Orientation Analysis
in 4D Light Fields
Gutachter:
Prof. Dr. Bernd Jähne
PD. Dr. Christoph Garbe
Zusammenfassung
Die vorliegende Arbeit beschäftigt sich mit der Analyse von 4D Lichtfeldern. Als Lichtfeld bezeichnen wir in diesem Zusammenhang eine Serie von digitalen 2D Bilder einer
Szene die auf einem planaren regulären Gitter von Kamerapositionen aufgenommen
werden. Essenziell ist dabei die Aufnahme einer Szene mittels vieler Kamerapositionen
konstanten Abstandes zueinander. Dadurch werden die von einem Punkt der Szene
ausgehenden Lichtstrahlen als Funktion der Kameraposition abgetastet. Dadurch ergibt
sich die bereits erwähnte Vierdimensionalität der Daten da, im Gegensatz zu einem
klassischen Bild, zusätzlich zur Ortsinformation eine Richtungsinformation der Lichtintensität abgebildet wird.
Lichtfelder sind ein relativ neues Forschungsfeld für die Bildverarbeitung, deren moderner
Ursprung eher in der Computergrafik zu suchen ist. Dort wurden sie verwendet, um
die aufwendige Modellierung der 3D Geometrie zu umgehen und mittels Interpolation
der Blickwinkel auch ohne Informationen über die Geometrie einen interaktiven 3D
Eindruck zu erzielen. Die vorliegende Arbeit hat die umgekehrte Intention und möchte
aufgenommene Lichtfelder dazu verwenden um die Geometrie der Szene zu rekonstruieren. Der Grund ist, dass Lichtfelder im Vergleich zu existierenden Verfahren der 3D
Rekonstruktion einen viel reicheren Informationsgehalt besitzen. Durch die reguläre
Abtastung des Lichtfeldes werden neben Information über die Geometrie ebenfalls
Materialeigenschaften abgebildet. Oberflächen, deren visuelle Erscheinung sich unter
Änderung des Betrachtungswinkels nicht konstant verhält, führen bei bekannten passiven
Rekonstruktionsverfahren zu großen Problemen. Das Verhalten solcher Oberflächen
unter Blickwinkeländerung wird in Lichtfeldern allerdings abgetastet und somit unmittelbar analysierbar.
Der wissenschaftliche Beitrag dieser Arbeit besteht aus verschiedenen Teilbeiträgen.
Es wird ein neues Verfahren vorgestellt, das aus den Rohdaten einer Lichtfeldkamera
(Plenopik Kamera 2.0) ohne explizite pixelweise Vorberechnung der Tiefeninformation
eine 4D Lichtfeldrepräsentation erzeugt. Diese spezielle Repräsentation, auch Lumigraph
genannt, ermöglicht den Zugang zu Epipolarebenen genannten 2D-Unterräumen dieser
Datenstruktur. Es wird ein Verfahren vorgestellt das aus einer Analyse dieser Epipolarebenen eine robuste Tiefenschätzung unter der Annahme Lambertscher Oberflächen
ermöglicht. Darauf aufbauend wird eine Erweiterung dieses Verfahrens auf kompliziertere
Materialien, zum Beispiel spiegelnder oder teiltransparenter Oberflächen, entwickelt.
Als Anwendungsbeispiele für die inherent vorhandene Tiefeninformation in Lichtfeldern
werden bekannte Verfahren wie Superresolution oder Objektsegmentierung auf Lichtfelder erweitert und mit Ergebnissen auf Einzelbildern verglichen. Außerdem ist im
Laufe dieser Arbeit eine große Benchmark Datenbank, bestehend aus simulierten und
realen Lichtfeldern entstanden, mit Hilfe derer die hier vorgestellten Verfahren getestet
werden, und die zukünftiger Forschung auf diesem Feld als Vergleichsbasis dienen soll.
5
Summary
This work is about the analysis of 4D light fields. In the context of this work a light
field is a series of 2D digital images of a scene captured on a planar regular grid of
camera positions. It is essential that the scene is captured over several camera positions
having constant distances to each other. This results in a sampling of light rays emitted
by a single scene point as a function of the camera position. In contrast to traditional
images – measuring the light intensity in the spatial domain – this approach additionally captures directional information leading to the four dimensionality mentioned above.
For image processing, light fields are a relatively new research area. In computer graphics,
they were used to avoid the work-intensive modeling of 3D geometry by instead using
view interpolation to achieve interactive 3D experiences without explicit geometry. The
intention of this work is vice versa, namely using light fields to reconstruct geometry of
a captured scene. The reason is that light fields provide much richer information content
compared to existing approaches of 3D reconstruction. Due to the regular and dense
sampling of the scene, aside from geometry, material properties are also imaged. Surfaces
whose visual appearance change when changing the line of sight causes problems for
known approaches of passive 3D reconstruction. Light fields instead sample this change
in appearance and thus make analysis possible.
This thesis covers different contributions. We propose a new approach to convert raw
data from a light field camera (plenoptic camera 2.0) to a 4D representation without
a pre-computation of pixel-wise depth. This special representation – also called the
Lumigraph – enables an access to epipolar planes which are sub-spaces of the 4D data
structure. An approach is proposed analyzing these epipolar plane images to achieve a
robust depth estimation on Lambertian surfaces. Based on this, an extension is presented
also handling reflective and transparent surfaces. As examples for the usefulness of this
inherently available depth information we show improvements to well known techniques
like super-resolution and object segmentation when extending them to light fields.
Additionally a benchmark database was established over time during the research for
this thesis. We will test the proposed approaches using this database and hope that it
helps to drive future research in this field.
