Aastra 53i IP Phone User guide
6753i IP Phone
User Guide
Release 2.2
Rev 01
www.8x8.com | 1.866.879.8647
Table of Contents
Introduction.................................................................................................................... 1
Phone Parts Checklist ................................................................................................... 1
Phone Features............................................................................................................ 3
Getting Started ............................................................................................................ 4
Plugging in and Starting the Phone............................................................................ 4
Idle Screens ..................................................................................................................... 6
Incomplete Configuration.............................................................................................. 7
No Service........................................................................................................................ 7
Connected State Screens............................................................................................ 8
IP Phone Keys and Key Descriptions............................................................... 8
Key Panel.......................................................................................................................... 9
Methods for Customizing Your Phone ..........................................................12
Phone Options via the IP Phone UI ..........................................................................12
Phone Options via the 8x8 Phone Web UI.............................................................14
Phone Status ..............................................................................................................17
Phone Status via IP Phone UI ....................................................................................17
Finding Your Phone’s IP Address ............................................................................18
Phone Status via the 8x8 Web Phone UI................................................................19
Customizing Your Phone ......................................................................................19
Line Keys and Programmable Keys ................................................................36
Multiple Line and Call Appearance Keys.................................................................36
Programmable Keys .....................................................................................................37
Line Key ..........................................................................................................................38
Speeddial Key ...............................................................................................................39
Do Not Disturb (DND) Key .........................................................................................43
Flash Key ........................................................................................................................44
Phonebook Key .............................................................................................................45
Callers List Key..............................................................................................................46
Transfer Key ...................................................................................................................47
iii
Table of Contents
Ring Tones and Tone Sets .........................................................................................19
Configuring Ring Tones and Tone Sets ..................................................................21
Contrast Level ...............................................................................................................22
Live Dialpad* ..................................................................................................................23
Set Audio........................................................................................................................23
Time and Date ...............................................................................................................25
Language........................................................................................................................28
User Password ..............................................................................................................30
Resetting a User Password........................................................................................31
Restarting your phone .................................................................................................32
Phone Lock ....................................................................................................................33
Defining an Emergency Dial Plan..............................................................................35
Table of Contents
Conference Key ............................................................................................................48
Intercom Key ..................................................................................................................49
None Key ........................................................................................................................51
Phone Lock Key ............................................................................................................51
Deleting a Key ..............................................................................................................53
Making Calls ................................................................................................................53
Dialing a Number ..........................................................................................................53
To Call an Outside Number........................................................................................54
To Call Another Extension ..........................................................................................54
Making a Call .................................................................................................................54
Receiving a Call ............................................................................................................54
Using Handsfree Speakerphone...............................................................................55
Using a Headset ...........................................................................................................55
Redial...............................................................................................................................56
Mute.................................................................................................................................58
Receiving Calls...........................................................................................................58
Answering an Incoming Call.......................................................................................59
Handling Calls ............................................................................................................59
Placing a Call on Hold .................................................................................................59
Transferring Calls..........................................................................................................61
Conferencing Calls.......................................................................................................62
Ending Calls...................................................................................................................65
Managing Calls ..........................................................................................................65
Additional Features..................................................................................................90
Suppress DTMF Playback ..........................................................................................92
Display DTMF Digits ....................................................................................................93
Enable/Disable Call Waiting ......................................................................................94
Play Call Waiting Tone ................................................................................................96
Stuttered Dial Tone ......................................................................................................97
XML Beep Support ......................................................................................................97
Status Scroll Delay.......................................................................................................98
Incoming Call Interrupts Dialing ................................................................................98
Goodbye Key Cancels Incoming Calls................................................................. 100
Message Waiting Indicator...................................................................................... 101
Incoming Intercom Call Features ........................................................................... 102
Using Redial Key for “Last Number Redial”......................................................... 105
Customizable Callers List Key ................................................................................ 105
Autodial (Hotline and Warmline) ............................................................................ 105
iv
Table of Contents
Directory List..................................................................................................................66
Callers List......................................................................................................................75
Call Forwarding .............................................................................................................81
Missed Calls Indicator .................................................................................................84
Voicemail System .........................................................................................................85
Table of Contents
Answer and Ignore Softkeys for XML Applications ........................................... 106
XML Softkey for Special Characters in XML Applications............................... 106
Model 536EM Expansion Module ................................................................. 107
Using the Expansion Module................................................................................... 108
Troubleshooting Solutions................................................................................109
Limited Warranty.....................................................................................................143
What Is Covered? ..................................................................................................... 144
Appendix A - Time Zone Codes .....................................................................A-1
Table of Contents
v
Introduction
Congratulations on the purchase of your 8x8 Virtual Office service and new
6753i IP Phone. The phone has been manufactured to meet very high standards
for convenient and reliable service.
This telephone will operate according to the preloaded scripts. Please use the
interactive menu and soft buttons to access features provided by your 8x8 Virtual
Office Service.
Phone Parts Checklist
Remember to save your sales receipt in case you ever need warranty service.
Check to make sure your package includes the items described below:
6753i IP Phone
Handset
Telephone Base Desk Legs
Power Adapter
Handset Cord
Wall Mount Drilling Template
Programmable Key Card
Ethernet Cable
CD Reference
Screws and Anchors for Wall Mount
Introduction
Model 6753i Series IP Phone User Guide — 1
Introduction
When you unpack your phone, you should ensure that you have all of the
following items. Remember to save your sales receipt in case you ever need
warranty service 6753i IP Phone Parts
6753i IP Phone
Wall Mount
Drilling Template
asdassa
asdadsda
Telephone Handset
Base Desk
Legs
Power
Adapter
Handset
Cord
Ethernet
Cable
Programmable
Key Card
Reference
CD
Wall Mount
Drilling Template
Screws and
Anchors for
Wall Mounting
Optional Accessories (Not Included)
PoE
(Power over Ethernet)
Inline Power Injector
Additional Ethernet Cable
(Category 5/5e straight
through cable)
2 — Model 6753i Series IP Phone User Guide
Model 536EM
Expansion Module
K ey Panel
6 keys with LEDs (4 are programmable)
High quality speakerphone
HAC handset
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
Goodbye key
Options key
Hold key
Redial Key
Volume control
Navigational keys
3-line LCD screen
Message waiting lamp
Keypad
Mute key
3 call appearance lines
Phone Features
• 3-line LCD screen
• 6 top keys: 4 are programmable keys
• 3 call appearance lines with LEDs
• Supports up to 9 call lines
• Full-duplex speakerphone for handsfree calls
• Headset support (modular connector)
• Built-in two-port, 10/100 Ethernet switch - lets you share a connection
with your computer
Model 6753i Series IP Phone User Guide — 3
Phone Features
Speakerphone/headset toggle key
Getting Started
• Inline power support (based on 802.3af standard) which eliminates
power adapters
• AC power adapter (included)
• Enhanced busy lamp fields*
• Set paging*
*Availability of feature dependent on your phone system or service provider.
Getting Started
The 6753i must be set up and configured prior to its first use. This section
describes phone behavior and start up screens you may see when the phone is
first plugged in, or when it is restarted.
Plugging in and Starting the Phone
The 6753i automatically begins the start up sequence as soon as it is
connected. The phone goes through this process the first time you plug in your
phone and every time you restart your phone. The phone displays the following
startup screens.
Initializing
network
8x8 6753i
The 6753i phone then checks settings and looks for new configuration and
firmware updates for the phone from a server. If a new update is found, the
phone displays the message “Updating Configuration”. This may take a few
moments while the phone downloads the latest updates.
Updating
configuration
4 — Model 6753i Series IP Phone User Guide
Note: New updates to your phone can be automatically scheduled from the
server. This is set up on the phone system by your System Administrator and should be scheduled during non-business hours or slow
call periods.
Important! Do not unplug or remove power to the phone while it is
checking or installing firmware and configuration information.
If language packs were loaded to your phone by your System Administrator, the following
screen displays during startup.
Downloading
language packs.....
When the configuration update is complete, the phone displays the
following screens.
Network
DSP
Done
Model 6753i Series IP Phone User Guide — 5
Getting Started
SIP
Getting Started
Idle Screens
Idle Screen 1
When the phone has successfully updated the configuration and connected to
the network, the phone displays the Idle State screen:
1
John Burns
9054550055
Sat Jun 8 2:55pm
The Idle State screen lists your name, extension (or phone number), and day,
date, and time. The "1" in the upper corner in the above example indicates the
idle screen for the first line appearance. You can use the left and right arrow keys
to scroll through the idle screens for all three line appearances. The 6753i allows
for scrolling up to 3 lines.
This screen is shown whenever your phone is not in use.
Idle Screen 2
The second display line displays the following temporary messages if the event
occurs:
• No Service
• DHCP Failed
• Restarting......
• New IP Obtained
• Network Disconnected/Connected
Note: Since the "Network Disconnected/Connected" display on two lines,
the date and time does not show if this event displays.
The second line can also display the following status messages, listed in order of
display priority:
• Call forward status
• DND On (Do Not Disturb)
• Number of missed calls
6 — Model 6753i Series IP Phone User Guide
When more than one status message displays, the
message to indicate you can use the
through the remaining messages.
1
and
is shown after the
navigation keys to scroll
John Burns
CFWD All
Jun 8 2:55pm
2
Network Connected
Incomplete Configuration
If your phone displays an "Incomplete Config" message without any extension
or user name at the end of the start up sequence instead of an Idle state screen,
this indicates the phone configuration that was downloaded from the
configuration server is not complete or correct. Contact your System
Administrator for assistance.
No Service
When the phone is not properly connected to the network, or the account
has not been configured by the Network Administrator, the "No Service" or
"Network Disconnected" prompt appears on the display and the telephone
status light turns ON. The phone also displays the default time and date of
12:00am Jan. 1st, 2000. Check that the cables are tightly connected to the
phone and to the wall jack. The phone should automatically detect when the
connection is reconnected and display the "Network Connected"
prompt temporarily.
For more information about connecting your phone, refer to the 8x8 6753i User
Reference Manual. Check with your System Administrator for assistance.
Model 6753i Series IP Phone User Guide — 7
Getting Started
If changes have been made to your phone settings, you may need to restart your
phone. For more information on restarting your phone, see "Restarting your
phone" on page 31.
IP Phone Keys and Key Descriptions
Connected State Screens
When the phone has successfully connected to the network, a
to the left of the phone number indicating the phone is on-hook.
1
icon appears
John Burns
9054550055
Sat Jan 1 12:15 p
When the phone is off-hook, the icon displays as follows.
1
John Burns
9054550055
03:00
Note: You can use the left and right arrow keys to display the Idle or
Connected screens on other lines.
IP Phone Keys and Key Descriptions
The following sections describe the various 6753i phone key functions, and how
they help you make and manage your calls and caller information.
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
8 — Model 6753i Series IP Phone User Guide
Key Panel
The following table identifies the keys on the key panel of your 6753i IP phone.
Keys
Key Description
Goodbye
Options
Goodbye key - Ends an active call. The Goodbye key also
exits an open list, such as the Options List, without saving
changes.
Hold
Hold key - Places an active call on hold. To retrieve a held
call, press the call appearance button beside the light that
is flashing.
Redial
Redial key - Redials up to 100 previously dialed numbers.
Pressing the Redial key twice simultaneously redials the
last dialed number.
Volume control key - Adjusts the volume for the handset,
headset, ringer, and handsfree speaker.
Line 1
Line/Call Appearance key - Connects you to a line or
call. The 8x8 6753i IP phone supports up to 3 line keys.
Line 2
Line 3
Speaker/
Headset
Mute
Handsfree key - Activates Handsfree for making and
receiving calls without lifting the handset. When the audio
mode option is set, this key is used to switch between a
headset and the handsfree speakerphone.
Mute key - Mutes the microphone so that your caller
cannot hear you (the light indicator flashes when the
microphone is on mute).
Model 6753i Series IP Phone User Guide — 9
IP Phone Keys and Key Descriptions
Options key - Accesses options to customize your phone.
Your System Administrator may have already customized
some of your settings. Check with your System
Administrator regarding the changing the administratoronly options.
IP Phone Keys and Key Descriptions
Keys
Key Description
Navigation keys - Pressing the UP and DOWN arrow
keys lets you view different status and text messages on
the LCD display (if there are multiple status/text
messages). These buttons also let you scroll through
menu selections, such as the Options List.
Pressing the LEFT and RIGHT arrow keys lets you view
the different line/call appearances. While in the Options
List, these keys allow you to exit or enter the current
option. When you are editing entries on the display,
pressing the LEFT arrow key erases the character on the
left; pressing the RIGHT arrow key sets the option.
Programmable keys - Six Top Keys: 4 are programmable
keys.
Note: Keys 1 and 2 are hardcoded as the SAVE and
DELETE keys, respectively, and cannot be altered.
The following are the default functions for the
programmable keys on the 6753i IP phone:
1 - Save
(hardcoded)
Allows you to save numbers
and/or names to the Directory.
Using this key, you enter the
number, name, and line (or
speeddial key) to record in the
Directory List.
2 - Del (Delete)
Allows you to delete entries
(hardcoded)
from the Directory List and
Callers List. (Must enter the
Directory or Callers list and
select an entry, then press
twice to delete entry).
3 - DND (Do Not Disturb) Allows you put your telephone
in a state that will not ring and
calls will automatically be
forwarded to voicemail (or to a
busy signal if voicemail is
turned off).
4 - Call Fwd
Access the last 200 calls
received.
5 - Xfer (Transfer)
Transfers the active call to
another number.
6 - Conf (Conference)
Begins a conference call with
the active call.
Note: For more information about programming keys 3, 4,
5, and 6 to perform specific functions, see the
"Programmable Keys" on page 36.
10 — Model 6753i Series IP Phone User Guide
Methods for Customizing Your Phone
There are two ways to customize specific options on your phone:
• Using the Options
Options
key on the IP Phone
• Using the 8x8 Web Phone UI in an Internet browser window from your PC.
Phone Options via the IP Phone UI
You can customize your phone by pressing the Options
accessing the IP Phone UI.
Options
key and
These options allow you to customize the following phone settings.
1
Call Forward
1. Cfwd Number
2. Cfwd Mode
3. No. Rings
2
Preferences
1. Tones
Ring Tone
Tone Set
2. Contrast Level
3. Live Dialpad
4. Set Audio
Audio Mode
Headset Mic Vol
5. Time and Date
Time Zone
Daylight Saving
Time Format
Date Format
Time Server
Time Server 1
Time Server 2
Time Server 3
Set Time
Set Date
6. Language
3
Phone Status
1. IP&MAC Addresses
2. LAN Port
3. PC Port
4. Firmware Info
4
User Password
5
Administrator Menu
(Password Protected)
6
Restart Phone
7
Phone Lock
Note: The Administrator Menu options are administrator level functions
only, and are not accessible by the user. These options should only
be set up and changed by your system administrator.
Model 6753i Series IP Phone User Guide — 11
Methods for Customizing Your Phone
Option
Option
Number
Methods for Customizing Your Phone
Simplified Options Menu
Your System Administrator may configure a simplified options menu for your
phone. The following table indicates the options that may appear on your phone
if the simplified options menu is applied.
Option
Option
Number
1
Call Forward
1. Cfwd Number
2. Cfwd Mode
3. No. Rings
2
Preferences
1. Tones
Ring Tone
Tone Set
2. Contrast Level
3. Live Dialpad
4. Set Audio
Audio Mode
Headset Mic Vol
3
Phone Status
1. IP&MAC Addresses
2. LAN Port
3. PC Port
4. Firmware Info
4
Phone Lock
Using the IP Phone UI (User Interface)
IP Phone UI
1. Press the Options key
Options
on the phone to enter the Options List.
2. Use
and
to scroll through the list of options, or press the number corresponding to the Option.
3. Press Enter, the 4 key, or press the digit number for the corresponding option
to select that option.
4. Change a selected option if applicable.
5. Press the Set or Done key to save the change.
6. Press the
button, the 3 key, or the
without saving changes.
Options
Goodbye
12 — Model 6753i Series IP Phone User Guide
button at any time to exit
Reference
For more information about customizing your phone using the available options
from the IP Phone UI, see the section "Customizing Your Phone" on page 18.
For more information about administrator options, contact your System
Administrator.
Phone Options via the 8x8 Phone Web UI
In addition to the IP Phone UI options, you can customize additional options on
the IP Phone using the 8x8 Web Phone UI. In order to access your phone using
the 8x8 Phone Web UI, you need to know your phone’s IP address. To find your
phone’s IP address, see "Finding Your Phone’s IP Address" on page 17.
8x8 IP Phone Web UI
1. Open your web browser, enter the phone’s IP address or host name into the
address field and press <Enter>.
The following logon screen displays.
Model 6753i Series IP Phone User Guide — 13
Methods for Customizing Your Phone
Using the 8x8 IP Phone Web UI
Methods for Customizing Your Phone
2. At the prompt, enter your username and password and click
Note: For a user, the default user name is “user” and the password field is
left blank.
The Network Status window displays for the IP phone you are accessing.
3. You can logout of the 8x8 IP Phone Web UI at any time by clicking Log Off.
14 — Model 6753i Series IP Phone User Guide
The following categories display in the side menu of the 8x8 Web Phone UI:
Status, Operation, Basic Settings.
Headings
Descriptions
Status
The Status section displays the network status and the MAC address of
the IP phone. It also displays hardware and firmware information about
the IP phone. The information in the Network Status window is read-only.
Operation
User Password - Allows you to change user password.
Phone Lock - Allows you to assign an emergency dial plan to the phone,
lock the phone to prevent any changes to the phone and to prevent use
of the phone, and reset the user password.
Note: Not all functions in the following list are support by 8x8
•
None
•
Sprecode
•
Line
•
Phone Lock
•
Speeddial
•
Pickup
•
Do Not Disturb (DND)
•
Transfer
•
Busy Lamp Field (BLF)
•
Directory
•
Flash
•
Callers List
•
Intercom
•
Conference
Expansion Module - Allows you to configure an additional 36 softkeys
with a 536M Expansion Module if it is attached to the phone. This option
displays on the side menu of the 8x8 Web Phone UI only if an Expansion
Module is attached.
Note: Not all functions in the table above apply to the Expansion
Modules.
Directory - Allows you to copy the Callers List and Directory List from
your IP phone to your PC.
Reset - Allows you to restart the IP phone when required.
Model 6753i Series IP Phone User Guide — 15
Methods for Customizing Your Phone
Programmable Keys - There are 6 function keys, 4 of which can be
configured to perform the functions identified in the following list.
Phone Status
Headings
Descriptions
Basic
Settings
Preferences - Allows you to enable/disable the following:
• Suppress DTMF Playback
• Display DTMF Digits
• Call Waiting
• Play Call Waiting Tone
• Stuttered Dial Tone
• XML Beep Support
• Status Scroll Delay
• Incoming Call Interrupts Dialing
• Goodbye Key Cancels Incoming Call
• UPnP Mapping Lines
• Message Waiting Indicator Line
This category also allows you to configure:
• Incoming Intercom Call Settings
• Ring Tones (global and per-line basis)
• Ring Tone Sets
• Time and Date Settings
• Language Settings.
Call Forward - Allows you to set a phone number destination for where
you want calls forwarded. Call forward can be configured using a
specific mode (off, all, busy, no answer, busy no answer) on a global or
per-line basis.
Phone Status
You can view the status of your phone using the IP Phone UI or the
8x8 Web Phone UI.
Phone Status via IP Phone UI
The Phone Status option on the IP phone displays the status of your phone to
the LCD display.
This option allows you to view your phone’s:
• Network status including your phone’s IP and MAC address
• Local Area Network (LAN) port
• PC port
• Firmware version
Use the following procedure to view the status of your phone using the IP
Phone UI.
16 — Model 6753i Series IP Phone User Guide
8x8 IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select Phone Status.
3. Select the option you want to view:
IP&MAC Address
LAN Port
PC Port
Firmware Info
The option you select displays to the LCD. Use the
through the LCD display.
and
keys to scroll the
Finding Your Phone’s IP Address
If you want to access your phone’s options using an Internet browser, you need
to enter the IP address for the phone in the browser to open the 8x8 Web Phone
UI. Use the following procedure to find your phone’s IP address.
8x8 IP Phone UI
1. Press the
Options
button on the phone to enter the Option List.
2. Select Phone Status and press the 4 key.
3 Phone Status
=Next
=Enter
3. Select "IP&MAC Addresses" and press the 4 key.
1 IP&MAC Addresses
The IP address of your 6753i IP phone displays in the IP Address field.
IP Address:
XX.XX.XX.XXX
=Next
=Exit
Model 6753i Series IP Phone User Guide — 17
Phone Status
=Enter
=Next
Customizing Your Phone
Phone Status via the 8x8 Web Phone UI
After accessing your phone via the 8x8 Web Phone UI, the first screen to display
is the phone’s Status Screen.
This screen is view only. It displays the Network Status of your phone which
includes the following:
• LAN Port
• PC Port
• MAC Address
• Hardware Information
• Firmware Information
Customizing Your Phone
The following paragraphs describe the options available from either the IP Phone
UI, the 8x8 Web Phone UI, or both, and provide procedures applicable to the
option.
Ring Tones and Tone Sets
You can configure ring tones and ring tone sets on the IP phone.
Ring Tones
There are several distinct ring tones a user can select from to set on the IP
phones. You can enable/disable these ring tones on a global or per-line basis.
The following table identifies the valid settings and default values for each type of
configuration method.
18 — Model 6753i Series IP Phone User Guide
Ring Tones Table
Configuration Method
Valid Values
Default Value
IP Phone UI
Global:
Tone 1
Tone 2
Tone 3
Tone 4
Global:
Tone 1
8x8 Web Phone UI
Global:
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Silent
Global:
Tone 1
Per-Line:
Global
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Silent
Per-Line:
Global
In addition to ring tones, you can configure ring tone sets on a global-basis on
the IP phone. Ring tone sets consist of tones customized for a specific country.
The ring tone sets configurable on the IP phones are:
• US (Default - also used in Canada)
• Mexico
• United Kingdom
• Italy
• Germany
• France
• Europe (generic tones)
• Australia
Model 6753i Series IP Phone User Guide — 19
Customizing Your Phone
Ring Tone Sets
Customizing Your Phone
When you configure the country's tone set, the country-specific tone is heard on
the phone for the following:
dial tone
secondary dial tone
ring tone
busy tone
congestion tone
call waiting tone
ring cadence pattern
Global ring tones and tone sets can be configured using the 8x8 Web Phone UI
and the IP Phone UI.
Configuring Ring Tones and Tone Sets
8x8 IP Phone UI
Use the following procedures to configure ring tones and tone sets on the IP
phone.
(global configuration only)
1. Press
Options
on the phone to enter the Options List.
2. Select Preferences.
3. Select Tones.
4. Select Ring Tone.
5. Select the type of ring tone (Tone 1 through Tone 5, or Silent).
6. Select Set and then press
.
7. Select Tone Set.
8. Select the country for which you want to apply the tone set. Valid values are
Australia, Europe, France, Germany, Italy, UK, Mexico, and US. Default is
US.
9. Press
.The ring tone and tone set you select is immediately applied to the
IP phone.
20 — Model 6753i Series IP Phone User Guide
8x8 IP Phone Web UI
1. Click on Basic Settings->Preferences->Ring Tones.
For global configuration:
3. Select a value from the Global Ring Tone field.
Note: See the Ring Tones Table on page 19 for valid values.
For per-line configuration:
4. In the Ring Tone section, select a line for which you want to set ring tone.
5. Select a value from the LineN field.
Note: See the Ring Tones Table on page 19 for valid values.
6. Click
to save your changes.
Contrast Level
The Contrast Level option on the IP phone allows you to set the amount of light
that illuminates the LCD display. Use this option to set the preference of contrast
level.
You can set the contrast level using the IP Phone UI only.
Model 6753i Series IP Phone User Guide — 21
Customizing Your Phone
2. In the Ring Tones section, select a country from the Tone Set field.
Valid values are Australia, Europe, France, Germany, Italy, UK, Mexico, and
US. Default is US.
Customizing Your Phone
Setting Contrast Level
8x8 IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select Preferences.
3. Select Contrast Level.
4. Use the
and
navigation buttons to increase or decrease the intensity
of contrast lighting on the LCD.
5. Press Set to save your selection.
Live Dialpad*
The Live Dialpad option on the IP phone turns the Live Dialpad mode ON or
OFF. With live dialpad ON, the 6753i IP phone automatically dials out and turns
ON Handsfree mode as soon as a dialpad key or softkey is pressed. With live
dialpad OFF, if you dial a number while the phone is on-hook, lifting the receiver
or pressing the
Speaker/
Headset
initiates a call to that number.
*Availability of feature dependent on your phone system or service provider.
You can enable/disable the live dialpad using the IP Phone UI only.
Enabling/Disabling Live Dialpad
8x8 IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select Preferences.
3. Select Live Dialpad.
4. Use the Change softkey to turn the live dialpad ON or OFF.
5. Press Done to save your selection.
Set Audio
The Set Audio option on the IP Phone allows you to set the audio mode for your
IP phone. It also allows you to set the volume level of the headset microphone.
You can set Audio on your IP phone using the IP Phone UI only.
22 — Model 6753i Series IP Phone User Guide
Audio Mode
The 6753i allows you to use a handset, a headset, or handsfree mode to handle
incoming and outgoing calls. The audio mode option provides different
combinations of these three methods to provide maximum flexibility in handling
calls. There are four audio mode options you can set:
Audio Mode
Option
Description
Speaker
This is the default setting. Calls can be made or received
using the handset or handsfree speakerphone. In handset
audio mode, pressing the
button on the phone
switches to handsfree speakerphone. In Speaker audio
mode, lift the handset to switch to the handset.
Speaker/
Headset
Headset
Choose this setting if you want to make or receive all calls
using a handset or headset. Calls can be switched from the
handset to headset by pressing the
button on the
phone. To switch from the headset to the handset, lift the
handset.
Speaker/
Headset
Speaker/Headset
Incoming calls are sent to the handsfree speakerphone first
when the
button is pressed. By pressing the button
again, you can switch back and forth between the handsfree
speakerphone and the headset. At anytime, lifting the
handset switches back to the handset from either the
handsfree speakerphone or the headset.
Speaker/
Headset
Incoming calls are sent to the headset first when the
button is pressed. By pressing the button again,
you can switch back and forth between the headset and the
handsfree speakerphone. At anytime, lifting the handset
switches back to the handset from either the headset or the
handsfree speakerphone.
Speaker/
Headset
Headset Mic Volume
The Headset Mic Volume option allows you to set the volume level for the
headset microphone.
Setting Audio Mode and Headset Mic Volume
8x8 IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select Preferences.
3. Select Set Audio.
4. Select Audio Mode.
Model 6753i Series IP Phone User Guide — 23
Customizing Your Phone
Headset/Speaker
Customizing Your Phone
5. Select the audio mode you want to use on your phone. Valid values are:
Speaker
Headset
Speaker/Headset
Headset/Speaker
6. Press Done to save your selection.
7. Select Headset Mic Volume.
8. Select the Low, Medium, or High volume level.
9. Press Done to save your selection.
Time and Date
On the IP phones, you can configure the following:
• Time and Date
• Time and Date Format
• Time Zone
• Daylight Saving Time
• Time Servers (Administrator use only;password protected)
Note: You can set the above features using the IP Phone UI. However, only
the Time and Date Formats can be set using the 8x8 Web Phone UI.
The "Time Server" configuration is for Administrator use only and is
password protected. Contact your System Administrator for more
information.
Configuring Time and Date
Use the following procedures to configure the time and date settings on the IP
phone.
8x8 IP Phone UI
Set Time and Time Format
1. Press
2.
3.
4.
5.
6.
7.
8.
9.
Options
on the phone to enter the Options List.
Select Preferences.
Select Time and Date.
Select Set Time.
Using the keys on the keypad, enter a time on the IP phone. Use the
and
navigation keys to move backward or forward when entering the
time. Use the "*" key to set either AM or PM.
Press Set to save the time setting.
Select Time Format.
Using the Change softkey, set the Time Format to either a 12 hour format or a
24 hour format. Valid values are 12h and 24h. Default is 12h.
Press Set to save the Time Format you selected.
24 — Model 6753i Series IP Phone User Guide
Set Date and Date Format
1. Select Preferences.
2. Select Time and Date.
3. Select Set Date.
4. Using the keys on the keypad, enter a date on the IP phone. Use the
navigation keys to move backward or forward when entering
and
the date.
5. Press Set to save the date setting.
6. Select Date Format.
7. Select a date format from the list of options. Default is Sun Jan 2. Valid values
are:
• Sun Jan 2 (Default)
• 2-Jan-00
• 2000 01 02
• 02/01/2000
• 02/01/00
• 02-01-00
• 01/.02/00
• Jan 2
• 2 Jan 2000
• Sun 2 Jan
• 02.01.2000
8. Press Set to save the Date Format setting.
Set Time Zone
1. Select Preferences.
2. Select Time and Date.
3. Select Time Zone.
4. Press * to display a list of Time Zone options. A list of Time Zones display
for different areas of the world.
5. Select a Time Zone that applies to your area. The default Time Zone
is US-Eastern.
Note: For a list of the Time Zones values available on the IP Phone, see
“Appendix A - Time Zone Codes.”.
6. Press Set to save the Time Zone setting.
Set Daylight Saving Time
1. Select Preferences.
2. Select Time and Date.
Model 6753i Series IP Phone User Guide — 25
Customizing Your Phone
• 2 Jan
Customizing Your Phone
3. Select Daylight Saving.
4. Select a Daylight Savings time from the list of options. Valid values are:
• OFF
• 30 min Summertime
• 1 h Summertime
• Automatic
Note: The default for Daylight Saving is Automatic.
5. Press Set to save the Daylight Saving setting.
8x8 Web Phone UI
1. Click on Basic Settings->Preferences->Time and Date Setting.
2. In the Time Format field, select the time format you want to use on your
phone. Valid values are:
12h (12 hour format) (default)
24h (24 hour format)
Note: The time and time format you configure display on the phone’s idle
screen.
3. In the Date Format field, select the date format you want to use on your
phone. Default is WWW MMM DD. Valid values are:
• WWW MMM DD (default)
• DD-MMM-YY
• YYYY-MM-DD
• DD/MM/YYYY
• DD/MM/YY
• DD-MM-YY
26 — Model 6753i Series IP Phone User Guide
• MM/DD/YY
• MMM DD
• DD MMM YYYY
• WWW DD MMM
• DD MMM
• DD.MM.YYYY
Note: The date and date format you configure display on the phone’s idle
screen.
4. Click
to save your changes.
Language
The IP phones support several different languages. You can have the IP Phone
UI and the Aastra Web UI display in a specific language as required. When you
set the language to use, all of the display screens (menus, services, options,
configuration parameters, etc.) display in that language. The IP phones support
the following languages:
• English (default)
• French
• Spanish
• German
• Italian
Once the language pack(s) are available on your phone from your System
Administrator, you can specify which language to use on the phone and/or the
8x8 Web Phone UI.
Note: All languages may not be available for selection. The available
languages are dependent on the language packs currently loaded to
the IP phone.
8x8 IP Phone UI
Use the following procedure to specify which language to use for the IP Phone
UI.
1. Press
Options
on the phone to enter the Options List.
2. Select Language and press Enter. The language setting displays a check
mark indicating this is the current language on the IP Phone.
3. Using the
and
keys, scroll through the languages. Valid values are:
English (English), Français (French), Español (Spanish), Deutsch (German), or
Italiano (Italian). Default is English.
Model 6753i Series IP Phone User Guide — 27
Customizing Your Phone
Specifying the Language to Use
Customizing Your Phone
4. Press Set to set the language on the phone. The change is dynamic.
When you exit the Options Menu, the phone displays all menu items in the
language you selected.
8x8 Web Phone UI
Note: You must have the language pack(s) already loaded to your phone in
order to use them. For more information about loading language
packs, see your System Administrator.
1. Click on Basic Settings->Preferences->Language Settings.
2. In the Webpage Language field, select a language to apply to the 8x8 Web
Phone UI. The IP phone supports the following languages:
English (default)
French
Spanish
German
Italian
Note: All languages may not be available for selection. The available
languages are dependent on the language packs currently loaded to
the IP phone by your System Administrator. English is the default
language and cannot be changed or removed.
3. Click
to save your settings. The change is global. The 8x8 Web
Phone UI displays all screens in the language you selected.
28 — Model 6753i Series IP Phone User Guide
User Password
This category allows you to change the user password for your phone. Changing
your password ensures that only you can alter your phone settings, and helps
keep your system secure. You can change your user password using the IP
Phone UI or the 8x8 Web Phone UI.
If you change the password
Then you need to:
Using the IP Phone UI,
Use that new password to log into the
8x8 Web Phone UI.
Using the 8x8 Web Phone UI,
Use that new password when changing
the user password via the IP Phone UI.
Note: Valid values when creating or changing a password are 0 to
4294967295 (integers only; symbols and alpha characters are not
allowed). Default password is an empty string "" (field is blank).
Setting a User Password
8x8 IP Phone UI
Options
on the phone to enter the Options List.
2. Select User Password and press Enter.
3. At the Current Password prompt, enter the current user password and press
Enter.
4. At the New Password prompt, enter the new user password and press Enter.
5. At the Enter Again prompt, re-enter the new user password and press Enter.
A message, Password Changed displays on the screen.
8x8 Web Phone UI
1. Click on Operation->User Password.
Model 6753i Series IP Phone User Guide — 29
Customizing Your Phone
1. Press
Customizing Your Phone
2. In the Current Password field, enter the current user password.
Note: By default, the user name is “user” (all lowercase) and the password
field is left blank.
3. In the New Password field, enter the new user password.
4. In the Password Confirm field, enter the new user password again.
5. Click
to save your changes.
Resetting a User Password
If you forget your password, you can reset it and enter a new password. The
reset user password feature resets the password to the factory default which is
blank (no password).
You can reset a user password using the 8x8 Web Phone UI only.
Note: Valid values when creating or changing a password are 0 to
4294967295 (integers only; symbols and alpha characters are not
allowed). Default password is an empty string "" (field is blank).
Reset a User Password
Use the following procedure to reset a user password.
8x8 Web Phone UI
1. Click on Operation->Phone Lock.
30 — Model 6753i Series IP Phone User Guide
2. In the Reset User Password field, click
screen displays.
. The following
3. Leave the Current Password blank.
4. Enter a new password in the New Password field.
5. Re-enter your new password in the Password Confirm.
6. Click
to save your settings.
Restarting your phone
You may want to restart your phone to check for updates for your phone on the
server. You may occasionally need to restart your phone to set changes or
updates to your phone or network settings. You may also need to restart your
phone if you have been asked to do so by your System Administrator, or should
you experience any unexpected behavior.
1. Press the
Options
button on the phone to enter the Options List.
2. Select Restart Phone.
3. Press # to confirm the restart of the phone. If you do not wish to restart your
phone, press the 3 key to cancel.
Note: Your phone is out of service temporarily during the restart and downloading process.
Model 6753i Series IP Phone User Guide — 31
Customizing Your Phone
8x8 IP Phone UI
Customizing Your Phone
8x8 Web Phone UI
1. Click on Operation->Reset.
2. Click
.
3. Click OK at the confirmation prompt.
Phone Lock
You can lock your phone to prevent the phone from being used or configured.
You can lock the phone using any of the following:
• At the path Options->Phone Lock on the IP Phone UI.
• At the path Operations->Phone Lock on the 8x8 Web Phone UI.
• At a configured key on the phone. For more information about configuring a
Lock/Unlock key on your phone, see "Phone Lock Key" on page 50.
In the 8x8 Web Phone UI, the Operation->Phone Lock path also allows you to
perform the following:
• Reset a user password. Clicking the Reset button in the Reset User
Password field displays a screen that allows you to enter and save a new
user password.
• Set an emergency dial plan. An emergency dial plan is 911.
The following procedures describe locking the phone, setting an emergency dial
plan, and resetting the user password.
32 — Model 6753i Series IP Phone User Guide
Locking/Unlocking a Phone
Use the following procedures to lock an IP phone and prevent it from being used
or configured.
8x8 IP Phone UI
Lock the Phone
1. Press Options on the phone to enter the Options List.
2. Select Phone Lock and press Enter.
3. At the Lock the phone? prompt, press Lock. The message Phone is
locked displays.
Unlock the Phone
1. Press Options on the phone to enter the Options List.
2. At the prompt, Password:, enter your user password and press Enter.
The phone unlocks.
8x8 Web Phone UI
Lock the Phone
2. In the Lock the Phone? field, click
.
The phone locks dynamically and displays the following message:
Phone is locked.
Unlock the Phone
3. Click on Operation->Phone Lock.
4. In the Unlock the Phone? field, click
.
The phone unlocks dynamically and displays the following message:
Phone is unlocked.
Model 6753i Series IP Phone User Guide — 33
Customizing Your Phone
1. Click on Operation->Phone Lock.
Customizing Your Phone
Defining an Emergency Dial Plan
Public telephone networks in countries around the world have a single
emergency telephone number (emergency services number), that allows a caller
to contact local emergency services for assistance when required. The
emergency telephone number may differ from country to country. It is typically a
three-digit number so that it can be easily remembered and dialed quickly. Some
countries have a different emergency number for each of the different emergency
services.
You can specify the digits to dial on the IP phone for contacting emergency
services. Once you specify the emergency number(s) on the phone, you can dial
those numbers directly on the dialpad when required and the phone
automatically dials to those emergency services.
The following table describes the default emergency numbers on the IP phones.
Emergency Number
Description
9911
A United States emergency number
You can set the emergency dial plan using the 8x8 Web Phone UI.
Define an Emergency Dial Plan
Use the following procedure to specify the numbers to use on your phone for
dialing emergency services in your area.
8x8 Web Phone UI
1. Click on Operation->Phone Lock.
2. In the "Emergency Dial Plan" field, enter the 3-digit number used in your
local area to contact emergency services. For example:
9911|
Default for this field is 9911.
3. Click
to save the emergency dial plan to your phone.
34 — Model 6753i Series IP Phone User Guide
Reference
For settings more advanced options, see "Additional Features" on page 90.
Line Keys and Programmable Keys
This section describes the Multiple Line/Call Appearance Keys (L1, L2, and L3)
and the customizable programmable keys located at the top left on the phone.
Programmable Keys
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Multiple Line/
Call Appearance
Keys
Mute
Multiple Line and Call Appearance Keys
The 6753i has 3 hard line/call appearance keys each with a corresponding
status light.
These line/call appearance buttons and lights can represent physical lines, calls
for your extension or calls from a group that your extension is part of. By pressing
a line/call appearance button, you connect to the line or a call it represents. The
line/call appearance light indicates the status of that line or call. When the phone
is taken off-hook, the phone automatically selects a line for you.
Line/Call
Appearance Light Behavior
Line/Call
Appearance Status
Off
Idle line or no call activity
Light flashes quickly
Ringing
Light is solid
Connected
Light flashes slowly
Hold
When you have more than one call, you can use the left and right navigation
to scroll left and right to the different call information screen.
buttons
and
Icons
and
appear if there is call information either left, right or on both
sides of the current information you are viewing.
Model 6753i Series IP Phone User Guide — 35
Line Keys and Programmable Keys
Goodbye
Line Keys and Programmable Keys
The display shows which line the call information is referring to (L1, L2, or L3),
the Caller ID information (name and number, if available), the call status
(Connected, Ring, Hold, etc.) and the timer specific to that call.
To configure shared line appearance, please log in to your account at
www.8x8.com.
Programmable Keys
There are six function keys on the 6753i phone, 4 of which are programmable,
located to the left of the paper label.
Save Key
Delete Key
Callers Dir
Do Not Disturb
Transfer
Conf (Conference)
Programmable Keys
Note: If a 536EM Expansion Module is attached to the phone, you can
configure 36 additional keys on each Expansion Module (Phone
allows up to 3 expansion modules totaling up to 108 additional softkeys). For more information about expansion modules, see "Model
536EM Expansion Module" on page 107.
You can use the 8x8 Web Phone UI only, to configure key functions. The
following table lists the functions you can set on the programmable keys and
provides a description for each function. Function changes made directly from
your IP Phone will override the settings stored within online account
management page in the 8x8 Self Service Portal.
Key Function
Description
None
Indicates no setting for the key.
Line
Indicates the key is configured for line use.
Speeddial
Indicates the key is configured for speeddial use. You can
also configure a prefix for a speeddial number.
Do Not Disturb
Indicates the key is configured for "Do Not Disturb" on the
phone.
Busy Lamp Field
(BLF)
Indicates the key is configured for Busy Lamp Field (BLF)
use. User can dial out on a BLF configured key.
(Maximum of 50 BLFs allowed on 536M Expansion
Module.)
36 — Model 6753i Series IP Phone User Guide
Key Function
Description
Indicates the key is configured to accept an XML
application for accessing customized XML services. You
can also specify an XML key URL for this option.
Flash
Indicates the key is set to generate a flash event when it is
pressed on the 6753i. The IP phone generates flash events
only when a call is connected and there is an active RTP
stream (for example, when the call is not on hold).
Callers List
(Key 3 by Default)
Indicates the key is configured to access the Directory List.
DND (Do Not Disturb)
(Key 4 by Default)
Indicates the key is configured to access the Callers List.
Transfer
(Key 5 by Default)
Indicates the key is configured as a Transfer key (Xfer) for
transferring calls.
Conference
(Key 6 by Default)
Indicates the key is configured as a Conference key (Conf).
Intercom
Indicates the key is configured to be used for intercom calls.
Phone Lock
Indicates the key is configured as a phone lock key, allowing
you to press this key to lock/unlock the phone.
Programmable keys can also be set up to quickly access features such as Do
Not Disturb (DND) or Voicemail.
Line Key
You can set a programmable key to act as a line/call appearance key on the
6753i. The programmable key acts as a line that behaves the same as a hard line
key (L1, L2, and L3). For more information about the behavior of line keys, see
"Multiple Line and Call Appearance Keys" on page 35.
You use the 8x8 Web Phone UI to set a programmable key as a line.
Configuring a Line Key
8x8 Web Phone UI
Use the following procedure to set a programmable key to function as a line.
1. Click on Operation->Programmable Keys.
or
Model 6753i Series IP Phone User Guide — 37
Line Keys and Programmable Keys
XML
Line Keys and Programmable Keys
Click on Operation->Expansion Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the Hard Key field, select Line to apply to the programmable key.
4. In the Line field, select a line for which to apply this programmable hard key.
Valid values are 4 through 9.
5. Click
to save your changes.
Speeddial Key
The normal function of the speeddial option allows you to dial a number quickly
by pressing a programmable key configured for speeddialing. You can program
the keys on the 6753i to speeddial outside numbers, dial directly to another
person’s line or extension, or set up to quickly access features such as Do Not
Disturb (DND) and Voicemail.
The speeddial function can be set using the IP Phone UI or the 8x8 Web Phone
UI.
Note: You can use a speeddial key while on an active call by placing the
active call on hold first, and then pressing the speeddial key.
Speeddial Prefix
The speeddial feature also allows you to specify a preset string of numbers
followed by a “+” that the phone dials automatically after pressing the speeddial
key. You can use this feature for numbers that contain long prefixes.
For example, if you had the following speeddial configuration in the 8x8 Web
Phone UI:
Key 1
Type=speeddial
Label=Europe Office
Value=1234567+
Line=2
38 — Model 6753i Series IP Phone User Guide
then, after you press key 1 on the phone, the prefix number displays on the
phone screen. The phone proceeds to dial the prefix number automatically and
pauses for you to enter the remaining phone number using the keypad on the
phone.
You can save up to 7 speeddial numbers on the 6753i.
Use the following procedures to set speeddial on the 6753i IP phone.
Creating a Speeddial Key Using the Programmable Keys
IP Phone UI
Pressing and holding down a programmable key on the phone initiates a
speeddial feature.
1. Press a programmable key or a number key on the keypad for 3 seconds.
A screen displays with the prompt, Enter number>.
2. Enter a phone number or extension to assign to that speeddial key.
The following example illustrates the screen display:
Speeddial
Enter number> 3456
After entering the number, the prompt, Use Save to end displays on the
screen.
3456
Use Save to end
3. Press Save to save the number as a speeddial key. By default, the phone
automatically assigns the speeddial key to line 1 if available. To select a different line, press the Change softkey and select a different line, or use the
phone’s keypad to select a number (1-9), or use the
and
to make your
selection.
Line: 1
Change
Use Save to end
Model 6753i Series IP Phone User Guide — 39
Line Keys and Programmable Keys
Note: When creating a speeddial key from the IP Phone UI, you must
select a programmable key that has no preassigned function (key
must be set to None).
Line Keys and Programmable Keys
4. Press Save to save the speeddial key to the line specified.
Note: Use the 8x8 Web Phone UI to edit or delete this speeddial key.
Creating a Speeddial Key Using the Save Key
IP Phone UI
Use the following procedure to create a speeddial key using the Save key. Use
the following illustration for reference.
Save Key
Programmable
Keys
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Save key. The screen displays Save to?
Save to?
2. Select a Programmable key you want to save to.
3. At the Enter Number prompt, use the dialpad key to enter the number.
Enter Number >
5553491234
4. Press the Save key to save the speeddial configuration.
5. At the Enter Name prompt, use the dialpad keys to select the letters. Continue to press the number key to access the next letter for that key (i.e. press 2
40 — Model 6753i Series IP Phone User Guide
three times to access C). Press 4 to move to the next space, or wait a moment
and the cursor automatically advances. To insert a space between letters,
press 4. To backspace and erase a mistake, press 3 or the Delete key. You
can save up to 16 letters and numbers on each programmable key entry.
Enter Name >
John Smith
6. Press the Save key to finish.
Saved Memory key
5553491234
8x8 Web Phone UI
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
2. Select from Key 3 through Key 6.
3. In the Hard Key field, select Speeddial to apply to the programmable key.
4. In the Value field, enter the phone number, extension, or speeddial prefix to
apply to this hard key. If you enter a speeddial prefix, you must enter the "+"
character at the end of the prefix number (for example, "123456+").
5. In the Line field, select a line for which to apply the speeddial to. Valid values
are 1 through 9.
6. Click
to save your changes.
Model 6753i Series IP Phone User Guide — 41
Line Keys and Programmable Keys
Creating a Speeddial Key Using the 8x8 Web Phone UI
Line Keys and Programmable Keys
Saving an Entry from the Redial, Callers, or Directory Lists to a
Speeddial Key
IP Phone UI
Use the following procedure to save an entry from your Directory List, Callers
List, or Redial List on the IP phone.
Save Key
*Callers List Key
Goodbye
Options
Redial List Key
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Callers List, or Redial List key. From the Callers List, or Redial List,
scroll through the list to find the name and number that you wish to save to
your speeddial.
2. Press the Save key.
3. Press the selected speeddial. If the name is displayed with the number, both
are saved to the speeddial. If no name is displayed, you can enter the name
using the phone’s keypad.
*Directory List is not a programmable key by default.
Do Not Disturb (DND) Key
The IP phones have a feature you can enable called "Do Not Disturb (DND). The
DND function allows you to turn "Do Not Disturb" ON and OFF.
Note: Key 3 is set as DND key by default.
If DND is ON, callers hear a busy signal or a message, depending on how your
System Administrator set up the configuration server. The second line on the
screen shows when DND is set.
If the phone shares a line with other phones, only the phone that has DND
configured is affected.
You can set DND on the programmable keys using the 8x8 Web Phone UI or by
logging into your 8x8 Self Service Portal. DND is not configurable from the IP
phone UI.
42 — Model 6753i Series IP Phone User Guide
Configuring a Do Not Disturb (DND) Key
8x8 Web Phone UI
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
3. In the "Hard Key" field, select do not disturb to apply to the programmable
key.
4. Click
to save your changes.
Flash Key
You can set a programmable key to generate a flash event when it is pressed on
the 6753i. You do this by setting the programmable key to "flash". The IP phone
generates flash events only when a call is connected and there is an active RTP
stream (for example, when the call is not on hold).
Configuring a Flash Key
8x8 Web Phone UI
1. Click on Operation->Programmable Keys.
2. Select a "Key 3" through "Key 6".
Model 6753i Series IP Phone User Guide — 43
Line Keys and Programmable Keys
2. Select a "Key 3" through "Key 6".
Line Keys and Programmable Keys
3. In the "Hard Key" field, select flash.
4. Click
to save your changes.
Phonebook Key
By default, the 6753i has no soft key configured for phone book key. However,
using the 8x8 Web Phone UI, you can assign the Directory key to another
available key if required (Key 3 through Key 6).
Phonebook
Key
Goodbye
Options
Hold
Redial
Line 3
Line 2
Line 1
Speaker/
Heading
Mute
The Phonebook List feature allows you to store frequently used names and
numbers on the phone. You can also dial directly from a directory entry.
You can use the Phonebook key to access a Directory List which contains a
customized list of names with phone numbers and labels.
In addition to creating a Phonebook key, you can also download a Directory List
to your PC if required using the 8x8 Web Phone UI.
Reference
For more information about the Directory List, see "Directory List" on page 65.
Configuring a Directory Key
8x8 Web Phone UI
Use the following procedure to configure a Directory key on the 6753i phone.
44 — Model 6753i Series IP Phone User Guide
1. Click on Operation->Programmable Key.
or
Click on Operation->Extension Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the Type field, select Directory.
4. Click
to save your changes.
By default, the 6753i has a Callers List key configured on Key 3. However, using
the 8x8 Web Phone UI, you can assign the Callers List key to another available
key if required (Key 3 through Key 6).
Callers List
Key 1
Goodbye
Options
Hold
Redial
Line 3
Line 2
Line 1
Speaker/
Heading
Mute
The Callers List is a stored log of your incoming calls. You can use the Callers
List key to access a list of callers that called your phone.
Reference
For more information about the Callers List, see "Callers List" on page 74.
Model 6753i Series IP Phone User Guide — 45
Line Keys and Programmable Keys
Callers List Key
Line Keys and Programmable Keys
Configuring a Callers List Key
8x8 Web Phone UI
Use the following procedure to configure a Callers List key on the 6753i phone.
Note: Key 3 is set as Call Forwarding key by default.
1. Click on Operation->Programmable Keys.
or
Click on Operation->Extension Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the Type field, select Callers List.
4. Click
to save your changes.
Transfer Key
By default, the 6753i has a Transfer key configured on Key 5. However, using the
8x8 Web Phone UI, you can assign the Transfer key to another available key if
required (Key 3 through Key 6).
Transfer
Key
Goodbye
Options
Hold
Redial
Line 3
Line 2
Line 1
Speaker/
Heading
Mute
The Transfer key allows you to perform blind or consultative call transfers to other
recipients. The blind transfer feature transfers a call to another number without
you having to talk to the recipient. A consultative transfer feature transfers a call
to another number but allows you to speak with the recipient before the call is
actually transferred.
46 — Model 6753i Series IP Phone User Guide
Reference
For more information about using blind and consultative call transfers, see
"Transferring Calls" on page 60.
Configuring a Transfer Key
8x8 Web Phone UI
Use the following procedure to configure a Transfer key on the 6753i phone.
Note: Key 5 is set as Transfer key by default.
2. Select from "Key 3" through "Key 6".
3. In the Type field, select Transfer.
4. Click
to save your changes.
Conference Key
By default, the 6753i has a Conference key configured on Key 6. However, using
the 8x8 Web Phone UI, you can assign the Conference key to another available
key if required (Key 3 through Key 6).
Conference
Key
Goodbye
Options
Hold
Redial
Line 3
Line 2
Line 1
Speaker/
Heading
Mute
The Conference key allows you to link three active calls into a single conference
(Local Conferencing). This key also helps to create multiple conferences with
unlimited participants on your phone if your System Administrator has enabled
Centralized Conferencing on your phone.
Model 6753i Series IP Phone User Guide — 47
Line Keys and Programmable Keys
1. Click on Operation->Programmable Keys.
or
Click on Operation->Extension Module <N>.
Line Keys and Programmable Keys
Reference
For more information about Local and Centralized Conferencing, see
"Conferencing Calls" on page 61.
Configuring a Conference Key
8x8 Web Phone UI
Use the following procedure to configure a Conference key on the 6753i phone.
Note: Key 6 is set as a Conference key by default.
1. Click on Operation->Programmable Keys.
or
Click on Operation->Extension Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the "Type" field, select Conference.
4. Click
to save your changes.
Intercom Key
By default, the IP phone allows incoming intercom calls to be automatically
answered without having to set up an Intercom key on your phone. For more
information about changing the behavior of incoming Intercom calls, see the
section "Incoming Intercom Call Features" on page 102.
Your System Administrator can enable outgoing intercom calls on your
phone. If enabled, you must configure an Intercom key on your phone to use for
outgoing intercom calls.You must configure a programmable key with the
function, Intercom.
Use the following procedure to configure a programmable key as an Intercom
key using the 8x8 Web Phone UI.
48 — Model 6753i Series IP Phone User Guide
Configuring an Intercom Key
8x8 Web Phone UI
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
3. In the Type field, select Intercom from the list of options.
4. Click
to save your changes.
Using the Icom Key (for Outgoing Intercom Calls)
IP Phone UI
1. Press the Intercom key.
2. Enter the extension number of the person you want to intercom for
that extension.
3. After a beep tone, your phone automatically connects with the remote extension and you can speak through its speaker.
4. To cancel intercom, press
Goodbye
or hang up the handset.
5. When you are finished speaking, hang up the phone by placing the handset
back on-hook or by pressing Goodbye or the line/call appearance button for the
active call. When you hang up, the remote phone also hangs up.
Reference
For more information about incoming intercom calls, see "Incoming Intercom Call
Features" on page 102.
Model 6753i Series IP Phone User Guide — 49
Line Keys and Programmable Keys
2. Select from "Key 3" through "Key 6".
Line Keys and Programmable Keys
None Key
You can set a key to force a blank entry on the IP phone display for a specific key.
You do this by setting the key to "none". If a particular key is not defined, it is
ignored.
Setting a None Key
8x8 Web Phone UI
Use the following procedure to configure a None key on the 6753i IP Phone.
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the Type field, select None.
4. Click
to save your changes.
Phone Lock Key
You can configure a programmable key on the phone to use as a lock/unlock key.
You assign the function of the key as “Phone Lock”.
Use the following procedure to configure a programmable key as a lock/unlock
key in the 8x8 Web Phone UI.
Configuring a Phone Lock Key
8x8 Web Phone UI
50 — Model 6753i Series IP Phone User Guide
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
2. Select from "Key 3" through "Key 6".
4. Click
to save your changes.
Note: You can lock/unlock the phone using the new key you just configured, using the 8x8 Web Phone UI at the path Operation->PhoneLock, or using the "Phone Lock" option on the IP Phone UI at the
path Options->Phone Lock. For more information about using the
lock/unlock feature, see "Phone Lock" on page 32.
Using the Lock/Unlock Key on the IP Phone
After configuring a programmable key as a lock/unlock key, refer to the following
procedure to use the key on the IP phone.
IP Phone UI
Lock the Phone
1. Press the Lock programmable key. The phone locks. The LED for the
programmable key AND the Message Waiting Lamp illuminate steady ON.
An Unlock label appears next to the programmable key you just pressed.
Unlock the Phone
1. Press the Unlock programmable key. A password prompt displays.
2. Enter your user password and press ENTER. The phone unlocks. The LED for
the programmable key AND the Message Waiting Lamp go OFF. The “Lock”
label appears next to the programmable key you just pressed.
Model 6753i Series IP Phone User Guide — 51
Line Keys and Programmable Keys
3. In the Type field, select Phone Lock from the list of options.
Making Calls
Deleting a Key
8x8 Web Phone UI
Use the following procedure to delete a programmable key function using the
8x8 Web Phone UI.
1. Click on Operation->Programmable Keys.
or
Click on Operation->Expansion Module <N>.
2. Select from "Key 3" through "Key 6".
3. In the "Type" field, select none from the list of options.
4. Click
to save your changes.
The programmable function is deleted from the IP phone memory.
Making Calls
This section describes ways to make calls on your 6753i phone, using your
handset, speakerphone or headset.
Dialing a Number
First, take the phone off-hook by:
• lifting the handset
• pressing
Speaker/
Headset
or
• pressing a line/call appearance button.
At the dial tone, enter the number you wish to call.
Note: After dialing the number, the phone has a short delay before sending
the call. To send the call immediately, you can press the "#" key
immediately after dialing the number. The phone sends the call without delay.
52 — Model 6753i Series IP Phone User Guide
If you are unable to make calls within certain area codes, check with your System
Administrator for any toll restrictions placed on your extension that may restrict
your access to long distance area codes or dialing prefixes.
=Dial
When your party picks up, a timer appears on your display that records the
length of your call.
If the Live DialPad option is on, as soon as you press the first digit on the dialpad
the phone automatically selects the next available line, go off-hook and dial as
digits are pressed.
To Call an Outside Number
Speaker/
Headset
Pick up the phone or press
. Dial 9 and then the number (7-digit if in same
area code, or 9+1+area code+number).
Note: You will not hear a dial tone after pressing "9" when making an
outside call.
To Call Another Extension
Pick up the phone or press
Speaker/
Headset
. Dial the extension number.
Making a Call
Speaker/
Headset
1. Pick up the Handset, or press the
button and listen for a dial tone.
2. Using the keypad, dial the desired telephone number. The number you are
dialing will appear on the display as you dial. When making a call or talking on
the phone, the “In Use” light will light up indicating the phone is in use. This
light will also be lit whenever another phone on the same phone line is in use.
Receiving a Call
cradle. You may also press the
the speakerphone. Press the
[Answer] softkey.
Speaker/
Headset
Speaker/
Headset
button to answer the call to enable
button to answer using headset, or
When you are finished talking, replace the handset in the handset cradle to end
the call. If you have been talking using the speakerphone, press the
button to hang up. You may press the
Goodbye
Speaker/
Headset
button to hang up at any time.
Model 6753i Series IP Phone User Guide — 53
Making Calls
1. When you hear the phone ring, simply pick up the handset from the handset
Making Calls
Using Handsfree Speakerphone
The handsfree feature allows you to speak to someone without using the handset
or headset. Your phone must be in either the Speaker or Speaker/Headset audio
mode. For more information about setting the audio mode on your phone, see
"Set Audio" on page 22.
IP Phone UI
• To dial using handsfree, first press
Speaker/
Headset
and enter a number at
the dial tone.
• To answer a call on your phone using handsfree, press
Speaker/
Headset
or the line/
call appearance button.
• If you are in Speaker audio mode, lift the handset and press
Speaker/
Headset
to
switch between handsfree and handset.
• If you are in Speaker/headset audio mode, press
Speaker/
Headset
to switch between
handsfree and headset.
• When the handset is on hook, press
Goodbye
to disconnect the call.
When handsfree is on, the speaker light turns on.
Using a Headset
The 6753i accepts headsets through the modular RJ9 jack on the back of the
phone. Contact your telephone equipment retailer or distributor to purchase a
compatible headset, or go to www.8x8.com.
Note: Customers should read and observe all safety recommendations
contained in headset operating guides when using any headset.
Advanced Volume Controls for the Headset Mic
On the 6753i, there are 3 options for the headset microphone volume. For more
information about the headset microphone, see "Headset Mic Volume" on
page 23.
IP Phone UI
To change the volume:
1. Press
Options
to enter the Options list.
2. Select Preferences.
3. Use
to scroll down to Set Audio and press
54 — Model 6753i Series IP Phone User Guide
to select.
4. Press
to scroll down to Headset/Mic Volume and press
5. Use
to scroll down the list and press
6. Press
to save changes and
to select.
to select your desired volume.
to exit.
7. If you do not wish to save changes, press
to return to the previous screen.
Note: By default, the volume for the headset microphone is set to medium.
Making and Receiving Calls Using a Headset
IP Phone UI
1. Ensure that you have selected a headset audio mode by accessing the
Options list (under option Preferences->Set Audio->Audio Mode on the
IP Phone).
2. Plug the headset into the jack.
3. Press the
key to obtain a dial tone or to answer an incoming call.
Speaker/
Headset
Depending on the audio mode selected from the options menu, a dial
tone or an incoming call is received on either the headset or the handsfree
speakerphone.
4. Press the
Goodbye
key to end the call.
Redial
IP Phone UI
• Press
Redial
to dial the most recent number you dialed from the phone.
• If you are off-hook and press
Redial
, the last number you called is called
Redial
, a Redial Directory list appears
back.
on-screen.
The redial list is available during active calls. It stores up to the last 100 numbers
you called, allowing you to scroll through and select the number you wish to
redial.
Note: Your System Administrator can set your Redial key to speeddial
a specific number. Contact your System Administrator for more
information.
Model 6753i Series IP Phone User Guide — 55
Making Calls
• If you are on-hook and press
Making Calls
Accessing the Redial List
IP Phone UI
1. If you are off-hook and press
Redial
, the telephone automatically dials the
last number you called.
2. If you are not on the phone, press
number and use
other numbers.
and
Redial
to display the most recently dialed
to scroll through the list to view the
3. Press
to see the second most recently dialed number, or
oldest call on your list.
4. To dial the displayed number press
Speaker/
Headset
to see the
, or lift the Handset or press any
line key.
5. Press
or the
Goodbye
Redial
key to cancel.
Note: The redial list is available during active calls. It also stores up to the
last 100 numbers you called, allowing you to scroll through and
select the number you wish to redial.
Deleting from the Redial List
Note: You cannot delete individual entries in the Redial List.
IP Phone UI
Delete All Items
1. Press
Redial
.
2. Press the Delete Key, then press the Delete Key again at the prompt to erase
all items.
DELETE again to
erase all items
Redial List is
empty
56 — Model 6753i Series IP Phone User Guide
Mute
You can use the Mute
Mute
key to mute the handset, headset, or
speakerphone. When you use the Mute key on your phone, you cannot be heard
on an active call or on a conference.
When a call is muted, the icon displays as follows.
1
John Burns
9054550055
03:00
For muted calls, the handsfree LED flashes and the Mute key LED is ON.
IP Phone UI
Press the
Mute
button at any time to mute handset, headset, or handsfree.
The speaker light flashes slowly and you can hear the caller, but they cannot hear
you. To switch mute on or off, press
Mute
.
Note: If you place a muted call on hold, the phone automatically takes the
call off mute when you reconnect to the call.
Receiving Calls
When a call is ringing at your extension, you see the "Inbound Call" Screen. The
line/call appearance light flashes quickly for the incoming call.
555-1234
Model 6753i Series IP Phone User Guide — 57
Receiving Calls
Laflamme & Assoc
Handling Calls
Answering an Incoming Call
IP Phone UI
To answer the call
• For handsfree operation, press
Speaker/
Headset
or the line/call appearance button for
the incoming call.
• Press
Speaker/
Headset
for handsfree or headset operation.
Note: The audio mode setting you have selected in the options list under
Set Audio->Audio Mode determines if the call goes to handsfree or
headset operation. For more information, see "Set Audio" on
page 22.
• Lift the handset for handset operation.
If the phone is already connected to a call, pressing the line/call appearance
button for the new incoming call automatically places the connected call on hold
and answers the new call. To reconnect to a party, press the line/call
appearance button for that call.
If you cannot answer the call, the caller automatically goes to voicemail.
Note: The Goodbye button can be used to cancel the call pickup
procedure.
Handling Calls
When you are connected to a call, you can use the hard keys or programmable
keys on the phone to place a call on hold, transfer a call, or conference.
Placing a Call on Hold
You can place an active call on hold by pressing the Hold
place a call on hold, only your phone can retrieve the call.
Hold
key. When you
When a call is on hold, the icon displays on-hook as follows.
1
Call held
03:05
For on-hold calls, the timer display begins and the Line and main LEDs flash.
58 — Model 6753i Series IP Phone User Guide
IP Phone UI
To place a call on hold
1. Connect to the call (if not already connected).
2. Press the Hold
key.
Hold
1
Call held
00:55
The line/call appearance light begins to flash slowly and after a short time the
phone beeps softly to remind you that you still have a call on hold. The screen
displays "Call Held" with the line number the call is held at the phone.
Note: If you are connected to another call, the phone does not beep to
remind you that you still have a call on hold.
When on Hold
To let your caller know that they are still on hold, music plays softly (if this has
been set up for your system). The call/line appearance light for the line you are
on remains solid to indicate that you are still connected.
John 1051
01:17
Automatic Hold
appearance button where that call is being held. Press
call.
Goodbye
to disconnect the
Retrieving a Held Call
If you have more than 1 call on hold, you can scroll through the held call
information by pressing 3 and 4 navigation keys. To reconnect to a call press the
line/call appearance button where that call is being held. If you press the call/line
appearance button again, you disconnect from the call.
Model 6753i Series IP Phone User Guide — 59
Handling Calls
When juggling between calls, you do not have to press the hold button to go
from one call to the next. The phone automatically puts your current call on hold
as soon as you press a new line/call appearance button. If you have more than
one call on hold, you can reconnect to a held call by pressing the line/call
Handling Calls
Transferring Calls
Blind Transfer
A blind transfer is when you transfer a call directly to another extension without
consulting with the person receiving the call. To do this, simply complete the
transfer immediately after you have entered the number. The call goes directly to
the extension or outside line you transferred to. If the party you are transferring
the call to does not answer, the transferred call rings back to your extension.
Consultative Transfer
You also have the option to consult with the person you are transferring the call
to, before you complete the transfer. To do this, remain on the line until the
receiving party answers the call. After consulting with the receiving party, you can
either complete the transfer or cancel the transfer to go back to the original call.
IP Phone UI
Use the following procedure to transfer a call to another extension. Use the
following illustration as a reference.
Transfer
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Connect to Party 1 (if not already connected). Party 1 is the party you want
to transfer.
2. Press the Transfer Key. You should hear a dial tone as a second line
opens up.
3. Dial the extension number (or the outside number) to Party 2. This is the Party
for which you want to transfer Party 1.
4. To complete a "blind" transfer, press the Transfer Key again before the
receiving party answers. To complete a consultative transfer, remain on the
line to speak with the Party 2, before pressing the Transfer Key again to
transfer Party 1 to Party 2. To cancel the transfer, select Cancel on the
display screen.
60 — Model 6753i Series IP Phone User Guide
Conferencing Calls
The 6753i IP phone offers two methods of conferencing:
• Local conferencing (default method).
By default, the Conference key is Key 6 on your phone. A Conference key must
be set up on your phone before you can set up conference calls. To assign a key
as a Conference key, see "Conference Key" on page 47.
Conference State Screens
When you use the Conference key to initiate a conference call, the following
screen displays.
1-1
1-2
John
Jim
03:05
= Drop
In a conference call, the call timer moves to the left. You use the up and down
arrow keys to scroll to a party on the list. You use the right arrow key to select the
party to drop.
Local Conferencing
The 6753i phone supports up to 3 parties (including yourself) in a conference
call. This is called Local Conferencing and is the default method of conferencing
on the 6753i.
Note: Your System Administrator can set your Conference key to speeddial a specific number. Contact your System Administrator for more
information.
Handling Calls
Model 6753i Series IP Phone User Guide — 61
Handling Calls
Using Local Conferencing
IP Phone UI
Use the following procedure to create a conference call using local
conferencing. Use the following illustration as a reference.
Conference
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. When you begin a conference, you are the first party in the conference (Party
1). Pickup the handset or press the speakerphone key. A line opens up.
2. Call Party 2 by dialing their number (or answer an incoming call of a Party).
3. Wait for Party 2 to answer. When Party 2 answers, you can consult with them
before adding them to the conference.
4. Press the Conf Key. A new line opens.
2
=Dial
5. Enter the phone number for Party 3.
6. Wait for Party 3 to answer. When Party 3 answers, you can consult with them
before adding them to the conference.
7. Press the Conf key again to add Party 3 to the conference. Party 1 (which is
yourself), Party 2, and Party 3 are all connected to a single conference.
8. To drop a party from the conference, press the Conf key once more.
Note: You can use
and
to scroll through and see the numbers and
names (if available) of the parties in the conference call. When a
name is displayed, pressing 4 drops the displayed party from the
call.
62 — Model 6753i Series IP Phone User Guide
Joining Two Active Calls in a Single Conference
IP Phone UI
1. Begin with active calls on two different lines (for example, Line 1 and Line 2
have active calls).
2. Press the Line key for which you want to conference the two calls together
(for example, Line 1).
3. Press the Conf key.
4. Press the Line key that has the second active call (for example, Line 2).
5. Press the Conf key. The two active calls link into a conference call on Line 1.
Note: You can use
and
to scroll through and see the numbers
and names (if available) of the parties in the conference call. When a
name is displayed, pressing 4 drops the displayed party from the
call.
Conference Bridge
A key business tool, the conference bridge allows users with an extension and
voicemail passwords to schedule and manage conference calls.
Basic functionality includes the ability to create and log into conference bridges.
There are also administrator modes that allow calling out and dropping parties
from the bridge.
Conference bridge supports up to 20 connected callers. An unlimited number of
conference bridges can be in session at the same time.
To Call into a Conference
Internal:
1. Call into the Conference Bridge by pressing More then Conf Bridge on your
phone.
External:
1. Call direct DID to Conference Bridge (only if a DID is assigned to Conference Bridge).
2. Call in Auto Attendant and select Menu Option that is assigned to
Conference Bridge.* (e.g. Option 4 > Conference Bridge)
Note: Conference Bridge must be configured to one of the Menu Options
in the Auto Attendant before accessing from the outside.
Conference Menu Options
Enter a Conference - (Option 1):
Model 6753i Series IP Phone User Guide — 63
Handling Calls
2. Dial 556 from your extension.
Managing Calls
1. Enter your extension then press #.
2. Enter conference ID then press #.
3. Please record first and last name then press #.
Create a Conference - (Option 2):
Enter your extension then press #.
Enter your password then press #. (Voicemail Password)
• Create a conference that expires in 2 weeks press 1
• Create a non expiring conference press 2
• Create a conference with a custom expiration date press 3
Delete Existing Conference - (Option 3):
1. Enter your extension then press #.
2. Enter your password then press #. (Voicemail Password)
3. Enter the conference ID you want to delete then press #.
Ending Calls
IP Phone UI
To end a call, you first need to connect or reconnect to the call if not already
connected (for example, if your caller is on hold). Press Goodbye or the line/call
appearance button of the active call to end the call. If connected through the
handset, you can also place the handset back on hook to end the call.
Managing Calls
The 6753i has several features that make it easier to manage calls, and to keep
track of your caller history, as well as your business and personal contacts.
These features include:
• Directory List
• Callers List
• Call Forwarding
• Missed Calls Indicator
• Voicemail
64 — Model 6753i Series IP Phone User Guide
Directory List
The Directory List is your personal phone book, conveniently stored within your
phone. You can enter up to 200 entries into the 6753i Directory by adding them
manually, or by saving the number and name from other lists stored on your
phone. You can also dial directly from a Directory entry. Each entry can contain a
maximum of 16 letters and numbers. On the 6753i you will need to program this
function into your softkey. Currently it is not programmed as your default softkey.
Accessing Your Directory
The Directory Key section assumes that you have programmed the softkey as the
directory key.
IP Phone UI
Use the following procedure to access your Directory List.
Note: You can use this function only after pre-programming as your softkey.
Press the Directory Key. The directory displays the number of entries in your list.
If the Directory List is empty, Directory Empty/Use Save to add is displayed.
Directory empty
Use Save to add
6. You can access entries by pressing
and
to scroll through the list.
8. To dial the displayed number press
Speaker/
Headset
or just lift the handset or press any
Line Key.
9. Press the Directory Key to cancel.
Sorting Entries and Quick Search Feature
You can also sort multiple numbers according to preference and perform a quicksearch feature that allows you to enter the first letter that corresponds to a name
in the Directory to find specific line items. The phone displays the first name with
this letter.
Note: The quick-search feature in the Directory List works only when the
Directory is first accessed.
Model 6753i Series IP Phone User Guide — 65
Managing Calls
7. To search for an entry by name, press the dialpad number corresponding to
the first letter of the name (for example, press 7 for the letter P). Continue to
press the dial pad number to access other letters on the same key (for example, press 7 three times for ‘Ron’). If there are multiple entries under the same
letter, you can use
and
to scroll through the list, or continue to press
the next letters of the name to find a better match.
Managing Calls
Managing the Directory List
From the Directory List in the IP Phone UI, you can perform the following:
• Add a new entry
• Edit an entry
• Delete an entry
• Save entries to the Directory List
- Save from the Display
- Save from the Caller List
- Save from the Redial List
Adding an Entry to the Directory List
IP Phone UI
Note: You can use this function only after pre-programming as your softkey.
Use the following procedures to add a new entry to the Directory List. Use the
following illustration as a reference.
Save Key
Delete Key
Directory
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
Note:
1. Use the 3 Key when required for backspacing.
2. You can exit the entry process any time by pressing
the
Goodbye
Key.
1. Press the Directory Key.
2. Press Save (Key 1). The "Enter Number" prompt displays.
3. Enter a phone number using the numbers on the keypad and press Save. To
backspace and erase a mistake, press
or press the Delete Key (Key 2).
The "Press 1st letter to enter name" prompt displays.
66 — Model 6753i Series IP Phone User Guide
4. Enter a name to associate with the phone number you just entered, and press
Save. Use the keypad to select the letters. Continue to press the number key
to access the next letter for that key (for example, press 2 three times to
access C). Press
to move to the next space, or wait a moment and the
cursor automatically advances. To insert a space between letters, press
.
To backspace and erase a mistake, press
or press the Delete Key.
The "Line" prompt displays. The default is Line 1.
5. If you want to save the new Directory entry to use Line 1, press Save to save
the new entry to the Directory List. If you want the new entry assotiated with a
different line, use the
key to select a different Line and press Save.
The new entry you added is saved to the Directory List.
Saved: Directory
John Burns
Adding an Entry to the Directory List from the Save Key
You can also add a new entry to the Directory List from the Save Key (Key 1).
Note:
1.Use the 3 Key when required for backspacing.
2.You can exit the entry process any time by pressing the
Key or the Directory Key.
Goodbye
1. Press the Save Key. The "Save to?" prompt displays.
2. Press the Directory Key. The "Enter Number" prompt displays.
3. Enter a phone number using the numbers on the keypad and press Save. To
backspace and erase a mistake, press
or press the Delete Key (Key 2).
The "Press 1st letter to enter name" prompt displays.
5. If you want to save the new Directory entry to use Line 1, press Save to save
the new entry to the Directory List. If you want the new entry to use a different
Key to select a different Line and press Save. The new entry
line, use the
you added is saved to the Directory List.
Saved: Directory
John Burns
Model 6753i Series IP Phone User Guide — 67
Managing Calls
4. Enter a name to associate with the phone number you just entered, and press
Save. Use the keypad to select the letters. Continue to press the number key
to access the next letter for that key (for example, press 2 three times to
access C). Press
to move to the next space, or wait a moment and the
cursor automatically advances. To insert a space between letters, press
.
To backspace and erase a mistake, press
or press the Delete Key.
The "Line" prompt displays. The default is Line 1.
Managing Calls
Editing an Entry in the Directory List
IP Phone UI
Use the following procedure to edit an entry in the Directory List. Use the
following illustration as a reference.
Save Key
Directory
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Directory Key.
2. Access the entry you want to edit by pressing the first letter of the name on
the dial pad, or use
and
to scroll through the list to find the name.
3. To begin editing, press
. Press
again to erase the numbers or letters to
the left or use the dialpad to enter additional digits or characters once you
have saved the number. If you don't want to change the number or name just
press the Directory Key or the Goodbye Key at any time to exit.
4. Press the Save Key to finish.
68 — Model 6753i Series IP Phone User Guide
Deleting an Entry from the Directory List
You can delete a single entry from the Directory List, or you can delete all entries
from the Directory List.
IP Phone UI
Use the following procedures to delete a single entry or all entries from the
Directory List. Use the following illustration as a reference.
Delete Key
Directory
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
Delete a Single Entry
1. Press the Directory Key.
2. Press
and
to find the entry you want to delete.
3. Press the Delete Key. The "DELETE again to erase this item"
prompt displays.
4. Press the Delete Key again at the prompt to erase the entry.
Delete All Entries
1. Press the Directory Key.
2. Press the Delete Key. The "DELETE again to erase all items"
prompt displays.
DELETE again to
erase all items
Model 6753i Series IP Phone User Guide — 69
Managing Calls
DELETE again to
erase this item
Managing Calls
3. Press the Delete Key again to erase all entries from the Directory List.
The "Directory empty" prompt displays.
Directory empty
Use Save to add
Saving an Entry to the Directory List
You can save entries (names and numbers) from other sources to your Directory
using any of the following methods:
• Saving from the Display
• Saving from the Caller List
• Saving from the Redial List
Saving from the Display
IP Phone UI
You can save the name and/or number displayed on your screen during a call to
the Directory List, or to one of your programmable keys using the following
procedure. Use the following illustration as a reference.
Save Key
Directory
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Save Key during the call.
Save to?
John Burns
9054550055
2. Press the Directory Key or an empty programmable key. If a name is displayed
both the number and name are saved in the Directory List or the programmable key. If no name or "Unknown Name" displays, you can enter the name
using the dialpad.
70 — Model 6753i Series IP Phone User Guide
3. Press the Save Key to finish.
Saving from the Callers List
IP Phone UI
Use the following procedure to save names/numbers from the Callers List to the
Directory. Use the following illustration as a reference.
Save Key
Directory
Key
Callers List
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Callers List Key (Key 4).
2. From the Callers List, scroll through the list to find the name and number that
you want to save to your Directory.
3. Press the Save Key.
4. Press the Directory Key to save the number you selected to the Directory List.
If the name is displayed with the number, both are saved to the Directory. If no
name is displayed, you can enter the name using the dial pad.
Managing Calls
Model 6753i Series IP Phone User Guide — 71
Managing Calls
Saving from the Redial List
IP Phone UI
Use the following procedure to save names/numbers from the Redial List to the
Directory. Use the following illustration as a reference.
Save Key
Directory
Key
Goodbye
Options
Redial List
Key
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Redial List Key (
Redial
).
2. From the Redial List, scroll through the list to find the name and number that
you want to save to your directory.
3. Press the Save Key.
4. Press the Directory Key to save the number you selected to the Directory List.
If the name is displayed with the number, both are saved to the Directory. If no
name is displayed, you can enter the name using the dial pad.
72 — Model 6753i Series IP Phone User Guide
Downloading the Directory List to Your PC
You can download the Directory List to your PC via the 8x8 Web Phone UI. The
phone stores the directorylist.csv file to your PC in comma-separated value
(CSV) format.
You can use any spreadsheet application to open the file for viewing. The
following is an example of a Directory List in a spreadsheet application. The file
displays the name, phone number, and line number for each Directory entry.
Note: Your System Administrator can populate your IP phone Directory List
with server directory files. Contact your System Administrator for
more details.
Download the Directory List
Use the following procedure to download the Directory List to your PC using the
8x8 Web Phone UI.
8x8 Web Phone UI
1. Click on Operation->Directory.
. A File Download
3. Click OK.
Model 6753i Series IP Phone User Guide — 73
Managing Calls
2. In the Directory List field, click on
message displays.
Managing Calls
4. Enter the location on your computer where you want to download the Directory List and click SAVE. The callerslist.csv file downloads to your computer.
5. Use a spreadsheet application to open and view the Directory List.
Callers List
The Callers List is a stored log of your incoming calls. The 6753i IP Phone stores
information for up to 200 incoming calls in the Callers list.
By default, the Callers List Key is on the top left of your phone.
Callers List Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
Your phone logs the number and name (if available) of the caller, when they last
called, and the number of times they tried to reach you. When the Callers list is
full, the oldest call records are deleted to accommodate the information for new
callers.
If the phone number of an incoming or outgoing call matches a number that you
have programmed with a name in a programmable key or in the Directory List, the
Callers List displays the name and number.
The display shows you how many callers have been added to the list since you
last checked it.
74 — Model 6753i Series IP Phone User Guide
Caller’s List Screen Display
Display Item
Description
450-349-0438
Indicates you have returned the call from the Callers list.
N MAR 04 3:30pm 2x
"N" indicates a new call.
XX New Callers
When you’re not on the telephone and not in the Callers
List, the display shows you how many callers have been
added to the list since you last checked it.
Indicates an unanswered call in the Callers List.
Indicates an answered call in the Callers List.
Indicates a Call Waiting call in the Callers List.
Indicates an incoming Call Waiting call.
John Burns
9054550055
Jun 8 2:41pm 2X
"2x" indicates this caller has called twice. The display
shows the date and time of the last call from that caller.
You can view, scroll, and delete line items in the Callers List from the IP phone
UI. You can also directly dial from a displayed line item in the Callers List.
Managing Calls
Model 6753i Series IP Phone User Guide — 75
Managing Calls
Accessing the Callers List
IP Phone UI
Use the following procedure to access the Callers List. Use the following
illustration as a reference.
Callers List
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Handsfree
Button
Mute
1. Press the Callers List Key. Press
List. Press
your List.
and
to move through the Callers
to see the most recent call, or
2. To dial the displayed number just press
Speaker/
Headset
to see the oldest call on
or lift the Handset or press
any line keys
3. Press the Callers List Key to cancel.
Editing Entries in the Callers List
Important: The Callers List does not save changes. Editing in the Callers List is
generally used if you plan to call the number and need to add a prefix.
If a dialpad key is pressed when a number and/or a name is displayed in the
Callers List, the cursor automatically adds the digit at the left side of the number
to enable the entry of the prefix.
007
N
John Burns
9054550055
Jun 8 2:55pm
76 — Model 6753i Series IP Phone User Guide
IP Phone UI
Use the following procedure to edit the Callers List. Use the following illustration
as a reference.
Callers List
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Handsfree
Button
Mute
1. Press the Callers List Key.
2. Press
and
to find the entry you want to edit. Press
most recent call, or
to view the
to see the oldest call on your list.
3. Press any key on the dialpad to begin editing.
4. To move the cursor one digit to the right, press
left of the cursor, press
.
5. To dial the displayed number press
Speaker/
Headset
. To erase one digit to the
, or just lift the handset, or press
any line key.
Managing Calls
Model 6753i Series IP Phone User Guide — 77
Managing Calls
Deleting Entries From the Callers List
You can delete individual items from the Callers List, or you can delete all items in
the Callers List.
IP Phone UI
Use the following procedure to delete an individual item from the Callers List.
Use the following illustration as a reference.
Delete Key
Callers List
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press the Callers List Key.
2. Press
and
to find the item you want to delete.
3. Press the Delete Key.
4. Press the Delete Key again at the prompt to erase the item.
IP Phone UI
Use the following procedure to delete all items from the Callers List.
1. Press the Callers List Key.
2. Press the Delete Key.
3. Press the Delete Key again at the prompt to erase all items.
78 — Model 6753i Series IP Phone User Guide
Downloading the Callers List to Your PC
You can download the Callers List to your PC for viewing using the 8x8 Web
Phone UI. When you download the Callers List, the phone stores the
callerlist.csv file to your computer in comma-separated value (CSV) format.
You can use any spreadsheet application to open the file for viewing. The
following is an example of a Callers List in a spreadsheet application. This file
displays the name, phone number, and the line that the call came in on.
Download the Callers List
Use the following procedure to download the Callers List to your PC using the
8x8 Web Phone UI.
8x8 Web Phone UI
1. Click on Operation->Directory.
. A File Download
3. Click OK.
4. Enter the location on your computer where you want to download the Callers
List and click SAVE. The callerslist.csv file downloads to your computer.
5. Use a spreadsheet application to open and view the Callers List.
Model 6753i Series IP Phone User Guide — 79
Managing Calls
2. In the Callers List field, click on
message displays.
Managing Calls
Call Forwarding
The call forwarding feature on the IP phone allows incoming calls to be
forwarded to another destination. The phone sends the SIP message to the SIP
proxy, which then forwards the call to the assigned destination.
Call forwarding is disabled by default. You can enable call forwarding on a global
basis or on an individual line-basis, for each line. If you have configured call
forwarding on an individual line, the settings for this line are used; otherwise, the
phone-wide call forward settings are used.
You can enable call forwarding on all phones (global settings) or on specific lines
(local settings) of a single phone. For local settings, you can set call forwarding
on up to 9 individual lines.
For global and local call forwarding, you can set the following:
• Call forward mode
• Destination number
• Number of rings before forwarding the call (from 1 to 9 rings)
The following are the call forward modes you can set.
Call Forward Mode
Description
Off
(8x8 Web Phone UI only)
Disables call forward.
All
Phone forwards all incoming calls
immediately to the specified
destination.
Busy
Phone forwards incoming calls if the
line is already in use.
No Answer
Phone forwards the call if it is not
answered in the specified number of
rings
Busy No Answer
Phone forwards the call if either the
line is already in use or the call is not
answered in the specified number of
rings.
80 — Model 6753i Series IP Phone User Guide
Note: You can set the global call forward settings using the IP phone UI or
the 8x8 Web Phone UI. However, you must use the 8x8 Web Phone
UI to set the per-line call forward settings. The per-line settings override the settings for global call forwarding.
You can also set the global call forward settings using the 8x8 Self
Service portal. Please note that the per-line settings made on the
8x8 Web Phone UI override the settings from the 8x8 Self Service
Portal.
Setting Call Forwarding
Use the following procedure to set global call forwarding.
For Global Call Forward Settings
IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select Call Forward and press 4.
3. Select Cfwd Number and press 4.
4. Enter the number destination for which you want your incoming calls to be forwarded and press 4.
Note: If you leave the "Number" field blank, call forwarding is disabled.
5. Press
to scroll to Cfwd Mode and press 4.
6. Use the
and
to select a value and press 4. Valid values are Off, All,
Busy, NoAns (No Answer), BusyNoAns (Busy No Answer).
8. Use the
to scroll to No. Rings and press 4.
and
to select a value and press 4. Valid values are 1 to 9.
Note: Number of Rings field applies to No Answer and Busy No Answer
modes only.
A message displays "confirmed".
The following example shows the idle screen on the IP Phone with Call
Forwarding set to "No Answer" mode.
Model 6753i Series IP Phone User Guide — 81
Managing Calls
7. Press
Managing Calls
1
CFWD NoAnswer
Sun Jan 2 03:00
82 — Model 6753i Series IP Phone User Guide
8x8 Web Phone UI
1. Click on Basic Settings->Call Forward.
2. In the "Mode" field, select the mode you want to set on your phone.
Note: To disable call forwarding in the 8x8 Web Phone UI, set the mode to
OFF and remove the phone number in the "Number" field.
3. In the Number field, enter the call forward number for which you want your
calls to be call forwarded.
4. In the Number of Rings field, enter the number of rings you want to set
before the call is forwarded. Valid values are 1 to 9.
5. Click
to save the Call Forward settings. The changes are global and
are immediately applied to the phone.
1
CFWD NoAnswer
Sun Jan 2 03:00
Model 6753i Series IP Phone User Guide — 83
Managing Calls
The following example shows the idle screen on the IP Phone with Call
Forwarding set to No Answer mode.
Managing Calls
For Per-Line Call Forward Settings
8x8 Web Phone UI
1. Click on Basic Settings->Call Forward.
2. Select a line to set Call Forwarding on.
3. In the "Mode" field, select the mode you want to set on this line.
Note:
1.To disable call forwarding in the 8x8 Web Phone UI, set the mode to OFF
and remove the phone number in the "Forward Number" field.
2.To force a line to use the global settings, set the "Mode" field to Global.
4. In the Forward Number field, enter the call forward number for which you
want your calls on this line to be call forwarded.
5. In the Number of Rings field, select the number of rings on the line before the
call is forwarded. Valid values are 1 to 9.
6. Click
to save the Call Forward settings. The changes are global and
are immediately applied to the phone.
Missed Calls Indicator
The IP phone has a "missed calls" indicator that increments the number of
missed calls to the phone. This feature is accessible from the IP phone UI only.
The number of calls that have not been answered increment on the phone’s idle
screen as "<number> New Calls". As the number of unanswered calls
increment, the phone numbers associated with the calls are stored in the Callers
List. The user can access the Callers List and clear the calls from the list. Once
the user accesses the Callers List, the "<number> New Calls" on the idle screen
is cleared.
84 — Model 6753i Series IP Phone User Guide
Accessing and Clearing Missed Calls.
IP Phone UI
Use the following procedure to access and clear missed calls from the Callers
List. Once you display the Callers List, the "<number> New Calls" indicator
clears. Use the following illustration as a reference.
Callers List
Key
Goodbye
Options
Line 3
Hold
Line 2
Redial
Line 1
Speaker/
Heading
Mute
1. Press Callers List key on the phone.
2. Use the
keys to scroll through the line items in the Callers List to find
the line items that have the b icon with the receiver ON. These are the missed
calls to the phone.
3. To clear a line item from the Callers List, select the line item you want to delete
and press the Clear softkey. The line item is deleted from the Callers List.
Voicemail System
To get started, record your first and last name, internal and external greetings,
and set your password. Your default password will be nothing. Press # after the
prompt asks for a password. It is important to record your first and last name to
appear in the dial by name and company directory from the auto-attendant, and
one number access greeting.
To Log into Voicemail
Internal
1. Dial the access number 555 or press the Voicemail soft key on the phone.
2. Enter your password then press #.
Model 6753i Series IP Phone User Guide — 85
Managing Calls
Virtual Office has a feature-rich, business-class voicemail solution that gives
users the ability to manage their calls when not available to answer the phone, by
providing callers messaging options. In the voicemail system, users can also
route their calls to an alternate number.
Managing Calls
From another Virtual Office extension
1. Dial 500.
2. Enter your extension number then press #.
3. Enter voicemail Password then press #.
External:
1. Dial your personal DID phone number (not the main company number).
4. Enter # during the voicemail greeting.
5. Enter the voicemail password then press #.
Password Entered Incorrectly: A message saying that the password is invalid is
followed by another chance to enter the password. Three password failure
attempts will lock the user out of the voicemail system. Hang up and try again. If
you continue to have difficulties, call 8x8 tech support with your phone number,
email address on file, and problem.
Important! The default password is blank. We highly recommend you that
change the password for security reason.
Managing Voicemail
Voicemail can be a powerful tool when you are not available to answer the
phone. Different greetings and routing can be accomplished with voicemail. The
following section includes listening, saving, deleting, and forwarding message
controls, and also includes creating, changing, and setting personal name and
greeting options.
Complete Voicemail Menu Tree
To listen to your messages, press 1
Once logging into voicemail, a summary of old and new messages is played, and
you will be prompted to proceed. The system will automatically start playing the
most recent new message and then the oldest saved messages.
• Press 1 for new messages.
• Press 2 for old and new messages. To replay message, press 1.
• To listen to next message, press 2.
• To delete message, press 3.
• To play previous message, press 4.
• To call to sender, press 5.
86 — Model 6753i Series IP Phone User Guide
Voicemail Call Return enables you to return a call from voicemail without dialing
the number. Simply press 5 while listening to a voicemail, if caller ID is
recognized Virtual Office will call the person back. To return to voicemail while
still on the call press * and you will be returned to that voicemail.
• To return to the main menu, press *.
• To enable voicemail internationally, contact Tech Support at 1.888.898.8733
• Press 3 for group messages (this prompt is only played if you belong to
a group extension).
• For the main menu, press *.
To establish or change a greeting, press 2
• To record your first and last name, press 1. (This will be the name that callers
hear if they select Dial By Name or Company Directory from the Auto Attendant. If no name is recorded, your name will not be heard on the company
auto-attendant directory.)
• To record your internal greeting, press 2 (played only to internal callers).
• To record your external greeting, press 3 (played only to external callers).
• To record your after business hours greeting, press 4.
• To record your lunch time greeting, press 5.
• To record your meeting greeting, press 6.
• To record your weekend greeting, press 7.
• To record your vacation greeting, press 8.
• To return to the previous menu, press *.
• To exit, press 9.
To change user preferences, press 3
• Password 1.
• Do not disturb 2.
• Call waiting 3.
• Busy, ring no answer, Internet outage handling 4.
• Email notification 6.
To establish or change forwarding rules, press 4
• Listen to forwarding rule, press 1.
• Change forwarding rule, press 2.
• To set forwarding rule, press 3.
• To delete forwarding rule, press 4.
• To return to main menu, press *.
• To exit, press 9.
Model 6753i Series IP Phone User Guide — 87
Managing Calls
• To return to the previous menu, press *.
Managing Calls
To set a specific greeting to play, press 5
• Business hours greeting, press 1.
• After business hours greeting, press 2.
• Lunch time greeting, press 3.
• Meeting greeting, press 4.
• Weekend greeting, press 5.
• Vacation greeting, press 6.
• To listen to the current greeting, press 0.
• Return to the previous menu, press *.
To turn on/off the announcement only mode, press 6
To exit, press 9
To place a call from voicemail press #
Calling out of voicemail enables users to take advantage of 8x8 competitive
international rates by dialing any number from inside voicemail. While accessing
your voicemail, press * then press #. You will hear dial tone. Press 9 and dial the
number to initiate your call. If on a cellular or mobile phone, you can access our
low international calling rates by dialing into your voicemail to originate call.
Note: Contact 8x8 Tech Support to enable this feature.
Message Playback Control
When listening to messages, the system gives the user several options:
• To hear more options, press 0.
• Press 1 to obtain more information about the message. The following will be
heard:
• External or internal message
• Priority type
• From Caller ID or extension
• Timestamp for message.
• Press 2 to forward the message to another extension.
• Press 3 to call the sender.
• Press * to return to main menu.
Note: At any time during the menus, you may press the desired keys to
interrupt voicemail prompts.
88 — Model 6753i Series IP Phone User Guide
Forwarding Messages
1. A user can forward a message to another user to share information.
2. Log into voicemail and select the message that is to be forwarded.
3. Press 0 after listening to the message.
4. Select 2 to forward message.
5. Enter the extension numbers where the message should be sent.
Personal Voicemail Greetings
Virtual Office allows an array of greetings to be recorded for different activities.
Users can select which greeting callers will hear when they are not able to
answer a call.
To Record Your Greetings into Voicemail
From voicemail's main menu, select 2 and then follow the prompts to record
each greeting personally.
• To record your first and last name, press 1.
Note: It is important to record your first and last name to be listed in both
the dial by name and the company directory from the auto-attendant
and one number access greeting.
• To record your internal greeting, press 2.
• To record your external greeting, press 3.
• To record your after business hours, press 4.
• To record your lunchtime greeting, press 5.
• To record your meeting greeting, press 6.
• To record your weekend greeting, press 7.
• To record your vacation greeting, press 8.
Selecting the Voicemail Greeting to Play
• Business hours greeting, press 1.
• After business hours greeting, press 2.
• Lunch time greeting, press 3.
• Meeting greeting, press 4.
• Weekend greeting, press 5.
• Vacation greeting, press 6.
Model 6753i Series IP Phone User Guide — 89
Managing Calls
From the voicemail main menu, select 5 and then follow the prompts to select
which greeting callers will hear.
Additional Features
Additional Features
This section describes additional features you can use on the 6753i phone.
Calling Features
Distinctive Ringing
Calls presented to an extension on Virtual Office will ring differently, depending
on where the call originated.
• Internal calls are distinguished by one ring.
• External calls are distinguished by two rings.
Call Waiting
Call waiting enables more than one call to be taken at a time. If a call comes in
while you're on the phone, the system will beep up to three times over a 24
second period before the call is routed into voicemail. You will be presented with
caller ID, if provided by the calling party, and the call waiting indicator tone. Call
waiting is configured at sign-up of service. Changes to enable or disable call
waiting can be done from the Extension Manager.
Multiple Call Handling
Multiple call handling allows users to pick up a second ringing call while placing
another one on hold. Multiple call handling also allows users to call out while
already on a phone call. Lastly, multiple call handling gives telephone users the
ability to toggle between calls. Multiple call waiting is configured at sign-up of the
service, and changes to enable or disable multiple call handling can be made on
a per call basis or setup online.
Taking Multiple Calls
While talking on the phone, a new call will be announced by an audio alert beep
to the phone, and call waiting with the caller ID number will display on the phone.
To pick up the second ringing call:
• Press the [Retrieve/Alternate] button, which will pick up the new call and
place the original caller on hold where they will hear music on hold.
Alternate Between Calls
While on the phone with two calls you can:
• Press [Retrieve/Alternate] to switch between callers.
Caller ID
When an internal extension call is received on a Virtual Office phone, the display
will present an extension name. On an external call, the display will present a
caller number. Additional caller numbers will be displayed with multiple calls.
• To identify the caller number on calls, you should wait at least two rings.
• In some cases, the caller number (or caller-ID) may not be available.
• Can be turned off for all calls from the Extension Manager.
90 — Model 6753i Series IP Phone User Guide
Three-party Conference
Three parties can conference in on the same call. Multiple conference calls can
be added together from other extensions within Virtual Office. Conference calls
can be initiated by calling out of a call and conferencing in, but also by adding a
call waiting to an existing call.
Transferring
Transferring calls provides users with the ability to pass a caller to another
person- either inside the company, or outside to an external phone. Transferring a
call can be done without notifying the recipient (unsupervised), or can be
announced (supervised) by you to the recipient before being passed on.
Do Not Disturb (DND)
Puts the telephone in a state that will not ring, and calls will be automatically
forwarded to voicemail.
Forwarding
Forwarding is an effective tool that helps avoid missing important calls. In some
cases, all calls for a particular extension may be forwarded to a cell phone to give
the impression a mobile person (on a mobile phone) is located in the office.
Forwarding can also be used outside the office, when an important caller is
expected.
All forwarding rules and routing can be managed from a remote location through
an individual's voicemail or from the Extension Manager.
Additional Features
Model 6753i Series IP Phone User Guide — 91
Additional Features
Extension Manager
Our new Extension Manager web portal with unique extension login allows
extension holders the ability to control all extension settings including busy, ringno-answer, and Internet outage handling, ring duration and forwarding
destinations. Other settings in Extension Manager including forwarding rules,
one number access, caller ID blocking, call waiting disable and other unique
settings.
Suppress DTMF Playback
A feature on the IP phones allows you to enable or disable the suppression of
DTMF playback when a number is dialed from the programmable keys.
When suppression of DTMF playback is disabled, and you press a
programmable key, the IP phone dials the stored number and displays each digit
as dialed in the LCD window.
When the suppression of DTMF playback is enabled, the IP phone dials the
stored number and displays the entire number immediately in the LCD window,
allowing the call to be dialed faster.
DTMF playback suppression is disabled by default. Suppressing DTMF playback
can be configured using the 8x8 Web Phone UI.
92 — Model 6753i Series IP Phone User Guide
Configuring Suppression of DTMF Playback
8x8 Web Phone UI
Use the following procedure to configure suppression of DTMF playback.
Note: "Suppress DTMF Playback" is disabled by default.
1. Click on Basic Settings->Preferences.
2. Go to the General section.
3. Enable the Suppress DTMF Playback field by checking the check box.
(Disable this field by unchecking the box). Default is disabled.
4. Click
to save your settings.
Display DTMF Digits
DTMF is the signal sent from the phone to the network that you generate when
you press the phone’s touch keys. This is also known as “touchtone” dialing.
Each key you press on your phone generates two tones of specific frequencies.
One tone is generated from a high-frequency group of tones and the other from a
low frequency group.
If you enable the Display DTMF Digits parameter, the digits you are dialing from
the keypad or from a programmable key display to the IP phone’s LCD display.
This parameter is disabled by default (no digits display when dialing).
You can enable the "Display DTMF Digits" parameter using the 8x8 Web Phone
UI.
Model 6753i Series IP Phone User Guide — 93
Additional Features
A feature on the IP phones allows users to enable or disable DTMF (dual-tone
multi-frequency) digits to display to the IP phone when using the keypad to dial,
or when dialing from a programmable key.
Additional Features
Configuring Display of DTMF Digits
8x8 Web Phone UI
Use the following procedure to configure the display of DTMF digits on the IP
phone.
Note: "Display DTMF Digits" is disabled by default.
1. Click on Basic Settings->Preferences->General.
2. Enable the Display DTMF Digits field by checking the check box.
(Disable this field by unchecking the box). Default is disabled.
3. Click
to save your settings.
Enable/Disable Call Waiting
The call waiting feature notifies the user on an active call, of a new incoming call.
You can disable the call waiting feature, so that the new incoming call is
automatically rejected by the phone with a busy message.
If you disable call waiting on the phone, and the user is on a call, any further
incoming calls receive busy unless “Call Forward Busy” or “Call Forward No
Answer and Busy” is configured on the phone (for information on
"Call Forwarding", see page 80.) It then forwards the call according to the rule
configured. The phone can only:
• transfer the currently active call.
or
• accept transferred calls if there are no active calls.
94 — Model 6753i Series IP Phone User Guide
If call waiting is disabled:
• intercom calls are treated as regular incoming calls and are rejected.
• pre-dialing with live dialpad disabled still accepts incoming calls.
• the “Incoming Call Interrupts Dialing” parameter is ignored because the
incoming call is automatically rejected (for information on "Incoming Call
Interrupts Dialing" see page 98).
• the Missed Calls List does not get updated with details of calls.
• the Blind Transfer feature on the phone may not work if two calls are made to
the phone at one time.
You can disable call waiting using the configuration files or the 8x8 Web Phone
UI.
Enabling/Disabling Call Waiting
8x8 Web Phone UI
Use the following procedure to enable or disable Call Waiting on the IP phone.
Note: Call Waiting is enabled by default.
1. Click on Basic Settings->Preferences->General.
3. Click
to save your settings.
Model 6753i Series IP Phone User Guide — 95
Additional Features
2. Call Waiting is enabled by default. If required, disable the Call Waiting field by
unchecking the check box.
Additional Features
Play Call Waiting Tone
You can enable or disable the playing of a call waiting tone when you are on an
active call and a new call comes into the phone.
You can configure this feature using the 8x8 Web Phone UI.
Configuring Call Waiting Tone
8x8 Web Phone UI
Use the following procedures to configure a call waiting tone on the IP phone.
Note: Play Call Waiting Tone is enabled by default.
1. Click on Basic Settings->Preferences->General.
2. A call waiting tone is enabled by default. If required, disable the Play Call
Waiting Tone field by unchecking the check box.
3. Click
to save your settings.
96 — Model 6753i Series IP Phone User Guide
Stuttered Dial Tone
You can enable or disable the playing of a stuttered dial tone when there is a
message waiting on the IP phone.
You can configure this feature using the 8x8 Web Phone UI.
Configuring Stuttered Dial Tone
8x8 Web Phone UI
Use the following procedures to configure stuttered dial tone on the IP phone.
Note: Stuttered Dial Tone is enabled by default.
1. Click on Basic Settings->Preferences->General.
3. Click
to save your settings.
XML Beep Support
Using the 8x8 Web Phone UI, you can enable or disable a beep to be audible
when the phone receives an XML application using the "XML Beep Support"
field at the path Basic Settings->Preferences->General. If you disable this
feature, no beep is heard when the XML application arrives to the phone.
If your System Administrator has set a value for this feature in a custom XML
application or in the configuration files, the value you set in the 8x8 Web Phone
UI overrides the Administrator’s setting. Setting and saving the value in the 8x8
Web Phone UI applies to the phone immediately.
Model 6753i Series IP Phone User Guide — 97
Additional Features
2. Stuttered dial tone is enabled by default. If required, disable the Stuttered
Dial Tone field by unchecking the check box.
Additional Features
Status Scroll Delay
Using the 8x8 Web Phone UI, you can specify a scroll delay option that allows
you to set the time delay, in seconds, between the scrolling of each status
message on the phone. You can specify this setting in the Status Scroll Delay
(seconds) field at the path Basic Settings->Preferences->General. The default
time is 5 seconds for each message to display before scrolling to the next
message. You can increase or decrease this time as required. Setting and saving
the value in the 8x8 Web Phone UI applies to the phone immediately.
Configuring Status Scroll Delay
8x8 Web Phone UI
Use the following procedures to specify a status scroll delay on the IP phone.
1. Click on Basic Settings->Preferences->General.
2. Enter a value in the "Status Scroll Delay (seconds)" field. Valid values are:
1 to 25 seconds. Default is 5.
3. Click
to save your settings.
Incoming Call Interrupts Dialing
If you are dialing a call on your phone and another call comes in while you are
dialing, you can allow the incoming call to interrupt dialing by enabling a
parameter called "Incoming Call Interrupts Dialing". You can enable or disable
this parameter in the 8x8 Web Phone UI at the path Basic
Settings->Preferences->General.
When you enable this field in the 8x8 Web Phone UI, an incoming call
automatically interrupts the outgoing call during dialing and allows the phone to
ring for you to answer the incoming call.
When you disable this parameter, which is the default, the phone does not
interrupt the outgoing call during dialing and instead rings the incoming call on
another free line (or sends busy signal if all remaining lines are busy). You have a
choice to ignore the incoming call, or answer the incoming call on another line. If
98 — Model 6753i Series IP Phone User Guide
you choose to answer the incoming call, you can answer the call, finish the call,
and then hang up. You can still go back to the original outgoing call and finish
dialing out.
Note: :
1. On a 6753i, you must use the down arrow key to ignore the call. To
answer the call you must press the line key where the call is coming in.
2. If you disable this field, and the phone receives an incoming call while
you are dialing an outgoing call, you can pick up the call and perform
transfer or conference as required.
Configuring Incoming Call Interrupts Dialing
8x8 Web Phone UI
Use the following procedures to configure "Incoming Call Interrupts Dialing" on
the IP Phone.
Note: Incoming Call Interrupts Dialing is disabled by default.
1. Click on Basic Settings->Preferences->General.
3. Click
to save your settings.
Model 6753i Series IP Phone User Guide — 99
Additional Features
2. Enable the Incoming Call Interrupts Dialing field by checking the check box.
(Disable this field by unchecking the box). Default is disabled.
Additional Features
Goodbye Key Cancels Incoming Calls
The 6753i has a feature that allows you to configure the Goodbye key to drop a
second incoming call or ignore incoming calls presented to the phone when you
are on an active call. The parameter is called "Goodbye Key Cancels Incoming
Call" and is configurable via the 8x8 Web Phone UI.
If you enable this parameter, which is the default, pressing the Goodbye key
rejects calls coming into the phone while you are on an active call. When you
disable this parameter, pressing the Goodbye key hangs up the active call.
If you disable this feature, and the phone receives another call when an active
call is already present, the 6753i displays "3 Ignore Answer 4" on the LCD. For
the 6753i, you must use the Right and Left arrow keys to answer or ignore the
call.
A User can set this parameter using only the 8x8 Web Phone UI.
Configuring Goodbye Key to Cancel Incoming Calls
8x8 Web Phone UI
Use the following procedure to configure the Goodbye key to cancel incoming
calls on the IP Phone.
Note: Goodbye Key Cancels Incoming Call is enabled by default.
1. Click on Basic Settings->Preferences->General.
2. The Goodbye Key Cancels Incoming Call field is enabled by default. If
required, disable this field by unchecking the check box.
3. Click
to save your settings.
100 — Model 6753i Series IP Phone User Guide
Using the Goodbye Key to Cancel Incoming Calls Feature
IP Phone UI
IF
THEN
Goodbye Key Cancels Incoming Call is
enabled AND a second call comes in while
you are on an active call,
press the Goodbye key to reject the
second incoming call.
Goodbye Key Cancels Incoming Call is
press the Goodbye key to hang up on the
disabled AND a second call comes in while active call so you can answer the second
you are on an active call,
incoming call.
Goodbye Key Cancels Incoming Call is
press the Left Arrow key to ignore the
disabled AND a second call comes in while second incoming call and remain on the
you are on an active call,
active call
OR
press the Right Arrow key to answer the
second incoming call.
Message Waiting Indicator
You can configure the Message Waiting Indicator (MWI) to illuminate for a
specific line or for all lines. For example, if you configure the MWI LED on line 3
only, the LED illuminates if a voicemail is pending on line 3. If you configure the
MWI LED for all lines, the LED illuminates if a voicemail is pending on any line on
the phone (lines 1 through 9).
You configure the MWI indicator using the 8x8 Web Phone UI.
8x8 Web Phone UI
Use the following procedure to configure the message waiting indicator on a
specific line or on all lines on the IP phone.
Note: Message Waiting Indicator Line parameter is set to ALL lines
by default.
Model 6753i Series IP Phone User Guide — 101
Additional Features
Configuring Message Waiting Indicator
Additional Features
1. Click on Basic Settings->Preferences->General.
2. The Message Waiting Indicator Line field is set to ALL lines by default. If
required, change the setting to a specific line by selecting a line from the list.
Valid values are All and lines 1 through 9.
3. Click
to save your settings.
Incoming Intercom Call Features
Incoming Intercom
By default, the IP phone allows incoming Intercom calls to be automatically
answered without having to set up an Intercom key on your phone. The phone
automatically plays a warning tone when it receives an incoming Intercom call. It
also mutes the microphone. If the Intercom call comes into the phone while an
active call is already present, the user will have an option to answer the intercom
call.
102 — Model 6753i Series IP Phone User Guide
You can change the behavior of how the phone handles incoming Intercom calls
by enabling/disabling specific parameters using the 8x8 Web Phone UI. The
following table describes these features.
Incoming Intercom
Features in
8x8 Web Phone UI
Description
Microphone Mute
Allows you to enable or disable the microphone on the IP
phone for Intercom calls made by the originating caller.
Auto Answer
Allows you to enable or disable the IP phone to
automatically answer an Intercom call. If auto-answer is
enabled on the IP phone, the phone plays a tone (if Play
Warning Tone is enabled) to alert the user before
answering the Intercom call. If auto-answer is disabled, the
phone rejects the incoming Intercom call and sends a busy
signal to the caller.
Note: Your Administrator can set a time period delay
before the phone automatically answers. Contact
your System Administrator for more information.
Play Warning Tone
Allows you to enable or disable a warning tone to play
when the phone receives an incoming Intercom call on an
active line.
Allow Barge In
Allows you to enable or disable how the phone handles
Incoming intercom calls while the phone is on an active
call.
Microphone Mute
Auto-Answer/Play Warning Tone
The auto-answer feature on the IP phone allows you to enable or disable
automatic answering for an Intercom call. If Auto-Answer is enabled, the phone
automatically answers an incoming Intercom call. If “Play Warning Tone” is also
enabled, the phone plays a tone to alert you before answering the Intercom call.
If “Auto-Answer” is disabled, the phone rejects the incoming Intercom call and
sends a busy signal to the caller.
Auto-Answer and Play Warning Tone are enabled by default.
Note: Your Administrator can set a time period delay before the phone
automatically answers. Contact your System Administrator for more
information.
Model 6753i Series IP Phone User Guide — 103
Additional Features
You can mute or unmute the microphone on the IP phone for Intercom calls
made by the originating caller. If you want to mute the Intercom call, you enable
this feature. If you want to unmute (or hear the Intercom call), you disable this
feature. "Microphone Mute" is enabled by default.
Additional Features
Allow Barge In
You can configure whether or not the IP phone allows an incoming Intercom call
to interrupt an active call. The Allow Barge In parameter controls this feature.
When you enable this parameter, which is the default value, an incoming
Intercom call takes precedence over any active call, by placing the active call on
hold and automatically answering the intercom call. When you disable this
parameter, and there is an active call, the phone treats an incoming Intercom
call like a normal call and plays the call warning tone. Allow Barge In is disabled
by default.
Configuring Incoming Intercom Settings
8x8 Web Phone UI
Use the following procedure to configure incoming Intercom settings on the IP
phone.
1. Click on Basic Settings->Preferences->Incoming Intercom Settings.
2. The Auto-Answer field is enabled by default. The automatic answering feature
is turned on for the IP phone for answering Intercom calls. To disable this
field, uncheck the box.
Note: If the Auto-Answer field is not checked (disabled), the phone rejects
the incoming intercom call and sends a busy signal to the caller.
104 — Model 6753i Series IP Phone User Guide
3. The Microphone Mute field is enabled by default. The microphone is muted
on the IP phone for Intercom calls made by the originating caller. To disable
this field, uncheck the box.
4. The Play Warning Tone field is enabled by default. If “Auto-Answer” is
enabled, the phone plays a warning tone when it receives in incoming intercom call. To disable this field, uncheck the box.
5. The Allow Barge In field is disabled by default. If Allow Barge In is enabled,
the phone puts an active call on hold and answers the incoming Intercom call.
To enable this field, check the box.
6. To enable this field, check the box. Click
to save your settings.
Using Redial Key for “Last Number Redial”
The IP phone has an enhanced redial user interface that allows a user to quickly
redial the last number that was dialed out from the phone. You can:
• Press the REDIAL button twice to redial the last number dialed.
• Press the REDIAL button once, scroll the list of numbers, then press the
REDIAL button again to dial the number that displays on the screen.
The last number redial feature for the Redial key is static and is
not configurable.
Customizable Callers List Key
Your System Administrator can specify an XML URI that creates a custom
Callers List application for your phone. When you press the Callers List key, the
phone accesses a custom XML URI Callers List instead of the standard Callers
List. Contact your System Administrator for more information.
Autodial (Hotline and Warmline)
• Hotline: The IP phone immediately dials a preconfigured number when you
lift the handset.
• Warmline: The IP phone waits for a specified amount of time after you lift the
handset before dialing a preconfigured number. If you do not dial a number
within the time allotted, then the IP phone begins to dial the number.
The Autodial feature is available on a global or per-line basis. Contact your
System Administrator for more information.
Note:
1. Any speeddial numbers that you configure on your IP phone are not
affected by autodial settings.
2. If Autodial is configured on your phone, any lines that function as hotlines
do not accept conference calls, transferred calls, and/or intercom calls.
Model 6753i Series IP Phone User Guide — 105
Additional Features
Your System Administrator can configure an autodial feature on your phone. If
autodial is enabled, the phone automatically dials a preconfigured number
whenever it is off-hook. Depending on the configuration specified by your
Administrator, the Autodial functions as either a “hotline”, or as a “warmline,” as
follows:
Additional Features
Answer and Ignore Softkeys for XML Applications
If you are accessing XML applications on your phone and a call comes in, your
System Administrator can create "Answer" and "Ignore" keys that you can use
to either answer the incoming call, or ignore it.
!N8-,APPLICATIONCANDISPLAY
HEREWHILEACALLISCOMINGIN
,JQRUH
$QVZHU
When the 3 Ignore Answer 4 line displays, you can press the Right Arrow key
(Answer) to answer the incoming call without disturbing the current XML
application. When you answer the call, the 3 Ignore Answer 4 line disappears
from the LCD. Pressing the Left Arrow key (Ignore) ignores the incoming call
without disturbing the current XML application. Contact your System
Administrator for more information.
XML Softkey for Special Characters in XML Applications
When using XML applications that require you to enter information such as email
addresses, that require special symbols (for example, the "@" symbol), your
System Administrator can create an XML softkey to access these symbols.
Pressing the symbol key in an XML application can display a single symbol or a
list of symbols from which you can choose the symbol you need. Contact your
System Administrator for more information.
106 — Model 6753i Series IP Phone User Guide
Model 536EM Expansion Module
The 6753i IP Phone offers an optional 536EM Expansion Module that attaches
to the right side of the phone to provide additional softkeys.
Model 536EM
The softkeys support the following features:
• Busy Lamp Fields (BLFs) (maximum of 50)
• Speedial
• Shared Call Appearance
• Phone Lock
You can purchase the module from the 8x8 accessories page at www.8x8.com.
Reference
For more information about configuring the expansion module softkeys with
these functions, see the "Programmable Keys" on page 36.
Model 6753i Series IP Phone User Guide — 107
Model 536EM Expansion Module
The 536EM provides 18 softkeys in each column (totaling 36 keys) on the
keypad. Each key provides an LED for indicating call status. The 536EM
provides a paper label for convenient key labeling.
Model 536EM Expansion Module
Using the Expansion Module
536EM Expansion Module
After configuring the softkeys on the 536EM Expansion Module, you can record
the name of the softkey on the paper labels provided with the Expansion Module.
Press the softkey you want to use when applicable.
Softkeys
Lock Phone
BLF Key
Office (speeddial)
References
For more information about configuring softkeys, see "Programmable Keys" on
page 36.
You can purchase the 536EM Expansion Module by going to the 8x8
accessories page at: http://www.8x8.com/store/
Default.aspx?page=business_accessories.
Creating a Speeddial Key from the Expansion Module Keypad
IP Phone UI
Pressing and holding down a key on the expansion module initiates a speeddial
feature.
When creating a speeddial key on the Expansion Module, you must select a key
that has no preassigned function (key must be set to none).
1. Press a key on the expansion module for 3 seconds. A screen displays on the
Phone UI with the prompt, "Enter number>".
2. Enter a phone number or extension to assign to that speeddial key using the
108 — Model 6753i Series IP Phone User Guide
phone’s keypad. The following example illustrates the screen display:
Speeddial
Enter number> 3456
After entering the number, the prompt, Use Save to end displays on the
screen.
3456
Use Save to end
3. Press Save to save the number as a speeddial key.
By default, the phone automatically assigns the speeddial key to line 1 if
available. To select a different line, press the Change softkey and select a
different line, or use the phone’s keypad to select a number (1-9), or use the
and
to make your selection.
4. Press Save to save the speeddial key to the line specified.
Note: Use the 8x8 Web Phone UI to edit or delete this speeddial key.
Troubleshooting Solutions
Why is my display blank?
Ensure that power is being provided to your phone. Make sure your phone is
plugged into a power source.
Why is my speakerphone not working?
If you press the
Speaker/
Headset
button and the speaker light flashes and you do not hear
dial tone through the speaker phone, the Set Audio option in the phone’s
Options list has been set up for headset use. Press
a second time and if
Speaker/
Headset
the light goes out, the phone has been set up to be used only with a headset or
handset. If the light stays on steady and you hear dial tone, the phone has been
Model 6753i Series IP Phone User Guide — 109
Troubleshooting Solutions
Line: 1
Change
Use Save to end
Troubleshooting Solutions
set up so that you can alternate between the speakerphone and the headset by
pressing
. See the section, "Set Audio" on page 22 for instructions on
Speaker/
Headset
how to change the Set Audio option.
Why can’t I get a dial tone?
Check for any loose connections and that the phone has been installed properly.
For installation instructions, please refer to the “Installation and Setup” section
in the 8x8 6753i Reference Manual provided with your phone.
Why doesn’t my phone ring?
Check the ring volume on your phone. It may be turned down or turned off. To
adjust the ringer volume setting, press the volume button when the phone is onhook and idle. For more information, refer to the “Adjusting Volume section” in
the 8x8 6753i Reference Manual provided with your phone.
How do I find the IP address of my phone?
Instructions on where to find the IP address of your phone can be found in this
guide in the section, "Finding Your Phone’s IP Address" on page 17.
How do I change my user password?
You can change the user password from the IP phone UI or the 8x8 Web Phone
UI.
IP Phone UI
1. Press
Options
on the phone to enter the Options List.
2. Select User Password and press
.
3. Enter the current user password and press
4. Enter the new user password and press
.
.
5. Re-enter the new user password and press
Changed" displays on the screen.
. A message, "Password
8x8 Web Phone UI
1. Click on Operation->User Password.
2. In the "Current Password" field, enter the current user password.
Note: By default, the user name is “user” (all lowercase) and the password
field is left blank. If you have forgotten your password, contact your
System Administrator for assistance.
3. In the New Password field, enter the new user password.
110 — Model 6753i Series IP Phone User Guide
4. In the Password Confirm field, enter the new user password again.
5. Click
to save your changes.
For information on how to access the 8x8 Web Phone UI, go to the section
"Using the 8x8 IP Phone Web UI" on page 13.
Why does my phone display Bad Encrypted Config?
The IP phone displays Bad Encrypted Config because encrypted configuration
files are enabled but the decryption process has failed. Report this error to your
System Administrator.
How do I restart the IP phone?
IP Phone UI
1. Press the
Options
button on the phone to enter the Options List.
2. Use the
key to scroll down the list of options to Phone Status and press
the 4. key to select.
3. Press the
key to scroll to the Restart Phone option.
Note: Your phone is out of service temporarily during the restart and downloading process.
8x8 Web Phone UI
1. Click on Operation->Reset.
2. Click
.
3. Click OK at the confirmation prompt.
Model 6753i Series IP Phone User Guide — 111
Troubleshooting Solutions
Press the 4. key to confirm and restart the phone. If you do not wish to restart
your phone, press the 3 key to cancel.
Troubleshooting Solutions
How do I lock my phone?
You can lock your phone to prevent the phone from being used or configured.
Using any of the following:
• At the path Options->Phone Lock on the IP Phone UI.
• At the path Operations->Phone Lock on the 8x8 Web Phone UI.
• At a configured key on the phone. For more information about configuring a
Lock/Unlock key on your phone, see "Phone Lock Key" on page 50.
Use the following procedure to lock an IP phone using the IP Phone UI.
IP Phone UI
Lock the Phone
1. Press
Options
on the phone to enter the Options List.
2. Select Phone Lock and press
3. Press
.
to set the phone to lock.
4. Press Options on the phone.
The following message displays: Phone is locked.
Unlock the Phone
1. Press
Options
on the phone to enter the Options List.
2. Enter your user password and press
. The phone unlocks.
Use the following procedure to lock an IP Phone using the 8x8 Web
Phone UI.
8x8 Web Phone UI
1. Click on Operation->Phone Lock.
112 — Model 6753i Series IP Phone User Guide
Lock the Phone
2. In the "Lock the Phone?" field, click
. The phone locks dynamically and
displays the following message: Phone is locked.
Unlock the Phone
3. Click on Operation->Phone Lock.
4. In the "Unlock the Phone?" field, click
. The phone unlocks dynamically and displays the following message: Phone is unlocked.
Troubleshooting Solutions
Model 6753i Series IP Phone User Guide — 113
Limited Warranty
This warranty applies only to products purchased and used in the United States.
What Is Covered?
Any defect in materials or workmanship for one year. (See 8x8 Virtual Office
terms and conditions.)
Appendix A - Time Zone Codes
The following table identifies the time zone name and time zone code to use on
the IP phone.
Time Zone Name/Time Zone Code Table
Time Zone Name
Time Zone Code
AD-Andorra
AG-Antigua
AI-Anguilla
AL-Tirane
AN-Curacao
AR-Buenos Aires
AS-Pago Pago
AT-Vienna
AU-Lord Howe
AU-Tasmania
AU-Melbourne
AU-Sydney
AU-Broken Hill
AU-Brisbane
AU-Lindeman
AU-Adelaide
AU-Darwin
AU-Perth
AW-Aruba
CET
AST
AST
CET
AST
ART
BST
CET
LHS
EST
EST
EST
CST
EST
EST
CST
CST
WST
AST
BA-Sarajevo
BB-Barbados
BE-Brussels
BG-Sofia
BM-Bermuda
BO-La Paz
BR-Noronha
BR-Belem
BR-Fortaleza
BR-Recife
BR-Araguaina
BR-Maceio
BR-Sao Paulo
BR-Cuiaba
BR-Porto Velho
BR-Boa Vista
BR-Manaus
BR-Eirunepe
BR-Rio Branco
BS-Nassau
BY-Minsk
BZ-Belize
EET
AST
CET
EET
AST
BOT
FNT
BRT
BRT
BRT
BRS
BRT
BRS
AMS
AMT
AMT
AMT
ACT
ACT
EST
EET
CST
Model 53i IP Phone User Guide
A-1
Time Zone Name
Time Zone Code
CA-Newfoundland
CA-Atlantic
CA-Eastern
CA-Saskatchewan
CA-Central
CA-Mountain
CA-Pacific
CA-Yukon
CH-Zurich
CK-Rarotonga
CL-Santiago
CL-Easter
CN-China
CO-Bogota
CR-Costa Rica
CU-Havana
CY-Nicosia
CZ-Prague
NST
AST
EST
EST
CST
MST
PST
PST
CET
CKS
CLS
EAS
CST
COS
CST
CST
EES
CET
DE-Berlin
DK-Copenhagen
DM-Dominica
DO-Santo Domingo
CET
CET
AST
AST
EE-Tallinn
ES-Madrid
ES-Canary
EET
CET
WET
FI-Helsinki
FJ-Fiji
FK-Stanley
FO-Faeroe
FR-Paris
EET
NZT
FKS
WET
CET
GB-London
GB-Belfast
GD-Grenada
GF-Cayenne
GI-Gibraltar
GP-Guadeloupe
GR-Athens
GS-South Georgia
GT-Guatemala
GU-Guam
GY-Guyana
GMT
GMT
AST
GFT
CET
AST
EET
GST
CST
CST
GYT
HK-Hong Kong
HN-Tegucigalpa
HR-Zagreb
HT-Port-au-Prince
HU-Budapest
HKS
CST
CET
EST
CET
IE-Dublin
IS-Reykjavik
IT-Rome
GMT
GMT
CET
A-2 Model 53i IP Phone User Guide
Time Zone Name
Time Zone Code
JM-Jamaica
JP-Tokyo
EST
JST
KY-Cayman
EST
LC-St Lucia
LI-Vaduz
LT-Vilnius
LU-Luxembourg
LV-Riga
AST
CET
EET
CET
EET
MC-Monaco
MD-Chisinau
MK-Skopje
MQ-Martinique
MS-Montserrat
MT-Malta
MX-Mexico City
MX-Cancun
MX-Merida
MX-Monterrey
MX-Mazatlan
MX-Chihuahua
MX-Hermosillo
MX-Tijuana
CET
EET
CET
AST
AST
CET
CST
CST
CST
CST
MST
MST
MST
PST
NI-Managua
NL-Amsterdam
NO-Oslo
NR-Nauru
NU-Niue
NZ-Auckland
NZ-Chatham
CST
CET
CET
NRT
NUT
NZS
CHA
PA-Panama
PE-Lima
PL-Warsaw
PR-Puerto Rico
PT-Lisbon
PT-Madeira
PT-Azores
PY-Asuncion
EST
PES
CET
AST
WET
WET
AZO
PYS
Model 53i IP Phone User Guide
A-3
Time Zone Name
Time Zone Code
RO-Bucharest
RU-Kaliningrad
RU-Moscow
RU-Samara
RU-Yekaterinburg
RU-Omsk
RU-Novosibirsk
RU-Krasnoyarsk
RU-Irkutsk
RU-Yakutsk
RU-Vladivostok
RU-Sakhalin
RU-Magadan
RU-Kamchatka
RU-Anadyr
EET
EET
MSK
SAM
YEK
OMS
NOV
KRA
IRK
YAK
VLA
SAK
MAG
PET
ANA
SE-Stockholm
SG-Singapore
SI-Ljubljana
SK-Bratislava
SM-San Marino
SR-Paramaribo
SV-El Salvador
CET
SGT
CET
CET
CET
SRT
CST
TR-Istanbul
TT-Port of Spain
TW-Taipei
EET
AST
CST
UA-Kiev
US-Eastern
US-Central
US-Mountain
US-Pacific
US-Alaska
US-Aleutian
US-Hawaii
UY-Montevideo
EET
EST
CST
MST
PST
AKS
HAS
HST
UYS
VA-Vatican
CET
YU-Belgrade
CET
A-4 Model 53i IP Phone User Guide
Warning!
Toll fraud is committed when individuals unlawfully gain access to a
customer’s telecommunication system. This is a criminal offense. Currently,
we do not know of any telecommunications system that is immune to this
type of criminal activity. 8x8, Inc. will not accept liability for any damages,
including long distance charges, which result from unauthorized and/or
unlawful use. Although 8x8, Inc. has designed security features into its
products and services, it is your sole responsibility to use the security
features and to establish security practices within your organization,
including training, security awareness, and call auditing to eliminate security
risks.
Notice
While every effort has been made to ensure accuracy, 8x8, Inc. will not be
liable for technical or editorial errors or omissions contained within this
documentation. The information contained in this documentation is subject
to change without notice.
This documentation may be used only in accordance with the terms of the
8x8, Inc. License Agreement.
If you’ve read this owner’s manual and consulted the online Troubleshooting
section at www.8x8.com and still have problems, please call
1-888-898-8733 for technical assistance.
www.8x8.com | 1.866.879.8647
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
