AVXMetallizedPolyFilm
A KYOCERA GROUP COMPANY
TPC
Metallized Polyester
Film Dielectric Capacitors
Contents
Comparative Table of the Plastic Film Dielectric Characteristics . . . . . . . . . . . . . 2
Characteristics of the Metallized Polyester Film Dielectric Capacitors. . . . . . . 3
Type Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
How To Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Types & Taping
Radial Leads
BF (CPM-83) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
BH (CPM-N) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
BT (CPM-85) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
BG (CPM-85) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
BC/BD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
BO (CPM-50) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
S4 (CPM-13) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Axial Leads
S8 (CPM-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
SH (CPM-8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
S9 (CPM-72) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
SG (CPM-72) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Guide for Customer’s Specific Requirements
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Normalized Series and Associated Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
As we are anxious that our customers should benefit from the latest developments in the technology and standards,
AVX reserves the right to modify the characteristics published in this brochure.
NOTICE: Specifications are subject to change without notice. Contact your nearest AVX Sales Office for the latest specifications. All statements,
information and data given herein are believed to be accurate and reliable, but are presented without guarantee, warranty, or responsibility of any
kind, expressed or implied. Statements or suggestions concerning possible use of our products are made without representation or warranty that
any such use is free of patent infringement and are not recommendations to infringe any patent. The user should not assume that all safety measures are indicated or that other measures may not be required. Specifications are typical and may not apply to all applications.
TPC
1
Metallized Polyester
Film Dielectric Capacitors
Characteristics
INTRODUCTION
TECHNOLOGY EMPLOYED
The intrinsic characteristics of polyester as a dielectric are:
• dielectric permittivity
• dielectric strength
• range of working temperatures (-55°C to +100°C and up
to 125°C for high temperature version).
They are particularly intended for use in bonding, chopping
and other applications where the AC component is weak in
comparison with the continuous nominal voltage.
The outstanding characteristic of the metallized film technology is the self-healing by evaporation of the metallized area
round a dielectric fault, thus allowing the electrical insulation
of the fault in the film.
PLASTIC FILM DIELECTRIC CHARACTERISTICS
Characteristics
Polypropylene
Polycarbonate
Polystyrene
Polyester
Dielectric Constant
(25°C / 50 Hz)
2.2
2.8
2.5
3.2
Minimum Thickness
(in micron)
4
2
6
1
Maximum Working Temperature
(°C)
100
125
85
125
Can Be Metallized
yes
yes
no
yes
Tangent Of Loss Angle
(25°C / 1000 Hz)
2
8
2
50
Insulation Resistance
(GΩ x µF)
100
50
100
50
< 0.01
0.3
0.1
0.2
Temperature Coefficient
(ppm / °C)
-300
±100
-120
+1200
Dielectric Strength
(kV / mm)
350
180
150
250
Water Absorption
% in weight
2
TPC
Metallized Polyester
Film Dielectric Capacitors
Characteristics
GENERAL ELECTRIC CHARACTERISTICS
Applicable specifications:
• Capacitance measurement between terminals:
– General specifications:
CEI 384-1/CECC 30.000/NFC 83.100
– Sectional specifications:
CEI 384-2/CECC 30.400/ NFC 83.151
Measurement frequency:
1 kHz (±0.1 kHz) ➝ CR ≤ 1 µF
100 Hz (±5 Hz)
➝ CR > 1 µF
• Measurement voltage
1 – Nominal capacitance (CR) and capacitance
tolerances
Nominal capacitance values are based on the E6 and E12
series (see tables of standard values on inside back cover)
and their multiples and decimals with the associated
tolerances are shown in the table below.
Peak value of applied voltage should not exceed, at 1kHz,
3% of the nominal voltage VR and at 100 Hz, 20% of the
nominal value with a maximum of 100 V (70 VRMS).
Tolerances
Values
Code
5%
J
10%
K
20%
M
TYPICAL CURVES
∆ C (%)
C
∆C (%)
C
2
5
kHz
100
kHz
10
z
1 kH
0
100
1
0
Hz
–1
–5
–2
T (°C)
–3
–4
0.05 0.1
1
10
100 F (kHz)
T (°C) : room temperat re
– 55
0
50
85
T: Room Temperature
TPC
3
Metallized Polyester
Film Dielectric Capacitors
Characteristics
2 - DC nominal voltage (VR -)
The nominal voltage is the maximum DC voltage that may be
applied to the capacitor at a temperature of 85°C.
Standard values: the standard values of the nominal voltage
comply with the R5 basic series standard numbers in the ISO
R3 recommendation (25-40-63-100-160) and their multiples
and decimals.
3 - AC nominal voltage (VR ~)
The frequency is 50 Hz unless a higher frequency is specified.
4 - Category voltage (VC)
The voltage category is the voltage that can be applied to a
capacitor used at the maximum temperature of its category.
This voltage is specified in the data sheet or detailed specification for each product.
5 - Test voltage (VE)
The test voltage applied between output terminals is a DC
voltage equal to:
– 1.4 VR- for 1 minute for Class 2 capacitors (general use)
– 1.6 VR- for 1 minute for Class 1 capacitors (long life)
6 - Tangent of loss angle (D.F.)
Measurement conditions:
– identical to those for the measurement of capacitance
between terminals.
Requirements:
– the tangent of loss angle should not exceed the values
shown in the table below.
D.F.
Measurement
frequency
Capacitance
Performance
category
1
Performance
category
2
1 kHz
CR ≤ 1 µF
≤ 0.8%
≤ 1.0%
100 Hz
CR > 1 µF
≤ 1%
≤ 1.0%
TYPICAL CURVES
D.F.
D.F.
1.0%
100 k
Hz
1.5%
10
z
1.0%
0.5%
10
0.5%
0.1%
–50
1
10
100 F (kHz)
T (°C) = room temperature
T: Room Temperature
4
TPC
kH
1k
H
0H z
z
0
50
T (°C)
85
Metallized Polyester
Film Dielectric Capacitors
Characteristics
7 - Insulation resistance (IR)
Nominal
Voltage
VR- < 10 V
10 V ≤ VR- < 100 V
100 V ≤ VR- < 500 V
500 V ≤ VR-
Measurement conditions:
• The opposite table gives the measurement voltages in
relation to the nominal voltage of the capacitor, unless
otherwise specified.
Requirements:
• The insulation resistance should meet the values shown in
the table below at 20°C.
CR ≤ 0.33 µF
Measuring
Points
CR > 0.33 µF
IR min (GΩ)
Performance
Class
1
Between
Terminals
Measurement
Voltage
VR ± 10%
10V ± 1 V
100V ± 15 V
500V ± 50 V
IR x C
R
Performance
Class
2
min (MΩ x µF)
Performance
Class
1
Performance
Class
2
VR≤ 100 V
VR> 100 V
VR≤ 100 V
VR> 100 V
VR≤ 100 V
VR> 100 V
VR≤ 100 V
VR> 100 V
15
30
3.75
7.5
5,000
10,000
1,250
2,500
Between
Terminals
and Ground
≥ 30,000 MΩ
TYPICAL CURVE
8 - Voltage gradient (dv/dt)R
Insulation resistance vs. temperature IR = f (T) °C.
• Pulses under VR
Example:
IR (MΩ X µF)
105
0.9 V R
104
(dv/dt) R
103
102
T (°C)
– 50
0
+ 50
0.1 V R
+ 100
0
t2
t1
t
(dv/dt) R = 0.8 V R/t2 – t1
• Pulses under VA
maximum voltage gradients of the capacitor
under VA:
(dv/dt)
Amax
TPC
=
VR
x (dv/dt)
VA
Rmax
5
Metallized Polyester
Film Dielectric Capacitors
Type Selection Guide
Type
Nominal Voltage
Presentation
TPC
UTE
VR-(V)
VR~(V)
63 ... 400
40 ... 200
Capacitance
Range (CR)
±5% (E6 - E12)
1 nF ... 2.2 µF
C83151
±5% (E6 - E12)
63 ... 400
40 ... 200
1 nF ... 2.2 µF
C83151
63 ... 630
40 ... 220
1 nF ... 22 µF
63 ...1,000
40 ... 250
1 nF ... 22 µF
250
–
0.47 µF ... 2.2 µF
C83151
Radial
Leads
CPM85
5.08 (0.200)
±10% (E6 - E12)
CPM85
BT
5.08 (0.200)
±10% (E6 - E12)
CPM-N
BH
Lead
Spacing
mm (inches)
CPM-83
BF
Tolerance
on CR
(Series)
BG
C83151
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
7.5 (0.295)
10.0 (0.394)
15.0 (0.591)
22.5 (0.886)
27.5 (1.083)
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
7.5
10.0
15.0
22.5
27.5
±5%
(0.295)
(0.394)
(0.591)
(0.886)
(1.083)
15.0 (0.591)
BC / BD
±10%
CPM50
BO
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
63 ... 400
40 ... 200
1 nF ... 10 µF
±5% (E6 - E12) 7.62 (0.300)
10.16 (0.400)
±10% (E6 - E12)
15.24 (0.600)
±20% (E6 - E12)
27.94 (1.100)
63 ... 400
40 ... 200
1 nF ... 10 µF
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
63 ... 1,000
40 ... 250
1 nF ... 22 µF
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
100 ... 630
40 ... 220
1 nF ... 10 µF
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
63 ... 1,000
40 ... 250
1 nF ... 22 µF
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
CPM13
C83151
CPM8
S8
C83151
CPM8
SH
C83151
Axial
Leads
CPM72
S9
C83151
CPM72
SG
C83151
630 ... 10,000
100 pF ... 1.5 µF
ST
6
(0.295)
(0.394)
(0.591)
(1.083)
1 nF ... 22 µF
C83151
S4
7.5
10.0
15.0
27.5
25 ... 200
40 ... 400
TPC
±5% (E6 - E12)
±10% (E6 - E12)
±20% (E6 - E12)
Metallized Polyester
Film Dielectric Capacitors
HOW TO ORDER
Example of an order: how to order a CPM85 100 nF ±10% 100 V.
BT07
4
E
Identification
Code
Dielectric Class
4
Voltage Code
C = 25/40 V
D = 50/63 V
E = 100 V
F = 160/200 V
G = 250 V
H = 275/300 V
I = 400 V
J = 500 V
K = 600/630 V
L = 1000 V
M = 1600 V
N = 2000 V
P = 2500 V
Q = 3000 V
R = 4000 V
S = 5000 V
T = 6000/6300 V
U = 8000 V
V = 10 kV
Radial Leads
CPM83 BF 01
CPM83 BF 02
CPM83 BF 05
CPM83 BF 06
CPM83 BF 07
CPM-N BH 01
CPM-N BH 02
CPM-N BH 05
CPM-N BH 06
CPM-N BH 07
CPM85 BT 07
CPM85 BT 10
CPM85 BT 15
CPM85 BT 22
CPM85 BT 27
CPM85 BG 07
CPM85 BG 10
CPM85 BG 15
CPM85 BG 22
CPM85 BG 27
–
BC 15
–
BD 15
CPM50 BO 07
CPM50 BO 10
CPM50 BO 15
CPM50 BO 27
CPM13 S4 07
CPM13 S4 10
CPM13 S4 15
CPM13 S4 27
Axial Leads
CPM8
S8 10
CPM8
S8 14
CPM8
S8 18
CPM8
S8 31
CPM8
SH 13
CPM8
SH 18
CPM8
SH 25
CPM8
SH 30
CPM8
SH 40
CPM72 S9 10
CPM72 S9 14
CPM72 S9 18
CPM72 S9 27
CPM72 S9 31
CPM72 SG 13
CPM72 SG 18
CPM72 SG 25
CPM72 SG 30
CPM72 SG 40
–
ST 22
–
ST 36
0104
K
Capacitance (EIA code)
Tolerance Code
Capacitance expressed by 2
J = ±5%
significant figures
K = ±10%
1st digit: 0 (zero)
M = ±20%
2nd and 3rd digit: the 2
significant figures of the
capacitance value
4th digit:
- for values ≥ 10 pF and ≤ 990 µF:
the number of zeros to be added
to the capacitance values
- for values ≥ 1 pF and ≤ 9.9 pF:
the numerical 9 signifying that
the capacitance value is to be
multiplied by 0.1
- for values < 1 pF: the numerical
8 signifying that the capacitance
value is to be multiplied by 0.01
Example:
1000 pF = 0102
8.2 pF = 0829
0.47 pF = 0478
Capacitance expressed by 3
significant figures
1st, 2nd and 3rd digit:
the 3 significant figures of the
capacitance value
4th digit:
- for values > 100 pF and ≤ 999 µF:
the number of zeros to be added
to the capacitance values
- for values > 10 pF and < 100 pF:
the numerical 9 signifying that the
capacitance value is to be
multiplied by 0.1
- for values > 1 pF and < 10 pF:
the numerical 8 signifying that the
capacitance value is to be multiplied by 0.1
Example:
196 pF = 1960
47.2 pF = 4729
8.28 pF = 8288
TPC
––
Suffix
DA - DB - DC - DD: lead spacing
5.08 mm taped on reel or
ammopack
EN
Radial types:
lead spacing 7.5/10/15 mm
taped on reel H=16.5 mm
Axial type: (SG series only)
Ammopack
EP: Taped on reel H=18.5 mm
(only for BG type)
GA or GB: standard axial taped
(S8, S9, ST types)
– – Bulk
7
BF 01/02/07/06/05/04: Radial Leads
CPM-83 — (pitch = 5.08mm / 0.200 inches)
GENERAL DESCRIPTION
• Dielectric: Metallized polyester film
(polyethylene teraphtalate)
• Stacked-film
• Leads: Radial tin-plated wire
• Protection: Plastic case (UL94: V-O) / Epoxy resin
• Marking: Logo
Nominal Capacitance
Tolerance (EIA)
DC Nominal Voltage
Example: T 100 nK 63
• Delivery Mode: Bulk
Taped (reel or ammopack)
STANDARDIZATION
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
APPLICATIONS
Complies with special specification:
CECC 30401-063
e
• Commodity Product:
• Supply decoupling
• Filter
• Integrators
• Treatment of analog signals
• Rejection of line perturbations etc.
L max
H max
e max
ø ± 0.02
01
02
07
06
05
04
7.50 (0.295)
7.50 (0.295)
7.50 (0.295)
7.50 (0.295)
7.50 (0.295)
7.50 (0.295)
6.50 (0.256)
8.00 (0.315)
8.00 (0.315)
9.60 (0.378)
12.0 (0.472)
13.0 (0.512)
2.50 (0.098)
3.20 (0.126)
5.00 (0.197)
6.00 (0.236)
6.00 (0.236)
7.50 (0.295)
0.50 (0.020)
0.50 (0.020)
0.50 (0.020)
0.50 (0.020)
0.50 (0.020)
0.50 (0.020)
H
millimeters (inches)
Case
4.10 (0.161)
±0.5 (0.020)
DIMENSIONS
0.4 (0.016) min
L
(0.024)
5.08 (0.200) -0.6
-0.1 (0.004)
*L dimension measured 3mm above base of case
HOW TO ORDER
BF01
4
D
0104
K
--
Type
Class
Voltage
Tolerance
Suffix
PET
63V
Capacitance
Value
EIA code
±10%
BF 01/02/07/06/05/04: Radial Leads
CPM-83 — (pitch = 5.08mm / 0.200 inches)
PERFORMANCE CHARACTERISTICS
Climatic Category
Capacitance Range
Tolerances on CR
55/100/56 Performance Class 2
CR 1nF to 2.2µF (E12)
±5%; ±10%
(other values on request)
VR_ 63/100/250/400V
VR~ 40/ 63/160/200V
Vc = 0.8VR- at 100°C
Ve = 1.6VR-/2s at 25°C
Nominal Voltages
Category Voltage
Test Voltage
• Tangent of Loss Angle: D.F.
• Insulation Resistance: IR
Measurement
Frequency
Capacitance
DF:
Performance
Category 2
1kHz
100 Hz
CR ≤ 1µF
CR> 1µF
≤ 1.0%
≤ 1.0%
Measuring
Points
CR <= 0.33µF
IR * CR min
(MΩ * µF)
Performance Class
Performance Class
2
2
VRVRVRVR≤ 100V
> 100V
≤ 100V
> 100V
3.75
7.5
1.25
2.5
≥ 30,000 MΩ
IR min (GΩ)
Between
Terminals
Between
Terminals and
Ground
VR(dv/dt)R max
PACKAGING
Avisert
19.5 ± 0.50
(0.768 ± 0.020)
12.0 (0.472)
±1.0 (0.039)
4.0 (0.157)
±0.3 (0.012)
12.7 (0.500)
±0.2 (0.008)
5.08 (0.200)
Thermoadhesive tape
(Other sizes according to standard CEI : 286-2)
Dimensions: millimeters (inches)
18.0 (0.709)
±0.5 (0.020)
H
12.7 (0.500)
±1.0 (0.039)
63
38
100
40
250
110
400
270
millimeters (inches)
Panasert
16.5 ± 0.30
(0.65 ± 0.012)
H
CR > 0.33µF
Case
Reel
Suffix DB
x
panasert
01
02
07
06
05
04
2500
1800
1200
900
900
750
DD
avisert
Quantity
Ammopack
DA
DC
panasert
avisert
2500
2000
1250
1100
1100
750
Bulk
USA Std.
1000
1000
1000
1000
1000
1000
-Europe /
Asia
Std.
5000
3800
2500
1500
1500
1000
BF 01/02/07/06/05/04: Radial Leads
CPM-83 — (pitch = 5.08mm / 0.200 inches)
CAPACITANCE VALUE (CR) and NOMINAL VOLTAGES (VR)
Capacitance
Range
(CR)
1,000 pF
1,200
1,500
1,800
2,200 pF
2,700
3,300
3,900
4,700 pF
5,600
6,800
8,200
10,000 pF
12,000
15,000
18,000
22,000
27,000
33,000
39,000
47,000 pF
56,000
68,000
82,000
100 nF
120
150
180
220 nF
270
330
390
470 nF
560
680
820
1 µF
1.5 µF
2.2 µF
Reference
BF
VR- / VR~ (V)
63/40 (voltage code: D) 100/63 (voltage code: E) 250/160 (voltage code: G) 400/200 (voltage code: I)
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF02
BF02
BF07/***BF02
BF07/***BF02
BF07
BF07
BF07
BF07
BF05*
BF05**
*Upon request - no change
**Upon request & only available 50 V (UR) - no change
***Case size reduction: BF07 to BF02 - New
BF04/BF06: New
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF07/***BF02
BF07/***BF02
BF07
BF07
BF07
BF07
BF05*
BF05*
BF05*
BF05
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF02
BF02
BF02
BF07
BF07
BF07
BF07
BF06
BF06
BF04
BF04
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF01
BF02
BF02
BF02
BF02
BF07
BF07
BF06
BF06
BF04
BF04
BF04
BF04
BH 01/02/05/06/07
CPM-N — 5.08 Radial Leads 63/100/250/400 VAPPLICATIONS
Schematic Cross Section
Non-inductive, self-healing, metallized polyester film capacitor.
Insulated* thermoplastic casing, epoxy resin sealed with
stand-offs*. Radial connections with a lead spacing of 5.08
mm.
Schoop
Metallized film
* Flame retardant case according to UL 94 VO.
e
Some examples of use:
Supply decoupling, filter, integrators, treatment of analog
signals, rejection of line perturbations, etc… Specifically
designed for working in severe environmental conditions
such as automotive applications: engine control, multiplexing
system, etc.
H
0.4 (0.016). min
L
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ list:
Complies with type CPM-N
RAQ2 production, equivalent AQAP-4 of NATO
5.08 (0.020)
4.1 (0.161)
± 0.5 (0.020)
STANDARDIZATION
+0.6 (0.024)
-0.1 (0.004)
DIMENSIONS:
Case L max.
millimeters (inches)
H max.
e max. ø ± 0.02 Observations
1nF ≤ CR ≤ 220nF
01
7.5 (0.295) 6.5 (0.256) 2.5 (0.098) 0.5 (0.020)
02
7.5 (0.295) 8.0 (0.315) 3.2 (0.126) 0.5 (0.020) 5.6nF ≤ CR ≤ 330nF
05
7.5 (0.295) 12.0 (0.472) 6.0 (0.236) 0.5 (0.020) 39nF ≤ CR ≤ 2.2µF
06
7.5 (0.295) 9.6 (0.378) 6.0 (0.236) 0.5 (0.020) 18nF ≤ CR ≤ 100nF
07
7.5 (0.295) 8.0 (0.315) 5.0 (0.197) 0.5 (0.020) 8.2nF ≤ CR ≤ 1µF
HOW TO ORDER
BH 01
4
D
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
PERFORMANCE CHARACTERISTICS
MARKING
Climatic category:
Capacitance range:
Tolerances on CR:
D 104 K E 49
DC nominal voltage
Nominal capacitance (EIA code)
Tolerance (EIA code)
Logo
Lot number
Example above: 63 VDC , 100nF, ±10%
55/125/56 - Performance Class 2
CR 1 nF to 2.2 µF (E12)
±5%, ±10%
(other values on request)
Nominal voltages:
VR– 63/100/250/400 V
VR~ 40/63/160/200 V
Category voltage:
VC = 0.8 VR- at 100°C/0.5 VRat 125°C
Test voltage:
Ve = 1.6 VR-/2 s at 25°C
Tangent of loss angle: D.F. (see page 4)
Insulation resistance: IR (see page 5)
Max. voltage gradient: (dv/dt)R (see page 5)
Life test:
∆C/C ≤ 5% after 125°C/1000
h/0.5 VRThermal shock:
-55/+125°C/time cycle 1hr/500
cycles ∆C/C ≤ 10%, D.F. 1kHz ≤ 1%
Humidity test:
85°C/85% R.H./1000 h ∆C/C ≤ 10%
10
TPC
VR-
63
100
250
400
(dv/dt) R max
38
40
110
270
BH 01/02/05/06/07
CAPACITANCE VALUES (CR) AND
NOMINAL VOLTAGES (VR) vs CASE SIZE
Capacitance
Range
(CR)
Reference
BH
VR-/VR~
63/40
100/63
250/160
400/200
1,000 pF
1,200
1,500
1,800
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
2,200 pF
2,700
3,300
3,900
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
4,700 pF
5,600
6,800
8,200
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH02
BH02
BH07
10,000 pF
12,000
15,000
18,000
22,000
27,000
33,000
39,000
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01/BH02*
BH02
BH02
BH02
BH07
BH07
BH07
BH07
BH06/BH05*
BH06/BH05*
BH06/BH05*
BH06/BH05*
BH05
47,000 pF
56,000
68,000
82,000
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH01
BH07
BH07
BH07
BH06/BH05*
BH05
100 nF
120
150
180
BH01
BH01
BH01
BH01
BH01
BH01/BH07*
BH01/BH07*
BH02/BH07*
BH06/BH05*
BH05
BH05
220 nF
270
330
390
BH01/BH02*
BH02
BH02
BH07
BH02/BH07*
BH07
BH07
BH07/BH05*
470 nF
560
680
820
BH07
BH07
BH07/BH06*
BH07/BH06*
BH05
BH05
BH05
BH05
1 µF
1.5 µF
2.2 µF
BH07/BH06*
BH05
BH05**
BH05
** (VR = 50 V)
* Upon request
TPC
11
BF 01/02/05/06/07
BH 01/02/05/06/07
CHARACTERISTICS CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
100
10
1
– 4,7
nF
nF
1
nF
– 22
nF
– 47
0 nF
– 10
0 nF
– 22
0 nF
– 47
µF
– 1
0.1
µF
– 1.5
0.01
– 10
0.1
10
100
ƒ (MHz)
Nominal RMS voltage vs. frequency (room temperature) allowing a 10°C increase of the external temperature of the box.
Vrms max.
Vrms max.
103
103
Cases VR – : 100 V
Cases VR – : 63 V
102
63
102
10 nF
22 nF
47 nF
100 nF
220 nF
470 nF
40
22 nF
47 nF
100 nF
220 nF
470 nF
1 µF
1.5 µF
101
101
102
103
104
105
101
101
106
ƒ (Hz)
Vrms max.
Vrms max.
103
103
102
Cases VR – : 250 V
103
Cases V R
104
–
105
106
ƒ (Hz)
: 400 V
200
150
102
2.2 nF
4.7 nF
10 nF
22 nF
47 nF
100 nF
101
101
12
1 nF
2.2 nF
4.7 nF
10 nF
22 nF
47 nF
102
101
102
103
104
105
106
ƒ (Hz)
101
TPC
102
103
104
105
106
ƒ (Hz)
BF 01/02/05/06/07
BH 01/02/05/06/07
5.08 – Radial Leads — Taping on Reel for Automatic Insertion
CHARACTERISTICS OF THE REEL –
Suffixes to be used (see page 7)
millimeters (inches)
12.7 (0.500)
± 1.0 (0.039)
Taping Suffixes
DB
DC
DD
16.5 ± 0.3
(0.650 ± 0.012)
19.5 ± 0.5
(0.768 ± 0.020)
REEL
–
PANASERT
–
AVISERT
AMMOPACK
PANASERT
–
AVISERT
–
Ø
12 (0.472)
± 1.0 (0.039)
H
H
4 (0.157)
± 0.3 (0.012)
18 (0.709)
± 0.5 (0.020)
DA
12.7 (0.500)
± 0.2 (0.008)
5.08 (0.200)
Thermoadhesive tape m
(Other sizes according to standard CEI : 286-2)
Dimensions millimeters (inches)
PACKAGING
01
02
05
06
07
Quantity
Reel
2500
1800
900
900
1200
Case
E (ext.)
01
02/05/06/07
43 (1.693)
48 (1.929)
D
Ammopack
E
2500
2000
1100
1100
1250
Ø 31 (1.220)
Case
Bulk
USA Std.
Europe &
Asia Std.
1000
1000
1000
1000
1000
5000
3800
1500
1500
2500
295
(11.614)
335
(13.189)
50
(1.968)
Maximum outer dimensions
of the case millimeters (inches)
TPC
13
BT 07/10/15/22/27
CPM-85 — 7.5/10/15/22.5/27.5 Radial Leads
63/100/160/250/400/630 VSchematic Cross Section
APPLICATIONS
Schoop
Non-inductive, self-healing, metallized polyester film capacitor.
Insulated* thermoplastic casing, epoxy resin sealed with
stand-offs*. Radial connections.
Metallized film
e
* Flame retardant resin and case according to UL 94 VO.
Some examples of use:
Supply decoupling, filter, integrators, treatment of analog
signals, rejection of line perturbations, etc.
+ 0 (0.000)
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ list:
Complies with type CPM85 – CPM-R
6 (0.236) – 1 (0.039)
STANDARDIZATION
H
0.4 (0.016). min
L
LS
---- for case* in table page 15
DIMENSIONS:
Size
Code
07
10
15
22
27
millimeters (inches)
L max.
H max.
e max.
LS ±0.4
+10%
ø -0.05
9.25 ... 10.1
(0.364 ... 0.398)
12.5
(0.492)
17.5
(0.689)
26.25
(1.033)
31.25
(1.230)
8.0 ... 12.0
(0.315 ... 0.472)
9.0 ... 13.5
(0.354 ... 0.531)
10.5 ... 14.5
(0.413 ... 0.571)
15.0 ... 19.5
(0.591 ... 0.768)
19.5 ... 30.0
(0.768 ... 1.181)
3.25 ... 6.0
(0.128 ... 0.236)
4.0 / 5.0
(0.157 / 0.197)
5.0 ... 8.5
(0.197 ... 0.335)
7.5 / 10.0
(0.295 / 0.394)
10.0 ... 17.5
(0.394 ... 0.689)
7.5
(0.295)
10.0
(0.394)
15.0
(0.591)
22.5
(0.886)
27.5
(1.083)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
Observations
1nF ≤ C ≤ 1µF
R
4.7nF ≤ C ≤ 470nF
R
33nF ≤ C ≤ 2.2µF
R
100nF ≤ C ≤ 6.8µF
R
330nF ≤ C ≤ 22µF
R
HOW TO ORDER
BT 10
4
G
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 27
PERFORMANCE CHARACTERISTICS
Climatic category:
Capacitance range:
Tolerances on CR:
55/100/56 - Performance Class 1
CR 1 nF to 2.2 µF (E6)
±5%, ±10%, ±20%
(other values on request)
Nominal voltages:
VR– 63/100/160/250/400/630 V
VR~ 40/63/80/160/200/220 V
Category voltage:
VC = 0.8 VR- at 100°C
Test voltage:
Ve = 1.6 VR-/2 s at 25°C
Tangent of loss angle: D.F. (see page 4)
Insulation resistance: IR (see page 5)
Max. voltage gradient: (dv/dt)R (see page 5)
14
Size
VR-
07
10
15
22
27
63
100
35
18
12
4
3
50
28
15
5
4
dv/dt V/µs
160 250 400
–
30
20
–
6
72
45
30
9
7
150
90
55
12
10
MARKING
Logo
Nominal capacitance
TPC
Tolerance (EIA code)
DC nominal voltage
630
300
180
100
20
15
BT 07/10/15/22/27
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
S
i
z
e
C
a
s
e
1
2
07
C
D
EO
10
4
6
7
15
IO
8
9
11
22
12
13
16
17*
27
18*
19*
Reference
BT
VR-/VR~
100/63
160/80
250/160
400/200
Range of Capacitance (CR min. ... max.)
DIMENSIONS:
millimeters (inches)
Max
L
Max
H
Max
e
+10%
-0.05
Ø
LS
±0.4
9.25
(0.364)
10.1
(0.398)
10.1
(0.398)
10.1
(0.398)
8.0
(0.315)
10.0
(0.394)
11.0
(0.433)
12.0
(0.472)
3.25
(0.128)
5.0
(0.197)
5.0
(0.197)
6.0
(0.236)
0.6
(0.024)
0.6
(0.024)
0.6
(0.024)
0.6
(0.024)
7.5
(0.295)
12.5
(0.492)
12.5
(0.492)
9.0
(0.354)
10.0
(0.394)
4.0
(0.157)
5.0
(0.197)
0.6
(0.024)
0.6
(0.024)
10.0
(0.394)
17.5
(0.689)
17.5
(0.689)
17.5
(0.689)
17.5
(0.689)
17.5
(0.689)
10.5
(0.413)
13.5
(0.531)
12.0
(0.472)
13.5
(0.531)
14.5
(0.571)
5.0
(0.197)
5.0
(0.197)
6.0
(0.236)
6.25
(0.246)
8.5
(0.335)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
15.0
(0.591)
26.25
(1.033)
26.25
(1.033)
26.25
(1.033)
15.0
(0.591)
17.5
(0.689)
19.5
(0.768)
7.5
(0.295)
7.5
(0.295)
10.0
(0.394)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
22.5
(0.886)
31.25
(1.230)
31.25
(1.230)
31.25
(1.230)
31.25
(1.230)
19.5
(0.768)
22.5
(0.886)
26.0
(1.024)
30.0
(1.181)
10.0
(0.394)
12.5
(0.492)
15.0
(0.591)
17.5
(0.689)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
27.5
(1.083)
63/40
630/220
68 nF ... 220 nF
22 nF ... 150 nF
–
6.8 nF ... 47 nF
1 nF ... 22 nF
1 nF ... 3.3 nF
330 nF/470 nF
220 nF/330 nF
–
68 nF ... 100 nF
–
4.7 nF/6.8 nF
680 nF
–
–
–
–
10 nF
1µF
–
–
150 nF
33 nF ... 47 nF
15 nF
33 nF ... 100 nF
6.8 nF ... 33 nF
–
220 nF ... 470 nF 100 nF ... 220 nF 100 nF ... 220 nF
–
–
–
–
47 nF
4.7 nF/22 nF
680 nF ... 1 µF
150 nF ... 1 µF
330 nF/470 nF
68 nF ... 220 nF
47 nF/68 nF
33 nF
–
–
–
–
100 nF
–
2.2 µF
–
680 nF
330 nF
–
–
–
–
1 µF
390 nF
150 nF
47 nF
–
–
2.2 µF
–
–
68 nF
–
1.5 µF
–
470 nF/680 nF
220 nF
100 nF
3.3 µF
2.2 µF
–
–
330 nF
150 nF
4.7 µF/6.8 µF
3.3 µF
–
1 µF/1.5 µF
470 nF
220 nF
6.8 µF
4.7 µF
3.3 µF
1.5 µF
470 nF 680 nF
330 nF
10 µF
6.8 µF
–
2.2 µF
1 µF
470 nF
15 µF
10 µF
–
3.3 µF
1.5 µF
680 nF
22 µF
–
–
4.7 µF
2.2 µF
1 µF
TPC
15
BT 07/10/15/22/27
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature)
Z
(Ω)
Z
(Ω)
Size : 0.7
Size : 10
100
10
10
1
–
–
–
1
–
0.1
–
–
– 22 nF
– 47 nF
F
– 100 n
Z
(Ω)
1
F
– 220 n
0.1
F
– 470 n
– 1 µF
0.01
10
0.01
– 10 nF
0.1
100
ƒ (MHz)
47
nF
47
nF
4.
7
nF
nF
nF
nF
nF
1
10
100
ƒ (MHz)
Z
(Ω)
Size : 15
Size : 22
100
10
10
1
1
µF
Size : 27
100
10
1
0.1
nF
TPC
0
– 33
0.1
µF
– 1
µF
– 2.2
.7 µF
– 4
0.01
µF
– 10
µF
– 22
0.01
10
ƒ (MHz)
µF
0.1
.8
Z
(Ω)
0.01
0.01
.7
µF
100
ƒ (MHz)
–6
2.2
10
nF
00
–1
nF
20
–2
nF
70
–4
µF
– 1 µF
.2
–2
0.1
–4
–
1
nF
– 33
0 nF
– 10
0 nF
– 22
0 nF
– 47
µF
– 1
0.1
16
0
22
0
0
0.001
0.1
100
0.01
0.1
–
10
22
10
10
ƒ (MHz)
BT 07/10/15/22/27
CHARACTERISTIC CURVES
Nominal RMS voltage vs. frequency (room temperature) allowing a 10°C increase of the external temperature of the box.
Vrmsmax.
Vrmsmax.
103
103
Cases V R – : 63 V
Cases V R – : 250 V
160
102
102
40
101
22 nF
47 nF
100 nF
220 nF
470 nF
1 µF
2.2 µF
4.7 µF
1
10
100 nF
220 nF
470 nF
1 µF
2.2 µF
4.7 µF
101
102
103
104
105
106
101
ƒ (Hz)
Vrmsmax.
103
104
105
106
ƒ (Hz)
103
103
102
Vrmsmax.
Cases V R – : 400 V
Cases V R – : 100 V
200
102
102
63
22 nF
47 nF
100 nF
220 nF
470 nF
1 µF
2.2 µF
4.7 µF
10 µF
101
101
102
103
104
105
22 nF
47 nF
100 nF
220 nF
470 nF
1 µF
2.2 µF
101
101
106
102
103
104
106
105
ƒ (Hz)
ƒ (Hz)
Vrms max.
Vrms max.
103
103
Cases V R – : 160 V
Cases V R – : 630 V
220
102
102
100 nF
220 nF
470 nF
1 µF
3.3 µF
101
101
102
103
104
105
4,7 nF
10 nF
22 nF
47 nF
100 nF
220 nF
470 nF
1 µF
101
106
ƒ (Hz)
TPC
101
102
103
104
105
106
ƒ (Hz)
17
BG 07/10/15/22/27
CPM-85 – 7.5/10/15/22.5/27.5
Boxed Metallized Polyester Capacitor
APPLICATIONS
Non-inductive, self-healing, metallized polyester film capacitor.
Insulated* thermoplastic casing, epoxy resin sealed with
stand-offs*. Radial connections.
L
e
* Flame retardant resin and case according to UL 94 VO .
Some examples of use:
Supply decoupling, filter, integrators, treatment of analogsignals, rejection of line perturbations, etc.
H
Max
6.1 (0.024)
STANDARDIZATION
millimeters (inches)
Lead Spacing (LS)
Diameter Ø
7.5 (0.295)
MARKING
Logo Capacitance
LS ±0.4
(0.016)
d
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ list:
Complies with type CPM85 – CPM-R
0.6 (0.024)
0.6(1)
10 (0.394)
Voltage
Tolerance
> 10 (0.394)
(0.024) / 0.8 (0.031)
0.8 (0.031)
(1): 0.6 (0.024) for capacitors with e ≤ 6 (0.024)
PERFORMANCE CHARACTERISTICS
Protection:
Temperature range:
Plastic casing, epoxy resin
sealed flame retardant case
(UL 94 VO)
-55°C to +100°C with voltage
derating of 1.25%/°C between
85°C and 100°C
55/100/56
63 VDC to 1000 VDC
1 nF to 22 µF
±5%, ±10%, ±20%
1.6 Vn/2 s
Climatic category:
Voltage range:
Capacitance range:
Tolerances on CR:
Test voltage:
Insulation resistance:
Measurement condition:
Temperature:
25°C ± 5°C
Duration:
1 minute
Measurement Voltage: 100 V for Vn ≥ 100 V
50 V for Vn < 100 V
Requirements:
For Un ≤ 100 V:
C
C
C
C
For Un > 100 V:
≤ 0.33 µF ≥ 15,000 MΩ
> 0.33 µF ≥ 5,000 S
≤ 0.33 µF ≥ 30,000 MΩ
> 0.33 µF ≥ 10,000 S
Tangent of loss angle:
LIMIT VALUES
C ≤ 0.1 µF
1 kHz
8x
10 kHz
15 x 10-3
100 Hz
30 x 10-3
0.1 µF < C ≤ 1 µF
10-3
8x
10-3
C > 1 µF
10 x 10-3
15 x 10-3
HOW TO ORDER
BG 10
4
G
0104
K
––
Type
Pitch 10mm = 10
Pitch 15mm = 15
Pitch 22.5mm = 22
Pitch 27.5mm = 27
Class
Voltage
Capacitance Value
Tolerance
Suffix
18
TPC
BG 07/10/15/22/27
Range
millimeters (inches)
L
e
H
Max
6.1 (0.024)
LS ±0.4
(0.016)
d
Capacitance
0.01
0.01
0.015
0.015
0.022
0.022
0.033
0.033
0.047
0.047
0.047
0.068
0.068
0.068
0.1
0.1
0.1
0.15
0.15
0.15
0.22
0.22
0.22
0.33
0.33
0.33
0.47
0.47
0.47
0.68
0.68
0.68
1
1
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
22
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
e
63 V DC / 40 V AC
H
L
LS
e
100 V DC / 63 V AC
H
L
LS
e
250 V DC / 160 V AC
H
L
LS
2.5 (0.098) 7.5 (0.295) 10.0 (0.394) 7.5 (0.295)
2.5 (0.098) 7.5 (0.295) 10.0 (0.394) 7.5 (0.295)
2.5 (0.098) 7.0 (0.276) 10.0 (0.394) 7.5 (0.295) 3.0 (0.118) 8.6 (0.339) 10.0 (0.394) 7.5 (0.295)
4.0 (0.157) 9.0 (0.354) 10.0 (0.394) 7.5 (0.295)
3.0 (0.118) 8.6 (0.339) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
4.0 (0.157) 9.0 (0.354) 10.0 (0.394) 7.5 (0.295)
3.0 (0.118) 8.6 (0.339) 10.0 (0.394) 7.5 (0.295) 9.0 (0.354) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
2.5 (0.098)
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
5.0 (0.197)
4.0 (0.157)
5.0 (0.197)
5.0 (0.197)
5.5 (0.216)
6.0 (0.236)
5.0 (0.197)
5.5 (0.216)
6.0 (0.236)
5.5 (0.216)
7.0 (0.276)
7.0 (0.276)
7.0 (0.276)
7.0 (0.276)
9.0 (0.354)
8.5 (0.335)
8.5 (0.335)
10.5 (0.413)
11.0 (0.433)
14.0 (0.551)
14.0 (0.551)
3.0 (0.118) 8.6 (0.339) 10.0 (0.394) 7.5 (0.295) 5.0 (0.197)
4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394) 4.0 (0.157)
5.0 (0.197)
4.0 (0.157) 9.0 (0.354) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157)
4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394) 5.5 (0.216)
6.0 (0.236)
4.0 (0.157) 9.0 (0.354) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157)
7.0 (0.276) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394) 5.5 (0.216)
5.0 (0.197)
9.0 (0.354) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157)
5.0 (0.197)
9.0 (0.354) 10.0 (0.394) 7.5 (0.295) 5.0 (0.197)
9.0 (0.354) 13.0 (0.512) 10.0 (0.394) 5.5 (0.216)
6.0 (0.236)
11.0 (0.433) 10.0 (0.394) 7.5 (0.295) 5.0 (0.197)
9.0 (0.354) 13.0 (0.512) 10.0 (0.394) 5.5 (0.216)
11.0 (0.433) 10.0 (0.394) 7.5 (0.295)
11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 6.0 (0.236)
10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 5.5 (0.216)
12.0 (0.472) 10.4 (0.409) 7.5 (0.295)
11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 6.0 (0.236)
10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 5.5 (0.216)
11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 7.0 (0.276)
10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276)
14.0 (0.551) 13.0 (0.512) 10.0 (0.394) 7.0 (0.276)
12.5 (0.492) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276)
12.5 (0.492) 18.0 (0.709) 15.0 (0.591) 9.0 (0.354)
15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 8.5 (0.335)
14.5 (0.571) 18.0 (0.709) 15.0 (0.591) 8.5 (0.335)
16.5 (0.650) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433)
10.5 (0.413)
16.5 (0.650) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433)
19.5 (0.768) 25.5 (1.004) 22.5 (0.886)
20.0 (0.787) 32.0 (1.260) 27.5 (1.083) 11.0 (0.433)
25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
11.0 (0.433)
9.0 (0.354)
11.0 (0.433)
11.0 (0.433)
10.5 (0.413)
12.0 (0.472)
11.0 (0.433)
10.5 (0.413)
10.0 (0.394)
13.0 (0.512)
10.0 (0.394)
13.0 (0.512)
18.0 (0.709)
10.4 (0.409)
13.0 (0.512)
18.0 (0.709)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
15.0 (0.591)
7.5 (0.295)
10.0 (0.394)
15.0 (0.591)
11.0 (0.433)
9.0 (0.354)
11.0 (0.433)
9.0 (0.354)
10.5 (0.413)
12.0 (0.472)
9.0 (0.354)
10.5 (0.413)
10.0 (0.394) 7.5 (0.295)
13.0 (0.512) 10.0 (0.394)
10.0 (0.394) 7.5 (0.295)
13.0 (0.512) 10.0 (0.394)
18.0 (0.709) 15.0 (0.591)
10.4 (0.409) 7.5 (0.295)
13.0 (0.512) 10.0 (0.394)
18.0 (0.709) 15.0 (0.591)
5.0 (0.197) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591)
6.0 (0.236) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591)
7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 7.0 (0.276) 12.5 (0.492) 18.0 (0.709) 15.0 (0.591)
10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
11.0 (0.433)
10.5 (0.413)
12.5 (0.492)
15.0 (0.591)
12.5 (0.492)
15.0 (0.591)
14.5 (0.571)
16.5 (0.650)
16.5 (0.650)
20.0 (0.787)
19.5 (0.768)
20.0 (0.787)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.5 (1.004)
18.0 (0.709)
25.5 (1.004)
18.0 (0.709)
25.5 (1.004)
25.5 (1.004)
32.0 (1.260)
25.5 (1.004)
32.0 (1.260)
10.0 (0.394)
15.0 (0.591)
15.0 (0.591)
22.5 (0.886)
15.0 (0.591)
22.5 (0.886)
15.0 (0.591)
22.5 (0.886)
22.5 (0.886)
27.5 (1.083)
22.5 (0.886)
27.5 (1.083)
9.0 (0.354)
7.0 (0.276)
8.5 (0.335)
11.0 (0.433)
10.5 (0.413)
11.0 (0.433)
14.5 (0.571)
15.0 (0.591)
16.5 (0.650)
20.0 (0.787)
19.5 (0.768)
20.0 (0.787)
18.0 (0.709) 15.0 (0.591)
25.5 (1.004) 22.5 (0.886)
25.5 (1.004) 22.5 (0.886)
32.0 (1.260) 27.5 (1.083)
25.5 (1.004) 22.5 (0.886)
32.0 (1.260) 27.5 (1.083)
11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083)
14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
20.0 (0.787) 32.0 (1.260) 27.5 (1.083)
TPC
19
BG 07/10/15/22/27
Range
L
e
H
Max
6.1 (0.024)
LS ±0.4
(0.016)
d
millimeters (inches)
Capacitance
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
0.01
0.01
0.015
0.015
0.022
0.022
0.033
0.033
0.047
0.047
0.047
0.068
0.068
0.068
0.1
0.1
0.1
0.15
0.15
0.15
0.22
0.22
0.22
0.33
0.33
0.33
0.47
0.47
0.47
0.68
0.68
0.68
1
1
1
1.5
1.5
2.2
2.2
20
nF
nF
nF
nF
nF
nF
nF
nF
nF
nF
nF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
e
400 V DC / 200 V AC
H
L
LS
e
630 V DC / 220 V AC
H
L
LS
e
1000 V DC / 250 V AC
H
L
LS
2.5 (0.098) 7.0 (0.276) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
2.5 (0.098) 7.0 (0.276) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
3.0 (0.118) 8.6 (0.339) 10.0 (0.394) 7.5 (0.295) 4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
2.5 (0.098)
7.0 (0.276) 10.0 (0.394) 7.5 (0.295)
3.0 (0.118)
8.6 (0.339) 10.0 (0.394) 7.5 (0.295)
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
5.0 (0.197)
4.0 (0.157)
5.0 (0.197)
4.0 (0.157)
6.0 (0.236)
4.0 (0.157)
5.5 (0.216)
6.0 (0.236)
5.0 (0.197)
5.5 (0.216)
9.0 (0.354)
9.0 (0.354)
9.0 (0.354)
11.0 (0.433)
9.0 (0.354)
11.0 (0.433)
9.0 (0.354)
12.0 (0.472)
9.0 (0.354)
10.5 (0.413)
12.0 (0.472)
11.0 (0.433)
10.5 (0.413)
10.0 (0.394)
10.0 (0.394)
13.0 (0.512)
10.0 (0.394)
13.0 (0.512)
10.0 (0.394)
13.0 (0.512)
10.4 (0.409)
13.0 (0.512)
18.0 (0.709)
10.4 (0.409)
13.0 (0.512)
18.0 (0.709)
7.5 (0.295)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
15.0 (0.591)
7.5 (0.295)
10.0 (0.394)
15.0 (0.591)
3.0 (0.118)
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
5.0 (0.197)
4.0 (0.157)
6.0 (0.236)
5.0 (0.197)
8.6 (0.339)
9.0 (0.354)
9.0 (0.354)
9.0 (0.354)
9.0 (0.354)
11.0 (0.433)
9.0 (0.354)
12.0 (0.472)
11.0 (0.433)
10.0 (0.394)
10.0 (0.394)
13.0 (0.512)
10.0 (0.394)
13.0 (0.512)
10.0 (0.394)
13.0 (0.512)
10.4 (0.409)
13.0 (0.512)
7.5 (0.295)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
7.5 (0.295)
10.0 (0.394)
4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
4.0 (0.157) 9.0 (0.354) 13.0 (0.512) 10.0 (0.394)
6.0 (0.236) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591)
5.0 (0.197) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 7.0 (0.276) 12.5 (0.492) 18.0 (0.709) 15.0 (0.591)
6.0 (0.236) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
6.0 (0.236) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
7.0 (0.276) 14.0 (0.551) 13.0 (0.512) 10.0 (0.394)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
6.0 (0.236) 11.0 (0.433) 13.0 (0.512) 10.0 (0.394) 7.0 (0.276) 12.5 (0.492) 18.0 (0.709) 15.0 (0.591)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 8.5 (0.335) 16.5 (0.650) 25.5 (1.004) 22.5 (0.886)
7.0 (0.276) 14.0 (0.551) 13.0 (0.512) 10.0 (0.394) 9.0 (0.354) 14.5 (0.571) 18.0 (0.709) 15.0 (0.591)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083)
5.5 (0.216) 10.5 (0.413) 18.0 (0.709) 15.0 (0.591) 9.0 (0.354) 14.5 (0.571) 18.0 (0.709) 15.0 (0.591)
7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083)
7.0 (0.276) 12.5 (0.492) 18.0 (0.709) 15.0 (0.591) 10.5 (0.413) 19.5 (0.768) 25.5 (1.004) 22.5 (0.886)
7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083) 14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
9.0 (0.354) 14.5 (0.571) 18.0 (0.709) 15.0 (0.591)
7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886) 11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083) 14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
7.0 (0.276) 15.0 (0.591) 25.5 (1.004) 22.5 (0.886)
11.0 (0.433) 20.0 (0.787) 32.0 (1.260) 27.5 (1.083) 14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
7.0 (0.276)
11.0 (0.433)
10.5 (0.413)
11.0 (0.433)
15.0 (0.591)
20.0 (0.787)
19.5 (0.768)
20.0 (0.787)
25.5 (1.004)
32.0 (1.260)
25.5 (1.004)
32.0 (1.260)
22.5 (0.886)
27.5 (1.083) 14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
22.5 (0.886)
27.5 (1.083)
14.0 (0.551) 25.0 (0.984) 32.0 (1.260) 27.5 (1.083)
TPC
BG 07/10/15/22/27
Packaging
LS
LS = 7.5 (0.295)
∆h
∆h
P2
P
P1
H1
d
W0
W2
t
F
P0
W1
7.5
(0.295)
H
W
D0
P1
10
(0.394)
LS = 10 (0.413) / 15 (0.591)
∆h
P
∆h
15
(0.591)
P2
W2
W1 W0
D0
W
F
P1
P0
d
22.5
(0.886)
27.5
(1.083)
Pn
Primary Minimum
Quantity Qty. Order
Dimensions
2.5 x 7 x 10
(0.098 x 0.276 x 0.394)
3 x 8 x 10
(0.118 x 0.315 x 0.394)
4 x 9 x 10
(0.157 x 0.354 x 0.394)
5 x 11 x 10
(0.197 x 0.433 x 0.394)
6 x 12 x 10
(0.236 x 0.472 x 0.394)
4 x 9 x 13
(0.157 x 0.354 x 0.512)
5 x 11 x 13
(0.197 x 0.433 x 0.512)
6 x 11 x 13
(0.236 x 0.433 x 0.512)
7 x 14 x 13
(0.276 x 0.551 x 0.512)
5.5 x 10.5 x 18
(0.216 x 0.413 x 0.709)
9 x 14.5 x 18
(0.354 x 0.571 x 0.709)
7 x 12.5 x 18
(0.276 x 0.492 x 0.709)
7 x 15 x 25.5
(0276 x 0.591 x 1.004)
8.5 x 16.5 x 25.5
(0.335 x 0.650 x 1.004)
10 x 19.5 x 25.5
(0.394 x 0.768 x 1.004)
11 x 20 x 32
(0.433 x 0.787 x 1.260)
14 x 25 x 32
(0.551 x 0.984 x 1.260)
LS
7.5
(0.295)
Max. ø 360
Max. ø 500
55
Max.
10
(0.394)
LS = 7.5 (0.295)
LS = 10 (0.394) or 15 (0.591)
Dimensions
P=7.5 (0.295) P=10 (0.394) P=15 (0.591)
d
P1
P2
F
0.6 (0.024)
2.6 (0.103)
6.35 (0.250)
7.5 (0.295)
0.6 ( 0.024)
7.7 (0.303)
12.7 (0.500)
10 (0.000)
0.8 (0.031)
5.2 (0.205)
12.7 (0.500)
15 (0.000)
P
P0
Ah
W
W0
W1
W2
H
12.7 (0.500)
12.7 (0.500)
0 (0.000)
18 (0.709)
15 (0.591)
9 (0.354)
0.5-3 (0.020)
16.5 (0.650)
18.5 (0.728)
32 (1.260)
4 (0.157)
25.4 (1.000)
12.7 (0.500)
0 (0.000)
18 (0.709)
15 (0.591)
9 (0.354)
0.5-3 (0.020)
16.0 (0.630)
18.5 (0.728)
32 (1.260)
4 (0.157)
25.4 (1.000)
12.7 (0.500)
0 (0.000)
18 (0.709)
15 (0.591)
9 (0.354)
0.5-3 (0.020)
16.0 (0.630)
18.5 (0.728)
32 (1.260)
4 (0.157)
H1
D0
2500
2500
2500
2500
2500
2000
2000
1200
1200
2200
2200
1500
1500
1200
1200
800
800
1700
1700
1200
1200
800
800
700
700
500
500
350
350
300
6000
200
6000
millimeters (inches)
ø 30
Symbol
2500
Note
Tol
15
(0.591)
e
e
e
e
e
e
e
e
e
e
e
e
e
=
=
=
=
=
=
=
=
=
=
=
=
2.5 (0.098)
3 (0.118)
4 (0.157)
5 (0.197)
6 (0.236)
4 (0.157)
5 (0.197)
6 (0.236)
7 (0.276)
5.5 (0.216)
7 (0.276)
9 (0.354)
Quantity
per reel
2500
2000
1500
1200
1000
1500
1300
1000
900
1100
900
600
±0.05
±0.7
±1
±0.6
-0.1
±1
±0.2
±0.2
±0.5
Max.
±0.5
±0.3
±0.5
Max.
±0.2
TPC
21
BC/BD 15
15 Radial Leads — 250 VAPPLICATIONS
Schematic Cross Section
Non-inductive, self-healing, metallized polyester film capacitor. Insulated* thermoplastic casing, epoxy resin sealed with
stand-offs*. Radial connections.
Schoop
Metallized film
e
* Flame retardant resin and case according to UL 94 VO.
Some examples of use:
Telecom applications, linking function in the ringing circuit.
6 (0.236) – 1 (0.039)
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
+ 0 (0.000)
STANDARDIZATION
LS
DIMENSIONS:
Type
BC 15
BD 15
H
0.4 (0.016)
. min
L
millimeters (inches)
Case
CR
(µF)
L
max
h
max
e
max
LS
±0.4
Ø
+10% -0.05
i0
8
9
9
9
9
9
8
8
8
0.47
0.68
0.80
0.82
1.0
1.5
2.2
0.80
0.82
1.0
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
17.5 (0.689)
12.0 (0.472)
13.5 (0.531)
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
13.5 (0.531)
13.5 (0.531)
13.5 (0.531)
6.0 (0.236)
6.25 (0.246)
8.5 (0.335)
8.5 (0.335)
8.5 (0.335)
8.5 (0.335)
8.5 (0.335)
6.25 (0.246)
6.25 (0.246)
6.25 (0.246)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
15.0 (0.591)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
HOW TO ORDER
BC 15
4
G
0105
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 27
PERFORMANCE CHARACTERISTICS
Climatic category:
Capacitance (CR):
Tolerance:
Nominal voltage (VR):
Test voltage (1.4 VR):
Category voltage (VC at 100°C):
Tangent of loss angle at
1 kHz (D.F.):
Insulation resistance between
terminals (IR under 100 V-):
Insulation resistance
between terminals and case:
Voltage gradient
(max. dv/dt peak):
22
55/100/56
See table
±5%, ±10%
250 V350 V0.75 VR
MARKING
BC 1µ0 K
250 V-
≤ 80.10-4
IR . CR ≥ 10 GΩ µF
≥ 30 GΩ
30 V/µs
TPC
Logo
Nominal capacitance
Tolerance (EIA code)
DC nominal voltage
BC/BD 15
CHARACTERISTIC CURVES
Nominal RMS voltage vs. frequency (room temperature) allowing a 10°C increase of the external temperature of the box.
VRMS (V max) 1000
160
100
10
470 nF
680 nF
820 nF
1 µF
1
F
10 Hz
100 Hz
1 kHz
TPC
10 kHz
100 kHz
1 MHz
23
BO 07/10/15/27
CPM-50 — 7.5/10/15/27.5 Radial Leads
40/63/160/250/400 VSchematic Cross Section
APPLICATIONS
Non-inductive, capacitor for professional use with radial
leads. Insulated thermoplastic casing, epoxy resin sealed
with stand-offs.
Schoop
Metallized film
Some examples of use:
e
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
6 (0.236) – 1 (0.039)
+ 0 (0.000)
0.4 (0.016). min
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM50
On the GAM-T1 list:
ARIANE qualified
LS
---- for case* in table page 25
DIMENSIONS:
Size
Code
millimeters (inches)
+10%
L max.
H max.
e max.
LS ±0.4
ø -0.05
10.1
(0.398)
12.5
(0.492)
17.5
(0.689)
31.25
(1.230)
10.0
(0.394)
10.0
(0.394)
10.5 ... 16.5
(0.413 ... 0.650)
15.0 ... 30.0
(0.591 ... 1.181)
5.0
(0.197)
5.0
(0.197)
5.0 ... 10.0
(0.197 ... 0.394)
7.5 ... 17.5
(0.295 ... 0.689)
7.5
(0.295)
10.0
(0.394)
15.0
(0.591)
27.5
(1.083)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
0.8
(0.031)
07
10
15
27
H
L
STANDARDIZATION
Observations
1nF ≤ C ≤ 8.2nF
R
4.7nF ≤ C ≤ 220nF
R
15nF ≤ C ≤ 2.2µF
R
150nF ≤ C ≤ 22µF
R
HOW TO ORDER
BO 15
4
G
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 27
PERFORMANCE CHARACTERISTICS
Climatic category:
Capacitance range:
Tolerances on CR:
(assoc. series)
Nominal voltages:
55/125/56 - Performance Class 1
CR 1 nF to 2.2 µF
±5%, ±10%, ±20% (E6)
(other values on request)
VR– 40/63/160/250/400 V
VR~ 25/40/100/180/200 V
Category voltage:
VC = 0.5 VR- at 125°C
Test voltage:
Ve = 1.6 VRTangent of loss angle: D.F. (see page 4)
Insulation resistance: IR (see page 5)
24
MARKING
Logo - CPM50B
Date of manufacture
Capacitance and tolerance 2 letter code
(CEI 62 code)
(year - month) according
Nominal voltage
to CEI 62
TPC
BO 07/10/15/27
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
S
i
z
e
C
a
s
e
DIMENSIONS:
millimeters (inches)
Max
L
10.1
(0.398)
12.5
10 4 (0.492)
17.5
6 (0.689)
17.5
7 (0.689)
17.5
15 8 (0.689)
17.5
9 (0.689)
17.5
10
(0.689)
31.25
14 (1.230)
31.25
15 (1.230)
31.25
16 (1.230)
27
17* 31.25
(1.230)
31.25
18* (1.230)
31.25
19* (1.230)
07
2
Max
H
Max
e
+10%
-0.05
Ø
10.0
(0.394)
10.0
(0.394)
10.5
(0.413)
13.5
(0.531)
13.5
(0.531)
14.5
(0.571)
16.5
(0.650)
15.0
(0.591)
17.5
(0.689)
19.5
(0.768)
22.5
(0.886)
26.0
(1.024)
30.0
(1.181)
5.0
(0.197)
5.0
(0.197)
5.0
(0.197)
5.0
(0.197)
6.25
(0.246)
8.5
(0.335)
10.0
(0.394)
7.5
(0.295)
8.75
(0.344)
10.0
(0.394)
12.5
(0.492)
15.0
(0.591)
17.5
(0.689)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
LS
±0.4
7.5
(0.295)
10.0
(0.394)
15.0
(0.591)
27.5
(1.083)
40/25
Reference
BO
VR-/VR~
63/40
160/100
250/180
Range of Capacitance (CR min. ... max.)
400/200
–
–
–
4.7 nF/8.2 nF
1 nF ... 3.3 nF
68 nF ... 220 nF
33 nF ... 100 nF
10 nF ... 47 nF
10 nF ... 22 nF
4.7 nF ... 10 nF
330 nF/470 nF
150 nF/220 nF
68 nF ... 150 nF
33 nF/47 nF
15 nF/22 nF
680 nF
330 nF
220 nF
68 nF
33 nF
1 µF
470 nF
–
100 nF
47 nF
1.5 µF
680 nF
330 nF
150 nF
68 nF
2.2 µF
1 µF
470 nF
220 nF
100 nF
3.3 µF
1.5 µF
680 nF/1 µF
330 nF
330 nF
4.7 µF
2.2 µF
1.5 µF/2.2 µF
470 nF
220 nF
6.8 µF
3.3 µF
–
680 nF
330 nF
10 µF
4.7 µF
–
1 µF
470 nF
15 µF
6.8 µF
3.3 µF
1.5 µF
680 nF
22 µF
10 µF
4.7 µF/6.8 µF
2.2 µF
1 µF
TPC
25
BO 07/10/15/27
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
Z
(Ω)
Size : 0.7
Size : 10
100
10
10
1
–4
.7
0n
nF
–1
F
F
7n
F
00
nF
20
nF
100
1000
ƒ (MHz)
Z
(Ω)
0.001
0.1
1
10
100
ƒ (MHz)
Z
(Ω)
Size : 15
Size : 27
100
100
10
10
1
1
F
150 n
F
220 n
F
470 n
F
TPC
0.1
1 µF
0.01
0.01
F
100
ƒ (MHz)
2.2 µ
10
15 µ F
1
4.7 µ
0.1
0.1
–2
0.01
F
5n
–1
F
2n
–2
F
7n
–4
nF
00
–1
nF
20
–2
nF
70
–4
µF
–1
µF
.2
0.1
26
–2
0.01
nF
10
2n
–1
nF
nF
6.8
0.01
1
–4
0.1
F
2.2
4.7
0.1
–2
1n
1
10
ƒ (MHz)
BT 07/10/15/BC 15
BO 07/10/15/BD 15
7.5/10/15 - Radial Leads – Taping on Reel for Automatic Insertion
CHARACTERISTICS OF THE REEL –
6 (0.236)
millimeters (inches)
Taping Suffix
EN
P
10
(0.394)
12.7 ± 1.0
(0.5 ± 0.039)
15
(0.590)
25.4 ± 1.0
(1.0 ± 0.039)
Ø 4 (0.157)
± 3 (0.012)
16 +1.5
-0.5
16.5 ± 0.3
(0.650 ± 0.012)
H
18 (0.709)
± 0.5 (0.020)
7.5
(0.295)
H
Lead Spacing tol ± 0.4 (0.016)
± 0.2 (0.008)
Suffixes to be used (see page 7)
Lead spacing: 7.5 (0.295)
(0.630
12.7 (0.500)
± 0.2 (0.008)
L.S.
+0.059
-0.020
)
6 (0.236)
18 (0.709)
± 0.5 (0.020)
H
± 0.2 (0.008)
Lead spacing: 10/15 (0.394/0.590)
PACKAGING
7.5
10
15
22
27
Case
Code
1
2
C
D
E0
4
5
6
7
I0
8
9
10
11
12
13
14
15
16
17
18
19
Minimum Quantity*
Reel
Bulk
2000
1250
1250
1000
850
700
700
1000
1000
1000
833
625
–
–
–
–
–
–
–
–
–
–
3000
1750
1500
1000
1750
1250
1000
750
3000
750
3000
2000
225
200
200
150
160
140
120
100
80
65
Ø
4 (0.157)
± 0.3 (0.012)
12.7 (0.500)
± 0.2 (0.008)
L.S.
P
Adhesive tape
m
(Other sizes according to standard CEI: 286-2)
Dimensions millimeters (inches)
Lead Spacing
D
E (ext)
7.5/10
360 (14.173)
48 (1.890)
15
500 (19.685)
52 (2.047)
D
E
Ø 31 (1.220)
Size
* Ordering quantities must be a multiple of the above figures
TPC
27
S4 07/10/15/27
CPM-13 — 7.62/10.16/15.24/27.94 Radial Leads
63/160/250/400 VSchematic Cross Section
APPLICATIONS
Non-inductive, capacitor for professional use with radial
leads. Flat, insulated (polyester tape wrapping) epoxy resin
sealed.
Schoop
Metallized film
L
Some examples of use:
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
STANDARDIZATION
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM13
On the GAM-T1 list.
L.S.
6 (0.236) min.
H
e
Ø
DIMENSIONS:
Size
Code
07
10
15
27
millimeters (inches)
L max.
H max.
e max.
LS
±0.5
ø -0.05
Observations
12.0
(0.472)
14.5
(0.571)
20.0
(0.787)
33.0
(1.299)
7.5
(0.295)
7.5 / 8.0
(0.295 / 0.315)
8.0 ... 15.5
(0.315 ... 0.610)
11.0 ... 27.5
(0.433 ... 1.083)
4.5
(0.177)
4.5 / 5.0
(0.177 / 0.197)
4.5 ... 10.5
(0.177 ... 0.413)
8.0 ... 18.0
(0.315 ... 0.709)
7.62
(0.300)
10.16
(0.400)
15.24
(0.600)
27.94
(1.100)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
1.0
(0.039)
1nF ≤ C ≤ 6.8nF
+10%
R
4.7nF ≤ C ≤ 100nF
R
15nF ≤ C ≤ 1µF
R
150nF ≤ C ≤ 10µF
R
HOW TO ORDER
S4 15
4
G
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 47
PERFORMANCE CHARACTERISTICS
MARKING
Climatic category:
Capacitance range:
Tolerances on CR:
(assoc. series)
Nominal voltages:
Logo - CPM13B
Capacitance and tolerance
(CEI 62 code)
Nominal voltage
55/125/21 - Performance Class 1
CR 1 nF to 10 µF
±5%, ±10%, ±20% (E6)
(other values on request)
VR– 63/160/250/400 V
VR~ 40/100/160/200 V
Category voltage:
VC = 0.5 VR- at 125°C
Test voltage:
Ve = 1.6 VRTangent of loss angle: D.F. (see page 4)
Insulation resistance: IR (see page 5)
28
TPC
Date of manufacture
2 letter code
(year - month) according
to CEI 62
except for L = 12 and 14.5mm
S4 07/10/15/27
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
DIMENSIONS:
millimeters (inches)
Size
Code
Max
L
Max
H
Max
e
+10%
-0.05
07
12.0 (0.472)
7.5 (0.295)
4.5 (0.177)
0.6 (0.024)
7.62
(0.300)
–
–
4.7 nF/6.8 nF
1 nF ... 3.3 nF
10
14.5 (0.571)
14.5 (0.571)
7.5 (0.295)
8.0 (0.315)
4.5 (0.177)
5.0 (0.197)
0.6 (0.024)
0.6 (0.024)
10.16
(0.400)
33 nF ... 100 nF
–
10 nF ... 33 nF
47 nF
10 nF ... 22 nF
–
4.7 nF ... 10 nF
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
8.0 (0.315)
8.0 (0.315)
8.5 (0.335)
8.5 (0.335)
4.5 (0.177)
5.5 (0.217)
4.5 (0.177)
5.0 (0.197)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
–
150 nF
220nF
68 nF
100 nF
–
–
33 nF
–
–
–
15 nF
–
–
22 nF
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
9.0 (0.354)
9.0 (0.354)
9.5 (0.374)
9.5 (0.374)
5.0 (0.197)
6.0 (0.236)
6.0 (0.236)
6.5 (0.256)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
330 nF
–
–
–
–
–
150 nF
47 nF
68 nF
–
–
–
–
33 nF
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
10.0 (0.394)
10.5 (0.413)
10.5 (0.413)
11.5 (0.453)
7.0 (0.276)
6.5 (0.256)
7.5 (0.295)
8.5 (0.335)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
470 nF
–
–
680 nF
–
–
220 nF
–
100 nF
–
–
–
–
47 nF
–
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
13.5 (0.531)
13.5 (0.531)
13.5 (0.531)
14.0 (0.551)
6.5 (0.256)
8.0 (0.315)
10.5 (0.413)
7.5 (0.295)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
–
1 µF
–
–
–
–
330 nF
–
150 nF
–
–
68 nF
–
–
–
20.0 (0.787)
20.0 (0.787)
15.0 (0.591)
15.5 (0.610)
8.5 (0.335)
9.0 (0.354)
0.8 (0.031)
0.8 (0.031)
–
–
–
470 nF
220 nF
–
100 nF
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
11.0 (0.433)
13.0 (0.512)
13.0 (0.512)
13.5 (0.531)
8.0 (0.315)
7.0 (0.276)
10.0 (0.394)
7.5 (0.295)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.5 µF
–
2.2 µF
–
–
–
–
680 nF
–
–
–
330 nF
–
150 nF
–
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
14.5 (0.571)
14.5 (0.571)
15.0 (0.591)
15.0 (0.591)
8.5 (0.335)
11.5 (0.453)
9.0 (0.354)
10.5 (0.413)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
3.3 µF
–
–
–
–
1 µF
–
470 nF
–
–
–
220 nF
–
–
330 nF
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
15.5 (0.610)
16.0 (0.630)
18.5 (0.728)
20.0 (0.787)
11.0 (0.433)
11.5 (0.453)
14.0 (0.551)
12.0 (0.472)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
–
4.7 µF
–
–
1.5 µF
–
2.2 µF
680 nF
–
–
–
–
–
–
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
20.5 (0.807)
21.0 (0.827)
23.5 (0.925)
24.0 (0.945)
11.0 (0.433)
16.5 (0.650)
14.0 (0.551)
14.5 (0.571)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
6.8 µF
–
–
–
–
–
–
1 µF
–
–
1.5 µF
470 nF
–
680 nF
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
24.5 (0.965)
26.5 (1.043)
27.5 (1.083)
15.0 (0.591)
17.0 (0.669)
18.0 (0.709)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
–
10 µF
3.3 µF
–
4.7 µF
–
–
2.2 µF
–
1 µF
–
15
27
Ø
LS
±0.5
Reference
S4
VR-/VR~
63/40
160/100
250/160
400/200
Range of Capacitance (CR min. ... max.)
15.24
(0.600)
27.94
(1.100)
TPC
29
S4 07/10/15/27
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
Size : 10
100
10
4,7
1
nF
10
nF
22
nF
47
nF
10
0.1
F
0n
0.01
0.1
1
Z
(Ω)
10
100
ƒ (MHz)
Size : 15
100
10
1
0.1
15 n
F
47 n
F
100
nF
nF
nF
220
1 µF
1
470
0.01
0.1
10
100
ƒ (MHz)
Z
(Ω)
10
Size : 27
1
nF
mF
2
mF
mF
10
mF
30
nF
1
2.
7
4.
–
0.001
0.01
0
47
–
–
–
0.01
50
–1
–
0.1
0.1
TPC
1
10
ƒ (MHz)
S8 10/14/18/31
CPM-8 — Axial Leads 63/160/250/400 VAPPLICATIONS
Schematic Cross Section
Non-inductive, capacitor for professional use. Flat axial, polyester wrapped, epoxy resin sealed.
Schoop
Metallized film
Some examples of use:
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
L
25 (0.984) min.
STANDARDIZATION
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM8
Ø
H
NOTE: For new design, please refer to SH series (optimized range)
e
DIMENSIONS:
Size
Code
millimeters (inches)
L max.
H max.
e max.
ø+10%
-0.05
12.0
(0.472)
14.5
(0.571)
20.0
(0.787)
33.0
(1.299)
6.5
(0.256)
6.0 ... 8.0
(0.236 ... 0.315)
8.0 ... 15.5
(0.315... 0.610)
11.0... 27.5
(0.433...1.083)
4.0
(0.157)
3.5 / 5.0
(0.138 / 0.197)
4.5 ... 10.5
(0.177... 0.413)
7.0 ... 18.0
(0.276... 0.709)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
1.0
(0.039)
10
14
18
31
Observations
1nF ≤ C ≤ 6.8nF
R
4.7nF ≤ C ≤ 100nF
R
15nF ≤ C ≤ 1µF
R
150nF ≤ C ≤ 10µF
R
HOW TO ORDER
S8 15
4
G
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 47
PERFORMANCE CHARACTERISTICS
MARKING
Climatic category:
Capacitance range:
Tolerances on CR
(assoc. series):
Nominal voltages:
Logo - CPM8B
Capacitance and tolerance
(CEI 62 code)
Nominal voltage
Category voltage:
Test voltage:
Tangent of loss angle:
Insulation resistance:
55/125/21 - Performance Class 1
CR 1 nF to 10 µF
±5%, ±10%, ±20% (E6)
(other values on request)
VR– 63/160/250/400 V
VR~ 40/100/160/200 V
VC = 0.5 VR– at 125°C
Ve = 1.6 VR–
D.F. (see page 4)
IR (see page 5)
TPC
Date of manufacture
2 letter code
(year - month) according
to CEI 62
except for L = 12 and 14.5mm
31
S8 10/14/18/31
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
DIMENSIONS:
millimeters (inches)
Size
Code
Max
H
Max
e
+10%
-0.05
Ø
10
12.0 (0.472)
6.5 (0.256)
4.0 (0.157)
0.6 (0.024)
–
–
4.7 nF/6.8 nF
1 nF ... 3.3 nF
14
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
6.0 (0.236)
6.5 (0.256)
6.5 (0.256)
7.0 (0.276)
3.5 (0.138)
3.5 (0.138)
4.0 (0.157)
4.0 (0.157)
0.6 (0.024)
0.6 (0.024)
0.6 (0.024)
0.6 (0.024)
33 nF
47 nF
–
68 nF
–
–
10 nF/22 nF
–
–
–
10 nF
15 nF
–
–
4.7 nF
–
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
7.0 (0.276)
7.5 (0.295)
8.0 (0.315)
4.5 (0.177)
4.5 (0.177)
5.0 (0.197)
0.6 (0.024)
0.6 (0.024)
0.6 (0.024)
–
100 nF
–
–
33 nF
47 nF
–
22 nF
–
6.8 nF/10 nF
–
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
8.0 (0.315)
8.0 (0.315)
8.5 (0.335)
8.5 (0.335)
4.5 (0.177)
5.5 (0.217)
4.5 (0.177)
5.0 (0.197)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
–
150 nF
220 nF
68 nF
100 nF
–
–
33 nF
–
–
–
15 nF
–
–
22 nF
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
9.0 (0.354)
9.0 (0.354)
9.5 (0.374)
9.5 (0.374)
5.0 (0.197)
6.0 (0.236)
6.0 (0.236)
6.5 (0.256)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
330 nF
–
–
–
–
–
150 nF
47 nF
68 nF
–
–
–
–
33 nF
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
10.0 (0.394)
10.5 (0.413)
10.5 (0.413)
11.5 (0.453)
7.0 (0.276)
6.5 (0.256)
7.5 (0.295)
8.5 (0.335)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
470 nF
–
–
680 nF
–
–
220 nF
–
100 nF
–
–
–
–
47 nF
–
–
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
13.5 (0.531)
13.5 (0.531)
13.5 (0.531)
14.0 (0.551)
6.5 (0.256)
8.0 (0.315)
10.5 (0.413)
7.5 (0.295)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
–
1 µF
–
–
–
–
330 nF
–
150 nF
–
–
68 nF
–
–
–
20.0 (0.787)
20.0 (0.787)
15.0 (0.591)
15.5 (0.610)
8.5 (0.335)
9.0 (0.354)
0.8 (0.031)
0.8 (0.031)
–
–
–
470 nF
220 nF
–
100 nF
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
11.0 (0.433)
13.0 (0.512)
13.0 (0.512)
13.5 (0.531)
8.0 (0.315)
7.0 (0.276)
10.0 (0.394)
7.5 (0.295)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.5 µF
–
2.2µF
–
–
–
–
680 nF
–
–
–
330 nF
–
150 nF
–
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
14.5 (0.571)
14.5 (0.571)
15.0 (0.591)
15.0 (0.591)
8.5 (0.335)
11.5 (0.453)
9.0 (0.354)
10.5 (0.413)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
3.3 µF
–
–
–
–
1 µF
–
470 nF
–
–
–
220 nF
–
–
330 nF
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
15.5 (0.610)
16.0 (0.630)
18.5 (0.728)
20.0 (0.787)
11.0 (0.433)
11.5 (0.453)
14.0 (0.551)
12.0 (0.472)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
–
4.7 µF
–
–
1.5 µF
–
2.2 µF
680 nF
–
–
–
–
–
–
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
20.5 (0.807)
21.0 (0.827)
23.5 (0.925)
24.0 (0.945)
11.0 (0.433)
16.5 (0.650)
14.0 (0.551)
14.5 (0.571)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
6.8 µF
–
–
–
–
–
–
1 µF
–
–
1.5 µF
470 nF
–
680 nF
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
24.5 (0.965)
26.5 (1.043)
27.5 (1.083)
15.0 (0.591)
17.0 (0.669)
18.0 (0.709)
1.0 (0.039)
1.0 (0.039)
1.0 (0.039)
–
–
10 µF
3.3 µF
–
4.7 µF
–
–
2.2 µF
–
1 µF
–
18
31
32
Max
L
Reference
S8
VR-/VR~
63/40
160/100
250/160
400/200
Range of Capacitance (CR min. ... max.)
TPC
S8 10/14/18/31
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
Size : 14
100
10
7
4.
1
nF
10
nF
22
nF
47
nF
0
10
0.1
nF
0.01
0.1
1
10
100
ƒ (MHz)
Z
(Ω)
Size : 18
100
10
1
f
nf
– 47
1
0 nf
– 10
0.1
0 nf
– 22
0 nf
– 47
µF
–1
0.01
n
– 15
0.1
10
100
ƒ (MHz)
Z
(Ω)
Size : 31
10
1
nf
70
µF
nf
–1
.2
–2
µF
F
F
0µ
–1
µ
.7
–4
0.01
0.001
0.01
50
–1
–4
0.1
0.1
1
TPC
10
ƒ (MHz)
33
SH 13/18/15/25/30/40
CPM-8 – Axial Leads 63/100/250/400/630/1000 VAPPLICATIONS
Non-inductive, capacitor for professional use. Flat axial, polyester wrapped, epoxy resin sealed.
dø
H
Some examples of use:
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
35 ± 5
35 ± 5
L
e
STANDARDIZATION
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM8
millimeters (inches)
e max.
≤5
>5
≥7
Ø d ± 0.05 (0.002)
0.6 (0.024)
0.8 (0.031)
1.0 (0.039)
PERFORMANCE CHARACTERISTICS
Protection:
Temperature range:
Flat axial leads, polyester
wrapped, epoxy resin sealed
-55°C to +100°C with voltage
derating of 1.25%/°C between
85°C and 100°C
55/100/56
63 VDC to 1000 VDC
1 nF to 22 µF
±5%, ±10%, ±20%
1.6 Vn-/2 s
Climatic category:
Voltage range:
Capacitance range:
Tolerances on CR:
Test voltage:
Insulation resistance:
Measurement condition:
Temperature:
25°C ± 5°C
Duration:
1 minute
Measurement Voltage: 100 V for Vn ≥ 100 V
50 V for Vn < 100 V
Requirements:
For Un ≤ 100 V:
C ≤ 0.33 µF ≥ 15 000 MΩ
C > 0.33 µF ≥ 5 000 S
For Un > 100 V:
C ≤ 0.33 µF ≥ 30 000 MΩ
C > 0.33 µF ≥ 10 000 S
Tangent of loss angle:
LIMIT VALUES
C ≤ 0.1 µF
34
10-3
1 kHz
8x
10 kHz
15 x 10-3
100 Hz
30 x 10-3
0.1 µF < C ≤ 1 µF
8x
10-3
C > 1 µF
10 x 10-3
15 x 10-3
TPC
SH 13/18/15/25/30/40
Range
dø
H
35 ± 5
35 ± 5
L
e
millimeters (inches)
63 V DC / 40 V AC
Capacitance
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
22
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
Size
Code
13
13
13
13
13
18
13
18
13
18
18
25
18
25
18
25
25
30
e
H
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
5.0 (0.197) 9.0 (0.354)
6.0 (0.236) 9.0 (0.354)
6.0 (0.236) 9.0 (0.354)
5.0 (0.197) 10.0 (0.394)
7.0 (0.276) 10.0 (0.394)
6.5 (0.260) 11.0 (0.433)
9.0 (0.354) 12.0 (0.472)
7.0 (0.276) 12.0 (0.472)
8.5 (0.335) 13.5 (0.531)
6.0 (0.236) 14.0 (0.551)
10.0 (0.394) 15.0 (0.591)
7.0 (0.276) 15.0 (0.591)
14.0 (0.551) 19.0 (0.748)
8.0 (0.315) 16.0 (0.630)
11.0 (0.433) 18.0 (0.709)
9.0 (0.354) 17.0 (0.669)
upon request
upon request
100 V DC / 63 V AC
L
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
13.0 (0.512)
18.0 (0.709)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
Size
Code
13
13
13
13
13
13
13
18
18
18
13
18
18
25
18
25
18
25
25
30
25
30
25
30
e
H
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
4.0 (0.157) 7.0 (0.276)
5.0 (0.197) 8.0 (0.315)
5.0 (0.197) 8.0 (0.315)
5.0 (0.197) 9.0 (0.354)
6.0 (0.236) 9.0 (0.354)
8.0 (0.315) 11.0 (0.433)
7.0 (0.276) 11.0 (0.433)
9.0 (0.354) 13.0 (0.512)
6.0 (0.236) 14.0 (0.551)
11.0 (0.433) 15.0 (0.591)
7.0 (0.276) 16.0 (0.630)
13.0 (0.512) 17.0 (0.669)
9.0 (0.354) 16.0 (0.630)
12.0 (0.472) 18.0 (0.709)
10.0 (0.394) 18.0 (0.709)
15.0 (0.591)121.0 (0.827)
13.0 (0.512) 21.0 (0.827)
18.0 (0.709) 25.0 (0.984)
14.0 (0.551) 26.0 (1.024)
upon request
upon request
TPC
L
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
250 V DC / 160 V AC
Size
e
H
L
Code
13
13
13
13
13
13
18
18
18
18
25
25
18
25
25
30
25
30
25
30
30
40
30
40
30
40
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
4.0 (0.157)
5.0 (0.197)
5.0 (0.197)
4.0 (0.157)
5.0 (0.197)
5.0 (0.197)
6.0 (0.236)
5.0 (0.197)
6.0 (0.236)
9.0 (0.354)
7.0 (0.276)
9.0 (0.354)
8.0 (0.315)
9.0 (0.354)
10.0 (0.394)
15.0 (0.591)
12.0 (0.472)
16.0 (0.630)
12.0 (0.472)
18.0 (0.709)
11.0 (0.433)
21.0 (0.827)
14.0 (0.551)
7.0 (0.276) 13.0 (0.512)
7.0 (0.276) 13.0 (0.512)
8.0 (0.315) 13.0 (0.512)
8.0 (0.315) 13.0 (0.512)
8.0 (0.315) 13.0 (0.512)
8.0 (0.315) 13.0 (0.512)
8.0 (0.315) 18.0 (0.709)
9.0 (0.354) 18.0 (0.709)
10.0 (0.394) 18.0 (0.709)
11.0 (0.433) 18.0 (0.709)
12.0 (0.472) 25.0 (0.984)
13.0 (0.512) 25.0 (0.984)
14.0 (0.551) 18.0 (0.709)
15.0 (0.591) 25.0 (0.984)
15.0 (0.591) 25.0 (0.984)
16.0 (0.630) 30.0 (1.181)
17.0 (0.669) 25.0 (0.984)
18.0 (0.709) 30.0 (1.181)
19.0 (0.748) 25.0 (0.984)
20.0 (0.787) 30.0 (1.181)
22.0 (0.866) 30.0 (1.181)
27.0 (1.063) 40.0 (1.575)
24.0 (0.945) 30.0 (1.181)
21.0 (0.827) 40.0 (1.575)
26.0 (1.024) 30.0 (1.181)
23.0 (0.906 40.0 (1.575)
35
SH 13/18/15/25/30/40
Range
dø
H
35 ± 5
35 ± 5
L
e
millimeters (inches)
Capacitance
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
1
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
22
36
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
400 V DC / 200 V AC
Size
e
H
L
Code
13
13
13
13
13
13
18
18
25
25
25
25
25
30
30
40
30
40
30
40
30
40
4.0 (0.157)
4.0 (0.157)
5.0 (0.197)
5.0 (0.197)
5.0 (0.197)
5.0 (0.197)
5.0 (0.197)
6.0 (0.236)
5.0 (0.197)
6.0 (0.236)
7.0 (0.276)
8.0 (0.315)
11.0 (0.433)
10.0 (0.394)
11.0 (0.433)
9.0 (0.354)
12.0 (0.472)
10.0 (0.394)
13.0 (0.512)
12.0 (0.472)
15.0 (0.591)
14.0 (0.551)
8.0 (0.315)
8.0 (0.315)
8.0 (0.315)
8.0 (0.315)
8.0 (0.315)
8.0 (0.315)
9.0 (0.354)
10.0 (0.394)
10.0 (0.394)
12.0 (0.472)
14.0 (0.551)
16.0 (0.630)
18.0 (0.709)
17.0 (0.669)
20.0 (0.787
18.0 (0.709)
22.0 (0.866)
20.0 (0.787)
25.0 (0.984)
23.0 (0.906)
26.0 (1.024)
26.0 (1.024)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
630 V DC / 220 V AC
Size
e
H
L
Code
13
13
13
18
18
18
18
25
25
30
30
30
25
30
30
40
30
40
5.0 (0.197)
5.0 (0.197)
5.0 (0.197)
5.0 (0.197)
6.0 (0.236)
6.0 (0.236)
6.0 (0.236)
6.0 (0.236)
7.0 (0.276)
8.0 (0.315)
11.0 (0.433)
12.0 (0.472)
11.0 (0.433)
14.0 (0.551)
16.0 (0.630)
13.0 (0.512)
19.0 (0.748)
15.0 (0.591)
TPC
8.0 (0.315)
8.0 (0.315)
8.0 (0.315)
9.0 (0.354)
10.0 (0.394)
12.0 (0.472)
13.0 (0.512)
13.0 (0.512)
15.0 (0.591)
18.0 (0.709)
18.0 (0.709)
21.0 (0.827)
20.0 (0.787)
23.0 (0.906)
25.0 (0.984)
25.0 (0.984)
27.0 (1.063)
30.0 (1.181)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
1000 V DC / 250 V AC
Size
e
H
L
Code
18
18
18
25
25
25
25
30
30
30
40
5.0 (0.197)
5.0 (0.197)
5.5 (0.217)
5.0 (0.197)
6.0 (0.236)
7.0 (0.276
9.0 (0.354)
9.0 (0.354)
10.0 (0.394)
14.0 (0.551)
10.0 (0.394)
10.0 (0.394) 18.0 (0.709)
10.0 (0.394) 18.0 (0.709)
11.0 (0.433) 18.0 (0.709)
11.0 (0.433) 25.0 (0.984)
12.0 (0.472) 25.0 (0.984)
16.0 (0.630) 25.0 (0.984)
16.0 (0.630) 25.0 (0.984)
16.0 (0.630) 30.0 (1.181)
20.0 (0.787) 30.0 (1.181)
23.0 (0.906) 30.0 (1.181)
22.0 (0.866) 40.0 (1.575)
SH Series
Packaging
BULK:
Quantity Per Voltage
Voltage
Capacitance
0.01 µF
0.015 µF
0.022 µF
0.033 µF
0.047 µF
0.068 µF
0.10 µF
0.15 µF
0.22 µF
0.33 µF
0.47 µF
0.38 µF
1
µF
1.5 µF
2.2 µF
3.3 µF
4.7 µF
6.8 µF
10
µF
63 V
2000
2000
2000
2000
2000
1250
750
700
700
700
300
100 V
2000
2000
2000
2000
2000
2000
2000
1250
1250
1250
1250
700
700
700
300
250
200
250 V
400 V
630V
1000 V
2000
2000
2000
2000
1500
1250
2000
1250
1250
1250
700
700
700
300
250
200
200
150
150
2000
2000
2000
2000
1500
1250
1250
1250
700
700
700
700
300
200
200
200
150
2000
2000
1250
1250
1250
1250
1250
700
700
300
250
200
200
200
200
1250
1250
1250
700
700
700
700
300
200
200
200
TPC
37
S9 10/13/18/27/31
CPM72 — Axial Leads 100/250/400/630 VAPPLICATIONS
Non-inductive, insulated capacitor for professional use.
Cylindrical axial leads, polyester wrapped, epoxy resin
sealed.
25 (0.984) min.
L
Some examples of use:
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
Ø
STANDARDIZATION
D
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM72
NOTE: For new design, please refer to SG series (optimized range)
DIMENSIONS:
Size
Code
10
13
18
27
31
millimeters (inches)
L max.
D max.
ø -0.05
+10%
Observations
12.0
(0.472)
14.5
(0.571)
20.0
(0.787)
27.5
(1.083)
33.0
(1.299)
5.0
(0.197)
5.0 ... 7.5
(0.197 ... 0.295)
7.5 ... 10.0
(0.295 ... 0.394)
8.75 ... 12.5
(0.344 ... 0.492)
12.5 ... 21.5
(0.492 ... 0.846)
0.6
(0.024)
0.6
(0.024)
0.8
(0.031)
0.8
(0.031)
.08
(0.031)
1nF ≤ C ≤ 100nF
R
4.7nF ≤ C ≤ 300nF
R
33nF ≤ C ≤ 1µF
R
100nF ≤ C ≤ 3.3µF
R
330nF ≤ C ≤ 10µF
R
HOW TO ORDER
S9 13
4
G
0104
K
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 47
PERFORMANCE CHARACTERISTICS
MARKING
Climatic category:
Capacitance range:
Tolerances on CR
(assoc. series):
Nominal voltages:
Logo - CPM72B
Capacitance and tolerance (CEI 62 code)
Nominal voltage
Date of manufacture
2 letter code
(year - month) according
to CEI 62
and available space
Category voltage:
Test voltage:
Tangent of loss angle:
Insulation resistance:
38
55/100/21 - Performance Class 1
CR 1 nF to 10 µF
±5%, ±10%, ±20% (E6)
(other values on request)
VR– 100/250/400/630 V
VR~ 40/100/160/200 V
VC = 0.75 VR– at 100°C
Ve = 1.6 VR–
D.F. (see page 4)
IR (see page 5)
TPC
S9 10/13/18/27/31
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
DIMENSIONS:
millimeters (inches)
Size
Code
Max
L
Max
D
+10%
-0.05
Ø
Reference
S9
VR-/VR~
100/40
250/100
400/160
630/200
Range of Capacitance (CR min. ... max.)
10
12.0 (0.472)
5.0 (0.197)
0.6 (0.024)
33 nF ... 100 nF
10 nF ... 22 nF
4.7 nF/6.8 nF
1 nF ... 3.3 nF
13
14.5 (0.571)
14.5 (0.571)
14.5 (0.571)
5.0 (0.197)
6.25 (0.246)
7.5 (0.295)
0.6 (0.024)
0.6 (0.024)
0.6 (0.024)
–
150 nF
220 nF/330 nF
33 nF
47 nF/68 nF
100 nF
10 nF/15nF
22 nF/33 nF
47 nF
4.7 nF/6.8 nF
10 nF
15 nF/22 nF
18
20.0 (0.787)
20.0 (0.787)
20.0 (0.787)
7.5 (0.295)
8.75 (0.344)
10.0 (0.394)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
470 nF
680 nF
1 µF
150 nF/220 nF
330 nF
470 nF
68 nF
100 nF
150 nF
33 nF
47 nF
68 nF
27.5 (1.083)
27.5 (1.083)
27.5 (1.083)
27.5 (1.083)
8.75 (0.344)
10.0 (0.394)
11.25 (0.443)
12.5 (0.492)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
1.5 µF
2.2 µF
3.3 µF
–
680 nF
1 µF
–
220 nF
330 nF
–
470 nF
100 nF
150 nF
–
220 nF
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
12.5 (0.492)
13.5 (0.531)
15.0 (0.591)
16.5 (0.650)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
4.7 µF
–
6.8 µF
1.5 µF
2.2 µF
–
3.3 µF
680 nF
–
1 µF
–
330 nF
–
470 nF
–
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
33.0 (1.299)
17.5 (0.689)
18.75 (0.738)
20.0 (0.787)
21.25 (0.837)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
0.8 (0.031)
–
–
10 µF
–
–
–
4.7 µF
–
1.5 µF
–
–
2.2 µF
–
680 nF
–
1 µF
27
31
TPC
39
S9 10/13/18/27/31
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
Z
(Ω)
Size : 13
Size : 10
100
100
10
10
10
nF
22
47
nF
nF
nF
22
nF
0
10
nF
0
10
0.1
nF
nF
1
nF
10
47
0.1
7
4.
2
2.
7
4.
1
nF
0
33
nF
10
100
1000
ƒ (MHz)
Z
(Ω)
0.01
0.1
nF
0.01
1
1
10
Z
(Ω)
Size : 18
Size : 27
1
0.1
0.1
0.01
1
Z
(Ω)
Size : 31
100
10
1
0.1
TPC
1
nF
330
nF
470
F
40
1 µF
F
2.2 µ
0.1
F
4.7 ˜µ
0.01
10 µ
0.01
10
ƒ (MHz)
F
0.001
0.1
F
100
ƒ (MHz)
0n
nF
nF
nF
10
0n
47
F
1µ
µF
2.2
µF
3.3
F
33 n
100
220
470
1 nF
1
F
1
0n
10
10
10
22
100
0.01
0.1
100
ƒ (MHz)
10
100
ƒ (MHz)
SG 13/18/25/30/40
CPM72 – Axial Leads 63/100/250/400/630/1000 VAPPLICATIONS
Non-inductive, insulated capacitor for professional use.
Cylindrical axial leads, polyester wrapped, epoxy resin
sealed.
Some examples of use:
Oscillating circuit, LF filter, coupling and decoupling, frequency
discriminator.
STANDARDIZATION
dø
35 ± 5
(1.378 ± 0.197)
L
35 ± 5
(1.378 ± 0.197)
D
Generic specifications:
CEI 384-1/CECC 30000/UTE 83100
Sectional specifications:
CEI 384-2/CECC 30400/UTE 83151
On the LNZ 44-04 list:
Complies with type CPM72
millimeters (inches)
PERFORMANCE CHARACTERISTICS
Protection:
Temperature range:
Cylindrical axial leads, polyester
wrapped, epoxy resin sealed
-55°C to +100°C with voltage
derating of 1.25%/°C between
85°C and 100°C
55/100/56
63 VDC to 1000 VDC
10 nF to 22 µF
±5%, ±10%, ±20%
1.6 Vn-/2 s
D max.
≤ 8mm
> 8mm
≥ 15mm
Ø d ± 0.05 (0.002)
0.6 (0.024)
0.8 (0.031)
1.0 (0.039)
Climatic category:
Voltage range:
Capacitance range:
Tolerances on CR:
Test voltage:
Insulation resistance:
Measurement condition:
Temperature:
25°C ± 5°C
Duration:
1 minute
Measurement Voltage: 100 V for Vn ≥ 100 V
50 V for Vn < 100 V
Requirements:
For Un ≤ 100 V:
C ≤ 0.33 µF ≥ 15 000 MΩ
C > 0.33 µF ≥ 5 000 S
For Un > 100 V:
C ≤ 0.33 µF ≥ 30 000 MΩ
C > 0.33 µF ≥ 10 000 S
Tangent of loss angle:
LIMIT VALUES
C ≤ 0.1 µF
0.1 µF < C ≤ 1 µF
C > 1 µF
1 kHz
8 x 10-3
8 x 10-3
10 x 10-3
10 kHz
15 x 10-3
15 x 10-3
100 Hz
30 x 10-3
TPC
41
SG 13/18/25/30/40
Range
millimeters (inches)
Capacitance
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
0.68
1
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
22
42
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
63 V DC / 40 V AC
Size
D
L
Code
13
13
13
13
18
13
18
13
18
18
25
18
25
18
25
25
30
25
30
6.5 (0.256)
6.5 (0.256)
7.0 (0.276)
7.0 (0.276)
6.5 (0.256)
8.0 (0.315)
7.5 (0.276)
8.0 (0.315)
8.5 (0.335)
9.5 (0.374)
8.5 (0.335)
11.0 (0.433)
10.0 (0.394)
13.0 (0.512)
12.0 (0.472)
15.0 (0.591)
12.0 (0.472)
17.0 (0.669)
14.5 (0.571)
upon request
upon request
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
13.0 (0.512)
18.0 (0.709)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
100 V DC / 63 V AC
Size
D
L
Code
250 V DC / 160 V AC
Size
D
L
Code
13
13
13
13
18
18
18
6.5 (0.256)
6.5 (0.256)
6.5 (0.256)
6.5 (0.256)
6.0 (0.236)
7.0 (0.276)
8.0 (0.315)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
13
13
13
13
13
18
18
18
6.5 (0.256)
7.0 (0.276)
7.0 (0.276)
7.5 (0.295)
8.0 (0.315)
8.0 (0.315)
9.0 (0.354)
10.0 (0.394)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
13
18
18
25
18
25
18
25
25
30
25
30
30
40
11.0 (0.433)
9.0 (0.354)
11.0 (0.433)
9.0 (0.354)
13.0 (0.512)
11.0 (0.433)
15.0 (0.591)
12.0 (0.472)
15.0 (0.591)
14.0 (0.551
17.0 (0.669)
16.0 (0.630)
18.0 (0.709)
16.0 (0.630)
upon request
upon request
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
18
25
25
30
25
30
25
30
30
40
30
40
30
40
12.0 (0.472)
10.0 (0.394)
10.0 (0.394)
11.0 (0.433)
14.0 (0.551)
13.0 (0.512)
17.0 (0.669)
14.0 (0.551)
18.0 (0.709)
11.0 (0.433)
21.0 (0.827)
13.0 (0.512)
23.0 (0.906)
14.0 (0.551)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
TPC
SG 13/18/25/30/40
Range
Capacitance
0.01
0.015
0.022
0.033
0.047
0.068
0.1
0.15
0.22
0.33
0.47
0.68
0.68
1
1
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
15
22
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
µF
400 V DC / 200 V AC
Size
D
L
Code
13
13
13
13
18
18
25
25
25
30
6.5 (0.256)
6.5 (0.256)
7.5 (0.276)
8.0 (0.315)
7.0 (0.276)
8.5 (0.335)
9.0 (0.354)
9.5 (0.374)
11.0 (0.433)
10.0 (0.394)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
25
30
30
40
30
40
30
40
16.0 (0.630)
11.0 (0.433)
12.0 (0.472)
14.0 (0.551)
13.0 (0.512)
17.0 (0.669)
16.0 (0.630)
20.0 (0.787)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
630 V DC / 220 V AC
Size
D
L
Code
13
13
13
18
18
18
18
25
25
25
25
30
6.5 (0.256)
7.0 (0.276)
8.0 (0.315)
6.5 (0.256)
7.0 (0.276)
8.0 (0.315)
10.0 (0.394)
10.0 (0.394)
12.5 (0.492)
13.0 (0.512)
14.0 (0.551)
12.0 (0.472)
13.0 (0.512)
13.0 (0.512)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
30
40
30
40
30
40
14.0 (0.551)
15.0 (0.591)
16.0 (0.630)
16.0 (0.630)
17.0 (0.669)
18.0 (0.709)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
30.0 (1.181)
40.0 (1.575)
TPC
1000 V DC / 250 V AC
Size
D
L
Code
13
18
18
18
18
25
25
30
30
40
40
40
8.0 (0.315)
8.0 (0.315)
9.0 (0.354)
11.0 (0.433)
12.0 (0.472)
11.0 (0.433)
13.0 (0.512)
14.0 (0.551)
16.0 (0.630)
16.0 (0.630)
19.0 (0.748)
21.0 (0.827)
13.0 (0.512)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
18.0 (0.709)
25.0 (0.984)
25.0 (0.984)
30.0 (1.181)
30.0 (1.181)
40.0 (1.575)
40.0 (1.575)
40.0 (1.575)
43
SG Series
Packaging
BULK:
Quantity Per Voltage
Capacitance
100 V
Voltage
250 V 400 V
630 V
1000 V
µF
2000
1250
0.015 µF
2000
1000
2000
1250
750
0.01
63 V
Suffix – –
0.022 µF
0.033 µF
0.047 µF
1250
500
1500
1250
750
0.068 µF
2000
2000
1250
1000
500
0.10
µF
2000
2000
1250
1000
500
0.15
µF
2000
1500
1000
500
300
0.22
µF
2000
2000
1250
500
300
200
0.33
µF
2000
1250
1000
500
300
150
0.47
µF
2000
1250
750
500
300
150
100
0.68
µF
2000
1000
750
400
400
1
µF
1500
750
750
400
300
1.5
µF
1500
500
500
400
200
2.2
µF
900
400
300
300
200
3.3
µF
800
400
300
150
4.7
µF
800
400
200
6.8
µF
250
400
150
µF
250
200
150
10
AMMOPACK
Space between capacitors
Capacitance
0.01
63 V
93 (3.66)
1.4 (.055)
l (.039) max.
d
(upon request)
Ø Capacitor (mm)
10.0 ... 14.0
15.0 ... 19.0
10 ± 0.5
15 ± 0.75
20 ± 1.0
100 V
Voltage
250 V 400 V
8 (.315)
±1.0 (.039)
115 (4.53)
630 V 1000 V
µF
1000
800
0.015 µF
950
800
0.022 µF
1000
800
700
0.033 µF
1000
1000
400
1000
900
950
300
0.068 µF
1000
950
800
800
400
0.10
µF
1000
950
950
450
300
0.15
µF
1000
900
800
450
300
0.22
µF
1000
1000
800
700
350
200
0.33
µF
1000
1100
800
700
300
200
0.47
µF
950
950
700
400
300
0.68
µF
1000
800
450
450
350
1
µF
1000
400
300
200
300
1.5
µF
800
400
450
350
200
2.2
µF
700
300
300
300
200
3.3
µF
400
300
200
200
4.7
µF
300
300
400
6.8
µF
200
200
300
µF
200
200
300
10
S
Suffix EN
5.0 ... 9.0
0.047 µF
44
2000
2000
TPC
Q ±1.2
(.047)
185 (7.28)
+2 (.079)
380 (
1
+3 (.14.96)
18)
120
(4.72)
+3 (.118)
ST 22/36
Axial Leads 630 V- ... 10,000 VAPPLICATIONS
Non-inductive, insulated capacitor. Cylindrical, axial leads,
polyester wrapped, epoxy resin sealed.
L
25 (0.984) min.
Some examples of use:
High voltage filtering, TV line recuperation.
SPACELAB qualified.
Important: In frequency the voltages can be limited by the
nominal RMS current.
Ø
D
DIMENSIONS:
Size
Code
millimeters (inches)
L max.
22.0
(0.866)
36.0
(1.417)
22
36
+10%
D max.
10.0
(0.394
10.0
(0.394
... 17.5
... 0.689)
... 27.5
... 1.083)
ø -0.05
Observations
0.8
(0.031)
1.0
(0.039)
150pF ≤ C ≤ 100nF
R
100pF ≤ C ≤ 1.5µF
R
HOW TO ORDER
ST 36
4
V
0102
M
––
Type
Class
Voltage
Capacitance Value
Tolerance
Suffix
Tape and Reel
See page 47
PERFORMANCE CHARACTERISTICS
MARKING
Climatic category:
Capacitance range:
Tolerances on CR
(assoc. series):
Nominal voltages:
Test voltage:
Tangent of loss angle:
Insulation resistance:
Logo - IE--Capacitance and tolerance (CEI 62 code)
Nominal voltage
Date of manufacture
2 letter code
(year - month) according
to CEI 62
and available space
40/085/21 - Performance Class 1
CR 100 pF to 1.5 µF
±5%, ±10%, ±20% (E6)
(other values on request)
VR– 630 V to 10,000 V
Ve = 1.25 VR–/1 mn
D.F. (see page 4)
IR (see page 5)
TPC
45
ST 22/36
NOMINAL VOLTAGE (VR) AND CAPACITANCE VALUES (CR)
DEPENDING ON THE DIMENSIONS
DIMENSIONS:
millimeters (inches)
Size Max
Code
L
22
36
Max
D
+10%
-0.05
Ø
22.0
(0.866)
22.0
(0.866)
22.0
(0.866)
22.0
(0.866)
10.0
(0.394)
12.5
(0.492)
15.0
(0.591)
17.5
(0.689)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
36.0
(1.417)
10.0
(0.394)
12.5
(0.492)
15.0
(0.591)
17.5
(0.689)
20.0
(0.787)
22.5
(0.886)
25.0
(0.984)
27.5
(1.083)
Reference
ST
VR1,600
2,500
5,000
6,300
Range of Capacitances (CR min. ... max.)
630
1,000
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
0.8
(0.031)
–
15 nF/22 nF
–
33 nF/47 nF
22 nF
6.8 nF
–
68 nF
33 nF
–
100 nF
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
1.0
(0.031)
–
6.8 nF ... 15 nF 2.2 nF ... 4.7 nF 150 pF/220 pF
10,000
–
–
330 pF/470 pF
–
–
10 nF/15 nF
680 pF
–
–
47 nF/68 nF
22 nF
1 nF
–
–
47 nF
15 nF... 33 nF
6.8 nF ... 10 nF
1.5 nF/2.2 nF
1 nF
100 pF/220 pF
–
68 nF/100 nF
47 nF
15 nF/22 nF
3.3 nF/4.7 nF
1.5 nF
330 pF
–
150 nF
68 nF/100 nF
33 nF
6.8 nF
2.2 nF/3.3 nF
470 pF/680 pF
–
220 nF
150 nF
47 nF
10 nF
4.7 nF
1 nF
–
330 nF
–
68 nF
15 nF
–
–
1 µF
470 nF
220 nF
100 nF
–
6.8 nF
1.5 nF
1.5 µF
–
330 nF
–
22 nF
10 nF
2.2 nF
–
680 nF
–
150 nF
33 nF
–
–
CHARACTERISTIC CURVES
Influence of the frequency on the impedance (room temperature).
Z
(Ω)
Z
(Ω)
Size : 22
Size : 36
100
10
F
1n
nF
nF
nF
10
n
22
F
nF
nF
F
0n
1.5
F
0n
nF
47
nF
0
22
.2
.7
–4
–1
0.01
F
0n
10
nF
–2
0.1
µF
F
2n
F
F
0n
46
10
0.01
1
7n
–4
–2
0.1
47
–1
1
4.7
1
2.2
10
10
100
1000
ƒ (MHz)
0.001
0.1
TPC
1
10
100
ƒ (MHz)
S4 07/10/15/27 – S8 10/14/18/31
S9 10/13/18/27/31 – ST 22/36
Bulk
M.O.Q. = 200
millimeters (inches)
Tape & Reel
Ø capacitor
Quantities
Pitch
Suffix: GA & GB
< 4.0
(0.0 < 0.157)
1800
10.0
(0.394)
4<Ø≤6
(0.161 < Ø ≤ 0.236)
1200
10.0
(0.394)
6<Ø≤8
(0.240 < Ø ≤ 0.315)
1000
10.0
(0.394)
8<Ø≤9
(0.319 < Ø ≤ 0.354)
800
10.0
(0.394)
9 < Ø ≤ 14.5
(0.358 < Ø ≤ 0.571)
300
20.0
(0.787)
Suffix
D
E (ext)
GA
360 (14.173)
90 (3.543)
GB
360 (14.173)
79 (3.110)
E
D
TPC
Ø 31 (1.220)
Suffix: GA
47
Guide for Customer’s Specific Requirements
PRESENTATION
ELECTRICAL CHARACTERISTICS
– Required shape
(rectangular or cylindrical case molded unit, etc.)
_________________________________
_________________________________
_________________________________
_________________________________
Max. and min.
operating temperatures
from ___________ to ____________°C
Max. and min.
storage temperatures
from ___________ to ____________°C
Capacitance/Tolerance
C ______________ µF ____________%
Max. operating voltages
(DC and AC)
VR DC__________
VR RMS ________ V
Max. overvoltages
– Duration
– Quantity
– Frequency
VS _____________ V
t_______________ ms
N ______________
F ______________ Hz
Test voltage between terminals
Ve DC __________V
Ve RMS ________ V
(F _______Hz)
Test voltage between shorted
terminals and case
Vi DC __________ V
Vi RMS _________ V
(F = 50 Hz)
Max. currents
– Peak
– RMS
– Frequency
Icr _____________ A
I/RMS __________ A
F ______________ Hz
Voltage gradient
(dv/dt)R _________ V/µs
Application: Diagram of the circuit
Other information
(resistive (or) inductive coupling, ...
Waveforms, etc.)
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
__________________________________
– Max. dimensions
_________________________________
_________________________________
_________________________________
– Required output terminals type
_________________________________
_________________________________
– One plate connected or not to
the case
_________________________________
_________________________________
_________________________________
– Environment
_________________________________
_________________________________
_________________________________
– Drawing (if necessary)
_________________________________
Marking
Standard _______________________ u
Other __________________________ u
_________________________________
Packaging
Bulk ____________________________u
One tape on reel ________________ u
_________________________________
48
TPC
(F _______Hz)
Normalized Series and Associated Values
E6
±20%
100
E 12
±10%
100
E 24
±5%
100
E 48
±2%
100
105
110
110
115
120
120
121
127
130
133
140
147
150
150
150
154
160
162
169
180
180
178
187
196
200
205
215
220
220
220
226
240
237
249
261
270
270
274
287
300
301
E 96
±1%
100
102
105
107
110
113
115
118
121
124
127
130
133
137
140
143
147
150
154
158
162
165
169
174
178
182
187
191
196
200
205
210
215
221
226
232
237
243
249
255
261
267
274
280
287
294
301
309
E6
±20%
E 12
±10%
E 24
±5%
330
330
330
E 48
±2%
316
332
348
360
365
383
390
390
402
422
430
442
470
470
470
464
487
510
511
536
560
560
562
590
620
619
649
680
680
680
681
715
750
750
787
820
820
825
866
910
909
953
TPC
E 96
±1%
316
324
332
340
348
357
365
374
383
392
402
412
422
432
442
453
464
475
487
499
511
523
536
549
562
576
590
604
619
634
649
665
681
698
715
732
750
768
787
806
825
845
866
887
909
931
953
976
49
USA
EUROPE
ASIA-PACIFIC
AVX Myrtle Beach, SC
Corporate Offices
AVX Limited, England
European Headquarters
AVX/Kyocera, Singapore
Asia-Pacific Headquarters
Tel: 843-448-9411
FAX: 843-448-1943
Tel: ++44 (0)1252 770000
FAX: ++44 (0)1252 770001
Tel: (65) 258-2833
FAX: (65) 350-4880
AVX Northwest, WA
AVX S.A., France
AVX/Kyocera, Hong Kong
Tel: 360-669-8746
FAX: 360-699-8751
Tel: ++33 (1) 69.18.46.00
FAX: ++33 (1) 69.28.73.87
Tel: (852) 2-363-3303
FAX: (852) 2-765-8185
AVX North Central, IN
AVX GmbH, Germany - AVX
AVX/Kyocera, Korea
Tel: 317-848-7153
FAX: 317-844-9314
Tel: ++49 (0) 8131 9004-0
FAX: ++49 (0) 8131 9004-44
Tel: (82) 2-785-6504
FAX: (82) 2-784-5411
AVX Northeast, MA
AVX GmbH, Germany - Elco
AVX/Kyocera, Taiwan
Tel: 508-485-8114
FAX: 508-485-8471
Tel: ++49 (0) 2741 2990
FAX: ++49 (0) 2741 299133
Tel: (886) 2-2516-7010
FAX: (886) 2-2506-9774
AVX Mid-Pacific, CA
AVX srl, Italy
AVX/Kyocera, China
Tel: 408-436-5400
FAX: 408-437-1500
Tel: ++390 (0)2 614571
FAX: ++390 (0)2 614 2576
Tel: (86) 21-6249-0314-16
FAX: (86) 21-6249-0313
AVX Southwest, AZ
AVX sro, Czech Republic
AVX/Kyocera, Malaysia
Tel: 602-539-1496
FAX: 602-539-1501
Tel: ++420 (0)467 558340
FAX: ++420 (0)467 558345
Tel: (60) 4-228-1190
FAX: (60) 4-228-1196
AVX South Central, TX
Elco, Japan
Tel: 972-669-1223
FAX: 972-669-2090
Tel: 045-943-2906/7
FAX: 045-943-2910
Kyocera, Japan - AVX
AVX Southeast, NC
Tel: (81) 75-604-3426
FAX: (81) 75-604-3425
Tel: 919-878-6357
FAX: 919-878-6462
Kyocera, Japan - KDP
AVX Canada
Tel: 905-564-8959
FAX: 905-564-9728
Tel: (81) 75-604-3424
FAX: (81) 75-604-3425
Contact:
A KYOCERA GROUP COMPANY
http://www.avxcorp.com
S-MPFDC13M599-C
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
