APPLICATION GUIDE FLW

APPLICATION

GUIDE

FLW

Congratulations you have made a wise choice. This product has been designed, assembled and supplied in one of our world class manufacturing facilities and we feel sure that it will meet your expectations.

CONTENTS

CONTENTS

• PRODUCT RANGE

• GENERAL DESCRIPTION

• SPECIFICATIONS

• ELECTRICAL DATA

• FAN SPECIFICATION

• COOLING CAPACITY TABLES

• OPERATING LIMIT

. WATER CONSUMPTION

• UNIT DIMENSIONS

• UNIT INSTALLATION

• MAINTENANCE

• OPTIONS

• POINTS TO KEEP IN MIND

PAGE

9

10

11

12-13

14

5

6-7

7

8

3

4

1

2

PRODUCT RANGE

MODEL

FLW 2K

FLW 2,5K

FLW 2,8K

FLW 3K

FLW 4K

FLW 5K

FLW 7K

V / Ph / 50 Hz

230 V - 1Ph

230 V - 1Ph

230 V - 1Ph

230 V - 1Ph

230 V - 3Ph

400 V - 3Ph

230 V - 3Ph

400 V - 3Ph

230 V - 3Ph

400 V - 3Ph

230 V - 3Ph

400 V - 3Ph

NOMINAL

CAPACITY W

6.050

7.600

8.650

10.750

14.600

16.350

19.350

1

POWER

INPUT KW

1,57

2,26

2,90

3,38

4,37

5,36

7,40

GENERAL INFORMATION

The air conditioner, horizontal compact, water condensed type FLW, are specially design for small and average installation, office, house etc..

On standard version you are able to incorporate electrical heater, hot water coil for use in heat.

CABINET

The cabinet is made of electrozinced steel with epoxy painted finish and finished on polyester powder. Its compact dimensions and features allow the unit to be positioned in almost any location.

Internally the unit incorporate thermal acoustic insulation to reduce sound level.

EXCHANGER

Made of copper tubing with aluminium swirl fins, they are designed and specially dimensioned to obtain the maximum output

COMPRESSOR

One compressor of the hermetically sealed type cooled with internal thermal insulation. It is mounted on vibration-absorbent blocks both on the inside and outside, statically and dynamically balanced. In all cases the compressors are acoustically isolated, resulting in silent operation.

FAN

The units include a centrifugal three speed motor fan, with a motor directly fitted (except FLW 7K with beltspully), with high performance on air flow.

CONDENSER

The unit includes condenser plate, compact and resistant made on inoxidable steel, specially selected for this type of unit.

AIR FILTER

A polypropylene washable air filter is incorporated in the unit it is accessible for maintenance

COOLING CIRCUIT

Made of welded dehumidifying copper tube with access connections. Includes dehydrator filter, liquid recipient expansion system and H.P on all models and L.P on models 3,4,5 and 7.

ELECTRIC CIRCUIT

The electrical panel includes a printed board, necessary for installation, main switch in all models, and plate circuit board ready to control the unit, and incorporate defrosting timer thermostat. the function of the unit is controlled by cable thermostat.

REMOTE CONTROL

Digital remote controller by cable at 24V, digital selector temperature which permit to choose the following function:

• Selection ON/OFF

• Three functions mode: cool, heat and fan operating.

• Two options fan operating: AUTO (automatic) which

Select turn on and stop automatically fan mode

temperature. On mode ON the fan doesn´t stop

even when temperature is selected.

• Selector three steps fan, except for model

FLW 7K, only one step.

OPTIONS

• Electrical heater mounted on fan discharge.

• Hot water coil.

• Presostatic valves regulating water flow

• Digital thermostat programmable.

2

SPECIFICATIONS

MODEL

Nominal cooling capacity

Nominal absorber capacity

Air flow (max./min.)

Available static pressure. (1)

Nominal air flow

Water pressure drop

Net weight

Sound pressure level

(LP)

(2)

H

Dimensions

W

L

Hydraulic connections

FLW 2K FLW 2,5K FLW 2,8K FLW 3K FLW 4K FLW 5K FLW 7K

W (*)

Kw

6050

1,57

7600

2,26

8650

2,90

10750

3,38

14600

4,37

16350

5,36

19350

7,40

1550/600 1400/800 2350/1000 2250/1200 3100/1500 3100/1800 4500/2250

Pa l/h

KPa

Kg dB(A)

(mm)

(mm)

(mm)

140

1310

15

74

49

440

490

790

3/4" G

100

1700

19

78

50

440

490

790

3/4" G

120

2000

23

100

52

440

620

1080

3/4" G

100

2430

38

105

53

440

620

1080

3/4" G

120

3260

20

150

57

480

700

1500

1" G

120

3730

28

150

58

480

700

1500

1" G

210

4600

40

165

60

480

700

1500

1" G

(*) Interchange air temperature inlet : 27ºC DB / 19ºC WB

Water temperature inlet/outlet : 30ºC / 35ºC

(1) With minimum air flow admissible

(2) Radiated sound level for unit 2 meter distance wit duct in aspiration and air discharge, normal absorption in accordance with local and capacity of the unit.

ELECTRICAL SPECIFICATIONS

Voltage

NOMINAL TOTAL INPUT POWER

Compressor

Kw.

Indoor Fan

TOTAL

Kw.

Kw.

RUNNING CURRENT

Rated current

A

Starting current

Starting current

A

A

FLW 2K FLW 2,5K FLW 2,8K FLW 3K FLW 4K FLW 5K FLW 7K

230V /1Ph

230V / 400V 3Ph

1,42

0,15

1,57

9,1

12,0

53

2,08

0,18

2,26

13,0

16,0

65

2,50

0,40

2,90

15,0

19,0

91

2,98

0,40

3,38

3,82

0,55

4,37

4,76

0,60

5,36

6,20

1,20

7,40

17,4

10,0/5,8 13,0/7,5 16,0/9,3 21,2/12,2

23,0

16,0/10,0 20,0/12,0 24,0/14,0 30,0/18,0

90

78/39 106/53 117/60 135/67

3

ELECTRICAL CONNECTIONS

2

1

1

2

Power supply

Thermostat connection

FOR ELECTRICAL CONNECTION

REFER TO WIRING DIAGRAM IN

THE UNIT

MODEL VOLTAGE

50Hz

FLW

2K-2,5K-2,8K

230 V / 1Ph

FLW 3K

FLW 4K-5K

FLW 7K

230 V / 1Ph

230 V / 3Ph

400 V / 3Ph

230 V / 3Ph

400 V / 3Ph

230 V / 3Ph

400 V / 3Ph

3 X 4mm

2

3 X 4mm

2

4 X 4mm

2

5 X 2,5mm

2

4 X 6mm

2

5 X 4mm

2

4 X 10mm

2

5 X 6mm

2

Nº OF WIRES X SECTION

1

2

6 X 1,5mm

2

6 X 1,5mm

2

6 X 1,5mm

2

6 X 1,5mm

2

6 X 1,5mm

2

6 X 1,5mm

2

5 X 1,5mm

2

5 X 1,5mm

2

1 2 3 4 5

FLW 2K-2,5K-2,8K-3K

6 7 8 9 10 11 12 13

THERMOSTAT

A B C D E F G H

PCB (Electronic plate control)

Power supply

Q

230V/50HZ 1Ph + N

FLW 3K-4K-5K

THERMOSTAT

1 2 3 4 5 6 7 8 9 10 11 12 13

FLW 7K

THERMOSTAT

1 2 3 4 5 6 7 8 9 10 11 12 13

A B C D

PCB (Electronic plate control)

E F G H

Power supply

Q

230V/50HZ 3Ph

Q

400V/50HZ 3Ph + N + PE

Q : Main switch

4

A B C D E F G H

PCB (Electronic plate control)

Power supply

Q

230V/50HZ 3Ph

Q

400V/50HZ 3Ph + N + PE

FAN SPECIFICATIONS

FLW 2K

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

0

AVAILABLE STATIC PRESSURE

Pa.

20 40 60 80 100 120 140

1550 1450 1350 1250

1175 1160 1140 1050

675 660 650 640

1150 1000 800 600

950 790 600 ---

625 -------

Units leave factory connected in medium and low speed.

AVAILABLE STATIC PRESSURE

Pa.

FLW 2,5K

0 20 40 60 80 100 120

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

1400 1300 1150 1075

1100 1050 1000 925

---------

Units leave factory connected in medium and low speed.

950 800

800 ---

-----

---

---

---

FLW 2,8K

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

0

AVAILABLE STATIC PRESSURE

Pa.

20 40 60 80 100 120

2350 2200 2050 1900

2200 2075 1950 1800

1700 1350 1000

1550 1250 ---

1860 1840 1750 1650 1375 1050 ---

Units leave factory connected in medium and low speed.

AVAILABLE STATIC PRESSURE

Pa.

FLW 3K

0 20 40 60 80 100 120

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

2250 2150 2000 1800

2100 2000 1875 1675

1850 1820 1700 1525

1500 1220

1400

1260

---

---

Units leave factory connected in medium and low speed.

---

---

---

140

---

---

---

140

---

---

---

140

---

---

---

FLW 4K

FLW 5K

0

0

AVAILABLE STATIC PRESSURE

Pa.

20 40 60 80 100 120

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

3100 2850 2650 2450

2450 2300 2150 1975

1900 1800 1700 1600

2250 2050

1500 ---

1800

1800 1600 ---

---

Units leave factory connected in medium and low speed.

AVAILABLE STATIC PRESSURE

Pa.

20 40 60 80 100 120

140

---

---

---

AIR FLOW

HIGH SPEED

MEDIUM SPEED

LOW SPEED

3100 2850 2650 2450

2450 2300 2150 1975

1900 1800 -----

2250 2050

1800

---

---

---

1800

---

---

Units leave factory connected in medium and low speed.

FLW 7K

AIR FLOW

HIGH SPEED

OPEN PULLEY 1-1/2 TURN

OPEN PULLEY 3 TURN

Units leave factory with open pulley (1-1/2 V)

140

---

---

---

AVAILABLE STATIC PRESSURE

Pa.

0 30 60 90 120 150 180 210

4500 4200 3900 3600

4060 3750 3450 3200

3300 3000 2750

3750 3400 3100 2800 2550 2250 ---

2500

2900 2650 2300 ---

---

5

COOLING CAPACITY

INLET AIR

TEMPERATURE TO

INDOOR UNIT

21°C DB

15°C WB

24°C DB

17°C WB

27°C DB

19°C WB

29°C DB

21°C WB

32°C DB

23°C WB

COOLING

CAPACITY

IN kW

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

30°C

5,72

4,18

6,21

4,49

6,75

4,79

7,33

4,83

7,95

5,12

FLW 2K

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

5,44

4,04

5,92

4,35

6,44

4,65

7,00

4,69

7,60

4,97

5,16

3,90

5,62

4,21

6,12

4,51

6,66

4,54

7,24

4,83

4,88

3,76

5,32

4,07

5,80

4,37

6,32

4,40

6,88

4,69

4,59

3,62

5,02

3,93

5,48

4,23

5,98

4,26

6,51

4,55

55°C

4,30

3,48

4,71

3,79

5,15

4,09

5,62

4,12

6,13

4,40

30°C

7,16

5,16

7,74

5,52

8,37

5,87

9,04

5,89

9,76

6,22

FLW 2,5K

35°C

CONDENSING TEMPERATURE

40°C 45°C 50°C

6,87

5,01

7,43

5,37

8,04

5,72

8,69

5,74

9,39

6,07

6,57

4,86

7,12

5,22

7,71

5,57

8,34

5,59

9,02

5,92

6,27

4,71

6,80

5,07

7,37

5,42

7,99

5,44

8,64

5,77

5,96

4,56

6,47

4,92

7,03

5,27

7,62

5,29

8,25

5,62

55°C

5,64

4,41

6,14

4,77

6,68

5,12

7,25

5,14

7,86

5,47

INLET AIR

TEMPERATURE TO

INDOOR UNIT

21°C DB

15°C WB

24°C DB

17°C WB

27°C DB

19°C WB

29°C DB

21°C WB

32°C DB

23°C WB

COOLING

CAPACITY

IN kW

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

30°C

8,07

6,20

8,77

6,70

9,52

7,17

10,32

7,21

11,19

7,66

FLW 2,8K

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

7,74

6,04

8,41

6,53

9,13

7,01

9,91

7,04

10,74

7,49

7,40

5,88

8,04

6,37

8,74

6,84

9,49

6,87

10,29

7,32

7,05

5,72

7,68

6,20

8,34

6,67

9,06

6,70

9,83

7,15

6,71

5,55

7,30

6,04

7,94

6,50

8,63

6,53

9,36

6,97

55°C

6,36

5,39

6,93

5,87

7,53

6,34

8,19

6,36

8,88

6,80

30°C

9,88

7,42

10,74

8,00

11,68

8,57

12,70

8,63

13,80

9,17

FLW 3K

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

9,50

7,23

10,34

7,81

11,24

8,37

12,23

8,43

13,29

8,97

9,11

7,05

9,92

7,62

10,80

8,18

11,76

8,24

12,78

8,77

8,72

6,86

9,51

7,43

10,36

7,99

11,28

8,04

12,27

8,57

8,33

6,67

9,09

7,24

9,91

7,80

10,79

7,85

11,74

8,38

55°C

7,93

6,48

8,66

7,05

9,45

7,60

10,30

7,65

11,21

8,18

INLET AIR

TEMPERATURE TO

INDOOR UNIT

21°C DB

15°C WB

24°C DB

17°C WB

27°C DB

19°C WB

29°C DB

21°C WB

32°C DB

23°C WB

COOLING

CAPACITY

IN kW

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

30°C

13,70

10,23

14,86

11,00

16,11

11,75

17,47

11,81

18,91

12,52

FLW 4K

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

13,10 12,52 11,94 11,37

9,93

14,23

10,70

15,44

11,45

16,74

11,51

18,14

12,22

9,64

13,60

10,41

14,77

11,16

16,03

11,21

17,37

11,92

9,36

12,98

10,13

14,11

10,87

15,32

10,92

16,61

11,63

9,09

12,37

9,85

13,45

10,59

14,61

10,64

15,85

11,34

55°C

10,81

8,83

11,77

9,59

12,80

10,32

13,91

10,36

15,09

11,06

Nominal capacity established on following conditions:

• Air inlet temperature : 27ºC DB/19ºC WB

• Inlet/outlet water temperature: 30ºC/35ºC

• Condensing Temperature between 40 and 45ºC depending on models

30°C

14,96

11,13

16,19

11,96

17,52

12,75

18,96

12,80

20,51

13,57

FLW 5K

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

14,45 13,93 13,39 12,83

10,88

15,65

11,70

16,95

12,50

18,36

12,55

19,87

13,32

10,62

15,10

11,45

16,36

12,24

17,73

12,30

19,21

13,06

10,36

14,53

11,18

15,75

11,98

17,08

12,03

18,51

12,79

10,09

13,93

10,91

15,12

11,70

16,41

11,76

17,79

12,52

55°C

12,27

9,82

13,33

10,64

14,47

11,43

15,71

11,48

17,04

12,24

DB:Dry bulb

WB:Wet bulb

6

COOLING CAPACITY

FLW 7K

INLET AIR

TEMPERATURE TO

INDOOR UNIT

COOLING

CAPACITY

IN kW

30°C

CONDENSING TEMPERATURE

35°C 40°C 45°C 50°C

21°C DB

15°C WB

24°C DB

17°C WB

27°C DB

19°C WB

29°C DB

21°C WB

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

TOTAL

SENSIBLE

18,46

13,65

19,97

14,65

21,61

15,62

23,38

15,69

17,81

13,33

19,29

14,33

20,89

15,30

22,61

15,36

17,15

13,01

18,59

14,00

20,14

14,97

21,81

15,03

16,47

12,67

17,86

13,67

19,36

14,63

20,98

14,69

32°C DB

23°C WB

TOTAL

SENSIBLE

25,28

16,61

24,46

16,29

23,61

15,95

22,72

15,61

21,80

15,26

Nominal capacity established on following conditions:

• Air inlet temperature : 27ºC DB/19ºC WB

• Inlet/outlet water temperature: 30ºC/35ºC

• Condensing Temperature between 40 and 45ºC depending on models

15,78

12,34

17,12

13,33

18,56

14,28

20,12

14,34

55°C

15,07

12,00

16,35

12,98

17,74

13,93

19,24

13,99

20,84

14,90

Data based on following air flow

AIR FLOW M3 /H

2K

1100

2,5K

1200

2,8K

1900

MODEL FLW

3K 4K

2000 2300

DB:Dry bulb

WB:Wet bulb

5K

2500

COEFFICIENTS OF CORRECTION OF COOLING CAPACITY

Data of cooling capacity rated on tables are calculated for nominal air flow, for minimum /maximum air flow, you must follow the following table

AIR FLOW

TOTAL CAPACITY

SENSIBLE CAPACITY

7K

3500

FLW 2K

MAX NOMINAL MIN.

1,05 1 0,89

1,15 1 0,77

AIR FLOW

TOTAL CAPACITY

SENSIBLE CAPACITY

FLW 2,5K

MAX NOMINAL MIN.

1,03

1,07

1

1

0,92

0,84

FLW 2,8K

MAX.

NOMINAL MIN

1,03

1,09

1

1

0,90

0,77

FLW 3K

MAX.

NOMINAL MIN.

1,02

1,05

1

1

0,91

0,80

AIR FLOW

TOTAL CAPACITY

SENSIBLE CAPACITY

FLW 4K

MAX.

NOMINAL MIN.

1,04 1 0,92

1,13 1 0,83

FLW 5K

MAX.

NOMINAL MIN

1,03 1 0,94

1,09 1 0,87

FLW 7K

MAX NOMINAL MIN

1,03 1 0,92

1,11 1 0,82

OPERATING LIMITS

32ºC / 38ºC

Water Temperature inlet

/outlet into the outdoor section

-- /21ºC

19°C / 14ºC 32°C / 23ºC

Air temperature inlet into indoor section D.B/W.B

7

W.B: Wet bulb

D.B: Dry bulb

WATER CONDENSER CONSUMPTION AND PRESSURE DROP

Normally, the water condense is used across a cooling tower with water temperature around 30ºC, and water flow available to work the unit with condensation temperature between 40 and 45ºC.

You are able not to use a cooling tower when the unit is near a river etc.. with enough flow and enough quality of the water. The use of the water must be used always across a previous Analysis of water.

If the water inlet temperature is below 20ºC, It is then necessary to use a regulation valve (Option) to maintain condensing temperature value between 40 and 45 ºC.

Depending inlet water temperature and condensation temperature needed you will be able to calculate water consumption following the table below.

TABLE OF WATER CONSUMPTION ON UNITS FLW (L/H) (*)

DIFFERENCES BETWEEN:

CONDENSATION TEMPERATURE AND INLET WATER TEMPERATURE (ºC)

UNIT

FLW 2K

10

2280

FLW 2,5K

2900

15

850

1100

20

500

650

25

360

470

30

275

360

35

225

300

40

185

245

45

160

210

1250 750 550 420 340 280 245

FLW 2,8K

3450

FLW 3K

4100

FLW 4K

5550

1500

2050

900

1200

650

850

500

600

360

470

350

470

300

400

FLW 5K

6250 2300 1400 1000 800 640 540 470

FLW 7K

7500 2900 1700 1300 1000 800 680 590

( * ) Indoor inlet temperature

27ºC WB / 19ºC DB

COEFFICIENTS FOR DIFFERENT AIR INLET TEMPERATURE.

For different air inlet temperature multiply the consumption by the coefficient of this table.

Coefficients of water consumption

21/15

INDOOR AIR INLET TEMPERATURE (DB/WB)

24/17 27/19 29/21 32/23

0,87 0,93 1 1,07 1,14

PRESSURE DROP ON WATER CONDENSER

100

90

80

70

60

50

40

30

FLW 2K-2,5K-2,8K-3K

FLW 4K-5K-7K

20

10

0

1000 1500 2000 2500 3000 3500 4000 4500 5000

WATER FLOW (L / H)

8

DIMENSIONS

A

B

C

D

E

I

F

G

H

J

K

L

M

N

Ñ

2K - 2,5K

440

790

490

335

410

45

35

385

20

55

405

30

40

380

20

2,8K - 3K

440

1080

620

540

490

50

25

395

20

120

480

20

30

395

15

4K - 5K - 7K

480

1500

700

545

910

45

25

435

20

145

515

40

30

435

15

C

B

A

8

11

10

38

9

6

2

9

8

11

6.2

6.1

D

E

B

F

20

J K

C

L

5

10

2

5

FLW 2K-2,5K

3

4

7

1

INLET AIR

FLW

2,8K-3K-

4K-5K-7K

12

3

7

4

1

INLET AIR

9

OUTLET

AIR

OUTLET

AIR

4

5

6.1

1

2

3

9

10

11

12

6.2

7

8

MOTOR FAN

COMPRESSOR

COIL

AIR FILTER

WATER EXCHANGER

ELECTRICAL BOX FLW 2,8-3

ELECTRICAL BOX FLW 4-5-7

DRAIN PAN

INLET/OUTLET WATER CONNECTIONS

POWER SUPPLY

MAIN SWITCH

DRAINAGE TUBE

MOTOR (ONLY MODEL 7)

DIAMETER DRAINAGE TUBE

FLW

2K-2,5K

16 mm

FLW

2,8K-3K-4K-5K-7K

27 mm

INSTALLATION

PRE-INSTALLATION

Prior to install the equipment make sure of the following points:

• Leave enough space for access to air supply, water section, power supply and outlet condense.

• The water section must have the correspondent valves.

• Easy extraction of the air filter.

• Easy access to lateral panel for easy accessibility to all services of the unit.

• Unit must be mounted with springs.

• The electrical section must be done following legal normative

• Check that the tension is the same as installation place.

• Check the water condense quality, across analysis.

• Keep in mind water inlet temperature of the unit. Temperature below 20ºC you will need a water regulation pressostatic valve ( element as option) to maintain condensation temperature value between 40 and 45ºC.

• Depending on water entry temperature, you have to calculate the water flow following the consumption table.

• Check that air flow needed correspond for duct installation.

• Keep in mind power supply for maximum consumption for each unit.

INSTALLATION

• All installation must be carried out by qualified personnel

• Make sure that the unit is completely disconnected from the power supply before carrying out any type of work on the unit.

Hydraulic circuit:

• Make sure that the water connections are correct, inlet water (down side), outlet water (upper side)

• Fit a water filter in the outlet water connection, the step of the mesh should not be less than 0.5mm, which avoid welded and dirty get to the unit.

• If quality of water is not good, may be necessary to install a decalcified

• Install cut off valves at inlet and outlet water connections, because of in case of repairs, the hydraulic circuit can be independent.

• Install an adequate water pump, and all the elements necessaries for the installation.

• Air flow:

• All models include three fan speed motor fan.

• Make the motor fan connections for the fan speed required to adequate the air flow needed for the installation

• Drainage tube:

• Use the flexible tube connected to the tray as a drainage tube.

Cause a siphon with this tube in order to avoid the inlet of scents from the installation to the unit.

• Install a siphon from the drainage tube of tray with a difference in height of 80 mm to prevent these from not evacuating due to the negative pressure created by the fans. The pipe will have a 2% slope to make it easier for the condensates to drain off.

Mín. 80 mm.

2%

Tapón para registro y limpieza

10

SERVICE AND MAINTENANCE

• The unit under supply, have rotating objects and high temperature into the pipe. Make sure to turn off electrically the unit before to access for maintenance or revision.

• Air filter: Clean the filter (maximum each 6 months), but the clean of the filter depend on the ambient where the units is working.

• Water filter: Realise a clean of the filter.

• Security elements: The unit include electrical elements of security( Internal thermal protection on the compressor and motor fan, external thermal protection on the compressor and motor three phase) and cooling elements of security like high and low pressostat pressure with electrical rearm. If limits of function of the unit is out of conditions of work, some protections will be display.

LOCALISATION OF PROBLEMS

PROBLEMS

• Cut low pressure (Electrical rearm) (*)

• Cooling capacity low.

• Freeze on coil

CAUSES

• Air in temperature very low

• Defect on refrigerant charge.

Test that the refrigerant is correct.

• Air filter dirty

• low air flow.

• Water temperature is too low

• Cut high pressure (Electrical ream) (*)

• High consumption

• Thermal compressor protection cut

• High water temperature

• Low air flow

(*) Rearm electrically the unit turning off/on, after repair the cause which produce a cut on high and low pressure.

11

OPTIONS

HOT WATER COIL TECHNICAL DATA

DIFFERENCES BETWEEN WATER INLET

TEMPERATURE AND COIL AIR INLET (ºC)

CAPACITY IN KW FOR WATER FLOW OF 250 L/H .

PRESSURE AIR DROP = 15 Pa.

PRESSURE WATER DROP = 20K Pa

3

DATA CALCULATED FOR AIR FLOW = 1100 m /h

FLW -2K -2,5K

60 50

5,10 4,25

40

3,40

DIFFERENCES BETWEEN WATER INLET

TEMPERATURE AND COIL AIR INLET (ºC)

CAPACITY IN KW FOR WATER FLOW OF 350 L/H .

PRESSURE AIR DROP = 20 Pa.

PRESSURE WATER DROP = 40K Pa

FLW -2,8K - 3K

60

50

40

7,70 6,50 5,20

DIFFERENCES BETWEEN WATER INLET

TEMPERATURE AND COIL AIR INLET (ºC)

CAPACITY IN KW FOR WATER FLOW OF 600 L/H .

PRESSURE AIR DROP = 13 Pa.

PRESSURE WATER DROP = 50K Pa

DATA CALCULATED FOR AIR FLOW = 2500 m /h

3

FLW -4K -5K

60 50 40

12,40 10,30 8,30

DIFFERENCES BETWEEN WATER INLET

TEMPERATURE AND COIL AIR INLET (ºC)

CAPACITY IN KW FOR WATER FLOW OF 600 L/H .

PRESSURE AIR DROP = 18 Pa.

PRESSURE WATER DROP = 50K Pa

3

DATA CALCULATED FOR AIR FLOW = 3500 m /h

FLW 7K

60 50 40

13,60 11,30 9,00

INSTALLATION

This option kit has a hot water coil with two profile attachment for coil to the unit

Make sure to install the hot water coil to the aspiration of the unit, then:

• Dismantle the air filter attachment.

• Fix the profile attachment across screw to the aspiration.

• Fix the hot water coil to the profile attachment. Put the new air filter across the profiles.

Air filter

Profile attachment

Hot water coil

12

OPTIONS

ELECTRICAL HEATER

FLW 2K - 2,5K

FLW

2,8K - 3K

FLW

4K - 5K - 7K

Power

5 Kw 1 Step

6 Kw 1Step

9 Kw 1Step

9 Kw 1Step

12 Kw 1 Step

Voltage

230 V 1Ph -50Hz

230 V /400 V 3Ph -50Hz

230 V /400 V 3Ph -50Hz

Electrical box

Electrical heater

Knock out

INSTALLATION

•The electrical should be install into the impulsion fan of the unit.

• Fix the screw following the figure.

• Take out the knock out, and take the electrical supply of the electrical heater to the elctrical box of the unit.

PRESOSTATIC VALVES

If water inlet temperature is below 20ºC we recommend to maintain level condensation temperature in (40 a

45ºC)

FUNCTION

The presostatic valve maintain some values of the condensation pressure regulating the water flow which enter into the condenser.

When the condensation pressure is up, the valve open and water enter. and when pressure is low the valve close.

Situation pipe in

Connect to plug high pressure

Water out

VASTAGE OF

REGULATION

Water in

CONDENSER

INSTALLATION

• Substitute the out pipe of the exchanger plate into the

unit for a presostatic valve.

• Keep in mind the row indicated in the valve.

• El vastage regulation must be above for easy access to the regulation.

• Connect the capillary tube of the valve to the plug of high pressure in the pipe of the unit.

UNIT

REGULATION PRESOSTATIC VALVES

• Connect a manometer of high pressure (30 bar) near the refrigerating circuit of the unit.

• Turn over the vastage in the head of the valve( right the valve open, left the valve close) regulating the water flow which enter into the unit.

• You must leave the unit working during 10 minutes and see the indication of the manometer. If the condensation pressure temperature is approximately 45ºC the valve is correctly regulated. If not restart the regulation described before.

13

POINTS TO KEEP IN MIND

Abrasive surfaces

Low temperature

High temperature

Risk of injury with moving objects

Electrical voltage

Risk of injury with rotating objects

ATTENTION - WARNING

Electrical shock hazard can cause injury or death. Before attempting to perform any service or maintenance on the unit, turn OFF the electrical power.

FILTER CLEANING

Check the air filter and make sure it is not blocked with dust or dirt

If the filter is dirty, wash it in a bowl neutral soap and water, drying it in the shade before inserting it in the unit

STANDARD GUIDELINES TO LENNOX EQUIPMENT

All technical data contained in these operating instructions including the diagrams and technical description remains the property of Lennox and may not be used (except for the purpose of familiarising the user with the equipment), reproduced, photocopied, transferred or transmitted to third parties without prior written authorisation from Lennox.

The data published in the operating instructions is based on the latest information available. We reserve the right

to make modifications without notice.

We reserve the right to modify our products without obligation to modify previously supplied goods.

These operating instructions contain useful and important information for the smooth operation and maintenance of your equipment.

The instructions also includes guidelines on how to avoid accidents and serious damage before commissioning the equipment and during its operation and how to ensure smooth and fault-free operation. Read the operating instructions carefully before starting the equipment, familiarise yourself with the equipment and handling of the installation and carefully follow the instructions. It is very important to be properly trained in handling the equipment.

These operating instructions must be kept in a safe near the equipment.

Like most equipment, the unit requires regular maintenance. This section concerns the maintenance personnel and management.

If you have any queries or would like to receive further information on any aspect relating to your equipment, do not hesitate to contact us.

14

BELGIUM :

CZECH REPUBLIC :

FRANCE :

GERMANY :

MIDDLE EAST :

NETHERLANDS :

POLAND :

PORTUGAL :

RUSSIA :

SLOVAKIA :

SPAIN :

UKRAINE :

UNITED KINGDOM :

OTHER EUROPEAN

COUNTRIES, AFRICA,

LENNOX DISTRIBUTION :

LENNOX BENELUX N.V./S.A.

tél. : + 32 3 633 30 45 fax : + 32 3 633 00 89 e-mail : [email protected]

LENNOX JANKA tél. : + 420 2 510 88 111 fax : + 420 2 579 10 393 e-mail : [email protected]

LENNOX FRANCE tél. : + 33 4 72 23 20 20 fax : + 33 4 78 20 07 76 e-mail : [email protected]

LENNOX DEUTSCHLAND GmbH tél. : + 49 69 42 09 79 0 fax : + 49 69 42 09 79 40 e-mail : [email protected]

LENNOX DISTRIBUTION tél. : + 971 4 262 9309 fax : + 971 4 266 7082 e-fax : + 1 240 368 73 62

Mobile : 971 50 4510669 e-mail : [email protected]

LENNOX BENELUX B.V.

tél. : + 31 33 2471 800 fax : + 31 33 2459 220 e-mail : [email protected]

LENNOX POLSKA Sp. z o. o.

tél. : + 48 22 832 26 61 fax : + 48 22 832 26 62 e-mail :

[email protected]

LENNOX CLIMATIZAÇAO LDA.

tél. : +351 22 999 84 60 fax : +351 22 999 84 68 e-mail : [email protected]

LENNOX DISTRIBUTION MOSCOW tél. : + 7 095 246 07 46 fax : + 7 502 933 29 55 e-mail : [email protected]

LENNOX SLOVAKIA tél. : + 421 2 44 87 19 27 fax : + 421 2 44 88 64 72

LENNOX REFAC S.A.

tél. : + 34 915 40 18 10 fax : + 34 915 42 84 04 e-mail : [email protected]

LENNOX DISTRIBUTION KIEV tél. : + 380 44 213 14 21 fax : + 380 44 213 14 21 e-mail : [email protected]

LENNOX INDUSTRIES LTD tél. : + 44 1604 599400 fax : + 44 1604 594200 e-mail : [email protected]

tél. : + 33 4 72 23 20 14 fax : + 33 4 72 23 20 28 e-mail : [email protected]

AGU-FLW-0302

www.Lennoxeurope.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
