Lake ® PROCESSING CARD
Español
Français
MY8-LAKE
Pусский
Italiano
Owner’s Manual
Bedienungsanleitung
Mode d’emploi
Manual de instrucciones
Manuale di istruzioni
Руководство пользователя
取扱 説 明 書
DE
中文
EN
FR
IT
RU
ZH
JA
日本語
ES
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE:
DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC,
to use the product.
2. IMPORTANT: When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable/s supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to
comply with the requirements listed in FCC
Regulations, Part 15 for Class “B” digital devices.
Compliance with these requirements provides a
reasonable level of assurance that your use of this
product in a residential environment will not result in
harmful interference with other electronic devices. This
equipment generates/uses radio frequencies and, if not
installed and used according to the instructions found
in the users manual, may cause interference harmful to
the operation of other electronic devices. Compliance
with FCC regulations does not guarantee that
interference will not occur in all installations. If this
product is found to be the source of interference, which
can be determined by turning the unit “OFF” and “ON”,
please try to eliminate the problem by using one of the
following measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient
the antenna. If the antenna lead-in is 300 ohm ribbon
lead, change the lead-in to co-axial type cable.
If these corrective measures do not produce
satisfactory results, please contact the local retailer
authorized to distribute this type of product. If you can
not locate the appropriate retailer, please contact
Yamaha Corporation of America, Electronic Service
Division, 6600 Orangethorpe Ave, Buena Park,
CA90620
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
(class B)
COMPLIANCE INFORMATION STATEMENT
(DECLARATION OF CONFORMITY PROCEDURE)
Responsible Party : Yamaha Corporation of America
Address : 6600 Orangethorpe Ave., Buena Park, Calif. 90620
Telephone : 714-522-9011
Type of Equipment : LAKE PROCESSING CARD
Model Name : MY8-LAKE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including interference that may cause undesired operation.
See user manual instructions if interference to radio reception is suspected.
* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.
(FCC DoC)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CANADA
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
• This applies only to products distributed by Yamaha Canada Music Ltd.
• Ceci ne s’applique qu’aux produits distribués par Yamaha Canada Musique Ltée.
(class B)
이 기기는 가정용(B급) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며, 모든 지역에서 사용할 수
있습니다.
(class b korea)
2
MY8-LAKE Owner’s Manual
Contents
PRECAUTIONS................................................... 4
Introduction........................................................ 5
Welcome ..................................................................... 5
Features ...................................................................... 5
Installation ................................................................... 5
Included Accessories ................................................. 5
USB Flash Drive Contents........................................... 6
Part Names and Functions ............................... 7
Configuration and Module ................................ 8
Mesa Configuration Signal Flow (System EQ) ............ 8
Contour Configuration Signal Flow (Crossover).......... 9
Contour/Mesa Configuration Signal Flow.................. 10
Frames and Modules ................................................ 10
System Examples ............................................ 11
System EQ (Mesa) .................................................... 11
Crossover (Contour).................................................. 11
Quick Start Guide ............................................ 12
Installation and Cable Connection............................ 12
Lake Controller Software Installation......................... 12
Console (Host Device) Settings ................................ 12
Starting the Lake Controller ...................................... 13
Placing Modules ....................................................... 13
I/O Configuration....................................................... 14
Levels Screen ........................................................... 16
PEQ & GEQ Overlays................................................ 18
HPF/LPF Screen (Mesa mode only).......................... 19
Storing Modules and Systems .................................. 20
Changing the MY8-LAKE Frame Configuration ........ 21
XOVER Screen (Contour mode only) ........................ 22
Contour Levels Screen.............................................. 22
Appendix .......................................................... 24
Problems and Warnings............................................ 24
Troubleshooting ........................................................ 25
Specifications............................................................ 30
MY8-LAKE Owner’s Manual
3
PRECAUTIONS
PLEASE READ CAREFULLY
BEFORE PROCEEDING
• Drain all static electricity from your clothing and body
before handling the card. Static electricity can damage
the card. Touch an exposed metal part of the host
device or other grounded object beforehand.
* Please keep this manual in a safe
place for future reference.
• Do not drop the card or subject it to physical shock as
this can result in breakage and/or malfunction.
WARNING
Always follow the basic precautions listed below
to avoid the possibility of serious injury or even
death from electrical shock, short-circuiting,
damages, fire or other hazards. These
precautions include, but are not limited to, the
following:
• Do not install the card in any Yamaha products not
specified by Yamaha for use with the card to avoid
possible electrical shock, fire, or equipment damage.
• Do not attempt to disassemble or modify the card. Do
not apply excessive force to card connectors or other
card components. Mishandling of the card may lead to
shock, fire hazard, or equipment failure.
• Be sure to disconnect the power cable of the host
device before installing the card and connecting/
disconnecting the cables (in order to eliminate shock
hazard, undesired noise, and avoid equipment
damage).
• Turn off all peripheral devices connected to the host
device before installation, and unplug all related cables
(in order to eliminate shock hazard, undesired noise,
and avoid equipment damage).
CAUTION
Always follow the basic precautions listed below
to avoid the possibility of physical injury to you or
others, or damage to the device or other
property. These precautions include, but are not
limited to, the following:
• Be sure to properly ground the host device to prevent
electrical shock and/or malfunction.
• Do not touch the metallic leads (pins) of the circuit
board when handling the card. The pins are sharp and
may cause hand cuts.
• Wear a pair of heavy gloves during installation to avoid
scratching or cutting your hands on sharp edges.
4
• Avoid touching exposed connectors and metal parts to
minimize the possibility of bad connections.
MY8-LAKE Owner’s Manual
• Do not drop screws or other small parts inside the
card. If power is applied while screws or similar metal
objects are loose inside the unit the card may
malfunction or be damaged. If you cannot retrieve
dropped objects yourself, refer the problem to qualified
Yamaha service personnel.
Yamaha cannot be held responsible for damage
caused by improper use or modifications to the
device, or data that is lost or destroyed.
• The illustrations as shown in this manual are for
instructional purposes only, and may be different from
the ones on your equipment.
• Lake is a registered trademark of Lab.gruppen AB.
• Windows is a registered trademark of Microsoft®
Corporation in the United States and other countries.
• The company names and product names in this manual
are the trademarks or registered trademarks of their
respective companies.
European models
Purchaser/User Information specified in EN55103-1 and
EN55103-2.
Conforms to Environments: E1, E2, E3 and E4
Introduction
Welcome
Thank you for choosing the Yamaha MY8LAKE Lake® Processing card. The MY8LAKE is a DSP expansion Mini-YGDAI card
for use with compatible Yamaha
professional audio devices. The card allows
audio processing via insert to the host
device or AES/EBU connection, enabling
you to take advantage of the built-in
advanced Lake® Processing technology for
system equalization (EQ) and loudspeaker
crossover processing. Lake Processing
technology contains digital audio signal
processing including EQ, levels, delay,
limiters and crossovers along with
advanced control capabilities via the Lake
Controller software.
To take advantage of the powerful features
and to ensure years of trouble-free use,
please read this manual in conjunction with
the Lake Controller Operation Manual
(included in the Lake Controller software),
before using the card.
Features
• Configurable as an 8 x 8 system EQ
(Mesa mode) or as a 4 x 12 crossover
(Contour mode) or as a hybrid
configuration (Contour/Mesa) featuring 4 x
4 system EQ and 2 x 6 crossover.
• Input EQ in both Mesa and Contour
modes features Lake Mesa EQ™
(asymmetric filtering) and Ideal Graphic
EQ™ with Raised Cosine Equalization
technology for accurate and faster EQ
control.
• Classic and linear phase crossovers are
available when configured in Contour
mode.
• Supports up to twelve audio processing
output channels (dependent on
configuration) featuring independent gain
and delay along with RMS and peak
limiters featuring Lake LimiterMax™
technology.
• Eight internal host inputs/outputs and
eight AES inputs/outputs.
• Network connectivity allows Lake
Controller software on Windows PC to
control and monitor the processing as well
as other Lake devices.
Installation
Refer to the owner’s manual supplied with
the host device for installation details. The
screws on the left and right sides of the
card also ground (earth) the device, so be
sure to tighten them securely.
NOTICE
Before installing the card in a host
device, verify that the device is
compatible with the card, and that the
maximum number of Yamaha and thirdparty expansion cards simultaneously
installed is not exceeded. Refer to the
owner’s manual supplied with the audio
device, and/or the Yamaha Pro Audio web
site at:
http://www.yamahaproaudio.com/
Included Accessories
• MY8-LAKE Owner’s manual (this
document)
This manual illustrates how to install the
card, make the settings of a host device,
and set up the Lake Controller software.
For details about the Lake Controller
software, refer to the Lake Controller
Operation Manual.
• USB Flash Drive (see contents on
next page)
MY8-LAKE Owner’s Manual
5
USB Flash Drive
Contents
• Lake Controller Software Installer
This software installer provides the Lake
Controller software (for Windows), which is
necessary for use of the MY8-LAKE card,
along with the associated documentation
and firmware update utilities.
Documentation is available from the
Windows Start Menu after software is
installed.
For the latest information about the system
requirements, refer to the Lake website:
http://www.lakeprocessing.com
• Lake Controller Operation Manual
(English only)
This PDF document is included as part of
the Lake Controller software installer, and
provides detailed information on the Lake
Controller software used to control the
audio processing and routing.
• Lake Network Configuration Guide
(English only)
This PDF document is included as part of
the Lake Controller software installer, and
provides detailed network configuration
information, such as IP address settings
and connection of multiple PCs.
• MY8-LAKE Owner’s Manual
A color PDF version of this manual is
included in the USB flash drive. Read this
owner’s manual thoroughly to help you
understand how to install and use the
software and hardware associated with
the MY8-LAKE card.
• Release Notes
This PDF document is included in the
Lake Controller software installer, and
contains the latest release notes and
important supplementary information.
6
MY8-LAKE Owner’s Manual
NOTE
• To verify that the included USB flash drive
contains the latest version of the Lake
Controller software, and to locate supporting
documentation, refer to the Lake website:
http://www.lakeprocessing.com
• To view PDF files, you will need to install
Adobe Reader on your computer. You can
download the latest Adobe Reader at the
following website:
http://www.adobe.com
Part Names and Functions
1
2
3
1 AES/EBU connector
This is a D-sub 25-pin connector that inputs and outputs eight digital audio signals in AES/
EBU format.
Supported sampling frequencies are 44.1, 48, 88.2, and 96 kHz.
2 NETWORK connector
This is a RJ-45 connector (100 Mbps) that connects to a PC (Lake Controller).
3 LED indicators
• SELECT: The white LED is lit (static) to confirm device selection from within the Lake
Controller software; it flashes when the Lake Controller is communicating with the device,
and is off when neither selection nor communication is occurring.
• FAULT: The red LED is either lit (static) or flashes to warn that a serious problem is
occurring. A fault can include an internal error, a slipping digital clock, module output
clipping, or a problem on the card interface.
For additional information about LED indications and their meaning, refer to the section
“Problems and Warnings” in the chapter “Appendix.”
• STATUS: The green LED flashes to indicate that the MY8-LAKE card is correctly booted
and operational; it is lit (static) when the digital input clock is locked.
MY8-LAKE Owner’s Manual
7
Configuration and Module
Mesa Configuration Signal Flow (System EQ)
The MY8-LAKE defaults to an 8x8 system EQ configuration referred to as Mesa mode. This
configuration provides eight discrete channels of audio processing as shown in the diagram
below.
Module Output Section
Input
Mixer A
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer B
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer C
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer D
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer E
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer F
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer G
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer H
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
Output Routing
Input Routers 1-8
Module Input Section
RMS/Peak
RMS/Peak
RMS/Peak
NOTE
• Each module is equipped with an Input Mixer, which allows the input signals to be mixed together.
• The Output Router provides the ability to directly route any input sources and Input Router outputs
as well as module outputs to any output destinations.
8
MY8-LAKE Owner’s Manual
Contour Configuration Signal Flow (Crossover)
In Contour mode (crossover), the MY8-LAKE provides 4x12 crossover modules as shown in
the diagram below.
Module Output Section
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
RMS/Peak
Module Input Section
EQ
Gain
Polarity / Mute
EQ
Gain
Polarity / Mute
EQ
Input
Mixer D
Gain
Polarity / Mute
EQ
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
Delay
Crossovers
Input
Mixer C
RMS/Peak
Delay
Input Routers 1-8
Input
Mixer B
RMS/Peak
Delay
Output Routing
Gain
Polarity / Mute
Crossovers
Input
Mixer A
RMS/Peak
RMS/Peak
Delay
RMS/Peak
RMS/Peak
MY8-LAKE Owner’s Manual
9
Contour/Mesa Configuration Signal Flow
In hybrid mode (Contour/Mesa), the MY8-LAKE provides 2x6 crossover modules and 4x4
system EQ modules as shown in the diagram below.
Module Output Section
EQ
Delay
Input
Mixer B
Gain
Polarity / Mute
EQ
Delay
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
EQ
Gain / Delay
Polarity / Mute
LimiterMax
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
Input
Mixer C
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer D
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer E
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Input
Mixer F
Gain
EQ
Delay
HPF/LPF
Gain / Delay
Polarity / Mute
LimiterMax
Output Routing
Gain
Polarity / Mute
Input Routers 1-8
Input
Mixer A
Crossovers
Module Input Section
EQ
RMS/Peak
RMS/Peak
RMS/Peak
RMS/Peak
Frames and Modules
The term “Frame” is used to represent a physical Lake device (e.g., the MY8-LAKE card).
The MY8-LAKE frame can contain two to eight audio processing units referred as “Modules.”
In Mesa mode (default) the MY8-LAKE Frame contains eight modules, labeled as modules
A – H. Each Mesa module provides a single channel of EQ, levels and dynamics processing
and only uses the module type of “Mesa EQ.”
In Contour mode the MY8-LAKE Frame contains up to four modules labeled A – D; in Contour/
Mesa mode there are up to six modules labeled A – F. The number of modules available in a
Contour or Contour/Mesa mode is dependent on the Contour module types in use.
Contour modules can be configured in many different ways, such as 2-, 3-, 4-, 5-, and 6-way
Classic Crossovers (Bessel, Butterworth, Linkwitz-Riley), 2-, 3-, and 4-way Linear Phase
Crossovers, or as full bandwidth Auxiliary Outputs. For a Contour module example, refer to the
section “XOVER Screen” later in the Quick Start Guide.
10
MY8-LAKE Owner’s Manual
System Examples
The MY8-LAKE card can be used in a variety of ways; this chapter describes two typical
scenarios.
System EQ (Mesa)
System EQ can be applied in Mesa mode; this is the default configuration for the MY8-LAKE
card. Mesa mode provides eight channels of discrete audio processing that can be assigned
to the host channel Insert Ins from the Insert Outs, without the use of any physical cabling—
thanks to the card solution. This configuration provides powerful Lake EQ and dynamics
processing for use as system EQ (in front-of-house mixes, for example), or as individual input
channel EQ (in vocal processing, for example). If three cards are installed, this powerful,
versatile EQ can be used in up to 24 mixes, which supports any scale of monitor system
equalization. The Mesa modules can also be used for subsystem aligning and tuning,
replacing the host console's Matrix section with an Input Mixer of each module.
Mesa
8
8
MY8-LAKE
Insert Out
Insert In
ST/MIX/MATRIX
ST/MIX/MATRIX
Out
8
Crossover
Amplifier
Crossover (Contour)
Crossover can be applied in the Contour mode for Lake. The MY8-LAKE provides a 4x12
crossover configuration; the processed channel signals can be routed internally back to the
host device (up to 8 channels), and/or output via the AES/EBU D-sub 25-pin connector (up to 8
channels). In this system example, the stereo main mix signals from the host are routed to the
MY8-LAKE for crossover, EQ, levels and dynamics processing. The processed signals are
sent back to the available channels on the host and/or the AES/EBU connector, then to the
power amplifiers or powered speakers.
The output signals contain only the relevant frequencies (post-crossover) for each amplifier
and speaker. This scenario removes the need for separate outboard crossover and EQ
processing, reducing the amount of external hardware and racks required to achieve the same
result as traditional active speaker crossover systems.
Contour
4
8
MY8-LAKE
Out
ST/MIX
Insert In
MIX/MATRIX
Out
8
Amplifier
MY8-LAKE Owner’s Manual
11
Quick Start Guide
Installation and Cable
Connection
The first thing you should do is to install the
card in your host device. For detailed
installation instructions, refer to the owner's
manual supplied with your host device.
1. Install the MY8-LAKE into an
appropriate slot on your host
device while the power is turned
off, and tighten the two screws
of the card to ensure a secure
connection.
2. Connect a Cat5/Cat6 Ethernet
cable between the MY8-LAKE
and the Windows PC that will be
used for the Lake Controller.
NOTE
• When using multiple PCs, Lake devices,
or wireless access points, a network
switch is required.
• The default IP Address Config on the
MY8-LAKE is Auto - Zero Conf
(169.254.x.x); if connectivity problems
are encountered, try setting the network
adapter of the PC to the same subnet
range or to another fixed IP address
such as 192.168.0.x.
• If Dante audio networking coexists on
the same network for the other Lake
devices, additional network
configuration will be required.
• For further details about configuring the
Lake Controller network, refer to the
Lake Controller Operation Manual and
Lake Network Configuration Guide.
• To prevent electromagnetic
interference, use an STP (shielded
twisted pair) Ethernet cable.
12
MY8-LAKE Owner’s Manual
Lake Controller
Software Installation
To enable full functionality and operation of
the MY8-LAKE, the Lake Controller software
must be installed in your Windows PC.
1. Insert the included USB flash
drive into your Windows PC.
2. Follow the on-screen prompts to
install the software.
We recommend that you check online
for the most recent version of the Lake
Controller.
Console (Host Device)
Settings
Before using the MY8-LAKE, the I/O
patchings on the console (host device)
must be executed according to the specific
mode, as described in the following
examples.
CAUTION
Make sure to mute or move the faders all
the way down when making the console
settings to avoid undesired sound.
Mesa mode: For typical applications for
system EQ or input EQ, you will normally
insert the Lake Processing into insert points
of any input or output channels on the
console. On the INSERT screen of the
console, patch the corresponding channels
of the SLOT for the MY8-LAKE card to the
Insert Outs and Ins of the desired channels
on the console, and make sure the INSERT
buttons are ON.
Contour mode: For typical applications
for crossover processing, the output ports
of the desired ST L/R or MIX channels
should be patched to the corresponding
channels of the SLOT for the MY8-LAKE
card. The post-crossover signals can be
routed back to the host or out to the AES/
EBU connector. In case of routing back to
the host, patch the corresponding channels
of the SLOT to the Insert In of any empty
output channels. If any input channels are
available instead, you can also patch to the
input ports and directly output the signals
via Direct Out.
NOTE
For details about the console settings, refer to
the owner’s manual supplied with your host
device.
Starting the Lake
Controller
To start the Lake Controller with an online
MY8-LAKE card connected for the first time,
follow the steps below.
1. Double-tap (click) the Lake
Controller icon on the Windows
desktop.
3. Tap [No] if prompted to recall the
last system configuration.
NOTE
• After a proper network configuration
and a valid Network connection are
established, your MY8-LAKE card is
now online and can be controlled using
the Lake Controller software.
• Ensure that the Lake Controller is
allowed full access through the
Windows firewall.
Placing Modules
The default configuration for the MY8-LAKE
is eight Mesa EQ modules, providing a total
of eight discrete module inputs and outputs.
For instructions on changing the
configuration, refer to “Changing the MY8LAKE Frame Configuration” on page 21.
1. Tap the [Modules] button from
the main Home screen to call up
the module scroll bar.
2. If the Select Network Adapter
dialog appears, select the
relevant network adapter for the
MY8-LAKE connection from the
list and tap [Select Adapter].
Modules button
MY8-LAKE Owner’s Manual
13
2. Drag the module scroll bar to the
left (or tap the button at the
bottom right) to reveal the eight
modules of the MY8-LAKE
Frame as shown below.
Scroll bar
Module
3. Tap on one of the eight module
icons, then drag the resulting
cursor (of blank circles) to the
main work area and tap again.
The icons will move from the scroll bar
as shown below.
I/O Configuration
This section describes how to configure the
input and output routings for a module.
4. Tap a module icon in the work
area to select it.
Additional functions are activated on
the button bar at the bottom of the
screen when a module is selected.
I/O Config button
5. Tap the [I/O Config] button at the
bottom of the screen.
The I/O Config screen (Simplified view)
will be displayed by default for the
MY8-LAKE card.
The existing data will be read from the
hardware to synchronize the Controller
with the MY8-LAKE. The Frame is now
online and ready for control and
adjustment.
14
MY8-LAKE Owner’s Manual
The left side of the screen provides
summary information regarding the
Digital Clock and Input Configuration,
as well as selection options for the
Analog Output Reference of the host
device, Routing Mode and the
Operation Mode of the card. Tapping
on a magnifying glass icon or on the
summary text will open a pop-up
screen with additional data; the right
side of the screen provides interactive
signal flow diagrams.
6. Toggle between the [Host Out
Ch] button and the [AES CH]
button to select a module input
source.
The selected input source will be
highlighted in orange.
Advanced I/O Configuration
(Classic view)
The default output configuration (Simplified
view) is routed to the Host inputs (i.e., Host
return) and to the AES output from each
module. If you want to change the output
configuration, you will need to change the
view to “Classic view” by following the steps
below.
1. Tap the [Routing Mode]
All modules can be displayed by
tapping and holding up/down to scroll.
7. Tap an [Input Mixer] magnifying
glass icon.
The Input Mixer screen will be
displayed. You can adjust the input
level, and route or disconnect input
signals to any module by using the ON/
OFF buttons and fader controls.
8. Tap the blue arrow at the bottomright of the screen to close the
Input Mixer.
magnifying glass icon at the
bottom left of the I/O Config
screen, then select the “Classic
view” from the pop-up menus.
In the Classic view, by default the
Mesa Module Outputs A – H are routed
simultaneously to both the “Host”
returns 1 – 8 and to “AES” channels
1 – 8 just as in the Simplified view.
2. Tap one of the blue boxes in the
module’s input mixer block
diagram.
NOTE
• For host devices unrecognized by the
MY8-AE96 (such as DIO8), you will
need to change the emulation mode of
the card to MY8-AT by tapping the
[Operation Mode] magnifying glass
icon at the bottom left of the screen and
reboot the host device.
• The digital clock and input configuration
summary can be found at the top left of
the screen.
The Input Mixer screen will be
displayed. You can adjust the input
level, and route or disconnect input
signals to any module by using the ON/
OFF buttons and fader controls.
3. Tap any of the magnifying glass
icons on the far right of the
screen.
The Output Configuration screen will
be displayed allowing you to route any
MY8-LAKE Owner’s Manual
15
available audio source to any available
output destination.
Levels Screen
The orange numbered blocks show
which module output is routed to which
of the currently selected “Destination”
outputs. The currently displayed audio
“Source” defaults to show the number
of “Module Outputs” channels listed on
the left and the visible audio
“Destination” defaults to display the
“Host” returns. The currently displayed
view can be changed by tapping the
appropriate left or right arrows beneath
the “Source” and “Destination” labels.
1. Tap the [Home] button, then tap
The Levels screen provides access to
controls for gain, delay, LimiterMax, input
mixer, mutes and polarity adjustments. This
section describes various example
scenarios to highlight key functionality.
a module icon.
If a submenu is not selected, tapping a
module icon provides a shortcut to the
EQ, Levels and HPF/LPF or XOVER
screens for the selected module.
2. Tap the [Levels] tab at the top
left of the screen (if not already
selected) then tap the red
[Output MUTED] button to
unmute the Mesa module output.
NOTE
Tap an orange numbered button to
disconnect that source/destination
routing only (turns blue); tap a blue
numbered button to patch the source to
the destination. The Disconnect All button
can be used to disconnect all outputs
for the displayed source/destination
matrix.
NOTE
Mesa EQ modules do not have a
separate module input mute. Input Router
and Input Mixer mutes and connectivity
can be reviewed by tapping the
associated magnifying glass icon shown
below.
4. Make any changes as required,
then tap the blue arrow at the
bottom right of the screen to
close the Output Configuration
screen.
NOTE
You can also close the screen by
pressing <Esc>, then pressing <F1> to
return to the Home screen.
16
MY8-LAKE Owner’s Manual
3. Check any associated mute and
level settings in the MY8-LAKE
host device.
Assuming there is an audio signal
passing from the host device into the
module, the screen will look similar to
that shown below after the input has
been unmuted.
DM2000, for example, you will need to
change the setting of the Analog Output
Reference.
5. Tap the [LimiterMax EXIT] button
to return to the top level menu.
6. To change polarity, tap the
[Enable Polarity] button, then tap
a polarity button
(located to
the right of the associated
channel’s mute button).
7. To label a channel, tap the [Label
NOTE
The Levels screen always displays active
RMS & Peak metering for the input and
output channels on the selected module.
The fader positions and associated
values change as each level type is
selected (Gain, Delay, LimiterMax etc.).
4. Tap the [LimiterMax] button to
display a submenu containing
additional options for RMS and
peak limiter controls.
Channel] button, then tap a
channel label button. Enter a
new name, then tap [OK] (or
press <Enter>).
NOTE
• The mute status text is removed from
the mute button and mute functionality
is temporarily disabled.
• The channel number is appended
automatically and does not need to be
included in the text label.
NOTE
• The MaxRMS Level, MaxRMS Corner,
MaxRMS Attack, MaxRMS Release and
MaxPeak Level controls can be used to
set independent peak and RMS output
limiters as required for your application.
• These limiter levels are specified in dB
units. Yamaha presets for Installation
series loudspeakers are tuned
assuming 26 dB amp gain, and the
“Analog Output Reference” in the I/O
Config screen is set to +24 dBu by
default for the MY8-LAKE (which is the
case for most of Yamaha consoles).
However, the limiter levels should be
adjusted according to the specific
output devices, amplifiers and your
particular applications. For use with +18
dBu maximum output devices such as
8. Tap the [Label Channel] button
again to exit channel labeling
and enable mute functionality
again.
NOTE
The Meter Options submenu includes
various other metering options and
functionality, some requiring Designer
Mode activation before the functions are
displayed. For further information on
Designer Mode and more detailed Levels
screen functionality, refer to the Lake
Controller Operation Manual.
MY8-LAKE Owner’s Manual
17
PEQ & GEQ Overlays
sides of the filter allowing for fast
asymmetrical filter creation.
The Lake Controller software provides
powerful EQ overlays that allow layering of
EQ using parametric EQ (PEQ) and fixedband graphic EQ style controls (GEQ).
5. Tap and drag one of the red “X”
1. Tap the [Home] button, then tap
”X” filter point
filter points up or down to boost/
cut.
a module icon.
2. Tap the [EQ] tab at the top of the
screen (if not already selected),
then tap the [PEQ1] tab.
The EQ tab expands to show the HPF/
LPF, PEQ and GEQ tabs.
PEQ1 tab
6. Use the filter edit tool at the
bottom of the screen to adjust
the slopes.
3. Select a Mesa EQ filter by
tapping the icon highlighted in
orange as illustrated below.
The cursor changes to the same shape
for confirmation.
Drag left or right in the numbered
zones to adjust the filter as described
below.
3
2
1 2 3
4. Drag the cursor and tap again
anywhere on the EQ graph in the
main section of the screen.
1 The overall center frequency of the
Mesa EQ filter
• Two filter edit boxes appear at the
top of the screen, two corresponding
filter points appear on the 0 dB line
in the middle of the screen, and a
graphical filter editing tool appears
at the bottom of the screen.
3 The slope steepness of the each
side
• The Mesa EQ filter is a unique filter
that allows separate control of both
18
MY8-LAKE Owner’s Manual
2 The center frequency of the each
side
7. Tap the [Filter Edit] button to
adjust filter gain, frequency
center point and slope.
12. Drag the filter point up or down
to boost/cut.
“X” filter points
8. Tap any of the blue boxes that
appear at the top left of the
screen to manually enter
specific values if needed.
9. If the [Frequency Lock] button at
the top left of the screen is
orange, tap the button to disable
this function.
NOTE
Frequency Lock is enabled by default
and restricts filter selection and frequency
adjustment by tapping and dragging on
the red ‘X’ filter points. When enabled, this
feature avoids accidental EQ adjustments
requiring selection of PEQ filters by
tapping on the associated filter box at the
top of the screen, and frequency
adjustment is only permitted using the EQ
filter edit tool described in step 6. For
GEQ, this feature forces the user to select
a GEQ filter by dragging the EQ selection
tool at the bottom of the screen.
10. Tap on the [GEQ2] tab at the top
of the screen.
NOTE
The EQ curve from the PEQ1 is visible on
GEQ2; the EQ overlays stack on top of
each other having a compounding effect
on the resulting EQ.
11. Tap on the associated filter point
‘X’ to select a GEQ2 filter that
overlaps the PEQ1 Mesa filter
frequency range.
The GEQ filter affects the overall EQ
curve indicated by the white line (i.e.
the sum of all filters on all PEQ/GEQ
overlays that affect the selected
module).
HPF/LPF Screen
(Mesa mode only)
The HPF/LPF screen provides control of
high- and low-pass filters that affect the
overall EQ on the selected module. Follow
the steps below to set and adjust HPF or
LPF filters on a Mesa module.
1. Tap the [Home] button, then tap
a module icon.
2. Tap the [EQ] tab at the top of the
screen (if necessary), then tap
the [HPF/LPF] tab.
3. Tap the [HPF Enable] and the
[LPF Enable] buttons (so that
they turn orange).
MY8-LAKE Owner’s Manual
19
4. Tap the HPF filter box at the top
left of the screen to select the
HPF filter. (The LPF filter box is
shown at the top right of the
screen when enabled.)
7. Tap the [HPF Set] button and tap
[Yes] after reading the warning
dialog.
NOTE
To view the overall EQ response including
the HPF/LPF and PEQ/GEQ filters, tap the
[HPF/LPF Functions] button, then tap the
[EQ Preferences] button, and finally tap
[Full Response]. The white line changes
to include the effect of all EQ filters from
all PEQ and GEQ overlays that affect the
selected module as shown below.
Filter box
5. Adjust the HPF frequency center
point by dragging the green HPF
adjustment tool to the left or
right.
Storing Modules and
Systems
Before we move to the next section, store
the existing configuration as an individual
module file and as a System file.
1. Tap the [Home] button, then tap
the [Modules] button.
2. Select a module icon in the work
area, then tap the [Module Store/
Recall] button.
HPF adjustment tool
NOTE
6. Tap the [HPF Select] button, then
A module must be selected before the
Module Store/Recall function is activated.
select a desired type of filter
from the scroll bar that appears.
3. Tap the [New Store] button, then
Scroll bar
20
MY8-LAKE Owner’s Manual
enter a module filename, and
then tap [OK] (or press <Enter>).
This stores all module information
(levels, x-over and EQ settings) from
the selected module as a new module
file for future recall. You can recall the
file and overwrite a different module.
2. Make sure that a module is
selected, then tap the [I/O
Config] button, and finally the
[Frame Config] button.
4. Tap the [Home] button, then tap
the [System Store/Recall] button.
5. Tap the [Store System] button,
then enter a system name, and
finally tap [OK] (or press
<Enter>).
This stores all data (frame and module
data) in your current system before
proceeding to change the device
configuration. Input and output routing
settings as well as input mixer settings
are part of frame data. We recommend
you get into a habit of regularly saving
your work to minimize the risk of data
loss.
NOTE
For further information about storing of
Module files, Base Configuration files,
System and Sub-System files, refer to the
Lake Controller Operation Manual.
3. Tap the [Contour Reset] button,
then tap [Yes] after reading the
important warning dialog.
The screen changes to show the
module scroll bar and the reconfigured
modules will appear on the scroll bar
after a few seconds. The Frame can be
configured using any of the three
available reset options shown above
as required.
4. Select one of the MY8-LAKE
Contour modules from the
module scroll bar and place it in
the main work area.
The default 4 x Classic 2-Way
Crossover modules appear as shown
below.
Changing the MY8-LAKE
Frame Configuration
To review the functionality of the MY8-LAKE
card in loudspeaker processor (Contour)
mode, the MY8-LAKE Frame configuration
must be changed from the default Mesa
mode to Contour mode.
1. Tap the [Home] button, then tap
the [Modules] button.
MY8-LAKE Owner’s Manual
21
XOVER Screen
(Contour mode only)
The XOVER screen is available only on
Contour modules when the MY8-LAKE card
is configured either in Contour mode or the
hybrid Contour/Mesa mode. This section
explains features specific to Contour
modules. When using loudspeaker presets
module files recalled from the “LoadLibrary”
folder, the XOVER screen may be hidden
and unavailable. This guide assumes the
use of the default Classic 2-Way module.
5. Select a module icon, and then
tap the [EQ/Levels] button.
If the XOVER screen is not displayed,
tap the XOVER tab at the top of the
screen.
6. Drag the green crossover
adjustment tool at the bottom of
the screen to the left or right to
adjust the center point of the
crossover frequency.
8. Add a parametric EQ filter to the
high channel then drag up or
down to boost/cut.
EQ changes on the XOVER screen only
affect the selected channel, even if the
slope of the EQ filter crosses the
frequency range of multiple channels.
Contour Levels Screen
The Contour Levels screen functions are
very similar to those described earlier in the
section “Levels Screen” on page 16. This
section describes some additional
functionality relevant for Contour modules
only.
9. Tap the [Levels] tab at the top
left of the screen (if not already
selected), then tap the red [Input
MUTED] button to unmute a
default Contour module.
NOTE
• When using Contour loudspeaker
Crossover adjustment tool
7. Tap the right-side of the
crossover adjustment tool to
select the High channel.
The selected channel is shaded in
green.
22
MY8-LAKE Owner’s Manual
preset module files, ensure that the
relationship between the module output
channel numbers, labels such as Low
and High, and the module output to AES
or Host routings are carefully verified
and adjusted for your particular
application prior to allowing any signal
to pass to external amplifiers or
powered speakers.
• Assuming the routing is correct and
there is an audio signal passing from
the host device (or via AES inputs if
used), the screen will look similar to that
shown below after the module input has
been unmuted.
• Contour modules can have between
one and six output channels dependent
on the module type. The example above
shows a 2-way module, with the input
channel (far left) and the two output
channels (Low & High) to the right.
• For additional information about the
Lake Controller, including module
grouping, XOVER and HPF/LPF
ganging, Designer Mode functionality,
and other advanced user options, refer
to the Lake Controller Operation
Manual.
MY8-LAKE Owner’s Manual
23
Appendix
Problems and Warnings
Problems, warnings, and other certain types of information are displayed via the MY8-LAKE
panel indicators.
LED
FAULT
Indicators
Flash
Lit (static)
Details
Solution
No input source is available.
Refer to “No Sound” in the
“Troubleshooting” section.
The digital clock is slipping.
Ensure the digital clock is locked
to a valid source. For details,
refer to “Unusual Sound (noise,
interruption, or distortion)” in the
“Troubleshooting” section, and to
the Lake Controller Operation
Manual.
The module output is clipping.
Check the level meters on the
module input and output as well
as on the console, and reduce
the input or output level.
An internal error of the card.
Restart the host device. If the
problem continues, connect via a
NETWORK connector and
update the firmware using the
Lake Update Utility, and then
restart the device.
* If any specific problem should persist, please contact your Yamaha dealer.
24
MY8-LAKE Owner’s Manual
Troubleshooting
No Sound
Is the card recognized correctly by the
host device?
In the default setting, the host device will recognize
the card as a MY8-AE96 card. For host devices
unrecognized by the MY8-AE96 (such as DIO8), you
will need to change the emulation mode of the card
to MY8-AT by tapping the [Operation Mode]
magnifying glass icon at the bottom left of the I/O
Config screen in the Lake Controller. For detailed
information on the emulation mode settings, refer to
the Yamaha Pro Audio website at:
http://www.yamahaproaudio.com/
Has the signal been correctly patched to
and from the host device?
Check the I/O patching on the console to and from
the corresponding MY8-LAKE slot.
Has the signal been connected correctly
in the input router and module input mixer?
Verify the input router and input mixer connectivity in
the I/O Config screen on the Lake Controller.
Has the signal been correctly routed to the
outputs via the Output Configuration
screen?
Verify that the module output is correctly connected
to the required host return or AES output on the
Output Configuration screen on the Lake Controller.
Are all mute points in the MY8-LAKE signal
path unmuted?
Check that all Input Router, module Input and module
Output Mutes are properly unmuted.
Unusual Sound (noise, interruption, or distortion)
Is the FAULT LED of the MY8-LAKE
illuminated?
A fault could indicate a signal clip or slipping clock.
Is the signal clipping at any point in the
signal path?
Check input and output levels on the host device and
on the Lake Controller software to ensure that the
signal is not clipping at any point during the signal
path.
Is the digital clock slipping?
Check the FAULT LED or view “Digital Clock” at top
left of the I/O Config screen in the Lake Controller
software to check for any digital clocking problems.
Network Control or Communication Problems
Is the MY8-LAKE card correctly installed
and the host device switched on?
Check to ensure that the STATUS LED on the card
flashes.
Is the Windows firewall enabled?
Ensure that the Lake Controller is allowed full access
through the Windows firewall. Refer to the Lake
Controller Operation Manual for further details.
Is the Lake Controller PC connected via a
Wireless Access Point?
Connect directly from your Windows PC to the MY8LAKE card using a Cat5/Cat6 Ethernet cable, and
then add a wireless access point once wired
connection has proven successful.
MY8-LAKE Owner’s Manual
25
Network Control or Communication Problems
Is the IP address on your PC correctly
configured?
The default IP Address Config on the MY8-LAKE is
Auto - Zero Conf (169.254.x.x); if connectivity
problems are encountered, try setting the network
adapter of the PC to the same subnet range or use
another fixed IP address, such as 192.168.0.x.
Are any Dante-enabled devices present
on the network?
Additional network hardware configuration may be
required; refer to the Lake Network Configuration
Guide.
* If any specific problem should persist, please contact your Yamaha dealer.
26
MY8-LAKE Owner’s Manual
Specifications
General Specifications
Sampling Frequency
Mini-YGDAI I/F
AES/EBU Input/Output
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Internal Operating Frequency
96 kHz
Signal Delay
Best case (synchronous 96 kHz
to synchronous 96 kHz) from
AES input to AES output via
module (Contour or Mesa)
0.7185 ms
Power Requirements
maximum 3W
Temperature range
Operating
0 to 40 °C (32 to 104 °F)
Storage
-20 to 60 °C (-4 to 140 °F)
I/O Characteristics
30
Terminal name
Format
Data
length
Sampling
Frequency
Level
Connector
AES/EBU
(In/Out Ch 1-8)
AES/EBU
24 bit
44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz
(I/O individually
selectable per Ch)
RS422
D-sub 25 pin
NETWORK
(Ethernet)
10Base-T/
100Base-T
-
-
-
RJ-45
MY8-LAKE Owner’s Manual
Connector Pin Assignment
13
AES/EBU
Signal
Pin
1
14
25
Input Ch
1–2
3–4
5–6
Output Ch
7–8
1–2
3–4
5–6
7–8
Hot
1
2
3
4
5
6
7
8
Cold
14
15
16
17
18
19
20
21
Open
GND
9, 11
10, 12, 13, 22,
23, 24, 25
176.1
(12)
164.1
Dimensions
40
120
Unit: mm
* Specifications and descriptions in this owner’s manual are for information purposes only. Yamaha Corp.
reserves the right to change or modify products or specifications at any time without prior notice. Since
specifications, equipment or options may not be the same in every locale, please check with your Yamaha
dealer.
* Die technischen Daten und Beschreibungen in dieser Bedienungsanleitung dienen nur der Information.
Yamaha Corp. behält sich das Recht vor, Produkte oder deren technische Daten jederzeit ohne vorherige
Ankündigung zu verändern oder zu modifizieren. Da die technischen Daten, das Gerät selbst oder
Sonderzubehör nicht in jedem Land gleich sind, setzen Sie sich im Zweifel bitte mit Ihrem Yamaha-Händler
in Verbindung.
MY8-LAKE Owner’s Manual
31
* Les caractéristiques techniques et les descriptions du mode d’emploi ne sont données que pour
information. Yamaha Corp. se réserve le droit de changer ou modifier les produits et leurs caractéristiques
techniques à tout moment sans aucun avis. Du fait que les caractéristiques techniques, les équipements et
les options peuvent différer d’un pays à l’autre, adressez-vous au distributeur Yamaha le plus proche.
* Las especificaciones y descripciones de este manual del propietario tienen sólo el propósito de servir como
información. Yamaha Corp. se reserva el derecho a efectuar cambios o modificaciones en los productos o
especificaciones en cualquier momento sin previo aviso. Puesto que las especificaciones, equipos u
opciones pueden no ser las mismas en todos los mercados, solicite información a su distribuidor Yamaha.
* Le specifiche e le descrizioni presenti in questo manuale sono fornite a fini puramente informativi. Yamaha
Corp. si riserva il diritto di modificare prodotti o specifiche in qualsiasi momento senza preavviso. Dato che
le specifiche, le apparecchiature o le opzioni possono essere diverse da paese a paese, verificarle con il
proprio rappresentante Yamaha.
* Технические характеристики и их описания в данном руководстве пользователя предназначены
только для общего сведения. Корпорация Yamaha сохраняет за собой право модифицировать свои
изделия и менять их технические характеристики без предварительного уведомления. Поскольку
технические характеристики, оборудование и набор возможностей могут зависеть от региона,
обращайтесь за информацией к местному представителю корпорации Yamaha.
* 本使用说明书中的技术规格及介绍仅供参考。YAMAHA公司保留随时更改或修订产品或技术规格的权利,若
确有更改,恕不事先通知。技术规格、设备或选购件在各个地区可能均会有所不同,因此如有问题,请和当地
YAMAHA经销商确认。
* 仕様および外観は改良のため、予告なく変更することがあります。
32
MY8-LAKE Owner’s Manual
Information for Users on Collection and Disposal of Old Equipment
This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products
should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with
your national legislation and the Directives 2002/96/EC.
By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on
human health and the environment which could otherwise arise from inappropriate waste handling.
For more information about collection and recycling of old products, please contact your local municipality, your waste disposal
service or the point of sale where you purchased the items.
[For business users in the European Union]
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
[Information on Disposal in other Countries outside the European Union]
This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the
correct method of disposal.
Verbraucherinformation zur Sammlung und Entsorgung alter Elektrogeräte
Befindet sich dieses Symbol auf den Produkten, der Verpackung und/oder beiliegenden Unterlagen, so sollten benutzte elektrische
Geräte nicht mit dem normalen Haushaltsabfall entsorgt werden.
In Übereinstimmung mit Ihren nationalen Bestimmungen und den Richtlinien 2002/96/EC bringen Sie alte Geräte bitte zur
fachgerechten Entsorgung, Wiederaufbereitung und Wiederverwendung zu den entsprechenden Sammelstellen.
Durch die fachgerechte Entsorgung der Elektrogeräte helfen Sie, wertvolle Ressourcen zu schützen, und verhindern mögliche
negative Auswirkungen auf die menschliche Gesundheit und die Umwelt, die andernfalls durch unsachgerechte Müllentsorgung
auftreten könnten.
Für weitere Informationen zum Sammeln und Wiederaufbereiten alter Elektrogeräte kontaktieren Sie bitte Ihre örtliche Stadt- oder
Gemeindeverwaltung, Ihren Abfallentsorgungsdienst oder die Verkaufsstelle der Artikel.
[Information für geschäftliche Anwender in der Europäischen Union]
Wenn Sie Elektrogeräte ausrangieren möchten, kontaktieren Sie bitte Ihren Händler oder Zulieferer für weitere Informationen.
[Entsorgungsinformation für Länder außerhalb der Europäischen Union]
Dieses Symbol gilt nur innerhalb der Europäischen Union. Wenn Sie solche Artikel ausrangieren möchten, kontaktieren Sie bitte Ihre örtlichen
Behörden oder Ihren Händler und fragen Sie nach der sachgerechten Entsorgungsmethode.
Information concernant la Collecte et le Traitement des déchets d’équipements électriques et électroniques.
Le symbole sur les produits, l'emballage et/ou les documents joints signifie que les produits électriques ou électroniques usagés ne
doivent pas être mélangés avec les déchets domestiques habituels.
Pour un traitement, une récupération et un recyclage appropriés des déchets d’équipements électriques et électroniques, veuillez
les déposer aux points de collecte prévus à cet effet, conformément à la réglementation nationale et aux Directives 2002/96/EC.
En vous débarrassant correctement des déchets d’équipements électriques et électroniques, vous contribuerez à la sauvegarde de
précieuses ressources et à la prévention de potentiels effets négatifs sur la santé humaine qui pourraient advenir lors d'un
traitement inapproprié des déchets.
Pour plus d'informations à propos de la collecte et du recyclage des déchets d’équipements électriques et électroniques, veuillez
contacter votre municipalité, votre service de traitement des déchets ou le point de vente où vous avez acheté les produits.
[Pour les professionnels dans l'Union Européenne]
Si vous souhaitez vous débarrasser des déchets d’équipements électriques et électroniques veuillez contacter votre vendeur ou fournisseur pour
plus d'informations.
[Information sur le traitement dans d'autres pays en dehors de l'Union Européenne]
Ce symbole est seulement valable dans l'Union Européenne. Si vous souhaitez vous débarrasser de déchets d’équipements électriques et
électroniques, veuillez contacter les autorités locales ou votre fournisseur et demander la méthode de traitement appropriée.
Información para Usuarios sobre Recolección y Disposición de Equipamiento Viejo
Este símbolo en los productos, embalaje, y/o documentación que se acompañe significa que los productos electrónicos y eléctricos
usados no deben ser mezclados con desechos hogareños corrientes.
Para el tratamiento, recuperación y reciclado apropiado de los productos viejos, por favor llévelos a puntos de recolección
aplicables, de acuerdo a su legislación nacional y las directivas 2002/96/EC.
Al disponer de estos productos correctamente, ayudará a ahorrar recursos valiosos y a prevenir cualquier potencial efecto negativo
sobre la salud humana y el medio ambiente, el cual podría surgir de un inapropiado manejo de los desechos.
Para mayor información sobre recolección y reciclado de productos viejos, por favor contacte a su municipio local, su servicio de
gestión de residuos o el punto de venta en el cual usted adquirió los artículos.
[Para usuarios de negocios en la Unión Europea]
Si usted desea deshacerse de equipamiento eléctrico y electrónico, por favor contacte a su vendedor o proveedor para mayor información.
[Información sobre la Disposición en otros países fuera de la Unión Europea]
Este símbolo sólo es válido en la Unión Europea. Si desea deshacerse de estos artículos, por favor contacte a sus autoridades locales y pregunte
por el método correcto de disposición.
Informazioni per gli utenti sulla raccolta e lo smaltimento di vecchia attrezzatura
Questo simbolo sui prodotti, sull’imballaggio, e/o sui documenti che li accompagnano significa che i prodotti elettriche e elettroniche
non dovrebbero essere mischiati con i rifiuti domestici generici.
Per il trattamento, recupero e riciclaggio appropriati di vecchi prodotti, li porti, prego, ai punti di raccolta appropriati, in accordo con
la Sua legislazione nazionale e le direttive 2002/96/CE.
Smaltendo correttamente questi prodotti, Lei aiuterà a salvare risorse preziose e a prevenire alcuni potenziali effetti negativi sulla
salute umana e l'ambiente, che altrimenti potrebbero sorgere dal trattamento improprio dei rifiuti.
Per ulteriori informazioni sulla raccolta e il riciclaggio di vecchi prodotti, prego contatti la Sua amministrazione comunale locale, il
Suo servizio di smaltimento dei rifiuti o il punto vendita dove Lei ha acquistato gli articoli.
[Per utenti imprenditori dell'Unione europea]
Se Lei desidera disfarsi di attrezzatura elettrica ed elettronica, prego contatti il Suo rivenditore o fornitore per ulteriori informazioni.
[Informazioni sullo smaltimento negli altri Paesi al di fuori dell'Unione europea]
Questo simbolo è validi solamente nell'Unione europea. Se Lei desidera disfarsi di questi articoli, prego contatti le Sue autorità locali o il rivenditore e
richieda la corretta modalità di smaltimento.
Yamaha Pro Audio global web site
http://www.yamahaproaudio.com/
Yamaha Manual Library
http://www.yamaha.co.jp/manual/
C.S.G., Pro Audio Division
© 2011 Yamaha Corporation
112MW-A0
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertising
