About Lifebreath
For over 25 years Airia Brands Inc. has manufactured indoor air quality products to a worldwide customer base. Product development, research, testing,
manufacturing, marketing, sales and technical support are headquartered at our 65,000 square foot facility in London, Ontario, Canada. We are
recognized worldwide for the quality and performance of our Lifebreath product line, our customer service and our technical support. We will continue
to lead the industry with technical innovations in our products, the highest level of customer support, superior warranties, and proven proficiency
in manufacturing.
Products
We hold seven U.S. patents including some of the most important and leading edge technologies in the industry, including:
heat recovery ventilator, air to air exchanger core (HRV core), combined furnace and heat recovery system, and more.
Many more patents are pending.
Our eco-friendly and energy efficient solutions include ECM motors in many models and standard
state-of-the-art digital controls that allow customers to personalize HRV operation for their
environment. We proudly manufacture the only five speed HRV available, with an included wall control.
Our patented aluminum HRV core carries a lifetime guarantee and is easily maintained. Just wash
and return. Our new ERV non-cellulose core will not deteriorate with moisture and is the only
water-washable ERV core available today. Everything in our line is designed for superior
performance and low maintenance to ensure complete installer and customer satisfaction.
Energy Star
A new ENERGY STAR® specification was introduced to the Canadian residential energy and heat recovery ventilator (ERV/HRV) industry
beginning January 2010. Airia Brands Inc., proud manufacturers of Lifebreath ® products are an active participant of this prominent program.
The ENERGY STAR® symbol identifies products that meet or exceed stringent energy efficiency criteria achieving uncompromised performance.
Our commitment to high performance and energy efficiency has always been of paramount importance to Airia Brands, and most Lifebreath®
residential products qualify for this important energy efficiency benchmark. ENERGY STAR® products may qualify for energy efficiency rebates.
Incentive programs vary by geography and date. Check industry programs in your area for qualifying incentives.
Look For This Symbol
This product earned the ENERGY STAR by meeting strict energy efficiency guidelines set by
Natural Resources Canada and the US EPA. This meets ENERGY STAR requirements only
when used in Canada.
Certified Lifebreath® HRV products include: RNC5-TPD, RNC 95, RNC 200, 95 MAX, 155 ECM, 195 ECM,
200 MAX, 200 MAX RX, 195 DCS and 300 DCS. See Ventilation section, pages 3-16 for more details.
INDEX
NEW FROM AIRIA
VENTILATION
HRV - Residential - MAX Series
2
HRV - Residential - RNC Series
3
11
ERV Series
17
Commercial Series
23
Pool Series
35
AIR CLEANING
TFP 3000 HEPA
37
HEATING / AIR HANDLING
Clean Air Furnace Series
Air Handler Series
39
47
IVS
53
INLINE FANS
Quantum Ventilation Series
55
59
Bathroom and Dryer Exhaust Series
LIFEBREATH ACCESSORIES
Ventilation Accessories
60
EasyAir Grilles and Fittings
61
62
Installation and Replacement
63
Controls and Timers
65
PRODUCT SELECTION GUIDELINES
66
TERMS AND CONDITIONS
68
For additional information about Lifebreath® products in this catalogue, downloads and much more, visit us at
www.lifebreath.com
1
NEW FROM AIRIA
RNC5-TPD
· Now with Door Port Balancing
· Unique Installer Selectable High Speed Setting,
accommodates multiple ventilation rates
· Smaller footprint saves space in utility room, while
still containing a full size heat recovery core
· Ideally suited for narrow installations
· Top ports add to ease of installation
· HVI and ENERGY STAR® certified
NEWDual Hood
· Saves installation time and money
· Requires only one 6 inch opening in exterior wall
to complete connections for intake/exhaust
· Highly robust design, with damage-resistant
metal construction through exterior wall
· Suitable for 5 or 6 inch connections
NEW
Hanging Strap System
EasyAir Grilles and Fittings
· Complete line of accessories that
complement the installation of all
Lifebreath ventilation products
· Now included with every Lifebreath Residential HRV
product* (*except RNC120D)
· Four heavy duty straps and S-hooks included
· Easy mount system enables pre-assembly on floor
· Leveling procedure greatly simplified with
adjustable clip
2
HR
V
Residentia
l
Dimensions: Inches (mm)
Dimensions: Inches (mm)
3
HR
V
Residenti
al
Dimensions: Inches (mm)
4
Dimensions: Inches (mm)
MAX SERIES
HR
V
Residenti
al
95 MAX
155 MAX / 155 MAX RX
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Weight: 52lbs (23.6Kg)
Dimensions: Inches (mm)
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
The RX version of this model is reverse flow.
The cold side ducting to the weatherhoods and damper
are located on the opposite side of the unit.
6
HR
V
HEAT RECOVERY VENTILATORS
MAX SERIES
HR
V
Residenti
al
95 MAX
155 MAX / 155 MAX RX
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Weight: 52lbs (23.6Kg)
Dimensions: Inches (mm)
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
The RX version of this model is reverse flow.
The cold side ducting to the weatherhoods and damper
are located on the opposite side of the unit.
6
HR
V
HEAT RECOVERY VENTILATORS
MAX SERIES
155 ECM
HR
V
Residentia
l
HEAT RECOVERY VENTILATORS
195 ECM
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
5 - High Speed
4 - Medium High Speed
5
3 - Medium Speed
2 - Medium Low Speed
1 - Low speed
4
3
2
1
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
Weight: 88lbs (40Kg)
Dimensions: Inches (mm)
7
MAX SERIES
HEAT RECOVERY VENTILATORS
HR
V
Residenti
al
200 MAX / 200 MAX RX
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
The RX version of this model is reverse flow.
The cold side ducting to the weatherhoods and damper
are located on the opposite side of the unit.
8
195 DCS
Weight: 88lbs (40Kg)
Dimensions: Inches (mm)
MAX SERIES
HR
V
Residentia
l
HEAT RECOVERY VENTILATORS
300 DCS
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 89lbs (40.5Kg)
Dimensions: Inches (mm)
9
11
HR
V
Residentia
l
HR
V
Residenti
al
12
RNC SERIES
Engineering Data
HR
V
Residentia
l
HEAT RECOVERY VENTILATORS
RNC 95
THERMALLY CONDUCTIVE, PATENTED ALUMINUM CORE
The cross-flow heat recovery core transfers heat between the two airstreams.
It is easily removed for cleaning or service.
MOTORS AND BLOWERS
Each air stream has one centrifugal blower driven by a common PSC motor.
2-speed fan operation.
RNC5-TPD and RNC 120 have two motors; one in each airstream.
RNC5-TPD has three selectable high speeds
FILTERS
Washable air filters in exhaust and supply air streams.
MOUNTING
Four threaded inserts at corners of the cabinet designed to accept the “s” hooks
and hanging straps supplied with the unit.
DEFROST - 2 Styles
Recirculating defrost system or damper defrost.
CASE
Twenty gauge prepainted galvanized steel for superior corrosion resistance.
Insulated to prevent exterior condensation. Drain connections 2 - 1/2" (12 mm)
OD.
CONTROLS & ELECTRONICS
· Built-in Relay for Interfacing to furnace
· A standard ON/OFF switch can be added to provide Low/High Ventilation
or ON/OFF functionality in order to meet building standards.
· Optional controls can be installed at the time of the installation
or at a later date
to upgrade the basic features of the ventilation system.
*Sensible Efficiency: thermal
OPTIONAL EQUIPMENT
CONTROLS
99-DX01
Lifestyle RNC Digital Control
· 2-Speed operation on each mode
· 4 user selectable operational modes: Continuous Ventilation, 20 ON/40 OFF,
20 ON/40 Recirculation, Continuous Recirculation
· Adjustable Dehumidistat function built into the main wall control
· Connect to (3 wire) 20 gauge wire (min.) 100’ length.
99-BC01
Lifestyle RNC Ventilation Control
· 2-Speed Fan setting (Low/High)
· Standby
· Dehumidistat
· Connect to (3 wire) 20 gauge wire (min.) 100’ length.
TIMERS
99-DET01
Lifestyle 20/40/60 Minute Timer - Initiates high speed ventilation for 20, 40,
or 60 minutes, (3 wire) 20 gauge wire (min.) 100’ length.
Weight: 52lbs (23.6Kg)
Dimensions: Inches (mm)
99-20M01
Lifestyle 20 Minute Timer - Initiates high speed ventilation for 20 minutes,
(3 wire) 20 gauge wire (min.) 100’ length.
ACCESSORIES
99-DH-01 Lifestyle Dehumidistat - Initiates high speed ventilation when the
indoor humidity level is above the set point. (3 wire) 20 gauge wire (min.)
100’ length.
99-190 Dual Hood - Suitable for 5” or 6” connections
99-185 Weatherhoods - Two - 5” (125 mm) c/w 1/4” (6 mm) mesh screen
99-186 Weatherhoods - Two - 6” (150 mm) c/w 1/4” (6mm) mesh screen.
Units carry a LIFETIME warranty
on the heat recovery core and a
5 year replacement parts warranty.
Many more accessory options available. See Accessories section for details.
All units conform to CSA and UL Standards.
13
RNC SERIES
HEAT RECOVERY VENTILATORS
HR
V
Residenti
al
RNC5-TPD
RNC 120D
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
HI 3 - High Speed
HI 2 - Medium High
HI 3
HI 1 - Medium Low
HI 2
HI 1
LOW
Weight: 61lbs (28Kg)
Dimensions: Inches (mm)
14
Weight: 61lbs (28Kg)
Dimensions: Inches (mm)
RNC SERIES
RNC 155
RNC 200
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
HR
V
Residentia
l
HEAT RECOVERY VENTILATORS
Weight: 71lbs (32.5Kg)
Dimensions: Inches (mm)
15
RNC SERIES
HEAT RECOVERY VENTILATORS
HR
V
Residenti
al
RNC 10
*Sensible Efficiency: thermal
*Sensible Efficiency: thermal
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 63lbs (28.7Kg)
Dimensions: Inches (mm)
16
RNC 20
Weight: 63lbs (28.7Kg)
Dimensions: Inches (mm)
17
ER
Resid.V/
Comm.
ER
V/
Resid.
Comm.
18
ERV SERIES
ER
Resid.V/
Comm.
ENERGY RECOVERY VENTILATORS
Engineering Data
CORES
120/150/200 ERV: The crossflow energy recovery core
transfers heat and vapour.
MOUNTING - NEW!
120/150/200 ERV: Four threaded inserts at corners of the
cabinet designed to accept the “s” hooks and hanging
500 ERV: Modular (4 section) 2-Enthalpic, 2 Aluminum straps supplied with the unit.
500 / 700 / 1200 ERV: Unit to be set on support brackets
700 ERV: Modular (2 section) enthalpic (moisture) transfer hung by threaded rod type apparatus (brackets and rods
not included).
cores arranged for efficient crossflow ventilation
arranged for high efficiency crossflow ventilation.
1200 ERV: Modular (3 section) latent recovery (moisture)
transfer cores arranged for efficient crossflow ventilation.
MOTORS
120 ERV: Each air stream has one PSC motor, 5 speed.
150/200 ERV: Each air stream has one centrifugal blower
driven by a common PSC motor, 5 speed fan operation.
High speed – 120 VAC.
CASE
Twenty gauge prepainted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
where required to prevent exterior condensation.
CONTROLS & ELECTRONICS
99-DXPL01 (included on 150/200/500 ERV units)
Lifestyle Digital Control
500 ERV: Two PSC, 5 speed double shafted 120 VAC, 3.15 Can be wall mounted in a central location of the home.
Amps each (6.3 total on high speed). HP – 1/10,
Connects to (3 wire) 20 gauge wire (min.) 100’ length.
1625RPM. Watts – total on high speed – 610.
Electronic features include:
700 ERV: Two PSC, 3 speed single shafted, 120 VAC, 2.75 · 5 Speed Operation on each mode
Amps each (5.5 total on high speed). HP – 1/10,
· 2 user selectable operational modes:
1625RPM. Watts – total on high speed – 648.
Continuous Ventilation, 20 ON/40 OFF
·
Humidity
Control through dehumidistat
1200 ERV: Two PSC, 3 speed double shafted, 120 VAC, 4
·
Adjustable
Dehumidistat function built into the main
Amps each (8.1 total on high speed). HP – 1/2, 1625RPM.
wall control
Watts – total on high speed – 972.
· Built-in Relay for interfacing to furnace
BLOWERS
OPTIONAL EQUIPMENT
120/150/200 ERV: Each air stream has one
centrifugal blower.
CONTROLS
500 ERV: Centrifugal type, rated at 530 cfm (250 L/s) free 99-LS01
air delivery. Each air stream has two centrifugal blowers
Lifestyle Programmable Control
driven by two PSC motors.
Contains all the features of the Lifestyle Digital Control
700 ERV: Centrifugal type, rated at 700 cfm (329 L/s) free with 7/24 programmable ventilation, 4 event feature
air delivery. Each air stream has one single shafted motor permits lifestyle programming. Connects to
(3 wire) 20 gauge wire (min.) 100’ length.
driving a centrifugal blower.
1200 ERV: Centrifugal type, rated at 1200 cfm (566 L/s)
free air delivery. Each air stream has one double shafted
motor driving a centrifugal blower.
FILTERS
Washable air filters in exhaust and supply air streams.
CONNECTION DUCT SIZES
120 ERV: 5” (127mm)
150/200 ERV: 6” (150mm)
500 ERV: Four – 14” x 8” (356mm x 200mm)
700 ERV: Four – 14” x 8” (356mm x 200mm)
1200 ERV: Four – 20” x 8” (508mm x 200mm).
Units carry a five year warranty
on the energy recovery core and a
5 year replacement parts warranty.
All units conform to CSA and UL Standards.
19
ERV SERIES
ENERGY RECOVERY VENTILATORS
ER
V/
Resid.
Comm.
120 ERV
*Sensible Efficiency: thermal
**Latent Efficiency: moisture
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Dimensions: Inches (mm)
20
150 ERV
*Sensible Efficiency: thermal
**Latent Efficiency: moisture
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 63lbs (28.7Kg)
Dimensions: Inches (mm)
ERV SERIES
200 ERV
*Sensible Efficiency: thermal
ER
Resid.V/
Comm.
ENERGY RECOVERY VENTILATORS
500 ERV
**Latent Efficiency: moisture
Effectiveness based on temperature differential between the
2 airstreams. Efficiency takes into account all power inputs.
Weight: 178lbs (81Kg)
Dimensions: Inches (mm)
Weight: 63lbs (28.7Kg)
Dimensions: Inches (mm)
21
ERV SERIES
ENERGY RECOVERY VENTILATORS
ER
V/
Resid.
Comm.
700 ERV
Weight: 178lbs (81Kg)
Dimensions: Inches
(mm)
22
1200 ERV
Weight: 191lbs (87Kg)
Dimensions: Inches
(mm)
23
HR
V
Commercia
l
HR
V
Commerci
al
24
COMMERCIAL
Engineering Data
HR
V
Commercia
l
HEAT RECOVERY VENTILATORS
500 DCS / 500 DCS-REV
CORES
Modular (4 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 5 speed double shafted, 120 VAC, 3.1 Amps each
(6.2 total on high speed). HP – 1/3, 1620 RPM.
Watts – total on high speed – 610.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 530 cfm (250 L/s) free air
delivery. Each air stream has two centrifugal blowers
driven by two PSC motors.
CONNECTION DUCT SIZES
Four – 14” x 8” (356mm x 200mm)
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connection, One – 1/2” (12mm) O.D.
DEFROST
Supply bypass damper routes indoor air to defrost cores.
CONTROLS & ELECTRONICS
The Lifestyle MAX Digital Control (99-DXPL01 included)
can be wall mounted in a central location. Connects to
(3 wire) 20 gauge wire (min.) 100’ length.
Features include:
· 5 speed operation on each mode
· 2 user selectable operational modes:
Continuous ventilation, 20 ON / 40 OFF
· Humidity Control through dehumidistat
· Adjust. Dehumidistat function built into main wall control
· Built-in relay for interfacing to furnace
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
Weight: 178lbs (81Kg)
Dimensions: Inches (mm) (500 DCS-REV Shown)
99-LS01 Lifestyle MAX Programmable Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
25
COMMERCIAL
HEAT RECOVERY VENTILATORS
HR
V
Commerci
al
Engineering Data
850 FD / 850 DD
CORES
Modular (6 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 3 speed double shafted, 120 VAC, 3.95 Amps
each (7.9 total on high speed). HP – 1/4, 1625 RPM.
Watts – total on high speed – 848.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 950 cfm (448 L/s) free air
delivery. Each air stream has one double shafted motor
driving a centrifugal blower.
CONNECTION DUCT SIZES
Three – 20” x 8” (508mm x 200mm). Stale air intake –
26” x 8” (660mm x 200mm).
Model 850DD – additional 20” x 8” defrost port.
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connections, two – 1/2” (12mm) O.D.
DEFROST
850 FD: Interrupts supply air while exhaust air
defrosts core.
850 DD: Supply bypass routes indoor air to
defrost core.
CONTROLS & ELECTRONICS
Integrated microprocessor circuit board. Built-in
interlock contacts. Automatic Self Test. Optional remote
speed control.
OPTIONS New
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
26
Weight: 255lbs (116Kg)
Dimensions: Inches (mm)
COMMERCIAL
Engineering Data
HR
V
Commercia
l
HEAT RECOVERY VENTILATORS
700 FD / 700 DD
CORES
Modular (2 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 3 speed single shafted, 120 VAC, 2.8 Amps each
(5.6 total on high speed). HP – 1/5, 1625 RPM.
Watts – total on high speed – 648.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 700 cfm (329 L/s) free air
delivery. Each air stream has one single shafted motor
driving a centrifugal blower.
CONNECTION DUCT SIZES
Four – 14” x 8” (356mm x 200mm)
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connections, two – 1/2” (12mm) O.D.
DEFROST
700 FD: Interrupts supply air while exhaust air
defrosts core.
700 DD: Supply bypass routes indoor air to
defrost core.
Weight: 155lbs (70Kg)
Dimensions: Inches (mm)
CONTROLS & ELECTRONICS
Integrated microprocessor circuit board. Built-in
interlock contacts. Automatic Self Test. Optional remote
speed control.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
27
COMMERCIAL
HEAT RECOVERY VENTILATORS
HR
V
Commerci
al
Engineering Data
700 FD PLUS / 700 DD PLUS
CORES
Modular (2 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 3 speed single shafted, 120 VAC, 4.5 Amps each
(9 total on high speed). HP – 1/4, 1450 RPM. Watts –
total on high speed – 1032.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 700 cfm (329 L/s) @ .5 in w.c.
Each air stream has one single shafted motor driving
a centrifugal blower.
CONNECTION DUCT SIZES
Four – 14” x 8” (356mm x 200mm)
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connections, two – 1/2” (12mm) O.D.
DEFROST
700 FD PLUS: Interrupts supply air while exhaust air
defrosts core.
700 DD PLUS: Supply bypass routes indoor air to
defrost core.
CONTROLS & ELECTRONICS
Integrated microprocessor circuit board. Built-in
interlock contacts. Automatic Self Test. Optional remote
speed control.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
28
Weight: 155lbs (70Kg)
Dimensions: Inches (mm)
COMMERCIAL
Engineering Data
HR
V
Commercia
l
HEAT RECOVERY VENTILATORS
1200 FD / 1200 DD
CORES
Modular (3 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 3 speed double shafted, 120 VAC, 4 Amps each
(8.1 total on high speed). HP – 1/4, 1625 RPM. Watts –
total on high speed – 972.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 1200 cfm (566 L/s) @ .5 in w.c.
Each air stream has one double shafted motor driving
a centrifugal blower.
CONNECTION DUCT SIZES
Four – 20” x 8” (508mm x 200mm)
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connections, two – 1/2” (12mm) O.D.
DEFROST
1200 FD: Interupts supply air while exhaust air
defrosts core
1200 DD: Supply bypass routes indoor air to
defrost core.
Weight: 191lbs (87Kg)
Dimensions: Inches (mm)
CONTROLS & ELECTRONICS
Integrated microprocessor circuit board. Built-in
interlock contacts. Automatic Self Test.
Optional remote speed control.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
29
COMMERCIAL
HEAT RECOVERY VENTILATORS
HR
V
Commerci
al
Engineering Data
1200 FD PLUS / 1200 DD PLUS
CORES
Modular (3 section) patented aluminum heat recovery
cores arranged for efficient cross-flow ventilation.
MOTORS
Two PSC, 3 speed double shafted, 120 VAC, 9.4 Amps each
(18.8 total on high speed).
HP – 1/2, 1625 RPM. Watts – total on high speed – 2256.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
Centrifugal type rated at 1200 cfm (566 L/s) @.5 in w.c.
Each air stream has one double shafted motor driving a
centrifugal blower.
CONNECTION DUCT SIZES
Four – 20” x 8” (508mm x 200mm)
MOUNTING
Unit to be set on support brackets hung by threaded rod
type apparatus (brackets and rods not included).
CASE
20 gauge pre-painted galvanized steel for superior
corrosion resistance. Insulated with foil faced insulation
duct liner where required to prevent exterior condensation.
Drain connections, two – 1/2” (12mm) O.D.
DEFROST
1200 FD PLUS: Interrupts supply air while exhaust air
defrosts core.
1200 DD PLUS: Supply bypass routes indoor air to
defrost core.
CONTROLS & ELECTRONICS
Integrated microprocessor circuit board. Built-in
interlock contacts. Automatic Self Test.
Optional remote speed control.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
30
Weight: 191lbs (87Kg)
Dimensions: Inches (mm)
COMMERCIAL
HR
V
Commercia
l
HEAT RECOVERY VENTILATORS
Engineering Data
1500 IFD / 1500 EFD
Engineering Data
2000 IFD / 2000 EFD
AIRFLOW
1500 cfm (705 L/s) at 1.0” wg ESP.
PERFORMANCE
65% effective at 1500 cfm (705 L/s).
CORES
Six patented aluminum heat recovery cores arranged for
efficient cross-flow ventilation.
MOTORS
Two single shaft ECM variable speed, 208/240V, 9.1 Amps,
1 ph, 1 hp, (18.2 amps total).
BLOWERS
Two direct drive centrifugal blowers, one per airstream.
FILTERS
Two – 20” x 16” x 2” (508mm x 406mm x 50 mm)
pleated filters in each airstream. MERV 6.
CONNECTION DUCT SIZES
1500 IFD: Four – 18” x 18” (457mm x 457mm).
1500 EFD: Two 19” x 16” (482mm x 406mm) to and from
building, under cabinet. Two 18” x 17” (457mm x 431mm)
hoods included on side of cabinet, with washable screens.
CABINET
20 gauge powder-coated galvanized steel 1” (25mm) thick.
Elastomeric insulation.
DEFROST
Factory set defrost time. Supply motor is shut off while
exhaust air defrosts core.
DRAIN
Two powder coated steel drain pans with 1/2” (12mm)
O.D. drain connections.
MOUNTING
Rooftop mounted on optional roof curb. (Part No. 53-1500)
CONTROLS & FUNCTION
Integrated microprocessor circuit board. Three
independently adjustable motor speeds.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
AIRFLOW
2000 cfm (940 L/s) at 1.0” wg ESP.
PERFORMANCE
65% effective at 2000 cfm (940 L/s).
CORES
Eight patented aluminum heat recovery cores arranged for
efficient cross-flow ventilation.
MOTORS
Two PSC. 2 hp, 1 ph, single speed, single shaft,
208/240VAC, 9.0 Amps (18 total).
Optional 460 V, 570 V, 3 phase
BLOWERS
Two belt drive centrifugal blowers with adjustable pulleys,
one per airstream.
FILTERS
Two – 16” x 25” x 2” (406mm x 635mm x 50 mm)
pleated filters in each airstream.
2 year limited.
15 year HRV Core, 5 year ERV Core.
CONNECTION DUCT SIZES
2000 IFD: Four – 18” x 22” (457mm x 558mm).
2000 EFD: Two 20” x 19” (508mm x 482mm) hoods
included with washable screens. Two 25” x 16” (635mm x
406mm) connections to and from building, under cabinet.
CABINET
20 gauge powder-coated galvanized steel exterior for
superior corrosion resistance. Unit includes metal lined
sides and roof panels with 2” fiberglass insulation (R8)
between linings.
DEFROST
Factory set defrost time. Supply motor is shut off while
exhaust air defrosts core.
DRAIN
Two powder coated galvanized steel drain pans with 1/2”
(12mm) O.D. drain connections.
MOUNTING
2000 IFD: Unit to be set on support brackets hung by
threaded rod type apparatus (brackets / rods not included).
2000 EFD: Optional roof curb. Part No. 53-2007.
CONTROLS & FUNCTION
Integrated microprocessor circuit board.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
All units conform to CSA and UL Standards.
31
COMMERCIAL
HEAT RECOVERY VENTILATORS
HR
V
Commerci
al
1500 IFD / 1500 EFD
32
2000 IFD / 2000 EFD
Dimensions 1500 IFD:
Weight: 480lbs (218Kg)
Dimensions 2000 IFD:
Dimensions 1500 EFD:
Weight: 480lbs (218Kg)
Dimensions 2000 EFD:
Weight: 750lbs (340Kg)
Weight: 750lbs (340Kg)
COMMERCIAL
Engineering Data
HR
V
Commercia
l
HEAT RECOVERY VENTILATORS
2500 IFD
AIRFLOW
2500 cfm (1175 L/s) at 1.0” wg ESP.
PERFORMANCE
70% effective at 2500 cfm (1172 L/s).
CORES
Single aluminum sensible heat recovery core. Plate-toplate type. Slides out of either side of cabinet for service.
MOTORS
Two single shaft PSC, 208/230V, 5.1 Amps, 1hp, 1ph, 3
speed motor (2 speeds selectable)
BLOWERS
Two direct-drive centrifugal blowers, one per air stream.
FILTERS
Two – 18” x 24” (457mm x 610mm) 4-inch pleated filters
in each air stream.
Weight: 700lbs (318Kg)
Dimensions: Inches (mm)
CONNECTION DUCT SIZES
Four – 24” x 16” (610mm x 406mm).
CABINET
20 gauge powder-coated galvanized steel exterior for
superior corrosion resistance. 16 gauge galvanized frame,
insulated with 1” fiberglass insulation to prevent
condensation.
DEFROST
Factory set defrost time. Supply motor is shut off while
exhaust air defrosts core. Two defrost times available.
DRAIN
Two stainless steel drain pans with 1/2” (12mm) NPT drain
spouts.
MOUNTING
Unit can be set on floor or support brackets hung by
threaded rod type apparatus. Brackets and rods
not included.
CONTROLS & FUNCTION
Integrated microprocessor circuit board, optional remote 2
speed control, built in interlock contacts.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
33
COMMERCIAL
HEAT RECOVERY VENTILATORS
HR
V
Commerci
al
Engineering Data
2500 EFD
AIRFLOW
2500 cfm (1175 L/s) at 1.0” wg ESP.
PERFORMANCE
70% effective at 2500 cfm (1172 L/s).
CORES
Single aluminum sensible heat recovery core. Plate-toplate type. Slides out of either side of cabinet for service.
MOTORS
Two single shaft PSC, 208/230V, 5.1 Amps, 1hp, 1ph, 3
speed motor (2 speeds selectable)
BLOWERS
Two direct-drive centrifugal blowers, one per air stream.
FILTERS
Two – 18” x 24” (457mm x 610mm) 4-inch pleated filters
in each air stream.
Weight: 700lbs (318Kg)
Dimensions: Inches (mm)
CONNECTION DUCT SIZES
Two - 24” x 16” (610mm x 406mm) to and from the
building, under cabinet. Two 28” x 18” (711mm x 457mm)
hoods, included on side of cabinet with screens.
CABINET
20 gauge powder-coated galvanized steel exterior for
superior corrosion resistance. 16 gauge galvanized frame,
insulated with 1” fiberglass insulation to prevent
condensation.
DEFROST
Factory set defrost time. Supply motor is shut off while
exhaust air defrosts core. Two defrost times available.
DRAIN
Two stainless steel drain pans with 1/2” (12mm) NPT drain
spouts.
MOUNTING
Rooftop mounted on optional roof curb. Part No. 53-2500.
CONTROLS & FUNCTION
Integrated microprocessor circuit board, optional remote 2
speed control, built in interlock contacts.
OPTIONS
99-DETO1 Digital Electronic Timer – 20/40/60 min
99-BC01 Lifestyle RNC Ventilation Control
99-DH01 Remote Wallmount Dehumidistat Control
99-500 3 Speed Control
34
2 year limited.
15 year HRV Core, 5 year ERV Core.
All units conform to CSA and UL Standards.
COMMERCIAL-POOL
HR
V
Poo
l
HEAT RECOVERY VENTILATORS
Engineering Data
700 POOL / 1200 POOL
CORES
Modular (2 section-model 700 / 3 section-model 1200)
patented aluminum heat recovery cores arranged for
efficient cross-flow ventilation. Meets the flame spread
and smoke developed classifications of the National
Building Code and NFPA 90A (1993 Edition).
All units carry a 15 year warranty
on the heat recovery cores and a
2 year replacement parts warranty.
All units conform to CSA and UL Standards.
MOTORS
700 POOL: Two PSC, 3 speed single shafted,
120 VAC, 4.5 Amps each (9 total on high speed).
HP - 1/4, 1450 RPM.
1200 POOL: Two PSC, 3 speed double shafted,
120 VAC, 9.4 Amps each (18.8 total on high speed).
HP - 1/2, 1625 RPM.
FILTERS
Washable air filters in exhaust and supply air streams.
BLOWERS
700 POOL: Each air stream has one single shafted motor
driving a centrifugal blower.
1200 POOL: Each air stream has one double shafted motor
driving 2 centrifugal blowers.
CONNECTION DUCT SIZES
700 POOL: Five - 14" x 8" H (356 mm x 200 mm).
1200 POOL: Five - 20" x 8" H (305 mm x 200 mm).
MOUNTING
Unit to be set on brackets or suspended by threaded rod.
(brackets and rod not provided).
CASE
Prepainted galvanized steel for superior corrosion
resistance. Insulated with closed cell foam insulation
where required to prevent exterior condensation.
Drain connections; two - 1/2” (12 mm) O.D.
CONTROLS & FUNCTION
Integrated microprocessor circuit board. Built-in interlock
contacts. Includes remote dehumidistat (Part# 99-DH01).
Optional 20/40/60 Minute timer (Part# 99-DET01).
DEFROST
Supply bypass routes indoor air to defrost core.
WEIGHT
700 POOL: Weight 155 lbs. (70 kg).
1200 POOL: Weight 210 lbs. (95 kg).
35
COMMERCIAL-POOL
HEAT RECOVERY VENTILATORS
HR
V
Po
ol
700 POOL
Weight: 155lbs (70Kg)
Dimensions: Inches (mm)
36
1200 POOL
Weight: 210lbs (95Kg)
Dimensions: Inches (mm)
TFP 3000
HEPA
Air
Cleaner
Dimensions: Inches (mm)
Dimensions: Inches (mm)
37
TFP 3000 HEPA
AIR CLEANER
Engineering Data
TFP 3000 HEPA
TFP 3000
HEPA
Air
Cleaner
MOTOR AND BLOWER
2 speed, high efficiency PSC Motor - 150 cfm/75 cfm.
110 watts - 120 VAC - standard three prong plug to
receptacle. The TFP is equipped with a standard power
cord 5’5” (1.6 meters) long.
OFF/LOW/HIGH SPEED SELECTOR SWITCH
Select 75 cfm (Low) or 150 cfm (High).
AIRFLOW
150cfm @ .4" WC (High Speed)
75 cfm @ .4" WC (Low Speed)
COLLECTORS
One replaceable TFP collector and one replaceable
HEPA filter
· Easy to remove for cleaning and replacement
· Annual inspection recommended
Dimensions: Inches (mm)
CASE
Twenty gauge prepainted galvanized steel for superior
corrosion resistance
WEIGHT
55 lbs. (24.4 Kgs)
ELECTRICAL CODES
Conforms to CSA and UL standards
MOUNTING THE WHOLE HOME TFP - VERY FLEXIBLE
· Mount to the furnace return
· Mount between the HRV and the furnace
· Hang from a joist and duct to the furnace
REPLACEMENT OPTIONS
65-503R - One replacement TFP collector
65-502R - One replacement HEPA filter
Optional Installation Kit: Part # 99-TFP
Includes:
- Two 7” duct connection collars
- 12.5’ of 7” non-insulated flex duct
- Four nylon duct zip ties
Five year warranty
on all replacement parts except
the collectors/filters.
Conforms to CSA and UL Standards.
38
39
CA
F
Hydroni
c
CA
F
Hydron
ic
40
41
CA
F
Hydroni
c
CA
F
Hydron
ic
42
CLEAN AIR FURNACE
HYDRONIC SERIES
Model Number Nomenclature Breakdown
CA
F
Hydroni
c
CAF - Clean Air Furnace (Built-in HRV)
Refer to AH (Air Handler) specifications if
a built-in HRV is not required
U - Upflow - Return Air off Left or Right side
D - Downflow - Return air off Left side, Right side or Top
(not available for L2A or 00 Coils)
H - Horizontal - Return on Left side only
(not available for L2A or 00 Coils)
Available Clean Air
Furnace Models
CAF-U-S4A-24-P16(E16)
CAF-D-S4A-24-P16(E16)
CAF-H-S4A-24-P16(E16)
CAF-U-L4A-36-P16(E16)
CAF-D-L4A-36-P16(E16)
CAF-H-L4A-36-P16(E16)
CAF-U-L2A-48-P16(E16)
CAF-U-00-24-P16(E16)
CAF-U-00-36-P16(E16)
CAF-U-00-48-P16(E16)
S4A - Small Coil - 4 Row Coil
L2A - Large Coil - 2 Row Coil
(available in upflow only)
L4A - Large Coil - 4 Row Coil
00 - No Hydronics - No Heating Coil, No Pump
(available in upflow only)
* CFM (High Speed)
Cooling Capacity
Refer to individual specification pages
for Hydronic Coil and Blower
outputs and configurations.
Units carry a lifetime warranty on the
heat recovery (aluminum) core, a five year warranty
on the energy recovery (enthalpic) core and a five year
replacement parts warranty on all other components.
All units conform to CSA and UL Standards.
43
CLEAN AIR FURNACE
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
CAF-D-S4A-24-P16 / CAF-H-S4A-24-P16 / CAF-U-S4A-24-P16
Technical Specifications
CA
F
Hydron
ic
CAF-D-S4A-24-P16
CAF-H-S4A-24-P16
CAF-U-S4A-24-P16
Dimensions
CAF-D-S4A-24-P16
CAF-H-S4A-24-P16
Engineering Data
CORE
Ventilation system has patented aluminum heat recovery core
(standard) or an enthalpic energy recovery core (optional) for
energy-efficient ventilation. Enthalpic cores are recommended
for regions where temperature does not drop below 25F (-4C).
FILTERS
Washable air filters in exhaust and supply air streams of
ventilation section. 1" (25mm) pleated in return plenum side.
CASE
Pre-painted galvanized steel for superior corrosion resistance.
OPTIONS
99-186
Weatherhoods, Two - 6" (150cm) c/w 1/4"
(6mm) mesh screen
99-DH01 Remote wall mount dehumidistat control
99-RSK6 6" (150mm) Backdraft damper
99-DET01 Digital Electronic Timer
44
CAF-U-S4A-24-P16
CLEAN AIR FURNACE
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
CAF-D-L4A-36-P16 / CAF-H-L4A-36-P16 / CAF-U-L4A-36-P16 / CAF-U-00-36-P16*
CAF-D-L4A-36-P16
CAF-H-L4A-36-P16
CAF-U-L4A-36-P16 CAF-U-00-36-P16*
Dimensions
CAF-D-S4A-36-P16
CA
F
Hydroni
c
Technical Specifications
CAF-H-S4A-36-P16
Engineering Data
CORE
Ventilation system has patented aluminum heat recovery core
(standard) or an enthalpic energy recovery core (optional) for
energy-efficient ventilation. Enthalpic cores are recommended
for regions where temperature does not drop below 25F (-4C).
CAF-U-S4A-36-P16 / CAF-U-00-36-P16
FILTERS
Washable air filters in exhaust and supply air streams of
ventilation section. 1" (25mm) pleated in return plenum side.
CASE
Pre-painted galvanized steel for superior corrosion resistance.
OPTIONS
99-186
Weatherhoods, Two - 6" (150cm) c/w 1/4"
(6mm) mesh screen
99-DH01 Remote wall mount dehumidistat control
99-RSK6 6" (150mm) Backdraft damper
99-DET01 Digital Electronic Timer
45
CLEAN AIR FURNACE
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
CAF-U-L2A-48-P16 / CAF-U-00-48-P16
Technical Specifications
CAF-U-L2A-48-P16
CAF-U-00-48-P16*
CA
F
Hydron
ic
Engineering Data
CORE
Ventilation system has patented aluminum heat recovery core
(standard) or an enthalpic energy recovery core (optional) for
energy-efficient ventilation. Enthalpic cores are recommended
for regions where temperature does not drop below 25F (-4C).
FILTERS
Washable air filters in exhaust and supply air streams of
ventilation section. 1" (25mm) pleated in return plenum side.
CASE
Pre-painted galvanized steel for superior corrosion resistance.
OPTIONS
99-186
Weatherhoods, Two - 6" (150cm) c/w 1/4"
(6mm) mesh screen
99-DH01 Remote wall mount dehumidistat control
99-RSK6 6" (150mm) Backdraft damper
99-DET01 Digital Electronic Timer
46
Dimensions
CAF-U-L2A-48-P16 / CAF-U-00-48-P16
47
Air
Handler
Serie
s
Air
Handler
Serie
s
48
AIR HANDLER
HYDRONIC SERIES
Model Number Nomenclature Breakdown
AH - Air Handler (No HRV)
Refer to CAF (Clean Air Furnace) specifications if
a built-in HRV is required
U - Upflow - Return Air off Left or Right side
D - Downflow models are unavailable for Air Handlers
H - Horizontal models are unavailable for Air Handlers
AH-U-S2A-30-P16(E16)
AH-U-S4A-24-P16(E16)
AH-U-L2A-48-P16(E16)
AH-U-L4A-36-P16(E16)
AH-U-L2B-48-P16(E16)
S2A - Small Coil - 2 Row Coil
S4A - Small Coil - 4 Row Coil
L2A - Large Coil - 2 Row Coil
L4A - Large Coil - 4 Row Coil
L2B - Large Coil - 2 Row Coil
Air
Handler
Serie
s
Available Air
Handler Models
* CFM (High Speed)
Cooling Capacity
Refer to individual specification pages
for Hydronic Coil and Blower
outputs and configurations.
Units carry a five year replacement parts warranty
on all components.
All units conform to CSA and UL Standards.
49
AIR HANDLER
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
AH-U-S4A-24-P16
Coil Output (1000’s of BTUH)
AH-U-S2A-30-P16
Air
Handler
Serie
s
Technical Specifications
Technical Specifications
AH-U-S4A-24-P16
AH-U-S2A-30-P16
Dimensions
AH-U-S4A-24-P16 / AH-U-S2A-30-P16
50
AIR HANDLER
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
AH-U-L2A-36-P16
Coil Output (1000’s of BTUH)
AH-U-L4A-36-P16
Technical Specifications
AH-U-L2A-36-P16
Air
Handler
Serie
s
Technical Specifications
AH-U-L4A-36-P16
Dimensions
AH-U-L2A-36-P16 / AH-U-L4A-36-P16
All units have an upflow configuration
51
AIR HANDLER
HYDRONIC SERIES
Coil Output (1000’s of BTUH)
AH-U-L2B-48-P16
Technical Specifications
AH-U-L2B-48-P16
Air
Handler
Serie
s
Dimensions
AH-U-L2B-48-P16
All units have an upflow configuration
52
53
IV
S
IV
S
54
55
Inline
Fans
Inline
Fans
56
57
Inline
Fans
Inline
Fans
58
QVS SERIES
Quantum® In-Line Fan Series
All fans are commercial and residential certified; temperature rated -40°F to 140°F, 120 Volt/60Hz
NBQ125-4
Airflow CFM (L/s)
Part
.2 (95 Pa)
Number
Features
Description
4” Dedicated Plastic
· Multi-position metal bracket included
120 CFM
99-NBQ-125-4
· Field selectable 4”, 5” or 6” duct
connection collars incl.
· Multi-position metal bracket included
180/
240/
270 CFM
99-NBQ-COMBI
4/5/6
NBQ325-6
· Multi-position metal bracket included
350 CFM
99-NBQ325-6
6” Dedicated Plastic
NBQ-440-8
· 8” pre-painted galvanized steel
· Multi-position metal bracket included
440 CFM on Hi
350 CFM on Low
99-NBQ-440-8
6” Dedicated Plastic
NBQ-700-10
· 10” pre-painted galvanized steel
· Multi-position metal bracket included
690 CFM on Hi
350 CFM on Low
99-NBQ-700-10
Mixed flow inline duct exhaust fan
NBQ-950-12
· 10” pre-painted galvanized steel
· Multi-position metal bracket included
950 CFM on Hi
600 CFM on Low
99-NBQ-950-12
Mixed flow inline duct exhaust fan
NBQ-COMBI-4/5/6
Fan Kits
QVS KIT
Combi fan.
Plastic 4”/5”/6”.
Components
Includes: NBQ-COMBI 4/5/6 fan, E-Box, 99-BC-01 (Ventilation Control), 2 x 99-DET01
(20/40/60 Minute Timers) and fan mounting bracket.
Part Number
93-QVS KIT
QVS KIT PLUS
Includes: NBQ-COMBI 4/5/6 fan, E-Box, 99-DX-01 (Digital Control), 2 x 99-DET01
(20/40/60 Minute Timers) and fan mounting bracket.
93-QVS KIT PLUS
QVS KIT -001
Remote E-Box only, for QVS Kit
93-QVS KIT-001
QVS
Series
Model
Number
59
BATH AND DRYER
EXHAUST SERIES
Bathroom Exhaust Kits
Bath Exhaust Kit
Options
Features
Part
Airflow CFM (L/s)
.2 (95 Pa)
Number
Bath Exhaust
Kit 4
4” Plastic Fan with mounting bracket, 4”
Tech grille and 4” Damper/collar.
120 CFM
Bath Exhaust
Kit Combi
COMBI 4/5/6 Fan with mounting bracket,
(2) 6” Tech grilles, 2 (6”) dampers.
180 CFM
270 CFM
Bath Exhaust
System
COMBI 4/5/6 Fan, BES Control Box, Fan
Speed Selection
99-BEK-4
99-BEK-COMBI
99-CAF-BESKIT
Description
4” Plastic Fan
Combi Fan
For use with a Lifebreath
Clean Air Furnace.
(See illustration below)
Dryer Exhaust Kits
Dryer Exhaust Kit
Options
Dryer Booster
Kit 4
Features
Airflow CFM (L/s)
Part
.2 (95 Pa)
Number
4” Plastic Fan with mounting bracket,
and Pressure Switch.
120 CFM
Dryer Booster Kit COMBI Fan with mounting bracket, and 180 CFM - 270 CFM
Current Switch.
Combi
Current Switch
Bathroom and
Dryer
Exhaust
Series
60
Superior to different pressure switches
120 VAC @ 2.5 Amps Max
Description
99-DBK-4-PRES
4” Plastic Fan
99-DBK-COMBI
Combi Fan
99-CSS
ACCESSORIES
Ventilation Accessories
Features
Part Number
Dual · Requires only one 6” opening for intake/exhaust
Hood · Robust design, with damage-resistant metal construction
99-190
for
exterior wall connection
· Durable rigid plastic for duct connections
· Fire-rated, UV resistant materials
A breakthrough design. Requires only one
6” opening for intake/exhaust connections.
Ideal for space constrained HRV
or ERV applications
Weatherhood · High density polyethylene for long life even in severe climates
99-185
Kits · Screens include to block entry by small animals, large
insects
· No moving parts, eliminates freezing or sticking potential
99-186
99-187
99-186-LT
Flow-Thru · Suits any forced warm air heating system
Humidifier · Unique electronically pulsed; reduces water
Description
99-Flothru
consumption
by up to 80%
· Left/right side flexible duct installation; mounts on supply
or return duct
Ideal for HRV, ERV and Inline apps.
Two 5” diameter hoods, 12” wall sleeve,
duct collar, white plastic
As above - 6” option
As above - 7” option
Two 6" diameter hoods without
sleeve or collar
Electronic controller pulses solenoid
water supply valve for 4 sec ON and
30 sec OFF, allowing evaporator pad
to be fully saturated while drastically
limiting water waste.
99-CAF-BESKIT Perfect way to ventilate specific locations
Bathroom
with a Clean Air Furnace.
Exhaust · Exhausts multiple areas quietly and economically, while
providing heat recovery thru the CAF.
System
(BES) · Includes: BES Control box, 4/5/6 Combi Fan,
Fan speed selection.
In-Line
Duct Heater · Equipped with highly advanced Electronic Modulating
Controller (SCR) and Air Flow Sensor to minimize
operating cost
· 120V, 1 phase
· Automatic reset prevents overheating, manual reset, coil
elements made of nickel-chrome resistance wire, corrosionresistant galvanized steel enclosure, air flow sensor, built-in
electronic temperature control and sensor, round
collars
simplify installation and reduce labour time.
99-160
99-161
99-163
99-164
99-159
7” diameter, 1KW, 120V/1phase
7” diameter, 2KW, 120V/1phase
6” diameter, 1KW, 120V/1phase
6” diameter, 2KW, 120V/1phase
Special Orders. Call for info.
Allows HRV to recover maximum heat,
and duct heater modulates output
required to reheat air to the desired
temperature. This system is generally
only used when the HRV has a fully
dedicated duct system.
Scrubber™ · Combats wood smoke, outside odours, dust, pollen and
airborne pollutants from entering the home.
Air
Treatment · Pre-filter mesh polyester fibre traps larger particles
System · Media Filter is a large (50mm/2in) pleated filter
94-600
94-600-7
94-601
· Activated carbon filters function as purifying absorption
nets,
trapping odours and impurities.
· Includes: 1 pre-filter, 1 pleated filter, and 5 carbon filters
Scrubber is installed after the HRV/ERV
in supply air.
Freshvent · Ventilates during low speed or hihh speed operation
Air-to-Air · 2 speed motor
Exchanger · Washable foam filter
99-1001DX
94-1001DXB
94-1001DXPRO
Summer · Unique design allows air to pass through without
transferring heat.
Core
68-250
· Slides in place of existing heat exchange core.
6” ports; includes one filter pack
7” ports; includes one filter pack
Filter pack replacement
35 CFM ventilation
70 CFM ventilation
85 CFM ventilation
Designed to take advantage of free
outdoor cooling for use in climates with
cooler summer night air.
Accessorie
s
61
ACCESSORIES
EasyAir Grilles and Fittings
Features
TechGrille™
Part Number
Description
· Fully adjustable ventilation grille.
· Center adjustment cone spins In-and-out, providing
variable
ventilation capacity.
· No screws required.
· Compression spring tabs clip the grille into 4”, 5”, 6” or 8”
round duct.
· Cool white, non-corrosive material
99-EAG4
99-EAG5
99-EAG6
99-EAG8
4” diameter
5” diameter
6” diameter
8” diameter
· Adapts to 4”/6” Tech Grille (see above)
· Fits neatly in 2”x4” walls
· Quick rough-in, and easy to secure
99-WF4
99-WF6
4” elbow
6” elbow
Quick Mount · All plastic design, will not sweat or rust
Fittings · Simple to install, saves time
99-QM4
99-QM5
99-QM6
4” diameter
5” diameter
6” diameter
99-CF4
99-CF5
99-CF6
99-CF-8
4” diameter
5” diameter
6” diameter
8” diameter
99-RIMF4
99-RIMF5
99-RIMF6
99-RIMF8
4” diameter
5” diameter
6” diameter
8” diameter
99-LIP8
Fits 8” round duct
Stack Head
Elbow
· Suitable for ceiling or wall applications
Ceiling/Wall · Complements Tech Grille; choose size to match
Fittings · Cool white, all plastic design
Rough In
Metal Fitting
· Metal
· Straps onto floor joists
· Available in 4 sizes
Lay In Ceiling · Full adjustable air flow
Diffuser · Non-sweating, won’t rust or dent
Accessori
es
· White finish, paintable, washable
Kitchen · White, Hinged 6”x10” exhaust grille.
Grille · Easy access to washable aluminum grease filter
(included).
62
10-002
10-002-2
Kit, includes 1 grease filter.
Replacement Grease filter only
ACCESSORIES
Installation and Replacement Accessories
Hanging · INCLUDED with all MAX & RNC products (except RNC 120D)
Strap · Easy mount system enables pre-assembly on floor
System · Adjustable clip simplifies leveling procedure
Airflow Measuring Flow Measuring Station
Equipment
Balancing Kit (Flow Station Style): Magnehelic gauge.
Includes
flow stations, hoses and carrying case.
Pitot Tube Balancing Kit, Magnehelic gauge, Pitot Tube, Hoses
and Carrying Case.
Part Number
99-80-102
HRV .5” ID Clear flexible vinyl drain hose, 100’/box
Miscellaneous 6” Diameter Balancing Collar
6” Spring-Loaded Back-draft Damper
Merv 8 Pleated filter Pack (6)
6” Duct Silencer
Mitre 4” Diameter, Plastic
Elbows 4” Diameter, Galvanized
5” Diameter, Galvanized
6” Diameter, Galvanized
Lint Trap
Lint Trap.
Pull out door with view window.
TFP Accessories Replacement TFP3000 Collector
Includes 4 heavy duty straps
and 4 S-hooks
99-150
99-152
99-153
99-155
5” Diameter
6” Diameter
7” Diameter
8” Diameter
99-166-5
99-166-6
5” Diameter
6” Diameter
99-167
Kit
99-168
Balancing kit for models 155 MAX, 200 MAX and
RNC5-TPD
Description
Pitot Tube only
99-181
99-200
99-165
99-122
99-RSK6
99-MERV8-6
99-SILENCER-6
Magnehelic Gauge only.
Also available in
4/5/8/10/12 diameters
Note: Not compatible with
95MAX, 195/300DCS.
6” port
10-001P
10-001
10-095
10-096
99-136
65-503R
Replacement HEPA Filter (for TFP3000)
Installation Kit.
65-502R
99-7TFP
Replacement filter kit (for TFP2000)
99-179
Accessorie
s
Features
Metal, with removable
2 ply lint screen
Annual replacement
recommended
Replace every 2-3 years.
Includes 7” Flex Duct, 2 – 7” Collars, 4
Nylon Ties.
6 Filters – approx 20”x20”x1”.
63
Controls
and
Timer
s
64
ACCESSORIES
Lifestyle Controls
Included
with all
MAX units
Optional
upgrade on
MAX units
Optional
on RNC
99-DXPL01 Digital Control
99-LS01 Programmable Control
99-DX01Digital Control
All Features of 99-DXPL01, plus: · 4 selectable operational modes*
· 5-speed operation
*Not available on all models
· DELUXE fully featured 5-speed,
· 4 user operational modes
· 2 speed operation on each mode
4 mode unit.
- continuous ventilation
- 20 min. ON, 40 min. OFF
· Fully PROGRAMMABLE, 4-event · Adjustable dehumidistat function
- 20 min. ON, 40 min. recirculation*
feature allows customization
· Dehumidistat disable
according to lifestyle.
- Continuous recirculation*
*Not available on all models
· Built-in interface to furnace
· Automatic service reminder
· Automatic control based on
outdoor temperature sensing.
99-DH01 Dehumidistat
· Initiates high speed
ventilation when the
indoor humidity level
is above the set point.
Optional
on RNC
Controls
andTimer
s
99-BC01 Ventilation Control
· 2 Speed operation
· Standby
· Unit On/Off
· Dehumidistat
Optional
on RNC
Timers
99-DET01
20/40/60 Minute Timer
· Initiate high speed operation
for 20, 40 or 60 minutes.
99-20M01
20 Minute Timer
· Initiates high speed operation
for 20 minutes.
(Both timers available on MAX and RNC Series)
65
SELECTION
Selecting the Right Size HRV
RESIDENTIAL Applications
The home ventilation system can be sized using room counts or by using whole-house ventilation. Using a whole-house ventilation rate of 0.3 ACH
(Air Changes per Hour) the HRV CFM has been determined for the following homes (basement included in calculations).
Condominium
(800 sq. ft.)
Bungalow
(2,800 sq. ft.)
Two Storey
(4,800 sq. ft.)
Two Storey
(5,500 sq. ft.)
800 sq.ft. x 8'h
(6,400 cu.ft.)
2,800 sq.ft. x 8'h
(22,400 cu.ft.)
4,000 sq.ft. x 8'h
(32,000 cu.ft.)
5,500 sq.ft. x 8'h
(44,000 cu.ft.)
6,400 cu. Ft./60
(106 CFM)
22,400 cu. Ft./60
(373 CFM)
32,000 cu. Ft./60
(534 CFM)
44,000 cu. Ft./60
(733 CFM)
106 CFM x 0.3 ACH
(32 CFM)
373 CFM x 0.3 ACH
(112 CFM)
534 CFM x 0.3 ACH
(160 CFM)
733 CFM x 0.3 ACH
(220 CFM)
Square
CFM
Footag
Ceilin
e
(Includi
required
ng
based on
Baseme g 8
0.35 70
nt 1500
9
79
(FT²) Heigh air
t 10 exchanges
88
(FT)
per hour
8
93
2000
9
105
10
117
2500
3000
3500
4000
Selecti
on
4500
8
9
117
131
10
8
146
140
9
158
10
8
9
10
8
9
10
8
9
10
175
163
184
204
187
210
233
210
236
263
95
RNC
MAX
RNC
95
RECOMMENDED RESIDENTIAL HRV
155 MAX
200 MAX
155 MAX
195
RX
200 MAX
RNC
300
155 ECM
RX
RNC 155
RNC 200
ECM
120D
5-TPD
195
DCS
Severe Conditions
DCS
Pacific
Conditions
Moderate
Conditions
HRV Recommended
ERV Recommended Extreme Area
High Humidity
Arid Zone
Dry Climate
ERV’s recommended in regions where high humidity
causes operation of air conditioning/dehumidification
more frequently than a heating system.
ERV’s are not recommended where temperatures
fall below 25 ºF (-4 ºC) for more than five days.
COMMERCIAL & INDUSTRIAL Applications
For outdoor air requirements, ASHRAE has produced the Ventilation Standard 62.1-2007 that is used to determine acceptable ventilation rates.
This standard is referenced directly or used as "Good Engineering practice" in most Code documents or design criteria.
Small
Restaurants,
Coffee Shops
66
Beauty &
Nail Salon
Bar,
Cocktail
Lounge
Health Club, Classrooms &
Dance Club, School Portables
Disco
(Age 9+)
Large
Public
Venue
Occupants
40
18
100
180
35
125
Staff
5
5
15
20
1
25
Total
45
23
115
200
36
150
ASHRAE req
(per person)
10 CFM
(5L/s)
20 CFM
(10L/s)
7.5 CFM
(3.75L/s)
20 CFM
(10L/s)
10 CFM
(5L/s)
5 CFM
(2.5L/s)
Ventilation req
(total xASHRAE)
450 cfm
(225 L/s)
460 cfm
(230 L/s)
862.5 cfm
(431.25 L/s)
4000 cfm
(2000 L/s)
360 cfm
(180 L/s)
750 cfm
(375 L/s)
SELECTION
Selecting the Right Size CAF / Air Handler
CLEAN AIR FURNACE - Hydronic
Model
Description
Output Range
Add on A/C
Capacity (Tons)
STANDARD PSC MOTOR
CAF-U-S4A-24-P16
CAF-U-L4A-36-P16
CAF-U-L2A-48-P16
Upflow
34,000 to 85,000
38,000 to 110,000
25,000 to 68,000
2
3
4
CAF-D-S4A-24-P16
CAF-D-L4A-36-P16
Downflow
34,000 to 85,000
38,000 to 110,000
2
3
CAF-H-S4A-24-P16
CAF-H-L4A-36-P16
Horizontal
34,000 to 85,000
38,000 to 110,000
2
3
Upflow
N0 Heat
2
3
4
CAF-U-S4A-24-E16
CAF-U-L4A-36-E16
CAF-U-L2A-48-E16
Upflow
34,000 to 85,000
38,000 to 110,000
25,000 to 68,000
2
3
4
CAF-H-S4A-24-E16
CAF-H-L4A-36-E16
Horizontal
34,000 to 85,000
38,000 to 110,000
2
3
CAF-U-00-24-P16
CAF-U-00-36-P16
CAF-U-00-48-P16
The Lifebreath Hydronic Clean Air Furnace uses the heat from
a hot water heater or boiler system to warm the circulating air.
Air returning to the furnace passes through an integral heat
recovery ventilator. Users enjoy a constant supply of fresh
healthy air and minimal energy costs.
UPGRADE ECM MOTOR
99-CAF-BESKIT
ECM motor is recommended
by the manufacturer for both new and
retrofit construction.
Kit (3-items) Includes: BES control box,
Quantum 4/5/6 Combi Fan, Fan speed selection
SELECTING THE CORRECT AIR HANDLER
Description
Output Range
Add on A/C
Capacity (Tons)
HYDRONIC
AH-U-S4A-24-P16
AH-U-L4A-36-P16
AH-U-S2A-30-P16
AH-U-L2A-36-P16
AH-U-L2B-48-P16
Upflow
34,000 to 85,000
38,000 to 110,000
27,000 to 56,000
25,000 to 68,000
38,000 to 79,000
2
3
2.5
3
4
The Lifebreath Air Handler is a forced air combo type heating
system. Combo systems use the hot water supplied by a
water heater or boiler. Thus, only one heating appliance is
needed to meet hot water and home heating demands.
System maximizes efficiency by minimizing "stand-by losses."
When heat is required, hot water is circulated through the coil
in the air handler and air blown through the coil picks up the
heat and delivers to the home. The water is then returned to
the water heater for water or heating use.
Selectio
n
Model
Lifebreath Academy
Our Residential HRV course and Membership helps
prepare you for the installation and promotion of Lifebreath
Heat Recovery Ventilators. HRV Duct Sizing Software is
included with the course materials.
The topics covered include:
- benefits of ventilation
- calculating the amount of ventilation required
- designing a simplified, partially dedicated, and
fully dedicated duct system
- correctly sizing the system
- selecting the controls
Successful completion of the course and exam qualifies you to
promote yourself as a "factory trained" member of the Lifebreath
Academy. Membership also qualifies you to participate in
Lifebreath's customer referral program.
Visit www.lifebreath.com for more information or speak to your
local Territory Manager.
67
TERMS AND CONDITIONS
Terms and Conditions
Terms
and
Conditio
ns
TERMS OF SALE
1. Payment: Net 30 days, from invoice date.
2. Canadian Customers – Taxes:
a. G.S.T. will be charged on all products, and shown
separately on each invoice.
b. P.S.T (where/as applicable) are extra and will be
charged unless AIRIA is supplied with a Provincial
Sales Tax license number.
c. H.S.T (where/as applicable) will be charged on all
products, and shown separately on each invoice.
3. U.S. & International Customers
a. Federal I.D. # is mandatory for all shipments.
b. Taxes not applicable.
4. Ownership of the product remains the property of AIRIA
until the invoice is paid in full.
GOODS RETURNED FOR CREDIT
1. Authorization must be obtained prior to returning any
goods. Use the Return Goods Authorization Form
(SM-01F) found on the front of the parts list.
2. Once authorized you will receive an RMA number/#;
this RMA number/# must be tagged on the
returned product.
3. Returned products must be freight prepaid and
adequately packaged to prevent damage. If damaged
or unusable, credit will be denied.
4. A minimum 15% restocking charge will apply.
5. Custom products and non-stock products are
non-returnable and non-refundable.
6. AIRIA reserves the right to refuse any request
for return.
SHIPPING AND DELIVERY
1. Order lead times (target timeframes):
· Residential units – as little as 5 business days
· Commercial – 10 business days
· Large Commercial – 15-20 business days
· Parts – 2 business days
2. To protect your product during transport, protective
packaging, containers or skids can increase shipping
weight by 5 - 20%. Exact weight can be confirmed at
time of order.
3. All orders are shipped via courier, and delivered during
normal business hours. Shipping charges are included
to most major centers in the U.S. Additional charges
may apply for shipments beyond those centers. You
will be notified of extra charges prior to order entry.
4. We regret that we cannot ship to a Post Office (P.O.)
Box address.
WARRANTY POLICY, REPLACEMENT PARTS, RETURNS
Airia Brands Inc. is proud to stand behind our products.
Should replacement parts be required, while under
warranty, they will be provided at no charge. Refer to the
warranty card enclosed with the product. Replacement
parts installed in units under warranty will assume the
original machine warranty remaining OR one year,
whichever is longer. Note, warranty is for parts only.
Freight or labor incurred is the responsibility of the
homeowner. Refer to the warranty card enclosed with the
product manual documentation.
PRICING
See pricing lists (available separately) for details
FREIGHT CLAIMS
1. All return Freight charges are the responsibility of
the sender.
2. Extra freight duty or brokerage costs charged to
Airia Brands Inc., will be deducted from your credit.
TO PLACE AN ORDER
FAX PURCHASE ORDER: 1-800-494-4185
For Order Information:
PH: 855-AIRIA-00 (855-247-4200)
68
Should a warranty claim for replacement parts be
necessary, please complete the following procedure:
1. Replacement warranty parts are invoiced on order.
2. When defective parts are ready for return for warranty
credit, complete RMA Form SM-01F noting the machine
model, serial number, date and explanation of failure.
3. Fax completed form for authorization before returning
defective parts to Airia. Defective parts being returned
must have an authorized SM-01F to receive credit.
4. Upon authorization, return the completed form together
with the defective part, Pre-Paid. U.S. returns should
be sent via Postal service (versus courier).
5. Address your prepaid, insured package to:
Airia Brands Inc, Attn: Returns, 511 McCormick Blvd,
London, Ontario, Canada N5W 4C8. COD deliveries will
not be accepted.
6. After completing the above, your account will be
credited within 30 days.
Partner Co-op Advertising Sample (Contact your Territory Manager for more details)
Leading the Way to
Total Home Comfort...
by improving your indoor air quality, and reducing energy consumption.
Are you ready to step up to Lifebreath?
(Name of Dealer) carries our full line including our high efficiency Hydronic
air handler with built-in air exchanger, the TFP HEPA Air Cleaner and the industry
leading HRV with patented aluminum core.
Lifebreath products are designed for one reason - to give your home or
business a healthier indoor air environment. Visit any of our locations
and let (Name of Dealer) show you how.
Let us show you how to give your
home or business a healthier indoor
air environment.
Setting a new standard
for energy efficient, clean air homes
Visit us at www.lifebreath.com
511 McCormick Blvd., London, ON, Canada N5W 4C8
(519) 457-1904
Residential Warranty
123 My Street
Our Town, ON A4B 5C6
(789)123-4567
www.websiteaddress.com
Commercial Warranty
We proudly stand behind our products
with a Full Warranty.
We proudly stand behind our products
with a Full Warranty.
LIFETIME on HRV aluminum cores
5 YEAR on ERV Enthalpic cores
5 YEAR on replacement components
15 YEAR on HRV aluminum cores
5 YEAR on the ERV Enthalpic cores
2 YEAR limited on replacement components
Setting a new standard
for energy efficient, clean air homes
511 McCormick Blvd.
London, Ontario, Canada N5W 4C8
Ph: (519) 457-1904
Toll Free: 1-855-AIRIA-00
(1-855-247-4200)
Manufacturer reserves the right to change specifications without notice.
Printed in Canada
www.lifebreath.com
98-CATLB (05-11)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
