AT&T Definity 7406D+ User`s guide
AT&T
® Communications
DEFINITY
System Generic 2
and System 85
7406BIS Voice Terminal
User's Guide
NOTICE
While reasonable efforts were made to ensure that the information in this document
was complete and accurate at the time of printing, AT&T can assume no responsibility
for any errors. Changes or corrections to the information contained in this document
may be incorporated into future issues.
TO ORDER COPIES OF THIS DOCUMENT
Contact:
Order:
AT&T Customer Information Center
2855 North Franklin Road
P. O. Box 19901
Indianapolis, IN 46219
1-800-432-6600,
In Canada: 1-800-255-1242
Document No. 555-104-721
Issue 2, April 1990
For more information about AT&T documents, see Business Communications Systems
Publications Catalog (555-000-010).
HEARING AID COMPATIBILITY
This equipment is compatible with the inductively coupled hearing aids prescribed by
the Federal Communication Commission (FCC).
Prepared by
AT&T Technical Publications Department
Denver, CO 80234
©1990 AT&T
All Rights Reserved
Printed in USA
Contents
Your 7406BIS Voice Terminal
1
A Quick Look at the Features
4
How to Use the Features
7
Voice Features
Abbreviated Dialing (AD)
9
9
Automatic Callback
11
Bridging
12
Call Coverage
12
Call Forwarding — Busy/Don’t Answer
13
Call Forwarding — Follow Me
14
Call Park
15
Call Pickup
16
Conference
16
Drop
17
Hold
Intercom (Automatic/Dial)
18
Last Number Dialed
19
Leave Word Calling (LWC)
19
18
Message
20
Mute
21
Priority Calling
21
Select Ring
22
Self-Test
22
Send All Calls
23
Shift
24
Speaker
24
Speakerphone
26
Terminal Busy Indication
27
Transfer
27
Display Features
28
Inspect
28
Message Retrieval
29
Normal
30
Time
30
Tones and Their Meanings
31
Key Words to Know
32
Quick-Reference Lists
34
Your 7406BIS Voice Terminal
The 7406BIS voice terminal is available in two models: one with a display and one
without a display. The display adds some functionality, but both models are designed
so that you can conveniently use the features of the AT&T DEFINITY®
Communications System Generic 2 and System 85.
The 7406BIS voice terminal also offers a high-quality, built-in speakerphone. You can
use the speakerphone for placing and answering calls or for using voice features
without lifting your handset, and for allowing others to participate in your telephone
conversations.
Note: For best sound quality, place your voice terminal flat on your desk or other
working area.
The display-equipped 7406BIS voice terminal is shown and explained on the following
pages. Both models (with display and without display) have the same button layout.
Call appearances/
feature buttons
Select Ring
button
Handset
Display
Shift button
Display-viewing
adjustment
Speaker button
Mute button
Feature button
Message light
Transfer button
Conference button
Hold button
Drop button
Volume control
(under voice
terminal)
Shiftable feature
buttons
Speaker volumecontrol buttons
Dial Pad
Figure 1. 7406BIS Voice Terminal
Starting at the upper left of Figure 1 and continuing clockwise:
Handset
For placing and answering calls. In most cases, you must lift
the handset (go off-hook) before you can use a feature. Also
known as the receiver.
Call appearances/
feature buttons
For handling incoming and outgoing calls (call appearances),
labeled with extension numbers. For accessing features
(feature buttons), labeled with feature names.
Display
For showing information (2-line, 48-character display).
Select Ring
button
For accessing the Select Ring feature.
Shift button
For accessing the top-labeled features on shiftable buttons.
Display-viewing
adjustment
For adjusting the viewing angle of the display.
Speaker button
For accessing the speaker or the built-in speakerphone and
microphone combination. Note: Your voice terminal can be
set for either the Speaker (listen-only) feature or the
Speakerphone (listen and talk) feature. Check with your
System Manager to see how your Speaker button is to be
used.
Mute button
For turning off the microphone of the built-in speakerphone
or the handset so that the caller cannot hear you. Note: If
your voice terminal is set for the Speaker (listen only) feature,
pressing the Mute button will affect only the handset.
Feature button
For accessing a feature, labeled with a feature name and
equipped with a green light.
Transfer button
For transferring a call to another voice terminal.
Hold button
For putting a call on hold.
Shiftable feature
buttons
For accessing each, two features, labeled with feature names;
features on the top of the label are accessed when [ Shift ] is
activated.
Speaker volumecontrol button
For adjusting the volume of the speaker or the built-in
speakerphone.
Dial pad
For dialing the telephone numbers and accessing features
(12-button pad).
Volume control (under
voice terminal)
For adjusting the volume of the tone ringer.
Drop button
For disconnecting from a call or dropping the last party
added to a conference call.
Conference button
For setting up conference calls.
Message light
For indicating when a message has been left for you (steady
green light).
The following optional modules are compatible with the 7406BIS voice terminal:
500A Headset Adapter
Provides a dual-purpose switch that turns on the adapter
connecting the headset to the voice terminal. Pressing the
ON switch is equivalent to going off-hook with the handset,
and pressing the OFF switch is equivalent to going on-hook
with the handset.
7400B Data Module
Provides data capability to the attached DCP voice terminal.
It also provides integrated simultaneous voice data
communications over standard twisted-pair wiring.
C401A or C401B Call
Coverage Module
Provides 20 call appearance/feature buttons to supplement
those on the associated voice terminal. For more information
about using the features assigned to this module, see the
appropriate feature procedures that follow.
D401A Digital Display
Module
Provides visual indication of call-related information, time
and date, elapsed time on calls, messages, and abbreviated
dialing numbers.
S101A and S201A
Speakerphone
Provides total voice terminal operation without using the
handset. Turning on the speakerphone is equivalent to going
off-hook when placing or answering a call and turning off the
speakerphone is equivalent to going on-hook. A mute switch
is provided to temporarily cut off transmission to the distant
caller.
A Quick Look at the Features
Here are brief descriptions of some features, including what each one does and how
you might want to use it. The first features are voice features followed by display
features. You will have the Conference, Drop, Hold, Message, Mute, Select Ring, SelfTest, Shift, and Transfer voice features, and Message Retrieval and Normal display
features. In addition, you may have many of the other features listed here; your
System Manager can advise you.
Voice Features
Abbreviated Dialing (AD) Allows you to store selected telephone numbers as 3 or
fewer digits for quick and easy dialing. Each number can be a complete or partial
telephone number, an extension number, or a trunk or feature code. There are 3
possible types of lists — personal, group, and system — and you can have a total of 3
lists. Numbers on a personal list are programmable by you; numbers on all other lists
are programmable only by the System Manager. Use this feature as a timesaver for
dialing frequently called, lengthy, or emergency numbers. Note: Check with your
System Manager for the types of lists you have and how many of each.
Automatic Callback Sends you a special 3-burst ring tone indicating that a
previously busy extension is now available. Use to avoid constant redialing when you
want to speak to someone who is frequently busy on the telephone. Note: You can
use this feature only for extensions, not outside numbers.
Bridging Permits you to answer or join calls to someone else’s extension by pressing
a bridged appearance button on your voice terminal. This button can be any call
appearance labeled with another user’s primary extension number, as assigned to you
by your System Manager. Use to assist in handling calls for a designated coworker.
Call Coverage Provides automatic redirection of certain calls to your voice terminal
for answering. (Your System Manager determines which calls will be sent to you.)
Use to answer calls for other extensions for whom you provide coverage. Call
Coverage can also automatically redirect your calls when your voice terminal is busy,
you are out of the office, or you have pressed the Send All Calls button.
Call Forwarding — Busy/Don’t Answer
Temporarily forwards all your calls to
another extension or to the attendant if your voice terminal is busy or you do not
answer your calls within a preset number of rings. Use when you want your calls to
be forwarded to a telephone number of your choice.
Call Forwarding — Follow Me Temporarily forwards all your calls to another
extension or to an outside number, depending on your system. Use when you want
your calls to be automatically forwarded to a telephone number of your choice.
Call Park Puts a call on hold at your voice terminal, for retrieval at any extension.
Use when you need to go elsewhere to get information during a call, or whenever you
want to complete a call from a different location. Also, if the call received is for
someone else, use it to hold the call until the called party can answer from the nearest
available voice terminal.
Call Pickup Lets you answer a call at your voice terminal for another extension in
your pickup group. Use when you want to handle a call for a group member who is
absent or otherwise unable to answer. Note: You can use this feature only if you and
the called party have been assigned to the same pickup group by your System
Manager.
Conference Allows you to add a third party to a call, so that you can conduct a 3way conversation. (If you want to conference more than 3 parties, call your attendant
for assistance.) Use to set up time-saving conferences, or to spontaneously include a
third party important to a discussion.
Drop Disconnects from a call without requiring you to hang up the handset or press
the switchhook. Can also be used with the Conference feature to disconnect the last
party added. Use whenever you want to continue using the handset for another action
after ending a call.
Hold Puts a call in a holding state until you can return to it. While a call is on hold,
you can place another call, activate another feature, answer a waiting call, or leave
your voice terminal to do another task. Use when you have a call that you don’t want
to drop, but have to interrupt briefly to do something else.
Intercom (Automatic/Dial) Gives you quick access to specified voice terminals. With
Automatic Intercom, you can call predetermined persons, by pressing a single feature
button. With Dial Intercom, you can call any member of a predetermined group by
pressing a feature button and then dialing the group member’s 2- or 3-digit code.
Last Number Dialed
Automatically redials the last number you dialed, either an
extension or an outside number. Use to save time in redialing a busy or unanswered
number. Available with DEFINITY Generic 2 and System 85 R2V4 and some R2V3
systems. Check with your System Manager to see if the feature is available in your
system.
Leave Word Calling (LWC)
Leaves a message for another extension to call you back.
The called party will be able to dial message center, AUDIX, or a covering user to
retrieve a short, standard message that gives your name and extension, the date and
time you called, and the number of times you called. Use any time you want to have
someone call you back; it will help cut down on repeated call attempts.
Message Retrieval
Lets you know that a caller has left a message for you when the
message light goes on. You can then follow your System Manager’s local message
retrieval procedures to get your message. See the Message Retrieval procedures
under the Display Features heading.
Mute
Allows you to turn off the microphone of the speakerphone or the handset so
that the caller cannot hear you.
Priority Calling Allows you to call another extension with a distinctive 3-burst ring
to indicate that your call requires immediate attention. Use when you have important
or timely information for someone.
Select Ring Allows you to select your own personalized ring from among 8
available ringing patterns. Use to distinguish your ring from that of other nearby
voice terminals.
Self-Test
terminal.
Allows you to test the operation of the lights and ringer of your voice
Send All Calls
Temporarily sends all your calls to the extension of a person
designated to answer them when you cannot (perhaps a secretary or receptionist). Use
when you will be away from your desk for awhile, or when you do not want to be
interrupted by telephone calls.
Shift
Allows you to access the top-labeled features on split-labeled, shiftable buttons,
including Select Ring. Use whenever you need to access one of these features.
Speaker
Allows you to place calls or access other voice features without lifting the
handset. However, in order to speak to the other party, you must lift the handset.
Use with features that require listening only, such as on-hook dialing, monitoring calls,
on hold, and group listening situations. Note: Your voice terminal has either the
Speaker (listen-only) or the Speakerphone function. Check with the System Manager.
Speakerphone
Allows you to place calls or access other voice features without lifting
the handset. Use any time you prefer hands-free communication, both speaking and
listening or for group listening. Note: Your voice terminal may be set for the Speaker
(listen-only) feature. Check with the System Manager.
Terminal Busy Indication Provides a visual indication of the busy (off-hook) or idle
(on-hook) status of a specified voice terminal. Use this information when servicing
calls for another person. For example, if you are a secretary servicing your
supervisor’s calls, use this feature to see whether your supervisor’s extension is busy
or idle.
Transfer
Transfers a call from your voice terminal to another extension or outside
number. Use when your caller needs to speak further with someone else. Note: Calls
from an outside number to your voice terminal can be transferred only to an extension,
not to another outside number.
Display Features
Note: These features can be used only with a 7406D05A voice terminal, the 7406BIS
voice terminal with a display.
Inspect
Shows you call-related information for an incoming call when you are
already active on a call. Use to identify and screen new calls.
Message Retrieval
Allows you to retrieve messages left for you that have lit your
message light. Will also let you retrieve messages for other voice terminals not
equipped with a display (if you are authorized as a systemwide message retriever by
your System Manager). Use to quickly and conveniently check messages, even when
you are already on a call.
Normal
Identifies current call appearance, calling/called party, and calling/called
number. Use to see who is calling you and, when placing a call, to verify the number
you have dialed.
Time
Shows you the date and time, and with the Elapsed Timer button, allows you
to measure elapsed time. Use as a handy calendar and clock, and to keep track of time
spent on a call or task.
How to Use the Features
Many features are available for use with your 7406BIS voice terminal. Because no
organization can use all of the available features, each organization must choose those
that best suit its needs. After the choices have been made, the person within your
organization who manages your telecommunication system must do any necessary
administration and label the feature buttons on individual voice terminals. This
System Manager can tell you how to use the features that have been administer for
your particular voice terminal. The procedures that follow give instructions for using
some of the more frequently used features. Features are listed alphabetically.
Special Instructions
The first time you use these procedures, you will need to customize them for yourself.
Your System Manager can supply the information required.
●
●
To the right of each feature name is a box. For each feature that you have, mark a
[ ✓ ] in the box if the box is blank. Voice features (Conference, Drop, Hold, Message,
Mute, Select Ring, Speakerphone, and Transfer) and display features (Message
Retrieval and Normal) are already marked for you.
To use a voice feature you must have the handset off-hook (that is, you must pick up the
handset or turn on the speakerphone, if you have one) unless you are instructed to remain
on-hook in the procedures. You can activate and cancel most of the voice features by
dialing 2- or 3-digit codes (if they are not already assigned to a button). Write the
feature code numbers in the blanks provided within the procedures. These codes
are unique to your system; see your System Manager for the codes or to obtain more
information.
●
System 85 exists in several versions. In some cases, a feature operates differently
with one version than it does with another; where this occurs, the procedures
include a release (R) and version (V) notation. Be sure to follow the directions
corresponding to the release and version you are using. Ask your System Manager
if you do not know the release and version you have.
Note: You must press [ Shift ] before you use any of the top-labeled features on
shiftable buttons. Also, if you receive an intercept tone (high-pitched, alternating high
and low tone) while attempting to operate any feature, you have taken too much time
to complete a step, have made a dialing error, or do not have the feature available to
you. If appropriate, hang up or press [ Drop ], get dial tone, and begin at the first step.
Conventions
The following conventions are used in the procedures:
Italic procedure steps
Procedural steps in italic type are steps that you should
follow if you do not have a button assigned for the
feature.
[ xxxxx ]
A box representing a call appearance that is used
exclusively for placing, receiving, or holding calls.
[ Feature ] and
[ Feature xxxxx ]
Boxes representing buttons that have features assigned
to them. The buttons are labeled with the feature name,
sometimes followed by an extension number or a
person’s name.
[ DISPLAY INFORMATION ] A box containing fully capitalized words represents
information shown on the display.
[feedback tone]
The tone appearing in brackets after a step indicates
what you hear after successfully performing that step.
For more information, see Tones and Their Meanings and Key Words to Know at the
end of this guide.
Quick-Reference Lists
At the end of this guide is a set of quick-reference lists. Use the lists to record your
feature and trunk codes, Abbreviated Dialing personal list items, and frequently called
miscellaneous extensions. Once you have completed the lists, flip to that page as
needed, or make a photocopy and keep it handy.
Voice Features
Note: When placing and answering calls or using the voice features, you have the
option of doing so by lifting the handset or by pressing the Speaker button. If your
voice terminal is set for the Speakerphone feature, pressing the Speaker button
simultaneously activates the built-in microphone so that you can place and answer calls
without lifting the handset.
Abbreviated Dialing (AD)
Note: If you hear the intercept tone while programming,. start over from the
beginning. Abbreviated Dialing buttons must first be assigned by your System
Manager.
To program or
reprogram an outside
number, extension, or
feature code into a
personal list
1
On a separate sheet of paper, jot down the outside
numbers, extensions, and feature codes you want to
program as items on your personal list (see example)
2
Press [ Program ] (while off-hook)
or dial Abbreviated Dialing program code (while off-hook)
[confirmation tone]
3
Press [ Personal List ]
or dial personal list code
4
Dial desired list item number (for example, 0-9, 01-95,
[dial tone]
and so on, depending on list size)
5
Dial outside number, extension, or feature code you
want to store
6
Press [ Personal
or press [ # ]
●
●
7
[confirmation tone]
Number is stored
Repeat steps 3 through 6 if you want to program
additional items on the same list
Hang up or press [
●
]
List
Drop
] to end programming
If you want to continue programming, begin again at
step 1 to program another personal list
Note: Record your personal list items on the
Abbreviated Dialing list in the back of this guide; group
and system lists are available from the controller of the
list or from your System Manager.
To place a call using a
personal, group, or
system list
1 Press [ Personal List ] or [ Group List ] or [ System List ] (while off-hook)
or dial appropriate Abbreviated Dialing list code (while offhook)
2
●
Personal
[dial tone]
●
Group
[dial tone]
●
System
[dial tone]
Dial desired list item (1, 2, 3..., 01, 02...)
●
To program an
Abbreviated Dialing
(AD) button
Stored number is automatically dialed
1
Press [ Program ] while off-hook)
or dial the Abbreviated Dialing program code (while off-hook)
[confirmation tone]
2
Press selected [ AD xxxxx ]
3
Dial the outside number, extension, or feature code you
want to store
4
Press [
5
Hang up or press [
AD xxxxx
] again
Drop
[confirmation tone]
] to end programming
To see number stored
on an Abbreviated
Dialing (AD) button
To place a call using an
Abbreviated Dialing
(AD) button
1
Press selected [ AD xxxxx ] while on-hook
●
Stored number is shown
2
Press [ Normal ] to return to normal display or repeat step
1 to see another number
1
Press selected [
●
AD xxxxx
] (while off-hook)
Call is automatically dialed
Automatic Callback
To automatically place
another call to an
extension that is
frequently busy
1
Press [
] before or during call attempt
[dial or confirmation tone]
or dial Automatic Callback code before call attempt
[dial tone]
●
2
If you have an [ Auto Callback ] button, green light goes on
until callback is completed or canceled
Hang up (within 7 seconds) or press [
●
3
Auto Callback
Drop
]
You will receive a 3-burst priority ring when both
your voice terminal and the called extension are idle
Lift handset when you hear priority ring
[ringback tone]
●
A call is automatically placed to called extension,
which receives regular ringing
Note: Only one Automatic Callback call at a time can
be placed, and Automatic Callback is canceled after 20
to 40 minutes if the callback call is unanswered.
To cancel Automatic
Callback
1
Press [ Auto Callback ] again (while off-hook)
or dial Automatic Callback cancel code (while off-hook)
[confirmation tone]
●
Green light goes off
Bridging
To answer a bridged
call
To prevent other
bridged voice terminals
from entering a call (on
a per-call basis)
1
Press [
xxxxx
] of bridged call
Note: If your voice terminal has Ringing Appearance
Preference, this step is not necessary; you will
automatically be connected to the call when you lift the
handset.
2
Pick up handset
1
Press [ Exclusion xxxxx ] while connected to the call
Note: Pressing [ Exclusion xxxxx ] again reactivates bridging.
Call Coverage
To answer a call for a
coworker for whom
you are a coverage
point
1
To leave a message
telling a coworker to
call the original caller’s
extension
1
To talk privately with a
coworker after
answering a redirected
call
1
Press [ xxxxx ] of incoming call when ring begins or green
light flashes
Note: The call is not at your voice terminal until the
light is flashing.
Press [
Coverage Callback
] while connected to the call
[confirmation tone]
Note: To leave a message telling a coworker to call you,
activate Leave Word Calling instead.
Press [
●
2
Transfer
] or [
Conference
]
[dial tone]
Call is temporarily put on hold
[priority ring to coworker]
Press [ C o n s u l t ]
or dial coworker’s extension
[single-burst ring to coworker]
Note: You can privately discuss call; if coworker is not
available, press the fluttering [ xxxxx ] to reconnect to call.
If your coworker has activated Send All Calls, you must
use [ Consult ] to reach your coworker.
3 Press [ Transfer ] again to send call to coworker or press
[ Conference ] to make it a 3-party call
Call Forwarding — Busy/Don't Answer
To activate Call
Forwarding —
Busy/Don’t Answer
1
Press [ Call Forward ] (while off-hook)
or dial Call Forwarding — Busy/Don’t Answer code
[dial tone]
(while off-hook)
Note: To find out
which type of Call
Forwarding [ Call Forward ]
activates, contact your
System Manager.
2
Dial extension where calls will be sent
[confirmation tone]
Note: If you hear intercept tone, you are attempting to
forward your calls to a restricted telephone, a telephone
with Call Forwarding — Follow Me activated, or a
telephone in another partition or group (if you are in a
tenant services environment). See your System
Manager for more information.
3
Hang up or press [
Drop
]
To cancel Call
Forwarding —
Busy/Don’t Answer
1
Press [ Call Forward ] again (while off-hook)
or dial Call Forward cancel code (while off-hook)
[confirmation tone]
2
Hang up
●
Your calls will ring at your own voice terminal again
Call Forwarding — Follow Me
To temporarily redirect
all calls to an extension
or outside number of
your choice
1
Press [ Call Forward ] (while off-hook)
or dial Call Forwarding — Follow Me code (while off-hook)
[dial tone]
2
Dial extension or number where calls will be sent
[confirmation tone]
Note: To find out
which type of Call
Forwarding [ Call Forward ]
activates, contact your
System Manager.
To cancel Call
Forwarding — Follow
Me
Note: You may hear a half ring for each call forwarded
after you have activated this feature and hung up.
Also, some voice terminals may have restrictions on
where calls can be forwarded (only on DEFINITY
Generic 2 and System 85 R2V4 and later releases); see
your System Manager.
1
Press [ Call Forward ] again (while off-hook)
or dial Call Forward cancel code (while off-hook)
[confirmation tone]
2 Hang up
●
Your calls will ring at your own voice terminal again
Call Park
To park a call (for
retrieval at any
extension)
1
Press [
●
2
Transfer
[dial tone
]
Second party is temporarily put on hold
Press [ Call Park ]
or dial Call Park trunk code
[dial tone
[confirmation tone
3
Dial the Call Park zone number
4
Dial an idle answer-back channel number
[confirmation tone
5
Press [
Recall
6
Press [
Transfer
7
Hang up
●
]
]
[ringback tone
Held party is transferred to the answer-back channel
and hears ringback tone (or music) while waiting
To retrieve parked call
from any extension
1 Dial Call Park answer-back code
[dial tone]
2 Dial channel number where call was parked
[confirmation tone]
Note: If you receive intercept tone, parked call has
been disconnected or retrieved by another party.
Call Pickup
To answer a call to a
member of your pickup
group when your voice
terminal is idle
1 Press [ Call Pickup ] (while off-hook)
or dial Call Pickup code (while off-hook)
To answer a call to
your pickup group
while on another call
1 Press [
●
You are connected to ringing call
Hold
]
l Present call put on hold
2 Press an idle call appearance
3
[dial tone]
Press [ Call Pickup ]
or dial Call Pickup code
●
●
Called voice terminal stops ringing
You are connected to ringing call
Note: To return to held call after completing present
call, press fluttering [ xxxxx ].
✓
Conference
To add a third party to
a call
1 Press [
]
[dial tone]
Present call temporarily put on hold and you are
given a new call appearance
●
2
Conference
Dial number of third party and wait for answer
Note: You can privately discuss the call with the third
party at this time; if no answer or busy, press fluttering
[ xxxxx ] to return to the original party.
3
Press [
●
To add a call you’ve
put on hold to another
call you’re connected to
All parties now connected
1
Press [
2
Press [
xxxxx
3
Press [
Conference
●
] again
Conference
Conference
]
] of first call
] again
All parties now connected
[dial tone]
To drop a third party
1 Press [
●
Drop
]
You remain connected to original party
✓
Drop
To disconnect from a
normal call, or to drop
the last party added to
a conference call
1 Press [
Drop
]
Hold
To keep a call waiting
while you answer
another call, make a
call, or perform some
other task
1
To answer a new call
while active on another
1
Press [
●
]
Green light flutters
Note: If you put a conference call on hold, the other
parties remain connected.
Press [
●
2
1
]
xxxxx
] of incoming call
You are connected to incoming call
Press [
●
Hold
Green light flutters
Press [
●
To return to a held call
Hold
xxxxx
] of held call
You are connected to held call
Note: If you are active on a call and you press the
[ xxxxx ] of the held call, the active call will be dropped.
Intercom (Automatic/Dial)
[ringback tone]
To make a call to your
predetermined
Automatic Intercom
partner
1
To dial a call to a
member of your Dial
Intercom group
1
Press [
2
Dial group member’s 1- or 2-digit code [ringback tone]
Press [ Icom Auto xxx ] (while off-hook)
●
●
To answer any
intercom call
1
Intercom ring is sent
Icom Dial xxx
] (while on-hook)
Intercom ring is sent
Pick up handset and press [
●
[dial tone]
Icom
]
You are connected to call
Note: If you are active on another call, first press
[ Hold ], then press flashing [ Icom ].
Last Number Dialed
To automatically redial
the last number you
dialed (extension,
outside number, or
trunk/feature code)
1
Press [ Last Dialed ] (while off-hook)
or dial Lust Number Dialed code (while off-hook)
●
Number is automatically dialed (up to 20 digits)
Note: Available with DEFINITY Generic 2 and System
85 R2V4 and some R2V3 systems. Check with your
System Manager to learn if the feature is available on
your system.
Limitations on this feature should be noted. Digits
dialed via Abbreviated Dialing, feature dial codes,
authorization codes, and Station Message Detail
Recording (SMDR) account codes are NOT retained in
memory and must be redialed for each call.
To see the number you
last dialed (you must
have a voice terminal
with a display and you
must be on-hook)
1
Press [ Last Dialed ] (while on-hook)
or dial Last Number Dialed code (while on-hook)
●
Last number dialed is shown
Leave Word Calling (LWC)
To leave a message
after dialing an
extension (when call is
not answered, or you
hear a coverage or
busy tone)
Note: You must have a
[ LWC ] button.
To leave a message
without ringing an
extension
1 Press [
●
LWC
] any time after you complete dialing
[confirmation tone
Message light on called voice terminal goes on (if so
equipped)
Note: If reorder tone is heard, message is not stored;
try again.
1 Press [ LWC ]
or dial Leave Word Calling code
2 Dial extension
●
[dial tone
[confirmation tone]
Message light on called voice terminal goes on (if so
equipped)
3 Hang up or press [
Drop
]
To cancel a Leave
Word Calling message
(you cannot cancel
messages for an
AUDIX subscriber)
1
Press [ Cancel LWC ] (while off-hook)
or dial Leave Word Calling cancel code (while off-hook)
[dial tone]
2
Dial extension
●
[confirmation tone]
Message is deleted
Note: If reorder tone is heard, message is not deleted;
try again.
✓
Message
To retrieve a message
when your message
light is on
1
See the Message Retrieval procedures under the
Display Features heading
or
Ask your System Manager for local retrieval methods
✓
Mute
Note: Use the Mute button in one of the following ways.
●
●
If your voice terminal has the Speakerphone feature, use the Mute button to turn off
the microphone associated with the built-in speakerphone or the handset.
If your voice terminal has the Speaker (listen-only) feature, the Mute button turns off
only the handset.
This feature has no effect on an external speakerphone.
To prevent other party
from hearing you
1
Press [
●
2
Mute
]
Red light goes on and other party cannot hear you
When you are ready to resume conversation with other
party, press [ Mute ] again
●
Red light goes off and other party can hear you again
Note: The Mute feature turns off automatically when
you hang up, or switch from the speakerphone to the
handset or from the handset to the speakerphone.
Priority Calling
To place a priority call
(3-burst ring)
To change a regular
call into a priority call
(3-burst ring) when you
hear a call-waiting
ringback tone
1
Press [ Priority ] (while off-hook)
or dial Priority Calling code (while off-hook)
[dial tone]
2
Dial extension
1
Press [ Priority ]
●
2
Called party receives a priority call-waiting tone
(3-burst ring)
Wait for called party to answer
Note: If you still receive a call-waiting ringback tone,
wait a few minutes and try again.
✓
Select Ring
To select a personalized
ring
1
Press [
●
2
Shift
] (while on-hook)
Green light goes on
Press [
Select Ring
]
●
Green light flashes; current ring pattern plays and
repeats every 4 seconds
●
Display shows [ PERSONAL RING #x ] (x is a number
from 1 to 8)
3 Adjust ringer volume with control on left underside of
voice terminal, if desired
4
Repeat step 2 to cycle through all 8 ring patterns
5 Press [ Shift ] again when you hear the desired ring
pattern
●
Your new ring is set; green light goes off
Note: If you receive a call, go off-hook, or lose power
during selection, process is interrupted and you must
begin again. If you lose power after selection, you will
have to select your ring pattern again.
✓
Self-Test
To test lights and
ringer of your voice
terminal
1
Press [
●
2
3
Shift
]
Green light goes on
Press and hold [
Drop
]
●
Ringer sounds
●
All columns of lights next to buttons above and to
right of dial pad go on
●
Display is activated
Release [
●
Drop
] to end test
Ringer and lights return to pretest state
Note: If ringer or lights do not respond during test,
notify your System Manager.
Send All Calls
To send all incoming
calls (except priority,
intercom, and personal
central office calls)
immediately to an
assigned extension,
AUDIX, or message
center for coverage
1
To send an assigned
group of extensions
(except priority,
intercom, and personal
central office calls)
immediately to an
assigned extension,
AUDIX, or message
center for coverage
1
Press [ Send All Calls ] (while on-hook or off-hook)
or lift handset and dial Send All Calls code
[confirmation tone]
Note: You may hear a half ring as each call is sent to
coverage if you have a DEFINITY Generic 2 or System
85 R2V4.
Press [
SAC Group
] (while on-hook or off-hook)
[confirmation tone]
To cancel Send All
Calls or SAC Group
1
Press [ Send All Calls ] or [ SAC Group ] again (while on-hook or offhook)
or lift handset and dial Send All Calls cancel code
[confirmation tone
●
Your calls ring at your own voice terminal again
✓
Shift
To use the Shift feature
1 Press [ Shift ] to access any of the top-labeled features on
buttons with split labels
●
2
Green light goes on
Press the split-labeled button whose top feature you
want to use
Note: When you press a feature button, the green light
for [ Shift ] automatically goes off; begin again at step 1
to use another top-labeled feature.
Speaker
Note: Your voice terminal is set for either the Speaker (listen-only) or the
Speakerphone (listen and talk) function. Check with your System Manager to see
which of these two features you can use.
Use the following procedures if your voice terminal is set for the Speaker (listen only)
feature.
To place a call without
lifting the handset, or
to use speaker with
any feature activity
(such as monitoring a
call on which you have
been put on hold, or
for group listening)
Note: In order for the
other party to hear
you, you must speak
through the handset.
1
Press [ Speaker ]
2
Place call, or access selected feature
3
Adjust speaker volume if necessary
●
To raise the volume, press the right half of the
Speaker Volume control button labeled [ ▲ ]; to
lower the volume, press the left half of the Speaker
volume control button labeled [ ▼ ]
●
If you have a display, it shows
[ SPEAKER L >>>> H ] (there are 8 possible volume
settings)
To mute the
microphone associated
with the handset so the
other party cannot hear
you
1
Press [ Mute ]
●
2
Red light goes on and other party cannot hear you
Press [ Mute ] again to resume talking to other party
through handset
●
Red light goes off and other party can hear you again
To change from
speaker to handset
1
Lift handset and talk
To change from
handset to speaker
1
Hang up handset
2
Press [
Speaker
]
To activate the speaker
while on the handset
1 Press [ Speaker ]
To turn off speaker and
return to handset only
1
To end a call if only the
speaker is active
(handset on-hook)
1
Press [ Speaker ]
To end a call if both the
handset and speaker
are active
1
Hang up handset
●
The handset will remain active, and the speaker will
also be active. This allows group listening, although
you can still only talk through the handset. Do not
hang up the handset or the call will be dropped
Press [ Speaker ]
●
●
The speaker turns off (handset remains active)
The speaker turns off automatically
Speakerphone
Note: If you are uncertain whether your voice terminal is set for Speaker (listen only)
or Speakerphone (listen and talk), check with your System Manager.
Use the following procedures if your voice terminal is set for Speakerphone (listen and
talk).
To place/answer a call
without lifting the
handset, or to use
speakerphone with any
feature
1
Press [
●
Speaker
]
Green light goes on next to [
Speaker
]
2
Place or answer call, or access selected feature
3
Adjust volume if necessary
●
To raise the volume, press the right half of the
Volume-control button labeled [ ▲ ]; to lower the
volume, press the left half of the Volume-control
button labeled [ ▼ ]
●
Display shows [ SPEAKER L >>>> H ]
(there are 8 possible volume settings)
Note: The Volume-control button does not affect an
external speakerphone.
4
Press [
●
Speaker
] again to hang up
Green light goes off
To prevent other party
from hearing you
Note: The Mute
feature can also turn
off the microphone
associated with the
handset.
1
Press [
●
2
To change from
speakerphone to
handset
1
To change from
handset to
speakerphone
1
Mute
] again to resume talking to party
Red light goes off and other party can hear you again
Lift handset and talk
●
Green light next to [
Press [
●
2
]
Red light goes on and party cannot hear you
Press [
●
Mute
Speaker
Speaker
] goes off
]
Green lights go on next to [
Hang up handset
Speaker
]
Terminal Busy Indication
To see if the specified
voice terminal is busy
or idle
1
Look at the Terminal Busy Indication status light
●
The light will be on if the terminal is busy and off if
the terminal is idle
✓
Transfer
To send present call to
another extension or
outside number
1
Press [
●
2
Present call put on hold and you are given a new call
appearance
Remain on the line and announce call if desired; if no
answer or number dialed is busy, return to held call
by pressing its call appearance
Press [
●
4
[dial tone]
]
Dial extension or number to which the call is to be
[ringback tone]
transferred
●
3
Transfer
Transfer
] again
Call is sent to dialed extension or number
Hang up or press [
Drop
]
Display Features
On/Off
The display is on when the voice terminal is on and off when the voice terminal is off.
Normal Mode
In the normal mode, the display shows call information for the current active call
appearance:
●
You may have as many as 10 call appearances. Beginning with the first button in
the upper left corner of your faceplate and going down, the display identifies the
first 5 buttons as a through e; the 5 buttons in the second column are identified as f
through j. When the display shows [ a = ], it represents call information for the
first call appearance. The next button down would be shown as [ b = ], and so on,
continuing through [ j = ] if all 10 of these buttons are used for call appearances.
●
When you dial an extension, that number is shown and then replaced by the called
party’s name and extension.
●
When a call is received from another extension, the caller’s name is shown (or the
caller’s extension if a name is not administered); when a call is received from
outside, [ OUTSIDE CALL ] or a trunk identifier is shown.
●
The display remains in normal mode until you activate one of the other display
features. After using any of these features, return to normal mode by pressing
[ Normal ].
Inspect
To see who’s calling
while on a call
To see who’s on hold
while on a call
1 Press [
●
Press [
Normal
1
Press [
Inspect
2
Press [
1
2
xxxxx
] to return to display for present call
]
] of held call
You remain connected to present call
Press [
●
]
Name and number of caller are shown if from
extension; [ OUTSIDE CALL ] or other trunk source is
shown if from outside
2
●
To answer a new call
while on a call
Inspect
Normal
] (if not already in normal mode)
Finish present call or put on hold
Press [ xxxxx ] of new call
✓
Message Retrieval
To see your messages
when your message
light is on (while onhook, off-hook, or on a
call)
To return a call to a
message sender
1 Press [
]
Message Retrieve
2
Press [ Next Message ] to see first message (and then for each
following message)
1
Pick up handset or activate speakerphone
[dial tone]
2 Press [ Return Call ] while any part of message is shown
To erase a message
1
Press [
To see a principal’s
(coworker’s) messages
(can be during a call
with principal)
1
Select an idle [ xxxxx ] button, or put principal on hold
and select an idle [ xxxxx ] button
[dial tone]
2
Press [
3
Dial principal’s extension
Delete
] while any part of message is shown
Covr Msg Retrieve
]
Note: You must first
be designated as a
system-wide message
retriever by your
System Manager or
principal must have
Message Retrieval
coverage that allows a
coverage point to
retrieve messages.
To return a call for the
principal to the
displayed extension
(while on a call with
principal)
4
Press [ Next Message ] to see the first message (and then for
each following message)
5 Press held [
appropriate
1
] to give them their messages, if
Press [ Transfer ]
●
Principal is put on hold
2
Press [ Return Call ] while any part of message is shown
3
Press [ Transfer ]
●
To erase a message
xxxxx
1
Principal is connected to call
Press [
Delete
] while any part of message is shown
✓
Normal
To return to normal
display after using any
display feature
1 Press [
●
Normal
]
Display will show call information for active call
appearance
Time
To see date and time
1
Press [
●
To see elapsed time
(hours, minutes,
seconds)
1
2
Timer
]
Green light goes on
Press [
●
]
Display returns to normal mode after a few seconds
Press [
●
Date/Time
Timer
] again to stop timer and clear display
Green light goes off
Tones and Their Meanings
Ringing tones are produced by an incoming call. Feedback tones are those that you
hear through the handset (receiver) or the speaker, if you have one.
Ringing Tones
●
1 ring — A call from another extension.
●
2 rings — A call from outside or from the attendant.
●
3 rings — A priority call from another extension, or a call from an Automatic
Callback call that you placed.
●
half ring — A call redirected from your voice terminal to another because Send All
Calls or Call Forwarding — Follow Me is active.
●
intercom ring — A call directed to you by the Intercom feature.
Feedback Tones
●
busy tone — A low-pitched tone repeated 60 times a minute; indicates that the
number dialed is in use.
●
call-waiting ringback tone — A ringback tone with a lower-pitched signal at the
end; indicates that the extension called is busy, but the called party has been given a
call-waiting tone.
●
confirmation tone — 3 short bursts of tone; indicates that a feature activation or
cancellation has been accepted.
●
coverage tone — 1 long burst of tone; indicates that your call will be sent to another
extension to be answered by a covering user.
●
dial tone — A continuous tone; indicates that dialing can begin.
●
intercept/time-out tone — An alternating high and low tone; indicates a dialing
error, a denial of the requested service, or a failure to dial within a preset interval
(usually 10 seconds) after lifting the handset or dialing the previous digit.
●
recall dial tone — 3 short bursts of tone followed by a steady dial tone; indicates
that the feature request has been accepted and dialing can begin.
●
reorder tone — A fast-busy tone repeated 120 times a minute; indicates that all
trunks are busy.
●
ringback tone — A low-pitched tone repeated 15 times a minute; indicates that the
number dialed is being rung.
Key Words to Know
access code
activate
See feature code.
To begin or turn on the operation of a feature.
attendant The person who handles incoming and outgoing calls at the main
telephone console.
AUDIX
Audio Information Exchange, an optional voice mail and message service
that provides coverage for calls to you by recording callers’ messages and reporting
Leave Word Calling messages.
call appearance A button used exclusively to place, receive, or hold calls. It has an
assigned extension number and is equipped with a red light and a green light.
coverage Automatic redirection of calls from an unanswered voice terminal to
another voice terminal of answering service. Redirection could be to the extension of a
receptionist, secretary, coworker, AUDIX, or message center. A person who provides
coverage is a covering user.
DEFINITY® Communications System Generic 2 The AT&T switch to which you
may be connected. It transmits and receives voice and data signals for all
communications equipment in your network. (See also System 85.)
dial pad
The 12 pushbuttons you use to dial a number and access features.
extension A dialing number of 3 to 5 digits assigned to each voice terminal
connected to your DEFINITY® Generic 2 or your System 85.
feature
A special function or service, such as Conference, Hold, and Send All Calls.
feature code A dial code of 1, 2, or 3 digits (4 digits in System 85 R2V4), that you use
to activate or cancel the operation of a feature.
group list One of the 3 types of Abbreviated Dialing lists; programmable by the
System Manager or a controller of the list. Contains telephone numbers useful to
members of a specific group, and stored as 1- or 2-digit list items, depending on the
number of members in the list.
handset The hand-held part of the voice terminal that you pick up, talk into, and
listen from. Also known as the receiver.
message retriever A person authorized by the System Manager to retrieve messages
for other users (coverage message retriever).
off-hook When the handset is removed from the cradle (for example, when you lift
the handset to place or answer a call) or speakerphone is ON.
on-hook
party
When the handset is left on the cradle or speakerphone is OFF.
A person who places or answers a call.
personal list One of the 3 types of Abbreviated Dialing lists; programmable by the
System Manager or by you, the user. Contains telephone numbers of your choice, and
stores each of them as a 1- or 2-digit list item, depending on the number of members
in the list.
personal list item
One of the slots on an Abbreviated Dialing personal list.
pickup group A group of telephone users who can answer calls for each other
through the Call Pickup feature. Group members are determined by the System
Manager and are usually located in the same work area or perform similar job
functions.
priority call An important or urgent call that sends a special 3-burst ring and does
not redirect to coverage or forward to designated alternative number.
program/reprogram To use your dial pad to assign a telephone number to a personal
list item for Abbreviated Dialing. Programming is activated by dialing an access code.
retrieve To collect telephone messages using your local retrieval methods. (Also,
with Call Park, to resume a call from an extension other than the one where the call
was first placed or received.)
ringer
The device that produces the electronic ringing sound in your voice terminal.
Ringing Appearance Preference If your voice terminal is assigned Ringing
Appearance Preference, you will automatically be connected to an incoming call when
you lift the handset. You do not have to press a call appearance.
stored number A telephone number that has been programmed and stored as a 1-,
2-, 3-, or 4-digit list item for use with Abbreviated Dialing. It can be a complete or
partial telephone number, an extension number, or a trunk or feature code. Once
programmed, a number can be accessed by first dialing the list, then the list item
digit(s) under which it is stored. If the number is stored on an [ AD xxxxx ] button, the
number can be accessed by simply pressing that button.
switch The device that makes connections for all voice and data calls for a network,
and also contains software for features. Also known as a system, switching system, or
PBX (private branch exchange). Your switch is an AT&T DEFINITY®
Communications System Generic 2 or an AT&T System 85.
System 85 The AT&T switch to which you maybe connected. It transmits and
receives voice and data signals for all communications equipment in your network.
(See also DEFINITY® Communications System Generic 2.)
system list One of the 3 types of Abbreviated Dialing lists; programmable only by
the System Manager. Contains telephone numbers helpful to all system users.
System Manager The person responsible for specifying and managing the operation
of features for all the voice and data equipment in your network.
trunk A telecommunications channel between your switch and the local or longdistance calling network or to another switch. Trunks of the same kind connecting to
the same endpoints are assigned to the same trunk group.
trunk code A dial code of up to 4 digits in that you dial to access a trunk group to
place an outside call.
voice terminal A telephone equipped with an array of specially designed features
(for example, administrable buttons) and functional capabilities that distinguish it from
a conventional telephone.
Quick-Reference Lists
Feature Codes
Feature
Personal
Group
System
Program
AUTOMATIC CALLBACK
Cancel
CALL FORWARDING —
BUSY/DON’T ANSWER
Cancel
CALL FORWARDING—
FOLLOW ME
Cancel
Code
Feature
CALL PARK
Answer Back
CALL PICKUP
LAST NUMBER DIALED
LEAVE WORD CALLING
Cancel
PRIORITY CALLING
SEND ALL CALLS
Cancel
Code
Abbreviated Dialing
Trunk Codes
Code
Description
Item
No.
1
2
3
4
Miscellaneous
5
6
Description
Extension
7
Message
8
Attendant
9
AUDIX
0
Personal List 1
Personal List 2
555-104-721
Issue 2, April 1990
Graphics© 1988 AT&T
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
