CSUN China Sunergy Product Catalog

CSUN China Sunergy Product Catalog

English bE1202

Europen Photovoltaic Industry Association

Energy for the Future

China Sunergy (Nanjing) Co., Ltd. (NASDAQ: CSUN), established in 2004, is a hi-tech corporation with its core business in R&D, manufacturing, and sale of high performance silicon based solar cells and modules.

As one of the leading PV enterprises in China, CSUN commits itself to providing the most advanced and clean solar energy for global customers, which contributes substantially to the global energy supply, as well as to the environmental protection.

Focus on High Efficiency

CSUN is the first PV company that applies SE technology to commercial production.

Dr. Jianhua Zhao, CTO of CSUN, keeps the world's highest record of silicon cell (mono) conversion efficiency for 22 years, which is 25% now.

R&D Roadmap (

Average Cell Efficiency

)

20.0%

19.5%

19.0%

18.5%

18.0%

17.5%

17.0%

16.5%

2011.1 2011.3 2011.6 2011.9 2011.12 2012.6

Cell Type

M156

S156

QSAR

TM

We've done a lot to achieve high efficiency.

Strict Selection of Wafer

We constantly improve our wafer selection criteria, to only choose the best wafers available.

Outstanding R&D

Under Dr. Zhao’s leadership, our R&D team has consistently improved its R&D capability and maintains as a leader in the industry.

Industrial Application

Compared with laboratory research achievements, industrial application is valued more in CSUN. So we devote ourselves on work flow optimization to minimize the power loss of every link during production.

Product is the Heart and

Soul of CSUN

Cells

Module

Future

As an early player in the PV industry, CSUN have devoted itself to high efficiency cells include HP, SE, and N type.

In 2010, CSUN have moved into modules and expand into end user’s market. This is to satisfy the demand of our target customers.

CSUN is changing with the market, with the change we can provide more to our customer.

Capacity Roadmap

980MW

1.2 GW

480MW

170MW

10MW

2007

30MW

2008 2009 2010

PV module

2011 2012

1GW

600MW

320MW

400MW

32MW

2005

192MW

2006 & 2007 2008 & 2009

2010

PV cell

2011 2012

Certification

S O L A R

China Sunergy (Nanjing) Co., Ltd.

(NASDAQ: CSUN)

No. 123, West Focheng Road, Jiangning, 211100 Nanjing, China

Tel: +86-25-5276 6681/6682/6684 Fax: +86-25-5276 6767

E-mail: [email protected]

[email protected]

www.chinasunergy.com

China Sunergy Europe GmbH

Sonnenstraße2, 80331 Munich, Germany

Tel: +49-89-5432 4970 Fax: +49-89-5329 7816

E-mail: [email protected]

China Sunergy (France) Co., Ltd.

Zone d'Activités des Travails, 17 Chemin des Travails - Entrée B,

06800 Cagnes Sur Mer, France

Tél: +33 489 74 03 47 Fax: +33 492 02 84 69

China Sunergy (US) Clean Tech Inc.

575 Market Street, Suite 3750, San Francisco, CA, 94105

Tel: +1-(415)229-7994 Fax: +1-415-229-7999

Email: [email protected]

CEEG (Nanjing) Renewable Energy Co., Ltd.

No.6, Shuige Road, Jiangning, 211100 Nanjing, China

Tel: +86-25-8713 8200

CEEG (Shanghai) Solar Science Technology Co., Ltd.

3G, Hongqiao Business Center, No.2272 Hongqiao Rd, 200336 Shanghai, China

Tel: +86-21-6237 6999

No.68, West Gangde Road, Songjiang, 201616 Shanghai, China (Factory)

Tel: +86-21-5785 0711

Case Study

OR

BOTH.

CSUN gives the answer with 33,302 pieces of high efficiency solar modules, which makes South

Nanjing Railway Station Rooftop the world’s largest

BAPV project of 10.67MW.

Chasing the sun around the world, CSUN explores every possibility.

Module type:

System size:

CSUN200-72M&CSUN250-60M

10.67MW

Date Completed:

Apr. 2011

Il Parco di Malalbergo

Module Type:

System Type:

System Size:

Location:

CSUN235/240-60P

Ground-mounted

11.3MW

Terontola, Italy

Date of Grid-connected:

May 27th, 2011

Victoria State, Australia

Module Type:

System Type:

System Size:

CSUN170W-72M

Rooftop

1.5KW per home

Total Capacity:

6MW, 4000 Homes

Date Completed:

Oct. 2009

Module Type:

System Type:

System Size:

CSUN185-72M-B

Rooftop

4 to 100KW each

Date Completed:

Oct. 2009

Friedland, Germany

Module Type:

System Size:

280 kW

System Type:

CSUN190-72M

Rooftop

Date Completed:

Jul. 2010

Sieversdorf, Germany

Module Type:

System Size:

666 kW

System Type:

CSUN185-72M

Rooftop

Date Completed:

Apr. 2009

Module Type:

System Size:

System Type:

CSUN185-72M

666 kW

Rooftop

Date Completed:

Apr. 2009

Dien du Temple Village, France

Module type:

System size:

CSUN 290-72M

1.03 MW

Date completed:

Jul. 2010

Czech Republic

Module Type:

System Type:

System Size:

CSUN240-60M

Ground-Mounted

4.3MW

Date Completed:

Dec. 2009 one of the biggest PV projects in the Czech Republic

Valchedram, Bulgaria

Module Type:

System Size:

1.9MW

System Type:

CSUN235/240-60P

Ground-mounted

Date Completed:

Jul. 2011

Novel Technology: Which from very initial stage to achieve excellent crystal purity and conformity, combine with CSUN leading technologies, as result of high- efficiency PSAR products.

High Profitability and Payback: More power contributed from each single panel, more system cost might be saved, and better payback we convinced .

System Cost Reduce Significantly:

Less panels, less initial installation cost; Less panels, less Maintenance cost during life cycle.

Description:

improves light response effectively and result in higher conversion efficiency at low cost of ownership.

Combined with the high quality wafer, new technology updated from conventional production process narrows the distribution of conversion efficiency and brings more advantages to the quality control.

In addition, PSAR technology adapts other new technology developed by CSUN’s R&D center to improve conversion efficiency continuously.

Features:

Extended module power range up to 260w (60pc layout).

Centralized power distribution.

Lower Light Induced Degradation (LID) means stable power output and better system yield after long-term operation.

Carefully selected subsidiary material allows maximum light permeability and impact-resistance.

Low power tolerance of ±3%;

Guarantee

*

Product workmanship: 10 years

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Certificates

Intertek

Test Standard

IEC61215 IEC61730

UL1703

Power Range

240W-260W

240W-275W is the trade mark owned by CSUN. It’s the brand name of polycrystalline solar module produced by CSUN.

Specifications of CSUN 250-60P PSAR module

Module name

Module type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating[A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

PSAR 260

CSUN 260 -60P

260

38.0

9.01

30.6

8.50

17.8%

16.02%

1000

PSAR 255

CSUN 255 -60P

PSAR 250

CSUN 250 -60P

Electrical typical data

255

250

37.9

37.7

8.92

8.83

30.4

8.39

30.2

8.28

17.46%

15.71%

17.12%

15.40%

-0.37%/K

+0.06%/K

-0.5%/K

20

PSAR 245

CSUN 245 -60P

245

37.5

8.75

30

8.17

16.78%

15.09%

6×10 pieces polycrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1640×990×40mm (L×W×H)

5,400 Pa maximum diameter of 25 mm with impact speed of 23 m·s

– 40 °C to + 85 °C

19.1kg

PSAR 240

CSUN 240 -60P

240

37.3

8.64

29.8

8.06

16.44%

14.78%

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: ± 3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%. certified in accordance with IEC 61215, IEC 61730-1/2and UL 1703.

Operating Condition & Packaging

Temperature range

Dimensions(L×W×H)

1640×990×40mm

IV Curve maximum dia

(51.2mph)

– 40 °C to + 85 °C

Container 20’

300

Container20’HC

324

Container40’

700

Container40’HC

756

8

6

4

2

800W/m 2

600W/m 2

400W/m 2

200W/m

2

0

0 10

Dimensions

20

Voltage/V

30

25 o C

250

200

150

40

0

100

50

8

6

4

2

0 o C o

25

50

C

75

C

C

0

0 10 20

Voltage/V

30

AM 1.5,1000W/m 2

250

100

50

0

200

150

40

10x10(0.39x0.39)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Junction box

B

10(0.39)

A-A

Φ 6(0.24)

Ground holes

2 places

35(1.38)

B

9(0.35)

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW is the trade mark owned by CSUN. It’s the brand name of polycrystalline solar module produced by CSUN.

QSAR

260

SERIES

CSUN255-60M

CSUN260-60M

CSUN265-60M

CSUN270-60M

19

%

Average Cell Efficiency

QSAR solar cell improves solar light response by restricting the recombination of light-induced holes and electrons, based on a novel fully emitter passivation technology, to obtain a single side PN at low temperature.

QSAR technology can deliver you much higher conversion efficiency, in a more simplified process. We successfully cut the production links and narrow the distribution of efficiency performance, to achieve better quality control.

In addition, QSAR technology is easy to combine with other technologies developed by CSUN to improve efficiency further.

Features

Higher power output than conventional solar modules;

Narrow distribution of conversion efficiency;

Concentrated current distribution performance;

Less mismatch;

Simplified process and better quality control.

Guarantee

*

Product workmanship: 10 years

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Certificates

Certification Authority

TÜV Rheinland

Intertek

Test Standard

IEC61215 IEC61730

UL1703

Power Range

255W-270W

255W-275W

is the trade mark owned by CSUN, also the brand name of high efficiency solar module produced by

CSUN. From March 2012, CSUN will change “QUASAR” originally used into “QSAR”.

Specifications

Module name

Module type

Peak Power (Pmpp)

Open Circuit Voltage (Voc)

Short Circuit Current (Isc)

Optimum operating Voltage (Vmpp)

Optimum operating Current (Impp)

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating[A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Weight

QSAR 270

CSUN 270-60M

270

38.3

9.07

31.2

8.65

16.63%

1000

QSAR 265

CSUN 265-60M

265

38.2

8.98

31.0

8.55

16.32%

QSAR 260

CSUN 260-60M

260

38.1

8.90

30.8

8.44

16.02%

-0.307%/K

+0.039%/K

-0.423%/K

20

6×10 pieces monocrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1640×990×40mm [64.57×38.98×1.57inch] (L×W×H)

19.1kg (42.1lbs)

QSAR 255

CSUN 255-60M

255

38.0

8.82

30.7

8.30

15.71%

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: 0~±3%; Performance deviation of Voc, Isc, Vmp and Imp: ± 10%.

Certified in accordance with IEC61215, IEC61730-1/2 and UL1703.

Packaging

Dimensions(L×W×H)

1640×990×40mm

Container 20’

300

Container20’HC

324

Container40’

700

Container40’HC

756

IV Curve

10

8

6

4

2

0

0

600w/m 2

10 20

Voltage[V]

Dimensions

30

25 o

C

250

200

150

40

0

100

50

10

8

6

4

2

0

0

70 o

C

55 o C

40 o

C

25 o C

10 o

C

10 20

Voltage[V]

30

50

40

0

150

100

300

250

200

Note:mm(inch)

10x10(0.39x0.39)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Junction box

10(0.39)

A-A

Φ 6(0.24)

Ground holes

2 places

35(1.38)

B

9(0.35)

B

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

is the trade mark owned by CSUN, also the brand name of high efficiency solar module produced by

CSUN. From March 2012, CSUN will change “QUASAR” originally used into “QSAR”.

CSUN 195-48P

Highest Module Efficiency: 14.92%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

48 High-Efficiency Polycrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

MCS

CGC

Test Standard

IEC61215 IEC61730

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

175W-205W

175W-205W

190W-230W

S O L A R

*

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

** Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

195-48P

195

29.6

8.67

23.8

8.19

16.69%

14.92%

190-48P

Electrical typical data

190

29.5

8.61

23.7

8.02

16.27%

14.54%

185-48P

185

29.4

8.57

23.6

7.84

15.84%

14.16%

180-48P

180

29.2

8.43

23.4

7.70

15.41%

13.77%

175-48P

175

29.0

8.26

23.2

7.55

14.98%

13.39%

1000

-0.292%/K

+0.045%/K

-0.408%/K

20

6×8 pieces polycrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate)

Composite film

Anodized aluminum profile

1320×990×35mm(L×W×H)

5400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm(1inch) with impact speed of 23 m/s (51.2mph)

– 40 °C to + 85 °C

Dimensions(L×W×H)

1320×990×35mm

IV-Curves

Container 20’

448

Container20’HC

480

Container40’

946

Container40’HC

1014

Dimensions

Note:mm(inch)

8×8 (0.31×0.31)

Drainage holes

4 places

14×9 (0.55×0.35)

Mounting slots

8 places

Φ6(0.24)

Ground holes

2 places

Junctionbox

B

A-A

10(0.39)

35(1.38)

B

9(0.35)

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 200-48M

Highest Module Efficiency: 15.69%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

48 High-Efficiency Monocrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

MCS

CGC

Test Standard

IEC61215 IEC61730

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

175W-215W

175W-215W

190W-230W

S O L A R

*

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

** Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating[A]

Front glass

Cells

Junction box

Cable

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

205-48M

24.2

8.47

200-48M

24.1

8.30

195-48M

205

30.0

8.86

Electrical typical data

200

195

29.9

8.78

29.7

8.71

23.9

8.16

17.87%

15.69%

1000

-0.307%/K

+0.039%/K

17.44%

15.31%

17.00%

14.92%

190-48M

190

29.6

8.59

23.8

7.99

16.57%

14.54%

185-48M

185

29.4

8.50

23.7

7.81

16.13%

14.16%

-0.423%/K

20

White toughened safety glass, 3.2 mm

6×8 pieces monocrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

EVA (Ethylene-Vinyl-Acetate)

Composite film

Anodized aluminum profile

1320×990×35mm [51.97x38.98x1.38inch] (L×W×H)

5400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm with impact speed of 23m/s (51.2mph)

– 40 °C to + 85 °C

Dimensions(L×W×H)

1320×990×35mm

IV-Curves

Container 20’

448

Container20’HC

480

Container40’

946

Container40’HC

1014

Dimensions

Note:mm(inch)

8×8 (0.31×0.31)

Drainage holes

4 places

14×9 (0.55×0.35)

Mounting slots

8 places

Ф 6(0.24)

Ground holes

2 places

Junction box

B

A -A

10(0.39)

35(1.38)

B

9(0.35)

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 200-72M

Highest Module Efficiency: 16.06%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

72 High-Efficiency Monocrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

TÜV InterCert

UL

Intertek

CEC

FSEC

MCS

CGC

Test Standard

IEC61215 IEC61730

IEC61215 IEC61730

UL1703

UL1703

IEC61215 UL1703

IEC61215 UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

170W-200W

160W-200W

170W-195W

170W-210W

160W-190W

160W-195W

170W-200W

170W-200W

S O L A R

*

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

**

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

205-72M

205

45.6

5.82

38.0

5.40

18.39%

16.06%

200-72M

Electrical typical data

200

45.3

5.72

37.6

5.32

17.94%

15.67%

195-72M

195

45.1

5.63

37.0

5.28

17.49%

15.27%

190-72M

190

45.0

5.56

36.5

5.21

17.05%

14.88%

185-72M

185

44.8

5.48

35.8

5.17

16.60%

14.49%

1000

-0.307%/K

+0.039%/K

-0.423%/K

10

6×12 pieces monocrystalline solar cells series strings (125mm×125mm) with 3 bypass diodes length 900 mm, 1×4 mm 2

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1580×808×35mm (L×W×H)

5400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1580×808×35mm

IV-Curves

Container 20’

384 tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm with impact speed of 23 m/s (51.2mph)

– 40 °C to + 85 °C

Container20’HC

408

Container40’

896

Container40’HC

952

Dimensions

Note:mm(inch)

8x8(0.31x0.31)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Φ6(0.24)

Ground holes

2 places

Junction box

B

A-A

10(0.39)

A A

35(1.38)

B

9(0.35)

808(31.8)

FRONT VIEW

758(29.83)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 215-54P

Highest Module Efficiency: 14.67%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

54 High-Efficiency Polycrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

Intertek

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

190W-230W

180W-215W

190W-230W

210W-255W

S O L A R

*

**

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

215-54P

215

33.3

210-54P

Electrical typical data

210

33.2

8.62

26.6

8.08

16.36%

14.67%

8.54

26.5

7.93

15.98%

14.33%

205-54P

205

33.0

8.45

26.4

7.77

15.60%

13.99%

200-54P

200

32.8

8.36

26.2

7.64

15.22%

13.65%

195-54P

195

32.6

8.23

26.0

7.50

14.84%

13.31%

1000

-0.292%/K

+0.045%/K

-0.408%/K

20

6×9 pieces polycrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1480×990×40mm (L×W×H)

5400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

17.6kg

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A], Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1480×990×40mm tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm(1inch) with impact speed of 23 m/s (51.2mph)

– 40 °C to + 85 °C

Container 20’

350

Container20’HC

378

Container40’

750

Container40’HC

810

IV-Curves

Dimensions

Note:mm(inch)

10x10(0.39x0.39)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Φ6(0.24)

Ground holes

2 places

Junction box

B

A-A

10.8(0.39)

B

9(0.35)

A

A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 225-54M

Highest Module Efficiency: 15.36%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

54 High-Efficiency Monocrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

Intertek

CEC

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

IEC61215 UL1730

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

190W-245W

190W-245W

190W-245W

190W-245W

210W-255W

S O L A R

*

**

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Front glass

Cells

Junction box

Cable

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

230-54M

230

33.7

8.90

27.3

8.42

17.82%

15.70%

225-54M

Electrical typical data

225

33.6

8.84

27.1

8.30

17.44%

15.36%

220-54M

220

33.5

8.75

27.0

8.15

17.05%

15.02%

215-54M

215

33.4

8.62

26.9

7.99

16.67%

14.67%

210-54M

210

33.3

8.52

26.7

7.83

16.28%

14.33%

-0.307 %/K

+0.039%/K

-0.423%/K

20

White toughened safety glass, 3.2 mm

6×9pieces monocrystalline solar cells series strings

(156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1480×990×40mm(L×W×H)

5400Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

17.6kg

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm(1inch) with impact speed of 23 m/s (51.2mph)

– 40 °C to + 85 °C

Dimensions(L×W×H)

1480×990×40mm

IV-Curves

Container 20’

350

Container20’HC

378

Container40’

750

Container40’HC

810

Dimensions

Note:mm(inch)

Junction box

10×10 (0.39×0.39)

Drainage holes

4 places

14×9 (0.55×0.35)

Mounting slots

8 places

Φ 6(0.24)

Ground holes

2 places

B

A-A

10(0.39)

35(1.38)

9(0.35)

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 245-60P

Highest Module Efficiency: 15.40%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

60 High-Efficiency Polycrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

Intertek

CEC

FSEC

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

IEC61215 UL1703

IEC61215 UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

210W-255W

200W-240W

220W-240W

200W-240W

210W-255W

255W-305W

S O L A R

*

**

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

250-60P

250

37.3

8.81

29.9

8.36

17.12%

15.40%

245-60P

Electrical typical data

245

37.1

8.74

29.7

8.25

16.78%

15.09%

240-60P

240

36.9

8.67

29.6

8.11

16.44%

14.78%

235-60P

235

36.8

8.59

29.5

7.97

16.10%

14.47%

230-60P

230

36.7

8.52

29.4

7.83

15.75%

14.17%

1000

-0.292%/K

+0.045%/K

-0.408%/K

20

6×10 pieces polycrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1640×990×40mm (L×W×H)

5,400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

19.1kg

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1640×990×40mm tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm(1inch) with impact speed of 23 m/s (51.2mph)

– 40 °C to + 85 °C

Container 20’

300

Container20’HC

324

Container40’

700

Container40’HC

756

IV-Curves

Dimensions

Note:mm(inch)

10x10(0.39x0.39)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Φ 6(0.24)

Ground holes

2 places

Junction box

B

A-A

10(0.39)

A

A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

35(1.38)

B

9(0.35)

CSUN 250 -60M

Highest Module Efficiency: 16.02%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

60 High-Efficiency Monocrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

Intertek

CEC

FSEC

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

IEC61215 UL1703

IEC61215 UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

210W-270W

210W-270W

210W-270W

210W-270W

210W-270W

255W-305W

S O L A R

*

**

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating[A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

250-60M 245-60M

Electrical typical data

240-60M 235-60M

250

37.3

8.78

30.1

8.31

17.44%

245

37.2

8.69

30.0

240

37.0

8.62

29.8

240

37.0

8.62

29.8

8.17

17.09%

15.09%

8.06

16.74%

14.78%

8.06

16.39%

14.47% 15.40%

1000

-0.307%/K

+0.039%/K

-0.423%/K

20

6×10 pieces monocrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2 white toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1640×990×40mm(L×W×H)

5,400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

19.1kg

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1640×990×40mm

Container 20’

300 tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm with impact speed of 23m/s (51.2mph)

– 40 °C to + 85 °C

Container20’HC

324

Container40’

700

Container40’HC

756

IV-Curves

Dimensions

Note:mm(inch)

10x10(0.39x0.39)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Junction box

A-A

10(0.39)

35(1.38)

Φ 6(0.24)

Ground holes

2 places

9(0.35)

B

A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

CSUN 290-72P

Highest Module Efficiency: 15.24%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

72 High-Efficiency Polycrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

UL

Intertek

CEC

FSEC

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

UL1703

IEC61215 UL1703

IEC61215 UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

255W-305W

245W-285W

240W-290W

275W-290W

240W-290W

255W-305W

255W-305W

S O L A R

*

**

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating[A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

295-72P 290-72P

Electrical typical data

285-72P 280-72P 275-72P

295

44.4

8.83

35.7

8.26

16.84%

15.24%

1000

-0.292%/K

290

44.3

8.75

35.6

8.15

16.55%

14.98%

285

44.1

8.67

35.4

8.05

16.27%

14.72%

280

44.0

8.58

35.3

7.94

15.98%

14.46%

275

43.8

8.48

35.2

7.82

15.70%

14.20%

+0.045%/K

-0.408%/K

20

6×12 pieces polycrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm

2 white toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1956×990×50mm(L×W×H)

5400 Pa maximum diameter of 25 mm with impact speed of 23 m·s

-1

– 40 °C to + 85 °C

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1956×990×50mm tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm with impact speed of 23m/s (51.2mph)

– 40 °C to + 85 °C

Container 20’

200

Container20’HC

215

Container40’

480

Container40’HC

516

IV-Curves

Dimensions

Note:mm(inch)

8x8(0.31x0.31)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Junction box

B

A-A

10.8(0.43)

Φ6(0.24)

Ground holes

2 places

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

35(1.38)

B

9(0.35)

CSUN 300-72M

Highest Module Efficiency: 15.75%

Our standard modules are designed, developed and manufactured for both residential and commercial, rooftop and ground-mounted, as well as on-grid and off-grid photovoltaic projects.

Quality of our products is the reason of CSUN’s life. We select the best raw materials and conduct regular testing to ensure that they can meet our rigorous quality standards. Every module has been tested before delivery to make sure the efficiency tolerance is in a narrow range. Each link is strictly controlled to ensure the benefit of our customers.

Features

72 High-Efficiency Monocrystalline Solar Cells;

Passing mechanical load test of 5400Pa according to IEC 61215(advanced test);

Tested to withstand hails with maximum diameter of 25mm with impact speed of 23m/s;

The high-transparency low-iron tempered glass allows maximum light permeability while enhancing stiffness and impact resistance;

Integrated bypass diodes to protect the solar cell circuit from hot spots during partial shadowing;

Our module technology avoids any problems of water freezing and warping;

Black backsheet or black frame is also available.

Quality and Certificates

10-year limited product warranty;

25-year power output warranty.*

Certifications**:

Certification Authority

TÜV Rheinland

Intertek

CEC

FSEC

MCS

CGC

Test Standard

IEC61215 IEC61730

UL1703

IEC61215 UL1703

IEC61215 UL1703

IEC61215 IEC61730

IEC61215 IEC61730

Power Range

255W-320W

255W-320W

255W-320W

255W-320W

255W-320W

255W-305W

S O L A R

*

12 year at 90% of the minimal rated power output, 20 year at 83%, and 25 year at 80%

** Note: All specifications, warranties, certifications about module of “CSUN” series also apply to that of “SST”.

Specifications

Type

Pmpp [W]

Voc [V]

Isc [A]

Vmpp [V]

Impp [A]

Practical module efficiency

Module efficiency

Maximum system voltage [V]

Voltage temperature coefficient

Current temperature coefficient

Power temperature coefficient

Series fuse rating [A]

Cells

Junction box

Cable

Front glass

Cell encapsulation

Back sheet

Frame

Dimensions

Maximum surface load capacity

Hail

Temperature range

Weight

305-72M

305

44.9

8.87

36.2

8.43

17.73%

15.75%

300-72M

Electrical typical data

300

44.8

8.80

36.1

8.32

17.44%

15.49%

295-72M

295

44.6

8.73

35.9

8.22

17.15%

15.23%

290-72M

290

44.5

8.67

35.8

8.11

16.86%

14.98%

285-72M

285

44.4

8.60

35.7

7.99

16.57%

14.72%

1000

-0.307%/K

+0.039%/K

-0.423%/K

20

6×12 pieces monocrystalline solar cells series strings (156mm×156mm) with 6 bypass diodes length 900 mm, 1×4 mm 2

White toughened safety glass, 3.2 mm

EVA (Ethylene-Vinyl-Acetate) composite film

Anodized aluminum profile

1956×990×50mm (L×W×H)

5,400 Pa maximum diameter of 25 mm with impact speed of 23 m·s -1

– 40 °C to + 85 °C

23.8kg

The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C.

Performance deviation of Pmpp: ±3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: ±10%.

Certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703.

Operating Condition & Packaging

Maximum surface load capacity

Hail

Temperature range

Dimensions(L×W×H)

1956×990×50mm

IV-Curves tested up to 5,400 Pa according to IEC 61215 maximum diameter of 25 mm with impact speed of 23m/s (51.2mph)

– 40 °C to + 85 °C

Container 20’

200

Container20’HC

215

Container40’

480

Container40’HC

516

Dimensions

Note:mm(inch)

8x8(0.31x0.31)

Drainage holes

4 places

14x9(0.55x0.35)

Mounting slots

8 places

Junction box

B

A-A

10.8(0.43)

Φ6(0.24)

Ground holes

2 places

35(1.38)

B

9(0.35)

A A

990(38.96)

FRONT VIEW

940(37)

BACK VIEW

China Sunergy (Nanjing) Co., Ltd.

www.chinasunergy.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
