How the STAPH-GUARD® system helps prevent cross
These durably-built models offer:
• Unique suspension system enables high extraction speeds for fast and fuel-efficient finishing.
• Staph-Guard® system for healthcare laundries to prevent cross-contamination.
• Microprocessor provides fully-automated operation and precise temperature control
via user-friendly display.
• Big inlet and drain valves for fast filling and draining accelerate production.
• Automatic supply injection improves quality and promotes consistency.
• Compact design saves space.
Model 42044:
Model 60044:
Model 72044:
• 200 lb. (90 kg) capacity.
• High extraction of 300 Gs.
• 450 lb. (200 kg) capacity.
• High Extraction of 317 Gs.
• 700 lb. (315 kg) capacity.
• High extraction of 300 Gs.
RAPID LOAD
Two pockets for higher productivity and
superior wash quality
Faster Unloading
Faster loading
Both pockets are open at one time for loading.
(No need to load one pocket, close the doors, inch
the cylinder, and then open another set of doors to
load the other pocket.)
Gravity makes sling loading easy. Plus, low doors
facilitate manual loading. In large installations with
several operators, two employees can load both
pockets simultaneously to save even more time.
For easy removal of goods, the load is fluffed by a
tumble cycle after extraction. Then the cylinder is
rotated to locate the load directly in front of the door
- about 18° below horizontal for unloading. (With
optional AUTOSPOT, positioning is done automatically,
in seconds.) The machine’s convenient door height
makes unloading easy. Plus, the shelf-like inner door
prevents the load from dropping between
cylinder and shell.
Better Washing Action
The second pocket is unloaded just
as easily by turning the cylinder to this position.
AUTOSPOT does the job easily and accurately.
RAPID LOAD’s large 60-in. diameter cylinder
- divided by only a single partition - provides
greater dropping action for outstanding soil
removal. Reversing action (note arrows) prevents
tangling. The big drop also fluffs the load at the
end of the cycle, making it easier to remove from
the machine
Microprocessor is simple,
versatile.
Automatic supply injection
promotes consistency.
Microprocessor controller provides 100 formulas,
98 fully field-programmable. Two pre-programmed
formulas get you started fast. Controller is userfriendly for both operator and programmer. Display
gives operating information, plus prompts for each
programming step. Help messages occur automatically
or as requested. Formulas can be added, created, deleted,
or modified in a single programming mode. Formulas
may be downloaded and/or printed and data can be
accumulated and printed. Easy-to-read graphics enhance
washroom operations and simplify personnel training.
This unit automatically injects up to five washing
supplies. Before injection, supplies are diluted to
prevent harm to the load. Central liquid supply
injection is available, too. This eliminates filling the
machine’s supply compartments between loads.
Accurate temperature control.
Desired temperature can be programmed into each step
of a formula – allowing infinite temperature settings.
The solid state temperature control is accurate, and it’ll
stay that way because it’s automatically calibrated.
How the STAPH-GUARD® system helps prevent cross-contamination.
The MILNOR STAPH-GUARD® System is a
thorough laundering system that combats
recontamination of clean hospital laundry.
Here are its essential features.
1. Barrier with pass-through
machines.
The system begins
with a barrier that
completely separates
the soiled laundry
handling area from the
clean laundry section.
Installed in this barrier
are STAPH-GUARD® washer-extractors. These
machines are equipped with separate sets of doors one set on the soiled side (for loading) and another
set on the clean side (for unloading). Different
personnel load and unload the machines.
2. StaphAIRTROL controls
air flow.
StaphAIRTROL keeps bacteria-laden air from
being discharged and recirculated in the clean
laundry section. It
permits air to be
drawn into each
washer-extractor
from the clean side
only and discharged
into the soiled
section only. This is critical since large volumes
of air are drawn into the machine and expelled
during normal operations.
3. Safety interlocks.
4. Positive/negative air pressure.
Automaticallycontrolled safety
interlocks maintain
the integrity
of complete
separation. Loading
and unloading doors
cannot be opened simultaneously. Doors on the
unloading side will not open until all cycles are
complete. When the unloading door is ajar, there
are no openings - even through the drain valve to the soiled side. Also, water drains to the soiled
work area only.
The entire hospital laundry should be designed
to include positive pressure ventilation in the
clean section and negative pressure ventilation
in the soiled section. Any air seepage through the
partition must be induced into the soiled section.
StaphAIRTROL prevents reverse air flow through
the washer-extractors themselves. Even the dump
valve automatically closes when the clean-side
doors are open, to prevent updraft of air into
the machine
from the highly
contaminated
drain gutter.
HYDRO-CUSHION® reduces
objectionable vibration.
Large, low doors
speed loading and unloading.
Ideal for poly-cottons
and regular cottons.
HYDRO-CUSHION® is a unique suspension system
designed to minimize objectionable vibration.
It includes a rugged steel frame and spring-hydraulic
units with heavy fluid damping. Provided a reasonable
safety factor exists, the machine can be installed on
any floor strong and rigid enough to support - without
undue or objectionable deflections - the dead weight
of the fully loaded machine, and the repeated forces
transmitted to the floor by the rotating machinery.
Consult manufacturer for full information.
Loading and unloading doors on RAPID LOAD models
are extra large for ease in handling. The conveniently
located doors are close to the washroom floor for
easy loading.
Precise temperature control is provided by MILNOR’s
solid state control. Infinite numbers of temperature
settings can be digitally programmed for virtually
any type of fabric. Accuracy is ensured by automatic
recalibration. Low speed extraction (optional extra)
helps keep wrinkles from setting in polyester-cottons.
AUTOSPOT (optional extra) automatically locates the
cylinder in precisely the right position each time for
loading and unloading. This speeds turnaround time
between loads by eliminating the guesswork usually
required to position the cylinder.
Compact design saves space.
MILNOR design yields low, compact outer dimensions
without sacrificing inner cylinder capacity - real space
savers for laundries.
SPECIFICATIONS
DIVIDED-CYLINDER WASHER-EXTRACTORS
Cylinder Volume - cu. ft. (L)
Capacity @ 10:1 – lbs. (kg)
Capacity @ 9:1 – lbs. (kg)
Cylinder diameter x depth - ins. (mm)
Number of cylinder compartments
Cylinder door area - sq.in. (sq. cm)
Height of loading doors above floor - ins. (mm)
Single-motor drive - HP (kw)
Wash motor - HP (kw)
Drain speed motor - HP (kw)
Extraction motor - HP (kw)
Low speed extraction motor - HP (kw)
Approx. wash speed (reversing 4 times/minute) - RPM
Approx. low speed extract - RPM
Maximum Extract speed - RPM (G forces)
Automatic drain valve - ins. (mm)
Automatic inlet valves - ins. (mm)
Overall width *** - ins. (mm)
Overall depth *** - ins. (mm)
Overall height *** - ins. (mm)
Approx. net weight - lbs. (kg)
42044 WP2
35
220
245
42x44
2
224
37
25
----32 *
375 *
700
8
1.5 **
84.63
70.18
81.13
5,700
60044 WP2
(999)
(99)
(111)
(1067x1118)
2
(1445)
(940)
(18.64)
-----(300)
(203)
(38)
**
(2150)
(1783)
(2061)
(2590)
72
450
500
60x44
2
1,076
34
50
----27 *
305 *
610
8
2 **
102.18
82.93
94
11,994
72044 WP2
104
(204)
647
(227)
719
(1524x1118) 72x44
2
2
(6941)
1,700
(863)
36.5
(37.28)
N/A
-10
-7.5
-20
-15
26
-220
(317)
535
(203)
10
(51) **
2**
(2595)
118.37
(2107)
84.5
(2388)
100.5
(5440)
17,260
(2039)
(2936)
(294)
(326)
(1829x1118)
2
(5484)
(927)
-(7.45)
(5.59)
(14.91)
(11.18)
-(300)
(254)
(51) **
(3007)
(2146)
(2553)
(7829)
* Programmable speeds. ** Equivalent flow rate *** With standard accessories.
Capacity depends on density and soil content of goods. Specifications subject to change without notice.
STAPH-GUARD® WASHER-EXTRACTORS
Cylinder Volume - cu. ft. (L)
Capacity @ 10:1 – lbs. (kg)
Capacity @ 9:1 – lbs. (kg)
Cylinder diameter x depth - ins. (mm)
Number of cylinder compartments
Cylinder door area - sq.in. (sq. cm)
Height of loading doors above floor - ins. (mm)
Single-motor drive - HP (kw)
Wash motor - HP (kw)
Drain speed motor - HP (kw)
Extraction motor - HP (kw)
Low speed extraction motor - HP (kw)
Approx. wash speed (reversing 4 times/minute) - RPM
Approx. low speed extract - RPM
Maximum Extract speed - RPM (G forces)
Automatic drain valve - ins. (mm)
Automatic inlet valves - ins. (mm)
Overall width *** - ins. (mm)
Overall depth *** - ins. (mm)
Overall height *** - ins. (mm)
Approx. net weight - lbs. (kg)
Printed in U.S.A.
© Pellerin Milnor Corporation
Class 5-8 Brochure B22SL00003/06282
42044 SP2
35
220
245
42x44
2
224
37.5
25
----34 *
375 *
700
8
1.5**
84.8
74.25
81.62
6,156
60044 SP2
72
(99)
450
(111)
500
(1067x1118) 60x44
-2
(1445)
538
(953)
33.5
(18.64)
50
--------27 *
-305 *
(300)
610
(203)
8
(38) **
2**
(2156)
102.8
(1886)
83
(2073)
109.75
(2792)
12,074
(999)
72044 SP2
104
(204)
647
(227)
719
(1524x1118) 72x44
-2
(3471)
850
(851)
36.5
(37.28)
N/A
-10
-7.5
-20
-15
26
-220
(317)
535
(203)
10
(51) **
2**
(2611)
121.8
(2108)
84.1
(2788)
108
(5477)
18,954
(2039)
Better
engineering
means
greater reliability.
(2936)
(294)
(326)
(1829x1118)
-(5484)
(927)
-(7.45)
(5.59)
(14.91)
(11.18)
-(300)
(254)
(51)
**
(3094)
(2135)
(2743)
Large, high capacity
roller bearings are
grease-lubricated.
Three seals shield
bearings from the
washing solution,
and keep oil and
grease from entering
the shell. Rugged
flange-type bearing
mountings, with
external boxed
bracing, provide
rigidity. Extraction
forces are transmitted
directly to front and
rear shell heads, to
minimize stress-strain
deflection and vibration.
Throughout each
machine, MILNOR
employs rugged
construction,
continuous welding,
and heavy materials
for superior strength.
Cylinders are fabricated
entirely of high
tensile stainless steel
- including front and
rear heads and
compartment partitions.
The machine’s stainless
steel shaft runs entirely
through the cylinder for
greater rigidity.
(8597)
Pellerin Milnor Corporation
P.O. Box 400, Kenner, LA 70063-0400 USA
504/712-7656 • 800/469-8780
Fax: 504/468-3094
E-mail: mktg@milnor.com
www.milnor.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
