SAFETY CAMERA & VIDEO CAPTURE SYSTEMS
A New Vision of Safety and Security
Protect your investment with advanced in-car
surveillance equipment from the world’s leading
provider of automotive media systems
As a world leader in the development and production of in-car media equipment,
Clarion has always been at the forefront of technological evolution. Our years of
experience — including more than four decades of development of in-vehicle camera
systems — have given us an expertise that none can match. And nowhere is that
expertise more important than in designing safety camera and monitor systems.
Our reliability is backed up by one of the world’s most rigorous production line quality
assurance systems because we know that our in-vehicle equipment must perform
consistently and reliably no matter where it’s being used — whether it’s the hot tropics,
Headquarters and
a parched desert, a wet rainforest, or the freezing cold of the far north. Our stateTechnical Center
of-the-art computer design system simulates various climatic conditions and every
product goes through a wide range of quality control tests. Only when products pass these tests, are they entitled to bear
the Clarion insignia and be delivered to our customers around the world. And thanks to advanced automation, our factories
produce 50,000 in-vehicle CCD cameras for both commercial and private vehicles in countries around the world each and
every month. So when it comes to in-car surveillance — leave it to Clarion. Because if it’s “in-car,” it’s Clarion.
2
Waterproof Test
Vibration Test
Temperature Test
Durability Test
Assuming vehicles
are washed by a car
wash and exposed to
the weather, we check
for water penetration
inside the camera
and determine
how watertight the
equipment is.
Assuming our
products are used in
commercial vehicles,
we confirm durability
by subjecting them to
severe vibrations.
Reliability under rapid
temperature change
is checked, including
performance
confirmation under
high and low
temperatures.
We expose each and every design, as
well as a sample from each production to
extreme operation testing. We check the
durability of movable parts such as shutter
opening/closing and monitor controls by
conducting more than 50,000 cycles. The
buttons on our monitors are given the same
challenge.
3
LCD COLOR MONITORS
Introducing high-quality Clarion monitors that deliver superior cost performance
in a sophisticated original design with dual camera connectivity.
7" WIDE COLOR LCD MONITOR
Large 7-inch screen delivers sharp, clear images in a sleek, stylish
design that fits attractively in your vehicle interior.
CJ7100E
7" Wide Color LCD Monitor (Compatible with
both DC 12V and 24V)
• Camera power supplies and a two-camera
switcher are built in.
• Convenient true/mirror image switching function.
• Automatic video switching with reverse
gear and turn signal link.
• Manual dimmer function.
• Image sources other than those from a camera
can be displayed via video input and audio input.
• Seven language display selection.
• Wireless remote control is included.
On-dash
mounting kit
IR Remote
5.6" COLOR LCD MONITOR
Good cost-to-performance value from a practical 5.6-inch
color LCD monitor.
CJ5600E
5.6" Color LCD Monitor (Compatible with
both DC 12V and 24V)
• Camera power supplies and a two-camera
switcher are built in.
• Convenient true/mirror image switching function.
• Automatic video switching with reverse
gear and turn signal link.
• Seven language display selection.
On-dash
mounting kit
4
QUAD CAMERA COLOR MONITOR
We can’t be in four places at once, but with the new new CJ7300G, you can see
what you want, when you want. Safety has never been easier.
CJ7300G
7" WIDESCREEN DIGITAL QUAD CAMERA
COLOR MONITOR
• Digital LCD panel delivers high image quality.
• Four display modes from one to four cameras
simultaneously in various screen combinations.
• Built-in power box allows direct connection of
up to 4 cameras.
• Left-right inversion display (normal /
mirror image switching) available.
• On-screen distance marker (Camera 1 only).
• Built-in speaker (works in combination
with the CC3000E’s microphone*).
• Touch-panel buttons and 8-language menu.
• Auxiliary video input terminal.
• Compatible with 12V and 24V electrical systems.
• On-dash mounting kit and remote
control are provided.
*Only Camera 1 input can be used with
the CC3000E’s microphone function.
Wireless
remote control
І 2-camera
display
І 3-camera
display
І 4-camera
display
On-dash
mounting kit
Camera Coverage Areas
Forward
looking
camera
Rear vision
camera
Side view
camera
Specifications
System Example
CCA-394 (Camera cable)
CCA-394 (Camera cable)
CC2001F (Mirror / Wide)
CCA-394
CC2000E
(Mirror / Wide)
CC2003E (True / Wide)
(Camera cable)
CCA-394
CJ7300G
(Camera cable)
CC2002E
(True / Narrow)
(7" WIDESCREEN DIGITAL
QUAD COLOR MONITOR)
5
HEAVY DUTY CCD CAMERAS
Based on the concept of safety and reliability, Clarion’s heavy-duty CCD cameras utilize
state-of-the-art technology and deliver high performance even under tough conditions.
HEAVY DUTY COLOR CCD CAMERAS
With motorized shutters to protect the
premium optics and extreme-duty cast
aluminum housings, reliability concerns
don’t exist.
CC2001F
Heavy Duty Color CCD Camera with Shutter
(Mirror Image/Wide Angle)
CC2004E
Heavy Duty Color CCD Camera with Shutter
(True Image/Wide Angle)
• Clarion’s flagship CCD camera delivers both
high image quality and high durability no
matter what the operating conditions are.
• Front gate shutter prevents visibility from
being obstructed by mud, grit, water, etc,
ensuring you always have a clear view.
• Dual chamber design keeps any moisture
or water that may leak from the harness
from getting inside in the camera.
• Sturdy aluminum die-cast housing ensures
the durability of the camera body.
Thanks to the digital CCD image sensor,
these heavy-duty cameras have exceptional
picture quality.
CC2000E
Heavy Duty Color CCD Camera
(Mirror Image/Wide Angle)
CC2003E
Heavy Duty Color CCD Camera
(True Image/Wide Angle)
CC2002E
Heavy Duty Color CCD Camera
(True Image/Narrow Angle)
6
Dual chamber design
Opening and
closing of shutter
is coupled with
camera operation
(CC2001F only).
The connector
can be tightened
securely with a
wrench to ensure
watertightness.
CCD CAMERAS
With a lineup that ranges from a model with infrared LED illumination to sleek,
ultra compact models and more, there’s a Clarion CCD camera to meet every need.
IR ILLUMINATED COLOR CCD CAMERA
Designed for a wide range of applications
with infrared LED light, microphone, preheater, and more.
CC3000E
IR Illuminated Color CCD Camera
• Illumination is provided by the camera’s infrared
LED light, making it especially convenient when
backing up at night or in a dark garage.
• Built-in microphone so you can hear, not just
see, what’s going behind your vehicle.
• Built-in pre-heater ensures the camera
is ready for use at all times.
• Combines cost performance and multifunctionality in a single unit.
Note: Microphone function is available only in
combination with the CJ7100E or CJ7300G.
ULTRA COMPACT COLOR CCD CAMERAS
Incorporating high-performance CCDs in ultra-compact bodies, these
small CCD color cameras are ideal for smaller vehicles.
CC2011E
/ CC2012E
CC2015E
Ultra Compact Color CCD Camera
• Wide 130° viewing angle provides the field of view
you need even at low mounting positions.
Ultra Conpact CCD
Wide View Angle
• Small, light design allows for easy mounting.
130°
CC2011E with Heavy Duty
Mounting Bracket and Metal
Shroud
• Heavy-duty version of the CC2011E
with strengthened mounting
bracket and metal shroud.
97°
CC2011E shown with optional
PQE-033 cover installed.
COMPACT COLOR CCD CAMERA
CC1030E
Compact Color CCD Camera (Mirror Image/Wide Angle)
• Compact size and light weight.
• Wide-angle view.
7
SDHC VIDEO CAPTURE
Surveillance recording in and around your vehicle is the best way to assure the
safety and security of both you and your passengers.
When it comes to surveillance recording, Clarion has the expertise to provide you with the superior, leading-edge
technology you demand. Building on our proven reputation for reliability, our CF5000E in-vehicle digital recorder uses
a new SDHC memory card, which is a large-capacity version of an SD card. Unlike a conventional hard disk, the SDHC
card feature high vibration resistance, low running cost and removable convenience, making it the ideal medium for invehicle dgital recording.
CF5000E
SDHC Quad Camera Digital Video Recorder
Tamper prevention
kit is included.
Large-capacity, easy-to-handle SDHC card
Up to 4 cameras can be connected
• Video data is compressed in the H.264 format and audio data
is compressed in the G.726 format, enabling approx. 4 hours of
recording per gigabyte (30 fps, 512 kbps, VGA).
•Up to 4 channels of video can be input for extensive coverage of
driving and vehicle conditions. When 4 Clarion CCD
cameras are installed at various locations inside and outside of
the vehicle, areas such as the front of the vehicle, the interior,
rear of the vehicle and door areas can be fully covered.
• Continuous recording mode is the default setting and
event-activated recording mode is also available.
• The CF5000E incorporates a built-in power supply for 4 highperformance, high-reliability Clarion color CCD cameras.
• Data storage on easy-to-handle, large-capacity SDHC cards
(up to 16 GB).
Driving/vehicle data recording
• The CF5000E incorporates a GPS receiver to record vehicle
location data and records other data including driving time,
vehicle ID, flagged points, activation of the brake and directional
signals and door contact status.
Emergency locked file function
• Images recorded while the emergency trigger button is kept
depressed cannot be overwritten.
Comprehensive security functions
• A tamper prevention kit with lock is incorporated to protect the
CF5000E’s main unit.
• Recorded data can only be played back when the vehicle
management information is verified via proprietary playback
software, which also has a data tampering detection function.
8
Note: The CC2001 camera with shutter cannot be used.
Automatic Run-On timer function
• The CF5000E can be configured continues recording for up
to 90 minutes after the car’s accessory power is turned off.
Specifically designed for in-vehicle usage
• Compatible with DC 12–24 V.
• Installation is easy thanks to the compact design.
• Since there are no mechanical moving parts, there is no need
for periodic replacement of components.
• Built to stand up to the most severe conditions including
vibrations, impact, high humidity, and high temperature.
General Features
• Camera images input as composite video signals (from up to 4 camera systems) can be H.264/AVC compressed and
recorded onto an SDHC memory card while being simultaneously display on a quarter-split screen video.
• H.264/AVC files recorded onto the SDHC memory card can be reviewed using dedicated software CTA-042-400 (sold
separately).
• The time of recording (year, month, date, hour, minutes and seconds) according to the internal clock can be
superimposed onto the camera image.
• Through the use of GPS reception, location information can be recorded together with the video image. Time
correction of the internal clock can also be made.
• By using a computer and Class 6 or above SDHC memory card reader/writer, files within the SDHC memory card can
be played, backed up, and formatted.
System configuration example
GPS Antenna
(included with CF5000E)
Emergency Trigger Button
SDHC Card
Video Image/Driving Data Storage
CF5000E
• Speed Sensor
• Engine RPM
• Power Supply +12 V/24 V
• Brake
Etc.
Color CCD Camera
Color CCD Camera
Color CCD Camera
Color CCD Camera
(True Front Image)
(True Cabin Image)
(True Cabin Image)
(Mirror Image for Rear View)
CC2002E
CC2003E
CC2003E
CC2000E
Specifications
Main unit dimensions
(excluding tamper prevention mechanism)
5 to 30 fps (NTSC)
VGA: 640 × 480 / CIF: 352 × 288
Frame rate
178 (W) × 40 (H) × 153 (D) mm
Resolution
Overall dimensions
(including tamper prevention mechanism)
(selectable)
193 (W) × 40 (H) × 170 (D) mm
Weight
Approx. 1.3 kg
Power supply
+12 V/+24 V
Recording media
4 GB to 16 GB SDHC memory card
Please ask your Clarion dealer for
recommended SDHC cards.
External input terminal
Camera input × 4 (DIN 5P × 4)
Alarm input × 4
Audio input × 1 (MIC input or Line input)
External output terminal
Video output × 1
Alarm output × 2
Audio output × 1
GPS receiver
Built in
Number of connected cameras
4 (Clarion cameras)
Recording compression method
MPEG4/AVC (H.264)
Recording time (Reference values)
Event recording
Creates an event file that includes the
triggered file, the file before the event
file and the file after the event file
Overwrite prevention function
Selectable overwrite protection of
event files
Run-On timer function
Recording can be continued for up
to 90 minutes after ACC power is
switched off
Camera angle of view (CC2003E)
Left-Right 118°, Up-Down 97°
Link to GPS mapping
Available
Operating temperature range
-10°C~+55°C
• Tamper prevention kit
• Camera connector
• Power cable
• Trigger input cable
• Mounting bracket • GPS antenna
Included accessories
Recording capacity 16GB
Bit rate [kbps]
No. of frames/sec.
Resolution
Audio recording
30/sec.
VGA
Available
2048
1024
512
Approx. 16 hrs.
Approx. 32 hrs.
Approx. 64 hrs.
256
128
Approx. 128 hrs. Approx. 256 hrs.
Note: The recording capacity does not change even when the number of frames is changed. When the number of frames is increased, the picture quality of each frame decreases.
9
VIDEO CAPTURE SOFTWARE
Offers unprecedented retrieval capability in a conventional viewer, while synchronizing all
video images with map routes and velocity graph.
CTA-042
Viewing Software Suite for CF5000E
• Allows you to confirm images as well as driving conditions and
locations as they are recorded.
• Sudden braking, abrupt starting, and abrupt steering are listed
chronologically to enable retrieval of dangerous driving events.
Turn signal and brake/door status are also displayed.
• Map routes and vehicle travelling data can be displayed in sync
with video images.
• Velocity values are shown on a graphic display.
• Cockpit view features animated reproduction of driving
conditions synchronized with the current on-screen images.
List view
Shows dangerous
driving information.
Map view
Video view
Graph view
Velocity values and
vehicle behavior are
shown on a graphic
display.
Cockpit view
Steering wheel
Left/right turn signals
Speedometer
Brake lamp
Reverse lamp
Information such as Vehicle Speed, Engine RPM, Turn Signals, Brake and Reverse Lamps requires connectiion during installation.
Download Wizard
Management functions
Easy-to-operate, user-friendly displays
• Setting and administration of vehicle information such as
• Data recorded on the SDHC card can be transferred to your PC’s hard disk and
• Contact setting/danger degree setting.
• Setting operation parameters including recording conditions
vehicle names and vehicle numbers.
stored for playback at anytime.
on SDHC card.
• Data tampering detection function.
• Password management function.
Main Menu
Insert the SDHC card.
Select the download.
Select the type of download according to the
degree of danger.
A graphic display shows
the available hard disk
capacity.
Start downloading.
Note: CTA-042 screen displays are subject to change due to product updates.
10
ACCESSORIES
Clarion offers all the cables and accessories required to complete a reliable installation on
any kind of vehicle.
Water-resistant Specifi cation Camera
Cables for CC2000 Series Camera
CCA-416 ( 5m / 16ft.)
CCA-392 ( 7m / 23ft.)
CCA-393 ( 10m / 33ft.)
CCA-435 ( 13m / 42ft.)
CCA-394 ( 15m / 49ft.)
CCA-436 ( 18m / 59ft.)
CCA-395 ( 20m / 65ft.)
CCA-437 ( 23m / 75ft.)
Water-resistant specifi cation
extension cables
CCA-439 ( 0.9m / 3ft.)
CCA-391 ( 5m / 16ft.)
CCA-415 ( 10m / 33ft.)
Cables & Installation Kit for Trailer
Power Box (only for 12V vehicles)
CAA-188
• DC12V power box.
• Connects Clarion cameras
to Clarion in-car TV.
• 8pin mini Din.
• Manual on / off switch.
CAA-185
• DC12V power box.
• Connects Clarion cameras
to Clarion in-car TV.
• Connects Clarion cameras
to any monitor with
composite video input.
Water-resistant Camera Cables for
CC2011E Series / CC1030E Camera
CCA-532 ( 7m / 23ft.)
CCA-533 ( 10m / 33ft.)
CCA-534 ( 15m / 49ft.)
CCA-535 ( 20m / 65ft.)
Trailer “break point” to camera cables
Optional Cover for CC2011E/CC2012E
CCA-452 ( 20m / 65ft.)
CCA-453 ( 15m / 49ft.)
CCA-451 (
5m / 16ft.)
Cabin (monitor) to trailer break cable
CCA-454 ( 15m / 49ft.)
PQE-033
Water-resistant Specifi cation Camera
Cables for CC3000E Camera
CCA-729
• For connecting CJ5600,
CJ7100 & CJ7300G.
• 20m / 65ft
CCA-730
• Only for DC12V.
• For connecting generalpurpose AV monitor with
video input terminal.
11
CCD CAMERAS
CC2001F/CC2004E CC2000E/CC2003E
CC2002E
CC1030E
CC2011E/CC2015E/
CC2012E
CC3000E
N
Dual chamber design
Y
Y
Y
N
N
Motorized lens shutter
Y
N
N
N
N
N
Digital zoom ( x 1.4)
Y
Y
Y
N
N
N
IR LED
N
N
N
N
N
Y
Microphone
N
N
N
N
N
Y
Low light rating (lux)
1
1
1
3 or less
3 or less
0.01 ( 6 LED ON)
Iris function
Y
Y
Y
N
N
N
CCD pixels
250,000
250,000
250,000
250,000
250,000
250,000
View angle(horiz./vert.)
Operating temperature range
118/97
118/97
40/30
115/88
130/97
95/70
-30°C to +70°C
-30°C to +70°C
-30°C to +70°C
-30°C to +70°C
-30°C to +70°C
-10°C to +60°C
1/4"
1/3"
CCD size
Power voltage (camera)
Current consumption
(camera)
Power voltage (shutter)
Current consumption
(shutter)
Vibration rating (G-force)
True/Mirror image select
1/4"
1/4"
1/4"
1/4"
9Vdc.neg connection
9Vdc.neg connection
9Vdc.neg connection
9Vdc.neg connection
Less than 150mA
Less than 150mA
Less than 150mA
Less than 150mA
Less than 120mA
Less than 200mA
DC12V
N/A
N/A
N/A
N/A
N/A
Less than 300mA
N/A
N/A
N/A
N/A
N/A
10
10
10
10
6.8
6.8
True
Mirror
Mirror(CC2011/CC2015)/True(CC2012)
Mirror
27 x 25 x 28.3
72g (CC2011/CC2012),
86g(CC2015)
NTSC
70 x 44 x 57
Mirror(CC2001F)/True(CC2004E) Mirror(CC2000E)/True(CC2003E)
Size (W x H x D mm )
80 x 40.5 x 57.4
80 x 40.5 x 53
80 x 40.5 x 53
48 x 35 x 32.5
Weight
300g
260g
260g
100g
Signal system
NTSC
NTSC
NTSC
NTSC
LCD COLOR MONITORS
CJ5600E
CJ7100E
5.6
7
7
DC12V/24V
DC12V/24V
DC12V/24V
Power consumption
550mA (DC12V, monitor set only)
450mA (DC12V, monitor set only)
900mA (DC14V, with one Camera)
Picture element pixel
320 (W) x 3 (RGB) x 234 (H)
480 (W) x 3 (RGB) x 234 (H)
800 (W) x 3 (RGB) x 480 (H)
Built-in speaker
N
Y
Y
Volume control
N/A
Y
Y
Day/Night dimming
MAN
MAN
MAN
Image:True/Mirror
Selectable
Diagonal screen size (inches)
Power supply
CJ7300G
Selectable
Selectable
Reverse gear on trigger
Y
Y
Y
Camera switcher
Auto triggering for 2nd
camera
Auto triggering for 3rd
camera
Separate video input
Y (2 cameras)
Y (2 cameras)
Y (4 cameras)
Y
Y
Y
N
N
Y
N
Y
Y
Separate video output
N
N
N
Separate audio input
N
Y (MONO INPUT)
Y (MONO INPUT)
Separate audio output
N
N
N
Electronic distance markers
N
N
Y (adjustable)
Operating temperature range
-10°C to +60°C
-10°C to +60°C
-10°C to +60°C
Size (W x H x D mm )
163 x 112 x 30
187 x 113.5 x 26.6
174 x 125 x 27
300g
450g
480g
NTSC (switch between NTSC/PAL)
NTSC (switch between NTSC/PAL)
NTSC
Weight
Signal system
Clarion Canada Inc.
2239 Winston Park Drive,
Oakville, Ontario, L6H 5R1, Canada
Tel:(1)905-829-4600
Fax:(1)905-829-4608
Specifications and design are subject to change without notice.
12
9Vdc.neg connection 12Vdc.neg connection
238g
NTSC
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
