Cadillac | 2013 XTS | CADIllAC XTS

CADIllAC XTS
A l l- n e w 2 0 1 3
C ADIll AC XTS
THE NEW STATE of
THE STATE of THE ArT.
For those in search of true, contemporary luxury, the long wait is over. The Canadianbuilt 2013 Cadillac XTS shatters expectations of what luxury driving can be. It’s
elegantly styled, with a bold presence that turns heads. It reinvents the way you
control mobile information, communication and entertainment, with the revolutionary
and intuitive Cadillac User Experience. It delivers formidable performance with
impressive efficiency, thanks to cutting-edge V6 power. It redefines chassis
technologies, with a standard Magnetic Ride Control ® suspension and premium
Brembo ® brakes. And it s cabin blends best-in-class spaciousness, ingenious
amenities and meticulous craftsmanship. In short, the new XTS is the most advanced
production sedan in Cadillac history – and the new state of the art in luxury sedans.
At Left: XTS, shown in Graphite Metallic with available Platinum Collection.
03
How can cold steel
generate so MUcH Heat?
In appearance as in every other aspect, the new XTS leaves the conventional far behind. The sheet
metal is chiselled and assertive. The stance, confident, poised and potent. Lines that sweep gracefully
from the front fenders to the Cadillac-signature vertical taillights suggest motion even when the car
is standing still. Best of all, XTS’s sleekly dramatic style also helps to smooth the flow of air over and
around the body. The resulting aerodynamic efficiency not only helps reduce fuel consumption, it also
contributes to more ef fortless performance, a quieter cabin and a more peaceful and relaxing ride.
1
2
3
1 Every XTS is equipped with advanced Xenon High-Intensity Discharge
2 Standard on XTS are elegant 19-inch premium painted aluminum
3 A distinctive feature of the new XTS’s exterior design is a sleeky styled third side window located
(HID) headlights. Premium Collection and Platinum Collection models
include adaptive forward lighting, which turns the headlights as you
steer into curves and corners for more effective illumination.
wheels with chrome inserts. The gleaming 20-inch, 15-spoke
wheels shown here are among the many premium features included
on Platinum Collection.
behind each rear door. These windows allow more light into the cabin, for a brighter, more enjoyable
ride, and give rear passengers an increased sense of space and a better view. A power rear window
shade and manual rear-side window shades are available to reduce bright glare on sunny days.
At Right: XTS, shown in Graphite Metallic with available Platinum Collection.
05
ATTENTION TO DETAIL
mAkEs ALL ThE DIffErENcE.
Design. Technology. Materials. Craftsmanship. The XTS cabin achieves a higher standard on all fronts. The
lines of the instrument panel sweep seamlessly into the upper doors, providing a satisfying sense of
space and unity. Expertly worked leathers, exotic woods and brushed metals reward both the eye and the touch.
Seating comfor t excels, t hank s t o cont our e d front bucket s t hat w er e r efine d t hrough t he us e of
pressure-mapping technology to eliminate “hot spots.” Your rear passengers will also enjoy a premium riding
experience, with best-in-class legroom* and a slightly raised seat height that affords them a superior view all round.
* Based on WardsAuto.com 2012 Middle Luxury segmentation. 2012 Model Year competitive data for segment based on latest published information available at time of printing.
1
1 Included with the Luxury Collection, Premium Collection and Platinum
Collection, an interior ambient lighting package highlights the quality of
the premium leathers, woods and metals that adorn the XTS cabin.
2
2 Supple leather seating surfaces are an integral part of every XTS
interior. The Platinum Collection takes that a step further, with seats
upholstered all around in unique, ultra-soft Opus aniline leathers.
At Left: XTS interior with available Premium Collection, shown in Caramel with Jet Black accents and available features.
07
IT fITs you lIke
a fINely TaIloReD BesPoke suIT.
In the XTS cockpit, every lever and switch is perfectly located, ideally weighted to deliver positive feedback and sculpted
with a fine sense of contemporary style. Together with a leather- and wood-trimmed steering wheel that’s power-adjustable
for both angle and reach, the well-bolstered 10-way power driver’s seat makes it a simple matter to find the driving position
that provides optimal comfort and control. Fine materials abound, and are a delight to both the eye and the hand, while the superb
sound reproduction of the Bose ® audio system beguiles the ear. For Cadillac’s state-of-the-art flagship sedan, it’s only fitting.
1
1 Included with the Premium Collection and Platinum Collection is the custom-designed 14-speaker Bose ® 5.1 Studio
Surround® audio system which delivers 6 channels of sound for a remarkably rich, detailed listening experience. An excellent
8-speaker Bose® audio system is standard on XTS and Luxury Collection.
2
2 With AudioPilot ® noise compensation technology and a pair of Personal® surround speakers mounted in the top of
each front seat, the Bose ® Studio Surround® audio system delivers all the emotion and dynamics of a live performance,
regardless of where you happen to be sitting in the car.
09
CADILLAC USER EXPERIENCE:
REvoLUtIoNARy, INtUItIvE CoNtRoL.
The entirely new Cadillac User Experience – CUE for short – puts a world of connectivity, entertainment
and communication at your fingertips. CUE lets you pair your XTS with up to ten Bluetooth ® -enabled
smartphones.* Access your contacts, audio files and more. Listen to text messages – and respond –
hands-free while you drive.** And store up to 60 presets, including points of interest, phone numbers,
as well as radio stations and more. Best of all, it employs an icon-based touch-screen control system
inspired by those found in the best smartphones, so you already know how to use it. CUE even detects
your hand as it approaches, then pulses to acknowledge your command. For a detailed demonstration
of how the revolutionary Cadillac User Experience changes driving forever, see your Cadillac dealer.
* Full functionality requires compatible Bluetooth ® and smartphone. Some devices require USB connectivity. ** Interim availability.
CONFIGURABLE INSTRUMENTATION
CUE lets you configure your XTS’s gauge cluster to display only the information you prefer.
1
2
3
1 Enhanced gauge cluster.
4
2 Balanced gauge cluster.
3 Simple gauge cluster.
4 Performance gauge cluster.
CONTROL
With a 203-mm (8-in.) touch screen featuring visual icons, proximity sensing, tactile feedback and voice recognition, CUE is as easy to use as your smartphone.
CONNECTIVITY
Using Bluetooth ® 3.0 technology, Cadillac’s revolutionary CUE can integrate your
smartphone and, on select models, 3D navigation into a single, intelligent system.
CONVENIENCE
To adjust the climate control system, change the radio station, contact OnStar ® or
perform a host of other functions, just touch the appropriate on-screen icon.
11
1
XTS SeeS more
So YoU KNoW more.
When driving, knowledge is your first line of defense. Using leading-edge ultrasonic,
radar and camera-based technologies, XTS advances that defense a step forward
with available driver warning systems including Forward Collision Alert, Lane
Departure Warning, Side Blind Zone Alert,* Rear Cross Traffic Alert, Front and
Rear Parking Assist and the innovative Safety Alert Seat. XTS’s advanced remote
sensing technology also enables a higher level of convenience in the form of
Adaptive Cruise Control.** When this available system is activated, your XTS
will slow automatically when it encounters a vehicle ahead, then maintain
apreset following distance until your preferred speed can be resumed.†
2
* Before making a lane change, always check the Side Blind Zone Alert display,
check the exterior and interior rear-view mirrors, look over your shoulder
for vehicles and hazards, and activate your turn signal.
** Interim availability.
† Adaptive Cruise Control is no substitute for the driver’s personal responsibility
to operate the vehicle in a safe manner. The driver needs to remain attentive
to traffic and road conditions and provide the steering, braking or
other inputs necessary to retain control of the vehicle.
1 XTS’s available Front and Rear Automatic Braking feature** monitors
for obstacles in front of and behind the car during low-speed manoeuvres.
When it senses that a collision may be about to take place, the
system alerts the driver and, if necessary, can apply
the brakes without driver intervention.
2 Included on Premium Collection and Platinum Collection is the Safety Alert Seat,
available exclusively on XTS. By sending an immediate pulse through the seat cushion,
either right or left, or simultaneously, this patented technology quickly and
intuitively warns you of the direction of a potential hazard.
At Left: XTS employs radar technology and strategically placed cameras to
monitor for potential hazards at the front, sides and rear of the vehicle.
13
1
EnginEEring that’s so far
ahEaD of thE CUrVE
yoU’ll think it’s magiC.
Today’s luxury means performance with efficiency, as demonstrated by the XTS’s
advanced new 3.6-litre V6 engine. Thanks to cutting-edge technologies like direct
fuel injection, it puts 304 horsepower at your disposal while also delivering
impressive fuel efficiency. XTS’s chassis behaviour is equally magical, thanks to
sophisticated HiPer Strut front suspension geometry and class-exclusive Magnetic
Ride Control ® technology* that helps both sharpen handling and smooth out
pavement irregularities. In addition, XTS’s available torque-vectoring Haldex
All-Wheel-Drive system is engineered to help optimize traction on slippery
surfaces. A rear electronic limited-slip differential distributes torque across the
rear axle, ensuring power goes to the wheel with the best grip. Rounding out the
technical package is a confidence-inspiring braking system by world leader
Brembo ® borrowing braking technology from Cadillac’s high-performance CTS-V.
* Based on WardsAuto.com 2012 Middle Luxury segmentation. 2012 Model Year competitive data for segment based on latest published information
available at time of printing.
1 XTS’s innovative 2-door capless fuel system is superior to some competitive single-door
systems which are vulnerable to leaks. Not only does it keep both your car and your hands cleaner,
it also helps prevent the paint scratches that a loose tethered cap can produce.
2 XTS’s V6 engine employs direct fuel injection, a very precise fuel delivery technology
that helps maximize power while simultaneously reducing fuel consumption and emissions.
3 To optimize ride and handling characteristics, Magnetic Ride Control® –
a technology pioneered by Cadillac – assesses driving conditions every millisecond
and can adjust individual shock absorber damping every 5 milliseconds.
At Far Right: XTS, shown in Graphite Metallic with available Platinum Collection.
3
2
15
Wrap yourself in an
ulTra-HiGH-sTrenGTH
sTeel safeTy BlanKeT.
With its strategic use of advanced ultra-high-strength steel, the XTS body structure
is engineered to resist intrusions into the passenger compartment in the event
of a collision. This rigid safety cage is supplemented by a full range of other
passenger protection essentials, including front and rear crumple zones,
pretensioners in the front safety belts and no fewer than ten standard airbags.
onsTar :
®
Drive connecteD.
Among the many powerful reasons for choosing XTS, OnStar ® is one of the very best.
OnStar ® is standard on every XTS, along with twelve months of the Directions &
Connections Plan with Turn-by-Turn Navigation.* Described below are some of the
remarkable services OnStar ® can perform for you.
AUtoMAtic crASH reSPonSe
reMote veHicLe DiAGnoSticS
Any time your XTS’s integrated crash sensors indicate that a
collision has taken place, the vehicle immediately forwards that
information to the OnStar ® Centre. An OnStar ® Advisor will call
immediately to see if you need help. If you’re unable to respond,
the Advisor can determine your exact location via GPS and
dispatch emergency services.*
OnStar ® can provide you with the information you need to keep your
new XTS in top condition. Every month, the system can run a series
of diagnostic and maintenance checks and send you a
comprehensive report via email.
StoLen veHicLe ASSiStAnce
In the unlikely event that your XTS should be stolen, OnStar ® can
help recover it. Using GPS technology, OnStar ® can locate your
vehicle and track its movements. OnStar ® can relay that
information to authorities who can use it to recover your XTS quickly
and safely.
tUrn-BY-tUrn nAviGAtion
When it comes to user-friendliness, OnStar ®’s Turn-by-Turn
Navigation has no equal. By pressing a single button, you make a
voice connection to an OnStar ® Advisor and tell him or her where
you want to go. Within seconds, clear, audible directions are
downloaded to your XTS. Turn-by-Turn Navigation will even help get
you back on track automatically if you take a wrong turn.
1
1 To ensure positive, immediate
braking response in wet
conditions, XTS’s Auto-Dry brake
system pulses pressure to the
brake calipers to wipe the rotors
dry. It also turns on automatically
when the available rain-sensing
windshield wipers are activated.
HAnDS-Free cALLinG
OnStar ®’s built-in wireless calling feature helps you make mobile
calls legally. It also provides a convenient and reliable connection,
even in areas where cellular reception is limited. Calling fees apply.
See dealer for details.
onStAr reMoteLink™
The OnStar RemoteLink™ app
makes it easy to connect to
OnStar ®, even when you’re not
in your car. OnStar RemoteLink™
allows you to perform a series of
functions remotely from your
iPhone® or select Android™
devices. Once you download and
register the app at onstar.ca,
you can access all the following
functions regardless of where you may happen to be:
•Lock/unlockyourdoors
•Startyourengineremotely
•Activateyourhornandlightstohelpyoufindyourvehicle
•Viewreal-timefuelinformation(rangetoempty,fuelremaining,current
fuel consumption and lifetime fuel consumption)
•SendOnStar® Turn-by-Turn Navigation directions to your vehicle
•Checkyourtirepressureandremainingoillife
•AccessyourOnStar ® account information
•ContactanOnStar ® Advisor, Roadside
Assistance or your preferred Cadillac dealer.
*Visitonstar.caforcoveragemap,detailsandsystemlimitations.
Services vary by model and conditions. OnStar ® acts as a link to
existing emergency service providers.
CadillaC Shield:
THE NEW STANDARD OF LUXURY OWNERSHIP.
At Cadillac, we believe our owners deserve the very best. That’s why when we set
out to create the ultimate customer experience, designing and engineering great
vehicles was just the beginning; we were also looking to create an experience
comparable with the world’s greatest luxury brands. Every vehicle we sell is backed
by Cadillac Shield, the most comprehensive suite of owner benefits offered by any
luxury automotive brand in the world. From innovations like Remote Vehicle
Diagnostics and advanced mobile apps to our no-charge Premium Care Maintenance
Program, Cadillac Shield sets an entirely new standard of luxury ownership.
CadillaC WaRRaNtY
COuRteSY tRaNSPORtatiON
diaGNOStiCS BY ONStaR ®
Every Cadillac is covered by a 4-year/80,000 km
Limited Warranty,* which covers repairs on your
entire vehicle, including par t s and labour, to
correct problems in materials and workmanship.
A 6 -year/ 110,000 km Power train Component
Limited Warranty* is also included that covers
select powertrain components.
W h e n e v e r y o u r X T S r e q u ir e s s c h e d u l e d
maintenance or warranty repair service during
the warranty period, your dealer will provide
you w it h s hu t tle t ra n s p or t ation f or d aily
service or an alternate car (or reimbursement
for rental or other transportation expenses) for
overnight service.
With best-in-class diagnostics from OnStar ®
you c an run r e gular ch e ck s on a w id e
variety of vehicle systems. You can also
receive updates via email or the OnSt ar
RemoteLink TM app for iPhone ® or select
Android TM phones.**
PReMiuM CaRe MaiNteNaNCe
NaViGatiON BY ONStaR ®
CONNeCtiONS BY ONStaR ®
Standard on every new Cadillac is the no-charge
Cadillac Premium Care Maintenance Program,
which covers select required maintenance services
during the first 4 years or 80,000 km of ownership.*
Jus t push t he OnSt ar ® but ton and a sk t he
Advisor for direc tions to your destination.
OnStar ® will download directions to your XTS
and a voice will call out every turn.**
With the OnStar RemoteLinkTM app, you can
access and control select vehicle information
and features from anywhere you have cell
phone service.**
ROadSide aSSiStaNCe
SeCuRitY BY ONStaR®
eMeRGeNCY BY ONStaR ®
A ny t im e yo u r e q uir e a s sis t a n c e d u rin g t h e
6 - y e a r/ 110,0 0 0 k m Po w e r t r ain C o m p o n e n t
Limited Warranty period,* regardless of where
you may be in Canada or the contiguous United
States, Roadside Assistance is at your disposal
24 hours a day, 7 days a week, 365 days a year.
In the unlikely event that your XTS is stolen,
OnStar ® can locate it via GPS. An Advisor can
t h e n s e n d a St ole n Ve hicle Slo w do w n ® or
Re mot e Ignition Block signal (working in
conjunction with police) to help authorities
safely recover your vehicle.**
In the unfor tunat e event of a cra sh,
O n St a r ® c a n a u t o m a t i c a ll y d i s p a t c h
emergency services to your exact location,
even if you’re unable to ask for help.**
* Whichever comes first, fully transferable. See dealer for complete details.
** Visit onstar.ca for coverage map, details and system limitations. Services vary by model and conditions. OnStar ® acts as a link to existing emergency service providers. Active OnStar ® subscription required.
17
XTS offerS a ColleCTion To
SuiT every luXury driver.
At Cadillac, we know every luxury car driver is unique. To assist you in tailoring
your new luxury sedan to your individual preference, the style, technology
and performance of XTS are offered in a choice of distinct Collections.
Standard ColleCtion
luxury ColleCtion
Outstanding style, exceptional quality, scintillating performance, thoughtful
amenities: all the essentials of the luxury car experience are present and
accounted for in the Standard Collection.
The Luxury Collection is equipped to deliver higher levels of comfort,
convenience and safety. A Memory Package for the driver’s seat, exterior
mirrors and steering column is included, as is a rear vision camera.
1
2
1
2
3
4
3
4
1 Genuine Sapele wood trim on XTS’s steering
wheel, centre console and centre stack adds warmth
and distinction.
2 A bold Cadillac logo framed by a finely detailed
bright chrome and piano-black front grille adds drama
to XTS’s front styling.
1 High-tech vertical LED daytime running lights
provide a distinctive styling accent at the front end
of the Luxury Collection.
2 As you approach your Luxury Collection equipped
XTS, the door handles glow softly to make themselves
easier to locate in the dark.
3 XTS’s front bucket seats feature supple leather
seating surfaces and are heated and ventilated for
four-season comfort.
4 Puddle lights located under the exterior rear-view
mirrors provide convenient illumination as you enter
and exit your XTS.
3 Bright dual integrated exhaust outlets add a
well-finished and contemporary look to the Luxury
Collection’s rear styling.
4 Luxury Collection’s wood-and-leather trimmed
steering wheel is heated, adding to your personal
comfort on chilly mornings.
Premium ColleCtion
Platinum ColleCtion
The Premium Collection delivers outstanding refinement and a higher level
of advanced technology. Features like Lane Departure Warning,* Forward
Collision Alert and Cadillac’s innovative Safety Alert Seat are all included.
For the best of the best, look no further than the Platinum Collection. Supple
Opus full-leather seats, gleaming Lineate wood trim and a luxurious
Alcantara® headliner are just a sampling of what’s included.
1
2
1
2
3
4
3
4
1 A full-colour Head-Up Display (HUD) delivers
essential driving information and reduces the need to
take your eyes off the road.
2 Premium Collection’s forward adaptive lighting
system automatically turns the headlights as you steer
into curves and corners.
1 The Platinum Collection’s large UltraView sunroof
extends over both the front and rear seats. A power
sunshade is also included.
2 The Platinum Collection’s doors, console and
instrument panel are all wrapped in leather for a soft
touch and elegant appearance.
3 Radar-based Adaptive Cruise Control** adds
convenience and peace-of-mind when you encounter
traffic ahead during highway driving.
4 Premium Collection adds a 3D GPS Navigation
System to further enhance the revolutionary Cadillac
User Experience.
3 Open the front doors of the Platinum Collection
equipped XTS and the sill plates glow softly to greet
you and guide your entry.
4 A unique mesh grille treatment adds an extra measure
of refinement to the front styling of the Platinum Edition.
* Before making a lane change, always check the Side Blind Zone Alert display, check the exterior and interior rear-view mirrors, look over
your shoulder for vehicles and hazards, and activate your turn signal.
** Adaptive Cruise Control is no substitute for the driver’s personal responsibility to operate the vehicle in a safe manner. The driver needs to
remain attentive to traffic and road conditions and provide the steering, braking or other inputs necessary to retain control of the vehicle.
19
2013 XTS FEATURES & OPTIONS
SAFETY AND SECURITY
XTS
FWD
XTS
XTS
XTS
Luxury
Premium
Platinum
Collection Collection Collection
FWD/AWD FWD/AWD FWD/AWD
mECHANICAl
AIRBAGS
BRAkES
Driver and front-passenger, dual-stage, frontal with
passenger detecting system and automatic passenger
airbag suppression
Driver and front-passenger, seat-mounted side-impact
Driver and front-passenger, knee protection
Front-to-rear, head curtain side-impact
Rear-passenger outboard seating positions, seat-mounted
side-impact
4-wheel vented disc brakes with Brembo® front calipers
4-wheel, 4-channel Anti-lock Braking System (ABS)
with Intelligent Brake Assist, Dynamic Rear
Brake Proportioning
Auto-Dry Brakes
Silver-painted Brembo® front brake calipers
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
AUTomATIC CollISIoN PREPARATIoN
When an imminent collision is detected, braking is
automatically applied to enable a driver to avoid,
or to lessen the severity of an impact
XTS
FWD
XTS
XTS
XTS
Luxury
Premium
Platinum
Collection Collection Collection
FWD/AWD FWD/AWD FWD/AWD
S
S
S
–
–
O1,2
S1
Leather-wrapped inserts
S
S
–
S
S
–
S
S
–
S
S
S
–
–/S
–/S
–/S
S
–
S/–
–/S
S/–
–/S
S/–
–/S
Front and rear carpeted
Front and rear premium carpeted
Power glovebox release, lockable
Cloth
Alcantara microfibre-sueded, includes sail panels and pillars
Leather-wrapped, instrument panel top cover
3.6L V6 VVT with Direct Injection
304 horsepower @ 6800 rpm and
264 lb.-ft. of torque @ 5200 rpm
Block heater
INSTRUmENTATIoN
S1
DooR loCkS
Rear-door, child-security, power
S
S
S
S
–
O3
S
S
FoRwARD CollISIoN AlERT
Radar-based system detects possible collision threats and
alerts the driver using audible/visual cues
lANE DEPARTURE wARNING
Camera-based detection system warns driver of unsignalled
lane changes using audible cues or Safety Alert Seat pulses
–
O3
S
S
S
S
S
S
REAR CRoSS-TRAFFIC AlERT
Radar-based system alerts driver of oncoming traffic with
visual and audible cues when in reverse
–
O3
S
S
SAFETY AlERT SEAT
Warns driver to potential hazard with pulses through
seat cushion either left, right or simultaneously
(corresponding to the location of the hazard)
–
O3
S
S
Remote, adaptive
–
S
–
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
Automatic, dual-zone electronic climate control with
rear seat outlets
Automatic, tri-zone electronic climate control with
rear seat outlets and controls
Automatic filtration system with particulate, pollen and
odour filter
Windshield humidity sensor with auto defog activation
–
O3
S
S
S
S
S
S
S
S
S
S
S
S
S
S
–
O
S
S
–
–
O
S
S
–
S
S
S
S
S
S
S
S
–
–
–
–
S
S
S
S
S
S/–
S
S/–
S
S/–
S
–
S
–
S
–
S
S
S
S
–
–
S
–
S
–
–
S
S
S
S
S
S
–
S
–
S
–
–
S
–
–
–
S
S
S
–
–
–
–
S
S
S6
S6
S
S
–
S
–
S
S
S
S
S
S
–
–
S
S
–
S
S
–
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
–
–
S
S
S
–
–
S
S
–
S
–
S
S
–
S
–
S
S
–
–
S
S
S
S
S
S
S
–
–
O
S
S
S
S
S
lIGHTING
Illuminated entry/exit, front map, interior door handles,
glove box, instrument panel storage area and cargo area
Ambient lighting with LED light pipes and spotlights
Iluminated front door sill plates
loCkS
mIRRoR
Auto-dimming rear-view mirror
–
–
O1,2
S1
12-volt auxiliary outlets, 3 – 1 in instrument panel storage
area, 1 in centre console storage area and 1 in rear of
centre console
Rear power centre with 110-volt outlet in rear of
centre console
STEERING wHEEl
Leather-wrapped with wood insert
Leather-wrapped, heated with wood insert7
Leather-wrapped, heated with premium wood insert7
Audio system, cruise and voice recognition controls
Power tilt and telescopic adjustable column
SUNSHADES
CRUISE CoNTRol
Electronic, steering wheel-mounted controls
Adaptive Cruise Control, automatically adjusts speed and
maintains a pre-set following distance, with steering
wheel-mounted controls5
S
–
PowER oUTlETS
CoNSolE
Front centre floor console with sliding armrest, dual
cupholders and storage with dual USB ports, SD card
slot and auxiliary audio input jack
Leather-wrapped, console cover
Analogue gauge cluster with 4.2" colour LCD display layout
(includes speedometer, tachometer, coolant temperature,
fuel gauges and compass)
Reconfigurable 12" colour gauge cluster with 4 layout
themes (includes Balanced, Enhanced, Performance
and Simple)
Driver Information Centre (includes odometer, 2 trip
odometers, instantaneous fuel consumption, average
fuel consumption, exterior temperature display, GM Oil
Life Monitoring System, programmable features and
message centre)
Head-Up Display (HUD), full-colour, reconfigurable, projects
key vehicle information onto windshield
Tire pressure monitoring system
Automatic power, programmable with lock-out protection
E-Z KeyTM passive entry system includes push button start,
lock/unlock passive entry and personalization with
activation notification and panic feature
CARGo AREA
S
DRIvER ASSISTANCE PACkAGE1
Includes Adaptive Cruise Control,5 Automatic Collision
Preparation, Automatic Front and Rear Braking
–
S
vEHIClE STARTER SYSTEm
ClImATE CoNTRol
DRIvER AwARENESS PACkAGE
Includes Lane Departure Warning, Forward Collision Alert,
Safety Alert Seat, Side Blind Zone Alert,4 Rear CrossTraffic Alert and LED reflective display
6-speed automatic with steering wheel-mounted paddle
shift controls
S
TRACTIoN CoNTRol
Electronic, full-function, all-speed with on/off switch
S
–
TRANSmISSIoN
S
THEFT-DETERRENT SYSTEm
Electronic immobilizer
4-wheel independent with HiPer Strut front suspension,
H-arm rear suspension and automatic rear level control
Magnetic Ride Control® continuously variable
real-time suspension, dual-mode Tour and Sport
S
STABIlITRAk®
Electronic stability control system
Power-assisted, hydraulic, rack-and-pinion, variable-effort
S
SIDE BlIND ZoNE AlERT4
Alerts driver with visual cues on exterior rearview mirrors if a
vehicle is detected entering into your blind spots
S
S
STEERING
Power trunk release
Cargo convenience net
SECURITY SYSTEm
Content theft alarm, audible/visible, programmable
S
S
INTERIoR
SAFETY RESTRAINTS
LATCH (Lower Anchors and top Tethers for Children), rear
seats in 3 positions
3-point belts for all seating positions, front safety belt
pre-tensioners
S
S
SUSPENSIoN
oNSTAR SYSTEm
OnStar® In-Vehicle Communications and Assistance Service,
includes 1-year of the Directions & Connections Plan*
with Turn-by-Turn Navigation and OnStar RemoteLinkTM
S
S
ExHAUST SYSTEm
Dual, stainless steel with hidden outlets
Dual, stainless steel with outlets integrated into rear fascia
S
INSTRUmENT PANEl
Short-range radar-based "virtual bumper" system uses
ultrasonic sensors to detect obstacles and alerts the
driver through a series of automated cues and/or
preventative braking to avoid low-speed collisions
O1,2
–
HEADlINER
ENGINE
–
–
GlovE ComPARTmENT
AUTomATIC FRoNT AND REAR BRAkING
–
–
FlooR mATS
DRIvE
Front-Wheel Drive
All-Wheel Drive, advanced with torque vectoring
XTS
FWD
DooR TRIm
S
DIFFERENTIAl
Rear, limited-slip, electronic
INTERIoR (Continued)
XTS
XTS
XTS
Luxury
Premium
Platinum
Collection Collection Collection
FWD/AWD FWD/AWD FWD/AWD
Driver and front-passenger extendable with illuminated
vanity mirrors
Power rear window sunshade (includes manual rear-side
window sunshades)
UNIvERSAl HomE REmoTE
3-channel programmable remote transmitter
INTERIOR (Continued)
XTS
FWD
XTS
XTS
XTS
Luxury
Premium
Platinum
Collection Collection Collection
FWD/AWD FWD/AWD FWD/AWD
WINDOWS
Power express-up and down all windows with pinchguard
and rear passenger lock-out
S
S
S
S
–
S
S
S
MEMORy/PERSONAlIzATION PACkAGE
Automatically recalls settings for 2 drivers; the recall
function remembers the position of the driver’s
seat, exterior rear-view mirror and steering wheel
preferences and driver personalization features
WOOD TRIM PACkAGE
Includes genuine Sapele Pommele wood trim inserts on
steering wheel, centre console and centre stack
Includes genuine Sapele Pommele wood trim inserts on
instrument panel and doors
Includes genuine Lineate wood trim inserts on steering
wheel, centre console, centre stack, instrument
panel and doors
S
S7
S7
–
–
S7
S7
–
–
–
–
S7
EXTERIOR
FUEl FIllER
Capless fueling system
S
S
S
S
S
S
S
S
S
S
S
S
S
–
S
–
S
S
S
–
S
S
S
–
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
GlASS
Acoustic laminated windshield
Solar-Ray, tinted
lIGHTS
Daytime running lights with automatic light control and
Twilight Sentinel®
Auxiliary LED daytime running lights in lower fascia
Headlights, Xenon High-Intensity Discharge (HID)
Adaptive forward lighting with auto levelling
Windshield wiper activated
Puddle lights
Tail lights, LED
Illuminated exterior door handles
MIRRORS
Heated, power remote control with integrated turn signals
Heated, power remote control with integrated turn signals
and driver-side auto-dimming feature
S
–
–
–
–
S
S
S
S
–
–
–
–
S
S
S
PARkING ASSIST
Ultrasonic rear obstacle detection system with audible/
visible warning
Ultrasonic front and rear obstacle detection system with
audible/visible warning
REAR vISION CAMERA
Reverse assist for parking with guidelines indicating
vehicle’s projected path when in reverse, display
located in LCD display
–
S
S
S
–
O
O
S
S
–
S
–
S
O1
–
S
S
–
–
–
–
S
–
–
–
S
O1
–
–
–
–
S
S
–
–
S
–
S
–
S
SUNROOF
UltraView roof with power tilt and sliding glass panel, power
sunshade and express-open/close feature
XTS
FWD
SEATING
Power 10-way driver and front-passenger seat
adjusters with manual adjustable thigh support
and power lumbar adjusters
Front buckets with leather seating surfaces
Front buckets with Opus full-leather seating
Heated and ventilated front bucket seats
Heated rear seats, outboard
Rear seatbacks, 60/40 split-folding with armrest, storage,
cupholders and pass-through
XTS
XTS
XTS
Luxury
Premium
Platinum
Collection Collection Collection
FWD/AWD FWD/AWD FWD/AWD
S
S
–
S
–
S
S
–
S
S
S
S
–
S
S
S
–
S
S
S
S
S
S
S
S
S
S
S
DIMENSIONS
D
A
B
ENTERTAINMENT
AM/FM stereo with single CD player (located in
glove compartment), MP3 compatibility,
Radio Data System® (RDS) and TheftLock®
Cadillac User Experience (CUE) infotainment system,
includes 8" LCD touch screen with haptic feedback
and proximity sensing, interactive gesture control,
voice recognition, enhanced USB music playback and
iPod® control, 60 "favourite" presets, smartphone apps
integration1 and SMS text messaging read-back1
Same as above plus Navigation System for map coverage in
Canada and USA† with voice and/or text guidance
8-speaker Bose® premium audio system
14-speaker Bose® 5.1 Studio Surround® audio system
Motorized flip-up/down screen for access to hidden
instrument panel storage area
USB ports, 3 – dual in centre console storage area and 1 in
instrument panel storage area
Auxiliary audio input jacks, 2 – 1 in centre console storage
area and 1 in instrument panel storage area
Bluetooth® 3.0 hands-free phone and wireless audio
streaming connectivity recognizes up to 10
Bluetooth®-enabled smartphones8
SD memory card slot with full song indexing, centre
console-mounted
SiriusXM Satellite RadioTM††
S – Standard. O – Optional individually or in combination with
other optional equipment.
1. Interim availability.
2. Included with available Driver Assistance Package.
3. Included with available Driver Awareness Package.
4. Before making a lane change, always check the Side Blind
Zone Alert display, check the exterior and interior rear-view
mirrors, look over your shoulder for vehicles and hazards,
and activate your turn signal.
5. Adaptive Cruise Control is no substitute for the driver’s
personal responsibility to operate the vehicle in a safe
manner. The driver needs to remain attentive to traffic and
road conditions and provide the steering, braking or other
inputs necessary to retain control of the vehicle.
6. Features 4.2" colour LCD display.
7. Includes leather-wrapped shifter with wood insert.
8. Full functionality requires Bluetooth® and smartphone.
Some devices require USB connectivity.
* Visit onstar.ca for coverage map, details and system
limitations. Services vary by model and conditions.
** All-season tires may not satisfy winter tire requirements
D
S
S
S
S
–
S
–
O
S
–
S
–
S
S
–
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
in all regions of the country. Tires specifically designed for
severe winter conditions and marked with the “winter tire”
symbol may be required during certain months or in
certain regions. Contact your Provincial, Municipal or local
road authority for information regarding which tires are
required in your particular area.
† At time of print, detailed map coverage is available for
most major urban areas of the United States and for
certain metropolitan areas of Canada (Vancouver, Calgary,
Edmonton, Winnipeg, Windsor, London, Toronto, Ottawa,
Montreal, Quebec City and Halifax). Coverage is significantly
limited outside these areas.
†† Available in 10 Canadian provinces and the 48 contiguous
United States. Subscription sold separately after trial period.
Visit xmradio.ca for details.
‡ Includes weight of trailer, cargo, passengers and equipment.
All towing recommendations are subject to change. Trailer
tongue should be 10% of the maximum trailer weight but
should not exceed the load rating specified for that vehicle,
engine or hitch combination. See your dealer or refer to the XTS
Owner’s Manual for details.
E
F
C
C
EXTERIOR DIMENSIONS mm (in.)
Wheelbase
Length
Width
Height
Front track
Rear track
(A)
(B)
(C)
(D)
(E)
(F)
2837
5131
1851
1501
1567
1576
(111.7)
(202.0)
(72.9)
(59.1)
(61.7)
(62.0)
INTERIOR DIMENSIONS mm (in.)
Headroom
Front/rear
Legroom
Front/rear
Shoulder room
Front/rear
Hip room
Front/rear
Seating capacity
990/960 (39.0/37.8)
1069/1016 (42.1/40.0)
1470/1430 (57.9/56.3)
1400/1379 (55.1/54.3)
5
CAPACITIES
Fuel – FWD
– AWD
Cargo volume
Towing‡
70.5 L
74.0 L
509 L
454 kg
(15.5 imp. gal.)
(16.2 imp. gal.)
(18.0 cu. ft.)
(1000 lb.)
CURB WEIGHT, ESTIMATED kg (lb.)
FWD
AWD
1817 kg (4006 lb.)
1912 kg (4215 lb.)
TIRES
P245/45R19 all-season**
P245/40R20 all-season**
WHEElS (shown on page 23)
19" x 8.5" premium painted aluminum with
chrome inserts Q6M (A)
19" x 8.5" polished aluminum RT9 (B)
20" x 8.5" premium painted aluminum RQA (C)
20" x 8.5" polished aluminum with chrome inserts RQ9 (D)
WIPER/WASHER SySTEM
2-speed with variable delay (intermittent)
Rainsense with automatic variable control
21
2013 XTS INTERIOR COLOURS
XTS / Jet Black1
XTS luXury ColleCTion / Shale with Cocoa Accents2
nutella sapele
XTS Premium ColleCTion / Caramel with Jet Black Accents 3
nutella sapele
XTS Premium ColleCTion / medium Titanium with Jet Black Accents 4
Raven sapele
XTS PlATinum ColleCTion / Jet Black with light Wheat Accents5
XTS PlATinum ColleCTion / light Platinum with Dark urban and Cocoa Accents5
lineate
1 – Jet Black available on XTS, XTS Luxury Collection and XTS Premium Collection.
2 – Shale with Cocoa Accents available on XTS, XTS Luxury Collection and XTS Premium Collection.
3 – Caramel with Jet Black Accents available on XTS Luxury Collection and XTS Premium Collection.
4 – Medium Titanium with Jet Black Accents available on XTS Luxury Collection and XTS Premium Collection.
5 – Available on XTS Platinum Collection only.
All interior trim configurations are available with all exterior colours.
Raven sapele
nutella sapele with inlay
2013 XTS EXTERIOR COLOURS
ACQUISITION OPTIONS
In addition to the many exclusive privileges of Cadillac ownership, General Motors of Canada has
created a range of supplementary support programs to enhance your ownership experience. Some of
these programs assist you in purchasing the Cadillac of your choice. Others help protect you and your
new Cadillac over the long term.
PURCHASING:
• Purchase Financing or Leasing – on-the-spot financing at your GM dealership†
• The GM Card – GM cardholders may redeem up to $3500 GM Card® Earnings (subject to Vehicle
Redemption Allowances) toward the Total Purchase Price on eligible new GM vehicles.†† For full
program details please visit thegmcard.ca
† Subject to eligibility. †† Program subject to change.
ADDITIONAL OWNERSHIP PROGRAMS:
GAN – Radiant Silver Metallic
GBE – Crystal Red Tintcoat*,1
GBA – Black Raven
• GM Protection Plan (GMPP) – the only extended service plan backed by the resources and
commitment of General Motors, GMPP may be purchased at the time of sale or subsequently during
the New Vehicle Limited Warranty period.‡
‡ Conditions and limitations apply.
INFORMATION RESOURCES:
You can obtain more information about Cadillac vehicles and programs from your Cadillac dealer, or at
these information centres:
• The Cadillac website at cadillac.ca
• The Cadillac Contact Centre at 1-888-446-2000
(1-800-263-3830 for TDD users).
A WORD ABOUT THIS BROCHURE
GBN – White Diamond Tricoat*,2
GLK – Black Diamond Tricoat*,2
GLJ – Graphite Metallic
Some of the equipment shown or described throughout this brochure may be available at extra cost.
We have tried to make this brochure comprehensive and factual. We reserve the right, however, to
make changes at any time, without notice, in prices, colours, materials, equipment, specifications,
models and availability. Specifications, dimensions, measurements, ratings and other numbers in this
brochure and other printed materials provided at the dealership or affixed to vehicles are approximates
based upon design and engineering drawings and prototypes and laboratory tests. Your vehicle may
differ due to variations in manufacture and equipment. Since some information may have been
adapted since the time of printing, please check with your Cadillac dealer for complete details. General
Motors of Canada Limited reserves the right to lengthen or shorten the model year for any product, for
any reason, or to start and end model years at different times.
A WORD ABOUT ASSEMBLy
GXH – Sapphire Blue Metallic
GWT – Silver Coast Metallic
The exterior and interior colours in this brochure are as close to the actual vehicle production colours as the printing process allows.
For more accurate colour samples, ask your Cadillac sales consultant to see the dealer showroom vehicle colour display.
* Available at extra cost.
1 – Tintcoat is a premium two-layer paint application with the
addition of a tinted clearcoat, lending the finish an extra depth
and brightness.
2 – Tricoat is a meticulous three-layer process that results in a
dramatic hue-shifting colour reminiscent of a show-car finish.
Cadillac vehicles are equipped with engines and components produced and assembled by different
operating units of General Motors, its subsidiaries and suppliers and these engines and components
may change or be obtained from different sources from time to time. All such engines and components
are approved for use in Cadillac vehicles. Certain equipment ordered may be unavailable at the time of
assembly and we suggest that you verify that your vehicle includes the equipment you ordered, or if
there are changes, that they are acceptable to you.
A WORD ABOUT CORROSION
Cadillacs are designed and built to resist corrosion. All body sheet metal components are warranted
against rust-through corrosion for 6 years. There is no deductible for rust-through repairs.
Application of additional rust-inhibiting materials is not required under the corrosion coverage
and none is recommended.
TRADEMARKS
The marks appearing in this Cadillac brochure including, but not limited to: General Motors, GM,
Cadillac, the Cadillac badge, Cadillac Shield, CTS-V, XTS, and their respective logos, emblems, slogans
and vehicle model names and body designs; and other marks such as Cadillac User Experience, CUE,
Magnetic Ride Control, E-Z Key, HiPer Strut, StabiliTrak and Twilight Sentinel are trademarks of
General Motors and/or General Motors of Canada Limited, its subsidiaries, affiliates or licensors.
OnStar and the OnStar emblem are registered trademarks and OnStar RemoteLink is a trademark
of OnStar, LLC.
TheftLock is a registered trademark of Delphi Technologies, Inc.
Bose and Studio Surround are registered trademarks of the Bose Corporation.
Radio Data System (RDS) is a registered trademark of the U.S. National Association of Broadcasters.
The SiriusXM name and related logos are trademarks of SiriusXM Canada, Canadian Satellite Radio. Inc.
iPhone and iPod are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
The Android mobile technology platform is a registered trademark of Google Inc.
Bluetooth is a registered trademark of Bluetooth SIG Inc.
Brembo is a registered trademark of Brembo S.p.A.
Alcantara is a registered trademark of Alcantara Spa, Italy.
WHEELS
A
C
B
A – 19" x 8.5" premium
painted aluminum with
chrome inserts (Q6M)
B – 19" x 8.5" polished
aluminum (RT9)
D
C – 20" x 8.5" premium
painted aluminum (RQA)
(interim availability)
D – 20" x 8.5" polished
aluminum with
chrome inserts (RQ9)
© Copyright 2012 General Motors of Canada Limited. All Rights Reserved. All text,
images, graphics, and other materials in this Cadillac brochure are subject to
the copyright and other intellectual property rights of General Motors and/or
General Motors of Canada Limited. These materials may not be reproduced,
distributed or modified without the express written permission of General Motors
and/or General Motors of Canada Limited.
Printed in Canada, June 2012.
23
cadillac.ca
192-13-B-003E
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
