Conair HC318DWXCSC User manual

® FIG. 2 To maintain the blades of your Conair ® clipper, oil them after every three or four haircuts. Gently place a few drops of oil on the teeth of the blades, using the special Conair oil included with your set. Turn the clipper on for a minute, then turn off. This light, natural oil was formulated specifically for the Conair ® high-speed clipper. Because it is the right oil to use, it will not slow down the blades. Never use any other product. There is no substitute for Conair oil. Keep oil away from children. SPECIAL OIL 3. Unplug clipper and slightly loosen screws. (See FIG. 2) 4. Position the extreme left-hand tooth of the top blade so that it either covers or appears on the left of the first small tooth on the bottom blade. 5. Make sure that the big tooth on the bottom blade touches the extreme right hand tooth of the top blade. 19 To Align Blades: 1. Add two or three drops of Conair Lubricating Oil (included). 2.Turn clipper on for a minute to disperse oil evenly over blades, then turn off. To prevent the clipper from contacting the skin or cutting too closely, make certain that the end top blade teeth are 1/32” to 1/16” back from bottom blade. FIG. 1 Conair® hair clippers are carefully inspected to insure that the blades are in perfect alignment. Of course you will need to realign the blades after removal for cleaning or replacement, or if they should be knocked out of alignment. How can you tell if blades need realigning? Simply match them up, point for point, to conform with FIG. 1 below: IF YOU DETERMINE THAT BLADE ALIGNMENT IS INCORRECT: CARE OF YOUR CLIPPERS —Para reducir el riesgo de quemaduras, electrocución, incendio o lesiones personales: Cuando se usen aparatos eléctricos, especialmente en la presencia de niños, siempre se deben tomar precauciones básicas de seguridad, entre las cuales las siguientes: USER-MAINTENANCE INSTRUCTIONS MEDIDAS DE SEGURIDAD IMPORTANTES LEA TODAS LAS INSTRUCCIONES ANTES DE USARLO MANTENGA EL APARATO PIEZAS For the front to the crown, cut the hair against the direction in which it grows. Then even it up with the sides. For a flat top, use the flat comb, not the attachment comb. Just cut hair on top of the head over flat comb. (see below). To taper hair down to the neckline, use attachment comb #1. Comb hair and check for uneven spots. Outline sideburns and neck areas (see “Outlining”). Hold the comb attachment flat against the head and slowly move the clipper up through the hair. Use the same technique for the sides, cutting from the bottom to the upper side of the head. Always cut from the back of the neck to the crown, using the longest comb setting. SHORT CUTS TO PERFECT FLAT TOPS, CREW CUTS, ETC. Conjunto de ALEJADO DEL AGUA Peluquería PELIGRO —Cualquier electrodoméstico permanece eléctricamente activo, incluso cuando el interruptor está apagado. Para reducir el riesgo de muerte o herida por descarga: NO TRATE DE ALCANZAR EL APARATO EN EL AGUA ADVERTENCIA For best results, do as the professionals do: comb hair often, and check clipping results as you comb. This way you avoid uneven sides, bangs, neckline, etc. STOP. COMB. CHECK. Outlining requires no attachments. Comb hair into the desired style. Position the clipper between the sideburns and the ear (see below), making sure the corner edge of the blade is against the hairline. With the outline of the hair as your guide, slowly move the clipper over, around and behind the ears. For the back of the neck and the sideburns, hold the clipper upside down (see above) and, holding it against the skin at the length desired, move the clipper downward. OUTLINING: aerosol (spray) o donde se esté administrando oxígeno 9. Siempre conecte el aparato al cable antes de enchufarlo. Para desconectarlo, coloque todos los ajustes en la posición “Apagado”, luego desenchufe el cable. 10. No coloque el aparato en ninguna superficie mientras esté funcionando 11. No use este aparato con un peine accesorio roto o lastimado o si le faltan dientes a la cuchilla. Esto podría provocar una herida. Asegúrese que las cuchillas estén correctamente alineadas antes de usarlo (véase la sección “Instrucciones de mantenimiento”) 12. Evite que las cuchillas toquen la piel cuando estén moviendo 13. Siempre asegúrese que el cable del aparato no esté enredado. Si el cable se enreda o se enrolla mientras está usando el aparato, apáguelo inmediatamente y enderece el cable antes de volverlo a usar. GUARDE ESTAS INSTRUCCIONES INSTRUCCIONES DE USO Remember, it’s better to leave too much hair than too little. For longer hair on top, use the barber comb and lift hair on the top of the head, cutting over the comb. Or hold the hair between the fingers and cut to desired length.Always working from the front to the back of the head, gradually cut the hair shorter by reducing the space between the comb or fingers and the head. Comb often to check for uneven strands, and to get rid of trimmed hair. Su conjunto de peluquería de Conair® tiene todo lo que usted necesita para lograr cortes de cabello profesionales en su casa. Incluye una cortadora para el cabello potente con una palanca de ajuste de recorte y cuchillas de acero duro para un cortado preciso. También incluye 9 peines accesorios (3 mm, 6 mm, 9 mm, 13 mm, 16 mm, 19 mm, 22 mm, peine para la oreja izquierda y peine para la oreja derecha), tijeras de peluquero, una capa de barbero, un bolso de almacenamiento, un peine de barbero con dientes rectas y 2 clips para el cabello más largo. También incluye aceite lubricante, un cepillo de limpieza y una cubierta protectora para las cuchillas. GUÍA DE CONAIR PARA CORTAR EL CABELLO EN SU CASA Antes de empezar: 1. Inspeccione el aparato para asegurarse que esté libre de cabello y polvo, que esté lubricado y que funcione correctamente 2. Coloque una toalla o una capa de barbero alrededor del cuello de la persona a quien le va a cortar el cabello 3. Siente a la persona de manera que su cabeza esté al nivel de sus ojos para mayor visibilidad y control 4. Desenrede el cabello, luego coja la cortadora confortablemente en su mano. Ya está listo para empezar. NOTE: Never push or shove the clipper through the hair to make it move more quickly. Professional experience shows that the clipper works most efficiently when it cuts through the hair at its own speed. To begin cutting hair: 1. The hair should be combed in its natural direction. 2. Using the largest attachment comb, trim sides from the bottom upward. Hold clipper lightly against the hair with teeth of the attachment comb pointing upward, yet flat against the head. Gradually lift the clipper upward and outward through the hair, trimming just a little at a time. To remove comb attachments, place index finger and thumb as illustrated; then pull out and up. If you want hair to be even shorter: A) Apply more pressure to the head with the attachment comb that is in place. This takes a little practice, of course. OR B) Just switch to a shorter attachment comb. Repeat around sides and back of head. a 1/8” (3 mm) • El peine accesorio mediano-corto (No.2) corta el cabello a 1/4” (6 mm) • El peine accesorio mediano-largo (No.3) corta el cabello a 3/8” (9 mm) • El peine accesorio largo (No.4) corta el cabello a 1/2” (13 mm) • El peine accesorio largo (No.5) corta el cabello a 5/8” (16 mm) • El peine accesorio largo (No.6) corta el cabello a 3/4” (19 mm) • El peine accesorio largo (No.7) corta el cabello a 7/8” (22 mm) • El peine accesorio para la oreja izquierda contornea la oreja izquierda • El peine accesorio para la oreja derecha contornea la oreja derecha Para ensamblar el peine accesorio, sosténgalo cabeza arriba y engánchelo en la parte inferior del filo de la cortadora. Para quitar el peine accesorio, cójalo entre los dedos índice y pulgar, tal como se ve en la ilustración, y jale el peine hacia arriba y CORTES MEDIANOS A LARGOS Before you start: 1. Inspect your clipper. Make sure it’s free of hair and dirt, properly oiled, and running smoothly. 2. Place a towel or cape around the neck of the person. 3. Seat the person so that his or her head is at your eye level.This gives you greater visibility and control. 4. First, comb hair until it’s tangle-free. Then hold clipper in a comfortable grip. Now you’re ready to cut. afuera SAVE THESE INSTRUCTIONS OPERATING INSTRUCTIONS THE CONAIR GUIDE TO CUTTING HAIR AT HOME Attach combs by holding them teeth up, then snapping onto the bottom of the clipper blade. Instrucciones de uso y de mantenimiento To begin with, cut only a small amount of hair until you become used to the length each attachment leaves the hair. Try the longest attachment on the clipper first. If you want a shorter cut, you can then use shorter combs. • Short attachment comb (number 1) cuts hair to 1/8” (3.175mm). • Medium-Short attachment comb (number 2) cuts hair to 1/4” (6.350mm). • Medium-Long attachment comb (number 3) cuts hair to 3/8” (9.525mm). • Long attachment comb (number 4) cuts hair to 1/2” (12.700mm). • Long attachment comb (number 5) cuts hair to 5/8" (15.875mm). • Long attachment comb (number 6) cuts hair to 3/4" (19.050mm). • Long attachment comb (number 7) cuts hair to 7/8" (22.225mm). • Left ear attachment comb lightly tapers over left ear. • Right ear attachment comb lightly tapers over right ear. MEDIUM TO LONG CUT brush and a blade guard for easy maintenance of the clipper blades. NOTA: Nunca empuje la cortadora para que corte más rápidamente. La experiencia profesional demuestra que funciona mejor cuando corta a su propia velocidad. This appliance is used on Alternating Current 120V AC (60 hertz) only. To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). As a safety feature, this plug will fit in the polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. Do not attempt to defeat this safety feature. Your new Conair® haircut kit has everything you need to achieve professional haircuts at home. It features a powerful clipper with adjustable taper control and high carbon steel blades for cutting precision. Also included are 9 attachment combs (1/8” (3.175mm), 1/4” (6.350mm), 3/8” (9.525mm), 1/2” (12.700mm), 5/8” (15.875mm), 3/4” (19.050mm), 7/8” (22.225mm) for different hair lengths (left and right ear combs), barber scissors, barber cape, storage case, a barber comb with straight teeth, and 2 styling clips to assist you in cutting longer hair styles. It also comes with lubricating oil, a cleaning be mindful of tangles or kinks in the cord. If the cord does become tangled during use, turn the unit off and straighten cord before operating again. Empiece por cortar poco cabello, hasta acostumbrase al cortado de cada peine accesorio. Use el peine accesorio más largo para empezar, luego use peines accesorios más cortos para acortar el cabello. • El peine accesorio corto (No.1) corta el cabello Empezar el corte de cabello: 1. Peine el cabello en la dirección de su crecimiento natural 2. Empiece el recorte a un lado de la cabeza, usando el peine accesorio más largo, y cortando de abajo hacia arriba. Sostenga la cortadora ligeramente contra el cabello con los dientes del peine apuntando hacia arriba y plano contra la cabeza. Pase la cortadora en el cabello gradualmente hacia arriba y hacia fuera, cortando un poco cada vez. Repita al otro lado y atrás de la cabeza . Si quiere un corte de cabello aún más corto: O, B) Cambie el peine accesorio por uno más corto. Recuérdese que es mejor dejar demasiado cabello que muy poco. Si quiere dejar el cabello más largo encima de la cabeza, use el peine de barbero o sus dedos para levantar el cabello y corte a lo largo deseado. Trabaje siempre de adelante por atrás de la cabeza y corte el cabello poco a poco, reduciendo el espacio entre sus dedos o el peine y la cabeza. Peine con frecuencia para verificar que no hayan mechones disparejos y para eliminar el cabello cortado. CONTORNEO El contorneo no requiere accesorios. Peine el cabello en el estilo deseado. Coloque la cortadora entre las patillas y la oreja (véase el dibujo) y asegúrese que la esquina de la cuchilla se encuentre contra el nacimiento del pelo. Mueva la cortadora lentamente sobre, alrededor y por atrás de las orejas, siguiendo la forma del cabello. Para cortar el pelo en la nuca y las patillas, sostenga la cortadora al revés (véase el dibujo), colóquela contra la piel al nivel deseado y muévala hacia abajo. DETÉNGASE. PEINE. VERIFIQUE. Para resultados óptimos, siga el ejemplo de los profesionales: peine el cabello con frecuencia y verifique los resultados mientras peine. Esto evitará tener lados, flequillos o líneas de nuca disparejos. PERFECTOS CORTES CON CORONILLAS PLANAS, CORTES MILITARES ETC. Siempre corte el cabello desde la parte trasera de la nuca hacia la coronilla, usando el peine accesorio más largo. Sostenga el peine contra la cabeza y mueva la cortadora lentamente en el cabello hacia arriba. Use la misma técnica para los lados, cortando desde abajo hasta la parte superior lateral de la cabeza. Para la parte delantera, corte el cabello en la dirección contraria a la del crecimiento natural del cabello, luego iguale los lados. Para una coronilla plana, use un peine plano en vez de un peine accesorio, y corte el cabello encima del peine (véase el dibujo). Para cortar el pelo en la nuca y en las patillas, use el peine accesorio No.1 (Véase la sección “Contorneo”). Aplique más presión con el peine accesorio. Esto necesita al principio un poco de práctica. DANGER 2. This appliance should not be used by, on, or near children or individuals with certain disabilities. 3. Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer. 4. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped, damaged, or dropped into water. Return the appliance to service center for examination and repair. 5. Keep the cord away from heated surfaces. 6.Never operate the appliance with the air opening blocked or while on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep the air openings free of lint, hair and the like. 7.Never drop or insert any object into any opening. 8. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered. 9. Always attach plug to appliance first, then to outlet. To disconnect, turn all controls to “off”, then remove plug from outlet. 10. Do not place appliance on any surface while it is operating. 11. Do not use this appliance with a damaged or broken comb or with teeth missing from the blades, as injury may occur. 12. Avoid skin contact with moving blades. 13. When using the appliance with its cord, Este aparato fue diseñado para uso con Corriente Alterna de 120V (60 hertzios) únicamente. Este aparato tiene un enchufe polarizado (un polo es más ancho que otro). Como medida de seguridad, se podrá enchufar de una sola manera en la toma de corriente polarizada. Si no entra por completo, inviértelo. Si aún no entra completamente, llame a un electricista calificado. No intente vencer esta función de seguridad. 1. An appliance should never be left unattended when plugged in. persons: DO NOT REACH INTO THE WATER WARNING—To reduce the risk of burns, electric shock, fire, or injury to To reduce the risk of electric shock: 1. Do not reach for an appliance that has fallen into water. Unplug immediately. 2. Do not use while bathing or in the shower. 3. Do not place or store appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid. 4. Always unplug this appliance from the electrical outlet immediately after using. 5. Unplug this appliance before cleaning. —Any appliance is electrically live, even when the switch is off. IMPORTANT SAFETY INSTRUCTIONS 1. Nunca deje este aparato desatendido mientras esté conectado 2. Este aparato no debería ser usado por, sobre o cerca de niños o personas con alguna discapacidad 3. Use este aparato únicamente con el propósito para el cual fue diseñado y tal como se describe en este manual. Sólo use accesorios recomendados por el fabricante. 4. Nunca utilice el aparato si el cable o el enchufe están dañados, si no funciona correctamente, si ha caído, si está dañado o si ha caído al agua. Llévelo a un centro de servicio autorizado para que lo examinen y lo reparen. 5. Mantenga el cable alejado de superficies calientes 6. Nunca bloquee las aberturas de aire o coloque el aparato en una superficie blanda, como una cama o un sofá, donde se puedan obstruir. Mantenga las aberturas libres de pelusas, cabellos y elementos similares. 7. Nunca deje caer ni inserte un objeto en ninguna de las aberturas 8. No utilice este aparato al aire libre, ni donde se estén usando productos en INSTRUCCIONES DE MANTENIMIENTO ALINEACIÓN DE LAS CUCHILLAS Mantenimiento de las cuchillas: Las cortadoras de Conair® son inspeccionadas para asegurarse que las cuchillas estén perfectamente alineadas. Usted necesitará alinearlas nuevamente después de extraerlas para limpiarlas o reemplazarlas o si se desalinearan por un golpe. Para determinar si las cuchillas necesitan alinearse de nuevo, simplemente hágalas coincidir como lo indican la figura que se encuentra a continuación (FIG.1). FIG. 1 Para evitar que la cortadora corte el pelo demasiado corto o que las cuchillas toquen la piel, asegúrese que la extremidad de la cuchilla superior esté a una distancia de 0.08 cm a 0.16 cm de la cuchilla inferior. Para alinear las cuchillas: 1. Coloque unas 2 o 3 gotas de aceite lubricante en las cuchillas 2. Encienda el aparato. Déjelo encendido durante un minuto para repartir el aceite, luego apáguelo. 3. Desenchufe el aparato y afloje ligeramente los pernos (FIG.2) 4. Asegúrese que el extremo diente izquierdo de la cuchilla superior cubra o esté a la izquierda del primer diente pequeño de la cuchilla inferior. 5. Asegúrese que el diente grande de la extremidad derecha de la cuchilla inferior toque el diente de la extremidad derecha de la cuchilla superior. ACEITE ESPECIAL Para mantener las cuchillas de su cortadora en condición óptima, lubríquelas después de tres o cuatro cortes de cabello. Aplique unas cuantas gotas de aceite lubricante en los dientes de las cuchillas, encienda la cortadora durante un minuto, luego apáguela. Este aceite lubricante ligero fue específicamente diseñado para las cortadoras de alta velocidad de Conair®. Porque es el aceite adecuado, no reducirá la velocidad de las cuchillas. Nunca use otro aceite para lubricar su aparato. No hay ningún substituto al aceite de Conair. FIG. 2 9:40 AM 1. No intente de alcanzar un aparato que ha caído al agua. Desenchúfelo inmediatamente. 2. No lo use mientras se esté bañando o tomando una ducha 3. No coloque ni guarde el aparato donde pueda caer o ser empujado a una bañera o un lavabo. No coloque el aparato ni lo deje caer al agua u otro líquido 4. Siempre desconecte el aparato inmediatamente después de usarlo 5. Desconecte el aparato antes de limpiarlo 9/29/06 MODELOS HC240ACSV MODELS HC240ACSV Instructions for Care and Use Haircut kit PIECE 19 READ ALL INSTRUCTIONS BEFORE USING KEEP AWAY FROM WATER When using electrical appliances, follow basic safety precautions, including the following: ® HC240ACSV IB Page 1 Page 2 Packed-in hair can slow down any clipper. To remove hair without removing the blades, do what the professionals do: keeping the clipper on, quickly push the taper lever back and forth from “close” to “longer” cut a few times. WARNING: IF YOU THINK THE POWER IS OFF WHEN THE SWITCH IS OFF, YOU'RE WRONG. Top Blade Bottom Blade To obtain service under this warranty, return the defective product to the service center listed below that is nearest you, together with your purchase receipt and $3.00 for postage and handling. California residents need only provide proof of purchase and should call 1-800366-0937 for shipping instructions. In the absence of a purchase receipt, the warranty period shall be 60 months from the date of manufacture. Conair will repair or replace (at our option) your unit free of charge for 60 months from the date of purchase if the appliance is defective in workmanship or materials. LIMITED FIVE YEAR WARRANTY Blade Guard *Sales Tax Blade Set for HC318D Barber Scissors Instructional DVD Approximate 28 Minute haircut video in Spanish & English (Optional) Lubricating Oil (pkg. of 3 tubes) Powerful DC motor makes this unique, lightweight clipper / trimmer a versatile cutting instrument as it can also be used for detailing and bikini line trimming. Model COMB-10 Deluxe White Vinyl Cape with Velcro Collar Neck Brush 3 attachment combs: 5/8", 3/4", 7/8". Fits all clippers 1" Comb fits all clippers Set of 2 Attachment Combs: left ear and right ear. Fits all clippers Model COMB-11 Model HC VIDEO Set of 4 Attachment Combs:1/8”, 1/4”, 3/8”, 1/2”. Fits all clippers Model COMB-13 PT1 Mighty Mini 15 Piece Clipper Kit ITEM EXCITING ITEMS FROM CONAIR Once again, thanks for buying a Conair product. $1.50 CLP-1 $1.00 HC-1 $6.50 BLD-8 $2.00 SC-1 $5.00 DVD-1 Model CAPE-1 HC90 10 Piece Haircut Kit Attachment combs should also be replaced if they are lost or broken. It is easier to cut hair with the accuracy of a pro when the necessary tools are at your fingertips. Your Conair ® clipper blades are made of high carbon stainless steel. They are engineered for precise, professional results. If blades feel like they are pulling or grabbing hair, it means they are losing their sharpness and should be replaced as soon as possible. Model HCNB-1 Model SC-1 Styling Clips (set of 3) Powerful magnetic motor clipper with stainless steel blades and 4 attachment combs. CUT HERE Close Cut KEEP AWAY FROM WATER FORMULARIO DE PEDIDO PARA PARTES DE REPUESTO Y ACCESORIOS Precios válidos hasta el 1ero de junio del 2008. Aceptaremos los pedidos después de esa fecha y notificaremos los clientes si los precios han cambiado. DESCRIPCIÓN NÚMERO PRECIO 4 peines accesorios para todas las cortadoras: 3 mm, 6 mm, 9 mm, 13 mm COMB-10 $5.00 2 peines accesorio para la oreja izquierda y derecha COMB-11 $1.75 Peine accesorio para todas las cortadoras: 25 mm COMB-12 $1.75 3 peines accesorio para todas las cortadoras: 16 mm, 19 mm, 22 mm COMB-13 $5.00 Cepillo para el cuello HCNB-1 $1.50 Capa de vinilo blanco con velcro CAPE-1 $5.00 Aceite lubricante (envase de 3) Modelo HCNB-1 Vídeo instructivo de 28 minutos en ingles o en español (opcional) DVD instructivo Modelo BLD-8 Modelo HC-1 Modelo CAPE-1 $5.00 SC-1 $2.00 Conjunto de cuchillas para HC318D BLD-8 $6.50 Cubierta protectora para las cuchillas HC-1 $1.00 Clips de modelado (envase de 3) CLP-1 $1.50 TOTAL Subtotal Impuestos a la venta* TOTAL Modelo DVD-1 NOMBRE__________________________________________________________________________________ DIRECCIÓN _________________________________________________ APTO. _______________________ CIUDAD____________________________ ESTADO __________ CÓDIGO POSTAL___________________ TELÉFONO ( ) _________________________________(sólo le llamaremos si tengamos alguna pregunta sobre su pedido) Para información sobre otras partes de los conjuntos de Conair®, llame 1-800-3-CONAIR Modelo COMB-12 $8.95 DVD-1 Para evitar demoras, por favor escriba claramente. Necesitamos una dirección completa ya que US no puede hacer entregas en casillas postales. Modelo CLP-1 $2.00 Tijeras de peluquero Incluya un cheque o giro postal a la orden de Conair (no podemos aceptar dinero en efectivo, estampillas, ni pedidos con pago con entrega). Los residentes de CT, IL, AZ y PA deben sumar al subtotal el impuesto estatal a las ventas que corresponda. Pedido mínimo de $10,00US o de lo contrario se sumará al pedido $2,00US por gastos administrativos. Todos los precios incluyen gastos administrativos y franqueo de envío. Los precios están sujetos a cambio sin previo aviso. Estos precios son válidos únicamente para los envíos en la parte continental de los Estados Unidos. La entrega demora entre 4 y 6 semanas Modelol HC OIL HC OIL HC VIDEO CANTIDAD Modelo COMB-10 HC90 Conjunto de Peluquería de 10 piezas MN253 Cortadora Cobra Cortadora de detalle de lujo con 3 cabezas intercambiables: cortadora, rasaradora, cortadora para el pelo de la nariz y de los oídos. * No se recomienda para las barbas gruesas. Longer Cut Modelo COMB-13 ADJUSTABLE TAPER LEVER Adjustable Taper Lever Modelo HC VIDEO Just like professional clippers, the Conair taper lever is positioned at your thumb. You can hold the clipper in your hand and adjust the lever at the same time...while you’re clipping. This taper lever eliminates the need for an attachment comb because it lets you gradually adjust the closeness of the cut. For the closest cut and the shortest hair, push taper lever up as far as it will go. To increase cutting length, slowly push lever down. If you push to the lowest position, it will leave hair about the same length as the short attachment. Because a different cutting edge is used in each setting, the taper lever lengthens the life of your blades. Conair makes a variety of accessories for different haircut kits. If your haircut kit does not include them, you may want to consider adding them to your professional haircutting tools. TOTAL Enclose check or money order made payable to Conair. (We cannot accept cash, stamps or C.O.D. orders.) CT, IL, AZ, and PA residents should add applicable state sales tax. Minimum order of $10.00 or a $2.00 handling charge will be added to order. All prices include handling and return postage. Prices are subject to change without notice. Prices are valid only for shipments within the Continental United States. Please allow 4-6 weeks for delivery. Subtotal IB-7255 ANY IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILITIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE 60 MONTH DURATION OF THIS WRITTEN, LIMITED WARRANTY. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you. Model HC-1 Model BLD-8 To avoid delays, please print clearly. We must have a street address, as UPS cannot deliver to a P.O. box. Model DVD-1 Un Aviso Público de la Asociación de los Fabricantes de Electrodomésticos y de Underwriters Laboratories, Inc. © 2006 CONAIR CORPORATION Service Department 7475 North Glen Harbor Blvd. Glendale, AZ 85307 Modelo COMB-11 Modelo SC-1 Cortadora potente con motor magnético, cuchillas de acero inoxidable y 4 peines accesorios. Switch Model CLP-1 Model HC OIL $8.95 HC VIDEO $2.00 HC OIL $5.00 CAPE-1 $1.50 HCNB-1 $5.00 COMB-13 $1.75 COMB-12 $1.75 COMB-11 $5.00 COMB-10 PART # PRICE QUANTITY AMOUNT Pricing in effect through June 1, 2008. Orders postmarked after this date will be accepted, and the customer will be notified if pricing has changed. HAIRCUT KIT REPLACEMENT PARTS & ACCESSORIES ORDER FORM Modelos HC240ACSV CENTROS DE SERVICIO: También puede ordenar el video de 30 minutos “Corte de cabello en casa” con instrucciones fáciles de seguir. El video muestra las técnicas básicas del corte de cabello y presenta cuatro atractivos cortes paso a paso. Le dará la confianza y los conocimientos que necesita para cortar el cabello a todos los miembros de la familia. IN NO EVENT SHALL CONAIR BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. Some states do not allow the exclusion or limitation of special, incidental, or consequential damages, so the above limitation may not apply to you. Mail to: NAME____________________________________________________________________________ SIEMPRE DESENCHUFE LOS APARATOS PEQUEÑOS Esta garantía le otorga derechos legales específicos y usted puede tener otros derechos que varían de un Estado a otro. PT1 Conjunto de Peluquería de 15 piezas If you do this after every clipping, especially with heavy hair cutting, the blades should remain free of cut hair. If clipper stops cutting and this action doesn’t help, check the blades. If they’ve become dull, replace them or return them to a Conair service center. We’ll be glad to sharpen them for you. For new blades, send check or money order for $6.50 (see order blank) which includes postage and handling(If $10 minimum is met) to: ADDRESS ___________________________________________________ APT. ________________ PRECAUCIÓN: Nunca jale, tuerce o enrolle el cable alrededor del aparato. Cuando no use el aparato, deje el cable libre al lado del aparato. Left and right ear attachment combs provide effortless, precise cutting around the ears. Styling clips hold hair in place when you are sectioning hair. A styling comb makes it easy to taper or cut hair at an angle. A barber cape ensures a comfortable and neat haircut and a convenient storage pouch keeps all your essentials in one place. CITY _______________________________________________STATE _______ ZIP ____________ Conair Corporation 150 Milford Rd. East Windsor, NJ 08520 This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. Conair Corporation Service Department 150 Milford Road East Windsor, NJ 08520-9730 ) _______________________________(We call only if we have a question about your order.) Todos saben que la combinación de electricidad y de agua es peligrosa. Pero ¿Sabe usted que un aparato eléctrico está eléctricamente activo aún cuando el interruptor está apagado? Si el enchufe está conectado, el aparato está encendido. De modo que cuando no use sus aparatos electrodomésticos, manténgalos desenchufados. Los peines para contornear la oreja izquierda y derecha brindan un corte de precisión sin esfuerzo. Los clips sostienen el cabello mientras lo está seccionando. El peine de modelar permite contornear o cortar el cabello en ángulo. La capa de peluquero asegura un corte confortable y limpio y el cómodo bolso de almacenamiento mantiene todo sus accesorios en el mismo lugar. NOVEDADES FASCINANTES DE CONAIR Esta cortadora pequeña y ligera con un motor de CD potente es una herramienta versátil que también se puede usar para los recortes de detalle y el bikini. Conair Corporation 150 Milford Rd. East Windsor, NJ 08520 TELEPHONE ( Interruptor CONAIR NO SERÁ RESPONSABLE EN NINGÚN CASO POR ALGÚN DAÑO ESPECIAL, INCIDENTAL O CONSECUENTE DEBIDO AL INCUMPLIMIENTO DE ESTA O DE CUALQUIER OTRA GARANTÍA, EXPRESA O IMPLÍCITA. Algunos Estados no permiten la exclusión o limitación de daños especiales, incidentales o consecuentes, de modo que las limitaciones mencionadas pueden no regir para usted. Conair también fabrica una variedad de accesorios para cortar el cabello. Si su conjunto para recorte no los incluye, los puede ordenar por separado. Everyone knows that electricity and water are a dangerous combination. But did you know that an electric appliance is still electrically alive even if the switch is off? If the plug is in, the power is on. So when you are not using your appliances, keep them unplugged. For information on other Conair® haircut kit parts call: 1-800-3-CONAIR. Palanca Reguladora Ajustable CUALQUIER GARANTÍA, OBLIGACIÓN O RESPONSABILIDAD IMPLÍCITAS, INCLUYENDO PERO NO LIMITADAS A LA GARANTÍA IMPLÍCITA DE COMERCIABILIDAD Y APTITUD PARA UN PROPÓSITO ESPECÍFICO, ESTARÁN LIMITADAS POR LOS 60 MESES DE LA PRESENTE GARANTÍA ESCRITA. Algunos Estados no permiten limitaciones sobre la duración de una garantía implícita, de modo que las limitaciones mencionadas pueden no regir para usted. También se deben cambiar los peines accesorios si se pierden o se dañan. Es más fácil cortar el pelo con exactitud profesional cuando se tienen las herramientas adecuadas. SERVICE CENTER: © 2006 CONAIR CORPORATION Service Department 7475 North Glen Harbor Blvd. Glendale, AZ 85307 MANTENGA ESTE APARATO ALEJADO DEL AGUA Para obtener servicio técnico bajo esta garantía, lleve o mande su aparato al Centro de Servicio más cercano, junto con su recibo de compra y un cheque de $3,00US por gastos de envío y manejo (los residentes de California sólo necesitan dar una prueba de compra y deben llamar al 1-800-366-0937 para recibir instrucciones de envío). En ausencia del recibo de compra, el período de garantía será de 60 meses a partir de la fecha de fabricación. NOTE: Never pull on the clipper cord. Never twist or wrap the cord around the clipper. Lay it flat with the cord coiled up when not in use. Model COMB-12 Cuchilla Superior Las cuchillas de su cortadora son de acero duro inoxidable, y fueron diseñadas para brindar resultados precisos y profesionales. Si siente que las hojas tironean o enganchan el pelo, significa que están perdiendo el filo y debe reemplazarlas lo más pronto posible. ALWAYS UNPLUG SMALL APPLIANCES MN253 Cobra Trimmer 3-in-1 Deluxe, rechargeable detailer. 3 interchangeable heads include a full size trimmer, shaver and nose and ear attachment for all facial fashions. *Not recommended for thick beards. Su cortadora puede perder velocidad si recortes de cabello están trabados en las cuchillas. Para limpiarlas sin removerlas, haga lo que los profesionales hacen: con el aparato encendido, mueva la palanca reguladora rápidamente de un lado por otro varias veces. Hacer esto después de cada uso, especialmente cuando se corta mucho cabello, mantendrá las cuchillas en condición óptima. Si la cortadora deje de funcionar, y que esto no solucione el problema, inspeccione las cuchillas. Si estén embotadas, cámbielas o regréselas a uno de nuestros centros de servicio. Las afilaremos con gusto. Para comprar nuevas cuchillas, mande un cheque o un giro postal de $6,50US (esto incluye gastos de envío y manejo si el pedido es de $10,00US o más) a la dirección más abajo junto con el formulario de pedido para partes de repuesto. Cuchilla Inferior Last but not least, an easy-to-follow 30minute “Haircuts at Home” video is available. It demonstrates basic haircutting techniques and follows four popular haircuts step by step. It will give you the confidence and instruction you need to give great looking haircuts to every member of your family. Corte más largo ADVERTENCIA: SI CREE QUE NO HAY CORRIENTE, SE EQUIVOCA Conair reparará o remplazará (a su opción) su aparato sin cargo por un período de 60 meses a partir de la fecha de compra si presenta defectos de mano de obra o en los materiales. Nuevamente, gracias por comprar un producto de Conair. CORTE AQUÍ Al igual que las cortadoras profesionales, su cortadora tiene una palanca reguladora ajustable al nivel de su dedo pulgar, para que pueda controlar el tamaño del cortado a medida que corta el cabello. La palanca reguladora le permite cortar el cabello más corto o más largo, sin que tenga que usar un peine accesorio. Para un corte más corto, empuje la palanca hacia arriba. Para un corte más largo, empuje la palanca lentamente hacia abajo. El ajuste más corto dejará el cabello tan corto como el peine accesorio corto No.1. Usar la palanca reguladora ajustable prolonga la vida útil de las cuchillas, puesto que nunca usan el mismo ángulo para cortar. GARANTÍA LIMITADA POR CINCO AÑOS Corte más corto PALANCA REGULADORA AJUSTABLE IB-7255 9:40 AM Public Service ad from Association of Home Appliance Manufacturers and Underwriters Laboratories, Inc. 9/29/06 MODELS HC240ACSV HC240ACSV IB Enviar a: Conair Corporation Service Department 150 Milford Road East Windsor, NJ 08520-9730
