750E
5HCL-900E
30E-1CL-5.5
40E-1CL-5.5
50E-1CL-5.5
65E-1CL-5.5
80E-1CL-5.5
100E-1CL-5.5
125E-1CL-5.5
150E-1CL-5.5
A055C1D0R0-30E
A055C1D0R0-40E
A055C1D0R0-50E
A055C1D0R0-65E
A055C1D0R0-80E
A055C1D0R0-100E
A055C1D0R0-125E
A055C1D0R0-150E
A055C1D0R0-200E
A055C1D0R0-250E
A055C1D0R0-300E
A055C1D0R0-400E
A055C2D0R0-450E
A055C2D0R0-500E
A055C2D0R0-600E
A055B3D0R0-750E
A055B3D0R0-900E
Cutler Hammer
GE
9F60HMH080
9F60HMH100
9F60FMH015
9F60FMH020
9F60FMH025
9F60FMH030
9F60FMH040
9F60FMH050
9F60FMH065
Littelfuse
10E-1C-15.5
80E-1C-15.5
100E-1C-15.5
175E-2C-15.5
200E-2C-15.5
15E-1C-15.5
20E-1C-15.5
25E-1C-15.5
30E-1C-15.5
40E-1C-15.5
50E-1C-15.5
65E-1C-15.5
150E-2C-15.5
300E-2CL-5.5
350E-2CL-5.5
400E-2CL-5.5
EATON Bussmann MV fuse links
111
Cross reference
US Style E-Rated fuse links
Bussmann
Mersen (Ferraz Shawmut)
E-Rated fuse links: CL-14 and bolt-in - 15.5 kV
ECL155-10E
A155C1D0R0-10E
Cutler Hammer
15HCL-10E
10E-1CL-15.5
ECL155-15E
A155C1D0R0-15E
15HCL-15E
15E-1CL-15.5
ECL155-20E
A155C1D0R0-20E
15HCL-20E
20E-1CL-15.5
ECL155-25E
ECL155-30E
ECL155-40E
ECL155-50E
A155C1D0R0-25E
A155C1D0R0-30E
A155C1D0R0-40E
A155C1D0R0-50E
15HCL-25E
15HCL-30E
15HCL-40E
15HCL-50E
25E-1CL-15.5
30E-1CL-15.5
40E-1CL-15.5
50E-1CL-15.5
ECL155-65E
A155C1D0R0-65E
15HCL-65E
65E-1CL-15.5
ECL155-80E
A155C1D0R0-80E
15HCL-80E
80E-1CL-15.5
ECL155-100E
ECL155-125E
A155C1D0R0-100E
A155C2D0R0-125E
15HCL-100E
15HCL-125E
100E-1CL-15.5
ECL155-150E
ECL155-200E
ECL155-250E
ECL155-300E
A155C3D0R0-150E
A155C3D0R0-200E
A155C3D0R0-250E
A155C3D0R0-300E
15HCL-150E
15HCL-200E
15HCL-250E
15HCL-300E
E-Rated fuses for transformers and feeder protection - 2.4 kV E-Rated indoor/enclosure
JCX-15E
2CLE-15E
JCX-20E
2CLE-20E
JCX-25E
2CLE-25E
JCX-30E
2CLE-30E
JCX-40E
2CLE-40E
JCX-50E
2CLE-50E
JCX-65E
2CLE-65E
JCX-80E
2CLE-80E
JCX-100E
2CLE-100E
JCX-125E
2CLE-125E
JCX-150E
2CLE-150E
JCX-200E
2CLE-200E
JCX-250E/280X
2CLE-250E
JCX-300E/325X
2CLE-300E
JCX-350X
2CLE-350X
JCX-400X
2CLE-400X
JCX-450X
2CLE-450X
E-Rated fuse links for transformers and feeder protection - 5.5 kV E-Rated indoor/enclosure
JCU-10E
5CLE-10E-D
JCU-15E
5CLE-15E
JCU-20E
5CLE-20E
JCU-25E
JCU-30E
JCU-40E
JCU-50E
JCU-65E
5CLE-25E
5CLE-30E-D
5CLE1-40E
5CLE1-50E
5CLE1-65E
JCU-80E
JCU-100E
JCU-125E
JCU-150E
JCU-175E
JCU-200E
JCU-250E
JCU-300E
JCU-350E
JCU-400E
JCU-450E
JCU-600E
JCU-750E
5CLE1-80E
5CLE1-100E
5CLE1-125E
5CLE-150E
5CLE-175E
5CLE-200E
5CLE-250E
5CLE-300E
5CLE-350E
5CLE-400E
5CLE-450E
5CLE-600E
5CLE-750E
112
EATON Bussmann MV fuse links
GE
9F60ECB030
9F60ECB040
9F60ECB050
9F60ECB065
9F60ECB080
9F60ECB100
9F60GCB125
9F60GCB150
9F60GCB200
Littelfuse
30E-1C-2.75
40E-1C-2.75
50E-1C-2.75
65E-1C-2.75
80E-1C-2.75
100E-1C-2.75
125E-1C-2.75
150E-1C-2.75
200E-1C-2.75
Cross reference
US style E-Rated fuse links
Bussmann
Mersen (Ferraz Shawmut)
Cutler Hammer
E-Rated fuse links for transformers and feeder protection - 8.3 kV E-Rated indoor/enclosure
JCZ-15E
8CLE-15E
JCZ-20E
8CLE-20E
JCZ-25E
JCZ-30E
8CLE-25E
8CLE-30E-D
JCZ-40E
8CLE-40E
JCZ-50E
JCZ-65E
8CLE-50E
8CLE-65E
JCZ-80E
8CLE-80E
JCZ-100E
8CLE-100E
JCZ-125E
JCZ-150E
8CLE-125E
8CLE-150E
GE
Littelfuse
E-Rated fuse links for potential and small power transformers - 2.4 kV E-Rated fuse non-indicating
JCD-1/2E
500E-4PT-2.4
JCD-1E
JCD-2E
1E-4PT-2.4
2E-4PT-2.4
E-Rated fuse links for potential and small power transformers - 5.5 kV E-Rated fuse indicating
JCQ-1/2E
JCQ-1E
JCQ-3E
JCQ-5E
JCQ-10E
E-Rated fuse links for potential and small power transformers - 8.3 kV E-Rated fuse indicating
JCI-1/2E
JCI-3E
9F60BDD905
9F60BDD001
9F60BDD003
1/2E-8PT-5.5
1E-8PT-5.5
3E-8PT-5.5
5E-8PT-5.5
10E-8PT-5.5
9F60BDE905
9F60BDE003
1/2E-8PT-8.25
3E-8PT-8.25
E-Rated fuse links for potential and small power transformers - 15.5 kV E-Rated fuse indicating
JCT-1/2E
JCT-1E
JCT-3E
1/2E-8PT-8.25
1E-8PT-15.5
3E-8PT-15.5
R-Rated fuse links for motor circuit protection - 2.4 kV
JCK-2R
A240R2R
JCK-3R
A240R3R
JCK-4R
A240R4R
JCK-5R
A240R5R
JCK-6R
A240R6R
JCK-9R
A240R9R
JCK-12R
A240R12R
JCK-18R
A240R18R
JCK-24R
A240R24R
2CLS-2R
2CLS-3R
2CLS-4R
2CLS-5R
2CLS-6R
2CLS-9R
2CLS-12R
2CLS-18R
2CLS-24R
70-2R-1C-2.75
100-3R-1C-2.75
130-4R-1C-2.75
150-5R-1C-2.75
170-6R-1C-2.75
200-9R-1C-2.75
230-12R-1C-2.75
390-18R-2C-2.75
450-24R-2C-2.75
R-Rated fuse links for motor circuit protection
JCK-A-2R
JCK-A-3R
JCK-A-4R
2ACLS-2R
2ACLS-3R
2ACLS-4R
70-2R-1C-2.75w
100-3R-1C-2.75w
130-4R-1C-2.75w
JCK-A-5R
JCK-A-6R
JCK-A-9R
JCK-A-12R
JCK-A-18R
JCK-A-24R
2ACLS-5R
2ACLS-6R
2ACLS-9R
2ACLS-12R
2ACLS-18R
2ACLS-24R
150-5R-1C-2.75w
170-6R-1C-2.75w
200-9R-1C-2.75w
230-12R-1C-2.75w
390-18R-2C-2.75w
450-24R-2C-2.75w
R-Rated fuse links for motor circuit protection
JCK-B-2R
JCK-B-3R
JCK-B-4R
JCK-B-5R
JCK-B-6R
JCK-B-9R
JCK-B-12R
JCK-B-18R
JCK-B-24R
2BCLS-2R
2BCLS-3R
2BCLS-4R
2BCLS-5R
2BCLS-6R
2BCLS-9R
2BCLS-12R
2BCLS-18R
2BCLS-24R
EATON Bussmann MV fuse links
113
Cross reference
US Style E-Rated Fuse Links
Bussmann
Mersen (Ferraz Shawmut)
Cuttler Hammer
Littelfuse
R-Rated fuse links for motor circuit protection - 2.4 kV Hermetically sealed, for use with ampguard motor starters
JCH-2R
2HCLS-2R
JCH-3R
JCH-4R
2HCLS-3R
2HCLS-4R
JCH-5R
JCH-6R
2HCLS-5R
2HCLS-6R
JCH-9R
2HCLS-9R
JCH-12R
2HCLS-12R
JCH-18R
2HCLS-18R
JCH-24R
2HCLS-24R
R-Rated fuse links for motor circuit protection - 4.8 kV
JCL-2R
A480R2R-1
JCL-3R
A480R3R-1
JCL-4R
A480R4R-1
JCL-5R
A480R5R-1
JCL-6R
A480R6R-1
JCL-9R
A480R9R-1
JCL-12R
A480R12R-1
JCL-18R
A480R18R-1
JCL-24R
A480R24R-1
5CLS-2R
5CLS-3R
5CLS-4R
5CLS-5R
5CLS-6R
5CLS-9R
5CLS-12R
5CLS-18R
5CLS-24R
70-2R-1C-5.5
100-3R-1C-5.5
130-4R-1C-5.5
150-5R-1C-5.5
170-6R-1C-5.5
200-9R-1C-5.5
230-12R-1C-5.5
390-18R-2C-5.5
450-24R-2C-5.5
R-Rated fuse links for motor circuit protection - 4.8 kV with Westinghouse ampguard hookeyes
JCL-A-2R
A480R2R-1HE
5ACLS-2R
JCL-A-3R
A480R3R-1HE
5ACLS-3R
JCL-A-4R
A480R4R-1HE
5ACLS-4R
JCL-A-5R
A480R5R-1HE
5ACLS-5R
JCL-A-6R
A480R6R-1HE
5ACLS-6R
JCL-A-9R
A480R9R-1HE
5ACLS-9R
JCL-A-12R
A480R12R-1HE
5ACLS-12R
JCL-A-18R
A480R18R-1HE
5ACLS-18R
JCL-A-24R
A480R24R-1HE
5ACLS-24R
70-2R-1C-5.5w
100-3R-1C-5.5w
130-4R-1C-5.5w
150-5R-1C-5.5w
170-6R-1C-5.5w
200-9R-1C-5.5w
230-12R-1C-5.5w
390-18R-2C-5.5w
450-24R-2C-5.5w
R-Rated fuse links for motor circuit protection - 4.8 kV Bolt-on
JCL-B-2R
JCL-B-3R
JCL-B-4R
JCL-B-5R
JCL-B-6R
JCL-B-9R
JCL-B-12R
JCL-B-18R
JCL-B-24R
70-2R-1BI-5.5
100-3R-1BI-5.5
130-4R-1BI-5.5
150-5R-1BI-5.5
170-6R-1BI-5.5
200-9R-1BI-5.5
230-12R-1BI-5.5
390-18R-2BI-5.5
450-24R-2BI-5.5
5BCLS-2R
5BCLS-3R
5BCLS-4R
5BCLS-5R
5BCLS-6R
5BCLS-9R
5BCLS-12R
5BCLS-18R
5BCLS-24R
R-Rated fuse links for motor circuit protection - 4.8 kV Hermetically sealed for use with ampguard motor starters
JCG-2R
5HCLS-2R
JCG-3R
5HCLS-3R
JCG-4R
5HCLS-4R
JCG-5R
5HCLS-5R
JCG-6R
5HCLS-6R
JCG-9R
5HCLS-9R
JCG-12R
5HCLS-12R
JCG-18R
5HCLS-18R
JCG-24R
5HCLS-24R
114
EATON Bussmann MV fuse links
Cross reference
US Style E-Rated Fuse Links
Bussmann
Mersen (Ferraz Shawmut)
Cutler Hammer
R-Rated fuse links for motor circuit protection - 7.2 kV with ampguard
JCR-A-2R
8ACLS-2R
Littelfuse
70-2R-1C-8.25w
JCR-A-3R
JCR-A-4R
JCR-A-5R
JCR-A-6R
8ACLS-3R
8ACLS-4R
8ACLS-5R
8ACLS-6R
100-3R-1C-8.25w
130-4R-1C-8.25w
150-5R-1C-8.25w
170-6R-1C-8.25w
JCR-A-9R
JCR-A-12R
7ACLS-9R
7ACLS-12R
200-9R-1C-8.25w
230-12R-1C-8.25w
JCR-A-18R
7ACLS-18R
390-18R-2C-8.25w
JCR-A-24R
7ACLS-24R
450-24R-2C-8.25w
R-Rated fuse links for motor circuit protection - 7.2 kV Bolt-On
JCR-B-2R
A072B1DAR0-2R
JCR-B-3R
A072B1DAR0-3R
JCR-B-4R
A072B1DAR0-4R
JCR-B-5R
A072B1DAR0-5R
JCR-B-6R
A072B1DAR0-6R
JCR-B-9R
A072B1DAR0-9R
JCR-B-12R
A072B1DAR0-12R
JCR-B-18R
A072B2DAR0-18R
JCR-B-24R
A072B2DAR0-24R
7BCLS-2R
7BCLS-3R
7BCLS-4R
7BCLS-5R
7BCLS-6R
7BCLS-9R
7BCLS-12R
7BCLS-18R
7BCLS-24R
70-2R-1BI-8.25
100-3R-1BI-8.25
130-4R-1BI-8.25
150-5R-1BI-8.25
170-6R-1BI-8.25
200-9R-1BI-8.25
230-12R-1BI-8.25
390-18R-2BI-8.25
450-24R-2BI-8.25
ANSI R-Rated fuse links for motor circuit protection - 2.4 kV system voltage
2.75VFRHA2R
A240R2R
2CLS-2R
2.75VFRHA3R
A240R3R
2CLS-3R
2.75VFRHA4R
A240R4R
2CLS-4R
2.75VFRHA6R
A240R6R
2CLS-6R
2.75VKRNA9R
A240R9R
2CLS-9R
2.75VKRNA12R
A240R12R
2CLS-12R
2.75VKRHK18R
A240R18R
2CLS-18R
2.75VKRHK24R
A240R24R
2CLS-24R
70-2R-1C-2.75
100-3R-1C-2.75
130-4R-1C-2.75
170-6R-1C-2.75
200-9R-1C-2.75
230-12R-1C-2.75
390-18R-2C-2.75
450-24R-2C-2.75
ANSI R-Rated fuse links for motor circuit protection - 4.8 kV system voltage
5.5VFNHA2R
A480R2R-1
5CLS-2R
5.5VFNHA3R
A480R3R-1
5CLS-3R
5.5VFNHA4R
A480R4R-1
5CLS-4R
5.5VFNHA6R
A480R6R-1
5CLS-6R
5.5VKNNA9R
A480R9R-1
5CLS-9R
5.5VKNNA12R
A480R12R-1
5CLS-12R
5.5VKNHK18R
A480R18R-1
5CLS-18R
5.5VKNHK24R
A480R24R-1
5CLS-24R
70-2R-1C-5.5
100-3R-1C-5.5
130-4R-1C-5.5
170-6R-1C-5.5
200-9R-1C-5.5
230-12R-1C-5.5
390-18R-2C-5.5
450-24R-2C-5.5
EATON Bussmann MV fuse links
115
Cross reference
Boric acid fuse links
Bussmann
17 kV
BBU17-3K
S&C
Electric company
S&C
Electric company
S&C
Electric company
702003
Bussmann
27 kV
BBU27-3K
703003
Bussmann
38 kV
BBU38-3K
BBU17-6K
BBU17-8K
702006
702008
BBU27-6K
BBU27-8K
703006
703008
BBU38-6K
BBU38-8K
704006
704008
BBU17-10K
BBU17-12K
702010
702012
BBU27-10K
BBU27-12K
703010
703012
BBU38-10K
BBU38-12K
704010
704012
BBU17-15K
702015
BBU27-15K
703015
BBU38-15K
704015
BBU17-20K
702020
BBU27-20K
703020
BBU38-20K
704020
BBU17-25K
BBU17-30K
702025
702030
BBU27-25K
BBU27-30K
703025
703030
BBU38-30K
BBU38-40K
704030
704040
BBU17-40K
702040
BBU27-40K
703040
BBU38-50K
704050
BBU17-50K
BBU17-65K
BBU17-80K
BBU17-100K
BBU17-140K
BBU17-200K
BBU17-5E
BBU17-7E
BBU17-10E
BBU17-13E
BBU17-15E
BBU17-20E
BBU17-25E
BBU17-30E
BBU17-40E
BBU17-50E
BBU17-65E
BBU17-80E
BBU17-100E
BBU17-125E
BBU17-150E
BBU17-175E
BBU17-200E
BBU17-15SE
702050
702065
702080
702100
702140
702200
612005
612007
612010
612013
612015
612020
612025
612030
612040
612050
612065
612080
612100
612125
612150
612175
612200
712015
BBU27-50K
BBU27-65K
BBU27-80K
BBU27-100K
BBU27-140K
BBU27-200K
BBU27-5E
BBU27-7E
BBU27-10E
BBU27-13E
BBU27-15E
BBU27-20E
BBU27-25E
BBU27-30E
BBU27-40E
BBU27-50E
BBU27-65E
BBU27-80E
BBU27-100E
BBU27-125E
BBU27-150E
BBU27-175E
BBU27-200E
BBU27-15SE
703050
703065
703080
703100
703140
703200
613005
613007
613010
613013
613015
613020
613025
613030
613040
613050
613065
613080
613100
613125
613150
613175
613200
713015
BBU38-65K
BBU38-80K
BBU38-100K
BBU38-140K
BBU38-200K
BBU38-5E
BBU38-7E
BBU38-10E
BBU38-13E
BBU38-15E
BBU38-20E
BBU38-25E
BBU38-30E
BBU38-40E
BBU38-50E
BBU38-65E
BBU38-80E
BBU38-100E
BBU38-125E
BBU38-150E
BBU38-175E
BBU38-200E
BBU38-15SE
BBU38-20SE
704065
704080
704100
704140
704200
614005
614007
614010
614013
614015
614020
614025
614030
614040
614050
614065
614080
614100
614125
614150
614175
614200
714015
714020
BBU17-20SE
BBU17-25SE
BBU17-30SE
BBU17-40SE
BBU17-50SE
712020
712025
712030
712040
712050
BBU27-20SE
BBU27-25SE
BBU27-30SE
BBU27-40SE
BBU27-50SE
713020
713025
713030
713040
713050
BBU38-25SE
BBU38-30SE
BBU38-40SE
BBU38-50SE
BBU38-65SE
714025
714030
714040
714050
714065
BBU17-65SE
BBU17-80SE
BBU17-100SE
BBU17-125SE
BBU17-150SE
BBU17-175SE
BBU17-200SE
712065
712080
712100
712125
712150
712175
712200
BBU27-65SE
BBU27-80SE
BBU27-100SE
BBU27-125SE
BBU27-150SE
BBU27-175SE
BBU27-200SE
713065
713080
713100
713125
713150
713175
713200
BBU38-80SE
BBU38-100SE
BBU38-125SE
BBU38-150SE
BBU38-175SE
BBU38-200SE
714080
714100
714125
714150
714175
714200
116
EATON Bussmann MV fuse links
704003
Time-current curves and cut-off curves list
kV
DIN Fuse links
3.6
Product range
Page number
Fuse type
Time-current
curve reference
Cut-off curve
reference
‘A’ and ‘W’ range
12
ADL
PF1001
N/A
3.6
‘A’ and ‘W’ range
12
ADO, WDO, WFO
PF1002
PF2002
7.2
‘T’ range
13
TDL, TFL
PF1042
PF2042
12
Full range
14
14
FFL
FDL
PF1067
PF1124
PF2067
PF2124
14
FXL
PF1242
PF2242
12
‘A’ and ‘T’ range
15
AIL
PF1129
N/A
15
15
TXL
TDL, THL, TKL
PF1197
PF1275
PF2197
PF2275
15
16-17
TFM, THM, TKM
AIL
PF1280
PF1006
PF2280
PF2006
16-17
16-17
16-17
16-17
18
19
19
19
20
20
AIM
TDL
TFL
TDM, THM, TKM
FDM, FFM
AFM, AIM
TFM, TXM
TDM, THM, TFM
TDQ, TFQ
TXQ
PF1005
PF1088
PF1246
PF1274
PF1119
PF1007
PF1236
PF1276
PF1046
PF1253
N/A
PF2088
PF2246
PF2274
PF2119
PF2007
PF2236
PF2276
PF2046
PF2253
24-25
24-25
26
28
28
29
WJON
WDO, WFO
WFN, WKN
WDO, WFO
WDL, WFL, WKL
WFM, WKM
PF1079
PF1002
PF1018
PF1002
PF1001
PF1018
N/A
PF2002
PF2018
PF2002
N/A
PF2018
34
35
36
36
37
NBU
ABW, ABC
ABW
AMW
ABC, ABW, OBC, OBW
PF1019
PF1020
PF1081, PF1082
PF1102, PF1103
PF1021
N/A
PF2020
PF2081
PF2102
PF2021
38
39
40
41
42
43
44
44
45
46
47
47
48
49
50
51
51
ABC, OBC
ABF, OBF
ABG, OBG
ABG, OBG
OBG
CAV
CAV
CAVH
CAV
CAV
CAV
CAVH
CAV
CAV
CAV
CAV
CAVH
PF1022
PF1061
PF1023
PF1024
PF1060
PF1251
PF1154, PF1155
PF1126
PF1250
PF1249
PF1152, PF1153
PF1126, PF1127
PF1226
PF1248
PF1223
PF1156, PF1157
PF1126, PF1127
PF2022
N/A
PF2023
PF2024
N/A
N/A
N/A
PF2126
N/A
N/A
N/A
PF2126
N/A
N/A
N/A
N/A
PF2126
17.5
‘A’ and ‘T’ range
24
24
Full range
‘A’ and ‘T’ range
36
‘T’ range
Motor fuse links
3.6
BS range
7.2
3.6
Motor BS range
Motor DIN range
7.2
Motor DIN range
Voltage and auxiliary transformer (V and T) fuse links
1.1
‘V’ and ‘T’ range
3.6
‘V’ and ‘T’ range
5.5
‘E’ range
7.2
‘V’ and ‘T’ range
12
15.5
17.5
24
36
3.6
5.5
‘V’ and ‘T’ range
‘V’ and ‘T’ range
‘V’ and ‘T’ range
‘V’ and ‘T’ range
‘V’ and ‘T’ range
CAV range
CAV range
7.2
12
15.5
CAV range
CAV range
CAV and CAVH range
17.5
24
36
38
CAV range
CAV range
CAV range
CAV and CAVH range
EATON Bussmann MV fuse links
117
Time-current curves and cut-off curves list
kV
Oil fuse links
3.6
7.2
Product range
Page number
Fuse type
Time-current
curve reference
Cut-off curve
reference
BS range
BS range
54
55
OEF, OEG, OLG
OEF
PF1025
PF1058
PF2025
PF2058
55
OHG
PF1064
PF2064
12
BS range
56
OEF, OHF
PF1053
PF2053
15.5
BS range
56
57
OHG, OLG
OEF, OHG, OLG
PF1117
PF1056
N/A
PF2056
17.5
24
BS range
BS range
58
59
OHG
OEG
PF1057
PF1059
PF2057
PF2059
Air fuse links
3.6
BS
62-63
62-63
ADG
ADF
PF1008
PF1247
PF2008
N/A
7.2
BS range
64-65
64-65
66-67
66-67
66-67
68
69
69
70
71
ADF, AFF
BDG, BFG
ADF, AFF
BDG, BFG, AKG
FFG
BDG, BFG
ADI, AFI
FDIHA
ADI, AFI, AFK
AFK
PF1256
PF2256
PF1009
PF1261
PF1010
PF1068
PF1011
PF1012
PF1094
PF1013
PF1014
PF2009
N/A
PF2010
PF2068
PF2011
PF2012
N/A
PF2013
PF2014
DIN (single barrel)
DIN (double barrel)
DIN (single barrel)
DIN (double barrel)
DIN (single barrel)
DIN (double barrel)
DIN (single barrel)
DIN (double barrel)
DIN (single barrel)
DIN (double barrel)
E-rated for transformers
E-rated for transformers
E-rated for transformers
E-rated for transformers
E-rated for transformers
E-rated for potential and small
power transformers
73
73
73
73
74
74
74
74
74
74
75-76
75-76
77
77
78-79
83
83
83
83
GFM, GDM
GFM, GDM
GXQ
GXQ
GDM, GFM, GXM, GXQ
GDM, GFM, GXM, GXQ
GDQ, GXQ, GXZ
GDQ, GXQ, GXZ
GFZ, GXZ
GFZ, GXZ
FFN
BFN, BKN
FFN
BFN
FFV
AMWNA
ABWNA
CAV
CAVH
PF1216, PF1217
PF1220, PF1221
PF1218, PF1219
PF1224, PF1225
PF1218, PF1219
PF1224, PF1225
PF1254, PF1255
PF1257, PF1258
PF1254, PF1255
PF1257, PF1258
PF1107, PF1108
PF1114, PF1115
PF1107, PF1108
PF1112, PF1113
PF1107, PF1108
PF1102, PF1103
PF1081, PF1082
PF1154, PF1155
PF1126, PF1127
PF2217
PF2220
PF2219
N/A
N/A
PF2224
PF2254
PF2257
PF2254
PF2257
PF2107
N/A
PF2107
N/A
PF2107
PF2102
PF2081
N/A
PF2126
E-rated for potential and small
power transformers
E-rated for potential and small
power transformers
83
AMWN
PF1277, PF1278
PF2277
83
83
83
83
CAV
CAVH
CAV
CAVH
PF1152, PF1153, PF1268, PF1269
PF1126, PF1127
PF1156, PF1157
PF1126, PF1127
N/A
PF2126
N/A
PF2126
91-92
Type T & K
PF1047, PF1049
N/A
12
BS range
15.5
24
BS range
BS range
36
72.5
BS range
BS range
E-rated fuse links
5.5
15.5
17.5
25.8
38
5.5
8.25
15.5
5.5
7.2
15.5
38
E-rated for potential and small
power transformers
Expulsion fuse links
15 kV to 72 kV Expulsion fuse links
118
EATON Bussmann MV fuse links
Index
Part numbers
1.1NBUN
12ABCN
Page
36
40
Part numbers
2.75VKRH
24ABGN
Page
32
43
Part numbers
36TDQSJ
36TFQSJ
Page
22
22
Part numbers
JCG
JCH
Page
89-91
89-90
12ADFH
68-69
24ADIH
71
36TXQEJ
22
JCI
84
12AFFH
68-69
24AFIH
71
38CAV
53 & 85
JCK
89-90
12AISLJ
12AKGH
17
68-69
24AFMSJ
24AIMSJ
21
21
38GFZSJ
38GXZSJ
75-76
75-76
JCL
JCL-A
89-90
89-91
12BDGH
12BFGH
68-69
68-69
24CAV
24FDIH
51
71
5.5ABWN
5.5AMWN
38 & 85
38 & 85
JCL-B
JCQ
89-91
84
12CAV2
48
24FDMSJ
20
5.5BFNH
77-78
JCR
89-91
12FDLSJ
16
24FFMSJ
20
5.5BKNH
77-78
JCT
84
12FFGN
12FFLSJ
68-69
16
24OBGN
24OEGM
43
61
5.5CAV
5.5FFNH
46 & 85
77-78
JCU
JCW
82-83
84
12FXLSJ
12OBCN
12OEFM
12OHFM
12OHGM
12OLGM
12TDLEJ
12TFMSJ
12THLEJ
12THMEJ
12TKLEJ
12TXLEJ
15.5ABFN
15.5BDGH
15.5BFGH
15.5CAV
15.5FFVH
15.5OBFN
15.5OEFM
15.5OHGM
15.5OLGM
155GXQSJ
17.5ABGN
17.5AILSJ
17.5AIMSJ
17.5CAV
17.5OBGN
17.5OHGM
17.5TDLSJ
17.5TDMEJ
17.5TFLSJ
17.5THMEJ
17.5TKMEJ
175GDMSJ
175GFMSJ
175GX
2.75VFRH
16
40
58
58
58
58
17
17
17
17
17
17
41
70
70
49 & 85
80-81
41
59
59
59
75
42
18-19
18-19
50
42
60
18-19
18-19
18-19
18-19
18-19
75-76
75-76
75-76
32
24TDMEJ
24TFMEJ
24THMEJ
24TXMEJ
258GDQSJ
258GXQSJ
258GXZSJ
270303
3.6ABCN
3.6ABWN
3.6ADFH
3.6ADGH
3.6ADLSJ
3.6ADOSJ
3.6CAV2
3.6OEFM
3.6OEGM
3.6OLGM
3.6WDFH
3.6WDLSJ
3.6WDOH
3.6WDOSJ
3.6WFFH
3.6WFGH
3.6WFLSJ
3.6WFOH
3.6WFOSJ
3.6WJON
3.6WKFGH
3.6WKFH
3.6WKGH
3.6WKLSJ
36ADIH
36AFIH
36AFKH
36CAV
36OBGN
21
21
21
21
75-76
75-76
75-76
92
37
37
64-65
64-65
14
14
45
56
56
56
26-27
30
26-27
14 & 30*
26-27
26-27
30
26-27
14 & 30*
26-27
26-27
26-27
26-27
30
72
72
72
52
44
5.5VFNH
5.5VKNH
55GDMSJ
55GFMSJ
7.2ABCN
7.2ABWN
7.2ADFH
7.2AFFH
7.2AMWN
7.2BDGH
7.2BFGH
7.2CAV
7.2OBCN
7.2OBWN
7.2OEFM
7.2OHGM
7.2TDLSJ
7.2TFLSJ
7.2WFMSJ
7.2WFNH
7.2WKMSJ
7.2WKNH
72.5AFKH
8.25BFNH
8.25FFNH
A3354705
A3354710
A3354720
A3354730
A3354745
ASL
BBU
ECL055
ECL083
ECL155
JCD
JCE
33
33
75
75
39
39
66-67
66-67
39 & 85
66-67
66-67
47
39
39
57
57
15
15
31
28
31
28
73
79
79
92
92
92
92
92
95-98
99-105
86
87
88
84
84
JCX
JCY
JCZ
JDZ
K81ERX
KB**
KBR**
KD**
KU**
MV055
MV155
SB**
SBR**
SD**
SU**
TB**
TBR**
TD**
TU**
XAB**
XABR**
XAD**
XAU**
82
82-83
82-83
82-83
29
93-94
93-94
93-94
93-94
77-78
80-81
93-94
93-94
93-94
93-94
93-94
93-94
93-94
93-94
93-94
93-94
93-94
93-94
* Page 14: DIN Fuse link, Page 30 DIN motor fuse link
** Expulsion fuse links
EATON Bussmann MV fuse links
119
At Eaton, we’re energized by the challenge of powering a world
that demands more. With over 100 years experience in electrical
power management, we have the expertise to see beyond today.
From groundbreaking products to turnkey design and engineering
services, critical industries around the globe count on Eaton.
We power businesses with reliable, efficient and safe electrical power management solutions. Combined with our personal
service, support and bold thinking, we are answering tomorrow’s
needs today. Follow the charge with Eaton. Visit eaton.com/electrical.
Contact your
local Eaton office
Electrical Sector
Eaton’s Bussmann business
Melton Road
Burton-on-the-Wolds
LE12 5TH
Leicestershire
United Kingdom
[email protected]
www.bussmann.com
Eaton Industries Manufacturing GmbH
Electrical Sector EMEA
Route de la Longeraie
71110 Morges, Switzerland
Eaton.eu
© 2014 Eaton
All Rights Reserved
Printed in XXX
Publication No. CA132003EN
June 2014
Changes to the products, to the information contained in this
document, and to prices are reserved; so are errors and omissions.
Only order confirmations and technical documentation by Eaton is
binding. Photos and pictures also do not warrant a specific layout or
functionality. Their use in whatever form is subject to prior approval
by Eaton. The same applies to Trademarks (especially Eaton, Moeller,
and Cutler-Hammer). The Terms and Conditions of Eaton apply, as
referenced on Eaton Internet pages and Eaton order confirmations.
Eaton is a registered trademark.
All other trademarks are property
of their respective owners.
Follow us on social media to get the
latest product and support information.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
